Advanced User`s Manual

Advanced User`s Manual

Version 5.5

Advanced User's Manual

Moving expertise - not people

Copyright © 1981-2008 Danware Data A/S. All Rights Reserved.

Portions used under license from third parties.

Document Revision: 2008037

Please send any comments to:

Danware Data A/S

Bregnerodvej 127

DK-3460 Birkerod

Denmark

Fax: Int +45 45 90 25 26

E-mail: [email protected]

Internet: http://www.netop.com

2

Warranty

Danware Data A/S warrants the quality of the physical material of the user package, that is manual and

CD-ROM. If these items are defective, we will exchange them at no cost within 60 days of purchase from

Danware Data.

Disclaimer

Danware Data A/S denies any and all responsibility for damages caused directly or indirectly as a result of any faults with the enclosed programs and/or documentation.

License

Danware Data A/S retains the copyright to the user manual. All patent, copyright and other proprietary rights in and to the programs will remain with Danware Data A/S or its licensers.

Your purchase gives you the right to copy and use the programs as described on your Danware License

Certificate included in your package.

Please save your Danware License Certificate and your original CD-ROM. They serve as your legal right to use the software. You may also need them in order to receive future updates to the product.

Please be careful not to install or run the software on more PCs than your Danware License Certificates permits you to do.

The programs may be copied for backup purposes only, and only as long as the above mentioned rules are adhered to.

Trademarks

NetOp® and the red kite are registered trademarks of Danware Data A/S. All other products mentioned in this manual are trademarks of their respective manufacturers.

3

Contents

Contents

4

Contents

5

Contents

6

Contents

7

Contents

8

Introduction

1 Introduction

The basic NetOp School user documentation consists of the Teaching with NetOp School startup guide, the NetOp Teacher Help and NetOp Student Help on-line help systems and the NetOp Teacher User's

Manual and NetOp Student User's Manual.

This NetOp School advanced user’s manual provides technical guidance to the advanced user or administrator. Being intended for technical specialists that are assumed to understand English, it is available only in English.

It contains these main sections:

·

Installation

·

NetOp Teacher

·

NetOp Student

·

Common tools

·

Advanced tools

9

Installation

2 Installation

The basic NetOp School user documentation covers interactive installation very briefly by recommending users to follow the installation on-line instructions.

This section covers in details interactive installation and the installation or update of

NetOp Student

on remote network computers in these sections:

·

Interactive Installation

·

Student Deployment

2.1 Interactive Installation

You can install the NetOp School modules

NetOp Teacher

and

NetOp Student

interactively from these

installation files:

· NetOpSchoolTeacher_<Language abbreviation>.msi

· NetOpSchoolStudent_<Language abbreviation>.msi

They are available for download from the NetOp

KnowledgeBase

, click Download products > NetOp School.

On the computer on which you want to install the module, run the installation file to show this window:

Click Next to show this window:

10

Read the license agreement and click one of the options:

¡ I accept the terms in the license agreement: Will enable the Next button.

¤ I do not accept the terms in the license agreement: Will leave the Next button disabled.

Until executing the installation, click Back to return to the previous window to change selections.

Click Next to show this window:

Installation

11

Installation

User name []: May retrieve the user name from Windows or from a license.dat file in the installation file directory. Specifying a user name is optional.

Organization []: May retrieve the organization name from Windows. Specifying an organization name is optional.

License number []: May retrieve the license number from a license.dat file in the installation file directory. A valid license number must be specified.

This is an example of a license.dat file:

The LICNAME value is a User name value.

The GSTSNR value is a

NetOp Teacher

License number value.

The HSTSNR value is a

NetOp Student

License number value.

Click Next to show this window:

12

Installation

Click one of these options:

·

Typical: Will install recommended features to show the

Windows firewall configuration

window when

clicking Next.

· Custom: Will enable you to select which features to install to show the

Custom setup

window when

clicking Next.

·

Complete: Will install all available features to show the

Windows firewall configuration

window when clicking Next.

Click Next to continue. If you clicked Custom, this window will be shown:

13

Installation

The pane will show the main feature expanding into available sub-features. This table shows available sub-features on

NetOp Teacher

and

NetOp Student :

Teacher

Sub feature

Assistant teacher

Assistant teacher help system

Web update

Help system

Available on module:

Functionality

Enables

Assistant teacher

Includes

Teacher

Help

with

Assistant teacher

Enables

Web update

Includes module

Help

Student

Click a sub-feature icon to show a menu of options.

Click Reset to restore the original selection.

Click Disk usage to show this window:

14

Installation

The pane will show records of available drives with disk size, available disk space and disk space required by the installation specified in the

Custom setup

window.

Click Browse to show this window:

It shows the selected destination folder name, its contents of folders and its path. You can select another destination folder to specify its path. Click OK to apply.

15

Installation

When satisfied with the specification in the

Custom setup

window, click Next to show this window:

Leave the box checked to modify the Windows firewall configuration to enable NetOp communication. Click

Next to show this window:

Check the box to save the installation msi file in the directory in which the NetOp module is installed to have it available for reinstallation. Click Install to execute installation. When completed, this window will be shown:

16

Leave the box checked to load the installed module. Click Finish to end installation.

Installation

17

Installation

2.1.1 Change or Remove

To change or remove a

NetOp Teacher

or

NetOp Student

installation, click Start > [Settings > ]Control Panel

> Add or Remove Programs.

An installed

NetOp Teacher

will be listed as NetOp School Teacher and an installed

NetOp Student

will be

listed as NetOp School Student.

Click a record to highlight and expand it to show Change and Remove buttons.

Click Change to show this window:

Click Next to show this window:

18

Installation

Click one of these options:

· Modify: Show the

Custom setup

window to modify installed features and the following

Interactive installation

windows to reinstall applying the modified setup. Installation files must be available.

· Repair: Show a Repair window like the

Ready to install

window and the following

Interactive installation

windows to reinstall. Installation files must be available.

· Remove: Show a Remove window like the

Ready to install

window. You can check a box to remove

module configuration files during module removal. The following

Interactive installation

windows will be

shown. Installation files do not need to be available.

In the Add or Remove Programs window, click Remove to remove the module showing a small window.

Installation files do not need to be available.

To remove NetOp completely from the computer, also delete the

NetOp.ini

file from the Windows (WINNT)

directory, remove other NetOp files placed in other directories and remove all NetOp keys from the Windows registry.

2.2 Student Deployment

Student deployment

installs and sets up

NetOp Student

on remote network computers.

Note: To facilitate the administration of student computers in a teaching environment, a uniform setup of

NetOp Student

on computers is typically demanded.

Student deployment

meets this demand.

Student deployment

has some basic requirements:

1. The deploying computer must run on one of the operating systems Windows Vista, XP, 2000 or NT.

2. Computers deployed to must run on one of the operating systems Windows Vista, XP, 2000 or NT.

3. The user logged on to Windows on the deploying computer must have remote installation rights, typically administrator rights, on computers deployed to.

You cannot deploy

NetOp Student

to computers that run on one of the operating systems Windows ME, 98

or 95. However, in NetOp Pack'n Deploy you can generate uniform setup installation files that can be used

19

Installation

for local installation.

This section contains these sections:

·

Deployment wizard

·

Deploy

2.2.1 Deployment Wizard

To start

Student deployment

, in the

NetOp Teacher

window

Tools

menu click

Run student deployment

to

show this window:

Click Next to show this window:

20

Installation

Click Next to show a Windows Open window to open a NetOpSchoolStudent_<Language abbreviation>.msi file to show this window:

Click one of these options:

¤ Simplified: Specify deployed

NetOp Student

module setup in the

NetOp Student

Setup wizard

.

21

Installation

¡ Advanced: Specify deployed

NetOp Student

module setup in the

NetOp Student

Options

window.

¡ Existing: Specify deployed

NetOp Student

module setup by the configuration files of an existing

NetOp

Student

installation.

Note: For Simplified and Advanced to work,

NetOp Student

must be installed on the deploying computer.

Click Next to continue to show one of these alternatives:

·

If Simplified was clicked, the

NetOp Student

Setup wizard

will run in front of a Create configuration files

window. Set up deployed

NetOp Student

modules in the

Setup wizard

. After ending the

Setup wizard

, in

the Create configuration files window click Next to continue.

·

If Advanced was clicked, the

NetOp Student

Options

window will be shown in front of a Create

configuration files window. Specify deployed

NetOp Student

module setup on the

Options

window tabs.

After closing the

Options

window, in the Create configuration files window click Next to continue.

·

If Existing was clicked, a Windows Open window will be shown to enable you to open the

User configuration files

of an existing

NetOp Student

installation. Open a set of

User configuration files

to continue.

When done, this window will be shown:

Click Next to open the NetOp Pack'n Deploy window

Deploy

page and show this window:

22

Click Finish to close the window ending the

Deployment wizard

.

Installation

23

Installation

2.2.2 Deploy

Click the

Deployment wizard

Start NetOp Pack'n Deploy

window Next button to show this window:

It is the

Deploy

page of the NetOp Pack'n Deploy deployment utility. It enables you to deploy configured installation files to install fully set up Netop modules on remote computers. It contains these details:

· Source data path [][Browse]: This disabled field will show the path to the installation file specified in the

Deployment wizard

Select Student installation source

window. You cannot change this selection here.

Deploy to

· Domain []: Click in the drop-down box list an available domain to show its name in the field and after browsing the names of its accessible computers in the Domain computers pane below. Unavailable computer names will show a icon. Available computer names will show a icon. To select computers to deploy to, click available computer names to show a icon. Click ¤ All or ¡ Selected to show all or only selected computer names in the pane. The two remaining options ¡ Success and ¡ Failed will be available after deployment.

· Computer list [] [Save] [Browse]: To save a computer selection, click [Save] to save the selection in a text file. To apply a saved computer selection, click [Browse] to select a text file to show its path in the field and mark available computer names in the pane that belong to the selection with a icon.

Credentials

· User name: Installing NetOp modules on remote computers will require administrator rights. Specify the name by which the user that installs on remote computers shall be identified.

24

Installation

·

Password: Specify the password by which the user that installs on remote computers shall be identified.

Optional

· License key []: If the directory in which the installation file resides contains a

license.dat

file with a

NetOp

Student

license number, this license number will be specified. The field must contain a valid

NetOp

Student

license number.

· Log path []: Deployment to each remote computer will on the deploying computer create a local log file named <Remote computer name>.log and if successfully connected to the remote computer a remote log file named <Remote computer name>.rlg. These plain text log files will tell what went wrong in a failed deployment. You can specify the folder in which these log files shall be saved. .\log means a DeployLog folder under the

NetOp Teacher

User configuration files

folder.

· Restart []: Click one of the options Never, If needed or Always to make the remote computer do that after installation.

· MSI parameters []: To apply selected Windows Installer parameters to installations on remote computers, specify them in this field. To view available Windows Installer parameters, from a command prompt specify msiexec. The special NetOp parameter DW_FORCE_LAUNCH=1 will force

NetOp Student

to load

after being deployed.

Deploy

To execute deployment, click Deploy.

Progress will be indicated by these icons replacing pane icons:

: Deploying installation files to the remote computer.

: Remote computer access failed. Read the <Remote computer name>.log file contents to identify what went wrong.

: Installing on the remote computer.

: Remote installation was successful.

: Remote installation failed. Read the <Remote computer name>.rlg file contents to identify what went wrong.

25

NetOp Teacher

3 NetOp Teacher

This section explains

Teacher

properties in these sections:

·

Load and unload Teacher

·

Teacher window

·

NetOp screen image

·

NetOp screen video

3.1 Load and Unload Teacher

To load the

Teacher

, click Start > All programs > NetOp School > Teacher or use one of the available

Loading alternatives

.

If you load the

Teacher

for the first time, the

Setup wizard

will run in front of the

Teacher

window.

If you have loaded the

Teacher

before, the

Teacher

window will be shown.

To unload the

Teacher

, in the

Teacher

window click the window control Close button, click the matching

window control command or

File

menu

Exit

command or press ALT+F4.

3.1.1 Loading Alternatives

These

Teacher

loading alternatives are available:

1. In the directory where the

Teacher

was installed, typically C:\Program Files\Danware Data\NetOp

School\Teacher, double-click ntchw32.exe.

2. Create a desktop shortcut to the

Teacher

program file ntchw32.exe. Double-click this shortcut.

3. From a Windows Run or Command prompt window, execute the

Teacher

program file ntchw32.exe.

To load the

Teacher

from another application, use a command that you can expand with a switch that

specifies the

Class

that shall be running on the

Teacher

when loaded.

The command syntax is:

<Path>ntchw32 [/N:<Class name>]

If the

Class

name contains spaces, it must be enclosed within quotation marks.

Example

To load a default directory installed

Teacher

to run the

Class

Dr. Nelson, use this command:

C:\Program Files\Danware Data\NetOp School\Teacher\ntchw32 /N:"Dr. Nelson"

26

NetOp Teacher

3.1.2 Setup Wizard

When a specific user loads the

Teacher

for the first time or if in the

Teacher

window you click the

Tools

menu

Run setup wizard

command, this window will be shown in front of the

Teacher

window:

The

Setup wizard

will guide you through initial

Teacher

setup.

Click Next to show this window:

27

NetOp Teacher

It enables you to specify the initial

Class

name and features selection in these elements:

Note: You can change all

Setup wizard

specifications from the

Teacher

window at any time.

Class name []: When the Teacher is newly installed, My class will be specified. You can edit the initial

Class

name in the field.

Features: Click one of these options:

¡ Simplified - Demonstrate, Attention, Control, Policy: Will enable only the

Demonstrate

,

Attention

,

Control

and

Policy

actions that for many

Teacher

users are the only ones ever used.

¤ Standard - full feature set: Will enable all available actions.

¡ Customized - your own selection: Will enable the Customize button below. Click it to show the

Options

window

Menu/Toolbar

tab for your own selection of enabled actions.

Click Next to show this window:

28

NetOp Teacher

It enables you to select which name type shall identify

Students

in the

Teacher

window. Click one of these

options:

¤ Student login name: The name type selected on the

Student

Options

window

Student login

tab.

¡ Windows login name: The

Student

computer user Windows login name.

¡ Computer name: The

Student

computer name.

Click Next to show this window:

29

NetOp Teacher

It selects a

Communication profile

and optionally specifies the use of

NetOp name management

in these elements:

·

Communication profile []: Click in the drop-down box the

Communication profile

by which the

Teacher

shall

communicate.

NetOp Name Server

o Use NetOp Name Server: Will be enabled if a

Communication profile

that uses the

TCP/IP

Communication device

is clicked in the Communication profile drop-down box above. Check the box to enable the use of

NetOp name management

and the fields below.

·

Primary []: Specify the primary

NetOp Name Server

address.

· Secondary []: Specify the secondary

NetOp Name Server

address.

· Name space ID []: Specify the

Name space ID

used by the

Students

with which you shall communicate.

Click Next to show this window:

30

NetOp Teacher

We recommend that you leave the default Yes, I want to register my NetOp license on-line selection unless you or somebody else in your organization has already registered or will register the license.

Click Next to connect to register or show this window:

Click Finish to close the window to end the

Setup wizard

.

31

3.2 Teacher Window

This is the

Teacher

window:

NetOp Teacher

It contains these sections:

·

Title bar

·

Menu bar

·

Toolbar

·

Class control panel

·

Status bar

3.2.1 Title Bar

This is the

Teacher

window title bar:

Click the left

Teacher

button or right-click anywhere in the title bar to show a standard window control menu.

Typically, the running

Class

name will be shown next to the NetOp Teacher window name. If

Teacher profiles

are implemented, the

Teacher profile

User name

of the user logged in to the

Teacher

will be shown instead

of the

Class

name.

3.2.2 Menu Bar

This is the

Teacher

window menu bar:

It contains these menus:

32

NetOp Teacher

·

File

·

Action

·

Tools

·

<Selected view>

·

Help

3.2.2.1 File Menu

This is the

Teacher

window File menu:

It contains this command:

·

Exit: Click this command, press ALT+F4, click the

Title bar

window control menu Close command, click the

Title bar

Close button or double-click the left

Title bar

button to unload the

Teacher

closing the

Teacher

window.

3.2.2.2 Action Menu

This is the

Teacher

window

Action

menu:

It can contain these commands that match

Toolbar

buttons:

·

Demonstrate: Click to show selected contents on selected

Student

computer screens as explained in the

Demonstrate

section.

·

Attention: Click to cover selected

Student

computer screens with a selected image to get users' attention

as explained in the

Attention

section.

·

Control: Click to execute a selected type of control with selected

Student

computers as explained in the

Control

section.

· Communicate: Expands into these commands:

· Audio-video chat: Click to start an

Audio-video chat

session with selected

Student

computer users as

explained in the

Audio-video chat

section.

· Chat: Click to start a

Chat

session with selected

Student

computer users as explained in the

Chat

section.

·

Send message: Click to send a

NetOp message

to selected

Student

computer users as explained in the

Send message

section.

· Workgroup: Click to create a

Workgroup

from selected

Students

as explained in the

Workgroup

section.

33

NetOp Teacher

·

Run test: ???Click to run a selected test on selected

Student

computers as explained in the

Run test

section.

· Run program: ???Click to run a selected program on selected

Student

computers as explained in the

Run

section.

· Commands: Expands into these commands:

· Log off: Click to log off users from Windows on selected

Student

computers.

·

Restart: Click to restart selected

Student

computers.

· Shut down: Click to shut down selected

Student

computers.

· Rejoin: Click to make selected

Student

Leave class

and

Join class

.

· Files: Expands into these commands:

·

Distribute files: Click to distribute selected files to selected

Student

computers as explained in the

Distribute files

section.

·

Collect files: Click to collect selected files from selected

Student

computers as explained in the

Collect files

section.

· File Manager: Click to manage and exchange files with selected

Student

computers as explained in the

File manager

section.

·

Policy: Click to apply a selected

Policy

to selected

Student

computers as explained in the

Policy

section.

