MX Sheet Version 1 Operating Manual

MX Sheet Version 1 Operating Manual

• SAFETY PRECAUTIONS •

(Always read these instructions before using this equipment.)

Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full attention to safety to handle the product correctly.

The instructions given in this manual are concerned with this product. For the safety instructions of the programmable controller system, please read the CPU module user's manual.

In this manual, the safety instructions are ranked as " !

WARNING " and " !

CAUTION".

!

!

WARNING

CAUTION

Indicates that incorrect handling may cause hazardous conditions, resulting in death or severe injury.

Indicates that incorrect handling may cause hazardous conditions, resulting in minor or moderate injury or property damage.

Note that the

!

CAUTION level may lead to serious consequences according to the circumstances.

Always follow the instructions of both levels because they are important to personal safety.

Please keep this manual in a convenient place so that you can refer to it and always forward it to the end user.

[Design Instructions]

!

WARNING

• Build an interlock circuit outside the PLC system to ensure that the whole system always works safely when changing the data of the running PLC or controlling the PLC status from the personal computer.

In addition, be sure to incorporate the corrective action into the system to deal with the communication error due to the poor cable connection while operating the PLC CPU online from the peripheral device.

[Operating Precautions]

!

CAUTION

• Read the manual carefully and confirm the safety before connecting a personal computer to the running CPU module to perform the online operation (especially forced output and operating status change).

Incorrect operation may cause the machine damage and accidents.

A - 1 A - 1

• CONDITIONS OF USE FOR THE PRODUCT •

(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; and ii) where the backup and fail-safe function are systematically or automatically provided outside of the

PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.

(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.

MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED

TO ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT,

PRODUCT LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO

PROPERTY CAUSED BY the PRODUCT THAT ARE OPERATED OR USED IN APPLICATION NOT

INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN

MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND

GUIDELINES FOR the PRODUCT.

("Prohibited Application")

Prohibited Applications include, but not limited to, the use of the PRODUCT in; y Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the public could be affected if any problem or fault occurs in the PRODUCT. y Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality assurance system is required by the Purchaser or End User. y Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator, Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for

Recreation and Amusement, and Safety devices, handling of Nuclear or Hazardous Materials or

Chemicals, Mining and Drilling, and/or other applications where there is a significant risk of injury to the public or property.

Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the

PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required. For details, please contact the Mitsubishi representative in your region.

A - 2 A - 2

REVISIONS

Print Date * Manual Number

* The manual number is given on the bottom left of the back cover.

Revision

Aug., 2002 SH (NA)-080348E-A First edition

Dec., 2003 SH (NA)-080348E-B Correction

Section 6.2.1, Section 6.3.1, Section 6.4.1, Section 6.5.1, Section 17.4,

Appendix 2

Aug., 2004 SH (NA)-080348E-C New Addition

Chapter 14, Chapter 15, Chapter 16

Correction

Operating Precautions, How to Use This Manual, Section 1.1,

Section 2.1, Section 3.1, Chapter 4, Chapter 5, Section 6.1, Section 6.2,

Section 6.3, Section 6.4, Section 6.5, Section 6.6, Chapter 7, Chapter 8,

Section 10.1, Section 10.2, Chapter 11, Section 12.1, Section 12.3,

Chapter 14 to 17 changed to Chapter 17 to 20, Appendix 2, Appendix 3,

Appendix 5

Sep., 2005 SH (NA)-080348E-D New Addition

Appendix 8

Correction

Precautions on setting MX Sheet, Section 2.1, Section 3.1, Section 3.2,

Section 6.2, Section 6.2.2, Section 6.2.3, Section 6.3, Section 6.3.3,

Section 6.4, Section 6.4.3, Section 6.5, Section 6.5.4, Section 6.6,

Section 6.6.2, Section 6.6.4, Appendix 2

Nov., 2006 SH (NA)-080348E-E Correction

Section 7.2

Oct., 2007 SH (NA)-080348E-F Correction

Operating Precautions, Generic Terms and Abbreviations, Section 2.1,

Section 3.1, Chapter 5, Section 6.2.1, Section 7.2, Section 10.1,

Section 10.2, Section 14.1, Section 20.1, Appendix 2, Appendix 8

May, 2008 SH (NA)-080348E-G Correction

Section 6.2.1, Section 6.3.1, Section 6.4.1, Section 6.5.1, Section 6.6.1,

Section 6.6.3

Jun., 2009 SH (NA)-080348E-H Correction

Operating Precautions, Manuals, Packing List, Section 6.2.1,

Section 7.2, Appendix 7, Appendix 8.1

A - 3 A - 3

Print Date * Manual Number

Dec., 2009 SH (NA)-080348E-I

Addition

Revision

CONDITIONS OF USE FOR THE PRODUCT

Correction

SAFETY PRECAUTIONS, Section 3.2, Chapter 9

May, 2010 SH (NA)-080348E-J Addition

Operating Precautions, Generic Terms and Abbreviations, Section 2.1,

Section 7.2, Chapter 4, Section 6.2.2, Section 20.1, Appendix 1,

Appendix 8, Appendix 9

Correction

Section 6.2.5, Section 6.4.2

May, 2011 SH (NA)-080348E-K New Addition

Appendix 9

Addition

Operating Precautions, Generic Terms and Abbreviations, Section 2.1,

Chapter 5, Section 6.2.1, Section 6.2.6, Section 7.2, Chapter 9,

Section 10.1, Section 10.2, Section 14.1, Appendix 3, Appendix 9

Correction

Appendix 9 changed to Appendix 10

Japanese Manual Version SH-080346-K

This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

© 2002 MITSUBISHI ELECTRIC CORPORATION

A - 4 A - 4

Operating Precautions

This section provides precautions in the following order.

1) Precautions on OS and personal computer

2) Precautions on setting MX Sheet

3) Precautions on editing cells and Excel sheets

4) Precautions on communication

5) Precautions on use of VBA

6) Precautions on use of other MELSOFT products

Precautions on OS and personal computer

(1) When using of Microsoft

R

Windows NT

R

Workstation Operating

System Version 4.0, Microsoft

R

Windows

R

2000 Professional

Operating System, Microsoft

R

Windows

R

XP Professional Operating

System, Microsoft

R

Windows

R

XP Home Edition, Windows Vista

R

, and Windows

R

7

To make/change Communication Settings, a user who has an administrator authority must log on.

The administrator authority is also required to execute the data conversion function (refer to Chapter 20).

If the user account that does not have the administrator authority is used to execute the data conversion function, MX Links/MX Chart data cannot be converted.

(2) Coexistence of different Excel versions

When different versions of Excel exist in a single personal computer, MX Sheet will not operate normally. For example, Excel 2000 and Excel 2002 cannot coexist.

(3) Resume function, etc. of personal computer

If any of the following has been set to the personal computer where MX Sheet is installed, a communication error will occur during communication with the PLC.

Do not set the following functions on the personal computer.

• Resume function

• Suspend function

• Power saving function

• Standby mode

A - 5 A - 5

Precautions on setting MX Sheet

(1) Word designation for bit and bit designation for word

In the following tabs and dialog boxes, word designation for bit (e.g. K4M0) and bit designation for word (e.g. D0.0) cannot be set.

1) <<Access Data>> tab *

1

2) <<Device Trigger>> Tab

3) <<Handshake>> tab

4) "Automatic Save" dialog box

5) "Automatic Print" dialog box

*1: When using MX Sheet Version 1.06 G or later, the device can be set by means of bit designated for word device (e.g. D0.0).

(2) Reading character strings

When character strings are read from the PLC, the device data which prefix is either of the following characters are not displayed normally on an Excel sheet.

When reading character strings from the PLC, make proper setting so that either of the following characters will not be prefixed.

1) = (equal)

2) ' (single quotation)

(3) Save of Excel sheets

If the file name specified in the "Automatic Save" dialog box or "Operating when cell is full" of the <<Use>> tab already exists, the old data is discarded and overwritten.

Make proper setting so that the file name specified in the "Automatic Save" dialog box or "Operating when cell is full" of the <<Use>> tab does not overlap those of the other Excel books.

designation

(a) Color designation

When using Excel 2003 or earlier and specifying any of the following colors for "Set the Color of Grid line" or "Set the Color for Filling" on the <<Use>> tab, the actual display color differs from the specified color.

(b) Color designation from Excel

If the line color and cell filling color have been specified from "Format Cells", of Excel, the colors specified in "Set the Color of Grind line" and "Set the

Color for Filling" of the <<Use>> tab are made invalid.

A - 6 A - 6

(c) Compatibility check

In Excel 2007 or later, when setting colors to a Book in Excel from 97 to 2003 version with Cell Settings of MX Sheet, if specifying the color of on the following screen, the Compatibility Checker screen appears on the Excel at saving the Book.

< Compatibility Checker screen >

(5) Operation guarantee according to version

Due to the upgrade, the functions of the MX Sheet have been added/extended.

Operate the Excel book where MX Sheet functions are set with the MX Sheet whose version is the same or later than the set MX Sheet for operation guarantee.

For description of the added/extended functions, refer to APPENDIX 8.

(6) Excel sheet where buttons are placed

When the Start Communication, End Communication or 1 Shot Communication button placed on the Excel sheet is focused, do not log off from Windows or exit from Windows without closing the Excel book.

To do so will display the following message and disable exit from Excel.

(7) Size of saved Excel file according to Format Cells

On Excel, Format Cells increases the saved file size.

Also on MX Sheet, the size of the saved Excel file may become several M bytes or more since Format Cells is changed according to the setting.

(Example)

• When "Set the Color of Grid line" or "Set the Color of Filling" is checked on the <<Use>> Tab

• When Logging is selected and "Add date and time details" is checked on the <<Use>> Tab

• When Alarm Summary is selected on the <<Use>> Tab

• When "Character string" is specified as the Data Type on the <<Access

Data>> Tab

• When "HEX" is specified as the Value on the <<Access Data>> Tab

A - 7 A - 7

Precautions on editing cells and Excel sheets

If either of the following settings has been made to the Excel book where the

ActiveX controls and forms have been applied, continuous operation of the personal computer will cause insufficient memory.

If insufficient memory has occurred, shut down the personal computer periodically.

• Save function of MX Sheet (automatic save function or save is performed when cell is full)

• Save function is called in a VBA program.

Excel 2007 or later may require much time to save a Book than Excel 2003 or earlier.

For expected time, refer to APPENDIX 3 (4).

(2) Changing of Excel sheet name

When changing the sheet name of the Excel sheet where MX Sheet has been set, change it from [MX Sheet] [Change Sheet Name].

(It can also be changed from the toolbar (icons) or a right-click of the mouse.)

If the sheet name is changed directly from Excel or from a VBA program, MX

Sheet will not operate normally.

If this happens due to sheet name change, set the previous sheet name again.

sheet

(a) Setting of sheet protection (workbook protection)

Do not set "Protect Sheet" and "Protect Workbook" to the ErrorLog sheet.

If such setting is made, the ErrorLog sheet will not operate normally.

(b) Sheet name

In the Excel book where MX Sheet has been set, do not give the name

"ErrorLog" to newly created worksheet, chart or dialog sheet.

If this happens, the ErrorLog sheet created by MX Sheet will not operate normally.

(4) Application error occurring during use of Excel 2000

If an application error occurs at an exit from Excel 2000, check the symptoms and corrective measures at the following URL site (as of July, 2002 *1). http://www. microsoft. com/JAPAN/support/kb/articles/jp319/8/02.asp

Document number: JP319802

Title: [XL2000] Opening the file that has been sent using Outlook Express results in a forced end at an exit from Excel

*1: The URL is valid as of July, 2002.

If the URL has been changed, confirm the above document number and title and contact Microsoft Corporation.

A - 8 A - 8

Precautions on communication

(1) Communication between personal computer and PLC

When PLC device data are collected/written using MX Sheet, the communication restrictions that apply to MX Component also occur between the personal computer and PLC.

For the restrictions on communications between the personal computer and PLC, refer to the MX Component Operating Manual.

(2) Preview setting of Excel

When starting the communication of MX Sheet, do not activate the preview setting (print preview, etc.) of Excel.

If the communication of MX Sheet is started with the preview setting of Excel active, a memory leak will occur.

(3) Simultaneous communication from multiple Excel books

Multiple Excel books where MX Sheet setting has been made cannot be started on a single personal computer to make communication simultaneously.

(4) When communicating Excel book is double-started

Do not make a double start (restart) of the Excel book that is communicating using MX Sheet.

If such operation is performed, the following dialog box appears.

Click No to interrupt a double start (restart).

(5) When logoff/shutdown is executed during communication

Do not log off or shut down the personal computer during usual communication or 1 shot communication.

Log off or shut down the personal computer after terminating the communication with the PLC and exiting from Excel.

If logoff or shutdown of the personal computer is executed during communication, the following symptoms will be observed.

In this case, take corrective actions to restore the system.

(a) Symptom

When MX Sheet setting is made, only the frame of Excel is displayed.

(b) Corrective action

In the following procedure, remove the hide attributes of the Excel book and overwrite the Excel book to restore the system.

1) Choose [Window] [Unhide] in the Excel menu.

A - 9 A - 9

2) Choose the hidden Excel book and click OK .

Office button

3) As the Excel book appears, save the Excel book.

communication

If the USB cable is connected/disconnected, the PLC CPU is reset or PLC is powered on/off frequently during communication with the PLC CPU, a communication error occurs and communication cannot be returned to normal.

If this happens, disconnect the USB cable completely, leave it for 5 seconds or more and reconnect it. (An error may occur at the time of initial communication after the above operation, however, communication will be made normally at and after the second time.)

(7) Excel operation during communication

(a) If Excel is in either of the following status, MX Sheet cannot execute operations on Excel (e.g. display into cells, or save or print of an Excel book).

• A cell is in input status (e.g. a cell is double-clicked, or the cursor is at the formula bar).

• A message box or a dialog box is displayed on Excel.

Minimize the number of input processes on Excel during communications.

(b) The operation of Excel during communication is restricted as follows:

• Excel 2000/2002/2003 hides the menu bar and toolbar.

• Excel 2007 hides tabs on the ribbon.

Although the office button and the quick access toolbar are displayed, do not operate them during communications.

Quick access toolbar

• Excel 2010 hides tabs on the ribbon. Although the <<File>> tab and the quick access toolbar are displayed, do not operate them during communications.

Quick access toolbar

<<File>> tab

A - 10 A - 10

(8) Mouse cursor during communication

While MX Sheet is communicating, the mouse cursor setting of an Excel sheet is fixed to the one of "Normal Select" in "Mouse Properties".

(9) Change to Design Mode of Excel during communication

For Excel during communication, do not change to the Design Mode using the toolbar or similar means. To do so may disable normal operation of MX Sheet.

(10) Continuous operation when saving data automatically in HTML format

Do not operate MX Sheet continuously when the Automatic save function is set to save data in HTML format.

For operating MX Sheet continuously, exit and reactivate Excel periodically.

If data are saved repeatedly in HTML format with the Automatic save function,

Excel may not operate properly.

The time for allowable continuous operation differs according to the operating

Precautions on use of VBA environment.

(1) Incorporation of VBA program

When incorporating a user-created VBA program into the Excel sheet where MX

Sheet has been set, check the operation of the VBA program first and then perform MX Sheet programming for the Excel sheet.

(2) VBA program creation

MX Sheet utilizes OLE Automation for communication.

Do not perform the following on VBA programs.

1) Do not execute the DoEvents method in a For-Next loop.

2) FileFilter is ignored in the GetSaveAsFileName method.

3) Do not execute the Reset method in the Excel menu.

A - 11 A - 11

Precautions on use of other MELSOFT products

(1) MX Component version

MX Component Version 3.01B or later is required to use MX Sheet.

If MX Component Version 3.00A or earlier is used, MX Sheet does not operate normally.

(2) Logical station number

Before deleting the logical station number from the Communication Setup Utility of MX Component, check that the logical station number to be deleted is not used in MX Sheet.

If the logical station number used in MX Sheet is deleted, MX Sheet does not operate normally.

(3) Coexistence with MX Chart

MX Sheet and MX Chart cannot be installed in a single personal computer to make communication simultaneously.

When communication via modem is to be made by MX Sheet, MX Sheet, GX

Developer and other applications (e.g. user applications utilizing MX Component) cannot perform communication simultaneously.

If simultaneous communication is attempted using MX Sheet, GX Developer and other applications, a fault such as a communication error, telephone line disconnection will occur.

When making communication via modem using MX Sheet, check that GX

Developer and other applications do not use modems.

A - 12 A - 12

INTRODUCTION

Thank you for choosing the Mitsubishi Integrated FA Software MELSOFT series.

Read this manual and make sure you understand the functions and performance of MELSOFT series thoroughly in advance to ensure correct use.

CONTENTS

SAFETY PRECAUTIONS............................................................................................................................... A- 1

CONDITIONS OF USE FOR THE PRODUCT .............................................................................................. A- 2

REVISIONS ......................................................................................................................................................A- 3

Operating Precautions .....................................................................................................................................A- 5

CONTENTS......................................................................................................................................................A-13

Manuals ............................................................................................................................................................A-17

Generic Terms and Abbreviations ...................................................................................................................A-18

How to Use This Manual..................................................................................................................................A-19

Definitions of Terms ........................................................................................................................................A-20

Packing List ......................................................................................................................................................A-21

1 OVERVIEW 1- 1 to 1- 4

1.1 Features ..................................................................................................................................................... 1- 2

2 SYSTEM CONFIGURATION 2- 1 to 2- 2

2.1 Operating Environment.............................................................................................................................. 2- 1

3 FUNCTION LIST OF MX Sheet 3- 1 to 3- 2

3.1 Function List of MX Sheet.......................................................................................................................... 3- 1

3.2 Accessible CPUs and Accessible Device Ranges ................................................................................... 3- 2

4 MX Sheet OPERATION PROCEDURE

5 MX Sheet MENU SELECTION METHOD

6 CELL SETTING

4- 1 to 4- 2

5- 1 to 5- 2

6- 1 to 6-75

6.1 Operation of Cell Setting Dialog Box......................................................................................................... 6- 1

6.2 When Logging Is Selected......................................................................................................................... 6- 2

6.2.1 Setting of the Use tab.......................................................................................................................... 6- 3

6.2.2 Setting of the Access Data tab ...........................................................................................................6-11

6.2.3 Setting of the Operation Interval tab...................................................................................................6-16

6.2.4 Setting of the Device Trigger tab ........................................................................................................6-22

6.2.5 Setting of the Handshake tab .............................................................................................................6-25

6.2.6 Setting of the CSV Logging tab ..........................................................................................................6-35

A - 13 A - 13

6.3 When Monitor Is Selected..........................................................................................................................6-38

6.3.1 Setting of the Use tab..........................................................................................................................6-39

6.3.2 Setting of the Access Data tab ...........................................................................................................6-42

6.3.3 Setting of the Operation Interval tab...................................................................................................6-43

6.3.4 Setting of the Device Trigger tab ........................................................................................................6-44

6.3.5 Setting of the Handshake tab .............................................................................................................6-45

6.3.6 Setting of the CSV Logging tab ..........................................................................................................6-46

6.4 When Write Is Selected .............................................................................................................................6-47

6.4.1 Setting of the Use tab..........................................................................................................................6-48

6.4.2 Setting of the Access Data tab ...........................................................................................................6-50

6.4.3 Setting of the Operation Interval tab...................................................................................................6-52

6.4.4 Setting of the Device Trigger tab ........................................................................................................6-53

6.4.5 Setting of the Handshake tab .............................................................................................................6-54

6.5 When Alarm Summary Is Selected ...........................................................................................................6-55

6.5.1 Setting of the Use tab..........................................................................................................................6-56

6.5.2 Setting of the Access Data tab ...........................................................................................................6-59

6.5.3 Setting of the Alarm Data tab..............................................................................................................6-61

6.5.4 Setting of the Operation Interval tab...................................................................................................6-63

6.5.5 Setting of the Device Trigger tab ........................................................................................................6-64

6.6 When Comment Is Selected......................................................................................................................6-65

6.6.1 Setting of the Use tab..........................................................................................................................6-66

6.6.2 Setting of the Access Data tab ...........................................................................................................6-67

6.6.3 Setting of the Comment Data tab .......................................................................................................6-69

6.6.4 Setting of the Operation Interval tab...................................................................................................6-72

6.6.5 Setting of the Device Trigger tab ........................................................................................................6-73

6.6.6 Setting of the Handshake tab .............................................................................................................6-74

7 AUTOMATIC SAVE SETTING 7- 1 to 7- 9

7.1 Operating of Automatic save list Dialog Box............................................................................................. 7- 1

7.2 Setting of the Automatic save Dialog Box................................................................................................. 7- 4

8 AUTOMATIC PRINT SETTING 8- 1 to 8- 5

8.1 Operating of Automatic print list Dialog Box ............................................................................................. 8- 1

8.2 Setting of the Automatic print Dialog Box.................................................................................................. 8- 2

9- 1 to 9- 2 9 AUTOMATIC COMMUNICATION STARTUP SETTING

10 COMMUNICATION START AND COMMUNICATION END 10- 1 to 10- 3

10.1 Communication Start .............................................................................................................................10- 1

10.2 Communication End...............................................................................................................................10- 3

11 1 SHOT COMMUNICATION 11- 1 to 11- 2

A - 14 A - 14

12 CELL EDITING 12- 1 to 12- 5

12.1 Cutting the Cell Area..............................................................................................................................12- 1

12.2 Copying the Cell Area............................................................................................................................12- 2

12.3 Pasting the Cell Area .............................................................................................................................12- 3

12.4 Deleting the Cell Area ............................................................................................................................12- 5

13 CHANGING THE SHEET NAME

14 Create Button

13- 1 to 13- 2

14- 1 to 14- 7

14.1 Start Communication Button..................................................................................................................14- 1

14.2 End Communication Button...................................................................................................................14- 6

14.3 1 Shot Communication Button...............................................................................................................14- 7

15 Protect/Unprotect MX Sheet setting 15- 1 to 15- 4

15.1 Protect MX Sheet setting .......................................................................................................................15- 1

15.2 Unprotect MX Sheet setting...................................................................................................................15- 4

16 Options 16- 1 to 16- 2

16.1 Setting of the error log ...........................................................................................................................16- 1

17 SETTING DATA EXPORT

18 SAMPLE PROGRAMS

19 ERRORLOG SHEET

20 DATA CONVERSION FUNCTION

17- 1 to 17- 3

18- 1 to 18- 2

19- 1 to 19- 2

20- 1 to 20- 8

20.1 Data Conversion Function .....................................................................................................................20- 1

20.2 Operation Procedure of MXComShConv.exe.......................................................................................20- 3

20.3 Conversion Log File ...............................................................................................................................20- 5

20.4 Precautions on Excel Book after Data Conversion Function Execution ..............................................20- 6

APPENDICES APP-1 to APP-29

APPENDIX 1 VERSION CONFIRMATION................................................................................................APP- 1

APPENDIX 2 COMPARISON BETWEEN MX Sheet AND MX Chart ......................................................APP- 2

APPENDIX 3 PROCESSING SPEED OF MX Sheet ................................................................................APP- 3

A - 15 A - 15

APPENDIX 4 PROCESSING MX Sheet ....................................................................................................APP- 5

Appendix 4.1 Collection Delay and Data Dropout..................................................................................APP- 5

Appendix 4.2 Date and Time ..................................................................................................................APP- 9

APPENDIX 5 CREATING THE Excel SHEET FOR MX Sheet.................................................................APP-10

APPENDIX 6 PROCEDURE TO TRANSPORT DATA TO OTHER PERSONAL COMPUTER .............APP-13

APPENDIX 7 HTML FILE ...........................................................................................................................APP-14

APPENDIX 8 Warning Message Appears on Windows Vista

R and Windows

R

7.....................................APP-15

Appendix 8.1 Overview of warning message .........................................................................................APP-15

Appendix 8.2 Methods for preventing the warning message.................................................................APP-16

APPENDIX 9 ACTION FOR ERRORS OCCURRED WHEN Excel 2007 OR LATER FOR WHICH

AUTOMATIC COMMUNICATION STARTUP HAS BEEN SET IS OPENED...................APP-21

APPENDIX 9.1 Situations .......................................................................................................................APP-21

APPENDIX 9.2 Error Cause ...................................................................................................................APP-21

APPENDIX 9.3 Corrective Action ...........................................................................................................APP-22

APPENDIX 10 ADDED/EXTENDED FUNCTIONS ...................................................................................APP-27

INDEX Index- 1 to Index- 2

A - 16 A - 16

Manuals

The following manuals are relevant to for this software package.

Refer to the table when ordering the manuals.

Relevant Manuals

Manual Name

Manual Number

(Model Code)

MX Sheet Version 1 Operating Manual (Introduction)

Explains the installation method, function outlines and operation methods of MX Sheet Version 1.

(Sold separately)

SH-080347E

(13JU34)

MX Component Version 3 Operating Manual

Explains the setting and operation methods of each utility on MX Component. (Sold separately)

SH-0800271

(13JU32)

MX Component Version 3 Programming Manual

Explains the programming procedures, details and error codes for ACT control. (Sold separately)

SH-080272

(13JF66)

Note: The MX Sheet Version 1 Operating Manual (Introduction) is stored on CD-ROM of the corresponding software package in PDF format.

Any of the manuals is available separately in printed form. Please indicate its manual number (model code) in the above table, when ordering the printed manual.

A - 17 A - 17

Generic Terms and Abbreviations

Unless otherwise stated, this manual uses the following abbreviations and terms for the explanation of MX Sheet.

Generic Term/Abbreviation Description

MX Sheet

IBM-PC/AT compatible

PC CPU module

Personal computer

MX Component

MX Links

MX Chart

Windows R 7

Windows Vista R

Windows R XP

Generic product name for product types SW1D5C-SHEET-E and SW1D5C-SHEET-EA.

-EA indicates a volume license product.

