ф MITSUBISHI
ELECTRIC
DLP™ PROJECTOR
MODEL
FD 730U
FD730U-G
User Manual
HIGH-DEFINITION MULTIMEDLA INTERFACE
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE
EXPOSURE.
NOTE:
SINCE THIS PROJECTOR IS PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET SHALL BE INSTALLED NEAR
THE EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
WARNING CAUTION
Use the attached specified power supply cord, If The attached power cord is to be used exclusively for
you use another power supply cord, it may cause this product. Never use it for other products.
interference with radio and television reception.
Contents
Important safeQgUardS O 4
N EEG 6
Remote CO a AAA A Mea asin Wen 8
Installation ities eh eet ete tetas eter ear eats es setae nece. RE RE 9
Basic CONNECTIONS EEE EEE EEEREKELKEEREIEEEREKERKEKKEREREEEREEKERREEEEREKEEERREEEEREEKEEEEEREKEEKE KERN 11
EN 14
Base NER 16
Menu operation ..............— EERRERKEERERKREEERKREREERREREERR EEE EEE RE eters 19
Ingrcto[=Ncto)1U"=1(011= | CO O O KREIEREN 27
Network SO EEE Tv eA 30
Advanced TealuléS -<==:===: AA Aa Вован осо 33
Lamp replacement .....................—...eserrercerrercereerconeercor eee ne enter rene eee nee nana nee ae nee ee rar eee re 37
TrOUDIESNOOUING...............…rcrrersercensersrrras serrer senc er ras carre en se anses sera ses sas naar s bas eee beers ee 39
INICIO O ivan co cts ravie CENICIENTA inerte 43
soppsancagas----- - - -_ -— _—_— _-— -_ _— " _ _ mm H_m— rm Taare RT RT TT TE 44
Important safeguards
Please read all these instructions regarding your
projector and retain them for future reference. Follow
all warnings and instructions marked on the projector.
1.
Read instructions
All the safety and operating instructions should be
read before the appliance is operated.
Retain instructions
The safety and operating instructions should be
retained for future reference.
Warnings
All warnings on the appliance and in the operating
instructions should be adhered to.
Instructions
All operating instructions must be followed.
Cleaning
Unplug this projector from the wall outlet before
cleaning it. Do not use liquid aerosol cleaners. Use
a damp soft cloth for cleaning.
Attachments and equipment
Never add any attachments and/or equipment
without the approval of the manufacturer as such
additions may result in the risk of fire, electric
shock or other personal injury.
Water and moisture
Do not use this projector near water or in contact
with water.
Accessories
Do not place this projector on an unstable cart,
stand, tripod, bracket or table. Use only with a
cart, stand, tripod bracket, or table recommended
by the manufacturer or sold with the projector.
Any mounting of the appliance should follow
the manufacturer's instructions and should use
a mounting accessory recommended by the
manufacturer.
10.
Tk
12.
13.
14,
15.
Power sources
This projector should be operated only from the
type of power source indicated on the marking
label, If you are not sure of the type of power,
please consult your appliance dealer or local
power company.
Power-cord protection
Power-supply cords should be routed so that
they are not likely to be walked on or pinched
by items placed upon or against them. Pay
particular attention to cords at plugs, convenience
receptacles, and points where they exit from the
appliance. Do not put the power cord under a
carpet.
Overloading
Do not overload wall outlets and extension cords
as this can result in a fire or electric shock.
Objects and liquids
Never push objects of any kind through openings
of this projector as they may touch dangerous
voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of any
kind on the projector.
Servicing
Do not attempt to service this projector by yourself.
Refer all servicing to qualified service personnel.
Damage requiring service
Unplug this projector from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
(a) If the power-supply cord or plug is damaged.
(b) If liquid has been spilled, or objects have fallen
into the projector.
(c) If the projector does not operate normally after
you follow the operating instructions. Adjust
only those controls that are covered by the
operating instructions. An improper adjustment
of other controls may result in damage and
may often require extensive work by a qualified
technician to restore the projector to its normal
operation.
(d) If the projector has been exposed to rain or
water.
la! If the nraiectar has hean draonnaed ar tha
Important safeguards (continued)
WARNING:
Unplug immediately if there is something wrong
with your projector.
Do not operate if smoke, strange noise or odor comes
out of your projector. It may cause fire or electric
shock. In this case, unplug immediately and contact
your dealer.
Never remove the cabinet.
This projector contains high voltage circuitry. An
inadvertent contact may result in an electric shock.
Except as specifically explained in User Manual, do
not attempt to service this product by yourself. Please
contact your dealer when you want to fix, adjust, or
inspect the projector.
Do not modify this equipment.
It can lead to fire or electric shock.
Do not keep using the damaged projector.
If the projector is dropped and the cabinet is
damaged, unplug the projector and contact your
dealer for inspection, It may lead to fire if you Keep
using the damaged projector.
Be sure to unplug the power cord from the wall
outlet if the projector is fractured or deformed.
Otherwise, it may result in fire or electric shock. Ask
your dealer for repair.
Do not face the projector lens to the sun.
It can lead to fire.
Use correct voltage.
If you use incorrect voltage, it can lead to fire.
Do not place the projector on uneven surface.
Place the projection on a leveled and stable surface only.
Do not look into the lens when it is operating.
It may hurt your eyes. Never let children look into the
lens when it is on.
Do not put any objects immediately in front of the
lens while the lamp is on.
The lens and the objects get hot and can cause fire or
breakdown.
Do not unplug the power cord during operation.
It can lead to lamp breakage, fire, electric shock or
other trouble.
Do not touch the exhaust vents and bottom plate.
Do not touch them or put other eauipment close to
Do not use the projector with condensation on it.
It can lead to breakdown or other failure.
Place of installation
For safety's sake, do not use the projector at any place
subjected to high temperature and high humidity.
Please maintain an operating temperature, humidity,
and altitude as specified below.
* Operating temperature: between +41°F (+5°C) and
+95°F (+35°C)
Operating humidity: between 30% and 90%
Never put any heat-producing device under the
projector to prevent the projector from being
overheated.
® Do not install the projector at a place that is
unstable or subject to vibration.
® Do not install the projector near any equipment that
produces a strong magnetic field. Also refrain from
installing the projector near any cable carrying a
large amount of current,
* Place the projector on a solid, vibration-free
surface. Otherwise it may fall, causing serious injury
or damage.
® Do not stand the projector on its end. It may fall,
causing serious injury or damage.
es Slanting the projector more than +10° (right and
left) or +15° (front and rear) may cause trouble or
explosion of the lamp.
* Do not place the projector near air-conditioning
unit, heater, or humidifier to avoid hot or moist air
to the exhaust and ventilation hole of the projector.
* Do not place the projector in the following places.
Otherwise, a short circuit, heat generation, or melting
of the power cord coating may occur, causing fire,
electric shock, product failure, or deformation.
« Qutdoors or non air-conditioned place
* Place where a gas such as a hydrogen sulfide is
generated (i.e. hot spring)
« Place where there is too much salt such as near
the coast
* Be sure to use this projector at an altitude of less
than 1500 meters.
Do not place a container containing water or other
liquid on the projector.
If water spills on or enters the projector, it may result in
fire or electric shock.
Do not put any object that is heavy or larger than
the outer frame on the projector.
FE Ln rn el ee cen «ай Моно нов E rem ms nee re ER me a nn Wee o Em el em rr ap e
Overview
|
CONFUTER VIDED
ALTE PET
Terminal panel
Lamp cover
Lens
FOCUS ring
ZOOM ring
LENS SHIFT dial
Remote control sensor (front)
Speaker
Lock bar
Intake vent
10 Control panel
11 Exhaust vent
12 Power jack
13 Terminal panel
14 Kensington Lock
CNOA WON ==
Caution:
* Do not replace the lamp immediately after using the
projector because the lamp would be extremely hot
and it may cause burns.
1 AUTO POSITION/A button
2 EFFICIENT MODE button
3 STATUS indicator
4 POWER indicator
5 COMPUTER/< button
6 Y button
7 VIDEO/P button
8 KEYSTONE/ENTER button
9 MENU button
10 POWER button (ON/STANDBY)
The status 15 changed between ON and STANDBY.
1 Remote control sensor (rear)
Overview (continued)
Bottom side
1 Adjustment feet
Remote control
1 ON button
2 MAGNIFY button
3 VOLUME UP, DOWN buttons
8 4 KEYSTONE button
9 5 MENU button
C-— 10 6 ENTER button
7 AV (Audio/Video) MUTE button
This model does 8 STANDBY button
not have this 9 ASPECT button
function.
10 EFFICIENT MODE button
— 11 11 AUTO POSITION button
12 A, V, <, > buttons
12 13 FREEZE button
— 13 14 VIDEO, S-VIDEO buttons
14 15 COMPUTER (1, 2) buttons
This model does 16 HDMI button
not have these — 15
functions. — 16
Remote control
Battery installation
Use two (AA, Bb) size batteries.
Inserting the batteries into the remote control
1. Remove the back cover of the remote control by pushing the battery compartment door in the direction of the arrow.
2. Load the batteries making sure that they are positioned correctly (+ to +, and - to -).
* | oad the batteries from - spring side, and make sure to set them tightly.
3. Replace the back cover.
Removing the batteries from the remote control
Remove the back cover of the remote control and take out the batteries.
Caution:
Use of a battery of wrong type may cause explosion.
e Only Carbon-Zinc or Alkaline-Manganese Dioxide type batteries should be used.
* Dispose of used batteries according to your local regulations.
* Before you dispose of the batteries, insulate them by placing insulation tape on the positive (+) and negative (-)
terminals. If you dispose of the batteries together with other conductive objects such as a metal piece, they may short
out, resulting in fire or explosion.
Batteries may explode if misused. Do not recharge, disassemble, or heat the batteries, or put them into fire or water.
Be sure to handle the batteries according to the instructions.
Load the batteries with its positive (+) and negative (-) sides correctly oriented as indicated on the remote control.
Keep batteries out of reach of children and pets. If children swallow the battery, see a doctor immediately.
Remove the batteries, if the remote control is not used for a long time.
Do not combine a new battery with an old one.
If the solution of batteries comes in contact with your skin or clothes, rinse with water. If the solution comes in contact
with your eyes, rinse them with water and then consult your doctor.
* Do not camry or store the batteries together with metallic ballpoint pens, necklaces, coins, or hairpins. Otherwise, they
may short out, causing explosion or liquid leakage and resulting in fire or injury.
Do not store the batteries where they are exposed to direct sunlight or subjected to high temperature and high humidity.
High temperature and high humidity may cause corrosion or liquid leakage.
Operation range (of the remote control)
The maximum operation distance of the remote control is about 10 m (or about 32 feet) when the remote control is
pointed at the remote control sensor of the projector. When the remote control is pointed to the screen, the distance
from the remote control to the projector via the screen should be 5 m or less. However, the operation distance varies
depending on the type of the screen used.
Reception angle (horizontal) Reception angle (vertical)
20°
20" —
Installation
Screen size and projection distance
Refer to the following tables to determine the screen size and projection distance.
* The figures in the tables are approximate and may be slightly different from the actual measurements.
* The lens shift height shows distances from the factory default position.
Screen helght (SF)
Hd
Screen width (SW)
Screen size (16:93) Projection distance (L) Lens shift height
Diagonal size | Width (SW) | Height (SH) e Shortest (Wide) | Longest (Tele) Hi H2
inch | cm | inch | em | inch | em | inch | em | inch | m | ineh| m | inch | em | inch | cm
40 102 30 89 20 20 6.6 17 47 1.2 71 1.8 3 7 2 6
60 152 22 133 29 Го 10 29 Mm 1.8 107 | 2.7 4 11 4 8
80 | 203 | 70 | 177 | 39 | 100 | 13 34 96 | 24 | 144 | 36 6 14 5 12
100 | 254 87 221 49 125 16 42 120 3:1 180 4.6 7 18 6 16
120 | 305 | 105 | 266 59 149 20 50 145 | 37 | 216 | 55 В 21 7 19
150 | 381 131 332 74 187 25 63 182 4-6 271 6.9 11 27 9 23
200 | 508 | 174 | 443 98 249 33 ВА 243 | 62 362 8.2 14 36 12 31
250 | 635 | 218 | 553 | 123 | 311 41 105 | 304 | 7.7 - - 18 45 15 39
300 | 762 | 261 664 | 147 | 374 49 126 | 365 9.3 - - 21 54 18 47
When the aspect ratio of the screen is 4:3
When the aspect ratio of the screen is 4:3, the positional relation between
the projected image and the screen is as shown on the right. Refer to the
following table for installation,
* When the aspect ratio of the image is 16:9
del
SH
H
NL
-——
m
Lai
— Screen (4:3)
Image (16:9)
Screen size (4:3)
Size of the projected image (16:9)
MNisnnnal elza! Width SW | Helaht (EH | Diagonal eizal Мень МАЛ Го наши mi |
Black space
Hd
Projection distance (L)
Lens shift height
| Ghorteet Mido | Lonanet Meta |
Ня | HA
Installation (continued)
Front projection, ceiling mounting
For ceiling mounting, you need the ceiling mount
Kit designed for this projector. Ask a specialist for
installation. For details, consult your dealer.
