User Manual of iVMS-4200
Contents
Chapter 1
1.1
1.2
1.3
1.4
Chapter 2
2.1
2.2
Overview ................................................................................................................... 4
Description ................................................................................................................ 4
Running Environment................................................................................................ 4
Function Modules ..................................................................................................... 4
Updates Instruction ................................................................................................... 7
Live View ................................................................................................................... 8
User Registration and Login ...................................................................................... 8
Adding the Device ..................................................................................................... 9
2.2.1
Adding Online Devices....................................................................................... 9
2.2.2
Adding Devices Manually ................................................................................ 11
2.2.3
Adding Devices by IP Segment ........................................................................ 11
2.2.4
Adding Devices by IP Server ............................................................................ 12
2.2.5
Adding Devices by HiDDNS .............................................................................. 13
2.3
Group Management ................................................................................................ 14
2.4
Basic Operations in Live View.................................................................................. 17
2.4.1
Starting and Stopping the Live View ............................................................... 19
2.4.2
Auto-switch in Live View ................................................................................. 20
2.4.3
PTZ Control in Live View .................................................................................. 21
2.4.4
Manual Recording and Capture....................................................................... 24
2.4.5
Instant Playback .............................................................................................. 26
2.4.6
Live View of Fisheye Camera ........................................................................... 28
2.4.7
Other Functions in Live View........................................................................... 30
Chapter 3
Remote Record Schedule Settings and Playback..................................................... 31
3.1
Remote Recording ................................................................................................... 31
3.1.1
Recording on Storage Devices on the DVRs, NVRs, or Network Cameras ....... 31
3.1.2
Recording on Storage Device........................................................................... 34
3.2
Remote Playback ..................................................................................................... 36
3.2.1
Normal Playback.............................................................................................. 37
3.2.2
Event Playback................................................................................................. 39
3.2.3
Synchronous Playback ..................................................................................... 40
3.2.4
VCA Playback ................................................................................................... 41
3.2.5
Playback of Fisheye Camera ............................................................................ 42
Chapter 4
Event Management ................................................................................................. 44
4.1
Configuring Motion Detection Alarm ...................................................................... 44
4.2
Configuring Video Tampering Alarm ....................................................................... 47
4.3
Configuring PIR Alarm ............................................................................................. 48
4.4
Configuring Video Loss Alarm ................................................................................. 49
4.5
Configuring Audio Detection Alarm ........................................................................ 50
4.6
Configuring Defocus Detection Alarm ..................................................................... 51
4.7
Configuring Face Detection Alarm .......................................................................... 52
4.8
Configuring Line Crossing Detection Alarm ............................................................. 53
4.9
Configuring Intrusion Detection Alarm ................................................................... 55
1
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
4.10
4.11
4.12
4.13
4.14
Chapter 5
5.1
5.2
Configuring Scene Change Alarm ............................................................................ 56
Configuring VCA Exception Alarm ........................................................................... 57
Configuring Alarm Input Linkage ............................................................................. 58
Configuring Device Exception Linkage..................................................................... 59
Viewing Alarm and Event Information .................................................................... 60
E-map Management ................................................................................................ 63
Adding an E-map ..................................................................................................... 63
The Hot Spot Function ............................................................................................ 65
5.2.1
Adding Hot Spots ............................................................................................. 65
5.2.2
Modifying Hot Spots........................................................................................ 66
5.2.3
Previewing Hot Spots ...................................................................................... 67
5.3
The Hot Region Function ......................................................................................... 67
5.3.1
Adding Hot Regions ......................................................................................... 68
5.3.2
Modifying Hot Regions .................................................................................... 68
5.3.3
Previewing Hot Regions................................................................................... 69
Chapter 6
Cloud Service ........................................................................................................... 70
6.1
Registering a Cloud Account.................................................................................... 70
6.2
Logging into Cloud Account..................................................................................... 70
6.3
Device Management ............................................................................................... 71
Chapter 7
VCA Devices Management ...................................................................................... 73
7.1
Allocating VCA Resource ......................................................................................... 73
7.2
Behavior Analysis Configuration.............................................................................. 74
7.2.1
VCA DVR/DVS/IPC Configuration ..................................................................... 74
7.2.2
VCA Server Configuration ................................................................................ 81
7.3
Configuring Face Capture IPC .................................................................................. 83
7.3.1
Camera Configuration ..................................................................................... 83
7.3.2
Shield Region Configuration ............................................................................ 83
7.3.3
VCA Rule Configuration ................................................................................... 84
7.3.4
Advanced Configuration .................................................................................. 85
7.4
VCA Speed Dome Configuration.............................................................................. 86
7.4.1
Behavior Analysis ............................................................................................ 86
7.4.2
Face Capture.................................................................................................... 92
7.4.3
Behavior & Face Capture ................................................................................. 96
Chapter 8
Transcoder Management ...................................................................................... 100
8.1
Adding Encoding Device to the Transcoder........................................................... 100
8.1.1
Adding the Transcoder to the Client Software .............................................. 100
8.1.2
Importing the Encoding Channel to the Transcoder ..................................... 101
8.2
Configuring the Transcoded Stream Parameters................................................... 102
8.3
Operating the Transcoded Stream ........................................................................ 103
Chapter 9
Log Management .................................................................................................. 104
Chapter 10
Account Management and System Configuration................................................. 106
10.1
Account Management ........................................................................................... 106
10.2
System Configuration ............................................................................................ 107
10.2.1 General Settings ............................................................................................ 108
2
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
10.2.2 File Saving Path Settings ................................................................................ 109
10.2.3 Keyboard and Joystick Shortcuts Settings ..................................................... 110
10.2.4 Alarm Sound Settings .................................................................................... 111
10.2.5 Email Settings ................................................................................................ 111
Chapter 11
Forwarding Video Stream through Stream Media Server ..................................... 113
11.1
Adding the Stream Media Server .......................................................................... 113
11.2
Adding Cameras to Stream Media Server to Forward Video Stream .................... 114
Chapter 12
Decoding and Displaying Video on Video Wall...................................................... 115
12.1
Adding the Encoding Device.................................................................................. 115
12.2
Adding the Decoding Device ................................................................................. 117
12.3
Configuring Video Wall Settings ............................................................................ 118
12.3.1 Linking Decoding Output with Video Wall .................................................... 118
12.3.2 Multi-screen Display ...................................................................................... 120
12.3.3 Configuring Background ................................................................................ 121
12.4
Displaying Video on Video Wall............................................................................. 122
12.4.1 Decoding and Displaying ............................................................................... 122
12.4.2 Windowing and Roaming Settings ................................................................ 124
12.4.3 Configuring Playback ..................................................................................... 125
12.4.4 Configuring Cycle Decoding........................................................................... 126
12.5
Configuring Video Wall Controller......................................................................... 127
12.5.1 Adding the Video Wall Controller.................................................................. 127
12.5.2 Linking Output with Video Wall .................................................................... 127
12.5.3 Configuring Virtual LED ................................................................................. 128
12.5.4 Configuring Video Wall Screens .................................................................... 129
12.5.5 Displaying Video on Video Wall..................................................................... 130
12.5.6 Configuring Plan ............................................................................................ 131
Chapter 13
Web Browsing ....................................................................................................... 133
13.1
Login ...................................................................................................................... 133
13.2
Device Management ............................................................................................. 134
13.3
Live View ............................................................................................................... 138
13.4
Playback ................................................................................................................ 142
13.5
Account Management ........................................................................................... 145
13.6
System Configuration ............................................................................................ 146
Troubleshooting ............................................................................................................................ 147
3
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Chapter 1 Overview
1.1 Description
iVMS-4200 is a versatile video management software for the DVRs, NVRs, IP cameras, encoders,
decoders, VCA device, alarm host, etc. It provides multiple functionalities, including real-time live view,
video recording, remote search and playback, file backup, alarm receiving, etc., for the connected
devices to meet the needs of monitoring task. With the flexible distributed structure and easy-to-use
operations, the client software is widely applied to the surveillance projects of medium or small scale.
This user manual describes the function, configuration and operation steps of iVMS-4200 software. To
ensure the properness of usage and stability of the software, please refer to the contents below and
read the manual carefully before installation and operation.
1.2 Running Environment
Operating System: Microsoft Windows 7 / Windows 2008 (32 / 64-bit), Windows 2003 / Windows XP
(32-bit)
CPU: Intel Pentium IV 3.0 GHz or above
Memory: 1G or above
Display: 1024*768 or above
Notes:

For high stability and good performance, these above system requirements must be met.

The software does not support 64-bit operating system; the above mentioned 64-bit operating
system refers to the system which supports 32-bit applications as well.
1.3 Function Modules
Control Panel of iVMS-4200:
4
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Menu Bar:
Open Captured picture
File
System
Open Video File
Open Log File
Search and view the video files recorded on local PC.
View the backup log files.
Exit
Exit the iVMS-4200 client software.
Lock
Lock screen operations. Log into the client again to unlock.
Switch User
Switch the login user.
Import System Config File
Import client configuration file from your computer.
Export System Config File
Export client configuration file to your computer.
View
1024*768
Display the window at size of 1024*768 pixels.
1280*1024
Display the window at size of 1280*1024 pixels.
1440*900
Display the window at size of 1440*900 pixels.
1680*1050
Display the window at size of 1680*1050 pixels.
Full Screen
Display the window in full screen.
Control Panel
Main View
Remote Playback
E-map
Auxiliary Screen Preview
Tool
Search and view the captured pictures stored on local PC.
Enter Control Panel interface.
Open Main View page.
Open Remote Playback page.
Open E-map page.
Open Auxiliary Screen Preview window.
Device Management
Open the Device Management page.
Event Management
Open the Event Management page.
Record Schedule
Account Management
Log Search
System Configuration
Open the Record Schedule page.
Open the Account Management page.
Open the Log Search page.
Open the System Configuration page.
5
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Broadcast
Device Arming Control
I/O Control
Player
Message Queue
Open Wizard
Open Video Wall Wizard
Help
User Manual (F1)
About
Language
Select camera to start broadcasting.
Set the arming status of devices.
Turn on/off the alarm output.
Open the player to play the video files.
Display the information of Email message to be sent.
Open the guide for the client configuration.
Open the guide for the video wall configuration.
Click to open the User Manual; you can also open the User
Manual by pressing F1 on your keyboard.
View the basic information of the client software.
Select the language for the client software and reboot the
software to activate the settings.
The iVMS-4200 client software is composed of the following function modules:
The Main View module provides live view of network cameras and video encoders, and
supports some basic operations, such as picture capturing, recording, PTZ control, etc.
The Remote Playback module provides the search, playback, export of record files.
The Video Wall module provides the management of decoding device and video wall and
the function of displaying the decoded video on video wall.
The E-map module provides the displaying and management of E-maps, alarm inputs, hot
regions and hot spots.
The Device Management module provides the adding, modifying and deleting of different
devices and the devices can be imported into groups for management.
The Event Management module provides the settings of arming schedule, alarm linkage
actions and other parameters for different events.
The Record Schedule module provides the schedule settings for recording.
The Account Management module provides the adding, modifying and deleting of user
accounts and different permissions can be assigned for different users.
The Log Search module provides the query of system log files and the log files can be
filtered by different types.
The System Configuration module provides the configuration of general parameters, file
saving paths, alarm sounds and other system settings.
Note: The Video Wall module only displays when decoding devices are added to the client. For adding
device devices, please refer to Section 12.2 Adding the Decoding Device.
The function modules are easily accessed by clicking the navigation buttons on the control panel or by
selecting the function module from the View or Tool menu.
You can check the information, including current user, network usage, CPU usage, memory usage and
time, in the upper-right corner of the main page.
6
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
1.4 Updates Instruction
Multiple newly-designed functions are offered in the latest iVMS-4200 client software. You can get a
brief view of the updates instruction from the following contents.

Support Management for Multiple New Device Types
Some new device types can be added and managed by the client, including the fisheye camera,
device registered on Cloud service, VCA device, transcoder, video wall controller

Support VCA Playback
VCA rule can be set to the searched record files and find the video that VCA event occurs,
including VCA Search, Intrusion and Line Crossing. This function helps to search out the video
that you may be more concerned, and the playback speed of the concerned video and
unconcerned video can be customized.

Newly Added Event Configuration
The event, such as audio detection, defocus detection, face detection and line crossing detection,
can be configured via the client. And alarm linkage settings for the events are also configurable.

Alarm and Event Information Filter
The received alarm and event information can be filtered by selecting the needed event types. In
this way, the important information can be searched quickly.
7
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Chapter 2 Live View
2.1 User Registration and Login
For the first time to use iVMS-4200 client software, you need to register a super user for login.
Steps:
1.
Input the super user name and password.
2.
Confirm the password.
3.
Optionally, check the checkbox Enable Auto-login to log into the software automatically.
4.
Click Register. Then, you can log into the software as the super user.
Notes:

A user name cannot contain any of the following characters: / \ : * ? “ < > |

The password cannot be empty and the length of the password should be no less than six
characters.
When opening iVMS-4200 after registration, you can log into the client software with the registered
user name and password.
Steps:
1.
Input the user name and password you registered.
Note: If you forget your password, please click Forgot Password and remember the encrypted
string in the pop-up window. Contact your dealer and send the encrypted string to him to reset
your password.
2.
Optionally, check the checkbox Enable Auto-login to log into the software automatically.
3.
Click Login.
8
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
After running the client software, a wizard will pop up to guide you to add the device and do some
basic settings.
2.2 Adding the Device
Purpose:
After running the iVMS-4200, devices including network cameras, video encoders, DVRs, NVRs,
decoder, etc. should be added to the client for the remote configuration and management, such as
live view, playback, alarm settings, etc.
Perform the following steps to enter the Device Adding interface:
1.
Click the
icon on the control panel,
or click Tools->Device Management to open the Device Management page.
2.
Click the Server tab.
3.
Click Encoding Device to enter Encoding Device Adding interface.
Note: Here we take the adding of encoding device as an example.
You can add the device in the following ways:

By detecting the online devices, see Section 2.2.1 Adding Online Devices.

By specifying the device IP address, see Section 2.2.2 Adding Devices Manually.

By specifying an IP segment, see Section 2.2.3 Adding Devices by IP Segment.

By IP Server, see Section 2.2.4 Adding Devices by IP Server.

By HiDDNS, see Section 2.2.5 Adding Devices by HiDDNS.
2.2.1 Adding Online Devices
Purpose:
The active online devices in the same local subnet with the client software will be displayed on a list.
You can click the Refresh Every 15s button to refresh the information of the online devices.
9
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Steps:
1.
Select the devices to be added from the list.
2.
Click Add to Client to open the device adding dialog box.
3.
Input the required information.
Nickname: Edit a name for the device as you want.
Address: Input the device’s IP address. The IP address of the device is obtained automatically in
this adding mode.
Port: Input the device port No.. The default value is 8000.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
5.
Click Add to add the device.
Add All the Online Devices
If you want to add all the online devices to the client software, click Add All and click OK in the pop-up
message box. Then enter the user name and password for the devices to be added.
Modify Network Parameters
Select the device from the list, click Modify Netinfo, and then you can modify the network
10
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
information of the selected device.
Note: You should enter the admin password the device in the Password field of the pop-up window to
modify the parameters.
Restore Default Password
Select the device from the list, click Restore Default Password, input the security code, and then you
can restore the default password of the selected device.
Note: The default admin password of the device is 12345, and the security code is returned after you
send the data and serial No. of the device to the manufacturer.
2.2.2 Adding Devices Manually
Steps:
1.
Click Add Device to open the device adding dialog box.
2.
Select IP/Domain as the adding mode.
3.
Input the required information.
Nickname: Edit a name for the device as you want.
Address: Input the device’s IP address or domain name.
Port: Input the device port No.. The default value is 8000.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
5.
Click Add to add the device.
2.2.3 Adding Devices by IP Segment
Steps:
1.
Click Add Device to open the device adding dialog box.
2.
Select IP Segment as the adding mode.
11
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
3.
Input the required information.
Start IP: Input a start IP address.
End IP: Input an end IP address in the same network segment with the start IP.
Port: Input the device port No.. The default value is 8000.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device IP. All the
channels of the device will be imported to the corresponding group by default.
5.
Click Add, and the device of which the IP address is between the start IP and end IP will be added
to the device list.
2.2.4 Adding Devices by IP Server
Steps:
1.
Click Add Device to open the device adding dialog box.
2.
Select IP Server as the adding mode.
3.
Input the required information.
Nickname: Edit a name for the device as you want.
Server Address: Input the IP address of the PC that installs the IP Server.
Device ID: Input the device ID registered on the IP Server.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
5.
Click Add to add the device.
12
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
2.2.5 Adding Devices by HiDDNS
Steps:
1.
Click Add Device to open the device adding dialog box.
2.
Select HiDDNS as the adding mode.
3.
Input the required information.
Nickname: Edit a name for the device as you want.
Server Address: www.hik-online.com.
Device Domain Name: Input the device domain name registered on HiDDNS server.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
5.
Click Add to add the device.
Note: iVMS-4200 also provides a method to add the offline devices. Check the checkbox Add Offline
13
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Device, input the required information and the device channel number and alarm input number, and
then click Add. When the offline device comes online, the software will connect it automatically.
The devices will be displayed on the device list for management after added successfully. You can
check the resource usage, HDD status, recording status, and other information of the added devices
on the list.
Click Refresh All to refresh the information of all added devices. You can also input the device name in
the filter field for search.
Select device from the list, click Modify/Delete, and then you can modify/delete the information of
the selected device.
Select device from the list, click Remote Config, and then you can do some remote configurations of
the selected device if needed. For detailed settings about the remote configuration, please refer to
the User Manual of the devices.
2.3 Group Management
Purpose:
The devices added can be organized into groups for a convenient management. You can get the live
view, play back the record files, and do some other operations of the device through the group.
Before you start:
Devices need to be added to the client software for group management.
Perform the following steps to enter the Group Management interface:
1.
Open the Device Management page.
2.
Click the Group tab to enter the Group Management interface.
Adding the Group
Steps:
14
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
1.
Click
to open the Add Group dialog box.
2.
Input a group name as you want.
3.
Click OK to add the new group to the group list.
You can also check the checkbox Create Group by Device Name to create the new group by the
name of the selected device.
Importing Encoding Device to Group
Steps:
1.
Click Import on Group Management interface, and then click the Encoding Channel tab to open
the Import Encoding Channel page.
2.
Select the thumbnails/names of the cameras in the thumbnail/list view.
3.
Select a group from the group list.
4.
Click Import to import the selected cameras to the group.
You can also click Import All to import all the cameras to a selected group.
Notes:


You can also click the icon
on the Import Encoding Channel page to add a new group.
Up to 64 cameras can be added to one group.
The following buttons are available on the Import Encoding Channel page:
List View
View the camera in list view.
Thumbnail View
View the camera in thumbnail view.
Refresh
Refresh the latest information of added cameras.
Import
Create a group named as device name-Encoding Channel
15
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
(Alarm Input) and import the device to group.
Collapse/Expand
Collapse/Expand the thumbnails of cameras.
Modifying the Group/Camera
Steps:
1.
Select the group/camera from the group list on the Import Encoding Channel page.
2.
3.
Click
, or double-click the group/camera name to open Modify Group/Camera dialog box.
Edit the group/camera information, including the group/camera name, the stream type, etc.
Video Stream: Select the stream for the camera as desired.
Protocol Type: Select the transmission protocol for the camera.
Stream Media Server: Configure to get stream of the camera via stream media server. You can
select and manage the available stream media server.
Copy to…: Copy the configured parameters to other camera(s).
Refresh: Get a new captured picture for the live view of the camera.
Note: For video stream and protocol type, the new settings will take effect after you reopen the
live view of the camera.
4.
Click OK to save the new settings.
You can also double-click the group/camera name on the Group Management interface to open
the Modify Group/Camera dialog box.
Removing Cameras from the Group
Steps:
1.
Select the camera from the group list on the Import Encoding Channel page.
2.
Click
to remove the camera from the group.
You can also select the camera on the Group Management interface, and then click Delete to
remove the camera from the group.
Select the group from the group list on the Import Encoding Channel page, click
remove all the cameras from the group.
and you can
Deleting the Group
16
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Steps:
1.
Select the group on the Group Management interface
2.
Click Delete Group or click the icon
deleted.
, the selected group and the resource under it will be
2.4 Basic Operations in Live View
Purpose:
For the surveillance task, you can view the live video of the added network cameras and video
encoders on the Main View page. And some basic operations are supported, including picture
capturing, manual recording, PTZ control, etc.
Before you start:
A camera group is required to be defined for live view.
Click the
icon on the control panel,
or click View->Main View to open the Main View page.
Main View Page
1 View List
2 Camera List
3 PTZ Control Panel
4 Display Window of Live View
5 Live View Toolbar
Camera Status:
The camera is online and works properly.
The camera is in live view.
The camera is in recording status.
The camera is offline.
17
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Live View Toolbar:
On the Main View page, the following toolbar buttons are available:
Set Screen Layout
Set the screen layout mode.
Save View
Save the new settings for the current view.
Save View as
Save the current view as another new view.
Stop Live View
Stop the live view of all cameras.
Previous
Go for live view of the previous page.
Next
Go for live view of the next page.
Resume/Pause
Auto-switch
Click to resume/pause the auto-switch in live view.
Show /Hide the Menu
Show/Hide the menu of auto-switch. Click again to hide.
Mute/Audio On
Turn off/on the audio in live view
Full Screen
Display the live view in full screen mode. Press ESC to exit.
Right-click on the display window in live view to open the Live View Management Menu:
The following buttons are available on the right-click Live View Management Menu:
Stop Live View
Stop the live view in the display window.
Capture
Capture the picture in the live view process.
Print Captured Picture
Capture the current picture and then print the picture.
Send Email
Start/Stop Recording
Open PTZ Control
Open Digital Zoom
Switch to Instant
Playback
Start/Stop Two-way
Audio
Capture the current picture and then send an Email notification to
one or more receivers. The captured picture can be attached.
Start/Stop the manual recording. The record file is stored in the PC.
Enable PTZ control function on the display window. Click again to
disable the function.
Enable the digital zoom function. Click again to disable the function.
Switch to instant playback mode.
Click to start/stop the two-way audio of the camera in live view.
18
/R&DOO
ZZZFFWYLUHODQGLH
VKRS#FFWYLUHODQGLH
User Manual of iVMS-4200
Enable/Disable Audio
Camera Status
Remote Config
Click to enable/disable the audio in live view.
Display the status of the camera in live view, including the recording
status, signal status, connection number, etc.
Open the remote configuration page of the camera in live view.
Enter the VCA configuration interface of the device if it is VCA
VCA Config
device.
Synchronization
Sync the camera in live view with the PC running the client software.
Batch Time Sync
Set time synchronization for devices in batch.
Enter the fisheye expansion mode. Only available when the device is
Fisheye Expansion
fisheye camera. For details, please refer to Section 2.4.6 Live View of
Fisheye Camera.
Full Screen
Display the live view in full screen mode. Click the icon again to exit.
2.4.1 Starting and Stopping the Live View
Starting Live View for One Camera
Steps:
1.
Open the Main View page.
2.
3.
Optionally, click the
icon in live view toolbar to select the screen layout mode for live view.
Click-and-drag the camera to the display window,
or double-click the camera name after selecting the display window to start the live view.
Note: You can click-and-drag the video of the camera in live view to another display window if
needed.
Starting Live View for Camera Group
Steps:
1.
Open the Main View page.
2.
Click-and-drag the group to the display window,
or double-click the group name to start the live view.
Note: The display window number is self-adaptive to the camera number of the group.
Starting Live View in Default View Mode
Purpose:
The video of the added cameras can be displayed in different view modes. 4 frequently-used default
view modes are selectable: 1-Screen, 4-Screen, 9-Screen and 16-Screen.
Steps:
1.
Open the Main View page.
2.
Click the icon
3.
Click to select the default view mode and the video of the added cameras will be displayed in a
to expand the default view list.
sequence in the selected view.
Note: Right-click the current default view name on the list and click Save View As. or click
you can save the default view as a custom view.
, and
19
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Starting Live View in Custom View Mode
Purpose:
The view mode can also be customized for the video live view.
Steps:
1.
Open the Main View page.
2.
Click the icon
to expand the custom view list.
3.
Click New View in the custom view list to create a new view.
4.
Input the view name and click Add. The new view is of 4-Screen mode by default.
5.
Optionally, click the
view.
6.
Click-and-drag the camera/group to the display window,
icon in live view toolbar and select the screen layout mode for the new
or double-click the camera/group name in custom view mode to start the live view.
7.
Click the icon
to save the new view.
Right-click the custom view name on the list, and a menu pops up as follows:
The following buttons are available on the right-click menu:
Edit View Name
Edit the name of the custom view.
Delete View
Delete the custom view.
Save View
Save the new settings of the custom view.
Save View As.
Save the current view as another custom view.
Stopping the Live View
Steps:
1.
Select the display window.
2.
Click the icon
display window,
that appears in the upper-right corner when the mouse pointer is over the
or click Stop Live View on the right-click menu to stop the live view of the display window.
You can also click the button
in live view toolbar to stop all the live view.
2.4.2 Auto-switch in Live View
Camera Auto-switch
Purpose:
The video stream of the cameras from the same group will switch automatically in a selected display
window in camera auto-switch.
Steps:
20
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
1.
Open the Main View page.
2.
Select a display window for camera auto-switch.
3.
Click the icon
4.
Select a group and click the icon
5.
You can click the icon
in the toolbar and select or customize the switching interval.
/
on the group node.
to pause/resume the camera auto-switch.
Single View Auto-switch
Purpose:
The video of all the cameras on the camera list will switch automatically in a selected default view in
single view auto-switch.
Steps:
1.
Open the Main View page.
2.
Click the icon
3.
Select a default view and click the icon
4.
You can click the icon
in the toolbar and select or customize the switching interval.
/
on the selected view node.
to pause/resume the single view auto-switch.
Multi-view Auto-switch
Purpose:
The custom views will switch automatically in multi-view auto-switch. The custom views need to be
added before proceeding.
Steps:
1.
Open the Main View page.
2.
Click the icon
3.
Click the icon
4.
You can click the icon
in the toolbar and select the switching interval.
on the custom view node.
/
to pause/resume the multi-view auto-switch.
2.4.3 PTZ Control in Live View
The software provides PTZ control for cameras with pan/tilt/zoom functionality. You can set the preset,
patrol and pattern for the cameras on the PTZ Control panel. And you can also open window PTZ
control for the operations of PTZ cameras.
Click the icon
to expand the PTZ Control panel.
21
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
The following buttons are available on the PTZ Control panel:
Zoom
Focus
Iris
Auxiliary Focus
3D Positioning
Light
Wiper
Lens Initialization
Configuring the Preset
A preset is a predefined image position which contains information of pan, tilt, focus and other
parameters.
Perform the following steps to add a preset:
1.
Click the Preset button to enter the PTZ preset configuration panel.
2.
Click the direction buttons and other buttons on the PTZ control panel to steer the camera to the
desired view.
3.
4.
Select a PTZ preset number from the preset list and click
Input the name of the preset in the pop-up dialog box.
5.
Click OK to save the settings.
.
To call a configured preset, double-click the preset, or select the preset and click the icon
To modify a configured preset, select the preset from the list and click the icon
To delete a configured preset, select the preset from the list and click the icon
.
.
.
Configuring the Pattern
A pattern is a memorized, repeating series of pan, tilt, zoom, and preset functions.
Perform the following steps to add a pattern:
1.
Click the Pattern button to enter the PTZ pattern configuration panel.
2.
3.
Click
to start recording of this pattern path.
Use the direction buttons to control the PTZ movement.
22
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.
Click
to stop and save the pattern recording.
5.
Click the icon
to call the pattern. To stop calling the pattern, click
.
Configuring the Patrol
A patrol is a scanning track specified by a group of user-defined presets, with the scanning speed
between two presets and the dwell time at the preset separately programmable.
Before you start:
Two or more presets for one PTZ camera need to be added.
Perform the following steps to add and call a patrol:
1.
Click the Patrol button to enter the PTZ patrol configuration panel.
2.
Select a track number from the drop-down list.
3.
4.
Click
to add a preset, and set the dwell time and patrol speed for the preset.
Repeat the above operation to add other presets to the patrol.
5.
Optionally, you can click
6. Click the icon
Notes:
or
to edit or delete a preset in the patrol path.
to call the patrol. To stop calling the patrol, click
.

Up to 16 patrols can be configured.

The preset dwell time can be set to 1~30 sec, and the patrol speed can be set to level 1~40.
23
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
2.4.4 Manual Recording and Capture
Toolbar in Each Live View Display Window:
In each live view display window, the following toolbar buttons are available:
Capture
Start/Stop Recording
Switch to Instant
Playback
Capture the picture in the live view process. The capture picture
is stored in the PC.
Start/Stop manual recording. The record file is stored in the PC.
Switch to the instant playback mode.
Manual Recording in Live View
Purpose:
Manual Recording function allows you to record the live video on the Main View page manually and
the record files are stored in the local PC.
Steps:
1.
Move the mouse pointer to the display window in live view to show the toolbar.
2.
Click
in the toolbar of the display window or on the right-click Live View Management Menu
to start the manual recording. The icon
3.
turns to
.
Click the icon
to stop the manual recording.
A prompt box with the saving path of the video files you just recorded will pop up if all the
operations succeed.
Notes:

During the manual recording, an indicator
window.

The saving path of video files can be set on the System Configuration interface. For details, see
appears in the upper-right corner of the display
Section 10.2.2 File Saving Path Settings.
Viewing Local Record Files
Steps:
1.
Click File->Open Video File to open the Record Files page.
2.
Select the camera to be searched from the Camera Group list.
3.
4.
Click the icon
to specify the start time and end time for the search.
Click Search. The video files recorded between the start time and end time will be displayed.
Select the video file, and click Delete. You can delete the video file.
Select the video file, and click Email Linkage. You can send an Email notification with the selected
video file attached.
Select the video file, and click Save as. You can save a new copy of the video file.
Note: To send an Email notification, the Email settings need to be configured before proceeding. For
details, see Section 10.2.5 Email Settings.
24
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Double-click the video file and the video file can be played back locally.
The following buttons are available on the local playback page:
CIF/4CIF
Display the video in cif/4cif resolution.
Full Screen
Display the local playback page in full screen mode.
Close
Close the local playback page of the record files.
Pause/Play
Pause/Start the playback of the record files.
Stop
Stop the playback of the record files.
Speed
Set the playback speed.
Single Frame
Play back the record files frame by frame.
Digital Zoom
Enable the digital zoom function. Click again to disable.
Enable/Disable Audio
Click to enable/disable the audio in the local playback.
Capture
Capture the picture in the playback process.
Capturing Picture in Live View
25
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Steps:
1.
Move the mouse pointer to the display window in live view to show the toolbar.
2.
Click the icon
in the toolbar of the display window or on the right-click Live View
Management Menu.
A small window of the captured picture will be displayed to notify whether the capturing
operation is done or not.
Note: The saving path of the captured pictures can be set on the System Configuration interface. For
details, see Section 10.2.2 File Saving Path Settings.
Viewing Captured Pictures
The pictures captured in live view are stored in the PC running the software. You can view the
captured pictures if needed.
Steps:
1.
Click File->Open Captured Picture to open the Captured Picture page.
2.
Select the camera to be searched from the Camera Group list.
3.
4.
Click the icon
to specify the start time and end time for the search.
Click Search. The pictures captured between the start time and end time will be displayed.
5.
Double-click the captured picture to enlarge it for a better view.
Select the captured picture, and click Print. You can print the selected picture.
Select the captured picture, and click Delete. You can delete the selected picture.
Select the captured picture, and click Email Linkage. You can send an Email notification with the
selected picture attached.
Select the captured picture, and click Save as. You can save a new copy of the selected picture.
2.4.5 Instant Playback
Purpose:
The record files can be played back instantly on the Main View page. Instant playback shows a passage
of the video which was remarkable, or which was unclear on the first sight. Thus, you can get an
immediate review if needed.
26
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Before you start:
The video files need to be recorded on the storage devices, such as the SD/SDHC cards and HDDs on
the DVRs, NVRs, Network Cameras, etc., or on the storage servers.
Steps:
1.
Start the live view and move the mouse pointer to the display window to show the toolbar.
2.
Click the icon
in the toolbar and a list of time periods pops up.
30s, 1 min, 3 min, 5 min, 8 min, and 10 min are selectable.
3.
Select a time period to start the instant playback.
Example: If the current time of the live view is 09:30:00, and you select 3 min, then the instant
playback will start from 09:27:00.
4. Click the icon
Notes:
again to stop the instant playback and go back for the live view.

During the instant playback, an indicator
window.

The live view process will continue after the instant playback completed.
appears in the upper-right corner of the display
Right-click on the display window to open the Instant Playback Management Menu:
The following buttons are available on the right-click Instant Playback Management Menu:
Pause/Play
Pause/Start the instant playback in the display window.
Stop
Stop the instant playback and return to the live view mode.
27
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Speed Up/Down
Increase/Decrease the play speed of the instant playback.
Single Frame
Play back the record file frame by frame.
Open Digital Zoom
Enable the digital zoom function. Click again to disable the function.
Capture
Capture the picture in the instant playback process.
Print Captured Picture
Capture the current picture and then print the picture.
Send Email
Capture the current picture and then send an Email notification to
one or more receivers. The captured picture can be attached.
Start/Stop Recording
Start/Stop clipping the record files.
Enable/Disable Audio
Click to turn on/off the audio in instant playback.
Switch to Live View
Switch to live view mode.
Full Screen
Display the instant playback in full screen mode. Click again to exit.
2.4.6 Live View of Fisheye Camera
Note: This section is only for the live view of the fisheye camera. A fisheye camera is a camera that
uses an extremely wide-angle lens to capture a view of 360 degrees or 180 degrees.
Steps:
1.
Add a fisheye camera to the iVMS-4200 client software. The fisheye should be added as encoding
device. For details, please to Section 2.2 Adding the Device.
2.
Click-and-drag the fisheye camera from the list to the display window, or double-click the camera
name after one display window selected to get the live view.
3.
Right-click on the playing window, and select Fisheye Expansion on the right-click menu.
Expand Mode
Fisheye, Panorama, 1 Fisheye + 3 PTZ, 1 Panorama +3 PTZ are selected for the expand mode, and the
default expand mode is 1 Fisheye+3 PTZ.
PTZ Control
If 1 Fisheye+ 3 PTZ or 1 Panorama + 3 PTZ is selected, you can use the PTZ control to adjust the PTZ
window.
28
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200

Select a PTZ window, and click one of the eight direction buttons to adjust the view angle.
Note: Click-and-drag the No. label in the fisheye window will change the view angle of the PTZ
window as well.



Select a PTZ window, and click
to start auto-scan, and click it again to stop auto-scan.
: Drag the slider to adjust the speed for PTZ movement.
: Zoom in or zoom out the selected PTZ window by clicking “+” or “-”. Or you can scroll
the mouse wheel to zoom in or zoom out.
Preset
A preset is a user-defined monitor position/point. You can simply call the preset number to change the
monitor scene to the defined position. Please follow the steps below to configure the preset.
Steps:
1.
Click preset tab to enter the preset configuration interface.
2.
Select a PTZ window, and adjust the scene to the place you want to mark as a preset.
3.
Click
4.
(Optional) Click
to call the configured preset.
5.
(Optional) Click
to delete the configured preset.
, input the preset name, and click OK to save a preset.
Patrol
A patrol is a scanning track specified by a group of user-defined presets, with the scanning speed
between two presets and the dwell time at the preset separately programmable. Please follow the
steps below to configure the patrol.
Note:
At least 2 presets have to be configured before you configure the patrol.
Steps:
1.
Click patrol tab to enter the patrol configuration interface.
2.
Select a path No. from the drop-down list.
3.
Click
4.
Repeat the above operation to add other presets to the patrol.
5.
Click
to add the configured presets, and set the dwell time and patrol speed for the preset.
to start the patrol, and click
to stop patrol.
29
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
6. Optionally, you can click
Notes:
or
to edit or delete a preset in the patrol path.

Up to 256 presets can be configured.

Up to 32 patrols can be set.

The dwell time ranges from 1 to 120s.

