Golden Tee GOLF 2013

Golden Tee GOLF 2013

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Version 11/12

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

WARNINGS AND NOTICES

NOTICE

This game is intended to be operated for amusement purposes only. It is not to be operated in violation of any federal, state, or local laws or regulations. As the owner and/or operator of this game you are responsible for its operation in compliance with such laws and regulations. The factory settings for this game may require adjustment in order to comply with the laws and/or regulations in the jurisdiction where the game is located. It is the sole responsibility of the operator to determine what laws and/or regulations are applicable and to make any adjustments to the game before operating it for its intended purpose.

This manual and the information contained within is subject to change without notice.

The Showpiece cabinet is intended for use with the Showpiece Integrated Stand (Model 304S).

WARNING

Use of unauthorized parts or making any unauthorized modifications will void the warranty and may result in the game operating in an unsafe or incorrect manner.

If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent.

This cabinet is not suitable for installation in an area where a water jet would be used. The cabinet must not be cleaned by a water jet.

WARRANTY, REPAIR, AND RETURN POLICY

90-day warranty on all electronic components. All warranty periods begin on the date of purchase from Incredible Technologies, Inc.

There is a minimum $75.00 service charge for all non-warranty repairs or returns.

For all servicing, return to Incredible Technologies, Inc.

ANY non-factory repair or attempted repair voids warranty.

RETURN MERCHANDISE AUTHORIZATION

All returned merchandise must have a Return Merchandise Authorization (RMA) number marked clearly on the outside of the package.

You must obtain all RMA numbers from Incredible Technologies. Please have the product's Cabinet Identification Device (CID) number available when calling for an RMA number.

Merchandise returned without an RMA number will not be accepted.

Warranty may be void if serial number or security labels are tampered with or removed. Opening the Nighthawk Chassis system will void your

warranty.

Advance replacement hardware will be shipped to the customer address on file unless specified otherwise.

Advance replacement hardware will be billed to the customer until Incredible Technologies, Inc. receives the returned merchandise, at which time a credit will be issued.

All repairs and/or replacements will ship as soon as possible after receipt or request (subject to availability).

PAYMENT FOR AND STORAGE OF REPAIR MATERIALS

Materials sent to IT for repair must be paid for according to current price schedules and in a reasonable time. Storage fees for repaired equipment will be charged at a rate of $50.00 (Fifty US Dollars) per calendar month or fraction thereof after 90 (Ninety) days from notice to the customer that the repairs are complete. IT reserves the right to resell repaired equipment to cover accumulated storage charges when the accumulated storage charge reaches 100% (One Hundred Percent) of the repaired items’ then-current replacement cost.

- INCREDIBLE TECHNOLOGIES, INC

GOLDEN TEE® GOLF, ITS®, INCREDIBLE TECHNOLOGIES®, IT®, ITNet®, and IT incredible TECHNOLOGIES® are the properties of Incredible Technologies, Inc. All

Rights Reserved.

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

PERPETUAL SOFTWARE LICENSE

Incredible Technologies, Inc. (“IT,”) hereby offers you (“Licensee”) the right to install and use certain copyrighted computer software produced by IT under the following terms and conditions. This License shall govern the use of the software known as “Golden Tee GOLF 2012” (“Update”) when applied as an update to pre-existing Golden Tee GOLFequipped hardware (“GT Cabinets”) equipped with an earlier version of the Golden Tee GOLF software

(“Prior Version.”)

1) Licensing Fee

The Licensing Fee (“LF”) shall be as follows:

US$0.00 (Zero United States Dollars and zero cents.)

2) Term

The License shall be valid on the first date that both the LF is paid for the Update and it is installed on a GT Cabinet. If the Update has been offered or sold to you under the terms of a Term Software License, the terms of this License shall become applicable if and when the Term Software License terminates in favor of this Perpetual Software License, as set forth in the Term Software License. The term shall be perpetual and throughout the

Universe for the Update on the GT Cabinet upon which it is installed at the time the LF is paid. Updates are not transferrable to any other GT Cabinet, for any reason. If a GT Cabinet with an Update is destroyed or otherwise taken out of operation, this License shall terminate.

3) License Rights

Licensee shall have the right to utilize the Update on authorized GT Cabinets in the normal course of business and as controlled by the Rules of ITNet, as set forth in a separate “Operator Agreement” document, the terms and conditions of which, where not conflicting with the terms and conditions herein, are hereby incorporated by reference. Updates may only be operated on GT Cabinets which are installed in commercial locations, as that term is defined by IT, and to which there is general access by all parties with a general right to enter the location where the GT Cabinet is operated.

4) Legal Operation

Updates include various features which may not be lawful to operate in any given jurisdiction. No provision of any feature, or its licensure to Licensee under the terms herein shall be deemed as advice that operation of that feature is lawful or not lawful in any given jurisdiction. Licensee shall make reasonable efforts to disable any user-adjustable feature which they know or should have known as not lawful to operate in the location where a GT

Cabinet with an Update is being operated.

5) Termination and Rollback

In the event that this License is terminated for whatever reason, Licensee shall have absolutely no right to operate any GT Cabinet upon which an

Update has been installed. IT reserves the absolute right, at its sole discretion, to terminate the operation of any GT Cabinet upon which an unlicensed

Update is installed. If Licensee wishes to restore such a GT Cabinet to operating condition without acquiring a new License for the Update, IT will rollback that GT Cabinet, at no charge to the Licensee, to the Prior Version upon return (at Licensee’s expense) of the required hardware to IT’s service center.

6) Governing Law and Jurisdiction

The validity and construction of this License and of the rights and obligations set forth herein shall be determined and governed by the laws of the State of Illinois. The parties hereby submit to the Jurisdiction of any state or federal court in Cook County Illinois. Licensees operating outside the borders of the United States of America, regardless of their citizenship or residency, explicitly agree to allow any assets they may have in the USA or any other foreign country to be attached, garnished, forfeited or otherwise reached by any legal act if, after due process of law, they are found to be liable to IT for damages by reason of breach of this License.

7) Warranty

If the Licensee discovers any physical defect in the media (disk, EPROM, flash media, etc.) on which the Update is distributed or in the documentation, which in the opinion of Incredible Technologies, Inc. (IT) prevents the product from being used as reasonably intended, IT will replace the media or documentation at no charge. The purchaser must return the item to be replaced, with proof of purchase, to IT within 90 days after taking delivery of the

Update.

8) Disclaimer and Waiver of Remedies

Acceptance of this License and installation of the Update includes disclaimer and waiver of any and all implied, statutory, or common-law warranties, including warranties of merchantability and fitness for a particular purpose, and limits the purchaser's remedy to returning the Update to IT for replacement.

IT makes no warranty or representation, either express or implied, with respect to Updates, their quality, performance, merchantability, or fitness for a particular purpose. Updates are licensed "as is," and the Licensee, by installing the Update, assumes the entire risk as to their quality and performance other than as explicitly set forth herein.

Acceptance of this License and installation of the Update includes disclaimer and waiver of any and all direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the Update, even if advised of the possibility of such damages. The warranty and remedies set forth above are exclusive and in lieu of all others, oral or written, express or implied. No person, seller, dealer, agent, or employee is authorized to make any modification or addition to this limited warranty.

In jurisdictions which do not allow the exclusion of implied warranties or liability for incidental or consequential damages, acceptance of this License and installation of the Update includes stipulation that the most minimal requirements of the law of those jurisdictions shall govern any additional required additional rights of Licensee.

9) Severability

If any provision of this License shall be held by a court of competent jurisdiction to be illegal, invalid or unenforceable, the parties nevertheless agree that the court should endeavor to give effect to the parties' intentions as reflected in the provision, and the remaining provisions shall remain in full force and effect.

GOLDEN TEE® GOLF, ITS®, INCREDIBLE TECHNOLOGIES®, IT®, ITNet®, and IT incredible TECHNOLOGIES® are the properties of Incredible Technologies, Inc. All

Rights Reserved.

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

GOLDEN TEE® GOLF, ITS®, INCREDIBLE TECHNOLOGIES®, IT®, ITNet®, and IT incredible TECHNOLOGIES® are the properties of Incredible Technologies, Inc. All

Rights Reserved.

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF 2013 Manual & User Guide

TABLE OF CONTENTS

TABLE OF CONTENTS ......................................................................................................................................... 1

NEW FEATURES FOR GOLDEN TEE GOLF 2013 .............................................................................................. 4

SHOWPIECE CABINET ......................................................................................................................................... 5

Showpiece Cabinet Contents ................................................................................................................................. 5

Leg Leveler Adjustment ......................................................................................................................................... 5

Mount Main Screen Display ................................................................................................................................... 5

Install Marquee ....................................................................................................................................................... 5

HDTV DIP SWITCH SETTINGS and NIGHTHAWK SYSTEM BOX ...................................................................... 6

Video Connections for 720p HDTV ........................................................................................................................ 7

INSTALL SECONDARY MONITOR ....................................................................................................................... 8

ABOUT THE SECONDARY MONITOR................................................................................................................. 8

Final Check ............................................................................................................................................................. 9

Apply Power ........................................................................................................................................................... 9

General Cabinet Maintenance .............................................................................................................................. 10

Care and Cleaning of Rubber Bumper ................................................................................................................ 10

Nighthawk Air Filter .............................................................................................................................................. 10

Trackball Maintenance ......................................................................................................................................... 10

Care and Cleaning of Cooling Fans and Vents ................................................................................................... 10

Showpiece Cabinet Repair Procedures ............................................................................................................... 11

System Chassis Box ............................................................................................................................................ 11

I/O Board .............................................................................................................................................................. 11

Cash Vault ............................................................................................................................................................ 12

Control Panel ....................................................................................................................................................... 13

Speakers .............................................................................................................................................................. 14

OFFLINE KIT CONTENTS ................................................................................................................................... 15

Recommended Tools ........................................................................................................................................... 15

Installation Preparation ........................................................................................................................................ 16

Preparing The Cabinet ......................................................................................................................................... 16

Cabinet Selection ................................................................................................................................................. 16

Preparing the Cabinet for Installation................................................................................................................... 16

Check High-Definition Television (Optional) ........................................................................................................ 18

Electronics Installation .......................................................................................................................................... 19

Install Nighthawk System box .............................................................................................................................. 19

Install Cabinet Identification Device (CID) ........................................................................................................... 19

Install I/O Board ................................................................................................................................................... 19

Control Panel Installation ..................................................................................................................................... 20

Install Optional Control Panel for Existing IT Cabinets ........................................................................................ 20

Trackball and Button Preparation (For Most Kits) ................................................................................................ 21

Control Panel Overlay Installation ........................................................................................................................ 22

Finishing The Control Panel ................................................................................................................................. 23

Complete System Box Connections ..................................................................................................................... 24

Attach I/O Power, Audio and USB cables ............................................................................................................ 24

Attach Main Video Cable ..................................................................................................................................... 24

Attach Power Cable ............................................................................................................................................. 24

Complete I/O Board Connections......................................................................................................................... 25

Golden Tee GOLF™ Version 11/12 Page 1

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Connect JAMMA Harness .................................................................................................................................... 25

Connect the Control Panel Switches and Cable .................................................................................................. 25

Connect Coin Door Lamps ................................................................................................................................... 25

Connect the Trackball .......................................................................................................................................... 25

Connect Audio Cables ......................................................................................................................................... 25

Connect the USB Cable ....................................................................................................................................... 25

Connect Medium or Low Resolution CRT Monitor .............................................................................................. 25

Connect VGA or SVGA CRT Monitor .................................................................................................................. 25

Connect High-Definition Television ...................................................................................................................... 25

Connect I/O Power Cable .................................................................................................................................... 25

Check All Connections ......................................................................................................................................... 25

Cabinet Graphics Installation ............................................................................................................................... 26

Marquee Installation ............................................................................................................................................. 26

Coin Doors, Test Switch, and Volume Controls ................................................................................................... 27

Initial Power-Up .................................................................................................................................................... 27

SYSTEM SETUP MENUS .................................................................................................................................... 28

Navigating The Menu System .............................................................................................................................. 28

Entering System Setup Mode .............................................................................................................................. 28

Selecting a Menu ................................................................................................................................................. 28

Choosing a Menu/Option ..................................................................................................................................... 28

Changing a Value................................................................................................................................................. 28

Main Menu ............................................................................................................................................................ 28

Collections & Earnings Menu ............................................................................................................................... 29

Do Collection ........................................................................................................................................................ 29

General Settings .................................................................................................................................................. 30

Operator Adjustables ........................................................................................................................................... 31

General Adjustments ........................................................................................................................................... 31

Money Slot Adjustments ...................................................................................................................................... 32

Sound Adjustments .............................................................................................................................................. 32

Collection Settings ............................................................................................................................................... 33

Reset to defaults .................................................................................................................................................. 34

System Tests ....................................................................................................................................................... 35

Video Tests .......................................................................................................................................................... 35

Color Test ............................................................................................................................................................. 36

Contrast Test ........................................................................................................................................................ 36

Screen Size Adjustment ....................................................................................................................................... 37

Sound Tests ......................................................................................................................................................... 37

Player Control Tests ............................................................................................................................................ 37

Mechanical Meter Test ......................................................................................................................................... 38

Hardware Tests .................................................................................................................................................... 38

Hardware/Software .............................................................................................................................................. 38

System Info .......................................................................................................................................................... 39

USB Info ............................................................................................................................................................... 39

Version Info .......................................................................................................................................................... 39

Check Hard Drive ................................................................................................................................................. 40

Check Cooling ...................................................................................................................................................... 40

Troubleshooting Shortcuts ................................................................................................................................... 41

Golden Tee Settings & Audits .............................................................................................................................. 41

Golden Tee Settings ............................................................................................................................................ 42

Casual Golf Spotlight Player ................................................................................................................................ 43

Spotlight Player Prize Settings ............................................................................................................................. 43

Golden Tee Audits ............................................................................................................................................... 44

Golden Tee Audits ............................................................................................................................................... 44

Player Cost Schedule .......................................................................................................................................... 45

Reset Leaderboards & Records ........................................................................................................................... 45

APPENDIX A Troubleshooting Guide .................................................................................................................. 46

APPENDIX B – SHOWPIECE Input/Output Connections (I/O Power, Trackball, etc.) ....................................... 51

APPENDIX B – KIT JAMMA, Trackball, and I/O Power Connections ................................................................. 52

APPENDIX C Replacement Part Numbers .......................................................................................................... 53

APPENDIX D Nighthawk Component Diagrams ................................................................................................. 54

APPENDIX F Menu Navigation Shortcuts ........................................................................................................... 65

Golden Tee GOLF™ Version 11/12 Page 2

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Game Icon Descriptions ....................................................................................................................................... 65

APPENDIX G Mounting Templates ..................................................................................................................... 67

Trackball Mounting Template ............................................................................................................................... 69

Button Templates ................................................................................................................................................. 71

NOTE

PLEASE RETAIN ORIGINAL SHIPPING BOX FOR SERVICE AND REPAIR.

Please be aware that with kit installations it is no longer possible to use CRT monitors with medium (512 x 384) or low (384 x 526) resolutions. If you have a low-resolution monitor it may be possible to switch it to a higher resolution.

Check your monitor’s manual for capabilities.

Do NOT perform any installation or repair when the cabinet is powered on.

Make sure the cabinet is unplugged from all power sources before and during installation.

Some game features may not be allowed in certain state or local jurisdictions.

Be sure to check your local laws before activating or allowing any features that may be questionable in your area. Adjust game settings from the System Setup

Menus. Refer to this manual for details.

Incredible Technologies cabinets are shipped with the USB cables disconnected from the I/O Board and the Cabinet Identification Device (CID). This prevents vibrations during shipment from damaging the contacts on the connectors.

These cables must be connected before operating the equipment.

