Yamaha BANSHEE YFZ350, BANSHEE YFZ350W Owner's Manual

OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
MANUAL DEL PROPIETARIO
YFZ350X
This A
3B5-28199-62
YAMAHA MOTOR CO., LTD.
PRINTED IN JAPAN
2007.06-0.2x1 !
(E,F,S)
OWNER’S MANUAL
YFZ350X
This A
3B5-28199-62-E0
EBU17170
INTRODUCTION
EBU17320
Congratulations on your purchase of the Yamaha YFZ350X. This ATV represents the result of many years
of Yamaha experience in the production of fine sporting, touring, and pacesetting racing machines. With the
purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability that have
made Yamaha a leader in these fields.
This manual will provide you with a good basic understanding of the features and operation of this ATV.
This manual includes important safety information. It provides information about special techniques and skills necessary to ride the ATV. It also includes basic maintenance and inspection procedures. If you have any questions regarding the operation or maintenance of your ATV, please consult a
Yamaha dealer.
AN IMPORTANT SAFETY MESSAGE:
READ THIS MANUAL COMPLETELY BEFORE OPERATING YOUR ATV. MAKE SURE YOU UNDERSTAND ALL INSTRUCTIONS.
● PAY CLOSE ATTENTION TO THE WARNING AND CAUTION LABELS ON THE ATV.
● THIS ATV, AND ANY OTHER ATV OVER 90 cc, SHOULD NOT BE RIDDEN BY ANYONE UNDER 16
YEARS OF AGE.
● THIS ATV IS A HIGH-PERFORMANCE ATV FOR OFF-ROAD USE ONLY, FOR SPORT-TYPE RECREATIONAL AND COMPETITIVE USE BY EXPERIENCED OPERATORS.
●
EBU17330
IMPORTANT MANUAL INFORMATION
EBU17341
FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERIOUS INJURY OR DEATH.
Particularly important information is distinguished in this manual by the following notations:
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR
SAFETY IS INVOLVED!
WARNING
Failure to follow WARNING instructions could result in severe injury
or death to the ATV operator, a bystander, or a person inspecting or
repairing the ATV.
CAUTION:
A CAUTION indicates special precautions that must be taken to avoid
damage to the ATV.
NOTE:
A NOTE provides key information to make procedures easier or clearer.
* Product and specifications are subject to change without notice.
EBU17350
IMPORTANT NOTICE
EBU17370
Welcome to the Yamaha world of motor sports!
This ATV is designed and manufactured for use on UNPAVED surfaces only. It is unsafe to operate this
ATV on any paved surface, paved street, paved road or motorway.
Please check your local riding laws and regulations before operating this ATV.
EBU17390
YFZ350X
OWNER’S MANUAL
©2007 by Yamaha Motor Co., Ltd.
1st edition, June 2007
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
Printed in Japan.
EBU17420
TABLE OF CONTENTS
SAFETY INFORMATION .............................. 1-1
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ............................ 2-1
DESCRIPTION .............................................. 3-1
Left view ..................................................... 3-1
Right view................................................... 3-1
Controls and instruments ........................... 3-2
INSTRUMENT AND CONTROL
FUNCTIONS .................................................. 4-1
Main switch ............................................... 4-1
Handlebar switches ................................... 4-2
Throttle lever ............................................. 4-2
Throttle OverRide System ......................... 4-3
Speed limiter ............................................. 4-3
Clutch lever ............................................... 4-4
Brake lever ................................................ 4-5
Brake pedal ............................................... 4-5
Parking brake ............................................ 4-5
Shift pedal ................................................. 4-7
Kickstarter ................................................. 4-7
Fuel tank cap ............................................. 4-7
Fuel ........................................................... 4-8
Fuel cock ................................................... 4-9
Starter (choke) ......................................... 4-10
Seat ......................................................... 4-11
Adjusting the front shock absorber
assemblies .............................................4-12
Adjusting the rear shock absorber
assembly ................................................4-13
PRE-OPERATION CHECKS ..........................5-1
Pre-operation check list ............................. 5-1
Fuel and 2-stroke engine oil mixing ratio ... 5-3
Transmission oil ......................................... 5-3
Coolant ...................................................... 5-3
Front and rear brakes ................................ 5-3
Throttle lever .............................................. 5-4
Drive chain ................................................. 5-4
Tires ........................................................... 5-5
Measuring the tire pressure ....................... 5-6
Tire wear limit ............................................ 5-6
Chassis fasteners ...................................... 5-7
Instruments, lights and switches ................ 5-7
OPERATION...................................................6-1
Starting a cold engine ................................ 6-1
Starting a warm engine .............................. 6-2
Shifting ....................................................... 6-3
Engine break-in .........................................
Parking ......................................................
Parking on a slope ....................................
Accessories and loading ...........................
6-4
6-5
6-6
6-6
RIDING YOUR ATV ...................................... 7-1
GETTING TO KNOW YOUR ATV.............. 7-2
RIDE WITH CARE AND GOOD
JUDGEMENT ...........................................7-2
BE CAREFUL WHERE YOU RIDE............ 7-8
TURNING YOUR ATV ............................. 7-12
CLIMBING UPHILL .................................. 7-14
RIDING DOWNHILL................................. 7-16
CROSSING A SLOPE.............................. 7-17
CROSSING THROUGH SHALLOW
WATER ..................................................7-18
RIDING OVER ROUGH TERRAIN .......... 7-20
SLIDING AND SKIDDING........................ 7-20
WHAT TO DO IF... ................................... 7-21
WHAT TO DO... ....................................... 7-21
PERIODIC MAINTENANCE AND MINOR
REPAIR .......................................................... 8-1
Owner’s manual and tool kit ...................... 8-1
Periodic maintenance chart for the
emission control system .......................... 8-3
General maintenance and lubrication
chart ........................................................ 8-5
Checking the spark plugs .......................... 8-8
Transmission oil ....................................... 8-10
Coolant .................................................... 8-12
Cleaning the air filter element .................. 8-17
Cleaning the spark arrester ..................... 8-20
Changing the carburetor settings ............. 8-22
Adjusting the engine idling speed ............ 8-29
Adjusting the throttle cable free play ........ 8-31
Checking the front and rear brake
pads .......................................................8-32
Checking the brake fluid level .................. 8-33
Changing the brake fluid .......................... 8-34
Checking the front brake lever free
play ........................................................8-34
Checking the brake pedal position ........... 8-35
Adjusting the parking brake free play ...... 8-36
Brake light switches ................................. 8-38
Adjusting the clutch lever free play .......... 8-38
Drive chain slack ...................................... 8-39
Lubricating the drive chain ....................... 8-41
Checking and lubricating the cables ........ 8-42
Checking and lubricating the brake and
clutch levers ...........................................8-43
Checking and lubricating the brake and
shift pedals .............................................8-43
Checking the wheel hub bearings ............ 8-43
Lubricating the rear suspension relay arm
and connecting arm pivoting points .......8-43
Lubricating the upper and lower arm
pivots .....................................................8-44
Lubricating the steering shaft ..................
Replacing a headlight bulb ......................
Adjusting a headlight beam .....................
Replacing the tail/brake light bulb ...........
Removing a wheel ...................................
Installing a wheel .....................................
Troubleshooting ......................................
Troubleshooting charts ............................
8-45
8-45
8-48
8-48
8-49
8-50
8-51
8-52
CLEANING AND STORAGE.......................... 9-1
Cleaning .................................................... 9-1
Storage ...................................................... 9-2
SPECIFICATIONS ...................................... 10-1
CONSUMER INFORMATION ...................... 11-1
Identification numbers ............................. 11-1
EBU17430
SAFETY INFORMATION
SAFETY INFORMATION
EBU17592
AN ATV IS NOT A TOY AND CAN BE HAZARDOUS TO OPERATE.
An ATV handles differently from other vehicles, including motorcycles and cars. A collision or rollover can occur quickly, even during routine
maneuvers such as turning and riding on hills or
over obstacles, if you fail to take proper precautions.
SEVERE INJURY OR DEATH can result if you do
not follow these instructions:
● Read this manual and all labels carefully and follow the operating procedures described.
● Never operate an ATV without proper training or
instruction.
● Always follow the age recommendation:
– A child under 16 years old should never operate an ATV with engine size greater than 90 cc.
● Never allow a child under age 16 to operate an
ATV without adult supervision, and never allow
●
●
●
●
●
●
●
1-1
continued use of an ATV by a child if he or she
does not have the abilities to operate it safely.
Never carry a passenger on an ATV.
Always avoid operating an ATV on any paved
surfaces, including sidewalks, driveways, parking lots and paved streets.
Never operate an ATV on any paved street,
paved road or motorway.
Watch carefully for other vehicles when operating on unpaved public streets or roads. Make
sure you know your country’s laws and regulations before you ride on unpaved public streets
or roads.
Never operate an ATV without wearing an approved motorcycle helmet that fits properly. You
should also wear eye protection (goggles or face
shield), gloves, boots, a long-sleeved shirt or a
jacket, and long pants.
Never consume alcohol or drugs before or while
operating this ATV.
Never operate at speeds too fast for your skills
1
2
3
4
5
6
7
8
9
10
11
1
2
●
●
3
4
5
6
●
●
7
8
●
9
10
11
●
●
or the riding conditions. Always go at a speed
that is proper for the terrain, visibility, operating
conditions, and your experience.
Never attempt wheelies, jumps, or other stunts.
Always inspect your ATV each time you use it to
make sure it is in safe operating condition. Always follow the inspection and maintenance
procedures and schedules described in this
manual.
Always keep both hands on the handlebars and
both feet on the footrests of the ATV during operation.
Always go slowly and be extra careful when operating on unfamiliar terrain. Always be alert to
changing terrain conditions when operating the
ATV.
Never operate on excessively rough, slippery or
loose terrain until you have learned and practiced the skills necessary to control the ATV on
such terrain. Always be especially cautious on
these kinds of terrain.
Always follow proper procedures for turning as
described in this manual. Practice turning at low
speeds before attempting to turn at faster
speeds and never turn at excessive speeds.
Never operate the ATV on hills too steep for the
●
●
●
●
1-2
ATV or for your abilities. Practice on smaller hills
before attempting larger hills.
Always follow proper procedures for climbing
hills as described in this manual. Check the terrain carefully before you start up any hill. Never
climb hills with excessively slippery or loose surfaces. Shift your weight forward. Never open the
throttle suddenly or make sudden gear changes.
Never go over the top of a hill at high speed.
Always follow proper procedures for going down
hills and for braking on hills as described in this
manual. Check the terrain carefully before you
start down any hill. Shift your weight backward.
Never go down a hill at high speed. Avoid going
down a hill at an angle that would cause the vehicle to lean sharply to one side. Go straight
down the hill where possible.
Always follow proper procedures for crossing
the side of a hill as described in this manual.
Avoid hills with excessively slippery or loose surfaces. Shift your weight to the uphill side of the
ATV. Never attempt to turn the ATV around on
any hill until you have mastered the turning technique described in this manual on level ground.
Avoid crossing the side of a steep hill if possible.
Always use proper procedures if you stall or roll
●
●
●
●
backwards when climbing a hill. To avoid stalling, use the proper gear and maintain a steady
speed when climbing a hill. If you stall or roll
backwards, follow the special procedure for
braking described in this manual. Dismount on
the uphill side or to a side if pointed straight uphill. Turn the ATV around and remount, following
the procedure described in this manual.
Always check for obstacles before operating in a
new area.
Never attempt to operate over large obstacles,
such as large rocks or fallen trees. Always follow
proper procedures when operating over obstacles as described in this manual.
Always be careful when skidding or sliding.
Learn to safely control skidding or sliding by
practicing at low speeds and on level, smooth
terrain. On extremely slippery surfaces, such as
ice, go slowly and be very cautious in order to reduce the chance of skidding or sliding out of control.
Never operate an ATV in fast flowing water or in
water deeper than that recommended in this
manual. Remember that wet brakes may have
reduced stopping ability. Test your brakes after
leaving water. If necessary, apply them several
●
●
●
●
times to let friction dry out the linings.
Always use the size and type of tires specified in
this manual.
Always maintain proper tire pressure as described in this manual.
Never modify an ATV through improper installation or use of accessories.
Never exceed the stated load capacity for an
ATV. Cargo should be properly distributed and
securely attached. Reduce speed and follow instructions in this manual for carrying cargo or
pulling a trailer. Allow greater distance for braking.
EWB00061
WARNING
●
●
●
●
1-3
Always turn off the engine when refueling.
Do not refuel right after the engine has been
running and is still very hot.
Do not spill gasoline on the engine or exhaust pipe/muffler when refueling. Never refuel while smoking, or in the vicinity of
sparks, open flames, or other sources of ignition such as the pilot lights of water heaters and clothes dryers. Gasoline can catch
fire and you could be burned.
When transporting the ATV in another vehi-
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
●
cle, be sure it is kept upright and that the fuel
cock is in the “OFF” position. Otherwise, fuel
may leak out of the carburetor or fuel tank.
Gasoline is poisonous. If you should swallow some gasoline or inhale a lot of gasoline
vapor, or get some gasoline in your eyes,
seek medical help immediately. If gasoline
spills on your skin, wash with soap and water. If gasoline spills on your clothing,
change your clothes.
in a closed area. Exhaust fumes are poisonous
and may cause loss of consciousness and
death within a short time.
6
7
8
9
10
11
EWB00070
WARNING
Always operate your ATV in an area with adequate ventilation. Never start or run the engine
1-4
EBU17660
LOCATION OF THE WARNING AND SPECIFICATION LABELS
1
2
3
1
3
5
4
5
6
7
2
8
9
4
6
10
11
2-1
EBU17670
1
2
Read and understand all of the labels on your ATV. These labels contain important information for safe and
proper operation.
Never remove any labels from your ATV. If a label becomes difficult to read or comes off, request a replacement label from your Yamaha dealer.
3
4
5
6
7
8
9
10
11
2-2
1
2
3
4
5
6
7
8
9
10
11
2-3
1
2
3
4
5
6
7
8
9
10
11
2-4
1
2
3
4
5
6
7
8
9
10
11
2-5
1
2
3
4
5
6
7
8
9
10
11
2-6
EBU17680
DESCRIPTION
1
EBU17690
EBU17700
Left view
Right view
1
2
4
3
1
5
2
2
3 4
5
3
4
5
6
7
7
1.
2.
3.
4.
5.
6.
7.
6
7
Front shock absorber assembly
Radiator
Fuel cock
Rear shock absorber assembly
Spark arrester
Starter (choke)
Shift pedal
1.
2.
3.
4.
5.
6.
7.
3-1
Tail/brake light
Seat
Kickstarter
Fuel tank cap
Headlight
Brake pedal
Brake light switch
6
8
9
10
11
EBU17712
Controls and instruments
1
1
2
3
4
2
3
4
5
6
6
7
8
9
1.
2.
3.
4.
5.
6.
5
Clutch lever
Parking brake lock plate
Main switch
Brake lever
Throttle lever
Handlebar switches
10
11
NOTE:
The ATV you have purchased may differ slightly
from the figures shown in this manual.
3-2
EBU17731
INSTRUMENT AND CONTROL FUNCTIONS
1
EBU17760
Main switch
OFF
The positions of the main switch are as follows:
ON
2
3
ON
All electrical systems are supplied with power. The
headlights and taillight come on when the light
switch is on, and the engine can be started. The
key cannot be removed.
4
5
6
OFF
All electrical systems are off. The key can be removed.
7
1. Main switch
8
9
10
11
4-1
EBU18061
EBU18140
Handlebar switches
Light switch “LIGHTS”
Set this switch to “LO” to turn on the low beams
and the taillight. Set the switch to “HI” to turn on the
high beams and the taillight. Set the switch to
“OFF” to turn off all the lights.
1
1
2
ECB00040
3
CAUTION:
4
Do not use the headlights with the engine
turned off for an extended period of time, otherwise the battery may discharge to the point
that the starter motor will not operate properly.
If this should happen, remove the battery and
recharge it.
5
2
6
7
1. Light switch “LIGHTS”
2. Engine stop switch “ENG. STOP”
EBU18280
8
Throttle lever
EBU18070
9
10
11
Once the engine is running, movement of the throttle lever will increase the engine speed.
