CIS VCC-G20E30B Product Specification & Operational Manual

VCC-G20E20B
Rev.900-710-35
English
Analog I/F
29mm Cubic EIA
Analog B/W Camera
VCC-G20E20B
Product Specification
& Operational Manual
CIS Corporation
©2014 CIS Corporation. All rights reserved.
VCC-G20E20B
Rev.900-710-35
Table of Contents
1. Scope of Application............................................................................................................................... 3
2. Handling Precautions ............................................................................................................................. 3
3. Product Outline...................................................................................................................................... 4
4. Specification .......................................................................................................................................... 5
4.1. General Specification ....................................................................................................................... 5
4.2. Camera Input/Output Signal Specification ............................................................................................ 7
4.3. CCD Spectral Response (Representative value) ..................................................................................... 8
5. Function Settings ................................................................................................................................... 8
6. External Connector Pin Assignment ....................................................................................................... 14
7. Timing Chart........................................................................................................................................ 14
7.1. Horizontal Sync Timing ..................................................................................................................... 14
7.2. Vertical Sync Timing (Field Storage)................................................................................................... 15
7.3. Vertical Sync Timing (Frame Storage) ................................................................................................ 15
8. CCD Optical Axis Accuracy .................................................................................................................... 16
9. Dimensions ......................................................................................................................................... 17
10. Cases for Indemnity (Limited Warranty) ............................................................................................... 18
11. CCD Pixel Defect ................................................................................................................................ 19
12. Product Support ................................................................................................................................. 19
©2014 CIS Corporation. All rights reserved.
2
VCC-G20E20B
1.
Rev.900-710-35
Scope of Application
This is to describe VCC-G20E20B analog EIA B/W CCD Camera. All specifications contained herein are subject
to change without prior notice. Reproduction in whole or in part is prohibited.
2.
Handling Precautions
The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical
failure or malfunction could result in serious bodily injury or loss of human life.
Our warranty does not apply to
damages or defects caused by irregular and/or abnormal use of the product.
Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these precautions.

Do not use or store the camera in the following extreme conditions:
 Extremely dusty or humid places.
 Extremely hot or cold places (operating temperature –5℃ to +45℃)
 Close to generators of powerful electromagnetic radiation such as radio or TV transmitters.
 Places subject to fluorescent light reflections.
 Places subject to unstable (flickering, etc.) lighting conditions.
 Places subject to strong vibration.

Do not apply excessive force or static electricity that could damage the camera.

Do not shoot direct images that are extremely bright (e.g., light source, sun, etc.), and when camera
is not in use, put the lens cap on.