IT recommends disconnecting these USB cables whenever transporting the unit.

Golden Tee GOLF™ Version 11/12 Page 3

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

NEW FEATURES FOR GOLDEN TEE GOLF 2013

In addition to five spectacular new 18-hole courses with advanced graphics, including Coconut Beach, Jack

Rabbit Junction, Bear Lodge, Cape Haven and Sequoia Grove, Golden Tee GOLF 2013 includes the following features:

ƒ Select from all 40 Golden Tee courses including the 5 all-new courses for 2013! More courses and more choices equals more earnings!

ƒ New Ball Types and Club Sets are available. Players will want them all as they experiment with matching equipment to their play style!

ƒ Dozens of New Clothing Items for repeat play! Players can change into even more fun and outlandish new outfits! x Some new courses feature real-time grass, which is a digitally enhanced grass that looks and plays like real grass. It appears in the rough of most courses. x All-new in-game user interface featuring a beautiful new gel look that looks great without sacrificing functionality. x All courses have new graphics filters that create an immersive experience for the player. x New difficulty settings give offline players the same challenging game feel as online players.

Golden Tee GOLF™ Version 11/12 Page 4

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

SHOWPIECE CABINET

SHOWPIECE CABINET CONTENTS

(1) Golden Tee Golf Showpiece Cabinet

Shipped inside a plastic parts bag attached to the front of the cabinet:

(1) Marquee Header

(1) Power Cord

(1) Game Manual

(1) HDMI Cable

Shipped inside the cardboard sleeve on the top of the control panel:

(2) Marquee Header Brackets

NOT Included with your Showpiece Cabinet

You will need to supply a digital display for the game's main monitor, and an appropriate stand or wall mount. Be sure that the stand or wall mount is UL listed. Incredible Technologies recommends a 42" HDTV that supports 720p for the best presentation, game play and earnings potential. A list of

Recommended Mounting Solutions can be found under Purchasing Info and Specs at the following address on the IT web site: http://www.itsgames.com/itsgames/Products/GoldenTee/GTGolf2013/specs.jsp

.

LEG LEVELER ADJUSTMENT

Once your game is in position at the location, it is necessary to adjust the leg levelers. The leg levelers will help stabilize the game on an uneven floor, and help it from moving or shifting during game play. The game is shipped with the two front and two rear leg levelers installed. Adjust the levelers as necessary to level and stabilize the game.

MOUNT MAIN SCREEN DISPLAY

Position the Showpiece cabinet in front of an HDTV. Incredible Technologies recommends 720p flat panel HDTVs from 32" or larger.

The HDTV can be mounted to a wall or to an appropriate display stand. There are many different types of wall mounts and floor stands available through retail, wholesale and Internet outlets. Be sure that the wall mount or stand you select must be UL listed. Check www.itsgames.com for some possible options. Be sure that the top of the Showpiece cabinet has at least 24" clearance in all directions. Insufficient clearance may result in damage to your display or player injury.

Recommended height for your display may vary depending on your location and player base. As a general rule, the minimum height of the bottom of the display viewing area should be 42" from the floor.

INSTALL MARQUEE

Your Showpiece cabinet comes with a framed marquee header that can be easily attached to the top of your monitor. The brackets for the header are shipped inside a separate cardboard insert labeled Parts

– Do Not Discard within the cabinet packaging. The insert is located on the top of the control panel.

First, attach the two brackets to the back of the universal mounting plate you are using for your HD display. The brackets share the same screws used to affix the display to the mounting plate, and are sandwiched between the plate and the back of the monitor. Once the brackets are in place, slide the marquee frame onto the clips on the two newly mounted brackets. Be sure the tab on the clips rest inside the channel on the marquee frame.

Golden Tee GOLF™ Version 11/12 Page 5

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

HDTV DIP SWITCH SETTINGS AND NIGHTHAWK SYSTEM

BOX

Before making any Nighthawk connections, make sure the USB cables are connected for the I/O Board and CID. See Complete System Box Connections for details.

Nighthawk System Box

DIP Switch Settings for HDTVs

The DIP switch settings in your Showpiece cabinet have been factory set to accommodate a 720p HDTV connected through HDMI cables. DIP switch bank Sw201 on the I/O Board controls the video resolution for the main monitor. If using a DVI-D or VGA connection, or for different resolutions, use this chart:

Notes:

A reboot is required when changing resolutions

Video and audio connections to HDTVs vary, and may require additional cables not included with the Showpiece cabinet. Also, some displays may not support the resolution needed for your game. Check your display's manual for additional information.

Golden Tee GOLF™ Version 11/12 Page 6

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

VIDEO CONNECTIONS FOR 720P HDTV

Golden Tee Golf 2013 supports 720p (1280x720) resolution. Be sure your HDTV is compatible.

For any questions related to Showpiece cabinet connections, see the Showpiece Connections Guide at http://www.itsgames.com/itsgames/Products/GoldenTee/GTGolf2013/specs.jsp

If you plan to use a Single HDTV as your only video output, follow the instructions below.

Connect to HDMI

Connect the HDMI cable (supplied) to the HDMI output on the Nighthawk system. Route the cable through the clip under the lock on the back wall, and down through the access panel on the back of the cabinet. Connect the other end of the HDMI cable to the proper HDMI input on your television.

Set Up Your HDTV

Refer to the HDTV manual to adjust the video signal to match the correct input for your game. Selecting the correct input is commonly found from a system menu accessed from the remote, or an Input Select button on the

HDTV.

Audio Connections for HDMI

The HDMI cable will also supply audio to the speakers on your HDTV. See Audio/Video Connections Table below for details on other connection types.

Note:

Be aware that when connecting a monitor with a resolution below 800x600 (and no lower than 640x480) you will need to use an analog audio connection. For more information see the Showpiece Cabinet A/V Connections Guide on IT’s web site at http://www.itsgames.com/itsgames/Support/Manuals . Follow the setup instructions for VGA.

The current version of the Nighthawk System Box does not support monitors with a resolution below 640x480.

Audio/Video Connections Table*

Video Mode Primary Video Connector Audio

1280x720 (HDMI) 720p HDMI with HDMI Cable

1280x720 (DVI-D) 720p

800x600 (HDMI)

DVI-D to HDMI

HDMI with HDMI Cable

Digital - Via HDMI cable

Secondary Video Connector

VGA

Analog - Via I/O Board or HDTV analog input

VGA

Digital - Via HDMI cable VGA

800x600 (DVI-D)

1280x720 (SVGA) 720p

800x600 (SVGA)

DVI-D to HDMI

DVI/VGA - VGA with adapter

DVI/VGA - VGA with adapter

Analog - Via I/O Board or HDTV analog input

Analog - Via I/O Board or HDTV analog input

Analog - Via I/O Board or HDTV analog input

VGA

HDMI - DVI-D

HDMI - DVI-D

640x480 (VGA)

DVI/VGA - VGA with adapter

Analog - Via I/O Board or HDTV analog input

HDMI - DVI-D

*Table applies to DB65AL motherboard systems with a Nighthawk System Box serial number 420000 and higher.

Golden Tee GOLF™ Version 11/12 Page 7

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

INSTALL SECONDARY MONITOR

If you plan to use Two TVs for your video outputs, follow the instructions below.

ABOUT THE SECONDARY MONITOR

Most Incredible Technologies games, including

Golden Tee GOLF, support a secondary monitor. The second monitor in Golden Tee displays unique information, including game replays and advertising screens. Most other games from IT support a second monitor to display the main game screen, so more of your players can see the action.

Golden Tee GOLF can also show the main display on the second monitor. See the System Setup Menus section of the

Golden Tee 2013 manual.

Incredible Technologies recommends using a 16:9 computer monitor. In all cases, the second monitor requires a VGA connection from the Nighthawk system box to the digital display of your choice. See the Sw202 DIP switch settings on the previous page to adjust the display.

PRIMARY VIDEO (HDMI to HDMI): Connect the HDMI cable from the HDMI Output on the back of the Nighthawk to the HDMI Input on the back of the HDTV.

SECONDARY VIDEO (VGA)

Connect the SVGA cable from the upper port to the VGA Output on the back of the second television. Route the cable through the clip under the lock on the back wall, and down through the access panel on the back of the cabinet. Common input label names for VGA are RGB, Computer or PC.

SET UP YOUR HDTV

Refer to the HDTV manual to adjust the video signal to match the correct input that your game is connected to.

Selecting the correct input is commonly found from a system menu accessed from the remote, or an input select button on the HDTV.

Golden Tee GOLF™ Version 11/12 Page 8

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

FINAL CHECK

APPLY POWER

Connect the power cable to the socket on the back of the cabinet. Then plug the cable into a 3-pronged, grounded wall socket. Locate the power switch on the back of the cabinet and turn it ON.

Note: If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent.

Watch the game carefully when you first turn it on. Look and smell for smoke. Turn it OFF immediately if there is smoke. Make sure the fan inside the system box is running and the LEDs on the I/O Board are flashing. If not, something is wrong, turn off the game.

Check the Cabinet ID Device (CID) Number

Watch the screen during boot-up and wait for the Golden Tee boot verification screen to appear. Note the

Cabinet ID Number (CID) that appears on this screen, and verify that it matches the CID number printed on the back of the cabinet. The screen will automatically time out and boot-up will continue.

Check the Coin Switch and Bill Validator

Try the coin switch. Drop quarters or tokens through to check the coin mechanism. Insert a dollar bill into the bill validator and listen for the credits to ring up. Make sure the game is adding credits and the correct quantity. You can use the Player Control Test by pressing the System Setup button inside the coin door and entering the

System Tests Menu. Make sure all of the controls work.

Cabinet Temperature

The state of the art Nighthawk hardware is extremely powerful, and therefore generates a substantial amount of heat. Measures have been taken to keep the various components cool during normal use. If overheating occurs, game play and hardware longevity may be affected. Use the Check Cooling menu in the System Setup menus to monitor the temperature within your cabinet. Enter System Setup by pressing the System Setup button inside the outer door of the coin vault. Once at the main System Setup menu, use the trackball and Start button to select Troubleshooting Shortcuts, then Check Cooling.

Custom Adjustments

Upon initial power-up, the game will initialize to factory default settings. These settings affect game elements such as number of credits per coin, volume settings, etc. The System Setup section in your game manual will describe how to alter these settings and view the system audits or run system tests.

Golden Tee GOLF™ Version 11/12 Page 9

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

GENERAL CABINET MAINTENANCE

Games that are in good working condition, with clear monitors, clean control panels and working trackballs will make more money than a machine in poor condition. It is definitely worth your time and attention to protect your investment with a little common care. Each week, clean the display and wipe down the control panel to bring back that new game look. Test the trackball and buttons regularly to make sure they are playing properly. And perhaps most important, make sure the coin mechanisms and bill acceptors are in good working order.

CARE AND CLEANING OF RUBBER BUMPER

The rubber bumper on the front of the cabinet’s control panel is made from durable nitrile rubber. Clean it using a mild soap and water solution or blue window cleaner.

NIGHTHAWK AIR FILTER

The Nighthawk System Box comes equipped with an external electrostatic air filter. This filter is held in place by a metal bracket, attached to the system box. The filter prevents debris from entering the system box and damaging the electronic components. A clogged filter will impede airflow, thus building up unwanted heat which can cause damage to your hardware. Be sure to check this filter at least once a month. Remove the filter by sliding it out of its housing. Shake off excess dirt and if necessary clean it with soap and water. Be sure the filter is completely dry before reinstalling the filter.

TRACKBALL MAINTENANCE

The trackball will require periodic maintenance to assure optimum performance. In most cases the inside of the trackball simply needs to be cleaned of any accumulated dust and debris. See page 13 for Trackball

Replacement.

To access the inside of the trackball, remove the 6 Phillips head screws that hold the trackball together and remove the top cover. Clean out any dust and debris inside the trackball. Polish the rollers and remove any foreign material that may be on the rollers. Do not lubricate the bearings, as this will only attract more dust. If the bearings do not spin freely it is best to replace the bearing assembly. Inspect the rollers for any nicks that may cause poor performance and replace if needed. Inspect the ball for any nicks and replace if needed.

Parts can be obtained from Happ Controls and is an economical option rather than replacing the entire trackball assembly.

It is critical that the green field ground wire be properly connected to field ground. This prevents the trackball from building a static charge that can cause the game to lock up or reset. A static discharge can also damage the trackball’s electronic components, as well as the main system.

CARE AND CLEANING OF COOLING FANS AND VENTS

The hardware that runs Golden Tee GOLF is quite sophisticated, and many of the chips and processors will get hot very quickly. Like your desktop PC, the Golden Tee GOLF hardware needs adequate ventilation to work properly. Dust and dirt can be a major cause to overheating and will lead to costly repairs. At least once a month, check to make sure the cabinet and system box fans are working and free of dust and debris. Use a vacuum to clear all the ventilation holes on the cabinet at this time as well.

CAUTION:

Incredible Technologies cabinets are shipped with the USB cables disconnected from the I/O

Board and the Cabinet Identification Device (CID). This prevents vibrations during shipment from damaging the contacts on the connectors. These cables must be connected before operating the equipment.

IT recommends disconnecting these USB cables whenever transporting the unit.

Golden Tee GOLF™ Version 11/12 Page 10

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

SHOWPIECE CABINET REPAIR PROCEDURES

SYSTEM CHASSIS BOX

The Nighthawk Chassis houses most of the game electronics and hardware in one box that can be easily installed. As with all electronic equipment, the Chassis box should be handled with extreme care. Shock, severe temperature, or sudden impacts can damage the internal components that require costly repair.

Note: Turn off power to the cabinet and remove the power cord from the back of the cabinet when performing any of the following.

System Chassis Removal

1. Unlock the control panel and open to expose the Nighthawk system box.

2. Disconnect all connections to the system box. Be sure all wires and connectors are clear and out of the way. Label the connectors for easy reconnection.

3. Loosen the 6 ¼" hex-head screws that secure the system box.

4. Carefully lift the system box off the screws and up out of the cabinet.

System Chassis Installation

1. Unlock the control panel and open to expose the inside of the cabinet.

2. Align the system box onto the 6 mounting screws of the internal slanted panel. The connection ports face up. Once the system box is in place, tighten the 6 ¼" hex-head screws to secure the box to the panel.

3. Connect the required connections. See the Connections

Diagram for more details.

I/O BOARD

Note: The I/O Board is game title specific and is not interchangeable with other game titles produced by Incredible Technologies on this system. Dedicated and Retrofit Kit I/O Boards are different and are not interchangeable.

I/O Board Removal

First, unlock the control panel and open to expose the interior of the Showpiece cabinet. Disconnect all connections from the I/O Board. Label the connectors for easy reconnection and move them safely out of the way. Next, remove the six ¼” wood screws that secure the board to the interior left side of the cabinet (as you face the game). Carefully remove the I/O Board from the cabinet.

I/O Board Installation

Place the I/O Board in the proper location on the interior left side of the cabinet (as you face the control panel of the game). Be sure it is oriented properly so the cables reach the board (the USB port on the I/O Board facing the top of the cabinet). Secure the I/O Board to the side of the cabinet with the six ¼” wood screws. Use the factory mounting holes if at all possible. Be sure the board does not “bow” or is not stressed in any way. Once mounted, connect the appropriate connections.

Golden Tee GOLF™ Version 11/12 Page 11

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Cabinet Identification Device (CID)

This device contains a specific ID number that identifies your cabinet. The CID is a permanent number and must be connected to the main system box via the USB cable and working properly in order for the game to operate.

CID Removal and Replacement

If for some reason you must replace the CID, disconnect the USB cable from the CID. This is the only connection to the CID. Next, remove the four ¼” wood screws that secure the CID to the interior left side of the cabinet (as you face the game). The CID is located above the I/O Board. To install a CID, mount the CID in the proper location using four ¼” wood screws. The CID should be mounted so the USB port is facing the top of the cabinet and the electronics are facing the wall.

