Operator's Manual – Fast Draw

© LAI GAMES

INSTALLING GUN BRACKET AND LEATHER

HOLSTER

For transportation safety we put the gun, bracket and leather holster with 4 L bolts

M5x 15 on top of the control panel,

Installation process, before proceed you need to equipped your self with M5 Allen key.

Step 1.

Take the gun, bracket and leather holster from control panel. As shown down here

Step 2.

Unscrew 4 L bolts on each side of control panel, as shown below,

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

Step 3,

Open the control panel by pull the whole control panel as shown below,

Step 4,

Position the bracket on it’s hole until all the four hole match with bracket inside the control panel as shown below,

Step 5,

Screw the 4 supplied L bolts to hold the bracket as shown below,

Step 6 Finishing,

Close the control panel and screw the 4 L bolts to it’s position,

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

TABLE OF CONTENTS

INSTALLING GUN BRACKET AND LEATHER HOLSTER ................................

II

TABLE OF CONTENTS ......................................................................................... IV

SAFETY PRECAUTIONS .......................................................................................... 1

MACHINE INSTALLATION

AND

INSPECTION ................................................... 2

INTRODUCTION ........................................................................................................ 3

SPECIFICATIONS .................................................................................................... 4

HOW TO PLAY ......................................................................................................... 5

OPERATION ............................................................................................................... 6

OPERATIONAL DIAGRAM .................................................................................. 6

POWER UP ............................................................................................................ 6

ATTRACT MODE .................................................................................................. 6

GAME PLAY MODE.............................................................................................. 6

GUN ALIGNMENT MODE ...................................................................................... 7

GUN ALIGNMENT SCREEN ................................................................................ 7

TEST MODE ............................................................................................................. 8

TEST MODE MAIN SCREEN V2.0 ....................................................................... 8

TEST MODE PROCEDURE.................................................................................. 8

TEST MODE OPTIONS DETAILED ..................................................................... 9

SETTINGS ............................................................................................................ 10

SETTINGS SCREEN ............................................................................................ 10

SETTINGS DETAILED ........................................................................................ 11

AUDITS ................................................................................................................ 12

AUDITS SCREEN ................................................................................................ 13

PARTS OF AUDITS SCREEN ............................................................................. 13

AUDITS DETAILED ............................................................................................ 13

SWITCH TEST ..................................................................................................... 14

SWITCH TEST SCREEN...................................................................................... 15

SCREEN TEST ..................................................................................................... 15

SCREEN TEST MAIN SCREEN........................................................................... 16

SCREEN TEST DETAILED ................................................................................. 16

SOUND TEST ...................................................................................................... 17

SOUND TEST SCREEN ....................................................................................... 17

SOUND TEST DETAILED .................................................................................. 17

ERRORS AND TROUBLESHOOTING ................................................................. 18

TROUBLESHOOTING GAME ERRORS ............................................................ 18

FUSE INFORMATION ........................................................................................... 19

FUSE LOCATION DIAGRAM ............................................................................. 19

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SECTION A: SERVICE INSTRUCTIONS ........................................................... 20

LOCATING AND ACCESSING PARTS ............................................................... 21

PARTS LOCATION DIAGRAM ........................................................................... 21

PARTS DESCRIPTION ........................................................................................ 23

LAMPS .................................................................................................................... 25

MAINTENANCE .................................................................................................... 26

SECTION B: TECHNICAL DETAILS ................................................................... 27

MAINS VOLTAGE ADJUSTMENT ...................................................................... 28

TICKET DISPENSER REFERENCE GUIDE ........................................................ 29

FAST DRAW JAMMA & CONNECTOR LIST ..................................................... 34

3D EXPLODE PARTS ............................................................................................ 35

FAST DRAW WIRING DIAGRAM ....................................................................... 36

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SAFETY PRECAUTIONS

The following safety precautions and advisories are used throughout this manual and are defined as follows.

* WARNING! *

Disregarding this text could result in

serious injury.

Disregarding this text could result in damage to the machine.

* CAUTION! *

* NOTE! *

An advisory text to hint or help understanding.

BE SURE TO READ THE FOLLOWING

* WARNING! *

Always turn OFF Mains AC power and unplugged the game, before opening or replacing any parts.

Always when unplugging the game from an electrical outlet, grasp the plug, not the line cord.

Always connect the Game Cabinet to grounded electrical outlet with a securely connected ground line.

Do Not install the Game Cabinet outdoors or in areas of high humidity, direct water contact, dust, high heat or extreme cold.

Do Not install the Game Cabinet in areas that would present an obstacle in case of an emergency, i.e. near fire equipment or emergency exits.

* CAUTION! *

Always use a Digital Multimeter, logic tester or oscilloscope for testing integrated circuit (IC) logic PC boards. The use of a continuity tester is not permitted.

