**Floating-Point Mathematical Co-Processor for a Single-Chip **

**On-Board Computer **

**Tanya Vladimirova, David Eamey, Sven Keller and Prof Sir Martin Sweeting **

**Surrey Space Centre **

**School of Electronics and Physical Sciences **

**University of Surrey, Guildford, UK, GU2 7XH **

**tel: +44(0)1483 689278, email: [email protected]**

**Abstract: **

This paper is concerned with the design of a 32-bit floating-point mathematical co-processor core using the CORDIC algorithm. The core implements the main arithmetic operations of addition, subtraction, multiplication and division, as well as 13 elementary functions. The co-processor conforms to the IEEE-754 standard for single-precision floating-point numbers, handling overflow, underflow and special number representations, such as infinity and not-a-number. The co-processor core was modelled in VHDL and integrated with the LEON SPARC V8 microprocessor core. The operation of the integrated design was tested on a XILINX

Virtex XCV800 FPGA. This paper outlines the co-processor design and discusses its integration with the LEON microprocessor core. Results, illustrating the performance of the co-processor core, are presented.

**1. Introduction **

Previously, work has been reported on the design of a system-on-a-chip on-board computer (SoC-OBC) for a

point mathematical co-processor peripheral IP core for the SoC-OBC. The co-processor is based on the Coordinate Rotation Digital Computer (CORDIC) algorithm and is capable of computing 17 mathematical functions: addition, subtraction, multiplication and division as well as square root, sine, cosine, tangent, inverse sine, inverse cosine, inverse tangent, hyperbolic sine, hyperbolic cosine, hyperbolic tangent, inverse hyperbolic tangent, exponential, and natural logarithm. The co-processor design conforms to the IEEE-754 standard for single-precision (32-bit) floating-point numbers, handling overflow, underflow and special number representations, such as infinity and not-a-number.

An RTL model of the co-processor was captured in VHDL. The functionality of the RTL design was fully verified and debugged, leading to the final version of the VHDL code, which was then synthesized and implemented. The co-processor was integrated with the LEON SPARC V8 microprocessor core and its operation was tested on a XILINX Virtex XCV800 FPGA.

The paper is structured as follows. Section 2 introduces the theory behind the CORDIC algorithm. Section 3 gives details about the structure and design of the co-processor. Section 4 discusses the interface of the coprocessor with the LEON microprocessor core. System-level integration and performance results are presented in Section 5.

**2. The CORDIC Algorithm **

navigation problems. The algorithm employs only shift and add/subtract operations, which makes it very attractive for hardware implementation. It belongs to the “digit-by-digit” iterative numerical algorithms, which have the property of generating one true binary digit of the result at each iteration. Generalization of the

domain. The computation scheme of the CORDIC algorithm is based on the rotation of a vector in a Cartesian coordinate system and the evaluation of the length and angle of the vector.

In the CORDIC method, the rotation of a vector

[

*x*

0

,

*y*

0

]

*T*

by an angle

θ is implemented as an iterative process, consisting of a sequence of elementary rotations during which the initial vector is rotated stepwise by predetermined step angles

α , where

*i i*

=

0 , 1 , 2 ,...,

*n*

−

1

can be positive or negative depending on the direction of rotation, denoted by

δ

*i*

∈

{

−

1 , 1 } . The angle of rotation

θ

≅

*n*

−

1

# ∑

δ

*i*

α

*i*

,

(1)

*i*

=

0

The direction of the next elementary rotation is determined by the sign of the difference between the angle

θ and the

*i*

-th partial sum of step angles,

θ −

*i j*

−

1

# ∑

=

0

δ α

*j*

. In the algorithm equations, an auxiliary variable serves the purpose of accumulating the step angles and determining the sign of the next step rotation.

The rotations of the CORDIC algorithm are usually carried out in two modes, called *rotation* and *vectoring*. In rotation angle and rotation at each iteration is aimed at making the angle accumulator converge towards zero. In the vectoring mode the vector is rotated to the

*x *-axis through whatever angle is necessary to align the result vector with the *x *-axis.