Note: The Cabinet Identification Device should NEVER be removed from the cabinet, even when replacing any of the other components. The CID is the cabinet’s PERMANENT Identifier, regardless of any other components.

CASH VAULT

The Cash Vault has been designed for optimal security. With the double-locking doors, service technicians can read meters and enter System Setup mode with no access to the cash box.

Cash Vault Removal and Replacement

1. Unlock and open the outer door of the Cash Vault.

2. Using a T-15 Torx wrench, unscrew the card reader/button plate located on the right side by removing the four #8-32 screws located at the top and bottom of the plate.

3. Disconnect the connectors for the coin meter and buttons.

4. Remove the plate and set it aside.

5. Remove the coin bin and the bill validator magazine to make it easier to work inside the vault.

6. Unplug the bill validator cables, and push the cables for the bill validator, buttons, and coin meter through the 2 holes located in the back of the vault.

7. The Cash Vault is attached by upper and lower locking brackets. These are each attached with two socket-head screws located within the vault.

8. Locate the socket-head screws on the top and bottom locking brackets. Remove the two bottom screws using a 9/64” hex key and remove the bottom locking bracket. Make sure to note how it was installed.

9. Remove the two top screws and remove the top locking bracket, again noting how it was installed.

10. You can now pull the entire vault assembly out from the front of the cabinet. The vault is attached with foam tape, so it will need to be pried out or pushed from behind to loosen the adhesive.

Locks

The outer lock is a secure T-handle lock, commonly used in vending. To open, insert the key and turn it clockwise until the lock-handle pops out. Next, rotate the lock-handle clockwise 90 degrees to open the outer door.

The inner door has a lock installed above the System Setup button. This lock is unlocked by turning the key 90 degrees clockwise.

Volume and Service Buttons

Mounted inside the outer door are controls for Volume and System Setup. Press the Volume Up button to increase the loudness of the sounds on the game, and press the Volume Down button to make your game quieter. Press the System Setup button to access the game’s software menu system. The System Setup menus cover a variety of important areas including collections, tests, game adjustments, and optional settings.

Golden Tee GOLF™ Version 11/12 Page 12

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Bill Acceptor

The dedicated cabinet ships with a MARS AE2481 D5 bill acceptor and is mounted on the cash vault door. The default DIPswitch settings for this acceptor are ON = 1, 2, 4-7 and OFF = 3, 8.

Bill Acceptor Removal

Disconnect the cable to the bill acceptor. Remove the four 11/32” sized nuts from the mounting studs.

Disconnect the ground wire from the one lower stud. Then gently pull the accepter off the studs from the back side of the coin door.

Bill Acceptor Installation

From the back side of the coin door, place the bill acceptor onto the four mounting studs. The faceplate will protrude out the front of the coin door. Place the field ground wire on a lower stud, and install the four 11/32” sized nuts on the mounting studs and tighten. Next, connect the bill acceptor cable in the cabinet to the mating cable on the bill acceptor itself.

Stacker Removal

A blue slide switch is located at the bottom of the stacker. Engaging it allows the stacker to be removed.

Coin Mechanism

Coin Mechanism Removal

Loosen the two finger screws to release the securing braces. Slide the upper brace upward, and the lower brace downward. The mechanism should pull straight out.

Meter

This 5-volt device is mounted behind the card reader plate next to the inner door of the coin vault. One lead of the meter is connected to a +5 volt source and the other lead is connected to the appropriate signal wire. An additional opening is available just below the meter, if a second meter is desired.

CONTROL PANEL

Opening the control panel provides access to all game controls and hardware components. To open the control panel, simply use the supplied key in the lock on the back of the cabinet and lift from the back. The control panel is hinged in front and will stay open when fully extended.

Soft Power Switch

A “soft power” switch has been added to the underside of the control panel, to assist in the update process. This switch will turn off power to the cabinet so you don’t have to reach around to the main power switch located on the back of the cabinet.

Note: If you turn power off using the Soft Power Switch, you must use this same switch when turning power back on.

Trackball Replacement

To replace a trackball, open the control panel and remove the 4 long screws holding the trackball in place. Be careful not to lose any of the screws, washers and lock washers. Disconnect the wire harness and ground wire and remove the old trackball. Position the new trackball in the proper orientation over the existing standoffs.

Make sure that the arrow on the trackball that points to the monitor is pointing up. Replace the 4 long screws and washers. Do not over tighten! Screw in until the lock washer is fully compressed. Reconnect the wiring connector and ground wire.

Note: The field ground wire is critical to avoid electrical problems and assure optimal performance.

Golden Tee GOLF™ Version 11/12 Page 13

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Button Replacement

All of the buttons on the control panel require a 1 1/8 th

inch hole, and are pre-drilled on the dedicated control panel. To remove a button, disconnect the wires from the button assembly by sliding the wires off of the micro switch posts. Next carefully twist the micro-switch assembly off of the button posts. Finally, unscrew the nut to remove the button from the control panel.

Place the new button assembly into the hole and position the smaller side of the micro-switch housing to face the rubber bumper, angled towards the middle. Tighten the supplied nut using a pushbutton wrench. Do not over tighten. Install the micro-switch by snapping it onto the pushbutton assembly by hand. Position the assembly so the micro switch posts face the rubber bumper, angling towards the middle. Reconnect the wires by sliding the wire assembly onto the contact posts of the appropriate micro switch. See the wiring diagrams in the back of this manual.

L.E.D. Lighted Buttons

The Help and Options buttons on Golden Tee GOLF are Light Emitting Diode buttons. The housing for the L.E.D. snaps into the back of the button assembly. The L.E.D. must be installed properly for the light to function properly. The Anode/positive side of the L.E.D. is connected to the +5 volts, and the Cathode/negative side of the L.E.D. is connected to the appropriate signal wire. The L.E.D. slides into the housing and the housing is marked Positive and Negative. See the lamps connector J202 in the cabinet wiring diagram in Appendix D.

Control Panel Removal

To remove the control panel from its hinge, Disconnect the trackball cable, field-ground wire, and the control panel interconnect connector to the I/O Board. Remove the screw that attaches the safety cable to the control panel. Remove the four ¼” screws holding the panel to the hinge.

Control Panel Graphics Removal

The control panel artwork has been screened onto a solid sheet of polycarbonate, which is resistant to scratches and burns. Unfortunately long exposure to excessive situations may damage the surface over time. To remove and replace this piece, the pushbutton and trackball assemblies must first be removed. Separate the polycarbonate piece from the wood portion of the panel by starting at one corner and slowly peeling the two apart.

The overlay has adhesive on the entire surface and will take some force to separate the pieces due to the adhesive. Once removed, the graphic overlay will not be able to be used again.

Control Panel Graphics Installation

To install a new polycarbonate graphics overlay, make sure the wood control panel surface is clean, smooth, and free from glue, dirt and debris. Remove the paper protecting the adhesive from the new artwork/cover panel.

Carefully place it on the wood panel, aligning it properly. Press and smooth firmly to assure that it is secure.

Replace the buttons and trackball in the correct orientation.

SPEAKERS

The speakers are mounted in the bottom front of the cabinet, just below the coin vault. Sounds and speech are important aspects to the play experience and should be adjusted and maintained for optimal results. Make sure your speakers are in good working condition, are wired correctly, and are grounded properly to avoid buzz or hiss.

Speaker Access

In order to reach the speakers, unlock and raise the hinged control panel. The speakers are located just below the coin vault. Remove the 4 nuts with an 11/32” nut driver to remove the speakers from their mounting.

Note: Both speakers must be identically wired to work properly. For optimal sounds, both speakers must be in phase with one another. Be sure the positive wire is connected to the positive terminal of each speaker and the negative speaker wire is connected to the negative terminal of each speaker.

Golden Tee GOLF™ Version 11/12 Page 14

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

OFFLINE KIT CONTENTS

Please refer to the IT part numbers in Appendix C when ordering parts.

(1) Golden Tee 2013 Nighthawk System Box

(1) I/O Board Assembly Golden Tee 2013

(1) Cabinet Identification Device (CID) for Golden Tee 2013

(1) HDMI cable

(1) DVI to VGA Adapter

(1) SVGA Cable

(1) Trackball Cable

(1) Input/Output Connections Cable

(1) Help Option Cable

(1) I/O Power Cable

(1) 6’ 2 RCA to 2 RCA Audio Cable

(2) 6’ USB Cable

(1) A.C. Power Cable

(1) 3” Trackball, White

(1) Trackball Plate for 3”

(1) Card Reader Blanking Plate

(1) Pushbutton Assy., Red

(4) Pushbutton Assy., White

(1) Pushbutton Assy., Blue Round Illuminated

(1) Pushbutton Assy., Yellow Round Illuminated

(1) Marquee, Golf Golf 2013

(1) Control Panel Graphics Overlay, Golden Tee GOLF 2013

(1) GoldenTee.com Card

(1) Manual, Golden Tee GOLF 2013

(1) Quick Install Guide Golf GOLF Kit

(1) Parts bag containing miscellaneous hardware

(1) *Fully-dressed Control Panel (Includes: assembled trackball, control panel overlay and buttons as a unit)

*There is an additional fee for kits with the fully-dressed control panel. If the fully-dressed control panel was not ordered, the kit includes ONLY: trackball, control panel overlay and loose buttons NOT assembled.

RECOMMENDED TOOLS

Have the following tools ready before you begin to install this kit:

‰

‰

‰

‰

‰

‰

‰

‰

‰

‰

‰

‰

‰

¼", 11/32" and 7/16" Sockets or Nut Drivers

Phillips Head #2 Screw Driver

3/16”, 7/32” and 9/32”, or 5/16”, 3/8”, and ¾” Drill Bits

1 1/8" and 3 1/2“ Hole Saw or Drill Bit

Small Flat Blade Screwdriver

Jig/Sabre Saw

Router

Push Button Nut Socket or Large Adjustable Pliers

X-acto® Knife or other Sharp Knife/Razor Blade

Wire Cutters

Scissors

Tape Measure

Putty Knife

Golden Tee GOLF™ Version 11/12 Page 15

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

‰

‰

‰

‰

Decal Roller/Squeegee

Liquid Window Cleaner & Cleaning Cloth

Vacuum Cleaner

Any tools needed to remove parts from your existing cabinet not listed above.

INSTALLATION PREPARATION

BEFORE YOU START…

Before you install the Golden Tee GOLF kit into your cabinet there are a few things you should check first:

1.

Check to make sure your existing cabinet's monitor, speakers, AC power cord, lights, bill acceptor and coin mechanisms work. Replace or repair where necessary.

2.

Check to make sure all the necessary parts are included in your kit. If any are missing/damaged please contact IT's Technical Support at 847-870-7027 x121.

3.

Check to make sure cabinet is wired with standard earth grounded AC plug compatible with local building codes and/or safety requirements. If not, have a qualified electrician install one (not provided).

4.

Have all the necessary tools available to install this kit. Refer to the recommended tools list to make sure you are prepared before you start.

5.

Make sure any parts of the system (lights, monitor, etc.) are not plugged in. Working with any part of the system plugged in or powered on can be dangerous.

6.

Keep in mind that it's been proven that the higher quality of work put into a kit installation results in a higher earning game. Make sure you have plenty of space, time, and focus to put into this kit installation.

PREPARING THE CABINET

CABINET SELECTION

You can choose either a new cabinet or a used cabinet for your GOLF game. Reusing a cabinet is a costeffective way to maximize the return on your initial investment. In either case, all you need to provide is the cabinet with a monitor, JAMMA harness, coin and bill acceptors, working fluorescent/marquee lights, and speakers.

When selecting a cabinet, keep in mind that a larger control panel allows you to mount the trackball farther from the monitor. This prevents players' hands from hitting the monitor glass when rolling the trackball forward, and will earn better than a smaller control panel closer to the monitor. An older-model Golden Tee Golf dedicated cabinet is ideal for this purpose.

If using an older IT cabinet made before 2005, such as Golden Tee 3D or Golden Tee Fore, consider ordering a new Control Panel from Incredible Technologies. These control panels come pre-installed with controls and graphics, and can save you considerable time and money through easy installation.

PREPARING THE CABINET FOR INSTALLATION

Follow these steps to prepare your cabinet before installation:

1. Remove the following from the cabinet: Main Logic Board(s) (and hard drive if present), Control Panel,

Monitor Viewing Glass, Marquee, and Power Supply. Now is a great time to clean both sides of the monitor viewing glass and monitor screen to ensure a clear view of the game.

2. Thoroughly clean out your cabinet. Remove all of the old buttons, joysticks, etc. DO NOT remove monitor and speaker wires or the wires that were previously hooked up to the control panel.

3. Remove the old graphics and adhesive from the cabinet including the control panel.

4. For a fresh look and best earnings, painting is highly recommended. Spray painting gives a better finish, but if an airbrush or paint sprayer is unavailable a roller is second best. Remember to cover all exposed surfaces not to be painted. When not installing into an existing Golden Tee Fore! dedicated cabinet, the recommended color choice is black.

5. Make sure to have the sides of the cabinet and the control panel as smooth and flat as possible to allow for a higher quality finish when applying the control panel background, labels, and side decals.

Golden Tee GOLF™ Version 11/12 Page 16

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

6. The "new game look" should always apply to the inside of your game as well. A few wire ties and shrink tubing on your harness, some fastening hardware on your subassemblies, and a sweep with the vacuum cleaner will help ensure that glitches do not occur.

Check JAMMA Harness and Wiring

The GOLF Kit comes with a special I/O Board that uses your cabinet’s existing JAMMA wiring harness. Make sure your existing wires and connectors are in good working order. Check the JAMMA wiring diagram in

Appendix B - Kit.

Check Coin Mechanisms and Bill Acceptor

Make sure your coin mechanisms and bill acceptor are functioning properly, and your coin box and stacker are in good condition. You want to make sure your game will accept money when players are ready to play.

Check Coin Door Connections

Your cabinet should already be wired correctly through the JAMMA connector. Now is a good time to make sure your game can accept money. Check the JAMMA pinout chart in Appendix B - Kit for the correct wire colors and pins. Trace the wiring to their sources and make sure they are connected properly and securely. Be sure the wires are away from the coin door where they can be pinched or crimped.

Check CRT Monitor

GOLF supports a number of resolutions, including SVGA (800 x 600), VGA (640 x 480), medium resolution (512 x

384) and low resolution (384 x 256) CRT monitors. The factory-installed monitors in all older IT cabinets are compatible with GOLF. However, to take advantage of the best and most current quality available, it is recommended to upgrade to an SVGA compatible monitor or high-definition television.

Operating GOLF at the highest possible resolution will give your game the best results (and revenue). Many standard cabinets contain a medium-res. or VGA monitor already. If you have a low-res monitor, it may be possible to switch it to a higher resolution. Check your monitor's manual for capabilities. If not, you should consider upgrading to a newer monitor or high-definition television.

Check your CRT monitor for a DB15 VGA connector. If your current monitor has a DB15 VGA connector, it is capable of VGA or SVGA resolutions. Check your monitor’s manual on how to switch the monitor to VGA mode.

Make sure the video dip switches on the I/O board match the resolution that the monitor is expecting. Plug the video cable from the Nighthawk System box directly into the monitor. Be sure to disconnect the old composite sync video cable from the monitor.

When operating with an SVGA or VGA monitor, GOLF uses the standard VGA sync timing and signals. When operating with medium resolution or low resolution monitors, which are common in older Golden Tee Fore! dedicated cabinets, GOLF operates with composite negative serrated sync.

NOTE: In all cases a horizontal mount raster scan monitor is required.

