Lubrication Equipment

Buyer’s Guide

Innovative Product Solutions for the Lubrication Marketplace

The E-Z FAX Document Ordering System

Go online at www.graco.com/lubrication for:

• Literature

• Instruction Manuals

• Buyer’s Guide

• Product Knowledge Exchange

• Distributor Locator

• What’s New

• GEDI ®

GEDI is the “Graco Extranet Distributor Information” area on our web site where distributors have access to up-to-the-minute pricing, product order and shipping status and order entry. Information is accessed by an account number and a confi dential password.

To Find Your Nearest Authorized Graco Lubrication Equipment Distributor

Call: 1-800-533-9655 (toll free North America)

Fax: 1-800-533-9656

Get the documents you need 24-hours-a-day!

Simply Call 1-800-533-9655

ABC

Press option to get into the E-Z FAX System.

2

ABC the number of the service manual or literature document you need.

The documents you request will be faxed directly to you!

L i t e r a t u r e I n d e x | S e r v i c e M a n u a l s | L i t e r a t u r e

2

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

www.graco.com

Table of Contents

Fluid Management Systems

Matrix ® 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Horizon

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Commander

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

Oil Pumps and Packages

Quick Reference Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

Fast-Ball ® 1:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

225, Fire-Ball 300, Fire-Ball 425 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16

Oil Pump Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-19

NXT

High-Flo ® and NXT Dura-Flo ® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21

Grease Pumps and Packages

Quick Reference Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

Mini Fire-Ball 225, 50:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Fire-Ball 300, 15:1, 50:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-27

Fire-Ball 425, 10:1, 50:1, 75:1; Bulldog 3:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29

Grease Pump Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

Check-Mate ® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Transfer Pumps

Air-Operated Double-Diaphragm Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Fast-Flo ® (Stainless Steel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-35

Electrical-Powered Oil and Fuel Pumps

Hurricane ™ Electric Dispense Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

APEX ™ Electric Dispense Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37-38

GTP10 and GTP12 Fuel Transfer Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Specialty Pump Package Solutions

Lube Truck and Undercoating/Rust-Proofi ng Packages . . . . . . . . . . . . . . . . . . . . . . . . . 40-41

Windshield Washer and Coolant Dispense Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Hydraulic Oil and Grease Pumps

Dyna-Star ® , Power-Star

and Viscount ® II Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43-44

Manually-Operated Oil and Grease Pumps and Packages

Hose Reels

Oil and Grease Dispense. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Fluid Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

LD, SD, XD, 700 and 750 Hose Reels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48-54

Reel Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56-57

Dispense Consoles

Multi-Station Consoles and Oil Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Dispense Meters and Control Valves

LD, SD, EM6, EM12 and In-Line Electronic Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59-63

Mechanical Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

SDV15, XDV20, Pro-Shot

and Accu-Shot

Control and Dispense Valves . . . . . . . . . . . 66-68

Manual Grease Guns

Grease Guns, Accessories and Fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69-71

Fluid Reclaim Packages

, Coolant King

, Oil Ace

and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 72-75

Hoses, Fittings and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75-81

Bulk Fluid Dispense

Tank Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83-87

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

3

Matrix

®

3

Fluid Management Systems

4

Automated, Wireless Oil Dispense Tracking and Bulk Tank Monitoring

Dispense meters, software, and wireless devices capture dispense history and monitor petroleum and synthetic oil products and anti-freeze mixture inventory levels.

Features and Benefi ts

• Wireless transmission and reception of meter and tank level information make it simple to track your entire facility’s activities

• Customize to fi t your business–three product platforms (Basic, Professional, and Premier) to fi t any size facility

• Multi-level security to protect your assets

• Precise measurement and control of fl uids ensures profi ts and eliminates out of stock issues for critical inventory

• ADP and Reynolds & Reynolds interfaces provide secure, reliable, data transfer between the Matrix database and the dealership management software

Premier software

256634

Typical Applications

• Auto dealerships

• Heavy-duty fl eet service

• Off-road maintenance shops

• Industrial in-plant lubrication

Typical Fluids Handled

• Petroleum- and synthetic-based oils

• Anti-freeze

Matrix Application Features

Transceiver

255231

Feature

Maximum Number of Transceivers

Maximum Number of Meters

Maximum Number of Tank Monitors

Client PC Networking

Number of users

Track Dispense by Work Order

Track Dispense by Technician

Track Dispense by Vehicle Number

Tank Level Email

Third Party Interface Capable

ADP ® Certifi ed Interface

Basic

1

30

0

0

250

X

Professional

2

100

12

6

500

X

X

X

Reynolds

®

Certifi ed Interface

No fl uid limitations with any Matrix Platform

FOR SALE TO AUTHORIZED DISTRIBUTORS ONLY

X

X

X

X

Premier

8

300

50

300

1000

X

X

X

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

Matrix Meter

256282

Tank Level Monitor

256285

Pump Air Control

247436

www.graco.com

Matrix

®

3

Fluid Management Systems

Software System Operating Requirements

Matrix software can be confi gured as a stand-alone PC or networked to multiple PC’s. This software is not compatible with Apple

®

Computers, and is not available for the Apple

®

Operating system. The

PC requirements for the Matrix Server and Matrix Client or shop PC’s are noted below.

Server PC Hardware Requirements

• Windows

®

XP Professional or Vista

®

operating system

• Pentium

®

4 or better processor

• Processor speed of 3.0 GHz or better

• RAM memory of 1 GB or better

• CD-RW or DVD/RW drive

• Serial port confi guration for (1) RS422 and (1) USB connection

PC Clients

• Windows

®

XP Professional or Vista ® operating system

• Pentium

®

4 or better processor

• Processor speed of 2.0 GHz or better

• RAM memory of 1 GB or better

Software Instruction Manuals

Basic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313104

Professional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313106

Premier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313108

ADP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313112

Reynolds & Reynolds. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313114

RF Communication

(Meters, Transceivers, Tank Level Monitors, Pump Air Control)

Description Performance

RF Communication

RF Communication Range

RF Temperature Range

Approvals

2.4 GHz Direct Sequence Spread Spectrum

Unobstructed: 300 to 500 ft (91 to 152 m); Obstructed: 250 to 300 ft (76 to 91 m)

-40° F to 185° F (-40° C to 85° C)

FCC, Industry Canada (IC), C-Tick, CE

Ordering Information

System Software

256634 Premier Software CD (includes 3rd party interface)

256635 Professional Software CD

256636 Basic Software CD

256637 Premier Software with ADP Interface

256638 Premier Software with Reynolds & Reynolds Interface

Transceiver and Connection Hardware

255231 Transceiver with Universal Power Adapter

255731 USB/RS422 Converter

15T999 15 ft USB Cable

15T998 3 ft USB Cable

119572 RS422 Bulk Wire (1000 ft roll)

Transceiver and Connection Hardware Technical Specifi cations

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0 lb (454 grams)

Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 – 240 V, 50/60 Hz to 12 VDC plug-in transformer

Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313008

www.graco.com

255231

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

5

Matrix

®

3

Fluid Management Systems

Matrix Meter and Accessories

Matrix Electronic Meter with Extension, 5 gpm or Less

256282 1/2 in npt(f) swivel, rigid extension and standard automatic non-drip quick-close nozzle for oil

256482 1/2 in npt(f) swivel, fl exible extension and standard automatic non-drip quick-close nozzle for oil

256483 1/2 in npt(f) swivel, gear lube extension and standard quick-close nozzle

256484 1/2 in npt(f) swivel, rigid extension and standard quick-close nozzle for anti-freeze

256485 1/2 in npt(f) swivel, fl exible extension and standard quick-close nozzle for anti-freeze

Matrix Electronic Meter with Extension, 14 gpm or Less

256486 1/2 in npt(f) swivel, rigid extension, high fl ow, quick-close nozzle for oil

256487 1/2 in npt(f) swivel, fl exible extension, high fl ow, quick-close nozzle for oil

256488 3/4 in npt(f) swivel, rigid extension, high fl ow, quick-close nozzle for oil

257120 3/4 in npt(f) swivel, fl exible extension, high fl ow, quick-close nozzle for oil

Swivel Covers

15T366 Black swivel cover (standard color with meter)

15T367 Red swivel cover

15T368 Blue swivel cover

15T369 Green swivel cover

15T370 Yellow swivel cover

Accessories

15B750 16 gallon and 55 gallon meter mounting bracket

249440 Console bracket

257539 Matrix meter for oil bar (swivel and extension removed)

256719 Oil bar console–complete cabinet without piping and meters

255370 Oil bar kit (fi ttings, nozzles, and piping)

Instruction Manual

313013

257556 Retro fi t kit–mount Matrix meter in 222107 console

Filter Kits for Matrix Meters

255885 Filter kit includes (10) fi lters/strainers ( 15M308), (10) spacers ( 15M309) and (10) O-rings ( 155332)

Technical Specifi cations

Flow Range (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1 to 14 gpm (0.4 to 53 lpm)

Maximum Working Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1500 psi (103.4 bar)

Operating Fluid Pressure Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 – 1500 psi (7–103 bar, 0.7–10.3)

Weight (with battery and rigid nozzle extension) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.07 lbs (2.75 kg)

Units of Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Programmable in pints, quarts, gallons, or liters

Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4 in–14 npt or 1/2 in–14 npt

Outlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4 in–16 straight thread O-ring Boss

Maximum Totalizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999,999 gallons or liters

Maximum Recorded Dispense . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999.9 Units

Maximum Pre-Set Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999.9 Units

Storage Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40–158º F (-40-70º C

Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–158º F (-20-70º C

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 AA alkaline or 4 AA lithium

Battery Life (3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Preset Models–six months, manual models–one year

Wetted Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Aluminum, sst, pbt/pc, nitrile rubber, cs

Fluid Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Petroleum- and synthetic-based oils and anti-freeze mixtures (not compatible with fuel and windshield washer fl uid)

Meter Pressure Loss

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 psi (12 bar) @ 14 gpm (53 lpm)

Accuracy

(2)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 0.5%

Repeatability ( 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±0.15 %

Dimension w/o Extension. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 in L x 3.75 in W x 5.75 in H, (33 cm x 9.5 cm x 14.6 cm)

Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313046

1. Tested in 10W oil at 70º F. Flow rates vary with fl uid pressure, temperature, viscosity, inlet fi tting and nozzle type.

2. At 2.5 gpm (9.5 lpm) @ 70º F (21º C) with 10 wt. oil and 1 gal (3.8 l) dispensed. May require re-calibration. Out-of-box accuracy ±1.25%.

3. Average shop use with alkaline batteries (included); 30-35% longer life with lithium AA

Matrix Meter

255200

Oil Bar

Components ordered separately. For complete unit, order oil bar 256719, kit 255370 (one per meter) and Matrix meters ( 257539) as needed

6

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

www.graco.com

Matrix

®

3

Fluid Management Systems

Tank Level Monitor

Choose one TLM for each bulk fl uid tank. Tank readings are automatic for used or new oil and anti-freeze products.

Tank Level Monitor

256285 Tank Level Monitor

Technical Specifi cations

Ultrasonic Tank Depth Measurement Range . . . . . 0 – 30 ft. (0-9 m) (Not recommended for use with pressurized tanks)

Fluid Level Measurement Accuracy*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 0.5%

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.34lb (1.06 kg)

Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -22° F - 122° F (-30° C - 50° C)

RF Operating Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40° F - 185° F (-40° C - 85° C)

Storage Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40° F - 185° F (-40° C - 85° C)

Ambient temperature range** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-22º F - 122º F (-30º C - 50º C)

Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (2) 9 VDC Alkaline only

Vertical Tanks . . . . . . . . . . . . . . . . . . . . . .Maximum volume: 999,999 gallons or liters, maximum height: 30 ft (360 in.)

Cylindrical Tanks . . . . . . . . . . . . . . . . . .Maximum volume: 999,999 gallons or liters, maximum diameter: 30 ft (360 in.)

Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FCC, Industry Canada (IC), C-Tick, CE

Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312964

Note: Do NOT use the Matrix Tank Level Monitor with gasoline, diesel fuel, or other fl ammable liquids, and materials with an auto ignition temperature below 419º F (215º C)

* The difference in air temperature between the inside and outside of the tank may affect the accuracy of fl uid levels

** Display will not function below 32º F (0º C)

Pump Air Control

One PAC required for each air pump. For safety and increased security, the PAC is a must have to maximize your fl uid management system. Designed to supply air to the pump only when Matrix authorizes the dispense.

Pump Air Control (PAC)

247435 23 scfm valve

247436 93 scfm valve

Technical Specifi cations

Operating Pressure Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-145 psi (1.7 - 10 bar)

Maximum Air Flow . . . . . . . . . . . . . . . . . . . . . . . . . 247435 - 23 SCFM (0.7m

3

/min), 247436 - 93 SCFM (2.6m

3

/min)

Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120-240 VAC line voltage, 24VDC solenoid

Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10mW - 100mW

AMPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1A

Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50/60 Hz

Operating Temperature Range* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32° F - 122° F (0° C - 50° C)

Enclosure Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NEMA Type 3

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247435 - 2.8 lbs (1.27 kg), 247436 - 3.4 lbs (1.5 kg)

Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312417

* The difference in air temperature between the inside and outside of the tank may affect the accuracy of fl uid levels. Display will not function below 32º F (0º C).

Tank Accessories

CleanLine Filter Assemblies

248421 900 psi tank mount CleanLine™ fi lter assembly (includes thermal relief)

248418 900 psi wall mount CleanLine fi lter assembly (includes thermal relief)

248419 1800 psi tank mount CleanLine fi lter assembly

248417 1800 psi wall mount CleanLine fi lter assembly

Replacement Filters

15D702 900 psi CleanLine screw-on type fi lter

119278 1800 psi CleanLine fi lter element

Tank Level Monitor

256285

Pump Air Control

247436

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

7

Horizon

Fluid Management System

Features and Benefi ts

• Allows multiple technicians to dispense simultaneously

• Easily confi gured and expandable for any facility

• Increases technician productivity

• Password-protected to prevent unauthorized dispensing

• Tracks inventory levels and alerts operators to low inventory conditions to minimize out-of-stock situations

Typical Applications

• Bulk-dispensing to multiple service bays

• Automotive dealerships

• Heavy-duty dealerships

• Fleet service facilities

Typical Fluids Handled

• Petroleum- and synthetic-based oils

• Anti-freeze

Technical Specifi cations

System Specifi cations

Control Modules on a System (1 Master only, plus 39 Slaves) ........... 40 maximum

Keypads on a System (1 keypad per Control Module) ....................... 40 maximum

Solenoids on a System (40 Control Modules, 6 ports each) ............. 240 maximum

Meters on a System (40 Control Modules, 6 ports each) ................. 240 maximum

Fluids on a System ........................................................................... 10 maximum

Dispense Areas (reel banks) .............................................................. 99 maximum

Operator Names / PIN Numbers ...................................................... 100 maximum

Dispense Records Stored................................................................ 668 maximum

Simultaneous Dispenses (same and/or different fl uids): .................... 12 maximum

Jobs Waiting in Queue ...................................................................... 12 maximum

Printer per System OR Attached Computer per System ......................... 1 maximum

(either must be connected to Master Control Module)

Accuracy of System .................................................................................. ±0.6%

Control Module Ports

Solenoid Ports (air or fl uid) per Control Module .................................................... 6

Pulse Meter Ports per Control Module ................................................................ 6

Port for Keypad per Control Module .................................................................... 1

Port for Printer or Computer per Master Control Module ...................................... 1

Voltage Input

90-120 Volts AC, 50/60 Hz, single phase, 2 amps maximum draw

208-240 Volts AC, 50/60 Hz, single phase, 1 amp maximum draw

Operating Temperature Range................................40 - 140º F (4 - 60º C) ambient

Pre-set or Free-fl ow Options

Maximum Preset or Free-Flow Dispense .............................................. 999.9 units

Minimum Preset Dispense ...................................................................... 0.5 units

Units of Measure

Dispense .........................liters, quarts, gallons or pints (confi gurable for each fl uid)

Inventory ..........................liters or gallons (dependent upon dispense units chosen)

Maximum Cable Lengths

From Keypad to Control Module .......................................................50 ft (15.3 m)

From Solenoid to Control Module .....................................................50 ft (15.3 m)

From Pulse Meter to Control Module ................................................50 ft (15.3 m)

From Printer/Computer to Master Control Module .............................50 ft (15.3 m)

From one end of the Control Module Network to the other end (daisy-chained) .......

...................................................................................................2000 ft (610 m)

Reference Data

Instruction Manual .................................................................................. 308607

8

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

www.graco.com

Horizon

Components and Accessories

Ordering Information

Control Module drives air and fl uid solenoids, and counts pulses from meters. On-board memory contains a map of available system resources, and a power supply that supports both 120 and 240 Volt AC operation. Combine one Master Control Module with up to 39 Slave Control Modules per system.

238624 Master Control Module (one per system)

238625 Slave Control Module (up to 39 per system)

Keypads: Basic, Enhanced and Administrative

113551 Basic Keypad for navigating through the Horizon’s menus

113553 Administrative Keypad is needed to set up and make changes to the system parameters

191368 Keypad Wall-Mounting Bracket

Air Solenoids open and close the air supply to the fl uid pump air motor. Each solenoid can be up to 50 ft (15.3 m) from a Control Module. Up to 6 solenoids (air or fl uid) can be connected to each Control Module.

215407 For pumps requiring normal air fl ow (Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1)

512926 For pumps requiring higher air fl ow (Fire-Ball 425, 6:1 and 3:1)

Fluid Solenoids start and stop the fl uid dispense cycles. These must be placed at each dispense point for each fl uid being dispensed. Each fl uid solenoid can be up to 50 ft (15.3 m) from a control module. Up to 6 solenoids

(either air or fl uid) can be connected to each control module. The low-fl ow model is available in a kit with a ready light which alerts the operator when the job is ready to dispense.

215487 Low-fl ow: supports 3 gpm (11.4 lpm)

512927 Higher-fl ow: supports up to 6 gpm (22.7 lpm)

514150 Anti-Freeze Solenoid

218588 Low-fl ow Solenoid with Ready Light Kit

238996 Ready Light Kit (only; less the solenoid)

Pulse Meters measure fl uid fl ow to dispense points and send a train of pulses back to the Control Modules which are counted to determine how much fl uid has been dispensed. If there are multiple meters for a single fl uid, check valves ( 111620) should be placed in series with each meter to prevent “cross talk” and oscillations. Pulse Meters can be used for either U.S. or metric units.

238618 For oils, gear lube, automatic transmission fl uid

215474 For anti-freeze

111620 Check Valve, 1/2 in

Thermal Relief Kits

235998 600 psi (41 bar)

102527 Thermal Relief Valve, 900 psi (62 bar)

237893 900 psi (62 bar)

240429 1600 psi (110 bar)

System Printer prints job tickets after each dispense is complete, plus has save function for later analysis

113774 Printer

514037 Printer paper, 1 roll

Keypad or Printer Cables

191393 25 Ft (7.6 M) cable with connectors

191394 Cable with connectors. 50 Ft (15.3 M)

Control Module Network

113559 500 Ft (152.5 M) bulk cable

113560 1000 Ft (305 m) bulk cable

Pulse Meter Cable

113555 Length: 500 ft (152.5 m)

113556 Length: 1000 ft (305 m)

Solenoids Cable

113557 Length: 500 ft (152.5 m)

113558 Length: 1000 ft (305 m)

Computer Cable with Connectors

192873 Computer I/O 25 ft (7.6 m)

192874 Computer I/O 50 ft (15.3 m)

www.graco.com

113553

238624

215487

113774

113551

215407

238618

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

9

Fluid Commander

Fluid Management System

Features and Benefi ts

• Provides increased accuracy over mechanical counters

• PIN code prevents unauthorized dispensing

• Dispense totals tracked by location

• Easy to read display

• Accurate controlled dispense with parts room authorization

Typical Applications

• Parts room authorized dispensing for inventory control

• Automotive dealerships

• Heavy-duty dealerships

• Fleet service facilities

Typical Fluids Handled

• Petroleum- and synthetic-based oils

• Anti-freeze

Technical Specifi cations

Maximum Number of Fluids ........................................................................ 1 or 2

Dispense Stations/Bays ............................................................................ 6 or 12

Air Solenoids Required .................................................................... 1 (per pump)

Fluid Solenoids Required ........................................... 1 (per fl uid dispense station)

Electrical Requirements .................................................... 120 V, 60 Hz, .25 amps

Weight .................................................................................... 4 lb, 5 oz. (8.0 kg)

Wiring Requirements ......................................................................... 90V; 2-wire

Distance/Gauge .....200 ft (61 m) = 18 gauge, 201 to 500 ft (61 m to 152 m) = 16 gauge, ...........................................................501 ft (152 m) or more = 14 gauge

Instruction Manual ................................................................................. 308238

Easy to Use

1. Service technician enters the service bay number, type of product, and amount to be dispensed, then activates the dispense button.

2. A “ready” light (located on the hose reel or dispense bar of the target service bay) signals when dispensing can begin.

3. As fl uid is dispensed, the Fluid Commander tallies the amount dispensed and shuts-off when the pre-set amount is reached.

No further dispensing takes place until new dispensing data is entered.

Typical Fluid Commander System Layout

10

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

A. Control*

B. Pressure Relief Kit**, 237893, 1-1/2 npt (m x f)

C. Supply Tank

D. Air Shutoff Valve, bleed-type

E. Air Filter

F. Air Solenoid Valve, 215407*

G. Air Regulator, 202156

H. Pump

J. Flexible Hose, 3-6 ft (0.9-1.8 m) long

K. Check Valve, 111620 (required)*

L. Fluid Filter, 223179

M. Pulse Meter, 236763 or 236764

N. Fluid Shutoff Valve, 108458, 1/2"

P. Fluid Solenoid Valve***, 215487*

Q. Hose Reel

R. Ready Light, 238996***

S. Dispense Valve

*These parts are included with model 232076, 240448, or 241905

** Kit required to protect system from rupture due to thermal expansion of fl uid lines. See instruction manual 308403.

** *218588 includes 238996 and 215487.

Note: For tank packages, pressure reliefs from instruction manual 308403 must be installed on outlet with pressure going either back to vent into the tank or to a container installed under the exit or relief valve.

www.graco.com

Fluid Commander

Fluid Management System

Ordering Information

Fluid Commander Systems

232076

240448

U.S. Measure Fluid Commander System for 2 products and 6 stations. Includes: One 2-product/6station Fluid Commander ( 235532), oil meter ( 236763), fl uid solenoid valve ( 215487), air solenoid valve ( 215407), Check valve ( 111620).

Metric Measure Fluid Commander System for 2 products and 6 stations. Includes: One 2-product/6station Fluid Commander ( 232077), oil meter ( 236764), Fluid Solenoid valve ( 215487), Air Solenoid valve ( 215407), check valve ( 111620).

Accessories

111620 Check valve

236763 Electronic Pulse Meter (quarts)

236764 Electronic Pulse Meter (liters)

215474 Mechanical Pulse Meter (quarts)

215745 Mechanical Pulse Meter (liters)

244342

Meter Pulse Converter, used when upgrading old-style modular fl uid commander to electronic allows use of 215474/ 215475 with the EFC. Instruction manual 309276

Air Solenoid Valves

215407

Air Solenoid Valve, 150 psi (10 bar) (1/2 npsm(f) conduit ports for wiring; 1/4 npt(f) air ports, adapted to 3/8(f) IN, 3/8(m) OUT) operates on 24V DC and 110 VAC. Automatically shuts-off air inlet to pump when pre-set dispensed amount is reached. Materials of construction: brass, SST, Buna.

105474

Air Solenoid Valve (bare) 150 psi (10 bar), same as 215407 but without wire connectors or adapters.

1/2 npsm(f) conduit ports for wiring; 1/4 npt(f) air ports.150 psi (10.3 bar) max. working pressure.

Fluid Solenoid Valves

215487

Fluid Solenoid Valve, 1/2 npt(f) 3000 psi (207 bar) operates on 24V DC. Automatically shuts-off fl uid when pre-set dispensed amount is reached. Includes tube, valve, pin connector, wire plug connector and adapter.

514150 Fluid Solenoid Valve for anti-freeze, 150 psi max. (10 bar), 1/2 npt(f), same as features as 215487

110025

Bare Fluid Solenoid Valve, 1/2 npt(f) 3000 psi, same features as 215487 above, but without wiring connectors or adapters.

Ready-Light Kits

218588

Ready-Light Kit, signals operator when dispensing can begin. Includes “ready to dispense” Indicator

Light ( 239019), Strainer ( 240417), Fluid Solenoid Valve ( 215487) and hardware. Manual 307696.

238996 Ready-Light with Junction Box (no solenoid or strainer)

239019 Ready-to-Dispense Indicator Light only

113859 Lamp for Indicator Only

Installation Components

223179 Fluid Filter Kit (for bare electronic meter)

186472 Wall-Mounting Bracket

108458 Fluid Shut-Off Valve

237893

Thermal Relief Kit for 900 psi (62 bar), relieves excess heat-induced pressure from dispense system.

Male and female ends allow for simple installation. Instruction manual 308403.

Connecting Cables for Connecting Solenoids and Consoles. 90-volt, 2-wire, 18-gauge.

215481 100 ft (30.5 m) pre-connected at both ends

215407

215487

215481

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

F L U I D M A N A G E M E N T

11

Oil Pumps Quick Reference

Technical Specifi cations and Selection Chart

Manuals:

Fast-Ball 307906

Fire-Ball 309869

Cycles per

Gallon

Fluid Flow gal/min

@ 80 cpm

Maximum

Fluid

Pressure

Air Motor

Effective

Diameter

Air Operating

Range

Approx. Air Use and Flow @ 100 psi and 80 cpm

Wetted

Materials

Air Inlet

Port

Size

Fluid

Inlet

Port Size

Fluid

Outlet

Port Size

Fast-Ball, 1:1*

10

(45.5 liters)

5

(19 liters)

180 psi

(12.5 bar)

1.4 in

(35.6 mm)

40-180 psi

(2.7-12.5 bar)

5 scfm

CS,

Polyurethane

1/4 in npt(f)

1-1/2 in npt(f)

3/4 in npt(f)

12

Line Length‡: Up to 100 ft (30.5 m)

Annual Usage: Up to 5,000 gal (19,000 l)

Dispense Points: 1 (not recommended with hose reel)

Typical Applications: Continuous duty, maintenance facility dispensing motor oil, automatic transmission fl uid, hydraulic fl uid

Mini Fire-Ball 225, 3:1

43.5

(11.4 liters)

1.84

(7.0 liters)

540 psi

(37 bar)

2.25 in

(57.2 mm)

40-180 psi

(2.8-12 bar)

8.5 scfm @ 2.1 gpm,

(0.241 m3/min

@ 7.9 lpm)

Steel, Buna-N,

Polyurethane,

Aluminum,

Rulon

®

3/8 in npt(f)

1-1/2 in npt(f)

1/2 in npt(f)

Line Length ‡ : Up to 250 ft (76.2 m)

Annual Usage: Up to 6,500 gal (24,602 l)

Dispense Points: 1 to 2

Typical Applications: Continuous duty, maintenance facility dispensing motor oil, gear oil, automatic transmission fl uid, hydraulic fl uid

Fire-Ball 300, 5:1

28.4

(8.6 liters)

2.8

(9.3 liters)

900 psi

(62 bar)

3 in

(76.2 mm)

40-180 psi

(2.8-12 bar)

27 scfm @ 3 gpm

(0.765 m 3 /min

@ 11.5 lpm)

Steel,

Polyurethane,

Aluminum,

Buna-N

3/8 npt(f) 1-1/2 npt(f) 1/2 npt(f)

Line Length ‡ : Up to 500 ft (152.5 m)

Annual Usage: Up to 30,000 gal (114,000 l)

Dispense Points: 1 to 3

Typical Applications: Continuous duty, maintenance facility dispensing motor oil, gear oil, automatic transmission fl uid, hydraulic fl uid

Fire-Ball 425, 3:1

6

(1.6 liters)

13.4

(50.6 liters)

540 psi

(37 bar)

4.25 in

(107.9 mm)

40-180 psi

(2.8-12 bar)

58 scfm @ 13.4 gpm

(1.64 m

3

/min

@ 50.6 lpm)

Steel,

Polyurethane,

Aluminum,

Nitrile

1/2 in npt(f)

1-1/2 in npt(f)

3/4 in npt(f)

Line Length ‡ : Up to 250 ft (76.2 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 3 to 4

Typical Applications: High fl ow, low pressure maintenance facility dispensing motor oil, gear oil, automatic transmission fl uid, hydraulic fl uid

Fire-Ball 425, 6:1

12

(3.2 liters)

6.6

(25.3 liters)

1100 psi

(76 bar)

4.25 in

(107.9 mm)

40-180 psi

2.8-12 bar)

49.5 scfm @ 6.8 gpm

(.334 m 3 /min

@ 25.7 lpm)

Steel,

Polyurethane,

Aluminum,

Nitrile

1/2 in npt(f)

1-1/2 in npt(f)

3/4 in npt(f)

Line Length ‡ : Up to 500 ft (152.5 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 3 to 4

Typical Applications: High fl ow, medium pressure, maintenance facility dispensing motor oil, gear oil, automatic transmission fl uid, hydraulic fl uid

Fire-Ball 425, 10:1

19.6

(5.2 liters)

4.1

(15.4 liters)

1800 psi

(124 bar)

4.25 in

(107.9 mm)

40-180 psi

2.8-12 bar)

32 scfm @ 4.1 gpm

(.555 m 3 /min

@ 15.4 lpm)

Steel,

Polyurethane,

Aluminum,

Nitrile

1/2 in npt(f)

Line Length ‡ : Up to 750 ft (228.6 m)

Annual Usage: Over 30,000 gal (114,000 l)

1-1/2 in npt(f)

Dispense Points: 3 to 4

Typical Applications: Long distance, maintenance facility dispensing motor oil, gear oil, automatic transmission fl uid, hydraulic fl uid

3/4 in npt(f)

‡ Consult your local authorized Graco representative for line or pipe sizing

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

www.graco.com

Oil Pumps Quick Reference

Technical Specifi cations and Selection Chart

See NXT Ordering Information for Instruction Manuals

Output

Per Cycle

Output at

60 CPM* gpm (lpm)

Maximum Fluid

Pressure psi (bar)

Motor Size

Maximum Air

Input Pressure psi (bar)

www.graco.com

Dura-Flo, 6:1

1000 cc 17.4 (65.9) 620 (42.7) NXT 3400 100 (6.9)

Line Length

: Up to 500 ft (152.5 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 3 to 4 (simultaneous) automatic transmission fl uid and hydraulic fl uid

Dura-Flo, 10:1

1000 cc 17.4 (65.9) 1180 (81.3) NXT 6500 100 (6.9)

Line Length

: Up to 750 ft (228.6 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 3 to 4 (simultaneous) automatic transmission fl uid and hydraulic Fluid

Dura-Flo, 12:1 Carbon Steel or Dura-Flo, 12:1 Stainless Steel

580 cc 9.2 (34.8) 1190 (82.1) NXT 3400 100 (6.9)

Line Length

: Up to 1000 ft (304.8 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 2 to 3 (simultaneous) automatic transmission fl uid and hydraulic fl uid

Dura-Flo, 23:1

580 cc 9.2 (34.8) 1725 (118.9) NXT 6500 75 (5.2)

Line Length

: Up to 1000 ft (304.8 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 2 to 3 automatic transmission fl uid and hydraulic fl uid

High-Flo, 3.5:1

2000 cc 31.5 (119.2) 350 (24.1) NXT 3400 100 (6.9)

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 4 to 5 automatic transmission fl uid and hydraulic fl uid

High-Flo, 4.5:1

1500 cc 23.2 (87.8) 450 (31) NXT 3400 100 (6.9)

Line Length

: Up to 450 ft (137.1 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 4 to 5 automatic transmission fl uid and hydraulic fl uid

High-Flo, 6:1

2000 cc 31.5 (119.2) 500 (34) NXT 6500 75 (5.2 )

Line Length

: Up to 500 ft (152.5 m)

Annual Usage: Over 30,000 gal (114,000 l)

Dispense Points: 4 to 5 automatic transmission fl uid and hydraulic fl uid

*Graco recommends 20 cpm or less for supply applications ‡ Consult your local authorized Graco representative for line or pipe sizing

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

13

Fast-Ball

®

1:1

Air-Operated Piston Pumps and Packages for Oil

Features and Benefi ts

• In-line design with fewer parts for less pump wear

• Differential air motor ensures smooth pumping

• Double-acting pump provides reliable fl uid fl ow

Typical Applications

• Lubricant transfer

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers

• Fleet service facilities

• Service shops

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Petroleum- and synthetic-based oils

(8.3)

80

(5.5)

40

(2.7)

20

(1.4)

0

gpm

(lpm)

Pump Performance psi

(bar) cycles/min scfm

(m3/min)

100 10

(0.3)

8

(0.23)

6

(0.17)

4

(0.12)

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

=40 psi

(2.8 bar)

1 2 3 4

(3.8) (7.6) (11) (15)

2

(0.08)

TEST FLUID: No. 10 Weight Oil

222602

239702

Ordering Information

Package

Container Size

Package No.

