Instructions manual

PELLET AND WOOD CHIP HEATING

Instructions manual

Top Light / Top Light M / Top Light M MBW

PZ8RL / PZ25RL / PZ32RL / PZ35RL

Innovative

CO

2

-neutral

Quality

Know-how

Efficient

Sustainable

Please read these instructions in full before operating the system.

940000100030 / EN / 60s / V2.0

Important

Content

01 General Information

02 Safety Notes

03 Return water riser

04 Minimum distance from walls

05 Technical data

06 Menu summery

07 Refilling of the pellet storage

7.1 Fuel

7.2 Pellet loading

08 Control Overview

8.1 General – Function keys

09 Main Menu of terminal board

9.1 Setting of date and time

10 Data storage menu

10.1 Enter the data saving menu

11 Operation modes

11.1 Domestic hot water tank operation mode

11.2 Automatic operation mode

11.3 Buffer operation mode

11.4 Time operation mode

11.5 Switching between operation modes

12 Pellet boiler settings

12.1 Setting of the target boiler temperature

12.2 Setting of the hysteresis

13 Domestic hot water tank loading

13.1 Setting of domestic hot water tank loading times

13.2 Setting of domestic hot water tank target / minimum temperature

13.3 Delete / activate domestic hot water tank loading times

13.4 Domestic hot water tank priority ON / OFF

13.5 Domestic hot water tank quick start

14 Pellet feeding device

14.1 Delete / activate suction times

14.2 Quick start of pellet feeding device

14.3 Automatic-Suction (FIXED VALUE – cannot be changed)

15 Heating circuits controlled by the outside temperature (max. 4 mixer circuits)

15.1 General Explanation

15.2 Main menu description for heating circuit regulation

15.3 Setting of operation mode outside temperature

15.4 Setting of MAX – Outside - Temperature

15.5 Setting of KP-room balancing (room ambiance)

15.6 Setting of heating times

15.7 Setting of the heating curve

15.8 Setting of Heating Circuit Regulator

22

22

23

23

24

24

25

26

26

26

30

30

31

32

32

27

27

28

29

16

16

18

18

18

18

19

19

20

20

21

11

11

14

15

8

9

10

10

10

7

7

5

6

16 Buffer setting

16.1 Setting of the buffer loading time

17 Maintenance – Manual working mode

18 Periodical maintenance for user

18.1 Emptying of the ash drawer / Cleaning of burner area

19 Failure codes / Remedy

20 List of parameters

21 Customer specific settings

22 Notes

37

37

41

53

55

57

33

34

36

01 General Information

Our customer service or an authorized specialist contractor must carry out assembly, installation, and initial start-up

(setting) of our pellet heating system.

Recommendation: For long burner running times, in order to reduce the start-stop emissions and to reduce maintenance costs, the boiler should be fitted with a buffer storage tank, thermosiphon buffer storage tank or combination storage tank. In practice, buffer capacities between 40 and 75 litres/kW have proven successful. Be sure to take into account the country-specific requirements regarding buffer storage tanks. The operation of the system is only permissible if it can be guaranteed that the boiler‘s nominal heat output can be reduced by 50% for a period of at least 2 hours.

Use only those fuels recommended by us - wood pellets pursuant to EN 14961-2, Class A1+ A2 (Ø 6 mm). Only in this way can low-emission, economic, and trouble-free operation of your pellet heating system be ensured. Non-compliance will result in voiding of the guarantee.

At regular intervals, perform the maintenance and cleaning procedures recommended by us in the manual for your pellet heating system. When this is done you not only ensure the functional reliability of the system and its safety systems, but also efficient, low-emission operation of the system. You achieve the best care of your pellet heating system by concluding a maintenance contract. The indicated cleaning and maintenance intervals must be unconditionally respected. Please note that, no warranty claim arises for damage that is the result of non-compliance with the maintenance instructions.

Your heating boiler is adjustable within an output range of 30% to 100% of the rated output. The units should be

operated if at all possible in the middle and upper output range (adjusted to the respective heat requirement), in order to avoid unnecessary emissions in low load operation. The ideal is the combination with a modulating room and heating regulator in order to avoid unnecessary cycles and to enable the longest possible running times.

If technical changes are undertaken independently, we assume no liability for damages that that may result thereof.

Any procedure undertaken by persons other than those authorized by us, and non-compliance with these general considerations and the safety notices described below, shall result in immediate voiding of any warranty claim as well as the guarantee.

Damaged parts and unit components must be replaced only with original replacement parts.

It is urgently recommended that this manual be kept within reach in the heating room.

The pellet heating system described in this manual has been tested in accordance with EN303-5.

The generally applicable rules of heating technology must be observed for protection against Legionella.

NOTE: When using pellet heating systems with 2 suction turbines (e.g. 100kW boiler) the daily tank is unequally emptied (complete emptying cannot be ensured). We have already recommended in the planning a division of the storage area of between 60 and 40%.

The mandatory maintenance of the system must be done by authorized technicians at least one a year but no later than when reaching 1500 hours of operation (with an output range of 80-100%).

If NO service is performed, the warranty claim or the warranty is void!

In the course of maintenance work on the pellet heating system all wear parts are replaced and billed, if necessary.

For service work to be performed, the system must be „cold“. If the system is not shut down in sufficient time and is still

“warm” when the service technician arrives, the resulting idle and waiting time will also be billed.

Foreign bodies in the fuel can result in damage to the system.

The regulations pursuant to A-Norm M 7136 (Transport and Storage Logistics) and M 7137 (Pellet Storage Requirement) must be observed.

Please note that you must observe the prescribed servicing intervals during the warranty period!

Properties that require a high degree of security for heat supply (the hotel business, process heating, etc.) are to be equipped with dual boiler systems. If this requirement is not met, we will deny any claims for consequential damage based on a faulty heating source. In a biomass heating system, it is essential to take appropriate care ( caretaker, porter, etc.) so that the stipulated maintenance tasks are carried out regularly!

5

• Datasheet on Wood Pellets pursuant to EN 14961-2, Classes A1 + A2 (Ø 6 mm)

Parameters (Unit)

Length (mm)

Fines (%, mass)

Ash content (%, mass)

Ash melting temp. (°C)

ENplus-A1

up to 40

≤ 1

2

≤ 0,7

3

≥ 1.200

1

1) Maximum 5% of the pellets may be longer than 40 mm, max. length 45 mm.

2) Particles < 3.15 mm, fines at the last loading site.

3) In a water-free state (wf)

ENplus-A2

up to 40

≤ 1

2

≤ 1,0

3

≥ 1.100

1

YMM 3x2.5 mm cable

2

; electrical connection: 230 V, 50 Hz; fusing 16 A, slow triggering.

Protection with protective multiple earthing with fault-current circuit breaker

(voltage limits pursuant to EN 50160) ATTENTION: ISO Norm 60364 must be observed!