Regulate the speed of the ATV by varying the
throttle position. Because the throttle is springloaded, the ATV will decelerate, and the engine will
return to an idle any time the hand is removed from
the throttle lever.
Engine stop switch “ENG. STOP”
Set this switch to “RUN” before starting the engine.
The engine stop switch controls the ignition and
stops the engine when it is running. Use this switch
to stop the engine in an emergency situation. The
engine will not start or run when this switch is set
to “OFF”.
4-2
EBU18300
Throttle OverRide System
If during operation, the carburetor or the throttle cable should malfunction and will not close fully, take
your thumb off the throttle lever.
The throttle override system immediately cuts off
the ignition.
1
2
3
EWB00260
WARNING
1
Riding with a malfunction increases the
chance for an accident and injury. Make sure
that the cause of the malfunction is corrected
before restarting the engine or have the ATV inspected by a Yamaha dealer.
1. Throttle lever
Before starting the engine, check the throttle to be
sure it is operating smoothly. Make sure it returns
to the idle position as soon as the lever is released.
EBU18321
4
5
6
7
8
Speed limiter
EWB00250
Your ATV was delivered with an adjustable speed
limiter. The speed limiter keeps the throttle from
fully opening, even when the throttle lever is
pushed to the maximum.
1. Loosen the locknut.
2. To increase the maximum engine power available and the maximum speed of the ATV, turn
the adjusting screw in direction (a). To decrease the maximum engine power available
WARNING
Malfunction of the throttle could make it difficult to speed up or slow down when you need
to. This could cause an accident. Check the operation of the throttle lever before you start the
engine. If the throttle does not work smoothly,
check for the cause. Correct the problem before riding the ATV or consult a Yamaha dealer.
4-3
9
10
11
and the maximum speed of the ATV, turn the
adjusting screw in direction (b).
aged. Always make sure the throttle lever free
play is adjusted to 4.0–6.0 mm (0.16–0.24 in).
(See page 8-31.)
1
3
2
1
2
EBU18372
Clutch lever
3
The clutch lever is located on the left handlebar. To
disengage the clutch, pull the clutch lever toward
the handlebar grip. To engage the clutch, release
the clutch lever. The clutch lever should be pulled
rapidly and released slowly for smooth clutch operation.
(b)
4
(a)
5
6
7
8
9
10
11
1. Locknut
2. Adjusting screw
3. No more than 12 mm (0.47 in)
1
3. Tighten the locknut.
EWB00240
WARNING
Improper adjustment of the speed limiter and
throttle could cause throttle cable damage or
improper throttle operation. You could lose
control, have an accident or be injured. Do not
turn the adjusting screw out more than 12 mm
(0.47 in) or the throttle cable could be dam-
1. Clutch lever
4-4
EBU18411
Brake lever
The brake lever is located at the right handlebar
grip. To apply the front brake, pull the brake lever
toward the handlebar grip.
1
2
3
1
4
1
1. Brake pedal
EBU18500
5
6
7
Parking brake
Use the parking brake before starting the engine or
parking the ATV, especially on a slope. Squeeze
the clutch lever while pushing the button, then
push in the lock plate to apply the parking brake.
Squeeze the clutch lever to release the parking
brake.
1. Brake lever
EBU18432
Brake pedal
The brake pedal is located on the right side of the
ATV. To apply the rear brake, push down on the
brake pedal.
NOTE:
When the parking brake is used, engine speed is
limited to 2300 r/min. Be sure the parking brake is
released before moving the throttle lever. Other4-5
8
9
10
11
wise, the engine will misfire, preventing normal operation.
1
2
1
3
4
5
1
2
6
1. Locked position
7
8
EWB00220
1. Button
2. Parking brake lock plate
WARNING
●
9
10
●
11
4-6
Always set the parking brake before starting
the engine. The ATV could start moving unexpectedly if the parking brake is not applied. This could cause loss of control or a
collision.
Always be sure you have released the parking brake before you begin to ride. The brake
could overheat if you ride the ATV without releasing the parking brake. You could lose
braking performance which could cause an
accident. You could also wear out the brakes
prematurely.
push it down smoothly but forcefully. This model is
equipped with a primary kickstarter, allowing the
engine to be started in any gear if the clutch is disengaged. However, shifting the transmission into
the neutral position before starting is recommended.
EBU18530
Shift pedal
This ATV is equipped with a constant-mesh 6speed transmission. The shift pedal is located on
the left side of the engine and is used in combination with the clutch when shifting.
1
1
2
3
4
5
6
6
5
4
3
2
7
N
8
1
2
1
9
1. Kickstarter
10
1. Shift pedal
2. Neutral position
EBU18720
Fuel tank cap
Remove the fuel tank cap by turning it counterclockwise.
EBU18650
Kickstarter
Fold out the kickstarter lever, move it down lightly
with your foot until the gears engage, and then
4-7
11
1
2
1
3
4
5
6
1. Fuel tank cap
7
EBU18772
1. Fuel level
2. Filler tube
Fuel
8
9
Recommended fuel:
PREMIUM UNLEADED GASOLINE ONLY
For Europe: PREMIUM UNLEADED GASOLINE ONLY with a research octane number
of 95 or higher.
Fuel tank capacity:
12.0 L (3.17 US gal) (2.64 Imp.gal)
Fuel reserve amount:
2.5 L (0.66 US gal) (0.55 Imp.gal)
Make sure that there is sufficient fuel in the tank.
Fill the fuel tank to the bottom of the filler tube as
shown.
10
11
NOTE:
If knocking or pinging occurs, use a different brand
4-8
of gasoline or higher octane grade.
The fuel cock lever positions are explained as follows and shown in the illustrations.
ECB00060
1
CAUTION:
OFF
Use only unleaded gasoline. The use of leaded
gasoline will cause severe damage to internal
engine parts, such as the piston rings, as well
as to the exhaust system.
2
3
1
RES
4
EWB00310
WARNING
●
●
●
●
OFF
Do not overfill the fuel tank. Fuel expands
when it heats up. If the fuel tank is overfilled,
fuel could spill out due to heat from the engine or the sun.
Be careful not to spill fuel, especially on the
engine or exhaust pipe which can cause a
fire and severe injury. Wipe up any spilled
fuel immediately.
Do not refuel right after the engine has been
running and is still very hot.
Be sure the fuel tank cap is closed securely.
5
ON
FUEL
6
7
1. Arrow mark positioned over “OFF”
With the fuel cock lever in this position, fuel will not
flow. Always turn the fuel cock lever to this position
when the engine is not running.
8
9
10
11
EBU18830
Fuel cock
The fuel cock supplies fuel from the tank to the carburetors while also filtering it.
4-9
ON
RES
1
RES
2
RES
3
OFF
4
1
5
1
RES
OFF
ON
FUEL
ON
FUEL
ON
6
7
8
9
1. Arrow mark positioned over “ON”
1. Arrow mark positioned over “RES”
With the fuel cock lever in this position, fuel flows
to the carburetors. Turn the fuel cock lever to this
position when starting the engine and riding.
This indicates reserve. With the fuel cock lever in
this position, the fuel reserve is made available.
Turn the fuel cock lever to this position if you run
out of fuel while riding. When this occurs, refuel as
soon as possible and be sure to turn the fuel cock
lever back to “ON”!
10
11
EBU18840
Starter (choke)
Starting a cold engine requires a richer air-fuel mixture, which is supplied by the starter (choke).
Move the starter (choke) in direction (a) to turn on
4-10
the starter (choke).
Move the starter (choke) in direction (b) to turn off
the starter (choke).
See the “Starting a cold engine” section on page
6-1 for proper operation.
1
2
3
4
(b)
1
(a)
1
1. Starter (choke)
EBU18870
Seat
5
1. Seat lock lever
6
To install the seat
Insert the projection on the front of the seat into the
seat holder and push down on the seat at the rear.
7
NOTE:
Make sure that the seat is securely fitted.
9
8
10
11
To remove the seat
Pull the seat lock lever upward and pull up the seat
at the rear.
4-11
1
A B
C D
E
1
2
2
(a)
3
(b)
4
6
1
2
5
1. Projection
2. Seat holder
1. Spring preload adjusting ring
2. Position indicator
EBU18990
NOTE:
A special wrench can be obtained at a Yamaha
dealer to make this adjustment.
7
8
9
10
11
Adjusting the front shock absorber
assemblies
The spring preload can be adjusted to suit the rider’s weight and the riding conditions.
Adjust the spring preload as follows.
Turn the adjusting ring in direction (a) to increase
the spring preload and thereby harden the suspension, and in direction (b) to decrease the spring
preload and thereby soften the suspension.
Spring preload setting:
Minimum (soft):
A
Standard:
C
Maximum (hard):
E
4-12
EWB00400
WARNING
●
Always adjust the shock absorber assemblies
on the left and right side to the same setting.
Uneven adjustment can cause poor handling
and loss of stability, which could lead to an accident.
●
cessive gas pressure.
Do not deform or damage the cylinder in any
way. Cylinder damage will result in poor
damping performance.
Do not dispose of a damaged or worn out
shock absorber assembly yourself. Take the
shock absorber assembly to a Yamaha dealer for any service.
1
2
3
4
EBU19100
Adjusting the rear shock absorber
assembly
Spring preload
1. Loosen the locknut.
2. Turn the adjusting nut in direction (a) to increase the spring preload and thereby harden
the suspension, and in direction (b) to decrease the spring preload and thereby soften
the suspension.
The spring preload, rebound damping and compression damping forces of the rear shock absorber assembly can be adjusted to suit the rider’s
weight and the riding conditions.
EWB00430
WARNING
5
6
7
8
9
This shock absorber assembly contains highly
pressurized nitrogen gas. Read and understand the following information before handling the shock absorber assembly.
● Do not tamper with or attempt to open the
cylinder assembly.
● Do not subject the shock absorber assembly
to an open flame or other high heat source.
This may cause the unit to explode due to ex-
10
11
4-13
1
2
3
1
(b)
1
2
4
(a)
5
6
1. Distance A
1. Locknut
2. Spring preload adjusting nut
7
8
9
10
11
Spring preload setting:
Minimum (hard):
Distance A = 213.5 mm (8.4 in)
Standard:
Distance A = 220.5 mm (8.7 in)
Maximum (soft):
Distance A = 228.5 mm (9.0 in)
NOTE:
● A special wrench can be obtained at a Yamaha
dealer to make this adjustment.
● The spring preload setting is determined by
measuring distance A, shown in the illustration.
The shorter distance A is, the higher the spring
preload; the longer distance A is, the lower the
spring preload. With each complete turn of the
adjusting nut, distance A is changed by 1.5 mm
(0.06 in).
3. Tighten the locknut to the specified torque.
Tightening torque:
Locknut:
54 Nm (5.4 m·kgf, 39 ft·lbf)
4-14
ECB00080
Rebound damping setting:
Minçimum (soft):
20 click(s) in direction (b)*
Standard:
12 click(s) in direction (b)*
Maximum (hard):
3 click(s) in direction (b)*
* With the adjusting dial fully turned in direction (a)
CAUTION:
Always tighten the locknut against the adjusting nut, and then tighten it to the specified
torque.
Rebound damping force
Turn the adjusting dial in direction (a) to increase
the rebound damping force and thereby harden
the damping, and in direction (b) to decrease the
rebound damping force and thereby soften the
damping.
(b)
1
2
3
4
5
Compression damping force
Turn the adjusting knob in direction (a) to increase
the compression damping force and thereby harden the damping, and in direction (b) to decrease
the compression damping force and thereby soften the damping.
(a)
6
7
8
9
10
1
11
1. Rebound damping force adjusting dial
4-15
the minimum and maximum settings.
(b)
1
NOTE:
Although the total number of clicks of a damping
force adjusting mechanism may not exactly match
the above specifications due to small differences in
production, the actual number of clicks always represents the entire adjusting range. To obtain a precise adjustment, it would be advisable to check the
number of clicks of each damping force adjusting
mechanism and to modify the specifications as
necessary.
2
(a)
3
4
1
5
6
1. Compression damping force adjusting knob
EWB00460
7
8
9
10
11
WARNING
Compression damping setting:
Minimum (soft):
1 click(s) in direction (a)*
Standard:
11 click(s) in direction (a)*
Maximum (hard):
15 click(s) in direction (a)*
* With the adjusting knob fully turned in direction (b)
Suspension components become hot during
operation. Never touch the compression
damping force adjusting knob, the rebound
damping force adjusting dial or the oil reservoir with your bare hand or skin until suspension components have cooled.
ECB00090
CAUTION:
Never turn an adjusting mechanism beyond
4-16
EBU19200
PRE-OPERATION CHECKS
1
EBU19222
Pre-operation check list
2
Before operating this ATV, be sure to check the items listed in the following table.
EWB00480
3
WARNING
Always inspect your ATV each time you use it to make sure it is in safe operating condition.
Always follow the inspection and maintenance procedures and schedules described in the Owner’s
Manual. Failure to inspect increases the possibility of an accident or equipment damage.
4
NOTE:
The maintenance of some items in the table has to be performed by a Yamaha dealer. Refer to the periodic
maintenance charts on page 8-3 to determine which service should be performed by a Yamaha dealer.
6
ITEM
ROUTINE
●
Fuel
●
●
Transmission oil
●
●
Coolant
●
Check fuel level in fuel tank, and add recommended fuel if necessary.
Check fuel line for leakage. Correct if necessary.
Check oil level in transmission case, and add recommended oil to
specified level if necessary.
Check ATV for oil leakage. Correct if necessary.
Check coolant level in reservoir, and add recommended coolant to
specified level if necessary.
Check cooling system for leakage. Correct if necessary.
5-1
5
7
PAGE
8
4-8, 5-3
9
10
5-3, 8-10
11
5-3, 8-12
ITEM
ROUTINE
1
2
●
Check operation, and correct if necessary.
●
●
●
●
Rear brake
●
5
6
●
●
Front brake
3
4
Check operation. If soft or spongy, have Yamaha dealer bleed
hydraulic system.
Check brake pads for wear, and replace if necessary.
Check brake fluid level in reservoir, and add recommended brake
fluid to specified level if necessary.
Check hydraulic system for leakage. Correct if necessary.
Check operation. If soft or spongy, have Yamaha dealer bleed
hydraulic system.
Check brake pads for wear, and replace if necessary.
Check brake fluid level in reservoir, and add recommended brake
fluid to specified level if necessary.
Check hydraulic system for leakage. Correct if necessary.
Check operation, and correct if necessary.
Lubricate cable if necessary.
Check lever free play, and adjust if necessary.
Make sure that operation is smooth. Lubricate cable and lever housing if necessary.
Check cable free play, and adjust if necessary.
Make sure that operation is smooth. Lubricate if necessary.
Check chain slack, and adjust if necessary.
Check chain condition. Lubricate if necessary.
Check wheel condition, and replace if damaged.
Check tire condition and tread depth. Replace if necessary.
Check air pressure. Correct if necessary.
Make sure that operation is smooth. Lubricate pedal pivoting points
if necessary.
Make sure that operation is smooth. Lubricate lever pivoting points
if necessary.
Make sure that all nuts, bolts and screws are properly tightened.
●
●
●
Clutch
●
●
7
●
Throttle lever
8
●
Control cables
9
Drive chain
10
Wheels and tires
●
●
●
●
●
●
11
●
Brake and shift pedals
Brake and clutch levers
Chassis fasteners
Instruments, lights
switches
and
●
5-2
PAGE
5-3, 8-32, 8-33, 8-34
5-3, 8-32, 8-33, 8-35
8-38
5-4, 8-31
8-42
5-4, 8-39, 8-41
5-5, 5-6, 5-6
8-43
8-43
5-7
5-7
EBU19550
EBU19630
Fuel and 2-stroke engine oil mixing
ratio
Coolant
Make sure that the coolant is at the specified level.
Add coolant as necessary. (See page 8-12.)
Recommended 2-stroke engine oil:
Yamalube “R” (Yamalube Racing 2-cycle oil)
Mixing ratio:
24:1
2
NOTE:
The coolant level must be checked on a cold engine since the level varies with engine temperature.
If Yamalube “R” oil is not available, select an oil
from the following list.