* The warranty on this projector does not cover any
damage caused by use of any non-recommended
ceiling mount Kit or installation of the ceiling mount
Kit in an improper location,
—
* When using the projector mounted on the celling,
set IMAGE REVERSE in the INSTALLATION menu
to MIRROR INVERT. See page 23.
e When the projector is mounted on the ceiling,
images may appear darker than those projected in
the case of tabletop mounting. This isn't a product
malfunction.
Ceiling mount installation
If you wish to install the projector using a ceiling
mount, please use the screw holes as the illustration
shows,
Important:
* Screws are not included. Please obtain the
appropriate screws for your type of ceiling. (M4
diameter)
e |t is recommended that you keep a reasonable
space between the bracket and the projector to
allow for proper heat distribution.
kit, (Don't use screw holes without arrow marks.) In
this case, make sure that the screw is inserted in
the projector at least 5 mm. The length of the screw
should be 20 mm or shorter. Also make sure that
no electrical current is flowing in the mount kit due
to current leakage or other cause.
Rear projection
Ask a specialist for installation. For details, consult
your dealer.
P
* For rear projection, set IMAGE REVERSE in the
INSTALLATION menu to MIRROR. See page 23.
Caution:
* Placing the projector directly on a carpet impairs
ventilation by the fans, causing damage or failure.
Put a hard board under the projector to facilitate
ventilation.
* Place the projector at least 50 cm (or 20 inch) away
from the wall to prevent the intake vents and the
exhaust vents that emit hot air from being blocked.
* Do not use the projector in the following locations
and manners, which may cause fire or electric
shock,
® [na dusty or humid place.
® [na sideways or upside-down position.
« Near a heater.
® |n an oily, smoky, or damp place such as a
Kitchen.
In direct sunlight.
* Where the temperature rises high, such as in a
closed car.
* Where the temperature is lower than +41°F (or
+5°C) or higher than +95°F (or +35°C ).
* Keep foliage plants and pets away from the
projector. The temperature around the exhaust
Basic connections
This projector can be connected with various devices such as a VCR, video camera, videodisc player, and personal
computer that have analog RGB output connectors.
Important:
* Make sure that the connected device is turned off before starting connection.
* Plug in the power cords of the projector and the connected devices firmly. When unplugging, hold and pull the
plug. Do not pull the cord.
* When the projector and the connected devices are located too close to each other, the projected image may be
affected by their interference.
* See the owner’s guide of each device for details about its connections.
Projector + AV device
S-VIDEO
option) *— [Ш \
VIDEO pe {| |]
(option)
AUDIO IN-3L —
(Option)
AUDIOIN-3H —
= To audio outpui (L) — — — IT
| |
F x ] — TO audio output (A) —
VCR, etc.
«== To video output «= = Е
<— To S-Video output «+ [mm —
Important:
* Match the colors of the video and audio plugs on the Audio cable with those of the terminals.
* Speaker output is mono.
Projector + DVD player or HDTV decoder
Some DVD players have an output connector for 3-line fitting (Y, Св, Cg). When connecting such DVD player with this
projector, use the COMPUTER/COMPONENT VIDEO [N terminal.
Audio cable (option)
DVD player or HDTV decoder i . y
пон «Пс „| о — O aa.
FA _ | ] OO ¿+ ES CS.
bg - He {EE == НН =— D и | 1
To audio output a EE TE
tt!
CEA EN BNC - RCA connector (option) = ñ —
Basic connections (continued)
Connection (for video equipment having an HDMI terminal)
Equipment having an
HDMI terminal
=
| To HDMI terminal
[ir =! ira
iil HDMI
y
HDMI (with HDMI logo) cable (option)
Important:
Use a commercially available HDMI (with HDMI logo) cable.
You don’t have to connect any cable for audio input. You can input video and audio using an HDMI cable only.
When HDMI audio isn't output, it may be output by turning off the power of the video equipment with the projector
and the video equipment connected to each other and then turning back on the power.
Some cables may not be connected correctly depending on the size and shape of their connectors.
To connect to the video device using a splitter, make sure to use the splitter compliant with the HDMI 1.3 Deep
Color Standard. If you use the splitter not compliant with the HDMI 1.3 standard, this projector may not display
any image or not operate correctly.
When you connect this projector and a Digital device (such as a DVD player) vía the HDMI terminal, black
color may appear dark and deep, depending on the type of the connected device.
This depends on the black level setting of the connected device. There are two kinds of methods to digitally
transfer image data, in which different black level settings are employed respectively. Therefore, the specifications
of the signals output from DVD players differ, depending on the type of the digital data transfer method they use.
Some DVD players are provided with a function to switch the methods to output digital signals. When your DVD
player is provided with such function, set it as follows.
EXPAND or ENHANCED -+ NORMAL
* See the users guide of your DVD player for details.
Set INPUT LEVEL of ADVANCED MENU in the IMAGE menu depending on the device to be used.
Basic connections (continued)
Projector + Computer
For computer with mini D-SUB
PC audio cable (option)
Computer cable
To PC audio output 3
Necessary when outputting to both Computer
a PC moniter and the projector.
Io Computer cable (option) JT
MONITOR OUT
Audio cable (option) op Os. = |
For analog connection:
1.
2.
Connect one end of the supplied computer cable to the COMPUTER/COMPONENT VIDEO IN terminal (1, 2) of the
projector.
Connect the other end of the computer cable to the monitor port of the computer.
For monitor connection:
Connect the computer cable from the monitor to the MONITOR OUT terminal of the projector.
Images may not be displayed correctly depending on the type of the input signal. See the instruction manual of
the monitor.
Signals are coming from the COMPUTER/COMPONENT VIDEO IN-1 terminal of the projector.
MONITOR OUT is not output during the STANDBY state.
When signals are coming from both COMPUTER/COMPONENT VIDEO IN terminals (1, 2), images are projected
from the terminal (1 or 2) currently or last selected in the projector's menu.
important:
When you use a longer computer cable instead of the provided cable, the image may not be projected correctly.
Some computers require additional connectors or analog RGB output adapters to be connected with this
projector. Contact your dealer for further information.
This projector uses stereo mini jack for its audio input. Check the type of the audio output terminal of the
connected computer and prepare a proper cable for connection. Some computers don't have the audio output
terminal.
Speaker output is mono.
When the audio cable is connected to the AUDIO OUT terminal. the speaker outout 1s muted
Preparation
Preparation for projection
1. Attach the provided power cord to the projector.
2. Plug the power cord in the wall outlet,
3. Remove the lens cap.
Warning:
* [Do not look into the lens directly when the projector
Is on.
* The lens cap is for protecting the lens. If you leave
the lens cap on the lens with the projector turned
on, it may be deformed because of heat build-
up. Remove the lens cap when you turn on the
projector.
* One of power cords for the U.S., Europe,
U.K., Australia, and South Korea is provided
appropriately.
* This projector uses the power plug of three-pin
grounding type. Do not remove the grounding pin
from the power plug. If the power plug doesn t fit
your wall outlet, ask an electrician to change the
wall outlet.
* In case that the power cord for the U.S. is provided
with this projector, never connect this cord to any
outlet or power supply using other voltages or
frequencies than rated. If you want to use a power
supply using other voltage than rated, prepare an
appropriate power cord separately.
* Use 100-240 V AC 50/60 Hz to prevent fire or
electric shock.
* Do not place any objects on the power cord or
do not place the projector near heat sources to
prevent damage to the power cord. If the power
cord should be damaged, contact your dealer for
replacement because it may cause fire or electric
shock.
* Do not modify or alter the power cord. If the power
cord is modified or altered, it may cause fire or
electric shock.
Caution:
* Plug in the power cord firmly. When unplugging,
hold and pull the power plug, not the power cord.
* Do not plug in or out the power cord with your
hand wet. It may cause electric shock.
* When you move the projector, turn off the power,
uno tha nowaer enrd fram tha wall auitlat and
Adjusting the position of the
projected image
To adjust the position of the projected image on the
screen, use the LENS SHIFT dial.
1. Rotate the LENS SHIFT dial inside the top cover of
the projector to adjust the image position.
« Rotating the dial clockwise (or counterclockwise
for a ceiling-mount projector) moves the image
up.
« Rotating the dial counterclockwise (or clockwise
for a ceiling-mount projector) moves the image
down.
* Be careful not to be caught in the opening in the
lens while the lens is moving.
* While the lens shift is working, the screen may
flicker.
* Projected images may become distorted, have
decreased resolution, or have shadows at their
corners if they are positioned close to the top or
bottom.
Adjustment of the projection angle
For the best projection, project images on a flat screen
installed at 90 degrees to the floor. If necessary, tilt the
projector using the two adjustment feet on the bottom
of the projector.
Using the adjustment feet (front)
1. Tilt up the projector to the appropriate angle.
2. Rotate the adjustment feet (front) for fine
adjustment,
Important:
e Install the screen on a flat wall at 90 degrees to the
floor.
FE Do o RL se o UB El Bit A о я ар бой EA E E Ed
Preparation (continued)
When projected images are
distorted to a trapezoid
To correct vertical keystone distortion, press the
KEYSTONE button on the projector or the remote
control to display KEYSTONE, and adjust the image by
pressing the A, Y button (or VOLUME 4, Y button
on the remote control).
In the following cases:
Press the Y button. Press the A button.
® |n the keystone adjustment, you can obtain an
optimum result when the LENS SHIFT dial is at the
factory default position. (See page 9.)
* You can correct the vertical keystones. However,
their adjustment ranges are limited in such
correction.
Important:
* When the keystone adjustment is carried out, the
adjustment value is indicated. Note that this value
doesn't mean a projection angle.
* The allowable range of the adjustment value in
the keystone adjustment varies depending on
the installation condition, input signal and aspect
settings in MENU.
* When the keystone adjustment takes effect, the
resolution decreases. In addition, stripes may
appear or straight lines may bend in images with
complicated patterns. They are not due to product
malfunctions.
* Noise may appear on the screen during the
keystone adjustment because of the type of the
video signal being projected and the setting values
of the keystone adjustment. In such cases, set the
keystone adjustment values in the range where the
image is displayed without noise.
* When the keystone adjustment is carried out, the
image may not be displayed correctly because of
the type of input signal.
Basic operation
4 — ===
6}
A
J
EFFIGIFNT
AUTO POSITION MODE
Lat as EI
EOMPLITER VIDES STATUS FOWER
REYETOME
=] o ©
| Cr rer
Lau,
Power-on °
1. Turn on the device connected to the projector first.
2. Plug the power cord in the wall outlet.
* The POWER indicator lights up.
Do not cover the lens with the lens cap while the
lamp is on.
* The projector starts warming up when the POWER
button is pressed. During the warm-up process,
images may appear dark and no commands are
e |fthe power cord is unplugged from the wall
outlet before the projector is cooled down
completely after use, the fans may start rotating
when the power cord is plugged in next time
and the POWER button may not function. In this
case, wait for the fans to stop and press the
POWER button to light the indicator.
3. Press the POWER button on the control panel or
the ON button on the remote control.
« |t may take about one minute for the lamp to
light up.
* The lamp occasionally fails to light up. Wait a
few minutes and try to light the lamp again.
accepted.
By blinking red, the STATUS indicator indicates that
the lamp should be replaced soon. Replace the
lamp when the STATUS indicator blinks red. (See
page 39 and 43.)
Images may not be projected with good quality in
an extremely hot or cold environment. (This is not a
product malfunction.)
In order to ensure the safety in case of trouble with
the projector, use an electrical outlet having an
earth leakage breaker to supply the power to the
projector. If you do not have such outlet, ask your
dealer to install it.
* After the POWER button is pressed, the image 4. Adjust the focus by turning the focus ring.
may flicker before the lamp becomes stable. « You are recommended to adjust the focus at the
This Is not a product malfunction. screen center.
* Regardless of the setting of LAMP MODE in the 5. Choose your desired external input source using
QUICK MENU or the INSTALLATION menu or
the EFFICIENT MODE menu, the STANDARD
lamp mode is activated by default whenever the
projector is turned on. The LAMP MODE is set
to either STANDARD or LOW depending on the
the COMPUTER, VIDEO or HDMI button.
* The input source is switched between
COMPUTER1, COMPUTER2, and HDMI at
every press of the COMPUTER button on the
Basic operation (continued)
* To avoid permanently imprinting a fixed image
onto your projector, please do not display the
same stationary images for long period.