Follow the instructions in Chapter 6, “External connector pin assignment” for connecting the camera.
Improper connection may cause damages not only to the camera but also to the connected devices.
 Confirm the mutual ground potential carefully and then connect the camera to monitors or computers.
AC leaks from the connected devices may cause damages or destroy the camera.
 Do not apply excessive voltage. (Use only the specified voltage.)
Unstable or improper power supply
voltage may cause damages or malfunction of the camera.
 The voltage ripple of camera power DC +12V±10% shall be within ±50mV.
Improper power
supply voltage may cause noises on the video signals.
In case of abnormal operation, contact the distributor from whom you purchased the product.
©2014 CIS Corporation. All rights reserved.
3
VCC-G20E20B
3.
Rev.900-710-35
Product Outline
VCC-G20E20B is a high-resolution industrial B/W analog camera module utilizing a 1/2 type TV format CCD.
380K pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution.
Key Features
□
HD/VD sync input or Trigger input are valid.
□
1/100s ～ 1/10,000s , 8 steps shutter speed can be set by rear switch as fixed trigger
shutter.
100μs ～ 250ms shutter speed can be set by trigger pulse width as pulse width trigger shutter.
□
Both EIA normal speed and EIA double speed can be operated.
□
Restart Rest mode to enable long time exposure can be set.
□
Frame or Field storage can be selectable.
□
Only 29mm cubic in size (excluding projection), light weight 45g, and speed makes it a best match for
use in embedded systems.
©2014 CIS Corporation. All rights reserved.
4
VCC-G20E20B
4.
Rev.900-710-35
Specification
4.1.
General Specification
Item
Specification
Device Type
1/2 type Interline Transfer B/W CCD, Sony
ICX418AL
Pickup device
Effective Pixel Number
768(H) x 494 (V)
Unit Cell Size
8.4μm (H) x 9.8μm (V)
Chip Size
7.4mm (H) x 5.95mm (V)
Pixel Clock
14.318 MHz
Horizontal
15.734 kHz
Pixel Clock
910 CLK
Frequency
1/30s 2:1 Interlaced 29.97 Hz
30fps
Vertical
Scanning lines
Frequency
1/60s Non Interlaced 59.94 Hz
Scanning lines
Video output frequency
Pixel Clock
28.636 MHz
Horizontal
31.468 kHz
525H
262.5H
Pixel Clock
910 CLK
Frequency
1/60s 2:1 Interlaced 59.94 Hz
60fps
Vertical
Scanning lines
Frequency
1/120s Non Interlaced 119.9 Hz
Scanning lines
Sync. system
525H
262.5H
Internal sync & HD/VD external sync
(Internal/External recognized automatically)
Video output standard Analog VS
Resolution
570 TV lines
Sensitivity
F8
Minimum illumination
F1.4
S/N ratio
56dB
Dust or stains in
No dust or stain shall be detected on the testing screen with setting the camera
optical system
aperture at F16.
Power requirements
DC +12V ± 10%
Power consumption
1.5 W typ (max. 1.8W) at DC +12V IN
Dimension
400 lx (30fps mode: Shutter speed 1/30s, Gain 0dB, 3200K)
1.0 lx (30fps mode: Shutter speed 1/30s, Max Gain, VS 50IRE)
Refer to overall dimension drawing (Clause 9)
29mm x 29mm x 29mm (excluding projection)
Mass
Approx. 45 gs
Lens mount
C mount (Refer to overall dimension drawing)
©2014 CIS Corporation. All rights reserved.
5
VCC-G20E20B
Rev.900-710-35
Item
Specification
Optical axis accuracy
Refer to drawing for CCD Optical Axis Accuracy (Clause 8)
Gain variable range
0～12dB (guaranateed range)
Gamma
1 (fixed)
<Normal Shutter Mode>
30fps mode: OFF(1/30), 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000s
Shutter speed
variable range
60fps mode: OFF(1/60), 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/20000s
<Trigger Shutter Mode>
30fps mode:1/100, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000s
60fps mode:1/200, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/20000s
Pulse Width: 100μ～250ms
Shutter Mode
Normal Shutter Mode, Restart/Reset Mode,
Fixed Trigger Shutter Mode, Pulse Width Trigger Shutter Mode
UL:
Conform to UL Standard including materials and others.
RoHS: Conform to RoHS
CE:
Safety/Quality
standards
Conform to EN55022: 2006 (Class B) for Emmission
Conform to EN61000-6-2: 2005 for Immunity
FCC: FCC Class A digital Device
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Vibration
Durability
98 m/s2 (10.0G)
Frequency
20～200 Hz
Direction
XYZ 3 directions
Testing time
120 min for each direction