Recommended 2-stroke engine oil
Mixing ratio
Castrol R30
Castrol A545
Castrol A747
20:1
1
EWB00510
WARNING
Wait for the engine and radiator to cool before
removing the radiator cap. You could be
burned by hot fluid and steam blown out under
pressure. Always put a thick rag over the cap
when opening. Allow any remaining pressure
to escape before completely removing the cap.
ECB00140
CAUTION:
3
4
5
6
7
8
9
Never mix two types of 2-stroke engine oil in
the same batch. Always use the same type of
oil to ensure maximum engine performance.
EBU19710
EBU19580
Transmission oil
Make sure that the transmission oil is at the specified level. Add oil as necessary. (See page 8-10.)
5-3
Front and rear brakes
10
Brake lever and brake pedal
● Check that there is no free play in the brake lever. If there is free play, have a Yamaha dealer
check the brake system.
● Check for correct brake pedal height. (See
11
1
2
3
4
5
6
7
8
9
10
11
●
page 8-35.) If the pedal height is incorrect, have
a Yamaha dealer adjust it.
Check the operation of the lever and pedal. They
should move smoothly and there should be a
firm feeling when the brakes are applied. If not,
have a Yamaha dealer check the brake system.
EWB00580
WARNING
Always check the brakes at the start of every
ride. Do not ride the ATV if you find any problem with the brakes or you could lose braking
ability, which could lead to an accident. If a
problem cannot be corrected by the adjustment procedures provided in this manual, have
a Yamaha dealer check for the cause.
Brake fluid level
Check the brake fluid level. Add fluid if necessary.
(See page 8-33.)
EBU19761
Recommended brake fluid:
DOT 4
Throttle lever
Check the operation of the throttle lever. It must
open smoothly and spring back to the idle position
when released. Have a Yamaha dealer correct if
necessary.
Brake fluid leakage
Check to see if any brake fluid is leaking out of the
pipe joints or brake fluid reservoirs. Apply the
brakes firmly for one minute. If there is any leakage, have a Yamaha dealer check the brake system.
EBU19770
Drive chain
Check the condition of the drive chain and check
the drive chain slack. Lubricate and adjust the
drive chain as necessary. (See page 8-39.)
Brake operation
Test the brakes at slow speed after starting out to
make sure they are working properly. If the brakes
do not provide proper braking performance, check
the brake pads for wear. (See page 8-32.)
5-4
●
EBU19791
Tires
EWB00601
WARNING
Use of improper tires on this ATV, or operation
of this ATV with improper or uneven tire pressure, may cause loss of control, increasing
your risk of accident.
Pay attention to the following.
● The tires listed below have been approved
by Yamaha Motor Co., Ltd. for this model.
Other tire combinations are not recommended.
Front:
Manufacturer/model:
DUNLOP/KT851B
Size:
AT21 x 7-10
Type:
Tubeless
Rear:
Manufacturer/model:
DUNLOP/KT877A
Size:
AT20 x 10-9
Type:
Tubeless
The tires should be set to the recommended
pressure:
Recommended tire pressure:
Front:
30 kPa (4.4 psi) (0.30 kgf/cm2)
Rear:
30 kPa (4.4 psi) (0.30 kgf/cm2)
Check and adjust tire pressures when the
tires are cold.
Tire pressures must be equal on both
sides.
Tire pressure below the minimum specified could cause the tire to dislodge from
the rim under severe riding conditions.
Minimum tire pressure:
Front:
27 kPa (3.9 psi) (0.27 kgf/cm2)
Rear:
27 kPa (3.9 psi) (0.27 kgf/cm2)
Use no more than the following pressures
when seating the tire beads.
Maximum tire seating pressure:
Front:
250 kPa (36 psi) (2.5 kgf/cm2)
Rear:
250 kPa (36 psi) (2.5 kgf/cm2)
●
2
3
4
●
5
●
6
●
5-5
1
7
8
9
10
11
1
2
3
4
5
6
7
Higher pressures and fast inflation may
cause a tire to burst. Inflate the tires very
slowly and carefully.
Set the tire pressure when the tires are cold. Set
the tire pressures to the following specifications:
Recommended pressure:
Front
30 kPa (4.4 psi) (0.30 kgf/cm2)
Rear
30 kPa (4.4 psi) (0.30 kgf/cm2)
Minimum:
Front
27 kPa (3.9 psi) (0.27 kgf/cm2)
Rear
27 kPa (3.9 psi) (0.27 kgf/cm2)
Maximum:
Front
33 kPa (4.8 psi) (0.33 kgf/cm2)
Rear
33 kPa (4.8 psi) (0.33 kgf/cm2)
EBU19820
Measuring the tire pressure
Use the low-pressure tire gauge.
NOTE:
The low-pressure tire gauge is included as standard equipment. Make two measurements of the
tire pressure and use the second reading. Dust or
dirt in the gauge could cause the first reading to be
incorrect.
8
1
9
10
EBU19830
11
Replace the tire when the tire groove decreases to
3 mm (0.12 in).
Tire wear limit
1. Low-pressure tire gauge
5-6
1
2
3
4
5
1. Tire wear limit
6
EBU19840
7
Chassis fasteners
8
Make sure that all nuts, bolts and screws are properly tightened.
9
EBU19850
Instruments, lights and switches
10
Check that all instruments, lights and switches are
working properly. Correct if necessary.
11
5-7
EBU19880
OPERATION
1
EBU19900
2
3
ECB00150
CAUTION:
Read the Owner’s Manual carefully before riding
the ATV.
See the “Engine break-in” section on page 6-4
prior to operating the engine for the first time.
EWB00630
4
5
6
7
1. Set the parking brake.
2. Turn the fuel cock to “ON”.
3. Turn the main switch to “ON” and the engine
stop switch to “RUN”.
4. Shift the transmission into neutral.
5. Use the starter (choke) in reference to the figure:
WARNING
Read the Owner’s Manual carefully to become
familiar with all controls in order to help prevent any loss of control, which could cause an
accident or injury. If there is a control or function you do not understand, ask your Yamaha
dealer.
Position (1):
● Cold engine start with ambient temperature below 5 °C (40 °F).
8
EBU20281
9
10
11
Starting a cold engine
EWB00640
WARNING
Position (2):
Cold engine start with ambient temperature between 0 °C (30 °F) and 30 °C (90 °F).
Always make sure all control cables work
smoothly before you begin riding in cold
weather. If the control cables are frozen or do
not work smoothly, you could be unable to
control the ATV, which could lead to an accident or collision.
●
Position (3):
● Cold engine start with ambient temperature
above 25 °C (80 °F).
6-1
Ambient temp./starter (choke) position
ECB00160
CAUTION:
0°
10°
30°
50°
1
2
20°
30° °C
70°
90° °F
3
4
1
1.
2.
3.
4.
2
For maximum engine life, always warm the engine up before starting off. Never accelerate
hard when the engine is cold!
1
8. Continue warming up the engine until it idles
smoothly, then return the starter (choke) to
position (3) before riding.
3
NOTE:
The engine is warm when it responds normally
to the throttle with the starter (choke) turned off.
● When the parking brake is applied, engine
speed is limited to 2300 r/min. Make sure the
parking brake is released before moving the
throttle lever, otherwise the engine will misfire,
preventing normal operation.
5
2
4
●
3
Fully open
Half open
Closed
Starter (choke)
6
7
8
9
6. Completely close the throttle lever and start
the engine by kicking the kickstarter.
7. If the engine is started with the starter (choke)
in position (1), the starter (choke) should be
returned to position (2) to warm up the engine.
If the engine is started with the starter (choke)
in position (2), keep the starter (choke) in this
position to warm up the engine.
EBU20291
Starting a warm engine
Follow the same procedure as for starting a cold
engine, with the exception that the starter (choke)
is not required when the engine is warm. Instead,
start the engine with the throttle slightly open.
6-2
10
11
1
2
3
4
5
EBU20520
EBU20570
Shifting
To start out and accelerate
1. Release the throttle lever.
This ATV has a 6-speed forward transmission. The
transmission allows you to control the amount of
power you have available at a given speed or for
starting, accelerating, climbing hills, etc.
To shift into neutral, return the throttle lever to the
closed position, apply the clutch, and then repeatedly depress the shift pedal until it stops.
When it stops, it will be in first gear. Raise the pedal
slightly to reach the neutral position.
ECB00200
CAUTION:
Always close the throttle before shifting gears,
otherwise damage to the engine and drive train
may result.
2. Pull the clutch lever to disengage the clutch.
3. Shift into first gear.
4. Open the throttle gradually and at the same
time, release the clutch lever slowly.
5. Once the ATV has attained adequate speed,
release the throttle, and at the same time,
quickly pull in the clutch lever.
6. Shift the transmission into second gear.
(Make sure not to shift the transmission into
neutral)
7. Open the throttle part way and gradually release the clutch lever.
8. Follow the same procedure when shifting to
the next higher gear.
6
7
6
5
4
3
2
8
9
N
10
11
1
2
1
EWB00730
1. Shift pedal
2. Neutral position
WARNING
Opening the throttle abruptly or releasing the
clutch lever too quickly could make the ATV
6-3
wheelie, which would increase the chance of
an accident, including an overturn.
EBU20650
To decelerate
When slowing down or stopping, release the throttle and apply the brakes smoothly and evenly. As
you slow down, shift to a lower gear. Be sure that
the engine has sufficiently slowed before engaging
a lower gear. Improper use of the brakes or shifting
can cause the tires to lose traction, reducing control and increasing the possibility of an accident.
●
for long distances. The transmission is properly lubricated only when the engine is running. Inadequate lubrication may damage
the transmission.
Always use the clutch when changing gears.
The engine, transmission and drive train are
not designed to withstand the shock of
forced shifting and can be damaged by shifting without using the clutch.
2
3
4
5
EBU20672
Engine break-in
EWB00710
WARNING
NOTE:
For ATVs equipped with an odometer or an hour
meter, follow the figures given in km (mi) or the
figures given in hours.
● For ATVs not equipped with an odometer or
hour meter, follow the figures given in hours.
●
Make sure the engine has sufficiently slowed
before shifting to a lower gear. Engaging a lower gear when the engine speed is too high
could make the wheels stop rotating and lose
traction. This could cause loss of control, an
accident and injury. It could also cause engine
or drive train damage.
There is never a more important period in the life of
your engine than the first 320 km (200 mi) or 20
hours of riding. For this reason, you should read
the following material carefully.
Since the engine is brand new, do not put an excessive load on it for the first 320 km (200 mi) or 20
hours. The various parts in the engine wear and
ECB00180
CAUTION:
●
1
Even with the transmission in the neutral position, do not coast for long periods of time
with the engine off, and do not tow the ATV
6-4
6
7
8
9
10
11
1
polish themselves to the correct operating clearances. During this period, prolonged full-throttle
operation or any condition that might result in engine overheating must be avoided.
the fuel cock to “OFF”.
1
2
3
4
5
6
7
8
0–160 km (0–100 mi) or 0–10 hours
Avoid prolonged operation above 1/2 throttle. Vary
the speed of the ATV regularly. Do not operate it at
one set throttle position.
2
160–320 km (100–200 mi) or 10–20 hours
Avoid prolonged operation above 3/4 throttle. Rev
the engine through the gears freely, but do not use
full throttle at any time.
1. Button
2. Parking brake lock plate
320 km (200 mi) or 20 hours and beyond
The ATV can now be operated normally.
ECB00220
9
10
11
CAUTION:
If any engine trouble should occur during the
engine break-in period, immediately have a
Yamaha dealer check the ATV.
EBU20721
Parking
When parking the ATV, stop the engine, shift into
first gear, apply the parking brake, and then turn
6-5
steep you could not walk up them easily.
1. Bring the ATV to a stop by applying the brakes
in first gear.
2. Stop the engine and release the clutch lever.
3. With the rear brake applied, apply the parking
brake and slowly release the brake pedal.
1
2
3
4
1
5
6
1. Locked position
7
EBU20860
Parking on a slope
8
EWB00850
WARNING
9
Avoid parking on hills or other inclines. Parking on a hill or other incline could cause the
ATV to roll out of control, increasing the
chance of an accident. If you must park on an
incline, place the ATV transversely across the
incline, shift into first gear, stop the engine, apply the parking brake, and then block the front
and rear wheels with rocks or other objects.
Do not park the ATV at all on hills that are so
EBU20910
Accessories and loading
10
EBU20920
11
Accessories
Accessories can affect the handling and control of
your ATV. Keep the following in mind when considering an accessory or operating an ATV which has
accessories.
6-6
●
1
2
3
4
5
●
6
7
●
8
9
10
11
●
Choose only accessories designed for your
ATV. Your Yamaha dealer has a variety of genuine Yamaha accessories. Other accessories
may also be available on the market. However,
it is not possible for Yamaha to test all nonYamaha accessories, nor control over their quality or suitability. Choose a genuine Yamaha accessory, or one that is equivalent in design and
quality.
Accessories should be rigidly and securely
mounted. An accessory which can shift position
or come off while you are riding could affect your
ability to control the ATV.
Do not mount an accessory where it could interfere with your ability to control the ATV. Examples include (but are not limited to) a heavy or
bulky object attached to the handlebars which
could make steering difficult, an accessory that
limits your ability to move around on the seat, or
one that limits your view.
Use extra caution when riding an ATV with accessories. The ATV may handle differently than
it does without accessories.
carry cargo or tow a trailer. If you choose to add accessories so that you can carry cargo or tow a trailer, you must use common sense and good
judgment as the stability and handling of an ATV
can be changed. When adding accessories, keep
the following points in mind:
● Never exceed the weight limits shown. An overloaded ATV can be unstable.
MAXIMUM LOADING LIMIT
ATV loading limit (total weight of rider, cargo,
accessories, and tongue):
100.0 kg (220 lb)
●
●
●
EBU20940
●
Loading
As originally equipped, this ATV is not designed to
●
6-7
If you are carrying cargo and towing a trailer, include the tongue weight in the maximum ATV
load limit.
Load cargo on the carriers as close to the center
of the ATV as possible. Put cargo at the rear of
the front carrier, at the front of the rear carrier,
and center it.
Tie down cargo securely to the carriers. Make
sure cargo in the trailer cannot move around. A
shifting load can cause an accident.
Make sure the load does not interfere with controls or your ability to see where you are going.
Ride more slowly than you would without a load.
●
●
●
The more weight you carry, the slower you
should go. Although conditions vary, it is good
practice not to exceed 2nd gear whenever you
are carrying heavier loads or when towing a trailer.
Allow more braking distance. A heavier ATV
takes longer to stop.
Avoid making sharp turns unless at very slow
speeds.
Avoid hills and rough terrain. Choose terrain
carefully. Added weight affects the stability and
handling of the ATV.
1
2
3
4
5
6
EWB00820
WARNING
7
Never exceed the stated load capacity for this
ATV. Overloading this ATV or carrying or towing cargo improperly could cause changes in
ATV handling which could lead to an accident.
Cargo should be properly distributed and securely attached. Reduce speed when carrying
cargo or pulling a trailer. Allow greater distance for braking.
8
9
10
11
6-8
EBU21141
RIDING YOUR ATV
1
2
3
4
5
6
7
8
9
10
11
7-1
Become familiar with this ATV at slow speeds first,
even if you are an experienced operator. Do not attempt to operate at maximum performance until
you are totally familiar with the ATV’s handling and
performance characteristics.
EBU21611
GETTING TO KNOW YOUR ATV
This ATV is intended for recreational use by experienced operators only. Even if you are an experienced operator of all other all terrain ATVs or
motorcycles, riding the ATV requires special skills
acquired through practice. Take your time to fully
learn techniques before attempting more difficult
maneuvers.
Riding your new ATV can be a very enjoyable activity, providing you with hours of pleasure. But it is
essential to familiarize yourself with the operation
of the ATV to achieve the skill necessary to enjoy
riding safely. Before you begin to ride, be sure you
have read this Owner’s Manual completely and understand the operation of the controls. Pay particular attention to the safety information on pages
1-1–1-4. Please also read all caution and warning
labels on your ATV.
1
2
EWB01380
WARNING
Never operate this ATV without proper instruction. Beginning and inexperienced operators
should regularly practice the skills and the operating techniques described in this Owner’s
Manual. The risk of an accident is greatly increased if the operator does not know how to
operate the ATV properly in different situations
and on different types of terrain.
