Owners Manual

S&S® V-Series Engines

DISCLAIMER:

S&S parts are designed for high performance, closed course, racing applications and are intended for the very experienced rider only. The installation of S&S parts may void or adversely effect your factory warranty. In addition such installation and use may violate certain federal, state, and local laws, rules and ordinances as well as other laws when used on motor vehicles used on public highways, especially in states where pollution laws may apply. Always check federal, state, and local laws before modifying your motorcycle. It is the sole and exclusive responsibility of the user to determine the suitability of the product for his or her use, and the user shall assume all legal, personal injury risk and liability and all other obligations, duties, and risks associated therewith.

The words Harley®, Harley-Davidson®, H-D®, Sportster®, Evolution®, and all H-D part numbers and model designations are used in reference only. S&S Cycle is not associated with Harley-Davidson, Inc.

SAFE INSTALLATION AND OPERATION RULES:

Before installing your new S&S part it is your responsibility to read and follow the installation and maintenance procedures in these instructions and follow the basic rules below for your personal safety.

• Gasoline is extremely flammable and explosive under certain conditions and toxic when breathed. Do not smoke. Perform installation in a well ventilated area away from open flames or sparks.

• If motorcycle has been running, wait until engine and exhaust pipes have cooled down to avoid getting burned before performing any installation steps.

• Before performing any installation steps disconnect battery to eliminate potential sparks and inadvertent engagement of starter while working on electrical components.

• Read instructions thoroughly and carefully so all procedures are completely understood before performing any installation steps. Contact S&S with any questions you may have if any steps are unclear or any abnormalities occur during installation or operation of motorcycle with a S&S part on it.

• Consult an appropriate service manual for your motorcycle for correct disassembly and reassembly procedures for any parts that need to be removed to facilitate installation.

• Use good judgment when performing installation and operating motorcycle.

Good judgment begins with a clear head. Don’t let alcohol, drugs or fatigue impair your judgment. Start installation when you are fresh.

• Be sure all federal, state and local laws are obeyed with the installation.

• For optimum performance and safety and to minimize potential damage to carb or other components, use all mounting hardware that is provided and follow all installation instructions.

Motorcycle exhaust fumes are toxic and poisonous and must not be breathed. Run motorcycle in a well ventilated area where fumes can dissipate.

WARRANTY:

All S&S parts are guaranteed to the original purchaser to be free of manufacturing defects in materials and workmanship for a period of twelve (12) months from the date of purchase. Merchandise that fails to conform to these conditions will be repaired or replaced at S&S’s option if the parts are returned to us by the purchaser within the 12 month warranty period or within 10 days thereafter.

In the event warranty service is required, the original purchaser must call or write

S&S immediately with the problem. Some problems can be rectified by a telephone call and need no further course of action.

A part that is suspect of being defective must not be replaced by a Dealer without prior authorization from S&S. If it is deemed necessary for S&S to make an evaluation to determine whether the part was defective, a return authorization number must be obtained from S&S. The parts must be packaged properly so as to not cause further damage and be returned prepaid to S&S with a copy of the original invoice of purchase and a detailed letter outlining the nature of the problem, how the part was used and the circumstances at the time of failure. If after an evaluation has been made by S&S and the part was found to be defective, repair, replacement, or refund will be granted.

OWNERS MANUAL — S&S® V-SERIES ENGINES

ADDITIONAL WARRANTY PROVISIONS:

(1) S&S shall have no obligation in the event an S&S part is modified by any other person or organization.

(2) S&S shall have no obligation if an S&S part becomes defective in whole or in part as a result of improper installation, improper maintenance, improper use, abnormal operation, or any other misuse or mistreatment of the S&S part.

(3) S&S shall not be liable for any consequential or incidental damages resulting from the failure of an S&S part, the breach of any warranties, the failure to deliver, delay in delivery, delivery in non-conforming condition, or for any other breach of contract or duty between S&S and a customer.

(4) S&S parts are designed exclusively for use in Harley-Davidson® and other

American v-twin motorcycles. S&S shall have no warranty or liability obligation if an

S&S part is used in any other application.

