AIC+ Advanced
Interface Converter
Catalog Number 1761-NET-AIC
User Manual
Important User Information
Solid state equipment has operational characteristics differing from those of
electromechanical equipment. Safety Guidelines for the Application,
Installation and Maintenance of Solid State Controls (publication SGI-1.1
available from your local Rockwell Automation sales office or online at
http://literature.rockwellautomation.com) describes some important
differences between solid state equipment and hard-wired electromechanical
devices. Because of this difference, and also because of the wide variety of
uses for solid state equipment, all persons responsible for applying this
equipment must satisfy themselves that each intended application of this
equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for
indirect or consequential damages resulting from the use or application of
this equipment.
The examples and diagrams in this manual are included solely for illustrative
purposes. Because of the many variables and requirements associated with
any particular installation, Rockwell Automation, Inc. cannot assume
responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to
use of information, circuits, equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without
written permission of Rockwell Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware
of safety considerations.
WARNING
IMPORTANT
ATTENTION
Identifies information about practices or circumstances that can cause
an explosion in a hazardous environment, which may lead to personal
injury or death, property damage, or economic loss.
Identifies information that is critical for successful application and
understanding of the product.
Identifies information about practices or circumstances that can lead
to personal injury or death, property damage, or economic loss.
Attentions help you identify a hazard, avoid a hazard, and recognize
the consequence
SHOCK HAZARD
Labels may be located on or inside the equipment, for example, a drive
or motor, to alert people that dangerous voltage may be present.
BURN HAZARD
Labels may be located on or inside the equipment, for example, a drive
or motor, to alert people that surfaces may be at dangerous
temperatures.
Allen-Bradley, PLC, SLC, MicroLogix, PanelView, DTAM, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Summary of Changes
The information below summarizes the changes to this manual since
the last printing.
To help you find new and updated information in this release of the
manual, we have included change bars as shown to the right of this
paragraph.
3
Topic
Page
Updated publication list
4
Ordering publications
4
Processor/cable compatibility
16...19
Publication 1761-UM004B-EN-P - June 2006
4
Summary of Changes
Publication 1761-UM004B-EN-P - June 2006
Table of Contents
Preface
Who Should Use This Manual . . .
Purpose of This Manual. . . . . . . .
Additional Resources . . . . . . .
Conventions Used in This Manual
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
3
3
4
4
Chapter 1
Product Overview
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Device Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 2
Installation and Wiring
Compliance to European Union Directives . . . .
EMC Directive . . . . . . . . . . . . . . . . . . . . . .
Low Voltage Directive . . . . . . . . . . . . . . . .
Safety Considerations . . . . . . . . . . . . . . . . . . .
Mount the AIC+ Advanced Interface Converter .
Mount to a DIN Rail . . . . . . . . . . . . . . . . .
Mount to a Panel . . . . . . . . . . . . . . . . . . .
Wire the AIC+ Advanced Interface Converter . .
Wire the Power Supply . . . . . . . . . . . . . . .
Wire to the Network Ports . . . . . . . . . . . . .
Cable Choices . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended User-supplied Components . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
..
..
..
..
..
..
..
..
..
..
..
..
. 9
. 9
. 9
10
11
11
12
13
13
14
16
19
Network Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Point-to-point Isolator . . . . . . . . . . . . . . . . . . . . . . . . . .
Components Replaced by the AIC+ Interface Converter .
DH-485 Network with SLC 5/03 and SLC 5/04 Processors
and a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DH-485 Network with a MicroLogix 1000 Controller . . . .
Typical Three-node OEM Network . . . . . . . . . . . . . . . .
Networked Operator-interface Device and MicroLogix
Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Networks Using Ganged Converters . . . . . . . . . . . . . . .
Network Extended to 2438 m (8000 ft) . . . . . . . . . . . . .
DF1 Master-slave Network with Modem . . . . . . . . . . . . .
Avoid Incorrect Connections . . . . . . . . . . . . . . . . . . . . .
21
21
22
Chapter 3
Network Connections
23
24
24
25
26
27
28
29
Chapter 4
Interpret the LED Indicators
i
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Publication 1761-UM004B-EN-P - June 2006
ii
Table of Contents
Appendix A
Specifications and Dimensions
General Specifications . . . . . . . . . . . . . . . . . . .
Hardware Handshaking . . . . . . . . . . . . . . .
Auto Transmit Delay (turnaround time) per
Communication Rate . . . . . . . . . . . . . . . . .
Mounting Template . . . . . . . . . . . . . . . . . .
Index
Publication 1761-UM004B-EN-P - June 2006
. . . . . . . . . . 33
. . . . . . . . . . 34
. . . . . . . . . . 35
. . . . . . . . . . 36
Preface
Read this preface to familiarize yourself with the rest of the manual.
This preface covers the following topics.
• Who should use this manual
• Purpose of this manual
• Conventions used in this manual
Who Should Use This
Manual
Use this manual if you are responsible for designing, installing,
programming, or troubleshooting control systems that use
Allen-Bradley Small Logic controllers.
You should have a basic understanding of SLC 500 and MicroLogix
products and be able to interpret the ladder-logic instructions required
to control your application. If you do not, contact your local
Allen-Bradley representative for information on available training
courses before using this product.