Operational limits: Max. ambient temperature 0-45 °C; max humidity 0-95%

We assume warranty obligations in accordance with the provisions of our warrantee conditions only when original Biotech replacement parts are used. Biotech grants repair service and supply of replacement parts for at least 10 years from the date of purchase of the system!

02 Safety Notes

A heating emergency switch (all-phase multidirectional switch off) must be arranged upstream of the combustion chamber! Switch it off before carrying out the maintenance and/or service work!

The safety notes must absolutely be read before operating the system! Non-compliance with the safety notes can result in physical injury, life-threatening situations, or damage to the system!

• The pellet heating system may be operated only in technically perfect condition. Malfunctions and damage that adversely affect or are capable of adversely affecting safety, must be resolved promptly by our technical personnel.

• Assembly must be done only by our customer service or by an authorized technical contractor . The system includes rotating parts that are driven at relatively high torque (crushing hazard).

• Live voltage parts are located under the enclosure and in the junction boxes. Therefore never remove enclosure parts or never open the junction boxes!

• During running operation never open the maintenance ports of the boiler; hot flue gas and dust can escape.

The system must be switched off prior to carrying out any maintenance. Use the ON/OFF switch to switch off the system. Wait until the system is cooled down (please refer to the boiler temperature on the display). Then switch the system off using the Heating Emergency OFF Switch. Secure the switch against accidental switch-on of the system.

Before sweeping the heating tube or the chimney by the chimney cleaner, switch off the system using the ON/

OFFswitch and wait for the burn-out process (about 20 minutes). Explosion hazard due to flue gas congestion.

• Never empty flammable liquid into the combustion chamber.

• Never perform repair work yourself on our systems but rely on our technical personnel. A warning sign „Smoking and tampering with open flame and fire is prohibited“ must be posted (hazard when refilling the pellet hopper).

• A certified fire extinguisher must be provided in the heating room.

Ensure an adequate supply of fresh air.

• Secure the heating room against unauthorized access, especially by children.

• The boiler doors and the water-side connections must be inspected once a month for tightness and damage.

• The safety temperature limiter (STL) must be inspected once a year (this should be done during maintenance or service).

• Safety and monitoring devices must not be removed, bypassed or in any other way made inoperative.

• When cleaning and when removing ashes use a dust mask in order to prevent hazards to health and damages.

• When filling the fuel bunker using pump vehicles, the system must be switched off (waiting time: 20 minutes).

• When setting the non-potable water temperature above 60 ºC ensure an appropriate mixture of cold water (scalding hazard).

6

• The pellet heating unit must be set up and operated only in heating or installation spaces that have been constructed in accordance with regulations.

• A suitable vent valve must be installed on the top of the boiler.

• The heating system must be filled with heating water in accordance with VDI 2035 or A-Norm H 5195-1.

• Annual inspection of the heating water pursuant to A-Norm H 5195-1.

• Annual inspection of the safety valves by a specialist.

• Regular inspection of the expansion daily tank by a specialist.

• Regular inspection in accordance with prTRVB H 118 of the discharge device, automatic wood firing systems, loader.

• Fire prevention specifications that are compliant with the applicable regulatory provisions must be implemented!

Please note that even when the system is switched off, different functions are still operating! (The frost protection device, pumps, and mixers are moved periodically during night times in order to prevent sticking of the bearings).

In order to be certain that absolutely no current is still flowing through the system, you must disconnect your heating unit from the mains!

• The manufacturer assumes no liability for damage arising from an incorrect hook-up of the flow and return – do not confuse these connections. Establish removable and non-distorted connections. When routing pipelines ensure venting of the boiler block. For the event of repair, equip the system at the appropriate point with shut-off devices (e.g. ball valve etc.).

• Before hooking up the boiler to the heat distribution system: Flush the lines and remove residues.

• Caution: Danger of injury by safety valve blow-off! Direct blow-out water to the drainage point.

• Check the boiler for leaks prior to initial start-up. Pressure test the boiler using the pressure equivalent to the safety valve response pressure. Large pressure will damage the pressure, control, and safety devices. Carryout closure integrity tests in accordance with local regulations.

• Fill the boiler only when it is in a cold condition The flow temperature must not exceed 40°C

03 Return water riser

It must be ensured that the return temperature never drops below 55 °C. Since this is not possible without an automatic return water riser, installation of the device is compulsory.

Disregard voids the warranty.

04 Minimum distance from walls

Model

To the back [mm]

Left side to wall [mm]

Right side to wall [mm]

0 - 100 0 - 100

0 - 100 * 0 - 100 *

400 400

MBW

0 - 100

0 - 100 *

400

PZ8RL PZ25RL

* … Recommendation from at least 250 mm, otherwise increased maintenance (costs)

PZ35RL

280 280 280

0 - 100 * 0 - 100 * 0 - 100 *

400 400 400

7

System type

Nominal heat performance (kW)

Degree of efficiency at full load (%)

Degree of efficiency at part load (%)

Max. adjustable boiler temperature (C°)

Tolerable operating pressure (bar)

CE designation according to low tension guidelines

Dimensions

Width of boiler (mm)

Depth of boiler (mm)

Total depth (mm)

Height of boiler (mm)

Height of smoke tube connection (mm)

Height of flow (mm)

Height of return flow (mm)

Height of ventilation (mm)

Diameter of smoke tube connection (mm)

Total weight (kg)

Water content (ltr.)

Reservoir – automatically useable (kg)

Ash box - useable (ltr.)

Connections

Flow (inch)

Return flow (inch)

Ventilation for boiler (inch)

Boiler emptying (inch)

Heating water fow resistance

ΔT= 20 K (mbar)

ΔT= 10 K (mbar)

Exhaust gas values

Exhaust gas temperature at full load (C°)

Exhaust gas temperature at part load (C°)

Exhaust gas mass fow at full load (g/s)

Exhaust gas mass fow at part load (g/s)

Co

2

at full load (Vol%)

Co

2

at part load (Vol%)

Necessary delivery pressure (mbar/Pa)

Electric power inpute

Standby (W)

Filling - Turbine (W)

Grate cleaning (W)

Pre-flling (W)

Ignition (W)

At 100% performance (W)

Minimum distance masonry

Backward (mm)

Left to masonry (mm)

Right to masonry (mm)

Placement dimension

At least (mm)

Minimum ceiling height

At least (mm)

Volume

In operation (DB)

During suction (DB)