Table of Contents:

Introduction ...................................................................................................... 2

Engine Installation ...............................................................................2

Oil Line Hook up ........................................................................................... 2

Oil Recommendations ................................................................................ 2

General Break-in Procedure ..................................................................... 5

Tune Up Information ...........................................................................7

Super Stock & IST Ignition Systems ....................................................... 7

EFI Information .............................................................................................. 7

Starting Procedure ....................................................................................... 8

Super E & G Carburetor Tuning Guide .................................................. 9

Engine Service Intervals ...........................................................................12

Engine Specifications ........................................................................13

Engine Dimensions ....................................................................................14

Torque Specifications ...............................................................................16

Specifications and Wear Limits .............................................................17

2

INTRODUCTION

The S&S® engine you have purchased is an air-cooled, v-twin. It is designed to offer Proven Performance® and reliability. Specifications for the 31⁄2", 35⁄8", 4", and 41⁄8" bore engines are found in this manual.

We have covered the most popular configurations, 80ci, 96ci, 111ci, and 124ci, based on their original S&S production designs. Some changes may have been made over time as these engines have been in production for a number of years. The specifications in this manual are based on the most recent production specifications.

ENGINE INSTALLATION

The procedure for installing an S&S engine is basically the same as outlined in the factory service manual for the model of motorcycle the engine is being installed in. However, S&S engines are sometimes taller then a stock engine so the installer must check to make sure there is adequate clearance between the engine and all chassis components including the frame and fuel tanks. An upgraded clutch should also be considered, since the S&S engine will produce more power than the stock engine it is replacing.

OIL LINE HOOK-UP

The following diagrams show how the crankcase breather and oil lines should be hooked up for S&S V-Series engines. Note most 41⁄8" bore engines have a use a vacuum breather system

Viscosity

SAE 20W50

SAE 50

SAE 25W60

SAE 60

Ambient Temperature (°F)

Above 30°–100°

Above 60°–100°

Above 80°

Above 80°

OIL RECOMMENDATIONS

S&S recommends synthetic engine oil such as S&S Premium Synthetic

20W50. However a premium petroleum based engine oil such as S&S

Heavy Duty 20W50 or 25W60 is acceptable.

Regardless of what type of oil you select, be sure to use only oil specifically designated for use in an air-cooled motorcycle, and select the viscosity suggested for the temperature range you will be operating your motorcycle in.

The oil filter used on an S&S® V-Series engine should be rated at 24 microns. Spin-on filters should not have an anti-drain back valve.

S&S filters are available to replace Harley-Davidson® #63805-80A and

63796-77A. The S&S part numbers are 31-4101 and 31-4102.

OIL LINE HOOK-UP V-SERIES

OWNERS MANUAL — S&S® V-SERIES ENGINES

3

4

OIL LINE HOOK-UP FOR V-SERIES WITH VACUUM BREATHING

OWNERS MANUAL — S&S® V-SERIES ENGINES

FUEL REQUIREMENTS

The gasoline used in your engine should have a US octane rating of 91 or higher. The United States uses the method of octane rating. In many countries outside the United States, the RON (Research Octane

Number) is used, which will result in a higher octane requirement of about 96.

GENERAL BREAK-IN NOTES

Remember that these are air-cooled engines. Sufficient air movement

is required to keep engine temperatures within safe operating limits.

Avoid heavy traffic and congestion or extended idle periods whenever

possible.

S&S v-twin performance engines are designed for, and happiest when

running between 2750-3500 at normal highway speeds.

Today’s heavier bikes and taller gearing can easily push a high

performance engine into a lugging condition which increases loads on engine components, causes detonation, builds excessive heat, and increases fuel consumption. If the engine does not accelerate easily when given some throttle, downshift to a lower gear.

S&S engines benefit from a warm-up period any time they are started,

allow engine to reach operating temperature before being subjected to heavy loads or quick throttle revs.

BREAK-IN OIL CONSIDERATIONS.

Either petroleum or synthetic oil designed for air-cooled v-twin engines can be used during the break-in period and during normal use.

If preferred, petroleum oil can be used for the break-in period, after which, the engine can be changed over to synthetic oil.

BREAK-IN PROCEDURE

1. Initial start up. Run engine approximately one minute at 1250-

1750 RPM. DO NOT crack throttle or subject to any loads during this period as head gaskets are susceptible to failure at this time.

During this time, check to see that oil pressure is normal, that oil is returning the oil tank, and that no leaks exist.