Abbreviation of the IBM PC/AT or its compatible personal computer.

Abbreviation of the MELSEC-Q series corresponding PC CPU module

(CONTEC CO., LTD.).

Generic term of PC CPU module and IBM-PC/AT compatible Personal computer.

Generic product name for product types SW3D5C-ACT-E and SW3D5C-ACT-EA.

-EA indicates a volume license product.

Generic product name of the product type SW3D5F-CSKP-E.

Generic product name of the product type SW3D5F-OLEX-E.

Microsoft R

Microsoft R

Microsoft R

Microsoft R

Microsoft R

Windows R

Windows R

Windows R

Windows R

Windows R

7 Starter Operating System,

7 Home Premium Operating System,

7 Professional Operating System,

7 Ultimate Operating System and

7 Enterprise Operating System.

Note that the 32-bit version is designated as "32-bit Windows

R is designated as "64-bit Windows R 7".

7", and the 64-bit version

Generic term of Microsoft

Microsoft R

R

Windows Vista R

Windows Vista R Home Basic Operating System,

Home Premium Operating System,

Microsoft

Microsoft

Microsoft

R

R

R

Windows Vista

Windows Vista

Windows Vista

R

R

R

Business Operating System,

Ultimate Operating System and

Enterprise Operating System.

Generic term of Microsoft

Microsoft R Windows R

R Windows R XP Professional Operating System and

XP Home Edition Operating System.

A - 18 A - 18

How to Use This Manual

This manual is organized with sections representing each aspect of MX Sheet.

Refer to the respective section when you need to know the following.

(1) The features (Section 1.1)

Section 1.1 gives the features.

(2) The system configuration and operating environment (Section 2.1)

Section 2.1 provides the operating environment.

(3) The functions, performance and applicable PLC CPUs of MX Sheet

(Sections 3.1 to 3.2)

Section 3.1 lists the functions of MX Sheet, and Section 3.2 gives information on the applicable PLC CPUs.

(4) The operation procedure of MX Sheet (Chapter 4)

Chapter 4 provides the operation procedure of MX Sheet.

(5) The menu of MX Sheet (Chapter 5)

Chapter 5 describes the MX Sheet menu selection method.

(6) The cell setting methods of MX Sheet (Chapter 6)

Chapter 6 describes the MX Sheet cell setting methods.

(7) Automatic save setting (Chapter 7)

Chapter 7 describes the automatic save setting of each data.

(8) Automatic print setting (Chapter 8)

Chapter 8 describes the automatic print setting of each data.

(9) Automatic communication startup setting (Chapter 9)

Chapter 9 describes the automatic communication startup setting of each function.

(10) Communication start and communication end (Chapter 10)

Chapter 10 describes communication start and communication end.

(11) 1 shot communication (Chapter 11)

Chapter 11 describes 1 shot communication.

(12) Cell editing (Chapter 12)

Chapter 12 describes cell editing (cutting, copying, pasting and deletion of cell area).

(13) The sheet name changing method (Chapter 13)

Chapter 13 describes the sheet name changing method.

A - 19 A - 19

Definitions of Terms

(14) Create Button (Chapter 14)

Chapter 14 describes the creation of the Start Communication, End

Communication, and 1 Shot Communication buttons.

(15) Protect/Unprotect MX Sheet setting (Chapter 15)

Chapter 15 describes Protect/Unprotect MX Sheet setting by password.

(16) Options (Chapter 16)

Chapter 16 describes Options for setting the output format of an error log sheet.

(17) The setting data export (Chapter 17)

Chapter 17 describes the setting data export.

(18) The error log checking method (Chapter 19)

Chapter 19 describes the error log checking method.

(19) The data utilization method of MX Chart (Chapter 20)

Chapter 20 describes the data utilization method of MX Chart.

(20) The version confirmation method (Appendix 1)

Appendix 1 describes the version confirmation method of MX Sheet.

The terms used in this manual have the following meanings and definitions.

(1) Logical station number

A number assigned to the group of data that is integrated from the connection target information required for communication within the Communication Setup

Utility.

Personal computer

Q02HCPU

Serial (COM1)

Time-out period

Baud rate transmission control

Connection information up to CPU of the communication target station is integrated into one data, to which logical station number is assigned.

A - 20 A - 20

Packing List

The MX Sheet consists of the following products.

SW1D5C-SHEET-E

MX Sheet Version 1(1-license product)

End-user software license agreement

(CD-ROM)

License certificate

MX Sheet Version 1(Volume license product) (CD-ROM)

SW1D5C-SHEET-EA

End-user software license agreement

License certificate

* 1: The number of included license agreements is equivalent to the number of licenses.

1

1

1

1

1 n * 1

A - 21 A - 21

1 OVERVIEW

MELSOFT

1

1 OVERVIEW

MX Sheet is a communication support software package that allows device data collection, etc. by simple, program-less setting using Excel.

Logging function, monitor function Write function Automatic print function

Alarm summary function Comment display function

MX Sheet

PLC CPU

Automatic save function

Excel book file

HTML file

CSV file

1 - 1 1 - 1

1 OVERVIEW

MELSOFT

1.1 Features

This section explains the features of MX Sheet.

(1) Program-less and easy setting

PLC device data can be collected/written by making simple setting without programming.

MX Sheet Excel

Making simple setting

PLC device data are displayed on Excel sheet.

(2) Collection/write of device data using a wide range of communication paths

MX Sheet uses MX Component for communication between the PLC and personal computer.

Using a variety of communication paths supported by MX Component, system configuration that meets user's requirement can be achieved.

<Examples of communication using MX Component>

Ethernet communication MELSECNET/H communication

GOT

Modem communication Gateway function communication

1

1 - 2 1 - 2

1 OVERVIEW

MELSOFT

(3) Each function can be controlled by device condition.

The condition of device data collection/write can be set to PLC devices.

The execution of any MX Sheet function can be controlled from the PLC side.

<When device data is collected/written while bit device is on>

Device data is collected/written

Device data is collected/written

ON

OFF

Corresponding functions

Logging

Write

Comment display

Monitor

Alarm summary

Automatic save

Automatic print

(4) Data logging using CSV file

Using the logging or monitor function, device data can be displayed on Excel sheet, and simultaneously, collected data can be saved into a CSV file.

Long-term data collection is enabled by a single CSV file.

Display on Excel sheet

Simultaneous execution!

[CSV file]

2002/05/04 08:00:00, 0, 0, 0, 0, 0, 0

Save into CSV file

2002/05/04 08:00:10, 10, 20, 30, 40, 50, 60

(5) Compatibility with MX Chart

MX Sheet can convert the set data of MX Chart into those of MX Sheet.

The communication settings of MX Links and various settings of MX Chart can be converted into the logical station numbers of MX Component and cell settings of MX Sheet, respectively, to utilize old assets efficiently.

MX Chart

Conversion

MX Sheet

1 - 3 1 - 3

1 OVERVIEW

MELSOFT

(6) Improvement of operability by buttons

By creating buttons, the Start Communication, End Communication, and 1 Shot

Communication functions can be executed by merely clicking the corresponding buttons.

Operability is improved as compared to the execution of the functions from the menu.

(Example) Start Communication

After displaying the MX Sheet menu, select the Start Communication.

Button

Click only

1 - 4 1 - 4

2 SYSTEM CONFIGURATION

MELSOFT

2 SYSTEM CONFIGURATION

The system configuration for MX Sheet is the same as that for MX Component Version 3.

For details, refer to the MX Component Version 3 Operating Manual.

2.1 Operating Environment

2

The following table indicates the operating environment of MX Sheet.

Item Description

Computer

IBM PC/AT compatible personal computer

Pentium

R

200MHz or higher *1 IBM PC/AT compatible personal computer installed with applicable OS *

2

PC CPU module MELSEC-Q series compatible PC CPU module (CONTEC CO., LTD.)

Required memory 64MB or more *

4

Hard disk free space

Disk drive

Display

100MB or more

CD-ROM disk drive

1024 × 768 dot or higher resolution

System Software

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Microsoft

R

Windows

R

98 Operating System (English version),

Windows

R

Millennium Edition Operating System (English version),

Windows NT

R

Workstation Operating System Version 4.0 (English version) *

3

,

Windows

Windows

Windows

R

R

R

2000 Professional Operating System (English version),

XP Professional Operating System (English version),

XP Home Edition Operating System (English version),

Windows Vista

R

Windows Vista

R

Windows Vista

R

Home Basic Operating System (English version),

Home Premium Operating System (English version),

Business Operating System (English version),

Windows Vista

Windows Vista

Windows

R

R

R

Ultimate Operating System (English version),

Enterprise Operating System (English version),

7 Starter Operating System (English version),

Windows

R

Windows

R

Windows

Windows

R

R

7 Home Premium Operating System (English version),

7 Professional Operating System (English version),

7 Ultimate Operating System (English version) or

7 Enterprise Operating System (English version).

Required

Software

Microsoft

R

Excel 2000 (English version), Microsoft

R

Excel *

5

Microsoft

R

Excel 2003 (English version), Microsoft

32-bit Microsoft

R

Excel 2010 (English version)*

7

R

MX Component*

8

MX Component version 3.01B or later

Excel 2002 (English version),

Excel 2007 (English version)*

6

, or

*1: A Pentium

R

300MHz processor or higher is recommended for Windows

R

XP Home

Edition. 1GHz or higher is recommended for Windows Vista

R and Windows

R

7.

*2: This product does not work with a multiprocessor IBM-PC/AT-compatible personal computer, because the driver is not compatible with it.

XP Professional and Windows

R

*3: Service Pack 3 or more is needed when using Windows NT

*4: 128MB or more is recommended for Windows

R

R

Workstation 4.0.

XP, 1GB or more is recommended for Windows

R

Vista and 32-bit

Windows

R

7, and 2GB or more is recommended for 64-bit Windows

R

7.

*5: Excel sheets created in the English environment can be used in the English environment only. They cannot be used in other environment.

*6: Windows R XP Service Pack 2 or later is required for Excel 2007.

*7: For 32-bit Microsoft R Excel 2010, Windows R XP Service Pack 3, Windows Vista R Service Pack 1 or higher, or

Windows R 7 or later is required.

64-bit Microsoft

R

Excel 2010 is not supported.

*8: When executing the Communication Setup Utility with administrator authority from Excel, MX Component Version

3.12N or later is required.

2 - 1 2 - 1

2 SYSTEM CONFIGURATION

MELSOFT

POINT

(1) When Windows

Windows

R

R

XP Professional Operating System, Microsoft

R

XP Home Edition Operating System, Windows Vista

R

or

Windows

R

7 is used, the following new functions cannot be used.

If any of the following new functions is used, this product may not operate normally.

Start of application in Windows

R compatible mode

Fast user switching

Remote desktop

Big fonts (Details setting of Screen properties).

R

XP and 64-bit Windows Vista

R are not supported.

(2) When Windows

R

7 is used, the following new functions cannot be used.

Windows XP Mode

Windows Touch

(3) When MX Sheet is tried to be installed on the personal computer where 64-bit

Microsoft

R

Excel 2010 has been installed, the following error message appears.

(4) When MX Sheet is installed, 64-bit Microsoft

R

Excel 2010 is installed and started, then an add-in is installed, the following error message appears.

To use MX Sheet, install 32-bit Microsoft

R

Excel 2010.

2

2 - 2 2 - 2

3 FUNCTION LIST OF MX Sheet

MELSOFT

3 FUNCTION LIST OF MX Sheet

3

This chapter describes the functions of MX Sheet, accessible CPUs and accessible devices.

3.1 Function List of MX Sheet

Function Name

The following table lists the functions of MX Sheet.

Description

Available Device

Points

Logging

Monitor

Write

Alarm summary

Comment display

Accumulates device data collected from PLC in cell range selected on Excel as history.

Displays device data collected from PLC in cell range selected on

Excel.

Writes values entered on Excel to PLC devices.

Converts ON/OFF data of bit devices into alarm comment character strings that are set separately and accumulates them on Excel sheet as alarm history.

Converts bit or word device values into comment character strings that are set separately and displays them on Excel sheet.

Device trigger

Handshake

Collects/Writes device data when set device conditions set for collection/write are met.

Sets handshake with PLC for secure device data collection/write.

CSV logging

Displays device data on Excel sheet with logging or monitor function, and simultaneously saves collected data as a CSV file.

Automatic save Automatically saves Excel book

Automatically prints Excel book. Automatic print

Automatic communication startup

Communication start

Communication end

1 shot communication

Automatically starts communication with PLC when Excel book is started.

This function starts communication with the PLC.

This function ends communication with the PLC.

Create Button

Protect/Unprotect

MS Sheet setting

Options

Setting data export

Executes functions set in the selected cell range at any desired timing.

This function creates buttons to facilitate Start Communication,

End Communication, and 1 Shot Communication operations.

This function sets/cancels the password for protecting the MX

Sheet setting.

This function sets the output format of the error log sheet.

Outputs MX Sheet settings in CSV file format.

Data conversion

Converts communication settings of MX Links (SW3D5F-

CSKPE) and various settings of MX Chart (SW3D5F-OLEXE) into logical station numbers of MX Component and cell settings of MX Sheet respectively.

256 points *

1,

*

2

2000 points *

1,

*

3

2000 points *

1,

*

3

2000 points *

2,

*

4

1 point *

5

256 columns

65536 rows

6 columns

65536 rows

Reference

Section

---- Chapter 7

---- Chapter 8

---- Chapter 9

----

---- Chapter 11

---- Chapter 14

---- Chapter 15

----

Available Cells

Section 6.2

Section 6.5

Section 10.1

Chapter 16

---- Chapter 17

---- Chapter 20

*1: This number of device points refers to the case where word device data are collected/written in 16 bit integer.

The number of device points that can be set changes depending on the device data type, etc.

*2: One Excel file (one Excel book) accepts 100 - cell - area setting.

*3: One Excel file (one Excel book) accepts 1000 - cell - area setting.

*4: Only bit devices can be set.

*5: One Excel file (one Excel book) accepts 500 - cell - area setting.

3 - 1 3 - 1

3 FUNCTION LIST OF MX Sheet

MELSOFT

3.2 Accessible CPUs and Accessible Device Ranges

This section describes the accessible CPUs and accessible device ranges of MX

Sheet.

(1) Accessible CPUs

The accessible CPUs in MX Sheet are the same as those in MX Component

Version 3.

For details, refer to the MX Component Version 3 Operating Manual.

(2) Accessible device ranges

The accessible device ranges in MX Sheet are the same as those in MX

Component Version 3, with the exception of the following item.

For details, refer to the MX Component Version 3 Operating Manual.

1) Device extension representation

MX Sheet does not allow access to any device by word designation for bit device (e.g. K4X0, K8M0) and bit designation for word device (e.g. D0.0,

W.01).*

1

*1: When using MX Sheet Version1.06 G or later, device setting by bit designation for word device (e.g. D0.0) is only possible in the setting on

<<Access Data >>tab.

(3) Specifying GOT timer contact devices and counter contact devices

In the cell settings of MX Sheet (Refer to Chapter 6), timer contact devices (TT) and counter contact devices (CT) which are the device representation of GOT can be entered.

The entered "TT" and "CT" are automatically changed to "TS" and "CS" respectively.

3

3 - 2 3 - 2

4

4 MX Sheet OPERATION PROCEDURE

MELSOFT

4 MX Sheet OPERATION PROCEDURE

The following indicates the MX Sheet operation procedure.

Install MX Sheet.

Refer to the MX Sheet

Operating Manual (Introduction).

Start Excel and save the Excel book. *1

Select the function to be used, and make MX Sheet settings.

Logging function

Write function

Comment display function

Automatic print function

Monitor function

Alarm summary function

Automatic save function

Refer to Chapters 6 to 8.

Start communication.

End communication.

Completion

Refer to Section 10.1.

Refer to Section 10.2.

*1: Before starting MX Sheet settings, save the Excel book. If not, MX Sheet cannot be set.

POINT

Communication efficiency changes depending on the MX Sheet setting. Refer to

APPENDIX 3 and APPENDIX 5.

REMARK

Refer to the Excel manual for how to operate Excel.

4 - 1 4 - 1

4 MX Sheet OPERATION PROCEDURE

MELSOFT

<Administrator authority when setting/changing communication setup on

Windows Vista

R

and Windows

R

7>

Administrator authority is required for setting/changing communication setup.

(1) Administrator authority in case of Windows Vista

R

and Windows

R

7

1) When user account control (UAC) is enabled

All users including administrator are fixed at and operate as "standard user".

To execute programs in administrator authority, specify "Run as administrator".

* When executing Excel with administrator authority, even if selecting "NO" for "Do you execute programs as an administrator?" executes with administrator authority.

2) When user account control (UAC) is disabled

Programs can be executed by login user.

(2) When setting/changing the communication setup on Windows

Vista

R

and Windows

R

7

The following three methods are available to set/change the communication setup.

• Execute Communication Setup Utility of MX Component with Administrator authority and make setting/change the setting.

• Execute the Communication Setup Utility with administrator authority from

Excel for setting/changing.

• Execute Excel with Administrator authority and make setting/change the setting.

* When executing Excel with administrator authority, the operations such as opening the file by dragging and dropping cannot be executed.

4

4 - 2 4 - 2

5 MX Sheet MENU SELECTION METHOD

MELSOFT

5

5 MX Sheet MENU SELECTION METHOD

MX Sheet can be operated from the menu bar, toolbar (icons) and right-click of the mouse. When using Excel 2007 or later, operate from the ribbon.

This chapter describes the displaying method and details of the MX Sheet menu options.

(1) Displaying method

(a) Using the menu bar (Excel 2003 or earlier)

Choose [MX Sheet] from the menu bar.

(b) Using the toolbar (icons) (Excel 2003 or earlier)

Choose [View] [Toolbars] on the menu bar and click on "MX Sheet".

(c) Using the right-click of the mouse

Specify the cell area and right-click the mouse.

(d) Displaying the <<Add-Ins>> tab (Excel 2007 or later)

Choose the <<Add-Ins>> tab [MX Sheet] on the ribbon.

Menu bar Right-click of mouse

<<Add-Ins>> tab

Toolbar (Icons)

REMARK

If the Excel sheet type is other than the worksheet, the MX Sheet menu is not displayed. When using MX Sheet, make setting on the worksheet.

5- 1 5 - 1

5 MX Sheet MENU SELECTION METHOD

MELSOFT

Menu bar

(2) MX Sheet menu details

The following table details the items of the MX Sheet menu.

Item

Description

Icon Right-click

----

----

----

----

----

Used to make cell setting.

Used to make automatic save setting.

Used to make automatic print setting.

Used to make automatic communication startup setting.

Used to start communication.

Used to end communication. *1

Used to make 1 shot communication.

Reference

Section

Chapter

6

Chapter

7

Chapter

8

Chapter

9

----

Used to cut a cell area

Used to copy a cell area.

Used to paste a cell area. *2

Used to delete a cell area.

Used to change the

Excel sheet name.

Section

10.1

Section

10.2

Chapter

11

Section

12.1

Section

12.2

Section

12.3

Section

12.4

Chapter

13

---- ----

Communication Button.

Create the End

Communication Button.

---- ----

----

----

Communication Button.

Protect the MX Sheet setting.

Unprotect the MX Sheet

Set the error log options.

---- ---- data export.

Section

14.1

Section

14.2

Section

14.3

Section

15.1

Section

15.2

Section

16.1

Chapter

17

Appendix

1

*1: Can be selected after start of communication.

*2: Can be selected after the cell area has been cut or copied.

5

5- 2 5 - 2

6

6 CELL SETTING

MELSOFT

6 CELL SETTING

This chapter describes cell setting required to operate MX Sheet.

6.1 Operation of Cell Setting Dialog Box

This section explains the displaying procedure and setting item change of the "Cell

Setting" dialog box.

In the "Cell Setting" dialog box, its setting items change automatically depending on the selected function.

(1) Displaying "Cell Setting" dialog box

Choose [MX Sheet] [Cell Setting] (

) from the menu bar.

(2) Setting items of "Cell Setting" dialog box

The setting of the "Cell Setting" dialog box can be changed by selecting "Use" of the <<Use>> tab.

Selecting "Use" changes setting items.

The following table indicates the function outlines and relevant sections for options of "use".

Logging

Monitor

Write

Alarm summary

Comment

Set when using the logging function.

Set when using the monitor function.

Set when using the write function.

Set when using the alarm summary function.

Set when using the comment display function.

Section 6.2

Section 6.3

Section 6.4

Section 6.5

Section 6.6

6 - 1 6 - 1

6 CELL SETTING

MELSOFT

6.2 When Logging Is Selected

<<Use>> tab

This section describes the "Cell Setting" dialog box when "Logging" is selected from

"Use" of the <<Use>> tab.

<<Access Data>> tab

Required setting

Refer to Section

6.2.1.

Required setting

Refer to Section

6.2.2.

<<Operation Interval>> tab

Required setting

Refer to Section

6.2.3.

<<Device Trigger>> tab

Set as necessary

Refer to Section

6.2.4.

6

<<Handshake>> tab

Set as necessary

Refer to Section

6.2.5.

<<CSV Logging>> tab

Set as necessary

Refer to Section

6.2.6.

6 - 2 6 - 2

6 CELL SETTING

MELSOFT

6.2.1 Setting of the Use tab

This section describes the setting of the <<Use>> tab for use of the logging function.

In the <<Use>> tab, set the cell area, logging data display position, displayed contents, and operation when the cell is full.

tab

a)

Use

Cell Area Name

New data location

Displayed Contents

Set the function to be used for the specified cell area. Choose "Logging" when using the logging function.

Set the name of the specified cell area.

(Maximum number of cell area names : 100)

Cell Area

Set the Color of Grid line

Enter the value to specify the cell area.

Set whether the specified cell area is provided with grid lines (including color designation) or not.

Set the Color for Filling Set whether the specified cell area is colored or not.

Clear cell area at the start of communication

When "Clear cell area at the start of communication" has a check mark, the data in the cell area specified at the start of communication is cleared.

(Default: check)

Set the latest data display position of the logging data.

• Last Line

The latest data is displayed at the lost of the specified cell area.

• First Line

The latest data is displayed at the first of the specified cell area.

Set whether the title and the date and time are added to the displayed logging data or not.

----

----

(2) (a)

(2) (b)

(2) (c)

(2) (d)

(2) (e)

(To the next page)

6 - 3 6 - 3

6 CELL SETTING

MELSOFT

Operating when cell is full

Set the operation to be performed when the specified cell area is full.

• To scroll

The displayed contents are scrolled and displayed.

• Display from the first without clearing the cell area

The data currently displayed in the cell area are overwritten and logging is resumed. Before logging is resumed, the Excel sheet can be printed and saved.

• Display from the first after clearing the cell area

The data displayed in the cell area are erased and logging is resumed.

Before logging is resumed, the Excel sheet can be printed and saved. a) (Preset cell areas) The settings of the cell areas preset to the Excel book are displayed.

(2) (f)

(2) (g)

Set the cell area to be used by the logging function.

<When a single cell range is specified (B2 to D5)>

B2 : D5

Enter the cell numbers with ":" in between.

Cell area from B2 to D5

(Number of cells : 12)

<When multiple cell areas are specified (B2 to D5 (Specified cell area 1) and B8 to D11 (Specified cell area 2))>

B2 : D5 , B8 : D11

Specified cell area 2

Enter the cell areas with "," in between.

Specified cell area 1

Specified cell area 1

(B2 to D5)

Specified cell areas 1 and 2 are displayed in this order.

In this case;

Number of specified cell area : 2

Number of cells : 24

Specified cell area 2

(B8 to D11)

The following indicates the available setting ranges for the cell area and number of specified cell areas.

• Cell area

When date and time are added: 255 columns 65536 rows

When date and time are not added: 256 columns 65536 rows

• Number of specified cell areas: Up to 16

6 - 4 6 - 4

6 CELL SETTING

MELSOFT

(b) "Set the Color of Grid line" and "Set the Color for Filling"

Set the colors of cell area grid lines and cell filling.

Depending on the selection, all area may be colored gray.

Refer to the Operating Precautions for details.

(c) "Clear cell area at the start of communication"

Set whether the cell area will be cleared or not at the start of communication.

1) Display example in the case where "Clear cell area at the start of communication" is checked

< Before the start of communication >

2004/05/24 Mon 13:00:00

2004/05/24 Mon 13:00:05

2004/05/24 Mon 13:00:10

15

16

17

37

39

42

< At the start of communication >

< At the completion of the first collection >

2004/05/24 Mon 15:00:00 31 102

2) Display example in the case where "Clear cell area at the start of communication" is not checked

< Before the start of communication >

2004/05/24 Mon 13:00:00

2004/05/24 Mon 13:00:05

2004/05/24 Mon 13:00:10

< At the start of communication >

2004/05/24 Mon 13:00:00

2004/05/24 Mon 13:00:05

2004/05/24 Mon 13:00:10

15

16

17

15

16

17

37

39

42

37

39

42

< At the completion of the first collection >

2004/05/24 Mon 13:00:00

2004/05/24 Mon 13:00:05

2004/05/24 Mon 13:00:10

2004/05/24 Mon 15:00:00

15

16

17

31

37

39

42

102

6 - 5 6 - 5

6 CELL SETTING

MELSOFT

(d) "New data location"

Set the newest data location when the logging function is used.

1) When "Last Line" is selected

Old data

2) When "First Line" is selected

New data

New data

Old data

1) "Add title" check box

Set whether the date and time and the title for device name will be displayed or not at the first line of the "Cell Area".

When displaying the title, check the check box.

<Display example>

When "Add date and time details" is checked and the devices D100 to D103 are set

The device name set on the <<Access Data>> tab is displayed.

Title

Collection data

Date Time

2004/05/24 Mon 13:24:14

2004/05/24 Mon 13:24:17

D100

30

40

D101

100

80

D102

0

0

D103

37

55

POINT

• The title display line will not be the target of cell area clear at the start of communication or clear when cell is full.

