SKY AIR PRODUCT RANGE

COMMERCIAL CATALOGUE

02

About Daikin

Daikin has a worldwide reputation based on nearly 90 years’ experience in the successful manufacture of high quality air conditioning equipment for industrial, commercial and residential use and 55 years as a leader in heat pump technology.

Daikin quality

Daikin’s much envied quality quite simply stems from the close attention paid to design, production and testing as well as aftersales support. To this end, every component is carefully selected and rigorously tested to verify its contribution to product quality and reliability.

Heat pump technology

Air to air heat pumps obtain 75% of their output energy from renewable sources: the ambient air, which is both renewable and inexhaustible*. Of course, heat pumps also require electricity to run the system, but increasingly this electricity can also be generated from renewable energy sources (solar energy, wind energy, hydropower, biomass).

3/4 kW

4/4 kW energy

* EU objective COM (2008)/30

1/4 kW electricity

Content

Sky Air, the solution for the light 04 commercial sector

Products in the spotlight

Sky Air product range

09

17

Ventilation 57

Control systems 69

Options & accessories

Europe’s New Energy Label

86

90

03

04

the solution

for the

light commercial sector

Sky Air is Daikin’s industry-leading light commercial range, which has been designed for optimum seasonal energy efficiency. Providing the ideal solution for all kinds of small commercial spaces, the Sky Air series offers a complete comfort solution that puts you in total control of your heating and cooling, ventilation and air curtains.

22

Using highly efficient heat pumps, Sky Air solutions offer year round comfort:

• All systems now optimised for seasonal energy efficiency.

• An outdoor unit can power several indoor units.

• For a long or irregularly shaped room you can use up to four indoor units linked to a single outdoor unit. All the indoor units are controlled at the same time.

• Air conditioning is available in every room: a multi system allows up to nine different indoor units to operate from a single outdoor unit. All the indoor units can be individually controlled and do not need to be installed at the same time.

Extra units can be added later.

• Select from a wide range of indoor units: wall and floor mounted, concealed or ceiling mounted.

• Very quiet and draught-free operation.

• Ideal for both new build and refurbishment projects.

Biddle air curtains

for entrances

Biddle air curtains can be used with the Sky Air system to provide heating at building entrances:

• Ideal for buildings with open-door policy such as retail stores.

• Year round climate control and comfort even on the most demanding days.

User-friendly controls

Our user friendly controls allows you to manage your Sky Air system for maximum efficiency:

• From individualised unit control to centralised management via touch-screen options and code based controllers, we put you in command at all times.

• The wired remote controller gives full access to the unit’s functions and energy saving features, including flexible scheduling for different seasons and the possibility to indicate kWh usage (round flow cassette).

• The DIII-net connection is standard, allowing you to link into the wider building management system.

• Text based remote control and monitoring of the entire building is available via the internet.

Ventilation

Daikin’s ventilation option provides a supply of fresh air to help create a healthy and high-quality indoor environment:

• Heat is reclaimed between outdoor and indoor air.

• The fresh air from the ventilation provides additional cooling virtually free.

• Optimum humidity control.

05

06

the solution for the light commercial sector

Sky Air for retailers

• Creates an inviting atmosphere for your customers

• Discreet with limited visual and operating impact

• Reduces energy usage and costs

• Worry-free installation

Our round flow cassettes blend with your décor as they are integrated in the ceiling with only the standard panel visible. This standard panel is the secret to increasing comfort levels and providing the perfect climate conditions for your customers as the various flaps can be individually opened and closed to ensure that the heating and cooling are directed to where they are needed.

The panel is also the secret to reducing maintenance as it can conceal the auto cleaning function that traps dust with a special filter that cleans itself once a day, while the collected dust can be easily removed with a vacuum cleaner. Up to

50% energy can be saved!

Managing this system couldn’t be easier as our intelligent touch manager enables you to monitor and control the system directly or via the Internet. It can also be set to provide easy management of your electricity consumption and can even control the lighting, while enhanced scheduling will make your life easier.

Sky Air for offices and banks

• Design and genius in one.

• Unique design in the market: integrates fully flat into the ceiling.

• Optional presence and floor sensors improve comfort and efficiency.

The fully flat cassette is unique in the market thanks to its remarkable blend of iconic design and engineering excellence.

Blending seamlessly with the décor of a modern office and meeting the demanding criteria of architects, the fully flat cassette totally integrates within a standard European ceiling panel, enabling lights, speakers and sprinklers to be installed in the adjoining ceiling tiles.

These units are ideal for heating or cooling smaller areas such as meeting rooms, together with our round flow cassettes. Both can be combined with presence and floor sensors and even with our ventilation option, to optimise the energy efficiency and provide perfect comfort.

The presence sensor adjusts the set point or switches the unit off when there is nobody in the room but when someone is there, the air-flow is directed away from that person to avoid draught. This combined process has been found to reduce energy usage.

The floor sensor detects the average temperature near the floor and ensures an even temperature distribution between ceiling and floor. Cold feet become history!

Daikin’s ventilation option provides a supply of fresh air to help create a healthy and high-quality indoor environment.

Using the KNX interface to connect your Sky Air system to the building management system allows central monitoring and control of several devices, including lights, shutters, and climate control systems as to maximize energy efficiency.

Sky Air for server rooms

• Continuous cooling operation.

-Automatic rotation between active units.

-Backup outdoor unit ensures continuous operation.

-Possible to block certain settings.

• Quality products.

Servers, especially racks of servers, generate a great deal of heat and this needs to be removed through continuous cooling and humidity control. This presents special challenges that the Sky Air system easily meets with its special server room configuration.

Each server room is fitted with two indoor units each connected to a single outdoor unit to ensure that if one outdoor unit fails, the other is there as an automatic back up.

The indoor units are configured for constant cooling and duty rotation. This is achieved through automatic switching between units after certain period of use to ensure that at any time one unit is working while the other is available for maintenance.

Given the critical importance of continuous cooling for server rooms, the system is managed via an RTD-NET controller that can monitor and control up to 16 indoor units either directly or via the building management system and has a ‘control of duty’ unit that locks the server room settings so that they cannot be changed by people in the server room.

Sky Air for restaurants

• Ensures an even temperature distribution to create the perfect dining environment.

• Highly energy efficient.

• Uses intelligent control systems operated from one central location.

Nothing should distract diners from enjoying the perfect ambience and that ambience includes the optimal temperature. That’s exactly what Daikin’s concealed ceiling units deliver through whisper-quiet operation and improved comfort from the 3-step air flow control and these turn your restaurant into a comfortable, welcoming environment for your customers. And with the centralised control and easy scheduling for the entire restaurant system, energy use is minimised to control your running costs.

07

08

Advantages for

building owners

• Your climate control system will meet legal requirements well beyond the current legislation.

• You will obtain optimal seasonal performance thus save on running costs, obtain rapid return on investment and contribute to ecological protection objectives.

• The climate control system will add value to the building thus protecting your investment.

• Advanced controls and monitoring features allow the delivery of optimal comfort levels with the minimum of cost.

Benefits for

installers

• Provide an easy transition from existing units to the technologically advanced units that offer far higher energy efficiency solutions.

• Modular designs and factory fitted extras make installation easier to achieve.

• Provide much more than just an installation service: special settings available for installers to improve system comfort and reliability.

• Sky Air range: a solution that meets all your customer’s needs, from high specifications, tailor-made solutions to basic cooling and heating.

Benefits for

consultant and design offices

• You will have the confidence of knowing that you can recommend the right climate control systems to meet tomorrow’s legislation.

• You will have systems that are designed to blend into any décor and provide optimal performance with top seasonal efficiencies.

• Our systems allow flexibility for you by having access to innovative technology and a wide range of products.

• Your credentials as an eco-conscious consultant and designer will be enhanced.

• Our tools allow you to maximize building performance.

Products in the spotlight:

Seasonal Smart

Seasonal Classic

Fully flat cassette

Round flow cassette

10

10

12

14

09

Seasonal Smart and Seasonal Classic

Daikin offers a complete light commercial range, optimised to achieve top efficiency!

FCQG / FCQHG FFQ FHQ FBQ FDQ FAQ FVQ

RZQG

RZQSG

FUQ

• Enhancement in efficiency and comfort thanks to selectable and variable refrigerant temperatures.

• Suits computer room applications (EDP).

• R-22/R-407C Replacement technology has been incorporated: replacement solutions deliver major energy savings, offering rapid payback and a cost-effective upgrade solution, phased for minimal downtime.

• Guarantees operation in heating mode down to -20°C.

• A 75m pipe run to achieve longer runs for installation.

• Compatibility with D-BACS – links your unit into the wider building management system.

• R-22/R-407C Replacement technology has been incorporated: replacement solutions deliver major energy savings, offering rapid payback and a cost-effective upgrade solution, phased for minimal downtime.

• Guarantees operation in heating mode down to -15°C.

• A 50m pipe run to achieve longer runs for installation.

10

Air conditioning with smart use –

User friendly remote controller

BRC1E52A/B

A series of energy saving functions that can be individually selected

• Temperature range limit.

• Setback function.

• Presence & floor sensor settings

(available on fully flat cassette & round flow cassette).

• Setting temperature auto reset.

• Off timer.

• kWh indication (round flow cassette).

• 3 weekly timers.

Night quiet mode function

Night quiet function: max. -5 dB(A)

During night time, sound level of the outdoor unit can be reduced for a certain period by limiting the maximum compressor frequency and fan speed: starting time and ending time can be set. The night quiet function can be enabled according to enduser preferences via 2 different modes:

Mode 1: automatic mode

• Set via the remote control.

• Time of maximum temperature is memorized.

• The low operating mode will become active 8 hours* after the peak temperature in daytime and operation will return to normal after 10 hours of low noise operation*.

Mode 2: customized mode

• Starting and ending times can be set by using an external timer control (optional adapter KRP58M51.

• Field supplied timer switch required for RZQ(S)G71-140).

* Notes: For factory settings: please refer to the service manual of these units or contact your local dealer.

Variable Refrigerant Temperature

Did you know that all Daikin Sky Air systems operate with variable refrigerant temperature?

In cooling mode for example the system will automatically increase its evaporating temperature (Te) and consequently discharge temperature if the gap between the achieved indoor temperature (Tin) and the request indoor temperature (Tset) becomes smaller.

This reduces the risk of cold draft and hence increases the customer comfort.

Tin / Tset

Tin

30°C

Big gap

Tin

28°C

Tin

26°C

Smaller gap

Tset =

22°C

Time

Higher Te

Te

Low Te

UNIQUE!

Seasonal Smart even adopts a special setting to further improve comfort & efficiency by offering the possibility to customize the boundaries of the evaporating (Te) or condensing (Tc) temperature limits. The perfect solution for those people looking for an even more comfortable indoor air climate & an even further reduction of their energy bill.

Cooling

Refrigerant temperature

Heating Refrigerant temperature

Default

Te max

Improved comfort

Reduced energy bill

Customized

Te max

Te min’

Te min

Tc max

Tc min

Tc max’

Tc min

11

Fully Flat Cassette: Design & Genius in one

UNIQUE!

Unique in the market, the fully flat cassette is a remarkable blend of iconic design and engineering excellence with an elegant white or a silver and white finish. Fitting flush within the ceiling modules and fully flat with the ceiling itself, the cassette is both stylish and unobtrusive. Superb efficiency and comfort is delivered through the combined use of floor and presence sensors and, when necessary, the individual flap control via the wired remote controller makes it simple to fix the position of each flap individually, to suit any new room configuration.

Silver and white White

12

Differentiated by excellence

Sensor-driven comfort

To ensure perfect comfort the fully flat cassette is fitted with two optional sensors linked to an advanced controller.

The ‘presence’ sensor detects when there are people in the room and it adjusts the temperature to the previously selected

‘set point’ thus establishing the perfect working conditions.

When the sensor establishes that the room is empty, it can switch off the cassette so that the user is not wasting money on unnecessary heating or cooling. The sensor also adapts the direction of the airflow depending of where people are situated in the room, ensuring every individual’s comfort at any time.

Because hot air rises, the natural temperature distribution in a room is for it to be warmer near the ceiling and cooler near the floor. The cassette’s ‘floor’ sensor detects the temperature difference and re-directs the airflow to ensure that the temperature distribution is even: cold feet are history!

Fully integrated, fully discreet

The concept our designers had in mind was for an unobtrusive cassette that blends seamlessly with the décor of a modern office while meeting the demanding criteria of architects for total integration within a standard European ceiling panel, enabling lights, speakers and sprinklers to be installed in the adjoining ceiling tiles. The result is the fully flat cassette with its near flush fit, 4-way air distribution and special sensors to ensure the delivery of perfect comfort. Available in white or white and grey, the fully flat cassette is the perfect blend of design and function.

Flexible solution

The need for flexible usage of space often means that temporary or permanent barriers are erected leaving the cassette close to a wall or in a corner with the resulting imbalances in airflow. Our advanced technology anticipates this and we have made it possible to use the controller to individually control or block (use option sealing kit for 3- or 2-directional air discharge) flaps to restore optimal efficiency and to save on energy costs.

Silent comfort

The fully flat cassette is amongst the quietest units in the market.

Air quality

The quality of the air in the room is as important as the temperature and we have fitted advanced filters to remove dust particles to ensure the air is clean. In addition, a special programme allows the humidity levels to be reduced without variations in temperature. Fresh air intake for healthy living via optional kit

(KDDQ44XA60).

Intuitive control

The fully flat cassette’s advanced controller provides the user with absolute control over their work environment. From setting the desired temperature to directing the airflow, from delivering the right temperature whenever the room is in use to ensuring that cold feet are history, from reconfiguring airflow to monitoring performance, the advanced controller is simple and intuitive to use. The large display screen and on-screen instructions combined with clearly marked function buttons give users total control enabling them to quickly set their desired conditions and to focus on the job at hand.

Top efficiency year-round

As with all Daikin products, this cassette delivers exceptional seasonal efficiency while the presence sensor has been shown to reduce energy consumption by around 27%*.

By using the controller to monitor performance and energy consumption, users can reduce their environmental impact while maintaining perfect working conditions.

*estimated

013

Round Flow Cassette : setting the standard for efficiency and comfort

The round flow cassettes FCQG and FCQHG-F series are designed for use in all forms and sizes of commercial offices and retail environments and provide you with a more energy efficient model. infrared presence sensor infrared floor sensor

Even more energy efficient ….

UNIQUE!

• Daikin was the first to launch an auto cleaning Standard panel. With this panel the costs can be further reduced as the filter cleans itself automatically once a day.

• Maintenance of the filter is facilitated and so less time is required.

• Running costs are reduced compared to standard solutions: up to 50% energy can be saved thanks to daily filter cleaning (Wolverhampton, UK).

9000

8000

7000

6000

Auto-cleaning panel

4000

saves up to 50%

1000

0

9000

8000

7000

6000

5000

4000

3000

2000

1000

0

• The optional presence sensor adjusts the temperature or switches off the unit when there is nobody in the room.

Up to 27% energy can be saved with this new function.

• If no presence is detected in the room for 15mins, the set temperature is changed until a minimum temperature (for heating) or maximum temperature (for cooling) is reached.

• Newly designed heat exchanger (diameter pipes are reduced to 5mm instead of 7mm), DC fan motor and DC drain pump enable even more energy to be saved.

Presence sensor

saves up to 27%*

5000

4000

3000

2000

1000

0

Energy consumption (kWh)

Cumulative energy comparison over 12 months

9000

8000

7000

6000

(Test site, Wolverhampton, UK)

50%

difference in electricity consumption

July

August

Sept emberOct ober

No vember

December

Januar y

Februar y

Mar ch

Apr il

May June

July

Auto cleaning cassette

Standard round flow cassette

Without sensor

26°

24°

22°

Nobody in the room

Cooling

Set point: 22° CDB

20°

time

09.00

09.30 10.00 10.30 11.00 11.30 12.00 12.30 13.00 13.30 14.00 14.30 15.00 15.30 16.00 16.30 17.00

With sensor (BRC1E52A/B required)

26°

24°

22° no presence detected for 15mins

20°

time

09.00

09.30 10.00 10.30 11.00 11.30 12.00 12.30 13.00 13.30 14.00 14.30 15.00 15.30 16.00 16.30 17.00

* estimated energy saving

14

… and improved comfort

• The unique 360° air flow discharge pattern ensures a uniform temperature distribution across the room without dead corners.

The comfort can be further enhanced thanks to the optional sensors:

• The presence sensor allows air flow control. It directs the air away from any person detected in the room, when the air flow control is on.

• With the floor sensor having cold feet becomes history.

This sensor detects the average floor temperature and ensures an even temperature distribution between ceiling and floor.

Flexible installation

The round flow cassette offers higher flexibility thanks to:

• The possibility of easily closing one flap via the wired remote controller (BRC1E52A/B - optional), to suit the room configuration. Optional closure kits are available as well.

change room configuration/ refurbishment

Other features

• Standard DIII-net compatibility – link your cassette into the wider building management system.

• Fresh air intake possible (max. 20%).

15

016

Sky Air product range

Sky Air Product portfolio

Indoor units

Outdoor units

Biddle standard air curtain

Air handling units

18

20

20

20

Benefits overview Sky Air 22

Pair application

Ceiling mounted cassette

Concealed ceiling unit

Wall mounted unit

Ceiling suspended unit

4-Way blow ceiling suspended unit

Floor standing unit

24

32

40

42

46

48

Twin, triple, double twin application

Seasonal Smart 51

Seasonal Classic

Super Inverter

52

53

Multi model application

Multi outdoor units 54

VRVIII-S heat pump for residential application 55

017

Product portfolio

18

Indoor units

Type

Ceiling mounted cassette

Concealed ceiling

Wall mounted

Ceiling suspended

Floor standing

Model

High COP, round flow cassette

• for shops, restaurants and offices requiring maximum floor space and perfect integration

• 360° air discharge

• auto-cleaning function

2

• presence and floor sensor 2

• ensures top performance

Round flow cassette

• for shops, restaurants and offices requiring maximum floor space and perfect integration

• 360° air discharge

• auto-cleaning function 2

• presence and floor sensor

2

Fully flat cassette

• for smaller spaces and offices requiring maximum floor space and perfect integration

• design and genius in one

• integrate fully flat into the ceiling and flush into ceiling tiles

• presence and floor sensor 2

Siesta, 4-way blow ceiling mounted cassette

• for shops requiring maximum floor space and perfect integration

• solution for basic cooling and heating

Small concealed ceiling unit

• designed for hotel bedrooms

• compact dimensions to be mounted in a ceiling void

• drain pan can be located to the left or to the right

Concealed ceiling unit

• for commercial spaces with no or narrow false ceilings

• easy installation thanks to automatic air flow adjustment

• reduced power consumption with DC inverter fans

• ESP up to 120Pa

Concealed ceiling unit

• for commercial spaces with no or narrow false ceilings

• easy installation thanks to automatic air flow adjustment

• reduced power consumption with DC inverter fans

• ESP up to 200Pa

Large concealed ceiling unit

• for large commercial spaces with no or narrow false ceilings

• ESP up to 250Pa

Siesta, concealed ceiling unit

• for shops requiring maximum floor space and perfect integration

• solution for basic cooling and heating

Wall mounted unit

• for commercial spaces with no or narrow false ceilings

• 5 different air discharge angles

Ceiling suspended unit

• for commercial spaces with no or narrow false ceilings

• comfortable air distribution in one direction

• coanda effect: air discharge up to 100°

4-way blow ceilling suspended unit

• for commercial spaces with no or narrow false ceilings

• comfortable air distribution in four directions

• low energy consumption

• improved comfort thanks to automatic air flow adjustment to required load

Siesta, ceiling suspended cassette

• for shops with narrow or no false ceiling

• solution for basic cooling and heating

Floor standing unit

• for commercial spaces with high ceilings

• perfect comfort thanks to selection of vertical and horizontal out blow patterns

• improved efficiency thanks to DC fan motor

1) Twin, triple, double twin application is only possible up to 125 class 2) Optional

Product name

FCQHG-F

FCQG-F

FFQ-C

ACQ-C

FDBQ-B

FBQ-C8

1

FDQ-C

FDQ-B

1

ABQ-C

FAQ-C

FHQ-C

FUQ-C

AHQ-C

FVQ-C

25 35 50 60 71 100 125 140 200

Capacity (class)

250

Type

Ceiling mounted cassette

Concealed ceiling

Wall mounted

Ceiling suspended

Floor standing

Model

High COP, round flow cassette

• for shops, restaurants and offices requiring maximum floor space and perfect integration

• 360° air discharge

• auto-cleaning function

2

• presence and floor sensor 2

• ensures top performance

Round flow cassette

• for shops, restaurants and offices requiring maximum floor space and perfect integration

• 360° air discharge

• auto-cleaning function 2

• presence and floor sensor

2

Fully flat cassette

• for smaller spaces and offices requiring maximum floor space and perfect integration

• design and genius in one

• integrate fully flat into the ceiling and flush into ceiling tiles

• presence and floor sensor 2

Siesta, 4-way blow ceiling mounted cassette

• for shops requiring maximum floor space and perfect integration

• solution for basic cooling and heating

Small concealed ceiling unit

• designed for hotel bedrooms

• compact dimensions to be mounted in a ceiling void

• drain pan can be located to the left or to the right

Concealed ceiling unit

• for commercial spaces with no or narrow false ceilings

• easy installation thanks to automatic air flow adjustment

• reduced power consumption with DC inverter fans

• ESP up to 120Pa

Concealed ceiling unit

• for commercial spaces with no or narrow false ceilings

• easy installation thanks to automatic air flow adjustment

• reduced power consumption with DC inverter fans

• ESP up to 200Pa

Large concealed ceiling unit

• for large commercial spaces with no or narrow false ceilings

• ESP up to 250Pa

Siesta, concealed ceiling unit

• for shops requiring maximum floor space and perfect integration

• solution for basic cooling and heating

Wall mounted unit

• for commercial spaces with no or narrow false ceilings

• 5 different air discharge angles

Ceiling suspended unit

• for commercial spaces with no or narrow false ceilings

• comfortable air distribution in one direction

• coanda effect: air discharge up to 100°

4-way blow ceilling suspended unit

• for commercial spaces with no or narrow false ceilings

• comfortable air distribution in four directions

• low energy consumption

• improved comfort thanks to automatic air flow adjustment to required load

Siesta, ceiling suspended cassette

• for shops with narrow or no false ceiling

• solution for basic cooling and heating

Floor standing unit

• for commercial spaces with high ceilings

• perfect comfort thanks to selection of vertical and horizontal out blow patterns

• improved efficiency thanks to DC fan motor

Product name

FCQHG-F

FCQG-F

FFQ-C

ACQ-C

FDBQ-B

FBQ-C8

FDQ-C

FDQ-B

ABQ-C

FAQ-C

FHQ-C

FUQ-C

AHQ-C

FVQ-C

1

1

25 35 50 60 71 100 125 140 200

Capacity (class)

250

19

Product portfolio

Outdoor units

System Type

Pair, twin, triple & double twin application

Product name

• for commercial applications and technical rooms

• best efficiency!

• most flexible installation

• widest range of efficient and comfortable connectable indoor units

• pair, twin, triple, double twin application

Air cooled Heat pump

• for commercial applications

• good value for money

• very efficient and comfortable indoor units

• pair, twin, triple, double twin application

• for large commercial applications

• pair, twin, triple, double twin application

• for shop application

• basic cooling/heating solution

• pair application

Biddle standard air curtain range

Type Product name

Biddle standard air curtain free hanging

Biddle standard air curtain cassette

Biddle standard air curtain recessed

CYQ S/M/L-DK-F easy wall installation

CYQ S/M/L-DK-C mounted into a false ceiling leaving only the decoration panel visible

CYQ S/M/L-DK-R neatly concealed in the ceiling

For connection with air handling units and biddle air curtain

System Type Product name

ERQ-AV1 1

Condensing Units

Air cooled Heat pump

ERQ-AW1

1

Condensing Units

• R-410A inverter condensing units

• pair application with air handling units

1) Only use the condensing units in combinations with an air handling unit.

Type Product name

Heat Reclaim Ventilation

Air handling units

VAM-FA/FB

DX fresh air package

• for shops, restaurants and offices requiring maximum floor space and perfect integration

• energy saving ventilation using indoor heating

• free cooling possible

• solution where building constraints occur

• plug and play installation

RZQG-L8/7V1

RZQG-L(8)Y1

RZQSG-L3/L8V1

RZQSG-L(8)Y1

RZQ-C

AZQS-BV1

AZQS-BY1

20

(1) Daikin AHU connected to Daikin chiller solution

71 100 125 140 200 250

71 100 125 140 200

Capacity (Class)

250

0 200 400 600 800 1,000 1,500 2,000 4,000 6,000

Air flow rate (m

3

/h)

8,000 124,000

System

Air cooled

Type

Heat pump

Product name

• for commercial applications and technical rooms

• best efficiency!