2. Shut off engine and thoroughly check for any leaks or other problems. Let engine cool to the touch.

3. After engine has cooled, start up again and allow the motor to build some heat. Engine should be run no longer than three to four minutes. When the cylinders become warm/hot to the touch

(approximately 150°F) shut the motor down and let it cool to room temp. Follow the same cautions as for the initial start-up, and continue to check for problems.

4. First 50 Miles: a. Street: Ride normally, do not lug the engine. Avoid high heat conditions and vary the RPM while riding. No stop and go traffic, extended idle periods, or high load or high RPM conditions. Max of 3,500 RPM or 60 MPH. b. Dyno: A chassis dynamometer can be used to put the first 50 miles on a new engine. See the notes and procedure below for chassis dyno break-in.

5

5. 50–100 Miles: Ride normally, do not lug the engine. Avoid high heat conditions, no stop and go traffic or extended idle periods.

Limited short bursts of throttle can aid in ring seating from this point forward during the break-in, but avoid continuous high speed or load conditions. Max of 4,250 RPM/70 MPH.

6. 100–500 Miles: Avoid lugging the engine and high heat conditions.

Max of 5,000 RPM. Change oil at 500 miles.

7. 500–1,000 miles: Ride bike normally, but avoid continuous high load operation and high heat conditions.

8. From 1,000 miles on: Break-in is complete, enjoy!

NOTES FOR COMPLETING INITIAL 50 MILE BREAK-IN AND INITIAL

TUNING ON A CHASSIS DYNO

When running the bike on the dyno it is critical that engine

temperatures are monitored, AFR is kept between 12.5–14.7 and the engine is not overheated. Fans must be used to keep the engine cool.

When tuning under higher loads stop regularly and allow the engine to cool.

A load must be placed on the engine to properly seat the rings.

Running a new engine continually with no load will result in cylinder glazing and poor ring seal. The engine should be loaded to simulate close to the weight of the bike, a load of 10–15% on a Dyno jet 250i is usually sufficient. It is not recommended to use an inertia only dyno to break-in an engine as no load can be placed on the engine.

6

Initial tuning on the engine can be completed during the initial 50

miles of dyno break-in. It is recommended the engine be run on the street for a minimum of 500 miles prior to completing tuning at full power. Monitor engine temperature during tuning to ensure the engine is not overheated.

DYNO BREAK-IN PROCEDURE (FIRST 50 MILES)

1. Follow the same procedure outlined above for initial start-up and heat cycling the engine.

2. Run the bike for 25 miles on the dyno under varying speeds and loads while going up and down through the gears. Keep engine

RPM below 3,500 RPM but do not lug the engine. The dyno must be operated so the engine runs under a load roughly equal to the power needed to move the bike down the road, this would be about 12 hp at 55 MPH. Keep engine head temperatures below

200°F at the temp sensor or surface of the head. Stop and cool the engine if needed.

3. Allow the engine to cool down to room temperature.

4. Run the bike for 25 more miles (50 miles total) under varying speeds, loads, and gears as before. Make sure there is some load on the engine. Keep engine speed below 4,250 RPM but do not lug the engine. Limited short bursts of throttle can aid in ring seating as long as the calibration/tune keeps the AFR in control.

Keep engine head temperatures below 225°F at the temp sensor or surface of the head.

5. After the first 50 miles on the dyno, it is recommended the normal break-in schedule be followed under normal riding conditions on the street. See Step 5 under BREAK-IN PROCEDURE.

OWNERS MANUAL — S&S® V-SERIES ENGINES

TUNE UP INFORMATION

S&S 4" bore and smaller V-Series engines come from the factory with

Champion RN12YC 14mm long reach spark plugs (S&S PN 55-1321). 4-1⁄8" bore engines come from the factory with Champion RA8HC 12mm spark plugs (S&S PN 55-1320). All spark plugs should be gapped between

.038- and .042-inch. If you are not using an S&S ignition system, refer to your ignition manufacturer for any additional recommendations.

IGNITION SYSTEM

Carbureted S&S V-Series engines come from the factory with either an S&S Super Stock™ or IST® ignition system installed. Fuel injected engines are equipped with an S&S VFI module.