The patrol speed ranges from 1 to 40.
2.4.7 Other Functions in Live View
There are some other functions supported in the live view, including digital zoom, two-way audio,
camera status and synchronization.
Auxiliary Screen Preview
The live video can be displayed on different auxiliary screens for the convenient preview of multiple
monitoring scenes. Up to 3 auxiliary screens are supported.
Digital Zoom
Use the left key of mouse to drag a rectangle area in the lower-right/upper-left direction, and then the
rectangle area will zoom in/out.
Two-way Audio
Two-way audio function enables the voice talk of the camera. You can get not only the live video but
also the real-time audio from the camera. This two-way audio can be used for only one camera at one
time.
Camera Status
The camera status, such as recording status, signal status, connection number, etc., can be detected
and displayed for check. The status information refreshes every 10 seconds.
Synchronization
The synchronization function provides a way to synchronize the device clock with the PC which runs
the client software. You can also synchronize the clock of multiple devices with the PC which runs the
client software in batch.
30
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 3 Remote Record Schedule
Settings and Playback
When the video storage devices are the HDDs, Net HDDs, SD/SDHC cards on the local device, or the
remote storage server connected, you can set the record schedule for the cameras for the continuous,
alarm triggered or command triggered recording. And the record files can be searched for the remote
playback.
3.1 Remote Recording
Purpose:
The video files can be recorded on the HDDs, Net HDDs, SD/SDHC cards on the local device, or the
storage server connected.
Click the
icon on the control panel,
or click Tool->Record Schedule to open the Record Schedule page.
3.1.1 Recording on Storage Devices on the DVRs, NVRs, or
Network Cameras
Purpose:
Some local devices, including the DVRs, NVRs, and Network Cameras, provide storage devices such as
the HDDs, Net HDDs and SD/SDHC cards for record files. You can set a record schedule or capture
schedule for the channels of the local devices.
Notes: The pictures captured through the capture schedule are stored on the local device and can be
searched on the remote configuration page of the device.
31
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Before you start:
The newly installed storage devices need to be formatted. Go to the remote configuration page of the
device, click Storage->General, select the HDD or SD/SDHC card, and click Format to initialize the
selected storage device.
Steps:
1.
Open the Record Schedule page.
2.
Select the camera in the Camera Group list.
3.
Check the checkbox Record Schedule / Capture Schedule under Local Recording to enable device
local recording or capture.
4.
Select the record schedule template from the drop-down list.
All-day Template: for all-day continuous recording.
Weekday Template: for working-hours continuous recording from 8:00 AM to 8:00 PM.
Event Template: for the event triggered recording.
Template 01-08: fixed templates for specific schedules. You can edit the templates if needed.
Custom: can be customized as desired.
If you need to edit or customize the template, see Configuring Record Schedule Template.
5.
Click Advanced Settings to set the recording parameters. For details, see Table 3.1 Advanced
Recording Settings and Table 3.2 Advanced Capture Settings.
6.
Optionally, click Copy to… to copy the record schedule settings to other channels.
7.
Click Save to save the settings.
Table 3.1 Advanced Recording Settings
Parameters
Pre-record
Post-record
Video Expired Time
Descriptions
Normally used for the event triggered record, when you want to record before
the event happens
After the event finished, the video can also be recorded for a certain time.
The time for keeping the record files in the storage device, once exceeded, the
files will be deleted. The files will be saved permanently if the value is set as 0.
32
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Redundant Record
Save the video files not only in the R/W HDD but also in the redundant HDD.
Record Audio
Record the video files with audio or not.
Video Stream
Select the stream type for the recording.
Table 3.2 Advanced Capture Settings
Parameters
Resolution
Picture Quality
Interval
Descriptions
Select the resolution for the continuous or event captured pictures.
Set the quality for the continuous or event captured pictures.
Select the interval which refers to the time period between two capturing
actions.
Configuring Record Schedule Template
Perform the following steps to configure the record schedule template:
If Template 01-08 is selected from the drop-down list, start from step 1;
If Custom is selected from the drop-down list, start from step 2.
1.
Click Edit to enter the Templates Management interface. Select the template to be set and you
can edit the template name.
2.
Set the time schedule for the selected template.
refers to normal schedule record. The schedule time bar is marked with
.
refers to the schedule record for the event. The schedule time bar is marked
with
.
marked with
refers to the schedule record triggered by command. The schedule time bar is
.
Note: Record triggered by command is only available for the ATM transactions when the ATM DVR
is added to iVMS-4200.
3.
When the cursor turns to
, you can edit the schedule time bar.
When the cursor turns to
, you can move the selected time bar you just edited.
When the cursor turns to
, you can lengthen or shorten the selected time bar.
Optionally, you can select the schedule time bar,
and then click the icon
or click the icon
or click the icon
4.
to delete the selected time bar,
to delete all the time bars,
to copy the time bar settings to the other dates.
Click OK to save the settings.
You can click Save as Schedule Template on the Custom Schedule interface, and then the custom
template can be saved as template 01--08.
Note: Up to 8 time periods can be set for each day in the record schedule.
33
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
3.1.2 Recording on Storage Device
Purpose:
You can add storage device to the client for storing the record files of the added encoding devices and
you can search the files for remote playback. The storage device can be storage server, CVR or other
NVR. Here we take the settings of storage server as an example.
Before you start:
The storage server application software needs to be installed and it is packed in the iVMS-4200
software package. When installing the iVMS-4200, check the checkbox Storage Server to enable the
installation of storage server.
Adding the Storage Server
Steps:
1.
Click the shortcut icon
on the desktop to run the storage server.
Note: You can also record the video files on the storage server installed on other PC.
34
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
2.
Open the Device Management page and click the Server tab.
3.
Click Add New Device Type, select Storage Server and click OK.
4.
Click Storage Server on the list to enter the Storage Server Adding interface.
You can add the storage server in the following ways:

By detecting the online devices, see Section 2.2.1 Adding Online Devices.

By specifying the device IP address, see Section 2.2.2 Adding Devices Manually.

By specifying an IP segment, see Section 2.2.3 Adding Devices by IP Segment.

By IP Server, see Section 2.2.4 Adding Devices by IP Server.
Formatting the HDDs
The HDDs of the storage server need to be formatted for the record file storage.
Steps:
1.
Select the added storage server from the list and click Remote Config.
2.
Click Storage->General, to enter the HDD Formatting interface.
3.
Select the HDD from the list and click Format. You can check the formatting process from the
process bar and the status of the formatted HDD changes from Raw to Normal Status.
Note: Formatting the HDDs is to pre-allocate the disk space for storage and the original data of the
formatted HDDs will not be deleted.
Configuring Storage Server Record Schedule
Before you start:
35
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
The storage server needs to be added to the client software and the HDDs need to be formatted for
the record file storage.
Steps:
1.
Open the Record Schedule page.
2.
Select the camera from the Camera Group list.
3.
Check the checkbox Storage Server to enable recording on storage server.
4.
Select the storage server from the drop-down list.
5.
Select the record schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Record Schedule Template.
6.
Click Advanced Settings to set the pre-record time, post-record time and video expired time.
7.
Click Save to save the settings.
3.2 Remote Playback
Purpose:
The record files stored on the local device or the storage server can be searched by custom view,
camera or triggering event, and then can be played back remotely.
Click the
icon on the control panel,
or click View->Remote Playback to open the Remote Playback page.
Remote Playback Page
1 View List, Camera List and Event List
2 Calendar
3 Search Options
4 Search Result List
5 Display Window of Playback
6 Playback Toolbar
7 Timeline
36
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
3.2.1 Normal Playback
Purpose:
The record files can be searched by custom view, camera or triggering event for the Normal Playback.
Searching Record Files for Normal Playback
Steps:
1.
Open the Remote Playback page.
2.
Click
3.
Select the view or camera to be searched from the list.
4.
Select the day to be searched on the calendar.
to expand the View List or Camera List on the left-side.
You can also click
to show more search options, and then click the icon
start time and end time for the search.
5.
to specify the
Click Search. The record files of the selected view or camera will be displayed on the Search
Result list. You can filter the results through the Filter text field.
Notes:

You can also search the record files by the ATM query (only applicable to ATM DVR) or by the file
type.

Up to 16 cameras can be searched simultaneously.
Playing Back Record Files
After searching the record files for the normal playback, you can play back the record files in the
following two ways:

Playback by File List
Select the record file from the search result list, and then click the icon
on the record file,
or double-click the record file to play the video on the display window of playback.
You can also select a display window and click the icon
corresponding record file.

in the toolbar to play back the
Playback by Timeline
The timeline indicates the time duration for the record file, and the record files of different types
37
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
are color coded. Click on the timeline to play back the video of the specific time.
You can click
or
to scale up or scale down the timeline bar.
You can click
or
to go to the previous or the next time period.
You can use the mouse wheel to zoom in or zoom out on the timeline.
Normal Playback Toolbar:
On the Normal Playback page, the following toolbar buttons are available:
Playback Speed
Set the playback speed for the selected display window.
Async/Sync
Click
Playback
synchronously/asynchronously.
Stop Playback
Stop the playback of all cameras.
Pause/Start
Playback
to
play
back
the
record
files
Pause/Start the playback of the record files.
Single Frame
Play back the record files frame by frame.
Volume
Click to turn on/off the audio and adjust the audio volume.
Full Screen
Display the video playback in full screen mode. Press ESC to
exit.
Right-click on the display window in playback to open the Playback Management Menu:
38
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
The following items are available on the right-click Playback Management Menu:
Reverse Playback
Play back the record file reversely.
Pause/Start
Pause/Start the playback.
Stop
Stop the playback.
Speed Up
Play back the record file at a faster speed.
Speed Down
Play back the record file at a slower speed.
Single Frame
Play back the record file frame by frame.
Open Digital Zoom
Enable the digital zoom function. Click again to disable the function.
Add default (default tag name TAG) or custom tag (customized tag
Tag Control
name) for the video file to mark the important video point. You can
also edit the tag or go to the tag position conveniently.
Accurate Positioning
Set the accurate time point to play back the record file.
Capture
Capture the picture in the playback process.
Print Captured Picture
Capture a picture and print it.
Send Email
Start/Stop Recording
Download
Capture the current picture and then send an Email notification to
one or more receivers. The captured picture can be attached.
Start/Stop the manual recording. The record file is stored in the PC.
Download the record files of the camera and the record files are
stored in the PC. You can select to download by file or by date.
Enable/Disable Audio
Click to enable/disable the audio in playback.
Full Screen
Display the playback in full-screen mode. Click the icon again to exit.
3.2.2 Event Playback
Purpose:
The recordings triggered by event, such as motion detection, video loss or alarm input, can be
searched for Event Playback and this function requires the support of the connected device.
Searching Record Files for Event Playback
Steps:
39
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
1.
Open the Remote Playback page.
2.
Click
3.
Select the event type from the drop-down list, and select the cameras or alarm input sensors.
4.
Select the day to be searched on the calendar.
to expand the Event List on the left-side.
You can also click
to show more search options, and then click the icon
start time and end time for the search.
5.
to specify the
Click Search. The recordings from the selected cameras and sensors triggered by event will be
displayed on the Search Result list.
Playing Back Record Files
After searching the recordings triggered by the event, you can play back the record files in the
following two ways:

Playback by File List
Select the record file from the search result list, and then click the icon
on the record file,
or double-click the record file to play the video on the display window of playback.
You can also select a display window and click the icon
corresponding record file.

in the toolbar to play back the
Playback by Timeline
The timeline indicates the time duration for the record file. Click on the timeline to play back the
video of the specific time.
You can click
or
to scale up or scale down the timeline bar.
You can click
or
to go to the previous or the next time period.
You can use the mouse wheel to zoom in or zoom out on the timeline.
Event Playback Toolbar:
On the Remote Playback page, the following toolbar buttons are available:
Playback Speed
Set the playback speed for the selected display window.
Stop Playback
Stop the playback of all channels.
Pause/Start Playback
Pause/Start the playback of record files.
Single Frame
Play back the record files frame by frame.
Previous Event
Go to the playback of the previous event.
Next Event
Go to the playback of the next event.
Volume
Click to turn on/off the audio and adjust the audio volume.
Full Screen
Display the video playback in full screen mode. Press ESC to exit.
3.2.3 Synchronous Playback
Purpose:
In synchronous playback, the record files can be played back in synchronization.
Note: Record files from up to 16 cameras can be played back simultaneously.
40
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Steps:
1.
Search the record files for the normal playback.
2.
Click
3.
Select the record file from the list and click
,
or click on the timeline to start the synchronous playback for all searched cameras.
4.
To disable the synchronous playback, click the icon
in the toolbar to enable the synchronous playback. The icon
turns to
.
.
3.2.4 VCA Playback
Purpose:
You can set VCA rule to the searched record files and find the video that VCA event occurs, including
VCA Search, Intrusion and Line Crossing. This function helps to search out the video that you may be
more concerned, mark it with red color and the playback speed of the concerned video and
unconcerned video can be customized.

VCA Search: Get all the related motion detection events that occurred in the pre-defined region.

Intrusion: Detect whether there are people, vehicles and other moving objects intruding into the
pre-defined region.

Line Crossing: Bi-directionally detect people, vehicles and other moving objects that cross a
virtual line.
Steps:
1.
Search the record files for the normal playback and play back the record file(s).
2.
Select a playback window and click
3.
Select the VCA Type, draw the detection region and set the sensitivity.
to expand the VCA Playback panel.
Notes:

For VCA Search, click
, and then click and move on the playback window to set the grid
rectangle as the detection region. Or you can click
camera as the detection region.
to set all the area shot by the
41
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.

For Intrusion, click
detection region.

For Line Crossing, click
and then click on the playback window to set the beginning
point in the area and move the mouse and click again to set the end of the line.
and then click on the playback window to set the vertex for the
 To delete the drawn region, click
to remove it.
Optionally, click
to expand the More Search Options panel. You can configure the advanced
settings for the VCA Search.

Skip Unconcerned Video: Check the checkbox and the video that no VCA event occurs will
be skipped during playback.

Speed of Unconcerned Video: Set the playback speed for the unconcerned video as
desired.

Speed of Concerned Video: Set the playback speed for the concerned video as desired.

Pre-play: Set the time to play back before the VCA event. For example, when a VCA event
occurs at 10:00, if you set the pre-play time as 5 seconds, the video plays back from 9:59:55.

Post-play: Set the time to play back after the VCA event. For example, when a VCA event
ends at 11:00, if you set the post-play time as 5 seconds, the video plays back till 11:00:05.
5.
Click Search and the VCA events occurred in the defined area will be red marked on the timeline.
3.2.5 Playback of Fisheye Camera
Note: This section is only for the playback of the fisheye camera.
Steps:
1.
Open the Remote Playback page.
2.
Click
3.
Select the fisheye camera to be searched from the list.
4.
Select the day to be searched on the calendar.
to expand the Camera List on the left-side.
You can also click
to show more search options, and then click the icon
start time and end time for the search.
5.
to specify the
Click Search. The record files of the selected view or camera will be displayed on the Search
Result list. You can filter the results through the Filter text field.
Playing Back Record Files
After searching the record files, you can play back the record files in the following two ways:

Playback by File List
Select the record file from the search result list, and then click the icon
on the record file,
or double-click the record file to play the video on the display window of playback.
You can also select a display window and click the icon
corresponding record file.

in the toolbar to play back the
Playback by Timeline
42
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
The timeline indicates the time duration for the record file, and the record files of different types
are color coded. Click on the timeline to play back the video of the specific time.
You can click
or
to scale up or scale down the timeline bar.
You can click
or
to go to the previous or the next time period.
You can use the mouse wheel to zoom in or zoom out on the timeline.
Note: For the function of other icons, please refer to Section 3.2.1 Normal Playback.
Right-click on the PTZ window, and select Fisheye Expansion to go to the Expansion Mode. You can
select the expand mode for playback as desired.
Right-click on a playing window and you can switch the selected window to fisheye mode, panorama
mode or full screen.
Press ESC key on the keyboard or right-click on the window and select Quit Full Screen to exit the full
screen mode.
43
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 4 Event Management
Purpose:
In iVMS-4200 client software, rules can be set up for triggers and linkage actions. You can assign
linkage actions to the trigger by setting up a rule. For example, when motion is detected, an audible
warning appears or other linkage actions happen.
Click the
icon on the control panel,
or click Tool->Event Management to open the Event Management page.
You can set different linkage actions for the following triggers:
Note: The event detection should be supported by the device before you can configure it.

Motion Detection

Video Tampering Alarm

PIR Alarm

Video Loss

Audio Detection

Defocus Detection

Face Detection

Line Crossing

Intrusion

Scene Change

Alarm Input

Device Exception
4.1 Configuring Motion Detection Alarm
Purpose:
44
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
A motion detection alarm is triggered when the client software detects motion within its defined area.
The linkage actions, including alarm output, channel record and client action can be set.
Note: The configuration varies according to different devices. For details, please refer to the User
Manual of the devices.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select Motion Detection as the event type.
3.
Check the checkbox Enable to enable the function of motion detection. Check the checkbox
Enable Motion Dynamic Analysis to mark the detected objects with green rectangles in live
view and playback.
4.
Select the arming schedule template from the drop-down list.
All-day Template: for all-day continuous arming.
Weekday Template: for working-hours continuous arming from 8:00 AM to 8:00 PM.
Template 01-09: fixed templates for special schedules. You can edit the templates if needed.
Custom: can be customized as desired.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
5.
Click-and-drag the mouse to draw a defined area for the arming region.
You can click the icon
to set the whole video area as detection area, or click the icon
clear all the detection area.
6.
to
Drag the slider on the sensitivity bar to adjust the motion detection sensitivity. The larger the
value is, the more sensitive the detection is.
7.
Check the checkboxes to activate the linkage actions. For details, see Table 4.1 Linkage Actions for
Motion Detection Alarm.
8.
Optionally, click Copy to… to copy the event parameters to other channels.
9.
Click Save to save the settings.
Table 4. 1 Linkage Actions for Motion Detection Alarm
Linkage Actions
Alarm Output
Channel Record
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Start the recording of the selected cameras when alarm is triggered.
45
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Audible Warning
Email Linkage
The client software gives an audible warning when alarm is triggered.
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image with alarm information pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
Configuring Arming Schedule Template
Perform the following steps to configure the arming schedule template:
If Template 01-09 is selected in the drop-down list, start from step 1;
If Custom is selected in the drop-down list, start from step 2.
Steps:
1.
Click Edit to enter the Templates Management interface. Select the template to be set and you
can edit the template name.
2.
3.
Set the time schedule for the selected template.
When the cursor turns to
, you can edit the schedule time bar.
When the cursor turns to
, you can move the selected time bar you just edited.
When the cursor turns to
, you can lengthen or shorten the selected time bar.
Optionally, you can select the schedule time bar,
and then click the icon
or click the icon
4.
to delete the selected time bar,
to delete all the time bars,
or click the icon
to copy the time bar settings to the other dates.
Click OK to save the settings.
You can click Save as Schedule Template on the Custom Schedule interface, and then the custom
template can be saved as template 01--09.
Note: Up to 4 time periods can be set for each day in the arming schedule template.
46
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.2 Configuring Video Tampering Alarm
Purpose:
A video tampering alarm is triggered when the camera is covered and the monitoring area cannot be
viewed. The linkage actions, including alarm output and client action can be set.
Steps:
1.
Open the Event Management page and click the Camera Event tab.
2.
Select the camera to be configured and select Video Tampering as the event type.
3.
Check the checkbox Enable to enable the function of video tampering.
4.
Select the arming schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
5.
Select the triggered camera. The image or video from the triggered camera will pop up or be
displayed on the Video Wall when tampering alarm occurs.
6.
Click-and-drag the mouse to draw a defined area for the arming region.
You can click the icon
to set the whole video area as detection area, or click the icon
clear the detection area.
to
7.
Drag the slider on the sensitivity bar to adjust the tampering alarm sensitivity.
8.
Check the checkboxes to activate the linkage actions. For details, see Table 4.2 Linkage Actions for
Tampering Alarm.
9.
Optionally, click Copy to… to copy the event parameters to other cameras.
10. Click Save to save the settings.
47
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Table 4. 2 Linkage Actions for Tampering Alarm
Linkage Actions
Alarm Output
Audible Warning
Email Linkage
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
The client software gives an audible warning when alarm is triggered.
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.3 Configuring PIR Alarm
Purpose:
A PIR (Passive Infrared) alarm is triggered when an intruder moves within the detector's field of view.
The heat energy dissipated by a person, or any other warm blooded creature such as dogs, cats, etc.,
can be detected.
Note: The PIR Alarm function requires the support of connected device.
Steps:
1.
Open the Event Management page and click the Camera Event tab.
2.
Select the camera to be configured and select PIR Alarm as the event type.
3.
Check the checkbox Enable to enable the function of PIR alarm.
4.
Input a descriptive name of the alarm.
5.
Check the checkboxes to activate the linkage actions. For details, see Table 4.3 Linkage Actions for
PIR Alarm.
6.
Optionally, click Copy to… to copy the event parameters to other channels.
7.
Click Save to save the settings.
48
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Table 4. 3 Linkage Actions for PIR Alarm
Linkage Actions
Alarm Output
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image with alarm information pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.4 Configuring Video Loss Alarm
Purpose:
When the client software cannot receive video signal from the front-end devices, the video loss alarm
will be triggered. The linkage actions, including alarm output and client action can be set.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select Video Loss as the event type.
3.
Check the checkbox Enable to enable the function of video loss alarm.
4.
Select the arming schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
5.
Select the triggered camera. The image or video from the triggered camera will pop up or be
displayed on the Video Wall when video loss alarm occurs.
6.
Check the checkboxes to activate the linkage actions. For details, see Table 4.4 Linkage Actions for
Video Loss Alarm.
49
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
7.
Optionally, click Copy to… to copy the event parameters to other cameras.
8.
Click Save to save the new settings.
Table 4. 4 Linkage Actions for Video Loss Alarm
Linkage Actions
Alarm Output
Audible Warning
Email Linkage
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
The client software gives an audible warning when alarm is triggered.
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.5 Configuring Audio Detection Alarm
Purpose:
The abnormal sounds, such as the silence detection, environment noise detection, and current
noise detection, can be detected
Enabling the Audio Input exception can detects the exceptions of audio input condition.
Enabling the Sudden Change of Sound Intensity can detects the change of the sound volume and
source in the environment.
Note: The Audio Detection function requires the support of connected device.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select Audio Detection as the event type.
3.
Check the related checkbox to enable the function of audio detection alarm.
4.
Set the sensitivity and sound intensity threshold.