3
4
5
6
7
8
Riding your ATV requires skills acquired
through practice over a period of time.
Take the time to learn the basic techniques well
before attempting more difficult maneuvers.
Not recommended for children under 16 years
of age.
RIDE WITH CARE AND GOOD JUDGEMENT
EWB01390
Get training if you are inexperienced.
Beginners should get training from a certified instructor.
WARNING
A child under 16 should never operate an ATV
7-2
9
10
11
1
with engine size greater than 90 cc. Use by children of ATVs that are not recommended for
their age can lead to severe injury or death of
the child.
harm to you and/or your passenger.
2
3
4
5
6
7
8
9
Apparel
Always wear an approved motorcycle helmet that
fits properly.
You should also wear:
● eye protection (goggles or face shield)
● gloves
● boots
● long-sleeved shirt or jacket
● long pants
This ATV is designed to carry operator only –
passengers prohibited.
EWB01400
10
11
WARNING
Never carry a passenger. The long seat is to allow the operator to shift position as needed
during operation. It is not for carrying passengers. Carrying a passenger on this ATV greatly
reduces your ability to balance and control this
ATV. It could cause an accident, resulting in
7-3
event of an accident. Operating without protective clothing increases your chances of severe
injury in the event of an accident.
Do not operate after consuming alcohol or
drugs.
The operator’s performance capability is reduced
by the influence of alcohol or drugs.
1
2
3
4
5
1.
2.
3.
4.
5.
Protective clothing
Goggles
Gloves
Boots
Helmet
6
7
8
EWB01410
9
WARNING
Never operate this ATV without wearing an approved motorcycle helmet, eye protection and
protective clothing. Operating without an approved motorcycle helmet increases your
chances of a severe head injury or death in the
event of an accident. Operating without eye
protection can result in an accident and increases your chances of a severe injury in the
EWB01420
WARNING
Never consume alcohol or drugs before or
while driving this ATV.
Pre-operation checks
Always perform the pre-operation checks listed on
7-4
10
11
1
page 5-1 before riding for proper care of the ATV
and to ensure safety.
Do not operate at speeds too fast for your
skills or the conditions.
EWB01430
EWB01450
WARNING
2
3
4
5
6
WARNING
Always inspect your ATV each time you use it
to make sure the ATV is in safe operating condition. Always follow the inspection and maintenance procedures and schedules described
in the Owner’s Manual. Failure to inspect the
ATV before operating or failure to properly
maintain the ATV increases the possibility of
an accident or equipment damage.
Always go at a speed that is proper for the terrain, visibility and operating conditions, and
your experience. Operating this ATV at speeds
too fast for your skills or the conditions increases your chances of losing control of the
ATV, which can result in an accident.
Speed limiter
For riders less experienced with this model, the
throttle lever housing is equipped with a speed limiter. The speed limiter keeps the throttle from fully
opening, even when the throttle lever is pushed to
the maximum. Turning in the adjusting screw limits
the maximum engine power available and decreases the maximum speed of the ATV. Turning
in the adjusting screw decreases top speed, and
turning it out increases top speed. (See page 4-3.)
EWB01440
7
8
9
10
11
WARNING
Always use the size and type tires specified in
the Owner’s Manual for this ATV on page 5-5.
Always maintain proper tire pressure as described in the Owner’s Manual on page 5-6.
Use of improper tires on this ATV, or operation
of this ATV with improper or uneven tire pressure, may cause loss of control, increasing
your risk of an accident.
7-5
MAXIMUM LOADING LIMIT
ATV loading limit (total weight of cargo, rider,
accessories, and tongue):
100.0 kg (220 lb)
1
2
3
EWB01460
WARNING
1
●
●
1. Adjusting screw
●
Loading and accessories
As originally equipped, this ATV is not designed to
carry cargo or tow a trailer. If you choose to add accessories so that you can carry cargo or tow a trailer, you must use common sense and good
judgment.
Use extra caution when riding the ATV with additional loads, such as accessories or cargo. The
ATV’s handling may be adversely affected. Reduce your speed when adding additional loads.
●
Never exceed the stated load capacity for
this ATV.
Cargo should be properly distributed and securely attached.
Reduce speed when carrying cargo or pulling a trailer. Allow greater distance for braking.
Always follow the instructions in your Owner’s Manual for carrying cargo or pulling a
trailer.
4
5
6
7
8
9
10
During operation
Always keep your feet on the footboards during operation, otherwise they may contact the rear
wheels.
7-6
11
EWB01480
WARNING
1
Never attempt stunts, such as wheelies or
jumps. Don’t try to show off.
2
3
4
5
6
7
8
9
10
11
EWB01470
WARNING
Always keep both hands on the handlebars
and both feet on the footboards of your ATV
during operation. Removing even one hand or
foot can reduce your ability to control the ATV
or could cause you to lose your balance and
fall off of the ATV. If you remove a foot from a
footboard, your foot or leg may come into contact with the rear wheels, which could injure
you or cause an accident.
Modifications
EWB01490
WARNING
Never modify this ATV through improper installation or use of accessories. All parts and
accessories added to this ATV should be genuine Yamaha or equivalent components designed for use on this ATV and should be
Avoid wheelies and jumping. You may lose control
of the ATV or overturn.
7-7
installed and used according to instructions.
Improper installation of accessories or modification of this ATV may cause changes in handling which in some situations could lead to an
accident. If you have questions, consult an authorized ATV dealer.
1
2
3
Exhaust system
The exhaust system on the ATV is very hot during
and following operation. To prevent burns, avoid
touching the exhaust system. Park the ATV in a
place where pedestrians or children are not likely
to touch it. Also, avoid parking in or around dry
grass, brush or other combustible materials to prevent causing a fire hazard.
4
5
BE CAREFUL WHERE YOU RIDE
This ATV is designed for use on unpaved surfaces
only. Riding on paved surfaces can cause loss of
control.
EWB01500
EWB01510
WARNING
●
●
●
WARNING
Do not touch the hot exhaust system.
Do not park the ATV during or after operation
in a place where others might be likely to
touch it.
Do not operate, idle, or park the ATV in dry
grass, dry ground cover, or combustible materials.
Always avoid paved surfaces, including sidewalks, driveways, parking lots and streets.
ATVs are designed for use on unpaved surfaces only. Paved surfaces may seriously affect
handling and control of the ATV, and may
cause the ATV to go out of control.
7-8
6
7
8
9
10
11
paved road or motorway. You can collide with
another vehicle. In many areas, it is illegal to
operate ATVs on public streets, roads and
highways.
1
2
3
4
5
6
7
8
9
10
11
While riding on unpaved public streets or roads
may be legal in your area, such operation can increase the risk of collision with other vehicles.
Watch carefully for other vehicles. Make sure you
know your country’s laws and regulations before
you ride on unpaved public streets or roads. Do not
ride on any paved public street, road or motorway.
Know the terrain where you ride. Ride cautiously in
unfamiliar areas. Stay alert for holes, rocks, or
roots in the terrain, and other hidden hazards
which may cause the ATV to upset.
EWB01530
WARNING
EWB01520
WARNING
Go slowly and be extra careful when operating
on unfamiliar terrain. Always be alert to chang-
Never operate this ATV on any paved street,
7-9
ing terrain conditions when operating the ATV.
1
2
3
4
5
6
When riding in an area where you might not easily
be seen, such as desert terrain, mount a caution
flag on the ATV. DO NOT use the flag pole bracket
as a trailer hitch.
EWB01540
WARNING
Do not operate on excessively rough, slippery
or loose terrain until you have learned and
practiced the skills necessary to control the
ATV on such terrain. Failure to use extra care
when operating on excessively rough, slippery
or loose terrain could cause loss of traction or
ATV control, which could result in an accident,
including an overturn.
7
8
9
10
11
7-10
1
2
3
4
5
6
7
8
9
10
11
Select a large, flat, unpaved area to become familiar with your ATV. Make sure that this area is free
of obstacles and other riders. You should practice
control of the throttle, brakes, shifting procedures,
and turning techniques in this area before trying
more difficult terrain. Always avoid riding on paved
surfaces: the ATV is designed for use on unpaved
surfaces only, and handling maneuvers are more
difficult to perform on pavement.
Set the parking brake and follow the instruction on
page 6-1 to start the engine. Once it has warmed
up you are ready to begin riding your ATV. As you
get on the ATV, be sure not to accidentally move
the shift pedal. Remember that the engine and exhaust pipe will be hot when riding and afterwards;
do not allow skin or clothing to come in contact with
EWB01550
WARNING
Always mount a caution flag on the ATV to
make you more visible when operating in areas
where you might not be seen by other vehicles.
Watch carefully for other vehicles.
Do not ride in areas posted “no trespassing”.
Do not ride on private property without getting permission.
7-11
these components.
With the engine idling, pull the clutch lever to disengage the clutch and shift into 1st gear, and then
release the parking brake. Open the throttle gradually, and at the same time, release the clutch lever slowly. Once the ATV has attained adequate
speed, release the throttle lever and at the same
time, quickly pull in the clutch lever and shift into
2nd gear. Open the throttle part way and gradually
release the clutch. Use this same procedure as
you move into the higher gears. Be sure to coordinate the use of the throttle and shift pedal properly.
If the throttle is applied too abruptly or if the throttle
is not released during shifting, or if the shift pedal
is not released before applying the throttle, the
front wheels may lift off the ground, resulting in a
loss of directional control. Avoid higher speeds until you are thoroughly familiar with the operation of
your ATV.
ECB00230
CAUTION:
Do not shift gears without releasing the throttle. Damage to the engine or drive train may occur.
1
When slowing down or stopping, release the throttle and apply the brakes smoothly and evenly. As
you slow down, shift to a lower gear. Be sure that
the engine has sufficiently slowed before engaging
a lower gear. Improper use of the brakes or shifting
can cause the tires to lose traction, reducing control and increasing the possibility of an accident.
3
2
4
5
6
EWB01560
WARNING
Make sure the engine has sufficiently slowed
before shifting to a lower gear. Engaging a lower gear when the engine speed is too high
could cause the wheels to stop rotating.
7
8
9
10
EWB01720
WARNING
TURNING YOUR ATV
To achieve maximum traction on unpaved surfaces, the two rear wheels are mounted solidly on one
axle and turn together at the same speed. Therefore, unless the wheel on the inside of the turn is allowed to slip or lose some traction, the ATV will
resist turning. A special turning technique must be
Always open the throttle gradually and release
the clutch lever slowly. Otherwise, the ATV
could wheelie which would increase the
chance of an accident.
7-12
11
1
used to allow the ATV to make turns quickly and
easily. It is essential that this skill be learned first at
low speed.
1
2
EWB01570
2
3
4
5
6
7
8
9
10
WARNING
Always follow proper procedures for turning
as described in this Owner’s Manual. Practice
turning at low speeds before attempting to turn
at faster speeds. Do not turn at speeds too fast
for your skills or the conditions.
As you approach a curve, slow down and begin to
turn the handlebars in the desired direction. As you
do so, put your weight on the footboard to the outside of the turn (opposite your desired direction)
and lean your upper body into the turn. Use the
throttle to maintain an even speed through the
turn. This maneuver will let the wheel on the inside
of the turn slip slightly, allowing the ATV to make
the turn properly.
1. Lean towards inside of turn.
2. Support your weight on the outer footrest.
This procedure should be practiced at slow speed
many times in a large unpaved area with no obstacles. If an incorrect technique is used, your ATV
may continue to go straight. If the ATV doesn’t
turn, come to a stop and then practice the procedure again. If the riding surface is slippery or loose,
it may help to position more of your weight over the
front wheels by moving forward on the seat.
Once you have learned this technique, you should
be able to perform it at higher speeds or in tighter
curves.
Improper riding procedures such as abrupt throttle
11
7-13
changes, excessive braking, incorrect body movements, or too much speed for the sharpness of the
turn may cause the ATV to tip. If the ATV begins to
tip over to the outside while negotiating a turn, lean
more to the inside. It may also be necessary to
gradually let off on the throttle and steer to the outside of the turn to avoid tipping over.
Remember: Avoid higher speeds until you are
thoroughly familiar with the operation of your ATV.
It is important when climbing a hill to make sure
that your weight is transferred forward on the ATV.
This can be accomplished by leaning forward and,
on steeper inclines, standing on the footboards
and leaning forward over the handlebars.
1
2
EWB01590
WARNING
●
CLIMBING UPHILL
Use proper riding techniques to avoid ATV overturns on hills. Be sure that you can maneuver your
ATV well on flat ground before attempting any incline and then practice riding first on gentle slopes.
Try more difficult climbs only after you have developed your skill. In all cases avoid inclines with slippery or loose surfaces, or obstacles that might
cause you to lose control.
●
●
●
●
●
EWB01580
WARNING
Never operate the ATV on hills too steep for the
ATV or for your abilities. The ATV can overturn
more easily on extremely steep hills than on
level surfaces or small hills. Practice on smaller hills before attempting large hills.
7-14
Always follow proper procedures for climbing hills as described in this Owner’s Manual.
Always check the terrain carefully before
you start up any hill.
Never climb hills with excessively slippery or
loose surfaces.
Shift your weight forward.
Never open the throttle suddenly or make
sudden gear changes. The ATV could flip
over backwards.
Never go over the top of any hill at high
speed. An obstacle, a sharp drop, or another
vehicle or person could be on the other side
of the hill.
3
4
5
6
7
8
9
10
11
OK
1
●
●
2
3
scribed in the Owner’s Manual.
Avoid hills with excessively slippery or loose
surfaces.
Shift your weight to the uphill side of the
ATV.
OK
4
5
6
7
8
If you are climbing a hill and you find that you have
not properly judged your ability to make it to the
top, you should turn the ATV around while you still
have forward motion (provided you have the room
to do so) and go down the hill.
EWB01600
9
10
11
If your ATV has stalled or stopped and you believe
you can continue up the hill, restart carefully to
make sure you do not lift the front wheels which
could cause you to lose control. If you are unable
to continue up the hill, dismount the ATV on the uphill side. Physically turn the ATV around and then
descend the hill.
If you start to roll backwards, DO NOT apply the
rear brake to stop or try to put the ATV in gear. The
ATV could easily tip over backwards. Instead, ap-
WARNING
Never attempt to turn the ATV around on any
hill until you have mastered the turning technique as described in the Owner’s Manual on
level ground. Be very careful when turning on
any hill. Avoid crossing the side of a steep hill
if possible.
When crossing the side of a hill:
● Always follow proper procedures as de7-15
ply the front brake gradually, or dismount the ATV
immediately on the uphill side.
1
EWB01731
WARNING
2
Use the proper gear and maintain a steady
speed when climbing a hill.
If you lose all forward speed:
● Keep weight uphill.
● Apply the brakes.
● Lock the parking brake after you are
stopped.
If you begin rolling backwards:
● Keep weight uphill.
● Never apply the rear brake while rolling
backwards. Apply the front brake.
● When fully stopped, apply the rear brake as
well, and then lock the parking brake.
Dismount on uphill side or to a side if pointed
straight uphill. Turn the ATV around and remount, following the procedure described in
the Owner’s Manual.
3
4
5
6
RIDING DOWNHILL
When riding your ATV downhill, shift your weight
as far to the rear and uphill side of the ATV as possible. Move back on the seat and sit with your arms
straight. Choose a low gear which will allow the engine compression to do most of the braking for
you. Improper braking may cause a loss of traction.
Use caution while descending a hill with loose or
slippery surfaces. Braking ability and traction may
be adversely affected by these surfaces. Improper
braking may also cause a loss of traction.
Whenever possible, ride your ATV straight down7-16
7
8
9
10
11
1
2
3
4
5
6
7
8
9
hill. Avoid sharp angles which could allow the ATV
to tip or roll over. Carefully choose your path and
ride no faster than you will be able to react to obstacles which may appear.
OK
EWB01620
WARNING
Always follow proper procedures for going
down hills as described in this Owner’s Manual.
Note: a special technique is required when
braking as you go down a hill.
● Always check the terrain carefully before
you start down any hill.
● Shift your weight backward.
● Never go down a hill at high speed.
● Avoid going down a hill at an angle that
would cause the ATV to lean sharply to one
side. Go straight down the hill where possible.