Pump

Dispense Kit

Regulator Assembly

Hose

Hose Length

Bung Adapter

Instruction Manual

Non-Metered

Dispense

55 gal (200 l)

222602

222103

218115

218316

109125

6 ft (1.8 m)

222308

307637

U.S./Metric

Metered Dispense

55 gal (200 l)

239702

222103

239703

218316

222308

307637

Bung-Mounted

55 gal (200 l)

222103

222103

222308

307906

Bung-Mounted

275 gal (1040 l)

222104

222104

222308

307906

222103

Universal

Universal

222051

222051

307906

222104

222051

14

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

www.graco.com

Mini Fire-Ball

®

225, Fire-Ball 300 and Fire-Ball 425

Air-Powered Piston Pumps and Packages for Oil

Features and Benefi ts

• Non-corrosive air motor design for long life (metal parts made of

SST, aluminum and chrome)

• No metal-to-metal contact means longer pump life and ensures pump will withstand harsh environments

• Double-acting pump provides reliable fl uid fl ow

• Few moving parts translates into low maintenance and low cost of ownership

• Open exhaust port provides continuous operation without icing

Typical Applications

• Medium to low volume and pressure lubricant transfer

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers and service shops

• Fleet service facilities

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Petroleum-and synthetic-based oils

Mini Fire-Ball 225, 3:1 Performance Chart

248230

psi

(bar)

500

(31.4)

400

(21)

300

(10.4)

200

(5.2)

100

(5.2) cycles/min

0

1 2 3 4

(lpm) (3.8) (7.6) (11.4) (15)

0

TEST FLUID: No. 10 Weight Oil scfm

(m3/min)

40

(0.3)

32

(0.23)

24

(0.23)

16

(0.17)

8

(0.12)

Inlet Air Pressures:

= 100 psi

(6.9 bar)

= 70 psi

(4.8 bar)

= 40 psi

(2.8 bar)

Fire-Ball 300, 5:1 Performance Chart

246775

psi

(bar)

26 53 80

(31.4)

300

(21)

150

(10.4)

75

(5.2)

0

gpm

(lpm) cycles/min

107 scfm

(m3/min)

10

(0.3)

8

(0.23)

6

(0.17)

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

=40 psi

(2.8 bar)

4

(0.12)

1 2 3 4

(3.8) (7.6) (11) (15)

2

(0.08)

TEST FLUID: No. 10 Weight Oil

Fire-Ball 425, 6:1 Performance Chart

238108

psi

(bar)

800

(55)

600

(41)

400

(27)

200

(13)

0

gpm

(lpm) cycles/min

2 4 6 8

(7.6) (15.4) (22.7) (30.3)

0

TEST FLUID: No. 10 Weight Oil

40

(1.1)

20

(0.6) scfm

(m3/min)

80

(2.2)

60

(1.7)

Inlet Air Pressures:

= 100 psi

(6.9 bar)

= 70 psi

(4.8 bar)

= 40 psi

(2.8 bar)

www.graco.com

Fire-Ball 425, 3:1 Performance Chart

250

(27)

150

(13)

50

gpm

(lpm) psi

(bar)

450

(55)

350

(41) cycles/min

2 6 10 14

(7.5) (23) (38) (53)

0

TEST FLUID: No. 10 Weight Oil

45

(1.2)

30

(0.9)

15

(0.4) scfm

(m3/min)

60

(1.7)

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

=40 psi

(2.8 bar)

237526

Fire-Ball 425, 10:1 Performance Chart

205626

psi

(bar)

1800

(125)

20

1400

(96)

1000

(70)

40 cycles/min

60 80 scfm

(m3/min)

100 80

(2.2)

60

(1.7)

40

(1.1)

Inlet Air Pressures:

= 100 psi

(6.9 bar)

= 70 psi

(4.8 bar)

= 40 psi

(2.8 bar)

600

(42)

200

(14)

(lpm)

1

(3.8) (7.6) (11.4) (15) (19)

0

TEST FLUID: No. 10 Weight Oil

20

(0.6)

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

15

Mini Fire-Ball

®

225, Fire-Ball 300 and Fire-Ball 425

Air-Powered Piston Pumps and Packages for Oil

16

Universal Supply

Cover-mounted

Bung-mounted

Portable

Mini Fire-Ball 225 and Fire-Ball 300 Ordering Information

Packages Portable Cover-Mounted Bung-Mounted Universal

Container Size 16 gal (60 l) 16 gal (60 l)

55 gal

(200 l)

55 gal

(200 l)

275 gal

(1040 l)

Universal

Mini Fire-Ball

225, 3:1 Package

Mini Fire-Ball, 225

3:1 Pump

Fire-Ball 300,

5:1 Package

Fire-Ball 300

Pump

Dispense/Hose

Fitting Kit

246903

248097

225728

203872

237075

(4)

(1), (3)

(2), (4)

246904

248097

225094

(1), (3)

(3), (4)

203872

222063

(4)

246906

(1), (3)

225642

203857

222063

(4)

248097

(3), (4)

246907

248097

225640

(3), (4)

(1), (3)

(3), (4)

204254

222063

Fluid Hose

Air Hose

6 ft x 1/2 in

(1.8 m x

12.7 mm)

6 ft x 1/2 in

(1.8 m x

12.7 mm)

6 ft x 3/8 in

(1.8 m x 9.5 mm)

224512

204574

6 ft x 1/2 in

(1.8 m x

12.7 mm)

6 ft x 3/8 in

(1.8 m x

9.5 mm)

224512

200326

6 ft x 1/2 in

(1.8 m x

12.7 mm)

6 ft x 3/8 in

(1.8 m x 9.5 mm)

Air Regulator

Cover

224512

204574

Caster Base

Bung Adapter for

300, 5:1

225, 3:1 Manual

203622

309868 309868 309868

300, 5:1 Manual 307884 307883 307883

(1)

248097 includes suction tube ( 15C502) and bung adapter ( 222308)

(2) Use 3/8 in (9.5 mm) installation kit ( 224512) as required

(3) Use 3/8 in (9.5 mm) air regulator 109075 as required; must be ordered separately

(4)

Order low-level cut-off 203688 (1 1/2 inch NPT) separately for metered dispense systems

222308

309868

307883

246907

248097

225931

(3), (4)

(1), (3)

(3), (4)

222087

222063

6 ft x 1/2 in

(1.8 m x 12.7 mm)

6 ft x 3/8 in

(1.8 m x 9.5 mm)

222308

309868

307883

248230

1.5 ft x 1/2 in

(0.5 m x 9.5 mm)

1.5 ft x 3/8 in

(0.5 m x 9.5 mm)

(3), (4)

246775

225852

203876

222062

309868

306520

Fire-Ball 425 Ordering Information

Packages

Container Size

Fire-Ball 425, 3:1 Package

Fire-Ball 425, 3:1 Pump

Fire-Ball 425, 6:1 Package

Fire-Ball 425, 6:1 Pump

Fire-Ball 425, 10:1 Package

Fire-Ball 425, 10:1 Pump

Hose/Fitting Kit

Fluid Hose

Air Hose

Cover-Mounted

55 gal (200 l)

225782 (1) (2)

222065

222066

6 ft x 3/4 in

(1.8 m x 19.05 mm)

6 ft x 1/2 in

(1.8 m x 12.7 mm)

Bung-Mounted

55 gal (200 l)

225786 (1) (2)

222095

222066

6 ft x 3/4 in

(1.8 m x 19.05 mm)

6 ft x 1/2 in

(1.8 m x 12.7 mm)

Universal Supply

Universal

225853 (1) (2)

205626

222068

1.5 ft x 3/4 in

(0.5 m x 19.05 mm

)

1.5 ft x 1/2 in

(0.5 m x 12.7 mm)

Wall-Mounted

Universal

244846

( 3)

237526

244628

(3)

238108

244847

205626

222068

1.5 ft x 3/4 in

(0.5 m x 19.05 mm

)

1.5 ft x 1/2 in

(0.5 m x 12.7 mm)

Cover

Filter Regulator

Air Shutoff Valve

200326

217072

110225

Fluid Shutoff Valve

Wall Mount Bracket

108537

238245

Instruction Manual 307883 306520 309351

(1) Use 1/2 in (12.7 mm) air regulator ( 104266) and air pressure gauge ( 100960) as required; must be ordered separately—see mounting accessories section

(2)

Order low-level cut off ( 203688) separately for metered dispense systems—see mounting accessories section

(3) Includes pump plus: Filter Regulator ( 217072), Hose and Fitting Kit ( 222068), Air Shutoff Valve ( 110225), Fluid Shutoff ( 108537), Wall Mount Bracket, ( 238245)

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

www.graco.com

Oil Pump Accessories

Air-Operated Piston Pumps and Packages for Oil

Hose and Fittings Kits for Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 Pumps

222062

222063

18 in (0.5 m) for connecting wall-mounted Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 pumps to piping. Includes air hose ( 204560) with swivel elbow ( 155494), fl uid hose ( 220598) with swivel elbow

( 155470). Instruction manual 306520.

6 ft (1.8 m) for use with drum-mounted Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 pumps.

Includes air hose ( 203320) with swivel elbow ( 155494), fl uid hose ( 220591) with swivel elbow

( 155470). Instruction manual 307883.

Dispense Kits for Mini Fire-Ball 225, 3:1 and Fire-Ball 300, 5:1 Pumps

237075

6 ft (1.8 m) for use with portable lubricators powered by the Fire-Ball 300, 5:1. Includes fl uid hose

( 220591) and SDM5 gear lube valve ( 255349). Instruction manual: 307884.

Hose and Fittings Kits for Fire-Ball 425, 3:1, 6:1 and 10:1

222068

18 in (0.5 m) for connecting wall-mounted Fire-Ball 425, 10:1 pumps to piping. Includes air hose

( 218093) with swivel elbow ( 155470), fl uid hose ( 109108) with swivel elbow ( 160327). Instruction manual: 306520.

238246

222066

24 in (0.6 m) for use with Fire-Ball 425, 3:1 and 6:1 wall-mounted pumps to piping. Includes air hose

( 218093) with swivel elbow ( 155470), fl uid hose ( 238247) with swivel elbow ( 160327).

6 ft (1.8 m) for use with drum-mounted Fire-Ball 425, 10:1 pumps. Includes air hose ( 205418) with swivel elbow ( 155470), fl uid hose ( 109105) with swivel elbow ( 160327). Instruction manual: 307883.

Suction Kits

236054

6 ft (1.8 m) Suction Kit for 55-gal. (200 l) drums. Includes: 55-gal. (200 l) drum tube, bung adapter and 6 ft (1.8 m) of 3/4 in fl uid hose with 3/4 in ID x 1-1/2 in bushing to adapt to any universal Graco oil pump. Allows use of Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 or Fire-Ball 425, 10:1 universal pumps with barrels. Order wall brackets separately. Use with low-level cut-off ( 203688) when metering fl uids. Instruction manual: 308335.

Drum Covers

200326

Cover for open-head 55 gal (200 l) drums. Use with Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 or

Fire-Ball 425, 10:1 pump. Use adapter 160754 for cover-mounting bung-style pumps.

204574

222058

Cover for open-head 16 gal (60 l) or 70 lb (32 kg) drums. Mounts Fast-Ball 1:1, Mini Fire-Ball or

Fire-Ball pumps.

Cover for 5 gal (20 l) pails. Mounts Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and 15:1 pumps. Bung adapter ( 222308) and bung adapter plate ( 160754) sold separately.

160754

Bung-adapter plate for 55 gal (200 l) or 16 gal (60 l) covers. Mounts to 55 gallon (400 lb; 200 l),

16 gal (120 lb; 60 l) drum or 5 gal (20 1) pail covers and converts mounting to standard 2 npt bung opening. Allows use of bung-mounted pumps with drum covers.

Wall-Mounting Brackets

203987

For universal Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and Fire-Ball 425, 10:1 pumps.

Clamps onto universal pump tube.

238245 For use with Fire-Ball 425, 3:1, 6:1 and 10:1 pumps. Mounts directly to pump fl ange.

236778

For use with Fire-Ball 425, 3:1, Dyna-Star 1/4:1 and Power-Star 1:1 pumps. Clamps to pump tube and provides mounting to wall surface by fl ange.

Clamps

203156

210880

Open-drum pump clamp. Attaches to side of open-head drum and mounts on any size pump except

Fire-Ball 425, 3:1.

Open-drum pump clamp for Fire-Ball 300, 5:1 and Fire-Ball 425, 10:1 pumps. Clamps onto pump tube and attaches to open-drum lip.

Tools for Working on Fire-Ball Air Motors

207579 Padded pliers

171818 Poppet gauge

168085 Insert tool

203987

203156

210880

200326

204574

160754

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

17

Oil Pump Accessories

Air-Operated Piston Pumps and Packages

Carts

203650

Cart for 5, 10 and 16 gal (20, 40, and 60 l) drums. Drums fi t into recess on formed base. Rim clamps secure drum to cart. Use with pail clamp ( 159952) when using cart with 5 gal (20 l) pails.

222243

Heavy-Duty Cart with Pneumatic Wheels for 120 lb (55 kg) drums. Used for moving lubrication equipment over rough terrain. Requires: Hold down kit ( 222061).

111470 55 gal (200 l) Drum Truck. Heavy-duty drum truck secures 55 gal (200 l) drum on roll-around base.

Portable Bases

205054 Band Dolly for 5 gal (20 l) pails (11-1/2 in ID)

204144 Band Dolly for 10 and 16 gal (40 and 60 l) drums (14 in ID)

203622 Caster Base for 5, 10 and 16 gal (20, 40 and 60 l) drums

Drum Elevator

241663

Air-powered elevator to speed-up 55 gal (200 l) drum changes. Maximum raised height is 39.5 in

(100.3 cm). Includes cover support ( 207562), drum elevator ( 204385), and air control kit ( 207561).

Suction Tubes For Pumps

238592

For 16 gal (60 l) cover-mounted Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and Fire-Ball

425, 10:1. Use bung adapter 222308 on all current production models. Includes ( 191126) 14-1/2 in

(0.36 m) extension ( 110127) foot spacer

238593 For 55-gal (200 l) cover-mounts. Includes ( 191128) 21-3/4 in (0.55 m) extension ( 110127) foot spacer.

238595

For 55 gal (200 l) bung-mounted Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300, 5:1 and Fire-Ball

425, 10:1. Use bung adapter 222308 on all current production models. Includes (191130) 26 in (0.66 m) extension ( 110127) foot spacer.

238596 For 275-gal (1100 l) bung-mounts. Includes ( 191131) 36 in (0.91 m) extension ( 110127) foot spacer.

15C502 Universal Down Tube 1-1/2 in tube marked for standard container lengths from 20-41 in (0.51-1.04 m)

Bung Adapters

222308

For Fast-Ball 1:1; Mini Fire-Ball 225, 3:1; Fire-Ball 300, 5:1; and Fire-Ball 425, 10:1 Pumps. Allows direct mounting of all universal length and extended Fast-Ball 1:1, Mini Fire-Ball 225, 3:1, Fire-Ball 300,

5:1 and Fire-Ball 425, 10:1 pumps into standard 2 npt drum bung.

238125

214583

For Mini Fire-Ball 225, 3:1; Fire-Ball 300, 5:1; and the Fire-Ball 425, 10:1. Includes double tap bushing

(191075), 1 ft 3/8 in hose (238370), and 90º 3/8 in adapter ( 155494) for mounting universal pumps to tanks (see 308403 for details).

For Fast-Flo 1:1 Pumps, allows direct mounting of full-length pump into standard 2 npt drum bung.

Comes with bushing sleeve ( 172405).

187754 Acetal Bung Adapter includes ( 100220) thumbscrew (for Fire-Ball 300, 15:1 SST undercoating pump)

176684 Bung Adapter for Suction Kit ( 203992). Includes ( 100220) thumbscrew.

Sealed Bung Adapters (prevents rain water and other fl uids from entering drum when pump is outdoors.)

204076

224579

203688

Sealed bung adapter for full-length Fire-Ball with 2-1/8 in (53.9 mm) bung and Mini Fire-Ball 225, 3:1

(2.140 inch diameter)

Sealed bung adapter for universal length Fire-Ball pumps, 2.159 inch diameter (will not fi t Mini Fire-Ball

225, 3:1 or old style pumps with bottom foot valve).

217359 Sealed bung adapter for Fast-Flo pumps; can be used with suction kit 236054

Low-Level Cut-Offs (Prevents air from entering pump by closing intake when fl uid supply to pump is exhausted.

Can be used with suction hose kit or standard suction tube without changing tube length.)

Low-level cut-offs for Fast-Ball and Fire-Ball pumps that have a universal design with suction tube extension supplying metered outlets; replaces stand-off suction tube; 1.5 npt (f) inlet. 3 in (76 mm) h.

111470

204144

3"

241663

203650

203622

203688

18

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

www.graco.com

Oil Pump Accessories

Air-Operated Piston Pumps and Packages

Thermal Relief Valve Kits (includes valve, hose and fi ttings)

235998 Mini Fire-Ball 225, 3:1 thermal relief valve rated to 600 psi (41 bar)

237893 Fire-Ball 300, 5:1 and Fire-Ball 425, 6:1 thermal relief valve rated to 900 psi (62 bar)

248296

Fire-Ball 300, 5:1 and Fire-Ball 425, 6:1 thermal relief valve rated to 900 psi (62 bar) (same as 237893 minus bung adapter and swivel. Includes 6 foot hose).

237601 Fire-Ball 425, 3:1 thermal relief valve rated to 600 psi (41 bar)

240429 Fire-Ball 425, 10:1 thermal relief valve rated to 1600 psi (110 bar)

248324

Fire-Ball 425, 10:1 thermal relief valve rated to 1600 psi (110 bar) (same as 240429 minus bung adapter and swivel. Includes 6 foot hose).

238899 Diaphragm pump thermal relief valve rated to 150 psi (10.4 bar)

112353 Diaphragm pump thermal relief valve for fuel dispense; rated to 50 psi (3.4 bar), valve only

Bleed-Type Air Shut-Off Valves (rated to 250 psi [17.4 bar]) Female ends

110223 1/4 in (6.4 mm)

110224 3/8 in (9.5 mm)

110225 1/2 in (12.7 mm)

110226 3/4 in (19.1 mm)

Fluid Shut-Off Valves (rated to 2000 psi [138 bar]) For isolating oil dispense lines.

108458 1/2 in (12.7 mm)

240418 3/8 in (9.5 mm)

108537 3/4 in (19.1 mm)

110314 1 in (25.4 mm)

240417

Fluid T-Strainers 60 Mesh Strainer, 750 psi (51 bar) working pressure. Prevents foreign material from entering dispense lines. Not for use with grease lines. 1/2 in npt(f) swivel x 1/2 in npt(m) ports.

Mesh Strainer Replacement for 240417

3 replacement Elements

238433

25 replacement Elements

238434

Mesh

40 mesh

238431

238429

238432 n/a

60 mesh (standard)

100 mesh

Y-Strainers 400 psi (28 bar) max. working pressure fi lters material before it enters the pump. 20 mesh screen.

Y-Strainer

101078

Replacement Screens

180199

Inlet/Outlet

3/4 npt(f) both ends

110877

110878

Mounting Accessories

Pump

Bung Adapter

110906

110907

1/2 npt(f) both ends

1 npt(f) both ends

Fire-Ball 425, 3:1

N/A‡

Connection Hose Kit

Wall Mounting Bracket

Thermal Relief Kit

Air Regulator and Gauge

Air Filter

Fast-Ball 1:1

222308

222118

18 inch (45.7 cm)

222119

72 inch (182.8 cm)

203987

-

110147

110146

Mini Fire-Ball 225, 3:1 Fire-Ball 300, 5:1

222308 222308

222062

18 inch (45.7 cm)

222063

72 inch (182.8 cm)

222062

18 inch (45.7 cm)

222063

72 inch (182.8 cm)

203987

235998

109075

106148

203987

237893

109075

106148

238246

24 inch (60.9 cm)

238245

237601

104266/ 100960

106149

Air Lubricator 110148

FRL*

Airline Shutoff Valve

110149

110223

Fluid Shutoff Valve

Fluid Outlet Filter

Low-Level Cutoff

108537

240417

203688

Suction Hose Kit 236054

* Filter, Regulator, Lubricator and Gauge

**Recommend 1-1/2 in, 6 ft hose assembly as suction kit

‡Must be wall-mounted or fl ange-mounted

214847

110150

110224

108458

240417

203688

236054

214847

110150

110224

108458

240417

203688

236054

214848

217072

110225

108537

101078

203688

N/A**

www.graco.com

Fire-Ball 425, 6:1

N/A‡

238246

24 inch (60.9 cm)

238245

240429

104266/ 100960

106149

214848

217072

110225

108537

112087

203688

N/A**

108458

240417

101078

Fire-Ball 425, 10:1

222308

222068

18 inch (45.7 cm)

222066

72 inch (182.8 cm)

203987

240429

104266/ 100960

106149

214848

217072

110225

108537

112087

203688

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

19

NXT

High-Flo

®

Air-Operated Piston Pumps for Oil

Features and Benefi ts

• Move large amounts of oil fast–dispenses up to 31 gallons of oil per minute

• Tested to outperform and outlast all other pumps on the market with its long-life packing design

• Models available with intuitive, easy-to-use DataTrak

controls–gives you pump diagnostics, material usage tracking and pump runaway protection

• Reduces icing and noise–new NXT air motor is up to 50% quieter than previous models

Typical Applications

• In-plant to supply long-pipe runs or large volume header systems with multiple dispense locations

• Fill remote reservoirs or feed an automated lubrication system

• Transfer and dispense large amounts of lubricant to supply a production process

• Mines/construction for rapid refi ll of lube trucks and to service off-road equipment

Package Number with DataTrak

Package Number without DataTrak

Ratio

Mounting

Pump with DataTrak and thermal relief kit

Pump w/o DataTrak and thermal relief kit

Output per Cycle

Output at 60 CPM*

Motor Size

Maximum Fluid Pressure

Maximum Air Input Pressure

System Manual

Pump Manual

Pump Lower Manual

Motor Manual

Pump Inlet Size

Pump Outlet Size

3/4 in x 4 ft Air Hose

1 in x 6 ft Fluid Hose

*Graco recommends 20 CPM or less for supply applications

Performance Charts

A = 100 psi (7.0 bar) air pressure

B = 70 psi (4.9 bar) air pressure

C = 40 psi (2.8 bar) air pressure

247888

24D602

3.5:1

Wall (255143)

24D590

24D596

2000cc

31.5 gpm (119.2 lpm)

NXT 3400

350 psi (24.1 bar)

100 psi (6.9 bar)

312862

311211

311690

311238

1 1/2 in npt (f)

1 in npt (f)

110048

115042

A = 100 psi (7.0 bar) air pressure

B = 70 psi (4.9 bar) air pressure

C = 40 psi (2.8 bar) air pressure

247889 247892

24D603 24D606

4.5:1

Wall (255143)

6:1

Wall (255143)

24D591 24D594

24D597

1500 cc

23.2 gpm (87.8 lpm)

NXT 3400

450 psi (31.0 bar)

100 psi (6.9 bar)

312862

311211

311690

311238

1 1/2 in npt (f)

1 in npt (f)

110048

115042

24D600

2000 cc

31.5 gpm (119.2 lpm)

NXT 6500

500 psi (35.2 bar)

75 psi (5.2 bar)

312862

311831

311832

311238

2 in npt (f)

2 in npt (f)

110048

247969

Test Fluid is No. 10 Weight Oil for all pumps

A = 70 psi (4.9 bar) air pressure

B = 55 psi (3.7 bar) air pressure

C = 40 psi (2.8 bar) air pressure

247893

24D607

6:1

Stand (218742)

24D594

24D600

2000 cc

31.5 gpm (119.2 lpm)

NXT 6500

500 psi (35.2 bar)

75 psi (5.2 bar)

312862

311831

311832

311238

2 in npt (f)

2 in npt (f)

110048

247969

20

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

www.graco.com

NXT

Dura-Flo

Air-Operated Piston Pumps for Oil

Performance Charts

A = 7 bar (100 psi) air pressure or 105 bar (1500 psi) hydraulic oil pressure

B = 4.9 bar (70 psi) air pressure or 75 bar (1050 psi) hydraulic oil pressure

C = 2.8 bar (40 psi) air pressure or 42 bar (600 psi) hydraulic oil pressure

Test Fluid is No. 10 Weight Oil for all pumps

Package Number with DataTrak

Package Number without DataTrak

Ratio

Mounting

Pump with DataTrak and thermal relief kit

Pump w/o DataTrak and thermal relief kit

Output per Cycle

Output at 60 CPM*

Motor Size

Max. Fluid Pressure

Max. Air Input Pressure

System Manual

Pump Manual

Pump Lower Manual

Motor Manual

Pump Inlet Size

Pump Outlet Size

3/4 in x 4 ft Air Hose

1 in x 6 ft Fluid Hose

*Graco recommends 20 CPM or less for supply applications

www.graco.com

247890

24D604

6:1

Wall ( 255143)

24D592

24D598

1000cc

17.4 gpm (65.9 lpm)

NXT 3400

620 psi (42.7, 4.3 bar)

100 psi (6.9 bar)

312862

311833

311717

311238

2 in npt(f)

1 1/2 in npt(m)

110048

115042

247894

24D608

10:1

Wall ( 255143)

24D595

24D601

1000cc

17.4 gpm (65.9 lpm)

NXT 6500

1180 psi (81.3 bar)

100 psi (6.9 bar)

312862

311833

311717

311238

2 in npt(f)

1 1/2 in npt(m)

110048

115042

247891

24D605

12:1

Wall ( 255143)

24D593

24D599

580cc

9.2 gpm (34.8 lpm)

NXT 3400

1190 psi (82.1 bar)

100 psi (6.9 bar)

312862

311826

311825

311238

2 in npt(f)

1 1/2 in npt(m)

110048

115042

247895

23:1

Wall ( 255143)

580cc

9.2 gpm (34.8 lpm)

NXT 6500

1725 psi (118.9 bar)

75 psi (5.2 bar)

312862

311826

311825

311238

2 in npt(f)

1 1/2 in npt(m)

110048

115042

L U B R I C A T I O N E Q U I P M E N T

O I L P U M P S

21

Grease Pumps Quick Reference

Technical Specifi cations and Selection Chart

Manual Number

Continuous-Duty

Flow Rate

Maximum

Fluid

Pressure

Air Motor

Effective

Diameter

Operating

Range

Approximate

Air Use

Wetted Materials

Air Inlet

Port

Size

Material

Inlet

Material

Outlet

Manual 309966

Mini Fire-Ball 225, 50:1

0.32 lb/min

(.15 kg/min.)

8400 psi

(578 bar)

2.25 in

(57.2 mm)

Line Length

: Up to 100 ft (30.5 m)

Annual Usage: Up to 5,000 lb (2,268 kg)

40-140 psi

(3-10 bar)

7.3 scfm @ 0.41 lb/min.

(.18 kg/min)

@ 100 psi @ 80 cpm

Steel, Urethane,

Aluminum, Buna-N,

Brass, Ethylene,

Delrin ®

Dispense Points: 1

Typical Applications: Small maintenance facility

3/8 in npt(f)

Slotted

1/4 in npt(f)

Manual 308883

Fire-Ball 300, 50:1

1.19 lb/min.

(.54 kg/min.)

8400 psi

(580 bar)

3 in

(76.2 cm)

30-140 psi

(3.0-9.7 bar)

22.8 cfm @100 psi

(7 bar)

CS, Delrin ® , Buna-N,

Polyurethane

3/8 in npt(f)

Slotted

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: Up to 10,000 lb (4,535 kg)

Dispense Points: 1 to 2

Typical Applications: High pressure grease to 8400 psi (579 bar)

1/4 in npt(f)

Fire-Ball 425, 50:1

3.35 lb/min

(1.5 kg/min.)

7500 psi

(517 bar)

4.25 in

(10.8 mm)

40-150 psi

(2.8-10.4 bar)

19 cfm @70 psi

(4.8 bar)

CS, Leather

1/2 in npt(f)

Slotted

3/8 in npt(f)

Manual

306674/ 306982

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: 20,000 lb or more (9,072 kg)

Dispense Points: 4 or more

Typical Applications: High pressure grease to 7500 psi (517 bar)

Fire-Ball 425, 75:1

1.95 lb/min

(.88 kg/min.)

7500 psi

(517 bar)

4.25 in

(10.8 cm)

40-100 psi

(2.8-7 bar)

26 cfm @100 psi

(7 bar)

CS, Leather

1/2 in npt(f)

Slotted

3/8 in npt(f)

Line Length

: Up to 500 ft (152.5 m) Dispense Points: 4 or more

Annual Usage: 15,000 lb or more (6,804 kg) Typical Applications: High pressure grease to 7500 psi (517 bar)

Manual

308777/ 306982

Fire-Ball 300, 15:1

0.7 gpm

2700 psi

(186 bar)

3 in

(7.6 cm)

40-180 psi

(2.8-12.5 bar)

17 [email protected] 100 psi

(7 bar)

CS, AL, Leather,

PTFE, Rubber

3/8 in npt(f)

1 in npt(f)

Straight

Inlet

1/4 in npt(f)

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: Up to 10,000 lb (4,535 kg)

Dispense Points: 1 to 2

Medium Pressure Grease to 2700 psi (186 bar)

Manual 306531

Fire-Ball 425, 10:1

3.5 gpm

1800 psi

(124 bar)

4.25 in

(10.8 cm)

40-180 psi

(2.8-12.5 bar)

13 cfm @100 psi

(7 bar)

Steel, Bass,

Aluminum, Leather,

Buna-N

1/2 in npt(f)

Slotted

Line Length

: Up to 500 ft (152.4 m) Dispense Points: 4 or more

Annual Usage: 20,000 lb or more (9,072 kg) Typical Applications: High pressure grease to 1800 psi (124 bar)

Manual 309407

* Not recommended with hose reel ‡ Consult your local authorized Graco representative for line or pipe sizing

1 in npt(f)

22

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

www.graco.com

Grease Pumps Quick Reference

Technical Specifi cations and Selection Chart

See NXT Ordering Information for Instruction Manuals

Output

Per Cycle

Output at

60 CPM*

Maximum

Fluid

Pressure

Motor

Size

Maximum Air Input

Pressure psi (bar)

Floor-mounted

Check-Mate, 14:1**

500cc

57.0 lb/min

(26.0 kg/min)

1400

(96.5 bar)

NXT 3400 100 (6.9)

Line Length

: Up to 100 ft (30.5 m)

Annual Usage: Up to 20,000 lb. (9,072 kg)

Check-Mate, 26:1

Dispense Points: 1

Typical Applications: Small maintenance facility

500cc

57.0 lb/min

(26.0 kg/min)

2600

(179.3 bar)

NXT 6500 100 (6.9)

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: Up to 20,000 lb. (9,072 kg)

Dispense Points: 1 to 2 (simultaneous)

Typical Applications: Smaller continuous duty, maintenance facility

Check-Mate, 29:1

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: Up to 20,000 lb. (9,072 kg)

250cc

28.0 lb/min

(13.0 kg/min)

2900

(200.0 bar)

NXT 3400 100 (6.9)

Dispense Points: 4 or more

Typical Applications: Medium continuous duty, maintenance facility

Check-Mate, 55:1

250cc

28.0 lb/min

(13.0 kg/min)

5500

(379.2 bar)

NXT 6500 75 (5.2)

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: Up to 20,000 lb. (9,072 kg)

Check-Mate, 63:1**

Dispense Points: 1 to 2 (simultaneous)

Typical Applications: Smaller continuous duty, maintenance facility

100cc

11.4 lb/min

(5.2 kg/min)

4500

(310.3 bar)

NXT 3400 72 (5.0)

Line Length

: Up to 250 ft (76.2 m)

Annual Usage: Up to 20,000 lb. (9,072 kg)

Check-Mate, 68:1**

Dispense Points: 1 to 2 (simultaneous)

Typical Applications: Smaller continuous duty, maintenance facility

200cc

22.8 lb/min

(10.4 kg/min)

5300

(356.5 bar)

NXT 6500 78 (5.4)

Line Length

: Up to 500 ft (152.5 m)

Annual Usage: Up to 20,000 lb. (9,072 kg)

* Graco recommends 20 CPM or less for supply applications.

**NXT Check-Mate pump is available in fl oor stand or RAM Package.

See NXT package section of this book for more information.

Dispense Points: 1 to 2 (simultaneous)

Typical Application: Smaller continuous duty, maintenance facility

RAM-mount

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

23

Mini Fire-Ball

®

225, 50:1

Air-Operated Piston Pumps and Packages for Grease

Features and Benefi ts

• Non-corrosive air motor design for long life

• Double-acting pump ensures smooth fl uid fl ow

• Robust grease inlet cage withstands the most abusive handling

Typical Applications

• Medium to high pressure, low to medium volume grease dispense

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube and service centers

• Fleet service facilities

• Lube trucks

• Mining

• In-plant

Typical Fluids Handled

• Grease up to NLGI #2 psi

(bar)

(552)

6000

(414)

4000

(276)

2000

(138)

0

Pump Performance cycles/min scfm

(m

3

/min)

14

(0.4)

10.5

(0.3)

7

(0.2)

4

(0.1)

0

Inlet Air Pressures:

=140 psi

(9.6 bar)

=100 psi

(6.9 bar)

=80 psi

(5.5 bar)

=40 psi

(2.8 bar)

TEST FLUID: No. 10 Weight Oil

24

246910

Grease Pumps and Packages

246911

246913

246914 246915 246916

246917

Portable Pail

Dispenser

Stationary Pail

Dispenser

Cart-Mounted Pail

Dispenser

Stationary

Supply Package

Portable Package w/ Caster Base

Portable Package w/ 2-Wheel Cart

Container Size

Package No.

Pump Only

Container

Follower Plate

Dispense Kit

Fluid Hose

Air Hose

Cover

Cart

35 lb (16 kg) pail

35 lb (16 kg) pails or 70 lb (32 kg) bulk

246911 +

35 lb (16 kg) pails or 70 lb (32 kg) bulk

246913 + 246910 +

246909

246909

204134

246909

204134

220653

236058

12 ft x 1/4 in

(3.7 m x 6.4 mm)

222059

222059

*

236058

12 ft x 1/4 in

(3.7 m x 6.4 mm)

204574

204574

204574

203650

120 lb (55 kg)

246914 +

246780

*

236058

12 ft x 1/4 in

(3.7 m x 6.4 mm)

204574

220654

222072

6 ft x 1/4 in

(1.8 m x 6.4 mm)

6 ft x 3/8 in

(1.8 m x 9.5 mm)

204574

309967 Manual 309967 309967 309967

+ Order 3/8 in (9.5 mm) air regulator ( 109075) separately

* Order follower plate 220653 separately for 35 lb (16 kg) pails or 220654 for 70 lb (32 kg) bulk

120 lb (55 kg)

246915 +

246780

220654

236058

12 ft x 1/4 in

(3.7 m x 6.4 mm)

204574

203622

309967

120 lb (55 kg)

246916 +

246780

220654

236058

12 ft x 1/4 in

(3.7 m x 6.4 mm)

204574

203650

309967

Stationary

Supply

Package

400 lb (180 kg)

246917 +

246781

223845

222072

6 ft x 1/4 in

(1.8 m x 6.4 mm)

6 ft x 3/8 in

(1.8 m x 9.5 mm)

200326

309967

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

www.graco.com

Fire-Ball

®

300, 15:1

Air-Operated Piston Pumps and Packages for Grease

Pump Performance psi

(bar)

(83)

900

(62)

600

(41)

300

(21)

0

gpm

(lpm) cycles/min

90 scfm

(m3/min)

12

(0.34)

9

(0.26)

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

=40 psi

(2.8 bar)

6

(0.17)

0.25 .50 .75 1

(0.95) (1.7) (2.9) (3.8)

3

(0.08)

TEST FLUID: No. 10 Weight Oil

Packages for 35-400 lb (16-180 kg) Containers

Container Size lb (kg)

Package No.

