Cisco Application Policy Infrastructure Controller Enterprise Module User Guide

Cisco Network Visibility Application on APIC-EM User Guide, Release
1.6.0.x
First Published: 2015-11-02
Last Modified: 2017-10-23
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS,
INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH
THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY,
CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB's public domain version of
the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS" WITH ALL FAULTS.
CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT
LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS
HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network
topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional
and coincidental.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com
go trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any
other company. (1721R)
© 2017
Cisco Systems, Inc. All rights reserved.
CONTENTS
Preface vii
Audience vii
Document Conventions vii
Related Documentation viii
Obtaining Documentation and Submitting a Service Request x
CHAPTER 1
New and Changed Information 1
New and Changed Information 1
CHAPTER 2
Overview 3
About the Cisco Application Policy Infrastructure Controller Enterprise Module (APIC-EM) 3
Logging into the Cisco APIC-EM 6
Cisco APIC-EM GUI 7
CHAPTER 3
Device Configuration Prerequisites 13
Required Platform Configurations 13
NETCONF Configuration 14
SNMP Trap Configuration 14
IP Device Tracking Configuration 15
Wireless LAN Controller Configuration 15
CHAPTER 4
Discovering Devices and Hosts 17
About Discovery 17
Understanding Discovery Credentials 18
Global Credentials 18
Job Specific Credentials 19
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
iii
Contents
Discovery Credentials Example 19
Discovery Credentials Rules 20
Discovery Credentials Caveats 21
Configuring Global Discovery Credentials 22
Configuring CLI Credentials 22
Configuring SNMP 23
Configuring SNMPv2c 24
Configuring SNMPv3 26
Configuring SNMP Properties 29
Enabling Device Controllability 31
Configuring the Polling Interval 32
Performing Discovery 33
Performing Discovery Using CDP 33
Performing Discovery Using an IP Address Range 38
Copying a Discovery Job 41
Stopping and Starting a Discovery Job 42
Deleting a Discovery Job 42
Understanding the Discovery Results 43
CHAPTER 5
Managing Devices and Hosts 47
Managing Your Device Inventory 47
Device Inventory Information 48
Device Inventory Tasks 54
Adding a Device Manually 55
Deleting a Device 57
Filtering Devices in the Device Inventory Window 58
Changing the Devices Layout View 59
Changing the Device Role 60
Adding or Removing a Device Tag in Device Inventory 62
Adding or Removing a Policy Tag in Device Inventory 63
Adding or Removing Location Tags 64
Adding or Changing a Location Marker 66
Deleting a Tag 67
Updating Device Credentials 68
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
iv
Contents
Resynchronizing Device Information 71
Running Commands on Devices 71
Updating a Device's Polling Interval 72
Managing Your Host Inventory 73
Filtering Hosts in the Host Inventory Window 74
CHAPTER 6
Using the Topology Map 77
About Topology 77
Topology Toolbar 78
Topology Icons 82
Displaying Device Data 83
Aggregating Devices 84
Aggregating Devices in the Topology Window 84
Disaggregating Devices in the Topology Window 86
Changing the Aggregated Devices Label 87
Configuring the Topology Structure 88
Saving a Topology Layout 90
Opening a Saved Topology Layout 91
Changing a Device's Role From the Topology Window 92
Searching for Devices and Hosts 93
Adding or Removing a Device Tag in Topology
95
Adding or Removing a Policy Tag in Topology 96
Displaying Devices with Tags 97
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
v
Contents
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
vi
Preface
Audience
This publication is intended for experienced network administrators who will configure and maintain the
Cisco Application Policy Infrastructure Controller Enterprise Module (Cisco APIC-EM). This guide is part
of a documentation set that is designed to help you install, troubleshoot, and upgrade your Cisco APIC-EM.
For a complete list of the Cisco APIC-EM documentation set, see Related Documentation, on page viii.
Note
In this guide, the Cisco Application Policy Infrastructure Controller Enterprise Module (Cisco APIC-EM) is
also referred to as the controller.
Document Conventions
This documentation uses the following conventions:
Convention
Description
^ or Ctrl
The ^ and Ctrl symbols represent the Control key.
For example, the key combination ^D or Ctrl-D
means hold down the Control key while you press
the D key. Keys are indicated in capital letters but are
not case sensitive.
string
A string is a unquoted set of characters shown in
italics. For example, when setting an SNMP
community string to public, do not use quotation
marks around the string or the string will include the
quotation marks.
Command syntax descriptions use the following conventions:
Convention
Description
bold
Bold text indicates commands and keywords that you
enter exactly as shown.
italics
Italic text indicates arguments for which you supply
values.
[x]
Square brackets enclose an optional element (keyword
or argument).
|
A vertical line indicates a choice within an optional
or required set of keywords or arguments.
[x | y]
Square brackets enclosing keywords or arguments
separated by a vertical line indicate an optional choice.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
vii
Preface
Related Documentation
Convention
Description
{x | y}
Braces enclosing keywords or arguments separated
by a vertical line indicate a required choice.
Nested sets of square brackets or braces indicate optional or required choices within optional or required
elements. For example:
Convention
Description
[x {y | z}]
Braces and a vertical line within square brackets
indicate a required choice within an optional element.
Examples use the following conventions:
Convention
Description
screen
Examples of information displayed on the screen are
set in Courier font.
bold screen
Examples of text that you must enter are set in Courier
bold font.
<>
Angle brackets enclose text that is not printed to the
screen, such as passwords.
!
An exclamation point at the beginning of a line
indicates a comment line.
[]
Square brackets enclose default responses to system
prompts.
Caution
Means reader be careful. In this situation, you might do something that could result in equipment damage or
loss of data.
Note
Means reader take note. Notes contain helpful suggestions or references to materials that may not be contained
in this manual.
Related Documentation
This section lists the Cisco APIC-EM and related documents available on Cisco.com at the following url:
http://www.cisco.com/c/en/us/support/cloud-systems-management/one-enterprise-network-controller/tsd-products-support-series-home.html
• Cisco APIC-EM Documentation:
• Cisco Application Policy Infrastructure Controller Enterprise Module Release Notes
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
viii
Preface
Preface
• Cisco APIC-EM Quick Start Guide (directly accessible from the controller's GUI)
• Cisco Application Policy Infrastructure Controller Enterprise Module Installation Guide
• Cisco Application Policy Infrastructure Controller Enterprise Module Upgrade Guide
• Cisco Application Policy Infrastructure Controller Enterprise Module Administrator Guide
• Cisco Application Policy Infrastructure Controller Enterprise Module Troubleshooting Guide
• Open Source Used In Cisco APIC-EM
• Cisco EasyQoS Application for Cisco APIC-EM
• Cisco EasyQoS Application for APIC-EM Release Notes
• Cisco EasyQoS Application for APIC-EM Supported Platforms
• Cisco EasyQoS Application for APIC-EM User Guide
• Cisco Network Visibility Application for the Cisco APIC-EM
• Cisco Network Visibility Application for APIC-EM Release Notes
• Cisco Network Visibility Application for APIC-EM Supported Platforms
• Cisco Network Visibility Application for APIC-EM User Guide
• Cisco Path Trace Application for Cisco APIC-EM
• Cisco Path Trace Application for APIC-EM Release Notes
• Cisco Path Trace Application for APIC-EM Supported Platforms
• Cisco Path Trace Application for APIC-EM User Guide
• Cisco IWAN Documentation for the Cisco APIC-EM:
• Release Notes for Cisco IWAN
• Release Notes for Cisco Intelligent Wide Area Network Application (Cisco IWAN App)
• Configuration Guide for Cisco IWAN on Cisco APIC-EM
• Software Configuration Guide for Cisco IWAN on APIC-EM
• Open Source Used in Cisco IWAN and Cisco Network Plug and Play
• Cisco Network Plug and Play Documentation for the Cisco APIC-EM:
• Release Notes for Cisco Network Plug and Play
• Solution Guide for Cisco Network Plug and Play
• Configuration Guide for Cisco Network Plug and Play on Cisco APIC-EM
• Cisco Network Plug and Play Agent Configuration Guide or Cisco Open Plug-n-Play Agent
Configuration Guide (depending on the Cisco IOS XE release)
• Mobile Application User Guide for Cisco Network Plug and Play
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
ix
Preface
Obtaining Documentation and Submitting a Service Request
• Cisco Active Advisor Documentation for the Cisco APIC-EM:
• Cisco Active Advisor for APIC-EM Release Notes
• Cisco Integrity Verification Documentation for the Cisco APIC-EM:
• Cisco Integrity Verification Application (Beta) for APIC-EM Release Notes
• Cisco Integrity Verification Application (Beta) for APIC-EM User Guide
• Cisco Remote Troubleshooter Documentation for the Cisco APIC-EM:
• Cisco Remote Troubleshooter Application for APIC-EM Release Notes
• Cisco Remote Troubleshooter Application for APIC-EM User Guide
Note
For information about developing your own application that interacts with the controller by means of the
northbound REST API, see the https://developer.cisco.com/site/apic-em/ Web site.
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information,
see the monthly What's New in Cisco Product Documentation, which also lists all new and revised Cisco
technical documentation at: http://www.cisco.com/c/en/us/td/docs/general/whatsnew/whatsnew.html.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
x
CHAPTER
1
New and Changed Information
• New and Changed Information, on page 1
New and Changed Information
The Cisco APIC-EM software release provides the following new network visibility applications (Discovery,
Inventory, Host) features and functionality:
• Support for Cisco 4221 Series Integrated Services Routers (ISR).
• Support for Cisco 1100 Series Integrated Service Routers (ISR).
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
1
New and Changed Information
New and Changed Information
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
2
CHAPTER
2
Overview
• About the Cisco Application Policy Infrastructure Controller Enterprise Module (APIC-EM), on page
3
• Logging into the Cisco APIC-EM, on page 6
• Cisco APIC-EM GUI, on page 7
About the Cisco Application Policy Infrastructure Controller
Enterprise Module (APIC-EM)
The Cisco Application Policy Infrastructure Controller - Enterprise Module (APIC-EM) is Cisco's Software
Defined Networking (SDN) Controller for Enterprise Networks (Access, Campus, WAN and Wireless).
The platform hosts multiple applications (SDN apps) that use open northbound REST APIs that drive core
network automation solutions. The platform also supports a number of south-bound protocols that enable it
to communicate with the breadth of network devices that customers already have in place, and extend SDN
benefits to both greenfield and brownfield environments.
The Cisco APIC-EM platform supports both wired and wireless enterprise networks across the Campus,
Branch and WAN infrastructures. It offers the following benefits:
• Creates an intelligent, open, programmable network with open APIs
• Saves time, resources, and costs through advanced automation
• Transforms business intent policies into a dynamic network configuration
• Provides a single point for network wide automation and control
The following table describes the features and benefits of the Cisco APIC-EM.
Table 1: Cisco APIC Enterprise Module Features and Benefits
Feature
Description
Network Information Database
The Cisco APIC-EM periodically scans the network to create a “single
source of truth” for IT. This inventory includes all network devices,
along with an abstraction for the entire enterprise network.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
3
Overview
About the Cisco Application Policy Infrastructure Controller Enterprise Module (APIC-EM)
Feature
Description
Network topology visualization
The Cisco APIC-EM automatically discovers and maps network
devices to a physical topology with detailed device-level data. The
topology of devices and links can also be presented on a geographical
map. You can use this interactive feature to troubleshoot your
network.
EasyQoS application
The EasyQoS application abstracts away the complexity of deploying
Quality of Service across a heterogeneous network. It presents users
with a workflow that allows them to think of QoS in terms of business
intent policies that are then translated by Cisco APIC-EM into a
device centric configuration.
Cisco Network Plug and Play (PnP)
application
The Cisco Network PnP solution extends across Cisco's enterprise
portfolio. It provides a highly secure, scalable, seamless, and unified
zero-touch deployment experience for customers across Cisco routers,
switches and wireless access points.
Note
Cisco Intelligent WAN (IWAN)
application
This application is not bundled with the Cisco APIC-EM
controller for this release. You need to download, install,
and enable this application to use it. For information about
these procedures, see the Cisco Application Infrastructure
Controller Enterprise Module Upgrade Guide.
The separately licensed IWAN application for APIC-EM simplifies
the provisioning of IWAN network profiles with simple business
policies. The IWAN application defines business-level preferences
by application or groups of applications in terms of the preferred path
for hybrid WAN links. Doing so improves the application experience
over any connection and saves telecom costs by leveraging cheaper
WAN links.
Note
This application is not bundled with the Cisco APIC-EM
controller for this release. You need to download, install,
and enable this application to use it. For information about
these procedures, see the Cisco Application Infrastructure
Controller Enterprise Module Upgrade Guide.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
4
Overview
About the Cisco Application Policy Infrastructure Controller Enterprise Module (APIC-EM)
Feature
Description
Cisco Active Advisor application
The Cisco Active Advisor application for APIC-EM offers
personalized life cycle management for your network devices by
keeping you up-to-date on:
• End-of-life milestones for hardware and software
• Product advisories, including Product Security Incident Response
Team (PSIRT) bulletins and field notices
• Warranty and service contract status
Note
Cisco Integrity Verification
application
This application is not bundled with the Cisco APIC-EM
controller for this release. You need to download, install,
and enable this application to use it. For information about
these procedures, see the Cisco Application Infrastructure
Controller Enterprise Module Upgrade Guide.
The Cisco Integrity Verification (IV) application provides automated
and continuous monitoring of network devices, noting any unexpected
or invalid results that may indicate compromise. The objective of the
Cisco IV application is early detection of the compromise, so as to
reduce its impact. The Cisco IV application operates within the Cisco
Application Policy Infrastructure Controller Enterprise Module
(APIC-EM) as a beta version for this release.
Note
Cisco Remote Troubleshooter
application
This application is not bundled with the Cisco APIC-EM
controller for this release. You need to download, install,
and enable this application to use it. For information about
these procedures, see the Cisco Application Infrastructure
Controller Enterprise Module Upgrade Guide.
The Cisco Remote Troubleshooter application uses the Cisco IronPort
infrastructure to create a tunnel that enables a support engineer to
connect to an APIC-EM cluster and troubleshoot issues with your
system. The app uses outbound SSH to create a secure connection to
the cluster through this tunnel.
As an administrator, you can use the Remote Troubleshooter
application to control when a support engineer has access to a
particular cluster and for how long (since a support engineer cannot
establish a secure tunnel on their own). You will receive indication
that a support engineer establishes a remote access session, and you
can end a session at any time by disabling the tunnel they are using.
Public Key Infrastructure (PKI) server The Cisco APIC-EM provides an integrated PKI service that acts as
Certificate Authority (CA) or sub-CA to automate X.509 SSL
certificate lifecycle management. Applications, such as IWAN and
PnP, use the capabilities of the embedded PKI service for automatic
SSL certificate management.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
5
Overview
Logging into the Cisco APIC-EM
Feature
Description
Path Trace application
The path trace application helps to solve network problems by
automating the inspection and interrogation of the flow taken by a
business application in the network.
High Availability (HA)
HA is provided in N+ 1 redundancy mode with full data persistence
for HA and Scale. All the nodes work in Active-Active mode for
optimal performance and load sharing.
Back Up and Restore
The Cisco APIC-EM supports complete back up and restore of the
entire database from the controller GUI.
Audit Logs
The audit log captures user and network activity for the Cisco
APIC-EM applications.
Logging into the Cisco APIC-EM
You access the Cisco APIC-EM GUI by entering its network IP address in your browser. The IP address was
configured for the Cisco APIC-EM network adapter during the initial setup using the configuration wizard.
