Graco Lubrification Buyers` Guide

Lubrication Equipment
Buyer’s Guide
Innovative Product Solutions for the Lubrication Marketplace
The E-Z FAX Document Ordering System
Go online at www.graco.com/lubrication for:
• Literature
• Instruction Manuals
• Buyer’s Guide
• Product Knowledge Exchange
• Distributor Locator
• What’s New
• GEDI®
GEDI is the “Graco Extranet Distributor Information” area on our web site where distributors have access to up-to-the-minute
pricing, product order and shipping status and order entry. Information is accessed by an account number and a confidential
password.
To Find Your Nearest Authorized Graco Lubrication Equipment Distributor
Call: 1-800-533-9655 (toll free North America)
Fax: 1-800-533-9656
Get the documents you need 24-hours-a-day!
Simply Call 1-800-533-9655
Press option 2 to get into the E-Z FAX System.
Press 1 for the Literature Index or Press 2 if you know
the number of the service manual or literature document you need.
The documents you request will be faxed directly to you!
ABC
ABC
Literature Index | Service Manuals | Literature
2
LUBR IC A T ION E QU IP M EN T ❚ O I L P U M P S
www.graco.com
Fluid Management Systems
Matrix® 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Horizon™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Fluid Commander™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Oil Pumps and Packages
Quick Reference Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Fast-Ball® 1:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mini Fire-Ball® 225, Fire-Ball 300, Fire-Ball 425 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
Oil Pump Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-19
NXT™ High-Flo® and NXT Dura-Flo® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21
Grease Pumps and Packages
Quick Reference Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23
Mini Fire-Ball 225, 50:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Fire-Ball 300, 15:1, 50:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-27
Fire-Ball 425, 10:1, 50:1, 75:1; Bulldog 3:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29
Grease Pump Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31
NXT Check-Mate® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Transfer Pumps
Air-Operated Double-Diaphragm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Fast-Flo® (Stainless Steel). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-35
Electrical Powered Oil and Fuel Pumps
Hurricane™ Electric Dispense Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
APEX™ Electric Dispense Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37-38
GTP10 and GTP12 Fuel Transfer Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Specialty Pump Package Solutions
Lube Truck and Undercoating/Rust-Proofing Packages . . . . . . . . . . . . . . . . . . . . . . . . . 40-41
Windshield Washer and Coolant Dispense Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Hydraulic Oil and Grease Pumps
Dyna-Star®, Power-Star™ and Viscount® II Pumps. . . . . . . . . . . . . . . . . . . . . . . . . . . . 43-44
Manually Operated Oil and Grease Pumps and Packages
Oil and Grease Dispense. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Fluid Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Hose Reels
Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
LD, SD, XD, 700 and 750 Hose Reels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48-54
Reel Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56-57
Dispense Consoles
Multi-Station Consoles and Oil Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Dispense Meters and Control Valves
LD, SD, EM6, EM12 and In-Line Electronic Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59-63
Mechanical Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
SDV15, XVD20, Pro-Shot and Accu-Shot™ Control and Dispense Valves . . . . . . . . . . . 66-68
Manual Grease Guns
Grease Guns, Accessories and Fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69-71
Fluid Reclaim Packages
Oil King™, Coolant King™, Oil Ace™ and Accessories . . . . . . . . . . . . . . . . . . . . . . . . 72-73
Used Fluid Handling Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74-75
Hoses, Fittings and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75-81
Bulk Fluid Dispense
Tank Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83-87
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ OI L PUMPS
Table Of Contents
Table of Contents
3
Matrix® 3
Fluid Management Systems
Fluid Management Systems
Automated, Wireless Oil Dispense Tracking and Bulk Tank Monitoring
Dispense meters, software, and wireless devices capture dispense history and monitor
petroleum and synthetic oil products and anti-freeze mixture inventory levels.
Features and Benefits
• Wireless transmission and reception of meter and tank level information make it simple to
track your entire facility’s activities
• Customize to fit your business– three product platforms (Basic, Professional, and Premier)
to fit any size facility
• Multi-level security to protect your assets
• Precise measurement and control of fluids ensures profits and eliminates out of stock
issues for critical inventory
• ADP and Reynolds & Reynolds interfaces provide secure, reliable, data transfer between
the Matrix database and the dealership management software
Premier software
256634
Typical Applications
• Auto dealerships
• Heavy-duty fleet service
• Off-road maintenance shops
• Industrial in-plant lubrication
Transceiver
255231
Matrix Meter
256282
Typical Fluids Handled
• Petroleum and synthetic based oils
• Anti-freeze
Matrix Application Features
Feature
Basic
Professional
Premier
Maximum Number of Transceivers
1
2
8
Maximum Number of Meters
30
100
300
Maximum Number of Tank Monitors
0
12
50
Client PC Networking
0
6
300
250
500
1000
X
X
X
Number of users
Track Dispense by Work Order
Track Dispense by Technician
X
Track Dispense by Vehicle Number
X
Tank Level Email
X
X
Third Party Interface Capable
X
X
ADP® Certified Interface
X
Reynolds® Certified Interface
X
Tank Level Monitor
256285
No fluid limitations with any Matrix Platform
FOR SALE TO AUTHORIZED DISTRIBUTORS ONLY
4
LUBR IC A T ION E QU IP M EN T ❚ F L U I D M A N A G E M E N T
Pump Air Control
247436
www.graco.com
Matrix® 3
Fluid Management Systems
Software System Operating Requirements
Fluid Management Systems
Matrix software can be configured as a stand-alone PC or networked to multiple PC’s. This software
is not compatible with Apple® Computers, and is not available for the Apple® Operating system. The
PC requirements for the Matrix Server and Matrix Client or shop PC’s are noted below.
Server PC Hardware Requirements
• Windows® XP Professional or Vista® operating system
• Pentium® 4 or better processor
• Processor speed of 3.0 GHz or better
• RAM memory of 1 GB or better
• CD-RW or DVD/RW drive
• Serial port configuration for (1) RS422 and (1) USB connection
PC Clients
• Windows® XP Professional or Vista® operating system
• Pentium® 4 or better processor
• Processor speed of 2.0 GHz or better
• RAM memory of 1 GB or better
Software Instruction Manuals
Basic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313104
Pro. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313106
Premier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313108
ADP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313112
Reynolds & Reynolds. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313114
RF Communication (Meters, Transceivers, Tank Level Monitors, Pump Air Control)
Description
Performance
RF Communication
2.4 GHz Direct Sequence Spread Spectrum
RF Communication Range
Unobstructed: 300 to 500 ft (91 to 152 m); Obstructed: 250 to 300 ft (76 to 91 m)
RF Temperature Range
-40°F to 185°F (-40°C to 85°C)
Approvals
FCC, Industry Canada (IC), C-Tick, CE
Ordering Information
System Software
256634
Premier Software CD (includes 3rd party interface)
256635
Professional Software CD
256636
Basic Software CD
256637
Premier Software with ADP Interface
256638
Premier Software with Reynolds & Reynolds Interface
Transceiver and Connection Hardware
255231
Transceiver with Universal Power Adapter
255731
USB/RS422 Converter
15T999
15 ft USB Cable
15T998
3 ft USB Cable
119572
RS422 Bulk Wire (1000 ft roll)
255231
Transceiver and Connection Hardware Technical Specifications
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0 lb (454 grams)
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 – 240 V, 50/60 Hz to 12 VDC plug-in transformer
Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313008
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ FLUID M ANAGEMENT
5
Matrix® 3
Fluid Management Systems
Matrix Meter and Accessories
Fluid Management Systems
Matrix Electronic Meter with Extension, 5 gpm or Less
256282
1/2 in npt(f) swivel, rigid extension and standard automatic non-drip quick-close nozzle for oil
256482
1/2 in npt(f) swivel, flexible extension and standard automatic non-drip quick-close nozzle for oil
256483
1/2 in npt(f) swivel, gear lube extension and standard quick-close nozzle
256484
1/2 in npt(f) swivel, rigid extension and standard quick-close nozzle for anti-freeze
256485
1/2 in npt(f) swivel, flexible extension and standard quick-close nozzle for anti-freeze
Matrix Electronic Meter with Extension, 14 gpm or Less
256486
1/2 in npt(f) swivel, rigid extension, high flow, quick-close nozzle for oil
256487
1/2 in npt(f) swivel, flexible extension, high flow, quick-close nozzle for oil
256488
3/4 in npt(f) swivel, rigid extension, high flow, quick-close nozzle for oil
257120
3/4 in npt(f) swivel, flexible extension, high flow, quick-close nozzle for oil
Swivel Covers
15T366
Black swivel cover (standard color with meter)
15T367
Red swivel cover
15T368
Blue swivel cover
15T369
Green swivel cover
15T370
Yellow swivel cover
Matrix Meter
255200
Accessories
15B750
16 gallon and 55 gallon meter mounting bracket
249440
Console bracket
257539
Matrix meter for oil bar (swivel and extension removed)
256719
Oil bar console–complete cabinet without piping and meters
255370
Oil bar kit (fittings, nozzles, and piping)
257556
Retro fit kit–mount Matrix meter in 222107 console
Instruction Manual
313013
Filter Kits for Matrix Meters
255885
Filter kit includes (10) filters/strainers (15M308), (10) spacers (15M309) and (10) O-rings (155332)
Technical Specifications
Flow Range (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.1 to 14 gpm (0.4 to 53 lpm)
Maximum Working Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1500 psi (103.4 bar)
Operating Fluid Pressure Range* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 – 1500 psi (7–103 bar, 0.7–10.3)
Weight (with battery and rigid nozzle extension) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.07 lbs (2.75 kg)
Units of Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Programmable in pints, quarts, gallons, or liters
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4 in–14 npt or 1/2 in–14 npt
Outlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4 in–16 straight thread O-ring Boss
Maximum Totalizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .999,999 gallons or liters
Maximum Recorded Dispense . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999.9 Units
Maximum Pre-Set Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999.9 Units
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 AA alkaline or 4 AA lithium
Battery Life (3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Preset Models–six months, manual models–one year
Wetted Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Aluminum, sst, pbt/pc, nitrile rubber, cs
Fluid Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Petroleum and synthetic based oils and
anti-freeze mixtures (not compatible with fuel and windshield washer fluid)
Meter Pressure Loss (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 0.5%
Accuracy (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 0.5%
Repeatability (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±0.15 %
Dimension w/o Extension. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 in L x 3.75 in W x 5.75 in H, (33 cm x 9.5 cm x 14.6 cm)
Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313046
Oil Bar
Components ordered separately. For
complete unit, order oil bar 256719,
kit 255370 (one per meter) and Matrix
meters (257539) as needed
1. Tested in 10W oil at 70º F. Flow rates vary with fluid pressure, temperature, viscosity, inlet fitting and nozzle type.
2. At 2.5 gpm (9.5 lpm) @ 70º F (21º C) with 10 wt. oil and 1 gal (3.8 l) dispensed. May require re-calibration. Out-of-box accuracy ±1.25%.
3. Average shop use with alkaline batteries (included); 30-35% longer life with lithium AA
6
LUBR IC A T ION E QU IP M EN T ❚ F L U I D M A N A G E M E N T
www.graco.com
Matrix® 3
Fluid Management Systems
Tank Level Monitor
Fluid Management Systems
Choose one TLM for each bulk fluid tank. Tank readings are automatic for used or new oil and anti-freeze products.
Tank Level Monitor
256285
Tank Level Monitor
Technical Specifications
Ultrasonic Tank Depth Measurement Range . . . . . 0 – 30 ft. (0-9 m) (Not recommended for use with pressurized tanks)
Fluid Level Measurement Accuracy*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 0.5%
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.34lb (1.06 kg)
Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -22° F - 122° F (-30° C - 50° F)
RF Operating Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40° F - 185° F (-40° C - 85° F)
Storage Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40° F - 185° F (-40° C - 85° F)
Ambient temperature range** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-22º F - 122º F (-30º C - 50º C)
Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (2) 9 VDC Alkaline only
Vertical Tanks . . . . . . . . . . . . . . . . . . . . . .Maximum volume: 999,999 gallons or liters, maximum height: 30 ft (360 in.)
Cylindrical Tanks . . . . . . . . . . . . . . . . . .Maximum volume: 999,999 gallons or liters, maximum diameter: 30 ft (360 in.)
Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FCC, Industry Canada (IC), C-Tick, CE
Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312964
Note: Do NOT use the Matrix Tank Level Monitor with gasoline, diesel fuel, or other flammable liquids, and materials with an auto
ignition temperature below 419ºF (215ºC)
* The difference in air temperature between the inside and outside of the tank may affect the accuracy of fluid levels
** Display will not function below 32ºF (0ºC)
Tank Level Monitor
256285
Pump Air Control
One PAC required for each air pump. For safety and increased security, the PAC is a must have to maximize your fluid
management system. Designed to supply air to the pump only when Matrix authorizes the dispense.
Pump Air Control (PAC)
247435
23 scfm valve
247436
93 scfm valve
Technical Specifications
Operating Pressure Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-145 psi (1.7 - 10 bar)
Maximum Air Flow . . . . . . . . . . . . . . . . . . . . . . . . . 247435 - 23 SCFM (0.7m3/min), 247436 - 93 SCFM (2.6m3/min)
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120-240 VAC line voltage, 24VDC solenoid
Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10mW - 100mW
AMPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1A
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50/60 Hz
Operating Temperature Range* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32°F to 122°F (0° C to 50° C)
Enclosure Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NEMA Type 3
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247435 - 2.8 lbs (1.27 kg), 247436 - 3.4 lbs (1.5 kg)
Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312417
Pump Air Control
247436
Note: Do NOT use the Matrix Tank Level Monitor with gasoline, diesel fuel, or other flammable liquids, and materials with an auto
ignition temperature below 419º F (215º C).
* The difference in air temperature between the inside and outside of the tank may affect the accuracy of fluid levels. Display
will not function below 32º F (0º C).
Tank Accessories
CleanLine Filter Assemblies
248421
900 psi tank mount CleanLine filter assembly (includes thermal relief)
248418
900 psi wall mount CleanLine filter assembly (includes thermal relief)
248419
1800 psi tank mount CleanLine filter assembly
248417
1800 psi wall mount CleanLine filter assembly
Replacement Filters
15D702
900 psi CleanLine screw-on type filter
119278
1800 psi CleanLine filter element
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ FLUID M ANAGEMENT
7
Horizon™
Fluid Management System
Fluid Management Systems
Features and Benefits
• Allows multiple technicians to dispense simultaneously
• Easily configured and expandable for any facility
• Increases technicians productivity
• Password-protected to prevent unauthorized dispensing
• Tracks inventory levels and alerts operators to lowinventory conditions to minimize out-of-stock situations
Typical Applications
• Bulk-dispensing to multiple service bays
• Automotive dealerships
• Heavy-duty dealerships
• Fleet service facilities
Typical Fluids Handled
• Petroleum and synthetic based oils
• Anti-freeze
Technical Specifications
System Specifications
Control Modules on a System (1 Master only, plus 39 Slaves) ........... 40 maximum
Keypads on a System (1 keypad per Control Module) ....................... 40 maximum
Solenoids on a System (40 Control Modules, 6 ports each) ............. 240 maximum
Meters on a System (40 Control Modules, 6 ports each) ................. 240 maximum
Fluids on a System ...........................................................................10 maximum
Dispense Areas (reel banks) ..............................................................99 maximum
Operator Names / PIN Numbers ......................................................100 maximum
Dispense Records Stored................................................................668 maximum
Simultaneous Dispenses (same and/or different fluids): .................... 12 maximum
Jobs Waiting in Queue......................................................................12 maximum
Printer per System OR Attached Computer per System .........................1 maximum
(either must be connected to Master Control Module)
Accuracy of System ..................................................................................±0.6%
Control Module Ports
Solenoid Ports (air or fluid) per Control Module.................................................... 6
Pulse Meter Ports per Control Module ................................................................ 6
Port for Keypad per Control Module .................................................................... 1
Port for Printer or Computer per Master Control Module ...................................... 1
8
LUBR IC A T ION E QU IP M EN T ❚ F L U I D M A N A G E M E N T
Voltage Input
90-120 Volts AC, 50/60 Hz, single phase, 2 amps maximum draw
208-240 Volts AC, 50/60 Hz, single phase, 1 amp maximum draw
Operating Temperature Range................................40 - 140º F (4 - 60º C) ambient
Pre-set or Free-flow Options
Maximum Preset or Free-Flow Dispense.............................................. 999.9 units
Minimum Preset Dispense ...................................................................... 0.5 units
Units of Measure
Dispense .........................liters, quarts, gallons or pints (configurable for each fluid)
Inventory ..........................liters or gallons (dependent upon dispense units chosen)
Maximum Cable Lengths
From Keypad to Control Module .......................................................50 ft (15.3 m)
From Solenoid to Control Module .....................................................50 ft (15.3 m)
From Pulse Meter to Control Module ................................................50 ft (15.3 m)
From Printer/Computer to Master Control Module .............................50 ft (15.3 m)
From one end of the Control Module Network to the other end (daisy-chained) .......
...................................................................................................2000 ft (610 m)
Reference Data
Instruction Manual: ................................................................................. 308607
www.graco.com
Horizon™
Components and Accessories
Ordering Information
238624
Master Control Module (one per system)
238625
Slave Control Module (up to 39 per system)
Keypads: Basic, Enhanced and Administrative
113551
Basic Keypad for navigating through the Horizon’s menus
113553
Administrative Keypad is needed to set up and make changes to the system parameters
191368
Keypad Wall-Mounting Bracket
Fluid Management Systems
Control Module drives air and fluid solenoids, and counts pulses from meters. On-board memory contains a map
of available system resources, and a power supply that supports both 120 and 240 Volt AC operation. Combine
one Master Control Module with up to 39 Slave Control Modules per system.
238624
Air Solenoids open and close the air supply to the fluid pump air motor. Each solenoid can be up to 50 ft (15.3 m)
from a Control Module. Up to 6 solenoids (air or fluid) can be connected to each Control Module.
215407
For Pumps Requiring Normal Air Flow (Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1)
512926
For Pumps Requiring Higher Air Flow (Fire-Ball 425, 6:1 and 3:1)
Fluid Solenoids start and stop the fluid dispense cycles. These must be placed at each dispense point for each
fluid being dispensed. Each fluid solenoid can be up to 50 ft (15.3 m) from a control module. Up to 6 solenoids
(either air or fluid) can be connected to each control module. The low-flow model is available in a kit with a ready
light which alerts the operator when the job is ready to dispense.
215487
Low-flow: supports 3 gpm (11.4 lpm)
512927
Higher-flow: supports up to 6 gpm (22.7 lpm)
514150
Anti-Freeze Solenoid
218588
Low-flow Solenoid with Ready Light Kit
238996
Ready Light Kit (only; less the solenoid)
113551
113553
Pulse Meters measure fluid flow to dispense points and send a train of pulses back to the Control Modules which
are counted to determine how much fluid has been dispensed. If there are multiple meters for a single fluid, check
valves #111620 should be placed in series with each meter to prevent “cross talk” and oscillations. Pulse Meters
can be used for either U.S. or metric units.
238618
For Oils, Gear Lube, Automatic Transmission Fluid
215474
For Anti-Freeze
111620
Check Valve, 1/2 in
215407
Thermal Relief Kits
235998
600 psi (41 bar)
102527
Thermal Relief Valve, 900 psi (62 bar)
237893
900 psi (62 bar)
240429
1600 psi (110 bar)
System Printer prints job tickets after each dispense is complete, plus has save function for later analysis
113774
Printer
514037
Printer Paper, 1 roll
215487
Keypad or Printer Cables
191393
25 ft (7.6 m) Cable with Connectors
191394
Cable with Connectors. 50 ft (15.3 m)
Control Module Network
113559
500 ft (152.5 m) Bulk Cable
113560
1000 ft (305 m) Bulk Cable
113774
Pulse Meter Cable
113555
Length: 500 ft (152.5 m)
113556
Length: 1000 ft (305 m)
Solenoids Cable
113557
Length: 500 ft (152.5 m)
113558
Length: 1000 ft (305 m)
Computer Cable with Connectors
192873
Computer I/O 25 ft (7.6 m)
192874
Computer I/O 50 ft (15.3 m)
www.graco.com
238618
LUBRIC AT ION E QUIP M E NT ❚ FLUID M ANAGEMENT
9
Fluid Commander™
Fluid Management Systems
Fluid Management System
Features and Benefits
• Provides increased accuracy over mechanical counters
• PIN code prevents unauthorized dispensing
• Dispense totals tracked by location
• Easy to read display
• Accurate controlled dispense with parts room authorization
Typical Applications
• Parts room authorized dispensing for inventory control
• Automotive dealerships
• Heavy-duty dealerships
• Fleet service facilities
Typical Fluids Handled
• Petroleum and synthetic based oils
• Anti-freeze
Technical Specifications
Maximum Number of Fluids ........................................................................ 1 or 2
Dispense Stations/Bays ............................................................................ 6 or 12
Air Solenoids Required .................................................................... 1 (per pump)
Fluid Solenoids Required ........................................... 1 (per fluid dispense station)
Electrical Requirements .................................................... 120 V, 60 Hz, .25 amps
Weight .................................................................................... 4 lb, 5 oz. (8.0 kg)
Wiring Requirements ......................................................................... 90V; 2-wire
Distance/Gauge .....200 ft (61 m) = 18 gauge, 201 to 500 ft (61 m to 152 m) = 16
gauge, ...........................................................501 ft (152 m) or more = 14 gauge
Instruction Manual ................................................................................. 308238
Typical Fluid Commander System Layout
Easy to Use
1. Service technician enters the service bay number, type of
product, and amount to be dispensed, then activates the
dispense button.
2. A “ready” light (located on the hose reel or dispense bar of
the target service bay) signals when dispensing can begin.
3. As fluid is dispensed, the Fluid Commander tallies the amount
dispensed and shuts-off when the pre-set amount is reached.
No further dispensing takes place until new dispensing data
is entered.
A. Air shut-off valve, bleed type (110224)
B. Air filter (106148)
C. Air solenoid valve (215407)
D. Air regulator and gauge (109075)
E. Pump
F. 40-mesh fluid strainer (223179)
G. Pulse meter (236763; 236764)
H. Thermal relief kit*
I. Fluid drain hose
J. Fluid shut-off valve (108458)
K. Fluid solenoid valve** (215487)
L. Hose reel
M. Ready-to-dispense indicator light** (238996)
N. Dispense valve
O. 1/2 npt check valve (111620)†
*Kit required to protect system from rupture due to thermal expansion of fluid lines. See
instruction manual 308403.
**#218588 includes #238996 and #215487.
Note: For tank packages, pressure reliefs from instruction manual 308403 must be
installed on outlet with pressure going either back to vent into the tank or to a container
installed under the exit or relief valve.
† Required to ensure meter accuracy.
10
LUBR IC A T ION E QU IP M EN T ❚ F L U I D M A N A G E M E N T
www.graco.com
Fluid Commander™
Fluid Management System
Ordering Information
232076
U.S. Measure Fluid Commander System for 2 products and 6 stations, includes: One 2-product/6station Fluid Commander (235532), oil meter (236763), fluid solenoid valve (215487), air solenoid
valve (215407), Check valve (111620)
241905
U.S. Measure Fluid Commander System for 1 product and 12 stations: Includes: One 1-product/12station Fluid Commander (235531), Oil Meter (236763), Fluid Solenoid valve (215487), Air Solenoid
valve (215407), check valve (111620)
240448
Metric Measure Fluid Commander System for 2 products and 6 stations: Includes: One 2-product/6station Fluid Commander (232077), oil meter (236764), Fluid Solenoid valve (215487), Air Solenoid
valve (215407), check valve (111620)
Fluid Management Systems
Fluid Commander Systems
Accessories
111620
Check valve
236763
Pulse Meter (quarts)
236764
Pulse Meter (liters)
215474
Pulse Meter (quarts)
215745
Pulse Meter (liters)
244342
Meter Pulse Converter, used when upgrading old-style modular fluid commander to electronic allows
use of 215474/215475 with the EFC. Instruction manual 309276
Air Solenoid Valves
215407
Air Solenoid Valve, 150 psi (10 bar) (1/2 npsm(f) conduit ports for wiring; 1/4 npt(f) air ports, adapted
to 3/8(f) IN, 3/8(m) OUT) operates on 24V DC and 110 VAC. Automatically shuts-off air inlet to pump
when pre-set dispensed amount is reached. Materials of construction: brass, SST, Buna.
105474
Air Solenoid Valve (bare) 150 psi (10 bar), same as #215407 but without wire connectors or adapters.
1/2 npsm(f) conduit ports for wiring; 1/4 npt(f) air ports.150 psi (10.3 bar) max. working pressure.
215407
Fluid Solenoid Valves
215487
Fluid Solenoid Valve, 1/2 npt(f) 3000 psi (207 bar) operates on 24V DC. Automatically shuts-off fluid
when pre-set dispensed amount is reached. Includes tube, valve, pin connector, wire plug connector
and adapter.
514150
Fluid Solenoid Valve for anti-freeze, 150 psi max. (10 bar), 1/2 npt(f), same as features as #215487
110025
Bare Fluid Solenoid Valve, 1/2 npt(f) 3000 psi, same features as #215487 above, but without wiring
connectors or adapters.
215487
Ready-Light Kits
218588
Ready-Light Kit, signals operator when dispensing can begin. Includes “ready to dispense” Indicator
Light #239019, Strainer #240417, Fluid Solenoid Valve #215487 and hardware. Manual 307696.
238996
Ready-Light with Junction Box (no solenoid or strainer)
239019
Ready-to-Dispense Indicator Light only
113859
Lamp for Indicator Only
Installation Components
223179
Fluid Filter Kit (for bare electronic meter)
186472
Wall-Mounting Bracket
108458
Fluid Shut-Off Valve
237893
Thermal Relief Kit for 900 psi (62 bar), relieves excess heat-induced pressure from dispense system.
Male and female ends allow for simple installation. Instruction manual 308403.
215481
Connecting Cables For connecting solenoids and consoles. 90-volt, 2-wire, 18-gauge.
215481
100 ft (30.5 m) pre-connected at both ends
215480
10 ft (3.1 m) pre-connected at both ends
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ FLUID M ANAGEMENT
11
Oil Pumps Quick Reference
Air Powered Oil Pumps and Packages
Technical Specifications and Selection Chart
Manuals:
Fast-Ball 307906
Fire-Ball 309869
Cycles
per
Gallon
Fluid Flow
gal/min
@ 80 cpm
Maximum
Fluid
Pressure
Air Motor
Effective
Diameter
Air Operating
Range
Approx. Air Use
and Flow @ 100
psi and 80 cpm
Wetted
Materials
Air Inlet
Port
Size
Fluid
Inlet
Port Size
Fluid
Outlet
Port Size
180 psi
(12.5 bar)
1.4 in
(35.6 mm)
40-180 psi
(2.7-12.5 bar)
5 scfm
CS,
Polyurethane
1/4 in
npt(f)
1-1/2 in
npt(f)
3/4 in
npt(f)
Fast-Ball 1:1*
10
(45.5 liters)
5
(19 liters)
Line Length‡: Up to 100 ft (30.5 m)
Annual Usage: Up to 5,000 gal (19,000 l)
Dispense Points: 1 (not recommended with hose reel)
Typical Applications: Continuous Duty, Maintenance Facility Dispensing Motor Oil,
Automatic Transmission Fluid, Hydraulic Fluid
Mini Fire-Ball 225, 3:1
43.5
(11.4 liters)
1.84
(7.0 liters)
540 psi
(37 bar)
2.25 in
(57.2 mm)
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Up to 6,500 gal (24,602 l)
40-180 psi
(2.8-12 bar)
8.5 scfm @ 2.1 gpm, Steel, Buna-N,
Polyurethane,
(0.241 m3/min
Aluminum,
@ 7.9 lpm)
Rulon®
3/8 in
npt(f)
1-1/2 in
npt(f)
1/2 in
npt(f)
Dispense Points: 1 to 2
Typical Applications: Continuous Duty, Maintenance Facility Dispensing Motor Oil,
Gear Oil, Automatic Transmission Fluid, Hydraulic Fluid
Fire-Ball 300, 5:1
28.4
(8.6 liters)
2.8
(9.3 liters)
900 psi
(62 bar)
3 in
(76.2 mm)
Line Length‡: Up to 500 ft (152.5 m)
Annual Usage: Up to 30,000 gal (114,000 l)
40-180 psi
(2.8-12 bar)
27 scfm @ 3 gpm
(0.765 m3/min
@ 11.5 lpm)
Steel,
Polyurethane, 3/8 npt(f) 1-1/2 npt(f) 1/2 npt(f)
Aluminum,
Buna-N
Dispense Points: 1 to 3
Typical Applications: Continuous Duty, Maintenance Facility Dispensing Motor Oil,
Gear Oil, Automatic Transmission Fluid, Hydraulic Fluid
Fire-Ball 425, 3:1
6
(1.6 liters)
13.4
(50.6 liters)
540 psi
(37 bar)
4.25 in
(107.9 mm)
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Over 30,000 gal (114,000 l)
40-180 psi
(2.8-12 bar)
Steel,
58 scfm @ 13.4 gpm
Polyurethane,
(1.64 m3/min
Aluminum,
@ 50.6 lpm)
Nitrile
1/2 in
npt(f)
1-1/2 in
npt(f)
3/4 in
npt(f)
Dispense Points: 3 to 4
Typical Applications: High Flow, Low Pressure Maintenance Facility Dispensing Motor Oil,
Gear Oil, Automatic Transmission Fluid, Hydraulic Fluid
Fire-Ball 425, 6:1
12
(3.2 liters)
6.6
(25.3 liters)
1100 psi
(76 bar)
4.25 in
(107.9 mm)
Line Length‡: Up to 500 ft (152.5 m)
Annual Usage: Over 30,000 gal (114,000 l)
40-180 psi
2.8-12 bar)
Steel,
49.5 scfm @ 6.8 gpm
Polyurethane,
(.334 m3/min
Aluminum,
@ 25.7 lpm)
Nitrile
1/2 in
npt(f)
1-1/2 in
npt(f)
3/4 in
npt(f)
Dispense Points: 3 to 4
Typical Applications: High Flow, Medium Pressure, Maintenance Facility Dispensing Motor Oil,
Gear Oil, Automatic Transmission Fluid, Hydraulic Fluid
Fire-Ball 425, 10:1
19.6
(5.2 liters)
4.1
(15.4 liters)
1800 psi
(124 bar)
4.25 in
(107.9 mm)
Line Length‡: Up to 750 ft (228.6 m)
Annual Usage: Over 30,000 gal (114,000 l)
40-180 psi
2.8-12 bar)
Steel,
32 scfm @ 4.1 gpm
Polyurethane,
(.555 m3/min
Aluminum,
@ 15.4 lpm)
Nitrile
1/2 in
npt(f)
1-1/2 in
npt(f)
3/4 in
npt(f)
Dispense Points: 3 to 4
Typical Applications: Long Distance, Maintenance Facility Dispensing Motor Oil,
Gear Oil, Automatic Transmission Fluid, Hydraulic Fluid
‡ Consult your local authorized Graco representative for line or pipe sizing
12
LUBR IC A T ION E QU IP M EN T ❚ O I L P U M P S
www.graco.com
Oil Pumps Quick Reference
See NXT Ordering Information
for Instruction Manuals
Output
Per Cycle
Output at
60 CPM*
gpm (lpm)
Maximum Fluid
Pressure psi (bar)
Motor Size
Maximum Air
Input Pressure
psi (bar)
1000 cc
17.4 (65.9)
620 (42.7)
NXT 3400
100 (6.9)
Dura-Flo, 6:1
Line Length‡: Up to 500 ft (152.5 m)
Annual Usage: Over 30,000 gal (114,000 l)
Dispense Points: 3 to 4 (simultaneous)
Typical Applications: High Pressure, High Volume For Motor Oil, Gear Oil,
Automatic Transmission Fluid and Hydraulic Fluid
Dura-Flo, 10:1
1000 cc
Line Length‡: Up to 750 ft (228.6 m)
Annual Usage: Over 30,000 gal (114,000 l)
17.4 (65.9)
1180 (81.3)
NXT 6500
100 (6.9)
Dispense Points: 3 to 4 (simultaneous)
Typical Applications: High Pressure, High Volume For Motor Oil, Gear Oil,
Automatic Transmission Fluid and Hydraulic Fluid
Dura-Flo, 12:1 Carbon Steel or Dura-Flo, 12:1 Stainless Steel
580 cc
Line Length‡: Up to Up to 1000 ft (304.8 m)
Annual Usage: Over 30,000 gal (114,000 l)
9.2 (34.8)
1190 (82.1)
NXT 3400
100 (6.9)
Dispense Points: 2 to 3 (simultaneous)
Typical Applications: High Pressure, High Volume For Motor Oil, Gear Oil,
Automatic Transmission Fluid and Hydraulic Fluid
Air Powered Oil Pumps and Packages
Technical Specifications and Selection Chart
Dura-Flo, 23:1
580 cc
Line Length‡: Up to Up to 1000 ft (304.8 m)
Annual Usage: Over 30,000 gal (114,000 l)
9.2 (34.8)
1725 (118.9)
NXT 6500
75 (5.2)
Dispense Points: 2 to 3
Typical Applications: High Pressure, High Volume For Motor Oil, Gear Oil,
Automatic Transmission Fluid and Hydraulic Fluid
High-Flo 3.5:1
2000 cc
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Over 30,000 gal (114,000 l)
31.5 (119.2)
350 (24.1)
NXT 3400
100 (6.9)
Dispense Points: 4 to 5
Typical Applications: High Volume Transfer For Motor Oil, Gear Oil,
Automatic Transmission Fluid and Hydraulic Fluid
High-Flo 4.5:1
1500 cc
Line Length‡: Up to 450 ft (137.1 m)
Annual Usage: Over 30,000 gal (114,000 l)
23.2 (87.8)
450 (31)
NXT 3400
100 (6.9)
Dispense Points: 4 to 5
Typical Applications: High Volume Transfer For Motor Oil, Gear Oil,
Automatic Transmission Fluid and Hydraulic Fluid
High-Flo 6:1
2000 cc
Line Length‡: Up to 500 ft (152.5 m)
Annual Usage: Over 30,000 gal (114,000 l)
31.5 (119.2)
500 (34)
NXT 6500
75 (5.2 )
Dispense Points: 4 to 5
Typical Applications: High Volume Transfer For Motor Oil, Gear Oil,
Automatic Transmission Fluid and Hydraulic Fluid
*Graco recommends 20 cpm or less for supply applications ‡ Consult your local authorized Graco representative for line or pipe sizing
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ OI L PUMPS
13
Fast-Ball® 1:1
Air-Operated Piston Pumps and Packages for Oil
Air Powered Oil Pumps and Packages
Features and Benefits
• In-line design with fewer parts for less pump wear
• Differential air motor ensures smooth pumping
• Double-acting pump provides reliable fluid flow
Typical Applications
• Lubricant transfer
• Automotive dealerships
• Heavy duty dealerships
• Fast lube centers
• Fleet service facilities
• Service shops
• In-plant
• Lube trucks
• Mining
Typical Fluids Handled
• Petroleum and synthetic based oils
222051
Pump Performance
25
cycles/min
50
scfm
(m3/min)
100 10
75
8
(0.23)
40
(2.7)
6
(0.17)
20
(1.4)
4
(0.12)
0
gpm
(lpm)
Inlet Air Pressures:
=100 psi
(6.9 bar)
(0.3)
80
(5.5)
222602
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
120
(8.3)
=70 psi
(4.8 bar)
=40 psi
(2.8 bar)
2
1
2
3
(3.8)
(7.6)
(11)
TEST FLUID: No. 10 Weight Oil
4 (0.08)
(15)
239702
222103
222104
Ordering Information
Package
Non-Metered
Dispense
U.S./Metric
Metered Dispense
Container Size
Package No.
