This chapter contains the following sections:
• New and Changed Information, on page 1
New and Changed Information
The following table provides an overview of the significant changes to the organization and features in this
guide up to this current release. The table does not provide an exhaustive list of all changes made to the guide
or of the new features up to this release.
Table 1: New Features and Changed Behavior in Cisco APIC for Cisco APIC Release 25.0(1)
Feature or Change
Description
Change in release numbering for
Cisco Cloud APIC
Beginning with release 25.0(1), the
release numbering has changed for
Cisco Cloud APIC. The sequential
order of releases for Cisco Cloud
APIC is as follows:
Where Documented
• 4.1(x) (support for AWS only)
• 4.2(x)
• 5.0(x)
• 5.1(x)
• 5.2(x)
• 25.0(x) (this release)
Support for Google Cloud with
Cisco Cloud APIC
Beginning with release 25.0(1),
support is now available for Google
Cloud with Cisco Cloud APIC.
Support for Prometheus Node
Exporter on Cisco Cloud APIC
The Prometheus Node Exporter is Monitoring VM Host Metrics, on
supported on Cisco Cloud APIC page 107
beginning with release 25.0(1).
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
1
New and Changed Information
New and Changed Information
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
2
CHAPTER
2
About Cisco Cloud APIC
• Overview, on page 3
• Guidelines and Limitations, on page 4
• About the Cisco Cloud APIC GUI, on page 4
Overview
Cisco Application Centric Infrastructure (ACI) customers who own a private cloud sometimes may run part
of their workload on a public cloud. However, migrating the workload to the public cloud requires working
with a different interface and learning different ways to set up connectivity and define security policies.
Meeting these challenges can result in increased operational cost and loss of consistency.
Beginning in Cisco Application Policy Infrastructure Controller (APIC) Release 4.1(1), Cisco ACI can use
Cisco Cloud APIC to extend a Cisco ACI fabric to certain public clouds.
Cisco Cloud APIC is supported on the following cloud computing platforms:
• Release 4.1(1): Support for Amazon Web Services (AWS)
• Release 4.2(1): Support for Microsoft Azure
• Release 25.0(1): Support for Google Cloud
What Cisco Cloud APIC Is
Cisco Cloud APIC is a software component of Cisco APIC that can be deployed on a cloud-based virtual
machine (VM). Cisco Cloud APIC provides the following features:
• Provides an interface that is similar to the existing Cisco APIC to interact with the Google Cloud public
cloud.
• Automates the deployment and configuration of cloud connectivity.
• Configures the cloud router control plane.
• Translates Cisco ACI policies to cloud native policies.
• Discovers endpoints.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
3
About Cisco Cloud APIC
Guidelines and Limitations
Guidelines and Limitations
This section contains the guidelines and limitations for Cisco Cloud APIC.
• Before configuring an object for a tenant, first check for any stale cloud resource objects. A stale
configuration might be present if it was not cleaned properly from the previous Cisco Cloud APIC virtual
machines that managed the account. Cisco Cloud APIC can display stale cloud objects, but it cannot
remove them. You must log in to the cloud account and remove them manually.
To check for stale cloud resources:
1. From the Cisco Cloud APIC GUI, click the Navigation menu > Application Management >
Tenants. The Tenants summary table appears in the work pane with a list of tenants as rows in a
summary table.
2. Double click the tenant you are creating objects for. The Overview, Topology, Cloud Resources,
Application Management, and Event Analytics tabs appear.
3. Click the Cloud Resources > Actions > View Stale Cloud Objects. The Stale Cloud Objects
dialog box appears.
About the Cisco Cloud APIC GUI
The Cisco Cloud APIC GUI is categorized into groups of related windows. Each window enables you to
access and manage a particular component. You move between the windows using the Navigation menu that
is located on the left side of the GUI. When you hover your mouse over any part of the menu, the following
list of tab names appear: Dashboard, Application Management, Cloud Resources, Operations,
Infrastructure, and Administrative.
Each tab contains a different list of subtabs, and each subtab provides access to a different component-specific
window. For example, to view the EPG-specific window, hover your mouse over the Navigation menu and
click Application Management > EPGs. From there, you can use the Navigation menu to view the details
of another component. For example, you can navigate to the Active Sessions window from EPGs by clicking
Operations > Active Sessions.
The Intent menu bar icon enables you to create a component from anywhere in the GUI. For example, to
create a tenant while viewing the EPGs window, click the Intent icon. A dialog appears with a search box
and a drop-down list. When you click the drop-down list and choose Application Management, a list of
options, including the Tenant option, appears. When you click the Tenant option, the Create Tenant dialog
appears displaying a group of fields that are required for creating the tenant.
For more information about the GUI icons, see Understanding the Cisco Cloud APIC GUI Icons, on page 4
For more information about configuring Cisco Cloud APIC components, see Configuring Cisco Cloud APIC
Components, on page 43
Understanding the Cisco Cloud APIC GUI Icons
This section provides a brief overview of the commonly used icons in the Cisco Cloud APIC GUI.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
4
About Cisco Cloud APIC
Understanding the Cisco Cloud APIC GUI Icons
Table 2: Cisco Cloud APIC GUI Icons
Icon
Description
Figure 1: Navigation Pane (Collapsed)
The left side of the GUI contains the Navigation pane,
which collapses and expands. To expand the pane, hover
your mouse icon over it or click the menu icon at the
top. When you click the menu icon, the Navigation
pane locks in the open position. To collapse it, click the
menu icon again. When you expand the Navigation
pane by hovering the mouse icon over the menu icon,
you collapse the Navigation pane by moving the mouse
icon away from it.
When expanded, the Navigation pane displays a list of
tabs. When clicked, each tab displays a set of subtabs
that enable you to navigate between the Cisco Cloud
APIC component windows.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
5
About Cisco Cloud APIC
Understanding the Cisco Cloud APIC GUI Icons
Icon
Description
Figure 2: Navigation Pane (Expanded)
The Cisco Cloud APIC component windows are
organized in the Navigation pane as follows:
• Dashboard Tab—Displays summary information
about the Cisco Cloud APIC components.
• Topology Tab—Displays topology information
about the Cisco Cloud APIC.
• Cloud Resources Tab—Displays information
about regions, VPCs, routers, endpoints, and
instances.
• Application Management Tab—Displays
information about tenants, application profiles,
EPGs, contracts, filters, VRFs, cloud context
profiles, and external networks.
• Operations Tab—Displays information about
event analytics, active sessions, backup & restore
policies, tech support policies, firmware
management, schedulers, and remote locations.
• Infrastructure Tab—Displays information about
the system configuration and external connectivity.
• Administrative Tab—Displays information about
authentication, security, local and remote users,
and smart licensing.
Note
For more information about the contents of
these tabs, see Viewing System Details, on
page 107
Figure 3: Search Menu-Bar Icon
The search menu-bar icon displays the search field,
which enables you to to search for any object by name
or any other distinctive fields.
Figure 4: Intent Menu-Bar Icon
The Intent icon appears in the menu bar between the
search and the feedback icons.
When clicked, the Intent dialog appears (see below).
The Intent dialog enables you to create a component
from any window in the Cisco Cloud APIC GUI. When
you create or view a component, a dialog box opens and
hides the Intent icon. Close the dialog box to access
the Intent icon again.
For more information about creating a component, see
Configuring Cisco Cloud APIC Components, on page
43.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
6
About Cisco Cloud APIC
Understanding the Cisco Cloud APIC GUI Icons
Icon
Description
Figure 5: Intent Dialog Box
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
7
About Cisco Cloud APIC
Understanding the Cisco Cloud APIC GUI Icons
Icon
Description
The Intent dialog box contains a search box and a
drop-down list. The drop-down list enables you to apply
a filter for displaying specific options. The search box
enables you to enter text for searching through the
filtered list.
• All Categories
• Workflows—Displays the following options:
• Cloud Set Up
• EPG Communication
• Region Management
• Application Management—Displays the
following options:
• Create Tenant
• Create Application Profile
• Create EPG
• Create Contract
• Create Filter
• Create VRF
• Create Cloud Context Profile
• Create Leak Route
• Create External Network
• Operations—Displays the following options:
• Create Backup Configuration
• Create Tech Support
• Create Scheduler
• Create Remote Location
• Administrative—Displays the following options:
• Create Login Domain
• Create Provider
• Create Security Domain
• Create Role
• Create RBAC Rule
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
8
About Cisco Cloud APIC
Understanding the Cisco Cloud APIC GUI Icons
Icon
Description
• Create Certificate Authority
• Create Key Ring
• Create Local User
Figure 6: Feedback Icon
The feedback icon appears in the menu bar between
the Intent and the bookmark icons.
When clicked, the feedback panel appears.
Figure 7: Bookmark Icon
The bookmark icon appears in the menu bar between
the feedback and the system tools icons.
When clicked, the current page is bookmarked on your
system.
Figure 8: System Tools Menu-Bar Icon
The system tools menu-bar icon provides the following
options:
• Open Object Store Browser—Opens the
Managed Object Browser, or Visore, which is a
utility that is built into Cisco Cloud APIC that
provides a graphical view of the managed objects
(MOs) using a browser.
• Model Documentation—Open the Cloud APIC
Object Model Documentation window.
Figure 9: Help Menu-Bar Icon
The help menu-bar icon shows the About Cloud APIC
menu option, which provides the version information
for the Cloud APIC. The help menu-bar icon also shows
the Help Center and Welcome Screen menu options.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
9
About Cisco Cloud APIC
Understanding the Cisco Cloud APIC GUI Icons
Icon
Description
Figure 10: User Profile Menu-Bar Icon
The user profile menu-bar icon provides the following
options:
"User Preferences" which is setting for time format
Local/UTC.
• User Preferences—Allows you to set the time
format (Local or UTC) and enable or disable the
Welcome Screen at login.
• Change Password—Enables you to change the
password.
• Change SSH Key—Enables you to change the
SSH key.
• Change User Certificate—Enables you to change
the user certificate.
• Logout—Enables you to log out of the GUI.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
10
CHAPTER
3
About Cisco Cloud APIC and Google Cloud
Beginning with release 25.0(1), support is now available for Google Cloud with Cisco Cloud APIC. The
following topics in this chapter provide information on how Cisco Cloud APIC deployments work with Google
Cloud.
• Summary of Changes in Release 25.0(1), on page 11
• Locating Important Google Cloud Project Information, on page 11
• Understanding Google Cloud Deployments with Cloud APIC, on page 12
• External Network Connectivity, on page 14
• Configuring Routing and Security Policies Separately, on page 18
• Understanding VPCs and Subnets Under Google Cloud and Cloud Context Profiles Under Cloud APIC,
on page 22
• Guidelines and Limitations For Configuring Cisco Cloud APIC with Google Cloud, on page 26
Summary of Changes in Release 25.0(1)
Following is a summary of changes that are part of release 25.0(1):
• Support for Google Cloud with Cisco Cloud APIC.
• Support is available for external connectivity from Google Cloud to other external sites. See External
Network Connectivity, on page 14 for more information.
• Support for configuring routing and security policies separately. See Configuring Routing and Security
Policies Separately, on page 18 for more information.
• Cisco Cloud APIC supports using route maps to configure routing policies independent of security
policies between a pair of VRFs, where both VRFs are internal VRFs or one VRF is an internal and
the other VRF is an external VRF. See Configuring Routing Policies, on page 18 for more
information.
• Support for configuring security policies using firewall rules. See Configuring Security Policies,
on page 19 for more information.
Locating Important Google Cloud Project Information
After you create a Google Cloud project, that project will be assigned three unique identifiers:
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
11
About Cisco Cloud APIC and Google Cloud
Understanding Google Cloud Deployments with Cloud APIC
• Project name
• Project ID
• Project number
You will need these three identifiers for your Google Cloud project at various points in the Cisco Cloud APIC
configuration process. To locate the Project Info pane with these Google Cloud project identifiers, log into
your Google Cloud account and select your particular Google Cloud project in the Select a project window.
The Dashboard for this project is displayed, which provides the Project Info pane with these three unique
identifiers for your Google Cloud project.
Understanding Google Cloud Deployments with Cloud APIC
Google Cloud organizes resources in a way that resembles a file system, where:
• The Organization at the top level can have multiple Folders.
• Every Folder can contain other Folders, or can contain Projects, where every Project has a unique ID.
• Cloud resources (such as VMs, VPCs, and subnets) are contained within a Project.
While the Organization and Folder levels are useful areas to understand from the Google Cloud perspective,
the Project level is the most relevant from the Cloud APIC perspective.
Each Cloud APIC tenant is mapped one-to-one to a Google Cloud Project, which means that:
• A Cloud APIC tenant cannot span multiple Google Cloud Projects
• There cannot be more than one Cloud APIC tenant in a Google Cloud Project
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
12
About Cisco Cloud APIC and Google Cloud
Understanding Google Cloud Deployments with Cloud APIC
With Cloud APIC, Google Cloud provides access to Projects using Service Accounts. These accounts are
meant for applications that need to access Google Cloud services. They can be used to run and deploy Cloud
APIC and to push policies for other tenants. Service accounts used in applications running within Google
Cloud do not need credentials, whereas applications that are run external to Google Cloud need a pre-generated
private key. Service Accounts reside in one Google Cloud Project, but they can also be given access to manage
policies for other Projects (for Cloud APIC, other tenants).
The following sections provide more information on different ways that Cloud APIC tenants can be configured
with Google Cloud:
• User Tenants With Managed Credentials, on page 13
• User Tenants With Unmanaged Credentials, on page 13
User Tenants With Managed Credentials
This type of user tenant has the following characteristics:
• This tenant account is managed by the Cisco Cloud APIC.
• You will first choose Managed Identity in the Cisco Cloud APIC GUI as part of the tenant configuration
process for this type of user tenant.
• After you have configured the necessary parameters in the Cisco Cloud APIC, you must then set the
necessary roles for this tenant in Google Cloud. Add the service account created by the Cloud APIC as
an IAM user with the following rules:
• Cloud Functions Service Agent
• Compute Instance Admin (v1)
• Compute Network Admin
• Compute Security Admin
• Logging Admin
• Pub/Sub Admin
• Storage Admin
For instructions on creating this sort of tenant, see Creating a Managed Tenant Using the Google Cloud and
Cisco Cloud APIC GUIs, on page 44.
User Tenants With Unmanaged Credentials
This type of user tenant has the following characteristics:
• This tenant account is not managed by the Cisco Cloud APIC.
• Before configuring the necessary parameters in the Cisco Cloud APIC for this type of tenant, you must
first download the JSON file that contains the necessary private key information from Google Cloud for
the service account associated with this tenant.
• You will then choose Unmanaged Identity in the Cisco Cloud APIC GUI as part of the tenant
configuration process for this type of user tenant. As part of the configuration process for this type of
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
13
About Cisco Cloud APIC and Google Cloud
External Network Connectivity
tenant in Cisco Cloud APIC, you will provide the following information from the downloaded JSON
file:
• Key ID
• RSA Private Key
• Client ID
• Email
For instructions on creating this sort of tenant, see Creating an Unmanaged Tenant Using the Google Cloud
and Cisco Cloud APIC GUIs, on page 46.
External Network Connectivity
Support is available for external connectivity between a Google Cloud site and non-Google Cloud sites or an
external device. You can have this IPv4 connection by creating a VPN connection between a Google Cloud
router and an external device, including a CSR.
The following sections provide more information on the components that allow for the new external network
connectivity provided in release 25.0(1).
External VRF
An external VRF is a unique VRF that does not have any presence in the cloud. This VRF is not referred to
in any cloud context profile used by Cisco Cloud APIC.
An external VRF represents an external network that is connected to other cloud sites or to on-premises sites.
Multiple cloud VRFs can leak routes to an external VRF or can get the routes from an external VRF. When
an external network is created on an external VRF, inter-VRF routing is set up so that routes received and
advertised on the external network are received or advertised on the external VRF.
Cloud Native Routers
When configuring Cisco Cloud APIC with Google Cloud, the infra VPC uses Google Cloud native routers
(Cloud Router and Cloud VPN gateway) to create IPsec tunnels and BGP sessions to on-premises sites, other
cloud sites, or any remote device. Only IPv4 connectivity is supported for this type of connectivity using
cloud native routers, where IPv4 sessions are created on an external VRF.
Google Cloud supports VPN connections both with static routes and with BGP. To create a VPN connection
with BGP, Cisco Cloud APIC needs both a Cloud Router and a VPN gateway. A VPC can have multiple
Cloud Routers and VPN gateways. However, Google Cloud has a restriction that both the Cloud Routers and
the VPN gateways must be in the same region and in the same VPC. In addition, Cisco Cloud APIC has a
restriction where only one cloud router and one cloud VPN gateway is supported per region.
VPN Communication
When configuring Cisco Cloud APIC with Google Cloud, the infra VPC is used to host the Cisco Cloud APIC
and to host the VPN connections to external devices and sites. However, the infra VPC is not used as a transit
to implement spoke-to-spoke communication. Instead, when configuring Cisco Cloud APIC with Google
Cloud, spoke-to-spoke communication is done though spoke-to-spoke VPC peering.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
14
About Cisco Cloud APIC and Google Cloud
Hub Network Configuration
The infra VPC uses the Google Cloud Router and Google Cloud VPN Gateway to create IPsec tunnels and
BGP sessions to on-premises sites or to other cloud sites. Spoke VPCs peer with the infra VPC to share the
VPN connections to external sites, where:
• Routes received on the VPN connections are leaked to the spoke VPCs
• Spoke VPC routes are advertised on the VPN connections
Using inter-VRF routing, the route is leaked between the external VRF of the VPN connections and the cloud
local spoke VRFs.
A VPN gateway has two interfaces, and Google Cloud allocates public IP addresses to each of the interfaces.
While the Google Cloud VPN gateway could have one or two interfaces, Cisco Cloud APIC only supports
VPN gateways with two interfaces because two interfaces are required to achieve high availability.
Hub Network Configuration
Starting with release 25.0(1), rather than creating the hub network in a region based on the spoke attachments,
the cloudRegionName MOs under a cloudtemplateHubNetworkName represents the regions where the hub
network will be deployed, where cloudtemplateHubNetworkName represents a Google Cloud Router. For
release 25.0(1), Cisco Cloud APIC has a restriction of only one cloudtemplateHubNetworkName.
The hub network provides a way for establishing connectivity to an external site. Creating a hub network is
a pre-requisite to creating an external network. Starting with release 25.0(1), you can create a hub network
by specifying a name for the hub and the regions where the hub network should be deployed. For example,
you may choose to deploy the hub network in us-central1 and us-east1. Cisco Cloud APIC will provision the
Google Cloud Routers in these regions. Remember that only one hub network can be created, which means
that Cisco Cloud APIC will only deploy one Cloud Router per region.
The following POST shows an example of network connectivity beginning with release 25.0(1) using this
model. The cloudtemplateHubNetwork is used to create the hub network. In this example, the hub network
is deployed in four regions. External networks are created from each of the four regions using the
cloudtemplateExtNetwork MOs.
<polUni>
<fvTenant name="infra" status="">
<fvCtx name="extv1" pcEnfPref="enforced" status=""/>
<fvCtx name="extv2" pcEnfPref="enforced" status=""/>
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
15
About Cisco Cloud APIC and Google Cloud
Hub Network Configuration
<fvCtx name="extv3" pcEnfPref="enforced" status=""/>
<cloudtemplateInfraNetwork name="default" vrfName="overlay-1"
hostRouterMode="manual" status="">
<cloudtemplateIpSecTunnelSubnetPool subnetpool= "169.254.7.0/24" poolname="pool1"
/>
<cloudtemplateIpSecTunnelSubnetPool subnetpool= "169.254.8.0/24" poolname="pool2"
/>
<cloudtemplateIpSecTunnelSubnetPool subnetpool= "169.254.10.0/24"
poolname="pool3" />
<cloudtemplateHubNetwork name="default" status="" >
<cloudtemplateHubNetworkName name="foo1" asn="64514" status="">
<cloudRegionName provider="gcp" region="us-west4" status="" />
<cloudRegionName provider="gcp" region="us-west2" status="" />
<cloudRegionName provider="gcp" region="us-east1" status="" />
<cloudRegionName provider="gcp" region="us-west1" status=""/>
</cloudtemplateHubNetworkName>
</cloudtemplateHubNetwork>
<cloudtemplateIntNetwork name="default">
<cloudRegionName provider="gcp" region="us-west1">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
<cloudRegionName provider="gcp" region="us-west2">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
<cloudRegionName provider="gcp" region="us-east1">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
<cloudRegionName provider="gcp" region="us-west4">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
</cloudtemplateIntNetwork>
<cloudtemplateExtNetwork name="default">
</cloudtemplateExtNetwork>
<cloudtemplateExtNetwork name="extnwfoo1" vrfName="extv1" hubNetworkName="foo1"
vpnRouterName="default" status="">
<cloudRegionName provider="gcp" region="us-west1" status=""/>
<cloudtemplateVpnNetwork name="onprem01" remoteSiteId="1" status="">
<cloudtemplateIpSecTunnel peeraddr="128.1.1.1" preSharedKey="abcd"
poolname="pool1" status="">
<cloudtemplateBgpIpv4 peeraddr="0.0.0.0/0" peerasn="64529" status=""/>
</cloudtemplateIpSecTunnel>
</cloudtemplateVpnNetwork>
</cloudtemplateExtNetwork>
<cloudtemplateExtNetwork name="extnwfoo2" vrfName="extv2" hubNetworkName="foo1"
vpnRouterName="default" status="">
<cloudRegionName provider="gcp" region="us-west2" status=""/>
<cloudtemplateVpnNetwork name="onprem02" remoteSiteId="2" status="">
<cloudtemplateIpSecTunnel peeraddr="128.1.1.2" preSharedKey="def"
poolname="pool2" status="">
<cloudtemplateBgpIpv4 peeraddr="0.0.0.0/0" peerasn="64529" status=""/>
</cloudtemplateIpSecTunnel>
</cloudtemplateVpnNetwork>
</cloudtemplateExtNetwork>
<cloudtemplateExtNetwork name="extnwfoo3" vrfName="extv3" hubNetworkName="foo1"
vpnRouterName="default" status="">
<cloudRegionName provider="gcp" region="us-east1" status=""/>
<cloudtemplateVpnNetwork name="onprem03" remoteSiteId="3" status="">
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
16
About Cisco Cloud APIC and Google Cloud
Hub Network Configuration
<cloudtemplateIpSecTunnel peeraddr="128.1.1.3" preSharedKey="abc"
poolname="pool3" status="">
<cloudtemplateBgpIpv4 peeraddr="0.0.0.0/0" peerasn="64529" status=""/>
</cloudtemplateIpSecTunnel>
</cloudtemplateVpnNetwork>
</cloudtemplateExtNetwork>
</cloudtemplateInfraNetwork>
</fvTenant>
</polUni>
In this example POST:
• cloudtemplateExtNetwork: You can have multiple cloudtemplateExtNetwork entries, each with a
unique name, that represent an external network on an external VRF.
Within the cloudtemplateExtNetwork area are the following fields:
• vrfName: This property represents the VRF used for the external network (for example, a transport
VRF). Multiple remote sites can use the same transport VRF, which means that all of these remotes
sites are treated as one VRF on the cloud and all of the remote sites receive the same routes from
the cloud.
• hubNetworkName: This property represents the name of the hub network used by this external network.
This name refers to one of the hub networks created in the cloudtemplateHubNetworkName area.
• vpnRouterName: This property represents the name of the VPN router used by this external network.
This name refers to the VPN router created by cloudtemplateVpnRouter.
In addition, an external network can be deployed in multiple regions, and a router used on the external
network should be deployed in those regions (in other words, hubNetworkName and vpnRouterName
should exist in those regions).
• cloudtemplateVpnNetwork: This MO represents a remote site.
Within the cloudtemplateVpnNetwork area is the remoteSiteId field. This property represents the
remote site ID.
• cloudtemplateVpnRouter: This MO translates to a Google Cloud VPN gateway. For release 25.0(1),
only one cloudtemplateVpnRouter is allowed, with the name default.
• cloudtemplateIpSecTunnel: This MO represents a remote peer.
• cloudtemplateBgpIpv4: This MO represents a remote site IPv4 BGP peer.
If the peeraddr entry under cloudtemplateBgpIpv4 has the default address (0.0.0.0/0), then the remote
BGP peer is assumed to be the inner address of the tunnel on the remote device.
Note that the model above supports the following:
• Both ikev1 and ikev2 to an external device.
• Multiple cloudtemplateIpSecTunnelSubnetPool subnet pools. The allowed IP ranges in the
cloudtemplateIpSecTunnelSubnetPool subnet pools is dependent on the cloud provider and use case.