Pump Only

Dispense Kit

Fluid Hose

Drum Cover

Instruction Manual

Stationary Pail Dispenser

35 lb (16 kg)

222078

206405

222080

15 ft x 3/8 in (4.6 m x 9.5 mm)

222058

Stationary Drum Dispenser

120 lb (55 kg)

220170

206699

222081

25 ft x 3/8 in (7.6 m x 9.5 mm)

204574

307882

Cover-Mounted Drum Dispenser

400 lb (180 kg)

220171

206700

222081

25 ft x 3/8 in (7.6 m x 9.5 mm)

200326

222078

www.graco.com

220170

220171

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

25

Fire-Ball

®

300, 50:1

Air-Operated Piston Pumps and Packages for Grease

Pump Performance psi

(bar)

(552)

6000

(414)

4000

(276)

2000

(138) cycles/min

0

lb/min

(kg/min)

1.0

(.5)

2.0

(.9)

3.0 4.0

(1.4) (1.8)

TEST FLUID: NLG1 #1 Grease at 70 F (21 C)

0 scfm

(m3/min)

40

(1.13)

30

(0.85)

20

(0.57)

10

(0.28)

Inlet Air Pressures:

=150 psi

(10.3 bar)

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

=40 psi

(2.8 bar)

222069 225827

225773

35-70 lb (16-32 kg) Pumps and Packages

Container Size

Package No.

Metered Package**

Pump Only

Dispense Kit

Fluid Hose

Air Hose

Follower Plate

Cover

Holster

Container

Cart

Elevator

Inductor Plate

Instruction Manual

Portable Pail

Dispenser

35 lb (16 kg)

222069 *

245694

239877

222070

12 ft x 1/4 in (3.7 m x 6.4 mm)

-

220653

222059

-

-

-

-

-

307878

Stationary Pail

Dispenser

35 lb or 70 lb

(16 kg or 32 kg)

225827 *

-

239877

222070

12 ft x 1/4 in (3.7 m x 6.4 mm)

-

204574

203976

204134

-

-

-

307878

Cart-Mounted

Pail Dispenser

35 lb or 70 lb

(16 kg or 32 kg)

225773 *

245695

239877

222070

12 ft x 1/4 in (3.7 m x 6.4 mm)

-

204574

203976

204134

203650

-

-

307878

* Use 3/8 in (9.5 mm) air regulator 109075; must be ordered separately

** Metered grease package includes 233807 Accu-Shot instead of 242056 Pro-Shot

† Order follower plate 220653 for 35 lb (16 kg) containers, and follower plate 220654 for 70 lb (32 kg) containers; must be ordered separately

226012

Cart-Mounted

Pail Topper

35 lb (16 kg)

226012 *

-

239877

222070

12 ft x 1/4 in (3.7 m x 6.4 mm)

-

-

-

203976

-

203650

203664

204351

307878

26

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

www.graco.com

Fire-Ball

®

300, 50:1

Air-Operated Piston Pumps and Packages for Grease

Stationary Supply

120 (55)

225014 *

-

239887

222072

6 ft x 1/4 in

(1.8 m x 6.4 mm)

6 ft x 3/8 in

(1.8 m x 9.5 mm)

220654

204574

-

-

-

-

-

-

306523

222073

225006

225026

222245

Packages For 120 lb (55 kg) Containers

Portable with

Caster Base

Portable with

Two-Wheel Cart

Container Size lb (kg) 120 (55) 120 (55)

Package No.

Metered Package

Pump Only

Dispense Kits

Fluid Hose

Air Hose

225006 *

-

239887

222070

12 ft x 1/4 in

(3.7 m x 6.4 mm)

-

225026 *

245696 **

239887

-

Follower Plate

Cover

Holster

Caster Base

Cart

Elevator

Pump Support

220654

204574

203976

203622

-

-

-

220654

204574

203976

-

203650

-

-

Hold Down Kit

Instruction Manual

-

306523

-

306523

* Use 3/8 in (9.5 mm) air regulator 109075; must be ordered separately

** Metered grease package includes 233807 Accu-Shot instead of 242056 Pro-Shot

† Pump support assembly includes dust cover, base, inductor plate and 6 ft (1.8 m) fl uid & air hoses

Packages for 400 lb (180 kg) Containers

Container Size lb (kg)

Stationary

400 (180)

Package No.

Pump Only

225016 *

239888

Hose & Fitting Kit 222072

Fluid Hose

Air Hose

Follower Plate

Cover

Carriage

Elevator

6 ft (1.8 m) x 1/4 in (6.4 mm)

6 ft (1.8 m) x 3/8 in (9.5 mm)

223845

200326

-

-

Inductor Plate

Base

-

-

Instruction Manual 307880

* Use 3/8 in (9.5 mm) air regulator 109075; must be ordered separately

Topper-Inductor

400 (180)

226013 *

239888

204467

6 ft (1.8 m) x 1/4 in (6.4 mm)

6 ft (1.8 m) x 3/8 in (9.5 mm)

-

-

204461

204385

204353

205339

306556

220654

222060

-

-

222243

-

-

222061

306523

Portable with

Heavy-Duty Cart

120 (55)

222245 *

-

239887

222383

25 ft x 1/4 in

(7.6 m x 6.4 mm)

-

www.graco.com

225014

225016

226013

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

Stationary Supply

Topper-Inductor

120 (55)

222073 *

-

239887

-

6 ft x 1/4 in

(1.8 m x 6.4 mm)

6 ft x 3/8 in

(1.8 m x 9.5 mm)

-

-

-

-

-

204121

222074†

-

306523

27

Fire-Ball

®

425, 10:1 and 50:1; Bulldog

®

3:1

Air-Operated Piston Pumps and Packages for Grease

28

Fire-Ball 425, 10:1 Performance psi

(bar)

(510)

6000

(408)

4500

(306)

3000

(204) cycles/min

53 scfm

(m3/min)

40

(1.1)

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

30

(.85)

20

(0.56)

0 lb/min 1 2 3 4

(kg/min) (0.45) (.9) (1.4) (1.8)

10

(0.28)

TEST FLUID: No. 10 Weight Oil

Fire-Ball 425, 10:1 Pump Only

Part No.

Application

205394 120 lb open

205395 400 lb open

965129 400 lb closed. Includes bung adapter.

965124 Stubby/universal

Fire-Ball 425, 50:1 Performance psi

(bar) cycles/min

13 27 41

(510)

6000

(408)

4500

(306)

3000

(204)

0

lb/min

(kg/min)

1 2

(0.45) (.9)

3 4

(1.4) (1.8)

TEST FLUID: No. 10 Weight Oil

53 scfm

(m3/min)

40

(1.1)

30

(.85)

20

(0.56)

10

(0.28)

Inlet Air Pressures:

=150 psi

(6.9 bar)

=100 psi

(4.8 bar)

223108

Packages for 120-400 lb (56-180 kg) Containers

Description Stationary Supply, 50:1 Stationary Supply, 50:1

Container Size lb (kg)

Package Number

Pump Number

Air Hose Kit

Fluid Hose

Air Hose

120 (55)

223108*

205394

222076

6 ft x 3/8 in

(1.8 m x 9.5 mm)

6 ft x 1/2 in

(1.8 m x 12.7 mm)

400 (180)

225781*

205395

222076

6 ft x 3/8 in

(1.8 m x 9.5 mm)

6 ft x 1/2 in

(1.8 m x 12.7 mm)

Cover

Follower Plate

Carriage

Elevator

Inductor Plate

Base

Ram

Air Regulator

204574

223344

Adapter Plate

Adapter Kit

Manual 307880 307880

* Use 1/2 in (12.7 mm) air regulator 104266 and gauge 100960; must be ordered separately

For Fire-Ball 425, 50:1 Lube Truck Packages, see the Specialty Pump Section

** For Fire-Ball 425 5:1, 10:1, 15:1 and 50:1

200326**

223846

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

Stationary Supply

Topper-Inductor, 50:1

400 (180)

226018*

205395

205102

6 ft x 3/8 in

(1.8 m x 9.5 mm)

6 ft x 1/2 in

(1.8 m x 12.7 mm)

204461

204385

205699

205339

306556

225781

Ram Package, 50:1

400 (180)

244905

205395

222076

6 ft x 3/8 in

(1.8 m x 9.5 mm)

6 ft x 1/2 in

(1.8 m x 12.7 mm)

207279

244844

162225

224266

309345

www.graco.com

226018

Bulldog (Sinker), 3:1

400 (180)

244848

205148

208610 / 244658

6 ft x 3/8 in

(1.8 m x 9.5 mm)

6 ft x 1/2 in

(1.8 m x 12.7 mm)

222404

207651

309345

Fire-Ball

®

425, 75:1

Air-Operated Piston Pumps and Packages for Grease

Pump Performance psi

(bar) cycles/min

53 scfm

(m3/min)

(510)

6000

(408)

4500

(306)

3000

(204)

40

(1.1)

30

(.85)

20

(0.56)

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

0 lb/min 1 2 3 4

(kg/min) (0.45) (.9) (1.4) (1.8)

10

(0.28)

TEST FLUID: No. 10 Weight Oil

Packages for 35-400 lb (16-180 kg) Containers

Description

Container Size lb (kg)

Package Number

Bare Pump Number

Hose & Fitting Kit

Drum Cover

Follower Plate

Carriage

Elevator

Base

Inductor

Ram

Air Regulator

Cover-Mount

120 (55)

244635*

239729

222076

204574

223344

-

-

-

-

-

-

Cover-Mount

400 (180)

244636*

239730

222076

200326

223846

-

-

-

-

-

-

Inductor

400 (180)

244637*

239730

205102

-

-

204461

204385

205339

205699

-

-

Ram

400 (180)

244906

239730

222076

-

-

-

-

-

-

207279

244844

Pail Length

35/70 lb (16/32 kg)

-

239731

-

204574

**

-

-

-

-

-

-

Bung or Cover

400 (180)

-

239730

-

-

-

-

-

-

-

-

-

Adapter Plate

Adapter Kit

-

-

-

-

-

-

162225

224266

-

-

-

-

Manual 307880 307880 306556 309345 -

* Use 1/2 in (12.7 mm) air regulator ( 104266) and gauge ( 100960); must be ordered separately ** 35 lb: 220653/ 70 lb: 223344 • For Lube Truck Packages, see the Specialty Pumps and Packages Solution Section

RAM Assemblies

Description Fire-Ball 300, 50:1

System Package

Bare Pump

Ram

Pump Mount Kit

Adapter Kit

Air Regulator and Gauge

Ram Plate Seal Kit

Air Hose 3/4 in x 6 ft

Fluid Hose 1 in x 6 ft

*Order individual components **Drum clamp: 206537

Drum Systems

*

239888

207279

247336

224267

203716

247335

-

-

Fire-Ball 425, 75:1

244906

239730

207279

247337

224266

244844

247335

-

-

Fire-Ball 425, 50:1

244905

205395

207279

247337

224266

244844

247335

-

-

Fire-Ball 425, 10:1

*

965129

207279

247337 not needed

207468

247335

-

-

3:1 Bulldog Ram,

400 lb (181 kg) Drum**

244641

205148

207279

-

-

207651

224829

208610

244658

Ram-Mount

• Force feed high volume pumps

• Extreme viscous grease

• Reduce waste

• Clean and convenient method of drum change

Inductor-Mount

• Reduce waste

• Clean and convenient method of drum change

Cover-Mount with Follower Plate

• Economical

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

29

Accessories

Air-Operated Piston Pumps and Packages for Grease

Dispense, Hose and Fitting Kits

Rated to 4000 - 5000 psi (276-345 bar) for Portable Fire-Ball 300, 50:1 or Mini Fire-Ball 225, 50:1 Pumps

222080

222081

236058

For Fire-Ball 300, 15:1. Includes: 15 ft (4.6 m) of 3/8 in (9.5 mm) fl uid hose ( 109165), grease dispense valve ( 242056), Z-Swivel ( 202577), 3/8 in (9.5 mm) closed nipple ( 156849), quick-disconnect nipple

( 169971), quick-disconnect air coupler ( 110198) and 3/8 in (9.5 mm) air regulator ( 110234).

For Fire-Ball 300, 15:1. Includes: 25 ft (7.6 m) of 3/8 in (9.5 mm) fl uid hose ( 109167), grease dispense valve ( 242056), Z-Swivel ( 202577), 3/8 in (9.5 mm) closed nipple ( 156849), quick-disconnect nipple

( 169971), quick-disconnect air coupler ( 110198) and 3/8 in (9.5 mm) air regulator ( 110234).

For Mini Fire-Ball 225, 50:1. Includes: 12 ft (3.6 m) fl uid hose ( 109151), air coupler ( 208536), air nipple ( 169971), grease dispense valve ( 242056), gun holder ( 188843) and Z-Swivel ( 202577).

222070

222383

For Fire-Ball 300, 50:1. Includes: 12 ft (3.6 m) fl uid hose ( 109151), air coupler ( 208536), air nipple

( 169971), grease dispense valve ( 242056) and Z-Swivel ( 202577). Instruction manual 307878.

For Portable Units Powered by the Mini Fire-Ball 225, 50:1 or Fire-Ball 300, 50:1 Pumps. Includes: dispense kit, grease dispense valve ( 242056), 25 ft (7.6 m) fl uid hose ( 109054), air coupler ( 208536), air nipple ( 169971) and Z-Swivel ( 202577). Instruction manual 307878.

Hose and Fitting Kits

Rated to 5000 psi (345 bar) for Stationary Drum-Mounted Fire-Ball 300, 50:1 Pumps

222072

Hose and Fittings Kit. Includes: 6 ft (1.8 m) air hose ( 203320) with swivel elbow ( 155494) and 6 ft

(1.8 m) fl uid hose ( 109150) with swivel elbow ( 155541). Instruction manual 307880.

Rated to 4000 psi (276 bar) for Stationary Drum-Mounted Fire-Ball 425, 50:1 Pumps

222076

Hose and Fittings Kit. Includes: 6 ft (1.8 m) air hose ( 205418) with swivel elbow ( 155470) and 6 ft

(1.8 m) fl uid hose ( 109163) with swivel elbow ( 155494). Instruction manual 307880.

Bung Adapters

239965 For Fire-Ball 425, 50:1 and 75:1 Pumps, 1.65 in ID

239966 For Fire-Ball 300, 15:1 and 50:1 Pumps

Lincoln-to-Graco Adapter Kit

241246 For Fire-Ball 300, 50:1 when replacing a Series 20 Lincoln

Flange Mounting Accessories for Fire-Ball Pumps

948393 Flange adapter (male) Fire-Ball 300

948392 Flange adapter (male) Fire-Ball 425

512874 Coupler (female)

Follower Plates

220653 For 35 lb (16 kg) pails with Mini Fire-Ball 225, 50:1, Fire-Ball 300, 15:1 and 50:1 pumps

220654

For 70 and 120 lb (32/55 kg) drum, Mini Fire-Ball 225, 50:1, Fire-Ball 300, 15:1 and 50:1 pumps

223344 For 120 lb (55 kg) drums with Fire-Ball 425, 50:1 and 75:1 pumps

223700 For 120 lb (55 kg) drums with Dyna-Star 5:1 pumps

223845 For 400 lb (180 kg) drum, Mini Fire-Ball 225, 50:1, Fire-Ball 300, 15:1 and 50:1 pumps, 1.19 in ID

204130 Follower plate same as 223845, but without fl exible wiper

223846 For 400 lb (180 kg) drums with Fire-Ball 425, 50:1 and 75:1 pumps, 1-13/32 in ID

205337 Follower plate same as 223846, but without fl exible wiper

223701 For 400 lb (180 kg) drums with Dyna-Star 5:1 and Fire-Ball 425, 10:1 pumps, 2.1 in ID

Drum Covers

200326

204574

222059

160754

Cover for open-head 400 lb (180 kg) drums. Use with any Mini Fire-Ball 225; Fire-Ball 225, 50:1;

Fire-Ball 300, 15:1 and 50:1; Fire-Ball 425, 10:1 or Dyna-Star 5:1 grease pump. Use adapter 160754 for bung-mounted pumps.

Cover for open-head 120 lb (55 kg) or 70 lb (32 kg) drums. Mounts Mini Fire-Ball 225, Fire-Ball grease pumps or Dyna-Star 5:1 pump. Use adapter 160754 for bung-mounted pumps.

Cover for 35 lb (16 kg) pails. Mounts Mini Fire-Ball 225, 50:1 and Fire-Ball 300, 50:1 pumps using friction-style clutch lock. Allows use of 70 lb (32 kg) length pump with 35 lb (16 kg) pail.

Bung-adapter plate. Mounts to standard 400 lb (180 kg) or 120 lb (55 kg) drum cover and converts mounting to standard 2 npt bung opening. Allows use of bung-mounted pumps with drum covers.

30

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

220653

204574

200326

222059

160754

www.graco.com

Accessories

Air-Operated Piston Pumps and Packages for Grease

Portable Bases

205054 Band Dolly for 35 lb (16 kg) pails

204144 Band Dolly Base for 70 lb (32 kg) or 120 lb (55 kg) drums

203622 Caster Base for 35 lb (16 kg), 70 lb (32 kg) or 120 lb (55 kg) drums

Carts

203650

For 35 lb (16 kg), 70 lb (32 kg) and 120 lb (55 kg) drums. Drums fi t onto recess on formed base. Rim clamps secure drum onto cart. Use with pail clamp 159952 when using cart with 35 lb (16 kg) pails.

222243 For 120 lb (55 kg) drums with pneumatic wheels for rough terrain.

111470 Heavy-duty drum truck for 400 lb (180 kg) drums secures drum onto roll-around base.

Drum Elevator

241663

Air-Powered Elevator to speed drum changes. Maximum raised height: 39.5 in (100.33 cm). Includes:

Cover Support ( 207562), Drum Elevator, ( 204385), Air Control Kit ( 207561)

Air Shut-Off Valves, Bleed-type, rated to 250 psi (17.4 bar)

110223 1/4 in (6.4 mm)

110224 3/8 in (9.5 mm)

110225 1/2 in (12.7 mm)

110226 3/4 in (19.1 mm)

High-Pressure Grease Shut-Off Valves

202869 5000 psi (345 bar) high-pressure needle valve, 1/2 npt(f) ported valve for drop-line isolation.

204144

202869

203622

241663

www.graco.com

203650

111470

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

31

NXT

Check-Mate

®

Packages

Air Operated Piston Pumps and Packages for Grease

Ordering Information

Package Number with DataTrak

Package Number without DataTrak

Ratio

Pump with DataTrak

Pump w/o DataTrak

Mounting

3/4 in x 6 ft Air Hose

1 in x 6 ft Fluid Hose

System Manual

Pump Manual

Pump Lower Manual

247973

24E006

14:1

P14MCS

P14DCS

Floor Stand

( 223952)

208610

115042

312863

312376

312375

247976

24E007

26:1

P26MCS

P26DCS

Floor Stand

( 223952)

208610

244657

312863

312376

312375

Motor Manual 311238

*Graco recommends 20 cpm or less for supply applications

311238

Performance Charts

A = 100 psi (7 bar)

B = 70 psi (5.0 bar)

C = 40 psi (2.8 bar)

D = 90 psi (6.3 bar)

247974

24E008

29:1

P29MCS

P29DCS

Floor Stand

( 223952)

208610

244657

312863

312376

312375

311238

247977

24E009

55:1

P55MCS

P55DCS

Floor Stand

( 223952)

208610

244657

312863

312376

312375

311238

247975

24E010

63:1

P63MCS

P63DCS

Floor Stand

( 223952)

208610

244657

312863

312376

312375

311238

247978

24E011

68:1

P68MCS

P68DCS

Floor Stand

( 223952)

208610

244657

312863

312376

312375

311238

Test Fluid : #10 Weight Oil for all pumps

Ordering Information

NXT Check-Mate RAM Packages

Ratio

Package Number

Mounting

Operation Manual

Repair and Parts Manual

14:1

247979

RAM System

312371

312373

63:1

247980

RAM System

312371

312373

32

L U B R I C A T I O N E Q U I P M E N T

G R E A S E P U M P S

68:1

247981

RAM System

312371

312373

www.graco.com

Diaphragm Pumps

Air-Operated Double Diaphragm Transfer Pumps

D31255

241906

647016

DF3525

DB3525 DK3525

Ordering Information and Technical Specifi cations

Key OT = Oil Transfer OE = Oil Evacuation WA = Water, Anti-Freeze FD = Fuel Dispense

(with 50 psi relief valve)

FT = Fuel Transfer WWS = Windshield Wash Solution

Body/Diaphragm Description

Part

Number

Typical

Application

Max.

Air

SCFM

Air

Inlet

NPT

Max. psi

(bar)

Fluid

Inlet/

Outlet

Free Flow gpm

(lpm)

Air Valve

Replacement

Kit

Kits

(Seats, Balls,

Diaphragms)

Diaphragm

Kit

Manual

307 3/8 in Diaphragm Pump

Acetal/TPE

D31255

OT, WA,

WWS

7 (1) 1/4 100(7) 3/8 7 (31.8) 239952 D03255 D03005 308553

515 3/4 in Diaphragm Pump

Aluminum/Buna N

716 3/4 in Diaphragm Pump

Acetal/Buna Dual Inlet

1 in Diaphragm Pumps

1050A Aluminum/TPE (UL)

241906

243669

647016

OT, OE,

WA, WWS

50/50

WWS, WA

OE, WA,

FT

(leaded fuel only)

28

28

(1)

(1)

67

1/4

1/4

1/2

100(7)

100(7)

120

(8.2)

3/4

3/4

1

16

(60.6)

16 (61)

50 (189)

241657

241657

24B766

1050A Aluminum/TPE (UL) 647648 FD 20

(2)

1/2

50

(3.4)

1 32 (121) 24B766

1590 1-1/2 in Diaphragm Pump

Aluminum/TPE

2150 2 in Diaphragm Pump

Aluminum/TPE

DB3525

DF3525

OT, OE,

WA

OT, OE,

WA

90

175

(3)

(3)

1/2

1/2

120

(8.3)

120

(8.3)

1 1/2

2

90 (341)

150(567)

236273

236273

3275 3 in Diaphragm Pump

Aluminum/TPE

NOTE: All pumps are 1:1 ratio

DK3525

(1)

Max air use at 100 psi (7.0 bar)

OT, OE,

WA

325

(3)

3/4

120

(8.3)

(2)

Max air use at 125 psi (8.6 bar)

3

275

(1,041)

(3)

Max air use at 120 psi (7.0 bar)

238765

D05277

D05277

24B634 and

24B639

24B634 and

24B639

D0B525

D0F525

D0K525

D05007 308573

D05007 308573

24B624 313597

24B624 313597

D0B005 308441

D0F005 308368

D0K005 308639

Mounting Accessories

Pump

Air Line Filter

Air Regulator & Gauge

Air Quick-Connect Coupler

Air Quick-Connect Nipple

Bleed Type Air Valve

Wall Bracket

Thermal Relief Kit

Thermal Relief Valves

150 psi (10.3 bar)

307

110146

515/716

110146

1050

106148

1590

106149

2150

106150

110147 110147 244844 202858 206199

208536, 1/4 npt(f) 208536, 1/4 npt(f) 110199, 1/2 npt(f) 110199, 1/2 npt(f) 110199, 1/2 npt(f)

169970, 1/4 npt(m) 169970, 1/4 npt(m) 110196, 1/2 npt(f) 110196, 1/2 npt(f) 110196, 1/2 npt(f)

110223 110223 110224 110225 110225

224835 224835 24C637 N/A N/A

238899

113497 al/bn,

112119 ss/tf

238428

113497 al/bn,

112119 ss/tf

238428

113497 al/bn ,

112119 ss/tf

N/A

113497 al/bn ,

112119 ss/tf

N/A

113497 al/bn ,

112119 ss/tf

Grounding Wire and Clamp

Suction Hose Kit

Flange Adapter Kit

222011

236054

N/A

222011

236054

N/A

222011

236054

N/A

Dual Inlet Manifold

Instruction Manual

N/A

308553

* 243669 comes with dual inlet **Dual inlet must be ordered separately for 685984

* 685984 **

308573 & 308981 308326 & 308479

222011

N/A

N/A

N/A

308441

222011

N/A

N/A

N/A

308368

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

T R A N S F E R P U M P S

3275

106150

207651

N/A

N/A

110226

N/A

N/A

113497 al/bn ,

112119 ss/tf

222011

N/A

N/A

N/A

308639

33

Fast-Flo

®

1:1

Transfer Pumps

Features and Benefi ts

• Differential air motor for smooth operation and reliability

• Stainless steel models available for corrosion resistance

Typical Applications

• Low pressure, high volume transfer of low viscosity fl uids

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers

• Fleet service facilities

• Service shops

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Water

• Anti-freeze

• Windshield wash fl uid

• Used oil

• Used anti-freeze

NOTE: Use Fast-Ball 1:1 for petroleum-based products.

Performance Chart psi

(bar)

25 50 75

(8.3)

80

(5.5)

40

(2.7)

20

(1.4) cycles/min

100 scfm

(m3/min)

10

(0.3)

8

(0.23)

6

(0.17)

4

(0.12)

0 gpm 1 2 3 4

(lpm) (3.8) (7.6) (11) (15)

2

(0.08)

TEST FLUID: No. 10 Weight Oil

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

=40 psi

(2.8 bar)

226948

226947

Manual

307427

Flow Rate gpm (lpm)

Maximum Fluid

Pressure psi (bar)

Operating Range

(1) psi (bar)

Wetted Materials Air Inlet Size Material Inlet

(2)

Material

Fast-Flo 1:1

5 (19) 180 (12.4) 40-180 (2.8-12) See Ordering Info 1/4 npt(f)

Line Length‡: Up to 100 ft (30 m) Dispense Points: 1

Annual Usage: Up to 5000 gal (18921 l) Typical Applications: In-Plant, Small Maintenance Facility

(1) Max Operating Air Pressure for 226951 is 60 psi (4.2 bar)

(2) For universal pumps

1-1/2 npt(f) 3/4 npt(f)

34

L U B R I C A T I O N E Q U I P M E N T

T R A N S F E R P U M P S

www.graco.com

Fast-Flo

®

1:1

Transfer Pumps

Ordering Information

Universal-Length Pumps (includes motor and pump-lower assembly)

Part Number

Material

Std. Seal

Repair Kits

226948

CS

218112

226952

SST

218112

237130

CS

213012

237131

CS

213013

Material

Typical Fluids

(Note: All seal repair kits are interchangeable with other Fast-Flo pumps.)

Drum-Length Pumps (includes motor and pump-lower assembly)

Part Number

Wetted Parts

Std. Seal

Repair Kits

Rubber

Motor Oil

226947

CS

218112

Rubber

Motor Oil

226951 †

CS

Motor Oil

Leather

Motor Oil

226953

SST

Motor Oil

PTFE

Motor Oil

237133

CS

213012

237132

SST

213013

PTFE

Motor Oil

237134

CS

213013

226943 *

CS

213012

Leather

Motor Oil

237129

SST

213013

226944 **

CS

215964

Polyethylene

Motor Oil

226940

CS

213012

215964

Polyethylene

Anti-Freeze, Windshield Wash

226941

CS

226945 **

SST

215964

226942

SST

215964

Material Rubber Rubber Rubber Leather PTFE PTFE

Leather, PTFE,

Leather

Motor Oil

Polyethylene,

UHMWPE

Motor Oil

Polyethylene,

UHMWPE

A/W Typical Fluids Motor Oil Motor Oil Motor Oil

Note: All seal repair kits are interchangeable with other Fast-Flo pumps.

* UL-listed

** UL-listed and CE-marked

† Adjustable down tube length between 18 in (457 mm) to 46.4 in (1180 mm)

Accessories

Motor Service Kits for all Fast-Flo 1:1 Pumps

Motor Oil Motor Oil Motor Oil

220168 Motor Service Kits for all Fast-Flo 1:1 Air Valve Piston Assembly (used with repair kit 214584, which must be ordered separately)

Hose and Fittings Kits

222118

222119

18 in (0.5 m) for connecting wall-mounted Fast-Flo 1:1 pumps to piping. Includes: air hose ( 109123) with swivel elbow ( 155541), fl uid hose ( 109108) with swivel elbow ( 160327).

6 ft (1.8 m) for use with drum-mounted Fast-Flo 1:1 pumps. Includes: air hose ( 109125) with swivel elbow ( 155541), fl uid hose ( 109105) with swivel elbow ( 160327).

Bung Adapters

214583 Allows direct mounting of full-length Fast-Flo 1:1 pumps into standard 2 npt drum bung.

217359 Sealed bung adapter for Fast-Flo pumps; can be used with suction kit 236054

Installation Kits

218316 Includes shut-off valve, regulators, gauges and fi ttings as necessary for normal installation.

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

T R A N S F E R P U M P S

35

Hurricane

Dispense System

Features and Benefi ts

• Electric pump with 6 ft (1.8 m) grounded power cord

• Digital metering standard on all units

• Quick-change bung adapter

• Pumps synthetic- or petroleum-based oils, ATF and antifreeze

(up to 50/50 mix)

• Simple two button operation

• Fits any container up to 44 in (1.1 m) tall with a 2 in NPT opening

• Measures in quarts, gallons, pints or liters

• Available with 8 ft or 25 ft (2.4 m or 7.6 m) meter and hose or built-in tapper

• Variety of portable package options

Typical Fluids Handled

• Synthetic- and petroleum-based oils

• Automatic transmission fl uid

• Anti-freeze (50/50 mix)

Technical Specifi cations

Voltage

Maximum current

Flow rate

Maximum container height

Weight (varies by model)

Meter accuracy

Instruction manual

ETL listed in US and Canada

110 Volts / 60 Hz

6 Amps

1.50 gpm (6.0 lpm)

44 in (1.1 m)

Up to 20 lbs (9 kg)

± 1.5%

311216

234902 and 249294 Hurricane with meter & hose

Ordering Information

Hurricane Dispense Systems

248918 Hurricane metered tapper unit

234902

249294

Hurricane 8 ft (2.4 m) hose and meter

Hurricane 25 ft (7.6 m) hose and meter

Portable Packages with 25 Gallon Dispense Cart

249783

249771

249821

Hurricane metered tapper unit

Hurricane 8 ft (2.4 m) hose and meter

Hurricane 25 ft (7.6 m) hose and meter

Portable Packages for 16 Gallon (60 l) Barrels

253487 Hurricane caster base with metered tapper

253486

253494

Hurricane caster base with 8 ft (2.4 m) hose and meter

Hurricane caster base with 25 ft (7.6 m) hose and meter

Accessories

253683 Hurricane caster base

36

249771 and 249821 Portable package with

25 gallon dispense cart

253486 and 253494 Portable package

16 gallon barrel not included

234902 and 249294

Hurricane with meter & hose

L U B R I C A T I O N E Q U I P M E N T

T R A N S F E R P U M P S

248918

Hurricane tapper unit

www.graco.com

APEX

and APEX On-Demand

Electric Transfer Pumps

APEX Transfer Pumps

• Available with 12 VDC, 115 VAC and 230 VAC electric motors

• Self-priming, positive displacement design

• Pumps petroleum- and synthetic-based lubricants up to 8 gpm (30 lpm)

• Built-in bypass valve

• Transfer used oil with inlet suction screen ( 260306)

• TENV electric motor for demanding environments, models 260105, 260106, 260108 and 260109

• System includes suction tube, fl uid hose, dispense valve and bung adapter for models 260100, 260101, 260102 and 260104

APEX On-Demand Dispensing Pumps

• On-demand sensing system automatically starts and stops the pump

• Low operating and installation costs

• Available in 12 VDC and 115 VAC

• TENV electric motor for demanding environments

• Extremely quiet pump operation

• Output fl ow is continuous and non-pulsating

• Inlet and outlet check valves with thermal relief valves included

Typical Applications

• Filling bulk tanks from drums

• Agricultural equipment

• Lubricant transfer from remote locations

• Filling in-plant machinery

• Construction equipment

• Evacuating used oil receivers

• Automotive and truck service garages

• Fleet marine and personal boat service

Typical Fluids Handled

• Synthetic oil • Used oil* • Anti-freeze

• Petroleum oil* • Non-fl ammable oil based solvents

*Not for food grade use

• Hydraulic fl uids • Cutting oils

• Oil-based herbicide carriers

APEX 115 VAC oil transfer system

APEX On-Demand

12 volt DC dispensing pump

Performance Charts by Part Number

80

(5.5, 0.5)

70

(4.8, 0.4)

60

(4.1, 0.4)

50

(3.4, 0.3)

40

(2.7, 0.2)

30

(2.0, 0.2)

20

(1.3, 0.1)

10

(0.6, 0.06)

A

C

B

0

gpm

0 2 4 6 8 10

(lpm) (7.6) (15.1) (22.7) (30.2) (37.8)

FLOW RATE

PART NUMBERS

A

= 260101, 260104

B

= 260100

C

= 260102

LEGEND

Relief valve opens

180

(12, 1.2)

160

(11, 1.1)

140

(9.6, 0.9)

120

(8.2, 0.8)

100

(6.8, 0.6)

80

(5.5, 0.5)

60

(4.1, 0.4)

40

(2.7, 0.2)

20

(1.3, 0.1)

A

B

C

D

700

(48.2, 4.8)

600

(41.3, 4.1)

500

(34.4, 3.4)

400

(27.5, 2.7)

300

(20.6, 2.1)

200

(13.7, 1.3)

100

(6.8, 0.6)

0

gpm

0 1 2 3 4 5 6 7 8 9

(lpm) (3.8) (7.6) (11.4) (15.1) (19) (22.7) (26.4) (30.2) (34)

0

C

A

B

D

E

gpm

0 1 2 3 4 5

(lpm) (3.7) (7.6) (11.3) (15.1) (18.9)

FLOW RATE

FLOW RATE

PART NUMBERS

A

= 260105, 260106

B

= 260108

C

= 260240

D

= 260109

LEGEND

Relief valve setting at 150 psi

(10.3 bar, 1.0 MPa)

PART NUMBERS

A

= 260112

B

= 260110

C

= 260111

D

E

= 260114

= 260113

LEGEND:

Pressure switch opens

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

T R A N S F E R P U M P S

37

APEX

and APEX On-Demand

Electric Transfer Pumps

APEX Transfer System

Part Number

Motor

Hertz

Horsepower

Maximum Current

Maximum Flow Rate

Maximum Pressure

Inlet Port

260100

12 VDC

NA

0.75

35 amps

5.8 gpm (22 lpm)

65 psi (4.5 bar)

1 npt(f)

260101

115 VAC

60 Hz

0.50

9.2 amps

4.25 gpm (16 lpm)

65 psi (4.5 bar)

1 npt(f)

Outlet Port

Weight

3/4 npt(f)

34 lbs (15 kg)

3/4 npt(f)

25 lbs (11 kg)

Instruction manual 311305 311305

Note: All oil transfer systems come with 3/4 in x 8 ft hose, 1 in x 34 in suction tube & 3/4 in outlet dispense valve

*Designed for fl uid viscosities of 1000 centistokes or less. If fl uid viscosity is greater than 1000 centistokes use part 260101.