CAUTION! Monitors are extremely dangerous and can result in severe injury. Make sure you follow and observe all safety precautions as outlined in your monitor's manual. ALWAYS disconnect the power to the cabinet before working on or around the monitor.

Golden Tee GOLF™ Version 11/12 Page 17

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

NOTE: In all cases a horizontal mount raster scan monitor is required.

CAUTION! Monitors are extremely dangerous and can result in severe injury. Make sure you follow and observe all safety precautions as outlined in your monitor's manual. ALWAYS disconnect the power to the cabinet before working on or around the monitor.

CHECK HIGH-DEFINITION TELEVISION (OPTIONAL)

GOLF supports a 720p resolution that is compatible with newer flat-panel LCD digital televisions. In addition, both

16:9 and 4:3 aspect ratios are supported. Refer to the Showpiece section of this manual for details on connecting video and audio to a 720p HDTV.

NOTE: Video and audio connections to these displays vary, and may require additional cables not included in the GOLF kit.

In addition, some televisions may not support the resolution needed for GOLF. Check your television's manual for additional information.

WARNING: Be sure top of cabinet has at least 18 inches or 45.7 centimeters of clearance in all directions. Insufficient clearance may result in damage to monitor or player injury.

Golden Tee GOLF™ Version 11/12 Page 18

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

ELECTRONICS INSTALLATION

INSTALL NIGHTHAWK SYSTEM BOX

The Nighthawk System box houses most of the game electronics and hardware into one box that can be easily installed. Verify that the Nighthawk System

box Power Switch is in the "ON" position.

1. Locate the area on the floor where the system box will be placed. Make sure there is enough clearance to plug in cables.

‰

The Nighthawk System box measures 19" W x 7" H x 11" D.

2. Relocate and secure any wires to make room for the system box.

3. Place the system box so it sits flat on the floor and does not pinch wires.

Be sure there will be sufficient air flow to the system box. Overheating can damage your system.

4. Mount the system box with 6 - #6 x ¾" Hex Washer Head Sheet Metal

Screws.

INSTALL CABINET IDENTIFICATION DEVICE (CID)

The Cabinet Identification Device or C.I.D. is an innovative and important component. This device permanently identifies your cabinet as GOLF. It should remain even if another component such as the I/O board or system box is replaced. The C.I.D. has a unique number to individualize the cabinet and is referred to as the Cabinet Identification Number.

1.

Attach the C.I.D. to the inside side of the cabinet using the 2 - #6 X 1” Hex Washer Head Sheet

Metal Screws. Mount so the port is facing up and the electronics face the wall.

2.

Attach the USB cable from the Nighthawk System box.

‰

‰

Place the included Cabinet Identification

Number on the back of the cabinet for future reference. Refer to this number to track your

equipment and whenever you are calling in

for service.

The Cabinet Identification Number is displayed in the operator menus in the lower right hand corner, and is labeled as Game ID. It is also displayed near the bottom of the initial boot-up screen.

INSTALL I/O BOARD

NOTE: Before installing any electronics make sure cabinet power switch is in the OFF position and the cabinet power is unplugged from the wall.

GOLF comes with a specially designed I/O board that works with your cabinet's already installed JAMMA harness. The I/O board is used as a connection interface between the JAMMA and the

Nighthawk System box.

Mount the I/O board inside the cabinet using 4 of the 6 x ¾" Hex

Washer Head Sheet Metal Screws, 1 in each corner. The existing

JAMMA harness edge connector will attach to this board. Do not attach cables at this time.

NOTE: Route all cables AWAY from the I/O Board. Laying cables on top of or below the I/O Board will result in unwanted noise or static during the game.

Golden Tee GOLF™ Version 11/12 Page 19

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

CONTROL PANEL INSTALLATION

INSTALL OPTIONAL CONTROL PANEL FOR EXISTING IT CABINETS

If you are installing your kit into an existing Golden Tee Fore! cabinet manufactured by IT, you can purchase a new, fully outfitted control panel. This will not only make your installation easier, it will make your game look and play better too. Use this section to install this control panel. For all other cabinet types, refer to the next section.

Attach the new control panel to the existing hinge on the control panel drawer. Drive the 4 Phillips screws into the holes in the bottom of the control panel. The control panel comes equipped with trackball and buttons in place.

Snap the switches onto the buttons. The following buttons need to be connected: Left, Right,

Fly-By, Help, Options, Spin and Start/Replay. Connect to the normally open post. Be sure common ground is connected to each common post.

Help and Options are new buttons and come with the cable installed to the buttons on the new control panel. Connect the

8-pin connector to the Lamps connector J202 on the I/O

Board. Connect the 10-pin connector to the Control Panel connector J203 on the I/O Board. Finally, connect the

Trackball to the trackball connector J208 on the I/O Board.

Golden Tee GOLF™ Version 11/12 Page 20

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

TRACKBALL AND BUTTON PREPARATION (FOR MOST KITS)

Mounting the trackball and buttons correctly and securely is very important for the profitability and safety of your new game. This kit is designed for use in cabinets with ¾" thick wood control panels where proper routing of the control panel is used to create a safe playing experience. If you do not have a ¾" thick wood control panel, please replace your control panel or choose a cabinet with a ¾" thick wood control panel installed. Keep in mind that if your current control panel has many old holes in it from previous buttons, joysticks, etc. that it may be easier to start with a new solid control panel. This will give your game a better look and feel and help it to earn better.

Note: If the cabinet already has a trackball plate installed, discard and replace with the new trackball plate. The metal trackball mounting plate and trackball mounting procedure have been designed to remove all bolts from the playing surface. Routing the wood control panel is required so the metal mounting plate is flush with the panel surface. An uneven playing surface or exposed edges will affect game play and could impact your earnings.

TIP: Trackball and button templates can be found in Appendix G of this manual. They include:

‰

‰

‰

Trackball Orientation Diagram to orient your trackball correctly when installing.

Trackball Mounting Template to install the trackball plate and make the appropriate routing.

Button Set Templates to position and install control panel buttons.

Trackball Preparation

Install the metal trackball plate by following these steps:

1. Cut out the template from Appendix G with a pair of scissors along the noted line. Tape this template to the top of the control panel as far away from the monitor as possible, making sure that the trackball will clear the cabinet beneath it.

Note: Installing the trackball as far away from the monitor as possible will prevent players' hands from hitting the monitor glass when rolling the trackball forward.

2. Using a sharp object, mark the eight points shown on the template on the control panel. Using a pencil, trace the outside of the template. Remove the template.

3. Drill Holes 1-4 with a 9/32" or 5/16" drill bit.

6. Using a sabre saw cut out the center portion by cutting between holes 5-8.

7. Once you have cleaned up the routed area, install the trackball plate into the control panel using the ¼"

Flat Washers and ¼-20 Nylon Hex Nuts. Be sure the mounting plate is flush with the top of the control panel.

Note: At this time you are only installing the trackball plate. Do NOT install the trackball or buttons until the control panel graphics have been applied.

Button Preparation

The following are the steps you should take to prepare your control panel for the installation of the button assemblies:

1. Cut out the template(s) (see Appendix G).

2. Using a tape measure, measure the specified distances from the center of the trackball hole in the trackball plate and make a mark the reference points indicated on the left and right button set templates

(see Appendix G).

3. Lay each template over the appropriate reference marking point. Mark the centers of the remaining holes using a sharp object.

4. Drill a 1 1/8" hole at each marked point.

Once the installation is complete, be sure to use the System Controls test in the game’s System Setup menus to ensure proper functionality of all the player controls.

Golden Tee GOLF™ Version 11/12 Page 21

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

CONTROL PANEL OVERLAY INSTALLATION

Golden Tee GOLF comes with an oversized control panel overlay that will accommodate a variety of existing game cabinets, but works best on Golden Tee Fore!, NFL® Blitz™ and EA Sports™ PGA Tour® Golf cabinets.

Follow these instructions to correctly install the control panel overlay on one of these cabinets:

1. Make sure that the newly drilled control panel has a smooth, clean surface. Sand where necessary to make sure the graphics are installed on an even surface.

2. Clean the control panel to make sure it is free from dust, grease, metal filings, etc. Make sure that all residues (adhesive, overlay material, etc.) from the previous control panel graphics are removed. This will ensure a clean, easy, and beautiful application of the control panel graphics.

3. It is very important that the trackball and control panel graphics be mounted perfectly straight. Find the center of your trackball template and lightly draw vertical and horizontal guidelines on the control panel, marking out your centering lines.

4. Remove a small section of the protective backing from the overlay. Carefully center the overlay over the control panel by lining up the die-cut hole with the trackball template. Be sure the graphic is positioned

perfectly straight. Line up your pencil guidelines with the lines incorporated into the art. Once in position, gently press down on the section with exposed adhesive, affixing the overlay into place. Once affixed, the overlay cannot be removed.

5. While holding down the overlay over the attached area, very carefully turn over one side and remove the exposed backing. Gently lay down the exposed overlay from the center outward, smoothing with your hands or a roller as you go. Be sure the overlay remains straight and square. Repeat the process with the other side of the overlay, so the entire surface is affixed to the control panel. Make sure all bubbles have been pressed out for a clean, flat surface.

TIP: Liquid window cleaner can be sprayed onto the control panel before placing the overlay onto the control panel. The window cleaner will allow the overlay to be positioned with less risk of damage to the overlay or adhesive. Once in position, use a decal roller or squeegee to force any excess cleaner out. Be sure to add additional time for the liquid to evaporate.

6. Using a razor knife (or other sharp instrument) carefully cut around the edges of your control panel, trimming any excess material.

7. Find the center of each hole you have drilled out for the buttons and use the knife to poke a hole into the overlay. Make a vertical and horizontal line (like a plus sign) from the center of the hole to the edges. You should be able to place your button in later with no edges showing.

CAUTION: If you choose to install a Plexiglas® cover over your control panel (not recommended), to ensure the safety of your players and the quality of your game make sure that all surfaces, edges and bolts that a player may come in contact with are smooth, safe and secure.

Golden Tee GOLF™ Version 11/12 Page 22

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

FINISHING THE CONTROL PANEL

1. Reattach the control panel to your cabinet adjusting any hinges or chains where necessary. Make sure not to pinch or crimp any wires while re-attaching the control panel.

2. Install the trackball into the trackball plate. The trackball must be oriented correctly in order to function properly. Refer to the diagram located in Appendix G for correct orientation. You will need the following parts in order to install the trackball correctly to the plate: 4 -10/32 x 2½" Phillips Head Machine Screws, 4 - #10

Flat Washers and 4 - #10 Split Lock Washers NOTE: Do not over-tighten the trackball. It will warp and cause the trackball to not operate correctly.

IMPORTANT! Be sure to install your trackball securely, and maintain it regularly. Loose, worn, or incorrectly mounted trackballs can result in decreased earnings and possible injury to players.

3. Secure the trackball ground wire to the trackball plate at the 8-32 stud on one end with an 8-32 KEPS nut and the other end to the cabinet ground stud (usually located near the AC power cord inlet) using an 8-32 KEPS nut.

4. Install the buttons in the holes located on your control panel. Make sure you use the red button assembly for the Start button.

5. Attach the micro switches to your newly installed buttons and connect the wires up to the correct pins on the

JAMMA harness.

Note: The post on the switch labeled COM should connect to the ground wire and the post labeled NO should connect to the signal wire. See the pin out chart in Appendix B.

WARNING: Trackball and trackball plate MUST BE GROUNDED to Earth Ground to prevent damage to the trackball, game electronics or harm to operators.

Golden Tee GOLF™ Version 11/12 Page 23

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

COMPLETE SYSTEM BOX CONNECTIONS

Follow these procedures to correctly connect the various electronic components. Be sure the cables are connected securely and in working order. Use cable clamps, with appropriate tension, where necessary to ensure all cables stay in place during operation. Dress all cables with additional clamps and wire tie wraps where needed. Avoid loose wires or disconnected cables, as they can cause an unneeded service call.

ATTACH I/O POWER, AUDIO AND USB CABLES

i I/O board power cable. Connect from the I/O board to one of the two 4-pin power output connectors on the system box. i Audio cables. Connect to the audio output jacks of the system box. Match the appropriate colors. i USB cable #1. Connect from the I/O board to any USB port on the system box. i USB cable #2 for future updates. Attach to any USB port on the system box. Route the other end to the control panel for easy access when updating. i USB cable #3 for Cabinet Identification Device (CID). Refer to the CID Installation Section for proper orientation and placement of the CID.

ATTACH MAIN VIDEO CABLE

If your cabinet has a VGA or SVGA monitor, connect the video cable from the system box directly to the VGA or

SVGA monitor input.

If your cabinet has Medium or Low Resolution monitor, connect the video cable from the system box to the I/O board.

If your monitor is a high-definition television, connect the appropriate video cable from the system box to the television inputs. Refer to Appendix D for help with the available connection configurations.

Be sure to adjust your Dip Switch settings to match your monitor’s resolution. Refer to Appendix D.

ATTACH POWER CABLE

Use the AC power cord that is currently in your cabinet. The cord plugs into the System box. Have a qualified electrician do the wiring. Verify A.C. main voltage selector switch is in the proper position. In North America the setting is 115 volts AC. In some countries this should be set at 230 VAC.

Golden Tee GOLF™ Version 11/12 Page 24

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

COMPLETE I/O BOARD CONNECTIONS

CONNECT JAMMA HARNESS

Connect the JAMMA Connector to the I/O Board. Be sure it fits tightly and is oriented correctly.

CONNECT THE CONTROL PANEL SWITCHES AND CABLE

Snap the switches onto the buttons. Connect the Control Panel wiring harness using the JAMMA wiring chart found in Appendix B - Kit.

CONNECT COIN DOOR LAMPS

Connect the coin door lamp cable to the pigtail off the I/O Power cable. If your cabinet originally had a Golden

Tee Fore! green PCB, then use the 9-pin connector. If your cabinet had a Golden Tee Fore! red PCB, then use the 4 pin connector. Find the mating connector leading to the coin door to make your connection.

CONNECT THE TRACKBALL

Locate the Trackball Cable and connect it to the connector labeled Trackball on the I/O board. The other end will connect to the trackball. Connect the green earth ground wire to the trackball plate.

CONNECT AUDIO CABLES

Locate the Audio Cables already connected to the system box, and connect them to the I/O board audio inputs.

Inputs are color coded, so be sure to connect red to red, etc.

CONNECT THE USB CABLE

Locate the 6 ft. USB Cable from the system box and connect it to the USB port on the I/O board.

CONNECT MEDIUM OR LOW RESOLUTION CRT MONITOR

If your cabinet has a Medium or Low Resolution monitor, you need to connect the video to the I/O board.

Connect the SVGA Video cable from system box to the J501 connector on the I/O Board. Connect the Red,

Green, Blue video outputs, the composite sync, and video ground from the JAMMA connector to the appropriate monitor inputs. To find the correct JAMMA pin outs refer to the diagram in Appendix B. Be sure to set the Video

Dip Switches on the I/O Board (Sw201) to match your resolution. Refer to the diagram in Appendix D.

CONNECT VGA OR SVGA CRT MONITOR

VGA or SVGA monitors are connected directly to the system box video output. Do not connect a video cable to the I/O Board if you are using these resolutions.

CONNECT HIGH-DEFINITION TELEVISION

In addition to traditional CRT monitors, GOLF also supports 800x600 and 1280x720 (SVGA, DVI-D and

Component) resolutions for some high-definition televisions. These televisions can be connected to the system box using Component, S-Video, DVI to VGA and DVI to HDMI connections. Refer to the diagrams in Appendix D for the proper connection for your television. Be sure to set the Video Dip Switches on the I/O Board (Sw201) to match your HDTV resolution.