• When the Cell Area is set at multiple locations, the title is displayed for only the

Cell Area specified first.

(Example) When the Cell Area on the <<Use>> tab is set to B2:E4, B6:E8

6 - 6 6 - 6

6 CELL SETTING

MELSOFT

2) "Add date and time details" check box

Set whether the logging date and time are added to the cell area set in the "Cell Area" or not.

When adding the date and time, check the check box.

In this case, the leftmost column of the logging data area is used for the date and time. (One item of logging data decreases.)

The date and time column displays the date and time of the personal computer where MX Sheet has been installed.

Indicates the time as "hours: minutes: seconds".

Indicates the day of the week as "Sun (Sunday),

Mon (Monday), Tue (Tuesday), Wed (Wednesday),

Thu (Thursday), Fri (Friday), Sat (Saturday)".

Indicates the date as "year/month/day".

REMARK

The above date and time can be edited on Excel.

If the cell setting is edited again after editing on Excel, the setting on Excel are invalid.

6 - 7 6 - 7

6 CELL SETTING

MELSOFT

(f) "Operating when cell is full"

Set the operation to be performed when the cell area is full of logging data.

When "New data location" is set for "First Line", "Display from the beginning without clearing the cell area" cannot be chosen.

1) When "To scroll" is selected

<When "New data location" is set for "Last Line">

First data

Second data

Third data

Fourth data

Fifth data

Second data

Third data

Fourth data

Fifth data

Sixth data

Scrolled up.

<When "New data location" is set for "First Line">

Fifth data

Fourth data

Third data

Second data

Sixth data

Fifth data

Fourth data

Third data

Scrolled down.

First data Second data

2) When "Display from the beginning without clearing the cell area" is selected

When the cell is full, Excel sheet print or Excel book save can also be performed.

First data

Second data

Third data

Print or save

Excel sheet.

Sixth data

Second data

Third data

Data are overwritten, beginning with the first data.

Fourth data

Fourth data

Fifth data

Fifth data

3) When "Display from the beginning after clearing the cell area" is selected

When the cell is full, Excel sheet print or Excel book save can also be performed.

First data

Second data

Sixth data

Third data

Fourth data

Print or save

Excel sheet.

Erased when cell is full.

Fifth data

4) When "Print the Excel sheet" is selected

The Excel sheet is printed when the cell is full.

After completion of print, all data are erased and logging is resumed.

This item can be selected when "Operating when cell is full" is set to 2) or 3).

6 - 8 6 - 8

6 CELL SETTING

MELSOFT

5) When "Save to file" is selected

The Excel book is saved when the cell is full.

After completion of save, all data are erased and logging is resumed.

This item can be selected when "Operating when cell is full" is set to 2) or 3).

When choosing "Save to file", make the following settings for the file where data will be saved.

Item Description

File name to save

The storage location and file name is set for the Excel book to be saved when the cell is full. *

1

The Excel file (.xls, .xlsx*

2

, .xlsm*

2

, .xlsb*

2

) or HTML file (.htm)*

3

or CSV file (.csv) can be set as the file type. *

4

The file set in "File name to save" saves data with the date and time added to its file name.

The following indicates a file name format when data is saved.

*****20020523183536.

extension

Add date and time to File name

Add sequential number to

File name

Extension set to "File name to save"

Seconds

Minutes

Hours

Day

Month

Year

File name set in "File name to save"

The file set in "File name to save" saves data with a number added to its file name.

A serial number can be set within the range of 000 to 999.

When the number is reached to the last, the file of the first number is overwritten by the newly saving file.

The following indicates the file name format when data is saved.

*****000.

extension

Extension set in "File name to save"

File number

File name set in "File name to save"

The file set in "File name to save" is overwritten by data. Fix the File name

*1: A UNC path name (\\server name\path name) cannot be specified as a file name. After assigning the network drive, specify the path name.

*2: .xlsx, .xlsm, and .xlsb are Workbook-format extensions added to Excel 2007 or later.

*3: For the continuous operation when saving data automatically in HTML format, refer to APPENDIX 7.

*4: In the case of an Excel file or HTML file, the whole Excel book is saved. However, in the case of a CSV file, only the data of the target sheet is saved.

6 - 9 6 - 9

6 CELL SETTING

MELSOFT

(g) "preset cell areas"

The cell areas already set to the Excel book are displayed.

The following operations are available by selecting the cell area name in the "preset cell areas".

1) Reading the settings

Choose and double-click the cell area name to read the settings of the selected cell area name to the "Cell Setting" dialog box.

2) Deleting the settings

Choose the cell area name and press the Delete key to erase all the settings of the selected cell area name.

6 - 10 6 - 10

6 CELL SETTING

MELSOFT

6.2.2 Setting of the Access Data tab

This section describes the setting of the <<Access Data>> tab for use of the logging function.

In the <<Access Data>> tab, set the logical station number required for communication with the PLC and the device data to be collected in the cell area.

(1) <<Access Data >> tab

a) b) c)

Logical Station Number

Communication settings

Remote password *1 a) (Access data) b) (Number of set devices) c) (Preset cell areas)

Select the logical station number required for making communication.

Used to start the Communication Setup Utility to set a new logical station number and change the settings.

Enter the password when the password has been set to the connection target PLC.

Set the devices to be logged.

(2) (a)

(2) (b)

(2) (c)

(2) (d)

The number of devices currently set is displayed. (2) (e)

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

*1: "Remote password" is displayed when the logical station number selected in "Logical Station Number" of the <<Access

Data>> tab is the one for the password function compatible module.

6 - 11 6 - 11

6 CELL SETTING

MELSOFT

(a) "Logical Station Number"

Choose the logical station number required for communication.

If the logical station number has already been set, the number appears in the list box and can be selected.

If the logical station number has not been set, click on

Communication Settings and set a new logical station number.

This button is used to start the Communication Setup Utility to set a new logical station number and change the settings.

Select "Run as administrator" when the screen appears asking if execute programs with administrator authority or not.

After starting the Communication Setup Utility, click on Wizard and set a new logical station number and change the settings with the

Communication Setting Wizard.

For the detailed explanation of the Communication Setup Utility and

Communication Setting Wizard, refer to the MX Component Operating

Manual.

"Remote password" box appears when the setting of the logical station number selected in "Logical Station Number" includes information on the connection to the module with the password function.

When the password has been set to the connection target PLC, enter the password.

It need not be entered when the password has not been set.

1) Order of display

Data are displayed in the cell area in the order of the numbers shown on the left of the <<Access Data>> tab.

<Device data display example>

Setting example of <<Access Data>> tab

Data numbers

The device data are displayed on Excel as shown below.

Displayed in order of data numbers.

Data No. 1 Data No. 2 Data No. 3

2) "Device"

Enter the device to be accessed.

Enter the device name and device number in this order.

Refer to Section 3.2 for the accessible devices.

6 - 12 6 - 12

6 CELL SETTING

MELSOFT

Set the data type to be displayed in the cell.

Bit

16 bit integer

(-32768 to 32767)

32 bit integer

(-2147483648 to

2147483647)

Character string

Bit device

Word device

(Bit specification)

Bit device

Word device

Bit device

Word device

Bit device

Word device

Real number

( 2

-126

|value| 2

128

, 0)

Bit device

Word device

Description

The bit devices set in "Device" are displayed in a single cell in units of one bit.

Designated bits for word device set in "Device" are displayed in a single cell in units of one bit (e.g. D0.0).

Displayed in a single cell in units of 1 word (16 bits), starting with the device number set in "Device". *

1

Displayed in a single cell in units of 1 word, starting with the device number set in "Device". *

1

Displayed in a single cell in units of 2 words (32 bits), starting with the device number set in "Device". *

1

Displayed in a single cell in units of 2 words, starting with the device number set in "Device". *

1

The data of the device number set in "Device" are displayed in the cell as character strings. *

2

The data of the device number set in "Device" are displayed in the cell as character strings. *

2

Displayed in a single cell in units of 2 words (32 bits), starting with the device number set in "Device". *

1

Displayed in a single cell in units of 2 words, starting with the device number set in "Device". *

1

*1: The displayed value changes depending on the "Zoom" setting.

Refer to 6) for details.

*2: The unit and the number of displayed characters of the read data change depending on the "No. of characters" setting.

Refer to 5) for details.

4) "Value"

Select the display format of the value to be displayed in the cell from

DEC and HEX.

Depending on the "Data Type", the "Value" and "Zoom" can be selected/set as described below.

Item

Cell data display

Data Type Value Zoom

Bit

16 bit integer

32 bit integer

Character String

Real number

Cannot be selected

DEC

HEX

DEC

HEX

Cannot be selected

Cannot be selected

Cannot be set

Can be set

Cannot be set

Can be set

Cannot be set

Cannot be set

Can be set

0 or 1

Displayed in decimal

Display in 4-digit hexadecimal (ex. 03EB)

Displayed in decimal

Display in 8-digit hexadecimal

(ex. 03EB03EA)

Character string is displayed (ex. ABCD)

Real number is displayed (ex. 1.36E-36)

6 - 13 6 - 13

6 CELL SETTING

MELSOFT

5) "No. of characters"

Set the number of characters to be displayed in a single cell.

Setting range: 40

Depending on the value set in "No. of characters" and device data, the character strings may not be displayed in the cell.

The following are the examples of setting 1 to 4 in "No. of characters".

(Example) When displaying the character strings stored in D0 to D3

D0 b15 to b8 b7 to b0

B A

D1 D C

D2 F E

D3 H G

<When "No. of characters" is set to "1">

The data is displayed in a single cell in units of 1 word (16 bits).

Only the character stored in b0 to b7 of D0 is displayed.

The character stored in b8 to b15 of D0 is not displayed.

D0 (b0 to b7) data is displayed.

<When "No. of characters" is set to "2">

The data is displayed in a single cell in units of 1 word (16 bits).

The character strings stored in b0 to b7 and b8 to b15 are displayed in this order.

D0 (b0 to b7, b8 to b15) data is displayed.

<When "No. of characters" is set to "3">

The data is displayed in a single cell in units of 2 words (32 bits).

The character strings stored in D0 (b0 to b7, b8 to b15) and D1 (b0 to b7) are displayed.

The character string stored in b8 to b15 of D1 is not displayed.

D0 (b0 to b7, b8 to b15) and D1 (b0 to b7) data is displayed.

<When "No. of characters" is set to "4">

The data is displayed in a single cell in units of 2 words (32 bits).

The character strings stored in D0 (b0 to b7, b8 to b15) and D1 (b0 to b7, b8 to b15) are displayed in this order.

D0 (b0 to b7, b8 to b15) and D1 (b0 to b7, b8 to b15) data is displayed.

6 - 14 6 - 14

6 CELL SETTING

MELSOFT

6) "Zoom"

The device value read from the PLC is multiplied by the zoom ratio and displayed in the cell.

When "Data Type" has been set to "Bit" or "Character string", the

"Zoom" setting is not possible.

When the "Value" is set to "HEX", the "Zoom" setting is not possible.

Setting range: 0.001 to 1000

PLC Excel

Set "Zoom" to "0.1".

D0

25

Displayed 2.5 on Excel.

7) "No. of cells"

Set the number of cells to be used for the device set in "Device" within the area specified in "Cell Area".

<Device data display example>

Setting example of <<Access Data>> tab

Device: D0

Data type: 16 bit integer

Number of cells: 3

The device data are displayed on Excel as shown below.

3 points are displayed in order, starting with D0.

These are set as the cell area but not used.

The points of the devices to be consecutively read starting with the device number set in "Device" are displayed.

The unit of the device to be shown in the cell is displayed.

(e) The number of set devices

The number of device points and others set to the cell area are displayed.

Indicates the number of device points set for the logging function in the cell area.

Indicates the number of cells available for the cell area.

Indicates the number of cells where the device has been set in the cell area.

6 - 15 6 - 15

6 CELL SETTING

MELSOFT

6.2.3 Setting of the Operation Interval tab

This section describes the setting of the <<Operation Interval>> tab for use of the logging function.

In the <<Operation Interval>> tab, set the day, time and time zone of the activation of the function for the cell area.

(1) <<Operation Interval>> tab

a)

Set the Operation Interval Set the operation of the cell area valid or invalid.

Operation day Set the operation day of the logging activation.

Operation time

Logging Time zone *1 a) (Preset cell areas)

Set the operation time of the logging activation.

Set the time zone of the logging activation.

The settings of the cell areas preset to the Excel book are displayed.

(2) (a)

(2) (b)

(2) (c)

(2) (d)

Section 6.2.1

*1: If the logical station number selected in "Logical Station Number" of the <<Access Data>> tab is the one for modem communication, "Logging Time zone" is switched to "Telephone line connectivity time zone".

Telephone line connectivity time zone

Sets the timing of connection and disconnection of the telephone line.

(2) (e)

6 - 16 6 - 16

6 CELL SETTING

MELSOFT

(a) "Set the Operation Interval"

To make the settings of cell area invalid or to use the function of cell area for 1 shot communication only, remove the check mark. (Do not remove the check mark for the case of ordinary operation.)

Set the operation day of device data collection.

1) When "Daily" is selected

Operation is performed every day.

2) When "Weekly" is selected

Operation is performed on the specified day of the week only.

Multiple days of the week can be set.

3) When "Monthly" is selected

Operation is performed on the specified days only.

If the specified day does not exist in some months, an alternate day can be specified.

Number of days that can be set: 31

<When "15th" is set>

Operation is performed on the 15th every month, e.g. January 15,

February 15, March 15.

<When "31st" is set>

Excepting February, April, June, September and November, operation is performed on the 31st every month.

For February, April, June, September and November, set the alternate day and processing in "Alternate day when a date does not exist".

The following table indicates the setting items of "Alternate day when a date does not exist".

Item Description

Last day of the current month Operation is performed on the last day of February, April, June, September or November.

First day of the next month

No operation

Operation is performed on the first day of the next month.

Operation is not performed in February, April, June, September and November.

Set the operation time of device data collection.

1) When "Regular interval" is selected

Device data is collected at the set second intervals.

When modem communication is used and "Connect each time depending " is set in "Telephone line ", set 30 seconds or more to

"Regular interval".

Setting range: 0.1 to 0.9 (in units of 0.1 seconds),

1 to 3600 (in units of 1 second)

When the date and time are added, the date and time displayed on the

Excel sheet will be in the "yyyy/mm/dd ddd hh:mm:ss" format if the setting is 0.1 to 0.9 seconds.

(Example) When 0.2 seconds interval is set

6 - 17 6 - 17

6 CELL SETTING

MELSOFT

2) When "Minutely" is selected

Device data is collected at the specified second every minute.

Number of times that can be set: 60

3) When "Hourly" is selected

Device data is collected at the specified minute every hour.

Number of times that can be set: 60

4) When "Time table" is selected

Device data is collected at the specified time.

Number of times that can be set: 50

(d) "Logging Time zone"

Set the time zone for logging.

1) When "Log Always" is selected

Logging is always performed at the specified operation time of the operation day.

2) When "Log only during the specified time zone" is selected

Logging is performed in the specified time zone only.

Number of settings: 4

When "Operation day" has been set to "Weekly" or "Monthly", do not make the following setting that will span two days.

(e) "Telephone line connectivity time zone"

Set the time zone for connection with the telephone line.

1) When "Be in connected state always from the start of the communication" is selected

The telephone line is connected upon start of MX Sheet communication, and is kept connected until termination of MX Sheet communication.

2) When "Connect during the specified time zone only" is selected

The telephone line is connected only in the specified time zone.

Number of settings: 4

When "Operation day" has been set to "Weekly" or "Monthly", do not make the following setting that will span two days.

3) When "Connect each time depending on the operation interval" is selected

The telephone line is connected and disconnected according to the settings of "Operation day" and "Operation time".

6 - 18 6 - 18

6 CELL SETTING

MELSOFT

(a) When using communication other than modem communication

(Log Always)

The following setting example shows that logging is always performed at regular intervals.

Set the Operation Interval : Marked

Operation day

Daily : Marked

Operation time

Regular interval : 60 seconds

Logging Time zone

Log Always : Marked

The following shows the operation timings in the setting example.

First Second Third Fourth Fifth Sixth

60s 60s 60s 60s 60s

Time

Device data collection is executed.

6 - 19 6 - 19

6 CELL SETTING

MELSOFT

(b) When using communication other than modem communication

(Log only during the specified time zone)

The following setting example shows that logging is performed in the specified time zone only.

Set the Operation Interval : Marked

Operation day

Weekly : Marked

Friday : Marked

Operation time

Hourly : 0 (minutes)

Logging Time zone

Log only during the specified time zone: Marked

Time zone : 10:00 to 13:00

The following shows the operation timing in the setting example.

Every Friday

9:00 10:00 11:00 12:00 13:00 14:00

Time

Device data collection is executed.

Device data collection is not executed.

6 - 20 6 - 20

6 CELL SETTING

MELSOFT

(c) When using modem communication

The setting example in the case of modem communication is shown below.

Set the Operation Interval : Marked

Operation day

: Marked

Operation time

Hourly : 0 (minutes)

Telephone line connectivity time zone

Connect each time depending

: Marked

The following shows the operation timing in the setting example.

9:00 10:00 11:00

Time

Connection of telephone line

Device data collection is executed.

Disconnection of telephone line

6 - 21 6 - 21

6 CELL SETTING

MELSOFT

6.2.4 Setting of the Device Trigger tab

This section describes the setting of the <<Device Trigger>> tab for use of the logging function.

In the <<Device Trigger>> tab, set the device conditions for the device trigger.

(1) <<Device Trigger>> tab

a) b)

Detailed

Item Description

Explanation

Set the Device Trigger Set when the device trigger is used. (2) (a) a) (Device conditions) b) (Preset cell areas)

Set the device conditions.

The settings of the cell areas preset to the Excel book are displayed.

(2) (b)

Section 6.2.1

6 - 22 6 - 22

When ON

ON

OFF

When OFF

ON

OFF

ON

ON

OFF

OFF

ON

OFF

6 CELL SETTING

< >

< =

> =

MELSOFT

(a) "Set the Device Trigger"

When using the device trigger, be sure to mark "Set the Device Trigger".

Set the device conditions for the device trigger.

Set the type of the device used for the device trigger.

Item Description

Bit Device

Word Device

Set when using a bit device for the device trigger.

Set when using a word device for the device trigger.

2) "Device"

Enter the device used for the device trigger.

Enter the device name and device number in this order.

Bit device

Word device

Bit device

Set the corresponding bit of the word device.

Setting range: 0 to 15

4) "Condition"

Set the device trigger condition.

Word device

Description

Set when operation is to be performed only once when the bit device turns on.

Set when operation is to be performed only once when the corresponding bit of the word device turns on (value: 1).

Set when operation is to be performed only once when the bit device turns off.

Set when operation is to be performed only once when the corresponding bit of the word device turns off (value: 0).

Bit device Set when operation is to be performed while the bit device is on.

Word device

Bit device

Word device

Set when operation is to be performed while the corresponding bit of the word device is on (value: 1).

Set when operation is to be performed while the bit device is off.

Set when operation is to be performed while the corresponding bit of the word device is off (value: 0).

Word device

Word device

Set when operation is to be performed when the device value is not equal to the "Value" setting.

Set when operation is to be performed when the device value is equal to or less than the "Value" setting.

Word device

Set when operation is to be performed when the device value is equal to or greater than the "Value" setting.

6 - 23 6 - 23

6 CELL SETTING

MELSOFT

5) "Value"

Enter the values used for "Condition".

Setting range: -32768 to 32767

<When "Range" has been set in "Condition">

When "Range" has been set in "Condition", enter the values in

"Value" as shown below.

Enter the upper limit value of the range.

Enter the lower limit value of the range.

6 - 24 6 - 24

6 CELL SETTING

MELSOFT

6.2.5 Setting of the Handshake tab

This section describes the setting of the <<Handshake>> tab for use of the logging function.

In the <<Handshake>> tab, set the handshake requesting source and handshake processing.

tab

a) b) c)

Detailed

Item Description

Explanation

Set Handshake Set when using a handshake. a) (Requesting source setting) Set the requesting source of the handshake. b) (Handshake processing) c) (Preset cell areas)

Set the handshake processing.

The settings of the cell areas preset to the Excel book are displayed.

(3) (a)

(3) (b)

(3) (c)

Section 6.2.1

6 - 25 6 - 25

6 CELL SETTING

MELSOFT

(2) Setting examples and operation timing

The following shows the handshake setting examples and operation timing.

(a) When "Start with the request from the PLC" is selected

(Device: Bit device)

<Setting example>

Set Handshake

Start with the request from the PLC

Responding device on the PC side

Bit device

Device

Value

Requesting device on the PLC side

: Marked

: Marked

: Marked

: M100

: ON

Bit device : Marked

Device

Condition

Monitoring time

: M0

: When ON

: 10 seconds

<Operation timing>

ON

M100

(Responding device on the PC side)

OFF

3)

2)

Device data collection

M0

(Requesting device on the PLC side)

ON

OFF

1)

4)

Time-out monitoring

(Monitoring time)

1) When M0 turns on, processing in 2) is started.

2) Device data is collected.

3) After device data is collected, M100 is turned on.

4) M0 is turned off.

5) M100 is turned off.

5)

6 - 26 6 - 26

6 CELL SETTING

MELSOFT

(b) When "Start with the request from the PLC" is selected

(Device: Word device)

<Setting example>

Set Handshake

Start with the request from the PLC

Responding device on the PC side

Word device

Device

Value

Requesting device on the PLC side

Word device

Device

Condition

Value

Monitoring time

: Marked

: Marked

: Marked

: D200

: 1 (left), 0 (right)

: Marked

: D100

: =

: 100

: 10 seconds

<Operation timing>

D200

(Responding device on the PC side)

D100

(Requesting device on the PLC side)

3)

1

5)

0

2)

Device data collection

1) 4)

100

Time-out monitoring

(Monitoring time)

1) When the D100 value reaches 100, processing in 2) is started.

2) Device data is collected.

3) After device data is collected, the D200 value is changed to 1.

4) The D100 value is changed to other than 100.

5) The D200 value is changed to 0.

6 - 27 6 - 27

6 CELL SETTING

MELSOFT

(c) When "Start with the request from the PC" is selected (Device:

Bit device)

<Setting example>

Set Handshake

Start with the request from the PC

Requesting device on the PC side

Bit device

Device

Value

Responding device on the PLC side

Bit device

Device

Condition

Monitoring time

: Marked

: Marked

: Marked

: M100

: ON

: Marked

: M0

: When ON

: 10 seconds

<Operation timing>

M100

(Requesting device on the PC side)

ON

OFF

1)

4)

3)

Device data collection

M0

(Responding device on the PLC side)

ON

OFF

2)

Time-out monitoring

(Monitoring time)

1) M100 is turned on.

2) When M0 turns on, processing in 3) is started.

3) Device data is collected.

4) After device data is collected, M100 is turned off.

5) M0 is turned off.

5)

REMARK

Time-out monitoring is not executed between 4) and 5) above.

If the operation in 5) is not performed in the PLC, device data collection is not executed when the handshake conditions are satisfied at the next time.

6 - 28 6 - 28

6 CELL SETTING

MELSOFT

(d) When "Start with the request from the PC" is selected (Device:

Word device)

<Setting example>

Set Handshake

Start with the request from the PC

Requesting device on the PC side

Word device

Device

Value

Responding device on the PLC side

Word device

Device

Condition

Value

Monitoring time

: Marked

: Marked

: Marked

: D200

: 1 (left), 0 (right)

: Marked

: D100

: =

: 100

: 10 seconds

<Operation timing>

D200

(Requesting device on the PC side)

1)

1

3)

Device data collection

4)

0

D100

(Responding device on the PLC side)

2)

5)

100

Time-out monitoring

(Monitoring time)

1) The D200 value is changed to 1.

2) When the D100 value reaches 100, processing in 3) is started.

3) Device data is collected.

4) After device data is collected, the D200 value is changed to 0.

5) The D100 value is changed to other than 100.

REMARK

Time-out monitoring is not executed between 4) and 5) above.

If the operation in 5) is not performed in the PLC, device data collection is not executed when the handshake conditions are satisfied at the next time.

6 - 29 6 - 29

6 CELL SETTING

MELSOFT

When using a handshake, be sure to mark "Set Handshake".

(b) Requesting source setting

Set the requesting source for a device data collection start.

Item Description

Start with the request from the PLC

Start with the request from the PC

Set when starting device data collection at the request of the PLC.

Set when starting device data collection at the request of the personal computer.

Set the handshake processing on the personal computer side and PLC side.

1) PC side processing

• Device type

Set the device type used for PC side processing.

Item Description

Bit device

Word device

Set when a bit device is used for PC side processing.

Set when a word device is used for PC side processing.

• "Device"

Enter the device used for PC side processing.

Enter the device name and device number in this order.

When specifying a bit of the word device, enter the bit number in "the bit".

• "Value"

Set the value of the device used for PC side processing.

ON

OFF

Empty (Value input)

Bit device

Word device (Bit specification)

Bit device

Word device (Bit specification)

Word device

Description

Set when the value of the device used for PC side processing is set for ON.

Set when the value of the device used for PC side processing is set for OFF.

Set the value of the word device used for PC side processing.

6 - 30 6 - 30

6 CELL SETTING

ON

OFF

MELSOFT

2) PLC side processing

• Device type

Set the device type used for PLC side processing.

Item Description

Bit device

Word device

Set when a bit device is used for PLC side processing.

Set when a word device is used for PLC side processing.

• "Device"

Enter the device used for PLC side processing.

Enter the device name and device number in this order.

When specifying the bit use of the word device, enter the bit number in "the bit".

• "Condition"

Set the conditions of the device used for PLC side processing.

Description

Bit device

Word device

(Bit specification)

Bit device

Word device

(Bit specification)

Set when the value of the device used for PLC side processing is set for ON.

Set when the value of the device used for PLC side processing is set for OFF.