Purpose of This Manual
This manual is a reference guide for the Advanced Interface Converter
(AIC+). This manual:
• gives you an overview of the AIC+ interface converter operation.
• explains the procedures to install and wire the AIC+ interface
converter.
3
Publication 1761-UM004B-EN-P - June 2006
4
Preface
Additional Resources
The following documents contain additional information regarding
Rockwell Automation products.
For
Related Documentation
Read This Document
Document
Number
A guide to understanding and selecting SLC 500 products
SLC 500 System Selection Guide
1747-SG001
A description on how to install and use your modular SLC 500
programmable controller
User Manual for Modular Hardware Style
Programmable Controllers
1747-UM011
A description on how to install and use your MicroLogix 1000
programmable controller
MicroLogix 1000 Programmable Controller User
Manual
1761-UM003
A description on how to install and use your MicroLogix 1200
programmable controller
MicroLogix 1200 Programmable Controller User
Manual
1762-UM001
A description on how to install and use your MicroLogix 1100
programmable controller
MicroLogix 1100 Programmable Controller User
Manual
1763-UM001
A description on how to install and use your MicroLogix 1500
programmable controller
MicroLogix 1500 Programmable Controller User
Manual
1764-UM001
A guide to DF1 protocol
Data Highway/Data Highway Plus/Data Highway 1770-UM022
II/Data Highway-485 Cable
A guide to wiring and grounding guidelines
Industrial Automation Wiring and Grounding
Guidelines
1770-IN041
A glossary of industrial automation terms and abbreviations
Allen-Bradley Industrial Automation Glossary
AG-7.1
If you would like a manual, you can:
• download a free electronic version from the Internet at
http://literature.rockwellautomation.com.
• purchase a printed manual by contacting your local distributor
or Rockwell Automation representative.
Conventions Used in This
Manual
Publication 1761-UM004B-EN-P - June 2006
The following conventions are used throughout this manual.
• Bulleted lists, such as this one, provide information, not
procedural steps.
• Numbered lists provide sequential steps or hierarchical
information.
• Bold type is used for emphasis
Chapter
1
Product Overview
Description
The AIC+ advanced interface converter provides a communication
link between various networked devices. The AIC+ interface converter
is compatible with a variety of SLC and MicroLogix controllers and
peripherals.
Communication Port and Switch Locations
RS-485
Communication Port
(Phoenix Plug)
RS-232 (8-pin mini-DIN)
Communication Port
Communication-rate
Selector Switch
RS-232 (DB-9, DTE)
Communication Port
DC Power-source
Selector Switch
Terminals for external 24V dc power
supply and chassis ground.
MicroLogix 1000, 1200, and 1500 controllers provide power to the
AIC+ interface converter via the RS-232 8-pin mini-DIN port’s cable.
However, if a MicroLogix controller is not connected to this port, a
24V dc power supply connected to the converter’s external power
terminals is required. The dc power-source selector switch needs to
be set for your particular configuration.
See Network Diagrams starting on page 21 for more details on how to
wire and configure the AIC+ interface converter.
5
Publication 1761-UM004B-EN-P - June 2006
6
Product Overview
The communication-rate selector switch is used to match the
communication rate filter of the AIC+ interface converter to the
network communication rate. This switch does not change the
network communication rate and is normally left in the AUTO
position. In high noise environments, the communication-rate selector
switch should be taken out of the AUTO mode and set to the same
communication rate as the network.
See Auto Transmit Delay on page 35 for more information on
communication rates.
Operation Modes
The AIC+ interface converter can be used in the following modes.
• Point-to-point isolator
• RS-232 to RS-485 isolator
• RS-232 to half-duplex user mode ASCII isolator
Communication is established using hardware handshaking or auto
transmit signals.
Device Compatibility
The AIC+ interface converter can be used to interconnect the
following devices.
•
•
•
•
•
•
•
•
SLC 500, 5/01, 5/02, and 5/03 processors (channel 1)
SLC 5/03, 5/04, and 5/05 processors (channel 0)
MicroLogix controllers
Logix controllers
1756-DH485 ControlLogix module
Operator interface devices
Personal computer serial ports (or any 9-pin DTE serial port)
Modems
TIP
Publication 1761-UM004B-EN-P - June 2006
You cannot connect the 1761-HHP-B30 Hand-held Programmer
to the AIC+ advanced interface converter.
Product Overview
7
Node Address Identification
There is no node
address associated
with the network
port.
The node address is
configured in the
device connected
with this port.
The node address is
configured in the
device connected
with this port.
Use this area to mark
the node address of
each connection.
Publication 1761-UM004B-EN-P - June 2006
8
Product Overview
Publication 1761-UM004B-EN-P - June 2006
Chapter
2
Installation and Wiring
Compliance to European
Union Directives
If this product has the CE mark it is approved for installation within
the European Union and EEA regions. It has been designed and tested
to meet the following directives.
EMC Directive
This product is tested to meet Council Directive 89/336/EEC
Electromagnetic Compatibility (EMC) and the following standards, in
whole or in part, documented in a technical construction file.
• EN 50081-2 EMC – Generic Emission Standard, Part 2 – Industrial
Environment
• EN 50082-2 EMC – Generic Immunity Standard, Part 2 –
Industrial Environment
This product is intended for use in an industrial environment.