CONNECT I/O POWER CABLE

Connect the I/O Power cable to the power input connector. Use the end with the pigtail. The other end connects to the system box.

CHECK ALL CONNECTIONS

Go over your entire cabinet again and double-check all of the connections. Make sure that all connectors are tight and secure and in their proper place. Look for frayed, broken or exposed wiring and repair as needed.

Bundle and wire-tie your wiring and secure it to the inside of the cabinet. A thorough and neat job now will save you a lot of time and trouble in the future.

Golden Tee GOLF™ Version 11/12 Page 25

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

CABINET GRAPHICS INSTALLATION

Included with your Golden Tee GOLF kit is a set of decals to place on the side of your cabinet and a brand new marquee. This will help identify your new game as Golden Tee GOLF. By placing and installing these correctly it can help give players instant recognition, even from a distance.

MARQUEE INSTALLATION

The following are the instructions for placing the new marquee in your cabinet:

1. Using the old marquee glass as a template, center the glass on top of your new marquee. Make sure that all the printed images are visible.

2. Using an X-acto® knife or other sharp blade, score the new marquee deeply by following the edges of the old glass as a guide.

CAUTION: Do not cut on table or counter top. Use a cutting board or a disposable surface.

4. Be sure the light behind the marquee works.

5. Clean the glass on both sides to give players a clear view of the new marquee.

Golden Tee GOLF™ Version 11/12 Page 26

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

FINAL CONNECTIONS

COIN DOORS, TEST SWITCH, AND VOLUME CONTROLS

Wire the coin doors as per the JAMMA Harness Connection table in Appendix B - Kit. Connect the door lamps to the appropriate (+12Vdc or +5Vdc) supply. Some games have separate power supply outputs for the lamps.

Install a test switch somewhere convenient inside the coin door area. This switch allows you to enter adjustables, run diagnostics, and see or clear audits. Make it readily accessible through the coin door. Wire it to the Test wire on the JAMMA Harness. GOLF has the ability to adjust volume at any time during a game. Install two push button switches (not included) inside the coin door for easy access. Connect the switches to the JAMMA harness. Refer to the JAMMA Harness Connection table in Appendix B - Kit.

INITIAL POWER-UP

There are several steps you should take when powering up your Golden Tee GOLF for the first time. This is a quick checklist for you to follow when doing your first initial power-up:

‰

Plug in the game and turn it ON; be sure the game powers up correctly into the attract mode.

‰

‰

Adjust volume levels to desired settings.

Adjust monitor settings for best picture.

NOTE: Sound and Video Tests are available through the System Tests Menu. They are beneficial when making any adjustments. Proper monitor and sound adjustment is very important.

‰

Try all money slots. Drop quarters or tokens through to check the coin mechanisms and insert a bill into the bill acceptor. Make sure the game is adding credits.

‰

NOTE: GOLF supports most bill acceptors. Installing a bill acceptor is highly recommended and will increase your earnings. Refer to your bill acceptor’s manual for installation specifications. The bill acceptor can be wired to coin door 3 on the JAMMA.

Test all of the player input controls. You can use the PLAYER CONTROL TESTS in the SYSTEM SETUP

MENU.

‰

Upon initial power-up the game is set to factory default settings. These settings affect game elements such as number of credits per coin, volume settings, etc. The SYSTEM SETUP MENUS section will describe how to alter these settings for your location.

Congratulations! You have finished installing

Golden Tee GOLF!

Golden Tee GOLF™ Version 11/12 Page 27

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

SYSTEM SETUP MENUS

NAVIGATING THE MENU SYSTEM

The System Setup menus cover a variety of important areas including collections, tests, game adjustments, and optional settings. You should familiarize yourself with these menus, as they are designed to optimize your game for your location and your business. Pay particular attention to the Collection menus, as they will detail how much money to give to your location and help you maximize your investment.

ENTERING SYSTEM SETUP MODE

There are two ways to enter System Setup. Open the coin door and press the Test button to access the game’s

System Setup software menu system. Or, from the I/O Board, move the DIP switch SW202 position 4 to the ON position. This switch needs to be moved back to OFF to exit the System Setup menus. Refer to the diagram in

Appendix D for all DIP switch settings.

SELECTING A MENU

A menu option can be selected at any time by rolling the trackball up or down or by pressing the Left or Right buttons.

CHOOSING A MENU/OPTION

A menu option can be chosen at any time by pressing the Start Button.

CHANGING A VALUE

A value can be changed at any time by rolling the trackball left or right.

MAIN MENU

The Main Menu displays five main areas that make up System

Setup mode. Please familiarize yourself with these areas, as they will help you maximize your earnings potential.

Collections & Earnings

– See Page 29

This section displays your machine’s monetary activity, and details the various areas for income and expenses. This section should be reviewed during every collection, to make sure you manage your split correctly.

General Settings

– See Page 30

This area allows you to change operator adjustables, perform system tests, and reset your game back to factory settings.

Troubleshooting Shortcuts

– See Page 41

This section presents a variety of tests and menus that will help you troubleshoot any problems you may be having with your game. The available sections are also accessible through the other main sections.

Golden Tee Settings & Audits

– See Page 41

This area allows you to adjust settings specific to Golden Tee GOLF including the player cost schedule, game features, and game audits.

ITNet Settings (Not available on GT GOLF)

Golden Tee GOLF is an offline product. The ITNet menu is not available.

Exit

This will exit the System Setup menus and take you back into the game’s attract mode.

Golden Tee GOLF™ Version 11/12 Page 28

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

COLLECTIONS & EARNINGS MENU

This menu allows you to perform a collection or view various earnings and fees.

Do Collection

This section is used when making a collection. The various screens will detail the cost breakdowns and show you how much of the cash box is to be paid to the location. Please take some time to familiarize yourself with this section. Using it wisely can save you money.

Clear Unused Cash

Sometimes when you go to make your collection, there is money in the game that has not been played yet. Use this setting to clear the unused cash from the screen, so your future collections will reconcile with game play.

Add Free Cash

Use this setting if you wish to add money to the game for free plays that do not advance the hard meter.

Back

This will take you back to the Main Menu.

DO COLLECTION

This screen is the main collection screen. There is a lot of helpful information displayed that will help you with your collection. It is highly recommended that you view this screen with every collection, and reset it when your collection is complete.

This screen displays the following helpful information:

Collection Date Range

The displayed dates are from your last collection until today.

Days In Operation

The number of days the machine was active and available for play since the last collection.

Reset

Highlight this to reset the number of days in operation field.

Total Income

The total income your machine made for this time period.

More Details

This brings up a second menu that further details income amounts.

Golden Tee GOLF™ Version 11/12 Page 29

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Total Fees

The total of the various fees that need to be set aside before making your split.

More Details

Select this to display a breakdown of the various fees, including Hardware Upgrade fees and tax splits.

Note: Hardware Upgrade Fees are included for your convenience, to help you cover the costs of owning and operating your equipment.

Balance

The total income minus the total fees.

Operator Portion of Balance

The amount of the collection that the operator keeps.

Operator Owes Location

The amount of the collection that you pay your location.

Back

If you do NOT wish to perform a collection and reset the audits, highlight Back to exit this screen and return to the

Collections & Earnings menu.

Do Collection and Exit

If you wish to perform a collection and reset the audits (recommended), highlight Do Collection and Exit and press

Start. This will set all the fields in the Do Collection screen to zero. Be sure to empty your cash box at the same time, so these screens will match the money at your next collection.

GENERAL SETTINGS

The General Settings menu houses various adjustable settings relating to the cabinet, and is divided into three sections.

Operator Adjustables

This area allows you to adjust options like volume, attract mode sounds, collection settings and money slot settings.

System Tests

This area allows you to perform diagnostics including video adjustments, input tests, and sound tests.

Back

This will take you back to the Main Menu.

Golden Tee GOLF™ Version 11/12 Page 30

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

OPERATOR ADJUSTABLES

This menu contains adjustable settings that pertain to you and your business. Please familiarize yourself with this section, as it can help you maximize the game’s earning potential.

General Adjustments

This area allows you to adjust options like coin message and money modes.

Money Slot Adjustments

This area allows you to adjust the settings of your various money slots on your cabinet.

Sound Adjustments

This area allows you to adjust the various sound settings including attract mode sounds, game volume, and stereo setup.

Collection Settings

This important area allows you to adjust various fees and splits for your collections.

Reset To Factory Settings

This option allows you to reset all the settings found in the Operator Adjustables section to factory defaults.

Back

This will take you back to the General Settings menu.

GENERAL ADJUSTMENTS

Coin Message

The default is set to Insert $.

Accept Credit Card (Not available)

This selection is not available on Golden Tee GOLF.

Game Mode

This lets you toggle between money/free play. The default

is set to Money Play.

2

nd

Monitor Mode

You can add an external monitor to your dedicated or kit game by connecting it to the appropriate video output on the Nighthawk Chassis. Use this setting to select from

SVGA and S-Video signals.

2

nd

Monitor Output

A second monitor can be added to clone the main monitor output.

Advertisements

This option allows you to “Show All Ads” or turn ads off.

Back

This will take you back to the Operator Adjustables menu.

Golden Tee GOLF™ Version 11/12 Page 31

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

MONEY SLOT ADJUSTMENTS

Money Slot 1 (all machines)

This adjusts how much one pulse equals for Money Slot 1.

The default is set to $0.25.

Money Slot 2 (kits only)

This adjusts how much one pulse equals for Money Slot 2.

The default is set to $0.25.

Money Slot 3

This adjusts how much one pulse equals for Money Slot 3.

The default is set to $0.25.

Credit Card (Not available)

This selection is not available on Golden Tee GOLF.

Reset Values

This resets all values to their default value located on this page.

No

This will not perform the reset and take you back to the previous menu.

Yes

This will perform the reset and take you back to the previous menu.

Back

This will take you back to the Operator Adjustables menu.

SOUND ADJUSTMENTS

In Game Volume

This option lets you adjust the In Game volume from OFF to 100%. The default is set to 30%.

Attract Volume

This option lets you adjust the Attract Mode Volume from

OFF to 100%. The default is set to 30%.

Attract Mode Sounds

This adjusts how often sounds are played in the attract mode: Never, Rarely, Sometimes, Often, and Always. The

default is set to On - Sometimes.

Stereo/Mono

This option is where you select stereo or mono setup. The default is set to Stereo.

Reset Values

This resets all values to their default value located on this page.

Back

This will take you back to the Operator Adjustables menu.

Golden Tee GOLF™ Version 11/12 Page 32

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

COLLECTION SETTINGS

Golden Tee GOLF allows you to adjust costs and percentages for the various income types that are received.

Use this menu to determine how much you want your location to help you pay for these charges and services.

Set Hardware Update Fee

This menu allows you to adjust the Hardware Update Fee.

This fee is included for your convenience, as a method to have the location pay for part of your equipment. The default value for 2013 machines is $0.00 per week. Adjust this value to an appropriate amount for your location.

Note: Hardware Update Fees are included for your convenience. No income is sent to IT on Golden Tee GOLF.

Operator/Location Income Splits

Use this menu to fine-tune your splits for any generated income. The default settings are displayed on the accompanying screen.

The adjustable settings refer to income generated from:

Cash

Player Account (Not available)

Credit Card (Not available)

ITNet Money Card (Not available)

Operator Money Card (Not available)

Golden Tee GOLF takes cash only.

Operator/Location Fee Splits

Use this menu to determine how you wish to split the various fees with your location. For example, since there is a fee associated with credit card usage, you may want to adjust the split in your favor to help cover the costs of the transaction fees.

ITNet Fees (Not available)

Prize Fund Fees (Not available)

Credit Card Fees (Not available)

Communication Fees (Not available)

Software Update Fees (Not available)

Hardware Update Fees

Golden Tee GOLF is an offline product and has no fees or income from online sources.

Hardware Update Fees are added for your convenience if you wish to have the location help pay for your equipment.

Golden Tee GOLF™ Version 11/12 Page 33

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Tax Settings

Many states require special taxes or license fees that affect your bottom line. Use this menu to separate these costs from your collection before making your normal split.

Set Tax Rate

This menu allows you to adjust your current tax rate percentage.

Set Tax Type

This menu helps you determine what part of the collection is taxed, and who pays for these taxes.

Set Tax Split

This menu allows you to split the tax fees with the location.

Reset to Defaults

This menu will set all of the collection settings to their factory default values. A verification screen will display to make sure you agree to the change.

Back

This will take you back to the Collection Settings menu.

RESET TO DEFAULTS

This menu will reset ALL settings in the Operator

Adjustments section to their default values. A verification screen will display to make sure you agree to the change.

Please Note:

This process may take several minutes to complete.

Golden Tee GOLF™ Version 11/12 Page 34

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

SYSTEM TESTS

This area allows you to perform diagnostics including video adjustments, input tests, and sound tests.

Video Tests

This area has tests that will help you to adjust your game’s color, contrast, and screen size.

Sound Tests

This area has tests that will help you adjust your game’s audio setup by playing a stored sound, a streaming sound, and testing the speaker(s).

Player Control Tests

This option allows you to test all inputs including trackball, buttons, and money slots.

Mechanical Meter

This test makes the hard meter adjust by one to make sure it is functioning properly.

Hardware Tests

This area includes a series of diagnostic screens and tests to help you make sure your game is functioning correctly.

Back

This will take you back to the General Settings menu.

VIDEO TESTS

The Video Tests section has a variety of tests that will help you adjust your monitor.

Color Test

This area will take you to a series of tests to adjust your monitor’s RGB settings to have each color display properly.

Contrast Test

This area will take you to a series of tests to adjust your monitor’s brightness/contrast so the game displays properly.

Screen Size Adjustments

Use this screen to align your monitor so that all the circles appear as circles and the boundary line appears on the edge of each side of the screen.

Back

This will take you back to the System Tests menu.

Golden Tee GOLF™ Version 11/12 Page 35

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

COLOR TEST

Color Grid Adjustment

Adjust your monitor to have each colored box display properly.

Red Screen

Adjust your monitor to have red display properly.

Green Screen

Adjust your monitor to have green display properly.

Blue Screen

Adjust your monitor to have blue display properly.

Back

This will take you back to the Video Tests menu.

CONTRAST TEST

White Screen

Adjust your monitor to have white display properly.

50% White Screen

Adjust your monitor to have 50% white display properly.

25% White Screen

Adjust your monitor to have 25% white display properly.

Black Screen

Adjust your monitor to have black display properly.

Contrast Screen

This option is a test you can use to adjust your monitor’s contrast and brightness settings to have the boxes displayed properly.

Note: May not work on older or often used monitors. If you have a monitor that's old or has been used often you may not be able to adjust the contrast and/or brightness levels accordingly. In this case adjust the monitor for best performance while getting close to the recommended settings.

Contrast Screen

This option is a test you can use to adjust your monitor’s contrast and brightness settings to have the boxes displayed properly.

Back

This will take you back to the Video Tests menu.

Golden Tee GOLF™ Version 11/12 Page 36

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

SCREEN SIZE ADJUSTMENT

Use this screen to adjust the size and aspect ratio of your picture. Press the Start button to exit.

If you are using an HDTV display, you may need to adjust this screen to see the complete image. Use the trackball to highlight BIGGER or SMALLER and press the Start button to adjust the screen image. Press DONE to exit.

Note: Adjusting the screen size will prompt a reboot upon exit of this menu.

SOUND TESTS

Stored Sound

This will play a stored sound so you can make sure your audio setup is functioning properly.

Streaming Sound

This will play a streaming sound so you can make sure your audio setup is functioning properly.

Speaker Test

This test will say MONO if you have your game set to Mono or LEFT and RIGHT if you have it set to stereo so you can make sure your audio setup is functioning properly.

Back

This will take you back to the System Tests menu.

