Bartscher 257160 Wall-mounted hood 700 w.motor, W1600 Data sheet

Wall-mounted hood 700 w.motor, W1600
• Fan regulation:
• Cut-out for the motor:
• Available on request:
Via an external controller
232 x 208 mm
Ceiling hood
Wall hood series 1100
Other sizes
• Lighting:
yes
• Flame protection filter: Type A
• Material filter:
CNS 18/10
• Number of filters:
3
• Including:
• Material:
CNS 18/10
• Number of fan motors/ 1
exhaust air outputs:
• Power load:
0,202 kW | 230 V | 50-60 Hz
• Important information: Can only be commissioned with
an additional controller
• Operating mode:
Exhaust air
• Assembly type:
Wall
• Properties:
Blare-free light installed with
grease protection cover
Filter carrier with additional gre­
ase collection channel
• Motor output:
184 W
• Max. air throughput:
1600 m³/h
• Lamps (number +
1 x 18 W
watt):
• Size:
W 1,600 x D 700 x H 450 mm
• Weight:
41 kg
.
GB
10/2021
1/2
Code-No.
Subject to technical modifications and errors.
257160
GTIN 4015613600949
Wall-mounted hood 700 w.motor, W1600
Intensive power cleaner F1L, set of 2
Control, steplessly variable
• Order quantity unit:
• Content:
• Ph level:
• HACCP compliant:
• Chlorine-free:
• Phosphate-free:
• Including:
• Important information:
• Material:
• Designed for:
• Size:
• Weight:
• Important information:
GB
Add on Products
10/2021
2/2
1 box (2 bottles)
2 x 1 litre
14
Yes
Yes
Yes
1 spray head
1 spray lance
Attention: Not suitable for surfaces sensitive to
alkali such aluminium
Exclusively available in Germany and Austria
Plastic
Extractor hoods with 1 phase
W 130 x D 90 x H 75 mm
0.2 kg
.
Code-No. 173080
Code-No. 220110
GTIN 4015613731933
GTIN 4015613603056
Subject to technical modifications and errors.
