Panasonic video surveillance system solutions deliver superior performance and cost-efficiency for virtually any
application. With the most comprehensive line of IP, analog and hybrid products available, you can configure the
system that best meets your specific needs without ever compromising quality or reliability. Our latest innovations
include i-PRO SmartHDTM cameras and recorders that combine to deliver real-time face detection and face matching,
and UniPhier® large-scale integrated chips assure the highest levels of integration. They’re advancements that will
make any system smarter and more cost-efficient. Any way you see it, Panasonic has got it all covered.
Panasonic System Networks Company of America
Surveillance, Monitoring & Video Imaging
i-PRO IP / Network
The demand for greater performance and cost efficiency in video
surveillance solutions continued to accelerate even during the
economic slowdown. At Panasonic, we never stopped looking forward.
Our product line-up for 2011 embodies our spirit of innovation with new
video surveillance solutions that reflect Panasonic’s core expertise in
imaging and integrated system solutions.
Our ongoing commitment to research and development enables us to
bring new levels of on-board intelligent capabilities to market. Our
newest i-PRO SmartHD network solutions featured in this catalog make
advanced functions like automatic real-time face detection and face
matching practical and affordable for mainstream small to medium size
applications. It’s just one more way we are working to bring more value
and a higher ROI to our customers.
Here you’ll find unique characteristics that deliver optimum performance
and functionality across our entire video surveillance product portfolio.
These products further extend the range of applications for professional
video surveillance systems beyond traditional security in areas like
manufacturing, retail and traffic analysis, healthcare diagnostics and
patient care where these operations can benefit from precise video data.
And our corporate-wide embrace of networked technologies provides
an open platform to facilitate higher levels of integration with related
business systems including telecommunications, teleconferencing,
education, and point-of-sale systems. With the continued migration to
networked enterprise level operations, there is no limit to what can be
achieved with more intelligent technologies.
As a global technology leader with core competencies that encompass
virtually every facet of the electronics industry, Panasonic truly has got
it all covered.
Bill Taylor, President, Panasonic System Networks Company of America
4
Visit www.panasonic.com/security for the latest product information
i-PRO Cameras
PTZ
Fixed Dome
Vandal-Resistant
Fixed Color
i-PRO Network Camera Lineup Chart
7-12
13-14
15-18
19-21
22-24
Cameras
Recording Software
Server/Management System
Converter
Network Camera Lineup Charts
25-30
31
32
33
34-35
Network Video Recorders
Recording Management Software
37-40
41-43
Network Cameras
i-PRO Recorders / Software
Table of Contents
i-PRO I P / Network
i-PRO Encoders / Decoders
Encoders and Decoders
45
Analog
Cameras
PTZ
Fixed Dome
Vandal-Resistant
Fixed Color
Ready-to-Go Packages
PTZ and Fixed Dome Camera Lineup Chart
Fixed Box Camera Lineup Chart
47-50
51-53
54-56
57-60
61
62
63
Digital Video Recorders
Accessory
Recording Management Software
i-PRO Recorders & Encoders/Decoders Lineup Chart
Management Software Comparison Chart
65-66
67
67-69
70
71
73
Management Server
Matrix Switcher
Management Software
Control Systems
75
76
77
78-79
Monitors
81-83
Recording Solutions
Encoders / Decoders
Matrix and Control Systems
LCD Displays
Accessories
Lenses
85-87
Housings and Mounting Brackets
88-89
Recommended Camera and Lens Combination Charts
100-101
Housing and Camera Cross Reference Charts
102-103
Housing and Bracket Compatibility Charts
104-105
System Diagrams
106-111
112
Testimonials
113
Installations
114-115
Resources
Panasonic Solution Developer Network (PSDN)
116
Contact Us
117
Technology in Detail Guide
118-119
Index
120-121
5
Visit www.panasonic.com/security for the latest product information
i-PRO Network Cameras
Panasonic i-PRO network cameras keep getting smarter. With
the introduction of new i-PRO SmartHD™ cameras, Panasonic
delivers a cost-efficient means to instantly enhance and detect
individuals’ faces. Employing the latest innovations in HD face
detection technology, select i-PRO SmartHD cameras seamlessly integrate with our new WJ-NV200 NVR to match stored
faces with real-time video, and alert you when unauthorized
individuals come into view. Additional new introductions
include i-PRO network PTZs, vandal-resistant dome cameras
and fixed cameras that deliver the most in-camera intelligence
available. We’ve got it all covered.
Panasonic System Networks Company of America
6
Surveillance, Monitoring & Video Imaging
i-PRO IP / Network
i - P R O
C A M E R A S
WV-SW395
Super Dynamic HD Dome Network Camera
I
720p HD images up to 30 fps
1.3 megapixel double speed MOS sensor
I Multiple H.264 (High profile) and JPEG streams ensure simultaneous real time
monitoring and high resolution recording
I UniPhier®, Panasonic’s proprietary System LSI platform
I Full frame (up to 30 fps) transmission at 1,280 x 960 image size
I 18x optical zoom with 12x digital zoom (216x total zoom) / 36x extra optical zoom
under VGA resolution with 12x digital zoom enabling 432x total zoom
I Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver
128x wider dynamic range compared with conventional cameras
I Face Super Dynamic technology ensures clear images of the face
I H.264 and MPEG-4 are selectable for system migration
I High sensitivity with Day/Night function : 0.5 lx (Color), 0.06 lx (B/W) at F1.6 (Wide)
I Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR integration ensures
reduced noise and motion blur in various conditions
I Superior color reproduction by primary (RGB) color filter
I Electronic sensitivity enhancement: auto (up to 16x) / OFF
I Panning with auto flip function can be performed 0 to 360 degrees
I Auto tracking: camera automatically pans and tilts to follow a moving subject and
keep it in the center of the image
I Drag and Zoom operation enables finer control
I VMD (Video Motion Detector) with 4 programmable detection areas, 15 steps sensitivity
level and 10 steps detection size
I Face detection function detects the position of human face and information is sent by
XML or video stream
I Privacy Zone can mask up to 8 private areas
I Alarm sources including 1 terminal input, VMD and Panasonic alarm command can trigger
actions such as SDHC/SD memory recording, FTP image transfer, E-mail notification,
Indication on browser, Alarm terminal output, and Panasonic protocol output
I Analog monitor output for easy installation
I Full duplex bi-directional audio allows interactive communication between camera site
and monitoring site
I Supports Power over Ethernet Plus (PoE+) IEEE802.3at
I IP66 rated water and dust resistant
I Dehumidification device for use in various weather conditions
I
Specs
Image Sensor
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Pan Range/Speed
Presets
I/O Terminals
Power/Consumption
Dimensions
Weight (camera)
1/3" MOS sensor
0.5 lux in color, 0.06 lux in B/W
52dB
-40°~ 122°F
Interlace/768 (H) x 494 (V)
Mega & Face Super Dynamic, IP66, Day/Night, Auto Tracking, Image Stabilizer, Face Detection, 360° map
4.7mm ~ 84.6mm/18x optical, 36x with extra optical
0°-350°/0.5°~100°/sec
64
3
24V AC/43W with heater on / PoE Plus 24W
9 7/16"x 14 3/16" (239mm x 360.5mm)
10.14 lbs (4.6kg))
Popular Accessories
MOUNTING
BRACKETS
Model No.
Description
Page Ref.
PWM20G
Gooseneck –
wall, Black
95
PWM20GB
Gooseneck –
wall, Beige
95
PWM20GS
Gooseneck –
wall, Silver
95
PWM30G
Parapet,
Black
95
PWM30GB
Parapet,
Beige
95
PPRM30G
Extended Parapet,
Black
95
PPRM30GB
Extended Parapet,
Beige
95
7
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i - P R O
WV-NW964
C A M E R A S
Super Dynamic III Weather Proof Day/Night
Dome Network Camera
I
All-in-one outdoor unit
Super Dynamic III (SDIII) technology delivers 128x wider dynamic range and Intelligent
Technology features for exceptional images in virtually any lighting condition
I High sensitivity with Day/Night function: 0.5 lux (color) at ƒ1.4, 0.04 lux (B/W) at ƒ1.4
I 30x optical zoom lens: 3.8 mm ~ 114 mm (300x with digital zoom)
I Pan/Tilt speed of max. 400°/sec at preset mode and 0.065°/sec super fine control at
manual mode
I Auto tracking: camera automatically pans and tilts to follow a moving subject and keep
it in the center of the image
I Built-in Video Motion Detection with 4 programmable detection areas
and 6 sensitivity levels
I Scene Change Detection alarms when lens is covered, spray painted,
removed or defocused
I SD memory card slot for manual, alarm or network failure recording
I Auto Image Stabilization for applications where vibration or wind is a concern
I Built-in MPEG-4/JPEG digital signal output at VGA image size with up to 30 ips
I MPEG-4 and JPEG dual stream output for simultaneous live monitoring and high
resolution recording
I Progressive output with motion adaptive interlace/progressive conversion allows every
image to be clear even when the object is moving
I “Drag and Zoom” operation enabling finer PTZ control
I Digital slip-ring transmission delivers higher image quality since data travels through
compact slip-ring without any DA/AD conversion
I
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Pan Range/Speed
Presets
I/O Terminals
Power/Consumption
Dimensions
Weight (camera)
1/4" CCD
540 lines in color, 570 lines in B/W
0.5 lux in color, 0.04 lux in B/W (Sens up = OFF)
Super Dynamic III, 52dB
-40°~ 122°F
Interlace/768 (H) x 494 (V)
SDIII, IP66, Day/Night, Auto Tracking, Image Stabilizer, Scene Change Detection, 360˚ map
3.8mm ~ 114mm/30x optical + 10x electronic (300x total)
360° endless/0.065°~ 120°/sec
256
6
24V AC/19W camera, 85 W heater
9 7/16”x 15 9/16”(239mm x 395.5mm)
10.34 lbs (4.7kg)
Popular Accessories
MOUNTING
BRACKETS
Model No.
Description
Page Ref.
PWM20G
Gooseneck –
wall, Black
95
PWM20GB
Gooseneck –
wall, Beige
95
PWM20GS
Gooseneck –
wall, Silver
95
PWM30G
Parapet,
Black
95
PWM30GB
Parapet,
Beige
95
PPRM30G
Extended Parapet,
Black
95
PPRM30GB
Extended Parapet,
Beige
95
8
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i - P R O
C A M E R A S
WV-NS954
Super Dynamic III Day/Night Dome Network Camera
I
Super Dynamic III (SDIII) technology delivers 128x wider dynamic range and Intelligent
Technology features for exceptional images in virtually any lighting condition
I High sensitivity with Day/Night function: 0.5 lux (color) at ƒ1.4, 0.04 lux (B/W) at ƒ1.4
I IR cut filter switches on and off to ensure optimal picture quality in both color and B/W
I Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR integration ensures reduced
noise and motion blur
I 30x optical zoom lens: 3.8 mm ~ 114 mm (300x with digital zoom)
I Pan/Tilt speed of max. 400°/sec at preset mode and 0.065°/sec super fine control
at manual mode
I Auto tracking: camera automatically pans and tilts to follow a moving subject and
keep it in center of image
I Built-in Video Motion Detection with 4 programmable detection areas and
6 sensitivity levels
I Scene Change Detection alarms when lens is covered, spray painted,
removed or defocused
I SD memory card slot for manual, alarm or network failure recording
I Auto Image Stabilization for applications where vibration or wind is a concern
I Built-in MPEG-4/JPEG digital signal output at VGA image size with up to 30 ips
I MPEG-4 and JPEG dual stream output for simultaneous live monitoring and
high resolution recording
I Progressive output with motion adaptive interlace/progressive conversion allows
every image to be clear even when the object is moving
I Digital slip-ring transmission delivers higher image quality since data travels through
compact slip-ring without any DA/AD conversion
I “Drag and Zoom” operation enabling finer PTZ control
I 360° map shot: 8 thumbnail images at 45˚ intervals
I Full duplex 2-way audio
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Pan Range/Speed
Presets
I/O Terminals
Power/Consumption
Dimensions
Weight (camera)
1/4" CCD
540 lines in color, 570 lines in B/W
0.5 lux in color, 0.04 lux in B/W (Sens up = OFF)
Super Dynamic III, 52dB
-14°~ 122°F
Interlace/768 (H) x 494 (V)
SDIII, IP66, Day/Night, Auto Tracking, Auto Image Stabilization, Scene Change Detection, 360˚ map
3.8mm ~ 114mm/30x optical + 10x electronic (300x total)
360° endless/0.065°~ 120°/sec
256
6
24V AC/15 W
6 1/16”x 9 3/16”(154.5mm x 233mm)
4.84 lbs (2.2kg)
Popular Accessories
HOUSINGS
Model No.
Type
Location
Description
Comments
PID9
Ceiling
Indoor
Steel
upper housing
Tinted dome
Page Ref.
89
POD9C
Pendant
Outdoor
Silver color/
clear dome
Includes
Heater/Blower
92
POD9CW
Wall
Outdoor
Silver color/
clear dome
Includes
Heater/Blower
92
POD9CWT
Wall
Outdoor
White color/
clear dome
Includes
Heater/Blower
92
POD9CT
Pendant
Outdoor
White color/
clear dome
Includes
Heater/Blower
92
PIDV7CN
Ceiling
Indoor
Steel upper
housing
Clear dome
PIDV7SN
Ceiling
Indoor
Steel upper
housing
Tinted dome
90
90
POD7CN
Pendant
Outdoor
White color/
clear dome
Includes
Heater/Blower
91
MOUNTING
BRACKETS
Model No.
Type
PWM9
Wall
WV-Q118
Wall
WV-CS3S
Smoke cover
Location
Comments
Indoor
White color
WV-Q117
Suspended
ceiling mount
Indoor
WV-Q105
Direct
ceiling mount
Indoor
Page Ref.
96
Indoor
1" cable
opening
97
WV-Q116
Embedded
ceiling mount
Indoor
96
96
97
96
Visit www.panasonic.com/security for the latest product information
POD7CWN
Wall
Outdoor
White color
clear dome
Includes
Heater/Blower
91
9
i-PRO IP / Network
i - P R O
WV-SC385
C A M E R A S
Super Dynamic HD Dome Network Camera
I
720p HD images up to 30 fps
1.3 Megapixel double speed MOS Sensor
I Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous
real time monitoring and high resolution recording
I UniPhier®, Panasonic’s proprietary System LSI platform
I Full frame (Up to 30 fps) transmission at 1,280 x 960 image size
I 18x optical zoom with 12x digital zoom enabling 216x zoom / 36x extra
optical zoom under VGA resolution with 12x digital zoom enabling 432x zoom
I Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver
128x wider dynamic range compared with conventional cameras
I Face Super Dynamic technology ensures clear images of the face
I H.264 and MPEG-4 are selectable for system migration
I High sensitivity with Day/Night function : 0.5 lx (Color), 0.06 lx (B/W) at F1.6 (Wide)
I Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR integration ensures
reduced noise and motion blur in various conditions
I Superior color reproduction by primary (RGB) color filter
I Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
I Panning with auto flip function can be performed 0 to 360 degrees
I Auto tracking: camera automatically pans and tilts to follow a moving subject
and keeps it in the center of the image
I Drag and Zoom operation enables finer control
I Up to 64 preset positions
I 360 map shot: 8 thumbnail images at 45 deg. intervals make it simple to
direct the camera
I Industrial grade Pan/Tilt/Zoom mechanism for high reliability
I VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
I Face detection function detects the position of a human face and the information
is sent by XML or video stream
I Privacy Zone can mask up to 8 private areas
I Full duplex bi-directional audio allows interactive communication between
camera site and monitoring site
I Prioritized stream control
I SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm
recording (H.264 / JPEG) and backup upon network failure (JPEG)
I IPv4/IPv6 protocol supported
I Analog Monitor output for easier installation
I Supports SSL, DDNS (viewnetcam, RFC2136)
I
Specs
Popular Accessories
Model No.
Description
Page Ref.
MOUNTING
BRACKETS
Model No.
Type
Location
Page Ref.
PISM5V
Indoor
vandal-resistant
housing
90
Photo Not
Available
WV-Q157
Inner
dome cover
Indoor
98
POSM5V
Outdoor
vandal-resistant
housing
93
Photo Not
Available
WV-Q156C
Clear
dome cover
Indoor
98
Image Sensor
Minimum Illumination
Dynamic Range
Ambient Temperature
Special Features
Lens
Pan Range/Speed
Presets
I/O Terminals
Power/Consumption
Dimensions
Weight (camera)
Photo Not
Available
WV-Q156S
Smoke
dome cover
Indoor
98
1/3" type MOS sensor
0.5 lux in color, 0.06 lux in B/W
Mega Super Dynamic, 52dB
14°~ 122°F
Mega & Face Super Dynamic, Day/Night, Auto Tracking, Face Detection, 360° map
4.7mm ~ 84.6mm18x optical, 36x with extra optical zoom
0-350°/0.05°~ 100°/sec
64
3
12V DC/PoE 12W
4 17/32" x 6 3/32" (115mm x 155mm)
2 lbs (900g)
Photo Not
Available
WV-Q155C
Clear embedded
ceiling mount
Indoor
97
Photo Not
Available
WV-Q155S
Smoke embedded
ceiling mount
Indoor
97
Photo Not
Available
WV-Q154C
Clear wall
bracket
Indoor
97
Photo Not
Available
WV-Q154S
Smoke wall
bracket
Indoor
97
10
Visit www.panasonic.com/security for the latest product information
WV-Q105
Direct
ceiling mount
Indoor
96
i-PRO IP / Network
i - P R O
C A M E R A S
WV-SC384
HD Dome Network Camera
I
720p HD images up to 30 fps
1.3 Megapixel MOS Sensor
I Multiple H.264 (High profile) streams and JPEG streams ensure
simultaneous real time monitoring and high resolution recording
I UniPhier®, Panasonic’s proprietary System LSI platform
I Full frame (up to 30 fps) transmission at 1,280 x 960 image size
I 18x optical zoom, 36x extra optical zoom at VGA resolution with
8x digital zoom enabling 288x zoom
I Face Wide Dynamic Range technology ensures clear image of the face
I H.264 and MPEG-4 are selectable for system migration
I High sensitivity with Day/Night function : 0.6 lx (Color), 0.5 lx (B/W)
at F1.6 (Wide)
I Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR integration
ensures reduced noise and motion blur in various conditions
I Superior color reproduction by primary (RGB) color filter
I Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
I Panning with auto flip function can be performed 0 to 360 degrees
I Drag and Zoom operation enables finer control
I Up to 64 preset positions
I 3600 map shot: 8 thumbnail images at 45 deg. intervals make it
simple to direct the camera
I Industrial grade Pan/Tilt/Zoom mechanism for high reliability
I VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
I Face detection function detects the position of a human face and
the information is sent by XML or video stream
I Privacy Zone can mask up to 2 private areas
I Full duplex bi-directional audio allows interactive communication between
camera site and monitoring site
I Prioritized stream control
I SDHC/SD Memory card slot for manual recording (H.264/JPEG),
alarm recording (H.264/JPEG) and backup upon network failure (JPEG)
I IPv4/IPv6 protocol supported
I Analog monitor output for easier installation
I Supports SSL, DDNS (viewnetcam, RFC2136)
I Still images (JPEG) can be viewed on mobile phones via Internet
I ONVIF compliant model
I
Specs
Image Sensor
Minimum Illumination
Dynamic Range
Ambient Temperature
Special Features
Lens
Pan Range/Speed
Presets
I/O Terminals
Power/Consumption
Dimensions
Weight (camera)
MOUNTING
BRACKETS
Model No.
Type
Location
Page Ref.
1/3" type MOS sensor
0.6 lux in color, 0.5 lux in B/W
Wide Dynamic
14°~ 122°F
Day/Night, Auto Tracking, Face Detection, Drag and Zoom, 360° map
4.7mm ~ 84.6mm18x optical, 36x with extra optical zoom
0-350°/0.05°~ 100°/sec
64
3
12V DC/PoE 10W
4 17/32" x 6 3/32" (115mm x 155mm)
2 lbs (900g)
Photo Not
Available
WV-Q157
Inner
dome cover
Indoor
98
Photo Not
Available
WV-Q156C
Clear
dome cover
Indoor
98
Photo Not
Available
WV-Q156S
Smoke
dome cover
Indoor
98
Photo Not
Available
WV-Q155C
Clear embedded
ceiling mount
Indoor
97
Photo Not
Available
WV-Q155S
Smoke embedded
ceiling mount
Indoor
97
Photo Not
Available
WV-Q154C
Clear wall
bracket
Indoor
97
Photo Not
Available
WV-Q154S
Smoke wall
bracket
Indoor
97
WV-Q105
Direct
ceiling mount
Indoor
96
11
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i - P R O
WV-NS202A
C A M E R A S
Super Dynamic III Day/Night Dome Network Camera
I
Super Dynamic III (SDIII) technology delivers 128x wider dynamic range and Intelligent
Technology features for exceptional images in virtually any lighting condition
I Built-in MPEG-4 and JPEG digital signal output at VGA image size with up to 30 ips
I MPEG-4/JPEG dual stream output for simultaneous live monitoring and
high resolution recording
I Progressive output with motion adaptive interlace/progressive conversion
allows every frame to be clear even when the object is moving
I Power over Ethernet (PoE) IEEE 802.3af
I High sensitivity: Color: 0.7 lux (Sens up OFF), B/W: 0.5 lux (Sens up OFF)
I Simple Day/Night function (no IR cut filter)
I Up to 32x automatic electronic sensitivity enhancement
I Video Motion Detector with 4 programmable detection areas and 3 sensitivity levels
I 22x zoom lens with 10x digital zoom (220x total)
I Auto tracking: Pan and tilt automatically controlled to keep moving objects
centered in screen
I “Drag and Zoom” operation enables finer control
I Multiple camera views from browser
I 64 presets
I 360 map shot: 8 thumbnail images at 45˚ intervals
I FTP client function enables periodic image data transfer or transfer upon alarm
I Alarm notification via e-mail
I SD memory card slot for manual, alarm or network failure recording
I One-touch fitting mechanism for easy installation
I Desktop/ceiling position choice for versatile installations
I 2-way audio (G.726, 32/16kbps)
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Pan Range/Speed/Angle
Presets
I/O Terminals
Power
Dimensions
Weight (camera)
1/4” CCD
VGA (640 x 480), QVGA (320 x 240)
0.7 lux color, 0.5 lux b/w
Super Dynamic III, 52dB
14° ~ 122° F
Progressive output/768 (H) x 494 (V)
SDIII, MPEG-4/JPEG, SD card slot, PoE, Auto Tracking, 3600 Map Shot
3.79mm ~ 83.4mm/22x optical + 10x electronic/F1.6 ~ 22
0° ~ 350°/100°/sec up to approx. 300°/sec
64
4
12V DC, PoE (IEEE802.3af)
4 17/32” x 6 1/16” (115mm ~ 154mm)
1.87 lbs (850g)
Popular Accessories
HOUSINGS
Model No.
Placement
Style
Description
Page Ref.
PID5CN
Ceiling
Indoor
Clear Dome
Recessed
Ceiling
PID5SN
Ceiling
Indoor
Smoke Dome
Recessed
Ceiling
PODV7CPNS
Pendant
Outdoor
Clear Dome
w/ 24VAC
Heater/Blower
PODV7CWNS
Wall
Outdoor
Clear Dome
w/ 24VAC
Heater/Blower
88
88
93
93
MOUNTING
BRACKETS
Model No.
Type
12
POD9C
Pendant
Outdoor
Silver color/
clear dome,
includes
Heater/Blower
92
POD9CT
Pendant
Outdoor
White color/
clear dome,
includes
Heater/Blower
92
WV-Q105
Direct Ceiling
WV-Q150S
Wall
Location
Description
Indoor
Page Ref.
96
Indoor
Smoke Dome
(also available
in Clear Dome,
WV-Q150C)
97
POD9CW
Wall
Outdoor
Silver color/
clear dome,
includes
Heater/Blower
92
WV-Q151S
Embedded
Ceiling
Indoor
Smoke Dome
(also available
in Clear Dome,
WV-Q151C)
97
Visit www.panasonic.com/security for the latest product information
POD9CWT
Wall
Outdoor
White color/
clear dome,
includes
Heater/Blower
92
WV-Q152S
Ceiling
Indoor
Smoke Dome
(also available
in Clear Dome,
WV-Q152C)
97
i-PRO IP / Network
i - P R O C A M E R A S
WV-SF336/WV-SF335/WV-SF332
Megapixel* Fixed Mini Dome Network Camera Series
I
720p HD images up to 30 fps (WV-SF336/WV-SF335)
1.3 Megapixel high sensitivity MOS Sensor
I Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous
real time monitoring and high resolution recording
I UniPhier®, Panasonic’s proprietary System LSI platform.
I Full frame (Up to 30 fps) transmission at 1,280 x 960 image size,
at SVGA 800 x 600 image size
I Wide Dynamic Range and ABS (Adaptive Black Stretch) technologies deliver
wider dynamic range compared with conventional cameras
I Face Wide Dynamic Range technology ensures clear images of the face
I H.264 and MPEG-4 are selectable for system migration.
I High sensitivity with Simple Day/Night function: 0.3 lux (Color), 0.2 lux (B/W) at ƒ1.3
(Wide) (WV-SF336/WV-SF335); 0.2 lux (Color), 0.13 lux (B/W) at ƒ1.3 (WV-SF332)
I ABF (Auto Back Focus) ensures easy installation and stable focus in both color
and B/W modes (WV-SF336)
I Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions.
I Progressive scan ensures clear images with less motion blur and no tearing
even when the subject is moving.
I Superior color reproduction by primary (RGB) color filter
I Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
I VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
I Face detection function detects the position of human face and the information is sent
by XML or video stream
I Meta data for VMD is supplied to work with the WJ-ND400 playback VMD function
I Privacy Zone can mask up to 2 private areas
I 2x, 4x digital zoom controlled by browser
I Full duplex bi-directional audio allows interactive communication between
camera site and monitoring site.
I JPEG image compression ratio can be changed by alarm so that
higher quality images can be provided
I Prioritized stream control
I SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm recording
(H.264 / JPEG) and backup upon network failure (JPEG)
I IPv4/IPv6 protocol supported
I Analog Monitor output for easier installation
I 2.8 mm ~ 10 mm, 3.6x Varifocal Auto Iris lens
I
*Models WV-SF336/WV-SF335 only
H.264
Specs
Image sensor
Resolution
Min. Illum.
Ambient Temp
Scan Method/Pixels
Special Features
Lens
I/O Terminals
Power
Dimensions
Weight (camera)
1/3” MOS sensor
1,280 x 960 (H.264, JPEG), 640 x 480 (VGA), 320 x 240 (QVGA) for models WV-SF336/335 / 800 x 600
(H.264), 640 x 480 (VGA), 320 x 240 (QVGA) for model WV-SF332
0.3 lux in color, 0.2 lux in B/W (WV-SF336/WV-SF335), 0.2 lux in color, 0.13 lux in B/W (WV-SF332)
14° ~ 122° F
Progressive
Face detection, Simple Day/Night, SDHC/SD, Adaptive Black Stretch, Auto Back Focus (WV-SF336 only)
2.8x vari-focal / 2.8 ~ 10mm
3
12V DC, 630 mA / PoE IEEE 802.3af, 7.6W
5 1/8" x 3 5/8"
0.9 lbs (410g)
Popular Accessories
Model No.
Description
Page Ref.
WV-Q168
Embedded
ceiling
mount
—
WV-CS5S
Smoked
dome cover
—
PRCM1
Embedded
mount
bracket
96
13
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i - P R O
C A M E R A S
WV-NF302
Ruggedized Megapixel Day/Night Fixed Dome Network Camera
I
1280 x 960 megapixel high quality image for superior identification (JPEG)
MPEG-4/JPEG digital signal output at VGA image size with up to 30 ips
I Power over Ethernet (PoE) IEEE 802.3af
I MPEG-4 and JPEG dual stream output for simultaneous live monitoring
and high resolution recording
I Progressive output provides clear images even when the subject is moving
I High sensitivity: 1.5 lux at ƒ1.3 (wide) when used with clear dome cover
I Adaptive Black Stretch enhances the visibility of dark areas without
compromising the bright areas
I Superior color reproduction by primary (RGB) color filter
I Up to 16x automatic electronic sensitivity enhancement
I Built-in 2.8 x 10mm, 3.6x vari-focal lens (plus up to 4x digital zoom)
I Video motion detection with 4 programmable detection areas and 15 step sensitivity
I Privacy Zone can mask up to 8 private areas
I Full duplex bi-directional audio allows interactive communication between camera
and monitoring sites
I Focus assist: best focus position can be achieved with focus adjustment position
on the screen
I SD memory card slot for manual recording, alarm recording and backup
due to network failure
I Analog monitor output for easy installation
I Three-way hinge (horizontal, vertical and swivel rotation) for versatile installation
I Heavy duty metal body ensures 24/7 operation
I IPv4/IPv6 protocol supported
I Outdoor/indoor selectable light controls
I Prioritized stream control
I
Clear dome standard; smoked dome optional
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
I/O Terminals
Power
Dimensions
Weight (camera)
1/3” CCD
4VGA (1280 x 960), VGA (640 x 480), QVGA (320 x 240)
1.5 lux w/clear dome (color), 0.9 lux w/clear dome (B/W)
14° ~ 122° F
Progressive/1.296 (H) x 976 (V)
MPEG-4/JPEG, SD card slot, PoE
3.6x vari-focal/2.8 ~ 10mm
3
12V DC, 510mA, PoE (IEEE802.3af), 6.4 W
4 7/8” x 5 5/16”
2.05 lbs (930g)
Popular Accessories
Model No.
Description
Page Ref.