55 gal (200 l)
222602
239702
Pump
Dispense Kit
Hose Length
218115
239703
218316
14
Bung-Mounted
Universal
275 gal (1040 l)
Universal
222104
222051
222104
222051
—
—
—
—
—
—
109125
—
—
—
—
6 ft (1.8 m)
—
—
—
—
Bung Adapter
Instruction Manual
222103
222103
Regulator Assembly
Hose
Bung-Mounted
222308
307637
LUBR IC A T ION E QU IP M EN T ❚ O I L P U M P S
—
307906
www.graco.com
Mini Fire-Ball® 225, Fire-Ball 300 and Fire-Ball 425
Air-Powered Piston Pumps and Packages for Oil
• Non-corrosive air motor design (metal parts made of SST, aluminum and
chrome) for long life
• No metal-to-metal contact means longer pump life and ensures
pump will withstand harsh environments
• Double-acting pump provides reliable fluid flow
• Few moving parts translates into low maintenance and low cost
of ownership
• Open exhaust port provides continuous operation without icing
Typical Applications
Mini Fire-Ball 225 3:1 Performance
psi
(bar)
43.5
FLUID OUTLET PRESSURE
500
(31.4)
(0.3)
32
(0.23)
300
(10.4)
24
(0.23)
200
(5.2)
16
(0.17)
100
(5.2)
8
(0.12)
300
(21)
8
(0.23)
150
(10.4)
6
(0.17)
75
(5.2)
4
(0.12)
Inlet Air Pressures:
=100 psi
(6.9 bar)
=70 psi
(4.8 bar)
=40 psi
(2.8 bar)
4 (0.08)
(15)
28
cycles/min
55
105 80
60
(1.7)
400
(27)
40
(1.1)
200
(13)
20
(0.6)
0
gpm
(lpm)
www.graco.com
250
(27)
30
(0.9)
150
(13)
15
(0.4)
0
2
4
6
8
(7.6) (15.4) (22.7) (30.3)
TEST FLUID: No. 10 Weight Oil
Inlet Air Pressures:
=100 psi
(6.9 bar)
=70 psi
(4.8 bar)
=40 psi
(2.8 bar)
0
2
6
10
(7.5)
(23)
(38)
TEST FLUID: No. 10 Weight Oil
14
(53)
= 70 psi
(4.8 bar)
= 40 psi
(2.8 bar)
205626
40
cycles/min
60
80
scfm
(m3/min)
100 80
(2.2)
1400
(96)
60
(1.7)
1000
(70)
40
(1.1)
600
(42)
20
(0.6)
200
(14)
gpm 1
2
3
4
(lpm) (3.8) (7.6) (11.4) (15)
TEST FLUID: No. 10 Weight Oil
AIR CONSUMPTION
600
(41)
60
scfm
(m3/min)
84 60
(1.7)
45
(1.2)
psi
(bar)
1800 20
(125)
Inlet Air Pressures:
= 100 psi
(6.9 bar)
(2.2)
12
cycles/min
36
Fire-Ball 425 10:1 Performance
scfm
(m3/min)
78
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
800
(55)
4
(15)
350
(41)
50
gpm
(lpm)
2
1
2
3
(3.8)
(7.6)
(11)
TEST FLUID: No. 10 Weight Oil
Fire-Ball 425 6:1 Performance
238108
psi
(bar)
450
(55)
FLUID OUTLET PRESSURE
0
gpm
(lpm)
= 40 psi
(2.8 bar)
Fire-Ball 425 3:1 Performance
FLUID OUTLET PRESSURE
80
scfm
(m3/min)
107 10
(0.3)
= 70 psi
(4.8 bar)
AIR CONSUMPTION
237526
26
cycles/min
53
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
450
(31.4)
Inlet Air Pressures:
= 100 psi
(6.9 bar)
0
1
2
3
(3.8)
(7.6) (11.4)
TEST FLUID: No. 10 Weight Oil
• Petroleum and synthetic based oils
Fire-Ball 300 5:1 Performance
scfm
(m3/min)
174 40
400
(21)
0
gpm
(lpm)
Typical Fluids Handled
cycles/min
87
130.5
AIR CONSUMPTION
• Medium to low volume and pressure lubricant transfer
• Automotive dealerships
• Heavy duty dealerships
• Fast lube centers
• Fleet service facilities
• Service shops
• In-plant
• Lube trucks
• Mining
Air Powered Oil Pumps and Packages
Features and Benefits
Inlet Air Pressures:
= 100 psi
(6.9 bar)
= 70 psi
(4.8 bar)
= 40 psi
(2.8 bar)
0
5
(19)
LUBRIC AT ION E QUIP M E NT ❚ OI L PUMPS
15
Mini Fire-Ball® 225, Fire-Ball 300 and Fire-Ball 425
Air-Powered Piston Pumps and Packages for Oil
Air Powered Oil Pumps and Packages
Universal Supply
Fire-Ball 425 Ordering Information
Packages
Cover-Mounted
Container Size
Bung-mounted
Bung-Mounted
Universal Supply
55 gal (200 l)
Wall-Mounted
Universal
Fire-Ball 425, 3:1 Package
—
—
—
244846( 3)
Fire-Ball 425, 3:1 Pump
—
—
—
237526
Fire-Ball 425, 6:1 Package
—
—
—
244628 (3)
Fire-Ball 425, 6:1 Pump
—
Fire-Ball 425, 10:1 Package
225782
Fire-Ball 425, 10:1 Pump
—
(1) (2)
225786
222065
Hose/Fitting Kit
—
(1) (2)
225853
222095
238108
(1) (2)
244847
205626
205626
222066
222068
Fluid Hose
6 ft x 3/4 in (1.8 m x 19.05 mm)
1.5 ft x 3/4 in (0.5 m x 19.05 mm)
Air Hose
6 ft x 1/2 in (1.8 m x 12.7 mm)
1.5 ft x 1/2 in (0.5 m x 12.7 mm)
Cover
200326
—
—
—
—
—
—
217072
Filter Regulator
Air Shutoff Valve
—
—
—
110225
Fluid Shutoff Valve
—
—
—
108537
Wall Mount Bracket
—
—
—
238245
306520
309351
Instruction Manual
307883
(1)
Use 1/2 in (12.7 mm) air regulator #104266 and air pressure gauge #100960 as required; must be ordered separately—see mounting
accessories section
(2)
Order low-level cut off #203688 separately for metered dispense systems—see mounting accessories section
(3)
Includes pump plus: Filter Regulator (217072), Hose and Fitting Kit (222068), Air Shutoff Valve (110225), Fluid Shutoff (108537), Wall
Mount Bracket, (238245)
Cover-mounted
Mini Fire-Ball 225 and Fire-Ball 300 Ordering Information
Packages
Container Size
Mini Fire-Ball 225,
3:1 Package
Portable
Cover-Mounted
16 gal (60 l)
246903 ‡
246904 ‡
Mini Fire-Ball, 225
3:1 Pump
Fire-Ball 300,
5:1 package
225728 *‡
225094 †‡
203872
Portable
16
246907 *‡
248230 *‡
246775
225642 †,‡
225640 †, ‡
225931 †, ‡
225852 †, ‡
203857
204254
222087
203876
222062
1.5 ft x 1/2 in
(0.5 m x 9.5 mm)
6 ft x 3/8 in
(1.8 m x 9.5 mm)
224512
204574
1.5 ft x 3/8 in
(0.5 m x 9.5 mm)
–
–
–
200326
—
—
—
—
—
—
203622
—
—
—
—
—
225, 3:1 Manual
300, 5:1 Manual
Universal
222063
—
Cover
Bung Adapter for
300, 5:1
246907 *‡
275 gal (1040 l)
6 ft x 1/2 in
(1.8 m x 12.7 mm)
Air Regulator
Caster Base
246906 ‡
237075
Fluid Hose
Air Hose
55 gal (200 l)
Universal
248097 †
Fire-Ball 300
Pump
Dispense/Hose
Fitting Kit
Bung-Mounted
222308
—
309868
307884
307883
306520
*248097 includes suction tube (15C502) and bung adapter (222308)
* Use 3/8 in (9.5 mm) installation kit (224512) as required
† Use 3/8 in (9.5 mm) air regulator 109075 as required; must be ordered separately
‡ Order low-level cut-off 203688 (1 1/2 inch NPT) separately for metered dispense systems
LUBR IC A T ION E QU IP M EN T ❚ O I L P U M P S
www.graco.com
Oil Pump Accessories
Air-Operated Piston Pumps and Packages for Oil
222062
18 in (0.5 m) for connecting wall-mounted Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 pumps
to piping. Includes: air hose (204560) with swivel elbow (155494), fluid hose (220598) with swivel
elbow (155470). Instruction manual 306520.
222063
6 ft (1.8 m) For use with drum-mounted Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 pumps.
Includes: air hose (203320) with swivel elbow (155494), fluid hose (220591) with swivel elbow
(155470). Instruction manual 307883.
Dispense Kits for Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 Pumps
237075
6 ft (1.8 m) For use with portable lubricators powered by the Fire-Ball 300, 5:1. Includes: fluid hose
(220591) and EM5 gear lube valve (238463). Instruction manual: 307884.
200326
Hose and Fittings Kits for Fire-Ball 425, 3:1, 6:1 and 10:1
222068
18 in (0.5 m) For connecting wall-mounted Fire-Ball 425, 10:1 pumps to piping. Includes: air hose
(218093) with swivel elbow (155470), fluid hose (109108) with swivel elbow (160327). Instruction
manual: 306520.
238246
24 in (0.6 m) For use with Fire-Ball 425, 3:1 and 6:1 wall-mounted pumps to piping. Includes: air
hose (218093) with swivel elbow (155470), fluid hose (238247) with swivel elbow (160327).
222066
6 ft (1.8 m) For use with drum-mounted Fire-Ball 425, 10:1 pumps. Includes: air hose (205418) with
swivel elbow (155470), fluid hose (109105) with swivel elbow (160327). Instruction manual: 307883.
204574
Suction Kits
236054
6 ft (1.8 m) Suction Kit for 55-gal. (200 l) drums. Includes: 55-gal. (200 l) drum tube, bung adapter
and 6 ft (1.8 m) of 3/4 in fluid hose with 3/4 in ID x 1-1/2 in bushing to adapt to any universal Graco
oil pump. Allows use of Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 or Fire-Ball 425, 10:1
universal pumps with barrels. Order wall brackets separately. Use with low-level cut-off (203688)
when metering fluids. Instruction manual: 308335.
Drum Covers
200326
Cover for open-head 55 gal (200 l) drums. Use with Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 or
Fire-Ball 425, 10:1 pump. Use adapter #160754 for cover-mounting bung-style pumps.
204574
Cover for open-head 16 gal (60 l) or 70 lb (32 kg) drums. Mounts Fast-Ball 1:1, Mini-Fire-Ball or
Fire-Ball pumps.
222058
Cover for 5 gal (20 l) pails. Mounts Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and 15:1
pumps. Bung adapter (222308) and bung adapter plate (160754) sold separately.
160754
Bung-adapter plate for 55 gal (200 l) or 16 gal (60 l) covers. Mounts to 55 gallon (400 lb; 200 l),
16 gal (120 lb; 60 l) drum or 5 gal (20 1) pail covers and converts mounting to standard 2 npt bung
opening. Allows use of bung-mounted pumps with drum covers.
160754
Air Powered Oil Pumps and Packages
Hose and Fittings Kits for Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 Pumps
203987
Wall-Mounting Brackets
203987
For universal Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and Fire-Ball 425, 10:1 pumps.
Clamps onto universal pump tube.
238245
For use with Fire-Ball 425, 3:1, 6:1 and 10:1 pumps. Mounts directly to pump flange.
236778
For use with Fire-Ball 425, 3:1, Dyna-Star 1/4:1 and Power-Star 1:1 pumps. Clamps to pump tube
and provides mounting to wall surface by flange.
Clamps
203156
203156
Open-drum pump clamp. Attaches to side of open-head drum and mounts on any size pump except
Fire-Ball 425, 3:1.
210880
Open-drum pump clamp for Fire-Ball 300, 5:1 and Fire-Ball 425, 10:1 pumps. Clamps onto pump
tube and attaches to open-drum lip.
Tools for Working on Fire-Ball Air Motors
207579
Padded Pliers
171818
Poppet Gauge
168085
Insert Tool
www.graco.com
210880
LUBRIC AT ION E QUIP M E NT ❚ OI L PUMPS
17
Oil Pump Accessories
Air-Operated Piston Pumps and Packages
Air Powered Oil Pumps and Packages
Carts
203650
Cart for 5, 10 and 16 gal (20, 40, and 60 l) drums. Drums fit into recess on formed base. Rim clamps
secure drum to cart. Use with pail clamp (159952) when using cart with 5 gal (20 l) pails.
222243
Heavy-Duty Cart with Pneumatic Wheels for 120 lb (55 kg) drums. Used for moving lubrication
equipment over rough terrain. Requires: Hold down kit (222061).
111470
55 gal (200 l) Drum Truck. Heavy-duty drum truck secures 55 gal (200 l) drum on roll-around base.
111470
Portable Bases
205054
Band Dolly for 5 gal (20 l) pails (11-1/2 in ID)
204144
Band Dolly for 10 and 16 gal (40 and 60 l) drums (14 in ID)
203622
Caster Base for 5, 10 and 16 gal (20, 40 and 60 l) drums
Drum Elevator
241663
Air-powered elevator to speed-up 55 gal (200 l) drum changes. Maximum raised height: 39.5 in (100.3
cm). Includes: cover support (207562), drum elevator (204385), and air control kit (207561).
Suction Tubes For Pumps
238592
For 16 gal (60 l) cover-mounted Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and Fire-Ball
425, 10:1. Use bung adapter #222308 on all current production models. Includes (191126) 14-1/2 in
(0.36 m) extension (110127) foot spacer
238593
For 55-gal (200 l) cover-mounts, includes (191128) 21-3/4 in (0.55 m) extension (110127) foot spacer
238595
For 55 gal (200 l) bung-mounted Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and Fire-Ball
425, 10:1. Use bung adapter #222308 on all current production models Includes (191130) 26 in (0.66
m) extension (110127) foot spacer
238596
For 275-gal (1100 l) bung-mounts, includes (191131) 36 in (0.91 m) extension (110127) foot spacer
15C502
Universal Down Tube 1-1/2 in tube marked for standard container lengths from 20-41 in (0.51-1.04 m)
203650
204144
Bung Adapters
222308
For Fast-Ball 1:1; Mini Fire-Ball 225, 3:1; Fire-Ball 300, 5:1; and Fire-Ball 425, 10:1 Pumps. Allows
direct mounting of all universal length and extended Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300,
5:1 and Fire-Ball 425, 10:1 pumps into standard 2 npt drum bung.
238125
For Mini Fire-Ball 225, 3:1; Fire-Ball 300, 5:1; and the Fire-Ball 425, 10:1. Includes double tap bushing
(191075), 1 ft 3/8 in hose (238370), and 90º 3/8 in adapter (155494) for mounting universal pumps to
tanks (see 308403 for details).
214583
For Fast-Flo 1:1 Pumps, allows direct mounting of full-length pump into standard 2 npt drum bung.
Comes with bushing sleeve (172405).
187754
Acetal Bung Adapter includes (100220) thumbscrew (for Fire-Ball 300, 15:1 SST undercoating pump)
176684
Bung Adapter for Suction Kit #203992 includes (100220) thumbscrew
203622
Sealed Bung Adapters (prevents rain water and other fluids from entering drum when pump is outdoors.)
204076
Sealed bung adapter for full-length Fire-Ball with 2-1/8 in (53.9 mm) bung and Mini Fire-Ball 225, 3:1
(2.140 inch diameter)
224579
Sealed bung adapter for universal length Fire-Ball pumps, 2.159 inch diameter (will not fit Mini Fire-Ball
225, 3:1 or old style pumps with bottom foot valve).
217359
Sealed bung adapter for Fast-Flo pumps; can be used with suction kit #236054
241663
Low-Level Cut-Offs (Prevents air from entering pump by closing intake when fluid supply to pump is exhausted.
Can be used with suction hose kit or standard suction tube without changing tube length.)
203688
18
Low-level cut-offs for Fast-Ball and Fire-Ball pumps that have a universal design with suction tube
extension supplying metered outlets; replaces stand-off suction tube; 1.5 npt (f) inlet. 3 in (76 mm) h.
204159
Low-level cut-off for models #203857, #203872 and #204254 built prior to 1996. 2 in (m) inlet
248296
Fire-Ball 300, 5:1 and Fire-Ball 425, 6:1 thermal relief valve rated to 900 psi (62 bar) (same as 237893
minus bung adapter and swivel. Includes 6 foot hose).
237601
Fire-Ball 425, 3:1 thermal relief valve rated to 600 psi (41 bar)
240429
Fire-Ball 425, 10:1 thermal relief valves rated to 1600 psi (110 bar)
248324
Fire-Ball 425, 10:1 thermal relief valves rated to 1600 psi (110 bar) (same as 240429 minus bung
adapter and swivel. Includes 6 foot hose)
238899
Diaphragm pump thermal relief valve rated to 150 psi (10.4 bar)
112353
Diaphragm pump thermal relief valve for fuel dispense; rated to 50 psi (3.4 bar), valve only
LUBR IC A T ION E QU IP M EN T ❚ O I L P U M P S
3"
203688
www.graco.com
Oil Pump Accessories
Air-Operated Piston Pumps and Packages
Thermal Relief Valve Kits (includes valve, hose and fittings)
Mini Fire-Ball 225, 3:1 thermal relief valve rated to 600 psi (41 bar)
237893
Fire-Ball 300, 5:1 and Fire-Ball 425, 6:1 thermal relief valve rated to 900 psi (62 bar)
248296
Fire-Ball 300, 5:1 and Fire-Ball 425, 6:1 thermal relief valve rated to 900 psi (62 bar) (same as 237893
minus bung adapter and swivel. Includes 6 foot hose).
237601
Fire-Ball 425, 3:1 thermal relief valve rated to 600 psi (41 bar)
240429
Fire-Ball 425, 10:1 thermal relief valves rated to 1600 psi (110 bar)
248324
Fire-Ball 425, 10:1 thermal relief valves rated to 1600 psi (110 bar) (same as 240429 minus bung
adapter and swivel. Includes 6 foot hose)
238899
Diaphragm pump thermal relief valve rated to 150 psi (10.4 bar)
112353
Diaphragm pump thermal relief valve for fuel dispense; rated to 50 psi (3.4 bar), valve only
108458
Bleed-Type Air Shut-Off Valves (rated to 250 psi [17.4 bar]) Female ends
110223
1/4 in (6.4 mm)
110224
3/8 in (9.5 mm)
110225
1/2 in (12.7 mm)
110226
3/4 in (19.1 mm)
Fluid Shut-Off Valves (rated to 2000 psi [138 bar]) For isolating oil dispense lines.
108458
1/2 in (12.7 mm)
240418
3/8 in (9.5 mm)
108537
3/4 in (19.1 mm)
240417
110314
1 in (25.4 mm)
240417
Fluid T-Strainers 60 Mesh Strainer, 750 psi (51 bar) working pressure. Prevents foreign material from
entering dispense lines. Not for use with grease lines. 1/2 in npt(f) swivel x 1/2 in npt(m) ports.
Mesh Strainer Replacement for #240417
3 replacement Elements
25 replacement Elements
Mesh
238433
238434
40 mesh
238431
238432
60 mesh (standard)
238429
n/a
100 mesh
Air Powered Oil Pumps and Packages
235998
Y-Strainers 400 psi (28 bar) max. working pressure filters material before it enters the pump. 20 mesh screen.
Y-Strainer
Replacement Screens
Inlet/Outlet
101078
180199
3/4 npt(f) both ends
110877
110906
1/2 npt(f) both ends
110878
110907
1 npt(f) both ends
101078
Mounting Accessories
Pump
Fast-Ball 1:1
Bung Adapter
Connection Hose Kit
Mini Fire-Ball 225 3:1
Fire-Ball 300 5:1
Fire-Ball 425 3:1
Fire-Ball 425 6:1
Fire-Ball 425 10:1
N/A‡
N/A‡
222308
222308
222118
(18 in [45.7 cm])
222119
(72 in [182.8 cm])
Wall Mounting Bracket
Thermal Relief Kit
222062 (18 in [45.7 cm])
222063 (72 in [182.8 cm])
203987
-
222068
(18 in [45.7 cm])
222066
(72 in [182.8 cm])
238246 (24 in [60.9 cm])
238245
235998
237893
203987
237601
240429
Air Regulator and Gauge
110147
109075
104266/100960
Air Filter
110146
106148
106149
Air Lubricator
110148
214847
214848
FRL*
110149
110150
217072
Airline Shutoff Valve
110223
110224
110225
Fluid Shutoff Valve
108537
108458
Fluid Outlet Filter
Low-Level Cutoff
Suction Hose Kit
108537
240417
101078
112087
203688
236054
N/A**
N/A**
*Filter, Regulator, Lubricator and Gauge
**Recommend 1-1/2 in, 6 ft hose assembly as suction kit
‡Must be wall-mounted or flange-mounted
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ OI L PUMPS
19
NXT™ High-Flo®
Air-Operated Piston Pumps for Oil
• Move large amounts of oil fast–dispenses up to 31 gallons of oil per minute
• Tested to outperform and outlast all other pumps on the market with its long-life packing design
• Models available with intuitive, easy-to-use DataTrak™ controls–gives you pump diagnostics, material
usage tracking and pump runaway protection
• Reduces icing and noise–new NXT air motor is up to 50% quieter than previous models
Typical Applications
• In-plant to supply long-pipe runs or large volume header systems with multiple dispense locations
• Fill remote reservoirs or feed an automated lubrication system
• Transfer and dispense large amounts of lubricant to supply a production process
• Mines/construction for rapid refill of lube trucks and to service off-road equipment
Package Number with DataTrak
247888
247889
247892
247893
Package Number without DataTrak
24D602
24D603
24D606
24D607
3.5:1
4.5:1
6:1
6:1
Ratio
Mounting
PUMP SPECIFICATIONS
Air Powered Oil Pumps and Packages
Features and Benefits
Wall (255143)
Wall (255143)
Wall (255143)
Stand (218742)
Pump with DataTrak and thermal relief kit
24D590
24D591
24D594
24D594
Pump w/o DataTrak and thermal relief kit
24D596
24D597
24D600
24D600
2000cc
1500 cc
2000 cc
2000 cc
23.2 gpm (87.8 lpm)
31.5 gpm (119.2 lpm)
Output per Cycle
Output at 60 CPM*
31.5 gpm (119.2 lpm)
Motor Size
Maximum Fluid Pressure
MANUALS
Maximum Air Input Pressure
NXT 3400
350 psi (24.1 bar)
450 psi (31.0 bar)
311211
Pump Lower Manual
311690
HOSES
INLET/
OUTLET
Motor Manual
311831
311832
311238
1 1/2 in npt (f)
2 in npt (f)
1 in npt (f)
2 in npt (f)
3/4 in x 4 ft Air Hose
1 in x 6 ft Fluid Hose
75 psi (5.2 bar)
312862
Pump Manual
Pump Outlet Size
500 psi (35.2 bar)
100 psi (6.9 bar)
System Manual
Pump Inlet Size
31.5 gpm (119.2 lpm)
NXT 6500
110048
115042
247969
*Graco recommends 20 CPM or less for supply applications
Performance Charts
A = 100 psi (7.0 bar) air pressure
B = 70 psi (4.9 bar) air pressure
C = 40 psi (2.8 bar) air pressure
20
LUBR IC A T ION E QU IP M EN T ❚ O I L P U M P S
Test Fluid is No. 10 Weight Oil for all pumps
A = 100 psi (7.0 bar) air pressure
B = 70 psi (4.9 bar) air pressure
C = 40 psi (2.8 bar) air pressure
A = 70 psi (4.9 bar) air pressure
B = 55 psi (3.7 bar) air pressure
C = 40 psi (2.8 bar) air pressure
www.graco.com
NXT™ Dura-Flo™
Air-Operated Piston Pumps for Oil
Air Powered Oil Pumps and Packages
Performance Charts
A = 7 bar (100 psi) air pressure or 105 bar (1500 psi) hydraulic oil pressure
B = 4.9 bar (70 psi) air pressure or 75 bar (1050 psi) hydraulic oil pressure
C = 2.8 bar (40 psi) air pressure or 42 bar (600 psi) hydraulic oil pressure
Test Fluid is No. 10 Weight Oil for all pumps
Package Number with DataTrak
247890
247894
247891
Package Number without DataTrak
24D604
24D608
24D605
–
6:1
10:1
12:1
23:1
Pump with DataTrak and thermal relief kit
24D592
24D595
24D593
–
Pump w/o DataTrak and thermal relief kit
24D598
24D601
24D599
–
Ratio
PUMP SPECIFICATIONS
Mounting
Wall (255143)
Output per Cycle
Output at 60 CPM*
Motor Size
Max. Fluid Pressure
1000cc
580cc
17.4 gpm (65.9 lpm)
9.2 gpm (34.8 lpm)
NXT 3400
NXT 6500
NXT 3400
NXT 6500
620 psi (42.7, 4.3 bar)
1180 psi (81.3 bar)
1190 psi (82.1 bar)
1725 psi (118.9 bar)
INLET/
OUTLET
MANUALS
Max. Air Input Pressure
HOSES
247895
100 psi (6.9 bar)
System Manual
75 psi (5.2 bar)
312862
Pump Manual
311833
311826
Pump Lower Manual
311717
311825
Motor Manual
311238
Pump Inlet Size
2 in npt(f)
Pump Outlet Size
1 1/2 in npt(m)
3/4 in x 4 ft Air Hose
110048
1 in x 6 ft Fluid Hose
115042
*Graco recommends 20 CPM or less for supply applications
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ OI L PUMPS
21
Grease Pumps Quick Reference
Technical Specifications and Selection Chart
Air Powered Grease Pumps and Packages
Manual Number
Continuous-Duty
Flow Rate
Maximum
Fluid
Pressure
Air Motor
Effective
Diameter
Operating
Range
Approx. Air Use
Wetted Materials
Air Inlet
Port
Size
Material
Inlet
Material
Outlet
3/8 in
npt(f)
Slotted
1/4 in
npt(f)
3/8 in
npt(f)
Slotted
1/4 in
npt(f)
Mini Fire-Ball 225, 50:1
0.32 lb/min
(.15 kg/min.)
8400 psi
(578 bar)
2.25 in
(57.2 mm)
40-140 psi
(3-10 bar)
Line Length‡: Up to 100 ft (30.5 m)
Annual Usage: Up to 5,000 lb. (2,268 kg)
309966
Steel, Urethane,
7.3 scfm @ 0.41 lb/min.) Aluminum,
Buna-N,
(.18 kg/min)
Brass, Ethylene,
@ 100 psi @ 80 cpm
Delrin®
Dispense Points: 1
Typical Applications: Small Maintenance Facility
Fire-Ball 300, 50:1
1.19 lb/min.
(.54 kg/min.)
8400 psi
(580 bar)
3 in
(76.2 cm)
30-140 psi
(3.0-9.7 bar)
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Up to 10,000 gal (4.535 kg)
308883
22.8 cfm @100 psi
(7 bar)
CS, Delrin®, Buna-N,
Polyurethane
Dispense Points: 1 to 2
Typical Applications: High Pressure Grease to 8400 psi, (579 bar) Outlet Pressure
Fire-Ball 425, 50:1
3.35 lb/min
(1.5 kg/min.)
7500 psi
(517 bar)
40-150 psi
4.25 in
(10.8 mm) (2.8-10.4 bar)
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: 20,000 lb or more (9,072 kg)
306674/306982
19 cfm @70 psi
(4.8 bar)
CS, Leather
1/2 in
npt(f)
Slotted
3/8 in
npt(f)
Dispense Points: 4 or more
Typical Applications: High Pressure Grease to 7500 psi, 517 bar)
Mini Fire-Ball 425, 75:1
1.95 lb/min
(.88 kg/min.)
7500 psi
(517 bar)
4.25 in
(10.8 cm)
40-100 psi
(2.8-7 bar)
Line Length‡: Up to 500 ft (152.5 m)
Annual Usage: 15,000 lb or more (6,804 kg)
26 cfm @100 psi
(7 bar)
CS, Leather
1/2 in
npt(f)
Slotted
3/8 in
npt(f)
Dispense Points: 4 or more
Typical Applications: High Pressure Grease to 7500 psi, 517 bar)
308777/306982
Fire-Ball 300, 15:1
0.7 gpm
2700 psi
(186 bar)
3 in
(7.6 cm)
40-180 psi
(2.8-12.5 bar)
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Up to 10,000 gal (4.535 kg)
17 cfm@ 100 psi
(7 bar)
CS, AL, Leather,
PTFE, Rubber
3/8 in
npt(f)
1 in npt(f)
Straight
Inlet
1/4 in
npt(f)
Dispense Points: 1 to 2
Medium Pressure Grease to 2700 psi, (186 bar) Outlet Pressure
306531
Fire-Ball 425, 10:1
3.5 gpm
1800 psi
(124 bar)
4.25 in
(10.8 cm)
40-180 psi
(2.8-12.5 bar)
Line Length‡: Up to 500 ft (152.4 m)
Annual Usage: 20,000 lb or more (9,072 kg)
13 cfm @100 psi
(7 bar)
Steel, Bass,
Aluminum, Leather,
Buna-N
1/2 in
npt(f)
Slotted
1 in
npt(f)
Dispense Points: 4 or more
Typical Applications: High Pressure Grease to 1800 psi, (124 bar)
309407
* Not recommended with hose reel
22
‡ Consult your local authorized Graco representative for line or pipe sizing
LUB R IC A T ION E QU IP M E N T ❚ G R EA S E P U M P S
www.graco.com
Grease Pumps Quick Reference
See NXT Ordering Information
for Instruction Manuals
Output
Per Cycle
Output at
60 CPM*
Maximum
Fluid
Pressure
Motor
Size
Maximum Air Input
Pressure psi (bar)
500cc
57.0 lb/min
(26.0 kg/min)
1400
(96.5 bar)
NXT 3400
100 (6.9)
Check-Mate 14:1**
Line Length‡: Up to 100 ft (30.5 m)
Annual Usage: Up to 20,000 lb. (9,072 kg)
Dispense Points: 1
Typical Applications: Small Maintenance Facility
Check-Mate 26:1
500cc
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Up to 20,000 lb. (9,072 kg)
57.0 lb/min
2600
(26.0 kg/min) (179.3 bar)
NXT 6500
100 (6.9)
Dispense Points: 1 to 2 (simultaneous)
Typical Applications: Smaller Continuous Duty, Maintenance Facility
Check-Mate 29:1
250cc
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Up to 20,000 lb. (9,072 kg)
28.0 lb/min
2900
(13.0 kg/min) (200.0 bar)
NXT 3400
100 (6.9)
Dispense Points: 4 or more
Typical Applications: Medium Continuous Duty, Maintenance Facility
Check-Mate 55:1
250cc
28.0 lb/min
5500
(13.0 kg/min) (379.2 bar)
NXT 6500
75 (5.2)
Air Powered Grease Pumps and Packages
Technical Specifications and Selection Chart
Floor-mounted
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Up to 20,000 lb. (9,072 kg)
Dispense Points: 1 to 2 (simultaneous)
Typical Applications: Smaller Continuous Duty, Maintenance Facility
Check-Mate 63:1**
100cc
Line Length‡: Up to 250 ft (76.2 m)
Annual Usage: Up to 20,000 lb. (9,072 kg)
11.4 lb/min
(5.2 kg/min)
4500
(310.3 bar)
NXT 3400
72 (5.0)
Dispense Points: 1 to 2 (simultaneous)
Typical Applications: Smaller Continuous Duty, Maintenance Facility
Check-Mate 68:1**
200cc
Line Length‡: Up to 500 ft (152.5 m)
Annual Usage: Up to 20,000 lb. (9,072 kg)
22.8 lb/min
5300
(10.4 kg/min) (356.5 bar)
NXT 6500
78 (5.4)
Dispense Points: 1 to 2 (simultaneous)
Typical Application: Smaller Continuous Duty, Maintenance Facility
* Graco recommends 20 CPM or less for supply applications.