PLAYER CONTROL TESTS

Use this screen to test all of the inputs, including the trackball, buttons, and money slots. When an input is active the appropriate graphic image will light. Press the Left, Right and

Start buttons simultaneously to exit this test screen.

When testing the trackball, the Current value will change depending on the direction the ball is spinning. The Max value will display the largest number reached during the test.

There is no exact number to determine whether a trackball is malfunctioning, but in general the Max number should be close to the same when spinning up and down, and close to the same when spinning left and right.

When testing coin and bill acceptor switches, the number of pulses read will be displayed below the appropriate image.

Golden Tee GOLF™ Version 11/12 Page 37

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

MECHANICAL METER TEST

Click Meter

This test makes the hard meter adjust by one to make sure it is functioning properly.

Back

This will take you back to the System Tests menu.

HARDWARE TESTS

This area includes a series of diagnostic screens and tests to help you make sure your game is functioning correctly.

Hardware/Software

This area has options to view your system, USB and version info.

Check Hard Drive

This test checks the integrity of your hard drive’s data. Note:

This test can take several minutes.

Check Cooling

This test helps you make sure your game is functioning at the proper temperature and all fans are working.

Check Card Reader (Not used on Golf)

This selection is not available on Golden Tee GOLF.

Back

This will take you back to the System Tests menu.

HARDWARE/SOFTWARE

System Info

This is a list of your game’s current basic system info.

USB Info

This is a list of your game’s current USB devices.

Version Info

This is a list of your game’s software version information.

Back

This will take you back to the Hardware Tests menu.

Golden Tee GOLF™ Version 11/12 Page 38

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

SYSTEM INFO

This is a list of your game’s current basic system information, including Hard Drive, CPU and Video Card.

Back

The Back button takes you back to the Hardware/Software menu.

USB INFO

This is a list of your game’s current USB devices.

Back

The Back button takes you back to the Hardware/Software menu.

VERSION INFO

This is a list of your machine’s software versioning.

Back

The Back button takes you back to the Hardware/Software menu.

Golden Tee GOLF™ Version 11/12 Page 39

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

CHECK HARD DRIVE

Check File Data

This test checks the integrity of your hard drive’s data.

Select Begin Test to initiate the process.

Note: This test can take up to 3 hours to complete.

If this test succeeds you will see the message: Status:

Hard Drive Functioning Properly. If this test fails, you will see the message: Hard Drive Error (#)

Select Back to skip the test and return to the Check Hard

Drive menu.

Check File System

This test REBOOTS YOUR GAME and performs a low level systems check of the integrity of your hard drive.

Note: This can take several minutes.

Back

This will take you back to the Hardware Tests menu.

CHECK COOLING

This checks that your game is functioning at the proper temperature and all fans are working. The current status is color-coded for easy viewing. If the results are displayed in green, your cabinet is at normal settings.

Back

The Back button takes you back to the Hardware Tests menu.

Golden Tee GOLF™ Version 11/12 Page 40

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

TROUBLESHOOTING SHORTCUTS

This section gathers many of the commonly used tests and menus into one convenient area. Check here first when troubleshooting problems or questions about the integrity of your machine.

The tests that are available in this section are:

Check Card Reader (Not available on Golf)

Check Cooling

Check Hard Drive

Screen Size Adjustments

Communications Settings (Not available on Golf)

Player Control Tests

System Tests

Descriptions of each of these tests and sections can be found elsewhere in this manual.

Back

This will take you back to the Main Menu.

GOLDEN TEE SETTINGS & AUDITS

Golden Tee Settings

This section allows you to make custom adjustments to certain features on your machine, such as the delay of game timer.

Golden Tee Audits

This area allows you to view your money audits, game purchase audits, and reset audits.

Player Cost Schedule

This option allows you to adjust the amount of money it costs a player to play various game types.

Reset Leaderboards & Records

This area allows you to clear any or all local Leaderboards and high score screens. Note: This process may take several minutes to complete.

Back

This will take you back to the Main Menu.

Golden Tee GOLF™ Version 11/12 Page 41

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

GOLDEN TEE SETTINGS

LIVE Prizes (Not available)

Prize play is not available on offline games.

Delay of Game Timeout

Adjust the timer that senses activity between shots.

Closest To The Pin LIVE (Not available)

Live play is not available on offline games.

Operator CTP

Activate the ability for the game to enter Closest to the Pin

(CTP) mode. This version of CTP does not display any sponsored or branded game elements.

Activate Sponsored CTP (Not available)

Sponsored CTP is not available on offline games.

Hole-N-Win (Not available)

Hole-N-Win is not available on offline games.

More

Selecting More brings you to a second page of Golden Tee settings.

Locked Conditions (Not available)

Locked Conditions are not available on offline games.

Free Holes in Attract Mode (Not available)

This feature is not available on offline games.

Difficulty

You can set the difficulty of the courses, to adapt the game to the needs of your specific location. Difficulty settings can be adjusted from 1 (easiest) to 5 (hardest). The default setting is 2.

Pre-game Casual Clothing (Not available)

Players have a selection of all clothing prior to 2013 available.

Mulligans

Mulligans allow casual game players to retake a bad shot during their game. To disable this feature select OFF.

Allow Casual Straight Shots

This allows casual players the option to choose whether to play with only straight shots or to allow curved shots as in standard settings mode. To disable this feature select NO.

Spotlight Player Settings

These settings allow local operators to offer prizes based on Golden Tee casual golf game play.

Reset Values

This will reset all Golden Tee Settings to their factory defaults.

Back

This will take you back to the Golden Tee Settings & Audits page.

Golden Tee GOLF™ Version 11/12 Page 42

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

CASUAL GOLF SPOTLIGHT PLAYER

This allows operators to set the prize for a weekly drawing based on all players who achieved a score of

PAR +17 or better.

Prize Settings

This opens This Week’s Prize Settings to set the prize available for the winner of the drawing.

Clear Last Winner

This removes the last winner from the results.

Reset Values

This will reset all Casual Weekly Drawing settings

SPOTLIGHT PLAYER PRIZE SETTINGS

Edit Prize Text

Enter the text that best explains the prize offered. For example, “Free dinner any week night to this week’s winner!”

Remove Prize

Select this option if you do not wish to run a prize drawing.

Golden Tee GOLF™ Version 11/12 Page 43

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

GOLDEN TEE AUDITS

This section displays various counts and totals for a number of game options. The following values are based on the last reset, the date of which is shown at the top of the screen.

Total Number of 18 hole purchases

Total Number of 9 hole purchases

Number of 1 hole purchases

Number of skins play purchases

Mulligans purchased

Coin Slot 1

Coin Slot 2

Bill Acceptor

Lifetime Money In

This field shows how much total money your machine has made since its initial registration with ITNet. This field is cumulative and is not affected by resetting the audits on this screen.

Reset Audits

This will reset all audits to zero, and update the date of the last audit reset. The Lifetime Money In field will not be affected by this function.

More

This will take you to another Golden Tee Audits page.

GOLDEN TEE AUDITS

This second page focuses on casual play feature audits.

Casual curve shots chosen

Casual straight shots chosen

Casual spotlight players eligible

Casual spotlight players accepted

Casual spotlight players declined

Back

This will take you back to the previous Golden Tee

Audits page.

Golden Tee GOLF™ Version 11/12 Page 44

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

PLAYER COST SCHEDULE

This screen details the costs of various play selections.

The player cost is shown as a total, with the Operator

Portion and the ITNet Portion broken out.

Play Golf (18 Holes)

This option lets you adjust how much it costs a player to play an 18-hole game. The default is set to $3.00.

Play Golf (9 Holes)

This option lets you adjust how much it costs a player to play a 9-hole game. The default is set to $2.00.

Play Golf (1 Hole)

This option lets you adjust how much it costs a player to play a single hole of Golf. The default is set to $0.25.

Mulligans

This option lets you adjust how much it costs a player buy a Mulligan and repeat his shot in Casual Play mode.

The USA default is set to $0.25.

Skins (3 Holes)

This option lets you adjust how much it costs a player to play 3 holes in Skins Play mode. The default is set to

$0.75.

Skins (9 Holes)

This option lets you adjust how much it costs a player to play 9 holes in Skins Play mode. The default is set to

$2.00.

Skins (18 Holes)

This option lets you adjust how much it costs a player to play 18 holes in Skins Play mode. The default is set to

$3.00.

View Fixed Costs

This menu is not available on Golf.

Reset Values

This resets all values to their default value located on this page.

Back

Select this to return to the Golden Tee Settings & Audits menu.

RESET LEADERBOARDS & RECORDS

Use this menu to reset various machine-specific

Leaderboards.

Reset Leaderboards

This leaderboard is displayed after every hole during a game. Use this setting to clear the current play data.

Reset Course Records

Course records, such as best score on each course, are displayed on various screens during a game and in the attract mode, and replayed in the game's attract mode.

Use this setting to clear all course records and game highlights.

Reset All

Use this setting to clear all Leaderboards, course records and game highlights.

Golden Tee GOLF™ Version 11/12 Page 45

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

TROUBLESHOOTING & REFERENCE

APPENDIX A

TROUBLESHOOTING GUIDE

Video Problems

Symptom

No picture on the 27” Monitor

No picture but game sounds are heard

Scrambled Picture

Entire picture is not seen on the screen or it does not fill the entire screen

Missing or washed out colors

Probable Cause

I/O Board DIP Switch settings are wrong.

Incorrect video connection configuration.

Misadjusted monitor.

Solution

Adjust DIP Switch settings to match the resolution of the monitor you are using. Refer to I/O DIP Switch

Settings in Appendix D.

Incorrect video connection configuration.

Be sure the video connections are correct according to the type of monitor you are using. Refer to the diagrams in Appendix D.

Monitor does not have a proper

A.C. voltage input.

Verify A.C. power to the Nighthawk

System box. Verify monitor is working on a known good system.

Repair or replace. Monitor is defective.

Nighthawk System box is defective Go to Nighthawk System box troubleshooting section.

Incorrect video connection configuration.

Verify video is connected to the system correctly. Refer to the diagrams in Appendix D.

Since you hear game sounds the system is working.

I/O Board DIP Switch settings are set wrong.

Review no picture troubleshooting section above.

Adjust DIP Switch settings to match the resolution of the monitor you are using. Refer to DIP Switch Settings in Appendix D.

Be sure the video connections are correct according to the type of monitor you are using. Refer to the diagrams in Appendix D.

Adjust the monitor width and height.

Bad Video connections

Contrast and brightness on the monitor needs to be adjusted.

Defective Monitor.

Use video screen adjustment in system tests. Refer to the monitor manual.

Verify continuity from the monitor to the video out on the I/O Board. Red,

Green, Blue video signal. Mid. and

Low resolution monitors only.

Refer to the monitor manual to make adjustments.

Verify by connecting a known good monitor to the system.

Golden Tee GOLF™ Version 11/12 Page 46

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Sound Problems

Symptom

No audio

Probable Cause

Audio Cable between the I/O Board and the Nighthawk system box are not connected.

Speakers are not connected properly.

Volume is set to the lowest level.

Solution

Verify audio cables are connected.

Refer to Appendix D.

Verify continuity from the I/O Board speaker output pins to the speakers.

Refer to Appendix D.

Adjust the volume to an audible level.

Choose one of the 5 Attract Mode Attract mode sounds may be set to all off. You will have sounds when playing the game.

Defective I/O Board. sound options in Sound

Adjustments.

Verify on a known working system.

Replace if necessary.

Defective Nighthawk system box. Be certain all other possibilities are explored before replacing the

Nighthawk system box.

DIP switch settings are incorrect for your application

Refer to Monitor Applications at the back of this manual for proper setup.

Distorted or scratchy game audio Bad speaker.

Loose speaker or grill cover is causing vibration.

Loose/defective audio cables from the Nighthawk system box to the

Replace blown speaker.

Verify all components are installed properly and securely.

Check the audio cable connections.

Replace cable.

I/O Board.

Defective I/O Board. Verify on a known working system.

Replace if necessary.

Defective Nighthawk system box. Be certain all other possibilities are explored before replacing the

Nighthawk system box.

Nighthawk Chassis Problems

Symptom

No video and no green lights on the I/O Board. Fans are not heard on the Nighthawk Chassis.

Probable Cause

No AC power to the Nighthawk

Chassis.

Power switch on the Nighthawk

Chassis is off.

Main cabinet power switch is off.

No video and no green lights on the I/O Board. Fans are heard on the Nighthawk Chassis.

Soft Power Shutdown

Defective Nighthawk Chassis.

DC power cord not connected from

Nighthawk Chassis to I/O Board.

Defective I/O Board.

Solution

Verify A.C. voltage is connected to the Nighthawk Chassis.

Flip the Nighthawk Chassis power switch to on.

Be certain the main cabinet switch is set to on.

Press the Soft Power button with the power turned on. Or, short the top 2 pins of the 6-pin connector on the system box. See Appendix D.

Be certain all other possibilities are explored before replacing the

Nighthawk Chassis.

Connect the DC power cord from the

Nighthawk Chassis to the I/O Board.

Try it on a known good system.

Verify by disconnecting all cables from the I/O Board except the DC power and USB cable to the

Nighthawk Chassis. No green lights, replace the I/O Board.

Golden Tee GOLF™ Version 11/12 Page 47

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Control Problems

Symptom

Button does not work.

Probable Cause

Switches Common post is not connected to digital ground.

Signal wire is not connected to the

Normally Open post of the switch.

Switch is defective.

Signal wire is connected to the

Normally Closed post of the switch.

Solution

Verify continuity to digital/power supply ground.

Verify continuity from the I/O Board to the Normally Open post of the switch.

Replace defective switch.

Connect signal wire to the Normally

Open post of the switch.

Button always indicates closed in the player control test. Pressing it will show it is not depressed.

Button always indicates closed in player control test even with the switch disconnected entirely.

Trackball is not functioning in any direction.

Defective I/O Board. Test on a known good system.

Replace if necessary.

Trackball does not work in a certain direction.

Trackball works intermittently.

Trackball is not connected to the

I/O Board properly.

Defective trackball Interconnect cable.

Trackball is defective.

I/O Board is defective

Trackball cable is defective.

Trackball is defective.

I/O Board is defective.

Inside of the trackball is dirty.

Rollers are worn.

Trackball is over-tightened.

Verify the trackball is connected to

J208 labeled trackball on the I/O

Board.

Verify continuity on the trackball

Interconnect cable.

Replace trackball.

Replace I/O Board. Try it on a known good system.

Verify continuity on the trackball cable. Repair or replace if needed.

Repair or replace the trackball. Try it on a known working system.

Repair or replace the I/O Board. Try it on a known working system.

Clean the inside of the trackball.

Replace the rollers and bearings.

Do not over-tighten the trackball.

Tighten just enough to flatten the lock washers.

HDTV Video Problems

Symptom

There is no picture during boot up.

Probable Cause

Incorrect video cable configuration.

Connected to the wrong output on the system box

Connected to the wrong input on the HDTV

Incorrect input selected on the

HDTV

DIP switch setting SW 201 on the

I/O Board set incorrectly.

Solution

Be sure you are using the proper cable connections. Refer to the

HDTV connections configurations.

Refer to the HDTV connections configurations.

HDTVs usually have more than 1 input for a certain input type.

Examples are Component 1 & 2;

HDMI 1 & 2.

Be sure the correct input is selected from the HDTV input menu.

Example: If using HDMI 1 that input must be selected from the HDTV video input menu.

Sw201 on the I/O Board must be configured to match the method of video you are using.

Golden Tee GOLF™ Version 11/12 Page 48

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Symptom Probable Cause

Normal black screen is displayed for a period of time just before 3D graphics are displayed.

Solution

This is normal operation. Be sure to wait at least two minutes after

LOADING GAME is displayed to see if video appears.