Do Not Connect or disconnect any of the integrated circuit (IC) logic PC boards while the power is

ON.

Do Not use any fuse that does not meet the specified rating.

Do Not Subject the game cabinet to extreme temperature variations.

Reliability of electrical components deteriorates rapidly over 60 o

C.

Page 1

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

MACHINE INSTALLATION and INSPECTION

When installing and inspecting “Fast Draw”, be very careful of the following points and pay attention to ensure that the players can enjoy the game safely.

Be sure to turn the power OFF before working on the machine.

* WARNING! *

Always Turn OFF mains power before removing safety covers and refit all safety covers when work is completed.

Make sure the power cord is not exposed on the surface (floor, ground, etc.) where people walk through.

Check that the rubber glide feet levelers are set evenly on the floor so that the game cabinet is unable to roll and is stable.

Always make complete connections for the integrated circuit (IC) logic PC Boards and other connectors. Insufficient insertion can damage the electrical components.

* CAUTION! *

Before switching the machine on be sure to check that it has been set on the correct voltage for your area!

Refer to the mains voltage adjustment section of this manual. Machines are normally shipped on 220V AC unless otherwise specified.

Only qualified personnel should inspect or test the integrated circuit (IC) logic PC

Boards.

If any integrated circuit (IC) logic PC Boards should need servicing. Please contact the nearest LAI GAMES distributor. (Refer to the back page of this manual)

Page 2

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

INTRODUCTION

CONGRATULATIONS! You have just bought the “Fast Draw”, another great product from LAI GAMES. In the Wild West, it was easy to tell the difference between

Glass

and Cans. In this fast action shooting game, players have to make quick decisions to shoot only the Cans and not to shoot Glass.

We hope you take the time to read this manual and learn about the many other features and user-friendly adjustments that can be made to “fine-tune” the game for maximum earning potential.

DESCRIPTION

The “Fast Draw” is a single player fast action shooting game. Players aim to shoot as many Cans before the game timer expires. The more Cans hit, the more tickets won.

PACKAGING

At delivery, the machine should arrive in good condition. To move the packaged machine for transport or placement, use a forklift and take care not to hit the package or stack heavy objects on top, as this may cause damage to the machine.

CONTENTS

The “Fast Draw” cabinet

Keys: 2 x coin door keys

2 x back door keys

2 x ticket door key

Operator’s manual

IEC Power Cord

Parts & Accessories

(In cash box)

(In cash box)

Page 3

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SPECIFICATIONS

DIMENSIONS

Weight: 160 kg (353lb)

Height: 2134.5mm (84”)

Width: 989 mm

Length: 895 mm

Power: Maximum 450 W – (220V @ 2.1A)(120V @ 3.8A)

(39)

(35”)

ELECTRIC SUPPLY

The game has the option to operate on a 110V, 120V, 220V or 240V AC 50/60Hz single phase mains electric supply.

The supply must be a three wire grounded supply.

* CAUTION! *

Before switching the machine on be sure to check that it has been set on the correct voltage for your area!

Please Refer to the mains voltage adjustment section of this manual. Machines are normally shipped on 220V AC unless otherwise specified.

LOCATION REQUIREMENTS

Ambient temperature: between 5 o

C and 40 o

C.

Ambient humidity: Low

Ambient U.V. radiation: Very low

Vibrations level: Low

Page 4

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

HOW TO PLAY

PLAYERS SHOOT CANS TO

SCORE POINTS FOR TICKETS

Insert coin/s for credits.

Take the Gun from the holster and

Press the Start Button to begin a game.

Use the Gun to shoot the Cans when the windows open to score points.

The faster you can shoot the Cans the more sets of windows are available before the game timer expires.

Shooting the glass will result in lost time and points.

Bonus Round can be played by shooting a certain number of Cans before the game timer expires.

In Bonus Round, try to shoot all the

Cans before the window sets change.

Tickets are awarded based on points scored during the game.

At the end of a game, Extra Tickets can be won by shooting one of the closed windows in the Mystery Bonus Round.

Players with the highest scores can use the gun to enter their initials for display in the High Score table.

Page 5

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

OPERATION

The “Fast Draw” game has five operational modes: Power Up mode, Attract mode,

Game Play mode, Gun Alignment Mode and Test Mode.

OPERATIONAL DIAGRAM

GUN ALIGNMENT

MODE

POWER UP

Loading Please Wait!

ATTRACT

MODE

GAME PLAY

MODE

TEST

MODE

Settings

Audits

Switch Test

Screen Test

Sound Test

Exit

POWER UP

The Power Up mode is active when power is first applied to the game. During this time, a LOADING PLEASE WAIT! phrase will appear on screen. Please wait for about 10 seconds for the loading to complete.

ATTRACT MODE

The Attract mode provides game sound and display while the game is not being played. This feature is to attract potential customers to play the game.

