DBO474-Black DBO475-Mirror
OVEN GEMINI PETIT CHEF PLUS
MULTIFUNCTION
Page 1
Cooking
Part number: 069489
Instruction manual
Dear Customer,
Your new Defy oven was manufactured in a state of the art facility and has passed the
strictest quality control procedures.
Please read this manual carefully before using your oven for the first time and then store it
within easy reach for future reference.
This manual will provide you with information on how to operate and care for your oven to
gain the maximum benefit from it.
We trust you will enjoy years of trouble free use.
EXPLANATION OF SYMBOLS
Important information
Warning—Hazardous situations
Warning—Electric shock
Caution; Warning for fire hazard
Caution; Warning for hot surfaces
PLEASE REGISTER YOUR PRODUCT AT
www.defy.co.za
DEFY APPLIANCES (PTY) LTD
P.O.BOX 12004
JACOBS
DURBAN
4026
SOUTH AFRICA
Page 2
Contents
1. Important Safety Instructions
General safety
Electrical safety
Appliance safety
Safety when working with electricity
Intended use
Safety for children
4
4
4
5
6
7
7
2. General information
Overview
Technical Specifications
8
8
9
3. Installation
Before installation
Oven Installation
Installation and connection
Initial use
Time setting
First cleaning of the appliance
Initial heating
10
10
11
12
12
12
13
13
Page 3
4. How to use the oven
General information about baking,
roasting and grilling
How to operate the electric oven
Operating modes
Using the oven clock
Activating the keylock
Setting the alarm clock
Setting the economy mode
Setting the screen brightness
Cooking times table
How to operate the grill
14
14
14
15
16
17
17
17
17
18
19
5. Maintenance and care
General information
Cleaning the oven
Removing the oven door
Removing the door inner glass
Replacing the oven light bulb
20
20
20
20
20
21
6. Trouble Shooting
22
7. Branches
23
8. Warranty
24
1. Important safety instructions
This section contains safety
instructions that will help you
avoid risk of injury and damage.
All warranties will become void if
you do not follow these
instructions.
General safety
x This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning the use
of the appliance by a person
responsible for their safety.
x Children must be supervised to
prevent them from tampering
with the appliance.
x Installation and repair
procedures must always be
performed by authorized
service agents. The
manufacturer shall not be held
responsible for damages arising
from procedures carried out by
unauthorized persons which
may also void the warranty.
Before installation read the
instructions carefully.
Page 4
x
Do not operate the appliance if
it is defective or has any visible
damage.
x Make sure that the appliance
function controls are switched
off after every use.
Electrical safety
x If the appliance has a failure, it
should not be operated unless it
is repaired by an authorized
service agent. There is a risk of
an electric shock!
x Connect the appliance to an
earthed outlet/line protected by
a fuse of suitable capacity.
Have the earth installation
made by a qualified electrician.
This appliance must be earthed
and the manufacturer and the
seller do not accept
responsibility for any damage
due to incorrect installation or
electrical connection.
x Never wash down the appliance
with water! There is the risk of
electric shock!
x The appliance must be
disconnected from the mains
during installation,
maintenance, cleaning and
repair procedures.
x
If the supply cord is damaged, it
must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
x The appliance must be installed
so that it can be completely
disconnected from the network.
The separation must be
provided either by a mains plug,
or a switch built into the fixed
electrical installation according
to construction regulations.
x The rear surface of the oven
gets hot when it is in use.
Ensure that the electrical
connection does not come into
contact with the rear surface so
as not to damage connections.
x Do not trap the mains cable
between the oven door and
frame and do not route it over
hot surfaces as the cable
insulation may melt and cause
a fire as a result of a short
circuit.
x Any work on electrical
equipment and systems should
only be carried out by
authorized and qualified
persons.
Page 5
x
In case of any damage, switch
off the appliance and
disconnect it from the mains. To
do this, switch off the circuit
breaker at the wall.
x Ensure that the fuse rating is
compatible with the appliance.
Appliance safety
x The appliance and its
accessible parts become hot
during use. Care should be
taken to avoid touching heating
elements inside the oven.
Children must be kept away
unless continually supervised.
x Never use the appliance when
your judgment or coordination is
impaired by the use of alcohol
and/or drugs.
x Be careful when using alcoholic
drinks in your dishes. Alcohol
evaporates at high
temperatures and may cause
fire since it can ignite when it
comes into contact with hot
surfaces.
x Do not place any flammable
materials close to the appliance
as the sides may become hot
during use.
x
Keep all ventilation slots clear
of obstructions.
x Do not heat closed tins and
glass jars in the oven. The
pressure that would build-up in
the tin/jar may cause the tin/jar
to burst.
x Do not place baking trays,
dishes or aluminium foil directly
onto the bottom of the oven.
The heat accumulation may
damage the bottom of the oven.
x Do not use harsh abrasive
cleaners or sharp metal
scrapers to clean the oven door
glass as these may scratch the
glass surface.
x Do not use steam cleaners to
clean the appliance as this may
cause an electric shock.
x Use the shelves as described in
“How to operate the electric
oven”
x Do not use the appliance if the
front door glass has been
removed or is cracked.
x Always use heat resistant oven
gloves when putting in or
removing dishes into/from the
hot oven.
Page 6
x
Ensure the appliance is
switched off before replacing
the lamp to avoid the possibility
of an electric shock.
x Do not carry out any repairs or
modifications on the appliance.
Safety when working with
electricity
x Defective electric equipment is
one of the major causes of
house fires
x Any work on electrical
equipment and systems should
only be carried out by
authorized and qualified
persons. If the appliance is
damaged in any way, do not
use it. Report the damage to
your dealer, who will take the
necessary corrective action.
x Make sure that the fuse rating is
compatible with the appliance.