·

Record: Click to start recording a

Teacher

computer screen movie as explained in the

Record

section.

3.2.2.3 Tools Menu

This is the

Teacher

window

Tools

menu:

It contains these commands:

·

Options: Click to show the

Options

window.

·

Options as icons: Will be included if the

Options

window tabs version is enabled. Click to enable the

Options

window icons version.

·

Protection password: Click to show the

Options

window

Protection

tab.

· Log off: Will be included if

Teacher profiles

are implemented. Click to log off from the

Teacher .

·

Ask class server: Will be enabled if the

Options

window

Class

tab

Use class server

box is checked. Click

to ask

Class server

for the current or upcoming

Class

.

·

Reannounce class: Will be enabled if the

Options

window

Class

tab

Use class server

box is unchecked.

34

NetOp Teacher

Click to send an

Announcement

of the running

Class

.

· Run student deployment: Click to run the

Deployment wizard

to install and set up

NetOp Student

on remote computers.

·

Check for new updates: Click to check for updates to the current

Teacher

installation according to the

Options

window

Web update

tab.

· Publish new updates: Click to show a Windows Browse for folder window to select a folder to upload downloaded

Web update

installation files to it.

· Run setup wizard: Click to run the

Teacher

Setup wizard

.

· Copy teacher to removable media: Click to show a Windows Browse for folder window to select a removable media folder, e.g. a USB key folder, to copy your entire

Teacher

installation to it to take it to another computer or keep it as backup.

· Import teacher data: Click to show this window:

It enables you to import

Teacher

data from removable media to your computer. Check the categories of

Teacher

data that you want to import and click OK to show the Browse for folder window to select the removable media folder from which to import

Teacher

data. Imported files will overwrite resident files with

the same name.

· Debug trace: To include this command, press ALT+Z while showing the

About NetOp School Teacher

window. Click to save a log of recent

Teacher

communication, which will assist NetOp professionals in

diagnosing communication problems. The debug trace is a plain text file. Interpreting its contents requires special NetOp skills.

35

NetOp Teacher

3.2.2.4 Selected View Menu

This menu will be named by the

Teacher

window

Class control panel

selected view and will contain

commands that execute actions in the selected view:

The Details view menu shown above matches the

Details view

Student context menu

.

Similarly, other selected view menus will contain the same commands as the view's context menus.

Menu contents will be explained in the respective view sections.

3.2.2.5 Help Menu

This is the

Teacher

window Help menu:

It contains these commands:

· Contents: Click to open the NetOp Teacher Help window that has a graphical table of contents in its left pane.

·

Online support: Click to open the Support for NetOp School web page to request technical support.

· Apply license/Online registration: Will be Apply license if a trial version is installed and Online registration if a licensed version is installed.

· Apply license: Click to show this window:

36

NetOp Teacher

Specify your licensee name and your

Teacher

license number and click OK to replace the trial version

licensee name and license number by the specified licensee name and license number.

· Online registration: Click to open the NetOp product registration web page to register your license with the NetOp manufacturer.

· About: Click to show this window:

It contains information on your

Teacher

installation. The build number in format YYYYDDD (Y=year

number digit, D=day number digit) is enclosed in parentheses next to the version number.

· System info: Click to show the

System info

window.

3.2.3 Toolbar

This is the

Teacher

window toolbar:

It contains buttons by which the

Teacher

user can execute actions, typically on selected

Students

. The full

37

NetOp Teacher

range includes these buttons:

·

Demonstrate

·

Attention

·

Control

·

Communicate

·

Workgroup

·

Run

·

Commands

·

Files

·

Policy

·

Record

Right-click in the tool bar to show this menu:

It contains these commands:

Show text labels: Click to hide or show button text labels hiding or showing the command check mark.

Customize: Click to show the Windows Customize toolbar window to customize the toolbar appearance.

Selection: Expands into these commands:

Select All: Click to select all connected

Students

in the

Class control panel

.

Deselect All: Click to deselect all

Students

in the

Class control panel

.

<Student groups>: Click a

Student group

to select connected

Students

in the selected

Student group

.

38

3.2.3.1 Demonstrate

This is the

Teacher

window

Toolbar

Demonstrate

button and menu:

NetOp Teacher

Demonstrate

enables showing selected contents on selected

Student

computers.

To start a

Demonstrate

session, select

Students

and click the

Action

menu

Demonstrate

command or click

the

Demonstrate

button for the default session or click a

Demonstrate

menu command for a custom session.

The

Demonstrate

menu that will open from the

Demonstrate

button down pointer button or from the

Student group context menu

Demo to this group

command contains these commands:

·

Entire desktop

·

Selected desktop area

·

Media file

·

Media file on the web

·

Recording

·

Specific monitor

·

Student desktop

·

Options

The default session command that is selected in the

Demonstrate

menu

Options

command

Demonstrate

window

Default button action

drop-down box will be enclosed by asterisks.

Note: You can demonstrate running a program on the

Teacher

computer from a

Toolbar

Run

button menu

program command

Demo

command.

During a

Demonstrate

session,

Details view

participating

Student

records will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

During a

Demonstrate

session, the

Demonstrate

button will appear pressed in and the

Action

menu

Demonstrate

command will be check marked.

Click the pressed in

Demonstrate

button or check marked

Demonstrate

command to end the

Demonstrate

session.

You can specify general

Demonstrate

properties on the

Tools

menu

Options

command/window

Demonstrate

tab.

39

NetOp Teacher

3.2.3.1.1 Entire Desktop

To

Demonstrate

the Teacher computer entire desktop, select

Students

and click this

Demonstrate

menu

command:

This will show the

Teacher

computer entire desktop or a scrolling section of it on selected

Student

computer

screens.

Note: If the

Teacher

computer uses multiple monitors, its entire desktop can spread across multiple

monitors.

You can control a screen area

Demonstrate

session from this

Teacher

computer screen toolbox:

It is explained in the

Screen control toolbox

section.

You can enable this toolbox on the screen of

Student

computers that receive a screen image demonstration:

It is explained in the

Student demo toolbox

section.

Screen Control Toolbox

On the

Teacher

computer, you can control a screen area

Demonstrate

session from this Screen control

toolbox:

Its title bar will show the Screen control name and <Teacher> if a Teacher screen is being demonstrated, otherwise the name of the demonstrated screen

Student

. Click the left square button to make the toolbox the

active window. Click the right down pointer button to minimize the toolbox to the Windows taskbar notification area.

It contains these tool tip identified buttons:

End session: Click this button to close the toolbox and end the

Demonstrate

session.

Teacher full screen/window: Will be enabled if a

Student

screen is demonstrated. Click to switch

between showing the

Student

screen in full screen mode or window mode on the

Teacher

. The startup

mode is specified in the

Options

window

Demonstrate

tab

On teacher during student demo

section.

Start/stop sound transfer: Click to start or stop the transfer of microphone input and running application sound from the computer being demonstrated to the computers that receive the demonstration.

Sound transfer

and

Audio-video chat

cannot run at the same time.

Note:

Sound transfer

will typically work smoothly with new computers with integrated sound devices.

On older computers with older sound devices and older operating systems, if

Sound transfer

does not

work, look into recording sound mix setup. NetOp expects to find the recording sound mix name Wave

Out Mix. If only other recording sound mix names are available, add this section to the

NetOp.ini

file:

[AUDIO]

Sound_Mix=<Recording sound mix name>

If the computer sound device does not support recording sound mix,

Sound transfer

will not work.

40

NetOp Teacher

Start/stop audio-video chat: Click to start or stop an

Audio-video chat

session with the

Students

that

take part in the

Demonstrate

session.

Audio-video chat

and

Sound transfer

cannot run at the same

time.

Start/stop NetOp marker utility: Click to start or stop

NetOp marker utility

to create markers or magnify

an area on the demonstrated screen.

Student full screen/window: Click to switch between showing the demonstrated screen in full screen mode or window mode on

Students

that receive demonstration. The startup mode is specified in the

Options

window

Demonstrate

tab

On receiving students

section.

Pass the chalk: Click to assign keyboard and mouse control in the demonstrated screen to a selected

Student

. This functionality is explained in the

Pass the chalk

section.

Student Demo Toolbox

Check the

Teacher

Options

window

Demonstrate

tab

Launch toolbox

box to show on the screen of

Student

computers that receive a demonstration this

Student demo

toolbox:

Its title bar will show the

Student

computer name. Click the left square button to make the toolbox the active window.

It contains these tool tip identified buttons (from left to right):

Request the microphone: Will be enabled if an

Audio-video chat

session is running during a

Demonstrate

session. Click to request the microphone to make the button appear pressed in and

show the request in the

Audio-video chat

window. Click the pressed in button to withdraw the

microphone request and release the button. When a microphone request has been met, the pressed in button will be released.

Request help: Click to

Request help

from the

Teacher

user to make the button appear pressed in.

Click the pressed in button to withdraw the help request and release the button. When a help request has been met, the pressed in button will be released.

Request the chalk: Click to request keyboard and mouse control in the demonstrated screen to make the button appear pressed in. Click the pressed in button to withdraw the chalk request and release the button. When a chalk request has been met, the pressed in button will be released.

41

NetOp Teacher

NetOp Marker Utility

NetOp marker utility

enables you to create figure and text markers on top of a screen image and magnifying

a section of a screen image.

You can load and unload

NetOp marker utility

on the

Teacher

computer from a

Demonstrate

Entire desktop

,

Selected desktop area

or

Specific monitor

session

Screen control toolbox

or

Record

session

Recording toolbox

Start/stop NetOp marker utility

button.

You can load and unload

NetOp marker utility

on a

Student

computer from a

Demonstrate

Student desktop

session

Screen control toolbox

Start/stop NetOp marker utility

button or

Remote control

session

NetOp marker utility

button or command.

Note: The

NetOp marker utility

program vitawrap.exe will run on the local

Teacher

or

Student

computer.

NetOp marker utility

will show this window:

It contains these elements:

·

Title bar

·

Upper toolbar

·

Lower toolbar

·

Status bar

Title Bar

This is the

NetOp marker utility

window title bar:

Click the title bar icon or right-click in the title bar to show this menu:

42

NetOp Teacher

The top section contains window control commands. The other sections contain these types of

NetOp marker utility

commands:

·

Figure marker commands, see

Figure markers

·

Text command, see

Text marker

·

Magnifier command, see

NetOp magnifier

· Undo and Clear all commands, see

Delete markers

· Properties and Help commands, see

Marker properties and help

Click Minimize to minimize the

NetOp marker utility

window into this Windows taskbar notification area button:

Behind the pencil, the most recently enabled marker tool symbol will be shown.

Right-click to show this menu:

43

NetOp Teacher

It contains a Restore command that will restore the

NetOp marker utility

window and the same

NetOp marker utility

commands as the

NetOp marker utility title bar menu

.

Upper Toolbar

This is the

NetOp marker utility

window upper toolbar:

It contains these buttons:

Draw Ellipse: Click to appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Ellipse command to enable the ellipse tool, see

Figure markers

.

Draw Rectangle: Click to appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Rectangle command to enable the rectangle tool, see

Figure markers

.

Draw Arrow: Click to appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Arrow command to enable the arrow tool, see

Figure markers

.

Draw Lines (Stop=MB2): Click to appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Line command to enable the sectioned line tool, see

Figure markers

.

Draw Freehand: Click to appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Freehand command to enable the freehand tool, see

Figure markers

.

Show Free Text: Click to appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Text command to enable the

Text marker

tool.

Show Magnifier: Click to appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Magnifier command to show the

NetOp magnifier

window.

Undo: Click or click the matching

NetOp marker utility title bar menu

or

NetOp marker utility button menu

command to delete the most recently selected marker, see

Delete markers

.

Clear All: Click or click the matching

NetOp marker utility title bar menu

or

NetOp marker utility button menu

command to delete all markers, see

Delete markers

.

44

NetOp Teacher

Lower Toolbar

This is the

NetOp marker utility

window lower toolbar:

It contains these buttons:

Select Font: Click or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Font command to show the Windows Font window to select a

Text marker

font, see

Marker properties and help

.

Select Color: Click or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Color command to show the Windows Color window to select a

Figure marker

color, see

Marker properties and help

.

Select Pen Thickness: Click to show a line width drop-down box or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Line Width command to select a

Figure marker

or

Text marker

frame line width, see

Marker properties and help

.

Help: Click or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Help

command to open the local help system on the

NetOp marker utility

section, see

Marker properties and help

.

Status Bar

This is the

NetOp marker utility

window status bar:

It will show a hint to the mouse pointer position button or highlighted menu command.

Figure Markers

To select a figure marker tool with the mouse, click the

Upper toolbar

figure marker button to make it appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

figure marker

command to change the mouse pointer into a pencil with the figure marker shape.

To enable a figure marker tool from the keyboard, place the mouse pointer on the active

NetOp marker utility

window

Upper toolbar

figure marker button and press F9 to change the mouse pointer into a pencil with the

figure marker shape. Alternatively, while the

NetOp marker utility

window is active press ALT+SPACE to show the

NetOp marker utility title bar menu

and press the figure marker command first character keyboard

key or highlight the figure marker command and press ENTER.

To create a figure marker with the mouse, drag (sectioned line: click). To end a sectioned line, right-click.

To draw a figure marker from the keyboard, move the figure marker with the arrow keys. Press INSERT to engage, move with the arrow keys and press INSERT to disengage or section a line. To end a sectioned line, press F10.

To move a marker or change its appearance, move the mouse pointer to it to show an arrow-pointed +.

To move, drag or press INSERT to engage, move with the arrow keys and press INSERT to disengage.

To change appearance, right-click or press F10 to show this menu:

45

NetOp Teacher

Color: Click or click the marker and click the

Lower toolbar Select color

button to show the Windows Color window to change the marker color selection (default: Red).

Line Width: Click to expand into a selection of numbers of pixels or click the marker and click the

Lower toolbar Select pen thickness

button to show a drop-down box with a selection of line widths to change the

marker line width selection.

Undo: Click click the marker and click the

Upper toolbar Undo

button to delete the selected marker.

Clear All: Click or click the marker and click the

Upper toolbar Clear All

button to to delete all markers.

Click outside the menu or press F10 to close the menu.

To change figure marker tool properties, right-click or press F10 to show this menu:

This menu is similar to the

Figure marker menu

but has Unselect instead of Undo.

Unselect: Click, press ESCAPE, click the

Upper toolbar

pressed in figure marker button to release it or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

figure marker command to unselect the figure marker tool to restore the normal mouse pointer.

Note: Selecting another marker tool will unselect the selected marker tool.

Text Marker

To select the text marker tool with the mouse, click the

Upper toolbar

the

Show free text

button to make it

appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Text

command to change the mouse pointer into an angle that indicates a text marker box corner.

To select the text marker tool from the keyboard, place the mouse pointer on the active

NetOp marker utility

window

Upper toolbar Show free text

button and press F9 to make the button appear pressed in and change

the mouse pointer into an angle that indicates a text marker box corner. Alternatively, while the

NetOp marker utility

window is active press ALT+SPACE to show the

NetOp marker utility title bar menu

and press the T key or highlight the Text command and press ENTER.

To unselect the text marker tool, press ESCAPE or use one of the selection procedures explained above to release the

Show free text

button and restore the normal mouse pointer.

Note: Selecting another marker tool will unselect the selected marker tool.

When the text marker tool is selected:

· To create a text marker with the mouse, drag a dotted rectangle to show the

Text marker

window.

46

NetOp Teacher

·

To create a text marker from the keyboard, move the text marker tool with the arrow keys. Press INSERT to engage, move with the arrow keys to create a dotted rectangle and press INSERT to disengage to show this window:

This window specifies the text marker contents and appearance.

In the pane, specify the text marker text. Right-click to show an edit menu.

Use frame: []: The field of this drop-down box will by default show No to show no frame around the text marker. The drop-down box list contains No and a selection of frame line widths. Select an option in the list to show it in the field.

Font: Click to show the Windows Font window to change the text marker font and color selection.

OK: Click to close the

Text marker

window to show the text marker.

To move a marker or change its appearance, move the mouse pointer to it to show an arrow-pointed +.

To move, drag or press INSERT to engage, move with the arrow keys and press INSERT to disengage.

To change appearance, right-click or press F10 to show this menu:

This menu is similar to the

Figure marker menu

but has Font instead of Color.

Font: Click to show the Windows Font window to change the text marker font and color selection.

Note: This menu will include a Line width command only if a framed text marker is selected.

47

NetOp Teacher

NetOp Magnifier

To show the

NetOp magnifier

window with the mouse, click the

Upper toolbar Show magnifier

button to make

it appear pressed in or click the

NetOp marker utility title bar menu

or

NetOp marker utility button menu

Magnifier command.

To show the

NetOp magnifier

window from the keyboard, place the mouse pointer on the active

NetOp marker utility

window

Upper toolbar Show magnifier

button and press F9 to make the button appear pressed

in. Alternatively, while the

NetOp marker utility

window is active press ALT+SPACE to show the

NetOp marker utility title bar menu

and press M or highlight the Magnifier command and press ENTER.

If the mouse pointer is outside this window, the window pane will show a magnified image of the mouse pointer surroundings.

To move the window, drag its title bar or place the mouse pointer in the title bar, press INSERT to engage, move with the arrow keys and press INSERT to disengage.

To resize the window, drag its sides or corners or position the mouse pointer on a side or corner to show a double arrow, press INSERT to engage, move with the arrow keys and press INSERT to disengage.

To change the pane image magnification, drag the right side scroll bar button or place the mouse pointer above or below it and press F9. Its top position will show a 1:1 scale image.

Right-click in the window or place the mouse pointer in the window and press F10 to show this menu:

Close: Click or click the

NetOp marker utility

window

Upper toolbar Show magnifier

button appearing pressed in to release it to close the

NetOp magnifier

window.

Copy Ctrl+C: Click or press CTRL+C to copy the pane contents to the clipboard.

