Asus ROG STRIX Z490-G GAMING (WI-FI) Motherboard User Manual

Motherboard
ROG STRIX
Z490-G
GAMING
(WI-FI)
E16474
Revised Edition V2
March 2020
Copyright © 2020 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by
any means, except documentation kept by the purchaser for backup purposes, without the express
written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN
THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional
data, you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from https://www.asus.com/support/
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
1F., No. 15, Lide Rd.,
Beitou Dist., Taipei City 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notification to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).
ii
Contents
Safety information....................................................................................................... iv
About this guide........................................................................................................... v
ROG STRIX Z490-G GAMING (WI-FI) specifications summary............................... vi
Connectors with shared bandwidth........................................................................... x
Package contents........................................................................................................ xi
Installation tools and components........................................................................... xii
Chapter 1:
Product Introduction
1.1
Before you proceed.................................................................................... 1-1
1.2
Motherboard layout..................................................................................... 1-2
Chapter 2:
2.1
Basic Installation
Building your PC system............................................................................ 2-1
2.1.1
CPU installation........................................................................... 2-1
2.1.2
Cooling system installation.......................................................... 2-3
2.1.3
DIMM installation......................................................................... 2-5
2.1.4
M.2 installation............................................................................. 2-6
2.1.5
Motherboard installation............................................................... 2-8
2.1.6
ATX power connection................................................................. 2-9
2.1.7
SATA device connection............................................................ 2-10
2.1.8
Front I/O connector.................................................................... 2-11
2.1.9
Expansion card installation........................................................ 2-12
2.1.10
Wi-Fi antenna installation........................................................... 2-13
2.2
BIOS update utility.................................................................................... 2-14
2.3
Motherboard rear and audio connections.............................................. 2-15
2.3.1
Rear I/O connection................................................................... 2-15
2.3.2
Audio I/O connections................................................................ 2-16
2.4
Starting up for the first time..................................................................... 2-19
2.5
Turning off the computer......................................................................... 2-19
Chapter 3:
BIOS and RAID Support
3.1
Knowing BIOS............................................................................................. 3-1
3.2
BIOS setup program................................................................................... 3-2
3.3
EZ Update.................................................................................................... 3-2
3.4
ASUS EZ Flash 3......................................................................................... 3-3
3.5
ASUS CrashFree BIOS 3............................................................................. 3-4
3.6
RAID configurations................................................................................... 3-5
Appendix
Notices ..................................................................................................................... A-1
ASUS contact information....................................................................................... A-8
iii
Safety information
Electrical safety
•
To prevent electrical shock hazard, disconnect the power cable from the electrical
outlet before relocating the system.
•
When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
•
Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
•
Seek professional assistance before using an adapter or extension cord. These
devices could interrupt the grounding circuit.
•
Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
•
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
Operation safety
iv
•
Before installing the motherboard and adding devices on it, carefully read all the
manuals that came with the package.
•
Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
•
To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
•
Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
•
Place the product on a stable surface.
•
If you encounter technical problems with the product, contact a qualified service
technician or your retailer.
•
Your motherboard should only be used in environments with ambient temperatures
between 0°C and 40°C.
About this guide
This user guide contains the information you need when installing and configuring the
motherboard.
How this guide is organized
This guide contains the following parts:
•
Chapter 1: Product Introduction
This chapter describes the features of the motherboard and the new technology it
supports. It includes description of the switches, jumpers, and connectors on the
motherboard.
•
Chapter 2: Basic Installation
This chapter lists the hardware setup procedures that you have to perform when
installing system components.
•
Chapter 3: BIOS and RAID Support
This chapter tells how to boot into the BIOS, upgrade BIOS using the EZ Flash Utility
and support on RAID.
Where to find more information
Refer to the following sources for additional information and for product and software
updates.
1.
ASUS website
The ASUS website (www.asus.com) provides updated information on ASUS hardware
and software products.
2.
Optional documentation
Your product package may include optional documentation, such as warranty flyers,
that may have been added by your dealer. These documents are not part of the
standard package.
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
CAUTION: Information to prevent damage to the components and injuries to
yourself when trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
v
ROG STRIX Z490-G GAMING (WI-FI) specifications
summary
Intel® Socket LGA1200 for 10th Gen Intel® Core™, Pentium® Gold and
Celeron® processors*
Supports Intel® 14 nm CPU
CPU
Supports Intel ® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max
Technology 3.0**
* Refer to www.asus.com for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset
Intel® Z490 Chipset
4 x DIMM, Max. 128GB, DDR4 4600(O.C) / 4500(O.C) / 4400(O.C) /
4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) /
3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) /
3200(O.C.) / 3000(O.C.) / 2933(O.C.) / 2800(O.C.) / 2666 / 2400 /
2133 MHz Non-ECC, Un-buffered Memory*
Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II
* 10th Gen Intel® Core™ i9/i7 CPUs support 2933/2800/2666/2400/2133 natively.
Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
1 x DisplayPort 1.4*
Graphics
1 x HDMI™ 1.4b
* Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please
refer to www.intel.com for any update.
* Graphics specifications may vary between CPU types.
Intel® 10th Gen Processors*
1 x PCIe 3.0 x16 slot (supports x16 mode)
Intel® Z490 Chipset
Expansion Slots
1 x PCIe 3.0 x16 slot (supports x4 mode)**
1 x PCIe 3.0 x1 slot
* Support PCIe bifurcation for RAID on CPU function.
** When PCIe 3.0 x16_2 runs at x4 mode, SATA6G_56 will be disabled.
Multi-GPU support
Supports AMD 2-Way CrossFireX™ Technology
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel® Z490 Chipset
M.2_1 slot (Key M), type 2242/2260/2280/22110
(supports PCIe 3.0 x4 modes)
Storage
M.2_2 slot (Key M), type 2242/2260/2280
(supports PCIe 3.0 x4 & SATA modes)*
6 x SATA 6Gb/s ports
Intel® Rapid Storage Technology supports Raid 0,1,5,10
Intel® Optane™ Memory Ready
* M.2_2 shares bandwidth with SATA6G_2. When M.2_2 runs SATA mode,
SATA6G_2 will be disabled.
Ethernet
1 x Intel® I225-V Ethernet
ASUS LANGuard
(continued on the next page)
vi
ROG STRIX Z490-G GAMING (WI-FI) specifications
summary
Intel® Wi-Fi 6 AX201
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO
Supports up to 2.4Gbps max data rate
Wireless & Bluetooth
Supports 2.4/5GHz Dual-Band
Supports channel bandwidth: HT20/HT40/HT80/HT160
Supports CNVI interface
Bluetooth v5.1*
* BT 5.1 function will be ready in Windows 10 build 19041 or later.
Rear USB (Total 8 ports)
2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C®)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
USB
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 7 ports)
1 x USB 3.2 Gen 2 Front Panel connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
- Impedance sense for front and rear headphone outputs
- Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR
recording input
- Supports up to 32-Bit/192kHz playback*
Audio
Audio Features:
- SupremeFX Shielding Technology
- Dual OP Amplifiers
- Rear optical S/PDIF out port
- Premium Japanese audio capacitors
- Audio cover
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio.