This IP address connects to the external network.
Step 1
In your browser address bar, enter the IP address of the Cisco APIC-EM in the following format:
https://IP address
Step 2
On the launch page, enter your username and password that you configured during the deployment procedure.
The Home page of the APIC-EM controller appears. The Home page consists of the following three tabs:
• DASHBOARD
• SYSTEM HEALTH
• SYSTEM INFO
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
6
Overview
Cisco APIC-EM GUI
Figure 1: SYSTEM INFO Tab
What to do next
Click on each tab and review the data provided in the GUI.
Cisco APIC-EM GUI
First GUI Window
When you log into the Cisco APIC-EM, the GUI appears. See the following tables for descriptions of the GUI
elements.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
7
Overview
Cisco APIC-EM GUI
Table 2: Cisco APIC-EM GUI Elements
Name
Description
Navigation pane
At the left side of the window, the Navigation pane provides access to the Cisco
APIC-EM functions and additional applications, such as EasyQoS, Path Trace, IWAN,
and Network Plug and Play.
Global toolbar
At the top of the window, the Global toolbar provides access to tools, such as API
documentation, settings, and notifications. For a full explanation of the icons on the
Global toolbar, see the Global Toolbar Options table below.
Application or
Function Pane
In the main window area, the application or function pane displays the interface of the
application or function. When you click an option in the Navigation pane or from the
Global toolbar, the corresponding application or function opens in this pane.
I wish this page
would... feedback
link
At the bottom of the window, the I wish this page would... feedback link opens a
preaddressed email in your email application, where you can provide input about your
experience using the Cisco APIC-EM and suggestions for improvements.
Navigation Pane Options
The Navigation pane provides options to access the major Cisco APIC-EM features and applications.
Table 3: Navigation Pane Options
Icon
Name
Description
Hide/Unhide Navigation
Allows you to hide and unhide the Navigation pane.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
8
Overview
Cisco APIC-EM GUI
Icon
Name
Description
Home
Provides information about the APIC-EM, such as its
network status, system health, and system information.
Discovery
Allows you to configure discovery options for scanning the
devices and hosts in your network.
Device Inventory
Provides access to the inventory database, where you can
display, filter, and sort tabular information about the
discovered devices in your network.
Host Inventory
Provides access to the inventory database, where you can
display, filter, and sort tabular information about the
discovered hosts in your network.
Topology
Presents the devices and links that the Cisco APIC-EM
discovers as a physical topology map with detailed
device-level data. The topology of devices and links can
also be presented on a geographical map. You can use this
interactive feature to troubleshoot your network.
IWAN
Simplifies the provisioning of IWAN network profiles with
simple business policies. The IWAN application defines
business-level preferences by application or groups of
applications with preferred paths for hybrid WAN links.
Doing so improves the application experience over any
connection and saves telecommunication costs by leveraging
cheaper WAN links.
EasyQoS
Enables you to configure quality of service on previously
discovered Cisco network devices that support the EasyQoS
feature. Using EasyQoS, you can group devices and then
define the business relevance of applications that are used
in your network. The Cisco APIC-EM takes your QoS
selections, translates them into the proper command line
interface (CLI) commands, and deploys them onto the
selected devices.
Path Trace
Helps to solve network problems by automating the
inspection and interrogation of the flow taken by a business
application in the network.
Network Plug and Play
Provides a highly secure, scalable, seamless, and unified
zero-touch deployment experience for customers across
Cisco routers, switches and wireless access points.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
9
Overview
Cisco APIC-EM GUI
Icon
Name
Description
Active Advisor
Provides information about devices in your Cisco APIC-EM
inventory that have hardware End-of-Life warnings and
vulnerabilities that have been identified by the Cisco Product
Security Incident Response Team (PSIRT), Cisco Active
Advisor provides Software End-of-Life, Field Notice,
warranty, and service contract coverage information about
those devices.
Integrity Verification
Provides automated and continuous monitoring of network
device integrity measurements, noting any unexpected or
invalid results that may indicate compromise. The objective
of the IV application is early detection of a compromise to
reduce its impact.
Remote Troubleshooter
Utilizes the Cisco IronPort infrastructure to create a tunnel
that enables a support engineer to connect to an APIC-EM
cluster and troubleshoot issues. The application uses
outbound SSH to create a secure connection to the cluster
through this tunnel.
Wide Area Bonjour
Provides controller functions in the network, as it enables
discovery and distribution of policy-based Apple Bonjour
services independent of network boundaries.
Global Toolbar Options
The Global toolbar provides access to API information, administrative functions, system notifications.
Table 4: Global Toolbar Options
Icon
Option
Description
API
Displays the automatically generated documentation
for the northbound REST APIs.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
10
Overview
Cisco APIC-EM GUI
Icon
Option
Description
System Notifications
Opens the System Notifications dialog box, which
provides information about system notifications that
have occurred.
The icons at the top provide a total of the number of
notifications in each of the following categories:
• Minor (yellow triangle icon)
• Major (orange triangle icon)
• Critical (red octagon icon)
If notifications have occurred, they are listed below the
icons. For example, any notifications about software
updates or security certificates updates appear in this
window.
Click the Notification History link to open the
Notifications window. This window provides
information about the notification, such as its severtiy,
source, timestamp, and status.
You can perform the following actions in this window:
• Acknowledge a notification.
• Filter notifications by status or security level.
• Sort notifications by source, detail, description,
timestamp, or status.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
11
Overview
Cisco APIC-EM GUI
Icon
Option
Description
Administrative
Functions
Opens a menu of options. From this menu, you can
choose the following administrative options:
• Settings—Allows you to configure controller
settings, such user profiles, discovery credentials,
network security settings, backup and restore, and
other controller settings.
• App Management—Allows you to individually
upload and enable Cisco and third-party
applications, backup and restore the controller data,
and update the Cisco APIC-EM software.
• System Administration—Allows you to manage
and troubleshoot controller services.
Important Only advanced users should access the
System Administration console to
attempt to troubleshoot the controller
services.
• Audit Logs—Provides information to help you
monitor policy creation and application.
• About APIC-EM—Displays the installed Cisco
APIC-EM software version.
You can perform the following user functions:
• Change Password—Allows you to change your
own password.
• Sign Out—Logs you out of the Cisco APIC-EM.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
12
CHAPTER
3
Device Configuration Prerequisites
• Required Platform Configurations, on page 13
Required Platform Configurations
You need to make the following configuration changes on these platforms for Discovery to work properly.
Table 5: Required Platform Configurations
Feature
Platform
Required Configuration
Discovery (device inventory
collection)
Cisco ASR 9000 router or any other Configure NETCONF on these
Cisco device that requires
platforms.
NETCONF support for their device
For information, see NETCONF
pack.
Configuration, on page 14.
Discovery (host inventory
collection)
Devices connected to hosts using
SNMP.
Configure SNMP traps on these
devices.
For information, see SNMP Trap
Configuration, on page 14.
Devices connected to hosts using
IPDT.
Enable IPDT for these devices.
For information, see IP Device
Tracking Configuration, on page
15.
• Cisco Series 2504 WLC
Configure SNMP traps and object
identifiers on these wireless LAN
• Cisco Series 5508/5520 WLC controllers.
• Cisco Series 8510/8540 WLC For information, see Wireless LAN
Controller Configuration, on page
15.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
13
Device Configuration Prerequisites
NETCONF Configuration
NETCONF Configuration
You must enable the NETCONF protocol for the Cisco ASR 9000 router or for any other Cisco device that
requires NETCONF support for their device pack. If NETCONF is not enabled, then the controller's inventory
collection process will be incomplete for that device.
Note
Though NETCONF typically runs over SSH or on its own port, with the Cisco APIC-EM and for the Cisco
ASR 9000 router NETCONF is run over a CLI session.
For specific information about enabling NETCONF for your own Cisco device, refer to that device’s
documentation. As an example, a typical configuration sequence on a terminal to enable NETCONF on a
Cisco device is as follows:
#ssh server v2
#netconf agent tty
#!
#xml agent tty
#!
#commit
#end
#crypto key generate rsa
Note
The rsa key needs to be generated to succeed with SSH. For this reason, the crypto key generate rsa command
needs to be executed in exec mode at the end of the configuration sequence if it has not already been done.
SNMP Trap Configuration
To ensure that Cisco APIC-EM captures data about the hosts connected to your network devices, you must
set up SNMP traps or notifications. Enter the following SNMP commands to set up SNMP traps on the devices
that connect to hosts within your network:
1. snmp-server enable traps snmp linkdown linkup
2. snmp-server host IP address version 2c public
Note
For Cisco Nexus devices, enter the following SNMP commands instead of the commands listed above:
1. snmp-server enable traps snmp linkdown linkup
2. snmp-server host IP address use-vrf default
After configuring SNMP traps on the network devices, the following data is captured and made available in
the controller's GUI:
• Host data including the MAC address, IP address, and type
• Device interface status
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
14
Device Configuration Prerequisites
IP Device Tracking Configuration
IP Device Tracking Configuration
The Cisco APIC-EM discovery function uses several protocols and methods to retrieve network information,
such as hosts IP addresses, MAC addresses, and network attachment points. To use IP Device Tracking (IPDT)
for discovery, you must manually enable IPDT on the devices and interfaces for this protocol to be used to
collect host information. To enable IPDT on your devices, refer to your specific device documentation. For
general information about IPDT, see IP Device Tracking (IPDT) Overview.
Wireless LAN Controller Configuration
The Cisco APIC-EM accepts SNMP traps from several Cisco Wireless LAN Controllers (WLCs). The SNMP
traps are used to update the host inventory database. You need to configure the WLCs so that the Cisco
APIC-EM is the trap receiver, and the WLCs send the enhanced traps to the Cisco APIC-EM.
The following WLCs require SNMP traps to be enabled:
• Cisco Series 2504 Wireless LAN Controller
• Cisco Series 5508/5520 Wireless LAN Controller
• Cisco Series 8510/8540 Wireless LAN Controller
The following table specifies the SNMP traps and object identifiers that must be set on the WLCs.
Trap Name
OID
ciscoLwappDot11ClientAssocTrap
1.3.6.1.4.1.9.9.599.0.9
ciscoLwappDot11ClientDeAuthenticatedTrap
1.3.6.1.4.1.9.9.599.0.10
ciscoLwappDot11ClientMovedToRunStateNewTrap 1.3.6.1.4.1.9.9.599.0.11
ciscoLwappDot11ClientMobilityTrap
1.3.6.1.4.1.9.9.599.0.12
The following configurations must be set to enable the above SNMP traps:
• config trapflags client enhanced-802.11-associate enable
• config trapflags client enhanced-802.11-deauthenticate enable
• config trapflags client enhanced-authentication enable
• config trapflags client enhanced-802.11-stats enable
Note
When setting the SNMP traps on the WLCs, ensure you configure the IP address of the Cisco APIC-EM as
the SNMP trap destination IP address. You set the Cisco APIC-EM IP address using the configuration wizard
during the deployment process. For information about this process and the controller IP address, see the Cisco
Application Policy Infrastructure Controller Enterprise Module Deployment Guide for additional information.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
15
Device Configuration Prerequisites
Wireless LAN Controller Configuration
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
16
CHAPTER
4
Discovering Devices and Hosts
• About Discovery, on page 17
• Understanding Discovery Credentials, on page 18
• Configuring Global Discovery Credentials, on page 22
• Performing Discovery, on page 33
• Understanding the Discovery Results, on page 43
About Discovery
The process of finding network devices and hosts is known as discovery. The Discovery function scans the
devices and hosts in your network and populates the Cisco APIC-EM database with the information that it
retrieves. To discover devices and hosts, you need to provide the controller with information about the devices
so that the Discovery function can reach as many of the devices in your network as possible and gather as
much information as it can.
The Discovery function uses the following protocols and methods to retrieve device information, such as
hosts IP addresses, MAC addresses, and network attachment points:
• Cisco Discovery Protocol (CDP)
• Community-based Simple Network Management Protocol Version 2 (SNMPv2c)
• Simple Network Management Protocol version 3 (SNMPv3)
• Link Layer Discovery Protocol (LLDP)
• IP Device Tracking (IPDT) (For Discovery to collect host information, you must manually enable IPDT
on devices. After IPDT is enabled, Discovery collects host information on a best-effort basis, because
in addition to IPDT, Discovery relies on ARP entries for host information.)
• LLDP Media Endpoint Discovery (LLDP-MED) (IP phones and some servers are discovered using
LLDP-MED).
For information about the required protocol configuration for your devices, see Device Configuration
Prerequisites, on page 13.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
17
Discovering Devices and Hosts
Understanding Discovery Credentials
Understanding Discovery Credentials
The Cisco APIC-EM supports two different types of discovery credentials: global and job specific (or discovery
request-specific). Both types of discovery credentials can consist of CLI or SNMP credentials that are configured
using the controller's GUI.
Global credentials can be configured in either the Discovery window or the Discovery Credentials windows
(as described in this chapter). Job specific credentials are only configured in the Discovery window.
Note
For information about the procedure to configure global and/or job specific credentials in the Discovery
window, see the Cisco Application Policy Infrastructure Controller Enterprise Module Configuration Guide.
Both CLI and SNMP credentials are required for a successful discovery. The SNMP credentials (either global
or job specific) are used for device discovery. The CLI credentials (either global or job specific) are used for
capturing or applying device configurations for the controller's inventory.
You should enter at least one set of SNMP credentials, either SNMPv2c or SNMPv3, for your device discovery.
If you are going to configure SNMPv2 settings in your network, then SNMP Read Only (RO) community
string values should be entered in the controller to assure a successful discovery and populated inventory.
However, if an SNMP RO community string and SNMP Read Writer (RW) community string is not entered
into the controller, as a best effort, discovery will run with the default SNMP RO community string "public."
Additionally, if no SNMP RO community string is entered but a SNMP RW community string is entered,
then the SNMP RW community string will be used as SNMP RO community string.
Note
You can enter values for both SNMP versions (SNMPv2c and SNMPv3) for a single discovery. The controller
supports multiple SNMP credential configurations. Altogether, you can enter a maximum of 5 global device
credentials (SNMP or CLI) using the Discovery Credentials windows as described in this chapter, with an
additional credentials set being created in the Discovery window. Therefore, for a single discovery scan
request, you can configure a total of 6 credential sets of each type (CLI or SNMP).
Global Credentials
Global credentials are defined as preexisting credentials that are common to the devices in a network. Global
credentials (CLI and SNMP) are configured on the devices using the GUI (Discovery window or Discovery
Credentials window) and permit successful login to the devices. Global credentials are used by the Cisco
APIC-EM to authenticate and access the devices in a network that share this device credential when performing
network discoveries.
You can configure the global CLI credentials in the CLI Credentials window. You access this window by
clicking either admin or the Settings icon (gear) on the menu bar at the upper right of the screen. You then
click the Settings link from the drop-down menu and then click CLI Credentials on the Setting Navigation
pane. You can also configure global CLI credentials in the Credentials field in the Discovery window. For
information about the procedure to configure global CLI credentials in the Discovery window, see the Cisco
Application Policy Infrastructure Controller Enterprise Module Configuration Guide.
You configure the global SNMP credentials in the SNMPv2c or SNMPv3 window . You access these
windows by clicking either admin or the Settings icon (gear) on the menu bar at the upper right of the screen.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
18
Discovering Devices and Hosts
Job Specific Credentials
You then click the Settings link from the drop-down menu and then click one of the SNMP window links on
the Setting Navigation pane. You can also configure global SNMP credentials in the Credentials field in the
Discovery window. For information about the procedure to configure global SNMP credentials in the Discovery
window, see the Cisco Application Policy Infrastructure Controller Enterprise Module Configuration Guide.