If the ignition system has a rev limiter, make sure it is set no higher than

6200 rpm..

Engine

V124

V117

V113

V111

V96

V80

Total Advance,

VOES Grounded

(deg BTDC)*

34°

35°

34°

35°

32°

35°

Max Advance,

Wide Open

Throttle (WOT)

29°

30°

29°

31°

27°

33°

RPM Max

Advance

@ WOT

5000

5000

5000

5000

5000

5000

S&S Super Stock ignition modules are factory programmed for the specific engine they are intended for. In addition the module is installed and timed to S&S specified timing. Changing the timing or removing the Super Stock ignition may void your warranty.

S&S IST ignition systems employ a knock sensor to automatically optimize ignition timing and protect your engine from damage.

Removing the IST ignition may void your warranty.

If you choose to install another EFI module on a fuel injected V124 engine, the following ignition table should be used as a guide for ignition advance under various conditions

Ignition timing in S&S fuel injected engines, is controlled by the S&S

VFI module. The calibration file supplied by S&S for the particular engine contains ignition timing curves. If the ignition curve is modified or if another fuel injection module is used, the engine warranty may be voided.

If you choose to install another ignition system, make sure that the total ignition advance is set according to the specifications in this chart.

EFI Ignition Table - S&S V124, 10.8:1 CR, 640 Cam

RPM

WOT

Cruise

1000

5.0°

16.0°

2000

15.4°

25.0°

3000

18.2°

34.1°

4000

19.5°

34.0°

5000

22.3°

31.7°

6000

26.0°

30.0°

Idle/Decel 15.5° 20.4° 34.4° 40.0° 42.3° 42.3°

7

START-UP — ENGINES EQUIPPED WITH S&S SUPER E

OR G CARBURETOR

1. S&S Super E & G carburetors have a mixture enrichment/fast idle lever used to aide in cold starts and help during the warm-up period. Do not ride the motorcycle with the lever engaged.

2. Turn the fuel supply valve on, wait a moment to make sure the carburetor bowl is full, and twist the throttle twice to prime the carburetor—starting in extremely cold weather may require additional priming.

3. Pull the fast idle lever up, turn on the ignition and press the start button or kick the engine through.

4. If the engine does not start after several kicks or five seconds of cranking, shut the ignition off for 15 seconds to let the starter cool.

5. Open the throttle slightly and press the starter button or kick the engine through again. It may be necessary to re-prime the engine.

If the engine kicks back, the throttle may be opened too far.

6. Once the engine is running, use the fast idle lever to maintain the proper engine speed required during warm-up.

7. When the engine has warmed up enough to idle without the enrichment system, disengage the fast idle lever. The fast idle lever is not required to restart a hot engine. data from the knock sensor and other sensors.

3. Ride the motorcycle as you would normally, being sure to include hills, highway speeds (for at least 20 minutes at a time) and around town. Be sure to use the throttle in as many settings as possible— without going past the suggested break-in procedures!

4. Once the engine is completely broken in, the IST will be tuned to optimize the engine’s performance.

5. Do not run the engine on a dyno until the IST has had time to tune itself to your engine.

START-UP – ENGINES EQUIPPED THE VARIABLE FUEL

INJECTION (VFI)

1. Turn the ignition and kill switches on. Listen for the fuel pump as it pressurizes.

2. Do not twist the throttle open to prime the system.

3. Press the starter button and let engine crank over—do not twist the throttle. If the engine is extremely hard to start—hot or cold—contact the S&S® Tech Line or visit www.sscycle.com for the location of the closest VFI Tuning Center.

INITIAL START UP WITH IST IGNITION

1. Start the motorcycle up as outlined above.

2. The IST ignition comes with a general ignition map that will allow the engine to be started and run. Within 3 to 5 hours of operation the IST module will optimize this map for your engine, based on

8

OWNERS MANUAL — S&S® V-SERIES ENGINES

SUPER E & G CARBURETOR TUNING GUIDE

1. Verify carburetor is set to stock settings: a. Idle mixture screw, 11/4 turns from lightly seated.

b. Idle speed screw, 1⁄2 turn clockwise from engagement point.

c. Accelerator adjustment screw, two turns counter-clockwise from seated.