Refresh F5: The pane image will refresh when the mouse pointer is moved but by default not refresh if the mouse pointer is not moved. Click or press F5 to refresh the pane image.

Refresh rate: Click to show this window:

48

NetOp Teacher

¨ Enable refresh timer: Check to refresh the pane image if the mouse pointer is not moved.

Interval (tenths of seconds): []: Specify a number to refresh at the specified interval.

Delete Markers

To delete markers, click one of these

Upper toolbar

buttons or click the matching

NetOp marker utility title bar menu

or

NetOp marker utility button menu

command:

Undo: Delete the most recently selected marker.

Clear All: Delete all markers.

Note: When

NetOp marker utility

is unloaded, all markers and any

NetOp magnifier

window will disappear.

Marker Properties and Help

Specify marker properties and show help from the

Lower toolbar

buttons or matching

NetOp marker utility title bar menu

or

NetOp marker utility button menu

commands:

(Select) Font: Click this button or click this command to show the Windows Font window to select a

Text marker

font and color.

(Select) Color: Click this button or click this command to show the Windows Color window to select a

Figure marker

color.

Select pen thickness/Line width: Click this button to show a line width drop-down box or click this command

to expand it into a selection of numbers of pixels to select a

Figure marker

or

Text marker

frame line width.

Help: Click this button or click this command to open the local help system on the

NetOp marker utility

topic.

Pass the Chalk

This is the

Demonstrate

Screen control

toolbox

Pass the chalk

button:

It enables the

Teacher

user to pass the chalk, i.e. assign keyboard and mouse control of a demonstrated

screen, to a

Student

user, pass the chalk on to another

Student

user and take it back.

If the

Student demo

toolbox is shown on

Students

that receive a demonstration,

Student

users can click the

Request the chalk

button to request the chalk. In the

Teacher

Demonstrate

Screen control

toolbox, the

Pass the chalk

button will get a raised hand like the

Request the chalk

button if any chalk request is pending:

Click the

Pass the chalk

button to show a list of the

Students

that receive the demonstration.

Students

with a

check mark have requested the chalk. Select any shown

Student

to pass the chalk to the selected

Student

closing the list. Click outside the list to close it without passing the chalk.

While a

Student

has the chalk, the

Pass the chalk

button will appear pressed in. The

Student

user with the

chalk and the

Teacher

user both have keyboard and mouse control in the demonstrated screen. If a

Student

desktop is demonstrated, also the demonstrated

Student

user has keyboard and mouse control in the

demonstrated screen.

Two, possibly three, users moving the

Teacher

mouse pointer at the same time can make it difficult for the

Teacher

user to execute desired mouse actions. The

Teacher

user can suppress

Student

keyboard and

49

NetOp Teacher

mouse input to the

Teacher

screen by holding down the CTRL key to execute desired mouse actions

undisturbed.

Note: Any keyboard or mouse action by the

Student

user with the chalk while the

Teacher

user holds down the CTRL key will return the chalk to the

Teacher

and release the

Pass the chalk

button.

Click the pressed in

Pass the chalk

button to show the list of

Students

that receive a demonstration. The

Student

with the chalk will be marked with asterisks. Click the asterisk-marked

Student

to take the chalk back and close the list. Click another

Student

to pass the chalk to the selected

Student

and close the list.

Click outside the list to leave the chalk where it is and close the list.

3.2.3.1.2 Selected Desktop Area

To

Demonstrate

a

Teacher

computer

Selected desktop area

, specify it in this

Demonstrate

window section:

Click Area to show a red frame window on your desktop. Drag its title bar and sides to enclose the area you want to demonstrate and click OK to apply.

Select

Students

and click this

Demonstrate

menu command:

This will show the

Teacher

computer

Selected desktop area

or a scrolling section of it on selected

Student

computer screens.

You can control a screen area

Demonstrate

session from this

Teacher

computer screen toolbox:

It is explained in the

Screen control toolbox

section.

You can enable this toolbox on the screen of

Student

computers that receive a screen area demonstration:

It is explained in the

Student demo toolbox

section.

3.2.3.1.3 Media File

To

Demonstrate

a

Media file

, specify its path in this

Demonstrate

window section:

Click Browse to select an avi, mpg, mpeg or wmv

Media file

to specify its path in the drop-down box field. The

drop-down box list will contain the paths of previously specified

Media files

.

Select

Students

and in the

Demonstrate

menu click

Media file

to expand into the names of

Media files

specified in the

Demonstrate options

window

Media file

section:

Click a

Media file

name to

Prepare media file

. When ready, the

Teacher

user can

Play media file

.

50

NetOp Teacher

Prepare Media File

When a

Media file

Demonstrate

session is started, it will first be checked that the specified

Media file

is

available on the

Teacher

computer. If not, the session will end with an error message.

Then, the

Teacher

will request selected

Students

to prepare for running the specified

Media file

showing this window:

Its pane will show selected

Student

records with a status message.

If

Students

report that the

Media file

is unavailable, the

Teacher

will attempt to distribute it to them.

If all selected

Students

become ready to run the

Media file

, the window will close.

If some selected

Students

cannot become ready to run the

Media file

, the window will remain. You will have

these options:

· Continue: Click to close the window to play the

Media file

only on the

Teacher

and

Students

that are ready.

· Cancel: Click to close the window to cancel the

Media file

Demonstrate

session.

51

NetOp Teacher

Play Media File

When in a

Media file

Demonstrate

session the

Teacher

and selected

Students

are ready, the

Teacher

computer screen will show this media player:

The media pane size will depend on the

Media file

. The media window title bar will show elapsed and in

parentheses total playing time in the format HH:MM:SS. The media pane may or may not show an initial

and/or final image. Depending on the

Teacher

Options

window

Demonstrate

tab settings, selected

Student

computer screens will show the media pane in a window or in full screen display with a black background.

You can control the

Media file

Demonstrate

session from the Media player control toolbox. Click its title bar

square button to make the toolbox the active window. It contains these buttons:

End session: Click to end the

Demonstrate

session to close the

Teacher

media player and selected

Students'

media pane display.

Play: Click to appear pressed in to play the media on the

Teacher

and selected

Students

. Click Pause to pause playing to resume or click Stop to end playing.

Pause: Click to appear pressed in to pause playing the media freezing the image and synchronizing

Student

media playing with

Teacher

media playing. Click Play to resume playing.

Stop: Click to appear pressed in to stop playing the media freezing the image. Click Play to play the media from the start.

Fast backward: Click to jump ten seconds back in the media, if playing or not.

Fast forward: Click to jump ten seconds forward in the media, if playing or not.

Zoom: Click to show 50, 100, 200 and Maximized. Click one to zoom the media pane by the selected percentage or maximize the media pane.

Play list: Click to show the ten most recently specified or demonstrated media files or web media. Click one to replace the currently selected media.

52

NetOp Teacher

3.2.3.1.4 Media File on the Web

To

Demonstrate

a media file that is available on the Internet, specify the media file URL in this

Demonstrate

window section:

The drop-down box list will contain the URLs of previously specified

Media files on the web

.

Select

Students

and in the

Demonstrate

menu click

Media file on the web

to expand into the names of

Media files on the web

specified in the

Demonstrate options

window

Media file on the web

section:

Click a

Media file on the web

name to

Prepare media file

. When ready, the

Teacher

user can

Play media file

.

3.2.3.1.5 Recording

To

Demonstrate

a

Teacher

computer desktop

Recording

, specify its file path in this

Demonstrate

window

section:

Click Browse to select a NetOp

Recording

dwr file to specify its path in the drop-down box field. The drop-down box list will contain the paths of previously specified dwr files.

Select

Students

and in the

Demonstrate

menu click

Recording

to expand into the names of recording files

specified in the

Demonstrate options

window

Recording

section:

Click a

Recording

file name to play the recording in the

Teacher

computer screen

Recording playback

window while demonstrating the

Teacher

computer

Entire desktop

to selected

Students

.

You can control a screen area

Demonstrate

session from this

Teacher

computer screen toolbox:

It is explained in the

Screen control toolbox

section.

You can enable this toolbox on the screen of

Student

computers that receive a screen area demonstration:

It is explained in the

Student demo toolbox

section.

3.2.3.1.6 Specific Monitor

To

Demonstrate

a

Specific monitor

of a

Teacher

computer that uses multiple monitors, select it in this

Demonstrate

window section:

53

NetOp Teacher

Click a monitor in the drop-down box list to show it in the field as selected.

Select

Students

and click this

Demonstrate

menu command:

This will show the

Teacher

computer specific monitor screen area or a scrolling section of it on selected

Student

computer screens.

You can control a screen area

Demonstrate

session from this

Teacher

computer screen toolbox:

It is explained in the

Screen control toolbox

section.

You can enable this toolbox on the screen of

Student

computers that receive a screen area demonstration:

It is explained in the

Student demo toolbox

section.

3.2.3.1.7 Student Desktop

To

Demonstrate

a

Student

computer desktop, select the

Student

whose desktop shall be demonstrated and

the

Students

to whom it shall be demonstrated and in the

Demonstrate

menu click

Student desktop

to expand into a list of the names of selected

Students :

One name may be enclosed by asterisks. That is the

Student

name selected in the

Demonstrate

window

Student desktop

section for a default

Student desktop

Demonstrate

session:

Click in the list any

Student

name to demonstrate the desktop of this

Student

computer to the other

Students

in the list. In fact, the

Teacher

will be running a

Remote control

session with the selected

Student

while

running an

Entire desktop

Demonstrate

session with the other

Students

in the list.

You can also start a

Student desktop

Demonstrate

session from the

Student context menu Demo this student

command.

You can control a screen area

Demonstrate

session from this

Teacher

computer screen toolbox:

It is explained in the

Screen control toolbox

section.

You can enable this toolbox on the screen of

Student

computers that receive a screen area demonstration:

It is explained in the

Student demo toolbox

section.

54

NetOp Teacher

3.2.3.1.8 Options

Click the

Demonstrate

menu

Options

command or click the

Tools

menu

Options

command/window

Demonstrate

tab

Default settings

button to show this window:

It contains these sections:

· Default button action: The drop-down box list contains the names of available

Demonstrate

session types.

Click one to show it in the field to start this type of session when clicking the

Demonstrate

button.

Teacher

·

Selected desktop area: Specifies a selected desktop area as explained in the

Selected desktop area

section.

· Media file: Specifies a media file as explained in the

Media file

section.

· Media file on the web: Specifies a media file on the web as explained in the

Media file on the web

section.

· Recording: Specifies a recording as explained in the

Recording

section.

· Specific monitor: Specifies a specific monitor as explained in the

Specific monitor

section.

Student

· Student desktop: Specifies a

Student

computer desktop as explained in the

Student desktop

section.

55

3.2.3.2 Attention

This is the

Teacher

window

Toolbar

Attention

button and menu:

NetOp Teacher

Attention

will cover selected

Student

computer screens to call

Student

user attention.

To apply

Attention

, select

Students

and click the

Action

menu

Attention

command or click the

Attention

button for the default

Attention

mode or click an

Attention

menu command for a custom

Attention

mode.

You can also apply default mode

Attention

from the

Student context menu Apply attention on this student

command and the

Student group context menu

Apply attention on this group

command.

The

Attention

menu that will open from the

Attention

button down pointer button contains these commands:

· Bitmap: Expands into the names of previously selected bitmap images and Browse. Click a bitmap image name to apply

Attention

showing it. Click Browse to open a bitmap image file to apply

Attention

showing its image.

· Text: Click to apply

Attention

showing a text specified on the

Tools

menu

Options

command/window

Attention

tab.

· Text file: Expands into the names of previously selected text files and Browse. Click a text file name to apply

Attention

showing its contents. Click Browse to open a text file to apply

Attention

showing its

contents.

·

Web: Click to apply

Attention

showing a web page specified on the

Tools

menu

Options

command/window

Attention

tab.

·

Options: Click to show the

Tools

menu

Options

command/window

Attention

tab.

The default

Attention

mode that is selected in the

Options

window

Attention

tab

Show attention

section will be

enclosed by asterisks.

While

Attention

is applied,

Details view

participating

Student

records will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

While

Attention

is applied, the

Attention

button will appear pressed in and the

Action

menu

Attention

command will be check marked. Click the pressed in

Attention

button or check marked

Attention

command

to lift

Attention .

You can specify general

Attention

properties on the

Options

window

Attention

tab.

56

NetOp Teacher

3.2.3.3 Control

This is the

Teacher

window

Toolbar

Control

button and menu:

Control

enables

Remote control

or

Monitoring

of selected

Students

.

To start a

Control

session, select

Students

and click the

Action

menu

Control

command or click the

Control

button for the default

Control

mode or click a

Control

menu command for a custom

Control

mode.

You can also start a

Remote control

session from the

Student context menu Remote control this student

command and start a

Monitor

session from the

Student context menu Monitor this student

command or

Student group context menu

Monitor this group

command.

The

Control

menu that will open from the

Control

button down pointer button contains these commands:

·

Remote control: Click to start a

Remote control

session with a selected

Student

as explained in the

Remote control

section.

·

Monitor students: Click to start a

Monitor

session with selected

Students

as explained in the

Monitor

section.

·

Options: Click to show the

Tools

menu

Options

command/window

Control

tab.

The default

Attention

mode that is selected in the

Options

window

Control

tab

Default control button

section

will be enclosed by asterisks.

During a

Remote control

session, a

Details view

participating

Student

record will show this icon in the

Status

column:

During a

Monitor

session, a

Details view

participating

Student

record will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

During a

Control

session, the

Control

button will appear pressed in and the

Action

menu

Control

command

will be check marked. Click the pressed in

Control

button or check marked

Control

command to end the

Control

session.

You can specify general

Control

properties on the

Options

window

Control

tab.

57

NetOp Teacher

3.2.3.3.1 Remote Control

To start a

Remote control

session with a selected

Student

, click the

Control

menu

Remote control

command,

or if

Remote control

is the default

Control

mode click the

Control

button.

If multiple

Students

are selected, this window will be shown:

Click in the drop-down box list which

Student

to

Remote control .

You can also start a

Remote control

session from the

Student context menu Remote control this student

command or by double-clicking a Student record or icon (not in

Class setup view

).

Note:

Remote control

is a one-to-one session between the

Teacher

and one

Student

. The

Teacher

can start up to ten

Remote control

sessions one at a time and run them in parallel.

The

Teacher

computer screen will show the

Student

computer screen image, typically in a window:

58

Remote control

functionalities are explained in the

Remote control window

section.

Remote Control Window

This is the

Remote control

window:

NetOp Teacher

It contains these elements:

·

Title bar

·

Toolbar

·

Pane

·

Status bar

Title Bar

This is the

Remote control window

title bar:

Click its left end

Remote control

icon or right-click anywhere in it to show this menu:

59

NetOp Teacher

Its upper section contains window control commands. Its lower section contains

Remote control

commands,

some of which are duplicated by toolbar buttons:

· Send keystrokes: Expands into these commands:

Note: Sending the following keystroke combinations from the keyboard can have undesirable effects.

Therefore, they should always be sent from this menu or matching toolbar buttons.

· Send Ctrl+Esc: Click or click the matching

Toolbar or toolbox

button to send the keystroke combination

CTRL+ESC to the

Student

, typically to show the

Student

computer Start menu.

·

Send Ctrl+Alt+Del: Click or click the matching

Toolbar or toolbox

button to send the keystroke

combination CTRL+ALT+DEL to the

Student

, typically to provide program shutdown options.

Note: This command will be disabled if you are remote controlling a

Student

on a Windows 95 classic

computer.

·

Send Alt+Tab: Click to send the keystroke combination ALT+TAB to the

Student

, typically to shift the

Student

computer screen active window clockwise.

· Send Alt+Shift+Tab: Click to send the keystroke combination ALT+SHIFT+TAB to the

Student

, typically to shift the

Student

computer screen active window counterclockwise.

·

Send Print screen: Click to send a PRINT SCREEN command to the

Student

to place an image of the

Student

computer screen on the

Student

computer clipboard.

· Send Alt+Print screen: Click to send an ALT+PRINT SCREEN command to the

Student

to place an image of the

Student

computer active window on the

Student

computer clipboard.

·

Clipboard: Expands into these commands:

· Clipboard to student: Click or click the matching

Toolbar or toolbox

button to send the

Teacher

computer

clipboard contents to the

Student

computer clipboard.

·

Clipboard from student: Click or click the matching

Toolbar or toolbox

button to retrieve the

Student

computer clipboard contents to the

Teacher

computer clipboard.

·

Print screen to clipboard: Click or click the matching

Toolbar or toolbox

button to take a snapshot of the

Student

computer screen and place it on the

Teacher

computer clipboard.

·

Print screen to file: Click or click the matching

Toolbar or toolbox

button to take a snapshot of the

Student

computer screen and save it as a

Teacher

computer file.

60

NetOp Teacher

Note: When you use this functionality for the first time, a NetOp SnapShot folder will be created on your computer desktop to contain snapshot files. You can change the snapshot files folder in the

Options

window

Sharing

tab

Snapshots

element.

· Session properties: Click or click the matching

Toolbar or toolbox

button to show the

Session properties

window.

· Full screen: Click or click the matching

Toolbar or toolbox

button or press the zoom hot key (default: CTRL

+Z) to show the

Student

screen image in full screen mode.

·

NetOp marker utility: Click or click the matching

Toolbar or toolbox

button to load

NetOp marker utility

on

the

Student

computer and check mark the command. Click the check marked command to unload

NetOp marker utility .

· Mouse marker: Click to show a mouse marker arrow when clicking in the

Student

screen image (click

functionality disabled) and check mark the command. Click the check marked command to disable.

·

Restart student PC: Click or click the matching

Toolbar or toolbox

button to restart the

Student

computer after a warning message.

· Lock keyboard and mouse: Click or click the matching

Toolbar or toolbox

button to disable the

Student

computer keyboard and mouse and check mark the command. Click the check marked command to enable the

Student

computer keyboard and mouse.

