JETLINE T M
JL-1 50
WATERJET
INTENSIFIER
20480269(R03)
WATERJET INTENSIFIER
OPERATION AND MAINTENANCE MANUAL
OPERATION AND MAINTENANCE MANUAL
JETLINE TM JL-1 50
JETLINE TM JL-1 50
WATERJET INTENSIFIER
OPERATION AND MAINTENANCE MANUAL
MANUAL 20480269(R03)
NOTICE
This document contains subject matter in which KMT Waterjet Systems has
proprietary rights. Recipients of this document shall not duplicate, use or disclose
information contained herein, in whole or in part, for other than the purpose for
which this manual was provided.
KMT Waterjet believes the information described in this manual to be accurate and
reliable. Much care has been taken in its preparation; however, the Company cannot
accept any responsibility, financial or otherwise, for any consequences arising out of
the use of this material. The information contained herein is subject to change, and
revisions may be issued advising of such changes and/or additions.
KMT WATERJET SYSTEMS 2009
KMT Waterjet Systems
635 West 12th Street
POB 231
Baxter Springs, KS 66713-0231
Phone:
Fax:
20480338
8-2010/Rev 02
(800) 826-9274
(620) 856-5050
TABLE OF CONTENTS
Title Page
Notice
Table of Contents
Appendix
Section
1
Introduction ...................................................................................................... 1-1
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
2
Overview...............................................................................................1-1
Product Nameplate................................................................................1-1
Operational Overview...........................................................................1-1
Low Pressure Water System .................................................................1-2
Recirculation System ............................................................................1-2
Hydraulic System..................................................................................1-2
High Pressure Water System ................................................................1-2
Operating System..................................................................................1-3
Safety ....................................................................................................1-4
Lockout/Tagout Procedure....................................................................1-4
Warning Labels.....................................................................................1-5
Emergency Medical Treatment.............................................................1-7
Worldwide Product Support .................................................................1-7
Spare Parts ............................................................................................1-8
Manual Organization ............................................................................1-8
Equipment and Service Manual Questionnaire.....................................1-8
Installation ........................................................................................................ 2-1
2.1
2.2
2.3
2.4
2.5
2.6
2.7
20480338
8-2010/Rev 02
Page
Overview...............................................................................................2-1
Installation Summary ............................................................................2-1
Site Requirements .................................................................................2-2
Transporting..........................................................................................2-2
Power Requirements .............................................................................2-3
Service Connections..............................................................................2-4
Cooling Water.......................................................................................2-5
Cutting Water........................................................................................2-6
Drain .....................................................................................................2-6
Plant Air ................................................................................................2-6
Contaminated Waste .............................................................................2-7
Flow Requirements ...............................................................................2-7
High Pressure Piping.............................................................................2-8
Measurements and Dimensions ............................................................2-10
Hand Coning .........................................................................................2-11
Power Coning........................................................................................2-12
Hand Threading ....................................................................................2-13
Power Threading...................................................................................2-13
i
2.8
2.9
2.10
3
Maintenance ..................................................................................................... 3-1
3.1
3.2
3.3
3.4
4
4.3
4.4
4.5
4.6
4.7
4.8
4.9
Overview...............................................................................................4-1
Startup Sequence...................................................................................4-1
Startup after Motor Stop .......................................................................4-1
Startup after Emergency Stop ...............................................................4-1
Keypad and Screen Functions...............................................................4-2
Run Screen ............................................................................................4-3
System Screen.......................................................................................4-4
Information Screen................................................................................4-4
Hours Screen.........................................................................................4-5
Capacity Screen ....................................................................................4-5
Stroke Rate Screen................................................................................4-6
Date/Time Screen..................................................................................4-6
Program Information Screen.................................................................4-7
Settings Screen......................................................................................4-7
Stroke Rate Screen................................................................................4-8
Configuration Screen ............................................................................4-8
Language Screen...................................................................................4-9
Serial Number Screen ...........................................................................4-9
Date/Time Screen..................................................................................4-9
HMI Screen...........................................................................................4-9
Maintenance Screen ..............................................................................4-10
Maintenance Hours Screen ...................................................................4-10
Maintenance Strokes Screen .................................................................4-11
Alarms...................................................................................................4-11
Low Pressure Water System ........................................................................... 5-1
5.1
5.2
5.3
5.4
20480338
8-2010/Rev 02
Overview...............................................................................................3-1
Maintenance..........................................................................................3-1
Daily Inspection ....................................................................................3-1
Periodic Maintenance............................................................................3-1
High Pressure System Maintenance......................................................3-2
Maintenance Precautions ......................................................................3-3
Tool Kit.................................................................................................3-4
Operation .......................................................................................................... 4-1
4.1
4.2
5
High Pressure Connections ...................................................................2-14
Standard Connections ...........................................................................2-14
Anti-Vibration Connections..................................................................2-15
Commissioning .....................................................................................2-16
Decommissioning .................................................................................2-18
Overview...............................................................................................5-1
Cutting Water Supply Quality ..............................................................5-2
Operation...............................................................................................5-2
Service and Maintenance Procedures ...................................................5-4
Filter Assembly and Strainer Maintenance...........................................5-4
Booster Pump Adjustment ....................................................................5-5
ii
6
Recirculation System ....................................................................................... 6-1
6.1
6.2
6.3
7
Hydraulic System ............................................................................................. 7-1
7.1
7.2
7.3
8
8.3
Overview...............................................................................................8-1
Operation...............................................................................................8-1
Sensors and Solenoids...........................................................................8-4
Service and Maintenance Procedures ...................................................8-8
Proximity Switch Maintenance.............................................................8-8
High Pressure Water System .......................................................................... 9-1
9.1
9.2
9.3
9.4
9.5
9.6
9.7
9.8
9.9
9.10
20480338
8-2010/Rev 02
Overview...............................................................................................7-1
Operation...............................................................................................7-2
Service and Maintenance Procedures ...................................................7-3
Hydraulic Operating Pressure ...............................................................7-4
Motor Maintenance...............................................................................7-5
Hydraulic Compensator Maintenance...................................................7-5
Electrical System .............................................................................................. 8-1
8.1
8.2
9
Overview...............................................................................................6-1
Operation...............................................................................................6-2
Service and Maintenance Procedures ...................................................6-3
Hydraulic Oil Maintenance...................................................................6-3
Electric Motor Bump ............................................................................6-5
Oil Filter Maintenance ..........................................................................6-6
Operating Temperature Adjustment .....................................................6-6
Overview...............................................................................................9-1
Operation...............................................................................................9-2
System Components..............................................................................9-4
Service and Maintenance Overview .....................................................9-6
Torque Specifications ...........................................................................9-7
Specialized Maintenance Tools ............................................................9-8
High and Low Pressure Water Piping...................................................9-9
High Pressure Cylinder Assembly ........................................................9-9
High Pressure Cylinder Assembly Removal.........................................9-10
High Pressure Cylinder Assembly Installation .....................................9-11
High Pressure Cylinder Maintenance ...................................................9-12
Sealing Head .........................................................................................9-13
High Pressure Discharge Check Valve .................................................9-13
Low Pressure Inlet Check Valve...........................................................9-15
Sealing Head Seal Assembly ................................................................9-16
Sealing Head Maintenance ...................................................................9-16
High Pressure Seal Assembly ...............................................................9-17
Hydraulic Seal Cartridge Replacement.................................................9-19
Hydraulic Seal Cartridge.......................................................................9-20
Hydraulic Piston and Plungers..............................................................9-23
Hydraulic Piston and Plunger Removal................................................9-23
Bearing Rings and Seal Assembly........................................................9-25
Plunger Maintenance ............................................................................9-25
Hydraulic Piston and Plunger Installation ............................................9-26
iii
9.11
9.12
9.13
9.14
10
Troubleshooting ............................................................................................... 10-1
10.1
10.2
11
Overview...............................................................................................10-1
Troubleshooting Guide .........................................................................10-1
Specifications .................................................................................................... 11-1
11.1
11.2
11.3
11.4
11.5
12
Hydraulic Cylinder Maintenance..........................................................9-27
High Pressure Attenuator......................................................................9-27
High Pressure Dump Valve ..................................................................9-28
Pneumatic Control Dump Valve...........................................................9-28
Pneumatic Actuator...............................................................................9-33
Weep Holes...........................................................................................9-34
Overview...............................................................................................11-1
Installation Specifications.....................................................................11-1
Environment..........................................................................................11-1
Sound Level ..........................................................................................11-1
Equipment Dimensions and Weights....................................................11-2
Service Connections..............................................................................11-2
Plant Air ................................................................................................11-2
Water Specifications .............................................................................11-3
Cutting Water Supply ...........................................................................11-3
Recirculation System ............................................................................11-3
Water Quality Standards .......................................................................11-4
Electrical Specifications........................................................................11-6
Electrical System ..................................................................................11-6
Ampacity and Power Voltage Requirements........................................11-6
Hydraulic and High Pressure System Specifications............................11-7
Hydraulic System..................................................................................11-7
High Pressure Water System ................................................................11-7
Orifice Capacity ....................................................................................11-8
Torque Specifications ...........................................................................11-9
Parts List ........................................................................................................... 12-1
12.1
12.2
Overview...............................................................................................12-1
Index .....................................................................................................12-2
APPENDIX
Exhibit
System Schematic
Electrical Schematic
Material Safety Data Sheets
20480338
8-2010/Rev 02
iv
SECTION 1
INTRODUCTION
1.1
Overview
The JetlineTM Series combines all the unique capabilities and advantages of waterjet cutting
systems with the reliability, ease of operation and service support that have made KMT
Waterjet Systems a leader in waterjet technology.
Table 1-1
JetlineTM JL-1
Motor
Horsepower
Rating
HP
Kw
1.2
Maximum
Operating
Pressure
Maximum
Flow Rate
(at full pressure)
Maximum Single
Orifice Diameter
(at full pressure)
30
22
55,000 psi (3,792 bar)
.60 gpm (2.3 L/min)
0.011 inch (0.28 mm)
50
37
55,000 psi (3,792 bar)
1.0 gpm (3.8 L/min)
0.014 inch (0.36 mm)
Product Nameplate
The product nameplate contains the pump model, serial, identification and part numbers for
each individual machine.
Figure 1-1: Nameplate
1.3
Operational Overview
The following provides a brief overview of the function and primary components associated
with the individual systems. A detailed discussion of each system is provided in Sections 4
through 9. Equipment specifications are provided in Section 11, Specifications.
20480273
9-2009/Rev 01
1-1
Section 1
Introduction
Low Pressure Water System
The low pressure water system supplies the cutting water flow to the intensifier. Major
system components include the booster pump and low pressure water filter assembly.
Figure 1-2: System Components
1
2
Low Pressure Water System
8
Oil Filter Assembly
4
Water Filter Assembly
9
Recirculation Pump
5
Booster Pump
3
Hydraulic System
Recirculation System
10 Hydraulic Pump
6
Hydraulic Oil Reservoir
11 Hydraulic Manifold
7
Heat Exchanger
12 Electric Motor
Recirculation System
The recirculation system is a cooling and filtration system that provides properly conditioned
oil to the main hydraulic system. Major system components include the recirculation pump,
heat exchanger, oil filter assembly and the hydraulic oil reservoir.
Hydraulic System
The hydraulic system supplies the intensifier with the hydraulic oil required to produce high
pressure water. Major system components include the electric motor, hydraulic pump, and
the 4-way directional control valve mounted on the hydraulic manifold.
High Pressure Water System
The high pressure water system is the heart of the waterjet system. Water is pressurized and
continuously delivered to the cutting head. As water passes through a tiny hole in the orifice,
water pressure is converted to water velocity capable of cutting most any material.
20480273
9-2009/Rev 01
1-2
Section 1
Introduction
The major components include the high pressure cylinder assemblies, hydraulic cylinder,
hydraulic piston, attenuator and the safety dump valve.
Figure 1-3: High Pressure System Components
1 High Pressure Cylinder Assembly
4 Safety Dump Valve
2 Hydraulic Cylinder Assembly
5 Attenuator
3 Hydraulic Piston
Operating System
A programmable logic controller (PLC) provides basic intensifier shift control and monitors
out of limit conditions. Operator interface is through the function-button control panel.
Figure 1-4: Control Panel
20480273
9-2009/Rev 01
1-3
Section 1
Introduction
1.4
Safety
The high pressure waterjet cutting system is a high energy cutting tool capable of cutting
many dense or strong materials. Do not touch or be exposed to high pressure water. High
pressure water will penetrate all parts of the human body. The liquid stream and the material
ejected by the extreme pressure can result in severe injury.
All personnel operating, servicing or working near the waterjet cutting equipment shall adhere
to the following safety precautions, as well as the applicable plant safety precautions.
•
Only KMT factory trained, qualified personnel shall service and maintain the
equipment.
•
The operator shall practice and promote safety at all times to avoid potential
injury and unnecessary downtime.
•
The operator shall ensure that the work area around the equipment is clean and
free of debris and oil spills.
•
All protective guards, shields or covers shall be in place on the equipment at all
times.
•
Safety glasses and ear protection shall be worn when operating or
working near the equipment.
Lockout/Tagout Procedure
This lockout/tagout procedure is designed to protect all employees from injuries caused by the
unexpected energizing or startup of the machine, or the release of stored energy during
service and maintenance.
This is accomplished with energy isolating devices that prevent the transmission or release of
energy. An energy source is any source of electrical, mechanical, hydraulic, pneumatic,
chemical, thermal, or other energy source that could cause injury to personnel.
A lockout device utilizes a lock and key to hold an energy isolating device in the safe position
and prevents the machine from being energized. A tagout device is a prominent warning
device that can be securely attached to the machine warning personnel not to operate the
energy isolating device. This procedure requires the combination of a lockout device and a
tagout device.
The lockout/tagout procedure applies to any employee who operates and/or performs service
or maintenance on the machine. Before any maintenance or repairs are performed, the
machine shall be isolated, and rendered inoperative as follows.
1. Shut down the machine by pressing the F1 key and open the high pressure cutting
water valve to bleed the water and hydraulic pressure from the system.
2. Disconnect, lockout and tag the main, customer supplied, power source.
3. Lockout and tag the circuit breaker/disconnect on the electrical enclosure door.
20480273
9-2009/Rev 01
1-4
Section 1
Introduction
4. Close, lockout and tag the manual shutoff valves for all service connections: cutting
water in, cooling water in and out, and air.
Warning Labels
Warning labels are posted on the machine to indicate potential hazards. The operator and
service personnel shall pay particular attention to these warning labels. Table 1-2 describes
the necessary precautions and provides the part number required to order replacement labels.
Table 1-2
Warning Label Precautions
The electrical enclosure and motor junction box can
present an electrical shock hazard. Always disconnect
and lockout the main power before opening the
enclosure.
1
P/N 05114962
Always disconnect and lockout the main power and the
circuit breaker/disconnect on the electrical enclosure
door before performing any type of maintenance
The surface of high pressure water and hydraulic
components becomes hot during normal operation.
Failed, or failing components, can become extremely
hot during operation.
2
P/N 05114970
Ensure all protective guards, shields or covers are in
place on the equipment at all times. Never operate the
pump with the guards removed.
3
P/N 80082209
20480273
9-2009/Rev 01
1-5
Section 1
Introduction
Table 1-2
Warning Label Precautions
High pressure water and/or hydraulic pressure can
remain in the system even when the pump has been shut
off. All pressure can be safely bled from the system by
opening the high pressure cutting water valve for a few
seconds after shutting off the pump.
4
Pressing the EMERGENCY STOP button turns the control
power to the intensifier off, stops the pump and bleeds
the high pressure water through the safety dump valve.
P/N 05098017
Depressurization of the high pressure system creates a
loud hissing sound when the dump valve opens. The
sound fades quickly as the pressure drops.
All personnel involved in the installation, operation
and/or service of the intensifier must carefully read,
understand and follow the procedures in this manual to
avoid creating unsafe conditions, risking damage to the
equipment, or personal injury.
5
P/N 20415794
Safety precautions and warnings for specific procedures are emphasized throughout this
manual as illustrated in the following examples. These precautions must be reviewed and
understood by operating and maintenance personnel prior to installing, operating or servicing
the machine. Adherence to all Warnings, Cautions and Notes is essential to safe and efficient
service and operation.
WARNING
Warnings emphasize operating or service procedures, or conditions that can result
in serious personal injury or death.
CAUTION
Cautions emphasize operating or service procedures, or conditions that can result
in equipment damage or impairment of system operation.
NOTE
Notes provide additional information that can expedite or improve operating or
service procedures.
20480273
9-2009/Rev 01
1-6
Section 1
Introduction
Emergency Medical Treatment
An emergency medical card is included in the binder of this manual. This information should
be used to aid in the treatment of a waterjet injury. Additional cards may be obtained by
contacting KMT Waterjet Systems using the address or telephone number shown on the card.
Medical Alert
This card is to be carried by personnel
working with high pressure waterjet
equipment. Obtain medical treatment
immediately for ANY high pressure waterjet
injuries.
KMT Waterjet Systems
635 West 12th Street
Baxter Springs, KS 66713
(620) 856-2151
1.5
This person has been working with water jetting at
pressures to 60,000 psi (414 MPa, 4137 bar, 4,218
Kg/cm2) with a jet velocity of 3,000 fps (914 mps).
Foreign material (sand) may have been injected
with water. Unusual infections with
microaerophilic organisms occurring at lower
temperatures have been reported, such as gram
negative pathogens as are found in sewage.
Bacterial swabs and blood cultures may therefore
be helpful. This injury must be treated as an acute
surgical emergency and be evaluated by a qualified
surgeon. Circulation may be compromised,
therefore, DO NOT APPLY HEAT TO INJURED
PART. For first aid: (1) Elevate injured part (2)
Antibiotics (3) Keep injured person NPO.
Worldwide Product Support
The KMT Waterjet Customer Service Department is available to answer your questions
regarding equipment installation and service. Technical assistance is available by phone and
on-site support is available on request.
On-site technical assistance is available during equipment installation and startup.
Additionally, technical support for service and maintenance issues and training of operators
and maintenance personnel is available. Periodic training sessions are also conducted at
KMT Waterjet and customer facilities.
Contact the KMT Waterjet Customer Service Department for additional information.
USA Customer Service Manager
20480273
9-2009/Rev 01
Europe
Technical Manager
KMT Waterjet Systems
PO Box 231
635 West 12th Street
Baxter Springs, KS 66713
USA
KMT Waterjet Systems GmbH
Wasserstrahl-Schneidetechnik
Auf der Laukert 11
D-61231 Bad Nauheim
Germany
Phone: (800) 826-9274
Fax: (620) 856-2242
Email:
[email protected]
[email protected]
Phone: +49-6032-997-117
Fax: +49-6032-997-270
Email:
[email protected]
1-7
Section 1
Introduction
1.6
Spare Parts
KMT Waterjet maintains a well-stocked Spare Parts Department, staffed by trained,
knowledgeable personnel. If required, emergency shipment is available. Contact the
Customer Service Department to order spare parts, or for additional information.
1.7
Manual Organization
This manual contains operating and maintenance procedures for the JetlineTM Series.
Information is organized as follows:
1.8
•
Section 1, Introduction, provides an overview of equipment features and options, a
brief operational overview, details regarding safety issues and contact information for
product support.
•
Section 2, Installation, details installation requirements and procedures. Systematic
guidelines for commissioning the intensifier are also provided.
•
Section 3, Maintenance, highlights routine and preventive maintenance requirements.
Precautions associated with high pressure cutting equipment are also reviewed.
•
Section 4, Operation, explains the control functions and the display panel where
operating parameters are set and monitored.
•
Sections 5 through 9 are specific to each individual system. Each section contains a
detailed description of the principles of operation and the function of each system.
Routine maintenance procedures associated with the system are also detailed.
•
Section 10, Troubleshooting, is a comprehensive guide containing the information
required to diagnose problems and repair the machine.
•
Section 11, Specifications, contains a comprehensive list of equipment specifications;
a detailed discussion of water quality standards and treatment guidelines; as well as
horsepower requirements for various orifice sizes.
•
Section 12, Parts List, contains part numbers, descriptions and drawings to facilitate
the ordering of replacement parts.
Equipment and Service Manual Questionnaire
We are interested in your impression of the KMT Waterjet System recently installed at your
location. Your comments and recommendations will aid us in our continuing goal to improve
our products, and make our technical information more useful to our customers.
At your convenience, please take a few minutes to complete the following questionnaire, and
return it to the applicable Customer Service Department listed above.
20480273
9-2009/Rev 01
1-8
Equipment and Service Manual Questionnaire
1.
General Appearance
Was the unit received in good condition?
Yes
No
Yes
No
Are the controls user friendly?
Yes
No
Is the unit easy to operate?
Yes
No
Does the unit perform smoothly and meet your expectations?
Yes
No
Does the unit run quietly?
Yes
No
Yes
No
Comments:
Is the unit a convenient size?
2.
Controls
Comments:
3.
Performance
Comments:
4.
Did the installation and startup go smoothly?
Comments:
5.
What features do you consider the most significant?
Quiet operation
Appearance
Performance/Operation
Repair/Maintenance
Other
6.
What areas could be improved?
Appearance
Performance
Serviceability
Other
20480273
9-2009/Rev 01
1
Equipment and Service Manual Questionnaire
7.
Manual Organization
Does the Table of Contents help you find topics easily?
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Comments:
Is the information well organized?
Comments:
Is the page layout suitable for the material being presented?
Comments:
8.
Graphics
Are the illustrations suitable for the material being presented?
Comments:
9.
Text
Does the information adequately explain how to operate and service the
equipment?
Comments:
Are there paragraphs or procedures you feel need clarification? Please
identify them by page number and add your comments.
Comments:
Is there anything you would add or delete to make the manual more useful?
Comments:
Is there any information that should receive more emphasis?
Comments:
Name
Title
Company
Date
Address
20480273
9-2009/Rev 01
2
SECTION 2
INSTALLATION
2.1
Overview
Installation and commissioning requirements and procedures are detailed in this section.
These procedures require a thorough understanding of the individual components and systems,
safety issues, and the overall operation of the intensifier.
All personnel involved in the installation, operation and/or service of the intensifier must
carefully review this manual prior to installing and commissioning the machine.
The Technical Service Department at KMT Waterjet Systems is available to assist in the
installation and commissioning process. Service and repair training for maintenance
personnel is also available.
2.2
Installation Summary
The following summary lists the procedures required for the installation and commissioning
of the intensifier system. Details and requirements for each item are discussed in this section.
•
Upon receipt, the machine must be uncrated and moved into position on a level
surface.
•
Properly sized power drops with fused disconnects must be installed.
•
A pneumatic drop with a manual shutoff valve and regulator for the air connection
must be installed.
•
Plumbing and manual shutoff valves for the inlet and outlet cooling water, and the
inlet and outlet cutting water must be installed.
Incoming source water must meet specific water quality standards, flow rates and
pressure requirements. It may be necessary to install water conditioning and/or
pressure boosting equipment to meet these water purity and pressure requirements.
20480282
8-2010/Rev 02
•
Drain water plumbing must be suitably located and installed for the proper disposal of
wastewater.
•
High pressure tubing runs from the intensifier to the cutting station must be installed
with the appropriate mountings, support brackets and hardware.
•
Wiring must be installed and connected between the intensifier and the cutting station
control system.
•
The machine must be commissioned and tested.
2-1
Section 2
Installation
2.3
Site Requirements
The intensifier must be installed indoors where air borne dust and contaminants are minimal.
