Asus A9800XT/TVD/256M Graphics Card User Manual

DVI-enabled Flat-Panel Display
VGA Output
S-Video
OR
This reference card
Driver and Utility CD
ASUS Radeon 9800XT/TVD/256M Graphics Card (PAL or NTSC)
Package contents
Projector
S
ASUS VIVO Adapter
S
Projector
VGA Output
®
TM
Frame
Buffer
(DDR)
(Visual Processing Unit)
ATI
Radeon 9800XT
VPU Chip
Frame
Buffer
(DDR)
Frame
Buffer
(DDR)
Frame
Buffer
(DDR)
• Use the same TV standard for all devices.
• Drawings are for reference only. The actual card layout may vary.
NOTES
DVI-I Dual-Link
output (24pins)
Video-in port
TV-out port
(9pins)
VGA Monitor
Output(15pin)
(Standard)
256MB DDR Frame Buffer
ASUS Radeon 9800XT / TVD / 256M Layout
Welcome!
Thank you for purchasing an ASUS® Radeon™ 9800XT Graphics Card!
With this purchase, you join the elite crowd of new generation graphics
enthusiasts.
Powered by the ATI® Radeon™ 9800XT visual processing unit (VPU), this
graphics card provides excellent cinematic resolutions, powerful graphics
acceleration, and sophisticated real-time visual effects to deliver leadingedge graphics performance. The card incorporates state-of-the-art
technologies and a wide stream of ASUS innovations, making it your best
choice to experience dynamic exquisite 3D graphics!
Key Features
•
ATI® Radeon™ 9800XT VPU
•
SMARTSHADER™ 2.1 provides hardware-accelerated support for DirectX® 9.0
programmable vertex and pixel shaders to enable realistic texture and lighting
effects
•
SMOOTHVISION™ 2.1 generates the sharpest and clearest images through full
scene anti-aliasing and anisotropic filtering modes
•
VIDEOSHADER™ integrates shader features to support digital and
high-definition video
•
FULLSTREAM™ removes blocky artifacts from streaming Internet video
•
HYDRAVISION™ provides flexible and user-friendly interface for multiple display
settings
•
ASUS Digital VCR transforms your PC into a TV and VCR in one
•
ASUS SmartDoctor provides power and fan monitoring, memory and chipset
overheating protection, and dynamic overclocking feature
•
ASUS GameFace allows real-time video/audio communication for enhanced
interactive gaming and point-to-point conferencing
•
ASUS VideoSecurity II allows setting up a customized security system
•
ASUS SmartCooling automatically adjusts the card’s power consumption
•
Built-in 128MB Double Data Rate frame buffer provides more resolutions and
color depths of up to 2048x1536 @ 85Hz
•
•
128-bit, 64-bit/32-bit per pixel floating point color formats
AGP 8X support maximizes the 2.1GB/s AGP 8X bandwidth for more realistic
graphics
High-quality TV output for big screen gaming or presentations
•
•
Video input supports real time video capture, high quality video compression,
and video editing
•
DVI, Dual VGA, DVI+VGA, DVI+TV-Out ports for diversified display
connectivity
•
Microsoft® DirectX® 9.0 and OpenGL® 1.4 support