05 Technical data

Top Light

9,20

92,00

92,20

80

3

CE

Top Light M

Top Light M MBW

14,90

93,00

93,50

90

3

CE

PZ8RL

14,50

93,64

96,34

90

3

CE

PZ25RL

25,00

94,19

93,80

90

3

CE

PZ32RL

32,20

92,39

95,76

90

3

CE

PZ35RL

35,00

92,39

95,76

90

3

CE

600

2000

35

67

20

1600

65

75

1020

50-80

0-100

0-100

8

400

3/4

3/4

1/2

1/2

-

-

1455 1

1450 1

1450 1

1450 1

130

246

25

27

13

900

480

620 2

1400 1

1060 / 1300

685 / 650

825 2 / 680 2,7

1345 1

1415 1

1445 1

1445 1

1435 1

130

312 / 334 7

60

40 / 180

6

1

1

1/2

1/2

5

20

7

7

7 1050

650

750 3

1365 1

815

346

925

935

130

269

50

34

6

1

1

1/2

1/2

9,5

37,8

1

1

1

1

1300

650

750

455

1180

1190

335

80

67

23

1

1

1/2

1/2

32,9

3

1520

1075

1

130

131,7

1

1

1

1

1300

650

750 3

1770 1

1328

454

130

388

120

134

23

5/4

5/4

1/2

1/2

25,8

1

1424

1434

103,2

1

1

1

1328 1

454 1

1424 1

1434 1

130

388

120

134

23

1300

650

750 3

1770 1

5/4

5/4

1/2

1/2

25,8

103,2

95,00

54,00

5,3

1,8

13,1

10,5

0,02-0,10/2-10

125

79

9,0

3,0

13,5

9,95

0,02-0,10/2-10

94,42

50,07

8,0

1,9

13,311

7,755

0,02-0,10/2-10

119,26

63,90

15,0

5,5

13,648

9,262

0,02-0,10/2-10

97,01

57,54

22,0

5,8

12,777

9,362

0,02-0,10/2-10

97,01

57,54

22,0

5,8

12,777

9,362

0,02-0,10/2-10

20

1600 / 0 6

65

75

1020

50-80

0-100

0-100

8

400

800

2000

35

67 / 0

7

20

1600

65

75

1020

50-80

280

0-100

8

400

800

2000

35

67

20

1600

65

75

1020

50-80

280

0-100

8

400

800

2200

35

67

20

1600

65

75

1020

50-80

280

0-100

8

400

800

2200

35

67

800

2200

35

67

20

1600

65

75

1020

50-80

280

0-100

8

400

1) Without adjustable feet 2) Incl. Control 4) 1983 mm if positioned on top

5) Incl. Ashbox 6) Incl. Heat exchanger cleaning7) Power consumption at pellet heating system TLM (MBW)

8) Technical Data at pellet heating system Top Light M (MBW)

9) Recommendation from at least 250 mm, otherwise increased maintenance (costs)

Individual values base on the standard sample testing. These can deviate in practice.

8

06 Menu summery

Main menu page 2 Main menu page 1

9

07 Refilling of the pellet storage

7.1 Fuel

The wood pellet boiler is designed for burning wood pellets according to Ö-Norm and DIN-Plus SWISSPELLET. By using other qualities of wood pellets, the consistent functioning of the pellet boiler cannot be granted. Failures that are caused by the use of different fuels will not be covered by warranty.

7.2 Pellet loading

While filling the pellet storage or underground tank, observe strictly the following instructions:

• Switch off the pellet boiler approx. 20 minutes before starting the filling operation in order to ensure that the flame inside the pellet boiler has completely extinguished.

• After re-filling the pellet storage, restart the pellet boiler.

• Pellet feeding by worm screw:

Remove possible excessive deposit of dust around the suction zone.

(Inform your pellet supplier or technical service or qualified re-seller).

Make sure that the worm screw is not feeding an excessive quantity of wood dust during the refilling of the pellet storage.

10

08 Control Overview

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

8.1 General – Function keys

The main menu shows the various menus to which you have access.

With the cursor (white highlighted field) you can choose the menu item to perform adjustments or changes.

The functions available and selections can be operated by the function keys which are located on the the right column of the display.

The current date and time is always displayed below, on the left hand side of the screen.

The current operation mode of the pellet boiler is displayed below, on the right hand side of the display.

ATTENTION!

If no key is pressed for long time, the display turns black (screen saver).

By pressing the key the menu reappears!

11

Function keys

With the function keys you can operate the offered functions left on the screen.

ON / OFF key

Switch the pellet boiler ON/OFF using this key. Keep pushing the key (approx. 4 seconds) until the desired operation mode is displayed (for instance HEATING OFF).

Menu key

By pressing the menu key, you always go back to the previous menu. By pressing it repeatedly, you go back to the main menu.

Arrow keys

With the arrow keys, it is possible to move the cursor downwards or upwards on the display in order to select the target menu.

Clear key

Press the clear key in order to delete the entered data (without overwriting them.)

Enter key

By pressing the enter key, you enter the desired sub-menu; the cursor will appear on the menu and it will be possible to enter data or modify existing ones.

12

Fields with light emitting diodes (LED)

The LED beside the writing indicates that the system is ON.

The LED beside the writing indicates that a malfunction has occured.

Chimney sweep function

This function starts by pressing . The power of the boiler rises up to 100% (in order to read the flue gas values).

Wait until the boiler temperature is at 60 C before taking the flue gas values.

Once the boiler is hot (text „HEAT“ on the display), you can proceed and read the flue gas values. During this operation, with boiler

„HOT“, make sure that there is enough heat load on the boiler

(e.g. activate the buffer loading, open the heating circuits, .....)

13

09 Main Menu of terminal board

The main menu is composed of two pages (see below). From this menu you have access to all other sub-menus.

To switch from one page to the other, press the arrow keys until you reach the next page. To select the target menu item, press the arrow keys until you reach the desired line of the menu; and then press .

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

14

Control of screen brightness

To control the brightness of the display, press and/or

9.1 Setting of date and time

Set time as follows:

• If you are not in the main menu, press until you reach the main menu

• Press till you reach the second page of the main menu

• Press

• Press

(= clock) - the day of the week is underneath the cursor

till target day appears

• Press to reach the date

• Proceed with all other settings as described above; to store the settings and to start date and time, press

15

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

ATTENTION:

The menu items SERVICE and COMPONENT TEST are for customer service only and secured by code!

Changes in these menus can lead to malfunctions and failure of the system.

10 Data storage menu

From this menu you can re-load data which has been saved by customer service during starting-up operations (for manual temporary variations). You can only enter the menu when the pellet boiler is switched OFF.

10.1 Enter the data saving menu

• Keep pressing till you reach the main menu

• Press arrow keys till the white bar highlights the menu Maintenance – Manual

• Press (sub-menu Maintenance appears on display)

T H E P E L L E T H E A T I N G

SERVICE

F1 = PELL-SUCTION

F2 = HEAT E.CLEAN

F3 = WORM SCREW

F4 = BURNER GRATE

* C = INDUCED DRAF

E = CONFIRM

WE 24.05.06

07:22:26

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

• Press until you enter the Data Storage Menu

16

DATA STORAGE MENU

T H E P E L L E T H E A T I N G

Exhaust measure

WE 24.05.06

07:23:03

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

ON/OFF

MESSAGE

• By pressing you can download the values saved on the eprom

You will be asked to confirm if you really wish to take over the values.

