Wall-mounted hood 700 w. motor, W1200

• Number of fan motors/ exhaust air outputs:

• Fan regulation:

1

Via an external controller

• Cut-out for the motor: 232 x 208 mm

• Operating mode: Exhaust air

• Assembly type: Wall

• Flame protection filter: Type A

• Number of filters: 2

• Material filter:

• Lighting:

CNS 18/10 yes

• Lamps (number + watt):

1 x 18 W

• Available on request: Ceiling hood

• Properties:

Other sizes

Wall hood series 1100

Blare-free light installed with grease protection cover

-

Filter carrier with additional gre­ ase collection channel

• Including:

Power load:

Material:

0,202 kW | 230 V | 50-60 Hz

CNS 18/10

• Important information: Can only be commissioned with an additional controller

• Motor output: 184 W

• Max. air throughput: 1400 m³/h

• Size:

• Weight:

W 1,200 x D 700 x H 450 mm

35 kg

GB

12/2021

1/1 Subject to technical modifications and errors.

Code-No.

257120

GTIN 4015613673509