2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C®)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 port(s) (2 x Type-A)
1 x DisplayPort
Back Panel I/O Ports
1 x HDMI™ port
1 x ASUS Wi-Fi Module
1 x Intel® I225-V Ethernet port
5 x Gold-plated audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™ button
(continued on the next page)
vii
ROG STRIX Z490-G GAMING (WI-FI) specifications
summary
Fan and cooling related
1 x 4-Pin CPU Fan header
1 x 4-Pin CPU OPT Fan header
2 x 4-Pin Chassis Fan headers
1 x W_PUMP+ header
1 x VRM heatsink Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
1 x 4-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
Internal I/O connectors
6 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 2 Front Panel connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous
2 x AURA Addressable Gen 2 headers
2 x AURA RGB headers
1 x Clear CMOS header
1 x CPU Over Voltage Jumper
1 x Front Panel Audio header (AAFP)
1 x 20-5 pin System Panel header
1 x Thermal Sensor header
Extreme Engine Digi+
- 5K Black Metallic Capacitors
- ON-semi NCP302045
- MicroFine Alloy Choke
ASUS Q-Design
- ASUS Q-DIMM
- ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device
[yellow green])
Special Features
- ASUS Q-Slot
ASUS Thermal Solution
- Aluminum M.2 heatsink
- Aluminum heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- Procool II
- Pre-mounted I/O shield
- SafeSlot
(continued on the next page)
viii
ROG STRIX Z490-G GAMING (WI-FI) specifications
summary
AURA Sync
Special Features
- Standard RGB headers
- Addressable Gen 2 RGB headers
ROG Exclusive Software
- RAMCache III
- ROG CPU-Z
- GameFirst VI
- Sonic Studio III + Sonic Studio Virtual Mixer
- Sonic Radar III
- DTS® Sound Unbound
- Overwolf
- Anti-virus software
ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
AI Suite 3
Software Features
- 5-Way Optimization with AI Overclocking
TPU
EPU
Digi+ VRM
Xpert 4
Turbo app
- EZ update
AI Charger
WinRAR
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
FlexKey
BIOS
192 (128+64) Mb Flash ROM, UEFI AMI BIOS
Manageability
WOL by PME, PXE
Operating System
Form Factor
Windows® 10 - 64 bit
Micro ATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm)
Specifications are subject to change without notice. Please refer to the ASUS website for
the latest specifications.
ix
Connectors with shared bandwidth
B
B
A
A
Configuration
A
1 (Default)
2
PCIEX16_2
x2
x4
SATA6G_56
V
-
1 (Default)
2
PCIe mode
SATA mode
V
-
Configuration
B
x
M.2_2
SATA6G_2
•
When PCIe 3.0 x16_2 runs at x4 mode, SATA6G_56 will be disabled.
•
M.2_2 shares bandwidth with SATA6G_2. When M.2_2 runs SATA mode,
SATA6G_2 will be disabled.
•
Please adjust BIOS setting for changing onboard device configuration.
Package contents
Check your motherboard package for the following items.
Motherboard
1 x ROG STRIX Z490-G GAMING (WI-FI) motherboard
1 x Addressable RGB extension cable
Cables
1 x RGB extension cable
4 x SATA 6Gb/s cables
1 x Cable ties pack
1 x M.2 Rubber package
Miscellaneous
1 x M.2 SSD screw package(s)
1 x ROG Strix stickers
1 x ROG Strix thank you card
1 x ASUS 2x2 dual band Wi-Fi moving antennas
Installation Media
1 x Support DVD
Documentation
1 x User manual
If any of the above items is damaged or missing, contact your retailer.
xi
Installation tools and components
Phillips (cross) screwdriver
PC chassis
Power supply unit
Intel® LGA 1200 CPU
Intel® LGA 1200 compatible CPU Fan
DDR4 DIMM
SATA hard disk drive
SATA optical disc drive (optional)
Graphics card (optional)
M.2 SSD module (optional)
1 Bag of screws
The tools and components in the table above are not included in the motherboard
package.
xii
Product Introduction
Product Introduction
1.1
Before you proceed
1
Chapter 1
Chapter 1:
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
•
Unplug the power cord from the wall socket before touching any component.
•
Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
•
Hold components by the edges to avoid touching the ICs on them.
•
Whenever you uninstall any component, place it on a grounded antistatic pad or in
the bag that came with the component.
•
Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
ROG STRIX Z490-G GAMING (WI-FI)
1-1
1.2
Motherboard layout
Chapter 1
1-2
Chapter 1: Product Introduction
ROG STRIX Z490-G GAMING (WI-FI)
Page
1-4
1-5
1-7
1-8
1-10
1-10
1-11
1-12
1-12
1-13
1-13
1-14
1-15
1-16
1-17
1-17
1-18
1-19
1-19
1-20
Chapter 1
Layout contents
1. CPU socket
2. DIMM slots
3. Expansion slots
4. Fan and Pump headers
5. VRM Heatsink Fan header
6. Power connectors
7. M.2 slot
8. SATA 6GB/s ports
9. USB 3.2 Gen 2 Front Panel connector
10. USB 3.2 Gen 1 header
11. USB 2.0 header
12. AURA Addressable Gen2 header
13. AURA RGB header
14. Clear CMOS header
15. CPU Over Voltage jumper
16. Front Panel Audio header
17. System Panel header
18. Thermal Sensor header
19. Q-LEDs
20. 8-pin Power Plug LED
1-3
1.
CPU socket
The motherboard comes with a LGA1200 socket designed for 10th Gen Intel® Core™,
Pentium® Gold and Celeron® processors.
Chapter 1
1-4
•
Ensure that you install the correct CPU designed for LGA1200 socket only. DO NOT
install a CPU designed for other sockets on the LGA1200 socket.
•
The CPU fits in only one correct orientation. DO NOT force the CPU into the socket
to prevent bending the connectors on the socket and damaging the CPU.
•
Ensure that all power cables are unplugged before installing the CPU.
•
Upon purchase of the motherboard, ensure that the PnP cap is on the socket and
the socket contacts are not bent. Contact your retailer immediately if the PnP cap
is missing, or if you see any damage to the PnP cap/socket contacts/motherboard
components. ASUS will shoulder the cost of repair only if the damage is shipment/
transit-related.
•
Keep the cap after installing the motherboard. ASUS will process Return
Merchandise Authorization (RMA) requests only if the motherboard comes with the
cap on the LGA1200 socket.
•
The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the
PnP cap.
Chapter 1: Product Introduction
2.
DIMM slots
The motherboard comes with Dual Inline Memory Modules (DIMM) slots designed for DDR4
(Double Data Rate 4) memory modules.
Chapter 1
A DDR4 memory module is notched differently from a DDR, DDR2, or DDR3 module. DO
NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.
Recommended memory configurations
ROG STRIX Z490-G GAMING (WI-FI)
1-5
Memory configurations
You may install 4 GB, 8 GB, 16 GB, and 32 GB unbuffered and non‑ECC DDR4 DIMMs into
the DIMM sockets.
Chapter 1
You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel configuration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
1-6
•
The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value.
•
For system stability, use a more efficient memory cooling system to support a full
memory load or overclocking condition.
•
Always install the DIMMS with the same CAS Latency. For an optimum compatibility,
we recommend that you install memory modules of the same version or data code
(D/C) from the same vendor. Check with the vendor to get the correct memory
modules.
•
Visit the ASUS website for the latest QVL.
Chapter 1: Product Introduction
3.
Expansion slots
Chapter 1
Unplug the power cord before adding or removing expansion cards. Failure to do so may
cause you physical injury and damage motherboard components.
Please refer to the following tables for the recommended VGA configuration and Hyper M.2
configuration.
ROG STRIX Z490-G GAMING (WI-FI)
1-7
Recommended VGA configuration
Chapter 1
Slot Description
1. PCIe 3.0 x16_1
3. PCIe 3.0 x16_2
Single VGA
x16
N/A
Dual VGA
X16
x4
•
We recommend that you provide sufficient power when running CrossFireX™ mode.
•
Ensure to connect the 8-pin and 4-pin power plugs when running CrossFireX™
mode.
•
Connect a chassis fan to the chassis fan connectors when using multiple graphics
cards for better thermal environment.
Hyper M.2 X16 series card configuration
Slot Description
1.
1-8
PCIe 3.0 x16_1
Up to 3 Intel® SSD on CPU support
x8+x4+x4
•
Hyper M.2 X16 series card is purchased separately.
•
When using up to 3 intel® SSD on CPU support, if you wish to connect a display, we
suggest using the internal VGA, or installing a VGA card to PCIe x16_2, which will
run at x4.
•
Enable the Hyper M.2 X16 series card under BIOS settings.
Chapter 1: Product Introduction
4.
Fan and Pump headers
Chapter 1
The Fan and Pump headers allow you to connect fans or pumps to cool the system.
•
DO NOT forget to connect the fan cables to the fan headers. Insufficient air flow
inside the system may damage the motherboard components. These are not
jumpers! Do not place jumper caps on the fan headers!
•
Ensure the cable is fully inserted into the header.
For water cooling kits, connect the pump connector to the W_PUMP+ header.
Header
CPU_FAN
CPU_OPT
CHA_FAN1
CHA_FAN2
VRM_HS_FAN
W_PUMP+
Max. Current
1A
1A
1A
1A
1A
3A
Max. Power
12W
12W
12W
12W
12W
36W
ROG STRIX Z490-G GAMING (WI-FI)
Default Speed
Q-Fan Controlled
Q-Fan Controlled
Q-Fan Controlled
Q-Fan Controlled
Q-Fan Controlled
Full-Speed
Shared Control
A
A
-
1-9
5.