The ambient temperature should be between 40° F (5° C) and 104° F (40° C), with a
maximum relative humidity of 95 percent.
Refer to Table 2-1, Equipment Dimensions and Weight, to establish a suitable installation site.
A minimum clearance of 36 inches (914 mm) should be provided on all sides of the machine
to facilitate service.
Figure 2-1: Equipment Dimensions
Table 2-1
Equipment Dimensions and Weight
Model
(1) Length
(2) Width
(3) Height
Weight
JL-1 30
78.98” (2,006 mm)
36.00” (914 mm)
46.58” (1,183 mm)
2,450 lbs (1,111 kg)
JL-1 50
78.98” (2,006 mm)
36.00” (914 mm)
46.58” (1,183 mm)
2,650 lbs (1,202 kg)
Transporting
The weight of the machine is not evenly distributed from one end to the other. Do not attempt
to lift the machine from either end. Note the warnings stamped on the crate. The center of
gravity is clearly identified on the sides of the crate. The forklift should be positioned
accordingly.
When the machine has been removed from the crate, note the position of the fork pockets on
the bottom of the machine. The pockets are positioned in relationship to the center of gravity
to balance the weight on the forklift.
CAUTION
Position the forklift carefully to avoid damage to the high pressure attenuator and
high pressure tubing.
20480282
8-2010/Rev 02
2-2
Section 2
Installation
Figure 2-2: Fork Pockets
Table 2-2
Fork Pockets
A
B
Fork Pocket Dimensions
Height
2.0” (50.8 mm)
Width
8.0” (203.0 mm)
Length
36.0” (914.4 mm)
Distance Between Pockets
36.0” (914.4 mm)
If the machine will be installed in an overhead location, a forklift or crane can be used to
position the pump. Heavy straps or chains, properly rated for the weight requirements, should
be placed through each fork pocket, and wrapped around the sides of the machine so they
meet on the top. The straps can then be attached to a crane or forklift to lift the machine.
CAUTION
The machine must be lifted from the bottom. Do not attempt to lift the machine
from the intensifier.
2.4
Power Requirements
Power supplied to the pump and wiring for remote control must comply with local, regional
and national electrical codes. Service voltage and ampacity must meet the requirements of
the specific model. Voltage fluctuations in excess of +/- 10 percent of nominal voltage may
damage the machine and void the warranty. Refer to Table 2-3, Ampacity and Power Voltage
Requirements.
20480282
8-2010/Rev 02
2-3
Section 2
Installation
Table 2-3
Ampacity and Power Voltage Requirements
Motor
Horsepower
Full Load
Amps
Circuit Breaker
Amps
208/3/60
30
80
100
230/3/60
30
76
100
380/3/50
30
44
60
400/3/50
30
43
60
415/3/50
30
43
60
460/3/60
30
38
50
575/3/60
30
32
40
200/3/50-60
50
132
175
208/3/50-60
50
128
175
240/3/60
50
112
175
380/3/50
50
69
100
400/3/50
50
66
100
415/3/50
50
64
100
480/3/60
50
56
80
575/3/60
50
47
80
Power Voltage
2.5
Service Connections
The intensifier requires two incoming water sources, cooling water and cutting water; two
drain lines, cooling water and wastewater; a high pressure discharge line, and an air supply
line. All piping must comply with local, regional and national codes.
All service connections are made on the rear bulkhead of the machine as shown in Figure 2-3,
Service Connections. Table 2-4 lists the fittings required for each interface connection.
With the exception of the wastewater drain line, manual shutoff valves should be installed for
all connections. To facilitate service, the valves should be located as close as practical to the
interface connection.
CAUTION
Thoroughly purge all supply plumbing prior to connection to remove any residue
that could contaminate the system.
20480282
8-2010/Rev 02
2-4
Section 2
Installation
Figure 2-3: Service Connections
Table 2-4
Service Connections
Connection
Height
A
Drain
1/2” BSPT
12.51” (318 mm)
B
Cutting Water In
1/2” BSPT
16.26” (413 mm)
C
Cooling Water In
1/2” BSPT
20.01” (508 mm)
D
Cooling Water Out
1/2” BSPT
23.76” (604 mm)
E
Contaminated Waste Drain
1/2” BSPT
28.76” (730 mm)
F
Cutting Water Out
9/16” HP
36.26” (921 mm)
G
Plant Air In
1/4” BSPT
40.26” (1,023 mm)
Cooling Water
Inlet cooling water flows through the oil-to-water heat exchanger in the hydraulic system to
control heat buildup in the hydraulic oil. The cooling water is then discharged through the
cooling water out port to either the drain or routed to a customer supplied water chiller.
Cooling water supply piping must be sized to meet the flow and pressure requirements of the
equipment. If municipal or well water is used for cooling, ensure the supply flow and
pressure meet the requirements in Section 11, Specifications.
If a facility-wide chilled water system is used for cooling, ensure there is a minimum of 35 psi
(2.4 bar) pressure differential between the facility supply and discharge plumbing.
Installation of an in-line pressure boosting pump may be necessary to provide adequate
cooling flow. Dedicated chilled water systems should be sized according to pump
horsepower as illustrated in Table 2-5, Chilled Water Systems.
20480282
8-2010/Rev 02
2-5
Section 2
Installation
Table 2-5
Chilled Water Systems
Cooling Requirements at Full Capacity
Horsepower
BTU/HR
30
13,400
50
22,000
Note: Coolant flow to the heat exchanger is regulated
by the temperature of the contents in the
hydraulic reservoir and will be shut off at times.
Cutting Water
Inlet cutting water is routed to the intensifier where it is pressurized and delivered to the
cutting head. The cutting water supply must meet the minimum water quality standards
outlined in Section 11, Specifications. Poor water quality will drastically shorten component
life and void the warranty.
Cutting water supply piping must be sized to meet the flow and pressure requirements listed
in Section 11. Only PVC, copper or rubber hose should be used between the cutting water
source and the machine.
The inlet cutting water must be maintained at a minimum pressure of 35 psi (2.4 bar) at all
times. If the facility water pressure is below, or can fall below 35 psi (2.4 bar), a water
pressure booster pump is required.
NOTE
The machine will not start if inlet cutting water pressure is below 30 psi (2 bar).
Drain
Cutting water released through the safety dump valve when the emergency stop button is
initiated is discharged from the drain port. The discharge is considered wastewater and must
be piped to an appropriate location, i.e. a sewer line. The volume of water released will be
minimal and does not require high pressure plumbing; however, piping must comply with
local, regional and national codes.
Plant Air
The facility compressed air connection should provide clean, dry air regulated to 85 psi (5.9
bar). Air usage is minimal, normally less than 1 scf/m.
The following table provides specifications for each ISO air quality classification. KMT
recommends adherence to Quality Class 4.
20480282
8-2010/Rev 02
2-6
Section 2
Installation
Table 2-6
ISO Air Quality Classifications
ISO Quality
Class
Maximum
Particle Size
(microns)
Maximum Pressure
Dew Point
(water @ 100 psi)
Maximum Oil Content
(Mg/m3)
1
0.1
-94° F (-60° C)
0.01
2
1
-40° F (-40° C)
0.1
3
5
-4° F (-20° C)
1
4
15
+38° F (+3° C)
5
5
40
+45° F (+7° C)
25
6
--
+50° F (+10° C)
--
Contaminated Waste Drain
Oil and water that can accumulate on the drip pans is disposed of through the contaminated
waste drain on each pan. This oil and water mixture is considered contaminated and disposal
must comply with local, regional and national codes. The volume of waste will be minimal
and can be collected in a container of some appropriate type.
2.6
Flow Requirements
Figure 2-4, Pressure Drop Values, illustrates the pressure drop for four different pipe sizes.
The graph can be used to calculate the minimum source water pressure.
1. Enter the graph at the required GPM and note the pressure drop figures for the
different pipe sizes.
2. Multiply the pressure drop (PSI/FT) by the length in feet of each pipe size used from
the water source to the intensifier. Add the values together for a total pressure drop
value.
3. Add 30 to the total pressure drop to determine the minimum flowing, source water
pressure required to provide adequate supply to the intensifier.
Cutting water and cooling water capacity should be calculated separately. Note that the
cutting water requirements represent instantaneous, not average, demand.
20480282
8-2010/Rev 02
2-7
Section 2
Installation
Figure 2-4: Pressure Drop Values
Pressure drop (PSI/FT)
Pipe Sizing
0.45
0.4
0.35
0.3
0.25
1/2" ID
3/4" ID
1" ID
0.2
0.15
0.1
0.05
0
1-1/4" ID
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Required GPM
2.7
High Pressure Piping
High pressure piping is used to transport high pressure cutting water from the machine to the
cutting station. High pressure piping and fittings must be properly rated and sized. When
transporting high pressure water over long distances, tubing and fittings with an outside
diameter of 9/16-inch are recommended. The large tubing size reduces vibration, strain and
motion; as well as reducing pressure drop and pulsation.
WARNING
High pressure tubing and fittings must be rated for 60,000 psi (4,136 bar). Failure
to use properly rated components may result in component failure causing
equipment damage, personal injury or death.
High pressure tubing lengths must be coned and threaded prior to installation. KMT Waterjet
provides both hand and power tools for coning and threading high pressure tubing. Tool
descriptions and part numbers are provided in Table 2-7.
Table 2-7
Coning and Threading Tools
Part Number
20480282
8-2010/Rev 02
Hand Tools
Power Tools
1/4” Coning Tool
05108832
05109897
3/8” Coning Tool
05108857
05109889
9/16” Coning Tool
05108840
05109871
1/4” Threading Tool
05108865
05122742
3/8” Threading Tool
05108873
05120258
9/16” Threading Tool
05108881
05122759
2-8
Section 2
Installation
Table 2-7
Coning and Threading Tools
Part Number
20480282
8-2010/Rev 02
1/4” Tube Vise
05108782
3/8” Tube Vise
05108790
9/16” Tube Vise
05108774
2-9
Section 2
Installation
Measurements and Dimensions
Tubing must be cut to the proper length, both ends of the tubing must then be coned, threaded
and deburred.
To determine the tube length, measure the distance between the fittings, and add two times
the engagement allowance shown in Table 2-8. Table 2-9 lists the required cone and thread
dimensions illustrated in Figure 2-6.
Figure 2-5: Tube Length
Table 2-8
Engagement Allowance (EA)
1/4” Tubing
0.49” (12.4 mm)
3/8” Tubing
0.68” (17.3 mm)
9/16” Tubing
0.86” (21.8 mm)
Tube Length = Length + 2(EA)
Figure 2-6: Cone and Thread Dimensions
Table 2-9
Cone and Thread Dimensions
Tube OD
Tube ID
D
(Maximum)
L
(Maximum)
Thread
UNF-LH
1/4” (6.35 mm)
0.083” (2.11 mm)
0.125” (3.2 mm)
0.562” (14.3 mm)
1/4” - 28
3/8” (9.52 mm)
0.125” (3.18 mm
0.219” (5.6 mm)
0.750” (19.1 mm)
3/8” - 24
9/16” (14.29 mm)
0.188” (4.78 mm)
0.281” (7.1 mm)
0.938” (23.8 mm)
9/16” - 18
20480282
8-2010/Rev 02
2-10
Section 2
Installation
Hand Coning
Figure 2-7: Hand Coning Tool
1 Tubing
5 Handle
2 Collet
6 Blade
3 Access Window
7 Body
4 Feed Nut
8 Gland Nut
1. Place the body of the coning tool in a vise allowing adequate clearance for the rotation
of the cutter handle. Position the tool so the cutter handle is elevated slightly so the
lubricant will flow to the cutting blade.
2. Turn the feed nut counter-clockwise to retract the cutting blade past the access
window.
3. Loosen the gland nut and insert the tubing through the collet. The end of the tubing
should just make contact with the cutting blade. Loosely tighten the gland nut to
slightly grip the tubing.
4. Turn the feed nut counter-clockwise 1/4 turn to retract the cutting blade away from the
tubing, and tighten the gland nut with a wrench.
5. Apply a liberal amount of cutting oil to the exposed end of the tubing, the cutting
blade and through the lubrication channel at the cutter handle.
Apply cutting oil frequently and liberally throughout the cutting operation. A medium
weight cutting oil with high sulfur content is recommended.
6. Turn the feed nut clockwise until the cutting blade contact the end of the tubing.
7. In a smooth, continuous motion, turn the cutter handle in a clockwise direction.
Simultaneously turn the feed nut in a clockwise direction to establish a constant feed.
Do not remove too much material at once; the cutting blade should make light,
uninterrupted cuts.
20480282
8-2010/Rev 02
2-11
Section 2
Installation
NOTE
Before interrupting the cut, back the cutter blade away from the tubing. Use
compressed air or a small brush to remove the accumulation of chips from the
blade and the tubing throughout the coning operation.
8. Continue the operation until the feed nut bottoms on the housing. Turn the cutter
handle several more rotations to face-off the end of the cone.
9. Retract the cutter blade, loosen the gland nut and remove the tubing. Inspect the cone
for surface finish and completeness.
NOTE
Clean the machining chips from the blade and from the collet before coning the
next tube.
Power Coning
1. Secure the tubing in a tube vise. No more than the recommended length of tubing
should extend beyond the face of the vice. See Table 2-10, Recommended Extension
Length.
2. Mount the coning tool in a 3/8-inch or 1/2-inch, variable speed power drill. Apply
cutting oil to the end of the tube and slide the coning tool on the tubing.
3. Apply steady pressure against the end of the tubing while the cone is being cut.
Apply cutting oil frequently and liberally throughout the cutting operation. A medium
weight cutting oil with high sulfur content is recommended.
4. The tool will stop cutting when the tube angle and facing is complete.
NOTE
Clean the machining chips from the blade and body of the tool before coning the
next tube.
20480282
8-2010/Rev 02
2-12
Section 2
Installation
Table 2-10
Recommended Extension Length
1/4” Tubing
1.25-1.50” (31.8-38.1 mm)
3/8” Tubing
1.25-1.50” (31.8-38.1 mm)
9/16” Tubing
1.75-2.00” (44.5-50.8 mm)
Hand Threading
1. Secure the coned tubing in a tube vise. No more than the recommended length of
tubing should extend beyond the face of the vice. See Table 2-10, Recommended
Extension Length.
2. Apply cutting oil to the end of the tube and slide the threading tool on the tubing.
3. Grip the handles of the tool firmly, apply steady pressure and turn the tool counterclockwise. Approximately every half turn, reverse direction to break off and remove
the chips.
Apply cutting oil frequently and liberally throughout the cutting operation. A medium
weight cutting oil with high sulfur content is recommended.
4. Continue threading until the proper thread length is reached, see Table 2-9, Column L.
Remove the tool from the end of the tubing.
NOTE
Clean the machining chips from the die and body of the tool before threading the
next tube.
Power Threading
1. Secure the coned tubing in a tube vise. No more than the recommended length of
tubing should extend beyond the face of the vice. See Table 2-10, Recommended
Extension Length.
2. Mount the threading tool in a 3/8-inch or 1/2-inch, variable speed power drill. Apply
cutting oil to the end of the tube and slide the threading tool on the tubing.
3. Make sure the drill is set to turn counter-clockwise. Apply steady pressure against the
end of the tubing while the threads are being cut.
Apply cutting oil frequently and liberally throughout the cutting operation. A medium
weight cutting oil with high sulfur content is recommended.
4. Continue threading until the proper thread length is reached. See Table 2-9, Column L.
Reverse the direction of the drill and remove the threading tool.
20480282
8-2010/Rev 02
2-13
Section 2
Installation
NOTE
Clean the machining chips from the die and body of the tool before threading the
next tube.
2.8
High Pressure Connections
When installing high pressure discharge piping it is essential that all burrs are carefully
removed and the tubing sections purged with clean compressed air prior to assembly. Lightly
spraying the inside of the tube with a carrier fluid, such as WD-40, before purging with air
will help carry the burrs.
High pressure piping must be installed without torsional or bending stresses and proper
supports and guides must be provided. Torsional stress will cause premature component
failure.
Pure Goop anti-seize compound must be applied to the threads and contact surfaces of all
stainless steel components prior to assembly. Failure to lubricate components with Pure
Goop will result in galling, rendering the components useless.
CAUTION
Do not use any other anti-seize compound. Apply Pure Goop only to stainless
steel components.
Standard Connections
Standard connections are used for general applications where internal pressure is the only
load on the tubing.
Figure 2-8: Standard High Pressure Connections
1 Gland Nut
3 Exposed Threads
2 Collar
4 Tubing
1. Deburr the tubing ID and thoroughly clean the tubing threads.
2. Slip the gland nut onto the tubing.
20480282
8-2010/Rev 02
2-14
Section 2
Installation
3. Apply Pure Goop to the threads on the tubing. Screw the collar onto the threaded end
of the tubing leaving 1-1/2 to 2-1/2 threads exposed on the tubing between the collar
and the coned tubing.
4. Apply Pure Goop to the male threads on the gland nut and insert the tubing into the
connection. Engage the gland nut and tighten finger tight.
5. Tighten the gland nut to the torque specifications in Table 2-11.
WARNING
Proper piping supports and guides must be provided. End connections will not
support the tubing load alone.
Table 2-11
Torque Specifications
High Pressure Connections
1/4” Tubing
25 ft-lb (34 Nm)
3/8” Tubing
50 ft-lb (68 Nm)
9/16” Tubing
110 ft-lb (149 Nm)
Anti-Vibration Connections
The bending stresses resulting from excessive vibration or shock on the threaded area of the
tubing can cause premature failure at the back of the thread. When tubing will be subjected to
vibration, rotation and movement, anti-vibration connections must be used. The antivibration collet gland transfers the stress to the unthreaded section of the tubing, and the
gripping action of the collet strengthens the entire assembly.
Figure 2-9: Anti-Vibration Connections
1 Gland Nut
4 Exposed Threads
2 Collet
5 Tubing
3 Collar
20480282
8-2010/Rev 02
2-15
Section 2
Installation
1. Deburr the tubing ID and thoroughly clean the tubing threads.
2. Slip the gland nut and the collet onto the tubing.
3. Apply Pure Goop to the threads on the tubing. Screw the collar onto the threaded end
of the tubing leaving 1-1/2 to 2-1/2 threads exposed on the tubing between the collar
and the coned tubing.
4. Apply Pure Goop to the male threads on the gland nut and insert the tubing into the
connection. Engage the gland nut and tighten finger tight.
5. Tighten the gland nut to the torque specifications in Table 2-11.
When a flexible whip is used to allow cutting nozzle movement, anti-vibration fittings and
proper supports and guides must be provided to prevent failures from non-water related
stresses. The whip will only flex in a single plane without being subjected to torsional stress.
The use of high pressure swivels is strongly recommended.
2.9
Commissioning
When the machine has been positioned, all service connections installed, and the high
pressure plumbing has been installed to the cutting area, the machine is ready to be
commissioned.
The following procedure is used for the initial startup and testing of the machine.
1. Check all areas in and around the pump for foreign objects and debris. Remove all
tools, parts, etc. from the area.
2. Check the hydraulic fluid level. The hydraulic system is pre-filled prior to shipping.
If the hydraulic fluid is low or empty due to leakage during transit, the system must be
filled. Follow the instructions and specifications in Section 6, Recirculation System.
3. Open the shutoff valves on the service connections and check for leaks.
4. Check the connection between the customer supplied, main power disconnect and the
disconnect/circuit breaker on the enclosure door. Verify the proper voltage supply.
Close the enclosure door and turn the control power on.
5. To activate control power, pull the EMERGENCY STOP button out and press the RESET
button. Refer to Section 4, Operation, for additional information regarding control
panel functions.
1
2
1 Emergency Stop
20480282
8-2010/Rev 02
2 Reset Button
2-16
Section 2
Installation
6. On the Run Screen, press the F3 button to select low pressure operation.
7. To avoid a sudden increase in pressure, it is necessary to adjust the high pressure
setting. The high pressure adjustment is made at the high pressure control valve on
the hydraulic manifold. Refer to Section 7, Hydraulic System, for additional
information.
Loosen the locking nut on the high pressure control valve by turning counterclockwise. Turn the high pressure control valve counter-clockwise, decreasing the
pressure to the lowest setting.
1 Hydraulic Manifold
3 High Pressure Control Valve
2 Hydraulic Pressure Gauge
8. Check the motor rotation. Press the F1 button from the Run Screen to start the motor,
and observe the pressure gauge on the hydraulic manifold. If the motor rotation is
correct, pressure will begin to build in just a few seconds. If the rotation is not correct,
the gauge will not move.
If the motor shaft is rotating in the wrong direction turn the control power off by
pressing the EMERGENCY STOP button.
The electrical power phase must be reversed to any two motor leads. The leads can be
reversed at the disconnect/circuit breaker on the enclosure door, or at the main power
disconnect.
CAUTION
Do not allow the motor to run backward. Incorrect motor rotation will result in
damage to the hydraulic pump.
9. Remove the cutting orifice and open the nozzle valve.
20480282
8-2010/Rev 02
2-17
Section 2
Installation
10. Activate the control power and press the F1 button on the Run Screen to start the
motor. The dump valve will open for a short time to allow trapped air to bleed from
the high pressure cylinders. Run the machine in low pressure for approximately five
minutes with the orifice removed to purge the system.
11. Check for any leaks in the plumbing, or around the high pressure cylinders. If leaks
are detected, stop the machine and correct any problems.
12. Observe the pressure gauge on the outlet manifold to ensure the discharge cutting
water pressure is between 90-120 psi (6-8 bar). If not, the booster pump pressure must
be adjusted. Refer to Section 5, Low Pressure Water System, for additional
information.
Remove the acorn nut on the side of the booster pump and use a flat blade screwdriver
to turn the adjustment screw. Turn the screw clockwise to increase the pressure or
counter-clockwise to decrease the pressure.
13. Check the safety circuits by pushing the EMERGENCY STOP button in and verifying that
the power goes off and high pressure water is drained from the system. If applicable,
check all remote start and emergency stop functions.
14. Install a large, inexpensive orifice and start the machine.
15. Press the F3 button from the Run Screen to select high pressure operation. Increase
the high pressure setting in gradual increments, checking for leaks at each interval.
Continue increasing the pressure until the operating pressure is reached.
The high pressure setting is increased by turning the high pressure control valve on the
hydraulic manifold clockwise.
NOTE
It is strongly recommended that the high pressure plumbing be purged under high
pressure operating conditions, using a large, inexpensive orifice. Contamination
can be released when the tubing expands under pressure. Early orifice failures
could be experienced if the piping is not adequately purged.
2.10
Decommissioning
All local regulations must be adhered to when the intensifier is decommissioned and taken out
of service for any reason.
20480282
8-2010/Rev 02
2-18
SECTION 3
MAINTENANCE
3.1
Overview
The JetllineTM series has been designed to fail safely. Systems fail gradually; seals and
connections can begin to leak slowly or suddenly through specially designed weep holes.
Water or oil dripping from a weep hole indicates internal seals or valves are beginning to fail,
a warning that maintenance will be required.
The comprehensive fault detection and troubleshooting logic built into the programmable
logic controller (PLC) monitors crucial temperature and fluid levels. Warning and shutdown
sensors guard against potential injury and equipment damage.
3.2
Maintenance
The waterjet system has been designed for ease of maintenance and long, reliable operation.