• By pressing all saved values (flow temperature, heating times) will be loaded and the display switches automatically back to the main menu

Please note: It is only possible to load data!

Saving data is secured by a code and is for the use of customer service only!

17

11 Operation modes

The current operation mode is displayed with the white bar.

11.1 Domestic hot water tank operation mode

Operation mode for the preparation of domestic hot water.

The pellet boiler only starts at the pre-set loading times (see production of domestic hot water).The heating circuit is not activated, even if the temperature falls below the summer / winter switching temperature. The domestic hot water tank pump only starts when the pellet boiler temperature reaches 55°C.

11.2 Automatic operation mode

Can only be selected in combination with a heating circuit regulation controlled by the external weather compensation (outside temperature).

In automatic mode, the domestic hot water tank and the heating are activated together. If there is no heating demand from the heating circuit controlled by the outside temperature, the pellet boiler automatically switches to SUMMER

MODE (domestic hot water tank mode) and switches back automatically to WINTER MODE (automatic mode) as soon as the heating is required again.

The switch over is the result of an automatic calculation (based on mixer setting) or of the average daily temperature.

The pellet boiler switches to domestic hot water operation mode if no „+“ order arrives from the mixer in 60 minutes.

The boiler is not kept on standby temperature anymore and as soon as the mixer demands heat, the pellet boiler restarts, as long as the boiler has reached the switch on temperature set in the hysteresis.

e.g.: Boiler SET:

Hysteresis:

Switch on temperature:

70°C

15°C

55°C

11.3 Buffer operation mode

Buffer operation mode is used in combination with a buffer. Choose this operation mode if the buffer control is controlled via the pellet boiler. Make sure that the buffer probes are mounted correctly

Buffer switch-on temperature = top probe

Buffer switch-off temperature = bottom probe

The buffer pump starts at a pellet boiler temperature of 56°C.

With buffer priority „ON“, the domestic hot water tank is loaded via the buffer.

With buffer priority „OFF“, the domestic hot water tank is loaded via the pellet boiler.

If the domestic hot water tank demand is activated and the buffer is cold first, the buffer is loaded until its temperature is

5°C above the set temperature of the domestic hot water tank.

18

11.4 Time operation mode

This operation mode is mostly used when no automatic heating circuit regulation is available.

The pellet boiler only starts at preset times.The domestic hot water tank loads at preset loading times even if these are different to the programmed heating times.

If the boiler is controlled using an external input then the boiler should be set to time operation mode and the time window set to 24 hour operation e.g.: from 05:00 to 04:59

11.5 Switching between operation modes

• Press until you reach the main menu

• Press until the white bar highlights the operation mode

• Press (submenu operation mode appears on the monitor)

• Press until the white bar is on the target operation mode

Press (the operation mode is now selected and the control switches automatically back to the main menu)

19

12 Pellet boiler settings

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

LCD +

LCD -

WE 24.05.06

08:07:37

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

12.1 Setting of the target boiler temperature

• Press until you reach the main menu

• Press until the white bar highlights the menu p. boiler setting

• Press (the menu boiler setting is displayed on the display)

• Press (cursor appears on display)

• Press to highlight BOILER SET

• Press or to set the target temperature (e.g.: 75°C.)

• Press to go back to the main menu

20

12.2 Setting of the hysteresis

The hysteresis determinates how far the boiler temperature should fall after it has switched off, before it switches on again.

Bsp.: Boiler set temp.:

Hysteresis temp.:

Switch on temp. temp.:

75°C

15°C

59,9°C

The switch on temperature should not be below 55°C - see return water riser.

• Press until you reach the main menu

• Press until the menu bioler setting is highlightedthe menu bioler setting is highlighted

• Press (the menu pellet boiler setting appears on the screen)

• Press (cursor appears on display)

• Press until the cursor is on hysteresis

• With and you can set the target hysteresis (default setting of 15°C can only be modified after previous agreement with customer service)

• Press to save the menu; you get back to the main menu

21

13 Domestic hot water tank loading

It is possible to program two loading times a day. Using this menu it is also possible to delete or reset the two programmed times. In the menu you can also program the “SET” and “MINIMUM” domestic hot water tank temperature, and to switch the domestic hot water tank priority ON or OFF. Finally you can also start the quick domestic hot water tank loading if you need to prepare hot water outside of the preset boiler loading times.

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

13.1 Setting of domestic hot water tank loading times

• Press until you reach the main menu

• Press until the menu domestic hot water tank setting is highlighted domestic hot water tank setting

• Press (the menu domestic hot water tank loading appears)

• Press (cursor appears on display)

• Press until you are on the target time of the day line

• Press and to set the target time for domestic hot water tank loading

(hours and minutes need to be set extra)

• Press to go back to the main menu

22

13.2 Setting of domestic hot water tank target / minimum temperature

The DHW is only loaded within the pre-set loading times (e.g. 08:00-09:00) and if the temperature falls below the minimum set temperature

• Press until you reach the main menu

• Press until the menu domestic hot water tanik is highlighted hot water tank setting

• Press (the menu hot water tank appears)

• Press (cursor appears on display)

• Press until the cursor is on MIN

• Press and to set target temperature

• Press to go back to the main menu

13.3 Delete / activate domestic hot water tank loading times

• Press until you reach the main menu

• Press until until the menu domestic hot water tanik is highlighted

• Press (the menu hot water tank loading appears)

• Press (cursor appears on display)

• Press until you reach the loading time to be deleted

• Press the loading time is deleted; instead of time, dashes „--:--„ are displayed

• By pressing once again the domestic hot water tank will be reactivated!

• Press to go back to the main menu

23

13.4 Domestic hot water tank priority ON / OFF

• Press until you reach the main menu

• Press until the menu domestic hot water tank is highlighted

• Press (the menu hot water tank appears)

• Press (cursor appears on display)

• Press until the cursor is on PRIORITY

• Press and to switch between ON and OFF

• Press to go back to the main menu

With Priority ON, no power is provided for the heating circuit during the domestic hot water tank loading;the full boiler power is used for the preparation of domestic water.

With Priority OFF, energy is for both hot water and heating circuits during the hot water tank loading phase: the domestic hot water tank loading process takes longer.

13.5 Domestic hot water tank quick start

It is possible to manually start the DHW loading outside the preset loading times

• Press until you reach the main menu

• Press until the menu domestic hot water tank setting is highlighted

• Press (the menu hot water tank loading appeares)

• Press = START key (domestic hot water loading is activated)

• Press to go back to the main menu

24

14 Pellet feeding device

It is possible to set up to 5 daily starting times of the pellet feeding device to refill the daily pellet tank.