WV-Q173
Recessed ceiling
mount bracket
98
14
Visit www.panasonic.com/security for the latest product information
WV-NF5S
Smoked
dome cover
—
i-PRO IP / Network
i - P R O
C A M E R A S
WV-NW502S
Super Dynamic Megapixel Vandal-Resistant Fixed Dome
Network Camera
I
Multiple H.264 high profile streams and JPEG streams ensure simultaneous real time
monitoring and high resolution recording
I Up to 30 fps full frame transmission at 1,280 x 960 image size (1.3 Megapixel mode)
I Super Dynamic and Adaptive Black Stretch (ABS) technologies deliver 128x wider
dynamic range for exceptional images in virtually any lighting condition
I Up to 3 Megapixel (2,048 x 1,536) JPEG stream (3 Megapixel mode, JPEG only)
I High sensitivity with Day/Night function: 1.0 lux (Color), 0.08 lux (B/W) at ƒ1.4
(1.3 Megapixel mode)
I Auto Back Focus (ABF) ensures easy installation and stable focus in both color
and B/W modes
I Adaptive Digital Noise Reduction: integration of 2D-DNR and 3D-DNR ensures noise
reduction in various conditions
I Progressive scan ensures clear images with less motion blur and no tearing even when
the subject is moving
I Superior color reproduction
I Face detection technology detects the position of human face and sends information by
XML or video stream
I Electronic sensitivity enhancement: auto (up to 16x) / off
I Video Motion Detector (VMD) with 4 programmable detection areas, 15 step sensitivity level
and 10 step detection size
I Privacy Zone can mask up to 8 private areas
I 2.8 ~ 8.0 mm, 2.8x vari-focal Auto Iris lens
I Dehumidification device for use in various weather conditions
I Alarm sources including 3 terminal input, VMD and Panasonic alarm command
I Full duplex bi-directional audio
I Prioritized stream control
I SD/SDHC memory card slot for manual recording, alarm recording and backup upon
network failure
I H.264/MPEG-4 max. bit rate/client and total bit rate control for flexible network
traffic management
I Supplied meta data for VMD works with WJ-ND400 NVR
I IPv4/IPv6 protocol supported
I IP66 rated for water and dust resistance
Clear dome standard; smoked dome optional
Other Models Available
WV-NW502S/09
WV-NW502S/15
WV-NW502S/22
with 9-22mm lens
with 15-50mm lens
with 2.2mm lens
H.264
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Power
Dimensions
Weight (camera)
1/3" CCD
2,048 x 1,536 (JPEG), 1,280 x 960 (H.264), 640 x 490 (MPEG-4)
1.0 lux (1.3 megapixel), 2.0 lux (3 megapixel)
-22˚ ~ 122˚ F
Progressive scan/1,296 (H) x 976 (V) x2
MEGA Super Dynamic w/Adaptive Black Stretch, H.264,
Vandal Auto Back Focus, Face Detection, IPv4/IPv6
2.8x vari-focal/2.8 ~ 8mm
12V DC, PoE
6 7/16” x 5 3/4” x 7 9/16” (164mm x 146mm x 191.5mm)
3.74 lbs (1.7kg)
Visit www.panasonic.com/megaSD for more
details on Mega Super Dynamic technology
including video demonstrations.
Popular Accessories
MOUNTING
BRACKETS*
Model No.
PCM484S
PHM484S
PPM484S
Type
Corner
Hanging
Pole
Location
Outdoor
Outdoor
Outdoor
Page Ref.
99
99
99
*Note: Brackets are designed for surface mount cameras only
MISCELLANEOUS
Model No.
WV-CW4S
Description
Smoked
Dome Cover
Page Ref.
—
WV-Q169
Recessed
Ceiling Mount
98
PWM484S
Wall
Outdoor
99
PRCM1
Embedded
Mount Bracket
96
Visit www.panasonic.com/security for the latest product information
15
i-PRO IP / Network
i - P R O
C A M E R A S
WV-NW484S
Super Dynamic III Vandal-Resistant Day/Night Fixed Dome
Network Camera
I
Built-in MPEG-4 and JPEG digital signal output at VGA image size with up to 30 ips
MPEG-4/JPEG dual stream output for simultaneous live monitoring and
high resolution recording
I Vandal Auto Back Focus automatically adjusts camera focus when switching
from color to B/W
I Progressive output with motion adaptive interlace/progressive conversion
allows every frame to be clear even when the object is moving
I Super Dynamic III (SDIII) technology delivers 128x wider dynamic range
and Intelligent Technology features for exceptional images in virtually
any lighting condition
I High sensitivity with Day/Night function: 0.6 lux (Color), 0.08 lux (B/W)
with clear dome cover at ƒ1.4 (wide)
I Power over Ethernet (PoE) IEEE 802.3af (including optional heater)
I Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR ensures noise reduction
in various conditions
I 3.8 ~ 8.0mm, 2x vari-focal lens with 3x digital zoom
I Scene Change Detection alarms when lens is covered, spray painted,
removed or defocused
I Video motion detection with 4 programmable detection areas
and 3 sensitivity levels
I Auto Image Stabilization for applications where vibration or wind is a concern
I Up to 32x automatic electronic sensitivity enhancement
I SD memory card slot for manual, alarm or network failure recording
I FTP client function enables periodic image data transfer or transfer upon alarm
I IP66 rated for water and dust resistance
I Dehumidification device for use in various weather conditions
I Three-way hinge (horizontal, vertical and swivel rotation) for easy installation
I Optional heater maintains operating temperature –22 °F ~ 122 °F
I
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Power
Dimensions
Weight (camera)
1/3" CCD
VGA (640 x 480), QVGA (320 x 240)
0.6 lux (DNR on) w/ clear dome
-22° ~ 122° F (with optional heater WV-CW4H)
Progressive output/768 (H) x 494 (V)
SDIII, Vandal Auto Back Focus, MPEG-4/JPEG,
Day/Night, IP66 rated
2x vari-focal/3.8 ~ 8mm
24V AC, 12V DC, PoE (IEEE802.3af)
6 1/4” x 6” (159mm x 152.5mm)
4.9 lbs (1.92kg)
Popular Accessories
LENSES
Model No.
Size
Iris
Type
Focal Length
Aperture
Page Ref.
PLA22T3DN
1/3"
Auto
Wide
2.2mm
ƒ1.2
86
PLZ15/33
1/3"
Auto
Wide
15 – 50mm
ƒ1.5
85
MOUNTING
BRACKETS*
Model No.
PCM484S
PHM484S
PPM484S
Type
Corner
Hanging
Pole
Location
Outdoor
Outdoor
Outdoor
Page Ref.
99
99
99
*Note: Brackets are designed for surface mount cameras only
MISCELLANEOUS
Model No.
WV-CW4H
Description
Heater Unit
Page Ref.
—
WV-CW4C
Clear
Dome Cover
—
WV-Q169
Recessed
Ceiling Mount
98
16
Visit www.panasonic.com/security for the latest product information
PWM484S
Wall
Outdoor
99
PRCM1
Embedded
Mount Bracket
96
i-PRO IP / Network
i - P R O
C A M E R A S
WV-SW355/WV-SW352
Super Dynamic HD* Vandal-Resistant Fixed Dome
Network Camera
I
720p HD images up to 30 fps (WV-SW355)
1.3 Megapixel high sensitivity MOS Sensor
I Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous
real time monitoring and high resolution recording
I UniPhier®, Panasonic’s proprietary System LSI platform
I Full frame (Up to 30 fps) transmission at 1,280 x 960 image size (WV-SW355)
I Full frame (Up to 30 fps) transmission at SVGA/800 x 600 image size (WV-SW352)
I Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x
wider dynamic range compared to conventional cameras
I Face Super Dynamic Range technology ensures clear images of the face
I H.264 and MPEG-4 are selectable for system migration
I High sensitivity with True Day/Night function: WV-SW355: 0.3 lx (Color), 0.05 lx (B/W)
at F1.6 (Wide) WV-SW352: 0.2 lx (Color), 0.04 lx (B/W) at F1.6 (Wide)
I VIQS (Variable Image Quality on Specified area) technology allows the designated
area to retain higher image quality while the excluded area will have a
decreased image quality enabling lower image file size and bit rate
I ABF (Auto Back Focus) ensures easy installation
I Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions
I Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
I Up to 7.2x extra optical zoom under VGA resolution. 2.8-10 mm, 3.6x vari-focal
auto iris lens (5.6-20 mm, 7.2x with Extra Optical Zoom under VGA)
I VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
I Face detection function detects the position of human face and
information is sent by XML or video stream
I Meta data for VMD is supplied to work with the WJ-NV200 /WJ-ND400 NVRs
playback VMD function
I Privacy Zone can mask up to 2 private areas
I Full duplex bi-directional audio allows interactive communication between
camera site and monitoring site
I Prioritized stream control
I SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm
recording (H.264 / JPEG) and backup upon network failure (JPEG)
I IPv4/IPv6 protocol supported
I Supports SSL, DDNS (viewnetcam, RFC2136)
I Still images (JPEG) can be viewed on mobile phones via Internet
I Analog Monitor output for easier installation
I IP66 rated water and dust resistant. Compatible with IEC60529
measurement standard
I Dehumidification device for use in various weather conditions
I Vandal resistant mechanism for high reliability
I
*Model WV-SW355
Specs
Image Sensor
Resolution
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Power
Dimensions
Weight
1/3" type MOS sensor
WV-SW355: 1,280 x 960 (H.264, JPEG), 640 x 480 (MPEG-4)
WV-SW352: 800 x 600 (H.264, JPEG), 640 x 480 (MPEG-4)
0.3 lux (WV-SW355), 0.2 lux (WV-SW352)
14° ~ 122° F
Progressive scan
MEGA Super Dynamic, H.264, vandal resistant, Auto Back Focus,
Face Detection, IPv4/IPv6
2.8mm – 10mm, 3.6x
12V DC, PoE
6 15/32" x 5 3/4" x 7 9/16" (164mm x 146mm x 191.5mm)
3.53 lbs (1.6kg)
Photo Not
Available
MISCELLANEOUS
Model No.
Description
Page Ref.
WV-Q169
Recessed
Ceiling Mount
98
WV-CW4S
Smoked
Dome Cover
—
WV-SW3H
Heater
unit
—
PRCM1
Embedded
Mount Bracket
96
17
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i - P R O C A M E R A S
WV-SF346/WV-SF342
Vandal-Resistant Fixed Dome Network Camera Series
I
720p HD images up to 30fps (WV-SF346)
1.3 Megapixel high sensitivity MOS Sensor
I Multiple H.264 (High profile) and JPEG streams ensure simultaneous
real time monitoring and high resolution recording
I UniPhier®, Panasonic’s proprietary System LSI platform
I Full frame (Up to 30 fps) transmission at 1,280 x 960 image size (WV-SF346),
at SVGA/800 x 600 image size (WV-SF342)
I Wide Dynamic Range and ABS (Adaptive Black Stretch) technologies deliver
wider dynamic range
I Face Wide Dynamic Range technology ensures clear images of the face
I H.264 and MPEG-4 are selectable for system migration
I High sensitivity with Simple Day/Night function
- WV-SF346: 0.3 lx (Color), 0.2 lx (B/W) at F1.3 (Wide)
- WV-SF342: 0.2 lx (Color), 0.13 lx (B/W) at F1.3 (Wide)
I ABF (Auto Back Focus) ensures easy installation (WV-SF346)
I Focus Assist for onscreen adjustments (WV-SF342)
I Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions
I Progressive scan ensures clear images with less motion blur and no tearing
even when the subject is moving
I Superior color reproduction by primary (RGB) color filter
I Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
I VMD (Video Motion Detector) with 4 programmable detection areas, 15 steps
sensitivity level and 10 steps detection size
I Face detection function detects the position of a human face and the
information is sent by XML or video stream
I Privacy Zone can mask up to 2 private areas
I 2x, 4x digital zoom controlled by browser
I Alarm sources including 1 terminal input, VMD and Panasonic alarm command
can trigger actions such as SDHC/SD memory recording, FTP image transfer,
E-mail notification, Indication on browser, Alarm terminal output, and Panasonic
protocol output
I Full duplex bi-directional audio allows interactive communication between
camera site and monitoring site
I Prioritized stream control
I SDHC/SD Memory card slot for manual recording (H.264 / JPEG),
alarm recording (H.264 / JPEG) and backup upon network failure (JPEG)
I IPv4/IPv6 protocol supported
I Analog Monitor output for easier installation
I 2.8 mm ~ 10 mm, 3.6x Varifocal Auto Iris lens
I
Specs
Image sensor
Resolution
1/3" type MOS sensor
WV-SF346: 1,280 x 960 (H.264, JPEG); 640 x 480 (MPEG-4)
WV-SF342: 800 x 600 (H.264, JPEG); 640 x 480 (MPEG-4)
Min. Illum.
0.3 lux in color (WV-SF346), 0.2 lux in color (WV-SF342)
Ambient Temp
14° ~ 122° F
Scan Method/Pixels Progressive
Special Features
Face Detection, Day/Night, Auto Back Focus (WV-SF346),
SDHC/SD memory card slot
Lens
2.8mm ~ 10mm, 3.6x varifocal auto iris lens
I/O Terminals
1
Power/Consumption 12V DC/320 mA / PoE, 4.2W
Dimensions
5 1/8" x 3 5/8" (129.5mm x 93mm)
Weight (camera)
approx. 1.4 lbs (640g)
Popular Accessories
Photo Not
Available
Model No.
Description
WV-Q105
Page Ref.
—
18
Visit www.panasonic.com/security for the latest product information
PRCM1
Embedded
Mount Bracket
96
i-PRO IP / Network
i - P R O
WV-SP306/WV-SP305/WV-SP302
C A M E R A S
Megapixel* Fixed Network Camera Series
I
Progressive scan ensures clear images with less motion blur
and no tearing
I Supports H.264/MPEG-4/JPEG video streams
I High sensitivity with automatic calibration for more details
I Panasonic Uniphier® technology for optimal performance
I Face detection for better subject identification
I Minimum illumination:
- WV-SP306: 0.3 lux in color, 0.05 lux in B/W at ƒ1.4
- WV-SP305: 0.3 lux in color, 0.2 lux in B/W at ƒ1.4
- WV-SP302: 0.2 lux in color, 0.13 lux in B/W at ƒ1.4
I Auto Back Focus ensures easy installation and perfect focus in color
and B/W modes (WV-SP306 only)
I Focus assist for on screen adjustments (WV-SP305/WV-SP302)
I Day/Night for 24 hour viewing (WV-SP306), simple Day/Night
(WV-SP305/WV-SP302)
I Power over Ethernet (PoE) IEEE 802.3af
I VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
I 2x, 4x digital zoom controlled by browser
I Privacy zone can mask up to two areas
I SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm
recording (H.264 / JPEG) and backup upon network failure (JPEG)
I JPEG image compression ratio can be changed by alarm so that higher
quality image can be provided
I Prioritized stream control
I Internet mode: H.264/MPEG-4 images can be transmitted over HTTP protocol
I Full duplex bi-directional audio allows interactive communication between
camera and monitoring site
I Analog video out
I IPv4/IPv6 protocol supported
*Models WV-SP306/WV-SP305 only
Lens optional
H.264
Specs
Image sensor
Resolution
1/3" MOS sensor
1,280 x 960 (H.264, JPEG), 640 x 480 (VGA), 320 x 240 (QVGA)
for models WV-SP306/305 / 800 x 600 (H.264), 640 x 480 (VGA),
320 x 240 (QVGA) for model WV-SP302
Min. Illum.
0.3 lux in color, 0.05 lux in B/W (WV-SP306), 0.3 lux in color, 0.2 lux
in B/W (WV-SP305), 0.2 lux in color, 0.13 lux in B/W (WV-SP302)
Ambient Temp
14° ~ 122° F
Scan Method/Pixels Progressive
Special Features
Face detection, Day/Night & Simple Day/Night, Adaptive Black
Stretch, SDHC/SD, Auto Back Focus (WV-SP306 only)
I/O Terminals
3
Power
12V DC, 350 mA / PoE IEEE 802.3af, 4.4W
Dimensions
2 15/16” x 2 9/16” x 5 3/16”
Weight (camera)
0.9 lbs (approx. 400g)
Popular Accessories
LENSES
Model No.
Size
Iris
Type
Focal Length
Aperture
Page Ref.
PLAMP2206
1/3"
Auto
Wide
2.2mm
ƒ1.3
86
PTVR0916DC
1/3"
Auto
Vari-focal
9-22mm
ƒ1.6
87
WV-LZA62/2
1/3"
Auto
2x Vari-focal
2.8-6mm
ƒ1.4(W), ƒ2.1(T)
85
19
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i - P R O C A M E R A S
WV-NP502
Super Dynamic Megapixel Network Camera*
I
*Lens Optional
Multiple H.264 high profile streams and JPEG streams ensure simultaneous
real time monitoring and high resolution recording
I Up to 30 fps full frame transmission at 1,280 x 960 image size
(1.3 Megapixel mode)
I Super Dynamic and Adaptive Black Stretch (ABS) technologies
deliver 128x wider dynamic range for exceptional images in
virtually any lighting condition
I Up to 3 Megapixel (2,048 x 1,536) JPEG stream
(3 Megapixel mode, JPEG only)
I High sensitivity with Day/Night function: 1.0 lux (Color), 0.08 lux (B/W) at ƒ1.4
(1.3 Megapixel mode)
I Auto Back Focus (ABF) ensures easy installation and stable focus in both color
and B/W modes
I Adaptive Digital Noise Reduction: integration of 2D-DNR and 3D-DNR ensures
noise reduction in various conditions
I Progressive scan ensures clear images with less motion blur and no tearing
even when the subject is moving
I Superior color reproduction by primary color filter
I Electronic sensitivity enhancement: auto (up to 16x) / off
I Selectable light control modes
I Video Motion Detector (VMD) with 4 programmable detection areas,
15 step sensitivity level and 10 step detection size
I Face detection technology detects the position of human face and
sends information by XML or video stream
I Privacy Zone can mask up to 8 private areas
I Full duplex bi-directional audio
I Prioritized stream control
I SD/SDHC memory card slot for manual recording, alarm recording
and backup upon network failure
I H.264/MPEG-4 max. bit rate/client and total bit rate control offers
flexible network traffic management
I IPv4/IPv6 protocol supported
I Analog monitor output for easier installation
H.264
Specs
Visit www.panasonic.com/megaSD for more
details on Mega Super Dynamic technology
including video demonstrations.
Image Sensor
Resolution
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
I/O Terminals
Power
Dimensions
Weight (camera)
1/3” CCD
2,048 x 1,536 (JPEG), 1,280 x 960 (H.264), 640 x 490 (MPEG-4)
1.0 lux (1.3 megapixel), 2.0 lux (3 megapixel)
22˚ ~ 122˚ F
Progressive scan/1,296 (H) x 976 (V) x2
MEGA Super Dynamic w/ Adaptive Black Stretch, H.264,
Face Detection, IPv4/IPv6
3
12V DC, PoE
2 15/16” x 2 9/16” x 5 3/16” (75mm x 65mm x 132.5mm)
0.95 lbs (430g)
Popular Accessories
HOUSINGS
Model No.
Placement
Style
Description
Comments
Page Ref.
POH1000
Outdoor
Bullet
10" - Ltwt.
Aluminum
Available with
Heater/Blower
(POH1000HB)
94
POH1500
Outdoor
Bullet
15" - Ltwt.
Aluminum
Available with
Heater/Blower
(POH1500HB)
94
LENSES
Model No.
Size
Iris
Type
Focal Length
Aperture
Page Ref.
PLAMP0550
1/3"
Auto
10x
5-50mm
ƒ1.4
86
PLAMP2406
1/3"
Auto
2.5x
2.4-6mm
ƒ1.2
86
PLAMP2812
1/3"
Auto
4x
2.8-12mm
ƒ1.4
86
20
Visit www.panasonic.com/security for the latest product information
WV-LZA62/2
1/3"
Auto
2x Vari-focal
2.8-6mm
ƒ1.4(W), ƒ2.1(T)
85
C A M E R A S
WV-SP105/WV-SP102
Network Cameras
I
720p HD images up to 30 fps (WV-SP105 only)
1.3 Megapixel high sensitivity MOS Sensor (WV-SP105)
I 0.32 Megapixel high sensitivity MOS Sensor (WV-SP102)
I Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous
real time monitoring and high resolution recording
I UniPhier®, Panasonic’s proprietary System LSI platform
I Full frame (Up to 30 fps) transmission at 1,280 x 960 image size (WV-SP105),
640 x 480 image size (WV-SP102)
I 2x extra zoom under VGA resolution (WV-SP105 only)
I 2x, 4x digital zoom controlled by browser
I ABS (Adaptive Black Stretch) technologies deliver wider dynamic range compared with conventional cameras
I High sensitivity with simple Day/Night function: 0.8 lx (color), 0.4 lx (B/W) at
ƒ2.2 (WV-SP105); 2.0 lx (color), 1.3 lx (B/W) at ƒ2.0 (WV-SP102)
I Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions
I Progressive scan ensures clear images with less motion blur and no tearing
even when the subject is moving
I Superior color reproduction by primary (RGB) color filter
I Electronic sensitivity enhancement: Auto (Up to 16x) / OFF (WV-SP105)
I Auto (Up to 8x) / OFF (WV-SP102)
I VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
I Privacy Zone can mask up to 2 private areas
I Prioritized stream control
I Internet mode: H.264 images can be transmitted over HTTP protocol
I IPv4/IPv6 protocol supported
I
i-PRO IP / Network
i - P R O
Specs
Image Sensor
Minimum Illumination
Ambient Temperature
Special Features
Power/Consumption
Dimensions
Weight (camera)
1/3 type MOS sensor (WV-SP105), 1/5 type MOS sensor (WV-SP102)
0.8 lux in color, 0.4 lux in B/W (WV-SP105), 2.0 lux in color,
1.3 lux in B/W (WV-SP102)
32˚ ~ 104˚ F
HD, Day/Night, Adaptive Black Stretch
12V DC, 200 mA (WV-SP105), 140 mA (WV-SP102)
2 5/32”x 2 5/32” x 4 13/16” (55mm x 55mm x 122mm))
0.4 lbs (180g)
21
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i-PRO Network Camera Lineup Chart
HD 720p
HD 720p
HD 720p
WV-SW395
WV-SC385
WV-SC384
WV-NW964
WV-NS954
WV-NS202A
WV-NW502S
Camera Type
1.3 MP Outdoor PTZ
(360° w/ auto flip)
1.3 MP Indoor PTZ
(360° w/ auto flip)
1.3 MP Indoor PTZ
(360° w/ auto flip)
Outdoor PTZ
(Continuous 360°)
Indoor PTZ
(Continuous 360°)
Indoor PTZ
(0~350°)
3.0 MP Outdoor
vandal dome
Super Dynamic
Mega Super Dynamic
Mega Super Dynamic
WDR (8x) *1
Imaging Device
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/4" CCD
Progressive Output
1/4" CCD
Progressive Output
1/4" CCD
Progressive Output
1/3" CCD
Progressive Scan
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
MPEG-4
JPEG
MPEG-4
JPEG
MPEG-4
JPEG
H.264
MPEG-4
JPEG
Day/Night
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Removable IR (D&N)
Yes
Yes
No
Yes
Yes
No
Yes
Auto Focus
Auto Focus
Auto Focus
Auto Focus
Auto Focus
Auto Focus
Yes
Future support
Future support
Future support
No
No
No
No
Color
0.5 lux
0.5 lux
0.6 lux
0.5 lux
0.5 lux
0.7 lux
3MP: 2.0 lux
1.3MP:1.0 lux
B/W
0.06 lux
0.06 lux
0.5 lux
0.04 lux
0.04 lux
0.5 lux
3MP: 0.16 lux
1.3MP: 0.08 lux
fps JPEG
30fps (1280 x 960)
30fps (1280 x 960)
30fps (1280 x 960)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
5fps (2048 x 1536)
30fps (1280 x 960)
fps MPEG-4
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x480)
30fps (640 x480)
30fps (640 x480)
30fps (640 x 480)
fps H.264
30fps (1280 x 960)
30fps (1280 x 960)
30fps (1280 x 960)
-
-
-
15fps (1920 x 1080)
30fps (1280 x 960)
1280 x 960
(JPEG & H.264)
1280 x 960
(JPEG & H.264)
1280 x 960
(JPEG & H.264)
Max 640 x 480
(JPEG & MPEG-4)
Max 640 x 480
(JPEG & MPEG-4)
Max 640 x 480
(JPEG & MPEG-4)
2048 x 1536 (JPEG)
1920 x 1080 (H.264)
2-way
2-way
2-way
2-way
2-way
2-way (Half-duplex)
2-way
Yes (SDHC)
Yes (SDHC)
Yes (SDHC)
Yes (Mini)
Yes
Yes
Yes (SDHC)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
1fps (JPEG)
1fps (JPEG)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
4.7mm~84.6mm
4.7mm~84.6mm
4.7mm~84.6mm
3.8mm~114mm
3.8mm~114mm
3.8mm~83mm
2.8x vari-focal
2.8mm~8.0mm
18x (1.3MP) optical
36x (VGA) EX optical
12x electric
18x (1.3MP) optical
36x (VGA) EX optical
12x electric
18x (1.3MP) optical
36x (VGA) EX optical
8x electric
30x optical
10x electric
30x optical
10x electric
22x optical
10x electric
2.8x optical
4x electric
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4
10/100 BASE-TX
IP v4
10/100 BASE-TX
IP v4
10/100 BASE-TX
IP v4/v6
24VAC
PoE+ (IEEE802.3at)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
24VAC
24VAC
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
2/1
2/1
2/1
2/1
2/1
2/1
2/1
Max Power
Comsumption
24W (PoE+)
43W (AC)
12W (PoE)
1000mA (DC)
10W (PoE)
690mA (DC)
85W
(w/ heater)
15W
12W (PoE)
1000mA (DC)
7.6W (PoE)
630mA (DC)
Operating
Temparature
-40°F~122°F (24VAC)
-30°F~122°F (PoE+)
14°F~122°F
14°F~122°F
-40°F~122°F
14°F~122°F
14°F~122°F
-22°F~122°F
Mobile Phone
Support *2
JPEG
PTZ/AUX Control
JPEG
PTZ/AUX Control
JPEG
PTZ/AUX Control
No
No
No
No
ID/PWD
Host Authentication
HTTPS
Auto Tracking
Drag and Zoom
Image Stabilizer
Face Detection
Face Mega SD
IP66
ID/PWD
Host Authentication
HTTPS
ID/PWD
Host Authentication
HTTPS
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
Auto Tracking
Drag and Zoom
Image Stabilizer
Face Detection
Face Mega SD
Drag and Zoom
Image Stabilizer
Face Detection
Face WDR
Auto Tracking
Drag and Zoom
Image Stabilizer
IP66
Auto Tracking
Drag and Zoom
Image Stabilizer
Auto Tracking
Drag and Zoom
Image Stabilizer
Face Detection
Face Mega SD
Dehumidification Device
IP66
Model
Video Compression
Auto Back Focus
VIQS
Minimum
Illumination
Max Image Resolution
* MPEG-4 (640 x 480)
Audio Capability
SD Memory Card Slot
SD Card Recording
Lens Type
Zoom
Network
Power
Alarm In-/Outputs
Security
Other Key Features
22
HD 1080p
SDIII
SDIII
SDIII
*1: WDR (Wide Dynamic Range) *2: See the supported mobile phones on the Panasonic web site
Visit www.panasonic.com/security for the latest product information
Mega Super Dynamic
HD 720p
HD 720p
HD 720p
HD 720p
Model
WV-SW355
WV-SW352
WV-NW484S
WV-SF346
WV-SF342
WV-SF336
WV-SF335
Camera Type
1.3 MP outdoor
vandal dome
Outdoor vandal dome
Outdoor vandal dome
1.3 MP Indoor
vandal dome
Indoor vandal dome
1.3MP Indoor dome
1.3MP Indoor dome
Super Dynamic
Mega Super Dynamic
Super Dynamic
WDR (8x) *1
WDR (8x) *1
WDR (8x) *1
WDR (8x) *1
Imaging Device
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/3" CCD
Progressive Output
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
Day/Night
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Removable IR (D&N)
Yes
Yes
Yes
No
No
No
No
Yes (Lens ABF)
Yes (Lens ABF)
Yes
Yes (Lens ABF)
Focus Assist
Yes (Lens ABF)
Focus Assist
Yes
Yes
No
Future Support
Future Support
Future Support
Future Support
Color
0.3 lux
0.2 lux
0.6 lux
0.3 lux
0.2 lux
0.3 lux
0.3 lux
B/W
0.05 lux
0.04 lux
0.08 lux
0.2 lux
0.13 lux
0.2 lux
0.2 lux
fps JPEG
30fps (1280 x 960)
30fps (800 x 600)
30fps (640 x 480)
30fps (1280 x 960)
30fps (800 x 600)
30fps (1280 x 960)
30fps (1280 x 960)
fps MPEG-4
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
fps H.264
30fps (1280 x 960)
30fps (800 x 600)
-
30fps (1280 x 960)
30fps (800 x 600)
30fps (1280 x 960)
30fps (1280 x 960)
1280 x 960
(JPEG & H.264)
800 x 600
(JPEG & H.264)
Max 640 x 480
(JPEG & MPEG-4)
1280 x 960
(JPEG & H.264)
800 x 600
(JPEG & H.264)
1280 x 960
(JPEG & H.264)
1280 x 960
(JPEG & H.264)
2-way
2-way
No
2-way
2-way
2-way
2-way
Yes (SDHC)
Yes (SDHC)
Yes
Yes (SDHC)
Yes (SDHC)
Yes (SDHC)
Yes (SDHC)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
3.6x vari-focal
2.8mm~10.0mm
3.6x vari-focal
2.8mm~10.0mm
2.0x vari-focal
3.8mm~8.0mm
3.6x vari-focal
2.8mm~10.0mm
3.6x vari-focal
2.8mm~10.0mm
3.6x vari-focal
2.8mm~10.0mm
3.6x vari-focal
2.8mm~10.0mm
3.6x optical
7.2x (VGA) EX optical
4x electric
3.6x optical
7.2x (VGA) EX optical
4x electric
2x optical
4x electric
3.6x optical
4x electric
3.6x optical
4x electric
3.6x optical
4x electric
3.6x optical
4x electric
Network
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
Power
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
24VAC/12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
1/1
1/1
1/1
1/1
1/1
1/1
1/1
Max Power
Comsumption
11.5W (PoE)
1.1 A (DC)
11.5W (PoE)
1.1 A (DC)
12W (PoE)
16 W (AC)
920mA (DC)
4.2W (PoE)
320mA (DC)
4.2W (PoE)
320mA (DC)
4.2W (PoE)
320mA (DC)
3.5W (PoE)
280mA (DC)
Operating
Temparature
-22°F~122°F
-22°F~122°F
-22°F~122°F
14°F~122°F
14°F~122°F
14°F~122°F
14°F~122°F
Mobile Phone
Support *2
JPEG
PTZ Control
JPEG
PTZ Control
No
No
No
No
No
ID/PWD
Host Authentication
HTTPS
ID/PWD
Host Authentication
HTTPS
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
Face Detection
Face Mega SD
Dehumidification Device
Heater PoE *3
IP66
Face Detection
Face Super Dynamic
Dehumidification Device
Heater PoE *3
IP66
Dehumidification Device
Heater PoE *3
IP66
Face Detection
Face WDR
Face Detection
Face WDR
Face Detection
Face WDR
Face Detection
Face WDR
Video Compression
Auto Back Focus
VIQS
Minimum
Illumination
Max Image Resolution
* MPEG-4 (640 x 480)
Audio Capability
SD Memory Card Slot
SD Card Recording
Lens Type
Zoom
Alarm In-/Outputs
Security
Other Key Features
SDIII
*1: WDR (Wide Dynamic Range) *2: See the supported mobile phones on the Panasonic web site *3: Heater optional
Visit www.panasonic.com/security for the latest product information
i-PRO IP / Network
i-PRO Network Camera Lineup Chart
23
i-PRO IP / Network
i-PRO Network Camera Lineup Chart
HD 1080p
HD 720p
HD 720p
WV-SF332
WV-NP502
WV-SP306
WV-SP305
WV-SP302
WV-SP105
WV-SP102
800x600 Indoor dome
3.0 MP box
1.3 MP box
1.3 MP box
800x600 box
1.3 MP box
Box
Super Dynamic
WDR (8x) *1
Mega Super Dynamic
WDR (8x) *1
WDR (8x) *1
WDR (8x) *1
No
No
Imaging Device
1/3" MOS Sensor
Progressive Scan
1/3" CCD
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/3" MOS Sensor
Progressive Scan
1/5" MOS Sensor
Progressive Scan
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
MPEG-4
JPEG
H.264
JPEG
H.264
JPEG
Day/Night
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Removable IR (D&N)
No
Yes
Yes
No
No
No
No
Focus Assist
Yes
Yes (Lens ABF)
Focus Assist
Focus Assist
No
No
Future Support
No
Future Support
Future Support
Future Support
No
No
0.2 lux
3MP: 2.0 lux
1.3MP:1.0 lux
0.3 lux
0.3 lux
0.2 lux
0.8 lux
2.0 lux
0.13 lux
3MP: 0.16 lux
1.3MP: 0.08 lux
0.05 lux
0.2 lux
0.13 lux
0.4 lux
1.3 lux
fps JPEG
30fps (800 x 600)
5fps (2048 x 1536)
30fps (1280 x 960)
30fps (1280 x 960)
30fps (1280 x 960)
30fps (800 x 600)
30fps (1280 x 960)
30fps (640 x 480)
fps MPEG-4
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
30fps (640 x 480)
-
-
fps H.264
30fps (800 x 600)
15fps (1920 x 1080)
30fps (1280 x 960)
30fps (1280 x 960)
30fps (1280 x 960)
30fps (800 x 600)
30fps (1280 x 960)
30fps (640 x 480)
800 x 600
(JPEG & H.264)
2048 x 1536 (JPEG)
1920 x 1080 (H.264)
1280 x 960
(JPEG & H.264)
1280 x 960
(JPEG & H.264)
800 x 600
(JPEG & H.264)
1280 x 960
(JPEG & H.264)
640 x 480
(JPEG & H.264)
2-way
2-way
2-way
2-way
2-way
No
No
Yes (SDHC)
Yes (SDHC)
Yes (SDHC)
Yes (SDHC)
Yes (SDHC)
No
No
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
30fps (H.264)
1fps (JPEG)
No
No
3.6x vari-focal
2.8mm~10.0mm
Optional
Optional
Optional
Optional
Fixed focal length
3.54mm
Fixed focal length
2.00mm
3.6x optical
4x electric
4x electric
4x electric
4x electric
4x electric
2x (VGA) Ex optical
No
Network
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
10/100 BASE-TX
IP v4/v6
Power
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
12VDC
PoE (IEEE802.3af)
1/1
2/1
1/1
1/1
1/1
No
No
Max Power
Comsumption
3.5W (PoE)
280mA (DC)
7.6W (PoE)
630mA (DC)
4.4W (PoE)
350mA (DC)
3.4W (PoE)
270mA (DC)
3.4W (PoE)
270mA (DC)
2.8W (PoE)
200mA (DC)
2.0W (PoE)
140mA (DC)
Operating
Temparature
14°F~122°F
14°F~122°F
14°F~122°F
14°F~122°F
14°F~122°F
32°F~104°F
32°F~104°F
Mobile Phone
Support *2
No
No
No
No
No
No
No
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
ID/PWD
Host Authentication
Face Detection
Face WDR
Face Detection
Face Mega SD
Face Detection
Face WDR
Face Detection
Face WDR
Face Detection
Face WDR
ABS *4
ABS *4
Model
Camera Type
Video Compression
Auto Back Focus
VIQS
Minimum
Illumination
Color
B/W
Max Image Resolution
* MPEG-4 (640 x 480)
Audio Capability
SD Memory Card Slot
SD Card Recording
Lens Type
Zoom
Alarm In-/Outputs
Security
Other Key Features
24
HD 720p
*1: WDR (Wide Dynamic Range) *2: See the supported mobile phones on the Panasonic web site *4: ABS (Adaptive Black Stretch)
Visit www.panasonic.com/security for the latest product information
C A M E R A S
BB-HCM581A/BB-HCM580A
PTZ Network Cameras
I
42x zoom (21x optical)
High-speed 350° pan / 210° tilt with presets
I Power over Ethernet (PoE) IEEE 802.3af compliant (BB-HCM581A only)
I Progressive scan
I Analog video output
I Simultaneous MPEG-4 and JPEG video streams
I SD card recording
I 0.09 lux color night view mode
I Up to 30 frames per second CCD
I Full screen monitoring
I Remote monitoring from cell phone
I 4-up, 9-up and 16-up multi-camera pages
I Up to 30 video users
I Built in web server/IP address (IPv4/v6)
I Two way audio capability (BB-HCM581A only)
I Sensor input to trigger movement (BB-HCM581A only)
I Email triggered by motion detection, sensor alert, timer
I Password protection
I Plug & play installation
I Multi-language interface
I Image date and time stamp
I
Network Cameras
N E T W O R K
Popular Accessories
Photo Not
Available
Model No.