In order to keep the equipment in optimum operating condition, routine and preventive
maintenance is essential. Detailed maintenance procedures for specific systems are provided
in subsequent sections of this manual.
Daily Inspection
The following inspection procedures should be performed each day. If problems are detected,
they should be remedied before placing the machine in service.
•
•
Prior to startup, inspect the area around the machine, the high pressure piping and
connections for indications of leaks.
•
Make sure there is no maintenance work in process.
•
Check the hydraulic oil level.
As the machine is started and water pressure increases, listen for unusual sounds.
•
Check for water or oil leakage.
•
Check the condition of the hydraulic oil filter
•
Check the condition of the low pressure water filter.
Periodic Maintenance
A number of factors can contribute to component failure; poor water quality, operating
conditions, or improper maintenance procedures. Maintaining a service log can be a useful
method of tracking component life and maintenance trends. Analyzing service intervals will
assist in preparing a preventive maintenance schedule tailored to your specific application and
production requirements. Periodic maintenance, at regularly scheduled intervals, will
minimize unscheduled downtime and premature component failure.
20480285
7-2011/Rev 03
3-1
Section 3
Maintenance
Improper assembly can lead to the premature failure of components. Maintenance procedures
must be followed carefully; components must be properly cleaned prior to assembly and
tightened to the correct torque specifications.
•
Maintain a clean, dust and dirt free work area for maintenance.
•
Use only clean, dry air and clean, filtered solvent when flushing parts.
•
Use lint free cloths for cleaning.
•
Use extreme care when aligning close tolerance parts for assembly. Do not force the
parts together. If parts bind during assembly, they must be disassembled and realigned.
•
Use only original KMT Waterjet replacement parts for consistent performance and
reliability; and to protect equipment warranty.
To avoid unsafe conditions and the risk of equipment damage, operating personnel and
service technicians must carefully read and follow the procedures in this manual.
High Pressure System Maintenance
All high pressure service components are readily accessible, and can be removed from the
unit easily for maintenance and service.
•
High pressure fittings, valves and tubing must be rated for 60,000 psi (4,137 bar).
Failure to use properly rated components may result in component failure, equipment
damage and personal injury.
•
Do not over-torque fittings to stop leakage.
•
Ensure all components are clean, free of burrs, metal particles, dirt and dust prior to
assembly.
After servicing high pressure components the high pressure water system must be thoroughly
flushed to remove any debris or contaminates.
1. Operate the intensifier for a short period with the nozzle valve open and the orifice
removed.
2. Turn the intensifier off and install an orifice.
3. Turn the machine on and increase the operating pressure in gradual increments.
Check all high pressure connections for leaks.
20480285
7-2011/Rev 03
3-2
Section 3
Maintenance
Many components are lubricated prior to assembly. Table 3-1 lists the recommended
lubricants and their applications. Substitutions are not recommended.
Table 3-1
Lubrication Specifications
Description
Application
Part Number
Pure Goop, 1 ounce
Stainless steel threads and metal-tometal joints
10084440
FML-2 Grease, 14-1/2 ounce
O-rings, backup rings, bearing rings,
seal components
10087385
Non-stainless steel threads
49832199
JL-M Grease, 16 ounce
3.3
Maintenance Precautions
Make sure all safety devices are operational. Each device should be checked on a specified
schedule. If the device does not function, it must be replaced before operating the machine.
Check the EMERGENCY STOP button. The normal operating position is pulled out. Turn the
power on and activate the emergency stop button by pushing it in to verify the power goes off
and the safety dump valve opens to bleed the high pressure from the system.
Before performing any maintenance on the equipment, take the system out of service and
make sure the controls are properly locked and marked. Never perform any maintenance on
the equipment without making sure the main control power is locked out in the OFF position.
20480285
7-2011/Rev 03
•
Never service or maintain the equipment while it is operating.
•
All high pressure leaks must be repaired immediately. Press the EMERGENCY STOP
button to turn the control power off and bleed off the high pressure water from the
intensifier before performing maintenance.
•
Never service or maintain any high pressure component, or loosen any high pressure
fitting when it is pressurized. Press the EMERGENCY STOP button to turn the control
power off and bleed off the high pressure water from the intensifier before servicing.
•
If leakage occurs at a sealing surface, high pressure water is released through weep
holes. If a pressurized fitting is loosened, a jet of high pressure water will exit the
nearest weep hole with possible hazardous results.
3-3
Section 3
Maintenance
3.4
Tool Kit
Table 3-2 provides a list of the spare parts and maintenance tools included in standard tool kit
for Jetline series pumps. Components can also be ordered individually.
Table 3-2
Tool Kit
Part Number
20480285
7-2011/Rev 03
Description
Installation
Tool Kit
20471547
10087385
FML-2 Grease, 14-1/2 ounce
1
10079986
Strap Wrench
1
20470475
Seal Installation Tools, Pneumatic Valve
1
72113886
Cartridge Removal Tool
1
10084440
Pure Goop, 1 ounce
3
10149052
Glass Pane, 8.0 x 8.0 x .25
1
10149045
Emery Cloth, 600 Grit
6
05066139
Cylinder Wrench
1
10148674
HP Seal Installation Tool
1
10149029
Emery Cloth, 320 Grit
2
10149037
Emery Cloth, 400 Grit
4
10081370
Spanner Wrench, .25
1
10127884
Spanner Wrench, .38
1
20487868
Threadlocker 242 Adhesive, .50 milliliter
1
20494983
Threadlocker Primer, 1-3/4 ounce
1
05103957
Hex Driver
1
20484488
Vee Block
1
3-4
SECTION 4
OPERATION
4.1
Overview
The JetlineTM Series utilizes a programmable logic controller (PLC) to provide fault detection
and troubleshooting logic. The operator functions and warnings offer a comprehensive view
of impending and shutdown faults. The operator interface is through a function-button
control panel.
Figure 4-1: Control Panel
4
2
1
4.2
5
3
6
1 Green Light flashes at startup and
remains on during operation
4 Emergency Stop
2 Red Light flashes to signal alarm
condition
5 Reset Button
3 Function Button Control Panel
6 Keyed switch transfers control to a
remote panel
Startup Sequence
The startup sequence varies depending on the previous stop condition.
Startup after Motor Stop
After a normal motor stop control power remains on, and the safety dump valve opens to
release high pressure in the system. Press the F1 button on the Run Screen to initiate normal
operation. The pump is held in low pressure for 20 seconds, it then goes to high pressure or
remains in low pressure, depending on the previous pressure setting.
Startup after Emergency Stop
After an emergency stop control power is turned off, and the safety dump valve opens to
release high pressure in the system. The dump valve will close three seconds after the
intensifier begins to stroke.
20480289
2-2009/Rev 0
4-1
Section 4
Operation
Pull the E-STOP button out and push the RESET button to activate control power. Press the F1
button on the Run Screen to start the motor. The machine will be held in low pressure for 20
seconds to allow trapped air to bleed from the high pressure cylinders. It then goes to high
pressure or remains in low pressure, depending on the previous pressure setting.
4.3
Keypad and Screen Functions
The keypad allows you to navigate and select functions on the screen, return to a previous
screen and acknowledge alarms.
Table 4-1
Keypad Functions
Function
Comments
Use the arrows to highlight the desired function on the
screen.
When a fault condition occurs an alarm message will
appear over the screen and a small triangle will flash
in the corner of the screen. Pressing ESC will clear the
message, allowing you to navigate the screen, but it
will not clear the fault.
Press ESC twice to return to the previous screen.
To clear a fault, press the ▲ arrow to highlight the
flashing triangle and press ENTER to display the alarm
message. Press the ACK button to acknowledge the
fault.
Press ENTER to initiate a function.
Icon displays above the F1 button on the System,
Information, Settings and Maintenance Screens. Press
F1 on these screens to return to the Run Screen.
20480289
2-2009/Rev 0
4-2
Section 4
Operation
4.4
Run Screen
The Run Screen is the only screen where the pump can be started to create pressure, and a
normal motor stop can be performed.
Figure 4-2: Run Screen
On the Run Screen, the state of the function buttons F1, F2, F3 and F4 changes according to
the current status of the pump. The available function at any given time is displayed above
each button. For example, if the pump has been shut down the inlet water solenoid valve will
be closed and the F1 button display will be RESET as illustrated above. Pressing the F1 button
will reset and open the valve, and the display will change to START. Pressing the F1 button at
this point will start the pump.
The following functions are performed from the Run Screen:
•
Press the F1 button to reset the inlet water solenoid valve, start the pump to create
pressure, or stop the pump. After the pump is stopped, there is a five-second delay
before startup.
The inlet water solenoid valve is automatically closed five minutes after the pump
shuts down. Press the F1 button to reset and open the valve.
20480289
2-2009/Rev 0
•
Press the F2 button to start the pump in recirculation mode. The pump will recirculate
for 10 minutes before the function shuts off. Recirculation can be manually stopped
by pressing the F2 button. Recirculation time is indicated in the lower right-hand
corner of the screen.
•
Press the F3 button to select low or high pressure operation.
•
Press the F4 button to display the System Screen.
4-3
Section 4
Operation
4.5
System Screen
Pressing the F4 button on the Run Screen will display the System Screen options: information,
settings and maintenance.
Figure 4-3: System Screens
4.6
•
Press F1 to return to the Run Screen
•
Press F2 to display the Information Screen
•
Press F3 to display the Settings Screen
•
Press F4 to display the Maintenance Screen
Information Screen
Information screens display equipment and operating information. No functions are
preformed from these screens. The ▲ or ▼ arrow in the top, left-hand corner of the screen
indicates additional options. Use the ▲ or ▼ arrow on the keypad to view all information
options.
Figure 4-4: Information Screen
20480289
2-2009/Rev 0
4-4
Section 4
Operation
Hours Screen
The Hours Screen displays the total operating hours.
Figure 4-5: Hours Screen
Capacity Screen
The Capacity Screen displays the pump capacity as a percentage based on stroke rate.
Figure 4-6: Capacity Screen
20480289
2-2009/Rev 0
4-5
Section 4
Operation
Stroke Rate Screen
The Stroke Rate Screen displays the actual stroke rate as strokes/minute on both the left and
right side of the intensifier.
Figure 4-7: Stroke Rate Screen
Date/Time Screen
The Date/Time Screen displays the date and time.
Figure 4-8: Date/Time Screen
20480289
2-2009/Rev 0
4-6
Section 4
Operation
Program Information Screen
The Program Information Screen displays the PLC and HMI program numbers and revision
levels.
Figure 4-9: Program Information Screen
4.7
Settings Screen
Operating parameters and equipment options are established on the settings screens. The ▲
or ▼ arrow in the top, left-hand corner of the screen indicates additional options. Use the ▲
or ▼ arrow on the keypad to view all information options.
All settings screens are password protected and some screens are not accessible at the
customer level. Customer available screens require a login and password to access.
Figure 4-10: Settings Screen
20480289
2-2009/Rev 0
4-7
Section 4
Operation
Stroke Rate Screen
The overstroke setpoint is increased or decreased from the Stroke Rate Screen. Stroke rate
should be set slightly higher than the desired operating rate to shutdown the machine quickly
in the event of an overstroke condition. The upper limit stroke rate is preset according to the
horsepower rating of the machine. The JL-1 30 is preset at 37 strokes per minute and the JL-1
50 is preset at 60 strokes per minute.
Before setting the stroke rate, monitor the actual strokes/minute during normal operation. The
overstroke setpoint should then be set 20% above that rate.
Figure 4-11: Stroke Rate Screen
To increase or decrease the stroke rate, use the arrows on the keypad to highlight the desired
▲ or ▼ button on the screen. Continue to press ENTER until the desired stroke rate is
displayed.
Configuration Screen
The configuration screen is used at initial startup to set the horsepower and equipment
parameters for the specific pump. The Configuration Screen is not accessible at the customer
level.
20480289
2-2009/Rev 0
4-8
Section 4
Operation
Language Screen
The Language Screen lists the available display languages. Use the arrows on the keypad to
highlight the desired language and press ENTER to select. Or Press F4 to toggle through the
languages.
Figure 4-12: Language Screen
Serial Number Screen
The Serial Number Screen is password protected and used to record the serial number for the
specific pump. The Serial Number Screen is not accessible at the customer level.
Date/Time Screen
The date and time are changed from the Date/Time Screen. Use the arrows on the keypad to
highlight the value to be changed, month, day, year, etc. Press ENTER until the desired value
is displayed.
Figure 4-13: Date/Time Screen
HMI Screen
The HMI Screen is used to load a new operating program and is not accessible at the
customer level.
20480289
2-2009/Rev 0
4-9
Section 4
Operation
4.8
Maintenance Screen
The Maintenance Screen is used to facilitate maintenance procedures and reset maintenance
hours and strokes. When started from the Maintenance Screen, the pump starts in
maintenance mode.
Figure 4-14: Maintenance Screen
•
Use the arrows on the keypad to highlight the START button and press ENTER to start
the pump in maintenance mode.
•
Use the arrows on the keypad to highlight the left or right arrow on the screen and
press ENTER to initiate.
The left arrow on the screen will extend the plunger to the left, allowing full exposure
to the left plunger when the unit is disassembled. The right arrow on the screen will
extend the plunger to the right, allowing full exposure to the right plunger when the
unit is disassembled.
•
Use the arrows on the keypad to highlight the STOP button and press ENTER to stop the
pump.
Maintenance Hours Screen
Use the arrows on the keypad to highlight the RESET button and press ENTER to reset the
maintenance hours.
Figure 4-15: Maintenance Hours Screen
20480289
2-2009/Rev 0
4-10
Section 4
Operation
Maintenance Strokes Screen
Use the arrows on the keypad to highlight the left or right RESET button and press ENTER to
reset the maintenance strokes.
Figure 4-16: Maintenance Strokes Screen
4.9
Alarms
When a fault condition occurs an alarm message appears over the screen and a small triangle
flashes in the corner of the screen. Pressing SHIFT and ESC will initiate the help function.
Additional information regarding the type of alarm and possible remedies will display.
Pressing ESC will clear the message, allowing you to navigate the screen, but it will not clear
the fault. To clear a fault, press the ▲ arrow on the keypad to highlight the flashing triangle
and press ENTER to display the alarm message. Press the ACK button to acknowledge the fault.
Table 4-2
Alarms
Alarm
Indication
Possible Remedies
Left Overstroke Shutdown
A left overstroke condition has
occurred.
Check left high pressure seal
Check right discharge check valve
Check left inlet check valve
Low Booster Pressure
Discharge pressure from the
booster pump is low, below 60
psi (4 bar).
Check the inlet water pressure
Check the filter element and
replace if dirty
Adjust or replace the booster pump
20480289
2-2009/Rev 0
Low Inlet Water Pressure
Inlet cutting water pressure is
low, below 30 psi (2 bar).
Check pipe sizing for inlet cutting
water for pressure and flow
Motor Feedback Failure
Start relay did not close at startup or opened due to a fault
Check motor starter relay
4-11
Section 4
Operation
Table 4-2
Alarms
Alarm
Indication
Possible Remedies
Motor Overload
PLC monitors the motor
overload relay and displays a
message when the overloads
trip. Overloads are set on
automatic reset.
Check incoming voltage
Check the motor amperage
Low oil level.
Check sight level gauge
Oil Level Low
Check overload setting
Check for hydraulic leaks
Check the oil level switch
Oil Temperature High
High oil temperature.
Check cooling water source
Check water modulating valve
Check the oil temperature switch
Right Overstroke
Shutdown
A right overstroke condition
has occurred.
Check right high pressure seal
Check left discharge check valve
Check right inlet check valve
T/W Overstroke Shutdown
An intensifier overstroke
condition has occurred.
Check plumbing for leaks
Check high pressure orifice
Check inlet water pressure
Check the inlet and discharge
check valves
Check the incoming water pressure
20480289
2-2009/Rev 0
4-12
SECTION 5
LOW PRESSURE WATER SYSTEM
5.1
Overview
The JetlineTM series utilizes two low pressure circuits: cutting water supply and cooling water
supply. This section will discuss the cutting water supply circuit. See Section 6,
Recirculation System, for a detailed explanation of the cooling water supply circuit.
The cutting water supply circuit supplies the intensifier with the required cutting water flow
and pressure. System components include the inlet water solenoid valve, strainer, booster
pump, and the low pressure filter assembly. Pressure switches, connected to the PLC,
monitor out of tolerance conditions in the cutting water circuit and provide automatic
shutdown protection.
Figure 5-1: Cutting Water Supply Circuit
20480293
2-2009/Rev 0
1 Cutting Water In
6
Relief Valve
11 60 psi Pressure Switch
2 Pressure Gauge
7
Booster Pump
12 Pressure Gauge
3 Inlet Water Solenoid Valve
8
Check Valve
13 Sealing Head
4 Strainer
9
Filter Assembly
14 Relief Valve
5 30 psi Pressure Switch
10 Air Bleed Valve
15 Drain
5-1
Section 5
Low Pressure Water System
5.2
Cutting Water Supply
The quality of the inlet cutting water supply is one of the most important factors affecting
component life and performance. Impurities in the water create grinding and corrosive effects
on all components. See Section 11, Specifications, for details regarding water quality
standards.
5.3
Operation
Cutting water is introduced through the 1/2-inch BSPT connection on the rear bulkhead of the
machine. Inlet cutting water pressure should be a minimum of 35 psi (2.4 bar) flowing, and
can be monitored from the supply gauge mounted on the inlet manifold.
Figure 5-2: Low Pressure Water System
20480293
2-2009/Rev 0
1 Filter Head
7
Filter Housing
13 30 psi Pressure Switch
2 60 psi Pressure Switch
8
Filter Element
14 Inlet Manifold
3 Outlet Manifold
9
In from Booster Pump
15 Relief Valve Acorn Nut
4 Pressure Gauge
10 Strainer
5 Out to Drain
11 Pressure Gauge
6 Out to Intensifier
12 Inlet Water Solenoid Valve
16 Booster Pump
5-2
Section 5
Low Pressure Water System
Cutting water enters through the normally closed, inlet water solenoid valve. When the
control power is turned on, the solenoid valve opens and allows water to flow through the
valve. The inlet water is monitored by a 30 psi pressure switch mounted on the inlet manifold.
If the pressure drops below 30 psi (2 bar) the switch activates an automatic shutdown circuit
in the PLC and the machine will not start.
NOTE
The machine will not start if inlet cutting water pressure is below 30 psi (2 bar).
If a shutdown occurs due to an overstroke condition, the inlet solenoid valve automatically
closes to prevent water waste due to an external leak.
Cutting water then passes through a strainer to remove debris before the water enters the
booster pump. The booster pump increases the pressure to the relief valve setting, up to a
maximum of 120 psi (8 bar) to ensure proper supply to the intensifier assembly.
Pressurized water passes through the filter assembly where debris is removed to prevent
contaminants from damaging the check valves and seals in the intensifier. The filter assembly
consists of a filter head, housing and a filter element. A bleed valve on the top of the filter
head is used to release pressure or air inside the housing.
As the water enters the outlet manifold, the pressure is monitored by a 60 psi pressure switch.
An automatic shutdown will occur if the pressure is below 60 psi (4 bar).
If the booster pump pressure exceeds 125 psi (8.6 bar) a relief valve opens allowing water to
exit through the 1/2-inch drain connection on the rear bulkhead. It is still possible to operate
the machine; however, excess water will continue to be released through the drain.
Discharge pressure is displayed on the pressure gauge mounted on the outlet manifold. The
gauge should read approximately 120 psi (8 bar) while the machine is idling. When it strokes,
the pressure drop should be no greater than 30 psi (2 bar). The water pressure range should
remain between 90-120 psi (6-8 bar) during operation.
NOTE
While the intensifier assembly reverses direction, the boosted pressure will
fluctuate slightly above and below the normal setting.
A relief valve built into the filter assembly prevents excessive discharge pressure and
typically operates when the machine is in a deadhead condition. The booster pump is factory
set to deliver 120 psi (8 bar) with an inlet pressure of 58 psi (4 bar). The pump may require
adjustment to satisfy system requirements. To reduce overheating during a deadhead
condition, water is re-circulated through the orifice and check valve, and routed back through
the strainer to the booster pump inlet.
From the outlet manifold, cutting water is routed to the inlet check valves in the sealing heads
on each end of the intensifier.
20480293
2-2009/Rev 0
5-3
Section 5
Low Pressure Water System
5.4
Service and Maintenance Procedures
To ensure water quality and supply to the high pressure system, the filter element, strainer and
booster pump will require routine servicing and maintenance. The procedures for servicing
these components are detailed below.
NOTE
Refer to Section 12, Parts List for a complete listing of replacement parts and part
numbers.
Filter Assembly and Strainer Maintenance
The life of the filter element is directly related to the quality of the inlet water. The condition
of the filter element can be monitored by observing the pressure gauge on the outlet manifold.
Document the pressure reading when the filter element is new. The element should be
replaced when the pressure drops to 15 psi (1 bar) below the original value. When the filter
element is replaced, the strainer should also be cleaned.
The following procedure is used to replace the filter element and clean the strainer.
Figure 5-3: Filter Element
1 Bleed Valve
3 Filter Element
2 Filter Head
4 Filter Housing
1. Turn the cutting water supply off.
2. Press the red bleed valve on the filter head to release any pressure trapped inside the
housing.
3. Use a filter wrench to unscrew the housing and remove the old element.
4. Install the new element. Apply FML-2 grease to the o-ring in the filter housing and
use the filter wrench to replace the housing.
20480293
2-2009/Rev 0
5-4
Section 5
Low Pressure Water System
Figure 5-4: Strainer
1 Plug
5. Unscrew and remove the strainer plug and seal ring. Remove and clean the mesh liner.
6. Install the liner. Ensure the seal ring is properly positioned; replace the plug and
hand-tighten.
7. Turn the cutting water supply on.
8. Press the red bleed valve to remove any air inside the filter housing.
9. Start the machine and verify satisfactory pressure readings.
Booster Pump Adjustment
If the discharge pressure from the booster pump stays below 90 psi (6 bar) while the
intensifier is shifting, the relief valve on the booster pump should be adjusted.
Figure 5-5: Booster Pump
1 Booster Pump
2 Relief Valve Acorn Nut
1. Turn the cutting water supply on.
2. Start the machine and initiate normal, shifting operation.
3. Observe the discharge pressure from the booster pump. If the pressure stays below 90
psi (6 bar), continue with Step 4.
4. Stop the intensifier and remove the acorn nut on the side of the pump to access the
adjustment screw. It is normal for water to leak out when the acorn nut is removed.
5. Use a flat screwdriver and turn the adjustment screw clockwise to increase the
discharge pressure or counter-clockwise to decrease the pressure. Adjust the pressure
to the highest desired pressure, within normal booster pump range.
20480293
2-2009/Rev 0
5-5
Section 5
Low Pressure Water System
CAUTION
If the adjustment screw is turned too far out (counter-clockwise) an internal spring
and relief will fall down inside the pump. If this occurs, the pump must be
removed and the parts must be reinstalled to avoid component damage.
6. Replace the acorn nut, resume normal operation and observe the booster discharge
pressure. Peak pressure should be in the range of 90 to 120 psi (6 to 8 bar). If it is not,
repeat the adjustment procedure.
20480293
2-2009/Rev 0
5-6
SECTION 6
RECIRCULATION SYSTEM
6.1
Overview
The oil recirculation circuit is a cooling and filtration system that provides properly
conditioned oil to the main hydraulic system. Hydraulic oil is maintained at the proper
operating temperature and condition by continuous recirculation.