·

Transfer sound: Click or click the matching

Toolbar or toolbox

button to transfer

Student

computer

microphone input and running application sound and check mark the command. Click the check marked command to not transfer

Student

computer microphone input and running application sound.

Note:

Transfer sound

will typically work smoothly with new computers with integrated sound devices. On older computers with older sound devices and older operating systems, if

Transfer sound

does not work,

look into recording sound mix setup. NetOp expects to find the recording sound mix name Wave Out Mix.

If only other recording sound mix names are available, add this section to the

NetOp.ini

file:

[AUDIO]

Sound_Mix=<Recording sound mix name>

If the computer sound device does not support recording sound mix, Transfer sound will not work.

·

Record: Click or click the matching

Toolbar or toolbox

button to start recording the

Teacher

desktop showing the

Recording toolbox

. Control and stop recording in the

Recording toolbox

.

·

Refresh: Click to refresh the

Student

screen image.

Toolbar or Toolbox

This is the

Remote control window

toolbar:

You can drag it by its left end to a horizontal or vertical position along a window edge or floating inside or outside the window. This is the

Remote control

full screen toolbox:

61

NetOp Teacher

They contain the same tool tip identified buttons by which you can execute

Remote control

actions:

End session: Click or use

Remote control window Title bar

Close controls to close the

Remote control

window/full screen display to end the

Remote control

session.

Session properties: Click or click the matching

Title bar

menu command to show the

Session properties

window.

Full screen/window: Click, click the matching

Title bar

menu command or press the zoom hot key

(default: CTRL+Z) to switch between full screen and window display mode.

Send Ctrl+Esc: Click or click the matching

Title bar

menu command to send the keystroke

combination CTRL+ESC to the

Student

to typically show the Windows Start menu.

Send Ctrl+Alt+Del: Click or click the matching

Title bar

menu command to send the keystroke

combination CTRL+ALT+DEL to the

Student

to typically provide program shutdown options.

Note: This button will be disabled if a

Student

running on a Windows 95 classic computer is remote controlled.

Restart student computer: Click or click the matching

Title bar

menu command to restart the

Student

computer after a warning message.

Clipboard to student: Click or click the matching

Title bar

menu command to send the

Teacher

computer clipboard contents to the

Student

computer clipboard.

Clipboard from student: Click or click the matching

Title bar

menu command to retrieve the

Student

computer clipboard contents to the

Teacher

computer clipboard.

Print screen to clipboard: Click or click the matching

Title bar

menu command to take a snapshot of

the

Student

computer screen and place it on the

Teacher

computer clipboard.

Print screen to file: Click or click the matching

Title bar

menu command to take a snapshot of the

Student

computer screen and save it as a

Teacher

computer file.

Note: When you use this functionality for the first time, a NetOp SnapShot folder will be created on your computer desktop to contain snapshot files. You can change the snapshot files folder in the

Options

window

Sharing

tab

Snapshots

element.

NetOp marker utility: Click or click the matching

Title bar

menu command to load

NetOp marker utility

on the

Student

computer and make the button appear pressed in. Click the pressed in button to

unload

NetOp marker utility

.

Lock keyboard and mouse: Click or click the matching

Title bar

menu command to disable the

Student

computer keyboard and mouse and make the button appear pressed in. Click the pressed in button to enable the

Student

computer keyboard and mouse.

Transfer sound: Click or click the matching

Title bar

menu command to transfer

Student

computer microphone input and running application sound and make the button appear pressed in. Click the pressed in button to not transfer

Student

computer microphone input and running application sound.

Note:

Transfer sound

will typically work smoothly with new computers with integrated sound devices.

On older computers with older sound devices and older operating systems, if

Transfer sound

does not

work, look into recording sound mix setup. NetOp expects to find the recording sound mix name Wave

Out Mix. If only other recording sound mix names are available, add this section to the

NetOp.ini

file:

[AUDIO]

Sound_Mix=<Recording sound mix name>

If the computer sound device does not support recording sound mix,

Transfer sound

will not work.

Record: Click or click the matching

Title bar

menu command to start recording the

Teacher

desktop

showing the

Recording toolbox

. Control and stop recording in the

Recording toolbox

.

62

Pane

This is the

Remote control window

pane:

NetOp Teacher

It will typically show an automatically scrolling full scale section of the

Student

computer screen image.

Alternatively, it can show a scaled

Student

computer screen image.

By default, the

Teacher

user and the

Student

user have equal access to working with

Student

computer

screen elements with keyboard and mouse.

The

Teacher

user can suppress the transfer of

Student

user mouse movements to the

Teacher

computer

screen by holding down the CTRL key.

The

Teacher

user can apply

Lock keyboard and mouse

generally when running a

Remote control

session or

during a session to disable any

Student

user keyboard and mouse activity.

On the other hand, you can generally protect the

Student

against specified

Teacher

actions including

controlling the

Student

without confirmation by its user.

Status Bar

This is the

Remote control window

status bar:

When the mouse pointer is over a

Title bar

menu command, the left end of the status bar will show a hint to

the command.

Two fields will show the

keyboard and mouse

status.

The right field will show the duration of the current session in the format HH:MM:SS.

63

Session Properties

This is the

Control

Session properties

window:

NetOp Teacher

It specifies

Remote control

and

Monitor

Session properties

on these tabs:

·

Display

·

Keyboard/Mouse

·

Compression

·

Desktop

64

Display Tab

This is the

Session properties

window

Display

tab:

NetOp Teacher

It specifies

Control

session window and DOS box characters display properties.

Student window fit

Click one of the options:

¤ Fit window to student screen: Resize the window to contain the full scale

Student

computer screen image.

If the

Student

computer screen image has more pixels than the maximized window

Pane

, the window will

have scrollbars.

¡ Fit student screen to window: Scale the

Student

computer screen image to fit within the selected window

Pane

.

¡ Do not fit: Show the part of the full scale

Student

computer screen image that will fit within the selected

window

Pane

. If the

Student

computer screen image has less pixels than the selected window

Pane

, it will be

surrounded by black borders. If the

Student

computer screen image has more pixels than the selected

window

Pane

, it will have scrollbars.

DOS box font

Command window (DOS box) characters will be transferred as data and typically shown using the

Teacher

computer system default font.

þ System default [Select font]: Leave checked to use the

Teacher

computer system default font. Click

[Select font] to show the Windows Font window to select a font and uncheck the box.

65

Keyboard/Mouse Tab

This is the

Session properties

window

Keyboard/Mouse

tab:

NetOp Teacher

It specifies

Control

session keyboard and mouse properties.

Keyboard

Click one of these options:

¤ Remote keyboard (Send all keystrokes to student): Send all

Teacher

computer keystrokes to the

Student

computer.

¡ Local keyboard (Don't send special keystrokes): Send all

Teacher

computer keystrokes except special

Send keystrokes

combinations to the

Student

computer. Send special

Send keystrokes

combinations to the

Teacher

computer.

¡ No keyboard control: Send all

Teacher

computer keystrokes to the

Teacher

computer.

¨ Use teacher keyboard layout: If the

Teacher

computer keyboard layout and the

Student

computer keyboard layout are different,

Teacher

computer keystrokes will come out wrong on the

Student

computer.

Check to send

Teacher

computer keystrokes not according to layout but according to contents.

¨ Don't transfer student Num Lock, Scroll Lock, Insert and Caps Lock: In some cases, these

Student

computer keyboard settings may cause

Teacher

computer keyboard lights to flash. Check to disable the

transfer of these settings.

Mouse

Click one of these options:

¤ Remote mouse (Send all mouse events): Send all

Teacher

computer mouse events (clicks, drags and moves) to the

Student

computer to move the

Student

computer mouse pointer in accordance with the

Teacher

computer mouse pointer.

¡ Local mouse (Only send clicks and drags): Send only

Teacher

computer clicks and drags (not moves) to

66

NetOp Teacher

the

Student

computer to move the

Student

computer mouse pointer only when the

Teacher

user clicks and

drags in the screen image.

¡ No mouse control: Send all

Teacher

computer mouse events to the

Teacher

computer.

þ Display student mouse movements: Leave checked to move the

Teacher

computer mouse pointer in accordance with

Student

user mouse movements. The

Teacher

computer user can press the CTRL key to

suppress this functionality.

Remote control hot keys assignment

· Zoom in and out ¨ Shift ¨ Ctrl ¨ Alt []: To change the keystroke combination that will switch between

Remote control

window mode and full screen mode, check/uncheck boxes and specify a key in the field.

Compression Tab

This is the

Session properties

window

Compression

tab:

It specifies

Control

session screen image transfer properties.

Compression level

Screen image data can be compressed to reduce bandwidth consumption and speed up image transfer across slow communication links. Click one of the options:

¤ Automatic: Compress screen image data according to the properties of the selected

Communication profile

.

¡ No compression: The optimum selection for fast communication links.

¡ Low: The optimum selection for medium fast communication links.

¡ High: The optimum selection for slow communication links.

Demo in bitmap mode

If on the

Options

window

Demonstrate

tab the

Demo in bitmap mode

box is checked, a

Student desktop

67

NetOp Teacher

Demonstrate

session will typically use accelerated bitmap transfer.

¨ Disable accelerated bitmap transfer: If a

Demo in bitmap mode

Student desktop

Demonstrate

session causes problems, check this box to see if it solves the problems.

Desktop Tab

This is the

Session properties

window

Desktop

tab:

It specifies

Control

session

Student

computer desktop features transfer properties.

Optimize screen transfer

Advanced

Student

computer desktop features slow down screen image transfer and are in most cases

unimportant to the

Teacher

and other

Students

that receive a demonstration. Therefore, NetOp will by default

transfer the screen image without advanced desktop features. If unacceptable, select which advanced desktop features to transfer.

¤ Always: Always apply the optimization specified in the section below.

¡ Only when high compression: Apply the optimization specified in the section below only when NetOp applies high compression to screen image data according to

Compression

tab settings.

¡ Never: Never apply the optimization specified in the section below.

Optimization Parameters

Click one of these options:

¤ Full optimization: Apply all Custom options subsection options.

¡ Custom optimization: Enable the Custom options subsection.

Custom Options

þ Disable wallpaper

68

NetOp Teacher

þ Disable screen saver

þ Disable animation gimmicks

þ Disable full window drag

þ Disable Active Desktop

þ Disable Vista Aero

3.2.3.3.2 Monitor

To start a

Monitor

session with selected

Students

, click the

Control

menu

Monitor students

command, or if

Monitor

is the default

Control

mode click the

Control

button.

You can also start a

Monitor

session from the

Student context menu Monitor this student

command or from

the

Student group context menu

Monitor this group

command.

Note:

Monitor

is a sequential one-to-one session between the

Teacher

and each selected

Student

.

The computer screen image of each selected

Student

will be shown sequentially on the

Teacher

computer

screen, typically in a window:

The

Monitor

display is very similar to the

Remote control

display, but the

Teacher

user will have no keyboard

and mouse control and most

Toolbar or Toolbox

buttons will be disabled.

69

NetOp Teacher

At an interval set on the

Options

window

Control

tab, the computer screen image of the next selected

Student

will be shown.

This toolbox will be shown on the

Teacher

computer screen:

It is explained in the

Monitor toolbox

section.

Monitor Toolbox

This is the

Monitor

toolbox:

Its title bar will show:

· During monitoring countdown: Monitoring:, the name of the

Student

being monitored and the number of

seconds remaining before monitoring the next

Student

.

· While holding monitoring countdown: Holding: and the name of the

Student

being monitored.

· If switched to

Remote control

: Remote controlling: and the name of the

Student

being remote controlled.

It contains these tool tip identified buttons:

End session: Click to end the

Monitor

session.

Continue: When Holding, click to continue countdown.

Hold: Click to hold countdown.

/

Previous student: During countdown, click to jump to the previous

Student

to start a new

countdown.

Next student: During countdown, click to jump to the next

Student

to start a new countdown.

Remote control/Monitor: Click to switch between

Remote control

and

Monitor

. During

Remote control

, the green icon

Monitor

control buttons will be disabled and countdown will be stopped.

The

Remote control

Title bar

menu and

Toolbar or toolbox

controls except

End session

,

Restart student computer

and

Record

will be enabled.

Full screen/Window: Click to switch between full screen mode and window mode.

/

Record: Click to start recording the

Teacher

desktop to show the

Recording toolbox

.

Print screen to clipboard: Click to take a snapshot of the

Student

computer screen and place it on

the

Teacher

computer clipboard.

Print screen to file: Click to take a snapshot of the

Student

computer screen and save it as a

Teacher

computer file.

Note: When you use this functionality for the first time, a NetOp SnapShot folder will be created on your computer desktop to contain snapshot files. You can change the snapshot files folder in the

Options

window

Sharing

tab

Snapshots

element.

Transfer sound: Enabled during

Monitor

Hold and

Remote control

. Click to transfer

Student

computer microphone input and running application sound and make the button appear pressed

70

NetOp Teacher

in. Click the pressed in button to not transfer

Student

computer microphone input and running application sound.

Note:

Transfer sound

will typically work smoothly with new computers with integrated sound

devices. On older computers with older sound devices and older operating systems, if

Transfer sound

does not work, look into recording sound mix setup. NetOp expects to find the recording

sound mix name Wave Out Mix. If only other recording sound mix names are available, add this

section to the

NetOp.ini

file:

[AUDIO]

Sound_Mix=<Recording sound mix name>

If the computer sound device does not support recording sound mix,

Transfer sound

will not work.

Student list: Click to show a list of selected

Students

in monitoring order. Click a

Student

to jump

to it to start a new countdown.

3.2.3.4 Communicate

This is the

Teacher

window

Toolbar

Communicate

button and menu:

Communicate

enables different types of communication with selected

Students

.

To start a

Communicate

session, select

Students

and click one of these

Action

menu

Communicate

command menu or

Toolbar

Communicate

button menu commands:

·

Audio-video chat

·

Chat

·

Send message

You can also start each type of

Communicate

session from the

Student context menu

or the

Student group context menu

.

71

NetOp Teacher

3.2.3.4.1 Audio-Video Chat

To start an

Audio-video chat

session with selected

Students

, click the

Communicate

menu

Audio-video chat

command to show this window:

It enables you to control an

Audio-video chat

session.

Note: Each

Teacher

and each

Student

can run only one

Audio-video chat

session at a time.

You can also start an

Audio-video chat

session from the

Student context menu Audio-video chat with this student

command or the

Student group context menu

Audio-video chat with this group

command.

A similar window with partly different controls will be shown on selected

Students'

computer screen. The

Teacher

Audio-video chat

window contains these elements:

Sound

Will show a microphone icon when the

Teacher

has the microphone, otherwise a loudspeaker icon.

The field will show sound send volume colored blocks.

Click Volume to show the

Teacher

computer sound device volume control window to adjust the loudspeaker

output volume.

Class

The table will contain

Audio-video chat

participant records with these column details:

· Student login name: Will show the

Teacher

name and the

Student login

name of participating

Students

.

Will show a microphone icon if the participant has the microphone. Will show a raised hand if the

Student

has requested the microphone (Request button is available on

Student

).

72

NetOp Teacher

·

Time: Will show the time of a microphone request.

· Request text: Will show the text of a microphone request (Request text field is available on

Student

).

With only two participants, you can click one of these options (not available on

Student

):

¤ Open discussion: Initial selection with two participants. Both will have the microphone for duplex communication (talk and listen at the same time).

¡ Moderated discussion: Always selected with more than two participants. The

Teacher

user can assign the microphone for simplex communication (one talks, others listen).

·

Assign: Enabled if Moderated discussion is selected. Click to make appear pressed in to enable assigning

the microphone by clicking a table record. Click again to withdraw the microphone to the

Teacher

(not

available on

Student

).

· Mute: Enabled if Moderated discussion is selected. Click to make appear pressed in to disable microphone input.

Video

Initially, video will be disabled by this section bottom selection (not available on

Student

):

¡ Video: Enable video.

¤ No video: Disable video.

Click Video to show the

Teacher

computer camera view in the top of the section and the

Student

computer

camera view in the bottom of the section. With more than two participants, the camera view of the computer to which the microphone is assigned will be shown in the bottom of the section. If a camera view is unavailable, an error message will be shown.

Stop: Click to end the

Audio-video chat

session (not available on

Student

).

During an

Audio-video chat

session, a

Details view

participating

Student

record will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

You can specify general

Audio-video chat

properties on the

Options

window

Audio-video chat

tab.

3.2.3.4.2 Chat

To start a

Chat

session with selected

Students

, click the

Communicate

menu

Chat

command to show this

window:

Each

Teacher

can run multiple

Chat

sessions at a time.To identify the

Chat

session, optionally specify its

topic in the Topic field. Click OK to show this window:

73

NetOp Teacher

It enables you to control a

Chat

session.

You can also start a

Chat

session from the

Student context menu Chat with this student

command or the

Student group context menu

Chat with this group

command.

A similar window without the End chat button will be shown on the computer screen of selected

Students

.

The

Teacher

Chat

window contains these elements:

· The title bar will show the specified

Chat

topic.

Chat

·

Dialog []: Will show the

Chat

dialog. The contributor's name will precede each contribution.

· Enter chat contribution and click send []: Specify your

Chat

contribution by typing or pasting (CTRL+V).

· Send: Click to send your

Chat

contribution to the other participants to appear in the pane above.

· Font: Click to show the Windows Font window to format your

Chat

contribution.

· End chat: Click to close the

Chat

window of the

Teacher

and selected

Students

to end the

Chat

session

(not available on

Student

).

· Save: Click to show a Windows Save as window to save the

Chat

dialog.

During a

Chat

session, a

Details view

participating

Student

record will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

74

NetOp Teacher

3.2.3.4.3 Send Message

To send a

NetOp message

to selected

Students

, click the

Communicate

menu

Send message

command to show this window:

It enables you to send a

NetOp message

to selected

Students

.

You can also open the

NetOp message

window from the

Student context menu Send message to this student

command or the

Student group context menu

Send message to this group

command.

Note: As long as the

NetOp message

window is open, you cannot work in the

Teacher

window.