• most flexible installation

• widest range of efficient and comfortable connectable indoor units

• pair, twin, triple, double twin application

• for commercial applications

• good value for money

• very efficient and comfortable indoor units

• pair, twin, triple, double twin application

• for large commercial applications

• pair, twin, triple, double twin application

• for shop application

• basic cooling/heating solution

• pair application

RZQG-L8/7V1

RZQG-L(8)Y1

RZQSG-L3/L8V1

RZQSG-L(8)Y1

RZQ-C

AZQS-BV1

AZQS-BY1

71 100 125 140 200 250

Capacity (class)

System

Air cooled

Type

Heat pump

Product name

ERQ-AV1 1

Condensing Units

ERQ-AW1

1

Condensing Units

• R-410A inverter condensing units

• pair application with air handling units

Type

Heat Reclaim Ventilation

Product name

VAM-FA/FB

Air handling units

DX fresh air package

• for shops, restaurants and offices requiring maximum floor space and perfect integration

• energy saving ventilation using indoor heating

• free cooling possible

• solution where building constraints occur

• plug and play installation

Door height (m)

3

2.3m

2.5m

2

3.0m

2.15m

2.4m

2.75m

2.0m

2.3m

2.5m

1

S M L

S M L

Favourable ex: covered shopping mall or revolving door entrance

S M L

S M L

Normal ex: little direct wind, no opposite open doors, building with ground floor only

S M L

L

S M

Unfavourable ex: location at a corner or square, multiple floors and / or open stairwell

Installation condition

71 100 125 140 200

Capacity (Class)

250

0 200 400 600 800 1,000 1,500 2,000 4,000 6,000

Air flow rate (m

3

/h)

8,000 124,000

(1)

21

Benefits overview

INVERTER

Seasonal efficiency - Smart use of energy

Inverter technology

Home leave operation

Fan only

Auto cleaning filter

Floor and presence sensor

Draught prevention

Whisper quiet

Auto cooling-heating changeover

Seasonal efficiency gives a more realistic indication on how efficient air conditioners operate over an entire heating or cooling season.

In combination with inverter controlled outdoor units

During absence, the indoor temperature can be maintained at a certain level.

The air conditioner can be used as fan, blowing air without cooling or heating.

The filter automatically cleans itself once per day. Simplicity of upkeep means optimum energy efficiency and maximum comfort without the need for expensive or time-consuming maintenance.

The presence sensor directs the air away from any person detected in the room, when the air flow control is on. The floor sensor detects the average floor temperature and ensures an even temperature distribution between ceiling and floor.

When starting to warm up or when the thermostat is off, the air discharge direction is set horizontally and the fan to low speed, to prevent draught. After warming up, air discharge and fan speed are set as desired.

Daikin indoor units are whisper quiet. Also the outdoor units are guaranteed not to disturb the quiet of the neightbourhood.

Automatically selects cooling or heating mode to achieve the set temperature.

Air filter

Removes airborne dust particles to ensure a steady supply of clean air.

 

 

   

  

             

Dry programme

22

Ceiling soiling prevention

Vertical auto swing

Fan speed steps

Individual flap control

Weekly timer

Infrared remote control

Wired remote control

Centralised control

Auto-restart

Self-diagnosis

Drain pump kit

Twin/triple/double twin application

Multi model application

VRV for residential application

For explanation on the benefits, see the end of this catalogue.

Allows humidity levels to be reduced without variations in room temperature.

          

A special function prevents air blowing out too long in horizontal position, to prevent ceiling stains.

Possibility to select automatic vertical moving of the air discharge louvre, for uniform air flow and temperature distribution.

Allows to select up to the given number of fan speed.

Individual flap control via the wired remote controller makes it simple to fix the position of each flap individually, to suit any new room configuration. Optional closure kits are available as well.

Timer can be set to start operation anytime on a daily or weekly basis

Infrared remote control with LCD to start, stop and regulate the air conditioner from a distance.

Wired remote control to start, stop and regulate the air conditioner from a distance.

Centralised control to start, stop and regulate several air conditioners from one central point.

The unit restarts automatically at the original settings after power failure.

Simplifies maintenance by indicating system faults or operating anomalies.

Facilitates condensation draining from the indoor unit.

2, 3 or 4 indoor units can be connected to only 1 outdoor unit even if they have different capacities. All indoor units operate within the same mode (cooling or heating) from one remote control.

Up to 5 indoor units (even different capacities) can be connected to a single outdoor unit. All indoor units can individually be operated within the same mode.

Up to 9 indoor units (even different capacities and up to 71 class) can be connected to a single outdoor unit.

All indoor units can individually be operated within the same mode.

3

3

3

4 2 3 3 2 3

3 3

3

3

3

    optional optional optional standard

  optional

       optional standard optional optional

 optional optional optional optional optional optional optional optional standard optional optional optional optional optional optional optional optional optional optional optional optional optional optional optional

   

    standard standard standard standard

  

 

  standard standard

 

 optional

 

  standard optional

 

Seasonal efficiency - Smart use of energy

Inverter technology

Home leave operation

Fan only

Auto cleaning filter

Floor and presence sensor

Draught prevention

Whisper quiet

Auto cooling-heating changeover

Seasonal efficiency gives a more realistic indication on how efficient air conditioners operate over an entire heating or cooling season.

In combination with inverter controlled outdoor units

During absence, the indoor temperature can be maintained at a certain level.

The air conditioner can be used as fan, blowing air without cooling or heating.

The filter automatically cleans itself once per day. Simplicity of upkeep means optimum energy efficiency and maximum comfort without the need for expensive or time-consuming maintenance.

The presence sensor directs the air away from any person detected in the room, when the air flow control is on. The floor sensor detects the average floor temperature and ensures an even temperature distribution between ceiling and floor.

When starting to warm up or when the thermostat is off, the air discharge direction is set horizontally and the fan to low speed, to prevent draught. After warming up, air discharge and fan speed are set as desired.

Daikin indoor units are whisper quiet. Also the outdoor units are guaranteed not to disturb the quiet of the neightbourhood.

Automatically selects cooling or heating mode to achieve the set temperature.

Air filter

Removes airborne dust particles to ensure a steady supply of clean air.

Ceiling mounted cassette Concealed ceiling unit

Ceiling suspended unit

4-Way blow ceiling suspended unit

Wall mounted unit

Floor standing unit

FCQHG-F FCQG-F FFQ-C ACQ-C FDBQ-B FBQ-C8 FDQ-C FDQ-B ABQ-C FHQ-C AHQ-C FUQ-C FAQ-C FVQ-C

 

 

   

 

             

Dry programme

Ceiling soiling prevention

Vertical auto swing

Fan speed steps

Individual flap control

Weekly timer

Infrared remote control

Wired remote control

Centralised control

Auto-restart

Self-diagnosis

Drain pump kit

Twin/triple/double twin application

Multi model application

VRV for residential application

Allows humidity levels to be reduced without variations in room temperature.

          

A special function prevents air blowing out too long in horizontal position, to prevent ceiling stains.

Possibility to select automatic vertical moving of the air discharge louvre, for uniform air flow and temperature distribution.

Allows to select up to the given number of fan speed.

Individual flap control via the wired remote controller makes it simple to fix the position of each flap individually, to suit any new room configuration. Optional closure kits are available as well.

Timer can be set to start operation anytime on a daily or weekly basis

Infrared remote control with LCD to start, stop and regulate the air conditioner from a distance.

Wired remote control to start, stop and regulate the air conditioner from a distance.

Centralised control to start, stop and regulate several air conditioners from one central point.

The unit restarts automatically at the original settings after power failure.

Simplifies maintenance by indicating system faults or operating anomalies.

Facilitates condensation draining from the indoor unit.

2, 3 or 4 indoor units can be connected to only 1 outdoor unit even if they have different capacities. All indoor units operate within the same mode (cooling or heating) from one remote control.

Up to 5 indoor units (even different capacities) can be connected to a single outdoor unit. All indoor units can individually be operated within the same mode.

Up to 9 indoor units (even different capacities and up to 71 class) can be connected to a single outdoor unit.

All indoor units can individually be operated within the same mode.

3

3

3

4 2 3 3 2 3

3 3

3

3

3

    optional optional optional standard

  optional

       optional standard optional optional

 optional optional optional optional optional optional optional optional standard optional optional optional optional optional optional optional optional optional optional optional optional optional optional optional

   

    standard standard standard standard

  

 

  standard standard

 

 optional

 

  standard optional

 

23

24

FCQG-F / RXS-L

Round flow cassette

UNIQUE!

FCQG35-60F presence sensor floor sensor

BRYQ140A RXS-L BRC1E52A/B

(optional)

BRC7F532F

(optional)

The round flow cassette provides a more comfortable environment and offers greater savings in energy consumption to shop, office and restaurant owners

360° air discharge ensures uniform air flow and temperature distribution

Modern style decoration panel is available in 3 different variations: pure white (RAL9010) auto cleaning panel, pure white (RAL9010) standard panel with grey louvers and pure white (RAL9010) standard panel with white louvers

Daikin introduces first auto cleaning cassette to European market.

Higher efficiency and comfort thanks to daily auto cleaning of the filter.

Lower maintenance costs thanks to auto cleaning function.

Easy dust removal with vacuum cleaner without opening the unit.

The presence sensor (optional) : adjusts the temperature or switches off the unit when there is nobody in the room - ensures the air flow is directed away from any person detected in the room, when the air flow control is activated

The floor sensor (optional) detects the average floor temperature and ensures even temperature distribution between ceiling and floor. Cold feet will become history.

Individual flap control: possibility to adapt the room layout by fixing the positon of each flap individually

Fresh air intake: up to 20 %

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling kW kW

Min./Nom./Max.

kW

Min./Nom./Max.

kW

Energy label

Pdesign kW

SEER

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Dimensions

Weight

Heating

(Average climate)

Unit

Unit

Decoration panel Model

Colour

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

HeightxWidthxDepth mm kg

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

Heating

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm kg

High/Nom./Low m³/min

High/Nom./Low m³/min

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage dBA dBA dBA dBA mm mm

Hz / V

FCQG35F

1.3/3.4/4.0

1.3/4.20/5.2

0.400/0.950/1.100

0.230/1.200/1.840

3.50

6.35

193

3.32

4.90

949

3.58

3.50

475

A/B

18

12.5/10.6/8.7

12.5/10.6/8.7

9.5

FCQG50F

1.7/5.0/5.3

1.7/6.00/6.0

-/1.410/-

-/1.620/-

A++

5.00

6.48

270

A++

19

BYCQ140D7W1/BYCQ140D7W1W/BYCQ140D7GW1

Pure White (RAL 9010)/

60x950x950/950x60x950/145x950x950

5.4/5.4/10.3

12.6/10.7/8.7

12.6/10.7/8.7

49

49

31/29/27

31/29/27

4.36

4.29

1,426

3.55

3.7

705

A/A

204x840x840

6.35

12.70

1~ / 50 / 220-240

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

HeightxWidthxDepth mm

High/Super low

High/Super low kg m³/min m³/min

Sound pressure level

Heating

Cooling

Heating

Operation range Cooling

Refrigerant

Piping connections

Heating

Type/GWP

Piping length dBA dBA

High/Low/Silent operation dBA

High/Low/Silent operation dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

RXS35L

550x765x285

34

36.0/30.1

28.3/25.6

61

61

48/-/44

48/-/45

20

15

1~ / 50 / 220-240

RXS50L

47

50.9/48.9

45.0/43.1

48/44/-

48/45/-

-10~46

-15~18

R-410A/1,975

-

735x825x300

62

62

30

20.0

1~ / 50 / 220-230-240

FCQG60F

1.7/5.7/5.7

1.7/7.0/7.0

-/1.640/-

-/1.990/-

5.70

6.22

321

A+

4.71

4.00

1,646

3.48

3.52

820

A/B

13.6/11.2/8.7

13.6/11.2/8.7

51

51

33/31/28

33/31/28

RXS60L

48

50.2/45.0

46.3/46

49/46/-

49/46/-

(1) EER/COP according to Eurovent 2012, for use outside EU only (2) The BYCQ140D7W1W has white insulations. Be informed that formation of dirt on white insulation is visibly stronger and that it is consequently not advised to install the BYCQ140D7W1W decoration panel in environments exposed to concentrations of dirt. (3) BYCQ140D7W1: pure white standard panel with grey louvers; BYCQ140D7W1W: pure white standard panel with white louvers; BYCQ140D7GW1: pure white auto cleaning panel.

25

FCQG-F / RZQG-L8/7V1/L(8)Y1

Round flow cassette

FCQG100-140F presence sensor floor sensor

BRYQ140A RZQG100-140L8/7V1/L(8)Y1 BRC1E52A/B

(optional)

BRC7FA532F

(optional)

UNIQUE!

The round flow cassette provides a more comfortable environment and offers greater savings in energy consumption to shop, office and restaurant owners

360° air discharge ensures uniform air flow and temperature distribution

Modern style decoration panel is available in 3 different variations: pure white (RAL9010) auto cleaning panel, pure white (RAL9010) standard panel with grey louvers and pure white (RAL9010) standard panel with white louvers

Daikin introduces first auto cleaning cassette to European market.

Higher efficiency and comfort thanks to daily auto cleaning of the filter.

Lower maintenance costs thanks to auto cleaning function.

Easy dust removal with vacuum cleaner without opening the unit.

The presence sensor (optional) : adjusts the temperature or switches off the unit when there is nobody in the room - ensures the air flow is directed away from any person detected in the room, when the air flow control is activated

The floor sensor (optional) detects the average floor temperature and ensures even temperature distribution between ceiling and floor. Cold feet will become history.

Individual flap control: possibility to adapt the room layout by fixing the positon of each flap individually

Fresh air intake: up to 20 %

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Dimensions

Weight

EER

COP

Annual energy consumption

Energy label Cooling/Heating

Unit

Unit

Decoration panel Model

Colour kWh

HeightxWidthxDepth mm kg

FCQG71F

-/6.8/-

-/7.5/-

2.01

1.89

6.80

350

A+

6.33

4.20

2,110

3.39

3.97

1,005

204x840x840

21

A++

6.80

FCQG100F

-/9.5/-

-/10.8/-

2.45

2.60

9.50

488

A++

11.30

4.61

3,431

3.87

4.15

1,225

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

Heating

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm

High/Nom./Low m³/min 15.0/12.1/9.1 22.8/17.6/12.4

High/Nom./Low m³/min 15.0/12.1/9.1 22.8/17.6/12.4

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage kg dBA dBA dBA dBA mm mm

Hz / V

51

51

33/31/28

33/31/28

54

54

37/33/29

37/33/29

FCQG125F

-/12.0/-

-/13.5/-

3.22

3.72

A+

12.00

6.00

700

A+

12.66

4.10

4,322

3.73

3.63

1,610

FCQG140F

-/13.4/-

-/15.5/-

4.17

4.30

-

-

-

-

-

-

-

-

3.21

3.61

2,085

FCQG71F

-/6.8/-

-/7.5/-

2.01

1.89

6.80

350

A+

6.33

4.20

2,110

3.39

3.97

1,005

A++

6.80

FCQG100F

-/9.5/-

-/10.8/-

2.45

2.60

9.50

246x840x840

24

A/A

204x840x840

21

BYCQ140D7W1/BYCQ140D7W1W/BYCQ140D7GW1

Pure White (RAL 9010)

60x950x950/950x60x950/145x950x950

26.0/19.2/12.4

26.0/19.2/12.4

58

58

41/35/29

41/35/29

5.4/5.4/10.3

15.0/12.1/9.1 22.8/17.6/12.4

15.0/12.1/9.1 22.8/17.6/12.4

51

51

33/31/28

33/31/28

54

54

37/33/29

37/33/29

9.52

15.9

1~ / 50 / 220-240

488

A++

11.30

4.61

3,431

3.87

4.15

1,225

FCQG125F

-/12.0/-

-/13.5/-

3.22

3.72

A+

12.00

6.00

700

A+

12.66

4.10

4,322

3.73

3.63

1,610

246x840x840

24

26.0/19.2/12.4

26.0/19.2/12.4

58

58

41/35/29

41/35/29

FCQG140F

-/13.4/-

-/15.5/-

4.17

4.30

-

-

-

-

3.21

3.61

2,085

-

-

-

-

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Heating

Cooling

Heating

Nom.

Nom.

Night quiet mode Level 1

Operation range Cooling

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA dBA dBA dBA

Ambient Min.~Max. °CDB

Refrigerant

Piping connections

Heating

Type/GWP

Piping length

Ambient Min.~Max. °CWB

OU - IU Max.

m

System Equivalent m

Power supply

Current - 50Hz

Level difference IU - OU Max.

IU - IU Max.

Phase / Frequency / Voltage

Maximum fuse amps (MFA) m m

Hz / V

A

RZQG71L8V1 RZQG100L8V1 RZQG125L8V1 RZQG140L7V1 RZQG71L8Y1 RZQG100L8Y1 RZQG125L8Y1 RZQG140LY1

990x940x320 1,430x940x320 990x940x320 1,430x940x320

78

59 70

102

84

80

59 70

101

84

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

-15~50

-20~15.5

R-410A/1,975

50

70

75

90

50

70

75

90

30.0

0.5

20

1~ / 50 / 220-240

32 16

3N~ / 50 / 380-415

20

(1) EER/COP according to Eurovent 2012 (2) The BYCQ140D7W1W has white insulations. Be informed that formation of dirt on white insulation is visibly stronger and that it is consequently not advised to install the BYCQ140D7W1W decoration panel in environments exposed to concentrations of dirt. (3) BYCQ140D7W1: pure white standard panel with grey louvers; BYCQ140D7W1W: pure white standard panel with white louvers; BYCQ140D7GW1: pure white auto cleaning panel.

26

FCQG-F / RZQSG-L(3/8)V1/L(8)Y1

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Dimensions

Weight

EER

COP

Annual energy consumption

Energy label Cooling/Heating

Unit

Unit

Decoration panel Model

Colour kWh

HeightxWidthxDepth mm kg

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

Heating

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm kg

High/Nom./Low m³/min

High/Nom./Low m³/min

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage dBA dBA dBA dBA mm mm

Hz / V

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound pressure level

Heating

Sound power level Cooling

Cooling

Heating

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min

Nom./Silent operation dBA

Nom.

Night quiet mode Level 1 dBA dBA dBA

Operation range Cooling

Heating

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Refrigerant

Piping connections

Type/GWP

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

FCQG71F

-/6.8/-

-/7.5/-

2.12

2.08

6.80

6.10

390

6.33

2,162

3.21

3.61

1,060

A/A

204x840x840

21

15.0/12.1/9.1

15.0/12.1/9.1

51

51

33/31/28

33/31/28

A++

4.10

FCQG100F

-/9.5/-

-/10.8/-

2.88

3.05

9.50

6.50

511

A+

7.60

2,595

3.30

3.54

1,440

22.8/17.6/12.4

22.8/17.6/12.4

54

54

37/33/29

37/33/29

A/B

FCQG125F

-/12.0/-

-/13.5/-

3.74

3.96

A

12.00

5.30

792

8.03

4.01

2,803

3.21

1,870

3.41

FCQG140F

-/13.4/-

-/15.5/-

4.45

4.54

-

-

-

-

-

-

-

-

3.01

7.60

4.10

2,595

3.30

2,225

B/B

246x840x840

24

3.54

1,440

FCQG100F

-/9.5/-

-/10.8/-

2.88

3.05

A++

9.50

6.50

511

BYCQ140D7W1/BYCQ140D7W1W/BYCQ140D7GW1

Pure White (RAL 9010)

60x950x950/950x60x950/145x950x950

5.4/5.4/10.3

26.0/19.2/12.4

26.0/19.2/12.4

58

58

41/35/29

41/35/29

22.8/17.6/12.4

22.8/17.6/12.4

54

54

37/33/29

37/33/29

9.52

15.9

1~ / 50 / 220-240

A+

A/B

FCQG125F

-/12.0/-

-/13.5/-

3.74

3.96

A

12.00

5.30

792

8.03

4.01

2,803

3.21

1,870

3.41

26.0/19.2/12.4

26.0/19.2/12.4

58

58

41/35/29

41/35/29

2,225

B/B

RZQSG71L3V1 RZQSG100L8V1 RZQSG125L8V1 RZQSG140LV1 RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1

770x900x320 990x940x320 1,430x940x320 990x940x320 1,430x940x320

67

52 76

81

77

102

83 76

82

77

101

83

83 62 83 48

65

49/47

51

69

53/49

57

-

70

54/49

58

53/49

54

69

53/-

57

70

54/-

58

49

62

69

53/-

54

-15~46

-15~15.5

R-410A/1,975

50

40 70

30

0.5

20

1~ / 50 / 220-240

32

3N~ / 50 / 380-415

20

FCQG140F

-/13.4/-

-/15.5/-

4.45

4.54

-

-

-

-

-

-

-

-

3.01

(1) EER/COP according to Eurovent 2012, for use ouside EU only. The BYCQ140D7W1W has white insulations. Be informed that formation of dirt on white insulation is visibly stronger and that it is consequently not advised to install the BYCQ140D7W1W decoration panel in environments exposed to concentrations of dirt. (3) BYCQ140D7W1: pure white standard panel with grey louvers; BYCQ140D7W1W: pure white standard panel with white louvers; BYCQ140D7GW1: pure white auto cleaning panel.

27

FCQHG-F / RZQG-L8/7V1/L(8)Y1

High COP, round flow cassette

UNIQUE!

presence sensor floor sensor

FCQHG71-140F BRYQ140A RZQG100-140L8/7V1/L(8)Y1 BRC1E52A/B

(optional)

BRC7FA532F

(optional)

High COP cassette ensures top energy performance

The round flow cassette provides a more comfortable environment and offers greater savings in energy consumption to shop, office and restaurant owners

360° air discharge ensures uniform air flow and temperature distribution

Modern style decoration panel is available in 3 different variations: pure white (RAL9010) auto cleaning panel, pure white (RAL9010) standard panel with grey louvers and pure white (RAL9010) standard panel with white louvers

Daikin introduces first auto cleaning cassette to European market.

Higher efficiency and comfort thanks to daily auto cleaning of the filter.

Lower maintenance costs thanks to auto cleaning function.

Easy dust removal with vacuum cleaner without opening the unit.

The presence sensor (optional) : adjusts the temperature or switches off the unit when there is nobody in the room - ensures the air flow is directed away from any person detected in the room, when the air flow control is activated

The floor sensor (optional) detects the average floor temperature and ensures even temperature distribution between ceiling and floor. Cold feet will become history.

Individual flap control: possibility to adapt the room layout by fixing the positon of each flap individually

Fresh air intake: up to 20 %

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Dimensions

Weight

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

EER

COP

Unit

Unit

Decoration panel Model

Colour

Dimensions

Fan - Air flow rate Cooling

Heating

Nom.

Nom.

Energy label

Pdesign

SEER

Annual energy consumption kWh

Energy label

Pdesign

SCOP

Annual energy consumption

Energy label Cooling/Heating kW kW kW kW kW kW

Annual energy consumption kWh kWh

FCQHG71F FCQHG100F FCQHG125F FCQHG140F

-/6.8/-

-/7.5/-

1.66

1.56

6.80

340

A+

7.60

4.54

2,343

4.09

4.80

830

7.00

-/9.5/-

-/10.8/-

2.15

2.16

A++

9.50

475

11.30

4.80

3,295

4.42

4.99

1,075

A++

-/12.0/-

-/13.5/-

3.00

3.07

12.00

6.61

635

12.66

4.63

3,829

4.00

4.40

1,500

-/13.4/-

-/15.5/-

4.00

3.77

-

FCQHG71F FCQHG100F FCQHG125F FCQHG140F

-/6.8/-

-/7.5/-

1.66

1.56

-

-

-

6.80

-

-

-

3.35

4.12

2,000

A/A

288x840x840

340

A+

7.60

4.54

2,343

4.09

4.80

830

7.00

-/9.5/-

-/10.8/-

2.15

2.16

A++

9.50

475

11.30

4.80

3,295

4.42

4.99

1,075

A++

-/12.0/-

-/13.5/-

3.00

3.07

12.00

6.61

635

12.66

4.63

3,829

4.00

4.40

1,500

-/13.4/-

-/15.5/-

4.00

3.77

-

-

-

-

-

-

-

-

3.35

4.12

2,000

HeightxWidthxDepth mm kg 25 26 25

BYCQ140D7W1/BYCQ140D7W1W/BYCQ140D7GW1

26

HeightxWidthxDepth mm

Pure White (RAL 9010)

60x950x950 / 950x60x950 / 145x950x950

High/Nom./Low m³/min 21.2/16.7/12.2 32.3/25.7/19.0 33.5/26.7/19.9 33.5/27.3/21.1 21.2/16.7/12.2 32.3/25.7/19.0 33.5/26.7/19.9 33.5/27.3/21.1

High/Nom./Low m³/min 21.2/16.7/12.2 32.3/25.7/19.0 33.5/26.7/19.9 33.5/27.3/21.1 21.2/16.7/12.2 32.3/25.7/19.0 33.5/26.7/19.9 33.5/27.3/21.1

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Heating

Cooling

Heating

Liquid

Gas

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage dBA dBA dBA dBA mm mm

Hz / V

53

53

36/33/29

36/33/29

44/39/33

44/39/33

61

61

45/40/35

45/40/35

45/41/37

45/41/37

9.52

15.9

53

53

36/33/29

36/33/29

1~ / 50 / 220-240

44/39/33

44/39/33

61

61

45/40/35

45/40/35

45/41/37

45/41/37

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Refrigerant

Heating

Sound power level Cooling

Sound pressure level

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

Nom.