System components include the water modulating valve, recirculation pump, heat exchanger,
oil filter assembly and the hydraulic oil reservoir. A temperature/low level switch, connected
to the PLC, monitors temperature and oil level conditions in the hydraulic oil reservoir and
provides automatic shutdown protection.
Figure 6-1: Oil Recirculation Circuit
1 Cooling Water Out
4
Water Modulating Valve
7
Pressure Gauge
2 Recirculation Pump
5
Oil Filter Assembly
8
Heat Exchanger
3 Hydraulic Oil Reservoir
6
Bypass Relief Valve
9
Cooling Water In
20480302
8-2010/Rev 01
6-1
Section 6
Recirculation System
6.2
Operation
Cooling water is introduced through the 1/2-inch BSPT connection on the rear bulkhead of
the machine. A water modulating valve in the outlet line regulates the cooling flow through
the heat exchanger. The valve is factory set, but may require adjustment to maintain the
operating oil temperature at 115° F (46° C). Oil temperature can be visually monitored from
a dual scale level/temperature sight gauge on the side of the hydraulic oil reservoir.
Figure 6-2: Recirculation System Components
1 Hydraulic Oil Reservoir
7
Oil Fill Port
2 Air Breather
8
Filter Element
3 Temperature/Low Level Switch
9
Water Modulating Valve
4 Level/Temperature Sight Gauge
10 Heat Exchanger
5 Filter Head
11 Recirculation Pump
6 Pressure Gauge
12 Case Drain
The recirculation pump pulls oil from the reservoir and sends it to the heat exchanger. The
oil-to-water heat exchanger controls heat build-up in the hydraulic oil. The plate style design
allows cooling water and oil to flow side by side through alternating plates.
The cooled oil then passes through the filter element and returns to the reservoir. The cooling
water either is discharged to the drain on the rear bulkhead or is routed to a customer supplied
water chiller.
20480302
8-2010/Rev 01
6-2
Section 6
Recirculation System
The hydraulic oil filter assembly consists of the filter head with bypass relief valve, pressure
gauge; filter element and the oil fill port. The filter element should be changed when the
gauge reads 40 psi (2.8 bar) at normal operating temperature.
If the element is not replaced, and fills with debris, the bypass relief in the filter head will
open to prevent over pressurization. The relief valve opens at 50 psi (3.4 bar). When the
valve opens, the oil bypasses the filter and unfiltered oil is allowed to return to the reservoir.
The temperature/low level switch monitors the oil temperature and level in the reservoir. An
automatic shutdown will occur if the operating oil temperature exceeds 145° F (63° C). An
automatic shutdown will also occur if the oil level falls below 30 gal (114 L).
NOTE
To conserve water usage it is recommended that the cooling water be shut off at
the end of the day. A sensor bulb from the modulating valve is submerged in the
reservoir. Even when the control power is off, the valve will remain open,
allowing water to flow until the oil is cooled.
6.3
Service and Maintenance Procedures
To ensure the supply of properly conditioned oil to the main hydraulic system, the
components will require routine servicing and maintenance. The procedures for servicing
these components are detailed below.
NOTE
Refer to Section 12, Parts List for a complete listing of replacement parts and part
numbers.
Hydraulic Oil Maintenance
The hydraulic oil should be replaced after 3,000 hours or one year of service, whichever
comes first. The oil should be replaced sooner if a fluid sample indicates contamination that
cannot be rectified by filtering.
An air breather and filter are located on the top of the reservoir. The air breather prevents dirt
from being sucked into the reservoir when the oil level drops, and allows air to escape when
the level rises. The air breather must not be used as a fill point. Oil must only be replaced at
the fill port on the filter head.
CAUTION
Do not attempt to fill the reservoir from the air breather. The oil will not be
filtered and will not conform to the cleanliness requirements of the system.
20480302
8-2010/Rev 01
6-3
Section 6
Recirculation System
Figure 6-3: Hydraulic Reservoir
1 Breather
3 Drain
2 Oil Fill Port
Before proceeding, disconnect and lockout the main power supply and the electrical enclosure;
and ensure that all high pressure water and hydraulic pressure has been bled from the system.
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before performing maintenance.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before performing maintenance.
1. Drain the oil reservoir by connecting the inlet hose from an oil transfer pump to the
drain valve on the reservoir.
2. Open the shut off valve on the drain and pump the used oil out to a container.
3. Close the shut off valve and remove the inlet hose from the drain valve.
NOTE
Oil from a new drum does not meet the cleanliness requirements of the hydraulic
system. For this reason, it is important to use an oil transfer pump that will force
oil through the return filter into the reservoir.
4. Remove the cap from the fill port on the oil filter.
20480302
8-2010/Rev 01
6-4
Section 6
Recirculation System
CAUTION
To ensure cleanliness, the oil fill port must be used to pump oil into the reservoir.
Filling at this point guarantees the hydraulic oil will pass through the oil filter
before entering the reservoir.
5. Connect the discharge hose from the oil transfer pump to the fill port and pump the
fresh oil into the reservoir.
NOTE
If 3/4-inch BSPP threads are required, install the adapter located on the inside of
the frame. When filling is complete, remove the adapter and install the fill port
cap.
6. Check the oil sight gauge on the reservoir to ensure proper fill level.
7. Remove the hose from the case drain on the main hydraulic pump to make sure the
pump case fills with oil. With the hose removed, head pressure from the reservoir will
force oil into the pump case.
CAUTION
Oil in the pump case provides internal lubrication for the main hydraulic pump.
Failure to the fill the pump case with oil will allow air to become trapped inside,
damaging the pump.
8. Disconnect the discharge hose from the fill port and replace the fill port cap.
9. Follow the initial start up sequence in Section 4, Operation, to ensure the system is
filled with oil.
10. Check the sight gauge again and follow the same procedure to add additional oil if
necessary.
Electric Motor Bump
Bumping is defined as allowing the electric motor to start rotating, but stopping it before the
motor gets up to full speed.
Whenever the hydraulic reservoir is emptied or the hydraulic pump has been changed,
bumping the electric motor is suggested. This procedure will ensure the hydraulic pump is
full of oil and deter cavitation which will cause the hydraulic pump to fail prematurely.
Do not perform this procedure until the correct motor rotation and the presence of hydraulic
oil in the hydraulic pump case drain line has been confirmed.
1. Start the pump in recirculation mode, count two seconds and turn the pump off.
20480302
8-2010/Rev 01
6-5
Section 6
Recirculation System
2. Repeat this process six times before allowing the hydraulic pump to create pressure.
Oil Filter Maintenance
If the filter element is not properly serviced and fills with debris, the oil will be forced
through the relief valve, bypassing the filter. The bypass relief valve opens at 50 psi (3.4 bar).
The filter element must be replaced when the pressure gauge reading is 40 psi (2.8 bar) or
greater during normal operating conditions. Normal operating conditions indicate the
machine is running and the oil temperature has reached 115° F (46° C).
Figure 6-4: Oil Filter Assembly
1 Filter Head
2 Filter Element
1. Use a filter wrench to unscrew the filter element from the filter head. Make sure the
old gasket is removed with the element.
2. Lubricate the gasket on the new element with fresh oil.
3. Use the filter wrench to screw the new element onto the filter head and hand-tighten.
Do not over tighten.
4. Start the machine and check for leaks.
NOTE
If the pressure gauge reads 40 psi (2.8 bar) or greater, check the operating
condition of the gauge or indicator. These components may require replacement.
Operating Temperature Adjustment
The cooling water flow through the heat exchanger is regulated by the water modulating
valve, a manually adjusted, thermostatic control valve. The valve is factory set to maintain
the operating oil temperature at 115° F (46° C). It is adjusted by increasing or decreasing the
spring tension on the valve.
20480302
8-2010/Rev 01
6-6
Section 6
Recirculation System
NOTE
In most cases, adjustment will be required during commissioning and with
seasonal changes to the cooling water temperature.
Figure 6-5: Water Modulating Valve
5. Locate the adjusting knob, a screwdriver slot on the top of the valve.
6. Use a flat screwdriver and turn counter-clockwise to compress the spring, slowing
water flow and increasing temperature. Or; turn clockwise to reduce spring tension,
increasing water flow and decreasing the temperature.
7. Monitor the sight gauge on the side of the reservoir until the adjusted temperature can
be determined. It will take some time for the temperature in the oil reservoir to change.
8. Repeat steps 2 and 3 if necessary.
20480302
8-2010/Rev 01
6-7
SECTION 7
HYDRAULIC SYSTEM
7.1
Overview
The main hydraulic power circuit supplies the intensifier assembly with the hydraulic oil
required to produce high pressure water. High pressure cutting water is generated from the oil
pressure in the hydraulic cylinder.
System components include the electric motor, hydraulic pump, 4-way directional control
valve and the hydraulic manifold. The manifold houses the high and low pressure control
valves, hydraulic gauge, two pressure solenoid valve and the main system relief valve. The
system relief valve monitors hydraulic oil pressure and provides system protection by limiting
excess pressure.
Figure 7-1: Main Hydraulic Power Circuit
20480306
2-2009/Rev 0
1 Hydraulic Pump
5
Solenoid Valve
9
Pressure Gauge
2 Electric Motor
6
Low Pressure Control
10 Intensifier
3 Hydraulic Manifold
7
High Pressure Control
4 System Relief Valve
8
Directional Control Valve
7-1
Section 7
Hydraulic System
7.2
Operation
The electric motor drives three pumps mounted in tandem; the main hydraulic pump, the
recirculation pump and the booster pump. The motor drives the variable displacement,
pressure compensated hydraulic pump by means of a flexible coupling.
Hydraulic fluid from the reservoir is drawn into the inlet, low pressure side of the hydraulic
pump. Oil delivered to the pump should be maintained at 110-115° F (43-46° C). Hydraulic
fluid then enters the bottom of the manifold through an internal anti-rotation check valve.
After a shutdown, the anti-rotation check valve prevents the pump from running backwards.
Figure 7-2: Hydraulic System Components
1 High/Low Limit Compensators
6 Low Pressure Control
2 Hydraulic Pump
7 High Pressure Control
3 Electric Motor
8 Directional Control Valve
4 Pressure Gauge
9 Relief Valve
5 High/Low Solenoid Valve
20480306
2-2009/Rev 0
7-2
Section 7
Hydraulic System
The main system relief valve provides system protection by monitoring the oil pressure
entering the manifold. If the hydraulic pressure exceeds 3,408 psi (235 bar), the valve opens
to limit the pressure. The valve is factory calibrated and is not serviceable. A drain line from
the valve prevents oil from collecting behind the relief valve to ensure a constant pressure
under all operating conditions.
The hydraulic system operates at high or low pressure settings up to the maximum flow
capacity of the hydraulic pump. The high and low limit compensators mounted on the pump
regulate the flow of hydraulic fluid to maintain constant operating pressures. Operating
pressures are set and adjusted at the high and low pressure control valves on the manifold.
CAUTION
The high and low limit compensators regulate the flow of hydraulic fluid to the
system by controlling the angle of the swashplate. If the oil is not properly
maintained, the compensators can become blocked with debris. As a result, pump
control will be lost and you will not be able to create hydraulic oil pressure.
The normally closed, two pressure solenoid valve is controlled by the operator’s selection of
high or low pressure. The valve is closed while operating in high pressure and is open during
low pressure operation. A light on the solenoid connector indicates low pressure operation.
A reference gauge on the top of the manifold displays hydraulic pressure to the intensifier.
When the intensifier shifts, it is normal for the pressure to quickly fall and then rise again.
The 4-way directional control valve directs pressurized oil to one end the hydraulic cylinder
and returns fluid to the reservoir from the opposite end, causing the intensifier to stroke. The
movement is controlled hydraulically by a pilot valve that is electronically operated by two
solenoids, energized by the PLC. Indicators light up as each solenoid is energized.
The directional control valve sends flow to the hydraulic cylinder in one direction until the
hydraulic piston activates the proximity switch at the end of the stroke. The activated switch
sends a signal to the PLC to reverse the direction of flow. The piston then moves in the
opposite direction until it activates the proximity switch at the opposite end of the stroke.
7.3
Service and Maintenance Procedures
The extreme duty cycles demanded of the hydraulic system make routine inspection and
maintenance acutely important. Leaks must be detected and remedied as soon as possible.
The operating pressure settings must be checked daily, and the electric motor must be
inspected at regular intervals. It is also possible for the flexible coupling to fail and require
replacement.
NOTE
Refer to Section 12, Parts List for a complete listing of replacement parts and part
numbers.
20480306
2-2009/Rev 0
7-3
Section 7
Hydraulic System
Hydraulic Operating Pressure
Hydraulic operating pressure settings should be checked daily and adjusted as necessary.
High and low operating pressure is adjusted at the high and low pressure control valves per
the specifications in Table 7-1.
Table 7-1
Hydraulic Operating Pressure Limits
Adjustment
Pressure Limits
Increase
Decrease
Minimum
Maximum
High Pressure
Clockwise
Counter-clockwise
290 psi (20 bar)
3,000 psi (207 bar)
Low Pressure
Clockwise
Counter-clockwise
290 psi (20 bar)
800 psi (55 bar)
Figure 7-3: High/Low Pressure Controls
1 High Pressure Control
2 Low Pressure Control
1. Check the operating pressure to determine if adjustment is necessary.
2. If high pressure adjustment is required, loosen the locking thumbscrew on the high
pressure control valve by turning counter-clockwise.
3. Turn the knob on the control valve clockwise to increase operating pressure. Turn the
knob counter-clockwise to decrease pressure.
4. Tighten the locking nut and verify the high pressure setting.
5. If low pressure adjustment is required, loosen the locking nut on the low pressure
control valve by turning counter-clockwise.
6. Turn the hex clockwise to increase operating pressure. Turn the hex counterclockwise to decrease pressure.
7. Tighten the locking nut and verify the low pressure setting.
20480306
2-2009/Rev 0
7-4
Section 7
Hydraulic System
Motor Maintenance
The motor should be inspected at regular intervals, approximately every 500 hours of
operation or every three months, whichever occurs first. Keep the motor clean and the
ventilation openings clear.
Hydraulic Compensator Maintenance
The high and low limit compensators regulate the flow of hydraulic fluid to the system. The
compensators can become blocked with debris resulting in loss of pump control.
Figure 7-4: Hydraulic Compensator Components
1
3
2
5
4
1 Spool
3
Springs
5
Plug Nut
2 Spring Cup
4
Spring Collar
6
Sealing Cap
6
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before performing maintenance on the
system components.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before performing maintenance.
1. Remove the hydraulic hose from the low limit compensator.
2. Remove the four socket screws that attach the compensators to the pump.
3. Remove the compensators and then remove the three plugs and o-rings on the back of
the housing.
20480306
2-2009/Rev 0
7-5
Section 7
Hydraulic System
4
1
5
2
3
6
1 O-Ring
3
O-Ring
5
Low Limit Compensator
2 Orifice
4
Plug
6
High Limit Compensator
4. Disassemble the compensators one at a time by first removing the hexagon sealing cap.
5. Loosen the lock nut, and then remove the plug nut.
6. Disassemble the plug by removing the spring collar, springs, spring cup and spool.
7. Clean the housing and all components with clean fluid and carefully dry with air.
8. Check and clean the small internal passages in the spools.
9. Check and clean the orifices in both spools.
10. Assemble in the reverse order, ensuring that the screw slot on the orifice is aligned
with the long axis of the body.
CAUTION
When the compensators are removed, the machine loses adjustment. The
compensators must be reset before operation can begin.
11. Start the machine and select the low pressure operating mode on the display panel.
12. Deadhead the machine.
20480306
2-2009/Rev 0
7-6
Section 7
Hydraulic System
1 Low Pressure Control
4 Low Limit Compensator
2 High Pressure Control
5 High Limit Compensator
3 Hydraulic Pressure Gauge
13. Set the high and low pressure control valves on the hydraulic manifold to the
minimum setting by turning then counter-clockwise.
14. Set the compensators to the minimum setting by turning the adjusting screws counterclockwise.
15. Select high pressure operating mode on the display panel and set the high pressure
control valve on the hydraulic manifold to the maximum setting by turning the knob
clockwise.
16. Turn the adjusting screw on the high limit compensator clockwise until the hydraulic
reference gauge reads 3,000 psi (207 bar).
17. Select low pressure operating mode on the display panel and turn the adjusting screw
on the low limit compensator clockwise until the reference gauge reads 290 psi (20
bar). Lock the adjustment screw in place.
18. Select high pressure operating mode on the display panel and turn the knob on the
high pressure control valve counter-clockwise until the reference gauge reads 2,000
psi (138 bar).
19. Open the high pressure water control valve, allowing water to flow. Set the desired
high operating pressure by adjusting the high pressure control valve.
20. While the machine is running and high pressure water is flowing, select low pressure
operating mode. Set the desired low operating pressure by adjusting the low pressure
control valve.
20480306
2-2009/Rev 0
7-7
SECTION 8
ELECTRICAL SYSTEM
8.1
Overview
The JetlineTM series is equipped with integral motor starter and control circuitry, enclosed in
the electrical panel. The operator controls the machine primarily through a function-button
control panel that communicates with the programmable logic controller (PLC). A series of
sensors provide automatic shutdown logic and diagnostics.
Major system components include the electric motor, control panel, high voltage and control
components, and the wiring harness that connects the sensors and solenoid valves to the PLC.
8.2
Operation
Electrical power from the utility grid enters the main circuit breaker/disconnect on the
electrical enclosure door as 3-phase alternating current. The power is then distributed in two
directions. The 3-phase AC, at the voltage provided from the grid, is routed to the motor
starter contactor(s) and then to the main motor. Single phase AC is routed to the transformer.
The transformer converts the incoming voltage to 230 volt AC that is routed to both the motor
starter contactor(s) and to the power supply. The power supply then provides 24 volt direct
current to the control circuits, including the emergency stop logic, the PLC and the display
panel.
20480310
2-2009/Rev 0
8-1
Section 8
Electrical System
Figure 8-1: Electrical Control Power
1 Line
7
230V AC
12 Display Panel
2 Customer Supplied
8
Power Supply
13 Motor Control Relay
3 Line Voltage (3-Phase Line Power)
9
24V DC
14 Contactor Coil (230V AC)
4 Wall Disconnect
10 E-Stop
15 Motor Starter Contactor
5 Circuit Breaker/Disconnect
11 PLC
16 Motor
6 Transformer
The motor starter contactors are solenoid operated by 230 volt AC control power. The
contactors are arranged in a wye-delta starter circuit. Wye-delta starter circuits are typically
installed in all low voltage machines that require high current draw. Three, 3-phase
contactors are used to start the motor slowly, minimizing the initial current draw.
20480310
2-2009/Rev 0
8-2
Section 8
Electrical System
Figure 8-2: Wye-Delta Configuration
1 Three, 3-Phase Contactors
The circuit breaker/door disconnect provides the primary over current protection for the
machine. All power is automatically disconnected from the machine when the main
disconnect on the enclosure door is opened. However, power is still present on the input side
of the circuit breaker/door disconnect. The only way to isolate all power to the machine is to
turn the customer installed main power disconnect off.
Figure 8-3: Electrical Enclosure Door
1 Circuit Breaker/Disconnect
20480310
2-2009/Rev 0
8-3
Section 8
Electrical System
NOTE
See Section 2, Installation, regarding specifications for the customer installed main
power disconnect.
Sensors and Solenoids
Warning and shutdown sensors monitor operating conditions, and electronically operated
solenoids provide basic intensifier shift control. The harness cable connects these sensors and
solenoids to the PLC.
Figure 8-4: Sensors and Solenoids
20480310
2-2009/Rev 0
1 Oil Level/Temperature
Switch
5
4-Way Valve ‘A’ Solenoid
9
Inlet Water Pressure
Switch
2 Dump Valve
6
4-Way Valve ‘B’ Solenoid
10 Water Inlet Valve
3 Left Proximity Switch
7
2-Pressure Solenoid
4 Right Proximity Switch
8
Booster Outlet Pressure
Switch
8-4
Section 8
Electrical System
Table 8-1
Sensors and Solenoids
Component
Function
Inlet Water Solenoid Valve
1
The normally closed, inlet water solenoid valve is
located at the service bulkhead. When the control
power is turned on, the valve opens and allows
low pressure cutting water to enter. The solenoid
valve functions as a safeguard by closing if an
overstroke condition occurs.
2
The temperature/low level switch monitors the oil
temperature and level in the reservoir. Although
the float switch and the temperature switch are
combined in a single unit, the two switches
function independently.
Hydraulic Reservoir
If the operating oil temperature exceeds 145° F
(63° C) an automatic shutdown occurs. If the
hydraulic fluid level falls below specifications, a
low oil level shutdown occurs.
Hydraulic Manifold
20480310
2-2009/Rev 0
3
The 4-way directional control valve shifts the
hydraulics back and forth to the intensifier. A
shift valve directs pressurized oil to one end of
the hydraulic cylinder and returns fluid to the
reservoir from the opposite end, causing the
intensifier to stroke. The movement is controlled
electronically by two solenoids, signaled by the
PLC. As power is directed from one solenoid to
the other, LEDs are alternately illuminated.
4
When low pressure is selected, a normally closed,
solenoid valve is activated. The valve remains
closed while operating in high pressure and is
held open electrically during low pressure
operation. An illuminated LED on the solenoid
indicates low pressure operation.
8-5
Section 8
Electrical System
Table 8-1
Sensors and Solenoids
Component
Function
Hydraulic Cylinder
5
As pressurized hydraulic oil is sent to one side of
the hydraulic cylinder, it pushes against the
piston, moving it in one direction until it activates
the proximity switch at the end of the stroke. The
hydraulic flow is then sent to the opposite side of
the cylinder, and the piston reverses direction
until it activates the proximity switch at the
opposite end of the stroke.
The green light on the proximity switch indicates
there is power to the switch. The light turns red
when the switch is activated. The proximity
switches are magnetically activated by the
presence of the metallic surface of the piston.
When the switch is activated, it sends a signal to
the PLC to change the flow of the directional
control valve and reverse direction.
High Pressure Safety Dump Valve
6
The safety dump valve releases the stored
pressure in the intensifier and high pressure
delivery lines. The high pressure dump valve
assembly includes a normally open high pressure
water valve and a solenoid operated air valve.
The normally open pneumatic dump valve is held
closed by air pressure. When the air supply is
interrupted from an emergency stop or a normal
stop, the valve opens and allows water to flow
through the valve. Pressure is released in the
intensifier and the high pressure water stream
exits through the drain.
20480310
2-2009/Rev 0
8-6
Section 8
Electrical System
Table 8-1
Sensors and Solenoids
Component
Function
Low Pressure Water Filter Assembly
20480310
2-2009/Rev 0
7
To ensure adequate water pressure and supply to
the intensifiers, the discharge pressure is
monitored by a 60 psi pressure switch. An
automatic shutdown occurs if the pressure is
below 60 psi (4 bar).
8
The 30 psi pressure switch, mounted on the inlet
manifold, monitors the inlet cutting water. If the
pressure drops below 30 psi (2 bar) the switch
activates an automatic shutdown circuit,
protecting the booster pump from damage due to
insufficient water supply pressure.
8-7
Section 8
Electrical System
8.3
Service and Maintenance Procedures
Electrical components require minimal service. The proximity switches on the hydraulic
cylinder may require replacement.
NOTE
Refer to Section 12, Parts List for a complete listing of replacement parts and part
numbers.
