MSI TV@nywhere Plus Owner's Manual

USER’S GUIDE
TV@nywhere-Plus
Version 1.0
January 2005
i
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance
with the i nstruc tion manual, may c ause harmful inter ferenc e to r adio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct
the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to
comply with the emission limits.
VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Mi cro Star I nternati on al
TV@nywhere-Pl us
ii
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR
INTERNATIONAL. We take every care in the preparation of this document, but
no guarantee is given as to the correctness of its contents. Our products are
under continual improvement and we reserve the right to make changes without
notice.
Trademarks
All trademarks are the properties of their respective owners.
† Intel® and Pentium® are registered trademarks of Intel Corporation.
† PS/2 and OS/2 are registered trademarks of International Business
Machines Corporation.
† Windows® 95/98/2000/NT/XP are registered trademarks of Microsoft
Corporation.
† Open GL® / DirectX® / DirectDraw® / Direct3D® / DirectVideo® / DirectActiveX®
are registered trademarks of Microsoft Corporation.
† Netware® is a registered trademark of Novell, Inc.
† Award® is a registered trademark of Phoenix Technologies Ltd.
† AMI® is a registered trademark of American Megatrends Inc.
† nVIDIA® / nfiniteFXTM is a registered trademark of nVIDIA Corporation.
Macrovision Corporation Product Notice
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other right owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
MSI Patent Notice
MSI has been working on graphics products for years and has achieved a
superior accomplishment in various graphics series. MSI is not only devoted to
delivering the best product quality, but also to bringing up the most novel solutions.
Here MSI presents the patents that MSI obtained for users reference.
Taiwan
Patent number:
446864
Patent number:
192403
United State
Patent number:
6629259B2
Mainland China
Patent number:
605251
iii
Important Safety Precautions
Always read and follow these basic safety precautions carefully when
handling any piece of electronic component.
1.
2.
Keep this User’s Manual for future reference.
Keep this equipment away from humidity.
3.
4.
Lay this equipment on a stable, flat surface before setting it up.
The openings on the enclosure are for air convection, hence they
protect the equipment from overheating.
5. Make sure the voltage of the power source and adjust properly
110/220V before connecting the equipment to the power inlet.
6. Place the power cord in a way that people are unlikely to step on it.
Do not place anything on the power cord.
7. Always Unplug the Power Cord before inserting any add-on card or
module.
8. All cautions and warnings on the equipment should be noted.
9. Never pour any liquid into the opening that could damage the
equipment or cause an electrical shock.
10. If any of the following situations arise, get the equipment checked
by a service personnel:
- The power cord or plug is damaged
- Liquid has penetrated into the equipment
- The equipment has been exposed to moisture
- The equipment has not functioned properly or in accordance
with the User’s Guide
- The equipment was dropped and damaged
- The equipment has obvious signs of breakage
11. DO NOT LEAVE THE EQUIPMENT IN AN UNCONDITIONED
ENVIRONMENT W ITH A STORAGE TEMPERATURE OF 600 C
(1400F) OR ABOVE. IT MAY DAMAGE THE EQUIPMENT.
iv
CONTENTS
Chapter 1 GETTING STARTED
1.1 How to Use this Guide ..................................................................... 1-2
1.2 Conventions of this Guide ................................................................ 1-3
Chapter 2 INTRODUCTION
2.1 System Requirements ...................................................................... 2-2
2.2 Product List ..................................................................................... 2-3
Chapter 3 HARDWARE INSTALLATION
3.1 Card Installation ............................................................................... 3-2
Chapter 4 SOFTWARE INSTALLATION
4.1 TV@nywhere-Plus Setup Utilities ...................................................... 4-2
4.2 TV@nywhere-Plus Software Installation ........................................... 4-4
4.3 Using TV@nywhere-Plus .................................................................. 4-6
4.4 Using TVR ........................................................................................ 4-7
4.4.1 Setting TV system and scanning channel ................................ 4-7
4.4.2 Main Panel Function ................................................................ 4-8
4.4.3 Input Source ......................................................................... 4-11
4.4.4 Schedule Function ................................................................ 4-11
4.4.5 Setup Utility .......................................................................... 4-14
4.4.6 Channel Preview .................................................................. 4-17
4.4.7 Snapshot ............................................................................. 4-17
4.4.8 Sleeping Timer ..................................................................... 4-17
4.4.9 Audio Output Mode............................................................... 4-18
4.4.10 FM function .......................................................................... 4-18
4.4.11 Pop-Up Menu ....................................................................... 4-20
4.4.12 Remote function ................................................................... 4-21
4.5 MPEG Encoder ................................................................................. 4-22
4.5.1 Interface Explanation ............................................................ 4-22
4.5.2 Practice Streaming Video Translation ..................................... 4-22
4.6 Video Editor .................................................................................... 4-25
4.6.1 Interface Explanation ............................................................ 4-25
4.6.2 Menu Area ........................................................................... 4-25
4.6.3 Display Area ........................................................................ 4-26
4.6.4 Original and Staging Clips ..................................................... 4-27
4.6.5 Frame Edit Mode ................................................................... 4-28
4.7 Burn DVD ........................................................................................ 4-29
4.7.1 Adding Files ......................................................................... 4-29
4.7.2 Burning ................................................................................ 4-30
4.8 FAQ ................................................................................................ 4-31
v
Νοτε
vi
1
GETTING STARTED
This user’s guide is designed for a series of TV
Tuner cards. Read this chapter first, and it will give
you a clear instruction on how to use this guide.