The

Teacher

NetOp message

window contains these elements:

·

Title bar

·

Menu bar

·

Toolbar

·

Message pane

·

Status bar

Title Bar

This is the

Teacher

NetOp message

window title bar:

It will show the path of an opened

NetOp message

file, otherwise Untitled.

Menu Bar

This is the

Teacher

NetOp message

window menu bar:

It contains these menus:

·

File

·

Edit

·

Search

·

Format

75

NetOp Teacher

File Menu

This is the

Teacher

NetOp message

window

File

menu:

It contains these commands:

· Send Message: Click or click the

Toolbar Send message

button to send the open

NetOp message

to

selected

Students

closing the

NetOp message

window.

Note: A sent

NetOp message

will not automatically be saved on the

Teacher

computer. It will appear on the computer screen of selected

Students

in a

NetOp message

window and automatically be saved on the

Student

computer. If sending the

NetOp message

to all selected

Students

fails, a

File distribution

window will

show what failed.

· New: Click or click the

Toolbar New

button to empty the

NetOp message

window to create a

NetOp message

.

· Open: Click or click the

Toolbar Open

button to show a Windows Open window to open a text file in the

NetOp message

window.

Note: To open a file in the

NetOp message

window, it must have an extension that identifies it as a text file,

typically rtf, txt or doc.

· Save: Click or click the

Toolbar Save

button to save the open

NetOp message

in a file. If no file path has been specified before, a Windows Save as window will be shown to specify it.

·

Save as: Click to show a Windows Save as window to save the open

NetOp message

in a new file.

· Print: Click or click the

Toolbar Print

button to show a Windows Print window to print the open

NetOp message

.

· Close: Click, press CTRL+F4, click the

Title bar

Close button or click the

Title bar

window control menu

Close command to close the

NetOp message

window.

Edit Menu

This is the

Teacher

NetOp message

window

Edit

menu:

It contains these commands:

76

NetOp Teacher

·

Undo Ctrl+Z: Click, press CTRL+Z or click the

Toolbar Undo

button to undo/redo the last

Message pane

action.

·

Cut Ctrl+X: Select

Message pane

text and click, press CTRL+X or click the

Toolbar Cut

button to remove

the selected text placing it on the clipboard.

· Copy Ctrl+C: Select

Message pane

text and click, press CTRL+C or click the

Toolbar Copy

button to copy

the selected text to the clipboard.

·

Paste Ctrl+V: Click, press CTRL+V or click the

Toolbar Paste

button to paste the clipboard contents in the

Message pane

cursor position.

· Clear all Ctrl+Del: Click or press CTRL+DEL to delete the

Message pane

contents.

· Delete Del: Select

Message pane

text and click or press DEL to delete the selected text.

Search Menu

This is the

Teacher

NetOp message

window

Search

menu:

It contains these commands:

·

Find: Click or click the

Toolbar Find

button to show the Windows Find window to specify a character sequence to find it in the

Message pane

.

· Replace: Click to show the Windows Replace window to specify a character sequence to find and replace it in the

Message pane

.

· Next F3: Click or press F3 to highlight the next occurrence of the character sequence specified in a

Windows Find or Replace window.

Format Menu

This is the

Teacher

NetOp message

window

Format

menu:

It contains these commands:

· Character: Select

Message pane

text and click an expanded

Bold

,

Italic

,

Underline

or Strikeout command

or click the matching

Toolbar

buttons to apply this formatting to or remove this formatting from the selected

text. Commands will be check marked and buttons will appear pressed in when the formatting is applied.

·

Font: Select

Message pane

text and click to show the Windows Font window to apply a selected font to the

selected text.

·

Text data/RTF data: One of these commands will be check marked to indicate the

Message pane

text data type. Click the unchecked command to change the

Message pane

text data type.

Note: The RTF data type supports hyperlinks.

77

NetOp Teacher

Toolbar

This is the

Teacher

NetOp message

window toolbar:

It contains these buttons:

Send message: Click or click the

File

menu

Send message

command to send the open

NetOp message

to selected

Students

closing the

NetOp message

window.

Note: A sent

NetOp message

will not automatically be saved on the

Teacher

computer. It will appear

on the computer screen of selected

Students

in a

NetOp message

window and automatically be saved

on the

Student

computer. If sending the

NetOp message

to all selected

Students

fails, a

File distribution

window will show what failed.

New: Click or click the

File

menu

New

command to empty the

NetOp message

window to create a

NetOp message

.

Open: Click or click the

File

menu

Open

command to show a Windows Open window to open a text

file in the

NetOp message

window.

Note: To open a file in the

NetOp message

window, it must have an extension that identifies it as a text file, typically rtf, txt or doc.

Save: Click or click the

File

menu

Save

command to save the open

NetOp message

in a file. If no file path has been specified before, a Windows Save as window will be shown to specify it.

Print: Click or click the

File

menu

Print

command to show a Windows Print window to print the open

NetOp message

.

Undo: Click, press CTRL+Z or click the

Edit

menu

Undo

command to undo/redo the last

Message pane

action.

Cut: Select

Message pane

text and click, press CTRL+X or click the

Edit

menu

Cut

command to

remove the selected text placing it on the clipboard.

Copy: Select

Message pane

text and click, press CTRL+C or click the

Edit

menu

Copy

command to

copy the selected text to the clipboard.

Paste: Click, press CTRL+V or click the

Edit

menu

Paste

command to paste the clipboard contents in

the

Message pane

cursor position.

Find: Click or click the

Search

menu

Find

command to show the Windows Find window to specify a

character sequence to find it in the

Message pane

.

Bold: Select

Message pane

text and click or click the

Format

menu

Character

>

Bold

command to apply this formatting to or remove this formatting from the selected text. The button will appear pressed in and the command will be check marked when the formatting is applied.

Italic: Select

Message pane

text and click or click the

Format

menu

Character > Italic

command to

apply this formatting to or remove this formatting from the selected text. The button will appear pressed in and the command will be check marked when the formatting is applied.

Underline: Select

Message pane

text and click or click the

Format

menu

Character > Underline

command to apply this formatting to or remove this formatting from the selected text. The button will appear pressed in and the command will be check marked when the formatting is applied.

78

NetOp Teacher

Message Pane

This is the

Teacher

NetOp message

window message pane:

In it, you can create and edit a

NetOp message

.

Note: The

Student

window

Messages

tab

Subject

column will show the contents of the first message line.

The

RTF data

type supports hyperlinks.

Status Bar

This is the

Teacher

NetOp message

window status bar:

The fields to the right will indicate this:

·

CAPS: Enabled (black text) if CAPS LOCK is enabled.

· NUM: Enabled (black text) if NUM LOCK is enabled.

· OVR: Enabled (black text) if INSERT is enabled.

3.2.3.5 Workgroup

This is the

Teacher

window

Toolbar

Workgroup

button:

Workgroup

enables creating a

Workgroup

session from selected

Students .

To create a

Workgroup

session, select the

Students

that shall be in it and click the

Action

menu

Workgroup

command or the

Toolbar

Workgroup

button to show this window:

79

NetOp Teacher

Note: You can create a

Workgroup

session with the connected

Students

of a

Student group

from the

Student group context menu

Workgroup session for this group

command.

It enables you to specify the

Workgroup

session in these elements:

· Workgroup session name []: Will by default show the

Class

name and a number (1 for the first

Class

Workgroup

session, 2 for the next, etc.). You can edit the field contents.

· Select the assistant teacher from the list []: The table will contain selected

Student

records with these column details:

·

Student display name: Icon and

Student

user

Student display name

.

·

Windows login name:

Student

user

Windows login name

.

· Computer name:

Student

Computer name

.

To appoint the

Workgroup

session

Assistant teacher

, select a record to highlight it and change the

Student

icon into a

Workgroup

icon.

Disable assistant teacher options

¨ Lock keyboard and mouse: Check to disable the

Assistant teacher

option to

Lock keyboard and mouse

of

Workgroup

session

Remote control

session

Student

computers.

¨ Audio-video chat: Check to disable the

Assistant teacher

option to run an

Audio-video chat

session with

Workgroup

session

Students

.

¨ Attention: Check to disable the

Assistant teacher

option to apply

Attention

to

Workgroup

session

Students

.

The OK button will become enabled when the

Assistant teacher

has been appointed. Click to apply selections closing the window.

80

NetOp Teacher

This will happen:

· On the

Student

appointed

Assistant teacher

, the

Student

window will minimize to the Windows taskbar

notification area and the

Assistant teacher

window that has almost the same appearance and functionality

as the

Teacher

window will open.

·

Workgroup

session

Students

will disconnect from the

Teacher

to connect to the

Assistant teacher

.

· In the

Teacher

window

Details view

, the

Student

appointed

Assistant teacher

will in the

Status

column show a

Workgroup

icon and in the

Information

column show Assistant teacher: <

Workgroup

name>.

Workgroup

session

Students

will in the

Status

column show an

Unconnected

icon and in the Student

display name column be named <

Workgroup

name>/<

Student display name

>.

· In the

Teacher

window

Classroom view

, the

Student

appointed

Assistant teacher

will show a

Workgroup

icon and other

Workgroup

session

Students

will appear unconnected being named <

Workgroup

name>/<

Student display name

>.

· In the

Teacher

window

Thumbnails view

, the

Student

appointed

Assistant teacher

will appear connected

and

Workgroup

session

Students

will appear unconnected being named <

Workgroup

name>/<

Student display name

>.

·

In the

Teacher

window

Activity view

, the

Student

appointed

Assistant teacher

will appear connected and

Workgroup

session

Students

will appear unconnected being named <

Workgroup

name>/<

Student display name

>.

· In the

Teacher

window

Class setup view

, the

Student

appointed

Assistant teacher

will appear connected

and

Workgroup

session

Students

will appear unconnected being named <

Workgroup

name>/<

Student display name

>.

·

The

Teacher

can control the

Assistant teacher

that will remain connected to the

Class

. In a

Remote control

session with the

Assistant teacher

, the

Teacher

can through the

Assistant teacher

window control

Workgroup

session

Students

.

·

To end a

Workgroup

session, in the

Student context menu

of the

Student

appointed

Assistant teacher

click

Stop workgroup session

to return all

Workgroup

session

Students

to the

Class

.

3.2.3.6 Run

This is the

Teacher

window

Toolbar

Run

button and menu:

Run

enables running a test, survey or program on selected

Students

.

To run a test, survey or program, select

Students

and click a

Toolbar

Run

button menu command. In the

Action

menu, click

Run test

to run the

Tests view pane

Tests

tab first

Test

or click

Run program

to show the

Run program browse

window to specify a

Program

to run it.

You can also run a test, survey or program from the

Student context menu

or the

Student group context menu

.

Run

includes these features:

·

Run test

81

NetOp Teacher

·

Run survey

·

Run program

3.2.3.6.1 Run Test

The

Run

menu

Run test

command will expand into

Tests view

Tests

tab available

Test

commands:

Click a

Test

command to run the

Test

on selected

Students

as explained in the

Results

section.

3.2.3.6.2 Run Survey

The

Run

menu

Run survey

command will expand into

Tests view

Surveys

tab available

Survey

commands:

Click a

Survey

command to run the

Survey

on selected

Students

as explained in the

Results

section.

3.2.3.6.3 Run Program

The

Run

menu can include these

Run program

elements:

· Click the Run program command to show the

Run program browse

window to browse for a program to run

it on selected

Students

.

·

Click the Options command to show the

Options

window

Run

tab to manage

Run

menu program commands.

· Click a program command to expand into these commands:

·

Run on student: Click to run the

Options

window

Run

tab specified program on selected

Student

computers. If a

Student

cannot find the program file on its computer, File not found will be shown in its

Details view

record

Information

column. To ensure that the program file is available on

Student

computers,

Distribute

it before attempting to

Run

it.

· Run locally: Click to run the program on the

Teacher

computer.

·

Demo: Click to run the program on the

Teacher

computer while running an

Entire desktop

Demonstrate

session with selected

Students

.

82

Run Program Browse

Click the

Run

menu

Run program

command to show this window:

NetOp Teacher

It enables you to browse for a program to run it on selected

Student

computers. It contains these elements:

· Program path [][Browse]: Must specify the program file path on selected

Student

computers. The

drop-down box list will contain program file paths that have been used before. Click one to show it in the field. Click [Browse] to show a Windows Open window to open a

Teacher

computer program file to show its path in the field or specify the program file path manually.

Note: By default, the Open window will show only program files. You can also run other files, e.g. text files.

To run on

Student

computers, the file must be available on

Student

computers and identifiable by the

Program path

drop-down box program file path specification.

·

Command line switches []: To run the

Program path

drop-down box specified program with command line

switches, they must be specified in this drop-down box. Its list will contain switches that have been used before. Click one to show it in the field or specify switches manually.

·

Translate: Click to replace

Program path

drop-down box field specified path elements by available

matching environment variables to facilitate path identification on

Student

computers regardless of

language differences.

Run

Click one of these options:

¤ Normal: Run the program in a normal size window.

¡ Maximized: Run the program in a maximized window.

¡ Minimized: Run the program minimized.

Click OK to run the specified program on selected

Student

computers. If a

Student

cannot find the program

file on its computer, File not found will be shown in the

Details view

Information

column. To ensure that the

program file is available on

Student

computers,

Distribute

it before attempting to

Run

it.

83

NetOp Teacher

3.2.3.7 Commands

This is the

Teacher

window

Toolbar

Commands

button and menu:

Commands

enables executing system control commands on selected

Students

.

To execute a system control command on selected

Students

, select

Students

and click an

Action

menu

Commands

command menu or

Toolbar

Commands

button menu command.

You can also execute a system control command from the

Student context menu

Execute command on this student

menu or the

Student group context menu

Execute command on this group

menu.

These

Commands

are available:

· Log off: Click to log off the user from Windows on selected

Student

computers.

·

Restart: Click to restart selected

Student

computers.

·

Shut down: Click to shut down selected

Student

computers.

· Rejoin: Click to make selected

Students

Leave class

and

Join class

.

3.2.3.8 Files

This is the

Teacher

window

Toolbar

Files

button and menu:

Files

enables distributing, collecting or managing files with selected

Students

.

To start a

Files

session with selected

Students

, select

Students

and click an

Action

menu

Files

command

menu or

Toolbar

Files

button menu command.

You can also start a

Files

session from the

Student context menu

or the

Student group context menu

.

These

Files

sessions are available:

·

Distribute files

·

Collect files

·

File manager

84

NetOp Teacher

3.2.3.8.1 Distribute Files

To

Distribute files

to selected

Student

computers, click the

Files

menu

Distribute files

command to show this window:

Click Next to show this window:

85

NetOp Teacher

It enables you to select which files and/or folders to distribute.

To select one or multiple files, click Add files to show the Windows Open window.

To select one folder, click Add folder to show the Windows Browse for folder window.

Note: All files and folders in a selected folder but not the folder itself will be distributed.

Selected files and folders will appear as check boxed table records. To deselect a file or folder, uncheck its record's box.

To specify distribution properties in the

Distribute files to students

window instead of in this

Distribution wizard

, click Advanced.

If at least one file is selected, the Next button will be enabled. Click it to show this window:

86

NetOp Teacher

It enables you to select to which

Students

files shall be distributed.

The To students pane will contain the names of connected

Students

. The names of initially selected

Students

will be highlighted. The To groups pane will contain the names of available

Student groups

. Click

Student

names to select/unselect

Students

. Click a

Student group

name to select the

Students

in the

Student group

.

If at least one

Student

is selected, the Next button will be enabled. Click it to show this window:

87

NetOp Teacher

It enables you to select the distributed files

Student

computer destination.

The Destination pane will contain available destination descriptions. Click a destination description to

highlight it to select the

Student

computer destination whose path is shown in the Details of selected item

field below. Path elements enclosed by % are environment variables.

If a

Student

computer destination is selected, the Distribute button will be enabled. Click it to distribute files

as specified.

This is the alternative

Distribute files to students

window:

88

NetOp Teacher

It combines the

Distribution wizard

window contents and includes additional options:

In the Source section, you can select a table record to enable the Delete button and show the record item path in the Details of selected item field. Click Delete to delete the selected record.

Note: Source pane contents will be retained after file distribution, even after switching to another

Class

and after logging off and on to the

Teacher

using

Teacher profiles

. Source pane contents will be lost when the

Teacher

is unloaded.

In the Destination section, you can create, edit and delete

Student

computer destinations. Click New to show this window:

It enables you to specify a

Student

computer destination in these elements:

· Description []: Specify the

Student

computer destination description.

· Path []: Specify the

Student

computer destination path, preferably by using environment variables.

Note: To show available computer environment variables, in a command window execute the command

89

NetOp Teacher

set. CLASSROOM, DESKTOP and MYDOCUMENTS are NetOp environment variables.

Select a destination and click Edit to show the

Location

window to edit it. Select a destination and click Delete

to delete it.

Note:

Student

computer locations are specific to each

Class

and will be retained when the

Teacher

is unloaded. Edited and newly created

Student

computer locations will be written to the locstd.ndb

NetOp configuration file

. Distributed files will without any warning overwrite any unprotected files with the same

name in the same

Student

computer location.

¨ Send files to same destination on students: Check to use the

Teacher

source location path as the

Student

destination location path.

¨ Use this destination when files are dropped and don't prompt with this dialog: Check to enable

Quick distribution

.

Quick distribution

Open Windows Explorer, select files and folders, drag them to a

Class control panel

Student

, selected

Students

,

Student group

or selected

Student groups

and drop them.

Note:

Quick distribution

will replace any Source section pane contents by

Quick distribution

selected source files and folders.

File distribution will show this window:

It will show file distribution progress and results in these elements:

File distribution info

File: The name of the file currently being distributed, or "-" if all files have been distributed.

Files sent: The current number of files distributed.

Bytes sent: The current number of bytes distributed.

Elapsed time: The elapsed time of file distribution in the format HH:MM:SS.

90

NetOp Teacher

The colored blocks progress bar will indicate file distribution progress.