To prevent a fire hazard
x Ensure the plug fits into the
socket well so as not to cause a
spark.
x Do not extend or cut the power
cable. Use only an original
power cable. Do not use a
damaged power cable.
x Ensure that there is no liquid or
moisture on the socket where
the appliance is plugged in.
Intended use
x The appliance must only be
used for domestic use and for
the purposes for which it was
designed. Commercial use will
void the guarantee. This
appliance is for cooking
purposes only. It must not be
used for other purposes, for
example room heating.
x Do not use the appliance for
warming plates under the grill,
drying towels, dish cloths or
similar textile products by
hanging them on the oven door
handle.
x The manufacturer shall not be
liable for any damage caused
by improper use or handling
errors.
x The oven can be used for
defrosting, baking, roasting and
grilling food.
Page 7
Safety for children
x Electrical appliances are
dangerous to children. Keep
children away from the
appliance when it is operating
and do not allow them to play
with the appliance.
x Accessible parts of the
appliance will become hot whilst
the appliance is in use. Children
should be kept away until the
appliance has cooled down.
x Do not place any items above
the appliance that children may
reach for.
x Please ensure that packaging
material is disposed of in a
responsible manner. Plastic
bags should be cut up to
prevent children playing with
them and accidentally
suffocating.
x When the oven door is open do
not load any heavy objects on it
and do not allow children to sit
on it. The appliance may
overturn or the door hinges may
be damaged.
x Some models feature a
protective film over stainless
steel trim. This film must be
carefully removed before using
the appliance.
SAVE THESE INSTRUCTIONS
2. General Information
Overview
1
Control panel
2
Wire shelf
Tray
3
4
5
Handle
Door
Roast pan
Used for pastries, large roasts, juicy dishes,
and for collecting fat while grilling.
Wire Shelf
Used for roasting and for placing food to be
baked, roasted or cooked in casserole
dishes on to the desired rack.
Bake tray
Used for pastries such as cookies and
biscuits.
Page 8
Accessories supplied may vary
depending on the model. Not all
accessories in the user manual
may be included with your
appliance. Accessories may be
purchased from Defy spares.
Placing the wire shelf and tray onto the
wire racks properly
It is important to place the wire shelf and/or
tray onto the rack properly. Slide the wire
shelf or tray between the 2 rails and make
sure that it is properly fitted before placing
any food on it.
Technical Specifications
Voltage / frequency
Maximum power consumption
Amperage
External dimensions (height / width / depth)
Installation dimensions (height / width / depth)
Main oven
Energy efficiency class*
Inner lamp
Grill power consumption
220-240V~ 50 Hz
3.2 kW
15 A
Refer to page 11
Refer to page 11
Multifunction oven
A
1 x 25W
2.2 kW
* Basics: Information on the energy label of electrical ovens is given in accordance with the
SANS 50304 standard. Those values are determined under standard load with bottom-top
heater or fan assisted heating (if any) functions.
The energy efficiency class is determined according to function.
** See Installation.
DANGER
Risk of scalding by hot steam!
Take care when opening the oven
door as steam may escape.
WARNING Hot surfaces may cause
burns! Do not touch the hot surfaces
of the appliance. Use oven gloves.
Keep children away from the
appliance.
DANGER Risk of fire by overheated
oil! When heating oil, do not leave it
unattended. Never try to extinguish a
fire with water! When oil has caught
fire, immediately cover the pot or pan
with a lid. Switch off the hob if safe to
do so and phone the fire service.
WARNING: Under no circumstances should the bake element be
covered with aluminium foil. Nor should a pan or tray be positioned
directly above the bake element.
Doing so would reflect the heat from the bake element downwards. Heat to
the oven would be restricted and overheating of the space below the
element would result in damage to the oven enamel.
Figures in this manual are schematic and may not exactly match your appliance.
Values stated on the appliance labels or in the documentation accompanying it are
obtained in laboratory conditions in accordance with relevant standards. Depending
on operational and environmental conditions of the appliance, these values may vary.
Page 9
3. Installation
The appliance must be installed by a qualified person
in accordance with the regulations in force.
Installation is the buyer’s responsibility.
The manufacturer accepts no liability for this service.
Any action that the manufacturer has to take as a
result of an erroneous installation will not be covered
by the warranty.
Preparation of location and electrical
and gas installation for the appliance
is the customer’s responsibility.
DANGER: The appliance must be
installed in accordance with all local gas
and/or electrical regulations.
DANGER: Prior to installation, visually
check if the appliance has any defects on
it. If so, do not have it installed. Damaged
appliances cause risks for your safety.
Before installation
The appliance is intended for installation in
commercially available kitchen cabinets. A safety
distance must be left between the appliance and the
kitchen walls and furniture. See figures on following
page: “Built in oven cut outs” (values in mm).
Cooking appliances generate considerable heat. The
layout and materials of the mounting cabinet should
take account of these characteristics.
x Surfaces, surrounding edges, synthetic laminates
and adhesives immediately adjacent to the
appliance should be able to withstand
temperatures of up to 100°C without delaminating
or discolouring.
x Kitchen cabinets must be set level and fixed.
x If there is a drawer beneath the oven, a shelf must
be installed between the oven and drawer.
x Carry the appliance with at least two persons.
Page 10
Do not install the appliance next to
refrigerators or freezers. The heat emitted
by the appliance will lead to an increased
energy consumption of cooling products.
The door and/or handle must not be used
for lifting or moving the appliance.
Do not place any objects onto the
appliance and move it in upright position.
Check the general appearance of your
appliance for any damages that might
have occurred during transportation.