Nom.

kg m³/min m³/min dBA dBA dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

RZQG71L8V1 RZQG100L8V1 RZQG125L8V1 RZQG140L7V1 RZQG71L8Y1 RZQG100L8Y1 RZQG125L8Y1 RZQG140LY1

990x940x320 1,430x940x320 990x940x320 1,430x940x320

78

59 70

102

84

80

59 70

101

84

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

-15~50

-20~15.5

R-410A/1,975

50

70

75

90

50

70

75

90

30.0

0.5

20

1~ / 50 / 220-240

32 16

3N~ / 50 / 380-415

20

28

FCQHG-F / RZQSG-L(3/8)V1/L(8)Y1

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Dimensions

Weight

EER

COP

Annual energy consumption

Energy label Cooling/Heating

Unit

Unit

Decoration panel Model

Colour kWh

HeightxWidthxDepth mm kg

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

Heating

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm kg

High/Nom./Low m³/min

High/Nom./Low m³/min

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage dBA dBA dBA dBA mm mm

Hz / V

FCQHG71F

-/6.8/-

-/7.5/-

1.94

1.83

6.80

6.50

366

7.60

4.15

2,563

3.50

4.10

970

25

21.2/16.7/12.2

21.2/16.7/12.2

53

53

36/33/29

36/33/29

A++

FCQHG100F

-/9.5/-

-/10.8/-

2.57

2.51

9.50

6.70

496

A+

4.30

2,614

3.70

4.30

1,285

32.3/25.7/19.0

32.3/25.7/19.0

8.03

FCQHG125F

-/12.0/-

-/13.5/-

3.71

3.60

A

12.00

5.40

777

FCQHG140F

-/13.4/-

-/15.5/-

4.17

4.29

-

-

-

FCQHG100F

-/9.5/-

-/10.8/-

2.57

2.51

A++

9.50

6.70

496

4.10

2,741

3.23

3.75

1,855

-

-

-

-

-

3.21

3.61

2,085

4.30

2,614

3.70

4.30

1,285

A/A

288x840x840

26

BYCQ140D7W1/BYCQ140D7W1W/BYCQ140D7GW1

A+

8.03

Pure White (RAL 9010)

60x950x950/950x60x950/145x950x950

33.5/26.7/19.9

33.5/26.7/19.9

5.4/5.4/10.3

33.5/27.3/21.1

33.5/27.3/21.1

32.3/25.7/19.0

32.3/25.7/19.0

FCQHG125F

-/12.0/-

-/13.5/-

3.71

3.60

A

12.00

5.40

777

4.10

2,741

3.23

3.75

1,855

33.5/26.7/19.9

33.5/26.7/19.9

44/39/33

44/39/33

45/40/35

45/40/35

45/41/37

45/41/37

9.52

15.9

1~ / 50 / 220-240

61

61

44/39/33

44/39/33

45/40/35

45/40/35

33.5/27.3/21.1

33.5/27.3/21.1

45/41/37

45/41/37

FCQHG140F

-/13.4/-

-/15.5/-

4.17

4.29

-

-

-

-

3.21

3.61

2,085

-

-

-

-

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Refrigerant

Heating

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA

Nom./Silent operation dBA

Nom.

dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

RZQSG71L3V1 RZQSG100L8V1 RZQSG125L8V1 RZQSG140LV1 RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1

770x900x320 990x940x320 1,430x940x320 990x940x320 1,430x940x320

67

52 76

81

77

102

83 76

82

77

101

83

83 62 83 48

65

49/47

51

69

53/49

57

-

70

54/49

58

53/49

54

69

53/-

57

70

54/-

58

49

62

69

53/-

54

-15~46

-15~15.5

R-410A/1,975

50

40 70

20

1~ / 50 / 220-240

32

30

0.5

3N~ / 50 / 380-415

20

(1) EER/COP according to Eurovent 2012 , for use outside EU only (2) The BYCQ140D7W1W has white insulations. Be informed that formation of dirt on white insulation is visibly stronger and that it is consequently not advised to install the BYCQ140D7W1W decoration panel in environments exposed to concentrations of dirt. (3) BYCQ140D7W1: pure white standard panel with grey louvers; BYCQ140D7W1W: pure white standard panel with white louvers; BYCQ140D7GW1: pure white auto cleaning panel.

29

FFQ-C / RXS-L

UNIQUE!

Fully flat cassette

30

FFQ-C (white panel) FFQ-C (silver and white panel) RXS-L BRC1E52A/B

(optional)

BRC7F530W

(optional)

Unique design in the market: integrates fully flat into the ceiling and fits flush into architectural ceiling modules

Remarkable blend of iconic design and engineering excellence with an elegant finish in white or a combination of silver and white

The presence sensor (optional) adjusts the set point with standard 1°C if no one is detected in the room, it is possible to adjust the set point with 2, 3 or 4°C (optional). It also automatically directs air flow away from any person to avoid draught.

The floor sensor (optional) detects the average floor temperature and ensures even temperature distribution between ceiling and floor. Cold feet will become history.

Individual flap control: possibility to adapt the room layout by fixing the positon of each flap individually

Low energy consumption thanks to specially developed small tube heat exchanger, DC fan motor and drain pump

Fresh air intake for healthy living

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling kW kW

Min./Nom./Max.

kW

Min./Nom./Max.

kW

Energy label

Pdesign kW

SEER

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Dimensions

Weight

Heating

(Average climate)

Unit

Unit

Decoration panel Model

Colour

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

HeightxWidthxDepth mm kg

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low kg m³/min m³/min

Sound power level Cooling

Sound pressure level

Cooling

Heating

Piping connections

Power supply

High/Nom./Low dBA dBA

Liquid

Gas

High/Nom./Low dBA

OD

OD

Phase / Frequency / Voltage mm mm

Hz / V

FFQ25C

1.4/2.50/4.0

1.3/3.20/5.1

0.360/0.560/1.470

0.300/0.820/1.650

2.50

6.11

143

2.31

4.24

763

4.46

3.90

280

A/A

9/8/6.5

9/8/6.5

48

31/28.5/25

31/28.5/25

A++

A+

16

9.5

FFQ35C

1.4/3.4/4.0

1.3/4.20/5.1

0.360/0.920/1.470

0.300/1.200/1.650

3.40

6.32

188

3.10

4.10

1,059

3.70

3.50

460

BYFQ60CW/BYFQ60CS/BYFQ60B2

White (N9.5)/White (N9.5) + Silver/White (RAL9010)

46x620x620/620x46x620/55x700x700

2.8/2.8/2.7

10/8.5/6.5

10/8.5/6.5

51

34/30.5/25

34/30.5/25

12/10/7.5

12/10/7.5

56

39/34/27

39/34/27

6.35

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

HeightxWidthxDepth mm

High/Super low

High/Super low kg m³/min m³/min

Heating

Cooling

Heating dBA dBA

High/Low/Silent operation dBA

Sound pressure level

Operation range Cooling

Heating

Refrigerant

Piping connections

High/Low/Silent operation dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Type/GWP

Piping length OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

RXS25L

33.5/30.1

59

59

46/-/43

47/-/44

(1) EER/COP according to Eurovent 2012, for use outside EU only (2) Dimensions do not include control box

-

-

550x765x285

34

28.3/25.6

1~ / 50 / 220-240

RXS35L

36.0/30.1

61

61

48/-/44

48/-/45

20

15

A/B

260x575x575

1~ / 50 / 220-240

-10~46

-15~18

R-410A/1,975

-

FFQ50C

1.7/5.0/5.3

1.7/5.8/6.0

-/1.560/-

-/1.660/-

5.00

593.00

295

A

3.84

3.90

1,378

3.21

3.49

780

RXS50L

47

50.9/48.9

45.0/43.1

48/44/-

48/45/-

A+

17.5

12.7

735x825x300

62

62

30

20.0

1~ / 50 / 220-230-240

FFQ60C

1.7/5.7/6.5

1.7/7.0/8.0

-/1.890/-

-/2.050/-

14.5/12.5/9.5

14.5/12.5/9.5

60

43/40/32

43/40/32

RXS60L

48

50.2/45.0

46.3/46

49/46/-

49/46/-

5.70

5.71

349

A+

3.96

4.04

1,373

3.02

3.41

945

B/B

ACQ-C / AZQS-BV1/BY1

Siesta, 4-way blow ceiling mounted cassette

ACQ71C AZQS71BV1 ARCWLA

Ideal solution for shops, restaurants or offices requiring maximum floor space for furniture, decorations and fittings

Air can be discharged in any of 4 directions

Air filter removes airborne dust particles to ensure a steady supply of clean air

Easy installation and maintenance

Control several indoor units at the same time via the Siesta Sky Air group control (optional)

Standard drain pump

Fresh air intake: up to 20 %

Heating & Cooling

Indoor unit

Cooling capacity Min./Nom./Max.

Heating capacity Min./Nom./Max.

Power input Cooling

Dimensions

Weight

Unit

Unit

Decoration panel Colour

Dimensions

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

ACQ71C

-/6.8/-

-/7.50/-

2.05

2.08

ACQ100C

-/9.5/-

-/10.80/-

2.96

2.99

ACQ125C

-/12.1/-

-/13.5/-

4.02

3.96

ACQ71C

-/6.8/-

-/7.50/-

2.05

2.08

1,025

B/A

265x820x820

31

ACQ100C

-/9.5/-

-/10.8/-

2.96

2.99

ACQ125C

-/12.1/-

-/13.5/-

4.02

3.96

Seasonal efficiency

(according to

EN14825)

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Heating

Cooling

Heating

(Average climate)

EER

COP

Energy label

Weight

Fan - Air flow rate Cooling

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Annual energy consumption

Cooling/Heating kWh

HeightxWidthxDepth mm kg

6.80

512

6.33

2,332

3.31

1,025

B/A

265x820x820

31

B

4.65

A

3.80

3.61

9.50

716

7.60

2,800

3.21

1,480

A/A

300x820x820

39

-

-

-

-

-

-

-

3.01

3.41

2,010

B/B

6.80

512

6.33

2,332

3.31

B

4.65

A

3.80

3.61

9.50

716

7.60

2,800

3.21

1,480

A/A

300x820x820

39

-

-

-

-

-

-

-

3.01

3.41

2,010

B/B

HeightxWidthxDepth mm kg

White

82x990x990

4

High/Nom./Low/Silent operation m³/min 24.4/20.5/17.6/15.0 29.2/24.4/21.0/17.6 34.0/29.2/26.3/22.1 24.4/20.5/17.6/15.0 29.2/24.4/21.0/17.6 34.0/29.2/26.3/22.1

Heating

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Heating

Cooling

Heating

Liquid

Gas

High/Nom./Low/Silent operation m³/min dBA dBA

High/Nom./Low/Silent operation dBA

High/Nom./Low/Silent operation dBA

OD

OD

Phase / Frequency / Voltage mm mm

Hz / V

24.4/20.5/17.6/15.0 29.2/24.4/21.0/17.6 34.0/29.2/26.3/22.1 24.4/20.5/17.6/15.0 29.2/24.4/21.0/17.6 34.0/29.2/26.3/22.1

54

54

41/38/35/32

41/38/35/32

57

56

44/41/38/36

44/41/38/36

60

60

47/44/43/41

47/44/43/41

9.52

15.88

54

54

41/38/35/32

41/38/35/32

1~ / 50 / 220-240

57

56

44/41/38/36

44/41/38/36

60

60

47/44/43/41

47/44/43/41

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound pressure level

Heating

Sound power level Cooling

Cooling

Heating

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min

Nom./Silent operation dBA

Nom.

Night quiet mode Level 1 dBA dBA dBA

Operation range Cooling

Heating

Refrigerant

Piping connections

Type/GWP

Piping length

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

OU - IU Max.

m

System Equivalent m

Power supply

Current - 50Hz

Level difference IU - OU Max.

IU - IU Max.

Phase / Frequency / Voltage

Maximum fuse amps (MFA) m m

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

AZQS71BV1

770x900x320

67

52.0

48.0

65

48/43

50

-

-5.0~46.0

-15.0~15.5

30

40

15.0

-

20

AZQS100BV1

76

70

53/-

57

1~ / 50 / 220-240

81

AZQS125BV1

990x940x320

AZQS100BY1

77

83

71

54/-

58

R-410A/1,975

49

-5~46

-15~15.5

50

70

30.0

0.5

-

76

70

53/-

57

82

AZQS125BY1

3N~ / 50 / 380-415

77

71

54/-

58

31

FBQ-C8 / RZQG-L8/7V1/L(8)Y1

Concealed ceiling unit with inverter driven fan

32

FBQ100-140C8 RZQG100-140L8/7V1/L(8)Y1 BRC1E52A/B

(optional)

BRC4C65

(optional)

Blends unobtrusively with any interior décor: only the suction and discharge grilles are visible

Easy installation thanks to automatic air flow adjustment towards nominal air flow rate

Reduction in power consumption thanks to DC inverter fans

Possibility to change ESP via wired remote control allows optimisation of the supply air volume

Up to 120Pa external static pressure facilitates using flexible ducts of variying lengths: ideal for shops and medium size offices

Whisper quiet operation: down to 29dBA sound pressure level

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

The air suction direction can be altered from rear to bottom suction

Standard built-in drain pump increases reliability of the drain system

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating

Casing

Dimensions

Colour

Unit

Required ceiling void >

Weight Unit kWh

HeightxWidthxDepth mm mm kg

Decoration panel Model

Colour

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Fan - External static pressure High/Nom.

Sound power level Cooling

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm

High/Low

High/Low

High/Low

High/Low

OD

OD

Phase / Frequency / Voltage kg m³/min m³/min

Pa dBA dBA dBA mm mm

Hz / V

300x1,000x700

34

BYBS71DJW1

55x1,100x500

4.5

18/15

18/15

100/30

57

37/29

37/29

389

A+

6.00

4.01

2,094

3.50

3.65

970

FBQ71C8

-/6.8/-

-/7.5/-

1.94

2.05

A++

6.80

6.11

9.50

5.80

573

A++

11.30

4.61

3,431

3.89

4.21

1,220

FBQ100C8

-/9.5/-

-/10.8/-

2.44

2.57

32/23

32/23

120/40

61

38/32

38/32

A+

FBQ125C8

-/12.0/-

-/13.5/-

3.15

3.53

12.00

5.81

722

A+

12.71

4.21

4,226

3.81

3.83

1,575

FBQ140C8

-/13.4/-

-/15.5/-

4.02

4.30

-

-

-

-

-

-

-

-

300x1,400x700

45

BYBS125DJW1

55x1,500x500

6

39/28

39/28

120/50

66

40/33

40/33

3.33

3.61

2,010

3.50

3.65

970

A/A

Not painted (galvanised)

300x1,000x700

350

34

BYBS71DJW1

White (10Y9/0.5)

55x1,100x500

41/29

4.5

18/15

18/15

100/30

41/34

57

37/29

37/29

9.52

15.9

1~ / 50/60 / 220-240/220

FBQ71C8

-/6.8/-

-/7.5/-

1.94

2.05

A++

6.80

6.11

389

A+

6.00

4.01

2,094

FBQ100C8

-/9.5/-

-/10.8/-

2.44

2.57

A+

9.50

5.80

573

A++

11.30

4.61

3,431

3.89

4.21

1,220

FBQ125C8

-/12.0/-

-/13.5/-

3.15

3.53

12.00

5.81

722

A+

12.71

4.21

4,226

3.81

3.83

1,575

32/23

32/23

120/40

61

38/32

38/32

300x1,400x700

45

BYBS125DJW1

55x1,500x500

6

39/28

39/28

40/33

120/50

66

40/33

41/29

41/34

FBQ140C8

-/13.4/-

-/15.5/-

4.02

4.30

-

-

-

-

-

-

-

-

3.33

3.61

2,010

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Refrigerant

Heating

Sound power level Cooling

Sound pressure level

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

Nom.

Nom.

kg m³/min m³/min dBA dBA dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

RZQG71L8V1 RZQG100L8V1 RZQG125L8V1 RZQG140L7V1 RZQG71L8Y1 RZQG100L8Y1 RZQG125L8Y1 RZQG140LY1

990x940x320 1,430x940x320 990x940x320 1,430x940x320

78

59 70

102

84

80

59 70

101

84

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

-15~50

-20~15.5

R-410A/1,975

50

70

75

90

50

70

75

90

30.0

0.5

20

1~ / 50 / 220-240

32 16

3N~ / 50 / 380-415

20

FBQ-C8 / RZQSG-L(8)Y1/L(3/8)V1

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating

Casing

Dimensions

Colour

Unit

Required ceiling void >

Weight Unit kWh

HeightxWidthxDepth mm mm kg

Decoration panel Model

Colour

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Fan - External static pressure High/Nom.

Sound power level Cooling

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm

High/Low

High/Low

High/Low

High/Low

OD

OD

Phase / Frequency / Voltage kg m³/min m³/min

Pa dBA dBA dBA mm mm

Hz / V

410

A

6.00

3.88

2,166

3.28

3.61

1,035

FBQ71C8

-/6.8/-

-/7.5/-

2.07

2.08

A+

6.80

5.81

300x1,000x700

34

BYBS71DJW1

55x1,100x500

4.5

18/15

18/15

100/30

57

37/29

37/29

A/A

FBQ100C8

-/9.5/-

-/10.8/-

2.87

2.96

9.50

5.50

604

A+

4.01

2,653

3.31

3.65

1,435

32/23

32/23

120/40

61

38/32

38/32

A

7.60

FBQ125C8

-/12.0/-

-/13.5/-

3.74

3.85

12.00

5.20

807

A

3.90

2,728

3.21

3.51

1,870

A/B

39/28

40/33

FBQ140C8

-/13.4/-

-/15.5/-

4.44

4.54

-

-

-

-

-

FBQ100C8

-/9.5/-

-/10.8/-

2.87

2.96

9.50

5.50

604

A+

-

-

-

3.02

3.41

2,220

B/B

Not painted (galvanised)

300x1,400x700

350

4.01

2,653

3.31

3.65

1,435

A/A

45

BYBS125DJW1

White (10Y9/0.5)

55x1,500x500

6

39/28

120/50

66

40/33

41/29

32/23

32/23

120/40

61

38/32

38/32 41/34

9.52

15.9

1~ / 50/60 / 220-240/220

A

7.60

FBQ125C8

-/12.0/-

-/13.5/-

3.74

3.85

12.00

5.20

807

A

3.90

2,728

3.21

3.51

1,870

A/B

39/28

40/33

39/28

120/50

66

40/33

FBQ140C8

-/13.4/-

-/15.5/-

4.44

4.54

-

-

-

-

-

-

-

-

3.02

3.41

2,220

B/B

41/29

41/34

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Refrigerant

Heating

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA

Nom./Silent operation dBA

Nom.

dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

RZQSG71L3V1 RZQSG100L8V1 RZQSG125L8V1 RZQSG140LV1 RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1

770x900x320 990x940x320 1,430x940x320 990x940x320 1,430x940x320

67

52 76

81

77

102

83 76

82

77

101

83

83 62 83 48

65

49/47

51

69

53/49

57

-

70

54/49

58

53/49

54

69

53/-

57

70

54/-

58

49

62

69

53/-

54

-15~46

-15~15.5

R-410A/1,975

50

40 70

30

0.5

20

1~ / 50 / 220-240

32

3N~ / 50 / 380-415

20

33

FBQ-C8 / RXS-L

Concealed ceiling unit with inverter driven fan

FBQ60C8 RXS-L BRC1E52A/B

(optional)

BRC7F530W

(optional)

Blends unobtrusively with any interior décor: only the suction and discharge grilles are visible

Easy installation thanks to automatic air flow adjustment towards nominal air flow rate

Reduction in power consumption thanks to DC inverter fans

Possibility to change ESP via wired remote control allows optimisation of the supply air volume

Up to 120Pa external static pressure facilitates using flexible ducts of variying lengths: ideal for shops and medium size offices

Whisper quiet operation: down to 29dBA sound pressure level

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

The air suction direction can be altered from rear to bottom suction

Standard built-in drain pump increases reliability of the drain system

34

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling kW kW

Min./Nom./Max.

kW

Min./Nom./Max.

kW

Energy label

Pdesign kW

SEER

Annual energy consumption kWh

Heating

(Average climate)

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Casing

Dimensions

EER

COP

Annual energy consumption

Energy label Cooling/Heating

Colour

Unit

Required ceiling void >

Weight Unit kWh

HeightxWidthxDepth mm mm kg

Decoration panel Model

Colour

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Fan - External static pressure High/Nom.

Sound power level Cooling

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm

High/Low

High/Low

High/Low

High/Low

OD

OD

Phase / Frequency / Voltage kg m³/min m³/min

Pa dBA dBA dBA mm mm

Hz / V

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

HeightxWidthxDepth mm

High/Super low

High/Super low kg m³/min m³/min

Heating

Cooling

Heating dBA dBA

High/Low/Silent operation dBA

Sound pressure level

Operation range Cooling

Heating

Refrigerant

Piping connections

High/Low/Silent operation dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Type/GWP

Piping length OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

FBQ35C8

1.4/3.40/3.9

1.3/4.00/5.0

0.490/1.060/1.490

0.270/1.110/1.760

3.50

5.97

205

A+

2.90

3.93

1,033

3.21

3.60

530

A/A

9.5

RXS35L

550x765x285

34

36.0/30.1

28.3/25.6

61

61

48/-/44

48/-/45

20

15

1~ / 50 / 220-240

FBQ50C8

1.7/5.0/5.3

1.7/5.5/6.0

-/1.650/-

-/1.610/-

A+

4.90

5.85

293

A

300x700x700

4.35

3.85

1,584

3.03

3.42

825

B/B

Not painted (galvanised)

350

25

BYBS45DJW1

White (10Y9/0.5)

55x800x500

3

16/11

16/11

100/30

63

37/29

37/29

6.35

12.7

1~ / 50/60 / 220-240/220

RXS50L

735x825x300

47

50.9/48.9

45.0/43.1

62

62

48/44/-

48/45/-

-10~46

-15~18

R-410A/1,975

30

20.0

1~ / 50 / 220-230-240

-

FBQ60C8

1.7/5.7/6.5

1.7/7.0/8.0

-/1.750/-

-/2.050/-

5.70

5.72

349

4.60

3.80

1,693

3.26

3.41

875

A/B

300x1,000x700

34

BYBS71DJW1

55x1,100x500

4.5

18/15

18/15

57

RXS60L

48

50.2/45.0

46.3/46

49/46/-

49/46/-

FDBQ-B

FDBQ25B BRC1E52A/B

(optional)

Designed for hotel bedrooms

Blends unobtrusively with any interior décor: only the suction and discharge grilles are visible

Compact dimensions (230mm high & 652mm deep), can easily be mounted in a ceiling void

Whisper quiet operation: down to 28dBA sound pressure level

The air suction direction can be altered from rear to bottom suction

For easy mounting, the drain pan can be located to the left or right of the unit

Small concealed ceiling unit

Heating & Cooling

Indoor unit

Cooling capacity Nom.

Power input

Dimensions

Weight

Cooling

Heating

Unit

Unit

Fan - Air flow rate Cooling

Heating

Nom.

Nom.

kW kW kW

HeightxWidthxDepth mm

High/Low

High/Low kg m³/min m³/min dBA Sound power level Cooling

Heating

Sound pressure level

Piping connections

Power supply

Cooling

Heating

Liquid

Gas

High/Low

High/Low

OD

OD

Drain

Phase / Frequency / Voltage dBA dBA dBA mm mm

Hz / V

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

HeightxWidthxDepth mm

High/Nom./Low

High/Low kg m³/min m³/min

Sound pressure level

Heating

Cooling

Heating

Operation range Cooling

Refrigerant

Piping connections

Heating

Type/GWP

Piping length

Nom.

Nom.

OU - IU Max.

Level difference IU - OU Max.

dBA dBA dBA dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB m m

Power supply

Current - 50Hz

IU - IU Max.

Phase / Frequency / Voltage

Maximum fuse amps (MFA) m

Hz / V

A

FDBQ25B

-

-

-

230x652x502

17,0

6,50/5,20

6,95/5,20

55

55

35,0/28,0

35,0/29,0

6,35

9,52

27,2

1~ / 50 / 230 only available in multi model application

35

FDQ-C / RZQG-L8/7V1/L(8)Y1, RZQSG-L(3/8)V1/L(8)Y1

Concealed ceiling unit

FDQ125C RZQG125L8V1/Y1 BRC1E52A/B

(optional)

Blends unobtrusively with any interior décor: only the suction and discharge grilles are visible

Easy installation thanks to automatic air flow adjustment towards nominal air flow rate

Reduction in power consumption thanks to DC inverter fans

Improved comfort thanks to 3-step air flow control

Up to 200Pa external static pressure allows extensive ductwork runs and flexible application: ideal for use in large areas

Less duct calculations are needed; moreover, the air flow can be adjusted during installation via the wired remote control (optional) instead of via channel adjustments

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

The air suction direction can be altered from rear to bottom suction

Standard drain pump with 625mm lift

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating

Casing

Dimensions

Colour

Unit

Required ceiling void >

Weight Unit kWh

HeightxWidthxDepth mm mm kg

Decoration panel Model

Colour

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Fan - External static pressure High/Nom.