APEX Transfer Pumps

Part Number

Motor

Hertz

Horsepower

Maximum Current

Maximum Flow Rate

Maximum Pressure

Inlet Port

Outlet Port

Weight

Instruction Manual

Note: All oil transfer pumps come with bung adapter.

*Part no. 260105 is a wall mount unit

APEX On-Demand Pumps

260105*

115 VAC

60 Hz

1.00

7.5 amps

3.0 gpm (11 lpm)

150 psi (10 bar)

1 npt

3/4 npt

25 lb (11 kg)

311306

260106

115 VAC

60 Hz

1.00

7.5 amps

3.0 gpm (11 lpm)

150 psi (10 bar)

1 npt

3/4 npt

25 lb (11 kg)

311306

Part Number

Voltage

Hertz

Horsepower

Maximum Current

Maximum Flow Rate

Maximum Pressure

Inlet Port

Outlet Port

260110

115 VAC

60 Hz

0.75

10 amps

2.3 gpm (9 lpm)

370 psi (25 bar)

3/4 npt

-12 JIC (m)

Weight 27 lb (12 kg)

Instruction Manual

Note: All on-demand pumps come with bung adapter

311307

260111

115 VAC

60 Hz

1.00

13 amps

3 gpm (11 lpm)

550 psi (38 bar)

3/4 npt

-12 JIC (m)

32 lb (15 kg)

311307

260113

115 VAC

60 Hz

1.50

18 amps

4.0 gpm (15 lpm)

470 psi (32 bar)

3/4 npt

-12 JIC (m)

41 lb (19 kg)

311307

260102*

115 VAC

0.75

9.0 amps

8.0 gpm (30 lpm)

30 psi (2.1 bar)

1 npt(f)

3/4 npt(f)

25 lbs (11 kg)

311305

260108

115 VAC

60 Hz

1.00

9.0 amps

4.0 gpm (15 lpm)

150 psi (10 bar)

1 npt

3/4 npt

25 lb (11 kg)

311306

260114

115 VAC

60 Hz

2.00

21 amps

4.0 gpm (15 lpm)

650 psi (45 bar)

3/4 npt

-12 JIC (m)

52 lb (24 kg)

311307

Accessories

260415

260145

Oil Meter with 3/4" npt inlet and outlet ports. Displays in quarts.

Wall Mounting Bracket, fi ts all models

260238

260306

260124

“Y” Strainer with 3/4" npt female in-line strainer for used oil transfer

Inlet Suction Screen Assembly, required for used oil applications, 20 mesh screen

55 in (1.3 m) PVC Suction Tube with inlet check valve

260104

230 VAC

50/60 Hz

0.50

3.9 amps

4.25 gpm (16 lpm)

65 psi (4.5 bar)

1 npt(f)

3/4 npt(f)

25 lbs (11 kg)

311305

260109

115 VAC

60 Hz

1.00

11.0 amps

8.0 gpm (30 lpm)

150 psi (10 bar)

1 npt

3/4 npt

30 lb (14 kg)

311306

260112

12 VDC

N/A

0.75

75 amps

3 gpm (11 lpm)

400 psi (28 bar)

3/4 npt

-12 JIC (m)

27 lb (12 kg)

311307

38

L U B R I C A T I O N E Q U I P M E N T

T R A N S F E R P U M P S

260415 Oil meter

www.graco.com

GTP10 and GTP12

Fuel Transfer Pumps

Features and Benefi ts

• Heavy-duty, die-cast aluminum

• CSA listed motor

• Built-in relief valve and fi lter strainer

• Easy-to-lock security

• High quality, UV resistant automotive fi nish

• Rain proof for extreme weather conditions

• Two year warranty

Typical Applications

• Fuel transfer for the construction, agriculture, manufacturing and marine industries

Typical Fluids Handled

• Gasoline

• Diesel fuel

• Kerosene

• Bio-fuels

Fuel Transfer Kit: Includes pump, fuel nozzle, bung adapter, 34 in (0.9 m) suction tube, 12 ft (3.7 m) grounded hose, elbow fi tting, 18 ft (5.5 m) power cable, wire nuts and strain relief

NOTE: AC units do not include power cable, wire nuts or strain relief

Ordering Information

Kit Number

Voltage

Inlet Port

Outlet Port

Current

Power Cord

Hose

Suction Tube

Weight

Max Fluid Flow

Instruction Manual

260000

12 VDC

1 npt

3/4 npt

12 amps

18 ft (5.5 m)

3/4 in x 12 ft (19 mm x 3.7 m)

1 in x 34 in (25 mm x 0.9 m)

20 lbs (9 kg)

10 gpm (38 lpm)

311304

260020

24 VDC

1 npt

3/4 npt

6 amps

18 ft (5.5 m)

3/4 in x 12 ft (19 mm x 3.7 m)

1 in x 34 in (25 mm x 0.9 m)

20 lbs (9 kg)

10 gpm (38 lpm)

311304

260025

115 VAC

1 npt

3/4 npt

1.7 amps

N/A

3/4 in x 12 ft (19 mm x 3.7 m)

1 in x 34 in (25 mm x 0.9 m)

20 lbs (9 kg)

12 gpm (45 lpm)

311304

260022

230 VAC

1 npt

3/4 npt

1 amps

N/A

3/4 in x 12 ft (19 mm x 3.7 m)

1 in x 34 in (25 mm x 0.9 m)

20 lbs (9 kg)

12 gpm (45 lpm)

311304

Accessories

260078 Unleaded nozzle

260083 Unleaded nozzle with auto shut-off

260082 Regular/diesel nozzle with auto shut-off

260079 Regular/diesel nozzle

260523 8 ft x 34 in (2.4 m) npt UL Listed hose

260521 12 ft x 3/4 in (3.7 m) npt UL Listed hose

260083

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

T R A N S F E R P U M P S

39

Lube Truck Package Solutions

Fire-Ball

®

Oil and Grease Packages

Oil Package Selection and Ordering Information

Ratio

Container Size

Package No.

Bare Pump Only

Hose/Fitting Kit

Hose Length

Air Regulator

Hold-Down Kit

Drum Cover

Bung Adapter

Pump Clamp

Instruction Manual

-

307883

-

307883

204095

307883

-

307883

* For closed-head drums, pump mounts off-center on drum cover. Pump draws through standard 2 npt bung opening and is equipped with grommet for rain-tight seal to the drum cover.

(1)

Order 3/8 in (9.5 mm) air regulator and gauge separately, ( 109075).

(2)

Order 1/2 in (12.7 mm) air regulator ( 104266) and gauge ( 100960) separately.

(3) Off set drum cover

Grease Package Selection and Ordering Information

Fire-Ball 300

Cover-Mounted

Package

Fire-Ball 300

Cover-Mounted

Package

Fire-Ball 425

Cover-Mounted

Package

Fire-Ball 425

Cover-Mounted

Package

Fire-Ball 425

Cover-Mounted

Package

Ratio 50:1 50:1 50:1 50:1 75:1

Container Size

Package No.

Bare Pump Only

Hose/Fitting Kit

Hose Length

Air Regulator

Fire-Ball 300

Cover-Mounted Package

5:1

16 gal (60 l) Open-head

222086

203872

222063

6 ft (1.8 m)

(1)

222061

222060

-

120 lb (55 kg)

Open-head

222085

239887

222072

6 ft (1.8 m)

*

Hold-Down Kit

Drum Cover

222061

222060

Follower Plate

Instruction Manual

220654

307880

* Order 3/8 in (9.5 mm) air regulator and gauge separately, ( 109075).

** Order 1/2 in (12.7 mm) air regulator ( 104266) and gauge ( 100960).

Fire-Ball 300

Cover-Mounted Package

5:1

55 gal (200 l) Closedhead*

206655

203857

222063

6 ft (1.8 m)

(1)

207361

207367

-

400 lb (180kg)

Open-head

222071

239888

222072

6 ft (1.8 m)

*

207361

207366

223845

307880

Fire-Ball 300

Bung-Mounted Package

5:1

55 gal (200 l) Closedhead*

207361

-

204076 (2.140 in Dia.)

120 lb (55 kg)

Open-head

223107

205394

222076

6 ft (1.8 m)

**

222061

222060

223344

307880

204264

204254

222063

6 ft (1.8 m)

(1)

400 lb (180 kg)

Open-head

222075

205395

222076

6 ft (1.8 m)

**

207361

207366

223846

307880

Fire-Ball 425

Cover-Mounted Package

10:1

55 gal (200 l) Closedhead*

206656

222065

222066

6 ft (1.8 m)

(2)

207361

207367

(3)

-

120 lb (55 kg)

Open-head

243817

239729

222076

6 ft (1.8 m)

**

222061

222060

223344

307880

Fire-Ball 425

Bung-Mounted Package

10:1

55 gal (200 l) Closedhead*

222067

222095

222066

6 ft (1.8 m)

(2)

207361

-

224579 (2.159 in Dia.)

204095

307883

Fire-Ball 425

Cover-Mounted

Package

75:1

400 lb (180 kg)

Open-head

243818

239730

222076

6 ft (1.8 m)

*

207361

207366

223846

307880

222086

206656

40

L U B R I C A T I O N E Q U I P M E N T

S P E C I A L T Y P U M P S

222067

223107

243818

www.graco.com

Undercoating/Rust-Proofi ng Packages

Fire-Ball

®

300, 15:1 Packages

Features and Benefi ts

• Available in carbon steel for petroleum-based or SST for water-based materials

• Durable air motor provides trouble-free operation

Typical Applications

• Undercoating, rust-proofi ng and sound-deadening materials

• Automotive and heavy-duty vehicle dealerships

• Fast lube centers and service shops

• Fleet service facilities

Typical Fluids Handled

• Undercoating and rust-proofi ng

(verify chemical compatibility for pump’s wetted components with undercoating material supplier or contact Graco directly at 1-800-533-9655)

226269

224826

Pump Performance psi

(bar) cycles/min

(83)

900

(62)

600

(41)

300

(21)

0

gpm

(lpm)

90 scfm

(m3/min)

12

(0.34)

9

(0.26)

6

(0.17)

0.25 .50 .75 1

(0.95) (1.7) (2.9) (3.8)

3

(0.08)

TEST FLUID: No. 10 Weight Oil

Inlet Air Pressures:

=100 psi

(6.9 bar)

=70 psi

(4.8 bar)

=40 psi

(2.8 bar)

Technical Specifi cations

Maximum Fluid Pressure ......................................................... 2700 psi (186 bar)

Effective Air Motor Diameter ......................................................... 3 in (76.2 mm)

Operating Range ......................................................... 40-180 psi (2.8-12.5 bar)

Continuous-Duty Flow Rate ..................................................... . 0.7 gpm (2.7 lpm)

Approx. Air Consumption @ 100 psi (7 bar) ............................................... 17 cfm

Air Inlet ............................................................................................... 3/8 npt(f)

Material Outlet ..................................................................................... 1/4 npt(f)

Material Inlet for Non-SST Pump ............................................. 1 npt (straight inlet)

Material Inlet for 224825 (SST Pump) ..................................... 1 npt (barbed inlet)

Wetted Parts for Non-SST Pump .............................. CS, Aluminum, PTFE, Rubber

Wetted Parts for SST pump ....................... SST, Aluminum, Leather, PTFE, Rubber

Instruction Manual for non-SST Pump ..................................................... 306531

Instruction Manual for SST Pump ............................................................ 308069

Ordering Information

Style

Container Size

Package No.

Pump

Dispense Kit

Tip

Portable

35 lb (16 kg)

222077

206405

222079

286517

Undercoating

Portable Dolly-Mounted

120 lb (54 kg)

226342

206699

222079

286517

Stationary

400 lb (180 kg)

226269

206700

222082

286517

Hose Length

Cover

15 ft (4.6 m)

222058

15 ft (4.6 m)

204574

25 ft (7.6 m)

200326

Caster Base

Instruction Manual

-

307879/ 306531

204144

307879/ 306531

* Package 224826 includes fl exible short tube (224022) long enough for 400 lb (180 kg) container, but can be trimmed to accommodate smaller containers.

-

307879/ 306531

Spray Masking

Bung-Mounted Stationary

400 lb (180 kg)

224826*

224825 (SST pump)

224023

286211 / 286621

25 ft (7.6 m)

-

-

308069

214570

234237

239966

60-mesh Aluminum fi lter (3/8 npt(f) inlet; 1/4 npt(f) outlet). Maximum working pressure: 3000 psi (210 bar)

Replacement Screen Elements (SST) 3-pack/25-pack

|

238435/ 238436

30-mesh |

238437/ 238438

60-mesh |

238439/ 238440

100-mesh

202577

206496

Z-Swivel allows non-binding movement for hard-to-reach spots. Order 155570 adapter separately to accommodate 234237 gun.

Nozzle Extension delivers 360º coating fan into blind areas. Length 30-3/4 in (99 cm) x 7/8-14(f) end. Tip 206502, size .043.

4 Finger Silver Gun with tip guard 243161 and tip 286517. 4500 psi (310 bar) x 3/8 npt(f) inlet. Must order 155570 adapter and 239663 straight swivel to accommodate gun to 1/4” (mbe) hose.

Bung Adapter

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

S P E C I A L T Y P U M P S

41

Windshield Wash and Coolant Dispense

Pump Package Solutions

Packages for Pre-Mixed Windshield Wash Solvent and Coolant Dispense

307 Air-Operated Double-Diaphragm Pump

237161 Complete package includes the following: 307 Diaphragm Pump ( D31255), 6 ft (1.8 m) air hose ( 109125), 4 ft (1.2 m) coupled nitrile fl uid hose ( 220596), air fi lter ( 110146), air gauge ( 108190), air line fi tting ( 111511), 1/4 npt air regulator ( 110318), elbow ( 100611), 15 in (381 mm) 3/8 in ID tube, ( 187479), mounting bracket ( 190125), adapter ( 156022), 1/4-18 npt nipple ( 156971), suction hose kit ( 223888), 6 ft (1.8 m) coupled PVC hose and 304 SST 16 mesh strainer, wall bracket ( 224835).

237160 Includes all items listed above except diaphragm pump and wall bracket.

Bulk Anti-Freeze and Windshield Solvent Transfer Packages

Description 1040 AODD

Dual Inlet

1040 AODD

Single Inlet

Package Number

Pump

Air Regulator

Fluid Connect Hose

Air Connect Hose

Air Shut-off Valve

Wall Mount Bracket

Dual Inlet Manifold

Suction Kit

Thermal Relief Kit

Instruction Manual

244679

647016

109075

115042

205418

110224

24C637

685984

2- 236054

238428

309353

244680

647016

109075

115042

205418

110224

24C637

236054

238428

309353

716 AODD

Dual Inlet

244681

243669

110147

109105

109125

110223

224835

2- 236054

113497

309353

716 AODD

Single Inlet

244682

241906

110147

109105

109125

110223

224835

236054

113497

309353

42

L U B R I C A T I O N E Q U I P M E N T

S P E C I A L T Y P U M P S

www.graco.com

Dyna-Star

®

and Power-Star

Pumps

For Oil Applications

Features and Benefi ts

• Ties into existing hydraulic systems on mobile equipment

• Operates quieter than air driven pumps and doesn’t require muffl ers

• Eliminates the need for air compressors

• Provides self-lubrication for long life and reliability

• Hydraulic changeover is faster with less pulsation allowing smoother output pressure, even with long plumbing runs

Typical Applications

• Low pressure, high volume oil transfer

• High pressure, high volume grease dispense

• Heavy-duty dealerships

• Fleet service facilities

• Service shops

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Petroleum- and synthetic-based oils

• Grease up to NLGI #2

Ordering Information for Oil Packages

Oil Applications Power-Star, 1:1 Dyna-Star

®

, 1:1

Drum Size Universal

Pump Number

Max. Input Pressure

Max. Fluid Input Volume

236754

1500 psi (102 bar)

12 gpm (45.4 lpm)

Max. Output Flow Rate

Maximum CPM

12 gpm (45.4 lpm)

60

Max. Fluid Output Pressure 1500 psi (102 bar)

Hydraulic Supply Inlet 3/4 npt

Hydraulic Return Outlet 1-1/4 npt

Fluid Outlet

Fluid Inlet

Max. Incoming Fluid Temp.

Instruction Manual

Applications

1/2 npt

1-1/2 npt

130º F (54º C)

308391

Bulk oil transfer

Universal

224741

1500 psi (102 bar)

3 gpm (11.4 lpm)

3 gpm (11.4 lpm)

60

1500 psi (102 bar)

3/8 npt

3/4 npt

1/2 npt

1-1/2 npt

130º F (54º C)

308155

Oil dispensing

Dyna-Star, 1:1

55 gal (200 l) Bung- or

Cover-Mounted

224742

1500 psi (102 bar)

3 gpm (11.4 lpm)

3 gpm (11.4 lpm)

60

1500 psi (102 bar)

3/8 npt

3/4 npt

1/2 npt

1-1/2 npt

130º F (54º C)

308155

Oil dispensing

Dyna-Star, 1/4:1

Universal

236753

1500 psi (102 bar)

3 gpm (11.4 lpm)

10 gpm (37.9 lpm)

60

375 psi (25.1 bar)

3/8 npt

3/4 npt

1/2 npt

1-1/2 npt

130º F (54º C)

308390

Bulk oil transfer

Stainless Steel Dyna-Star, 1:1

Universal

237653

1000 psi (70 bar)

3 gpm (11.4 lpm)

3 gpm (11.4 lpm)

60

1500 psi (102 bar)

3/8 npt(f)

3/4 npt(f)

1/2 npt(f)

1-1/2 npt

130º F (54º C)

308155

Anti-freeze dispensing

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

H Y D R A U L I C P U M P S

43

Dyna-Star

®

and Viscount

®

II Pumps

For Oil and Grease Applications

Ordering Information for Grease Packages

Grease Applications

Part No. – Drum Size

Dyna-Star, 5:1

224912 – 35 lb (16 kg)

224751 – 120 lb (55 kg)

224752 – 400 lb (180 kg)

Max. Input Pressure

Max. Hydraulic Fluid Input Vol.

Max Grease Flow Output Rate

Maximum CPM

Max. Fluid Output Pressure

Hydraulic Supply Inlet

Hydraulic Return Outlet

Fluid Outlet

Maximum Incoming

Hydraulic Fluid Temp.

Instruction Manual

1500 psi (102 bar)

3 gpm (11.4 lpm)

4 lb/min (1.8 kg)

60

7500 psi (517 bar)

3/8 npt

3/4 npt

1/2 npt

130º F (54º C)

308156

Dyna-Star, 10:1

247540 – 60 lb (27 kg)

247443 – 120 lb (55 kg)

247450 – 400 lb (180 kg)

600 psi (41 bar)

3 gpm (11.4 lpm)

1.1 lb/min (0.5 kg)

60

7500 psi (517 bar)

3/4-16 in. JIC (37º Flare)

3/4 npt

1/2 npt

200ºF (93ºC)

312350

Viscount II, 2.4:1

222902 – 400 lb (180 kg)

1500 psi (102 bar)

12 gpm (45.4 lpm)

54 lb/min (20.4 kg)

60

2300 psi (159 bar)

3/4 npt

1 npt

1-1/2 npt

130ºF (54ºC)

308149

Hydraulic Fluid Controls (Required for each pump)

236864

Dyna-Star Fluid Controls [1500 psi (102 bar); 3 gpm (11.4 lpm)]. Includes manifold with pressure-reducing valve, fl ow control valve, pressure gauge, shut-off ball valves and 3 ft (0.9 m) supply and return hoses. Instruction manual 308395.

236865

Power-Star and Viscount II Fluid Controls [1500 psi (102 bar); 12 gpm (45.4 lpm)]. Includes manifold with pressure-reducing valve, fl ow control valve, pressure gauge, shut-off ball valves and 3 ft (0.9 m) supply and return hoses. Instruction manual 308395.

237904 1:1 Dyna-Star Thermal Relief Valve, 1600 psi (110 bar)

235998 Mini Fire-Ball 225, 3:1 thermal relief valve rated to 600 psi (41 bar)

Accessories

Follower Plates

224916 Follower plate for 35 lb (16 kg)

223700 Follower plate for 120 lb (55 kg)

223701 Follower plate for 400 lb (180 kg)

Covers

224915

204574

200326

Cover for 35 lb (16 kg)

Cover for 120 lb (55 kg)

Cover for 400 lb (180 kg)

Tie-Down Covers

222060* Tie-Down Cover for 120 lb (55 kg)

207366** Tie-Down Cover for 400 lb (180 kg)

*Use with hold-down kit 222061 **Use with hold-down kit 207361

222902

44

L U B R I C A T I O N E Q U I P M E N T

H Y D R A U L I C P U M P S

236754

224741

247540

www.graco.com

Manual Pumps

For Oil and Grease

16 Gallon (60 l) Metered and Non-Metered Dispensing Packages

Designed for manual dispensing of fl uid oil from bulk containers to point of application.

Description

Portable Metered

ATF Dispenser

Portable Metered

Gear Lube Dispenser

Cart-Mounted Metered

Gear Lube Dispenser

Package No.

Pump Only

Metered Dispense Kit

Dispense Kit

Hose Diameter

Hose Length

Drum Cover

Caster Base

Cart

Instruction Manual

* Hydraulic; can be used for gear oil dispensing.

225880

204867

239707

-

-

-

204574

203622

-

306436

225376

204867

239705

-

-

-

204574

203622

-

306436

225384

204867

239705

-

1/2 in (12.7 mm)

6 ft (1.8 m)

204574

-

203650

306436

Stationary Non-Metered

Gear Lube Dispenser

225380

204867

-

214658

1/2 in (12.7 mm)

6 ft (1.8 m)

204574

-

-

306436

Portable Non-Metered

Gear Lube Dispenser

225378 *

204867

-

214658

1/2 in (12.7 mm)

6 ft (1.8 m)

204574

203622

-

306436

Pail Dispensing Package for 5 gal (20 l) Pails

Mounts on top of a standard 5 gal (20 l) pail (pail not included). Delivery hose has curved nozzle that stores in cover port.

Description Economy Gear-Lube Dispenser (Dispenses 1.6 to 1.9 oz. [47.3 to 56.2 ml] per stroke)

Package No.

Hose length

Instruction manual

226289

4 ft (1.2 m)

306875

225380

225376

225880

www.graco.com

226289

225378

225384

L U B R I C A T I O N E Q U I P M E N T

M A N U A L P U M P S

45

Manual Pumps

For Fluid Transfer

Pumping Bulk Lubricants out of 16 gal (60 l) or 55 gal (200 l) Drums

(1)

All pumps come with suction tube and bung adapter.

Description Lever Pump

(2)

Pump Number 114829

Rotary Pump

(3)

226290

Delivery rate

Fluids Handled

Hose Length

0.1 gal (0.4 l) per downstroke

Petroleum-based products, Anti-freeze

-

1 gal (3.7 l) per 18 cycles

Petroleum-based products

-

Instruction manual 308896 306876

(1) Drums not included

(2) Telescopic suction tube mounts 2 npt bung opening of 16 gal (60 l) or 55 gal (200 l) drum. Package includes bung adapter and spout outlet.

(3)

Package has adjustable 2 npt bung mounting to allow use with either 16 gal (60 l) or 55 gal (200 l) drum. Package includes bung adapter and spout outlet.

(4) A double-action high volume pump for gasoline and similar petroleum products. Fits 30 gal (113 l) to 55 gal (200 l) drum. Complete with an 8 ft (2.4 m) hose with 3/4 in fi ttings and aluminum telescoping suction pipe. Delivers approximately one gallon per nine strokes.

(5) This package is recommended for gasoline, diesel, heating oil and petroleum products, but NOT recommended for water-based fl uids, solvents or weak acids.

Hand-Lever Diaphragm Pump

(4)

112202

1 gal (3.7 l) per 9 cycles

Petroleum-based products

(5)

8 ft (2.5 m)

-

Manual Dispense from Bulk Containers

Description

Container Size

Package No.

Pump

Dispense Kit

Buckshot Luber with Booster Gun

35 lb (16 kg)

225914 (1)

203702

203703

Buckshot Luber without Booster Gun

35 lb (16 kg)

225844 (1)

203702

203703

Grease Gun

Fill Pump

35 lb (16 kg)

112197

-

(2)

Filler Adapter (3)

Grease Gun

Fill Pump

120 lb (55 kg)

112198

-

(2)

Filler Adapter (3)

Booster Gun

Cover and Follower Plate

203697

203701

-

203701

-

-

Instruction Manual 306455 306455 -

(1) Delivers 1/4 oz (0.7 grams) of grease per stroke at pressures to 3000 psi (207 bar). Can service fi ttings directly or be used to charge a booster gun for more effi ciency at higher pressures.

(2)

Fills all three-way loading grease guns equipped with fi ller fi ttings. See instruction manual 308306 for fi lling adapters.

(3) Dispense kit 203703 can be used for direct greasing applications (must be ordered separately).

-

-

-

114829

112197

226290

46

L U B R I C A T I O N E Q U I P M E N T

M A N U A L P U M P S

112202

(2 inch bung adapter, (2) 3/4 in npt(f) inlets, includes down tube and hose)

225914

112198

www.graco.com

Hose Reels

Selection Guide

Hose Reel LD Series SD Series

Hose Length Up to 65 ft (19.8 m)

Typical Application • Small maintenance shops

• Tire/muffl er shops

• Small fast lubes

• Independent repair facilities

• Industrial manufacturing facilities

• Car dealerships

• Light/medium-duty truck dealers

• Fleet maintenance

• Mining maintenance

• Public works garages

• Construction vehicle maintenance

• Light-utility service trucks

Typical Fluids • Petroleum– and synthetic–based oils

• Grease

• Air only

• Air/water

• Anti-freeze

• Windshield washer

• Petroleum– and synthetic–based oils

• Grease

• Air

• Water

• Anti-freeze

• Windshield washer

Enclosed Enclosed Enclosure available

XD Series

Up to 75 ft (22.9 m)

• Heavy-duty truck dealers

• Fleet maintenance

• Mining maintenance

• Public works garages

• Construction vehicle maintenance

• Heavy-duty mobile service trucks

• Mining

700 Series

75 ft (22.9 m)

• Extreme-duty

• Auto dealers

• Heavy-duty dealers

• Fleet service

• Service shops

• In-plant

• Lube trucks

• Mining

• Petroleum– and synthetic–based oils

• Grease

• Fuel evacuation

• Pressure wash

• Air

• Water

• Anti-freeze

• Windshield washer

• Petroleum– and synthetic–based oils

• Air

• Water

• Anti-freeze

• Windshield wash

• Used oil and anti-freeze

• Fuel

750 Series

50 ft (15.2 m)

• Extreme-duty

• Heavy-duty dealers

• Fleet service

• Service shops

• In-plant

• Lube trucks

• Mining

• Petroleum– and synthetic–based oils

• Water

• Anti-freeze

• Unleaded and diesel fuels

Enclosure available

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

47

LD Series

Enclosed Hose Reels

Features

• Designed for light-duty applications

• Enclosed for safety and protection, extends hose life

• Flexible mounting options–hang on wall or ceiling; bench, table or tank top-mount options are available

• Full-fl ow swivel maximizes fl uid fl ow with minimal pressure drop

• Easy spring tension adjustment–increase or decrease pressure spring tension while reel is pressurized

• Installs in minutes (with included swivel bracket)

• Inlet hose kit sold separately (see accessories)

Enclosed hose reel comes with ceiling/wall mounting swivel bracket.

Required inlet hose kit sold separately.

D

A

B

C

Dimensions

LD SERIES

7.1 in (180 mm)

23.0 in (585 mm)

18.5 in (470 mm)

25.6 in (650 mm)

A

D

B

C

Ordering Information Technical Specifi cations

Applications

Air Only

Air/Water

Petroleum– and

Synthetic–based

Oils

Grease

Model

Numbers

HEL13D

HEL15D

HEL23D

HEL25D

HEL33D

HEL34D

HEM23D

HEM33D

HEH13D

Pressure psi (bar)

Hose id x Length

250 (17.2) 6 mm x 11 m 1/4 in x 35 ft

250 (17.2)

250 (17.2)

250 (17.2)

250 (17.2)

250 (17.2)

1800 (124)

1800 (124)

5000 (345)

6 mm x 15 m

10 mm x 11 m 3/8 in x 35 ft

10 mm x 15 m 3/8 in x 50 ft

12 mm x 11 m 1/2 in x 35 ft

12 mm x 14 m 1/2 in x 45 ft

10 mm x 11 m 3/8 in x 35 ft

12 mm x 11 m 1/2 in x 35 ft

6 mm x 11 m

1/4 in x 50 ft

1/4 in x 35 ft

Connection Size

Inlet bspp(m) x Outlet bspt(m)

1/2 in x 1/4 in

1/2 in x 1/4 in

1/2 in x 3/8 in

1/2 in x 3/8 in

1/2 in x 1/2 in

1/2 in x 1/2 in

1/2 in x 3/8 in

1/2 in x 1/2 in

3/8 in x 1/4 in

14–140º F

(-10–60º C)

0–140º F

(-17–60º C)

0–140º F

(-17–60º C)

0–140º F

(-17–60º C)

0–140º F

(-17–60º C)

0–140º F

(-17–60º C)

Operating

Temp.

14–140º F

(-10–60º C)

0–140º F

(-17–60º C)

0–140º F

(-17–60º C)

WETTED

PARTS

Aluminum,

Buna-N, Rubber,

PVC

Aluminum,

Buna-N, Rubber,

PVC

Aluminum,

Buna-N, Rubber

Aluminum,

Buna-N, Rubber

Aluminum,

Buna-N, Rubber

Aluminum,

Buna-N, Rubber

Carbon Steel,

Buna-N, Rubber,

UHMWPE

Carbon Steel,

Buna-N, Rubber,

UHMWPE

Carbon Steel,

Buna-N, Rubber,

UHMWPE

WEIGHT

9 kg

(19.8 lb)

9.5 kg

(21 lb)

10.4 kg

(23 lb)

11 kg

(24.25 lb)

10.5 kg

(23.1 lb)

11 kg

(24.3 lb)

11.4 kg

(25.1 lb)

14 kg

(38.8 lb)

13.2 kg

(29.1 lb)

Instruction Manual: 313938

48

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

www.graco.com

SD Series

Composite Spool Hose Reels

Features

• Designed for standard-duty applications such as small service garages and repair shops

• Structurally reinforced frame doesn’t fl ex when handling hose

• Guide arm position easily changes for mounting on bench, ceiling or wall

• Enamel fi nish protects the reel from the environment

• Lightweight composite spool made from high strength resins resists dents and corrosion

• Compact design easily fi ts inside tool bench or cabinet

• Enclosure kits available–ideal when appearance and protection is important (see accessories)

• Available in six colors. Metallic blue is standard.

• Inlet hose kit sold separately (see accessories)

Single pedestal with composite spool.

Inlet hose kit sold separately.

E

F

C

D

A

B

Dimensions

SD SERIES

7.0 in (177 mm)

18.1 in (460 mm)

23.4 in (594 mm)

19.2 in (488 mm)

21.8 in (554 mm)

25.2 in (640 mm)

A

F E

C

D

B

Ordering Information

Applications

Air, water, antifreeze, windshield washer fl uid

Metallic

Blue

Model Numbers by Color

White Red

Technical Specifi cations

Pressure

Black Dark Blue Yellow psi (bar) ID

Hose

Length ft (mt)

HRL56B HRL56A HRL56C HRL56D HRL56E HRL56F 300 (20.7) 3/8 in 65 (20)

HRL65B HRL65A HRL65C HRL65D HRL65E HRL65F 300 (20.7) 1/2 in 50 (15)

Connection Size

Inlet npsm(m)

Outlet

1/2

Operating

Temp.

3/8 npt(m)

-20º – 190º F

(-28º – 87º C)

1/2 1/2 npt(m)

-20º – 190º F

(-28º – 87º C)

Petroleum– and synthetic–based oils

HRM65B HRM65A HRM65C HRM65D HRM65E HRM65F 2,000 (138) 1/2 in 50 (15) 1/2 1/2 npt(m)

-20º – 190º F

(-28º – 87º C)

Grease HRH55B HRH55A HRH55C HRH55D HRH55E HRH55F 4,000 (276) 3/8 in 50 (15) 3/8 1/4 npt(m)

-40º – 200º F

(-40º – 93º C)

Wetted parts–bare hose reel only: zinc plated steel, anodized aluminum, nitrile rubber

Dry Weight: 44 lbs (20 kg)

Instruction Manual: 313431

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

49

SD Series

Steel Spool Hose Reels

50

Features

• For daily use applications, such as dealerships, fl eet service and maintenance facilities

• Structurally engineered frame made from high strength steel won’t bend or fl ex

• Long-lasting spring provides constant spring torque through the entire range of motion

• Flexible positioning of guide arm for mounting on bench or ceiling, wall or utility truck

• Steel spool for demanding applications

• Open swivel ports ensure high fl uid fl ow with minimal pressure loss

• Enclosure kits available–ideal when appearance and protection is important

• Available in six colors. Metallic blue is standard.