Under-counter oven installation
x Note: The oven cavity must vent through the
front only. Avoid gaps between the cavity
sides and the underside of the worktop.
x Insert the oven into the cupboard.
x Open the door to expose the fixing holes in the
side trims.
x Secure the oven by 4 countersunk screws
(fasteners are not supplied).
x The hob should be installed in a ventilated
cupboard fitted with a sturdy worktop .
x Secure the hob using the fixing brackets provided.
Oven installation
x Insert the oven into the cupboard.
x Open the door to expose the fixing holes in the side trims.
x Secure the oven by 4 countersunk screws (fasteners are not supplied).
APERTURE
668 H x 700 W x 580 D
668
APERTURE
700
APERTURE
A
Page 11
B
C
HEIGHT
WIDTH
DEPTH
668 mm
700 mm
580 mm
D
E
F
HEIGHT
WIDTH
DEPTH
675 mm
730 mm
550 mm
Installation and connection
The appliance must be installed in accordance with all
local gas and electrical regulations.
Electrical installation
This appliance must be earthed and the manufacturer
and the seller do not accept responsibility for any
damage due to incorrect installation or electrical
connection.
This appliance should not be connected through an
earth leakage system. Refer to S.A.N.S.10142
Support the oven in front of the aperture and make
the electrical connection before installing. This will
ensure enough cable length for subsequent
servicing.
Connection to the power supply
The connection must be carried out by a licensed
electrician, who will ensure that the oven is correctly
connected and safely earthed. The rated current is
printed on the serial number label attached to the
oven side trim.
The appliance must be connected to the mains
through a double pole isolating switch which has a
minimum clearance between the contacts of 3 mm. in
both poles.
A means for disconnection must be provided in the
fixed wiring.
DANGER: The appliance must be
connected to the mains supply only by
authorised and qualified persons. The
appliances warranty period starts only
after correct installation. The
manufacturer shall not be held
responsible for damages arising from
procedures carried out by unauthorised
persons.
Purchase a standard plastic/metal saddle type
bracket, capable of going around the 20 mm diameter
sprague and with a hole pitch of 38 mm (Plastic) 45
mm (Metal), from your local hardware and 2 off 4.2
mm x 12 mm self tapping screws.
1
Connect the cabling onto the stove connecter.
2
Place the plastic/metal saddle around the sprague
and fasten via the 2 self tapping screws onto the
factory pre punched holes on the back of the stove.
3
DANGER: Risk of electric shock, short
circuit or fire by damage of the mains
lead! The mains lead must not be
clamped, bent or trapped or come into
contact with hot parts of the oven. If the
mains lead is damaged, it must be
replaced by a qualified electrician.
DANGER: Risk of electric
shock! Before starting any work on
the electrical installation, please
disconnect the appliance from the
mains supply.
Connecting the sprague to the oven
WARNING! ELECTRICAL
CONNECTION MUST ONLY BE
DONE BY A QUALIFIED
ELECTRICIAN!
Page 12
Initial use
x Touch
to energise the oven.
Time setting
x Touch
until
flashes. Press +/- keys
to set the time of the day after the oven is
energized for the first time. Confirm the
setting by touching symbol and wait for 4
seconds without touching any keys to
confirm.
While making any adjustment,
related symbols will flash on the
display.
1
2
3
4
5
6
7
8
9
10
11
12
Adjustment key
Keylock symbol
Clock symbol
Alarm volume symbol
Eco mode symbol
Plus key
Minus key
Time pie symbol
Alarm symbol
End of Cooking Time symbol
Cooking Time symbol
Program key
If the initial time is not set, clock will run
starting from 12:00 and the clock symbol
will be displayed. The symbol will
disappear once the time is set.
Current time settings are cancelled in
case of power failure. It needs to be
readjusted.
First cleaning of the appliance
Surfaces might get damaged by some
detergents or cleaning materials. Do not
use aggressive detergents, cleaning
powders/creams or any sharp objects
during cleaning. Do not use harsh
abrasive cleaners or sharp metal
scrapers to clean the oven door glass
since they can scratch the surface,
which may result in the glass shattering.
1. Remove all packaging materials.
2. Wipe the surfaces of the appliance with a damp
cloth or sponge and dry with a cloth.
Initial heating
Heat up the appliance for about 30 minutes and then
switch it off. Thus, any production residues or layers
will be burnt off and removed.
WARNING: Hot surfaces cause
burns! The appliance may be hot when
it is in use. Never touch the inner
sections of the oven, heaters etc. Keep
children away. Always use heat
resistant oven gloves when placing or
removing dishes into/from the hot oven.
Page 13
Electric oven
1.Take all baking trays and the wire shelves out of the
oven.
2.Close the oven door.
3.Select Static position.
4.Select the highest grill power; (See section on how
to operate the electric oven).
5.Operate the oven for about 30 minutes.
6.Turn off your oven; (See section on how to operate
the electric oven).
Grill oven
1.Take all baking trays and the wire shelves out of the
oven.
2.Close the oven door.
3. Select the highest grill power; (See section on how
to operate the grill).
4. Operate the grill about 30 minutes.
5. Turn off your grill; (See section on how to operate
the grill).
Smoke and smell may emit for a couple
of hours during the initial operation. This
is quite normal. Ensure that the room is
well ventilated to remove the smoke and
smell. Avoid directly inhaling the smoke
and the smell that emits.
Final check: Check the functions.
For appliances with a cooling fan
The built-in
cooling fan
cools both the
built-in cabinet
and the front of
the appliance.
1 Cooling fan
2 Control panel
3 Door
Please note that the cooling fan
may continue to run well after the
oven has been switched off. The
duration is dependent on the
selected operating temperature.
This is a built-in safety feature to
ensure that your oven is cooled
down correctly. To reduce the
cooling fan running time, the oven
door may be left ajar after the
oven has been switched off.