Walther [5] has summarised the algorithm using a set of unified CORDIC iteration equations as follows:

*x i*

+

1

=

*x i*

−

*my i*

δ

*i*

2

−

*i*

(2)

*y i*

+

1

*z i*

+1

=

=

*y i z i*

−

+

*x i*

δ

*i*

2

−

*i*

δ

*i*

α

*i*

(3)

(4) where

δ

*i*

=

*sign*

(

*z i*

) and

*i*

=

0 , 1 , 2 ,...,

*n*

−

1 . The mode variable, , takes the value of 1 , or

−

1 for circular, linear and hyperbolic groups of functions, and the elementary angle of rotation,

α , is an arctangent, a power of

*i*

two or a hyperbolic arctangent, correspondingly.

Using the unified CORDIC iteration equations, we can compute a wide range of mathematical functions.

Figure 1, adapted from Walther [5], shows the outputs of the algorithm,

*y n*

and

*z n*

, for the three groups of functions, where the diagrams in the left-hand column represent rotation mode and the diagrams in the righthand column – vectoring mode.

**x y x y **

**K**

**1**

** (x cos z – y sin z) **

**K**

**1**

** (y cos z + x sin z) x y x y**

**K**

**1**

** (x**

**2**

** + y**

**2**

**)**

**1/2**

**0 z x y z **

**CIRCULAR (m=1), **

δ** = sgn z **

**K**

**1**

** i=0 **

**CIRCULAR (m=1), **

δ** = - sgn y **

**n -1 **

** = 1 / **

Π** (1 + 2**

**-2i**

**)**

**1/2**

** **for n iterations** **

**x x x 0 x y **

**0 y + xz z y z y z + tan**

**-1**

**(y/x) **

**0 z x z **

**LINEAR (m=0), **

δ** = sgn z **

**x **

**0 **

**K **

**-1**

** (x cosh z – y sinh z) z x z**

**LINEAR (m=0), **

δ** = - sgn y **

**x z + y/x **

**K **

**-1**

** (x**

**2**

** - y**

**2**

**)**

**1/2 y z y z **

**K **

**-1**

** (y cosh z + x sinh z)**

**0 y z**

y z

**0 z + tanh**

**-1**

**(y/x) **

**HYPERBOLIC (m=-1), **

δ** = sgn z**

**K **

**-1 n -1 **

** = 1 / **

Π** (1 – 2**

** i=0 **

**-2i**

**)**

**HYPERBOLIC (m=-1), **

δ** = - sgn y **

**1/2**

** **for n iterations** **

**Figure 1. **Input-output relationships for CORDIC modes.

2

The input arguments values in the input-output relationships in Figure 1 can be chosen so as to make calculation of functions like

*x*

⋅

*z*

,

*y*

÷

*x*

, sin

*z*

, tan

−

1

*y*

, sinh

*z*

, cosh

*z*

and tanh

−

1

*y*

possible. From these, we are then able to generate the following composite functions: tan tanh

*z z*

=

= sin

*z*

sinh

/ cos

*z*

/

*z*

cosh

*z*

exp

*z*

= sinh

*z*

+ cosh

*z*

(5)

(6)

(7) ln

*w*

=

2 tanh

−

1 (

*y*

/

*x*

) , where

*x*

= *w* +

1 and

*y*

= *w* −

1 (8)

*w*

1 / 2

=

(

*x*

2

−

*y*

2 ) 1 / 2 , where

*x*

= *w* +

1 / 4 and

*y*

= *w* −

1 / 4 (9)

method,

δ is obtained in a different way, as it is defined as:

δ

*i*

=

⎧

⎨

⎩

+

1

*if*

−

1

*if y y i i*

<

≥

*c c*

(10)

Stepping through the iteration equations in circular mode (

*m*

=

1 ) produces:

*x n*

=

[(

*K n x*

0

) 2

−

*c*

2 ] 1 / 2

*y n*

=

*c z n*

=

*z*

0

+ arcsin[

*c*

/(

*K n x*

0

)]

(11)

(12)

(13)

The *arccosine* can be computed from the *arcsine* by subtracting 90

° from the result and inverting the sign of this new result.