VRM Heatsink fan header
The VRM Heatsink fan header is for connecting the VRM Heatsink fan on the
integrated heatsink.
Chapter 1
1-10
Chapter 1: Product Introduction
6.
Power connectors
Chapter 1
These Power connectors allow you to connect your motherboard to a power supply.
The power supply plugs are designed to fit in only one orientation, find the proper
orientation and push down firmly until the power supply plugs are fully inserted.
Ensure to connect the 8-pin power plug.
•
For a fully configured system, we recommend that you use a power supply unit
(PSU) that complies with ATX 12V Specification 2.0 (or later version) and provides a
minimum power of 350 W.
•
We recommend that you use a PSU with a higher power output when configuring a
system with more power-consuming devices. The system may become unstable or
may not boot up if the power is inadequate.
•
If you want to use two or more high-end PCI Express x16 cards, use a PSU with
1000W power or above to ensure the system stability.
ROG STRIX Z490-G GAMING (WI-FI)
1-11
7.
M.2 slot
The M.2 slot allows you to install M.2 SSD modules.
Chapter 1
•
M.2_1 slot supports PCIe 3.0 x4 mode Key M design and type 2242 / 2260/ 2280 /
22110 storage devices.
•
M.2_2 slot supports PCIe 3.0 x4 and SATA mode Key M design and type 2242 /
2260 / 2280 storage devices.
•
M.2 slots supports IRST (Intel® Rapid Storage Technology).
The M.2 SSD module is purchased separately.
1-12
Chapter 1: Product Introduction
8.
SATA 6Gb/s ports
Chapter 1
The SATA 6Gb/s ports allows you to connect SATA devices such as optical disc
drives and hard disk drives via a SATA cable.
If you installed SATA storage devices, you can create a RAID 0, 1, 5, and 10 configuration
with the Intel® Rapid Storage Technology through the onboard Intel® Z490 chipset.
9.
•
The slots are set to [AHCI] by default. If you intend to create a SATA RAID set using
these connectors, set the SATA Mode item in the BIOS to [Intel RST Premium with
Intel Optane System Acceleration (RAID)].
•
Before creating a RAID set, refer to the RAID Configuration Guide. You can
download the RAID Configuration Guide from the ASUS website.
USB 3.2 Gen 2 Front Panel connector
The USB 3.2 Gen 2 connector allows you to connect a USB 3.2 Gen 2 module for
additional USB 3.2 Gen 2 ports. The USB 3.2 Gen 2 connector provides data transfer
speeds of up to 10 Gb/s.
The USB 3.2 Gen 2 module is purchased separately.
ROG STRIX Z490-G GAMING (WI-FI)
1-13
10.
USB 3.2 Gen 1 header
The USB 3.2 Gen 1 header allows you to connect a USB 3.2 Gen 1 module for
additional USB 3.2 Gen 1 ports. The USB 3.2 Gen 1 header provides data transfer
speeds of up to 5 Gb/s.
Chapter 1
The USB 3.2 Gen 1 module is purchased separately.
11.
USB 2.0 header
The USB 2.0 header allows you to connect a USB module for additional USB
2.0 ports. The USB 2.0 header provides data transfer speeds of up to 480 Mb/s
connection speed.
DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the
motherboard!
The USB 2.0 module is purchased separately.
1-14
Chapter 1: Product Introduction
12.
AURA Addressable Gen2 header
Chapter 1
The Addressable Gen2 header allows you to connect individually addressable RGB
WS2812B LED strips or WS2812B based LED strips.
The Addressable Gen2 header supports WS2812B addressable RGB LED strips (5V/
Data/Ground), with a maximum power rating of 3A (5V), and the addressable headers on
this board can handle a combined maximum of 500 LEDs.
Before you install or remove any component, ensure that the power supply is switched off
or the power cord is detached from the power supply. Failure to do so may cause severe
damage to the motherboard, peripherals, or components.
•
Actual lighting and color will vary with LED strip.
•
If your LED strip does not light up, check if the addressable RGB LED strip is
connected in the correct orientation, and the 5V connector is aligned with the 5V
header on the motherboard.
•
The addressable RGB LED strip will only light up when the system is powered on.
•
The addressable RGB LED strip is purchased separately.
ROG STRIX Z490-G GAMING (WI-FI)
1-15
13.
AURA RGB header
The AURA RGB header allows you to connect RGB LED strips.
Chapter 1
The AURA RGB header supports 5050 RGB multi-color LED strips (12V/G/R/B), with a
maximum power rating of 3A (12V).
Before you install or remove any component, ensure that the power supply is switched off
or the power cord is detached from the power supply. Failure to do so may cause severe
damage to the motherboard, peripherals, or components.
1-16
•
Actual lighting and color will vary with LED strip.
•
If your LED strip does not light up, check if the RGB LED extension cable and the
RGB LED strip is connected in the correct orientation, and the 12V connector is
aligned with the 12V header on the motherboard.
•
The LED strip will only light up when the system is powered on.
•
The LED strip is purchased separately.
Chapter 1: Product Introduction
14.
Clear CMOS header
Chapter 1
The Clear CMOS header allows you to clear the Real Time Clock (RTC) RAM in
the CMOS, which contains the date, time, system passwords, and system setup
parameters.
To erase the RTC RAM:
1.
Turn OFF the computer and unplug the power cord.
2.
Short-circuit pin 1-2 with a metal object or jumper cap for about 5-10 seconds.
3.
Plug the power cord and turn ON the computer.
4.
Hold down the <Del> key during the boot process and enter BIOS setup to
re-enter data.
DO NOT short-circuit the pins except when clearing the RTC RAM. Short-circuiting or
placing a jumper cap will cause system boot failure!
If the steps above do not help, remove the onboard button cell battery and move the
jumper again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the
button cell battery.
ROG STRIX Z490-G GAMING (WI-FI)
1-17
15.
CPU Over Voltage jumper
Chapter 1
The CPU Over Voltage jumper allows you to set a higher CPU voltage for a flexible
overclocking system (depending on the type of the installed CPU). Set to pins 2-3 to
increase the CPU voltage setting, or set to pins 1-2 to use the default CPU voltage
setting.
16.
Front Panel Audio header
The front panel audio header is for a chassis-mounted front panel audio I/O module
that supports HD Audio. Connect one end of the front panel audio I/O module cable to
this header.
We recommend that you connect a high-definition front panel audio module to this
connector to avail of the motherboard’s high-definition audio capability.
1-18
Chapter 1: Product Introduction
17.
System Panel header
Chapter 1
The System Panel header supports several chassis-mounted functions.
•
System Power LED header (PLED)
The 2-pin header allows you to connect the System Power LED. The System Power
LED lights up when the system is connected to a power source, or when you turn on
the system power, and blinks when the system is in sleep mode.
•
Storage Device Activity LED header (HDD_LED)
The 2-pin header allows you to connect the Storage Device Activity LED. The Storage
Device Activity LED lights up or blinks when data is read from or written to the storage
device or storage device add-on card.
•
System Warning Speaker header (SPEAKER)
The 4-pin header allows you to connect the chassis-mounted system warning
speaker. The speaker allows you to hear system beeps and warnings.
•
Power Button/Soft-off Button header (PWRSW)
The 3-1 pin header allows you to connect the system power button. Press the
power button to power up the system, or put the system into sleep or soft-off mode
(depending on the operating system settings).
•
Reset button header (RESET)
The 2-pin header allows you to connect the chassis-mounted reset button. Press the
reset button to reboot the system.
ROG STRIX Z490-G GAMING (WI-FI)
1-19
18.
Thermal Sensor header
Chapter 1
The Thermal Sensor header allows you to connect a sensor to monitor the
temperature of the devices and the critical components inside the motherboard.
Connect the thermal sensor and place it on the device or the motherboard’s
component to detect its temperature.
The thermal sensor is purchased separately.
19.
Q-LEDs
The Q-LEDs check key components (CPU, DRAM, VGA, and booting devices) during
the motherboard booting process. If an error is found, the critical component’s LED
stays lit up until the problem is solved.
The Q-LEDs provide the most probable cause of an error code as a starting point for
troubleshooting. The actual cause may vary from case to case.
1-20
Chapter 1: Product Introduction
20.
8-pin Power Plug LED
Chapter 1
The 8-pin Power Plug LED lights up to indicate that the 8-pin power plug is not
connected.