Please be cautious of hot
surfaces.
4. How to use the oven
General information on baking, roasting and
grilling
DANGER:
Be careful when opening the oven door
as steam may escape. Exiting steam can
scald your hands, face and/or eyes
Tips for baking
Use non-sticky coated appropriate metal plates or
aluminum vessels or heat-resistant silicone moulds.
Make best use of the embossed shelf runners.
Place the baking mould in the middle of the shelf.
Select the correct embossed shelf runner position
before turning the oven or grill on. Do not change the
shelf position when the oven is hot.
Keep the oven door closed.
Tips for roasting
Treating whole chicken, turkey and large pieces of
meat with dressings such as lemon juice and black
pepper before cooking will increase the cooking
performance.
It takes about 15 to 30 minutes longer to roast meat
with bones when compared to roasting the same size
of meat without bones.
Each centimeter of meat thickness requires
approximately 4 to 5 minutes of cooking time.
Leave meat in the oven for about 10 minutes after the
cooking time is over. The juice is better distributed all
over the roast and does not run out when the meat is
cut.
Warning: Do not put metal items such
as forks, knives or saucepan covers into
your oven since they can get very hot.
Fish should be placed on the middle or lower shelf in
a heat-resistant plate.
Tips for grilling
When meat, fish and poultry are grilled, they quickly
brown, develop a crust and do not dry out quickly.
Flat pieces, meat skewers and sausages are
particularly suited for grilling as are vegetables with
high water content such as tomatoes and onions.
Distribute the pieces to be grilled on the wire shelf or
in the baking tray on the wire shelf so that the space
covered does not exceed the size of the grill element.
Slide the wire shelf or baking tray into the desired
level of the oven. If you are grilling on the wire shelf,
slide the baking tray to the lower rack to collect any
fats. Add some water in the tray for easy cleaning.
Foods that are not suitable for grilling
create a fire risk. Only grill food which is
suitable for intensive grilling heat.
Do not place the food too far in towards
the back of the grill. This is the hottest
area and fatty food may catch fire.
Page 14
How to operate the electric oven
Your oven is equipped with pop-out knobs that
protrude when you press them.
1. Press inwards to protrude the knob and then turn it
to make the desired setting .
2. When the cooking process is finished, turn the
knob to off (upper) position and press it inwards.
Select temperature and operating mode
1. Function knob
2. Thermostat knob
x Set the Function knob (oven selector) to the
desired operating mode.
x Set the Temperature knob to the desired
temperature.
» Oven heats up to the adjusted temperature and
maintains it. During heating, temperature lamp stays
on.
Switching off the electric oven
Turn the function knob and temperature knob to off
(upper) position.
Rack positions (For models with wire shelf)
It is important to place the wire shelf onto the side
rack correctly. Wire shelf must be inserted between
the side racks as illustrated in the figure.
Do not let the wire shelf stand against the rear wall of
the oven. Slide your wire shelf to the front section of
the rack and settle it with the help of the door in order
to obtain a good grill performance.
Operating modes
Turbo Grill
The order of operating modes shown here may be
different from the arrangement on your product.
Operating with fan
Grilling effect is not as strong as in Full Grill
x Put small or medium-sized portions in correct shelf
position under the grill heater for grilling.
x Set the desired temperature.
x Turn the food after half of the grilling time.
The oven is not heated. Only the fan (in the rear wall)
is in operation. Suitable for thawing frozen granular
food slowly at room temperature and cooling down
the cooked food.
Full grill
Top and bottom heating (Static)
Food is heated simultaneously from the top and
bottom. Suitable for cakes, pastries, or cakes and
casseroles in baking moulds. Cook with one shelf
only. No tray.
Large grill at the ceiling of the oven is in operation. It
is suitable for grilling large amount of meat.
x Put big or medium-sized portions in correct rack
position under the grill heater for grilling.
x Set the temperature to maximum level.
x Turn the food after half of the grilling time.
"3D" function
Fan assisted heating
Top heating, bottom heating and Thermofan heating
are in operation.
Warm air heated by the top and bottom heater is
evenly distributed throughout the oven rapidly by
means of the fan. Suitable for cooking your meals on
different shelf levels. Suitable for cooking with two
shelves.
Thermofan heating
Warm air heated by the rear heater is evenly
distributed throughout the oven rapidly by means of
the fan. It is suitable for cooking your meals in
different rack levels and preheating is not required in
most cases. Suitable for cooking with multi trays.
Bottom heating
Only bottom heating is in operation. It is suitable for
pizza and for subsequent browning of food from the
bottom.
Page 15
Food is cooked evenly and quickly all around. Cook
with one shelf only.
Using the oven clock
Cooking by setting the cooking time;
You can set the oven so that it will stop at the end of
the specified time by setting the cooking time on the
timer.
1. Touch
until
for cooking time.
symbol appears on display
2. Set the cooking time with
1
2
3
4
5
6
7
8
9
10
11
12
Adjustment key
Keylock symbol
Clock symbol
Alarm volume symbol
Eco mode symbol
Plus key
Minus key
Time pie symbol
Alarm symbol
End of Cooking Time symbol
Cooking Time symbol
Program key
Maximum time that can be set for end
of cooking is 5 hours 59 minutes.
Program will be cancelled in case of
power failure. You must reprogram
the oven.
While making any setting, related
symbols will flash on the display. You
must wait for a short time for the
settings to take effect.
If no cooking setting is made, time of
the day cannot be set.
Remaining time will be displayed if
cooking time is set when the cooking
starts.
/
keys.
» » After the cooking time is set,
symbol and the
time slice will appear on display continuously.