Sound power level Cooling

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm

High/Low

High/Low

High/Low

High/Low

OD

OD

Phase / Frequency / Voltage kg m³/min m³/min

Pa dBA dBA dBA mm mm

Hz / V

FDQ125C

3.20

3.53

A+

5.81

722

A+

12.71

4.21

4,226

3.75

3.83

1,600

A/A

FDQ125C

-/12.0/-

-/13.5/-

12.00

Not painted (galvanised)

300x1,400x700

350

45

BYBS125DJW1

White (10Y9/0.5)

55x1,500x500

6.5

39/28

39/28

200/50

66

40/33

40/33

9.52

15.9

1~ / 50/60 / 220-240/220

FDQ125C

3.74

3.85

A

5.20

807

A

7.60

3.90

2,728

3.21

3.51

1,870

A/B

FDQ125C

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

HeightxWidthxDepth mm kg

Nom.

Nom.

m³/min m³/min

Sound power level Cooling

Sound pressure level

Cooling

Heating

Nom./Silent operation dBA

Nom.

Night quiet mode Level 1 dBA dBA dBA

Operation range Cooling

Heating

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Refrigerant

Piping connections

Type/GWP

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

36

(1) EER/COP according to Eurovent 2012 , for use outside EU only

RZQG125L8V1

1,430x940x320

RZQG125L8Y1

102

1~ / 50 / 220-240

32

70

62

67

51/-

53

45

-15~50

-20~15.5

75

90

101

3N~ / 50 / 380-415

20

R-410A/1,975

RZQSG125L8V1

990x940x320

RZQSG125L8Y1

81 82

77

83

70

54/49 54/-

58

49

-15~46

-15~15.5

50

70

30.0

0.5

1~ / 50 / 220-240

32

3N~ / 50 / 380-415

20

FDQ-B / RZQ-C

Large concealed ceiling unit

FDQ-B RZQ-C BRC1E52A/B

(optional)

Blends unobtrusively with any interior décor: only the suction and discharge grilles are visible

Up to 250Pa external static pressure allows extensive ductwork runs and flexible application: ideal for use in large areas

Up to 26.4kW in heating mode

Heating & Cooling

Indoor unit

Cooling capacity

Power input

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Min./Nom./Max.

Heating capacity Min./Nom./Max.

Cooling

Heating

EER

COP

Annual energy consumption

Casing

Dimensions

Energy label

Colour

Unit

Required ceiling void >

Nom.

Nom.

Cooling/Heating kW kW kW kW kWh

HeightxWidthxDepth mm mm

Weight Unit

Fan - Air flow rate Cooling

Heating

Fan - External static pressure High/Nom./Low

Nom.

Nom.

kg m³/min m³/min

Pa

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Cooling

Heating

Liquid

Gas

High

Low

OD

OD

Phase / Frequency / Voltage dBA dBA dBA mm mm

Hz / V

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Fan - External static pressure Max.

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min

Sound power level Cooling

Heating

Sound pressure level Nom.

Operation range Cooling

Refrigerant

Piping connections

Pa dBA dBA dBA

Heating

Type/GWP

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping length OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012 , for use outside EU only

FDQ200B

-/20.0/-

-/23.0/-

6.23

6.74

3.21

3.41

3,115

89.0

69.0

69.0

81

45.0

45.0

9.52

RZQ200C

183

-/-

Unpainted

450x1,400x900

450

250/250/250

22.2

1~ / 50 / 230

1,680x930x765

171

171

78

78

78

57

-5.0~46.0

-15.0~15.0

R-410A/1,975

100

-

3N~ / 50 / 380-415

20

FDQ250B

-/24.1/-

-/26.4/-

8.58

8.22

2.81

3.21

4,290

94.0

89.0

89.0

82

47.0

47.0

12.7

RZQ250C

184

37

ABQ-C / AZQS-BV1/BY1

Siesta, concealed ceiling unit

ABQ71C AZQS71BV1 ARCW8

(standard)

Ideal solution for shops, requiring maximum floor space for furniture, decorations and fittings

Blends unobtrusively with any interior décor: only the suction and discharge grilles are visible

Air filter removes airborne dust particles to ensure a steady supply of clean air

Easy installation and maintenance

Double-protection drainage system: primary and secondary drain pan

38

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Dimensions

Weight

Energy label

Unit

Unit

Fan - Air flow rate Cooling

Cooling/Heating

HeightxWidthxDepth mm

High/Nom./Low kWh kg m³/min

Heating High/Nom./Low m³/min

Fan - External static pressure Super high/High/Nom./Low Pa

Sound power level Cooling

Heating

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

Super high/High/Nom./Low dBA

High/Nom./Low

OD

OD

Phase / Frequency / Voltage dBA dBA dBA mm mm

Hz / V

ABQ71C

6.8

7.5

6.8

512

7.5

2.082

B

4.65

A

3.80

285x1,007x600

35

*

*

ABQ100C

9.5

10.8

9.5

715

10.8

2.498

*

*

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound pressure level

Heating

Sound power level Cooling

Cooling

Heating

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min

Nom./Silent operation dBA

Nom.

Night quiet mode Level 1 dBA dBA dBA

Operation range Cooling

Heating

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Refrigerant

Piping connections

Type/GWP

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

AZQS71BV1

770x900x320

67

52.0

48.0

64

48/43

50

-

30

40

15.0

-

20

ABQ125C

12.1

13.5

ABQ140C

13.0

15.5

*

*

ABQ125C

9.5

10.8

12.1

13.5

-

-

-

-

-

-

13.0

15.5

B

9.5

4.65

624

A

10.8

3.80

3.500

*

*

*

*

378x1,388x541 378x1,588x541 378x1,388x541

50.0

56.0

50.0

-/-/-

-/-/-

*

*

*

*

*

9.52

15.88

1~ / 50 / 220-240

AZQS100BV1 AZQS125BV1

990x940x320

81

76 77

83

70

53/-

57

71

54/-

58

1~ / 50 / 220-240

AZQS140BV1

1,430x940x320

102

83

62

54

-5~46

-15~15.5

R-410A/1,975

70

53/-

49

50

70

30.0

0.5

-

ABQ100C

12.1

13.5

12.1

13.5

*

*

*

*

AZQS100BY1 AZQS125BY1

990x940x320

82

76 77

57

83

71

54/-

58

3N~ / 50 / 380-415

-

-

-

-

-

-

ABQ140C

13.0

15.5

13.0

15.5

378x1,588x541

56.0

-/-/-

-/-/-

AZQS140BY1

1,430x940x320

101

83

62

70

53/-

54

(1) EER/COP according to Eurovent 2012, for use outside EU only

*Note: grey cells contain preliminary data

foto

39

FAQ-C / RZQG-L8V1/L8Y1

FAQ100C RZQG100L8V1/Y1 BRC1E52A/B

(optional)

Ideal solution for shops, restaurants or offices with no or narrow false ceilings

Can be installed in both new and existing buildings

Flat, stylish front panel blends easily within any interior décor and is more easy to clean

5 different discharge angles can be programmed via the remote control

Maintenance operations can be performed from the front of the unit

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

BRC7EB518

(optional)

Wall mounted unit

40

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Heating

(Average climate)

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Colour

Unit

Unit

Heating

Heating

Cooling

Heating

Liquid

Gas

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage kg

High/Nom./Low m³/min m³/min dBA dBA

High/Nom./Low dBA dBA mm mm

Hz / V

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Refrigerant

Heating

Sound power level Cooling

Sound pressure level

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

Nom.

Nom.

kg m³/min m³/min dBA dBA dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

FAQ71C

-/6.8/-

-/7.5/-

2.00

2.03

6.80

6.51

365

6.33

4.02

2,204

3.40

3.70

1,000

290x1,050x238

13

18/16/14

18/16/14

61

61

45/42/40

45/42/40

FAQ100C

-/9.5/-

-/10.8/-

2.63

3.00

FAQ71C

-/6.8/-

-/7.5/-

2.00

2.03

A++

9.50

6.11

544

6.80

6.51

365

A+

10.20

4.01

3,561

3.62

3.61

1,315

6.33

4.02

2,204

3.40

3.70

1,000

A/A

Fresh White

340x1,200x240

17

26/23/19

26/23/19

65

65

49/45/41

49/45/41

9.52

15.9

1~ / 50/60 / 220-240/220

290x1,050x238

13

18/16/14

18/16/14

61

61

45/42/40

45/42/40

FAQ100C

-/9.5/-

-/10.8/-

2.63

3.00

9.50

6.11

544

10.20

4.01

3,561

3.62

3.61

1,315

340x1,200x240

17

26/23/19

26/23/19

65

65

49/45/41

49/45/41

RZQG71L8V1

990x940x320

78

59

49

64

48

50

43

50

70

20

1~ / 50 / 220-240

RZQG100L8V1

1,430x940x320

102

70

62

66

50

52

45

-15~50

-20~15.5

R-410A/1,975

75

90

30.0

0.5

32

RZQG71L8Y1

990x940x320

80

59

49

64

48

50

43

50

70

16

3N~ / 50 / 380-415

RZQG100L8Y1

1,430x940x320

101

70

62

66

50

52

45

75

90

20

FAQ-C / RZQSG-L(3/8)V1/L8Y1

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Heating

(Average climate)

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Colour

Unit

Unit

Heating

Heating

Cooling

Heating

Liquid

Gas

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage kg

High/Nom./Low m³/min m³/min dBA dBA

High/Nom./Low dBA dBA mm mm

Hz / V

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Refrigerant

Heating

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA

Nom./Silent operation dBA

Nom.

dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

FAQ71C

-/6.8/-

-/7.5/-

2.12

2.08

6.80

6.05

393

A

6.00

3.90

2,155

3.21

3.61

1,060

A/A

290x1,050x238

13

18/16/14

18/16/14

61

61

45/42/40

45/42/40

RZQSG71L3V1

770x900x320

67

52

48

65

49/47

51

40

20

-

1~ / 50 / 220-240

FAQ100C

-/9.5/-

-/10.8/-

3.16

3.17

A+

Fresh White

9.52

15.9

1~ / 50/60 / 220-240/220

340x1,200x240

17

26/23/19

26/23/19

65

65

49/45/41

49/45/41

9.50

5.61

592

A+

6.81

4.01

2,377

3.01

3.41

1,580

B/B

RZQSG100L8V1

990x940x320

81

76

83

69

53/49

57

-15~46

-15~15.5

R-410A/1,975

50

70

30

0.5

32

FAQ100C

RZQSG100L8Y1

82

53/-

49

3N~ / 50 / 380-415

20

41

FHQ-C / RZQG-L8/7V1/L(8)Y1

Ceiling suspended unit

FHQ100-140C RZQG100-140L8/7V1/L(8)Y1 BRC1E52A/B

(optional)

BRC7GA53

(optional)

Ideal solution for commercial spaces with narrow or no false ceilings

The unit can easily be mounted in corners and narrow spaces, as it only needs 30mm lateral service space

Low energy consumption thanks to DC fan motor and drain pump

Stylish unit blends easily with any interior, as the flaps close entirely when not in operation

Can be installed in both new and existing buildings

Wider air discharge thanks to Coanda effect: up to 100°

42

Air flow distribution for ceiling heights up to 3.8m without capacity loss

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Heating

Seasonal efficiency Cooling

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Colour

Unit

Unit

Heating

Heating

Cooling

Heating

Liquid

Gas

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage kg

High/Nom./Low m³/min m³/min dBA dBA

High/Nom./Low dBA dBA mm mm

Hz / V

235x1,270x690

32

20.5/17/14

20.5/17/14

55

55

38/36/34

38/36/34

6.80

6.95

342

A+

7.60

4.32

2,462

3.82

4.13

890

FHQ71C

-/6.8/-

-/7.5/-

1.78

1.82

A++

FHQ100C

-/9.5/-

-/10.8/-

2.49

2.60

9.50

6.11

544

A++

11.30

4.61

3,431

3.81

4.15

1,245

28/24/20

28/24/20

60

60

42/38/34

42/38/34

698

A+

14.13

4.23

4,676

3.35

3.89

1,790

FHQ125C

-/12.0/-

-/13.5/-

3.58

3.48

A+

12.00

6.01

235x1,590x690

38

31/27/23

31/27/23

62

62

44/41/37

44/41/37

-

3.31

3.63

2,025

-

-

-

-

FHQ140C

-/13.4/-

-/15.5/-

4.05

4.27

-

-

-

FHQ71C

-/6.8/-

-/7.5/-

1.78

1.82

A++

6.80

6.95

342

A+

7.60

4.32

2,462

3.82

4.13

890

34/29/24

34/29/24

64

64

A/A

Fresh White

235x1,270x690

32

46/42/38

46/42/38

20.5/17/14

20.5/17/14

55

55

38/36/34

38/36/34

9.52

15.9

1~ / 50/60 / 220-240/220

FHQ100C

-/9.5/-

-/10.8/-

2.49

2.60

9.50

6.11

544

A++

11.30

4.61

3,431

3.81

4.15

1,245

28/24/20

28/24/20

60

60

42/38/34

42/38/34

235x1,590x690

38

31/27/23

31/27/23

62

62

44/41/37

44/41/37

698

A+

14.13

4.23

4,676

3.35

3.89

1,790

FHQ125C

-/12.0/-

-/13.5/-

3.58

3.48

A+

12.00

6.01

-

3.31

3.63

2,025

-

-

-

-

FHQ140C

-/13.4/-

-/15.5/-

4.05

4.27

-

-

-

34/29/24

34/29/24

64

64

46/42/38

46/42/38

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Refrigerant

Heating

Sound power level Cooling

Sound pressure level

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

Nom.

Nom.

kg m³/min m³/min dBA dBA dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

RZQG71L8V1 RZQG100L8V1 RZQG125L8V1 RZQG140L7V1 RZQG71L8Y1 RZQG100L8Y1 RZQG125L8Y1 RZQG140LY1

990x940x320 1,430x940x320 990x940x320 1,430x940x320

78

59 70

102

84

80

59 70

101

84

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

-15~50

-20~15.5

R-410A/1,975

50

70

75

90

50

70

75

90

30.0

0.5

20

1~ / 50 / 220-240

32 16

3N~ / 50 / 380-415

20

FHQ-C / RZQSG-L(3/8)V1/L(8)Y1

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Heating

Seasonal efficiency Cooling

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Colour

Unit

Unit

Heating

Heating

Cooling

Heating

Liquid

Gas

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage kg

High/Nom./Low m³/min m³/min dBA dBA

High/Nom./Low dBA dBA mm mm

Hz / V

FHQ71C

-/6.8/-

-/7.5/-

1.97

1.88

6.80

424

3.90

2,727

3.46

4.00

985

A

FHQ100C

-/9.5/-

-/10.8/-

2.96

2.99

A+

9.50

5.61

592

7.60

3.91

2,721

3.21

3.61

1,480

A/A

235x1,270x690

32

20.5/17/14

20.5/17/14

55

55

38/36/34

38/36/34

28/24/20

28/24/20

60

60

42/38/34

42/38/34

FHQ125C

-/12.0/-

-/13.5/-

4.15

3.73

12.00

748

A+

4.01

2,653

2.89

3.62

2,075

C/A

31/27/23

31/27/23

62

62

44/41/37

44/41/37

FHQ140C

-/13.4/-

-/15.5/-

4.45

4.54

-

-

-

-

FHQ100C

-/9.5/-

-/10.8/-

2.96

2.99

9.50

592

A

-

-

-

3.01

3.41

2,225

B/B

Fresh White

3.91

2,721

3.21

3.61

1,480

A/A

235x1,590x690

38

34/29/24

34/29/24

28/24/20

28/24/20

64

64

46/42/38

46/42/38

60

60

42/38/34

42/38/34

9.52

15.9

1~ / 50/60 / 220-240/220

A+

5.61

7.60

FHQ125C

-/12.0/-

-/13.5/-

4.15

3.73

12.00

748

A+

4.01

2,653

2.89

3.62

2,075

C/A

31/27/23

31/27/23

62

62

44/41/37

44/41/37

FHQ140C

-/13.4/-

-/15.5/-

4.45

4.54

-

-

-

-

-

-

-

3.01

3.41

2,225

B/B

34/29/24

34/29/24

64

64

46/42/38

46/42/38

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Refrigerant

Heating

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA

Nom./Silent operation dBA

Nom.

dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

RZQSG71L3V1 RZQSG100L8V1 RZQSG125L8V1 RZQSG140LV1 RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1

770x900x320 990x940x320 1,430x940x320 990x940x320 1,430x940x320

67

52 76

81

77

102

83 76

82

77

101

83

83 62 83 48

65

49/47

51

69

53/49

57

-

70

54/49

58

53/49

54

69

53/-

57

70

54/-

58

49

62

69

53/-

54

-15~46

-15~15.5

R-410A/1,975

50

40 70

30

0.5

20

1~ / 50 / 220-240

32

3N~ / 50 / 380-415

20

43

FHQ-C / RXS-L

Ceiling suspended unit

FHQ60C RXS-L

Ideal solution for commercial spaces with narrow or no false ceilings

The unit can easily be mounted in corners and narrow spaces, as it only needs 30mm lateral

service space

Low energy consumption thanks to DC fan motor and drain pump

Stylish unit blends easily with any interior, as the flaps close entirely when not in operation

Can be installed in both new and existing buildings

Wider air discharge thanks to Coanda effect: up to 100°

BRC1E52A/B

(optional)

BRC7F530W

(optional)

44

Air flow distribution for ceiling heights up to 3.8m without capacity loss

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling kW kW

Min./Nom./Max.

kW

Min./Nom./Max.

kW

Energy label

Pdesign kW

SEER

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Heating

(Average climate)

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Colour

Unit

Unit

Heating

Heating

Cooling

Heating

Liquid

Gas

Drain

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low

OD

OD

OD

Phase / Frequency / Voltage kg

High/Nom./Low m³/min m³/min dBA dBA

High/Nom./Low dBA dBA mm mm mm

Hz / V

FHQ35C

1.4/3.40/4.0

1.3/4.00/5.1

0.410/0.950/1.490

0.270/0.980/1.980

A++

3.40

6.18

193

A+

3.10

4.43

981

3.58

4.08

475

A/A

24

14/11.5/10

14/11.5/10

53

53

36/34/31

36/34/31

9.5

VP20

235x960x690

FHQ50C

1.7/5.0/5.3

1.7/6.0/6.0

-/1.570/-

-/1.790/-

5.00

5.87

298

4.35

3.86

1,578

3.18

3.35

785

B/C

Fresh White

25

15/12/10

15/12/10

37/35/32

37/35/32

6.35

1~ / 50/60 / 220-240/220

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

HeightxWidthxDepth mm

High/Super low

High/Super low kg m³/min m³/min

Heating

Cooling

Heating dBA dBA

High/Low/Silent operation dBA

Sound pressure level

Operation range Cooling

Heating

Refrigerant

Piping connections

High/Low/Silent operation dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Type/GWP

Piping length OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

RXS35L

550x765x285

34

36.0/30.1

28.3/25.6

61

61

48/-/44

48/-/45

20

15

1~ / 50 / 220-240

RXS50L

47

50.9/48.9

45.0/43.1

48/44/-

48/45/-

-10~46

-15~18

R-410A/1,975

-

A+

A

54

54

12.7

-

735x825x300

62

62

30

20.0

1~ / 50 / 220-230-240

FHQ60C

1.7/5.7/5.7

1.7/7.20/7.2

-/1.750/-

-/2.170/-

5.70

6.02

332

4.71

3.87

1,705

3.26

3.32

875

A/C

235x1,270x690

31

19.5/15/11.5

19.5/15/11.5

37/35/33

37/35/33

RXS60L

48

50.2/45.0

46.3/46

49/46/-

49/46/-

AHQ-C / AZQS-BV1/BY1

Siesta, ceiling suspended unit

AHQ125CV1 AZQS140BV1/BY1

Ideal solution for commercial spaces with no or narrow false ceilings

Can be installed in both new and existing buildings

Air filter removes airborne dust particles to ensure a steady supply of clean air

Decrease of temperature variation by automatic fan speed selection or freely selectable 3-step fan speed.

Easy installation and maintenance

ARCWLA

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign

SEER kW kW kW kW kW

Annual energy consumption kWh

Energy label

Pdesign

SCOP kW

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Colour

Unit

Fan - External static pressure High/Nom./Low

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Unit

Fan - Air flow rate Cooling

Heating

Heating

Cooling

Heating

Liquid

Gas

HeightxWidthxDepth mm kg

High/Nom./Low m³/min

High/Nom./Low

High/Nom./Low m³/min

Pa dBA dBA dBA

High/Nom./Low dBA

OD

OD

Phase / Frequency / Voltage mm mm

Hz / V

AHQ71C

-/6.8/-

-/7.5/-

2.24

2.46

AHQ100C

-/9.5/-

-/10.8/-

3.62

3.17

AHQ125C

-/12.1/-

-/13.5/-

4.60

3.74

AHQ140C

-/13.0/-

-/15.5/-

4.32

4.55

AHQ100C

-/9.5/-

-/10.8/-

3.62

723

A

7.60

3.80

AHQ125C

-/12.1/-

-/13.5/-

4.60

3.74

AHQ140C

-/13.0/-

-/15.5/-

4.32

4.55

6.80

4.65

511

6.33

2,332

3.03

3.05

1,120

B/D

B

A

3.80

9.50

4.60

723

7.60

2,800

2.62

3.41

1,810

D/B

2.63

3.61

2,300

D/A

-

-

-

-

-

-

-

-

3.01

2,159

B/B

3.41

3.17

B

9.50

4.60

2,800

2.62

1,810

D/B

2.63

3.61

2,300

D/A

-

-

-

-

-

-

-

-

3.01

3.41

2,159

B/B

White

260x1,320x634 260x1,538x634 260x1,786x634 285x1,902x680 260x1,538x634 260x1,786x634 285x1,902x680

38

23.8/21.3/18.9

23.8/21.3/18.9

45

31.1/27.8/24.8

31.1/27.8/24.8

54

34.4/30.6/27.2

34.4/30.6/27.2

70

43.9/39.1/28.3

43.9/39.1/28.3

0/0/0

45

31.1/27.8/24.8

31.1/27.8/24.8

54

34.4/30.6/27.2

34.4/30.6/27.2

70

43.9/39.1/28.3

43.9/39.1/28.3

59

62

49/48/46

49/48/46

64

64

52/47/46

52/47/46

69

69

52/50/49

52/50/49

70

70

56/53/46

56/53/46

9.52

15.88

1~ / 50 / 220-240

64

64

52/47/46

52/47/46

69

69

52/50/49

52/50/49

70

70

56/53/46

56/53/46

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Refrigerant

Heating

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA

Nom./Silent operation dBA

Nom.

dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only

AZQS71BV1

770x900x320

67

52.0

48.0

65

48/43

50

-

-5.0~46.0

-15.0~15.5

30

40

15.0

-

20

AZQS100BV1 AZQS125BV1

990x940x320

81

76 77

83

70

53/-

57

71

54/-

58

1~ / 50 / 220-240

AZQS140BV1

1,430x940x320

102

83

62

70

53/-

54

AZQS100BY1 AZQS125BY1

990x940x320

82

76 77

57

83

71

54/-

58

49

-5~46

-15~15.5

R-410A/1,975

50

70

30.0

0.5

3N~ / 50 / 380-415

-

AZQS140BY1

1,430x940x320

101

83

62

70

53/-

54

45

FUQ-C / RZQG-L8V1/L8Y1

4-way blow ceiling suspended unit

FUQ-C RZQG100-125L8V1/Y1 BRC1E52A/B

(optional)

Ideal solution for commercial spaces with no or narrow false ceilings

Low energy consumption thanks to specially developed small tube heat exchanger, DC fan motor and drain pump

Stylish unit blends easily with any interior, as the flaps close entirely when not in operation

Improved comfort thanks to automatic air flow adjustment to required load

Individual flap control: possibility to adapt the room layout by fixing the positon of each flap individually

(BRC1E52) in case you would refurbish or rearrange your interior

Can be installed in both new and existing buildings

Same outlook for all models (unified dimensions)

Auto swing function ensures efficient air and temperature distribution

Air can be discharged in 5 different angles between 0 and 60°

BRC7C58

(optional)

Possibility to shut 1 or 2 flaps for easy installation in corners

46

Air flow distribution for ceiling heights up to 3.5m without capacity loss

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Colour

Unit

Unit

Fan - Air flow rate Cooling

HeightxWidthxDepth mm kg

High/Nom./Low m³/min

High/Nom./Low m³/min Heating

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Heating

Cooling

Heating

Liquid

Gas

High/Nom./Low

High/Nom./Low dBA

OD

OD

Phase / Frequency / Voltage dBA dBA dBA mm mm

Hz / V

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound pressure level

Heating

Sound power level Cooling

Cooling

Heating

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min

Nom./Silent operation dBA

Nom.