1-1
Chapter 1
1.1 How to Use this Guide
This user’s guide is designed for a series of TV Tuner cards. Before
you start reading this guide, find out the product name of the TV Tuner
card you have just purchased on the gift box, and look for the specification and function description in next chapter in accordance with the product
name of your TV Tuner card .
Chapter 2, INTRODUCTION, provides the brief specification and function of each TV Tuner card. For detailed description of all functions, you
may refer to the rest of the chapters. Note that the TV Tuner card you
purchased may not cover all functions mentioned herein; therefore, it is
recommended to read the “Reference” information first, which indexes
the correspoding founction description of each different TV Tuner card,
and then find the proper function description for your TV Tuner card in
the other chapters.
Chapter 3, HARDWARE INSTALLATION, tells you how to install your TV
Tuner card into your computer correctly, and the function of each connector on the TV Tuner card. Also note that your TV Tuner card may not
cover all functions mentioned in this chapter. Check on Chapter 2,
INTRODUCTION, for the specification of the TV Tuner card you purchased if you have any problem finding the proper function description
for your card.
Chapter 4, SOFTWARE INSTALLATION, describes how to install MSI TV
Tuner card software for Windows XP or 2000, including the driver and
useful utilities.
1-2
Getting Started
1.2 Conventions of this Guide
Read the conventions of this guide, and it will give you an idea about
how this guide is designed and how this guide should be used.
Th e pr od uc t
name of the TV
Tuner card
TV @nywhere
Layout
CATV
The lay out of
the TV Tuner
card
Th e p ac k a g e
contents of this
TV Tuner card
The c om ponents on the
TV Tuner card
Phili ps 7131
PCI Inte rfac e
Rem ote IC
TD A 8275
FM R adio Antenna Connec tor
CATV_IN C onnec tor
AV_IN/OUT Conne ctor
.
Package Contents
Unpac k the pac k age and ins pec t al l the items c areful ly. If any item
contai ned is da maged or m is sin g, pl eas e contac t y our lo cal dea ler
as s oon as poss ibl e. Als o, keep the box and pac ki ng material s i n
cas e y ou need to s hip the unit in the future.
Your VGA card pac k age sh ou ld co nta in the fol lowi ng items :
T V Car d
Softw are Pack Cds
Us ers ' Manual
Reference
1. Get t ing S t ar te d..................................................................1-1
2. Int ro d uct ion.......................................................................2-1
2.1S ys t em Req uir em ent s ....................................................2-2
2.2P r od uct List ...................................................................2-4
3.. H ar d wa re I nst a lla tio n......................................................... 3-1
4. So ft wa r e Ins t alla t ion........................................................... 4-1
Corresponding function for
each particular TV Tuner
card
1-3
Chapter 1
Νοτε
1-4
2
INTRODUCTION
This chapter provides some brief specification and
function of each card. For detailed description of
all functions, you may need to refer to the other
chapters. Note that the card you purchased may
not cover all functions mentioned herein; therefore,
it is recommended that you read the “Reference”
information first, which indexes the correspoding
founction description to each different card, and
then find the proper function description for your
card in other chapters.
2-1
Chapter 2
2.1 System Requirements
To install the TV Tuner card, your system needs to meet the following
Computer
PC with Pentium III 800, or above 128M
RAM (256MB is recommended), or
compatible system
Expansion Slot
PCI 2.2 Compliant Slot
Monitor
VGA support, minimum 640 x 480
resolution
Operating System
Windows® XP/2000
CD-ROM Drive
Double Speed or Higher
Antenna
Work UHF/VHF Antenna
Speakers
Hardisk
1GB Free HD Space
Others
§ Graphic Card (Support Microsoft DirectX 9.0 or above)
§ Sound Card (SoundBlaster 16 Compatible Sound Card)
§ Available Terrestrial Signal in your region
2-2
Introduction
2.2 Product List
TV@nywhere-Plus
Layout
CATV
Philips 7131
PCI Interface
Remote IC
TDA 8275
FM Radio Antenna Connector
CATV_IN Connector
AV_IN/OUT Connector
Remote Receiver Connector
2-3
Chapter 2
Features
*
*
*
*
*
*
*
*
*
*
*
*
*
High Quality 9-Bits NTSC/PAL/SECAM video decoder chip
Integrated TV worldwide audio decoder on chip, including MTS,
EIAJ, A2, Nicam
Support Teletext for PAL system
User-Friendly and Powerful TVR application
- Enhanced 16:9 Wide-Format Display
- Auto Channel Scan and Name Recognition
- Multiple Channel Preview
- TV/Video always on the top of the monitor screen
- TV/Video wallpaper
- On-Line Help
Support TimeShifting – Record & Playback Live TV Program at the
same time
Support Real-Time Video Recording in MPEG-4/2/1 format
(MPEG4 is compatible with DivX or Microsoft MPEG4). (Note : you
have to download the codec by yourself.)