File distribution status []: The pane will graphically show the current file distribution status.

Students

to which

files have been distributed will be indicated by a named icon. File distribution errors will be indicated by a red exclamation mark. Expand each line by clicking the [+] button in front of it to show the paths and names of distributed files and in case of file distribution errors a text that indicates their nature.

During a

Distribute files

session, a

Details view

participating

Student

record will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

3.2.3.8.2 Collect Files

To

Collect files

from selected

Student

computers, click the

Files

menu

Collect files

command to show this window:

Click Next to show this window:

91

NetOp Teacher

It enables you to select which files and/or folders to collect.

Initially, the pane will contain the file and folder records of the most recent

Distribute files

session. To add

files to the selection, click Specify files to show this window:

It enables you to specify a collect file name or mask and a

Student

computer location in these elements:

· File type []: Specify a file name or a file mask (a file name with wildcard characters like *) to collect one

or multiple files in the

Student

computer location selected in the Location pane below. Leave empty to

collect all files in the location.

·

Location []: Click a

Student

computer location to highlight it as selected. If the desired

Student

computer location is unavailable, click Edit student location list to show this window:

92

NetOp Teacher

Its table contains records of available

Student

computer locations.

Click New to show the

Location

window to create a

Student

computer location. Select a record and click

Edit to edit the location in the

Location

window. Select a record and click Delete to delete it. When done,

click Close to close the window returning to the Collect file window.

Note:

Student

computer locations are specific to each

Class

and will be retained when the

Teacher

is

unloaded. Edited and newly created

Student

computer locations will be written to the locstd.ndb

NetOp configuration file

.

The OK button will become enabled when a

Student

computer location has been selected. Click it to close

the window adding the collect file specification in the wizard window Source pane.

To deselect a collect file specification, uncheck its box.

¨ Include subfolders: Check to include the subfolders of specified folders.

¨ Delete on student after collection: Check to remove collected files from the

Student

computer.

Caution: Check only if you are certain that no files needed on the

Student

computer will be removed.

To specify collection properties in the

Collect files from students

window instead of in this

Collection wizard

,

click Advanced.

If at least one file is selected, the Next button will be enabled. Click it to show this window:

93

NetOp Teacher

It enables you to select from which

Students

files shall be collected.

The From students pane will contain the names of connected

Students

. The names of initially selected

Students

will be highlighted. The From groups pane will contain the names of available

Student groups

. Click

Student

names to select/unselect

Students

. Click a

Student groups

name to select the

Students

in the

Student group

.

If at least one

Student

is selected, the Next button will be enabled. Click it to show this window:

94

NetOp Teacher

It enables you to select the

Teacher

computer destination of collected files.

The Destination pane will contain available destination descriptions. Click a destination description to

highlight it to select the

Teacher

computer destination whose path is shown in the Details of selected item

field below. Path elements enclosed by % are environment variables.

If a

Teacher

computer destination is selected, the Collect button will be enabled. Click it to collect files as

specified.

This is the alternative

Collect files from students

window:

95

NetOp Teacher

It combines the

Collection wizard

window contents and includes additional options:

In the Source section, you can select a table record to enable the Delete button and show the record item path in the Details of selected item field. Click Delete to delete the selected record.

In the Destination section, you can create, edit and delete

Teacher

computer destinations. Click New to show

the

Location

window to create a

Teacher

computer location. Select a destination and click Edit to show the

Location

window to edit it. Select a destination and click Delete to delete it.

Note: Edited and newly created

Teacher

computer locations will be written to the loctch.ndb

NetOp configuration file

. Files collected from

Students

will be placed in a <

Student

name> folder in the specified

Teacher

computer location to overwrite without any warning any unprotected files with the same name in the

same location.

File collection will show this window:

96

NetOp Teacher

It will show file collection progress and results in these elements:

File collection info

Student: The name of the

Student

from which files are currently being collected, or "-" if files have been

collected from all selected

Students

.

File: The name of the file currently being collected, or "-" if all files have been collected.

Files received: The current number of files collected.

Bytes received: The current number of bytes collected.

Elapsed time: The elapsed time of file collection in the format HH:MM:SS.

File collection status []: The pane will graphically show the current file collection status.

Students

from which files have been collected will be indicated by a named icon. File collection errors will be indicated by a red exclamation mark. Expand each line by clicking the [+] button in front of the line to show the paths and names of collected files and in case of file collection errors a text that indicates their nature.

During a

Collect files

session, a

Details view

participating

Student

record will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

97

NetOp Teacher

3.2.3.8.3 File Manager

To manage the files of a selected

Student

computer, click the

Files

menu

File manager

command.

If multiple

Students

are selected, this window will be shown:

Click in the drop-down box list the name of the

Student

whose files you want to manage.

You can also start a

File manager

session from the

Student context menu

File transfer with this student

command.

Note:

File manager

is a one-to-one session between the

Teacher

and one

Student

. The

Teacher

can start up

to ten

File manager

sessions one at a time and run them in parallel.

This window will be shown:

It contains these elements:

·

Title bar

·

Menu bar

·

Toolbar

98

NetOp Teacher

·

Records panels

During a

File manager

session, a

Details view

participating

Student

record will show this icon in the

Status

column:

Classroom view

and

Class setup view

participating

Student

icons will show a green check mark.

To end a

File manager

session, click the

File manager

window

File

menu

Close

command or use a

Title bar

Close window control.

Title Bar

This is the

File manager

title bar:

It will show the name of the

Student

with which the

File manager

session is running.

Menu Bar

This is the

File manager

menu bar:

It contains these menus:

·

File

·

Edit

·

View

·

Options

·

Help

File Menu

This is the

File manager

window

File

menu:

It contains these commands:

·

Copy files: Select

Record panel

records and click or click the matching

Record panel

context menu

command or

Toolbar Copy files

button or press any matching

keyboard shortcut to show the

Copy

window.

99

NetOp Teacher

Note: Alternatively, drag records from one

Record panel

to the other and drop them to typically show the

Transfer status

window.

·

Move files: Select

Record panel

records and click or click the matching

Record panel

context menu

command or

Toolbar

Move files

button or press any matching

keyboard shortcut to show the

Move

window.

·

Sync files: Click or click the

Toolbar

Synchronize files

button to show the

Synchronize

window.

Note: By default,

Synchronize files

will transfer folders and files to include folders and files that exist in

either

Record panel

in both

Record panels

replacing older files by newer files. On the

Options

window

Transfer

tab, you can select the

Synchronize

options

Transfer only if file exists

and

Transfer only one way

.

· Clone files: Click or click the

Toolbar

Clone files

button to show the

Clone

window.

Note:

Clone files

will delete all folders and files in the unselected

Record panel

and copy all folders and files in the selected

Record panel

to the unselected

Record panel

.

·

New folder: Click or click the

Toolbar

New folder

button or press any matching keyboard shortcut to show

this window:

Specify the new folder name and click OK to create the folder in the selected

Record panel

.

· Drive info: Click to show this window:

It will show information on the selected

Record panel

computer drives in these elements:

· Drives: Will show drive icons and letters. Select a drive to show information on it in the Information section.

·

Information: Will show this information on the drive selected in the Drives pane:

· Type: Drive type.

· File system: Drive file system.

· Used space: Drive used space in bytes.

100

NetOp Teacher

·

Free space: Drive free space in bytes.

· Capacity: Drive capacity in bytes.

· Delete: Select

Record panel

records and click or click the matching

Record panel

context menu command

or the

Toolbar

Delete

button or press the matching

keyboard shortcut to delete selected records. If

selected

, a confirmation window will be shown.

Caution: If you delete a folder, folders and files in it will be deleted.

·

Rename: Select a

Record panel

record and click or click the matching

Record panel

context menu

command or press any matching keyboard shortcut to show this window:

Edit the name and click OK to rename the record.

· Properties: Select a

Record panel

record and click or click the matching

Record panel

context menu

command or the

Toolbar

Properties

button or press the matching

keyboard shortcut

to show this window:

Check/uncheck Attributes boxes and click OK to apply changes.

·

Close: Click, use a matching

Title bar

window control or press the matching

keyboard shortcut to end the

File manager

session closing the

File manager

window.

101

NetOp Teacher

Copy/Move/Synchronize/Clone

Execute the

File manager

Copy files

,

Move files

,

Sync files

or

Clone files

functionality to show this window:

Note: The title bar will show the name of the selected operation.

It specifies operation details, some of which you can edit before execution:

From

·

Computer: Will show the selected

Record panel

designation.

·

Folder/File: Will show the selected

Record panel

selection path, for one selected folder <Folder path>\*.*, for one selected file <Folder path>\<File name>.

To

·

Computer: Will show the unselected

Record panel

designation.

· Folder/File []: Will highlight the unselected

Record panel

current folder path and for one selected folder *.*, for one selected file <File name>. You can edit the field contents to specify another destination folder and/or file name.

Selected

· Folders: Will show the number of selected folders.

·

Files: Will show the number of selected files.

Options

¨ Include subfolders: Will be enabled and checked if you have selected folders. Leave checked to transfer also selected folder subfolders and their file contents. Uncheck to transfer only selected folders and their file contents.

¨ End session when finished: Check to end the

File manager

session when this operation is finished.

·

Options: Click to show the

Options

window to manage options for this operation.

Click OK to execute the operation to show the

Transfer status

window.

102

Transfer Status

Click OK in the

Copy/Move/Synchronize/Clone

window to show this window:

NetOp Teacher

It will show

File manager

Transfer status

on these tabs:

·

Progress

·

History

·

Session history

Close: Will be enabled after the operation has completed. Click to close the window.

Cancel: Will be enabled during the operation. Click it to interrupt the operation. Executed file transfers will not be undone.

103

Progress Tab

This is the

File manager

Transfer status

window

Progress

tab:

NetOp Teacher

It will show operation execution progress in these elements:

Current command

Will during the operation show the command being executed. Will after the operation show Transfer ended.

Overall progression

Will show these overall progression details:

·

Files transmitted: Will show the number of transferred files.

· Total files: Will show the number of selected files.

· Bytes transmitted: Will show the number of transferred bytes.

· Total bytes: Will show the number of bytes in selected files.

· Elapsed time: Will show the elapsed transfer time.

· Estimated time: Will show the estimated total transfer time.

The colored blocks bar will indicate overall operation progress.

Sending/Sent/Receiving/Received

104

NetOp Teacher

Will show the current or last file transfer local path and name.

The colored blocks bar will indicate the current or last file transfer progress.

·

Bytes sent/received: Number of bytes sent or received in the current or last file transfer.

· BPS: Current or last file transfer speed in bytes per second.

¨ End session when finished: Check to end the

File manager

session when this operation is finished.

History Tab

This is the

File manager

Transfer status

window

History

tab:

Its pane will show a graphical event log of the current or last

File manager

operation. Click [+] buttons to

expand and [-] buttons to collapse the event structure.

Event log elements are explained in the NetOp script section of the NetOp Remote Control User's Manual that is available from the www.netop.com

website, select Support > KnowledgeBase > Documentation >

Manuals. Guest matches

Teacher

and Host matches

Student

.

105

Session History Tab

This is the

File manager

Transfer status

window

Session history

tab:

NetOp Teacher

Its pane will show a graphical event log of the current

File manager

session. Click [+] buttons to expand and

[-] buttons to collapse the event structure.

Event log elements are explained in the NetOp script section of the NetOp Remote Control User's Manual that is available from the www.netop.com

website, select Support > KnowledgeBase > Documentation >

Manuals. Guest matches

Teacher

and Host matches

Student

.

Edit Menu

This is the

File manager

window

Edit

menu:

It contains these commands:

· Select all: Click or press any matching

keyboard shortcut

to select all folders and files in the selected

106

NetOp Teacher

Record panel

.

· Select by: Click or click the

Toolbar

Select files

button or press any matching keyboard shortcut to show

this window:

Replace *.* by a file mask (a file name with wildcard characters like *) and click OK to select selected

Record panel

unselected folders and files by the file mask.

· Deselect by: Click or press any matching

keyboard shortcut

to show this window:

Replace *.* by a file mask (a file name with wildcard characters like *) and click OK to deselect selected

Record panel

selected folders and files by the file mask.

·

Invert selection: Click or press any matching keyboard shortcut to make all selected

Record panel

selected

folders and files unselected and all unselected folders and files selected.

·

Clear selection: Click to deselect all selected

Record panel

selected folders and files.

View Menu

This is the

File manager

window

View

menu:

It contains these commands:

· Large icons: Click to check mark or click the

Toolbar

Large icons

button to show

Record panel

records as

horizontal rows of large icons.

· Small icons: Click to check mark or click the

Toolbar

Small icons

button to show

Record panel

records as

horizontal rows of small icons.

· List: Click to check mark or click the

Toolbar

List

button to show

Record panel

records as vertical columns

of small icons.

107

NetOp Teacher

·

Details: Click to check mark or click the

Toolbar

Details

button to show

Record panel

records in a table

with details in columns.

· Local: Click to check/uncheck or click the

Toolbar

Local

button to switch between remote and local file

management.

· Arrange icons: Expands into these commands:

·

By name: Click or press any matching keyboard shortcut to sort

Record panel

file records by file name,

ascending/descending like the

Details

selection.

·

By type: Click or press any matching keyboard shortcut to sort

Record panel

file records by extension,

ascending/descending like the

Details

selection.

· By size: Click or press any matching

keyboard shortcut to sort

Record panel

file records by file size,

ascending/descending like the

Details

selection.

·

By date: Click or press any matching keyboard shortcut to sort

Record panel

file records by time,

ascending/descending like the

Details

selection.

· Auto arrange: Click to uncheck/check to disable/enable automatic file sorting by the current selection.

Note: Folder records in alphabetically ascending order will always be shown before file records. In

Details

view, click a column heading to sort file records ascending/descending by it.

·

Refresh: Click or press the matching keyboard shortcut to retrieve new information from the computers to

refresh

Record panel

contents.

Options Menu

This is the

File manager

Options

menu:

It contains this command:

· Options: Click to show this window:

108

It enables you to specify

File manager

options on these tabs:

·

Transfer

·

Confirmation

·

Layout

NetOp Teacher

109

Transfer Tab

This is the

File manager

Options

window

Transfer

tab:

NetOp Teacher

It enables you to specify

File manager

Transfer

options in these elements:

Synchronize

¨ Transfer only if file exists: Check to

Synchronize files

only if they exist in the unselected

Record panel

.

¨ Transfer only one way: Check to

Synchronize files

only from the selected

Record panel

to the unselected

Record panel

.

General Transfer

þ Include subfolders: Leave checked to transfer also the contents of subfolders of selected folders.

þ Use delta file transfer: Leave checked to compare source files with matching destination files to transfer only differences between source and destination files to save transmission bandwidth.

þ Enable crash recovery: Leave checked to transfer files in a way that they can be recovered after a computer or network crash during file transfer.

¨ Close dialog when finished: Check to close the

Transfer status

window when a file transfer is finished.

¨ End session when finished: Check to end the

File manager

session when a file transfer is finished.

Default: Click to restore tab default settings.

110

Confirmation Tab

This is the

File manager

Options

window

Confirmation

tab:

NetOp Teacher

It enables you to specify

File manager

Confirmation

options in these elements:

Confirm when...

þ Delete non-empty folders: Leave checked to show this window if you are about to delete a folder that contains folders or files:

Skip: Click to skip deleting the specified folder.

Delete: Click to delete the specified folder.

Advanced: Click to show this window:

111

NetOp Teacher

It will show your Delete confirmation selections to enable you to change them for this file transfer operation before continuing.

Cancel: Click to cancel the file transfer at this point. Executed file transfer actions will not be undone.

¨ Overwriting/deleting files: Check to show this window or the

Delete

window if you are about to overwrite or

delete files:

Skip: Click to skip overwriting the specified file.

Overwrite: Click to overwrite the specified file.

Advanced: Click to show this window:

112

NetOp Teacher

Always skip...

Check boxes in this section to skip file transfer in this file transfer operation in case of checked properties:

¨ Existing files

¨ Read-only files

¨ Hidden files

¨ System files

¨ On file write error

¨ On file read error

Confirm when...

This section will show your Overwrite/Delete confirmation selections to enable you to change them for this file transfer operation before continuing.

þ Overwriting existing files: Leave checked to show the

Overwrite

window if you are about to overwrite

existing files.

þ Overwriting/deleting read-only files: Leave checked to show the relevant confirmation window if you are about to overwrite/delete read-only files.

þ Overwriting/deleting hidden files: Leave checked to show the relevant confirmation window if you are about to overwrite/delete hidden files.

þ Overwriting/deleting system files: Leave checked to show the relevant confirmation window if you are about to overwrite/delete system files.

þ Overwriting/deleting read-only files: Leave checked to show the relevant confirmation window if you are about to overwrite/delete read-only files.

þ Overwriting/deleting hidden files: Leave checked to show the relevant confirmation window if you are about to overwrite/delete hidden files.

113

NetOp Teacher

þ Overwriting/deleting system files: Leave checked to show the relevant confirmation window if you are about to overwrite/delete system files.

¨ Drag and drop (copying files with the mouse): Check to show a confirmation window before executing a drag and drop file transfer.

Default: Click to restore tab default settings.

Layout Tab

This is the

File manager

Options

window

Layout

tab:

It enables you to specify

File manager

Layout

options in these elements:

Screen

þ Show toolbar: Leave checked to show the

File manager

window

Toolbar

.

þ Show status bar: Leave checked to show a status bar at the bottom of the two

Record panels

.

þ Save session path at exit: Leave checked to show the same

Record panel

contents when starting a

File manager

session with the same

Student

next time. Uncheck to always show the system drive contents

when starting a

File manager

session.

Keyboard

Select one of these options:

¤ Use system hotkey layout: Use the operating system hot key layout, see the table below.

¡ Use NetOp hotkey layout: Use the NetOp hot key layout, see the table below.