ROG STRIX Z490-G GAMING (WI-FI)
1-21
Chapter 1
1-22
Chapter 1: Product Introduction
Chapter 2:
Basic Installation
Basic Installation
2.1
Building your PC system
2
The diagrams in this section are for reference only. The motherboard layout may vary with
models, but the installation steps are the same for all models.
CPU installation
•
Ensure that you install the correct CPU designed for LGA1200 socket only. DO
NOT install a CPU designed for LGA1155, LGA1156, and LGA1151 sockets on the
LGA1200 socket.
•
ASUS will not cover damages resulting from incorrect CPU installation/removal,
incorrect CPU orientation/placement, or other damages resulting from negligence by
the user.
ROG STRIX Z490-G GAMING (WI-FI)
Chapter 2
2.1.1
2-1
Chapter 2
2-2
Chapter 2: Basic Installation
2.1.2
Cooling system installation
Apply Thermal Interface Material to the
CPU cooling system and CPU before you
install the cooling system, if necessary.
Chapter 2
To install a CPU heatsink and fan assembly
ROG STRIX Z490-G GAMING (WI-FI)
2-3
To install an AIO cooler
If you wish to install an AIO cooler, we recommend installing the AIO cooler after installing
the motherboard into the chassis.
Chapter 2
W_PUMP+
CPU_FAN
CPU_OPT
2-4
Chapter 2: Basic Installation
DIMM installation
Chapter 2
2.1.3
To remove a DIMM
ROG STRIX Z490-G GAMING (WI-FI)
2-5
2.1.4
M.2 installation
1
2
1
Chapter 2
•
The M.2 rubber pad
is optional for when
installing a single
sided M.2 storage
device. Ensure to
install the bundled
M.2 rubber pad before
installing your single
sided M.2 storage
device.
•
DO NOT install the
bundled M.2 rubber
pads when installing
a double-sided M.2
storage device.
The rubber pad
installed by default
is compatible with
double sided M.2
storage devices.
3
OPTIONAL
5
4
4
2-6
Chapter 2: Basic Installation
8
7
8
6
Chapter 2
The M.2 is purchased separately.
ROG STRIX Z490-G GAMING (WI-FI)
2-7
2.1.5
Motherboard installation
Chapter 2
1.
Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to
the chassis’ rear I/O panel.
2.
Place eight (8) screws into the holes indicated by circles to secure the motherboard to
the chassis.
DO NOT over tighten the screws! Doing so can damage the motherboard.
2-8
Chapter 2: Basic Installation
ATX power connection
Chapter 2
2.1.6
OR
AND
•
DO NOT connect the 4-pin power plug only, the motherboard may overheat under
heavy usage.
•
Ensure to connect the 8-pin power plug, or connect both the 8-pin and 4-pin power
plugs.
ROG STRIX Z490-G GAMING (WI-FI)
2-9
2.1.7
SATA device connection
OR
Chapter 2
2-10
Chapter 2: Basic Installation
2.1.8
Front I/O connector
To install front panel connector
To install USB 3.2 Gen 2 connector
USB 3.2 Gen 2
To install USB 3.2 Gen 1 connector
Chapter 2
This connector will only fit in one
orientation. Push the connector until it
clicks into place.
To install USB 2.0 connector
USB 3.2 Gen 1
USB 2.0
To install front panel audio connector
AAFP
ROG STRIX Z490-G GAMING (WI-FI)
2-11
2.1.9
Expansion card installation
To install PCIe x16 cards
Chapter 2
To install PCIe x1 cards
2-12
Chapter 2: Basic Installation
2.1.10
Wi-Fi antenna installation
Installing the ASUS 2x2 dual band W-Fi antenna
Chapter 2
Connect the bundled ASUS 2x2 dual band Wi-Fi antenna connector to the Wi-Fi ports at the
back of the chassis.
•
Ensure that the ASUS 2x2 dual band Wi-Fi antenna is securely installed to the Wi-Fi
ports.
•
Ensure that the antenna is at least 20 cm away from all persons.
The illustration above is for reference only. The I/O port layout may vary with models, but
the Wi-Fi antenna installation procedure is the same for all models.
ROG STRIX Z490-G GAMING (WI-FI)
2-13
2.2
BIOS update utility
BIOS FlashBack™
BIOS FlashBack™ allows you to easily update the BIOS without entering the existing BIOS
or operating system. Simply insert a USB storage device to the USB port (the USB port hole
is marked on the I/O shield) then press the BIOS FlashBack™ button for three seconds to
automatically update the BIOS.
To use BIOS FlashBack™:
1.
Insert a USB storage device to the BIOS FlashBack™ port.
We recommend you to use a USB 2.0 storage device to save the latest BIOS version for
better compatibility and stability.
Chapter 2
2.
Visit https://www.asus.com/support/ and download the latest BIOS version for this
motherboard.
3.
Manually rename the file as SZ490GW.CAP, or launch the BIOSRenamer.exe
application to automatically rename the file, then copy it to your USB storage device.
The BIOSRenamer.exe application is zipped together with your BIOS file when you
download a BIOS file for a BIOS FlashBack™ compatible motherboard.
4.
Shut down your computer.
5.
Press the BIOS FlashBack™ button for three seconds until the BIOS FlashBack™
LED blinks three times, indicating that the BIOS FlashBack™ function is enabled.
BIOS FlashBack™ port
6.
BIOS FlashBack™ button
Wait until the light goes out, indicating that the BIOS updating process is completed.
For more BIOS update utilities in BIOS setup, refer to the section Updating BIOS in
Chapter 3.
2-14
•
Do not unplug portable disk, power system, or short the CLRTC header while BIOS
update is ongoing, otherwise update will be interrupted. In case of interruption,
please follow the steps again.
•
If the light flashes for five seconds and turns into a solid light, this means that the
BIOS FlashBack™ is not operating properly. This may be caused by improper
installation of the USB storage device and filename/file format error. If this scenario
happens, please restart the system to turn off the light.
•
Updating BIOS may have risks. If the BIOS program is damaged during the process
and results to the system’s failure to boot up, please contact your local ASUS Service
Center.
Chapter 2: Basic Installation
Motherboard rear and audio connections
2.3.1
Rear I/O connection
Chapter 2
2.3
Rear panel connectors
1.
2.
3.
4.
5.
6.
7.
8.
DisplayPort
USB 3.2 Gen 1 Type-A ports 1, 2, 9 and 10
Intel® I225-V Ethernet port
HDMI™ port
USB 2.0 ports 11 and 12
BIOS FlashBack™ button
USB 3.2 Gen 2 Type-A port 3
USB 3.2 Gen 2 Type-C® port C4
9.
Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth V5.1
10.
Optical S/PDIF out port
11.
Gold-plated audio jacks*
* Refer to the table on the next page for audio port definitions.
•
We strongly recommend that you connect your devices to ports with matching
data transfer rate. Please connect your USB 3.2 Gen 1 devices to USB 3.2 Gen 1
ports and your USB 3.2 Gen 2 devices to USB 3.2 Gen 2 ports for faster and better
performance for your devices.
•
Due to the design of the Intel chipset, all USB devices connected to the USB 3.2 Gen
1 ports are controlled by the xHCI controller. Some legacy USB devices must update
their firmware for better compatibility.
ROG STRIX Z490-G GAMING (WI-FI)
2-15
* Audio 2, 4, 5.1 or 7.1-channel configuration
4-channel
5.1-channel
7.1-channel
Light Blue
Lime
Pink
Orange
Headset
2-channel
Line In
Line Out
Mic In
–
Line In
Front Speaker Out
Mic In
–
Black
–
Rear Speaker Out
Line In
Front Speaker Out
Mic In
Center/Sub
woofer
Rear Speaker Out
Side Speaker Out
Front Speaker Out
Mic In
Center/Sub
woofer
Rear Speaker Out
Port
2.3.2
Audio I/O connections
Chapter 2
Audio I/O ports
Connect to Headphone and Mic
Connect to Stereo Speakers
2-16
Chapter 2: Basic Installation
Connect to 2-channel Speakers
Chapter 2
Connect to 4-channel Speakers
Connect to 5.1-channel Speakers
ROG STRIX Z490-G GAMING (WI-FI)
2-17
Connect to 7.1-channel Speakers
Chapter 2
2-18
Chapter 2: Basic Installation
2.4
Starting up for the first time
1.