CROSSING A SLOPE
Traversing a sloping surface on your ATV requires
you to properly position your weight to maintain
proper balance. Be sure that you have learned the
basic riding skills on flat ground before attempting
to cross a sloping surface. Avoid slopes with slippery surfaces or rough terrain that may upset your
balance.
As you travel across a slope, lean your body in the
uphill direction. It may be necessary to correct the
steering when riding on loose surfaces by pointing
the front wheels slightly uphill. When riding on
slopes, be sure not to make sharp turns either up
or down hill.
If your ATV does begin to tip over, gradually steer
10
11
7-17
in the downhill direction if there are no obstacles in
your path. As you regain proper balance, gradually
steer again in the direction you wish to travel.
OK
1
EWB01631
2
WARNING
Never attempt to turn the ATV around on any
hill until you have mastered the turning technique as described in the Owner’s Manual on
level ground. Be very careful when turning on
any hill. Avoid crossing the side of a steep hill
if possible.
When crossing the side of a hill:
● Always follow proper procedures as described in the Owner’s Manual.
● Avoid hills with excessively slippery or loose
surfaces.
● Shift your weight to the uphill side of the
ATV.
3
4
5
CROSSING THROUGH SHALLOW WATER
The ATV can be used to cross slow moving, shallow water of up to a maximum of 35 cm (14 in) in
depth. Before entering the water, choose your path
carefully. Enter where there is no sharp drop off,
and avoid rocks or other obstacles which may be
slippery or upset the ATV. Drive slowly and carefully.
6
7
8
9
10
EWB01640
WARNING
Never operate this ATV in fast flowing water or
in water deeper than that specified in your
Owner’s Manual. Remember that wet brakes
may have reduced stopping ability. Test your
brakes after leaving water. If necessary, apply
7-18
11
1
2
them several times to let friction dry out the linings. If the ATV is operated through deep or
fast flowing water, the tires may float, causing
loss of traction and loss of control, which
could lead to an accident.
3
4
5
6
ECB00240
CAUTION:
7
After riding your ATV in water, be sure to drain
the trapped water by removing the check hose
at the bottom of the air filter case. Wash the
ATV in fresh water if it has been operated in
salt water or muddy conditions.
8
9
10
11
Test your brakes after leaving the water. Do not
continue to ride your ATV without verifying that you
have regained proper braking ability.
7-19
you go over obstacles, always follow proper
procedures as described in the Owner’s Manual.
SLIDING AND SKIDDING
Care should be used when riding on loose or slippery surfaces since the ATV may slide. If unexpected and uncorrected, sliding could lead to an
accident.
To reduce the tendency for the front wheels to slide
in loose or slippery conditions, positioning your
weight over the front wheels will sometimes help.
1
1. Air filter case check hose
1
2
3
4
5
6
7
RIDING OVER ROUGH TERRAIN
Riding over rough terrain should be done with caution. Look out for obstacles which could cause
damage to the ATV or could lead to an upset or accident. Be sure to keep your feet firmly mounted on
the footboards at all times. Avoid jumping the ATV
as loss of control and damage to the ATV may result.
8
9
10
11
EWB01650
WARNING
Before operating in a new area, check for obstacles. Never attempt to ride over large obstacles, such as large rocks or fallen trees. When
If the rear wheels of your ATV start to slide sideways, control can usually be regained (if there is
room to do so) by steering in the direction of the
7-20
slide. Applying the brakes or accelerating is not
recommended until you have corrected the slide.
go slowly and be very cautious in order to reduce the chance of skidding or sliding out of
control.
1
2
WHAT TO DO IF...
This section is designed to be a reference guide
only. Be sure to read each section on riding techniques completely.
3
4
WHAT TO DO...
● If your ATV doesn’t turn when you want it to:
Bring the ATV to a stop and practice the turning
maneuvers again. Be sure you are putting your
weight on the footboard to the outside of the
turn. Position your weight over the front wheels
for better control. (See page 7-12.)
● If your ATV begins to tip while turning:
Lean more into the turn to regain balance. If necessary, gradually let off the throttle and/or steer
to the outside of the turn. (See page 7-12.)
● If your ATV starts to slide sideways:
Steer in the direction of the slide if you have the
room. Applying the brakes or accelerating is not
recommended until you have corrected the
slide. (See page 7-20.)
● If your ATV can’t make it up a hill you are trying
5
6
7
8
9
10
11
With practice, over a period of time, skill at controlled sliding can be developed. The terrain
should be chosen carefully before attempting such
maneuvers, since both stability and control are reduced. Bear in mind that sliding maneuvers should
always be avoided on extremely slippery surfaces
such as ice, since all control may be lost.
EWB01661
WARNING
Learn to safely control skidding or sliding by
practicing at low speeds and on level, smooth
terrain.
On extremely slippery surfaces, such as ice,
7-21
●
●
to climb:
Turn the ATV around if you still have forward
speed. If not, stop, dismount on the uphill side of
the ATV and physically turn the ATV around. If
the ATV starts to slip backwards, DO NOT USE
THE REAR BRAKE – the ATV may tip over on
top of you. Dismount the ATV on the uphill side.
(See page 7-14.)
If your ATV is traversing a sloping surface:
Be sure to ride with your weight positioned towards the uphill side of the ATV to maintain
proper balance. If the ATV starts to tip, steer
down the hill (if there are no obstacles in your
way) to regain balance. If you discover that the
ATV is going to tip over, dismount on the uphill
side. (See page 7-14.)
If your ATV encounters shallow water:
Ride slowly and carefully through slow moving
water, watching for obstacles. Be sure to let water drain from the ATV and CHECK YOUR
BRAKES FOR PROPER OPERATION when
you come out of the water. Do not continue to
ride your ATV until you have regained adequate
braking ability. (See page 7-18.)
1
2
3
4
5
6
7
8
9
10
11
7-22
EBU28781
PERIODIC MAINTENANCE AND MINOR REPAIR
1
maintenance work.
EBU21670
2
3
4
5
6
7
8
9
10
11
Safety is an obligation of the owner. Periodic inspection, adjustment and lubrication will keep your
ATV in the safest and best operating condition
possible. The most important points of inspection,
adjustment, and lubrication are explained on the
following pages.
The intervals given in the periodic maintenance
and lubrication chart should be considered as a
general guide under normal riding conditions.
However, DEPENDING ON THE WEATHER,
TERRAIN, GEOGRAPHICAL LOCATION, AND
INDIVIDUAL USE, THE MAINTENANCE INTERVALS MAY NEED TO BE SHORTENED.
EBU21690
Owner’s manual and tool kit
Be sure to put this owner’s manual and the lowpressure tire gauge in the plastic bag and always
carry them along with the owner’s tool kit under the
seat.
1
3
EWB01840
WARNING
2
Never service an engine while it is running.
Moving parts can catch clothing or parts of the
body, causing injury. Electrical components
can cause shocks or start fires. Turn off the engine when performing maintenance unless
otherwise specified. Have a Yamaha dealer
perform the service if you are not familiar with
1. Owner’s manual
2. Low-pressure tire gauge
3. Owner’s tool kit
8-1
The service information included in this manual
and the tools provided in the owner’s tool kit are intended to assist you in the performance of preventive maintenance and minor repairs. However,
additional tools such as a torque wrench may be
necessary to perform certain maintenance work
correctly.
1
2
3
4
NOTE:
If you do not have the tools or experience required
for a particular job, have a Yamaha dealer perform
it for you.
5
6
EWB01850
WARNING
7
Never modify this ATV through improper installation or use of accessories, as it may
cause changes in handling, which in some situations could lead to an accident. All parts and
accessories added to this ATV should be genuine Yamaha or equivalent components designed for use on this ATV and should be
installed and used according to instructions. If
you have questions, consult an authorized
Yamaha ATV dealer.
8
9
10
11
8-2
EBU21742
Periodic maintenance chart for the emission control system
1
2
3
4
NOTE:
● For ATVs not equipped with an odometer or an hour meter, follow the month maintenance intervals.
● For ATVs equipped with an odometer or an hour meter, follow the km (mi) or hours maintenance intervals. However, keep in mind that if the ATV isn’t used for a long period of time, the month maintenance
intervals should be followed.
● Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools,
data and technical skills.
5
INITIAL
6
NO.
ITEM
7
CHECK OR MAINTENANCE
JOB
Whichever comes
first
8
1
9
*
2
Fuel line
Spark plugs
●
●
●
10
3
*
Carburetors
4
*
Crankcase breather
system
●
11
●
●
5
*
Exhaust system
●
month
1
3
6
6
12
km
(mi)
320
(200)
1300
(800)
2500
(1600)
2500
(1600)
5000
(3200)
hours
20
80
160
160
320
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
Check fuel hoses for cracks or other damage, and
replace if necessary.
Replace.
Check starter (choke) operation and correct if necessary.
Check engine idling speed and synchronization,
and adjust if necessary.
Check breather hose for cracks or other damage,
and replace if necessary.
Check for leakage and replace gasket(s) if necessary.
Check for looseness and tighten all screw clamps
and joints if necessary.
8-3
EVERY
√
INITIAL
NO.
6
ITEM
Spark arrester
CHECK OR MAINTENANCE
JOB
●
Whichever comes
first
Clean.
EVERY
month
1
3
6
6
12
km
(mi)
320
(200)
1300
(800)
2500
(1600)
2500
(1600)
5000
(3200)
hours
20
80
160
160
320
√
√
√
1
2
3
4
5
6
7
8
9
10
11
8-4
EBU21864
General maintenance and lubrication chart
1
2
INITIAL
NO.
ITEM
CHECK OR MAINTENANCE
JOB
3
Whichever comes
first
1
3
6
6
12
km
(mi)
320
(200)
1300
(800)
2500
(1600)
2500
(1600)
5000
(3200)
20
80
160
160
320
hours
4
5
1
2
*
Air filter element
●
Clean and replace if necessary.
Clutch
●
Check operation and adjust if necessary.
Check operation and correct if necessary.
Check fluid level and ATV for fluid leakage, and
correct if necessary.
Replace brake pads.
Check operation and correct if necessary.
Check brake pedal free play and adjust if necessary.
Check fluid level and ATV for fluid leakage, and
correct if necessary.
Replace brake pads.
Check for cracks or other damage, and replace if
necessary.
Replace.
Check operation and adjust if necessary.
Check runout and for damage, and replace if necessary.
Check tread depth and for damage, and replace if
necessary.
Check air pressure and balance, and correct if
necessary.
●
6
3
*
Front brake
●
●
7
●
●
8
4
*
Rear brake
●
9
●
10
●
5
*
Brake hoses
6
*
Parking brake
●
11
7
*
Wheels
●
●
●
8
*
Tires
●
8-5
EVERY
month
Every 20–40 hours (more often in wet or
dusty areas)
√
√
√
√
√
√
√
√
√
Whenever worn to the limit
√
√
√
√
√
Whenever worn to the limit
√
√
√
√
Every 4 years
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
INITIAL
NO.
ITEM
9
*
Wheel hub bearings
10
*
Upper and lower
arm pivots
11
Drive chain
CHECK OR MAINTENANCE
JOB
*
Drive chain rollers
13
*
Chassis fasteners
14
*
Shock absorber
assemblies
15
*
Steering system
Transmission oil
17
Cooling system
18
Moving parts and
cables
3
6
6
12
km
(mi)
320
(200)
1300
(800)
2500
(1600)
2500
(1600)
5000
(3200)
hours
20
80
160
160
320
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
7
√
√
√
8
√
√
√
9
√
√
√
10
√
√
√
11
√
√
●
Lubricate with lithium-soap-based grease.
●
●
Check chain slack and adjust if necessary.
Check rear wheel alignment and correct if necesssary.
Clean and lubricate.
Check for wear and replace if necessary.
Make sure that all nuts, bolts, and screws are
properly tightened.
Check operation and correct if necessary.
Check for oil leakage and replace if necessary.
Check operation and repair or replace if damaged.
Check toe-in and adjust if necessary.
Change.
Check ATV for oil leakage, and correct if necessary.
Check coolant level and ATV for coolant leakage,
and correct if necessary.
Replace coolant.
●
Lubricate.
●
●
●
●
●
●
●
●
●
*
1
Check for looseness or damage, and replace if
necessary.
●
16
month
●
●
12
Whichever comes
first
√
1
2
3
4
5
√
6
√
√
√
√
√
√
√
Every 2 years
√
8-6
EVERY
√
INITIAL
1
NO.
ITEM
CHECK OR MAINTENANCE
JOB
2
3
4
5
6
7
8
9
10
20
21
*
Throttle lever housing and cable
*
Front and rear brake
switches
*
Lights and switches
1
3
6
6
12
km
(mi)
320
(200)
1300
(800)
2500
(1600)
2500
(1600)
5000
(3200)
hours
20
80
160
160
320
√
√
√
√
√
●
●
Check operation and correct if necessary.
√
√
√
√
√
●
Check operation and correct if necessary.
Adjust headlight beams.
√
√
√
√
√
●
●
EBU23070
NOTE:
● The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
● Hydraulic brake service
Regularly check and, if necessary, correct the brake fluid level.
Every two years replace the internal components of the brake master cylinders and calipers, and
change the brake fluid.
Replace the brake hoses every four years and if cracked or damaged.
●
●
11
month
Check operation and correct if necessary.
Check throttle cable free play and adjust if necessary.
Lubricate throttle lever housing and cable.
●
19
Whichever comes
first
EVERY
●
8-7
kit.
EBU28320
Checking the spark plugs
1
The spark plugs are important engine components, which are easy to check. Since heat and deposits will cause any spark plug to slowly erode,
the spark plugs should be removed and checked in
accordance with the periodic maintenance and lubrication chart. In addition, the condition of the
spark plugs can reveal the condition of the engine.
1
2
3
4
5
To remove a spark plug
1. Remove the spark plug cap.
6
1. Spark plug wrench
7
To check the spark plugs
1. Check that the porcelain insulator around the
center electrode of each spark plug is a medium-to-light tan (the ideal color when the ATV
is ridden normally).
2. Check that all spark plugs installed in the engine have the same color.
1
NOTE:
If any spark plug shows a distinctly different color,
the engine could be operating improperly. Do not
attempt to diagnose such problems yourself. In-
1. Spark plug cap
2. Remove the spark plug as shown, with the
spark plug wrench included in the owner’s tool
8-8
8
9
10
11
stead, have a Yamaha dealer check the ATV.
1
2
3
3. Check each spark plug for electrode erosion
and excessive carbon or other deposits, and
replace it if necessary.
Specified spark plug:
NGK/BR8ES
4
5
6
7
To install a spark plug
1. Measure the spark plug gap with a wire thickness gauge and, if necessary, adjust the gap
to specification.
1. Spark plug gap
Spark plug gap:
0.7–0.8 mm (0.028–0.031 in)
2. Clean the surface of the spark plug gasket
and its mating surface, and then wipe off any
grime from the spark plug threads.
3. Install the spark plug with the spark plug
wrench, and then tighten it to the specified
torque.
8
9
10
Tightening torque:
Spark plug:
20 Nm (2.0 m·kgf, 14 ft·lbf)
11
NOTE:
If a torque wrench is not available when installing
8-9
a spark plug, a good estimate of the correct torque
is 1/4–1/2 turn past finger tight. However, the spark
plug should be tightened to the specified torque as
soon as possible.
2
3
1
4. Install the spark plug cap.
1
2
3
EBU23341
Transmission oil
4
The transmission oil level should be checked before each ride. In addition, the transmission oil
must be changed at the intervals specified in the
periodic maintenance and lubrication chart.
5
To check the transmission oil level
1. Place the ATV on a level surface.
2. Start the engine, warm it up for several minutes, and then turn it off.
3. Wait a few minutes until the oil settles, remove
the oil filler cap, wipe the dipstick off with a
clean rag, insert it back into the oil filler hole
(without screwing it in), and then remove it
again to check the oil level.
1. Dipstick
2. Maximum level mark
3. Minimum level mark
6
NOTE:
The transmission oil should be between the minimum and maximum level marks.
8
4. If the oil is at or below the minimum level mark,
add sufficient oil of the recommended type to
raise it to the correct level.
5. Insert the dipstick into the oil filler hole, and
then tighten the oil filler cap.