2. Start bike, bring to operating temperature.

3. Set idle speed adjusting screw, clockwise to increase RPM, counter-clockwise to decrease RPM. Idle RPM range should be 950 to 1050 RPMs.

4. Adjust idle mixture by turning idle mixture screw slowly clockwise until the engine runs poorly. Note position. Slowly turn the screw counter-clockwise until it starts to stumble. Note position. Set the idle mixture screw halfway between the positions, or at the strongest idle. Inconsistent idle may indicate a manifold leak.

5. With engine idling, turn accelerator adjustment screw clockwise until it lightly seats. Snap throttle open—engine should stumble.

Turn screw counter-clockwise 1/4 or 1⁄2 of a turn at a time, until engine responds to throttle twist with smooth, quick response.

6. Ride motorcycle in various RPM ranges, and then try to maintain a consistent 40- to 50-MPH. If the engine has a flat spot, or is popping/sneezing in the air cleaner, it can indicate a lean condition. If you notice stumbling or sputtering, it can indicate a rich condition.

7. Low RPM operation is controlled by the intermediate jet (#11 on following page). If sneezing or popping is experienced below approximately 3000 RPMs the intermediate jet must be replaced with a larger sized (richer) jet. If the engine does not run smoothly at low speeds, fouls plugs, blows black smoke or gets bad gas mileage a smaller (leaner) intermediate jet needs to be installed.

Always readjust the idle mixture (#2) and idle speed (#1) screws after making a jet change.

8. To test the main jet, do a roll-on from 50-MPH to 70-MPH in 3rd gear. If the engine backfires or breaks up in the carb, increase the main jet size .004". If the engine is flat or will not accelerate, decrease the main jet by .004".

9. Since 2004 S&S shorty carbs have been fitted with an adjustable main jet air bleed (#13). Changing this jet to a larger size will delay the signal to the main jet, therefore aiding with high speed tuning as described in step 8. This also aides with tuning an engine that is fitted with an exhaust system that is not intended for high performance. The air bleed uses main jets, the stock size is 40. If it needs to be changed the range is normally 50 to 60.

10. NOTE: Drag or straight pipes, especially large diameter or long

designs, can prevent you from obtaining optimum carburetor performance.

11. If the S&S teardrop air cleaner is being replaced with an aftermarket air cleaner, be sure to remove the auxiliary bowl vent screw (#14).

Never use a velocity stack on a street driven motorcycle! Poor throttle response will be experienced.

12. Always be sure to attach the hose to the overflow tube fitting (#6) and route it toward the back of the engine.

9

10

Approximate Jetting For S&S® Super E & G Carburetors

Displacement 883cc 74 – 88ci 96 – 107ci 111 – 124ci

Intermediate Jet

Main Jet

.265 – .028

.066

.0295

.072

.031

.076

.031

.078

These jetting recommendations are a starting point only. Re-jet carb for best performance.

2

3

1

4

5

1- Idle Speed Screw

2- Idle Mixture Screw

3- Accelerator Pump Adjustment Screw

4- Enrichment Device

5- Serial Number

8

7

6- Overflow Tube Fitting

7- Fuel Inlet

8- Bowl Vent Hole

9- Bowl Plug

9

6

10

11

OWNERS MANUAL — S&S® V-SERIES ENGINES

13

12

10- Accelerator Pump Pushrod

11- Intermediate Jet

12- Main Jet

13- Main Jet Air Bleed

14- Auxiliary Bowl Vent Plug

14

11

ENGINE SERVICE INTERVALS

Item

Engine Oil & Filter

Interval

Change at 500, 2,500 miles (80, 800, 4,000 kilometers), every 2,500 miles (4,000 kilometers) thereafter

1

.

Air Cleaner Element

Tappet Oil Screen

Petcock, Lines, & Fittings,

Vacuum Lines

Fuel Tank Filter Screen &

In-Line Fuel Filter (If used)

Engine Idle Speed

Operation of Throttle &

Enrichment Device Controls

Spark Plugs

Ignition Timing

Engine Mounts

External Fasteners Except

Engine Head Bolts

Inspect at 50 and 500 miles (80 and 800 kilometers), every 2,500 miles (4,000 kilometers) thereafter

2

.

Replace every 5,000 miles (8,000 kilometers).

Inspect every 2,500 miles (4,000 kilometers). Replace every 5,000 miles (8,000 kilometers).