Proximity Switch Maintenance
A proximity switch has failed and needs to be replaced if the LEDs do not change state,
indicating they are not sensing the piston, if an LED flashes continuously, or if the
appropriate input is not noted on the PLC processor annunciator light panel in the electrical
enclosure.
Figure 8-5: Proximity Switch
1 Proximity Switch
2
O-Ring Spacer
1. Turn the machine off and observe the appropriate Lockout/Tagout procedures.
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before performing maintenance on the
system components.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before performing maintenance.
2. Remove the electrical cable from the failed proximity switch.
3. Remove the two socket head screws, the failed switch and the o-ring spacer.
20480310
2-2009/Rev 0
8-8
Section 8
Electrical System
4. Install a new proximity switch by positioning the o-ring spacer and the switch. Ensure
the o-rings are correctly oriented.
5. Apply JL-M grease to the threads on the screws and tighten to 140-160 in-lbs (16-18
Nm).
CAUTION
Ensure that the proximity switch is properly installed and secured prior to starting
the machine. Failure to tighten the two hold down screws on each switch will
result in the spray of hydraulic oil.
20480310
2-2009/Rev 0
8-9
SECTION 9
HIGH PRESSURE WATER SYSTEM
9.1
Overview
The high pressure water system is supported by both the cutting water supply circuit and the
hydraulic circuit. Cutting water of sufficient flow and pressure is routed from the cutting
water supply circuit to the intensifier where it is pressurized up to 55,000 psi (3,792 bar) and
delivered to the cutting head.
The directional control valve in the hydraulic system creates the stroking action of the
intensifier by sending pressurized hydraulic oil to one side of the hydraulic cylinder or the
other. As the flow is sent to one side, hydraulic fluid is returned to the reservoir from the
opposite side.
Figure 9-1: High Pressure Water System Circuit
1 Cutting Water In
6
Hydraulic Cylinder
11 Drain
2 Inlet Check Valve
7
Hydraulic Piston
12 Air In
3 Sealing Head
8
Discharge Check Valve
13 Cutting Water Out
4 Soft Seal End Cap
9
Attenuator
5 High Pressure Cylinder
10 Safety Dump Valve
System components include a double-ended hydraulic cylinder; reciprocating piston assembly;
high pressure cylinders attached to each end of the hydraulic cylinder; two plungers, sealing
heads and soft seal end caps; a one liter capacity attenuator, and a safety dump valve.
Sophisticated check valves and seal assemblies ensure hydraulic oil, and the low pressure and
high pressure water travel in the appropriate direction. Warning and shutdown sensors
monitor system temperature and fluid levels to safeguard against component damage.
20480314
7-2011/Rev 02
9-1
Section 9
High Pressure Water System
9.2
Operation
The directional control valve sends pressurized hydraulic oil to one side of the hydraulic
cylinder. The pressurized oil pushes against the piston, moving it in one direction until it
activates the proximity switch at the end of the stroke. The hydraulic flow is then sent to the
opposite side of the cylinder, and the piston reverses direction until it activates the proximity
switch at the opposite end of the stroke.
Figure 9-2: High Pressure Water System
1 Soft Seal End Cap
5
High Pressure Cylinder
2 Hydraulic Cylinder Head
6
Safety Dump Valve
3 Hydraulic Cylinder
7
Attenuator
4 Proximity Switch
The green light on the proximity switch indicates there is power to the switch. The red light
illuminates when the switch is activated. The proximity switches are magnetically activated
by the presence of the metallic surface of the piston. When the switch is activated, it sends a
signal to the PLC to change the flow of the directional control valve and reverse direction.
As the pressurized oil pushes the piston in one direction, the plunger on that end extends and
pushes against the water in the high pressure cylinder, increasing the pressure up to 55,000 psi
(3,792 bar). When the piston reverses direction, the plunger retracts and the plunger in the
opposite cylinder extends to deliver the high pressure water.
Low pressure water is routed through the inlet water ports to the inlet passages in the sealing
heads. When the plunger retracts, the inlet check valve opens to allow water to fill the high
pressure cylinder. When the plunger extends to create high pressure water, the inlet valve
closes to seal the inlet passage and the discharge check valve opens to allow the high pressure
water to exit the cylinder. As the plunger retracts, the discharge check valve closes.
20480314
7-2011/Rev 02
9-2
Section 9
High Pressure Water System
Figure 9-3: High Pressure Cylinder
1 Discharge Check Valve
5
Hydraulic Piston
9
High Pressure Cylinder
2 Sealing Head
6
Retracted Plunger
10 Inlet Water Passage
3 Inlet Check Valve
7
Hydraulic Cylinder
11 Inlet Water Port
4 Extended Plunger
8
Hydraulic Oil In
12 Outlet Water Passage
The intensifier is a reciprocating pump. As the piston and plungers move from one side to the
other, high pressure water exits one side of the intensifier as low pressure water fills the
opposite side.
The high pressure water is then routed to the attenuator. The attenuator acts as a shock
absorber to dampen pressure fluctuations and ensure a steady and consistent supply of water.
From the attenuator, the high pressure water exits to the cutting head.
The safety dump valve releases the stored pressure in the intensifier and high pressure
delivery lines. The high pressure dump valve assembly includes a normally open high
pressure water valve and an electrically controlled air valve.
The normally open pneumatic dump valve is held closed by air pressure. When the air supply
is interrupted and exhausted from an emergency stop or a normal stop, the valve opens and
allows water to flow through the valve. Pressure is released in the intensifier and the high
pressure water stream exits through the drain.
20480314
7-2011/Rev 02
9-3
Section 9
High Pressure Water System
9.3
System Components
The following figures illustrate the individual high pressure water system components.
Figure 9-4: High Pressure Cylinder Assembly
1 O-Ring
5
Sealing Head Seal Assembly
2 Sealing Head Collar
6
Cylinder Liner
3 Soft Seal End Cap
7
High Pressure Cylinder
4 Sealing Head
8
High Pressure Seal Assembly
20480314
7-2011/Rev 02
9-4
Section 9
High Pressure Water System
Figure 9-5: Hydraulic Cylinder Assembly
1 Retaining Ring
6
Backup Ring
2 Bushing Retainer Flange
7
O-Ring
3 Hydraulic Seal Cartridge
8
Hydraulic Cylinder
4 Socket Head Screw
9
O-Ring Spacer
5 Hydraulic Cylinder Head
10 Proximity Switch
Figure 9-6: Hydraulic Piston
1 Plunger
3
High Pressure Cylinder Assembly
2 Hydraulic Piston Assembly
20480314
7-2011/Rev 02
9-5
Section 9
High Pressure Water System
9.4
Service and Maintenance Overview
Never perform any type of maintenance on the high pressure water system while it is
pressurized. Always turn the power off and bleed the high pressure water before servicing.
Pressing the emergency stop button turns the control power off to the intensifier, and bleeds
high pressure water through the dump valve.
Improper assembly can lead to the premature failure of components. Maintenance procedures
must be followed carefully; components must be properly cleaned prior to assembly and
tightened to the correct torque specifications.
Some high pressure components are not serviceable at the customer level, others require
precise refinishing. KMT Waterjet Systems offers maintenance and refinishing services for
these components.
NOTE
Refer to Section 12, Parts List for a complete listing of replacement parts and part
numbers.
20480314
7-2011/Rev 02
9-6
Section 9
High Pressure Water System
Torque Specifications
Table 9-1, Torque Specifications, details the torque specifications and tightening sequences
for the high pressure components and connections.
Table 9-1
Torque Specifications
High Pressure Water System
Hydraulic Cylinder Head
Socket Head Screws
Torque
Hex Key
8 (M14) each
75-80 ft-lbs (102-108 Nm)
M12
Proximity Switch
Socket Head Screws
Torque
Hex Key
2 (M6) each
140-160 in-lbs (16-18 Nm)
M5
Sealing Head
Discharge Gland Nut
Poppet Retainer
130 ft-lbs (176 Nm)
25-30 in-lbs (2.8-3.4 Nm)
Pneumatic Control Valve
HP Adapter
25 ft-lbs (34 Nm)
1/4-inch Outlet to Drain
25 ft-lbs (34 Nm)
Pneumatic Actuator
3/8-inch HP Gland Nut
5 ft-lbs (7 Nm)
50 ft-lbs (68 Nm)
High Pressure Fittings
1/4” HP Gland Nut
25 ft-lbs (34 Nm)
3/8” HP Gland Nut
50 ft-lbs (68 Nm)
9/16” HP Gland Nut
110 ft-lbs (149 Nm)
20480314
7-2011/Rev 02
9-7
Section 9
High Pressure Water System
Specialized Maintenance Tools
KMT Waterjet has designed tools to facilitate the removal and installation of specialized
system components. These tools are illustrated in Figure 9-7, Specialized Maintenance Tools,
and part numbers are provided in Table 9-2.
Figure 9-7: Specialized Maintenance Tools
Table 9-2
Specialized Maintenance Tools
High Pressure Water System
Part Number
20480314
7-2011/Rev 02
1
Cartridge Removal Tool
72113886
2
Seal Removal Tool
10148674
3
Cylinder Wrench
05066139
4
Vee Block Cradle
20494488
9-8
Section 9
High Pressure Water System
9.5
High and Low Pressure Water Piping
Before performing any maintenance on the high pressure components, it is necessary to
remove the high and low pressure water piping. The following procedure should be used to
remove and install the piping.
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before performing maintenance on the high
pressure system components.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before performing maintenance.
1. Turn the cutting water supply off.
2. Loosen and remove the high pressure gland fitting connected to the discharge high
pressure check valve. Move the tubing to clear the work area.
3. Loosen and remove the low pressure piping connected to the inlet water port on the
sealing head collar.
4. When the required maintenance has been completed and the components reassembled,
connect the low pressure water piping to the inlet water port on the sealing head collar.
5. Apply Pure Goop to the threads on the high pressure gland fitting. Before installing
the high pressure fitting, ensure proper collar position, 1-1/2 to 2-1/2 threads should be
exposed. Install and tighten the fitting to the torque specifications in Table 9-1.
6. Turn the cutting water supply on and check for low pressure leaks.
7. Remove the cutting orifice and start the machine. Operate in low pressure mode to
flush the high pressure passages.
8. Install the orifice and operate at high pressure to check for leaks.
9.6
High Pressure Cylinder Assembly
The high pressure cylinder assembly must be disassembled to service the inlet check valves,
sealing head seal assembly, plunger, high pressure seals, hydraulic piston and hydraulic seal
cartridge. Disassembly is not required when servicing the discharge check valves.
20480314
7-2011/Rev 02
9-9
Section 9
High Pressure Water System
High Pressure Cylinder Assembly Removal
Prior to removing electrical power or any high or low pressure piping, bring the hydraulic
piston in the left or right stop position to facilitate maintenance. The plunger will extend in
the selected direction, allowing full exposure when the unit is disassembled. Refer to Section
4, Operation.
1. Turn the machine off and observe the appropriate Lockout/Tagout procedures.
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before proceeding.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before proceeding.
2. Disconnect the high and low pressure water piping, following the procedure, High and
Low Pressure Water Piping.
3. Gently pry the sealing head collar off of the sealing head.
Figure 9-8: High Pressure Cylinder Assembly Removal
1 Sealing Head Collar
5
Sealing Head Seal Assembly
2 Soft Seal End Cap
6
Cylinder Liner
3 Inlet Water Groove
7
High Pressure Cylinder
4 Sealing Head
8
Hydraulic Cylinder Head
4. Position a pin spanner wrench on the soft seal end cap to turn counter-clockwise.
Position a cylinder wrench on the high pressure cylinder to turn clockwise. Break the
end loose. It may be necessary to tap the spanner wrench with a plastic hammer.
5. Unscrew the end cap until it is flush with the inlet water groove on the sealing head.
With a screwdriver in the groove, supported by the end cap, gently pry the sealing
head out as far as possible. Repeat this process until the sealing head is loose from the
high pressure cylinder.
20480314
7-2011/Rev 02
9-10
Section 9
High Pressure Water System
6. Unscrew and remove the end cap and sealing head from the cylinder.
7. Use the seal removal tool to remove the sealing head seal components from the
cylinder.
To service the high pressure seals, plunger, hydraulic piston or hydraulic seal cartridge
continue with Step 8.
8. Remove the cylinder liner.
9. Position the vee block cradle under the high pressure cylinder to support the weight.
Unthread and remove the cylinder from the hydraulic cylinder head and plunger. The
cylinder can be rotated with the cylinder wrench or by hand.
CAUTION
Due to the weight of the high pressure cylinder, adequate support must be provided
to prevent damage to the plunger or seals during removal and installation.
NOTE
If thread or metal surface galling is detected during cylinder removal, galled
surfaces and threads must be filed, sanded and lubricated prior to reassembly. See
the procedure, High Pressure Cylinder Maintenance.
High Pressure Cylinder Assembly Installation
1. Verify that the high pressure cylinder threads and alignment surfaces are adequately
cleaned and lubricated with Pure Goop, and that the threads have been sanded and
dressed if galling was encountered during removal.
2. Verify that the high pressure seal assembly is correctly installed. While supporting the
weight with the vee block cradle, align the cylinder with the plunger and the hydraulic
cylinder head. Carefully push the cylinder into position until the threads are ready to
engage.
3. Thread the cylinder into the hydraulic cylinder head. The cylinder will become
difficult to rotate as it slides over the high pressure seal assembly. Use the cylinder
wrench as necessary.
NOTE
If galling occurs during threading, remove the high pressure cylinder and inspect
the mating surfaces and threads. Repair surfaces, thoroughly clean, lubricate and
thread the cylinder into the hydraulic cylinder head.
4. Hand-tighten the cylinder with the cylinder wrench. Tap the wrench with the palm of
your hand to tighten.
20480314
7-2011/Rev 02
9-11
Section 9
High Pressure Water System
5. Clean and install the cylinder liner.
6. Lightly coat the sealing head seal components with FML-2 grease and slide the seal
assembly onto the inlet end of the sealing head.
7. Lightly coat the outboard bore of the high pressure cylinder with FML-2 grease.
8. Clean and lubricate the cylinder threads with Pure Goop.
9. Apply Pure Goop to the sealing surface of the sealing head. Position the sealing head
in the end cap. Hold the sealing head securely against the end cap and thread the end
cap onto the cylinder.
If the sealing head begins to resist turning as the end cap threads onto the cylinder, tap
the outboard end of the sealing head with a plastic hammer until the sealing head seats
against the end of the cylinder.
CAUTION
Avoid hitting the end of the sealing head against the cylinder to prevent damage to
the inlet check valve, seals and sealing surfaces.
Avoid rotating the sealing head relative to the cylinder to avoid premature seal
leakage.
10. Turn the end cap until it bottoms out. Tighten the end cap with the spanner wrench
and finish with a single, light tap on the wrench handle. Do not tighten further.
11. Lubricate the o-rings on the sealing head collar with FML-2 grease and install the
collar.
12. Connect the high and low pressure water piping, following the procedure, High and
Low Pressure Water Piping.
13. Start the machine in low pressure mode to flush air from the high pressure components
and to check for obvious leaks. After 5-10 strokes, switch to high pressure operation
and check for leaks.
If leaks are detected, turn the machine off and remedy the problem. When the
problem has been remedied, repeat the start up procedure, moving from low to high
pressure soon after the intensifier starts pumping water. There is no further need to
flush air from the system.
High Pressure Cylinder Maintenance
The plunger seal area in the high pressure cylinder bore should be inspected and cleaned each
time the high pressure seal assembly is replaced.
1. Clean the sealing area on the inside diameter of the high pressure cylinder and inspect
the bore for rings, scratches, pits, residue or other potential leak paths.
20480314
7-2011/Rev 02
9-12
Section 9
High Pressure Water System
Seal material or residue can build up, forming a ring. Running a fingernail across the
buildup will cause it to appear as a surface flaw. Grooves or ridges are typically seal
debris buildup rather than marks on the inside diameter wall of the cylinder.
2. Polish the inside diameter of the cylinder where the seals will locate with 600-grit
wet/dry sandpaper. Hold the sandpaper on the end of your finger and move in a
cylindrical wiping motion. Polish in a circumferential motion only. Do not polish or
drag the sandpaper along the length of the cylinder.
3. Clean the residue from the inside diameter of the cylinder and re-inspect for surface
defects.
9.7
Sealing Head
The sealing head is sealed to the outboard end of the high pressure cylinder by the sealing
head seal assembly. The inlet and discharge check valves in the sealing head ensure the low
pressure and high pressure water only travels in the appropriate direction.
Figure 9-9: Sealing Head
1 Sealing Head
4
Inlet Check Valve
2 Soft Seal End Cap
5
Discharge Check Valve
3 High Pressure Cylinder
6
Inlet Water Groove
High Pressure Discharge Check Valve
The high pressure discharge check valves require service when water leakage is present at the
sealing head weep hole or when the sealing head and discharge gland are warm to the touch.
The discharge check valve can be serviced with the sealing head either installed or removed
from the high pressure cylinder.
1. Turn the machine off and observe the appropriate Lockout/Tagout procedures.
20480314
7-2011/Rev 02
9-13
Section 9
High Pressure Water System
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before proceeding.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before proceeding.
2. Disconnect the high pressure water piping, following the procedure, High and Low
Pressure Water Piping.
3. Use two wrenches to remove the gland nut. The poppet pin, spring and poppet check
valve will normally remain in the gland nut when it is removed. Remove the
components from the gland nut.
4. Use a magnet to remove the seat from the sealing head.
5. Inspect the poppet pin for wear and replace the pin if worn.
6. Inspect both faces of the seat for damage or cracking. A cracked or damaged seat
must be replaced. The seat can be installed with either face toward the poppet valve.
If one face is worn, but the opposite is not, the seat can be reversed, placing the new
surface toward the poppet valve. A slight burr at the hole edge identifies the used side
of the seat. If both faces are worn, the seat must be replaced.
NOTE
The seat, spring and poppet valve should be replaced as a set. If one component
requires replacement, replace all components.
Figure 9-10: High Pressure Discharge Check Valve
1 Gland Nut
4
Discharge Poppet Check Valve
2 Poppet Pin
5
Seat
3 Compression Spring
7. Apply a thin film of Pure Goop to the face of the seat opposite the poppet check valve
and install the seat into the sealing head. If the existing seat is reused, install the seat
with the new surface facing the poppet valve.
8. Install the poppet pin, spring and poppet valve into the gland nut.
20480314
7-2011/Rev 02
9-14
Section 9
High Pressure Water System
9. Apply Pure Goop to the sealing face and the threads on the gland nut and thread the
gland nut into the sealing head. Hand-tighten until there is a 0.20 inch (5 mm) gap
between the gland nut and the sealing head. No threads should show. If the gap
exceeds 0.20 inch (5 mm), the poppet or seat has slipped out of position. The parts
must be removed, inspected and re-assembled.
10. Use a crowfoot/torque wrench combination and tighten the gland nut to the torque
specifications in Table 9-1.
Low Pressure Inlet Check Valve
The need for inlet check valve service is indicated by unbalanced shifting or if the inlet ring is
warm to the touch. The high pressure cylinder assembly components must be disassembled to
service the inlet check valve. Follow the procedure, High Pressure Cylinder Assembly
Removal. When the components have been removed, proceed with Step 1 below.
Figure 9-11: Low Pressure Inlet Check Valve
1 Poppet Retainer
3
Inlet Poppet Check Valve
2 Compression Spring
1. Use a 1/2-inch flat blade screwdriver to remove the poppet retainer from the sealing
head.
2. Inspect the sealing head for scratches or wear on the sealing head seal contact surface,
and on the inlet poppet valve contact surface. If defects are detected, the surfaces
must be refinished. See the procedure, Sealing Head Maintenance.
3. Inspect both faces on the inlet poppet valve. The poppet valve can be installed with
either face toward the sealing head. If one face is worn, but the opposite is not, the
poppet can be reversed, placing the best surface toward the sealing head. If both faces
are worn, the poppet valve must be replaced.
4. Spray Loctite 7649 on the threads of the poppet retainer and allow to dry. Assemble
the spring and the inlet poppet valve on the poppet retainer. Apply a small amount of
Loctite 242 to the poppet retainer threads only. Do not get any Loctite on the poppet
or any other surfaces on the inlet check valve.
5. Use the flat blade screwdriver to tighten the poppet retainer. Tighten the poppet
retainer to the torque specifications in Table 9-1.
6. Inspect the assembled unit to ensure the poppet moves freely, the spring is fully
guided on the poppet retainer, the spring end is 90 degrees from the screwdriver slot
on the retainer and the poppet retainer is seated against the sealing head.
20480314
7-2011/Rev 02
9-15
Section 9
High Pressure Water System
Sealing Head Seal Assembly
Whenever maintenance requires the sealing head to be removed, the sealing head seal
assembly must be replaced.
1. Prior to installing a new seal assembly, inspect and clean the seal surfaces on the
sealing head and the high pressure cylinder bore. Inspect and clean the cylinder liner.
2. Install the cylinder liner.
3. Lightly coat the seal components with FML-2 grease and slide the seal assembly onto
the inlet end of the sealing head as illustrated. The wedge ring chamfer must be
installed against the chamfered shoulder of the sealing head and the o-ring must face
the inlet check valve.
Figure 9-12: Sealing Head Seal Assembly
1 Sealing Head Seal Assembly
3
Wedge Ring
2 Inlet Check Valve
4
Seal w/O-Ring
Sealing Head Maintenance
The sealing head should be inspected for scratches, excessive sealing damage or erosion
marking on the sealing head seal contact surface, and on the inlet poppet valve contact surface.
The inlet water groove should be inspected for cracking. If defects are detected, the surfaces
must be refinished. The sealing head can be returned to KMT Waterjet for refinishing.
1. Inspect the inlet poppet valve sealing surface for pits, scratches or jetting erosion. If
necessary, refinish the surface.
Place a piece of 1/4-1/2” thick plate glass, not window glass, on a sturdy table to
provide an absolutely flat surface. Place a piece of 400-grit wet/dry sandpaper on the
glass. Use even, deliberate strokes, rotating the sealing head approximately 10-15
degrees after each stroke. Polish the sealing head until it is flat and smooth. Be
careful not to cause additional damage by tilting or tipping the part while polishing.
2. When the sealing head is flat and smooth, perform a final polish with 600-grit wet/dry
sandpaper.
20480314
7-2011/Rev 02
9-16
Section 9
High Pressure Water System
9.8
High Pressure Seal Assembly
The following procedure should be used to replace the high pressure seal assembly.
Figure 9-13: High Pressure Seal Assembly
1 U-Body Seal
Seal Orientation
2 J5 Hyper Seal
6
Plunger
3 O-Ring
7
Piston
4 Backup Ring
8
Sealing Head
5 Packing Follower
9
Red Surfaces
Prior to removing electrical power or any high or low pressure piping, bring the hydraulic
piston in the left or right stop position to facilitate maintenance. The plunger will extend in
the selected direction, allowing full exposure when the unit is disassembled. Refer to Section
4, Operation.
1. Turn the machine off and observe the appropriate Lockout/Tagout procedures.
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before proceeding.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before proceeding.
2. Disconnect the high and low pressure water piping, following the procedure, High and
Low Pressure Water Piping.
20480314
7-2011/Rev 02
9-17
Section 9
High Pressure Water System
3. Remove the high pressure cylinder assembly components, following the procedure,
High Pressure Cylinder Assembly Removal.