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

• Press until you reach the main menu

• Press until menu VACU-TRANS is highlighted

• Press (menu vacu-trans appears on display)

• Press (cursor appears on display)

• Press to reach the suction times

• Press and to set target times

• Press to go back to the main menu

Recommendation:

The time span between the suction times shall have the same intervals.

e.g. Interval for 3 suction times in 8 hours: 06:00 14:00 22:00

25

14.1 Delete / activate suction times

• Press until you reach the main menu

• Press until the menu VACU-TRANS is highlighted

• Press (menu vacu-trans appears on display)

• Press (cursor appears on display)

• Press until you reach the suction time to delete

• Press the suction time is deleted; instead of time, dashes „--:--„ appear)

• By pressing C again, the suction time will be reactivated

• Press to save the value; you get back to the main menu

14.2 Quick start of pellet feeding device

It is possibl to manually start a pellet feeding cycle outside the pre-set times

• Press until you reach the main menu

• Press until the menu VACU-TRANS is highlilghtes

• Press (menu vacu-trans appears on display)

• Press = START key (feeding cycle starts)

• Press to go back to the main menu

14.3 Automatic-Suction (FIXED VALUE – cannot be changed)

After a preset numbers of cycles of the worm screw in the daily tank, the daily pellet tank is automatically refilled irrespective of the pre-set loading times. This safety function ensures that the pellet daily tank never runs out of pellets.

At least two suction times shall be set, since with every filling process the automatic heat exchanger cleaning is activated.

The value automatic-suction is a preset variable (number of cycles) defined by

Biotech and it differs according to the type of boiler. This value can be changed after consulting with Biotech, without support of after-sales-service.

26

15

Heating circuits controlled by the outside temperature

(max. 4 mixer circuits)

15.1 General Explanation

The integrated heating regulation („climatic“) adjusts the flow water temperature according to the outside temperature and the pre-set hysteresis temperature curve.

It is possible to reduce tthe flow temperature in the night or during the day

(e.g. if nobody is at home during the day).

It is possible to set two time intervals of reduced temperature a day depending on individual customer needs.

You can determinate the value of the temperature reduction according to your personal needs.

TIME

DAY

NIGHT

Available operation modes ●Time / Day / Night

The control works according to the preset heating times and reduced temperature times

The control does not consider the set times and temperature reduction values but works according to the heating curve, without reducing the temperature (suitable setting for very slow heating systems)

The control only works according to the preset reduced temperature (if you are not at home for several days and wish however to ensure a minimum temperature)

Available operation modes ● External / Fixed / Off

EXTERNAL The control works according to the outside temperature

FIXED

OFF

It is possible to set a fixed temperature of the flow water. The control will maintain this temperature, independently from the outside temperature, day, night or time setting.

The climatic regulation is turned off

27

15.2 Main menu description for heating circuit regulation

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

• Operation mode

In this menu, you select the boiler operating mode: Day /Night / Fixed or on Time. It is also possible to set the value of the reduced temperature, the fixed temperature, the curve value for the room thermostat and the MAX temperature

(switching temperature for SUMMER / WINTER)

• Heating times

In this menu you can set the target heating times. It is also possible to view the outside temperature, the calculated temperature or, the ACTUAL temperature of the flow water and the selected operation mode.

• Heating curve

In this menu, it is possible to suit the heating curve according to your individual needs.

• Heating circuit regulator

The setting of the heating circuit regulator is for the use of Customer Service only (secured by code).

28

15.3 Setting of operation mode outside temperature

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

The integrated heating circuit regulation (climatic) regulates the flow temperature according to the outside temperature and the preset temperature curve.

• Press until you reach the main menu

• Press to highlight the heating circuit

• Press to open heating circuit menu

• Press to set the operation mode

• Press to select different settings

• Press and to set target operating mode

The following sub-menus can be changed using the procedure described above

Fixed temperature

Heating circuits OFF

Setting of reduced temperature

29

15.4 Setting of MAX – Outside - Temperature

This value determines the switching point for the automatic changeover from “automatic mode” with DHW loading to the “DHW mode” without heating.

If the displayed average daily temperature is higher than the preset Max – Outside – Temp., only the the boiler switches into DHW mode.

e.g.: Max outside 17,0°C

Daily average 17,1°C

If the average daily temperature falls under the preset MAX-Outside temperature, the boiler switches to automatic mode with DHW loading.

e.g.: Max outside 17,0°C

Daily average 16,9°C

15.5 Setting of KP-room balancing (room ambiance)

In combination with room temperature controller.

This value defines how many degrees Celsius the flow temperature is corrected if the target room temperature varies of one degree Celsius (+/-).

This values defines the flow water temperature at any variation of 1 degree Celsius in the room

30

15.6 Setting of heating times

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

LCD +

LCD -

WE 24.05.06

08:07:37

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

• Press until you reach the main menu

• Press to highlight heating circuit menu

• Press to open heating circuit menu

• Press until the heating time menu is highlighted

• Press to open the heating times menu

• Press (the cursor appears on the display)

• Press to reach the line of the target day and field of the target hour

• Press and to set the target minute

Following this procedure you can set the heating time for each day of the week.

31

15.7 Setting of the heating curve

T H E P E L L E T H E A T I N G

M A I N M E N U

1 OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

WE 24.05.06

08:07:37

LCD +

LCD -

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

The heating curve calculates the flow temperature according to the outside temperature. If you change the temperature at T-20°C ot T+20 C, the heating curve is automatically recalculated and the flow temperature chages in cold days respectively in warm days.

• press until you reach the main menu

• press until the heating circuit menu is highlighted

• press .

• press until the the heating curve menu is highlighted

• press .

• press (the cursor appears on the display)

• press and to set target flow temperature at T-20°C

• press until the white bar is on the flow water temperature T+20°C

• press key and to set the target flow temperature at T+20C

15.8 Setting of Heating Circuit Regulator

This is for the use of Customer Service only and secured by a code!

32

16 Buffer setting

Recommendation: to ensure ideal operation of the heating circuits we recommend an around the clock activation

(e.g. from 05:00 till 04:59)

It is possible to set a daily programming of two buffer loading times. You can also delete or reset these loading times.

You can set the

Buffer maximum temperature / Switch-off temperature (below)

Buffer minimum temperature / Switch-on temperature (above)

The buffer priority ON or OFF is a basic setting which depends on the hydraulic installation

(for the plumber or customer service only).

ON means: The hot water tank is loaded by the buffer.

OFF means: The hot water tank is loaded by the boiler.

33

16.1 Setting of the buffer loading time

T H E P E L L E T H E A T I N G

BUFFER SETTING

SU

MO

TU

WE

TH

FR

SA

05:00-04: 59 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

PRIORITY: ON

ON minAct OFF maxAct

58 80 80 82

WE 24.05.06

13:10:56

HEATING

79.7

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

• Press until you reach the main menu

• Press until the buffer setting menu is highlighted

• Press (menu buffer loading appears on display)

• Press (the cursor appears on the display)

• Press to move the cursor to the target line of the value to be changed

• Press and to make amendments

• Press to activate or delete, instead of the time, dashes (“--:--“) appear on the display

• Press to save the values; you get back to the main menu

34

The following sub-menus can be modified using the same procedure described above

Buffer switch-on temperature

If the temperature falls under the switch-on temperature, the buffer is loaded

Buffer switch-off temperature

When the switch-off temperature is reached, the buffer loading stops

Set buffer loading times

Activate / Delete buffer loading times

Buffer priority ON / OFF

T H E P E L L E T H E A T I N G

BUFFER SETTING

SU

MO

TU

WE

TH

FR

SA

05:00-04: 59 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

05:00-12:00 12:30-22:00

PRIORITY: ON

ON minAct OFF maxAct

58 80 80 82

WE 24.05.06

13:10:56

HEATING

79.7

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

35

17 Maintenance – Manual working mode

The display of this menu is only possible if the display shows „Heating OFF“.