» Cooking time starts to count down on display when
cooking starts and all parts of time slice symbol is lit.
The set cooking time is divided into 4 equal parts and
when the time of each parts ends, the symbol of that
parts turns off. So you can understand the ratio of
remaining cooking time to total cooking time easily.
Setting the end of cooking time to a later time;
After setting the cooking time on the timer, you can
set the end of cooking time to a later time.
1. Touch
until
for cooking time.
symbol appears on display
2. Set the cooking time with
/
» » Once the Cooking Time is set,
appear on display continuously.
keys.
symbol will
3. Touch
until
symbol appears on display for
the end of cooking time.
4. Press
/
keys to set the end of cooking time.
» After the cooking time is set,
symbol plus
symbol and the time slice will appear on display
continuously. Once the cooking starts,
symbol
disappears.
5. Put your dish into the oven.
6. Select operating mode and temperature.
» Oven timer calculates the startup time by deducting
the cooking time from the end of cooking time
you have set. Selected operating mode is
activated when the startup time of cooking has come
and the oven is heated up to the set temperature. It
maintains this temperature until the end of cooking
time.
» Cooking time starts to count down on display when
cooking starts and all parts of time slice symbol is lit.
The set cooking time is divided into 4 equal parts and
when the time of each parts ends, the symbol of that
parts turns off. So you can understand the ratio of
remaining cooking time to total cooking time easily.
7. After the cooking process is completed, "End"
appears on the displayed and the timer gives an
audio warning.
8. Audio warning sounds for 2 minutes. To stop the
audio warning, just press any key. Audio warning will
be silenced and current time will be displayed.
Page 16
If you press any key at the end of the
audio warning, the oven will restart
operating. Turn the temperature knob
and function knob to "0" (off) position to
switch off the oven in order to prevent reoperation of the oven at the end of
warning.
Activating the keylock
You can prevent oven from being intervened with by
activating the key lock function.
1. Touch
until
symbol appears on display.
» "OFF" will appear on the display.
2. Press
to activate the key lock.
» Once the key lock is activated, "On" appears on the
display and the
To deactivate the keylock
1. Touch
until
symbol appears on display.
» "On" will appear on the display.
2. Disable the key lock by pressing the
key.
» "OFF" will be displayed once the keylock is
deactivated.
Setting the alarm clock
You can use the timer of the product for any warning
or reminder apart from the cooking program.
The alarm clock has no influence on the functions of
the oven. It is only used as a warning. For example,
this is useful when you want to turn food in the oven
at a certain point of time. Timer will give an audio
warning at the end of the set time.
until
symbol appears on display.
2. Set the alarm duration by using
/
keys.
»
symbol will remain lit and the alarm time will
appear on the display once the alarm time is set.
3. At the end of the alarm time,
symbol starts
flashing and the audio warning is heard.
Turning off the alarm
1. Audio warning sounds for 2 minutes. To stop the
audio warning, just press any key.
» Audio warning will be silenced and current time will
be displayed.
Cancelling the alarm;
1. Touch
until
symbol appears on display in
order to cancel the alarm.
2. Press and hold
Page 17
Changing alarm tone
1. Touch
key until "00:00" is displayed.
until
symbol appears on display.
2. Adjust the desired alarm tone with
/
keys.
3. The tone you have set will be activated in a short
time.
» Selected alarm tone will appear as "b-01", "b-02"
or "b-03" on the display.
Changing the time of the day
To change the time of the day you have previously
set:
1. Touch
symbol remains lit.
Oven keys are not functional when the
key lock is activated. Key lock will not be
cancelled in case of power failure.
1. Touch
Alarm time will be displayed. If the alarm
time and cooking time are set
concurrently, shortest time will be
displayed.
until
symbol appears on display.
2. Set the time of the day with
/
keys.
3. The time you have set will be activated in a short
time.
Economy mode
You can save energy with economy mode while
cooking by setting cooking time in the oven.
This mode completes the cooking with the inner
temperature of the oven by switching off the heaters
before the end of cooking time.
Maximum alarm time can be 23 hours
and 59 minutes.
Setting the economy mode
1. Touch
symbol until eco symbol appears on
display.
» "OFF" will appear on the display.
2. Enable economy mode by touching
key.
» Once the key lock is activated, "On" appears on the
display and the eco symbol remains lit.
Disabling economy mode
1. Touch
symbol until eco symbol appears on
display.
» "On" will appear on the display.
2. Disable economy mode by touching
key.
» "Off" will be displayed once the key lock is
deactivated.
Setting the screen brightness
1. Touch
until d-01 or d-02 or d-03 appears on
display for display brightness.
2. Set the desired brightness with
/
keys.
» The time you have set will be activated in a short
time.
Rack positions
Baking and roasting
1st rack of the oven is the bottom rack.
Note: The higher top heat in the new
Gemini Oven will necessitate a lower
shelf position than previously used in
older Gemini models.
Cooking times table
The timings in the chart below are meant
as a guide. Timings may vary due to
temperature of food, thickness, type and
your own preference of cooking.