10
To change the transmission oil
1. Place the ATV on a level surface.
8-10
7
9
11
1
2
3
2. Start the engine, warm it up for several minutes, and then turn it off.
3. Place an oil pan under the transmission to collect the used oil.
4. Remove the oil filler cap and the drain bolt to
drain the oil from the transmission.
6. Add the specified amount of the recommended transmission oil, and then install and tighten the oil filler cap.
Recommended transmission oil:
See page 10-1.
Oil quantity:
1.5 L (1.59 US qt) (1.32 Imp.qt)
4
ECB00430
CAUTION:
5
●
6
7
8
9
10
11
1
1. Transmission oil drain bolt
●
5. Install the drain bolt, and then tighten it to the
specified torque.
In order to prevent clutch slippage (since the
transmission oil also lubricates the clutch),
do not mix any chemical additives. Do not
use oils with a diesel specification of “CD” or
oils of a higher quality than specified. In addition, do not use oils labeled “ENERGY
CONSERVING II” or higher.
Make sure that no foreign material enters the
crankcase.
7. Start the engine, and then let it idle for several
minutes while checking the transmission for
oil leakage. If oil is leaking, immediately turn
the engine off and check for the cause.
8. Turn the engine off, and then check the oil level and correct it if necessary.
Tightening torque:
Transmission oil drain bolt:
20 Nm (2.0 m·kgf, 14 ft·lbf)
8-11
EBU23470
Coolant
The coolant level should be checked before each
ride. In addition, the coolant must be changed at
the intervals specified in the periodic maintenance
and lubrication chart.
1
2
1
2
EBU23501
To check the coolant level
1. Place the ATV on a level surface.
3
4
5
NOTE:
The coolant level must be checked on a cold engine since the level varies with engine temperature.
1. Maximum level mark
2. Minimum level mark
6
7
2. Check the coolant level in the coolant reservoir.
3. If the coolant is at or below the minimum level
mark, remove the seat. (See page 4-11.)
4. Open the coolant reservoir cover.
NOTE:
The coolant should be between the minimum and
maximum level marks.
8
9
10
11
8-12
1
1
●
2
2
3
●
4
5
6
ter or salt water since it is harmful to the engine.
If water has been used instead of coolant, replace it with coolant as soon as possible,
otherwise the cooling system will not be protected against frost and corrosion.
If water has been added to the coolant, have
a Yamaha dealer check the antifreeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will
be reduced.
6. Close the coolant reservoir cover.
7. Install the seat.
1. Coolant reservoir cover
2. Coolant reservoir cap
7
8
9
NOTE:
If the engine overheats, see page 8-52 for further
instructions.
5. Remove the reservoir cap, add coolant or distilled water to the maximum level mark, and
then install the reservoir cap.
Coolant reservoir capacity (up to the maximum
level mark):
0.28 L (0.30 US qt) (0.25 Imp.qt)
10
11
EBU23521
To change the coolant
EWB01890
WARNING
ECB00401
Wait for the engine and radiator to cool before
removing the radiator cap. You could be
burned by hot fluid and steam blown out under
pressure. Always place a thick rag over the cap
CAUTION:
●
If coolant is not available, use distilled water
or soft tap water instead. Do not use hard wa8-13
when opening. Allow any remaining pressure
to escape before completely removing the cap.
1
1. Place the ATV on a level surface.
2. Remove the radiator cover by removing the
bolts.
2
1
1
1
3
2
4
5
2
1. Coolant drain bolt
4. Remove the radiator cap.
6
7
8
9
1. Radiator cover
2. Radiator cover bolt
10
3. Place a container under the engine and remove the coolant drain bolts.
11
8-14
1
2
1
1
3
4
5
6
7
1. Radiator cap
1. Coolant reservoir cap
5. Remove the coolant reservoir cap.
6. Disconnect the hose on the coolant reservoir
side and drain the coolant from the coolant
reservoir.
8
9
10
11
8-15
voir to the maximum level mark, and then install the reservoir cap.
11. Pour the recommended coolant into the radiator until it is full.
1
1
2
Antifreeze/water mixture ratio:
1:1
Recommended antifreeze:
High-quality ethylene glycol antifreeze containing corrosion inhibitors for aluminum engines
Coolant quantity:
Radiator capacity (including all routes):
1.50 L (1.59 US qt) (1.32 Imp.qt)
Coolant reservoir capacity (up to the maximum level mark):
0.28 L (0.30 US qt) (0.25 Imp.qt)
2
1. Coolant reservoir hose
2. Coolant reservoir
7. After draining the coolant, thoroughly flush the
cooling system with clean tap water.
8. Replace the coolant drain bolt washers if they
are damaged, and then tighten the coolant
drain bolts to the specified torque.
ECB00401
CAUTION:
●
Tightening torque:
Coolant drain bolt:
10 Nm (1.0 m·kgf, 7 ft·lbf)
●
9. Connect the coolant reservoir hose.
10. Pour the recommended coolant into the reser8-16
If coolant is not available, use distilled water
or soft tap water instead. Do not use hard water or salt water since it is harmful to the engine.
If water has been used instead of coolant, replace it with coolant as soon as possible,
otherwise the cooling system will not be pro-
3
4
5
6
7
8
9
10
11
●
1
2
3
4
5
6
7
tected against frost and corrosion.
If water has been added to the coolant, have
a Yamaha dealer check the antifreeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will
be reduced.
NOTE:
There is a check hose at the bottom of the air filter
case. If dust or water collects in this hose, empty
the hose and clean the air filter element and air filter case.
12. Install the radiator cap, start the engine, let it
idle for several minutes, and then turn it off.
13. Remove the radiator cap to check the coolant
level in the radiator. If it is low, add sufficient
coolant until it reaches the top of the radiator,
and then install the radiator cap.
14. Start the engine, and then check for coolant
leakage.
9
NOTE:
If any leakage is found, have a Yamaha dealer
check the cooling system.
10
15. Install the radiator cover by installing the bolts.
11
Cleaning the air filter element
8
areas.
1
1. Air filter case check hose
EBU23621
1. Remove the seat. (See page 4-11.)
2. Remove the air filter case cover by unhooking
the holders.
The air filter element should be cleaned at the intervals specified in the periodic maintenance and
lubrication chart. Clean the air filter element more
frequently if you are riding in unusually wet or dusty
8-17
2
1
2
2
3
4
1
1
5
1. Air filter case cover
2. Air filter case cover holder
1. Air filter element lock plate
4. Remove the lock plate by turning it, and then
remove the sponge material from the air filter
element frame.
3. Pull the air filter element out of the air filter
case.
6
7
8
9
10
11
8-18
ECB00440
CAUTION:
2
1
Do not twist the sponge material when squeezing it.
1
2
3
2
1
3
4
5
6
7
8
9
10
11
1. Sponge material
2. Air filter element frame
3. Air filter element lock plate
5. Wash the sponge material gently but thoroughly in solvent.
7. Check the sponge material and replace it if
damaged.
8. Apply a quality foam air filter oil to the sponge
material.
EWB01940
WARNING
Always use parts cleaning solvent to clean the
sponge material. Never use low-flash-point
solvents or gasoline to clean the sponge material because the engine could catch fire or explode.
NOTE:
The sponge material should be wet but not dripping.
9. Pull the sponge material over the air filter element frame, and then install the lock plate by
6. Squeeze the excess solvent out of the sponge
material and let it dry.
8-19
joint to the carburetor fittings and the rubber joint
manifold fittings for an air-tight seal. Tighten all fittings securely to avoid the possibility of unfiltered
air entering the engine.
turning it.
1
1
2
ECB00460
CAUTION:
●
●
1. Air filter element
10. Insert the air filter element into the air filter
case, and then install the air filter case cover
by hooking the holders onto the air filter case.
11. Install the seat.
Make sure that the air filter element is properly seated in the air filter case.
Never operate the engine with the air filter element removed. This will allow unfiltered air
to enter the engine, causing rapid engine
wear and possible engine damage. Additionally, operation without the air filter element
will affect carburetor jetting with subsequent
poor performance and possible engine overheating.
3
4
5
6
7
8
9
EBU28310
NOTE:
The air filter element should be cleaned every 20–
40 hours. It should be cleaned and lubricated more
often if the ATV is operated in extremely dusty areas. Each time the air filter element maintenance
is performed, check the air inlet of the air filter case
for obstructions. Check the air filter case rubber
8-20
Cleaning the spark arrester
10
Be sure the exhaust pipe and muffler are cool before cleaning the spark arrester.
1. Remove the screws.
11
1
2
1
3
1
2
3
4
5
6
7
8
9
10
1. Screw
1. Tailpipe
2. Spark arrester
3. Gasket
2. Remove the tailpipe by pulling it out of the
muffler.
3. Tap the tailpipe lightly, and then use a wire
brush to remove any carbon deposits from the
spark arrester portion of the tailpipe and inside
of the tailpipe housing.
4. Make sure the gasket is properly positioned,
then insert the tailpipe into the muffler and
align the screw holes.
5. Install the screws and tighten them.
EWB02340
WARNING
11
Do not start the engine when cleaning the
spark arrester, otherwise it could cause injury
to the eyes, burns, carbon monoxide poisoning, possibly leading to death, and start a fire.
Always let the exhaust system cool prior to
8-21
touching exhaust components.
erating the ATV to make sure it is working
correctly.
1
EBU23992
Standard settings
Changing the carburetor settings
Main jet
Jet needle clip position
Pilot air screw
In extremely cold weather, it is necessary to
change the carburetor settings to maintain optimum engine performance and to prevent engine
damage.
#200
3rd groove
2.0 turns out
WARNING
●
●
●
3
4
EWB01990
●
2
1
Improperly servicing or adjusting the carburetors could cause them to malfunction with
the possibility of an accident, or the carburetors could leak fuel, which would be a fire
hazard.
Carburetor adjustments should only be performed by a Yamaha dealer. Do not attempt
to perform these procedures unless you
have mechanical knowledge and the necessary tools.
Do not perform this procedure while the engine is hot. Place a rag under each carburetor to catch any fuel. Wipe up any spilled fuel
completely.
After servicing the carburetors, always
check the throttle lever operation before op-
5
6
7
8
9
1. Main jet number
10
11
8-22
1
2
1
3
4
5
6
1. Standard position: Groove 3
7
Carburetor setting chart
Altitude
8
Temperature
9
10
11
0–1500 m (5000 ft)
Main jet
Above 0°C (32°F)
from +5 °C (41 °F) to
–15 °C (5 °F)
from –10 °C (14 °F) to
–30 °C (–22 °F)
Jet needle
Above 1500 m (5000 ft)
Pilot air screw
Main jet
Jet needle
Pilot air screw
#200
3rd groove
2.0 turns out
#190
3rd groove
2 1/2 turns out
#220
3rd groove
1 1/2 turns out
#200
3rd groove
2.0 turns out
#240
4th groove
1 1/2 turns out
#220
3rd groove
1 1/2 turns out
8-23
Changing the settings of the carburetors
To change the settings of the carburetors, you
need to disassemble and remove them. Follow the
procedures for both carburetors.
5. Disconnect the fuel hoses.
6. Remove the fuel tank by removing the bolts.
2
1
Disassembling and removing the carburetors
1. Turn the fuel cock to the “OFF” position.
2. Turn out the carburetor drain screw to drain
the fuel.
3. Remove the seat.
4. Remove the radiator cover and side cover by
removing the screws.
3
1
3
1
2
2
3
4
2
2
1. Fuel tank
2. Bolt
3
7. Remove the air filter case cover by unhooking
the holders.
3
5
6
7
8
9
10
2
11
1. Radiator cover
2. Fuel tank
3. Screw
8-24
2
1
2
2
1
3
4
5
6
2
1
1. Air filter case cover
2. Air filter case cover holder
1. Mixing chamber cap securing plate
2. Screw
7
8
8. Remove the mixing chamber cap securing
plate by removing the screw.
9. Loosen the carburetor joint screws.
9
10
11
8-25
1
1
1
1
1
4
1
2
2
3
3
4
5
1. Joint screw
1.
2.
3.
4.
10. Remove the mixing chamber cap.
11. Remove the throttle cable from the throttle
valve, and then remove the throttle cable holder by removing the screws.
Throttle cable
Throttle valve
Throttle cable holder
Screw
6
7
8
9
10
11
8-26
13. Remove the float and needle valve.
1
1
3
2
3
4
5
6
7
2
12. Remove the carburetor, and then remove the
float chamber by removing the screws.
2
1. Float
2. Needle valve
3. Main jet
2
8
14. Change the main jet and the jet needle clip position.
9
10
NOTE:
● Optional main jets can be obtained at a Yamaha
dealer.
● After the jet needle clip position is changed, the
throttle cables may need to be adjusted.
1
11
2
2
1. Float chamber
2. Screw
8-27
Assembling and installing the carburetors
Assemble and install both carburetors by the following steps.
1. Install the needle valve and float.
2. Install the float chamber by installing the
screws.
3. Install the carburetor and tighten the joint
screws.
4. Assemble the throttle valve.
5. Install the mixing chamber cap, and then tighten it securely to the specified torque.
2
1
2
1
3
3
4
4
5
1.
2.
3.
4.
Tightening torque:
Mixing chamber cap:
4 Nm (0.4 m·kgf, 2.9 ft·lbf)
Mixing chamber cap securing plate
Projection
Slot
Screw
6
7
8
6. Install the mixing chamber cap securing plate
by installing the screw.
7. Tighten the mixing chamber cap securing
plate screw to the specified torque.
ECB00501
CAUTION:
Tightening torque:
Mixing chamber cap securing plate screw:
3.5 Nm (0.35 m·kgf, 2.5 ft·lbf)
Be sure to match one of the projections on the
carburetor cap with one of the slots on the securing plate. If the securing plate does not
match a projection, tighten the carburetor cap
until they align. Do not loosen the carburetor
cap.
8. Tighten the carburetor joint screws.
Adjusting the throttle cables
1. Move the throttle lever a few times.
8-28
9
10
11
1
2
2. Push the throttle lever forward until it stops
and hold it in this position.
3. Check through each carburetor window to see
if the punch mark on the throttle valve is at the
specified position.
1
3
4
2
1
5
6
2
1. Adjusting nut
2. Locknut
7
5. Move the throttle lever a few times and recheck the position.
6. Install the fuel tank, side cover, radiator cover
and air filter case cover.
7. Connect the fuel hoses.
8. Install the seat.
8
9
10
11
1. Punch mark
2. Specified position: 0–1mm
4. If not, loosen the locknut and turn the adjusting nut until the specified position is obtained.
EBU24020
Adjusting the engine idling speed
The engine idling speed must be checked and, if
necessary, adjusted as follows at the intervals
specified in the periodic maintenance and lubrica8-29
tion chart.
NOTE:
A diagnostic tachometer is needed to make this
adjustment.
● The carburetor synchronization and the throttle
cable free play must be checked, and adjusted if
necessary, before adjusting the engine idling
speed.
1
●
2
1
3
4
1. Start the engine and warm it up.
5
NOTE:
The engine is warm when it quickly responds to the
throttle.
1. Pilot air screw
5. Remove the seat. (See page 4-11.)
6. Check the engine idling speed and, if necessary, adjust it to specification by turning the
throttle stop screws at the carburetors. To increase the engine idling speed, turn the throttle stop screws in direction (a), and to
decrease it, turn the screws in direction (b).
2. Attach the tachometer to the spark plug lead.
3. Turn in both pilot air screws until they lightly
seat.
4. Turn out both pilot air screws to specification.
(See the “Changing the carburetor settings”
section on the page 8-22.)
6
7
8
9
10
11
8-30
optimum engine performance.
1
1
NOTE:
If the specified idling speed cannot be obtained as
described above, have a Yamaha dealer make the
adjustment.
2
3
7. Install the seat.
(b) (a) (b) (a)
4
EBU24043
Adjusting the throttle cable free play
5
6
The throttle cable free play should be checked
and, if necessary, adjusted at the intervals specified in the periodic maintenance and lubrication
chart.
The throttle cable free play should measure 4.0–
6.0 mm (0.16–0.24 in) at the throttle lever. Periodically check the throttle cable free play and, if necessary, adjust it as follows.
1. Throttle stop screw
7
Engine idling speed:
1450–1550 r/min
8
ECB00510
9
10
CAUTION:
●
11
●
The throttle stop screws were preset at the
factory. When adjusting the idling speed,
turn both throttle stop screws the same
amount, otherwise the carburetor synchronization will be incorrect.