6. Adjust the image size by turning the zoom ring.
7. Adjust the vertical position of the displayed image
by turning the LENS SHIFT dial.
If necessary, adjust the focus and zoom again.
When fine streaks are seen on projected
images
This Is due to interference with the screen surface and
Is not a malfunction. Replace the screen or displace
the focus a little.
Power-off
Use the following procedure to turn off the projector,
The lamp may deteriorate If the projector is powered
off and on repeatedly within 30 minutes after the lamp
is lighted.
1. Press the POWER button on the control panel or
the STANDBY button on the remote control.
* The message "POWER OFF? YES : PRESS
AGAIN" appears on the screen.
® To cancel, press any button except the POWER
button. (Some buttons on the remote control
don't function for cancel.)
2. Press the POWER button on the control panel or
the STANDBY button on the remote control within
10 seconds again.
* The lamp will go out and the STATUS indicator
will start blinking.
Wait about 90 seconds for the STATUS indicator to
be turned off.
4. Unplug the power cord.
* The POWER indicator will go out.
e |f the power cord should be unplugged
accidentally while either the STATUS indicator is
blinking or the lamp is on, allow the projector to
cool down for 10 minutes with the power off. To
light the lamp again, press the POWER button
(or ON button). If the lamp doesn’t light up
immediately, repeat pressing the POWER button
(or ON button) two or three times. If it should still
Ca)
(Wait about 10 minutes before turning the projector
back on.)
« Before shutting down the projector, be sure to close
the menu screen. If you shut down the projector
without closing the menu, the setting data of the
menu may not be saved.
* |f you shut down the projector while controlling
the projector using the network function, the
application software such as ProjectorView may
fail. For details, see “User Manual of LAN Control
Utility” contained in the CD-ROM.
AUTO POSITION button
When the image supplied from the computer is
displaced, carry out the following procedure,
1. Project a bright image containing as many texts
and characters as possible.
2. When the screen saver has been enabled, disable
It.
3. Press the AUTO POSITION button.
* The projector automatically makes optimum
positional settings for the input signal.
* When you press the AUTO POSITION button
while a signal from a video device (or signal
marked with *2 on page 46) is being input, a
window to select either of the following two
adjustment modes is displayed.
- AUTO ADJUST:
Suitable for signals supplied from a
computer.
- VIDEO SIGNAL:
Suitable for signals supplied from a video
device such as DVD. (When you select
this mode, the adjustment using the
RESOLUTION (MEMORIZE) menu (page 25)
becomes unavailable.)
Select an appropriate mode using the < or >
button and then press the ENTER button.
* |[f the projected image is still displaced even after
pressing the AUTO POSITION button several times,
refer to the procedure to adjust computer images.
(See pages 28 and 29.)
* When you carry out this procedure with a dark
image, the image may be displaced.
Basic operation (continued)
AV mute
The video and audio signals are temporarily muted
when the AV MUTE button is pressed. To cancel
muting, press the AV MUTE button again.
Setting the aspect ratio
You can change the aspect ratio of the input video
signal (or the ratio of width to height of the image).
Change the setting according to the type of the input
video signal.
With the remote control:
1. Press the ASPECT button.
* Every time the ASPECT button Is pressed, the
aspect mode changes from AUTO to 16:9, to
NATIVE, and back to AUTO.
With the FEATURE menu:
(See page 22 for menu setting.)
1. Display the FEATURE menu.
2. Select ASPECT by pressing the A or Y button.
PIES y Y
FEO e
fe — o de
f na
FER
E ASPECT 4 AUTO ›
3. Select your desired aspect ratio by pressing the 4
or P button.
To cancel the menu:
4, Press the MENU button.
Important:
* When a 4.3 image is kept displayed for a long
time before displaying 16:9 image, the afterimages
of the black bars may appear on the 16:9 image
screen. Consult your dealer in this case.
Caution:
e The lamp can’t be lit again for one minute after
turned off for safety purpose. It will take another
one minute for the STATUS indicator to go out. If
you want to turn on the projector again, wait until
the indicator goes out, and then press the POWER
button.
+ [ha exhaust fans rotate faster as the temperatura
Wall Screen
This function is to reproduce natural color tones
when images are projected directly onto a screen
or wall surface. You can select from BEIGE, LIGHT
BLUE, LIGHT GREEN, PINK, BLACK BOARD, WHITE
BOARD, and OFF, to match the color of the screen or
wall to be used for projection.
1. Display the INSTALLATION menu. (See page 23 for
more details.)
[a (pt ;
DS]
2. Press the A or ¥ button to select WALL SCREEN.
3. Press the < or P button to select the color
closest to that of the screen on which images are
projected.
* When the GAMMA MODE setting is changed,
images may not be displayed correctly.
* When OFF or BLACK BOARD/WHITE BOARD is
selected, the density cannot be adjusted.
« When WHITE BOARD is selected,
BrilliantColor™ in the COLOR ENHANCER
menu of the IMAGE menu cannot be used.
Additionally, THEATER in the COLOR
ENHANCER menu of the IMAGE menu has
no effect and is automatically canceled when
WHITE BOARD is selected.
4. Press the ENTER button.
| = LIGHT BLUE 4 1 >|
5. Press the «< ог № button to adjust the density of the
selected color.
When connecting to a laptop computer:
When this projector is connected to a laptop
computer, there may be times when images may not
be projected. When it occurs, set the computer so that
it can output signals externally, The procedure varies
across computers in use, See the instruction manual
of your computer.
Menu operation
As one of the two types of MENU display following QUICK MENU appears on the screen when pressing MENU button on the remote control. In
addition, DETAIL MENU (See page 21) appears when selecting DETAIL MENU in this MENU and pressing ENTER button,
« Comparing QUICK MENU with DETAIL MENU, if the contents in those two menus are same each other, the functions in those two menus are
same as well.
* To close QUICK MENU or DETAIL MENU, press MENU button when MENU is displayed.
QUICK MENU
* Menus are not displayed when no signai is supplied to the projector.
MENU COLOR
SIANDEY MODE
INPUT
*1 Not available with certain signals
“2 Not available when the Input signal Is from the VIDEO IN or S-VIDEO IN terminal.
QUICK MENU Basic operation 3. Pressthe À or Y button to select CONTRAST
Several settings can be adjusted using the menu. D co 4 5 > |
Example ; Contrast setting
1. Press the MENU button.
4. Press the < or P button to adjust the contrast.
= 4 — = 1
“чо E
Menu operation (continued)
Menu Options
Set the following options provided in the respective menus.
1. QUICK MENU
Menu option Setting Feature description
AUTO Automatically sets an optimal color balance based on the Input signal.
Use this setting for most Cases.
PRESENTATION Makes projected images bright and crisp.
COLOR ENHANCER STANDARD Makes projected Images look natural,
THEATER Makes projected images soft and smooth, Best suited for movies,
USER Reflected by the value set In IMAGE menu. (See page 27.)
CONTRAST +30 Adjusts the contrast of projected Images. (See page 27.)
BRIGHTNESS +30 Adjusts the brightness of projected images. (See page 27.)
COLOR TEMP 4 opllons Adjusts the color temperature. (See page 27.)
SHARPNESS +5 Adjusts the sharpness of projected Images. (See page 27.)
STANDARD Select this setting when you want to view images In a well-lit room.
Select this setting when you want to view images at a moderate light
LAME MODE Intensity The operating sound Is consequently reduced, and the lamp
LOW lifetime becomes longer.
» When this mode 15 switched, projected Images may flicker.
« [f this mode Is frequently switched, the lamp may be deteriorated.
ALTIÖ Select to change the aspect ratio automatically depending on the input
signal. (Select this option for normal use.)
ASPECT 16:9 Select to project images in full size (1920 x 1080 pixels) imespective of
type of input signal.
NATIVE Select to project Images in their original size as Input.
USER MENU Displays the menu Item selected in SELECT USER MENU.
SELECT USER MENU Select the [tem To display In USER MENU.
DETAIL MENU Moves to DETAIL MENU,
EE
5. EmAANCEN: 4 am
_ В [const « , a
DC EAIGHTNESS 4 a |
1 coLOR TEMP 4 sua p
S SHARPNESS 4 o ›
GE Laure move 4 momo |
| AsPECT 4 AUTO »
== USER MENU
5 Usen meno 4 com }
Es DETAL MENU ок)
® You cannot adjust COLOR TEME when WALL SCREEN in the INSTALLATION menu is set to other than OFF
* When COLOR ENHANCER is switched, projected images may be distorted.
* The STANDARD lamp mode is activated by default whenever the projector is turned on. When the LOW LAMP MODE has been chosen, the
default STANDARD lamp mode is switched to the LOW lamp mode in 1 minute.
2. INFORMATION menu
№ мест COMPUTER?
| RESOLUTION 1024x788
[ee FREQUENCY 75.04 Hz
% = HORIZONTAL B0.08 KHz
Menu option Feature description
This menu shows a lamp operating time (hour) calculated assuming that LAMP MODE is LOW.
« When the LAMP MODE is STANDARD, this menu shows a longer lamp operating time than
the actual time. (See page 38 for the Interval of lamp replacement.)
LAME TIME (LOW) = When the lamp operating time is 0 to 10 hours, "0H" is displayed. When the lamp operating
time exceeds 10 hours, the actual hours are displayed.
= When the lamp operating time reaches 3750 hours, the bar turns yellow. When it reaches
4750 hours, the bar turns red.
(The lamp lifetime is 5000 hours.)
INPUT Indicates the name of the terminal to which the currently projected video signal is being input.
RESOLUTION Indicates the resolution of the currently projected video signal.
VERTICAL FREQUENCY Indicates the vertical frequency of the curently projected video signal.
ORIO NACER Indicates the horizontal frequency of the currently projected video signal.
QUENCY
SYNC. TYPE Indicates the type of the sync signal for the currently projected video signal.
Menu operation (continued)
DETAIL MENU
“ Menus are not displayed when no signal is supplied to the projector.
= IMAGE | COLOR ENHANCER |
Menu operation (continued)
Basic operation 5. Press the A or ¥ button to select AUTO POWER OFE
Several settings can be adjusted using the menu. 0 AUTO POWER q 775 >
Example : Auto power off time setting = ON a
1. Press the MENU button. @ AUTO POWER 4 отт "
2. Select the DETAIL MENU and press the ENTER button (or Y
Press the < ог № button to adjust the auto power off time.
button). 6.
o a ;
E AUTO POWER 4 OFF »
ar POWER 4 ent »
7. Exit the menu by pressing the MENU button several times.
3 Important:
* When the button doesn't function, unplug the power cord from the
wall outlet. Wait about 10 minutes, plug the power cord in, and try
again,
* After selecting the items marked with EJ , press the ENTER but-
4. ton.
EE WALL SCREEN 4 b
Menu Options
Set the following options provided in the respective menus.
1. IMAGE menu
Menu option setting Feature description
AUTO Automatically sets an optimal color balance based on the Input signal.
Use this setting for most cases.
| PRESENTATION Makes projected Images bright and crisp.
SANA ENERNCER STANDARD Makes projected images look natural.
THEATER Makes projected Images soft and smooth. Best sulted for movies.
USER Adjusts the gamma curve, color Intensity, or balance. (See page 27.)
CONTRAST +30 Adjusts the contrast of projected images. (See page 27.)
BRIGHTNESS +30 Adjusts the brightness of projected Images. (See page 27.)
COLOR TEMP 4 options Adjusts the color temperatura: (See page 27.)
Adjusts the color tone of projected Images. (See page 27.) You cannot
COLOR +10 select this setting when the COMPUTER 1 or COMPUTER 2 or HDMI Is
selected as the input source.
TINT 410 Adjusts the color tint of projected images. (See page 27) You can select
this setting only when NTSC is selected as the input signal.
SHARPNESS +5 Adjusts the sharpness of projected images. (See page 27.)
ADVANCED MENU OK
NOISE REDUCTION ON/OFF Reduces noise of projected images when the Input signal is noisy
CT ON/OFF Comects smeared color borders.