Description
BB-HCA3A
AC power supply
Page Ref.
—
PISM5V
Indoor
vandal-resistant
housing
90
POSM5V
Outdoor
vandal-resistant
housing
93
25
Visit www.panasonic.com/security for the latest product information
Network Cameras
N E T W O R K
C A M E R A S
BB-HCM547A
Outdoor* Mini Dome Network Camera
I
Ceiling mount
Pan/Tilt/2.3 auto vari-focal lens
I Power over Ethernet (PoE) IEEE 802.3af compliant
I Progressive scan
I 2.3 optical, 2x digital zoom
I Analog video output
I Simultaneous MPEG-4 and JPEG video streams
I SD card recording with audio
I 0.2 lux color night view mode
I Up to 30 frames per second MAICO
I Full screen monitoring
I Remote monitoring from cell phone
I 4-up, 9-up and 16-up multi-camera pages
I Up to 30 video users
I Built in web server/IP address (IPv4/v6)
I Two way audio capability
I Built-in microphone
I
*Splash resistant body: camera placement under an eave is recommended
Popular Accessory
Photo Not
Available
Model No.
Description
Page Ref.
BB-HCA3A
AC power supply
—
BB-HCM527A
Mini Dome Network Camera
I
Ceiling mount
Pan/tilt/ 2.3 auto vari-focal lens
I Power over Ethernet (PoE) IEEE 802.3af compliant
I Progressive scan
I 2.3 optical, 2x digital zoom
I Analog video output
I Simultaneous MPEG-4 and JPEG video streams
I SD card recording with audio
I 0.2 lux color night view mode
I Up to 30 frames per second MAICO
I Full screen monitoring
I Remote monitoring from cell phone
I 4-up, 9-up and 16-up multi-camera pages
I Up to 30 video users
I Built in web server/IP address (IPv4/v6)
I Two way audio capability
I Built-in microphone
I
Popular Accessories
Photo Not
Available
Model No.
Description
BB-HCA3A
AC power Supply
Page Ref.
—
BB-HCA10A
Flush Mount
Ceiling Bracket
—
26
Visit www.panasonic.com/security for the latest product information
C A M E R A S
BB-HCM735A/BB-HCM715A
Megapixel Network Cameras
I
Sends H.264 or MPEG-4 and JPEG images simultaneously
Power over Ethernet (PoE) IEEE 802.3af compliant
I Progressive scan
I Splash resistant body for outdoor* use (BB-HCM735A only)
I Image transfer by timer, alarm, motion, sound or shock
I Pan, tilt, 6x digital zoom with presets
I 0.07 lux color night view mode
I Up to 30 frames per second
I SD memory card recording
I Remote monitoring from cell phone
I 4-up, 9-up, 16-up multi-cameras pages
I Built-in web server/IP address (IPv4/v6)
I Two way audio capability
I Password protection
I Plug & play installation
I Multi-language interface
I Image date and time stamp
I
Network Cameras
N E T W O R K
*Splash resistant body: camera placement under an eave is recommended
Popular Accessory
Photo Not
Available
Model No.
Description
Page Ref.
BB-HCA7A
AC power supply
—
27
Visit www.panasonic.com/security for the latest product information
Network Cameras
N E T W O R K
C A M E R A S
BB-HCM531A/BB-HCM511A
PTZ Network Cameras
I
Pan/tilt/digital zoom with presets
Power over Ethernet (PoE) IEEE 802.3af compliant
I Progressive scan
I Splash resistant for outdoor* use (BB-HCM531A only)
I Analog video output
I Simultaneous MPEG-4 and JPEG streams
I SD card recording with audio
I 0.2 lux color night view mode
I Up to 30 frames per second CCD
I Full screen monitoring
I Remote monitoring from cell phone
I 4-up, 9-up and 16-up multi-camera pages
I Up to 30 video users
I Built in web server/IP address (IPv4/v6)
• Two way audio capability
• Built-in microphone
I Dual sensor input to trigger movement
I Image transfer by motion detection, sensor alert, timer
I Password protection
I Plug & play installation
I Multi-language interface
I Image date and time stamp
I
*Splash resistant body: camera placement under an eave is recommended
Popular Accessory
Photo Not
Available
Model No.
Description
Page Ref.
28
Visit www.panasonic.com/security for the latest product information
BB-HCA3A
AC power supply
—
C A M E R A S
BB-HCM705A/BB-HCM701A
Mini Dome Network Cameras
I
Sends H.264 or MPEG-4 and JPEG images simultaneously
Power over Ethernet (PoE) IEEE 802.3af compliant
I Progressive scan
I Compact size and flexible installation
I Image transfer by timer, alarm, motion, sound or shock
I Pan, tilt, 6x digital zoom with presets (BB-HCM705A),
3x digital zoom (BB-HCM701A)
I 0.07 lux color night view mode (BB-HCM705A), 0.04 lux (BB-HCM701A)
I Up to 30 frames per second
I SD memory card recording
I Remote monitoring from cell phone
I 4-up, 9-up, 16-up multi-cameras pages
I Built-in web server/IP address (IPv4/v6)
I Built-in microphone
I Password protection
I Plug & play installation
I Multi-language interface
I Image date and time stamp
I
Network Cameras
N E T W O R K
Camera/Recorder Bundles
WJ-ND200/705A4
WJ-ND200/701A4
WJ-ND200 NVR with 320GB storage and (4) BB-HCM705A network cameras
WJ-ND200 NVR with 320GB storage and (4) BB-HCM701A network cameras
Popular Accessories
Photo Not
Available
Photo Not
Available
Model No.
Description
BB-HCA7A
AC power
supply
PRCM1
Embedded
mount bracket
BB-HCA11A
Bracket
Page Ref.
—
96
—
PISM5V
Indoor
vandal-resistant
housing
90
POSM5V
Outdoor
vandal-resistant
housing
93
29
Visit www.panasonic.com/security for the latest product information
Accessories
N E T W O R K
C A M E R A S
BB-HCM371A
Wireless Pan/Tilt Network Camera
I
802.11g/b wireless
Pan/tilt/digital zoom with presets
I Splash resistant for outdoor* use
I SD card recording
I 0.2 lux color night view mode
I Up to 30 frames per second CCD
I Remote monitoring from cell phone
I 4-up and 12-up multi-camera pages
I Up to 30 video users
I Built in web server/IP address (IPv4/v6)
I Two way audio capability
I Built-in microphone
I Dual sensor input to trigger movement
I Image transfer by motion detection, sensor alert, timer
I Password protection
I Plug & play installation
I
*Splash resistant body: camera placement under an eave is recommended
30
Visit www.panasonic.com/security for the latest product information
S O F T W A R E
BB-HNP17A
Camera Management Recording Software
Images can be recorded for up to 64 cameras
Record and play H.264, MPEG-4 and JPEG images
Easy to use graphical user interface (GUI), simplified icons
Customizable settings and browser screens
Remote access by browser
Alarm trigger recording (JPEG only)
Scheduled preset position recording
E-mail alert when alarm is detected
Search images quickly via keyword or date/time
Accessories
R E C O R D I N G
31
Visit www.panasonic.com/security for the latest product information
Accessories
S E R V E R / M A N A G E M E N T
S Y S T E M
BB-HCS301A
Network Camera Server
I
Convert nearly any video source to an internet video stream
Analog video conversion to Motion JPEG
I SD memory card recording
I Up to 30 frames per second
I Remote monitoring from cell phone
I 4-up and 12-up multi-camera pages
I Up to 30 video users (stack up to 5 units for 150 users)
I Built in web server/IP address (IPv4/v6)
I Two way audio capability
I Sensor input
I Image transfer by motion detection, sensor alert, timer
I Password protection
I Plug & play installation
I
BB-HGW700A
Camera Management System
I
Automatically configure up to 16 network cameras
Flexible 802.11b/g wireless communication
I Connect multiple devices through a single line
I Built-in firewall protection
I Powerful 64/128/152-bit WEP encryption
I
32
Visit www.panasonic.com/security for the latest product information
BY-HPE11KT
Coaxial-LAN Converter with PoE Function
Easily migrate from an analog system to a network system using
existing coaxial cable
Implement over long distances (up to 1,640’ for PoE connections and
6,561’ for non-PoE connections) when using RG-6/U coaxial cable
High speed digital data transmission up to 45 Mbps
Built-in PoE function powers select Panasonic network cameras
while eliminating the need to install power outlets for each camera
No set-up required, just move the coaxial cable to the
coaxial – LAN converter
Kit includes center and camera adaptors
Meets PoE standards (IEEE802.3af)
Accessories
C O N V E R T E R S
Popular Accessory
Model No.
Description
BY-HCA10
Rack mount
bracket
33
Visit www.panasonic.com/security for the latest product information
Network Cameras
Network Camera Lineup Chart
BB-HCM705A
BB-HCM701A
BB-HCM715A
BB-HCM527A
BB-HCM581A
BB-HCM580A
1.3 Megapixel
fixed dome
Fixed dome
1.3 Megapixel
pan/tilt
PTZ
PTZ
PTZ
1/3" MOS
Progressive Scan
1/5" CMOS
Progressive Scan
1/3" MOS
Progressive Scan
1/3.6" MOS
Progressive Scan
1/4" CCD
Progressive Scan
1/4" CCD
Progressive Scan
Motion JPEG,
MPEG-4, H.264
Motion JPEG,
MPEG-4, H.264
Motion JPEG,
MPEG-4, H.264
Motion JPEG,
MPEG-4
Motion JPEG,
MPEG-4
Motion JPEG,
MPEG-4
Yes
Yes
Yes
Yes
Yes
No
1.5lux
(0.4lux)
0.6lux
(0.07lux)
2x2 Pixel Binning: 0.3lux
(0.04lux)
2lux
(0.2lux)
2lux
(0.09lux)
2lux
(0.09lux)
Shock detection
Sound detection
Motion detection
Cell phone monitoring1
Shock detection
Sound detection
Motion detection
Cell phone monitoring1
Motion detection
Cell phone monitoring1
Motion detection
Cell phone monitoring1
Motion detection
Cell phone monitoring1
Motion detection
Cell phone monitoring1
Up to 30
Up to 30
Up to 30
Up to 30
Up to 30
Up to 30
Image Resolution
1,280 x 960
(Quad-VGA)
640 x 480 (VGA)
1,280 x 960
(Quad-VGA)
640 x 480 (VGA)
640 x 480 (VGA)
640 x 480 (VGA)
Audio Capability
1-way monitoring
(camera to PC)
Built-in microphone
1-way monitoring
(camera to PC)
Built-in microphone
2-way (half duplex)
External microphone
input2
No
Yes (SD/SDHC)
Yes (SD/SDHC)
Yes (SD/SDHC)
Yes (SD/SDHC)
Model
Camera Type
Imaging Device
Compression
PoE
0.6lux
Minimum Illumination
(0.07lux)
(color night view mode) 2x2 Pixel Binning: 0.3lux
(0.04lux)
Key Features
Frames Per Second
SD Memory Card Slot
Lens Type
Yes (SD/SDHC)
ƒ2.4
ƒ2.0
ƒ2.4
69˚/51˚
20˚/104˚
57˚/114˚
66˚/50˚
20˚/104˚
57˚/114˚
69˚/51˚
104˚
53˚
6x zoom (2x Ex zoom,
3x digital zoom)
3x digital zoom
10/100 Base-TX
10/100 Base-TX
10/100 Base-TX
I/O Terminals
1
1
Analog Video Output
No
Viewing Angle (Horiz/Vert)
Pan (Horiz/Vert)
Tilt (Horiz/Vert)
Zoom
Network
Security
Operating Temperature
Operating Humidity
34
2-way (half duplex)
2-way (half duplex)
Built-in microphone
Built-in microphone
External microphone input External microphone input
1Only
Yes (SD/SDHC)
ƒ1.9 (wide)-ƒ2.8 (tele) ƒ1.6 (wide)-ƒ3.6 (tele) ƒ1.6 (wide)-ƒ3.6 (tele)
73˚/55˚
350˚
82˚
42x (21x optical,
2x digital)
42x (21x optical,
2x digital)
10/100 Base-TX
10/100 Base-TX
10/100 Base-TX
3
3
3
3
No
NTSC/PAL
NTSC/PAL
NTSC/PAL2
NTSC/PAL
User ID/Password,
SSL
User ID/Password,
SSL
User ID/Password,
SSL
User ID/Password,
SSL
User ID/Password
User ID/Password
32˚F – 104˚F
32˚F – 104˚F
32˚F – 104˚F
32˚F – 104˚F
32˚F – 104˚F
32˚F – 104˚F
20% to 80%
(No condensation)
20% to 80%
(No condensation)
20% to 80%
(No condensation)
20% to 80%
(No condensation)
20% to 80%
(No condensation)
20% to 80%
(No condensation)
still images in JPEG format can be displayed on a cell phone.
6x zoom (2x Ex zoom, 4.6x (2.3x optical,
3x digital zoom)
2x digital)
51˚/38˚
51˚/38˚
350˚
350˚
120˚on table/90˚on ceiling 120˚on table/90˚on ceiling
2 Connection
with external devices requires the included Audio/Video Cable.
Visit www.panasonic.com/security for the latest product information
Model
Camera Type
Imaging Device
Compression
PoE
Minimum Illumination
(color night view mode)
BB-HCM511A
BB-HCM735A
BB-HCM547A
BB-HCM531A
BB-HCM371A
Pan/tilt
Outdoor*
1.3 Megapixel pan/tilt
Outdoor* PTZ
Outdoor* Pan/tilt
Wireless
Outdoor* Pan/tilt
1/4" CCD
Progressive Scan
1/3" MOS
Progressive Scan
1/3.6" MOS
Progressive Scan
1/4" CCD
Progressive Scan
1/4" CCD
Progressive Scan
Motion JPEG,
MPEG-4
Motion JPEG,
MPEG-4, H.264
Motion JPEG,
MPEG-4
Motion JPEG,
MPEG-4
Motion JPEG
Yes
Yes
Yes
Yes
No
2lux
(0.2lux)
0.6lux
(0.07lux)
2x2 Pixel Binning: 0.3lux
(0.04lux)
2lux
(0.2lux)
2lux
(0.2lux)
3lux
(0.2lux)
Motion detection
Cell phone monitoring1
Splash resistance
Motion detection
Cell phone monitoring1
Splash resistance
Motion detection
Motion detection
Motion detection
Cell phone monitoring1 Cell phone monitoring1
Cell phone monitoring1 Splash
resistance (IP55)
Splash resistance
Key Features
Frames Per Second
Image Resolution
Audio Capability
SD Memory Card Slot
Up to 30
Up to 30
Up to 30
Up to 30
Up to 30
640 x 480 (VGA)
1,280 x 960
(Quad-VGA)
640 x 480 (VGA)
640 x 480 (VGA)
640 x 480 (VGA)
2-way (half duplex)
2-way (half duplex)
2-way (half duplex)
2-way (half duplex)
2-way (half duplex)
Built-in microphone
Built-in microphone
Built-in microphone
Built-in microphone
Built-in microphone
External microphone input External microphone input External microphone input External microphone input External microphone input
Yes (SD/SDHC)
Yes (SD/SDHC)
Yes (SD/SDHC)
Yes (SD/SDHC)
Yes (SD/SDHC)
Lens Type
ƒ2.8
ƒ2.4
ƒ1.9 (wide)-ƒ2.8 (tele)
ƒ2.8
ƒ3.5
Viewing Angle (Horiz/Vert)
Pan (Horiz/Vert)
Tilt (Horiz/Vert)
54˚/40˚
120˚
65˚
69˚/51˚
104˚
53˚
73˚/55˚
350˚
82˚
54˚/40˚
120˚
65˚
53˚/40˚
120˚
65˚
Zoom
10x digital (by area)
Network
I/O Terminals
Analog Video Output
Security
Operating Temperature
Operating Humidity
1Only
Network Cameras
Network Camera Lineup Chart
6x zoom (2x Ex zoom, 4.6x (2.3x optical,
3x digital zoom)
2x digital)
10x digital (by area) 10x digital (by area)
10/100 Base-TX
10/100 Base-TX
10/100 Base-TX
10/100 Base-TX
10/100 Base-TX
3
3
3
3
3
NTSC/PAL
NTSC/PAL
NTSC/PAL
NTSC/PAL
No
User ID/Password
User ID/Password,
SSL
User ID/Password,
SSL
User ID/Password
User ID/Password
32˚F – 104˚F
-4˚F – 122˚F
-4˚F – 122˚F
-4˚F – 122˚F
-4˚F – 122˚F
20% to 80%
(No condensation)
20% to 90%
(No condensation)
20% to 90%
(No condensation)
20% to 90%
(No condensation)
20% to 90%
(No condensation)
still images in JPEG format can be displayed on a cell phone.
*Splash resistant body: camera placement under an eave is recommended
Visit www.panasonic.com/security for the latest product information
35
i-PRO Recorders and Software
The difference between a conventional network recording
device and a Network Video Recorder is a matter of intelligence.
Our new WJ-NV200 NVR clearly distinguishes itself with embedded
real time face matching technology that eliminates the need and
expense of external software. It provides real time face matching
to match registered face images with a face detected by a
Panasonic i-PRO SmartHDTM camera. Just another example of
Panasonic technology that makes advanced functionality available
for every level of application. We’ve got it all covered.
Panasonic System Networks Company of America
36
Surveillance, Monitoring & Video Imaging
V I D E O
WJ-ND400 Series
Network Video Recorder (NVR)
H.264, MPEG-4 and JPEG multi-format recording
Up to 64 network cameras can be connected and
recorded simultaneously
Supports various Axis camera models
No per camera license fees
Expandable up to 54 HDD slots
Recording modes: manual, schedule, event (pre/post),
emergency, external timer
Panasonic camera control: pan/tilt, zoom, focus, brightness,
preset position, and auto mode (depending on camera model)
8 recording programs including individual recording mode
for each camera, and up to 6x schedule per day
Audio can be recorded and played back - G.726 (ADPCM)
32 kbps/16kbps (up to 64 Panasonic i-Pro cameras)
Camera assignment to 1 of 8 groups for easy browsing
Flexible playback controls: go to date (jumps to specific time/date),
go to last (jumps to 5 sec. ~ 5 min. before the recording ended)
Display modes: spot, quad (16 patterns), spot sequence,
quad sequence (live/playback)
Filtered search: time & date, event type, and camera number
VMD search: motion in a specified area of the recorded images
can be searched quickly (works with supported i-PRO cameras and WJ-NT314)
2x and 4x digital zoom (live/playback)
Recorded images can be downloaded to a PC
2x built-in network interfaces (10Base-T/100Base-TX) for camera
recording and client access
Quick IP setup for Panasonic i-PRO network cameras
Bandwidth control: 32k/64k/128k/256k/512k/1,024k/2M/5M/10M (bps)
and unlimited
Up to 16 clients can monitor image and control WJ-ND400 NVR simultaneously
Image transfer to FTP server: recorded image upon alarm and/or live image
Automatically transfer SD memory card stored images from Panasonic i-Pro cameras
Alteration detection and recorded data encryption for data security
Multi-site system management with optional i-Pro management software
Disk partitioning: normal, event, pre-event, and copy for flexible record management
RAID5/6 redundant recording for data security
Reliable embedded Real-Time Operating System
IPv4/IPv6 multi-protocol support
R E C O R D E R S
i-PRO Recorders / Software
N E T W O R K
Specs
Max Storage
Network I/F
Power Source
Ambient Op. Temperature
Dimensions
Weight
Alarm/Control Ports
18 TB (internal), 108 TB (external)
2 x 1000 Mbps, 1 x 100 Mbps
120 VAC, 60Hz, 170W
41° ~ 113° F
16 15/16" x 5 3/16" x 15 3/4" (excludes feet)
28.6 lbs (without canister or HDDs)
32 alarm inputs
Popular Accessories
Model No.
Description
Page Ref.
WJ-HDE400
Hard disk
expansion unit
(9 HDD bays)
—
WV-ASM100
Management
Software
41
WV-ASM100L
Management
SoftwareLight
42
Canister/1000
1TB HDD
in canister
—
37
Visit www.panasonic.com/security for the latest product information
i-PRO Recorders / Software
N E T W O R K
V I D E O
R E C O R D E R S
WJ-ND300A Series
Network Video Recorder (NVR)
Up to 32 network cameras can be connected and recorded
H.264, MPEG-4 and JPEG multi-format recording
No camera licenses
Various recording modes: manual, schedule, event (pre/post), emergency,
and external timer
Alarm sources include 16x terminal inputs, 16x camera alarms
Panasonic camera control: pan/tilt, zoom, focus, brightness, preset
position, auto mode (depending on camera model)
Cameras may be assigned to one of 8 groups to meet
application requirements
Flexible playback controls: A-B repeat, go to date (jump to specific
time/date), go to last (jump to 5 sec. ~ 5 min. before the record end)
Various display modes: spot, quad (8 patterns), spot sequence,
quad sequence
8 quad screens are fully programmable
Filtered search: time & date, event type, camera number and text
Recorded images can be downloaded to a PC
Downloadable viewer software allows playback of images downloaded
from the recorder
Built-in network interfaces (10Base-T/100Base-TX)
Quick IP setup for Panasonic i-Pro series network cameras
Bandwidth control: 32k/64k/128k/256k/512k/1,024k/2M/5M/10M (bps)
and unlimited
Up to 8 clients can monitor images and control WJ-ND300A simultaneously
Image transfer to FTP server
Images recorded on the SD memory card can be downloaded manually
Alarm notification by e-mail
Multi-site system using optional i-Pro management software
Disk partitioning for flexible record management: normal, event, copy
RAID5 capability with optional WJ-NDB301 board
Specs
Max Storage
Network I/F
Power Source
Ambient Op. Temperature
Dimensions
Weight
Alarm/Control Ports
4 TB (internal), 28 TB (external)
2 – 100 Mbps, 1 – 10 Mbps
120 VAC, 60 Hz, 85 W
41° ~ 113° F
16 9/16" x 3 7/16" x 13 3/4" (excludes feet)
18.3 lbs
16 alarm inputs, 16 alarm outputs, control/aux
Popular Accessories
Model No.
Description
WJ-NDB301
RAID5 board
Page Ref.
—
WJ-HDE300
Expansion unit
(4 HDD bays)
—
WV-ASM100
Management
Software
41
38
Visit www.panasonic.com/security for the latest product information
WV-ASM100L
Management
Software- Light
42
V I D E O
WJ-ND200 Series
Network Video Recorder (NVR)
H.264, MPEG-4 and JPEG multi-format recording
Up to 16 network cameras can be connected and recorded
No camera licenses
Various recording modes: manual, schedule, event (pre/post),
emergency, external timer
Various alarm sources include 16x terminal inputs, 16x camera alarm
Panasonic camera control: pan/tilt, zoom, focus, brightness,
preset position, auto mode (depending on camera model)
Audio from the i-Pro network cameras can be recorded and
played back, G.726 (ADPCM) 32 kbps
Cameras may be assigned to one of 4 groups to meet
application requirements
Flexible playback controls: go to date (jump to specific time/date),
go to last (jump to 5 sec. ~ 5 min. before the recording ends)
Various display modes: spot, quad (4 patterns), spot sequence,
quad sequence (sequence: live only)
4 Quad screens are fully programmable
Recorded images can be downloaded to a PC
Quick IP setup for Panasonic i-Pro series network cameras
Bandwidth control: 32 k / 64 k / 128 k / 256 k / 512 k / 1,024 k /
2 M / 5 M / 10 M (bps) and unlimited
Up to 4 clients can monitor and control WJ-ND200 simultaneously
Image transfer to FTP server
Performance measurement function for appropriate recording frame
rate setup
SD memory recording for network failure (automatic or manual)
Up to 2 hard disk drives (HDDs) can be installed
Removable HDD can be connected to a PC via the optional WJ-HDC20
connection unit and played back with provided HDD viewer software
Alarm notification by e-mail
User/Host authentication, 4 user levels and user-camera
view/control partitioning
RAID1 mirroring capability
R E C O R D E R S
i-PRO Recorders / Software
N E T W O R K
Specs
Max Storage
Network I/F
Power Source
Ambient Op. Temperature
Dimensions
Weight
Alarm/Control Ports
1000 GB (internal, removable)
1 - 100 Mbps
120 VAC, 60 Hz, 35 W
41° ~ 113° F
10 5/8" x 3 1/2" x 14 1/4" (excludes feet)
11 lbs
16 alarm inputs, 16 alarm outputs, control/aux
Popular Accessories
Model No.
Description
Page Ref.