Note
Multiple credentials can be configured in the CLI Credentials window.
Job Specific Credentials
Job specific credentials (request-specific credentials) are defined as preexisting device credentials for a specific
network device or set of devices that do not share the global credentials.
You configure job specific credentials in the Discovery window prior to performing a discovery that is
exclusive for that set of network devices. You access this window by clicking Discovery on the Navigation
pane.
Discovery Credentials Example
Assume a network of 200 devices that form a CDP neighborship (neighboring devices discovered using Cisco
Discovery Protocol (CDP)). In this network, 190 devices share a global credential (Credential-0) and the 10
remaining devices each have their own unique or job specific credentials (Credential 1- 5)
To properly authenticate and access the devices in this network by the Cisco APIC-EM, you perform the
following tasks:
1. Configure the CLI global credentials as Credential-0 for the controller.
You can configure the global credentials in the CLI Credentials window. You access this window, by
clicking either admin or the Settings icon (gear) on the menu bar at the upper right of the screen. You
then click the Settings link from the drop-down menu and then click CLI Credentials on the Setting
Navigation pane.
2. Configure the SNMP (v2c or v3) global credentials.
You can configure these global credentials in the two SNMP windows. You access these GUI windows
by clicking the Settings button at the top right and then clicking SNMPv2c or SNMPv3 on the Setting
Navigation pane.
3. Run a CDP discovery using one of the 190 device IP addresses (190 devices that share the global
credentials) and selecting the global credentials in the GUI. You run a CDP discovery in the Discovery
window. You access this window, by clicking Discovery on the Navigation pane.
4. Run 10 separate Range discoveries for each of the remaining 10 devices using the appropriate job specific
credentials and SNMP values (for example, Credential-1, Credential-2-5, etc.).
You configure the job specific credentials in the Discovery window. You access this window, by clicking
Discovery on the Navigation pane.
5. Review the Device Inventory table in the Device Inventory window to check the discovery results
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
19
Discovering Devices and Hosts
Discovery Credentials Rules
Discovery Credentials Rules
Discovery credentials (global and job specific) operate under the rules as described in the bullet list and table
below.
Job Specific Credential Rules
• Job specific credentials can be provided when creating a new network discovery, but only a single set
of job specific credentials is allowed per network discovery.
• Job specific credentials take precedence over any configured global credentials.
• If the job specific credentials are provided as part of a network discovery and cause an authentication
failure, then discovery is attempted a second time with the configured global credentials (if explicitly
selected in the Discovery window of the controller's GUI). If discovery fails with the global credentials
then the device discovery status will result in an authentication failure.
• When using Cisco APIC-EM APIs for a network discovery and the job specific credentials (both CLI
and SNMP) are not provided as part of the network discovery, then the global credentials (both CLI and
SNMP provided by the user) are used to authenticate devices.
Global Credential Rules
Table 6: Global Credential Rules
Global Credentials
Job Specific Credentials
Result
Not configured
Not configured
If the network discovery is run from
the controller's GUI, then the
default SNMP read community
string (public) is used for the
discovery scan. A discovery failure
will not occur in this case.
If the network discovery is run
using Cisco APIC-EM APIs, then
a discovery failure will occur since
both CLI and SNMP credentials
must be configured for a successful
device discovery using the Cisco
APIC-EM APIs.
Not configured
Configured
The specified job specific
credentials will be used for
discovery.
Configured
Not configured
All the configured global
credentials will be used.
Configured but not selected
Configured
Only the job specific credentials
will be used.
Configured and selected
Not configured
Only selected global credential will
be used.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
20
Discovering Devices and Hosts
Discovery Credentials Caveats
Global Credentials
Job Specific Credentials
Result
Configured and selected
Configured
Both specified credentials (global
and job specific) will be used for
discovery.
Configured, but wrong global
Correct job specific credentials
credential IDs are mentioned in the configured
discovery POST REST API.
Discovery fails.
Configured, but wrong global
Not configured
credential IDs are mentioned in the
discovery POST REST API.
Discovery fails.
Note
Note
This scenario is only
possible by API not
from the controller GUI.
This scenario is only
possible by API not
from the controller GUI.
Discovery Credentials Caveats
The following are caveats for the Cisco APIC-EM discovery credentials:
• If a device credential changes in a network device or devices after Cisco APIC-EM discovery is completed
for that device or devices, any subsequent polling cycles for that device or devices will fail. To correct
this situation, an administrator has following options:
• Start a new discovery scan with changed job specific credentials that matches the new device
credential.
• Edit the existing discovery by updating or modifying the global credentials, and then rerun the
discovery scan.
• If the ongoing discovery fails due to a device authentication failure (for example, the provided discovery
credential is not valid for the devices discovered by current discovery), then the administrator has following
options:
• Stop or delete the current discovery. Create one or more new network discovery jobs (either a CDP
or Range discovery type) with a job specific credential that matches the device credential.
• Create a new global credential and execute a new discovery selecting the correct global credential.
• Edit an existing global credential and re-run the discovery.
• Deleting a global credential does not affect already discovered devices. These already discovered devices
will not report an authentication failure.
• The Cisco APIC-EM provides a REST API which allows the retrieval of the list of managed network
devices in the Cisco APIC-EM inventory. The purpose of this API is to allow an external application to
synchronize its own managed device inventory with the devices that have been discovered by the Cisco
APIC-EM. For example, for Cisco IWAN scenarios, Prime Infrastructure makes use of this API in order
to populate its inventory with the IWAN devices contained in the Cisco APIC-EM inventory in order to
provide monitoring of the IWAN solution.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
21
Discovering Devices and Hosts
Configuring Global Discovery Credentials
Note
Only the username is provided in clear text. SNMP community strings and
passwords are not provided in cleartext for security reasons.
Configuring Global Discovery Credentials
Configuring CLI Credentials
CLI credentials are defined as preexisting device credentials that are common to most of the devices in a
network. CLI credentials are used by the Cisco APIC-EM to authenticate and access the devices in a network
that share this CLI credential when performing devices discoveries.
You configure the CLI global credentials in the CLI Credentials window or the Discovery window. This
procedure describes how to configure CLI global credentials in the CLI Credentials window.
Note
You can configure up to five CLI credentials.
Figure 2: CLI Credentials Window
Before you begin
You must have successfully deployed the Cisco APIC-EM and it must be operational.
You must have administrator (ROLE_ADMIN) permissions and either access to all resources (RBAC scope
set to ALL) or an RBAC scope that contains all of the resources that you want to group. For example, to create
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
22
Discovering Devices and Hosts
Configuring SNMP
a group containing a specific set of resources, you must have access to those resources (custom RBAC scope
set to all of the resources that you want to group).
For information about user permissions and RBAC scopes required to perform tasks using the Cisco APIC-EM,
see the chapter, "Managing Users".
Step 1
In the Home window, click either admin or the Settings icon (gear) at the top right corner of the screen.
Step 2
Click the Settings link from the drop-down menu.
Step 3
In the Settings navigation pane, click CLI Credentials to view the CLI Credentials window.
In the CLI Credentials window, enter the appropriate CLI global credentials for the devices within your network or
networks.
Step 4
Enter the CLI Credentials username in the Username field.
Step 5
Enter the CLI Credentials password in the Password field.
Step 6
Reenter the CLI Credentials password in the Confirm Password field to confirm the value that you just entered.
Step 7
If your network devices have been configured with an enable password, then enter the CLI Credentials for the enable
password in the Enable Password field.
Note
Both the CLI credentials password and enable password are saved in the controller in encrypted form. You
cannot view these original passwords after you enter them.
Step 8
If you entered an enable password in the Enable Password field, reenter it in the Confirm Enable Password field to
confirm the value that you just entered.
Step 9
In the CLI Credentials window, click Add to save the credentials to the Cisco APIC-EM database.
What to do next
Proceed to configure SNMP values for your network device discovery.
For a successful device discovery (with all the device information to be collected), CLI credentials (global
and/or job specific) should be configured using the controller. The global credentials for CLI and SNMP (v2c
or v3) can be configured in the Discovery Credentials windows (as described in this chapter) or the Discovery
window, and are used in addition to any job specific credentials (for CLI and SNMP) that are also configured
in the Discovery window.
Configuring SNMP
You configure SNMP for device discovery using the following Discovery Credentials windows in the Cisco
APIC-EM GUI:
• SNMPv2c
• SNMPv3
• SNMP Properties
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
23
Discovering Devices and Hosts
Configuring SNMPv2c
Note
You can also configure SNMP for device discovery in the Discovery window of the controller's GUI. For
information about the procedures to configure SNMP for device discovery in the Discovery window, see the
Cisco Application Policy Infrastructure Controller Enterprise Module Configuration Guide.
Important
You can use SNMP and the existing security features in SNMP v3 to secure communications between the
controller and the devices in your network. SNMP v3 provides both privacy (encryption) and authentication
capabilities for these communications. If possible for your network, we recommend that you use SNMPv3
with both privacy and authentication enabled.
Configuring SNMPv2c
You configure SNMPv2c for device discovery in the SNMPv2c window in the Cisco APIC-EM GUI. The
SNMP values that you configure for SNMPv2c for the controller must match the SNMPv2c values that have
been configured for your network devices.
Note
You can configure up to five read community strings and five write community strings.
Figure 3: Configuring SNMPv2c
SNMP is an application-layer protocol that provides a message format for communication between SNMP
managers and agents. SNMP provides a standardized framework and a common language used for the
monitoring and management of devices in a network. The different versions of SNMP are SNMPv1, SNMPv2,
SNMPv2c, and SNMPv3.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
24
Discovering Devices and Hosts
Configuring SNMPv2c
SNMPv2c is the community string-based administrative framework for SNMPv2. Community string is a type
of password, which is transmitted in clear text. SNMPv2c does not provide authentication or encryption
(noAuthNoPriv level of security).
Note
In addition to configuring SNMPv2c for device discovery in the controller, a "best effort" Cisco APIC-EM
discovery is in place, meaning that devices having SNMP with Read-Only (RO) community string set to
"public" will be discovered all the time irrespective of the configured SNMP Read/Write community string.
Before you begin
You must have successfully deployed the Cisco APIC-EM and it must be operational.
You must have your network's SNMP information available for this configuration procedure.
You must have administrator (ROLE_ADMIN) permissions and either access to all resources (RBAC scope
set to ALL) or an RBAC scope that contains all of the resources that you want to group. For example, to create
a group containing a specific set of resources, you must have access to those resources (custom RBAC scope
set to all of the resources that you want to group).
For information about user permissions and RBAC scopes required to perform tasks using the Cisco APIC-EM,
see the chapter, "Managing Users".
Step 1
In the Home window, click either admin or the Settings icon (gear) at the top right corner of the screen.
Step 2
Click the Settings link from the drop-down menu.
Step 3
In the Settings navigation pane, click SNMPv2c to view the SNMPv2c window.
Step 4
In the SNMPv2c window, click Read Community.
Enter your Read Community values:
• Name/Description—Description of the Read-Only (RO) community string value and/or the device or devices that
are configured with it.
• Read Community—Read-Only community string value configured on devices that you need the controller to
connect to and access. This community string value must match the community string value pre-configured on the
devices that the controller will connect to and access.
• Confirm Read Community—Reenter the Read-Only community string to confirm the value that you just entered.
Note
Step 5
If you are configuring SNMPv2c for your discovery, then configuring Read Community values is mandatory.
Click Save to save your Read Community values.
The Read Community values will appear in the table below.
Step 6
(Optional) In the SNMPv2c window, click Write Community.
Enter your Write Community values:
• Name/Description—Description of the Write community string value and/or the device or devices that are configured
with it.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
25
Discovering Devices and Hosts
Configuring SNMPv3
• Write Community—Write community string value configured on devices that you need the controller to connect
to and access. This community string value must match the community string value pre-configured on the devices
that the controller will connect to and access.
• Confirm Write Community—Reenter the Write community string to confirm the value that you just entered.
Step 7
(Optional) Click Save to save your Write Community values.
The Write Community values will appear in the table below.
What to do next
If required for your SNMP configuration, proceed to configure either SNMPv3 or SNMP Properties using
the GUI.
Configuring SNMPv3
You configure SNMPv3 for device discovery in the SNMPv3 window in the Cisco APIC-EM GUI. The
SNMP values that you configure for SNMPv3 for the controller must match the SNMPv3 values that have
been configured for your network devices. You can configure up to five SNMPv3 settings.
Figure 4: Configuring SNMPv3
SNMP is an application-layer protocol that provides a message format for communication between SNMP
managers and agents. SNMP provides a standardized framework and a common language used for the
monitoring and management of devices in a network. The different versions of SNMP are SNMPv1, SNMPv2,
SNMPv2c, and SNMPv3.
SNMPv3 provides secure access to devices by a combination of authenticating and encrypting frames over
the network. The following are supported SNMPv3 security models:
• Message integrity—Ensures that a packet has not been tampered with in-transit.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
26
Discovering Devices and Hosts
Configuring SNMPv3
• Authentication—Determines the message is from a valid source
• Encryption—Scrambles the packet contents to prevent it from being seen by unauthorized sources
SNMPv3 provides for both security models and security levels. A security model is an authentication strategy
that is set up for a user and the role in which the user resides. A security level is the permitted level of security
within a security model. A combination of a security model and a security level determines which security
mechanism is employed when handling an SNMP packet.
The security level determines if an SNMP message needs to be protected from disclosure and if the message
needs to be authenticated. The various security levels that exist within a security model are as follows:
• noAuthNoPriv—Security level that does not provide authentication or encryption
• AuthNoPriv—Security level that provides authentication but does not provide encryption
• AuthPriv—Security level that provides both authentication and encryption
The following table identifies what the combinations of security models and levels mean:
Table 7: SNMP Security Models and Levels
Model
Level
Authentication
Encryption
What Happens
v2c
noAuthNoPriv
Community String
No
Uses a community
string match for
authentication.
v3
noAuthNoPriv
User Name
No
Uses a username
match for
authentication.
v3
AuthNoPriv
Either:
No
Provides
authentication based
on the Hash-Based
Message
Authentication Code
(HMAC) Message
Digest 5 (MD5)
algorithm or the
HMAC Secure Hash
algorithm (SHA)
• HMAC-MD5
• HMAC-SHA
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
27
Discovering Devices and Hosts
Configuring SNMPv3
Model
Level
Authentication
Encryption
v3
AuthPriv
Either:
Either:
• HMAC-MD5
• HMAC-SHA
What Happens
Provides
authentication based
• CBC-DES
on the HMAC-MD5
• CBC-AES-128 or HMAC-SHA
algorithms.
Provides Data
Encryption Standard
(DES) 56-bit
encryption in
addition to
authentication based
on the Cipher Block
Chaining (CBC)
DES (DES-56)
standard or
CBC-mode AES for
encryption.
Before you begin
You must have successfully deployed the Cisco APIC-EM and it must be operational.
You must have your network's SNMP information available for this configuration procedure.
You must have administrator (ROLE_ADMIN) permissions and either access to all resources (RBAC scope
set to ALL) or an RBAC scope that contains all of the resources that you want to group. For example, to create
a group containing a specific set of resources, you must have access to those resources (custom RBAC scope
set to all of the resources that you want to group).
For information about user permissions and RBAC scopes required to perform tasks using the Cisco APIC-EM,
see the chapter, "Managing Users".