Function

Copy files

Move files

New folder

Windows hot key NetOp hot key

F3

F6

F7

114

NetOp Teacher

Delete

Rename

Close

Properties

Select all

Select by

Deselect by

Invert selection

Arrange icons by name

Arrange icons by type

Arrange icons by size

Arrange icons by date

Refresh

Select the left record panel

Select the right record panel

Help

DELETE

F2

ALT+F4

ALT+ENTER

CTRL+A

F5

F1

Note: Hot keys will be shown next to menu commands.

-

*

+

F8

F10

SHIFT+F1

CTRL+F3

CTRL+F4

CTRL+F6

CTRL+F5

CTRL+R

ALT+F1

ALT+F2

F1

Icons

Select one of these options:

¡ Local associated and Host 'exe' icons: Show

Record panel

file icons according to

Teacher

file associations

but show

Student

.exe file icons according to

Student

file associations.

¤ Local associated icons: Show

Record panel

file icons according to

Teacher

file associations (saves

transmission bandwidth).

¡ Default icons: Show the same default icon for all

Record panel

files (saves transmission bandwidth and

processor capacity).

Default: Click to restore tab default settings.

Help Menu

This is the

File manager

Help

menu:

It contains this command:

· Help topics F1: Click or press F1 to show NetOp Teacher Help.

Toolbar

This is the

File manager

toolbar:

It contains these buttons:

Copy files: Select

Record panel

records and click or click the

File

menu or

Record panel

context

menu

Copy files

command or press any matching

keyboard shortcut to show the

Copy

window.

Note: Alternatively, drag records from one

Record panel

to the other and drop them to typically show

the

Transfer status

window.

115

NetOp Teacher

Move files: Select

Record panel

records and click or click the

File

menu or

Record panel

context

menu

Move files

command or press any matching

keyboard shortcut to show the

Move

window.

Synchronize files: Click or click the

File

menu

Sync files

command to show the

Synchronize

window.

Note: By default,

Synchronize files

will transfer folders and files to include folders and files that exist in

either

Record panel

in both

Record panels

replacing older files by newer files. On the

Options

window

Transfer

tab, you can select the

Synchronize

options

Transfer only if file exists

and

Transfer only one way

.

Clone files: Click or click the

File

menu

Clone files

command to show the

Clone

window.

Note:

Clone files

will delete all folders and files in the unselected

Record panel

and copy all folders

and files in the selected

Record panel

to the unselected

Record panel

.

New folder: Click or click the

File

menu

New folder

command or press any matching keyboard shortcut

to show the

New folder

window.

Delete: Select

Record panel

records and click or click the

File

menu or

Record panel

context menu

Delete

command or press the matching

keyboard shortcut to delete selected records. If

selected , a

confirmation window will be shown.

Properties: Select a

Record panel

record and click or click the

File

menu or

Record panel

context

menu

Properties

command or press the matching

keyboard shortcut

to show the

Properties

window.

Select by: Click or click the

Edit

menu

Select by

command or press any matching

keyboard shortcut to

show the

Select

window.

Options: Click or click the

Options

menu

Options

command to show the

Options

window.

Local: Click to appear pressed in/released or click the

View

menu

Local

command to check/uncheck it to switch between remote and local file management.

Large Icons: Click to appear pressed in or click the

View

menu

Large icons

command to check mark it to show

Record panel

records as horizontal rows of large icons.

Small Icons: Click to appear pressed in or click the

View

menu

Small icons

command to check mark it

to show

Record panel

records as horizontal rows of small icons.

List: Click to appear pressed in or click the

View

menu

List

command to check mark it to show

Record panel

records as vertical columns of small icons.

Details: Click to appear pressed in or click the

View

menu

Details

command to check mark it to show

Record panel

records in a table with details in columns.

116

Record Panel

The two

File manager

record panels have identical layout:

NetOp Teacher

The top title bars will show <Teacher> in the left record panel and the

Student

name in the right record panel.

In a local file transfer session, the right record panel will show Teacher.

The selected record panel title bar will have a strong color and the unselected record panel title bar will have a dimmed color. Click in a record panel or press a

keyboard shortcut

to select it. Press TAB to switch the record panel selection. Record panels will remain equally sized.

The folder bar below contains a left drive drop-down box and a right folder drop-down box.

The drive drop-down box field will show the selected drive icon and letter. The drop-down box list will contain the icon, letter and name of local and mapped network drives. Click a drive in the list to show it in the field.

The folder drop-down box field will show the path of the selected folder. The drop-down box list will contain the paths of up to 30 folders that have been selected during the current

File manager

session. Select a folder

path in the list to show it in the field to show folder contents in the records pane below. Alternatively, specify a folder path in the drop-down box field and press ENTER to select the folder.

The records pane below will contain records of folders and files in the selected folder as

Large icons

,

Small icons

,

List

or

Details

. Change the view from the

Toolbar

or the

View

menu. Folder records in alphabetically

ascending order are shown before file records. Sort file records by clicking

Details

column headings or by

pressing a keyboard shortcut

.

Details

will show record details in a table with these column contents:

· Name: Record name.

117

NetOp Teacher

·

Ext: <DIR> for folder, file extension for file.

· Size: File size in bytes. Folder size is 0 bytes.

· Date: Date and time of last record change.

·

Attrib: First letters of record attributes:

· r: Read-only

· a: Archive

· h: Hidden

· s: System

Double-click a folder record to select this folder to show its path in the folder bar and its contents in the records pane.

Double-click a records pane top folder record with two period characters (..) to move one step up in the folder tree structure.

The bottom status bar will show the number of bytes in the number of selected record files. Bytes in files in selected folder record folders are not included in the byte count.

Execute file transfers and manage records from

Toolbar

buttons and menu commands.

Right-click a record or multiple selected records to show this context menu:

Top section commands that may be different with different file selections and computer setups are similar to

Windows Explorer right-click context menu commands.

Lower sections commands match

File

menu commands.

Drag selected records in one record pane to the other record pane and drop them to copy them to a record folder, if highlighted, or to the folder whose records are shown in the pane.

Press the right mouse button and drag selected records in one record pane to the other record pane and drop them to show this context menu:

·

Copy here: Click to copy selected records to a record folder, if highlighted, or to the folder whose records are shown in the pane.

·

Move here: Click to move selected records to a record folder, if highlighted, or to the folder whose records are shown in the pane.

· Cancel: Click to cancel the attempted file transfer.

118

3.2.3.9 Policy

This is the

Teacher

window

Toolbar

Policy

button and menu:

NetOp Teacher

Policy

enables applying an

Application

and

Internet

Policy

to selected

Students

.

The

Options

window

Class

tab

Policy

section

Startup policy

drop-down box selection determines the

Policy

that will apply to

Students

when they connect to a

Class

.

To apply a

Policy

to selected

Students

, click the

Action

menu

Policy

command or the

Toolbar

Policy

button to

apply the default

Policy

or click a

Policy

menu command to apply an available

Policy

.

The

Policy

menu that opens from the

Toolbar

Policy

button down pointer button will contain these

commands:

·

Reset policy: Click to apply the

Class

Startup policy

to selected

Students

.

· Allow all: Click to allow selected

Students

to run all

Applications

and access all

Internet

addresses.

· Deny all: Click to deny selected

Students

to run all

Applications

and access all

Internet

addresses.

· <Policy name>: Click to apply a user specified

Policy

to selected

Students

. The

Policy

menu can contain

multiple user specified

Policy

commands.

·

Options: Click to show the

Options

window

Policy

tab to manage

Policies

.

Note: The default

Policy

name will be enclosed by asterisks.

3.2.3.10 Record

This is the

Teacher

window

Toolbar

Record

button:

Record

enables creating a

Teacher

computer desktop NetOp recording.

Note: You can also create a

Teacher

computer desktop NetOp recording from the

Remote control

window

Title bar

menu or

Toolbar or toolbox

, from the

Monitor toolbox

and from the the

Recordings view

pane

context menu. You can create a .avi screen video with

NetOp screen video

.

Click the

Record

button to start recording the

Teacher

computer desktop showing this

Recording toolbox

:

It contains these tool tip identified buttons:

119

End session: Click to end recording closing the toolbox and showing this window:

NetOp Teacher

To facilitate identifying recordings in the

Recordings

view, rename New recording into another

recording name and click OK to apply.

Note: Each NetOp recording will automatically be saved in the

Teacher

User configuration files

folder

screcord folder in a file named <Date and time>-Teacher-<Recording name>.dwr.

Record: Click to resume recording after Pause.

Pause: Click to pause recording.

Start/Stop NetOp marker utility: Click to make the button appear pressed in to load

NetOp marker utility

on the

Teacher

computer. Click to make the button appear released to unload

NetOp marker utility

.

Start/Stop microphone: Click to make the button appear pressed in to include

Teacher

computer microphone input in the recording. Click to make the button appear released to exclude

Teacher

computer microphone input.

120

3.2.4 Class Control Panel

This is the

Teacher

window

Class control panel

:

NetOp Teacher

It enables managing the running

Class

in views that you can select by clicking left view selection bar buttons:

121

NetOp Teacher

Details view

: The upper

Details view

pane enables managing

Class

Students

shown as

records with details in columns. The lower

Groups

pane enables managing

Class

Student groups

shown as icons or records.

Classroom view:

The upper

Classroom view

pane enables managing

Class

Students

shown as named icons on an image background. The lower

Groups

pane enables managing

Class

Student groups

shown as icons or records.

Thumbnails view:

The upper

Thumbnails view

pane enables managing

Class

Students

shown

as named computer screen miniature images on an image background. The lower

Groups

pane enables managing

Class

Student groups

shown as icons or records.

Lesson plan view

: Enables creating, managing and executing

Class

Lesson plans

.

Recordings view

: The upper

Recordings view

pane enables managing

Class

screen image

Recordings

. The lower

Groups

pane enables managing

Class

Student groups

shown as icons or records.

Tests view

: The upper

Tests view

pane enables managing

Class

Tests

,

Surveys

and their

Results

. The lower

Groups

pane enables managing

Class

Student groups

shown as icons or

records.

Activity view

: The upper

Activity view

pane enables managing which

Applications

and

Websites

Class

Students

shown as records are running. The lower

Active applications and sites

pane enables managing which applications and websites shown as records are run by

which

Class

Students

.

Class setup view:

The upper

Class setup view

pane enables managing

Class

Students

and

Student groups

shown as icons in a

Class

structure. The lower

Available students

pane

enables managing

Students

that are available for any

Class .

122

3.2.4.1 Details View

This is the

Class control panel

Details view :

NetOp Teacher

It enables you to manage

Class

Students

shown as records and

Student groups

.

A moveable horizontal separation divides it into two panes:

· The upper

Details view

pane enables you to manage

Class

Students

shown as table records.

· The lower

Groups

pane enables you to manage

Class

Student groups

shown as icons or table records.

123

3.2.4.1.1 Details View Pane

This is the

Details view

pane:

NetOp Teacher

Its title bar will show the names of the view and the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The title bar right end will show a part/whole button:

Click it to switch between part mode without the upper right sector and whole mode with the upper right sector. In part mode, only connected

Students

will be shown in the pane. In whole mode, also unconnected

Student

members of the

Class

will be shown.

Class

Students

will be shown as records in a table with these column contents:

· Status: Icons will indicate

Student

status:

Unconnected.

In a

Demonstrate

session.

In an

Attention

session.

In a

Remote control

session.

In a

Monitor

session.

In an

Audio-video chat

session.

In a

Chat

session.

Assistant

Teacher

in a

Workgroup

session.

In a

Distribute files

session.

In a

Collect files

session.

124

NetOp Teacher

In a

File manager

session.

Has a pending

Help request

.

·

Student display name:

Student

name as selected in the

Options

window

General

tab

Student display name

section.

· Windows login name:

Student

computer Windows user login name.

·

Computer name:

Student

computer Windows name.

·

Policy:

Student

applied

Policy

name or None.

· Information: Any

Student

status messages such as a

Help request

message.

You can add up to two more custom columns from the

Options

window

General

tab

Display custom columns in details view

section.

To execute an action with a connected

Student

, click its record to highlight it as selected and click a

Toolbar

button or button menu command,

Action

menu command or

Selected view

menu command or right-click its

record and click a

Student context menu

command.

To start a

Remote control

session with a connected

Student

, double-click its record.

To execute an action with multiple connected

Students

, select

Students

by one of these methods:

· Click one record and while pressing the SHIFT key click another record to select clicked and in between records connected

Students

.

·

Click records while pressing the CTRL key to select clicked records connected

Students

.

· From outside records, drag a dotted rectangle to select connected

Students

whose records are covered by

the rectangle.

Selecting connected

Students

will enable all available

Toolbar

buttons and

Action

menu commands. Click a

button or command to execute the action with selected

Students

.

Note: To execute an action with multiple

Students

, it may be faster and easier to create a

Student group

for

this purpose.

3.2.4.1.2 Change Class Menu

In the

Class control panel

upper pane title bar, click the down pointer button to the right of the

Class

name to

show this

Change class

menu:

It contains these commands:

·

<Running class>: Will be included unless the

Options

window

Class

tab

Use class server

box is checked.

The running

Class

disabled name will be check marked.

·

<Previous class>: Will be included unless the

Options

window

Class

tab

Use class server

box is checked.

Up to ten enabled names of previously run

Classes

can be included. Click a previously run

Class

name to

end running the <Running class> to start running the clicked name

Class .

Caution: Changing the

Class

will disconnect connected

Students

.

· Show all classes: Will be enabled unless the

Options

window

Class

tab

Use class server

box is checked.

Click to show this window:

125

NetOp Teacher

It enables you to select a

Teacher

specified

Class .

The pane will contain the names of available

Teacher

specified

Classes

.

Select a

Class

name and click OK to end the running

Class

to start the selected

Class

.

Caution: Changing the

Class

will disconnect connected

Students

.

·

Ask class server: Will be enabled if the

Options

window

Class

tab

Use class server

box is checked. Click

to show the

Select class

window.

·

Options: Click to show the

Options

window

Class

tab.

3.2.4.1.3 Groups Pane

This is the

Class control panel

Groups

pane:

It enables you to manage

Student groups

.

Right-click in the pane outside a

Student group

icon or record to show this menu:

It contains these commands:

·

Large icons: Click to show

Student groups

as horizontal rows of large icons.

126

NetOp Teacher

·

Small icons: Click to show

Student groups

as horizontal rows of small icons.

· List: Click to show

Student groups

as vertical columns of small icons.

·

Details: Click to show

Student groups

as records in a table with these column contents:

·

Group name:

Student group

name.

· Member count:

Student group

number of members.

· Members:

Student group

members'

Student display name

.

· Create group: Click to show this window:

Specify the

Student group

name and click OK to create the

Student group

.

Note: You can edit or delete a

Student group

in

Class setup view

.

The

Groups

pane will always contain an All

Student group

that contains all

Students

in the

Class

.

You can add

Students

to a

Student group

by dragging their

View

pane records, icons or thumbnails to a

Groups

pane

Student group

record or icon and drop them. Each

Student

can be a member of multiple

Student groups

.

To execute actions with connected

Students

in a

Student group

, right-click the

Student group

icon or record

to show the

Student group context menu

. It will also contain a

Delete

command by which you can delete the

Student group .

To execute actions with connected

Students

in multiple

Student groups

, select

Students

by one of these

methods:

· Click a

Student group

icon or record to select it and connected

Students

in it.

· Click

Student group

icons while pressing the SHIFT or CTRL key to select them and connected

Students

in

them.

·

Click one

Student group

record and while pressing the SHIFT key click another

Student group

record to

select clicked and in between records

Student groups

and connected

Students

in them.

· Click

Student group

records while pressing the CTRL key to select clicked records

Student groups

and connected

Students

in them.

· From outside icons or records, drag a dotted rectangle to select

Student groups

whose icons or records are covered by the rectangle and connected

Students

in them.

· Click the All

Student group

to select all connected

Students

in the

Class

.

This will enable all available

Toolbar

buttons and

Action

menu commands.

127

NetOp Teacher

3.2.4.1.4 Student Context Menu

Right-click a connected

Student

Details view

record,

Classroom view

icon or

Thumbnails view

thumbnail to

show this context menu:

It enables you to execute actions with the right-clicked

Student

from these commands:

· Demo this student: Will be enabled if at least one other connected

Student

is selected. Click to

Demonstrate

the right-clicked

Student

desktop to other selected

Students

.

·

Apply attention on this student: Click to start an

Attention

session with the

Student

.

· Monitor this student: Click to start a

Monitor

session with the

Student

.

· Remote control this student: Click to start a

Remote control

session with the

Student

.

· Chat with this student: Click to start a

Chat

session with the

Student

.

·

Audio-video chat with this student: Click to start an

Audio-video chat

session with the

Student

.

· Send message to this student: Click to create a

NetOp message

to the

Student

.

·

Stop workgroup session: Will be enabled if the

Student

is assistant

Teacher

in a

Workgroup

. Click to end

the

Workgroup

session.

·

Move this student to another class: Click to show this window:

128

NetOp Teacher

It enables you to temporarily move the

Student

to a running

Class

on another computer.

·

To temporarily move the

Student

to a specific name running

Class

of a

Teacher

that the

Student

can

reach by browse communication, click Class name, specify the

Class

name and click Move.

·

To temporarily move the

Student

to the running

Class

of a specific address

Teacher

, click Teacher IP

address or DNS name, specify the

Teacher

computer IP address or DNS name and click Move.

If the

Class

is not found and when the moved to

Class

ends running, the

Student

will return.

· Run a test on this student: Will expand into available

Tests

. Click one to run it on the

Student

.

·

Run a survey on this student: Will expand into available

Surveys

. Click one to run it on the

Student

.

· Run a program on this student: Will expand into the

Run

menu

Run program

elements. Click one to run it on the

Student

.

· Execute command on this student: Will expands into the

Commands

menu. Click a command to execute it

on the

Student

.

· Collect files from this student: Click to start a

Collect files

session with the

Student

.

·

Distribute files to this student: Click to start a

Distribute files

session with the

Student

.