Suggested temperatures for Thermofan and
Conventional ovens
SPONGE CAKE
Egg and sugar creaming method
BUTTER CAKE
Margarine / butter and sugar creaming method
LOAF CAKE
Date, Ginger and Banana Loaf
THERMOFAN OVEN
CONVENTIONAL OVEN
TEMP ºC
MINUTE
RACK
POSITION
TEMP ºC
MINUTE
RACK
POSITION
175ºC - 180Cº
20 - 25
3
190ºC
20 - 25
2
165ºC
20 - 25
3
180ºC
20 - 25
2
165ºC
45
3
180ºC
45
2
PASTRIES
200ºC - 210ºC
20
3
220ºC
20
2
SCONES
200ºC - 210ºC
12 - 15
3
220ºC
12 - 15
2
PIES AND SAUSAGE ROLLS
200ºC - 210ºC
25
3
220ºC
25
2
BISCUITS
Golden brown
Sensitive biscuits
160ºC
150ºC
15 - 20
3
180ºC
15 - 20
2
SHORTBREAD 15mm thick
140ºC
60
3
150ºC
60
2
MERINGUES
Important: Leave meringues in oven until
cold ‘Sensitive’
120ºC
110ºC
75
90
3
135ºC
120ºC
75
90
2
165ºC
25 - 30
3
180ºC
25 - 30
2
25
10
25 - 30
3
25
10
25 - 30
2
TARTS
Apple, Lemon Meringue, Milk
CHEESECAKE Temperatures and times may
vary depending on the type of cheesecake being
made. Some require slower baking. NOTE: Size
and depth of the cheese filling will determine
baking time.
CHEESE CAKECRUST/PASTRY The crust of
the cheesecake will be better if pre•baked at..
165ºC
Bake 170ºC
Then 150ºC
170ºC
10 - 12
ROASTS Chicken, Beef, Mutton
The time will vary according to level of rareness
desired
Bake 200ºC
Then 180ºC
30 ± 90
BREAD Using yeast
Bake 210ºC
Then 190ºC
FRUIT CAKE Rich Fruit Cake
The larger the tin, the longer the period.
Temperatures and times given are for a square
8” (20cm) tin. NOTE: Lightly test the centre of
the cake with a forefinger at 3½ - 4 hours
baking time. This will ensure that the cake is not
overdone. The centre of the cake must feel firm
to the touch and leave no indentation.
Bake 130ºC
Then 120ºC
BOILED FRUIT CAKE The larger the tin, the
longer the period. Temperatures and times given
are for a square 8” (20cm) tin.
150ºC
Page 18
180ºC
3
Bake180ºC
Then 160ºC
2
180ºC
10 -12
3
Bake 200ºC
Then 180ºC
30 ± 90
3
15 - 45
3
Bake 220ºC
Then 180ºC
15 - 45
2
60 - 180
3
Bake 145ºC
Then 135ºC
60 - 180
2
120
3
160ºC
120
2
Tips for baking cake
If the cake is too dry, increase the temperature by 10°
C and decrease the cooking time. If the cake is wet,
use less liquid or lower the temperature by 10°C.
Foods that are not suitable for grilling
create a fire risk. Only grill food which
is suitable for intensive grilling heat.
Do not place the food too far in the
back of the grill. This is the hottest
area and fatty food may catch fire.
If the cake is too dark on top, place it on a lower rack,
lower the temperature and increase the cooking time.
If cooked well on the inside but sticky on the outside
use less liquid, lower the temperature and increase
the cooking time.
Tips for baking pastry
If the pastry is too dry, increase the temperature by
10°C and decrease the cooking time. Dampen the
layers of dough with a sauce composed of milk, oil,
egg and yoghurt.
If the pastry takes too long to bake, pay care that the
thickness of the pastry you have prepared does not
exceed the depth of the tray. If the upper side of the
pastry gets browned, but the lower part is not cooked,
make sure that the amount of sauce you have used
for the pastry is not too much at the bottom of the
pastry. Try to scatter the sauce equally between the
dough layers and on the top of pastry for an even
browning.
Do not use the top embossed runner
for grilling.
Cooking times table for grilling
Grilling with electric grill
Food
Fish
Sliced chicken
Tips for cooking vegetables
If the vegetable dish runs out of juice and gets too
dry, cook it in a pan with a lid instead of a tray. Closed
vessels will preserve the juice of the dish. If a
vegetable dish does not get cooked, boil the
vegetables beforehand or prepare them like canned
food and put in the oven.
How to operate the grill
WARNING Close oven door during
grilling. Hot surfaces may cause burns!
Switching on the grill
1.Turn the Function knob to the desired grill symbol.
2.Then, select the desired grilling temperature.
3.If required, perform a preheating of about 5
minutes.
» Temperature light turns on.
Switching off the grill
1.Turn the Function knob to Off (top) position.
Page 19
Grilling time
(approx.)
20...25 min. #
25...35 min.
Lamb chops
4...5
20...25 min.
Roast beef
4...5
25...30 min. #
Veal chops
4...5
25...30 min. #
Toast bread
4
1...2 min.
#
Cook the pastry in accordance with the
mode and temperature given in the
cooking table. If the bottom part is still not
browned enough, place it on one lower
rack next time.
Insertion
level
4...5
4...5
depending on thickness
Tips for saving energy
The following information will help you to use your
appliance in an ecological way, and to save energy:
x Use dark coloured or enamel coated cookware in
the oven since the heat transmission will be better.
x While cooking your dishes, perform a preheating
operation if it is advised in the user manual or
cooking instructions.
x Do not open the door of the oven frequently during
cooking.
x Try to cook more than one dish in the oven at the
same time whenever possible. You can cook by
placing two cooking vessels onto the wire shelf.
x Cook more than one dish one after another. The
oven will already be hot.
x You can save energy by switching off your oven a
few minutes before the end of the cooking time. Do
not open the oven door.
x Defrost frozen dishes before cooking them.
5. Maintenance and care
General information
x Clean the appliance thoroughly after each use,
making it easier to remove cooking residues and
helps prevent these from burning on the next use
of the appliance.
x Wipe down the cabinet, door, control panel, trims
and handles with a damp, hot soapy cloth.
x Use only liquid household cleaners and avoid
abrasive powders, scouring pads and caustic
cleaners.
x Rinse and wipe down with a clean cloth.