For analog signal input: The input level of video signal differs among
45 devices t&o be connected. High input level causes solld white in displayed
IRC AT | VF
Image and low Input level causes displayed Image to get dark. Use this
Menu operation (continued)
2. INSTALLATION menu
Menu option Setting Feature description
OFF/BEIGE M)/ LIGHT Selects a desired setting based on the color of the screen or wall
WALL SCREEN BLUE P/ LIGHT GREEN on which images are projected. When selecting a setting other
E] PINK PI/BLACK than BLACK BOARD/WHITE BOARD, you can fine-tune the color b
BOARD/WHITE BOARD tone to the desired level on the 1 to 5 scale. (See page 18.) »
STANDARD Select this setting when you want to view images in a well-lit mena =}
room. AUTO »
Salect this setting when you want to view images at a moderate ve OFF b
LAMP MODE llght intensify The operating sound Is consequently reduced, and Fi) AUTO POWER 4 er »
LOW the lamp INetime becomes longer — BE mac CAPTURE un
« When this mode is switched, projected images may flicker. a sa _ фе = +
« [i this mode Is frequently switched, the lamp may be deterio- | —
rated. RACK COLOR d BLUE +
| LAN can be activated in STANDARD MODE. MONITOR OUT 2 MUTE MODE 4 ENT »
STANDBY MODE STANDARD cannot be activated. ll ve -— 4 OFF »
9 А, Power consumption can be lowered when selecting LOW, How- BE respeta { chossHacH Em >
ever, LAN and MONITOR OUT cannot! be activated.
If AUTO is selected, selects AUDIO 1 when the input source is
AUTO COMPUTER 1, selects AUDIO 2 whan the input source is COM-
PUTER 2, selects AUDIO 3 when the input source is VIDEO/S-
AUDIO INPUT VIDEO, selects HDMI when the input source ls HDMI.
AUDIO 1/AUDIO 2/AUDIO 3 Select the audio input.
MIX Selects MIX signal of AUDIO 1 and AUDIO 2. You can change the
balance of AUDIO 1/AUDIO 2 using MIX E.
When this mode is set to ON, the lamp is automatically lit when
‘the power cord Is plugged in the wall outlet. Select ON when you
AUTO POWER ON ON/OFF sel the projector at the calling.
« When the lamp is off, the projector is in standby. Use the
remote control to turn on the lamp.
Selects a desired timer setting until the projector enters the
AFTER OE EEE MG standby mode when there Is no signal Input from the source.
IMAGE CAPTURE SETUP Use to capture the screen for the splash screen. (See page 33.)
SPLASH SCREEN ON/OFF Select ON to display the splash screen when the projector is pow-
ered on.
Selects the background color that is displayed when there is no
BACK COLOR BLUE/BLACK/IMAGE sigrial input from the Source.
Use to choose the background, either BLACK, or IMAGE, which
АМ MUTE MODE BLACK/IMAGE will be displayed when the AV MUTE button |s pressed. When
IMAGE |s chosen, the splash screen will be displayed.
OFF Select this setting when you want to view Images from the front
with the projector set on the floor.
MIRROR Select this setting whan you want to view Images from behind the
MAGE REVERSE screen with the projector set on the floor.
Select this sefting when you want to view Images from behind The
INVERT E : ;
screen with the projector set at the ceiling.
Select this setting when you want to view Images from the front
MERCER. INVERT with the projector set at tha ceiling.
CROSS HATCH Select to show the test cross hatch pattern.
TEST PATTERN WHITE Select to show the maximum brightness Image.
BLACK PI Select to show the minimum brightness image.
* The STANDARD lamp mode is activated by default whenever the projector is turned on. When the LOW LAMP MODE has been chosen, the
default STANDARD lamp mode is switched to the LOW lamp mode in 1 minute.
i la Á ¡1 mm CTE A" LN TÚ A E TX EE > — ” KA u а В Ее в шлет, ae FEE FR а OE ATR J EEE
Menu operation (continued)
3, FEATURE menu
Menu option Setting Feature description
AUTO Select 1o change the aspect ratio automatically depending on the
input signal. (Select this option for normal use.)
ASPECT 16:0 Select to project images in full size (1920 x 1080 pixels) Imespective of
type of input signal.
NATIVE Select to project images in their Original size as input.
PASSWORD FUNCTION Usa this setting to activate or deactivate the password lock.
MENU POSITION 2 options Use this setting to change the position of the menu on the screen.
The film mode will be automatically activated when a film source sig-
nal is input.
AUTO Select AUTO for normal use.
CINEMA MODE When Tllcker occurs on the screen, frame dropping or other incorrect
display occurs, or jaggies on slanting lines ame remarkable, select
either FILM or VIDEO, which Improves the symptom better,
FILM Fixed to the film mode.
VIDEO The film mode will not be activated.
Select Auto to automatically set the appropriate video format In rela-
VIDEO SIGNAL 8 options tive 1o the input signal. If projected Images aren't displayed correctly,
select a desired video format manually
ALITO Select this setting to automatically change the SETUP mode.
Select this setting to Increase the density of black. Use this setting
OFF
SETUP when images are dark.
Select this selling to lower the density of black.
3.75%/7.5% « When7,5% is set, the brighiness is decreased by the setup can-
cel function for the U.S.
SPLIT oK Use to sprit the screen in two and display a computer image on the left
screen anda video image on the right screen. (See page 33.)
LANGUAGE 12 languages Selects a desired language for the menu. 225252525
QUICK MENU OK Moves to QUICK MENU.
RESET ALL OK Resets all menu settings except for PASSWORD FUNCTION and
LANGUAGE to the default.
e ‘You can select CINEMA MODE only when the input signal is a TVB0, TV50, 480i, 576i ог 1080p video signal.
— 3 и в mm e AUTO ›
2 пасти «о обман в В
©, MENU POSITION LE] ›
Lim VIDEO SIGNAL AUTO +
EJ SPLIT ox
= QUICK MENU ока
a RESETML O ox El
Menu operation (continued)
4. SIGNAL menu
Menu option Setting Feature description
Use to select the setting of RESOLUTION (MEMORIZE) already saved,
Impossible to select if no setting has been saved. AUTO is selected by
MEMORY CALL MENON, | ' default, It optimizes the signal format automatically depending on the
type of video signal supplied from the computer. Press the ENTER but-
ton to clear the setting already saved.
RESOLUTION The current resolution is displayed. To change the current setting, press
(MEMORIZE HI) the ENTER button to display the RESOLUTION (MEMORIZE) rmenu.
The new setting can be saved to MEMORY 1 or MEMORY 2.
VERTICAL The vertical frequency of the currently projected video signal Is dis-
FREQUENCY played.
HORIZONTAL . The horizontal frequency of the currently projected video signal Is dis-
FREQUENCY played.
The number of horizontal pixels of the currently projected video signal is
displayed. When you change the current setting, select EXECUTE, and
HORIZ. PIXELS 640-1920 then press the ENTER button, the image is automatically adjusted
according to the resolution you set, The adjustment result can be saved
to MEMORY 1 or MEMORY 2,
The number of vertical pixels of the currently projected video signal is
displayed. When you change the current setting, select EXECUTE, and
VERT LINES 350-1200 then press the ENTER button, the image is automatically adjusted 4028
according to the resolution you sat. The adjustment result can be saved Tea
to MEMORY 1 or MEMORY 2. on El
Press ihe ENTER button to start the automatic adjustment. At the com CANCEL ока
EXECUTE OK № etion of the automatic adjustment, am is di and you
El Er uen meet DRM o MEM. > SIGNAL RESOLUTION
The process to change the current resolution is canceled and the SIG- EMORIZE) menu
МНЕ en NAL mes is mansión. -
HORIZ. POSITION 0-999 Use to adjust the horizontal position of the projected image. №.
VERT, POSITION 0-999 Use to adjust the vertical position of the projected image. E i
FINE SYNC: 0-31 Use to eliminate flickering or blur, Il appears, viewing the projected USER I
image. = Бобом 4 1 >
TRACKING 0-9999 Use to eliminate vertical wide stripes, If appears, viewing the projected FL clave wom 4 1 »
image. A ver. sc: 4 AUTO »
AUTO The proper setting Is automatically selected. Be ups q or ›
AGE Select this option when connecting ihe projector to high definition video | = semen 4 0 »
COMPUTER INPUT equipment having R, G, and B output terminals. S sure, q 5 b
Select this option when connecting the projector to a DVD player or I sures 4 о >
YCeCa/YPaPn other device having Y Ca, and Ca (or Y Ps, and Pe) component video = SHUTTTERME] 4 5 E
output terminals.
OVER SCAN 100%-90% Use to adjust the display area of projected Image. SIGNAL USER menu
HOLD OEF ON Use to adjust the image when flagging occurs near the top of the
screen.
USER OK
CLAMP POSITION — 1-255 Use to comect solid white or solid black In the projected image.
CLAMP WIDTH 1-63 Use to correct solid black in the projected image.
Use to adjust the image when its motion doesn't run smoothly Select
VERL SYNC AUTO / OFF AUTO for normal use:
LPF ON / OFF Use to select whether or not to enable the LPF
SHUTTER(U) 006 = x adjust the image when noise appears on the top part of the
SHUTTER(L) 0-20 Use to adjust the image when noise appears on the bottom part of the
Image.
Menu operation (continued)
5. NETWORK menu
Menu option setting Feature description
sie: Displays PROJECTOR NAME. Displays PROJECTOR NAME In
ECTOR NAME blank when PROJECTOR NAME is not set.
SET Sel PROJECTOR NAME. Enter up to 15 characters (alphabets or
numeric characters).
NETWORK PASSWORD OK Sel the password for Web control or PJLink certification,
IP CONFIG OK Select this setting for IP Configuration.
Use this setting when you obtain IP CONFIG automatically by
DHCP ОМ 3] / OFF DHCP sarver
van vue наи жай Displays IP ADDRESS. However, |P ADDRESS Is not set as factory
IP Are default, and cannot be displayed. | |
SET Set IP ADDRESS. When DHCP ls se Ho ON, you cannot change
this setting.
че че ча. жи Displays SUBNET MASK. However, SUBNET MASK is not set as
TM factory default, and cannot be displayed.
SHENET WASH Sal SUBNET MASK. When DHCP is set to ON, you cannot change
SET
this setting.
ALZAN Displays DEFAULT GATEWAY However, DEFAULT GATEWAY is —
о LT Ма not set as factory default, and cannot be displayed. NETWORK IP CONFIG
Set DEFAULT GATEWAY When DHCP is set to ON, you cannot menu
SET
change this setting.
MAC ADDRESS XX-XX-XX-XX-XX-XX Displays MAC ADDRESS.
PJLink CERTIFICATION ON {OFF Use this setting for PJLink Certification.
NETWORK RESET OK F] Resets the Network Selling.
6. INFORMATION menu
Menu option Feature description
This menu shows a lamp operating time (hour) calculated assuming that LAMP MODE Is LOW.
= When the LAMP MODE Is STANDARD, this menu shows a longer lamp operating time than
the actual time. (See page 38 for the Interval of lamp replacemant.)
- ‘When the lamp operating time is 0 to 10 hours, "OH" is displayed. When the lamp operating LAMP Low,
ai OM time exceeds 10 hours, the actual hours are displayed. a TIME [|
= When the lamp operating time reaches 3750 hours, the bar turns yellow. When it reaches
4750 hours, the bar turns red. INPUT COMPUTERZ
(The lamp lifetime is 5000 hours.) UE 1024768
INPUT indicates the name of the terminal to which the currently projected video signal is being input. a don
RESOLUTION Indi El FREQUENOY ==
cates the resolution of the currently projected video signal.
VERTICAL FREQUENCY Indicates the vertical frequency of the currentiy projected video signal. Al FREQUENCY 60,02 КНЕ
ONTAI ЧР Bi; =F
tues FRE indicates the horizontal frequency of the currently projected video signal. ya SMA TEE sin
SYNC. TYPE Indicates the type of the sync signal for the currently projected video signal,
Image adjustment
Adjusting projected images
To adjust the brightness (CONTRAST and BRIGHT-
NESS):
You can make adjustments of the brightness of the projected image
using the menu.
(See page 20 or 22 for the menu options.)
1. Display the QUICK MENU or the IMAGE menu.
2, Select CONTRAST or BRIGHTNESS by pressing the A or Y
button.
3. Adjust the selected option by pressing the< or P button.
To cancel the menu;
4, Press the MENU button.
CONTRAST
Select to adjust the contrast of the image. Every time the P button is
pressed, the image becomes brighter and more clearly defined. Every
time the « button is pressed, the image becomes darker and less
clearly defined.
BRIGHTNESS
Every time the P button is pressed, the image becomes brighter,
Every time the «< button is pressed, the image becomes darker,
To adjust the color (COLOR and TINT):
You can adjust the color of the projected image using the menu,
(See page 22 for the menu options.)
1. Display the IMAGE menu.
2. Select COLOR or TINT by pressing the A or Y button.
* COLOR and TINT is selectable only when the input signal is
VIDEO.
* TINT is selectable only when the NTSC or 4.43NTSC signal
Is input.
3. Adjust the selected option by pressing the ог № button.
To cancel the menu:
4. Press the MENU button.
COLOR
Use to adjust the color density of the projected image. Every time the
= button is pressed, the color becomes darker. Every time the Dut-
ton is pressed, the color becomes lighter
TINT
Lise to adjust the tint of the projected image. Every time the# button
is pressed, the Image appears more greenish. Every time the «< but-
fon is pressed, the image appears more reddish.