After making all the connections, replace the system case cover.
2.
Ensure that all switches are off.
3.
Connect the power cord to the power connector at the back of the system chassis.
4.
Connect the power cord to a power outlet that is equipped with a surge protector.
5.
Turn on the devices in the following order:
Monitor
b.
External storage devices (starting with the last device on the chain)
c.
System power
After applying power, the system power LED on the system front panel case lights
up. For systems with ATX power supplies, the system LED lights up when you press
the ATX power button. If your monitor complies with the “green” standards or if it has
a “power standby” feature, the monitor LED may light up or change from orange to
green after the system LED turns on.
Chapter 2
6.
a.
The system then runs the power-on self tests (POST). While the tests are running,
the BIOS beeps (refer to the BIOS beep codes table) or additional messages appear
on the screen. If you do not see anything within 30 seconds from the time you turned
on the power, the system may have failed a power-on test. Check the jumper settings
and connections or call your retailer for assistance.
7.
2.5
BIOS Beep
Description
One short beep
VGA detected
Quick boot set to disabled
No keyboard detected
One continuous beep followed by two
short beeps then a pause (repeated)
No memory detected
One continuous beep followed by three
short beeps
No VGA detected
One continuous beep followed by four
short beeps
Hardware component failure
At power on, hold down the <Delete> key to enter the BIOS Setup. Follow the
instructions in Chapter 3.
Turning off the computer
While the system is ON, press the power button for less than four seconds to put the system
on sleep mode or soft-off mode, depending on the BIOS setting. Press the power button
for more than four seconds to let the system enter the soft-off mode regardless of the BIOS
setting.
ROG STRIX Z490-G GAMING (WI-FI)
2-19
Chapter 2
2-20
Chapter 2: Basic Installation
Chapter 3:
BIOS and RAID Support
BIOS and RAID Support
3
For more details on BIOS and RAID configurations, please refer to www.asus.com/
support.
3.1
Knowing BIOS
The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI
architecture, offering a user-friendly interface that goes beyond the traditional keyboardonly BIOS controls to enable a more flexible and convenient mouse input. You can easily
navigate the new UEFI BIOS with the same smoothness as your operating system. The
term “BIOS” in this user manual refers to “UEFI BIOS” unless otherwise specified.
•
An error message appears on the screen during the system bootup and requests you
to run the BIOS Setup.
•
You have installed a new system component that requires further BIOS settings or
update.
Chapter 3
BIOS (Basic Input and Output System) stores system hardware settings such as storage
device configuration, overclocking settings, advanced power management, and boot
device configuration that are needed for system startup in the motherboard CMOS. In
normal circumstances, the default BIOS settings apply to most conditions to ensure
optimal performance. DO NOT change the default BIOS settings except in the following
circumstances:
Inappropriate BIOS settings may result to instability or boot failure. We strongly
recommend that you change the BIOS settings only with the help of a trained
service personnel.
•
When downloading or updating the BIOS file, rename it as SZ490GW.CAP for this
motherboard.
•
BIOS settings and options may vary due to different BIOS release versions. Please
refer to the latest BIOS version for settings and options.
ROG STRIX Z490-G GAMING (WI-FI)
3-1
3.2
BIOS setup program
Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screen
include navigation keys and brief onscreen help to guide you in using the BIOS Setup
program.
Entering BIOS at startup
To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test
(POST). If you do not press <Delete> or <F2>, POST continues with its routines.
Entering BIOS Setup after POST
To enter BIOS Setup after POST:
•
Press <Ctrl>+<Alt>+<Delete> simultaneously.
•
Press the reset button on the system chassis.
•
Press the power button to turn the system off then back on. Do this option only if you
failed to enter BIOS Setup using the first two options.
After doing either of the three options, press <Delete> key to enter BIOS.
•
Ensure that a USB mouse is connected to your motherboard if you want to use the
mouse to control the BIOS setup program.
•
If the system becomes unstable after changing any BIOS setting, load the default
settings to ensure system compatibility and stability. Select the Load Optimized
Defaults item under the Exit menu or press hotkey <F5>.
•
If the system fails to boot after changing any BIOS setting, try to clear the CMOS and
reset the motherboard to the default value.
•
The BIOS setup program does not support Bluetooth devices.
Chapter 3
BIOS menu screen
The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode.
You can change modes from Setup Mode in Boot menu or by pressing the <F7> hotkey.
3.3
EZ Update
The EZ Update is a utility that allows you to update the motherboard BIOS in Windows®
environment.
3-2
•
EZ Update requires an Internet connection either through a network or an ISP
(Internet Service Provider).
•
This utility is available in the support USB drive that comes with the motherboard
package.
Chapter 3: BIOS Setup
3.4
ASUS EZ Flash 3
The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS‑based
utility.
Ensure to load the BIOS default settings to ensure system compatibility and stability.
Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.
To update the BIOS:
•
This function can support devices such as a USB flash disk with FAT 32/16 format
and single partition only.
•
DO NOT shut down or reset the system while updating the BIOS to prevent system
boot failure!
Insert the USB flash disk that contains the latest BIOS file to the USB port.
2.
Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select
ASUS EZ Flash 3 Utility and press <Enter>.
3.
Press <Tab> to switch to the Drive field.
4.
Press the Up/Down arrow keys to find the USB flash disk that contains the latest
BIOS, and then press <Enter>.
5.
Press <Tab> to switch to the Folder field.
6.
Press the Up/Down arrow keys to find the BIOS file, and then press <Enter> to
perform the BIOS update process. Reboot the system when the update process is
done.
Chapter 3
1.
ROG STRIX Z490-G GAMING (WI-FI)
3-3
3.5
ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the
BIOS file when it fails or gets corrupted during the updating process. You can restore a
corrupted BIOS file using the motherboard support DVD or a USB flash drive that contains
the BIOS file.
The BIOS file in the motherboard support DVD may be older than the BIOS file published
on the ASUS official website. If you want to use the newer BIOS file, download the file at
https://www.asus.com/support/ and save it to a USB flash drive.
Recovering the BIOS
To recover the BIOS:
1.
Turn on the system.
2.
Insert the motherboard support DVD to the optical drive, or the USB flash drive
containing the BIOS file to the USB port.
3.
The utility automatically checks the devices for the BIOS file. When found, the utility
reads the BIOS file and enters ASUS EZ Flash 3 automatically.
4.
The system requires you to enter BIOS Setup to recover the BIOS setting. To ensure
system compatibility and stability, we recommend that you press <F5> to load default
BIOS values.
DO NOT shut down or reset the system while updating the BIOS! Doing so can cause
system boot failure!
Chapter 3
3-4
Chapter 3: BIOS Setup
3.6
RAID configurations
The motherboard comes with the Intel® Rapid Storage Technology that supports RAID 0,
RAID 1, RAID 5 and RAID 10 configuration.
For more information on configuring your RAID sets, please
refer to the RAID Configuration Guide which you can find at
https://www.asus.com/support, or by scanning the QR code.
RAID definitions
RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in
parallel, interleaved stacks. Two hard disks perform the same work as a single drive but at a
sustained data transfer rate, double that of a single disk alone, thus improving data access
and storage. Use of two new identical hard disk drives is required for this setup.
RAID 1 (Data mirroring) copies and maintains an identical image of data from one drive to
a second drive. If one drive fails, the disk array management software directs all applications
to the surviving drive as it contains a complete copy of the data in the other drive. This RAID
configuration provides data protection and increases fault tolerance to the entire system.
Use two new drives or use an existing drive and a new drive for this setup. The new drive
must be of the same size or larger than the existing drive.
RAID 5 stripes both data and parity information across three or more hard disk drives.
Among the advantages of RAID 5 configuration include better HDD performance, fault
tolerance, and higher storage capacity. The RAID 5 configuration is best suited for
transaction processing, relational database applications, enterprise resource planning, and
other business systems. Use a minimum of three identical hard disk drives for this setup.
ROG STRIX Z490-G GAMING (WI-FI)
Chapter 3
RAID 10 is data striping and data mirroring combined without parity (redundancy data)
having to be calculated and written. With the RAID 10 configuration you get all the benefits
of both RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing
drive and three new drives for this setup.