For example, 169.254.0.0/16 or a lesser subnet of it is supported for Google Cloud VPN connections.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
17
About Cisco Cloud APIC and Google Cloud
Configuring Routing and Security Policies Separately
Configuring Routing and Security Policies Separately
To allow communication between two endpoints in different VRFs, you need to establish routing and security
policies separately:
• Routing policies: Policies used to define routes to establish traffic flow
• Security policies: Rules used for security purposes, such as zoning rules, security-group rules, ACLs,
and so on
For Google Cloud, routing must be configured independent of security. In other words, for Google Cloud,
"contracts" are used only for security. To configure routing, you must configure route-maps.
Configuring Routing Policies
Using inter-VRF routing, you can configure an independent routing policy to specify which routes to leak
between a pair of VRFs. To establish routing, you must configure route maps between a pair of VRFs.
For situations where you can use route maps to set which routes to leak between a pair of VRFs, the following
types of VRFs are used for inter-VRF routing:
• External VRF is a VRF that is associated with one or more external networks.
• Internal VRF is a VRF that has one or more cloud context profiles or cloud subnets associated with it.
When configuring inter-VRF routing with these types of VRFs:
• Between a pair of internal VRFs, you must always leak all routes.
• From an internal VRF to an external VRF, you can leak specific routes or all routes.
• From an external VRF to an internal VRF, you must leak all routes.
Guidelines and Restrictions
The following guidelines apply when using inter-VRF routing to leak routes between a pair of VRFs using
route maps:
• Routes are always leaked bi-directionally between two VRFs. For every route leak entry from one
tenant/VRF under another tenant/VRF, there must be a corresponding route leak entry going in the
opposite direction.
For example, assume there are two tenants (t1 and t2) and two corresponding VRFs (v1 and v2). For
every route leak entry t1:v1 under the VRF t2:v2, there must be a corresponding route leak entry t2:v2
under the VRF t1:v1.
• Once you associate an external VRF with an external network, if you want to change the external VRF,
you need to delete the external network and then recreate the external network with the new external
VRF.
• You cannot configure "smaller" prefixes to be leaked while a "larger" prefix is already being leaked. For
example, configuring the 10.10.10.0/24 prefix will be rejected if you already have the 10.10.0.0/16 prefix
configured to be leaked. Similarly, if you configure the 0.0.0.0/0 (leak all) prefix, no other prefix will
be allowed to be configured.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
18
About Cisco Cloud APIC and Google Cloud
Configuring Security Policies
Configuring Security Policies
While an EPG in Cisco Cloud APIC corresponds to security groups in AWS and Azure, there is no equivalent
corresponding component in Google Cloud for an EPG. The closest equivalent in Google Cloud is a combination
of firewall rules and network tags.
The firewall resource in Google Cloud is global to the project (tenant). Firewall rules are associated with a
single VPC and their scope applies to the entire VPC globally. The scope of the firewall rule is further defined
by the Target parameter. In other words, the set of instances that a rule is applied to can be selected by one
or more of the following Target types:
• Network tags: Network tags are key strings that drive the VM’s firewall and routing configuration on
Google Cloud. Instances (for example, VMs) can be tagged with unique strings. Firewall rules are applied
to all instances with equal tags. Multiple tag values act as a logical ‘or’ operator, where the firewall rule
is applied as long as at least one tag matches.
• All instances in the network: The firewall rule applies to all instances in the VPC.
Firewall rules also identify the source and destination of the traffic. Depending on whether the rule is for
ingress traffic (going to a VM) or egress traffic (leaving a VM), the source and destination fields accept
different values. The following list provides more information on those values:
• Ingress rules:
• Source: Can be identified using:
• Network tags
• IP addresses
• A combination of IP addresses and network tags with a logical ‘or’ operator
• Destination: The Target parameter identifies the destination instances
• Egress rules:
• Source: The Target parameter identifies the source instances
• Destination: Can be identified using only IP addresses (not network tags)
How Cisco Cloud APIC Implements Firewall Rules With Google Cloud
The following list describes how Cisco Cloud APIC implements firewall rules with Google Cloud :
• Global resources: VPCs and firewalls in Google Cloud are global resources, so Cisco Cloud APIC does
not have to program firewall rules for endpoints that span multiple regions. The same firewall rules apply
for any region where the endpoint resides.
• Firewall egress rules and network tags: Firewall egress rules do not support network tags as a destination
field, so you must list individual IP addresses for endpoints.
• Source tags in firewall ingress rules and alias IP ranges: Firewall ingress rules do not include the
alias IP ranges of VMs matching the network tags used in the source field.
• Priority fields in firewall rules: Google Cloud evaluates firewall rules following their priority values.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
19
About Cisco Cloud APIC and Google Cloud
Configuring Security Policies
Given that Google Cloud firewall rules follow a priority list, Cisco Cloud APIC configures a pair of low-priority
deny-all ingress and egress rules when the VPC is created. Afterwards, Cisco Cloud APIC configures rules
that open traffic according to the EPG’s contracts with higher priority. Therefore, if there is no explicit rule
that allows certain traffic as a result of an EPG contract, the low-priority rule matches and the default behavior
is deny-all.
Endpoints and Endpoint Selectors
On the Cisco Cloud APIC, a cloud EPG is a collection of endpoints that share the same security policy. Cloud
EPGs can have endpoints in one or more subnets and are tied to a VRF.
The Cisco Cloud APIC has a feature called endpoint selector, which is used to assign an endpoint to a Cloud
EPG. The endpoint selector is essentially a set of rules run against the cloud instances assigned to the Google
Cloud VPC managed by Cisco ACI. Any endpoint selector rules that match endpoint instances will assign
that endpoint to the Cloud EPG. The endpoint selector is similar to the attribute-based microsegmentation
available in Cisco ACI.
Following are the types of endpoint selectors available for the two types of cloud EPGs:
• Application EPGs:
• IP: Used to select by the IP address or subnet.
• Region: Used to select by the region of the endpoint.
• Custom: Used to select by a custom tag or label. For example, if you added a Location tag in Google
Cloud, you might create the custom tag Location in this field to match the Location tag that you
added in Google Cloud earlier.
• External EPGs:
Subnet: The subnet selector is a type of endpoint selector where the match expression uses the IP address
of a subnet, so an entire subnet is assigned as being part of the EPG. Essentially, when you use the subnet
selector as the endpoint selector, all of the endpoints within that subnet belongs to the associated EPG.
When using Cisco Cloud APIC endpoint selectors with Google Cloud, a network tag is applied that associates
the EPG to the matching VM in Google Cloud. Once the network tag is configured in the VM, Google Cloud
applies the firewall rules for the VM’s traffic.
VMs on Google Cloud also support labels. Labels are key-value pairs that are meant to be an organizational
tool. The custom endpoint selector in Cisco Cloud APIC recognizes the labels assigned to the VMs in Google
Cloud.
Cisco Cloud APIC reserves a unique network tag string for each EPG. In Google Cloud, this value is used as
the target field in the firewall rules created for the EPG. When a new VM matches an endpoint selector of the
EPG, Cisco Cloud APIC appends this value to the existing VM’s network tags. In addition, the EPG’s network
tag is used in the source field of the Google Cloud firewall rules.
For example, consider the sample configuration below:
<cloudEPg name="epg1" >
<cloudRsCloudEPgCtx tnFvCtxName="v1"/>
<fvRsProv tnVzBrCPName="httpSSHFamily"/>
<cloudEPSelector name="web-selector" matchExpression="custom:server=='web'"/>
<cloudEPSelector name="web-selector" matchExpression="custom:server==backend"/>
</cloudEPg>
<cloudEPg name="epg2" status="">
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
20
About Cisco Cloud APIC and Google Cloud
Configuring Security Policies
<cloudRsCloudEPgCtx tnFvCtxName="v1"/>
<fvRsCons tnVzBrCPName="httpSSHFamily"/>
<cloudEPSelector name="database-selector" matchExpression="custom:server=='database'"/>
</cloudEPg>
Assuming there are three endpoints in the VPC with the following configuration, Cisco Cloud APIC configures
the following network tags, where the Cisco Cloud APIC-configured network tags are in the following format:
capic-<app-profile-name>-<epg-name>
Endpoint
Application Profile EPG
EP1
First application
profile (app01)
EP2
Second application Second EPG
profile (app02)
(epg02)
EP3
Primary IP
Labels
Cloud
APIC-Configured
Network Tags
server:web
capic-app01-epg01
20.0.0.1
server:backend
capic-app02-epg02
Second application Third EPG (epg03) 30.0.0.1
profile (app02)
server:database
capic-app02-epg03
First EPG (epg01) 10.0.0.1
Cisco Cloud APIC needs admin permission over the VMs in order to set their network tags. This permission
is granted by the Compute Instance Admin role.
There might be cases where Cisco Cloud APIC does not have this permission and cannot manage the VM’s
tags. In those scenarios, you can configure the network tags in your VMs first and then provide the proper
endpoint selector configuration to Cisco Cloud APIC later on.
To see firewall rules:
• In Google Cloud: In your Google Cloud account, navigate to VPC Network > Firewall.
• If the VM is part of an EPG, you can find the endpoints by expanding a firewall rule and then
viewing the multiple entries shown in the Filters column. which are the endpoints.
• Use the entry in the Type column to determine if a particular firewall rule is an ingress or an egress
firewall rule.
• If the firewall rule is an ingress type, then traffic is being sent to these endpoints.
• If the firewall rule is an egress type, then these entries show where it can receive the traffic.
• In Cisco Cloud APIC: Firewall rules are associated with VPCs, so navigate to Cloud Resources >
VPCs, then double-click on a VPC to get the detail screen. Then click on the Cloud Resources tab; there
you will see the ingress and egress rules.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
21
About Cisco Cloud APIC and Google Cloud
Understanding VPCs and Subnets Under Google Cloud and Cloud Context Profiles Under Cloud APIC
UnderstandingVPCsandSubnetsUnderGoogleCloudandCloud
Context Profiles Under Cloud APIC
In Google Cloud, a VPC is a global resource, whereas a subnet is regional and spans every availability zone
in the region, but a subnet cannot overlap with other subnets in the same VPC or in peered VPCs.
Each subnet must have exactly one primary CIDR block (IP range) and can have up to 30 secondary CIDR
blocks. There can be up to 300 primary and secondary CIDRs in a VPC. The NIC for each VM gets its primary
internal IP address from the primary CIDR block, whereas secondary IP ranges can only be used for alias IP
ranges, which is a Google Cloud organizational tool to assign address pools to containers or applications
running inside the VM.
The following provides more information on the associations between Cisco Cloud APIC objects and Google
Cloud objects:
• One-to-one mapping of Google Cloud VPC to Cisco Cloud APIC VRF: A Google Cloud VPC is
deployed for each Cisco Cloud APIC VRF (fvCtx object). Cloud context profiles (cloudCtxProfile
object) define the set of regional subnets to deploy. Every cloud context profile in the same VRF maps
to the same VPC.
• Google Cloud subnets and their secondary IP ranges: Cisco Cloud APIC deploys a subnet with primary
and secondary IP ranges using Cisco Cloud APIC CIDR and subnet objects. The Cisco Cloud APIC
subnet object is used to represent an IP range and the Cisco Cloud APIC CIDRs’s primary property tells
whether it is primary or secondary. Secondary Cisco Cloud APIC subnet objects are associated with the
corresponding primary one, because only the latter deploys the actual subnet in Google Cloud.
Understanding VPC Groups
The cloud context profile is used within Cisco Cloud APIC as a mapping tool for a VPC, where one cloud
context profile is associated with one VPC. The cloud context profile also contains information on the region
association, where the cloud context profile is used to determine which region a VPC gets deployed to.
In Google Cloud, when you want to create a VPC, you might have to create multiple cloud context profiles
through Cisco Cloud APIC if you want to deploy subnets in multiple regions. However, VPCs are global in
nature with Google Cloud, where a VPC spans all the regions.
Therefore, a property called VPC group (vpcGroup) is available within the cloud context profile that allows
Cisco Cloud APIC to group multiple cloud context profiles together to form one VPC. Multiple cloud context
profiles that are associated with each other using the VPC group feature form the VPC construct within Google
Cloud, where the VPC group name is shown in Google Cloud.
Since only one Google Cloud VPC is allowed within one Cisco Cloud APIC VRF for release 25.0(1), you
must use the same name for the VPC group property for each cloud context profile listed in a VRF. Profiles
having the same VPC group name reside in the same VPC.
The scope of this matching mechanism is at the tenant level. The same values can be reused across tenants,
but they implicitly define different groups, since they are also part of different Google Cloud Projects.
Cisco Cloud APIC deploys a VPC for each distinct fvCtx, cloudRsToCtx and vpcGroup tuple, as long as there
is at least one cloudSubnet defined. The cloud context profile becomes a container of regional resources,
such as subnets, associated to a VRF, and it no longer maps to a VPC.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
22
About Cisco Cloud APIC and Google Cloud
Understanding VPCs and Subnets Under Google Cloud and Cloud Context Profiles Under Cloud APIC
The example below defines two context profiles (c1 and c2) inside the same VRF (v1) with one VPC group
(vpc-1). This configuration deploys one VPC, where the subnets defined in profiles c1 and c2 are deployed
in that VPC because they are part of the same VPC group.
<fvTenant name="t1">
<fvCtx name="v1"/>
<cloudCtxProfile name="c1" vpcGroup="vpc-1">
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-west1" />
<cloudRsToCtx tnFvCtxName="v1"/>
<cloudCidr addr="10.0.0.0/16" primary="yes" >
<cloudSubnet ip="10.0.1.0/24">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
<cloudCtxProfile name="c2" vpcGroup="vpc-1">
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-east1" />
<cloudRsToCtx tnFvCtxName="v1"/>
<cloudCidr addr="20.0.0.0/16" primary="yes" >
<cloudSubnet ip="20.0.1.0/24">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-east1/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
</fvTenant>
Understanding Primary and Secondary Subnets and Subnet Groups
Cisco Cloud APIC deploys every subnet (cloudSubnet) in the VPC (which is identified by the tuple fvCtx,
cloudRsToCtx, and vpcGroup) in the region that is pointed to by the cloudRsCtxProfileToRegion relation.
In Google Cloud, there is no concept of a primary CIDR for the VPC, but the primary flag in the CIDR
(cloudCidr) field in the cloud context profile is available for Cisco Cloud APIC to support secondary IP
ranges. Every subnet configured under a primary CIDR will be deployed as an actual Google Cloud subnet
with the specified primary IP range (named primary subnets). For release 25.0(1) for Google Cloud, having
multiple CIDRs set as primary under a given cloud context profile (cloudCtxProfile) is supported. Therefore,
you can have more than one primary CIDR under a given cloud context profile with multiple primary subnets.
The following POST shows an example where one VPC and three subnets are deployed in Google Cloud.
<polUni>
<fvTenant name="t1">
<fvCtx name="v1"/>
<cloudCtxProfile name="c1" vpcGroup="vpc-1">
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-west1" />
<cloudRsToCtx tnFvCtxName="v1"/>
<cloudCidr addr="10.0.0.0/16" primary="yes" >
<cloudSubnet ip="10.0.1.0/24">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
<cloudSubnet ip="10.0.2.0/24">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-west/zone-default"/>
</cloudSubnet>
</cloudCidr>
<cloudCidr addr="20.0.0.0/16" primary="yes" >
<cloudSubnet ip="20.0.1.0/24">
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
23
About Cisco Cloud APIC and Google Cloud
Understanding VPCs and Subnets Under Google Cloud and Cloud Context Profiles Under Cloud APIC
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-west/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
</polUni>
In the example above, one VPC is configured for the VRF v1 with three primary subnets (10.0.1.0/24,
10.0.2.0/24, and 20.0.1.0/24) deployed in the us-west region.
A secondary CIDR contains the secondary IP ranges (called secondary subnets) that are configured in the
existing primary subnets. When designating a CIDR as either primary or secondary, it's helpful to consider
these differences between the two:
• The primary CIDR is normally the VM.
• The secondary CIDR is more of a container used for the application.
You can group together primary and secondary subnets into a subnet group. This grouping mechanism assigns
secondary subnets (for example, IP ranges) to a primary subnet, which is mapped to an actual Google Cloud
subnet. The scope of the subnet group is at the cloud context profile level. While you can have multiple cloud
context profiles within the same tenant, subnets are part of a subnet group only within the same cloud context
profile.
You will use the subnet group label to assign a unique label to a specific subnet group. If you have multiple
subnets that have the same subnet group label, then those subnets all belong to the same subnet group as long
as they are all within the same cloud context profile. Note that while the subnet group label is used within
Cisco Cloud APIC to group primary and secondary subnets, it is not used in Google Cloud.
Note the following guidelines for the primary and secondary CIDRs:
• Primary CIDR:
• Any subnet group can have at maximum of only one subnet from the primary CIDR.
• You can have multiple subnets in the primary CIDR, but all of the subnets must be in a separate
subnet group.
• Secondary CIDR: You can have multiple subnets from the secondary CIDR in the same subnet group.
The following POST shows an example where two VPCs with two subnets each in different regions and
having secondary CIDRs are deployed in Google Cloud.
<polUni>
<fvTenant name="t1">
<fvCtx name="v1"/>
<fvCtx name="v2"/>
<cloudCtxProfile name="c1" vpcGroup="vpc-1">
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-west1" />
<cloudRsToCtx tnFvCtxName="v1"/>
<cloudCidr addr="10.0.0.0/16" primary="yes" >
<cloudSubnet ip="10.0.1.0/24" subnetGroup="subnet-1">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
<cloudSubnet ip="10.0.2.0/24" subnetGroup="subnet-2">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
</cloudCidr>
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
24
About Cisco Cloud APIC and Google Cloud
Understanding VPCs and Subnets Under Google Cloud and Cloud Context Profiles Under Cloud APIC
<cloudCidr addr="40.0.0.0/16" primary="no">
<cloudSubnet ip="40.0.1.0/24" subnetGroup="subnet-1">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
<cloudCtxProfile name="c2" vpcGroup="vpc-2">
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-east1" />
<cloudRsToCtx tnFvCtxName="v2"/>
<cloudCidr addr="20.0.0.0/16" primary="yes">
<cloudSubnet ip="20.0.1.0/24" subnetGroup="subnet-1">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-east1/zone-default"/>
</cloudSubnet>
</cloudCidr>
<cloudCidr addr="30.0.0.0/16" primary="no">
<cloudSubnet ip="30.0.1.0/24" subnetGroup="subnet-1">
<cloudRsZoneAttach
tDn="uni/clouddomp/provp-gcp/region-us-east1/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
</fvTenant>
</polUni>
Note that the subnet group subnet-1 in the cloud context profile c2 is not the same subnet group in the cloud
context profile c1, because the scope of the subnet group is at the cloud context profile level.
The intent of the example above is summarized as follows:
• Tenant t1 defines VRF v1 and v2.
• Cloud context profile c1 defines the subnets in region us-west1 for VRF v1 and VPC group vpc-1. This
deploys VPC vpc-1.
• Cloud context profile c2 defines the subnets in region us-east1 for VRF v2 and VPC group vpc-2. This
deploys VPC vpc-2.
• The following subnets are deployed in VPC vpc-1 in region us-west1:
• Subnet-1 subnet group:
• Primary IP range: 10.0.1.0/24
• Secondary IP ranges: 40.0.1.0/24
• Subnet-2 subnet group:
• Primary IP range: 10.0.2.0/24
• The following subnets are deployed in VPC vpc-2 in region us-east1:
• Subnet-1:
• Primary IP range: 20.0.1.0/24
• Secondary IP ranges: 30.0.1.0/24
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
25
About Cisco Cloud APIC and Google Cloud
Guidelines and Limitations For Configuring Cisco Cloud APIC with Google Cloud
Guidelines and Limitations For Configuring Cisco Cloud APIC
with Google Cloud
Following are the guidelines and limitations when configuring Cisco Cloud APIC with Google Cloud:
• Google Cloud does not support routing based on contracts.
• External connectivity between two Google Cloud sites is not supported in release 25.0(1).
• The external VRF can be configured only in the infra tenant in Cisco Cloud APIC.
• The tenant common in Cisco Cloud APIC cannot be associated with any Google Cloud project.
• In Google Cloud, the infra VPC and spoke VPCs are connected through VPC peering.
• For release 25.0(1), in order to configure connectivity between the on-premises data center and the public
cloud, you must manually configure the remote device by downloading the external device configuration
files and manually enabling connectivity between Google Cloud and the external devices.
The external device configuration files that you download are not final configurations. Instead, the
external device configuration files are provided more as a guidance. You must manually modify the
information in the configuration files to configure the Google Cloud Router with IPSec, which is used
to create connectivity between the on-premises data center and the public cloud, where:
• The Google Cloud Router and tunnels are deployed in the infra (hub) VPC.
• For release 25.0(1), one cloud router per region is supported. Cloud routers can be deployed in a
maximum of four regions.
• Spoke VPCs peer with the infra VPC to share the VPN connections to external sites, such as the
on-premises data center.
Naming Length Restrictions Imposed By Google Cloud Firewall Rules
Google Cloud firewall rules are named resources, and Cisco Cloud APIC derives a name from the internal
policy and uses that to deploy the Google Cloud firewall rules. Cisco Cloud APIC uses the following naming
scheme for the internal policy:
{VPC-name}-{in/eg}-{target App-name}-{target EPG-name}-{contract-name}
The maximum length for a Google Cloud firewall rule name is 62 characters. This imposes a restriction on
the names that you can use when configuring the following Cisco Cloud APIC components whose names are
used in the Google Cloud firewall rule name:
• VPC group
• Application profile
• Application EPG or external EPG
• Contract
Knowing that the maximum number of characters is 62 for a Google Cloud firewall rule name, and taking
into account the fixed areas in the string that makes up the Google Cloud firewall rule name:
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
26
About Cisco Cloud APIC and Google Cloud
Guidelines and Limitations For Configuring Cisco Cloud APIC with Google Cloud
• Hyphens (4 characters total)
• in (ingress) or eg (egress) value (2 characters)
That means that the total number of characters available for the combined names of all of the individual Cisco
Cloud APIC components cannot exceed 56:
62 - 4 (number of hypens) - 2 (in or eg characters) = 56 characters
So, the sum of the lengths of the names of the VPC group, application profile, application EPG or external
EPG, and contract must be smaller than 56 characters. On average, this allows for roughly 14 characters for
the name of each component.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
27
About Cisco Cloud APIC and Google Cloud
Guidelines and Limitations For Configuring Cisco Cloud APIC with Google Cloud
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
28
CHAPTER
4
Cisco Cloud APIC Policy Model
• About the ACI Policy Model, on page 29
• Policy Model Key Characteristics, on page 29
• Logical Constructs, on page 30
• The Cisco ACI Policy Management Information Model, on page 31
• Tenants, on page 32
• Cloud Context Profile, on page 33
• VRFs, on page 33
• Cloud Application Profiles, on page 34
• Cloud Endpoint Groups, on page 35
• Contracts, on page 36
• About the Cloud Template, on page 38
• Managed Object Relations and Policy Resolution, on page 40
• Default Policies, on page 41
About the ACI Policy Model
The ACI policy model enables the specification of application requirements policies. The Cisco Cloud APIC
automatically renders policies in the cloud infrastructure. When you or a process initiates an administrative
change to an object in the cloud infrastructure, the Cisco Cloud APIC first applies that change to the policy
model. This policy model change then triggers a change to the actual managed item. This approach is called
a model-driven framework.
Policy Model Key Characteristics
Key characteristics of the policy model include the following:
• As a model-driven architecture, the software maintains a complete representation of the administrative
and operational state of the system (the model). The model applies uniformly to cloud infrastructure,
services, system behaviors, and virtual devices attached to the network.
• The logical and concrete domains are separated; the logical configurations are rendered into concrete
configurations by applying the policies in relation to the available resources. No configuration is carried
out against concrete entities. Concrete entities are configured implicitly as a side effect of the changes
to the Cisco Cloud policy model.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
29
Cisco Cloud APIC Policy Model
Logical Constructs
• The system prohibits communications with newly connected endpoints until the policy model is updated
to include the new endpoint.
• Network administrators do not configure logical system resources directly. Instead, they define logical
(hardware-independent) configurations and the Cisco Cloud APIC policies that control different aspects
of the system behavior.
Managed object manipulation in the model relieves engineers from the task of administering isolated, individual
component configurations. These characteristics enable automation and flexible workload provisioning that
can locate any workload anywhere in the infrastructure. Network-attached services can be easily deployed,
and the Cisco Cloud APIC provides an automation framework to manage the lifecycle of those network-attached
services.