No picture after boot up

Distorted of fuzzy picture

Picture is too big for the screen or does not fill the entire screen.

Your VGA cable is connected to the second monitor output.

Incompatible video mode

Improper cable connection

Incorrect DIP switch configuration.

Connect the VGA connector to the main output port.

Many monitors will not accept SVGA

720p or 800 X 600. 640 x 480 usually works. A commercial grade

HDTV will usually work.

Be sure the video cables are securely connected at the computer video card and at the HDTV. This is especially critical if using a component video cable.

Be sure Sw201 is configured to match the desired video.

Increase or decrease screen size in games adjustments.

Location is in General

Settings>Operator>System

Tests>Video Screen

Settings>Screen Size Adjust

HDTV Audio Problems

No Audio

Low volume

Scratchy or distorted audio

No audio

RCA audio cable is not connected to the system box or HDTV

RCA audio cable is connected to the wrong audio input of the HDTV

HDTV audio is muted

Volume is turned down on the monitor or game sounds are set too low.

Volume is turned down on the monitor or game sounds are set too low.

Poor cable connection RCA cable

Connect the RCA audio cable to the system box and then to the proper input on the HDTV.

You must connect the audio cable to the matching video input selected.

For example: If you are using

Component 1 the audio must go to

Component 1.

Turn the mute off in the HDTV menu.

Adjust the volume on the game to

75% and then adjust the game volume to your desired level.

Adjust the volume on the game to

75% and then adjust the game volume to your desired level.

Be sure the RCA audio cable is securely and entirely connected the mating connectors.

DIP switch settings are incorrect for your application

Refer to Monitor Applications at the back of this manual for proper setup.

Golden Tee GOLF™ Version 11/12 Page 49

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Flash Code Messages

Flash Code (I/O Diode D102) Code Description

Flash Code 2

Flash Code 3

Flash Code 4

Flash Code 5

Solution

Possible IO board failure

Info: Last reboot due to Watchdog time out.

First Check Connections. Turn off game, wait 10 seconds, turn game on. If

Problem persists call IT tech support.

Turn off game, wait 10 seconds, turn game on. If Problem persists call IT tech support.

Error When updating CID to latest

Version

Updated USB CID was detected. This is not an error but a notification.

Typically CID failure. Turn off game, wait

10 seconds, turn game on. If Problem persists call IT tech support.

Turn off game, wait 10 seconds, turn game on. If Problem persists call IT tech support.

Flash Code 6

Flash Code 7

Flash Code 10

Flash Code 11

Flash Code 12

Flash Code 13

Flash Code 14

Miscellaneous Problems

Symptom

Unable to exit Operator Menus.

Disconnected Cabinet ID Device (CID) was detected.

CID Malfunction. Typically CID is defective.

Error When updating USB IO board to latest version. Typically an IO board failure

Check USB connection. Turn off game, wait 10 seconds, turn game on. If

Problem persists call IT tech support.

Turn off game, wait 10 seconds, turn game on. If Problem persists call IT tech support.

Turn off game, wait 10 seconds, turn game on. If Problem persists call IT tech support.

Turn off game, wait 10 seconds, turn

Updated USB IO board to latest version. game on. If Problem persists call IT tech

This is not an error but a notification. support.

Turn off game, Check USB and power connections, turn game on. If Problem

A disconnected IO board was detected. persists call IT tech support.

IO board malfunction. Typically IO board has failed.

Turn off game, wait 10 seconds, turn game on. If Problem persists call IT tech support.

Game is incompatible with USB IO board.

This usually means the wrong type of IO board. It does not match the system box software. Try turning off game, wait 10 seconds, turn game on. If problem persists call IT tech support.

No fluorescent light

Coin Meter is not working

Probable Cause

DIPswitch SW202 position 4 is in the on position.

Test switch wired from the I/O

Board is closed.

No 120 volts A.C. power going to the light fixture.

Defective fluorescent light.

Defective starter

Defective ballast.

Defective Coin Meter

Not wired properly

Defective I/O Board

Solution

Set position 4 of SW202 to off.

Press start to exit.

Verify satellite test switch is not closed.

Verify A.C. voltage to the light fixture.

Replace fluorescent light.

Replace the starter.

Replace the ballast.

Replace with a known good one.

Connect one lead to +5 or +12 volts depending on device. The other lead to coin meter on Service Panel Pin

2.

Replace with a known good board.

Golden Tee GOLF™ Version 11/12 Page 50

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

APPENDIX B

– SHOWPIECE INPUT/OUTPUT CONNECTIONS (I/O POWER,

TRACKBALL, ETC.)

For Standard Online Kit and Deluxe Retrofit Kit

Trackball Harness Connector Pin Outs

I/O Board Connector Trackball Connector

PIN WIRE #6 – Black PIN WIRE #1 – Black

PIN WIRE #1 – Red

PIN WIRE #2 – Yellow

PIN WIRE #3 – Green

PIN WIRE #5 – Blue

PIN WIRE #2 – Red

PIN WIRE #3 – Yellow

PIN WIRE #4 – Green

PIN WIRE #5 – Blue

I/O Power Cable Pin Outs

Pin Number Wire Color Function

1 Yellow + 12 Volts DC

2

3

4

Black

Red

Black

Ground

+ 5 Volts DC

Ground

PIN WIRE #4 – Purple PIN WIRE #6 – Purple

Control Panel J203 Connector Pin Outs

Pin Color Function

1 Green-White Options

2

3

Brown-White Left

N.C.

4 Yellow-White Right

5

6

7

Violet-White

Black

Black-White

Flyby

Volume GND

Spin

8

9

10

Blue-White

Red-White

Black

Help

Start

Ground

Pin

1

2

3

4

Color

Yellow-Red

Yellow-Green

White-Red

White-Green

Lamps J202 Connector Pin Outs

Pin

1

5

6

Color

Red-Black

Red-Yellow

Red-Green

Function

Lamp Power – Buttons

Help Lamp

Options Lamp

Service

Function

Pin Color Function

Left Speaker +

1

Red-Black Meter Power

Left Speaker -

2

Red-Green Coin Meter

Right Speaker +

Right Speaker -

3

4

5

6

7

Orange-White

Orange-Yellow

Blue

Black

Volume Up

Volume Down

N.C.

Test

Test Ground

Pin

1

2

3

4

5

6

7

8

9

10

11

Coin Door J205

Color Function

Red-Black Lamp Power – Coin

Black

Black

Lamp Ground – Coin

N.C.

Bill Ground

Grey-White Bill

N.C.

N.C.

Green-Blue

Red-Blue

Black

Coin 2

Coin 1

N.C.

Coin Ground

Note: N.C. stands for No Connection

Golden Tee GOLF™ Version 11/12 Page 51

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

APPENDIX B

– KIT JAMMA, TRACKBALL, AND I/O POWER CONNECTIONS

JAMMA Harness Connection

SOLDER SIDE PARTS SIDE

WIRE COLOR

KEY

Yellow-Green

White-Green

Green-Black

White

Green-Blue

Orange-Yellow

Black

Black

FUNCTION

*

*

*

*

*

Count 2

Left Speaker (-)

Right Speaker (-)

Video Green

Video Sync

Coin 2

Volume Down

GND

GND

FUNCTION

*

*

*

*

*

KEY

Coin Counter

Left Speaker (+)

Right Speaker (+)

Video Red

Video Blue

Video GND

Test

Coin1

Start /Options

Overview

Left

Right

Volume Up

Coin 3 (Bill)

GND

GND

15

16

17

18

19

20

21

22

23

24

25

26

27

28

7

8

9

10

11

12

13

14

1

2

3

4

5

6

Y

Z a b

S

T

U

V

W

X c d e f

M

N

P

R

H

J

K

L

A

B

C

D

E

F

*NOTE: Power is NOT routed through the JAMMA connector.

Trackball Harness Connector Pin Outs

I/O Board Connector Trackball Connector

PIN WIRE #6 – Black PIN WIRE #1 – Black

I/O Power Cable Pin Outs

Pin Number

1

Wire Color

Yellow

Function

+ 12 Volts DC

PIN WIRE #1 – Red

2

PIN WIRE #2 – Yellow

PIN WIRE #3 – Green

PIN WIRE #5 – Blue

PIN WIRE #4 – Purple

PIN WIRE #2 – Red

PIN WIRE #3 – Yellow

PIN WIRE #4 – Green

PIN WIRE #5 – Blue

PIN WIRE #6 – Purple

3

4

Black

Red

Black

Ground

+ 5 Volts DC

Ground

WIRE COLOR

Red-Green

Yellow-Red

White-Red

Red-Black

Blue-Black

White-Black

Blue

Red-Blue

Red-White

Violet-White

Brown-White

Yellow-White

Orange-White

Gray-White

Black

Black

Golden Tee GOLF™ Version 11/12 Page 52

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

APPENDIX C

REPLACEMENT PART NUMBERS

Please refer to these IT part numbers when placing orders.

Part Number Description

925000328P SHOWPIECE CABINET, US GOLDEN TEE GOLF (OFFLINE) 2013 COMPLETE UNIT

900146007R CABINET IDENTIFICATION DEVICE, GOLF

915000285R CABLE ASSY, AUDIO CABLE, 6 FT 2RCA PLUG TO 2RCA PLUG

915250304R CABLE ASSY, I/O POWER FOR KITS

915000745 CABLE ASSY, POWER CORD. A.C.

915000315R CABLE ASSY, SVGA, 6 FT. DB15HD M-M

915000310R CABLE ASSY, USB CABLE, 6 FT.

915000173R CABLE ASSY, TRACKBALL/GUN INTERFACE

915015400R CABLE ASSY, HDMI, 15 FT.

999000060R CARD READER BLANKING PLATE

938291715 CASH VAULT COMPLETE ASSEMBLY W/ $1-5 DBA

825100294R CONTROL PANEL OVERLAY GRAPHIC, DIECUT WITH CONTROL LABELS/TB HOLE

999000288 DBA, MARS $1-5 BILL ACCEPTOR FOR IT CASH VAULT ONLY MODEL AE2481D5E

900328000R I/O BOARD FOR GT GOLF 2013 DEDICATED

900100328R I/O BOARD FOR GT GOLF 2013 KIT

840500250R GT.COM LOGO CARD FOR NON-TOURN. CABINETS

925000328 KIT – GT GOLF (OFFLINE) 2013

815000328 MANUAL, GT GOLF 2013

820000328R MARQUEE, GT GOLF 2013

850000001R PUSHBUTTON ASSY, RED WITH VERTICAL MOUNTED SWITCH

850000003R PUSHBUTTON ASSY, WHITE WITH VERTICAL MOUNTED SWITCH

840250100 QUICK INSTALL GUIDE, GT GOLF

830000294R SIDE DECAL, GT GOLF

900065327R2 SYSTEM BOX, GT 2013

753304004 SYSTEM BOX FILTER

752259500R SYSTEM BOX FILTER BRACKET

880000030R TRACKBALL ASSY, 3" WHITE

885000030R TRACKBALL PLATE FOR 3" TRACKBL WITH STANDOFFS

Golden Tee GOLF™ Version 11/12 Page 53

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

APPENDIX D

NIGHTHAWK COMPONENT DIAGRAMS

Nighthawk System Box Diagram

I/O Board Diagram

Golden Tee GOLF™ Version 11/12 Page 54

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Video and I/O DIP Switch Settings for CRT Monitors

Video and I/O DIP Switch Settings for High Definition Televisions (HDTV)

Golden Tee GOLF™ Version 11/12 Page 55

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Showpiece Cabinet Connection Diagram

Golden Tee GOLF™ Version 11/12 Page 56

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

KIT Cabinet Connection Diagram

Golden Tee GOLF™ Version 11/12 Page 57

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 58

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

SW-PB

SOFT POWER

UNDER

CONTROL

PANEL

HDMI CABLE

TO CUSTOMER SUPPLIED TV

LEFT RIGHT

SW-PB

FLYBY

SW-PB

SW-PB

CONTROL PANEL

GREEN/YELLOW

.093 6PIN PLUG

TRACKBALL

+5V

LAMP

COIN MECH 1

SW SPST

VAULT

TRACKBALL

TEST

SW-PB

GREEN

SPIN

SW-PB

SOFT POWER (WHITE/YELLOW)

SOFT POWER (WHITE/ORANGE)

.093 2PIN RECEPTACLE

1

2

GND (BLACK)

+12VDC (YELLOW)

.093 2PIN RECEPTACLE

1

2

GND (BLACK)

+12VDC (YELLOW)

+5V LAMP

HELP

SW-PB

SW-PB

VOLUME DOWN

SW-PB

VOLUME UP

SERVICE PANEL

COIN

METER

+5V LAMP

OPTIONS

SW-PB

START

SW-PB

WHITE RCA JACK

RED RCA JACK

NIGHTHAWK DB65 SYSTEM

BOX

HDMI

DP

USB CABLE

CID PCB

J1

USB

RIGHT

GREEN/YELLOW

RIGHT SPEAKER - (WHITE/GREEN)

RIGHT SPEAKER + (WHITE/RED)

SPEAKER

LEFT

GREEN/YELLOW

LEFT SPEAKER - (YELLOW/GREEN)

LEFT SPEAKER + (YELLOW/RED)

SPEAKER

PLUG AC FEMALE

USB

USB

ETHERNET

USB

USB

15 PIN VGA

ADAPTOR

BROWN

CHASSIS POWER

SJT CABLE UL1015 TYPE

BLUE

YELLOW/GREEN

USB CABLE

LAMP (RED/BROWN)

LAMP (RED/YELLOW)

LAMP POWER (RED/BLACK)

GND (BLACK)

START (RED/WHITE)

HELP (BLUE/WHITE)

SPIN (BLACK/WHITE)

VOL GND (BLACK)

FLY BY (VIOLET/WHITE)

RIGHT (YELLOW/WHITE)

LEFT (BROWN/WHITE)

OPTIONS (GREEN/WHITE)

8

7

6

5

4

3

2

1

10

9

8

7

6

5

4

3

2

1

U209 PIN 9

U209 PIN 6

U209 PIN 5

U209 PIN 4

U209 PIN 3

U209 PIN 2

U209 PIN 7

J103

USB

3

4

1

2

5

1

2

3

4

+12V (YELLOW)

GND (BLACK)

+5V (RED)

GND (BLACK)

USB CABLE

BLACK/RED

GREEN/YELLOW

WHITE/RED

1

2

3

3191 3 PIN PLUG

1

2

3

BLACK/RED

YELLOW/GREEN

WHITE/RED

3191 3 PIN RECEPTACLE

DBA POWER

110VAC

BILL (GREY/WHITE)

BILL GND (BLACK)

TEST GND (BLACK)

TEST (BLUE)

VOL DOWN (ORANGE/YELLOW)

VOL UP (ORANGE/WHITE)

COIN METER (RED/GREEN))

METER POWER (RED/BLACK)

5

4

3

2

1

7

6

U210 PIN 7

U210 PIN 6

U210 PIN 8

U210 PIN 9

Q206 COLLECTOR

DEDICATED I/O PCB

6005 REV 2.3 RoHS

DBA

.093 9 PIN PLUG

.093 9 PIN RECEPTACLE

AC HOT (BLACK/RED)

AC NEUTRAL (WHITE/RED)

BILL (GREY/WHITE)

BILL GND (BLACK)

COIN 1 (RED/BLUE)

COIN GND (BLACK)

LAMP GND (BLACK)

LAMP POWER (RED/BLACK)

TEST GND (BLACK)

TEST (BLUE)

VOL GND (BLACK)

VOL DOWN (ORANGE/YELLOW)

VOL UP (ORANGE/WHITE)

METER POWER (RED)

COIN METER (BLACK)