No malfunction shall be occurred with 980m/s2(100G) for ±X, ±
Shock
Y, ±Z, 6 directions. (without package)
Temperature
Operation guaranteed: -5℃～+45℃
Performance guaranteed: 0℃～+40℃
Operation environment
Storage environment
Acceleration
Humidity
RH 20～80% with no condensation
Temperature
-25℃ ～ +60℃
Humidity
RH 20～80% with no condensation
©2014 CIS Corporation. All rights reserved.
6
VCC-G20E20B
Rev.900-710-35
4.2. Camera Input/Output Signal Specification
Item
Video output
Sync signals
Input /Output
Specification
Effective output:
752(H) × 485(V)
HD/VD Input signal level: 2～5Vp-p
10kΩ/75Ω
Input impedance:
Allowable frequency deviation:
Phase difference:
Jitter:
at 2:1 Interlaced scan
±1%
HD/VD: under 0±5μs
under 20ns
3.3V
WEN output
CMOS (74VHC04 equivalent)
Output impedance 100Ω
33K
HD/VD
IN/OUT
4.7K
75
10K
47pF
HD/VD/WEN output signal level
Low 0.5V (max), High 4V (Min)
SW
100
Trigger input
Polarity:
Input signal level:
Input impedance:
Trigger input width:
1K
Video signal
CMOS
Positive
Low 0.5V (max), High 2.5～5V
1kΩ
4μs ～ 250ms
4.7K
Trigger IN
5V
5V
TTL
47pF
VS output 1.0V (p-p), Sync. Negative, 75Ω unbalanced, DC connect
White clip level:
820 ± 70 mVp-p
Setup level:
20 ± 15 mVp-p
SYNC level:
290 ± 50 mVp-p
©2014 CIS Corporation. All rights reserved.
7
VCC-G20E20B
Rev.900-710-35
4.3. CCD Spectral Response (Representative value)
※ Lens characteristics and illuminant characteristics are not considered.
5.
Function Settings
1
2
3
4
5
6
7
8
9
10
●
●
●
●
●
●
●
●
●
●
●
ES2
ES1
ES0
FLD/FRM
Mode2
Mode1
Mode0
75ohm
Speed
IN/OUT
◇Shutter Speed: 8 steps
At 30fps: OFF(1/30s) ～ 1/10000s
At 60fps: OFF(1/60s) ～ 1/20000s
◇Field/Frame
◇Shutter Mode
Normal Shutter Mode, Restart/Reset Mode, Trigger Shutter Mode
◇HD/VD Impedance 10kΩ/75Ω
◇30fps CLK = 14.318MHz/ 60fps CLK = 28.636MHz
◇HD/VD signal input and output setting (No. 6 & 7 pin of 12pins
circular connector.)
OFF
Indicates initial setting position.
©2014 CIS Corporation. All rights reserved.
8
VCC-G20E20B
Rev.900-710-35
Shutter Speed Settings
(At 30fps Mode)
ES2 ES1 ES0 Shutter Speed
Actual Time
Normal
Shutter
Trigger Shutter
SW1 SW2 SW3
OFF OFF OFF
OFF (1/30s)
33.4 ms
10.0 ms
OFF OFF ON
1/125 s
8.1 ms
8.1 ms
OFF ON
OFF
1/250 s
4.0 ms
4.0 ms
OFF ON
ON
1/500 s
2.0 ms
2.0 ms
ON
OFF OFF
1/1000 s
986 μs
982 μs
ON
OFF ON
1/2000 s
478 μs
478 μs
ON
ON
OFF
1/4000 s
225 μs
225 μs
ON
ON
ON
1/10000 s
98 μs
98 μs
(At 60fps Mode)
ES2 ES1 ES0
SW1 SW2 SW3
OFF OFF OFF
OFF OFF ON
OFF ON
OFF
OFF ON
ON
ON
OFF OFF
ON
OFF ON
ON
ON
OFF
ON
ON
ON
Shutter Speed
OFF (1/60s)
1/250 s
1/500 s
1/1000 s
1/2000 s
1/4000 s
1/8000 s
1/20000 s
Actual Time
Normal Shutter
Trigger Shutter
16.7 ms
5.0 ms
4.0 ms
4.0 ms
2.0 ms
2.0 ms
1.0 ms
1.0 ms
493 μs
494 μs
239 μs
240 μs
113 μs
113 μs
49 μs
49 μs
Indicates initial setting position
CCD Charge Storage Mode Settings
SW4 OFF
FLD
Field Storage
ON
FRM
Frame Storage
Indicates initial setting position
Shutter Mode Settings
Mode1 Mode0 Setting Mode
SW5 SW6 SW7
OFF
OFF
OFF
Normal Shutter Mode
OFF
ON
ON
Restart/Reset Mode
ON
OFF
OFF
Fixed Trigger Shutter Mode (SYNC Reset Mode)
〃
(SYNC Non Reset Mode)
ON
OFF
ON
ON
ON
OFF
Pulse Width Trigger Shutter Mode (SYNC Reset Mode)
〃
(SYNC Non Reset Mode)
ON
ON
ON
Indicates initial setting position
Mode2
©2014 CIS Corporation. All rights reserved.
9
VCC-G20E20B
Rev.900-710-35
Table of Settings
Operation Mode Normal
Shutter Mode
Restart/Reset
Mode
Fixed Trigger
Shutter Mode
○
×
(One side field)
○
Pulse Width
Trigger Shutter
Mode
×
(One side field)
○
○
×
○
○
×
×
○
○
○
○
○
×
○
○
○
○
Function
2:1 Interlaced
○
○
Field/Frame
Shutter Speed Settings by
rear switch
Shutter Speed Settings by
trigger pulse width
HD/VD Input
HD/VD Output
○
Normal Shutter Mode
At normal shutter mode, consecutive video signals are read with EIA compliant 2:1 interlaced scanning.
With shutter function, rapidly moving objects can be captured clearly.
When adding external sync input, please follow the HD/VD input conditions shown below for 30fps
mode.
External VD
1st Field
±5μs
2nd Field
fh ±5μs
External HD
VD Reset Pulse
16.0μs
32.0μs
1HD 63.56μs
Restart-Reset Mode
With adding EXT VD at random timing with over 1VD, data for one screen image is read out. This
function is useful when sensitivity with regular exposure time is not sufficient or when indicating the