• "Value"

Set the value of the device used for PLC side processing.

This can be set only when "=" has been selected in "Condition".

Set the time during which the PC side device monitors the PLC side device.

Setting range: 1 to 3600

The monitoring time changes depending on the requesting source setting.

The following table indicates the monitoring time.

Requesting Source Setting

Start with the request from the

PLC

Start with the request from the

PC

Monitoring time

Monitoring is executed from the time when the PC side responding device is set to the time when the PLC side requesting device is reset. If the PLC side responding device is not reset after the elapse of the monitoring time, the collected device data is discarded and the error log is displayed in the ErrorLog sheet.

Monitoring is executed from the time when the PC side requesting device is set to the time when the PLC side responding device is set. If the PLC side requesting device is not set after the elapse of the monitoring time, the error log is displayed in the ErrorLog sheet.

6 - 31 6 - 31

6 CELL SETTING

MELSOFT

(4) Sample ladders for handshake

The following is the sample ladders for handshake used in the setting examples in (2).

(a) When "Start with the request from the PLC" is selected

(Device: Bit device)

6 - 32 6 - 32

6 CELL SETTING

MELSOFT

(b) When "Start with the request from the PLC" is selected

(Device: Word device)

(c) When "Start with the request from the PC" is selected (Device:

Bit device)

6 - 33 6 - 33

6 CELL SETTING

MELSOFT

(d) When "Start with the request from the PC" is selected (Device:

Word device)

6 - 34 6 - 34

6 CELL SETTING

MELSOFT

6.2.6 Setting of the CSV Logging tab

This section describes the setting of the <<CSV Logging>> tab for use of the logging function.

In the <<CSV Logging>> tab, the file name and the saving contents with which logging data is saved to CSV file.

(1) <<CSV Logging>> tab

a)

Detailed

Item Description

Explanation

Save as CSV file

Contents to save

Set when using the CSV logging.

Set when adding the device name to the first line.

(2) (a)

(2) (b)

No. of lines to be saved

File name to save a) (Preset cell areas)

Set the number of lines to be saved.

Set the file name to save.

The settings of the cell areas preset to the Excel book are displayed.

(2) (c)

(2) (d)

Section 6.2.1

6 - 35 6 - 35

6 CELL SETTING

MELSOFT

(a) "Save as CSV file"

When using the CSV logging, be sure to mark "Save as CSV file".

(b) "Contents to save"

Activate this setting when adding the device name to the first line of the data to be saved into a CSV file.

Device name is added to first line.

If 0.1 to 0.9 seconds are set to the "Regular interval" on the <<Operation

Interval>> tab, the date and time to be written to the CSV file will be in the

"yyyy/mm/dd hh:mm:ss" format.

(Example) When 0.2 seconds interval is set

(c) "No. of lines to be saved"

Set the number of lines to be saved into a single CSV file.

Setting range: 1 to 9999999 *1

*1: Set any of 1 to 65535 when using the CSV file on Excel.

6 - 36 6 - 36

6 CELL SETTING

MELSOFT

(d) "File name to save"

Set the CSV file name to save.

Item Description

File name to save Sets the saving location and file name of the CSV file. *

1

Adds the date and time data to the file name set in "File name to save" and saves it.

In CSV logging, data is added until the data in the CSV file reach the number of lines set in "No. of lines to be saved".

When they reach the set number of lines, a new CSV file is created.

The following shows the file name when data are saved.

*****20020523183536.csv

Add date and time to File name

Seconds

Add sequential number to

File name

Minutes

Hours

Day

Month

Year

File name set in "File name to save"

Adds the file number to the file name set in "File name to save" and saves it.

The serial number can be set in a range from 000 to 999.

When the number reaches the last, the data of the next file are overwritten to the file of the first number.

In CSV logging, data is added until the data in the CSV file reach the number of lines set in "No. of lines to be saved".

When they reach the set number of lines, a new CSV file is created.

The following shows the file name when data are saved.

*****000.csv

Fix the File name

File number

File name set in "File name to save"

Overwrites data to the CSV file set in "File name to save".

In CSV logging, data is added until the data in the CSV file reach the number of lines set in

"No. of lines to be saved".

*1: A UNC path name (\\server name\path name) cannot be specified as a file name. After assigning the network drive, specify the path name.

6 - 37 6 - 37

6 CELL SETTING

MELSOFT

6.3 When Monitor Is Selected

<<Use>> tab

This section describes the "Cell Setting" dialog box when "Monitor" is selected from

"Use" of the <<Use>> tab.

<<Access Data>> tab

Required setting

Refer to Section

6.3.1.

Required setting

Refer to Section

6.3.2.

<<Operation Interval>> tab

Required setting

Refer to Section

6.3.3.

<<Device Trigger>> tab

Set as necessary

Refer to Section

6.3.4.

<<Handshake>> tab

Set as necessary

Refer to Section

6.3.5.

<<CSV Logging>> tab

Set as necessary

Refer to Section

6.3.6.

6 - 38 6 - 38

6 CELL SETTING

MELSOFT

6.3.1 Setting of the Use tab

This section describes the setting of the <<Use>> tab for use of the monitor function.

In the <<Use>> tab, set the cell area and monitor data display direction. a)

Detailed

Item Description

Explanation

Use

Cell Area Name

Cell Display Direction a) (Preset cell areas)

Set the function to be used for the specified cell area. Choose "Monitor" when using the monitor function.

Set the name of the specified cell area.

(Maximum number of cell area names : 1000)

Cell Area

Set the Color of Grid line

Enter the value to specify the cell area.

Set whether the specified cell area is provided with grid lines (including color designation) or not.

Set the Color for Filling Set whether the specified cell area is colored or not.

Clear cell area at the start of communication

When "Clear cell area at the start of communication" has a check mark, the data in the cell area specified at the start of communication is cleared.

(Default: no check)

Set the monitor data display sequence.

• Left to Right

Monitor data are displayed from left to right in the specified cell area in order.

• Top to Bottom

Monitor data are displayed from top to bottom in the specified cell area in order.

The settings of the cell areas preset to the Excel book are displayed.

(2) (a)

Section 6.2.1

(2) (b)

(2) (c)

Section 6.2.1

6 - 39 6 - 39

6 CELL SETTING

MELSOFT

With the exception of the following items, the setting of the <<Use>> tab for use of the monitor function is the same as that of the <<Use>> tab for use of the logging function.

Refer to Section 6.2.1 for details.

Set the cell area to be used by the monitor function.

Refer to Section 6.2.1 for the "Cell Area" setting examples.

The following indicates the possible setting ranges of the cell area and number of specified cell areas.

Number of cells : 2000

Number of specified cell areas : 16

(b) "Clear cell area at the start of communication"

Set whether the cell area will be cleared or not at the start of communication.

1) Display example in the case where "Clear cell area at the start of communication" is checked

< Before the start of communication >

1005

1002

990

35

30

36

102

200

151

10

15

25

< At the start of communication >

< At the completion of the first collection >

910

880

925

33

34

31

111

180

135

15

22

18

6 - 40 6 - 40

6 CELL SETTING

MELSOFT

2) Display example in the case where "Clear cell area at the start of communication" is not checked

< Before the start of communication >

1005

1002

990

35

30

36

102

200

151

< At the start of communication >

1005

1002

990

35

30

36

102

200

151

< At the completion of the first collection >

10

15

25

10

15

25

910

880

925

33

34

31

(c) "Cell Display Direction"

Set the monitor data display sequence.

1) When "Left to Right" is selected

<When cell area (B2:D5) is set to "Left to Right">

111

180

135

15

22

18

7

10

1

4

8

11

2

5

9

12

3

6

Monitor data are displayed in order of 1 to 12.

2) When "Top to Bottom" is selected

<When cell area (B2:D5) is set to "Top to Bottom ">

3

4

1

2

5

6

7

8

9

10

11

12

Monitor data are displayed in order of 1 to 12.

6 - 41 6 - 41

6 CELL SETTING

MELSOFT

6.3.2 Setting of the Access Data tab

This section describes the setting of the <<Access Data>> tab for use of the monitor function.

In the <<Access Data>> tab, set the logical station number required for communication with the PLC and the device data to be collected in the cell area.

(1) <<Access Data >> tab

a) b) c)

Detailed

Item Description

Explanation

Logical Station Number

Select the logical station number required for making communication.

Communication settings

Remote password *1 a) (Access data) b) (Number of set devices) c) (Preset cell areas)

Used to start the Communication Setup Utility to set a new logical station number and change the settings.

Enter the password when the password has been set to the connection target PLC.

Set the devices to be monitored.

Section 6.2.2

The number of devices currently set is displayed.

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

*1: "Remote password" is displayed when the logical station number selected in "Logical Station Number" of the <<Access

Data>> tab is the one for the password function compatible module.

The setting of the <<Access Data>> tab for use of the monitor function is the same as that of the <<Access Data>> tab for use of the logging function.

Refer to Section 6.2.2 for details.

6 - 42 6 - 42

6 CELL SETTING

MELSOFT

6.3.3 Setting of the Operation Interval tab

This section describes the setting of the <<Operation Interval>> tab for use of the monitor function.

In the <<Operation Interval>> tab, set the day, time and time zone of the activation of the function for the cell area.

(1) <<Operation Interval>> tab

a)

Set the Operation Interval Set the operation of the cell area valid or invalid.

Operation day

Operation time

Set the operation day of the monitor function activation.

Set the operation time of the monitor function activation.

Section 6.2.3

(2) (a)

Telephone line connectivity time zone *1

Set the telephone line connection timing and disconnection timing. Section 6.2.3 a) (Preset cell areas) The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

*1: "Telephone line connectivity time zone" is displayed when the logical station number selected in "Logical Station

Number" of the <<Access Data>> tab is the one for modem communication.

(2) Detailed explanation

With the exception of the following item, the setting of the <<Operation Interval>> tab for use of the monitor function is the same as the setting of the <<Operation

Interval>> tab for use of the logging function.

Refer to Section 6.2.3 for details.

The setting except for "Regular interval" is the same as that of the logging function.

Refer to Section 6.2.3 for the setting except for "Regular interval".

1) When "Regular interval" is selected

Device data is collected at the set second intervals.

When modem communication is used and "Telephone line connectivity time zone" is set to "Connect each time depending on the operation interval", set "Regular interval" to 30 seconds or more.

Setting range: 0.1 to 0.9 (in units of 0.1 seconds), 1 to 3600 (in units of 1 second)

6 - 43 6 - 43

6 CELL SETTING

MELSOFT

6.3.4 Setting of the Device Trigger tab

This section describes the setting of the <<Device Trigger>> tab for use of the monitor function.

In the <<Device Trigger>> tab, set the device conditions for the device trigger.

(1) <<Device Trigger>> tab

a) b)

Detailed

Item Description

Explanation

Set the Device Trigger Set when the device trigger is used.

Section 6.2.4 a) (Device conditions) b) (Preset cell areas)

Set the device conditions.

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

The setting of the <<Device Trigger>> tab for use of the monitor function is the same as that of the <<Device Trigger>> tab for use of the logging function.

Refer to Section 6.2.4 for details.

6 - 44 6 - 44

6 CELL SETTING

MELSOFT

6.3.5 Setting of the Handshake tab

This section describes the setting of the <<Handshake>> tab for use of the monitor function.

In the <<Handshake>> tab, set the handshake requesting source and handshake processing.

tab

a) b) c)

Detailed

Item Description

Explanation

Set Handshake Set when using a handshake. a) (Requesting source setting) Set the requesting source of the handshake.

Section 6.2.5 b) (Handshake processing) c) (Preset cell areas)

Set the handshake processing.

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

The setting of the <<Handshake>> tab for use of the monitor function is the same as that of the <<Handshake>> tab for use of the logging function.

Refer to Section 6.2.5 for details.

6 - 45 6 - 45

6 CELL SETTING

MELSOFT

6.3.6 Setting of the CSV Logging tab

This section describes the setting of the <<CSV Logging>> tab for use of the monitor function.

In the <<CSV Logging>> tab, set the file name and the saving contents with which the monitor data is saved into the CSV file.

(1) <<CSV Logging>> tab

a)

Detailed

Item Description

Explanation

Save as CSV file

Contents to save

Set when using the CSV logging.

Set when adding the device name to the first line.

Section 6.2.6

No. of lines to be saved

File name to save a) (Preset cell areas)

Set the number of lines to be saved.

Set the file name to save.

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

The setting of the <<CSV Logging>> tab for use of the monitor function is the same as that of the <<CSV Logging>> tab for use of the logging function.

Refer to Section 6.2.6 for details.

6 - 46 6 - 46

6 CELL SETTING

MELSOFT

6.4 When Write Is Selected

<<Use>> tab

This section describes the "Cell Setting" dialog box when "Write" is selected from "Use" of the <<Use>> tab.

<<Access Data>> tab

Required setting

Refer to Section

6.4.1.

Required setting

Refer to Section

6.4.2.

<<Operation Interval>> tab

Required setting

Refer to Section

6.4.3.

<<Device Trigger>> tab

Set as necessary

Refer to Section

6.4.4.

<<Handshake>> tab

Set as necessary

Refer to Section

6.4.5.

6 - 47 6 - 47

6 CELL SETTING

MELSOFT

6.4.1 Setting of the Use tab

This section describes the setting of the <<Use>> tab for use of the write function.

In the <<Use>> tab, set the cell area and display direction of written data. a)

Use

Cell Area Name

Cell Area

Detailed

Item Description

Explanation

Set the function to be used for the specified cell area. Choose "Write" when using the write function.

Set the Color of Grid line

Set the Color for Filling

Clear cell area at the start of communication

Cell Display Direction a) (Preset cell areas)

Set the name of the specified cell area.

(Maximum number of cell area names : 1000)

Enter the value to specify the cell area.

Set whether the specified cell area is provided with grid lines (including color designation) or not.

Set whether the specified cell area is colored or not.

When "Clear cell area at the start of communication" has a check mark, the data in the cell area specified at the start of communication is cleared.

(Default: no check)

Set the input cells for the write data.

• Left to Right

Write data are set from left to right in the specified cell area in order.

• Top to Bottom

Write data are set from top to bottom in the specified cell area in order.

The settings of the cell areas preset to the Excel book are displayed.

(2) (a)

Section 6.2.1

Section 6.3.1

(2) (b)

Section 6.2.1

6 - 48 6 - 48

6 CELL SETTING

MELSOFT

With the exception of the following items, the setting of the <<Use>> tab for use of the write function is the same as that of the <<Use>> tab for use of the logging function.

Refer to Section 6.2.1 for details.

(a) The "Cell Area"

Set the cell area to be used by the write function.

Refer to Section 6.2.1 for the "Cell Area" setting examples.

The following indicates the possible setting ranges of the cell area and number of specified cell areas.

Number of cells : 2000

Number of specified cell areas : 16

(b) "Cell Display Direction"

Set the written data cell sequence.

1) When "Left to Right" is selected

<When cell area (B2:D5) is set to "Left to Right">

7

10

1

4

8

11

2

5

9

12

3

6

Cell sequence is set in order of 1 to 12.

2) When "Top to Bottom" is selected

<When cell area (B2:D5) is set to "Top to Bottom ">

3

4

1

2

5

6

7

8

9

10

11

12

Cell sequence is set in order of 1 to 12.

6 - 49 6 - 49

6 CELL SETTING

MELSOFT

6.4.2 Setting of the Access Data tab

This section describes the setting of the <<Access Data>> tab for use of the write function.

In the <<Access Data>> tab, set the logical station number required for communication with the PLC and the device data to be written from the cell area.

(1) <<Access Data>> tab

a) b) c)

Detailed

Item Description

Explanation

Logical Station Number Select the logical station number required for making communication.

Communication settings

Remote password *1 a) (Access data) b) (Number of set devices) c) (Preset cell areas)

Used to start the Communication Setup Utility to set a new logical station number and change the settings.

Enter the password when the password has been set to the connection target PLC.

Set the devices where data will be written.

Section 6.2.2

(2) (a)

The number of devices currently set is displayed. Section 6.2.2

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

*1: "Remote password" is displayed when the logical station number selected in "Logical Station Number" of the <<Access

Data>> tab is the one for the password function compatible module.

6 - 50 6 - 50

6 CELL SETTING

MELSOFT

With the exception of the following item, the setting of the <<Access Data>> tab for use of the write function is the same as that of the <<Access Data>> tab for use of the logging function.

Refer to Section 6.2.2 for details.

The setting except for "Zoom" is the same as that of the logging function.

Refer to Section 6.2.2 for the setting except for "Zoom".

1) "Zoom"

The value entered into the cell is multiplied by the zoom ratio and written to the PLC device.

When "Data Type" has been set to "Bit" or "Character string", the

"Zoom" setting is not possible.

When the "Value" is set to "HEX", the "Zoom" setting is not possible.

Setting range: 0.001 to 1000

Excel

Set "Zoom" to "0.1".

PLC

D0

100

Enter 1000 into cell.

100 is written to PLC.

POINT

When "Zoom" is set for the write data and fractional decimals occurs in the data to be actually written to PLC, set "Real number" in "Data type".

6 - 51 6 - 51

6 CELL SETTING

MELSOFT

6.4.3 Setting of the Operation Interval tab

This section describes the setting of the <<Operation Interval>> tab for use of the write function.

In the <<Operation Interval>> tab, set the day, time and time zone of the activation of the function for the cell area will be activated.

(1) <<Operation Interval>> tab

a)

Set the Operation Interval Set the operation of the cell area valid or invalid.

Operation day

Operation time

Set the operation day of the write function activation.

Set the operation time of the write function activation.

Telephone line connectivity time zone *1 a) (Preset cell areas)

Set the telephone line connection timing and disconnection timing.

The settings of the cell areas preset to the Excel book are displayed.

Section 6.2.3

(2) (a)

Section 6.2.3

Section 6.2.1

*1: "Telephone line connectivity time zone" is displayed when the logical station number selected in "Logical Station

Number" of the <<Access Data>> tab is the one for modem communication.

explanation

With the exception of the following item, the setting of the <<Operation Interval>> tab for use of the write function is the same as that of the <<Operation Interval>> tab for use of the logging function.

Refer to Section 6.2.3 for details.

The setting except for "Regular interval" is the same as the that of the logging function.

Refer to Section 6.2.3 for the setting except for "Regular interval".

1) When "Regular interval" is selected

Device data is collected at the set second intervals.

When modem communication is used and "Telephone line connectivity time zone" is set to "Connect each time depending on the operation interval", set "Regular interval" to 30 seconds or more.

Setting range: 0.1 to 0.9 (in units of 0.1 seconds), 1 to 3600 (in units of 1 second)

6 - 52 6 - 52

6 CELL SETTING

MELSOFT

6.4.4 Setting of the Device Trigger tab

This section describes the setting of the <<Device Trigger>> tab for use of the write function.

In the <<Device Trigger>> tab, set the device conditions for the device trigger.

(1) <<Device Trigger>> tab

a) b)

Detailed

Item Description

Explanation

Set the Device Trigger Set when the device trigger is used.

Section 6.2.4 a) (Device conditions) b) (Preset cell areas)

Set the device conditions.

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

The setting of the <<Device Trigger>> tab for use of the write function is the same as that of the <<Device Trigger>> tab for use of the logging function.

Refer to Section 6.2.4 for details.

6 - 53 6 - 53

6 CELL SETTING

MELSOFT

6.4.5 Setting of the Handshake tab

This section describes the setting of the <<Handshake>> tab for use of the write function.

In the <<Handshake>> tab, set the handshake requesting source and handshake processing.

tab

a) b) c)

Detailed

Item Description

Explanation

Set Handshake Set when using a handshake. a) (Requesting source setting) Set the requesting source of the handshake. b) (Handshake processing) c) (Preset cell areas)

Set the handshake processing.

The settings of the cell areas preset to the Excel book are displayed.

Section 6.2.5

Section 6.2.1

The setting of the <<Handshake>> tab for use of the write function is the same as that of the <<Handshake>> tab for use of the logging function.

Refer to Section 6.2.5 for details.

6 - 54 6 - 54

6 CELL SETTING

MELSOFT

6.5 When Alarm Summary Is Selected

<<Use>> tab

This section describes the "Cell Setting" dialog box when "Alarm summary" is selected from "Use" of the <<Use>> tab.

<<Access Data>> tab

Required setting

Refer to Section

6.5.1.

Required setting

Refer to Section

6.5.2.

<<Alarm Data>> tab

Set as necessary

Refer to Section

6.5.3.

<<Operation Interval>> tab

Set as necessary

Refer to Section

6.5.4.

<<Device Trigger>> tab

Set as necessary

Refer to Section

6.5.5.

6 - 55 6 - 55

6 CELL SETTING

MELSOFT

6.5.1 Setting of the Use tab

This section describes the setting of the <<Use>> tab for use of the alarm summary function.

In the <<Use>> tab, set the cell area, display position of alarm data and operation in the case where cell is full. a)

Use

Cell Area Name

Cell Area

Set the Color of Grid line

Set the Color for Filling

Clear cell area at the start of communication

New data location

Displayed Contents

Set the function to be used for the specified cell area. Choose "Alarm summary" when using the alarm summary function.

Set the name of the specified cell area.

(Maximum number of cell area names : 100)

Enter the value to specify the cell area.

Set whether the specified cell area is provided with grid lines (including color designation) or not.

Set whether the specified cell area is colored or not.

When "Clear cell area at the start of communication" has a check mark, the data in the cell area specified at the start of communication is cleared.

(Default: check)

Set the latest data display position of the alarm summary.

• Last Line

The latest data is displayed at the last of the specified cell area.

• First Line

The latest data is displayed at the first of the specified cell area.

Set whether the title, elapsed time, and number of occurrences will be added to the Alarm Summary or not.

(2) (a)

Section 6.2.1

(2) (b)

(To the next page)

6 - 56 6 - 56

6 CELL SETTING

MELSOFT

Operating when cell is full a) (Preset cell areas)

Set the operation to be performed when the specified cell area is full.

• To scroll

The displayed contents are scrolled and displayed.

• Display from the first without clearing the cell area

The data currently displayed in the cell area are overwritten and the alarm summary is resumed.

Before the alarm summary is resumed, the Excel sheet can be printed and saved.

• Display from the first after clearing the cell area

The data displayed in the cell area are erased and the alarm summary is resumed.

Before the alarm summary is resumed, the Excel sheet can be printed and saved.

The settings of the cell areas preset to the Excel book are displayed.

Section 6.2.1

Section 6.2.1

With the exception of the following item, the setting of the <<Use>> tab for use of the alarm summary function is the same as that of the <<Use>> tab for use of the logging function.

Refer to Section 6.2.1 for details.

Set the cell area to be used by the alarm summary function.

Refer to Section 6.2.1 for the "Cell Area" setting examples.

The following indicates the possible setting ranges of the cell area and number of specified cell areas.

Number of cells : 4 columns (indispensable) 65536 rows

Number of specified cell areas : 16

*1: When displaying the elapsed time and number of occurrences in the Alarm Summary, increase the number of columns by 1, respectively. 6 columns are required to display both.

1) "Add title" check box

Set whether the title for the column item indicated in the following table will be displayed or not on the first line of the set "Cell Area".

When displaying the title, check the check box.

Title Column item

On time String/Off time String (Refer to Section 6.5.3)

The On time String is displayed when the device turns from OFF to ON, or the Off time String is displayed when the device turns from ON to OFF.

Date and time when the device turns from OFF to ON or from ON to OFF

Alarm String set to the device (Refer to Section 6.5.3)

Status String set to the device (Refer to Section 6.5.3)

Elapsed time from when the device turns ON until it turns OFF (Refer to 2))

Number of times when the device turned from OFF to ON after the start of communication (Refer to 3))

ON/OFF

Date time

Alarm

Status

Elapsed time

Number of occurrences

6 - 57 6 - 57

6 CELL SETTING

MELSOFT

POINT

• The title display line will not be the target of cell area clear at the start of communication or clear when cell is full.

• When the Cell Area is set at multiple locations, the title is displayed for only the

Cell Area specified first.

2) "Add elapsed time" check box

Set whether the elapsed time from when the device set on the

<<Access Data>> tab turns ON until it turns OFF will be displayed in the Alarm Summary or not.

When displaying the elapsed time, check the check box.

The display format is "hour:minute:second".

POINT

(Example) Display when the elapsed time is 1 minute 25 seconds

0:01:25

• When the device is ON at the start of communication, the time from when communication starts until the device turns OFF is displayed as the elapsed time.

3) "Add number of occurrences" check box

POINT

Set whether the number of times when the device set on the <<Access

Data>> tab turns from OFF to ON after the start of communication will be displayed in the Alarm Summary or not.

When displaying the number of occurrences, check the check box.

In this case, the "Clear cell area at the start of communication" check box must have been checked.

• When the device is ON at the start of communication, it is counted as the first alarm.

• When the number of occurrences exceeds 65535, it returns to 0.

<Display contents example on the Excel sheet when "Add title", "Add elapsed time", and "Add number of occurrences" are all checked>

ON/OFF Date time Alarm Status Elapsed time Number of occurrences

Generation 2004/05/24 Mon 15:05:20 Parts1 Abnormal fault Major failure

Generation 2004/05/24 Mon 15:05:31 Parts 2 Quantity error Minor failure

Restoration 2004/05/24 Mon 15:06:48 Parts1 Abnormal fault Major failure 0:01:28

1

1

1

Restoration 2004/05/24 Mon 15:07:52 Parts 2 Quantity error Minor failure 0:02:21 1

6 - 58 6 - 58

6 CELL SETTING

MELSOFT

6.5.2 Setting of the Access Data tab

This section describes the setting of the <<Access Data>> tab for use of the alarm summary function.

In the <<Access Data>> tab, set the logical station number required for communication with the PLC and the device data to be used for the alarm summary function.

(1) <<Access Data>> tab

a) b) c)

Detailed

Item Description

Explanation

Logical Station Number Select the logical station number required for making communication.