Support Scheduled Recording
Support Still Image Capture in JPEG or BMP format
Support Picture-In-Picture (PIP) function
Additional AV/S Video Input for Connect Other Video Sources. (
such as DVD Player/ VCD/ VHS/ Camcorder)
SRPO – Schedule-Recording in PC Power-Off Mode
Power-Off PC by Remote Controller
Other Valued Software
- MPEG Converter
- MPEG Editor
- DVD Burn
Spcifications
*
*
*
2-4
Video Input / TV Input
- 75 Ohm (UHF/VHF) TV Antenna
- Composite Video
- S-Video
Audio Input
- Connect External Audio Source
TV Receiving Frequency
- 55.25 – 855.25 MHz (NTSC)
- 48.25 – 863.25 MHz (PAL)
- FM radio band – 87.5 to 108.00 MHz (option)
Introduction
Package Contents
Unpack the package and inspect all the items carefully. If any item
contained is damaged or missing, please contact your local dealer as
soon as possible. Also, keep the box and packing materials in case you
need to ship the unit in the future.
Your card package should contain the following items:
Remote Controller
TV@nywhere
PCI Card
Software Pack CD
4 in 1 AV-Cable
User’s Guide
Remote Receiver Cable
FM Radio
Antenna
Reference
1. GETTING STARTED .................................................................
2. INTRODUCTION ......................................................................
2.1 System Requirements ......................................................
2.3 Product List .....................................................................
3. HARDWARE INSTALLATION ....................................................
3.1 Card Installation ...............................................................
4. SOFTWARE INSTALLATION ....................................................
1-1
2-1
2-2
2-4
3-1
3-2
4-1
2-5
Chapter 2
Νοτε
2-6
3
HARDWARE
INSTALLATION
This chapter tells you how to install your card into
your computer correctly and how to use the connectors on the card. Note that your card may not
cover all functions mentioned in this chapter.
Check on Chapter 2, INTRODUCTION, for the
specification of the card you purchased if you have
any problem in finding the proper function description for your card.
3-1
Chapter 3
3.1 Card Installation
To install the card into your computer, please follow
the steps below:
1.
Follow the Windows® shut down procedure
to turn off your computer.
M SI reminds you...
Warning: Always remember to turn off your
computer before installing or removing
hardware to or from your computer. Neither the manufacturer nor the dealer is
responsible for damages if the user ignores this warning!!!
2.
Remove the cover from your
computer.
3.
Put the card directly over the PCI
slot and press one end of the
card into the slot first. Gently but
firmly press the other end until
it is fully seated in the slot. Secure the card with a bracket
screw.
3-2
HardwareInstallation
4.
Install the computer cover.
5.
Connect all necessary cables.
CATV
FM Radio Antenna
CATV_IN Connector
AV_IN/OUT Connector
Remote Receiver Connector
3-3
Chapter 3
Νοτε
3-4
4
SOFTWARE
INSTALLATION
This chapter describes how to install software
under W indows® XP / 2000, including the drivers
and useful utilities.
3-1
Chapter 4
4.1 TV@nywhere-Plus Setup Utilities
The TV @nywhere package comes with complete Windows software
utilities. These utilities can be found from the CD-ROM in this package. Before
installation, it is highly recommended that all background programs are
disabled. These include such applications as anti-virus software and system
monitoring applications.
1. When you finish the hardware
setup and restart your system. The
“Found New Hardware Wizard”
window will pop up. Please click
“Cancel ” and you can make use
of DVB-T setup utilities to easily
install it.
2. Please click “Driver_Install” to install
drivers and utilities of
TV@Anywhere-Plus.
3. The TV card driver utilities will help
you to install all the drivers. First, it
will install the TV remote control on
your system. Click “Next” to
continue.
4-2
Software Instal lati on
4. Then the utilities will help you install
the TV card driver automatically.
Please click “Next” to install
TV@Anywhere-Plus.
5. When you see the message as left,
that means all of your drivers has
been installed and it will start
launch TV Setup and initialize TV
settings. Please select “Yes, I
want to restart my computer
now” and click “Finish” to end the
installation.
4-3
Chapter 4
4.2 TV@nywhere-Plus Software Installation
TV@Anywhere-Plus installation CD comes with complete W indows software
utilities. These utilities can be found from the CD-ROM in this package. Before
installation, it is highly recommended that all background programs are disabled.
These include such applications as anti-virus software and system monitoring
applications. Please follow the step below to install the TV@Anywhere-Plus
application.
1.
Insert the installation CD disk into
th e C D - R OM d r i v e . T h e
TV@ Any where-Plus Auto run
Page will appear as the above,
please select “TV@ANYW HEREPLUS (PVR Plus)”.
2.
Then the install wizard will guide
you to install the TV@AnywherePlus application, please click “Next”
to continue.
3.
Please choose destination location
where you want to install files. You
can click the “Browse” to change
the destination folder.
4-4
Software Instal lati on
4.
Setup will add program icons to the
Program Folder listed below. You
may type a new folder name, or
select one from the existing folders
list. After you c lick “Next”, the
installshield wizard will start copy
files to your destination folders. It
may take a few minutes, please wait
a moment.
5.
After the installshield wizard has
finished installing
TV@Anywhere-Plus on your
computer, it will show the
message as left. Please click
“Finish” to end the installation.