• Inlet hose kit sold separately (see accessories)

Single pedestal with metal spool.

Inlet hose kit sold separately.

Dimensions

D

E

B

C

F

A

SD SERIES SIZE 10

7.0 in (177 mm)

16.2 in (412 mm)

21.0 in (533 mm)

17.1 in (435 mm)

19.5 in (495 mm)

22.5 in (571 mm)

B

C

D

E

F

A

SD SERIES SIZE 20

7.0 in (177 mm)

18.1 in (460 mm)

23.4 in (594 mm)

19.2 in (488 mm)

21.8 in (554 mm)

25.2 in (640 mm)

A

F E

C

D

B

Ordering Information

Applications

Model numbers by color

Metallic

Blue

White Red Black Dark Blue Yellow

HPL23B HPL23A HPL23C HPL23D HPL23E HPL23F

Technical Specifi cations

Pressure Hose psi (bar) id

(in)

Length ft (mt)

300 (20.7) 3/8 35 (11)

Connection Size

Inlet npsm(m)

1/2

Outlet

3/8 npt (m)

Air, Water,

Anti-freeze,

Windshield

Washer Fluid

HPL25B HPL25A HPL25C HPL25D HPL25E HPL25F

HPL33B HPL33A HPL33C HPL33D HPL33E HPL33F

HPL56B HPL56A HPL56C HPL56D HPL56E HPL56F

300 (20.7) 3/8 50 (15)

300 (20.7) 1/2 35 (11)

300 (20.7) 3/8 65 (20)

HPL65B HPL65A HPL65C HPL65D HPL65E HPL65F 300 (20.7) 1/2 50 (15)

HPM33B HPM33A HPM33C HPM33D HPM33E HPM33F 2,000 (138) 1/2 35 (11)

Petroleum– or Synthetic– based Oils

HPM3BB* HPM3BA* HPM3BC* HPM3BD* HPM3BE* HPM3BF* 2,000 (138) 1/2 35 (11)

HPM65B HPM65A HPM65C HPM65D HPM65E HPM65F 2,000 (138) 1/2 50 (15)

HPM6DB* HPM6DA* HPM6DC* HPM6DD* HPM6DE* HPM6DF* 2,000 (138) 1/2 50 (15)

HPH15B HPH15A HPH15C HPH15D HPH15E HPH15F 5,000 (345) 1/4 50 (15)

HPH23B HPH23A HPH23C HPH23D HPH23E HPH23F 4,000 (276) 3/8 35 (11)

Grease HPH1DB* HPH1DA* HPH1DC* HPH1DD* HPH1DE* HPH1DF* 5,000 (345) 3/8 35 (11)

HPH55B HPH55A HPH55C HPH55D HPH55E HPH55F 4,000 (276) 3/8 50 (15)

HPH5DB* HPH5DA* HPH5DC* HPH5DD* HPH5DE* HPH5DF* 4,000 (276) 3/8 50 (15)

* Bare Reel–hose sold separately

Wetted parts–bare hose reel only: zinc plated steel, steel, nitrile rubber Dry Weight: 52 lbs (23.5 kg) Instruction Manual: 313431

1/2

3/8

3/8

3/8

1/2

1/2

3/8

3/8

1/2

1/2

1/2

1/2

1/2

3/8 npt (m)

1/2 npt (m)

3/8 npt (m)

1/2 npt (m)

1/2 npt (m)

1/2 npsm (f)

1/2 npt (m)

1/2 npsm (f)

1/4 npt (m)

1/4 npt (m)

1/4 npt (f)

1/4 npt (m)

1/4 npt (f)

Operating

Temp.

-20º–190º F

(-28º–87º C)

-40º–200º F

(-40º–93º C)

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

www.graco.com

XD Series

Hose Reels

Size 10

Size 20

Size 30

Features

• For robust/heavy-duty applications such as mobile lube trucks or large equipment service, yet with a narrow footprint to fi t more reels into small spaces

• Dual pedestal frame provides increased strength for extreme-duty applications

• Long lasting spring is sealed for protection against the weather

• Durable steel spool rides on sealed roller bearings to ensure trouble-free performance

• Available in four colors. Metallic blue is standard.

• Available with arms removed for bulkhead mounting (see installation manual)

• Inlet hose kit sold separately (see accessories)

• Installation manual: 3A0138

Dimensions

D

E

F

A

B

C

XD SERIES SIZE 10

7.5 in (196 mm)

16.2 in (412 mm)

21.0 in (533 mm)

18.0 in (457mm)

18.5 in (470 mm)

22.5 (571 mm)

A

XD SERIES SIZE 20

A 7.5 in (196 mm)

B 18.1 in (460 mm)

C 23.4 in (594 mm)

D 20.0 in (508 mm)

E 21.0 in (533 mm)

F 25.2 in (640 mm)

E

F

C

B

D

NOTE: Hose Inlet Kit for all XD Reels sold separately.

www.graco.com

B

C

D

E

F

XD SERIES SIZE 30

A 9.0 in (229 mm)

21.50 in (546.00 mm)

25.96 in (659.45 mm)

22.12 in (561.73 mm)

23.10 in (588.00 mm)

27.60 in (700.82 mm)

A

E

F

C

D

B

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

51

XD Series

Hose Reels

Ordering Information

Applications

Metallic Blue

Model numbers by color

White

Technical Specifi cations

Pressure

Yellow Desert Sand psi (bar) id in

Hose

Length ft (m)

Connection Size

Inlet in

Outlet in

HSL25B HSL25A HSL25F HSL25G 300 (20.7) 3/8 50 (15) 1/2 npsm(m) 3/8 npt(m)

Air, water,

Anti-freeze, windshield

Washer fl uid

HSL33B

HSL56B

HSL65B

HSL33A

HSL56A

HSL65A

HSL33F

HSL56F

HSL65F

HSL33G

HSL56G

HSL65G

300 (20.7)

300 (20.7)

300 (20.7)

1/2

3/8

1/2

35 (11) 1/2 npsm(m) 1/2 npt(m)

65 (20) 1/2 npsm(m) 3/8 npt(m)

50 (15) 1/2 npsm(m) 1/2 npt(m)

HSLC8B HSLC8A HSLC8F HSLC8G 300 (20.7) 1/2 75 (23) 1/2 npsm(m) 1/2 npt(m)

Petroleum– and synthetic– based oils

Grease

HSLD5B HSLD5A

HSM33B HSM33A

HSLD5F HSLD5G 300 (20.7) 3/4 50 (15) 3/4 npsm(m) 3/4 npt(m)

HSM33F HSM33G 2,000 (138) 1/2 35 (11) 1/2 npsm(m) 1/2 npt(m)

HSM3BB * HSM3BA * HSM3BF * HSM3BG * 2,000 (138) 1/2 35 (11) 1/2 npsm(m) 1/2 npt(f)

HSM65B HSM65A HSM65F HSM65G 2,000 (138) 1/2 50 (15) 1/2 npsm(m) 1/2 npt(m)

HSM6DB * HSM6DA * HSM6DF * HSM6DG * 2,000 (138) 1/2 50 (15) 1/2 npsm(m) 1/2 npt(f)

HSMC8B HSMC8A HSMC8F HSMC8G 1,500 (103) 1/2 75 (23) 1/2 npsm(m) 1/2 npt(m)

HSMCFB * HSMCFA * HSMCFF * HSMCFG * 2,000 (138) 1/2 75 (23) 1/2 npsm(m) 1/2 npsm(f)

HSMD5B HSMD5A HSMD5F HSMD5G 1,250 (86) 3/4 50 (15) 3/4 npsm(m) 3/4 npt(m)

HSMDDB * HSMDDA * HSMDDF * HSMDDG * 2,000 (138) 3/4 50 (15) 3/4 npsm(m) 3/4 npsm(f)

HSH15B HSH15A HSH15F HSH15G 5,000 (345) 1/4 50 (15) 3/8 npsm(m) 1/4 npt(m)

HSH1DB * HSH1DA * HSH1DF * HSH1DG * 5,000 (345) 3/8 35 (11) 3/8 npsm(m) 3/8 npt(f)

HSH55B HSH55A HSH55F HSH55G 4,000 (276) 3/8 50 (15) 3/8 npsm(m) 1/4 npt(m)

HSH5DB* HSH5DA* HSH5DF* HSH5DG* 5,000 (345) 3/8 50 (15) 3/8 npsm(m) 3/8 npsm(f))

HSHC5B

HSPB8B

HSHC5A

HSPB8A

HSHC5F HSHC5G 5,000 (345) 1/2 50 (15) 1/2 npsm(m) 1/2 npt(m)

HSHCDB * HSHCDA * HSHCDF * HSHCDG * 5,000 (345) 1/2 50 (15) 1/2 npsm(m) 1/2 npsm(f)

HSPB8F HSPB8G 4,000 (276) 3/8 75 (23) 1/2 npsm(m) 3/8 npt(m)

Pressure wash

HSHFFB * HSHFFA * HSHFFF * HSHFFG * 4,000 (276) 3/8 75 (23) 1/2 npsm(m) 3/8 npsm(f)

1 30 (9) 3/4 npsm(m) 1 npt(m)

Operating

Temp.

-

40–180º F

(-40–82º C)

-

40–180º F

(-40–82º C)

-

40–200 ºF

(-40º–93 ºC)

-

40–200 ºF

(-40º–93 ºC)

-

40–200 ºF

(-40º–93 ºC)

-

40–200 ºF

(-40º–93 ºC)

-

40–180 ºF

(-40–82 ºC)

-

40–180 ºF

(-40–82 ºC)

-

20–225º F

(-28–107º C)

-

20–190º F

(-28–87º C)

-

20–190º F

(-28–87º C)

-

20–190º F

(-28–87º C)

-

20–190º F

(-28–87º C)

-

40–180º F

(-40–82º C)

-

40–180º F

(-40–82º C)

-

20–190º F

(-28–87º C)

-

20–190º F

(-28–87º C)

-

20–190º F

(-28–87º C)

-

20–190º F

(-28–87º C)

-

40–180º F

(-40–82º C)

-

40–180º F

(-40–82º C)

-

20–225º F

(-28–107º C)

-

40–120º F

(-40–49º C)

Fuel/Evacuation HSLE3B HSLE3A HSLE3F HSLE3G

Maximum dry weight with hose: XD10 = 54 lbs (24.5 kg), XD20 = 59 lbs (27 kg), XD30 = 98 lbs (44.5 kg)

Wetted parts–Bare hose reel only: zinc plated steel, anodized aluminum, nitrile rubber

Instruction Manuals: XD10 and XD20: 313431, XD30: 3A0138

* Bare reel–hose sold separately

** Not recommended for overhead installation. Maximum installed height is 7 feet (2.13 meters).

125 (8.6)

52

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

www.graco.com

700 Series

Hose Reels

237875 with 237932

Overhead mounting kit. Includes all parts needed for ceiling-mounting.

Features

• Fully ported swivel and shaft for unrestricted fl ow

• Handles hose lengths up to 75 ft (23 m)

• Heavy-duty ball bearings outlast sleeved-type bearings

• Easy rewind with minimal hose guidance

Typical Fluids Handled

• Petroleum- and synthetic-based oils

• Air

• Water

• Anti-freeze

• Windshield wash fl uid

• Used oil

• Used anti-freeze

Dimensions

700 SERIES

A 26.25 in (628 mm)

B 24.0 in (609 mm)

C 11.83 in (300 mm)

A

Ordering Information

Medium-Pressure Oil Dispense Reels (rated to 1500 psi/103 bar)

237728

237879 *

Bare Hose Reel

Hose Reel with 3/4 in x 75 ft (19.1 mm x 23 m) hose

Medium-Pressure Oil Evacuation and Dispense Reels (rated to 212 psi/14.6 bar)

241910 * Hose Reel with 1 in x 50 ft (25.4 mm x 15 m) hose; 24 in (0.3 m) Hg vacuum

Medium-Pressure Fuel Dispense Reel (rated to 125 psi/8.6 bar)

237884 * Hose Reel with 1 in x 50 ft (25.4 mm x 15 m) hose

* Not recommended for overhead installation

Technical Specifi cations

Inlet npsm (m)

Outlet npt (m)

1 npt(f) 1 npt(f)

Max. Pressure

Psi (bar)

1500 psi (bare reel))

Maximum Vacuum Operating Temp.

24 in Hg

-40º F to 180º F

(-40º C to 82º C)

B

Wetted Parts

Carbon Steel,

Buna

Weight

(bare reel)

103 lb

(46.7 kg)

C

Instruction

Manual

308546

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

53

750 Series

Hose Reels

Features

• Heavy-duty, high volume reel

• Industrial-grade paint for high abrasion and corrosion resistance

• Full-fl ow shaft

• Heavy-duty brackets and springs

• Rugged base and hose rollers

• Heavy-duty latch mechanism

Typical Fluids Handled

• Unleaded, leaded and diesel fuels

• Petroleum- and synthetic-based oils

• Water

• Anti-freeze

Dimensions

750 Series

A 26.25 in (667 mm)

B 26.25 in (667 mm)

C 21.88 in (556 mm)

D 13.75 in (349 mm)

E 24.25 in (616 mm)

F 17.50 in (445 mm)

G 22.125 in (562 mm)

H 13.50 in (343 mm)

B

A

D

C

F

H

G

E

54

Ordering Information

Bulk Dispense Reels (rated to 125psi/8.6 bar))

245410 Bare hose reel

Technical Specifi cations

Inlet npsm (m)

Outlet npt (m)

1-1/2 npt(f) 1-1/2 npt(f)

Max. Pressure

Psi (bar)

375 psi

(26 bar)

Hose Capacity Operating Temp.

50 ft (15.2m) x

1.50 in ID Hose

150º F (65º C)

Wetted Parts

Carbon Steel,

Buna

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

Weight

(bare reel)

139 lbs (63 kg)

Instruction

Manual

309442

www.graco.com

Packages

Hose Reels

LD Enclosed Hose Reel Packages

Application Package

Motor Oil

Motor Oil

Motor Oil

Motor Oil

24D197

24D198

24D199

24D200

Reel

HEM33D

HEM33D

HEM33D

HEM33D

SD Reel Packages with Enclosure Kit

Application SD Packages

Air/Water

Air

Water

24B812

24B813

24B814

Motor Oil

Chassis Grease

24B815

24B816

Hose Reel

HRL56B

HRL56B

HRL56B

HRM65B

HRH55B

SD Reel Packages with Enclosure Kit

Application SD Packages Hose Reel

Air/Water 24D989 HPL23B

Air/Water

Air/Water

Air

Water

Water

Motor Oil

Motor Oil

Motor Oil

24D990

24D991

24D992

24D993

24D994

24D995

24D996

24D997

HPL25B

HPL33B

HPL23B

HPL23B

HPL33B

HPM33B

HPM33B

HPM33B

Hose Inlet Kit

24C538

24C538

24C538

24C538

Hose Inlet Kit

218549

218549

218549

218549

218549

218549

218549

218549

218549

Hose Inlet Kit

218549

218549

218549

218549

218550

Dispense Valve/Meter

LDM5 Rigid with trigger guard ( 256215)

LDM5 Flex with trigger guard ( 258693)

LDP5 Rigid with trigger guard ( 256216)

LDP5 Flex with trigger guard ( 258694)

White Enclosure

24A218

24A218

24A218

24A218

24A218

White Enclosure Dispense Valve/Meter

24A217 –

24A217

24A217

24A217

24A217

24A217

24A217

24A217

24A217

218545

180685

180685

255350

255348

Dispense Valve

218545

180685/ 150287

Fitting

150287

159842

SD Reel Packages without Enclosure Kit

Application SD Packages Hose Reel

Air

Water

Motor Oil

Motor Oil

24D998

24D999

24E001

24E002

HPL23B

HPL23B

HPM33B

HPM33B

Hose Inlet Kit

218549

218549

218549

218549

Enclosure

Dispense Valve/Meter

218545

180685

255350

255348

Fitting

150287

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

55

Accessories

For LD, SD and XD Reels

Ordering Information

LD Enclosed Mounting Brackets

24C793 Ceiling/Wall Stationary Bracket

24C772 Tote, Bench or Wall Mount Post

Ceiling/Wall Stationary

Bracket 24C793

Tote, Bench or Wall

Mount Post 24C772

Hose Inlet Kits for LD Enclosed Hose Reel

Part

Number

Hose Inlet

Description

Fits Reel

Pressure psi (bar)

24C437

24C437

24C438

24C438

24C440

24C440

Air

Air

Air/ water

Air/ water

Oil

Oil

HEL13D

HEL15D

HEL23D

HEL25D

HEM23D

HEM33D

250 (17.2)

250 (17.2)

250 (17.2)

250 (17.2)

1,800 (124)

1,800 (124)

24C442

24C443

24C443

24C444

24C445

Grease

Air

Air

Air/water

Air/water

HEH13D

HEL13D

HEL15D

HEL23D

HEL25D

5,000 (345)

250 (17.2)

250 (17.2)

250 (17.2)

250 (17.2)

24C537 Oil HEM23D

24C538 Oil HEM33D

24C539 Grease HEH13D

* NPT hose connection when using BSP to NPT adapter (included)

1,800 (124)

1,800 (124)

5,000 (345)

Reel Enclosures

• Designed for enclosing SD single pedestal reels

• Enclosures provide protection to extend the life of hoses and bearings

Enclose kits for one reel

White* Metallic Blue

Part numbers by color

Red Black Dark Blue Yellow

Size 10 Enclosure

Size 20 Enclosure

24A217

24A218

24A940

24A945

24A941 24A942 24A943

24A946 24A947 24A948

24A944

24A949

Size 10 End Caps (2) – – – 24A950 – –

Size 20 End Caps (2) – – – 24A951 – –

Mounting Channels

Enclosure mounting channels accommodate one, two, three, four, fi ve or six reels (includes all parts needed to mount hose reels to walls or ceilings)

Mounting channel

Description

1 Reel 2 Reels 3 Reels 4 Reels 5 Reels 6 Reels

SD10 and SD20*

XD10 and XD20

24A934

24A219

Enclosure Kit

* For use without enclosure kit

203521

24A935

24A220

203522

24A936

24A221

203523

24A937

203524

24A938

203525

24A939

24A222

203526

Hose id in (mm)

1/4 (6)

1/4 (6)

1/2 (12)

1/2 (12)

1/2 (12)

1/2 (12)

1/4 (6)

1/4 (6)

1/4 (6)

3/8 (10)

1/2 (12)

3/8 (10)

1/2 (12)

1/4 (6)

Length in (mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

36 in (915 mm)

Hose Inlet Kit for

LD enclosed reels

Hose Inlet in

1/4 bspt(m)

1/4 bspt(m)

1/2 bspt(m)

1/2 bspt(m)

1/2 bspt(m)

1/2 bspt(m)

1/4 bspt(m)

1/4 npt(m)*

1/4 npt(m)*

1/2 npt(m)*

1/2 npt(m)*

1/2 npt(m)*

1/2 npt(m)*

1/4 npt(m)*

Mounting Channel

Hose Outlet in

1/4 bspt(m)

1/4 bspt(m)

3/8 bspt(m)

3/8 bspt(m)

3/8 bspt(m)

1/2 bspt(m)

1/4 bspt(m)

1/4 npt(m)*

1/4 npt(m)*

3/8 npt(m)*

1/2 npt(m)*

3/8 npt(m)*

1/2 npt(m)*

1/4 npt(m)*

56

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

www.graco.com

Accessories

For SD, XD, 700 and 750 Series Reels

Retrofi t Bracket to 500 Series

Mounting Bracket

Ball Stop Kit

Hose Inlet Kit for SD and

XD open reels

237944

Ordering Information

Retrofi t Adapter Kits

24A224

24C100

Mounting Bracket

Includes all parts to mount hose reel to existing 500 series mounting pattern

Includes all parts to convert SD10 hose reels to fi t existing 250 series enclosures

204741

Secures mounting channel to I-beam without drilling. Two brackets are required for 1-3 hose reels; three brackets for 4-6 hose reels.

Typical Hose id

Ball Stop Kits

222225* For 1/4 in (6.4 mm) i.d. hose

218340*

218341*

237872

For 1/4-3/8 in (6.4-9.5 mm) i.d. hose

.782 ID used for 3/8 in and 1/2 in 9.5 mm and 12.7 mm) hose

1.0 ID used for 5/8 in (15.9 mm) hose

237873

237874

1.123 ID used for 3/4 in (19.1 mm) hose

1.374 ID used for 1 in (25.4 mm) hose

24D132 For 3/8 in (9.5 mm) o.d. hose

24D133 For 1/2 in (12.7 mm) o.d. hose

*Not for use with XD30, 700 or 750 reels

Hose Inlet Kits for SD and XD Reels

218549

218550

222417

Description

Low /medium pressure

High pressure

High pressure

Pressure psi (bar)

Hose id in

(mm)

2000 (137) 1/2 (12)

4000 (276) 3/8 (10)

5000 (345) 1/4 (6)

Length in (mm)

24 (610)

24 (610)

24 (610)

Hose

Inlet npt(m) npt(m) npt(m)

Medium-Pressure Oil Dispense Reels (rated to 1500 psi/103 bar)

218591 Hose Roller Repair Kit

Valve Hanger Kit

224444 Mounts to side of reel to allow hanging of non-metered and high fl ow dispensing valves

Metal Label Kits (includes one 3/4 in x 4-1/4 in (1.9 cm x 10.8 cm) metal label and mount)

218670 Motor oil 218675 Air

218671

218672

218673

218674

Grease

Gear lube

ATF

Hydraulic Oil

218676

218677

218678

Water

Anti-freeze

Evacuation

Self Adhesive Identifi cation Label Set

180698

Set includes: 1 in x 5 in (25.4 mm x 127 mm) hose reels labels for Anti-Freeze, Water, SAE 5-40,

SAE 10-40, SAE 20W, Hydraulic, Gear, SAE 10W, SAE 10-30, SAE 30W, Dexron, Air, Chassis, ATF

237932*

237944*

Overhead mounting kit includes all parts needed for ceiling-mounting reel. (one required per reel.)

Roller support kit includes roller support accessories for ceiling mounted reels (reel not included).

109064 Hose inlet kit 1 (mbe) x 28 in (71 cm)

*Required for overhead mounting

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

H O S E R E E L S

57

Dispense Consoles

Multi-Station Consoles*

Six-Station Console

222629

Includes upper and lower fl oor plates with roller guides and brackets (1- 110236; 5- 196471) to hold one water bib and fi ve Graco LDM dispense valves. Console dimensions (without brackets): 27 in high x 54 in long x 12 in wide (68.58 cm high x 139.7 cm long x 25.4 cm wide). Console requires a fl oor opening of 6 in x 51 in (15.2 cm x 122.4 cm).

Four-Station Console

223448

Includes upper and lower fl oor plates, roller guides and brackets (1- 110236; 3- 196471) to hold one water bib and three Graco LDM dispense valves. Console dimensions (without brackets): 27 in high x 36 in long x

12 in wide (68.58 cm high x 139.7 cm long x 25.4 cm wide). Console requires fl oor opening of 6 in x 33 in

(15.2 cm x 83.8 cm).

Single Add-On Fluid Module

222645

For adding-on to four- or six-station consoles. Includes add-on module, fl oor plates with roller guides to fi t module and one 196471. Console requires fl oor opening of 6 in x 8-1/2 in (15.2 cm x 21.6 cm). Add-on fl uid module dimensions 27 in high x 9 in long x 10 in wide (68.5 cm high x 22.86 cm long x 25.4 cm wide).

*Hoses not included

Lubricant Dispense Consoles Accessories

110236 Water bib bracket

110237 Em6 mounting bracket

110285 Pistol-grip dispense valve bracket

196471 Universal dispense valve bracket for EM5 and PM5

249440 Matrix dispense valve bracket

222641 Console roller repair kit (upper)

218591 Floor plate roller repair kit (lower)

178670 Roller only

234423 End panel replacement comes with 8 screws

Oil Dispense Bar

220107

Tough metal cabinet with baked-on enamel fi nish. Constructed with single-dispense tap and waste pan with plated, perforated metal service area and drain connection. Modular convenient design allows up to 2 oil dispense taps or 3 meters to be added at the time of installation, or later if required. Instruction manual

307742. Maximum working pressure 900 psi (62 bar). 22.6 in H x 13.25 in D x 18.3 in W (57.4 cm H x

33.7 cm D x 46.5 cm W).

Tap Kit

220112

Add to oil dispense bar to convert into two or three taps, as needed. Kit also includes non-drip dispense valve, manifold and all necessary mounting hardware.

Meter Kit

239706

Any individual tap on the oil dispense bar can be fi tted with a fl uid meter. Kit includes meter 239824 and all necessary mounting hardware. Maximum working pressure 500 psi (34 bar).

220110 Spigot valve replacement

Console Roller

222641

Floor Plate Roller

218591

222629

58

L U B R I C A T I O N E Q U I P M E N T

D I S P E N S E C O N S O L E S

222629

220107

234423

222645

www.graco.com

LD Series Electronic Meters

LDM5 and LDP5 Dispense Meters

Features and Benefi ts

• Manual and Preset Dispense

• Dispenses in gallons, quarts, pints and liters

• Easy to read LCD display with durable switches for long life

• Rugged engineered material for superior impact resistance and long life

• Ergonomically-designed handle for optimum comfort

• Standard rigid extension kit and automatic thermal compensating nozzle

• Optional extensions available

Typical Applications

• Metered oil dispense

• Heavy-duty dealerships

• Fleet service facilities

• For indoor use only

• Automotive dealerships

• Fast lube centers

• Service shops

• In-plant

Typical Fluids Handled

• Petroleum- and synthetic-based oils

• Anti-freeze

Technical Specifi cations

Flow Range (1) .............................................................. 0.1 - 5 gpm (0.4 - 19 lpm)

Maximum Working Pressure .......................................................1000 psi (69 bar)

Units of measure ........................ Quarts, pints, gallons, liters (factory set to quarts)

Weight .......................................................................................... 3 lb (1.36 kg)

Inlet .................................................................................................... 1/2 in npt

Outlet .................................................................................................. 1/2 in npt

Operating Temperature Range......................................... 32 - 120º F (0 - 48.8º C)

Storage Temperature Range.................................... -30 - 120º F (-34.4 - 48.8º C)

Battery .......................................................................................... 9 volt alkaline

Battery Life ............................................................................................ one year

Wetted Parts ........................................................... sst, nitrile rubber, zinc, cs, lcp

Meter Pressure Loss

(1)

..................................... 90 psi (6.2 bar) @ 5 gpm (19 lpm)

Accuracy (2) ............................................................................................... ±0.5%

Dimensions (without extension) ................................. 11 in L x 3.25 in W x 3.25 H

(28 cm L x 8.3 cm W x 8.3 cm H)

Maximum Totalizer ......................................................... 999,999 gallons or liters

Maximum Recorded Dispense .......................................... 999.9 Units (LDP5 only)

Warranty ............................................................................................. Two Years

Instruction Manual ................................................................................. 312668

(1) Tested in 10W oil at 70ºF. Flow rates vary with fl uid pressure, temperature, viscosity, inlet fi tting and nozzle type.

(2) @ 2.5 gpm (9.5 lpm) @ 70º F (21º C) with 10 wt. oil and 1 gal (3.8 l) dispensed.

May require re-calibration. Out-of-box accuracy ±1.25%. Not recommended for in-line installation.

256215

256216

255277

255751

258693

258694

Ordering Information

LDM5 Manual Dispense Meters

255751

1/2 in npt(f) swivel, fl exible extension and automatic nozzle for oil and anti-freeze

256215

258693

1/2 in npt(f) swivel, rigid extension, trigger guard/boot and automatic nozzle for oil and anti-freeze

1/2 in npt(f) swivel, fl exible extension, trigger guard/boot and automatic nozzle for oil and anti-freeze

LDP5 Preset Dispense Meters

255277

1/2 in npt(f) swivel, fl exible extension and automatic nozzle for oil and anti-freeze

256216

258694

1/2 in npt(f) swivel, rigid extension, trigger guard/boot and automatic nozzle for oil and anti-freeze

1/2 in npt(f) swivel, fl exible extension, trigger guard/boot and automatic nozzle for oil and anti-freeze

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

D I S P E N S E M E T E R S A N D C O N T R O L V A L V E S

59

SD Series Electronic Meters

Dispense Meters and Control Valves

60

Features and Benefi ts

• Fluid inlet options (½ in and ¾ in npt) meets standard and high-fl ow requirements

• Large LCD display and simple operator controls

– Adjusts for easy reading in all lighting conditions

– Calibration easily adjusts from keypad

• Solid construction to stand up to harsh environments and provide years of trouble-free performance

– Locking trigger (SDP5/SDP15 models)

– Durable cast trigger guard prevents accidental triggering

• Flush-mount nozzle valve design prevents leaks and contamination

• Designed for no leak performance

Typical Applications

• Metered oil dispense in demanding environments

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers

• Fleet service facilities

• Service shops

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Petroleum- and synthetic-based oils

• Anti-freeze

Technical Specifi cations

Flow Range

(1)

............................................................. 0.1–14 gpm (0.4 - 53 lpm)

Maximum Working Pressure ..................................................1500 psi (103.4 bar)

Weight ............................................................................................5 lbs (2.3 kg)

Inlet ..................................................................... 3/4 in–14 npt or 1/2 in–14 npt

Outlet ..........................................................3/4 in–16 straight thread O-ring Boss

Maximum Totalizer .......................................................... 999,999 gallons or liters

Maximum Recorded Dispense ............................................................. 999.9 Units

Maximum Pre-Set Volume .................................................................. 999.9 Units

Storage Temperature Range.............................................. -40–158º F (-40-70º C)

Operating Temperature Range...............................................4–158º F (-20-70º C)

Battery ..................................................................... 4 AA alkaline or 4 AA lithium

Battery Life (3) . . . Preset Models – six months with alkaline, manual models – one year with alkaline 4 AA alkaline or lithium

Wetted Parts ..............................................Aluminum, sst, pbt/pc, nitrile rubber, cs

Meter Pressure Loss (1) .................................. 180 psi (12 bar) @ 14 gpm (53 lpm)

Accuracy (2) ........................................................................................... +/- 0.5%

Dimensions (without extension) ..............................13 in L x 3.75 in W x 5.75 in H ,

(33cm x 9.5cm x 14.6cm)

Warranty ................................................ Five years overall, three years electronics

Instruction Manual .................................................................................. 312865

1. Tested in 10W oil at 70º F. Flow rates vary with fl uid pressure, temperature, viscosity, inlet and nozzle type.

2. At 2.5 gpm (9.5 lpm) @ 70º F (21º C) with 10 wt. oil and 1 gal (3.8 l) dispensed. May require re-calibration.

Out-of-box accuracy ±1.25%.

3. Average shop use with alkaline batteries (included); 30-35% longer life with lithium AA.

255350

Ordering Information

SDM5 MANUAL DISPENSE ELECTRONIC METER, 5 GPM OR LESS

255350

1/2 in npt(f) swivel, rigid oil extension with standard automatic non-drip quick-close nozzle

255348

255349

255802

255803

1/2 in npt(f) swivel, fl exible oil extension with standard automatic non-drip quick-close nozzle

1/2 in npt(f) swivel, gear lube extension with standard quick-close nozzle

1/2 in npt(f) swivel, rigid anti-freeze extension with standard quick-close nozzle

1/2 in npt(f) swivel, fl exible anti-freeze extension with standard quick-close nozzle

SDM15 MANUAL DISPENSE ELECTRONIC METER, 14 GPM OR LESS

256836

1/2 in npt(f) swivel, rigid oil extension with high fl ow, quick-close nozzle

256837

255800

1/2 in npt(f) swivel, fl exible oil extension with high fl ow, quickclose nozzle

3/4 in npt(f) swivel, rigid oil extension with high fl ow, quick-close nozzle

255801

3/4 in npt(f) swivel, fl exible oil extension with high fl ow, quickclose nozzle

SDP5 PRESET DISPENSE ELECTRONIC METER, 5 GPM OR LESS

255200

255351

1/2 in npt(f) swivel, rigid oil extension with standard automatic non-drip quick-close nozzle

1/2 in npt(f) swivel, fl exible oil extension with standard automatic non-drip quick-close nozzle

255352

255355

1/2 in npt(f) swivel, gear lube extension with standard quick-close nozzle

1/2 in npt(f) swivel, rigid anti-freeze extension with standard quick-close nozzle for anti-freeze

255356

1/2 in npt(f) swivel, fl exible anti-freeze extension with standard quick-close nozzle for anti-freeze

SDP15 PRESET DISPENSE ELECTRONIC METER, 14 GPM OR LESS

256838

256839

255353

255354

1/2 in npt(f) swivel, rigid oil extension with high fl ow, quick-close nozzle

1/2 in npt(f) swivel, fl exible oil extension with high fl ow, quickclose nozzle for oil

3/4 in npt(f) swivel, rigid oil extension with high fl ow, quick-close nozzle for oil

3/4 in npt(f) swivel, fl exible oil extension with high fl ow, quickclose nozzle for oil

L U B R I C A T I O N E Q U I P M E N T

DISPENSE METERS AND CONTROL VALVES

www.graco.com

EM6

Electronic Meter

Dispense Meters and Control Valves

Features and Benefi ts

• Screw-tight nozzle for positive shut off

• Ball bearing swivel for ease of use

• Durable design ideal for use in harsh environments

• Reset capable for periodic dispense history information

Typical Applications

• Metered oil dispense in demanding environments

• Automotive dealerships

• Heavy-duty dealerships

• Service and fast lube centers

• Fleet service facilities

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled*

• Petroleum- and synthetic-based oils

* Not recommended for use with anti-freeze or windshield washer fl uid

243599

Ordering Information

EM6 Electronic Meters

243599 U.S. measure (rigid extension)

243600 U.S. measure (gear lube extension)

243601 U.S. measure (fl exible extension)

243602 Metric measure (rigid extension)

243603 Metric measure (gear lube extension)

243604 Metric measure (fl exible extension)

243992 1/2 in (12.7 mm) bare valve (without locking trigger)

Accessories

235878 U.S. Electronic Control Replacement

235901 Metric Electronic Control Replacement

203655 Twist Lock Nozzle Replacement 1/4 npt(m)

203687 Flex Extension, hose with 203655 tip

201701 Gear Lube Extension with tip

203265 Rigid Extension with tip

Color-coded Impact Guards for Electronic Meters

Color-code various fl uids dispensed to reduce errors, match store colors, or create a customized appearance. For electronic meters only.