GAME PLAY MODE

The “Fast Draw” has two play modes. The Standard Coin Play mode, where a coin, or coins are inserted. Or Free Play where no coins are necessary.

COIN PLAY

The Coin Play mode is entered from Attract mode, by inserting coins in any of the two coin slots on the front of the machine cabinet, then following the instructions in the “How to Play” section of this manual.

FREE PLAY

The Free Play mode is entered by setting the Coin per Credit to “free”.

(For Coin per Play settings, see page 8)

For a single free game, just press the Service button once. When issuing single free games in this manner, Tickets can be won as normal.

Page 6

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

GUN ALIGNMENT MODE

The “Fast Draw” has a Gun Alignment Mode allowing you to set the calibration for gun accuracy. To enter Gun Alignment Mode, press the yellow Gun Calibration push button located on the service bracket.

The screen will display a background with white and red targets; one will appear in the upper left of the screen and the other in the lower right. To calibrate the gun alignment, aim and shoot first the upper left target and then the lower right target. The game will exit into Attract Mode automatically.

(Refer to the Gun Alignment Screen below).

GUN ALIGNMENT SCREEN

Aim & Shoot this

Target First

Aim & Shoot this

Target Second

Page 7

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

TEST MODE

The “Fast Draw” has Test Mode from which you can adjust the game settings, see the audits, do switch test, screen test, and sound test. From the main screen of the Test

Mode you can choose one of the six options available that is suitable to your need.

(Refer to the Test Mode Main Screen below).

TEST MODE MAIN SCREEN V2.0

Settings

Audits

Switch Test

Screen Test

Sound Test

Exit

TEST MODE PROCEDURE

ENTER The Test Mode can be entered by pressing the red Test button located on the service bracket while in Attract mode once.

SELECT The green Service button is pressed to step through each of the Test

Mode options, starting from Settings stepping down through Exit and then looping again until the mode is exited.

* NOTE! *

By holding down the

SERVICE button, you can step through the options quicker.

ENTERING OPTIONS SETTINGS

The two white Up and Down buttons are used to enter the chosen Test

Mode option.

EXIT The Test mode is exited by highlighting the Exit using Service button and pressing one of the white buttons.

Page 8

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SERVICE BRACKET

Coin

Meter

Gun Calibrate

Push Button

UP

Push Button

DOWN

Push Button

TEST MODE OPTIONS DETAILED

SETTINGS

Highlighting

SETTINGS and pressing one of the two white buttons will advance to the Settings screen. In this screen you can do some adjustments related to the game.

AUDITS

Highlighting AUDITS and pressing one of the two white buttons will advance to the Audits screen. In this screen you can see the audits of the game.

SWITCH TEST

This test is used to test all the game switches. To enter the Switch Test, highlight

SWITCH TEST in the Test Mode main screen and press one of the white buttons.

SCREEN TEST

This test is used to test the game screen. To enter the Screen Test, highlight

SCREEN TEST in the Test Mode main screen and press one of the white buttons.

SOUND TEST

This test is used to test the audio channel of the game. To enter the Sound Test, highlight SOUND TEST in the Test Mode main screen and press one of the white buttons.

EXIT

To exit the Test Mode main screen, highlight EXIT in the Test Mode main screen and press one of the white buttons.

Ticket

Meter

SERVICE

Push Button

TEST

Push Button

Volume

Control

Page 9

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SETTINGS

ENTER The Settings can be entered by highlighting SETTINGS while in Test

Mode main screen and pressing the white buttons. Or, by pressing the red Test button while in Attract mode once, highlighting SETTINGS, and pressing the white buttons.

SELECT The Service button is pressed to step through each of the adjustment configurations, starting from the highlighted “Cancel” dialog button, stepping through each adjustment and then looping again until the

Settings is exited.

CHANGE The two white buttons change the displayed value, Up to increase and

Down to decrease. For the dialog buttons, either of the white buttons will activate the highlighted dialog button.

* NOTE! *

Certain adjustments have a fast adjustment feature. By holding down the

UP or DOWN push buttons, the values step through quicker.

EXIT The Settings is exited into Test Mode main screen by highlighting and pressing one of the white buttons on the “OK” dialog button to exit & save the changes. Or by highlighting and pressing the white buttons on the “CANCEL” dialog button to exit without saving the changes.

SETTINGS SCREEN

Page 10

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SETTINGS DETAILED

CANCEL

(Exit Without Save Changes)

Highlighting the CANCEL dialog button and pressing either of the two white buttons will exit the Settings without save any changes made.

OK

(Exit & Save Changes)

Highlighting the OK dialog button and pressing either of the two white buttons will exit the Settings and save any changes made.

RESET DEFAULT

(Reset all Adjustments to Default)

Highlighting the RESET DEFAULT dialog button and pressing either of the two white buttons will reset all adjustments back to factory defaults.