Low Voltage Directive
This product is tested to meet Council Directive 73/23/EEC Low
Voltage, by applying the safety requirements of EN 61131–2
Programmable Controllers, Part 2 – Equipment Requirements and
Tests.
For specific information required by EN 61131-2, see the appropriate
sections in this publication, as well as the Industrial Automation
Wiring and Grounding Guidelines, publication 1770-IN041.
9
Publication 1761-UM004B-EN-P - June 2006
10
Installation and Wiring
Safety Considerations
This equipment is suitable for use in Class I, Division 2, Groups A, B,
C, D, or nonhazardous locations only.
ATTENTION
Explosion Hazard —
Substitution of components may impair suitability for Class I,
Division 2.
Do not replace components or disconnect equipment unless
power is switched off and the area is known to be
nonhazardous.
Do not connect or disconnect connectors or operate switches
while circuit is live unless the area is known to be
nonhazardous.
This product must be installed in an enclosure. All cables
connected to the product must remain in the enclosure or be
protected by conduit or other means.
AIC+ interface converter must be operated from an external
power source.
All wiring must comply with N.E.C. articles 501, 502, 503,
and/or C.E.C. Section 18-1J2, as appropriate.
Use only the following communication cables and replacement
connectors in Class I, Division 2, hazardous locations.
Communication Cables for Class 1, Div Environments
Environment Classification
Communication Cables
Class I, Division 2 Hazardous Environment
1761-CBL-PM02 (Series C or later)
1761-CBL-HM02 (Series C or later)
1761-CBL-AM00 (Series C or later)
1761-CBL-AP00 (Series C or later)
2707-NC8 (Series B)
2707-NC9 (Series B)
2707-NC10 (Series B)
2707-NC11 (Series B)
1746-RT30 AIC+ Connector
Publication 1761-UM004B-EN-P - June 2006
Installation and Wiring
Mount the AIC+ Advanced
Interface Converter
11
The AIC+ interface converter can be mounted in the vertical or
horizontal position. There are no spacing requirements except as
necessary for DIN-rail latch movement.
Mount to a DIN Rail
Follow these steps to install your interface converter.
1. Mount your DIN rail.
2. Snap the DIN-rail latch into the closed position.
3. Hook the top slot over the DIN rail.
Side View
DIN Rail
Latch
4. While pressing the AIC+ interface converter against the rail, snap
the AIC+ interface converter into position.
Follow these steps to remove your interface converter.
1. Place a screwdriver in the DIN-rail latch at the bottom of the
AIC+ interface converter.
2. Holding the AIC+ interface converter, pry downward on the
latch until the AIC+ interface converter is released from the DIN
rail.
Publication 1761-UM004B-EN-P - June 2006
12
Installation and Wiring
Side View
DIN Rail
Mount to a Panel
Follow these instructions to mount your AIC+ interface converter to a
panel.
1. Remove the mounting template from this document.
2. Secure the template to the mounting surface.
3. Drill holes through the template.
4. Remove the mounting template.
5. Mount the AIC+ interface converter.
Mounting
Template
Publication 1761-UM004B-EN-P - June 2006
Installation and Wiring
Wire the AIC+ Advanced
Interface Converter
13
This section provides power supply wiring and network port wiring
information.
Wire the Power Supply
ATTENTION
EXPLOSION HAZARD —
An external power supply must be used in Class I, Division 2
applications and the dc power-source selector switch must be
in the EXTERNAL position before connecting the power supply
to the AIC+ interface converter.
IMPORTANT
In nonhazardous locations, external power is not required if the
AIC+ interface converter 8-pin mini-DIN com port is connected
to a MicroLogix controller.
Power Supply
Bottom
View
24VDC
DC
NEUT
CHS
GND
IMPORTANT
Some devices provide power to the AIC+ interface converter via
the 8-pin mini-DIN com port cable. The dc power-source
selector switch needs to be set for your particular
configuration.
If you are using a 1746-P1 or 1746-P2 power supply, the AIC+
interface converter is the only device that can be connected to
that power supply.
Always connect the CHS GND (chassis ground) terminal to the
nearest earth ground. This connection must be made whether
or not an external 24V dc supply is used.
Publication 1761-UM004B-EN-P - June 2006
14
Installation and Wiring
Wire to the Network Ports
Use these instructions for wiring Belden cable.
Attach the RS-485 Connector to the Communication Cable
IMPORTANT
A daisy-chained network is recommended. Other chained
networks are not recommended.
Daisy-chain Network
Belden
#3106A or
#9842
Belden
#3106A or
#9842
Belden
#3106A or
#9842
Connector
Connector
Connector
Incorrect
Attach the connector to the Belden #3106A or #9842 cable as shown
below.
Single Cable Connection
Orange with White Stripes
White with Orange Stripes
Shrink Tubing
Recommended
6 Termination
5
A
4
B
3 Common
2 Shield
1 Chassis Ground
Drain Wire
Blue (#3106A) or
Blue with White Stripes (#9842)
Multiple Cable Connection
to Previous Device
to Successive Device
Publication 1761-UM004B-EN-P - June 2006
Installation and Wiring
15
The table below shows connections for Belden #3106A.