ST320REM
320 GB
removable HDD
—
WV-ASM100
Management
Software
41
WV-ASM100L
Management
Software-Light
42
39
Visit www.panasonic.com/security for the latest product information
i-PRO Recorders / Software
N E T W O R K
V I D E O
R E C O R D E R S
WJ-NV200 Series
Network Video Recorder (NVR)
H.264, MPEG-4 and JPEG multi format
Up to 16 network cameras can be connected and recorded
Quick setup via automatic camera detection and simple setup wizard
without the use of PC
‘Referenced recording days’ is automatically calculated by frame rate,
image quality and HDD capacity
Simple mouse operation with new GUI without the use of a PC
Quick intuitive search with calendar and timeline
RTSP over HTTP supported for monitoring via the Internet
Live images from up to 16 cameras can be displayed simultaneously
Supports Full HD output (HDMI) which can display recorded images
and live images in High Definition
Real Time Face Matching function matches registered face images with a
face displayed on live images - only 1 channel with cameras supports
face detection (WV-NP502, WV-SP306, WV-SP305 recommended)
Face matching alarm is notified by Buzzer / E-mail / Panasonic alarm /
Terminal output / Indicator
Various alarm sources include 9x Terminal inputs, 16x Camera alarm,
Panasonic Alarm Protocol
Flexible alarm actions include Alarm recording, E-mail notification,
Alarm message, Camera positioning, Terminal output, Panasonic
alarm protocol output, Buzzer and Indicator
Camera control: Pan/Tilt, Zoom, Focus, Brightness, Preset Position,
Auto mode
Audio recording and playback from select i-PRO network cameras,
G.726 (ADPCM) 32 kbps
Flexible Playback Controls: Goto Date (Jump to specific time/date),
Goto Last (Jump to 30 sec. before the recording ends)
Various Display Modes: Spot, Multi-screen (4 / 16 split screen display,
3 / 6 / 9 / 16 split screen display on a full screen)
Various Recording Modes: Schedule, Event (Pre/Post)
Filtered Search: Time & Date, Event Type, Camera number, Timeline
Recorded images can be downloaded to a PC
Downloadable viewer software allows playback of images downloaded
from the Recorder
Built-in network interface (10Base-T / 100Base-TX / 1000Base-T)
for recording and client access
Up to 2 clients can monitor image and control WJ-NV200 simultaneously
Up to 2 HDDs can be installed - 3.5 inch Serial ATA HDD
Specs
Max Storage
Network
Power Source
Ambient Op. Temperature
Dimensions
Weight
Alarm/Control Ports
6 TB (internal, 3TB HDD)
1 - 100 Mbps
120 VAC, 60 Hz, 45 W
41° ~ 113° F
16 17/32" x 3 15/32" x 11 13/16" (excludes feet)
approx. 14 lbs
9 alarm inputs/16x camera alarms
40
Visit www.panasonic.com/security for the latest product information
M A N A G E M E N T
S O F T W A R E
WV-ASM100
Management Software Solution for Panasonic
NVR’s, DVR’s and i-PRO Cameras
Complete software management and live monitoring software
for Panasonic WJ-ND400/ND300A/NV200/ND200 NVR series,
WJ-HD716/HD616/HD300A DVR series and i-PRO network
cameras and encoders
Up to 100 recorders, 64 encoders and 256 directly connected
cameras can be registered. Up to 6,400 cameras and 256 cameras
on the encoders are automatically registered on the software
For flexible design, live images can be received directly from the
camera/encoder or via the recorder
Multi-monitor option enables simultaneous use of Operation
Display (1/4/9/16 split), Live Display (1/4/9/16 split) and Map
Display each on a dedicated monitor
Up to 400 camera groups: cameras and multi-screen mode for the
Operation Display can be programmed and called up by manual or
sequence operation
Image resolution dynamically changes depending on the screen
mode: VGA for Quad screen, QVGA for 16 split screen
Panasonic camera control
A camera, a group or a sequence can be called up on the
Operation Display by ID with the optional system controller
WV-CU950
Alarm pop-up notification/messaging
Up to 64 camera icons can be freely positioned on a map with
alarm status indicated by the color of the icons
Download video clips for archiving
Minimum PC Requirements:
- CPU
Intel Core 2 Duo 2.66 GHz or faster
Intel Core i7-920 or faster (during H.264 operation)
- RAM
1GB or more
3GB or more (during H.264 operation)
- Video card
VRAM: 128MB or more, compatible with Microsoft
DirectX 9.0c or later
- OS
Microsoft Windows 7 Professional 32bit/64bit
Microsoft Windows Vista Business SP2 32bit/64bit
Microsoft Windows XP Home SP3, Microsoft Windows XP
Professional SP3
Optional Equipment Shown
i-PRO Recorders / Software
R E C O R D I N G
Accessory
Model No.
Description
Page Ref.
WV-CU950
System
Controller
79
See Management Software Comparison Chart on page 71
41
Visit www.panasonic.com/security for the latest product information
i-PRO Recorders / Software
R E C O R D I N G
M A N A G E M E N T
S O F T W A R E
WV-ASM100L
Management Software Solution for Panasonic
NVR’s, DVR’s and i-PRO Cameras Light Version
Complete software management and live monitoring software
for Panasonic WJ-ND400/ND300A/NV200/ND200 NVR series,
WJ-HD716/HD616/HD300A DVR series and i-PRO network
cameras and encoders
Up to 100 recorders, 64 encoders and 256 directly connected
cameras can be registered. Up to 6,400 cameras and 256 cameras
on the encoders are automatically registered on the software
For flexible design, live images can be received directly from the
camera/encoder or via the recorder
Up to 400 camera groups: cameras and multi-screen mode for
the Operation Display can be programmed and called up by
manual or sequence operation
Image resolution dynamically changes depending on the
screen mode: VGA for Quad screen, QVGA for 16 split screen
Panasonic camera control
Alarm pop-up notification/messaging
Up to 64 camera icons can be freely positioned on a map
with alarm status indicated by the color of the icons
Download video clips for archiving
Minimum PC Requirements:
- CPU
Intel Core 2 Duo 2.66 GHz or faster
Intel Core i7-920 or faster (during H.264 operation)
- RAM
1GB or more
3GB or more (during H.264 operation)
- Video card
VRAM: 128MB or more, compatible with Microsoft
DirectX 9.0c or later
- OS
Microsoft Windows 7 Professional 32bit/64bit
Microsoft Windows Vista Business SP2 32bit/64bit
Microsoft Windows XP Home SP3, Microsoft Windows XP
Professional SP3
See Management Software Comparison Chart on page 71
42
Visit www.panasonic.com/security for the latest product information
i-PRO Recorders / Software
M A N A G E M E N T
S O F T W A R E
WV-ASM970
Management Software for PMPU1000
Dedicated GUI (Graphic User Interface) for PMPU1000
Two monitor operation is available (1st: map & operation,
2nd: live and playback video)
Multi-split screen (1/4/7/9/10/13/16 split) support
Up to 30 ips/camera can be displayed in 16 split-screen in
H.264 1.5 Mbps mode with VGA
Camera Control (PTZ, Preset, Iris, Auto function and so on) supported
Recorder Control (REC, Play, R-Play, FF, REW, Pause, Stop, Go to date,
Go to last and so on) supported
Up to 100 map (JPEG or Bitmap) with up to 64 camera icons in a map
File converter is included; converts Panasonic file format to MP4
One license per PMPU1000 server
License includes up to 64 WV-ASM970 installations
Minimum PC Requirements:
- CPU
Intel CoreTM2 Quad Q9650 or faster
Intel CoreTM i7-920 or faster (Panasonic recommends)
- RAM
3GB or more
- Video Card
VRAM: 256MB or more, compatible with DirectX 9.0c
- OS
Microsoft Windows 7 Professional (32bit/64bit) (English or Chinese Version)
Microsoft Windows Vista Business SP2 (32bit/64bit) (English or Chinese Version)
Microsoft Windows XP Professional SP3 (32bit) (English or Chinese Version)
Operation Window
Camera Control Panel
Video Window
Playback Control Panel
File Converter
43
Visit www.panasonic.com/security for the latest product information
i-PRO Encoders and Decoders
Panasonic makes it easy to integrate your analog cameras on
a network platform with the performance features you want.
Our encoders and decoders feature advanced built-in video
analytics, High Definition quality, multi-format output for viewing
and recording, and multiplex combinations to accommodate
multiple cameras. We’ve got it all covered.
Panasonic System Networks Company of America
44
Surveillance, Monitoring & Video Imaging
/
D E C O D E R S
WJ-GXE500
4-Channel H.264 Video Encoder
Full frame H.264 transmission for all 4 channels
Dual streams of H.264 (High profile) and JPEG at
VGA / D1 image size
Motion adaptive interlace/progressive conversion
produces clear frames even when the subject is moving
Compensates picture degration caused by
long-distance cable - clear picture is maintained
Coaxial communication ensures the control of
Panasonic PTZ cameras via coaxial cable
Open command conversion table for RS-485 ensures the control
of various manufacturer’s PTZ cameras
SD/SDHC Memory card slot for manual recording, alarm recording,
and backup upon network failure (JPEG)
Camera title display: up to 16 alphanumeric characters embedded
in the image
Full duplex bi-directional audio allows interactive communication
PoE (power will be supplied by simply connecting a LAN cable –
IEEE802.3af compliant)
Rack mountable with mounting brackets
Alarm sources including 3 terminal input, VMD, camera site alarm,
video loss, and Panasonic alarm
VMD (Video Motion Detector) with 4 programmable detection areas
Face detection technology detects the position of human face and
the information is sent by XML or video stream (Ch1 only)
Meta data for VMD is supplied to work with the WJ-ND400 NVR
playback VMD function
Specs
i-PRO Encoders / Decoders
E N C O D E R S
Popular Accessory
Image compression
Protocol
Video input
Resolution
Op. Temp.
Power/Consump.
Dimensions
Weight:
H.264/MPEG-4/JPEG
IPv6: TCP/IP, UDP/IP, HTTP, RTP, FTP, SMTP, DNS, NTP, SNMP
4x
720 x 480 (D1), 640 x 480 (VGA), 320 x 240 (QVGA)
14º ~ 122º F
12V DC, 500 mA / PoE, 6W
5 1/2" x 1 ¾" x 7 9/32"
2.21 lbs (1kg)
Model No.
Description
Page Ref.
WV-Q204/2S
Rack mounting bracket
(2 units)
—
WJ-GXD400
Multi-Channel High Definition Video Decoder
for i-PRO Network Surveillance System
Multi-channel high-definition video decoder with HDMI video interface
1x 4 VGA (1280 x 960) images with 2x VGA images in 3 split
screens or 6x VGA (640 x 480) images in 6 split screens
VGA image displayed at 30ips/sec
Registers up to 256 cameras including the cameras connected to
i-PRO Network Video Encoders
Supports tour sequence and group sequence
Supports camera site alarm signal: alarm indication displayed and
alarm terminal output activated
Supports multicast / unicast for efficient network usage
Single channel audio decoding G.726
High-speed network interface (100Base-T/1000Base-T),
maintenance port (10Base-T)
Browser GUI
Embedded Real-Time Operating System delivers high reliability
Operating temperature 14° ~ 122°F
Specs
Popular Accessories
Image Format
Resolution
Audio Format
Video Output
Network Interface
Multicast
Power/Consumption
Dimensions
Weight
MPEG-4, JPEG (multi-decoding)
1,280 x 960, 640 x 480, 320 x 240
G.726 (ADPCM), 32 kbps / 16 kbps
1,920 x 1,080: 1 x 4VGA (1,280 x 960) with 2x VGA or
6x VGA 30 frames/sec., audio supported
10Base-T/100-BaseTX/1000Base-T, RJ-45 connector
Yes
12V DC, 1.4 A
8 1/4” x 1 3/4” x 12 1/16” (210mm x 44mm x 300mm)
4.4 lbs (2.0kg)
Model No.
Description
Page Ref.
Visit www.panasonic.com/security for the latest product information
WV-Q204/1S
Rack mounting bracket
(1 unit only)
—
WV-Q204/2S
Rack mounting bracket
(2 units)
—
45
Analog Cameras
Panasonic continues to introduce new imaging solutions that
make any analog platform smarter. Our Super Dynamic 5 camera
technology produces superior resolution images with features
like Adaptive Black Stretch (ABS), intelligent Video Motion
Detection (i-VMD) and enhanced Day/Night operation. Available
in a wide variety of configurations, Super Dynamic 5 cameras
are the most advanced analog imaging devices available for
professional security applications. We’ve got it all covered.
Panasonic System Networks Company of America
46
Surveillance, Monitoring & Video Imaging
Analog Cameras
P T Z
C A M E R A S
WV-CW974
Super Dynamic III Weather Proof Day/Night Dome Camera
All-in-one outdoor unit
Advanced auto tracking for precise surveillance
Template matching algorithm tracks human subjects accurately
Weather-proof environmental structure meets IP66 standards
Built-in fan/heater for temperature changes between -40°F ~ +122°F
Super Dynamic III (SDIII) technology delivers 128x wider dynamic range and Intelligent
Technology features for exceptional images in virtually any lighting condition
540 lines of horizontal resolution in color mode, 570 lines in B/W
Minimum illumination of 0.5 lux in color mode, 0.04 lux in B/W at ƒ1.4 (wide)
Auto Image Stabilization function for applications where vibration or wind is a concern
Day/Night operation can be selected to automatically or manually switch from
color to B/W
30x optical zoom lens, plus 10x electronic digital zoom (300x total)
Adaptive Digital Noise Reduction: integration of 2D-DNR and 3D-DNR ensures
noise reduction in various conditions
Electronic sensitivity enhancement (auto/manual)
Panning speed of max. 400°/sec at preset mode and 0.065°/sec super fine control
at manual mode
256 presets
Built-in Video Motion Detection with sensitivity (256 steps, mask 8x6 areas)
Scene Change Detection alarms when lens is covered, spray painted,
removed or defocused
4 alarm input and 2 output terminals
Over the coaxial cable or RS-485 data communication
Built-in sun shield permits camera locations in direct sunlight
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Pan Range/Speed
Power/Consumption
Dimensions
Weight (camera)
1/4" CCD
540 lines in color, 570 lines on B/W
0.5 lux in color, 0.04 lux in B/W at ƒ1.4 (wide)
SDIII, 52dB
-40° ~ 122° F
Interlace/768 (H) x 494 (V)
Auto Image Stabilization, Scene Change Detection, SDIII, Day/Night, Advanced
Auto Tracking with template matching algorithm, auto focus
3.8-114mm / 30x optical + 10x electronic (300x total)
360°/0.065° ~ 120°sec
24V AC, 60 Hz, 17 W (62 W heater)
9 7/16” x 15 9/16” (239mm x 395.5mm)
10.4 lbs (4.7kg)
Popular Accessories
MOUNTING
BRACKETS
Model No.
Description
Page Ref.
PWM20G
Gooseneck –
wall, Black
95
PWM20GB
Gooseneck –
wall, Beige
95
PWM20GS
Gooseneck –
wall, Silver
95
PWM30G
Parapet,
Black
95
PWM30GB
Parapet,
Beige
95
PPRM30G
Extended Parapet,
Black
95
PPRM30GB
Extended Parapet,
Beige
95
MISCELLANEOUS
Model No.
WV-7176E
Description
Sunshield cover
Page Ref.
—
47
Visit www.panasonic.com/security for the latest product information
Analog Cameras
P T Z
C A M E R A S
WV-CW964
Super Dynamic III Weather Proof Day/Night Dome Camera
Super Dynamic III (SDIII) technology delivers 128x wider dynamic range and Intelligent
Technology features for exceptional images in virtually any lighting condition
Automatic Day/Night switching for 24-hour surveillance
Weather proof camera meets IP66 international standards for water and dust resistance
540 lines of horizontal resolution in color, 570 lines in B/W
Delivers B/W images in as little as 0.04 lux of illumination, 0.5 lux in color
300x zoom magnification (30x optical – 10x electronic)
Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR integration ensures reduced
noise in various conditions
Panning speed of max. 400°/sec at preset mode and 0.065°/sec super fine control
at manual mode
Auto tracking: camera follows largest movement in image automatically and will
pan and tilt to keep subject in center of image
Built-in Video Motion Detection with sensitivity (256 steps, mask 8 x 6 areas)
Scene Change Detection alarms when lens is covered, spray painted,
removed or defocused
Built-in fan/heater for temperature changes of –40° F ~ +122° F
All-in-one outdoor unit
Built-in sun shield permits camera locations in direct sunlight
256 presets
Over the coax cable or RS-485 data communication
4 alarm input and 2 output terminals
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Pan Range/Speed
Presets
I/O Terminals
Power/Consumption
Dimensions
Weight (camera)
1/4" CCD
540 lines in color, 570 lines in B/W
0.5 lux color, 0.04 lux B/W
Super Dynamic III, 52dB
-40° ~ 122° F
Interlace/768 (H) x 494 (V)
SDIII, IP66, Day/Night, Auto Tracking, Auto Image Stabilization,
Auto Scene Change Detection
3.8mm ~ 114mm/30x optical + 10x electronic/ƒ1.4 ~ 22
360°/0.065° ~ 120°/sec
256
6
24V AC/17 W camera, 62 W heater
9 7/16” x 15 9/16” (239mm x 395.5mm)
10.4 lbs (4.7kg)
Popular Accessories
MOUNTING
BRACKETS
Model No.
Description
Page Ref.
PWM20G
Gooseneck –
wall, Black
95
PWM20GB
Gooseneck –
wall, Beige
95
PWM20GS
Gooseneck –
wall, Silver
95
PWM30G
Parapet,
Black
95
PWM30GB
Parapet,
Beige
95
PPRM30G
Extended Parapet,
Black
95
PPRM30GB
Extended Parapet,
Beige
95
MISCELLANEOUS
Model No.
WV-7176E
Description
Sunshield cover
Page Ref.
—
48
Visit www.panasonic.com/security for the latest product information
C A M E R A S
WV-CS954
Super Dynamic III Day/Night Dome Camera
Super Dynamic III (SDIII) technology delivers 128x wider dynamic range and
Intelligent Technology features for exceptional images in virtually any lighting condition
30x optical zoom and 10x electronic zoom (300x total)
540 lines of horizontal resolution in color, 570 lines in B/W
Up-the-coax camera control / RS485 camera control
Minimum sensitivity; 0.04 lux in B/W mode or 0.5 lux in color mode at ƒ1.4 (wide)
Privacy zone masking function
Automatic Day/Night switching for 24-hour surveillance
Auto panning function with 256 preset positions
Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR integration ensures reduced noise
and motion blur in various conditions
Pan/Tilt speed of max. 400°/sec at preset mode and 0.065°/sec super fine control
at manual mode
Auto tracking: camera automatically pans and tilts to follow moving subject and keeps it
in center of the image
Proportional pan/tilt speed: speed varies corresponding to zoom position for easier operation
Built-in Video Motion Detection with sensitivity (256 steps, mask 8 x 6 areas)
Scene change detection alarms when lens is covered, spray painted, removed or defocused
Privacy zone can mask up to 8 private areas
Patrol function
256 presets
Analog Cameras
P T Z
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Pan Range/Speed
Presets
I/O Terminals
Power/Consumption
Dimensions
Weight (camera)
1/4" CCD
540 lines in color, 570 lines in B/W
0.5 lux color, 0.04 lux B/W at ƒ1.4 (wide)
Super Dynamic III, 52dB
14° ~ 122° F
Interlace/768 (H) x 494 (V)
SDIII, Auto Tracking, Image Stabilizer, Day/Night, Scene Change Detection
3.8mm ~ 114mm/30x optical + 10x electronic/F1.4 ~ 22
360°/0.065° ~ 120°sec
256
4
24V AC/13 W
6 1/16” x 9 3/16” (154.5mm ~ 233mm)
4.84 lbs (2.2kg)
Popular Accessories
HOUSINGS
Model No.
Type
Location
Description
Comments
PIDV7CN
Ceiling
Indoor
Steel
upper housing
Clear dome
PIDV7SN
Ceiling
Indoor
Steel
upper housing
Tinted dome
PID9
Ceiling
Indoor
Steel
upper housing
Tinted dome
Page Ref.
90
90
89
MOUNTING
BRACKETS
Model No.
Type
Location
Comments
Page Ref.
POD9C
Pendant
Outdoor
Silver color/
clear dome
Includes
Heater/Blower
92
WV-Q105
Direct
ceiling mount
Indoor
WV-Q116
Embedded
ceiling mount
Indoor
WV-Q117
Suspended
ceiling mount
Indoor
96
96
97
POD9CW
Wall
Outdoor
Silver color/
clear dome
Includes
Heater/Blower
92
WV-Q118
Wall
POD9CWT
Wall
Outdoor
White color/
clear dome
Includes
Heater/Blower
92
POD9CT
Pendant
Outdoor
White color/
clear dome
Includes
Heater/Blower
92
MISCELLANEOUS
Model No.
WV-CS3S
Description
Smoke cover
Page Ref.
—
Indoor
1" cable
opening
97
49
Visit www.panasonic.com/security for the latest product information
Analog Cameras
P T Z
C A M E R A S
WV-CS574
Color Dome Camera
510 lines of horizontal resolution
Minimum illumination of 1 lux at ƒ1.6 (wide)
22x optical zoom lens,10x electronic zoom (220x total)
Auto panning function w/32 preset positions
Optical Slip Ring System
Privacy zone can mask up to 8 areas
Image hold during panning
Auto focus lens
Patrol learn function
Digital Noise Reduction: 3D-DNR reduces noise in various conditions
Electronic sensitivity enhancement: auto (up to 32x) / fix (up to 32x)
Pan/Tilt speed of max. 300°/sec at preset mode and 0.1°/sec super fine control
at manual mode
64 presets
Video Motion Detection with sensitivity (32 steps, 8 x 6 mask areas)
Over the coaxial cable or RS-485 data communication
Area title – displays OSD title for each of 8 panning directions
Popular Accessories
HOUSINGS
Model No.
Type
Location
Description
PDM9
Drop Ceiling
Indoor
For suspended
ceiling
PIDV7CN
Ceiling
Indoor
Steel upper
housing
Clear dome
PIDV7SN
Ceiling
Indoor
Steel upper
housing
Tinted dome
89
90
90
Comments
Page Ref.
POD9C
Pendant
Outdoor
Silver color/
clear dome
Includes
Heater/Blower
92
MOUNTING
BRACKETS
Model No.
Type
Location
Comments
Page Ref.
POD9CW
Wall
Outdoor
Silver color/
clear dome
Includes
Heater/Blower
92
POD9CT
Pendant
Outdoor
White color/
clear dome
Includes
Heater/Blower
92
WV-Q105
Direct
ceiling mount
Indoor
WV-Q117
Suspended
ceiling mount
Indoor
96
97
ACCESSORIES
Model No.
WV-CS2S
Type
Smoke cover
Page Ref.
—
50
Visit www.panasonic.com/security for the latest product information
POD9CWT
Wall
Outdoor
White color/
clear dome
Includes
Heater/Blower
92
WV-Q118
Wall
Indoor
1" cable
opening
97
WV-CS2M
Mirror cover
—
D O M E
C A M E R A S
WV-CF504
Super Dynamic 5 Fixed Dome Camera
Super Dynamic 5 delivers superior image by combining Super Dynamic, ABS
(Adaptive Black Stretch) and i-VMD (intelligent- Video Motion Detection) technology
High resolution: 650 TV lines typical (Color mode), 700 TV lines minimum (B/W mode)
High sensitivity with Day/Night function: 0.1 lx (Color), 0.01 lx (B/W) at F1.4 (Wide) IR cut filter switches on/off to enhance the sensitivity in B/W mode
i-VMD (intelligent-Video Motion Detection) including video motion detection,
object detection (removal and left behind), scene change detection when
lens is covered, spray painted, removed or defocused
ABF (Auto Back Focus) ensures easy installation and stable focus in both color
and B/W modes
3-dimensional color conversion function for natural color reproduction even in
lower color temperature situation
Adaptive Digital Noise Reduction: Integration of 2D-DNR and 3D-DNR ensures
noise reduction in various conditions
Electronic sensitivity enhancement: Auto (Up to 32x) / Manual (Up to 32x)
Electronic shutter from 1/100 (NTSC), 1/120 (PAL) to 1/10,000 s
3.8 ~ 8.0 mm, 2x vari-focal Auto Iris lens with 2x digital zoom
Auto Image Stabilizer for applications where vibration or wind is a concern
Internal / Line-lock / Multiplexed Vertical Drive (VD2) synchronization
Over the coaxial cable data communication
16 alphanumeric camera title display
Multi -language: English, French, Italian, Spanish, German, Russian
Monitor output for easier installation
3-way hinge (horizontal, vertical and swivel rotation) for easy installation
Mounting options: surface mount or embedded ceiling mount
Analog Cameras
F I X E D
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Special Features
Scan Method/Pixels
Lens
Power/Consumption
Dimensions
1/3" type CCD
650 lines in color, 700 in B/W
0.1 lux in color, 0.01 lux in B/W at ƒ1.4
14° ~ 122° F
Super Dynamic 5, Day/Night, Auto Back Focus (ABF), i-VMD
Interlace/976 (H) x 494 (V)
2x vari-focal/3.8 ~ 8 mm
24V AC/602 Hz, 3.4W, 12V DC/280 mA
5 15/16" x 5 1/16" H (151 mm x 129 mm)
Popular Accessories
Photo Not
Available
Model No.
Description
Page Ref.
WV-Q175
Embedded
ceiling mount
WV-CW4S
Smoked
Dome Cover
—
51
Visit www.panasonic.com/security for the latest product information
Analog Cameras
F I X E D
D O M E
C A M E R A S
WV-CF324
Ruggedized Day/Night Fixed Dome Camera
540 lines of horizontal resolution
High sensitivity with simple Day/Night function: 0.9 lux (with optional clear dome cover),
1.8 lux (with standard smoke dome cover) at ƒ1.3 (wide)
Adaptive Black Stretch enhances the visibility of dark areas without compromising
the bright areas
Auto Back Focus (ABF) re-adjusts back focus when switching from color to B/W,
ensuring optimal picture quality and reducing post-installation intervention
Various adjustment features include: Back-Light Compensation (BLC),
Auto Tracing White Balance (ATW) and Automatic Light Control (ALC)
2.8 ~ 10 mm, 3.6x vari-focal auto iris lens
Monitor output and ELC mode for easy lens adjustment during installation
Three-way hinge (horizontal, vertical and swivel rotation) for flexible installation
Ruggedized metal body and polycarbonate dome cover for durability
Internal/multiplexed vertical drive synchronization:
multiple cameras can be synchronized easily
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illuminations
Ambient Temperature
Scan Methods/Pixels
Special Features
Lens
Power/Consumption
Dimensions
Weight (camera)
¼" CCD
540 lines in color
1.8 lux in color (smoke dome), 0.9 lux in color
(clear dome) at ƒ1.3 (wide)
14º ~ 122ºF
Interlace/768 (H) x 494 (V)
Simple Day/Night, Auto Back Focus (ABF)
3.6x vari-focal/2.8 ~ 10 mm
24V AC, 12 V DC/2.7W, 220 mA
5 3/4" x 3 7/8" H (146 mm x 98 mm)
1.65 lbs (750g)
Popular Accessory
Model No. WV-NF5C
Description Clear dome cover
Page Ref.
—
52
Visit www.panasonic.com/security for the latest product information
D O M E
C A M E R A S
WV-CF294/WV-CF284 Series
Day/Night Fixed Dome Camera
540 lines of horizontal resolution
Adaptive Black Stretch enhances the visibility of dark areas without compromising
the bright areas
High sensitivity with simple Day/Night function: 0.9 lux (Color or B/W)
Auto Back Focus (ABF) re-adjusts back focus when switching from color to B/W, ensuring
optimal picture quality and reducing post-installation intervention (WV-CF294 Series only)
Adjustment features include: Back-Light Compensation (BLC), Auto Tracing White Balance
(ATW) and Automatic Light Control (ALC)
2.8 ~ 10mm, 3.6x vari-focal auto iris lens (WV-CF294 series only)
2.8 ~ 6mm, 2x vari-focal auto iris lens (WV-CF284 series only)
Monitor output and ELC mode for easier lens adjustment upon installation
Three-way hinge (horizontal, vertical and swivel rotation) for easy installation
Internal/multiplexed vertical drive synchronization: multiple cameras can be
synchronized easily
Various mounting options: surface mount, embedded mount (with optional WV-Q168),
mounting to junction box (locally obtained)
Analog Cameras
F I X E D
WV-CF294
Series
only
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Power/Consumption
Dimensions
Weight (camera)
1/4" CCD
540 lines in color
0.9 lux in color
14° ~ 122° F
Interlace/768 (H) x 494 (V)
Auto Back Focus (WV-CF294 Series only), Simple Day/Night
(chrominance signal is removed to achieve B/W), UTP version available
WV-CF294 Series: 3.6x vari-focal/2.8 ~ 10mm/ƒ1.3 ~ 3.1
WV-CF284 Series: 2x vari-focal/2.8 ~ 6mm/ƒ1.4 ~ 1.8
24V AC, 12V DC/2.7 W
5 1/8” x 3 5/8” (129.5mm x 93mm)
1 lb (460g)
Popular Accessories
Model No.
Description
Page Ref.
PCRM1
Recessed
ceiling
housing
96
WV-Q168
Embedded
ceiling
mount
—
53
Visit www.panasonic.com/security for the latest product information
Analog Cameras
VA N D A L - R E S I S TA N T
C A M E R A S
WV-CW504 Series
Super Dynamic 5 Vandal-Resistant Fixed Dome Camera
Super Dynamic 5 delivers superior image quality by incorporating a combination
of Super Dynamic, ABS (Adaptive Black Stretch) and i-VMD (intelligent-Video
Motion Detection) compensation technology
650 lines of horizontal resolution (color), 700 lines (B/W)
High sensitivity with Day/Night function: 0.1 lux (Color), 0.01 lux (B/W) with clear dome
cover at ƒ1.4 (Wide). IR cut filter switches on/off to enhance the sensitivity in B/W mode
i-VMD (intelligent-Video Motion Detection) including video motion detection, object
abandonment/removal detection, scene change detection when lens is covered,
spray painted, removed or defocused
Auto Back Focus (ABF) ensures easy installation and stable focus in both color
and B/W modes
3-dimensional color conversion function for natural color reproduction even in lower
color temperature situations
Adaptive Digital Noise Reduction: Integration of 2D-DNR and 3D-DNR ensures
noise reduction in various conditions
Electronic sensitivity enhancement: auto (up to 32x) / manual (up to 32x)
Electronic shutter from 1/100 to 1/10,000 sec.
3.8 ~ 8.0 mm, 2x vari-focal Auto Iris lens with 2x digital zoom
Auto Image Stabilizer for applications where vibration or wind is a concern
Internal / Line-lock / Multiplexed Vertical Drive (VD2) synchronization
Over the coaxial cable data communication
IP66 rated water and dust resistant. Compatible with IEC60529 measurement standard
Dehumidification device for use in various weather conditions
Vandal resistant mechanism for high reliability
Monitor output for easier installation
3-way hinge (horizontal, vertical and swivel rotation) for easy installation
2 piece mounting bracket structure for easy cable connection
Available in flush mount (WV-CW504F) and surface mount (WV-CW504S) options
Optional heater (model WV-CW5H) maintains operating temperature –22 °F ~ 122 °F
Clear dome standard; smoked dome optional
Specs
Visit www.panasonic.com/SD5 for more details
on Super Dynamic 5 technology
including video demonstrations.
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Other Models Available
WV-CW504F/09
WV-CW504F/15
WV-CW504F/22
WV-CW504S/09
WV-CW504S/15
WV-CW504S/22
Flush mount camera with 9-22mm lens
Flush mount camera with 15-50mm lens
Flush mount camera with 2.2mm lens
Surface mount camera with 9-22mm lens
Surface mount camera with 15-50mm lens
Surface mount camera with 2.2mm lens
1/3" CCD
650 lines in color, 700 lines in B/W
0.1 lux in color, 0.01 lux in B/W
SD5, 52dB
-22° ~ 122°F (with optional heater WV-CW5H)
Interlace/976 (H) x 494 (V)
SD5, Auto Back Focus (ABF), Adaptive Black Stretch (ABS), Day/Night,
intelligent VMD (i-VMD), IP66 rated, 3.8-8.0mm 2x vari-focal auto iris
lens, dehumidification device
24V AC/11W, 12V DC/280 mA
6 7/16” x 7 9/16” x 5 3/4” (164mm x 191.5mm x 146.2mm) surface,
6 1/16” x 5 3/4” (154mm x 191.5mm x 145.7mm) flush
3.74 lbs (1.7kg) surface, 2.97 lbs. (1.35kg) flush
Power/Consumption
Dimensions
Weight (camera)
Popular Accessories
MOUNTING
BRACKETS*
Model No.