3-5
Chapter 3
3-6
Chapter 3: BIOS Setup
Appendix
Appendix
Notices
FCC Compliance Information
Responsible Party:
Asus Computer International
Address: 48720 Kato Rd., Fremont, CA 94538, USA
Phone / Fax No: (510)739-3777 / (510)608-4555
Identification of the assembled product: INTEL® WI-FI 6 AX201
Identification of the modular components used in the assembly:
Model Name: INTEL® WI-FI 6 AX201 FCC ID: PD9AX201NG
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-C
onnect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RF exposure warning
Appendix
This equipment must be installed and operated in accordance with provided instructions and
the antenna(s) used for this transmitter must be installed to provide a separation distance of
at least 20 cm from all persons and must not be co-located or operating in conjunction with
any other antenna or transmitter. End-users and installers must be provide with antenna
installation instructions and transmitter operating conditions for satisfying RF exposure
compliance.
ROG STRIX Z490-G GAMING (WI-FI)
A-1
Compliance Statement of Innovation, Science and Economic
Development Canada (ISED)
This device complies with Innovation, Science and Economic Development Canada licence
exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for
harmful interference to co-channel mobile satellite systems.
CAN ICES-3(B)/NMB-3(B)
Déclaration de conformité de Innovation, Sciences et
Développement économique Canada (ISED)
Le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement
économique Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage,
et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
La bande 5150–5250 MHz est réservée uniquement pour une utilisation à l’intérieur afin de
réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant
les mêmes canaux.
CAN ICES-3(B)/NMB-3(B)
VCCI: Japan Compliance Statement
Class B ITE
KC: Korea Warning Statement
Appendix
A-2
Appendix
Google™ License Terms
Copyright© 2020 Google Inc. All Rights Reserved.
Licensed under the Apache License, Version 2.0 (the “License”); you may not use this file
except in compliance with the License. You may obtain a copy of the License at:
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software distributed under the
License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS
OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and limitations under the
License.
NCC: Taiwan Wireless Statement
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻
率、加大功率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及
干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或
工業、科學及醫療用電波輻射性電機設備之干擾。
應避免影響附近雷達系統之操作。
Japan RF Equipment Statement
屋外での使用について
本製品は、5GHz帯域での通信に対応しています。電波法の定めにより5.2GHz、5.3GHz帯域の電
波は屋外で使用が禁じられています。
法律および規制遵守
本製品は電波法及びこれに基づく命令の定めるところに従い使用してください。日本国外では、
その国の法律または規制により、本製品の使用ができないことがあります。このような国では、本
製品を運用した結果、罰せられることがありますが、当社は一切責任を負いかねますのでご了承
ください。
a.
Soyez particulièrement vigilant quant à votre sécurité lors de l’utilisation de cet
appareil dans certains lieux (les avions, les aéroports, les hôpitaux, les stationsservice et les garages professionnels).
b.
Évitez d’utiliser cet appareil à proximité de dispositifs médicaux implantés. Si
vous portez un implant électronique (stimulateurs cardiaques, pompes à insuline,
neurostimulateurs…), veuillez impérativement respecter une distance minimale de 15
centimètres entre cet appareil et l’implant pour réduire les risques d’interférence.
c.
Utilisez cet appareil dans de bonnes conditions de réception pour minimiser le niveau
de rayonnement. Ce n’est pas toujours le cas dans certaines zones ou situations,
notamment dans les parkings souterrains, dans les ascenseurs, en train ou en voiture
ou tout simplement dans un secteur mal couvert par le réseau.
d.
Tenez cet appareil à distance du ventre des femmes enceintes et du bas-ventre des
adolescents.
ROG STRIX Z490-G GAMING (WI-FI)
Appendix
Précautions d’emploi de l’appareil :
A-3
Declaration of compliance for product environmental
regulation
ASUS follows the green design concept to design and manufacture our products, and
makes sure that each stage of the product life cycle of ASUS product is in line with global
environmental regulations. In addition, ASUS disclose the relevant information based on
regulation requirements.
Please refer to http://csr.asus.com/Compliance.htm for information disclosure based on
regulation requirements ASUS is complied with:
EU REACH and Article 33
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/REACH.htm.
EU RoHS
This product complies with the EU RoHS Directive. For more details, see
http://csr.asus.com/english/article.aspx?id=35
India RoHS
This product complies with the “India E-Waste (Management) Rules, 2016” and prohibits
use of lead, mercury, hexavalent chromium, polybrominated biphenyls (PBBs) and
polybrominated diphenyl ethers (PBDEs) in concentrations exceeding 0.1% by weight in
homogenous materials and 0.01% by weight in homogenous materials for cadmium, except
for the exemptions listed in Schedule II of the Rule.
Vietnam RoHS
ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of
the Vietnam Circular 30/2011/TT-BCT.
Các sản phẩm ASUS bán tại Việt Nam, vào ngày 23 tháng 9 năm2011 trở về sau, đều phải đáp ứng
các yêu cầu của Thông tư 30/2011/TT-BCT của Việt Nam.
Turkey RoHS
AEEE Yönetmeliğine Uygundur
ASUS Recycling/Takeback Services
Appendix
ASUS recycling and takeback programs come from our commitment to the highest
standards for protecting our environment. We believe in providing solutions for you to
be able to responsibly recycle our products, batteries, other components as well as the
packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed
recycling information in different regions.
A-4
Appendix
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.
Regional notice for California
WARNING
Appendix
Cancer and Reproductive Harm www.P65Warnings.ca.gov
ROG STRIX Z490-G GAMING (WI-FI)
A-5
Appendix
Simplified EU Declaration of Conformity
ASUSTek Computer Inc. hereby declares that this device is in compliance
with the essential requirements and other relevant provisions of Directive
2014/53/EU. Full text of EU declaration of conformity is available at
https://www.asus.com/support/
The WiFi operating in the band 5150-5350MHz shall be restricted to indoor
use for countries listed in the table below:
Déclaration simplifiée de conformité de l’UE
ASUSTek Computer Inc. déclare par la présente que cet appareil est
conforme aux critères essentiels et autres clauses pertinentes de la directive
2014/53/EU. La déclaration de conformité de l’UE peut être téléchargée à
partir du site internet suivant : https://www.asus.com/support/
Dans la plage de fréquence 5150-5350 MHz, le Wi-Fi est restreint à une
utilisation en intérieur dans les pays listés dans le tableau ci-dessous:
Vereinfachte EU-Konformitätserklärung
ASUSTek COMPUTER INC erklärt hiermit, dass dieses Gerät mit den
grundlegenden Anforderungen und anderen relevanten Bestimmungen
der Richtlinie 2014/53/EU übereinstimmt. Der gesamte Text der EUKonformitätserklärung ist verfügbar unter: https://www.asus.com/support/
Der WLAN-Betrieb im Band von 5150-5350 MHz ist für die in der unteren