191782 Black

191783 Red

191784 Blue

Technical Specifi cations

Maximum Recommended Flow Rate .........................................6 gpm (23.01 lpm)

Maximum Operating Pressure ......................................... 1500 psi (105 bar, 10.5,)

Operating Temperature Range............................................-40-180º F (-40-82º C)

Storage Temperature Range...............................................-40-140º F (-40-60º C)

Inlet .........................................................................................................1/2 npt

Outlet .......................................................................................................1/2 npt

Wetted Parts ............................. aluminum, SST, CS, acetal, nitrile rubber, Geolast ™

Instruction Manual .................................................................................. 308642

Accuracy/Repeatability .......................................................................... +/- 0.6%

Geolast™ is a registered trademark of Advanced Elastomer Systems.

235878

243392

191782

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

D I S P E N S E M E T E R S A N D C O N T R O L V A L V E S

61

EM12

Electronic Meter

Dispense Meters and Control Valves

Features and Benefi ts

• Locking trigger for hands-free operation

• High-fl ow capability provides up to 12 gpm (45 lpm)

• Rugged design withstands demanding environments

• Reset capable for periodic dispense history information

Typical Applications

• Automotive and heavy-duty dealerships

• Service and fast lube centers

• Fleet service facilities

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled*

• Petroleum- and synthetic-based oils

* Not recommended for use with anti-freeze or windshield washer fl uid

Ordering Information

EM12 Electronic Meters with 3/4 in npt(f) swivel inlet

238636 U.S. measure, rigid extension

238637 U.S. measure, fl exible extension

238638 Metric measure, rigid extension

238639 Metric measure, fl exible extension

EM12 Electronic Meters with 1/2 in npt(f) swivel inlet

238640 U.S. measure, rigid extension

238641 U.S. measure, fl exible extension

238642 Metric measure, rigid extension

238643 Metric measure, fl exible extension

Bare Valves with Locking Trigger (no meter or extension)

238647 Inline fl ow through with 1/2 npt(f) swivel inlet and outlet

238646 Inline fl ow through 3/4 npt(f) swivel inlet; 1/2 npt(f) outlet

Accessories

235878 U.S. Electronic control replacement

235901 Metric electronic control replacement

223920 High fl ow twist lock nozzle, 1/2 npt(f) with 1 in diameter tip.

238400 Automatic nozzle 1/2 npt(f) with 1 in diameter tip

185416 Filter 40 mesh stainless steel

Color-coded Impact Guards for Electronic Meters

For color-coding fl uids dispensed to reduce errors, match store colors, or to protect vehicle’s fi nish. For electronic meters only.

191782 Black

191783 Red

191784 Blue

238647

238641

Technical Specifi cations

Maximum Recommended Flow Rate .........................................12 gpm (45.4 lpm)

Maximum Operating Pressure ...................................................1500 psi (105 bar)

Operating Temperature Range..............................................-4-130º F (-20-55º C)

Storage Temperature Range...............................................-40-140º F (-40-60º C)

Inlet ...................................................................................... 1/2 npt and 3/4 npt

Outlet .......................................................................................................1/2 npt

Wetted Parts ................................aluminum, SST, CS, acetal, nitrile rubber, Geolast

Instruction Manual .................................................................................. 308642

191782

223920

62

L U B R I C A T I O N E Q U I P M E N T

DISPENSE METERS AND CONTROL VALVES

www.graco.com

In-Line Electronic Meters

Dispense Meters and Control Valves

IM5, Low Pressure

• Heavy-duty construction for outdoor use

• Easy-to-use meter dispenses pints, quarts, liters or gallons

• Easy-to-replace battery

Typical Applications/Fluids Handled

• Automotive dealerships

• Fast lube centers

• Service shops

• In-plant

• Petroleum- and synthetic-based oils; anti-freeze; windshield wash fl uid

IM6 and SDI15, Medium/High Pressure

• Reset capable for periodic dispense history information

• Durable design ideal for rugged environments; shock-resistant

• Easy-to-use meter dispenses pints, quarts, liters or gallons

• Easy-to-replace battery (SDI15 - AA battery)

• SDI15 is for indoor use only

Typical Applications/Fluids Handled

• Automotive and large truck dealerships

• Fast lubes and service shops

• Fleet service facilities

• In-plant

• Lube trucks (IM6 only)

• Mining

• Petroleum- and synthetic-based oils; anti-freeze (SDI15)*

* Not recommended with anti-freeze or windshield wash

Ordering Information

IM5 In-Line Meter

239824 IM5 In-Line Meter

IM6 In-Line Electronic Meter

244075 In-Line Meter (U.S.)

244076

235878

235901

In-Line Meter (Metric)

Replacement

Electronics (U.S.)

Replacement

Electronics (Metric)

SDI15 In-Line Electronic Meter

247453 In-Line Meter (U.S.)

Technical Specifi cations

239824

244075

247453

IM5 In-Line Meter IM6 In-Line Meter SDI15 In-Line Meter

Flow Range*

Max. Working Pressure

Weight

Units of Measurement

Accuracy

Inlet/Outlet

Operating Temperature Range

Storage Temperature Range

Outdoor

Max Totalizer

Max Recorded Dispense

Meter Pressure Loss

Battery

0.5 to 5 gpm (1.9 to 19 lpm)

500 psi (34 bar)

1.8 lb (0.8 kg)

± 0.5%

1/2 npt*

-4 - 122º F (-20 - 50º C)

-13 - 122º F (-25 - 50º C) yes

99,999

999.99

15 psi (1 bar) @ 5 gpm (19 lpm)

9-volt, alkaline

0.12 to 12.0 gpm (0.46 to 45.6 lpm)

1500 psi (103 bar)

1.9 lb (0.95 kg)

Quarts, pints, gallons, liters (factory-set to quarts)**

± 1.0%

1/2 npt*

-4º - 130º F (-20º - 55º C)

-40º - 140º F (-40º - 60º C) yes

19,999

999.99

120 psi (8.3 bar) @ 6 gpm (23 lpm)

Lithium

0.1 to 14 gpm (0.4 to 53 lpm)

1500 psi (103 bar)

1.8 lb (0.82 kg)

± 0.5%

1/2 npt*

-4 - 122º F (-20 - 50º C)

-13 - 122º F (-25 - 50º C) no

99,999

999.99

22 psi (1.5 bar) @ 14 gpm (53 lpm)

2AA alkaline

Wetted Parts nickel, zinc, zenite, nitrile rubber aluminum, carbon steel, nitrile rubber, nickel, bronze, SST #304, cast ALNICO 8

Instruction Manual 308687 307965

*Tested with number 10 motor oil. Flow rates vary with fl uid pressure and viscosity.

** Display shows quantity in 0.01 increments up to 999.99 gallons, quarts, pints, or liters. Totalizes in gallons or liters up to 99,999 units (IM5 only).

aluminum, carbon steel, nitrile rubber, nickel, bronze, SST, Geolast

313048

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

D I S P E N S E M E T E R S A N D C O N T R O L V A L V E S

63

Mechanical Meters

Dispense Meters and Control Valves

Features and Benefi ts

• Balanced, lightweight, rugged construction, and comfortable grip

• Non-resettable totalizing register helps manage material usage

• Handles a variety of petroleum- and synthetic-based oils and anti-freeze

• Ideal for indoor and outdoor use

Typical Applications

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers

• Fleet service facilities

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Petroleum- and synthetic-based oils and anti-freeze

Technical Specifi cations

Maximum Flow* ........................................................................ 4 gpm (15.1 lpm)

Minimum Flow* ........................................................................ 0.4 gpm (1.5 lpm)

Maximum Operating Pressure ................................................. 1000 psi (68.9 bar)

Operating Temperature Range........................................... -40-140º F (-40-60º C)

Accuracy ............................................................................................. ± 0.65%

Weight ......................................................................................... 6.0 lb (2.7 kg)

Inlet and outlet connections ................................................................... 1/2 npt(f)

For use with petroleum-based fl uids only.

*Tested with Mobil® DTE-25 motor oil. Minimum/maximum fl ow rates will vary with fl uid viscosity.

Ordering Information

Manual Meters

256556 16 Quart Meter with fl exible extension and twist lock nozzle

253601 10 Liter Meter with fl exible extension and twist lock nozzle

256786 16 Quart Meter with rigid extension and twist lock nozzle

256788 10 Liter Meter with rigid extension and twist lock nozzle

256787 16 Quart Meter with gear lube extension and automatic nozzle

256789 10 Liter Meter with gear lube extension and automatic nozzle

Preset Meters

207738 60 Quart Meter valve with rigid extension and automatic nozzle

207739 60 Gallon Meter valve with rigid extension and automatic nozzle

207742 60 Liter Meter valve with rigid extension and automatic nozzle

Nozzles

255459 Quick-close nozzle only for oil

255460 Quick-close nozzle only for anti-freeze

255470 Quick-close nozzle only for gear lube

64

L U B R I C A T I O N E Q U I P M E N T

DISPENSE METERS AND CONTROL VALVES

256556

256787

256786

207738

www.graco.com

Accessories

Dispense Meters and Control Valves

LDM and LDP Accessories

Nozzle Extension Kits

255861 Automatic nozzle with fl exible extension for oil and anti-freeze*

239949 Automatic thermal compensating nozzle with rigid extension for oil and anti-freeze

239951 Automatic thermal compensating nozzle with fl exible extension for oil and anti-freeze

239950 Automatic thermal compensating nozzle with rigid extension for gear lube

239829 Automatic thermal compensating nozzle for oil and anti-freeze without extension

238371 Automatic thermal compensating gear lube nozzle without extension

*Economical extension used on model 255751

Additional LDM5 Accessories

240416 Inlet Swivel

114017 Inlet Filter, 80 mesh

196471 Valve Bracket for Dispense Console

240453 Valve Repair Kit

238555 Electronic Cover Control Assembly Kit

Swivel Covers

191294* Black

191287 Red

191288 Blue

191289 Green

191295 Yellow

Protective Boots with Trigger Guard

247759* Black

243835 Red

243836

243837

247760

Blue

Green

Yellow

*Included on meter 256215

SDM and SDP Accessories

Nozzle Extension Replacement Kits For SD Series Meters

255852 Automatic non-drip quick-close nozzle with rigid extension for oil

255853 Automatic non-drip quick-close nozzle with fl exible extension for oil

255854 Non-drip quick-close nozzle with rigid extension for gear lube

255855 Non-drip quick-close nozzle with rigid extension for anti-freeze

255856 Non-drip quick-close nozzle with fl exible extension for anti-freeze

255459 Automatic non-drip quick-close nozzle only for oil

255460 Quick-close nozzle only for anti-freeze

255470 Quick-close nozzle only for gear oil

255857 Non-drip quick-close high-fl ow nozzle with rigid extension for oil and anti-freeze

255858 Non-drip quick-close high-fl ow nozzle with fl exible extension for oil and anti-freeze

255461 Quick-close high-fl ow nozzle only for oil and anti-freeze

Swivel Covers

15T366 Black swivel cover (standard color with meter)

15T367 Red swivel cover

15T368 Blue swivel cover

15T369 Green swivel cover

15T370 Yellow swivel cover

Filter Kits for SD Series Meters

255885 Filter kit includes (10) fi lters/strainers ( 15M308), (10) spacers ( 15M309) and (10) O-rings ( 155332)

191294

239951

255861

239950

255854

239949

247759

255852

255853

255857

www.graco.com

15T366

L U B R I C A T I O N E Q U I P M E N T

D I S P E N S E M E T E R S A N D C O N T R O L V A L V E S

65

SDV15 Control Valve

Dispense Meters and Control Valves

Features and Benefi ts

• Moves fl uid up to 15 gpm (56.8 lpm) (15 gpm obtained with high-fl ow nozzle–purchased separately)

• Sturdy cast body designed for use in tough environments

• Lock-on trigger

• 1/2 in npt(f) inlet with built-in ball bearing swivel allows for ergonomic operation

• Inlet screen aids in keeping fl uids clean

Typical Applications

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers

• Fleet service facilities

• Service shops

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Motor oils

• Transmission fl uid

• Anti-freeze

247712

Technical Specifi cations

Maximum Recommended Flow Rate ........................................ 15 gpm (18.9 lpm)

Maximum Operating Pressure ...................................................1500 psi (103 bar)

Weight ....................................................................................... 0.4 lb (0.18 kg)

Operating Temperature Range........................................ -40º–180º F (-40º–82º C)

Inlet ........................................................................................................ 1/2 npt

Outlet ......................................................... 3/4 in, 16 straight thread O-ring boss

Wetted Parts ........................................ Aluminum, sst, cs, acetal, nitrile rubber, tpe

Warranty ............................................................................................. Five years

Instruction Manual ................................................................................. 312789

1. Tested in 10W oil at 70º F. Flow rates vary with fl uid pressure, temperature, viscosity, inlet fi tting and nozzle type.

Ordering Information

SDV15 Control Valves

247712 1/2 in npt(f) swivel, locking open trigger, rigid extension and standard automatic non-drip quick-close nozzle for oil products

247713 1/2 in npt(f) swivel, locking open trigger, fl exible extension and standard automatic non-drip quick-close nozzle for oil products

247714 1/2 in npt(f) swivel locking open trigger, gear lube extension and standard quick-close nozzle

247715 1/2 in npt(f) swivel locking open trigger, rigid extension and standard quick-close nozzle for anti-freeze

247716 1/2 in npt(f) swivel locking open trigger, fl exible extension and standard quick-close nozzle for anti-freeze

Bare Valve (no extension)

247717 1/2 in npt(f) swivel locking open trigger, 3/4 in - 16(f) straight thread O-ring boss outlet, and trigger lock, no extension

Accessories

256164 Filter kit includes (10) fi lters/strainers ( 185416)

255459 Quick-close nozzle only for oil

255460 Quick-close nozzle only for anti-freeze

255470 Quick-close nozzle only for gear lube

255857 Non-drip quick-close high-fl ow nozzle with rigid extension for oil and anti-freeze

255858 Non-drip quick-close high-fl ow nozzle with fl exible extension for oil and anti-freeze

255461 Quick-close high-fl ow nozzle only for oil and anti-freeze

66

L U B R I C A T I O N E Q U I P M E N T

DISPENSE METERS AND CONTROL VALVES

www.graco.com

XDV20 Control Valve

Dispense Meters and Control Valves

Features and Benefi ts

• Moves fl uid up to 20 gpm (76 lpm)

• Lock-on/lock-off trigger for hands-free operation

• Rugged cast-body design withstands harsh environments

• Built-in ball bearing swivel allows for ergonomic operation

• Inlet screen aids in keeping fl uids clean

• Quick close high fl ow nozzle for high volume dispensing–moves fl uids fast!

Typical Applications

• High-fl ow, non-metered oil dispense

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers

• Fleet service facilities

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Motor oils

• Transmission fl uid

• Anti-freeze

247724

247722

Technical Specifi cations

Maximum Recommended Flow Rate ........................................ 20 gpm (45.4 lpm)

Maximum Operating Pressure .................................................. 1500 psi (105 bar)

Assembly Weight (no meter) ........................................................ 0.4 lb (0.18 kg)

Operating Temperature Range........................................ -40º–180º F (-40–82º C)

Inlet ..................................................................................... 1/2 npt and 3/4 npt

Outlet .............................................................. 7/8-14 straight thread o-ring boss

Wetted Parts ............................... aluminum, SST, CS, acetal, nitrile rubber, Geolast

Warranty ..............................................................................................Five years

Instruction Manual ................................................................................. 308642

Ordering Information

XDV20 Control Valves

247718

247721

247722

1/2 npt(f) swivel inlet, 1/2 in (12.7 mm); rigid extension, high fl ow, quick-close nozzle

1/2 npt(f) swivel inlet, 1/2 in (12.7 mm); fl exible extension, high fl ow, quick-close nozzle

3/4 npt(f) swivel inlet, 1/2 in (12.7 mm); rigid extension, high fl ow, quick-close nozzle

247723 3/4 npt(f) swivel inlet, 1/2 in (12.7 mm); fl exible extension, high fl ow, quick-close nozzle

Bare Valves (no extension)

247724

247725

Accessories

Has locking trigger and in-line fl ow through 1/2 npt(f) swivel inlet; 7/8-14 straight thread O-ring boss outlet

Has locking trigger and in-line fl ow through 3/4 npt(f) swivel inlet; 7/8-14 straight thread O-ring boss outlet

255793

255859

255921

Quick-close high fl ow nozzle for oil, ATF and anti-freeze; 7/8-14 straight thread O-ring boss inlet (XDV20 only)

Flex extension with quick-close nozzle ( 255793) for XDV20

Rigid extension with quick-close nozzle ( 255793) for XDV20

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

D I S P E N S E M E T E R S A N D C O N T R O L V A L V E S

67

Grease Dispense Valves

Dispense Meters and Control Valves

Pro Shot

Non-Metered Grease Valves

• Rugged design for harsh environments

• Pressure-assisted trigger for ease of operation

• Easy top adjustment with locking nut

• Pro-Shot adjustment nut protected by rigid guard

Typical Applications

• Service shops

• Heavy-duty dealerships

• Fast lube centers

• Automotive dealerships

• In-plant

• Lube trucks

• Mining

Typical Fluids Handled

• Grease up to NLGI #2

242056

Ordering Information

Pro-Shot Grease Dispense Valve

242056

242055

242058

242057

224872

1/4 npt(f) inlet with coupler and extension 200389

1/4 npt(f) inlet without coupler or extension

3/8 npt(f) inlet with coupler and extension 200389

3/8 npt(f) inlet without coupler or extension

Includes 30 in (76.2 cm) whip hose ( 109148), Z-Swivel ( 202577) and grease valve ( 242056)

Accu-Shot

Metered Grease Valves

• Accurate grease metering within ±3%

• Easy-to-read LCD display

• Handles pressure up to 5000 psi (345 bar) and fl ow up to 36 oz/min (1 kg/min)

Typical Applications

• Lube trucks

• Heavy-duty dealerships

• In-plant

• Fleet service facilities

• Mining

Typical Fluids Handled

• Grease up to NLGI #2

Ordering Information

Accu-Shot Electronic Metered Grease Valve

233807 U.S. Measurement, includes extension and hydraulic coupler

233933 Metric Measurement, includes extension and hydraulic coupler

233807

68

L U B R I C A T I O N E Q U I P M E N T

DISPENSE METERS AND CONTROL VALVES

www.graco.com

Manual Grease Guns and Fittings

Grease Guns, Accessories and Fittings

Ordering Information

Grease Guns

202600

110218

110216

110203

203697

1/8 npt(f) Power-Shot Booster Gun boosts incoming pressure up to 18,000 psi (1,242 bar). Use with any high-pressure lubricator. Maximum inlet pressure: 5000 psi (345 bar). Includes nozzle ( 200389). (Hose swivel 202579 must be ordered separately). Instruction Manual: 306271.

Standard Lever-Action Grease Gun: Develops up to 6000 psi (400 bar) working pressure and pumps

1.8 oz (51 g) per 40 strokes. Can be loaded via cartridge or bulk fi ll. Optional loader fi tting available.

Equipped with rigid extension and hydraulic coupler.

Heavy-Duty Lever-Action Grease Gun with high-pressure variable low-volume. Three-way loading: bulk fi ll, loader fi tting or 14 oz cartridge. Pumps 1.24 oz per 40 strokes. Includes air bleeder valve. Equipped with rigid extension and hydraulic coupler (M IL-G-3859). Can develop up to 10,000 psi (690 bar).

Comes with 236171, easy fi ll valve.

Pistol-Matic Grease Gun with three-way loading: bulk fi ll, loader fi tting or cartridge. Pumps .72 oz

(28.4 g) per 40 strokes. Includes air bleeder valve. Equipped with rigid extension and hydraulic coupler.

Can develop up to 3500 psi (241 bar).

1/8 npt(f) Hot-Shot Portable Booster Gun for portable operation without continuous connection to grease supply. Has 4 oz (113 g) grease reservoir in handle capable of servicing up to 100 fi ttings before needing a refi ll. Has grease fi tting for recharging from either manual or air-powered luber. Single-hand operation squeeze handle develops up to 10,000 psi (690 bar). Includes grease extension and nozzle 200389.

Instruction Manual: 306460.

110202

112196

110201

Pistol-Matic Grease Gun is the same as 110203 but with 12 in (30.4 cm) fl exible rubber hose and hydraulic coupler.

1/4 npt Pistol-Style Air-Operated Grease Gun is a spring-primed, single-shot gun. Three-way loading: bulk fi ll, loader fi tting or 14 oz (400 g) cartridge. Air input range of 75 to 100 psi (5 to 7 bar); working pressure of 6000 psi (414 bar). Pumps 1.2 oz (34 g) per 40 pulls at 100 psi (7 bar). Includes standard gun coupler and bleeder valve, 1/8 in-27 NPT rigid extension. (1/4 npt air input connection).

Suction Gun for evacuating and fi lling fl uids into gear housings, differentials, transmissions and related applications. Holds 1 pint (16 oz/473 cc), comes with red clear plastic 12 in (30.4 cm) hose.

Z-Swivels

202579

202577

224569

207948

1/8 npt(m) x 1/4 npt(f) free-ball bearing

1/4 npt(m) x 1/4 npt(f) free-ball bearing use with dispense valve 242055 and 242056

3/8 npt(m) x 3/8 npt(f) free-ball bearing use with dispense valve 242057 and 242058

1/2 npt(m) x 1/2 npt(f) free-ball bearing

Straight Swivels

204082

204083

204084

214925

1/8 npt(m) x 1/8 npt(f) 8000 psi (550 bar) free-ball bearing

1/4 npt(m) x 1/8 npt(f) 8000 psi (550 bar) free-ball bearing

1/4 npt(m) x 1/4 npt(f) 8000 psi (550 bar) free-ball bearing

3/8 npt(f) x 1/4 npsm(f-union) 5000 psi (345 bar)

214926

207946

3/8 npt(f) x 1/2 npsm(f-union) 5000 psi (345 bar)

3/8 npt(f) x 1/2 npsm(f-union) 5000 psi (345 bar)

207947

360º Swivels

1/2 npt(m) x 1/2 npt(f) 6000 psi (414 bar)

Swivels and locks into full 360º angle. Use for maximum coupler adaptability and reach.

203597 360º Grease Swivel with tapered-nose coupler (200325)

203198 360º Grease Swivel, 8,000 psi (552 bar) maximum working pressure (without coupler)

204082

110218

110216

110203

110202

203597

202600

112196

www.graco.com

203198

202577

L U B R I C A T I O N E Q U I P M E N T

G R E A S E G U N S

69

Grease Guns

Accessories and Fittings

Grease Nozzles

200389

Standard nozzle. Includes straight 6 in (15.2 cm), 1/8 npt(m) extension tube ( 150622) and tapered nose coupler ( 200325).

204072

204897

Swivel nozzle. Includes straight 6 in (15.2 cm), 1/8 npt(m) extension tube ( 150622) and tapered nose coupler ( 200325). Coupler has 360º swivel adapter ( 203198) for added convenience.

Swivel nozzle. Includes straight 12 in (30.4 cm), 1/8 npt(m) extension tube ( 155836) and tapered nose coupler ( 200325)0. Coupler has 360º swivel adapter ( 203198) for added convenience.

204204* Flexible 12 in (30.4 cm) hose nozzle. 1/8 npt(m) includes tapered-nose coupler ( 200325).

203504*

109148*

Flexible 12 in (30.4 cm) hose nozzle. 1/8 npt(m) includes tapered-nose coupler ( 200325) and lock sleeve connector ( 203497) for quick connection to any grease nozzle having tapered-nose coupler.

109145 12 In (30.4 cm) hose nozzle without coupler

112255 18 In (45.8 cm) hose nozzle without coupler

30 In (76.2 cm) hose nozzle without coupler, has 1/8 npt(m) both ends. Use as alternate for rigid nozzle with tapered-nose coupler 200325.

*Warning: potential injection hazard. Not for use above 5000 psi (345 bar).

Grease Couplers

200325

202650

1/8 npt(f) inlet standard tapered-nose coupler. Hardened jaws grip grease fi ttings through widesealing angle, but release easily. Maximum working pressure 8000 psi (551 bar).

1/8 npt(f) inlet standard straight nose grease coupler for manual operated grease guns only.

Maximum working pressure 3000 psi (206 bar).

200020 1/8 npt(f) inlet standard button-head coupler. Gives fast, positive seal on button-head fi ttings.

200021 1/8 npt(f) inlet giant button-head coupler. Gives fast, positive seal on larger button-head fi ttings.

Adapters have lock-sleeve quick-connector, works with any grease nozzle with a tapered-nose coupler.

201881 Hydraulic-to-push adapter. Used for U-joints and low-pressure service.

205532

205582

Hydraulic-to-steel needle adapter. Used for fl ush fi ttings. 250 psi (17 bar) max, not for air grease applications or guns.

Hydraulic-to-nylon needle adapter. Used for removable plugs. 250 psi (17 bar) max, not for air grease applications or guns.

223187 90º hydraulic-to-push adapter (K-car). Refer to instruction manual 306708.

203497

236171

Lock sleeve connector. 1/8 npt(f) outlet. Allows for quick connection to tapered-nose coupler. Inlet is standard grease fi tting with sleeve to lock connector in place.

Easy-fi ll valve. For faster loading of graco hand grease guns with gun loaders. Replaces hydraulic fi ttings on all grease guns with 1/8 npt(f). Refer to instruction manual 308306.

204929

205592

Grease loader valve. For use with lever-operated, high-volume grease pumps. Permits quick bulk-fi lling of hand-operated grease lever guns equipped with easy-fi ll valve 236171. Refer to instruction manual 308306.

Hydraulic adapter assortment package. Contains needle adapter ( 205568), plug adapter

( 205554), push adapter ( 201881), nylon needle adapter ( 205582), hydraulic-to-steel needle adapter ( 205532) and whip hose nozzle connector ( 203504).

Grease Gun Fittings

1/8 npt Threaded Grease Fittings (steel; ball-check)

Part No.

100054

101277

100970

100834

100971

100833

Shank

9/32

1-9/32

9/32

9/32

9/32

9/32

Description

1/8 npt straight

1/8 npt straight

1/8 npt 30º angle

1/8 npt 45º angle

1/8 npt 65º angle

1/8 npt 90º angle

Pressure Rating

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

200020

205532

205582

70

L U B R I C A T I O N E Q U I P M E N T

G R E A S E G U N S

200325

200389

204072

203497

205592

100833

100970

www.graco.com

Grease Guns

Accessories and Fittings

1/4 npt Threaded Grease Fittings (steel; ball-check)

100848 3/8

100846

100847

101283

3/16

13/64

3/16

1/4 npt 67º angle

1/4-28 straight

1/4-28 45º angle

1/4-28 90º angle

101281

110702

11/32

19/64

1/4-28 straight

1/4-28 65º angle

100835 12/32 1/4-28 straight

1/4 npt Thread-Forming Grease Fittings (steel; ball-check)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

110703

110705

110709

13/64

13/64

7/32

Drive-Type Grease Fittings (steel; no check)

1/4-28 straight

1/4-28 90º angle

3/16 npt Thread-Forming Grease Fittings (steel; ball-check)

110706 3/32 3/16 npt straight

3/16 npt 65º angle

110713

101312

110710

101287

1/4

1/4

1/4

17/64

Standard Button-Head Grease Fitting (steel)

3/16 npt straight

3/16 npt straight

5/16 npt straight

1/4 npt straight

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

10,000 psi (690 bar)

Shank

9/32

9/32

9/32

3/16

13/64

Easy-Outs

101604

101605

100837

101297

7/16

33/64

110711 35/64

Giant Button-Head Grease Fitting (steel)

1/4 npt straight

3/8 npt straight

1/2 npt straight

110712

100854

9/16

1/2

3/8 npt straight

1/4 npt straight

Grease Accessory Packages

202654 Convenient Storage Box Contains the following threaded fi ttings in the quantity listed:

Description

1/8 npt straight

1/8 npt 30º angle

1/8 npt 90º angle

1/4-28 straight

1/4-28 45º angle

Grease Fitting No.

100054

100970

100833

100846

100847

1/8 npt

1/4-28 unf

Quantity

30

10

10

20

10

101605

101287

101297

100834

110704

110712

202654

www.graco.com

101604

L U B R I C A T I O N E Q U I P M E N T

G R E A S E G U N S

71

Oil King,

Coolant King

and Oil Ace

Fluid Reclaim Packages

Oil King and Coolant King

• Large 25 gallon capacity with sight gauge

• Convenient tool trays and fi lter areas

• Large offset collection pan with screen

• Oversized tires to get over hose and rough fl oors

• Color specifi c receiver for easy identifi cation

Typical Applications

• Used fl uid receiver

• Automotive dealerships

• Heavy-duty dealerships

• Fast lube centers

• Fleet service facilities

• Service shops

Typical Fluids Handled

• Used oil–Oil King

• Used antifreeze–Coolant King

Ordering Information

Oil King Oil Receiver

238866

25 gal (95 l) Polyethylene tank with used-fi lter tray, tool holders and sight gauge. Includes all hardware for topside evacuation or bottom drain*. Instruction manual 308667.

Coolant King Anti-Freeze Receiver

248632

25 gal (95 l) Polyethylene tank with used-fi lter tray, tool holders and sight gauge. Includes all hardware for topside evacuation or bottom drain. *

* Must use 222090 or 224873 for topside evacuation. Must ship via truck.

Oil Ace

• Easy to drain using shop air pressure

• Large 24 gallon capacity

• Large offset collection pan with screen

Typical Applications

• Pressurized used oil receiver • Service shops

• Automotive dealerships • Fast lube centers

• Heavy-duty dealerships • Fleet service facilities

Typical Fluids Handled

• Used oil

Ordering Information

Oil Ace

119577 24 gal (90 l) Steel-tank Pressurized Oil Drain

238866

248632

72

L U B R I C A T I O N E Q U I P M E N T

F L U I D R E C L A I M

www.graco.com

Fluid Reclaim Packages and Accessories

Ordering Information

16 gal (60 l) Used-Oil Receiver with drum

239301 Use with evacuation kit 240832. Instruction manual 306449.

16 gal (60 l) Used-Oil Receiver without drum

239302 Instruction manual 306449.

Funnel Kit

243650 Use with 238866, 239301, 239302 and 248632. Includes tray and pipe.

Wall-Mounted Funnel Drain

154616

Use with Pedestal Receiver 225272 to open automatic check-valve and drain used oil through wall to waste tank. Drain has 1-1/4 npt(f) outlet.

Drum-Mounted Funnel Drain

156789

Use with Pedestal Receiver ( 225272) to open automatic check-valve and drain used oil into standard drum.

Funnel drain has 2 npt bung fi tting for use with 55 gal (210 l) or 16 gal (60 l) drums, or 275 gallon

(1,100 l) tanks.

ATF Drain Funnel

208009

Use with Pedestal Receiver ( 225272) to extend funnel reach. Use for draining transmissions.

(Not equipped with drain plug.) 16 in x 24 1/2 in

Rolling Used-Oil Receiver

218969

Specially designed for car and truck fast-lube facilities where speed and mobility are important. Adjustable steel rollers fi t track widths of 39 in (99 cm) to 46 inches (117 cm), with a minimum running width of

2-1/2 in (63.5 mm). Front and rear drain fi ttings allow use of two drains on a single track, permitting two receivers to be drained simultaneously. Instruction manual 307727. Unit includes 30 gal (114 l) steel tank,

1-1/2 npt drain valve ( 108204), 1-1/2 npt quick coupler ( 108202) and 1-1/2 npt coupler cap. Dimensions:

24 in (61 cm) wide; 33 in (84 cm) long; 11 in (28 cm) deep; 3 in (7.6 cm) diameter wheels. 1-1/2 in drain hose–see manual provided.

Narrow Rolling Used-Oil Receiver

235346

Same as 218969 above, except track width range is from 34.2 in (87 cm) to 42.2 in (108 cm). 27 gal (102 l) capacity. Instruction manual 307727. See accessories on page 101.

Big Hauler ™ Truck Drain

244055

Specially-designed for truck maintenance facilities, the Big Hauler Truck Drain boasts a large capacity and easy maneuverability. Dimensions: 42 in (106.7 cm) long; 30 in (76.2 cm) wide; 9 in (22.9 cm) deep.

Capacity: 26 gallons (98 l). Instruction manual 309194. Gravity drain valve at bottom of unit allows for easy drain access. 3/4 in npt outlet can also be used with 224873 or 222090 for diaphragm evacuation.

240832 can be ordered separately for existing diaphragm pump evacuation systems.

Instruction manual 308719.

239301

208009

www.graco.com

244055

218969

L U B R I C A T I O N E Q U I P M E N T

FLUID RECLAIM

73

Fluid Reclaim Packages and Accessories

Packages for Used-Oil Evacuation with Air-Operated Diaphragm Pumps

Wall-Mounted Packages

24E166

Includes: 1050A (1 in) diaphragm pump ( 647016), wall bracket ( 24C637), air installation kits ( 240684), fl uid installation kits ( 240685), drum style adapter kits ( 240832).

NOTE: Used-oil receivers are not included and must be ordered separately. See instruction manual 313597 for more information.

224873

Includes: 716 (3/4 in) diaphragm pump ( 241906), wall bracket ( 224835), air installation kits, fl uid installation kits ( 240685), drum style adapter kits ( 240832).