4-5
Chapter 4
4.3 Using TV@nywhere-Plus
After you finish the installation of Digital @nywhere application, you can start
to use the application to watch free-to-air digital terrestrial TV on your system.
(Note that to have the best capability of your system, please install the
Microsoft DirectX 9.0 before you use Digital @nywhere.)When you start to
use the Digital @nywhere, you can select one of the functions as below.
TVR turns your PC into a full-featured video recorder.
(For the detailed instruction, please refer to chapter 4.4)
MPEG Encoder allows you to convert AVI files into MPEG
format.
(For the detailed instruction, please refer to chapter 4.5)
Video Editor makes editing MPEG videos easy.
(For the detailed instruction, please refer to chapter 4.6)
Burn DVD allows you to create a VCD, SVCD and DVD
that can be played on a PC or DVD player.
(For the detailed instruction, please refer to chapter 4.7)
Switch to FM.
(For the detailed instruction, please refer to chapter 4.8)
4-6
Software Instal lati on
4.4 Using TVR
TVR is a powerful and easy-to-use TV application provides the most featurerich video/audio entertainment. TVR provides a convenient way to watch and
record TV or video on your personal computer and also allows you to play
recorded TV or video. You can also listen to FM radio broadcasts under the FM
mode if it is included in your model.
4.4.1 Setting TV system and scanning channel
When you first time execute TVR, TVR will prompt a TV setup Wizard to help
you to set TV configuration step-by- step.
1. Select frequency table and video
standard (NTSC, PAL or SECAM)
either by country or TV system.
2. In this step, you have to select the
TV frequency scan mode and TV
audio live & recording port.
(1) Scan all of your TV channel
To scan your TV channels1, we
suggest you can use the “Use
default table” to scan all of your
channels first. If some of the TV
channels c an’t been sc an,
please select the “Use free scan”
to scan your channels again.
(2) Select the TV audio live & recording port.
Basically we suggest desktop
use to connect the audio cable
to the line in of your sound card.
Laptop user please connect the
audio cable to the Microphone in
of the sound card. Please base
on how you connect the audio
cable to select audio live and
recording port. So that you can
hear the sound when you watch
TV programs and playback recorded file.
4-7
Chapter 4
3. If you use the “Use free scan” to
scan all of your TV channels, you
would see the message window
as left.
The program will depends on the
step size to scan all of the TV
frequency step by step. It may
takes for a while, please wait a
moment.
4. When you finish this configuration,
please click “Finish” to end the TV
Frequency Table setup Wizard.
TVR will obeys the frequency table
to do channel mapping.
NOTE:
1. TVR depends on current country code of Windows OS to give you a default
value on country, but this might not be correct, you should check and select
a valid option for your environment otherwise you can’t view all TV programs
anyway.
2. When you want to re-configure your current TV frequency table anytime,
you can choice “Reset TV Option” on popup menu to do this job again.
4.4.2 Main Panel Function
Main window is the most important window of TVR that display live video or
playback. You can drag it to everywhere of screen or adjust its size by
mouse or double click to switch to full-screen. There are six major functions
of the TVR
4-8
Software Instal lati on
Information W indow
Display current time, state (Live, REC,
Playback, Time Shifting), TV sound
state (Mono, Stereo or SAP), recording
file size, recording time, time control
bar ,minimize ,maximize and help file.
Basic Tool Part
It has eight buttons, see following descriptions.
: Video source switch
: Scheduling
: Setup
: Channel preview
: Snapshot
: Sleeping timer setup
: TV sound switching
: Switch to FM
Channel Adjust Part
You can do channel selecting by click number key
on control panel
or keyboard when video source is set to Antenna, Cable or Memory.
Channel up
: Go to previous enabled channel.
Channel down
: Go to next enabled channel.
Note: You must set channel to enabled state either by manual selecting or autoscanning then you can use channel up/down functions.
Recall channel
: Go to last selected channel.
Volume Adjust Part
Increase Volumn
Mute
Decrease Volumn
4-9
Chapter 4
Record, Playback ,TimeShifting Part
1. Record Function
At Live mode, then you can start recording current live video by click
capture button on control panel or choice “Capture” on popup menu. Once
you are in capturing, click
stop button on control panel or choice
“Stop” on popup menu to stop current recording. You can review your
recorded files in the playback list after recording.
2. Playback Function
You can do playback by click play button on control panel or choice “Play”
on popup menu. This will bring a playback dialog that show all captured
files you have done and all recent played files. You can assign more than
one file from recorded file or importing from file dialog, TVR will gather all
files you selected to a play list.
Add: Add selected item to
Play list. Double-click
the selected item to
add it into the Play list.
Delete: Delete selected item.
Delete All: Delete all items.
Rename: Rename selected item.
Import: Import file(s) to play
list.
Clear: Clear all items on play
list.
While playing, you can use following functions:
- Play button
- Pause button
: If media file is paused, resume playback.
: To pause the current playing media file.
- Stop button
: Stop current playing media file and go to Live mode.
- Backward button
: Go backward.
- Forward button
: Go forward.
4-10
Software Instal lati on
3. TimeShifting Function
At Live mode, you can do time shifting by click
time-shifting button on
control panel or choice “Time Shifting” on popup menu. Once you are in
time-shifting mode, you need to wait for at least 4 seconds before
play button on control panel or choice
start playing by click
“Play” on popup menu. Once you want to stop time shifting, click
stop button on control panel or choice “Stop” on popup menu to
stop it.