BASE TIME

(Default 45) (Adjustable 45 – 90, Steps ±15)

This variable sets the minimum time a game will play, this is regardless if player hits or misses any Cans.

COINS PER CREDIT

(Default 1) (Adjustable Free, 1 – 5, Steps ±1)

This sets the number of coins that need to be inserted into the coin mechanisms for each credit. The setting “Free” will sets the game in Free Play Mode.

BONUS ROUND TIME

(Default 15) (Adjustable 10 – 30, Steps ±5)

This variable sets the time in seconds that the bonus round is active. Bonus Round

Time is added to the Base Time if the play hits the required number of Cans.

CANS HIT FOR BONUS

(Default 50) (Adjustable 20 – 100, Steps ±5)

This variable sets the number of Cans that need to be hit to get to the bonus round.

MYSTERY BONUS AVERAGE

(Default 5) (Adjustable 1 – 9, Steps ±1)

This variable sets the desired number of tickets the operator would like to average on the Mystery Bonus Round at the end of a game.

JACKPOT TICKETS

(Default 10) (Adjustable 1 – 20, Steps ±1)

This variable sets the maximum number of Jackpot tickets that can be won on a

Mystery Bonus Round at the end of a game.

Page 11

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

TICKET PAYOUT

(Default ON) (Adjustable ON-OFF)

This setting turns the ticket payout ON or OFF. If sets to ON, the machine will payout tickets won by player. If sets to OFF, the machine will not dispense any tickets.

ATTRACT MODE SOUNDS

(Default ON) (Adjustable ON-OFF)

This adjustment turns the attract mode sounds ON or OFF. This is the sound and music that the game generates to attract customers when it is not being played.

CALIBRATE X

&

CALIBRATE Y

(Displayed for Information Only)

This displays the X & Y off-set values stored in memory for the Gun Calibration.

The display of “#” indicates an invalid value and calibration is required.

TICKET PAYOUT TABLE

(Adjustable 0 – 30,000, Steps ±50)

Default Values

No. of Tickets

1

2

3

4

Score

0

1500

3000

4500

No. of Tickets

5

6

+1

Score

6000

7500

3000

These variables set the number of score points required for tickets. The points needed from 1 to 6 tickets can be set individually for scalable payout. For more then 6 tickets, +1 is set to the number of extra points needed for each additional ticket above 6 tickets.

* NOTE! *

It is recommended that Number of Tickets 1 to 6 have progressively increasing score values, or unpredictable ticket payout may occur.

AUDITS

ENTER The Audits can be entered by highlighting AUDITS while in Test

Mode main screen and pressing the white buttons. Or, by pressing the red Test button while in Attract mode once, highlighting

AUDITS, and pressing the white buttons.

SELECT

The Service button is pressed to step between “Clear” and “Exit” dialog buttons repeatedly until the Audits is exited.

ACTIVATE The two white buttons will activate the highlighted dialog button.

EXIT The Audits is exited into Test Mode main screen by highlighting and pressing one of the white buttons on the “Exit” dialog button.

Page 12

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

AUDITS SCREEN

PARTS OF AUDITS SCREEN

USER

The User section enables the operator to see statistics for number of coins inserted, tickets dispensed, Service button pressed, and games played since the last game audits cleared. The statistics in this section can be cleared by highlighting the Clear dialog button, press one of the white buttons, and choose YES in the dialog box that appears. automatically stop increasing.

* NOTE! *

If an audit value in the User section reaches the value of 999,999, it will

MACHINE

The Machine section displays total statistics for number of coins inserted, tickets dispensed, Service button pressed, and games played. The statistics in this section is the total number of statistics that were in the User section. Every statistics that were in the User section will be added to statistics in this section. Statistics in this section can not be cleared. reset itself to 0.

* NOTE! *

If an audit value in the Machine section reaches the value of 999,999, it will

AUDITS DETAILED

CLEAR

Highlighting the CLEAR dialog button, pressing either of the two white buttons, and choosing YES in dialog box appeared will clear the statistics in the User section.

Page 13

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

EXIT

Highlighting the EXIT dialog button and pressing either of the two white buttons will exit the Audits and go back to Test Mode main screen.

NUM COINS [ 1 ]

This audit tells the number of coins inserted into coin mechanism 1. It is available in User and Machine section.

NUM COINS [ 2 ]

This tells the number of coins inserted into coin mechanism 2. This audit is available in User and Machine section.

NUM TICKETS [ 1 ]

This audit tells the number of tickets payout from ticket mechanism 1. It is available in User and Machine section.

NUM TICKETS [ 2 ]

This audit tells the number of tickets payout from ticket mechanism 2. It is available in User and Machine section.