**NXT Check-Mate pump is available in floor stand or RAM Package.
See NXT package section of this book for more information.
RAM-mount
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ GREASE PUMPS
23
Mini Fire-Ball® 225, 50:1
Air-Operated Piston Pumps and Packages for Grease
Pump Performance
• Non-corrosive air motor design for long life
• Double-acting pump ensures smooth fluid flow
• Robust grease inlet cage withstands the most abusive handling
FLUID OUTLET PRESSURE
psi
(bar)
8000
(552)
Typical Applications
• Medium to high pressure, low to medium volume grease dispense
• Automotive dealerships
• Heavy duty dealerships
• Fast lube and service centers
• Fleet service facilities
• Lube trucks
• Mining
• In-plant
30
cycles/min
60
scfm
(m3/min)
14
(0.4)
90
6000
(414)
10.5
(0.3)
4000
(276)
7
(0.2)
2000
(138)
4
(0.1)
0
lb/min
(kg/min)
Inlet Air Pressures:
=140 psi
(9.6 bar)
AIR CONSUMPTION
Air Powered Grease Pumps and Packages
Features and Benefits
=100 psi
(6.9 bar)
=80 psi
(5.5 bar)
=40 psi
(2.8 bar)
0
0.17
(0.08)
0.32 0.49
(0.15) (0.22)
TEST FLUID: No. 10 Weight Oil
Typical Fluids Handled
• Grease up to NGLI #2
Mini Fire-Ball 225, 50:1 (246915)
Mini Fire-Ball 225, 50:1 (246914)
Mini Fire-Ball 225, 50:1 (246916)
Grease Pumps and Packages
Portable Pail
Dispenser
Container Size
Package No.
246910 +
Follower Plate
Cart-Mounted Pail
Dispenser
Stationary
Supply Package
35 lb (16 kg) pails
or 70 lb (32 kg) bulk
35 lb (16 kg) pail
Pump No.
Container
Stationary Pail
Dispenser
246911 +
220653
Dispense Kit
Fluid Hose
Air Hose
222059
Cover
222059
Cart
–
Portable Package
w/ 2-Wheel Cart
120 lb (55 kg)
246913 +
246914 +
246909
–
Portable Package
w/ Caster Base
246915 +
400 lb (180 kg)
246916 +
246780
204134
*
–
*
Stationary
Supply
Package
246917 +
246781
–
–
220654
–
223845
236058
222072
236058
222072
12 ft x 1/4 in
(3.7 m x 6.4 mm)
6 ft x 1/4 in
(1.8 m x 6.4 mm)
12 ft x 1/4 in
(3.7 m x 6.4 mm)
6 ft x 1/4 in
(1.8 m x 6.4 mm)
204574
204574
6 ft x 3/8 in
(1.8 m x 9.5 mm)
–
–
204574
–
203650
Manual
–
6 ft x 3/8 in
(1.8 m x 9.5 mm)
200326
203622
203650
–
309967
+ Order 3/8 in (9.5 mm) air regulator (109075) separately
* Order follower plate #220653 separately for 35 lb (16 kg) pails or #220654 for 70 lb (32 kg) bulk
24
LUB R IC A T ION E QU IP M E N T ❚ G R EA S E P U M P S
www.graco.com
Fire-Ball® 300, 15:1
Air-Operated Piston Pumps and Packages for Grease
22
cycles/min
45
90 scfm
3
67
(m /min)
900
(62)
12
(0.34)
600
(41)
9
(0.26)
300
(21)
6
(0.17)
0
gpm
(lpm)
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
1200
(83)
Inlet Air Pressures:
=100 psi
(6.9 bar)
=70 psi
(4.8 bar)
=40 psi
(2.8 bar)
3
0.25
.50
.75
(0.95) (1.7) (2.9)
TEST FLUID: No. 10 Weight Oil
1 (0.08)
(3.8)
Packages for 35-400 lb (16-180 kg) Containers
Stationary Pail Dispenser
Stationary Drum Dispenser
Cover-Mounted Drum Dispenser
35 lb (16 kg)
120 lb (55 kg)
400 lb (180 kg)
Package No.
222078
220170
220171
Pump No.
206405
206699
206700
Dispense Kit
222080
222081
222081
Fluid Hose
15 ft x 3/8 in (4.6 m x 9.5 mm)
25 ft x 3/8 in (7.6 m x 9.5 mm)
25 ft x 3/8 in (7.6 m x 9.5 mm)
Drum Cover
222058
204574
200326
Container Size lb (kg)
Instruction Manual
307882
Air Powered Grease Pumps and Packages
Pump Performance
222078
220170
220171
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ GREASE PUMPS
25
Fire-Ball® 300, 50:1
Air-Operated Piston Pumps and Packages for Grease
FLUID OUTLET PRESSURE
psi
(bar)
8000
(552)
30
cycles/min
60
90
scfm
(m3/min)
40
(1.13)
6000
(414)
30
(0.85)
4000
(276)
20
(0.57)
2000
(138)
10
(0.28)
Inlet Air Pressures:
=150 psi
(10.3 bar)
AIR CONSUMPTION
Air Powered Grease Pumps and Packages
Pump Performance
=100 psi
(6.9 bar)
=70 psi
(4.8 bar)
=40 psi
(2.8 bar)
0
0
lb/min
1.0
2.0
3.0
4.0
(kg/min)
(.5)
(.9)
(1.4) (1.8)
TEST FLUID: NLG1 #1 Grease at 70 F (21 C)
Mini Fire-Ball 225, 50:1 (246911) or
Fire-Ball
300, 50:1 (225827) Package
Mini Fire-Ball 225, 50:1 (246910) or
Fire-Ball 300, 50:1 (222069) Package
35-70 lb (16.32 kg) Pumps and Packages
Portable Pail
Dispenser
Stationary Pail
Dispenser
Cart-Mounted
Pail Dispenser
Cart-Mounted
Pail Topper
35 lb (16 kg)
35 lb or 70 lb
(16 kg or 32 kg)
35 lb or 70 lb
(16 kg or 32 kg)
35 lb (16 kg)
Package No.
222069 *
225827 *
225773 *
226012 *
Metered Package**
245694
-
245695
-
Container Size
Pump No.
239877
Dispense Kit
222070
Fluid Hose
12 ft x 1/4 in (3.7 m x 6.4 mm)
Air Hose
-
-
-
-
Follower Plate
220653
†
†
-
Cover
222059
Holster
-
204574
203976
Container
-
204134
Cart
-
-
Elevator
-
-
-
203664
Inductor Plate
-
-
-
204351
Instruction Manual
204134
203650
307878
* Use 3/8 in (9.5 mm) air regulator #109075; must be ordered separately
** Metered grease package includes 233807 Accu-Shot instead of 242056 Pro-Shot
† Order follower plate #220653 for 35 lb (16 kg) containers, and follower plate #220654 for 70 lb (32 kg) containers; must be ordered separately
Mini Fire-Ball 225, 50:1 (246913) or
Fire-Ball 300, 50:1 (225773) Package
26
Mini Fire-Ball 225, 50:1 (246917)
LUB R IC A T ION E QU IP M E N T ❚ G R EA S E P U M P S
Fire-Ball 300, 50:1 (226012)
www.graco.com
Fire-Ball® 300, 50:1
Air-Operated Piston Pumps and Packages for Grease
Portable with
Caster Base
Portable with
Two-Wheel Cart
Portable with
Heavy-Duty Cart
225006 *
225026 *
222245 *
Container Size lb (kg)
Package No.
Stationary Supply
Stationary Supply
Topper-Inductor
225014 *
222073 *
222072
-
120 (55)
Metered Package
245696 **
Pump No.
239887
Dispense Kits
Fluid Hose
Air Hose
222070
222383
12 ft x 1/4 in
(3.7 m x 6.4 mm)
25 ft x 1/4 in
(7.6 m x 6.4 mm)
6 ft x 1/4 in
(1.8 m x 6.4 mm)
-
6 ft x 3/8 in
(1.8 m x 9.5 mm)
-
-
Follower Plate
220654
-
Cover
204574
222060
204574
-
Holster
203976
-
-
-
Caster Base
203622
-
-
-
Cart
-
203650
222243
-
-
Elevator
-
-
-
-
204121
Pump Support
-
-
-
-
222074†
Hold Down Kit
-
-
222061
-
-
Instruction Manual
306523
Packages for 400 lb (180 kg) Containers
Stationary
Container Size lb (kg)
Package No.
Topper-Inductor
400 (180)
225016 *
Pump No.
226013 *
239888
Hose & Fitting Kit
222072
Fluid Hose
204467
6 ft (1.8 m) x 1/4 in (6.4 mm)
Air Hose
6 ft (1.8 m) x 3/8 in (9.5 mm)
Follower Plate
223845
Cover
-
200326
-
Carriage
-
204461
Elevator
-
204385
Inductor Plate
-
204353
Base
-
205339
307880
306556
Instruction Manual
*
**
†
Air Powered Grease Pumps and Packages
Packages For 120 lb (55 kg) Containers
225016
222073
Use 3/8 in (9.5 mm) air regulator #109075; must be ordered separately
Metered grease package includes 233807 Accu-Shot instead of 242056 Pro-Shot
Pump support assembly includes dust cover, base, inductor plate and 6 ft (1.8 m) fluid & air hoses
226013
225014
225006
www.graco.com
222245
225026
LUBRIC AT ION E QUIP M E NT ❚ GREASE PUMPS
27
Fire-Ball® 425, 10:1 and 50:1; Bulldog® 3:1
Air-Operated Piston Pumps and Packages for Grease
Fire-Ball 425, 10:1 Performance
FLUID OUTLET PRESSURE
13
cycles/min
27
41
53 scfm
(m3/min)
6000
(408)
40
(1.1)
4500
(306)
30
(.85)
3000
(204)
20
(0.56)
10:1 Pump Packages
Inlet Air Pressures:
=100 psi
(6.9 bar)
AIR CONSUMPTION
Air Powered Grease Pumps and Packages
psi
(bar)
7500
(510)
1
2
3
(0.45) (.9)
(1.4)
TEST FLUID: No. 10 Weight Oil
965129
=70 psi
(4.8 bar)
10:1 Pumps and Accessories
10
0
lb/min
(kg/min)
Fire-Ball 425, 10:1 pump for closed 400 lb (180 kg) head drums
complete with bung adapter. For open head drum, remove bung
adapter and mount to #200326, 400 lb (180 kg) drum cover. Ideal
for transferring grease from 400 lb (180 kg) drum or side pocket of
tote tank. Can be modified for stubby horizontal mount on tote tanks.
Contact Graco technical assistance for information.
4 (0.28)
(1.8)
965124
Stubby mount Fire-Ball 425, 10:1 pump only
200326
Drum cover
223701
Follower plate
Fire-Ball 425, 50:1 Performance
13
cycles/min
27
41
53 scfm
3
(m /min)
6000
(408)
40
(1.1)
4500
(306)
30
(.85)
3000
(204)
20
(0.56)
0
lb/min
(kg/min)
Inlet Air Pressures:
=150 psi
(6.9 bar)
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
7500
(510)
=100 psi
(4.8 bar)
10
1
2
3
(0.45) (.9)
(1.4)
TEST FLUID: No. 10 Weight Oil
4 (0.28)
(1.8)
225781
223108
226018
Packages for 120-400 lb (56-180 kg) Containers
Stationary Supply
Stationary Supply
Stationary Supply
Topper-Inductor
Ram
Bulldog 3:1 (Sinker)
Container Size lb (kg)
120 (55)
400 (180)
400 (180)
400 (180)
400 (180)
Package No.
223108*
225781*
226018*
244905
244848
Pump No.
205394
205395
205395
205395
205148
Air Hose Kit
222076
222076
205102
222076
208610 / 244658
Description
Fluid Hose
6 ft x 3/8 in (1.8 m x 9.5 mm)
Air Hose
6 ft x 1/2 in (1.8 m x 12.7 mm)
Cover
204574
200326
–
–
–
Follower Plate
223344
223846
–
–
–
Carriage
–
–
204461
–
–
Elevator
–
–
204385
–
–
Inductor Plate
–
–
205699
–
222404
Base
–
–
205339
–
–
Ram
–
–
–
207279
–
Air Regulator
–
–
–
244844
207651
Adapter Plate
–
–
–
162225
–
Adapter Kit
Manual
–
–
–
224266
–
307880
307880
306556
309345
309345
* Use 1/2 in (12.7 mm) air regulator #104266 and gauge #100960; must be ordered separately
For Fire-Ball 425, 50:1 Lube Truck Packages, see the Specialty Pump Section
See Tank and Tote Section for more Inductor and Ram packages
28
LUB R IC A T ION E QU IP M E N T ❚ G R EA S E P U M P S
www.graco.com
Fire-Ball® 425, 75:1
Air-Operated Piston Pumps and Packages for Grease
cycles/min
27
13
41
53 scfm
3
(m /min)
6000
(408)
40
(1.1)
4500
(306)
30
(.85)
3000
(204)
20
(0.56)
Inlet Air Pressures:
=100 psi
(6.9 bar)
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
7500
(510)
=70 psi
(4.8 bar)
10
0
lb/min
(kg/min)
1
2
3
(0.45) (.9)
(1.4)
TEST FLUID: No. 10 Weight Oil
4 (0.28)
(1.8)
Packages for 35-400 lb (16-180 kg) Containers
Description
Cover-Mount
Cover-Mount
Inductor
Ram
Pail Length
Bung or Cover
Container Size lb (kg)
120 (55)
400 (180)
400 (180)
400 (180)
35/70 lb (16/32 kg)
400 (180)
Package
244635 *
244636 *
244637 *
244906
Bare pump no.
239729
239730
239730
239730
239731
239730
Hose & Fitting Kit
222076
222076
205102
222076
Drum Cover
204574
200326
-
-
204574
Follower Plate
223344
223846
-
-
**
Carriage
-
-
204461
-
Elevator
-
-
204385
-
Base
-
-
205339
-
Inductor
-
-
205699
-
Ram
-
-
-
207279
Air Regulator
-
-
-
244844
Adapter Plate
-
-
-
162225
Adapter Kit
-
-
-
224266
307880
307880
306556
309345
Manual
-
Air Powered Grease Pumps and Packages
Pump Performance
-
* Use 1/2 in (12.7 mm) air regulator #104266 and gauge #100960; must be ordered separately ** 35 lb: 220653/ 70 lb: 223344 • For Lube Truck Packages, see the Package Solution Section
RAM Assemblies
Description
System Package
Fire-Ball 300, 50:1
Fire-Ball 425, 75:1
Fire-Ball 425, 50:1
Fire-Ball 425, 10:1
*
244906
244905
*
Bare Pump
239888
239730
205395
965129
Ram
207279
207279
207279
207279
Pump Mount Kit
247336
247337
247337
247337
Adapter Kit
224267
224266
224266
not needed
Air Regulator and Gauge
203716
244844
244844
207468
Ram Plate Seal Kit
247335
247335
247335
247335
Air Hose 3/4 in x 6 ft
-
-
-
-
Fluid Hose 1 in x 6 ft
-
-
-
*Order individual components
Drum Systems
Ram Mount
• Force feed high volume pumps
• Extreme viscous grease
• Reduce waste
• Clean and convenient
method of drum change
www.graco.com
Inductor Mount
• Reduce waste
• Clean and convenient
method of drum change
Cover Mount with Follower Plate
• Economical
LUBRIC AT ION E QUIP M E NT ❚ GREASE PUMPS
29
Accessories
Air-Operated Piston Pumps and Packages for Grease
Dispense, Hose and Fitting Kits
Air Powered Grease Pumps and Packages
Rated To 5000 psi (345 bar) for Portable Fire-Ball 300, 50:1 or Mini Fire-Ball 225, 50:1 Pumps
222080
For Fire-Ball 300, 15:1 Includes: 15 ft (4.6 m) of 3/8 in (9.5 mm) fluid hose #109165, grease dispense
valve #242056, Z-Swivel #202577, 3/8 in (9.5 mm) closed nipple #156849, quick-disconnect nipple
#169971, quick-disconnect air coupler #110198 and 3/8 in (9.5 mm) air regulator #110234.
222081
For Fire-Ball 300, 15:1 Includes: 25 ft (7.6 m) of 3/8 in (9.5 mm) fluid hose #109167, grease dispense
valve #242056, Z-Swivel #202577, 3/8 in (9.5 mm) closed nipple #156849, quick-disconnect nipple
#169971, quick-disconnect air coupler #110198 and 3/8 in (9.5 mm) air regulator #110234.
236058
For Mini Fire-Ball 225, 50:1 Includes: 12 ft (3.6 m) fluid hose #109151, air coupler #208536, air
nipple #169971, grease dispense valve #242056, gun holder #188843 and Z-Swivel #202577.
222070
For Fire-Ball 300, 50:1 Includes: 12 ft (3.6 m) fluid hose #109151, air coupler #208536, air nipple
#169971, grease dispense valve #242056 and Z-Swivel #202577. Instruction manual 307878.
222383
For Portable Units Powered by the Mini Fire-Ball 225, 50:1 or Fire-Ball 300, 50:1 Pumps Includes:
dispense kit includes: grease dispense valve #242056, 25 ft (7.6 m) fluid hose #109054, air coupler
#208536, air nipple #169971 and Z-Swivel #202577. Instruction manual 307878.
220653
Hose and Fitting Kits
Rated to 5000 psi (345 bar) for Stationary Drum-Mounted Fire-Ball 300, 50:1 Pumps
222072
Hose and Fittings Kit Includes: 6 ft (1.8 m) air hose #203320 with swivel elbow #155494 and 6 ft
(1.8 m) fluid hose #109150 with swivel elbow #155541. Instruction manual 307880.
204574
Rated to 4000 psi (276 bar) for Stationary Drum-Mounted Fire-Ball 425, 50:1 Pumps
222076
Hose and Fittings Kit Includes: 6 ft (1.8 m) air hose #205418 with swivel elbow #155470 and 6 ft
(1.8 m) fluid hose #109163 with swivel elbow #155494. Instruction manual 307880.
Bung Adapters
239965
For Fire-Ball 425, 50:1 and 75:1 Pumps, 1.65 in ID
239966
For Fire-Ball 300, 15:1 and 50:1 Pumps
Lincoln-to-Graco Adapter Kit
241246
For Fire-Ball 300, 50:1 when replacing a Series 20 Lincoln
200326
Flange Mounting Accessories for Fire-Ball Pumps
948393
Flange adapter (male) Fire-Ball 300
948392
Flange adapter (male) Fire-Ball 425
512874
Coupler (female)
Follower Plates
220653
For 35 lb (16 kg) pails with Mini Fire-Ball 225, 50:1, Fire-Ball 300, 15:1 and 50:1 pumps
220654
223344
For 70 and 120 lb (32/55 kg) drum, Mini Fire-Ball 225, 50:1, Fire-Ball 300, 15:1 and 50:1 pumps
For 120 lb (55 kg) drums with Fire-Ball 425, 50:1 and 75:1 pumps
223700
For 120 lb (55 kg) drums with Dyna-Star 5:1 pumps
223845
For 400 lb (180 kg) drum, Mini Fire-Ball 225, 50:1, Fire-Ball 300, 15:1 and 50:1 pumps, 1.19 in ID
204130
Follower plate same as #223845, but without flexible wiper
223846
For 400 lb (180 kg) drums with Fire-Ball 425, 50:1 and 75:1 pumps, 1-13/32 in ID
205337
Follower plate same as #223846, but without flexible wiper
223701
For 400 lb (180 kg) drums with Dyna-Star 5:1 and Fire-Ball 425, 10:1 pumps, 2.1 in ID
222059
160754
Drum Covers
30
200326
Cover for open-head 400 lb (180 kg) drum Use with any Mini Fire-Ball 225, Fire-Ball grease pump or
Dyna-Star 5:1 pump. Use with adapter #160754 for cover-mounted pumps.
204574
Cover for open-head 120 lb (55 kg) or 70 lb (32 kg) drums Mounts Mini Fire-Ball 225, Fire-Ball grease
pumps or Dyna-Star 5:1 pump. Use with adapter #160754 for cover-mounted pumps.
222059
Cover for 35 lb (16 kg) pails Mounts Mini Fire-Ball 225, 50:1 and Fire-Ball 300, 50:1 pumps using
friction-style clutch lock. Allows use of 70 lb (32 kg) length pump with 35 lb (16 kg) pail.
160754
Bung-adapter plate Mounts to standard 400 lb (180 kg) or 120 lb (55 kg) drum cover and converts
mounting to standard 2 npt bung opening. Allows use of bung-mounted pumps with drum covers.
LUB R IC A T ION E QU IP M E N T ❚ G R EA S E P U M P S
www.graco.com
Accessories
Air-Operated Piston Pumps and Packages for Grease
205054
Band Dolly for 35 lb (16 kg) pails
204144
Band Dolly Base for 70 lb (32 kg) or 120 lb (55 kg) drums
203622
Caster Base for 35 lb (16 kg), 70 lb (32 kg) or 120 lb (55 kg) drums
Carts
203650
For 35 lb (16 kg), 70 lb (32 kg) and 120 lb (55 kg) drums. Drums fit onto recess on formed base. Rim
clamps secure drum onto cart. Use with pail clamp #159952 when using cart with 35 lb (16 kg) pails.
222243
For 120 lb (55 kg) drums with pneumatic wheels for rough terrain.
111470
Heavy-duty drum truck for 400 lb (180 kg) drums secures drum onto roll-around base.
204144
Drum Elevators
241663
Air-Powered Elevator to speed drum changes. Maximum raised height: 39.5 in (100.33 cm). Includes:
Cover Support (207562), Drum Elevator, (204385), Air Control Kit (207561)
Air Shut-Off Valves, Bleed-type, rated to 250 psi (17.4 bar)
110223
1/4 in (6.4 mm)
110224
3/8 in (9.5 mm)
110225
1/2 in (12.7 mm)
110226
3/4 in (19.1 mm)
203622
High-Pressure Grease Shut-Off Valves
202869
5000 psi (345 bar) high-pressure needle valve, 1/2 npt(f) ported valve for drop-line isolation.
202869
Air Powered Grease Pumps and Packages
Portable Bases
241663
111470
203650
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ GREASE PUMPS
31
NXT™ Check-Mate® Packages
Air Operated Piston Pumps and Packages for Grease
Air Powered Grease Pumps and Packages
Ordering Information
Package Number
with DataTrak
247973
247976
247974
247977
247975
247978
Package Number
without DataTrak
24E006
24E007
24E008
24E009
24E010
24E011
14:1
26:1
29:1
55:1
63:1
68:1
Pump with DataTrak
P14MCS
P26MCS
P29MCS
P55MCS
P63MCS
P68MCS
Pump w/o DataTrak
P14DCS
P26DCS
P29DCS
P55DCS
P63DCS
P68DCS
Ratio
Mounting
Floor Stand (223952)
3/4 in x 6 ft Air Hose
1 in x 6 ft Fluid Hose
208610
115042
244657
System Manual
312863
Pump Manual
312376
Pump Lower Manual
312375
Motor Manual
311238
*Graco recommends 20 cpm or less for supply applications
Performance Charts
A = 100 psi (7 bar)
B = 70 psi (5.0 bar)
C = 40 psi (2.8 bar)
D = 90 psi (6.3 bar)
Test Fluid : #10 Weight Oil for all pumps
Ordering Information
NXT Check-Mate RAM Packages
Ratio
Package Number
Mounting
32
14:1
63:1
68:1
247979
247980
247981
RAM System
Operation Manual
312371
Repair and Parts Manual
312373
LUB R IC A T ION E QU IP M E N T ❚ G R EA S E P U M P S
www.graco.com
Diaphragm Pumps
Air-Operated Double Diaphragm Transfer Pumps
236265
241906
DF3525
DB3525
DK3525
Ordering Information and Technical Specifications
Key
OT = Oil Transfer
OE = Oil Evacuation
WA = Water, Anti-Freeze
Body/Diaphragm Description
Part
Typical
Number Application
307 3/8 in Diaphragm Pump
Acetal/TPE
D31255
515 3/4 in Diaphragm Pump
Aluminum/Buna N
241906
716 3/4 in Diaphragm Pump
Acetal/Buna Dual Inlet
243669
1 in Diaphragm Pumps
1050A Aluminum/TPE (UL)
647016
1050A Aluminum/TPE (UL)
647648
1050A Aluminum/TPE
647666
1590 1-1/2 in Diaphragm Pump
Aluminum/TPE
DB5525
2150 2 in Diaphragm Pump
Aluminum/TPE
3275 3 in Diaphragm Pump
Aluminum/TPE
NOTE: All pumps are 1:1 ratio
(1)
FD = Fuel Dispense (with 50 psi relief valve)
Max.
Air
SCFM
Air
Inlet
NPT
Max.
psi
(bar)
7(1)
1/4
100(7)
3/8
7 (31.8)
28(1)
1/4
100(7)
3/4
28(1)
1/4
100(7)
67
1/2
20(2)
FT = Fuel Transfer
Fluid Free Flow
Air Valve
Inlet/
gpm
Replacement
Outlet
(lpm)
Kit
WWS = Windshield Wash Solution
Kits
(Seats, Balls,
Diaphragms)
Diaphragm
Kit
Manual
239952
D03255
D03005
308553
16
(60.6)
241657
D05277
D05007
308573
3/4
16 (61)
241657
D05277
D05007
308573
125
(8.6)
1
50 (189)
1/2
50
(3.4)
1
32 (121)
67(2)
1/2
125
(8.6)
1
50 (189)
OT, OE,
WA
90(3)
1/2
120
(8.3)
1 1/2
90 (341)
236273
D0B525
D0B005
308441
DF3525
OT, OE,
WA
175(3)
1/2
120
(8.3)
2
150(567)
236273
D0F525
D0F005
308368
DK3525
OT, OE,
WA
325(3)
3/4
120
(8.3)
3
275
(1,041)
238765
D0K525
D0K005
308639
OT, WA,
WWS
OT, OE,
WA, WWS
50/50
WWS, WA
OT, WA,
OE
OE, FT,
WA, FD
Max air use at 100 psi (7.0 bar)
(2)
Max air use at 125 psi (8.6 bar)
(3)
313597
24B766
24B634
and
24B639
24B624
313597
312877
Diaphragm Pumps and Accessories
D31255
Max air use at 120 psi (7.0 bar)
Mounting Accessories
Pump
307
Air Line Filter
Air Regulator & Gauge
515/716
110146
110147
110147
Air Quick-Connect Coupler
208536, 1/4 npt(f)
Air Quick-Connect Nipple
169970, 1/4 npt(m)
Bleed Type Air Valve
Thermal Relief Kit
Thermal Relief Valves
150 psi (10.3 bar)
1590
2150
3275
106148
106149
106150
106150
244844
202858
206199
207651
110199, 1/2 npt(f)
110224
224835
N/A
110225
189233
238899
238428
113497 al/bn, 112119 ss/tf
110226
N/A
N/A
N/A
N/A
N/A
N/A
113497 al/bn , 112119 ss/tf
Grounding Wire and Clamp
222011
Suction Hose Kit
Flange Adapter Kit
N/A
110196, 1/2 npt(f)
110223
Wall Bracket
1040
236054
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Dual Inlet Manifold
N/A
*
685984 **
N/A
N/A
N/A
Instruction Manual
308553
308573 & 308981
308326 & 308479
308441
308368
308639
*243669 comes with dual inlet **Dual inlet must be ordered separately for 685984
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ T RANSF ER PUMPS
33
Fast-Flo® 1:1
Transfer Pumps
Features and Benefits
• Stainless steel models available for corrosion resistance
• Differential air motor for smooth operation and reliability
Transfer Pumps and Accessories
Typical Applications
• Low pressure, high volume transfer of low viscosity fluids
• Automotive dealerships
• Heavy duty dealerships
• Fast lube centers
• Fleet service facilities
• Service shops
• In-plant
• Lube trucks
• Mining
226948
Typical Fluids Handled
• Water
• Anti-freeze
• Windshield wash fluid
• Used Oil
• Used Anti-freeze
NOTE: Use Fast-Ball 1:1 for petroleum-based products.
226947
Performance Chart
25
cycles/min
50
75
scfm
(m3/min)
100 10
(0.3)
80
(5.5)
8
(0.23)
40
(2.7)
6
(0.17)
20
(1.4)
4
(0.12)
0
gpm
(lpm)
Manual
307427
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
120
(8.3)
Inlet Air Pressures:
=100 psi
(6.9 bar)
=70 psi
(4.8 bar)
=40 psi
(2.8 bar)
2
1
2
3
(3.8)
(7.6)
(11)
TEST FLUID: No. 10 Weight Oil
Flow Rate
gpm (lpm)
4 (0.08)
(15)
Maximum Fluid
Pressure psi (bar)
Operating Range (1)
psi (bar)
Wetted Materials
Air Inlet Size
Material Inlet(2)
Material Outlet
180 (12.4)
40-180 (2.8-12)
See Ordering Info
1/4 npt(f)
1-1/2 npt(f)
3/4 npt(f)
Fast-Flo 1:1
5 (19)
Line Length‡: Up to 100 ft (30 m)
Annual Usage: Up to 5000 g (18921 l)
Dispense Points: 1
Typical Applications: In-Plant, Small Maintenance Facility
(1) Max Operating Air Pressure for #226951 is 60 psi (4.2 bar)
(2) For universal pumps
34
LUBR IC A T ION E QU IP M EN T ❚ TR A N S F E R P U M P S
www.graco.com
Fast-Flo® 1:1
Transfer Pumps
Ordering Information
Universal-Length Pumps (includes motor and pump-lower assembly)
Material
226948
226952
237130
237131
237132
226943 *
226944 **
226945 **
CS
SST
CS
CS
SST
CS
CS
SST
Std. Seal
Repair Kits
218112
218112
213012
213013
213013
213012
215964
215964
Material
Rubber
Rubber
Leather
PTFE
PTFE
Leather
Polyethylene
Typical Fluids
Motor Oil
Polyethylene
Anti-Freeze, Windshield Wash
(Note: All seal repair kits are interchangeable with other Fast-Flo pumps.)
Drum-Length Pumps (includes motor and pump-lower assembly)
Part Number
226947
226951 †
226953
237133
237134
237129
226940
226941
226942
CS
CS
SST
CS
CS
SST
CS
CS
SST
Accessories
Wetted Parts
Std. Seal
Repair Kits
218112
213012
213013
213012
215964
Material
Rubber
Leather
PTFE
Leather, PTFE,
Leather
Polyethylene, UHMWPE
Typical Fluids
Motor Oil
A/W
Note: All seal repair kits are interchangeable with other Fast-Flo pumps.
* UL-listed
** UL-listed and CE-marked
† Adjustable down tube length between 18 in (457 mm) to 46.4 in (1180 mm)
Accessories
Motor Service Kits for all Fast-Flo 1:1 Pumps
220168
Motor Service Kits for all Fast-Flo 1:1 Air Valve Piston Assembly (used with repair kit #214584, which must be ordered separately)
Hose and Fittings Kits
222118
18 in (0.5 m) for connecting wall-mounted Fast-Flo 1:1 pumps to piping. Includes: air hose (109123) with swivel elbow (155541), fluid hose (109108)
with swivel elbow (160327).
222119
6 ft (1.8 m) for use with drum-mounted Fast-Flo 1:1 pumps. Includes: air hose (109125) with swivel elbow (155541), fluid hose (109105) with swivel
elbow (160327).
Transfer Pumps and Accessories
Part Number
Bung Adapters
214583
Allows direct mounting of full-length Fast-Flo 1:1 pumps into standard 2 npt drum bung.
217359
Sealed bung adapter for Fast-Flo pumps; can be used with suction kit #236054
Installation Kits
218316
Includes shut-off valve, regulators, gauges and fittings as necessary for normal installation.