To sharpen or soften the projected image (SHARPNESS):
You can adjust the sharpness of the projected image using the menu.
(See page 20 or 22 for the menu options.)
1. Display the QUICK MENU or the IMAGE menu,
2. Select SHARPNESS by pressing the 4 or Y button.
3. Adjust the selected option by pressing the< or > button.
To adjust the tone of white (To customize the color tem-
perature):
To set (and store) a user-defined color temperature, perform the fol-
lowing procedure.
(See page 22 for the menu options.)
Select COLOR TEMP in the IMAGE menu.
Press the € or > button to select USER PY.
Press the ENTER button.
Press the A or Y button to select the desired setting.
Press the < or P button to adjust the selected setting.
Repeat steps 4 and 5 for optimal adjustment results.
a oa LN
Ken] Mal too SGEN
=
de Ae | AA
se eee
- lw ww + * +
97 #4 += ww
AE
To cancel the menu:
7. Press the MENU button.
To enable the stored color temperature:
1. Set COLOR TEMP to USER in the IMAGE menu.
‘ About color temperature i
There are different variations in white color. Color temperature is a
way to show these variations in white. When the temperature is
low, white appears reddish. When the temperature rises, white
appears bluish. For example, you can change the temperature
using the following procedures.
To raise the temperature: Increase CONTRAST B (blue) and
decrease CONTRAST R (red).
To reduce the temperature; Decrease CONTRAST B (blue) and
increase CONTRAST R (red).
е |fyou set CONTRAST R, G, and B to negative values, the
brightness of the Image can't retain the original even when you
maximize the value of CONTRAST in the QUICK MENU or the
IMAGE menu.
Color Enhancer
You can set user-defined values for the brightness and hue using the
menu. (See page 22 for the menu options.)
1. Display the IMAGE menu.
Select COLOR ENHANCER by pressing the A or Y button.
Select USER PI by pressing the < or P button.
Press the ENTER button,
Select a setting you want to sel.
sn
125. ENNANCER 4 mo +
Image adjustment (continued)
BrilliantColor™
Use this setting to make colors with medium brightness, such as yellow and the skin tone appear natural. Press the 4 button to decrease the value
to lessen the effect. Press the p+ button to increase the value toheighten the effect. (BrilllantColor™ has no effect at value 0.)
6. Select a value by pressing the 4 or P button.
« For more enhanced color reproduction, set BrilliantColor™to 0. The white area of the color wheel is disabled, and you can reproduce true-
color images.
RGB-COLOR
Lise to adjust the color intensity of the projected image. Every time the» button is pressed, the color becomes thicker. Every time the 4 button is
pressed, the color becomes lighter,
RGB-TINT
Use to adjust the color balance of the projected image. Every time the > button is pressed, the image appears more greenish. Every time the € but-
ton is pressed, the image appears more reddish.
How to adjust the computer image
This projector automatically selects a proper signal format according to the type of video signal supplied from the computer. However, video signals
from the computer may not be projected correctly depending on the types of the computer and images to be projected. In such a case, make adjust-
ment according to the flowchart below.
When the size and position of
the computer image are not correct.
Project a bright computer image containing as many texts and characters as possible.
Note) Disable the screen saver if it is active.
|
Press the AUTO POSITION button. When a signal from a video device (or signal marked with "2 on page 46) 1s being input, a window
to select the adjustment mode is displayed. Select AUTO ADJUST using the ог № button and press the ENTER button.
Settings are automatically and optimally adjusted for the input signal. |
NO
|
Display the screen resolution setting menu of your computer
(Example: In the case of Windows™ PC, right-click on the desktop, select Properties, and click the
Settings tab to display the screen resolution setting.)
YES
resolution setting of your computer
is different from the setting of RESOLUTION
(MEMORIZE BI) in the SIGNAL menu
of the projector
NO
Select RESOLUTION (MEMORIZE Bl) in the SIGNAL menu
and press the ENTER button.
|
Sat HORLZ. PIXELS and VERT. LINES to the values of the screen resolution of your computer.
(Example: When the screen resolution of the computer is 1280x800, set HORIZ PIXELS to 1280 and
VERT LINES to 800.)
| Select EXECUTE and press the ENTER button.
| Automatic adjustment starts according to the selected resolution,
Image adjustment (continued)
How to adjust the image supplied from the computer using the menu:
Carry out the following procedures according to the sy
Wide Strips appear «eames sims sisi:
The projected image flickers.
The projected image is blurred. . nnn
The projected image Is displaced horizontally:..
The projected image is displaced vertically ..........c.......
The top part of the image flAgs. een
A solid black or solid white appears in the image. ........
The motion doesn't run smoothly. .. i »
Moise appears on the right or left half of the —
Noise appears on the top or bottom part of the Image.
1. Display the SIGNALmenu.
mptoms.
Adjust TRACKING in the SIGNAL menu.
...... Adjust FINE SYNC. in the SIGNAL menu.
… Adjust HORIZ. POSITION in the SIGNAL menu. Every time the < button is pressed, the
image moves to the right. Every time the P button is pressed, the image moves to the left.
Adjust VERT POSITION in the SIGNAL menu. Every time the « button is pressed, the
image moves down. Every time the P+ button is pressed, the image moves up.
. Change the setting of HOLD in the SIGNAL menu, Select ON E) , press the ENTER button,
and adjust BEGIN or END to minimize the flagging.
Adjust CLAMP POSITION or CLAMP WIDTH in the SIGNAL — USER menu.
... Adjust VERT SYNC in the SIGNAL - USER menu. Select AUTO for normal use.
.. Adjust SHUTTER(LS) or SHUTTER(RS) in the SIGNAL - USER menu.
Adjust SHUTTER(U) or SHUTTER(L) in the SIGNAL - USER menu.
2. Press the A or ¥ button to select an item to adjust.
3. Adjustthe selected item by pressing the 4 or P button.
To cancel the menu:
4. Press the MENU button,
* [Do not change the settings of the SIGNAL menu in
normal Use:
Simple method to adjust the image
To adjust the horizontal position:
the right side of the screen by adjusting TRACKI
To adjust the vertical position:
1. Align the left edge of the image with the left side of the screen by adjusting HORIZ. POSITION. Then, align the right edge ofthe image with
2. Repeat step 1 above to complete the adjustment of the horizontal position.
3. Align the upper edge of the image with the upper side of the screen by adjusting VERT. POSITION.
position
NG.
LPF (Progressive filter)
You can select whether or not to enable the LPE
Vertical or horizontal streak noise may appear on the projected image, depending on the type of the DVD player or game console you use. In such a
case, you can reduce such streak noise by enabling the LPE However, projected images become softened slightly
Network settings
You can set the network of the projector using the menu.
A NETWORK RESET ox)
Setting Projector Name
1. Display the NETWORK menu. (See page 22? for menu setting.)
2. Press the A or Y button to select PROJECTOR NAME.
3. Pressthe dor P button to select SETH] .
4. Press the ENTER button.
« PROJECTOR NAME screen appears.
— PROJECTOR MAME
[CODE : FOT30 v7 7%
LT
|+
ARCO PENE AN ALCL Fly xd |
NjojPiOjRIS|T|U| YW X|Y]Z] caps |
of1l2|3|a|5|e|7|B|B[=].|-] NEXT |
яр "| 079) le] 771 SPACE]
CLEAR
ok | CANCEL |
5. Press the direction buttons to move the key cursor, select the
characters or marks to enter, and press the ENTER button.
* Projector Name can be set using up to 15 characters includ-
ing alphabets (capital/small), numeric characters, or marks.
« key: Shifting the position of enter cursor to the
left for each character.
> key: Shifting the position of enter cursor to the
right for each character.
DEL key: Deleting the character in the position of
enter cursor for each character
caps/CAPS key: Switching an alphabet character to CAPI-
TAL or small.
NEXT/PREV key:Switching the marks listed on the fourth
line.
SPACE key: Inserting a space in the position of enter
cursor
CLEAR key: Deleting all the entered characters.
6. When selecting OK, the setting is completed as the name
stored. However, when selecting CANCEL, the setting is com-
pleted without storing.
If may take some time to reflect the settings.
Network Password Settings
1. Display the NETWORK menu. (See page 22 for menu setting.)
4. Press the direction buttons to move the key cursor, select the
characters or marks to enter, and press the ENTER button.
* Password can be set using up to 32 characters including
alphabets (capital/small) or numeric characters.
< key:
— key:
DEL key:
caps/CAPS key:
CLEAR key:
Shifting the position of enter cursor to the
left for each character.
Shifting the position of enter cursor to the
right for each character.
Deleting the character in the position of
enter cursor for each character.
Switching an alphabet character to CAPI-
TAL or small,
Deleting all the entered characters.
= The default password Is "admin".
5. Select OK, and NEW NETWORK PASSWORD screen appears
if the entered password is correct.
« [f the entered password isnot correct, CURRENT NET-
WORK PASSWORD screen appears again.
NEW NETWOTE PASSWD
SC EE HE AE UE DE
¡EOMPIRM NETWORK PASSWORD
ERA AAA о
4
А| В] © |9 | Е) Ее н| 11 31 К] Е) м) DEL |
Nojpla|RislTiujviw|x|v| Z| caps |
09| 1] 2| 3] 4] 5] 5} 7] в] | CLEAR |
95| CANCEL |
6. Enter the NEW NETWORK PASSWORD and CONFIRM NET-
WORK PASSWORD.
* Password can be set using up to 32 characters including
alphabets (Capital/small) or numeric characters.
<— Key:
— key:
1 key:
DEL key:
caps/CAPS key:
CLEAR key:
Shifting the position of enter cursor to the
left for each character
Shifting the position of enter cursor to the
right for each character
Shifting the position of enter cursor
between NEW NETWORK PASSWORD
and CONFIRM NETWORK PASSWORD.
Deleting the character in the position of
enter cursor for each character.
Switching an alphabet character to CAPI-
TAL or small.
Deleting all the entered characters.
7... When NEW NETWORK PASSWORD and CONFIRM NET-
WORK PASSWORD are matched, the setting is completed after
changing the NETWORK PASSWORD,
« [fthe entered content is not matched, NEW NETWORK
PASSWORD screen appears again after an error dialog is
displayed.
* |tmay take some time to reflect the settings.
Network settings (continued)
Setting or Clearing DHCP
1. Display thelP CONFIG menu.
2. Press the A or Y button to select DHCP
XE DHCP ONE
3. Press the ENTER button.
* Confirmation dialog appears.
DHCP : 4 ONE |3
OK : ENTER CANCEL : MENU
4. EFressthe < or > button to select ON] or OFF PU].
5. Select the item to set, and press the ENTER button.
* Jo cancel the setting, press the MENU button.
« |t may take some time to reflect the settings.
* When setting DHCP to ON, IP ADDRESS, SUBNET MASK,
and DEFAULT GATEWAY cannot be set. If you set those set-
tings, set DHCP to OFF and perform the IP settings as the
following procedures.
IP Address Settings
1. Display the IP CONFIG menu.
2. Press the A or ¥ button to select IP ADDRESS.
Li Panoness 4 sere »
3. Pressthe < or » button to select SET PU .
4. Press the ENTER button.
* IP ADDRESS screen appears.
1P ADDRESS
[197-168 0. 10 real
Df 1] 2] 24] 5] 6] 7188] CLEAR]
5. Press the direction buttons to move the key cursor, select the
numbers to enter, and press the ENTER button,
« Set the numeric value within the range from 0 to 255. How-
ever, set the numeric value for the final octet within the range
from 1 to 254,
+ Key: Shifting the position of enter cursor to the left.
— key: Shifting the position of enter cursor to the right.
DEL key:Deleting the character in the position of enter cur-
sor for each character.
6. When selecting OK, the setting is completed as the IP
ADDRESS stored. However, when selecting CANCEL, the set-
ting Is completed without storing.
« It may take some time to reflect the settings.
Subnet Mask Settings
1. Display the IP CONFIG menu.
2. Press the & or Y button to select SUBNET MASK.
6. When selecting OK, the setting is completed as the Subnet
Mask stored. However, when selecting CANCEL, the setting is
completed without storing.
e It may take some time to reflect the settings.
Default Gateway Settings
1. Display the IP CONFIG menu.
2. Press the A or ¥ button to select DEFAULT GATEWAY,
fil Geren « ==)
3. Press the «< ог № button to select SETH] .
4. Press the ENTER button.
a DEFAULT GATEWAY screen appears.
| DEFAULT GATEWAY
[ 10.198. © 1
ый al]
DEL |
(M | L'ANCEL |
a = але лая
5. Enter the Default Gateway.
= Hefer to IP Address Settings for the detail of entering.