Adjusting the pilot air screws and the idling
speed are separate procedures, but they
must be adjusted at the same time to achieve
NOTE:
The engine idling speed must be checked, and adjusted if necessary, before adjusting the throttle cable free play.
1. Loosen the locknut.
2. To increase the throttle cable free play, turn
the adjusting bolt in direction (a). To decrease
8-31
the throttle cable free play, turn the adjusting
bolt in direction (b).
EBU24140
Front brake pads
Each brake pad is provided with a wear indicator,
which allows you to check the brake pad wear
without having to disassemble the brake. To check
the brake pad wear, check the position of the wear
indicator while applying the brake. If a brake pad
has worn to the point that the wear indicator almost
touches the brake disc, have a Yamaha dealer replace the brake pads as a set.
1 2
1
2
3
4
5
1
3
6
7
1. Throttle lever free play adjusting bolt
2. Locknut
3. Throttle cable free play
8
9
3. Tighten the locknut.
10
EBU24130
Checking the front and rear brake pads
The front and rear brake pads must be checked for
wear at the intervals specified in the periodic maintenance and lubrication chart.
1. Wear indicator
EBU24190
Rear brake pads
Each brake pad is provided with a wear indicator,
which allows you to check the brake pad wear
8-32
11
1
2
3
without having to disassemble the brake. To check
the brake pad wear, check the position of the wear
indicator while applying the brake. If a brake pad
has worn to the point that the wear indicator almost
touches the brake disc, have a Yamaha dealer replace the brake pads as a set.
4
sary. A low brake fluid level may indicate worn
brake pads and/or brake system leakage. If the
brake fluid level is low, be sure to check the brake
pads for wear and the brake system for leakage.
Front brake
1
1
LOWER
5
6
7
8
1
1. Minimum level mark
9
1. Wear indicator
10
EBU24251
11
Checking the brake fluid level
Insufficient brake fluid may allow air to enter the
brake system, possibly causing it to become ineffective.
Before riding, check that the brake fluid is above
the minimum level mark and replenish if neces8-33
●
Rear brake
●
LOWER
1
●
EBU24290
1. Minimum level mark
Changing the brake fluid
Have a Yamaha dealer change the brake fluid at
the intervals specified in the NOTE after the periodic maintenance and lubrication chart. In addition, have the oil seals of the master cylinders and
calipers as well as the brake hoses replaced at the
intervals listed below or whenever they are damaged or leaking.
● Oil seals: Replace every two years.
● Brake hoses: Replace every four years.
Observe these precautions:
● When checking the fluid level, make sure that
the top of the brake fluid reservoir is level.
● Use only the recommended quality brake fluid,
otherwise the rubber seals may deteriorate,
causing leakage and poor braking performance.
Recommended brake fluid:
DOT 4
●
Be careful that water does not enter the brake
fluid reservoir when refilling. Water will significantly lower the boiling point of the fluid and may
result in vapor lock.
Brake fluid may deteriorate painted surfaces or
plastic parts. Always clean up spilled fluid immediately.
As the brake pads wear, it is normal for the brake
fluid level to gradually go down. However, if the
brake fluid level goes down suddenly, have a
Yamaha dealer check the cause.
EBU24390
Refill with the same type of brake fluid. Mixing
fluids may result in a harmful chemical reaction
and lead to poor braking performance.
Checking the front brake lever free play
The brake lever free play must be checked at the
8-34
1
2
3
4
5
6
7
8
9
10
11
1
2
●
●
intervals specified in the periodic maintenance and
lubrication chart. The brake lever should have a
free play of zero mm (zero in) as shown. If the free
play is incorrect, have a Yamaha dealer check the
brake system.
3
Make sure the brakes do not drag.
Make sure the brakes are not spongy. All air
must be bled from the brake system.
Replacement of brake components requires
professional knowledge. These procedures
should be performed by a Yamaha dealer.
1
EBU24611
4
Checking the brake pedal position
5
The brake pedal position must be checked and, if
necessary, adjusted at the intervals specified in
the periodic maintenance and lubrication chart.
The top of the brake pedal should be positioned
10.0 mm (0.39 in) below the top of the footrest as
shown. If the brake pedal is not positioned as specified, have a Yamaha dealer adjust it.
6
7
8
9
10
11
1. Brake lever free play
EWB02070
WARNING
Operating with improperly serviced or adjusted brakes could cause loss of braking ability,
which could lead to an accident.
After servicing:
● Make sure the brakes operate smoothly and
that the free play is correct.
8-35
should be performed by a Yamaha dealer.
1
EBU24670
Adjusting the parking brake free play
The parking brake free play must be checked and,
if necessary, adjusted at the intervals specified in
the periodic maintenance and lubrication chart.
Cable length “A” should measure 46–50 mm
(1.81–1.97 in). Adjust the parking brake free play
as follows.
1
2
3
4
5
1. Brake pedal position
6
EWB02110
7
WARNING
8
Operating with improperly serviced or adjusted brakes could cause loss of braking ability,
which could lead to an accident.
After servicing:
● Make sure the brakes operate smoothly and
that the brake pedal position is correct.
● Make sure the brakes do not drag.
● Make sure the brakes are not spongy. All air
must be bled from the brake system.
Replacement of brake components requires
professional knowledge. These procedures
9
1
10
11
1. Cable length “A”
1. Release the parking brake.
2. Fully loosen the locknut and the adjusting bolt
at the clutch lever.
8-36
1
2
3. Loosen the locknut and the adjusting bolt at
the rear brake caliper.
4. Turn the adjusting bolt at the clutch lever in direction (a) to increase the cable length, and in
direction (b) to decrease it.
1/8 turn and tighten its locknut to the specified
torque.
3
1 2
4
(a)
5
1
7
1. Adjusting bolt
2. Locknut
8
9
10
11
2
(b)
6
1. Locknut
2. Adjusting bolt
Tightening torque:
Locknut (rear brake caliper):
16 Nm (1.6 m·kgf, 11 ft·lbf)
NOTE:
If the cable length cannot be adjusted to specification, consult a Yamaha dealer.
ECB00520
CAUTION:
When tightening the locknut, hold the adjusting bolt with a wrench so that it does not turn
together with the locknut.
5. Tighten the locknut at the clutch lever.
6. Turn in the adjusting bolt at the rear brake caliper by hand until it feels tight, then turn it out
8-37
effect.
EWB02090
WARNING
Turn the adjusting nut while holding the brake light
switch in place. To make the brake light come on
earlier, turn the adjusting nut in direction (a). To
make the brake light come on later, turn the adjusting nut in direction (b).
Operating with improperly serviced or adjusted brakes could cause the brakes to malfunction,
resulting
in
reduced
braking
performance. This could increase the chance
of a collision or accident. After adjusting the
parking brake free play, block the rear of the
ATV off the ground and spin the rear wheels.
Check to make sure there is no brake drag. If
brake drag is noticed, perform the adjustment
again.
1
2
3
4
1
(a)
2
(b)
5
6
7
EBU24740
Brake light switches
8
The operation of the brake light switches must be
checked and, if necessary, adjusted at the intervals specified in the periodic maintenance and lubrication chart.
The brake light switch for the brake pedal can be
adjusted as follows, but the other brake light
switches should be adjusted by a Yamaha dealer.
9
1. Brake light switch
2. Brake light switch adjusting nut
10
EBU24810
11
Adjusting the clutch lever free play
NOTE:
The brake light switch is properly adjusted when
the brake light comes on just before braking takes
The clutch lever free play must be checked and, if
necessary, adjusted at the intervals specified in
the periodic maintenance and lubrication chart.
The clutch lever free play should measure as
8-38
shown. If the free play is incorrect, adjust it as follows.
rectly, have a Yamaha dealer check the internal
clutch mechanism.
1
3
EBU24851
2
1
3
Drive chain slack
2
(a)
The drive chain slack should be checked before
each ride and adjusted if necessary.
4
To check the drive chain slack
1. Place the ATV on a level surface.
(b)
5
NOTE:
When checking and adjusting the drive chain
slack, there should be no weight on the ATV and
all tires must be touching the ground.
6
7
8
9
10
11
1. Locknut
2. Clutch lever free play adjusting bolt
3. Clutch lever free play
2. Move the ATV back and forth to locate the
tightest portion of the drive chain, and then
measure the drive chain slack as shown.
1. Loosen the locknut at the clutch lever.
2. To increase the clutch lever free play, turn the
adjusting bolt in direction (a), and to decrease
it, turn the bolt in direction (b).
3. Tighten the locknut.
Drive chain slack:
12.0–18.0 mm (0.47–0.71 in)
NOTE:
If the specified free play cannot be obtained as described above or if the clutch does not operate cor8-39
1
2
1
1
3
4
2
1. Axle holding nut (upper)
2. Axle holding nut (lower)
1. Drive chain slack
5
6
7
3. If the drive chain slack is incorrect, adjust it as
follows.
2. Loosen the locknut on each side of the swingarm. To tighten the drive chain, turn the adjusting bolts in direction (a). To loosen the
drive chain, turn the adjusting bolts in direction
(b) and push the wheels forward. Turn each
adjusting bolt exactly the same amount to
maintain correct axle alignment.
To adjust the drive chain slack
1. Loosen the axle holding nuts.
NOTE:
There are alignment marks on each side of the
swingarm and on the wheel hubs. Use them to
check for proper wheel axle alignment.
8-40
8
9
10
11
1
Tightening torques:
Locknut:
16 Nm (1.6 m·kgf, 11 ft·lbf)
Axle holding nut (upper):
120 Nm (12.0 m·kgf, 85 ft·lbf)
Axle holding nut (lower):
60 Nm (6.0 m·kgf, 43 ft·lbf)
3
2
3
4
2 1
5
6
EBU24880
Lubricating the drive chain
7
1. Locknut
2. Drive chain slack adjusting bolt
3. Alignment marks
8
ECB00541
9
10
11
The drive chain must be cleaned and lubricated at
the intervals specified in the periodic maintenance
and lubrication chart, otherwise it will quickly wear
out, especially when riding in dusty or wet areas.
Service the drive chain as follows.
CAUTION:
Improper drive chain slack will overload the engine as well as other vital parts of the ATV and
can lead to drive chain slippage or breakage.
To prevent this from occurring, keep the drive
chain slack within the specified limits.
3. Tighten the locknuts and the axle holding nuts
to the specified torques.
8-41
ECB00580
CAUTION:
Do not use engine oil or any other lubricants
for the drive chain, as they may contain substances that could damage the O-rings.
1
2
3
EBU24900
Checking and lubricating the cables
The operation and the condition of all control cables should be checked before each ride, and the
cables and cable ends should be lubricated if necessary. If a cable is damaged or does not move
smoothly, have a Yamaha dealer check or replace
it.
1. O-ring
ECB00560
CAUTION:
The drive chain must be lubricated after washing the ATV or riding in the rain.
Recommended lubricant:
Engine oil
1. Clean the drive chain with kerosene and a
small soft brush.
4
5
6
7
8
9
EWB02130
ECB00570
WARNING
CAUTION:
Inspect cables frequently and replace if damaged. Corrosion can result when the cable
sheaths become damaged, and cables can
also become frayed or kinked, which could restrict the operation of controls and lead to an
accident or injury.
To prevent damaging the O-rings, do not clean
the drive chain with steam cleaners, high-pressure washers or inappropriate solvents.
2. Wipe the drive chain dry.
3. Thoroughly lubricate the drive chain with a
special O-ring chain lubricant.
8-42
10
11
EBU24921
1
2
3
4
5
6
Checking and lubricating the brake and
clutch levers
Recommended lubricants:
Brake pedal:
Silicone grease
Shift pedal:
Lithium-soap-based grease (all-purpose
grease)
The operation of the brake and clutch levers
should be checked before each ride, and the lever
pivots should be lubricated if necessary.
Recommended lubricants:
Brake lever:
Silicone grease
Clutch lever:
Lithium-soap-based grease (all-purpose
grease)
EBU24962
Checking the wheel hub bearings
The front and rear wheel hub bearings must be
checked at the intervals specified in the periodic
maintenance and lubrication chart. If there is play
in a wheel hub or if a wheel does not turn smoothly,
have a Yamaha dealer check the wheel hub bearings.
7
EBU24931
8
9
10
Checking and lubricating the brake and
shift pedals
The operation of the brake and shift pedals should
be checked before each ride, and the pedal pivots
should be lubricated if necessary.
EBU25002
Lubricating the rear suspension relay
arm and connecting arm pivoting
points
11
The rear suspension relay arm and connecting
arm pivoting points must be lubricated at the intervals specified in the periodic maintenance and lubrication chart.
Lubricate the pivoting points using a grease gun.
8-43
Recommended lubricant:
Lithium-soap-based grease (all-purpose
grease)
1
2
3
4
1
1
1. Grease nipple
EBU25031
Lubricating the upper and lower arm
pivots
The upper and lower arm pivots must be lubricated
at the intervals specified in the periodic maintenance and lubrication chart.
Lubricate the pivoting points using a grease gun.
1. Grease nipple
Recommended lubricant:
Lithium-soap-based grease (all-purpose
grease)
8-44
5
6
7
8
9
10
11
Left side
Right side
1
2
3
4
5
1
1
6
1. Grease nipple
1. Grease nipple
7
EBU25101
8
Lubricating the steering shaft
9
The steering shaft must be lubricated at the intervals specified in the periodic maintenance and lubrication chart.
10
Recommended lubricant:
Lithium-soap-based grease (all-purpose
grease)
11
EBU26881
Replacing a headlight bulb
If a headlight bulb burns out, replace it as follows.
8-45
1. Remove the headlight unit by removing the
screw.
1
1
2
3
1
4
5
1. Headlight bulb holder cover
3. Remove the bulb holder by turning it counterclockwise.
1. Screw
2. Remove the headlight bulb holder cover.
6
7
8
9
10
11
8-46
1
1
2
3
4
1
5
6
7
1. Headlight bulb holder
1. Do not touch the glass part of the bulb.
4. Remove the defective bulb.
ECB00650
CAUTION:
EWB02200
8
9
10
11
WARNING
Do not touch the glass part of the headlight
bulb to keep it free from oil, otherwise the
transparency of the glass, the luminosity of the
bulb, and the bulb life will be adversely affected. Thoroughly clean off any dirt and fingerprints on the headlight bulb using a cloth
moistened with alcohol or thinner.
A headlight bulb is hot when it is on and immediately after it is turned off. Wait for the bulb to
cool before touching or removing it. You can
be burned, or a fire could start if the bulb
touches something flammable.
5. Place a new bulb into position, and then install
the bulb holder by turning it clockwise.
6. Install the bulb holder cover.
8-47
EBU25550
Adjusting a headlight beam
ECB00690
1
CAUTION:
1
2
It is advisable to have a Yamaha dealer make
this adjustment.
To raise a headlight beam, turn the adjusting
screw in direction (a).
To lower a headlight beam, turn the adjusting
screw in direction (b).
3
2
3
4
5
6
1. Headlight bulb holder cover
2. Headlight bulb holder
3. Headlight unit
7
8
ECB00680
1
CAUTION:
Make sure the bulb holder cover is securely fitted over the bulb holder and seated against the
reflector.
(a)
(b)
9
10
11
7. Place the headlight unit in the original position, and then install the screw.
8. Adjust the headlight beam if necessary.
1. Headlight beam adjusting screw
EBU25610
Replacing the tail/brake light bulb
If the tail/brake light bulb burns out, replace it as
8-48
1
follows.
1. Remove the bulb holder (together with the
bulb) by turning it counterclockwise.
2
3
4
1
2
5
6
1
1. Tail/brake light bulb holder
2. Tail/brake light bulb
7
8
9
3. Insert a new bulb into the bulb holder, push it
in, and then turn it clockwise until it stops.
4. Install the bulb holder (together with the bulb)
by turning it clockwise.
1. Tail/brake light bulb holder
2. Remove the defective bulb by pushing it in
and turning it counterclockwise.
10
EBU25650
Removing a wheel
11
1. Loosen the wheel nuts.
8-49
Front
Rear
1
1
2
1
3
1
4
1
5
6
1. Wheel nut
1. Wheel nut
7
2. Elevate the ATV and place a suitable stand
under the frame.