4. Remove the high pressure seal assembly from the cylinder by inserting the seal
removal tool into the cylinder and pushing the seal assembly out. Use caution to avoid
scratching the cylinder bore.
Figure 9-14: High Pressure Seal Removal
1 Seal Removal Tool
3
2 High Pressure Cylinder
4
Cylinder Liner
High Pressure Seal Assembly
5. Remove the cylinder liner from the bore and inspect for possible heat or wear damage,
or for debris. If cracks or brittleness are detected on the tabs on the ends of the liner,
the liner must be replaced.
6. Feel approximately one inch into the cylinder bore for obvious ridges or grooves. If
seal debris is present, follow the procedure, High Pressure Cylinder Maintenance.
7. Inspect the plunger surface for flaws. Rotate the plunger 360 degrees by hand while
viewing light reflection on the surface to detect any dullness, streaks, pits or other
defects. Run a fingernail perpendicular to the direction of the suspected flaws to
determine the severity of defects. Depending on the seal life achieved with the
removed seal assembly, make a judgment regarding plunger and/or cylinder
replacement. If seal debris is present on the plunger, polish with 600-grit wet/dry
sandpaper, using a radial motion.
8. Lightly coat the new seal components with FML-2 grease and install the new
components on the plunger. Ensure the proper orientation of the backup rings as
illustrated in Figure 9-13, High Pressure Seal Assembly.
9. Slide the cylinder liner over the plunger.
10. Install the high pressure cylinder into the hydraulic cylinder head, following the
procedure, High Pressure Cylinder Assembly Installation.
11. Reconnect the high and low pressure water piping and turn the low pressure water
supply on.
20480314
7-2011/Rev 02
9-18
Section 9
High Pressure Water System
9.9
Hydraulic Seal Cartridge Replacement
The following procedure is used to remove and replace the hydraulic seal cartridge.
Prior to removing electrical power or any high or low pressure piping, bring the hydraulic
piston in the left or right stop position to facilitate maintenance. The plunger will extend in
the selected direction, allowing full exposure when the unit is disassembled. Refer to Section
4, Operation.
1. Turn the machine off and observe the appropriate Lockout/Tagout procedures.
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before proceeding.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before proceeding.
2. Disconnect the high and low pressure water piping, following the procedure, High and
Low Pressure Water Piping.
3. Remove the proximity switch on the end of the hydraulic cylinder to be serviced. This
will allow the hydraulic oil to drain back to the reservoir, minimizing oil spillage. It
will take approximately five minutes for the oil to drain.
4. Remove the high pressure cylinder assembly components, following the procedure,
High Pressure Cylinder Assembly Removal.
5. Use a flat screwdriver to remove the retaining ring from the hydraulic cylinder head.
6. Remove the bushing retainer flange and clean the surfaces, weep holes and grooves.
Check the retainer flange for cracks.
7. Replace the proximity switch by positioning the o-ring spacer and the switch. Apply
JL-M grease to the threads on the socket head screws and tighten, following the torque
specifications in Table 9-1.
CAUTION
It is recommended that the proximity switch be reinstalled as soon as practical.
Removal of the switch presents the potential of an oil spray hazard.
Ensure that the proximity switch is properly installed and secured prior to starting
the machine. Failure to tighten the two hold down screws on each switch will
result in the spray of hydraulic oil.
8. Thread the large end of the cartridge removal tool onto the hydraulic cartridge seal and
pull the cartridge out, over the plunger.
20480314
7-2011/Rev 02
9-19
Section 9
High Pressure Water System
Figure 9-15: Hydraulic Seal Cartridge Removal
1 Plunger
5
Retaining Ring
2 Bushing Retainer Flange
6
Hydraulic Cylinder
3 Hydraulic Cylinder Head
7
Hydraulic Seal Cartridge
4 Cartridge Removal Tool
Hydraulic Seal Cartridge
Seals in the hydraulic cartridge can be removed and replaced, or the complete cartridge can be
replaced.
Use caution during the removal and installation of the seal components to avoid scratching
the surface of the cartridge. The seal removal tool, a plastic or wooden dowel, or similar
object can be used for seal removal. Do not use screwdrivers, wires or other metal objects
that could damage the cartridge. To avoid damaging the new seals, the seal installation tool
can be used for installation.
20480314
7-2011/Rev 02
9-20
Section 9
High Pressure Water System
Figure 9-16: Hydraulic Seal Cartridge
1 Seal Bushing
5
Packing Ring w/O-Ring
2 O-Ring
6
O-Ring
3 Backup Ring
7
Backup Ring
4 O-Ring
8
U-Cup Packing Seal
1. Carefully remove the worn seals and o-rings from the cartridge by pushing them with
a plastic or wooden dowel, or similar object. Remove the seals closest to the open
ends first, and work toward the center.
2. Inspect the seals for unusual wear, deformation or cuts. Note any unusual buildup of
solid material or debris creating possible leak paths.
3. Inspect the surface of the cartridge body for scratches, deformation, signs of metal-tometal contact or other unusual wear. Carefully examine the surface of the grooves on
the inside diameter. Note any scratches in the axial direction that could create a leak
path.
4. Apply FML-2 grease to the inside and outside diameter of the cartridge body, and to
the individual seal components.
5. Install the seals, starting in the center and working toward the ends. See Figure 9-16
for the proper orientation of the u-cup packing seal. If available, use the seal
installation tool to install the u-cup packing seal. See Figure 9-23, Pneumatic Valve
Seal Tools.
6. Verify that the u-cup o-ring is properly positioned after installation.
7. When the seal components are properly installed, apply FML-2 grease to the exposed
surfaces of the seals and slide the hydraulic cartridge seal over the plunger, into the
cavity of the hydraulic cylinder head.
20480314
7-2011/Rev 02
9-21
Section 9
High Pressure Water System
8. Thoroughly clean the bushing retainer flange, including the cross-drilled weep holes.
Install the retainer flange over the plunger.
9. Install the retaining ring, ensuring the retaining ring fully seats inside the groove in the
hydraulic cylinder head.
The o-rings on the hydraulic cartridge will take up clearance. Tap lightly on the
bushing retainer flange with the cartridge removal tool to compress the o-rings enough
to start the retaining ring in the groove. Use a flat blade screwdriver to push on the
outer edge of the retainer flange while working one end of the retaining ring into the
groove. The retainer flange should tilt or tip enough to allow the retaining ring to
move into the groove. Continue working the ring into the groove while tilting the
retainer flange until the ring is fully seated.
10. Install the high pressure cylinder into the hydraulic cylinder head, following the
procedure, High Pressure Cylinder Assembly Installation.
11. Connect the high and low pressure water piping and turn the low pressure water
supply on.
20480314
7-2011/Rev 02
9-22
Section 9
High Pressure Water System
9.10
Hydraulic Piston and Plungers
Two bearing rings provide wear contact between the piston and the inside diameter of the
hydraulic cylinder. On each end of the piston, a plunger retainer and retaining ring hold the
plungers in position.
Figure 9-17: Hydraulic Piston Components
1 Piston Seal Assembly
5
Plunger
2 Bearing Ring
6
Retaining Ring
3 Ram Piston
7
Backup Ring
4 Plunger Retainer
8
O-Ring
Hydraulic Piston and Plunger Removal
The following procedure is used to remove the hydraulic piston and plungers. It is necessary
to remove the components from both ends of the intensifier.
Prior to removing electrical power or any high or low pressure piping, bring the hydraulic
piston in the left or right stop position to facilitate maintenance. The plunger will extend in
the selected direction, allowing full exposure when the unit is disassembled. Refer to Section
4, Operation.
1. Turn the machine off and observe the appropriate Lockout/Tagout procedures.
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lockout/Tagout procedures before proceeding.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before proceeding.
20480314
7-2011/Rev 02
9-23
Section 9
High Pressure Water System
2. Disconnect the high and low pressure water piping from both ends of the intensifier,
following the procedure, High and Low Pressure Water Piping.
3. Remove the high pressure cylinder assembly components on each end of the
intensifier, following the procedure, High Pressure Cylinder Assembly Removal.
Figure 9-18: Hydraulic Piston Removal
1 O-Ring
5
Hydraulic Seal Cartridge
9
Hydraulic Piston
2 Backup Ring
6
Bushing Retainer Flange
10 Hydraulic Cylinder
3 Hydraulic Cylinder Head
7
Retaining Ring
11 Proximity Switch
4 Socket Head Screw
8
Plunger
12 O-Ring Spacer
4. Remove both of the proximity switches to prevent interference and to allow the
hydraulic oil to drain back to the reservoir, minimizing oil spillage. It will take
approximately five minutes for the oil to drain.
5. Remove the retaining rings, bushing retainer flanges and the hydraulic cartridge seals.
6. Loosen and remove the socket head screws in the hydraulic cylinder heads.
7. Remove the hydraulic cylinder heads with the o-rings and backup rings. The
mounting flat for the proximity switch provides a small lip for loosening the cylinder
head.
8. Grasp the plunger firmly and pull the piston out of the hydraulic cylinder.
9. Place the piston in a vice and remove the retaining ring on each end of the piston.
20480314
7-2011/Rev 02
9-24
Section 9
High Pressure Water System
10. Pull each plunger to remove it from the piston. The plunger retainer will remain with
the plunger when it is removed.
11. Remove the o-ring and the backup ring from each side of the piston.
Bearing Rings and Seal Assembly
1. Use a smooth, dull-edged blade made from brass or similar soft metal material to
remove the two bearing rings and the two-piece seal assembly.
NOTE
Do not scratch the surfaces of the piston seal groove. Scratches on the sides or
bottom of the groove can result in hydraulic leaks.
2. Inspect the bottom of the seal grooves for marks, scratches and residue buildup. Clean
and/or repair the groove surfaces as required.
3. Apply FML-2 grease to the new bearing rings and install the rings.
4. The piston seal assembly consists of a seal ring and an o-ring. Apply FML-2 grease to
both rings. Use the smooth, dull-edged blade to install the o-ring, ensuring the ring is
not twisted after installation. Slide the outer seal ring over the metal edges and ease it
into position over the inner, o-ring.
Figure 9-19: Hydraulic Piston
1 Bearing Ring
3
Inner O-Ring
2 Outer Seal Ring
Plunger Maintenance
Plunger surfaces can become streaked with longitudinal scratches or flaws, and discolored or
dull in appearance. If any of these conditions become severe, the high pressure seal assembly
and possibly the hydraulic cartridge seal will leak.
20480314
7-2011/Rev 02
9-25
Section 9
High Pressure Water System
Accumulation of debris on the surface of the plunger can be removed by polishing in a radial
direction with 600-grit sandpaper. However, plunger surface flaws usually cannot be repaired
on site. The plunger can be returned to KMT Waterjet for reconditioning.
Figure 9-20: Plunger
1 Plunger
3
Button Chamfer
2 Plunger Button
Hydraulic Piston and Plunger Installation
1. Apply FML-2 grease to the new o-ring and backup rings. Install the backup ring and
then the o-ring in the groove in the plunger socket.
2. Slide the plunger retainer onto the piston and push the plunger onto the plunger socket.
3. Make sure the retainer is properly positioned in the socket.
4. Install the retaining ring into the cavity of the plunger socket.
Figure 9-21: Hydraulic Piston Installation
1 Hydraulic Piston
4
Plunger
2 Backup Ring
5
Plunger Retainer
3 O-Ring
6
Retaining Ring
5. Repeat steps 1-3 to install the second plunger.
6. Ensure that the hydraulic cylinder bore is free of grit or contamination.
20480314
7-2011/Rev 02
9-26
Section 9
High Pressure Water System
7. Lubricate the bearing rings and seal assembly, and lightly lubricate 2-3 inches of the
cylinder bore with FML-2 grease.
8. Install the piston and plungers into the hydraulic cylinder bore.
9. Verify that the o-rings and backup rings are properly positioned in the grooves on the
hydraulic cylinder heads, and that they are sufficiently lubricated with FML-2 grease.
10. Position the cylinder heads in the end of the hydraulic cylinder. Apply JL-M grease to
the threads on the socket head screws. Install the screws in the hydraulic cylinder
heads and tighten, following the torque specifications in Table 9-1.
11. Verify that the plunger moves freely when handled. If it feels tight, there may be
residue buildup in the pocket or the pocket depth may be insufficient.
12. Replace the hydraulic cartridge seals, bushing retainer flanges and retaining rings in
the hydraulic cylinder heads.
13. Replace the proximity switches by positioning the o-ring spacers and the switches.
Apply JL-M grease to the threads on the socket head screws and tighten, following the
torque specifications in Table 9-1.
CAUTION
Ensure that the proximity switches are properly installed and secured prior to
starting the motor. Failure to tighten the two hold down screws on each switch
will result in the spray of hydraulic oil.
14. Install the high pressure cylinders into the hydraulic cylinder heads and install the
remaining cylinder assembly components, following the procedure, High Pressure
Cylinder Assembly Installation.
15. Connect the high and low pressure water piping. And turn the low pressure water
supply on.
9.11
Hydraulic Cylinder Maintenance
The inside diameter surface of the hydraulic cylinder should be inspected for wear grooves
and surface finish whenever the hydraulic cylinder heads are removed. Excessive grooving is
indicative of piston seal wear.
9.12
High Pressure Attenuator
The high pressure attenuator is not serviceable at the customer level. KMT Waterjet Systems
tests the seals in the attenuator at pressures exceeding normal operating pressure, making
disassembly difficult. If the attenuator develops a high pressure water leak, it should be
replaced.
20480314
7-2011/Rev 02
9-27
Section 9
High Pressure Water System
9.13
High Pressure Dump Valve
The high pressure dump valve assembly includes a normally open high pressure water valve
and a solenoid operated pneumatic actuator. The following procedure is recommended for
servicing the high pressure dump valve. Failure to follow this procedure will cause damage
to the stem, valve seat, or both.
WARNING
The high pressure dump valve is a safety device designed to instantly release high
pressure from the system. Proper maintenance is imperative to prevent potential
personal injury.
Figure 9-22, Pneumatic Valve Seal Tools, illustrates the special tools recommended for this
procedure.
Figure 9-22: Pneumatic Valve Seal Tools
1 Seal Tool Kit (20470475)
4
Seal Positioning Tool (05067350)
2 Seal Installation Tool (20470417)
NO/NC Pneumatic Valves
3 Seal Push Tool (20470413)
2-Port Pneumatic Dump Valves
5
Seal Positioning Tool (49833114)
Quick Release Valves
3-Port Pneumatic Dump Valves
Pneumatic Control Dump Valve
For reliable operation the valve seat, seal assembly, brass backup ring and stem shall
always be replaced at the same time. The SST backup ring can be reused.
Before proceeding, disconnect and lockout the main power supply and the electrical enclosure;
and ensure that all high pressure water and hydraulic pressure has been bled from the system.
20480314
7-2011/Rev 02
9-28
Section 9
High Pressure Water System
WARNING
Severe injury can result if the machine is not properly locked out. Observe
electrical Lock Out/Tag Out procedures before proceeding.
Ensure all pressure is relieved or blocked from the hydraulic and high pressure
circuits before proceeding.
1. Turn the air supply off.
2. Remove the air supply hose, and the electrical connection to the solenoid valve.
Figure 9-23: High Pressure Dump Valve
1 Pneumatic Actuator
5
Signal from PLC
2 HP Water Out to Cutting Head
6
Solenoid Valve
3 Out to Drain
7
Control Air In
4 Valve Assembly
3. Loosen and remove the high pressure gland connections and the drain connection.
4. Remove the valve and actuator assembly from the machine.
20480314
7-2011/Rev 02
9-29
Section 9
High Pressure Water System
Figure 9-24: Dump Valve Components
1 Pneumatic Actuator
5
Seal Assembly
2 Stem
6
Valve Body
3 SST Backup Ring
7
Valve Seat
4 Brass Backup Ring
8
High Pressure Adapter
5. Loosen the cylinder head on the actuator. Unscrew and remove the actuator from the
valve body.
6. Unscrew the high pressure adapter and remove the adapter and valve seat.
7. Remove the stem, SST backup ring and brass backup ring from the valve body.
8. Remove the seal assembly by pushing it with the seal push tool (P/N 20470413). The
assembly must be pushed out through the actuator port in the top of the valve
body.
9. Discard the stem, brass backup ring, seal assembly and valve seat.
10. Clean and inspect the valve body, being careful not to damage or scratch the bore.
20480314
7-2011/Rev 02
9-30
Section 9
High Pressure Water System
Figure 9-25: Valve Seal Installation
1 Pneumatic Actuator
6
Seal Positioning Tool
2 Seal Push Tool
7
High Pressure Adapter
3 Seal Assembly
8
O-Ring
4 Seal Installation Tool
9
Seal
5 Valve Body
10 Bronze Wedge Ring
11. Place the seal positioning tool into the opposite end of the valve body as shown in
Figure 9-25, Valve Seal Installation. Thread the high pressure adapter into the valve
body until light contact is made with the positioning tool. Tighten finger-tight only.
12. Apply Pure Goop anti-seize compound to the threads on the seal installation tool.
Screw the seal installation tool into the threads of the valve body. Tighten fingertight only. See Figure 9-25, Valve Seal Installation.
13. Lubricate the new seal and o-ring with FML-2 food grade grease. Insert the seal, oring and bronze wedge ring into the seal installation tool, inserting the o-ring end of
the seal first so the tapered end of the seal (wedge ring end) faces the actuator. The
tapered end of the seal must face the actuator. See Figure 9-25, Valve Seal Installation.
14. Use the seal push tool to push the seal assembly into the bore of the valve body until
the seal makes light contact with the seal positioning tool.
15. Remove the push tool and the installation tool from the valve body.
16. Install the existing SST backup ring and a new brass backup ring on a new stem. The
vee groove on the SST backup ring must face toward the brass backup ring. The small
OD of the brass backup ring must face toward the seal assembly. See Figure 9-24,
Dump Valve Components.
17. Apply FML-2 grease to the tip of the stem and insert the stem with the backup rings
into the top of the valve body so the stem enters the ID of the seal assembly. Insert
the stem until the chamfer on the stem is seated against the SST backup ring. See
Figure 9-26, Valve Stem Placement.
20480314
7-2011/Rev 02
9-31
Section 9
High Pressure Water System
CAUTION
Do not push the o-ring on the seal assembly past the inlet port on the valve body.
This will damage the seal o-ring.
Figure 9-26: Valve Stem Placement
1 SST Backup Ring
4
Seal O-Ring
2 Inlet Port
5
Stem Chamfer
3 Seal Positioning Tool
18. Remove the high pressure adapter and the seal positioning tool.
19. Apply Pure Goop anti-seize compound to the threads of the actuator and carefully
thread it into the valve body, guiding the stem head into the hole in the actuator. Turn
the actuator clockwise until resistance is felt. Reverse the actuator 1/4-turn, and give
it a quick spin clockwise to seat it. Hand-tighten only, 5 ft-lbs (7 Nm).
20. Apply Pure Goop anti-seize compound to all surfaces, except the ID, of a new valve
seat. Install the seat into the valve body, inserting the small OD first.
21. Apply anti-seize compound to the threads on the high pressure adapter. Install the
adapter and torque to 25 ft-lbs (34 Nm).
22. Replace the 1/4-inch drain gland nut and collar and torque to 25 ft-lbs (34 Nm).
23. Apply anti-seize compound to the threads on the 3/8-inch high pressure gland fittings.
Install the collar and the gland fittings and torque to 50 ft-lbs (68 Nm).
24. Install the air supply hose and the electrical connection to the solenoid valve. Turn the
air pressure to the actuator on and test the valve for leaks and proper operation.
20480314
7-2011/Rev 02
9-32
Section 9
High Pressure Water System
Pneumatic Actuator
The following procedure is used to service the pneumatic actuator.
Figure 9-27: Pneumatic Actuator
1 Cylinder Head
7
Cylinder Head
2 O-Ring
8
O-Ring
3 O-Ring
9
O-Ring
4 Piston
10 Pneumatic Cylinder
5 Pneumatic Cylinder
11 Piston
6 Control Air
1. Unscrew and remove the cylinder head using a strap wrench and a pin spanner.
Remove the piston from the cylinder.
CAUTION
Do not install the pneumatic cylinder in a vise to remove the cylinder head. This
may distort the body and seize the piston, preventing proper operation.
2. Remove the o-ring on the cylinder head. Apply FML-2 grease to a new o-ring and
install.
3. Remove the two o-rings on the piston. Apply FML-2 grease to two new o-rings and
install.
4. Install the piston in the pneumatic cylinder. Apply anti-seize compound to the threads
on the cylinder head and screw it into the pneumatic cylinder.
20480314
7-2011/Rev 02
9-33
Section 9
High Pressure Water System
9.14
Weep Holes
High pressure seals and connections fail gradually and begin leaking slowly. Weep holes are
located at every threaded high pressure connection to provide a vent for internal leaks. Water
or oil dripping from a weep hole indicates one or more internal components are beginning to
fail.
Table 9-3 lists the location of the weep hole, the possible source of the leak and the corrective
action required.
Table 9-3
Weep Holes
High Pressure Water System
Location
Indication
Comments
Hydraulic oil leaking from the
weep hole in the hydraulic
cylinder head
Failed hydraulic cartridge seal
Replace the cartridge seal. If
the leak persists, check the
plunger for linear scratches or
scoring.
Water leaking from the weep
hole on the hydraulic cylinder
head flange
Failed high pressure seal
assembly
Replace the high pressure seal
assembly.
Damaged plunger
Check the plunger for
longitudinal scratches or flaws.
If detected, replace the plunger
or return to KMT for
evaluation.
Seal material buildup on plunger
Polish the plunger surface
following the procedure,
Plunger Maintenance.
Damaged high pressure cylinder
Check for scratches, grooves
or material buildup on the
inside diameter of the cylinder.
If detected, polish the bore
following the procedure, High
Pressure Cylinder
Maintenance.
Hydraulic Cylinder Head
Check the inside diameter of
the cylinder for expansion
where the high pressure seal
assembly is located. If
detected, replace the cylinder.
20480314
7-2011/Rev 02
9-34
Section 9
High Pressure Water System
Table 9-3
Weep Holes
High Pressure Water System
Location
Indication
Comments
Seat in the discharge check valve
is not sealing properly
Make sure the gland nut is
tightened to the proper torque
specification.
Sealing Head
Water leaking from the weep
hole in the sealing head
Inspect the seat, sealing head
and gland nut for cracks.
Internal crack in sealing head
Replace the sealing head.
A cracked sealing head can
result in water leaking from
the high pressure outlet
passage to the low pressure
inlet passages.
The sealing head body can
become extremely hot.
Water leaking from the weep
hole in the gland nut
Improper torque on gland nut
Tighten the gland nut to the
proper torque specification.
Erosion or scratches on the
contact surface of the sealing
head, or on the gland nut where
the seat makes contact
Polish the surfaces following
the procedure, Sealing Head
Maintenance.
High pressure piping gland nut is
not tight and is not sealing
properly
Tighten the gland nut to the
proper torque specification.
Improper high pressure piping
connection
Check the number of exposed
threads past the collar on the
high pressure piping. Only 11/2 to 2-1/2 threads should be
exposed.
Check high pressure piping for
damage, cracks or
deformation.
Inspect the gland nut for
deformation of the threads.
Damaged sealing head gland nut
20480314
7-2011/Rev 02
Check the gland nut for cracks
due to fatigue. If cracks are
detected, replace the gland nut.