locus of moving object. ODD/EVEN field is determined by EXT HD/VD phase.
External HD
External VD
(Internal VD)
262.5H min
(1V min)
1H
ODD Field Exposure
EVEN Field Exposure
Video Output
ODD Image
20H
EVEN Image
242.5H
10H
WEN Output
©2014 CIS Corporation. All rights reserved.
10
252.5H
VCC-G20E20B
Rev.900-710-35
Fixed Trigger Shutter Mode
Exposure time shall be the value set by the rear switch.
In case of SYNC Reset mode
Internal VD is reset after completion of exposure and video output signals are read out after 1 ～ 2H.
Internal VD, Composite Sync, and WEN signals are one-to-one correspondence to trigger input so that
capturing images can be done with any output signals.
HD/VD sync signals are not necessary basically, but signals can be synchronized with internal HD with
inputing HD signals externally.
Exposure time = when setting with switch SW 1 ～4: 1/100 ～ 1/10000s at 30fps.
1/200 ～ 1/20000s at 60fps.
Trigger Input
Pulse Width: 4μs～250ms
Exposure Time
Setting time by Rear dip switch
Internal HD
Internal VD
1～2H
Video Output
20H
242.5H
10H
252.5H
WEN Output
In case of SYNC Non-Reset mode
Video output signals are read out at the first VD position generated after completion of exposure.
Single VD should be input between 10μs ～ 65ms after completion of exposure.
External VD input, Composite Sync, and WEN signals are one-to-one correspondence so that any
signals can be used to capture images.
Exposure time = when setting with switch SW 1 ～4: 1/100 ～ 1/10000s at 30fps.
1/200 ～ 1/20000s at 60fps.
Trigger Input
Exposure Time
Pulse Width: 4μs～250ms
Setting time by Rear dip switch
External HD
External VD
(Internal VD)
1H
10μs～65ms
Video Output
20H
242.5H
WEN Output
©2014 CIS Corporation. All rights reserved.
11
10H
252.5H
VCC-G20E20B
Rev.900-710-35
Pulse Width Trigger Shutter Mode
Exposure time shall be the value set by the trigger pulse width.
In case of SYNC Reset mode
Internal VD is reset after completion of exposure and video output signals are read out after 1 ～ 2H.
Internal VD, Composite Sync, and WEN signals are one-to-one correspondence to trigger input so that
capturing images can be done with any output signals.
HD/VD sync signals are not necessary basically, but signals can be synchronized with internal HD with
inputing HD signals externally.
Exposure time = Trigger Pulse Width (μs) + 96μs at 30fps.
Trigger Pulse Width (μs) + 48μs at 60fps.
Trigger Input
Pulse Width: 4μ s～250ms
Exposure Time
Setting time by (Trigger Pulse Width + 96μ s)
Internal HD
Internal VD
1～2H
Video Output
20H
242.5H
10H
252.5H
WEN Output
In case of SYNC Non-Reset mode
Video output signals are read out at the first VD position generated after completion of exposure.
Single VD should be input between 10μs ～ 65ms after completion of exposure.
External VD input, Composite Sync, and WEN signals are one-to-one correspondence so that any
signals can be used to capture images.
Exposure time = Trigger Pulse Width (μs) + 96μs at 30fps.
Trigger Pulse Width (μs) + 48μs at 60fps.
Trigger Input
Pulse Width: 4μ s～250ms
Exposure Time
Setting time by (Trigger Pulse Width + 96μ s)
External HD
External VD
(Internal VD)
1H
10μ s～65ms
Video Output
20H
242.5H
WEN Output
©2014 CIS Corporation. All rights reserved.
12
10H
252.5H
VCC-G20E20B
Rev.900-710-35
Cautions for Trigger Shutter Modes
Caution 1: When the next trigger is input before the completion of video signals output for the prior
trigger, the images could be improper.
Caution 2: Smear or blooming could occur when strong incident light is extensively illuminated, with
setting the electric shutter at high speed. To avoid this smear or blooming, lower the volume of
incident light or use a stroboscopic light source to control the light volume.
Caution 3: Please refer to the exposure timing chart below for 30fps mode for the actual timing to start
exposure after adding trigger input, and or for the actual timing to complete exposure at pulse width
trigger shutter operation.
Trigger Input
(Discharge)
(Readout)
Exposure Time
3.0μ s
99μ s
Exposure = (Trigger Pulse Width) +96μ s
HD/VD Input Impedance Selection
SW8
OFF
HD/VD Input Impedance
ON
HD/VD Input Impedance
10kΩ
75Ω
Frame Rate Speed Selection
OFF
30fps Mode