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ T RANSF ER PUMPS
35
Hurricane™
Dispense System
Electrical Powered Pumps and Packages
Features and Benefits
• Electric pump with 6 ft (1.8 m) grounded power cord
• Digital metering standard on all units
• Quick-change bung adapter
• Pumps synthetic or petroleum based oils, ATF and antifreeze
(up to 50/50 mix)
• Simple two button operation
• Fits any container up to 44 in (1.1 m) tall with a 2 in =NPT opening
• Measures in quarts, gallons, pints or liters
• Available with 8 ft or 25 ft (2.4 m or 7.6 m) meter and
hose or built-in tapper
• Variety of portable package options
Typical Fluids Handled
• Synthetic Oil
• Petroleum Based Oils
• ATF
• Antifreeze (50/50 mix)
234902 and 249294 Hurricane with meter & hose
Technical Specifications
Ordering Information
Voltage
110 Volts / 60 Hz
Hurricane Dispense Systems
Maximum current
6 Amps
248918
Hurricane metered tapper unit
Flow rate
1.50 gpm (6.0 lpm)
234902
Hurricane 8 ft (2.4 m) hose and meter
Maximum container height
44 in (1.1 m)
249294
Hurricane 25 ft (7.6 m) hose and meter
Weight (varies by model)
Up to 20 lbs (9 kg)
Portable Packages with 25 Gallon Dispense Cart
Meter accuracy
± 1.5%
249783
Hurricane metered tapper unit
249771
Hurricane 8 ft (2.4 m) hose and meter
249821
Hurricane 25 ft (7.6 m) hose and meter
Instruction manual
311216
ETL listed in US and Canada
Portable Packages for 16 Gallon (60 l) Barrels
253487
Hurricane caster base with metered tapper
253486
Hurricane caster base with 8 ft (2.4 m) hose and meter
253494
Hurricane caster base with 25 ft (7.6 m) hose and meter
Accessories
253683
249771 and 249821 Portable package with
25 gallon dispense cart
36
253486 and 253494 Portable package
16 gallon barrel not included
LUBR IC A T ION E QU IP M EN T ❚ TR A N S F E R P U M P S
Hurricane caster base
234902 and 249294
Hurricane with meter & hose
248918
Hurricane tapper unit
www.graco.com
APEX™ and APEX On-Demand
Electric Transfer Pumps
APEX Transfer Pumps
• Available with 12 VDC, 115 VAC and 230 VAC electric motors
• Self-priming, positive displacement design
• Pumps petroleum- and synthetic-based lubricants up to 8 gpm (30 lpm)
• Built-in bypass valve
• Transfer used oil with inlet suction screen (260306)
• TENV electric motor for demanding environments, models 260105, 260106, 260108
and 260109
• System includes suction tube, fluid hose, dispense valve and bung adapter
for models 260100, 260101, 260102 and 260104
Electrical Powered Pumps and Packages
APEX 115 VAC oil transfer system
APEX On-Demand Dispensing Pumps
• On-demand sensing system automatically starts and stops the pump
• Low operating and installation costs
• Available in 12 VDC and 115 VAC
• TENV electric motor for demanding environments
• Extremely quiet pump operation
• Output flow is continuous and non-pulsating
• Inlet and outlet check valves with thermal relief valves included
Typical Applications
APEX On-Demand
12 volt DC dispensing pump
• Filling bulk tanks from drums
• Agricultural equipment
• Lubricant transfer from remote locations
• Filling in-plant machinery
• Construction equipment
• Evacuating used oil receivers
• Automotive and truck service garages
• Fleet marine and personal boat service
Typical Fluids Handled
• Synthetic oil
• Liquid soap
• Petroleum oil*
• Used oil*
• Non-flammable oil based solvents
• Anti-freeze
• Hydraulic fluids
• Oil based herbicide carriers
• Cutting oils
*Not for food grade use
psi (bar, MPa)
70
(4.8, 0.4)
60
(4.1, 0.4)
50
(3.4, 0.3)
40
(2.7, 0.2)
30
(2.0, 0.2)
20
(1.3, 0.1)
A
B
C
10
(0.6, 0.06)
0
gpm 0
(lpm)
180
(12, 1.2)
160
(11, 1.1)
140
(9.6, 0.9)
120
(8.2, 0.8)
100
(6.8, 0.6)
80
(5.5, 0.5)
60
(4.1, 0.4)
40
(2.7, 0.2)
B
FLUID OUTLET PRESSURE psi (bar, MPa)
80
(5.5, 0.5)
FLUID OUTLET PRESSURE
FLUID OUTLET PRESSURE psi (bar, MPa)
Performance Charts by Part Number
C
A
D
20
(1.3, 0.1)
4
(15.1)
6
(22.7)
8
(30.2)
10
(37.8)
gpm 0
(lpm)
1
(3.8)
2
(7.6)
3
(11.4)
FLOW RATE
PART NUMBERS
LEGEND
A = 260101, 260104
Relief
valve opens
B = 260100
C = 260102
www.graco.com
600
(41.3, 4.1)
500
(34.4, 3.4)
D
C
400
(27.5, 2.7)
300
(20.6, 2.1)
E
A
200
(13.7, 1.3)
100
(6.8, 0.6)
B
0
0
2
(7.6)
700
(48.2, 4.8)
4
(15.1)
5
(19)
6
(22.7)
7
(26.4)
8
(30.2)
9
(34)
gpm 0
(lpm)
1
(3.7)
2
(7.6)
FLOW RATE
PART NUMBERS
LEGEND
A = 260105, 260106
Relief valve
setting at 150 psi
(10.3 bar, 1.0 MPa)
B = 260108
C = 260240
D = 260109
3
(11.3)
4
(15.1)
5
(18.9)
FLOW RATE
PART NUMBERS
A = 260112
B = 260110
C = 260111
D = 260114
E = 260113
LEGEND:
Pressure switch opens
LUBRIC AT ION E QUIP M E NT ❚ T RANSF ER PUMPS
37
APEX™ and APEX On-Demand
Electric Transfer Pumps
APEX Transfer System
Part Number
260100
260101
260102*
260104
Motor
12 VDC
115 VAC
115 VAC
230 VAC
Hertz
NA
Horsepower
Maximum Current
Maximum Flow Rate
0.50
50/60 Hz
0.75
0.50
35 amps
9.2 amps
9.0 amps
3.9 amps
5.8 gpm (22 lpm)
4.25 gpm (16 lpm)
8.0 gpm (30 lpm)
4.25 gpm (16 lpm)
30 psi (2.1 bar)
65 psi (4.5 bar)
Maximum Pressure
Transfer Pumps and Accessories
60 Hz
0.75
65 psi (4.5 bar)
Inlet port
1 npt(f)
Outlet port
3/4 npt(f)
Weight
34 lbs (15 kg)
25 lbs (11 kg)
Instruction manual
311305
Note: All oil transfer systems come with 3/4 in x 8 ft hose, 1 in x 34 in suction tube & 3/4 in outlet dispense valve
*Designed for fluid viscosities of 1000 centistokes or less. If fluid viscosity is greater than 1000 centistokes use part # 260101.
APEX Transfer Pumps
Part Number
260105*
260106
Motor
115 VAC
Hertz
60 Hz
Horsepower
260108
260109
9.0 amps
11.0 amps
4.0 gpm (15 lpm)
8.0 gpm (30 lpm)
1.00
Maximum Current
7.5 amps
Maximum Flow Rate
3.0 gpm (11 lpm)
Maximum Pressure
150 psi (10 bar)
Inlet port
1 npt
Outlet port
3/4 npt
Weight
25 lb (11 kg)
30 lb (14 kg)
Instruction manual
311306
Note: All oil transfer pumps come with bung adapter.
*Part no. 260105 is a wall mount unit
APEX On-Demand Pumps
Part Number
260110
260111
Voltage
Hertz
Horsepower
Maximum Current
260113
260114
260112
115 VAC
12 VDC
60 Hz
N/A
0.75
1.00
1.50
2.00
0.75
10 amps
13 amps
18 amps
21 amps
75 amps
650 psi (45 bar)
400 psi (28 bar)
52 lb (24 kg)
27 lb (12 kg)
Maximum Flow Rate
2.3 gpm (9 lpm)
3 gpm (11 lpm)
Maximum Pressure
370 psi (25 bar)
550 psi (38 bar)
4.0 gpm (15 lpm)
470 psi (32 bar)
Inlet port
3 gpm (11 lpm)
3/4 npt
Outlet port
-12 JIC (m)
Weight
27 lb (12 kg)
32 lb (15 kg)
Instruction manual
41 lb (19 kg)
311307
Note: All on-demand pumps come with bung adapter
Accessories
260415
Oil Meter with 3/4” npt inlet and outlet ports. Displays in quarts.
260145
Wall Mounting Bracket, fits all models
260238
“Y” Strainer with 3/4” npt female in-line strainer for used oil transfer
260306
Inlet Suction Screen Assembly, required for used oil applications, 20 mesh screen
260124
55 in (1.3 m) PVC Suction Tube With inlet check valve
260415 Oil meter
38
LUBR IC A T ION E QU IP M EN T ❚ TR A N S F E R P U M P S
www.graco.com
GTP10 and GTP12
Fuel Transfer Pumps
• Heavy duty, die-cast aluminum
• CSA listed motor
• Built-in relief valve and filter strainer
• Easy-to-lock security
• High quality, UV resistant automotive finish
• Rain proof for extreme weather conditions
• Two year warranty
Typical Applications
• Fuel transfer for the construction, agriculture, manufacturing and
marine industries
Typical Fluids Handled
• Gasoline
• Diesel fuel
• Kerosene
• Bio-fuels
Fuel Transfer Kit: Includes pump, fuel nozzle, bung adapter, 34 in (0.9 m) suction
tube, 12 ft (3.7 m) grounded hose, elbow fitting, 18 ft (5.5 m) power cable, wire nuts
and strain relief
NOTE: AC units do not include power cable, wire nuts or strain relief
Ordering Information
Kit Number
260000
260020
260025
260022
Voltage
12 VDC
24 VDC
115 VAC
230 VAC
1.7 amps
1 amps
Inlet Port
Transfer Pumps and Accessories
Features and Benefits
1 npt
Outlet Port
3/4 npt
Current
12 amps
Power Cord
6 amps
18 ft (5.5 m)
Hose
N/A
3/4 in x 12 ft (19 mm x 3.7 m)
Suction Tube
1 in x 34 in (25 mm x 0.9 m)
Weight
20 lbs (9 kg)
Max Fluid Flow
Instruction Manual
10 gpm (38 lpm)
12 gpm (45 lpm)
311304
Accessories
260078
Unleaded nozzle
260083
Unleaded nozzle with auto shut-off
260082
Regular/diesel nozzle with auto shut-off
260079
Regular/diesel nozzle
260523
8 ft x 34 in (2.4 m) npt UL Listed hose
260521
12 ft x 3/4 in (3.7 m) npt UL Listed hose
www.graco.com
260083
LUBRIC AT ION E QUIP M E NT ❚ T RANSF ER PUMPS
39
Lube Truck Package Solutions
Fire-Ball® Oil and Grease Packages
Oil Package Selection and Ordering Information
Fire-Ball 300
Cover-Mounted Package
Fire-Ball 300
Cover-Mounted Package
Ratio
Fire-Ball 425
Cover-Mounted Package
5:1
Container Size
16 gal (60 l) Open-head
Fire-Ball 425
Bung-Mounted Package
10:1
55 gal (200 l) Closed-head†
55 gal (200 l) Closed-head†
Package No.
222086
206655
204264
206656
Bare Pump No.
203872
203857
204254
222065
Hose/Fitting Kit
Specialty Pumps and Packages
Fire-Ball 300
Bung-Mounted Package
222063
222067
222095
222066
Hose Length
6 ft (1.8 m)
6 ft (1.8 m)
6 ft (1.8 m)
6 ft (1.8 m)
6 ft (1.8 m)
Air Regulator
(1)
(1)
(1)
(2)
(2)
207367(3)
-
Hold-Down Kit
222061
Drum Cover
222060
207367
-
207361
Bung Adapter
-
-
204076 (2.140 in Dia.)
-
224579 (2.159 in Dia.)
Pump Clamp
-
-
204095
-
204095
Instruction Manual
307883
† For closed-head drums, pump mounts off-center on drum cover. Pump draws through standard 2 npt bung opening and is equipped with grommet for rain-tight seal to the drum cover.
(1)
Order 3/8 in (9.5 mm) air regulator and gauge separately, #109075.
(2)
Order 1/2 in (12.7 mm) air regulator #104266 and gauge #100960 separately.
(3) Off set drum cover
Grease Package Selection and Ordering Information
Fire-Ball 300
Cover-Mounted
Package
Fire-Ball 300
Cover-Mounted
Package
Fire-Ball 425
Cover-Mounted
Package
Fire-Ball 425
Cover-Mounted
Package
Fire-Ball 425
Cover-Mounted
Package
120 lb (55 kg)
Open-head
400 lb (180kg)
Open-head
120 lb (55 kg)
Open-head
400 lb (180 kg)
Open-head
120 lb (55 kg)
Open-head
400 lb (180 kg)
Open-head
Package No.
222085
222071
223107
222075
243817
243818
Bare Pump No.
239887
239888
205394
205395
239729
239730
Ratio
50:1
Container Size
Hose/Fitting Kit
Fire-Ball 425
Cover-Mounted
Package
75:1
222072
222076
Hose Length
6 ft (1.8 m)
Air Regulator
*
**
*
Hold-Down Kit
222061
207361
222061
207361
222061
207361
Drum Cover
222060
207366
222060
207366
222060
207366
Follower Plate
220654
223845
223344
223846
223344
223846
Instruction Manual
307880
* Order 3/8 in (9.5 mm) air regulator and gauge separately, #109075.
** Order 1/2 in (12.7 mm) air regulator #104266 and gauge #100960.
243818
222067
222086
40
206656
LUB R ICA T ION E QU IP M E N T ❚ S P E C I A L T Y P U M P S
233107
www.graco.com
Undercoating/Rust-Proofing Packages
Fire-Ball® 300, 15:1 Packages
Features and Benefits
• Available in carbon steel for petroleum-based or SST for water-based materials
• Durable air motor provides trouble-free operation
Typical Applications
• Undercoating, rust-proofing and sound-deadening materials
• Automotive and heavy-duty vehicle dealerships
• Fast lube centers and service shops
• Fleet service facilities
224826
• Undercoating and rust-proofing
226269
(verify chemical compatibility for pump’s wetted components with undercoating
material supplier or contact Graco directly at 1-800-533-9655)
Technical Specifications
Pump Performance
22
cycles/min
45
67
90 scfm
3
(m /min)
900
(62)
12
(0.34)
600
(41)
9
(0.26)
300
(21)
6
(0.17)
Maximum Fluid Pressure
2700 psi (186 bar)
Effective Air Motor Diameter
3 in (76.2 mm)
Operating Range
40 to 180 psi (2.8 to 12.5 bar)
Continuous-Duty Flow Rate
. 0.7 gpm (2.7 lpm)
Approx. Air Consumption @ 100 psi (7 bar)
17 cfm
Air Inlet
3/8 npt(f)
Material Outlet
1/4 npt(f)
Material Inlet for Non-SST Pump
1 npt (straight inlet)
Material Inlet for 224825 (SST Pump)
1 npt (barbed inlet)
Wetted Parts for Non-SST Pump
CS, Aluminum, PTFE, Rubber
Wetted Parts for SST pump
SST, Aluminum, Leather, PTFE, Rubber
Instruction Manual for non-SST Pump
306531
Instruction Manual for SST Pump
308069
Inlet Air Pressures:
=100 psi
(6.9 bar)
AIR CONSUMPTION
FLUID OUTLET PRESSURE
psi
(bar)
1200
(83)
=70 psi
(4.8 bar)
=40 psi
(2.8 bar)
3
0
gpm
(lpm)
0.25
.50
.75
(0.95) (1.7) (2.9)
TEST FLUID: No. 10 Weight Oil
1 (0.08)
(3.8)
Ordering Information
Undercoating
Style
Container Size
Spray Masking
Portable
Portable Dolly Mounted
Stationary
Bung Mounted Stationary
400 lb (180 kg)
35 lb (16 kg)
120 lb (54 kg)
400 lb (180 kg)
Package No.
222077
226342
226269
224826*
Pump
206405
206699
206700
224825 (SST pump)
Dispense Kit
222079
222079
222082
Tip
286517
Hose Length
Cover
Caster Base
224023
286211 / 286621
15 ft (4.6 m)
15 ft (4.6 m)
25 ft (7.6 m)
25 ft (7.6 m)
222058
204574
200326
-
204144
-
-
Instruction Manual
Specialty Pumps and Packages
Typical Fluids Handled
307879/306531
308069
* Package #224826 includes flexible short tube #224022 long enough for 400 lb (180 kg) container, but can be trimmed to accommodate smaller containers.
214570
60-mesh Aluminum filter (3/8 npt(f) inlet; 1/4 npt(f) outlet) Max. working pressure: 3000 psi (210 bar)
Replacement Screen Elements (SST) 3-pack/25-pack
| 238435/238436 30-mesh | 238437/238438 60-mesh | 238439/238440 100-mesh
202577
Z-Swivel allows non-binding movement for hard-to-reach spots. Order 155570 adapter separately to accommodate 234237 gun
206496
Nozzle Extension delivers 360º coating fan into blind areas. Length 30-3/4 in (99 cm) x 7/8-14(f) end. Tip 206502, size .043
234237
4 Finger Silver Gun with tip guard 243161 and tip 286517. 4500 psi (310 bar) x 3/8 npt(f) inlet. Must order 155570 adapter
and 239663 straight swivel to accommodate gun to 1/4” (mbe) hose
239966
Bung Adapter
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ S P E C IAL TY PUMPS
41
Windshield Wash and Coolant Dispense
Specialty Pumps and Packages
Pump Package Solutions
Packages for Pre-Mixed Windshield Wash Solvent and Coolant Dispense
Powered by the 307 air-operated double-diaphragm pump, this package is designed for transferring and dispensing pre-mixed windshield wash and coolant.
237161
Complete Package Includes the Following:*
307 Diaphragm Pump (D31255), 6 ft (1.8 m) air hose (109125), 4 ft (1.2 m) coupled nitrile fluid hose (220596), 3/8-18 npt x 1/2-14 npt (mbe) air filter (110146), air
gauge (108190), air line fitting (111511), 1/4 npt air regulator (110318), elbow (100611), 15 in (381 mm) 3/8 in ID tube, (187479), mounting bracket (190125), adapter
(156022), 1/4-18 npt nipple (156971), suction hose kit (223888), 6 ft (1.8 m) coupled PVC hose and 304 SST 16 mesh strainer, wall bracket (224835).
237160
Includes all items listed above except diaphragm pump and wall bracket.
Bulk Anti-Freeze and Windshield Solvent Transfer Packages
Description
Package Number
1040 AODD
1040 AODD
716 AODD
716 AODD
Dual Inlet
Single Inlet
Dual Inlet
Single Inlet
244679
244680
244681
244682
Pump
236265
Air Regulator
109075
110147
Fluid Connect Hose
115042
109105
Air Connect Hose
205418
109125
Air Shut-off Valve
110224
110223
Wall Mount Bracket
189233
Dual Inlet Manifold
Suction Kit
Thermal Relief Kit
685984
2-236054
LUB R ICA T ION E QU IP M E N T ❚ S P E C I A L T Y P U M P S
241906
224835
–
–
236054
2-236054
238428
Instruction Manual
42
243669
–
236054
113497
309353
www.graco.com
Dyna-Star® and Power-Star™ Pumps
For Oil and Grease Applications
Features and Benefits
• Ties into existing hydraulic systems on mobile equipment
• Operates quieter than air driven pumps and doesn’t require mufflers
• Eliminates the need for air compressors
• Provides self-lubrication for long life and reliability
• Hydraulic changeover is faster with less pulsation allowing smoother
output pressure, even with long plumbing runs
• Low pressure, high volume oil transfer
• High pressure, high volume grease dispense
• Heavy-duty dealerships
• Fleet service facilities
• Service shops
• In-plant
• Lube trucks
• Mining
Typical Fluids Handled
• Petroleum and synthetic based oils
• Grease up to NGLI #2
Ordering Information for Oil Packages
Oil Applications
Power-Star 1:1
Drum Size
Dyna-Star® 1:1
Dyna-Star 1:1
Universal
Pump No.
236754
Dyna-Star 1/4:1
55 gal (200 l) Bung- or
Cover-Mounted
224741
224742
Max. Input Pressure
Stainless Steel Dyna-Star 1:1
Universal
236753
237653
1500 psi (102 bar)
Max. Fluid Input Volume
12 gpm (45.4 lpm)
Max. Output Flow Rate
12 gpm (45.4 lpm)
3 gpm (11.4 lpm)
3 gpm (11.4 lpm)
Maximum CPM
10 gpm (37.9 lpm)
3 gpm (11.4 lpm)
375 psi (25.1 bar)
1500 psi (102 bar)
3/8 npt
3/8 npt(f)
60
Max. Fluid Output Pressure
1500 psi (102 bar)
Hydraulic Supply Inlet
3/4 npt
Hydraulic Return Outlet
1-1/4 npt
3/4 npt
3/4 npt
3/4 npt
3/4 npt(f)
1/2 npt
1/2 npt
1/2 npt
1/2 npt
1/2 npt(f)
Fluid Outlet
3/8 npt
3/8 npt
Fluid Inlet
1-1/2 npt
Max. Incoming Fluid Temp.
130º F (54º C)
Instruction Manual
Applications
Hydraulic Powered Pumps and Packages
Typical Applications
308391
308155
308390
308155
Bulk oil transfer
Oil dispensing
Bulk oil transfer
Anti-freeze dispensing
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ H Y DRAUL I C PUMPS
43
Dyna-Star® and Viscount® II Pumps
For Oil and Grease Applications
Ordering Information for Grease Packages
Grease Applications
Dyna-Star 5:1
Dyna-Star 10:1
Viscount II 2.4:1
Part No. – Drum Size
224912 – 35 lb (16 kg)
224751 – 120 lb (55 kg)
224752 – 400 lb (180 kg)
247540 – 60 lb (27 kg)
247443 – 120 lb (55 kg)
247450 – 400 lb (180 kg)
222902 – 400 lb (180 kg)
Max. Input Pressure
1500 psi (102 bar)
600 psi (41 bar)
1500 psi (102 bar)
Max. Fluid Input Vol.
3 gpm (11.4 lpm)
Max Flow Output Rate
7.5 gpm (28.5 lpm)
4 lb/min (1.8 kg)
1.1 lb/min (0.5 kg)
Maximum CPM
60
Max. Fluid Output Pressure
Hydraulic Supply Inlet
Hydraulic Powered Pumps and Packages
9 lb/min (4.1 kg)
7500 psi (517 bar)
3/8 npt
2300 psi (159 bar)
3/4-16 in. JIC (37º Flare)
3/4 npt
Hydraulic Return Outlet
3/4 npt
1 npt
Fluid Outlet
1/2 npt
1-1/2 npt
Maximum Incoming
Hydraulic Fluid Temp.
Instruction Manual
130º F (54º C)
200ºF (93ºC)
130ºF (54ºC)
308149
247540, 247443, 247450
308149
Hydraulic Fluid Controls (Required for each pump)
236864
Dyna-Star Fluid Controls [1500 psi (102 bar); 3 gpm (11.4 lpm)]. Includes manifold with pressure-reducing valve, flow control valve, pressure gauge, shut-off
ball valves and 3 ft (0.9 m) supply and return hoses. Instruction manual 308395.
236865
Power-Star Fluid Controls [1500 psi (102 bar); 12 gpm (45.4 lpm)] Includes manifold with pressure-reducing valve, flow control valve, pressure gauge, shutoff ball valves and 3 ft (0.9 m) supply and return hoses. Instruction manual 308395.
237904
1:1 Dyna-Star Thermal Relief Valve, 1600 psi (110 bar)
235998
Mini Fire-Ball 225, 3:1 thermal relief valve rated to 600 psi (41 bar)
Accessories
Follower Plates
Covers
224916
Follower plate for 35 lb (16 kg)
224915
Cover for 35 lb (16 kg)
Tie-Down Covers
223700
Follower plate for 120 lb (55 kg)
204574
223701
Follower plate for 400 lb (180 kg)
200326
222060*
Tie-Down Cover for 120 lb (55 kg)
Cover for 120 lb (55 kg)
207366**
Tie-Down Cover for 400 lb (180 kg)
Cover for 400 lb (180 kg)
*Use with hold-down kit #222061 **Use with hold-down kit #207361
247540
222902
236754
224741
44
LUB R ICA T ION E QU IP M E N T ❚ H YD R A U L I C P U M P S
www.graco.com
Manual Pumps
For Oil and Grease
16 Gallon (60 l) Metered and Non-Metered Dispensing Packages
Designed for manual dispensing of fluid oil from bulk containers to point of application.
Description
Portable Metered
ATF Dispenser
Portable Metered
Gear Lube Dispenser
Cart-Mounted Metered
Gear Lube Dispenser
Stationary Non-Metered
Gear Lube Dispenser
Portable Non-Metered
Gear Lube Dispenser
Package No.
225880
225376
225384
225380
225378 *
-
-
214658
214658
Pump No.
204867
Metered Dispense Kit
239707
239705
Dispense Kit
-
-
Hose Diameter
-
-
Hose Length
-
-
Drum Cover
-
1/2 in (12.7 mm)
6 ft (1.8 m)
204574
Caster Base
203622
Cart
-
-
Instruction Manual
-
-
203622
203650
-
-
306436
* Hydraulic; can be used for gear oil dispensing.
Pail Dispensing Package for 5 gal (20 l) Pails
Description
Economy Gear-Lube Dispenser (Dispenses 1.6 to 1.9 oz. [47.3 to 56.2 ml] per stroke)
Package No.
226289
Hose length
4 ft (1.2 m)
Instruction manual
306875
Manually Operated Pumps
Mounts on top of a standard 5 gal (20 l) pail (pail not included). Delivery hose has curved nozzle that stores in cover port.
225380
225376
225880
226289
www.graco.com
225378
225384
LUBRIC AT ION E QUIP M E NT ❚ M ANUAL PUMPS
45
Manual Pumps
For Fluid Transfer
Pumping Bulk Lubricants out of 16 gal (60 l) or 55 gal (200 l) Drums*
All pumps come with suction tube and bung adapter.
Description
Lever Pump**
Pump No.
Delivery rate
Fluids Handled
Rotary Pump†
Hand-Lever Diaphragm Pump‡
114829
226290
112202
0.1 gal (0.4 l) per downstroke
1 gal (3.7 l) per 18 cycles
1 gal (3.7 l) per 9 cycles
Petroleum-based products, Anti-freeze
Petroleum-based products
Petroleum-based products+
-
-
8 ft (2.5 m)
308896
306876
-
Hose Length
Instruction manual
* Drums not included
** Telescopic suction tube mounts 2 npt bung opening of 16 gal (60 l) or 55 gal (200 l) drum. Package includes bung adapter and spout outlet.
† Package has adjustable 2 npt bung mounting to allow use with either 16 gal (60 l) or 55 gal (200 l) drum. Package includes bung adapter and spout outlet.
‡ A double-action high volume pump for gasoline and similar petroleum products. Fits 30 gal (113 l) to 55 gal (200 l) drum. Complete with an 8 ft (2.4 m) hose
with 3/4 in fittings and aluminum telescoping suction pipe. Delivers approximately one gallon per nine strokes.
+ This package is recommended for gasoline, diesel, heating oil and petroleum products, but NOT recommended for water-based fluids, solvents or weak acids.
Manual Dispense from Bulk Containers
Description
Buckshot Luber
with Booster Gun
Buckshot Luber
without Booster Gun
Container Size
Manually Operated Pumps
Package No.
Grease Gun
Fill Pump
35 lb (16 kg)
225914 *
225844 *
Pump
203702
Dispense Kit
203703
Booster Gun
Grease Gun
Fill Pump
203697
120 lb (55 kg)
112197 **
112198 **
-
Filler Adapter+
-
-
Cover and Follower Plate
203701
-
-
-
Instruction Manual
306455
-
-
* Delivers 1/4 oz (0.7 grams) of grease per stroke at pressures to 3000 psi (207 bar). Can service fittings directly or be used to charge a booster gun for more efficiency at higher pressures.
** Fills all three-way loading grease guns equipped with filler fittings. See instruction manual 308306 for filling adapters.
+ Dispense kit #203703 can be used for direct greasing applications (must be ordered separately).
225914
114829
112197
226290
46
LUBR IC A T ION E QU IP M EN T ❚ M A N U A L P U M P S
112202, 2 inch bung adapter, (2)
3/4 in npt(f) inlets includes down
tube and hose
112198
www.graco.com
Hose Reels
Selection Guide
LD Series
Hose Length
SD Series
Up to 65 ft (19.8 m)
XD Series
Up to 75 ft (22.9 m)
700 Series
75 ft (22.9 m)
750 Series
50 ft (15.2 m)
Typical Application
• Small Maintenance
Shops
• Tire/Muffler Shops
• Small Fast Lubes
• Independent Repair
Facilities
• Industrial Manufacturing
Facilities
• Car Dealerships
• Light/Medium-Duty
Truck Dealers
• Fleet Maintenance
• Mining Maintenance
• Public Works Garages
• Construction Vehicle
Maintenance
• Light-Utility Service
Trucks
• Heavy-Duty Truck
Dealers
• Fleet Maintenance
• Mining Maintenance
• Public Works Garages
•Construction Vehicle
Maintenance
• Heavy-Duty Mobile
Service Trucks
• Mining
• Extreme-Duty
• Auto Dealers
• Heavy-Duty Dealers
• Fleet Service
• Service Shops
• In-Plant
• Lube Trucks
• Mining
• Extreme-Duty
• Heavy-Duty Dealers
• Fleet Service
• Service Shops
• In-Plant
• Lube Trucks
• Mining
Typical Fluids
• Petroleum– and
Synthetic–Based Oils
• Grease
• Air only
• Air/Water
• Petroleum– and
Synthetic–Based Oils
• Grease
• Air
• Water
• Anti-Freeze
• Windshield Washer
• Petroleum– and
Synthetic–Based Oils
• Grease
• Fuel Evac
• Pressure Wash
• Air
• Water
• Anti-Freeze
• Windshield Washer
• Petroleum– and
Synthetic–Based Oils
• Air
• Water
• Anti-Freeze
• Windshield Wash
• Used Oil and Anti-Freeze
• Fuel
• Petroleum– and
Synthetic–Based Oils
• Water
• Anti-Freeze
• Unleaded and Diesel
Fuels
Enclosed
www.graco.com
Enclosure Available
Enclosure Available
LUBRIC AT ION E QUIP M E NT ❚ HOSE REEL S
Hose Reels and Packages
Hose Reel
47
LD Series
Enclosed Hose Reels
Features
• Designed for light-duty applications
• Enclosed for safety and protection, extends hose life
• Flexible mounting options–hang on wall or ceiling; bench, table or tank top-mount options
are available
• Full-flow swivel maximizes fluid flow with minimal pressure drop
• Easy spring tension adjustment–increase or decrease pressure spring tension while reel
is pressurized
Dimensions
D
A
B
LD SERIES
Hose Reels and Packages
Enclosed hose reel comes with ceiling/wall
mounting swivel bracket. Required inlet hose
kit sold separately.
Ordering Information
Applications
A
7.1 in (180 mm)
B
23.0 in (585 mm)
C
18.5 in (470 mm)
D
25.6 in (650 mm)
C
Technical Specifications
Model
Numbers
Pressure
psi (bar)
HEL13D
250 (17.2)
6 mm x 11 m
1/4 in x 35 ft
HEL15D
250 (17.2)
6 mm x 15 m
1/4 in x 50 ft
HEL23D
250 (17.2)
10 mm x 11 m 3/8 in x 35 ft
1/2 in x 3/8 in
HEL25D
250 (17.2)
10 mm x 15 m 3/8 in x 50 ft
1/2 in x 3/8 in
HEL33D
250 (17.2)
12 mm x 11 m 1/2 in x 35 ft
1/2 in x 1/2 in
HEL34D
250 (17.2)
12 mm x 14 m 1/2 in x 45 ft
1/2 in x 1/2 in
Hose
id x Length
Air Only
Connection Size
Inlet bspt(m) x Outlet bspt(m)
Operating
Temp.
WETTED
PARTS
1/2 in x 1/4 in
14–140º F
(-10–60º C)
Aluminum,
Buna-N, Rubber,
PVC
48
HEM23D
1800 (124)
10 mm x 11 m 3/8 in x 35 ft
1/2 in x 3/8 in
HEM33D
1800 (124)
12 mm x 11 m 1/2 in x 35 ft
1/2 in x 1/2 in
Grease
HEH13D
5000 (345)
6 mm x 11 m
3/8 in x 1/4 in
LUBR IC A T ION E QU IP M EN T ❚ H O S E R E E L S
1/4 in x 35 ft
9 kg
(19.8 lb)
9.5 kg
(21 lb)
10.4 kg
(23 lb)
Aluminum,
Buna-N, Rubber
Air/Water
Petroleum– and
Synthetic–based
Oils
WEIGHT
0–140º F
(-17–60º C)
11 kg
(24.25 lb)
10.5 kg
(23.1 lb)
11 kg
(24.3 lb)
11.4 kg
(25.1 lb)
Carbon Steel,
Buna-N, Rubber,
UHMWPE
14 kg
(38.8 lb)
13.2 kg
(29.1 lb)
www.graco.com
SD Series
Composite Spool Hose Reels
Features
• Designed for standard-duty applications such as small service garages and
repair shops
• Structurally reinforced frame doesn’t flex when handling hose
• Guide arm position easily changes for mounting on bench, ceiling or wall
• Enamel finish protects the reel from the environment
• Lightweight composite spool made from high strength resins resists dents
and corrosion
• Compact design easily fits inside tool bench or cabinet
• Enclosure kits available–ideal when appearance and protection is important
• Available in six colors. Metallic blue is standard.