While time shifting, you can switch current video and time-shifting video
window by choice “Real Screen” on popup menu.
4.4.3 Input Source
There are five video input source for user selecting, they are Antenna, Cable,
Memory, Composite, and S-Video. You can change video source by click video
or
) button on control panel or choice “Switch Video
source (like
Source” on popup menu to do this job.
When video source is changed successfully, the control panel will also change
to current status as you see.
4.4.4 Schedule Function
When you click
, you can start
setting the schedule properties.
Capture
- Capture Source: Capture source
includes DVB-T, Composite and SVideo.
- Channel: Select the channel
which you want to record.
- Capture format (profile): When
you select DVB-T as the capture
source, you can only use MPEG2
as capture format. (If you use
other capture source such as composite or S-Video, you can use other
capture format such as VCD, DVD or MPEG4.)
- File name option: You can use the date/time as your capture file name
or define by yourself.
4-11
Chapter 4
Time option
- Current time: Show the current time.
- Starting time: Enter the date and time when you want to start recording
the files.
- Duration: Enter the length you want to record the program.
- Recording rule: Enter the recording rule you want to use. The default
value is “Once only”.
Schedule Recording Agent Setting
When you input a record schedule, you will find that your record schedule
1. Open
-
Insert: Insert a new record schedule.
Edit: Edit the record schedule.
Delete: Delete a record schedule.
Delete All: Delete all of the record
schedule.
- Start Power-off Schedule: If you
click this button, the system will turn
off immediately. When the scheduled
recording time comes, your PC will turn
on automatically and start recording TV
programs as scheduled.
Note: To enable this function, please enable the “Hibernate”
function in the windows power management configuration in
advance.
2. Today To-do List
It will show all of the record schedule
items of the day.
4-12
Software Instal lati on
3. Log
If your record schedule fails, the error
message will show in Log description.
You can check error messages here.
4. Setup
- Output folder: You can change the
different capture folder to save your
record files.
- Auto-execute at start up: Enabling
this option makes schedule agent
always execute at start up, otherwise it doesn’t. Default is enabled.
- Enable Power-off schedule
recording mode: Enabling this
option makes system shutdown
automatically when schedule
recording finishes. Default is
disabled.
4-13
Chapter 4
4.4.5 Setup Utility
TV Tuner Setup
The TV Tuner setup property page, allows you to customize and configure your
TV channels or edit your favorite memory channel. You can do automatically
scan your cable or antenna signal for available channels or you can label and
identify your favorite channels, as well as include or exclude channels from the
channel list. At channel list, you can double click on each column to change
channel setting, like video standard, MTS option, channel name and frequency
fine tune.
Normal Group
Switch TV source from Antenna or
Cable.
Memory Group
Using Memory Group function. At memory
mode, users can assign any order of
channel number or video source they
like.
Auto Scan: Click the button to start
Auto Scan function.
Preview Setup
The preview setup property page, allows you to customize and configure your
TV channels for channel surfing. There two preview option: standard and
customized. At standard mode, channel surfing order
Standard
To select the Preview dimension: 2x2,
3x3, 4x4, 5x5
Preview time interval: Setting the interval time. The minimized value is 2 sec.
Customize
If you select this function, you can setting the video source of each channel.
Just click on the number key then you
can setting the video source which you
want to see.
4-14
Software Instal lati on
Capture Function
- Video capture device: To decide
your video capture device.
- Video input format: Select your
video input format as YUY2, UYVY or
RGB.
- Capture format (profile): Setting
what kind of video format which you
want to record.
- Capture Size: Setting video capture
size.
- Bite Rate (Kbps): Setting capture
bite rate.
- Capture quality: Setting capture
quality.
- Frame Rate: Setting capture frame rate.
- Capture location: To setting your capture folder.
- Capture filename: Setting your capture file name. You can choose
“User date/time “ as filename or define by yourself.
- Enable time limit: To limit your record time.
- Capture audio device: You can select “Capture audio”, “Capture audio
only, No Video” or no audio. When you select “Capture audio only, No
Video”, you can capture the file as WAV or MP3 format.
- Audio capture device: Select which audio capture device which you
want to use.
- Audio Source: To setting where the audio source. (Recommend using
Line in.)
- Audio format: Setting your audio capture format.
4-15
Chapter 4
Video Setup Function
Color
Brightness, contrast, hue and saturation adjustment. Move the pointer of
each scroll bars to see the effect.
Video System
Although the TV tuner on your TV tuner capture card is fixed and you have
to set up the TV system right after the first time you launch TV PLUS, you
still have the chance to use this product to display the varies standards of
video system.
- Always On Top: The preview
window will show topmost.
- Enable high quality preview:
Enable high quality preview mode
- Don’t use overlay as display
surface: If your graphic card
doesn’t supports Overlay mode,
click on this option.
- Display Aspect Ratio: You can
change the display aspect ratio at 4 :
3 , 16 : 9 or free mode.
Other Setup Function
- Multi language option: To select
the different language interface on
line.
- Enable PIP playback: Enable the
Picture-In-Picture function while you
are playback files.