Tabelle aufgeführten Länder auf den Innenbereich beschränkt:
Dichiarazione di conformità UE semplificata
ASUSTek Computer Inc. con la presente dichiara che questo dispositivo è
conforme ai requisiti essenziali e alle altre disposizioni pertinenti con la
direttiva 2014/53/EU. Il testo completo della dichiarazione di conformità UE
è disponibile all’indirizzo: https://www.asus.com/support/
L’utilizzo della rete Wi-Fi con frequenza compresa nell’intervallo 51505350MHz deve essere limitato all’interno degli edifici per i paesi presenti
nella seguente tabella:
Упрощенное заявление о соответствии европейской директиве
ASUSTek Computer Inc. заявляет, что устройство соответствует основным
требованиям и другим соответствующим условиям директивы 2014/53/
EU. Полный текст декларации соответствия ЕС доступен на
https://www.asus.com/support/
Работа WiFi в диапазоне частот 5150-5350 должна быть ограничена
использованием в помещениях для стран, перечисленных в таблице ниже:
‫إعالن التوافق المبسط الصادر عن االتحاد األوروبي‬
‫ أن هذا الجهاز يتوافق مع المتطلبات األساسية واألحكام‬ASUSTek Computer ‫تقر شركة‬
‫ يتوفر النص الكامل إلعالن التوافق‬.2014/53/EU ‫األخرى ذات الصلة الخاصة بتوجيه‬
:‫الصادر عن االتحاد األوروبي على‬
https://www.asus.com/support/
‫ ميجا هرتز على االستخدام المنزلي للبلدان‬5150-5350 ‫ العاملة بـ‬WiFi ‫يجب حصر استخدام‬
.‫المدرجة بالجدول‬
Опростена декларация за съответствие на ЕС
С настоящото ASUSTek Computer Inc. декларира, че това устройство е
в съответствие със съществените изисквания и другите приложими
постановления на свързаната Директива 2014/53/EC. Пълният текст на
ЕС декларация за съвместимост е достъпен на адрес
https://www.asus.com/support/
WiFi, работеща в диапазон 5150-5350MHz, трябва да се ограничи до
употреба на закрито за страните, посочени в таблицата по-долу:
Declaração de Conformidade UE Simplificada
ASUSTek Computer Inc. declara que este dispositivo está em conformidade
com os requisitos essenciais e outras disposições relevantes relacionadas às
diretivas 2014/53/UE. O texto completo da declaração de conformidade CE
está disponível em https://www.asus.com/support/
O WiFi operando na banda 5150-5350MHz deve ser restrito para uso interno
para os países listados na tabela abaixo:
Pojednostavljena EU Izjava o sukladnosti
ASUSTeK Computer Inc. ovim izjavljuje da je ovaj uređaj sukladan s bitnim
zahtjevima i ostalim odgovarajućim odredbama direktive 2014/53/EU. Cijeli
tekst EU izjave o sukladnosti dostupan je na https://www.asus.com/support/
WiFi koji radi na opsegu frekvencija 5150-5350 MHz bit će ograničen na
upotrebu u zatvorenom prostoru u zemljama na donjem popisu:
Zjednodušené prohlášení o shodě EU
Společnost ASUSTek Computer Inc. tímto prohlašuje, že toto zařízení splňuje
základní požadavky a další příslušná ustanovení směrnice 2014/53/ EU. Plné
znění prohlášení o shodě EU je k dispozici na adrese
https://www.asus.com/support/
V zemích uvedených v tabulce je provoz sítě Wi-Fi ve frekvenčním rozsahu 5
150 - 5 350 MHz povolen pouze ve vnitřních prostorech:
A-6
Forenklet EU-overensstemmelseserklæring
ASUSTeK Computer Inc. erklærer hermed at denne enhed er i
overensstemmelse med hovedkravene og øvrige relevante bestemmelser i
direktivet 2014/53/EU. Hele EU-overensstemmelseserklæringen kan findes
på https://www.asus.com/support/
Wi-Fi, der bruger 5150-5350 MHz skal begrænses til indendørs brug i lande,
der er anført i tabellen:
Vereenvoudigd EU-conformiteitsverklaring
ASUSTeK Computer Inc. verklaart hierbij dat dit apparaat voldoet aan de
essentiële vereisten en andere relevante bepalingen van Richtlijn 2014/53/
EU. De volledige tekst van de EU-conformiteitsverklaring is beschikbaar op
https://www.asus.com/support/
De WiFi op 5150-5350MHz zal beperkt zijn tot binnengebruik voor in de
tabel vermelde landen:
Lihtsustatud EÜ vastavusdeklaratsioon
Käesolevaga kinnitab ASUSTek Computer Inc, et seade vastab direktiivi
2014/53/EÜ olulistele nõuetele ja teistele asjakohastele sätetele. EL
vastavusdeklaratsiooni täistekst on saadaval veebisaidil
https://www.asus.com/support/
Sagedusvahemikus 5150-5350 MHz töötava WiFi kasutamine on järgmistes
riikides lubatud ainult siseruumides:
Eurooppa - EY:n vaatimustenmukaisuusvakuutus
ASUSTek Computer Inc. ilmoittaa täten, että tämä laite on direktiivin
2014/53/EU olennaisten vaatimusten ja muiden asiaankuuluvien lisäysten
mukainen. Koko EY:n vaatimustenmukaisuusvakuutuksen teksti on
luettavissa osoitteessa https://www.asus.com/support/
5 150 - 5 350 MHz:in taajuudella toimiva WiFi on rajoitettu sisäkäyttöön
taulukossa luetelluissa maissa:
‫تبعیت از نسخه ساده شده بیانیه اتحادیه اروپا‬
‫ در اینجا اعالم می کند که این دستگاه با نیازهای اساسی و سایر‬ASUSTek Computer Inc
‫ متن کامل پیروی از این بیانیه اتحادیه‬.‫ مطابقت دارد‬.2014/53/EU ‫مقررات مربوط به بیانیه‬
:‫اروپا در این آدرس موجود است‬
.https://www.asus.com/support/
‫ باید برای استفاده در فضای داخل ساختمان برای‬WiFi ‫ مگاهرتز برای‬5150-5350 ‫عملکرد‬
.‫ محدود شود‬،‫کشورهای فهرست شده در جدول‬
Απλοποιημένη Δήλωση Συμμόρφωσης ΕΕ
Διά του παρόντος η ASUSTek Computer Inc. δηλώνει ότι αυτή η συσκευή
είναι σύμμορφη με τις βασικές προϋποθέσεις και άλλες σχετικές διατάξεις
της Οδηγίας 2014/53/ΕE. Το πλήρες κείμενο της δήλωσης συμμόρφωσης της
ΕΕ είναι διαθέσιμο στη διεύθυνση https://www.asus.com/support/
Το WiFi που λειτουργεί στη ζώνη 5150-5350MHz περιορίζεται για χρήση σε
εσωτερικούς χώρους για τις χώρες που αναφέρονται στον παρακάτω πίνακα:
‫הצהרת תאימות רגולטורית מקוצרת עבור האיחוד אירופי‬
‫ מצהירה בזאת כי מכשיר זה תואם לדרישות‬ASUSTek Computer Inc.‎
‫ ניתן לקרוא את‬.‎2014/53/EU ‫החיוניות ולשאר הסעיפים הרלוונטיים של תקנה‬
:‫הנוסח המלא של הצהרת התאימות הרגולטורית עבור האיחוד האירופי בכתובת‬
https://www.asus.com/support/‎
‫ לשימוש‬‎5150-5350MHz ‫ הפועלות ברצועת התדרים‬Wi-Fi ‫יש להגביל רשתות‬
:‫בתוך מבנים סגורים בארצות המפורטות ברשימה הבאה‬
Egyszerűsített EU megfelelőségi nyilatkozat
Az ASUSTek Computer Inc. ezennel kijelenti, hogy ez az eszköz megfelel az
2014/53/EU sz. irányelv alapvető követelményeinek és egyéb vonatkozó
rendelkezéseinek. Az EU megfelelőségi nyilatkozat teljes szövegét a
következő weboldalon tekintheti meg: https://www.asus.com/support/
Az 5150-5350 MHz-es sávban működő Wi-Fi-t beltéri használatra kell
korlátozni az alábbi táblázatban felsorolt országokban:
Pernyataan Kesesuaian UE yang Disederhanakan
ASUSTeK Computer Inc. dengan ini menyatakan bahwa perangkat ini
memenuhi persyaratan utama dan ketentuan relevan lainnya yang terdapat
pada Petunjuk 2014/53/EU. Teks lengkap pernyataan kesesuaian EU tersedia
di: https://www.asus.com/support/
WiFi yang Beroperasi pada 5150-5350 MHz akan terbatas untuk penggunaan
dalam ruangan di negara yang tercantum dalam tabel
Vienkāršota ES atbilstības paziņojums
ASUSTeK Computer Inc. ar šo paziņo, ka šī ierīce atbilst Direktīvas
2014/53/ES būtiskajām prasībām un citiem citiem saistošajiem
nosacījumiem. Pilns ES atbilstības paziņojuma teksts pieejams šeit:
https://www.asus.com/support/
Wi-Fi darbība 5150–5350 MHz ir jāierobežo lietošanai telpās valstīs, kuras
norādītas tālāk.
Appendix
ROG STRIX Z490-G GAMING (WI-FI)
ประกาศเกี่ยวกับความสอดคล้องของสหภาพยุโรปแบบย่อ
ASUSTek Computer Inc.