Logical Constructs
The policy model manages the entire cloud infrastructure, including the infrastructure, authentication, security,
services, applications, cloud infrastructure, and diagnostics. Logical constructs in the policy model define
how the cloud infrastructure meets the needs of any of the functions of the cloud infrastructure. The following
figure provides an overview of the ACI policy model logical constructs.
Figure 11: ACI Policy Model Logical Constructs Overview
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
30
Cisco Cloud APIC Policy Model
The Cisco ACI Policy Management Information Model
cloud infrastructure-wide or tenant administrators create predefined policies that contain application or shared
resource requirements. These policies automate the provisioning of applications, network-attached services,
security policies, and tenant subnets, which puts administrators in the position of approaching the resource
pool in terms of applications rather than infrastructure building blocks. The application needs to drive the
networking behavior, not the other way around.
The Cisco ACI Policy Management Information Model
The cloud infrastructure comprises the logical components as recorded in the Management Information Model
(MIM), which can be represented in a hierarchical management information tree (MIT). The Cisco Cloud
APIC runs processes that store and manage the information model. Similar to the OSI Common Management
Information Protocol (CMIP) and other X.500 variants, the Cisco Cloud APIC enables the control of managed
resources by presenting their manageable characteristics as object properties that can be inherited according
to the location of the object within the hierarchical structure of the MIT.
Each node in the tree represents a managed object (MO) or group of objects. MOs are abstractions of cloud
infrastructure resources. An MO can represent a concrete object, such as a cloud router, adapter, or a logical
object, such as an application profile, cloud endpoint group, or fault. The following figure provides an overview
of the MIT.
Figure 12: Cisco ACI Policy Management Information Model Overview
The hierarchical structure starts with the policy universe at the top (Root) and contains parent and child nodes.
Each node in the tree is an MO and each object in the cloud infrastructure has a unique distinguished name
(DN) that describes the object and locates its place in the tree.
The following managed objects contain the policies that govern the operation of the system:
• A tenant is a container for policies that enable an administrator to exercise role-based access control.
The system provides the following four kinds of tenants:
• The administrator defines user tenants according to the needs of users. They contain policies that
govern the operation of resources such as applications, databases, web servers, network-attached
storage, virtual machines, and so on.
• Although the system provides the common tenant, it can be configured by the cloud infrastructure
administrator. It contains policies that govern the operation of resources accessible to all tenants,
such as firewalls, load balancers, intrusion detection appliances, and so on.
• The infrastructure tenant is provided by the system but can be configured by the cloud infrastructure
administrator. It contains policies that govern the operation of infrastructure resources. It also enables
a cloud infrastructure provider to selectively deploy resources to one or more user tenants.
Infrastructure tenant policies are configurable by the cloud infrastructure administrator.
• The cloud infra policies enable you to manage on-premises and inter-region connectivity when setting
up the Cisco Cloud APIC. For more information, see the Cisco Cloud APIC Installation Guide.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
31
Cisco Cloud APIC Policy Model
Tenants
• Cloud inventory is a service that enables you to view different aspects of the system using the GUI. For
example, you can view the regions that are deployed from the aspect of an application or the applications
that are deployed from the aspect of a region. You can use this information for cloud resource planning
and troubleshooting.
• Access, authentication, and accounting (AAA) policies govern user privileges, roles, and security domains
of the Cisco Cloud ACI cloud infrastructure. For more information, see Cisco Cloud APIC Security, on
page 121
The hierarchical policy model fits well with the REST API interface. When invoked, the API reads from or
writes to objects in the MIT. URLs map directly into distinguished names that identify objects in the MIT.
Any data in the MIT can be described as a self-contained structured tree text document encoded in XML or
JSON.
Tenants
A tenant (fvTenant) is a logical container for application policies that enable an administrator to exercise
domain-based access control. A tenant represents a unit of isolation from a policy perspective, but it does not
represent a private network. Tenants can represent a customer in a service provider setting, an organization
or domain in an enterprise setting, or just a convenient grouping of policies. The following figure provides
an overview of the tenant portion of the management information tree (MIT).
Figure 13: Tenants
Tenants can be isolated from one another or can share resources. The primary elements that the tenant contains
are filters, contracts, Virtual Routing and Forwarding (VRF) instances, cloud context profiles, Google Cloud
provider configurations, and cloud application profiles that contain cloud endpoint groups (cloud EPGs).
Entities in the tenant inherit its policies. VRFs are also known as contexts; each VRF can be associated with
multiple cloud context profiles. A cloud context profile, in conjunction with a VRF, tenant and region,
represents a resource group in Google Cloud. A VPC is created inside the resource group based on the VRF
name.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
32
Cisco Cloud APIC Policy Model
Cloud Context Profile
Tenants are logical containers for application policies. The cloud infrastructure can contain multiple tenants.
The ACI cloud infrastructure supports IPv4 and dual-stack configurations for tenant networking.
Cloud Context Profile
The cloud context profile contains information on the following Cisco Cloud APIC components:
• CIDRs
• VRFs
• EPGs
• Regions
• VPCs
• Endpoints
VRFs
A Virtual Routing and Forwarding (VRF) object (fvCtx) or context is a tenant network (called a VRF in the
Cisco Cloud APIC GUI). A tenant can have multiple VRFs. A VRF is a unique Layer 3 forwarding and
application policy domain. The following figure shows the location of VRFs in the management information
tree (MIT) and their relation to other objects in the tenant.
Figure 14: VRFs
A VRF defines a Layer 3 address domain. One or more cloud context profiles are associated with a VRF. You
can only associate one cloud context profile with a VRF in a given region. All the endpoints within the Layer
3 domain must have unique IP addresses because it is possible to forward packets directly between these
devices if the policy allows it. A tenant can contain multiple VRFs. After an administrator creates a logical
device, the administrator can create a VRF for the logical device, which provides a selection criteria policy
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
33
Cisco Cloud APIC Policy Model
Cloud Application Profiles
for a device cluster. A logical device can be selected based on a contract name, a graph name, or the function
node name inside the graph.
External VRF
Beginning with release 25.0(1), an external VRF is introduced as a new type of VRF available for Cisco
Cloud APIC. An external VRF is a unique VRF that does not have any presence in the cloud. This VRF is
not referred to in any cloud context profile used by Cisco Cloud APIC.
An external VRF represents an external network that is connected to other cloud sites or to on-premises sites.
Multiple cloud VRFs can leak routes to an external VRF or can get the routes from an external VRF. When
an external network is created on an external VRF, inter-VRF routing is set up so that routes received and
advertised on the external network are received or advertised on the external VRF.
Cloud Application Profiles
A cloud application profile (cloudAp) defines the policies, services and relationships between cloud EPGs.
The following figure shows the location of cloud application profiles in the management information tree
(MIT) and their relation to other objects in the tenant.
Figure 15: Cloud Application Profiles
Cloud application profiles contain one or more cloud EPGs. Modern applications contain multiple components.
For example, an e-commerce application could require a web server, a database server, data located in a
storage service, and access to outside resources that enable financial transactions. The cloud application profile
contains as many (or as few) cloud EPGs as necessary that are logically related to providing the capabilities
of an application.
Cloud EPGs can be organized according to one of the following:
• The application they provide, such as a DNS server or SAP application (see Tenant Policy Example in
Cisco APIC REST API Configuration Guide).
• The function they provide (such as infrastructure)
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
34
Cisco Cloud APIC Policy Model
Cloud Endpoint Groups
• Where they are in the structure of the data center (such as DMZ)
• Whatever organizing principle that a cloud infrastructure or tenant administrator chooses to use
Cloud Endpoint Groups
The cloud endpoint group (cloud EPG) is the most important object in the policy model. The following figure
shows where application cloud EPGs are located in the management information tree (MIT) and their relation
to other objects in the tenant.
Figure 16: Cloud Endpoint Groups
A cloud EPG is a managed object that is a named logical entity that contains a collection of endpoints. Endpoints
are devices that are connected to the network. They have an address (identity), a location, attributes (such as
version or patch level), and are virtual. Knowing the address of an endpoint also enables access to all its other
identity details. Cloud EPGs are fully decoupled from the physical and logical topology. Endpoint examples
include servers, virtual machines, storage services, or clients on the Internet. Endpoint membership in a cloud
EPG can be dynamic or static.
The ACI cloud infrastructure can contain the following types of cloud EPGs:
• Cloud endpoint group (cloudEPg)
• Cloud external endpoint group (cloudExtEPg)
Cloud EPGs contain endpoints that have common policy requirements such as security services. Rather than
configure and manage endpoints individually, they are placed in a cloud EPG and are managed as a group.
Policies apply to cloud EPGs, never to individual endpoints.
Regardless of how a cloud EPG is configured, cloud EPG policies are applied to the endpoints they contain.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
35
Cisco Cloud APIC Policy Model
Contracts
WAN router connectivity to the cloud infrastructure is an example of a configuration that uses a static cloud
EPG. To configure WAN router connectivity to the cloud infrastructure, an administrator configures a
cloudExtEPg cloud EPG that includes any endpoints within an associated WAN subnet. The cloud infrastructure
learns of the cloud EPG endpoints through a discovery process as the endpoints progress through their
connectivity life cycle. Upon learning of the endpoint, the cloud infrastructure applies the cloudExtEPg cloud
EPG policies accordingly. For example, when a WAN connected client initiates a TCP session with a server
within an application (cloudEPg) cloud EPG, the cloudExtEPg cloud EPG applies its policies to that client
endpoint before the communication with the (cloudEPg) cloud EPG web server begins. When the client server
TCP session ends, and communication between the client and server terminates, the WAN endpoint no longer
exists in the cloud infrastructure.
The Cisco Cloud APIC uses endpoint selectors to assign endpoints to Cloud EPGs. The endpoint selector is
essentially a set of rules that are run against the cloud instances that are assigned to the Google Cloud VPC
managed by Cisco ACI. Any endpoint selector rules that match endpoint instances assign that endpoint to the
Cloud EPG. The endpoint selector is similar to the attribute-based microsegmentation available in Cisco ACI.
Contracts
In addition to cloud EPGs, contracts (vzBrCP) are key objects in the policy model. Cloud EPGs can only
communicate with other cloud EPGs according to contract rules. The following figure shows the location of
contracts in the management information tree (MIT) and their relation to other objects in the tenant.
Figure 17: Contracts
An administrator uses a contract to select one or more types of traffic that can pass between cloud EPGs,
including the protocols and ports allowed. If there is no contract, inter-EPG communication is disabled by
default. There is no contract required for intra-EPG communication; intra-EPG communication is always
implicitly allowed.
Contracts govern the following types of cloud EPG communications:
• Between cloud EPGs (cloudEPg), both intra-tenant and inter-tenant
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
36
Cisco Cloud APIC Policy Model
Filters and Subjects Govern Cloud EPG Communications
Note
In the case of a shared service mode, a contract is required for inter-tenant
communication. A contract is used to specify static routes across VRFs, although
the tenant VRF does not enforce a policy.
• Between cloud EPGs and cloud external EPGs (cloudExtEPg)
Contracts govern the communication between cloud EPGs that are labeled providers, consumers, or both. The
relationship between a cloud EPG and a contract can be either a provider or consumer. When a cloud EPG
provides a contract, communication with the cloud endpoints in that cloud EPG can be initiated from cloud
endpoints in other cloud EPGs as long as the communication complies with the provided contract. When a
cloud EPG consumes a contract, the cloud endpoints in the consuming cloud EPG may initiate communication
with any cloud endpoint in a cloud EPG that is providing that contract.
Note
A cloud EPG can both provide and consume the same contract. A cloud EPG can also provide and consume
multiple contracts simultaneously.
Filters and Subjects Govern Cloud EPG Communications
Subject and filter managed-objects enable mixing and matching among cloud EPGs and contracts so as to
satisfy various applications or service delivery requirements. The following figure shows the location of
application subjects and filters in the management information tree (MIT) and their relation to other objects
in the tenant.
Figure 18: Subjects and Filters
Contracts can contain multiple communication rules and multiple cloud EPGs can both consume and provide
multiple contracts. A policy designer can compactly represent complex communication policies and re-use
these policies across multiple instances of an application.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
37
Cisco Cloud APIC Policy Model
About the Cloud Template
Note
Subjects are hidden in Cisco Cloud APIC and not configurable. For rules installed in Google Cloud, source
port provided in the filter entry is not taken into account.
Subjects and filters define cloud EPG communications according to the following options:
• Filters are Layer 3 to Layer 4 fields, TCP/IP header fields such as Layer 3 protocol type, Layer 4 ports,
and so forth. According to its related contract, a cloud EPG provider dictates the protocols and ports in
both the in and out directions. Contract subjects contain associations to the filters (and their directions)
that are applied between cloud EPGs that produce and consume the contract.
• Subjects are contained in contracts. A subject within a contract uses filters to specify the type of traffic
that can be communicated and how it occurs. For example, for HTTPS messages, the subject specifies
the direction and the filters that specify the IP address type (for example, IPv4), the HTTP protocol, and
the ports allowed. Subjects determine if filters are unidirectional or bidirectional. A unidirectional filter
is used in one direction. Unidirectional filters define in or out communications but not the same for both.
Bidirectional filters are the same for both; they define both in and out communications.
• ACI contracts rendered in Google Cloud constructs are always stateful, allowing return traffic.
About the Cloud Template
The cloud template provides a template that configures and manages the Cisco Cloud APIC infra network.
The template requires only the most essential elements for the configuration. From these elements, the cloud
template generates a detailed configuration necessary for setting up the Cisco Cloud APIC infra network.
However, it is not a one-time configuration generation—it is possible to add, modify, or remove elements of
the template input. The cloud template updates the resulting configuration accordingly.
One of the central things in the Google Cloud network configuration is the Virtual Private Cloud (VPC).
Google Cloud supports many regions worldwide and one VPC is specific to one region.
The cloud template accepts one or more region names and generates the entire configuration for the infra
VPCs in those regions. They are the infra VPCs. The Cisco Cloud APIC-managed object (MO) corresponding
to the Google Cloud VPC is cloudCtxProfile. For every region specified in the cloud template, it generates
the cloudCtxProfile configuration. A cloudCtxProfile is the topmost MO for all the configuration
corresponding to a region. Underneath, it has many of other MOs organized as a tree to capture a specific
configuration. The cloudCtxProfile MO for the infra VPC is generated by the cloud template. It carries
ctxProfileOwner == SYSTEM, which means that this MO is generated by the system. For the non-infra network,
it is possible to configure cloudCtxProfile directly; in this case, cloudCtxProfile carries ctxProfileOwner
== USER.
A primary property of a Google Cloud VPC is the CIDR. In Cisco Cloud APIC, you can choose and deploy
CIDRs in the user VPCs. The CIDRs for the infra VPC are provided by users to the cloud template during
the initial setup of the cloud site, and are deployed to the Google Cloud by the cloud template.
A property called createdBy is also available for the CIDR. The default value for this createdBy property is
USER.
• For all user-created CIDRs, the value for the createdBy property is set to USER.
• For cloud template-created CIDRs, the value for the createdBy property is set to SYSTEM.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
38
Cisco Cloud APIC Policy Model
About the Cloud Template
Multiple CIDR and subnet blocks can be configured on the infra VPC. You can create CIDRs and associate
subnets in the infra VPC. The cloud template subnets will be mapped to the overlay-1 VRF. All subnets in
the respective VRFs will have separate route tables in the cloud for VRF segregation.
For more information, see Creating an Application EPG Using the Cisco Cloud APIC GUI, on page 60.
The cloud template generates and manages a huge number of MOs in the cloudCtxProfile subtree including,
but not limited to, the following:
• Subnets
• Cloud routers
• IP address allocation for the cloud router interfaces
• IP address allocation and configuration for tunnels
• IP address allocation and configuration for loopbacks
Without the cloud template, you would be responsible for configuring and managing these.
The Cisco Cloud Template MO table contains a brief summary of the inputs (MOs) to the cloud template.
Table 3: Cloud Template MOs
MO
Purpose
cloudtemplateInfraNetwork
The root of the cloud template configuration.
Attributes include:
numRoutersPerRegion—The number of cloud routers
for each cloudRegionName specified under
cloudtemplateIntNetwork.
cloudtemplateIntNetwork
Contains a list of regions, which specify where you
deploy the cloud routers. Each region is captured
through a cloudRegionName child MO
cloudtemplateExtNetwork
Contains infra network configuration input that is
external of the cloud.
Contains a list of regions where cloud routers are
configured for external networking.
Each region is captured through a cloudRegionName
child MO
cloudtemplateIpSecTunnel
Captures the IP address of the IPSec peer in the ACI
on-premises site.
In Cisco Cloud APIC, the layering of MOs is slightly different from a regular Cisco APIC due to the cloud
template. In a regular Cisco APIC, you post logical MOs that go through two layers of translation:
1. Logical MO to resolved MO
2. Resolved MO to concrete MO
In Cisco Cloud APIC, there is an additional layer of translation for the infra network. This additional layer is
where the cloud template translates logical MOs in the cloudtemplate namespace to logical MOs in the cloud
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
39
Cisco Cloud APIC Policy Model
Managed Object Relations and Policy Resolution
namespace. For configurations outside of the infra network, you post logical MOs in the cloud namespace.
In this case, the MOs go through the usual two-layer translation as in the regular Cisco APIC.
Figure 19: Cloud and Cloud Template MO Conversion
Note
For information about configuring the cloud template, see Configuring Cisco Cloud APIC Components, on
page 43
Managed Object Relations and Policy Resolution
Relationship-managed objects express the relation between managed object instances that do not share
containment (parent-child) relations. MO relations are established between the source MO and a target MO
in one of the following two ways:
• An explicit relation, such as with cloudRsCloudEPgCtx, defines a relationship that is based on the target
MO distinguished name (DN).
• A named relation defines a relationship that is based on the target MO name.
The dotted lines in the following figure show several common MO relations.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
40
Cisco Cloud APIC Policy Model
Default Policies
Figure 20: MO Relations
For example, the dotted line between the cloud EPG and the VRF defines the relation between those two
MOs. In this figure, the cloud EPG (cloudEPg) contains a relationship MO (cloudRsCloudEPgCtx) that is
named with the name of the target VRF MO (fvCtx). For example, if production is the VRF name
(fvCtx.name=production), then the relation name is production
(cloudRsCloudEPgCtx.tnFvCtxName=production).
In the case of policy resolution based on named relations, if a target MO with a matching name is not found
in the current tenant, the ACI cloud infrastructure tries to resolve in the common tenant. For example, if the
user tenant cloud EPG contained a relationship MO targeted to a VRF that did not exist in the tenant, the
system tries to resolve the relationship in the common tenant. If a named relation cannot be resolved in either
the current tenant or the common tenant, the ACI cloud infrastructure attempts to resolve to a default policy.
If a default policy exists in the current tenant, it is used. If it does not exist, the ACI cloud infrastructure looks
for a default policy in the common tenant. Cloud context profile, VRF, and contract (security policy) named
relations do not resolve to a default.
Default Policies
Warning
Default policies can be modified or deleted. Deleting a default policy can result in a policy resolution process
to complete abnormally.
The ACI cloud infrastructure includes default policies for many of its core functions. Examples of default
policies include the following:
• Google Cloud provider (for the infra tenant)
• Monitoring
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
41
Cisco Cloud APIC Policy Model
Default Policies
Note
To avoid confusion when implementing configurations that use default policies, document changes made to
default policies. Be sure that there are no current or future configurations that rely on a default policy before
deleting a default policy. For example, deleting a default firmware update policy could result in a problematic
future firmware update.
A default policy serves multiple purposes:
• Allows a cloud infrastructure administrator to override the default values in the model.
• If an administrator does not provide an explicit policy, the Cisco Cloud APIC applies the default policy.
An administrator can create a default policy and the Cisco Cloud APIC uses that unless the administrator
provides any explicit policy.
The policy model specifies that an object is using another policy by having a relation-managed object (MO)
under that object and that relation MO refers to the target policy by name. If this relation does not explicitly
refer to a policy by name, then the system tries to resolve a policy that is called default. Cloud context profiles
and VRFs are exceptions to this rule.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
42
CHAPTER
5
Configuring Cisco Cloud APIC Components
• About Configuring the Cisco Cloud APIC, on page 43
• Configuring the Cisco Cloud APIC Using the GUI, on page 43
• Configuring Cisco Cloud APIC Using the REST API, on page 97
About Configuring the Cisco Cloud APIC
You create the Cisco Cloud APIC components using either the Cisco Cloud APIC GUI or the REST API.
This section explains how to create configuration, application management, operations, and administrative
components. `
Note
For information about the GUI, such as navigation and a list of configurable components, see About the Cisco
Cloud APIC GUI, on page 4.
Configuring the Cisco Cloud APIC Using the GUI
Creating a Tenant
The following sections describe now to create a managed tenant or unmanaged tenant.
As described in Understanding Google Cloud Deployments with Cloud APIC, on page 12, each Cisco Cloud
APIC tenant is mapped one-to-one to a Google Cloud project. If you do not have a Google Cloud project
created yet for your Cisco Cloud APIC tenant, follow these procedures to create a Google Cloud project:
1. Log into your Google account.
2. Navigate to IAM & Admin > Manage resources.
3. Using the Select organization drop-down list at the top of the page, choose the organization where you
want to create a project.
4. Click + CREATE PROJECT.
5. In the New Project window that appears, enter a project name and select a billing account as applicable.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
43
Configuring Cisco Cloud APIC Components
Creating a Managed Tenant Using the Google Cloud and Cisco Cloud APIC GUIs
A project name can contain only letters, numbers, single quotes, hyphens, spaces, or exclamation points,
and must be between 4 and 30 characters.
6. Enter the parent organization or folder in the Location field.
That resource will be the hierarchical parent of the new project.
7. Click CREATE.
Creating a Managed Tenant Using the Google Cloud and Cisco Cloud APIC GUIs
This section explains how to create a tenant that will be managed by Cisco Cloud APIC using the GUI.
Step 1
Create a new Google Cloud project to be associated with this Cisco Cloud APIC tenant, if necessary.
As described in Understanding Google Cloud Deployments with Cloud APIC, on page 12, each Cisco Cloud APIC tenant
is mapped one-to-one to a Google Cloud project. See Creating a Tenant, on page 43 for those procedures, if necessary.
Step 2
In the Cisco Cloud APIC GUI, navigate to Application Management > Tenants.
A table of already-configured tenants is displayed.
Step 3
Click Actions and choose Create Tenant.
The Create Tenant dialog box appears.
Step 4
Choose the appropriate options and enter the appropriate values in each field as listed in the following Create Tenant
Dialog Box Fields table then continue.
Table 4: Create Tenant Dialog Box Fields
Properties
Description
Name
Enter the name of the tenant. Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following
characters must be hyphens, lowercase letters, or digits, except the last character,
which cannot be a hyphen.
Description
Enter a description of the tenant.
Settings
Add Security Domain
To add a security domain for the tenant:
a. Click Add Security Domain. The Select Security Domains dialog appears
with a list of security domains in the left pane.
b. Click to choose a security domain.
c. Click Select to add the security domain to the tenant.
Google Cloud Project
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
44
Configuring Cisco Cloud APIC Components
Creating a Managed Tenant Using the Google Cloud and Cisco Cloud APIC GUIs
Properties
Description
Google Cloud Project ID
Enter the Google Cloud Project ID that will be associated with this Cisco Cloud
APIC tenant.
Access Type
For a tenant that will be managed by the Cisco Cloud APIC, choose Managed
Identity as the access type.
For more information, see Understanding Google Cloud Deployments with Cloud
APIC, on page 12.
Add Security Domain for Google
Cloud Project
Note
Adding a security domain for Google Cloud is optional when creating
a tenant.
To add a security domain for the account:
a. Click Add Security Domain for Google Cloud Project. The Select Security
Domains dialog appears with a list of security domains in the left pane.
b. Click to choose a security domain.
c. Click Select to add the security domain to the tenant.
Step 5
Click Save when finished.
Step 6
Because you selected Managed Identity as the access type, next set the necessary permissions for this tenant in Google
Cloud.
a) In the Google Cloud GUI, log into the Google Cloud project that is associated with this Cisco Cloud APIC tenant.
The Dashboard for the project is displayed.
b) In the left nav bar, click on IAM & Admin, then choose IAM.
The IAM window appears with several service accounts displayed.
c) Locate the service account that was created by Cisco Cloud APIC in the project that is associated with the Cisco
Cloud APIC infra account.
d) Copy the service account name.
e) Add this service account name as an IAM user in the user tenant project.
f) Set the permissions for this service account.
1. Click the pencil icon on the row for this service account.
The Edit Permissions window is displayed.