3. Remove the nuts from the wheel.
4. Remove the wheel.
EBU25660
8
9
10
Installing a wheel
1. Install the wheel and the nuts.
2. Lower the ATV to the ground.
3. Tighten the wheel nuts to the specified
torques.
8-50
11
EWB02280
1
2
3
4
WARNING
Tightening torques:
Front wheel nut:
45 Nm (4.5 m·kgf, 32 ft·lbf)
Rear wheel nut:
45 Nm (4.5 m·kgf, 32 ft·lbf)
Do not smoke when checking the fuel system.
Fuel can ignite or explode, causing severe injury or property damage. Make sure there are no
open flames or sparks in the area, including pilot lights from water heaters or furnaces.
EBU25740
Troubleshooting
5
6
7
8
9
10
11
Although Yamaha ATVs receive a thorough inspection before shipment from the factory, trouble
may occur during operation. Any problem in the fuel, compression, or ignition systems, for example,
can cause poor starting and loss of power.
The following troubleshooting charts represent
quick and easy procedures for checking these vital
systems yourself. However, should your ATV require any repair, take it to a Yamaha dealer, whose
skilled technicians have the necessary tools, experience, and know-how to service the ATV properly.
Use only genuine Yamaha replacement parts. Imitation parts may look like Yamaha parts, but they
are often inferior, have a shorter service life and
can lead to expensive repair bills.
8-51
EBU25841
Troubleshooting charts
1
Starting problems or poor engine perfor-
mance
2
1. Fuel
There is
Check the compression.
enough fuel.
3
Check the fuel level in
the fuel tank.
There is
Supply fuel.
no fuel.
The engine does not start.
Check the compression.
4
5
2. Compression
There is compression.
Check the ignition.
There is
Have a Yamaha dealer
no compression.
check the ATV.
6
Operate the kickstarter.
7
8
3. Ignition
Wet
Wipe off with a dry cloth and correct the
Open the throttle halfway and operate
spark plug gaps, or replace the spark plugs.
the kickstarter.
9
Remove the spark plugs
and check the electrodes.
Dry
Have a Yamaha dealer check the ATV.
The engine does not start.
10
Have a Yamaha dealer check the ATV.
11
8-52
Engine overheating
EWB02290
1
2
3
WARNING
Wait for the engine and radiator to cool before removing the radiator cap. You could be burned by
hot fluid and steam blown out under pressure. Always put a thick rag over the cap when opening.
Allow any remaining pressure to escape before completely removing the cap.
4
5
6
7
The coolant level is low.
Check the cooling system
for leakage.
Wait until the
engine has cooled.
Check the coolant level in the
reservoir and radiator.
The coolant level
is OK.
There is
leakage.
There is
no leakage.
Have a Yamaha dealer check
and repair the cooling system.
Add coolant. (See NOTE.)
Start the engine. If the engine overheats again, have a
Yamaha dealer check and repair the cooling system.
8
9
10
NOTE:
If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.
11
8-53
EBU25860
CLEANING AND STORAGE
1
ed from improper high-pressure detergent
applications such as those available in coinoperated car washers.
EBU25920
Cleaning
Frequent, thorough cleaning of your ATV will not
only enhance its appearance but will improve its
general performance and extend the useful life of
many components.
1. Before cleaning the ATV:
a. Block off the end of the exhaust pipe to
prevent water entry. A plastic bag and
strong rubber band may be used.
b. Make sure the spark plugs and all filler
caps are properly installed.
2. If the engine case is excessively greasy, apply
degreaser with a paint brush. Do not apply degreaser to the chain, sprockets or wheel axles.
3. Rinse the dirt and degreaser off with a garden
hose. Use only enough pressure to do the job.
4. Once most of the dirt has been hosed off,
wash all surfaces with warm water and mild,
detergent-type soap. An old toothbrush or bottle brush is handy for hard-to-reach places.
5. Rinse the ATV off immediately with clean water and dry all surfaces with a chamois, clean
towel or soft absorbing cloth.
6. Dry the chain and lubricate it to prevent it from
rusting.
7. Clean the seat with a vinyl upholstery cleaner
to keep the cover pliable and glossy.
8. Automotive type wax may be applied to all
painted and chrome plated surfaces. Avoid
combination cleaner-waxes. Many contain
abrasives which may mar the paint or protective finish. When finished cleaning, start the
engine and let it idle for several minutes.
ECB00710
CAUTION:
Excessive water pressure may cause water
seepage and deterioration of wheel bearings,
brakes, transmission seals and electrical devices. Many expensive repair bills have result-
EWB02310
WARNING
Wet brakes may have reduced stopping ability,
9-1
2
3
4
5
6
7
8
9
10
11
1
increasing the chance of an accident. Test the
brakes after washing. Apply the brakes several
times at slow speeds to let friction dry out the
linings.
section of this chapter.
2. Turn the fuel cock lever to “OFF”.
3. Drain the carburetor float chamber by loosening the drain bolt; this will prevent fuel deposits
from building up. Pour the drained fuel into the
fuel tank.
4. Fill up the fuel tank and add fuel stabilizer (if
available) to prevent the fuel from deteriorating.
2
3
4
5
6
EBU25951
Storage
Short-term
Always store your ATV in a cool, dry place and, if
necessary, protect it against dust with a porous
cover.
ECB00720
CAUTION:
7
●
8
9
●
10
11
Specified amount:
7.5 ml of stabilizer to each liter of fuel (or 1 oz
of stabilizer to each gallon of fuel)
5. Perform the following steps to protect the cylinders, piston rings, etc. from corrosion.
a. Remove the spark plug caps and spark
plugs.
b. Pour a teaspoonful of engine oil into each
spark plug bore.
c. Install the spark plug caps onto the spark
plugs, and then place the spark plugs on
the cylinder head so that the electrodes
are grounded. (This will limit sparking during the next step.)
d. Turn the engine over several times with
the starter. (This will coat the cylinder walls
Storing the ATV in a poorly ventilated room
or covering it with a tarp while it is still wet,
will allow water and humidity to seep in and
cause rust.
To prevent corrosion, avoid damp cellars,
stables (because of the presence of ammonia) and areas where strong chemicals are
stored.
Long-term
Before storing your ATV for several months:
1. Follow all the instructions in the “Cleaning”
9-2
with oil.)
e. Remove the spark plug caps from the
spark plugs, and then install the spark
plugs and the spark plug caps.
6. Lubricate all control cables and the pivoting
points of all levers and pedals.
7. Check and, if necessary, correct the tire air
pressure, and then block up the ATV so that
all of its wheels are off the ground. Alternatively, turn the wheels a little every month in order
to prevent the tires from becoming degraded
in one spot.
8. Cover the muffler outlet with a plastic bag to
prevent moisture from entering it.
1
2
3
4
5
6
7
NOTE:
Make any necessary repairs before storing the
ATV.
8
9
10
11
9-3
EBU25960
SPECIFICATIONS
1
Bore × stroke:
64.0 × 54.0 mm (2.52 × 2.13 in)
Compression ratio:
6.50 :1
Starting system:
Kickstarter
Lubrication system:
Premix
Type:
YAMALUBE 2-R, Castrol R30, A545, A747
Engine oil quantity:
Mixing ratio:
YAMALUBE R 24:1
EBU2597A
2
3
4
5
6
7
8
9
10
Dimensions:
Overall length:
1855 mm (73.0 in)
Overall width:
1100 mm (43.3 in)
Overall height:
1080 mm (42.5 in)
Seat height:
800 mm (31.5 in)
Wheelbase:
1280 mm (50.4 in)
Ground clearance:
135 mm (5.3 in)
Minimum turning radius:
3600 mm (142 in)
Transmission oil:
Type:
SAE10W30 type SE motor oil (EUR)
YAMALUBE 4 (10W30) or SAE10W30 type SE motor oil
(AUS)(NZL)
Quantity:
1.5 L (1.59 US qt) (1.32 Imp.qt)
Weight:
With oil and fuel:
187.0 kg (412 lb)
Cooling system:
Engine:
11
Coolant reservoir capacity (up to the maximum level mark):
0.28 L (0.30 US qt) (0.25 Imp.qt)
Radiator capacity (including all routes):
1.50 L (1.59 US qt) (1.32 Imp.qt)
Engine type:
Liquid cooled 2-stroke
Cylinder arrangement:
Forward-inclined parallel 2-cylinder
Displacement:
347.0 cm3
Air filter:
Air filter element:
Wet element
10-1
Fuel:
Operation:
Left foot operation
1st:
32/13 (2.461)
2nd:
29/16 (1.812)
3rd:
27/18 (1.500)
4th:
25/20 (1.250)
5th:
23/22 (1.045)
6th:
21/24 (0.875)
Recommended fuel:
Premium unleaded gasoline only
Fuel tank capacity:
12.0 L (3.17 US gal) (2.64 Imp.gal)
Fuel reserve amount:
2.5 L (0.66 US gal) (0.55 Imp.gal)
Carburetor:
Manufacturer:
MIKUNI
Type x quantity:
VM26SS x 2
Spark plug (s):
Manufacturer/model:
NGK/BR8ES
Spark plug gap:
0.7–0.8 mm (0.028–0.031 in)
Chassis:
Frame type:
Steel tube frame
Caster angle:
9.0 °
Trail:
40.0 mm (1.57 in)
Clutch:
Clutch type:
Wet, multiple-disc
Transmission:
Front tire:
Primary reduction system:
Helical gear
Primary reduction ratio:
66/23 (2.869)
Secondary reduction system:
Chain drive
Secondary reduction ratio:
41/14 (2.929)
Transmission type:
Constant mesh 6-speed
Type:
Tubeless
Size:
AT21 x 7-10
Manufacturer/model:
DUNLOP/KT851B
Rear tire:
Type:
Tubeless
10-2
1
2
3
4
5
6
7
8
9
10
11
1
2
3
Rear wheel:
Size:
AT20 x 10-9
Manufacturer/model:
DUNLOP/KT877A
Wheel type:
Panel wheel
Rim size:
9 x 8.5AT
Loading:
Front brake:
Maximum loading limit:
100.0 kg (220 lb)
(Total weight of rider, cargo, accessories, and tongue)
Type:
Dual disc brake
Operation:
Right hand operation
Recommended fluid:
DOT 4
Tire air pressure (measured on cold tires):
4
5
6
7
8
9
10
11
Recommended:
Front:
30 kPa (4.4 psi) (0.30 kgf/cm2)
Rear:
30 kPa (4.4 psi) (0.30 kgf/cm2)
Minimum:
Front:
27 kPa (3.9 psi) (0.27 kgf/cm2)
Rear:
27 kPa (3.9 psi) (0.27 kgf/cm2)
Maximum:
Front:
33 kPa (4.8 psi) (0.33 kgf/cm2)
Rear:
33 kPa (4.8 psi) (0.33 kgf/cm2)
Rear brake:
Type:
Single disc brake
Operation:
Right foot operation
Recommended fluid:
DOT 4
Front suspension:
Type:
Double wishbone
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
230 mm (9.1 in)
Front wheel:
Wheel type:
Panel wheel
Rim size:
10 x 6.0AT
Rear suspension:
Type:
Swingarm (link suspension)
Spring/shock absorber type:
Coil spring/gas-oil damper
10-3
Wheel travel:
220 mm (8.7 in)
Electrical system:
1
Ignition system:
CDI
Charging system:
AC magneto
2
3
Headlight:
Bulb type:
Krypton bulb
4
Bulb voltage, wattage x quantity:
Headlight:
12 V, 30.0/30.0 W × 2
Tail/brake light:
12 V, 5.0/21.0 W × 1
5
6
7
8
9
10
11
10-4
EBU26000
CONSUMER INFORMATION
1
2
3
4
5
EBU26011
EBU26020
Identification numbers
Key identification number
The key identification number is stamped into the
key. Record this number in the space provided and
use it for reference when ordering a new key.
Record the key identification number, vehicle identification number and model label information in
the spaces provided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the ATV is stolen.
● KEY IDENTIFICATION NUMBER:
6
1
7
8
●
VEHICLE IDENTIFICATION NUMBER:
●
MODEL LABEL INFORMATION:
9
10
1. Key identification number
EBU26030
11
Vehicle identification number
The vehicle identification number is stamped into
the frame.
11-1
1
1
2
3
1
4
5
1. Vehicle identification number
1. Model label
6
7
NOTE:
The vehicle identification number is used to identify your ATV.
8
9
EBU26050
Model label
The model label is affixed at the location in the illustration. Record the information on this label in
the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
10
11
11-2
INDEX
A
Accessories and loading ................................................ 6-6
Air filter element, cleaning............................................ 8-17
Drive chain slack .......................................................... 8-39
E
Engine break-in .............................................................. 6-4
Engine, cold start ........................................................... 6-1
Engine idling speed...................................................... 8-29
Engine, starting a warm ................................................. 6-2
Engine stop switch ......................................................... 4-2
B
Brake and clutch levers, checking and lubricating ....... 8-43
Brake and shift pedals, checking and lubricating ......... 8-43
Brake fluid, changing.................................................... 8-34
Brake fluid level, checking............................................ 8-33
Brake lever ..................................................................... 4-5
Brake lever free play, checking the front...................... 8-34
Brake light switches ..................................................... 8-38
Brake pads, checking the front and rear ...................... 8-32
Brake pedal .................................................................... 4-5
Brake pedal position, checking .................................... 8-35
Brakes, front and rear .................................................... 5-3
F
Fuel ................................................................................ 4-8
Fuel and 2-stroke engine oil mixing ratio ....................... 5-3
Fuel cock........................................................................ 4-9
Fuel tank cap.................................................................. 4-7
H
Handlebar switches........................................................ 4-2
Headlight beam, adjusting............................................ 8-48
Headlight bulb, replacing.............................................. 8-45
C
Cables, checking and lubricating ................................. 8-42
Carburetor settings, changing ...................................... 8-22
Chassis fasteners........................................................... 5-7
Cleaning ......................................................................... 9-1
Clutch lever .................................................................... 4-4
Clutch lever free play, adjusting ................................... 8-38
Coolant................................................................. 5-3, 8-12
D
Drive chain ..................................................................... 5-4
Drive chain, lubricating................................................. 8-41
I
Identification numbers .................................................. 11-1
Instruments, lights and switches .................................... 5-7
K
Key identification number............................................. 11-1
Kickstarter ...................................................................... 4-7
L
Label locations ............................................................... 2-1
Light switch .................................................................... 4-2
M
Main switch .....................................................................4-1
Maintenance and lubrication chart ..................................8-5
Maintenance chart, emission control system ..................8-3
Model label....................................................................11-2
O
Owner’s manual and tool kit............................................8-1
P
Parking............................................................................6-5
Parking brake..................................................................4-5
Parking brake free play, adjusting.................................8-36
Parking on a slope ..........................................................6-6
Part locations ..................................................................3-1
Pre-operation check list ..................................................5-1
R
Riding your ATV..............................................................7-1
S
Safety information ...........................................................1-1
Seat...............................................................................4-11
Shifting ............................................................................6-3
Shift pedal .......................................................................4-7
Shock absorber assemblies, adjusting the front ...........4-12
Shock absorber assembly, adjusting the rear...............4-13
Spark arrester, cleaning................................................8-20
Spark plugs, checking.....................................................8-8
Specifications................................................................10-1
Speed limiter ...................................................................4-3
Starter (choke) ..............................................................4-10
Steering shaft, lubricating .............................................8-45
Storage ...........................................................................9-2
Suspension, lubricating the upper and lower arm
pivots ......................................................................... 8-44
Suspension relay arm and connecting arm pivoting
points, lubricating the rear ......................................... 8-43
T
Tail/brake light bulb, replacing ..................................... 8-48
Throttle cable free play, adjusting ................................ 8-31
Throttle lever ...........................................................4-2, 5-4
Throttle OverRide System.............................................. 4-3
Tire pressure, measuring ............................................... 5-6
Tires ............................................................................... 5-5
Tire wear limit................................................................. 5-6
Transmission oil ....................................................5-3, 8-10
Troubleshooting ........................................................... 8-51
Troubleshooting charts ................................................ 8-52
V
Vehicle identification number ....................................... 11-1
W
Wheel hub bearings, checking..................................... 8-43
Wheel, installing........................................................... 8-50
