MSI V801 N690GTX-P3D4GD5 Owner's Manual

Getting Started
∙ Blu-ray 3D Support
Connect your PC to any 3D enabled TV over HDMI and enjoy a cinematic 3D experience in your home with
seamless support for 1080p Blu-ray 3D discs.
Blu-ray 3D playback requires the purchase of a compatible software player from CyberLink, ArcSoft, Corel,
or Sonic.
∙ TrueHD and DTS-HD Audio Bitstreaming
Full support for TrueHD and DTS-HD advanced lossless multi-channel HD audio codecs brings the rich
sound of the master recording to your living room.
∙ Microsoft® DirectX 11 Support
DirectX 11 GPU with ShaderModel 5.0 support designed for ultrahigh performance in the new API's key
graphics feature, GPU-accelerated tessellation.
Quick Installation
Hardware
Follow the instructions below to install the VGA card:
1. Remove the computer case.
2. Locate the expansion slot on your mainboard.
Warning: Inserting the VGA card into a wrong
slot may damage your card (refer to your
mainboard manual for further Information).
3. Put the card directly over the expansion slot and
press one end of the card into the slot first.
Gently but firmly press the other end until the card is
fully seated in the slot.
4. Secure the card with a bracket screw.
5. Attach the power cable of the power supply with
recommended wattage to the VGA card, if necessary.
∙ Microsoft Windows 7 Support
Windows 7 is a new generation operating system that will mark a dramatic improvement in the way the OS
takes advantage of the graphics processing unit (GPU) to provide a more compelling user experience. By
taking advantage of the GPU for both graphics and computing, Windows 7 will not only make today's PCs
more visual and interactive but also ensure that they have the speed and responsiveness customers want.
6. Install all other cards and devices and connect all the
cables, and then re-install the computer case.
∙ NVIDIA® FXAA Technology
Shader-based anti-aliasing technology available from the NVIDIA Control Panel that enables ultra-fast
anti-aliasing in hundreds of PC games.
7. Connect the monitor. Now, you are ready to install
the driver and software on your computer.
∙ NVIDIA® PhysX® - Technology
Full support for NVIDIA PhysX technology,enabling a totally new class of physical gaming interaction for a
more dynamic and realistic experience with GeForce.
∙ PCI Express 3.0 Support
Designed for the new PCI Express 3.0 bus architecture offering the highest data transfer speeds for the
most bandwidth-hungry games and 3D applications, while maintaining backwards compatibility with
existing PCI Express motherboards for the broadest support.
GRAPHICS CARD
N690GTX
115V
series
Headquarters
∙ NVIDIA® CUDATM Technology
NVIDIA®CUDATM technology unlocks the power of the GPU's processing cores to accelerate the most
demanding system tasks - such as video transcoding - delivering up to 7x performance over traditional
CPUs.
Requires application support for CUDA technology.
Installing the VGA card...
Attaching the power cable...
Connecting the monitor...
∙ NVIDIA® Adaptive Vertical Sync
Dynamically enables vertical sync based on your current frame rates for the smoothest gaming experience.
∙ HDMI
Support for HDMI including GPU accelerated Blu-ray 3D support, x.v.Color, HDMI Deep Color, and 7.1
digital surround sound.
∙ Dual-link DVI
Able to drive industry’s largest and highest resolution flat-panel displays up to 2560x1600.
Part NO: G52-V801206
Overview
Power Connector
NVIDIA GeForce 690GTX
4096MB GDDR5 memory
Fan Connector
SLI Interface
PCI Express Interface
NVIDIA GeForce 690GTX
LIVE UPDATE 5
Enabling HDMI Output
MSI Live Update 5 offers users with brand-new update service experience, which can significantly save your
time while searching files. Live Update 5 is capable to automatically analyze and list drivers, BIOS, and
utilities you need. With the easy-to-use updating approaches, you can increase the performance of your
system easily and quickly. Follow the instructions below, with a few mouse clicks, you can acquire the
related files for the system updating.
Follow the steps below to enable HDMI Output function:
2. Click the Utility tab on the setup screen.
3. Click the MSI Live Update 5.
Follow the on-screen nstructions to
complete the installation.
Software
To install the driver of the VGA card to your
computer, please follow the steps below:
1. Turn on the computer.
2. Insert the driver disk into the optical device drive.
The AUTORUN program will start the Setup
program, and show the setup screen as shown
on the right.
Mini Display port
For further information, please visit MSI website at www.msi.com
1. Find the DVI-to-HDMI adapter, if provided.
The adapter may not come with the package, consult your
dealer to purchase the adapter, if needed.
3. Ensure that the adapter is firmly installed.
4096MB GDDR5 memory
The VGA card shown here is for reference only, and may vary from the actual card.
Optionally Supported
2. Attach the DVI-to-HDMI adapter to the DVI connector.
1. Insert the driver disk into the optical
device drive, and start the Setup program.
4. Launch MSI Live Update utility to proceed
the updating function.
DL-DVI-I Ports
- HDMI supported
- HDCP supported
- Dual-link DVI output supported
Quick Installation
Functions
3. Click the Driver tag, and follow the on-screen
instructions to complete the installation.
WARNING!!
DO NOT touch the cooling
system since it may produce a
certain heat while processing
tasks.
CAUTION!!
Do not force the GPU cooler
against the fragile GPU to avoid
damage to the GPU.
4. Once the installation is completed, restart the
computer as instructed.