2. Click + ADD ANOTHER ROLE, then choose Cloud Functions Service Agent as the role.
You are returned to the IAM window with the service accounts displayed.
3. Click + ADD ANOTHER ROLE again, then add the remaining necessary roles for this service account.
Following is the full list of roles that you must assign to this service account, including the Cloud Functions
Service Agent that you added in the first step of this process:
• Cloud Functions Service Agent
• Compute Instance Admin (v1)
• Compute Network Admin
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
45
Configuring Cisco Cloud APIC Components
Creating an Unmanaged Tenant Using the Google Cloud and Cisco Cloud APIC GUIs
• Compute Security Admin
• Logging Admin
• Pub/Sub Admin
• Storage Admin
4. After you have added all the necessary roles, click SAVE.
You are returned to the IAM window with the service accounts displayed and the necessary roles assigned to
this service account.
Creating an Unmanaged Tenant Using the Google Cloud and Cisco Cloud APIC GUIs
This section explains how to create a tenant that will not be managed by Cisco Cloud APIC using the GUI.
Step 1
Create a new Google Cloud project to be associated with this Cisco Cloud APIC tenant, if necessary.
As described in Understanding Google Cloud Deployments with Cloud APIC, on page 12, each Cisco Cloud APIC
tenant is mapped one-to-one to a Google Cloud project. See Creating a Tenant, on page 43 for those procedures, if
necessary.
Step 2
In Google Cloud, select the Google Cloud project that will be associated with this Cisco Cloud APIC tenant, if you
have not selected it already .
Step 3
In the left nav bar, click on IAM & Admin, then choose Service Accounts.
The service accounts for this Google Cloud project are displayed.
Step 4
Select an existing service account or click + CREATE SERVICE ACCOUNT to create a new one.
Information on this service account is displayed, with the Details tab selected by default.
Step 5
Click the KEYS tab.
Step 6
Click ADD KEY > Create New Key.
A window appears, providing an option to create a private key for this service account.
Step 7
Leave the JSON key type selected, then click Create.
A window appears, saying that the private key has been saved to your computer.
Step 8
Locate the JSON file that was downloaded to your computer and move it to a secure location on your computer.
This JSON file will contain the key information that you need to fill in the fields for the unmanaged tenant.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
46
Configuring Cisco Cloud APIC Components
Creating an Unmanaged Tenant Using the Google Cloud and Cisco Cloud APIC GUIs
Step 9
In the Cisco Cloud APIC GUI, navigate to Application Management > Tenants.
A table of already-configured tenants is displayed.
Step 10
Click Actions and choose Create Tenant.
The Create Tenant dialog box appears.
Step 11
Choose the appropriate options and enter the appropriate values in each field as listed in the following Create Tenant
Dialog Box Fields table then continue.
Table 5: Create Tenant Dialog Box Fields
Properties
Description
Name
Enter the name of the tenant. Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase
letter, and all the following characters must be hyphens,
lowercase letters, or digits, except the last character, which
cannot be a hyphen.
Description
Enter a description of the tenant.
Settings
Add Security Domain
To add a security domain for the tenant:
a. Click Add Security Domain. The Select Security
Domains dialog appears with a list of security domains
in the left pane.
b. Click to choose a security domain.
c. Click Select to add the security domain to the tenant.
Google Cloud Project
Google Cloud Project ID
Enter the Google Cloud Project ID that will be associated
with this Cisco Cloud APIC tenant.
Access Type
For a tenant that will not be managed by the Cisco Cloud
APIC, choose Unmanaged Identity as the access type.
For more information, see Understanding Google Cloud
Deployments with Cloud APIC, on page 12.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
47
Configuring Cisco Cloud APIC Components
Creating an Application Profile Using the Cisco Cloud APIC GUI
Properties
Description
Key ID
Enter the information from the private_key_id field in
the JSON file that you downloaded at the beginning of
these procedures.
RSA Private Key
Enter the information from the private_key field in the
JSON file that you downloaded at the beginning of these
procedures.
Client ID
Enter the information from the client_id field in the
JSON file that you downloaded at the beginning of these
procedures.
Email
Enter the email address associated with your Google Cloud
project.
Add Security Domain for Google Cloud Project
Note
Adding a security domain for Google Cloud is
optional when creating a tenant.
To add a security domain for the account:
a. Click Add Security Domain for Google Cloud
Project. The Select Security Domains dialog appears
with a list of security domains in the left pane.
b. Click to choose a security domain.
c. Click Select to add the security domain to the tenant.
Step 12
Click Save when finished.
Creating an Application Profile Using the Cisco Cloud APIC GUI
This section explains how to create an application profile using the Cisco Cloud APIC GUI.
Before you begin
Create a tenant.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create Application Profile. The Create Application
Profile dialog box appears.
Step 4
Enter a name in the Name field.
Note the following restrictions:
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
48
Configuring Cisco Cloud APIC Components
Creating a VRF Using the Cisco Cloud APIC GUI
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters must be hyphens,
lowercase letters, or digits, except the last character, which cannot be a hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions imposed by the Google
Cloud firewall rules. Refer to Naming Length Restrictions Imposed By Google Cloud Firewall Rules, on page 26
to better understand the restriction and the total number of characters allowed for each of the Cisco Cloud APIC
components that make up the firewall rule name.
Step 5
Choose a tenant:
a) Click Select Tenant.
The Select Tenant dialog box appears.
b) From the Select Tenant dialog, click to choose a tenant in the left column then click Select.
You return to the Create Application Profile dialog box.
Step 6
Enter a description in the Description field.
Step 7
Click Save when finished.
Creating a VRF Using the Cisco Cloud APIC GUI
This section explains how to create a VRF using the Cisco Cloud APIC GUI.
Note
To configure a external VRF, you will select infra in the Tenant field below. The VRF will be identified as
a external VRF if it is:
• Configured under the infra tenant
• Associated with an external network (see Creating an External Network Using the Cisco Cloud APIC
GUI, on page 50)
• Not associated with a cloud context profile
Before you begin
Create a tenant.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create VRF. The Create VRF dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create VRF Dialog Box Fields table then continue.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
49
Configuring Cisco Cloud APIC Components
Creating an External Network Using the Cisco Cloud APIC GUI
Table 6: Create VRF Dialog Box Fields
Properties
Description
General
Enter a name for the VRF in the Name field.
Name
Note the following restrictions:
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters
must be hyphens, lowercase letters, or digits, except the last character, which cannot be a
hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions
imposed by the Google Cloud firewall rules. Refer to Naming Length Restrictions Imposed
By Google Cloud Firewall Rules, on page 26 to better understand the restriction and the
total number of characters allowed for each of the Cisco Cloud APIC components that
make up the firewall rule name.
All VRFs are assigned a vrfEncoded value. If the Tenant and VRF name combination has more
than 32 characters, then a VRF name (which also contains the tenant name) is identified in the
cloud router using the vrfEncoded value. To see the vrfEncoded value, navigate to Application
Management > VRFs subtab. Click a VRF on the right hand pane and look for Encoded VRF
Name in Cloud Router.
To choose a tenant:
Tenant
a. Click Select Tenant. The Select Tenant dialog box appears.
b. From the Select Tenant dialog, click to choose a tenant in the left column then click Select.
You return to the Create VRF dialog box.
Description
Step 5
Enter a description of the VRF.
When finished, click Save.
Creating an External Network Using the Cisco Cloud APIC GUI
This procedure describes how to create an external network. You can have a single external network that can
connect to multiple routers on the on-premises site, or you can have multiple external networks with multiple
VRFs that you can use to connect to CSRs.
Before you begin
You must have a hub network created before you can create an external network.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
50
Configuring Cisco Cloud APIC Components
Creating an External Network Using the Cisco Cloud APIC GUI
Step 1
In the left navigation bar, navigate to Application Management > External Networks.
The configured external networks are displayed. Note that because Cisco Cloud APIC supports only one hub network,
you will see only one hub network displayed in the Hub Network column.
Step 2
Click Actions, then choose Create External Network.
The Create External Network window appears.
Note
Step 3
If there is no hub network configured yet, you will see a warning at the top of the page, saying that you must
create a hub network before you can create an external network. Click the blue Cloud APIC Setup link in the
message to create a hub network, then return here. For more information on creating a hub network, see the
"Configuring Cisco Cloud APIC Using the Setup Wizard" chapter in the Cisco Cloud APIC for Google Cloud
Installation Guide, Release 25.0(x) or later.
Enter the appropriate values in each field as listed in the following Create External Network Dialog Box Fields table then
continue.
Table 7: Create External Network Dialog Box Fields
Properties
Description
General
Name
Enter the name for the external network.
VRF
This external VRF will be used for external connectivity with the on-premises CSR. You can create
multiple external VRFs for this purpose.
This VRF will be identified as an external VRF if the VRF has all three of the following characteristics:
• Configured under the infra tenant
• Associated with an external network
• Not associated with a cloud context profile
Any VRF that is associated with an external network becomes an external VRF. At that point, that external
VRF is not allowed to be created under any tenant other than the infra tenant, and that external VRF is
not allowed to be associated with a cloud context profile or subnet.
To choose an external VRF:
a. Click Select VRF.
The Select VRF dialog box appears.
b. From the Select VRF dialog, click to choose a VRF in the left column.
You can also create a VRF using the + Create VRF option.
c. Click Select.
You return to the Create External Network dialog box.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
51
Configuring Cisco Cloud APIC Components
Creating an External Network Using the Cisco Cloud APIC GUI
Properties
Description
Hub Network
The hub network is displayed automatically after you configured it in the First Time Setup.
Note
VPN Router
If there is no hub network configured yet, you must create a hub network before you can create
an external network. For more information on creating a hub network, see the "Configuring
Cisco Cloud APIC Using the Setup Wizard" chapter in the Cisco Cloud APIC for Google
Cloud Installation Guide, Release 25.0(x) or later.
This field is not editable. The default VPN router is automatically selected.
Settings
Regions
To choose a region:
a. Click Add Regions.
The Select Regions dialog box appears.
• The regions that you selected as part of the First Time Setup are displayed here.
• You can select multiple regions to bring up the cloud router in multiple regions.
b. From the Select Regions dialog, click to choose a region in the left column then click Select.
You return to the Create External Network dialog box.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
52
Configuring Cisco Cloud APIC Components
Configuring Inter-VRF Route Leaking Using the Cisco Cloud APIC GUI
Properties
Description
VPN Networks
The VPN networks entries are used for internal connectivity. All configured VPN networks will be applied
to all the selected regions.
To add a VPN network:
a. Click Add VPN Network.
The Add VPN Network dialog box appears.
b. In the Name field, enter a name for the VPN network.
c. Click + Add IPSec Peer.
Two tunnels are created for each IPSec peer entry.
d. Enter values for the following fields for the IPSec peer that you want to add:
• Public IP of IPSec Tunnel Peer
• Pre-Shared Key
• IKE Version: Select ikev1 or ikev2 for IPSec tunnel connectivity
• BGP Peer ASN
• Subnet Pool Name: Click Select Subnet Pool Name.
The Select Subnet Pool Name dialog box appears. Select one of the available subnet pools that
are listed, then click Select.
e. Click the checkmark to add this IPSec tunnel.
Click + Add IPSec Tunnel if you want to add another IPSec tunnel.
f.
Click Add in the Add VPN Network dialog box.
You return to the Create External Network dialog box.
Step 4
When you have finished creating the external network, click Save.
After you click Save in the Create External Network window, cloud routers are then configured in Google Cloud.
To verify that cloud routers were configured in Google Cloud, in your Google Cloud account, navigate to Hybrid
Connectivity > Cloud Routers. You should see the cloud routers created for the different regions (note that you might
have to click Refresh to bring up the newly-configured cloud routers).
To see the IPSec sessions, navigate to Hybrid Connectivity > VPN > Cloud VPN Tunnels.
Configuring Inter-VRF Route Leaking Using the Cisco Cloud APIC GUI
Using inter-VRF route leaking, you can configure an independent routing policy to specify which routes to
leak between a pair of VRFs when you are setting up routing between these types of sites:
• Two cloud sites
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
53
Configuring Cisco Cloud APIC Components
Configuring Inter-VRF Route Leaking Using the Cisco Cloud APIC GUI
• A cloud site and a non-ACI on-premises site
Note
See Configuring Routing and Security Policies Separately, on page 18 for more information.
Step 1
In the left navigation bar, navigate to Application Management > VRFs.
The configured VRFs are displayed.
Step 2
Click the Leak Routes tab.
Any already-configured leak routes are displayed.
Step 3
Click Actions, then choose Create Leak Route.
The Create Leak Route window appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Leak Routes Dialog Box Fields table then
continue.
Table 8: Create Leak Routes Dialog Box Fields
Properties
Description
Source VRF
To choose a source VRF:
a. Click Select a Source VRF.
The Select a VRF dialog box appears.
b. From the Select a VRF dialog, click to choose a VRF in the left column to use for the source VRF.
Note that the source VRF can be an internal or an external (transport) VRF.
c. Click Select to select this source VRF.
You return to the Create Leak Route dialog box.
Destination VRF
To choose a destination VRF:
a. Click Select a Destination VRF.
The Select a VRF dialog box appears.
b. From the Select a VRF dialog, click to choose a VRF in the left column to use for the destination
VRF.
c. Click Select to select this destination VRF.
You return to the Create Leak Route dialog box.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
54
Configuring Cisco Cloud APIC Components
Configuring Inter-VRF Route Leaking Using the Cisco Cloud APIC GUI
Properties
Description
Type
Choose the type of leaked route that you want to configure:
• Leak All: Select to configure all routes to leak between the VRFs.
The entry 0.0.0.0/0 is entered automatically in the subnet IP area by default in this case.
• Subnet IP: Select to configure a specific subnet IP address as the route to leak between VRFs. The
Subnet IP box appears.
In the Subnet IP box, enter a subnet IP address as the route to leak between VRFs.
To configure multiple subnet IP addresses as the route to leak between VRFs, enter additional entries
for the different subnets.
Step 5
When finished, click Save.
The Success window appears.
Step 6
Determine if you want to configure additional inter-VRF route leaking.
• If you want to add another route to leak between a pair of VRFs, click the Add Another Route option in the
Success window.
You are returned to the Add Leak Route window. Repeat Step 4, on page 54 through Step 5, on page 55 to
configure another route to leak between a pair of VRFs.
• If you want to add a reverse route, where:
• The destination VRF from the previous configuration now becomes the source VRF, and
• The source VRF from the previous configuration now becomes the destination VRF
Then click the Add Reverse Route option in the Success window.
You are returned to the Add Leak Route window. Repeat Step 4, on page 54 through Step 5, on page 55 to
configure another route, but this time:
• In the Source VRF field, select the VRF that you had selected as a destination VRF in the previous
configuration.
• In the Destination VRF field, select the VRF that you had selected as a source VRF in the previous
configuration.
Step 7
When you have finished configuring leak routes, click Done.
The Leak Routes tab in the main VRFs page is displayed again, with the newly configured leak route displayed.
Step 8
To get more information on a source or destination VRF, or to make changes to a configured leak route, double-click
the VRF in the Leak Routes tab in the main VRFs page.
The Overview page for that VRF is displayed.
Step 9
Click the Application Management tab at the top of the VRF page, then click the Leak Routes tab in the left nav bar.
The leak routes associated with this particular VRF are displayed.
Step 10
Configure additional leak routes associated with this VRF, if necessary.
• To add a leak route from this VRF, click Actions, then choose Add Leak Route from <VRF_name>.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
55
Configuring Cisco Cloud APIC Components
Enabling Connectivity Between Google Cloud and External Devices
The Add Leak Route window appears. Enter the necessary information as you did previously using the information
in Step 4, on page 54. Note that the entry in the Source VRF is pre-selected and cannot be changed in this situation.
• To add a leak route to this VRF, click Actions, then choose Add Leak Route to <VRF_name>.
The Add Leak Route window appears. Enter the necessary information as you did previously using the information
in Step 4, on page 54. Note that the entry in the Destination VRF is pre-selected and cannot be changed in this
situation.
Enabling Connectivity Between Google Cloud and External Devices
Follow these procedures to manually enable connectivity between a Google Cloud Router and an external
device.
Downloading the External Device Configuration Files
Step 1
In the Cisco Cloud APIC GUI, click on Dashboard.
The Dashboard view for the Cisco Cloud APIC appears.
Step 2
In the Connectivity area, under External Connectivity Status, click on the number above the Cloud Routers entry.
The External Connectivity window appears.
Step 3
Click Actions > Download External Device Configuration Files.
The Download External Device Configuration Files pop-up appears.
Step 4
Select the external device configuration files to download and click Download.
This action downloads a zip file that contains configuration information that you will use to enable connectivity between
the Google Cloud Router and the external devices.
Enabling Connectivity Between Google Cloud and the External Devices
Before you begin
Download the external device configuration files using the procedures in Downloading the External Device
Configuration Files, on page 56.
Step 1
Gather the necessary information that you will need to enable connectivity between the Google Cloud Router and the
external devices.
Step 2
Log into the external device.
Step 3
Enter the configuration information to connect an external networking device with the cloud ACI fabric.
If you downloaded the external device configuration files using the instructions in Downloading the External Device
Configuration Files, on page 56, locate the configuration information for the first tunnel and enter that configuration
information.
Following is an example of what the external device configuration file might look like for the first tunnel, where
PRESHARED-KEY is taken from the vpn-connectivity configuration page:
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
56
Configuring Cisco Cloud APIC Components
Enabling Connectivity Between Google Cloud and the External Devices
! The following file contains configuration recommendation to connect an external networking device
with the cloud ACI Fabric
! The configurations here are provided for an IOS-XE based device. The user is expected to understand
the configs and make any necessary amends before using them
! on the external device. Cisco does not assume any responsibility for the correctness of the config.
! Tunnel to 54.215.245.58 5.500 for
hcextnwTunnIf.acct-[infra]/region-[us-west1]/hubCtx-[1]-id-[0]/ext-[extnwfoo_us-west1]/vpn-[vpnnwfoo]/rtr-default-peer-54.215.245.58/src-1-dest-[54.215.245.58]
! USER-DEFINED: please define rd: RD
! USER-DEFINED: please provide preshared-key: PRESHARED-KEY
! USER-DEFINED: please define router-id: ROUTER-ID
! USER-DEFINED: please define gig-number: GIG-NUMBER
! USER-DEFINED: please define gig-gateway: GIG-GATEWAY
! ikev: ikev2
! vrf-name: extv1
! user name: root
! tunnel counter: 5
! IPV4 address: 35.220.50.132
! tunnel interface destination: 54.215.245.58
! tunne id: 500
! BGP peer address: 169.254.10.6
! BGP peer neighbor address: 169.254.10.5
! BGP peer ASN: 64513
! hcloudHubCtx ASN: 64512
vrf definition extv1
rd RD:1
address-family ipv4
exit-address-family
exit
interface Loopback0
vrf forwarding extv1
ip address 41.41.41.41 255.255.255.255
exit
crypto ikev2 proposal ikev2-1
encryption aes-cbc-256 aes-cbc-192 aes-cbc-128
integrity sha512 sha384 sha256 sha1
group 24 21 20 19 16 15 14 2
exit
crypto ikev2 policy ikev2-1
proposal ikev2-1
exit
crypto ikev2 keyring keyring-root-5
peer peer-ikev2-keyring
address 35.220.50.132
pre-shared-key PRESHARED-KEY
exit
exit
crypto ikev2 profile ikev-profile-root-5
match address local interface GIG-NUMBER
match identity remote address 35.220.50.132 255.255.255.255
identity local address 54.215.245.58
authentication remote pre-share
authentication local pre-share
keyring local keyring-root-5
lifetime 3600
dpd 10 5 periodic
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
57
Configuring Cisco Cloud APIC Components
Enabling Connectivity Between Google Cloud and the External Devices
exit
crypto ipsec transform-set ikev-transport-root-5 esp-gcm 256
mode tunnel
exit
crypto ipsec profile ikev-profile-root-5
set transform-set ikev-transport-root-5
set pfs group14
set ikev2-profile ikev-profile-root-5
exit
interface Tunnel500
vrf forwarding extv1
ip address 169.254.10.6 255.255.255.252
ip mtu 1400
ip tcp adjust-mss 1400
tunnel source GIG-NUMBER
tunnel mode ipsec ipv4
tunnel destination 35.220.50.132
tunnel protection ipsec profile ikev-profile-root-5
exit
ip route 35.220.50.132 255.255.255.255 GIG-NUMBER GIG-GATEWAY
router bgp 64513
bgp router-id ROUTER-ID
bgp log-neighbor-changes
address-family ipv4 vrf extv1
network 41.41.41.41 mask 255.255.255.255
neighbor 169.254.10.5 remote-as 64512
neighbor 169.254.10.5 ebgp-multihop 255
neighbor 169.254.10.5 activate
exit-address-family
exit
The following figures provide more information on what each set of fields is used for in the external device configuration
file:
• The fields shown in the following figure are used to configure these areas:
• VRF definition
• IPSec global configurations
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
58
Configuring Cisco Cloud APIC Components
Enabling Connectivity Between Google Cloud and the External Devices
• The fields shown in the following figure are used to configure these areas:
• IPSec and ikev1 per tunnel configurations
• BGP configurations for the VRF neighbor
• The fields shown in the following figure are used to configure these areas:
• Ikev2 global configurations
• IPSec and ikev2 per tunnel configurations
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
59
Configuring Cisco Cloud APIC Components
Creating an EPG Using the Cisco Cloud APIC GUI
Creating an EPG Using the Cisco Cloud APIC GUI
Use the procedures in this section to create an application EPG or an external EPG. The available configuration
options vary, depending on which type of EPG you are creating.
Creating an Application EPG Using the Cisco Cloud APIC GUI
This section explains how to create an application EPG using the Cisco Cloud APIC GUI. Each service needs
at least one consumer EPG and one provider EPG.
Before you begin
Create an application profile and a VRF.
Step 1
Click the Intent icon.
The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create EPG.
The Create EPG dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create EPG Dialog Box Fields table then continue.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
60
Configuring Cisco Cloud APIC Components
Creating an Application EPG Using the Cisco Cloud APIC GUI
Table 9: Create EPG Dialog Box Fields
Properties
Description
General
Name
Enter the name of the EPG.
Note the following restrictions:
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters must
be hyphens, lowercase letters, or digits, except the last character, which cannot be a hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions imposed
by the Google Cloud firewall rules. Refer to Naming Length Restrictions Imposed By Google Cloud
Firewall Rules, on page 26 to better understand the restriction and the total number of characters
allowed for each of the Cisco Cloud APIC components that make up the firewall rule name.
Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box appears.
b. From the Select Tenant dialog, click to choose a tenant in the left column.
c. Click Select. You return to the Create EPG dialog box.
Application Profile
To choose an application profile:
a. Click Select Application Profile. The Select Application Profile dialog box appears.
b. From the Select Application Profile dialog, click to choose an application profile in the left column.
Note
If you are creating an EPG in the infra tenant, we recommend that you do not choose the
cloud-infra application profile because that application profile is used by EPGs in
the overlay-1 VRF. Select a different application profile or click Create Application
Profile to create a new one.
c. Click Select. You return to the Create EPG dialog box.
Description
Enter a description of the EPG.
Settings
Type
Because this will be an application EPG, choose Application as the EPG type.
VRF
To choose a VRF:
a. Click Select VRF. The Select VRF dialog box appears.
b. From the Select VRF dialog, click to choose a VRF in the left column.
c. Click Select. You return to the Create EPG dialog box.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
61
Configuring Cisco Cloud APIC Components
Creating an Application EPG Using the Cisco Cloud APIC GUI
Properties
Description
Endpoint Selectors
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
62
Configuring Cisco Cloud APIC Components
Creating an Application EPG Using the Cisco Cloud APIC GUI
Properties
Description
Note
See Configuring Virtual Machines in Google Cloud, on page 76 for instructions on configuring
virtual machines in Google Cloud as part of the endpoint selector configuration process.
To add an endpoint selector:
a. Click Add Endpoint Selector to open the Add Endpoint Selector dialog.
b. In the Add Endpoint Selector dialog, enter a name in the Name field.
c. Click Selector Expression. The Key, Operator, and Value fields are enabled.
d. Click the Key drop-down list to choose a key. The options are:
• Choose IP if you want to use an IP address or subnet for the endpoint selector.
• Choose Region if you want to use the Google Cloud region for the endpoint selector.
• Choose Custom if you want to create a custom key for the endpoint selector.
Note
When choosing the Custom option, the drop-down list becomes a text box. You need
to enter a name for the key in the spaces after custom: (for example, custom:
Location).
e. Click the Operator drop-down list to choose an operator. The options are:
• equals: Used when you have a single value in the Value field.