Dimensions
C
A
D
LD SERIES
7.0 in (177 mm)
B
18.1 in (460 mm)
C
23.4 in (594 mm)
D
19.2 in (488 mm)
E
21.8 in (554 mm)
F
25.2 in (640 mm)
F E
Ordering Information
Technical Specifications
Model Numbers by Color
Pressure
Metallic
Blue
Air, Water, Antifreeze, Windshield
Washer Fluid
HRL56B
HRL56A HRL56C HRL56D
HRL56E
HRL65B
HRL65A HRL65C HRL65D
HRL65E
Petroleum– and
Synthetic–based
Oils
Grease
SIZE 20
Applications
Hose
Connection Size
ID
HRL56F
300 (20.7)
3/8 in
65 (20)
1/2
3/8 npt(m)
HRL65F
300 (20.7)
1/2 in
50 (15)
1/2
1/2 npt(m) -20º – 190º F
(-28º – 87º C)
HRM65B
HRM65A HRM65C HRM65D HRM65E HRM65F 2,000 (138) 1/2 in
50 (15)
1/2
1/2 npt(m)
HRH55B
HRH55A HRH55C HRH55D
50 (15)
3/8
1/4 npt(m)
White
Red
Black
Dark Blue Yellow
HRH55E
HRH55F 4,000 (276) 3/8 in
Inlet
npsm(m)
Outlet
Operating
Temp.
psi (bar)
Length
ft (mt)
Hose Reels and Packages
Single pedestal with
composite spool. Inlet
Hose Kit sold separately.
A
B
-40º – 200º F
(-40º – 93º C)
Wetted parts–bare hose reel only: zinc plated steel, anodized aluminum, nitrile rubber
Dry Weight: 44 lbs (20 kg)
Instruction Manual: 313431
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ HOSE REEL S
49
SD Series
Steel Spool Hose Reels
Features
• Designed for daily use by professional mechanics
• Structurally engineered frame made from high strength steel won’t bend or flex
• Long-lasting spring provides constant spring torque through the entire range of motion
• Flexible positioning of guide arm for mounting on bench or ceiling, wall or utility truck
• Steel spool for demanding applications
• Open swivel ports ensure high fluid flow with minimal pressure loss
• Enclosure kits available – ideal when appearance and protection is important
• Available in six colors. Metallic blue is standard.
Dimensions
C
SD SERIES SIZE 10
7.0 in (177 mm)
B
16.2 in (412 mm)
C
21.0 in (533 mm)
D
17.1 in (435 mm)
E
19.5 in (495 mm)
F
22.5 in (571 mm)
D
B
F E
A
7.0 in (177 mm)
B
18.1 in (460 mm)
C
23.4 in (594 mm)
D
19.2 in (488 mm)
E
21.8 in (554 mm)
F
25.2 in (640 mm)
Ordering Information
Technical Specifications
Model numbers by color
Red
Black
Dark Blue
Yellow
HPL23B
HPL23A
HPL23C
HPL23D
HPL23E
HPL25B
HPL25A
HPL25C
HPL25D
HPL33B
HPL33A
HPL33C
HPL33D
SIZE 20
HPL56B
HPL56A
HPL56C
HPL65B
HPL65A
HPM33B
SIZE 10
White
SIZE 10
Petroleum–
or Synthetic–
based Oils
Pressure
Metallic
Blue
SIZE 10
Applications
Air, Water,
Anti-freeze,
Windshield
Washer Fluid
SIZE 20
Grease
Hose
Connection Size
psi (bar)
id
(in)
Length
Inlet
ft (mt) npsm(m)
HPL23F
300 (20.7)
3/8
35 (11)
1/2
3/8 npt (m)
HPL25E
HPL25F
300 (20.7)
3/8
50 (15)
1/2
3/8 npt (m)
HPL33E
HPL33F
300 (20.7)
1/2
35 (11)
1/2
1/2 npt (m)
HPL56D
HPL56E
HPL56F
300 (20.7)
3/8
65 (20)
1/2
3/8 npt (m)
HPL65C
HPL65D
HPL65E
HPL65F
300 (20.7)
1/2
50 (15)
1/2
1/2 npt (m)
HPM33A
HPM33C
HRM33D
HRM33E
HPM33F
2,000 (138)
1/2
35 (11)
1/2
1/2 npt (m)
HPM3BB*
HPM3BA*
HPM3BC*
HPM3BD*
HPM3BE*
HPM3BF*
2,000 (138)
1/2
35 (11)
1/2
1/2 npsm (f)
HPM65B
HPM65A
HPM65C
HPM65D
HPM65E
HPM65F
2,000 (138)
1/2
50 (15)
1/2
1/2 npt (m)
HPM6DB*
HPM6DA*
HPM6DC*
HPM6DD*
HPM6DE*
HPM6DF*
2,000 (138)
1/2
50 (15)
1/2
1/2 npsm (f)
HPH15B
HPH15A
HPH15C
HPH15D
HPH15E
HPH15F
5,000 (345)
1/4
50 (15)
3/8
1/4 npt (m)
HPH23B
HPH23A
HPH23C
HPH23D
HPH23E
HPH23F
4,000 (276)
3/8
35 (11)
3/8
1/4 npt (m)
HPH1DB*
HPH1DA*
HPH1DC*
HPH1DD*
HPH1DE*
HPH1DF*
5,000 (345)
3/8
35 (11)
3/8
1/4 npt (f)
Outlet
HPH55B
HPH55A
HPH55C
HPH55D
HPH55E
HPH55F
4,000 (276)
3/8
50 (15)
3/8
1/4 npt (m)
HPH5DB*
HPH5DA*
HPH5DC*
HPH5DD*
HPH5DE*
HPH5DF*
4,000 (276)
3/8
50 (15)
3/8
1/4 npt (f)
* Bare Reel–hose sold separately
Wetted parts–bare hose reel only: zinc plated steel, steel, nitrile rubber
50
A
SD SERIES SIZE 20
SIZE 20
Hose Reels and Packages
Single pedestal with
metal spool. Inlet Hose Kit
sold separately.
A
LUBR IC A T ION E QU IP M EN T ❚ H O S E R E E L S
Dry Weight: 52 lbs (23.5 kg)
Operating
Temp.
-20º–190º F
(-28º–87º C)
-40º–200º F
(-40º–93º C)
Instruction Manual: 313431
www.graco.com
XD Series
Hose Reels
Size 10
Features
• Designed for robust/heavy-duty applications such as mobile lube trucks or large equipment
service, yet with a narrow footprint to fit more reels into small spaces
• Dual pedestal frame provides increased strength for extreme-duty applications
• Long lasting spring is sealed for protection against the weather
• Durable steel spool rides on sealed roller bearings to ensure trouble-free performance
• Available in four colors. Metallic blue is standard.
• Available with arms removed for bulkhead mounting*
* Contact your local distributor for more information
Dimensions
XD SERIES SIZE 10
XD SERIES SIZE 20
A
7.5 in (196 mm)
A
7.5 in (196 mm)
B
16.2 in (412 mm)
B
18.1 in (460 mm)
C
21.0 in (533 mm)
C
23.4 in (594 mm)
D
18.0 in (457mm)
D
20.0 in (508 mm)
E
18.5 in (470 mm)
E
21.0 in (533 mm)
F
22.5 (571 mm)
F
25.2 in (640 mm)
Hose Reels and Packages
Size 20
A
F
E
Size 30
B
C
D
XD SERIES SIZE 30
A
9.0 in (229 mm)
B
21.50 in (546.00 mm)
C
25.96 in (659.45 mm)
D
22.12 in (561.73 mm)
E
23.10 in (588.00 mm)
F
27.60 in (700.82 mm)
A
E
F
B
C
D
NOTE: Hose Inlet Kit for all XD Reels sold separately.
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ HOSE REEL S
51
XD Series
Hose Reels
Ordering Information
Technical Specifications
Model numbers by color
psi (bar)
Hose
id
in
Length
ft (m)
Connection Size
Inlet
in
SIZE 10
SIZE 20
SIZE 30**
SIZE 10
Outlet
in
Metallic Blue
White
Yellow
Desert Sand
HSL25B
HSL25A
HSL25F
HSL25G
3/8
50 (15)
3/8 npt(m)
HSL33B
HSL33A
HSL33F
HSL33G
1/2
35 (11)
1/2 npt(m)
HSL56B
HSL56A
HSL56F
HSL56G
3/8
65 (20)
1/2 npsm(m)
3/8 npt(m)
HSL65B
HSL65A
HSL65F
HSL65G
SIZE 20
SIZE 30**
Fuel/Evacuation
SIZE 30
Pressure Wash
-20–190 ºF
(-28–87 ºC)
50 (15)
1/2 npt(m)
HSLC8B
HSLC8A
HSLC8F
HSLC8G
75 (23)
HSLD5B
HSLD5A
HSLD5F
HSLD5G
HSM33B
HSM33A
HSM33F
HSM33G
2,000 (138)
35 (11)
1/2 npt(m)
HSM3BB *
HSM3BA *
HSM3BF
HSM3BG
2,000 (138)
35 (11)
1/2 npt(f)
HSM65B
HSM65A
HSM65F
HSM65G
2,000 (138)
3/4
50 (15)
3/4 npsm(m)
50 (15)
1/2
3/4 npt(m)
1/2 npt(m)
HSM6DB *
HSM6DA *
HSM6DF *
HSM6DG
2,000 (138)
50 (15)
1/2 npt(f)
HSMC8B
HSMC8A
HSMC8F
HSMC8G
1,500 (103)
75 (23)
1/2 npt(m)
HSMCFB *
HSMCFA *
HSMCFF *
HSMCFG *
2,000 (138)
75 (23)
1/2 npsm(f)
HSMD5B
HSMD5A
HSMD5F
HSMD5G
1,250 (86)
HSMDDB *
HSMDDA *
HSMDDF *
HSMDDG *
HSH15B
HSH15A
HSH15F
HSH15G
2,000 (138)
3/4
-20–190 ºF
(-28–87 ºC)
3/4 npt(m)
-40–180 ºF
(-40–82 ºC)
3/4 npsm(m)
3/4
1/4
-40–180 ºF
(-40–82 ºC)
1/2 npsm(m)
3/4 npsm(f)
50 (15)
1/4 npt(m)
5,000 (345)
HSH1DB *
HSH1DA *
HSH1DF *
HSH1DG *
35 (11)
3/8 npt(f)
3/8 npsm(m)
Grease
Operating
Temp.
300 (20.7)
50 (15)
SIZE 30
Hose Reels and Packages
Petroleum–
and Synthetic–
based Oils
Pressure
1/2
SIZE 30
Air, Water,
Anti-freeze,
Windshield
Washer Fluid
SIZE 20
SIZE 10
Applications
HSH55B
HSH55A
HSH55F
HSH55G
HSH5DB*
HSH5DA*
HSH5DF*
HSH5DG*
4,000 (276)
3/8
1/4 npt(m)
-40–200 ºF
(-40º–93 ºC)
3/8 npsm(f))
50 (15)
HSHC5B
HSHC5A
HSHC5F
HSHC5G
5,000 (345)
1/2 npt(m)
1/2
HSHCDB *
HSHCDA *
HSHCDF *
HSHCDG *
HSPB8B
HSPB8A
HSPB8F
HSPB8G
1/2 npsm(f)
3/8 npt(m)
4,000 (276)
HSHFFB *
HSHFFA *
HSHFFF *
HSHFFG *
HSLE3B
HSLE3A
HSLE3F
HSLE3G
1/2 npsm(m)
3/8
75 (23)
1/2 npsm(m)
3/8 npsm(f)
125 (8.6)
1
30 (9)
3/4 npsm(m)
1 npt(m)
-40–180 ºF
(-40–82 ºC)
-20–225 ºF
(-28–107 ºC)
-40–120 ºF
(-40–49 ºC)
Maximum dry weight with hose: XD10 = 54 lbs (24.5 kg), XD20 = 59 lbs (27 kg), XD30 = 98 lbs (44.5 kg)
Wetted parts–Bare hose reel only: zinc plated steel, anodized aluminum, nitrile rubber
Instruction Manuals: XD10 and XD20: 313431, XD30: 3A0138
* Bare reel–hose sold separately
** Not recommended for overhead installation. Maximum installed height is 7 feet (2.13 meters).
52
LUBR IC A T ION E QU IP M EN T ❚ H O S E R E E L S
www.graco.com
700 Series
Hose Reels
Features
• Fully ported swivel and shaft for unrestricted flow
• Handles hose lengths up to 75 ft (23 m)
• Heavy-duty ball bearings outlast sleeved-type bearings
• Easy rewind with minimal hose guidance
Typical Fluids Handled
• Petroleum and synthetic based oils
• Air
• Water
• Anti-freeze
• Windshield wash fluid
• Used Oil
• Used Anti-freeze
Dimensions
700 SERIES
237875 with 237932
Overhead mounting kit. Includes all
parts needed for ceiling-mounting.
26.25 in (628 mm)
B
24.0 in (609 mm)
C
11.83 in (300 mm)
Hose Reels and Packages
A
A
Ordering Information
Medium-Pressure Oil Dispense Reels (rated to 1500 psi/103 bar)
237728
Bare Hose Reel
237879 *
Hose Reel with 3/4 in x 75 ft (19.1 mm x 23 m) hose
B
C
Medium-Pressure Oil Evacuation and Dispense Reels (rated to 212 psi/14.6 bar)
241910 *
Hose Reel with 1 in x 50 ft (25.4 mm x 15 m) hose; 24 in (0.3 m) Hg vacuum
Medium-Pressure Fuel Dispense Reel (rated to 125 psi/8.6 bar)
237884 *
Hose Reel with 1 in x 50 ft (25.4 mm x 15 m) hose
* Not recommended for overhead installation
Technical Specifications
Inlet
npsm (m)
Outlet
npt (m)
Max. Pressure
Psi (bar)
1 npt(f)
1 npt(f)
1500 psi (bare
reel))
www.graco.com
Maximum Vacuum Operating Temp.
24 in Hg
-40ºF to 180ºF
(-40ºC to 82ºC)
Wetted Parts
Weight
(bare reel)
Instruction
Manual
Carbon Steel,
Buna
103 lb
(46.7 kg)
308546
LUBRIC AT ION E QUIP M E NT ❚ HOSE REEL S
53
750 Series
Hose Reels
Features
• Heavy-duty, high volume reel
• Industrial-grade paint for high abrasion and corrosion resistance
• Full-flow shaft
• Heavy-duty brackets and springs
• Rugged base and hose rollers
• Heavy-duty latch mechanism
Typical Fluids Handled
• Unleaded, leaded and diesel fuels
• Petroleum and synthetic based oils
• Water
• Anti-freeze
Dimensions
Hose Reels and Packages
750 Series
A
26.25 in (667 mm)
B
26.25 in (667 mm)
C
21.88 in (556 mm)
D
13.75 in (349 mm)
E
24.25 in (616 mm)
F
17.50 in (445 mm)
G
22.125 in (562 mm)
H
13.50 in (343 mm)
B
A
D
C
F
H
G
E
Ordering Information
Bulk Dispense Reels (rated to 125psi/8.6 bar))
245410
Bare Hose Reel
Technical Specifications
54
Inlet
npsm (m)
Outlet
npt (m)
Max. Pressure
Psi (bar)
Hose Capacity
Operating Temp.
Wetted Parts
Weight
(bare reel)
Instruction
Manual
1-1/2 npt(f)
1-1/2 npt(f)
375 psi
(26 bar)
50 ft (15.2m) x
1.50 in ID Hose
150º F (65º C)
Carbon Steel,
Buna
139 lbs (63 kg)
309442
LUBR IC A T ION E QU IP M EN T ❚ H O S E R E E L S
www.graco.com
Packages
Hose Reels
LD Enclosed Hose Reel Packages
Package
Reel
Hose Inlet Kit
Dispense Valve/Meter
24D197
HEM33D
24C538
LDM5 Rigid with trigger guard (256215)
24D198
HEM33D
24C538
LDM5 Flex without trigger guard (255751)
24D199
HEM33D
24C538
LDP5 Rigid with trigger guard (256216)
24D200
HEM33D
24C538
LDP5 Flex without trigger guard (255277)
Composite Spool
SD Reel Packages with Enclosure Kit
SD Packages
Hose Reel
Hose Inlet Kit
White Enclosure
Dispense Valve
24B812
HRL56B
218549
24A218
–
24B813
HRL56B
218549
24A218
218545
24B814
HRL56B
218549
24A218
180685/150287
24B815
HRM65B
218549
24A218
–
24B816
HRH55B
218550
24A218
–
SD Packages
Hose Reel
Hose Inlet Kit
White Enclosure
Dispense Valve/Meter
Fitting
24D989
HPL23B
218549
24A217
–
–
24D990
HPL25B
218549
24A217
–
–
24D991
HPL33B
218549
24A217
–
–
24D992
HPL23B
218549
24A217
218545
–
24D993
HPL23B
218549
24A217
180685
150287
24D994
HPL33B
218549
24A217
180685
159842
24D995
HPM33B
218549
24A217
–
–
24D996
HPM33B
218549
24A217
255350
–
24D997
HPM33B
218549
24A217
255348
–
Steel Spool
SD Steel Spool Reel Packages
SD Packages
Hose Reel
Hose Inlet Kit
Enclosure
Dispense Valve/Meter
Fitting
24D998
HPL23B
218549
–
218545
–
24D999
HPL23B
218549
–
180685
150287
24D001
HPM33B
218549
–
255350
–
24D002
HPM33B
218549
–
255348
–
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ HOSE REEL S
Hose Reels and Packages
Steel Spool
SD Reel Packages with Enclosure Kit
55
Accessories
For LD, SD and XD Reels
Ordering Information
LD Enclosed Mounting Brackets
24C793
Ceiling/Wall Stationary Bracket
24C772
Tote, Bench or Wall Mount Post
Ceiling/Wall Stationary
Bracket 24C793
Tote, Bench or Wall
Mount Post 24C772
FOR NPT CONNECTIONS
Hose Reels and Packages
FOR BSP CONNECTIONS
Hose Inlet Kits for LD Enclosed Hose Reel
Part
Number
Hose Inlet
Description
24C437
Air
24C438
Grease
24C445
24C537
24C538
24C539
HEL25D
HEM23D
24C442
HEH13D
5,000 (345)
1/4 bspt(m)
1/4 bspt(m)
1/2 (12)
1/2 bspt(m)
3/8 bspt(m)
1/4 bspt(m)
1/4 bspt(m)
1/4 npt(m)*
1/4 npt(m)*
36 in (915)
1/4 (6)
250 (17.2)
HEL23D
3/8 (10)
HEL25D
3/8 npt(m)*
1/2 (12)
HEM23D
HEH13D
1/2 npt(m)*
1/2 npt(m)*
3/8 (10)
1,800 (124)
HEM33D
Grease
1/4 (6)
1/4 (6)
HEL15D
Oil
Hose Outlet
in
1/2 bspt(m)
HEL13D
Air/water
Hose Inlet
in
1,800 (124)
HEM33D
Air
Length
in (mm)
250 (17.2)
HEL23D
Air/ water
Oil
24C444
Hose id
in (mm)
HEL13D
HEL15D
24C440
24C443
Pressure
psi (bar)
Fits Reel
Hose Inlet Kit for
LD enclosed reels
3/8 npt(m)*
1/2 (12)
5,000 (345)
1/2 npt(m)*
1/4 (6)
1/4 npt(m)*
1/4 npt(m)*
* NPT hose connection when using BSP to NPT adapter (included)
Reel Enclosures
• Designed for enclosing SD single pedestal reels
• Enclosures provide protection to extend the life of hoses and bearings
Part Numbers by Color
Enclose Kits for
One Reel
White*
Metallic Blue
Red
Black
Dark Blue
Yellow
Size 10 Enclosure
24A217
24A940
24A941
24A942
24A943
24A944
Size 20 Enclosure
24A218
24A945
24A946
24A947
24A948
24A949
Size 10 End Caps (2)
–
–
–
24A950
–
–
Size 20 End Caps (2)
–
–
–
24A951
–
–
* White enclosures available for immediate shipment. Consult factory for lead-time for other colors.
Mounting Channels
Enclosure mounting channels accommodate one, two, three, four, five or six reels
(includes all parts needed to mount hose reels to walls or ceilings)
Mounting Channel
Description
1 Reel
2 Reels
3 Reels
4 Reels
5 Reels
6 Reels
SD10 and SD20*
24A934
24A935
24A936
24A937
24A938
24A939
XD10 and XD20
24A219
24A220
24A221
—
—
24A222
Enclosure Kit
203521
203522
203523
203524
203525
203526
Mounting Channel
Mounting Bracket
* For use without enclosure kit
56
LUBR IC A T ION E QU IP M EN T ❚ H O S E R E E L S
www.graco.com
Accessories
For SD, XD, 700 and 750 Series Reels
Ordering Information
Retrofit Adapter Kits
24A224
Includes all parts to mount hose reel to existing 500 series mounting pattern
24C100
Includes all parts to convert SD10 hose reels to fit existing 250 series enclosures
Mounting Bracket
Retrofit Bracket to 500 Series
Ball Stop Kit
204741
Secures mounting channel to I-beam without drilling. Two brackets are required for 1-3 hose
reels; three brackets for 4-6 hose reels.
Ball Stop Kits
Typical Hose id
222225*
For 1/4 in (6.4 mm) i.d. hose
218340*
For 1/4-3/8 in (6.4-9.5 mm) i.d. hose
218341*
.782 ID used for 3/8 in and 1/2 in 9.5 mm and 12.7 mm) hose
237872
1.0 ID used for 5/8 in (15.9 mm) hose
237873
1.123 ID used for 3/4 in (19.1 mm) hose
237874
1.374 ID used for 1 in (25.4 mm) hose
24D132
For 3/8 in (9.5 mm) o.d. hose
24D133
For 1/2 in (12.7 mm) o.d. hose
Hose Inlet Kit for SD and
XD open reels
Hose Inlet Kits for SD
and XD Reels
Description
Pressure
psi (bar)
Hose id in
(mm)
Length
in (mm)
Hose
Inlet
218549
Low /medium pressure
2000 (137)
1/2 (12)
24 (610)
npt(m)
218550
High pressure
4000 (276)
3/8 (10)
24 (610)
npt(m)
222417
High pressure
5000 (345)
1/4 (6)
24 (610)
npt(m)
Medium-Pressure Oil Dispense Reels (rated to 1500 psi/103 bar)
218591
Hose Roller Repair Kit
Valve Hanger Kit
224444
Mounts to side of reel to allow hanging of non-metered and high flow dispensing valves
Metal Label Kits (includes one 3/4 in x 4-1/4 in (1.9 cm x 10.8 cm) metal label and mount)
218670
Motor Oil
218675
Air
218671
Grease
218676
Water
218672
Gear Lube
218677
Anti-Freeze
218673
ATF
218678
Evacuation
218674
Hydraulic Oil
Hose Reels and Packages
*Not for use with XD30, 700 or 750 reels
Self Adhesive Identification Label Set
237944
180698
Set includes: 1 in x 5 in (25.4 mm x 127 mm) hose reels labels for Anti-Freeze, Water, SAE 5-40,
SAE 10-40, SAE 20W, Hydraulic, Gear, SAE 10W, SAE 10-30, SAE 30W, Dexron, Air, Chassis, ATF
237932*
Overhead mounting kit includes all parts needed for ceiling-mounting reel. (one required per reel.)
237944*
Roller support kit includes roller support accessories for ceiling mounted reels (reel not included).
109064
Hose inlet kit 1 (mbe) x 28 in (71 cm)
*Required for overhead mounting
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ HOSE REEL S
57
Dispense Consoles
Multi-Station Consoles*
Six-Station Console
222629
Includes upper and lower floor plates with roller guides and brackets (1-110236; 5-196471) to hold one
water bib and five Graco LDM dispense valves. Console Dimensions (without brackets): 27 in high x 54 in
long x 12 in wide (68.58 cm high x 139.7 cm long x 25.4 cm wide) Console requires a floor opening of 6 in
x 51 in (15.2 cm x 122.4 cm)
Four-Station Console
223448
Includes upper and lower floor plates, roller guides and brackets (1-110236; 3-196471) to hold one water
bib and three Graco LDM dispense valves. Console Dimensions (without brackets): 27 in high x 36 in long x
12 in wide (68.58 cm high x 139.7 cm long x 25.4 cm wide) Console requires floor opening of 6 in x 33 in
(15.2 cm x 83.8 cm).
Single Add-On Fluid Module
222645
For adding-on to four- or six-station consoles. Includes add-on module, floor plates with roller guides to fit
module and one 196471. Console requires floor opening of 6 in x 8-1/2 in (15.2 cm x 21.6 cm). Add-on
fluid module dimensions 27 in high x 9 in long x 10 in wide (68.5 cm high x 22.86 cm long x 25.4 cm wide).
222629
*Hoses not included. See ordering information on page 140
Dispense Consoles
Lubricant Dispense Consoles Accessories
110236
Water Bib Bracket
110237
EM6 Mounting Bracket
110285
Pistol-Grip Dispense Valve Bracket
196471
Universal Dispense Valve Bracket for EM5 and PM5
249440
Matrix Dispense Valve Bracket
222641
Console Roller Repair Kit (upper)
218591
Floor Plate Roller Repair Kit (lower)
178670
Roller only
234423
End Panel Replacement comes with 8 screws
Oil Dispense Bar
220107
Tough metal cabinet with baked-on enamel finish. Constructed with single-dispense tap and waste pan
with plated, perforated metal service area and drain connection. Modular convenient design allows up to 2
oil dispense taps or 3 meters to be added at the time of installation, or later if required. Instruction manual
307742. Maximum working pressure 900 psi (62 bar). 22.6 in H x 13.25 in D x 18.3 in W (57.4 cm H x
33.7 cm D x 46.5 cm W)
Tap Kit
220112
Add to oil dispense bar to convert into two or three taps, as needed. Kit also includes non-drip dispense
valve, manifold and all necessary mounting hardware.
220107
Meter Kit
239706
Any individual tap on the oil dispense bar can be fitted with a fluid meter. Kit includes meter #239824 and
all necessary mounting hardware. Maximum working pressure 500 psi (34 bar).
220110
Spigot Valve Replacement
Console Roller
222641
Floor Plate Roller
218591
58
LUBR IC A T ION E QU IP M EN T ❚ H O S E R E E L S
234423
222629
222645
www.graco.com
LD Series Electronic Meters
Dispense Meters and Control Valves
Features and Benefits
• Manual and Preset Dispense
• Dispenses in gallons, quarts, pints and liters
• Easy to read LCD display with durable switches for long life
• Rugged engineered material for superior impact resistance
and long life
• Ergonomically-designed handle for optimum comfort
• Standard rigid extension kit and automatic thermal
compensating nozzle
• Optional extensions available
LDM5 Manual Dispense Meter
Two Models to Choose From
• LDM5 with inlet boot, trigger guard and rigid extension with
thermal compensating nozzle
• LDM5 with flexible extension and automatic nozzle
LDP5 Preset Dispense Meters
• LDP5 preset dispense model with inlet boot, trigger guard and
rigid extension with thermal compensating nozzle
• LDP5 preset dispense model with flexible extension and
automatic nozzle
Typical Applications
• Metered oil dispense
• Heavy-duty dealerships
• Fleet service facilities
• For indoor use only
• Automotive dealerships
• Fast lube centers
• Service shops
• In-plant
Typical Fluids Handled
256215
258693
Technical Specifications
Flow Range(1) ........................................................... 0.1 to 5 gpm (0.4 to 19 lpm)
Maximum Working Pressure .......................................................1000 psi (69 bar)
Units of measure........................ Quarts, pints, gallons, liters (factory set to quarts)
Weight .......................................................................................... 3 lb (1.36 kg)
Inlet .................................................................................................... 1/2 in npt
Outlet .................................................................................................. 1/2 in npt
Operating Temperature Range........................................ 32 to 120ºF (0 to 48.8ºC)
Storage Temperature Range................................... -30 to 120ºF (-34.4 to 48.8ºC)
Battery .......................................................................................... 9 volt alkaline
Battery Life ............................................................................................ one year
Wetted Parts........................................................... sst, nitrile rubber, zinc, cs, lcp
Meter Pressure Loss(1) ................................................................ 90 psi @ 5 gpm
Accuracy(2) ............................................................................................... ±0.5%
Dimensions (without extension) ................................. 11 in L x 3.25 in W x 3.25 H
......................................................................... (28 cm L x 8.3 cm W x 8.3 cm H)
Maximum Totalizer ......................................................... 999,999 gallons or liters
Maximum Recorded Dispense.......................................... 999.9 Units (LDP5 only)
Warranty ............................................................................................. Two Years
Instruction Manual ................................................................................. 312668
255751
258694
256216
(1) Tested in 10W oil at 70ºF. Flow rates vary with fluid pressure, temperature,
viscosity, inlet fitting and nozzle type.
(2) @ 2.5 gpm (9.5 lpm) @ 70ºF (21ºC) with 10 wt. oil and 1 gal (3.8 l)
dispensed.
May require re-calibration. Out-of-box accuracy ±1.25%.
Not recommended for in-line installation.
255277
Ordering Information
LDM5 Manual Dispense Meters
LDP5 Preset Dispense Meters
255751
1/2 in npt(f) swivel, flexible extension and automatic nozzle for oil
and anti-freeze
255277
1/2 in npt(f) swivel, flexible extension and automatic nozzle for oil
and anti-freeze
256215
1/2 in npt(f) swivel, rigid extension, trigger guard/boot and automatic
nozzle for oil and anti-freeze
256216
1/2 in npt(f) swivel, rigid extension, trigger guard/boot and automatic
nozzle for oil and anti-freeze
258693
1/2 in npt(f) swivel, flexible extension, trigger guard/boot and
automatic nozzle for oil and anti-freeze
258694
1/2 in npt(f) swivel, flexible extension, trigger guard/boot and
automatic nozzle for oil and anti-freeze
www.graco.com
Dispense Meters and Control Valves
• Petroleum and synthetic based oils
• Anti-freeze
LUBRIC AT ION E QUIP M E NT ❚ DIS P E NS E M E T E RS AND C ONTROL VAL VES
59
SD Series Electronic Meters
Dispense Meters and Control Valves
Features and Benefits
Dispense Meters and Control Valves
• Fluid inlet options (½ in and ¾ in npt) meets standard and
high-flow requirements
• Large LCD display and simple operator controls
– Adjusts for easy reading in all lighting conditions
– Calibration easily adjusts from keypad
• Solid construction to stand up to harsh environments and provide
years of trouble-free performance
– Locking trigger (LDP5 models)
– Durable cast trigger guard prevents accidental triggering
• Flush-mount nozzle valve design prevents leaks and contamination
• Designed for no leak performance
Typical Applications
Ordering Information
• Metered oil dispense in demanding environments
• Automotive dealerships
• Heavy-duty dealerships
• Fast lube centers
• Fleet service facilities
• Service shops
• In-plant
• Lube Trucks
• Mining
SDM5 MANUAL DISPENSE ELECTRONIC METER, 5 GPM OR LESS
255350
1/2 in npt(f) swivel, rigid oil extension with standard automatic
non-drip quick-close nozzle
255348
1/2 in npt(f) swivel, flexible oil extension with standard automatic
non-drip quick-close nozzle
255349
1/2 in npt(f) swivel, gear lube extension with standard quick-close
nozzle
255802
1/2 in npt(f) swivel, rigid anti-freeze extension with standard
quick-close nozzle
255803
1/2 in npt(f) swivel, flexible anti-freeze extension with standard
quick-close nozzle
SDM15 MANUAL DISPENSE ELECTRONIC METER, 14 GPM OR LESS
Typical Fluids Handled
256836
• Petroleum and synthetic based oils
• Anti-freeze
1/2 in npt(f) swivel, rigid oil extension with high flow, quick-close
nozzle
256837
1/2 in npt(f) swivel, flexible oil extension with high flow, quickclose nozzle
255800
3/4 in npt(f) swivel, rigid oil extension with high flow, quick-close
nozzle
255801
3/4 in npt(f) swivel, flexible oil extension with high flow, quickclose nozzle
Technical Specifications
Flow Range (1) ......................................................... 0.1 to 14 gpm (0.4 to 53 lpm)
Maximum Working Pressure ..................................................1500 psi (103.4 bar)
Weight ............................................................................................5 lbs (2.3 kg)
Inlet ................................................................. 3/4 in – 14 npt or 1/2 in – 14 npt
Outlet ........................................................3/4 in – 16 straight thread O-ring Boss
Maximum Totalizer .......................................................... 999,999 gallons or liters
Maximum Recorded Dispense............................................................. 999.9 Units
Maximum Pre-Set Volume .................................................................. 999.9 Units
Storage Temperature Range........................................-40º to 158ºF (-40º to 70ºC)
Operating Temperature Range........................................ 4º to 158ºF (-20º to 70ºC)
Battery ..................................................................... 4 AA alkaline or 4 AA lithium
Battery Life (3) . . . Preset Models – six months with alkaline, manual models – one
year with alkaline 4 AA alkaline or lithium
Wetted Parts..............................................Aluminum, sst, pbt/pc, nitrile rubber, cs
Meter Pressure Loss (1) .......................................................................... +/- 0.5%
Accuracy (2) ........................................................................................... +/- 0.5%
Dimension w/o Extension13 in L x 3.75 in W x 5.75 in H, (33cm x 9.5cm x 14.6cm)
Warranty ................................................ Five years overall, three years electronics
Instruction Manual .................................................................................. 312865
1. Tested in 10W oil at 70ºF. Flow rates vary with fluid pressure, temperature, viscosity, inlet and nozzle type.
2. At 2.5 gpm (9.5 lpm) @ 70ºF (21ºC) with 10 wt. oil and 1 gal (3.8 l) dispensed. May require re-calibration.
Out-of-box accuracy ±1.25%.