Night quiet mode Level 1 dBA dBA dBA

Operation range Cooling

Heating

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Refrigerant

Piping connections

Type/GWP

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

FUQ71C

-/6.8/-

-/7.5/-

1.68

1.84

6.80

6.50

366

7.60

4.20

2,533

4.05

4.08

840

25

23/19.5/16

23/19.5/16

59

59

41/38/35

41/38/35

AZQS71BV1

770x900x320

67

52.0

48.0

65

48/43

50

-

-5.0~46.0

-15.0~15.5

30

40

15.0

-

20

A++

A/A

FUQ100C

-/9.5/-

-/10.8/-

2.46

2.73

9.50

6.11

544

11.30

4.50

3,515

3.86

3.95

1,230

31/25.5/20

31/25.5/20

64

64

46/42/39

46/42/39

26

AZQS100BV1 AZQS125BV1

990x940x320

81

76 77

83

70

53/-

57

71

54/-

58

1~ / 50 / 220-240

FUQ125C

-/12.0/-

-/13.5/-

3.54

3.95

A+

12.00

5.61

748

FUQ71C

-/6.8/-

-/7.5/-

1.68

1.84

6.80

6.50

366

A+

14.13

4.44

4,456

3.39

3.42

1,770

A/B

7.60

4.20

2,533

4.05

4.08

840

Fresh White

198x950x950

32.5/26.5/20.5

32.5/26.5/20.5

65

65

47/43/40

47/43/40

25

23/19.5/16

23/19.5/16

59

59

41/38/35

41/38/35

9.52

15.9

1~ / 50/60 / 220-240/220

AZQS140BV1

1,430x940x320

102

83

62

54

70

53/-

49

-5~46

-15~15.5

R-410A/1,975

50

70

30.0

0.5

-

57

A++

A/A

FUQ100C

-/9.5/-

-/10.8/-

2.46

2.73

9.50

6.11

544

11.30

4.50

3,515

3.86

3.95

1,230

31/25.5/20

31/25.5/20

83

64

64

46/42/39

46/42/39

26

AZQS100BY1 AZQS125BY1

990x940x320

82

76 77

71

54/-

58

3N~ / 50 / 380-415

FUQ125C

-/12.0/-

-/13.5/-

3.54

3.95

A+

12.00

5.61

748

14.13

4.44

4,456

3.39

3.42

1,770

A/B

32.5/26.5/20.5

32.5/26.5/20.5

65

65

47/43/40

47/43/40

AZQS140BY1

1,430x940x320

101

83

62

70

53/-

54

(1) EER/COP according to Eurovent 2012, for use outside EU only

47

FVQ-C / RZQG-L8/7V1/L(8)Y1

Floor standing unit

FVQ100-140C RZQG100-140L8/7V1/L(8)Y1 BRC1E52A/B

(optional)

Ideal solution for shops, restaurants or offices with no or narrow false ceilings

Can be installed in both new and existing buildings

Very efficient for use in rooms with high ceilings

Decrease of temperature variation by automatic fan speed selection or freely selectable 3-step fan speed.

Improved comfort as a result of better airflow distribution from the vertical out blow which allows manual adjustment of air outlet blades at the top of the unit. Selectable horizontal out blow to better suit the layout of the room (via BRC1E52).

Improved efficiency by adoption of the DC fan motor.

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

48

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Heating

Seasonal efficiency Cooling

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Colour

Unit

Unit

Heating

Heating

Cooling

Heating

Liquid

Gas

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage kg

High/Nom./Low m³/min m³/min dBA dBA

High/Nom./Low dBA dBA mm mm

Hz / V

FVQ71C

-/6.8/-

-/7.5/-

2.02

2.06

A++

6.80

6.31

377

6.33

4.05

2,188

3.37

3.64

1,010

1,850x600x270

39

18/16/14

18/16/14

55

55

43/41/38

43/41/38

A+

FVQ100C

-/9.5/-

-/10.8/-

2.49

2.61

9.50

592

4.20

3,766

3.81

4.14

1,245

28/25/22

28/25/22

62

62

50/47/44

50/47/44

A+

5.61

11.30

FVQ125C

-/12.0/-

-/13.5/-

3.74

3.65

12.00

748

A

3.87

4,087

3.70

1,870

1,850x600x350

47

28/26/24

28/26/24

63

63

51/48/46

51/48/46

3.21

FVQ140C

-/13.4/-

-/15.5/-

4.17

4.30

-

-

-

-

-

-

-

-

6.33

4.05

2,188

3.37

3.61

2,085

A/A

Fresh White

3.64

1,010

FVQ71C

-/6.8/-

-/7.5/-

2.02

2.06

A++

6.80

6.31

377

30/28/26

30/28/26

65

65

53/51/48

53/51/48

1,850x600x270

39

18/16/14

18/16/14

55

55

43/41/38

43/41/38

9.52

15.9

1~ / 50/60 / 220-240/220

A+

FVQ100C

-/9.5/-

-/10.8/-

2.49

2.61

9.50

592

4.20

3,766

3.81

4.14

1,245

A+

5.61

11.30

FVQ125C

-/12.0/-

-/13.5/-

3.74

3.65

12.00

748

A

3.87

4,087

3.70

1,870

3.21

FVQ140C

-/13.4/-

-/15.5/-

4.17

4.30

-

-

-

-

-

-

-

-

3.61

2,085

28/25/22

28/25/22

62

62

50/47/44

50/47/44

1,850x600x350

47

28/26/24

28/26/24

63

63

51/48/46

51/48/46

30/28/26

30/28/26

65

65

53/51/48

53/51/48

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Refrigerant

Heating

Sound power level Cooling

Sound pressure level

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

Nom.

Nom.

kg m³/min m³/min dBA dBA dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only.

RZQG71L8V1 RZQG100L8V1 RZQG125L8V1 RZQG140L7V1 RZQG71L8Y1 RZQG100L8Y1 RZQG125L8Y1 RZQG140LY1

990x940x320 1,430x940x320 990x940x320 1,430x940x320

78

59 70

102

84

80

59 70

101

84

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

-15~50

-20~15.5

R-410A/1,975

50

70

75

90

50

70

75

90

30.0

0.5

20

1~ / 50 / 220-240

32 16

3N~ / 50 / 380-415

20

FVQ-C / RZQSG-L(3/8)V1/L(8)Y1

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Heating

Seasonal efficiency Cooling

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

(Average climate)

Nom.

Nom.

Energy label

Pdesign kW kW kW kW kW

SEER

Annual energy consumption kWh

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

Casing

Dimensions

Weight

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Piping connections

Power supply

Colour

Unit

Unit

Heating

Heating

Cooling

Heating

Liquid

Gas

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage kg

High/Nom./Low m³/min m³/min dBA dBA

High/Nom./Low dBA dBA mm mm

Hz / V

FVQ71C

-/6.8/-

-/7.5/-

2.12

2.08

6.80

433

A

6.33

3.86

2,296

1,060

1,850x600x270

39

18/16/14

18/16/14

55

55

43/41/38

43/41/38

3.21

3.61

A/A

FVQ100C

-/9.5/-

-/10.8/-

2.96

2.99

A

9.50

5.50

604

A+

4.01

2,653

1,480

28/25/22

28/25/22

62

62

50/47/44

50/47/44

7.60

FVQ125C

-/12.0/-

-/13.5/-

4.27

3.96

12.00

763

A

3.85

2,763

2.81

2,135

C/B

28/26/24

28/26/24

63

63

51/48/46

51/48/46

3.41

FVQ140C

-/13.4/-

-/15.5/-

4.45

4.54

-

-

-

FVQ100C

-/9.5/-

-/10.8/-

2.96

2.99

9.50

-

-

-

-

-

3.01

604

A+

4.01

2,653

3.21

3.61

2,225

B/B

Fresh White

1,850x600x350

47

1,480

A/A

30/28/26

30/28/26

65

65

53/51/48

53/51/48

9.52

15.9

1~ / 50/60 / 220-240/220

28/25/22

28/25/22

62

62

50/47/44

50/47/44

A

5.50

7.60

FVQ125C

-/12.0/-

-/13.5/-

4.27

3.96

12.00

763

A

3.85

2,763

2.81

2,135

C/B

28/26/24

28/26/24

63

63

51/48/46

51/48/46

3.41

FVQ140C

-/13.4/-

-/15.5/-

4.45

4.54

-

-

-

-

-

-

-

-

3.01

2,225

B/B

30/28/26

30/28/26

65

65

53/51/48

53/51/48

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Refrigerant

Heating

Cooling

Heating

Heating

Type/GWP

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA

Nom./Silent operation dBA

Nom.

dBA

Night quiet mode Level 1

Operation range Cooling dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping connections

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

(1) EER/COP according to Eurovent 2012, for use outside EU only.

RZQSG71L3V1 RZQSG100L8V1 RZQSG125L8V1 RZQSG140LV1 RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1

770x900x320 990x940x320 1,430x940x320 990x940x320 1,430x940x320

67

52 76

81

77

102

83 76

82

77

101

83

83 62 83 48

65

49/47

51

69

53/49

57

-

70

54/49

58

53/49

54

69

53/-

57

70

54/-

58

49

62

69

53/-

54

-15~46

-15~15.5

R-410A/1,975

50

40 70

30

0.5

20

1~ / 50 / 220-240

32

3N~ / 50 / 380-415

20

49

Twin/triple/double twin and multi application

The benefits of a twin/triple/double twin system

• Air conditioning in long or irregularly shaped rooms

A twin/triple/double twin application allows up to 4 indoor untis to operate in L-shaped, U-shaped or long rooms powered by a single outdoor unit.

All indoor units are controlled at the same time.

• The widest choice

Different types of indoor units – wall mounted, concealed ceiling, cassettes etc – can be selected for twin/triple/double twin application

• Ideal comfort in every part of the room

Delivery of optimal efficiency and comfort in each part of a long or irregularly shaped room.

Possible outdoor units

50

RZQG71-140L8/7V1/L(8)Y1

The Benefits of a Multi system

• Air conditioning in every room

A Multi system allows up to 9 indoor units to operate from a single outdoor unit, thereby reducing installation space and costs. All indoor units can be individually controlled and do not need to be installed at the same time - extra units (up to a maximum of 9) can be added later.

• The widest choice

Different types of indoor units — wall mounted, concealed ceiling, floor standing etc - in different capacities can be mixed together in Multi system applications. Thus the ideal indoor unit can be selected for the bedroom, living room, office or wherever, according to the installation surface or personal requirements.

• An ideal indoor climate

A single outdoor unit can heat up or cool down a complete house, office or small shop at different times. A pleasant climate can be enjoyed whilst working at the desk in the afternoon, as well as a constant temperature in the living room and cool bedrooms in the evening.

RZQSG71-140L(3/8)V1/L(8)Y1 RZQ200-250C

Possible outdoor units

Multi outdoor units:

2MXS

2 indoor units

3MXS

3 indoor units

4MXS

4 indoor units

5MXS

5 indoor units

VRVIII-S for residential application:

RXYSQ-P8V1

9 indoor units

RZQG-L8/7V1/L(8)Y1

Seasonal efficiency, optimized for all seasons

Seasonal smart series comply with the EU’s 2014 Eco-Design requirements

The perfect balance in efficiency and comfort thanks to Variable

Refrigerant Temperature: top seasonal efficiency throughout most of the year and quick reaction speed on the hottest days

Suits computer room applications (EDP)

Re-use of existing R-22 or R-407C technology

Down to -20°C in heating mode

Standard night quiet mode

Maximum piping length up to 75m minimum piping length is 5m

Compatibility with D-BACS

Twin, triple, double twin

capacity class

RZQG71L8V1 RZQG71L8Y1

FCQHG-F

71

RZQG100L8V1 RZQG100L8Y1

RZQG125L8V1 RZQG125L8Y1

RZQG140L7V1 RZQG140LY1 2

3

4

35

2

4

FCQG-F

50 60 71

2

3

3

2

2

3

4

35

2

4

FFQ-C

50 60

2

3

3

2 4

4

2

3

35

FDXS-F (9)

50 60

2

3 2

3

3

4

35

2

4

2

3

3

FBQ-C8

50 60 71

2

2

3

4

35

2

4

50

FHQ-C

60

2

3

3

2

71

FAQ-C FUQ-C

71 71

2 2 2

Heating & Cooling

Indoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Heating

Cooling

Heating

Nom.

Nom.

Night quiet mode Level 1

Operation range Cooling

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min dBA dBA dBA dBA

Ambient Min.~Max. °CDB

Refrigerant

Piping connections

Heating

Type/GWP

Piping length

Ambient Min.~Max. °CWB

OU - IU Max.

m

System Equivalent m

Power supply

Current - 50Hz

Level difference IU - OU Max.

IU - IU Max.

Phase / Frequency / Voltage

Maximum fuse amps (MFA) m m

Hz / V

A

RZQG71L8V1 RZQG100L8V1 RZQG125L8V1 RZQG140L7V1 RZQG71L8Y1 RZQG100L8Y1 RZQG125L8Y1 RZQG140LY1

990x940x320 1,430x940x320 990x940x320 1,430x940x320

78

59 70

102

84

80

59 70

101

84

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

49

64

48

50

43

66

50

52

62

67

51

45

53

69

52

-15~50

-20~15.5

R-410A/1,975

50

70

75

90

50

70

75

90

30.0

0.5

20

1~ / 50 / 220-240

32 16

3N~ / 50 / 380-415

20

51

RZQSG-L(3/8)V1/L(8)Y1

Seasonal efficiency, optimized for all seasons

Re-use of existing R-22 or R-407C technology

Down to -15°C in heating mode

Maximum piping length up to 50m

Compatibility with D-BACS

Twin, triple, double twin

Capacity class

RZQSG71L3V1

RZQSG100L8V1

RZQSG125L8V1

RZQSG140LV1

RZQSG100L8Y1

RZQSG125L8Y1

RZQSG140LY1

FCQHG-F

71

2

3

4

35

2

4

FCQG-F

50 60 71

2

3

3

2

2

3

4

35

2

4

FFQ-C

50 60

2

3

3

2 4

4

2

3

35

FDXS-F(9)

50 60

2

3 2

3

3

4

35

2

4

FBQ-C8

50 60 71

2

3

3

2

2

3

4

35

2

4

50

FHQ-C

60

2

3

3

2

71

FAQ-C

71

2 2

52

Heating & Cooling

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound pressure level

Heating

Sound power level Cooling

Cooling

Heating

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min

Nom./Silent operation dBA

Nom.

Night quiet mode Level 1 dBA dBA dBA

Operation range Cooling

Heating

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Refrigerant

Piping connections

Type/GWP

Piping length OU - IU Max.

m

System Equivalent m

Level difference IU - OU Max.

IU - IU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

RZQSG71L3V1 RZQSG100L8V1 RZQSG125L8V1 RZQSG140LV1 RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1

770x900x320 990x940x320 1,430x940x320 990x940x320 1,430x940x320

67

52 76

81

77

102

83 76

82

77

101

83

83 62 83 48

65

49/47

51

69

53/49

57

-

70

54/49

58

53/49

54

69

53/-

57

70

54/-

58

49

62

69

53/-

54

-15~46

-15~15.5

R-410A/1,975

50

40 70

30

0.5

20

1~ / 50 / 220-240

32

3N~ / 50 / 380-415

20

RZQ-C

Re-use of existing R-22 or R-407C piping

Down to -15°C in heating mode

Standard night quiet mode

Maximum piping length up to 100m

Maximum installation height difference up to 30m

Twin, triple, double twin

Capacity class

RZQ200C

RZQ250C

50

4

60

3

4

FCQG-F FFQ-C

71 100 125 50 60

3 2 4

2

3

4

FDXS-F(9)

50 60

4 3

4

50

4

60

3

4

FBQ-C8

71 100 125 50

3 2 4

4

60

3

2

FHQ-C FUQ-C FAQ-C FDQ-C

71 100 125 71 100 125 71 100 125

3 2 3 2 3 2

2 2 2

Heating & Cooling

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Fan - External static pressure Max.

HeightxWidthxDepth mm

Nom.

Nom.

kg m³/min m³/min

Sound power level Cooling

Heating

Sound pressure level Nom.

Operation range Cooling

Refrigerant

Piping connections

Pa dBA dBA dBA

Heating

Type/GWP

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Piping length OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

RZQ200C

183

1,680x930x765

171

171

78

78

78

57

-5.0~46.0

-15.0~15.0

R-410A/1,975

100

-

3N~ / 50 / 380-415

20

RZQ250C

184

53

MXS-E/F/G/H/K

Wide range from 2 to 5 port units

Possibility to connect up to 5 indoor units

3-port 40 multi outdoor unit gives an answer to lower capacity requirements of better insulated houses. The 15-class wall mounted allows efficient distribution of the lower capacity of the multi outdoor unit.

All indoor units can be individually controlled and do not need to be installed in the same room or even at the same time

Outdoor units are fitted with a Daikin swing compressor renowned for its low noise and high energy efficiency

Possibility to combine different types of indoor units: wall mounted, floor standing, concealed ceiling, ceiling suspended units, round flow or

4-way blow cassettes

Multi model application

Heating & Cooling

Connectable indoor units

2MXS40H

2MXS50H

3MXS40K

3MXS52E

3MXS68G

4MXS68F

4MXS80E

5MXS90E

FTXG-L CTXS-K

Wall mounted

FTXS-K FTXS-G FTX-JV

Floor standing

FVXG-K FVXS-F

Flexi type

FLXS-B(9)

Round flow cassette

FCQG-F

Fully flat cassette

FFQ-C

Concealed ceiling

Ceiling suspended

FDXS-F(9) FDBQ-B/FBQ-C8 FHQ-C

20 25 35 50 15 35 20 25 35 42 50 60 71 20 25 35 25 35 50 25 35 50 25 35 50 60 35 50 60 25 35 50 60 25 35 50 60 25 35 50 60 35 50 60

● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ●

● ● ● ● ●

● ●

● ●

● ●

● ●

● ●

● ●

● ●

● ●

● ●

● ●

● ● ●

● ●

● ● ●

● ●

● ● ●

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

54

Heating & Cooling

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Sound power level Cooling

Sound pressure level

Refrigerant

Piping connections

Heating

Cooling

Heating

Operation range Cooling

Heating

HeightxWidthxDepth mm

High/Nom./Low

High/Nom./Low kg m³/min m³/min

Nom.

Nom.

dBA dBA dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

Type/GWP

Piping length OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

IU - IU Max.

Phase / Frequency / Voltage

Maximum fuse amps (MFA) m

Hz / V

A

2MXS40H 2MXS50H

550x765x285

38

36/33/30

42

37/34/34

32/32/32

62

47

48

34/34/34

63

48

50

10~46

20

1~ / 50 / 220-240

16

3MXS40K

45/45/41

49

45/-/41

59

46

47

3MXS52E 3MXS68G

735x936x300

45/45/45

4MXS68F

58

52.7/49.4/43.5

46.4/44.5/16.3

61

48

49

-10~46

-15~18

R-410A/1,975

25

15

7.5

1~ / 50 / 230

20

4MXS80E 5MXS90E

770x900x320

72 73

54.5/46/46.0

57.1/54.5/46.0

46.0/-/14.7

62

52.5/-/14.7

66

52

52

RXYSQ-P8V1

VRVIII-S heat pump for residential application

Energy efficient heating system based on air source heat pump technology

Low energy bills and low CO

2

emissions

Possibility to connect up to 9 indoor units

All indoor units can be individually controlled and do not need to be installed in the same room or even at the same time

Possibility to combine different types of indoor units: wall mounted, floor standing, concealed ceiling, ceiling suspended units, round flow or

4-way blow cassettes

Slim design for flexible installation

Easy installation thanks to automatic refrigerant charging operation, automatic test operation

Possibility to limit peak power consumption between 30 and 80%, for example during periods with high power demand

Heating & Cooling

Connectable indoor units

RXYSQ-P8V1

Wall mounted Floor standing Flexi type

Round flow cassette Fully flat cassette

FCQG-F FFQ-C

Concealed ceiling

FDXS-F(9)

Ceiling suspended

FDBQ-B /FBQ-C8 FHQ-C FTXG-L CTXS-K FTXS-K FTXS-G FVXG-K FVXS-F FLXS-B(9)

20 25 35 50 15 35 20 25 35 42 50 60 71 25 35 50 25 35 50 25 35 50 60 35 50 60 25 35 50 60 25 35 50 60 25 35 50 60 35 50 60

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

Heating & Cooling

Outdoor unit

Capacity range

Cooling capacity Nom.

Heating capacity Nom.

Power input - 50Hz Cooling

Heating

Nom.

Nom.

EER

COP

Maximum number of connectable indoor units

Indoor index connection

Min.

Nom.

HP kW kW kW kW

Dimensions

Weight

Fan

Max.

Unit

Unit

Air flow rate

Sound power level Cooling

Sound pressure level

Cooling

Heating

Operation range Cooling

Heating

Refrigerant

Piping connections

HeightxWidthxDepth mm

Cooling Nom.

Nom.

Nom.

Nom.

Min.~Max.

Min.~Max.

kg m³/min dBA dBA dBA

°CDB

°CWB

Type

Liquid

Gas

OD

OD mm mm

Total piping length System Actual m

Power supply

Current - 50Hz

Phase/Frequency/Voltage

Maximum fuse amps (MFA)

Hz/V

A

(1) In case VRV indoor units are connected (2) In case RA indoors are connected

RXYSQ4P8V1

4

12.6

14.2

3.24

3.12

3.89

4.55

8 (1) / 8 (2)

50

130

66

50

52

300 (1) / 115 (2)

15.9 (1) / 19.1 (2)

RXYSQ5P8V1

5

14.0

16.0

3.51

3.86

3.99

4.15

10 (1) / 9 (2)

62.5

-

162.5

1,345x900x320

120

106

67

51

53

-5~46

-20~15.5

R-410A

9.52

300 (1) / 135 (2)

1N~/50/220-240

32.0

RXYSQ6P8V1

6

15.5

18.0

4.53

4.57

3.42

3.94

12 (1) / 9 (2)

70

182

69

53

55

19.1

300 (1) / 145 (2)

Branch provider

Connectable indoor units

Max. indoor unit connectable capacity

Max. connectable combination

Dimensions Height x Width x Depth

Weight mm kg

BPMKS967B2

1~2

14.2

71+71

7

180x294x350

BPMKS967B3

1~3

20.8

60+71+71

8

55

Ventilation

Biddle Air Curtain for ERQ

Heat Reclaim Ventilation

Air handling units

58

60

62

58

CYQS/M/L-DK-F/C/R

CYQM150DK80FSN

Connectable to ERQ heat pump

ERQ is among the first DX system suitable for connection to air curtains

Free-hanging model (F): easy wall mounted installation

A payback period of less then 1.5 years compared to installing an electric air curtain

Easy and quick to install at reduced costs since no additional water sytems, boilers and gas connections are required

Maximum energy efficiency stemming from almost zero down flow turbulence, optimised air flow and the application of advanced discharge rectifier technology

Around 85% air separation efficiency, greatly reducing both heat loss and required indoor unit heating capacity

Biddle air curtain for ERQ

ERQ

Separate system for heating or cooling

Biddle standard air curtain (cy)

BIDDLE STANDARD AIR CURTAIN FOR CONNECTION TO ERQ

Power input

Delta T

Casing

Dimensions

Fan only

Heating

Colour

Height

Width

Depth

Required ceiling void >

Door height

Door width

Max.

Max.

Weight Unit

Fan-Air flow rate Heating

Nom.

Nom.

Inlet= room temperature

Unit F/C/R

Unit F/C/R

Unit F/C/R

Sound pressure level Heating

Refrigerant Type

Piping connections Liquid (OD) / Gas

Required accessories (should be ordered separately)

Power supply Voltage kW kW

K

V mm mm mm mm m m kg m³/h dBA

CYQS150DK80F

*BN / *SN

Small

CYQS200DK100F

*BN / *SN

CYQS250DK140F

*BN / *SN

CYQM100DK80F

*BN / *SN

Medium

CYQM150DK80F

*BN / *SN

CYQM200DK100F

*BN / *SN

CYQM250DK140F

*BN / *SN

0.35

0.35

0.46

0.46

15

BN: RAL9010 / SN: RAL9006

0.58

0.58

16

0.37

0.37

17

0.56

0.56

0.75

0.75

14 13

BN: RAL9010 / SN: RAL9006

0.94

0.94

15

270 / 270 / 270 270 / 270 / 270

1,500 / 1,500 / 1,548 2,000 / 2,000 / 2,048 2,500 / 2,500 / 2,548 1,000 / 1,000 / 1,048 1,500 / 1,500 / 1,548 2,000 / 2,000 / 2,048 2,500 / 2,500 / 2,548

290 / 821 / 561

420

290 / 821 / 561

420

2.3 (1) / 2.15 (2) / 2.0 (3) 2.3 (1) / 2.15 (2) / 2.0 (3) 2.3 (1) / 2.15 (2) / 2.0 (3) 2.5 (1) / 2.4 (2) / 2.3 (3) 2.5 (1) / 2.4 (2) / 2.3 (3) 2.5 (1) / 2.4 (2) / 2.3 (3) 2.5 (1) / 2.4 (2) / 2.3 (3)

1.5

2.0

2.5

1.0

1.5

2.0

2.5

66

1,746

49

83

2,328

50

R-410A

107

2,910

51

57

1,605

50

73

2,408

51

R-410A

94

3,210

53

108

4,013

54

9.52 / 16.0

9.52 / 19.0

Daikin wired remote control (BRC1E52A/B or BRC1D52)

230

9.52 / 16.0

9.52 / 19.0

Daikin wired remote control (BRC1E52A/B or BRC1D52)

230

BIDDLE STANDARD AIR CURTAIN FOR CONNECTION TO ERQ

Power input

Delta T

Casing

Dimensions

Fan only

Heating

Nom.