- MPEG4 Codec: You can use this
option to select different MPG4 code
such as Microsoft and DivX codec.
4-16
Software Instal lati on
4.4.6 Channel Preview
You can do channel surfing by clicking
on control panel or choose
“Channel Preview” from the pop-up
menu.
While channel surfing, you can select
every channel sub-window by 4 arrow
keys (left, right, up, down) or directly
mouse click. When you want to finish
channel surfing, you can use mouse
double click or enter key to the channel
sub-window you want.
4.4.7 Snapshot
You can do Snapshot (Still Image Capture) on current preview window by
on control panel or choose “Snapshot” from the pop-up menu. When
click
snapshot is done, the snapshot window will show up and you can do View/
Save/Delete for all images.
Note that the saved image format supports both BMP and JPEG, you can
decide which format you want to save when you execute “Save / Save All”
on file dialog.
4.4.8 Sleeping Timer
You can use sleeping timer function to
set when you want to shutdown your
system.
After you select the button, you would
see the dialog box as below:
You can use slide bar or left and right
key to adjust sleeping timer value, click
“OK” to start. “Cancel” to exit.
4-17
Chapter 4
4.4.9 Audio Output Mode
If your product model support Multilanguage function, you can click the icon to
select different audio output mode. For example, you can setting your audio
output mode as Stereo, Mono or SAP.
4.4.10 FM function
FM is a powerful application provides you listen and record FM radio. There are
50 memory channels can be assigned and you can use schedule recording to
specific memory channels.
The FM control panel is designed to look like controls on a electric appliance, you
can click button on control panel to do the function you want. The following page
shows descriptions for the FM control panel functions, and tips for operating FM
features.
Information W indow
Display current time, current state (FM, REC,
Playback), audio state, recording time, recording
file size and current time, minimize, maximize and
help file.
Tuning Frequency Adjusting
You can click or drag the frequency slide bar to set
new frequency
Basic tool
: Switch to TV
: Scheduling
: Setup
: Add current frequency to memory channel list
: Increase 0.05MHz to current frequency value
: Decrease 0.05MHz to current frequency value
: Go to next channel
: Back to last channel
4-18
Software Instal lati on
Channel Adjusting
Enter the number key and Enter (
) or wait 1
seconds that direct jump to the channel you input.
: Go to last selected channel.
Volumn Adjusting
or
: Mute or restore sound
Record/Playback/Time-shifting:
: Start recording
: Start playback
: Pause current playback
: Stop playback and back to Live mode
: Go backward
: Go forward
Time control bar
While playback, it shows general elapsed time or time remaining, also jump to
specific time in program by mouse click.
Recording
You can start recording current audio channel by click
capture button on
control panel or choice “Capture” on popup menu. Once you are in capturing,
click
stop button on control panel or choice “Stop” on popup menu to stop
current recording. You can review your recorded files in the playback list after
recording.
Playback
Same as playback of TVR. Please refer chapter 4.4.2.
4-19
Chapter 4
4.4.11 Pop-Up Menu
Any time while running TVR, you can put the cursor on the display window or
control panel and right-click to see a pop-up text menu. This menu will also
appear when you press the [F12] key on your keyboard. The commands on this
right-click menu are the same as those on the TVR control panel, along with
some extra options added. The right-click menu is explained below.
- Full Screen: Switch to full screen or restore to
normal window
- Always On Top: Set main window to topmost
- Display Aspect Ratio: Set the aspect ratio of
the display window (Free, 4:3 or 16:9)
- Switch Video Source: Switch video source
(DVB-T, Composite or S-Video)
- Previous Channel: Go to previous available
channel
- Next Channel: Go to next available channel
- Recall Channel: Go back to last selected
channel
- Memo Channel
- Channel Preview: Browse available channels
as sub-window
- Capture: Start recording video
- Play: Start playback of recorded program
- Time shifting: Start time shifting
- Snapshot: Capture still images of current picture
- Mute: Mute or restore sound
- Setup: Open DTVR setup window
- FM Mode: Switch to FM
- Reset TV Frequency Table: Reset TV setup
utility and frequency table
- Sleeping Timer: Set sleeping timer on/off
- Schedule Recording: Open scheduling
recordings
- About: Show version and copyright information
- Exit: Exit DTVR
4-20
Software Instal lati on
4.4.12 Remote function
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
POWER: Press this button to turn On / OFF TV@ANYWHERE-PLUS.
SOURCE: Switch video source (Antenna, Cable, Memory, Composite
and S-Video.)
SCAN: Scan all channels.
Numeric Keypad: Select the desired channel directly.
MUTE: Press this button to mute the sound.
ZOOM: Click this button full screen display video.
PREVIEW: Channel preview
SNAP: Click this button to capture image.
REC: Start recording current live video
STOP: Stop recording current live video
PAUSE: To pause the current playing media file
PLAY: Click this button to playback recorded file
BACKWARD: Go backward while playback a recorded file
FORWARE: Go forward while playback a recorded file
CH+: Click this button to go to next channel.
CH-: Click this button to go to previous channel.
VOL+: Click this button to increase the audio volume
VOL-: Click this button to decrease the audio volume
PIP: Enable the PIP (Picture-In-Picture) function while you are playback
files.