• not equals: Used when you have a single value in the Value field.
• in: Used when you have multiple comma-separated values in the Value field.
• not in: Used when you have multiple comma-separated values in the Value field.
• has key: Used if the expression contains only a key.
• does not have key: Used for an expression that does not contain a key.
f.
Enter a value in the Value field then click the check mark to validate the entries. The value you enter
depends on the choices you made for the Key and Operator fields. For example, if the Key field is
set to IP and the Operator field is set to equals, the Value field must be an IP address or subnet.
However, if the Operator field is set to has key, the Value field is disabled.
g. When finished, click the check mark to validate the selector expression.
h. Determine if you want to create additional endpoint selector expressions to the endpoint selector. If
you create more than one expression under a single endpoint selector, a logical AND exists between
those expressions.
For example, assume you created two sets of expressions under a single endpoint selector:
• Endpoint selector 1, expression 1:
• Key: Region
• Operator: equals
• Value: us-west1
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
63
Configuring Cisco Cloud APIC Components
Creating an External EPG Using the Cisco Cloud APIC GUI
Properties
Description
• Endpoint selector 1, expression 2:
• Key: IP
• Operator: equals
• Value: 192.0.2.1/24
In this case, if both of these expressions are true (if the region is us-west1 AND if the IP address
belongs to subnet 192.0.2.1/24), then that endpoint is assigned to the Cloud EPG.
i.
Click the check mark after every additional expression that you want to create under this endpoint
selector then click Add when finished.
If you create more than one endpoint selector under an EPG, a logical OR exists between those
endpoint selectors. For example, assume you had created endpoint selector 1 as described in the
previous step, and then you created a second endpoint selector as described below:
• Endpoint selector 2, expression 1:
• Key: Region
• Operator: in
• Value: us-east1, us-central1
In this case:
• If the region is us-west1 AND the IP address belongs to the 192.0.2.1/24 subnet (endpoint selector
1 expressions)
OR
• If the region is either us-east1 or us-central1 (endpoint selector 2 expression)
Then that end point is assigned to the Cloud EPG.
Step 5
Click Save when finished.
Creating an External EPG Using the Cisco Cloud APIC GUI
This section explains how to create an external EPG using the Cisco Cloud APIC GUI. Each service needs
at least one consumer EPG and one provider EPG.
Before you begin
Create an application profile and a VRF.
Step 1
Click the Intent icon.
The Intent menu appears.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
64
Configuring Cisco Cloud APIC Components
Creating an External EPG Using the Cisco Cloud APIC GUI
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create EPG.
The Create EPG dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create EPG Dialog Box Fields table then continue.
Table 10: Create EPG Dialog Box Fields
Properties
Description
General
Name
Enter the name of the EPG.
Note the following restrictions:
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters must
be hyphens, lowercase letters, or digits, except the last character, which cannot be a hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions imposed
by the Google Cloud firewall rules. Refer to Naming Length Restrictions Imposed By Google Cloud
Firewall Rules, on page 26 to better understand the restriction and the total number of characters
allowed for each of the Cisco Cloud APIC components that make up the firewall rule name.
Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box appears.
b. From the Select Tenant dialog, click to choose a tenant in the left column.
c. Click Select. You return to the Create EPG dialog box.
Application Profile
To choose an application profile:
a. Click Select Application Profile. The Select Application Profile dialog box appears.
b. From the Select Application Profile dialog, click to choose an application profile in the left column.
Note
If you are creating an EPG in the infra tenant, we recommend that you do not choose the
cloud-infra application profile because that application profile is used by EPGs in
the overlay-1 VRF. Select a different application profile or click Create Application
Profile to create a new one.
c. Click Select. You return to the Create EPG dialog box.
Description
Enter a description of the EPG.
Settings
Type
Because this will be an external EPG, choose External as the EPG type.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
65
Configuring Cisco Cloud APIC Components
Creating an External EPG Using the Cisco Cloud APIC GUI
Properties
Description
VRF
To choose a VRF:
a. Click Select VRF. The Select VRF dialog box appears.
b. From the Select VRF dialog, click to choose a VRF in the left column.
c. Click Select. You return to the Create EPG dialog box.
Route Reachability
The type of route reachability for the external EPG will be automatically selected (either Internet or
External-Site).
Endpoint Selectors
Note
See Configuring Virtual Machines in Google Cloud, on page 76 for instructions on configuring
virtual machines in Google Cloud as part of the endpoint selector configuration process.
To add an endpoint selector:
a. Click Add Endpoint Selector to add an endpoint selector.
b. Enter a name in the Name field.
c. Enter a subnet in the Subnet.
d. When finished, click the check mark to validate the endpoint selector.
e. Determine if you want to create additional endpoint selectors.
If you create more than one endpoint selector under an EPG, a logical OR exists between those
endpoint selectors. For example, assume you created two endpoint selectors:
• Endpoint selector 1:
• Name: EP_Sel_1
• Subnet: 192.1.1.1/24
• Endpoint selector 2:
• Name: EP_Sel_2
• Subnet: 192.2.2.2/24
In this case:
• If the IP address belongs to the 192.1.1.1/24 subnet (endpoint selector 1)
OR
• If the IP address belongs to the 192.2.2.2/24 subnet (endpoint selector 2)
Then that end point is assigned to the Cloud EPG.
Step 5
Click Save when finished.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
66
Configuring Cisco Cloud APIC Components
Creating a Filter Using the Cisco Cloud APIC GUI
Creating a Filter Using the Cisco Cloud APIC GUI
This section explains how to create a filter using the Cisco Cloud APIC GUI.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create Filter. The Create Filter dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Filter Dialog Box Fields table then continue.
Table 11: Create Filter Dialog Box Fields
Properties
Description
Name
Enter a name for the filter in the Name field.
Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box
appears.
b. From the Select Tenant dialog, click to choose a tenant
in the left column then click Select. You return to the
Create Filter dialog box.
Description
Enter a description of the filter.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
67
Configuring Cisco Cloud APIC Components
Creating a Contract Using the Cisco Cloud APIC GUI
Properties
Description
Add Filter
To add a filter:
a. Click Add Filter Entry. The Add Filter Entry dialog
box appears.
b. Enter a name for the filter entry in the Name field.
c. Click the Ethernet Type drop-down list to choose an
ethernet type. The options are:
• IP
• Unspecified
Note
When Unspecified is chosen, any
traffic type is allowed, including IP, and
the remaining fields are disabled.
d. Click the IP Protocol drop-down menu to choose a
protocol. The options are:
• ICMP
• TCP
• UDP
• Unspecified
Note
The remaining fields are enabled only
when TCP or UDP is chosen.
e. Enter the appropriate port range information in the
Destination Port fields.
f.
Step 5
When finished entering filter entry information, click
Add. You return to the Create Filter dialog box where
you can repeat the steps to add another filter entry.
When finished, click Save.
Creating a Contract Using the Cisco Cloud APIC GUI
This section explains how to create a contract using the Cisco Cloud APIC GUI.
Before you begin
Create filters.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
68
Configuring Cisco Cloud APIC Components
Creating a Contract Using the Cisco Cloud APIC GUI
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create Contract. The Create Contract dialog box
appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Contract Dialog Box Fields table then continue.
Table 12: Create Contract Dialog Box Fields
Properties
Description
Name
Enter the name of the contract.
Note the following restrictions:
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters
must be hyphens, lowercase letters, or digits, except the last character, which cannot be a
hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions
imposed by the Google Cloud firewall rules. Refer to Naming Length Restrictions Imposed
By Google Cloud Firewall Rules, on page 26 to better understand the restriction and the
total number of characters allowed for each of the Cisco Cloud APIC components that
make up the firewall rule name.
Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box appears.
b. From the Select Tenant dialog, click to choose a tenant in the left column.
c. Click Select. You return to the Create Contract dialog box.
Description
Enter a description of the contract.
Settings
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
69
Configuring Cisco Cloud APIC Components
Creating an Inter-Tenant Contract Using the Cisco Cloud APIC GUI
Properties
Description
Scope
The scope limits the contract to any endpoint groups within the same application profile, within
the same VRF instance, throughout the fabric (globally), or within the same tenant.
Note
Shared services enables communication between EPGs in different tenants and
between EPGs in different VRFs.
To enable EPGs in one tenant to communicate with EPGs in another tenant, choose
Global scope.
To enable an EPG in one VRF to communicate with another EPG in a different VRF,
choose Global or Tenant scope.
Click the drop-down arrow to choose from the following scope options:
• Application Profile
• VRF
• Global
• Tenant
Add Filter
To choose a filter:
a. Click Add Filter. The filter row appears with a Select Filter option.
b. Click Select Filter. The Select Filter dialog box appears.
c. From the Select Filter dialog, click to choose a filter in the left column then click Select.
You return to the Create Contract dialog box.
Step 5
Click Save when finished.
Creating an Inter-Tenant Contract Using the Cisco Cloud APIC GUI
This section explains how to create an inter-tenant contract using the Cisco Cloud APIC GUI.
Before you begin
Create filters.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create Contract. The Create Contract dialog box
appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Contract Dialog Box Fields table then continue.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
70
Configuring Cisco Cloud APIC Components
Creating an Inter-Tenant Contract Using the Cisco Cloud APIC GUI
Table 13: Create Contract Dialog Box Fields
Properties
Description
Name
Enter the name of the contract.
This is the name of the contract in Google Cloud. Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters
must be hyphens, lowercase letters, or digits, except the last character, which cannot be a hyphen.
Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box appears.
b. From the Select Tenant dialog, click to choose a tenant in the left column.
c. Click Select. You return to the Create Contract dialog box.
Description
Enter a description of the contract.
Settings
Scope
The scope limits the contract to any endpoint groups within the same application profile, within
the same VRF instance, throughout the fabric (globally), or within the same tenant.
For inter-tenant communication, you will first create a contract with the Global scope in one
of the tenants (for example, tenant1). This tenant’s EPG will always be the provider of this
contract.
This contract will then be exported to the other tenant (for example, tenant2). For the other
tenant that imports this contract, its EPG will be the consumer of the imported contract. If you
want tenant2’s EPG to be the provider and tenant1’s EPG to be the consumer, then create a
contract in tenant2 and then export it to tenant1.
Add Filter
To choose a filter:
a. Click Add Filter. The filter row appears with a Select Filter option.
b. Click Select Filter. The Select Filter dialog box appears.
c. From the Select Filter dialog, click to choose a filter in the left column then click Select.
You return to the Create Contract dialog box.
Step 5
Click Save when finished.
Step 6
Export the contract that you just created to another tenant.
For example, assume the following:
• The contract that you created in the procedure above is named contract1 in tenant tenant1.
• The contract that you want to export is named exported_contract1 and you are exporting it to tenant tenant2.
a) Navigate to the Contracts page (Application Management > Contracts).
The configured contracts are listed.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
71
Configuring Cisco Cloud APIC Components
Creating an Inter-Tenant Contract Using the Cisco Cloud APIC GUI
b) Select the contract that you just created.
For example, scroll through the list until you see the contract contract1 and click the box next to it to select it.
c) Go to Actions > Export Contract.
The Export Contract window appears.
d) Click Select Tenant.
The Select Tenant window appears.
e) Select the tenant that you want to export the contract to, then click Save.
For example, tenant2. You are returned to the Export Contract window.
f) In the Name field, enter a name for the exported contract.
For example, exported_contract1.
g) In the Description field, enter a description for the exported contract, if necessary.
h) Click Save.
The list of contracts appears again.
Step 7
Configure the first tenant's EPG as the provider EPG, with the original contract, as the first part of the EPG communication
configuration.
a) Click the Intent button, then choose EPG Communication.
The EPG Communication window appears.
b) Click Let's Get Started.
c) In the Contract area, click Select Contract.
The Select Contract window appears.
d) Locate and select the contract that you created at the beginning of these procedures.
In this example, you would locate and select contract1.
e) Click Select.
The EPG Communication window appears.
f) In the Provider EPGs area, click Add Provider EPGs.
The Select Provider EPGs window appears.
g) Leave the Keep selected items box checked, then select the first tenant's (tenant1) EPG.
h) Click Select.
The EPG Communication window appears.
i) Click Save.
Step 8
Configure the second tenant's EPG as the consumer EPG, with the exported contract, as the second part of the EPG
communication configuration.
a) Click the Intent button, then choose EPG Communication.
The EPG Communication window appears.
b) Click Let's Get Started.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
72
Configuring Cisco Cloud APIC Components
Specifying Consumer and Provider EPGs Using the Cisco Cloud APIC
c) In the Contract area, click Select Contract.
The Select Contract window appears.
d) Locate and select the contract that you created at the beginning of these procedures.
In this example, you would locate and select exported_contract1.
e) Click Select.
The EPG Communication window appears.
f) In the Consumer EPGs area, click Add Consumer EPGs.
The Select Consumer EPGs window appears.
g) Leave the Keep selected items box checked, then select the second tenant's (tenant2) EPG.
h) Click Select.
The EPG Communication window appears.
i) Click Save.
Specifying Consumer and Provider EPGs Using the Cisco Cloud APIC
This section explains how to specify an EPG as a consumer or a provider.
Before you begin
• You have configured a contract.
• You have configured an EPG.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Configuration.
A list of Configuration options appears in the Intent menu.
Step 3
From the Configuration list in the Intent menu, click EPG Communication. The EPG Communication dialog box
appears with the Consumer EPGs, Contract, and Provider EPGs information.
Step 4
To choose a contract:
a) Click Select Contract. The Select Contract dialog appears.
b) In the pane on the left side of the Select Contract dialog, click to choose a contract then click Select. The Select
Contract dialog box closes.
Step 5
To add a consumer EPG:
a) Click Add Consumer EPGs. The Select Consumer EPGs dialog appears.
Note
EPGs within the tenant (where the contract is created) are displayed.
b) In the pane on the left side of the Select Consumer EPGs dialog, click to place a check in a check box to choose an
EPG.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
73
Configuring Cisco Cloud APIC Components
Creating a Cloud Context Profile Using the Cisco Cloud APIC GUI
Step 6
To add a provider EPG:
a) Click Add Provider EPGs. The Select Provider EPGs dialog appears.
EPGs within the tenant (where the contract is created) are displayed.
Note
b) In the pane on the left side of the Select Provider EPGs dialog, click to place a check in a check box to choose a
provider EPG.
If the chosen contract is an Imported Contract, the provider EPG selection is disabled.
Note
c) When finished, click Select. The Select Provider EPGs dialog box closes, and you return to the EPG Communication
Configuration window.
d) Click Save.
Creating a Cloud Context Profile Using the Cisco Cloud APIC GUI
This section explains how to create a cloud context profile using the Cisco Cloud APIC GUI.
Before you begin
Create a VRF.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Application Management.
A list of Application Management options appear in the Intent menu.
Step 3
From the Application Management list in the Intent menu, click Create Cloud Context Profile. The Create Cloud
Context Profile dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Cloud Context Profile Dialog Box Fields table then
continue.
Table 14: Create Cloud Context Profile Dialog Box Fields
Properties
Description
Name
Enter the name of the cloud context profile. Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters
must be hyphens, lowercase letters, or digits, except the last character, which cannot be a hyphen.
Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box appears.
b. From the Select Tenant dialog, click to choose a tenant in the left column then click Select.
You return to the Create Cloud Context Profile dialog box.
Description
Enter a description of the cloud context profile.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
74
Configuring Cisco Cloud APIC Components
Creating a Cloud Context Profile Using the Cisco Cloud APIC GUI
Properties
Description
Settings
Region
To choose a region:
a. Click Select Region. The Select Region dialog box appears.
b. From the Select Region dialog, click to choose a region in the left column then click Select.
You return to the Create Cloud Context Profile dialog box.
VRF
To choose a VRF:
a. Click Select VRF. The Select VRF dialog box appears.
b. From the Select VRF dialog box, click to choose a VRF in the left column then click Select.
You return to the Create Cloud Context Profile dialog box.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
75
Configuring Cisco Cloud APIC Components
Configuring Virtual Machines in Google Cloud
Properties
Description
Add CIDR
Note
See Understanding VPCs and Subnets Under Google Cloud and Cloud Context
Profiles Under Cloud APIC, on page 22 for more information on primary and
secondary CIDRs and subnet group labels.
To add a CIDR:
a. Click Add CIDR. The Add CIDR dialog box appears.
b. Enter the address in the CIDR Block Range field.
c. Click to check (enabled) or uncheck (disabled) the Primary check box.
• You must have at least one primary CIDR added for each cloud context profile.
• If you are adding additional secondary CIDRs and subnets for VPCs, leave the Primary
box unchecked.
d. Click Add Subnet and enter the following information:
• In the Address field, enter the subnet address.
• In the Name field, enter the name for this subnet.
• In the Subnet Group Label field, choose one of the following:
• Select Existing: Click Select Subnet Group Label, then choose an existing
subnet group label to associate with this subnet.
• Create New: Enter a unique name for the subnet group label to associate with
this subnet.
e. In the VRF field, make a selection, if necessary.
• If you checked the box next to the Primary field, this CIDR is automatically associated
with the primary VRF.
• If you did not check the box next to the Primary field, you can associate this CIDR
with a secondary VRF. Click the X next to the VRF, then click on Select VRF to select
the secondary VRF to associate with this CIDR.
f.
Step 5
When finished, click Add.
Click Save when finished.
Configuring Virtual Machines in Google Cloud
When you configure endpoint selectors for Cisco Cloud APIC, you will also need to configure the virtual
machines that you will need in Google Cloud that will correspond with the endpoint selectors that you configure
for Cisco Cloud APIC.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
76
Configuring Cisco Cloud APIC Components
Configuring Virtual Machines in Google Cloud
This topic provides the requirements for configuring the virtual machines in Google Cloud. You can use these
requirements to configure the virtual machines in Google Cloud either before you configure the endpoint
selectors for Cisco Cloud APIC or afterward.
For example, assume that you are using Custom as the type of endpoint selector, as described in Endpoints
and Endpoint Selectors, on page 20.
• You might go to your account in Google Cloud and create a custom tag or label in Google Cloud first,
then create an endpoint selector using a custom tag or label in Cisco Cloud APIC afterward.
• Or you might create an endpoint selector using a custom tag or label in Cisco Cloud APIC first, then go
to your account in Google Cloud and create a custom tag or label in Google Cloud afterward.
Before you begin
You must configure a cloud context profile as part of the Google Cloud virtual machine configuration process.
When you configure a cloud context profile, the configurations, such as the VRF and region settings, are
pushed out to Google Cloud afterward.
Step 1
Review your cloud context profile configuration to get the following information:
• VRF name
• Subnet information
• Google Cloud Project ID
• The resource group that corresponds to where the cloud context profile is deployed.
Note
In addition to the information above, if you are using tag-based EPGs, you also need to know the tag names.
The tag names are not available in the cloud context profile configuration.
To obtain the cloud context profile configuration information:
a) From the Navigation menu, choose the Application Management tab.
When the Application Management tab expands, a list of subtab options appear.
b) Choose the Cloud Context Profiles subtab option.
A list of the cloud context profiles that you have created for your Cisco Cloud APIC are displayed.
c) Select the cloud context profile that you will use as part of this Google Cloud virtual machine configuration process.
Various configuration parameters are displayed for this cloud context profile, such as the region, VRF, IP address
and subnets. Use the information displayed in this window when you configure the Google Cloud virtual machine.
Step 2
Log in to the Google Cloud portal account for the Cisco Cloud APIC user tenant and begin creating an Google Cloud
VM using the information you gathered from the cloud context profile configuration.
Note
For information about how to create the VM in the Google Cloud portal, see the Google Cloud documentation.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
77
Configuring Cisco Cloud APIC Components
Creating a Backup Configuration Using the Cisco Cloud APIC GUI
Creating a Backup Configuration Using the Cisco Cloud APIC GUI
This section explains how to create a backup configuration.
Before you begin
Create a remote location and a scheduler, if needed.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Operations.
A list of Operations options appear in the Intent menu.
Step 3
From the Operations list in the Intent menu, click Create Backup Configuration. The Create Backup Configuration
dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Backup Configuration Dialog Box Fields table
then continue.
Table 15: Create Backup Configuration Dialog Box Fields
Properties
Description
General
Name
Enter the name of the backup configuration.
Description
Enter a description of the backup configuration.
Settings
Backup Destination
Choose a backup destination.
• Local
• Remote
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
78
Configuring Cisco Cloud APIC Components
Creating a Backup Configuration Using the Cisco Cloud APIC GUI
Properties
Description
Backup Object
Choose the root hierarchical content to consider for the
backup
• Policy Universe
• Selector Object—When chosen, this option adds the
Object Type drop-down list and Object DN field.
a. From the Object Type drop-down list, choose
from the following options:
• Tenant—When chosen the Select Tenant
option appears.
• Application Profile—When chosen the
Select Application Profile option appears.
• EPG—When chosen the Select EPG option
appears.
• Contract—When chosen the Select Contract
option appears.
• Filter—When chosen the Select Filter option
appears.
• VRF—When chosen the Select VRFoption
appears.
• Cloud Context Profile—When chosen the
Select Cloud Context Profile option appears.
b. Click the Select <object_name>. The Select
<object_name> dialog appears.
c. From the Select <object_name> dialog, click to
choose from the options in the left column then
click Select. You return to the Create Backup
Configuration dialog box.
Note
The Object DN field is automatically
populated with the DN of the object it
will use as root of the object tree to
backup
• Enter DN—When chosen, this option displays the
Object DN field.
a. From the Object DN field, enter the DN of a
specific object to use as the root of the object tree
to backup.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
79
Configuring Cisco Cloud APIC Components
Creating a Tech Support Policy Using the Cisco Cloud APIC GUI
Properties
Description
Scheduler
a. Click Select Scheduler to open the Select Scheduler
dialog and choose a scheduler from the left-side column.
b. Click the Select button at the bottom-right corner when
finished.
Trigger Backup After Creation
Choose one of the following:
• Yes—(Default) Trigger a backup after creating the
backup configuration.
• No—Do not trigger a backup after creating the backup
configuration.
Step 5
Click Save when finished.
Creating a Tech Support Policy Using the Cisco Cloud APIC GUI
This section explains how to create a tech support policy.
Before you begin
When creating a tech support policy for a remote location, you must first create the remote location.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Operations.
A list of Operations options appear in the Intent menu.
Step 3
From the Operations list in the Intent menu, click Create Tech Support. The Create Tech Support dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Tech Support Dialog Box Fields table then
continue.
Table 16: Create Tech Support Dialog Box Fields
Properties
Description
General
Name
Enter the name of the tech support policy.
Description
Enter a description of the tech support.
Settings
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
80
Configuring Cisco Cloud APIC Components
Creating a Scheduler Using the Cisco Cloud APIC GUI
Properties
Description
Export Destination
Choose an export destination.
• Controller
• Remote Location—When chosen the Select Remote
Location option appears.
a. Click Select Remote Location. The Select
Remote Location dialog box appears.
b. From the Select Remote Location dialog, click
to choose a remote location in the left column then
click Select. You return to the Create Tech
Suport dialog box.
Click to place a check in the Enabled check box if you
want to include pre-upgrade logs in the tech support policy.
Include Pre-Upgrade Logs
Step 5
Click Save when finished.
Creating a Scheduler Using the Cisco Cloud APIC GUI
This section explains how to create a scheduler, which would be in User Laptop Browser local time and will
be converted to the Cisco Cloud APIC default UTC time.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Operations.
A list of Operations options appear in the Intent menu.
Step 3
From the Operations list in the Intent menu, click Create Scheduler. The Create Scheduler dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Scheduler Dialog Box Fields table then continue.
Table 17: Create Scheduler Dialog Box Fields
Properties
Description
General
Name
Enter the name of the trigger scheduler policy.
Description
Enter a description of the trigger scheduler.
Settings
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
81
Configuring Cisco Cloud APIC Components
Creating a Scheduler Using the Cisco Cloud APIC GUI
Properties
Description
Recurring Windows
Click Add Recurring Window. The Add Recurring
Window dialog appears.
a. From the Schedule drop-down list, choose from the
following.
• Every Day
• Even Days
• Odd Days
• Monday
• Tuesday
• Wednesday
• Thursday
• Friday
• Saturday
• Sunday
b. From the Start Time field, enter a time.
c. In the Maximum Concurrent Tasks field, choose one
of the following:
• Unlimited: There is no maximum number of
concurrent tasks that can be enforced on the
scheduler window.