Type
Location
PCM484S
Corner
Outdoor
PHM484S
Hanging
Outdoor
PPM484S
Pole
Outdoor
Page Ref.
99
99
99
*Note: Brackets are designed for surface mount cameras only
54
LENSES
Model No.
Size
Iris
Type
Focal Length
Aperture
Page Ref.
PLA22T3DN
1/3"
Auto
Wide
2.2mm
ƒ1.2
86
PLZ15/33
1/3"
Auto
Wide
15 – 50mm
ƒ1.5
85
PWM484S
Wall
Outdoor
WV-Q115
Mounting
Base
WV-Q169
Embedded
Ceiling Mount
99
96
98
MISCELLANEOUS
Model No.
WV-CW4S
Description
Smoked
Dome Cover
Page Ref.
—
Visit www.panasonic.com/security for the latest product information
WV-CW5H
Heater
Unit
—
WV-CW364
Vandal-Resistant Fixed Dome Camera
High resolution: 540 TV lines
High sensitivity with true Day/Night function: 0.6 lx (Color): 0.05 lx (B/W)
ABS (Adaptive Black Stretch) enhances visibility of dark area without degrading image
quality in bright areas
Vandal-resistant mechanism for high reliability
IP66 rated water and dust resistant - compatible with IEC60529 measurement standard
Adjustment features include: BLC (Back Light Compensation), ATW (Auto Tracing White
Balance) and ALC (Automatic Light Control)
2 White Balance modes are selectable with Dip Switch: ATW (Auto Tracking White
Balance) / AWC (Automatic White Balance Control)
2.8 ~ 10 mm 3.6x vari-focal Auto Iris lens
Internal/Multiplexed Vertical Drive (VD2) synchronization
Monitor output for easier lens adjustment upon installation
3-way hinge (horizontal, vertical and swivel rotation) for easy installation
Mounting options: flush mount, surface mount and embedded ceiling mount
Optional heater maintains operating temperature –30 °C ~ +50 °C (–22 °F ~ 122 °F)
C A M E R A S
Analog Cameras
VA N D A L - R E S I S TA N T
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Power/Consumption
Dimensions
Weight (camera)
1/3" CCD
525 lines in color
0.6 lux in color, 0.05 lux in B/W at ƒ1.4 (wide)
50dB
-22° - 122° F (with optional heater WV-CW5H)
Interlace/768 (H) x 494 (V)
IP66 rated, vandal-resistant, Day/Night
3.6x vari-focal/2.8 - 10m
24V AC, 12V DC/3 W (with optional heater)
6 7/16” x 7 9/16” x 5 3/4” (164mm x 191.5mm x 146.2mm) surface,
6 1/16” x 5 3/4” (154mm x 191.5mm x 145.7mm) flush
3.74 lbs (1.7kg) surface, 2.97 lbs. (1.35kg) flush
Photo Not
Available
MISCELLANEOUS
Model No.
Description
Page Ref.
WV-Q169
Recessed
Ceiling Mount
98
WV-CW4S
Smoked
Dome Cover
—
WV-CW5H
Heater
unit
55
Visit www.panasonic.com/security for the latest product information
Analog Cameras
VA N D A L - R E S I S TA N T
C A M E R A S
WV-CW334
Vandal-Resistant Fixed Dome Camera
High resolution: 540 TV lines
High sensitivity with simple Day/Night function: 0.6 lx (Color): 0.4 lx (B/W)
ABS (Adaptive Black Stretch) enhances visibility of dark area without
degrading image quality in bright areas
Vandal-resistant mechanism for high reliability
IP66 rated water and dust resistant -compatible with IEC60529
measurement standard
Various adjustment features including BLC (Back Light Compensation),
ATW (Auto Tracing White Balance) and ALC (Automatic Light Control)
2 White Balance modes are selectable with Dip Switch: ATW
(Auto Tracking White Balance) / AWC (Automatic White Balance Control)
2.8 - 10 mm, 3.6x vari-focal Auto Iris lens
Internal/Multiplexed Vertical Drive (VD2) synchronization
Monitor output for easier lens adjustment upon installation
3-way hinge (horizontal, vertical and swivel rotation) for easy installation
Mounting options: flush mount, surface mount and embedded ceiling mount
Optional heater maintains operating temperature –30 °C ~ +50 °C
(–22 °F ~ 122 °F)
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Power/Consumption
Dimensions
Weight (camera)
1/3” CCD
525 lines in color
0.6 lux in color, 0.4 lux in B/W at ƒ1.3 (wide)
-22° - 122° F (with optional heater WV-CW5H)
Interlace/768 (H) x 494 (V)
IP66 rated, vandal-resistant, simple Day/Night
3.6x vari-focal/2.8 - 10mm
24V AC, 12V DC/3 W (with optional heater)
6 7/16" x 5 3/4" x 7 9/16" (164mm x 146mm x 191.5mm)
2.53 lbs (1.27kg)
Photo Not
Available
MISCELLANEOUS
Model No.
Description
Page Ref.
WV-Q169
Recessed
Ceiling Mount
98
WV-CW4S
Smoked
Dome Cover
—
56
Visit www.panasonic.com/security for the latest product information
WV-CW5H
Heater
unit
C O L O R
C A M E R A S
WV-CW384
Super Dynamic III Weather Proof Day/Night Camera
Self-contained bullet style outdoor camera with sun shield
Super Dynamic III (SDIII) technology delivers 128x wider dynamic range and
Intelligent Technology features for exceptional images in virtually any lighting condition
Auto Back Focus (ABF) re-adjusts back focus when switching from color to B/W,
ensuring optimal picture quality and reducing post-installation intervention
Day/Night operation: 540 lines of horizontal resolution (color), 570 (B/W)
High sensitivity: 0.65 lux (Color), 0.09 lux (B/W) at ƒ1.6 (wide)
Signal-to-Noise Ratio: 50 dB
Electronic sensitivity enhancement: auto (up to 10x), manual (up to 32x)
Electronic shutter from 1/100 to 1/10,000 sec
Video Motion Detection with sensitivity (32 steps, mask 8 x 6 areas)
5.0 ~ 40mm, 8x vari-focal lens with 2x digital zoom
Monitor output and ELC mode for easy lens adjustment during installation
Built-in flashing blue LED acts as additional deterrent
Meets IP66 standards for water and dust resistance
Built-in fan, heater and sun shield maintains operating temperature
Versatile mounting bracket encloses the video and power cables properly
Auto Image Stabilizer for applications where vibration or wind is a concern
Over the coaxial cable data communication
Internal/line-lock/multiplexed vertical drive (VD2) synchronization
16 alphanumeric camera title display
Sleek design and easy installation
Analog Cameras
F I X E D
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Lens
Power/Consumption
Dimensions
Weight (camera)
1/3” CCD
540 lines in color, 570 lines in B/W
0.65lux color, 0.09lux B/W at ƒ1.6 (wide)
SDIII, 50dB
-22° ~ 122° F
Interlace/768 (H) x 494 (V)
SDIII, Day/Night, IP66, All-in-one unit
8x vari-focal/5 ~ 40mm/ƒ1.6 ~ 176
24V AC, 12V DC/3.8 W (heater 12 W)
5 1/8” x 9 5/16” x 18 3/16” (130mm x 237mm x 462mm)
2.9 lb (1.3kg)
57
Visit www.panasonic.com/security for the latest product information
Analog Cameras
F I X E D
C O L O R
C A M E R A S
WV-CL930 Series
½" CCD Day/Night Camera*
540 lines of horizontal resolution (color), 570 lines (B/W)
Ultra high sensitivity with Day/Night function: 0.09 lux (Color), 0.008 lux (B/W) at ƒ1.4
Auto Back Focus (ABF) re-adjusts back focus when switching from color to B/W,
ensuring optimal picture quality and reducing post-installation intervention
Adaptive Digital Noise Reduction: 2D-DNR and 3D-DNR integration ensures
reduced noise in various conditions
Back Light Compensation (BLC)
Electronic sensitivity enhancement: auto (up to 32x) / manual (up to 128x)
Video Motion Detection with sensitivity (256 steps, mask 8 x 6 areas)
Scene Change Detection alarms when lens is covered, spray painted, removed or defocused
Day/Night input and alarm output terminals
Auto Image Stabilization for applications where vibration or wind is a concern
Function command: shutter speed and sensitivity enhancement level can be
controlled precisely by function number with optional Panasonic controller
Model WV-CL930: 120V AC, WV-CL934: 24V AC or 12V DC
*Lens Optional
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Power
Dimensions
Weight (camera)
1/2” CCD
540 lines in color, 570 lines in B/W
0.09 lux color, 0.008 lux B/W
14° ~ 122° F
Interlace/768 (H) x 494 (V)
Day/Night, Low light sensitivity, Auto Back Focus
24V AC, 12V DC (WV-CL934), 120V AC (WV-CL930)
2 3/4" x 2 9/16" x 5 15/16" (70mm x 65mm x 151mm)
1.23 lb (560g) WV-CL934, 1.25 lb (570g) WV-CL930
Popular Accessories
LENSES
Model No.
Size
Iris
Type
Focal Length
Aperture
Page Ref.
HOUSINGS
Model No.
Placement
Style
Description
Comments
Page Ref.
PLAHS1770
1/2"
Auto
Zoom Lens
7-70mm
ƒ1.4
87
POH1000
Outdoor
Bullet
10" - Ltwt.
Aluminum
Available with
Heater/Blower
(POH1000HB)
94
BRACKETS
Model No.
Placement
Type
Comments
Page Ref.
WV-LZ81/6A
1/2"
Auto
Zoom Lens
8.5-51mm
ƒ1.2
87
POH1500
Outdoor
Bullet
15" - Ltwt.
Aluminum
Available with
Heater/Blower
(POH1500HB)
94
PUM8
Indoor
Wall
Maximum
weight = 3 lbs
96
58
Visit www.panasonic.com/security for the latest product information
WV-LZA62/2
1/2"
Auto
Zoom Lens
8-80mm
ƒ1.4
85
POH1500HB
Outdoor
Bullet
15" - Ltwt.
Aluminum
Heater/Blower
94
PWM800
Outdoor
Wall
Use with
POH1000/1500
housings
96
C O L O R
Analog Cameras
F I X E D
C A M E R A S
WV-CP500 Series
Super Dynamic 5 Day/Night Fixed Camera*
Super Dynamic 5 delivers superior image quality by incorporating a combination of
Super Dynamic, ABS (Adaptive Black Stretch) and i-VMD (intelligent-Video Motion
Detection) compensation technology
650 lines of horizontal resolution (color), 700 lines (B/W)
High sensitivity with Day/Night function: 0.3 lux (color), 0.04 lux (B/W) at ƒ1.4,
IR cut filter switches on/off to enhance the sensitivity in B/W mode
i-VMD (intelligent-Video Motion Detection) including video motion detection,
object abandonment/removal detection, scene change detection when
lens is covered, spray painted, removed or defocused
Auto Back Focus (ABF) ensures easy installation and stable focus
in both color and B/W modes
3-Dimensional color conversion function for natural color reproduction
even in lower color temperature situation
Adaptive Digital Noise Reduction: integration of 2D-DNR and 3D-DNR ensures
noise reduction in various conditions
Electronic sensitivity enhancement: auto (up to 32x) / manual (up to 32x)
Electronic shutter from 1/100 to 1/10,000 sec.
Digital zoom: up to 2x
Alarm input and alarm output terminals
Auto Image Stabilizer for applications where vibration or wind is a concern
Internal / line-lock / multiplexed vertical drive (VD2) synchronization
Over the coaxial cable data communication
Available in 24V AC or 12V DC (WV-CP504) or 120V AC (WV-CP500) power sources
*Lens Optional
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Dynamic Range
Ambient Temperature
Scan Method/Pixels
Special Features
Power/Consumption
Dimensions
Weight (camera)
1/3" CCD
650 lines in color, 700 lines in B/W
0.3 lux in color, 0.04 lux in B/W
SD5, 52dB
14° ~ 122°F
Interlace/976 (H) x 494 (V)
SD5, Auto Back Focus (ABF), Adaptive Black Stretch (ABS), Day/Night,
intelligent VMD (i-VMD), digital zoom (2x)
24V AC, 12V DC, 120V AC/up to 3.6W
2 13/16” x 2 9/16” x 4 1/16” (72mm x 65mm x 103.5mm) WV-CP504,
2 15/16” x 2 9/16” x 5 3/16” (75mm x 65mm x 132.5mm) WV-CP500
0.77 lbs (350g) WV-CP504, 0.95 lbs. (430g) WV-CP500
Visit www.panasonic.com/SD5 for more details
on Super Dynamic 5 technology
including video demonstrations.
Popular Accessories
LENSES
Model No.
Size
Iris
Type
Focal Length
Aperture
Page Ref.
MOUNTING
BRACKETS
Model No.
Type
Location
Duty
Page Ref.
WV-LZ62/8S
1/3"
Auto
8x Vari-focal(ALC)
5-40mm
ƒ1.6(W)-ƒ1.9 (T)
85
PUM8
Wall
Indoor
Light
(up to 3 lbs.)
96
WV-LZA61/2S
1/3"
Auto
2x Vari-focal (ALC)
3.8-8mm
ƒ1.4 (W) - ƒ1.8 (T)
85
PWM800
Wall
Outdoor
Medium
(up to 25 lbs.)
96
PTVR0916DC
1/3"
Auto
Vari-focal
9-22mm
ƒ1.6
87
HOUSINGS
Model No.
Placement
Style
Description
Comments
Page Ref.
POH1000
Outdoor
Bullet
10" - Ltwt.
Aluminum
Available with
Heater/Blower
(POH1000HB)
94
POH1500
Outdoor
Bullet
15" - Ltwt.
Aluminum
Available with
Heater/Blower
(POH1500HB)
94
59
Visit www.panasonic.com/security for the latest product information
Analog Cameras
F I X E D
C O L O R
C A M E R A S
WV-CP290 Series
Day/Night Camera
New high performance Digital Signal Processor (DSP)
High resolution: 540 TV lines
High sensitivity with Day/Night function: 0.6 lx (Color), 0.04 lx (B/W) at F1.2
IR cut filter switches on/off to enhance the sensitivity in B/W mode
Signal-to-Noise Ratio: 50 dB (equivalent to AGC Off, Weight On)
ABS (Adaptive Black Stretch) enhances visibility of dark area without
degrading image quality in bright areas
Adjustment features include: BLC (Back Light Compensation), ATW (Auto
Tracing White Balance) and ALC (Automatic Light Control)
2 White Balance modes are selectable with Dip Switch: ATW (Auto Tracking
White Balance) / AWC (Automatic White Balance Control)
Internal / Line-lock / Multiplexed Vertical Drive (VD2) synchronization
CS-mount lenses. DC-servo ALC lenses
WV-CP290: 120V AC, 60 Hz; WV-C P294: 24V AC, 60 Hz or 12V DC
Specs
Image Sensor
Resolution (Horizontal)
Minimum Illumination
Ambient Temperature
Scan Method/Pixels
Special Features
Power/Consumption
Dimensions
Weight (camera)
1/3" CCD
540 lines in color
0.8 lux in color, 0.05 in B/W with ƒ1.4 lens
14° ~ 122° F
Interlace/768 (H) x 494 (V)
Adaptive Black Stretch, Day/Night
120V AC 60 Hz, 2.5W (WV-CP290),
24V AC, 50 Hz, 12V DC/240mA (WV-CP294)
2 15/16" x 2 9/16" x 5 3/8" (75m x 65mm x 137)
approx. 0.77 lb (350g)
Popular Accessories
LENSES
Model No.
Size
Iris
Type
Focal Length
Aperture
Page Ref.
WV-LZ62/8S
1/3"
Auto
8x Vari-focal(ALC)
5-40mm
ƒ1.6(W)-ƒ1.9 (T)
85
60
Visit www.panasonic.com/security for the latest product information
WV-LZA61/2S
1/3"
Auto
2x Vari-focal (ALC)
3.8-8mm
ƒ1.4 (W) - ƒ1.8 (T)
85
Pre-tested, pre-assembled, ready for installation
These time-saving packages streamline your ordering and installation. Each package arrives as a fully-assembled unit — complete with
camera, lens, and housing — and is ready for immediate installation at the job site. No separate components to order, unpack,
and collate. You have a wide choice of indoor and outdoor packages, color or day/night and a broad array of vari-focal lenses to
satisfy your system requirements.
Panasonic quality and reliability
Every component in our Ready-to-Go camera packages delivers the quality you expect from Panasonic. Each package is backed
by a three-year Panasonic limited warranty that covers all components.
Indoor/Outdoor Fixed or Dome
Type
Camera
Lens
Housing
Analog Cameras
Panasonic Ready-to-Go Camera Packages
Mount
Color
Model
WV-NP502 WV-CP504 WV-CS954 5-50mm
(i-PRO)
(analog)
(analog) Vari-Focal
Telephoto
Day/Night
2.4-6mm 2.8-12mm
Standard
Built-in
Bullet
Zoom Lens
with PTZ
Outdoor
Dome
Wall or
Outdoor
Dome
Pendant
FIXED
POCNP502LMP05
•
POCNP502LMP24
•
•
•
•
•
•
NETWORK
DAY/
NIGHT
•
DOME
w/PTZ
POS954D
•
•
•
•
POS954DW
•
•
•
•
•
SDIII
DAY/
NIGHT
•
FIXED
POC504L2
•
POC504L5
•
•
•
•
•
•
ANALOG
DAY/
NIGHT
•
Lenses manufactured by third party provider
61
Visit www.panasonic.com/security for the latest product information
Analog Cameras
PTZ and Fixed Dome Camera Lineup
Model
WV-CW974/964
WV-CS954
WV-CS574
WV-CW504S/F
WV-CW364
WV-CW334
Outdoor PTZ
Indoor PTZ
Indoor PTZ
Outdoor Vandal
Outdoor Vandal
Outdoor Vandal
Super Dynamic
SDIII
SDIII
No
SD5
Adaptive
Black Stretch
Adaptive
Black Stretch
Imaging Device
1/4"
1/4"
1/4"
1/3"
1/3"
1/3"
Day/Night
Yes
Yes
No
Yes
Yes
Yes (Simple)
Auto focus
Auto focus
Auto focus
Yes
No
No
0.5lux
0.5lux
1.0lux
0.1lux
0.6lux
0.6lux
0.02lux @ 32x sens up
0.02lux @ 32x sens up
0.032lux @ 32x sens up
0.01lux @ 32x sens up
0.04lux
0.04lux
0.05lux
0.4lux
Adaptive
Black Stretch
IP66 rated
Adaptive
Black Stretch
IP66 rated
Camera Type
Auto Back Focus
Minimum Illumination
(w/clear dome when applicable)
Color
Color w/enhancement
B/W
B/W w/enhancement
Key Features
0.01lux
0.0013lux @ 32x sens up 0.0013lux @ 32x sens up
0.0015lux @ 32x sens up
Advanced auto tracking
High Sensitivity
w/automatic PTZ
Adaptive Digital
Advanced auto tracking
(WV-CW974)
Noise Reduction
Privacy zone masking
w/pan/tilt
Auto tracking
3D Color Conversion/
w/pan/tilt (WV-CW964) Privacy zone masking
intelligent VMD (object
Privacy zone masking
abandonment/removal)
540 lines
540 lines
510 lines
650 lines
540 lines
540 lines
3.8mm-114mm
3.8mm-114mm
3.79mm-83.4mm
2.1x vari-focal
3.8mm-8.0mm
CS lens mount
3.6x vari-focal
2.8-10mm
3.6x vari-focal
2.8-10mm
30x optical/
10x digital
30x optical/
10x digital
22x optical/
10x digital
2.1x optical/
2x digital
3.6x optical
3.6x optical
Motion Detection
Yes
Yes
Yes
i-VMD (Intelligent VMD)
No
No
On Screen Display
Yes
Yes
Yes
Yes
No
No
Image Stabilization
Yes
Yes
No
Yes
No
No
IP66
Yes
No
No
Yes
Yes
Yes
24VAC
24VAC
24VAC
24VAC/12VDC
24VAC/12VDC
24VAC/12VDC
Camera AC 17 W
w/heater AC 62 W
AC 13 W
AC 13 W
AC 14 W w/heater
DC 280mA
AC 13.1 W w/heater
AC 13.1 W w/heater
14°F – 122°F
14°F – 122°F
-22°F – 122°F
When optional
heater used
14°F – 122°F
-22°F – 122°F
When optional
heater used
14°F – 122°F
-22°F – 122°F
When optional
heater used
Horiz. Resolution
Focal Length
Zoom
Power
Power Consumption
Operating Temp.
-40°F – 122°F
14°F – 122°F
62
Visit www.panasonic.com/security for the latest product information
Analog Cameras
Fixed Dome and Fixed Box Camera Lineup
WV-CF504
WV-CF324
WV-CF294/284
WV-CW384
Indoor Fixed Dome
Ruggedized Indoor
Minidome
Indoor
Minidome
Outdoor Fixed Box
Fixed Box
Fixed Box
Fixed Box
SD5
Adaptive
Black Stretch
Adaptive
Black Stretch
SDIII
No
SD5
Adaptive
Black Stretch
1/3"
1/4"
1/4"
1/3"
1/2"
1/3"
1/3"
Yes
Yes (Simple)
Yes (Simple)
Yes
Yes
Yes
Yes
Yes
Lens ABF
WV-CF294: Lens ABF
WV-CF284: N/A
Yes
Yes
Yes
No
0.1lux
0.9lux
0.9lux
0.9lux
0.01lux
Adaptive
Black Stretch
WV-CL930 series WV-CP500 series WV-CP290 series
0.3lux
(w/o sens up)
0.065lux(w/10x sens up) 0.003lux (w/32x sens up) 0.01lux (w32x sens up)
0.4lux
0.09lux
0.008lux
(w/o sens up)
0.009ux (w/10x sens up) 0.0003lux (w/32x sens up) 0.015lux (w32x sens up)
0.65lux
0.09lux
0.8lux
0.05lux
High sensitivity/Adaptive
Digital Noise Reduction/
3D Color Conversion
Intelligent VMD (object
abandonment/removal)
Adaptive
Black Stretch
Adaptive
Black Stretch
All-in-one unit
IP66 Rated
1/2" CCD
High IR Sensitivity
(B/W mode)
540 lines
540 lines
540 lines
540 lines
650 lines
540 lines
2.1x vari-focal
3.8mm-8.0mm
CS lens mount
WV-CF294:
3.6x vari-focal
2.8mm-10.0mm
3.6x vari-focal, 2.8-10.0mm
8x vari-focal
5mm-40mm (Built-in)
CS lens mount
Lens optional
CS lens mount
Lens optional
CS lens mount
Lens optional
CS lens mount
2.1x optical/
2x digital
3.6x optical
WV-CF294: 3.6x optical
WV-CF284: 2.1x optical
2x digital
Yes
2x digital
N/A
i-VMD (Intelligent VMD)
No
No
Yes
Yes
i-VMD (Intelligent VMD)
No
Yes
No
No
Yes
Yes
Yes
No
Yes
No
No
Yes
Yes
Yes
No
No
No
No
Yes
No
No
No
Super Dynamic 5
intelligent VMD
Auto Back Focus
650 lines
Metal body
Polycarbonate
dome cover
WV-CF284:
2.1x vari-focal, 2.8-6.0mm
WV-CL930:120VAC
Camera 24VAC/12VDC
WV-CP290: 120VAC
WV-CP500:120VAC
WV-CL934: 24VAC/12VDC WV-CP504: 24VAC/12VDC WV-CP294: 24VAC/12VDC
Heater 24VAC
24VAC/12VDC
24VAC/12VDC
24VAC/12VDC
AC 3.4 W
DC 280mA
AC 2.7 W
DC 220mA
WV-CF294:
AC 3.0 W DC 220mA
WV-CF284:
AC 2.7 W DC 265mA
24VAC 18 W
12VDC 540mA
120VAC 4.6 W
24VAC 4.0 W
12VDC 350mA
120VAC 3.2 W
24VAC 3.6 W
12VDC 310mA
120VAC 2.5 W
24VAC 2.9 W
12VDC 240mA
14°F – 122°F
14°F – 122°F
14°F – 122°F
-22°F – 122°F
(Heater On)
14°F – 122°F
14°F – 122°F
14°F – 122°F
63
Visit www.panasonic.com/security for the latest product information
Recording Solutions
Panasonic continues to build on our reputation for advanced
recording solutions with advanced H.264 real time recorders
that conserve storage space without compromising image
quality. They deliver a combination of features that provide
extreme versatility including DVD back-up recording and
archiving, scalable on-board storage, dual streaming viewing
and playback, and network interfaces. And with our powerful
management control software, you can easily control and
program multiple DVRs and cameras via an easy to use
Graphic User Interface (GUI). We’ve got it all covered.
Panasonic System Networks Company of America
64
Surveillance, Monitoring & Video Imaging
V I D E O
R E C O R D E R S
WJ-HD716 Series
16 Channel Real-Time H.264 Digital Video Recorder
H.264 compression technology for more efficient use of disk space
Panasonic proprietary UniPhier® System LSI Platform provides
real-time field recording of 480 images per second (ips) and frame
recording of 240 ips
Intelligent Video Motion Detection (i-VMD) with Super Dynamic 5 Link
(SD5Link) to share metadata information between cameras
and the recorder
Dual HDMI video outputs for true 1080i (1,920 x 1,080) HD playback
16 analog video inputs including 16 Panasonic coaxial camera
control inputs and 4 audio inputs
Up to 960 ips at 16 channels, 2x monitor real-time live
Live/playback monitor out and live monitor out (HDMI, BNC)
SD/SDHC memory card slot for easy copy of recorded image data
RTSP over HTTP supported for monitoring via the Internet
Various display modes: 4/7/8/9/12/16 split screen display
Up to 5 recorders can be cascaded for increased camera support
• Equipped with four front accessible hard disk drive slots
Expandable hard drive storage capacity via optional expansion units
Up to four optional WV-CU650 system controllers can be connected via PS-Data
• Easy operation with GUI and USB mouse
Remote monitoring
H.264 image transfer at QVGA resolution for optimal bandwidth utilization
Set-up data transferable via SD/SDHC memory card
User/host authentication (up to 32 user registrations)
Up to 8 users can operate simultaneously via network
Easy maintenance capability through front access
Recording Solutions
D I G I TA L
Specs
Max. Hard Drives
Input/Output (Video)
1TB base unit (up to 8 HDDs internally, 62 HDDs externally)
16x 1.0 V [p-p] 75 ohm composite video inputs (BNC) / 16x multiplexed
control data (1-16 ch.) / Cascade IN: 2x HDMI, 1x BNC
Input/Output (Audio) 4x – 10dBv, 10 K ohm (RCA) (1-4ch.) / Rear: 1x-10 dBv, 600 ohm,
Front: 1x-10 dBv, 600 ohm
Input/Output (Alarm) 16x terminal inputs, 16x camera alarm, PS-Data
Ambient Temperature 41º ~ 113º F
Interface (Ethernet)
10Base-T/100Base-TX (RJ-45) x 1
Interface (DATA)
2x RS-485 (RJ-11), 2/4 wire, half duplex, for 1-16 ch.
Power/Consumption 120V AC, 60 Hz/130W
Dimensions
16 15/16" x 5 3/16" x 15 3/4" (430mm x 132mm x 400mm)
Weight
37.4 lbs (17kg) with 4 HDDs
Popular Accessories
Model No.
Description
Page Ref.
Canister/1000
1TB HDD
in canister
(9 HDD bays)
—
Photo Not
Available
Photo Not
Available
WJ-HDE400
Hard disk
expansion unit
WJ-HDB601
RAID 5/6
board
WJ-HDB611
DVD Drive
WV-ASM100
Management
Software
37
—
—
41
WV-ASM100L
Management
Software
Light
42
Controller Compatibility
WJ-HD716
WV-CU161C
No
WV-CU650
Yes *1 *2
WV-CU950
No
*1 In PS-Data mode
*2 May require firmware update
65
Visit www.panasonic.com/security for the latest product information
Recording Solutions
D I G I TA L
V I D E O
R E C O R D E R S
WJ-HD616 Series
16 Channel H.264 Digital Video Recorder
H.264 compression technology for more efficient use of disk space
Panasonic proprietary UniPhier® System LSI Platform provides real-time field recording of
240 images per second (ips) and frame recording of 120 ips
Intelligent Video Motion Detection (i-VMD) with Super Dynamic 5 Link (SD5Link) to share
metadata information between cameras and the recorder
Dual HDMI video outputs for true 1080i (1,920 x 1,080) HD playback
16 analog video inputs including 8 Panasonic coaxial camera control inputs and 4 audio
inputs
Live/playback monitor out and live monitor out (HDMI, BNC)
SD/SDHC memory card slot for easy copy of recorded image data
RTSP over HTTP supported for monitoring via the Internet
Various display modes: 4/7/8/9/12/16 split screen display
• Up to 5 recorders can be cascaded for increased camera support
Equipped with four front accessible hard disk drive slots
Expandable hard drive storage capacity via optional expansion units
Up to four optional WV-CU650 system controllers can be connected via PS-Data
Easy operation with GUI and USB mouse
Remote monitoring
H.264 image transfer at QVGA resolution for optimal bandwidth utilization
Set-up data transferable via SD/SDHC memory card
User/host authentication (up to 32 user registrations)
Up to 8 users can operate simultaneously via network
Easy maintenance capability through front access
Specs
Max. Hard Drives
Input/Output (Video)
1TB base unit (up to 8 HDDs internally, 62 HDDs externally)
16x 1.0 V [p-p] 75 ohm composite video inputs (BNC) / 8x multiplexed
control data (1-8 ch.) / Cascade IN: 2x HDMI, 1x BNC
Input/Output (Audio) 4x – 10dBv, 10 K ohm (RCA) (1-4ch.) / Rear: 1x-10 dBv, 600 ohm,
Front: 1x-10 dBv, 600 ohm
Input/Output (Alarm) 16x terminal inputs, 16x camera alarm, PS-Data
Ambient Temperature 41º ~ 113º F
Interface (Ethernet)
10Base-T/100Base-TX (RJ-45) x 1
Interface (DATA)
2x RS-485 (RJ-11), 2/4 wire, half duplex, for 1-16 ch.
Power/Consumption 120V AC, 60 Hz/130W
Dimensions
16 15/16" x 5 3/16" x 15 3/4" (430mm x 132mm x 400mm)
Weight
37.4 lbs (17kg) with 4 HDDs
Popular Accessories
Model No.
Description
Page Ref.