Belden #3106A Cable
For This Wire/Pair
Connect This Wire
To This Terminal
Shield/Drain
Non-jacketed
Terminal 2 – Shield
Blue
Blue
Terminal 3 – (Common)
White/Orange
White with Orange Stripe
Terminal 4 – (Data B)
Orange with White Stripe
Terminal 5 – (Data A)
The table below shows connections for Belden #9842.
Belden #9842 Cable
For This Wire/Pair
Connect This Wire
To This Terminal
Shield/Drain
Non-jacketed
Terminal 2 – Shield
Blue/White
White with Blue Stripe
Cut back – no connection(1)
Blue with White Stripe
Terminal 3 – (Common)
White with Orange Stripe
Terminal 4 – (Data B)
Orange with White Stripe
Terminal 5 – (Data A)
White/Orange
(1)
To prevent confusion when installing the communication cable, trim the white and blue striped wire
immediately after the insulation jacket is removed. This wire is not used by DH-485.
Only one connector at the end of the link must have Terminals 1 and
2 jumpered together. This provides an earth-ground connection for
the shield of the communication cable.
Both ends of the network must have Terminals 5 and 6 jumpered
together. This connects the termination impedance (120 Ω) that is built
into each AIC and AIC+ interface converter as required by the RS-485
specification.
End of Line Termination
Jumper
Jumper
Belden #3106A or #9842 Cable
1219 m (4000 ft) Maximum
Jumper
Publication 1761-UM004B-EN-P - June 2006
16
Installation and Wiring
Cable Choices
This section provides information that will help you determine the
appropriate cable for your application.
1761-CBL-AC00 and 1747-CP3 Cable
1747-CP3
1761-CBL-AC00
1761-CBL-AC00 and 1747-CP3 Cable
Cable
Length
Connects
from
1747-CP3,
1761-CBL-AC00
Publication 1761-UM004B-EN-P - June 2006
3 m (9.8 ft),
SLC 5/03, SLC 5/04, or SLC 5/05
45 cm (17.7 in.) processor, channel 0
to AIC+
Interface
Converter
RS-232 (DB-9,
DTE)
Communication
Port
PC com port
RS-232 (DB-9,
DTE)
Communication
Port
PanelView through NULL modem
adapter
RS-232 (DB-9,
DTE)
Communication
Port
RS-232 (DB-9, DTE) Communication
Port on another AIC+ interface
converter
RS-232 (DB-9,
DTE)
Communication
Port
Installation and Wiring
17
1761-CBL-AS03 and 1761-CBL-AS09 Cable
1761-CBL-AS09
1761-CBL-AS03
1761-CBL-AS03 and 1747-CBL-AS09 Cable
Cable
Length
Connects
from
to AIC+
Interface
Converter
1761-CBL-AS03, 3 m (9.8 ft),
SLC 500 Fixed, SLC 5/01, SLC 5/02,
1761-CBL-AS09 9.9 m (29.5 ft) and SLC 5/03 processors
PanelView RJ45 port
RS-485
Communication
Port (Phoenix
Plug)
RS-485
Communication
Port (Phoenix
Plug)
1761-CBL-AM00 and 1761-CBL-HM02 Cable
1761-CBL-HM02
1761-CBL-AM00
1761-CBL-AM00 and 1761-CBL-HM02 Cable
Cable
1761-CBL-AM00
1761-CBL-HM02(1)
(1)
Length
45 cm
(17.7 in.),
2m
(6.5 ft)
Connects
External Selection
Power
Switch
Supply
Setting
Required
from
to AIC+
Interface
Converter
MicroLogix
1000, 1200, and
1500
processors
RS-232 (8-pin No
mini-DIN)
communication
port
Cable
RS-232 (8-pin
mini-DIN)
communication
port on another
AIC+ interface
converter or
MicroLogix
1100
RS-232 (8-pin Yes
mini-DIN)
communication
port
External
Series B cables are required for hardware handshaking.
Publication 1761-UM004B-EN-P - June 2006
18
Installation and Wiring
1761-CBL-AP00 and 1761-CBL-PM02 Cable
1761-CBL-PM02 (1)
1761-CBL-AP00
1761-CBL-AP00 and 1761-CBL-PM02 Cable
Cable
1761-CBL-AP00,
1761-CBL-PM02(1)
Publication 1761-UM004B-EN-P - June 2006
Length
45 cm,
(17.7 in.),
2m
(6.5 ft)
Connects
External
Power
Supply
Required
Selection
Switch
Setting
Yes
External
from
to AIC+
Interface
Converter
SLC 5/03, SLC
5/04, or SLC
5/05
processors,
channel 0
RS-232 (8-pin
mini-DIN)
communication
port
MicroLogix
1000, 1200,
and 1500
processors
RS-232 (DB-9, Yes(2)
DTE)
Communication
Port
External
PanelView
RS-232 (8-pin
through NULL
mini-DIN)
modem adapter communication
port
Yes
External
PC com port
Yes
External
RS-232 (8-pin
mini-DIN)
communication
port
(1)
Series B cables are required for hardware handshaking.
(2)
An external power supply is required unless the AIC+ interface converter is powered by a MicroLogix controller
connected to the RS-232 (8-pin mini-DIN) communication port with a 1761-CBL-AM00 or 1761-CBL-HM02 or
equivalent cable.