6. When selecting OK, the setting is completed as the Default
Gateway stored, However, when selecting CANCEL, the setting
is completed without storing.
® |! may take some time to reflect the settings.
Setting or Clearing PJLink Certification
Perform the settings to start PJLink protocol communication.
« See page 35 for the detail of PJLink.
1. Display the NETWORK menu. (See page 22 for menu setting.)
2. Press the A or ¥ button to select PdLink CERTIFICATION.
3. Press the ENTER button.
* Confirmation dialog appears.
A Ty ЗЫ 4 ONE 4
OK © ENTER CANCEL : MENU
4. Press the « or button to select ON PI or OFF PI.
5. Select the item to set, and press the ENTER button.
e To cancel the setting, press the MENU button.
« |t may take some time to reflect the settings.
Initialization of Network Settings
1. Display the NETWORK menu. (See page 22 for menu setting.)
2. Press the A or Y button to select NETWORK RESET
{= NETWORK RESET oK EJ
3. Press the ENTER button.
e Confirmation dialog appears.
A If nrececinma the ENTER Вал ал the Network Sattnne can
Network settings (continued)
trator.
`.
Glossary
How to Use Network Function
* When connecting a computer and projector with LAN, config-
ure the both IP Addresses in the same network group.
If connecting in different network group, be sure to use a
router. As for the settings of a router, ask the network adminis-
* Configure the IP CONHG correctly. If the settings are not cor-
rect, the communication may be unavailable. For the detall,
consult the network administrator.
* Depending on the settings of standby mode of the projector,
LAN function may be unavailable. See page 23 for the detail of
standby mode.
For more detail of the glossary below, refer to the technical book that
is commercially available.
Term Description
Abbreviation for Dynamic Host Configuration
DHCP Protocol. This protocol automatically assigns IP
Address to networked devices.
IP Address Numerical address to identify networked comput-
ers.
A numeric value to define the number of bits
Subnet Mask used for a network address of a divided network
(or subnet) in an IP Address.
A server (or router) to communicate across net-
Herr Gate: works (subnets) that are divided by Subnet
way
Mask.
Abbreviation for Media Access Control Address.
MAC Address is a unique ID number assigned to
MAC Address | each network adapter. And this is based on
which data are sent and received between net-
work adapters.
Advanced features
Setting of the image displayed during startup
or muting
You can display your desired image as the startup screen (or splash
screen). Using the menu, you can also use such image as a back-
ground that is displayed while the video is muted or no signal is sup-
plied.
Important:
* You can't set IMAGE CAPTURE when PASSWORD FUNCTION in
the FEATURE menu has been set to SPLASH ID SCREEN to
enable the password lock.
* YOU can'tset IMAGE CAPTURE when the component video signal
is inputted.
Setting procedure
1. Press the COMPUTER button to select the image supplied to
the COMPUTER/COMPONENT VIDEO IN terminal.
Display your desired image.
Display the INSTALLATION menu.
Select IMAGE CAPTURE by pressing the 4 or Y button.
Press the ENTER button.
* Thesetting menu will be displayed.
a > eN
Set the background color
(Set the background color only when you set the image size to x1 or
x4.)
6. Select BACK COLOR by pressing the A or Y button.
7. Select your desired color for the background (GRAY RED,
GREEN, BLUE, BLACK, WHITE, RED50%, GREEN50%, or
BLUES0%) by pressing the < or P button.
Set the image size
8. Select SIZE by pressing the 4 or Y button.
9. Select x1, x4, or FULL by pressing the < or p button.
FULL
x1
Capture the image
10. Select CAPTURE by pressing the A or Y button.
11. Press the ENTER button.
* À red frame appears. (The size of the red frame is 640 x 360
pixels.)
a
a E "Ne
SARTRE y EG -= ENTER my -
CAMCEL - REC = :
F J
ol 5 Cl dt Cl LR tee te ee JE J el Cp ed te Cpl oe pet ee mm a et Se Tt Rn sy Нос" нарко тре
13. Press the ENTER button twice.
* Image capture will start.
* Press the MENU button to cancel the procedure.
| Lom | E |
la
s When the image capture completes, the captured image will
be displayed for a few seconds.
Important:
* You can’t change the new startup screen back to the original star-
tup screen. (Even when you select RESET ALL in the FEATURE
menu, the factory default screen isn't avallable any longer.) When
you want to change the startup screen again, capture another
image,
« The captured image will be displayed from the next startup. If the
captured image isn’t displayed, make sure that the setting of
SPLASH SCREEN in the INSTALLATION menu isn’t OFF (See
page 23.)
* Jo display the captured image while the video is muted, set AV
MUTE MODE in the INSTALLATION menu to IMAGE. (See page
23)
« When BACK COLOR in the INSTALLATION menu is set to
IMAGE, the captured image will be displayed while no signal is
supplied.
« In the mute mode, or when no signal is input, it takes longer time
to display the captured image.
* Some images can't be captured correctly because of their signal
type.
Split
You can split the screen in Two and display a computer image on the
left screen and a video image on the right screen.
Left screen
Right screen
To use the split mode:
1. Display the FEATURE menu.
2. Select SPLIT by pressing the 4 or Y button,
3. Press the ENTER button.
® The screen is split in two and the left and right screens dis-
nlay tho folloswino (manoac-
Advanced features (continued)
* When you display 60-Hz and 50-Hz video signals at the
same time, motion images may not be displayed properly. In
this case, set VERT SYNC of USER in the SIGNAL menu to
OFF for the left screen. (See page 25.)
* When BACK COLOR of the INSTALLATION menu is set to
IMAGE, you cannot use the split mode.
To change the input source of the left or right screen:
* Jo change the input source of the left screen, press the a button
on the remote control,
* Jo change the input source of the right screen, press the }- button
on the remote control.
Freeze
To stop the motion in the image temporarily (or to dis-
play a still image):
Press the FREEZE button on the remote control,
* The Image freezes temporarily.
To resume the motion in the image:
Press the FREEZE button on the remote control again.
Important:
« Do not keep displaying a still picture for an extended period of
time, as the afterimages may linger on the screen.
Password function
This projector provides the passwordfunction that Is intended to pre-
vent wrong operations by children and set controlled access for speci-
fied users,
DISPLAY INPUT............ When the projector is turned on, the star-
tup screen (or splash screen) appears and
stays on the screen until the password is
entered. When the password is entered,
the startup screen switches to the regular
operation screen.
MENU ACCESS............ All the buttons except for the POWER but-
ton on the projector are disabled. (The
buttons on the remote control are
enabled.) You can use this mode to pre-
vent wrong operations by children and set
controlled access for specified users.
SPLASH ID SCREEN ... IMAGE CAPTURE and SPLASH
SCREEN in the menu become unselect-
able. SPLASH SCREEN is set to ON
automatically
To enable the password function:
1. Display the FEATURE menu.
2. Press the A or Y button to select PASSWORD FUNCTION.
3. Press the <q or P button to change the mode among DISPLAY
INPUT Æ], MENU ACCESS №).
e When the password has already been set. the mode never
changes. Press the ENTER button to cancel the password
7. Press the ENTER button.
« To cancel the procedure, press the MENU button.
8. Enter the password again for confirmation using the same steps.
9. Press the ENTER button.
* [fthe entered passwords are incorrect, an error message
appears.
® To cancel the procedure, press the MENU button.
To cancel the password function:
1. Display the FEATURE menu.
2. Pressthe A or Y button to select PASSWORD FUNCTION.
3. Press the ENTER button.
« The screen for canceling the password function appears.
4. Press the ENTER button.
e The screen for entering the password appears.
1111141
44 be | ox:ENTEN | |cANCEL: MENU |
È—
wd
5. Enter a4 - 8 digit password using the A, ¥, < ог № buttons on
the remote control as shown below.
(A=1,—2, Y=3, 44)
6. Press the ENTER button.
* |fyou enter a wrong password, an error message appears.
® To cancel the procedure, press the MENU button.
Important:
= When the screen for entering the password |s displayed, to disable
the password function, hold down the MENU and ENTER buttons
on the control panel together.
Magnify
By pressing the MAGNIFY button on the remote control, you can mag-
nify the image to view the details.
* The MAGNIFY mode doesn't function with some input signals. For
details, see page 46.
* The MAGNIFY mode doesn't work with video or S-video signal.
MAGNIFY
|
Magnified image
Ta uea tha MAGNIEY mada
Advanced features (continued)
Setting the efficient mode
By pressing the EFFICIENT MODE button, you
can display the EFFICIENT MODE menu to set the
following menu items: LAMP MODE, STANDBY
MODE, and AUTO POWER OFF. (For details of each
item, see page 23.)
1. Press the EFFICIENT MODE button.
* The EFFICIENT MODE menu appears.
EFFICIENT MOD
Ap 4 STANDARD ›
STANDEY MODE q STANDARD ›
AUTO POWER 4 OFF ›
2. Select an desired item to set by pressing the A or
Y button.
3. Set the selected ¡item by pressing the < or >
button.
4. Repeat steps 2-3 for each setting.
5. Press the EFFICIENT MODE button to exit the
menu.
Supervising and controlling by computer
You can supervise and control the projector's
operation using a personal computer via a LAN.
Major functions
ProjectorView Global+
Batch projector controlling / supervising application
software
* Batch operation of stand-alone projector / multiple
projectors
* Scheduling function to turn ON/OFF for each day of
the week
* (Checking each condition of the projector and
detecting a theft
Setting of the projector's IP CONFIG
Startup of the controlling / supervising tool
(ProjectorView) using the Web browser
* Activating Visual PA2 to display the specified
characters on the projectors screen
ProjectorView
The controlling /supervising tool using the Web
browser
About ProjectorView Global+ and ProjectorView
* For details, see “LAN control UTILITY operation
manual” in the CD-ROM.
(About PJLink™ O
® To use PJLink™ function, the PJLink™
application software is required.
* To use this function, set the PJLink'* certification
properly according to the setting of the network
application to be used. (See page 31.)
* For the specifications of PJLink™, access to
the Web site of Japan Business Machine and
Information System Industries Association
(JBMIA). (http://pjlink.jbmia.or.jp/english)
* This projector is fully compliant to the
specifications of JBMIA PJLink™ Class 1. It
supports all the commands defined by PJLink™
Class 1, and the compliance has been verified
with the PJLink™ standard specifications
\ Version 1.0. )
Important:
* For the commands for PJLink™, see the table on
the next page.
* The control may not be performed correctly or the
monitoring data may not be obtained correctly in
the following conditions:
- During standby
- During input source switching
- During auto position execution
- During AV mute
- During command processing
- Before the splash screen disappears after the
power is turned on.
Use 1 controller to control/monitor 1 projector.
For how to control/monitor using PJLink™, see the
operation manual of the PJLink™ application you
use.
* When you monitor the projector's operating state
using this function by issuing inquiry commands
successively, issue an inquiry command after
receiving the response to the previous inquiry
command from the projector.
Advanced features (continued)
Connection
For details of the connection, see “LAN control UTILITY operation manual” in the CD-ROM.
When STANDBY MODE in the INSTALLATION menu or the EFFICIENT MODE menu of the projector
is set to LOW, the LAN network is disabled. To enable the LAN network, set STANDBY MODE to
STANDARD. (See page 23.)
Configure the initial network settings first.
You can configure the initial settings using the projector menu (see pages 30 to 32) or ProjectorView Global+ or
ProjectorView. For details of ProjectorView Global+ and ProjectorView, see “LAN control UTILITY operation manual” in
the CD-ROM.
Using the User Manual
The User Manual for LAN Control Utility is prepared in the Portable Document Format (PDF) in the CD-ROM.
Opening the User Manual:
1. Load the CD-ROM into the CD-ROM drive.
2. Open CD-ROM “PROJECTOR,”
3. Double-click on “MANUAL LAN.HTML” within the CD-ROM. A language selection list for the User Manual will be
displayed.
4. Move the mouse pointer to the desired language and click.
PJLink™ supported commands
The table below shows commands to control the projector using the PJLink™ protocol.
Command | Description Remark (Parameter)
POWR Power control 0 = Standby
1 = Power on
POWR ? Inquiry about the power state 0 = Standby
1 = Power on
2 = Cooling down
3 = Warming up
INPT Input switching 11 = COMPUTER1
INPT ? | irv about input switchi 12 = COMPUTER?
