Getting Started with Symbio
Part Names
Where to put your Symbio
Because Symbio includes a security
camera, you should place it where
the camera can see what you want to
monitor. On a shelf or on the kitchen
counter are great options.
How to talk to Symbio
Volume up
button &
Lens cover
Night vision
Symbio uses Amazon Alexa Voice
Service, so just say “Alexa,” and then
ask a question. You can ask Alexa
to play music, hear the news, check
weather, and more. Refer to the
Toshiba Smart Home app to learn
how to use Alexa to control your
smart home. For more details, visit .
Light ring
Volume up/volume down buttons
Press these buttons to adjust the
Volume indicator
Dots light up as the volume is
Microphone mute button & Indicator
Press this button to turn off the
microphones. The icon will turn red
when the microphones are off. Press it
again to turn them back on.
Night vision LED
Infrared irradiation LED for night vision.
Lens cover
Can be rotated to cover and turn off
the video camera.
Light ring
Lights up in different colors to let you
know what Symbio is doing.
Recording indicator
Light up during recording.
Quick Start Guide
AC adapter
Pairing button
Press briefly to activate Bluetooth®
pairing mode.
Press and hold for about 5 seconds to
activate Wi-Fi pairing mode.
* The USB terminal is used on the
manufacturing line and for aftersales
Using the Symbio
Product Information
1. Plug in your Symbio
Safety, compliance, and other
important information regarding your
Toshiba Symbio can be found on the
website at
Plug the included AC adapter into
the Symbio and connect to an AC
outlet. When you first plug it in,
the light ring will be white. When
Symbio is ready for the next step,
the light ring will start blinking
2. Download the Toshiba Smart
Home app
Download the Toshiba Smart Home
app to your smartphone or tablet
from the App Store or Google Play.
The app is where you will control
most of the features and settings of
the Symbio.
3. Start the Toshiba Smart Home
app and set it up
The setup process will start
automatically when you open the
app. During the setup, you will be
connecting Symbio to the internet.
You will need;
• Your Wi-Fi password
• An Amazon account sign-in
* Bluetooth is a trademark owned
by Bluetooth SIG, Inc. and used by
Toshiba under license.
* App Store is a service mark of Apple
* Google Play is a trademark owned by
Google Inc.
The rating plate is on the bottom of the product.
t The AC adapter is used as disconnect device and it
should be located in such a manner that it can be easily
unplugged in case the product requires service. In order
to disconnect the product from the mains completely,
the AC adapter should be unplugged from the mains
socket outlet.
t The product shall not be exposed to dripping or splashing
and that no objects filled with liquid, such as vases, shall
be placed on the product.
t Keep the product away from direct sunlight, extreme cold,
or heat sources such as a heater. This may reduce the life
of the product.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this product near water.
Clean only with a dry cloth.
Do not block any of the ventilation openings. Install in
accordance with this instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other product (including
amplifiers) that produce heat.
9. Protect the AC adapter from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the product.
10. Only use attachments/accessories specified by the
11. Unplug this product during lightning storms or when
unused for long periods of time.
12. Refer all servicing to qualified service personnel.
Servicing is required when the product has been
damaged in any way, such as the power-supply cord or
plug is damaged, liquid has been spilled or objects have
fallen into the product, the product has been exposed
to rain or moisture, does not operate normally, or has
been dropped.
13. Do not overload wall outlets; extension cords, or
integral convenience receptacles as this can result in a
risk of fire or electric shock.
14. Never expose the product to dripping or splashing or
place items such as vases, aquariums, any other item
filled with liquid, or candles on top of the product.
15. If the product should emit smoke or an unusual odor,
immediately disconnect the AC adapter from the wall
outlet. Wait until the smoke or smell stops. Neglecting
to do so may cause fire.
16. During thunderstorms, do not touch the connecting
cables or the product.
17. Warning: To prevent spread of fire, keep candles or
other open flames away from this product at all times.
Federal Communications Commission Statement
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the
following measures:
t Reorient or relocate the receiving antenna.
t Increase the separation between the equipment and
t Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
t Consult the dealer or an experienced radio/TV technician
for help.
Notes on cleaning
Wireless Radio
For product available in the USA market, only channel
1-11 can be operated. Selection of other channels is not
possible. The device could automatically discontinue
transmission in case of absence of information to transmit,
or operational failure. Note that this is not intended to
prohibit transmission of control or signaling information
or the use of repetitive codes where required by the
technology. If this device is going to be operated in 5.155.25GHz frequency range, then it is restricted to an indoor
environment only.
Important: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
This device and its antenna(s) must not be co-located
or operating in conjunction with any other antenna or
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance
20cm between the radiator & your body.