Inspect at 50 and 500 miles (80 and 800 kilometers), every 2,500 miles (4,000 kilometers) thereafter.

Inspect every 5,000 miles (8,000 kilometers).

Adjust as required.

Inspect at 500 miles (800 kilometers) and every 2,500 miles (4,000 kilometers) thereafter.

Inspect every 5,000 miles (8,000 kilometers). Replace every 10,000 miles (16,000 kilometers) or as needed.

Inspect every 5,000 miles (8,000 kilometers).

Inspect at 500 miles (800 kilometers) and every 5,000 miles (8,000 kilometers) thereafter.

Re-torque at 500 miles (800 kilometers) and every 5,000 miles (8,000 kilometers) thereafter.

1- S&S recommends that petroleum-based oil not specifically formulated for motorcycles should be changed every 1,000 miles (1,600 kilometers) after the break-in period.

2- Replace more frequently if required or if engine is operated in a dusty environment.

12

OWNERS MANUAL — S&S® V-SERIES ENGINES

ENGINE SPECIFICATIONS

The following chart contains information about a number of S&S engines covered by this owners manual.

Engine

V80

V96

V96 TÜV

V111

V113 TÜV

V124

V124 TÜV

Displacement Bore

80"

96"

96"

111"

113"

124"

124"

31⁄2"

35⁄8"

35⁄8"

41⁄8"

4"

41⁄8"

41⁄8"

Stroke

41/4"

45⁄8"

45⁄8"

41⁄8"

41⁄2"

45⁄8"

45⁄8"

CR

8.4:1

9.5:1

10.1:1

9.8:1

10.1:1

10.8:1

9.5:1

Cam

508

585

520

585

547

640

547

Tappets

Hydraulic

“Hydraulic w/HL2T”

“Hydraulic”

“Hydraulic w/HL2T”

“Hydraulic w/HL2T”

“Hydraulic w/HL2T”

“Hydraulic w/HL2T”

Fuel System Ignition

System

“Super E or

None”

“Super Stock or None”

Super E

Super E

Super E

“Super Stock or IST”

IST

“Super Stock or IST”

Super G IST

Super G or VFI “Super Stock,

IST, or VFI”

Super G IST

13

ENGINE DIMENSIONS

Some S&S engines are taller than stock engines. These diagrams show the dimensions of various S&S engines. This information will be most useful to customers building custom motorcycles with after market frames.

Engine A B

V80

V88

V96

V96 TUV

V100

15.898"

15.736"

15.912"

15.912"

15.623"

20.299"

20.165"

20.310"

20.310"

20.062"

V107

V113

V113 TUV

V124

V124 TUV

15.728"

15.846"

15.846"

15.979"

16.048"

20.163"

20.266"

20.266"

20.366"

20.424"

14

Front of Engine

OWNERS MANUAL — S&S® V-SERIES ENGINES

Nothing lasts forever, and despite the superior materials and design of the components in your S&S engine, some day it will need to be serviced. Who better to repair your engine, than the technicians at the company where it was made? To obtain factory service for your S&S engine, have your S&S dealer contact the S&S Service & Speed Center.

To find an S&S dealer in your area go to the S&S Dealer Locator at www.sscycle.com/dealer-locator

CHARGING SYSTEM NOTE -

you must install a S&S® spacer (PN 31-4033). If you do not use this spacer the rotor could bottom out against the case when the sprocket shaft nut is tightened.

If you are going to use a 45 amp alternator

IMPORTANT INFORMATION

• S&S engines are not recommended for inexperienced riders because the increased performance requires a higher level of riding skill.

• Do not lug your S&S engine. This is a high performance engine, designed to produce excellent horsepower at higher RPM. It was not well suited to pull heavy loads at low RPM. We recommend that the engine not be operated below 2500 RPM for extended periods of time. Shift to a lower gear to keep the engine speed up when traveling at lower speeds.

• Your S&S Engine is air cooled, which means that it depends on air moving across the cooling fins to keep it from over heating. Do not allow your engine to idle for extended periods of time. Avoid stop and go traffic or any other situation where the motorcycle is not moving while the engine is running.

• To avoid engine damage, do not operate the engine above 6200

RPM.