Note
With SNMPv3, passwords (or passphrases) must be at least 8 characters in length (minimum). Additionally,
for several Cisco Wireless LAN controllers, passwords (or passphrases) must be at least 12 characters in
length (minimum). Failure to ensure these required minimum character lengths for the passwords will result
in devices not being discovered, monitored, and/or managed by the controller.
Step 1
In the Home window, click either admin or the Settings icon (gear) at the top right corner of the screen.
Step 2
Click the Settings link from the drop-down menu.
Step 3
In the Settings navigation pane, click SNMPv3 to view the SNMPv3 window.
If you use SNMPv3 in your network to monitor and manage devices, then configure the SNMPv3 values for discovery
for your network.
Step 4
In the SNMPv3 window, enter a Username value and choose a Mode from the drop down menu.
The following Mode options are available:
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
28
Discovering Devices and Hosts
Configuring SNMP Properties
• AuthPriv
• AuthNoPriv
• NoAuthNoPriv
Note
Step 5
Subsequent SNMPv3 configuration options might or might not be available depending upon your selection for
this step.
If you selected AuthPriv or AuthNoPriv as a Mode option, then choose an Authentication type from the drop down
menu and enter an authentication password.
The following Authentication options are available:
• SHA—Authentication based on the Hash-Based Message Authentication Code (HMAC), Secure Hash algorithm
(SHA) algorithm
• MD5—Authentication based on the Hash-Based Message Authentication Code (HMAC), Message Digest 5 (MD5)
algorithm
Step 6
If you selected AuthPriv as a Mode option, then choose a Privacy type from the drop down menu and enter a SNMPv3
privacy password.
The SNMPv3 privacy password is used to generate the secret key used for encryption of messages exchanged with devices
that support DES or AES128 encryption.
The following Privacy type options are available:
• DES—Data Encryption Standard (DES) 56-bit encryption in addition to authentication based on the Cipher Block
Chaining (CBC) DES (DES-56) standard.
• AES128—Cipher Block Chaining (CBC) mode AES for encryption.
Step 7
Click Save to save your SNMPv3 configuration values.
The SNMPv3 configured values will appear in the table below.
What to do next
If required for your SNMP configuration, proceed to configure either SNMPv2c or SNMP Properties using
the GUI.
Configuring SNMP Properties
You configure SNMP properties for device discovery in the SNMP Properties window in the Cisco APIC-EM
GUI.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
29
Discovering Devices and Hosts
Configuring SNMP Properties
Figure 5: Configuring SNMP Properties
Before you begin
You must have successfully deployed the Cisco APIC-EM and it must be operational.
You must have your network's SNMP information available for this configuration procedure.
You must have administrator (ROLE_ADMIN) permissions and either access to all resources (RBAC scope
set to ALL) or an RBAC scope that contains all of the resources that you want to group. For example, to create
a group containing a specific set of resources, you must have access to those resources (custom RBAC scope
set to all of the resources that you want to group).
For information about user permissions and RBAC scopes required to perform tasks using the Cisco APIC-EM,
see the chapter, "Managing Users".
Step 1
In the Home window, click either admin or the Settings icon (gear) at the top right corner of the screen.
Step 2
Click the Settings link from the drop-down menu.
Step 3
In the Settings navigation pane, click SNMP Properties to view the SNMP Properties window.
Configure the SNMP property settings for discovery in your network.
Step 4
In the SNMP Properties window, enter a value in the Retries field.
The value entered in this field is the number of attempts the controller attempts to use SNMP to communicate with your
network devices.
Step 5
In the SNMP Properties window, enter a value in the Timeout field.
The value entered in this field is the length of time in seconds the controller attempts to use SNMP to communicate with
your network devices.
Step 6
Click Apply to save your SNMP configuration values.
You can also click Revert to Defaults to revert to the SNMP property default values. The following are the SNMP
property default values:
• Retries—3
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
30
Discovering Devices and Hosts
Enabling Device Controllability
• Timeout—5
What to do next
If required for your SNMP configuration, proceed to configure either SNMPv2c or SNMPv3 using the GUI.
Enabling Device Controllability
You can enable device controllability in the Device Controllability window of the Cisco APIC-EM GUI.
When you enable device controllability, the controller performs two actions during a discovery:
• The controller automatically configures (applies) the SNMP credentials that you entered using the
controller's GUI on any network devices without SNMP credentials (SNMPv2c and/or SNMPv3).
• The controller automatically enables IP device tracking (IPDT) on any network devices where it is
supported.
Note
If you want to discover hosts through a trunk interface, you must manually enable IPDT on the trunk interface.
IPDT is enabled only on devices that are identified as Access role in Device Inventory window during the
initial inventory collection. The device does not need to be in a Managed state to have IPDT enabled. The
IPDT configuration is applied to devices as long as Device Inventory has the device's software version, role,
and so on.
Note
The device controllability functionality depends upon whether the CLI credentials provided by the user permits
the controller to log into the device in enable mode (privilege level 15 for Cisco IOS devices).
Figure 6: Enabling Device Controllability
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
31
Discovering Devices and Hosts
Configuring the Polling Interval
Before you begin
You must have successfully deployed the Cisco APIC-EM and it must be operational.
You must have administrator (ROLE_ADMIN) permissions and either access to all resources (RBAC scope
set to ALL) or an RBAC scope that contains all of the resources that you want to group. For example, to create
a group containing a specific set of resources, you must have access to those resources (custom RBAC scope
set to all of the resources that you want to group).
For information about user permissions and RBAC scopes required to perform tasks using the Cisco APIC-EM,
see the chapter, "Managing Users".
Step 1
In the Home window, click either admin or the Settings icon (gear) at the top right corner of the screen.
Step 2
Click the Settings link from the drop-down menu.
Step 3
In the Settings navigation pane, click Device Controllability to view the Device Controllability window.
Step 4
(Optional) Click Yes for SNMP Autoconfig to automatically to enable this feature.
Clicking Yes for SNMP Autoconfig automatically applies the SNMP credentials you configured using the controller's
GUI to any devices in your network without an SNMP configuration.
Step 5
(Optional) Click Yes for IPDT Autoconfig to enable this feature.
Clicking Yes for IPDT Autoconfig automatically enables IP device tracking (IPDT) on any devices in your network
where it is supported but not enabled.
Step 6
Click Save to save your configuration.
What to do next
If you have not already done so, configure SNMP in either the Discovery window or the appropriate CLI
Credentials window for SNMP in Settings.
Configuring the Polling Interval
You can configure the polling interval for inventory data collection for devices managed by Cisco APIC-EM.
This polling interval configuration will be used for all managed devices, unless the polling interval of a device
is updated specifically in the Inventory page.
You configure the polling interval in the Polling Interval Settings window of the Cisco APIC-EM GUI.
Note
The polling interval value that you configure is a global value used for performing periodic inventory data
collection, it is not used for discovering the device.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
32
Discovering Devices and Hosts
Performing Discovery
Figure 7: Polling Interval Window
Before you begin
You must have successfully deployed the Cisco APIC-EM and it must be operational.
You must have administrator (ROLE_ADMIN) permissions and either access to all resources (RBAC scope
set to ALL) or an RBAC scope that contains all of the resources that you want to group. For example, to create
a group containing a specific set of resources, you must have access to those resources (custom RBAC scope
set to all of the resources that you want to group).
For information about user permissions and RBAC scopes required to perform tasks using the Cisco APIC-EM,
see the chapter, "Managing Users".
Step 1
In the Home window, click either admin or the Settings icon (gear) at the top right corner of the screen.
Step 2
Click the Settings link from the drop-down menu.
Step 3
In the Settings navigation pane, click Polling Interval to view the Polling Interval window.
Step 4
Enter a polling interval value in minutes in the Polling Interval field.
The default polling interval is 25 minutes for device discovery by the controller.
Step 5
Click Save to save your polling interval configuration.
Performing Discovery
Performing Discovery Using CDP
You can discover devices and hosts using CDP.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
33
Discovering Devices and Hosts
Performing Discovery Using CDP
Figure 8: Discovery Using CDP
Figure 9: Discovery Using CDP
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
34
Discovering Devices and Hosts
Performing Discovery Using CDP
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
CDP must be enabled on the devices in order for them to be discovered.
Note
CDP is required for the hostname column to be populated.
Your devices must have the required device configurations, as described in Device Configuration Prerequisites,
on page 13.
Step 1
From the Navigation pane, click Discovery.
Step 2
From the Discovery window, click + New Discovery.
The New Discovery pane appears.
Step 3
In the Discovery Name field, enter a unique name for the discovery job.
Step 4
In the IP Ranges area, configure the following settings:
a) In the Type field, choose CDP.
b) In the IP Address field, enter a seed IP address for the Cisco APIC-EM to use to start the discovery scan.
c) (Optional) In the Subnet Filter field, enter the IP address or subnet and click + the plus sign..
You can enter the address as an individual IP address (x.x.x.x) or as a classless inter-domain routing (CIDR) address
(x.x.x.x/y) where x.x.x.x refers to the IP address and y refers to the subnet mask. The subnet mask can be a value from
0 to 32.
Repeat this step to exclude multiple subnets from the discovery job.
d) (Optional) In the CDP Level field, enter the number of hops from the seed device that you want to scan.
Valid values are from 1 to 16. The default value is 16. For example, CDP level 3 means that CDP will scan up to
three hops from the seed device.
Step 5
Open the Credentials area and configure the credentials that you want to use for the discovery job.
You can configure credentials to be used for the current discovery job, or you can check the Save as global settings
checkbox to save the credentials for future discovery jobs.
a) Make sure that any global credentials that you want to use are checked. If you do not want to use a credential, remove
it by clicking the check mark.
b) To add additional credentials, click + Add Credentials, complete the fields in the following tables for the credentials
that you want to use, and click Add.
With the SNMP Autoconfig option enabled under Settings > Device Controllability, Cisco APIC-EM configures
devices that do not have SNMP credentials with the SNMP credentials set in Global Settings or in the specific
discovery job, whichever one takes priority.
Discovery requires the correct SNMP Read Only (RO) community string. If an SNMP RO community string is not
provided, as a best effort, discovery uses the default SNMP RO community string, "public."
Note
CLI credentials are not required to discover hosts; hosts are discovered through the devices that they are
connected to.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
35
Discovering Devices and Hosts
Performing Discovery Using CDP
Table 8: CLI Credentials
Field
Description
Username
Username that is used to log into the command line interface
(CLI) of the devices in your network.
Password
Password that is used to log into the CLI of the devices in
your network.
Confirm Password
For security reasons, you must enter the password again as
confirmation.
Passwords are encrypted for security reasons and are not
displayed in the configuration.
Password used to move to a higher privilege level in the
CLI.
Enable Password
Confirm Enable Password
For security reasons, you must enter the enable password
again as confirmation.
Passwords are encrypted for security reasons and are not
displayed in the configuration.
Table 9: SNMP v2c Credentials
Field
Description
Read
SNMP read-only (RO) community string configuration, which comprises the following fields:
• Name/Description—Name or description of the SNMP v2c settings that you are adding.
• Read Community and Confirm Read Community—Read-only community string password
used only to view SNMP information on the device.
Write
Note
Passwords are encrypted for security reasons and are not displayed in the configuration.
Note
To enable discovery on the network devices, configure the network device's IP host
address as the client address.
SNMP read-write (RW) community string configuration, which comprises the following fields:
• Name/Description—Name or description of the SNMP v2c settings that you are adding.
• Write Community and Confirm Write Community—Read/Write community string
password used to view and make changes to SNMP information on the device.
Note
Passwords are encrypted for security reasons and are not displayed in the configuration.
Note
To enable discovery on the network devices, configure the network device's host IP
address as the client IP address.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
36
Discovering Devices and Hosts
Performing Discovery Using CDP
Table 10: SNMP v3 Credentials
Field
Description
Username
Username associated with the SNMPv3 settings.
Mode
Specifies the security level that an SNMP message requires and whether the message needs to
be authenticated. Choose one of the following modes:
• noAuthNoPriv—Security level that does not provide authentication or encryption
• AuthNoPriv—Security level that provides authentication but does not provide encryption
• AuthPriv—Security level that provides both authentication and encryption
Auth Password
SNMPv3 password used for gaining access to information from devices that use SNMPv3.
Note
Auth Type
Passwords are encrypted for security reasons and are not displayed in the configuration.
Specifies the authentication type to be used.
• SHA—Authentication based on the Hash-Based Message Authentication Code (HMAC),
Secure Hash algorithm (SHA) algorithm
• MD5—Authentication based on the Hash-Based Message Authentication Code (HMAC),
Message Digest 5 (MD5) algorithm
• None—No authentication
Privacy Password
SNMPv3 privacy password is used to generate the secret key used for encryption of messages
exchanged with devices that support DES or AES128 encryption.
Note
Privacy Type
Passwords are encrypted for security reasons and are not displayed in the configuration.
Specifies the privacy type:
• DES—Data Encryption Standard (DES) 56-bit encryption in addition to authentication
based on the Cipher Block Chaining (CBC) DES (DES-56) standard.
• AES128—Cipher Block Chaining (CBC) mode AES for encryption.
• None—No privacy
Table 11: SNMP Properties
Field
Description
Retries
Number of attempts to connect to the device. Valid values are from 0 to 4 attempts.
Timeout (in Seconds) Number of seconds the controller waits when trying to establish a connection with a device
before timing out. Valid values are from 5 to 120 seconds in intervals of 5 seconds.
Step 6
(Optional) To configure the protocols to be used to connect with devices, open the Advanced area and do the following:
a) Click the protocols that you want to use. A green checkmark indicates that the protocol is selected.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
37
Discovering Devices and Hosts
Performing Discovery Using an IP Address Range
Valid protocols are SSH (default) and Telnet.
b) Drag and drop the protocols in the order that you want them to be used.
Step 7
Click Start Discovery.
The Discoveries window displays the results of your scan.
The Discovery Details pane shows the status (active or inactive) and the discovery configuration. The Discovery Devices
pane displays the host names, IP addresses, and status of the discovered devices for the selected discovery.
Performing Discovery Using an IP Address Range
You can discover devices using an IP address range.
Figure 10: Discovery Using IP Address Range
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Your devices must have the required device configurations, as described in Device Configuration Prerequisites,
on page 13.
Step 1
From the Navigation pane, click Discovery.
Step 2
From the Discovery window, click + New Discovery.
The New Discovery pane appears.
Step 3
In the Discovery Name field, enter a unique name for the discovery job.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
38
Discovering Devices and Hosts
Performing Discovery Using an IP Address Range
Step 4
If the Discovery Details pane does not appear, click Add New.
Step 5
In the Discovery Name field, enter a unique name for this discovery.
Step 6
In the IP Ranges area, do the following:
a) From the Discovery Type field, choose Range for the discovery scan type.
b) In the IP Address field, enter the beginning and ending IP addresses (IP range) for the devices being discovered and
click + (the plus sign).
You can enter a single IP address range or multiple IP addresses for the discovery scan.
c) Repeat Step b to enter additional IP address ranges.
Step 7
Open the Credentials area and configure the credentials that you want to use for the discovery job.
You can configure credentials to be used for the current discovery job, or you can check the Save as global settings
checkbox to save the credentials for future discovery jobs.
a) Make sure that any global credentials that you want to use are checked. If you do not want to use a credential, remove
it by clicking the check mark.
b) To add additional credentials, click + Add Credentials, complete the fields in the following tables for the credentials
that you want to use, and click Save.
With the SNMP Autoconfig option enabled under Settings > Device Controllability, Cisco APIC-EM configures
devices that do not have SNMP credentials with the SNMP credentials set in Global Settings or in the specific
discovery job, whichever one takes priority.