The CORDIC equations impose a limited domain upon the arguments for the evaluated mathematical functions.

In order to make the algorithm work over the whole range, the inputs and outputs need to be scaled. A table of pre-scaling identities is given in Table 1, taken from Walther [5].

**Table 1. **Pre-scaling identities for mathematical functions.** **

**Identity Domain **

{ sin D if Q mod 4 = 0 } sin(Q 90 + D) = { cos D if Q mod 4 = 1 }

{ -sin D if Q mod 4 = 2 }

{ -cos D if Q mod 4 = 3 }

|D| < 90

{ cos D if Q mod 4 = 0 } cos(Q 90 + D) = { -sin D if Q mod 4 = 1 }

{ -cos D if Q mod 4 = 2 }

{ sin D if Q mod 4 = 3 }

|D| < 90 tan(Q 90 + D) = sin(Q 90 + D) / cos(Q 90 + D) tan

-1

(1/y) = 90 – tan

-1 sinh(Q log e

(y)

2 + D) = (2

Q

|D| < 90

|y| < 1

/2)[cosh D + sinh D – 2

-2Q

(cosh D – sinh D)] |D| < log e

2

2 cosh(Q log e

2 + D) = (2

Q tanh(Q log tanh

-1 e

/2)[cosh D + sinh D + 2

-2Q

2 + D) = sinh(Q log

(1 – M2

-E

) = tanh

-1

(cosh D – sinh D)] |D| < log e e

2 + D) / cosh(Q log

(T) + (E/2) log e

2 where T = (2 – M – M2

-E e

2 + D)

) / (2 + M – M2

-E

)

|D| < log e

2

0.17 < T < 0.75 for 0.5

≤ M < 1, E ≥ 1 exp(Q log e log e

(M2

E sqrt(M2

2 + D) = 2

Q

) = log

E

) ={ 2

{ 2 e

E/2

(cosh D + sinh D)

M + E log e

2

sqrt(M), if E mod 2 = 0 }

(E+1)/2

sqrt (M/2), if E mod 2 = 1 }

|D| < log e

2

0.5

≤ M < 1.0

{0.5

≤ M < 1.0

{0.25

≤ M/2 < 0.5

(M x

2

Ex

(M y

2

Ey

)(M z

2

Ez

) = (M x

M

) / (M x

2

Ex

) = (M z

)2

Ex + Ez y

/ 2M x

)2

Ey – Ex + 1

0.5

≤ M z

0.25

≤ M

< 1.0 y

/ 2M x

< 1.0

Before any development work was carried out in VHDL, the floating-point operation of the CORDIC algorithm was fully investigated via software modelling at bit-level using the C programming language.

3

**3. Design of the Co-processor IP Core **

The input/output interface of the CORDIC maths co-processor core is shown in Figure 2. There are two 32-bit wide input ports for the two possible arguments A and B. There is a 6-bit input port “OP”, which specifies which function is to be calculated, according to encoding shown below in Table 2 of Section 3.2. A “GO” input signal is to tell the co-processor that the desired values are on the inputs and to begin calculation. There is also a clock input signal. In terms of output ports, there is the 32-bit result output and also a “Done” output signal to indicate the end of a computation.

A

B

**Co-processor **

Result

OP

GO

CLK

Done

**Figure 2. **Input/output interface of the maths co-processor module.

**3.1 Structure of the Maths Co-Processor **

The VHDL model of the co-processor IP core, “Math.vhd”, has a multi-level hierarchical structure. Figure 3 shows the top level of the design hierarchy, consisting of the following blocks - a generic iterative CORDIC module, eight pre-scaling modules (Prescale000 to Prescale111), eight post-scaling modules (Postscale000 to

Postscale111), multiplexers and a finite state machine (“SM_scale.vhd”). Due to the fact that the CORDIC algorithm will only work for arguments within a certain domain, as discussed in Section 2 above, there are three stages in the computation. Any input arguments outside the specified domain are first of all scaled to within it, before being input to the iterative CORDIC module at the centre of the co-processor. The results from the

CORDIC module finally pass through post-scaling blocks, to give the true result.