Installation and Wiring
19
User-supplied Cable
User-supplied Cable
User-supplied Cable
Cable
Straight through 9
pin
Recommended
User-supplied Components
Length Connects
—
from
to AIC+ Interface
Converter
Modem or other
communication device
RS-232 (DB-9, DTE)
communication port
These components can be purchased from your local electronics
supplier.
User-supplied Components
Component
Recommended Model
External power supply and
chassis ground
Power supply rated for 20.4...28.8V dc
NULL modem adapter
Standard AT
Straight through 9 pin RS-232
cable
User-supplied cable
User-supplied Components
DB-9 RS-232
Port 1
1761-CBL-AP00 or 1761-CBL-PM02
DH-485 Connector
Port 3
6
6
7
1
2
8
3
4
9
5
Cable Straight-D Connector
Port 2
678
3
4
5
12
5
4
3
2
1
Publication 1761-UM004B-EN-P - June 2006
20
Installation and Wiring
Ports
Pin #
DB-9 RS-232
RS-232 (8-pin mini-DIN)
Communication Port(1)
(1761-CBL-PM02 cable)
Port 3
DH-485 Connector
1
Received line signal
detector (DCD)
Not applicable
Chassis ground
2
Received data (RxD)
Signal common (GRD)
Cable shield
3
Transmitted data (TxD)
Request to send (RTS)
Signal ground
4
DTE ready (DTR)
Received data (RxD)
DH-485 data B
5
Signal common (GRD)
Same state as port 1’s
DCD signal
DH-485 data A
6
DCE ready (DSR)
Clear to send (CTS)
Termination
7
Request to send (RTS)
Transmitted data (TxD)
Not applicable
8
Clear to send (CTS)
Not applicable
Not applicable
9
Not applicable
Not applicable
Not applicable
(1)
Publication 1761-UM004B-EN-P - June 2006
An 8-pin mini-DIN connector is used for making connections to the RS-232 (8-pin mini-DIN) communication
port. This connector is not commercially available. If you are making a cable to connect to the RS-232 (8-pin
mini-DIN) communication port, you must configure your cable to connect to the Allen-Bradley cable.
Chapter
3
Network Connections
Network Diagrams
This chapter provides various network connections. The item number
provided in the Communication Port table corresponds to the
designated port on the AIC+ advanced interface converter shown in
each illustration.
Communication Port
Item Number
Port
1
RS-232 (DB-9, DTE) com port
2
RS-232 (8-pin mini-DIN) com port
3
RS-485 com port
Point-to-point Isolator
Point-to-point Isolator
1761-CBL-AM00 or
1761-CBL-HM02 Cable
MicroLogix
1000 Processor
PC
AIC+ Converter
3
2
1
1747-CP3 or 1761-CBL-AC00 Cable
24V dc
(Not needed in this
configuration since the
MicroLogix 1000 processor provides
power to the RS-232 (8-pin mini DIN) com port.)
21
Publication 1761-UM004B-EN-P - June 2006
22
Network Connections
Components Replaced by the AIC+ Interface Converter
The AIC+ interface converter replaces the combination of a 1747-PIC
interface converter and 1747-AIC isolated link coupler in most
applications.
Components Replaced by the AIC+ Interface Converter
DH-485 Network using 1747-AIC Interface Converter
SLC 5/04 Processor
24V dc Power
1747-PIC
Interface
Converter
1747-AIC Isolated
Link Coupler
1747-AIC Isolated
Link Coupler
SLC 5/02 Processor
1747-AIC Isolated
Link Coupler
SLC 5/03 Processor
DH-485 Network using 1747-AIC+ Interface Converter
SLC 5/04 Processor
3
2
AIC+
Converter
1747-AIC Isolated
Link Coupler
1747-AIC Isolated
Link Coupler
24V dc Power
SLC 5/02 Processor
Publication 1761-UM004B-EN-P - June 2006
SLC 5/03 Processor
Network Connections
23
DH-485 Network with SLC 5/03 and SLC 5/04 Processors and a PC
DH-485 Network with SLC 5/03 and SLC 5/04 Processors and a PC
PC
SLC 5/03 or SLC 5/04 Processor
APS
24V dc Power
Connection from Processor
Channel 0
1761-CBL-AP00 or
1761-CBL-PM02 Cable
1761-CBL-AP00 or
1761-CBL-PM02 Cable
3
AIC+ Converter
3
2
1
SLC DH-485 Network
1747-CP3 or
1761-CBL-AC00
Cable
1747-AIC Isolated
Link Coupler
SLC 5/02 Processor
1
1747-CP3 or
1761-CBL-AC00 Cable
2
AIC+ Converter
24V dc
(user
supplied)
1747-AIC Isolated
Link Coupler
SLC 5/03 Processor
Publication 1761-UM004B-EN-P - June 2006
24
Network Connections
DH-485 Network with a MicroLogix 1000 Controller
DH-485 Network with a MicroLogix 1000 Controller
MicroLogix 1000 Processor (series C or later)
PC
Connection from
Port 1 or Port 2
to MicroLogix 1000 Processor
1761-CBL-AM00 or
1761-CBL-HM02 Cable
AIC+ Converter
2
3
1761-CBL-AP00 or
1761-CBL-AP00 or
1761-CBL-PM02 Cable
1761-CBL-PM02 Cable
3
1
1
24V dc
(User supply needed
if using RS-232 (DB-9, DTE) com port.)