• Custom: In the second Maximum Concurrent
Tasks field, enter the maximum number of tasks
that can be processed concurrently. The maximum
value allowed in this field is 65535.
d. In the Maximum Running Time field, choose one of
the following:
• Unlimited: There is no time limit enforced on the
scheduler window.
• Custom: In the second Maximum Running Time
field, enter the maximum duration of the window.
The acceptable format for this field is
dd:hh:mm:ss.
e. Click Add when finished.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
82
Configuring Cisco Cloud APIC Components
Creating a Remote Location Using the Cisco Cloud APIC GUI
Properties
Description
Add One Time Window
Click Add One Time Window. The Add One Time
Window dialog appears.
a. From the Start Time field, enter a date and time.
b. From the Maximum Concurrent Tasks field, enter a
number or leave the field blank to specify unlimited.
c. From the Maximum Running Time, click to choose
Unlimited or Custom.
d. Click Add when finished.
Step 5
Click Save when finished.
Creating a Remote Location Using the Cisco Cloud APIC GUI
This section explains how to create a remote location using the Cisco Cloud APIC.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Operations.
A list of Operations options appear in the Intent menu.
Step 3
Step 4
From the Operations list in the Intent menu, click Create Remote Location. The Create Remote Location dialog box
appears.
Enter the appropriate values in each field as listed in the following Create Remote Location Dialog Box Fields table then
continue.
Table 18: Create Remote Location Dialog Box Fields
Properties
Description
General
Name
Enter the name of the remote location policy.
Description
Enter a description of the remote location policy.
Settings
Hostname/IP Address
Enter the hostname or IP address of the remote location
Protocol
Choose a protocol:
• FTP
• SFTP
• SCP
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
83
Configuring Cisco Cloud APIC Components
Creating a Login Domain Using the Cisco Cloud APIC GUI
Properties
Description
Path
Enter the path for the remote location.
Port
Enter the port for the remote location.
Username
Enter a username for the remote location.
Authentication Type
When using SFTP or SCP, choose the authentication type:
• Password
• SSH Key
Step 5
SSH Key Content
Enter the SSH key content.
SSH Key Passphrase
SSH key passphrase.
Password
Enter a password for accessing the remote location.
Confirm Password
Reenter the password for accessing the remote location.
Click Save when finished.
Creating a Login Domain Using the Cisco Cloud APIC GUI
This section explains how to create a login domain using the Cisco Cloud APIC GUI.
Before you begin
Create a provider before creating a non-local domain.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Administrative.
A list of Administrative options appear in the Intent menu.
Step 3
From the Administrative list in the Intent menu, click Create Login Domain. The Create Login Domain dialog box
appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Login Domain Dialog Box Fields table then
continue.
Table 19: Create Login Domain Dialog Box Fields
Properties
Description
Name
Enter the name of the login domain.
Description
Enter a description of the login domain.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
84
Configuring Cisco Cloud APIC Components
Creating a Login Domain Using the Cisco Cloud APIC GUI
Properties
Description
Realm
Choose a realm:
• Local
• LDAP—Requires adding providers and choosing an
authenication type.
• RADIUS—Requires adding providers.
• TACACS+—Requires adding providers.
• SAML—Requires adding providers.
Providers
To add a provider:
a. Click Add Providers. The Select Providers dialog
appears with a list of providers in the left pane.
b. Click to choose a provider.
c. Click Select to add the provider.
Advanced Settings
Displays the Authentication Type and LDAP Group Map
Rules fields.
Authentication Type
When LDAP is chosen for realm option, choose one of the
following authentication types:
• Cisco AV Pairs—(Default)
• LDAP Group Map Rules—Requires adding LDAP
group map rules.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
85
Configuring Cisco Cloud APIC Components
Creating a Login Domain Using the Cisco Cloud APIC GUI
Properties
Description
LDAP Group Map Rules
To add an LDAP group map rule:
a. Click Add LDAP Group Map Rule. The Add LDAP
Group Map Rule dialog appears with a list of providers
in the left pane.
b. Enter a name for the rule in the Name field.
c. Enter a description for the rule in the Description field.
d. Enter a group DN for the rule in the Group DN field.
e. Add security domains:
1. Click Add Security Domain. The Add Security
Domain dialog box appears.
2. Click Select Security Domain. The Select Security
Domain dialog box appears with a list of security
domains in the left pane.
3. Click to choose a security domain.
4. Click Select to add the security domain. You return
to the Add Security Domain dialog box.
5. Add a user role:
a. From the Add Security Domain dialog box,
click Select Role. The Select Role dialog box
appears with a list of roles in the left pane.
b. Click to choose a role.
c. Click Select to add the role. You retun to the
Add Security Domain dialog box.
d. From the Add Security Domain dialog box,
click the Privilege Type drop-down list and
choose Read Privilege or Write Privilege.
e. Click the check mark on the right side of the
Privilege Type drop-down list to confirm.
f.
Step 5
Click Save when finished.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
86
Click Add when finished. You return to the
Add LDAP Group Map Rule dialog box
where you can add another security domain.
Configuring Cisco Cloud APIC Components
Creating a Security Domain Using the Cisco Cloud APIC GUI
Creating a Security Domain Using the Cisco Cloud APIC GUI
A security domain restricts the tenant to the security domains that you add. If you do not add a security domain,
all security domains will have access to this tenant. This section explains how to create a security domain
using the GUI.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Administrative.
A list of Administrative options appear in the Intent menu.
Step 3
From the Administrative list in the Intent menu, click Security > Security Domains > Create Security Domain. The
Create Security Domain dialog box appears.
Step 4
In the Name field, enter the name of the security domain.
Step 5
In the Description field, enter a description of the security domain.
Step 6
In the Type field, choose the type of security domain:
• Unrestricted: Users who are assigned to this domain are able to see policies, profiles, or users configured in other
security domains.
• Restricted: Users who are assigned to this domain will not be able to see policies, profiles, or users configured in
other security domains.
Step 7
Click Save when finished.
Creating a Role Using the Cisco Cloud APIC GUI
This section explains how to create a role using the Cisco Cloud APIC GUI.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Administrative.
A list of Administrative options appear in the Intent menu.
Step 3
From the Administrative list in the Intent menu, click Create Role. The Create Role dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Role Dialog Box Fields table then continue.
Table 20: Create Role Dialog Box Fields
Properties
Description
General
Name
Enter a name for the role in the Name field.
Description
Enter a description of the role.
Settings
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
87
Configuring Cisco Cloud APIC Components
Creating a Role Using the Cisco Cloud APIC GUI
Properties
Description
Privilege
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
88
Configuring Cisco Cloud APIC Components
Creating a Role Using the Cisco Cloud APIC GUI
Properties
Description
Click to place a check mark in the check boxes of the privileges you want to assign the user.
The privileges are:
• aaa—Used for configuring authentication, authorization, accouting and import/export
policies.
• access-connectivity—Used for Layer 1-3 configuration under infra, static route
configurations under a tenant's L3Out, management infra policies, and tenant ERSPAN
policies.
• access-equipment—Used for access port configuration.
• access-protocol—Used for Layer 1-3 protocol configurations under infra, fabric-wide
policies for NTP, SNMP, DNS, and image management, and operations-related access
policies such as cluster policy and firmware policies.
• access-qos—Used for changing CoPP and QoS-related policies.
• admin—Complete access to everything (combine ALL roles)
• config-manager
• custom-port-privilege
• custom-privilege-1 through custom-privilege-22
• fabric-connectivity—Used for Layer 1-3 configuration under the fabric, firmware and
deployment policies for raising warnings for estimating policy deployment impact, and
atomic counter, diagnostic, and image management policies on leaf switches and spine
switches.
• fabric-equipment—Used for atomic counter, diagnostic, and image management
policies on leaf switches and spine switches.
• fabric-protocol—Used for Layer 1-3 protocol configurations under the fabric,
fabric-wide policies for NTP, SNMP, DNS, and image management, ERSPAN and
health score policies, and firmware management traceroute and endpoint tracking
policies.
• none—No privilege.
• nw-svc-params—Used for managing Layer 4 to Layer 7 service policies.
• nw-svc-policy—Used for managing Layer 4 to Layer 7 service devices and network
service orchestration.
• ops—Used for operational policies including monitoring and troubleshooting policies
such as atomic counter, SPAN, TSW, tech support, traceroute, analytics, and core
policies.
• site-admin
• site-policy
• tenant-connectivity—Used for Layer 1-3 connectivity changes, including bridge
domains, subnets, and VRFs; for atomic counter, diagnostic, and image management
policies on leaf switches and spine switches; tenant in-band and out-of-band management
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
89
Configuring Cisco Cloud APIC Components
Creating a Certificate Authority Using the Cisco Cloud APIC GUI
Properties
Description
connectivity configurations; and debugging/monitoring policies such as atomic counters
and health score.
• tenant-epg—Used for managing tenant configurations such as deleting/creating endpoint
groups, VRFs, and bridge domains.
• tenant-ext-connectivity—Used for write access firmware policies; managing tenant
L2Out and L3Out configurations; and debugging/monitoring/observer policies.
• tenant-ext-protocol—Used for managing tenant external Layer 1-3 protocols, including
BGP, OSPF, PIM, and IGMP, and for debugging/monitoring/observer policies such as
traceroute, ping, oam, and eptrk. Generally only used for write access for firmware
policies.
• tenant-network-profile—Used for managing tenant configurations, such as deleting
and creating network profiles, and deleting and creating endpoint groups.
• tenant-protocol—Used for managing configurations for Layer 1-3 protocols under a
tenant, for tenant traceroute policies, and as write access for firmware policies.
• tenant-qos—Only used as Write access for firmware policies.
• tenant-security—Used for Contract related configurations for a tenant.
• vmm-policy—Used for managing policies for VM networking.
Step 5
Click Save when finished.
Creating a Certificate Authority Using the Cisco Cloud APIC GUI
This section explains how to create a certificate authority using the GUI.
Before you begin
• Have the certificate chain.
• If the certificate authority is for a tenant, create the tenant.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Administrative.
A list of Administrative options appears in the Intent menu.
Step 3
From the Administrative list in the Intent menu, click Create Certificate Authority. The Create Certificate Authority
dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Certificate Authority Dialog Box Fields table
then continue.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
90
Configuring Cisco Cloud APIC Components
Creating a Key Ring Using the Cisco Cloud APIC GUI
Table 21: Create Certificate Authority Dialog Box Fields
Properties
Description
Name
Enter the name of the certificate authority.
Description
Enter a description of the certificate authority.
Used for
Choose from the following options:
• Tenant—Choose if the certificate authority is for a
specific tenant. When chosen, the Select Tenant option
appears in the GUI.
• System—Choose if the certificate authority is for the
system.
Select Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box
appears.
b. From the Select Tenant dialog, click to choose a tenant
in the left column then click Select. You return to the
Create Certificate Authority dialog box.
Certificate Chain
Enter the certificate chain in the Certificate Chain text
box.
Note
Add the certificates for a chain in the following
order:
a. CA
b. Sub-CA
c. Subsub-CA
d. Server
Step 5
Click Save when finished.
Creating a Key Ring Using the Cisco Cloud APIC GUI
This section explains how to create a key ring using the Cisco Cloud APIC GUI.
Before you begin
• Create a certificate authority.
• Have a certificate.
• If the key ring is for a specific tenant, create the tenant.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
91
Configuring Cisco Cloud APIC Components
Creating a Key Ring Using the Cisco Cloud APIC GUI
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Administrative.
A list of Administrative options appear in the Intent menu.
Step 3
From the Administrative list in the Intent menu, click Create Key Ring. The Create Key Ring dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Key Ring Dialog Box Fields table then continue.
Table 22: Create Key Ring Dialog Box Fields
Properties
Description
Name
Enter the name of the key ring.
Description
Enter a description of the key ring.
Used for
• System—The key ring is for the system.
• Tenant—The key ring is for a specific tenant. Displays
a Tenant field for specifying the tenant.
Select Tenant
To choose a tenant:
a. Click Select Tenant. The Select Tenant dialog box
appears.
b. From the Select Tenant dialog, click to choose a tenant
in the left column then click Select. You return to the
Create Key Ring dialog box.
Settings
Certificate Authority
To choose a certificate authority:
a. Click Select Certificate Authority. The Select
Certificate Authority dialog appears.
b. Click to choose a certificate authority in the column on
the left.
c. Click Select. You return to the Create Key Ring dialog
box.
Private Key
Choose one of the following:
• Generate New Key—Generates a new key.
• Import Existing Key—Displays the Private Key text
box and enables you to use an existing key.
Private Key
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
92
Enter an existing key in the Private Key text box (for the
Import Existing Key option).
Configuring Cisco Cloud APIC Components
Creating a Local User Using the Cisco Cloud APIC GUI
Properties
Description
Modulus
Click the Modulus drop-down list to choose from the
following:
• MOD 512
• MOD 1024
• MOD 1536
• MOD 2048—(Default)
Enter the certificate information in the Certificate text box.
Certificate
Step 5
Click Save when finished.
Creating a Local User Using the Cisco Cloud APIC GUI
This section explains how to create a local user using the Cisco Cloud APIC GUI.
Step 1
Click the Intent icon. The Intent menu appears.
Step 2
Click the drop-down arrow below the Intent search box and choose Administrative.
A list of Administrative options appear in the Intent menu.
Step 3
From the Administrative list in the Intent menu, click Create Local User. The Create Local User dialog box appears.
Step 4
Enter the appropriate values in each field as listed in the following Create Local User Dialog Box Fields table then
continue.
Table 23: Create Local User Dialog Box Fields
Properties
Description
Username
Enter the username of the local user.
Password
Enter the password for the local user.
Confirm Password
Reenter the password for the local user.
Description
Enter a description of the local user.
Settings
Account Status
To choose the account status:
• Active—Activates the local user account.
• Blocked—Blocks the local user account.
• Inactive—Deactivates the local user account.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
93
Configuring Cisco Cloud APIC Components
Creating a Local User Using the Cisco Cloud APIC GUI
Properties
Description
First Name
Enter the first name of the local user.
Last Name
Enter the last name of the local user.
Email Address
Enter the email address of the local user.
Phone Number
Enter the phone number of the local user.
Security Domains
To add a security domain:
a. Click Add Security Domain. The Add Security
Domain dialog box appears.
b. Click Select Security Domain. The Select Security
Domain dialog box appears with a list of security
domains in the left pane.
c. Click to choose a security domain.
d. Click Select to add the security domain. You return to
the Add Security Domain dialog box.
e. Add a user role:
1. From the Add Security Domain dialog box, click
Select Role. The Select Role dialog box appears
with a list of roles in the left pane.
2. Click to choose a role.
3. Click Select to add the the role. You retun to the
Add Security Domain dialog box.
4. From the Add Security Domain dialog box, click
the Privilege Type drop-down list and choose Read
Privilege or Write Privilege.
5. Click the check mark on the right side of the
Privilege Type drop-down list to confirm.
6. Click Add when finished. You return to the Create
Local User dialog box where you can add another
security domain.
Step 5
Click Advanced Settings and enter the appropriate values in each field as listed in the following Create Local User
Dialog Box Fields: Advanced Settings table then continue.
Table 24: Create Local User Dialog Box Fields: Advanced Settings
Property
Description
Account Expires
If you choose Yes, the account is set to expire at the time
that you choose.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
94
Configuring Cisco Cloud APIC Components
Managing Regions (Configuring a Cloud Template) Using the Cisco Cloud APIC GUI
Property
Description
Password Update Required
If you choose Yes, the user must change the password upon
the next login.
OTP
Put a check in the box to enable the one-time password
feature for the user.
User Certificate Attribute
The attribute for the user certificate.
User Certificates
To add a user certificate:
a. Click Add X509 Certificate. The Add X509
Certificate dialog box appears.
b. Enter a name in the Name field.
c. Enter the X509 certificate in the User X509 Certificate
text box.
d. Click Add. The X509 certificate in the User X509
Certificate dialog box closes. You return to the Local
User dialog box.
To add a an SSH key:
SSH Keys
a. Click Add SSH Key. The Add SSH Key dialog box
appears.
b. Enter a name in the Name field.
c. Enter the SSH key in the Key text box.
d. Click Add. The Add SSH Key dialog box closes. You
return to the Local User dialog box.
Step 6
Click Save when finished.
Managing Regions (Configuring a Cloud Template) Using the Cisco Cloud APIC
GUI
With Google Cloud, the VPC resource is a global resource, which means that it spans all Google Cloud regions.
By default, all regions are managed by Google Cloud and inter-region connectivity is present. Cloud APIC
manages all 25 Google Cloud regions.
Step 1
Click the Intent icon.
The Intent menu appears.
Step 2
In the Workflows area, click Cloud APIC Setup.
The Set up - Overview dialog box appears with options for DNS and NTP Servers, Region Management, and Smart
Licensing.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
95
Configuring Cisco Cloud APIC Components
Managing Regions (Configuring a Cloud Template) Using the Cisco Cloud APIC GUI
Step 3
For Region Management, click Edit Configuration.
The Region Management window appears.
Step 4
Determine if you want to configure external connectivity.
Click the box next to Enable to enable external connectivity.
Step 5
Verify that all of the regions in the page are selected.
This page shows all of the regions that are supported by Google Cloud. All of the regions are managed by Cloud APIC.
Step 6
Click Next at the bottom of the page.
If you enabled external connectivity, the General Connectivity page appears.
Step 7
Enter the necessary information in the Hub Network area.
Hub network management is used to deploy cloud routers on specific managed regions. Configure the fabric infra
connectivity for the cloud site and define the configuration template used for the cloud routers in the cloud site in this
area.
Note the following restrictions:
• You can create only one hub network in Google Cloud.
• Under the hub network, only one cloud router is created in Google Cloud.
a) In the Hub Network area, click Add Hub Network.
The Add Hub Network window appears.
b) In the Name field, enter a name for the hub network.
c) Enter a value in the BGP Autonomous System Number field.
The BGP Autonomous System Number (ASN) is used for BGP peering inside the cloud site and for MP-BGP IPv4
peering to other sites.
The ASN must be a private ASN. Enter a value between 64512 and 65534 or between 4200000000 and 4294967294,
inclusive, for each hub network, then click the check mark next to the field.
d) In the Region field, select the appropriate regions.
You can add up to four regions to deploy hub network in this area. The hub network will create one cloud router in
each region selected.
e) In the VPN Router field, enter a name for the VPN router.
The infra VPC uses the cloud router and VPN Gateway to create IPSec tunnels and BGP sessions to on-premises
sites or other cloud sites. The spoke VPCs peer with the infra VPC to share the VPN connections to external sites.
Step 8
Enter the necessary information in the IPSec Tunnel Subnet Pools area.
a) In the IPSec Tunnel Subnet Pools area, click Add IPSec Tunnel Subnet Pools.
The Add IPSec Tunnel Subnet Pools window appears.
b) Enter the subnet pool to be used for IPSec tunnels, if necessary.
By default, a subnet pool of 169.254.0.0/16 is populated to create the IPsec tunnels. You can delete the existing
subnet pool and add additional subnet pools, if necessary.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
96
Configuring Cisco Cloud APIC Components
Configuring Cisco Cloud APIC Using the REST API
The subnets used for the IPSec Tunnel Subnet Pools entry must be common /30 CIDRs from the 169.254.0.0/16
block. For example, 169.254.7.0/24 and 169.254.8.0/24 would be acceptable entries for the subnet pools
in this field.
Click the check mark after you have entered in the appropriate subnet pools.
Step 9
When you have entered all the necessary information on this page, click Save and Continue at the bottom of the page.
You are given the option to create external networks and complete external connectivity configurations, if necessary. Go
to Creating an External Network Using the Cisco Cloud APIC GUI, on page 50 for those procedures.
Configuring Cisco Cloud APIC Using the REST API
Creating a Tenant Using the REST API
Before you begin
Review the information provided in Understanding Google Cloud Deployments with Cloud APIC, on page
12 before proceeding with the procedures in this section.
Step 1
Enter the following POST to share the same credentials across multiple tenants, where you are duplicating the
cloudCredentials object in each tenant and specifying the same Google Cloud Service Account.
Note the following:
• Tenant T1 defines the cloudCredentials object that carries the private key for the Service Account.
• Both tenant T1 and T2 then refer to this cloudCredentials object through the cloudRsCredentials relation.
• The Service Account defined by tenant T1 must be a member of Google Cloud Projects project1 and project2 in
this scenario.
• The highlighted areas in the POST for tenant T2 show the credentials that are shared with the first user tenant
POST https://<cloud-apic-ip-address>/api/mo/uni.xml
<fvTenant name="T1">
<cloudAccount id="project1" vendor="gcp" accessType="credentials" >
<cloudRsCredentials tDn="uni/tn-T1/credentials-creds1" />
</cloudAccount>
<cloudCredentials name="creds1" keyId="de22a1bc-7872-4651-9d09-c5d820af7e1c"
rsaPrivateKey="-----BEGIN .... -----END PRIVATE KEY-----\n" clientId="28763876"
email="[email protected]"/>
<fvRsCloudAccount tDn="uni/tn-T1/acct-[project1]-vendor-gcp"/>
</fvTenant>
<fvTenant name="T2">
<cloudAccount id="project2" vendor="gcp" accessType="credentials" >
<cloudRsCredentials tDn="uni/tn-T2/credentials-creds1" />
</cloudAccount>
<cloudCredentials name="creds1" keyId="de22a1bc-7872-4651-9d09-c5d820af7e1c"
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
97
Configuring Cisco Cloud APIC Components
Configuring Inter-VRF Route Leaking Using the REST API
rsaPrivateKey="-----BEGIN .... -----END PRIVATE KEY-----\n" clientId="28763876"
email="[email protected]"/>
<fvRsCloudAccount tDn="uni/tn-T2/acct-[project2]-vendor-gcp"/>
</fvTenant>
Step 2
To create a user tenant where the Cloud APIC runs outside of Google Cloud (the infra tenant with credentials):
Note that the new properties added specifically for Google Cloud are highlighted below.
POST https://<cloud-apic-ip-address>/api/mo/uni.xml
<fvTenant name="infra">
<cloudAccount id="project1" vendor="gcp" accessType="credentials" >
<cloudRsCredentials tDn="uni/tn-infra/credentials-creds1" />
</cloudAccount>
<cloudCredentials name="creds1" keyId="de22a1bc-7872-4651-9d09-c5d820af7e1c"
rsaPrivateKey="-----BEGIN .... -----END PRIVATE KEY-----\n" clientId="28763876"
email="[email protected]"/>
<fvRsCloudAccount tDn="uni/tn-infra/acct-[project1]-vendor-gcp"/>
</fvTenant>
<fvTenant name="T2">
<cloudAccount id="project2" vendor="gcp" accessType="credentials" >
<cloudRsCredentials tDn="uni/tn-infra/credentials-creds1" />
</cloudAccount>
<fvRsCloudAccount tDn="uni/tn-T2/acct-[project2]-vendor-gcp"/>
</fvTenant>
Step 3
To create a managed user tenant where the user shares the infra service account across multiple Google Cloud projects:
POST https://<cloud-apic-ip-address>/api/mo/uni.xml
<fvTenant name="infra">
<cloudAccount id="project1" vendor="gcp" accessType="managed" />
<fvRsCloudAccount tDn="uni/tn-infra/acct-[project1]-vendor-gcp"/>
</fvTenant>
<fvTenant name="T2">
<cloudAccount id="project2" vendor="gcp" accessType="managed" />
<fvRsCloudAccount tDn="uni/tn-T2/acct-[project2]-vendor-gcp"/>
</fvTenant>
Configuring Inter-VRF Route Leaking Using the REST API
This example demonstrates how to configure leak routes for the Cloud APIC using the REST API. This
example shows how to configure inter-VRF route leaking, between an external VRF and a cloud VRF, as
shown in the following figure.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
98
Configuring Cisco Cloud APIC Components
Configuring Inter-VRF Route Leaking Using the REST API
To configure inter-VRF route leaking for this example:
Example:
<polUni>
<fvTenant name="t1">
<fvCtx name="VRF1">
<leakRoutes>
<leakInternalPrefix ip="0.0.0.0/0" status="">
<leakTo tenantName="infra" ctxName="Ext-VRF2" scope="public" status=""/>
</leakInternalPrefix>
</leakRoutes>
</fvCtx>
<cloudCtxProfile name="v1-us-west1" type="regular" vpcGroup="one" status="">
<cloudRsToCtx tnFvCtxName="VRF1"/>
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-west1"/>
<cloudCidr addr="100.100.0.0/16" primary="yes">
<cloudSubnet ip="100.100.100.0/20" scope="public,shared" subnetGroup="one">
<cloudRsZoneAttach tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
</fvTenant>
<fvTenant name="infra" status="">
<fvCtx name="Ext-VRF2">
<leakRoutes>
<leakExternalPrefix ip="0.0.0.0/0" status="">
<leakTo tenantName="t1" ctxName="VRF1" scope="public" status=""/>
</leakInternalPrefix>
</leakRoutes>
</fvCtx>
</fvTenant>
</polUni>
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
99
Configuring Cisco Cloud APIC Components
Creating a Filter Using the REST API
Creating a Filter Using the REST API
This section demonstrates how to create a filter using the REST API.