Nom.

Inlet= room temperature

Colour

Height

Width

Depth

Unit F/C/R

Unit F/C/R

Unit F/C/R

Required ceiling void >

Door height Max.

Door width

Weight

Max.

Unit

Fan-Air flow rate Heating

Sound pressure level Heating

Refrigerant Type

Piping connections Liquid (OD) / Gas

Required accessories (should be ordered separately)

Power supply Voltage kW kW

K

V mm mm mm mm m m kg m³/h dBA

F: Freehanging model, C: Cassette model, R: Recessed model

(1) Favourable condition | (2) Normal condition | (3) Unfavourable condition

CYQL100DK125F*BN / *SN

0.75

0.75

1,000 / 1,000 / 1,048

3.0 (1) / 2.75 (2) / 2.5 (3)

1.0

76

3,100

53

9.52 / 16.0

15

CYQL150DK200F*BN / *SN

Large

CYQL200DK250F*BN / *SN CYQL250DK250F*BN / *SN

1.13

1.13

1.50

1.50

14

BN: RAL9010 / SN: RAL9006

370 / 370 / 370

1,500 / 1,500 / 1,548 2,000 / 2,000 / 2,048

745 / 745 / 745

520

1.88

1.88

12

2,500 / 2,500 / 2,548

3.0 (1) / 2.75 (2) / 2.5 (3)

1.5

100

4,650

54

3.0 (1) / 2.75 (2) / 2.5 (3)

2.0

126

6,200

56

R-410A

9.52 / 16.0

Daikin wired remote control (BRC1E52A/B or BRC1D52)

9.52 / 22.0

230

3.0 (1) / 2.75 (2) / 2.5 (3)

2.5

157

7,750

57

59

60

VAM-FA/FB

Total heat exchanged foul air

Clean outdoor air

Foul indoor air

Total heat exchanged clean air

The Daikin heat reclaim ventilation system modulates the temperature and humidity of incoming fresh air to match indoor conditions. A balance is thus achieved between indoor and outdoor ambients, enabling the cooling or heating load placed on the air conditioning system to be reduced significantly.

HRV units can be controlled individually or integral with the air conditioning system (Daikin VRV or Sky Air series).

Energy saving ventilation using indoor heating, cooling and moisture recovery

Ideal solution for shops, restaurants or offices requiring maximum floor space for furniture, decorations and fittings

Free cooling when outdoor temperature is below indoor temperature (eg. during night time)

Low energy consumption thanks to DC fan motor on 350 to 2000 units

Prevent energy losses from over-ventilation while maintaining indoor air quality with optional CO

2

sensor

Can be used as stand alone or integrated in the Sky Air or

VRV system

Wide range of units: air flow rate from 150 up to 2,000 m³/h

Optional medium and fine dust filters M6, F7, F8 grades to meet customer request or legislation

Shorter installation time thanks to easy adjustment of nominal air flow rate, so less need for dampers compared with traditional installations

Specially developed heat exchange element with High

Efficiency Paper (HEP)

No drain piping needed

Can operate in over- and under pressure

Total solution for fresh air with Daikin supply of both VAM and electrical heater

Heat Reclaim Ventilation

Ventilation

High Efficiency Paper

RH: Relative Humidity SA: Supply Air (to room) RA: Return Air (from room)

OUTDOOR INDOOR

30.6°C

62% RH

SA

27.4°C

63% RH

Temperature and humidity

SA

Integrallyformed liner

RA 32°C

70% RH

RA

26°C

50% RH

Ventilation

Power input - 50Hz Heat exchange mode Nom.

Bypass mode Nom.

Temperature exchange efficiency - 50Hz Ultra high/High/Low

Enthalpy exchange efficiency - 50Hz

Cooling

Heating

Ultra high kW

Ultra high kW

%

Ultra high/High/Low %

Ultra high/High/Low %

Operation mode

Heat exchange system

Heat exchange element

Casing Material

Dimensions

Weight

Fan-Air flow rate

- 50Hz

Unit

Unit

Heat exchange mode Ultra high

Bypass mode

HeightxWidthxDepth mm

Ultra high kg m³/h m³/h

Fan-External static pressure - 50Hz Ultra high

Sound pressure level - 50Hz

Heat exchange mode Ultra high

Bypass mode

Operation range Min.

Max.

Relative humidity

Connection duct diameter

Air filter

Power supply

Current

Type

Ultra high

Phase/Frequency/Voltage

Maximum fuse amps (MFA)

Pa dBA dBA

°CDB

°CDB

% mm

Hz/V

A

Integrally-formed liner

VAM150FA VAM250FA VAM350FB VAM500FB VAM650FB VAM800FB VAM1000FB VAM1500FB VAM2000FB

0.116

0.141

0.132

0.178

0.196

0.373

0.375

0.828

0.852

0.116

74/74/79

0.141

72/72/77

0.132

75/75/80

0.178

74/74/77

0.196

0.373

74/74/76

0.375

75/75/76.5

0.828

75/75/78

0.852

58/58/64

64/64/69

58/58/62

64/64/68

61/61/67

65/65/70

58/58/63

62/62/67 63/63/66

60/60/62

65/65/67

61/61/63

Heat exchange mode / Bypass mode / Fresh-up mode

Air to air cross flow total heat (sensible + latent heat) exchange

61/61/64

66/66/68

61/61/66

66/66/70

150

150

285x776x525

24

69

27 / 28.5

27 / 28.5

100

250

250

64

28 / 29

28 / 29

150

350

350

32

32

Specially processed non-flammable paper

Galvanised steel plate

301x828x816

33

364x1,004x868

52 55

98

500

500

33

33.5

650

650

93

34.5

800

800

137

34.5

-15

50

80% or less

36

36

364x1,004x1,156 726x1,512x868 726x1,512x1,156

64 131 152

1,000

1,000

157

1,500

1,500

137

2,000

2,000

39.5

40.5

40

40

250 350

15

200

Multidirectional fibrous fleeces

1~/50/60/220-240/220

16

Total solution for fresh air with Daikin supply of both VAM and electrical heaters

Increased comfort in low outdoor temperature thanks to the heated outdoor air

Integrated electrical heater concept (no additional accessories required)

Standard dual flow and temperature sensor

Flexible setting with adjustable setpoint

Increased safety with 2 cut-outs: manual & automatic

BMS integration thanks to:

Volt free relay for error indication

0-10VDC input for setpoint control

Capacities ranging from 1 to 2.5 kW

VH Electrical heater for VAM

61

62

Daikin Air handling units

Wide range of air flows

In situations where the Daikin commercial range of ventilation units cannot satisfy the ventilation requirement due to building constraints

(large atriums, banquet halls, etc) air handling units represent the ideal solution. Daikin’s wide range of air handling systems handle air flow rates from 500 m³/h up to 140,000 m³/h. The air handler unit can be adapted to deliver whatever air flow you require, via the specific dimensions of flow section available at the installation.

Air flow (m

3

/h * 1000)

0 15 30 45 60 75 90 105 120 135

The most flexible solution

D-AHU Professional

1,100 m

3

/h up to 140,000 m

3

/h

D-AHU Energy

1,500 m 3 /h

Best seasonal performance and return on investment

up to 70,000 m

3

/h

D-AHU Easy

500 m

3

/h

Ideal to cover your basic AHU needs

up to 30,000 m

3

/h

Daikin fresh air package - plug & play

The D-AHU Professional and Energy series provide a complete solution including unit control (EKEXV, EKEQ, DDC controller) factory mounted and configured, plug & play with our ERQ and

VRV condensing units.

The easiest solution as you save time and only have one point of contact!

Return on investment

The air handling unit (AHU) is critical to an effective climate control system and, although the initial investment can appear high, the savings generated by our advanced designs and operating efficiencies guarantee a rapid return on the investment made.

Our AHU Energy series has been designed to deliver exceptional performance thus driving down the energy consumed and so lowering energy bills. Taken over the expected 15-year life-span of the equipment, this will result in a substantial saving, especially in a time of ever increasing energy prices.

Pre-defined sizes

27 fixed sizes are available, optimized to reach the best compromise between competitiveness and manufacturing standardisation.

However, Daikin’s section by section design means that units can be sized by 1cm increments and assembled on site, without welding, to suit the space constraints of the installation.

High efficiency components

All Daikin air handlers have been designed for optimum energy efficiency. Polyurethane or Mineral wool panels guarantee excellent thermal insulation performance. Filters are provided with a large choice of efficiency filtration class.

ASTRA is the powerful software that Daikin has developed to offer a quick and comprehensive service for the customer in order to make the technical choice and the economic valorization of each AHU. It is a complete tool that can configure any type of product and respond exactly to the strictest design needs. The result is a comprehensive economic offer including all the technical data and drawings, the psychrometric diagram with the relative air treatment and the fans’ performance curves.

The ASTRA software features a specific DX heat pump coil section able to calculate cooling and heating performances with the automatic selection of the appropriate Daikin expansion valve.

63

64

ERQ for air handling unit application

Why use ERQ for connection to air handling units?

High Efficiency

Daikin heat pumps are renowned for their high energy efficiency with COPs up to 4.56 in heating

1

.

1 ERQ100AV1 heat pump

High Comfort Levels

Daikin ERQ units respond rapidly to fluctuations in the supply air temperature, resulting in a steady indoor temperature, together with the dehumidification this results in high comfort levels for the end user.

Easy Design and Installation

The system is easy to design and install since no additional water systems such as boilers, tanks and gas connections etc are required. This also reduces the total system cost.

Flexible control options

In order to maximize installation flexibility,

3 types of control systems are offered.

Control x:

Control of air temperature (discharge temperature, suction temperature, room temperature) via external device (DDC controller)

Control y:

Control of evaporating temperature via Daikin control (no DDC controller needed)

Control z:

Control of air temperature (suction temperature, room temperature) via Daikin control (no DDC controller needed)

Flexible control possibilities for air handling applications

In order to maximise installation flexibility, 3 types of control systems are offered:

Possibility X (Td/Tr control):

Air temperature control via DDC controller

Room temperature is controlled as a function of the air handling unit suction or discharge air (customer selection). The DDC controller is translating the temperature difference between set point and air suction temperature (or air discharge temperature or room temperature) into a reference voltage (0-10V) which is transferred to the Daikin control box (EKEQFCBA). This reference voltage will be used as the main input value for the compressor frequency control.

Possibility Y (Te/Tc control):

By fixed evaporating temperature

A fixed target evaporating temperature of between 3°C and 8°C can be set by the customer. In this case, room temperature is only indirectly controlled. The cooling load is determined from the actual evaporating temperature (i.e. load to the heat exchanger). A Daikin wired remote controller (BRC1D52 or BRC1E52A/B - optional) can be connected for error indication.

Possibility Z (TS/Tr control):

Using Daikin wired remote controller

(BRC1D52 or BRC1E52A/B - optional)

Set point can be fixed via standard Daikin wired remote controller.

Remote ON/OFF can be achieved by an optional adapter KRP4A51.

No external DDC controller should be connected. The cooling load is determined from the air suction temperature and set point on the

Daikin controller.

DDC

Daikin control box:

EKEQFCB

Ts

TR

Te

AHU

Td

Room

Daikin control box:

EKEQFCB

Ts

Te

AHU

Td

TR

Room

BRC1D52

BRC1E52A/B

ON / OFF

KRP4A51

Daikin control box:

EKEQDCB

EKEQMCB

Ts

Te

AHU

Td

TR

Room

BRC1D52

BRC1E52A/B

Ts = Air suction temperature

Td = Air discharge temperature

Tr = Room temperature

Te = Evaporating temperature

AHU = Air Handling Unit

DDC = Digital Display Controller

OPTION KIT

Possibility x

Possibility y

Possibility z

* EKEQMCB (for ’multi’ application)

EKEQFCB

EKEQDCB

EKFQMCB*

FEATURES

DDC controller is required

Temperature control using air suction or air discharge temperature

Using fixed evaporating temperature, no set point can be set using remote controller

Using Daikin wired remote controller BRC1D52 or BRC1E52A/B

Temperature control using air suction temperature

65

ERQ

Air handling application (pair)

A range of R-410A inverter condensing units for pair application with air handling units.

› Inverter controlled units

› Large capacity range (from 100 to 250 class)

› Heat pump

› R-410A

› Wide range of expansion valve kits available

› Up to 4 ERQ units can be connected to an interlaced coil in one air handling unit

The “Daikin Fresh Air Package” provides a complete Plug & Play

Solution including AHU, ERQ or VRV Condensing Unit and all unit control (EKEQ, EKEX, DDC controller) factory mounted and configured. The easiest solution with only one point of contact

.

Daikin air handling unit

F1 - F2

Refrigerant piping

66

VENTILATION

Capacity range

Cooling capacity Nom.

Heating capacity Nom.

Power input Cooling

Heating

EER

COP

Dimensions

Weight

Fan-Air flow rate Cooling

Heating

Sound power level Cooling

Sound pressure level

Cooling

Heating

Operation range Cooling

Refrigerant

Piping connections

Power supply

Current

Unit

Unit

Heating

On coil temperature

Nom.

Nom.

HP kW kW kW kW

HeightxWidthxDepth mm kg

Nom.

Nom.

m³/min m³/min

Nom.

Nom.

Nom.

Min./Max.

Min./Max.

Heating Min.

Cooling Max.

Type

Liquid

Gas

Drain

OD

OD

OD

Phase/Frequency/Voltage

Maximum fuse amps (MFA) dBA dBA dBA

°CDB

°CWB

°CDB

°CDB mm mm mm

Hz/V

A

VENTILATION

Capacity range

Cooling capacity Nom.

Heating capacity Nom.

Power input Cooling

Heating

EER

COP

Dimensions

Weight

Unit

Unit

Fan-Air flow rate Cooling

Heating

Sound power level Nom.

Sound pressure level Nom.

Operation range Cooling

Heating

On coil temperature

Refrigerant

Piping connections

Power supply

Current

Nom.

Nom.

HP kW kW kW kW

HeightxWidthxDepth mm kg

Nom.

Nom.

m³/min m³/min

Min./Max.

Min./Max.

Heating Min.

Cooling Max.

dBA dBA

°CDB

°CWB

°CDB

°CDB

Type

Liquid

Gas

OD

OD

Phase/Frequency/Voltage

Maximum fuse amps (MFA) mm mm

Hz/V

A

ERQ100AV1

4

11.2

12.5

2.81

2.74

4.56

102

66

50

52

ERQ125AW1

5

14.0

16.0

3.52

4.00

3.98

4.00

1,680x635x765

159

95

95

72

54

15.9

16

3.99

15.9

ERQ125AV1

5

14.0

16.0

3.51

3.86

4.15

1,345x900x320

120

106

67

51

53

-5/46

-20/15.5

10

35

R-410A

9.52

26x3

1N~/50/220-240

32.0

105

ERQ140AV1

6

15.5

18.0

4.53

4.57

3.42

3.94

69

53

55

19.1

ERQ200AW1

8

22.4

25.0

5.22

5.56

4.29

4.50

187

171

171

57

-5/43

-20/15

10

35

R-410A

9.52

19.1

3N~/50/400

1,680x930x765

78

ERQ250AW1

10

28.0

31.5

7.42

7.70

3.77

4.09

240

185

185

58

22.2

25

Overview of expansion valves and control boxes

Daikin also offers a range of expansion valve kits and control boxes to connect ERQ to third party air handling units.

ERQ combination table

OUTDOOR UNIT

1~

3 ~

ERQ100AV1

ERQ125AV1

ERQ140AV1

ERQ125AW1

ERQ200AW1

ERQ250AW1

P: Pair: Combination depending on air handling units coils volume.

CLASS 63

EKEXV63

P

P

-

P

-

-

CLASS 80

EKEXV80

P

P

P

P

-

-

CLASS 100

EKEXV100

P

P

P

P

P

-

EXPANSION VALVE KIT

CLASS 125

EKEXV125

P

P

P

P

P

P

CLASS 140

EKEXV140

-

P

P

P

P

P

CLASS 200

EKEXV200

-

-

-

-

P

P

CLASS 250

EKEXV250

-

-

-

-

P

P

EKEXV - Expansion valve kit for air handling applications

EKEXV140 VENTILATION

Dimensions

Weight

Unit

Unit

Sound pressure level Nom.

Operation range On coil temperature

Refrigerant

Piping connections

Type

Liquid

Gas

HeightxWidthxDepth mm

Heating Min.

Cooling Max.

kg dBA

°CDB

°CDB

EKEXV50 EKEXV63 EKEXV80 EKEXV100 EKEXV125

401x215x78

2.9

45

10 (1)

35 (2)

R-410A

OD

OD mm mm

6.35

6.35

(1) The temperature of the air entering the coil in heating mode can be reduced to -5°CDB. Contact your local dealer for more information. (2) 45% Relative humidity.

9.52

9.52

EKEXV200 EKEXV250

EKEQ - Control box for air handling applications

EKEQFCB VENTILATION

Application

Outdoor unit

Dimensions

Weight

Power supply

Unit

Unit

HeightxWidthxDepth mm

Phase/Frequency/Voltage kg

Hz/V

3.9

Pair

ERQ

132x400x200

1~/50/230

EKEQDCB

3.6

67

Control systems

Individual control systems

Wired / infrared remote control

Control systems Siesta Sky Air

68

70

70

Centralised control systems 74

Centralised remote control /

Unified ON/OFF control / Schedule timer 74

DTA113B51 75

75

Management control 78

76

Standard protocol interfaces 80

KNX Interface 80

81

81

Sensors & other devices

Wireless room temperature sensor

Wired room temperature sensor

Other intergration devices

Specifications : Ventilation, condensing units & AHU application 84

82

82

83

Option lists

Ventilation, condensing units

& AHU application

Sky Air

86

86

69

ARC*/BRC*

Individual control systems

70

BRC1D52 BRC944B2 ARC466A1 BRC4*/BRC7* BRC2C51 BRC3A61

BRC944B2*/BRC1D52

Wired remote control

Schedule timer:

Five day actions can be set as follows:

set point: unit is switched ON and normal operation is maintained

-

OFF: unit is switched OFF 1

limits: unit is switched ON and min./max. control (cf. limit operation for more details)

Home leave (frost protection): during absence, the indoor temperature can be maintained at a certain level.

This function can also switch the unit ON/OFF

User friendly HRV function, thanks to the introduction of a button for ventilation mode and fan speed

Constantly monitoring of the system for malfunctions in a total of 80 components

Immediate display of fault location and condition

Reduction of maintenance time and costs

Display

Operating mode

1

Heat Recovery Ventilation (HRV) in operation

Cool / heat changeover control

Centralised control indication

Group control indication

Set temperature

1

Air flow direction

1

Programmed time

Inspection test / operation

Fan speed

1

Clean air filter

Defrost / hot start

Malfunction

1

Only functions marked with ‘1’ are available on BRC944B2

ARC4*/BRC4*/BRC7*

Infrared remote control

Operation buttons: ON / OFF, timer mode start / stop, timer mode on / off, programme time, temperature setting, air flow direction (1), operating mode, fan speed control, filter sign reset (2), inspection (2)/ test indication (2)

Display: Operating mode, battery change, set temperature, air flow direction (1), programmed time, fan speed, inspection / test operation (2)

1. Not applicable for FXDQ, FXSQ, FXNQ, FBDQ, FDXS, FBQ

2. For FX** units only

3. For all features of the remote control, refer to the operation manual

BRC3A61

Simplified built-in remote control for hotel applications

Compact, user friendly unit, ideal for use in hotel bedrooms

Operation buttons: ON/OFF, fan speed control, temperature setting

Display: Heat Recovery Ventilation (HRV) in operation, set temperature, operating mode, centralised control indication, fan speed, defrost/hot start, malfunction

BRC2C51

Simplified remote control

Simple, compact and easy to operate unit, suitable for use in hotel bedrooms

Operation buttons: ON/OFF, operating mode selection, fan speed control, temperature setting

Display: Cool/heat changeover control, Heat Recovery Ventilation (HRV) in operation, set temperature, operating mode, centralised control indication, fan speed, defrost/hot start, malfunction adjustment, operating mode selection, fan speed control, filter sign reset, inspection test/operation

NEW

Simplified wired remote control developed for hotel applications

Symbol driven interface for intuitive control

Functions restricted to basic customer needs

Contemporary design

Energy saving thanks to set point limitation

Flat backpanel for easy installation

2 versions available:

• Heat pump type: temperature, fan speed, ON/OFF

• Heat recovery type: temperature, mode, fan speed, ON/OFF

Replaces existing BRC2C51 & BRC3A61

Available spring 2014

BRC1E52A/B

User friendly remote control with contemporary design

Save energy

A series of energy saving functions that can be individually selected

Temperature range limit

Setback function

Presence & floor sensor connection

(available on new round flow cassette)

› kWh indication

Set temperature auto reset

Off timer

Temperature range limit avoids excessive heating or cooling

Save energy by constraining the lower temperature limit in cooling and upper temperature limit in heating mode.

note : Also available in auto cooling/heating change over mode.

kWh indication keeps track of your consumption

The kWh indication shows an indicative electricity consumption of the last day/ month/year.

Other functions

Up to 3 independent schedules can be set, so the user can easily change the schedule himself throughout the year (e.g. Summer, winter, mid-season)

Possibility to individually restrict menu functions

Easy to use: all main functions directly accessible

Easy setup: clear graphical user interface for advanced menu settings

Real time clock with auto update to daylight saving time

Built-in backup power: when a power failure occurs all settings remain stored up to 48 hours

Supports multiple languages

-

English, German, Dutch, Spanish, Italian, Portuguese, French, Greek, Russian,

Turkish, Polish (BRC1E52A)

-

English, German, Czech, Croatian, Hungarian, Romanian, Slovenian,

Bulgarian, Slovak, Serbian, Albanian (BRC1E52B)

Graphical display of indicative electricity consumption

(function available in combination with FCQG and FCQHG)

71

ARCWLA / ARCWB

Siesta individual control systems

Overview controllers for Siesta Sky Air

Siesta Sky Air indoor units

ACQ-C 4-way blow, ceiling mounted cassette

AHQ-C ceiling suspended

ABQ-C concealed ceiling

Controllers

- Standard infrared remote control (ARCWLA) in box of decoration panel ADP125A

- Optional wired remote control ARCWLA

- Optional group controller R04084124324

- Standard infrared remote control in box of indoor unit ARCWLA

- Optional wired remote control ARCWB

- Optional group controller R04084124324

- Standard wired remote control (ARCWB) in box of indoor unit

- Optional group controller R04084124324

Overview of features

Feature

ARCWB

Option for AHQ-C and ACQ-C

Standard for ABQ-C

5

6

7

3

4

8

9

11

12

13

14

19

20

21

15

16

17

18

1

2

10

ON/OFF switch

Temperature setting

Default range 16-30°C

Optional range 20-30°C

Switch between °C and °F

Room temperature sensor on remote control

Cool / Fan dry / Heat / Auto

Sleep mode

Fan Speed selection

Delay timer

7-days programmable timer

Real time clock display

Air swing selection

ON/OFF swing mode

Change swing option

(draft/soil prevention or standard)

LCD display without backlight

Key lock

Error code indication

IR receiver to enable compatibility with infrared remote control

(disabled when lock function is activated)

Last state memory from indoor PCB

Silent mode

Turbo mode

Compressor test model (compressor force ON)

Daikin inverter error code

UART communication port (for Daikin protocol)

Backup battery

Standard

Standard

By dipswitch selection

Standard

Standard

Standard

Standard

Standard

1, 2 & 4 hours delay

Standard

Standard

Standard

Standard

Standard

Standard

Standard

Standard

Standard

By dipswitch selection

By dipswitch selection

Standard

Standard

Standard

Standard

72

Specifications

Dimensions (length x width x height) ARCWB: 0.15 m x 0.21 m x 0.04 m.

ARCWB comes standard with a 10 meter wire, which can be extended to maximum wire length of 15 meter.

ARCWB can only control one indoor unit at a time; group control is only possible when using option R04084124324.

73

RTD

Integration of

RA, Sky Air, VRV and AHU in BMS or home automation systems

Modbus Interface

RTD-RA

› Modbus interface for monitoring and control of residential indoor units

RTD-NET

› Modbus interface for monitoring and control of Sky Air, VRV,

VAM and VKM

RTD-20

› Advanced control of Sky Air, VRV, VAM/VKM and air curtains

› Clone or independent zone control

› Increased comfort with integration of CO

2 volume control

sensor for fresh air

› Save on runningcosts via

- pre/post and trade mode

- set point limitation

- overall shut down

- PIR sensor for adaptive deadband

74

RTD-10

› Advanced integration into BMS of Sky Air, VRV, VAM and VKM through either:

- Modbus

- Voltage (0-10V)

- Resistance

› Duty/standby function for server rooms

RTD-HO

› Modbus interface for monitoring and control of Sky Air, VRV,

VAM and VKM

› Intelligent hotel room controller

Overview functions

Main functions

Dimensions

Key card + window contact

H x W x D mm

Set back function

Prohibit or restrict remote control functions (setpoint limitation, ...)