Pow er-O ff PC by remote contr ol:
Click the RESET button when you want to
power-off your PC. You will see the message pop up as below. Press “Power”
button of the remote controller or click
“OK” button on the message window and
the system will shot down immediately.
(You have to turn off the software TVR
before using this function.)
4-21
Chapter 4
4.5 MPEG Encoder
4.5.1 Interface Explanation
The default page is composed of four parts:
Header Buttons
Add input files; Delete files; Edit options; Start and Stop transcoding.
Batch Process Display W indow
Displays file name, encoding status, screen size and play time of files to be
transcoded.
Progress Display Window
Displays formatting information about the file being transcoded.
Preview Display Window
Displays the video of the file being transcoded.
4.5.2 Practice Streaming Video Translation
MPEG Encoder transcodes
multimedia files among video
formats. For using MPEG
Encoder, they must be able to
be played with Windows Media
Player. File formats that can be
transcoded are: AVI, DV-AVI,
MPEG-1, MPEG-2, ASF, WMV,
DivX, and DAT.
To add a multimedia file to be transcoded, click on the “+” or “Add”. This will
open the “Browse” dialog box. Browse to the directory/file wanted and click
on “Open”. (Another method of adding files to the Batch Process Display
Window is to simply highlight a file, then drag and drop it into the Batch
Process Display W indow.)
4-22
Software Instal lati on
Once the multimedia file is added to the Batch
Process Display W indow, the Option Dialog
Box appears. This begins the process of
selecting the output format for the
transcoder. Choose among four categories
of formats: MPEG-1, MPEG-2; Category tabs
appear at the top of the window. After
selecting a format category, choose a
specific video format (and detailed options if
necessary).
The output file will be created in the same
directory as the original file unless a different
path is manually chosen. It will also maintain
the original video file name and add a file
extension matching the video format of the
output type selected. The file name can also
be manually changed.
Once the output video format and options are selected, click “OK” and the file
will appear in the Batch Process Display Window.
The Batch Process Display W indow shows three states of process in the
Status column.
1. Waiting: The media file displayed is queued for transcoding (compression
and/or translation). The transcoding of video files in the “W aiting” state
begins when the Encoding is clicked.
2. Exclusion: Transcoding of that file will not occur.
3. Done: The transcoding (compression and/or translation) is successfully
completed.
To change a file’s status between Waiting and Exclusion (and vice versa),
double click on the file line. The Waiting state will change to an Exclusion state
and be reported as “Skip”. Similarly, a file with a “Skip” status when doubleclicked, will change to “Waiting”.
4-23
Chapter 4
During Transcoding, the Status
column changes to display the
percent of progress
accomplished. Also, once the
transcoding process has
begun, the (right arrow)
Encoding button changes to a
Stop button. If the Stop button
is clicked-on during
transcoding, the process will
stop. Once the transcoding process completes successfully, the status will
change to Done. To transcode the same file again - for example, with an option
change - double click on the file in the Batch Process Display Window and the
Status will change to Waiting. To change the options again, highlight the file
with a single mouse click and then click on the “Option” or “Edit” button to
execute the Option Selection Dialog box.
To view the transcoded output video file, highlight the video file and click-on
the Output Play button.
4-24
Software Instal lati on
4.6 Video Editor
4.6.1 Interface Explanation
Video Editor’s screen has following areas.
- Menu Area: file open, file/video clip delete, video property, change skin
color, minimize, maximize, close and help
- Display Area: play original video clips, play edited video clips (preview),
display saving progress information
- Video Clip Staging Area: Original Clips, Staging Clips
- Frame Edit Area: mark frame range, sequence arrangement, merge
multiple frames into one video
- Title Edit Area: add title, font style, size, color, movement (straight line,
curve line)
- Audio Edit Area: add audio and create sound effect
- Special Effect Edit Area: use Color Effect, Filter Effect, Transition Effect,
Transition In Effect, Transition Out Effect, Noise Reduction Filter
File open
Clip/File
delet e
MPEG
Properties
Dialog
4.6.2 Menu Area
File open
- Support MPEG-1, 2 system file(Video
and Audio), AVI(DV-AVI).
- Select a file and click “Open” button.
Clip/File delete
- Delete clips registered in
Original/Staging Clips.
- Actual file on a hard disk is
deleted when “Delete File” is
checked.
4-25
Chapter 4
MPEG Properties Dialog
- Display your input MPEG file properties
4.6.3 Display Area
Original Video Display W indow
- Displays videos in Original Clips.
(Double Click or Drag and Drop)
- Videos in Staging Clips cannot
be displayed in this window.
- In Title editing mode, Title can be
edited in this window.
- In Audio editing mode, it displays
registered audio files.
- In Special Effect mode, it
displays all available filters.
- Displays the progress information when final video is created.
4-26
Edited Video Display W indow
- Displays videos in Staging Clips.
(Double Click or Drag and Drop)
- Videos in Original Clips can be
displayed in this window.
- Preview function displays
edited video in this window.
Software Instal lati on
4.6.4 Original and Staging Clips
Original Clips
- This is the area where video clips that need to be edited are added and
managed.
- Video clips can be dragged and dropped into the Original Clips area.
- The sequence of video clips added can also be rearranged easily by drag
and drop.
How to add video clips
button in the menu area to browse and select video clips
a. Use the
to add to the Original Clips area.
b. Drag and Drop video files to the Original Clips area.