To create a filter:
https://<IP_Address>/api/node/mo/.xml
<?xml version="1.0" encoding="UTF-8"?>
<!-- api/node/mo/uni/.xml -->
<polUni>
<fvTenant name="t15">
<vzFilter name="rule1">
<vzEntry etherT="ip" dToPort="22" prot="tcp" dFromPort="22" name="ssh"/>
<vzEntry etherT="ip" prot="unspecified" name="any"/>
</vzFilter>
<vzFilter name="rule2">
<vzEntry etherT="ip" dToPort="http" prot="tcp" dFromPort="http" name="http"/>
</vzFilter>
<vzFilter name="rule3">
<vzEntry etherT="ip" dToPort="22" prot="tcp" dFromPort="22" name="ssh"/>
</vzFilter>
<vzFilter name='all_rule'>
<vzEntry etherT="ip" prot="unspecified" name="any"/>
</vzFilter>
<vzBrCP name="c1">
<vzSubj name="c1">
<vzRsSubjFiltAtt tnVzFilterName="rule2"/>
<vzRsSubjGraphAtt tnVnsAbsGraphName="c13_g1"/>
<vzRsSubjFiltAtt tnVzFilterName="rule3"/>
<vzRsSubjFiltAtt tnVzFilterName="all_rule"/>
</vzSubj>
</vzBrCP>
</fvTenant>
</polUni>
Creating a Contract Using the REST API
This example demonstrates how to create a contract for the Cisco Cloud APIC using the REST API.
Before you begin
Create filters.
To create a contract:
<polUni>
<fvTenant name="t2" status="">
<vzFilter descr="" name="http-family-destination" ownerKey="" ownerTag="">
<vzEntry name="http" prot="tcp" etherT="ip" dFromPort="http" dToPort="http"/>
<vzEntry name="https" prot="tcp" etherT="ip" dFromPort="https" dToPort="https"/>
</vzFilter>
<vzBrCP name="httpFamily">
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
100
Configuring Cisco Cloud APIC Components
Creating a Cloud Context Profile Using the REST API
<vzSubj name="default" revFltPorts="yes" targetDscp="unspecified">
<vzRsSubjFiltAtt action="permit" directives="" tnVzFilterName="http-family-destination"/>
</vzSubj>
</vzBrCP>
</fvTenant>
</polUni>
Note the following restrictions for the name of the contract (the vzBrCP entry):
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters must be hyphens,
lowercase letters, or digits, except the last character, which cannot be a hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions imposed by the Google
Cloud firewall rules. Refer to Naming Length Restrictions Imposed By Google Cloud Firewall Rules, on page 26
to better understand the restriction and the total number of characters allowed for each of the Cisco Cloud APIC
components that make up the firewall rule name.
Creating a Cloud Context Profile Using the REST API
This section demonstrates how to create a cloud context profile.
Before you begin
Create a VRF.
Step 1
To create a basic cloud context profile:
Example:
<?xml version="1.0" encoding="UTF-8"?>
<!-- api/node/mo/uni/.xml -->
<polUni>
<fvTenant name="tn15">
<cloudCtxProfile name="cProfilewest1151">
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-west1"/>
<cloudRsToCtx tnFvCtxName="ctx151"/>
<cloudCidr addr="15.151.0.0/16" primary="true" status="">
<cloudSubnet ip="15.151.1.0/24" name="GatewaySubnet" usage="gateway">
<cloudRsZoneAttach tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
<cloudSubnet ip="15.151.2.0/24" name="albsubnet" >
<cloudRsZoneAttach tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
<cloudSubnet ip="15.151.3.0/24" name="subnet" usage="">
<cloudRsZoneAttach tDn="uni/clouddomp/provp-gcp/region-us-west1/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
</fvTenant>
</polUni>
Step 2
To create a cloud context profile where you are adding a secondary VRF, CIDR, and subnet for a VNet:
Example:
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
101
Configuring Cisco Cloud APIC Components
Creating an Application Profile Using the REST API
<?xml version="1.0" encoding="UTF-8"?>
<!-- api/node/mo/uni/.xml -->
<polUni>
<fvTenant name="tenant1" status="">
<fvCtx name="VRF1" />
<fvCtx name="VRF2” />
<cloudCtxProfile name="vpc1" status="">
<cloudRsCtxProfileToRegion tDn="uni/clouddomp/provp-gcp/region-us-central1" status=""/>
<cloudRsToCtx tnFvCtxName="VRF1" />
<cloudRsCtxProfileToGatewayRouterP tDn="uni/tn-infra/gwrouterp-default" status=""/>
<cloudCidr name="cidr1" addr="192.0.2.0/16" primary="yes" status="">
<cloudSubnet ip="192.0.3.0/24" usage="gateway" status="">
<cloudRsZoneAttach status=""
tDn="uni/clouddomp/provp-gcp/region-us-central1/zone-default"/>
</cloudSubnet>
</cloudCidr>
<cloudCidr name="cidr1" addr="193.0.2.0/16" primary="no" status="">
<cloudSubnet ip="193.0.3.0/24" usage="" status="">
<cloudRsSubnetToCtx tnFvCtxName="VRF2"/>
<cloudRsZoneAttach status=""
tDn="uni/clouddomp/provp-gcp/region-us-central1/zone-default"/>
</cloudSubnet>
</cloudCidr>
</cloudCtxProfile>
</fvTenant>
</polUni>
Creating an Application Profile Using the REST API
This section demonstrates how to create an application profile using the REST API.
Before you begin
Create a tenant.
To create an application profile:
https://<IP_Address>/api/node/mo/.xml
<?xml version="1.0" encoding="UTF-8"?>
<!-- api/node/mo/uni/.xml -->
<polUni>
<fvTenant name="tn15">
<fvRsCloudAccount tDn="uni/tn-infra/act-[<gcp-id>]-vendor-gcp" />
<fvCtx name="ctx151"/>
<cloudVpnGwPol name="VgwPol1"/>
<cloudApp name="a1">
</cloudApp>
</fvTenant>
</polUni>
For the application profile name, note the following restrictions:
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
102
Configuring Cisco Cloud APIC Components
Creating an EPG Using the REST API
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters must be hyphens,
lowercase letters, or digits, except the last character, which cannot be a hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions imposed by the Google
Cloud firewall rules. Refer to Naming Length Restrictions Imposed By Google Cloud Firewall Rules, on page 26
to better understand the restriction and the total number of characters allowed for each of the Cisco Cloud APIC
components that make up the firewall rule name.
Creating an EPG Using the REST API
Use the procedures in this section to create an application EPG or an external EPG using the REST API.
Creating a Cloud EPG Using the REST API
This example demonstrates how to create a cloud EPG using the REST API.
Before you begin
Create an application profile and a VRF.
To create a cloud EPG:
<?xml version="1.0" encoding="UTF-8"?>
<!-- api/node/mo/uni/.xml -->
<polUni>
<fvTenant name="tn15">
<fvRsCloudAccount tDn="uni/tn-infra/act-[<gcp-id>]-vendor-gcp" />
<fvCtx name="ctx151"/>
<cloudVpnGwPol name="VgwPol1"/>
<cloudApp name="a1">
<cloudEPg name="epg1">
<cloudRsCloudEPgCtx tnFvCtxName="ctx151"/>
<cloudEPSelector matchExpression="custom:tag1=='value1'" name="selector-1"/>
</cloudEPg>
</cloudApp>
</fvTenant>
</polUni>
Note the following restrictions:
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
103
Configuring Cisco Cloud APIC Components
Creating an External Cloud EPG Using the REST API
This means that the first character must be a lowercase letter, and all the following characters must be hyphens,
lowercase letters, or digits, except the last character, which cannot be a hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions imposed by the Google
Cloud firewall rules. Refer to Naming Length Restrictions Imposed By Google Cloud Firewall Rules, on page 26
to better understand the restriction and the total number of characters allowed for each of the Cisco Cloud APIC
components that make up the firewall rule name.
Creating an External Cloud EPG Using the REST API
This example demonstrates how to create an external cloud EPG using the REST API.
For the name of the external EPG, note the following restrictions:
• Match the regular expression:
[a-z]([-a-z0-9]*[a-z0-9])?
This means that the first character must be a lowercase letter, and all the following characters must be
hyphens, lowercase letters, or digits, except the last character, which cannot be a hyphen.
• We recommend using 14 characters or fewer for this name, if possible, due to the restrictions imposed
by the Google Cloud firewall rules. Refer to Naming Length Restrictions Imposed By Google Cloud
Firewall Rules, on page 26 to better understand the restriction and the total number of characters allowed
for each of the Cisco Cloud APIC components that make up the firewall rule name.
Before you begin
Create an application profile and a VRF.
Step 1
To create an external cloud EPG:
Example:
<?xml version="1.0" encoding="UTF-8"?>
<!-- api/node/mo/uni/.xml -->
<polUni>
<fvTenant name="tn15">
<fvRsCloudAccount tDn="uni/tn-infra/act-[<gcp-id>]-vendor-gcp" />
<fvCtx name="ctx151"/>
<cloudVpnGwPol name="VgwPol1"/>
<cloudApp name="a1">
<cloudExtEPg routeReachability="internet" name="extEpg-1">
<fvRsCons tnVzBrCPName="extEpg-1"/>
<cloudRsCloudEPgCtx tnFvCtxName="ctx151"/>
<cloudExtEPSelector name="extSelector1" subnet="0.0.0.0/0"/>
</cloudExtEPg>
</cloudApp>
</fvTenant>
</polUni>
Step 2
To create an external cloud EPG with type site-external, or an infra L3Out EPG:
Example:
<?xml version="1.0" encoding="UTF-8"?>
<!-- api/node/mo/uni/.xml -->
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
104
Configuring Cisco Cloud APIC Components
Creating Cloud Routers, External Networks, and External VRFs Using the REST API
<polUni>
<fvTenant name="infra">
<cloudApp name="a1">
<cloudExtEPg routeReachability="site-ext" name="extEpg-1">
<fvRsCons tnVzBrCPName="extEpg-1"/>
<cloudRsCloudEPgCtx tnFvCtxName="ctx152"/>
<cloudExtEPSelector name="extSelector1" subnet="10.100.0.0/16"/>
</cloudExtEPg>
</cloudApp>
</fvTenant>
</polUni>
Creating Cloud Routers, External Networks, and External VRFs Using the REST
API
This section demonstrates how to create cloud routers, external networks, and external VRFs using the REST
API.
Following is an example POST that shows how to bring up the cloud router in four regions and add an external network
with an external VRF in each region.
<polUni>
<fvTenant name="infra" status="">
<fvCtx name="extv1" pcEnfPref="enforced" status=""/>
<fvCtx name="extv2" pcEnfPref="enforced" status=""/>
<fvCtx name="extv3" pcEnfPref="enforced" status=""/>
<cloudtemplateInfraNetwork name="default" vrfName="overlay-1" hostRouterMode="manual"
status="">
<cloudtemplateIpSecTunnelSubnetPool subnetpool= "169.254.7.0/24" poolname="pool1" />
<cloudtemplateIpSecTunnelSubnetPool subnetpool= "169.254.8.0/24" poolname="pool2" />
<cloudtemplateIpSecTunnelSubnetPool subnetpool= "169.254.10.0/24" poolname="pool3" />
<cloudtemplateHubNetwork name="default" status="" >
<cloudtemplateHubNetworkName name="foo1" asn="64514" status="">
<cloudRegionName provider="gcp" region="us-west4" status="" />
<cloudRegionName provider="gcp" region="us-west2" status="" />
<cloudRegionName provider="gcp" region="us-east1" status="" />
<cloudRegionName provider="gcp" region="us-west1" status=""/>
</cloudtemplateHubNetworkName>
</cloudtemplateHubNetwork>
<cloudtemplateIntNetwork name="default">
<cloudRegionName provider="gcp" region="us-west1">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
<cloudRegionName provider="gcp" region="us-west2">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
<cloudRegionName provider="gcp" region="us-east1">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
<cloudRegionName provider="gcp" region="us-west4">
<cloudtemplateVpnRouter name="default" status=""/>
</cloudRegionName>
</cloudtemplateIntNetwork>
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
105
Configuring Cisco Cloud APIC Components
Creating Cloud Routers, External Networks, and External VRFs Using the REST API
<cloudtemplateExtNetwork name="default">
</cloudtemplateExtNetwork>
<cloudtemplateExtNetwork name="extnwfoo1" vrfName="extv1" hubNetworkName="foo1"
vpnRouterName="default" status="">
<cloudRegionName provider="gcp" region="us-west1" status=""/>
<cloudtemplateVpnNetwork name="onprem01" remoteSiteId="1" status="">
<cloudtemplateIpSecTunnel peeraddr="128.1.1.1" preSharedKey="abcd" poolname="pool1"
status="">
<cloudtemplateBgpIpv4 peeraddr="0.0.0.0/0" peerasn="64529" status=""/>
</cloudtemplateIpSecTunnel>
</cloudtemplateVpnNetwork>
</cloudtemplateExtNetwork>
<cloudtemplateExtNetwork name="extnwfoo2" vrfName="extv2" hubNetworkName="foo1"
vpnRouterName="default" status="">
<cloudRegionName provider="gcp" region="us-west2" status=""/>
<cloudtemplateVpnNetwork name="onprem02" remoteSiteId="2" status="">
<cloudtemplateIpSecTunnel peeraddr="128.1.1.2" preSharedKey="def"
poolname="pool2" status="">
<cloudtemplateBgpIpv4 peeraddr="0.0.0.0/0" peerasn="64529" status=""/>
</cloudtemplateIpSecTunnel>
</cloudtemplateVpnNetwork>
</cloudtemplateExtNetwork>
<cloudtemplateExtNetwork name="extnwfoo3" vrfName="extv3" hubNetworkName="foo1"
vpnRouterName="default" status="">
<cloudRegionName provider="gcp" region="us-east1" status=""/>
<cloudtemplateVpnNetwork name="onprem03" remoteSiteId="3" status="">
<cloudtemplateIpSecTunnel peeraddr="128.1.1.3" preSharedKey="abc"
poolname="pool3" status="">
<cloudtemplateBgpIpv4 peeraddr="0.0.0.0/0" peerasn="64529" status=""/>
</cloudtemplateIpSecTunnel>
</cloudtemplateVpnNetwork>
</cloudtemplateExtNetwork>
</cloudtemplateInfraNetwork>
</fvTenant>
</polUni>
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
106
CHAPTER
6
Viewing System Details
• Monitoring VM Host Metrics, on page 107
• Viewing Application Management Details, on page 110
• Viewing Cloud Resource Details, on page 111
• Viewing Operations Details, on page 112
• Viewing Infrastructure Details, on page 114
• Viewing Administrative Details, on page 114
• Viewing Health Details Using the Cisco Cloud APIC GUI, on page 116
Monitoring VM Host Metrics
Beginning with release 25.0(1), support is available for monitoring metrics for the VM host where the Cisco
Cloud APIC is deployed using the Prometheus Node Exporter. The Prometheus Node Exporter provides
visibility to a wide variety of hardware and kernel-related metrics, where it collects technical information
from Linux nodes, such as CPU, disk, and memory statistics. For overview information on the Prometheus
Node Exporter, see:
https://prometheus.io/docs/introduction/overview/
If your Cisco Cloud APIC is running on release 25.0(1) or later, the Prometheus Node Exporter is automatically
available by default.
Guidelines and Limitations
HTTP is not supported for monitoring metrics using the Prometheus Node Exporter. Only HTTPS is supported
for monitoring metrics using the Prometheus Node Exporter.
Monitoring VM Host Metrics Using the GUI
These procedures describe how to enable the Prometheus Node Exporter to monitor VM host metrics using
the GUI.
Step 1
In the Cisco Cloud APIC GUI, navigate to Infrastructure > System Configuration, then click on the Management
Access tab.
Step 2
In the HTTPS area to the right of the window, note the entry in the Node Exporter field.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
107
Viewing System Details
Monitoring VM Host Metrics Using the GUI
• Enabled: The Prometheus Node Exporter has already been enabled. You do not have to continue with these
instructions in that case.
• Disabled: The Prometheus Node Exporter is not enabled yet. Proceed with these instructions to enable the Prometheus
Node Exporter.
Step 3
Click the pencil icon in the HTTPS area to edit the HTTPS settings.
The HTTPS Settings window appears.
Step 4
Locate the Node Exporter field and click Enable.
A warning message appears, telling you that saving these settings will restart the web service, and that it will take a
moment for it to resume responding to requests. Click OK to confirm these changes.
Step 5
At the bottom of the window, click Save.
You are returned to the System Configuration/Management Access window. The web service reboots and comes back
online in a few seconds.
Step 6
In the HTTPS area to the right of the window, verify that the entry in the Node Exporter field is set to Enabled.
This verifies that the Prometheus Node Exporter is enabled.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
108
Viewing System Details
Monitoring VM Host Metrics Using the REST API
Step 7
Click the link under the Enabled text in the Node Exporter area.
Another tab in your browser appears, showing the metrics for the VM host where the Cisco Cloud APIC is deployed.
Monitoring VM Host Metrics Using the REST API
These procedures describe how to enable the Prometheus Node Exporter to monitor VM host metrics using
the REST API.
Step 1
To determine if the Prometheus Node Exporter is enabled or not, send the following GET call:
GET https://<cloud-apic-ip-address>/api/mo/uni/fabric/comm-default/https.xml
Locate the nodeExporter field to determine if it is set to enabled or disabled.
Step 2
To monitor VM host metrics, send the following post to enable the Prometheus Node Exporter:
POST https://<cloud-apic-ip-address>/api/mo/uni/fabric/comm-default/https.xml
<commHttps nodeExporter="enabled" />
The metrics are displayed for the VM host where the Cisco Cloud APIC is deployed.
Step 3
To view the metrics using REST API, send the following GET call:
GET https://<cloud-apic-ip-address>/nodeexporter/metrics
Step 4
To disable the Prometheus Node Exporter, send the following post:
POST https://<cloud-apic-ip-address>/api/mo/uni/fabric/comm-default/https.xml
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
109
Viewing System Details
Viewing Application Management Details
<commHttps nodeExporter="disabled" />
Viewing Application Management Details
This section explains how to view application management details using the Cisco Cloud APIC GUI. The
application management details include the information of a specific tenant, application profile, EPG, contract,
filter, VRF, cloud context profile, or external network.
Step 1
From the Navigation menu, choose the Application Management tab.
When the Application Management tab expands, a list of subtab options appear. See the Application Management
Options table for more information.
Table 25: Application Management Subtabs
Step 2
Subtab Name
Description
Tenants
Displays tenants as rows in a summary table.
Application Profiles
Displays application profiles as rows in a summary table.
EPGs
Displays an EPGs as rows in a summary table.
Contracts
Displays a contracts as rows in a summary table.
Filters
Displays filters as rows in a summary table.
VRFs
Displays VRFs as rows in a summary table.
Cloud Context Profiles
Displays cloud context profiles as rows in a summary table.
External Networks
Displays external networks as rows in a summary table.
Click the tab that represents the component with the details you want to view.
A summary table appears with items as rows in the table. For example, if you chose the Tenants subtab, a list of tenants
appear as rows in a summary table
You can filter the rows by clicking the Filter by Attributes bar. Choose the attribute, operator and filter-value. For example,
for filtering based on a tenant, choose Name == T1 (where T1 is the name of a tenant).
Step 3
To view a summary pane, click the row that represents the specific component you want to view.
Step 4
For more information, double-click the summary table row that represents the specific component you want to view.
A new dialog box appears over the work pane with any of the following tabs:
Note
The tabs that appear differ between components and configurations.
• Overview—Provides a general overview of cloud resources, configuration relationships, and settings of the component.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
110
Viewing System Details
Viewing Cloud Resource Details
• Topology —Provides visual relationship between an object and other related objects. The chosen object is displayed
at the center.
• Cloud Resources—Contains a list of subtabs that display the cloud resource information related to the component.
• Application Management—Contains a list of subtabs that display the ACI relation information related to the
component.
• Event Analytics—Contains a list of subtabs that display faults, events, and audit logs.
Note
The dialog box that appears over the work pane contains an edit button in the top-right corner between the
refresh button and the Actions button. When clicked, the edit button enables you to edit the chosen component.
Viewing Cloud Resource Details
This section explains how to view cloud resource details using the Cisco Cloud APIC GUI. The cloud resource
details include the information about a specific region, VPC, router, security group (application security
group/network security group), endpoint, VM, and cloud service.
Step 1
From the Navigation menu, choose the Cloud Resources tab.
When the Cloud Resources tab expands, a list of subtab options appear. See the Cloud Resource Options table for more
information.
Table 26: Cloud Resource Subtabs
Step 2
Subtab Name
Description
Regions
Displays regions as rows in a summary table.
VPCs
Displays VPCs as rows in a summary table.
Routers
Displays routers as rows in a summary table.
Endpoints
Displays endpoints as rows in a summary table.
Instances
Displays instances as rows in a summary table.
Click the tab that represents the component with the details you want to view.
A summary table appears with items as rows in the table. For example, if you chose the Endpoints subtab, a list of
endpoints appear as rows in a summary table.
You can filter the rows by selecting an attribute from the drop-down menu when you click the Filter by attributes bar.
The attributes displayed in the drop-down menu depend on the selected subtab.
For the Endpoints subtab, you can narrow down the search based on a cloud tag, by entering a key or value term. If you
want to search based on both terms, click the (+) displayed as a superscript to the key or value term (depending on which
was entered first). Cloud tag filters cannot be edited. To modify a search, first delete the filters, and then enter the desired
key or value term again. Search based on multiple cloud tag filters is supported.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
111
Viewing System Details
Viewing Operations Details
Step 3
To view a summary pane, click the row that represents the specific component you want to view.
Step 4
For more information, double-click the summary table row that represents the specific component you want to view.
A new dialog box appears over the work pane with any of the following tabs:
Note
The tabs that appear differ between components and configurations.
• Overview—Provides a general overview of cloud resources, configuration relationships, and settings of the component,
including the cloud tags associated with endpoints.
• Cloud Resources—Contains a list of subtabs that display the cloud resource information related to the component.
• Application Management—Contains a list of subtabs that display the ACI relation information related to the
component.
• Event Analytics—Contains a list of subtabs that display faults, events, and audit logs.
Viewing Operations Details
This section explains how to view operations details using the Cisco Cloud APIC GUI. The operations details
include the information of a specific fault, event, audit log, active sessions, backup and restore policies, tech
support policies, firmware management, scheduler policies, and remote locations.
Step 1
From the Navigation menu, choose the Operations tab.
When the Operations tab expands, a list of subtab options appear. See the Operations Options table for more information.
Table 27: Operations Subtabs
Subtab Name
Description
Event Analytics
Contains the following subtabs:
• Faults Tab—Displays faults as rows in a summary
table.
• Fault Records Tab—Displays fault records as rows
in a summary table.
• Events Tab—Displays events as rows in a summary
table.
• Audit Logs Tab—Displays audit logs as rows in a
summary table.
Active Sessions
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
112
Displays a list of active users who are logged into Cloud
APIC.
Viewing System Details
Viewing Operations Details
Subtab Name
Description
Backup & Restore
Contains the following subtabs:
• Backups Tab—Displays backup as rows in a summary
table.
• Backup Policies Tab—Displays backup policies as
rows in a summary table.
• Job Status Tab—Displays the job status as rows in a
summary table.
• Event Analytics Tab—Contains the following subtabs:
• Faults Tab—Displays faults as rows in a
summary table.
• Events Tab—Displays events as rows in a
summary table.
• Audit Logs Tab—Displays audit logs as rows in
a summary table.
Tech Support
Contains the following subtabs:
• Tech SupportTab—Displays tech support policies as
rows in a summary table.
• Core Logs Tab—Displays core logs as rows in a
summary table.
Firmware Management
Contains the following subtabs:
• Controllers Tab—Displays general firmware
management information, such as Current Firmware
Version, Upgrade Status, and so on.
• Images Tab—Displays a list of images.
• Event Analytics Tab—Contains the following subtabs:
• Faults Tab—Displays faults as rows in a
summary table.
• Events Tab—Displays events as rows in a
summary table.
• Audit Logs Tab—Displays audit logs as rows in
a summary table.