Prescale000 Postscale000

CORDIC

Module

Prescale001 Postscale001

GO

…

Finite

State

Machine

…

Done

CORDIC algorithm in Section 2. The module is able to evaluate functions in the circular ( and hyperbolic (

*m*

= −

1

**Fig. 3. **Top-level block-diagram of the co-processor IP core.

The generic computational CORDIC module in Figure 3 implements the unified equations (2)-(4) of the

*m*

=

1 ), linear (

*m*

=

0 )

) modes, as shown in Figure 1. The design work also involved providing support for vectoring mode and for computing *arcsine* and *arccosine*.

4

The 16 scaling modules (8 pre-scaling and 8 post-scaling modules) implement the scaling identities in Table 1. A complex state machine, “SM_scale.vhd”, comprising different branches for each operation group, controls the scaling operations, needing to be carried out. Multiplexers could then be used to select from which pre-scaling block to take the *x *, ,

*c*

δ and inputs for the CORDIC module and also which post-scaling block to take the final result from. The diagram presented in Figure 3 only includes two sets of pre-scaling and postscaling blocks and only the

*x *,

*y*

and

*z * inputs are connected to the CORDIC module.

Main components of the generic CORDIC module in Figure 3 are three 32-bit floating-point adders/subtractors and a state machine “SM_CORD.vhd” controlling its operation.

**3.2 Extending the Domain **

Extending the domain of the arguments involved first of all scaling the input argument to be within a certain domain as specified in Table 1, starting the CORDIC module with this new argument and then scaling of the result from the CORDIC module so as to obtain the desired result.

Some of the functions can be grouped together, an obvious example being *sine*, *cosine* and *tangent*, as CORDIC can compute the *sine* and *cosine* of the angle at the same time. All that needs to be done is for the post-scaling to select either one of the two outputs, or channel both the outputs back into the division pre-scaling block, so as to produce the result for *tangent*. Similarly, it is logical to group together *sinh*, *cosh* and *tanh*. Also, as exponential is computed by addition of the *sinh* and *cosh* results, this can also be included in the group. Taking this argument a little further yields the grouping of the trigonometric and the hyperbolic functions together. The pre-scaling for both involves dividing the original argument by a constant to obtain a quotient and a remainder. The only difference is that this constant is 90º for the trigonometric functions and *log*

*e*

* 2* otherwise. Although different post-scaling would be needed, this could still be implemented in the same post-scaling block, but with multiplexers to select which result is taken. Table 2 shows the result of grouping functions together. It can be seen that each operation now has a 6-bit representation, with the 3 most significant bits being the group number and the least significant 3 bits referring to a specific function within that group.

It can be noticed that after the first two groups, it proved difficult to group any of the remaining functions together, due to the differences between the scaling techniques used. This is in spite of the fact that the *log*

*e*

function is being computed using the *tanh*

*-1*

function.

**Table 2. **Grouping of functions for pre-scaling and

post-scaling.** **

**Function Group sin cos tan sinh **

000 000

000 001

000 010

000 100

**cosh tanh exp **

000 101

000 110

000 111

**sin cos**

**-1**

**-1**

001 000

001 010

**tan**

**-1**

**tanh**

**-1**

010 000

011 000

**sqrt multiplication division log**

**e**

100 000

101 000

110 000

111 000

5

**3.3 IEEE Standard 754 Special Cases **

precision numbers, the special representations shown in Table 3.