3. Average shop use with alkaline batteries (included); 30-35% longer life with lithium AA.
60
255350
SDP5 PRESET DISPENSE ELECTRONIC METER, 5 GPM OR LESS
255200
1/2 in npt(f) swivel, rigid oil extension with standard automatic
non-drip quick-close nozzle
255351
1/2 in npt(f) swivel, flexible oil extension with standard automatic
non-drip quick-close nozzle
255352
1/2 in npt(f) swivel, gear lube extension with standard quick-close
nozzle
255355
1/2 in npt(f) swivel, rigid anti-freeze extension with standard
quick-close nozzle for anti-freeze
255356
1/2 in npt(f) swivel, flexible anti-freeze extension with standard
quick-close nozzle for anti-freeze
SDP15 PRESET DISPENSE ELECTRONIC METER, 14 GPM OR LESS
256838
1/2 in npt(f) swivel, rigid oil extension with high flow, quick-close
nozzle
256839
1/2 in npt(f) swivel, flexible oil extension with high flow, quickclose nozzle for oil
255353
3/4 in npt(f) swivel, rigid oil extension with high flow, quick-close
nozzle for oil
255354
3/4 in npt(f) swivel, flexible oil extension with high flow, quickclose nozzle for oil
LUB R ICA T ION E QU IP M EN T ❚ DISPENSE METERS AND CONTROL VALVES
www.graco.com
EM6™ Electronic Meter
Dispense Meters and Control Valves
Features and Benefits
• Screw-tight nozzle for positive shut off
• Ball bearing swivel for ease of use
• Durable design ideal for use in harsh environments
• Reset capable for periodic dispense history information
Typical Applications
• Metered oil dispense in demanding environments
• Automotive dealerships
• Heavy-duty dealerships
• Service and fast lube centers
• Fleet service facilities
• In-plant
• Lube Trucks
• Mining
Typical Fluids Handled*
• Petroleum and synthetic based oils
Ordering Information
Technical Specifications
EM6 Electronic Meters
Maximum Recommended Flow Rate .........................................6 gpm (23.01 lpm)
Maximum Operating Pressure ......................................... 1500 psi (105 bar, 10.5,)
Operating Temperature Range.....................................-40º to 180ºF (-40º to 82ºC)
Storage Temperature Range........................................-40º to 140ºF (-40º to 60ºC)
Inlet .........................................................................................................1/2 npt
Outlet .......................................................................................................1/2 npt
Wetted Parts............................aluminum, SST, CS, acetal, nitrile rubber, Geolast™
Instruction Manual .................................................................................. 308642
Accuracy/Repeatability .......................................................................... +/- 0.6%
243599
U.S. measure (rigid extension)
243600
U.S. measure (gear lube extension)
243601
U.S. measure (flexible extension)
243602
Metric measure (rigid extension)
243603
Metric measure (gear lube extension)
243604
Metric measure (flexible extension)
243992
1/2 in (12.7 mm) bare valve (without locking trigger)
Geolast™ is a registered trademark of Advanced Elastomer Systems.
Accessories
235878
U.S. Electronic Control Replacement
235901
Metric Electronic Control Replacement
203655
Twist Lock Nozzle Replacement 1/4 npt(m)
203687
Flex Extension, hose with 203655 tip
201701
Gear Lube Extension with tip
203265
Rigid Extension with tip
Color-coded Impact Guards for Electronic Meters
Color-code various fluids dispensed to reduce errors, match store colors, or
create a customized appearance. For electronic meters only.
191782
Black
191783
Red
191784
Blue
191785
Green
235878
Dispense Meters and Control Valves
243599
* Not recommended for use with anti-freeze or windshield washer fluid
243392
191782
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ DIS P E NS E M E T E RS AND C ONTROL VAL VES
61
EM12™ Electronic Meter
Dispense Meters and Control Valves
Features and Benefits
• Locking trigger for hands-free operation
• High-flow capability provides up to 12 gpm (45 lpm)
• Rugged design withstands demanding environments
• Reset capable for periodic dispense history information
Typical Applications
• Automotive and Heavy-Duty dealerships
• Service and fast lube centers
• Fleet service facilities
• In-plant
• Lube Trucks
• Mining
Typical Fluids Handled*
238641
• Petroleum and synthetic based oils
Dispense Meters and Control Valves
* Not recommended for use with anti-freeze or windshield washer fluid
Ordering Information
Technical Specifications
EM12 Electronic Meters with 3/4 in npt(f) swivel inlet
Maximum Recommended Flow Rate .........................................12 gpm (45.4 lpm)
Maximum Operating Pressure ...................................................1500 psi (105 bar)
Operating Temperature Range.......................................-4º to 130ºF (-20º to 55ºC)
Storage Temperature Range........................................-40º to 140ºF (-40º to 60ºC)
Inlet ...................................................................................... 1/2 npt and 3/4 npt
Outlet .......................................................................................................1/2 npt
Wetted Parts................................aluminum, SST, CS, acetal, nitrile rubber, Geolast
Instruction Manual .................................................................................. 308642
238636
U.S. measure 1/2 in (12.7 mm) rigid extension
238637
U.S. measure 1/2 in (12.7 mm) flexible extension
238638
Metric measure 1/2 in (12.7 mm) rigid extension
238639
Metric measure 1/2 in (12.7 mm) flexible extension
EM12 Electronic Meters with 1/2 in npt(f) swivel inlet
238640
U.S. measure 1/2 in (12.7 mm) rigid extension
238641
U.S. measure 1/2 in (12.7 mm) flexible extension
238642
Metric measure 1/2 in (12.7 mm) rigid extension
238643
Metric measure 1/2 in (12.7 mm) flexible extension
Bare Valves with locking trigger (No meter or extension)
238647
Inline flow through with 1/2 npt(f) swivel inlet and outlet
238646
Inline flow through 3/4 npt(f) swivel inlet; 1/2 npt(f) outlet
Accessories
235878
U.S. Electronic Control Replacement
235901
Metric Electronic Control Replacement
223920
High Flow Twist Lock Nozzle, 1/2 npt(f) with 1 in diameter tip.
238400
Automatic Nozzle 1/2 npt(f) with 1 in diameter tip
185416
Filter 40 mesh stainless steel
Color-coded Impact Guards for Electronic Meters
For color-coding fluids dispensed to reduce errors, match store colors, or to
protect vehicles finish. For electronic meters only.
191782
191782
238647
223920
Black
Red
62
191784
Blue
190386
Green
LUB R ICA T ION E QU IP M EN T ❚ DISPENSE METERS AND CONTROL VALVES
www.graco.com
In-Line Electronic Meters
Dispense Meters and Control Valves
IM5 Low Pressure Meter
• Heavy-duty construction for outdoor use
• Easy-to-use meter dispenses pints, quarts, liters or gallons
• Easy-to-replace 9-volt alkaline battery
• Compatible with windshield wash solvent or anti-freeze
Typical Applications
IM6 and SDI15
Medium/High Pressure Meters
• Reset capable for periodic dispense history information
• Durable design ideal for rugged environments
• Easy-to-use meter dispenses pints, quarts, liters or gallons
• Shock-resistant durability
Typical Applications
• Automotive dealerships
• Fast lube centers
• Service shops
• In-plant
• Automotive and large truck dealerships
• Fast lubes and service shops
• Fleet service facilities
• In-plant
• Lube trucks (IM6 only)
• Mining
Typical Fluids Handled
• Petroleum and synthetic based oils
• Anti-freeze
• Windshield wash fluid
Typical Fluids Handled*
• Petroleum and synthetic based oils
* Not recommended with anti-freeze or windshield wash
Ordering Information
IM5 In-Line Meter
IM5 In-Line Meter
IM6 In-Line Electronic Meter
244075
In-Line Meter (U.S.)
244076
In-Line Meter (Metric)
235878
Replacement
Electronics (U.S.)
235901
Replacement
Electronics (Metric)
SDI15 In-Line Electronic Meter
247453
In-Line Meter (U.S.)
244075
239824
247453
Technical Specifications
Flow Range*
Max. Working Pressure
Weight
IM5 In-Line Meter
IM6 In-Line Meter
SDI15 In-Line Meter
0.5 to 5 gpm (1.9 to 19 lpm)
0.12 to 12.0 gpm (0.46 to 45.6 lpm)
0.1 to 14 gpm (0.4 to 53 lpm)
500 psi (34 bar)
1500 psi (103 bar)
1.8 lb (0.8 kg)
1.9 lb (0.95 kg)
Units of Measurement
Accuracy
1.8 lb (0.82 kg)
Quarts, pints, gallons, liters (factory-set to quarts)**
± 0.5%
± 1.0%
Operating Temperature Range
-4 to 122ºF (-20 to 50ºC)
-4º to 130ºF (-20º to 55ºC)
-4 to 122ºF (-20 to 50ºC)
Storage Temperature Range
-13 to 122ºF (-25 to 50ºC)
-40º to 140ºF (-40º to 60ºC)
-13 to 122ºF (-25 to 50ºC)
Inlet/Outlet
Battery
Wetted Parts
Instruction Manual
± 0.5%
1/2 npt*
9-volt, alkaline
Dispense Meters and Control Valves
239824
2AA alkaline
nickel, zinc, zenite, nitrile rubber
aluminum, carbon steel, nitrile rubber,
nickel, bronze, SST #304, cast ALNICO 8
aluminum, carbon steel, nitrile rubber,
nickel, bronze, SST, Geolast
306687
307965
313048
*Tested with number 10 motor oil. Flow rates vary with fluid pressure and viscosity.
**Display shows quantity in 0.01 increments up to 999.99 gallons, quarts, pints, or liters. Totalizes in gallons or liters up to 99,999 units.
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ DIS P E NS E M E T E RS AND C ONTROL VAL VES
63
Mechanical Meters
Dispense Meters and Control Valves
Features and Benefits
• Balanced, lightweight, rugged construction, and comfortable grip
• Non-resettable totalizing register helps manage material usage
• Handles a variety of petroleum and synthetic based oils and anti-freeze
• Ideal for indoor and outdoor use
Typical Applications
• Automotive dealerships
• Heavy-duty dealerships
• Fast lube centers
• Fleet service facilities
• In-plant
• Lube trucks
• Mining
207738
Typical Fluids Handled
• Petroleum and synthetic based oils and anti-freeze
Dispense Meters and Control Valves
Technical Specifications
Maximum Flow* .................................................... 4 gpm (15.1 lpm)
Minimum Flow*.................................................... 0.4 gpm (1.5 lpm)
Maximum Operating Pressure ............................. 1000 psi (68.9 bar)
Operating Temperature Range ........... -40ºF to 140ºF (-40ºC to 60ºC)
Accuracy .......................................................................... ± 0.65%
Weight ...................................................................... 6.0 lb (2.7 kg)
Inlet and outlet connections ............................................... 1/2 npt(f)
For use with petroleum-based fluids only.
*Tested with Mobil® DTE-25 motor oil. Minimum/maximum flow rates will vary with fluid viscosity.
Ordering Information
256786
Manual Meters
256556
16 Quart Meter with flexible extension and twist lock nozzle
253601
10 Liter Meter with flexible extension and twist lock nozzle
256786
16 Quart Meter with rigid extension and twist lock nozzle
256788
10 Liter Meter with rigid extension and twist lock nozzle
256787
16 Quart Meter with gear lube extension and automatic nozzle
256789
10 Liter Meter with gear lube extension and automatic nozzle
Preset Meters
207738
60 Quart Meter valve with rigid extension and automatic nozzle
207739
60 Gallon Meter valve with rigid extension and automatic nozzle
207742
60 Liter Meter valve with rigid extension and automatic nozzle
256787
Nozzles
255459
Quick-close nozzle only for oil
255460
Quick-close nozzle only for anti-freeze
255470
Quick-close nozzle only for gear lube
253601
64
LUB R ICA T ION E QU IP M EN T ❚ DISPENSE METERS AND CONTROL VALVES
www.graco.com
Accessories
Dispense Meters and Control Valves
LDM and LDP Accessories
Nozzle Extension Kits
255861
Automatic nozzle with flexible extension for oil and anti-freeze*
239949
Automatic thermal compensating nozzle with rigid extension for oil and anti-freeze
239951
Automatic thermal compensating nozzle with flexible extension for oil and anti-freeze
239950
Automatic thermal compensating nozzle with rigid extension for gear lube
239829
Automatic thermal compensating nozzle for oil and anti-freeze without extension
238371
Automatic thermal compensating gear lube nozzle without extension
255861
239949
*Economical extension used on model 255751
Additional LDM5 Accessories
Inlet Swivel
114017
Inlet Filter, 80 mesh
196471
Valve Bracket for Dispense Console
240453
Valve Repair Kit
238555
Electronic Cover Control Assembly Kit
239951
Swivel Covers
Protective Boots with Trigger Guard
191294*
Black
247759*
Black
191287
Red
243835
Red
191288
Blue
243836
Blue
191289
Green
243837
Green
191295
Yellow
247760
Yellow
239950
247759
*Included on meter 256215
SDM and SDP Accessories
191294
Nozzle Extension Replacement Kits For SD Series Meters
255852
Automatic non-drip quick-close nozzle with rigid extension for oil
255853
Automatic non-drip quick-close nozzle with flexible extension for oil
255854
Non-drip quick-close nozzle with rigid extension for gear lube
255855
Non-drip quick-close nozzle with rigid extension for anti-freeze
255856
Non-drip quick-close nozzle with flexible extension for anti-freeze
255459
Automatic non-drip quick-close nozzle only for oil
255460
Quick-close nozzle only for anti-freeze
255470
Quick-close nozzle only for gear oil
255857
Non-drip quick-close high-flow nozzle with rigid extension for oil and anti-freeze
255858
Non-drip quick-close high-flow nozzle with flexible extension for oil and anti-freeze
255461
Quick-close high-flow nozzle only for oil and anti-freeze
255852
255853
255470
Swivel Covers
15T366
Black swivel cover (standard color with meter)
15T367
Red swivel cover
15T368
Blue swivel cover
15T369
Green swivel cover
15T370
Yellow swivel cover
Dispense Meters and Control Valves
240416
255461
Filter Kits for SD Series Meters
255885
Filter kit includes (10) filters/strainers (15M308), (10) spacers (15M309) and (10) O-rings (155332)
15T366
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ DIS P E NS E M E T E RS AND C ONTROL VAL VES
65
SDV15 Control Valve
Dispense Meters and Control Valves
Features and Benefits
• Moves fluid up to 15 gpm (56.8 lpm) (15 gpm obtained with
high-flow nozzle–purchased separately)
• Sturdy cast body designed for use in tough environments
• Lock-on trigger
• 1/2 in npt(f) inlet with built-in ball bearing swivel allows for
ergonomic operation
• Inlet screen aids in keeping fluids clean
Typical Applications
• Automotive dealerships
• Heavy-duty dealerships
• Fast lube centers
• Fleet service facilities
• Service shops
• In-plant
• Lube trucks
• Mining
Dispense Meters and Control Valves
Typical Fluids Handled
66
• Dispenses motor oils
• Transmission fluid,
• Anti-freeze
247712
Technical Specifications
Maximum Recommended Flow Rate ........................................ 15 gpm (18.9 lpm)
Maximum Operating Pressure ...................................................1500 psi (103 bar)
Weight ....................................................................................... 0.4 lb (0.18 kg)
Operating Temperature Range...................................-40º to 180º F (-40º to 82º C)
Inlet ........................................................................................................ 1/2 npt
Outlet ......................................................... 3/4 in, 16 straight thread O-ring boss
Wetted Parts........................................Aluminum, sst, cs, acetal, nitrile rubber, tpe
Warranty ............................................................................................. Five years
Instruction Manual ................................................................................. 312789
1. Tested in 10W oil at 70ºF. Flow rates vary with fluid pressure, temperature, viscosity, inlet fitting and
nozzle type.
Ordering Information
SDV15 Control Valves
247712
1/2 in npt(f) swivel, locking open trigger, rigid extension and standard automatic non-drip quick-close nozzle for oil products
247713
1/2 in npt(f) swivel, locking open trigger, flexible extension and |standard automatic non-drip quick-close nozzle for oil products
247714
1/2 in npt(f) swivel locking open trigger, gear lube extension and standard quick-close nozzle
247715
1/2 in npt(f) swivel locking open trigger, rigid extension and standard quick-close nozzle for anti-freeze
247716
1/2 in npt(f) swivel locking open trigger, flexible extension and standard quick-close nozzle for anti-freeze
Bare Valve (no extension)
247717
1/2 in npt(f) swivel locking open trigger, 3/4 in - 16(f) straight thread O-ring boss outlet, and trigger lock, no extension
Accessories
256164
Filter kit includes (10) filters/strainers (185416)
255459
Quick-close nozzle only for oil
255460
Quick-close nozzle only for anti-freeze
255470
Quick-close nozzle only for gear lube
255857
Non-drip quick-close high-flow nozzle with rigid extension for oil and anti-freeze
255858
Non-drip quick-close high-flow nozzle with flexible extension for oil and anti-freeze
255461
Quick-close high-flow nozzle only for oil and anti-freeze
LUB R ICA T ION E QU IP M EN T ❚ DISPENSE METERS AND CONTROL VALVES
www.graco.com
XDV20 Control Valve
Dispense Meters and Control Valves
Features and Benefits
• Moves fluid up to 20 gpm (76 lpm)
• Lock-on lock-off trigger for hands-free operation
• Rugged cast-body design withstands harsh environments
• Built-in ball bearing swivel allows for ergonomic operation
• Inlet screen aids in keeping fluids clean
Typical Applications
• High-flow, non-metered oil dispense
• Automotive dealerships
• Heavy-duty dealerships
• Fast lube centers
• Fleet service facilities
• In-plant
• Lube trucks
• Mining
247722
Typical Fluids Handled
Maximum Recommended Flow Rate ........................................ 20 gpm (45.4 lpm)
Maximum Operating Pressure .................................................. 1500 psi (105 bar)
Assembly Weight (no meter) ........................................................ 0.4 lb (0.18 kg)
Operating Temperature Range.................................. -40º to 180º F (-40º to 82º C)
Inlet ..................................................................................... 1/2 npt and 3/4 npt
Outlet .............................................................. 7/8-14 straight thread o-ring boss
Wetted Parts............................................................... aluminum, SST, CS, acetal,
.......................................................................................... nitrile rubber, Geolast
Instruction Manual ................................................................................. 308642
247724
Ordering Information
XDV20 Control Valves
247718
1/2 npt(f) swivel inlet, 1/2 in (12.7 mm); rigid extension
247721
1/2 npt(f) swivel inlet, 1/2 in (12.7 mm); flexible extension
247722
3/4 npt(f) swivel inlet, 1/2 in (12.7 mm); rigid extension
247723
3/4 npt(f) swivel inlet, 1/2 in (12.7 mm); flexible extension
Dispense Meters and Control Valves
Technical Specifications
• Dispenses motor oils
• Transmission fluid
• Anti-freeze
Bare Valves (no extension)
247724
Has locking trigger and in-line flow through 1/2 npt(f) swivel inlet; 1/2 npt(f) outlet
247725
Has locking trigger and in-line flow through 3/4 npt(f) swivel inlet; 1/2 npt(f) outlet
Accessories
255793
Quick-close high flow nozzle for oil, ATF and anti-freeze; 7/8-14 ORB (XDV20 only)
255859
Flex extension with quick-close nozzle (255793) for XDV20
255921
Rigid extension with quick-close nozzle (255793) for XDV20
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ DIS P E NS E M E T E RS AND C ONTROL VAL VES
67
Grease Dispense Valves
Dispense Meters and Control Valves
Pro Shot™ Non-Metered Grease Valves
• Rugged design for harsh environments
• Pressure-assisted trigger for ease of operation
• Easy top adjustment with locking nut
• Pro-Shot adjustment nut protected by rigid guard
Typical Applications
• Service shops
• Heavy-duty dealerships
• Fast lube centers
• Automotive dealerships
• In-plant
• Lube trucks
• Mining
242056
Typical Fluids Handled
• Grease up to NLGI #2
Ordering Information
Dispense Meters and Control Valves
Pro-Shot Grease Dispense Valve
242056
1/4 npt(f) inlet with coupler and extension #200389
242055
1/4 npt(f) inlet without coupler or extension
242058
3/8 npt(f) inlet with coupler and extension #200389
242057
3/8 npt(f) inlet without coupler or extension
224872
Includes 30 in (76.2 cm) whip hose #109148, Z-Swivel #202577 and grease valve #242056.
Accu-Shot™ Metered Grease Valves
• Accurate grease metering within ±3%
• Easy to read LCD display
• Handles pressure up to 5000 psi and flow up to 36 oz/min
Typical Applications
• Lube trucks
• Heavy-duty dealerships
• In-plant
• Fleet service facilities
• Mining
233807
Typical Fluids Handled
• Grease up to NLGI #2
Ordering Information
Accu-Shot Electronic Metered Grease Valve
68
233807
U.S. Measurement Includes extension and hydraulic coupler
233933
Metric Measurement Includes extension and hydraulic coupler
LUB R ICA T ION E QU IP M EN T ❚ DISPENSE METERS AND CONTROL VALVES
www.graco.com
Manual Grease Guns and Fittings
Grease Guns, Accessories and Fittings
Ordering Information
Grease Guns
202600
1/8 npt(f) Power-Shot Booster Gun boosts incoming pressure up to 18,000 psi (1,242 bar). Use with any
high-pressure lubricator. Maximum inlet pressure: 5000 psi (345 bar). Includes nozzle (200389). (Hose
swivel #202579 must be ordered separately). Instruction Manual: 306271.
110218
Standard Lever-Action Grease Gun: Develops up to 6000 psi (400 bar) working pressure and pumps
1.8 oz. (51 g) per 40 strokes. Can be loaded via cartridge or bulk fill. Optional loader fitting available.
Equipped with rigid extension and hydraulic coupler.
110216
Heavy-Duty Lever-Action Grease Gun with high-pressure variable low-volume. Three-way loading: bulk
fill, loader fitting or 14 oz. cartridge. Pumps 1.24 oz. per 40 strokes. Includes air bleeder valve. Equipped
with rigid extension and hydraulic coupler (M IL-G-3859). Can develop up to 10,000 psi. Comes with
236171, easy fill valve.
110203
Pistol-Matic Grease Gun with three-way loading: bulk fill, loader fitting or cartridge. Pumps .72 oz. (28.4
g) per 40 strokes. Includes air bleeder valve. Equipped with rigid extension and hydraulic coupler. Can
develop up to 3500 psi
203697
1/8 npt(f) Hot-Shot Portable Booster Gun for portable operation without continuous connection to grease
supply. Has 4 oz. (113 g) grease reservoir in handle capable of servicing up to 100 fittings before
needing a refill. Has grease fitting for recharging from either manual or air-powered luber. Single-hand
operation squeeze handle develops up to 10,000 psi (690 bar). Includes grease extension and nozzle
#200389. Instruction Manual: 306460.
110202
Pistol-Matic Grease Gun is the same as #110203 but with 12 in (30.4 cm) flexible rubber hose and
hydraulic coupler.
112196
1/4 npt Pistol-Style Air-Operated Grease Gun is a spring-primed, single-shot gun. Three-way loading:
bulk fill, loader fitting or 14 oz. (400 g) cartridge. Air input range of 75 to 100 psi (5 to 7 bar); working
pressure of 6000 psi (414 bar). Pumps 1.2 oz. (34 g) per 40 pulls at 100 psi (7 bar). Includes standard
gun coupler and bleeder valve, 1/8 in-27 NPT rigid extension. (1/4 npt air input connection).
110201
Suction Gun for evacuating and filling fluids into gear housings, differentials, transmissions and related
applications. Holds 1 pint (16 oz, 473 cc), comes with red clear plastic 12 in (30.4 cm) hose.
202600
110218
110216
110203
202579
1/8 npt(m) x 1/4 npt(f) free-ball bearing
202577
1/4 npt(m) x 1/4 npt(f) free-ball bearing use with dispense valve #242055 and #242056
224569
3/8 npt(m) x 3/8 npt(f) free-ball bearing use with dispense valve #242057 and 242058
207948
1/2 npt(m) x 1/2 npt(f) free-ball bearing
Straight Swivels
204082
1/8 npt(m) x 1/8 npt(f) free-ball bearing (8000 psi; 550 bar)
204083
1/4 npt(m) x 1/8 npt(f) free-ball bearing (8000 psi; 550 bar)
204084
1/4 npt(m) x 1/4 npt(f) free-ball bearing (8000 psi; 550 bar)
214925
3/8 npt(f) x 1/4 npsm(f-union) (5000 psi; 345 bar)
214926
3/8 npt(f) x 1/2 npsm(f-union) (5000 psi; 345 bar)
207946
3/8 npt(f) x 1/2 npsm(f-union) (6000 psi; 414 bar)
207947
1/2 npt(m) x 1/2 npt(f) (6000 psi; 414 bar)
110202
360º Swivels
Swivels and locks into full 360º angle. Use for maximum coupler adaptability and reach.
203597
360º Grease Swivel with tapered-nose coupler #200325
203198
360º Grease Swivel, 8,000 psi maximum working pressure (without coupler)
204082
112196
Manually Operated Grease Guns
Z-Swivels
203597
203198
www.graco.com
202577
LUBRIC AT ION E QUIP M E NT ❚ GREASE GUNS
69
Grease Guns
Accessories and Fittings
Grease Nozzles
200389
Standard Nozzle. Includes straight 6 in (15.2 cm), 1/8 npt(m) extension tube #150622 and
tapered nose coupler #200325.
204072
Swivel Nozzle. Includes straight 6 in (15.2 cm), 1/8 npt(m) extension tube #150622 and tapered
nose coupler #200325. Coupler has 360º swivel adapter #203198 for added convenience.
204897
Swivel Nozzle. Includes straight 12 in (30.4 cm), 1/8 npt(m) extension tube #155836 and tapered nose coupler #200325. Coupler has 360º swivel adapter #203198 for added convenience.
204204*
Inlet Flexible 12 in (30.4 cm) Hose Nozzle. 1/8 npt(m) Includes tapered-nose coupler #200325.
203504*
Inlet Flexible 12 in (30.4 cm) Hose Nozzle. 1/8 npt(m) Includes tapered-nose coupler #200325
and lock sleeve connector #203497 for quick connection to any grease nozzle having taperednose coupler.
109145
12 in (30.4 cm) Hose Nozzle without Coupler
112255
18 in (45.8 cm) Hose Nozzle without Coupler
109148*
30 in (76.2 cm) Hose Nozzle without Coupler, has 1/8 npt(m) both ends. Use as alternate for rigid
nozzle with tapered-nose coupler #200325.
200389
204072
200325
*Warning: potential injection hazard. Not for use above 5000 psi (345 bar).
Grease Couplers
200325
1/8 npt(f) inlet Standard Tapered-Nose Coupler. Hardened jaws grip grease fittings through widesealing angle, but release easily. Maximum working pressure 8000 psi (551 bar).
202650
1/8 npt(f) inlet Standard Straight Nose Grease Coupler for manual operated grease guns only.
Maximum working pressure 3000 psi (206 bar).
200020
1/8 npt(f) inlet Standard Button-Head Coupler. Gives fast, positive seal on button-head fittings.
200021
1/8 npt(f) inlet Giant Button-Head Coupler. Gives fast, positive seal on larger button-head fittings.
200020
203497
Manually Operated Grease Guns
Adapters have lock-sleeve quick-connector, works with any grease nozzle with a tapered-nose coupler.
201881
Hydraulic-to-Push Adapter. Used for U-joints and low-pressure service.
205532
Hydraulic-to-Steel Needle Adapter. Used for flush fittings. 250 psi max, not for air grease applications or guns.
205582
Hydraulic-to-Nylon Needle Adapter. Used for removable plugs. 250 psi max, not for air grease
applications or guns.
223187
90º Hydraulic-to-Push Adapter (K-Car) Refer to Instruction Manual 306708.
203497
Lock Sleeve Connector. 1/8 npt(f) outlet. Allows for quick connection to tapered-nose coupler. Inlet
is standard grease fitting with sleeve to lock connector in place.
236171
Easy-Fill Valve. For faster loading of Graco hand grease guns with gun loaders. Replaces hydraulic
fittings on all grease guns with 1/8 npt(f). Refer to Instruction Manual 308306.
204929
Grease Loader Valve. For use with lever-operated, high-volume grease pumps. Permits quick
bulk-filling of hand-operated grease lever guns equipped with Easy-Fill Valve #236171. Refer to
Instruction Manual 308306.
205592
Hydraulic Adapter Assortment Package. Contains needle adapter #205568, plug adapter
#205554, push adapter #201881, nylon needle adapter #205582, hydraulic-to-steel needle
adapter #205532 and whip hose nozzle connector #203504.
205582
205532
Grease Gun Fittings
1/8 npt Threaded Grease Fittings (steel; ball-check)
Part No.
Shank
Description
Pressure Rating
100054
9/32
1/8 npt straight
10,000 psi (689 bar)
101277
1-9/32
1/8 npt straight
10,000 psi (689 bar)
100970
9/32
1/8 npt 30º angle
10,000 psi (689 bar)
100834
9/32
1/8 npt 45º angle
10,000 psi (689 bar)
100971
9/32
1/8 npt 65º angle
10,000 psi (689 bar)
100833
9/32
1/8 npt 90º angle
10,000 psi (689 bar)
205592
100970
70
LUBR IC A T ION E QU IP M EN T ❚ G R E A S E G U N S
100833
www.graco.com
Grease Guns
Accessories and Fittings
1/4 npt Threaded Grease Fittings (steel; ball-check)
100848
3/8
1/4 npt 67º angle
10,000 psi (689 bar)
100846
3/16
1/4-28 straight
10,000 psi (689 bar)
100847
13/64
1/4-28 45º angle
10,000 psi (689 bar)
101283
3/16
1/4-28 90º angle
10,000 psi (689 bar)
101281
11/32
1/4-28 straight
10,000 psi (689 bar)
110702
19/64
1/4-28 65º angle
10,000 psi (689 bar)
100835
12/32
1/4-28 straight
10,000 psi (689 bar)
101287
100834
1/4 npt Thread-Forming Grease Fittings (steel; ball-check)
110703
13/64
1/4-28 straight
10,000 psi (689 bar)
110704
13/64
1/4-28 45º angle
10,000 psi (689 bar)
110705
13/64
1/4-28 90º angle
10,000 psi (689 bar)
101297
3/16 npt Thread-Forming Grease Fittings (steel; ball-check)
110706
3/32
3/16 npt straight
10,000 psi (689 bar)
110709
7/32
3/16 npt 65º angle
10,000 psi (689 bar)
110704
Drive-Type Grease Fittings (steel; no check)
110713
1/4
3/16 npt straight
101312
1/4
3/16 npt straight
110710
1/4
5/16 npt straight
101287
17/64
1/4 npt straight
110712
100837
7/16
1/4 npt straight
101297
33/64
3/8 npt straight
110711
35/64
1/2 npt straight
Giant Button-Head Grease Fitting (steel)
110712
9/16
3/8 npt straight
100854
1/2
1/4 npt straight
Grease Accessory Packages
202654
Convenient Storage Box Contains the following threaded fittings in the quantity listed:
Shank
Description
Grease Fitting No.
Quantity
9/32
1/8 npt straight
100054
30
9/32
1/8 npt 30º angle
100970
10
9/32
1/8 npt 90º angle
100833
10
3/16
1/4-28 straight
100846
20
13/64
1/4-28 45º angle
100847
10
202654
Easy-Outs For installation and removal of grease fittings.
101604
1/8 npt
101605
1/4-28 unf
101605
Manually Operated Grease Guns
Standard Button-Head Grease Fitting (steel)
101604
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ GREASE GUNS
71
Oil King,™ Coolant King™ and Oil Ace™
Fluid Reclaim Packages
Oil King and Coolant King
• Large 25 gallon capacity with sight gauge
• Convenient tool trays and filter areas
• Large offset collection pan with screen
• Oversized tires to get over hose and rough floors
• Color specific receiver for easy identification
Typical Applications
• Used fluid receiver
• Automotive dealerships
• Heavy-duty dealerships
• Fast lube centers
• Fleet service facilities
• Service shops
Typical Fluids Handled
248632
• Used oil – Oil King
• Used antifreeze – Coolant King
238866
Ordering Information
Oil King Oil Receiver
238866
25 gal (95 l) Polyethylene tank with used-filter tray, tool holders and sight gauge. Includes all hardware
for topside evacuation or bottom drain*. Instruction manual 308667.