NUM SERVICES

This tells how many times the Service button are pressed since the last game audits cleared. This audit is only available in the User section of the Audits.

TOTAL GAME PLAYS

This audit tells the number of games played. It is available in User and Machine section of the Audits.

SWITCH TEST

ENTER The Switch Test can be entered by highlighting SWITCH TEST while in Test Mode main screen and pressing the white buttons. Or, by pressing the red Test button while in Attract mode once, highlighting

SWITCH TEST, and pressing the white buttons.

TESTING GAME SWITCHES

To test the game switches, activate any of the game switches and see in the Switch Test screen whether the activated switch is ON or OFF.

When ON the switch is active, if OFF the switch is not active.

TICKET DISPENSER NOTCH

The Ticket Notch Switch (C1) can be activated or deactivated from the

Ticket Feed Button on the Ticket Dispenser PCB or by manually pushing the tickets from the ticket holder through the dispenser after pulling the ticket release rod upwards.

Page 14

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

Ticket Tensioning mechanism

Ticket release rod

For more information on the servicing and testing the ticket dispenser

* NOTE! *

please look at the Dispenser Reference guide.

EXIT The Switch Test is exited into Test Mode main screen by pressing the

Service button once.

SWITCH TEST SCREEN

SCREEN TEST

ENTER The Screen Test can be entered by highlighting SCREEN TEST while in Test Mode main screen and pressing the white buttons. Or, by pressing the red Test button while in Attract mode once, highlighting

SCREEN TEST, and pressing the white buttons.

Page 15

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SELECT The Service button is pressed to step through each of the Screen Test options available, starting from Scale stepping down through Exit and then looping again until the Screen Test is exited.

ENTERING OPTIONS SETTINGS

One of the white Up and Down buttons is pressed to enter the chosen

Screen Test option.

EXIT The Screen Test is exited by highlighting the Exit using Service button and pressing one of the white buttons.

SCREEN TEST MAIN SCREEN

Scale

Full Screen

Grid

Exit

SCREEN TEST DETAILED

SCALE

This option is used for adjusting the color balance of the screen monitor. To enter the color Scale display, highlight Scale in the Screen Test main screen and press one of the white buttons. The color Scale display is exited into Screen Test main screen by pressing Service button once.

FULL SCREEN

Full Screen display is used for adjusting the color purity of the screen monitor. It is entered by highlighting Full Screen in the Screen Test main screen and pressing one of the white buttons. The Full Screen display is exited into Screen Test main screen by pressing Service button once.

GRID

Grid is used for adjusting the screen geometric of the screen monitor. It is entered by highlighting Grid in the Screen Test main screen and pressing one of the white buttons. Grid is exited into Screen Test main screen by pressing Service button once.

EXIT

Highlighting Exit and pressing one of the white buttons will exit the Screen Test main screen and go back to Test Mode main screen.

Page 16

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SOUND TEST

ENTER The Sound Test can be entered by highlighting SOUND TEST while in Test Mode main screen and pressing the white buttons. Or, by pressing the red Test button while in Attract mode once, highlighting

SOUND TEST, and pressing the white buttons.

SELECT The Service button is pressed to step through each of the Sound Test options available, starting from Left Channel stepping down through

Exit and then looping again until the Sound Test is exited.

ENTERING OPTIONS SETTINGS

One of the white Up and Down buttons is pressed to enter the chosen

Sound Test option.

EXIT

The Sound Test is exited by highlighting the Exit using Service button and pressing one of the white buttons.

SOUND TEST SCREEN

Left Channel

Right Channel

Both Channel

Exit

SOUND TEST DETAILED

LEFT CHANNEL

This is for testing the left audio channel of the machine. When this option is chosen, sound will comes out only from the left audio channel. To test the Left

Channel, highlight Left Channel and press one of the white buttons while in

Sound Test screen.

RIGHT CHANNEL

This is for testing the right audio channel of the machine. When this option is chosen, sound will comes out only from the right audio channel. To test the Right

Channel, highlight Right Channel and press one of the white buttons while in

Sound Test screen.

BOTH CHANNELS

Both Channel is used to test both audio channels of the machine. When this option is chosen, sound will comes out from both audio channels. Highlight Both

Channel and press one of the white buttons while in Sound Test screen to test both audio channels.

EXIT

Highlighting Exit and pressing one of the white buttons will exit the Sound Test screen and go back to Test Mode main screen.

Page 17

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

ERRORS AND TROUBLESHOOTING

If the game microprocessor detects any problems with the operation of the game, an

Error will be displayed on the screen. There is one error message for Most Wanted, listed as follows:

SOLUTION ERROR DESCRIPTION

TICKET ERROR

Jammed tickets, no tickets or no ticket notch pulse for longer than

3 seconds.

Clear ticket/capsule dispenser jam or replenish tickets. After this, push Test button once to clear error.