Communication settings

Remote password *1 a) (Access data) b) (Number of set devices) c) (Preset cell areas)

Used to start the Communication Setup Utility to set a new logical station number and change the settings.

Enter the password when the password has been set to the connection target PLC.

Set the devices use for the alarm summary function.

Section 6.2.2

(2) (a)

The number of devices currently set is displayed. (2) (b)

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

*1: "Remote password" is displayed when the logical station number selected in "Logical Station Number" of the <<Access

Data>> tab is the one for the password function compatible module.

6 - 59 6 - 59

6 CELL SETTING

MELSOFT

With the exception of the following items, the setting of the <<Access Data>> tab for use of the alarm summary function is the same as that of the <<Access

Data>> tab for use of the logging function.

Refer to Section 6.2.2 for details.

Data are displayed in the <<Alarm Data>> tab in the order of the numbers shown on the left of the <<Access Data>> tab.

Setting example of <<Access Data>> tab

Data numbers

The device data are displayed on the <<Alarm Data>> tab as shown below.

Data No. 1

Displayed in order of data numbers.

Data No. 2

Data No. 3

2) "Device"

Only the bit device can be specified for the alarm summary.

Enter the device name and device number in this order.

The points of the devices to be consecutively registered starting with the device number set in "Device" are displayed.

(b) The number of set devices

The number of device points registered to the cell area and the number of device points that can be registered are displayed.

Indicates the number of device points that can be registered to the cell area.

Indicates the number of device points that has been registered to the cell area.

6 - 60 6 - 60

6 CELL SETTING

MELSOFT

6.5.3 Setting of the Alarm Data tab

This section describes the setting of the <<Alarm Data>> tab for use of the alarm summary function.

In the <<Alarm Data>> tab, set the character strings to be displayed in the cell area.

(1) <<Alarm Data>> tab

a) b) a) (Alarm data) b) (Preset cell areas)

Set the alarm data to be used for the alarm summary function.

The settings of the cell areas preset to the Excel book are displayed.

(2) (a) to (e)

Section 6.2.1

explanation

(a) "Device"

The device registered to the <<Access Data>> tab is displayed.

(b) "ON time String"

Enter the character string to be displayed in the cell when the registered device turns on.

Number of characters: Up to 16

(c) "OFF time String"

Enter the character string to be displayed in the cell when the registered device turns off.

Number of characters: Up to 16

Enter an alarm character string.

Number of characters: Up to 40

Enter a status character string.

Number of characters: Up to 16

6 - 61 6 - 61

6 CELL SETTING

MELSOFT

The following shows the <<Alarm Data>> tab setting example and the data displayed on the Excel sheet.

<<Alarm Data>> tab setting example

Device

ON time String

OFF time String

Alarm String

Status String

:M0

: Generation

: Restoration

: Material storage

: Minor failure

<Operation of M0>

ON

1)

OFF

<Data displayed on Excel sheet>

2)

Displayed in order of "date and time of occurrence", "alarm character string" and

"status character string".

1) Displayed in the cell (when M0 is on).

2) Displayed in the cell (when M0 is off).

6 - 62 6 - 62

6 CELL SETTING

MELSOFT

6.5.4 Setting of the Operation Interval tab

This section describes the setting of the <<Operation Interval>> tab for use of the alarm summary function.

In the <<Operation Interval>> tab, set the operation interval for the function of the cell area.

(1) <<Operation Interval>> tab

a)

Regular interval

Telephone line connectivity time zone *1 a) (Preset cell areas)

Set the operation interval of the alarm summary function.

Set the telephone line connection timing and disconnection timing.

The settings of the cell areas preset to the Excel book are displayed.

(2) (a)

Section 6.2.3

Section 6.2.1

*1: "Telephone line connectivity time zone" is displayed when the logical station number selected in "Logical Station

Number" of the <<Access Data>> tab is the one for modem communication.

explanation

With the exception of the following item, the setting of the <<Operation Interval>> tab for use of the alarm summary function is the same as that of the <<Operation

Interval>> tab for use of the logging function.

Refer to Section 6.2.3 for details.

Device data is collected at the set second intervals.

Setting range: 0.1 to 0.9 (in units of 0.1 seconds), 1 to 3600 (in units of 1 second)

If 0.1 to 0.9 seconds are set to the "Regular interval" on the <<Operation

Interval>> tab, the ON/OFF time displayed on the Excel sheet will be in the

"yyyy/mm/dd ddd hh:mm:ss" format.

(Example) When 0.2 seconds interval is set and the ON time is 11 hours 5 minutes 2 seconds 80

6 - 63 6 - 63

6 CELL SETTING

MELSOFT

6.5.5 Setting of the Device Trigger tab

This section describes the setting of the <<Device Trigger>> tab for use of the alarm summary function.

In the <<Device Trigger>> tab, set the device conditions for the device trigger.

(1) <<Device Trigger>> tab

a) b)

Detailed

Item Description

Explanation

Set the Device Trigger Set when the device trigger is used.

Section 6.2.4

a) (Device conditions) b) (Preset cell areas)

Set the device conditions.

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

The setting of the <<Device Trigger>> tab for use of the alarm summary function is the same as that of the <<Device Trigger>> tab for use of the logging function.

Refer to Section 6.2.4 for details.

6 - 64 6 - 64

6 CELL SETTING

MELSOFT

6.6 When Comment Is Selected

<<Use>> tab

This section describes the "Cell Setting" dialog box when "Comment" is selected from

"Use" of the <<Use>> tab.

<<Access Data>> tab

Required setting

Refer to Section

6.6.1.

Required setting

Refer to Section

6.6.2.

<<Comment Data>> tab

Required setting

Refer to Section

6.6.3.

<<Operation Interval>> tab

Set as necessary

Refer to Section

6.6.4.

<<Device Trigger>> tab

Set as necessary

Refer to Section

6.6.5.

<<Handshake>> tab

Set as necessary

Refer to Section

6.6.6.

6 - 65 6 - 65

6 CELL SETTING

MELSOFT

6.6.1 Setting of the Use tab

This section describes the setting of the <<Use>> tab for use of the comment display function.

In the <<Use>> tab, set the cell area.

tab

a)

Use

Cell Area Name

Cell Area

Set the Color of Grid line

Set the Color for Filling

Clear cell area at the start of communication a) (Preset cell areas)

Set the function to be used for the specified cell area.

Choose "Comment" when using the comment display function.

Set the name of the specified cell area.

(Maximum number of cell area names : 500)

Enter the value to specify the cell area.

Set whether the specified cell area is provided with grid lines (including color designation) or not.

Set whether the specified cell area is colored or not.

When "Clear cell area at the start of communication" has a check mark, the data in the cell area specified at the start of communication is cleared.

(Default: no check)

The settings of the cell areas preset to the Excel book are displayed.

(2) (a)

Section 6.2.1

Section 6.3.1

Section 6.2.1

With the exception of the following item, the setting of the <<Use>> tab for use of the comment display function is the same as that of the <<Use>> tab for use of the logging function.

Refer to Section 6.2.1 for details.

Set the cell area to be used by the comment display function.

Setting range: 1

6 - 66 6 - 66

6 CELL SETTING

MELSOFT

6.6.2 Setting of the Access Data tab

This section describes the setting of the <<Access Data>> tab for use of the comment display function.

In the <<Access Data>> tab, set the logical station number required for communication with the PLC and the device data to be used for the comment display function.

(1) <<Access Data >> tab

a) b) c)

Detailed

Item Description

Explanation

Logical Station Number

Select the logical station number required for making communication.

Communication settings

Remote password *1 a) (Access data) b) (Number of set devices) c) (Preset cell areas)

Used to start the Communication Setup Utility to set a new logical station number and change the settings.

Enter the password when the password has been set to the connection target PLC.

Set the devices use for the comment display function.

Section 6.2.2

(2) (a)

The number of devices currently set is displayed. Section 6.2.2

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

*1: "Remote password" is displayed when the logical station number selected in "Logical Station Number" of the <<Access

Data>> tab is the one for the password function compatible module.

6 - 67 6 - 67

6 CELL SETTING

MELSOFT

With the exception of the following items, the setting of the <<Access Data>> tab for use of the comment display function is the same as that of the <<Access

Data>> tab for use of the logging function.

Refer to Section 6.2.2 for details.

1) "Device"

Set the device used for the comment display function.

Enter the device name and device number in this order.

Refer to Section 3.2 for the accessible devices.

Bit

Item

16 bit integer

(-32768 to 32767)

Set the data type of the device used for the comment display function.

Device That Can be

Specified

Description

Bit device

Word device

(Bit specification)

Bit device

Word device

32 bit integer

(-2147483648 to 2147483647)

Bit device

Word device

The bit devices set in "Device" are displayed in a single cell in units of one bit.

Designated bits for word device set in "Device" are displayed in a single cell in units of one bit (e.g. D0.0).

Set when 1 word (16 bits), starting from the device number set in

"Device", is used for the comment display function.

Set when the word device set in "Device" is used for the comment display function.

Set when 2 words (32 bits), starting from the device number set in "Device", are used for the comment display function.

Set when 2 words, starting from the device number set in

"Device", are used for the comment display function.

6 - 68 6 - 68

6 CELL SETTING

MELSOFT

6.6.3 Setting of the Comment Data tab

This section describes the setting of the <<Comment Data>> tab for use of the comment display function.

In the <<Comment Data>> tab, set the comment data to be displayed in the cell area.

(1) <<Comment Data>> tab

a) b)

Device

Data Type

Value

Detailed

Item Description

Explanation

The device set in "Device" of the <<Access Data>> tab is displayed. ----

The data type set in "Data Type" of the <<Access Data>> tab is displayed.

The contents set to the "Value" on the <<Access Data>> tab are displayed.

----

---- a) (Comment data) b) (Preset cell areas)

Set the comment data to be used for the comment display function.

The settings of the cell areas preset to the Excel book are displayed.

(2) (a)

Section 6.2.1

6 - 69 6 - 69

6 CELL SETTING

MELSOFT

1) "Range (Lower)" and "Range (Upper)"

Set the lower and upper limit values of the device.

The setting range changes depending on the data type.

The following table indicates the setting range of each data type.

Data Type

Bit

16 bit integer

32 bit integer

Setting Range

1 (ON), 0 (OFF)

-32768 to 32767

-2147483648 to 2147483647

Enter the comment character string to be displayed in the cell.

Number of characters: up to 40

Set the color of the comment character string displayed in the cell.

Depending on the specified colors, all colors may turn to gray.

Refer to the Operating Precautions for details.

POINT

If multiple comment data are set and their setting ranges are overlapped, the comment character string with the lowest data number is displayed.

Be sure to prevent double setting of the setting ranges.

6 - 70 6 - 70

6 CELL SETTING

MELSOFT

The following shows the setting examples in the cases where the data type is set to "Bit" and "16 bit integer".

(a) When data type is set to "Bit"

<<Comment data>> tab setting example

Operation of M0

1) 1)

ON

OFF

2)

1) While M0 is on, "Error occurrence" is displayed in the cell.

2) While M0 is off, "Normal operation" is displayed in the cell.

(b) When data type is set to "16 bit integer"

<<Comment data>> tab setting example

Operation of D0

1)

10000

2)

1500

1) If the D0 value is 10000 or more, "Temperature upper limit over" is

displayed in the cell.

2) If the D0 value is less than 10000, no comment character string is

displayed.

6 - 71 6 - 71

6 CELL SETTING

MELSOFT

6.6.4 Setting of the Operation Interval tab

This section describes the setting of the <<Operation Interval>> tab for use of the comment display function.

In the <<Operation Interval>> tab, set the day, time and time zone of the activation of the function for the cell area.

(1) <<Operation Interval>> tab

a)

Set the Operation Interval Set the operation of the cell area valid or invalid.

Operation day Set the operation day of the comment display function activation.

Operation time

Telephone line connectivity time zone *1 a) (Preset cell areas)

Set the operation time of the comment display function activation.

Set the telephone line connection timing and disconnection timing.

The settings of the cell areas preset to the Excel book are displayed.

Section 6.2.3

(2) (a)

Section 6.2.3

Section 6.2.1

*1: "Telephone line connectivity time zone" is displayed when the logical station number selected in "Logical Station

Number" of the <<Access Data>> tab is the one for modem communication.

(2) Detailed explanation

With the exception of the following item, the setting of the <<Operation Interval>> tab for use of the comment display function is the same as that of the

<<Operation Interval>> tab for use of the logging function.

Refer to Section 6.2.3 for details.

The setting except for "Regular interval" is the same as that of the logging function.

Refer to Section 6.2.3 for the setting except for "Regular interval".

1) When "Regular interval" is selected

Device data is collected at the set second intervals.

When modem communication is used and "Telephone line connectivity time zone" is set to "Connect each time depending on the operation interval", set "Regular interval" to 30 seconds or more.

Setting range: 0.5 to 0.9 (in units of 0.1 seconds), 1 to 3600 (in units of 1 second)

6 - 72 6 - 72

6 CELL SETTING

MELSOFT

6.6.5 Setting of the Device Trigger tab

This section describes the setting of the <<Device Trigger>> tab for use of the comment display function.

In the <<Device Trigger>> tab, set the device conditions for the device trigger.

(1) <<Device Trigger>> tab

a) b)

Detailed

Item Description

Explanation

Set the Device Trigger Set when the device trigger is used.

Section 6.2.4 a) (Device conditions) b) (Preset cell areas)

Set the device conditions.

The settings of the cell areas preset to the Excel book are displayed. Section 6.2.1

The setting of the <<Device Trigger>> tab for use of the comment display function is the same as that of the <<Device Trigger>> tab for use of the logging function.

Refer to Section 6.2.4 for details.

6 - 73 6 - 73

6 CELL SETTING

MELSOFT

6.6.6 Setting of the Handshake tab

This section describes the setting of the <<Handshake>> tab for use of the comment display function.

In the <<Handshake>> tab, set the handshake requesting source and handshake processing.

tab

a) b) c)

Detailed

Item Description

Explanation

Set Handshake Set when using a handshake. a) (Requesting source setting) Set the requesting source of the handshake. b) (Handshake processing) c) (Preset cell areas)

Set the handshake processing.

The settings of the cell areas preset to the Excel book are displayed.

Section 6.2.5

Section 6.2.1

The setting of the <<Handshake>> tab for use of the comment display function is the same as that of the <<Handshake>> tab for use of the logging function.

Refer to Section 6.2.5 for details.

6 - 74 6 - 74

6 CELL SETTING

MEMO

MELSOFT

6 - 75 6 - 75

7 AUTOMATIC SAVE SETTING

MELSOFT

7 AUTOMATIC SAVE SETTING

The following explains the setting contents for saving the Excel book or Excel sheet

(CSV format) during MX Sheet operation (hereafter abbreviated to the Automatic save setting data).

7.1 Operation of Automatic save list Dialog Box

In the "Automatic save list" dialog box, manage the automatic save conditions in the form of a list.

(1) Displaying "Automatic save list" dialog box

Choose [MX Sheet] [Automatic save list] (

(2) "Automatic save list" dialog box

) from the menu bar. a) b) c) d) e) a) Automatic save name list b) Create New

Display a list of automatic save names created in the "Automatic save" dialog box (refer to Section 7.2).

Create new automatic save setting data. c) Edit d) Delete e) Close

Change the contents of the existing automatic save setting data.

Delete the selected automatic save name from the automatic save name list.

Close the "Automatic save list" dialog box.

(3) (a)

(3) (b)

(3) (c)

(3) (d)

----

7

7 - 1 7- 1

7

7 AUTOMATIC SAVE SETTING

MELSOFT

(a) Automatic save name list

Enable

Item Description

Automatic save name

End of communication

Date time

Device trigger

Clear cell area

Check the one to be automatically saved.

Checked when new data is created.

Display the automatic save names created in the "Automatic save" dialog box.

Display whether the "Save at the end of communication" check box in the "Automatic save" dialog box is checked or not in the form of Settings or No settings.

Display whether the "Set the date and time" check box in the "Automatic save" dialog box is checked or not in the form of Settings or No settings.

Display whether the "Set the Device trigger" check box in the "Automatic save" dialog box is checked or not in the form of Settings or No settings.

Display whether the " Clear cell area after automatic save" check box in the "Automatic save" dialog box is checked or not in the form of Settings or No settings.

When Create New is clicked, the "Automatic save" dialog box is displayed. Refer to Section 7.2 for the setting operation.

7 - 2 7- 2

7 AUTOMATIC SAVE SETTING

MELSOFT

(c) Edit

In the setting of the selected automatic save name, the "Automatic save" dialog box is displayed. Refer to Section 7.2 for the setting operation.

POINT

When the automatic save name list is double-clicked or the Enter key is pressed with the clicked line highlighted, that operation has the same function as Edit .

(d) Delete

The selected automatic save name is deleted.

POINT

When the Delete key is pressed with the clicked line highlighted, that operation has the same function as Delete .

7 - 3 7- 3

7 AUTOMATIC SAVE SETTING

MELSOFT

7.2 Setting of the Automatic Save Dialog Box

In the "Automatic Save" dialog box, set the save timing and file name.

timing

The following 3 save timings are available for the automatic save setting. (All of them can be set at a time.)

• Automatic save is performed at the end of communication. (Detailed explanation: (4) (b))

• Automatic save is performed at a specified time. (Detailed explanation: (4) (c) to

(e))

• Automatic save is performed using the device trigger. (Detailed explanation: (4)

(f) to (g))

(2) Displaying "Automatic Save" dialog box

In the "Automatic save list" dialog box, click Create New or Edit .

(3) "Automatic Save" dialog box

a) b)

Automatic save name

Save at the end of communication

Set the date and time

Operation day

Manage the automatic save setting data with specific names.

Set when performing automatic save at the end of communication.

(4) (a)

(4) (b)

Set when performing automatic save at the specified date and time.

Set the operation day when automatic save is performed at the specified date and time.

(4) (c)

(4) (d)

(To the next page)

7 - 4 7- 4

7 AUTOMATIC SAVE SETTING

MELSOFT

Operation time

Set the device trigger a) (Device conditions)

Clear cell area after automatic save

Set the operation time when automatic save is performed at the specified date and time.

Set when performing automatic save using the device trigger.

Set the device conditions for the device trigger.

Make setting when clearing the cell area data after automatic save.

(4) (e)

(4) (f)

(4) (g)

(4) (h)

Specify the cell area name b) (Save file setting)

OK

From the list, select the cell area name that will be the target of "Clear cell area after automatic save".

(4) (i)

Set the file name to automatically save data. *

1

(4)

Register the newly created or edited "Automatic save name" to the

"Automatic save list" dialog box.

(4) (k)

*1: A UNC path name (\\server name\path name) cannot be specified as a file name. After assigning the network drive, specify the path name.

(a) "Automatic save name"

Attach specific names to the automatic save setting data.

Up to 50 automatic save names can be registered.

(b) "Save at the end of communication"

Set this when performing automatic save at the end of communication.

POINT

When "Clear cell area at the start of communication" has been checked on the

<<Use>> tab in the "Cell Settings" dialog box, MX Sheet clears the target cell area data at the start of communication and starts data collection.

To save the data at the end of communication, check "Save at the end of communication".

(c) "Set the date and time"

Set this when performing automatic save at the specified date and time.

7 - 5 7- 5

7 AUTOMATIC SAVE SETTING

MELSOFT

day"

Set the operation day of the automatic save function.

1) When "Daily" is selected

Save is performed every day.

2) When "Weekly" is selected

Save is performed on the specified day of the week only.

Multiple days of the week can be set.

3) When "Monthly" is selected

Save is performed on the specified days only.

If the specified day does not exist in some months, an alternate day can be specified.

Number of days that can be set: 31

<When "15th" is set>

Operation is performed on the 15th every month, e.g. January 15,

February 15, March 15.

<When "31st" is set>

Excepting February, April, June, September and November, operation is performed on the 31st every month.

For February, April, June, September and November, set the alternate day and processing in "Alternate day when a date does not exist".

The following table indicates the setting items of "Alternate day when a date does not exist".

No operation

Item Description

Last day of the current month

First day of the next month

Operation is performed on the last day of

February, April, June, September or November

Operation is performed on the first day of the next month.

Operation is not performed in February, April,

June, September and November

Set the operation time of automatic save.

1) When "Regular interval" is selected

The Excel book is saved at the set minute intervals.

Setting range: 1 to 1440

<When "Regular interval" is set to "5">

The Excel book is saved at intervals of 5 minutes, e.g. 8:05, 8:10,

8:15.

2) When "Hourly" is selected

Automatic save is performed at the specified minute every hour.

Number of times that can be set: 60

3) When "Time table" is selected

Automatic save is performed at the specified time.

Number of times that can be set: 50

(f) "Set the Device trigger"

Set this when performing automatic save using the device trigger.

Whether the device trigger conditions are satisfied or not is checked at intervals of 1 second.

7 - 6 7- 6

7 AUTOMATIC SAVE SETTING

When ON

ON

OFF

When OFF

ON

OFF

MELSOFT

1) "Logical Station Number"

Choose the logical station number used for the device trigger.

If the logical station number has already been set, the number appears in the list box and can be selected.

If the logical station number has not been set, click on

Communication Setting and set a new logical station number.

2) Communication Setting button

This button is used to start the Communication Setup Utility to set a new logical station number and change the settings.

Select "Run as administrator" when the screen appears asking if execute programs with administrator authority or not.

After starting the Communication Setup Utility, click on Wizard and set a new logical station number and change the settings with the

Communication Setting Wizard.

For the detailed explanation of the Communication Setup Utility and

Communication Setting Wizard, refer to the MX Component Operating

Manual.

"Remote password" box appears when the setting of the logical station number selected in "Logical Station Number" includes information on the connection to the module with the password function.

When the password has been set to the connection target PLC, enter the password.

It need not be entered when the password has not been set.

Set the type of the device used for the device trigger.

Item Description

Bit Device

Word Device

Set when using a bit device for the device trigger.

Set when using a word device for the device trigger.

5) "Device"

Enter the device used for the device trigger.

Enter the device name and device number in this order.

Set the corresponding bit of the word device.

Setting range: 0 to 15

7) "Condition"

Set the device trigger conditions.

Bit device

Word device

Bit device

Word device

Description

Set when automatic save is to be performed when the bit device turns on.

Set when automatic save is to be performed when the corresponding bit of the word device turns on (value: 1).

Set when automatic save is to be performed when the bit device turns off.

Set when automatic save is to be performed when the corresponding bit of the word device turns off (value: 0).

7 - 7 7- 7

7 AUTOMATIC SAVE SETTING

MELSOFT

(h) "Clear cell area after automatic save"

Set whether the data of the cell area selected in the "Specify the cell area name" will be cleared or not after automatic save is performed.

To clear the cell area data after automatic save, check the check box.

(i) "Specify the cell area name"

From the list box, select the "Cell Area Name" of the cell area whose data will be cleared after automatic save. (Multiple names can be selected.)

The list box displays all "Cell Area Names" set in the "Cell Settings" dialog box.

(j) Save file setting

1) "File name to save"

Set the storage location and file name of the Excel book to be saved automatically.

The Excel file (.xls, .xlsx*

1

, .xlsm*

1

, .xlsb*

1

) or HTML file (.htm)*

2

or

CSV file (.csv) is available as the file type.

*1: .xlsx, .xlsm, and .xlsb are Workbook-format extensions added to

Excel 2007 or later.

*2: For the continuous operation when saving data automatically in

HTML format, refer to APPENDIX 7.

2) "Specify the sheet name"

Select the sheet name to be saved from the combo box.

It can be specified only when the "File name to save" is a CSV file.

3) "Add date and time to File name"

The data and time data are added to the file name set in "File name to save".

The following indicates the file name format when data is saved.

*****20020523183536.extension

Extension set to "File name to save"

Seconds

Minutes

Hours

Day

Month

Year

File name set in "File name to save"

4) "Add sequential number to File name"

The file number is added to the file name set in "File name to save".

A serial number can be set within the range from 000 to 999.

When the number reaches the last, the data of the next file are overwritten to the file of the first number.

The following indicates the file name format when data is saved.

*****000.extension

Extension set in "File name to save"

File number

File name set in "File name to save"

5) "Fix the File name"

Data is overwritten to the file set in "File name to save".

7 - 8 7- 8

7 AUTOMATIC SAVE SETTING

MELSOFT

Register the newly created or edited automatic save setting data.

When the registration is completed, the automatic save name and settings are displayed as described below in the "Automatic save list" dialog box.

Edit

Operation

Create New

When automatic save name is changed

When automatic save name is the same

Display in "Automatic save list"

The automatic save name and settings are additionally displayed at the bottom of the list, and "enable" is checked.

The automatic save name and settings are additionally displayed at the bottom of the list, and "enable" is checked.

The automatic save name and settings are displayed in the same position of the list.

When the settings are changed, the new settings are displayed.

POINT

When registering the existing automatic save setting data under a different automatic save name, change the automatic save name in the "Automatic save" dialog box.

7 - 9 7- 9

8 AUTOMATIC PRINT SETTING

MELSOFT

8 AUTOMATIC PRINT SETTING

The following explains the setting contents for printing the Excel book or Excel sheet

(CSV format) during MX Sheet operation (hereafter abbreviated to the Automatic print setting data).

8.1 Operation of Automatic print list Dialog Box

In the "Automatic print list" dialog box, manage the automatic print conditions in the form of a list.

(1) Displaying "Automatic print list" dialog box

Choose [MX Sheet] [Automatic print list] (

) from the menu bar.

(2) "Automatic print list" dialog box

a) b) c) d) e)

8 a) Automatic print name list b) Create New

Display a list of automatic print names created in the "Automatic print" dialog box (refer to Section 8.2).

Create new automatic print setting data. c) Edit d) Delete e) Close

Change the contents of the existing automatic print setting data.

Delete the selected automatic print name from the automatic print name list.

Close the "Automatic print list" dialog box.