Step 2
Schedulers
Displays scheduler policies as rows in a summary table.
Remote Locations
Displays remote locations as rows in a summary table.
Click the tab that represents the component you want to view.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
113
Viewing System Details
Viewing Infrastructure Details
A summary table appears with items as rows in the table. For example, if you chose the Active Sessions subtab, a list of
active sessions appear as rows in a summary table.
You can filter the rows by clicking the Filter by Attributes bar. Choose the attribute, operator and filter-value. For example,
for filtering based on a username, choose username == user1 (where user1 is a user logged into Cloud APIC).
Step 3
To view a summary pane, click the row that represents the specific component you want to view.
Step 4
For more information, double-click the summary table row that represents the specific item you want to view.
A new dialog box appears over the work pane that displays additional information about the item you chose from the
summary table.
Viewing Infrastructure Details
This section explains how to view infrastructure details using the Cisco Cloud APIC GUI. The infrastructure
details include information about system configuration, inter-region connectivity, and external connectivity.
Step 1
From the Navigation menu, choose the Infrastructure tab.
When the Infrastructure tab expands, a list of subtab options appear. See the Infrastructure Options table for more
information.
Table 28: Infrastructure Subtabs
Step 2
Subtab Name
Description
System Configuration
Displays General system configuration information,
Management Access information, Controllers, and Event
Analytics.
External Connectivity
Displays one pane with a map that contains the inter-region
connectivity view.
Click the tab that represents the component with the details you want to view.
Viewing Administrative Details
This section explains how to view administrative details using the Cisco Cloud APIC GUI. The administrative
details include the information about authentication, security, users, and smart licensing..
Step 1
From the Navigation menu, choose the Administrative tab.
When the Administrative tab expands, a list of subtab options appear. See the Administrative Options table for more
information.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
114
Viewing System Details
Viewing Administrative Details
Table 29: Administrative Subtabs
Subtab Name
Description
Authentication
Displays the Authentication Default Settings, Login
Domains, Providers and Event Analytics subtabs, which
contain the information described below:
• Authentication Default Settings Tab—Displays
settings information.
• Login Domains Tab—Displays the login domains as
rows in a summary table.
• Providers Tab—Displays the providers as rows in a
summary table.
• Event Analytics Tab—Displays the Faults, Events,
and Audit Logs subtabs, each with the corresponding
information displayed as rows in a summary table.
Security
Contains the following list of subtabs:
• Security Default Settings Tab—Enables you to view
the default security settings information.
• Security Domains Tab—Enables you to view security
domain information in a summary table.
• Roles Tab—Enables you to view the role information
in a summary table.
• RBAC Rules Tab—Enables you to view RBAC rule
information in a summary table.
• Certificate Authorities Tab—Enables you to view
the certificate authority information in a summary
table.
• Key Rings Tab—Enables you to view key ring
information in a summary table.
• User Activity Tab—Enables you to view user activity.
Users
Contains the following subtabs:
• Local Tab—Displays local users as rows in a summary
table.
• Remote Tab—Displays remote users as rows in a
summary table.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
115
Viewing System Details
Viewing Health Details Using the Cisco Cloud APIC GUI
Subtab Name
Description
Smart Licensing
Contains the following subtabs:
• General Tab—Displays the licenses as rows in a
summary table.
• CSRs Tab—Displays CSRs as rows in a summary
table.
• Faults Tab—Displays faults as rows in a summary
table.
Step 2
Click the tab that represents the component you want to view.
For some options, a summary table appears with items as rows in the table (For example, if you choose the Users tab, a
list of users appear as rows in a summary table). To view a summary pane, click the row that represents the specific
component you want to view. To view more information, double-click the summary table row that represents the specific
item you want to view. A new dialog box appears over the work pane that displays additional information about the item
you chose from the summary table.
You can filter the rows by clicking the Filter by Attributes bar. Choose the attribute, operator and filter-value. For example,
for filtering based on a user, choose User ID == admin (where admin is a user ID. ).
Viewing Health Details Using the Cisco Cloud APIC GUI
This section explains how to view health details using the Cisco Cloud APIC GUI. You can view health details
for any object that you can see in the Cloud Resources area in the Cisco Cloud APIC GUI, such as the following:
• Regions
• VPCs
• Endpoints
• Instances
Step 1
From the Navigation menu, choose the Dashboard tab.
The Dashboard window for the Cisco Cloud APIC system appears. From this window, you can view the overall health
status of your system.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
116
Viewing System Details
Viewing Health Details Using the Cisco Cloud APIC GUI
Step 2
Click within the Fault Summary area in the Dashboard window.
The Event Analytics window appears, showing more detailed information for the specific fault level that you clicked.
The following screen shows an example Event Analytics window for the faults listed with critical severity.
Step 3
Click the X next to the Severity level to display Event Analytics information for all faults.
The information provided in the Event Analytics window changes to show the events with critical, major, and warning
levels of severity.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
117
Viewing System Details
Viewing Health Details Using the Cisco Cloud APIC GUI
Step 4
From the Navigation menu, choose the Cloud Resources tab.
When the Cloud Resources tab expands, a list of subtab options appear. See the Administrative Options table for more
information.
Step 5
Choose any item under the Cloud Resources tab to display health information for that component.
For example, the following figure shows health information that might be displayed when you click on Cloud Resources >
Regions. The health of each region is displayed in the left column of the table in the Regions window.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
118
Viewing System Details
Viewing Health Details Using the Cisco Cloud APIC GUI
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
119
Viewing System Details
Viewing Health Details Using the Cisco Cloud APIC GUI
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
120
CHAPTER
7
Cisco Cloud APIC Security
This chapter contains the following sections:
• Access, Authentication, and Accounting, on page 121
• Configuring TACACS+, RADIUS, LDAP and SAML Access, on page 122
• Configuring HTTPS Access, on page 130
Access, Authentication, and Accounting
Cisco Cloud Application Policy Infrastructure Controller (Cloud APIC) policies manage the authentication,
authorization, and accounting (AAA) functions. The combination of user privileges, roles, and domains with
access rights inheritance enables administrators to configure AAA functions at the managed object level in a
granular fashion. These configurations can be implemented using the REST API or the GUI.
Note
There is a known limitation where you cannot have more than 32 characters for the login domain name. In
addition, the combined number of characters for the login domain name and the user name cannot exceed 64
characters.
For more access, authentication, and accounting configuration information, see Cisco APIC Security
Configuration Guide, Release 4.0(1) at https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/
sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Configuration
The admin account is configured in the initial configuration script, and the admin is the only user when the
system starts.
Configuring a Local User
Refer to Creating a Local User Using the Cisco Cloud APIC GUI, on page 93 to configure a Local User and
associate it to the OTP, SSH Public Key, and X.509 User Certificate using the Cloud APIC GUI.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
121
Cisco Cloud APIC Security
Configuring TACACS+, RADIUS, LDAP and SAML Access
Configuring TACACS+, RADIUS, LDAP and SAML Access
The following topics describe how to configure TACACS+, RADIUS, LDAP and SAML access for the Cloud
APIC.
Overview
This topic provides step-by-step instructions on how to enable access to the Cloud APIC for RADIUS,
TACACS+, LDAP, and SAML users, including ADFS, Okta, and PingID.
For additional TACACS+, RADIUS, LDAP, and SAML information, see Cisco APIC Security Configuration
Guide, Release 4.0(1) at https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/
Cisco-APIC-Security-Configuration-Guide-401.html.
Configuring Cloud APIC for TACACS+ Access
Before you begin
• The Cloud Application Policy Infrastructure Controller (Cloud APIC) is online.
• The TACACS+ server host name or IP address, port, and key are available.
• The Cloud APIC management endpoint group is available.
Step 1
In the Cloud APIC, create the TACACS+ Provider.
a) On the menu bar, choose Administrative > Authentication.
b) In the Work pane, click on Providers tab and then click on the Actions drop-down and select Create Provider.
The Create Provider dialog box appears.
c)
d)
e)
f)
Step 2
In the Host Name/IP Address field, enter the Host Name/IP Address of the provider.
In the Description field, enter a description of the provider.
Click the Type drop-down list and choose TACACS+.
In Settings section, specify the Key and Confirm Key, Port, Authentication Protocol, Timeout, Retries,
Management EPG. Select either Enabled or Disabled for Server Monitoring.
Create the Login Domain for TACACS+.
a) On the menu bar, choose Administrative > Authentication.
b) In the Work pane, click on Login Domains tab and then click on the Actions drop-down and select Create Login
Domain.
The Create Login Domain dialog box appears.
c) Enter the appropriate values in each field as listed in the following Create Login Domain Dialog Box Fields table
then continue.
Properties
General
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
122
Description
Cisco Cloud APIC Security
Configuring Cloud APIC for RADIUS Access
Properties
Description
Name
Enter the name of the Login Domain
Description
Enter the description of the Login Domain.
Settings
Realm
Choose TACACS+ from the dropdown menu
Providers
To choose a Provider(s):
1. Click Add Providers. The Select Providers dialog
appears.
2. Click to choose a provider(s) in the column on the
left.
3. Click Select. You return to the Create Login Domain
dialog box.
d) Click Save to save the configuration.
What to do next
This completes the TACACS+ configuration steps. Next, if a RADIUS server will also be used, configure
the Cloud APIC for RADIUS.
Configuring Cloud APIC for RADIUS Access
Before you begin
• The Cloud Application Policy Infrastructure Controller (Cloud APIC) is online.
• The RADIUS server host name or IP address, port, and key are available.
• The Cloud APIC management endpoint group is available.
Step 1
In the Cloud APIC, create the RADIUS Provider.
a) On the menu bar, choose Administrative > Authentication.
b) In the Work pane, click on Providers tab and then click on the Actions drop-down and select Create Provider.
The Create Provider dialog box appears.
c)
d)
e)
f)
In the Host Name/IP Address field, enter the Host Name/IP Address of the provider.
In the Description field, enter a description of the provider.
Click the Type drop-down list and choose RADIUS.
In the Settings section, specify the Key and Confirm Key, Port, Authentication Protocol, Timeout, Retries,
Management EPG. Select either Enabled or Disabled for Server Monitoring.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
123
Cisco Cloud APIC Security
Configuring a Cisco Secure Access Control Server for RADIUS and TACACS+ Access to the Cloud APIC
Step 2
Create the Login Domain for RADIUS.
a) On the menu bar, choose Administrative > Authentication.
b) In the Work pane, click on Login Domains tab and then click on the Actions drop-down and select Create Login
Domain.
The Create Login Domain dialog box appears.
c) Enter the appropriate values in each field as listed in the following Create Login Domain Dialog Box Fields table
then continue.
Properties
Description
General
Name
Enter the name of the Login Domain
Description
Enter the description of the Login Domain.
Settings
Realm
Choose RADIUS from the dropdown menu
Providers
To choose a Provider(s):
1. Click Add Providers. The Select Providers dialog
appears.
2. Click to choose a provider(s) in the column on the
left.
3. Click Select. You return to the Create Login Domain
dialog box.
d) Click Save to save the configuration.
What to do next
This completes the Cloud APIC RADIUS configuration steps. Next, configure the RADIUS server.
Configuring a Cisco Secure Access Control Server for RADIUS and TACACS+
Access to the Cloud APIC
Refer to the section Configuring a Cisco Secure Access Control Server for RADIUS and TACACS+ Access to the APICin
the Cisco APIC Security Configuration Guide, Release 4.0(1) at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
124
Cisco Cloud APIC Security
Configuring LDAP Access
Configuring LDAP Access
There are two options for LDAP configurations:
• Configure a Cisco AVPair
• Configure LDAP group maps in the cloud APIC
The following sections contain instructions for both configuration options.
Configuring Windows Server 2008 LDAP for APIC Access with Cisco AVPair
Refer to the section Configuring Windows Server 2008 LDAP for APIC Access with Cisco AVPair in the Cisco APIC
Security Configuration Guide, Release 4.0(1) at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Configuring Cloud APIC for LDAP Access
Before you begin
• The Cloud Application Policy Infrastructure Controller (Cloud APIC) is online.
• The LDAP server host name or IP address, port, bind DN, Base DN, and password are available.
• The cloud APIC management endpoint group is available.
Step 1
In the Cloud APIC, create the LDAP Provider.
a) On the menu bar, choose Administrative > Authentication.
b) In the Work pane, click on Providers tab and then click on the Actions drop-down and select Create Provider.
The Create Provider dialog box appears.
c)
d)
e)
f)
In the Host Name/IP Address field, enter the Host Name/IP Address of the provider.
In the Description field, enter a description of the provider.
Click the Type drop-down list and choose LDAP.
Specify the Bind DN, Base DN, Password, Confirm Password, Port, Timeout, Retries, SSL, SSL Certificate
Validation Level, Attribute, Filter Type, Management EPG, and Server Monitoring.
In the SSL Certificate Validation Level field, you have the following options:
• Permissive: A debugging knob to help diagnose DUO LDAP SSL Certificate issues.
• Strict: A level that should be used when in production.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
125
Cisco Cloud APIC Security
Configuring Cloud APIC for LDAP Access
Note
• The bind DN is the string that the Cloud APIC uses to log in to the LDAP server. The Cloud APIC
uses this account to validate the remote user attempting to log in. The base DN is the container name
and path in the LDAP server where the Cloud APIC searches for the remote user account. This is
where the password is validated. Filter is used to locate the attribute that the Cloud APIC requests to
use for the cisco-av-pair. This contains the user authorization and assigned RBAC roles for use on
the Cloud APIC. The Cloud APIC requests the attribute from the LDAP server.
• Attribute field—Enter one of the following:
• For LDAP server configurations with a Cisco AVPair, enter CiscoAVPair.
• For LDAP server configurations with an LDAP group map, enter memberOf.
Step 2
Create the Login Domain for LDAP.
a) On the menu bar, choose Administrative > Authentication.
b) In the Work pane, click on Login Domains tab and then click on the Actions drop-down and select Create Login
Domain.
c) Enter the appropriate values in each field as listed in the following Create Login Domain Dialog Box Fields table
then continue.
Properties
Description
General
Name
Enter the name of the Login Domain
Description
Enter the description of the Login Domain.
Settings
Realm
Choose LDAP from the dropdown menu
Providers
To choose a Provider(s):
1. Click Add Providers. The Select Providers dialog
appears.
2. Click to choose a provider(s) in the column on the
left.
3. Click Select. You return to the Create Login Domain
dialog box.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
126
Cisco Cloud APIC Security
Configuring Cloud APIC for SAML Access
Properties
Description
Authentication Type
1. Select Cisco AV Pairs, if provider(s) was configured
with CiscoAVPair as the Attribute.
2. Select LDAP Group Map Rules, if provider(s) was
configured with memberOf as the Attribute.
a. Click Add LDAP Group Map Rule. The dialog
box appears.
b. Specify the map rule Name, Description
(optional), and Group DN.
c. Click the + next to Add Security Domain. The
dialog box appears.
d. Select the security domain using the Select
Security Domain option.
e. Click the + to access the Role name and Role
Privilege Type (Read or Write) fields. Click
check mark.
f.
If necessary, repeat the previous step to add more
roles. Then click Add.
g. If you want to add more security domains, click
the + next to Add Security Domain, then follow
those steps again. Then click Add.
d) Click Save on Create Login Domain dialog box.
Configuring Cloud APIC for SAML Access
The following sections provide detailed information on configuring Cloud APIC for SAML access.
About SAML
Refer to the section About SAML in the Cisco APIC Security Configuration Guide, Release 4.0(1) at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Basic Elements of SAML
Refer to the section Basic Elements of SAML in the Cisco APIC Security Configuration Guide, Release
4.0(1) at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
127
Cisco Cloud APIC Security
Configuring Cloud APIC for SAML Access
Supported IdPs and SAML Components
Refer to the section Supported IdPs and SAML Components in the Cisco APIC Security Configuration
Guide, Release 4.0(1) at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Configuring Cloud APIC for SAML Access
Note
SAML based Authentication is only for Cloud APIC GUI and not for REST.
Before you begin
• The SAML server host name or IP address, and the IdP’s metadata URL are available.
• The Cloud APIC management endpoint group is available.
• Set up the following:
• Time Synchronization and NTP
• Configuring a DNS Provider Using the GUI
• Configuring a Custom Certificate for Cisco ACI HTTPS Access Using the GUI
Step 1
In the Cloud APIC, create the SAML Provider.
a)
b)
c)
d)
e)
f)
On the menu bar, choose Administrative > Authentication.
In the Work pane, click on Providers tab and then click on the Actions drop-down and select Create Provider.
In the Host Name/IP Address field, enter the Host Name/IP Address of the provider.
In the Description field, enter a description of the provider.
Click the Type drop-down list and choose SAML.
In Settings pane, perform following:
• Choose the Identity Provider option (ADFS, OKTA, or PING IDENTITY).
• Specify the IdP metadata URL:
• In case of AD FS, IdP Metadata URL is of the format https://<FQDN
ofADFS>/FederationMetadata/2007-06/FederationMetadata.xml.
• In case of Okta, to get the IdP Metadata URL, copy the link for Identity Provider Metadata URL in the
Sign On section of the corresponding SAML Application from the Okta server.
• Specify the Entity ID for the SAML-based service.
• Configure the HTTPS Proxy for Metadata URL if it is needed to access the IdP metadata URL.
• Enter a value in the GUI Redirect Banner Message (URL) field.
• Select the Certificate Authority if IdP is signed by a Private CA.
• Enter a value in the Timeout (sec) field.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
128
Cisco Cloud APIC Security
Setting Up a SAML Application in Okta
• Enter a value in the Retries field.
• Select the Signature Algorithm Authentication User Requests from the drop-down.
• Select checkbox to enable Sign SAML Authentication Requests, Sign SAML Response Message, Sign
Assertions in SAML Response, Encrypt SAML Assertions.
g) Click Save to save the configuration.
Step 2
Create the login domain for SAML.
a) On the menu bar, choose Administrative > Authentication.
b) In the Work pane, click on the Login Domains tab and then click on the Actions drop-down and select Create Login
Domain.
c) Enter the appropriate values in each field as listed in the following Create Login Domain Dialog Box Fields table
then continue.
Properties
Description
General
Name
Enter the name of the Login Domain
Description
Enter the description of the Login Domain.
Settings
Realm
Choose SAML from the dropdown menu
Providers
To choose a Provider(s):
1. Click Add Providers. The Select Providers dialog
appears.
2. Click to choose a provider(s) in the column on the
left.
3. Click Select. You return to the Create Login Domain
dialog box.
d) Click Save to save the configuration.
Setting Up a SAML Application in Okta
Refer to the section Setting Up a SAML Application in Okta of Cisco APIC Security Configuration Guide, Release
4.0(1) at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
129
Cisco Cloud APIC Security
Setting Up a Relying Party Trust in AD FS
Setting Up a Relying Party Trust in AD FS
Refer to the section Setting Up a Relying Party Trust in AD FS in the Cisco APIC Security Configuration Guide, Release
4.0(1) at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/Cisco-APIC-Security-Configuration-Guide-401.html.
Configuring HTTPS Access
The following sections describe how to configure HTTPS access.
About HTTPS Access
This article provides an example of how to configure a custom certificate for HTTPS access when using Cisco
ACI.
For more information, see the section HTTPS Access in the Cisco APIC Security Configuration Guide,
Release 4.0(1) at https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/security/
Cisco-APIC-Security-Configuration-Guide-401.html.
Guidelines for Configuring Custom Certificates
• Wild card certificates (such as *.cisco.com, which is used across multiple devices) and its associated
private key generated elsewhere are not supported on the Cisco Cloud APIC as there is no support to
input the private key or password in the Cisco Cloud APIC. Also, exporting private keys for any
certificates, including wild card certificates, is not supported.
• You must download and install the public intermediate and root CA certificates before generating a
Certificate Signing Request (CSR). Although a root CA Certificate is not technically required to generate
a CSR, Cisco requires the root CA certificate before generating the CSR to prevent mismatches between
the intended CA authority and the actual one used to sign the CSR. The Cisco Cloud APIC verifies that
the certificate submitted is signed by the configured CA.
• To use the same public and private keys for a renewed certificate generation, you must satisfy the following
guidelines:
• You must preserve the originating CSR as it contains the public key that pairs with the private key
in the key ring.
• The same CSR used for the originating certificate must be resubmitted for the renewed certificate
if you want to re-use the public and private keys on the Cisco Cloud APIC.
• Do not delete the original key ring when using the same public and private keys for the renewed
certificate. Deleting the key ring will automatically delete the associated private key used with
CSRs.
• Only one Certificate Based Root can be active per pod.
• Client Certificate based authentication is not supported for this release.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
130
Cisco Cloud APIC Security
Configuring a Custom Certificate for Cisco Cloud APIC HTTPS Access Using the GUI
Configuring a Custom Certificate for Cisco Cloud APIC HTTPS Access Using
the GUI
Determine from which authority you will obtain the trusted certification so that you can create the appropriate
Certificate Authority.
Before you begin
CAUTION: PERFORM THIS TASK ONLY DURING A MAINTENANCE WINDOW AS THERE IS A
POTENTIAL FOR DOWNTIME. Expect a restart of all web servers on Cloud APIC during this operation.
Step 1
On the menu bar, choose Administrative > Security.
Step 2
In the Work pane, click on Certificate Authorities tab and then click on the Actions drop-down and select Create
Certificate Authority.
Step 3
In the Create Certificate Authority dialog box, in the Name field, enter a name for the certificate authority and in the
Description field, enter a description.
Step 4
Select System in the Used for field.
Step 5
In the Certificate Chain field, copy the intermediate and root certificates for the certificate authority that will sign the
Certificate Signing Request (CSR) for the Cloud Application Policy Infrastructure Controller (Cloud APIC). The
certificate should be in Base64 encoded X.509 (CER) format. The intermediate certificate is placed before the root CA
certificate. It should look similar to the following example:
-----BEGIN CERTIFICATE----<Intermediate Certificate>
-----END CERTIFICATE---------BEGIN CERTIFICATE----<Root CA Certificate>
-----END CERTIFICATE-----
Step 6
Click Save.
Step 7
On the menu bar, choose Administrative > Security.
Step 8
In the Work pane, click on the Key Rings tab, then click on the Actions drop-down and select Create Key Ring.
Step 9
In the Create Key Ring dialog box, enter a name for the key ring in the Name field and a description in the Description
field.
Step 10
Select System in the Used for field.
Step 11
For the Certificate Authority field, click on Select Certificate Authorityand select the Certificate Authority that you
created earlier.
Step 12
Select either Generate New Key or Import Existing Key for the field Private Key. If you select Import Existing
Key, enter a private key in the Private Key text box.
Step 13
Select modulus from the Modulus drop-down. menu
Step 14
In the Certificate field, do not add any content.
Step 15
Click Save.
In the Work pane, in the Key Rings area, the Admin State for the key ring created displays Started.
Step 16
Double-click on the created Key Ring to open Key Ring key_ring_name dialog box from the Work pane.
Step 17
In the Work pane, click on Create Certificate Request.
Step 18
In the Subject field, enter the fully qualified domain name (FQDN) of the Cloud APIC.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
131
Cisco Cloud APIC Security
Configuring a Custom Certificate for Cisco Cloud APIC HTTPS Access Using the GUI
Step 19
Fill in the remaining fields as appropriate.
Step 20
Click Save.
The Key Ring key_ring_name dialog box appears.
Step 21
Copy the contents from the field Request to submit to the Certificate Authority for signing.
Step 22
From the Key Ring key_ring_name dialog box, click on edit icon to display the Key Ring key_ring_name dialog box.
Step 23
In the Certificate field, paste the signed certificate that you received from the certificate authority.
Step 24
Click Save to return to the Key Rings work pane.
The key is verified, and in the Work pane, the Admin State changes to Completed and is now ready for use in the
HTTPs policy.
Step 25
Navigate to Infrastructure > System Configuration, then click the Management Access tab.
Step 26
Click the edit icon on the HTTPS work pane to display the HTTPS Settings dialog box.
Step 27
Click on Admin Key Ring and associate the Key Ring that you created earlier.
Step 28
Click Save.
All web servers restart. The certificate is activated, and the non-default key ring is associated with HTTPS access.
What to do next
You must remain aware of the expiration date of the certificate and take action before it expires. To preserve
the same key pair for the renewed certificate, you must preserve the CSR, as it contains the public key that
pairs with the private key in the key ring. Before the certificate expires, the same CSR must be resubmitted.
Do not delete or create a new key ring, as deleting the key ring will delete the private key stored internally
on the Cloud APIC.
Cisco Cloud APIC for Google Cloud User Guide, Release 25.0(x)
132

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