9-35
Section 9
High Pressure Water System
Table 9-3
Weep Holes
High Pressure Water System
Location
Indication
Comments
Damaged high pressure cylinder
Check for scratches or grooves
on the sealing surface. If
detected, polish to remove
following the procedure, High
Pressure Cylinder
Maintenance.
External crack in sealing head
Replace the sealing head.
Damaged sealing head
Check for scratches or grooves
on the sealing surface of the
sealing head. If detected,
polish the surface following
the procedure, Sealing Head
Maintenance.
Worn sealing head seal assembly
Replace seal assembly.
Soft Seal End Cap
Water leaking from the weep
holes in the soft seal end cap
20480314
7-2011/Rev 02
9-36
SECTION 10
TROUBLESHOOTING
10.1
Overview
The troubleshooting guide will help identify the probable cause of a system malfunction and
assist in providing corrective action. The following symptoms are discussed in this section:
10.2
1.
High oil temperature resulting in shutdown
2.
Low oil level resulting in shutdown
3.
Hydraulic pressure but no high pressure water pressure
4.
No hydraulic oil pressure
5.
Pump will not start
6.
Console display and lights do not illuminate
7.
Pump quits running
8.
No control power
9.
Red light on operator’s console is flashing
10.
Abnormal fluctuations in high pressure water signal
11.
Hot surfaces on the high pressure cylinder components
12.
Low cutting water supply pressure
13.
Low cutting water pressure
14.
Hydraulic oil leaking from the weep hole in the hydraulic cylinder head
15.
Water leaking from the weep hole on the hydraulic cylinder head flange
16.
Water leaking from the weep hole in the sealing head
17.
Water leaking from the weep hole in the sealing head gland nut
18.
Water leaking from the weep holes in the hard seal end cap
19.
Outlet booster pump pressure is falling below 60 psi (4 bar)
20.
Inlet water flow is poor and the filter housing is not filling completely
21.
Water is leaking around the bleed valve on the filter head
Troubleshooting Guide
Listen to the machine and observe it in operation. Learn to recognize the normal sounds and
operating conditions of the system. Carefully define the symptom of the problem. Locate the
symptom on the troubleshooting guide that most closely corresponds to the problem.
If the symptoms in the guide do not correspond to the malfunction, or if the problem is not
resolved by the recommended corrective action, contact the KMT Customer Service
Department for assistance.
20480318
2-2009/Rev 0
10-1
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
1.
Malfunction
Indication
Comments
High oil temperature
resulting in shutdown
Cooling water flow is
restricted
Check cooling water source
for proper temperature and
flow rate.
The water pressure delivered
to the heat exchanger requires
a minimum of 35 psi (2.4 bar)
for flow through the
exchanger.
2.
Water modulating valve is
stuck open or closed, or is
out of adjustment
Replace the valve.
Scale build up in the heat
exchanger has restricted the
flow
The heat exchanger will need
to be flushed or replaced.
Low oil level resulting in
shutdown
Adjust the valve.
Check the level gauge.
Check for hydraulic leaks.
Check the level switch.
3.
20480318
2-2009/Rev 0
Hydraulic pressure but no
high pressure water
pressure
Proximity switch failure
From the Maintenance Screen
on the control panel, jog the
intensifier left and right and
verify that the red light comes
on at both proximity switches.
Coil failure on the directional
control valve
Check the coils on the
directional valve with a volt
meter to verify if they are good
or bad.
PLC failure
If there are inputs from the
proximity switches, but no
outputs, contact the KMT
Customer Service Department
for a logic review and
verification of PLC failure.
10-2
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
4.
5.
Malfunction
Indication
Comments
No hydraulic oil pressure
The high and low limit
compensators on the
hydraulic pump are blocked
with debris and are not
controlling the swashplate
Disassemble the compensators,
clean and inspect the
components following the
maintenance procedure in
Section 7, Hydraulic System.
Incorrect motor rotation
Check the motor rotation.
The flexible coupling has
failed
Replace the flexible coupling.
Emergency stop button is
depressed
Pull the E-STOP button out and
press the RESET button.
Pump will not start
Check all remote E-STOP
buttons.
6.
Console display and lights
do not illuminate
Output signal has been
interrupted
Check the Q:0.0 relay.
A protection fault has been
activated
Check the display panel for
fault messages.
Motor overload relay has
been tripped
Identify the source of the
overload and remedy the
problem. Reset the overload
relay.
Main power is disconnected
Check the main power and
verify that the main power
disconnect is on.
Control power is not
available
Check the power supply circuit
for a tripped breaker.
Check the input and output of
the 24 volt DC power supply.
20480318
2-2009/Rev 0
10-3
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
7.
Malfunction
Indication
Comments
Pump quits running
A system fault has been
detected
Check the display panel for
fault messages.
Electrical power has been
interrupted
Check the power supply circuit
for a tripped breaker.
Check the input and output of
the 24 volt DC power supply.
Verify that power is available
at the main power source.
Check for a tripped main
circuit breaker.
Check the Q:0.0 relay.
8.
No control power
Motor overload relay has
been tripped
Identify the source of the
overload and remedy the
problem. Reset the overload
relay.
Circuit breaker has been
tripped
Check the input and output of
all circuit breakers.
Power supply fault
Check the input and output
voltages at the power supply.
Emergency stop button is
depressed
Pull the E-STOP button out.
Check all remote E-STOP
buttons.
20480318
2-2009/Rev 0
Master control relay is not
energized
Verify that the contactor coil is
pulling in on the master
control relay.
Contact set failure on the
master control relay
Verify that the contact sets on
the master control relay are
changing states when the relay
is energized.
10-4
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
9.
Malfunction
Indication
Comments
Red light on operator’s
console is flashing
An alarm condition has
occurred
Check the display panel for
fault messages.
Refer to Section 4, Operation,
for additional information
regarding warning and alarm
conditions and recovery
procedures.
10.
Abnormal fluctuations in
high pressure water signal
Large, worn or damaged
orifice
Make sure the orifice does not
exceed the capacity of the
pump.
Make sure the orifice is in
good working condition.
Verify that the jewel is
installed in the orifice mount.
Check valve leakage
Inspect the discharge check
valves in the sealing heads.
Inspect the inlet check valves
in the sealing heads.
Seal leakage
Inspect the high pressure seal
on the plunger.
Inspect the sealing head seal
assembly.
Hydraulic control
malfunction
Check the operation of the
hydraulic relief valve.
Verify that the directional
control valve is shifting
properly.
Check the operation of the
proximity switches.
20480318
2-2009/Rev 0
10-5
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
11.
12.
13.
Malfunction
Indication
Comments
Hot surfaces on the high
pressure cylinder
components
Leaking discharge check
valve, hot sealing head body
and discharge gland
Inspect the condition of the
seat, poppet valve, spring,
poppet pin and sealing head
surface on the discharge end of
the sealing heads.
Leaking inlet check valve,
hot inlet ring
Inspect the condition of the
poppet valve, poppet retainer
and the spring on the inlet end
of the sealing heads.
Damaged sealing head
Check the sealing head for
cracks.
Damaged high pressure
cylinder
Check the high pressure
cylinder for cracks.
Restricted water supply
Check cutting water supply
flow and pressure.
Clogged water filter
Check the condition of the low
pressure water filter and
replace the filter element if
necessary.
Trapped air
Bleed the air from the cutting
water plumbing.
Low hydraulic pressure
setting
If operating in low pressure,
switch to high pressure
operation and check the
hydraulic pressure setting.
Low cutting water supply
pressure
Low cutting water pressure
Clean the high pressure
adjustment valve.
Clean the compensators on the
hydraulic pump.
14.
20480318
2-2009/Rev 0
Hydraulic oil leaking from
the weep hole in the
hydraulic cylinder head
Collapsed element in the
high pressure line filter
Check the element in the high
pressure line filter.
Failed hydraulic cartridge
seal
Replace the cartridge seal. If
the leak persists, check the
plunger for linear scratches or
scoring.
10-6
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
15.
Malfunction
Indication
Comments
Water leaking from the
weep hole on the hydraulic
cylinder head flange
Failed high pressure seal
assembly
Replace the high pressure seal
assembly.
Damaged plunger
Check the plunger for
longitudinal scratches or flaws.
If detected, replace the plunger
or return to KMT Waterjet for
evaluation and rework.
Seal material buildup on
plunger
Polish the plunger surface
following the procedure,
Plunger Maintenance, detailed
in Section 9, High Pressure
Water System.
Damaged high pressure
cylinder
Check for scratches, grooves
or material buildup on the
inside diameter of the cylinder.
If detected, polish the bore
following the procedure, High
Pressure Cylinder
Maintenance, detailed in
Section 9, High Pressure
Water System.
Check the inside diameter of
the cylinder for expansion
where the high pressure seal
assembly is located. If
detected, replace the cylinder.
16.
Water leaking from the
weep hole in the sealing
head
Seat in the discharge check
valve is not sealing properly
Make sure the gland nut is
tightened to the proper torque
specification.
Inspect the seat, sealing head
and gland nut for scratches,
erosion or cracks.
20480318
2-2009/Rev 0
Improper torque on gland nut
Tighten the gland nut to the
proper torque specification.
Erosion or scratches on the
contact surface of the sealing
head, or on the gland nut
where the seat makes contact
Polish the surfaces following
the procedure, Sealing Head
Maintenance, detailed in
Section 9, High Pressure
Water System.
10-7
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
17.
Malfunction
Indication
Comments
Water leaking from the
weep hole in the sealing
head gland nut
High pressure piping gland
nut is not tight and is not
sealing properly
Tighten the gland nut to the
proper torque specification.
Improper high pressure
piping connection
Check the number of exposed
threads past the collar on the
high pressure piping. Only 11/2 to 2-1/2 threads should be
exposed.
Check high pressure piping for
damage, cracks or
deformation.
Inspect the gland nut for
deformation of the threads.
18.
Water leaking from the
weep holes in the soft seal
end cap
Damaged sealing head gland
nut
Check the gland nut for cracks
due to fatigue. If cracks are
detected, replace the gland nut.
Worn sealing head seal
assembly
Replace seal assembly.
Damaged high pressure
cylinder
Check for scratches or grooves
on the sealing surface. If
detected, polish to remove
following the procedure, High
Pressure Cylinder
Maintenance, detailed in
Section 9, High Pressure
Water System.
Replace the high pressure
cylinder.
20480318
2-2009/Rev 0
External crack in sealing
head
Replace the sealing head.
Damaged sealing head
Check for scratches or grooves
on the sealing surface of the
sealing head. If detected,
polish the surface following
the procedure, Sealing Head
Maintenance, detailed in
Section 9, High Pressure
Water System.
10-8
Section 10
Troubleshooting
JetlineTM JL-1 Troubleshooting Guide
19.
Malfunction
Indication
Comments
Outlet booster pump
pressure is falling below 60
psi (4 bar)
Booster pump needs to be
adjusted or replaced
Booster pump should be
adjusted to 120 psi (8 bar)
when deadheaded.
Inlet water pressure is low
Filter element is dirty and
needs to be replaced
20480318
2-2009/Rev 0
20.
Inlet water flow is poor and
the filter housing is not
filling completely
Pipe sizing for inlet cutting
water should be checked for
pressure and flow
Cutting water supply will be
lacking capacity or flow.
21.
Water is leaking around the
bleed valve on the filter
head
O-ring that closes the
passage has deteriorated
A small o-ring under the valve
can deteriorate causing the
passage to remain open. The
o-ring can be replaced by
removing the screw and spring
on the underneath side.
10-9
SECTION 11
SPECIFICATIONS
11.1
Overview
Comprehensive listings of specifications for the JetlineTM series are provided in this section.
Table 11-1
JetlineTM JL-1
Model
11.2
Motor Horsepower
Rating
HP
Kw
JL-1 30
30
22
JL-1 50
50
37
Installation Specifications
Environment
Installation location
Indoors
Air borne dust/contaminants
Minimal
Ambient temperature
Minimum storage
36° F (2° C)
Minimum operating
40° F (5° C)
Maximum operating
104° F (40° C)
Maximum relative humidity*
(at maximum operating temperature)
95%
*Note: When the relative humidity is above 50%, the oil in the reservoir
should be checked frequently for water content.
Sound Level
Sound level with optional side panels
20480327
7-2011/Rev 03
75.0 [dB(A)]
11-1
Section 11
Specifications
Equipment Dimensions and Weights
Length
Width
Height
Weight
JL-1 30
78.98” (2,006 mm)
36.00” (914 mm)
46.58” (1,183 mm) 2,450 lbs (1,111 kg)
JL-1 50
78.98” (2,006 mm)
36.00” (914 mm)
46.58” (1,183 mm) 2,650 lbs (1,202 kg)
Service Connections
Connection
Height
A
Drain
1/2” BSPT
12.51” (318 mm)
B
Cutting Water In
1/2” BSPT
16.26” (413 mm)
C
Cooling Water In
1/2” BSPT
20.01” (508 mm)
D
Cooling Water Out
1/2” BSPT
23.76” (604 mm)
E
Contaminated Waste Drain
1/2” BSPT
28.76” (730 mm)
F
Cutting Water Out
9/16” HP
36.26” (921 mm)
G
Plant Air In
1/4” BSPT
40.26” (1,023 mm)
Plant Air
The facility compressed air connection should provide clean, dry air regulated to 85 psi (5.9
bar). Air usage is minimal, normally less than 1 scf/m.
The following table provides specifications for each ISO air quality classification. KMT
recommends adherence to Quality Class 4.
Table 11-2
ISO Air Quality Classifications
20480327
7-2011/Rev 03
ISO Quality
Class
Maximum
Particle Size
(microns)
Maximum Pressure
Dew Point
(water @ 100 psi)
Maximum Oil Content
(Mg/m3)
1
0.1
-94° F (-60° C)
0.01
2
1
-40° F (-40° C)
0.1
3
5
-4° F (-20° C)
1
4
15
+38° F (+3° C)
5
5
40
+45° F (+7° C)
25
6
--
+50° F (+10° C)
--
11-2
Section 11
Specifications
11.3
Water Specifications
Cutting Water Supply (Low Pressure Water System)
Maximum required inlet water flow
JL-1 30
JL-1 50
2.5 gpm (9.5 L/min)
4.0 gpm (15.1 L/min)
Minimum inlet water pressure
35 psi (2.4 bar) flowing
Maximum inlet water pressure
80 psi (5.5 bar)
Maximum booster outlet water pressure
120 psi (8.3 bar)
Booster pump factory set inlet pressure
58 psi (4 bar)
Booster pump factory set outlet pressure
120 psi (8.3 bar)
Optimum inlet water temperature
65° F (18° C)
Maximum inlet water temperature
85° F (29° C)
Low inlet water pressure
30 psi (2 bar)
Low booster pressure
60 psi (4 bar)
Recirculation System
JL-1 30
Maximum consumption at 75° F (24° C)
Total heat rejection
JL-1 50
1.5 gpm (5.7 L/min) 3.0 gpm (11.4 L/min)
5.3 HP (4.0 kW)
8.6 HP (6.4 kW)
Reservoir capacity
40 gal (151 L)
Low oil level shutdown
30 gal (114 L)
Minimum operating oil temperature
60° F (15° C)
Optimum operating oil temperature
115° F (46° C)
Hot oil shutdown (maximum operating oil temperature)
145° F (63° C)
Minimum inlet cooling water pressure
35 psi (2.4 bar)
Maximum inlet cooling water pressure
100 psi (6.9 bar)
Oil filtration rating (Beta filtration rating)
Fluid cleanliness rating (ISO fluid cleanliness rating))
Nominal recirculation pressure
Β7≥1000*
17/14**
30 psi (2 bar)
Recommended oil type
General service
Mobil #DTE Heavy Medium, No.
021029
Conoco Hydroclear TM multi-purpose
R&O
Food service
Fuchs/Geralyn AW68 Food Grade Oil
* Note: For each particle per milliliter downstream of the filter greater than 7 microns, there are 1000
particles per milliliter larger than 7 microns upstream of the filter.
20480327
7-2011/Rev 03
11-3
Section 11
Specifications
Recirculation System
**Note: Indicates ISO 4406 range numbers for maximum permissible number of particles per
milliliter, greater than 5 and 15 microns.
17
<1,300 particles per milliliter, >5 microns
14
<160 particles per milliliter, >15 microns
Water Quality Standards
The quality of the inlet cutting water supply is one of the most important factors affecting
component life and performance. Water treatment requirements can be determined by a water
analysis.
The cutting water supply must meet the following standards. A high concentration of
dissolved solids, especially calcium, silica and chlorides will affect high pressure component
life.
Table 11-3
Water Quality Standards
Constituent
(mg/l)
Minimum
Requirement
Better
Best
Alkalinity
50
25
10
Calcium
25
5
0.5
Chloride
100
15
1
1
1
0.05
Iron
0.2
0.1
0.01
Magnesium as Mg
0.5
0.1
0.1
Manganese as Mn
0.1
0.1
0.1
Nitrate
25
25
10
Silica
15
10
1
Sodium
50
10
1
Sulfate
25
25
1
TDS*
200
100
35**
Total Hardness
25
10
1
6.5-8.5
6.5-8.5
6.5-8.5
5
5
1
Free Chlorine
pH
Turbidity (NTU)
* Note: Total dissolved solids
20480327
7-2011/Rev 03
11-4
Section 11
Specifications
Table 11-3
Water Quality Standards
Constituent
(mg/l)
Minimum
Requirement
Better
Best
**Note: Do not reduce the TDS beyond this amount or the water will be too aggressive.
Table 11-4
Water Impurities
Constituent
Chemical Formula
Comments
Alkalinity
Bicarbonate (HCO3)
Carbonate (CO3)
Hydrate (OH),
expressed as CaCO3
Acid neutralizing capacity of water. Foaming
and carryover of solids, causes embrittlement of
steel, can produce CO2, a source of corrosion.
Calcium
Ca
When dissolved makes water hard; contributes to
the formation of scale.
Chloride
Cl
Adds to solid content and increases corrosive
character of water; in relative percentage
presence with oxygen induces stress corrosion
cracking.
Free Chlorine
Cl2
Oxidizing agent; can attack elastomeric seals and
damage reverse osmosis (RO) membranes.
Iron
Fe++ (ferrous)
Fe+++ (ferric)
Discolors water or precipitation; source of scale
and erosion.
Magnesium as Mg
When dissolved makes water hard; contributes to
the formation of scale.
Manganese as Mn
Mn++
Discolors water or precipitation; source of scale
and erosion.
Nitrate
NO3
Adds to solid content; effect is not generally
significant industrially.
Silica
SiO2
Causes scale
Sodium
Na
Found naturally; introduced to water in the ion
exchange water softening process.
Sulfate
SO4
Adds to solid content; combines with calcium to
form calcium sulfate scale.
TDS
Total Hardness
20480327
7-2011/Rev 03
Measure of the total amount of dissolved matter
in water.
CaCO3
Sum of all hardness constituents in water;
typically expressed as their equivalent
concentration of calcium carbonate; primarily due
to calcium and magnesium in solution, but may
include small amounts of metal. Carbonate
hardness is usually due to magnesium and
calcium bicarbonate; non-carbonate hardness is
due to sulfates and chlorides.
11-5
Section 11
Specifications
Table 11-4
Water Impurities
Constituent
Chemical Formula
Comments
pH
11.4
Intensity of the acidic or alkaline solids in water;
pH scale runs from 0, highly acidic, to 14, highly
alkaline; with 7 being neutral.
Electrical Specifications
Electrical System
Motor type
TEFC (Totally Enclosed Fan Cooled)
Controls
Voltage
24 volts DC
Power supply
5 amps DC
Ampacity and Power Voltage Requirements
Motor
Horsepower
Full Load
Amps
Circuit Breaker
Amps
208/3/60
30
80
100
230/3/60
30
76
100
380/3/50
30
44
60
400/3/50
30
43
60
415/3/50
30
43
60
460/3/60
30
38
50
575/3/60
30
32
40
200/3/50-60
50
132
175
208/3/50-60
50
128
175
240/3/60
50
112
175
380/3/50
50
69
100
400/3/50
50
66
100
415/3/50
50
64
100
480/3/60
50
56
80
575/3/60
50
47
80
Power Voltage
20480327
7-2011/Rev 03
11-6
Section 11
Specifications
11.5
Hydraulic and High Pressure Water System Specifications
Hydraulic System
Maximum operating pressure
2,750 psi (190 bar)
Main system relief valve
3,408 psi (235 bar)
High Pressure Water System
Maximum flow rate
55,000 psi (3,792 bar)
Plunger diameter
JL-1 30
JL-1 50
0.60 gpm (2.3 L/min)
1.0 gpm (3.8 L/min)
0.875” (22 mm)
Piston diameter
4.03” (102.4 mm)
Intensification ratio
20:1
Minimum outlet pressure
6,000 psi (414 bar)
Maximum outlet pressure
55,000 psi (3,792 bar)
Pneumatic Control Valve
Maximum water pressure
60,000 psi (4,137 bar)
Regulated air pressure
85 psi (5.9 bar)
1.0 cfm (0.028) m3/min
Maximum flow rate
Orifice Capacity
The following tables provide horsepower requirements for some of the more popular orifices.
Table 11-5
Single Orifice Diameter
Model
20480327
7-2011/Rev 03
Motor
Horsepower
Rating
HP
Kw
Maximum
Operating
Pressure
Maximum Single
Orifice Diameter
(at full pressure)
JL-1 30
30
22
55,000 psi (3,792 bar)
0.011 inch (0.28 mm)
JL-1 50
50
37
55,000 psi (3,792 bar)
0.014 inch (0.36 mm)
11-7
Section 11
Specifications
Table 11-6
Horsepower Requirements
Orifice Size
inches (mm)
45,000 psi
(3,103 bar)
50,000 psi
(3,447 bar)
55,000 psi
(3,792 bar)
0.003 (0.076)
1.7
2.0
2.3
0.004 (0.102)
3.0
3.5
4.0
0.005 (0.127)
4.6
5.4
6.2
0.006 (0.152)
6.7
7.8
9.0
0.007 (0.178)
9.1
10.6
12.2
0.008 (0.203)
11.8
13.9
16.0
0.009 (0.229)
15.0
17.5
20.2
0.010 (0.254)
18.5
21.6
25.0
0.011 (0.279)
22.4
26.2
30.2
0.012 (0.305)
26.6
31.2
36.0
0.013 (0.330)
31.2
36.6
42.2
0.014 (0.356)
36.2
42.4
48.9
0.015 (0.381)
41.6
48.7
56.2
0.016 (0.406)
47.3
55.4
63.9
The horsepower requirements for operating multiple orifices are determined by adding the
requirements in Table 11-6 for each orifice. Examples are shown below.
Orifice Size
inches (mm)
Number of
Orifices
Operating
Pressure
Calculation
Total
Horsepower
0.005 (0.127)
3
55,000
3 x 6.2
18.6
0.012 (0.305)
0.009 (0.229)
1
1
50,000
31.2 + 17.5
48.7
Torque Specifications
Measurements are made with lubricated components and a certified calibrated torque wrench.
Inconsistencies in wrench settings, lubrication and technique may not produce a leak free seal.
If leakage occurs, the torque can be increased to seal the components. However, do not
exceed the recommended torque value by more than 15 percent. If leakage persists, there
is a component problem.
WARNING
Excessive torque can cause component damage or failure, resulting in potential
hazards to equipment and personnel.