COIN METER

.062 2 PIN RECEPTACLE

TEST VOLUME

.062 3 PIN RECEPTACLE

.062 4 PIN RECEPTACLE

COINS

1

2

3

4

5

6

7

8

9

7

8

5

6

9

3

4

1

2

COIN 4 (GREY/BROWN)

LAMP GND (BLACK)

LAMP POWER (RED/BLACK)

COIN 3 (GREY/ORANGE)

COIN 2 (GREEN/BLUE)

COIN 1 (RED/BLUE)

BILL (GREY/WHITE)

BILL GND (BLACK)

COIN GND (BLACK)

.093 9 PIN PLUG .093 9 PIN RECEPTACLE

.062 2 PIN PLUG

COIN METER

.062 4 PIN PLUG

VOLUME

.062 3 PIN PLUG

TEST

LINE FILTER W/ IEC INPUT

QUALTEK 857-10/033

EARTH GROUND

GREEN

GREEN/YELLOW

YELLOW/GREEN

GREEN/YELLOW

GREEN

HOT (BLACK)

NEUTRAL (WHITE)

J205

11PIN MINI KK

COINS

TRACKBALL

3

4

1

2

5

6

.093 6PIN RECEPTACLE

THERMAL CIRCUIT BREAKER

4A TYCO W28-XQ1A-4

AC HOT

BLACK/RED

6PIN COMMONING CONNECTOR

BROWN

BLACK/RED

1

3

5

2

4

6

J208

6PIN MINI KK

TRACKBALL

HOT (BLACK/ORANGE)

AC NEUTRAL

6PIN COMMONING CONNECTOR

WHITE/RED

BLUE

WHITE/RED

1

3

5

2

4

6

BLACK/RED

WHITE/RED

ON/OFF SWITCH

NKK JWL21RC2A

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 60

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

BLACK/RED

GREEN/YELLOW

WHITE

FLORESENT

LAMP POWER

110VAC

LEFT

SPEAKER

GREEN

FLORESENT

LAMP

SOFT POWER (WHITE/YELLOW)

SOFT POWER (WHITE/ORANGE)

FAN

LEFT SPEAKER + (YELLOW/RED)

LEFT SPEAKER - (YELLOW/GREEN)

RIGHT SPEAKER + (WHITE/RED)

RIGHT SPEAKER - (WHITE/GREEN)

RIGHT

SPEAKER

GREEN

3

4

5

6

1

2

.093 6PIN PLUG

FROM I/O PCB

DC POWER CABLE

SOUND CABLE

NIGHTHAWK DB65 SYSTEM

WHITE RCA JACK

RED RCA JACK

BOX

PLUG AC FEMALE

USB

USB

ETHERNET

USB

USB

HDMI

15 PIN VGA

ADAPTOR

DVI

VGA CABLE

USB CABLE

CID PCB

J1

USB

GND (BLACK)

+12V (YELLOW)

1

2

BOOSTER POWER

.093 2PIN RECEPTACLE

+5V (RED)

+5V (RED)

GND (BLACK)

GND (BLACK)

GND (BLACK)

+12V (YELLOW)

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8

9

+5V (RED)

+5V (RED)

GND (BLACK)

GND (BLACK)

GND (BLACK)

+12V (YELLOW)

.093 9PIN PLUG .093 9PIN RECEPTACLE

POWER FOR COIN LAMPS

SOUND CABLE

+12V (YELLOW)

GND (BLACK)

GND (BLACK)

+5V (RED)

1

2

3

4

1

2

3

4

+12V (YELLOW)

GND (BLACK)

GND (BLACK)

+5V (RED)

4 PIN HARD DRIVE

POWER PLUG

4 PIN HARD DRIVE

POWER RECEPTACLE

1

2

.093 3PIN PLUG

1

2

BLACK

GREEN

WHITE

3

.093 3PIN PLUG

MONITOR POWER

110VAC

3

OSD PCB

LEFT RIGHT

SW-PB

FLYBY

SW-PB

SW-PB

CONTROL PANEL

SW-PB

SOFT POWER

.093 3PIN PLUG

110VAC

BLACK

GREEN

WHITE

1

2

3

GREEN

LOW/MEDIUM/TRI-MODE

MONITOR

10 PIN HEADER

VIDEO

RED

1

BLUE

2

GREEN

3 PIN HEADER

WHITE/BLACK

3

4

110VAC

BLACK

1

GREEN

2

WHITE

3

WHITE

5

6

7

8

9

10

GREEN

UNDER CONTROL PANEL

6 PIN RECEPTACLE

TRACKBALL

GND (BLACK)

TRACKBALL

+5V

LAMP

COIN MECH 1

SW SPST

+5V

LAMP

+5V LAMP

HELP

SW-PB

SPIN

SW-PB

COIN MECH 2

SW SPST

.156 10PIN KK CONNECTOR

7

8

9

10

5

6

1

2

3

4

VIDEO

.093 6PIN PLUG

RED

BLUE

GREEN

WHITE/BLACK

WHITE

1

2

3

4

5

6

1

2

3

4

5

6

PLUG AC MALE

BLACK

CHASSIS POWER

110VAC

.093 6PIN RECEPTACLE

WHITE

GREEN

SW-PB

FLY BY (VIOLET/WHITE)

RIGHT (YELLOW/WHITE)

LEFT (BROWN/WHITE)

+5V LAMP

LAMP POWER (RED/BLACK)

HELP LAMP (RED/YELLOW)

OPTIONS LAMP (RED/GREEN)

BACK SPIN (BLACK/WHITE)

HELP (BLUE/WHITE)

OPTIONS (GREEN/WHITE)

START (RED/WHITE)

GND (BLACK)

OPTIONS

+5V (RED)

GND (BLACK)

GREEN

START

SW-PB

.093 9PIN PLUG

.093 9PIN RECEPTACLE

GREEN

SERVICE

SW-PB

TEST

SW-PB

BILL (GRAY/WHITE)

COIN 1 (RED/BLUE)

COIN2 (GREEN/RED)

+5V (RED)

GND (BLACK)

VOL UP (ORANGE/WHITE)

SERVICE (ORANGE/BLACK)

VOL DOWN (ORANGE/YELLOW)

TEST (BLUE)

.093 2PIN RECEPTACLE

1

2

1

2

.093 2PIN PLUG

+5V (RED)

COIN METER (RED-GREEN)

SW-PB

VOLUME UP

SW-PB

VOLUME DOWN

SERVICE PANEL

COIN

METER

VGA CABLE USB CABLE

OPTIONS LAMP (RED/GREEN)

HELP LAMP (RED/YELLOW)

4

3

2

1

8

7

6

5

.093 6PIN RECEPTACLE

GREEN

LAMP POWER (RED/BLACK)

TO SPEAKERS

LEFT SPEAKER + (YELLOW-RED)

LEFT SPEAKER - (YELLOW-GREEN)

RIGHT SPEAKER + (WHITE/RED)

RIGHT SPEAKER - (WHITE/GREEN)

U303 PIN 1

U303 PIN 2

U303 PIN 15

U303 PIN 14

RED (RED-BLACK)

GREEN (GREEN-BLACK)

BLUE (BLUE-BLACK)

GND (WHITE-BLACK)

COMPOSITE SYNC (WHITE)

FLY BY (VIOLET-WHITE)

RIGHT (YELLOW-WHITE)

LEFT (BROWN-WHITE)

BACK SPIN (BLACK/WHITE)

HELP (BLUE/WHITE)

OPTIONS (GREEN/WHITE)

START (RED-WHITE)

J204 PIN 23

J204 PIN 24

J204 PIN 25

J204 PIN 27

U204 PIN 6

U209 PIN 4

U209 PIN 3

U209 PIN 2

U209 PIN 5

U209 PIN 9

GND (BLACK)

BILL (GRAY-WHITE)

COIN 2 (GREEN-RED)

COIN 1 (RED-BLUE)

VOLUME UP (ORANGE-WHITE)

SERVICE (ORANGE-BLACK)

VOLUME DOWN (ORANGE-YELLOW)

U210 PIN 2

U210 PIN 4

U210 PIN 3

U210 PIN 8

U210 PIN 6

TEST (BLUE)

COIN METER (RED-GREEN)

+5V (RED)

GND (BLACK)

GREEN

JAMMA

HARNESS

U210 PIN 9

U210 PIN 7

Q206 PIN 6

.093 9PIN RECEPTACLE

.093 9PIN PLUG

TRACKBALL

.093 6PIN RECEPTACLE

3

4

5

6

1

2

HOT (BLACK)

PLUG AC MALE

NEUTRAL (WHITE)

110VAC

POWER

8

7

10

9

6

5

4

3

2

1

KIT I/O PCB

6010 REV 1.2 RoHS

J208

U209 PIN 6

U209 PIN 7

6PIN MINI KK

TRACKBALL

SW DPDT

110VAC X 4

1

2

3

BLACK

GREEN

WHITE

.093 3PIN RECEPTACLE

J103

USB

1

2

3

+5V(RED)

GND(BLACK)

+12V(YELLOW)

1

2

3

4

.093 3PIN RECEPTACLE

+12V (YELLOW)

GND (BLACK)

+5V (RED)

GND (BLACK)

MODEL # 10VBAG5

VGA CABLE

LOW/MEDIUM

RESOLUTION ONLY

USB CABLE

DELTA LINE FILTER

BLACK

GREEN

WHITE

LITTLEFUSE

MODEL# 354

5 AMP

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 62

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

APPENDIX E

GNU General Public License

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The "Program", below, refers to any such program or work, and a "work based on the Program" means either the Program or any derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifications and/or translated into another language. (Hereinafter, translation is included without limitation in the term

"modification".) Each licensee is addressed as "you".

Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running the

Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program

(independent of having been made by running the Program). Whether that is true depends on what the Program does.

1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided that you also meet all of these conditions: a) You must cause the modified files to carry prominent notices stating that you changed the files and the date of any change. b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this License. c) If the modified program normally reads commands interactively when run, you must cause it, when started running for such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty

(or else, saying that you provide a warranty) and that users may redistribute the program under these conditions, and telling the user how to view a copy of this License. (Exception: if the Program itself is interactive but does not normally print such an announcement, your work based on the Program is not required to print an announcement.) These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Program, and can be reasonably considered independent and separate works in themselves, then this

License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a work based on the Program, the distribution of the whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program.

In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License.

3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of

Sections 1 and 2 above provided that you also do one of the following: a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and

2 above on a medium customarily used for software interchange; or, b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing source distribution, a complete machine-readable copy of the corresponding source code, to be distributed under the terms of

Sections 1 and 2 above on a medium customarily used for software interchange; or, c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with

Subsection b above.)

The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the executable. However, as a special exception, the source code distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable.

If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically receives a license from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not distribute the Program at all. For example, if a patent license would not

Golden Tee GOLF™ Version 11/12 Page 63

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

permit royalty-free redistribution of the Program by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system, which is implemented by public license practices. Many people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.

8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder who places the Program under this License may add an explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded.

In such case, this License incorporates the limitation as if written in the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the Program specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by the Free

Software Foundation. If the Program does not specify a version number of this License, you may choose any version ever published by the

Free Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.

NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE; THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT

PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER

PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING,

BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE

ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE

DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY

OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR

DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR

INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE

OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER

PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

How to Apply These Terms to Your New Programs If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it free software which everyone can redistribute and change under these terms.

To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively convey the exclusion of warranty; and each file should have at least the "copyright" line and a pointer to where the full notice is found.

One line to give the program's name and an idea of what it does.

Copyright (C) yyyy name of author

This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the

Free Software Foundation; either version 2 of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of

MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.

You should have received a copy of the GNU General Public License along with this program; if not, write to the Free Software Foundation,

Inc., 59 Temple Place - Suite 330, Boston, MA 02111-1307, USA.

Copyright 2004 Incredible Technologies, Inc. (IT). Certain programs, identified at IT's Website are free software subject to an associated license.

1. Because certain programs are licensed free of charge, see it's website, there is no warranty for such programs to the extent permitted by applicable law. Except when otherwise stated in writing the copyright holders and/or other parties provide those programs "as is" without warranty of any kind, either expressed or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. The entire risk as to the quality and performance of those programs is with you. Should the programs prove defective, you assume the cost of all necessary servicing, repair or correction.

2. In no event unless required by applicable law or agreed to in writing will any copyright holder, or any other party who may modify and/or redistribute those programs be liable to you for damages including any general, special, incidental or consequential damages arising out of the use or inability to use those programs (including but not limited to loss of data or data being rendered inaccurate or losses sustained by you or third parties or a failure of those programs to operate with any other programs), even if such holder or other party has been advised of the possibility of such damages.

A complete machine-readable copy of the source code of those programs and associated license is available to any third party, at the it website.

Golden Tee GOLF™ Version 11/12 Page 64

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

APPENDIX F

MENU NAVIGATION SHORTCUTS

Change Collection Settings

x Push the red System Setup button inside the coin door

General Settings menu x Select x Select x Select the menu that you want changed

Add Operator Free Cash

x Push the red System Setup button inside the coin door

Collection and Earnings x Select x Move the trackball left/right to select the desired dollar amount

GAME ICON DESCRIPTIONS

Cooling Icon

The cooling icon (pictured right) will appear in the game's attract mode to warn you that a fan is not operating at minimum recommended standards. If the fans do not operate at suggested levels it may cause your game to overheat and fail.

Call Incredible Technologies Technical Support at 847-870-7027 x121 for assistance.

Golden Tee GOLF™ Version 11/12 Page 65

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 66

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

APPENDIX G

MOUNTING TEMPLATES

Golden Tee GOLF™ Version 11/12 Page 67

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 68

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

TRACKBALL MOUNTING TEMPLATE

Golden Tee GOLF™ Version 11/12 Page 69

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 70

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

BUTTON TEMPLATES

Golden Tee GOLF™ Version 11/12 Page 71

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 72

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 73

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Golden Tee GOLF™ Version 11/12 Page 74

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Contact Information

IT Sales and Service

To purchase additional Golden Tee machines or any of IT's other fine products please visit IT's website at www.itsgames.com and click on PRODUCTS!

General Numbers

IT Sales Hotline:

800-262-0323 x383

847-870-7027 x383

Technical Support, Warranty & Repair: Parts and Customer Service:

Incredible Technologies, Inc.

800-262-0323 x380 or x381

847-870-7027 x380 or x381

847-454-9008 Fax

Incredible Technologies, Inc.

800-262-0323 x386

847-870-7027 x 386

847-454-9156 Fax

Operator Services:

Incredible Technologies, Inc.

800-262-0323 x382

847-870-7027 x382

847-454-9155 Fax

Accounting

Incredible Technologies, Inc.

800-262-0323 x382

847-870-7027 x382

847-454-9007 Fax

IT Mailing Address:

Incredible Technologies, Inc.

200 Corporate Woods Parkway

Vernon Hills, IL 60061

ITNet Registration Fax Number

847-454-9155

Sales Fax Number

847-454-9156

General Fax Number: 847-870-0120

Tech Services Fax Number: 847-454-9008

IT Vendor Information

Mars Technical Service:

Phone: 800-345-8172

Happ Controls:

Phone: 888-289-4277

GOLDEN TEE® GOLF, ITS®, INCREDIBLE TECHNOLOGIES®, IT®, ITNet®, and IT incredible TECHNOLOGIES® are the properties of Incredible Technologies, Inc. All

Rights Reserved.

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Incredible Technologies, Inc.

200 Corporate Woods Parkway

Vernon Hills, IL 60061

Phone (847) 870-7027 (800) 262-0323

www.itsgames.com

GOLDEN TEE® GOLF, ITS®, INCREDIBLE TECHNOLOGIES®, IT®, ITNet®, and IT incredible TECHNOLOGIES® are the properties of Incredible Technologies, Inc. All

Rights Reserved.

© Copyright 2012 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