NPT nquiry about input switching 91 — VIDEO
22 = S-VIDEO
31 = HDMI
AVMT Mute control 30 = Video and audio mute disable
AVMT ? Inguiry about the mute state 31 = Video and audio mute enable
ERST? Inquiry about the error state 1st byte: Fan error, 0 or 2
end byte: Lamp error, 0 to 2
3rd byte: Temperature error, 0 or 2
4th byte: Cover open error, 0 or 2
5th byte: Always 0
6th byte: Other error, 0 or 2
0 to 2 mean as follows:
| 0 = No error detected, 1 = Warning, 2 = Error
Lamp replacement
This projector is equipped with a lamp to project 3. Loosen the two screws (d) of the lamp unit, and
images. This lamp Is a consumable. It may burn out then pull out the lamp unit (f) by the handle (e).
or its brightness may decrease during use. In such
cases, replace the lamp with a new one as soon as (e)
possible. Be sure to replace the lamp with a new lamp
separately sold that is exclusive to this projector.
Contact your dealer for purchase of the lamp. (a)
| Spare lamp for FD730U/FD730U-G: VLT-XD700LP |
Caution:
* Do not remove the lamp immediately after using the
projector. You may get burned because the lamp 15
hot after use.
* Before replacing the lamp, press the POWER
button to turn off the lamp and wait for two minutes
for lamp to cool down. npg the power cord from
wall outlet and wait one hour for the lamp to cool
down completely.
* Do not remove the lamp except for replacement.
Careless handling can cause injury or fire.
* Do not touch the lamp with bare hands or give
a shock to the lamp. Attach the lamp properly.
Improper handling may cause explosion.
* Be sure not to drop the lamp lid screw into the
projector. Also be sure not to put metal or any
= mm т
Caution:
* When replacing the lamp, do not loosen the
screws other than two screws (d). № may cause
the failure of projector.
* Pull he lamp unit out of the projector slowly.
If it is pulled out quickly, the lamp may break,
scattering glass fragments.
« Do not spill liquid on the removed lamp unit or
do not place it near any flammable object or
where children can reach to prevent injuries or
flammable objects inside because it may cause fire fire. | В
or electric shock. If any objects should fall inside, 4. Insert the new lamp unit, and secure it with two
unplug and contact your dealer. screws firmly.
e Install the lamp securely to prevent failure and fire. 5. Secure the lamp cover with screw (b) back again,
» |[f the lamp should break, small glass fragments and mount the cover (a).
may fall out through the vents and some may
remain inside of the projector or the lamp box. Caution:
When taking the lamp box out, be sure to turn over * Make sure that the lamp cover is secured firmly.
the projector and hold the handle of the lamp box Otherwise, the POWER indicator flashes red and
to avoid injury due to the glass fragments. green, disallowing the projector to be powered
ff the lamp should break never ‚shake the mp; box on.
or hold it in front of your face after removing it. The : ;
glass fragments may fall out and cause injury to B) ati projector is mounted to the
our eyes. . . :
. When femovina the lamp from the ceiling-mounted When removing the lamp unit from the projector
projector, use the lamp replacement attachment mounted to the ceiling, never fail to use the lamp
packed with the projector or option lamp to prevent replacement attachment to protect yourself from glass
glass fragments from scattering. fragments and so on. |
* Be sure to use the lamp dedicated to this projector, * Contact your dealer when replacing the lamp unit
VLT-XD700LP for FD730U/FD730U-G. Use of other with the projector mounted to the ceiling.
lamps may cause a failure of the projector. 1. Remove the lamp cover referring to the procedure
A) When the projector is placed on the lange of “A) When the projector is placed on the
table
Make sure that the projector is securely held in place. Caution:
1. Remove the cover (a) of the screw fixing the lamp * When opening the lamp cover to replace the
cover with a fingernail. If it is difficult to remove lamp of the ceiling-mounted projector, pay
it with a fingernail, use a finetipped tool such as careful attention because glass fragments may
Lamp replacement (continued)
3. Assemble the lamp replacement attachment by
folding two taping portions (g) and two cutout
portions (h) along the folding line as the figure.
4. Insert the two cutout portions (h) in the slit of the
projector, paste the two taping portions (g) with the
tape included in the lamp replacement attachment,
and then fix the lamp replacement attachment to
the projector.
(9)
6. Remove the tape fixing the lamp replacement
attachment, and remove the lamp replacement
attachment with the lamp unit remainina in the bac.
Reset of the lamp operation time
Flug in the power cord, and reset the lamp operation
time by keep pressing the 4, >, and POWER buttons
on the control panel at the same time.
important;
Unless these three buttons are pressed at the same
time, the lamp operation time isn't reset.
* Make sure that the STATUS indicator is lit twice and
the lamp operation time is reset successfully.
* The projector doesn't turn on if the lamp cover isn't
attached securely.
« Be sure to reset the lamp operation time whenever
you replace the lamp.
* Do not reset the lamp operation time unless you
replace the lamp.
Caution:
¢ The lamp is fragile. If it is broken, be careful not to
cut yourself with glass fragments.
* Contact your dealer for a new lamp.
Interval of lamp replacement
The recommended interval of lamp replacement is
about 5000 hours"? of consecutive use. Such interval
differs depending on the operating environment and
may be shorter than 5000 hours™™.
Decrease in luminescence and/or color brightness
indicates that the lamp needs to be replaced. When
the lamp operation time exceeds 3750 hours’, the
indicator will blink alternately between green and
red (while the lamp is lit; when the lamp is not lit, the
indicator will be lit red only) and the lamp replacement
message will appear on the screen for one minute
everytime the lamp is turned on. When the lamp has
been used for about 4750 hours™, the replacement
message (LAMP EXCHANGE) will appear on the
screen for one minute every 25 hours™ thereafter.
When the lamp operation time exceeds 5000
hours™™, the projector automatically shuts off and
can't be used until the lamp is replaced and the
lamp operation time is reset.
*1; Duration when LAMP MODE in the QUICK MENU or the
INSTALLATION menu or the EFFICIENT MODE menu is
set to LOW. When it is set to STANDARD, this duration
will be shorted.
*2. When LAMP MODE is set to STANDARD, this duration
will beshorted to 3000 hours.
Important:
* Do not open the lamp cover when the projector is
set at a ceiling or a high place. Lamp fragments
may fall from the inside if the lamp were broken.
Please contact your dealer when you need to
replace the lamp with a new one.
Troubleshooting
Before asking for repair of the projector, check the following. If the symptom persists, stop using the projector, be
sure to unplug the power plug, and then contact your dealer.
No image appears on the screen.
Problem
Solution
Power can not be
turned on.
Check whether the indicators are on or off and how they are lightning.
POWER STATUS | Solution
o © « Connect the power cord to the projector.
off Off * Plug the power cord into a wall outlet,
« |f any objects are blocking the intake or exhaust vents, remove them and
carry out the following.
o 1, Unplug the power cord from the wall outlet.
Off 2. Make sure that the projector has cooled off,
3. Plug the power cord into the wall outlet.
4. Press the POWER button.
* |fany objects are blocking the intake or exhaust vents, remove them.
it 97-0- |= Don't expose the exhaust vents to hot air emitted from a heating appliance.
78: Blinking orange
Steady red
» After the STATUS indicator stops blinking, press the POWER button.
о —26; « |f vou unplug the power cord while the fan is rotating, the lamp may not tum on
A about 1 minute when you plug the power cord next time.
Bilnking green « The lamp can't turn on again for 1 minute after it goes out.
« Press the POWER button several times.
-e- * Replace the lamp. (The lamp is at the end of its life.)
Steady red
g * Áttach the lamp cover on the top.
Off
0-20; Sa » Unplug the power cord from the wall outlet and contact your dealer.
Blinking E
red/green Tu
О 2-8:
Blinking
No image appears on
the screen.
Cancel the AV mute by pressing the AV MUTE button.
Check that the lens cap is removed.
It may take about 1 minute for the lamp to light up.
The lamp fails to light up on rare occasions. In such a case, wait for a few minutes
and then try again.
If the projector was turned off before the lamp was cooled down sufficiently last time,
the fan may start rotating and the POWER button may not work after the power cord
is plugged. Press the POWER button to turn back on the POWER indicator.
Check that the intake vent is clean.
Check that the lamp cover is closed. (See page 38.)
Check that the cables connected to the external devices are not broken.
When an extension cable is being used, replace it with the supplied cable for check.
When images are displayed correctly, add an RGB signal amplifier to the extension
cable.
Power turns off.
This problem may occur when the intake vent and/or exhaust vents are blocked. (In
ест à Ames Flas CTATI VC dear alas ara À
Troubleshooting (continued)
No image appears on the screen. (continued)
Problem
Solution
The screen for
entering the password
appears.
PASSWORD FUNCTION in the FEATURE menu has been set to DISPLAY INPUT to
enable the password lock.
> Enter the password or contact the person in charge of management of the
projector. (See page 34.)
“NO SIGNAL” is
displayed.
Turn on the power of the connected device, or check whether there is something
wrong with the connected device.
Check whether the external device output signals. (Check this especially when the
external device is a notebook computer.)
Check that the cable connected to the external device isn’t defective.
Check that the projector is connected to the external device using the correct
terminals.
Check that the connected device is correctly selected as the input source.
When an extension cord is being used, replace it with the supplied cable and check
whether images are projected correctly. If images are projected correctly, use an RGB
signal amplifier along with the extension cord.
Images are not displayed correctly.
Problem Solution
Projected images are « Check that the cable connected to the external device isn't intermittent.
shaking. * Connect the cable's plug with the external device's connector firmly.
Projected images are | * Press the AUTO POSITION button.
displaced. * Some computers output out-of-spec signals on rare occasion. Adjust the SIGNAL
menu. (See page 29.)
Projected images are
distorted.
Adjust the projector and the screen so that they are perpendicular to each other. (See
page 14.)
Projected images are
dark.
Adjust BRIGHTNESS and CONTRAST in the QUICK MENU or the IMAGE menu. (See
page 27.)
Replace the lamp. (See page 37.)
Projected images are
blurred.
Adjust the focus. (See page 16.)
Clean the lens.
Press the 4 or P button on the remote control to eliminate flicker.
Adjust TRACKING and FINE SYNC. in the SIGNAL menu. (See page 29.)
Adjust BRIGHTNESS and CONTRAST in the QUICK MENU or the IMAGE menu. (See
page 27.)
Adjust the projector and the screen so that they are perpendicular to each other. (See
page 14.)
Afterimages persist on
the screen.
This phenomenon is improved by keeping projecting an evenly bright image. (Such
“Image burn-in" phenomenon where afterimages persist on the screen may occur if a
stationary image is kept displayed on the screen for a long time.)
—
White dnte ara ceen
This nhannmenon le normal for a NI PTM nmrmierctor and is not a malfunction (A very
Troubleshooting (continued)
Images are not displayed correctly. (continued)
Problem
Solution
Hue is not appropriate.
Check that the cables connected to the external devices are not broken.
Tint in projected
images is incorrect.
If the setting of COMPUTER INPUT in the SIGNAL menu is inconsistent with the RGB/
YCbCr output setting of the external device even when the input source is other than
COMPUTER (for example, when the input source is HDMI), the entire image appears
reddish or greenish.
> Check that COMPUTER INPUT in the SIGNAL menu is correctly set. (See page
25.)
Check that the cable connected to the external device isn't broken.
Different color tint.
When comparing images projected by two projectors, tints in the displayed images may be
different because of variation between their optical components. This is not a malfunction.
When comparing the image projected by this projector with those displayed on the
television or PC monitor, tints in the displayed images may be different because of
difference in the range of color reproducibility. This is not a malfunction.
Only the motion areas
in the images supplied
from the computer
aren't displayed.
This is caused by the computer being used. Contact the manufacturer of your
computer.
Projected images are
obscured.
Match the output resolution of your computer with the resolution of the projector.
For the method to change the output resolution of the computer, contact the
manufacturer of your computer. (See page 46.)
some images and texts appear obscured during the keystone adjustment. In such
cases, use the projector without applying the keystone adjustment. (See page 15.)
Projected images are
flickering.
After the POWER button or ON button on the remote has been pressed, or the LAMP
MODE setting has changed, images may be flickering until the lamp lights stably. This
is an expected behavior.
When selecting the input signal, Auto Position, and Color Enhancer, the projected
image may be flickering temporarily. This is not a product malfunction.
Others
Problem
Solution
The exhaust vents
emit warm air.
This air comes out after cooling the inside of the projector. You may feel hot, but this
Is not a malfunction,
No audio is output.
Check that the volume isn't set to low.
Check the Audio Input setting.
When the external device is connected with an HDMI cable, set the audio output of
the device to PCM output.
The menu can't be
used.
The microcomputers inside the projector may be wrongly operating because of noise.
> Press the POWER button to turn off the lamp and unplug the power cord from the
wall outlet. Wait about 10 minutes, plug the power cord in, and try again.