This menu is for the cleaning and maintenance of the pellet boiler. From this menu it is possible to select specific components of the pellet boiler and to operate them manually. It is possible to select this menu only with the pellet boiler switched off. An asterisk “*” on the display (see induced draught) will warn you if the heating system is ON.

T H E P E L L E T H E A T I N G

SERVICE

F1 = PELL-SUCTION

F2 = HEAT E.CLEAN

F3 = WORM SCREW

F4 = BURNER GRATE

* C = INDUCED DRAF

E = CONFIRM

WE 24.05.06

07:22:26

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

Activate the following functions by pressing the successive keys:

... Starts the suction turbine

... Starts the cleaning of the heat exchanger

... By keeping it pressed, it starts the pellet metering screw;

it is necessary to refill the metering screw if it runs empty of pellets

... Opens the burner grate

... Starts the flue gas exhauster

... Confirm maintenance

36

18 Periodical maintenance for user

In order to maintain the performance of your Biotech boiler system a periodic cleaning regime is necessary.

18.1 Emptying of the ash drawer / Cleaning of burner area

Depending on the pellet boiler model / working hours / pellet quality, the ash drawer needs to be emptied once every

6-18 weeks. The ash drawer is located on the bottom left of he boiler and is closed via the ash door (fastened by two screwed rotating handles.).

Procedure

ATTENTION: Never take out hot or glowing ashes !

Switch off the heating system by means of ON / OFF key.

ATTENTION: After switchingoff the system, please let it cool down for at least 2-3 hours before you can proceed with the following maintenance operations:

ATTENTION:

After switching-off the system, please let it cool down for at least 2-3 hours

Damage caused by the non-compliance with maintenance instructions will not be covered by warranty!

M A I N M E N U

1

OPERATION MODE

2 P. BOILER SERVICE

3 D. HOT. W. TANK SETTING

4 PELLETS-FILL TIME

5 SERVICE MANUAL

6 AGGREGATE TEST

T H E P E L L E T H E A T I N G

• Await the cooling of the heating system (see heating unit temperature on the display)

Exhaust measure

LCD +

LCD -

• Call the Maintenance – annual working mode menu as follows:

• Press until you are back in main menu

WE 24.05.06

08:07:37

HEATING OFF

• By means of arrow keys

Maintenance - Manual

ON

OFF

MENU MESSAGE

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

37

• Press (maintenance menu appears on the display)

T H E P E L L E T H E A T I N G

SERVICE

F1 = PELL-SUCTION

F2 = HEAT E.CLEAN

F3 = WORM SCREW

F4 = BURNER GRATE

C = INDUCED DRAF

E = CONFIRM

WE 24.05.06

07:22:26

HEATING OFF

PLEASE NOTE!

Do not operate the system before having read these instructions thoroughly!

ON

OFF

MENU

Exhaust measure

ON/OFF

MESSAGE

• By pressing the heat exchanger cleaning will start. Let it run for approx. 5 minutes in order to permit a deep cleaning of the heat exchanger pipes. The procedure will be stopped by pressing again this key.

• Press to open the burner grate; the ashes fall directly onto the ash drawer underneath.

• In order to prevent dust escaping while opening the boiler door, start the flue gas exhaustern by means of

ATTENTION:

If the display turns black (after approx. 10 minutes), all aggregate units automatically switch off !ADVICE: If you wish to restart an aggregate unit, start it again with the correspondent key!

• Open the covering door (or remove front cover) in order to have access to the burner cleaning door

38

• Open the lower cleaning door (fastened with star grips) / wing nuts) to get to the ash chamber..

• Take out the ash drawer from the lower cleaning opening (ash chamber) and empty it.

• Open the upper cleaning door (fastened with 2 star grips) and keep the emptied Ashtray under it.

Fig.: Cleaning door

• Remove flue ash which remains around the burner (ash scraper available at Biotech or at your local distributor). Also clean the area around the pellet discharge slides (see pictures below).

39

• Remove the residual ashes with a vacuum cleaner until the burner area is completely clean

• By means of an vacuum cleaner, remove the residual ash on the ash chamber

• Put back the ash drawer into its original position

• Close both cleaning doors

• Press to confirm the cleaning operation (all aggregates switch off)

• The removed ashes may be used as fertiliser or disposed with biological waste

• Restart the heating system.

The cleaning procedures described above can be carried out in the course of the annual service by trained personnel!

40

19 Failure codes / Remedy

Failure messages can mostly be reset by switching off the pellet boiler by means of key.

Before starting the boiler it is necessary to clean the burner and to remove residual pellets to prevent any danger of deflagration.

Contact the customer service whenever you are not sure how to handle with any failure that may occures

41

Failure

Boiler service

(LED is blinking, boiler runs regularly, no error)

Cause

Bioler requires cleaning

Dark screen

Emergency switch turned OFF

Safety Temperature Limiter has released

Message No. 1

Pellets could not ignite

Pellet tank empty

Pellets does not burn

Lambda probe (too low falling off value of oxygen during ignition phase).

Suction turbine does not feed pellets

Flue gas temperature sensor or lambda probe are dirty or defect

Flue gas temperature increase is not enough see also no. 3 – no pellet feeding from daily tank

Ignition device is defect

Remedy

Clean the boiler according to instruction (burner and ash-room; see chapter periodical maintenance) Once the boiler has been cleaned enter the menu “maintenance - manual working mode” and press 2-times “E” to reset the counter to “0”“

Attention: These point does not release you from servicing your boiler regularly. If no service / maintenance is done, the warranty expires.

The maintenance of the boiler should be done in a way to avoid the upcoming of the warning: last hint to service / maintenance

Turn it ON

Let the boiler cool down to 80°C Reset the Safety Temperature Limiter and search for cause (e.g. defect pump…)

Check if there are still pellets in the daily tank

After removing the problem, refill pellet worm screw in manualmode

Take out the flue gas temperature sensor and clean it. Check exhaust gas fan temperature in

„Pellet Boiler Setting Menu“.

Should sensor be defect:

• Inform customer service

• Inform customer service

42

Failure Cause

Pellet dust percentage is too high

No more pellets in daily tank

Pellet feeding is not working

Remedy

Use recommended pellet quality

Refil

Search for the cause (the flap of the vacutrans does notclose). The flap must oscillate smoothly. Hose of return air from turbine to the feeding worm screw may be too short.