Cleaning the oven
x Open the oven door and allow the oven to cool
down.
x Clean the oven with a damp, hot soapy cloth. Do
not use a steam cleaner.
x It may be necessary to soak burnt soils with a
liquid cleaner to soften them before scrubbing
them with a nylon brush or scouring sponge.
x Heavy soils on the bottom of the oven may require
overnight soaking under a sponge liberally
sprinkled with household ammonia. Remove the
soil the following morning by washing normally.
x Always ensure that any excess liquid is thoroughly
wiped off after cleaning and any spillage is
immediately wiped dry.
x Do not use cleaning agents that contain acid or
chloride to clean the stainless or inox surfaces and
the handle. Use a soft cloth with a liquid detergent
(not abrasive) to wipe these parts clean, paying
attention to sweep in one direction.
x For your convenience, the shelves may be
removed to improve access.
x To prevent the wire grill and tray inside the oven
from damaging the oven door, place a strip of
cardboard onto the inside of the oven door that
lines up with the position of the trays. Tape the
oven door to the side walls.
x Do not use the door or handle to lift or move the
appliance.
Removing the oven door
Lift-off oven door
The oven door may be removed to improve oven
access during cleaning.
1 Front door
2 Hinge
3 Oven
Removing the oven door
1. Open the front door (1).
2. Open the clips at the hinge housing (2) on the right
and left hand sides of the front door by lifting them
up. Hold the door on both sides and then close the
door and lift the door up to remove it. Refitting is
the reversal of removing.
DANGER Risk of electric shock!
Switch off the electricity before cleaning
the appliance to avoid an electric
shock.
DANGER Hot surfaces may cause
burns! Allow the appliance to cool
down before you clean it.
The surface may get damaged by
some detergents or cleaning materials.
Do not use aggressive detergents,
cleaning powder/cream or any sharp
objects. Do not use any harsh abrasive
cleaners or sharp metal scrapers to
clean the oven door and glass since
they can scratch the surface, destroy
the glass and could result in the glass
shattering.
Future Transportation
x Keep the appliances original carton and transport
the appliance in it. Follow the instructions on the
carton. If you do not have the original carton, pack
the appliance in bubble wrap or thick cardboard
and tape it securely.
Page 20
Steps carried out during the removal
process should be carried out in
reverse order to install the door. Do not
forget to close the clips at the hinge
housing when reinstalling the door.
Removing the door inner glass
The entire inner glass panel of the oven door can be
removed for cleaning.
1.Open the oven door.
1 Screw
2 Profile
3 Inner glass pane
4 Plastic slot
2. Using a screwdriver remove both screws at the top
of the door profile (one on each side).
3. Remove the door profile and carefully take out the
glass.
4. When refitting the glass ensure the bottom edge of
the glass is securely placed in the plastic slots.
Refit the door profile using the screws.
Oven light
The oven light is switched on by the multifunction
selector switch and switches off when the knob
is returned to 0.
Replacing the oven light bulb
DANGER: Before replacing the oven
lamp, ensure that the appliance is
disconnected from mains and cooled
down to avoid the risk of an electrical
shock. Hot surfaces may cause burns!
The oven lamp is a special electric light
bulb that can resist up to 300°C. See
Technical specifications for details. Oven
lamps can be obtained from Authorised
Service Agents.
Position of lamp might vary from the
figure.
1
2
3
Inner glass panel
Outer glass panel
Plastic glass & hinge holder
If your oven is equipped with a square lamp:
1.
Disconnect the product from mains.
2.
Remove the wire racks as described. See
diagram on following page.
As illustrated in figure, raise the inner glass panel (1)
slightly in direction A and pull it out in direction B.
3.
4.
5.
Remove the protective glass cover with a
screwdriver.
Unscrew oven lamp and replace it with
new one.
Install the glass cover and then the wire
racks.
If your oven is equipped with a round lamp:
1.
Disconnect the product from mains.
2.
Turn the glass cover counter clockwise to
remove it.
When installing the inner glass panel (1), make sure
that the printed side of the panel faces towards the
inside of the oven. It is important to seat the lower
corner of inner glass panel into the lower plastic slot.
Push the plastic part towards the frame until you hear
a "click".
3.
Page 21
4.
Remove the oven lamp by turning it counter
clockwise and replace it with the new one.
Install the glass cover
To remove the wire rack:
1. Pull A in the direction of the arrow so that
the front part of the rack unclips from the
oven cavity.
2. Pull B in the direction of the arrow to
remove.
6. Troubleshooting
Oven emits steam when it is in use.
It is normal that steam escapes during operation
>>> This is not a fault.
The appliance emits metal noises while heating and cooling.
When the metal parts are heated, they may expand
>>> This is not a fault.
and cause noise.
The appliance does not operate.
>>> Check the mains distribution board for tripped
The mains distribution board has tripped.
circuit breakers.
The appliance is not plugged into the wall socket.
>>> Check the plug connection.
The wall switch is not on.
>>> Check the wall switch is on.
Buttons/knobs/keys on the control panel do not
function.
Oven light does not work.
Oven lamp is defective.
>>> Keylock may be enabled. Please disable it. (See:
Using the keylock)
Power is cut.
>>> Replace oven lamp.
>>> Check if there is power. Check the fuses in the fuse
box. If necessary, replace or reset the fuses.
Oven does not heat.
Function and/or Temperature are not set
>>> Set the function and the temperature with the
Function and/or Temperature knob/key.
Power is cut.
>>> Check if there is power. Check the fuses in the fuse
box. If necessary, replace or reset the fuses.
Owner’s responsibility
Since the following are not factory faults, they are the owner’s responsibility.
x Damage to exterior finish.
x Breakage of glass and other components.
x Replacement of the light bulb.
x Damage through improper use or installation of the appliance.
x Damage caused by moving the appliance.