**Table 3. **Special representations for single-precision floating-point numbers.** **

**Sign bit Exponent Mantissa Number represented **

0 0 0 Zero

0 255 0 +∞

1 255 0 -∞

0 or 1 255 Not 0 Not-a-number (NaN)

If the result of a computation carried out will have magnitude greater than is possible to represent normally with a single-precision number (1.999 x 2

127

), then the magnitude of this number must instead be set to infinity. This is known as *overflow*. Similarly, if the result of a computation will have magnitude less than is possible to represent (1.0 x 2

-126

), then the result should instead be set to zero. This is known as *underflow*.

Giving certain arguments to a particular operation might result in one of the special cases, listed in Table 3 above, being the desired result. For instance, we have no way here of representing imaginary numbers, so if a negative number is given as the argument for a square root calculation, we will want to return the *not-a-number*

(NaN) representation. Also, if a NaN representation is given as an input to an operation, then the result should also be NaN. There are a number of cases like that when the result can be determined directly, given the arguments. A list of these special cases is shown in Table 4.

**Table 4. **Special cases**. **

**Operation Argument A Argument B Result **

sin/cos/tan/sinh/cosh/tanh/ sin

-1

/cos

-1

/tan

-1

/tanh

-1

/exp sin/cos/tan/sinh/cosh/tanh/ sin

-1

/cos

-1

/tan

-1

/tanh

-1

/exp

±∞ N/A NaN

NaN N/A NaN

Sqrt +∞ N/A +∞ number NaN multiplication +∞ multiplication +∞ multiplication -∞ multiplication -∞

-∞

+∞

+∞

-∞

±∞

-∞

+∞

-∞

+∞ multiplication 0 Any 0

0 division NaN NaN division ±∞ ±∞ NaN ln +∞ N/A +∞

Eight control signals are used to detect any of the special cases based on the values of the inputs. Two of these are the sign bits of each of the two inputs (0 for positive, 1 for negative). The remaining control signals are obtained by connecting the eight exponent bits of each input to both an “allzero” detector and an “allone” detector, and the twenty-three mantissa bits of each to an “allzero” detector. The “allzero” detector outputs logic

‘1’ when all input bits are zero, logic ‘0’ otherwise. The “allone” detector performs a similar function, detecting ones.

It is ensured that all the eventualities are handled if the inputs are special case numbers. As long as the values of the input arguments are normal numbers, they will be scaled, so as to be within the domain required by the

6

CORDIC module. The CORDIC module will then compute accurate results for the mathematical operation. The state machine of the maths co-processor “SM_scale.vhd” checks for any of the aforementioned special cases. If any of these occur, then the machine jumps straight to the “Done” state, at the same time setting a certain output signal to logic ‘1’. There are four of these output signals, to show that the result should be either +∞, -∞, zero or not-a-number. In the top-level co-processor module, which contains the state machine, a 3-bit number is set dependent on these output signals from the state machine. This 3-bit number is then used as the input to a multiplexer, to select an appropriate result. This result can be either one of the special number representations or a result output from the computational part of the co-processor (a result that has been calculated in the normal way).

Of the functions computed by the co-processor, the only ones capable of producing *overflow* or *underflow* are

*sinh*, *cosh*, *tanh*, *multiplication* and *division*. It is in the post-scaling blocks where *overflow* and *underflow* are handled. Adding or subtracting a number to or from the exponent of the result achieves the final part of postscaling for each of the appropriate functions. This number comes from the corresponding pre-scaling block and is dependent on how much the original input argument had to be scaled. The addition or subtraction of the exponent is carried out with a fixed-point binary adder using the value of its most significant carry output signal as an indication of *overflow* or *underflow*. Programming in this logic, along with some checks that the final value of the exponent was not either 0 or 255 (all zeroes or all ones), enabled select signals to be produced in the postscaling blocks. These were then connected to multiplexers, to select either the scaled result, positive or negative infinity, or zero as our final result.

**4. Interfacing the Co-processor to the LEON Microprocessor Core **

**4.1 Generic Co-Processor Interface **

The LEON processor provides a generic interface enabling a co-processor to be connected. The interfacing of a

the co-processor’s execution unit to operate in parallel to the integer unit (IU). Figure 4 shows a waveform diagram defining the timing for all of the co-processor inputs and outputs [8].