How to view and manage video clips in the Original Clips area
a. To view a video clip in the Original Clips are, either double click on the
video clip or drag and drop the video clip from the Original Clips area
on to the Original Video Display window.
b. Clicking on the right mouse button will bring up a Pop-up Menu. This
menu performs the following functions: copy, delete and show
property information.
Staging Clips
- This is the area where video clips are added after frame ranges are
specified.
- Video clips can be managed for further editing in this area.
- Editing, deletion and sequence arranging are done here.
- File properties for each video clip can be obtained by right mouse clicking
on the clip.
- Video clips are acted upon and added to the Staging area using the four
application buttons on the left side of Video Editor. Those four buttons are
“Cut”, “Title”, “Audio” and “Effect”.
4-27
Chapter 4
4.6.5 Frame Edit Mode
Frame Range Selection for Editing
- Specify frame range
- To add an entire video
clip, drag the clip from the
Original Clips area and
drop it in the Staging Clips
area.
- To add portions of a video
clip, drag the clip from the
Original Clips area and
drop it in the left preview
window. Then using the
Mark-in/Mark-out button,
cut the portion of the
video clip to be edited and
then click the
button to transfer the clip to the Staging Clips area.
- Users can repeat the above steps to add multiple video frames.
Video Frames Editing and Saving
1. Adding Video Clip
- Use the
button in the menu area to browse and select video clips to
add to the original clips area.
- Drag and drop video files to the original clips area.
- Double click on added video clips in original clips area or drag and drop
them to original video.
- Display W indow to view and select frames for further editing.
2. Selecting frame ranges for video editing click mark-in to specify the
beginning of a clip and mark-out to set the end of the clip. Next, click on
the button to move the clips from the auto edit window to the Staging Clips
area.
3. Editing video frames
- Select video frames in staging clips area.
- Users can rearrange the sequence of videos.
- Users can repeat the same scene by putting the same video frames
multiple times.
- Users can delete sections of video they do not want.
- Users can confirm the video before final saving using preview function.
- User can repeat the above steps.
- Save the final video when editing is completed.
4-28
Software Instal lati on
4.7 Burn DVD
4.7.1 Adding Files
1. Select format
DVD: For DVD.
VCD: For Video CD.
SVCD: For Super VCD.
DATA: For multi-media data CD.
and the dialog box will
2. Click
shows up as left. It will show you all
the video files in this folder. Please
select the video file which you want
use.
3. Added files also can be deleted.
Click on the file then click the
button, the file will be
delete from the list.
4. When all necessary files are added,
to move to next step.
click on
4-29
Chapter 4
4.7.2 Burning
3
1. The window shown on the right
appears.
4
2. This “Back” button allows users to
go back to previous step. Users can
go back to previous step and
change selected files or selected
format.
3. Select DVD/CD burner to use.
4. Eject DVD/CD drive.
5. Erase all content on DVD/CD media.
6. Open option dialog box.
- NTSC, PAL, Both: Select video
type.
- Support XVCD and XSVCD:
Data rate is not checked in order
to support XVCD and XSVCD.
- Perform W riting Test before
recording: Checks to insure that
the DVD/CD writer is functioning
correctly before actual burning.
- Use W indows temporary
directory: [Default] Use W indows temporary directory as DVD
Maker’s temporary directory.
- Path: Users can specify DVD
Maker’s temporary directory.
7. After selecting DVD/CD burner and
changing settings in Option dialog
to start burning DVD
D
box, click
or CD.
4-30
5
6
2
7
Software Instal lati on
4.8 FAQ
Q1. How do I use the power-off schedule recording function?
Before you use the power-off schedule recording function, please make sure
your system can support hibernate function.
Step 1.
Enter to the “display properties” and
choose the “screen saver”.
Step 2.
Click the “Power” button to and enter to
the “Hibernate” function. You would
see the option “Enable hibernate
support”. Please click on the function
so that you can use the power-off
schedule recording function.
Step 3.
button
Then you can click on the
to start setting the schedule properties.
After you finish the setting, please click
the “OK” to the next step.
Step 4.
Then you would see your setting in the
schedule. If you want to use poweroff schedule recording now, please
click on the “Start Power-off Schedule
” button. It will pop up a message to
ask you if you want to shutdown
system after schedule recording.
If you want to shutdown your PC after
schedule recording, please click “Yes.
4-31
Chapter 4
Q2. How to capture video clip as MPEG4 format?
If you use other capture source such as composite or S-Video, you can
record video clips as MPEG4. (When you select DVB-T as the capture source,
you can’t capture video format as MPEG4.) Please follow the steps below to
record files as MPEG4 format.
Step 1.
We provide two kinds of MPEG4
format, Microsoft and DIVX.
Please download the MPEG4 Codec
from Internet.
DIVX: http://www.divx.com/
Microsoft: http://www.microsoft.com
Or you can e-mail to our technical
support department.
Step 2.
Install the MPEG4 codec
Step 3.
Click the setup button (
) and enter
to the capture setting. Please select the
MPEG4 record format.
Step 4.
Go to the other setting. Select the
Mpge4 codec you want to use,
Microsoft or DIVX.
Step 5.
When you finish the setting, please
4-32
Software Instal lati on
Νοτε