(3) (a)

(3) (b)

(3) (c)

(3) (d)

----

8 - 1 8 - 1

8 AUTOMATIC PRINT SETTING

MELSOFT

Enable

(a) Automatic print name list

Item Description

Automatic print name

End of communication

Date time

Device trigger

Clear cell area

Check the one to be automatic printed.

Checked when new data is created.

Display the automatic print names created in the "Automatic print" dialog box.

Display whether the "Print at the end of communication" check box in the "Automatic print" dialog box is checked or not in the form of Settings or No settings.

Display whether the "Set the date and time" check box in the "Automatic print" dialog box is checked or not in the form of Settings or No settings.

Display whether the "Set the Device trigger" check box in the "Automatic print" dialog box is checked or not in the form of Settings or No settings.

Display whether the "Clear cell area after automatic print" check box in the "Automatic print" dialog box is checked or not in the form of Settings or No settings.

When Create New is clicked, the "Automatic print" dialog box is displayed. Refer to Section 8.2 for the setting operation.

(c) Edit

In the setting of the selected automatic print name, the "Automatic print" dialog box is displayed. Refer to Section 8.2 for the setting operation.

POINT

When the automatic print name list is double-clicked or the Enter key is pressed with the clicked line highlighted, that operation has the same function as Edit .

(d) Delete

The selected automatic print name is deleted.

POINT

When the Delete key is pressed with the clicked line highlighted, that operation has the same function as Delete .

8

8 - 2 8 - 2

8 AUTOMATIC PRINT SETTING

MELSOFT

8.2 Setting of the Automatic Print Dialog Box

In the "Automatic Print" dialog box, set the print timing and print area.

The following 3 timings are available for the automatic print setting. (All of them can be set at a time.)

Refer to Chapter 7 for details.

• Automatic print is performed at the end of communication.

• Automatic print is performed at a specified time.

• Automatic print is performed using the device trigger.

(2) Displaying "Automatic Print" dialog box

In the "Automatic print list" dialog box, click Create New or Edit .

(3) "Automatic Print" dialog box

a)

Automatic print name

Print at the end of communication

Set the date and time

Operation day

Operation time

Set the device trigger a) (Device conditions)

Manage the automatic print setting data with specific names.

Set when performing automatic print at the end of communication.

(4) (a)

Set when performing automatic print at the specified date and time.

Set the operation day when automatic print is performed at the specified date and time.

Set the operation time when automatic print is performed at the specified date and time.

Set when performing automatic print using the device trigger.

Set the device conditions for the device trigger.

Section 7.1

(To the next page)

8 - 3 8 - 3

8 AUTOMATIC PRINT SETTING

MELSOFT

Clear cell area after automatic print

Specify the cell area name

Print Area

OK

Make setting when clearing the cell area data after automatic print.

From the list, select the cell area name that will be the target of "Clear cell area after automatic print".

Set the area where automatic print will be performed.

Register the newly created or edited "Automatic print name" to the

"Automatic print list" dialog box.

(4) (b)

(4) (c)

(4) (d)

(4) (e)

With the exception of the following items, the setting of the "Automatic Print" dialog box is the same as that of the "Automatic Save" dialog box.

Refer to Chapter 7 for details.

(a) "Automatic print name"

Attach specific names to the automatic print setting data.

Up to 50 automatic print names can be registered.

(b) "Clear cell area after automatic print"

Set whether the data of the cell area selected in the "Specify the cell area name" will be cleared or not after automatic print is performed.

To clear the cell area data after automatic print, check the check box.

(c) "Specify the cell area name"

From the list box, select the "Cell Area Name" of the cell area whose data will be cleared after automatic print. (Multiple names can be selected.)

The list box displays all "Cell Area Names" set in the "Cell Settings" dialog box.

Set the area where automatic print will be performed.

The entire Excel book (all sheets) where automatic print setting has been made is printed automatically.

2) "Specify the sheet"

Automatic print is executed for the specified sheet only.

Multiple sheets can be selected and printed simultaneously.

8 - 4 8 - 4

8 AUTOMATIC PRINT SETTING

MELSOFT

Register the newly created or edited automatic print setting data.

When the registration is completed, the automatic print name and settings are displayed as described below in the "Automatic print list" dialog box.

Edit

Operation

Create New

When automatic print name is changed

When automatic print name is the same

Display in "Automatic print list"

The automatic print name and settings are additionally displayed at the bottom of the list, and "enable" is checked.

The automatic print name and settings are additionally displayed at the bottom of the list, and "enable" is checked.

The automatic print name and settings are displayed in the same position of the list.

When the settings are changed, the new settings are displayed.

POINT

• When registering the existing automatic print setting data under a different automatic print name, change the automatic print name in the "Automatic print" dialog box.

• When multiple printers are set to a single personal computer, the Excel sheet where automatic print is set is output from the printer specified to "Set as Default" in [Printers] in [My Computer].

8 - 5 8 - 5

9 AUTOMATIC COMMUNICATION STARTUP SETTING

MELSOFT

9 AUTOMATIC COMMUNICATION STARTUP SETTING

This chapter describes the settings for starting communication with the PLC automatically at the start of the Excel book.

(1) Displaying "Automatic Communication Startup setting/Disabled" dialog box

Choose [MX Sheet] [Automatic Communication Startup setting] ( ) from the menu bar.

(a) Dialog boxes for "Automatic Communication Startup setting"

When the automatic communication startup setting has not been set to the

Excel book being edited, the following dialog box appears.

Click on Yes to set the automatic communication startup setting to the

Excel book being edited.

When the automatic communication startup setting has been made, communication with the PLC is started automatically at the start of the set

Excel book.

As the following dialog box appears, click on OK .

After editing the Excel book, restart the Excel book to make the automatic communication startup setting valid.

(b) "Automatic Communication Startup Disabled" dialog box

When the automatic communication startup setting has been set to the

Excel book being edited, the following dialog box appears.

Click on Yes to cancel the automatic communication startup setting of the

Excel book being edited.

9

9 - 1 9 - 1

9

9 AUTOMATIC COMMUNICATION STARTUP SETTING

MELSOFT

POINT

(1) For the automatic communication startup setting, do not save the Excel book under the hidden status. An error occurs when starting the Excel book and MX

Sheet cannot be used. In such case, save the Excel book under the display status, and restart Excel.

To display the Excel book, choose [Window] [Unhide] from the menu bar.

(2) When an Excel book on which the automatic communication startup has been set is opened with Excel 2007 or later, the following symptoms may occur.

• Excel does not respond.

• Either of the following errors occurs.

If the symptoms described above occur, refer to APPENDIX 9 and install the

COM add-in "MXShRibbon".

9 - 2 9 - 2

10 COMMUNICATION START AND COMMUNICATION END

MELSOFT

10 COMMUNICATION START AND COMMUNICATION END

This chapter describes the start and end of MX Sheet communication.

10.1 Communication Start

This section explains the procedure to start MX Sheet communication manually.

Choose [MX Sheet] [Start Communication] ( ) from the menu bar. (Excel

2003 or earlier)

Choose <<Add-Ins>> tab [MX Sheet] [Start Communication] ( ) (Excel

2007 or later).

Or, click the Start Communication Button (refer to Section 14.1).

(2) Explanation of "Start Communication" dialog box

Click on Yes to start communication between the Excel book being edited and the PLC and read/write device data. b)

(3) Display of Excel book and task bar during communication

The following shows how the Excel book, which is communicating with the PLC using MX Sheet, and the task bar are displayed.

(a) Display of Excel book

<Excel 2003 or earlier> a) c)

10

Item a) (Menu bar) b) (Icons) c) (MX Sheet menu)

Status during Communication

Only [MX Sheet] can be selected.

Only the End Communication and 1 Shot Communication icons can be selected.

Only [End Communication], [1 Shot Communication] and [Version Info.] can be selected.

10 - 1 10 - 1

10 COMMUNICATION START AND COMMUNICATION END

MELSOFT d) e) f)

<Excel 2007 or later> g)

Item d) (Tab) e) (Group) f) (MX Sheet menu) g) (Icon)

Status during Communication

Only the <<Add-Ins>> tab can be selected.

Only [MX Sheet] can be selected.

Only [Communication End], [1 Shot Communication…], and [Version Info….] can be selected.

Only the Communication End and 1 Shot Communication icons can be selected.

(b) Display of task bar

During communication with the PLC using MX Sheet, the following icon is displayed on the task bar of Windows

R

.

10

Icon is displayed on task bar.

(4) Confirmation at communication error

If an error occurs at the start of communication or during communication, the error information is displayed on the "ErrorLog" sheet.

When a communication error has occurred, end MX Sheet communication and correct the error in accordance with the corrective action on the "ErrorLog" sheet.

Refer to Chapter 19 for details of the "ErrorLog" sheet.

At occurrence of communication error, error information is displayed on "ErrorLog" sheet.

10 - 2 10 - 2

10 COMMUNICATION START AND COMMUNICATION END

MELSOFT

10.2 Communication End

This section explains the procedure to end MX Sheet communication.

communication

Choose [MX Sheet] [End Communication] ( ) from the menu bar. (Excel

2003 or earlier)

Choose <<Add-Ins>> tab [MX Sheet] [End Communication] ( ) (Excel

2007 or later).

Or, click the End Communication Button (refer to Section 14.2).

(2) Confirmation at communication end

At the end of communication, MX Sheet displays the communication end message on the "ErrorLog" sheet.

Confirm the message on the "ErrorLog" sheet at the end of communication.

Refer to Chapter 19 for details of the "ErrorLog" sheet.

<Excel 2003 or earlier>

At end of communication, communication end message is displayed on "ErrorLog" sheet.

<Excel 2007 or later>

At end of communication, communication end message is displayed on "ErrorLog" sheet.

10 - 3 10 - 3

11 1 SHOT COMMUNICATION

MELSOFT

11

11 1 SHOT COMMUNICATION

This chapter describes 1 shot communication function that makes communication with the selected cell area only once at any timing.

The "1 Shot Communication" dialog box is used to set a cell area and execute 1 shot communication for the cell area.

POINT

(1) 1 shot communication function ignores the device trigger and handshake settings made to the cell area, and makes communication only once.

(2) 1 shot communication function cannot work with the alarm summary function.

(1) Displaying "1 Shot Communication" dialog box

Choose [MX Sheet] [1 Shot Communication] ( ) from the menu bar.

Or, click the 1 Shot Communication Button (refer to Section 14.3).

(2) "1 Shot Communication" dialog box

Item Description

Cell Area Name

Choose the cell area for 1 shot communication.

Only the cell area name set in the currently selected Excel sheet is displayed in "Cell Area Name".

OK

OK can be clicked after the cell area is selected in "Cell Area

Name".

Click on OK to execute 1 shot communication.

Cancel

Used to close the "1 Shot Communication" dialog box.

REMARK

(1) After selecting the cell area set on the Excel sheet with the mouse or similar device, start 1 shot communication by clicking [OK] in the "1 Shot

Communication" dialog box. This displays the cell area name specified in "Cell

Area Name".

(2) Setting the cell area name in "Cell Area Name" displays the cell area on the

Excel sheet.

11 - 1 11 - 1

11 1 SHOT COMMUNICATION

MEMO

11 - 2 11 - 2

MELSOFT

11

12 CELL EDITING

MELSOFT

12

12 CELL EDITING

This chapter describes how to edit the cell area set using MX Sheet.

12.1 Cutting the Cell Area

This section explains the procedure to delete the settings of the selected cell area and paste them to another cell area.

(1) Displaying "Cut Cell Area" dialog box

Choose [MX Sheet] [Cut Cell Area] ( ) from the menu bar.

(2) "Cut Cell Area" dialog box

OK

Item Description

Cell Area Name Choose the cell area name to be cut.

OK can be clicked after the cell area name is selected in

"Cell Area Name".

Click on OK to cut the cell area.

Cancel

Used to close the "Cut Cell Area" dialog box.

REMARK

Paste the cell area after cutting it.

Refer to Section 12.3 for pasting the cell area.

12 - 1 12 - 1

12 CELL EDITING

MELSOFT

12.2 Copying the Cell Area

This section explains the procedure to copy the settings of the selected cell area to another cell area.

(1) Displaying "Copy Cell Area" dialog box

Choose [MX Sheet] [Copy Cell Area] ( ) from the menu bar.

(2) "Copy Cell Area" dialog box

12

Cell Area Name Choose the cell area name to be cut.

Item Description

OK

OK can be clicked after the cell area name is selected in

"Cell Area Name".

Click on OK to copy the cell area.

Cancel

Used to close the "Copy Cell Area" dialog box.

REMARK

Paste the cell area after copying it.

Refer to Section 12.3 for pasting the cell area.

12 - 2 12 - 2

12 CELL EDITING

MELSOFT

12.3 Pasting the Cell Area

This section explains the procedure to paste the cut or copied cell area to another cell area.

(1) Displaying "Paste Cell Area" dialog box

Choose [MX Sheet] [Paste Cell Area] ( ) from the menu bar.

(2) "Paste Cell Area" dialog box

Item Description

Target Cell area for

Paste operation

Target Cell area name for Paste operation

Source Cell area for the

Paste operation

Enter the cell area to be pasted.

Enter the cell area name to be pasted. *1

The cut or copied cell area is displayed.

OK

OK can be clicked after the "Target Cell area for Paste operation" and "Target Cell area name for Paste operation" are set.

Click on OK to copy the cell area.

Cancel

Used to close the "Paste Cell Area" dialog box.

*1: When pasting the cell area after copying it, enter into "Target Cell area name for Paste Operation" the cell area name that differs from the copied cell area name.

REMARK

Paste the cell area after cutting or copying it.

The cell area cannot be pasted unless the cell area has been selected by cutting or copying it.

12 - 3 12 - 3

12 CELL EDITING

MELSOFT

(3) Precautions for pasting the cell

Paste the cell area while paying attention to the followings:

(a) Paste starting cell in cell area

The paste starting cell in the cell area is the cell selected on the Excel sheet.

1) Select cell and past cell area.

2) Paste cell area using selected

cell as paste starting cell.

(b) Overlap of cell areas

If the paste area overlaps the other cell area that is already set, the selected cell cannot be pasted.

Paste the cell after checking the other cell area.

Cell area to be pasted

Already set cell area

As cell area enclosed by dotted lines overlaps, cell area cannot be pasted.

12 - 4 12 - 4

12 CELL EDITING

MELSOFT

12.4 Deleting the Cell Area

This section explains the procedure to delete the settings of the cell area.

(1) Displaying "Delete Cell Area" dialog box

Choose [MX Sheet] [Delete Cell Area] ( ) from the menu bar.

(2) "Delete Cell Area" dialog box

OK

Item Description

Cell Area Name Choose the cell area name of which settings will be deleted.

OK can be clicked after the cell area name is selected in "Cell

Area Name".

Click on OK to delete the cell area.

Cancel Used to close the "Delete Cell Area" dialog box.

12 - 5 12 - 5

13 CHANGING THE SHEET NAME

MELSOFT

13 CHANGING THE SHEET NAME

This chapter describes the changing the sheet name of the Excel sheet where MX

Sheet has been set.

In the "Change Sheet Name" dialog box, choose a Excel sheet and set a new name for the sheet.

POINT

Always change the sheet name of the Excel sheet, where MX Sheet has been set, from the "Change Sheet Name" dialog box.

If the sheet name is changed from Excel directly or from a VBA program, MX Sheet will not operate normally.

13

(1) Displaying "Change Sheet Name" dialog box

Choose [MX Sheet] [Change Sheet Name] ( ) from the menu bar.

(2) "Change Sheet Name" dialog box

Item Description

Sheet name before change

Select the Excel sheet of which sheet name to be changed.

Sheet name after change Enter a new sheet name.

OK can be clicked after the "Sheet name before change"

OK and "Sheet name after change" are selected.

Click on OK to change the sheet name.

Cancel

Used to close the "Change Sheet Name" dialog box.

(3) Changing the sheet name

If the sheet name of the Excel sheet, where MX Sheet has been set, is changed from Excel directly or from a VBA program, return the sheet name to the old one from Excel.

If the sheet name is changed from the VBA program, delete the program part that changes the sheet name.

13- 1 13- 1

13 CHANGING THE SHEET NAME

13

MEMO

MELSOFT

13- 2 13- 2

14 CREATE BUTTON

MELSOFT

14 Create Button

The following explains the Start Communication, End Communication and 1 Shot

Communication execution button creation procedures and the property setting.

By merely clicking the created button, Start Communication, End Communication or 1

Shot Communication operation can be performed and easily operated.

14.1 Start Communication Button

Create the button for execution of Start Communication and paste it to an Excel sheet.

(1) Button pasting method

1) Specify the cell on the Excel sheet where the button will be placed, and choose [MX Sheet] -

[Create Button] - [Start Communication Button] on the menu bar.

* In Excel 2007 or later, choose the <<Add-

Ins>> tab [MX Sheet] [Create Button]

[Start Communication Button].

14

2) The button is placed in the specified cell position.

Use the property setting of the property page to change the display characters on the button, set whether the start message will be displayed or hidden at execution of the button function, and change the type/size of the display character font on the button. Refer to (2), (3).

14 - 1 14 - 1

14 CREATE BUTTON

MELSOFT

14

(2) Property page starting method

1) Click in the Control Toolbox*

1

to select the

Design Mode.

To display the Control Toolbox, check the Control

Toolbox on the <<Toolbars>> Tab in the dialog box that is displayed by choosing [Tools] - [Customize] in the Excel menu.

*1: In Excel 2007 or later, click in the

<<Developer>> tab.

<Excel 2007>

To display the <<Developer>> tab, choose [Office button] - [Excel Options].

Select “Show Developer tab in the Ribbon” and click OK .

(To the next page)

14 - 2 14 - 2

14 CREATE BUTTON

(From the previous page)

MELSOFT

<Excel 2010>

To display the <<Developer>> tab, choose

<<File>> tab - [Options].

Choose "Customize Ribbon", select

"Developer", and click OK .

The <<Developer>> tab appears.

2) Choose [MXShBtnStart Control Object] -

[Properties] in the menu displayed by rightclicking the created button with the mouse.

3) The property page starts.

Set the properties shown in (3).

POINT

When the property setting is finished, click ( for Excel 2007 or later) to exit from the Design Mode.

14 - 3 14 - 3

14 CREATE BUTTON

MELSOFT

Set the Caption, ShowMessage and Font properties.

1) <<Caption>> tab

Edit the Caption (display characters on the button) of the button.

2) <<Show Message>> tab

Set whether the following Start Communication message will be displayed or not when the Start Communication button is clicked.

3) <<Font>> tab

Set the type and size of the Caption font.

TRUE : Display

FALSE : Not display

14 - 4 14 - 4

14 CREATE BUTTON

MELSOFT

POINT

• When the button was created or any property was changed, save the Excel book.

• Do not execute [Grouping] - [Ungroup] from the right-click menu of the button.

Executing Ungroup will disable the button from functioning.

• If the font size is set on the <<Font>> Tab of the property, a value (error) different from the set font size may be displayed when the <<Font>> Tab is displayed next time.

(Example) When the font size is set to 8, 8.25 will be displayed next time.

• If [Split], [Freeze Panes] or [New Window] in the [Window] menu is executed for the Excel sheet where buttons have been placed, correct operation may not be performed, e.g. the buttons remain displayed or the buttons cannot be clicked.

• If the zoom of Excel is set to a large magnification, the button may be displayed above the row/column number. When this phenomenon has occurred, click the button. The button will then move to the correct position.

• If a button is created in design mode and then the mode is ended and set repeatedly, the button may not be clicked.

In this case, minimize and restore the Excel book window. This enables the button to be clicked.

• When moving a button or changing button size after creating it, the button is not checked for its position.

• If the button position exceeds the supported range (256 columns ×65536 rows) when Excel from 97 to 2003 version is saved in book format, any of the following occurs depending on the button size, button position, height of the row and/or cell width.

(1) When saved Book is reopened, the button is reduced or moved so that it is fit within the supported range.

(2) The button has disappeared when saved Book is reopened.

(3) The Compatibility Checker screen appears on the Excel at saving the Book.

14 - 5 14 - 5

14 CREATE BUTTON

MELSOFT

14.2 End Communication Button

Create the button for execution of End Communication and paste it to an Excel sheet.

(1) Button pasting method

Similar to the Start Communication Button. Refer to Section 14.1 (1).

Choose [MX Sheet] [Create Button] [End Communication Button] in the menu.

(2) Property page starting method

Similar to the Start Communication Button. Refer to Section 14.1 (2).

Choose [MXShBtnEnd Control Object] [Properties] in the menu.

(3)

Property setting

Set the Caption and Font properties.

Refer to Section 14.1 (3).

14 - 6 14 - 6

14 CREATE BUTTON

MELSOFT

14.3 1 Shot Communication Button

Create the button for execution of 1 Shot Communication and paste it to an Excel sheet.

(1) Button pasting method

Similar to the Start Communication Button. Refer to Section 14.1 (1).

Choose [MX Sheet] [Create Button] [1 Shot Communication Button] in the menu.

(2) Property page starting method

Similar to the Start Communication Button. Refer to Section 14.1 (2).

Choose [MXShBtn1Shot Control Object] [Properties] in the menu.

Set the Caption, CellAreaName and Font properties.

Similar to the Start Communication Button. Refer to Section 14.1 (3).

1) <<CellAreaName>> Tab

The Cell Area Name list displays all Cell Area Names of Logging, Monitor,

Write and Comment in the Excel book.

Check the check box for the Cell Area Name that will be the target of 1 Shot

Communication.

Up to 10 Cell Area Names can be checked.

14 - 7 14 - 7

15 PROTECT/UNPROTECT MX SHEET SETTING

MELSOFT

15 Protect/Unprotect MX Sheet setting

15

The following explains Protect MX Sheet setting and Unprotect MX Sheet setting by a password.

15.1 Protect MX Sheet setting

Protect the MX Sheet setting by a password so that the setting contents cannot be changed.

The setting contents cannot be edited until the MX Sheet setting is unprotected.

(1) Displaying "Protect MX Sheet setting" dialog box

Choose [MX Sheet] [Protect MX Sheet setting] from the menu bar.

POINT

When Protect MX Sheet setting has been set, the [Protect MX Sheet setting] menu is not displayed and the [Unprotect MX Sheet setting] menu is displayed.

(2) "Protect MX Sheet setting" dialog box

Enable check setting data

Password (optional)

OK

Cancel

The menu that can be selected when Protect MX Sheet setting has been set changes depending on whether a check mark exists or not.

Enter the password for protecting the setting contents.

The password may also be registered as a blank.

The "Confirm Password" dialog box is displayed.

When the password is blank, however, the "Confirm Password" dialog box is not displayed and the MX Sheet setting is protected.

The "Protect MX Sheet setting" dialog box is closed. The MX Sheet setting is not protected.

Detailed

Explanation

(3) (a)

----

(3) (b)

----

15 - 1 15 - 1

15 PROTECT/UNPROTECT MX SHEET SETTING

MELSOFT

(a) "Enable check setting data"

Depending on whether "No check" (setting contents cannot be confirmed) or "Check" (setting contents can be confirmed) is selected, the menu that can be selected when Protect MX Sheet setting has been set changes as described in the following table.

MX Sheet menu

Cell Settings

Automatic Save Setting

Automatic Print Setting

Automatic Communication Startup Setting

Communication Start

Communication End

1 Shot Communication

Cutting the Cell Area

Copying the Cell Area

Pasting the Cell Area

Deleting the Cell Area

Changing the Sheet Name

Create Button

Unprotect MX Sheet setting

Options

Setting data export

Version Info.

No check Check

*

*

*

1

1

1

: Menu that can be selected

: Menu that cannot be selected

*1: [Read only] is displayed after the title of the following dialog box related to the Cell Settings, Automatic save setting and Automatic print setting.

The setting contents can be confirmed but cannot be changed.

• Cell Settings

• Automatic Save list

• Automatic Save

• Automatic Print list

• Automatic Print

15

15 - 2 15 - 2

15 PROTECT/UNPROTECT MX SHEET SETTING

MELSOFT

(b) OK

The "Confirm Password" dialog box is displayed.

Enter the password entered in the "Protect MX Sheet setting" dialog box again.

OK

Cancel

Item Description

The "Confirm Password" dialog box is closed, and the MX Sheet setting is protected.

The "Confirm Password" dialog box is closed. The MX Sheet setting is not protected.

POINT

If the MX Sheet setting is protected, the properties of the Start Communication, End

Communication, and 1 Shot Communication buttons can be edited.

15 - 3 15 - 3

15 PROTECT/UNPROTECT MX SHEET SETTING

MELSOFT

15.2 Unprotect MX Sheet setting

The MX Sheet setting is unprotected, and the setting contents can be changed.

(1) Displaying "Unprotect MX Sheet setting" dialog box

Choose [MX Sheet] [Unprotect MX Sheet setting] from the menu bar.

POINT

• When Protect MX Sheet setting has not been set, the [Unprotect MX Sheet setting] menu is not displayed.

• When the password is blank, the "Unprotect MX Sheet setting" dialog box is not displayed and the MX Sheet setting is unprotected.

(2) "Unprotect MX Sheet setting" dialog box

Password

Item Description

Enter the password set in the "Protect MX Sheet setting" dialog box.

OK

Cancel

The "Unprotect MX Sheet setting" dialog box is closed, and the MX Sheet setting is unprotected.

The MX Sheet menu selection and setting screen editing restriction are cancelled.

The "Unprotect MX Sheet setting" dialog box is closed. The MX Sheet setting is not unprotected.

15 - 4 15 - 4

16 OPTIONS

MELSOFT

16 Options

Make Option setting for specifying the Error log sheet output format, etc.

To display the "Options" dialog box, choose [MX Sheet] - [Options] on the menu bar.

16.1 Setting of the error log

Set the Error log sheet output format on the <<Error log>> tab in the "Options" dialog box.

Refer to Chapter 19 for details of the Error log sheet.