Modbus (RS485)

Group control

0 - 10 V control

Resistance control

IT application

Heating interlock

Output signal (on/defrost, error)

Retail application

Partitioned room control

Air curtain

(1): By combining RTD-RA devices

Control functions

On/Off

Set point

Mode fan

Louver

HRV Damper control

Prohibit/Restrict functions

Forced thermo off

Monitoring functions

On/Off

Set point

Mode fan

Louver

RC temperature

RC mode nbr units

Fault

Fault code

Return air temperature (Average /Min/Max)

Filter alarm

Termo on

Defrost

Coil In/Out temperature

RTD-RA

80 x 80 x 37,5

(1)

M

M

M

M

M

RTD-RA

M,C

M

M

M

M

M

M

RTD-RA

M

M

M

M

M

RTD-NET

 ***

RTD-NET

M

M

M

M

M

M

M

RTD-NET

M

M

M

M

M

M

M

M

M

M

M

M

M

M

M

RTD-10

M

M

M

M

M

M

M

M

M

M

M

M

M

M

M

 ***

RTD-10

M,V,R

M,V,R

M,V,R

M,V,R

M,V,R

M,V,R

M,V,R

RTD-10

100 x100 x 22

RTD-20

 ****

 **

RTD-20

M

M

M

M

M

M

M

RTD-20

M

M

M

M

M

M

M

M

M

M

M

M

M

M

M

RTD-HO

RTD-HO

M*

M*

M*

M*

M*

M*

RTD-HO

M

M

M

M

M

M

M

M

M

M

M

M

M

M

M

M : Modbus / R : Resistance / V : Voltage / C: control

* : only when room is occupied / ** : setpoint limitation / (*) if available

*** : no fan speed control on the CYV air curtain / **** : run & fault

75

Centralised control systems

DCS302C51 DCS301B51

DST301B51

Centralised control of the Sky Air and VRV system can be achieved via 3 user friendly compact controls: centralised remote control, unified on/off control and schedule timer. These controls may be used independently or in combination where 1 group = several (up to 16) indoor units in combination and 1 zone = several groups in combination.

A centralised remote control is ideal for use in tenanted commercial buildings subject to random occupation, enabling indoor units to be classified in groups per tenant (zoning).

The schedule timer programmes the schedule and operation conditions for each tenant and the control can easily be reset according to varying requirements.

76

DCS302C51

Centralised remote control

Providing individual control of 64 groups

(zones) of indoor units.

• a maximum of 64 groups

(128 indoor units, max. 10 outdoor units) can be controlled

• a maximum of 128 groups

(128 indoor units, max. 10 outdoor units) can be controlled via 2 centralised remote controls in separate locations

• zone control

• group control

• malfunction code display

• maximum wiring length of

1,000m (total: 2,000m)

• air flow direction and air flow rate of HRV can be controlled

• expanded timer function

DCS301B51

Unified ON/OFF control

Providing simultaneous and individual control of 16 groups of indoor units.

DST301B51

Schedule timer

Enabling 64 groups to be programmed.

• a maximum of 16 groups

(128 indoor units) can be controlled

• 2 remote controls in separate locations can be used

• operating status indication

(normal operation, alarm)

• centralised control indication

• maximum wiring length of 1,000m

(total: 2,000m)

• a maximum of 128 indoor units can be controlled

• 8 types of weekly schedule

• a maximum of 48 hours back up power supply

• a maximum wiring length of

1,000m (total: 2,000m)

DTA113B51

Basic solution for control of Sky Air and VRV

DS-NET adapter

DTA113B51

› Rotation function

› Backup operation function.

BRC1D52

Up to 4 units / 1 adapter

DCS601C51

Detailed & easy monitoring and operation of

VRV systems (max. 64 indoor units groups)

Air conditioning

Network Service

System

Public line

Onboard modem third party controller (domotics, BMS, etc.)

Ethernet

DIII-NET

Forced OFF contact input

Fire alarm

Indoor units HRV

DCS601C51

Languages

English

French

German

Italian

Spanish

Dutch

Portuguese

System layout

Up to 64 indoor units can be controlled

Touch panel (full colour LCD via icon display)

Management

Easy management of electricity consumption

Enhanced history function

Control

Individual control

(set point, start/stop, fan speed) (max. 64 groups/indoor units)

Set back shedule

Enhanced scheduling function

(8 schedules, 17 patterns)

Flexible grouping in zones

Yearly schedule

Fire emergency stop control

Interlocking control

Increased HRV monitoring and control function

Automatic cooling / heating change-over

Heating optimization

Temperature limit

Password security: 3 levels

(general, administration & service)

Quick selection and full control

Simple navigation

Monitoring

Visualisation via Graphical User

Interface (GUI)

Icon colour display change function

Indoor units operation mode

Indication filter replacement

Multi PC

Cost performance

Free cooling function

Labour saving

Easy installation

Compact design: limited installation space

Overall energy saving

Open interface

Communication to any third party controller (domotics,

BMS, etc.) is possible via open interface (http option)

Connectable to

VRV

HRV

Sky Air

Split (via interface adapter)

77

New

Mini Building Management System

Mini BMS with full integration across all product pillars

System overview

iTM Integrator

(DCM601A53)

A maximum of 5 intelligent Touch

Managers can be connected to a single iTM Integrator.

9

Price competitive mini BMS

9

Cross-pillar integration of Daikin products

9

Integration of third party equipment

HUB Up to 2,560 groups

78

Fire alarm kWh meter

Di/Pi line

Max. 200m

NE

W

BACnet protocol

WAGO interface

DCM601A51

Internet

Extranet

LAN

Web

Access

Direct plug & play connection!

Split

indoor units, air curtain, hydrobox

Lighting

Pump

Fan

Sensor

NE

W

NE

W

Mini Building Management System DCM601A51

User friendliness

› Intuitive user interface

› Visual lay out view and direct access to indoor unit main funtions

› All functions direct accessible via touch screen or via web interface

Smart energy management

› Monitoring if energy use is according to plan

› Helps to detect origins of energy waste

› Powerful schedules guarantee correct operation throughout the year

› Save energy by interlocking A/C operation with other equiment such as heating

Flexibility

› Cross-pillar integration (heating, air conditioning, applied systems, refrigeration)

› BACnet protocol for 3rd party products integration

› I/O for integration of equipment such as lights, pumps… on WAGO modules

› Modular concept for small to large applications

› Control up to 2,560 indoor unit groups

Easy servicing and commissioning

› Remote refrigerant containment check preventing on site visit

› Simplified troubleshooting

› Save time on commissioning thanks to the pre-commissioning tool

› Auto registration of indoor units

Functions overview

DCM601A51

Languages

› English

› French

› German

› Italian

› Spanish

› Dutch

› Portuguese

System layout

› Up to 2,560 unit groups can be controlled

(ITM plus Integrator + 7 iPU (incl. iTM adaptor)

› Ethernet TCPIP

Management

› Web access

› Power Proportional Distribution (option)

› Operational history (malfunctions, operation hours, …)

› Smart energy management

› - monitor if energy use is according to plan

› - detect origins of energy waste

› Setback function

› Sliding temperature

Control

› Individual control (2,560 groups)

› Schedule setting (Weekly schedule, yearly calender, seasonal schedule)

› Interlock control

› Setpoint limitation

› Temperature limit

Flexibility in size

64 up to 2,560 groups

WAGO Interface

› Modular integration of 3rd party equipment

- WAGO coupler

(interface between WAGO and Modbus)

- Di module

- Do module

- Ai module

- Thermistor module

Connectable to

-

DX Split, Sky Air, VRV

- Chillers

(via POL638.70 controller)

- Daikin AHU

- Fan coils

- Daikin Altherma Flex type

- LT and HT hydroboxes

- Air curtains

- WAGO I/O

- BACnet protocol

79

80

Standard protocol interfaces

KNX interface

Integration

of Sky Air and VRV in HA/BMS systems

Connect Sky Air / VRV indoor units to KNX interface for BMS integration

light shop shutter control tv

Interface Daikin protocol/ KNX

Domotica

Controller

KNX interface line-up

The integration of Daikin indoor units through the KNX interface allows monitoring and control of several devices, such as lights and shutters, from one central controller. One particularly important feature is the ability to programme a ‘scenario’ - such as “Home leave” - in which the end-user selects a range of commands to be executed simultaneously once the scenario is selected. For instance in “Home leave” , the air conditioner is off, the lights are turned off, the shutters are closed and the alarm is on.

KNX interface for

BASIC CONTROL

ON/OFF

Mode

Temperature

Fan speed levels

Swing

ADVANCED FUNCTIONALITIES

Error management

Scenes

Auto switch off

Temperature limitation

Initial configuration

Master and slave configuration

Sky Air

Auto, heat, dry, fan, cool

2 or 3

Stop or movement

KLIC-DI Size 45x45x15mm

VRV

Auto, heat, dry, fan, cool

2 or 3

Swing or fixed positions (5)

Communication errors,

Standard protocol interfaces

BACnet Interface

Integrated control system for seamless connection between VRV and BMS systems

› PPDdata is available on BMS system

› Interface for BMS system

› Communication via BACnet protocol

(connection via Ethernet)

› 256 units connectable per BACnet gateway

› Unlimited sitesize

› Easy and fast installation

DIII- NET

DAM602B51/52 Local Control

VAM

DAIKIN A/C INFRASTRUCTURE

Sky Air

Outdoor unit

Remote Control

Security Power supply facility

Fire alarm

Building

Control

Network

Pump Lighting Elevator

Standard protocol interfaces

LonWorks Interface

Open integration of VRV monitoring and control functions into LonWorks networks

› Interface for Lon connection to

LonWorks networks

› Communication via Lon protocol

(twisted pair wire)

› 64 units connectable per DMS-IF

› Unlimited sitesize

› Quick and easy installation

LON BMS adapter

LonTalk

DMS504B51

VAM

Local Control

Building control network adapter

LonPoint

LonTalk

LonPoint

Security

Fire alarm

System

DIII- NET

Sky Air

Outdoor unit

Remote Control

DAIKIN A/C INFRASTRUCTURE

81

K.RSS

Wireless room temperature sensor

Flexible and easy installation

› Accurate temperature measurement thanks to flexible placement of the sensor

› No need for wiring

› No need to drill holes

› Ideal for refurbishment

Connection diagram

Daikin indoor unit PCB (FBQ-C8 example)

Power supply – X35A

Air sensor – X16A

RF RECEIVER RF SENDER

Specifications

Dimensions

Weight

Power supply

Battery life

Battery type

Maximum range

Operation range

Communication

Type

Frequency mm g m

°C

MHz

WIRELESS ROOM TEMPERATURE SENSOR KIT (K.RSS)

WIRELESS ROOM TEMPERATURE RECEIVER WIRELESS ROOM TEMPERATURE SENSOR

50 x 50

40

16VDC, max. 20 mA

N/A

N/A

ø 75

60

N/A

+/- 3 years

3 Volt Lithium battery

10

0~50

RF

868.3

› Room temperature is sent to the indoor unit every 90 seconds or if the temperature difference is 0.2°C or larger.

KRCS01-1B

KRCS01-4B

› Accurate temperature measurement, thanks to flexible placement of the sensor

Wired room temperature sensor

82

Specifications

Dimensions (HxW)

Weight

Length of branch wiring mm g m

60 x 50

300

12

Other integration devices

Daikin’s adapter PCB’s provide simple solutions for unique requirements. They are a low cost option to satisfy simple control requirements and can be used on single or multiple units.

(E)KRP1B* adapter for wiring

KRP2A*/KRP4A*

Wiring adapter for electrical appendices

› Facilitates integration of auxiliary heating apparatus, humidifiers, fans, damper

› Powered by and installed at the indoor unit

› Remotely start and stop up to 16 indoor units (1 group) (KRP2A* via P1 P2)

› Remotely start and stop up to 128 indoor units (64 groups) (KRP4A* via F1 F2)

› Alarm indication/ fire shut down

› Remote temperature setpoint adjustment

Concept and benefits

› Low cost option to satisfy simple control requirements

› Deployed on single or multiple units

83

Ventilation, condensing units & AHU application

ERQ

Central drain pan

Central drain plug

Cool/heat selector

Fixing box

ERQ100-125AV1

KKPJ5F180

ERQ140AV1

KKPJ5F180

KRC19-26A6

KJB111A

ERQ125AW1

KWC26B160

-

ERQ200-250AW1

KWC26B280

Notes

(1) Filter chamber has a suction-type flange. (Main unit does not). Some options may not be usable due to the equipment installations conditions. Please conrfirm prior to ordering. Some options may not be used in combination. Operating sound may increase somewhat depending on the options used.

Dust filters EN779 Medium M6

EN779 Fine F7

EN779 Fine F8

Model name Silencer

Nominal pipe Diameter (mm)

CO

2

sensor

VH electrical heater for VAM

VAM150FA

-

-

VH1B

-

-

-

-

VAM250FA

-

-

VH2B

-

-

-

-

VAM350FB

EKAFV50F6

EKAFV50F7

EKAFV50F8

-

-

BRYMA65

VH2B

VAM500FB

EKAFV50F6

EKAFV50F7

EKAFV50F8

KDDM24B50

200

BRYMA65

VH3B

VAM650FB

EKAFV80F6

EKAFV80F7

EKAFV80F8

KDDM24B100

200

BRYMA65

VH3B

VAM800FB VAM1000FB VAM1500FB VAM2000FB

EKAFV80F6

EKAFV80F7

EKAFV100F6 EKAFV100F6 x2 EKAFV100F6 x2

EKAFV100F7 EKAFV100F7 x2 EKAFV100F7 x2

EKAFV80F8 EKAFV100F8 EKAFV100F8 x2 EKAFV100F8 x2

KDDM24B100 KDDM24B100 KDDM24B100 x2 KDDM24B100 x2

250 250

BRYMA100 BRYMA100

VH4B / VH4/AB VH4B / VH4/AB

250

BRYMA200

VH5B

250

BRYMA200

VH5B

INDIVIDUAL CONTROL SYSTEMS

Wired remote control

VAM wired remote control

VAM-FA/FB

BRC1D52

BRC301B61

EKEQFCB 2

BRC1D52

-

EKEQDCB 2

BRC1D52

1

-

EKEQMCB 2

BRC1D52

1

-

CENTRALISED CONTROL SYSTEMS

Centralised remote control

Unified ON/OFF control

Schedule timer

VAM-FA/FB

DCS302C51

DCS301B51

DST301B51

EKEQFCB

2

-

-

-

OTHERS VAM150-250FA VAM350-2000FB EKEQFCB 2

Wiring adaptor for electrical appendices (note 6)

Adaptor PCB for humidifier

KRP2A51 (3)

KRP50-2 (3)

KRP2A51(3)

BRP4A50A (4/5)

KRP2A61

-

Adaptor PCB for 3rd party heater

Remote sensor

BRP4A50

-

BRP4A50A (4/5)

-

-

-

Notes

(1) Cool/heat selector required for operation

(2) Do not connect the system to DIII-net devices (Intelligent controller, Intelligent Manager, LonWorks interface, BACnet interface…).

(3) Installation box KRP50-2A90 needed for VAM150-250FA.

(4) Fixing plate EKMPVAM additionally needed for VAM1500-2000FB.

(5) 3rd party heater and 3rd party humidifier cannot be combined

(6) For external control and monitoring (ON/OFF control, operation signal, error indication)

(7) Only use ERQ, EKEQ, EKEXV in combination with an air handling unit. Do not connect this system to other indoor units.

EKEQDCB

2

-

-

-

EKEQDCB 2

-

-

-

-

EKEQMCB

2

-

-

-

EKEQMCB 2

KRP4A51

-

-

KRCS01-1

Supply voltage

Output current (maximum)

Temperature sensor

Temperature control range

Run on timer

Control fuse

LED indicators

Mounting holes

Maximum ambient adjacent to terminal box

Auto high temp. cutout

Man. reset high temp. cutout

Run relay

BMS setpoint input

VH ELECTRICAL HEATER FOR VAM

220/250V ac 50/60 Hz. +/-10%

19A at 40°C (ambient)

5k ohms at 25°C (table 502 1T)

0 to 40°C / (0-10V 0-100%)

Adjustable from 1 to 2 minutes (factory set at 1.5 minutes)

20 X5 mm 250 m A

Power ON - Yellow

Heater ON - Red (solid or flashing, indicating pulsed control)

Airflow fault - Red

98mm X 181mm centres 5 mm ø holes

35°C (during operation)

100°C Pre-set

125°C Pre-set

1A 120V AC or 1A 24V DC

0-10VDC

VH ELECTRICAL HEATER FOR VAM

Capacity

Duct diameter

Connectable VAM kW mm

OUTDOOR UNITS

Air direction adjustment grille

VH1B

1

100

VAM150FA

-

VH2B

1

150

VAM250FA

VAM350FB

VH3B

1

200

VAM500FB

VAM650FB

VH4B

1.5

250

VAM800FB

VAM1000FB

VH4/AB

2.5

250

VAM800FB

VAM1000FB

VH5B

2.5

350

VAM1500FB

VAM2000FB

2MXS40H 2MXS50H 3MXS40K 3MXS52E

KPW945A4

3MXS68G 4MXS68F 4MXS80E 5MXS90E

External control adaptor for outdoor unit

Allows to activate Low Noise Operation and three levels of Demand Limiting via external dry contacts. Connects to the F1/F2 communication line and requires power supply from an indoor unit.

KRC19-26A6

Mechanical cool/heat selector – allows to switch an entire Heat Pump system, or one BS-box of a Heat Recovery system between cooling, heating and fan only. Connects to the A-B-C terminals of the outdoor unit / BS-box.

KJB111A

Installation box for remote cool/heat selector KRC19-26

BPMKS967B2B/B3B

Branch provider (for connection of 2/3 RA indoor units)

KKPJ5F180

Central drain plug

RXYSQ

DTA104A53/61/62

For installation into an indoor unit: exact adaptor type depends on type of indoor unit

See options & accessories of indoor units

85

86

Options & accessories -

INDOOR UNITS - CONTROL SYSTEMS

Wired remote control

Infrared remote control + decoration panel

I-touch controller

Infrared remote control (heat pump)

Simplified remote control

Remote control for hotel use

Centralised remote control

Unified ON/OFF control

Schedule timer

Adapter for wiring (interlock for fresh air intake fan)

Adapter for external ON/OFF and monitoring/for electrical appendices

Interface adapter for Sky Air

Installation box for adapter PCB

Remote sensor

Remote ON/OFF, forced OFF

FCQHG71F FCQHG100F FCQHG125F FCQHG140F FCQG35F FCQG50F FCQG60F FCQG71F FCQG100F FCQG125F FCQG140F ACQ71B ACQ100B ACQ125B FFQ25C FFQ35C FFQ50C FFQ60C FDBQ25B FBQ35C8 FBQ50C8 FBQ60C8 FBQ71C8 FBQ100C8 FBQ125C8 FBQ140C8 ABQ71B ABQ125A ABQ140A

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

DCS601C51

BRC7FA532F (5)

-

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP1B57/KRP4A53 (1)(5)

-

KRP1H98 (5)

KRCS01-4

EKRORO2

Electrical box with earth terminal (3 blocks)

Electrical box with earth terminal (2 blocks)

KJB311A

KJB212A

Adapter for wiring (hour meter)

Options PCB for external electrical heater, humidifier and/or hour meter

EKRP1C11 (1)(5)

-

Option PCB for group control (NIM03) -

Notes

(1) Installation box for adapter PCB is necessary

(2) Interface adapter for Sky Air series (DTA112B51) is necessary

(3) Including following languages: English, German, French, Italian, Spanish, Dutch, Greek, Russian, Turkish, Purtuguese, Polish

(4) Including following languages: English, German, Czech, Croatian, Hungarian, Romanian, Slovenian, Bulgarian, Slovak, Serbian, Albanian.

(5) Option not available in combination with BYCQ140*G

(6) Installation box for adapter PCB (KRP1B101) is necessary

(7) Electrical heater, humidifier and hour meter are field supply. These parts should not be installed inside the equipment.

(8) Sensing function is not available

(9) Independently controllable flaps function is not available

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

DCS601C51

BRC7FA532F (5)

-

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP1B57/KRP4A53 (1)(5)

-

KRP1H98 (5)

KRCS01-4

-

KJB311A

KJB212A

EKRP1C11 (1)(5)

-

-

ARCWB

ADP125A

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

R04084124324

BRC1D52 / BRC1E52A (3) - BRC1E52B (4)(9)

-

DCS601C51

BRC7EB530/BRC7F530W/BRC7F530S (8-9)

-

-

DCS302B51

DCS301B51

DST301B51

-

KRP1B57/KRP4A53(6)

-

KRP1B101/ KRP1BA101

KRCS01-4

-

-

-

EKRP1B2

-

-

BRC1D52 /

BRC1E52A (3)

BRC1E52B (4)

-

-

EKRP1B2

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

BRC1D52 / BRC1E52A (3) BRC1E52B (4)

-

DCS601C51 (2)

BRC4C65

-

BRC3A61

DCS302C51

DCS301B51

DST301B51

KRP1B54

KRP4A51/KRP2A51

DTA112B51

-

KRCS01-1

EKRORO3

-

-

-

EKRP1B2A (7)

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

R04084124324

INDOOR UNITS

Replacement long-life filter

Drain pump kit

Sealing member of air discharge outlet

Decoration panel

Decoration panel + infrared remote control

Kit for mounting of decoration panel direct onto unit

Fresh air intake kit (direct installation type)

Air discharge adapter for round duct

Panel spacer

FCQHG71F FCQHG100F FCQHG125F FCQHG140F FCQG35F FCQG50F FCQG60F FCQG71F FCQG100F FCQG125F FCQG140F ACQ71B ACQ100B ACQ125B FFQ25C FFQ35C FFQ50C FFQ60C FDBQ25B FBQ35C8 FBQ50C8 FBQ60C8 FBQ71C8 FBQ100C8 FBQ125C8 FBQ140C8 ABQ71B ABQ125A ABQ140A

KAFP551K160 standard

KDBHQ55B140 (4)

BYCQ140D + BYCQ140DW(1) + BYCQ140DG (2)(3)

-

-

KDDQ55B140-1 (4)+ KDDQ55B140-2 (6)

-

-

KAFP551K160 standard

KDBHQ55B140 (4)

BYCQ140D + BYCQ140DW(1) + BYCQ140DG (2)(3)

-

KDDQ55B140-1 (4)+ KDDQ55B140-2 (6)

-

-

-

Sensor kit BRYQ140A (5) BRYQ140A (5)

Notes

(1) The BYCQ140DW has white insulations. Be informed that dirt is more visible on white insulation and that it is consequently not advised to install the BYCQ140DW decoration panel in environments exposed to concentrations of dirt.

(2) To be able to control the BYCQ140DG, the controller BRC1E* is needed

(3) The BYCQ140DG is only compatible with Sky Air RZQ(G), RZQS(G); All VRV outdoors; Split RKS, RXS

(4) Option not available in combination with BYCQ140DG

(5) Sensor kit can only be operated with BRC1E52A/B

(6) BYFQ60B2 = basic , BYFQ60CW = White , BYFQ60CS = Grey

(7) BRYQ60AW = White, BRYQ60AS = Grey

(8) Both parts of the fresh air intake kit are needed for each unit.

standard

-

-

ADP125A

-

-

-

-

-

KAFQ441BA60 standard

BDBHQ44C60

BYFQ60B3/BYFQ60CW/BYFQ60CS (6)

-

-

KDDQ44XA60

-

KDBQ44B60

BRYQ60AW/BRYQ60AS (7)

-

-

-

-

-

-

-

-

-

-

BYBS45D

BYBS45D

KDAJ25K56A

standard

BYBS71D

BYBS71D

KDAJ25K71A

-

-

-

-

-

BYBS125D

BYBS125D

KDAJ25K140A

-

-

-

-

-

-

-

-

-

-

INDOOR UNITS - CONTROL SYSTEMS

Wired remote control

Infrared remote control + decoration panel

I-touch controller

Infrared remote control (heat pump)

Simplified remote control

Remote control for hotel use

Centralised remote control

Unified ON/OFF control

Schedule timer

Adapter for wiring (interlock for fresh air intake fan)

Adapter for external ON/OFF and monitoring/for electrical appendices

Interface adapter for Sky Air

Installation box for adapter PCB

Remote sensor

Remote ON/OFF, forced OFF

FCQHG71F FCQHG100F FCQHG125F FCQHG140F FCQG35F FCQG50F FCQG60F FCQG71F FCQG100F FCQG125F FCQG140F ACQ71B ACQ100B ACQ125B

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

DCS601C51

BRC7FA532F (5)

-

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP1B57/KRP4A53 (1)(5)

-

KRP1H98 (5)

KRCS01-4

EKRORO2

Electrical box with earth terminal (3 blocks)

Electrical box with earth terminal (2 blocks)

KJB311A

KJB212A

Adapter for wiring (hour meter)

Options PCB for external electrical heater, humidifier and/or hour meter

EKRP1C11 (1)(5)

-

Option PCB for group control (NIM03) -

Notes

(1) Installation box for adapter PCB is necessary

(2) Interface adapter for Sky Air series (DTA112B51) is necessary

(3) Including following languages: English, German, French, Italian, Spanish, Dutch, Greek, Russian, Turkish, Purtuguese, Polish

(4) Including following languages: English, German, Czech, Croatian, Hungarian, Romanian, Slovenian, Bulgarian, Slovak, Serbian, Albanian.