Canister/1000
1TB HDD
in canister
(9 HDD bays)
—
Photo Not
Available
Photo Not
Available
WJ-HDE400
Hard disk
expansion unit
WJ-HDB601
RAID 5/6
board
WJ-HDB611
DVD Drive
WV-ASM100
Management
Software
37
—
—
41
WV-ASM100L
Management
Software
Light
42
Controller Compatibility
WJ-HD616
WV-CU161C
No
*1 In PS-Data mode
*2 May require firmware update
66
Visit www.panasonic.com/security for the latest product information
WV-CU650
Yes *1 *2
WV-CU950
No
Recording Solutions
A C C E S S O R Y
SCT08P
Converter
Enables control of Pelco PTZ cameras through Panasonic WJ-HD300A DVR
series utilizing Panasonic system controller WV-CU650
Ability to upgrade existing VCR / MUX systems to Panasonic WJ-HD300A
DVR series, while utilizing previously installed Pelco PTZ cameras
Control up to 8 Pelco protocol cameras with 1 converter
Ability to select first 8 channels (1-8) or 2nd set of 8 channels (9-16)
Supports P-Protocol and D-Protocol
Supports basic control functions (Pan/Tilt/Zoom/Preset)
AC adapter, RJ-11 cable for Panasonic camera RS-485 port included
R E C O R D I N G
M A N A G E M E N T
S O F T W A R E
WV-ASM100
Management Software Solution for Panasonic
NVR’s, DVR’s and i-PRO Cameras
Complete software management and live monitoring software
for Panasonic WJ-ND400/ND300A/NV200/ND200 NVR series,
WJ-HD716/HD616/HD300A DVR series and i-PRO network
cameras and encoders
Up to 100 recorders, 64 encoders and 256 directly connected
cameras can be registered. Up to 6,400 cameras and 256 cameras
on the encoders are automatically registered on the software
For flexible design, live images can be received directly from the
camera/encoder or via the recorder
Multi-monitor option enables simultaneous use of Operation
Display (1/4/9/16 split), Live Display (1/4/9/16 split) and Map
Display each on a dedicated monitor
Up to 400 camera groups: cameras and multi-screen mode for the
Operation Display can be programmed and called up by manual or
sequence operation
Image resolution dynamically changes depending on the screen
mode: VGA for Quad screen, QVGA for 16 split screen
Panasonic camera control
A camera, a group or a sequence can be called up on the
Operation Display by ID with the optional system controller
WV-CU950
Alarm pop-up notification/messaging
Up to 64 camera icons can be freely positioned on a map with
alarm status indicated by the color of the icons
Download video clips for archiving
Minimum PC Requirements:
- CPU
Intel Core 2 Duo 2.66 GHz or faster
Intel Core i7-920 or faster (during H.264 operation)
- RAM
1GB or more
3GB or more (during H.264 operation)
- Video card
VRAM: 128MB or more, compatible with Microsoft
DirectX 9.0c or later
- OS
Microsoft Windows 7 Professional 32bit/64bit
Microsoft Windows Vista Business SP2 32bit/64bit
Microsoft Windows XP Home SP3, Microsoft Windows XP
Professional SP3
Optional Equipment Shown
Accessory
Model No.
Description
Page Ref.
WV-CU950
System
Controller
79
See Management Software Comparison Chart on page 71
67
Visit www.panasonic.com/security for the latest product information
Recording Solutions
R E C O R D I N G
M A N A G E M E N T
S O F T W A R E
WV-ASM100L
Management Software Solution for Panasonic
NVR’s, DVR’s and i-PRO Cameras –
Light Version
Complete software management and live monitoring software
for Panasonic WJ-ND400/ND300A/NV200/ND200 NVR series,
WJ-HD716/HD616/HD300A DVR series and i-PRO network
cameras and encoders
Up to 100 recorders, 64 encoders and 256 directly connected
cameras can be registered. Up to 6,400 cameras and 256 cameras
on the encoders are automatically registered on the software
For flexible design, live images can be received directly from the
camera/encoder or via the recorder
Up to 400 camera groups: cameras and multi-screen mode for
the Operation Display can be programmed and called up by
manual or sequence operation
Image resolution dynamically changes depending on the
screen mode: VGA for Quad screen, QVGA for 16 split screen
Panasonic camera control
Alarm pop-up notification/messaging
Up to 64 camera icons can be freely positioned on a map
with alarm status indicated by the color of the icons
Download video clips for archiving
Minimum PC Requirements:
- CPU
Intel Core 2 Duo 2.66 GHz or faster
Intel Core i7-920 or faster (during H.264 operation)
- RAM
1GB or more
3GB or more (during H.264 operation)
- Video card
VRAM: 128MB or more, compatible with Microsoft
DirectX 9.0c or later
- OS
Microsoft Windows 7 Professional 32bit/64bit
Microsoft Windows Vista Business SP2 32bit/64bit
Microsoft Windows XP Home SP3, Microsoft Windows XP
Professional SP3
See Management Software Comparison Chart on page 71
68
Visit www.panasonic.com/security for the latest product information
M A N A G E M E N T
S O F T W A R E
WV-ASM970
Management Software for PMPU1000
Dedicated GUI (Graphic User Interface) for PMPU1000
Two monitor operation is available (1st: map & operation,
2nd: live and playback video)
Multi-split screen (1/4/7/9/10/13/16 split) support
Up to 30 ips/camera can be displayed in 16 split-screen in
H.264 1.5 Mbps mode with VGA
Camera Control (PTZ, Preset, Iris, Auto function and so on) supported
Recorder Control (REC, Play, R-Play, FF, REW, Pause, Stop, Go to date,
Go to last and so on) supported
Up to 100 map (JPEG or Bitmap) with up to 64 camera icons in a map
File converter is included; converts Panasonic file format to MP4
One license per PMPU1000 server
License includes up to 64 WV-ASM970 installations
Minimum PC Requirements:
- CPU
Intel CoreTM2 Quad Q9650 or faster
Intel CoreTM i7-920 or faster (Panasonic recommends)
- RAM
3GB or more
- Video Card
VRAM: 256MB or more, compatible with DirectX 9.0c
- OS
Microsoft Windows 7 Professional (32bit/64bit) (English or Chinese Version)
Microsoft Windows Vista Business SP2 (32bit/64bit) (English or Chinese Version)
Microsoft Windows XP Professional SP3 (32bit) (English or Chinese Version)
Operation Window
Camera Control Panel
Recording Solutions
R E C O R D I N G
Video Window
Playback Control Panel
File Converter
See Management Software Comparison Chart on page 71
69
Visit www.panasonic.com/security for the latest product information
Recording Solutions
Recorders & Encoders/Decoders Lineup Chart
Network
Video Recorders
Model
WJ-ND400
WJ-ND300
WJ-NV200
H.264 / MPEG-4 / M-JPEG
H.264 / MPEG-4 / M-JPEG
H.264 / MPEG-4 / M-JPEG
9 drives (internal) 54 drives (w/ external)
4 drives (internal) 28 drives (w/ external)
2 drives (internal)
18TB (internal, 2TB HDD)
108TB (w/ external, 2TB HDD)
8TB (internal, 2TB HDD)
56TB (w/ external, 2TB HDD)
6TB (internal, 3TB HDD)
64 at H.264 2Mbps
32 at H.264 2Mbps
16 at H.264 4Mbps
Supported Video Resolution
3MP (2048 x 1536), 1.3MP (1280 x 960),
VGA (640 x 480), QVGA (320 x 240)
1.3MP (1280x960), VGA (640x480),
QVGA (320x240)
1.3MP (1280x960), VGA (640x480),
QVGA (320x240)
Max. Recording Rate (Total)
Approx. 1,920fps (30 fps at 64 cameras)
Approx. 960fps (30 fps at 32 cameras)
Approx. 480fps (30 fps at 16 cameras)
RAID5/6
RAID5 Optional (WJ-NDB301)
No
Supported Video Compression
Max. HDD
Max. Storage
Max. IP Camera
RAID Support
64Mbps (Camera recording) 32Mbps (PC monitoring)
128Mbps (Camera recording) 72Mbps (PC monitoring) 64Mbps (Camera recording) 32Mbps (PC monitoring)
13Mbps (HDMI out monitoring)
Max. Network Bandwidth
Network I/F
Supported Camera Brands
Alarm/Control Ports
RTP over HTTP (For internet monitoring)
Functions
Power Consumption
Rack Mountable
Remote Monitoring
2x 1Gbps, 1x 10Mbps
2x 100Mbps, 1x 10Mbps
1x 1Gbps
Panasonic, Axis (JPEG, MPEG4)
Panasonic, Axis (JPEG)
Panasonic, Axis (JPEG)
32 terminal alarm inputs/outputs, Control/AUX
16 terminal alarm inputs/outputs, Control/AUX
9 terminal alarm inputs/outputs
Will support in June 2010 (tentative)
No
Yes
HD1080i HDMI Output (Built-in Decoder)
Real-time face matching, mouse operation
Metadata smart search
-
120 VAC, 60Hz/Approx. 170W
120 VAC, 60Hz/Approx. 85W
Yes
Yes
Optional
Yes (Microsoft Internet Explorer),
WV-ASM100/100L, WV-ASM970)
Yes (Microsoft Internet Explorer),
WV-ASM100/100L, WV-ASM970)
Yes (Microsoft Internet Explorer),
WV-ASM100/100L, WV-ASM970)
120 VAC, 60Hz/Approx. 45W
Digital
Video Recorders
Model
WJ-HD716
Video Inputs
Video Loop Through
16
Yes (16)
Yes (16)
Audio Inputs
4
4
Monitor Out
2x HDMI, 2x Composite (BNC) (All: Multiscreen)
2x HDMI, 2x Composite (BNC) (All: Multiscreen)
Audio Outputs
Recording Video Compression
Max. HDD
Max. Storage
Recording Resolution
Max. Recording Rate (Total)
RAID Support
Network I/F
HDMI Cascade
Coax PTZ Control
RS485 Camera Interface
Alarm/Control Ports
Copy Ports
RTP over HTTP (for Internet monitoring)
2
2
H.264
H.264
4 drives (internal) 31 drives (w/ external)
4 drives (internal) 31 drives (w/ external)
8TB (internal, 2TB HDD) 62TB (w/ external, 2TB HDD)
8TB (internal, 2TB HDD) 62TB (w/ external, 2TB HDD)
Frame (720x480) Field (720x240)
Frame (720x480) Field (720x240)
480ips at Field (720x240) 240ips at Frame (720x480)
240ips at Field (720x240) 120ips at Frame (720x480)
RAID5/6 Optional (WJ-HDB601)
RAID5/6 Optional (WJ-HDB601)
2x 100Mbps
2x 100Mbps
Up to 3 extention units
Up to 3 extention units
16 (for Panasonic camera)
8 (for Panasonic camera)
2x RS485, 2/4 wire, half duplex (for 1-16 CH)
2x RS485, 2/4 wire, half duplex (for 1-16 CH)
16 terminal alarm inputs/outputs, 1 alarm reset input, 1 alarm suspend input
16 terminal alarm inputs/outputs, 1 alarm reset input, 1 alarm suspend input
Built-in SD/SDHC slot CD/DVD burner (Optional: WJ-HDB611)
Built-in SD/SDHC slot CD/DVD burner (Optional: WJ-HDB611)
Yes
Yes
Dual HD1080i HDMI Outputs, mouse operation, timeline bar search, SD5 Link
Dual HD1080i HDMI Outputs, mouse operation, timeline bar search, SD5 Link
Power
120 VAC, 60Hz
120 VAC, 60Hz
Power Consumption
Approx. 130W
Approx. 130W
Functions
Rack Mountable
Remote Monitoring
Encoders/
Decoders
70
WJ-HD616
16
Model
Product Type
Supported Video Compression
Video Inputs
Audio Inputs
Supported Video Resolution
Max. fps
Functions
Power Consumption
Rack Mountable
Yes
Yes
Yes (Microsoft Internet Explorer), WV-ASM100/100L, WV-ASM970)
Yes (Microsoft Internet Explorer), WV-ASM100/100L, WV-ASM970)
Video Decoder
Video Encoder
WJ-GXE500
4CH Video Encoder
H.264 / MPEG-4 / M-JPEG
4
1
D1 (720x480), VGA (640x480), QVGA (320x240)
30fps/ch at H.264 in all resolutions
Face Detection (CH1 only), Dual Stream, RTP over HTTP
PoE, 12VAC/6W
Optional (WV-Q204/1S, WV-Q204/2S)
Model
WJ-GXD400
Product Type
6CH HD1080i Video Decoder
Supported Video Compression
H.264 / MPEG-4 / M-JPEG
Video Outputs
HDMI x1NTSC Composite (BNC) x1
Audio Outputs
RCA x1
Display Pattern
Single (1x 1280x960) 3 split-screen (1x 1280x960, 2x VGA) 6 split-screen (6x VGA)
Max .fps
30fps/ch at H.264 in VGA
Functions
HD1080i HDMI Output
Power/Power Consumption
12VDC/12VDC, 1.4A
Rack Mountable
Optional (WV-Q204/1S, WV-Q204/2S)
Visit www.panasonic.com/security for the latest product information
Functions
WV-ASM100 (Ver. 8.0)
Management Software
Main Functions/Description
Supported Video Formats
Supported Camera Direct
Devices
Via Recorder
Recorder NVR
WV-ASM100L (Ver. 8.0)
Management Software - Light
Live / Playback / Control
Live / Playback / Control
H.264 / MPEG-4 / M-JPEG
H.264 / MPEG-4 / M-JPEG
i-Pro series 1
i-Pro series 1
i-Pro series 1, Axis 2, BB series 2
i-Pro series 1, Axis 2, BB series 2
WJ-ND400, WJ-ND300/300A,
WJ-ND400, WJ-ND300/300A,
WJ-ND200, WJ-NV200 series
WJ-ND200, WJ-NV200 series
WJ-HD716/616, WJ-HD309A/316A, WJ-HD716/616, WJ-HD309A/316A,
DVR
WJ-RT416 series
WJ-RT416 series
Encoder
WJ-GXE500, WJ-NT304/NT314
WJ-GXE500, WJ-NT304
Controller
WV-CU950
No
Max.
Camera Direct
256
256
Devices
Via Recorder
6,400 (with WJ-ND400 series)
6,400 (with WJ-ND400 series)
3,200 (with WJ-ND300 series)
3,200 (with WJ-ND300 series)
Via Encoder
256
256
Recorder
100
100
Encoder
64
64
Controller
1
No
Camera Control
Yes (PTZ, Preset, Auto mode etc.) Yes (PTZ, Preset, Auto mode etc.)
Recorder Control
Yes (Playback, REC etc.)
Yes (Playback, REC etc.)
Multi-screen Pattern
1 / 4 / 9 / 16
1 / 4 / 9 / 16
Display Performance
30 ips x 16 screens
30 ips x 16 screens
@ MPEG4 2 Mbps/H.264 1.5 Mbps @ MPEG4 2 Mbps/H.264 1.5 Mbps
Yes
No
AVMD Display
(Frame and Tracking Line)
Multiple Monitors Supported
Yes (Up to 3 monitors:
No
Operation / Live / Map)
Map Function
Yes
No
Audio3
Yes (Live: 2-way, Playback: 1-way) Yes (Live: 2-way, Playback: 1-way)
Supported Alarm
Panasonic Alarm Protocol
Panasonic Alarm Protocol
Event Search (T&D, Event type etc.)
Yes
Yes
VMD Search
Yes (with WJ-ND400 series)
No
Image Download
Yes
Yes
1
2
Recording Solutions
Management Software Comparison Chart
Except model WV-NM100
Specific models only. Camera control is not supported. Only JPEG supported.
71
Visit www.panasonic.com/security for the latest product information
Encoders and Decoders
Panasonic makes it easy to integrate your analog cameras on
a network platform with the performance features you want.
Our encoders and decoders feature advanced built-in video
analytics, High Definition quality, multi-format output for viewing
and recording, and multiplex combinations to accommodate
multiple cameras. We’ve got it all covered.
Panasonic System Networks Company of America
72
Surveillance, Monitoring & Video Imaging
/
Encoders / Decoders
E N C O D E R S
D E C O D E R S
WJ-GXE500
4-Channel H.264 Video Encoder
Full frame H.264 transmission for all 4 channels
Dual streams of H.264 (High profile) and JPEG at
VGA / D1 image size
Motion adaptive interlace/progressive conversion
produces clear frames even when the subject is moving
Compensates picture degration caused by
long-distance cable - clear picture is maintained
Coaxial communication ensures the control of
Panasonic PTZ cameras via coaxial cable
Open command conversion table for RS-485 ensures the control
of various manufacturer’s PTZ cameras
SD/SDHC Memory card slot for manual recording, alarm recording,
and backup upon network failure (JPEG)
Camera title display: up to 16 alphanumeric characters embedded
in the image
Full duplex bi-directional audio allows interactive communication
PoE (power is supplied by simply connecting a LAN cable –
IEEE802.3af compliant)
Rack mountable with mounting brackets
Alarm sources including 3 terminal input, VMD, camera site alarm,
video loss, and Panasonic alarm
VMD (Video Motion Detector) with 4 programmable detection areas
Face detection technology detects the position of human face and
the information is sent by XML or video stream (Ch1 only)
Meta data for VMD is supplied to work with the WJ-ND400 NVR
playback VMD function
Specs
Popular Accessory
Image compression
Protocol
Video input
Resolution
Op. Temp.
Power/Consump.
Dimensions
Weight:
H.264/MPEG-4/JPEG
IPv6: TCP/IP, UDP/IP, HTTP, RTP, FTP, SMTP, DNS, NTP, SNMP
4x
720 x 480 (D1), 640 x 480 (VGA), 320 x 240 (QVGA)
14º ~ 122º F
12V DC, 500 mA / PoE, 6W
5 1/2" x 1 ¾" x 7 9/32"
2.21 lbs (1kg)
Model No.
Description
Page Ref.
WV-Q204/2S
Rack mounting bracket
(2 units)
—
WJ-GXD400
Multi-Channel High Definition Video Decoder
for i-Pro Network Surveillance System
Multi-channel high-definition video decoder with HDMI video interface
1x 4 VGA (1280 x 960) images with 2x VGA images in 3 split
screens or 6x VGA (640 x 480) images in 6 split screens
VGA image displayed at 30ips/sec
Registers up to 256 cameras including cameras connected to
i-Pro Network Video Encoders
Supports tour sequence and group sequence
Supports camera site alarm signal: alarm indication displayed and
alarm terminal output activated
Supports multicast / unicast for efficient network usage
Single channel audio decoding G.726
High-speed network interface (100Base-T/1000Base-T),
maintenance port (10Base-T)
Browser GUI
Embedded Real-Time Operating System delivers high reliability
Operating temperature 14° ~ 122°F
Specs
Popular Accessories
Image Format
Resolution
Audio Format
Video Output
Network Interface
Multicast
Power/Consumption
Dimensions
Weight
H.264, MPEG-4, JPEG (multi-decoding)
1,280 x 960, 640 x 480, 320 x 240
G.726 (ADPCM), 32 kbps / 16 kbps
1,920 x 1,080: 1 x 4VGA (1,280 x 960) with 2x VGA or
6x VGA 30 frames/sec., audio supported
10Base-T/100-BaseTX/1000Base-T, RJ-45 connector
Yes
12V DC, 1.4 A
8 1/4” x 1 3/4” x 12 1/16” (210mm x 44mm x 300mm)
4.4 lbs (2.0kg)
Model No.
Description
Page Ref.
Visit www.panasonic.com/security for the latest product information
WV-Q204/1S
Rack mounting bracket
(1 unit only)
—
WV-Q204/2S
Rack mounting bracket
(2 units)
—
73
Matrix and Control Systems
Panasonic puts you in complete control of video surveillance
operations with management control software-driven server
solutions. Configurable for system configurations with over
1,000+ IP and/or analog cameras, multiple controllers and
displays, Panasonic server based solutions provide intelligent
and versatile functionality. Features include intuitive GUIs with
site map overlays, advanced multi-group and tour sequences,
scalable system expansion, and seamless integration with
Panasonic’s complete line of video surveillance solutions.
We’ve got it all covered.
Panasonic System Networks Company of America
74
Surveillance, Monitoring & Video Imaging
Matrix and Control Systems
M A N A G E M E N T
S E R V E R
PMPU1000
System Management Server
Linux based system management server
No device license fees
Satellite feature allows linking 64 PMPU1000 standalone systems to a
global system with universal cross network access
Supports up to 2,048 alarm inputs and various alarm source types
and management
Supports up to 2,048 event schedules
Flexible system design for use with both analog and IP systems
16 Simultaneous operators per local system
Operator management, priority, access and timer executed restrictions
Redundant server option
User-friendly administrator console
3x Built-in network interfaces (10Base-T/100Base-TX)
Supported Devices
Maximum Size per PMPU1000 Server
IP
Cameras
Hybrid
1,023
Logical Monitors
1,024
DVR/NVR
64
Controllers
64
Alarms
Total
1,023
Analog
2,048
Sequences
128
Steps per Sequence
64
Switchers
512
DVRs
64
Analog
Cameras
32
Consult
Panasonic
for system
design
Analog Matrix
IP
IP Cameras
NVRs
64
WJ-SX650, WJ-SX850 series
WJ-HD300/300A, WJ-RT416, WJ-HD616, WJ-HD716 series
Supported via Matrix Switcher or DVR
All i-PRO cameras except for WV-NM100
WJ-ND400, WJ-ND300/300A, WJ-ND200 series
1,024
Encoders
WJ-GXE500, WJ-NT304, WJ-NT314
128
Decoder
WJ-GXD400
64
Controller
WV-CU950
Management
Software
Registered Users
512
512
Satellites
64
64
WV-ASM970
We recommend you contact a Panasonic representative to assist
you with your system design.
Optional System Components
Model No.
Description
Page Ref.
WV-ASM970
Management
software
unit for archiving
77
IP
Hybrid
Analog
75
Visit www.panasonic.com/security for the latest product information
Matrix and Control Systems
M AT R I X
S W I T C H E R
WJ-SX650
Mid-Range Matrix Switcher
Easy configuration
256 inputs x 32 outputs, expandable up to 512 x 64
Simple set-up with administrator console
Removable boards: front access
Seamless control integration with WJ-HD300A
and WJ-RT416 DVR series
Supports up to 1,024 alarm inputs
Compact design
Controller Compatibility
WJ-SX650
WV-CU161C
No
WV-CU650
Yes *1 *2
WV-CU950
No
*1 In PS-Data mode
*2 In Terminal mode
Optional Equipment Shown
Accessories
Photo Not
Available
Model No.
Description
WJ-SX650U
Card Cage
for WJ-SX650
Matrix Switcher
Page Ref.
—
WJ-PB65C32
Video Input
Board for
WJ-SX650
Matrix Switcher
—
WJ-PB65E01
Ethernet Board
for WJ-SX650
Matrix Switcher
—
WJ-PB65M16
Video Output
Board for
WJ-SX650
Matrix Switcher
—
WJ-CA65L20K
Expansion Cable
Kit (2m – 6.6 ft.)
for WJ-SX650
Matrix Switcher
—
WJ-CA65L07K
Expansion Cable
Kit (0.7m – 2.3 ft.)
for WJ-SX650
Matrix Switcher
—
Satellite System Concept
Domain #1
Domain #2
WJ-SX650 #1
WJ-SX650 #2
WJ-SX650 #1
WJ-SX650 #2
1-256
(256x32)
257-512
(256x32)
1-256
(256x32)
257-512
(256x32)
WJ-SX650 #3
(64 in x 32 out)
WJ-SX650 #4
WJ-SX650 #5
1-256
(256x32)
257-512
(256x32)
Video
Link
WJ-SX650 #4
WJ-SX650 #5
(256x32)
(256x32)
WJ-SX650 #6
(64 in x 32 out)
WJ-SX650 #6
(64 x 32)
PMPU1000
PMPU1000
0
C96
-AS
WJ
0
C96
-AS
WJ
Need
WJ-ASC960
76
WJ-SX650 #3
(64 x 32)
Need
WJ-ASC960
IP Network
Visit www.panasonic.com/security for the latest product information
WJ-CA68
D-sub/BNC
Video Cable
for WJ-SX650
Matrix Switcher
—
WV-CU650
System
Controller
77
S O F T W A R E
WV-ASM970
Management Software for PMPU1000
Dedicated GUI (Graphic User Interface) for PMPU1000
Two monitor operation is available (1st: map & operation,
2nd: live and playback video)
Multi-split screen (1/4/7/9/10/13/16 split) support
Up to 30 ips/camera can be displayed in 16 split-screen in
H.264 1.5 Mbps mode with VGA
Camera Control (PTZ, Preset, Iris, Auto function and so on) supported
Recorder Control (REC, Play, R-Play, FF, REW, Pause, Stop, Go to date,
Go to last and so on) supported
Up to 100 map (JPEG or Bitmap) with up to 64 camera icons in a map
File converter is included; converts Panasonic file format to MP4
One license per PMPU1000 server
License includes up to 64 WV-ASM970 installations
Minimum PC Requirements:
- CPU
Intel CoreTM2 Quad Q9650 or faster
Intel CoreTM i7-920 or faster (Panasonic recommends)
- RAM
3GB or more
- Video Card
VRAM: 256MB or more, compatible with DirectX 9.0c
- OS
Microsoft Windows 7 Professional (32bit/64bit) (English or Chinese Version)
Microsoft Windows Vista Business SP2 (32bit/64bit) (English or Chinese Version)
Microsoft Windows XP Professional SP3 (32bit) (English or Chinese Version)
Operation Window
Camera Control Panel
Matrix and Control Systems
M A N A G E M E N T
Video Window
Playback Control Panel
File Converter
See Management Software Comparison Chart on page 71
77
Visit www.panasonic.com/security for the latest product information
Matrix and Control Systems
C O N T R O L
S Y S T E M S
WV-CU650
System Controller
Control of Panasonic switchers and
digital recorders
PTZ camera control
Panasonic digital recorders control
buttons and jog/sechuttle
Separate 3D joystick control
Enables complete cascade function
for WJ-HD300A DVR Series
RS485 data port for PS•Data link
or terminal mode
Controller Compatibility
WJ-SX650
WJ-HD309A
WJ-HD316A
WJ-HD616
WJ-HD716
WJ-RT416
WV-CU650
Yes *1 *2
Yes *1
Yes *1
Yes
Yes
Yes *1 *3
*1 In PS-Data mode
*2 In Terminal mode
*3 May require firmware update
78
Visit www.panasonic.com/security for the latest product information
S Y S T E M S
WV-CU950
System Controller
Control of Panasonic switchers
and digital recorders
PTZ camera control
Separate 3D joystick control
Panasonic digital recorders control
buttons and jog/sechuttle
10Base-T/100Base-TX Ethernet port
RS485 data port for PS•Data link
or terminal mode
Matrix and Control Systems
C O N T R O L
Controller Compatibility
WJ-SX650
WV-ASM100
WV-CU950
Yes*
Yes
*PMPU1000, WJ-PB650E01 is needed
79
Visit www.panasonic.com/security for the latest product information
LCD Displays
Panasonic LCD displays deliver the resolution and reliable
operation you demand for head-end operations. They feature
high resolution image reproduction, 16:9 ratio wide screens,
wide angle viewing capability, true color reproduction, multiple
inputs for multiple sources, and selectable scan sizes.
We’ve got it all covered.
Panasonic System Networks Company of America
80
Surveillance, Monitoring & Video Imaging
D I S P L AY S
PLCD42HD
42" High Definition LCD Monitor
Monitors
L C D
High Definition resolution: 1,920 x 1,200
High contrast ratio – 1300:1
Active Matrix TFT with approx. 16.7 million colors
2x BNC composite inputs with loop through outputs
S-Video in/out
DVI and HDMI inputs
Two built-in speakers
Pedestal stand included
Power: 120V AC
Specs
Display Pixel
Aspect Ratio
Contrast Ratio
Viewing Angle
Brightness
Special Features
Power/Consumption
Dimensions
Weight
1,920 x 1,080
16 x 9
1300:1
H: 178º / V: 178º
500 cd/m2 (typical)
High Definition, pedestal stand
120V AC, 250W
41.85" x 28.45" x 12" (1,063mm x 725mm x 305mm)
77.2 lbs (35kg)
PLCD24HD
24" High Definition LCD Monitor
High Definition resolution: 1,920 x 1,200
High contrast ratio - 1000:1
Active Matrix TFT with approx.
16.7 million colors
2x BNC composite inputs with
loop through outputs
S-Video in/out
RGB for PC input
DVI and HDMI inputs
Two built-in speakers with gradual
volume increase
Picture-in-picture
Space saving design
Equipped with standard VESA
mounting holes
Power: 120V AC
Specs
Display Pixel
Aspect Ratio
Contrast Ratio
Viewing Angle
Brightness
Special Features
Power/Consumption
Dimensions
Weight
1,920 x 1,200
16 : 9
1000 : 1 (typical)
H: 160°, V: 160°
400 cd/m2 (typical)
High Definition, energy efficient, space saving design
120V AC, 110W
22 4/9" x 15 1/3" x 3 7/10" (570.4mm x 389mm x 94mm)
26.46 lbs (12kg)
81
Visit www.panasonic.com/security for the latest product information
Monitors
L C D
D I S P L AY S
PLCD20P
20" LCD Monitor
Resolution screen: 1,600 x 1,200
High contrast ratio - 800:1
Active Matrix TFT with approx.
16.7 million colors
2x BNC composite inputs with
loop through outputs
S-Video in/out
RGB for PC input
DVI and HDMI inputs
Two built-in speakers with
gradual volume increase
Picture-in-picture
Space saving design
Equipped with standard VESA
mounting holes
Power: 120V AC
Specs
Display Pixel
Aspect Ratio
Contrast Ratio
Viewing Angle
Brightness
Special Features
Power/Consumption
Dimensions
Weight
1,600 x 1,200
4:3
800 : 1 (typical)
H: 178°, V: 178°
300 cd/m2 (typical)
Energy efficient, space saving design
120V AC, 70W
18 1/9" x 15 5/9" x 3 15/79" 460.4mm x 395.1mm x 81mm)
23.1 lbs (10.5kg) includes stand
Popular Accessory
Photo Not
Available
Model No.
Description
Page Ref.
82
Visit www.panasonic.com/security for the latest product information
PRMK08
Optional rack
mount kit
—
D I S P L AY S
PLCD15V
15" LCD Monitor
Resolution screen: 1,024 x 768
High contrast ratio - 600:1
Active Matrix TFT with approx.
16.7 million colors
2x BNC composite inputs with
loop through outputs
S-Video in/out
Monitors
L C D
RGB for PC input
Two built-in speakers with
gradual volume increase
Space saving design
Equipped with standard
VESA mounting holes
Power: 120V AC
Specs
Display Pixel
Aspect Ratio
Contrast Ratio
Viewing Angle
Brightness
Special Features
Power/Consumption
Dimensions
Weight
1,024 x 768
4:3
600 : 1 (typical)
H: 160°, V: 160°
300 cd/m2 (typical)
Energy efficient, space saving design
120V AC, 36W
13 5/6" x 13 2/3" x 7 5/6" 351mm x 348mm x 200mm)
12.6 lbs (5.7kg) includes stand
Popular Accessory
Photo Not
Available
Model No.
Description
Page Ref.
PRMK08
Optional rack
mount kit
—
83
Visit www.panasonic.com/security for the latest product information
Accessories
Panasonic offers a comprehensive line of camera lenses, housings
and brackets to outfit any of our IP and analog cameras to fit exactly
where you need them. Our wide selection of high quality lenses
feature precision optics in various fixed and zoom focal ranges
to focus in on what you need to see. And our indoor and outdoor
line of camera housings allows you to position cameras in
the most hostile environments, or seamlessly blend them into
the backgrounds of the most aesthetically pleasing spaces.