Discovery requires the correct SNMP Read Only (RO) community string. If an SNMP RO community string is not
provided, as a best effort, discovery uses the default SNMP RO community string, "public."
Note
CLI credentials are not required to discover hosts; hosts are discovered through the devices that they are
connected to.
Table 12: CLI Credentials
Field
Description
Username
Username that is used to log into the command line interface
(CLI) of the devices in your network.
Password
Password that is used to log into the CLI of the devices in
your network.
Confirm Password
For security reasons, you must enter the password again as
confirmation.
Passwords are encrypted for security reasons and are not
displayed in the configuration.
Enable Password
Confirm Enable Password
Password used to move to a higher privilege level in the
CLI.
For security reasons, you must enter the enable password
again as confirmation.
Passwords are encrypted for security reasons and are not
displayed in the configuration.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
39
Discovering Devices and Hosts
Performing Discovery Using an IP Address Range
Table 13: SNMP v2c Credentials
Field
Description
Read
SNMP read-only (RO) community string configuration, which comprises the following fields:
• Name/Description—Name or description of the SNMP v2c settings that you are adding.
• Read Community and Confirm Read Community—Read-only community string used
only to view SNMP information on the device.
Note
Passwords are encrypted for security reasons and are not displayed in the configuration.
Note
To enable discovery on the network devices, configure the network device's IP host
address as the client address.
SNMP read-write (RW) community string configuration, which comprises the following fields:
Write
• Name/Description—Name or description of the SNMP v2c settings that you are adding.
• Write Community and Confirm Write Community—Read/Write community string used
to view and make changes to SNMP information on the device.
Note
Passwords are encrypted for security reasons and are not displayed in the configuration.
Note
To enable discovery on the network devices, configure the network device's IP host
address as the client address.
Table 14: SNMP v3 Credentials
Field
Description
Username
Username associated with the SNMPv3 settings.
Mode
Specifies the security level that an SNMP message requires and whether the message needs to
be authenticated. Choose one of the following modes:
• noAuthNoPriv—Security level that does not provide authentication or encryption
• AuthNoPriv—Security level that provides authentication but does not provide encryption
• AuthPriv—Security level that provides both authentication and encryption
Auth Password
SNMPv3 password used for gaining access to information from devices that use SNMPv3.
Auth Type
Specifies the authentication type to be used.
• SHA—Authentication based on the Hash-Based Message Authentication Code (HMAC),
Secure Hash algorithm (SHA) algorithm
• MD5—Authentication based on the Hash-Based Message Authentication Code (HMAC),
Message Digest 5 (MD5) algorithm
• None—No authentication
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
40
Discovering Devices and Hosts
Copying a Discovery Job
Field
Description
Privacy Password
SNMPv3 privacy password is used to generate the secret key used for encryption of messages
exchanged with devices that support DES or AES128 encryption.
Privacy Type
Specifies the privacy type:
• DES—Data Encryption Standard (DES) 56-bit encryption in addition to authentication
based on the Cipher Block Chaining (CBC) DES (DES-56) standard.
• AES128—Cipher Block Chaining (CBC) mode AES for encryption.
• None—No privacy
Table 15: SNMP Properties
Field
Description
Retries
Number of attempts to connect to the device. Valid values are from 0 to 4 attempts.
Timeout (in Seconds) Number of seconds the controller waits when trying to establish a connection with a device
before timing out. Valid values are from 5 to 120 seconds in intervals of 5 seconds.
Step 8
Click Start Discovery.
The Discoveries window displays the results of your scan.
The Discovery Details pane shows the status (active or inactive) and the discovery configuration. The Discovery Devices
pane displays the host names, IP addresses, and status of the discovered devices for the selected discovery.
Step 9
(Optional) To configure the protocols to be used to connect with devices, open the Advanced area and do the following:
a) Click the protocols that you want to use. A green checkmark indicates that the protocol is selected.
Valid protocols are SSH (default) and Telnet.
b) Drag and drop the protocols in the order that you want them to be used.
Copying a Discovery Job
You can copy a discovery job and retain all of the information defined for the job, except the SNMP and CLI
credentials. The SNMP and CLI credentials are included in the copy only if you used global credentials (saved
in Settings) for the original job. If you defined specific (one-time only) SNMP and CLI credentials for the
original job, the credentials are not copied.
Before you begin
You have created at least one discovery scan.
Step 1
From the Navigation pane, click Discovery.
Step 2
From the Discoveries pane, select the discovery job.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
41
Discovering Devices and Hosts
Stopping and Starting a Discovery Job
Step 3
From the Discovery Details pane, click Copy.
The discovery job is copied, and the new job is named Copy of Discovery_Job.
Step 4
(Optional) Change the name of the discovery job.
Step 5
Define or update the SNMP and CLI credentials and any other parameters for the discovery job.
Stopping and Starting a Discovery Job
You can stop a discovery job that is in progress, and restart it.
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Step 1
From the Navigation pane, click Discovery.
Step 2
To stop an active discovery job, do the following:
a) From the Discoveries pane, select the discovery job.
b) From the Discovery Details pane, click Stop.
c) Click OK to confirm that you want to stop the discovery job.
Step 3
To restart an inactive discovery, do the following:
a) From the Discoveries pane, select the discovery job.
b) From the Discovery Details pane, click Start.
Deleting a Discovery Job
You can delete a discovery job whether it is active or inactive.
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Step 1
From the Navigation pane, click Discovery.
Step 2
From the Discoveries pane, select the discovery job that you want to delete.
Step 3
From the Discovery Details pane, click Delete.
Step 4
Click OK to confirm that you want to delete the discovery.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
42
Discovering Devices and Hosts
Understanding the Discovery Results
Understanding the Discovery Results
The Discovery Results pane provides information about the selected scan.
To access the Discovery Results pane, do the following:
1. From the Navigation pane, click Discovery.
2. From the Discoveries pane, select the discovery job that you want to display.
The Discovery Results pane appears. See the following figures and table for information.
Figure 11: Discovery Results Window—List
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
43
Discovering Devices and Hosts
Understanding the Discovery Results
Figure 12: Discovery Results Window—Chart
Table 16: Discovery Pane
Name
Description
Discovery Identification Displays the following information:
and Action Area
• Name of the discovery job.
• Status of the discovery job.
• Number of devices discovered.
From this area, you can delete, clone, edit, or start a discovery job.
Discovery Details area
Open this area to display detailed information about the parameters that were used
to perform the discovery, including the CDP level (if used), protocol order, retry
count, timeout value, IP address (seed) or range of IP addresses used, and IP
address filter list.
Credentials area
Open this area to display the credentials used in the discovery job and identifies
them as either global or job-specific.
Last Runs area
Open this area to display a table showing information about each iteration of the
discovery job, including the job number, its status, an option to view the devices
discovered, and the duration of the job. Clicking the View link in the Devices
column opens the Devices pane.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
44
Discovering Devices and Hosts
Understanding the Discovery Results
Name
Description
Devices pane
(Shown when you open the Last Runs area and click the View link in the Devices
column.)
The devices pane displays the results of the device discovery in two forms:
• List—For each device, provides the following information:
• IP address—IP addresses of the devices that Cisco APIC-EM discovered
or attempted to discover.
• Device name—Name of the device, if available.
• Status—Status of the discovery for the device. Possible states are
success, unreachable, failure, not tried, or unavailable.
• Internet Control Message Protocol (ICMP)—Status of the ICMP for
the device.
• SNMP—Status of theCisco APIC-EM's use of the SNMP settings to
gather SNMP information from the device.
• CLI—Status of theCisco APIC-EM's use of the CLI username and
passwords to gather information from the device.
• Chart—Displays a circle graph showing the proportional representation of
successful versus failed discovered devices.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
45
Discovering Devices and Hosts
Understanding the Discovery Results
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
46
CHAPTER
5
Managing Devices and Hosts
• Managing Your Device Inventory, on page 47
• Managing Your Host Inventory, on page 73
Managing Your Device Inventory
The Device Inventory window displays the results of the discovery scan. To access the Discovery window,
from the Navigation pane, click Device Inventory.
Figure 13: Device Inventory Window
Note
The information that is displayed depends on the Layout that you selected.
After the initial discovery, network devices are polled every 30 minutes. Polling occurs for each device, link,
host, and interface. Only devices that have been active for less than a day are displayed. This prevents any
stale device data from being displayed. On average, polling 500 devices takes approximately 20 minutes.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
47
Managing Devices and Hosts
Device Inventory Information
For information about the actions that you can perform from the Device Inventory window, see Device
Inventory Tasks, on page 54.
The following table describes the main elements in the Device Inventory table.
Window Element
Description
Device Selection check Allows you to select devices to perform tasks.
boxes
When you select a device, the action buttons appear above the Device Inventory
table. For information about these buttons and the actions that you can perform
with them, see Device Inventory Tasks, on page 54.
Filters
Allows you to refine the list of devices that are displayed in the table by name,
location tag, and IP address.
To remove filters, click Clear Filters.
Layout
Allows you to choose from three predefined layouts or a customized layout:
• Status—Layout shows the device name, IP address, state of the device, how
long it has been up, and the last time it was updated.
• Hardware—Layout shows the device name, IP address, device family,
platform, serial number, MAC address, and role, along with its IOS/firmware
version and a link to its configuration file.
• Tagging—Layout shows the device name, IP address, MAC address, device
role, location, and tags.
• Customize—Layout shows the information in the columns that you have
selected to display.
For descriptions of the columns of information that you can display, see the Device
Inventory Information table below.
Below the Device Inventory table, you can adjust the number of devices displayed in the table (10, 25, 50,
100), and you can click First, Previous, Next, Last, or the page number to navigate through the table.
Device Inventory Information
The Device Inventory table displays the following information for each discovered device. All of the columns,
except the Config column, support sorting. Clicking on the column header sorts the rows in an ascending
order. Clicking on the column header again sorts the rows in descending order.
For more information, see the Cisco Application Policy Infrastructure Controller Enterprise Module
Configuration Guide.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
48
Managing Devices and Hosts
Device Inventory Information
Table 17: Device Inventory Information
Column Name
Description
Device Status
State of the device.
• Connecting—Controller is connecting to the
device.
• Reachable:
• Discovered—Controller has connected to
the device and is able to execute Cisco
commands using the CLI .
• Failure—Controller has connected to the
device, but is unable to execute Cisco
commands using the CLI. This status
usually indicates that the device is not a
Cisco device.
• Authentication Failed—Controller has
connected to the device but is unable to
determine what type of device it is. This device
status also usually indicates that the device is not
a Cisco device.
• Unreachable—Controller is unable to connect
to the device.
Note
If credentials are not provided at the
time a discovery request is made or
earlier, then the device status could
be displayed as "Not reachable." You
need to perform a new discovery with
the correct credentials.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
49
Managing Devices and Hosts
Device Inventory Information
Column Name
Description
Device Name
Name of the device. Click the device name to display
the Device Overview dialog box with the following
information:
• Device serial number
• Device IP address
• MAC address
• Cisco OS version
• Up time
• Product ID
• Vendor
• Memory size
Note
The device name appears red for any
device whose inventory has not been
updated for more than 30 minutes.
The Device Overview dialog box also includes an
Interfaces tab with the following interface data:
• Status—Up or down
• Interface name—Name of the interface.
• MAC address—MAC address of the interface.
MAC Address
MAC address of the device.
IP Address
IP address of the device.
IOS/Firmware
Cisco IOS software currently running on the device.
Platform
Cisco product part number.
Serial Number
Cisco device serial number.
Up Time
Period of time that the device has been up and
running.
Config
Click View to display detailed configuration
information similar to the CLI show running-config
command output.
Note
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
50
This feature is not supported for access
points and wireless LAN controllers,
therefore configuration data is not returned
for these device types.
Managing Devices and Hosts
Device Inventory Information
Column Name
Description
Device Role
Role assigned to each discovered device during the
scan process. The device role is used to identify and
group devices according to their responsibilities and
placement within the network. If the controller is
unable to determine a device role, it sets the device
role as unknown.
Note
The controller can change the device role
as the network topology changes, but if
you manually change the device role, then
the role will not change as the network
topology changes.
If desired, you can use the drop-down list in this
column to change the assigned device role. The
following device roles are available:
• Unknown
• Access
• Core
• Distribution
• Border Router
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
51
Managing Devices and Hosts
Device Inventory Information
Column Name
Description
Location
Tag that you can apply to a device to denote its
geographic location. By applying the same tag to
several devices, you can group them based on a
common attribute. The Device Inventory window
and Topology window support location tags.
Use the following guidelines when creating location
tags:
• Location tag information is maintained on the
controller only and not deployed to or dirived
from the device itself.
• A location defined on the controller is not the
"civic-location" property that some devices
support.
• You cannot create, use, or search for location
tags in the Topology window.
• Location tags cannot be attached to hosts.
• You can apply only one location tag to a device.
However, you can use both a location tag and a
device tag together.
For information about adding location tags, see
Adding or Removing Location Tags, on page 64.
Along with the location tag, you can add a
geographical marker on a world map to a device. For
information, see Adding or Changing a Location
Marker, on page 66.
Device Tag
Tag assigned to devices to identify them by a common
attribute. For example, you can create a tag and use
it to group devices based on a platform ID or Cisco
IOS release.
A number in the Tag column indicates how many tags
have been applied to that device.
Note
You are permitted to use both a location
tag and a device tag together.
For information about adding or removing device tags,
see Adding or Removing a Device Tag in Device
Inventory, on page 62.
For information about deleting a tag from the
controller database, see Deleting a Tag, on page 67.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
52
Managing Devices and Hosts
Device Inventory Information
Column Name
Description
Policy Tag
Tag applied to a group of devices that will share the
same policy.
After applying a policy tag, you need to configure the
policies that will be applied to the devices with the
same policy tag. For information about configuring
QoS policies, see the Cisco EasyQoS Application for
APIC-EM User Guide.
Last Updated Time
Date and time that the device was last scanned and
the controller database was updated.
Device Family
Group of related devices, as follows:
• Cisco Interfaces and Modules
• Routers
• Switches and Hubs
• Third Party Device
• Unsupported Cisco Device
• Wireless Controller
Device Series
Series number of the device, for example, Cisco
Catalyst 4500 Series Switches.
Last Inventory Collection Status
Status of the last discovery scan for the device:
• Managed—Device is in a fully managed state.
• Partial Collection Failure—Device is in a
partial collected state and not all the inventory
information has been collected. Move the cursor
over the Information (i) icon to display
additional information about the failure.
• Unreachable—Due to device connectivity
issues, the device could not be reached and no
inventory information was collected. This
condition can occur when periodic collection
happens.
• Wrong Credentials—If the device credentials
are changed after adding the device to the
inventory, this condition is noted.
• In Progress—Inventory collection is occurring.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
53
Managing Devices and Hosts
Device Inventory Tasks
Device Inventory Tasks
The actions that you can perform from the Device Inventory window depend on the layout that you choose.
When you select one or more devices, you can click any of the following buttons to perform the corresponding
action.
Table 18: Device Inventory Buttons
Button
Action
Add Device
Allows you to discover a specific device and add it
to your inventory. If authentication of the device fails
due to invalid credentials, the device enters the
collection failure state. For information, see Adding
a Device Manually, on page 55.
Set Location
Sets the location of the devices associated with a
location tag on a geographical map. For information,
see Adding or Changing a Location Marker, on page
66.
Set Device Tags
Groups devices according to common attributes. For
information, see Adding or Removing a Device Tag
in Device Inventory, on page 62.