1747-CP3 or
1761-CBL-AC00 Cable
2
AIC+ Converter
24V dc
(user supplied)
Typical Three-node OEM Network
Typical Three-node Network
PanelView Operator Interface
MicroLogix 1000 Processor (series C or later)
1761-CBL-AM00 or
1761-CBL-HM02 Cable
RJ45 Port
1761-CBL-AS09 or 1761-CBL-AS03 Cable
AIC+ Converter
3
2
PC
1
24V dc
(Not needed in this
configuration since the
1747-CP3 or 1761-CBL-AC00 Cable
MicroLogix 1000 processor
provides power to the
AIC+ interface converter.)
Publication 1761-UM004B-EN-P - June 2006
Network Connections
25
Networked Operator-interface Device and MicroLogix Controller
Networked Operator-interface Device and MicroLogix Controller
PanelView 550 Operator Interface
PC
RS-232 Port
NULL Modem
Adapter
Connection from NULL Modem
Adapter
1761-CBL-AP00 or
1761-CBL-PM02 Cable
1761-CBL-AP00 or
1761-CBL-PM02 Cable
AIC+ Converter
2
3
1
1747-CP3 or
1761-CBL-AC00 Cable
AIC+ Converter
3
2
1
1747-CP3 or
1761-CBL-AC00 Cable
24V dc
(user supplied)
24V dc
(user supplied)
3
SLC DH-485 Network
1747-AIC
Isolated Link Coupler
SLC 5/03 Processor
AIC+ Converter
2
24V dc
(Not needed in this
configuration since
the MicroLogix
1000 provides
power to the AIC+
via port 2.)
1761-CBL-AM00 or
1761-CBL-HM02 Cable
MicroLogix 1000 Processor (series C or later)
Publication 1761-UM004B-EN-P - June 2006
26
Network Connections
Networks Using Ganged Converters
Networks Using Ganged Converters
DH-485 Network with PanelView Interface
PanelView Interface
1761-CBL-AM00 or
1761-CBL-HM02 Cable
RJ45 Port
PC
1761-CBL-AS09 or
1761-CBL-AS03 Cable
3
2
3
AIC+ Converter
2
AIC+ Converter
1
24V dc
24V dc
(user supplied) (user supplied)
1747-CP3 or 1761-CBL-AC00 Cable
DH-485
Network
SLC 500 Fixed Controller
RJ45 Port
24V dc power
1761-CBL-AS09 or
1761-CBL-AS03 Cable
1761-CBL-AM00 or 1761-CBL-HM02 Cable
3
AIC+ Converter
2
3
1
DH-485
Network
Publication 1761-UM004B-EN-P - June 2006
2
AIC+ Converter
1747-CP3 or
1761-CBL-AC00 Cable
PC
Network Connections
27
Network Extended to 2438 m (8000 ft)
Network Extended to 2438 m (8000 ft)
DH-485 Network
1219 m (4000 ft), Maximum
Extended DH-485 network
2438 m (8000 ft), maximum
and 32 nodes total.
1761-CBL-AM00 or
1761-CBL-HM02 Cable
3
3
2
AIC+ Converter
24V dc
(User supplied or
from 24V dc terminals
on SLC controller.)
2
AIC+ Converter
24V dc
(User supplied or
from 24V dc terminals
on SLC controller.)
DH-485 Network
1219 m (4000 ft), Maximum
Publication 1761-UM004B-EN-P - June 2006
28
Network Connections
DF1 Master-slave Network with Modem
DF1 Master-slave Network with Modem
SLC 5/03 Processor
SLC 5/03 Processor
CH0
DF1
Master
3
1761-CBL-AP00 or
1761-CBL-PM02 Cable
2
Radio Modem
or Lease Line
AIC+ Converter
1
SLC 5/03 processor
CH0
DF1
Slave
3
1
1761-CBL-AP00 or
1761-CBL-PM02 Cable
1747-CP3 or
1761-CBL-AC00 Cable
AIC+ Converter
2
1
Straight
9...25
Pin Cable
SLC 5/03 Processor
CH0
DF1
Slave
3
2
1761-CBL-AP00 or
1761-CBL-PM02 Cable
AIC+ Converter
Straight 9...25 Pin Cable
Radio Modem
or Lease Line
CH0
DF1
Slave
3
2
1761-CBL-AP00 or
1761-CBL-PM02 Cable
1747-CP3 or
1761-CBL-AC00 Cable
1
AIC+ Converter
Use this diagram for user-mode ASCII as well as DF1 master-slave
protocol.
See Specifications for more information on hardware handshaking and
communication protocols.
Publication 1761-UM004B-EN-P - June 2006
Network Connections
29
Avoid Incorrect Connections
Incorrect Connections
DH-485
Network
1747-AIC Isolated
Link Coupler
1761-CBL-AS09 or
1761-CBL-AS03 Cable
AIC+ Converter
3
1761-CBL-AS09 or
1761-CBL-AS03 Cable
1747-AIC Isolated
Link Coupler
DH-485
Network
SLC 5/03 Processor
IMPORTANT
In this configuration, the cable will fit but not function properly.