Coolant King Anti-Freeze Receiver
248632
25 gal (95 l) Polyethylene tank with used-filter tray, tool holders and sight gauge. Includes all hardware
for topside evacuation or bottom drain. *
* Must use 222090 or 224873 for topside evacuation. Must ship via truck.
Fluid Reclaim Packages
Oil Ace
• Easy to drain using shop air pressure
• Large 24 gallon capacity
• Large offset collection pan with screen
Typical Applications
• Pressurized used oil receiver • Service shops
• Automotive dealerships
• Fast lube centers
• Heavy-duty dealerships
• Fleet service facilities
Typical Fluids Handled
• Used Oil
Ordering Information
Oil Ace
119577
72
24 gal (90 l) Steel-tank Pressurized Oil Drain
LUBR ICA T ION E QU IP M E N T ❚ F L U I D R EC L A I M
www.graco.com
Fluid Reclaim Packages and Accessories
Ordering Information
16 gal (60 l) Used-Oil Receiver with drum.
239301
Use with evacuation kit #240832. Instruction manual 306449.
16 gal (60 l) Used-Oil Receiver without drum.
239302
Instruction manual 306449.
Funnel Kit
243650
Use with 238866, 239301, 239302 and 248632. Includes tray and pipe.
Wall-Mounted Funnel Drain
154616
Use with Pedestal Receiver #225272 to open automatic check-valve and drain used oil through wall to
waste tank. Drain has 1-1/4 npt(f) outlet.
Drum-Mounted Funnel Drain
156789
Use with Pedestal Receiver (#225272) to open automatic check-valve and drain used oil into standard
drum. Funnel drain has 2 npt bung fitting for use with 55 gal (210 l) or 16 gal (60 l) drums, or 275 gallon
(1,100 l) tanks.
ATF Drain Funnel
208009
Use with Pedestal Receiver #225272 to extend funnel reach. Use for draining transmissions.
(Not equipped with drain plug.) 16 in x 24 1/2 in
Rolling Used-Oil Receiver
218969
Specially designed for car and truck fast-lube facilities where speed and mobility are important. Adjustable
steel rollers fit track widths of 39 in (99 cm) to 46 inches (117 cm), with a minimum running width of
2-1/2 in (63.5 mm). Front and rear drain fittings allow use of two drains on a single track, permitting two
receivers to be drained simultaneously. Instruction manual 307727. Unit includes: 30 gal (114 l) steel tank,
1-1/2 npt drain valve #108204, 1-1/2 npt quick coupler #108202 and 1-1/2 npt coupler cap. Dimensions:
24 in (61 cm) wide; 33 in (84 cm) long; 11 in (28 cm) deep; 3 in (7.6 cm) diameter wheels. 1-1/2 in drain
hose–see manual provided.
239301
Narrow Rolling Used-Oil Receiver
235346
Same as #218969 above, except track width range is from 34.2 in (87 cm) to 42.2 in (108 cm). 27 gal
(102 l) capacity. Instruction manual 307727. See accessories on page 101.
244055
Specially-designed for truck maintenance facilities, the Big Hauler Truck Drain boasts a large capacity
and easy maneuverability. Dimensions: 42 in (106.7 cm) long; 30 in (76.2 cm) wide; 9 in (22.9 cm) deep.
Capacity: 26 gallons (98 l). Instruction manual 309194. Gravity drain valve at bottom of unit allows for
easy drain access. 3/4 in npt outlet can also be used with 224873 or 222090 for diaphragm evacuation.
240832 can be ordered separately for existing diaphragm pump evacuation systems. Instruction manual
308719.
208009
244055
Fluid Reclaim Packages
Big Hauler™ Truck Drain
218969
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ FLUID RECLAIM
73
Fluid Reclaim Packages and Accessories
Packages for Used-Oil Evacuation with Air-Operated Diaphragm Pumps
Wall-Mounted Packages
222090
Includes: 1040 (1 in) diaphragm pump (236265), Wall bracket (189233), Air installation kits (240684),
Fluid installation kits (240685), Drum style adapter kits (240832).
NOTE: Used-oil receivers are not included and must be ordered separately. See instruction manual 308719 for more information.
24E166
Includes: 1050A (1 in) diaphragm pump (647016), Wall bracket (224835), Air installation kits, Fluid
installation kits (240685), Drum style adapter kits (240832).
224873
Includes: 716 (3/4 in) diaphragm pump (241906), Wall bracket (224835), Air installation kits (240684),
Fluid installation kits (240685), Drum style adapter kits (240832).
NOTE: Used-oil receivers are not included and must be ordered separately. See instruction manual 313597 for more information.
NOTE: Used-oil receivers are not included and must be ordered separately.
Stationary Gear-Oil Evacuation Systems with 716 or 1040 Diaphragm Pump
System evacuates lube from differential case using suction generated by a diaphragm pump. Nylon tubes ranging in
size from 3/16 in OD to 1/2 in OD are included to fit through sight plug to completely drain the case. Evacuated gear
lube is then pumped to waste tank. Piping and waste tank not included. Systems are fully-groundable and bondable for
safe transfer of used oil.
224955
Includes: 716 diaphragm pump #241906, air control kit #110149, mounting kit #224759, swivel union
#157785, hose coupler #111474,suction hose/wand** #221146 and control valve** #220969.
222148
Includes: UL-listed 1040 diaphragm pump #236265, air control kit (221147), hose and fitting kit (222149),
evacuation, suction hose/wand** #(221146) and wall bracket (189233).
24E167
*Package 224873
(Package does not include
238866 receiver or tank)
**Order additional suction hose/wand #221146 and additional control valve #220969 for each additional suction point.
Note: Order grounding clamp #222011 or use locally-supplied grounding wires and clamps in accordance with applicable codes.
**Order additional suction hose/wand #221146 and additional control valve #220969 for each additional suction point.
Note: Order grounding clamp #222011 or use locally-supplied grounding wires and clamps in accordance with applicable codes.
Includes: UL-listed 1050A diaphragm pump (647016), air control kit (221147), hose and fitting kit
(222149), evacuation, suction hose/wand** (221146) and wall bracket (189233).
**Order additional suction hose/wand #221146 and additional control valve #220969 for each additional suction point.
Note: Order grounding clamp #222011 or use locally-supplied grounding wires and clamps in accordance with applicable codes.
See instruction manual 313597 for more information.
Port-Evacuation Pump
223695
Port-Evacuation allows fast, clean withdrawal of gear lube, ATF, anti-freeze, and related fluids. Includes:
716 diaphragm pump (241906), mounting kit with 10 ft (3 m) suction hose (223697) which attaches to
wands of four different diameters (suction wand kit, 223696): 1/2 in (12.7 mm); 3/8 in (9.5 mm); 1/4 in
(6.4 mm), and 3/16 in (4.7 mm). Instruction manual 308035.
223695
Fluid Reclaim Packages
Suction Wand Kits
223696
15 in (38.1 cm)
224762
48 in (121.9 cm)
Used-Oil Handling Accessories
Tandem Drain Kit
218970
Tandem drain kit connects two rolling receivers for flow-through draining operation. Kit includes connector
hose, shut-off valve, pipe nipple, and quick-connect nipple. Instruction manual 307727.
108491
Drain hose kit allows rolling used-oil receiver to be drained directly into the used-oil line. Kit is 24 in (0.6 m)
in length with camlock coupler on one end.
218970
Swing-Arm Drain Kit
221007
Used for servicing single rolling used-oil receiver (218969). When used with tandem drain kit (218970) it
can service two receivers on a single track. Kit includes swivel elbow (108867), connector hose (111931),
dust cap (108203) and male adapter (108202).
116229
Oil Tank Monitor
116229
Shuts off air to the pump when tank is full. Mounted at either end of fast lube service pit, swing-arm drain
stores against pit wall and is rotated into position for use.
Accessories for Port-Evac Pump (223965)
223888
6 ft (1.8 m) suction hose for ATF and anti-freeze. Includes filter screen.
223888
74
LUBR ICA T ION E QU IP M E N T ❚ F L U I D R EC L A I M
www.graco.com
Fluid Reclaim Packages and Accessories
Fluid Reclaim Accessories
222178
U-Tube for Used-Oil Drain Cart Evacuation System (222148) Size: 1/2 npt(mbe).
222011
Grounding Clamp for all Used-Oil Handling Systems Includes 25 ft (7.6 m) grounding wire.
Fas-Vac Evacuation Systems
224667*
Fas-Vac Evacuation System (without drum) Basic System includes 716 diaphragm pump and mounting
hardware. Instruction manual 308154.
224700*
16-gal (60 l) System with 16-gal. (72.7 l) drum Includes pump #224667, dolly #224665, wand storage kit
#224666, evacuation hose #224669 and 16 gal drum #111468. Instruction manual 308154.
224763*
16-gal (60 l) System (without drum) Includes same items as #224700 above, but no drum. Instruction
manual 308154.
224701*
55-gal (200 l) System (without drum) Includes pump #224667, 55 gal (200 l) drum truck #111470, wand
storage kit #224666 and evacuation hose #224702. Instruction manual 308154.
187359
4-Way Valve 1/2 npt(f) ports
224701
*224759 FLR mounting kit and 110149 FRL must be ordered separately. See instruction manual 308163.
Hoses, Fittings and Accessories
Air Filters
Centrifugal action 1/4, 3/8 and 1/2 npt. (with 20 micron filters); 3/4 npt having 40 micron filters to remove water and
foreign particles from air supply.
110146
1/4 npt(fbe)
106148
3/8 npt(fbe)
106149
1/2 npt(fbe)
106150
3/4 npt(fbe)
106148
Automatic Filter Drain
106151
Float-type drain for automatic emptying of accumulated fluid in a filter assembly. 1/4 npt(m) (does not fit
air filter #110146)
Air Regulators
110318
1/4 npt(fbe)
110147
1/4 npt(fbe) with gauge
110234
3/8 npt(fbe)
109075
3/8 npt(fbe) with gauge
202858
3/8 npt(m) x 1/2 npsm(f) with gauge
104266
1/2 npt(fbe)
244844
1/2 npt(fbe) with gauge
207755
3/4 npt(fbe)
244845
3/4 npt(fbe) with gauge
109075
Installation Kits
Installation kits include: shut-off valve, regulators, gauges and fittings as necessary for normal installation.
218316
Installation kits for Fast-Flo, Fire-Ball, or Husky 307 and 716 diaphragm pumps
224512
Installation kits for Mini Fire-Ball 225 and Fire-Ball
224512
Fluid Reclaim Packages
Provides precision control of outlet air pressure. Feedback principle provides constant pressure to pump regardless of
air demand rate and fluctuations in supply pressure. (Additional fittings required except air regulators with installation
kits.)
Air Lubricators
Extends pump life and smooths pump movement by applying measured lubricant to all moving parts within the pump air
motor. Control knob and sight window allow adjustment of dispensed lubricant.
214848
1/2 npt(fbe)
110148
1/4 npt(fbe)
214847
3/8 npt(fbe)
214849
3/4 npt(fbe)
www.graco.com
214847
LUBRIC AT ION E QUIP M E NT ❚ FLUID RECLAIM
75
Hoses and Fittings
Accessories
FRL Combination Units
Each includes filter, regulator, pressure gauge, lubricator and connection fittings.
110149
1/4 npt (fbe)
110150
3/8 npt (fbe)
217072
1/2 npt (fbe)
217073
3/4 npt (fbe)
110150
Bleed-type Air Shut-off Valves
Closes air inlet to pump and relieves trapped air pressure down line from valve. Recommended for each pump drop line.
(Note: Be certain to install correctly: if installed backwards air will constantly escape from the valve.)
110223
1/4 npt(fbe)
110224
3/8 npt(fbe)
110225
1/2 npt(fbe)
110226
3/4 npt(fbe)
107142
1/2 npt(mxf)
107141
3/4 npt(mxf)
Air Line Shut-off Valves Ball valve-type air line shut-off valve; non-pressure relieving.
208390
1/4 npt(mbe)
208393
3/8 npt(mbe)
208630
1/2 npt(m) x 3/8 npt(f)
109077
3/4 npt(fbe)
118464
1 npt(fbe)
106151
110223
107142
Quick-Connect Coupler
Permits quick, convenient attachment of air supply hoses.
208536
1/4 npt(fbe)
110198
3/8 npt(f)
110199
1/2 npt(f)
110200
3/4 npt(f)
208536
Quick-Connect Nipple
Hoses and Fittings
Allows quick attachment of air supply hoses to pump motor.
169970
1/4 npt(m)
169967
1/4 npt(f)
169971
3/8 npt(m)
110196
1/2 npt(m)
110197
3/4 npt(m)
169970
Air Needle Valve
Controls pump speed by restricting air flow to pump or other air-operated equipment.
205090
1/4 npt(f) outlet port; 1/4 npt(m) inlet port
206264
1/8 npt(f) outlet port; 1/4 npt(m) inlet port
205090
Air Pressure Relief Valve
Prevents pump from operating beyond recommended working pressure by opening at a pre-set maximum air pressure.
103347
90 psi (6 bar)
110065
60 psi (4 bar)
110065
76
LUB R ICA T ION E QU IP M E N T ❚ H O S E S A N D F I T T I N G S
www.graco.com
Hoses and Fittings
Accessories
Air Pressure Gauge
Allows visual check of air pressure being supplied to the pump. Rated to 200 psi (14 bar).
110319
1/8 npt(m) bottom inlet; black
100960
1/4 npt(m) bottom inlet; black
101180
1/4 npt(m) bottom inlet; chrome
100960
Air manifold
Supply several pumps from a common air supply line. Air inlet port is larger than delivery ports to ensure adequate air
flow to all pumps.
158990
Four outlet ports; 3/8 npt(f)
601950
Three outlet ports; 1/2 npt(f)
158990
Runaway Valve
Prevents pump damage by automatically closing the air line to stop the pump when a runaway pump condition occurs
due to an empty barrel or hose leak.
224040
224040
3/4 npt(fbe)
Blow Guns
208627
Air Blow Gun, 1/4 npt(f), use with coupler 208536.
236211
Safety Blow Gun tip swivels freely and cannot be removed. Tip pressure will not exceed 30 psi (2 bar),
adequate for cleaning. Maximum Working Pressure 150 psi (10 bar). Use with coupler 208536.
208627
Tire Inflators
236205
Heavy-Duty Tire Inflator includes 12 in (30 cm) hose with swivel dual-foot chuck and pop-out gauge.
Tapered chuck nut fits wheel-cover holes on cars and light trucks. Gauge ranges from 0-120 psi in 2 psi
increments. Maximum Working Pressure 250 psi (18 bar), 1/4 npt(f) inlet.
236206
Passenger Car Tire Inflator includes 12 in (30 cm) hose with straight-on chuck and pop-out gauge.
Tapered chuck nut fits wheel cover holes on cars and light trucks. Ideal for use on reels. Gauge ranges
from 0-90 psi in 2 psi increments. Maximum Working Pressure 250 psi (18 bar), 1/4 npt(f) inlet.
218545
1/4 npt(f) Tire Chuck, durable, full-volume tool for adding/relieving air pressure.
236211
236206
Water Valve
180685
Water/Anti-Freeze Bib is a durable, full-volume dispense nozzle for water, anti-freeze and windshield
washer fluid. Nitrile rubber seals with 1/4 npt(f) inlet. Maximum pressure is 100 psi.
180685
Heavy-Duty Reinforced Hoses
Heavy-duty reinforced hose for use with grease, oil and undercoating material. Hoses are black, male at both ends.
Lubrication hoses listed herein are grounded for static electrical discharge.
Part No.
Length
Fittings
109145
12 in (0.3 m)
1/8 in x 1/8 in with bend restrictor
109146
15 in (0.4 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
109147
24 in (0.6 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
109148
30 in (0.8 m)
1/8 in x 1/8 in with bend restrictor
109149
48 in (1.2 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109150
72 in (1.8 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109151
12 ft (3.6 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109152
15 ft (4.6 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109153
20 ft (6.1 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
109154
25 ft (7.6 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109156
35 ft (10.6 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
109157
40 ft (12.2 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
109158
50 ft (15.3 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
www.graco.com
Hoses and Fittings
1/4 in ID hoses with maximum pressure rating of 5000 psi (345 bar)
LUBRIC AT ION E QUIP M E NT ❚ HOSES AND FITTINGS
77
Hoses and Fittings
Lubrication Hoses
3/8 in ID hoses with maximum pressure rating of 4000 psi (276 bar)
Part No.
Length
Fittings
109160
12 in (0.3 m)
1/4 in x 1/2 in (6.4 mm x 12.7 mm)
109161
24 in (.62 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
109162
48 in (1.2 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
109163
72 in (1.8 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
109165
15 ft (4.6 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109170
50 ft (15.3 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
109169
40 ft (12.2 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
109170
50 ft (15.3 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
Lubrication Hoses (Oil)
Hoses and Fittings
1/2 in ID hoses with maximum pressure rating of 3000 psi (207 bar)
Part No.
Length
Fittings
220604
12 in (0.3 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
110069
15 in (0.4 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
220598
18 in (0.5 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
220600
54 in (1.4 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
220591
72 in (1.8 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
220590
10 ft (3.1 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
220592
16 ft (4.9 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
220593
20 ft (6.1 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
220608
25 ft (7.6 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
221092
40 ft (12.2 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
221093
50 ft (15.3 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
237861
75 ft (22.9 m)
1/2 in x 3/4 in (12.7 mm x 19.1 mm)
109108
18 in (0.4 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
109105
72 in (1.8 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
111010
10 ft (3.0 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
237865
75 ft (22.9 m)
1/2 in x 1 in (12.7 mm x 25.4 mm)
237866
50 ft (15.2 m)
1/2 in x 1 in (12.7 mm x 25.4 mm)
1 in ID hose rated to maximum pressure of 125 psi (8.7 bar)
Part No.
Length
Fittings
249058
50 ft (15.2)
1 in x 1 in (25.4 mm x 25.4 mm)
1 in ID hose rated to maximum pressure of 212 psi (14.6 bar)
Part No.
Length
Fittings
241908
50 ft (15.2)
1 in x 1 in (25.4 mm x 25.4 mm)
241907
30 ft (9.1 m)
1 in x 1 in (25.4 mm x 25.4 mm)
Air/Water Hoses
Hoses for air, water, anti-freeze and windshield washer fluid. Hoses are red with male fittings at both ends.
Coiled 1/4 in ID hose with maximum pressure rating of 180 psi (12 bar)
78
Part No.
Length
Fittings
205600
50 ft (15.3 m)
1/4 in x 50 ft (6.4 mm x 15.3 m)
LUB R ICA T ION E QU IP M E N T ❚ H O S E S A N D F I T T I N G S
www.graco.com
Hoses and Fittings
Lubrication Hoses
Fabric-Reinforced 1/4 in ID hoses with maximum pressure rating of 180 psi (12 bar)
Part No.
Length
Fittings
109123
18 in (0.5 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109124
4 ft (1.2 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109125
6 ft (1.8 mm)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109126
10 ft (3.1 m)
1/4 in x 1/4 in (6.4 mm x 6.4 mm)
109127
25 ft (7.6 mm)
1/4 in x 1/2 in (6.4 mm x 12.7 mm)
109128
40 ft (12.2 m)
1/4 in x 1/2 in (6.4 mm x 12.7 mm)
218491
40 ft (12.2 m)
3/8 in x 1/4 in (9.5 mm x 6.4 mm)
3/8 in ID hoses with maximum pressure rating of 180 psi (12 bar)
Part No.
Length
Fittings
109129
15 in (0.4 m)
3/8 in x 1/2 in (9.5 mm x 12.7 mm)
204560
18 in (0.5 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
109130
4 ft (1.2 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
203320
6 ft (1.8 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
109131
10 ft (3.1 m)
3/8 in x 3/8 in (9.5 mm x 9.5 mm)
110326
16 ft (4.9 m)
1/4 in x 3/8 in (6.4 mm x 9.5 mm)
109132
25 ft (7.6 m)
3/8 in x 1/2 in (9.5 mm x 12.7 mm)
109133
30 ft (9.2 m)
3/8 in x 1/2 in (9.5 mm x 12.7 mm)
249181
40 ft (12.2 m)
1/2 in x 3/8 in (12.7 mm x 9.5 mm)
109134
40 ft (12.2 m)
3/8 in x 1/2 in (9.5 mm x 12.7 mm)
109135
60 ft (18.3 m)
3/8 in x 1/2 in (9.5 mm x 12.7 mm)
Part No.
Length
Fittings
218093
22 in (0.56 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
110046
4 ft (1.2 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
205418
6 ft (1.8 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
214656
10 ft (3.1 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
248312
25 ft (7.6 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
248313
50 ft (15.2 m)
1/2 in x 1/2 in (12.7 mm x 12.7 mm)
Hoses and Fittings
1/2 in ID hose with maximum pressure rating of 180 psi (12 bar)
3/4 in ID hoses with maximum pressure rating of 180 psi (12 bar)
Part No.
Length
Fittings
110047
18 in (0.5 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
110048
4 ft (1.2 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
208610
6 ft (1.8 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
214955
10 ft (3.1 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
208611
25 ft (7.6 m)
3/4 in x 3/4 in (19.1 mm x 19.1 mm)
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ HOSES AND FITTINGS
79
Hoses and Fittings
Pipe Fittings and Swivels
Busing – reducing, standard and expanding
Part No.
Thread Size (m x f)
Part No.
Thread Size (m x f)
Part No.
Thread Size (m x f)
100030
1/4 in x 1/8 in
159841
3/8 in x 1/4 in
100206
1/2 in x 1/4 in
100081
1/2 in x 3/4 in
100615
3/4 in x 1/4 in
100505
3/4 in x 3/8 in
100896
3/4 in x 1/2 in
100380
1 in x 1/2 in
158586
1 in x 3/4 in
Pipe Adapters
Part No.
Thread Size (m x f)
Part No.
Thread Size (m x f)
Part No.
Thread Size (m x f)
150171
1/8 in x 1/8 in
159840
1/8 in x 1/4 in
156580
1/8 in x 3/8 in
150287
1/4 in x 3/8 in
159842
1/4 in x 1/2 in
150286
3/8 in x 3/8 in
156022
3/8 in x 1/2 in
168595
1/2 in x 3/4 in
Street Elbows
Part No.
Thread Size (m x f)
Part No.
Thread Size (m x f)
Part No.
Thread Size (m x f)
100840
1/4 in x 1/4 in
155699
3/8 in x 3/8 in
158683
1/2 in x 1/2 in
176393
3/4 in x 3/4 in
Coupling (standard)
Part No.
Thread Size
Part No.
Thread Size
Part No.
Thread Size
100451
1/8 in
113093
1/4 in
162024
3/8 in
158581
1/2 in
100385
3/4 in
100474
1 in
Hex Nipple (standard and reducing)
Part No.
Thread Size
Part No.
Thread Size
Part No.
Thread Size
151519
1/4 in x 1/8 in
156971
1/4 in x 1/4 in
156296
3/8 in x 1/8 in
165198
3/8 in x 1/4 in
156849
3/8 in x 3/8 in
162449
1/2 in x 1/4 in
159239
1/2 in x 3/8 in
158491
1/2 in x 1/2 in
194048
3/4 in x 3/8 in
157191
3/4 in x 1/2 in
175013
3/4 in X 3/4 in
158555
1 in x 3/4 in
Square-Head Plug
Part No.
Thread Size
Part No.
Thread Size
Part No.
Thread Size
111697
1/4 in
100040
3/8 in
100737
1/2 in
104663
3/4 in
Straight Swivel Adapter*
Part No.
Rigid (m) x Swivel (f)
Part No.
Rigid (m) x Swivel (f)
Part No.
Rigid (m) x Swivel (f)
208434
1/8 in x 1/4 in
156823
1/4 in x 1/4 in
157705
1/4 in x 3/8 in
155665
3/8 in x 3/8 in
162505
3/8 in x 1/2 in
156684
1/2 in x 1/2 in
158256
1/2 in x 3/8 in
157785
3/4 in x 3/4 in
202965
1 in x 3/4 in
160022
1 in x 1 in
Hoses and Fittings
90º Swivel Adapter*
Part No.
Rigid f) x Swivel (f)
Part No.
Rigid (f) x Swivel (f)
Part No.
Rigid (f) x Swivel (f)
157676
1/4 in x 1/4 in
155677
3/8 in x 3/8 in
159801
3/8 in x 1/2 in
157416
1/2 in x 1/2 in
156589
3/4 in x 3/4 in
Straight Swivel Adapter*
Part No.
Rigid (f) x Swivel (f)
Part No.
Rigid (f) x Swivel (f)
Part No.
Rigid (f) x Swivel (f)
155570
1/4 in x 1/4 in
159153
3/8 in x 1/4 in
156173
3/8 in x 3/8 in
155653
1/2 in x 1/4 in
161077
1/2 in x 3/8 in
155865
1/2 in x 1/2 in
156172
3/5 in x 3/4 in
158383
1 in x 1 in
90º Swivel*
Part No.
Rigid (M) x Swivel (F) Part No.
Rigid (M) x Swivel (F)
Part No.
Rigid (M) x Swivel (F)
155541
1/4 in x 1/4 in
155495
3/8 in x 1/4 in
155494
3/8 in x 3/8 in
217430
3/8 in x 1/2 in
161037
1/2 in x 3/8 in
155470
1/2 in x 1/2 in
160327
3/4 in x 3/4 in
Part No.
Rigid (M) x Swivel (F)
45º Swivel Adapter*
Part No.
Rigid (M) x Swivel (F) Part No.
Rigid (M) x Swivel (F)
161889
3/8 in x 3/8 in
3/4 in x 3/4 in
105281
*Not a “live” swivel, position is stationary after tightened
80
LUB R ICA T ION E QU IP M E N T ❚ H O S E S A N D F I T T I N G S
www.graco.com
Hoses and Fittings
Tube and Fittings
Tube Fittings
Maximum pressure rating of 3000 psi (207 bar) with appropriate tubing wall thickness.
Tube Union Flow 90º Elbow
Part No.
Tube OD
101012
5/8 in
101376
7/8 in
Tube Union – Straight
Part No.
Tube OD
101009
5/8 in
101340
7/8 in
Male Connector
Part No.
Tube OD
Thread
101339
7/8 in
3/4 npt
Female Connector – Straight
Part No.
Tube OD
Thread
101008
5/8 in
1/2 npt
101520
7/8 in
3/4 npt
Tube Tee with Female Branch
Part No.
Tube OD
Thread
101013
5/8 in
5/8 npt
101378
7/8 in
3/4 npt
NOTE: Consult you local distributor for additional tube-fitting requirements (ie: high-pressure, low-pressure, etc.) and
fitting recommendations: Parker; AeroQuip; Weatherhead; Lenz; Crawford; or Imperial Eastmand.
Technical Information
Always use a qualified installer and ensure the installer follows the detailed instructions included with every Graco product.
1. Always use new pipe. Make certain that pipes are clean and free of rust and scale.
2. When cutting pipe remove burrs and chips that may damage dispense valves and meters.
3. Always flush the system with oil before attaching dispense valves and meters.
Air Lines
Main Line
Branch Line
Pump Model
3/4 in or 1 in ID pipe
3/8 in or 1/2 in ID pipe
Fast-Ball; Mini Fire-Ball 225
3/4 in or 1 in ID pipe
1/2 in ID pipe
Fire-Ball
Fluid Lines
This information applies to typical automotive flow rate service requirements.
Supply Line Length
Supply Pump
Hydraulic Supply Line Tubing
ASTM A53 or A106 Grade “B”
Seamless Pipe (6000 psi forged steel fittings)
Up to 50 feet
50:1 Fire-Ball 300, 425
5/8" OD x .109" Wall Tube
1/2" Schedule 80
50 to 100 feet
50:1 Fire-Ball 300, 425
5/8" OD x .109" Wall Tube
1" Schedule 160
100 to 200 feet
50:1 Fire-Ball 300
N/A
1-1/4" Schedule 160
100 to 200 feet
50:1 Fire-Ball 425
N/A
1-1/2" Schedule 160
200 feet and up
50:1 Fire-Ball 300, 425
N/A
1-1/2" Schedule 160
Motor Oil, Gear Lube, or ATF Lubricant Supply Lines (based upon 1000 psi maximum working pressure)
Supply Line Length
Supply Pump
Hydraulic Supply Line Tubing
ASTM A53 Butt welded Pipe (Class 300
malleable fittings)
Up to 50 feet
5:1 Fire-Ball 300
5/8" OD x .049" Wall Tube
1/2" Schedule 40
Up to 50 feet
10:1 Fire-Ball 425
3/4" OD x .049" Wall Tube
3/4" Schedule 40
50 to 100 feet
5:1 Fire-Ball 300
3/4" OD x .049" Wall Tube
3/4" Schedule 40
50 to 100 feet
10:1 Fire-Ball 425
1" OD x .049" Wall Tube
1" Schedule 40
100 to 200 feet
5:1 Fire-Ball 300
1" OD x .049" Wall Tube
1" Schedule 40
100 to 200 feet
10:1 Fire-Ball 425
1-1/2" OD x .095" Wall Tube
1-1/4" Schedule 40
200 feet and up
5:1 Fire-Ball 300
1-1/2" OD x .095" Wall Tube
1-1/4" Schedule 40
200 feet and up
10:1 Fire-Ball 425
1-1/2" OD x .095" Wall Tube
1-1/4" Schedule 40
www.graco.com
LUBRIC AT ION E QUIP M E NT ❚ HOSES AND FITTINGS
Hoses and Fittings
Chassis Grease Lubricant Supply Lines (based upon 5000 psi maximum working pressure)
81
Tank Packages
Fluid Dispense Packages
Mini Fire-Ball® 225, 3:1 Bulk-Oil Dispensing Packages
Mini Fire-Ball 225, 3:1 Pump Package
248623*
Includes: Mini Fire-Ball 225, 3:1 Universal pump with bung adapter and down tube (248097), SD Series
reel with 50 ft (15.2 m) x 1/2 in (12.7 mm) fluid hose (HPM65B), LDM5 meter (256215)
248622*
Includes: Mini Fire-Ball 225, 3:1 Universal pump with bung adapter and down tube (248097), SD Series
reel with 25 ft (7.6 m) x 1/2 in (12.7 m) fluid hose (HPM33B), EM5 meter (256215)
*Order 218549 (1/2 in x 24 in) hose reel inlet kit separately NOTE: Tanks not included
Fire-Ball 300, 5:1 Deluxe Bulk-Oil Dispensing Packages
Fire-Ball 300, 5:1 Pump Packages
241633*
Includes: Fire-Ball 300, 5:1 pump universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), 3/8 in
(9.5 mm) x 3/8 in (9.5 mm) nipple (156849), 2 in (50.8 mm) bung adapter (222308), SD Series reel with
25 ft (7.6 m) x 1/2 in (12.7 mm) hose (HPM33B), EM5 meter (255350)
224541*
Includes: Fire-Ball 300, 5:1 pump universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), 3/8 in
(9.5 mm) x 3/8 in (9.5 mm) nipple (156849), 2 in (50.8 mm) bung adapter (222308), SD Series reel with
50 ft (15.3 m) x 1/2 in (12.7 mm) hose (HPM65B), 18 in (45.7 cm) hose (220598), 90º swivel (inlet on
hose reel) (157416), SDM5 meter (255350)
244038*
Includes: Fire-Ball 300, 5:1 pump universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), 3/8 in
(9.5 mm) x 3/8 in (9.5 mm) nipple (156849), 2 in (50.8 mm) bung adapter (222308), SD Series reel with
50 ft (15.3 m) x 1/2 in (12.7 mm) hose (HPM65B), 18 in (45.7 cm) hose (220598), 90º swivel (157416),
SDP5 meter (255200)
224534*
Dispensing from Bench-Top Tanks with Fire-Ball 300, 5:1 Pump Package. Includes: Fire-Ball 300, 5:1
pump, Universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), Air filter (106148), 3/8 in (9.5
mm) x 3/8 in (9.5 mm) nipple (156849), SD Series reel with 50 ft (15.3 m) x 1/2 in 12.7 mm) hose
(HPM65B), Drain valve (106151), 72 in (182.9 cm) hose kit (222063), Thermal relief valve (237893), 90º
swivel (157416), SDM5 Meter (255350)
Package
248623
(tank not included)
Bulk Fluid Dispense
*Order 218549 (1/2 in x 24 in) hose reel inlet kit separately NOTE: Tanks not included
82
Package
224541
(tank not included)
LUBR IC A T ION E QU IP M E N T ❚ B U L K F L U I D D I S P EN S E
Package
224534
(tank not included)
www.graco.com
Index
Part No.
Page No.