Sensitivity: Range [1-100], the smaller the value the more severe the change
should be to trigger the detection.
50
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200

Sound Intensity Threshold: Range [1-100], it can filter the sound in the
environment, the louder the environment sound, the higher the value should be. You
can adjust it according to the real environment.
5.
Select the arming schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
6.
Check the checkboxes to activate the linkage actions. For details, see Table 4.5 Linkage
Actions for Audio Detection Alarm.
7.
Optionally, click Copy to… to copy the event parameters to other cameras.
8. Click Save to save the new settings.
Table 4. 5 Linkage Actions for Audio Detection Alarm
Linkage Actions
Alarm Output
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.6 Configuring Defocus Detection Alarm
Purpose:
The image blur caused by defocus of the lens can be detected and a series of alarm action can be
triggered.
Note: The Defocus Detection function requires the support of connected device.
51
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select Defocus Detection as the event type.
3.
Check the checkbox Enable to enable the function of defocus detection alarm.
4.
Set the detection sensitivity by dragging the slider on the sensitivity bar.
5.
Check the checkboxes to activate the linkage actions. For details, see Table 4.6 Linkage
Actions for Defocus Detection Alarm.
6.
Optionally, click Copy to… to copy the event parameters to other cameras.
7.
Click Save to save the new settings.
Table 4. 6 Linkage Actions for Defocus Detection Alarm
Linkage Actions
Audible Warning
Email Linkage
Descriptions
The client software gives an audible warning when alarm is triggered.
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.7 Configuring Face Detection Alarm
Purpose:
The camera will detect human faces within the monitoring area automatically if the function is
enabled. A series of alarm action will be triggered if the alarm is triggered.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select Face Detection as the event type.
3.
Check the checkbox Enable to enable the function of face detection alarm.
4.
Select the arming schedule template from the drop-down list.
52
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
If you need to edit or customize the template, see Configuring Arming Schedule Template.
5.
Set the sensitivity for face detection.
6.
Check the checkbox Enable Dynamic Analysis for Face Detection if you want the detected
face get marked with rectangle in the live view.
7.
Check the checkboxes to activate the linkage actions. For details, see Table 4.7 Linkage
Actions for Face Detection Alarm.
8.
Optionally, click Copy to… to copy the event parameters to other cameras.
9.
Click Save to save the new settings.
Table 4. 7 Linkage Actions for Face Detection Alarm
Linkage Actions
Alarm Output
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.8 Configuring
Line
Crossing
Detection
Alarm
Purpose:
53
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
This function can be used for detecting people, vehicles and objects crossing a pre-defined virtual
line. The crossing direction can be set as bidirectional, from left to right or from right to left. And
a series of linkage method will be triggered if any object is detected.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2. Select the camera to be configured and select Line Crossing as the event type.
3.
Check the checkbox Enable to enable the function.
4.
Select the arming schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
5.
Configure the arming region.
Virtual Line ID: Click the drop-down list to choose an ID for the virtual line.
Virtual Line Direction: You can select the directions as A<->B, A ->B, and B->A.
A<->B: When an object going across the line with both directions can be detected and
alarms are triggered.
A->B: Only the object crossing the virtual line from the A side to the B side can be
detected.
B->A: Only the object crossing the virtual line from the B side to the A side can be
detected.
6.
Set the sensitivity [1~100].
7.
Click
and draw a virtual line on the preview window. Optionally, you can click
drag the virtual line to adjust its position, click
to delete the selected line, or click
and
to
clear all the lines.
Note: Select another virtual line ID and draw another one. Up to 4 lines can be drawn.
8.
Check the checkboxes to activate the linkage actions. For details, see Table 4.8 Linkage
Actions for Line Crossing Detection Alarm.
9.
Optionally, click Copy to… to copy the event parameters to other cameras.
10. Click Save to save the settings.
Table 4. 8 Linkage Actions for Line Crossing Detection Alarm
Linkage Actions
Descriptions
54
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Enable the alarm output function. Select the alarm output port and the
Alarm Output
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.9 Configuring Intrusion Detection Alarm
You can set a detection area in the surveillance scene for Intrusion and once the area is been entered
longer than the set time duration, a set of alarm action is triggered.
Note: The Intrusion Detection function requires the support of connected device.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select Intrusion as the event type.
3.
Check the checkbox Enable to enable the function of intrusion detection alarm.
4.
Select the arming schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
5.
Configure the arming region.
Region ID: Click the dropdown list to choose a region ID for the arming region.
Trigger Time Threshold: Range [0-10s], the threshold for the time of the object loitering
in the region. If you set the value as 0, alarm is triggered immediately after the object
entering the region.
Percentage: Range [1-100]. Percentage defines the ratio of the in-region part of the
object which can trigger the alarm. For example, when you set the percentage as 50%,
half of the object entering the region will trigger the alarm.
Sensitivity: Range [1-100]. The value of the sensitivity defines the size of the object
which can trigger the alarm, when the sensitivity is high, a very small object can trigger
the alarm.
6.
Click
and draw a quadrangle on the preview window. Optionally, you can click
drag the virtual line to adjust its position, click
to delete the selected line, or click
and
to
clear all the lines
Note: When you draw the quadrangle, click on the preview window to set the vertex to set
the quadrangle. Up to 4 areas are supported.
7.
Check the checkboxes to activate the linkage actions. For details, see Table 4.9 Linkage
Actions for Intrusion Alarm.
55
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
8.
Optionally, click Copy to… to copy the event parameters to other cameras.
9.
Click Save to save the new settings.
Table 4. 9 Linkage Actions for Intrusion Alarm
Linkage Actions
Alarm Output
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.10 Configuring Scene Change Alarm
Purpose:
Scene change detection is used to detect the change of surveillance environment affected by the
external factors; such as the intentional rotation of the camera.
Note: The Scene Detection function requires the support of connected device.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select Scene Detection as the event type.
3.
Check the checkbox Enable to enable the function of audio detection alarm.
Sensitivity: Range [1-100]. The higher the sensitivity, the easier the change of scene can
trigger the alarm.
4.
Select the arming schedule template from the drop-down list.
56
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
If you need to edit or customize the template, see Configuring Arming Schedule Template.
5.
Check the checkboxes to activate the linkage actions. For details, see Table 4.10 Linkage
Actions for Scene Change Alarm.
6.
Optionally, click Copy to… to copy the event parameters to other cameras.
7.
Click Save to save the new settings.
Table 4. 10 Linkage Actions for Scene Change Alarm
Linkage Actions
Alarm Output
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.11 Configuring VCA Exception Alarm
Purpose:
When the VCA alarm of the connected device occurs, a series of linkage actions can be triggered.
Note: The VCA Exception function requires the support of connected device.
Steps:
1.
Open the Event Management page and click Camera Event tab.
2.
Select the camera to be configured and select VCA Exception as the event type.
3.
Check the checkbox Enable to enable the function of VCA Exception alarm.
4.
Select the arming schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
57
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
5.
Check the checkboxes to activate the linkage actions. For details, see Table 4.11 Linkage
Actions for VCA Exception Alarm.
6.
Optionally, click Copy to… to copy the event parameters to other cameras.
7.
Click Save to save the new settings.
Table 4. 11 Linkage Actions for VCA Exception Alarm
Linkage Actions
Alarm Output
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image of the triggered camera pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.12 Configuring Alarm Input Linkage
Purpose:
When a device's alarm input port receives a signal from an external alarm device, such as smoke
detector, doorbell, etc., the alarm input linkage actions are triggered for notification.
Before you start:
Add the alarm inputs to the client, click Import on the Group Management interface, click the Alarm
Input tab and import alarm inputs into groups for management.
Steps:
1.
Open the Event Management page and click the Alarm Input tab.
2.
Select the alarm input channel to be configured.
3.
Check the checkbox Enable.
58
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.
Input a descriptive name of the alarm.
5.
Set the alarm status according to the alarm input device.
6.
Select the arming schedule template from the drop-down list.
If you need to edit or customize the template, see Configuring Arming Schedule Template.
7.
Check the checkboxes to activate the linkage actions. For details, see Table 4.12 Linkage Actions
for Alarm Input.
8.
Optionally, click Copy to… to copy the event parameters to other alarm inputs.
9.
Click Save to save the settings.
Table 4. 12 Linkage Actions for Alarm Input
Linkage Actions
Alarm Output
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
Channel Record
Start the recording of the selected cameras when alarm is triggered.
Audible Warning
The client software gives an audible warning when alarm is triggered.
Email Linkage
Send an Email notification of the alarm information to one or more receivers.
Alarm on E-map
Display the alarm information on the E-map.
Alarm Triggered
The image with alarm information pops up when alarm is triggered.
Pop-up Image
Alarm Triggered
Video Wall Display
Display the video on the Video Wall when alarm is triggered.
Note: This option is only available when the decoding device is added.
4.13 Configuring Device Exception Linkage
Steps:
1.
Open the Event Management page and click the Device Exception tab.
2.
Select the device to be configured.
3.
Select the device exception type, including HDD full, HDD exception, illegal login, etc.
4.
Check the checkbox Enable.
5.
Check the checkboxes to activate the linkage actions. For details, see Table 4.13 Linkage Actions
59
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
for Device Exception.
6.
Optionally, click Copy to… to copy the event parameters to other devices.
7.
Click Save to save the settings.
Table 4. 13 Linkage Actions for Device Exception
Linkage Actions
Alarm Output
Audible Warning
Email Linkage
Descriptions
Enable the alarm output function. Select the alarm output port and the
external device connected to the port can be controlled.
The client software gives an audible warning when alarm is triggered.
Send an Email notification of the alarm information to one or more receivers.
4.14 Viewing Alarm and Event Information
The information of recent alarms and events can be displayed. Click the icon
in Alarms and Events
Toolbar to show the Alarms and Events panel. Or click
to display the Alarm Event interface.
60
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
On the Alarms and Events panel, the following toolbar buttons are available:
Clear Info
Enable/Disable Alarm
Triggered Pop-up Image
Clear the information of alarms and events displayed on the list.
Click to enable/disable image pop-up when alarms occur.
Enable/Disable Audio
Click to enable/disable the audio warning for the alarm.
Auto Hide/Lock
Click to hide automatically/lock the Alarms and Events panel.
Maximize
Maximize the Alarms and Events panel in a new tab page.
Show/Hide
Click to show/hide the Alarms and Events panel.
Viewing Alarms Information
Different alarm types can be displayed on the panel: Motion Detection, Video/Audio Exception, Alarm
Input, Device Exception, VCA Alarm and Other Alarm. You can check the checkbox to enable the
displaying of that type alarm.
Before you start:
To display the alarms, the event parameters need to be configured.
Steps:
1.
Click the Alarm tab.
2.
Check the checkboxes of different alarm types.
3.
When an alarm occurs, the icon
twinkles to call attention. The alarm information, including
the time, source, details and content will be displayed.
Click
Click
to get a live view of the alarm triggered camera.
to send an Email notification of the alarm to one or more receivers.
Click
to display the video of alarm triggered camera on the Video Wall. You can enter the
Video Wall interface to check the alarm triggered video playing on the screen which set as the
alarm window. The physical video wall also display the video.
Note: You should add decoding device and configure the video wall. For details, please refer to
Chapter 12 Decoding and Displaying Video on Video Wall.
Click under the Note column to input the description for the alarm.
61
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.
To clear the alarm information, click the icon
Clear.
, or right-click on an alarm log and then click
Viewing Events Information
Purpose:
The abnormal events of the client software, such as the live view failure, device disconnection, can
also be displayed.
Steps:
1.
Click the Event tab.
The event information, including the time and detailed description will be displayed.
2.
To clear the event information, click the icon
Clear.
, or right-click on the event log and then click
62
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 5 E-map Management
Purpose:
The E-map function gives a visual overview of the locations and distributions of the installed cameras
and alarm input devices. You can get the live view of the cameras on the map, and you will get a
notification message from the map when alarm is triggered.
Click the
icon on the control panel,
or click View->E-map to open the E-map page.
E-map Page
1 Group List
2 Map Display Area
3 E-map Toolbar
5.1 Adding an E-map
Purpose:
An E-map needs to be added as the parent map for the hot spots and hot regions.
Steps:
1.
Open the E-map page.
2.
Select a group for which you want to add a map.
3.
4.
Click the icon
in the Map Display Area to open the map adding dialog box.
Input a descriptive name of the added map as desired.
5.
6.
Click the icon
and select a map file from the local path.
Click OK to save the settings.
Notes:

The picture format of the map can only be *.png, *.jpg or *.bmp.
63
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200

Only one map can be added to a group.
The map added is displayed in the Map Display Area. Use the mouse wheel or click
or
, to
zoom in or zoom out on the map. You can click-and-drag the yellow window in the lower-right corner
or use the direction buttons and zoom bar to adjust the map area for view.
Click the button Edit Map or Map Preview in the E-map toolbar to enter the map editing mode or
map preview mode.
E-map Toolbar in Map Editing Mode:
E-map Toolbar in Map Preview Mode:
On the E-map page, the following toolbar buttons are available:
Modify Map
Modify the map information, including the map name and file path.
Delete Map
Delete the current map.
Add Camera
Add a camera as the hot spot on the map.
Add Alarm Input
Add an alarm input sensor as the hot spot on the map.
Add Hot Region
Add a map as the hot region on the current map.
Modify
Modify the information of the selected hot spot or hot region.
Delete
Delete the selected hot spot or hot region.
64
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Clear Alarm Info
Back to Parent
Map
Clear the alarm information displayed on the map.
Go back to the parent map.
5.2 The Hot Spot Function
Purpose:
The cameras and alarm inputs can be added on the map and are called the hot spots. The hot spots
show the locations of the cameras and alarm inputs, and you can also get the live view and alarm
information of the surveillance scenarios through the hot spots.
5.2.1 Adding Hot Spots
Adding Cameras as Hot Spots
Steps:
1.
Click the Edit Map button in the E-map toolbar to enter the map editing mode.
2.
3.
Click the icon
in the toolbar to open the Add Hot Spot dialog box.
Check the checkboxes to select the cameras to be added.
4.
Optionally, you can edit hot spot name, select the name color and select the hot spot icon.
5.
Click OK to save the settings. The camera icons are added on the map as hot spots and the icons
of added cameras changes from
to
in the group list. You can click-and-drag the camera
icons to move the hot spots to the desired locations.
You can also click-and-drag the camera icons from the group list to the map directly to add the
hot spots.
Adding Alarm Inputs as Hot Spots
Steps:
1.
Click the Edit Map button in the E-map toolbar to enter the map editing mode.
2.
Click the icon
in the toolbar to open the Add Hot Spot dialog box.
65
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
3.
Check the checkboxes to select the alarm inputs to be added.
4.
Optionally, you can edit hot spot name, select the name color and select the hot spot icon.
5.
Click OK to save the settings. The alarm input icons are added on the map as hot spots and the
icons of added alarm inputs changes from
to
in the group list. You can click-and-drag
the alarm input icons to move the hot spots to the desired locations.
You can also click-and-drag the alarm input icons from the alarm input list to the map directly to
add the hot spot.
5.2.2 Modifying Hot Spots
Purpose:
You can modify the information of the added hot spots on the map, including the name, the color, the
icon, etc.
Steps:
1.
Click the Edit Map button in the E-map toolbar to enter the map editing mode.
2.
Select the hot spot icon on the map and then click
in the toolbar, right-click the hot
spot icon and select Modify, or double-click the hot spot icon on the map to open the Modify Hot
Spot dialog box.
3.
You can edit the hot spot name in the text field and select the color, the icon and the linked
camera or alarm input.
4.
Click OK to save the new settings.
To delete the hot spot, select the hot spot icon and click
spot icon and select Delete.
in the toolbar, or right-click the hot
66
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
5.2.3 Previewing Hot Spots
Steps:
1.
Click the Map Preview button in the E-map toolbar to enter the map preview mode.
2.
Double-click the camera hot spots, and you can get the live view of the cameras.
3.
If there is any alarm triggered, an icon
will appear and twinkle near the hot spot. Click the
alarm icon, and then you can check the alarm information, including alarm type and triggering
time.
Note: To display the alarm information on the map, the Alarm on E-map functionality needs to be set
as the alarm linkage action. For details, refer to Chapter 4 Event Management.
5.3 The Hot Region Function
Purpose:
The hot region function links a map to another map. When you add a map to another map as a hot
67
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
region, an icon of the link to the added map is shown on the main map. The added map is called child
map while the map to which you add the hot region is the parent map.
Note: A map can only be added as the hot region for one time.
5.3.1 Adding Hot Regions
Before you start:
Add another map to the group.
Steps:
1.
Click the Edit Map button in the E-map toolbar to enter the map editing mode.
2.
Select an added map as the parent map.
3.
4.
Click the icon
in the toolbar to open the Add Hot Region dialog box.
Check the checkbox to select the child map to be linked.
5.
Optionally, you can edit the hot region name, and select the hot region color and icon.
6.
Click OK to save the settings. The child map icons are added on the parent map as the hot regions.
You can click-and-drag the child map icons to move the hot regions to the desired locations.
5.3.2 Modifying Hot Regions
Purpose:
You can modify the information of the hot regions on the parent map, including the name, the color,
the icon, etc.
Steps:
1.
Click the Edit Map button in the E-map toolbar to enter the map editing mode.
2.
Select the hot region icon on the parent map and then click
in the toolbar, right-click the hot
spot icon and select Modify, or double-click the hot region icon to open the Modify Hot Region
dialog box.
3.
You can edit the hot region name in the text field and select the color, the icon and the linked
child map.
4.
Click OK to save the new settings.
To delete the hot region, select the hot region icon and click
in the toolbar, or right-click the
68
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
hot spot icon and select Delete.
5.3.3 Previewing Hot Regions
Steps:
1.
Click the Map Preview button in the E-map toolbar to enter the map preview mode.
2.
Click the hot region icon to go to the linked child map.
3.
The hot spots can also be added on the hot regions.
4.
You can click the icon
You can also click the icon
in the toolbar to go back to the parent map.
in the toolbar to clear the alarm information.
69
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 6 Cloud Service
Purpose:
The client software also supports to register a Cloud account, log into your Cloud and manage the
devices which support the Cloud service.
6.1 Registering a Cloud Account
Purpose:
If you do not have a Cloud account, you can register one.
Steps:
1.
Open the Device Management page and click the Server tab.
2.
Click Add New Device Type, select Device Registered on Cloud and click OK.
3.
Click Device on Cloud on the list and then click Register.
4.
Enter the required information to register an account.
Cloud Accout: Edit a user name for your account as desired.
Password and Confirm: Enter the password for your account and confirm it.
Email: Enter your email account to register the account.
Verification Code: Enter the verification code shown in the picture. If it is not clear, you can click
Refresh to get a new one.
Email Verification Code: Click Get Verification Code and enter the verification code received by
your email.
5.
Click Register to get a Cloud account.
6.2 Logging into Cloud Account
Steps:
1.
Click Login and enter the Cloud account and password.
2.
Click Login to log into your Cloud account.
Note:
70
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
If you forget your password, click Forgot Password to verify your account and reset your
password.
Cloud Accout: Edit user name of your account.
Verification Code: Enter the verification code shown in the picture. If it is not clear, you can click
Refresh to get a new one.
Email Verification Code: Click Get Verification Code and enter the verification code received by
your email.
Password and Confirm: Click Next and enter a new password for your account and confirm it.
3.
After login, you can click Login to switch to another account or click Logout to log out of your
Cloud account.
6.3 Device Management
Steps:
1.
Click Add Device and input the serial No. and verification code of the device.
Notes:
2.

