Simplicity ISX3300 Series w/ 72" Mower Deck & ROPS (ISX3300BVE3772SS) Manual

Parts Manual
Mfg. No: 5901856
ISX3300 Series w/ 72" Mower Deck &
ROPS (ISX3300BVE3772SS)
Copyright © Briggs & Stratton. All Rights reserved
19-Dec-2021
Attachments and Accessories
5600962 - Striping Kit, 72 iCD Deck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5023279 - Flat Free Tire Assembly w/ Tapered Bearings (13 X 6.5 - 6). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5600587 - Mulch Kit for ZTR w/ 72" iCD Deck - S/N: 2015425347 & Above. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5600891 - Roll Bar Mounted LED Headlight Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5601079 - Service Jack Extension Sleeve Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5601080 - Service Jack Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5601235 - Service Jack Mount Kit (7.25") 2200/3300. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5106752S - Laser Edge Blade Set, 72" Deck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5106751X1 - Terra Trac Tire, 26 X 12 - 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
r
o
u
F
d
t
o
o
r
N ep
R
Copyright © Briggs & Stratton. All Rights reserved
i
t
c
2
n
o
19-Dec-2021
Table Of Contents
Model Components
Page
72" Mower Deck Group - Housing, Covers, Spindles & Blades (2 Belt System). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
72" Mower Deck Group - Pulleys, Belts & Idler Arms (2 Belt System). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
72" Mower Deck Group - Pusher Bars. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
72" Mower Deck Group - Rollers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Decal Group - Brand and Model. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Decal Group - Safety & Operation (North America Models). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deck Lift Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deck Lift Group - Deck Hangers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Group - Briggs & Stratton Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic - Charging Circuit - B&S 61E877. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic - Cranking Circuit - B&S 61E877. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic - Ign. Ground Circuit/Op Pres. - B&S 61E877. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic - PTO Clutch Circuit - B&S 61E877. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine & PTO Group - Briggs & Stratton EFI (Remote Oil Tank). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Remote Oil Tank, Hoses, & Mount Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Supply Hose, Tank Replacement Parts, and EVAP Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Tank & Mount Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Group S/N: 4002026249 and Below. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Group S/N: 4002026250 and Above. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main Frame and Front Suspension Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Motion Control Group - Control System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Motion Control Group - Handles & Dampeners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking Brake Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Bumper and ROPS Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Suspension Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Mount and Floor Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spindle Service Parts - 5413009. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Drive Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle SERVICE PARTS - ZT5400. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel and Tire Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Specification Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
r
o
u
F
d
t
o
o
r
N ep
R
Copyright © Briggs & Stratton. All Rights reserved
i
t
c
3
n
o
4
6
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
19-Dec-2021
72" Mower Deck Group - Housing, Covers, Spindles & Blades (2 Belt System)
Note: Unless noted otherwise, use the standard torque specifications
r
o
u
F
d
t
o
o
r
N ep
R
Copyright © Briggs & Stratton. All Rights reserved
i
t
c
4
Mfg. No: 5901856
n
o
19-Dec-2021
72" Mower Deck Group - Housing, Covers, Spindles & Blades (2 Belt System)
REF NO
PART NO
QTY
DESCRIPTION
1
5600979
1
1
5601127
1
1
5601123
1
1
5601124
1
2
3
4
5
6
7
8
9
10
11
5416044B
5416043B
5413387A
5413385A
5407876A
5025045
5413009
5413499
5025392
5102227S
1
1
1
1
1
2
3
1
3
1
12
13
14
15
5101005
5061300
5025477
5025320X14
1
1
3
3
5025390X10
18
5025146X12
5025394
5022308
5025145X6
5025011X6
5025155
5025011X8
3
21
6
2
1
8
6
DECK SHELL W/DECALS, 72, 3200Z (5415350B)
-(Domestic Models - S/N: 2017954955 & Below)
DECK SHELL W/DECALS, 72-3200E (5415350B)
-(Export Models - S/N: 2017954955 & Below)
DECK SHELL W/DECALS, 3200-72 (5417007B)
-(Domestic Models - S/N: 2017954956 & Above)(Refer to Note: *)
DECK SHELL W/DECALS, 3200-72E (5417007B)
-(Export Models - S/N: 2017954956 & Above)(Refer to Note: *)
GUARD,MOWER DECK,LH,72 2-BELT 3200 - RED
GUARD,MOWER DECK,RH,72 2-BELT 3200 - RED
WELD, MOUNT, DISCHARGE CHUTE - BLK
SUPPORT, DISCHARGE CHUTE - BLK
PLATE, DEFLECTOR, 72 - BLK
NUT, Hex, Nylon Lock, 5/16-24
SPINDLE, ASSM, CAST IRON - 10.0
CHUTE, RUBBER DISCHARGE (5104442)
NUT, 5/16-18 HEX NYLOCK FLANGE NUT
BLADE, 25 X 25 X 2.50, HIGH LIFT (SET OF 3)
-(SET OF THREE BLADES)
SAFETY WALK, 9.75 X 6.00
ROD, MOUNT, CHUTE, 61, CZ
WASHER, BLADE BOLT, 9/16" F436, CZ
BOLT, 5/8-11 X 1-3/4 GD8
-(Torque blade mounting bolts to 120 ft-lbs (163 Nm)
BOLT, 3/8-16 X 1-1/4, FLANGE, GD 5, CZ
-(Torque spindle mounting bolts to 30 ft-lbs (41 Nm)
BOLT, 3/8-16 X 1-1/2, CARRIAGE, GD5, CZ
NUT, 3/8 - 16 HEX NYLOCK FLANGE
BODY CLIP, 5/16-18 7GA. MATERIAL
BOLT, 5/16-18 X 3/4, CARRIAGE, GD5, CZ
BOLT, 5/16-18 X 3/4 GD5
WASHER, 5/16" SAE
BOLT, 5/16-18 X 1" GRD5 YZ
16
17
18
19
20
21
22
23
r
o
u
F
d
t
o
o
r
N ep
R
i
t
c
n
o
Footnotes:
Note: * If replacing the deck shell with decals on units in serial number range 2017954956 - 2018105410, you must also order 5105844 - Qty: 1, 5025098 - Qty: 1, 5025089 - Qty: 1,
5025158 - Qty: 2.
Copyright © Briggs & Stratton. All Rights reserved
5
19-Dec-2021
72" Mower Deck Group - Pulleys, Belts & Idler Arms (2 Belt System)