Set Policy Tag
Groups devices so that you can deploy the same QoS
policy to those devices at the same time. For
information, see Adding or Removing a Policy Tag
in Device Inventory, on page 63.
Delete
Deletes the selected devices from inventory. For
information, see Deleting a Device, on page 57.
Update Credentials
Changes the credentials of the selected devices. In
future discoveries, these credentials are used for the
selected devices instead of the global or discovery
job-specific credentials. For information, see Updating
Device Credentials, on page 68
Update Polling Interval
You can update the polling interval of selected
devices. These device-specific settings override the
global and job-specific settings for the selected
devices. For information, see Updating a Device's
Polling Interval, on page 72.
Resync (Resynchronize Devices)
Immediately polls the selected device for updated
device information and status. For information, see
Resynchronizing Device Information, on page 71.
Command Runner
Sends CLI commands to the selected devices using
API commands. Currently, show and other read-only
commands are permitted. For information, see
Running Commands on Devices, on page 71.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
54
Managing Devices and Hosts
Adding a Device Manually
Adding a Device Manually
You can manually add a device to your inventory.
Figure 14: Add Device Dialog box
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
Click Add Device.
Step 3
From the Add Device dialog box, enter the device's IP address in the Device IP field.
Step 4
In the Version field, choose the SNMP version from the drop-down list: V2C or V3 and complete the corresponding
fields:
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
55
Managing Devices and Hosts
Adding a Device Manually
Table 19: SNMP V2C Fields
Field
Description
Read Community
Read-Only community string value configured on devices that allows
the controller to connect to and access the devices. This community
string value must match the community string value that was
pre-configured on the devices.
Write Community
Write community string value configured on devices that allows the
controller to connect to, access, and change the devices. This community
string value must match the community string value pre-configured on
the devices.
Table 20: SNMP V3 Fields
Field
Description
Mode
Authentication mode to be used. Valid modes are Authentication and
Privacy, Authentication, No Privacy, No Authentication, No
Privacy.
Auth. Type
Valid only if you chose Authentication and Privacy or
Authentication, No Privacy. Two authentication types are available:
• SHA—Authentication based on the Secure Hash algorithm (SHA).
SHA is a hash algorithm that is used to authenticate packet data.
• MD5—Authentication based on the Message Digest 5 (MD5)
algorithm. MD5 is a hash algorithm that is used to authenticate
packet data.
Username
Valid only if you chose SHA or MD5.
Text string associated with the SNMP user and the chosen
authentication type (SHA or MD5).
Auth. Password
Valid only if you chose SHA or MD5.
Encrypted text string stored as the SNMP user password and associated
with the authentication type (SHA or MD5).
Privacy Type
Valid only if you chose Authentication and Privacy mode. Two
privacy types are available:
• DES—Data Encryption Standard (DES) 56-bit encryption in
addition to authentication based on the Cipher Block Chaining
(CBC) DES (DES-56) standard.
• AES128—Cipher Block Chaining (CBC) mode AES for
encryption.
Privacy Password
SNMPv3 privacy password associated with the chosen privacy type
(DES or AES128) and used to generate the secret key to encrypt
messages that are exchanged with devices.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
56
Managing Devices and Hosts
Deleting a Device
Step 5
Expand the SNMP RETRIES AND TIMEOUT area, if it is not already expanded, and complete the following fields:
Table 21: SNMP Retries and Timeout Fields
Step 6
Field
Description
Retries
Number of attempts the controller makes to communicate
with the devices using SNMP. The default is 3 tries.
Timeout
Number of seconds the controller waits while attempting
to communicate with the devices using SNMP before the
attempt fails. The default is 5 seconds.
Expand the CLI area, if it is not already expanded, and complete the following fields:
Table 22: CLI Fields
Step 7
Field
Description
Protocol
Protocol used from a remote management station to connect
device CLI. Valid options are Telnet (Telnet TCP/IP) or
SSH2 (Secure Shell 2.0).
Username
Identification used to log into a device's CLI.
Password
Password used to log into a device's CLI.
Enable Password
After successful login to the CLI, password used to access
Privileged EXEC mode.
Click Add.
Deleting a Device
You can delete devices from the Cisco APIC-EM database.
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
Click the check box next to the device that you want to delete.
A toolbar opens.
Note
Even after the toolbar opens, you can select multiple devices by clicking additional check boxes, or you can
select all devices by clicking the checkbox at the top of the list.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
57
Managing Devices and Hosts
Filtering Devices in the Device Inventory Window
Step 3
From the open toolbar, click Delete.
Filtering Devices in the Device Inventory Window
You can filter the devices displayed in the Devices Inventory window by device name, location, IP address
and VRF instance.
Note
To remove the filters, click Clear Filters.
Figure 15: Device Inventory Window Showing Filters
Before you begin
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Device Inventory toolbar, click Filters.
The following filters display:
• Device Name
• Device Location
• Device IP Address
• Device VRF
Step 2
Enter the appropriate value in the selected filter field.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
58
Managing Devices and Hosts
Changing the Devices Layout View
For example, for the Device Name filter, enter the name of a device.
The controller presents you with auto-complete values as you enter values in the other fields. Choose one of the suggested
values or finish entering the desired value.
Note
Step 3
You can also use a wildcard (asterisk) with these filters. You can enter values with the asterisk at the beginning,
end, or in the middle of the string value.
Click the plus (+) icon to perform the filter.
The data displayed in the Devices table automatically updates according to your filter selection.
Step 4
(Optional) If needed, add more filters following the above steps.
Note
Step 5
You can filter on more than one value per filter or across several different filter types.
To remove the filter, click the x icon next to the filter value.
What to do next
Review the updated information displayed in the Device Inventory window. If required for your network
configuration, make changes to the displayed columns within the Devices table view.
Changing the Devices Layout View
You can change the information that is displayed in the Devices table by selecting different layout views or
by customizing a layout view for the devices in your network.
Figure 16: Device Inventory Window Showing Layout Options
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
59
Managing Devices and Hosts
Changing the Device Role
Before you begin
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Device Inventory toolbar, click the Layout field and choose one of the following layout options from the
drop-down list:
• Status—Displays general device status information, including up time, update frequency, and number of updates.
• Hardware—Displays hardware information, including IOS/firmware, serial number, and device role.
• Tagging—Displays tagging information, including device role, location, and tag.
• Customize—Displays a list of options to choose from to create your own layout.
APIC-EM displays the information for the chosen layout.
Step 2
To customize a specific layout, choose Customize and select the desired display options.
Display options toggle on and off. Blue options with checkmarks indicate that the option is on and is displayed in the
table.
What to do next
Review the updated information displayed in the Device Inventory window. If required for your network
configuration, make any adjustments.
Changing the Device Role
During the scan process, the controller assigns a role to each discovered device. The device role is used to
identify and group devices according to their responsibilities and placement in the network.
A device can have one of the following roles:
• Unknown—Device role is unknown.
• Access—Device is located in and performs tasks required of the access layer or first tier/edge of the
network.
• Border Router—Device performs tasks required of a border router.
• Distribution—Device is located in and performs tasks required of the distribution layer of the network.
• Core—Device is located in and performs tasks required of the core of the network.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
60
Managing Devices and Hosts
Changing the Device Role
Figure 17: Device Roles and Network Locations
You can change the device role in the Device Inventory window.
Note
You can also change the device role from the Topology window. See Changing a Device's Role From the
Topology Window, on page 92.
Before you begin
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
You must have either administrator (ROLE_ADMIN) or policy administrator (ROLE_POLICY_ADMIN)
permissions and the appropriate RBAC scope to perform this procedure.
Step 1
From the Navigation pane, click Device Inventory.
The Devices Inventory window appears.
Step 2
From the Device Inventory toolbar, choose one of the options from the Layout drop-down list.
Valid options are Hardware, Tagging, or Customize > Device Role. The table refreshes and includes a column for the
Device Role.
Step 3
Locate the device you want to change and choose a new role from the drop-down list in the Device Role column.
Valid choices are Unknown, Access, Core, Distribution, or Border Router.
What to do next
If required, change the role of other devices in the Device Inventory window.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
61
Managing Devices and Hosts
Adding or Removing a Device Tag in Device Inventory
Adding or Removing a Device Tag in Device Inventory
You can group devices according to common attributes by applying device tags. For example, you may want
to apply device tags to group devices by their platform ID or Cisco IOS release. A single device can have
multiple device tags; similarly, a single device tag can be applied to multiple devices.
Note
For information about Policy tags and Location tags, see Adding or Removing a Policy Tag in Device Inventory,
on page 63 and Adding or Removing Location Tags, on page 64.
Figure 18: Device Tags Dialog Box
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
From the Device Inventory toolbar, choose Layout > Tagging from the drop-down list.
The table refreshes and displays a Device Tag column in addition to other columns.
Step 3
Select the check box to the left of the desired devices and click Set Device Tags.
Note
Step 4
For a single device, you can also click the number displayed in the Device Tag column.
Do one of the following:
• To apply a device tag, from the Available Tags list, click the tags that you want to apply to the selected devices.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
62
Managing Devices and Hosts
Adding or Removing a Policy Tag in Device Inventory
Note
If the desired tag is not in the list, enter a name for the tag and click +New Tag.
• To remove a device tag, from the Applied Tags list, click the Trash can icon next to the tag that you want to remove
from the selected devices.
Note
Step 5
The Applied Tags list is populated only if at least one of the selected devices has a tag applied to it.
Click x to close the dialog box.
What to do next
If required for your network configuration, add location or policy tags to your devices.
Adding or Removing a Policy Tag in Device Inventory
You can apply a policy tag applied to a group of devices so that you can deploy the same QoS policy to those
devices at the same time.
Figure 19: Policy Tag Dialog Box
Before you begin
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
SUMMARY STEPS
1.
2.
3.
4.
From the Navigation pane, click Device Inventory.
From the Device Inventory toolbar, choose Layout > Tagging from the drop-down list.
Select the check box to the left of the desired devices and click Set Policy Tag.
Do one of the following:
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
63
Managing Devices and Hosts
Adding or Removing Location Tags
5. Click x to close the dialog box.
DETAILED STEPS
Step 1
From the Navigation pane, click Device Inventory.
Step 2
From the Device Inventory toolbar, choose Layout > Tagging from the drop-down list.
The table refreshes and displays a Policy Tag column in addition to other columns.
Step 3
Select the check box to the left of the desired devices and click Set Policy Tag.
Note
Step 4
For a single device, you can also click Add displayed in the Policy Tag column.
Do one of the following:
• To apply a policy tag, from the Available Tags list, click the tag that you want to apply to the selected devices.
Note
If the desired tag is not in the list, enter a name for the tag and click +New Tag.
• To remove a policy tag, from the Applied Tags list, click the Trash can icon next to the tag that you want to remove
from the selected devices.
Note
Step 5
The Applied Tags list is populated only if at least one of the selected devices has a tag applied to it.
Click x to close the dialog box.
What to do next
If you added a policy tag to devices and now want to configure QoS policies, see the Cisco EasyQoS Application
for APIC-EM User Guide.
Adding or Removing Location Tags
You can apply a location tag to a device to name a device's geographic location. By applying the same tag to
several devices, you can group them based on their common location. You can create a location tag and,
optionally, place a corresponding location marker on a geographical map. For information, see Adding or
Changing a Location Marker, on page 66.
Use the following guidelines when adding location tags:
• Location tag information is maintained on the controller only and not deployed to or dirived from the
device itself.
• When location tags and markers are used, the Topology window displays them on a geographical map.
• A location defined on the controller is not the "civic-location" property that some devices support.
• Location tags cannot be attached to hosts.
• You can apply only one location tag to a device. However, you can use both a location tag and a device
tag together.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
64
Managing Devices and Hosts
Adding or Removing Location Tags
Figure 20: Set Location Tag Dialog Box
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
From the Device Inventory toolbar, choose Layout > Tagging from the drop-down list.
The table refreshes and displays a Location column in addition to other columns.
Step 3
Select the check box to the left of the desired devices (or select the check box at the top of the list to select all devices)
and click Set Location.
Note
Step 4
For a single device, you can also click the Add link displayed in the Location column for that device.
Do one of the following:
• To apply a location tag, from the Available Tags list, click the tag that you want to apply to the selected devices.
If the desired tag is not in the list, click the plus icon (+), enter a name for the tag, and click the check mark icon.
• To remove a location tag assignment from the devices, in the Edit Location field, click the x icon . The devices
now have no location tag assignment.
• To change the current location tag to another one, click the new location tag that you want to assign.
• To delete the location tag, first make sure that it is not in use (either change device assignments to other location
tags or remove the tag assignment altogether). Then, click the trash can icon next to the location tag that you want
to delete.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
65
Managing Devices and Hosts
Adding or Changing a Location Marker
Step 5
When you are done, click x to close the dialog box.
What to do next
If required for your network configuration, add or remove other location tags to other devices or add location
markers.
Related Topics
Adding or Changing a Location Marker, on page 66
Adding or Changing a Location Marker
A location marker is an icon used to indicate the location of the devices associated with a location tag on a
geographical map. You can add a location marker to devices in the Device Inventory window.
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
You have already added location tags to your devices.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
From the Device Inventory toolbar, choose Layout > Tagging from the drop-down list.
The table refreshes and displays a Location column in addition to other columns.
Step 3
(Optional) To display devices with a specific location tag, from the Device Inventory toolbar, click Filters, enter a
location tag in the Device Location field, and click the + icon.
Step 4
Select the desired location tag from the Locations column.
Note
Step 5
Because you are not assigning a location tag, it is not important which device you choose. When you add or
remove a location marker, the change is applied to the location tag, and all devices that have the location tag
will be updated.
To add or change a location marker, select the location tag from the Available Locations pane and do one of the following:
• In the Address of Location field on the right side of the geographical map, enter the address where you want to
place the location marker. You can enter a complete address or part of an address, for example, a city name or zip
code. Cisco APIC-EM displays the location on the map. Click the map where you want the marker to be placed and
confirm the action in the confirmation dialog box that appears.
• Position the map as close to the desired location as possible using your mouse to drag and drop, zoom in, and zoom
out on the map, then click the map.
Note
If you need to reposition the marker, click the map again where you want the marker to be placed.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
66
Managing Devices and Hosts
Deleting a Tag
Figure 21: Edit Location Dialog Box Showing Location Marker
Step 6
(Optional) To add additional location markers, click another location tag and repeat Step 5.
Step 7
When you are done, click x to close the dialog box.
Deleting a Tag
When a device tag, policy tag, or location tag is no longer needed, you can delete it, and it is removed
permanently from the controller. You can delete device tags using the Device Inventory window or the
Topology window. Policy tags and location tags can be deleted only from the Device Inventory window.
This procedure shows you how to delete tags from the Device Inventory window.
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Before you can delete a tag, you need to remove it from all devices that have been assigned the tag.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
From the Device Inventory toolbar, choose Layout > Tagging from the drop-down list.
Step 3
Do one of the following:
• To delete a device tag, click any number in the Device Tag column. From the Available Tags list, click the Trash
can icon next to the tag or tags that you want to delete.
• To delete a policy tag, click Add or the name of a policy tag in the Policy Tag column. From the Available Tags
list, click the Trash can icon next to the tag or tags that you want to delete.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
67
Managing Devices and Hosts
Updating Device Credentials
• To delete a location tag, click Add or the name of a location tag in the Location column. From the Available
Locations list, click the Trash can icon next to the tag or tags that you want to delete.
Step 4
Click OK to confirm the deletion.
The tag is removed permanently from the controller.