We’ve got it all covered.
Panasonic System Networks Company of America
Surveillance, Monitoring & Video Imaging
84
Visit www.panasonic.com/security for the latest product information
L E N S E S
WV-LZA62/2
WV-LZA61/2S
Megapixel Lens
1/3" Vari-focal Lens
2x variable
ƒ1.4 (wide), ƒ2.1 (tele)
2.8-6 mm focal length
Auto iris
WV-LZ62/8S
1/3" Vari-focal Lens
8x variable lens
ƒ1.6 (wide), ƒ1.9 (tele)
aperture ratio
5-40 mm focal length
Auto iris
Silver color
Lenses
1 / 3 "
2x variable
3.8-8 mm focal length
Auto iris
Silver color
PLZ15/33
1/3" Vari-focal Lens2
Wide-angle lens
ƒ1.5 aperture ratio
15-50 mm focal length
Auto iris
Vandal-resistant
camera compatible*
PLZ29/27
1/3" Vari-focal
Day/Night Lens2
Wide-angle lens
ƒ0.95 aperture ratio
2.9–8.0 mm focal length (2.7x)
Auto iris
Vandal-resistant camera compatible*
For Camera/Lens Compatibility, Visit Pages 100-101
*Only the factory installed lens qualifies for the vandal-resistant rating
Visit www.panasonic.com/security for the latest product information
85
Lenses
1 / 3 "
L E N S E S
PLA22T3DN
PLAMP2206
1/3" Fixed Focal Lens1
1/3" Megapixel Lens2
Wide-angle lens
ƒ1.2 aperture ratio
2.2 mm focal length
Auto iris
Vandal-resistant
camera compatible*
Wide-angle lens
2.2 mm focal length
Auto iris
Megapixel camera compatible
PLAMP2406
PLAMP2812
1/3" Megapixel Lens2
1/3" Megapixel Lens2
Wide-angle lens
ƒ1.2 aperture ratio
2.4-6 mm focal length
Auto iris
Megapixel camera compatible
Wide-angle lens
ƒ1.4 aperture ratio
2.8-12 mm focal length
Auto iris
Megapixel camera compatible
PLAMP0550
1/3" Megapixel Lens2
For Camera/Lens Compatibility, Visit Pages 100-101
86
Wide-angle lens
ƒ1.4 aperture ratio
5-50 mm focal length
Auto iris
Megapixel camera compatible
1. OEM partnership w/Tamron
2. OEM partnership w/Fujinon
*Only the factory installed lens qualifies for the vandal-resistant rating
Visit www.panasonic.com/security for the latest product information
L E N S E S
PLZ27/5DN
PLZ20/5
1/3" Vari-focal
Day/Night Lens2
1/3" Vari-focal Lens1
Wide-angle lens
ƒ1.3 aperture ratio
2.7–13.5 mm focal length (5x)
Auto iris
Lenses
1 / 3 "
Wide-angle lens
ƒ1.6 aperture ratio
20.0–100.0 mm
focal length (5x)
Auto iris
PTVR0916DC
1/3" Vari-focal Lens1
PLZ5/10
1/3" Vari-focal Lens
2
Wide-angle lens
ƒ1.6 aperture ratio
5.0–50.0 mm focal length (10x)
Auto iris
1 / 2 "
PLAHS1770
1/2" Vari-focal Lens2
10x variable lens
ƒ1.8 aperture ratio
7-70 mm focal length
Manual iris
For WV-CL930 camera series
ƒ1.6 aperture ratio
9-22 mm focal length
Auto iris
L E N S E S
WV-LZ81/6A
1/2" Zoom Lens
6x motorized lens
ƒ1.2 aperture ratio
8.5-51 mm focal length
Auto iris
For Camera/Lens Compatibility, Visit Pages 100-101
1. OEM partnership w/Tamron
2. OEM partnership w/Fujinon
Visit www.panasonic.com/security for the latest product information
87
Housings and Mounting Brackets
I N D O O R
D O M E
H O U S I N G S
PID5SN
Indoor Recessed Ceiling
Housing – Smoked
Discreet enclosure for mounting into a drop
ceiling tile or sheet rock ceiling
Metal back box, plenum rated
Smoked dome
For WV-NS202, WV-NF284,WV-CF294/284
& WV-CW484 cameras
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Dome Recessed Ceiling
No
Indoor
None
14" x 11" x 11" (HxWxD)
4 lbs.
Camera Compatibility:
WV-NS202A, WV-SC385/384, WV-SF336/335/332,
WV-SF346/342, WV-NF284, WV-CF324, WV-CF294,
WV-CF284, WV-CF504
PID5CN
Indoor Recessed Ceiling
Housing – Clear
Discreet enclosure for mounting into a drop
ceiling tile or sheet rock ceiling
Metal back box, plenum rated
Clear dome
For WV-NS202, WV-NF284, WV-CF294/284
& WV-CW484 cameras
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Dome Recessed Ceiling
No
Indoor
None
14" x 11" x 11" (HxWxD)
4 lbs.
Camera Compatibility:
WV-NS202A, WV-SC385/384, WV-SF336/335/332,
WV-SF346/342, WV-NF284, WV-CF324, WV-CF294,
WV-CF284, WV-CF504
88
Visit www.panasonic.com/security for the latest product information
D O M E
H O U S I N G S
PDM9
Indoor Drop Ceiling Mount
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Drop Ceiling
No
Indoor
None
2' x 2'
5 lbs.
Camera Compatibility:
WV-CS954, WV-CS574
For discreet indoor surveillance;
mounts into a standard 2 x 2 or 2 x 4
suspended ceiling
Can be used alone or in conjunction with
the entire ceiling tile
For the WV-CS954 and WV-CS574 cameras
Camera not included
PID9
Indoor In-Ceiling Dome Housing
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Recessed Ceiling
No
Indoor
None
8.4" x 8.4" x 6.6" (HxWxD)
3.5 lbs.
Housings and Mounting Brackets
I N D O O R
Opaque liner combined with lower tinted
dome hides camera position
Steel upper housing
For WV-CS574 and WV-CS954 cameras
(camera not included)
Camera Compatibility:
WV-NS954, WV-NS202A, WV-CS954, WV-CS574
89
Visit www.panasonic.com/security for the latest product information
Housings and Mounting Brackets
I N D O O R
VA N D A L - R E S I S TA N T
H O U S I N G S
PIDV7CN/PIDV7SN
Vandal-Resistant Indoor Recessed Ceiling Housing
and Mount
Easy installation into sheetrock or drop ceilings
Heavy duty construction with durable 7" polycarbonate dome
Includes a decorative trim ring with security screws
Plenum rated metal top
PIDV7CN: Clear lower dome
PIDV7SN: Smoked lower dome
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Clear lower dome shown
Recessed Ceiling
No
Indoor
None
11.5" x 11.8" x 11.8" (HxWxD)
8 lbs
Camera Compatibility:
WV-NS954, WV-CS954, WV-CS574
PISM5V
Indoor Vandal-Resistant Housing
Easy camera installation
Constructed of high-impact polycarbonate for vandal resistance
Surface mount primary design with the ability to be pendant or wall mounted by way
of 1" pipe thread attachment point on the top of the enclosure (plug included when
not used)
Designed to meet IP66 standards
The enclosure also features a side knock-out for ¾" conduit opening to meet a variety
of installations conditions
Mounting support for multiple Panasonic cameras
Specs
Type
Heater/Blower
Operating Temperature
Weight
Surface Mount
Yes
-40 F to +122 F
5 lbs
Camera Compatibility:
WV-NS202A, WV-NF302, WV-SC385/384,
WV-SF336/335/332, WV-CF324, WV-CF504,
WV-CF294/284
Popular Accessory
Photo Not
Available
Model No.
Description
Page Ref.
90
Visit www.panasonic.com/security for the latest product information
PWMSM5V
1" NPT
gooseneck
wall mount
—
Specs
Type
Dome Pendant
PTZ Camera Mount
Heater/Blower
Yes
Operating Temperature -20 F to +120 F
Power/Consumption
24VAC/52 W
Dimensions
14" x 10" x 10" (HxWxD)
Weight
6.6 lbs
H O U S I N G S
POD7CN
Outdoor Dome Housing
Camera Compatibility:
WV-NS954, WV-NS202A, WV-SC385/384, WV-CS954,
WV-CS574
D O M E
Housings and Mounting Brackets
O U T D O O R
Pendant mount style for PTZ dome cameras
Easy installation
24-hour fan operation for effective heating and
condensation protection
24VAC heater for low power installation
Surge protection for video line and power
Ground loop protection by optional unit
PWBT1621 (isolation transformer)
Optically clear dome material
Lower dome: 7” diameter
Camera not included
Specs
Type
Dome Wall
PTZ Camera Mount
Heater/Blower
Yes
Operating Temperature -20° F to +120° F
Power/Consumption
24VAC/52 W
Dimensions
14" x 15" x 10" (HxWxD)
Weight
19.8 lbs
POD7CWN
Outdoor Dome Housing
Includes same features as POD7CN, except:
Wall mount style for PTZ dome cameras
Camera Compatibility:
WV-NS954, WV-NS202A, WV-SC385/384,WV-CS954,
WV-CS574
POD8CF
Outdoor Dome Housing
Specs
Type
Dome Pendant
Fixed Camera Mount
Heater/Blower
Yes
Operating Temperature -50° F to +120° F
Power/Consumption
24VAC, 50 W
Dimensions
17" x 14" x 17" (HxWxD)
Weight
11 lbs.
Camera Compatibility:
WV-NP502, WV-CP500 Series, WV-SP105/102,
WV-CP290 Series
Pendant mount for fixed cameras
White housing
Durable engineered plastic top, UV protected
Optional mounts for corner, pole, and parapet
applications PACA2, PAPM3
24VAC blowers and thermostatically controlled
heaters for condensation protection
Surge protection for both video and power
Thermoformed, optically clear,
cell-cast acrylic material
Use optional PWM20G or PWM20GB
for wall mount application
Specs
POD8CWF
Type
Outdoor Dome Housing
Dome Wall
Fixed Camera Mount
Heater/Blower
Yes
Operating Temperature -50° F to +120° F
Power/Consumption
24VAC, 50 W
Dimensions
17" x 14" x 17" (HxWxD)
Weight
11 lbs.
Wall mount for fixed cameras
White housing
Includes same features as POD8CF
Optional mounts for corner, pole and
parapet applications
Camera Compatibility:
WV-NP502, WV-CP500 Series, WV-SP105/102,
WV-CP290 Series
Popular Accessories
MOUNTING
BRACKETS
Model No.
Description
Page Ref.
PWM20G
Gooseneck
wall mount,
black
95
PWM20GB
Gooseneck
wall mount,
beige
95
PWM30G
Parapet mount
(inside wall),
black
95
PWM30GB
Parapet mount
(inside wall),
beige
95
PPRM30G
Parapet mount
(outside wall),
black
95
PPRM30GB
Parapet mount
(outside wall),
beige
95
Visit www.panasonic.com/security for the latest product information
PWBT1621
Ground loop
isolation
transformer
—
PACA2
Corner mount
adapter
black
95
PAPM3
Pole mount
adapter,
black
95
PMSM5
Pendant
shroud
93
91
Housings and Mounting Brackets
O U T D O O R
D O M E
H O U S I N G S
POD9CT
Outdoor Dome Housing
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Pendant mount style for PTZ dome cameras
Built-in heater/blower for effective
heating/condensation protection
Surge protection for video and power lines
Optically clear dome material, UV protected
White housing
Dome Pendant Mount
Yes
-40° F to +122° F
24VAC, 50 W
15" x 11" x 16" (HxWxD)
7 lbs.
Camera Compatibility:
WV-NS202A, WV-CS954, WV-CS574, WV-NS954
POD9CWT
Outdoor Dome Housing
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Wall mount style for PTZ dome cameras
Built-in heater/blower for effective
heating/condensation protection
Surge protection for video and power lines
Optically clear dome material, UV protected
White housing
Dome Wall Mount
Yes
-40° F to +122° F
24VAC, 50 W
15" x 11" x 16" (HxWxD)
7 lbs.
Camera Compatibility:
WV-NS202A, WV-CS954, WV-CS574, WV-NS954
POD9C
Outdoor Dome Housing
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Pendant mount style for PTZ dome cameras
Built-in heater/blower for effective
heating/condensation protection
Surge protection for video and power lines
Optically clear dome material, UV protected
Silver housing
Dome Pendant Mount
Yes
-40° F to +122° F
24VAC, 50 W
15" x 11" x 11" (HxWxD)
7 lbs.
Camera Compatibility:
WV-NS202A, WV-CS954, WV-CS574, WV-NS954
POD9CW
Outdoor Dome Housing
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Wall mount style for PTZ dome cameras
Built-in heater/blower for effective
heating/condensation protection
Surge protection for video and power lines
Optically clear dome material, UV protected
Silver housing
Dome Wall Mount
Yes
-40° F to +122° F
24VAC, 50 W
15" x 11" x 16" (HxWxD)
7 lbs.
Camera Compatibility:
WV-NS202A, WV-CS954, WV-CS574, WV-NS954
Popular Accessories
MOUNTING
BRACKETS
Model No.
Description
92
Page Ref.
PWM20G
Gooseneck
wall mount,
black
95
PWM20GB
Gooseneck
wall mount,
beige
95
PWM30G
Parapet mount
(inside wall),
black
95
PWM30GB
Parapet mount
(inside wall),
beige
95
PPRM30G
Parapet mount
(outside wall),
black
95
PPRM30GB
Parapet mount
(outside wall),
beige
95
PWBT1621
Ground loop
isolation
transformer
—
PACA2
Corner mount
adapter
black
95
Visit www.panasonic.com/security for the latest product information
PAPM3
Pole mount
adapter,
black
95
PMSM5
Pendant
shroud
93
VA N D A L - R E S I S TA N T
H O U S I N G S
PODV7CPNS
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Dome Pendant Mount
24 VAC 25 W
-20° F to +122°F
24V AC/54 W
10.3" x 10.3" x 14.6"
(262mm x 262mm x 371mm)
7 lbs.
Outdoor Vandal-Resistant Housing
White housing
Power board included
Heater/blower
Pendant mount
Camera Compatibility:
WV-NS202A, WV-CS574, WV-SC385/384
PODV7CWNS
Specs
Outdoor Vandal-Resistant Housing
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Dome Wall Mount
24 VAC 25 W
-20° F to +122°F
24V AC/25 W
10.3" x 10.3" x 14.6"
(262mm x 262mm x 371mm)
7 lbs.
White housing
Power board included
Heater/blower
Wall mount
Camera Compatibility:
WV-NS202A, WV-CS574, WV-SC385/384
PODV9CPT
Housings and Mounting Brackets
O U T D O O R
Outdoor Vandal-Resistant Housing
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Dome Pendant Mount
24 VAC 25 W
-20° F to +122°F
24V AC/52 W
10.3" x 10.3" x 14.6"
(262mm x 262mm x 371mm)
9 lbs.
Pendant mount with easy camera installation
Strong cast aluminum top and trim ring
Rugged UV protected polycarbonate lower dome
Heater/blower for effective heating
and condensation protection
Camera Compatibility:
WV-CS954, WV-CS574, WV-NS954, WV-NS202A
PODV9CWT
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Dome Wall Mount
24 VAC 25 W
-20° F to +122°F
24V AC/52 W
10.3" x 10.3" x 14.6"
(262mm x 262mm x 371mm)
9 lbs.
Outdoor Vandal-Resistant Housing
Wall mount with easy camera installation
Strong cast aluminum top and trim ring
Rugged UV protected polycarbonate lower dome
Heater/blower for effective heating
and condensation protection
Camera Compatibility:
WV-CS954, WV-CS574, WV-NS954, WV-NS202A
POSM5V
Specs
Type
Heater/Blower
Operating Temperature
Weight
Outdoor Vandal-Resistant Housing
Surface Mount
Yes
-40 F to +122 F
5 lbs
Constructed of high impact polycarbonate
Surface mount with ability to pendant or wall mount
Easy camera installation
Camera Compatibility:
WV-NS202A, WV-CF294/284, WV-CF504, WV-CF324,
WV-SC385/384, WV-SF346/342, WV-SF336/335/332
PMSM5
Pendant Shroud
Sunshield
1.5” collar convert for POSM5V
Popular Accessories
MOUNTING
BRACKETS
Model No.
Description
Page Ref.
PWM20G
Gooseneck
wall mount,
black
95
PWM20GB
Gooseneck
wall mount,
beige
95
PWM30G
Parapet mount
(inside wall),
black
95
PWM30GB
Parapet mount
(inside wall),
beige
95
PPRM30G
Parapet mount
(outside wall),
black
95
PPRM30GB
Parapet mount
(outside wall),
beige
95
Visit www.panasonic.com/security for the latest product information
PWBT1621
Ground loop
isolation
transformer
—
PACA2
Corner mount
adapter
black
95
PAPM3
Pole mount
adapter,
black
95
PMSM5
Pendant
shroud
93
93
Housings and Mounting Brackets
I N D O O R / O U T D O O R
F I X E D
H O U S I N G S
POH1000
Outdoor Housing
10" aluminum housing for all Panasonic
standard body cameras and all current
Panasonic vari-focal and fixed lenses
Lightweight aluminum chassis
Side hinges for ease of access when
focusing and adjusting
Terminal block interface for easy connection
Provision for optional heater/blower
and sun shield
Includes PWM800 wall mount kit
Specs
Type
Standard Fixed Camera
Heater/Blower
Yes
Operating Temperature -20° F to +120° F
Power/Consumption
24VAC, 27 W
Dimensions
4.3" x 5.6" x 11" (HxWxD)
Weight
5 lbs.
Camera Compatibility:
WV-NP502, WV-CL930 Series, WV-CP500 Series,
WV-CP290 Series, WV-SP105/102
Popular Accessory
Model No.
Description
POH1000HB
Outdoor Housing
Includes same features as POH1000, plus:
Built-in 24VAC heater/blower
POH1000NWM
Outdoor Housing
Includes same features as POH1000, plus:
Intelligently operates from a PoE Plus,
IEEE 802.3at input to power the H&B system
and compliant camera
Midspan included
Standard combination wall/pole mount option
Easy camera installation using only one
network cable
Built-in thermostatically controlled H&B
Lightweight aluminum chassis
Vandal-resistant polycarbonate viewing window
POH1500
Outdoor Housing
15" housing for fixed box cameras
Lightweight aluminum chassis
Side hinge for ease of access when
adjusting and servicing camera
Dual conduit opening on housing bottom,
sealed with rubber grommets
Terminal block interface for easy connection
Provision for optional heater/blower
and sun shield
Includes PWM800 wall mount kit
Page Ref.
PSS10
Sunshield, also
performs as
hanging mount
—
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Standard Fixed Camera
Yes
-20° F to +120° F
120-240VAC, 50-60 Hz
(midspan input)
8.6" x 8.6" x 8.4" (HxWxD)
7 lbs.
Camera Compatibility:
WV-NP502, WV-CL930 Series, WV-CP500 Series,
WV-CP290 Series, WV-SP105/102
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Standard Fixed Camera
Yes
-20° F to + 120° F
24VAC, 27 W
4.3" x 5.6" x 16" (HxWxD)
7 lbs.
Camera Compatibility:
WV-NP502, WV-CL930 Series, WV-CP500 Series,
WV-CP290 Series, WV-SP105/102
Popular Accessory
POH1500HB
Outdoor Housing
Model No.
Description
Includes same features as POH1500, plus:
Built-in 24VAC heater/blower
Page Ref.
P R E S S U R I Z E D
H O U S I N G S
PPFD9C/PPFD9CN
Pressurized Dome Housing
94
PSS15
Sunshield, also
performs as
hanging mount
—
Constructed of durable engineered plastic top,
94 VO with UV protected and polycarbonate
lower dome
Standard with pendant mount
Meets DE and IP67 standards
Pressurized indicator
50 W heater turns on at 40º F and off at 60º F
Power and video surge protector
PPFD9C: for analog cameras
PPFD9CN: for network cameras
Specs
Type
Heater/Blower
Operating Temperature
Power/Consumption
Dimensions
Weight
Camera Compatibility:
WV-CS954, WV-CS574
Visit www.panasonic.com/security for the latest product information
Pendant
24 VAC 54 W
-50° F to +122°F
24V AC/52 W
13" x 11.5" x 11.5" (HxWxD)
(262mm x 262mm x 371mm)
7 lbs.
B R A C K E T S
PACA2 – Black Finish
PACA2B – Beige Finish
PAPM3 – Black Finish
PAPM3B – Beige Finish
Outdoor Corner Mount
Adapter
Outdoor Pole Mount Adapter
200 lbs. load weight
To corner mount dome housing models:
POD7CW, POD8CWF, POD9CWT, POD9CW,
PODV7CWNS, PWM20G, PWM20GB,
PWM20GS
Mounted to a round pole larger than
3" in diameter by stainless steel straps
(not included)
200 lbs. load weight
To mount dome housing models:
POD7CW, POD8CWF, POD9CWT,
POD9CW, PODV7CWNS, PWM20G,
PWM20GB, PWM20GS
PPMF12D
PHM5
Pendant Mount Bracket
Hanging Mount Bracket
Mounting bracket and back box
for housing models: POD7C, POD8CF,
POD9C, POD9CT, PODV7CNS in a
hanging mount application
Includes knockouts for conduit
1-1/2" standard pipe
(not included)
PPRM30G – Black Finish
PPRM30GB – Beige Finish
Parapet Mount
Durable powder coat finish
All aluminum construction
1 1/2" pipe thread on end for quick
and easy dome mounting
Access plug for easy wire pulls
Extension piece for added flexibility
Swivels for easy camera mounting
50 lbs. load rating
For pendant housings
Designed for indoor use and
for pendant mounting from a
flat surface
Pipe extension (not included)
For use with Panasonic PTZ cameras
Camera not included
PSRCW2000B
Outdoor Parapet
Roof Top Mount Bracket
Heavy-duty
Designed to be mounted on a flat
roof top or roof top parapet
Swivels for easy camera mounting
150 lbs. load weight
Black
For use with outdoor dome housing
models: POD7CW, PODV7CWNS,
POD8CW, POD9CWT
PWM30G –
Black Finish
PWM30GB –
Beige Finish
PWM20G – Black Finish
PWM20GB – Beige Finish
PWM20GS – Silver Finish
Parapet Mount
Housings and Mounting Brackets
M O U N T I N G
Wall Mount
Durable powder coat finish
All aluminum construction
1 1/2" pipe thread on end for
quick and easy dome mounting
Access plug for easy wire pulls
Swivels for easy camera mounting
50 lbs. load rating
Durable powder coat finish
All aluminum construction
1 1/2" pipe thread on end for quick
and easy dome mounting
Access plug for easy wire pulls
50 lbs. load rating
For all pendant mounts
95
Visit www.panasonic.com/security for the latest product information
Housings and Mounting Brackets
M O U N T I N G
B R A C K E T S
PRCM1
PUM8
Embedded Mount Bracket
Indoor Wall
Mount Bracket
For use in recessed ceiling applications
(ceiling tile or sheetrock)
White trim plate
Designed for BB-HCM701A,
BB-HCM705A, WV-CW484, WV-NF284,
WV-NS202A, WV-NW484S cameras
For wall mount applications
or can be quickly converted
for ceiling mounting
For Panasonic’s standard body
cameras with maximum
camera and lens length of 8"
and maximum weight of 3 lbs.
PWM9
PWM800
Wall Mount Bracket
Outdoor Wall/Pole Mount
Designed for indoor use, supports
Panasonic PTZ cameras
Mounts to a flat wall and
has a 1" cable opening
Camera not included
Medium-duty outdoor mount
Designed for mounting to a
flat wall or round pole
(larger than 3.5" diameter)
Supports weight loads up to 25 lbs.
Black, textured powder coat finish
Use with POH1000/POH1500
bullet housing series
WV-Q105
WV-Q106
Direct Ceiling
Installation Bracket
Embedded Ceiling
Mount Bracket
For WV-CS954, WV-CS574
and WV-NS202A cameras
For WV-CS574 camera
WV-Q115
WV-Q116
Mounting Bracket
Embedded Ceiling
Installation Bracket
For WV-CW504F camera
For WV-CS954 camera
96
Visit www.panasonic.com/security for the latest product information
B R A C K E T S
WV-Q117
WV-Q118
Suspended Ceiling
Installation Bracket
Wall Mount Bracket
WV-Q150C - Clear Dome
WV-Q150S - Smoke Dome
Wall Mount Bracket
For WV-CS954 and WV-CS574 cameras
For WV-NS202A network PTZ camera
For WV-CS954 and
WV-CS574 cameras
WV-Q151C - Clear Dome
WV-Q151S - Smoke Dome
Embedded Ceiling Mount
Bracket
For WV-NS202A
network PTZ camera
WV-Q152C - Clear Dome
WV-Q152S - Smoke Dome
WV-Q154C - Clear Dome
WV-Q154S - Smoke Dome
Ceiling Mount Bracket
Wall Mount Bracket
For WV-NS202A network PTZ camera
Housings and Mounting Brackets
M O U N T I N G
For WV-SC385 and WV-SC384
network PTZ cameras
WV-Q155C - Clear Dome
WV-Q155S - Smoke Dome
Embedded Ceiling Mount Bracket
For WV-SC385 network PTZ camera
97
Visit www.panasonic.com/security for the latest product information
Housings and Mounting Brackets
M O U N T I N G
B R A C K E T S
WV-Q156C Clear Dome Cover
WV-Q156S Smoke Dome Cover
WV-Q157
Inner Dome Cover
For WV-SC385
network PTZ camera
For WV-SC385 network PTZ camera
WV-Q169
WV-Q173
Embedded Ceiling Mount
Bracket
Embedded Ceiling
Mount Bracket
For WV-NW484S camera
For WV-NF302 camera
WV-Q174
Recessed Ceiling Bracket
For WV-SF330 Series network cameras
98
Visit www.panasonic.com/security for the latest product information
C A M E R A
PS484S
PPM484S
Vandal-Resistant Shroud
Vandal-Resistant
Pole Mount
Weatherproof
Durable cast aluminum construction
1 ½" NPT thread for easy mounting
Weatherproof
Pass through for
wire connections
Pole outdoor mount for
WV-CW244S, WV-CW484S,
WV-NW484S and
WV-NW502S cameras
PCM484S
PHM484S
Vandal-Resistant
Corner Mount
Vandal-Resistant
Hanging Mount
Weatherproof
Pass through for
wire connections
Corner outdoor mount for
WV-CW244S, WV-CW484S,
WV-NW484S and
WV-NW502S cameras
B R A C K E T S
Housings and Mounting Brackets
VA N D A L - R E S I S TA N T
Weatherproof
Pass through for
wire connections
Made of 1" thick
steel tubing
Beige powder coat finish
Outdoor hanging mount for
WV-CW244S, WV-CW484S,
WV-NW484S and
WV-NW502S cameras
PWM484S
Vandal-Resistant
Wall Mount
Weatherproof
Pass through for wire
connections
Outdoor wall mount for
WV-CW244S, WV-CW484S,
WV-NW484S and
WV-NW502S cameras
99
Visit www.panasonic.com/security for the latest product information
Camera and Lens Combinations
Recommended Camera and Lens Combinations
Camera Models
WV-NW502S
Lens Models
Size
Model
Focal length (mm)
Aperture ratio
Auto iris
1/3"
PLA22T3DN
2.2
ƒ1.2
Y
1/2"
PLAHS1770
7.0~70.0
ƒ1.8
N
1/3"
PLAMP0550
5.0~50.0
ƒ1.4
Y
1/3"
PLAMP2206
2.2
ƒ1.3
Y
1/3"
PLAMP2406
2.4~6.0
ƒ1.2
Y
1/3"
PLAMP2812
2.8~12.0
ƒ1.4
Y
1/3"
PLZ15/33
15.0~50.0
ƒ1.5
Y
1/3"
PLZ20/5
20.0~100.0
ƒ1.6
Y
1/3"
PLZ27/5DN
2.7~13.5
ƒ1.3
Y
1/3"
PLZ29/27
2.9~8.0
ƒ0.95
Y
1/3"
PLZ5/10
5.0~50.0
ƒ1.6
Y
1/3"
PTVR0916DC
9.0~22.0
ƒ1.6
Y
1/3"
WV-LZ62/8S
5.0~40.0
ƒ1.6 (W);
ƒ1.9 (T)
Y
1/2"
WV-LZ81/6A
8.5~51.0
ƒ1.2
Y
1/3"
WVLZA61/2S
3.8~8.0
ƒ1.4 (W);
ƒ1.8 (T)
Y
1/3"
WV-LZA62/2
2.8~6.0
ƒ1.4 (W);
ƒ1.2 (T)
Y
WV-NW484S
WV-NP502
WV-SF306/305/302
•
•
•
•
•
•
•
•
•
100
Visit www.panasonic.com/security for the latest product information
Camera Models
WV-CW504
series
Lens Models
WV-CL930
series
WV-CP500
series
WV-CP290
series
Size
Model
Focal length (mm)
Aperture ratio
Auto iris
1/3"
PLA22T3DN
2.2
ƒ1.2
Y
1/2"
PLAHS1770
7.0~70.0
ƒ1.8
N
1/3"
PLAMP2206
2.2
ƒ1.3
Y
1/3"
PLZ15/33
15.0~50.0
ƒ1.5
Y
•
1/3"
PLZ20/5
20.0~100.0
ƒ1.6
Y
•
1/3"
PLZ27/5DN
2.7~13.5
ƒ1.3
Y
•
1/3"
PLZ29/27
2.9~8.0
ƒ0.95
Y
•
1/3"
PLZ5/10
5.0~50.0
ƒ1.6
Y
•
1/3"
PTVR0916DC
9.0~22.0
ƒ1.6
Y
•
•
1/3"
WV-LZ62/8S
5.0~40.0
ƒ1.6 (W);
ƒ1.9 (T)
Y
•
•
1/2"
WV-LZ81/6A
8.5~51.0
ƒ1.2
Y
1/3"
WVLZA61/2S
3.8~8.0
ƒ1.4 (W);
ƒ1.8 (T)
Y
•
•
1/3"
WV-LZA62/2
2.8~6.0
ƒ1.4 (W);
ƒ1.2 (T)
Y
•
•
•
•
•
Camera and Lens Combinations
Recommended Camera and Lens Combinations
•
101
Visit www.panasonic.com/security for the latest product information
(refer to individual specifications for more detail)
Housing Features
Camera Models
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
PCM484S
•
•
•
•
•
•
•
PHM484S
•
•
•
•
•
•
•
PWM484S
•
•
•
•
•
•
•
WV-CF324
WV-CF294/284
WV-CF504
•
•
•
•
•
•
•
•
•
•
•
•
•
WV-CS574
•
•
WV-CS954
•
WV-SF346/342
•
WV-NP502
•
WV-NF302
•
WV-NS202A
•
WV-NS954
•
Heater/Blower
•
•
•
Recessed
Ceiling
PID9
•
Clear Dome
•
•
Smoke Dome
PID5SN
WV-SP105/102
•
•
WV-SC385/384
•
PID5CN
Wall Mount
•
•
Pendant
Mount
•
PDM9
Outdoor
WV-CW504F/S
WV-CP290 Series
•
WV-CW364/334
WV-CP500 Series
WV-SF336/335/332
•
•
Housing
Model
Indoor
Housing and Camera Cross Reference Chart
Housing and Camera Cross Reference Chart
•
•
•
•
•
PIDV7CN
•
•
•
PIDV7SN
•
•
•
•
•
POD7CN
•
•
POD7CWN
•
POD8CF
•
POD8CWF
•
PISM5V
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
PS484S
•
PPM484S
POSM5V
PRCM1
•
•
•
102
Visit www.panasonic.com/security for the latest product information
(refer to individual specifications for more detail)
Housing Features
Camera Models
•
POD9CT
(WHITE)
•
•
•
•
•
•
•
•
POD9CW
(SILVER)
•
•
•
•
•
•
•
•
POD9CWT
(WHITE)
•
•
•
•
•
•
•
•
PODV7CPNS
•
•
•
•
•
•
•
PODV7CWNS
•
•
•
•
•
•
•
•
•
•
POH1000HB
•
•
POH1000NWM
•
POH1500HB
PPFD9C
POH1000
•
•
WV-SP105/102
WV-SC385/384
WV-CP290 Series
WV-CS574
WV-CP500 Series
WV-CS954
WV-CL930 Series
WV-NS202A
WV-SW355/352
WV-NS954
•
WV-NW502S
Heater/Blower
•
WV-NP502
Clear Dome
•
Wall Mount
•
Pendant
Mount
•
Vandal
•
Outdoor
•
Indoor
POD9C
(SILVER)
Housing
Model
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
PRCM1
•
•
PS484S
•
•
PPM484S
•
•
PCM484S
•
•
PHM484S
•
•
PWM484S
•
•
Housing and Camera Cross Reference Chart
Housing and Camera Cross Reference Chart
•
103
Visit www.panasonic.com/security for the latest product information
Housing and Bracket Compatibility Chart
104
Housing and Bracket Compatibility Chart
Page
95
95
95
95
95
PACA2/PACA2B
PAPM3/PAPM3B
PHM5
PPMF12D
PPRM30G/30GB
Housing
Page
Description
Outdoor corner
mount bracket
Outdoor pole
mount adapter
Hanging mount
bracket
Pendant mount
bracket
Extended parapet
mount
POD7CN
91
Outdoor dome
housing, pendant
w/ optional
PWM20G
series
w/ optional
PWM20G
series
•
•
•
POD7CWN
91
Outdoor dome
housing, wall bracket
•
•
POD8CF
91
Outdoor pendant
mount housing for
fixed cameras
w/ optional
PWM20G
series
w/ optional
PWM20G
series
•
•
•
POD8CWF
91
Outdoor pendant
mount housing for
fixed cameras,
wall bracket
•
•
POD9C
92
Outdoor pendant
mount housing, silver
•
•
92
Outdoor pendant
mount housing, white
w/ optional
PWM20G
series
w/ optional
PWM20G
series
•
POD9CT
w/ optional
PWM20G
series
w/ optional
PWM20G
series
•
•
•
POD9CW
92
Outdoor housing,
wall mount, silver
•
•
POD9CWT
92
Outdoor housing, wall
mount, white
•
•
PODV7CPNS
93
Outdoor vandal-resistant w/ optional
housing, pendant,
PWM20G
white
series
•
•
•
PODV7CWNS
93
Outdoor vandal-resistant
housing, wall mount,
white
PODV9CPT
93
Outdoor vandal-resistant w/ optional
housing, pendant,
PWM20G
white
series
•
•
•
PODV9CWT
93
Outdoor vandal-resistant
housing, wall mount,
white
POH1000
94
10" outdoor fixed box
housing
POH1000HB
94
10" outdoor fixed box
housing with
heater/blower
POH1000NWM
94
10" outdoor fixed box
housing with
heater/blower and PoE+
POH1500
94
15" outdoor fixed box
housing
POH1500HB
94
15" outdoor fixed box
housing with
heater/blower
PPFD9C
94
Pressurized dome
housing
•
•
•
•
w/ optional
PWM20G
series
•
w/ optional
PWM20G
series
•
•
w/ optional
PWM20G
series
w/ optional
PWM20G
series
Visit www.panasonic.com/security for the latest product information
Page
95
95
95
95
PSRCW2000B
PWM20G/PWM20GB/PWM20GS
PWM30G/30GB
PWM800
Outdoor parapet
roof top bracket
Parapet mount
Parapet mount
Outdoor wall/pole mount
•
•
•
•
Housing
Page
Description
POD7CN
91
Outdoor dome
housing, pendant
POD7CWN
91
Outdoor dome
housing, wall bracket
POD8CF
91
Outdoor pendant
mount housing for
fixed cameras
POD8CWF
91
Outdoor pendant mount
housing for fixed
cameras, wall bracket
POD9C
92
Outdoor pendant
mount housing, silver
•
•
POD9CT
92
Outdoor pendant
mount housing, white
•
•
POD9CW
92
Outdoor housing,
wall mount, silver
•
POD9CWT
92
Outdoor housing, wall
mount, white
•
PODV7CPNS
93
Outdoor vandal-resistant
housing, pendant,
white
•
•
PODV7CWNS
93
Outdoor vandal-resistant
housing, wall mount,
white
PODV9CPT
93
Outdoor vandal-resistant
housing, pendant,
white
•
•
PODV9CWT
93
Outdoor vandal-resistant
housing, wall mount,
white
POH1000
94
10" outdoor fixed box
housing
•
POH1000HB
94
10" outdoor fixed box
housing with
heater/blower
•
POH1000NWM
94
10" outdoor fixed box
housing with
heater/blower and PoE+
•
POH1500
94
15" outdoor fixed box
housing
•
POH1500HB
94
15" outdoor fixed box
housing with
heater/blower
•
PPFD9C
94
Pressurized dome
housing
•
•
Housing and Bracket Compatibility Chart
Housing and Bracket Compatibility Chart
•
•
Visit www.panasonic.com/security for the latest product information
•
•
105
System Diagrams
Total System Solutions
Panasonic provides total system solutions for analog and IP systems, including hybrid solutions which allow
migration from analog to digital platforms. All product information is provided as an example only. Contact
your local Panasonic representative for system design assistance.