Only the device that supports the Cloud service can be added.

The serial No. and the verification code is marked on the label of you device.

The device can only be added to one Cloud account.
Click OK to add the device and the successfully added device will list on the device management
interface.
Note: A group named as your account name is created by default, you can import the cameras of
the added devices to the default group or other groups. For group management, please refer to
Section 2.3 Group Management.
3.
For live view, please refer to Section 2.4 Basic Operations in Live View; for playback, please refer
to Section 3.2 Remote Playback; for e-map settings, please refer to Chapter 5 E-map
Management.
4.
If you want delete the device, select the device(s) and click Delete Device. You can also enter the
keyword of the device name in the Filter field to filter the required devices.
71
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
72
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 7 VCA Devices Management
Purpose:
The VCA (Video Content Analysis) devices can be added to the client for management, including VCA
resource allocation, rule settings, VQD (Video Quality Diagnostics), etc.
7.1 Allocating VCA Resource
Before you start: You should add the VCA device to the software. Please refer to Section 2.2 Adding
the Device for adding the VCA device as Encoding Device.
Purpose: Before you can set the VCA configuration for the added device, you need to configure the
VCA resource of the device which means to enable the VCA function of the corresponding cameras.
Steps:
1.
In the Device Management Configuration interface, select Server tab.
2.
Click to select the VCA device and click VCA Allocation to activate the VCA Resource Allocation
window.
In the Resource Information panel, you can view the VCA type and VCA resource usage of the
device.
Example: In the figure shown below, the VCA type of the device is Behavior Analysis and 32
cameras are available for configuring VCA settings. And among the 32 cameras, the VCA
functions of 3 cameras have been enabled and the others are disabled.
3.
In the VCA Resource Allocation panel, check
camera. Or you can uncheck
checkbox to enable the VCA function of the
checkbox to disable the VCA function.
73
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
7.2 Behavior Analysis Configuration
7.2.1 VCA DVR/DVS/IPC Configuration
Camera Configuration
Steps:
1.
In the Device Management Configuration interface, select Group tab.
Note: Before you can set the VCA configuration for the device, you should configure the group
settings for it. For details, please refer to Section 2.3 Group Management.
2.
Select a camera of the VCA device for configuration and click VCA Config to enter the VCA
Configuration interface.
3.
Click the Camera tab to enter the camera configuration interface.
Note: The supported functions may vary among different connected devices.
Basic Information
Click the View button to check the VCA type. If you need to edit it, please refer to Section 7.1
Allocating VCA Resource for details.
VCA Picture
Notify Surveillance Center: Upload the picture to the surveillance center when an VCA alarm occurs.
And if supported, the quality and resolution of the picture can be separately configured.
Local Storage: The alarm triggered pictures can be stored in local PC when the network is
disconnected.
Display Information
Displaying the target info and rule info on the alarm picture are supported; you can enable the
functions by checking the corresponding checkbox on your demand.
And if you check the checkbox of display VCA on stream, the information will be added to the video
stream, and the overlay will be displayed if you get live view or play back by the VSPlayer.
74
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Scene Description
Purpose:
Select the scene for the camera according to actual situation to increase the detection accuracy.
Click the Scene Description tab and click to select a scene.
Camera Calibration
Purpose:
Perform the following steps to three-dimensionally measure and quantize the image from the camera,
and then calculate the size of every target. The VCA detection will be more accurate if the camera
calibration is configured.
Click the Camera Calibration tab and check the checkbox of Camera Calibration to enable the
function.
Icon Description
Icon
Description
Icon
Description
75
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Delete the selected line on the
Draw the horizontal line.
image.
/
Draw the vertical line.
Calibrate
Verify the calibrated height.
Verify the calibrated length.
Pause/Play live view
Task1: Automatically Calculate
Steps:
1.
Click the
icon and drag the mouse to draw a line to calibrate the length of the object, and
input the textbox of Real Length.
2.
Click the
icon and drag the mouse to draw a line to calibrate the height of the object, and
input the texbox of Real Height.
3.
Repeat the above 2 steps until there are at least 4 lines and click the Save button on the bottom
right of the window to finish calibration.
4.
Click the
icon to finish drawing and the device will automatically generate the value of
“Mounting Height”, “Tilt” and “Horizon”. You can check whether the calculated values are correct,
if not, calibrate again.
5.
Click the
and
icons to check the length and height of the object.
Note: It’s highly recommended to set lines apart.
Task2: Manually Input
Steps:
1.
Set the “Mounting Height”, “Tilt” and “Horizon” as Known, and enter the value of corresponding
option.
Note: the “Horizon” is the boundary line between sky and earth, if it does not exist in the image,
you may set the value of it as “100%”.
2.
Click the Save button and then click the
Height”, “Tilt” and “Horizon”.
3.
Click the
and
icon to show the generated value of “Mounting
icons to check the length and height of the object.
Shield Region Configuration
Purpose:
You can set the shield region in which all the VCA rules are invalid.
Steps:
1.
Click the Shield Region tab to enter the shield region interface. Up to 4 shield regions can be set.
2.
Click the
icon, then click and drag the mouse to draw the region, and right-click to finish
drawing.
3.
(Optional) Click to select an added shield region, and click
to delete it.
76
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.
Click Save to save the settings.
VCA Rule Configuration
Click the Rule tab to set the VCA rules.
Steps:
1.
Check the corresponding checkbox to enable the rule.
Notes:
2.
1)
The related operation only takes effect after the rule is enabled.
2)
Up to 8 pieces of rules can be added.
To set the rule name, double-click the corresponding rule name area, and input the rule name on
your demand.
3.
Click the event type and select the type in the drop-down list.
The selectable event type depends on the configured VCA type.
Rule and Attribute
Click the Rule and Attribute tab.
Note: The rule should be enabled if you want to modify the rule.
Icon
Description
Delete the selected rule.
Draw the rectangle arming area.
Draw the polygon arming area.
Set the full-screen arming area.
Note: The event type is intrusion.
Draw the virtual line.
Note: The event type is line crossing.
Draw the maximum size filter.
Note: The rule and the size filter should be enabled.
77
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Draw the minimum size filter.
Note: The rule and the size filter should be enabled.
Start/Pause the live view of the camera.
/
Set the rule
Task1: Draw the virtual line (only for Line Crossing)
Steps:
1.
Please make sure the rule is enabled and the Rule Type is set as the “Line Crossing” in the area 1
in the above figure.
2.
Click the
icon in the area 2 and click to set the beginning point in the area 3 and move the
mouse to the end of the line and click again to set another line. Right-click to finish setting the
virtual line.
Note: You can click the
icon to draw again.
Task2: Draw the arming region
Steps:
1.
Please make sure the rule is enabled in the area 1 in the above figure.
78
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
2.
To draw a rectangle, click the
icon in the area 2 and click to set the top left corner (bottom
right corner) of the region in the area 3 and move the mouse to the bottom right corner (top left
corner) and click again.
To draw a polygon, click the
icon and click to select the first corner of the region in the area 3
and move mouse to one after another corner and click, right-click to finish drawing.
Note: The decagonal region can be supported, and once the tenth point is located, the system will
connect it to the first one with a line automatically.
Attribute
Line Crossing: The detection direction can be modified as “Bidirectional”, “From A to B”, and “From B
to A”, and the detection sensitivity can set.
Intrusion: The detection sensitivity and duration can be modified according to the actual demand.
Arming Schedule
1.
Click the Arming Schedule tab and edit the arming time segment.
2.
(Optional) Copy to Whole week and Copy to All Rules are available.
3.
Click the Save button to save the settings
Note: The arming schedule can be modified for each rule separately.
Alarm Linkage
Click the Alarm Linkage tab and check the checkbox of corresponding linkage actions to enable it.
Note: The alarm linkage methods may vary according to the device types.
Video Quality Diagnostics
Purpose:
The video quality of the camera can be checked and alarm actions will be triggered when the video is
exceptional.
Note: This function is only available for the VCA server.
Steps:
1.
Click the Video Quality Diagnostics tab.
79
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
2.
Check the checkbox to enable the related quality detection of the video.
3.
Set the corresponding parameters for the quality detection.
4.
Click Save to saving the settings.
Advanced Settings
Click the Advanced Configuration to configure the advanced parameters.

Global Size Filter
Click the Global Size Filter tab.
Task1: Pixel Size Filter
Steps:
1.
Check the checkbox of Size Filter and select the filter type as Pixel.
2.
Click the
icon to edit the size of maximum size filter.
Click the
icon to edit the size of minimum size filter.
You can click and drag your mouse to draw a rectangle, and the corresponding value changes
when drawing. And release when it reaches to the proper size.
Note: The height and the width of the maximum size must be larger than the ones of the
minimum size respectively.
Task2: Meter Size Filter
Steps:
1.
Check the checkbox of Size Filter and select the filter type as Meter.
Note: Please set the camera calibration first.
2.
Input the value in the corresponding textbox and click Save button to finish editing.
And when the size of target is in the defined range, the alarm will be triggered.
Note: The height and the width of the maximum size must be larger than the ones of the
minimum size respectively.

Parameters
80
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Click the Parameter tab, and the interface is shown in the following figure.
Parameter
Detection Sensitivity
Background Update
Rate
Triggering Position
Single Alarm
Leaves Interference
Suppression
Description
The greater the sensitivity is, the easier the target will be detected.
If a detected target remains in the monitoring scene for a certain time, the
system will count the target as the background automatically. The greater
the value is, the faster the target will be counted as the background.
The position of the target which breaks the rule.
If the function is enabled, a single alarm will be triggered when the same
target breaks the same rule.
Suppress the interference caused by the swing of leaves.
Note: The index number and value are for the debugging; please do not configure it without
authorization.
7.2.2 VCA Server Configuration
The VCA server can get the video stream from the normal device to do video content analysis, and
then forward the result to the client software.
81
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Steps:
1.
In the Device Management Configuration interface, select Group tab.
Note: Before you can set the VCA configuration for the device, you should configure the group
settings for it. For details, please refer to Section 2.3 Group Management.
2.
Select a camera of the VCA device for configuration and click VCA Config to enter the VCA
Configuration interface.
3.
Click the Streaming tab to enter the stream getting interface.
4.
Configure the target device information. Target device refers to the normal device that connects
with the VCA server via netwrok.
Input the IP address of the target device, user name, password, port No. and camera No. in the
corresponding textbox.
5.
(Optional) Check the sub-stream checkbox to enable getting the sub-stream from the device.
6.
Configure the server to get the video stream from stream media server.
(1) Check the checkbox to get the stream from the stream media server.
(2) Input the IP address and the port of the stream media server.
(3) (Optional) You can click the Connection Test button to test the settings of the target device.
7.
Click the Save button to save the settings.
82
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
7.3 Configuring Face Capture IPC
In the Device Management Configuration interface, select Group tab. Select a camera of the VCA
device for configuration and click VCA Config to enter the VCA Configuration interface.
Note: Before you can set the VCA configuration for the device, you should configure the group settings
for it. For details, please refer to Section 2.3 Group Management.
7.3.1 Camera Configuration
Click Camera tab to enter the camera configuration interface.
Note: The supported functions may vary among different connected devices.
Basic Information
You can view the basic information of the camera. Parent Device refers the VCA device that the
camera connects with. For face capture IPC, it refers to the camera itself. While for other camera like
the camera connecting to behavior analysis DVR (e.g. iDS-8100HFI-ST), parent device refers to the
DVR.
Click the View button to check the allocation the VCA resource, you may refer to Section 7.1
Allocating VCA Resource for details.
VCA Picture
Picture Quality: Configure the quality of the picture as good, better or best.
Display Information
If you check the checkbox, the VCA info will be added to the alarm picture or video stream, and the
information will be displayed if you get live view or play back by the VSPlayer.
7.3.2 Shield Region Configuration
Click the Shield Region tab to enter the shield region interface. Up to 4 shield regions can be set.
83
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
You can set the shield region of the VCA rule, in which all the VCA rules are invalid.
Click the
icon, and then click and drag the mouse to draw the region, right-click to finish drawing.
Click to select the added shield region, and click
to delete it.
You can also click
to pause the live view and click
Click Save to save the settings.
to resume.
7.3.3 VCA Rule Configuration
Click the Rule tab to enter the VCA rules settings interface.
Steps:
1.
Check Rule checkbox to enable the rule settings.
Note: The related operation only takes effect after the rule is enabled.
2.
Click
to draw a rectangle detection rule or click
will be detected when passing through this region.
to draw a polygon detection rule. People
Note:
1)
To draw a polygon, click in the live view area to set the vertex of the polygon and then drag
84
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
the mouse to other place and click to set another vertex. After set all the vertexes, right-click
to finish drawing the polygon rule.
2)
The decagonal region can be supported, and once the tenth point is located, the system will
connect it to the first one with a line automatically.
3)
The height of the detection rule should be no larger than 2-thirds of the live view height.
3.
Click
to draw the minimum detection size.
Note: The face size greater than the minimum size will be detected.
4.
Optionally, you can check the ROI Switch checkbox to enable this function if supported by the
device.
To delete the drawing rule, click to select the rule and click
You can also click
to pause the live view and click
to delete it.
to resume.
7.3.4 Advanced Configuration
Click Advanced Configuration to enter the advanced configuration interface.
Parameter
Capture Interval
Description
The interval between two capture actions. E.g., if it is set as 5, then the
capture action executes every 5 frames.
Capture Times
The times for capturing the person who passes through the detection
region. If the person passes very fast, the capture times may be less than
the set parameter.
Generation Speed
The speed for generating the target frame (green) when the person enters
the detection region. If you increase this parameter, the target will
generate faster and also the false detection rate will rise. In general, it is
recommended to use the default value.
Sensitivity
The sensitivity for face detection. Larger value means higher sensitivity,
more faces will be detected and also false detection rate will rise. In
general, it is recommended to use the default value. Decrease the value if
85
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
the false detection rate is high.
Capture Sensitivity
The grade for face which is used for decreasing the false capture actions. If
you increase this value, then the face with better quality and clarity will be
captured.
Reference Brightness
The exposure adjustment for face capture. If the brightness of the face in
the image is lower than the set value, the face capture IPC will increase
the brightness of the image and vice versa.
Enable Face Exposure
Set the exposure time for face capture.
7.4 VCA Speed Dome Configuration
In the Device Management Configuration interface, select Group tab. Select a camera of the VCA
device for configuration and click VCA Config to enter the VCA Configuration interface.
Note: Before you can set the VCA configuration for the device, you should configure the group settings
for it. For details, please refer to Section 2.3 Group Management.
7.4.1 Behavior Analysis
If you set the VCA resource as Behavior Analysis, perform the following steps to configure the VCA
settings.
Basic Parameters Configuration
When having enabled the VCA resource of behavior analysis, the speed dome can auto-track the
object which triggers the configured rules. Before configure the auto-tracking settings for the speed
dome, you need to configure the basic parameters first.
In the VCA configuration interface, click Camera tab to enter the camera configuration interface.
Refer to the description below for the configuration of each item.
86
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
VCA Checkbox: Check the checkbox to enable the auto-tracking function.
VCA Picture: Enable/disable the upload of captured pictures to the software when the VCA rule is
triggered. The quality and resolution of the captured picture are adjustable.
Display Target Info on Alarm Picture: Enable/disable the function of overlaying target information on
an alarm picture.
Display Rule Info on Alarm Picture: Enable/disable the function of overlaying rule information on an
alarm picture.
Display VCA Info on Stream: Enable/disable the function of overlaying target and rule information on
steam.
Display Target Info on Original Picture: Enable/disable the function of overlaying target information
on original picture.
Display Rule Info on Original Picture: Enable/disable the function of overlaying rule information on
original picture.
Note: If you check the checkbox of display target info and rule on stream, the information will be
added to the video stream, and the overlay will be displayed only when you get live view or play back
by the VSPlayer.
Auto-tracking Configuration
Setting Single Scene Auto-tracking
Enable VCA function. Operate the PTZ of speed dome to select a scene for auto-tracking. Set rules for
the scene and save the settings. The speed dome will track the detected target automatically.
The specific steps are as follows:
Steps:
1.
In the camera configuration interface, check VCA checkbox to enable the VCA function.
2.
Click Auot-tracking to enter the Auto-tracking interface.
87
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
3.
Click
to the Scene List.
on the live view image to adjust the scene and click Add to add the scene
4.
Double-click the Scene Name filed and edit a name for the scene.
5.
Set PTZ limit to restrict the tracking region (Optional).
1) Click Display to unfold the Limit column in Scene List.
2) Check the checkbox under Limit to enable the limit function.
3) Click
to display the limit settings panel.
4) Control the PTZ and set the Top, Bottom, Left and Right limit for limiting the tracking area.
Click Set to configure the current position as the limit position. And you can click Return to
go to the corresponding limit position.
6.
Click Save under Scene Settings to save the scene settings. You can also click Return to go to the
scene.
7.
If you set the Tracking Duration, the speed dome stops tracking the target after the duration
time.
8.
Click Rule Settings field to enter the Rule Settings interface.
9.
Check
to enable a rule. Double-click the Rule Name field and edit a name for the rule. Click
the Event Type field and select a type for the rule.
Note: Up to 8 rules can be set for each scene.
88
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
10. Click
or
. Draw a rectangle or polygon on the live view image. (If you want to delete the
rule, click to select the rule and click
Notes:
1)
to delete it.)
To draw a polygon, click in the live view area to set the vertex of the polygon and then drag
the mouse to other place and click to set another vertex. After set all the vertexes, right-click
to finish drawing the polygon rule.
2)
The decagonal region can be supported, and once the tenth point is located, the system will
connect it to the first one with a line automatically.
11. Set size filter (Optional).
1) Check Size Filter checkbox.
2) Click
and draw rectangle to filter the maximum size objects.
3) Click
and draw rectangle to filter the minimum size objects. The specific size will be
displayed on Attribute column as follows.
Note: The object size that is between the maximum size and minimum size will be detected.
12. Set the tracking duration for the rule. This item is only available for Intrusion event type. If you
set 10 for this item, then the speed dome will track an object that intrudes into the pre-defined
region longer than the 10 seconds.
13. Set the direction for the rule. This item is only available for Line Crossing event type. You can set
unidirectional or bidirectional line crossing detection.
89
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
14. Click Save to save the settings.
15. Repeat the steps from 8 to 13 to enable more rules for this scene. Then click
to exit the rule
settings interface.
16. Click Advanced Configuration on the VCA Configuration interface to enter the Advanced
Configuration interface.
17. Click Zooming Ratio Settings tab.
18. Click
to set the zoom ratio and click Set Zoom Ratio to save the settings.
19. Click Save to save the settings. The speed dome tracks the objects according this zoom ratio.
Setting Multiple Scenes Auto-tracking
Steps:
1.
To set more scenes, repeat the steps from 1 to 19 of Setting Single Scene Auto-tracking section.
2.
Set the patrol sequence and duration for the scenes as follows. The speed dome patrols
according to the sequence No.. After the duration time, the speed dome patrols to the next
scene.
3.
Click Save to save the settings.
Arming Schedule of a Rule
When you set the arming schedule, the configured rule takes effect only in the time segment. You can
set up to 8 time segments for each rule.
Steps:
1.
In the VCA Configuration interface, select a scene and click Rule Settings field to enter the Rule
Settings interface.
2.
Select a rule in the rule list panel and click the Arming Schedule tab to edit the arming schedule
for the rule.
90
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
3.
Choose the day you want to set the arming schedule in the Week field.
4.
Check the checkbox
5.
After you set the arming schedule, you can click Copy to copy the schedule to other days
to enable a time segment and enter a start time and end time.
(Optional).
6.
Click Copy to All Rules, if you want to copy this arming schedule to other rules of one scene
(Optional).
7.
Click Save to save the settings.
Auto-tracking Alarm Linkage
Purpose:
After you set the alarm linkage, the alarm will be triggered when speed dome tracks objects
automatically.
Check the checkbox to select the linkage method.
Advanced Parameters Configuration
In the VCA Configuration interface, click Advanced Configuration to enter the VCA parameters
interface
91
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
The parameter description is as follows.
Parameter
Description
Detection Sensitivity
Background
Update
Rate
easily when the sensitivity is set higher.
It is used to adjust the rate of blending static object into the detected
scene. The rate is higher, the blending is faster.
Minimum Target Size
Displacement
Constraint
The sensitivity of detecting a target. The target can be detected more
for
Target
Generation
Triggering Position
Light
Change
When the target size is smaller than this minimum size, the target will
not be analyzed.
It is used to constraint the speed of generating a target. The value is
larger, the target generates harder and the false alarm will be fewer.
The rules can be triggered according to the target center, bottom or
top.
If there is a quick change of scene light, enable this function to
Suppression
suppress the change.
Tracking Duration after
The default value is 5s. You can set the duration to 2s, 3s, 4s, 5s, 6s, 7s
Target is Still
or 8s.
Force Tracking
After enabling this function, the speed dome will find the target and
the tracking continues after the target is blocked for a while.
7.4.2 Face Capture
If you set the VCA resource as Face Capture, perform the following steps to configure the VCA settings
for capturing the face of the people who trigger the configured rules in the pre-defined region.
92
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Camera Configuration
Click Camera tab to enter the camera configuration interface.
Note: The supported functions may vary among different connected devices.
Basic Information
You can view the basic information of the camera. Parent Device refers the VCA device that the
camera connects with. For face capture speed dome, it refers to the camera itself. While for other
camera like the camera connecting to behavior analysis DVR (e.g. iDS-8100HFI-ST), parent device
refers to the DVR.
Click the View button to view the VCA resource.
VCA Picture
Picture Quality: Configure the quality of the picture as good, better or best.
Display VCA Info on Picture
If you check the checkbox, the VCA info will be added to the video stream, and the information will be
displayed if you get live view or play back by the VSPlayer.
Shield Region Configuration
Click the Shield Region tab to enter the shield region interface. Up to 4 shield regions can be set.
You can set the shield region of the VCA rule, in which all the VCA rules are invalid.
Click the
icon; click and drag the mouse to draw the region; right-click to finish drawing.
Click to select the added shield region, and click
to delete it.
You can also click
to pause the live view and click
Click Save to save the settings.
to resume.
93
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
VCA Rule Configuration
Click the Rule tab to enter the VCA rules settings interface.
Steps:
1.
Check
checkbox to enable the rule settings.
Note: The related operation only takes effect after the rule is enabled.
2.
Click
to draw a rectangle detection rule. Click on the live view image to set a vertex, move the
mouse and click again to finish drawing the rectangle. People will be detected when passing
through this region.
You can also click
to draw a polygon. Click in the live view area to set the vertex of the
polygon and then drag the mouse to other place and click to set another vertex. After setting all
the vertexes, right-click to finish drawing the polygon rule. People will be detected when passing
through this region.
Note: The height of the detection rule should be no larger than 2/3 of the live view height.
3.
Click
to draw the square minimum detection size. Click on the live view image to set a vertex,
move the mouse and click again to finish drawing the minimum detection size. Or you can set the
94
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
minimum detection size in the attribute area.
Notes:

The following figure shows the recommended way for setting the minimum detection size
(square). The face should be clear enough to be recognized.

The face size that is between the maximum size and minimum size will be detected.
To delete the drawing rule, click to select the rule and click
You can also click
to pause the live view and click
4. Click Save to save the settings.
to delete it.
to resume.
Advanced Parameters Configuration
In the VCA Configuration interface, click Advanced Configuration to enter the advanced configuration
interface.
Parameter
Capture Interval
Description
The interval between two capture actions. E.g., if it is set as 5, then the
capture action executes every 5 frames. Default value: 1.
Capture Times
The times for capturing the person who passes through the detection
region. If the person passes very fast, the capture times may be less than
the set parameter. Default value: 1.
95
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Generation Speed
The speed for generating the target frame (green) when the person enters
the detection region. If you increase this parameter, the target will
generate faster and also the false detection rate will rise. In general, it is
recommended to use the default value. Default value: 3.
Sensitivity
The sensitivity for face detection. Larger value means higher sensitivity,
more faces will be detected and also false detection rate will rise. In
general, it is recommended to use the default value. Decrease the value if
the false detection rate is high. Default value: 3.
Capture Sensitivity
The grade for face which is used for decreasing the false capture actions. If
you increase this value, then the face with better quality and clarity will be
captured. Default value: 4.
7.4.3 Behavior & Face Capture
If you set the VCA resource as Behavior& Face Capture, the speed dome provides the capability of
both behavior analysis and face capture. Perform the following steps to configure the VCA settings.
Basic Parameters Configuration
In the VCA configuration interface, click Camera tab to enter the camera configuration interface.
Please refer to the Basic Parameters Configuration section of Section 7.4.1 Behavior Analysis for the
description of each item in this interface.
Note: If you check the checkbox of display target info and rule on stream, the information will be
added to the video stream, and the overlay will be displayed only when you get live view or play back
by the VSPlayer.
96
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Behavior Analysis and Face Capture Configuration
For auto-tracking function configuration, you can set single auto-tracking and multiple scenes
auto-tracking. Please refer to Auto-tracking Configuration section of Section 7.4.1 Behavior Analysis
for detailed settings.
Face Capture Settings
The speed dome can capture the face of the people who trigger the configured rules in the
pre-defined region.
Steps:
1.
In the camera configuration interface, check VCA checkbox to enable the VCA function.
2.
Click Face Capture Configuration to enter the Face Capture interface.
3.
Check Face Capture checkbox to enable this function.
4.
Set the parameters for this function, including the following items:
Capture Interval: The interval between two capture actions. E.g., if it is set as 5, then the capture
action executes every 5 frames. Default value: 1.
Capture Times: The times for capturing the person who passes through the detection region. If
the person passes very fast, the capture times may be less than the set parameter. Default value:
1.
Sensitivity: The sensitivity for face detection. Larger value means higher sensitivity, more faces
will be detected and also false detection rate will rise. In general, it is recommended to use the
default value. Decrease the value if the false detection rate is high. Default value: 3.
Capture Sensitivity: The grade for face which is used for decreasing the false capture actions. If
you increase this value, then the face with better quality and clarity will be captured. Default
value: 4.
5.
Click Save to confirm the settings.
Arming Schedule of a Rule
When you set the arming schedule, the configured rule takes effect only in the time segment. You can
set up to 8 time segments for each rule.
Steps:
1.
In the VCA Configuration interface, select a scene and click Rule Settings field to enter the Rule
Settings interface.
2.
Select a rule in the rule list panel and click the Arming Schedule tab to edit the arming schedule
for the rule.
97
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
3.
Choose the day you want to set the arming schedule in the Week field.
4.
Check the checkbox
5.
After you set the arming schedule, you can click Copy to copy the schedule to other days
to enable a time segment and enter a start time and end time.
(Optional).
6.
Click Copy to All Rules, if you want to copy this arming schedule to other rules of one scene
(Optional).
7.
Click Save to save the settings.
Alarm Linkage Settings
Purpose:
After you set the alarm linkage, the alarm will be triggered when speed dome detects the object(s).
Check the checkbox to select the linkage method.
Advanced Parameters Configuration
In the VCA Configuration interface, click Advanced Configuration to enter the VCA parameters
interface.
98
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
The parameter description is as follows.
Parameter
Detection Sensitivity
Background Update
Rate
Minimum Target Size
Displacement
Constraint for Target
Generation
Triggering Position
Light Change
Suppression
Tracking Duration after
Target is Still
Force Tracking
Stop Tracking after Face
Detected
Grade Threshold for
Stopping Tracking
Description
The sensitivity of detecting a target. The target can be detected more
easily when the sensitivity is set higher.
It is used to adjust the rate of blending static object into the detected
scene. The rate is higher, the blending is faster.
When the target size is smaller than this minimum size, the target will
not be analyzed.
It is used to constraint the speed of generating a target. The value is
larger, the target generates harder and the false alarm will be fewer.
The rules can be triggered according to the target center, bottom or
top.
If there is a quick change of scene light, enable this function to
suppress the change.
The default value is 5s. You can set the duration to 2s, 3s, 4s, 5s, 6s, 7s
or 8s.
After enabling this function, the speed dome will find the target and
the tracking continues after the target is blocked for a while.
If you can enable this function, the speed dome stops tracking the
target after it is captured by the speed dome.
The grade for the captured face. If you want to capture a clear face
before stopping tracking, you should set a higher grade threshold.
After the speed dome gets a face picture which meets the grade
requirement, the auto-tracking stops. Default value: 6.
99
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 8 Transcoder Management
Purpose:
Transcoder is designed for real-time transcoding of different streams. With the use of transcoder,
streams and control signals from different manufactures and different surveillance systems can be
effectively integrated and standardized. iVMS-4200 client software supports to add transcoder and
configure the transcoding function for it.
8.1 Adding Encoding Device to the Transcoder
8.1.1 Adding the Transcoder to the Client Software
Steps:
1.
Click the
on the control panel to enter the Device Management interface and click the
Server tab.
2.
Click Add New Device Type on the Organization list and select Transcoder.
3.
Click OK to save the settings, and the added transcoder type is displayed on the Organization list.
4.
Click Add Device to add the transcoder to the management list of the software.
100
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Select the adding mode by IP/Domain or by IP segment, and configure the corresponding settings
for the device.
For the detailed configuration about the adding modes, please refer to the following sections:
5.

By specifying the device IP/Domain address, see Section 2.2.2 Adding Devices Manually.

By specifying an IP segment, see Section 2.2.3 Adding Devices by IP Segment.
The successfully added transcoder can be viewed in the list:
8.1.2 Importing the Encoding Channel to the Transcoder
Before you start:
The cameras of encoding devices should be organized into groups before being imported to the
transcoder. For detailed configuration, please refer to Section 2.3 Group Management.
Steps:
1.
On the Device Management interface, select a transcoder from the device list and click Settings to
enter the transcoder settings interface.
2.
Select a group or a camera from the Group list and click the Import button to import the selected
camera or the cameras of the group, or click Import All to import the cameras of all groups to the
transcoder on the right.
3.
Optionally, you can click to select the stream and click
to remove it from the transcoding list.
101
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
8.2 Configuring the Transcoded Stream
Parameters
Steps:
1.
On the Transcoder Settings interface, select a stream from the list and you can configure its
parameters in the Selected Transcoded Stream area.
2.
Configure the parameters of the transcoded stream as needed, including the resolution, bitrate,
package format, video encoding type, protocol type and video stream from the drop-down list.
3.
(Optional) Check the checkbox of Obtain Video Stream Via Stream Media Server if you want to
use the stream media server to forward the video stream.
Note: You should add a stream media server to the client before you can select the stream media
server.
4.
Click Advanced Settings to enter the advanced settings of the selected transcoded stream.
(1) Edit the parameters of the transcoded stream on demands, including the stream type, video
quality, bitrate type, frame rate, frame type, audio encoding type, profile and I frame interval.
You can also remain the default parameters of the stream.
102
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
(2) Click OK to save the settings.
5.
(Optional) Click the Copy to on the Selected Transcoded Stream settings area to copy the settings
of the current stream to other stream(s).
6.
Click Save to save the settings.
8.3 Operating the Transcoded Stream
Purpose:
After successfully transcoding, the live view of the camera uses transcoded stream.
Steps:
1.
Enter the Main View interface and select a transcoded camera for live view. For detailed
configuration, please refer to Section 2.4 Basic Operations in Live View.
Note: If the camera is in live view before transcoding, please stop the live view first and then start
the live view again to view the live video of the camera via transcoded stream.
2.
During the live view, you can right-click on the camera node and select Transcoding Status to view
the transcoding status.
3.
For e-map settings, please refer to Chapter 5 E-map Management; for displaying on video wall,
please refer to Chapter 12 Decoding and Displaying Video on Video Wall.
Note: Displaying the transcoded stream on video wall should be supported by the decoder.
103
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 9 Log Management
Purpose:
The log files of the client software are stored on the local PC and can be searched for checking. 2 types
of log files are provided: client logs and server logs. The client logs refer to the log files of the client
and are stored on the local PC; the server logs refer to the log files of the connected devices and are
stored on the local device.
Click the
icon on the control panel to open the Log Search page.
Searching Log Files
Steps:
1.
Open the Log Search page.
2.
Select the log type. If Server Logs is selected, then click to specify the device for search.
3.
4.
Click the icon
to specify the start time and end time.
Click Search. The log files between the start time and end time will be displayed on the list.
You can check the operation time, description and other information of the logs.
Note: Please narrow the time range or filter the log type for search if there are too many log files.
104
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Filtering Log Files
Purpose:
After searched out successfully, the log files can be filtered by the keyword or condition, and thus you
can find the logs as you want.
Steps:
1.
Click Log Filter or the icon
2.
Select Filter by Keyword, and then input keyword for filtering in the text field; or
on the Log Search page to expand the Log Filter panel.
select Filter by Condition, and then specify log type in the drop-down list.
3.
Optionally, you can click More… to filter the log files more accurately.
4.
Click Filter to start filtering. You can click Clear Filter the cancel the filtering.
Backing up Log Files
Purpose:
The log files, including the client logs and server logs, can be exported for backup.
Steps:
1.
Set the condition and search the log file.
2.
Click Backup Log to open the Backup Log dialog box.
3.
4.
Click the icon
, select a local saving path and set a name for the file.
Click Backup to export the selected log file for backup.
You can click FileOpen Log File to check the information of the backup log files on local PC.
105
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 10 Account Management and
System Configuration
10.1 Account Management
Purpose:
Multiple user accounts can be added to the client software, and you are allowed to assign different
permissions for different users if needed.
Click the
icon on the control panel,
or click Tool->Account Management to open the Account Management page.
Note: The user account you registered to log into the software is set as the super user.
Adding the User
Steps:
1.
Open the Account Management page.
2.
Click Add User to open the Add User dialog box.
3.
Select the user type from the drop-down list. 2 types of user accounts are selectable:
Administrator: The administrator account has all permissions by default, and can modify the
passwords and permissions of all operators and its own account.
Operator: The operator account has no permission by default and you can assign the permissions
manually. An operator can only modify the password of its own account.
4.
Input the user name, password and confirm password as desired.
5.
Check the checkboxes to assign the permissions for the created user. Optionally, you can select a
user in the Copy from drop-down list, to copy the permissions of the selected user.
6.
Optionally, you can click Default Permission to restore the default permissions of this user.
106
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
7.
Click Save to save the settings.
Notes:

A user name cannot contain any of the following characters: / \ : * ? “ < > |. And the length of the
password cannot be less than 6 characters.