Publication 1761-UM004B-EN-P - June 2006
30
Network Connections
Publication 1761-UM004B-EN-P - June 2006
Chapter
4
Interpret the LED Indicators
Diagnostics
LED Indicators and Selector Switch
TX RS-485 LED Indicator
TX RS-232 (8-pin
mini-DIN) LED Indicator
TX RS-232 (9-pin) LED
Indicator
PWR (Power) LED
Indicator
DC Power-source
Selector Switch
LED Indicator Status
LED Indicator
Status
Condition
TX RS-232 9-pin
Flashing
Transmitting.
Off
Receiving or idle.
Flashing
Transmitting.
Off
Receiving or idle.
Flashing
Transmitting.
Off
Receiving or idle.
On
Power OK.
Off
No power to AIC+ interface converter or dc
source switch set incorrectly.
Cable
24V dc power supplied to AIC+ interface
converter from device connected to RS-232
(8-pin mini-DIN) communication port.
External
24V dc power supplied to AIC+ interface
converter from external source (use 24V dc
power from SLC or user-supplied 24V dc
power supply).
TX RS-232 8-pin
TX RS-485
PWR – Power OK
Power Source
Selection Switch
31
Publication 1761-UM004B-EN-P - June 2006
32
Interpret the LED Indicators
Publication 1761-UM004B-EN-P - June 2006
Appendix
A
Specifications and Dimensions
General Specifications
AIC+ Advanced Interface Converter - 1761-NET-AIC
Attribute
Value
24V dc Power Source
Requirement
20.4...28.8V dc
Current Draw
0...120 mA
200 mA inrush current, max
Internal Isolation (see below)
500V dc
DH-485, DF1, or User Network
• Number of nodes, max = 32 per multidrop network
• Length, max = 1219 m (4000 ft) per multidrop
network
• Number of ganged multidrop networks, max = 2
Environmental Specifications
Attribute
Value
Operating Ambient Temperature
0...60 °C (32...140 °F)
Storage Temperature
-40...85 °C (-40...175 °F)
Certifications
Certification
Agency Certification
Value
(1)
• UL 1604
• C-UL C22.2 No. 213
• Class I Division 2 Groups A, B, C, D
• CE compliant for all applicable
directives
(1)
33
See the Product Certification link at http:ab.com for Declaration of Conformity, certificates, and other
certification details.
Publication 1761-UM004B-EN-P - June 2006
34
Specifications and Dimensions
Isolation Between All Ports and Power Supply Terminals
RS-485 Communication
Port (Phoenix Plug)
RS-232 (8-pin mini-DIN)
Communication Port
RS-232 (DB-9, DTE)
Communication Port
Terminals for external 24V dc power
supply and chassis ground.
Hardware Handshaking
To implement hardware handshaking, use cables that support the
following signals.
Signals Needed for Hardware Handshaking
Signal Definition
Function
RTS active
An input to AIC+ interface converter port.
CTS active
An output from AIC+ interface converter
port.
When hardware handshaking is used, the auto transmit delay
(turnaround time) is zero.
Protocol for Hardware Handshaking
Publication 1761-UM004B-EN-P - June 2006
Protocol
AIC+ Interface Converter Support of
Hardware Handshaking
DF1 Full-duplex (point-to-point isolator)
Yes(1)
DF1 Master-slave
Yes(2)
User-mode ASCII
Yes(2)
(1)
You can connect two DF1 Full-duplex devices together with one AIC+ interface converter.
(2)
Any communication coming off of the RS-485 line will not drive the carrier detect lines on the RS-232 (DB-9,
DTE) communication port and the RS-232 (8-pin mini-DIN) communication port. If the devices require carrier
detect high, it must be jumpered high locally at the device’s RS-232 port. Devices on RS-232 (DB-9, DTE)
communication port and RS-232 (8-pin mini-DIN) communication port can drive the other RS-232 ports
handshaking lines and the RS-485 transmitter.
Specifications and Dimensions
35
Auto Transmit Delay (turnaround time) per Communication Rate
Communication Min Delay
Rate (Kbps)
(ms)
Max Delay
(ms)
Typical Delay
(ms)
Pre-send
Transmit Delay
Setting (ms)(1)
600
7.3
15.0
10.8
16
1200
7.3
15.0
10.8
16
2400
5.5
11.2
8.1
12
4800
2.7
5.7
4.0
6
9600
1.3
2.8
2.0
3
14400
0.9
1.9
1.4
2
19200
0.6
1.4
1.0
2
AUTO
0.3
0.7
0.5
(2)
(1)
The pre-send transmit delay setting is used in your device’s (for example, SLC and MicroLogix controller)
communications configuration.
(2)
Use a pre-send value, depending upon the network communication rate being used.
Auto-transmit Delay for AIC+ Interface Converter Using Auto-transmit Detection
(no hardware handshaking)
RS-485 Communication
Port (Phoenix Plug)
Network Device
Packet to
Network Device
Packet From
Network Device
Auto Transmit Delay
(turnaround time)
Auto Transmit Delay is measured from the time the AIC+ interface
converter transmits its last mark out of the RS-485 port, until the delay
time expires. The AIC+ interface converter will not accept RS-485 port
data during the Auto Transmit Delay time.