If the deletion fails, the tag might still be assigned to devices. Remove the tag from these devices and try to delete the
tag again.
Step 5
Click x to close the dialog box.
Updating Device Credentials
You can update the discovery credentials of selected devices. The updated settings override the global and
job-specific settings for the selected devices.
Figure 22: Update Device Credentials Dialog Box
Before you begin
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
You must have either administrator (ROLE_ADMIN) or policy administrator (ROLE_POLICY_ADMIN)
permissions and the appropriate RBAC scope to perform this procedure.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
Select the devices that you want to update.
Step 3
Click Update Credentials.
Step 4
Click OK to confirm this action.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
68
Managing Devices and Hosts
Updating Device Credentials
Step 5
From the Update Credentials dialog box, expand the SNMP area, if it is not already expanded.
Step 6
In the Version field, choose the SNMP version from the drop-down list: V2C or V3 and complete the corresponding
fields:
Note
Both the SNMP and CLI credentials are updated together, so you need to provide both credentials. If you
provide only SNMP credentials, Cisco APIC-EM saves only the SNMP credentials. The CLI credentials are
not updated.
Table 23: SNMP V2C Fields
Field
Description
Read Community
Read-Only community string value configured on devices that allows
the controller to connect to and access the devices. This community
string value must match the community string value that was
pre-configured on the devices.
Write Community
Write community string value configured on devices that allows the
controller to connect to, access, and change the devices. This community
string value must match the community string value pre-configured on
the devices.
Table 24: SNMP V3 Fields
Field
Description
Mode
Authentication mode to be used. Valid modes are Authentication and
Privacy, Authentication, No Privacy, No Authentication, No
Privacy.
Auth. Type
Valid only if you chose Authentication and Privacy or
Authentication, No Privacy. Two authentication types are available:
• SHA—Authentication based on the Secure Hash algorithm (SHA).
SHA is a hash algorithm that is used to authenticate packet data.
• MD5—Authentication based on the Message Digest 5 (MD5)
algorithm. MD5 is a hash algorithm that is used to authenticate
packet data.
Username
Valid only if you chose SHA or MD5.
Text string associated with the SNMP user and the chosen
authentication type (SHA or MD5).
Auth. Password
Valid only if you chose SHA or MD5.
Encrypted text string stored as the SNMP user password and associated
with the authentication type (SHA or MD5).
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
69
Managing Devices and Hosts
Updating Device Credentials
Field
Description
Privacy Type
Valid only if you chose Authentication and Privacy mode. Two
privacy types are available:
• DES—Data Encryption Standard (DES) 56-bit encryption in
addition to authentication based on the Cipher Block Chaining
(CBC) DES (DES-56) standard.
• AES128—Cipher Block Chaining (CBC) mode AES for
encryption.
Privacy Password
Step 7
SNMPv3 privacy password associated with the chosen privacy type
(DES or AES128) and used to generate the secret key to encrypt
messages that are exchanged with devices.
Expand the SNMP RETRIES AND TIMEOUT area, if it is not already expanded, and complete the following fields:
Table 25: SNMP Retries and Timeout Fields
Step 8
Field
Description
Retries
Number of attempts the controller makes to communicate
with the devices using SNMP. The default is 3 tries.
Timeout
Number of seconds the controller waits while attempting
to communicate with the devices using SNMP before the
attempt fails. The default is 5 seconds.
Expand the CLI area, if it is not already expanded, and complete the following fields:
Both the SNMP and CLI credentials are updated together, so you need to provide both credentials. If you
provide only SNMP credentials, Cisco APIC-EM saves only the SNMP credentials. The CLI credentials are
not updated.
Note
Table 26: CLI Fields
Step 9
Field
Description
Protocol
Protocol used from a remote management station to connect
device CLI. Valid options are Telnet (Telnet TCP/IP) or
SSH2 (Secure Shell 2.0).
Username
Identification used to log into a device's CLI.
Password
Password used to log into a device's CLI.
Enable Password
After successful login to the CLI, password used to access
Privileged EXEC mode.
Click Update.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
70
Managing Devices and Hosts
Resynchronizing Device Information
Resynchronizing Device Information
You can select devices to be polled immediately for updated device and status information, regardless of the
polling interval that is set. A maximum of 40 devices can be resynchronized at the same time.
Figure 23: Device Inventory Window Showing Resync in Progress
Step 1
From the Navigation pane, click Device Inventory.
Step 2
Select the device or devices on which you want to gather information about.
Step 3
Click Resync.
Step 4
Confirm the resynchronization by clicking OK.
Running Commands on Devices
You can run show commands and other read-only commands on selected devices and display the output in
Cisco APIC-EM. To determine the allowed command keywords, from the global toolbar, click API > Network
Poller > network-device-poller > /network-device-poller/cli/legit-reads > Try it out!
From the GUI, you can run a maximum of 5 commands per device, with a maximum of 20 devices per request.
When a device is part of another request that has not completed yet, no other commands are executed on it.
Access points are not supported. If you choose access points, they are omitted from executing commands.
Commands are only run on the other selected devices.
Before you begin
The command runner application is not installed on Cisco APIC-EM by default. To use the command running
application, you need to download the image from Cisco.com, install it, and enable the Command Runner
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
71
Managing Devices and Hosts
Updating a Device's Polling Interval
application. For information, see the Cisco Application Policy Infrastructure Controller Enterprise Module
Administrator Guide.
You must have either administrator (ROLE_ADMIN) or policy administrator (ROLE_POLICY_ADMIN)
permissions and the appropriate RBAC scope to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
Select the device on which you want to run commands.
Step 3
Click Command Runner.
Step 4
In the Command field, enter the command that you want to run and click the plus sign (+) icon to add the command to
the list of commands to be run.
You can add only one command at a time and up to 5 commands total.
Step 5
When you have defined all of the commands that you want to run, click Run.
Cisco APIC-EM runs the commands on the selected devices and displays the command output.
Note
Command Runner does not maintain any cache or history of the command results. If you run commands and
then close or navigate to a different window, all actions performed in command runner and their results are
lost.
Updating a Device's Polling Interval
You can update the polling interval at the global level for all devices on the Settings > Polling Interval page
or at the device level for a specific device in the Device Inventory window. When you set the polling interval
at the device level, that value takes precedence over the global polling interval value.
For information about setting the polling interval at the global level, see the Cisco Application Policy
Infrastructure Controller Enterprise Module Administrator Guide.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
72
Managing Devices and Hosts
Managing Your Host Inventory
Figure 24: Update Polling Interval Dialog Box
Before you begin
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
You must have either administrator (ROLE_ADMIN) or policy administrator (ROLE_POLICY_ADMIN)
permissions and the appropriate RBAC scope to perform this procedure.
Step 1
From the Navigation pane, click Device Inventory.
Step 2
Select the devices that you want to update.
Step 3
Click Update Polling Interval.
Step 4
Click OK to confirm this action.
Step 5
From the Update Polling Interval dialog box, in the Status field, click Enabled to turn on polling or click Disabled to
turn off polling.
Step 6
In the Polling Time field, enter the time interval (in minutes) between successive polling cycles. Valid values are from
25 to 1440 minutes (24-hours).
Note
Step 7
The device-specific polling time supersedes the global polling time. If you set the device-specific polling time
and then change the global polling time, Cisco APIC-EM continues to use the device-specific polling time.
Click Update.
Managing Your Host Inventory
Cisco APIC-EM displays information about the discovered hosts in the Host Inventory window.
The following table describes the information that is displayed about the hosts in your inventory.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
73
Managing Devices and Hosts
Filtering Hosts in the Host Inventory Window
Note
Use the filters located below the Host Inventory table to limit the number of hosts displayed in the table (10,
25, 50, 100) or to view groups of hosts at a time (First, Previous, Next, Last, or 1-3).
Figure 25: Host Inventory Window
The following table describes the information that is displayed about the hosts in your inventory.
Table 27: Host Inventory
Host Inventory
Description
Host Name
Name of the host.
Host MAC address
MAC address of the host.
Host IP address
IP address of the host.
Host type
Type of host (wired or wireless).
Connected Network Device IP Address
IP address of the device that is connected to the host.
Note
Connected Interface Name
IP addresses of only wired devices are
shown.
Name of the interface that the device is connected to.
For example, GigabitEthernet1/0/24.
Filtering Hosts in the Host Inventory Window
You can filter the hosts displayed in the Host Inventory window by host MAC address, host IP address, host
name, host type, connected network device IP address, or connected interface name.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
74
Managing Devices and Hosts
Filtering Hosts in the Host Inventory Window
Figure 26: Host Inventory Window Showing Filters Pane
Before you begin
Make sure that you have hosts in your inventory. If not, discover them using the Discovery function.
Step 1
From the Host Inventory toolbar, click Filters.
You can choose from the following filter options:
• Host MAC Address
• Host IP Address
• Host Name
• Host Type
• Connected Network Device IP Address
• Connected Interface Name
Step 2
Enter the appropriate value in the selected filter field.
For example, for the Host Name filter, enter the name of the host.
The controller presents you with auto-complete values as you enter values in the other fields. Choose one of the suggested
values or finish entering the value.
Note
Step 3
You can also use a wildcard (asterisk) with these filters. You can enter values with the asterisk at the beginning,
end, or in the middle of the string value.
Click the plus (+) icon to perform the filter.
The data displayed in the Devices table automatically updates according to your filter selection.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
75
Managing Devices and Hosts
Filtering Hosts in the Host Inventory Window
Step 4
(Optional) If needed, add more filters following the above steps.
Note
Step 5
You can filter on more than one value per filter or across several different filter types.
To remove the filter, click the x icon next to the filter value.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
76
CHAPTER
6
Using the Topology Map
• About Topology, on page 77
• Displaying Device Data, on page 83
• Aggregating Devices, on page 84
• Configuring the Topology Structure, on page 88
• Saving a Topology Layout, on page 90
• Opening a Saved Topology Layout, on page 91
• Changing a Device's Role From the Topology Window, on page 92
• Searching for Devices and Hosts, on page 93
• Adding or Removing a Device Tag in Topology , on page 95
• Adding or Removing a Policy Tag in Topology, on page 96
• Displaying Devices with Tags, on page 97
About Topology
The Topology window displays a graphical view of your network. Using the discovery settings that you have
configured, the Cisco APIC-EM discovers and maps devices to a physical topology with detailed device-level
data.
Note
The entire network topology is displayed. However, you will only have access to device information and
functions if the device is listed in the device scope in your user profile. If the device is not in your device
scope, then you will not be able to view additional information about the device, or, in the case of a user
profile with ROLE_ADMIN or ROLE_POLICY_ADMIN, tag devices or change device roles.
To access the Topology window, from the Navigation pane, click Topology. The Topology window appears
and displays a topology map of your network.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
77
Using the Topology Map
Topology Toolbar
Figure 27: Topology Window
The topology map includes the following key features:
• Auto-visualization of Layer 2 and 3 topologies on top of the physical topology for a granular view for
design planning and simplified troubleshooting.
• For a Layer 2 topology, display of configured VLANs within your network. For a Layer 3 topology,
display of OSPF, IS-IS, and so on, depending on what is currently configured and in use in your network.
• Device information.
• Display of a path trace in the topology map. For additional information about performing a path trace,
see the Cisco Path Trace Application for APIC-EM User Guide.
Note
Individual device configurations are retrieved and stored in a network information database (NIDB).
Topology Toolbar
The Topology toolbar is located at the top of the Topology window.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
78
Using the Topology Map
Topology Toolbar
Figure 28: Topology Window
Icon
Name
Description
Toggle Aggregation
Enables or disables device aggregation. Aggregating
devices means grouping devices together. You can
group devices in any way that makes sense to you.
You can save the layout for future reference by
clicking the Save icon.
This grouping does not effect the physical
configuration on the devices. Aggregation is enabled
by default.
Toggle Multiselect
Allows you to select multiple devices by dragging
the mouse over the desired devices or shift-clicking
on devices. You can also select multiple groups of
devices by clicking shift and dragging the mouse
over a group of devices. After selecting the group
of devices, you can aggregate or tag them. If you
aggregate devices of different product families, the
Cisco APIC-EM shows them as generic devices
(without a device type) and the number of devices.
Multiselect is off by default.
Search Topology
Searches for a host or device by host name, device
name, device type, or IP address. As you enter
information into this field, the Cisco APIC-EM
displays matches. Select the host or device from the
results that appear. The selected host or device
appears in the Topology window.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
79
Using the Topology Map
Topology Toolbar
Icon
Name
Description
Filters
Allows you to choose a filter that you can apply to
the topology map. For each filter, you can make
additional adjustments using the Advanced options.
For information, see Configuring the Topology
Structure, on page 88.
• Enterprise (Default)—Displays your network
topology, separating your devices on
connection branches. For example, if a group
of devices are connected to Router A, and
another group of devices are connected to
Router B, the topology would show this
division and would separate the devices.
• Connections—Displays the devices according
to their number of connections. Starting from
the left, the devices with no connections are
displayed, then devices with one connection,
then devices with two connections, and so on.
• Type and Role—Displays the devices
according to their role in the network: access
router, distribution switch, core switch and
hub, and boarder router.
• Advanced—Provides options for you to refine
the topology display.
Adjusts the Topology window's view.
Click the - (minus) icon to minimize the
view of the network hosts and devices.
Zoom out
Note
Zoom in
Adjusts the Topology window's view. Click the +
(plus) icon on the menu bar to maximize the view
of the network hosts and devices.
Toggle Color Code
Toggles between displaying the device icons in
different colors or in a single color. Color coding
is enabled by default.
Device Tags
Displays the available device tags. Clicking on an
individual tag highlights the device or devices in
the Topology window that have this tag.
You can also apply tags to devices by selecting the
device, clicking Device Tagging in the Device
Information dialog box, and then creating and
applying the tags.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
80
Using the Topology Map
Topology Toolbar
Icon
Name
Description
Policy Tags
Displays the available policy tags. Clicking on an
individual tag adds the device to the policy scope.
You can also applypolicy tags to devices in the
EasyQoS > Policy Scopes.
Layers
Displays devices with the following attributes on
the topology map:
• Layer 2—Displays devices based on the
selected VLAN or Layer 2 protocol. Select
either a VLAN from the drop-down menu or
one of the Layer 2 protocols.
Note
You can also access a management
network view by choosing a
management selection from the
drop-down menu.
• Layer 3—Displays devices based on the
selected Layer 3 protocol. The following Layer
3 protocols are available:
• Intermediate System-to-Intermediate
System (IS-IS)
• Open Shortest Path First (OSPF)
• Enhanced Interior Gateway Routing
Protocol (EIGRP)
• Static-Route
Note
The default Layer 3 topology has
all Layer 3 protocols.
• VRF—Displays devices that have Virtual
Routing and Forwarding (VRF) tables.
Save and Load Options
Displays the following options:
• Save Current Layout—Saves the current
layout, device aggregations, and labels.
• Load Saved Layout—Loads the previously
saved layout, device aggregations, and labels)
options.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
81
Using the Topology Map
Topology Icons
Icon
Name
Description
Map view
Displays the Topology map view. Click this icon
to view the network topology in a graphical
representation of your network's physical location.
This icon is displayed only if you have
added location markers for your devices
from the Device Inventory window.
Note
Topology Icons
The following icons appear in the Topology window:
Icon
Network Element
Description
Cloud
Representation of the external network.
Router
Displays the device name.
Switch
Displays the device name.
Access Point
Displays the device name.
Wireless LAN
Controller
Displays the device name.
Aggregated Devices
Displays the number of aggregated devices and the
device type.