Up to 50 user accounts can be added for the client software.
Managing the User
Purpose:
After created successfully, the user account is added to the user list on the Account Management page.
You can edit or delete the information of the user accounts.
To edit the information of the user, select the user from the list, and click Edit User.
To delete the information of the user, select the user from the list, and click Delete User.
For super and administrator user, you can click Copy to to copy the permissions to other user(s).
Note: The super user cannot be deleted and only the password of the super user can be edited.
10.2 System Configuration
Purpose:
The general parameters, file saving paths, keyboard and joystick shortcuts, alarm sounds and Email
settings can be configured.
Click the
icon on the control panel,
or click Tool->System Configuration to open the System Configuration page.
107
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Note: You can click Default Value to restore the defaults of all the system configurations.
10.2.1 General Settings
Purpose:
The frequently-used parameters, including the log expired time, view scale, etc., can be set.
Steps:
1.
Open the System Configuration page.
2.
Click the General tab to enter the General Settings interface.
3.
Configure the general parameters. For details, see Table 7.1 General Parameters.
4.
Click Save to save the settings.
Table 7.1 General Parameters
Parameters
Descriptions
Log Expired Time
The time for keeping the log files, once exceeded, the files will be deleted.
View Scale
The view scale of the video in live view or playback. It can be set as Full
Screen, 4:3, 16:9 or Original Resolution.
108
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Network Performance
Play Performance
Picture Format
The current network conditions. It can be set as Normal, Better or Best.
The play performance of the live video. It can be set as Shortest Delay or
Self-adaptive.
Set the file format for the captured pictures during live view or playback.
The server port for accessing iVMS-4200 client via web browser. By
default, it is 80. If the port No. of your PC running the iVMS-4200 is
Web Server Port
occupied, you can modify it.
After changing the port No., you should access the client via web browser
by inputting IP address of the PC running the client : new port No.. Please
refer to Section 13.1 Login for details.
Enable Screen Toolbar
Show the toolbar on each display window in live view or playback.
Display
Enable Auto-login
Prioritize Playback of
Record Files on Storage
Log into the client software automatically.
Play back the video files recorded on the storage server preferentially.
Otherwise, play back the video files recorded on the local device.
Server
Resume Live View
Resume the latest live view status after you log into the client again.
Status
Auto-change Stream
Type
Change the stream type automatically in live view according to the size of
the display window.
Highlight for Motion
Mark the detected objects with green rectangles in live view and
playback.
Display Transaction
Display the transaction information in the live view.
Information
VCA Rule
Auto Time Adjustment
Display the VCA rule in the live view.
Adjust the time automatically at a specified time point.
10.2.2 File Saving Path Settings
Purpose:
The video files from manual recording, the captured pictures and the system configuration files are
stored on the local PC. The saving paths of these files can be set.
Steps:
1.
Open the System Configuration page.
2.
Click the File tab to enter the File Saving Path Settings interface.
3.
4.
Click the icon
and select a local path for the files.
Click Save to save the settings.
109
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
10.2.3 Keyboard and Joystick Shortcuts Settings
Purpose:
DS-1003KI keyboard can be connected to the client and be used to control the PTZ cameras. You can
set the shortcuts for PC keyboard and USB joystick to get quick and convenient access to the
commonly used actions.
Steps:
1.
For keyboard: Select the COM port from the drop-down list if DS-1003KI keyboard is connected to
the PC installed with the client.
2.
For PC keyboard and USB joystick:
1)
Select a certain function from the list.
2)
Double-click the item field under the PC Keyboard or USB Joystick column.
3)
Select the compound keys operation or number from the drop-down list to set it as the
shortcuts for the function of the PC keyboard or USB joystick.
3.
Click Save to save the settings.
110
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
10.2.4 Alarm Sound Settings
Purpose:
When the alarm, such as motion detection alarm, video exception alarm, etc., is triggered, the client
can be set to give an audible warning and the sound of the audible warning can be configured.
Steps:
1.
Open the System Configuration page.
2.
Click the Alarm Sound tab to enter the Alarm Sound Settings interface.
3.
Click the icon
4.
5.
Optionally, you can click the icon
Click Save to save the settings.
and select the audio files from the local path for different alarms.
for a testing of the audio file.
Note: The format of the audio file can only be *wav.
10.2.5 Email Settings
Purpose:
An Email notification can be sent when a system alarm occurs. To send the Email to some specified
receivers, the settings of the Email need to be configured before proceeding.
Steps:
1.
Open the System Configuration page.
2.
Click the Email tab to enter the Email Settings interface.
3.
Input the required information.
Server Authentication (Optional): If your email server requires authentication, check this
checkbox to use authentication to log into the server and enter the login user name and
password of your email account.
SMTP Server: Input the SMTP Server address.
Port: Input the communication port of Email service. The port is 25 by default.
User Name: Input the user name of the sender Email address if Server Authentication is checked.
Password: Input the password of the sender Email address if Server Authentication is checked.
Sender Address: Input the Email address of the sender.
Receiver 1—3: Input the Email address of the receiver. Up to 3 receivers can be set.
111
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.
Optionally, you can check the checkbox Enable SSL to increase the security of email sending.
5.
Optionally, you can click Send Test Email to send an email to the receiver for test.
6.
Click Save to save the settings.
112
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 11 Forwarding Video Stream
through Stream Media Server
Purpose:
There is always a limit of the device remote access number. When there are many users wanting to get
remote access to the device to get the live view, you can add the stream media server and get the
video data stream from the stream media server, thus to lower the load of the device.
11.1 Adding the Stream Media Server
Before you start:
The stream media server application software needs to be installed and it is packed in the iVMS-4200
software package. When installing the iVMS-4200, check the checkbox Stream Media Server to
enable the installation of stream media server.
Steps:
1.
Click the shortcut icon
on the desktop to run the stream media server.
Note: You can also forward the video through the stream media server installed on other PC.
2.
Open the Device Management page and click the Server tab.
3.
Click Add New Device Type, select Stream Media Server and click OK.
4.
Click Stream Media Server on the list and then click Add Device.
You can add the stream media server in the following two ways:

Adding Stream Media Server by IP Address
Perform the following steps to add the stream media server:
1)
Select IP Address as the adding mode.
2)
Input the nickname and IP address of the stream media server. The default port value is
554.
3)

Click Add to add the stream media server to the client software.
Adding Stream Media Server by IP Segment
Perform the following steps to add the stream media server by IP segment:
1)
Select IP Segment as the adding mode.
2)
Input the start IP and end IP. The default port value is 554.
3)
Click Add to add the stream media server to the client software. The stream media
113
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
server of which the IP address is between the start IP and end IP will be added to the
client.
Note: For one client, up to 16 stream media servers can be added.
11.2 Adding Cameras to Stream Media Server to
Forward Video Stream
Purpose:
To get the video stream of a camera via stream media server, you need to connect the camera to the
stream media server.
Steps:
1.
Select the stream media server from the list.
2.
Click Configure to enter the Stream Media Server Settings interface.
3.
Select the cameras of which the video stream is to be forwarded via the stream media server.
4.
Click OK to save the new settings.
5.
Go the Main View page and start the live view of the cameras again. You can check the channel
number of the video stream forwarded through or sent from the stream media server.
Note: For one stream media server, up to 64 channels of video stream can be forwarded through it
and up to 200 channels of video stream can be sent to clients from it.
114
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 12 Decoding and Displaying
Video on Video Wall
The Video Wall module provides the video decoding functionality, and the decoded video can be
displayed on the Video Wall for an attention-grabbing performance.
Click the
icon on the control panel, or click View->Video Wall to open the Video Wall page.
12.1 Adding the Encoding Device
Purpose:
You should add the encoding device for decoding and displaying on the video wall. If you do not add
the encoding devices in the Device Management page, you can add them in Video Wall page.
Steps:
1.
In the Camera area, click
to activate the adding device window.
115
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
2.
Select the adding mode and configure the corresponding settings for the device.
For the detailed configuration about the 4 adding modes, please refer to the following sections:

By specifying the device IP address, see Section 2.2.2 Adding Devices Manually.

By specifying an IP segment, see Section 2.2.3 Adding Devices by IP Segment.

By IP Server, see Section 2.2.4 Adding Devices by IP Server.

By HiDDNS, see Section 2.2.5 Adding Devices by HiDDNS.
(Optional) If you want to add the third-party encoding device, please perform the following steps:
1.
Go to the Device Management page and click the Server tab.
2.
Click Add New Device Type, select Third-party Encoding Device and click OK.
3.
Select Third-party Encoding Device in the organization panel and click Add Device to activate the
Add Device window.

For IP/Domain: Edit the nickname, IP address / domain name, port No., user name,
password, channel number, start from and manufacturer for the device.

For IP Segment: Edit the start IP, end IP, port No., user name, password, channel number,
start from and manufacturer for the device.
Note: If you edit 4 in Start From field, the software will get stream from the device since the fourth
channel.
116
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
12.2 Adding the Decoding Device
Purpose:
To decode the video of the encoding device and display the decoded video on the Video Wall, the
decoding device needs to be added to the client.
Steps:
1.
Click Enter Video Wall Config to enter the decoding device and video wall configuration interface.
2.
In the Decoding Output area, click
3.
Set the device type as Decoder or Cascading Server.
to activate the Quick Adding of Decoding Device window.
For Decoder, there are 2 adding modes available. Select the adding mode and configure the
corresponding settings for the device.
For the detailed configuration about the 2 adding modes, please refer to the following sections:

By specifying the device IP address, see Section 2.2.2 Adding Devices Manually.

By specifying an IP segment, see Section 2.2.3 Adding Devices by IP Segment.
For Cascading Server, you can add the device via IP address. For detailed configuration, see
Section 2.2.2 Adding Devices Manually.
Edit the Output of the Decoding Device
Steps:
1.
In the Decoding Output area, click
2.
Double-click an output and you can edit the parameters for it. Or you can right-click a decoding
before the decoding device to list the outputs of it.
output in the video wall area and select Decoding Output Configuration to edit its parameters.
Note: For HDMI and VGA outputs, the resolution can be configured; for BNC output, the video
standard can be configured.
3.
(Optional) you can check the checkbox of Batch Configuration and select other outputs to copy
the settings to.
4.
Click OK to save the settings.
117
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
12.3 Configuring Video Wall Settings
Purpose:
After the encoding device and decoding device have been added, the parameters of Video Wall need
to be configured for video display.
12.3.1 Linking Decoding Output with Video Wall
Steps:
1.
Click Enter Video Wall Config to enter the decoding device and video wall configuration interface.
2.
A default video wall view with the window division of 3*3 is provided. You can edit the default
video wall or add a new video wall as desired.
Task 1: Add a Video Wall
1) Right-click the video wall and select Add Video Wall, or click
Wall window.
to activate the Add Video
2) Enter the name, row number, column number and proportion of the video wall.
118
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
3) Click Add.
Task 2: Edit a Video Wall
1) Right-click the video wall and select Modify Video Wall to edit it.
2) In the pop-up window, you can edit the name, row number, column number and proportion
of the video wall.
Note: You can also drag your mouse to set the needed video wall.
3) Click Modify to save the settings.
Task 3: Delete a Video Wall
To delete the video wall, right-click the video wall and select Delete Video Wall.
3.
Click-and-drag the decoding output on the left-side list to the display window of video wall, to
configure the one-to-one correspondence. You can also click and hold the Ctrl or Shift key to
select multiple outputs and then drag them to the video wall for configuring linkage in batch. You
can click
in the upper-right corner of the display window to release the linkage.
Notes:

Up to 4 video walls can be added to the client software.

The total number of the display windows of the video wall should be no more than 100.

The ranges of the row number and column number are both between 1 and 10.
119
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
12.3.2 Multi-screen Display
Purpose:
For DS-6400HDI-T series decoder, you can joint multiple screens as a whole window. In this way, the
decoded video of one camera can be shown on the jointed window.
Before you start:
You should add DS-6400HDI-T series decoding device to the client. Please refer to Section 12.2 Adding
the Decoding Device for detailed configuration about adding decoding device.
Steps:
1.
Perform the step 3 of Section 12.3.1 Linking Decoding Output with Video Wall to configure the
linkage between the decoder and video wall.
2.
Click-and-drag you mouse to select the adjacent display windows for jointing.
Notes:
1.
You can only joint the same output interfaces as a whole window. E.g., you can only joint 4
VGA interfaces or HDMI interfaces.
2.
3.
Click
BNC interface does not support jointing.
to confirm jointing the screens.
120
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
4.
(Optional) You can set the resolution for the jointed window by right-clicking on it and select
Decoding Output Configuration.
To cancel the multi-screen display, click
in the upper-right corner of the display window.
12.3.3 Configuring Background
Purpose:
You can upload pictures for showing as the background of the video window.
Note: Only the cascading server supports background configuration.
Steps:
1.
2.
Click
to expand the Background Picture panel.
Select a background picture and click
to activate the background uploading window.
3.
4.
Click
to select a picture file.
Select an index for the picture. Each index is related to a picture.
5.
Click Upload to upload the picture.
6.
Click and drag the configured background picture to the desired position of the video wall.
7.
You can move the window when the cursor becomes
and adjust its size when the cursor
becomes directional arrow. Right-click on the background picture and select Background Picture
you can control the background picture.
Note: The picture will be displayed on the physical video wall after you upload the background.
121
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
12.4 Displaying Video on Video Wall
Purpose:
After the settings of the encoding device, decoding device and video wall, the video stream from the
encoding devices can be decoded and displayed on the Video Wall.
Note: After enable decoding and displaying, the captured picture of the video from the encoding
device displays on the Video Wall interface. And the real-time live view is shown on the physical video
wall.
12.4.1 Decoding and Displaying
Steps:
1.
Click Back to Operation Page to go back to the Video Wall Operation interface.
2.
Click
to save the linkage settings for the current scene. Or click
scene to save the settings for.
(beside
) and select a
Notes:

Scene settings are only supported by the cascading server. For setting the decoder, please skip
step 2 and 3.

8 scenes can be set for a video wall. Each scene can be configured with different linkage
settings and window divisions.

For editing the name of a scene, select a scene and click
can also click
to define a new name for it. You
to clear all the settings for the scene.
3.
Select a scene which is configured with linkage settings and click
to enable the scene.
4.
Click-and-drag the camera on the left-side list to the display window of video wall. The video
stream from the camera will be decoded and displayed on the Video Wall. You can also select a
decoding window and then double-click a camera to decode and display the video. You can also
click and hold the Ctrl or Shift key to select multiple cameras and then drag them to the video
wall.
5.
Select a playing window and click the icon
to get a preview of the video in the lower-right
corner of the screen. Or you can directly drag a camera to the preview window for live view. You
can also double-click the preview window to get a full-screen view.
Note: You can move the mouse to the window and click
in the lower-right corner to stop
decoding.
6.
(Optional) Select a decoding window and click
save the settings for the current scene. Or click
settings for.
7.
to set the window division for it. Click
(beside
If the decoded camera supports PTZ control, you can click
to
) and select a scene to save the
beside PTZ to activate the PTZ
control panel. For detailed configuration, please refer to Section 2.4.3 PTZ Control in Live View.
8.
Right-click on a playing window to activate the decoding management menu, as shown below:
Note: The menu differs depending on the devices.
122
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Stop / Start Decoding: Stop / Start the decoding.
Start / Pause Successive Decoding: Start / Pause the cycle decoding. This function is only supported
by decoder.
Refresh: Refresh the decoding.
Open / Close Digital Zoom: Enable / Disable digital zoom.
Enable Audio: Turn on / off the audio of the decoding video.
Enlarge Window: Display the window in full-screen mode.
Decoding Channel Status: View the status of the decoding channel, such as decoding status, stream
type.
Upload Logo: Upload a picture as the logo to the video window and set the display parameters for it.
After setting, the logo shows in the defined position of the window on physical video wall.
Show / Hide Logo: Show / Hide the logo.
Stick on Top: Always stick the window on the top layer. This function is only supported by cascading
server.
Stick at Bottom: Always stick the window at the bottom layer. This function is only supported by
cascading server.
Lock: Lock the window to disable the roaming function.
Set Alarm Window: Display the video triggered by event or alarm input on Video Wall.
Decoding Delay: Set the delay degree of the decoding according to the actual needs. This function is
only supported by cascading server.
Go to Playback: Enter the playback mode. This function is only supported by decoder.
123
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Icon
Description
Start all the decoding
Stop all the decoding
Stop all the roaming windows
Refresh all the decoding windows
Set cycle decoding and switching interval
12.4.2 Windowing and Roaming Settings
Purpose:
Windowing is to open a new window on the screen(s). The window can be within a screen or span
multiple screens. You can move the playing window within the video wall as desired and this function
is called roaming.
Note: The windowing and roaming function should be supported by the decoding device.
Steps:
1.
Click-and-drag on a screen which links to a decoding output to open a window. The window can
be within a screen or span multiple screens. If you want to open a window on the opened window,
click-and-drag and hold the Ctrl key to create one. And for the locked window (refer to step 6),
you can click-and-drag to create a new window on it.
Note: At least one camera should be selected before opening window.
2.
You can move the window when the cursor becomes
and adjust its size when the cursor
124
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
becomes directional arrow. You can also hold the Shift key to scale the window in proportion.
3.
During moving the window, the dotted borders will display. The window will be adjusted to align
with the borders if it is moved to the location near the dotted borders.
4.
Double-click the window and it will enlarge to fill the spanning screens and display on the top
layer. You can double-click again to restore.
5.
(Optional) Select a window and click
settings for it.
6.
Right-click on a window and select Lock in the right-click menu to disable the roaming function,
and the
to set the window division for it. Click
to save the
icon shows on the top-right corner of the window. In this way, the window cannot be
moved and resized. You can right-click on the window and select Unlock in the right-click menu to
recover the roaming function.
7.
Right-click on a window and select Stop Decoding in the right-click menu, or move the mouse to
the window and click
8.
in the upper-right corner to stop the decoding of the window and it will
be closed. You can also click
to close all the roaming windows.
The window only shows a captured picture of the decoded video. You can right-click on a window
and select Refresh in the right-click menu, or move the mouse to the window and click
in the
lower-right corner to capture a latest picture of the decoded video and display on the window.
9.
If you want to view the specific area of the video in details, you can right-click on a window and
select Open Digital Zoom in the right-click menu and the cursor becomes
. Use the mouse to
drag on the video to realize digital zoom. You can check the effect on the physical video wall
10. Select a playing window and click the icon
to get a preview of the video in the lower-right
corner of the screen. Or you can directly drag a camera to the preview window for live view. You
can also double-click the preview window to get a full-screen view.
11. Right-click on a playing window and you can control decoding management via the right-click
menu.
12.4.3 Configuring Playback
Purpose:
125
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
The record file is supported to be played back on the video wall.
Note: playback function is only supported by decoder.
Steps:
1.
Click-and-drag the camera on the left-side list to the display window of video wall, or you can
open a window if supported.
2.
Move the mouse to the window and click
in the upper-right corner. Or you can right-click on
the window and select Go to Playback in the right-click menu.
3.
If there is record file of current day, the record file will be played back automatically. If not, you
can set the search condition on the search panel which shows in the left area of the interface, and
click Search to find the record file. For detailed configuration about searching record files, please
refer to Section 3.2.1 Normal Playback.
4.
Right-click on the playback window and you can control the playback through the right-click menu,
such as pause, stop, fast forward, slow forward, capture, start recording and full-screen playback.
Note: The saving path for the captured pictures and recorded files can be configured on System
Configuration page. Please refer to Section 10.2.2 File Saving Path Settings for detailed settings.
When you move the mouse to the screen, the icons will display as shown below.
Icon
Description
Pause the playback
Stop the playback
Capture the playback video
Record the playback video
Back to live view mode
Playback speed.
12.4.4 Configuring Cycle Decoding
Purpose:
The cycle decoding refers that you can configure multiple video streams of encoding devices to one
decoding output and you can set the switching interval for the decoding.
Note: The cycle decoding is only supported by decoder.
Steps:
1.
Click
beside
and set the switching interval for the cycle decoding.
2.
Click-and-drag the camera on the left-side list to the display window of video wall, or you can
open a window if supported.
3.
Move the mouse to the group node and click
to start cycle decoding. Right-click on the
126
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
window and you can control decoding management via the right-click menu.
12.5 Configuring Video Wall Controller
Purpose:
The client provides the function of managing the added video wall controller.
12.5.1 Adding the Video Wall Controller
Purpose:
You should add the video wall controller to the client for management.
Steps:
1.
Go to the Device Management page and click the Server tab.
2.
Click Add New Device Type, select Video Wall Controller and click OK.
3.
Select Video Wall Controller in the organization panel and click Add Device to activate the Add
Device window.
4.
Edit the nickname, IP address / domain name, port No., user name and password for the device.
5.
Click Add to save the settings.
6.
For edit the output, please refer to Section 12.2 Adding the Decoding Device.
12.5.2 Linking Output with Video Wall
Steps:
1.
Click Enter Video Wall Config to enter the configuration interface.
2.
A default video wall with the added video wall controller name is provided. You can edit the
default video wall as desired. For details, please refer to Section 12.3.1 Linking Decoding Output
with Video Wall.
3.
Click-and-drag the output of the added video wall controller on the left-side list to the display
window of video wall, to configure the one-to-one correspondence. You can also click and hold
the Ctrl or Shift key to select multiple outputs and then drag them to the video wall for
127
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
configuring linkage in batch. You can click
in the upper-right corner of the display window to
release the linkage.
4.
For background settings, please refer to the Section 12.3.3 Configuring Background.
Notes:

The total number of the display windows of the video wall should be no more than 100.