TROUBLESHOOTING GAME ERRORS

CLEARING GAME ERRORS

Game errors can be cleared, by pushing the test button ONCE. The game will try and check if the error is fixed. If the reason for the error is fixed, the game will continue as normal. If the error is not fixed, the error will remain on the screen.

TICKET ERROR

This usually occurs if the game has run out of tickets or there is a ticket jam. A less common reason is if the game PCB tries to dispense tickets but doesn’t get a notch pulse for approximately three seconds. Test the notch pulse by passing a ticket in and out of the notch sensor.

If the game was out of tickets, replace the tickets, clear the ticket jam and then push the test button once to clear the error. The game will then payout any owed tickets.

Page 18

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

Main AC Supply

Fuse

6A QB M205

FUSE INFORMATION

* WARNING! *

Always turn OFF Mains power and unplugged the game, before replacing any fuses.

MAIN AC SUPPLY FUSE (1 x 6 AMP FAST BLOW, M205 TYPE)

This fuse is for the main AC supply and is situated in the IEC mains input socket.

* NOTE! *

The power cord must be removed before the fuse can be accessed.

MONITOR POWER FUSE (1 x 3 AMP FAST BLOW, M205 TYPE)

This fuse is for the power supply on the 29” SVGA Monitor PCB.

* CAUTION! *

Do Not use any fuse that does not meet the specified rating.

FUSE LOCATION DIAGRAM

As viewed from rear

Monitor Power

Fuse

3A QB M205

Page 19

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SECTION A: SERVICE INSTRUCTIONS

BE SURE TO READ THE FOLLOWING

Carefully before servicing this machine

A

Page 20

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Florescent FL15

Lamp

Operator's Manual – Fast Draw

© LAI GAMES

LOCATING AND ACCESSING PARTS

PARTS LOCATION DIAGRAM

As viewed from front

Header

Acrylic

Header Support

Poles

Front Monitor

Glass

Control

Panel

Start Button

Fiberglass

Molded Roof

29” SVGA

Monitor

Monitor

Display Area

Recoil Gun

& Holster

Ticket

Door

Game

Speakers

Rubber Glide

(Leg Levelers)

Coin

Door

Coin

Mechanisms

Casters

(4 units)

Page 21

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Ticket

Mechanism

Komodo

Game PCB

Ticket

Holder

+12/+5VDC

Power Supply

Power

Inlet (IEC)

Fiberglass

Molded Header

Fiberglass

Molded Roof

29” SVGA

Monitor Tube

Operator's Manual – Fast Draw

© LAI GAMES

PARTS LOCATION DIAGRAM

Cont.

As viewed from rear

Header

Vent

Upper

Vent

29” SVGA

Monitor PCB

Coin

Mechanisms

Service

Bracket

Cash Box &

Housing

Ballasts and

Starters

Lower

Vent

Page 22

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

PARTS DESCRIPTION

COIN MECHANISMS

The coin mechanisms can be accessed inside the Coin door on the front of the machine cabinet.

CASH BOX

The cash box is located inside the coin door on the front of the machine cabinet.

TICKET MECHANISM

The ticket mechanism can be accessed inside the ticket door to the Right on the front of the machine cabinet.

SPEAKERS

Two speakers are located to the front of the cabinet below the control panel.

Access is through the rear door.

SERVICE CONTROLS:

Located on the service panel mounted on top of the cash box and accessed through the Coin Door.

SERVICE BUTTON: Used to input credits to the game without activating the coin counter, and to perform adjustment procedures in combination with the test button

TEST BUTTON: Used to perform the adjustment mode, in combination with the

Service button.

UP BUTTON: Used to increase values in the adjustment mode, in combination with the Service & Test buttons.

DOWN BUTTON: Used to decrease values in the adjustment mode, in combination with the Service & Test buttons.

GUN CALIBRATE BUTTON: Used to enter the Gun Calibration Mode in combination with the Recoil Gun.

VOLUME KNOB: Used to adjust the speaker’s sound level.

Coin

Meter

Gun Calibrate

Push Button

Ticket

Meter

SERVICE

Push Button

UP

Push Button

TEST

Push Button

DOWN

Push Button

Volume

Control

Page 23

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

FUSES

Always turn OFF Mains power and unplugged the game, before replacing any

GAME CONTROLS:

Located in the center of the machine cabinet. The control panel can be Access through removing the six Allen head bolts on the control panel.

START BUTTON: The Start button is the large RED round illuminated button.

This button is used to start a game.

RECOIL GUN: The recoil gun is located at the right-hand side of the control panel in a leather holster. The gun is used to shoot targets on the screen.

POWER CORD

The power cord is a standard IEC power cord (as used on computers) that is plugged in to the power inlet socket at the rear of the machine. The power cord can be removed for transport.