20480327
7-2011/Rev 03
11-8
Section 11
Specifications
Torque Specifications
Hydraulic Cylinder Head
Socket Head Screws
Torque
Hex Key
8 (14M) each
75-80 ft-lbs (102-108 Nm)
M12
Proximity Switch
Socket Head Screws
Torque
Hex Key
2 (M6) each
140-160 in-lbs (16-18 Nm)
M5
Intensifier Mount
Socket Head Screws
Torque
Hex Key
4 (M10) each
60-65 ft-lbs (80-88 Nm)
M8
Sealing Head
Discharge Gland Nut
Poppet Retainer
130 ft-lbs (176 Nm)
25-30 in-lbs (2.8-3.4 Nm)
Pneumatic Control Valve
3/8-inch HP Inlet Gland Nut
50 ft-lbs (68 Nm)
1/4-inch Outlet to Drain
25 ft-lbs (34 Nm)
Pneumatic Actuator
HP Adapter
5 ft-lbs (7 Nm)
25 ft-lbs (34 Nm)
High Pressure Fittings
1/4-inch Gland Nut
25 ft-lb (34 Nm)
3/8-inch Gland Nut
50 ft-lb (68 Nm)
9/16-inch Gland Nut
110 ft-lb (149 Nm)
20480327
7-2011/Rev 03
11-9
(800) 826-9274
(620) 856-2242
[email protected]
[email protected]
Phone
Fax
Email
+49-6032-997-119
+49-6032-997-271
[email protected]
Spare Parts Manager
KMT Waterjet Systems GmbH
Wasserstrahl Schneidetechnik
Auf der Laukert 11
D-61231 Bad Nauheim
Germany
Customer Service Department
KMT Waterjet Systems
PO Box 231
635 West 12th Street
Baxter Springs, KS 66713-0231
USA
Phone
Fax
Email
Email
Europe
USA
Use the following information to contact the Customer Service Department at KMT Waterjet Systems.
12-1
This section contains a comprehensive list of all standard and optional parts for the JetlineTM JL-1 50. To facilitate the ordering of replacement parts,
item numbers in each table correspond to the identifying numbers in the accompanying figures.
Overview
20480330
7-2011/Rev 03
12.1
PARTS LIST
SECTION 12
JL-1 50 Intensifier Unit
Intensifier Assembly
Hydraulic Cartridge Seal
Sealing Head Assembly
Pneumatic Valve/Actuator Assembly
Hydraulic Piston Assembly
High Pressure Water Assembly
Low Pressure Water Filter
Hydraulic Power Package
12-1
12-2
12-3
12-4
12-5
12-6
12-7
12-8
12-9
Table Description
Part lists are arranged in the following sequence:
Index
20480330
7-2011/Rev 03
12.2
20476908
20454810
20476916
72112358
20427739
05116769
80086622
20460873
Part
Number
12-17
12-15
12-13
12-11
12-9
12-8
12-7
12-5
12-3
Page
12-15
12-14
12-13
12-12
12-11
12-10
Electrical Configuration
Electrical Assembly
Bulkhead Pipe Assembly
Reservoir Assembly
Hydraulic Hose Connections
Pump/Manifold Assembly
Table Description
Parts List Index
20477068
20477742
20477264
20477035
20477268
20478196
Part
Number
12-29
12-27
12-25
12-23
12-21
12-19
Page
12-2
Section 12
Parts List
20480330
7-2011/Rev 03
Part
Number
20453979
10064715
49883580
20476974
80070931
10070175
20476954
Item
1
2
3
4
5
6
7
Decal Package
Hex Nut, M10
Nameplate
Frame Assembly
Flat Washer, M10
Lock Washer, M10
Electrical Enclosure
Description
Table 12-1
JL-1 50 Intensifier Unit
1
4
1
1
4
4
1
Quantity
12-3
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-1: JL-1 50 Intensifier Unit
12-4
Section 12
Parts List
05059712
05039771
05116769
05034772
20422243
10110393
05059688
80086622
05007786
20497767
10074904
1
2
3
4
5
6
7
8
9
11
12
20480330
7-2011/Rev 03
Part
Number
Item
O-Ring, 1.56 x 1.75 x .09
Liner, High Pressure Cylinder
Bushing Retainer Flange
Hydraulic Cartridge Seal Assembly
Soft Seal End Cap
Sealing Head Seal Assembly
High Pressure Seal Assembly
Hydraulic Cylinder Head
Sealing Head Assembly
Plunger
High Pressure Cylinder
Description
4
2
2
2
2
2
2
2
2
2
2
Quantity
23
21
20
19
18
17
16
15
14
13
Item
05144183
72112358
10183572
20453934
05141106
05034855
10075000
05034764
05034798
10110401
Part
Number
Table 12-2
Intensifier Assembly
20460873
Spacer, Proximity Switch
Hydraulic Piston Assembly
Socket Head Screw, M6 x 1.0 x 22MM
Proximity Switch
Socket Head Screw, M14 x 60
Backup Ring
O-Ring, 3.75 x 4.0 x .13
Hydraulic Cylinder
Retaining Ring
Collar, Sealing Head
Description
2
1
4
2
16
2
2
1
2
2
Quantity
12-5
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-2: Intensifier Assembly
12-6
Section 12
Parts List
80086630
05015060
10193522
05050760
05129481
05013024
05129515
05027255
1
2
3
4
5
6
7
8
20480330
7-2011/Rev 03
Part
Number
Item
Packing Seal, U-Cup
Backup Ring, 1.127 x .891
O-Ring, 1.25 x 1.38 x .06
O-Ring, 1.0 x 1.13 x .06
Backup Ring, 1.188 x 1.375
O-Ring, 1.19 x 1.38 x .09
Packing Ring
Seal Bushing
Description
1
1
1
1
1
1
1
1
Quantity
Table 12-3
Hydraulic Cartridge Seal
80086622
Figure 12-3: Hydraulic Cartridge Seal
12-7
Section 12
Parts List
10106417
10107894
05116777
05112768
05116561
10118552
49884562
05116751
AV500260
1
2
3
4
5
6
8
9
10
20480330
7-2011/Rev 03
Part
Number
Item
Compression Spring
Poppet Pin
Compression Spring
Poppet Retainer
Discharge Poppet Check Valve
Seat
Gland Nut
Inlet Poppet Check Valve
Sealing Head Body
Description
1
1
1
1
1
1
1
1
1
Quantity
Table 12-4
Sealing Head Assembly
05116769
Figure 12-4: Sealing Head Assembly
12-8
Section 12
Parts List
20427648
10178697
49830904
20435636
10188233
20428052
1
2
3
4
5
6
20480330
7-2011/Rev 03
Part
Number
Item
Seal Assembly
Backup Ring, Brass
Valve Stem
Adapter, HP Water Valve
Valve Seat
Valve Body
Description
1
1
1
1
1
1
Quantity
10074714
10074565
12
10187250
BV501184
BV601184
BV401184
10189553
Part
Number
11
10
9
8
7
Item
O-Ring, 2.25 x 2.38 x .06
O-Ring, 2.44 x 2.63 x .09
Backup Ring, SST
Piston
Cylinder Head
Pneumatic Cylinder
Actuator Assembly, Normally Open
Description
Table 12-5
Pneumatic Valve/Actuator Assembly, Normally Open
20427739
2
1
1
1
1
1
Quantity
12-9
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-5: Pneumatic Valve/Actuator Assembly, Normally Open
12-10
Section 12
Parts List
20480330
7-2011/Rev 03
72111944
20498800
20418031
05087713
05049994
05117965
05117940
2
3
4
5
6
7
Part
Number
1
Item
Bearing
Seal Assembly
Backup Ring, 1.25 x 1.50
O-Ring, 1.25 x 1.50
Retaining Ring
Plunger Retainer
Ram Piston
Description
Table 12-6
Hydraulic Piston Assembly
72112358
2
1
2
2
2
2
1
Quantity
12-11
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-6: Hydraulic Piston Assembly
12-12
Section 12
Parts List
20460873
20467648
80070311
10078715
10078129
10078590
80070303
95413696
95383790
72102577
10079531
20498314
10078780
72102585
20427739
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
20480330
7-2011/Rev 03
Part
Number
Item
Valve/Actuator Assembly
HP Tube, Bent, .38
Elbow, HP, .38 x .38
Attenuator Assembly, .96L
Coupling, HP/HP, .56 x .38
HP Tube, Bent, .38
Socket Head Screw, 1/2-13 x 1
Lock Washer, .50
HP Tube, Bent, .38
Tee, HP, .38
HP Gland, .38
HP Collar, .38
HP Tube, Bent, .38
HP Tube, Bent, .25
Intensifier Assembly
Description
1
1
1
1
2
1
4
4
1
1
4
4
1
1
1
Quantity
30
29
28
27
26
25
24
23
21
20
19
18
17
Item
10105443
05081872
05061486
10074409
20427804
20427994
10078426
10078459
10083897
10094704
72102593
20455068
49830581
Part
Number
Table 12-7
High Pressure Water Assembly
20476916
HP Tube, .38 x 4.0
Gasket
Lock Washer, M10
O-Ring, 1.0 x 1.25 x .13
Intensifier Support, 3.0
Socket Head Screw, M10 x 1.50
HP Collar, .25
HP Gland, .25
Ferrule, .25
HP Tube, .38 x 3.0
Clamp, Attenuator
Socket Head Screw, M12 x 1.75 x 20
Coupling, Bulkhead, .56 x .38
Description
1
2
8
2
2
8
1
1
8
1
2
4
1
12-13
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-7: High Pressure Water Assembly
12-14
Section 12
Parts List
20468959
10069797
20469505
20468963
20468967
20468646
10081230
20468970
20468974
20468978
1
2
3
4
5
6
7
8
9
10
20480330
7-2011/Rev 03
Part
Number
Item
Filter Housing Assembly
Adapter, BSPT/Hose, .50 x .50
U-Bolt, .75
Elbow, Pipe, .75 x .75
Manifold, Outlet
Elbow, BSPT, .50 x .50
Nipple, BSPT, .75
Relief Valve
Flat Washer, #6
Plug, Pipe, .25
Description
1
2
2
1
1
1
2
1
4
1
Quantity
18
17
16
15
14
13
12
11
Item
20468724
20468955
10078152
10070183
10106722
10069888
20468991
20468982
Part
Number
Table 12-8
Low Pressure Water Filter Assembly
20454810
Hose Barb, .50 x .50
Adapter, BSPT/JIC, .50 x .50
Bushing, Pipe, .75 x .50
Hex Nut, M6
Filter Element, 10 Micron
Lock Washer, #6
Adapter, BSPT/Hose, .50 x .50
Check Valve
Description
1
1
1
4
1
4
2
1
12-15
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-8: Low Pressure Water Filter Assembly
12-16
Section 12
Parts List
49890460
10092302
05049168
10116952
49887094
95838314
95572897
10069714
95750394
95416319
49883580
10064715
49886989
10189025
20476925
20477006
20478196
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
20480330
7-2011/Rev 03
Part
Number
Item
Pump/Manifold Assembly
Flange, Motor/Pump
Coupling, Flex Drive
Adapter, Hose/JIC, .50 x .50
Adapter, JIC/Pipe, .50 x .38
Lock Washer, M10
Flat Washer, M10
Hex Head Screw, 3/8-16 x 1
Lock Washer, .38
Flat Washer, .38
Hex Head Screw, 1/4-20 x 5/8
Lock Washer, .25
Water Pump, Vane
Caplug, 1.04
Adapter, Water Pump
Shaft Coupling
Electric Motor, 50HP
Description
1
1
1
2
2
2
2
2
2
2
3
3
1
2
1
1
1
Quantity
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
Item
20477807
20477803
20477800
20477758
49833072
10142644
10144749
10091510
05139720
49892359
20432331
05037593
20477284
49892375
49892342
05045364
Part
Number
Table 12-9
Hydraulic Power Package
20476908
Hex Nut, M18
Lock Washer, M18
Flat Washer, M18
Hex Head Screw, M18 x 2.50 x 70MM
Lock Washer, .63
Adapter, JIC/ORB, .25 x .25
Adapter, JIC/ORB, .25 x .25
Arrow Decal
O-Ring, 85MM x 3MM
Lock Washer, M16
Socket Head Screw, M16 x 2 x 50MM
Socket Head Screw, M10 x 1.50 x 25MM
Vibration Isolation Module
Hex Head Screw, M16 x 2 x 60MM
Flat Washer, M16
Gear Pump
Description
8
8
8
8
4
2
2
1
1
6
4
2
2
6
6
1
12-17
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-9: Hydraulic Power Package
12-18
Section 12
Parts List
05045505
05044144
05091756
05050356
10074953
05071717
20437164
95055059
95688750
05071055
1
2
3
4
5
6
7
8
9
10
20480330
7-2011/Rev 03
Part
Number
Item
Plug, ORB, .75
Lock Washer, .50
Socket Head Screw, 1/2-13 x 2-1/2
Directional Control Valve
Relief Valve
O-Ring, 1.50 x 1.75 x .13
Lock Washer, .44
Socket Head Screw, 7/16-14 x 6
Manifold
Hydraulic Pump
Description
3
6
6
1
1
1
4
4
1
1
Quantity
19
18
17
16
15
14
13
12
11
Item
05045497
05089792
49889769
49889736
49889744
10187060
10187052
10185585
05055017
Part
Number
Table 12-10
Pump/Manifold Assembly
20478196
Pressure Gauge
Flat Washer, .44
Plug, ORB, .25
Check Valve
Retainer, Cartridge Valve
Relief Valve
Relief Valve
Solenoid Valve
Plug, ORB, .13
Description
1
12
1
1
1
1
1
1
2
12-19
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-10: Pump/Manifold Assembly
12-20
Section 12
Parts List
20449078
10091163
10083517
10179018
05048780
05048806
20468826
20477713
20455089
1
2
3
4
5
6
7
8
9
20480330
7-2011/Rev 03
Part
Number
Item
Hose Assembly, Hydraulic, .75 x 29.0
Hose Assembly, Hydraulic, .75 x 29.0
Hose Assembly, Hydraulic, .75 x 23.0
Adapter, Flange/Hose, 2.0 x 2.0
Split Flange Kit, 2.0
Radiator Hose, 2.0
Hose Clamp
Adapter, JIC/ORB, .75 x .75
Hose Assembly, Hydraulic, 1.0 x 15.50
Description
2
2
1
1
1
10.0"
2
1
1
Quantity
17
16
15
14
13
12
11
10
Item
20477869
10150688
05060751
80086192
05064407
95702619
05052493
05050331
Part
Number
Table 12-11
Hydraulic Hose Connections
20477268
Hose Assembly, Hydraulic, 1.0 x 19.0
Hose Assembly, Hydraulic, .25 x 24.0
Hose Assembly, Hydraulic, .25 x 32.0
Adapter, JIC/ORB, 1.0 x 1.0
Adapter, JIC/ORB, 1.0 x .75
Adapter, JIC/ORB, .75 x .75
Adapter, JIC/ORB, .75 x .63
Adapter, JIC/ORB, .75 x .63
Description
1
1
2
1
1
2
1
2
12-21
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-11: Hydraulic Hose Connections
12-22
Section 12
Parts List
20478147
20478151
20462991
20468655
20476941
20468662
20468666
20468670
05069976
20468683
80087687
20468687
20468691
20468695
20468704
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
20480330
7-2011/Rev 03
Part
Number
Item
Adapter, BSPT/JIC, 1.0 x 1.0
Plug, BSPT, .50
Ball Valve, 2-Way
Bulb Well
Diffuser
Adapter, BSPT/JIC, .75 x .75
Cap, JIC Swivel, .75
Tee, BSPT/JIC, .75 x .75
Filter Element
Filter Head, Hydraulic
Adapter, BSPT/ORB, .75 x .75
Gauge, Level/Temperature
Gasket
Reservoir Lid
Reservoir Weldment
Description
2
1
1
1
1
1
1
1
1
1
1
1
95.0”
1
1
Quantity
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Item
10191484
49883499
49898729
10134278
20468740
05050026
20468736
20468732
20479720
20470406
20477570
10069672
10070191
20468711
20468708
Part
Number
Table 12-12
Reservoir Assembly
20477035
Pan Head Screw, M5 x 10MM
Lock Washer, M12
Flat Washer, M12
Socket Head Screw, M12 x 1.75 x 25MM
Bushing, BSPT, 1.25 x .75
Switch, Temperature/Level
Air Breather
Heat Exchanger
Adapter, BSPT/JIC, .25 x .25
Hose Barb, .50 x .50
Adapter, JIC/BSPT, .75 x .50
Lock Washer, M8
Hex Nut, M8
Adapter, BSPT/JIC, .75 x .75
Adapter, BSPT/JIC, .25 x .25
Description
3
4
4
4
2
1
1
1
1
2
2
2
4
1
1
12-23
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-12: Reservoir Assembly
12-24
Section 12
Parts List
05142062
20469501
20469497
20469488
10070092
20468995
20469007
20469016
20469020
20469023
20469027
20469031
20469035
20470406
20469039
20469042
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20480330
7-2011/Rev 03
20454810
20468724
Part
Number
3
2
Item
Adapter, BSPT/Tube, .50 x .50
Nipple, BSPT, .50
Hose Barb, .50
Elbow, BSPT, .50 x .50
Tee, BSPT, .50 x .50
Adapter, Tube/Pipe, 6MM x .13
Poly Tube, 6MM
Coupling, Tube, 6MM x .12
Solenoid Valve
Check Valve
Elbow, BSPT, .12 x .25
Jam Nut, 1-14
Coupling, Bulkhead, BSPT, 1.50 x .50
Coupling, Bulkhead, .94 x .25
Pressure Gauge, 0-200 psi
Pressure Switch, 60 psi
Filter Assembly, LP Water
Hose Barb, .50
Description
6
1
1
3
1
1
1
12.0”
1
1
1
1
5
5
1
1
1
1
Quantity
36
35
34
33
32
31
30
29
27
26
25
24
23
22
21
20
Item
20469989
20469985
20470149
49834328
05111406
20421272
20469091
05140751
20469484
20468642
20469083
20469074
20469070
20469066
20469063
20469054
Part
Number
Table 12-13
Bulkhead Pipe Assembly
20477264
Nipple, BSPT, .12 x .12
Jam Nut, 3/4-16
Adapter, JIC/BSPT, .50 x .50
Adapter, Pipe/Tube, .50 x .25
Adapter, JIC/Pipe, .50 x .25
Hose, Push-On, .50
Filter, Strainer
Pressure Switch, 30 psi
Pressure Gauge, 0-100 psi
Manifold, LP Water
Nipple, BSPT, .50 x 2.0
Solenoid Valve
Nipple, BSPT, .50 x 3.0
Adapter, BSPT/JIC, .50 x .50
Water Modulating Valve
Adapter, BSPT/Tube, .50 x .50
Description
1
1
1
2
1
2
300.0"
1
1
1
1
2
1
1
2
1
12-25
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-13: Bulkhead Pipe Assembly
12-26
Section 12
Parts List
20480330
7-2011/Rev 03
20468572
20469123
05141700
20469132
20469136
95423695
20470325
10069763
20468875
20477288
20468427
95716890
10125912
20477068
2
3
4
5
6
7
8
9
10
11
12
13
14
Part
Number
1
Item
Electrical Configuration
Cable Tie
Lock Washer, .50
Connector, Crimp Ferrule, #8
Cable, 9MM
Wire, 10MM, Black
Flat Washer, .50
Terminal Lug, #14-2/0
Hex Nut, 1/2-13
Connector, Flexible Conduit, 1.50
Flex Conduit, 1.50
Ring Terminal, #8
Connector, Flexible Conduit, 1.50
Harness, Sensor/Solenoid
Description
Table 12-14
Electrical Assembly
20477742
1
5
4
18
48.0"
276.0"
4
6
4
1
22.0"
2
1
1
Quantity
12-27
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-14: Electrical Assembly
12-28
Section 12
Parts List
20477059
05081955
20468452
20468448
05141650
20468420
10167070
95750469
95146429
20477288
05141700
20468313
20468440
10073492
10069730
20468346
20468892
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
20480330
7-2011/Rev 03
Part
Number
Item
Wire, 2.5MM, Black
Wiring Duct
Flat Washer, #8
Pan Head Screw, 8-32 x 1/2
DIN Rail
Terminal Block
Ring Terminal, #8
Cable, 9MM
Hex Head Screw, #8-32
Lock Washer, #8
Pan Head Screw, 8-32 x 1
Ground Lug
Ground Lug, #4-#0
Breaker, Terminal Cover
Rotary Drive, Circuit Breaker
Socket Head Screw, 8-32 x 2
Circuit Breaker, 100A
Description
60.0"
148.0"
33
33
77.0"
1
4
110.0"
4
8
8
2
4
2
1
4
1
Quantity
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
Item
20470165
20469108
20468424
20468900
20468239
80078223
20477048
20470128
20470137
20477632
20470103
20473532
204770555
20468427
20468875
20468235
20468416
Part
Number
Table 12-15
Electrical Configuration
Wye-Delta
20477068
Relay, Wye-Delta Timing
Circuit Breaker, 1A
Connector, Crimp Ferrule, #16
Wire, 1.5MM, Red
Transformer, 200VA, 230VAC
End Block, #22-#10
Kit, Star Delta Wiring
Buss Bar
Interlock, Contactor
Auxiliary Contact Block
Contactor, 32A
Overload Relay
Contactor, 50A
Connector, Crimp Ferrule, #8
Wire, 10MM, Black
Circuit Breaker, 2A
Connector, Crimp Ferrule, #14
Description
1
1
250
160.0"
1
10
1
1
1
2
1
1
2
6
72.0"
1
8
12-29
Quantity
Section 12
Parts List
20468403
20468896
20468904
20468883
80078207
20468395
20468391
20468378
20468375
20468371
20468367
20468358
20468305
20468248
20468256
20468264
20468277
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
20480330
7-2011/Rev 03
Part
Number
Item
Block, Lamp Socket
Switch, Pushbutton
Tube Base Relay
Relay Base
Terminal Block
Marker, Terminal Block
Jumper, Terminal Block
End Barrier
Terminal Block, #14-22
Legend Plate
Switch, E-Stop
Circuit Breaker, 6A
Terminal Block, #24-#10
Wire, 1MM, Yellow/Green
Wire, 1.5MM, Blue/White
Wire, 1.5MM, Blue
Power Supply, 24VDC
Description
1
1
2
2
7
16
5
2
79
1
1
1
9
80.0"
240.0"
1040.0"
1
Quantity
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
Item
20470141
20468333
20468354
20468273
20468280
20468322
20468284
20468326
20468382
20468252
20468260
20468309
20468301
20468297
20468342
20468350
20468288
Part
Number
Table 12-15
Electrical Configuration
Wye-Delta
20477068
Auxiliary Contact Block
Ring Terminal, 14-10
Subplate
Hole Seal, 50MM
Hole Seal, 20MM
Spiral Wrap
Pilot Light, Green
Pilot Light, Red
Contact Block
Legend Plate
Selector Switch, 2 Position
Display, OP73
Cable, Profibus
Connector, Profibus
PLC Battery
Memory, PLC EEPROM
PLC-S7200
Description
2
3
1
2
10
12.0"
1
1
1
1
1
1
48.0"
1
1
1
1
12-30
Quantity
Section 12
Parts List
20480330
7-2011/Rev 03
Figure 12-15: Electrical Configuration – Wye-Delta
12-31
Section 12
Parts List