The ranges of the row number and column number are both between 1 and 10.
12.5.3 Configuring Virtual LED
Purpose:
You can display the required contents on the video wall by using virtual LED.
Steps:
1.
Click Enter Video Wall Config to enter the configuration interface.
2.
Click
3.
Click-and-drag the virtual LED to the video wall.
4.
You can move the window when the cursor becomes
becomes directional arrow.
5.
Right-click the virtual LED in the panel and select Virtual LED Settings to set the parameters for it.
to display the Virtual LED panel, click
to expand the added video wall controller.
and adjust its size when the cursor

Content: Set the content that you want to display on the video wall.

Show Mode: Select the mode of the virtual LED as desired.

Moving Speed: Set the scrolling effect for the displayed text.

Font Size: Set the size of the displayed text.

Font Color: Set the color of the displayed text by clicking Color.

Background Color: Set the color of the background by clicking Color
128
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
12.5.4 Configuring Video Wall Screens
Purpose:
The screens of the video wall can be configured, including screen type, opening screen, closing
screen, input source and image parameters.
Steps:
1. Click Back to Operation Page to go back to the Video Wall Operation interface.
2.
3.
Click
to activate the Screen Control window.
Click-and-drag on the video wall to select the screens and configure the parameters for
them.
Screen Type: Select the type for the selected screens for different screen type adopting
different communication protocols.
Open Screen / Close Screen: Open or close the selected screens.
Open All / Close All: Open or close all the screens.
Input Source Type: Select the input source for the screen and click Set to save the settings.
Image Parameters and Position Adjustment: Select brightness or contrast and click
or
to adjust the image parameters. Select horizontal or vertical and click
or
to
adjust the image position on the screen.
129
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
12.5.5 Displaying Video on Video Wall
Purpose:
After adding the video wall controller and linking the output with the video wall, the video stream
from the encoding devices or the signal source can be displayed on the video wall.
Notes:

Encoding devices refer to the devices connected to iVMS-4200 client via network.

Decoding module should be connected to the video wall controller before the video of the
encoding devices can be decoded and displayed.

Signal source refers to the video signal (e.g., analog camera) connected to the video wall
controller via the local interfaces of the controller.

After enable decoding and displaying, the captured picture of the video from the encoding
device displays on the Video Wall interface. And the real-time live view is shown on the physical
video wall.

For signal source, no captured pictures displaying on the output window. You can check the live
video on the physical video wall.
Steps:
1.
Click Back to Operation Page to go back to the Video Wall Operation interface.
2.
Select a scene which is configured with linkage settings and click
3.
Click-and-drag the camera or signal source on the left-side list to the display window of video wall.
to enable the scene.
The video stream from the camera or signal source will be displayed on the Video Wall. You can
also select a decoding window and then double-click a camera to decode and display the video.
You can also click and hold the Ctrl or Shift key to select multiple cameras and then drag them to
the video wall.
4.
Or you can select a camera or signal source, then click-and-drag on a screen which links to an
output to open a window. The window can be within a screen or span multiple screens. If you
want to open a window on the opened window, click-and-drag and hold the Ctrl key to create one.
For details, please refer to Section 12.4.2 Windowing and Roaming Settings.
5.
Select a playing window and click the icon
to get a preview of the video in the lower-right
corner of the screen. Or you can directly drag a camera to the preview window for live view. You
can also double-click the preview window to get a full-screen view.
6.
Click
to save the current settings as a scene. Or click
create a new scene to save the settings for.
(beside
) and select a scene or
Notes:

32 scenes can be set for a video wall controller.

For editing the name of a scene, select a scene and click
can also click
click
7.
to define a new name for it. You
to clear all the settings for the scene. For calling a scene, select a scene and
to enable the scene.
Right-click on a playing window to activate the decoding management menu, as shown below:
Note: The menu differs depending on the devices. Please refer to Section 12.4.1 Decoding and
Displaying for detailed introduction.
8.
For displaying the record files of the encoding device on the video wall, please refer to Section
12.4.3 Configuring Playback.
130
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
12.5.6 Configuring Plan
Purpose:
The plan function of video wall controller provides the switching the configured scene(s) and turning
on or off the screens at a certain time. You can also set the time schedule for switching the operations
(such as scene, close screens) and the plan can also be auto-switched.
Before you start: Scene(s) should be added for the video wall controller. Please refer to Section 12.5.5
Displaying Video on Video Wall for adding scenes.
Steps:
1.
Click Back to Operation Page to go back to the Video Wall Operation interface.
2.
Click
to display the Plan panel, click Add Plan or right-click on the panel and select Add Plan
to pop up the Add Plan window.
Note: Up to 16 plans can be added to a video wall controller.
3.
Set the parameters for the plan:
Nickname: Edit a name for the plan as desired.
Mode: Select the mode to execute the plan. Manual, Auto and Auto-switch are selectable.

Manual: Automatically execute the plan until you stop calling the plan manually.

Auto: Execute the plan according to the configured start time and execution times in
Parameters panel.

Auto-switch: Execute the plan according to the configured time schedule and execution
times in Parameters panel.
Plan Task: Set the operations for the plan. The plan will be execute the added operations in
order.

Add: Add an operation for the plan. If you select the Task Type as Display Scene, you can
select the configured scene in the Scene drop-down list and set the dwell time. If you select
the Task Type as Open Screen or Close Screen, you can select the screen type for opening or
closing and set the dwell time.

Up: Move the selected operation up.

Down: Move the selected operation down.

Delete: Remove the selected operation.
Parameters:
If you select Auto as the mode, you can set the Start Time and Execution Times. E.g., you set the
131
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Start Time as 2014-06-04 00:00:00 and Execution Times as 4, then the plan will be executed from
2014-06-04 00:00:00 and continuously for 4 times before stopping.
If you select Auto-switch as the mode, you can set the Weekday Settings and Execution Times.
E.g., you set the Weekday Settings as 10:30:00 of Mon and 08:30:00 of Wed, and Execution
Times as 6, the plan will be executed from 10:30:00 of Monday and continuously for 6 times,
then from 08:30:00 of Wednesday and continuously for 6 times. The next week, the plan will be
executed at the configured time.
4.
Click OK to save the settings.
5.
To call a plan, select a plan and click
click
to enable the plan. For editing the plan, select a plan and
to edit the settings for it. You can also click
to clear all the settings for the plan. To
stop the plan, right-click a plan and select Stop Plan.
Note: Please stop the plan before you want to configure the video wall controller.
132
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Chapter 13 Web Browsing
Purpose:
The iVMS-4200 client software can also be accessed through web browsing. It provides the
functionalities of live view, playback, device management, account management, system configuration,
etc.
13.1 Login
Steps:
1.
Input the IP address of the PC running the iVMS-4200 in the address bar of the web browser, and
press the Enter key. A login window will pop up.
2.
Input the user name and password of iVMS-4200.
3.
Optionally, check the checkbox Remember password to save the password.
4.
Click Login.
Note: You can set the language as Chinese or English in the upper-right corner of the login interface.
The homepage of the web browser after you login is shown as below.
133
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
13.2 Device Management
Purpose:
Before doing any operations via the web browser, devices need to be added to the system for
monitoring and management. You can add devices through the web browser.
Adding the Encoding Device
Steps:
1.
Click the Device Management tab to open the Device Management page.
2.
Click the Server tab.
3.
Click Encoding Device to enter Encoding Device Adding interface.
You can add the encoding device in the following ways:

Adding Devices Manually.

Adding Devices by IP Segment.

Adding Devices by IP Server.

Adding Devices by HiDDNS.
Adding Devices Manually
Steps:
1.
2.
Click the
icon to open the device adding dialog box.
Select IP/Domain as the adding mode from the drop-down list.
3.
Input the required information.
Nickname: Edit a name for the device as you want.
Address: Input the device’s IP address or domain name.
Port: Input the device port number. The default value is 8000.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
5.
Click OK to add the device.
134
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Adding Devices by IP Segment
Steps:
1.
2.
Click the
icon to open the device adding dialog box.
Select IP Segment as the adding mode from the drop-down list.
3.
Input the required information.
Start IP: Input a start IP address.
End IP: Input an end IP address in the same network segment with the start IP.
Port: Input the device port number. The default value is 8000.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device IP. All the
channels of the device will be imported to the corresponding group by default.
5.
Click OK, and the device of which the IP address is between the start IP and end IP will be added
to the device list.
135
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Adding Devices by IP Server
Steps:
1.
2.
Click the
icon to open the device adding dialog box.
Select IP Server as the adding mode from the drop-down list.
3.
Input the required information.
Nickname: Edit a name for the device as you want.
Server Address: Input the IP Server address.
Device ID: Input the device ID registered on the IP server.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
5.
Click OK to add the device.
Adding Devices by HiDDNS
Steps:
1.
2.
Click the
icon to open the device adding dialog box.
Select HiDDNS as the adding mode from the drop-down list.
3.
Input the required information.
Nickname: Edit a name for the device as you want.
Server Address: www.hik-online.com.
Device Domain Name: Input the device domain name registered on the HiDDNS server.
User Name: Input the device user name. By default, the user name is admin.
Password: Input the device password. By default, the password is 12345.
4.
Optionally, you can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
5.
Click OK to add the device.
136
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Note: Check the checkbox Add Offline Device, input the required information and the device channel
count, and then click Add. When the offline device comes online, the software will connect it
automatically.
The devices will be displayed on the device list for management after added successfully. You can
check the nickname, IP address, serial No., HDD status, recording status and other information of the
added devices on the list.
Click Refresh All to refresh the information of all added devices. You can also input the device name in
the filter field for search.
Select device from the list, click Modify/Delete, and then you can modify/delete the information of
the selected device.
Select device from the list, click Remote Config, and then you can do some remote configurations of
the selected device if needed.
Importing Devices to Groups
Purpose:
After the devices added successfully, you can import the devices into groups for a convenient
management.
Steps:
1.
Open the Device Management page.
2.
Click the Group tab to enter the Group Management interface.
3.
Click Add Group to open the Add Group dialog box.
4.
Input the group name and click OK to create a new group.
5.
Click Import to enter the Import Device interface.
6.
Select the encoding channels from the device list and then select a group from the group list.
7.
Click Import Select to import the selected encoding channels to the group.
You can also click Import All to import all the encoding channels to a selected group.
137
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Click Add, and you can add a new group to the group list.
Click Modify after selecting a group/camera, and you can modify the group/camera information.
Click Delete after selecting a group/camera, and you can remove all cameras/the selected camera
from the group.
To delete a group, select the group from the list on the Group Management interface and click the
Delete Group button
13.3 Live View
Purpose:
On the Live View page, you can view the live video of the added cameras and do some basic
operations, including picture capturing, recording, PTZ control, etc.
Before you start:
A camera group is required to be defined for live view.
Click the Live View tab to open the Live View page.
138
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Starting Live View
Steps:
1.
Open the Live View page.
2.
3.
Optionally, click the
icon in the live view toolbar, and select the screen layout mode.
Click-and-drag the camera to the display window,
or double-click the camera name after selecting the display window to start the live view.
Live View Toolbar:
On the Live View page, the following toolbar buttons are available:
Set View
Set the screen layout mode. 4 types of screen layout modes are
selectable: 1-Screen, 4-Screen, 9-Screen and 16-Screen.
Stop/Start Live View
Stop/Start the live view of all cameras.
Capture
Capture the picture in the live view process.
Start/Stop Recording
Start/Stop the manual recording. The record file is stored in the PC.
Previous
Go for live view of the previous page.
Next
Go for live view of the next page.
Mute/Audio On
Turn off/on the audio in live view
Digital Zoom
Enable/Disable the digital zoom function.
Full Screen
Display the live view in full screen mode. Press ESC to exit.
PTZ Control Functionality
Purpose:
Cameras with the pan/tilt/zoom functionality can be controlled through the web browser. You can also
set the preset, patrol and pattern for the cameras.
Click the
icon to expand the PTZ Control panel on the Live View page.
139
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Configuring the Preset
Perform the following steps to add a preset:
1.
Click the Preset button to enter the PTZ preset configuration panel.
2.
Click the direction buttons to steer the camera to the desired view.
3.
Select a PTZ preset number from the preset list and click the icon
.
To call a configured preset, select the preset from the list and click the icon
To delete a configured preset, select the preset from the list and click the icon
.
.
Configuring the Pattern
1.
Click the Pattern button to enter the PTZ pattern configuration panel.
2.
3.
Click
to start recording of this pattern path.
Use the direction buttons to control the PTZ movement.
4.
Click
to stop and save the pattern recording.
5. Click the icon
to call the pattern. To stop calling the pattern, click
.
Note: Only one pattern can be configured, and the newly-defined pattern will overwrite the previous
140
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
pattern.
Configuring the Patrol
Before you start:
Two or more presets for one camera need to be added.
Perform the following steps to add and call a patrol:
1.
Click the Patrol button to enter the PTZ patrol configuration panel.
2.
Select a track number from the drop-down list.
3.
4.
Click
to add a preset, and set the dwell time and patrol speed for the preset.
Repeat the above operation to add other presets to the patrol.
5.
Optionally, you can click
6. Click the icon
Notes:
or
to edit or delete the preset in the patrol path.
to call the patrol. To stop calling the patrol, click
.

Up to 16 patrols can be configured.

The preset dwell time can be set to 1~255 sec, and the patrol speed can be set to level 1~40.
141
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Video Settings Functionality
Purpose:
The video parameters, including the brightness, contrast, saturation and hue, can be configured to
create better visual effects.
Steps:
1.
2.
Click the
icon to expand the Video Settings panel on the Live View page.
Move the slider to adjust the brightness, contrast, saturation or hue of the live video.
3.
Click Default Value, and you can restore the defaults of the video parameters.
13.4 Playback
Purpose:
The record files stored on the storage devices such as the HDDs, Net HDDs and SD/SDHC cards on the
local device can be searched and played back remotely through the web browser.
Click the Playback tab to open the Playback page.
Playback Toolbar:
On the Playback page, the following toolbar buttons are available:
Set View
Set the screen layout mode. 4 types of screen layout modes are
142
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
selectable: 1-Screen, 4-Screen, 9-Screen and 16-Screen.
Stop/Start Playback
Stop/Start the playback of all channels.
Capture
Capture the picture in the playback process.
Start/Stop Clipping
Start/Stop clipping the record files.
Mute/Audio On
Turn off/on the audio in playback.
Full Screen
Display the playback in full screen mode. Press ESC to exit.
Searching Record Files
Steps:
1.
Open the Playback page.
2.
Select the cameras to be searched from the list.
3.
4.
Click the icon
to specify the start time and end time for the search.
Click Search. The record files of the selected cameras will be displayed on the Search Result tab
page.
Notes:

You can also search the record files by the card number (only applicable to ATM DVR) or by the
file type.

Up to 16 cameras can be searched simultaneously.
Playing Back Record Files
After searching the record files, you can play back the record files in the following two ways:

Playback by File List
Select the record file from the search result list, and then click the icon
the display window of playback.
to play the video on
143
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200

Playback by Timeline
The timeline indicates the time duration for the record file. Click on the timeline to play back the
video of the specific time.
You can click
or
to scale up or scale down the timeline bar.
You can use the mouse wheel to zoom in or zoom out on the timeline.
Move the mouse pointer to the display window in playback to show the toolbar.
Toolbar in Each Playback Display Window:
In each playback display window, the following toolbar buttons are available:
Pause/Start Playback
Pause/Start the playback of the record files.
Stop Playback
Stop the playback of all cameras.
Speed Down
Decrease the playback speed of the record files.
Speed Up
Increase the playback speed of the record files.
Single Frame
Play back the record files frame by frame.
Download
Download the record file for backup.
144
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
13.5 Account Management
Purpose:
Different user accounts can be added for the client through the web browser and you can also assign
permissions for the added users. The user you registered is set as the super administrator.
Click the Account Management tab to open the Account Management page.
Adding the User
Steps:
1.
Open the Account Management page.
2.
Click Add to open the Add User dialog box.
3.
Select the user type. You can set the user type as Administrator or Operator.
4.
Input the user name, password and confirm password as desired.
5.
Check the checkboxes to assign the permissions for the created user.
6.
Optionally, you can click Default Permission to restore the default permissions of this user.
7.
Click Save to save the settings.
Notes:

A user name cannot contain any of the following characters: / \ : * ? “ < > |. And the length of the
password cannot be less than 6 characters.

Up to 50 user accounts can be added for the client software.
145
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Managing the User
Purpose:
The newly created user account is added to the user list. You can edit or delete the information of the
user accounts.
To edit the information of the user, select the user from the user list, and click Modify.
To delete the information of the user, select the user from the user list, and click Delete.
13.6 System Configuration
Purpose:
The general parameters, including network performance, play performance and saving paths of files
can be configured through the web browser.
Click the System Configuration tab to open the System Configuration page.
Steps:
1.
Open the System Configuration page.
2.
Set the network performance and play performance. Click the icon
path for the files. For details, see Table 10.1 System Parameters.
3.
Optionally, you can click Default Value to restore the defaults of all system parameters.
4.
Click Save to save the settings.
to select a local saving
Table 10.1 System Parameters
Parameters
Network Performance
Play Performance
Saving Path of Video
Descriptions
The current network conditions. It can be set as Normal, Better or Best.
The play performance of the live video. It can be set as Shortest Delay, Real
Time, Balanced or Fluency.
The saving path of video files recorded by manual recording.
Files
Saving Path of Pictures
Saving Path of
The saving path of the captured pictures in live view or playback.
The saving path of the system configuration files.
Configuration File
146
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
Troubleshooting
Live View
Problem:

Failed to get the live view of a certain device.
Possible Reasons:
 Unstable network or the network performance is not good enough.
 The device is offline.
 Too many accesses to the remote device cause the load of the device too high.
 The current user has no permission for live view.
 The version of the client software is below the needed version.
Solutions:





Check network status and disable other not in use process on your PC.
Check the device network status.
Restart the device or disable other remote access to the device.
Log in with the admin user and try again.
Download the client software of the latest version.
Recording
Problem:

Local recording and remote recording are confused.
Solutions:

The local recording in this manual refers to the recording which stores the record files on the
HDDs, SD/SDHC cards of the local device.

The remote recording refers to the recording action commanded by the client on the remote
device side.
Playback
Problem:

Failed to download the record files or the downloading speed is too slow.
Possible Reasons:
 Unstable network or the network performance is not good enough.
 The NIC type is not compatible.
 Too many accesses to the remote device
 The current user has no permission for playback.
 The version of the client software is below the needed version.
Solutions:





Check network status and disable other not in use process on your PC.
Directly connect the PC running the client to device to check the compatibility of the NIC card.
Restart the device or disable other remote access to the device.
Log in with the admin user and try again.
Download the client software of the latest version.
0202001040529
147
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
User Manual of iVMS-4200
148
Lo-Call 1890 866 900
www.cctvireland.ie
[email protected]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