POWER INLET

The power inlet is located at the rear of the machine on the Left-hand side as viewed from the rear. It is a standard IEC inlet socket.

MAINS SWITCH

The mains switch is located on the power inlet assembly along with the mains fuse, and IEC inlet socket.

For locations of all fuses refer to Fuses and Fuse location, of this manual.

fuses

Always use the correct rated fuse. Refer to fuse information.

PCB’s

For location of all game PCB’s, refer to the Parts Location diagram page of this manual.

POWER SUPPLY

* WARNING! *

The power supply is located at the back of the cabinet and is accessed from the rear of the machine. It is a multi voltage switching power supply.

BALLAST & STARTER

29” SVGA MONITOR

The header fluorescent ballast & starter is located at the back of the cabinet and is accessed from the rear of the machine. It is a 15W Ballast and F2 Starter.

The 29” SVGA Monitor is located to the left at the back of the cabinet and is accessed from the rear of the machine.

Page 24

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

LAMPS

* WARNING! *

Always turn OFF Mains power and unplugged the game, before replacing any lamps.

Always allow time for cooling as Lamps that have been active for a time may still be too hot to touch.

COIN DOOR LAMPS

The coin door lamps all are 12V/DC GE194 or equivalent and can be accessed through the coin door.

BUTTON LAMP

The button lamp is 12V/DC GE194 or equivalent and can be accessed through the coin door or back door.

HEADER LAMP

There is one standard FL 15 fluorescent tube for the Header Display. Access is by the removing of the machine header cover and accessing the tube from the front.

* CAUTION! *

Always replace the lamps with the same or equivalent size, wattage and voltage.

Page 25

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

MAINTENANCE

CLEANING AND CHECK UP

EXTERIOR

Regularly dust and clean the external cabinet areas as required, using a soft water-damp cloth and mild soap. Check for blown bulbs and replace as required.

Any scratches or marks in the fiberglass or acrylic can be buffed out using car polish or cut and polish.

INTERIOR

* CAUTION! *

Do not use solvents on the panels as it may affect the artwork.

Regularly dust and vacuum the interior of the cabinet, taking care to remove any objects that may have fallen on the PCBs. Check and tighten all fixing hardware and fasteners as required.

interior of the machine.

* WARNING! *

Always turn OFF Mains power and unplugged the game, before cleaning the

Always after cleaning the cabinet interior, check all harness connectors and restore all loose or interrupted connections.

Regularly check that the Button Lamp is operating and the Gun accuracy is good.

Replace the lamp if blown and calibrate the gun if necessary.

Page 26

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

SECTION B: TECHNICAL DETAILS

It is advised that anybody using SECTION B for repairing or modifying any of the components of the game should be a qualified technician, having at least a basic knowledge of digital components, integrated circuits and electricity.

B

Page 27

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

MAINS VOLTAGE ADJUSTMENT

POWER SUPPLY

The Switch Mode Power Supply has a switch to set the mains voltage range. It is located at the rear of the game cabinet, and is accessed via the back door. Use a thin blade screwdriver to move the selector switch to the desired mains voltage

(See Diagram Below)

FLORESCENT TUBE BALLASTS AND STARTERS

Locate the florescent tube ballasts and starters in the back of the cabinet. If unsure of the location of any ballasts or starters, refer to Parts location diagram on page

21 of this manual. These have to be removed and replaced with an equivalent wattage at you local mains voltage level.

29” SVGA MONITOR

The 29” SVGA Monitor is a “Voltage Free” type and can run on any AC source between 95VAC and 250VAC.

Page 28

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

TICKET DISPENSER REFERENCE GUIDE

Page 29

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

Page 30

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

Page 31

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

Page 32

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

Page 33

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

FAST DRAW JAMMA & CONNECTOR LIST

SOLDER SIDE

GND

GND

+5V

JAMMA

A 1

B 2

C 3

+5V D 4

E 5

+12V F 6

POLARIZING KEY H 7

SPEAKER +R

SPEAKER +L

(NC) GREEN*

(NC) SYNC*

SERVICE

PARTS SIDE

GND

GND

+5V

+5V

+12V

POLARIZING KEY

J 8

K 9

L 10

M 11

TICKET DRIVE

START LAMP

SPEAKER –R

SPEAKER –L

N 12

P 13

(NC) RED*

(NC) BLUE*

R 14 (NC) VIDEO GND*

S 15

COIN SWITCH 2 T 16

TRIGGER SWITCH U 17

DOWN SWITCH

V 18

W 19

X 20

CALIBRATE SWITCH Y 21

TEST

COIN SWITCH 1

START SWITCH

UP SWITCH

COIN COUNTER

A 22 a 23 b 24 TICKET NOTCH c 25 TICKET COUNTER

GND d 26 e 27 GND

GND f 28 GND

*Note: JAMMA Video Outputs used for CGA Games only.