Change the pellets (PVA/PVD) Pellet dust percentage is too high

(angle of repose 70°)

Worm screw of daily tank is not full

Heating is not connected to ignition device

Too many slags on ignition pipe

(burner)

Let the worm screw run (no pellets in the burner)

Switch ON (Switch on position 2)

Clean it

Ignition pipe does not lead to the burner

Adjust it

Not enough pellets are fed into the burner during ignition phase

Condenser of worm screw motor is defect

Increase pre-filling quantity (dust percentage is too high

Replace it

• Inform customer service

Worm screw motor is defect Replace it

• Inform customer service

Message No. 3

No pellet feeding from daily tank

Feeding worm screw is blocked

Worm screw is blocked by something

(stones,…)

Empty the pellet tank daily and check if there is something blocking the worm screw and then remove it.After removing the problem, fill the worm screw in the manual working mode.

• In case you find nothing, inform the customer service

43

Failure

Message no. 4

Reference is missing

Terminal is defect

Message no. 5

Temperature control sensor of the worm screw is defect

Message no. 6

Boiler service

Cause Remedy

• Inform customer service

Terminal is defect

The temperature control sensor positioned on the tube of the worm screw is not working

Check if the pellet tank is hot or if there is smoke in the area. If yes, take extinguish actions.

• Inform the customer service

The pellet boiler is not properly insulated

Replace it and provide a minimum grounding of 1.5 mm² for the terminal.

The pellet separator (flap) must also be grounded.

Provide a proper insulation.

Safety temperature switch on worm screw switched on and did not reset.

Check if pellet daily tank is empty.

OK.

Restart the boiler

The burner is dirty; the flow gas fan is dirty or defect

Air flow sensor or cable is defect

Clean the burner.

Check if fue gas fan is blocked.

• Inform the customer service

• Inform the customer service

44

Failure Cause

The pre-set value of primary air sensor has

been > 80 over a period of 60 seconds and this

failure occured successively 3 times.

Heat exchanger cleaning defect

ATTENTION: if more than 10 Volt are needed to reach the SET air value, the worm screw on daily tank will stop.

Pellet boiler doors are leaking or open

Flue gas fan defect

Air flow blocked

Air flow probe is defect

Wire break

Air fow sensor plug loose

Air fow sensor (primary air) is dusty

Message no. 7

Burner Service

Not enough secondary air

Burner is dirty, secondary air fan is dirty or defect

The pre-set value of secondary air sensor

has been < 50% over a period of 60 secs. and this failure occured successively 3 times.

Air flow sensor or cable are defect

Fan is defect

Air flow sensor (secondary air) is dusty

Fan is blocked

Cable break

Air flow sensor plug loose

Air mass indicator

Remedy

Double check functioning of HE motor and cleaning

Seal / close them

Replace it

Remove the problem (Clean boiler resp. burner) Air fow probe is defect

Replace it

If possible repair or replace it

Remove the problem

Clean it

Clean the burner Check if secondary air fan is blocked

• Inform customer service

• Inform customer service

Replace it

Clean it

Loosen fan (test it in the diagnose)

If possible repair it or replace it

If possible repair it or replace it

Replace it

45

Failure Cause Remedy

Message no. 8

Pellet storage empty

Failure on suction device

Inductive vacu trans (the number of set suction cycles is exceeded without message)

The suction device did not feed pellets.

Pellet storage is empty

Check if the pellet suction hose is obstructed. If suction probe is used: check if obstructed. Take out the probe, inspect the suction hose and air hose. If jammed, remove pellets and put probe back in position.

Bring pellets into the suction areas.

Refll pellet storage

Increase the number Number of pre-set loading cycles is not enough

Hose (suction probe) not properly laid. No ventilation in the pellet storage.

1,5 m vertical; 0,3 m horizontal

Motor of worm screw is not working Remove the problem

Flap not properly adjusted Resolve – Opening when standstill

10 mm

Counter weight loose

Suction hose damaged

Fix it

Replace it

Return air tube must be at least 2 m longer than the pellet tube (if suction tube is less than 5 m)

Extension of return air tube

Suction hose to turbine is leaking

Foreign substance at suction point

(ex. Insul.paper)

Fix it

Remove it

Distance of pellet level sensor wrong The distance with closed flap must be 3 to max. 5 mm

Pellet level sensor wrongly wired

Pellets too long

Fix the problem

See specif. PVA / DIN + pellets

46

Failure Cause

Message no. 11

Start sensor error

Release:

Primary air sensor

The primary air sensor has not been achieved the preset value of „60“ during grate cleaning process

Heat exchanger cleaning defect

Boiler doors leaking or open

Flue gas fan fan is defect

Air flow is blocked

Luftmassensensor defekt

Remedy

Check functioning of heat exchanger motor and cleaning

Seal / close them

Replace it

Remove the cause (clean boiler or burner)

Austauschen

47

Failure

Message no. 12

Lambda probe is defect

Message no. 13

Ash tank is full

Burner grate is not closing

Cause Remedy

Lambda probe is not sending any signal

• Inform customer service

Reset the failure by means of ON / OFF KEY .

The pellet boiler works on emergency mode !

Lambda probe is not sending tension values anymore

Remove the problem

The limit value during the calibration has been exceeded (0-15)

Lambda probe is wrongly wired

(ca. + 15mV)

Seal lambda probe, calibrate it again and if necessary, replace lambda probe

Connect it accordingly to wiring diagram

+20 to +30 Volt displayed

Ash tank is full

Fuse of lambda probe is defect

Empty it

Grate rod is blocked

Ash box full

Grate cleaning motor is defect

The grate does not close

Lubricate the grate rod

(see maintenance)

Empty

Replace, check connecting wiring

(1 x neutral wire; 2 x Phase)

Check the grate rods and grate motor (it must be possible to move them by hand)

48

Failure

Ready (no failure)

External Control

Black Display

Cause Remedy

Sensor is wrongly adjusted

Sensor is not reacting

Adjust limit switch (distance to the rod min. 2 mm, max. 4 mm)

Check connection to terminal boards

No heat request Open mixer

(change temperatures)

External start bridge on main PCB is missing

Remove the problem

External control

Operation mode set incorrectly

External contact does not close

Probes of Heating Circuit

Regulation are missing or defect

150°C displayed

Pellet boiler probe is not connected or defect

Setting Domestic Hot WaterTank ,

Buffer or Automatic

External contact does not close

Safety Temperature Limiter (STL)

Boiler sensor burnt because it has been wrongly laid

No power

Provide a bridge (In 4)

Select the correct one

Check external control

Connect probes

Replace it

Choose Time operation mode

(program time window)

Check external control Return voltage of external control min. 15 Volt

Wait or reset (check pumps)