As can be seen from Figure 4 the *start* signal should go high on a rising clock edge. For the one clock cycle that this is high, the correct opcode will be available on the opcode input. On the following clock rising edge, the

*load* signal will go high and the two operands will be available on the *op1* and *op2* inputs. At the same time as the *load* signal going high, the *busy* output from the co-processor must go high, and stay high until at least one clock cycle before the correct *result*; *condition* *codes* *(cc)* and *exception (exc)* will be available on the corresponding outputs.

Figure 4. Timing diagram for generic co-processor interface.

Although 64-bit operands and results are allowed for in the VHDL model of LEON, the co-processor was designed to handle single-precision numbers, which need only 32 bits. Thus it was decided that the co-processor would use only the 32 least significant bits of the inputs and outputs values. It should also be noted that 10-bit opcodes are used.

7

Being a reduced instruction set computer (RISC) architecture, it is one of the features of the SPARC standard that all computational type of operations are carried out exclusively register-to-register [9]. To facilitate this, a register file consisting of thirty-two 32-bit registers is included in the design of the co-processor unit as illustrated in Figure 5. There are specific co-processor *load* and *store* operations, which are used to move data between co-processor registers and memory locations.

The basic principle of performing a co-processor operation follows these steps:

1. Loading the operands to the coprocessor register.

2. Asserting the start signal together with a valid opcode to start execution.

3. After finishing the operation the co-processor writes the results back to a coprocessor register.

4. A store operation writes the results back to memory.

Figure 5. Interface between the LEON processor and the co-processor.

**4.2 Co-processor Operation Codes **

Two co-processor operate commands are provided, *cpop1* and *cpop2*, each of which carry a 9-bit opcode segment. The formats for these two instructions are shown in Table 5. In this table, “*rd*” represents destination register, “*rs1*” - source register 1 and “*rs2*” - source register 2. The 10-bit opcode passed to the co-processor is made up of a 0 or a 1, for *cpop1* and *cpop2* respectively, followed by the 9-bit opcode supplied with these commands in field *opc*, bits 5 to 13.

Table 5. Format of the co-processor operate instructions.

**Command 31-30 29-25 24-19 18-14 13-5 4-0 cpop1 cpop2 **

The co-processor design, described in Section 3 above, already makes use of 6-bit opcodes, so it was decided to simply add on an extra four ‘0’ bits at the most significant end of the opcode number to make these up to 10-bit opcodes. Only the *cpop1* command is actually used.

In order to implement the co-processor interface specification [8] in VHDL, a “co-processor wrapper” was created. This would contain the co-processor within itself, and implement suitable logic to map from the LEON interface to the co-processor module.

Several modifications had to be made to the LEON VHDL code so that it would interface with the co-processor correctly. Next, LEON had to be configured to accept the co-processor. Different configurations for LEON are stored as constant records in the “*target.vhd*” file. The first stage was to create a new integer unit configuration, as it is this part that decides whether or not the user-defined co-processor is enabled. A new LEON configuration record also had to be created to make use of this new IU. Once again, this was based on an existing configuration, with only the IU being altered:

8

constant fpga_2k2k_softprom_cp : config_type := (

synthesis => syn_gen, iu => iu_fpga_v8_cp, fpu => fpu_none,

cp => cp_cpc,

cache => cache_2k2k, ahb => ahb_fpga, apb => apb_std,

mctrl => mctrl_mem16,

boot => boot_mem, debug => debug_disas, pci => pci_none,

peri => peri_fpga);

Finally, the “*device.vhd*” file had to be altered to select this new configuration record.

**5. System-Level Integration and Performance Results **

The co-processor was integrated with the LEON SPARC V8 (LEON-2, version 1.0.9) microprocessor core and

its operation was tested on a XILINX Virtex XCV800 FPGA using the XSV800 [10] prototyping board as

shown in Figure 7. The bitstream was downloaded to the FPGA either directly from host PC 2 or indirectly from the on-board flash memory. Communication with LEON was carried out from host PC1 via a serial connection.