“"TENADEDATI IDEN? |=
This indication annears when the ambient temnpnerature risas hoh When the ambient
Troubleshooting (continued)
Others (continued)
Problem Solution
The buttons on the * PASSWORD FUNCTION in the FEATURE menu has been set to MENU ACCESS to
control panel (except enable the password lock.
for the POWER > Cancel the password lock or contact the person in charge of management of the
button) don't function. projector. (See page 34.)
Abnormal sound is * Because the color wheel spins at a high speed, metallic sounds may be heard in rare
heard. occasions. Such symptom is not a malfunction.
If the following problem occurs after the lamp is replaced, check the following first.
Problem Solution
The projector does not | * Fit the lamp cover securely. (See pages 37 and 38.)
turn on. « Reset the lamp operating time. (See page 38.)
The STATUS indicator | « Reset the lamp operating time. (See page 38.)
blinks.
Maintenance
Warning:
* Do not use flammable solvents (benzene, thinner, etc.) and flammable aerosols when cleaning the projector body
and lens. Flammable substances may ignite causing fire or breakdown while the lamp is illuminating.
Caution:
* Be sure to turn off the lamp and unplug the power cord from the wall outlet before you perform any maintenance
on the projector.
* Ask your dealer for annual cleaning of the inside of the projector. If you continue to use the projector with dust
Inside, it may result in fire or malfunction.
Cleaning of the projector and the vents
Use a soft cloth to clean the projector and the vents. When the vents become dirty, wipe them with a soft cloth
dampened with diluted mild detergent, and then wipe them with a dry cloth.
To protect the surface of the projector from fading or deteriorating:
* [Do not spray insecticide on or inside the projector.
+ Do not use benzin or thinner to clean it.
* Do not let rubber or plastic materials contact with projector.
Cleaning of the lens
Use a standard lens-cleaning brush or a piece of lens tissue dampened with lens cleaning fluid. The lens surface is
fragile. Use only recommended, nonabrasive lens-cleaning materials. Do not touch the lens with your fingers.
Kensington Lock
This projector has a Kensington Security Standard connector for use with Kensington MicroSaver Security System.
Dafar tra than mfr atime *+kaaf aaa arta TR da muaa Cana Far metre ata za boa Ea rica 14 Le aa Th
Indicators
This projector has two indicators, each of which shows the operation condition of the projector.
The following offer solutions to possible problems. If these problem persist, turn the projector off and consult your
dealer.
EFFICIENT
AUTO PLISITION MODE
COMPUTER VIDED CO STATUS POWER
KEYS TONE |
(+) 2) |
—
STATUS indicator POWER indicator
Normal condition
POWER STATUS CONDITION NOTE
© Stand-by
ESE, or
Steady red о o Lamp stand-by for power-off The power cannot be turned on by pressing
Biinking green the POWER button.
© 32-6" Lamp stand-by for power-on The power cannot be turned off by pressing
a Blinking green the POWER button.
Sicady green : ©- The power is on. (Normal condition)
Sleady grean
Abnormal condition
POWER STATUS CONDITION POSSIBLE SOLUTION
“ot Abnormal temperature Clean the vents.
Steady green o e The vents are clogged with dust or dirt. Relocate the projector to a cooler place.
$ coh e The room temperature Is high.
Steady red
The protection circuit is working or the lamp is | = Wait until the STATUS indicator goes
E oO “e- in an abnormal condition. out, then press the POWER bution.
Steady red Blinking green * If the above solution is not effective,
replace the lamp.
e к The lamp operation time exceeds the time Replace the lamp.
fp Fo elapsed until the lamp lifetime notice while the | Change with a new lamp If this problem
Tara Flia areenired power is on. (See page 38.) recurs.
Le e The lamp operation time exceeds the time
| 14 à elapsed until the lamp lifetime notice while the
Steady red Sinkina red power is off. (See page 38.)
В “4 The lamp operation time exceeds the time
Sa a est re elapsed until the lamp lifetime. (See page 38.)
Specifications
EE a
Type DLP™ projector
Model FD730U/FD730U-G
Rated power supply 100 - 240 V AC; 50/60 Hz
Power consumption 4.2A
During standby: 0.5W (when STANDBY MODE is LOW)
Display Technology 0.65-inch single chip Digital Micromirror Device (DMD)
Pixels: 1920 x 1080 = 2073600 pixels
Colors 16770000 colors
Projection lens F 24-28, f=20.6-30.1 mm
Light source lamp 280 W
Picture size
40-300 inch (Wide) (aspect ratio 16:9)
PC compatibility
Maximum resolution: 1920 x 1080 dots (Compressed in the case of 1600 x 1200 dots)
Panel resolution; 1920 x 1080 dots
Video compatibility
NTSC/NTSC 4.43/PAL (including PAL-M, N)/SECAM/PAL-60
Component Video (DVD/HDTYV) (4801, 5761, 480p, 576p, 1080, 720p, 1080p)
Speaker 10 W mono x 1
S-video input Luminance signal: 1.0 Vp-p 75 O (negative sync.)
Chroma signal: 0.286 Vp-p 75 Q (burst signal)
Video input 1.0 Vp-p 75 Q (negative sync.)
Audio input 350 ;mYrms, 10 kQ or more
Analog RGB input
RGB: 0.7 Vp-p 75 Q (negative sync.)
Y PaPr/Y CaGar:
Y: 1.0 Vp-p (negative sync.)
PePr/CsCr: 0.7 Vp-p
HD/CS: TTL level (positive or negative)
VD: TTL level (positive or negative)
HDMI input
HDMI 19-pin
HDMI interface (TMDS single link) (only PCM audio is supported)
Control connector
SERIAL terminal (45-232C), LAN terminal (RJ-45)
Outside dimensions
345 x 134 x 270 mm (width x height x depth)
Weight
Approx. 4.3 kg
Length of power cord
71 inch (1.8 m)
Temperature, humidity
(performance guaranteed)
+41°F (+5°C) - +95°F (+35°C), 30 - 90%
The specifications and outside appearance of the projector are subject to change without prior notice.
Specifications (continued)
Connectors
COMPUTER/COMPONENT VIDEO IN, MONITOR OUT (mini D-SUB 15-pin) HDMI (HDMI 19-pin)
1 19
a
2 18
COMPUTER/COMPONENT
VIDEO IN Pm No. Spec.
Pin No. Spec. 1 TMDS Data 2 +
1 R {RED)Y/Cr 2 TMDS Data 2 Shield
2 G (GREENVY à TMDS Data ? -
3 E (BLUEVCa A TMDS Data 1 +
4 GND 5 TMDS Data1 Shield
5 GND 6 TMS Data 1
6 GND 7 TMDS Data D +
7 GND 8 TMDS Data 0 Shield
8 GND 9 TMDS Data D -
g DOC 5V 10 TMDS Clock +
10 GND 11 TMDS Clock Shield
11 GND 12 TMDS Clock -
12 DDC Data 13 CEC
13 HD/CS 14 -
14 Vo 15 SCL
15 DOC Clock 16 SDA
17 DOC Ground
18 +5 Y Power
19 Hol Plug Detect
iE
[
EII —
Specifications (continued)
Specification of RGB signals in each computer mode of the projector
1400 x 1050
1440 x. 1080
nic Resolution Horizontal - Vertical Normal mode Native mode
(H x V) frequency (KHz) frequency (Hz) (H x V) (Hx V)
TV60, 4801 (5251) 720 x 480 15.73 59:94 1440 x 1080 640 x 480
TV50, 5761 (6251) 720 x 576 15.63 50.00 1440 x 1080 768 x 576
1080160 (1125160) 1920 x 1080 33.75 60.00 1920 x 1080 1920 x 1080
1080150 (1125150) 1920 х 1080 28.13 50.00 1920 х 1080 1920 х 1080
480p (525p) 720 x 480 31.47 59.94 1440 x 1080 640 x 480
576p (625p) 720 x 576 31.25 50.00 1440 x 1080 788 x 576
720p60 (750p60) 1280 x 720 45.00 60.00 1920 x 1080 1280 x 720
720p50 (750p50) 1280 x 720 37.50 50.00 1920 x 1080 1280 x 720
1080p60 (1125p60) 1920 x 1080 67.50 60.00 1920 x 1080 1920 x 1080
1080p50 (1125p50) 1920 x 1080 56.25 50.00 1920 x 1080 1920 x 1080
ССАТО 640 х 400 31.47 70.09 1728 x 1080 640 х 400
ССАВА 640 х 400 37.86 84.13 1728 x 1080 640 x 400
| ССАВБ 640 х 400 37.86 85.08 1728 х 1080 640 х 400
VGABO 640 x 480 31.47 50.04 1440 x 1080 640 x 480
VGA72 640 x 480 37.86 72.81 1440 x 1080 640 х 480
VGA75 640 x 480 37.50 75.00 1440 x 1080 640 x 480
VGA85 640 x 480 43.27 85.01 1440 x 1080 840 x 480
SVGA56 800 x 600 35.16 56.25 1440 x 1080 800 x 600
SVGABD 800 x 600 37.88 60.32 1440 x 1080 800 x 600
SVGA72 800 x 600 48.08 72.19 1440 x 1080 800 x 600
SVGA75 800 x 600 46.88 75.00 1440 x 1080 800 x 600
SVGAB5 800 x 600 53.67 85.06 1440 x 1080 800 x 600
SVGA95 800 x 600 59.97 94.89 1440 x 1080 800 x 600
XGABO 1024 x 768 48.36 60.00 1440 x 1080 1024 x 768
ХСАТО 1024 х 768 56.48 70.07 1440 x 1080 1024 x 768
XGA75 1024 x 768 60.02 75.03 1440 x 1080 1024 x 768
XGAB5 1024 x 768 68.68 85.00 1440 x 1080 1024 x 768
SXGA70a 1152 x B64 63.85 70.01 1440 x 1080 1152 x 864
SXGA75a 1152 x 864 67.50 75.00 1440 x 1080 1152 x 864
SXGAB5a 1152 x 864 77.49 85.06 1440 x 1080 1152 x 864
WXGA60 1280 x 768 47.78 50.87 1800 x 1080 1280 x 768
WXGA60a 1280 x 800 49.70 59.81 1728 x 1080 1280 x 800
WXGA6O0b 1360 х 768 47.71 60.02 1912 x 1080 1380 x 768
WXGA60c 1366 x 768 47.50 59.75 1920 x 1080 1366 x 768
WXGA+60 1440 x 900 55.94 59.89 1728 x 1080 1440 x 900
SXGABOb 1280 x 960 60.00 60.00 1440 x 1080 1280 x 960
SXGA75b 1280 x 960 75.00 75.00 1440 x 1080 1280 x 960
SXGABSb 1280 x 960 85.94 85.00 1440 x 1080 1280 x 960
SXGAGO 1280 x 1024 63.98 60,02 1350 x 1080 1280 x 1024
SXGA75 1280 x 1024 79.98 75.02 1350 x 1080 1280 x 1024
SXGA85 1280 x 1024 91.15 85,02 1350 x 1080 1280 x 1024
60.02
1400 x 1050
Ele oT PY
«i I party bly
e
*
*1
"1
71,2
1,2
+1, *2
1,42
Я
"
"1
a
*1
ía
Specifications (continued)
Specification of RGB signals in each computer mode of
the projector (continued)
Important:
Some computers aren't compatible with the projector.
The projector's maximum resolution is 1920 x 1080 pixels. It may
not display Images of higher resolutions than 1920 x 1080 cor-
rectly
Images with SYNC on G (Green) signal may jitter
Images with SYNC on G (Green) signal may be tinged with green,
If the resolution and frequency of your computer aren't shown on
the table, find the compatible resolution and frequency by chang-
ing the resolution of your computer.
TV60 and TV50 are equivalent to 480i and 576i respectively
When these signals are supplied to the VIDEO IN or S-VIDEO IN
terminal, the signal mode is indicated as TV60 or TV50. When
they are supplied to the COMPUTER/COMPONENT VIDEO IN
terminals, the signal mode is indicated as 480i or 576i.
This projector doesn’t support 480p signals from video devices
having 4 lines (R, G, B, CS”) or having 5 lines (R, G, B, H, V).
* : Composite Sync
When a certain signal such as SXGAB5, SXGAB5b and UXGAGO
is input, the number of displayed colors may decrease depending
on the setting of ASPECT in the FEATURE menu. Change the sig-
nal format of the computer, if necessary.
NATIVE mode
When moire patterns or lines of uneven thickness appear on the pro-
jected image, these symptoms may be improved by displaying it in its
original image size (NATIVE mode). To display the image in the NATIVE
mode, set ASPECT of the FEATURE menu to NATIVE. (See page 22 for
menu setting.)
« [nthe NATIVE mode, you cannot change the magnification factor
and magnification range.
« [mages of which resolution is larger than the panel resolution can-
not be displayed in the NATIVE mode.
In the NATIVE mode, images are black-framed when the image res-
olution is lower than the panel resolution.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