Product Information
Cable Information
106
Visit www.panasonic.com/security for the latest product information
System Diagrams
Small Analog System
Mid Size Analog System
107
Visit www.panasonic.com/security for the latest product information
System Diagrams
Large Analog System (Single Site)
Large Analog System
108
Visit www.panasonic.com/security for the latest product information
System Diagrams
Small IP System
Mid Size IP System
109
Visit www.panasonic.com/security for the latest product information
System Diagrams
Large IP System
Large Satellite System
110
Visit www.panasonic.com/security for the latest product information
System Diagrams
Mid Size Hybrid System
Large Hybrid System
111
Visit www.panasonic.com/security for the latest product information
Testimonials
User Testimonials
Healthcare
“For 26 years... we have used Panasonic
equipment. It has been very good and
reliable. It's just high quality equipment.”
Don Sullivan
Toledo Hospital
Don Sullivan at Toledo Hospital is confident that whatever
happens throughout the hospital, his security department
will have video of it.
Corrections
“The Panasonic equipment is very rugged.
The Panasonic NVRs went through two
hurricanes with no problems.”
Mark Piatt
Calcasieu Parish Sheriff's Office
As security auditor for Calcasieu Parish corrections, Mark Piatt was
tasked with overseeing a project to implement a new Panasonic
video surveillance system.
Transportation
“When you have a system of this size,
you want a supplier like Panasonic.”
Nick Sachs
David S. Brown Enterprises, Ltd.
Ken Voland (L), property manager, and Nick Sachs (R), asset
manager, both of David S. Brown Enterprises Ltd., worked with
Robert W. Harry Jr. (C) of Signals Communication Systems Inc.
to ensure the Panasonic installation went smoothly.
112
Visit www.panasonic.com/security for the latest product information
Education
Corrections / Government
Abington School District - Abington, PA
Avon Comm. Schools - Avon, IN
Bibb County School District - Bibb County, GA
Bowling Green University - Bowling Green, OH
Burlington County Technical Schools, Westampton, NJ
Calhoun County Schools - Calhoun County, MI
Camden County Technical School - Berlin, NJ
Carthage Ind. School District - Carthage, TX
Channhassen High School – Channhassen, MN
City College - Ft. Lauderdale, FL
Coatesville School District - Coatesville, PA
Colonial School District – Plymouth Meeting, PA
Duluth Public Schools – Duluth, MN
East Ridge High School – Woodbury, MN
Edinboro University – Edinboro, PA
Fayetteville State University – Fayetteville, NC
Fergus Falls Community College – Fergus Falls, MN
Francis Howell School District - St. Louis, MO
Greenville County Schools -Greenville, VA
Hamilton Board of Education – Hamilton, NJ
Hammond Schools - Hammond, IN
Hardee County School District - Wauchula, FL
Hermantown Schools – Hermantown, MN
Horry County School District – Myrtle Beach, SC
Indian River State College - Fort Pierce, FL
Lancaster School District – Lancaster, PA
Maple Plain Schools – Maple Plain, MN
Proctor Schools – Proctor, MN
St. Anthony / New Brighton Schools – New Brighton, MN
St. Mary’s County Public Schools – Bushwood, MD
St. Michael Albertville High School – St. Michael, MN
Texas Christian University - Ft. Worth, TX
Trinity Preparatory School - Winter Park, FL
University of Memphis - Memphis, TN
University of Pennsylvania - Philadelphia, PA
University of Tennessee - Knoxville, TN
Villanova University – Villanova, PA
Greensville County Schools - Greenville, VA
Calcasieu Parrish Corrections – Lake Charles, LA
Evesham Fire Department – Evesham, NJ
Government Printing Office – Washington, DC
Huron Valley State Correctional - Ypsilanti, MI
Middletown Municipal Building - Middletown, DE
Midland County Corrections – Midland, MI
NASA – Lanham, MD
Philadelphia Housing Authority - Philadelphia, PA
Ramsey County Library – St. Paul, MN
Shakopee Police and Fire Departments – Shakopee, MN
U.S. Customs – Harpers Ferry, WV
Education
Transportation / Utilities
Ardmore Public Schools - Ardmore, OK
Broward County Public Schools - Fort Lauderdale, FL
Miami-Dade Community College - Miami, FL
Millersville University - Millersville, PA
Philadelphia Community College - Philadelphia, PA
Robinsdale Schools – Robinsdale, MN
University of Minnesota – Minneapolis, MN
Amtrak - Harrisburg, PA
BAE Shipyard – Norfolk, VA
Basin Electric – Bismark, ND
Duke Energy – Charlotte, NC
Owing Mills Metro Center – Owing Mills, MD
Installations
This is a representative listing of key Panasonic analog, hybrid, and i-Pro IP
installations. For more installations and detailed application stories, visit
panasonic.com/security
Transportation / Utilities
Amtrak - Bear, DE
City of Tallahassee Electric Utility Services – Tallahassee, FL
Kent County Airport - Grand Rapids, MI
Metro Transit – Minneapolis, MN
Commercial / Industrial / Hospitality
American Kennel Club – Raleigh, NC
Conectiv – Mays Landing, NJ
Dietz and Watson - Delanco, NJ
Indiana-Purdue Ft. Wayne (IPFW) - Ft. Wayne, IN
J.B. Hunt Trucking - Lowell, AR
Lockheed Martin HQ – Rockville, MD
Logan Aluminum - Russellville, KY
Marriott Downtown - Memphis, TN
Moffitt Cancer Center - Tampa, FL
Oberthur Card Systems - Exton, PA
Owatonna Hospital – Owatonna, MN
Pfizer - Kalamazoo, MI
Philadelphia Museum of Art - Philadelphia, PA
Southern Maryland Electric Co-op – Hughesville, MD
Westat – Rockville, MD
Wooddale Church – Eden Prairie, MN
Commercial / Industrial / Hospitality
Continental Tire – Gastonia, NC
E.I. Dupont - Wilmington, DE
Gaylord Palms Hotel & Conference Center - Kissimmee, FL
Little Sisters of the Poor – St. Paul, MN
Minneapolis Convention Center – Minneapolis, MN
QVC - West Chester, PA
S&D Coffee – Concord, NC
Corrections / Government
Atlantic City Housing Authority - Atlantic City, NJ
Library of Congress – Washington, DC
Nuclear Regulatory Commission – Rockville, MD
Stearns County – St. Cloud, MN
Hybrid
Education
Bay District Schools - Panama City, FL
Evansville School Corp. - Evansville, IN
Ft. Bend Ind. School District - Houston, TX
Norfolk State University – Norfolk, VA
Old Dominion University – Norfolk, VA
Palm Beach County School District - West Palm Beach, FL
West Chester University - West Chester, PA
Corrections / Government
Allen County Jail - Ft. Wayne, IN
FEMA/NETC - Emmittsburg, MD
State of New Jersey - Trenton, NJ
Transportation / Utilities
DFW Airport - Ft. Worth, TX
Entergy - Little Rock, AR
Southwest Airlines - Dallas, TX
Commercial / Industrial / Hospitality
Bank of America - Wilmington, DE
Giant Foods - Carlisle, PA
Lincoln Financial Field - Philadelphia, PA
Munson Hospital - Traverse City, MI
Pinnacle’s River City Casino - St. Louis, MO
SPX Corporation – Charlotte, NC
Visit www.panasonic.com/security for the latest product information
113
Resources
Panasonic Training University
Panasonic regards knowledge and information as central to understanding our technology,
our products, and the industry overall. Through P-Tech, Panasonic offers a variety of topical
course subjects for end users, dealers, integrators, and A&E’s. Our training university is staffed
by highly capable, professional Panasonic subject matter experts, as well as reputable guest
trainers from within the industry.
Classroom training
Instructor-lead classroom training takes place throughout the year across the country.
Subjects include:
- Best Practices for Video Surveillance Systems
- i-Pro Network Products
- Network Infrastructure
- Solving Real Problems with IP Video
Webcasts
Webcasts provide an easy, cost-effective and convenient way to learn from anywhere with
an internet connection. Regularly scheduled webcasts are held on key subjects including:
- Network Switches and Protocols
- Network Design for the Security Professional
- And more…
Past webcasts can be retrieved through our archives on the P-Tech website.
Self-paced online training
Panasonic offers a comprehensive selection of product-specific online training modules,
providing an interactive and convenient way to learn more about Panasonic analog, i-Pro IP,
and hybrid products.
Continuing education
Many of Panasonic’s classroom courses are eligible for Continuing Education Credits and/or
recertification through organizations such as ASIS International, NICET, NTS, and BiCSi.
For more detailed and up-to-date information, visit panasonic.com/P-Tech.
114
Visit www.panasonic.com/security for the latest product information
Resources
i-Pro Certified Reseller Program
Panasonic Security Systems offers the i-Pro Certified Reseller (IPCR) Program to train
highly capable channel resellers who can design, implement, and support newly emerging
opportunities in the IP/IT security space.
Key benefits include:
- Free training through P-Tech
- Quick and easy availability of Panasonic’s leading i-Pro IP product lineup
- Subsidized demo equipment
- Resource-rich sales and marketing materials
- And more...
Potential i-Pro Certified Resellers must be accepted for candidacy and obtain training
provided by Panasonic.
For more detailed information about the certification process and training requirements,
visit panasonic.com/P-Tech.
spec assist
spec assist, Panasonic’s award winning video surveillance system design tool, provides
valuable information and resources for systems integrators, dealers, consultants, architect &
engineers, and end users to help formulate bids and proposals. All on a handy DVD, spec
assist contains bid specifications for Panasonic video surveillance systems products, along
with CAD illustrations, operating instructions, spec sheets and calculator tools to
optimize system configurations and proposals.
spec assist also includes product literature and video demonstrations in addition to product
selectors, estimators and calculators, product operating instructions, housing and lens
compatibility charts, presentations and much more. The convenient search function makes
finding information quick and easy.
spec assist is available at no cost to professional system designers, installers, and security
professionals. Make sure you have the most updated version by ordering your free DVD at
panasonic.com/security.
115
Visit www.panasonic.com/security for the latest product information
Panasonic Solution Developer Network (PSDN)
psdn
panasonic solution
developer network
Panasonic Solution Developer Network (PSDN)
Panasonic’s continually expanding Panasonic Solution Developer Network (PSDN) now
boasts more than 125+ worldwide partners. The program promotes interoperability and
integration capabilities for Panasonic video surveillance solutions and participating
equipment and software manufacturers.
PSDN offers a unified API to simplify integration, along with interface protocols, software
development tools, and technical information and support to efficiently integrate
Panasonic’s leading line of i-Pro network video surveillance products.
Panasonic is committed to providing resellers with expanded product solutions and
endusers with seamless system capabilities to meet their security needs.
PSDN partners include:
™
S2 SECURITY CORPORATION
For a complete list of PSDN members and more information on our program, visit psdn.info.
116
Visit www.panasonic.com/security for the latest product information
S U P P O R T
To place, modify or check an order, or make shipping changes.
Toll-Free Phone:
877.733.3689
Toll-Free Fax:
877.665.5647
T E C H N I C A L
Contact Us
C U S T O M E R
S U P P O R T
For technical support on installation,
programming and configuration.
Toll-Free Phone:
800.528.6747
Toll-Free Fax:
888.809.6198
e-mail:
[email protected]
H E A D Q U A R T E R S
Panasonic System Networks Company
One Panasonic Way
Secaucus, NJ 07094
panasonic.com/security
©2011 Panasonic Corporation of North America. All rights reserved.
Specifications are subject to change without notice. Weights and dimensions are approximate.
Products in this catalog are subject to export control regulations.
Actual product appearance may vary from the photos/images represented in this catalog.
Super Dynamic, SDIII, SD5, SD5Link, Uniphier, i-PRO and i-PRO SmartHD logos are trademarks or
registered trademarks of Panasonic Corporation.
All other trademarks are the property of their respective copyright holders.
117
Visit www.panasonic.com/security for the latest product information
Technology in Detail Guide
T E C H N O L O G Y
I N
D E TA I L
G U I D E
22x optical zoom
Equates to 3.8mm to 83mm focal length lens with 10x digital zoom, providing
220x total zoom capability.
30x optical zoom
Equates to 3.8mm to 114mm focal length lens with 10x digital zoom, providing
300x total zoom capability.
ABS
Adaptive Black Stretch technology makes the dark areas of a scene clearly visible.
Auto Back Focus Optimizes the back focus automatically for clear, sharp images. The CCD
position automatically adjusts when changing from color to B/W mode, eliminating
any focus shift problems. Virtually eliminates post-installation manual adjustments.
H.264
Day/Night
Camera will automatically or manually switch from color mode (daytime)
to B/W mode (night time) to achieve optimal viewing.
Day/Night IR
Considered “true” Day/Night, this technology offers the most effective transition from
color (daytime) to B/W mode (nighttime). As daylight fades, the camera senses the
lower light levels and mechanically removes the IR cut filter instantly switching to a
more sensitive B/W mode.
Face Detection
Provides better subject identification by detecting the position of the human face
(up to 8 individuals) and transmitting the data via XML or video stream.
H.264
A new video compression format that offers high video resolution at lower file sizes.
IP66
“Ingress Protection 66” - the 66 refers to ingress protection for dust, and
water from heavy seas, or water projected in powerful jets shall not enter
the enclosure in harmful quantities.
i-PRO
Intelligent and professional IP video security solutions exclusively from Panasonic.
The series combines Panasonic’s performance, reliability and quality with the
latest advancements in IP technology.
i-PRO MEGA
Super Dynamic
Exclusive Panasonic technology offers 128x dynamic range, plus Adaptive Black
Stretch (ABS) for exceptional resolution even in low light; auto image stabilization and
face detection to enhance image details. Check individual product specifications.
i-PRO SmartHD
Offers a unique combination of high performance features, including: HD picture
quality images with Panasonic’s UniPhier LSI processor, Intelligent Technology including
face detection, energy efficiency and bandwidth savings, and simple installation/set-up
and operation.
118
Visit www.panasonic.com/security for the latest product information
I N
D E TA I L
G U I D E
Megapixel
A resolution of one million pixels.
H.264/
MPEG-4/JPEG
Selectable compression technologies. H.264 is also known as MPEG-4 AVC and is
currently one of the most commonly used formats for the recording, compression and
distribution of high definition video. H.264 offers better quality at lower files sizes than
both MPEG-2 and MPEG-4. MPEG-4 is a Wavelet-based file that delivers professional
quality audio and video streams over a wide range of bandwidths. Defined by the
Moving Pictures Expert Group (MPEG) and was standardized in October 1998. JPEG
is the standard for compressing still images. It produces high quality images but typically requires more space for storage. Defined by the Joint Photographic Experts
Group.
PoE
Power over Ethernet (IEEE802.3af).
Ready Tuff
Panasonic Vandal-resistant camera designation.
SDIII
Offers numerous camera performance attributes including: 128x dynamic range;
pixel-based digital contrast correction; Intelligent Technology features such as Auto
Image Stabilization, Auto Scene Change Detection, Auto Back Focus, Auto Tracking;
30x optical zoom (300x electronically); adaptive digital noise reduction; 540 lines of
color resolution; and extreme low light sensitivity in color (0.5 lux) and B/W (0.06 lux).
Check individual products for exact specifications.
SD5
Exclusive Panasonic technology offers 128x dynamic range, plus Adaptive Black
Stretch (ABS) for exceptional resolution even in low light, intelligent Video Motion
Detection (i-VMD) includes object detection (removal and left behind), scene change
detection when lens is covered, removed, defocused and auto image stabilization.
Check individual product specifications.
SD/SDHC
“Secure Digital”- A small memory card featuring a high data transfer rate and
encryption capability to protect content.
UniPhier LSI
(large scale integrated circuit): this proprietary next generation image processing chip
provides superior HD image quality utilizing half the data size. The advanced highdensity chip technology enables delivery of multiple H.264 and JPEG video streams
for simultaneous real-time monitoring and HD recording with enhanced interoperability.
It also features a unique processing platform that allows Panasonic to share software
and hardware resources across multiple Panasonic product lines.
Up-the-Coax
Supports up-the-coax (coaxial cable) signal transmission and control.
Technology in Detail Guide
T E C H N O L O G Y
119
Visit www.panasonic.com/security for the latest product information
Index
MODEL NUMBER
PAGE(S)
MODEL NUMBER
PAGE(S)
MODEL NUMBER
PAGE(S)
BB-HCA10A....................................26
PLAHS1770.................58,87,100,101
POH1500HB...20,58,59,94,103,104,105
BB-HCA11A....................................29
PLAMP0550......................20,86,100
POS954D...................................61
BB-HCA3A............................25,26,28
PLAMP2206................19,86,100,101
POS954DW................................61
BB-HCA7A.................................27,29
PLAMP2406.....................20,86,100
POSM5V...................10,25,29,93,102
BB-HCM371A............................30,35
PLAMP2812.....................20,86,100
PPFD9C.....................94,103,104,105
BB-HCM511A............................28,35
PLCD15V.....................................83
PPFD9CN...................................94
BB-HCM527A...........................26,34
PLCD20P.....................................82
PPM484S.....................15,16,54,99
BB-HCM531A..........................28,35
PLCD24HD.................................81
PPMF12D................................95,104
BB-HCM547A..........................26,35
PLCD42HD.................................81
PPRM30G..7,8,47,48,91,92,93,95,104
BB-HCM580A..........................25,34
PLCDRMK.............................82,83
PPRM30GB..7,8,47,48,91,92,93,95,104
BB-HCM581A..........................25,34
PLZ15/33...............16,54,85,100,101
PRCM1......13,15,16,17,18,29,96,102
BB-HCM701A..........................29,34
PLZ20/5...........................87,100,101
PRMK08...............................82,83
BB-HCM705A..........................29,34
PLZ27/5DN......................87,100,101
PS484S........................................99
BB-HCM715A..........................27,34
PLZ29/27.........................85,100,101
PSRCW2000B.........................95,105
BB-HCM735A..........................27,35
PLZ5/10...........................87,100,101
PSS10............................................94
BB-HCS301A................................31
PMPU1000...........................43,69,75
PSS15........................................94
BB-HGW700A...............................31
PMSM5.........................91,92,93,102
PTVR0916DC.........19,59,87,100,101
BB-HNP17A..................................31
POC504L2...................................61
PUM8................................58,59,96
BY-HCA10A...............................32
POC504L5...................................61
PWBT1621........................91,92,93
BY-HPE11KT.............................33
POCNP502LMP05........................61
PWM20G..7,8,47,48,91,92,93,95,105
CANISTER/1000..................37,65,66
POCNP502LMP24......................61
PWM20GB..7,8,47,48,91,92,93,95,105
PACA2......................91,92,93,95,104
POD7CN.................9,91,102,104,105
PWM20GS...............7,8,47,48,95,105
PACA2B...................................95,104
POD7CWN..............9,91,102,104,105
PWM30G..7,8,47,48,91,92,93,95,105
PAPM3.....................91,92,93,95,104
POD8CF.....................91,102,104,105
PWM30GB..7,8,47,48,91,92,93,95,105
PAPM3B..................................95,104
POD8CWF..................91,102,104,105
PWM484S.......................15,16,54,99
PCM484S.......................15,16,54,99
POD9C....9,12,49,50,92,103,104,105
PWM800.......................58,59,96,105
PCRM1..........................................53
POD9CT...9,12,49,50,92,103,104,105
PWM9.....................................9,96
PDM9.................................50,89,102
POD9CW...9,12,49,50,92,103,104,105
PWMSM5V.....................................90
PHM484S......................15,16,54,99
POD9CWT..9,12,49,50,92,103,104,105
SCT08P.......................................67
PHM5......................................95,104
PODV7CPNS.........12,93,103,104,105
ST320REM..................................39
PID5CN..............................12,88,102
PODV7CWNS........12,93,103,104,105
WJ-CA65L07K.............................76
PID5SN..............................12,88,102
PODV9CPT........................93,104,105
WJ-CA65L20K.............................76
PID9................................9,49,89,102
PODV9CWT.......................93,104,105
WJ-CA68....................................76
PIDV7CN....................9,49,50,90,102
POH1000...20,58,59,94,103,104,105
WJ-GXD400.........................45,70,73
PIDV7SN....................9,49,50,90,102
POH1000H....20,58,59,94,103,104,105
WJ-GXE500..........................45,70,73
PISM5V.....................10,25,29,90,102
POH1000NWM..........94,103,104,105
WJ-HD616 Series......................66,70
PLA22T3DN..........16,54,86,100,101
POH1500..........20,58,59,94,104,105
WJ-HD716 Series......................65,70
Numbers in bold indicate main product page for that item.
120
Visit www.panasonic.com/security for the latest product information
PAGE(S)
MODEL NUMBER
PAGE(S)
MODEL NUMBER
PAGE(S)
WJ-HDB601...........................65,66
WV-CW364...........................55,62
WV-Q151C..................................97
WJ-HDB611...........................65,66
WV-CW384...........................57,63
WV-Q151S...................................97
WJ-HDE300................................38
WV-CW4C..................................16
WV-Q152C..................................97
WJ-HDE400.......................37,65,66
WV-CW4H..................................16
WV-Q152S...............................12,97
WJ-ND200 Series......................39,70
WV-CW4S.............15,17,51,54,55,56
WV-Q154C…………......…10,11,97
WJ-ND300A Series....................38,70
WV-CW504F……..............54,62,101
WV-Q154S…………......…10,11,97
WJ-ND400 Series......................37,70
WV-CW504F/09...........................54
WV-Q155C………….....…10,11,97
WJ-NDB301................................38
WV-CW504F/15..........................54
WV-Q155S…………....…10,11,97
WJ-NV200 Series..…………...40,70
WV-CW504F/22..........................54
WV-Q156C…………....…10,11,98
WJ-PB65C32..............................76
WV-CW504S......................54,62,101
WV-Q156S…………...….10,11,98
WJ-PB65E01................................76
WV-CW504S/09...........................54
WV-Q157…………...…...10,11,98
WJ-PB65M16...............................76
WV-CW504S/15..........................54
WV-Q168...............................13,53
WJ-SX650...................................76
WV-CW504S/22...........................54
WV-Q169.........15,16,17,54,55,56,98
WJ-SX650U.................................76
WV-CW5H........................54,55,56
WV-Q173................................14,98
WV-7176.................................47,48
WV-CW964...........................48,62
WV-Q174.....................................98
WV-ASM100..37,38,39,41,65,66,67,71
WV-CW974............................47,62
WV-Q175....................................51
WV-ASM100L 37,38,39,42,65,66,68,71
WV-LZ62/8S...........59,60,85,100,101
WV-Q204/1S.............................45,73
WV-ASM970....................43,69,75,77
WV-LZ81/6A................58,87,100,101
WV-Q204/2S.............................45,73
WV-CF284.......................53,63,102
WV-LZA61/2S.........59,60,85,100,101
WV-SC384….......……………10,22
WV-CF294..........................53,63,102
WV-LZA62/2......19,20,58,85,100,101
WV-SC385…….......…………10,22
WV-CF324..........................52,63,102
WV-NF302.....................14,102,103
WV-SF332.............................13,24
WV-CF504.................................51,63
WV-NF5C...................................52
WV-SF335..............................13,23
WV-CL930............58,63,101,102,103
WV-NF5S...................................14
WV-SF336..............................13,23
WV-CL934............58,63,101,102,103
WV-NP502......20,24,61,100,102,103
WV-SF342…..………………..18,23
WV-CP290...........60,63,101,102,103
WV-NS202A................12,22,102,103
WV-SF346…………………..18,23
WV-CP294...........60,63,101,102,103
WV-NS954....................9,22,102,103
WV-SP102…….......………….21,24
WV-CP500...........59,63,101,102,103
WV-NW484S..................16,23,100
WV-SP105…….......………….21,24
WV-CP5..........59,61,63,101,102,103
WV-NW502S..................15,22,100
WV-SP302.......................19,24,100
WV-CS2M..................................50
WV-NW964.................................8,22
WV-SP305..........................19,24,100
WV-CS2S...................................50
WV-Q105..............10,12,18,49,50,96
WV-SP306..........................19,24,100
WV-CS3S.................................9,49
WV-Q106...................................96
WV-SW352................................17,23
WV-CS57....................50,62,102,103
WV-Q115..............................54,96
WV-SW355..............................17,23
WV-CS5S...................................12
WV-Q116...........................9,49,96
WV-SW395.................................7,22
WV-CS954 ............49,61,62,102,103
WV-Q117......................9,49,50,96
WV-SW3H......................................17
WV-CU650 .....................65,66,76,78
WV-Q118......................9,49,50,96
WV-CU950......................41,65,67,79
WV-Q150C.....................................97
WV-CW334...........................56,62
WV-Q150S..............................12,97
Index
MODEL NUMBER
121
Visit www.panasonic.com/security for the latest product information
panasonic.com/security

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