Figure 7. Integration of the LEON processor and the co-processor core.

system (RTOS), which provides a high performance environment for embedded systems. It supports preemptive multitasking capabilities, multiprocessor support task prioritization and intertask communication and synchronization. The RTOS RTEMS was installed on the LEON processor and software applications were run with and without its support as illustrated in Figure 8.

Figure 8. Running software applications on LEON with and without RTEMS.

Major problem in implementing (SPARC) co-processor support for a conventional C-program is, that the compiler cannot invoke the operations of the co-processor directly. In order to achieve that, a number of assembly language routines have to be “hard-coded” within the user C-program for each function, which requires deep knowledge of the underlying hardware by the application programmer. This may be feasible for small programs but it is truly not applicable to larger “real-world” applications. Nested co-processor calls are almost impossible using such a coding-style.

9

Therefore an additional mathematical software library “cpmath” has been developed in the programming language C. The developed C-library provides an application program interface (API) and therefore removes the need to use assembly language code to support co-processor function calls in a user program. The library is built into a single library file (libcpmath.a) using a Makefile. If a program now wants to make use of the co-processor operations, the library has to be linked to the program. Either copying the library to the standard library search path or adding the path where the library resides to the search path using gcc options <PATH_TO_LIBRARY> and -lcpmath in addition to the standard options can do this.

The Whetstone floating-point benchmark program was used to test the performance of the floating-point coprocessor. As the LEON core does not include a floating-point processor, the usual way to deal with floatingpoint calculations is to use the

-msoft-float

option during compile time, which emulates floating-point unit

(FPU) calls.

In order to use the mathematical co-processor with the newly built math-library it was necessary to make the

Whetstone test program compatible with the format of the co-processor library functions. For this purpose changes were introduced in two of the most important modules of the test. As an example, changes in module 7 of the Whetstone program are shown in Figure 9, where the co-processor functions are used in the

#ifdef CP_ENABLE

clause whereas in the

#else

clause the original code is used. It can be seen that, with the use of the cpmath library the co-processor function calls are much easier to implement compared to the alternative method of assembly language coding for each function call. However, it can also be seen, that replacing even two lines of original code by co-processor calls can sometimes be rather complicated.

#ifdef CP_ENABLE a = cpmul(t, cpatan(cpmul( t2, cpmul(cpsin(x), cpdiv(cpcos(x),

(cpadd(cpcos(cpadd(x,y)),

(cpsub(cpcos(cpsub(x,y)),

1.0))))))))); b = cpmul(t, cpatan(cpmul( t2, cpmul(cpsin(y), cpdiv(cpcos(y),

(cpadd(cpcos(cpadd(x,y)),

(cpsub(cpcos(cpsub(x,y)),

1.0)))))))));

#else c = t * atan(t2*sin(x)*cos(x) / (cos(x+y)+cos(x-y)-1.0)); d = t * atan(t2*sin(y)*cos(y) / (cos(x+y)+cos(x-y)-1.0));

#endif

Figure 9. Enabling co-processor support in a user program.

The Whetstone test was executed on four different versions of the hardware, configured as follows:

1) LEON, cp-disabled - the LEON processor on its own;

2) LEON, cp-enabled - the LEON processor with integrated co-processor core;

3) LEON/RTEMS, cp-disabled - the LEON processor on its own but running under RTEMS; and

4) LEON/RTEMS, cp-enabled - the LEON processor with integrated co-processor core and running under RTEMS.

The co-processor has shown impressive capabilities in this test. The advantages of the co-processor can be clearly seen from Table 6 and Figure 10, which show the performance results in seconds of execution time and kilo Whetstone-instructions per second (KWIPS).

Table 6. Whetstone test - performance results.

10

Figure 10. Whetstone test – comparison of performance in KWIPS.