SERVICE SPECIFICATIONS FOR S&S ENGINES

For the most part if an S&S engine requires service, a qualified mechanic who services Harley-Davidson® engines can do the work. However the specifications for S&S engines are somewhat different. These charts are provided for reference. For more detailed information about any specific S&S component, installation instructions are available for free download from the S&S website www.sscycle.com.

15

16

TORQUE SPECIFICATIONS

Item

Rocker Box 1/4"

Torque Recommended

100-120 in-lbs Loctite® 243

Rocker Box base 5⁄16"

Rocker arm support plate

Cylinder head bolts

Cylinder studs

Crankcase fasteners

15-18 ft-lbs

15-18 ft-lbs

8 ft-lbs, 18 ftlbs, 90°

10 ft-lbs

12-15 ft-lbs (1/4)

Loctite 243

Loctite 243

Oil threads

Loctite 272

Piston oilers

Pinion nut

Tappet guide fasteners

Pushrod locknuts

18-20 ft-lbs (5⁄16)

25 in-lbs

50 ft-lbs

90-120 in-lbs

90-120 in-lbs

Gear cover fasteners

Timing hole plug

Oil pump cover/mounting bolts (4) 90-120 in-lbs

Loctite 243

Loctite 272

Loctite 243

100-120 in-lbs Loctite 243

120 in-lbs Anti-seize

Oil pump top mounting (2)

Intake manifold to head

Intake manifold to carb

60 in-lbs

16 ft-lbs

18 ft-lbs

Loctite 243

Loctite 243

Item

Compression releases

Exhaust flange to head

Head temp sensor

Knock sensor

Crank position sensor

Spark plug

NOTE: 12 in-lbs equals 1 ft-lbs

Torque

32-37 ft-lbs

15-18 ft-lbs

10-12 ft-lbs

11 ft-lbs

90-120 in-lbs

11-18 ft-lbs

Recommended

Anti-seize

Anti-seize

Anti-seize

Anti-seize

Anti-seize

SPECIFICATIONS & WEAR LIMITS

Description

Rocker Arm

Specification

Shaft in bushing .0007"-.0018"

Bushing fit in rocker arm (press) .0012"-.0032"

Rocker arm endplay .001"-.012"

Cylinder Head

Valve to guide fit intake

Valve to guide fit exhaust

Valve guide in head (press)

Valve seat in head (press)

Seat width intake

Seat width exhaust

Valve stem protrusion

Pistons

Fit in cylinder

Compression ring gap

Oil ring gap

.0012"-.0020"

.0017"-.0025"

.0015"-.0030"

.0050"-.0070"

.031"

.047"

2.045"-2.060"

.002"-.0026"

.017"-.026"

.010"-.040"

Wear Limit

.0035"

<.0012"

.0035"

.0040"

<.0015"

<.0050"

.041"

.057"

2.080"

.0055"

.030"

.050"

OWNERS MANUAL — S&S® V-SERIES ENGINES

Description

Connecting Rods

Side play

Wristpin in rod

Crankpin running clearance

Flywheels

Run out at bearing

Timken endplay

Pinion bearing fit

Cam Chest

Breather gear endplay

Specification

.006"-.036"

.0005"-.001"

.001"-.0012"

.0005"-.001"

.001"-.005"

.0004"-.001"

.005"-.015"

Breather clearance

Camshaft in bushing

Camshaft endplay

Pinion shaft in bushing

.0015"-.003"

.0007"-.002"

.005"-.015"

.001"-.0025"

Bushing fit in gear cover (press) .0007"-.0023"

Oil pump shaft .0005"-.0025"

Lifters

Lifter fit in guide .0006"-.0017"

Wear Limit

.040"

.002"

.002"

.006"

.005"

.002"

.016"

.004"

.0035"

.016"

.0035"

<.0006"

.0035"

.0022"

17

OWNERS MANUAL — NOTES

S&S

®

Cycle, Inc

.

14025 County Hwy G

Viola, WI 54664

Phone: 608-627-1497 • Fax: 608-627-1488

Technical Service Phone: 608-627-TECH (8324)

Technical Service Email: [email protected]

www.sscycle.com

510-0365

04/02/15

Copyright © 2015 by S&S® Cycle, Inc. All rights reserved. Printed in the U.S.A.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