Use the 15pin Monitor Plug for Fast Draw (VGA)

Check and adjust the +5VDC that it is between 4.8 and 5.1 Volts at the edge connector.

* NOTE! *

Polarity Key is to prevent accidental reverse insertion of edge connector

ULN DRIVER

1 RECOIL SOLENOID*

2 RECOIL SOLENOID*

3 RECOIL SOLENOID*

4 RECOIL SOLENOID*

5 (NC)

6 (NC)

7 (NC)

8 (NC)

9 (NC)

*Note: Solenoid Drivers all

Wired in Parallel

EXTERNAL VOLUME

1 AUDIO RETURN 1

2 AUDIO OUT 1

3 AUDIO RETURN 2

4 AUDIO OUT 2

5 AUDIO GND (SHIELD)

Note: Set onboard volume to

Minimum levels when

Using external controls

GUN CONNECTOR

1 OPTICAL INPUT

2 +5VDC

3 (NC)

4 (NC)

5 LOGIC GND

Page 34

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

3D EXPLODE PARTS

Page 35

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

FAST DRAW WIRING DIAGRAM

Page 36

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Operator's Manual – Fast Draw

© LAI GAMES

DISCLAIMER

OPERATOR WILL TAKE NOTE.

BY ACCEPTING DELIVERY OF AND PLACING THIS HARDWARE AND

LICENSED SOFTWARE INTO OPERATION, OPERATOR REPRESENTS AND

WARRANTS THAT IT WILL ONLY OPERATE THE HARDWARE AND

LICENSED SOFTWARE PROVIDED BY LAI GAMES IN COMPLIANCE WITH

THE REGULATORY REQUIREMENTS OF THE COUNTRY, STATE, AND/OR

MUNICIPALITY IN WHICH THE HARDWARE AND LICENSED SOFTWARE

ARE USED AND/OR OPERATED. LAI GAMES HAS PROVIDED THIS

HARDWARE AND LICENSED THE SOFTWARE ONLY FOR LEGITIMATE

AND LEGAL USE, AND ANY USE OF THE HARDWARE AND LICENSED

SOFTWARE IN A MANNER THAT VIOLATES ANY LAWS OF THE

COUNTRY, STATE, AND/OR MUNICIPALITY IN WHICH THE HARDWARE

AND LICENSED SOFTWARE ARE USED AND/OR OPERATED IS WHOLLY

UNAUTHORIZED AND SHALL BE AT OPERATOR’S SOLE AND COMPLETE

RISK.

Operator assumes any and all risk and liability for any civil or criminal legal claims or causes of action arising from the unauthorized use and/or operation of the provided hardware and licensed software, such improper and unauthorized use specifically including, but not limited to:

(a) Operating or allowing the operation of the hardware and licensed software in a manner that violates the laws and regulations of the country, state, and/or municipality in which the hardware and licensed software are used or operated;

(b) Assembling or causing the assembly of the hardware in a manner not authorized by or disclosed in this manual;

(c) Any tampering with, changes to, or modifications of the licensed software that occur after the software leaves LAI GAMES’ factory that is not made by authorized LAI GAMES personnel and that is directly or indirectly caused by Operator; and

(d) Any tampering with the computer chip/electronic programmable read only memory (EPROM) by or on behalf of Operator that directly or indirectly causes the tamper-indicating holographic seal on the computer chip/EPROM to be broken or damaged in any way.

LAI GAMES shall have no liability related to such improper and unauthorized use and/or operation of the hardware and licensed software, and Operator shall indemnify, defend, and hold LAI GAMES harmless for any claim or cause of action brought against LAI GAMES arising from Operator’s or Operator’s representative’s improper and unauthorized use and/or operation of the hardware and licensed software.

ANY IMPROPER AND UNAUTHORIZED USE SHALL COMPLETELY AND

TOTALLY VOID ANY AND ALL WARRANTIES, BOTH EXPRESS AND

IMPLIED, OF THE HARDWARE AND LICENSED SOFTWARE PROVIDED BY

LAI GAMES.

Page 37

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

WARRANTY

LAI GAMES warrants its manufactured products for a period of 3 months inclusive of parts and labor from the date of sale.

LAI GAMES exclusive obligation is to repair any item with any defects as a result of faulty workmanship or materials, providing the defective item or items of equipment are returned to the LAI GAMES distributor from which the machine was purchased.

LAI GAMES shall have no obligation to make repairs necessitated by negligence or interference to any component by any unauthorized personal. This will automatically void any existing warranty.

IF MAKING A WARRANTY CLAIM:

(a) A Copy of the sales invoice must accompany the claim.

(b) To and from Transport and freight costs are not covered by the warranty.

(c) Warranty is not transferable with the sale of a machine from one owner to another.

LAI GAMES

[email protected]

www.laigames.com

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