Replace and lay with insulation

Provide power supply

49

Failure

Burner creaks

Chimney is sweating

Pellet boiler is sweating

Heating circuits do not work

Cause

Fuse is defect (250mA)

Screen saver

Loose cable connection

Lamp is defect

Misaligned contrast

Temperature in central heating room above 60°C or below -10°C:

Display can fail

The boiler is on hot water tank operation mode

Setting OFF – MANUAL – FIX

Tmot wrong value

Hydraulic problem

Night temp. reduction

Day

Remedy

Replace. Check air fow sensor: replace if necessary

Press a key

Fix the problem

Replace the terminal

2 x Menu, press arrow 10 seconds upwards, then press 2 minutes long

or

Provide adequate temperature in central heating room, air the room or close the door

Burner is new (wait)

Insulate, increase the minimum power, increase the boiler temperature, it may be necessary to restore the chimney

Check return water riser at external control

Select automatic mode

Select Outside

Adjust

Contact installer

Adjust

Adjust

50

Failure

Domestic hot water tank loading does not work / is not correct

Cause Remedy

Altered heating curve

Heating circuit pump is defect or air is in the system

Mixer motor is defect or wrongly connected

Pumps run on wrong rotation speed

Mixer does not properly close

Adjust

Fix it

Fix it

Fix it

Room regulation device is not working

Loading takes place by gravity

Fix it

Connect it properly, program the values

No loading times

Dom. Hot water tank probe is defect

Install gate valve, hydraulic switch, or contact installer

Program them

Replace it

Pump is defect or air is in the system Fix it

Priority OFF Switch it ON

Operation mode incorrect Select buffer mode

51

Failure

Buffer loading does not work

Boiler power is too low

Room thermostat does not work

Wrong and unbelievable value on display

K-Power?

Cause Remedy

No loading times (SET temperature) Adjust

Buffer probe is defect (2 pcs.) Replace it

Pump is defect or air in the system

Loading takes place in gravity

Fix it

Brakes, Contact the installer

Heat exchanger cleaning is defect

Condenser (Worm Screw) is defect

Fix it

Replace it

Set value of secondary air cannot be achieved

Fix the problem

Probe wrongly connected

Temperature variation is not programmed (KP Room)

Check connection

Enter a value

Wrong compensation values have been programmed

Enter the right values

Wire break (no temperature probe)

Adjust fixed values or sensor setting on room thermostat

Check circuit

The boiler could not reach the preset boiler temperatur within a period of 12 hours.

Check the return fow increase and the boiler power

• Inform customer service

52

20 List of parameters

Menu

Operation mode

Pellet Boiler setting

D.h.water t. setting

Vacu-Trans

Operation mode

Heating times

Hheating curve

Heating regul.

Parameters

Operation mode

Set temperature

Hysteresis

Material Type

D.h.water t. priority max. temperature

Suction time 1

Suction time

Suction time 4

Automatic suction

Heat. circ. mode

Operation mode

Flow reduction

Fix value

KP-Room

Max. Outside temp.

T –20

T +20

Setting field

Default setting

Automatic mode

Time progr.

See starting times of the pellet boiler

1 – 30 K

50 – 200

See loading times of the domestic hot water tank

45 – 88°C

00:00 – 23:59

00:00 – 23:59

00:00 – 23:59

00:00 – 23:59

00:00 – 23:59

0 – 99999

Outside temperature

Heating circuit OFF

FIX

Outside temperature

Heating circuit OFF

FIX

10 – 99°C

0,0 – 30,0

0 – 30°C

10 – 90°C

10 – 60°C

Funzionamento automatico

70°C

15 K

100

OFF

60°C

08:00

20:00

--:--

--:--

--:--

Depensing on the model of the boiler

Time regul.

12 K

4,0

17°C

See heating times heating circuit 1

68°C

30°C

Only for customer service

Starting up Customized setting

53

Menu

Heating circuit 2

Operation mode

Parameters

Heating circuit mode

Operation mode

Flow reduction

Fix value

KP-room

Max. Outside temp.

Heating times

Hating curve

Heating regul.

Heating circuit 3

Operation mode

T –20

T +20

Heating circuit mode

Operation mode

Flow reduction

Fix value

KP-room

Max. Outside temp.

Heating times

Heating curve

Heating circuit regul.

Heating circuit 4

T –20

T +20

Heating circuit mode

Operation mode

Heating curve

Heating circuit regul.

Reduction

Fix value

KP-room max. outside temp.

T +20

Setting field

Outside temperature

Heating circuit OFF

FIX

Default setting

1 – 30 K

10 – 99°C

0,0 – 30,0

0 – 30°C

10 – 90°C

10 – 60°C

Outside temp.

12 K

30°C

4,0

17°C

See heating times heating circuit 1

60°C

23°C

Only for customer service

Outside temperature

Heating circuit OFF

FIX

Outside temperature

Heating circuit OFF

FIX

1 – 30 K

10 – 99°C

0,0 – 30,0

0 – 30°C

10 – 90°C

10 – 60°C

Outside temp.

12 K

30°C

4,0

17°C

See heating times heating circuit 1

45°C

20°C

Only for customer service

Outside temperature

Heating circuit OFF

FIX

Outside temperature

Heating circuit OFF

FIX

10 – 99°C

Outside temp.

12 K

30°C

0 – 30°C

10 – 90°C

10 – 60°C

17°C

See heating times heating circuit 1

45°C

20°C

Only for customer service

Starting up Customized setting

54

21 Customer specific settings

Pellet boiler times (valid only on time operation mode)

Start-up Day

Su

Mo

Tu

We

Th

Fr

Sa

Default setting

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

Domestic hot water loading times

Day

Su

Mo

Tu

We

Th

Fr

Sa

Default setting

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

Start-up

Buffer loading times (valid only on buffer operation mode)

Day

Su

Mo

Tu

We

Th

Fr

Sa

Day

Su

Mo

Tu

We

Th

Fr

Sa

Default setting

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

-- :-- - -- :--

Heating times for heating circuit 1

Default setting

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

Start-up

Start-up

Customized setting

Customized setting

Customized setting

Customized setting

55

Heating times for heating circuit 2

Day

Su

Mo

Tu

We

Th

Fr

Sa

Default setting

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

Heating times for heating circuit 3

Day

Su

Mo

Tu

We

Th

Fr

Sa

Day

Su

Mo

We

Th

Fr

Sa

Default setting

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

Heating times for heating circuit 4

Default setting

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

05:00 – 04:59

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

12 :00 – 22 :00

Start-up Customized setting

Start-up Customized setting

Start-up Customized setting

56

22 Notes

57

Subject to technical changes and errata!

58

Version: 940000100030 06/13 EN

Natural, sustainable

heating

with Biotech pellet and chipping heating systems.

Biotech Energietechnik GmbH

Mayrwiesstraße 12

5300 Hallwang, Austria

T +43 662 454072-0

F +43 662 454072-555 [email protected]

www.biotech-heizung.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