3A0138 .......................................52
15B750 .........................................6
15C502 .................................16, 18
15D702 .........................................7
15M308 ...................................6, 65
15M309 ...................................6, 65
15T366 ....................................6, 65
15T367 ....................................6, 65
15T368 ....................................6, 65
15T369 ....................................6, 65
15T370 ....................................6, 65
15T998 ..........................................5
15T999 ..........................................5
24A217 .......................................56
24A218 .................................55, 56
24A219 .......................................56
24A220 .......................................56
24A221 .......................................56
24A222 .......................................56
24A224 .......................................57
24A934 .......................................56
24A935 .......................................56
24A936 .......................................56
24A937 .......................................56
24A938 .......................................56
24A939 .......................................56
24A940 .......................................56
24A941 .......................................56
24A942 .......................................56
24A943 .......................................56
24A944 .......................................56
24A945 .......................................56
24A946 .......................................56
24A947 .......................................56
24A948 .......................................56
24A949 .......................................56
24A950 .......................................56
24A951 .......................................56
24B624 .......................................33
24B634 .......................................33
24B639 .......................................33
24B766 .......................................33
24B812 .......................................55
24B813 .......................................55
24B814 .......................................55
24B815 .......................................55
24B816 .......................................55
24C100 .......................................57
24C437 .......................................56
24C438 .......................................56
24C440 .......................................56
24C442 .......................................56
24C443 .......................................56
24C444 .......................................56
24C445 .......................................56
24C537 .......................................56
24C538 .................................55, 56
24C539 .......................................56
24C772 .......................................56
24C793 .......................................56
24D132 .......................................57
24D133 .......................................57
24D197 .......................................55
24D198 .......................................55
24D199 .......................................55
24D200 .......................................55
24D590 .......................................20
24D591 .......................................20
24D592 .......................................21
24D593 .......................................21
24D594 .......................................20
24D595 .......................................21
24D596 .......................................20
24D597 .......................................20
www.graco.com
Part No.
Page No.
24D598 .......................................21
24D599 .......................................21
24D600 .......................................20
24D601 .......................................21
24D604 .......................................21
24D605 .......................................21
24D608 .......................................21
24E006 ........................................32
24E007 ........................................32
24E008 ........................................32
24E009 ........................................32
24E010 ........................................32
24E011 ........................................32
24E166 ........................................74
24E167 ........................................74
38439..........................................41
100030........................................80
100040........................................80
100054..................................70, 71
100081........................................80
100206........................................80
100220........................................18
100380........................................80
100385........................................80
100451........................................80
100474........................................80
100505........................................80
100611........................................42
100615........................................80
100737........................................80
100833..................................70, 71
100834..................................70, 71
100835........................................71
100837........................................71
100840........................................80
100846........................................71
100847........................................71
100848........................................71
100854........................................71
100896........................................80
100960......... 16, 19, 28, 29, 40, 77
100970..................................70, 71
100971........................................70
101008........................................81
101009........................................81
101012........................................81
101013........................................81
101078........................................19
101180........................................77
101277........................................70
101281........................................71
101283........................................71
101287........................................71
101297........................................71
101312........................................71
101339........................................81
101340........................................81
101376........................................81
101378........................................81
101520........................................81
101604........................................71
101605........................................71
102527..........................................9
103347........................................76
104266......... 16, 19, 28, 29, 40, 75
104663........................................80
105281........................................80
105474........................................11
106148............... 10, 19, 33, 75, 82
106149............................19, 33, 75
106150..................................33, 75
106151............................75, 76, 82
107141........................................76
107142........................................76
Part No.
Page No.
108190........................................42
108202..................................73, 74
108203........................................74
108204........................................73
108458............................10, 11, 19
108491........................................74
108537..................................16, 19
108867........................................74
109054........................................30
109064........................................57
109075.. 16, 19, 24, 26, 27, 40, 42,
75, 82
109077........................................76
109105......................17, 35, 42, 78
109108............................17, 35, 78
109123..................................35, 79
109124........................................79
109125......................14, 35, 42, 79
109126........................................79
109127........................................79
109128........................................79
109129........................................79
109130........................................79
109131........................................79
109132........................................79
109133........................................79
109134........................................79
109135........................................79
109145..................................70, 77
109146........................................77
109147........................................77
109148............................68, 70, 77
109149........................................77
109150..................................30, 77
109151..................................30, 77
109152........................................77
109153........................................77
109154........................................77
109156........................................77
109157........................................77
109158........................................77
109160........................................78
109161........................................78
109162........................................78
109163..................................30, 78
109165..................................30, 78
109167........................................30
109169........................................78
109170........................................78
110025........................................11
110046........................................79
110047........................................79
110048............................20, 21, 79
110065........................................76
110069........................................78
110127........................................18
110146......................19, 33, 42, 75
110147......................19, 33, 42, 75
110148..................................19, 75
110149......................19, 74, 75, 76
110150..................................19, 76
110196..................................33, 76
110197........................................76
110198..................................30, 76
110199..................................33, 76
110200........................................76
110201........................................69
110202........................................69
110203........................................69
110216........................................69
110218........................................69
110223............... 19, 31, 33, 42, 76
110224......... 10, 19, 31, 33, 42, 76
110225............... 16, 19, 31, 33, 76
Part No.
Page No.
110226......................19, 31, 33, 76
110234..................................30, 75
110236........................................58
110237........................................58
110285........................................58
110314........................................19
110318..................................42, 75
110319........................................77
110326........................................79
110702........................................71
110703........................................71
110704........................................71
110705........................................71
110706........................................71
110709........................................71
110710........................................71
110711........................................71
110712........................................71
110713........................................71
110877........................................19
110878........................................19
110906........................................19
110907........................................19
111010........................................78
111468........................................75
111470............................18, 31, 75
111474........................................74
111511........................................42
111620..............................9, 10, 11
111697........................................80
111931........................................74
112087........................................19
112119........................................33
112196........................................69
112197........................................46
112198........................................46
112202........................................46
112255........................................70
112353..................................18, 19
113093........................................80
113497..................................33, 42
113551..........................................9
113553..........................................9
113555..........................................9
113556..........................................9
113557..........................................9
113558..........................................9
113559..........................................9
113560..........................................9
113774..........................................9
113859........................................11
114017........................................65
114829........................................46
115042......................20, 21, 32, 42
116229........................................74
118464........................................76
119278..........................................7
119572..........................................5
119577........................................72
150171........................................80
150286........................................80
150287..................................55, 80
150622........................................70
151519........................................80
154616........................................73
155332....................................6, 65
155470............................17, 30, 80
155494......................17, 18, 30, 80
155495........................................80
155541............................30, 35, 80
155570..................................41, 80
155653........................................80
155665........................................80
155677........................................80
83
Index
Part No.
Page No.
155699........................................80
155836........................................70
155865........................................80
156022..................................42, 80
156172........................................80
156173........................................80
156296........................................80
156580........................................80
156589........................................80
156684........................................80
156789........................................73
156823........................................80
156849............................30, 80, 82
156971..................................42, 80
157191........................................80
157416..................................80, 82
157676........................................80
157705........................................80
157785..................................74, 80
158256........................................80
158383........................................80
158491........................................80
158555........................................80
158581........................................80
158586........................................80
158683........................................80
158990........................................77
159153........................................80
159239........................................80
159801........................................80
159840........................................80
159841........................................80
159842..................................55, 80
159952..................................18, 31
160022........................................80
160327............................17, 35, 80
160754..................................17, 30
161037........................................80
161077........................................80
161889........................................80
162024........................................80
162225..................................28, 29
162449........................................80
162505........................................80
165198........................................80
168085........................................17
168595........................................80
169967........................................76
169970..................................33, 76
169971..................................30, 76
171818........................................17
172405........................................18
175013........................................80
176393........................................80
176684........................................18
178670........................................58
180199........................................19
180685..................................55, 77
180698........................................57
185416..................................62, 66
186472........................................11
187359........................................75
187479........................................42
187754........................................18
188843........................................30
189233............................33, 42, 74
190125........................................42
190386........................................62
191126........................................18
191128........................................18
191131........................................18
191287........................................65
191288........................................65
191289........................................65
84
Part No.
Page No.
191294........................................65
191295........................................65
191368..........................................9
191393..........................................9
191394..........................................9
191782..................................61, 62
191783..................................61, 62
191784..................................61, 62
191785........................................61
192873..........................................9
192874..........................................9
194048........................................80
196471..................................58, 65
200020........................................70
200021........................................70
200325..................................69, 70
200326.. 16, 17, 24, 25, 27, 28, 29,
30, 41, 44
200389............................68, 69, 70
201701........................................61
201881........................................70
202577......................30, 41, 68, 69
202579........................................69
202600........................................69
202650........................................70
202654........................................71
202858..................................33, 75
202869........................................31
202965........................................80
203156........................................17
203198..................................69, 70
203265........................................61
203320............................17, 30, 79
203497........................................70
203504........................................70
203521........................................56
203522........................................56
203523........................................56
203524........................................56
203525........................................56
203526........................................56
203597........................................69
203622......... 16, 18, 24, 27, 31, 45
203650......... 18, 24, 26, 27, 31, 45
203655........................................61
203664........................................26
203687........................................61
203688......................16, 17, 18, 19
203697..................................46, 69
203701........................................46
203702........................................46
203703........................................46
203716........................................29
203857............................16, 18, 40
203872............................16, 18, 40
203876..................................16, 82
203976..................................26, 27
203987..................................17, 19
203992........................................18
204072........................................70
204076..................................18, 40
204082........................................69
204083........................................69
204084........................................69
204095........................................40
204121........................................27
204130........................................30
204134..................................24, 26
204144............................18, 31, 41
204159........................................18
204204........................................70
204254............................16, 18, 40
204264........................................40
204351........................................26
LUBR IC A T ION E QU IP M E N T ❚ I N D EX
Part No.
Page No.
204353........................................27
204385............... 18, 27, 28, 29, 31
204461............................27, 28, 29
204467........................................27
204560..................................17, 79
204574.. 16, 17, 24, 25, 26, 27, 28,
29, 30, 41, 44, 45
204741........................................57
204897........................................70
204929........................................70
205054..................................18, 31
205090........................................76
205102..................................28, 29
205148........................................28
205337........................................30
205339............................27, 28, 29
205394..................................28, 40
205395............................28, 29, 40
205418......................17, 30, 42, 79
205532........................................70
205554........................................70
205568........................................70
205582........................................70
205592........................................70
205600........................................78
205626..................................15, 16
205699..................................28, 29
206199........................................33
206264........................................76
206405..................................25, 41
206496........................................41
206502........................................41
206655........................................40
206656........................................40
206699..................................25, 41
206700..................................25, 41
207279..................................28, 29
207361..................................40, 44
207366..................................40, 44
207367........................................40
207468........................................29
207561..................................18, 31
207562..................................18, 31
207579........................................17
207651..................................28, 33
207738........................................64
207739........................................64
207742........................................64
207755........................................75
207946........................................69
207947........................................69
207948........................................69
208009........................................73
208390........................................76
208393........................................76
208434........................................80
208536......................30, 33, 76, 77
208610............................28, 32, 79
208611........................................79
208627........................................77
208630........................................76
210880........................................17
213012........................................35
213013........................................35
214570........................................41
214583..................................18, 35
214584........................................35
214656........................................79
214658........................................45
214847..................................19, 75
214848..................................19, 75
214849........................................75
214925........................................69
214926........................................69
Part No.
Page No.
214955........................................79
215407..............................9, 10, 11
215474....................................9, 11
215475........................................11
215480........................................11
215481........................................11
215487..............................9, 10, 11
215964........................................35
217072............................16, 19, 76
217073........................................76
217359..................................18, 35
217430........................................80
218093..................................17, 79
218112........................................35
218115........................................14
218316............................14, 35, 75
218340........................................57
218341........................................57
218491........................................79
218545..................................55, 77
218549............................55, 57, 82
218550..................................55, 57
218588..............................9, 10, 11
218591..................................57, 58
218670........................................57
218671........................................57
218672........................................57
218673........................................57
218674........................................57
218675........................................57
218676........................................57
218677........................................57
218678........................................57
218969..................................73, 74
218970........................................74
220107........................................58
220110........................................58
220112........................................58
220168........................................35
220170........................................25
220171........................................25
220590........................................78
220591..................................17, 78
220592........................................78
220593........................................78
220596........................................42
220598............................17, 78, 82
220600........................................78
220604........................................78
220608........................................78
220653......................24, 26, 29, 30
220654............... 24, 26, 27, 30, 40
220969........................................74
221007........................................74
221092........................................78
221093........................................78
221146........................................74
221147........................................74
222011............................33, 74, 75
222051........................................14
222058............................17, 25, 41
222059............................24, 26, 30
222060............................27, 40, 44
222061......................18, 27, 40, 44
222062............................16, 17, 19
222063............... 16, 17, 19, 40, 82
222065..................................16, 40
222066......................16, 17, 19, 40
222067........................................40
222068............................16, 17, 19
222069........................................26
222070............................26, 27, 30
222071........................................40
222072......................24, 27, 30, 40
www.graco.com
Index
Part No.
Page No.
222073........................................27
222074........................................27
222075........................................40
222076......................28, 29, 30, 40
222077........................................41
222078........................................25
222079........................................41
222080..................................25, 30
222081..................................25, 30
222082........................................41
222085........................................40
222086........................................40
222087........................................16
222090............................72, 73, 74
222095..................................16, 40
222103........................................14
222104........................................14
222118..................................19, 35
222119..................................19, 35
222148..................................74, 75
222149........................................74
222178........................................75
222225........................................57
222243............................18, 27, 31
222245........................................27
222308......... 14, 16, 17, 18, 19, 82
222383..................................27, 30
222404........................................28
222417........................................57
222602........................................14
222629........................................58
222641........................................58
222645........................................58
222902........................................44
223107........................................40
223108........................................28
223179..................................10, 11
223187........................................70
223344......................28, 29, 30, 40
223448........................................58
223695........................................74
223696........................................74
223697........................................74
223700..................................30, 44
223701............................28, 30, 44
223845......................24, 27, 30, 40
223846......................28, 29, 30, 40
223888..................................42, 74
223920........................................62
223952........................................32
223965........................................74
224023........................................41
224040........................................77
224266..................................28, 29
224267........................................29
224444........................................57
224512..................................16, 75
224534........................................82
224541........................................82
224569........................................69
224579..................................18, 40
224665........................................75
224666........................................75
224667........................................75
224669........................................75
224700........................................75
224701........................................75
224702........................................75
224741..................................43, 44
224742........................................43
224751........................................44
224752........................................44
224759..................................74, 75
224762........................................74
www.graco.com
Part No.
Page No.
224763........................................75
224825........................................41
224826........................................41
224835............................33, 42, 74
224872........................................68
224873............................72, 73, 74
224912........................................44
224915........................................44
224916........................................44
224955........................................74
225006........................................27
225014........................................27
225016........................................27
225026........................................27
225094........................................16
225272........................................73
225376........................................45
225378........................................45
225380........................................45
225384........................................45
225640........................................16
225642........................................16
225728........................................16
225773........................................26
225781........................................28
225782........................................16
225786........................................16
225827........................................26
225844........................................46
225852........................................16
225853........................................16
225880........................................45
225914........................................46
225931........................................16
226012........................................26
226013........................................27
226018........................................28
226269........................................41
226289........................................45
226290........................................46
226342........................................41
226940........................................35
226941........................................35
226942........................................35
226943........................................35
226944........................................35
226945........................................35
226947..................................34, 35
226948..................................34, 35
226951..................................34, 35
226952........................................35
226953........................................35
232076........................................11
232077........................................11
233807............................26, 27, 68
233933........................................68
234237........................................41
234423........................................58
234902........................................36
235346........................................73
235531........................................11
235532........................................11
235878............................61, 62, 63
235901............................61, 62, 63
235998..............................9, 19, 44
236054......... 17, 18, 19, 33, 35, 42
236058..................................24, 30
236171..................................69, 70
236205........................................77
236206........................................77
236211........................................77
236265............................33, 42, 74
236267........................................33
236273........................................33
Part No.
Page No.
236753........................................43
236754..................................43, 44
236763..................................10, 11
236764..................................10, 11
236778........................................17
236864........................................44
236865........................................44
237075..................................16, 17
237129........................................35
237130........................................35
237131........................................35
237132........................................35
237133........................................35
237134........................................35
237160........................................42
237526..................................15, 16
237601..................................18, 19
237653........................................43
237728........................................53
237861........................................78
237865........................................78
237866........................................78
237873........................................57
237874........................................57
237879........................................53
237884........................................53
237893................. 9, 11, 18, 19, 82
237904........................................44
237932..................................53, 57
237944........................................57
238108..................................15, 16
238125........................................18
238245............................16, 17, 19
238246..................................17, 19
238247........................................17
238371........................................65
238400........................................62
238428..................................33, 42
238429........................................19
238431........................................19
238432........................................19
238433........................................19
238434........................................19
238435........................................41
238436........................................41
238437........................................41
238438........................................41
238440........................................41
238463........................................17
238555........................................65
238592........................................18
238593........................................18
238595........................................18
238596........................................18
238618..........................................9
238624..........................................9
238625..........................................9
238636........................................62
238637........................................62
238638........................................62
238639........................................62
238640........................................62
238641........................................62
238642........................................62
238643........................................62
238646........................................62
238647........................................62
238765........................................33
238866............................72, 73, 74
238899............................18, 19, 33
238996..............................9, 10, 11
239019........................................11
239301........................................73
239302........................................73
Part No.
Page No.
239663........................................41
239702........................................14
239703........................................14
239705........................................45
239706........................................58
239707........................................45
239729..................................29, 40
239730..................................29, 40
239731........................................29
239824..................................58, 63
239829........................................65
239877........................................26
239887..................................27, 40
239888............................27, 29, 40
239949........................................65
239950........................................65
239951........................................65
239952........................................33
239965........................................30
239966..................................30, 41
240416........................................65
240417..................................11, 19
240418........................................19
240429..............................9, 18, 19
240448........................................11
240453........................................65
240684........................................74
240685........................................74
240832..................................73, 74
241246........................................30
241633........................................82
241657........................................33
241663..................................18, 31
241905........................................11
241906............................33, 42, 74
241907........................................78
241908........................................78
241910........................................53
242055..................................68, 69
242056............... 26, 27, 30, 68, 69
242057..................................68, 69
242058..................................68, 69
243161........................................41
243392........................................61
243599........................................61
243600........................................61
243601........................................61
243602........................................61
243603........................................61
243604........................................61
243650........................................73
243669..................................33, 42
243817........................................40
243818........................................40
243835........................................65
243836........................................65
243837........................................65
243992........................................61
244038........................................82
244055........................................73
244075........................................63
244076........................................63
244342........................................11
244628........................................16
244635........................................29
244636........................................29
244637........................................29
244657........................................32
244658........................................28
244679........................................42
244680........................................42
244681........................................42
244682........................................42
244844......................28, 29, 33, 75
85
Index
Part No.
Page No.
244845........................................75
244846........................................16
244847........................................16
244905..................................28, 29
244906........................................29
245410........................................54
245694........................................26
245695........................................26
245696........................................27
246775........................................16
246781........................................24
246903........................................16
246904........................................16
246906........................................16
246907........................................16
246909........................................24
246910..................................24, 26
246911..................................24, 26
246913..................................24, 26
246914........................................24
246915........................................24
246916........................................24
246917..................................24, 26
247335........................................29
247336........................................29
247337........................................29
247435..........................................7
247436......................................4, 7
247443........................................44
247450........................................44
247453........................................63
247540........................................44
247712........................................66
247713........................................66
247714........................................66
247715........................................66
247716........................................66
247717........................................66
247718........................................67
247721........................................67
247722........................................67
247723........................................67
247724........................................67
247725........................................67
247759........................................65
247760........................................65
247890........................................21
247891........................................21
247894........................................21
247895........................................21
247969........................................20
247973........................................32
247974........................................32
247975........................................32
247976........................................32
247977........................................32
247978........................................32
247979........................................32
247980........................................32
247981........................................32
248097..................................16, 82
248230........................................16
248296..................................18, 19
248312........................................79
248313........................................79
248324..................................18, 19
248417..........................................7
248418..........................................7
248419..........................................7
248421..........................................7
248622........................................82
248623........................................82
248632..................................72, 73
248918........................................36
86
Part No.
Page No.
249058........................................78
249181........................................79
249294........................................36
249440....................................6, 58
249771........................................36
249783........................................36
249821........................................36
253486........................................36
253487........................................36
253494........................................36
253601........................................64
253683........................................36
255143........................................21
255200..........................4, 6, 60, 82
255231......................................4, 5
255277..................................55, 59
255348..................................55, 60
255349........................................60
255350............................55, 60, 82
255351........................................60
255352........................................60
255353........................................60
255354........................................60
255355........................................60
255356........................................60
255370..........................................6
255459............................64, 65, 66
255460............................64, 65, 66
255461..................................65, 66
255470............................64, 65, 66
255731..........................................5
255751............................55, 59, 65
255793........................................67
255800........................................60
255801........................................60
255802........................................60
255803........................................60
255852........................................65
255853........................................65
255854........................................65
255855........................................65
255856........................................65
255857..................................65, 66
255858..................................65, 66
255859........................................67
255861........................................65
255885....................................6, 65
255921........................................67
256164........................................66
256215......................55, 59, 65, 82
256216..................................55, 59
256282..........................................6
256285......................................4, 7
256482..........................................6
256483..........................................6
256484..........................................6
256485..........................................6
256486..........................................6
256487..........................................6
256488..........................................6
256556........................................64
256634......................................4, 5
256635..........................................5
256636..........................................5
256637..........................................5
256638..........................................5
256719..........................................6
256786........................................64
256787........................................64
256788........................................64
256789........................................64
256836........................................60
256837........................................60
256838........................................60
LUBR IC A T ION E QU IP M E N T ❚ I N D EX
Part No.
Page No.
256839........................................60
257120..........................................6
257539..........................................6
257556..........................................6
258693........................................59
258694........................................59
260000........................................39
260020........................................39
260022........................................39
260025........................................39
260078........................................39
260079........................................39
260082........................................39
260083........................................39
260100..................................37, 38
260101..................................37, 38
260102..................................37, 38
260104..................................37, 38
260105..................................37, 38
260106..................................37, 38
260108..................................37, 38
260109..................................37, 38
260110........................................38
260111........................................38
260112........................................38
260113........................................38
260114........................................38
260124........................................38
260145........................................38
260238........................................38
260306..................................37, 38
260415........................................38
260521........................................39
260523........................................39
263265........................................33
286211........................................41
286517........................................41
286621........................................41
306271........................................69
306436........................................45
306449........................................73
306455........................................46
306460........................................69
306520..................................16, 17
306523........................................27
306531..................................22, 41
306556............................27, 28, 29
306674........................................22
306687........................................63
306875........................................45
306876........................................46
306982........................................22
307427........................................34
307637........................................14
307696........................................11
307727..................................73, 74
307742........................................58
307878..................................26, 30
307879........................................41
307880............... 27, 28, 29, 30, 40
307882........................................25
307883............................16, 17, 40
307884..................................16, 17
307906..................................12, 14
307965........................................63
308035........................................74
308069........................................41
308149........................................44
308154........................................75
308155........................................43
308163........................................75
308238........................................10
308306..................................46, 70
308326........................................33
Part No.
Page No.
308335........................................17
308368........................................33
308390........................................43
308391........................................43
308395........................................44
308403............................10, 11, 18
308441........................................33
308479........................................33
308546........................................53
308553........................................33
308573........................................33
308607..........................................8
308639........................................33
308642............................61, 62, 67
308667........................................72
308719..................................73, 74
308777........................................22
308883........................................22
308896........................................46
308981........................................33
309194........................................73
309276........................................11
309345..................................28, 29
309351........................................16
309353........................................42
309407........................................22
309442........................................54
309868........................................16
309869........................................12
309966........................................22
309967........................................24
311211........................................20
311216........................................36
311238............................20, 21, 32
311304........................................39
311305........................................38
311306........................................38
311307........................................38
311690........................................20
311717........................................21
311825........................................21
311826........................................21
311831........................................20
311832........................................20
311833........................................21
312371........................................32
312373........................................32
312375........................................32
312376........................................32
312417..........................................7
312668........................................59
312789........................................66
312862..................................20, 21
312863........................................32
312865........................................60
312877........................................33
312964..........................................7
313008..........................................5
313013..........................................6
313046..........................................6
313048........................................63
313104..........................................5
313106..........................................5
313108..........................................5
313112..........................................5
313114..........................................5
313431........................................52
512874........................................30
512926..........................................9
512927..........................................9
514037..........................................9
514150....................................9, 11
601950........................................77
647666........................................33
www.graco.com
Index
Part No.
Page No.
685984..................................33, 42
948392........................................30
948393........................................30
965124........................................28
965129..................................28, 29
D0B005 .......................................33
D0B525 .......................................33
D0F005........................................33
D0F525........................................33
D0K005 .......................................33
D0K525 .......................................33
D03005 .......................................33
D03255 .......................................33
D05007 .......................................33
D05277 .......................................33
D31255 .................................33, 42
DB5525 .......................................33
DF3525........................................33
DK3525 .......................................33
HEH13D .......................................56
HEH33D .......................................48
HEL13D..................................48, 56
HEL15D..................................48, 56
HEL23D..................................48, 56
HEL25D..................................48, 56
HEL33D........................................48
HEM23D ................................48, 56
HEM33D ..........................48, 55, 56
HPH1DA .......................................50
HPH1DB .......................................50
HPH1DC .......................................50
HPH1DD .......................................50
HPH1DE .......................................50
HPH1DF .......................................50
HPH5DA .......................................50
HPH5DB .......................................50
HPH5DC .......................................50
HPH5DD .......................................50
HPH5DE .......................................50
HPH5DF .......................................50
HPH15A .......................................50
HPH15B .......................................50
HPH15C .......................................50
HPH15D .......................................50
HPH15E .......................................50
HPH15F .......................................50
HPH23A .......................................50
HPH23B .......................................50
HPH23C .......................................50
HPH23D .......................................50
HPH23E .......................................50
HPH23F .......................................50
HPH55A .......................................50
HPH55B .......................................50
HPH55C .......................................50
HPH55D .......................................50
HPH55E .......................................50
HPH55F .......................................50
HPL23A........................................50
HPL23B........................................50
HPL23C .......................................50
HPL23D .......................................50
HPL23E ........................................50
HPL23F ........................................50
HPL25A........................................50
HPL25B........................................50
HPL25C .......................................50
HPL25D .......................................50
HPL25E ........................................50
HPL25F ........................................50
HPL33A........................................50
HPL33B........................................50
HPL33C .......................................50
HPL33D .......................................50
HPL33E ........................................50
www.graco.com
Part No.
Page No.
HPL33F ........................................50
HPL56A........................................50
HPL56B........................................50
HPL56C .......................................50
HPL56D .......................................50
HPL56E ........................................50
HPL56F ........................................50
HPL65A........................................50
HPL65B........................................50
HPL65C .......................................50
HPL65D .......................................50
HPL65E ........................................50
HPL65F ........................................50
HPM3BA ......................................50
HPM3BB ......................................50
HPM3BC ......................................50
HPM3BD ......................................50
HPM3BE.......................................50
HPM3BF.......................................50
HPM6DA ......................................50
HPM6DB ......................................50
HPM6DC ......................................50
HPM6DD ......................................50
HPM6DE ......................................50
HPM6DF.......................................50
HPM33A ......................................50
HPM33B ..........................50, 55, 82
HPM33C ......................................50
HPM33F .......................................50
HPM65A ......................................50
HPM65B ................................50, 82
HPM65C ......................................50
HPM65D ......................................50
HPM65E .......................................50
HPM65F .......................................50
HRH55A .......................................49
HRH55B .................................49, 55
HRH55C .......................................49
HRH55D .......................................49
HRH55E .......................................49
HRH55F .......................................49
HRL56A .......................................49
HRL56B .................................49, 55
HRL56C .......................................49
HRL56D .......................................49
HRL56E ........................................49
HRL56F ........................................49
HRL65A .......................................49
HRL65B .......................................49
HRL65C .......................................49
HRL65D .......................................49
HRL65E ........................................49
HRL65F ........................................49
HRM33D ......................................50
HRM33E.......................................50
HRM65A ......................................49
HRM65B ................................49, 55
HRM65C ......................................49
HRM65D ......................................49
HRM65E.......................................49
HRM65F.......................................49
HSH1DA .......................................52
HSH1DB .......................................52
HSH1DF .......................................52
HSH1DG .......................................52
HSH5DA .......................................52
HSH5DB .......................................52
HSH5DF .......................................52
HSH5DG .......................................52
HSH15A .......................................52
HSH15B .......................................52
HSH15F .......................................52
HSH15G .......................................52
HSH55A .......................................52
HSH55B .......................................52
Part No.
Page No.
HSH55F .......................................52
HSH55G .......................................52
HSHC5A .......................................52
HSHC5B .......................................52
HSHC5F .......................................52
HSHC5G .......................................52
HSHCDA .......................................52
HSHCDB .......................................52
HSHCDF .......................................52
HSHCDG.......................................52
HSHFFA........................................52
HSHFFB........................................52
HSHFFF ........................................52
HSHFFG .......................................52
HSL25A........................................52
HSL25B........................................52
HSL25F ........................................52
HSL25G .......................................52
HSL33A........................................52
HSL33B........................................52
HSL33F ........................................52
HSL33G .......................................52
HSL56A........................................52
HSL56B........................................52
HSL56F ........................................52
HSL56G .......................................52
HSL65A........................................52
HSL65B........................................52
HSL65F ........................................52
HSL65G .......................................52
HSLC8A .......................................52
HSLC8B .......................................52
HSLC8F........................................52
HSLC8G .......................................52
HSLD5A .......................................52
HSLD5B .......................................52
HSLD5F........................................52
HSLD5G .......................................52
HSLE3A ........................................52
HSLE3B ........................................52
HSLE3F ........................................52
HSLE3G........................................52
HSM3BA ......................................52
HSM3BB ......................................52
HSM3BF.......................................52
HSM3BG ......................................52
HSM6DA ......................................52
HSM6DB ......................................52
HSM6DF.......................................52
HSM6DG ......................................52
HSM33A ......................................52
HSM33B ......................................52
HSM33F .......................................52
HSM33G ......................................52
HSM65A ......................................52
HSM65B ......................................52
HSM65F .......................................52
HSM65G ......................................52
HSMC8A ......................................52
HSMC8B ......................................52
HSMC8F.......................................52
HSMC8G ......................................52
HSMCFA.......................................52
HSMCFB.......................................52
HSMCFF .......................................52
HSMCFG ......................................52
HSMD5A ......................................52
HSMD5B ......................................52
HSMD5F.......................................52
HSMD5G ......................................52
HSMDDA ......................................52
HSMDDB ......................................52
HSMDDF ......................................52
HSMDDG ......................................52
HSPB8A .......................................52
HSPB8B .......................................52
HSPB8F........................................52
HSPB8G .......................................52
87
ABOUT GRACO
Founded in 1926, Graco is a world leader in fluid handling systems and components. Graco products
move, measure, control, dispense and apply a wide range of fluids and viscous materials used
in vehicle lubrication, commercial and industrial settings.
The company’s success is based on its unwavering commitment to technical excellence, world-class
manufacturing and unparalleled customer service. Working closely with qualified distributors, Graco
offers systems, products and technology that set the quality standard in a wide range of fluid handling
solutions. Graco provides equipment for spray finishing, protective coating, paint circulation, lubrication,
and dispensing sealants and adhesives, along with power application equipment for the contractor
industry. Graco’s ongoing investment in fluid management and control will continue to provide
innovative solutions to a diverse global market.
GRACO LOCATIONS
MAILING ADDRESS
P.O. Box 1441
Minneapolis, MN 55440-1441
Tel: 612-623-6000
Fax: 612-623-6777
AMERICAS
ASIA PACIFIC
Graco Australia Pty Ltd.
Suite 17, 2 Enterprise Drive
Bundoora, Victoria 3083
Australia
Tel: 61 3 9467 8558
Fax: 61 3 9467 8559
Graco Hong Kong Ltd.
India Liaison Office
Room 432, Augusta Point
Regus Business Centre 53
Golf Course Road
Gurgaon, Haryana
India 122001
Tel: 91 124 435 4208
Fax: 91 124 435 4001
CHINA
JAPAN
Graco Hong Kong Ltd.
Shanghai Representative Office
Room 118 1st Floor
No.2 Xin Yuan Building
No.509 Cao Bao Road
Shanghai, 200233
The People’s Republic of China
Tel: 86 21 649 50088
Fax: 86 21 649 50077
Graco K.K.
1-27-12 Hayabuchi
Tsuzuki-ku
Yokohama City, Japan 2240025
Tel: 81 45 593 7300
Fax: 81 45 593 7301
AUSTRALIA
MINNESOTA
Worldwide Headquarters
Graco Inc.
88 -11th Avenue N.E.
Minneapolis, MN 55413
EUROPE
BELGIUM
European Headquarters
Graco N.V.
Industrieterrein-Oude Bunders
Slakweidestraat 31
3630 Maasmechelen,
Belgium
Tel: 32 89 770 700
Fax: 32 89 770 777
SALES/
DISTRIBUTION/
SERVICE
INDIA
KOREA
Graco Korea Inc.
Shinhan Bank Building
4th Floor #1599
Gwanyang-Dong, Dongan-Ku,
Anyang-si, Korea 431-060
Tel: 82 31 476 9400
Fax: 82 31 476 9801
Call today for product information or to speak with a Graco representative.
800-533-9655 or visit us at www.graco.com.
Graco Inc. is registered to I.S. EN ISO 9001
North America
Customer Service
800-533-9655
Fax 800-533-9656
©2009 Graco Inc. 303245 Rev. H 11/09 All written and visual data contained in this document are based on the latest product information available at the time
of publication. Graco reserves the right to make changes at any time without notice. All other brand names or marks are used for identification purposes and
are trademarks of their respective owners.

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