Publication 1761-UM004B-EN-P - June 2006
36
Specifications and Dimensions
Mounting Template
52.07 mm (2.05 in.)
107 mm (4.20 in.)
118 mm (4.64 in.)
27.7 mm (1.09 in.)
Publication 1761-UM004B-EN-P - June 2006
Allow 15 mm (0.6 in.) clearance
for DIN-rail latch movement
during installation and removal.
Index
A
AIC+ Advanced Interface Converter
compatibility with other devices 6
connect to a network 21
dimensions 36
LED indicators 31
mount 11
operating modes 6
product overview 5
specifications 33
wire 13
C
cables
1747-CP3 16
1761-CBL-AC00 16
1761-CBL-AM00 17
1761-CBL-AP00 18
1761-CBL-AS03 17
1761-CBL-AS09 17
1761-CBL-HM02 17
1761-CBL-PM02 18
user-supplied 19
compliance to European Union
directives 9
conventions used in this manual 4
D
device compatibility 6
dimensions 36
DIN rail mount 11
H
N
networks
components replaced by AIC+ Advanced
Interface Converter 22
DF1 master-slave network with modem
28
DH-485 with a MicroLogix 1000
controller 24
DH-485 with SLC 5/03 and SLC 5/04
processors and a PC 23
extended to 2438 m (8000 ft) 27
incorrect connections 29
operator interface device and MicroLogix
controller 25
point-to-point isolator 21
typical three-node OEM 24
with ganged converters 26
O
operating modes 6
P
panel mount 12
product overview 5
purpose of manual 3
R
related documentation 4
S
safety considerations 10
specifications 33
hardware handshaking 34
U
L
user-supplied components 19
LED indicators 31
W
M
mount the AIC+ Advanced Interface
Converter
DIN rail 11
panel mount 12
mounting template 36
who should use this manual 3
wire
network port 14
power supply 13
Publication 1761-UM004B-EN-P - June 2006
2
Index
Publication 1761-UM004B-EN-P - June 2006
How Are We Doing?
Your comments on our technical publications will help us serve you better in the future.
Thank you for taking the time to provide us feedback.
You can complete this form and mail (or fax) it back to us or email us at
[email protected]
Pub. Title/Type AIC+ Advanced Interface Converter User Manual
Cat. No.
1761-NET-AIC
Pub. No.
1761-UM004B-EN-P
Pub. Date June 2006
Part No.
Please complete the sections below. Where applicable, rank the feature (1=needs improvement, 2=satisfactory, and 3=outstanding).
Overall Usefulness
Completeness
(all necessary information
is provided)
Technical Accuracy
(all provided information
is correct)
1
2
3
How can we make this publication more useful for you?
1
2
3
Can we add more information to help you?
1
1
Clarity
(all provided information is
easy to understand)
2
3
procedure/step
illustration
feature
example
guideline
other
explanation
definition
Can we be more accurate?
text
2
Other Comments
3
illustration
How can we make things clearer?
You can add additional comments on the back of this form.
Your Name
Your Title/Function
Location/Phone
Would you like us to contact you regarding your comments?
___No, there is no need to contact me
___Yes, please call me
___Yes, please email me at _______________________
___Yes, please contact me via _____________________
Return this form to:
Rockwell Automation Technical Communications, 1 Allen-Bradley Dr., Mayfield Hts., OH 44124-9705
Fax: 440-646-3525
Publication CIG-CO521C-EN-P- May 2003
Email: [email protected]
PNXXXXXX-XX957782-91
PLEASE FASTEN HERE (DO NOT STAPLE)
PLEASE FOLD HERE
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
BUSINESS REPLY MAIL
FIRST-CLASS MAIL PERMIT NO. 18235 CLEVELAND OH
POSTAGE WILL BE PAID BY THE ADDRESSEE
1 ALLEN-BRADLEY DR
MAYFIELD HEIGHTS OH 44124-9705
PLEASE REMOVE
Other Comments
Rockwell Automation
Support
Rockwell Automation provides technical information on the Web to assist
you in using its products. At http://support.rockwellautomation.com, you can
find technical manuals, a knowledge base of FAQs, technical and application
notes, sample code and links to software service packs, and a MySupport
feature that you can customize to make the best use of these tools.
For an additional level of technical phone support for installation,
configuration, and troubleshooting, we offer TechConnect Support programs.
For more information, contact your local distributor or Rockwell Automation
representative, or visit http://support.rockwellautomation.com.
Installation Assistance
If you experience a problem with a hardware module within the first 24
hours of installation, please review the information that's contained in this
manual. You can also contact a special Customer Support number for initial
help in getting your module up and running.
United States
1.440.646.3223
Monday – Friday, 8am – 5pm EST
Outside United
States
Please contact your local Rockwell Automation representative for any
technical support issues.
New Product Satisfaction Return
Rockwell tests all of its products to ensure that they are fully operational
when shipped from the manufacturing facility. However, if your product is
not functioning, it may need to be returned.
United States
Contact your distributor. You must provide a Customer Support case
number (see phone number above to obtain one) to your distributor in
order to complete the return process.
Outside United
States
Please contact your local Rockwell Automation representative for
return procedure.
Publication 1761-UM004B-EN-P - June 2006 7
Supersedes Publication 1761-6.4 - April 1998
Copyright © 2006 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