It must be noted that the maths library “cpmath”, discussed above, is totally hardware-dependent and only works with this *specific co-processor.* However the principles are the same for any SPARC V8 architecture and different co-processor op-codes can easily be adopted by changing the *cpop.c*, *cpop.h* and *cpmath.h* files.

**6. Conclusions **

This paper has described the main features of a 32-bit mathematical co-processor VHDL core for a system-on-achip on-board computer, based on the LEON SPARC V8 IP core. The co-processor is aimed at speeding up computationally intensive applications on-board a small satellite, traditionally implemented in software, e.g. attitude/orbit determination and control system (AODCS) algorithms.

The co-processor is compliant with the 32-bit floating-point IEEE 754 standard and implements 10 trigonometric and hyperbolic functions, as well as square root, logarithm and exponential functions alongside the four main arithmetic operations of addition, subtraction, multiplication and division.

Comprehensive investigation of the accuracy and correctness of the numerical results, generated by the coprocessor, was undertaken, which has shown that, overall, the accuracy of the co-processor is extremely good.

The co-processor operates at 25 MHz - when working standalone and at 2.5MHz, when integrated with the

LEON IP core. The co-processor accelerates the execution of floating-point calculations on the LEON processor.

The Whetstone benchmark runs 70% faster on the LEON processor with integrated co-processor core under

RTEMS, compared with the time it takes on LEON under RTEMS but without the co-processor. The coprocessor occupies half the size of a XILINX Virtex XCV800 chip.

The developed co-processor design is modular and its functionality can easily be tailored to a particular application via reduction or expansion of the range of supported mathematical functions.

**Acknowledgements **

We would like to gratefully acknowledge financial support from the Surrey Satellite Technology Ltd. (SSTL), which has enabled us to integrate the co-processor core with LEON under RTEMS and to run performance tests.

Thanks are due to Alex da Silva Curiel from SSTL for his encouragement and support.

**References **

1. H.Tiggeler, T.Vladimirova, J.Gaisler. “Designing a System-on-a-chip for Small Satellite Data Processing and

Control”, IIE Magazine on Engineering Technology, vol. 4, N 6, June 2001, pp. 38-42 .

2. D.Zheng, T.Vladimirova, M.Sweeting. “A CCSDS-Based Communication System for a Single Chip On-

Board Computer”, Proceedings of the 5 th

Military and Aerospace Applications of Programmable Devices and

Technologies International Conference (MAPLD'2002), D5, September 2002, Laurel, Maryland, US.

11

3

.

D.Zheng, T.Vladimirova, H.Tiggeler. M. Sweeting. “Reconfigurable Single-Chip On-Board Computer for a

Small Satellite” – Proceedings of the 52 nd

October 2001, Toulouse, France.

International Astronautical Federation Congress, IAF-01-U3.09,

4. J. Volder. “The CORDIC Trigonometric Computing Technique”, IRE Trans. Electronic Computing,

Vol EC-8, pp. 330-334, September, 1959.

5. J.S. Walther. “A Unified Algorithm for Elementary Functions”, Proceedings of the Spring Joint Computer

Conference, 1971, pp. 379-385.

6

.

R. Andraka. “A Survey of CORDIC Algorithms for FPGA Based Computers”, FPGA 98, Monterey CA USA,

Andraka Consulting Group, Inc, 1998.

7. “IEEE Standard for Binary Floating-Point Arithmetic”, ANSI/IEEE Std. 754-1985, The Institute of Electrical and Electronic Engineers, Inc., 345 East 47th Street, New York, New York 10017, July 1985

8. J. Gaisler. “The LEON Processor User’s Manual”, Gaisler Research, http://www.gaisler.com/

9.“The SPARC Architecture Manual, Version 8”, SPARC International Inc., http://www.sparc.org/standards/V8.pdf

10. “XCV800 Prototyping Board V1.1 Manual, How to install and use your new XSV Board”, X Engineering

Software Systems (XESS) Corporation, http://www.xess.com/manuals/xsv-manual-v1_1.pdf

11. RTEMS Features, http://www.rtems.com/features.html

12

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

### Related manuals

advertisement