CLK= 14.318MHz
ON
60fps Mode
CLK= 28.636MHz
When changing pixel clock, please reboot the camera power.
SW9
HD/VD Input and Output Selection
SW10 OFF
HD/VD Output
ON
HD/VD Input
(Internal/External Sync can be recognized automatically.)
Indicates initial setting position
©2014 CIS Corporation. All rights reserved.
13
VCC-G20E20B
6.
Rev.900-710-35
External Connector Pin Assignment
12 pins Circular Connector SNH-10-12(RPCB)
(SAMWOO)
Pin No.
7.
1
GND
2
Power In DC+12V
3
GND
4
Video Out
5
GND
6
HD In/Out
7
VD In/Out
8
GND
9
N/A
10
WEN Out
11
Trig In
12
GND
Timing Chart
7.1. Horizontal Sync Timing
Horizontal Scanning (1H) = 910CLK (63.56μs)
Camera HD
CLK = 14.318MHz at 30fps
91
(6.36μs)
CCD Output
1
Black
Transmit
Dummy Pixels
Effective Pixels
40
77
25
768
22
(1.54μs)
68
(4.75μs)
68
(4.75μs)
Video Output
Horizontal Blanking
158CLK(11.0μs)
Video Active Period
752(52.5μs)
©2014 CIS Corporation. All rights reserved.
14
VCC-G20E20B
Rev.900-710-35
7.2. Vertical Sync Timing (Field Storage)
ODD Field 262.5H
EVEN Field 262.5H
9
9
491+492
493+494
7+8
9+10
1+2
490+491
492+493
494
8+9
1
2+3
491+492
493+494
Camera VD
CCD Output
Transmit
1
8
Black
Effective Lines
6
248
1
Transmit
Black
8
6
Effective Lines
247
Video Output
Vertical Blanking
20H
Video Active Period
242.5H
Vertical Blanking
20H
10H
Video Active Period
242.5H
10H
WEN Output
7.3. Vertical Sync Timing (Frame Storage)
ODD Field 262.5H
EVEN Field 262.5H
9
9
492
494
6
8
2
491
493
9
1
3
492
494
Camera VD
CCD Output
Transmit
1
8
Black
6
Effective Lines
247
2
Transmit
Black
8
6
Effective Lines
247
Video Output
Vertical Blanking
20H
10H
Video Active Period
242.5H
Vertical Blanking
20H
10H
WEN Output
©2014 CIS Corporation. All rights reserved.
15
Video Active Period
242.5H
VCC-G20E20B
Rev.900-710-35
8. CCD Optical Axis Accuracy
29
6±0.3
Inclination of
optical axis to
datum plane
6±0.3
29
29
±0.2°
14.5±0.3( *)
M2
12
M2
M3
6±0.3
6±0.3
10±0.3
10±0.3
Datum
Plane
Datum
Plane
Product Name
Label Position( ? )
±0.5
°
Inclination of effective pixels Theta
to datum plane shall be
?? ±0.5°
The center of effective pixels shall be
within f 0.6 to the center of lens mount.
(*) Dimension from datum plane to the center of lens mount.
©2014 CIS Corporation. All rights reserved.
16
910-015-00-00
(Unit : mm)
VCC-G20E20B
Rev.900-710-35
9. Dimensions
©2014 CIS Corporation. All rights reserved.
17
VCC-G20E20B
Rev.900-710-35
10. Cases for Indemnity (Limited Warranty)
We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user
in the following cases.

In case damage or losses are caused by fire, earthquake, or other acts of God, acts by third party,
deliberate or accidental misuse by the user, or use under extreme operating conditions.

In case indirect, additional, consequential damages (loss of business interests, suspension of
business activities) are incurred as result of malfunction or non-function of the equipment, we
shall be exempted from responsibility for such damages.

In case damage or losses are caused by failure to observe the information contained in the
instructions in this product specification & operation manual.

In case damage or losses are caused by use contrary to the instructions in this product
specification & operation manual.

In case damage or losses are caused by malfunction or other problems resulting from use of
equipment or software that is not specified.

In case damage or losses are caused by repair or modification conducted by the customer or any
unauthorized third party (such as an unauthorized service representative).

Expenses we bear on this product shall be limited to the individual price of the product.
©2014 CIS Corporation. All rights reserved.
18
VCC-G20E20B
Rev.900-710-35
11. CCD Pixel Defect
After delivery, CCD pixel defects might be noted with time of usage of the products.
The cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS shall be
exempted from taking responsibility on it.
12. Product Support
When defects or malfunction of our products occur, and if you would like us to investigate on the cause and
repair, please contact your distributors you purchased from to consult and coordinate.
©2014 CIS Corporation. All rights reserved.
19

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