ขอประกาศในที่นี้ว่าอุปกรณ์นี้มีความสอดคล้องกับความ
ต้องการที่จำ�เป็นและเงื่อนไขที่เกี่ยวข้องอื่น ๆ ของบทบัญญัติข้อกำ�หนด
2014/53/EU เนื้อหาที่สมบูรณ์ของประกาศความสอดคล้องกับ EU มีอยู่ที่
https://www.asus.com/support/
การทำ�งานของ WiFi ที่ 5150-5350MHz
ถูกจำ�กัดให้ใช้ในอาคารสำ�หรับประเทศที่แสดงในตาราง
Basitleştirilmiş AB Uyumluluk Bildirimi
ASUSTek Computer Inc., bu aygıtın 2014/53/EU Yönergesinin temel
gereksinimlerine ve diğer ilgili hükümlerine uygun olduğunu bildirir. AB
uygunluk bildiriminin tam metni şu adreste bulunabilir:
https://www.asus.com/support/
5150-5350 MHz arasındaki WiFi çalışması, tabloda listelenen ülkeler için
iç mekân kullanımıyla kısıtlanacaktır.
Спрощена декларація про відповідність нормам ЄС
ASUSTek Computer Inc. заявляє, що цей пристрій відповідає основним
вимогам та іншим відповідним вимогам Директиви 2014 / 53 / EU.
Повний текст декларації відповідності нормам ЄС доступний на
https://www.asus.com/support/
Робота Wi-Fi на частоті 5150-5350 МГц обмежується використанням у
приміщенні для країн, поданих у таблиці нижче:
AT
BE
BG
CZ
DK
EE
FR
DE
IS
IE
IT
EL
ES
CY
LV
LI
LT
LU
HU
MT
NL
NO
PL
PT
RO
SI
SK
TR
FI
SE
CH
UK
HR
INTEL® WI-FI 6 AX201 output power table:
Function
WiFi
Bluetooth
Frequency
Maximum Output Power
(EIRP)
2412 - 2472 MHz
18.64 dBm
5150 - 5350 MHz
19.08 dBm
5470 - 5725 MHz
18.77 dBm
5725 - 5850 MHz
9.21 dBm
2402 - 2480 MHz
12.06 dBm
For the standard EN 300 440 V2.1.1, if this device operates in
5725-5875 MHz, it will be considered as a receiver category 2.
Intel® Wi-Fi 6 AX201
CCAH18LP3520T2
Model: AX201NGW
IFETEL: RCPINAX18-2041
FCC ID: PD9AX201NG
CMIT ID: 2018AJ7550(M)
IC: 1000M-AX201NG
ANATEL: 06970-18-04423
Jordan: TRC/SS/2019/71
R-C-INT-AX201NGW
003-180232
D180131003
MR 18750 ANRT 2019
05/02/2019
Appendix
Supaprastinta ES atitikties deklaracija
Šiame dokumente bendrovė „ASUSTek Computer Inc.“ pareiškia, kad šis
prietaisas atitinka pagrindinius reikalavimus ir kitas susijusias Direktyvos
2014/53/ES nuostatas. Visas ES atitikties deklaracijos tekstas pateikiamas čia:
https://www.asus.com/support/
Toliau nurodytose šalyse „WiFi“ ryšiu, veikiančiu 5 150–5 350 MHz dažnio
juostoje, galima naudotis tik patalpose:
Forenklet EU-samsvarserklæring
ASUSTek Computer Inc. erklærer herved at denne enheten er i samsvar med
hovedsaklige krav og andre relevante forskrifter i direktivet 2014/53/EU.
Fullstendig tekst for EU-samsvarserklæringen finnes på:
https://www.asus.com/support/
Wi-Fi-området 5150–5350 MHz skal begrenses til innendørs bruk for landene
som er oppført i tabellen:
Uproszczona deklaracja zgodności UE
Firma ASUSTek Computer Inc. niniejszym oświadcza, że urządzenie to jest
zgodne z zasadniczymi wymogami i innymi właściwymi postanowieniami
dyrektywy 2014/53/EU. Pełny tekst deklaracji zgodności UE jest dostępny
pod adresem https://www.asus.com/support/
W krajach wymienionych w tabeli działanie sieci Wi-Fi w paśmie 5150–
5350 MHz powinno być ograniczone wyłącznie do pomieszczeń:
Declaração de Conformidade Simplificada da UE
A ASUSTek Computer Inc. declara que este dispositivo está em
conformidade com os requisitos essenciais e outras disposições relevantes
da Diretiva 2014/53/UE. O texto integral da declaração de conformidade da
UE está disponível em https://www.asus.com/support/
A utilização das frequências WiFi de 5150 a 5350MHz está restrita a
ambientes interiores nos países apresentados na tabela:
Declarație de conformitate UE, versiune simplificată
Prin prezenta, ASUSTek Computer Inc. declară că acest dispozitiv este în
conformitate cu reglementările esențiale și cu celelalte prevederi relevante
ale Directivei 2014/53/UE. Textul complet al declarației de conformitate UE
este disponibil la adresa https://www.asus.com/support/
Pentru ţările listate în tabelul de mai jos, reţelele WiFi care funcţionează în
banda de frecvenţă de 5.150-5.350 MHz trebuie utilizate doar în interior:
Pojednostavljena Deklaracija o usaglašenosti EU
ASUSTek Computer Inc. ovim izjavljuje da je ovaj uređaj usaglašen sa
osnovnim zahtevima i drugim relevantnim odredbama Direktive 2014/53/
EU. Ceo tekst Deklaracije o usaglašenosti EU dostupan je na lokaciji
https://www.asus.com/support/
WiFi koji radi u frekventnom opsegu od 5150 MHz do 5350 MHz ograničen
je isključivo na upotrebu u zatvorenom prostoru za zemlje navedene u
tabeli ispod:
Zjednodušené vyhlásenie o zhode platné pre EÚ
Spoločnosť ASUSTek Computer Inc. týmto vyhlasuje, že toto zariadenie je
v súlade so základnými požiadavkami a ďalšími príslušnými ustanoveniami
smernice č. 2014/53/EÚ. Plné znenie vyhlásenia o zhode pre EÚ je k dispozícii
na lokalite https://www.asus.com/support/
Činnosť WiFi v pásme 5150 - 5350 MHz bude obmedzená na použitie vo
vnútornom prostredí pre krajiny uvedené v tabuľke nižšie:
Poenostavljena izjava EU o skladnosti
ASUSTek Computer Inc. tukaj izjavlja, da je ta naprava skladna s temeljnimi
zahtevami in drugimi relevantnimii določili Direktive 2014/53/EU. Polno
besedilo izjave EU o skladnosti je na voljo na
https://www.asus.com/support/
WiFi, ki deluje v pasovnem območju 5150–5350 MHz, mora biti v državah,
navedenih v spodnjem seznamu, omejen na notranjo uporabo:
Declaración de conformidad simplificada para la UE
Por la presente, ASUSTek Computer Inc. declara que este dispositivo cumple
los requisitos básicos y otras disposiciones pertinentes de la directiva
2014/53/EU. En https://www.asus.com/support/ está disponible el texto
completo de la declaración de conformidad para la UE.
La conexión WiFi con una frecuencia de funcionamiento de 5150-5350 MHz
se restringirá al uso en interiores para los países enumerados en la tabla:
Förenklad EU-försäkran om överensstämmelse
ASUSTek Computer Inc. deklarerar härmed att denna enhet överensstämmer
med de grundläggande kraven och andra relevanta bestämmelser i direktiv
2014/53/EU. Fullständig text av EU-försäkran om överensstämmelse finns på
https://www.asus.com/support/
WiFi som använder 5150-5350 MHz kommer att begränsas för användning
inomhus i de länder som anges i tabellen:
ER69428/19
0018841/09
A-7
ASUS contact information
ASUSTeK COMPUTER INC.
Address
Telephone Fax
Web site
Technical Support
Telephone Online support
1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan
+886-2-2894-3447
+886-2-2890-7798
https://www.asus.com
+86-21-38429911
https://qr.asus.com/techserv
ASUS COMPUTER INTERNATIONAL (America)
Address
48720 Kato Rd., Fremont, CA 94538, USA
Telephone+1-510-739-3777
Fax
+1-510-608-4555
Web site
https://www.asus.com/us/
Technical Support
Support fax
Telephone Online support
+1-812-284-0883
+1-812-282-2787
https://qr.asus.com/techserv
ASUS COMPUTER GmbH (Germany and Austria)
Address
Harkortstrasse 21-23, 40880 Ratingen, Germany
Web site
https://www.asus.com/de
Online contacthttps://www.asus.com/support/Product/ContactUs/
Services/questionform/?lang=de-de
Technical Support
Telephone (DE)
Telephone (AT)
Online support
+49-2102-5789557
+43-1360-2775461
https://www.asus.com/de/support
Appendix
A-8
Appendix

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