If you have followed the instructions and still have a problem, contact the nearest Defy Technical
Support Centre. They will be able to advise you on any aspect of the product or send a qualified
technician to repair it. Never attempt to repair a defective appliance yourself.
Remember that you may be charged for a service call even during the warranty period if the fault is
due to or caused by any of the above.
Page 22
7.
Branches
If you have followed the instructions and still have a problem, contact the customer care line
on 086 100 3339. They will be able to advise you on any aspect of the appliance.
South African Branches:
Sub-Saharan Africa Service Agents:
BLOEMFONTEIN
Unit Number 5
Monument Business Park
50 Monument Road
Oranjesig
Bloemfontein
[email protected]
ZAMBIA: SOUTHGATE INVESTMENTS LTD
Plot 1606, Sheki Sheki Road
P.O. Box 33681
Lusaka, 10101, Zambia
Tel: +260 0211 242332/3
Fax: +260 0211 242933
[email protected]
CAPE TOWN
5A Marconi Rd. Montague Gardens, 7441
[email protected]
NAMIBIA: ATLANTIC DISTRIBUTORS (PTY)
LTD
10 Tienie Louw Street, Northern Industrial Area
P.O. Box 21158, Windhoek, Namibia
Tel: (061) 216162
Fax: (061) 216134
[email protected]
DURBAN
135 Teakwood Road, Jacobs,
Durban, 4052
[email protected]
EAST LONDON
Robbie de Lange Road, Wilsonia,
East London, 5201
[email protected]
GAUTENG, MIDRAND
127 15th Road, Cnr Pharmaceutical &15th Rd,
Midrand, Gauteng
[email protected]
POLOKWANE
87 Nelson Mandela Drive, Superbia 0699
[email protected]
PORT ELIZABETH
112 Patterson Road, North End, Port Elizabeth
6001
[email protected]
ZIMBABWE: TRADECOMAFRICA
Trade Com Africa, 183 Loreley Crescent
Msasa, Harare, Zimbabwe
Tel: +263 4 486165/6
Cell: +263 772 469010
Cell: +263 772 469011
BOTSWANA: RAY MORGAN AGENCIES
RMA Service Centre, Plot 48, East Gate
Gaborone International Commerce Park
Kgale View, Gaborone
Botswana
Tel: +267 390 3996 / 390 3912
Fax: +267 318 7376
Cell: +267 7134 6539
[email protected]; [email protected]
SWAZILAND: LYNDS DISTRIBUTORS
P.O Box 716, Mbabane, Swaziland, H100
Tel: (00268) 2515 4310/8
Fax: (00268) 2518 4318
MOZAMBIQUE: COOL WORLD. LDA
Rua da Resistencia No. 97B R/C
Cell: +258 84 44 61 234
[email protected]
Nosso Show Room
Av: da Industrias, Parcela No.735 * 735A
Machava, Maputo
Page 23
8. Warranty
This certificate is issued by DEFY APPLIANCES (PTY) LTD manufacturers of Defy and Ocean
products, hereinafter the Company, to the original purchaser only, of the appliance described on the
certificate and shall constitute the only warranty given in respect of this appliance.
The Company warrants to the original purchaser that for a period of THREE YEARS from date of
purchase the appliance is free from defect under normal domestic use, both in workmanship and
material, subject to the following conditions.
1. Repair or replacement of any part of this appliance, found by the Company to be defective, shall
be at the election of the Company. The Company reserves the right to effect such service through
any of its Service Divisions or Authorised Service Dealers. The cost of such service shall be borne
by the Company in full, provided that the appliance is located no further than 50 km from a
Company Service Centre or an Authorised Service Dealer. Where the appliance is located beyond
the 50 km radius, the purchaser shall be liable for the standard travelling charges, as determined by
the Company.
CARRY IN SERVICE Microwave ovens, Compact cookers and small appliances are repaired in our
service centres and are not collected from the customers home. Faulty units must be delivered to
the purchasing dealer or to the nearest Company Service Centre for warranty repairs.
2. Rusted or corroded plates, vitreous enamelware, fuses and lamps are specifically excluded from
these warranties. It is an express condition of these warranties that the purchaser takes due care
and attention in the use and maintenance of the appliance. Abuse, misuse in conflict with operating
instructions, connection to incorrect voltages and subjection to commercial use shall release the
Company from its obligations.
3. This warranty shall become void and cease to operate if the appliance is dismantled by, or any
repairs to the appliance are effected by any persons not duly authorised by the Company, or if
substitute parts not approved by the Company are used in the appliance, or if the serial number of
the appliance is removed.
4. The Company shall not be responsible for damages resulting from fire, flood, civil disturbances or
any Act of God. The Company shall not, in terms of these warranties be responsible nor held liable
for any consequential loss or damage of any kind caused by or due to the failure or malfunction of
the appliance. The Company shall not be responsible for damages caused by insect and/or animal
infestation.
5. The Company shall not be responsible for transportation or other costs other than those incurred
within the provisions of Point 1 of this Certificate.
6. For warranties in the Republic of South Africa and Sub-Saharan Africa, please contact the
customer care line. Please refer to the previous page for respective South African branches
and Sub-Saharan Africa branches.
7. Where service is requested under warranty and no fault or defect can be found by the Company,
all costs incurred will be for the purchaser's account.
8. This Certificate as well as your invoice will serve as proof of purchase. For the purpose of
warranty, it will be essential to produce this Certificate and invoice. Failure to do so, will render the
purchaser liable for service costs.
KEEP THIS CERTIFICATE AND SALES INVOICE AS PROOF OF PURCHASE FOR
WARRANTY PURPOSES.
Page 24