(5) Option not available in combination with BYCQ140*G

(6) Installation box for adapter PCB (KRP1B101) is necessary

(7) Electrical heater, humidifier and hour meter are field supply. These parts should not be installed inside the equipment.

(8) Sensing function is not available

(9) Independently controllable flaps function is not available

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

DCS601C51

BRC7FA532F (5)

-

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP1B57/KRP4A53 (1)(5)

-

KRP1H98 (5)

KRCS01-4

-

KJB311A

KJB212A

EKRP1C11 (1)(5)

-

-

ARCWB

ADP125A

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

R04084124324

FFQ25C FFQ35C

-

-

-

-

-

-

-

-

-

FFQ50C FFQ60C FDBQ25B FBQ35C8 FBQ50C8 FBQ60C8 FBQ71C8 FBQ100C8 FBQ125C8 FBQ140C8 ABQ71B ABQ125A ABQ140A

BRC1D52 / BRC1E52A (3) - BRC1E52B (4)(9)

-

DCS601C51

BRC7EB530/BRC7F530W/BRC7F530S (8-9)

DCS302B51

DCS301B51

DST301B51

KRP1B57/KRP4A53(6)

KRP1B101/ KRP1BA101

KRCS01-4

EKRP1B2

BRC1D52 /

BRC1E52A (3)

BRC1E52B (4)

-

-

EKRP1B2

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

BRC1D52 / BRC1E52A (3) BRC1E52B (4)

-

DCS601C51 (2)

BRC4C65

-

BRC3A61

DCS302C51

DCS301B51

DST301B51

KRP1B54

KRP4A51/KRP2A51

DTA112B51

-

KRCS01-1

EKRORO3

-

-

-

EKRP1B2A (7)

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

R04084124324

INDOOR UNITS

Replacement long-life filter

Drain pump kit

Sealing member of air discharge outlet

Decoration panel

Decoration panel + infrared remote control

Kit for mounting of decoration panel direct onto unit

Fresh air intake kit (direct installation type)

Air discharge adapter for round duct

Panel spacer

FCQHG71F FCQHG100F FCQHG125F FCQHG140F FCQG35F FCQG50F FCQG60F FCQG71F FCQG100F FCQG125F FCQG140F ACQ71B ACQ100B ACQ125B FFQ25C FFQ35C

KAFP551K160 standard

KDBHQ55B140 (4)

BYCQ140D + BYCQ140DW(1) + BYCQ140DG (2)(3)

-

-

KDDQ55B140-1 (4)+ KDDQ55B140-2 (6)

-

-

KAFP551K160 standard

KDBHQ55B140 (4)

BYCQ140D + BYCQ140DW(1) + BYCQ140DG (2)(3)

-

KDDQ55B140-1 (4)+ KDDQ55B140-2 (6)

-

-

-

Sensor kit BRYQ140A (5) BRYQ140A (5)

Notes

(1) The BYCQ140DW has white insulations. Be informed that dirt is more visible on white insulation and that it is consequently not advised to install the BYCQ140DW decoration panel in environments exposed to concentrations of dirt.

(2) To be able to control the BYCQ140DG, the controller BRC1E* is needed

(3) The BYCQ140DG is only compatible with Sky Air RZQ(G), RZQS(G); All VRV outdoors; Split RKS, RXS

(4) Option not available in combination with BYCQ140DG

(5) Sensor kit can only be operated with BRC1E52A/B

(6) BYFQ60B2 = basic , BYFQ60CW = White , BYFQ60CS = Grey

(7) BRYQ60AW = White, BRYQ60AS = Grey

(8) Both parts of the fresh air intake kit are needed for each unit.

standard

-

-

ADP125A

-

-

-

-

-

FFQ50C

KAFQ441BA60 standard

BDBHQ44C60

FFQ60C FDBQ25B FBQ35C8 FBQ50C8 FBQ60C8 FBQ71C8 FBQ100C8 FBQ125C8 FBQ140C8 ABQ71B ABQ125A ABQ140A

BYFQ60B3/BYFQ60CW/BYFQ60CS (6)

-

-

KDDQ44XA60

-

KDBQ44B60

BRYQ60AW/BRYQ60AS (7)

-

-

-

-

-

-

-

-

-

-

BYBS45D

BYBS45D

KDAJ25K56A

standard

BYBS71D

BYBS71D

KDAJ25K71A

-

-

-

-

-

BYBS125D

BYBS125D

KDAJ25K140A

-

-

-

-

-

-

-

-

-

-

87

88

Options & accessories -

INDOOR UNITS - CONTROL SYSTEMS FDQ125C FDQ200B FDQ250B FAQ71C FAQ100C

Wired remote control BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

I-touch controller

Infrared remote control (heat pump)

Simplified remote control

Remote control for hotel use

Centralised remote control

Unified ON/OFF control

Schedule timer

Adapter for wiring (interlock for fresh air intake fan)

DCS601C51

BRC4C65 -

-

-

-

DCS302C51

DCS301B51

DST301B51

KRP1B54 KRP1C64

Adapter for external ON/OFF and monitoring/for electrical appendices

Interface adapter for Sky Air (2)

Installation box for adapter PCB

Remote sensor

Remote ON/OFF, forced OFF

Electrical box with earth terminal (3 blocks)

Electrical box with earth terminal (2 blocks)

Options PCB for external electrical heater, humidifier and/or hour meter

Mounting plate for adapter PCB

-

KRCS01-4B

EKRORO3

EKRP1B2

KRP4A96

KRP4A51

DTA112B51

-

-

-

-

EKRORO

EKRP1B2

-

Option PCB for group control (NIM03) -

Notes

(1) Installation box for adapter PCB is necessary

(2) Interface adapter for Sky Air series (DTA112B51) is necessary

(3) Including following languages: English, German, French, Italian, Spanish, Dutch, Greek, Russian, Turkish, Purtuguese, Polish

(4) Including following languages: English, German, Czech, Croatian, Hungarian, Romanian, Slovenian, Bulgarian, Slovak, Serbian, Albanian.

(5) Electrical heater, humidifier and hour meter are field supply. These parts should not be installed inside the equipment.

(6) With the infrared remote control, the individual flap control and automatic air volume control cannot be controlled.

BRC1D52 / BRC1E52A (3) /

BRC1E52B (4)

DCS601C51

BRC7EB518

BRC2C51

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP4A51 (1)

-

KRP4A93

KRCS01-1

-

KJB311A

KJB212A

-

-

-

INDOOR UNITS FDQ125C FDQ200B

Replacement long-life filter

Drain pump kit

L-type piping kit (upward direction)

Sealing member of air discharge outlet

Decoration panel for air discharge

Decoration panel

Decoration panel option standard

-

-

-

-

BYBS125D(1)

EKBYBSD

Noise filter

Air discharge adapter for round duct

Fresh air intake kit (direct installation type)

Notes

(1) Decoration panel option EKBYBSD is required for direct mounting of the decoration panel of the unit.

-

-

KDAJ25K140A

-

FDQ250B FAQ71C FAQ100C

-

K-KDU572EVE

-

-

-

-

-

KEK26-1A

-

-

FHQ35C FHQ50C FHQ60C FHQ71C

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

BRC7G53

-

-

DCS302C51

DCS301B51

DST301B51

-

KRP1B54 / KRP4A52(1)

-

KRP1D93A

KRCS01-4B

EKRORO4

KJB311A

KJB212A

-

-

-

FHQ35C FHQ50C

KAFP501A56

KHFP5M35

KDU50P60

KHFP5N63

FHQ60C FHQ71C

KAFP501A80

-

-

-

-

-

-

KDDQ50A140

FHQ100C

FHQ100C

KAFP501A160

KDU50P140

KHFP5N160

FHQ125C FHQ140C

FHQ125C AHQ71C

AHQ71C AHQ100C AHQ125C

ARCWB

-

-

-

-

-

-

-

-

-

R04084124324

-

-

-

-

-

-

-

-

AHQ140C

AHQ100C

-

-

-

-

-

-

-

-

-

-

AHQ125C AHQ140C FUQ71C

FUQ71C FUQ100C FUQ125C

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

BRC7C58 (6)

-

-

DCS302C51

DCS301B51

DST301B51

-

KRP4A53 (1)

-

KRP1B97

KRCS01-4

EKRORO5

KJB311A

KJB212A

-

-

-

FUQ100C

KAFP551K160 standard

-

KDBHP49B140

KDBTP49B140

-

-

-

-

-

FUQ125C FVQ71C

FVQ71C FVQ100C FVQ125C FVQ140C

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

DCS301C51

-

BRC2C51

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP1B57 / KRP4A52

-

KRP4AA95

-

-

-

-

-

-

-

FVQ100C FVQ125C

KAFJ95L160

-

-

-

-

-

-

-

-

-

FVQ140C

OUTDOOR UNITS RZQG71L8V1/Y1 RZQG100L8V1/Y1 RZQG125L8V1/Y1 RZQG140LV1/Y1

Air direction adjustment grille

Central drain plug -

-

Refrigerant branch piping

For twin

For triple

For double twin

-

-

KHRQ22M20TA (KHRQ58T) ²

KHRQ127H (KHRQ58T) ²

KHRQ22M20TA (KHRQ58T)²

KRP58M51

-

Demand adapter kit

Bottom plate heater EKBPH140L7 1

Notes

(1) Bottom plate heater is only available for RZQG* models

(2) For combination of RZQ(S)G71-140 in combination with FCQG35-71F or FCQHG71F use the refrigerant branch piping mentioned between brackets.

(3) For RZQG71L8V1 and EKBPH140L7 it is required to use the demand adapter kit KRP58M51 in order to connect the bottom plate heater.

-

RZQSG71L3V1

-

RZQSG100L8V1/Y1 RZQSG125L8V1/Y1 RZQSG140LV1/Y1

-

-

KHRQ22M20TA (KHRQ58T) ²

KHRQ127H (KHRQ58T)²

KHRQ22M20TA (KHRQ58T)²

KRP58M51

-

AZQS71BV1/BY1 AZQS125BV1/BY1

-

-

-

-

-

KRP58M51

AZQS140BV1/BY1

-

RZQ200C RZQ250C

-

KWC26B280

KHRQ22M20TA

KHRQ250H7

KHRQ22M20TA (x3)

KRP58M51

INDOOR UNITS - CONTROL SYSTEMS FDQ125C FDQ200B FDQ250B FAQ71C FAQ100C

Wired remote control BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

I-touch controller

Infrared remote control (heat pump)

Simplified remote control

Remote control for hotel use

Centralised remote control

Unified ON/OFF control

Schedule timer

Adapter for wiring (interlock for fresh air intake fan)

DCS601C51

BRC4C65 -

-

-

-

DCS302C51

DCS301B51

DST301B51

KRP1B54 KRP1C64

Adapter for external ON/OFF and monitoring/for electrical appendices

Interface adapter for Sky Air (2)

Installation box for adapter PCB

Remote sensor

Remote ON/OFF, forced OFF

Electrical box with earth terminal (3 blocks)

Electrical box with earth terminal (2 blocks)

Options PCB for external electrical heater, humidifier and/or hour meter

Mounting plate for adapter PCB

-

KRCS01-4B

EKRORO3

EKRP1B2

KRP4A96

KRP4A51

DTA112B51

-

-

-

-

EKRORO

EKRP1B2

-

Option PCB for group control (NIM03) -

Notes

(1) Installation box for adapter PCB is necessary

(2) Interface adapter for Sky Air series (DTA112B51) is necessary

(3) Including following languages: English, German, French, Italian, Spanish, Dutch, Greek, Russian, Turkish, Purtuguese, Polish

(4) Including following languages: English, German, Czech, Croatian, Hungarian, Romanian, Slovenian, Bulgarian, Slovak, Serbian, Albanian.

(5) Electrical heater, humidifier and hour meter are field supply. These parts should not be installed inside the equipment.

(6) With the infrared remote control, the individual flap control and automatic air volume control cannot be controlled.

BRC1D52 / BRC1E52A (3) /

BRC1E52B (4)

DCS601C51

BRC7EB518

BRC2C51

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP4A51 (1)

-

KRP4A93

KRCS01-1

-

KJB311A

KJB212A

-

-

-

INDOOR UNITS FDQ125C FDQ200B

Replacement long-life filter

Drain pump kit

L-type piping kit (upward direction)

Sealing member of air discharge outlet

Decoration panel for air discharge

Decoration panel

Decoration panel option standard

-

-

-

-

BYBS125D(1)

EKBYBSD

Noise filter

Air discharge adapter for round duct

Fresh air intake kit (direct installation type)

Notes

(1) Decoration panel option EKBYBSD is required for direct mounting of the decoration panel of the unit.

-

-

KDAJ25K140A

-

FDQ250B FAQ71C FAQ100C

-

K-KDU572EVE

-

-

-

-

-

KEK26-1A

-

-

FHQ35C FHQ50C FHQ60C FHQ71C

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

BRC7G53

-

-

DCS302C51

DCS301B51

DST301B51

-

KRP1B54 / KRP4A52(1)

-

KRP1D93A

KRCS01-4B

EKRORO4

KJB311A

KJB212A

-

-

-

FHQ35C FHQ50C

KAFP501A56

KHFP5M35

KDU50P60

KHFP5N63

FHQ60C FHQ71C

KAFP501A80

-

-

-

-

-

-

KDDQ50A140

FHQ100C FHQ125C

FHQ100C FHQ125C

KAFP501A160

KDU50P140

KHFP5N160

FHQ140C

AHQ71C

AHQ71C AHQ100C AHQ125C

ARCWB

-

-

-

-

-

-

-

-

-

R04084124324

-

-

-

-

-

-

-

-

AHQ140C FUQ71C FUQ100C FUQ125C

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

-

BRC7C58 (6)

-

-

DCS302C51

DCS301B51

DST301B51

-

KRP4A53 (1)

-

KRP1B97

KRCS01-4

EKRORO5

KJB311A

KJB212A

-

-

-

AHQ100C

-

-

-

-

-

-

-

-

-

-

AHQ125C AHQ140C FUQ71C FUQ100C

KAFP551K160 standard

-

KDBHP49B140

KDBTP49B140

-

-

-

-

-

FUQ125C FVQ71C

FVQ71C FVQ100C FVQ125C FVQ140C

BRC1D52 / BRC1E52A (3) / BRC1E52B (4)

DCS301C51

-

BRC2C51

BRC3A61

DCS302C51

DCS301B51

DST301B51

-

KRP1B57 / KRP4A52

-

KRP4AA95

-

-

-

-

-

-

-

FVQ100C FVQ125C

KAFJ95L160

-

-

-

-

-

-

-

-

-

FVQ140C

OUTDOOR UNITS RZQG71L8V1/Y1 RZQG100L8V1/Y1 RZQG125L8V1/Y1 RZQG140LV1/Y1

Air direction adjustment grille

Central drain plug -

-

Refrigerant branch piping

For twin

For triple

For double twin

-

-

KHRQ22M20TA (KHRQ58T) ²

KHRQ127H (KHRQ58T) ²

KHRQ22M20TA (KHRQ58T)²

KRP58M51

-

Demand adapter kit

Bottom plate heater EKBPH140L7

Notes

(1) Bottom plate heater is only available for RZQG* models

(2) For combination of RZQ(S)G71-140 in combination with FCQG35-71F or FCQHG71F use the refrigerant branch piping mentioned between brackets.

(3) For RZQG71L8V1 and EKBPH140L7 it is required to use the demand adapter kit KRP58M51 in order to connect the bottom plate heater.

1

-

RZQSG71L3V1

-

RZQSG100L8V1/Y1 RZQSG125L8V1/Y1 RZQSG140LV1/Y1

-

-

KHRQ22M20TA (KHRQ58T) ²

KHRQ127H (KHRQ58T)²

KHRQ22M20TA (KHRQ58T)²

KRP58M51

-

AZQS71BV1/BY1 AZQS125BV1/BY1

-

-

-

-

-

KRP58M51

AZQS140BV1/BY1

-

RZQ200C RZQ250C

-

KWC26B280

KHRQ22M20TA

KHRQ250H7

KHRQ22M20TA (x3)

KRP58M51

Rooftop controller

PCB

EXV

Gold Fin (NA549)

Scroll compressor

Saranet Air Filter

Side flow

Convertible

Filter drier

High pressure switch

Low pressure switch

Economiser

No options available for UATYP-AY1(B)

No options available for ECONO-AY1

UATYQ-C

ECONO-AY1

89

90

Europe's New Energy Label

Labelling encourage intelligent choices

To enable consumers to compare and make purchasing decisions based on uniform labelling criteria, Europe has introduced energy labels. The previous European energy label for air conditioners, introduced in 1992, has had its effect. In 2013 Europe has introduced a

Seasonal energy label. This label allows end-users to make even better informed choices, since seasonal efficiency reflects air conditioner efficiency over an entire season.

The energy label includes multiple classifications from A+++ to D reflected in colour shadings ranging from dark green (most energy efficient) to red (least efficient). Information on the label includes not only the seasonal efficiency ratings for heating (SCOP) and cooling

(SEER), but also annual energy consumption and sound levels.

The label more in detail

Name of manufacturer and product

SEER: seasonal efficiency values in cooling

Classifications from A+++

(most energy efficient) to D (least energyefficient)

Design load for cooling

New seasonal efficiency ratings in cooling (SEER)

Annual energy consumption during a cooling season, including auxiliary modes

Sound power value for indoor unit

Sound power value for outdoor unit

Combination of indoor and outdoor unit

SCOP: seasonal efficiency values in heating

Classifications from A+++

(most energy efficient) to D (least energy efficient)

Design load for heating

New seasonal efficiency ratings in heating (SCOP)

Annual energy consumption during a heating season, including auxiliary modes

To take into account the broad range of conditions, 3 climate zones are used: cold, average and warm

Blue = colder climate (optional)

Green = average climate (compulsory)

Orange = warmer climate (optional)

Power supply

V1 = 1~, 220-240V, 50Hz

VE = 1~, 220-240V/220V, 50Hz/60Hz*

W1 = 3N~, 400V, 50Hz

* For VE power supply only 1~, 220-240V, 50Hz data is displayed in this catalogue.

Measuring conditions

Air conditioning

1) nominal cooling capacities are based on:

Indoor temperature

Outdoor temperature

Refrigerant piping length

Level difference

2) nominal heating capacities are based on:

Indoor temperature

Outdoor temperature

Refrigerant piping length

Level difference

27°CDB/19°CWB

35°CDB

7.5m

0m

20°CDB

7°CDB/6°CWB

7.5m

0m

The sound pressure level is measured via a microphone at a certain distance from the unit. It is a relative value, depending on the distance and acoustic environment (for measuring conditions: please refer to the technical databooks).

The sound power level is an absolute value indicating the “power” which a sound source generates.

For more detailed information please consult our technical databooks.

91

92

Notes

93

Design in

one

Design in

one

The present leaflet is drawn up by way of information only and does not constitute an offer binding upon Daikin Europe N.V.. Daikin Europe N.V. has compiled the content of this leaflet to the best of its knowledge. No express or implied warranty is given for the completeness, accuracy, reliability or fitness for particular purpose of its content and the products and services presented therein. Specifications are subject to change without prior notice. Daikin Europe

N.V. explicitly rejects any liability for any direct or indirect damage, in the broadest sense, arising from or related to the use and/or interpretation of this leaflet. All content is copyrighted by Daikin Europe N.V.

Daikin Europe N.V. participates in the Eurovent

Certification programme for Liquid Chilling Packages

(LCP) and Fan coil units (FCU), Check ongoing validity of certificate online: www.eurovent-certification.com or using: www.certiflash.com

Daikin products are distributed by:

FSC ECPEN14-114

Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende

95

FCQG-F / RXS-L

Round flow cassette

UNIQUE!

FCQG35-60F presence sensor floor sensor

BRYQ140A RXS-L BRC1E52A/B

(optional)

BRC7F532F

(optional)

The round flow cassette provides a more comfortable environment and offers greater savings in energy consumption to shop, office and restaurant owners

360° air discharge ensures uniform air flow and temperature distribution

Modern style decoration panel is available in 3 different variations: pure white (RAL9010) auto cleaning panel, pure white (RAL9010) standard panel with grey louvers and pure white (RAL9010) standard panel with white louvers

Daikin introduces first auto cleaning cassette to European market.

Higher efficiency and comfort thanks to daily auto cleaning of the filter.

Lower maintenance costs thanks to auto cleaning function.

Easy dust removal with vacuum cleaner without opening the unit.

The presence sensor (optional) : adjusts the temperature or switches off the unit when there is nobody in the room - ensures the air flow is directed away from any person detected in the room, when the air flow control is activated

The floor sensor (optional) detects the average floor temperature and ensures even temperature distribution between ceiling and floor. Cold feet will become history.

Individual flap control: possibility to adapt the room layout by fixing the positon of each flap individually

Fresh air intake: up to 20 %

No optional adapter needed for DIII-connection, link your unit into the wider building management system.

Heating & Cooling

Indoor unit

Cooling capacity

Heating capacity

Power input

Seasonal efficiency

(according to

EN14825)

Min./Nom./Max.

Min./Nom./Max.

Cooling

Heating

Cooling kW kW

Min./Nom./Max.

kW

Min./Nom./Max.

kW

Energy label

Pdesign kW

SEER

Annual energy consumption kWh

Nominal efficiency

(cooling at 35°/27° nominal load, heating at 7°/20° nominal load)

Dimensions

Weight

Heating

(Average climate)

Unit

Unit

Decoration panel Model

Colour

Energy label

Pdesign kW

SCOP

Annual energy consumption kWh

EER

COP

Annual energy consumption

Energy label Cooling/Heating kWh

HeightxWidthxDepth mm kg

Dimensions

Weight

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

Heating

Sound pressure level

Cooling

Heating

Piping connections

Power supply

Liquid

Gas

HeightxWidthxDepth mm kg

High/Nom./Low m³/min

High/Nom./Low m³/min

High/Nom./Low

High/Nom./Low

OD

OD

Phase / Frequency / Voltage dBA dBA dBA dBA mm mm

Hz / V

FCQG35F

1.3/3.4/4.0

1.3/4.20/5.2

0.400/0.950/1.100

0.230/1.200/1.840

3.50

6.35

193

3.32

4.90

949

3.58

3.50

475

A/B

18

12.5/10.6/8.7

12.5/10.6/8.7

9.5

FCQG50F

1.7/5.0/5.3

1.7/6.00/6.0

-/1.410/-

-/1.620/-

A++

5.00

6.48

270

A++

19

BYCQ140D7W1/BYCQ140D7W1W/BYCQ140D7GW1

Pure White (RAL 9010)/

60x950x950/950x60x950/145x950x950

5.4/5.4/10.3

12.6/10.7/8.7

12.6/10.7/8.7

49

49

31/29/27

31/29/27

4.36

4.29

1,426

3.55

3.7

705

A/A

204x840x840

6.35

12.70

1~ / 50 / 220-240

Outdoor unit

Dimensions

Weight

Unit

Unit

Fan - Air flow rate Cooling

Heating

Sound power level Cooling

HeightxWidthxDepth mm

High/Super low

High/Super low kg m³/min m³/min

Sound pressure level

Heating

Cooling

Heating

Operation range Cooling

Refrigerant

Piping connections

Heating

Type/GWP

Piping length dBA dBA

High/Low/Silent operation dBA

High/Low/Silent operation dBA

Ambient Min.~Max. °CDB

Ambient Min.~Max. °CWB

OU - IU Max.

Level difference IU - OU Max.

m m

Power supply

Current - 50Hz

Phase / Frequency / Voltage

Maximum fuse amps (MFA)

Hz / V

A

RXS35L

550x765x285

34

36.0/30.1

28.3/25.6

61

61

48/-/44

48/-/45

20

15

1~ / 50 / 220-240

RXS50L

47

50.9/48.9

45.0/43.1

48/44/-

48/45/-

-10~46

-15~18

R-410A/1,975

-

735x825x300

62

62

30

20.0

1~ / 50 / 220-230-240

FCQG60F

1.7/5.7/5.7

1.7/7.0/7.0

-/1.640/-

-/1.990/-

5.70

6.22

321

A+

4.71

4.00

1,646

3.48

3.52

820

A/B

13.6/11.2/8.7

13.6/11.2/8.7

51

51

33/31/28

33/31/28

RXS60L

48

50.2/45.0

46.3/46

49/46/-

49/46/-

(1) EER/COP according to Eurovent 2012, for use outside EU only (2) The BYCQ140D7W1W has white insulations. Be informed that formation of dirt on white insulation is visibly stronger and that it is consequently not advised to install the BYCQ140D7W1W decoration panel in environments exposed to concentrations of dirt. (3) BYCQ140D7W1: pure white standard panel with grey louvers; BYCQ140D7W1W: pure white standard panel with white louvers; BYCQ140D7GW1: pure white auto cleaning panel.

96

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