NOTE: Used-oil receivers are not included and must be ordered separately.

Stationary Gear-Oil Evacuation Systems with 716 or 1040 Diaphragm Pump

System evacuates lube from differential case using suction generated by a diaphragm pump. Nylon tubes ranging in size from 3/16 in OD to 1/2 in OD are included to fi t through sight plug to completely drain the case. Evacuated gear lube is then pumped to waste tank. Piping and waste tank not included. Systems are fully-groundable and bondable for safe transfer of used oil.

224955

24E167

Includes: 716 diaphragm pump ( 241906), air control kit ( 110149), mounting kit ( 224759), swivel union

( 157785), hose coupler ( 111474),suction hose/wand** ( 221146) and control valve** ( 220969).

** Order additional suction hose/wand ( 221146) and additional control valve ( 220969) for each additional suction point.

Note: Order grounding clamp ( 222011) or use locally-supplied grounding wires and clamps in accordance with applicable codes.

Includes: UL-listed 1050A diaphragm pump ( 647016), air control kit, hose and fi tting kit ( 222149), evacuation, suction hose/wand** ( 221146) and wall bracket (24C637).

** Order additional suction hose/wand 221146 and additional control valve 220969 for each additional suction point.

Note: Order grounding clamp 222011 or use locally-supplied grounding wires and clamps in accordance with applicable codes.

See instruction manual 313597 for more information.

Port-Evacuation Pump

223695

Port-Evacuation allows fast, clean withdrawal of gear lube, ATF, anti-freeze, and related fl uids. Includes:

716 diaphragm pump ( 241906), mounting kit with 10 ft (3 m) suction hose ( 223697) which attaches to wands of four different diameters (suction wand kit, 223696): 1/2 in (12.7 mm); 3/8 in (9.5 mm); 1/4 in

(6.4 mm), and 3/16 in (4.7 mm). Instruction manual 308035.

Suction Wand Kits

223696 15 in (38.1 cm)

224762 48 in (121.9 cm)

Used-Oil Handling Accessories

Tandem Drain Kit

218970

108491

Tandem drain kit connects two rolling receivers for fl ow-through draining operation. Kit includes connector hose, shut-off valve, pipe nipple, and quick-connect nipple. Instruction manual 307727.

Drain hose kit allows rolling used-oil receiver to be drained directly into the used-oil line. Kit is 24 in (0.6 m) in length with camlock coupler on one end.

Swing-Arm Drain Kit

221007

Used for servicing single rolling used-oil receiver ( 218969). When used with tandem drain kit ( 218970) it can service two receivers on a single track. Kit includes swivel elbow ( 108867), connector hose ( 111931), dust cap ( 108203) and male adapter ( 108202).

Oil Tank Monitor

116229

Shuts off air to the pump when tank is full. Mounted at either end of fast lube service pit, swing-arm drain stores against pit wall and is rotated into position for use.

Accessories for Port-Evac Pump ( 223965)

223888 6 ft (1.8 m) suction hose for ATF and anti-freeze. Includes fi lter screen.

*Package 224873

(Package does not include

238866 receiver or tank)

223695

116229

218970

74

L U B R I C A T I O N E Q U I P M E N T

F L U I D R E C L A I M

223888

www.graco.com

Fluid Reclaim Packages and Accessories

Fluid Reclaim Accessories

222178 U-tube for used-oil drain cart evacuation system ( 222148) size: 1/2 npt(mbe).

222011 Grounding clamp for all used-oil handling systems includes 25 ft (7.6 m) grounding wire.

Fas-Vac Evacuation Systems

224667*

224700*

Fas-vac evacuation system (without drum) basic system includes 716 diaphragm pump and mounting hardware. Instruction manual 308154.

16 gallon (60 l) system includes pump ( 224667), dolly ( 224665), wand storage kit ( 224666), evacuation hose ( 224669) and 16 gallon (60 l) drum ( 111468). Instruction manual 308154.

224763*

224701*

16 gallon (60 l) system (without drum) includes same items as 224700 above, but no drum. Instruction manual 308154.

55 gallon (200 l) system (without drum) includes pump ( 224667), 55 gallon (200 l) drum truck ( 111470), wand storage kit ( 224666) and evacuation hose ( 224702). Instruction manual 308154.

187359 4-way valve 1/2 npt(f) ports

* 224759 FLR mounting kit and 110149 FRL must be ordered separately. See instruction manual 308163.

Hoses, Fittings and Accessories

Air Filters

Centrifugal action 1/4, 3/8 and 1/2 npt. (with 20 micron fi lters); 3/4 npt having 40 micron fi lters to remove water and foreign particles from air supply.

110146

106149

1/4 npt(fbe)

1/2 npt(fbe)

106148

106150

3/8 npt(fbe)

3/4 npt(fbe)

Automatic Filter Drain

106151

Float-type drain for automatic emptying of accumulated fl uid in a fi lter assembly. 1/4 npt(m) (does not fi t air fi lter 110146)

Air Regulators

Provides precision control of outlet air pressure. Feedback principle provides constant pressure to pump regardless of air demand rate and fl uctuations in supply pressure. (Additional fi ttings required except air regulators with installation kits.)

110318

110147

110234

109075

1/4 npt(fbe)

1/4 npt(fbe) with gauge

3/8 npt(fbe)

3/8 npt(fbe) with gauge

202858

104266

244844

207755

244845

3/8 npt(m) x 1/2 npsm(f) with gauge

1/2 npt(fbe)

1/2 npt(fbe) with gauge

3/4 npt(fbe)

3/4 npt(fbe) with gauge

Installation Kits

Installation kits include: shut-off valve, regulators, gauges and fi ttings as necessary for normal installation.

218316

224512

Installation kits for Fast-Flo, Fire-Ball, or Husky 307 and 716 diaphragm pumps

Installation kits for Mini Fire-Ball 225 and Fire-Ball

Air Lubricators

Extends pump life and smooths pump movement by applying measured lubricant to all moving parts within the pump air motor. Control knob and sight window allow adjustment of dispensed lubricant.

214848

110148

214847

214849

1/2 npt(fbe)

1/4 npt(fbe)

3/8 npt(fbe)

3/4 npt(fbe)

106148

109075

224701

106151

224512

214847

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

FLUID RECLAIM

75

Hoses and Fittings

Accessories

FRL Combination Units

Each includes fi lter, regulator, pressure gauge, lubricator and connection fi ttings.

110149

110150

217072

217073

1/4 npt (fbe)

3/8 npt (fbe)

1/2 npt (fbe)

3/4 npt (fbe)

Bleed-type Air Shut-off Valves

Closes air inlet to pump and relieves trapped air pressure down line from valve. Recommended for each pump drop line.

(Note: Be certain to install correctly: if installed backwards air will constantly escape from the valve.)

110223

110224

110225

110226

1/4 npt(fbe)

3/8 npt(fbe)

1/2 npt(fbe)

3/4 npt(fbe)

107142

107141

1/2 npt(mxf)

3/4 npt(mxf)

Air Line Shut-off Valves Ball valve-type air line shut-off valve; non-pressure relieving.

208390 1/4 npt(mbe)

208393

208630

109077

118464

3/8 npt(mbe)

1/2 npt(m) x 3/8 npt(f)

3/4 npt(fbe)

1 npt(fbe)

Quick-Connect Coupler

Permits quick, convenient attachment of air supply hoses.

208536 1/4 npt(fbe)

110198

110199

3/8 npt(f)

1/2 npt(f)

110200 3/4 npt(f)

Quick-Connect Nipple

Allows quick attachment of air supply hoses to pump motor.

169970 1/4 npt(m)

169967

169971

1/4 npt(f)

3/8 npt(m)

110196

110197

1/2 npt(m)

3/4 npt(m)

Air Needle Valve

Controls pump speed by restricting air fl ow to pump or other air-operated equipment.

205090

206264

1/4 npt(f) outlet port; 1/4 npt(m) inlet port

1/8 npt(f) outlet port; 1/4 npt(m) inlet port

Air Pressure Relief Valve

Prevents pump from operating beyond recommended working pressure by opening at a pre-set maximum air pressure.

103347

110065

90 psi (6 bar)

60 psi (4 bar)

76

L U B R I C A T I O N E Q U I P M E N T

H O S E S A N D F I T T I N G S

110150

110223

107142

208536

169970

205090

110065

www.graco.com

Hoses and Fittings

Accessories

Air Pressure Gauge

Allows visual check of air pressure being supplied to the pump. Rated to 200 psi (14 bar).

110319

100960

1/8 npt(m) bottom inlet; black

1/4 npt(m) bottom inlet; black

101180

Air manifold

1/4 npt(m) bottom inlet; chrome

Supply several pumps from a common air supply line. Air inlet port is larger than delivery ports to ensure adequate air fl ow to all pumps.

158990 Four outlet ports; 3/8 npt(f)

601950 Three outlet ports; 1/2 npt(f)

Runaway Valve

Prevents pump damage by automatically closing the air line to stop the pump when a runaway pump condition occurs due to an empty barrel or hose leak.

224040 3/4 npt(fbe)

Blow Guns

208627

236211

Air Blow Gun, 1/4 npt(f), use with coupler 208536.

Safety Blow Gun tip swivels freely and cannot be removed. Tip pressure will not exceed 30 psi (2 bar), adequate for cleaning. Maximum working pressure 150 psi (10 bar). Use with coupler 208536.

Tire Infl ators

236205

236206

218545

Heavy-duty Tire Infl ator includes 12 in (30 cm) hose with swivel dual-foot chuck and pop-out gauge.

Tapered chuck nut fi ts wheel-cover holes on cars and light trucks. Gauge ranges from 0-120 psi in 2 psi increments. Maximum working pressure 250 psi (18 bar), 1/4 npt(f) inlet.

Passenger Car Tire Infl ator includes 12 in (30 cm) hose with straight-on chuck and pop-out gauge.

Tapered chuck nut fi ts wheel cover holes on cars and light trucks. Ideal for use on reels. Gauge ranges from 0-90 psi in 2 psi increments. Maximum working pressure 250 psi (18 bar), 1/4 npt(f) inlet.

1/4 npt(f) Tire Chuck, durable, full-volume tool for adding/relieving air pressure.

109151

109152

109153

109154

109156

109157

109158

Water Valve

180685

Water/Anti-Freeze Bib is a durable, full-volume dispense nozzle for water, anti-freeze and windshield washer fl uid. Nitrile rubber seals with 1/4 npt(f) inlet. Maximum pressure is 100 psi (7 bar).

Heavy-Duty Reinforced Hoses

Heavy-duty reinforced hose for use with grease, oil and undercoating material. Hoses are black, male at both ends.

Lubrication hoses listed are grounded for static electrical discharge.

1/4 in ID hoses with maximum pressure rating of 5000 psi (345 bar)

Part No.

Length Fittings

109145

109146

12 in (0.3 m)

15 in (0.4 m)

1/8 in x 1/8 in (4.8 mm x 4.8 mm) with bend restrictor

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

109147

109148

109149

109150

24 in (0.6 m)

30 in (0.8 m)

48 in (1.2 m)

72 in (1.8 m)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

1/8 in x 1/8 in (4.8 mm x 4.8 mm) with bend restrictor

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

12 ft (3.6 m)

15 ft (4.6 m)

20 ft (6.1 m)

25 ft (7.6 m)

35 ft (10.6 m)

40 ft (12.2 m)

50 ft (15.3 m)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

158990

208627

www.graco.com

100960

224040

236211

236206

180685

L U B R I C A T I O N E Q U I P M E N T

HOSES AND FITTINGS

77

Hoses and Fittings

Lubrication Hoses

3/8 in ID hoses with maximum pressure rating of 4000 psi (276 bar), npt (mbe)

Part No.

Length Fittings

109160

109161

12 in (0.3 m)

24 in (.62 m)

1/4 in x 1/2 in (6.4 mm x 12.7 mm)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

109162

109163

109165

109170

109169

109170

48 in (1.2 m)

72 in (1.8 m)

15 ft (4.6 m)

50 ft (15.3 m)

40 ft (12.2 m)

50 ft (15.3 m)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

Lubrication Hoses (Oil)

1/2 in ID hoses with maximum pressure rating of 3000 psi (207 bar), npt (mbe)

Part No.

220604

110069

220598

220600

220591

220590

220592

220593

220608

221092

Length

12 in (0.3 m)

15 in (0.4 m)

18 in (0.5 m)

54 in (1.4 m)

72 in (1.8 m)

10 ft (3.1 m)

16 ft (4.9 m)

20 ft (6.1 m)

25 ft (7.6 m)

40 ft (12.2 m)

Fittings

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

221093

237861

109108

109105

50 ft (15.3 m)

75 ft (22.9 m)

18 in (0.4 m)

72 in (1.8 m)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 3/4 in (12.7 mm x 19.1 mm)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

111010

237865

10 ft (3.0 m)

75 ft (22.9 m)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

1/2 in x 1 in (12.7 mm x 25.4 mm)

237866 50 ft (15.2 m) 1/2 in x 1 in (12.7 mm x 25.4 mm)

1 in ID hose rated to maximum pressure of 125 psi (8.7 bar), npt (mbe)

Part No.

249058

Length

50 ft (15.2)

Fittings

1 in x 1 in (25.4 mm x 25.4 mm)

1 in ID hose rated to maximum pressure of 212 psi (14.6 bar)

Part No.

Length Fittings

241908

241907

50 ft (15.2)

30 ft (9.1 m)

1 in x 1 in (25.4 mm x 25.4 mm)

1 in x 1 in (25.4 mm x 25.4 mm)

Air/Water Hoses

Hoses for air, water, anti-freeze and windshield washer fl uid. Hoses are red with male fi ttings at both ends.

Coiled 1/4 in ID hose with maximum pressure rating of 180 psi (12 bar), npt (mbe)

Part No.

Length Fittings

205600 50 ft (15.3 m) 1/4 in x 50 ft (6.4 mm x 15.3 m)

78

L U B R I C A T I O N E Q U I P M E N T

H O S E S A N D F I T T I N G S

www.graco.com

Hoses and Fittings

Air/Water Hoses

Fabric-Reinforced 1/4 in ID hoses with maximum pressure rating of 180 psi (12 bar), npt (mbe)

Part No.

Length Fittings

109123

109124

18 in (0.5 m)

4 ft (1.2 m)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

109125

109126

109127

109128

6 ft (1.8 mm)

10 ft (3.1 m)

25 ft (7.6 mm)

40 ft (12.2 m)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 1/4 in (6.4 mm x 6.4 mm)

1/4 in x 1/2 in (6.4 mm x 12.7 mm)

1/4 in x 1/2 in (6.4 mm x 12.7 mm)

218491 40 ft (12.2 m) 3/8 in x 1/4 in (9.5 mm x 6.4 mm)

3/8 in ID hoses with maximum pressure rating of 180 psi (12 bar), npt (mbe)

Part No.

109129

Length

15 in (0.4 m)

Fittings

3/8 in x 1/2 in (9.5 mm x 12.7 mm)

204560

109130

203320

109131

18 in (0.5 m)

4 ft (1.2 m)

6 ft (1.8 m)

10 ft (3.1 m)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

3/8 in x 3/8 in (9.5 mm x 9.5 mm)

110326

109132

109133

249181

16 ft (4.9 m)

25 ft (7.6 m)

30 ft (9.2 m)

40 ft (12.2 m)

1/4 in x 3/8 in (6.4 mm x 9.5 mm)

3/8 in x 1/2 in (9.5 mm x 12.7 mm)

3/8 in x 1/2 in (9.5 mm x 12.7 mm)

1/2 in x 3/8 in (12.7 mm x 9.5 mm)

109134

109135

40 ft (12.2 m)

60 ft (18.3 m)

3/8 in x 1/2 in (9.5 mm x 12.7 mm)

3/8 in x 1/2 in (9.5 mm x 12.7 mm)

1/2 in ID hose with maximum pressure rating of 180 psi (12 bar), npt (mbe)

Part No.

Length Fittings

218093

110046

205418

214656

22 in (0.56 m)

4 ft (1.2 m)

6 ft (1.8 m)

10 ft (3.1 m)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

248312

248313

25 ft (7.6 m)

50 ft (15.2 m)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

1/2 in x 1/2 in (12.7 mm x 12.7 mm)

3/4 in ID hoses with maximum pressure rating of 180 psi (12 bar), npt (mbe)

Part No.

Length Fittings

110047

110048

208610

214955

208611

18 in (0.5 m)

4 ft (1.2 m)

6 ft (1.8 m)

10 ft (3.1 m)

25 ft (7.6 m)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

3/4 in x 3/4 in (19.1 mm x 19.1 mm)

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

HOSES AND FITTINGS

79

Hoses and Fittings

Pipe Fittings and Swivels

Bushing – reducing, standard and expanding

Part No.

Thread Size (m x f) Part No.

100030

100081

1/4 in x 1/8 in

1/2 in x 3/4 in

159841

100615

100896

Pipe Adapters

3/4 in x 1/2 in

Part No.

150171

Thread Size (m x f)

1/8 in x 1/8 in

100380

Part No.

159840

150287

156022

1/4 in x 3/8 in

3/8 in x 1/2 in

159842

168595

Street Elbows

Part No.

Thread Size (m x f) Part No.

155699 100840

176393

1/4 in x 1/4 in

3/4 in x 3/4 in

Coupling (standard)

Part No.

Thread Size Part No.

100451

158581

1/8 in

1/2 in

113093

100385

Hex Nipple (standard and reducing)

Part No.

Thread Size Part No.

151519

165198

159239

157191

1/4 in x 1/8 in

3/8 in x 1/4 in

1/2 in x 3/8 in

3/4 in x 1/2 in

156971

156849

158491

175013

Square-Head Plug

Part No.

Thread Size

111697

104663

1/4 in

3/4 in

Part No.

100040

Straight Swivel Adapter*

Part No.

Rigid (m) x Swivel (f) Part No.

208434

155665

1/8 in x 1/4 in

3/8 in x 3/8 in

156823

162505

157785 158256

160022

1/2 in x 3/8 in

1 in x 1 in

90º Swivel Adapter*

Part No.

Rigid f) x Swivel (f) Part No.

157676

157416

1/4 in x 1/4 in

1/2 in x 1/2 in

155677

156589

Straight Swivel Adapter*

Part No.

Rigid (f) x Swivel (f) Part No.

155570

155653

156172

90º Swivel*

1/4 in x 1/4 in

1/2 in x 1/4 in

3/5 in x 3/4 in

159153

161077

158383

Part No.

155541

Rigid (M) x Swivel (F) Part No.

1/4 in x 1/4 in 155495

217430 3/8 in x 1/2 in 161037

160327 3/4 in x 3/4 in

45º Swivel Adapter*

Part No.

161889

Rigid (M) x Swivel (F)

3/8 in x 3/8 in

Part No.

105281

*Not a “live” swivel, position is stationary after tightened

Thread Size (m x f)

3/8 in x 1/4 in

3/4 in x 1/4 in

1 in x 1/2 in

Thread Size (m x f)

1/8 in x 1/4 in

1/4 in x 1/2 in

1/2 in x 3/4 in

Thread Size (m x f)

3/8 in x 3/8 in

Thread Size

1/4 in

3/4 in

Thread Size

1/4 in x 1/4 in

3/8 in x 3/8 in

1/2 in x 1/2 in

3/4 in X 3/4 in

Thread Size

3/8 in

Part No.

100206

100505

158586

Part No.

156580

150286

Part No.

158683

Part No.

162024

100474

Part No.

156296

162449

194048

158555

Part No.

100737

Rigid (m) x Swivel (f) Part No.

1/4 in x 1/4 in 157705

3/8 in x 1/2 in 156684

3/4 in x 3/4 in 202965

Rigid (f) x Swivel (f) Part No.

3/8 in x 3/8 in

3/4 in x 3/4 in

159801

Rigid (f) x Swivel (f) Part No.

3/8 in x 1/4 in

1/2 in x 3/8 in

1 in x 1 in

156173

155865

Rigid (M) x Swivel (F) Part No.

3/8 in x 1/4 in 155494

1/2 in x 3/8 in 155470

Rigid (M) x Swivel (F)

3/4 in x 3/4 in

Thread Size (m x f)

1/2 in x 1/4 in

3/4 in x 3/8 in

1 in x 3/4 in

Thread Size (m x f)

1/8 in x 3/8 in

3/8 in x 3/8 in

Thread Size (m x f)

1/2 in x 1/2 in

Thread Size

3/8 in

1 in

Thread Size

3/8 in x 1/8 in

1/2 in x 1/4 in

3/4 in x 3/8 in

1 in x 3/4 in

Thread Size

1/2 in

Rigid (m) x Swivel (f)

1/4 in x 3/8 in

1/2 in x 1/2 in

1 in x 3/4 in

Rigid (f) x Swivel (f)

3/8 in x 1/2 in

Rigid (f) x Swivel (f)

3/8 in x 3/8 in

1/2 in x 1/2 in

Rigid (M) x Swivel (F)

3/8 in x 3/8 in

1/2 in x 1/2 in

80

L U B R I C A T I O N E Q U I P M E N T

H O S E S A N D F I T T I N G S

www.graco.com

Hoses and Fittings

Tube and Fittings

Tube Fittings

Maximum pressure rating of 3000 psi (207 bar) with appropriate tubing wall thickness.

Tube Union Flow 90º Elbow

Part No.

101012

101376

Tube Union – Straight

Part No.

Tube OD

5/8 in

7/8 in

101009

101340

Male Connector

Part No.

Tube OD

5/8 in

7/8 in

Tube OD

101339

Female Connector – Straight

7/8 in

Part No.

Tube OD

101008

101520

5/8 in

7/8 in

Tube Tee with Female Branch

Part No.

Tube OD

101013 5/8 in

Thread

3/4 npt

Thread

1/2 npt

3/4 npt

Thread

5/8 npt

101378 7/8 in 3/4 npt

NOTE: Consult you local distributor for additional tube-fi tting requirements (ie: high-pressure, low-pressure, etc.) and fi tting recommendations: Parker; AeroQuip; Weatherhead; Lenz; Crawford; or Imperial Eastmand.

Technical Information

Always use a qualifi ed installer and ensure the installer follows the detailed instructions included with every Graco product.

1. Always use new pipe. Make certain that pipes are clean and free of rust and scale.

2. When cutting pipe remove burrs and chips that may damage dispense valves and meters.

3. Always fl ush the system with oil before attaching dispense valves and meters.

Air Lines

Main Line

3/4 in or 1 in ID pipe

Branch Line

3/8 in or 1/2 in ID pipe

Pump Model

Fast-Ball; Mini Fire-Ball 225

3/4 in or 1 in ID pipe 1/2 in ID pipe Fire-Ball

Fluid Lines

This information applies to typical automotive fl ow rate service requirements.

Chassis Grease Lubricant Supply Lines (based upon 5000 psi (345 bar) maximum working pressure)

Supply Line Length

Up to 50 feet

Supply Pump

50:1 Fire-Ball 300, 425

Hydraulic Supply Line Tubing

5/8" OD x .109" Wall Tube

50 to 100 feet

100 to 200 feet

100 to 200 feet

200 feet and up

50:1 Fire-Ball 300, 425

50:1 Fire-Ball 300

50:1 Fire-Ball 425

50:1 Fire-Ball 300, 425

5/8" OD x .109" Wall Tube

N/A

N/A

N/A

Motor Oil, Gear Lube, or ATF Lubricant Supply Lines (based upon 1000 psi maximum working pressure)

Supply Line Length Supply Pump Hydraulic Supply Line Tubing

Up to 50 feet

Up to 50 feet

50 to 100 feet

5:1 Fire-Ball 300

10:1 Fire-Ball 425

5:1 Fire-Ball 300

5/8" OD x .049" Wall Tube

3/4" OD x .049" Wall Tube

3/4" OD x .049" Wall Tube

50 to 100 feet

100 to 200 feet

100 to 200 feet

200 feet and up

200 feet and up

10:1 Fire-Ball 425

5:1 Fire-Ball 300

10:1 Fire-Ball 425

5:1 Fire-Ball 300

10:1 Fire-Ball 425

1" OD x .049" Wall Tube

1" OD x .049" Wall Tube

1-1/2" OD x .095" Wall Tube

1-1/2" OD x .095" Wall Tube

1-1/2" OD x .095" Wall Tube

www.graco.com

L U B R I C A T I O N E Q U I P M E N T

HOSES AND FITTINGS

81

Tank Packages

Fluid Dispense Packages

Mini Fire-Ball

®

225, 3:1 Bulk-Oil Dispensing Packages

Mini Fire-Ball 225, 3:1 Pump Package

248623*

248622*

Includes: Mini Fire-Ball 225, 3:1 Universal pump with bung adapter and down tube ( 248097), SD Series reel with 50 ft (15.2 m) x 1/2 in (12.7 mm) fl uid hose ( HPM65B), LDM5 meter ( 256215)

Includes: Mini Fire-Ball 225, 3:1 Universal pump with bung adapter and down tube ( 248097), SD Series reel with 25 ft (7.6 m) x 1/2 in (12.7 m) fl uid hose ( HPM33B), LDM5 meter ( 256215)

*Order 218549 (1/2 in x 24 in) hose reel inlet kit separately NOTE: Tanks not included

Fire-Ball 300, 5:1 Deluxe Bulk-Oil Dispensing Packages

Fire-Ball 300, 5:1 Pump Packages

241633*

Includes: Fire-Ball 300, 5:1 pump universal ( 203876), 3/8 in (9.5 mm) regulator/gauge ( 109075), 3/8 in

(9.5 mm) x 3/8 in (9.5 mm) nipple ( 156849), 2 in (50.8 mm) bung adapter ( 222308), SD Series reel with

25 ft (7.6 m) x 1/2 in (12.7 mm) hose ( HPM33B), SDM5 meter ( 255350)

224541*

244038*

Includes: Fire-Ball 300, 5:1 pump universal ( 203876), 3/8 in (9.5 mm) regulator/gauge ( 109075), 3/8 in

(9.5 mm) x 3/8 in (9.5 mm) nipple ( 156849), 2 in (50.8 mm) bung adapter ( 222308), SD Series reel with

50 ft (15.3 m) x 1/2 in (12.7 mm) hose ( HPM65B), 18 in (45.7 cm) hose ( 220598), 90º swivel (inlet on hose reel) ( 157416), SDM5 meter ( 255350)

Includes: Fire-Ball 300, 5:1 pump universal ( 203876), 3/8 in (9.5 mm) regulator/gauge ( 109075), 3/8 in

(9.5 mm) x 3/8 in (9.5 mm) nipple ( 156849), 2 in (50.8 mm) bung adapter ( 222308), SD Series reel with

50 ft (15.3 m) x 1/2 in (12.7 mm) hose ( HPM65B), 18 in (45.7 cm) hose ( 220598), 90º swivel ( 157416),

SDP5 meter ( 255200)

224534*

Dispensing from Bench-Top Tanks with Fire-Ball 300, 5:1 Pump Package. Includes: Fire-Ball 300, 5:1 pump, Universal ( 203876), 3/8 in (9.5 mm) regulator/gauge ( 109075), Air fi lter ( 106148), 3/8 in (9.5 mm) x 3/8 in (9.5 mm) nipple ( 156849), SD Series reel with 50 ft (15.3 m) x 1/2 in 12.7 mm) hose

( HPM65B), Drain valve ( 106151), 72 in (182.9 cm) hose kit ( 222063), Thermal relief valve ( 237893), 90º swivel ( 157416), SDM5 Meter ( 255350)

*Order 218549 (1/2 in x 24 in) hose reel inlet kit separately NOTE: Tanks not included

Package

248623

(tank not included)

Package

224541

(tank not included)

82

L U B R I C A T I O N E Q U I P M E N T

B U L K F L U I D D I S P E N S E

Package

224534

(tank not included)

www.graco.com

Index

Part No. Page No.

Part No.

100030........................................ 80

100040........................................ 80

100054.................................. 70, 71

100081........................................ 80

100206........................................ 80

100220........................................ 18

100380........................................ 80

100385........................................ 80

100451........................................ 80

100474........................................ 80

100505........................................ 80

100611........................................ 42

100615........................................ 80

100737........................................ 80

100833.................................. 70, 71

100834.................................. 70, 71

100835........................................ 71

100837........................................ 71

100840........................................ 80

100846........................................ 71

100847........................................ 71

100848........................................ 71

100854........................................ 71

100896........................................ 80

100960........... 16, 19, 28, 29, 40, 77

100970.................................. 70, 71

100971........................................ 70

101008........................................ 81

101009........................................ 81

101012........................................ 81

101013........................................ 81

101078........................................ 19

101180........................................ 77

101277........................................ 70

101281........................................ 71

101283........................................ 71

101287........................................ 71

101297........................................ 71

101312........................................ 71

101339........................................ 81

101340........................................ 81

101376........................................ 81

101378........................................ 81

101520........................................ 81

101604........................................ 71

101605........................................ 71

102527.......................................... 9

103347........................................ 76

104266........... 16, 19, 28, 29, 40, 75

104663........................................ 80

105281........................................ 80

105474........................................ 11

106148.......................19, 33, 75, 82

106149.............................19, 33, 75

106150.................................. 33, 75

106151.................................. 75, 82

107141........................................ 76

107142........................................ 76

108190........................................ 42

108202.................................. 73, 74

108203........................................ 74

108204........................................ 73

108458.................................. 11, 19

108491........................................ 74

108537.................................. 16, 19

108867........................................ 74

109054........................................ 30

109064........................................ 57

109075...................... 16, 19, 24, 26,

27, 40, 42, 75, 82

109077........................................ 76

109105.......................17, 35, 42, 78

109108.............................17, 35, 78

109123.................................. 35, 79

Page No.

109124........................................ 79

109125.......................14, 35, 42, 79

109126........................................ 79

109127........................................ 79

109128........................................ 79

109129........................................ 79

109130........................................ 79

109131........................................ 79

109132........................................ 79

109133........................................ 79

109134........................................ 79

109135........................................ 79

109145.................................. 70, 77

109146........................................ 77

109147........................................ 77

109148.............................68, 70, 77

109149........................................ 77

109150.................................. 30, 77

109151.................................. 30, 77

109152........................................ 77

109153........................................ 77

109154........................................ 77

109156........................................ 77

109157........................................ 77

109158........................................ 77

109160........................................ 78

109161........................................ 78

109162........................................ 78

109163.................................. 30, 78

109165.................................. 30, 78

109167........................................ 30

109169........................................ 78

109170........................................ 78

110025........................................ 11

110046........................................ 79

110047........................................ 79

110048.............................20, 21, 79

110065........................................ 76

110069........................................ 78

110127........................................ 18

110146.......................19, 33, 42, 75

110147.......................19, 33, 42, 75

110148.................................. 19, 75

110149.......................19, 74, 75, 76

110150.................................. 19, 76

110196.................................. 33, 76

110197........................................ 76

110198.................................. 30, 76

110199.................................. 33, 76

110200........................................ 76

110201........................................ 69

110202........................................ 69

110203........................................ 69

110216........................................ 69

110218........................................ 69

110223................. 19, 31, 33, 42, 76

110224................. 19, 31, 33, 42, 76

110225................. 16, 19, 31, 33, 76

110226.......................19, 31, 33, 76

110234.................................. 30, 75

110236........................................ 58

110237........................................ 58

110285........................................ 58

110314........................................ 19

110318.................................. 42, 75

110319........................................ 77

110326........................................ 79

110702........................................ 71

110703........................................ 71

110704........................................ 71

110705........................................ 71

110706........................................ 71

110709........................................ 71

110710........................................ 71

Part No. Page No.

110711........................................ 71

110712........................................ 71

110713........................................ 71

110877........................................ 19

110878........................................ 19

110906........................................ 19

110907........................................ 19

111010........................................ 78

111468........................................ 75

111470.............................18, 31, 75

111474........................................ 74

111511........................................ 42

111620.................................... 9, 11

111697........................................ 80

111931........................................ 74

112087........................................ 19

112119........................................ 33

112196........................................ 69

112197........................................ 46

112198........................................ 46

112202........................................ 46

112255........................................ 70

112353........................................ 19

113093........................................ 80

113497.................................. 33, 42

113551.......................................... 9

113553.......................................... 9

113555.......................................... 9

113556.......................................... 9

113557.......................................... 9

113558.......................................... 9

113559.......................................... 9

113560.......................................... 9

113774.......................................... 9

113859........................................ 11

114017........................................ 65

114829........................................ 46

115042.......................20, 21, 32, 42

116229........................................ 74

118464........................................ 76

119278.......................................... 7

119572.......................................... 5

119577........................................ 72

15B750 ......................................... 6

15C502 ................................. 16, 18

15D702 ......................................... 7

15M308 ................................... 6, 65

15M309 ................................... 6, 65

15T366 .................................... 6, 65

15T367 .................................... 6, 65

15T368 .................................... 6, 65

15T369 .................................... 6, 65

15T370 .................................... 6, 65

15T998 .......................................... 5

15T999 .......................................... 5

150171........................................ 80

150286........................................ 80

150287.................................. 55, 80

150622........................................ 70

151519........................................ 80

154616........................................ 73

155332.................................... 6, 65

155470.............................17, 30, 80

155494.......................17, 18, 30, 80

155495........................................ 80

155541.............................30, 35, 80

155570.................................. 41, 80

155653........................................ 80

155665........................................ 80

155677........................................ 80

155699........................................ 80

155836........................................ 70

155865........................................ 80

156022.................................. 42, 80

Part No. Page No.