<<Error log>> tab

16

Item Description

Display error log

Information (Blue) *1

Warning (Pink) *1

Error (Red) *1

Display Error Log sheet when an error occurs

Clear error log at the start of communication

Set whether the information/warning/error that occurred during the execution of communication will be displayed in the Error log sheet or not.

Check: Display / No check: Not display

Set whether the information message (blue) during the execution of communication will be displayed in the Error log sheet or not.

Check: Display / No check: Not display

Set whether the warning message (pink) during the execution of communication will be displayed in the Error log sheet or not.

Check: Display / No check: Not display

Set whether the error message (red) during the execution of communication will be displayed in the Error log sheet or not.

Check: Display / No check: Not display

Set whether the display will be switched to the Error log sheet or not if a warning or error occurs during the execution of communication.

Check: Display will be switched to the Error log sheet.

No check: Display will not be switched to the Error log sheet.

Set whether the Error log will be cleared or not at the start of communication.

Check: clear / No check: Not clear

*1: Setting can be made only when the "Display error log" check box has been checked.

16 - 1 16 - 1

16 OPTIONS

MEMO

MELSOFT

16

16 - 2 16 - 2

17 SETTING DATA EXPORT

MELSOFT

17 SETTING DATA EXPORT

This chapter describes the procedure to output the settings of MX Sheet to a CSV file.

(1) "Setting Data Export" procedure

Choose [MX Sheet] [Setting Data Export] from the menu bar.

By selecting the above menu, the details of MX Sheet set in the Excel book are output to the CSV file.

After setting data export, the following dialog box appears.

17

(2) Save destination of CSV file

After setting data export, MX Sheet saves the CSV file in the folder where the original Excel book is saved.

(3) File name of CSV file

The following indicates the file name of the CSV file.

SET*******.csv

Excel book name that executed setting data export

17 - 1 17 - 1

17 SETTING DATA EXPORT

MELSOFT

(4) Saved contents of CSV file

The following shows the contents of the CSV file saved by the setting data export. a) b) c)

17 d)

17 - 2 17 - 2

17 SETTING DATA EXPORT

MELSOFT

Item Description a) (Cell Setting) b) (Automatic Save) c) (Automatic Print)

The settings of the sheet name and cell setting are displayed.

The settings of automatic save are displayed.

The settings of automatic print are displayed. d) (Automatic Communication Startup) The settings of automatic communication startup are displayed.

17 - 3 17 - 3

18 SAMPLE PROGRAMS

MELSOFT

18 SAMPLE PROGRAMS

This chapter describes the sample programs registered at MX Sheet installation.

The sample programs are attached for reference when creating user programs.

Please use them on customer's own responsibility.

(b) Logical station number

"1" is assigned to all sample programs as logical station number by default.

To use the sample programs, make the settings for the logical station number "1" or assign other logical station number and make the setting for the number.

(2) Sample program list

The following table indicates the sample programs (Sample1.xls, Sample2.xls) that are registered by choosing [User-specified folder] [Sheet] [Sample] at

MX Sheet installation.

Sample Program

Excel book name Excel sheet name

Description

Sample1. xls

Sample2. xls

Logging

Automatic Save

Logging is performed for D0 to D4 at 1 second intervals.

Monitor, Comment, Write

Alarm Summary

Monitor, display their assigned comments and write the device data

D10 to D12 at intervals of 5 seconds.

Alarm summary is performed using M0 to M4.

Monitor, Write (Conditioning) Monitor and write the device data using device trigger.

Logging (Conditioning) Logging is performed using handshake.

Save the data on the Excel sheet automatically when M20 turns on.

(Automatic save is described in Excel sheet.)

Logging Sheet Monitor, Comment, Write Sheet Alarm Summary Sheet

18

Monitor, Write (Conditioning) SheetMonitor Logging (Conditioning) Sheet Automatic Save Sheet

18 - 1 18 - 1

18 SAMPLE PROGRAMS

18

MEMO

MELSOFT

18 - 2 18 - 2

19 ERRORLOG SHEET

MELSOFT

19 ERRORLOG SHEET

This chapter describes the ErrorLog sheet that displays the communication status of

MX Sheet.

The communication status, error information and corrective action of MX Sheet are displayed in the ErrorLog sheet.

Troubleshooting can be performed by confirming the corrective action displayed in the

ErrorLog sheet.

Kind

Date

Detailed

Item Description

Explanation

(2) (b)

Cell Area Name

Error No

The type of the communication status is displayed.

The date and time when the communication status is changed are displayed.

The displayed time is the date and time of the personal computer where MX

Sheet is operating.

The cell area name where the communication status is changed is displayed.

(2) (c)

(2) (d)

(2) (e)

Contents

The error number of the error that has occurred is displayed.

The details of the communication status is displayed.

The error definition, error code and corrective action are displayed when an error occurs.

(2) Details

(2) (f)

19

The following table indicates the ErrorLog sheet specifications.

Item Description

Maximum number of display lines 2000 lines (fixed)

New data location

Operating when cell is full

The last line has the latest data.

Overwritten in due order, starting with the first line.

19 - 1 19 - 1

19 ERRORLOG SHEET

MELSOFT

19

(b) "Kind"

The following table indicates the communication statuses displayed in

"Kind".

Communication Status Description

Information

Displayed when the communication with the PLC starts and ends during 1 shot communication.

Error

Displayed when a fatal error occurred and the function of the cell area stopped.

Displayed when communication error or collection delay occurs. Warning

(c) "Date"

"Date" displays the date and time of the personal computer at ErrorLog sheet registration.

Indicates the time as "hour: minute: second".

Indicates the day of the week as "Sun (Sunday),

Mon (Monday), Tue (Tuesday), Wed (Wednesday),

Thu (Thursday), Fri (Friday), Sat (Saturday)".

Indicates the date as "year/month/day".

(d) "Cell Area Name"

The cell area name registered to the ErrorLog sheet is displayed.

It is not displayed when the communication starts and ends.

The error number is displayed.

Please specify the error number when inquiring about errors.

(f) "Contents"

The data displayed in "Contents" are shown below.

Error definition is displayed.

Corrective action for error is displayed.

POINT

• If the same error occurs twice or more successively in the same cell area, only the error information of the first error will be registered to the ErrorLog sheet. (The error information of the second error or later will not displayed.)

• Make setting related to the Error Log sheet output format in the "Options" dialog box. Refer to Section 16.1.

19 - 2 19 - 2

20 DATA CONVERSION FUNCTION

MELSOFT

20 DATA CONVERSION FUNCTION

This chapter describes the function to convert the Excel book created using MX Chart into the Excel book for MX Sheet.

20.1 Data Conversion Function

This section explains the data conversion functions, the relevant system configuration and utility.

The following table lists the data conversion functions.

Function Description

Conversion of MX Links data

This function converts automatically the communication settings made using the utilities of MX Links into the communication settings (logical station numbers) of MX Component.

Conversion of MX Chart data

This function converts automatically the set data of MX Chart into the cell settings of MX

Sheet.

The following table indicates the system configuration that executes the data conversion function.

Function Description

Personal computer

MX Links

MX Chart

Personal computer where any of the following OSes operates and MX Links and MX

Chart have been installed *1

Microsoft

Microsoft

R

R

Windows

R

98 Operating System (English version)

Windows NT

R

Workstation Operating System Version 4.0 (English version)

SW3D5F-CSKP-E Version 10B or later

SW3D5F-OLEX-E Version 00A or later

Conversion source Excel book Excel book created using Excel 97 (English version) or Excel 2000 (English version) *2

*1: The utilities of MX Links must have been set for communication.

*2: MX Chart must have been set to the Excel book for data conversion.

20

20 - 1 20 - 1

20

20 DATA CONVERSION FUNCTION

MELSOFT

REMARK

The following OSes and conversion source Excel book do not support the data conversion function.

OS

Microsoft

Microsoft

Microsoft

Microsoft

Microsoft

Microsoft

R

R

R

R

R

R

Windows

R

Windows

R

Windows

R

Windows

R

95 Operating System (English version)

Millennium Edition Operating System (English version)

2000 Professional Operating System (English version)

XP (English version)

Windows Vista

Windows

R

R

(English version)

7 (English version)

Conversion source Excel book Excel 95 (English version)

(3) Utility

Data conversion function uses MXComShConv.exe stored in the following folder.

[User-specified folder *1] [Sheet] MXComShConv.exe

*1: This will be "Melsec" when the installation destination folder has not been changed at installation.

(4) Data conversion function procedure

The following indicates the data conversion function procedure.

Start

Start MXComShConv.exe.

Refer to Section 20.2.

Set the data conversion function in the

"MXComShConv" dialog box.

Start the conversion log file and check the converted data.

Refer to Section 20.3.

Start the new Excel book and check the cell settings.

Refer to Section 20.4.

Start the Communication Setup Utility and conduct a communication test on the new logical station number.

Refer to MX Component

Operating Manual.

Completion

20 - 2 20 - 2

20 DATA CONVERSION FUNCTION

MELSOFT

20.2 Operation Procedure of MXComShConv.exe

This section explains the operation procedure of MXComShConv.exe used for the data conversion function.

1) Install MX Component and MX Sheet into the personal computer where MX Links and MX Chart have been installed.

Set various settings of MX Links and MX Chart correctly.

2) Double-click MXComShConv.exe stored in the following folder.

[User-specified folder *1] [Sheet]

MXComShConv.exe

*1: This will be "Melsec" when the installation destination folder has not been changed at installation.

3) The "MXComShConv" dialog box appears.

Set the following items and click on Execute .

"Convert the communication setting"

Mark the check box when converting the set data of MX Links.

"Convert the MX Chart used in Excel book"

Mark the check box when converting the set data of MX Chart.

"Excel book"

Enter the save place and file name of the Excel book to be converted.

4) The left screen appears during conversion of the Excel book for MX Chart.

Click on OK .

(To the next page)

20 - 3 20 - 3

20 DATA CONVERSION FUNCTION

MELSOFT

(From the previous page)

(Complete)

5) After all data are converted, the left dialog box appears.

Click on Yes to start the conversion log file.

Check the logical station numbers registered to the conversion log file and the log messages such as the error information that occurred during conversion.

The conversion log file is saved automatically as a txt file after the data conversion function is executed.

Refer to Section 20.3 for the save destination and details of the conversion log file.

Data conversion is complete.

The new Excel book is saved under the following file name in the same folder as the conversion source Excel book.

Cnv_*******.xls

Conversion source Excel book name

After data conversion, start the new Excel book, and perform a check on the MX Sheet settings and a communication test on the logical station number.

Refer to Section 20.4 for the precautions on the new Excel book.

20 - 4 20 - 4

20 DATA CONVERSION FUNCTION

MELSOFT

20.3 Conversion Log File

This section explains the save destination and display data of the conversion log file.

(1) Save destination of conversion log file

The conversion log file is saved in the following folder as a txt file.

[Temporary folder *1] ConvLogMXLinksToMXCom.txt

*1: The conversion log file is saved in the following folder when the temporary folder setting has not been changed.

When Windows

R

98 is used

When Windows NT

R

: [Windows] [Temp]

Workstation 4.0 is used: [Temp]

(2) Display data of conversion log file

With the conversion log file, the new logical station numbers and the log messages such as the error information that occurred during conversion can be checked.

Log message during conversion is saved.

20 - 5 20 - 5

20 DATA CONVERSION FUNCTION

MELSOFT

20.4 Precautions on Excel Book after Data Conversion Function Execution

After the data conversion function is executed, the settings in the Excel book have been converted for MX Sheet.

This section describes things to be cautioned. Be sure to start the Excel book and recheck the settings after executing the data conversion function.

This section describes the precautions in the following order.

1) Precautions logical station numbers

2) Precautions cell areas and sheet names

3) Precautions devices

4) Precautions alarm summary conversion

5) Precautions simple logging conversion

6) Precautions automatic save and automatic print conversion

7) Precautions tag setup conversion

8) Precautions on OLEX functions

Precautions on logical station numbers

(1) When only the data of MX Chart have been converted by the data conversion function, the "Logical Station Numbers" in the <<Access Data>> tabs are all converted into "0" in the cell settings of MX Sheet.

(2) When setting has been made using the direct station number system in "Network" of the Tag Setup Utility of MX Chart, the "Logical Station Numbers" in the

<<Access Data>> tabs are all converted into "0" in the "Cell Setting" dialog box of

MX Sheet.

(3) When converting the MX Links communication settings for MX Component, data conversion function automatically searches the empty MX Component logical station numbers and assigns the numbers to the communication settings.

MX Component logical station numbers

MX Component logical station numbers after data conversion

Logical Station

Number

0

Comment

Serial direct - Q25HCPU

1 Serial direct - Q2ACPU

4

5

Ethernet connection - Q25HCPU

Ethernet connection - Q2ACPU

MX Links logical station numbers

Logical Station

Number

0

Comment

Computer link connection - Q25HCPU

1

2

Computer link connection - Q2ACPU

USB connection - Q25HCPU

Data conversion execution

4

5

2

3

Logical Station

Number

0

Comment

Serial direct - Q25HCPU

1 Serial direct - Q2ACPU

6

Computer link connection - Q25HCPU

Computer link connection - Q2ACPU

Ethernet connection - Q25HCPU

Ethernet connection - Q2ACPU

USB connection - Q25HCPU

20 - 6 20 - 6

20 DATA CONVERSION FUNCTION

MELSOFT

Precautions on cell areas and sheet names

(1) When the cell area name has been set to "invalid" in the "Cell area name valid/invalid" dialog box of MX Chart, the "Set the Operation Interval" checkbox of the <<Operation Interval>> tab is unmarked in the "Cell Setting" dialog box of MX

Sheet to make the cell area setting invalid.

(2) If a non-existing Excel sheet has been set in the "Cell area name valid/invalid" dialog box of MX Chart, data conversion is continued ignoring the settings of the non-existing Excel sheet.

Precautions on devices

(1) When the data types of the following devices have been set to other than "Bit" on

MX Chart, the settings are not converted for MX Sheet.

• TT (timer contact)

• TC (timer coil)

• CT (counter contact)

• CC (counter coil)

• STT (retentive timer contact)

• STC (retentive timer coil)

Precautions on alarm summary conversion

(1) When a handshake has been set in the cell area used for the alarm summary of

MX Chart, the handshake settings are not converted.

The alarm summary function of MX Sheet does not support a handshake.

(2) If device settings overlap in the cell area for the alarm summary of MX Chart, the settings made second and later are not converted.

Precautions on simple logging conversion

(1) If "Interrupt logging" has been set in "Display option when reach to the end of cell areas" of the "Logging setup/revision" dialog box of MX Chart, "Operating when cell is full" of the <<Use>> tab is changed to "Display from the beginning after clearing the cell area" in the "Cell Setting" dialog box of MX Sheet.

(2) "Display option" in the "Logging setup/revision" dialog box of MX Chart is converted into the following display format on MX Sheet.

Indicates the time as "hour: minute: second".

Indicates the day of the week as "Sun (Sunday),

Mon (Monday), Tue (Tuesday), Wed (Wednesday),

Thu (Thursday), Fri (Friday), Sat (Saturday)".

Indicates the date as "year/month/day".

(3) If multiple cells of different column widths have been set in "Cell Area" of the

"Logging setup/revision" dialog box of MX Chart, the column widths of the cell area are converted into the same minimum column width in the cell area.

20 - 7 20 - 7

20 DATA CONVERSION FUNCTION

MELSOFT

Precautions on automatic save and automatic print conversion

(1) If "At refresh timing" has been set in "Save timing" of the "Automatic Save Setting" dialog box of MX Chart, "Save Automatically" check box is unmarked to make the automatic save settings invalid in the "Automatic Save" dialog box of MX Sheet.

(2) If "At refresh timing" has been set in "Print timing" of the "Automatic Print Setting" dialog box of MX Chart, "Print Automatically" check box is unmarked to make the automatic print settings invalid in the "Automatic Print" dialog box of MX Sheet.

Precautions on tag setup conversion

(1) If "Comm. Status" of the <<Communication settings>> tab has been set to

"invalid" in the "Tag setup" utility of MX Chart, the "Set the Operation Interval" check box of the <<Operation Interval>> tab is unmarked to make the cell area settings invalid in the "Cell Setting" dialog box of MX Sheet.

(2) If the collection conditions and handshake have been set in the "Extended" dialog box of MX Chart, they are converted into the settings of the <<Device Trigger>> tab and <<Handshake>> tab of the "Cell Setting" dialog box of MX Sheet.

Also in the "Extended" dialog box of MX Chart, the logical station numbers in the collection conditions and handshake are not converted for MX Sheet.

(3) If the ms unit setting has been made in "Comm. Period name" of the "Tag setup" utility of MX Chart, it is rounded up to the second unit and converted into MX

Sheet.

However, when the following functions are used, 0.5s to 0.9s settings are not rounded up.

• Monitor function

• Write function

• Alarm summary function

• Comment display function

Precautions on OLEX functions

(1) Be sure to delete the user program which uses OLEX functions after converting the Excel book which uses the OLEX functions.

OLEX function will not work on MX Sheet.

20 - 8 20 - 8

APPENDICES

MELSOFT

APPENDICES

APPENDIX 1 VERSION CONFIRMATION

This section explains how to confirm the MX Sheet version.

Confirm the MX Sheet version in the "Product information about MX Sheet" dialog box.

(1) Displaying "Product information about MX Sheet" dialog box

Choose [MX Sheet] [Version Info.] from the menu bar.

APP

APP - 1 APP - 1

APPENDICES

MELSOFT

APPENDIX 2 COMPARISON BETWEEN MX Sheet AND MX Chart

APP

The following table indicates comparison between MX Sheet and MX Chart.

Logging function

Monitor function

Write function

Alarm summary function

Comment display function

Automatic save/automatic print function

1 shot communication

Macro

Item

Number of device points

Number of logging lines

Number of cell areas that can be set

Communication interval

Save, print when cell is full

Number of CSV logging save points

Number of CSV logging save lines

Number of device points

Number of cell areas that can be set

Communication interval

Number of CSV logging save points

Number of CSV logging save lines

Number of device points

Number of cell areas that can be set

Communication interval

Number of device points

Number of history lines

Number of cell areas that can be set

Communication interval

Number of device points

Number of comments

Maximum number of registered points

Communication interval

Time designation

Device trigger designation

Automatic save format

For logging function

For monitor function

For write function

For alarm summary function

For comment function

Read function

Write function

MX Sheet

256 points *

1

MX Chart

65536 lines 2000 lines

100/1 Excel book

0.1s to 3600s, time designation

1s to 3600s, time designation

Available

256 points

9999999 lines

2000 points *

1

1000/1 Excel book

0.1s to 3600s, time designation

N/A

N/A

N/A

0.5s to 3600s, time designation

1000 points N/A

9999999 lines N/A

2000 points *

1

1000

1000/1 Excel book

0.1s to 3600s, time designation

2000 points

65536 lines

0.5s to 3600s, time designation

300 points

300 lines

0.1s to 3600s

100/1 Excel book

0.5s to 3600s

1 points

1000 comments

500/1 Excel book

0.1s to 3600s, time designation

0.5s to 3600s, time designation

Available

Available

Excel file, HTML file, CSV file

Available

Available

Available

N/A

N/A

Excel file

Available

N/A

N/A

N/A

Available

(OLEXRead function)

Available

(OLEXWrite function)

*1: This number of device points applies to the case word device data is collected/written in 16 bit integer.

APP - 2 APP - 2

APPENDICES

MELSOFT

APPENDIX 3 PROCESSING SPEED OF MX Sheet

This section explains the performance values and the scroll processing performance of

Excel when the monitor and logging functions have been executed using the personal computer of the following performance.

The performance values indicate the numbers of device points where no collection delay will occur when only one cell area has been set to the Excel book and the device data of D device are collected by the monitor or logging function. (If multiple cell areas have been set, reduce the number of device points per cell to maintain the same performance.)

The actual performance values vary depending on the performance or similar of the personal computer.

Use the performance values given in this section as reference values.

OS

CPU

Memory

Excel

Cell area

: Pentium III(800MHz)

: 256MB

: Excel 2002

: Only one

<Setting example 1>

The setting example 1 indicates the case where only one access data is set.

<Setting example 2>

The setting example 2 indicates the case where two or more access data are set.

(1) Performance values for computer link communication

The following table indicates the performance values when the monitor and logging functions are executed using computer link communication.

CPU type: A3ACPU

Connected module: AJ71UC24 (19200bps)

Number of Device Points

Interval

Setting example 1 Setting example 2

Monitor function

Logging function

0.5s

1s

5s

1s

5s

120 points

260 points

1400 points *

1

200 points

1024 points *

1

30 points

70 points

70 points

400 points *

1

*1: This number of device points applies to the case the data type is set to a character string.

APP - 3 APP - 3

APPENDICES

MELSOFT

(2) Performance values for Ethernet communication

The following table indicates the performance values when the monitor and logging functions are executed using Ethernet communication.

CPU type: Q25HCPU

Connected module: QJ71E71 (10Mbps)

Monitor function

0.5s

1s

5s

1s

Operation

Interval

Number of Device Points

Function

Logging function

Setting example 1

4000 points *

1

12000 points *

1

20000 points *

1

5120 points *

1

5120 points *

1

Setting example 2

1792 points *

1

10000 points *

1

1792 points *

1

5120 points *

1

5s

*1: This number of device points applies to the case the data type is set to a character string.

(3) Scroll processing performance of Excel

The following table indicates the times required by Excel for scroll processing when the logging function is used.

The following times applies to the case only Excel has been started on the personal computer.

Scroll Range

10 columns 1000 rows

10 columns 2000 rows

10 columns 65536 rows

256 columns 1000 rows

256 columns 2000 rows

256 columns 65536 rows

Time Required for Scroll Processing

0.95s

1.1s

6.1s

4.5s

6.8s

20min and 30s

(4) File size at save and required time

The following table shows references for file size at save and time taken for saving a file depending on Excel version (Book format).

In Excel 2007 or later (especially in standard format), file size may increase or time taken for saving a file may lengthen.

Excel version

Cell range

Excel 2000

Excel 2007 (standard format)

Excel 2007 (binary format)

12 columns 30 rows

Size (MB)

Time

(second)

0.112

0.034

0.022

0.035

0.022

Less than 1

Less than 1

Less than 1

Less than 1

Less than 1

128 columns 32768 rows 255 columns 65535 rows

Size (MB)

Time

(second)

Size (MB)

Time

(second)

9.4

11.1

0.45

11.1

0.46

1

7

3

4

2

35.1

42.5

14.3

42.5

14.3

5

23

11

14

8

Excel 2010 (standard format)

Excel 2010 (binary format)

Measurement condition: 1 type is set for cell settings (application: logging).

Measurement environment: Intel

R

Core

TM

2 Duo E8400 3.0GHz, 1GB MM,

Windows

R

XP Professional SP3

APP - 4 APP - 4

APPENDICES

MELSOFT

APPENDIX 4 PROCESSING MX Sheet

This section explains the processing of MX Sheet.

Appendix 4.1 Collection Delay and Data Dropout

On MX Sheet, collection delay, data dropout or similar problem may occur depending on the communication time with the PLC and the collection timing of device data.

The following explains the collection delay and data dropout.

Device data collection delay will occur depending on the communication time with the PLC and the corresponding processing time.

Collection delay occurs only when "Operation time" is set to "Regular interval".

When a collection delay occurs, it will be registered to the ErrorLog sheet as error information.

When a collection delay occurs, check the ErrorLog sheet.

The following explains the cases where a collection delay occurs.

(a) When the actual communication time is longer than the specified operation interval

When the communication time with the PLC is longer than the operation interval of MX Sheet, a device data collection delay occurs.

(Example) "Operation time" is set to "Regular interval (3s)" but the communication time with the PLC is 5s

Operation interval set to 3s

3s

2s waiting time occurs.

Time

Communication time: 5s

Since communication time is longer, actual operation interval is 5s.

APP - 5 APP - 5

APPENDICES

MELSOFT

(b) Collection delay when device trigger function is used

When the sum of the device trigger condition check time and the communication time with PLC is longer than the operation interval of MX

Sheet, a collection delay occurs during the next device trigger condition check.

(Example) When "B0" = "When ON" has been set as the device trigger condition (operation interval is 3s)

Operation interval set to 3s

3s

2s waiting time occurs.

Time

1)

2)

ON

B0

OFF

Time necessary for communication: 5s

1) Device trigger condition check time

2) Communication time

1) + 2) is time necessary for communication.

(c) Collection delay when handshake function is used

When the sum of the requesting device check time, the communication time with PLC and the handshake processing time is longer than the operation interval of MX Sheet, a collection delay occurs during the next requesting device check.

(Example) When the PLC side requesting device has been set to "M0" and the PC side responding device

to "M100" (operation interval is 3s)

Operation interval set to 3s

2s waiting time occurs.

3s

Time

1)

2)

3)

Time necessary for communication: 5s

ON

M100

OFF

M0

ON

OFF

1) + 2) + 3) is time necessary for communication.

1) Requesting device check time

2) Communication time

3) Handshake processing time

APP - 6 APP - 6

APPENDICES

MELSOFT

The data to be collected may dropout depending on the communication time with the PLC and the collection timing of device data.

The following explains the cases where a data dropout occurs.

(a) When the actual communication time is longer than the specified operation interval

When the communication time with the PLC is longer than the operation interval, the data to be collected dropouts.

If a data dropout has occurred, increase the operation interval setting of MX

Sheet.

(Example) When "Operation time" has been set to "Hourly (0min, 1min, 2min)" but the communication

time with the PLC is longer than 1min

If previous data collection is still being executed when it has reached the operation time as shown below, a data dropout occurs on MX Sheet.

12:00 12:01 12:02

Time

Communication time: 1min 30s

Since data at 12:00 is being collected, data at

12:01 is not collected.

(b) Data dropout when device trigger function is used

When the device trigger condition holds for the specified operation time, the condition cannot be checked and the data to be collected dropouts.