Notes on handling
t When shipping the product, the original shipping carton
and packing materials come in handy. For maximum
protection, repack the product as it was originally packed
at the factory. Take care not to give it a shock or shake
when carrying.
t Do not use volatile liquids, such as insect spray, near
the product. Do not leave rubber or plastic products in
contact with this product for a long time. They will leave
marks on the finish.
t The product may become warm after a long period of use.
This is not a malfunction.
t When the product is not in use, to disconnect the power.
t If you do not use the product for a long period, the
product may not function properly in the future. Turn on
and use the product occasionally.
Notes on locating
Place the product on a level surface. Do not use it on a
shaky or unstable surface such as a wobbling table or
inclined stand.
When you place this product near a TV, radio, or VCR, the
playback picture may become poor and the sound may be
distorted. In this case, place the product away from the TV,
radio, or VCR.
Do not use this product in places which are extremely hot,
cold, dusty or humid.
Do not restrict the air flow of this product by placing
somewhere with poor air flow, by covering it with a cloth,
or by placing it on bedding or carpeting.
Use a soft, dry cloth for cleaning.
t For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe. Use a dry cloth to wipe it
dry. Do not use any type of solvent, such as thinners and
benzene, as they may damage the surface of the product.
t If you use a chemical saturated cloth to clean the product,
follow that product’s instructions.
Notes on moisture condensation
Moisture condensation damages the product
Please read the following carefully:
t Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day.
t Drops of water form on the outside of the glass.
Moisture condensation occurs during the following cases:
t When you bring the product directly from a cold place to
a warm place.
t When you use the product in a room where you just
turned on the heater, or a place where the cold wind from
the air conditioner directly hits the product.
Important Legal Disclaimers. Please note that
some Legal Disclaimers are product or feature
specific and may not be applicable to you.
See Legal Disclaimers for:
1. Product specifications
Product design and specification are subject to change
or modification without notice. All product specifications
mentioned depending on model and configuration and
local availability.
2. Warranty
Toshiba Visual Solutions Corporation (hereinafter
referred to as TVS) does not give any additional
warranties beyond those contained in TVS’s description
of the individual product or as provided by law.
3. Internet Capability
Some features may require an always-on broadband
internet connection, firmware update and/or additional
bandwidth. Internet services may not be available to
you in your region. Third party internet services are not
provided by TVS, may change or be discontinued at
any time and may be subject to third party restrictions.
TVS makes no representations or warranties about
these services, which may require the creation of a user
account through a computer with internet access and
one-time and/or recurring charges.
4. Third party internet services
Third party internet services are not provided by TVS,
may change or be discontinued at any time and may
be subject to internet service provider restrictions. TVS
makes no warranties, representations, or assurances
about the content, accuracy, availability or functionality
of third-party content or services. Use of third party
internet services may require the creation of a separate
account through a computer with internet access and/
or payment of one-time and/or recurring charges
and membership. Not all third party services may be
available on or compatible with this product. In order
to experience the full suggested capabilities of this
product, fully-compatible devices may be required.
5. Third party trademarks, service marks and trade
All the trademarks, service marks and trade names
belong to their respective owners. TVS disclaims any
proprietary interest in the trademarks and names of
other parties and their publication does not grant third
parties any right or license with respect to them.
Home IoT cloud service may be temporarily shut down
without prior notice due to maintenance for security
reasons. During such a time, certain functions of product
will be restricted. This includes details of events being sent
to your smartphone and video recording.
Amazon cloud service may be temporarily shut down
without prior notice due to maintenance for security
reasons or other server issues. During such a time, the
Alexa function of product will be restricted.
The Wi-Fi CERTIFIED Logo is a certification mark of the WiFi Alliance. Bluetooth is owned by the trademark holder, and
Toshiba Visual Solutions Corporation uses it under license.
Z-Wave and Z-Wave Plus are registered trademarks of
Sigma Designs and its subsidiaries in the United States and
other countries. ZigBee® is a registerd trademark ZigBee®
Alliance. amazon alexa is a registerd trademark of Amazon.
com, Inc. Pandra is a registerd trademark of Pandora
Media, Inc. Spotify is a registered trademark of Spotify
Technology S.A. App Store is a service mark of Apple Inc..
GooglePlay™ logo is registered trademark of Google Inc.
Under the copyright laws, this guide cannot be reproduced
in any form without the prior written permission of Toshiba
Visual Solutions Corporation. No patent liability is assumed,
however, with respect to the use of the information
contained herein. © TOSHIBA VISUAL SOLUTIONS
CORPORATION 2017 All rights reserved.
Need Help?
Most problems are easy to correct. Save time with one of
these simple solutions.
Consult the electronic User’s Guide
To access the electronic User’s Guide please visit www. For solutions to the most common
problems, refer to the Troubleshooting section of the User’s
Visit Toshiba’s Support Web site
Was this manual useful for you? Yes No
Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Download PDF