156172........................................ 80

156173........................................ 80

156296........................................ 80

156580........................................ 80

156589........................................ 80

156684........................................ 80

156789........................................ 73

156823........................................ 80

156849.............................30, 80, 82

156971.................................. 42, 80

157191........................................ 80

157416.................................. 80, 82

157676........................................ 80

157705........................................ 80

157785.................................. 74, 80

158256........................................ 80

158383........................................ 80

158491........................................ 80

158555........................................ 80

158581........................................ 80

158586........................................ 80

158683........................................ 80

158990........................................ 77

159153........................................ 80

159239........................................ 80

159801........................................ 80

159840........................................ 80

159841........................................ 80

159842.................................. 55, 80

159952.................................. 18, 31

160022........................................ 80

160327.............................17, 35, 80

160754.................................. 17, 30

161037........................................ 80

161077........................................ 80

161889........................................ 80

162024........................................ 80

162225.................................. 28, 29

162449........................................ 80

162505........................................ 80

165198........................................ 80

168085........................................ 17

168595........................................ 80

169967........................................ 76

169970.................................. 33, 76

169971.................................. 30, 76

171818........................................ 17

172405........................................ 18

175013........................................ 80

176393........................................ 80

176684........................................ 18

178670........................................ 58

180199........................................ 19

180685.................................. 55, 77

180698........................................ 57

185416.................................. 62, 66

186472........................................ 11

187359........................................ 75

187479........................................ 42

187754........................................ 18

188843........................................ 30

190125........................................ 42

191126........................................ 18

191128........................................ 18

191131........................................ 18

191287........................................ 65

191288........................................ 65

191289........................................ 65

191294........................................ 65

191295........................................ 65

191368.......................................... 9

191393.......................................... 9

191394.......................................... 9

191782.................................. 61, 62

www.graco.com

83

Index

Part No. Page No.

Part No.

191783.................................. 61, 62

191784.................................. 61, 62

192873.......................................... 9

192874.......................................... 9

194048........................................ 80

196471.................................. 58, 65

200020........................................ 70

200021........................................ 70

200325.................................. 69, 70

200326.......... 16, 17, 24, 25, 27, 28,

29, 30, 41, 44

200389.............................68, 69, 70

201701........................................ 61

201881........................................ 70

202577.......................30, 41, 68, 69

202579........................................ 69

202600........................................ 69

202650........................................ 70

202654........................................ 71

202858.................................. 33, 75

202869........................................ 31

202965........................................ 80

203156........................................ 17

203198.................................. 69, 70

203265........................................ 61

203320.............................17, 30, 79

203497........................................ 70

203504........................................ 70

203521........................................ 56

203522........................................ 56

203523........................................ 56

203524........................................ 56

203525........................................ 56

203526........................................ 56

203597........................................ 69

203622........... 16, 18, 24, 27, 31, 45

203650........... 18, 24, 26, 27, 31, 45

203655........................................ 61

203664........................................ 26

203687........................................ 61

203688.......................16, 17, 18, 19

203697.................................. 46, 69

203701........................................ 46

203702........................................ 46

203703........................................ 46

203716........................................ 29

203857.................................. 16, 40

203872.................................. 16, 40

203876.................................. 16, 82

203976.................................. 26, 27

203987.................................. 17, 19

203992........................................ 18

204072........................................ 70

204076.................................. 18, 40

204082........................................ 69

204083........................................ 69

204084........................................ 69

204095........................................ 40

204121........................................ 27

204130........................................ 30

204134.................................. 24, 26

204144.............................18, 31, 41

204204........................................ 70

204254.................................. 16, 40

204264........................................ 40

204351........................................ 26

204353........................................ 27

204385................. 18, 27, 28, 29, 31

204461.............................27, 28, 29

204467........................................ 27

204560.................................. 17, 79

204574...................... 16, 17, 24, 25,

26, 27, 28, 29, 30, 41, 44, 45

204741........................................ 57

Page No.

204897........................................ 70

204929........................................ 70

205054.................................. 18, 31

205090........................................ 76

205102.................................. 28, 29

205148........................................ 28

205337........................................ 30

205339.............................27, 28, 29

205394.................................. 28, 40

205395.............................28, 29, 40

205418.......................17, 30, 42, 79

205532........................................ 70

205554........................................ 70

205568........................................ 70

205582........................................ 70

205592........................................ 70

205600........................................ 78

205626.................................. 15, 16

205699.................................. 28, 29

206199........................................ 33

206264........................................ 76

206405.................................. 25, 41

206496........................................ 41

206502........................................ 41

206655........................................ 40

206656........................................ 40

206699.................................. 25, 41

206700.................................. 25, 41

207279.................................. 28, 29

207361.................................. 40, 44

207366.................................. 40, 44

207367........................................ 40

207468........................................ 29

207561.................................. 18, 31

207562.................................. 18, 31

207579........................................ 17

207651.................................. 28, 33

207738........................................ 64

207739........................................ 64

207742........................................ 64

207755........................................ 75

207946........................................ 69

207947........................................ 69

207948........................................ 69

208009........................................ 73

208390........................................ 76

208393........................................ 76

208434........................................ 80

208536.......................30, 33, 76, 77

208610.............................28, 32, 79

208611........................................ 79

208627........................................ 77

208630........................................ 76

210880........................................ 17

213012........................................ 35

213013........................................ 35

214570........................................ 41

214583.................................. 18, 35

214584........................................ 35

214656........................................ 79

214658........................................ 45

214847.................................. 19, 75

214848.................................. 19, 75

214849........................................ 75

214925........................................ 69

214926........................................ 69

214955........................................ 79

215407.................................... 9, 11

215474.................................... 9, 11

215475........................................ 11

215481........................................ 11

215487...............................9, 10, 11

215964........................................ 35

217072.............................16, 19, 76

Part No. Page No.

217073........................................ 76

217359.................................. 18, 35

217430........................................ 80

218093.................................. 17, 79

218112........................................ 35

218115........................................ 14

218316.............................14, 35, 75

218340........................................ 57

218341........................................ 57

218491........................................ 79

218545.................................. 55, 77

218549.............................55, 57, 82

218550.................................. 55, 57

218588...............................9, 10, 11

218591.................................. 57, 58

218670........................................ 57

218671........................................ 57

218672........................................ 57

218673........................................ 57

218674........................................ 57

218675........................................ 57

218676........................................ 57

218677........................................ 57

218678........................................ 57

218969.................................. 73, 74

218970........................................ 74

220107........................................ 58

220110........................................ 58

220112........................................ 58

220168........................................ 35

220170........................................ 25

220171........................................ 25

220590........................................ 78

220591.................................. 17, 78

220592........................................ 78

220593........................................ 78

220596........................................ 42

220598.............................17, 78, 82

220600........................................ 78

220604........................................ 78

220608........................................ 78

220653.......................24, 26, 29, 30

220654................. 24, 26, 27, 30, 40

220969........................................ 74

221007........................................ 74

221092........................................ 78

221093........................................ 78

221146........................................ 74

222011.............................33, 74, 75

222051........................................ 14

222058.............................17, 25, 41

222059.............................24, 26, 30

222060.............................27, 40, 44

222061.......................18, 27, 40, 44

222062.............................16, 17, 19

222063................. 16, 17, 19, 40, 82

222065.................................. 16, 40

222066.......................16, 17, 19, 40

222067........................................ 40

222068.............................16, 17, 19

222069........................................ 26

222070.............................26, 27, 30

222071........................................ 40

222072.......................24, 27, 30, 40

222073........................................ 27

222074........................................ 27

222075........................................ 40

222076.......................28, 29, 30, 40

222077........................................ 41

222078........................................ 25

222079........................................ 41

222080.................................. 25, 30

222081.................................. 25, 30

222082........................................ 41

Part No. Page No.

222085........................................ 40

222086........................................ 40

222087........................................ 16

222090.................................. 72, 73

222095.................................. 16, 40

222103........................................ 14

222104........................................ 14

222118.................................. 19, 35

222119.................................. 19, 35

222148........................................ 75

222149........................................ 74

222178........................................ 75

222225........................................ 57

222243.............................18, 27, 31

222245........................................ 27

222308........... 14, 16, 17, 18, 19, 82

222383.................................. 27, 30

222404........................................ 28

222417........................................ 57

222602........................................ 14

222629........................................ 58

222641........................................ 58

222645........................................ 58

222902........................................ 44

223107........................................ 40

223108........................................ 28

223179........................................ 11

223187........................................ 70

223344.......................28, 29, 30, 40

223448........................................ 58

223695........................................ 74

223696........................................ 74

223697........................................ 74

223700.................................. 30, 44

223701.................................. 30, 44

223845.......................24, 27, 30, 40

223846.......................28, 29, 30, 40

223888.................................. 42, 74

223920........................................ 62

223952........................................ 32

223965........................................ 74

224023........................................ 41

224040........................................ 77

224266.................................. 28, 29

224267........................................ 29

224444........................................ 57

224512.................................. 16, 75

224534........................................ 82

224541........................................ 82

224569........................................ 69

224579.................................. 18, 40

224665........................................ 75

224666........................................ 75

224667........................................ 75

224669........................................ 75

224700........................................ 75

224701........................................ 75

224702........................................ 75

224741.................................. 43, 44

224742........................................ 43

224751........................................ 44

224752........................................ 44

224759.................................. 74, 75

224762........................................ 74

224763........................................ 75

224825........................................ 41

224826........................................ 41

224835.............................33, 42, 74

224872........................................ 68

224873.............................72, 73, 74

224912........................................ 44

224915........................................ 44

224916........................................ 44

224955........................................ 74

www.graco.com

84

L U B R I C A T I O N E Q U I P M E N T

I N D E X

Index

Part No. Page No.

Part No.

225006........................................ 27

225014........................................ 27

225016........................................ 27

225026........................................ 27

225094........................................ 16

225272........................................ 73

225376........................................ 45

225378........................................ 45

225380........................................ 45

225384........................................ 45

225640........................................ 16

225642........................................ 16

225728........................................ 16

225773........................................ 26

225781........................................ 28

225782........................................ 16

225786........................................ 16

225827........................................ 26

225844........................................ 46

225852........................................ 16

225853........................................ 16

225880........................................ 45

225914........................................ 46

225931........................................ 16

226012........................................ 26

226013........................................ 27

226018........................................ 28

226269........................................ 41

226289........................................ 45

226290........................................ 46

226342........................................ 41

226940........................................ 35

226941........................................ 35

226942........................................ 35

226943........................................ 35

226944........................................ 35

226945........................................ 35

226947.................................. 34, 35

226948.................................. 34, 35

226951.................................. 34, 35

226952........................................ 35

226953........................................ 35

232076........................................ 11

232077........................................ 11

233807.............................26, 27, 68

233933........................................ 68

234237........................................ 41

234423........................................ 58

234902........................................ 36

235346........................................ 73

235532........................................ 11

235878.............................61, 62, 63

235901.............................61, 62, 63

235998...............................9, 19, 44

236054........... 17, 18, 19, 33, 35, 42

236058.................................. 24, 30

236171.................................. 69, 70

236205........................................ 77

236206........................................ 77

236211........................................ 77

236265........................................ 74

236267........................................ 33

236273........................................ 33

236753........................................ 43

236754.................................. 43, 44

236763........................................ 11

236764........................................ 11

236778........................................ 17

236864........................................ 44

236865........................................ 44

237075.................................. 16, 17

237129........................................ 35

237130........................................ 35

237131........................................ 35

Page No.

237132........................................ 35

237133........................................ 35

237134........................................ 35

237160........................................ 42

237526.................................. 15, 16

237601........................................ 19

237653........................................ 43

237728........................................ 53

237861........................................ 78

237865........................................ 78

237866........................................ 78

237873........................................ 57

237874........................................ 57

237879........................................ 53

237884........................................ 53

237893.........................9, 11, 19, 82

237904........................................ 44

237932.................................. 53, 57

237944........................................ 57

238108.................................. 15, 16

238125........................................ 18

238245.............................16, 17, 19

238246.................................. 17, 19

238247........................................ 17

238371........................................ 65

238400........................................ 62

238428.................................. 33, 42

238429........................................ 19

238431........................................ 19

238432........................................ 19

238433........................................ 19

238434........................................ 19

238435........................................ 41

238436........................................ 41

238437........................................ 41

238438........................................ 41

238439........................................ 41

238440........................................ 41

238555........................................ 65

238592........................................ 18

238593........................................ 18

238595........................................ 18

238596........................................ 18

238618.......................................... 9

238624.......................................... 9

238625.......................................... 9

238636........................................ 62

238637........................................ 62

238638........................................ 62

238639........................................ 62

238640........................................ 62

238641........................................ 62

238642........................................ 62

238643........................................ 62

238646........................................ 62

238647........................................ 62

238765........................................ 33

238866.............................72, 73, 74

238899.................................. 19, 33

238996...............................9, 10, 11

239019........................................ 11

239301........................................ 73

239302........................................ 73

239663........................................ 41

239702........................................ 14

239703........................................ 14

239705........................................ 45

239706........................................ 58

239707........................................ 45

239729.................................. 29, 40

239730.................................. 29, 40

239731........................................ 29

239824.................................. 58, 63

239829........................................ 65

Part No. Page No.

239877........................................ 26

239887.................................. 27, 40

239888.............................27, 29, 40

239949........................................ 65

239950........................................ 65

239951........................................ 65

239952........................................ 33

239965........................................ 30

239966.................................. 30, 41

24A217 ....................................... 56

24A218 ................................. 55, 56

24A219 ....................................... 56

24A220 ....................................... 56

24A221 ....................................... 56

24A222 ....................................... 56

24A224 ....................................... 57

24A934 ....................................... 56

24A935 ....................................... 56

24A936 ....................................... 56

24A937 ....................................... 56

24A938 ....................................... 56

24A939 ....................................... 56

24A940 ....................................... 56

24A941 ....................................... 56

24A942 ....................................... 56

24A943 ....................................... 56

24A944 ....................................... 56

24A945 ....................................... 56

24A946 ....................................... 56

24A947 ....................................... 56

24A948 ....................................... 56

24A949 ....................................... 56

24A950 ....................................... 56

24A951 ....................................... 56

24B624 ....................................... 33

24B634 ....................................... 33

24B766 ....................................... 33

24B812 ....................................... 55

24B813 ....................................... 55

24B814 ....................................... 55

24B815 ....................................... 55

24B816 ....................................... 55

24C100 ....................................... 57

24C437 ....................................... 56

24C438 ....................................... 56

24C440 ....................................... 56

24C442 ....................................... 56

24C443 ....................................... 56

24C444 ....................................... 56

24C445 ....................................... 56

24C537 ....................................... 56

24C538 ................................. 55, 56

24C539 ....................................... 56

24C637 ............................33, 42, 74

24C772 ....................................... 56

24C793 ....................................... 56

24D132 ....................................... 57

24D133 ....................................... 57

24D197 ....................................... 55

24D198 ....................................... 55

24D199 ....................................... 55

24D200 ....................................... 55

24D590 ....................................... 20

24D591 ....................................... 20

24D592 ....................................... 21

24D593 ....................................... 21

24D594 ....................................... 20

24D595 ....................................... 21

24D596 ....................................... 20

24D597 ....................................... 20

24D598 ....................................... 21

24D599 ....................................... 21

24D600 ....................................... 20

24D601 ....................................... 21

Part No. Page No.

24D604 ....................................... 21

24D605 ....................................... 21

24D608 ....................................... 21

24D989 ....................................... 55

24D990 ....................................... 55

24D991 ....................................... 55

24D992 ....................................... 55

24D993 ....................................... 55

24D994 ....................................... 55

24D995 ....................................... 55

24D996 ....................................... 55

24D997 ....................................... 55

24D998 ....................................... 55

24D999 ....................................... 55

24E001 ........................................ 55

24E002 ........................................ 55

24E006 ........................................ 32

24E007 ........................................ 32

24E008 ........................................ 32

24E009 ........................................ 32

24E010 ........................................ 32

24E011 ........................................ 32

24E166 ........................................ 74

24E167 ........................................ 74

240416........................................ 65

240417.................................. 11, 19

240418........................................ 19

240429.................................... 9, 19

240448........................................ 11

240453........................................ 65

240684........................................ 74

240685........................................ 74

240832.................................. 73, 74

241246........................................ 30

241633........................................ 82

241657........................................ 33

241663.................................. 18, 31

241906.............................33, 42, 74

241907........................................ 78

241908........................................ 78

241910........................................ 53

242055.................................. 68, 69

242056................. 26, 27, 30, 68, 69

242057.................................. 68, 69

242058.................................. 68, 69

243161........................................ 41

243392........................................ 61

243599........................................ 61

243600........................................ 61

243601........................................ 61

243602........................................ 61

243603........................................ 61

243604........................................ 61

243650........................................ 73

243669.................................. 33, 42

243817........................................ 40

243818........................................ 40

243835........................................ 65

243836........................................ 65

243837........................................ 65

243992........................................ 61

244038........................................ 82

244055........................................ 73

244075........................................ 63

244076........................................ 63

244342........................................ 11

244628........................................ 16

244635........................................ 29

244636........................................ 29

244637........................................ 29

244657........................................ 32

244658........................................ 28

244679........................................ 42

244680........................................ 42

www.graco.com

85

Index

Part No. Page No.

Part No.

244681........................................ 42

244682........................................ 42

244844.......................28, 29, 33, 75

244845........................................ 75

244846........................................ 16

244847........................................ 16

244905.................................. 28, 29

244906........................................ 29

245410........................................ 54

245694........................................ 26

245695........................................ 26

245696........................................ 27

246775.................................. 15, 16

246781........................................ 24

246903........................................ 16

246904........................................ 16

246906........................................ 16

246907........................................ 16

246909........................................ 24

246910........................................ 24

246911........................................ 24

246913........................................ 24

246914........................................ 24

246915........................................ 24

246916........................................ 24

246917........................................ 24

247335........................................ 29

247336........................................ 29

247337........................................ 29

247435.......................................... 7

247436...................................... 4, 7

247443........................................ 44

247450........................................ 44

247453........................................ 63

247540........................................ 44

247712........................................ 66

247713........................................ 66

247714........................................ 66

247715........................................ 66

247716........................................ 66

247717........................................ 66

247718........................................ 67

247721........................................ 67

247722........................................ 67

247723........................................ 67

247724........................................ 67

247725........................................ 67

247759........................................ 65

247760........................................ 65

247890........................................ 21

247891........................................ 21

247894........................................ 21

247895........................................ 21

247969........................................ 20

247973........................................ 32

247974........................................ 32

247975........................................ 32

247976........................................ 32

247977........................................ 32

247978........................................ 32

247979........................................ 32

247980........................................ 32

247981........................................ 32

248097.................................. 16, 82

248230.................................. 15, 16

248296........................................ 19

248312........................................ 79

248313........................................ 79

248324........................................ 19

248417.......................................... 7

248418.......................................... 7

248419.......................................... 7

248421.......................................... 7

248622........................................ 82

Page No.

248623........................................ 82

248632.................................. 72, 73

248918........................................ 36

249058........................................ 78

249181........................................ 79

249294........................................ 36

249440.................................... 6, 58

249771........................................ 36

249783........................................ 36

249821........................................ 36

253486........................................ 36

253487........................................ 36

253494........................................ 36

253601........................................ 64

253683........................................ 36

255143........................................ 21

255200...........................4, 6, 60, 82

255231...................................... 4, 5

255277........................................ 59

255348.................................. 55, 60

255349.................................. 17, 60

255350.............................55, 60, 82

255351........................................ 60

255352........................................ 60

255353........................................ 60

255354........................................ 60

255355........................................ 60

255356........................................ 60

255370.......................................... 6

255459.............................64, 65, 66

255460.............................64, 65, 66

255461.................................. 65, 66

255470.............................64, 65, 66

255731.......................................... 5

255751.................................. 59, 65

255793........................................ 67

255800........................................ 60

255801........................................ 60

255802........................................ 60

255803........................................ 60

255852........................................ 65

255853........................................ 65

255854........................................ 65

255855........................................ 65

255856........................................ 65

255857.................................. 65, 66

255858.................................. 65, 66

255859........................................ 67

255861........................................ 65

255885.................................... 6, 65

255921........................................ 67

256164........................................ 66

256215.......................55, 59, 65, 82

256216.................................. 55, 59

256282.......................................... 6

256285...................................... 4, 7

256482.......................................... 6

256483.......................................... 6

256484.......................................... 6

256485.......................................... 6

256486.......................................... 6

256487.......................................... 6

256488.......................................... 6

256556........................................ 64

256634...................................... 4, 5

256635.......................................... 5

256636.......................................... 5

256637.......................................... 5

256638.......................................... 5

256719.......................................... 6

256786........................................ 64

256787........................................ 64

256788........................................ 64

256789........................................ 64

Part No. Page No.

256836........................................ 60

256837........................................ 60

256838........................................ 60

256839........................................ 60

257120.......................................... 6

257539.......................................... 6

257556.......................................... 6

258693.................................. 55, 59

258694.................................. 55, 59

260000........................................ 39

260020........................................ 39

260022........................................ 39

260025........................................ 39

260078........................................ 39

260079........................................ 39

260082........................................ 39

260083........................................ 39

260100.................................. 37, 38

260101.................................. 37, 38

260102.................................. 37, 38

260104.................................. 37, 38

260105.................................. 37, 38

260106.................................. 37, 38

260108.................................. 37, 38

260109.................................. 37, 38

260110........................................ 38

260111........................................ 38

260112........................................ 38

260113........................................ 38

260114........................................ 38

260124........................................ 38

260145........................................ 38

260238........................................ 38

260306.................................. 37, 38

260415........................................ 38

260521........................................ 39

260523........................................ 39

263265........................................ 33

286211........................................ 41

286517........................................ 41

286621........................................ 41

3A0138 ................................. 51, 52

306271........................................ 69

306436........................................ 45

306449........................................ 73

306455........................................ 46

306460........................................ 69

306520.................................. 16, 17

306523........................................ 27

306531.................................. 22, 41

306556.............................27, 28, 29

306674........................................ 22

306875........................................ 45

306876........................................ 46

306982........................................ 22

307427........................................ 34

307637........................................ 14

307696........................................ 11

307727.................................. 73, 74

307742........................................ 58

307878.................................. 26, 30

307879........................................ 41

307880................. 27, 28, 29, 30, 40

307882........................................ 25

307883.............................16, 17, 40

307884.................................. 16, 17

307906.................................. 12, 14

307965........................................ 63

308035........................................ 74

308069........................................ 41

308149........................................ 44

308154........................................ 75

308155........................................ 43

308156........................................ 44

Part No. Page No.

308163........................................ 75

308238........................................ 10

308306.................................. 46, 70

308326........................................ 33

308335........................................ 17

308368........................................ 33

308390........................................ 43

308391........................................ 43

308395........................................ 44

308403.............................10, 11, 18

308441........................................ 33

308479........................................ 33

308546........................................ 53

308553........................................ 33

308573........................................ 33

308607.......................................... 8

308639........................................ 33

308642.............................61, 62, 67

308667........................................ 72

308687........................................ 63

308719.................................. 73, 74

308777........................................ 22

308883........................................ 22

308896........................................ 46

308981........................................ 33

309194........................................ 73

309276........................................ 11

309345.................................. 28, 29

309351........................................ 16

309353........................................ 42

309407........................................ 22

309442........................................ 54

309868........................................ 16

309869........................................ 12

309966........................................ 22

309967........................................ 24

311211........................................ 20

311216........................................ 36

311238.............................20, 21, 32

311304........................................ 39

311305........................................ 38

311306........................................ 38

311307........................................ 38

311690........................................ 20

311717........................................ 21

311825........................................ 21

311826........................................ 21

311831........................................ 20

311832........................................ 20

311833........................................ 21

312350........................................ 44

312371........................................ 32

312373........................................ 32

312375........................................ 32

312376........................................ 32

312417.......................................... 7

312668........................................ 59

312789........................................ 66

312862.................................. 20, 21

312863........................................ 32

312865........................................ 60

312877........................................ 33

312964.......................................... 7

313008.......................................... 5

313013.......................................... 6

313046.......................................... 6

313048........................................ 63

313104.......................................... 5

313106.......................................... 5

313108.......................................... 5

313112.......................................... 5

313114.......................................... 5

313431.............................49, 50, 52

313938........................................ 48

www.graco.com

86

L U B R I C A T I O N E Q U I P M E N T

I N D E X

Index

Part No.

512874........................................ 30

512926.......................................... 9

512927.......................................... 9

514037.......................................... 9

514150.................................... 9, 11

601950........................................ 77

647016.............................33, 42, 74

685984.................................. 33, 42

948392........................................ 30

948393........................................ 30

965124........................................ 28

965129........................................ 29

D0B005 ....................................... 33

D0B525 ....................................... 33

D0F005........................................ 33

D0F525........................................ 33

D0K005 ....................................... 33

D0K525 ....................................... 33

D03005 ....................................... 33

D03255 ....................................... 33

D05007 ....................................... 33

D05277 ....................................... 33

D31255 ................................. 33, 42

DB5525 ....................................... 33

DF3525........................................ 33

DK3525 ....................................... 33

HEH13D ....................................... 56

HEH33D ....................................... 48

HEL13D.................................. 48, 56

HEL15D.................................. 48, 56

HEL23D.................................. 48, 56

HEL25D.................................. 48, 56

HEL33D........................................ 48

HEM23D ................................ 48, 56

HEM33D ...........................48, 55, 56

HPH1DA ....................................... 50

HPH1DB ....................................... 50

HPH1DC ....................................... 50

HPH1DD ....................................... 50

HPH1DE ....................................... 50

HPH1DF ....................................... 50

HPH5DA ....................................... 50

HPH5DB ....................................... 50

HPH5DC ....................................... 50

HPH5DD ....................................... 50

HPH5DE ....................................... 50

HPH5DF ....................................... 50

HPH15A ....................................... 50

HPH15B ....................................... 50

HPH15C ....................................... 50

HPH15D ....................................... 50

HPH15E ....................................... 50

HPH23A ....................................... 50

HPH23B ....................................... 50

HPH23C ....................................... 50

HPH23D ....................................... 50

HPH23E ....................................... 50

HPH23F ....................................... 50

HPH55A ....................................... 50

HPH55B ....................................... 50

HPH55C ....................................... 50

HPH55D ....................................... 50

HPH55E ....................................... 50

HPH55F ....................................... 50

HPL23A........................................ 50

HPL23B........................................ 50

HPL23C ....................................... 50

HPL23D ....................................... 50

HPL23E ........................................ 50

HPL23F ........................................ 50

HPL25A........................................ 50

HPL25B........................................ 50

HPL25C ....................................... 50

HPL25D ....................................... 50

HPL25E ........................................ 50

Page No.

Part No.

HPL25F ........................................ 50

HPL33A........................................ 50

HPL33B........................................ 50

HPL33C ....................................... 50

HPL33D ....................................... 50

HPL33E ........................................ 50

HPL33F ........................................ 50

HPL56A........................................ 50

HPL56B........................................ 50

HPL56C ....................................... 50

HPL56D ....................................... 50

HPL56E ........................................ 50

HPL56F ........................................ 50

HPL65A........................................ 50

HPL65B........................................ 50

HPL65C ....................................... 50

HPL65D ....................................... 50

HPL65E ........................................ 50

HPL65F ........................................ 50

HPM3BA ...................................... 50

HPM3BB ...................................... 50

HPM3BC ...................................... 50

HPM3BD ...................................... 50

HPM3BE ....................................... 50

HPM3BF ....................................... 50

HPM6DA ...................................... 50

HPM6DB ...................................... 50

HPM6DC ...................................... 50

HPM6DD ...................................... 50

HPM6DE ...................................... 50

HPM6DF....................................... 50

HPM33A ...................................... 50

HPM33B ...........................50, 55, 82

HPM33C ...................................... 50

HPM33F ....................................... 50

HPM65A ...................................... 50

HPM65B ................................ 50, 82

HPM65C ...................................... 50

HPM65D ...................................... 50

HPM65E ....................................... 50

HPM65F ....................................... 50

HRH55A ....................................... 49

HRH55B ................................. 49, 55

HRH55C ....................................... 49

HRH55D ....................................... 49

HRH55E ....................................... 49

HRH55F ....................................... 49

HRL56A ....................................... 49

HRL56B ................................. 49, 55

HRL56C ....................................... 49

HRL56D ....................................... 49

HRL56E ........................................ 49

HRL56F ........................................ 49

HRL65A ....................................... 49

HRL65B ....................................... 49

HRL65C ....................................... 49

HRL65D ....................................... 49

HRL65E ........................................ 49

HRL65F ........................................ 49

HRM33D ...................................... 50

HRM33E ....................................... 50

HRM65A ...................................... 49

HRM65B ................................ 49, 55

HRM65C ...................................... 49

HRM65D ...................................... 49

HRM65E ....................................... 49

HRM65F ....................................... 49

HSH1DA ....................................... 52

HSH1DB ....................................... 52

HSH1DF ....................................... 52

HSH1DG ....................................... 52

HSH5DA ....................................... 52

HSH5DB ....................................... 52

HSH5DF ....................................... 52

HSH5DG ....................................... 52

Page No.

Part No. Page No. Part No.

HSH15A ....................................... 52

HSH15B ....................................... 52

HSH15F ....................................... 52

HSH15G ....................................... 52

HSH55A ....................................... 52

HSH55B ....................................... 52

HSH55F ....................................... 52

HSH55G ....................................... 52

HSHC5A ....................................... 52

HSHC5B ....................................... 52

HSHC5F ....................................... 52

HSHC5G ....................................... 52

HSHCDA ....................................... 52

HSHCDB ....................................... 52

HSHCDF ....................................... 52

HSHCDG ....................................... 52

HSHFFA ........................................ 52

HSHFFB ........................................ 52

HSHFFF ........................................ 52

HSHFFG ....................................... 52

HSL25A........................................ 52

HSL25B........................................ 52

HSL25F ........................................ 52

HSL25G ....................................... 52

HSL33A........................................ 52

HSL33B........................................ 52

HSL33F ........................................ 52

HSL33G ....................................... 52

HSL56A........................................ 52

HSL56B........................................ 52

HSL56F ........................................ 52

HSL56G ....................................... 52

HSL65A........................................ 52

HSL65B........................................ 52

HSL65F ........................................ 52

HSL65G ....................................... 52

HSLC8A ....................................... 52

HSLC8B ....................................... 52

HSLC8F ........................................ 52

HSLC8G ....................................... 52

HSLD5A ....................................... 52

HSLD5B ....................................... 52

HSLD5F ........................................ 52

HSLD5G ....................................... 52

HSLE3A ........................................ 52

HSLE3B ........................................ 52

HSLE3F ........................................ 52

HSLE3G........................................ 52

HSM3BA ...................................... 52

HSM3BB ...................................... 52

HSM3BF ....................................... 52

HSM3BG ...................................... 52

HSM6DA ...................................... 52

HSM6DB ...................................... 52

HSM6DF....................................... 52

HSM6DG ...................................... 52

HSM33A ...................................... 52

HSM33B ...................................... 52

HSM33F ....................................... 52

HSM33G ...................................... 52

HSM65A ...................................... 52

HSM65B ...................................... 52

HSM65F ....................................... 52

HSM65G ...................................... 52

HSMC8A ...................................... 52

HSMC8B ...................................... 52

HSMC8F ....................................... 52

HSMC8G ...................................... 52

HSMCFA ....................................... 52

HSMCFB....................................... 52

HSMCFF ....................................... 52

HSMCFG ...................................... 52

HSMD5A ...................................... 52

HSMD5B ...................................... 52

HSMD5F....................................... 52

Page No.

HSMD5G ...................................... 52

HSMDDA ...................................... 52

HSMDDB ...................................... 52

HSMDDF ...................................... 52

HSMDDG ...................................... 52

HSPB8A ....................................... 52

HSPB8B ....................................... 52

HSPB8F........................................ 52

HSPB8G ....................................... 52

www.graco.com

87

ABOUT GRACO

GRACO LOCATIONS

Founded in 1926, Graco is a world leader in fluid handling systems and components. Graco products move, measure, control, dispense and apply a wide range of fluids and viscous materials used in vehicle lubrication, commercial and industrial settings.

The company’s success is based on its unwavering commitment to technical excellence, world-class manufacturing and unparalleled customer service. Working closely with qualified distributors, Graco offers systems, products and technology that set the quality standard in a wide range of fluid handling solutions. Graco provides equipment for spray finishing, protective coating, paint circulation, lubrication, and dispensing sealants and adhesives, along with power application equipment for the contractor industry. Graco’s ongoing investment in fluid management and control will continue to provide innovative solutions to a diverse global market.

MAILING ADDRESS

P.O. Box 1441

Minneapolis, MN 55440-1441

Tel: 612-623-6000

Fax: 612-623-6777

AMERICAS

MINNESOTA

Worldwide Headquarters

Graco Inc.

88 -11th Avenue N.E.

Minneapolis, MN 55413

EUROPE

BELGIUM

European Headquarters

Graco N.V.

Industrieterrein-Oude Bunders

Slakweidestraat 31

3630 Maasmechelen,

Belgium

Tel: 32 89 770 700

Fax: 32 89 770 777

ASIA PACIFIC

AUSTRALIA

Graco Australia Pty Ltd.

Suite 17, 2 Enterprise Drive

Bundoora, Victoria 3083

Australia

Tel: 61 3 9467 8558

Fax: 61 3 9467 8559

CHINA

Graco Hong Kong Ltd.

Shanghai Representative Offi ce

Room 118 1st Floor

No.2 Xin Yuan Building

No.509 Cao Bao Road

Shanghai, 200233

The People’s Republic of China

Tel: 86 21 649 50088

Fax: 86 21 649 50077

INDIA

Graco Hong Kong Ltd.

India Liaison Offi ce

Room 432, Augusta Point

Regus Business Centre 53

Golf Course Road

Gurgaon, Haryana

India 122001

Tel: 91 124 435 4208

Fax: 91 124 435 4001

JAPAN

Graco K.K.

1-27-12 Hayabuchi

Tsuzuki-ku

Yokohama City, Japan 2240025

Tel: 81 45 593 7300

Fax: 81 45 593 7301

KOREA

Graco Korea Inc.

Shinhan Bank Building

4th Floor #1599

Gwanyang-Dong, Dongan-Ku,

Anyang-si, Korea 431-060

Tel: 82 31 476 9400

Fax: 82 31 476 9801

SALES/

DISTRIBUTION/

SERVICE

Call today for product information or to speak with a Graco representative.

800-533-9655

or visit us at www.graco.com.

Graco Inc. is registered to I.S. EN ISO 9001

North America

Customer Service

800-533-9655

Fax 800-533-9656

©2009, 2010 Graco Inc. 303245 Rev. I 3/10 All written and visual data contained in this document are based on the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. All other brand names or marks are used for identification purposes and are trademarks of their respective owners.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