If a data dropout occurs during use of the device trigger, decrease the operation interval setting of MX Sheet.

(Example) When "B0" = "When ON" has been set as the device trigger condition

(operation interval is 60s)

If the device trigger condition holds for the specified operation time as shown below, a data dropout occurs on MX Sheet.

Device trigger condition is checked at every operation time.

12:00 12:01 12:02 12:03

Time

ON

B0

OFF

Data collection is executed when condition holds.

Condition has held but data collection is not executed since condition does not hold for condition check.

REMARK

Note that if a data dropout occurs during use of the device trigger, error information is not registered to the ErrorLog sheet.

APP - 7 APP - 7

APPENDICES

MELSOFT

(c) Data dropout when handshake function is used

When the requesting device condition holds for the specified operation time, the data to be collected dropouts.

If a data dropout occurs during use of the handshake, decrease the operation interval setting of MX Sheet.

(Example) When the PLC side requesting device has been set to "M0" and the PC side responding

device to "M100" (operation interval is 60s)

If the requesting device condition holds for the operation time as shown below, a data dropout occurs on MX Sheet.

Requesting device is checked at every operation time.

12:00 12:01 12:02 12:03

Time

ON

M100

OFF

ON

M0

OFF

Data collection is executed when requesting device condition holds.

Requesting device condition has held but data collection is not executed since condition does not hold for condition check.

REMARK

Note that if a data dropout occurs during use of the handshake, error information is not registered to the ErrorLog sheet.

APP - 8 APP - 8

APPENDICES

MELSOFT

(3) Data dropout when modem communication function is used

When modem communication function is used and "Telephone line connectivity time zone" is set for "Connect each time depending on the operation interval", a data dropout occurs due to use of a modem.

To collect PLC device data using modem communication function, set MX Sheet while considering the modem connection time.

If a data dropout occurs during modem communication, increase the operation interval setting of MX Sheet.

As operation interval, set time longer than sum of 1) + 2) + 3).

Operation interval

Time

1)

2)

3)

Appendix 4.2 Date and Time

Time necessary for modem communication

1) Time to connect to modem

2) Communication time

3) Time to disconnect from modem

When the logging function and CSV logging are used, the date and time in the cell area and the CSV file may not be displayed correctly.

The following describes an example of the incorrect display, the causes and corrective actions.

<Example (when "Regular interval" is set to 1s)>

Although communication is made at the specified interval, the date and time are not displayed correctly as shown

below, since the time when data has been actually read exceeds the regular interval.

(Unlike with collection delay, the error information is not displayed in the ErrorLog sheet.)

Time of 13:08:27 is incorrectly displayed as 13:08:28.

<Causes>

Multiple cell areas have been set to the Excel book.

Multiple cell areas use the same communication path.

"Operation time" of the <<Operation Interval>> tab has been set to "Regular interval".

<Corrective actions>

Decrease the number of cells set to the Excel book.

Increase the "Regular interval" setting.

Reexamine the cell area settings. (Refer to APPENDIX 5.)

APP - 9 APP - 9

APPENDICES

MELSOFT

APPENDIX 5 CREATING THE Excel SHEET FOR MX Sheet

When collecting/writing device data by using MX Sheet, the efficiency of communication with the PLC varies depending on the cell area settings.

The following provides the example of setting cell area for more effective communication.

(1) Communication efficiency and cell area specifying method

When multiple cell areas have been set, MX Sheet executes communication with the PLC in order of the cell areas.

When the same communication path has been set to multiple cell areas, communication efficiency decreases since all cell areas use one communication path to communicate with the PLC.

The following setting example indicates the case where the same communication path has been set to multiple cell areas.

<Setting example>

Cell Area Name

Product type

Lot No.

A

B

C2

C3

C5: C7

E5: E7

When the above setting example is divided into four cell areas as indicated in the following table, MX Sheet executes communication four times. This causes communication load to increase, decreasing communication efficiency.

Cell Area

Logical station number

0: Ethernet

0: Ethernet

0: Ethernet

0: Ethernet

Access Data Settings

Device setting

D0 Character string

D5 Character string

D10 16 bit integer

D20 16 bit integer

1

1

3

3

Number of cells

Operation

Interval

1s interval

1s interval

1s interval

1s interval

When the above setting example is integrated into one cell area as indicated in the following table, the collection/write of device data is completed by making communication once. This enables communication load to decrease, improving communication efficiency.

Cell Area Name Cell Area

Logical station number

Access Data Settings

Device setting

Product information C2, C3, C5: C7, E5: E7 0: Ethernet

D0 Character string

D5 Character string

D10 16 bit integer

D20 16 bit integer

1

1

3

3

Number of cells

Operation

Interval

1s interval

APP - 10 APP - 10

APPENDICES

MELSOFT

(2) Communication efficiency and access data setting

When one type of device is set as multiple devices, the efficiency of communication with the PLC decreases.

The following setting example indicates the case where one type of device is specified consecutively.

<Setting example>

If the above setting example is divided into three access data as indicated below, MX Sheet recognizes them as three types of devices and executes communication, decreasing communication efficiency.

If the above setting example is integrated into one access data as indicated below, MX Sheet recognizes it as one type of device and executes communication, improving communication efficiency.

REMARK

Any of the following settings prevents the improvement of communication efficiency even if efficient setting has been made.

(1) When "Data Type" has been set to "Bit", the device number setting of "Device" is not a multiple of 16.

(2) CN200 (current value of 32-bit counter device) or later of the FXCPU has been set.

APP - 11 APP - 11

APPENDICES

MELSOFT

(3) Communication efficiency and use of Excel function (cell reference)

When inconsecutive device data are displayed on Excel, the efficiency of communication with the PLC decreases if multiple cell areas are set.

The following setting example indicates the case where inconsecutive device data are displayed on Excel.

<Setting example>

Cell Area Name

Line A

Line B

Line C

Line D

C3: E3

C4: E4

C5: E5

C6: E6

When the above setting example is divided into four cell areas as indicated in the following table, MX Sheet executes communication four times. This causes communication load to increase, decreasing communication efficiency.

Cell Area

Logical station number

0: Ethernet

0: Ethernet

0: Ethernet

0: Ethernet

Access Data Settings

Device setting

D0 16 bit integer

D5 16 bit integer

D10 16 bit integer

D15 16 bit integer

3

3

3

3

Number of cells

Operation

Interval

1s interval

1s interval

1s interval

1s interval

When the above setting example is integrated into one cell area as indicated in the following table and device data are collected in the other

Excel sheet (Sheet 2), this decreases communication load, improving communication efficiency.

Set cell reference so that Excel sheet 1, which actually displays the device data, will refer to the corresponding cells within Excel sheet2, which collects the device data.

(MX Sheet need not be set in the Excel sheet where device data will be displayed actually (Sheet 1).)

Cell Area Name Cell Area

Logical station number

Line information A2: E5 (Area set to Sheet 2) 0: Ethernet

Access Data Settings

Device setting

D0 16 bit integer

Number of cells

20

Operation

Interval

1s interval

Sheet 1 (Excel sheet where device data will be displayed actually) Sheet 2 (Excel sheet where device data will be collected)

Set Sheet 1 to refer to cells of Sheet 2.

APP - 12 APP - 12

APPENDICES

APPENDIX 6 PROCEDURE TO TRANSPORT DATA TO OTHER PERSONAL

COMPUTER

MELSOFT

This section explains the procedure to transport the settings of MX Sheet from a development personal computer to an on-site personal computer.

POINT

MX Sheet and MX Component must have been installed in the personal computer where the settings of MX Sheet will be transported.

Start *1

Start the Communication Setup Utility and execute the export of the communication settings. *2

Operation on development personal computer Copy the following files to the on-site personal computer.

Excel book of MX Sheet

Export file of Communication Setup Utility

Operation on on-site personal computer

Start the Communication Setup Utility and import the export file created on the development personal computer. *2

Start the Excel book of MX Sheet and recheck the settings.

Completion

*1: The Excel book for MX Sheet should have been created on

the development personal computer.

*2: For the import and export operations of communication

settings, refer to the MX Component Operating Manual.

APP - 13 APP - 13

APPENDICES

MELSOFT

APPENDIX 7 HTML FILE

This section explains the HTML file saved during MX Sheet operation.

MX Sheet allows an HTML file to be saved automatically into the folder specified when any of the following functions is used.

• Logging function (when cell is full)

• Alarm summary function (when cell is full)

• Automatic save setting

Plant

(2) Convenient use of HTML file

The data collected by MX Sheet can be snapshot-monitored from a business destination, office or other place via the Internet/intranet, with the plant side personal computer (personal computer where MX Sheet is operating) used as a

Web server.

Web server

HTML file is created by automatic save function of MX Sheet.

Internet

Intranet

MX Sheet is unnecessary.

Plant conditions can be snapshot-monitored from office and business destination.

APP - 14 APP - 14

APPENDICES

MELSOFT

(3) Continuous operation when saving data automatically in HTML format

Do not operate MX Sheet continuously when the Automatic save function is set to save data in HTML format.

For operating MX Sheet continuously, exit and reactivate Excel periodically.

If data are saved repeatedly in HTML format with the Automatic save function,

Excel may not operate properly.

The time for allowable continuous operation differs according to the operating environment.

APPENDIX 8 Warning Message Appears on Windows Vista

R

and Windows

R

7

Appendix 8.1 Overview of warning message

The user account control function has been added to Windows Vista

Windows

R

7.

R

and

By this function, a warning message appears when executing Excel with Administrator authority. (Refer to Chapter 4)

< Windows Vista

R

> < Windows

R

7>

APP - 15 APP - 15

APPENDICES

MELSOFT

Appendix 8.2 Methods for preventing the warning message

POINT

The user account control (UAC) function prevents a crash (e.g. prevention of startup of a program which executes unintended operation).

Before setting this function, grasp that the security function offered by UAC will be disabled and fully understand the risk.

The following two methods are available for preventing a warning message.

(1) Disabling the user account control function

The following shows a procedure for disabling the user account control function.

1) Select [Start] – [Control Panel].

2) Select [User Accounts].

(To next page)

APP - 16 APP - 16

APPENDICES

(From preceding page)

3) Select [User Accounts].

MELSOFT

4) Select [Turn User Account Control on or off].

5) Deselect [Turn on User Account Control (UAC) to make your computer more secure].

(Setting completion)

APP - 17 APP - 17

APPENDICES

MELSOFT

(2) Allowing the warning message without showing it

The following shows a procedure for allowing a warning message without showing it.

1) Select [Start] – [Control Panel].

2) Select [Classic View].

3) Select [Administrative Tools].

(To next page)

APP - 18 APP - 18

APPENDICES

(From preceding page)

MELSOFT

4) Select [Local Security Policy].

* When user account control is enabled, the following screen appears.

Click Continue or Yes .

< Windows Vista

R

> < Windows

R

7>

5) Select [Local Policies].

6) Select [Security Options].

(To next page)

APP - 19 APP - 19

APPENDICES

(From preceding page)

MELSOFT

7) Select [User Account Control: Behavior of the elevation prompt for administrators in Admin

Approval Mode Prompt for consent

8) Select [Elevate without prompting] on the <<Local

Security Setting>> tab, and click OK .

(Setting completion)

APP - 20 APP - 20

APPENDICES

MELSOFT

APPENDIX 9 ACTION FOR ERRORS OCCURRED WHEN Excel 2007 OR LATER FOR

WHICH AUTOMATIC COMMUNICATION STARTUP HAS BEEN SET IS

OPENED

When an Excel book for which automatic communication startup has been set is opened with Microsoft

R

Chapter 9).

Appendix 9.1 Situations

Excel 2007 or later, the following situations may occur (refer to

• Excel does not respond.

• Either of the following errors occurs.

Appendix 9.2 Error Cause

The errors occur if the following three conditions are met:

(1) MX Sheet Version 1.08J or later is used.

(2) An Excel book for which MX Sheet automatic communication startup has been set is opened.

(3) An Excel book is opened with Microsoft

R

Excel 2007 or later.

APP - 21 APP - 21

APPENDICES

Appendix 9.3 Corrective Action

Take an action in the following flow.

Start

Is MX Sheet Version 1.10L or earlier used?

Yes

Update MX Sheet.

MELSOFT

...

Check the version by selecting [MX Sheet] [Version Info.] on Excel.

No

...

Obtain data for the update from your local representative.

Is Windows XP SP2 or earlier or

Windows Vista SP1 or earlier used?

Yes

Install the required Service Pack.

...

Check the Service Pack for the operating environment.

No

...

Refer to "(1) Installation of Service Pack".

Check the .NET Framework and the related module not yet installed, and install it.

Execute "MXShRegRCom. exe".

...

Refer to "(2) Checking and installation of .NET Framework and the related module".

...

Refer to "(3) Execution of "MXShRegRCom.exe"".

Check that the action works.

...

Refer to "(4) Checking if the action works".

End

POINT

Update MX Sheet or install Service Pack, .NET Framework, and the related module using the administrator account.

APP - 22 APP - 22

APPENDICES

MELSOFT

Used OS

Windows

R

XP Windows

R

Windows Vista

R

Service Pack

XP Service Pack 3

R

Service Pack 2

URL (as of March 4, 2011) http://windows.microsoft.com/en-us/windows/help/learn-how-toinstall-windows-xp-service-pack-3-sp3 http://windows.microsoft.com/en-US/windows-vista/Learn-how-toinstall-Windows-Vista-Service-Pack-2-SP2

(2) Checking and installation of .NET Framework and the related module

The following tables list .NET Frameworks and the related modules required for each operating environment.

If they are not installed, install them in the order listed in (a), (b), or (c).

The installers of .NET Frameworks and the related modules are stored on the

CD-ROM provided with MX Sheet Version 1.11M or later. If the CD-ROM is not obtained, visit the website shown in (a), (b), or (c).

(a) Excel 2007 is used on Windows

R

XP

Order

(1) Installation of Service Pack

Install the Service Pack required for the used OS.

.NET Framework and the related module

File name on the CD-ROM

*1

URL

*2

(as of March 4, 2011)

1

2

3

Microsoft R

3.5 SP1

.NET Framework

Microsoft R .NET Framework

4.0 Extended

Microsoft R Visual Studio 2010

Tools for Office Runtime (x86) dotnetfx35.exe dotNetFx40_Full_x86_x64.exe vstor40_x86.exe http://www.microsoft.com/downloads/en/ details.aspx?displaylang=en&FamilyID=a b99342f-5d1a-413d-8319-81da479ab0d7 http://www.microsoft.com/downloads/en/ details.aspx?displaylang=en&FamilyID=0 a391abd-25c1-4fc0-919f-b21f31ab88b7 http://www.microsoft.com/downloads/en/ details.aspx?FamilyID=06C32242-2289-

4471-93AA-CE96AA5CBC36

*1: The file is in the "DOTNET" folder.

*2: If the website cannot be accessed, refer to (d).

APP - 23 APP - 23

APPENDICES

MELSOFT

Order

1

2

(b) Excel 2010 is used on Windows

R

XP, or Excel 2007 or later is used on Windows Vista

R

or 32-bit Windows

R

7

.NET Framework and the related module

File name on the CD-ROM

*1

URL

*2

(as of March 4, 2011)

Microsoft

R

.NET Framework

4.0 Extended

Microsoft

R

Visual Studio 2010

Tools for Office Runtime (x86) dotNetFx40_Full_x86_x64.exe vstor40_x86.exe http://www.microsoft.com/downloads/en/ details.aspx?displaylang=en&FamilyID=0 a391abd-25c1-4fc0-919f-b21f31ab88b7 http://www.microsoft.com/downloads/en/ details.aspx?FamilyID=06C32242-2289-

4471-93AA-CE96AA5CBC36

*1: The file is in the "DOTNET" folder.

*2: If the website cannot be accessed, refer to (d).

(c) Excel 2007 or later is used on 64-bit Windows

R

7

Order

.NET Framework and the related module

File name on the CD-ROM

*1

URL

*2

(as of March 4, 2011)

1

2

Microsoft R .NET Framework

4.0 Extended

Microsoft R Visual Studio 2010

Tools for Office Runtime (x64) dotNetFx40_Full_x86_x64.exe vstor40_x64.exe http://www.microsoft.com/downloads/en/ details.aspx?displaylang=en&FamilyID=0 a391abd-25c1-4fc0-919f-b21f31ab88b7 http://www.microsoft.com/downloads/en/ details.aspx?FamilyID=06C32242-2289-

4471-93AA-CE96AA5CBC36

*1: The file is in the "DOTNET" folder.

*2: If the website cannot be accessed, refer to (d).

(d) If a website shown in (a), (b), or (c) cannot be accessed

URL (as of March 4, 2011) http://msdn.microsoft.com/en-us/netframework/ http://www.microsoft.com/downloads/en/default.aspx

Operation

The module related to Microsoft R .NET Framework can be obtained. Read the explanation on the displayed page.

The module related to Microsoft R Visual Studio 2010 Tools for

Office Runtime can be obtained. Search for "Visual Studio

2010 Tools for Office Runtime" on the displayed page.

APP - 24 APP - 24

APPENDICES

MELSOFT

POINT

Check if the required .NET Framework and the related module are installed or not by the following operations.

• When using Windows

R

XP

Select [Start] [Control Panel] [Add or Remove Programs].

• When using Windows Vista

R or Windows

R

7

Select [Start] [Control Panel] [Uninstall a program].

Check if the "Add or Remove Programs" screen or the "Uninstall or a change a program" screen displays the required .NET Framework and the related module.

(3) Execution of "MXShRegRCom.exe"

After installing .NET Framework and the related module, execute

"MXShRegRCom.exe" in the folder where MX Sheet has been installed

("C:\MELSEC\Sheet\" when the installation location folder was not changed at installation).

* When the user account control is enabled, the following screen appears.

Click Continue or Yes .

<Windows Vista

R

> <Windows

R

7>

The message shown in the figure to the left appears to notify the completion.

Click OK .

APP - 25 APP - 25

APPENDICES

(4) Checking if the action works

The following explains how to check if the action works or not.

MELSOFT

2) When either of the screens to the left is displayed, click Install .

3) < Office 2007 >

Select [Office button] [Excel Options].

< Office 2010 >

Select <<File>> tab [Options].

The "Excel Options" screen appears. Select [Add-

Ins], change the item in "Manage" to [COM Add-ins], and click Go... .

4) In the "COM Add-Ins" dialog box, check that

"MXShRibbon" is displayed, and its check box is selected.

Checked

APP - 26 APP - 26

APPENDICES

MELSOFT

APPENDIX 10 ADDED/EXTENDED FUNCTIONS

Compatible

Versions

Version

1.03D

The following shows the functions added/extended to the MX Sheet due to upgrade.

Added/extended

Functions

Description

Under the following operating systems, MX Sheet can be operated regardless of administrator authority.

• Microsoft

R

Windows NT

R

Workstation Operating System Version 4.0 (Operating

Environment) • Microsoft

R

• Microsoft

R

Windows

R

Windows

R

2000 Professional Operating System

XP Professional Operating System

• Microsoft

R

(Excel) Microsoft

R

Windows

R

XP Home Edition Operating System

Excel 2003 (English version)

Cell Settings

<<Use>> tab settings

Cell Settings

<<Access Data>> tab settings

Cell Settings

<<Operation Interval>> tab settings

Enabled to clear a desired cell range at the start of communication.

Enabled to express the numeric in hexadecimal.

Enabled to set data collection at 0.1-second interval.

Reference

Section

Section 2.1

Section 2.1

Chapter 6

Chapter 6

Chapter 6

Error log

Logging

Alarm Summary

Alarm Summary

Automatic save

Automatic print

The following options can be set on the <<Error log>> tab.

• Clears error log at the start of communication.

• Selects the display format of error log.

• Automatically displays the error log sheet when an error occurs.

• Enabled to automatically create a title in the display area of

Logging/Alarm Summary.

• Enabled to set CSV file format to save Excel book when the cell is full.

Enabled to display the number of occurrences and elapsed time.

• Enabled to clear a desired cell range after performing Automatic save/Automatic print.

• Enabled to make multiple setting of Automatic Save/Automatic Print condition.

• Enabled to save a file as a CSV file using Automatic Save dialog box.

Section

16.1

Section 6.2

Section 6.5

Section 6.5

Chapter 7

Chapter 8

Communication Start

Communication End

Shot Communication

Protect MX Sheet setting

Enabled to create the buttons for operation and paste them in Excel sheet for operation.

Enabled to protect the setting by means of password.

Chapter 10

Chapter 11

Chapter 14

Chapter 15

(To the next page)

APP - 27 APP - 27

APPENDICES

MELSOFT

Compatible

Versions

Version

1.06G

Version

1.08J

Version

1.09K

Version

1.10L

Version

1.11M

Added/extended

Functions

Description

Cell Settings

<<Access Data>> tab settings

• Enabled to extend the settable number of points in a cell range.

2000 points*

1

2000 points*

1

Alarm Summary: 300 points 2000 points

• Enabled to set the device up as word device with bit specification by device specification in the access data

Cell Settings

<<Operation Interval>> tab settings

Enabled to set the operation interval at 1-minute and n-second interval.

(Operating

Environment)

Windows Vista

(Excel) Microsoft

R

R

(English version)

Excel 2007 (English version)

Cell Settings

Enabled to specify GOT timer contact devices (TT) and counter contact devices (CT).

(Operating

Environment)

(Operating

Environment)

32-bit Windows

64-bit Windows

R

R

7 (English version)

7 (English version)

Reference

Section

Chapter 6

Chapter 6

Section 2.1

Section 2.1

Section 3.2

Chapter 6

Section 2.1

Section 2.1

Section 2.1

*1: This number of device points is applied to the case the word device is set as 16 bit integer.

The settable device points depend on the device data type, etc.

APP - 28 APP - 28

APPENDICES

MEMO

MELSOFT

APP - 29 APP - 29

Ind

INDEX

[1]

1 Shot Communication......................... 3- 1, 11- 1

[A]

[C]

[D]

Access data ..............6-10, 6-41, 6-49, 6-58, 6-66

Accessible CPUs............................................ 3- 2

Accessible device ranges .............................. 3- 2

Alarm Data..................................................... 6-60

Alarm String................................................... 6-60

Alarm summary function ....................... 3- 1, 6-54

Automatic Communication Startup setting

................................................................ 3- 1, 9- 1

Automatic print function.......................... 3- 1, 8- 1

Automatic save function......................... 3- 1, 7- 1

Cell Area ....................6- 3, 6-38, 6-47, 6-55, 6-65

Cell Display Direction ........................... 6-38, 6-47

Cell Setting dialog box ................................... 6- 1

Change Sheet Name ................................... 13- 1

Color for filling................................................. 6- 3

Color of grid line ............................................. 6- 3

Comment Data .............................................. 6-68

Comment display function..................... 3- 1, 6-60

Comment String ............................................ 6-69

Communication error.................................... 10- 2

Communication Setup Utility.................. 6- 9, 7- 3

Comparison between MX Sheet and MX Chart

................................................................... APP- 2

Contents to save ........................................... 6-34

Conversion Log File ..................................... 20- 5

Copy Cell Area ............................................. 12- 2

CSV Logging ................................3- 1, 6-34, 6-45

Cut Cell Area ................................................ 12- 1

Data conversion function ..................... 3- 1, 20- 1

Data Type ............................................. 6-12, 6-67

Delete Cell Area ........................................... 12- 5

Dev. Points ........................................... 6-14, 6-59

Device Trigger ...............................3- 1, 6-21, 7- 2

Displayed Contents ........................................ 6- 3

[E]

[F]

End Communication .....................................10- 3

ErrorLog sheet ..............................................19- 1

Function list .....................................................3- 1

[H]

[I]

Handshake............................................ 3- 1, 6-24

How to create the Excel sheet................. APP-10

HTML file.................................................. APP-14

[L]

Icons ................................................................5- 1

In unit..............................................................6-14

Logging function.......................................3- 1,6- 2

Logging Time zone ........................................6-15

Logical Station Number ........................ 6-10, 7- 7

[M]

[N]

Menu bar .........................................................5- 1

Monitor function .................................... 3- 1, 6-35

MX Chart .......................................................20- 1

MX Component...............................................2- 1

MX Links........................................................20- 1

MX Sheet menu ..............................................5- 1

MXComShConv.exe .......................... 20- 2, 20- 3

[O]

New data location ................................. 6- 3, 6-55

No. of cells......................................................6-14

No. of characters............................................6-13

No. of lines to be saved .............. 6-32, 6-34, 6-45

Number of set devices.......................... 6- 8, 6-54

Off time String ...................................... 6-56, 6-60

On time String ...................................... 6-56, 6-60

Operation day ....................................... 6-15, 7- 4

Operation Interval .... 6-15, 6-42, 6-51, 6-62, 6-71

Operation time .......... 6-15, 6-42, 6-51, 6-71, 7- 5

Operation when cell is full...............................6- 4

Index - 1 Index - 1

[P]

[R]

Paste Cell Area ............................................ 12- 3

Preset cell areas............................................. 6- 9

Processing of MX Sheet ........................... APP- 5

Processing speed of MX Sheet ................ APP- 3

[S]

Remote password ................................... 6- 8,7- 3

Right-click ....................................................... 5- 1

[T]

Sample programs......................................... 18- 1

Setting Data Export .............................. 3- 1, 17- 1

Start Communication.................................... 10- 1

Status String .................................................. 6-56

[U]

Telephone line connectivity time zone ......... 6-13

Transport data .......................................... APP-13

Use.................................................................. 6- 1

[V]

Version Info. .............................................. APP- 1

[W]

Write function......................................... 3- 1, 6-43

[Z]

Zoom..................................................... 6-12, 6-47

Index - 2 Index - 2

Ind

Microsoft, Windows and Windows NT, Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries.

Pentium is a registered trademark of Intel Corporation in the United States and other countries.

Other company and product names herein are either trademarks of registered trademarks of their respective owners.

SH (NA)-080348E-K

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