Note
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
82
If different devices types are aggregated, only
the number of aggregated devices is
displayed.
Using the Topology Map
Displaying Device Data
Icon
Network Element
Description
Location Marker
Displays the device name. The device icon is displayed
with a location marker as a background.
If you add location markers to your devices (from the
Device Inventory window) and then click Topology in
the navigation pane or click the Map button on the
Topology toolbar, the Topology map view appears. The
map view shows where you have placed your location
markers (for example, San Jose and London). Click a
location marker on the map to display the topology for
that location (for example, San Jose).
Devices that use a different location marker (for
example, London) are shown with a location marker as
a background.
Links
Lines between devices.
Click on a link to display information about the
connected devices.
Note
Some of the links may be hidden due to
device aggregations.
Displaying Device Data
You can display data for a specific device in the Topology window. Displaying device data is helpful when
troubleshooting network connectivity issues between devices.
Note
The device data that is accessible in the Topology window is also accessible in the Device Inventory window.
The following device data is available:
• Location (Location information is displayed if the selected device icon has a location marker background.
Click the Location link to display the topology for devices that share that location marker.)
• Type
• Device role (For information about changing the device role, see Changing the Device Role, on page
60.
• IP address
• MAC address
• OS (operating system)
• Software version
• Ports
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
83
Using the Topology Map
Aggregating Devices
• Gigabit Ethernet ports
• 10-Gigabit Ethernet ports
• Management ports
• VLAN (if exists)
• Number of connections
• List of connected devices (Each connected device shows its device type (icon) and the number of
connections. Clicking on a connected device displays the details for that device.)
• Tags
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Note
If you have added location markers for your devices from the Device Inventory window, the Topology map
view appears. Click a location marker to display the Topology for that location.
Step 2
To display data for a specific device, click that device in the Topology window.
Step 3
To display a list of aggregated devices, do the following:
a) In the Topology window, click an aggregated devices icon.
b) In the Device Details pane, click the Details link for each device to view the device data.
c) Click the Aggregated Results link to return to the list of aggregated devices.
What to do next
Select and review data from other devices within your network, or perform other tasks including the following:
• Aggregate or disaggregate selected groups
• Search for device using device names and IP addresses
• Apply tags to devices within your network
• Change the device role
Aggregating Devices
You use the Cisco APIC-EM device aggregation feature to adjust how devices are displayed in the Topology
window. This feature enhances network navigation and manageability.
Aggregating Devices in the Topology Window
You can aggregate and disaggreate devices into and out of groups in the Topology window.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
84
Using the Topology Map
Aggregating Devices in the Topology Window
Before you begin
Scan your network using the discovery functionality of the Cisco APIC-EM to populate device and host
inventory for the database.
Determine how the devices within your network configuration are to be visually grouped and organized.
Step 1
Click Topology in the navigation pane.
The Topology window appears.
Note
Step 2
Click the Toggle Aggregation icon to enable device aggregation.
Note
Step 3
If you have added location markers for your devices from the Device Inventory window, the Topology map
view appears. Click a location marker to display the Topology for that location.
Device aggregation is enabled by default.
Drag and drop a device icon onto another device icon.
The device icon changes to an aggregated devices icon. For more information about the aggregated devices icon, see
Topology Icons, on page 82.
Note
You can also select multiple devices by clicking the Multiselect icon, dragging the mouse over the desired
devices, and clicking the Aggregate Selected link.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
85
Using the Topology Map
Disaggregating Devices in the Topology Window
Disaggregating Devices in the Topology Window
You can ungroup devices by disaggregating them in the Topology window.
Figure 29: Topology Window Showing Disaggregate Option in Devices List
Before you begin
Scan your network using the discovery functionality of the Cisco APIC-EM to populate device inventory for
the database.
Determine how the devices within your network configuration are to be visually grouped and organized.
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Note
Step 2
If you have added location markers for your devices from the Device Inventory window, the Topology map
view appears. Click a location marker to display the Topology for that location.
Click on an aggregated devices icon.
A list of the aggregated devices appears.
Step 3
From the list, click the Disaggregate link for each device that you want to remove from the aggregated devices.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
86
Using the Topology Map
Changing the Aggregated Devices Label
The device is removed from the list and from the aggregated devices icon. The aggregated device label and the aggregated
devices icon are updated to reflect the number of devices.
Changing the Aggregated Devices Label
The default label for aggregated devices is the number of devices and the device type (# devicetype Devices).
However, you can change the default label to one that is meaningful in the context of your network topology.
Before you begin
Scan your network using the discovery functionality of the Cisco APIC-EM to populate device inventory for
the database.
Determine how the devices within your network configuration are to be visually grouped and organized.
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Note
Step 2
If you have added location markers for your devices from the Device Inventory window, the Topology map
view appears. Click a location marker to display the Topology for that location.
Click an aggregated devices icon.
A list of the aggregated devices appears. At the top of the list is the aggregated devices label.
Step 3
Click the aggregated devices label to open an edit field where you can change the label.
Step 4
Change the label, then click outside of the edit field to save your changes.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
87
Using the Topology Map
Configuring the Topology Structure
Configuring the Topology Structure
You can choose from three default topology layouts. You can also use advanced settings to modify these
layouts, such as the overall size of the topology graph, the spacing that separates individual elements, and
more.
Figure 30: Topology Window Showing Filters Drop-Down List
Before you begin
Scan your network using the discovery functionality of the Cisco APIC-EM to populate device inventory for
the database.
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Note
If you have added location markers for your devices from the Device Inventory window, the Topology map
view appears. Click a location marker to display the Topology for that location.
Step 2
From the Topology toolbar, click the Filters icon.
Step 3
Select a filter from the drop down list. Available options are Enterprise Collapsed, Enterprise Expanded, or Device
Type & Role.
Step 4
Click the Advanced View button to configure how each filter is displayed. Click the Basic View button to return to the
basic view.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
88
Using the Topology Map
Configuring the Topology Structure
Filter
Basic View
Advanced View
Enterprise
Arranges the device icons into a
Device type—Use the slider to adjust the amount of
structured connection hierarchical view, space between device icons based on their device types.
from top to bottom.
cloud-centralizeX— When checked (default), the device
icons are centered along the X axis. When unchecked,
the device icons are aligned to the X axis.
Device role—Use the slider to adjust the amount of
space between device icons based on their device roles.
Branch— Use the slider to adjust the amount of space
between branches.
Node overlap—Use the slider to adjust the amount of
space between nodes.
Note
Connections
Arranges the device icons from left to
Connections—Use the slider to adjust the amount of
right based on the number of connections, space between connections.
from least to most.
Node overlap—Use the slider to adjust the amount of
Note
Aggregated devices are
space between nodes.
disaggregated in this view.
centralizeY—When checked, the device icons are
centered along the Y axis. When unchecked, the device
icons are aligned to the Y axis.
Note
Type and Role
Select x or y from the drop down next to each
slider to change how the device icons are
displayed, horizontally or vertically.
Arranges the device icons from top to
bottom based on device type (cloud,
router, WLC, switch, access point, wired,
wireless) and role (border router, core,
distribution, and access)
Note
Aggregated devices are
disaggregated in this view.
Select x or y from the drop down next to each
slider to change how the device icons are
displayed, horizontally or vertically.
Device type—Use the slider to adjust the amount of
space between device icons based on their device types.
Device role—Use the slider to adjust the amount of
space between device icons based on their device roles.
Node overlap—Use the slider to adjust the amount of
space between nodes.
centralizeX—When checked, the device icons are
centered along the X axis. When unchecked, the device
icons are aligned to the X axis.
Note
Select x or y from the drop down next to each
slider to change how the device icons are
displayed, horizontally or vertically.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
89
Using the Topology Map
Saving a Topology Layout
What to do next
Save the current layout or load a previously saved layout. For information, see Saving a Topology Layout,
on page 90 and Opening a Saved Topology Layout, on page 91.
Saving a Topology Layout
You can save a topology layout so that you can open and view it later.
Figure 31: Topology Window Showing Save Dialog Box
Before you begin
You must have administrator role permissions.
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Step 2
From the Topology toolbar, click the Save icon.
Step 3
In the Topology Title field, enter a name for the topology and click Save as New.
Step 4
Click OK to confirm the save.
The topology is saved and the name appears at the top of the dialog box.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
90
Using the Topology Map
Opening a Saved Topology Layout
Opening a Saved Topology Layout
You can open a topology layout that you have previously saved.
Figure 32: Topology Window Showing Previously Saved Topology Layouts in Save Dialog Box
Before you begin
You must have administrator (ROLE_ADMIN) permissions and access to all devices (RBAC Scope set to
ALL) to perform this procedure.
Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Step 2
From the Topology toolbar, click the Save icon.
A dialog box appears listing the saved topology layouts.
Step 3
For the topology layout that you want to open, click the Folder icon..
Step 4
Click OK to confirm.
The topology layout opens in the Topology window.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
91
Using the Topology Map
Changing a Device's Role From the Topology Window
Changing a Device's Role From the Topology Window
During the scan process, a device role is automatically assigned to each discovered device. The device role
is used for identifying and grouping devices according to their responsibilities and placement within the
network.
A device can have one of the following roles within the Cisco APIC-EM:
• Unknown—Device role is unknown.
• Access—Device is located within and performs tasks required for the access layer or first tier/edge.
• Border Router—Device performs the tasks required for a border router.
• Distribution—Device is located within and performs tasks required for the distribution layer.
• Core—Device is located within and performs tasks required for the core.
You can change the device role when you select a device and display the device data.
Note
You can also change the device role from the Device Inventory window.
Figure 33: Topology Window Showing Role Drop-Down List
Before you begin
Scan your network using the discovery functionality of the Cisco APIC-EM to populate device inventory for
the database.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
92
Using the Topology Map
Searching for Devices and Hosts
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Note
If you have added location markers for your devices from the Device Inventory window, the Topology map
view appears. Click a location marker on the map to display the Topology for that location.
Step 2
Click a specific device in the Topology window to select it.
Step 3
Choose a role from the Role drop-down list: Access, Core, Distribution, or Border Router.
Step 4
(Optional) Select additional devices and change device roles.
Step 5
Click the Filters icon on the Topology toolbar.
Step 6
(Optional) Select a filter from the drop down list. Available options are Branch, Connections, or Device and Role.
Step 7
Click the refresh button to the right of the filter type to update all of the device roles.
The Topology structure refreshes showing the changed device roles.
Searching for Devices and Hosts
You use the Cisco APIC-EM search function to locate specific devices or hosts within your network. This
function allows you to search the network using any string value. To locate a specific device or host quickly,
use any of the following values in the search field:
• Device or host name
• Aggregation label
• IP address
• Device role
• Device type
Note
The search function supports fragmented results. For example, if you enter 12 in the search field, you will get
results for devices with IP addresses or device names that contain 1 and 2 (.12, .120, .102, 10.20, 1-switch2,
etc).
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
93
Using the Topology Map
Searching for Devices and Hosts
Figure 34: Topology Window Showing Device Search List
Before you begin
Scan your network using the discovery functionality of the Cisco APIC-EM to populate device and host
inventory for the database.
Determine the string value to be used within your network for your search.
Step 1
Click Topology in the navigation pane.
The Topology window appears.
Note
Step 2
If you have added location markers for your devices from the Device Inventory window, the Topology map
view appears. Click a location marker on the map to display the Topology for that location.
From the Topology toolbar, enter a keyword in the Search Topology field.
As you begin typing, the controller displays a list of possible matches to your entry.
Note
You can click the x in the search field to clear the search keyword field and the results.
Step 3
Click on a device from the search results to highlight that device and its links in the Topology window. Click on the
device again to display detailed data for that device.
Step 4
Proceed with any provisioning or troubleshooting tasks on the located devices or hosts.
What to do next
Search using other string values for other devices or hosts within your network, or perform other tasks including
the following:
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
94
Using the Topology Map
Adding or Removing a Device Tag in Topology
• Viewing the data for specific devices
• Applying tags to devices within your network
• Host a meeting using the topology co-editor to collaborate with other users in real-time on the network
Adding or Removing a Device Tag in Topology
In the Topology window, you can add device tags to associate devices that share a common attribute. For
example, you can create a tag and use it to group devices based upon a platform ID, Cisco IOS releases, or
location. Similarly, you can remove tags from devices.
You can also add or remove device tags from the Device Inventory window or from the EasyQoS window.
For information, see Adding or Removing a Device Tag in Device Inventory, on page 62 or the Cisco EasyQoS
Application for APIC-EM User Guide.
Note
Applying a tag to a host is not supported.
Figure 35: Device Tag Dialog Box
Before you begin
• Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
Step 1
From the Navigation pane, click Topology.
Step 2
Click the device or devices you want to tag. To select more than one device, click the Multiselect icon. For information
about how to use the multiselect function, see Topology Icons, on page 82.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
95
Using the Topology Map
Adding or Removing a Policy Tag in Topology
Note
To deselect devices in your selection, click outside of the selected device.
The Device Information dialog box appears.
Step 3
Click Device Tagging.
The Device Tagging dialog box appears.
Step 4
From the Available Tags column, click a tag to apply it to the selected device or devices. If the tag you want does not
exist, you can create it by entering the name of the tag in the Device Tag Title field and clicking +Create Tag.
Step 5
When you are done, click x to close the dialog box.
Adding or Removing a Policy Tag in Topology
Before you can create a QoS policy, you need to identify the policy scope, that is, the devices that will be
configured with QoS policies. You identify the devices by tagging them with a policy tag.
You can also add or remove policy tags from the Device Inventory window or the EasyQoS window. For
information, see Adding or Removing a Device Tag in Device Inventory, on page 62 or the Cisco EasyQoS
Application for APIC-EM User Guide.
Figure 36: Policy Tag Dialog Box
Before you begin
• Make sure that you have devices in your inventory. If not, discover devices using the Discovery function.
From the Topology or Device Inventory window, verify that the device roles assigned to devices during
discovery are appropriate for your network design. If necessary, change any of the device roles that are not
appropriate.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
96
Using the Topology Map
Displaying Devices with Tags
Step 1
From the Navigation pane, click Topology.
Step 2
Click the device or devices you want to tag. To select more than one device, click the Multiselect icon. For information
about how to use the multiselect function, see Topology Icons, on page 82.
Note
To deselect devices in your selection, click outside of the selected device.
The Device Information dialog box appears.
Step 3
Click Policy Tagging.
The Multiple Policy Tagging dialog box appears.
Step 4
From the Available Policy Tags column, click a tag to apply it to the selected device or devices. If the tag you want does
not exist, you can create it by entering the name of the tag in the Policy Tag Title field and clicking +Create Tag.
Step 5
When you are done, click x to close the dialog box.
Displaying Devices with Tags
To display tagged devices from the Topology window, perform the following steps.
Figure 37: Topology Window Showing Devices with Tags
Before you begin
You should have performed the following tasks:
• Discovered the devices on your network to populate the device inventory database.
• Created tags and applied them either through the Device Inventory or Topology window.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
97
Using the Topology Map
Displaying Devices with Tags
Step 1
From the Navigation pane, click Topology.
The Topology window appears.
Step 2
From the Topology toolbar, click the Tags.
A tag selection box appears.
Step 3
To identify the devices associated with a tag, click the tag. To return the devices to their normal display, click the tag
again.
Tags are color-coded, so when you click a tag, a circle of the same color is drawn around its associated devices.
Note
You can click more than one tag at a time. The tag that you chose to display first is the innermost circle around
the device, followed by the next tag as the next circle, and so on.
Cisco Network Visibility Application on APIC-EM User Guide, Release 1.6.0.x
98