· Distribute files on clipboard: Will be enabled if files are stored on the

Teacher

computer clipboard. Click to

Distribute

the

Teacher

computer clipboard contents to the most recently specified

Student

computer file

location.

·

File transfer with this student: Click to start a

File manager

session with the

Student

.

· Clear help request: Will be enabled if a help request from this

Student

is pending. Click to cancel the help

request on

Teacher

and

Student

.

Note: The menu can contain additional

View

specific commands. Commands will be disabled if unavailable

with the current

Teacher

status.

3.2.4.1.5 Student Group Context Menu

Right-click a

Groups

pane

Student group

icon or record to show this context menu:

It enables you to execute actions with the connected

Students

in the right-clicked

Student group

from these

commands:

Note: If no

Students

in the

Student group

are connected, the menu will contain only

Create group

and

Delete

129

NetOp Teacher

.

· Demo to this group: Will expand into the

Demonstrate

menu. Click an element to start a

Demonstrate

session with the

Student group

connected

Students .

· Apply attention on this group: Click to start an

Attention

session with the

Student group

connected

Students

.

·

Monitor this group: Click to start a

Monitor

session with the

Student group

connected

Students

.

·

Chat with this group: Click to start a

Chat

session with the

Student group

connected

Students

.

·

Audio-video chat with this group: Click to start an

Audio-video chat

session with the

Student group

connected

Students

.

·

Send message to this group: Click to create a

NetOp message

to the

Student group

connected

Students

.

·

Workgroup session for this group: Click to start a

Workgroup

session with the

Student group

connected

Students

.

·

Move this group to another class: Click to show this window:

It enables you to temporarily move the

Student group

connected

Students

to a running

Class

on another computer.

·

To temporarily move the

Student group

connected

Students

to a specific name running

Class

of a

Teacher

that the

Student group

connected

Students

can reach by browse communication, click Class

name, specify the

Class

name and click Move.

·

To temporarily move the

Student group

connected

Students

to the running

Class

of a specific address

Teacher

, click Teacher IP address or DNS name, specify the

Teacher

computer IP address or DNS

name and click Move.

If the

Class

is not found and when the moved to

Class

ends running, the

Student group

connected

Students

will return.

· Run a test on this group: Will expand into available

Tests

. Click one to run it on the

Student group

connected

Students

.

·

Run a survey on this group: Will expand into available

Surveys

. Click one to run it on the

Student group

connected

Students

.

·

Run a program on this group: Will expand into the

Run

menu

Run program

elements. Click one to run it on

the

Student group

connected

Students

.

·

Execute command on this group: Will expands into the

Commands

menu. Click a command to execute it on the

Student group

connected

Students

.

· Distribute files to this group: Click to start a

Distribute files

session with the

Student group

connected

Students

.

· Collect files from this group: Click to start a

Collect files session with the

Student group

connected

Students

.

130

NetOp Teacher

·

Distribute files on clipboard: Will be enabled if the

Teacher

computer clipboard contains files. Click to start

a

Distribute files

session with the

Student group

connected

Students

using clipboard

Source

files.

·

Create group: Click to show the

New folder

window to create a

Student group

.

· Delete: Click to show a confirmation window to confirm deleting the

Student group

.

Note: Commands will be disabled if unavailable with the current

Teacher

status.

3.2.4.2 Classroom View

This is the

Class control panel

Classroom view :

It enables you to manage

Class

Students

shown as icons and

Student groups

.

A moveable horizontal separation divides it into two panes:

· The upper

Classroom view

pane enables you to manage

Class

Students

shown as named icons on an image background.

· The lower

Groups

pane enables you to manage

Class

Student groups

shown as icons or table records.

131

3.2.4.2.1 Classroom View Pane

This is the

Classroom view

pane:

NetOp Teacher

Its title bar will show the names of the view and the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The title bar right end will show a part/whole button:

Click it to switch between part mode without the upper right sector and whole mode with the upper right sector. In part mode, only connected

Students

will be shown in the pane. In whole mode, also unconnected

Student

members of the

Class

will be shown.

Class

Students

will be shown as these variants of named icons:

Connected: The

Student

is connected to the

Class

but not in session.

Unconnected: The

Student

is recognized as a member but currently not connected to the

Class .

In session: The

Student

is connected to the

Class

and in one or multiple sessions.

Help request: The

Student

is connected to the

Class

with a pending

Help request

.

Students

will preferably be named by their

Student display name

. If no name of the

Student display name

type was specified when the

Student

record was created, the name with which the

Student

record was created will be enclosed in brackets.

You can drag

Student

icons all over the pane. If the pane size has been reduced to leave

Student

icons outside the visible part of the pane, the pane will have scrollbars.

132

Right-click in the pane to show this context menu:

Note: Any other commands in the menu belong to the

Student context menu

.

Click Set background bitmap to show this window:

NetOp Teacher

It enables you to manage the background image in these elements:

Bitmap

þ Enable background bitmap: Leave checked to use a background image. Uncheck to use a white background and disable the other window options.

þ Tile background bitmap: Leave checked to repeat a small background image as tiles covering the entire pane. Uncheck to show the background image only in the upper left corner of the pane.

[] [Browse]: Click [Browse] to show a Windows Open window to select a .bmp image file to show its path in the field.

Tip: The Media folder in the folder in which the

Teacher

is installed contains multiple .bmp background image files. Some users create their own classroom plan or geographical map image for the

Student

icon background.

To execute an action with a connected

Student

, click its icon to highlight it as selected and click a

Toolbar

button or button menu command,

Action

menu command or

Selected view

menu command or right-click its

record and click a

Student context menu

command.

To start a

Remote control

session with a connected

Student

, double-click its icon.

To execute an action with multiple connected

Students

, select

Students

by one of these methods:

·

Click icons while pressing the SHIFT or CTRL key to select clicked icons connected

Students

.

· From outside icons, drag a dotted rectangle to select connected

Students

whose icons are covered by the

rectangle.

Selecting connected

Students

will enable all available

Toolbar

buttons and

Action

menu commands. Click a

button or command to execute the action with selected

Students

.

Note: To execute an action with multiple

Students

, it may be faster and easier to create a

Student group

for

this purpose.

133

3.2.4.3 Thumbnails View

This is the

Class control panel

Thumbnails view

:

NetOp Teacher

It enables you to manage

Class

Students

shown as computer screen miniature images and

Student groups

.

A moveable horizontal separation divides it into two panes:

·

The upper

Thumbnails view

pane enables you to manage

Class

Students

shown as named computer

screen miniature images on an image background.

· The lower

Groups

pane enables you to manage

Class

Student groups

shown as icons or table records.

134

NetOp Teacher

3.2.4.3.1 Thumbnails View Pane

This is the

Thumbnails view

pane:

Its title bar will show the names of the view and the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The title bar right end will show a part/whole button:

Click it to switch between part mode without the upper right sector and whole mode with the upper right sector. In part mode, only connected

Students

will be shown in the pane. In whole mode, also unconnected

Student

members of the

Class

will be shown.

Class

Students

will be shown as these variants of named computer screen miniature images:

Connected: The

Student

is connected to the

Class

.

Unconnected: The

Student

is recognized as a member but currently not connected to

the

Class .

Students

will preferably be named by their

Student display name

. If no name of the

Student display name

type was specified when the

Student

record was created, the name with which the

Student

record was created will be enclosed in brackets.

Right-click in the pane to show this context menu:

135

NetOp Teacher

Note: Any other commands in the menu belong to the

Student context menu

.

It contains these commands:

· Thumbnail: Expands into thumbnail sizes in pixels width times height with a check mark next to the selected size and Customize. Click a size to apply it to thumbnails in pane. Click Customize to show this window:

It enables you to create a customized thumbnail in these elements:

· Width [] X []: Specify the thumbnail pixels width in the field and the horizontal pixels spacing between thumbnails in the spin box.

· Height:[] Y:[]: Specify the thumbnail pixels height in the field and the vertical pixels spacing between thumbnails in the spin box.

· Colors: Select in the drop-down box the number of thumbnail colors from 16 to 16777216.

·

Update interval [] s: Specify the image update interval in seconds in the spin box. Use the controls to adjust the update interval

Note: Smaller thumbnails, fewer colors and a longer update interval will generate less network traffic.

When applied, a customized thumbnail size will appear in the list of thumbnail sizes.

· Sort: Expands into these commands, one of which will be check marked as the currently selected option:

·

None: Thumbnails in horizontal rows from the upper left pane corner will not be sorted.

· Ascending: Thumbnails in horizontal rows from the upper left pane corner will be sorted alphabetically ascending.

· Descending: Thumbnails in horizontal rows from the upper left pane corner will be sorted alphabetically descending.

· Floating: You can drag thumbnails all over the pane. If the pane size has been reduced to leave thumbnails outside the visible part of the pane, the pane will have scrollbars.

· Display group first: Expands into None and the names of available

Student groups

, one of which will be check marked as the current selection. Click a

Student group

name to place the thumbnails of its

Student

members before other thumbnails placed in horizontal rows from the upper left pane corner.

· Set background bitmap: Click to show this window:

136

NetOp Teacher

It enables you to manage the background image in these elements:

Bitmap

þ Enable background bitmap: Leave checked to use a background image. Uncheck to use a white background and disable the other window options.

þ Tile background bitmap: Leave checked to repeat a small background image as tiles covering the entire pane. Uncheck to show the background image only in the upper left corner of the pane.

[] [Browse]: Click [Browse] to show a Windows Open window to select a .bmp image file to show its path in the field.

Tip: The Media folder in the folder in which the

Teacher

is installed contains multiple .bmp background image files. Some users create their own classroom plan or geographical map image for the

Student

thumbnail background.

To execute an action with a connected

Student

, click its thumbnail to highlight it as selected and click a

Toolbar

button or button menu command,

Action

menu command or

Selected view

menu command or

right-click its record and click a

Student context menu

command.

To start a

Remote control

session with a connected

Student

, double-click its thumbnail.

To execute an action with multiple connected

Students

, select

Students

by one of these methods:

·

Click thumbnails while pressing the SHIFT or CTRL key to select clicked icons connected

Students

.

·

From outside thumbnails, drag a dotted rectangle to select connected

Students

whose thumbnails are covered by the rectangle.

Selecting connected

Students

will enable all available

Toolbar

buttons and

Action

menu commands. Click a

button or command to execute the action with selected

Students

.

Note: To execute an action with multiple

Students

, it may be faster and easier to create a

Student group

for

this purpose.

137

3.2.4.4 Lesson Plan View

This is the

Class control panel

Lesson plan view :

NetOp Teacher

It enables you to create, manage and execute

Lesson plans

that facilitate running a

Class

smoothly by using prepared

Lesson actions

that shall be executed during the

Class

.

Its title bar will show the names of the view and the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The title bar right end will show <No lesson plan selected> or the selected

Lesson plan

name.

Click the down pointer button to the right of <No lesson plan selected> or the selected

Lesson plan

name to

show the

Change lesson plan

menu.

Click the title bar far right Execute button ( ) to execute the

Lesson action

whose record is selected in the

table below.

The table will contain

Lesson action

records with these column details:

· Description:

Toolbar

button action type icon, execution icon (Undone (nothing), Done ( ) or Disabled ( )) and

Lesson action

description.

·

Action: Action

menu or

Toolbar

button action type name.

· Details: Action option name, if applicable.

· Student/Group: Name of the

Student

or

Student group

on which the

Lesson action

will be executed.

·

Notes: First line of the

Lesson action

notes.

The Notes pane below will show the complete selected

Lesson action

record notes.

Right-click a

Lesson action

record to show this context menu:

138

NetOp Teacher

It will contain some or all of these commands:

· Execute: Will be disabled if the selected

Lesson action

record is marked Done ( ) or Disabled ( ). Click,

click the

Lesson plan view

title bar far right Execute button ( ) or double-click the

Lesson action

record to

execute the

Lesson action

.

· Add: Click to show the

Lesson action

window to add a

Lesson action

record below the selected

Lesson action

record.

· Edit: Click to show the

Lesson action

window to edit the selected

Lesson action

record.

·

Delete: Click to delete the selected

Lesson action

record.

· Disable/Enable: Click to disable/enable the selected

Lesson action

record marking it accordingly.

·

Mark as done/undone: Click to mark the selected enabled

Lesson action

record as Done (

) or Undone

(nothing).

· Move up (-): Click or press - (minus) to move the selected

Lesson action

record one step up.

·

Move down (+): Click or press + (plus) to move the selected

Lesson action

record one step down.

3.2.4.4.1 Change Lesson Plan

Click the

Lesson plan view

title bar

Change lesson plan

down pointer to show this

Change lesson plan

menu:

It enables you to manage

Lesson plans

from these commands.

·

The upper menu section can contain the disabled and check marked name of the selected

Lesson plan

and the names of up to ten previously selected

Lesson plans

. Click a previously selected

Lesson plan

to

select it to show it in the

Lesson plan view .

· Show all lesson plans: Click to show this window:

139

NetOp Teacher

The pane will contain all

Lesson plans

of the running

Class

. Select a

Lesson plan

and click Select to show

it in the

Lesson plan view

.

Manage lesson plans: Click to show this window:

It enables you to create, copy, delete and select

Lesson plans

in these elements:

· The pane will contain all

Lesson plans

of the running

Class

.

· New: Click to show this window:

Specify a

Lesson plan

name and click OK to create an empty

Lesson plan

.

· Copy: Select a

Lesson plan

in the pane and click to show the

Lesson plan

window. Specify a

Lesson plan

name and click OK to create a copy of the selected

Lesson plan

.

· Delete: Select a

Lesson plan

in the pane and click to delete it.

· Select: Select a

Lesson plan

in the pane and click to show it in the

Lesson plan view .

140

NetOp Teacher

·

Close: Click to close the window without showing the selected

Lesson plan

in the

Lesson plan view

.

Note:

Lesson plan

.xml files will by default be stored in the

Teacher

User configuration files

Lessonpl folder.

You can change the

Lesson plan

files folder in the

Options

window

Sharing

tab

Lesson plans

element.

3.2.4.4.2 Lesson Action

Click the

Lesson action

menu

Add

or

Edit

command to show this window:

It enables you to create or edit a

Lesson action

record in these elements:

· Action []: The drop-down box list will contain available

Toolbar

button icons and names. Click the

Toolbar

button icon and name under which to specify the desired action to show it in the field as selected. If options are available under the selected

Toolbar

button, a [Configure] button will be available. Click it to show the

Toolbar

button options window to select an option to show it or its selection elements under the Action drop-down box. Complete available selections to specify the action.

· Student/Group []: Depending on the specified action, the drop-down box list will contain available

Student

or

Student group

names. Click one to show it in the field to execute the action on the shown

Student

or

Student group

Student

members.

·

Description []: Specify what shall identify the

Lesson action

in the

Lesson plan view

table

Description

column.

· Notes []: Specify in the pane the notes that shall accompany the

Lesson action .

141

3.2.4.5 Recordings View

This is the

Class control panel

Recordings view :

NetOp Teacher

It enables you to manage and play back

NetOp recordings

and manage

Student groups

.

A moveable horizontal separation divides it into two panes:

· The upper

Recordings view

pane enables you to play back and manage

Class

NetOp recordings

.

· The lower

Groups

pane enables you to manage

Class

Student groups

shown as icons or table records.

142

NetOp Teacher

3.2.4.5.1 Recordings View Pane

This is the

Recordings view

pane:

Its title bar will show the names of the view and the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The left folders pane will initially contain a Recordings root folder. Right-click in the folders pane to show this context menu:

It contains these commands:

· Cut: Select a user created folder and click to remove the folder with its contents to place it on the clipboard.

· Copy: Select a folder and click to place a copy of the folder with its contents on the clipboard.

· Paste: Click to paste the clipboard contents into the selected folder.

· New folder: Click to create a folder in the selected folder showing this window:

Specify the folder name and click OK to create.

·

Delete: Select a folder and click to show a confirmation window to confirm deleting the folder with its

143

NetOp Teacher

contents.

· Rename: Select a folder and click to show this window:

Edit the folder name and click OK to rename

Note: New NetOp recordings will by default be saved in the

Teacher

User configuration files

folder

screcord folder <

Class

name> folder to appear as records in the Recordings root folder. You can change

the recordings files folder in the

Options

window

Sharing

tab

Recordings

element.

The right records pane will show selected folder recording records in a table with these column contents:

· Name: Recording icon and recording name.

· Recorded: Recording date and time.

·

Duration: Recording duration.

· Teacher: Recording type of NetOp module.

Right-click in the records pane to show this context menu:

It contains these commands:

· Local playback: Click to play back the most recently clicked record recording in the

Recording playback

window.

· Rename: Click to rename the most recently clicked record recording in this window:

Edit the recording name and click OK to rename.

· Cut: Select one or multiple (pressing SHIFT or CTRL) records and click to remove records to place them on the clipboard.

· Copy: Select one or multiple (pressing SHIFT or CTRL) records and click to place a copy of them on the clipboard.

144

NetOp Teacher

·

Paste: Click to paste the clipboard contents into the records pane.

· New: Expands into:

·

Local recording: Click to start a

Record

session.

·

Folder: Click to show the

New folder

window to create a folder in the selected folder.

· Delete: Select one or multiple (pressing SHIFT or CTRL) records and click to show a confirmation window to confirm deleting them.

Drag or press CTRL and drag selected records to a folder and drop them to move or copy selected records to the folder.

Drag records to a

Groups

pane

Student group

and drop them to distribute record recording files to

Student group

connected

Students

.

Double-click a record to play back the record recording in the

Recording playback

window.

Note: You can create a .avi screen video with

NetOp screen video

.

3.2.4.5.2 Recording Playback

In the

Teacher

Recordings view pane

records pane, double-click a record or click the context menu

Local playback

command or in the

Student

Recordings

tab records pane double-click a record or click the context

menu

Playback recording

command to play back the recording in this window:

Note: If you run a

Demonstrate

Recording

session, the recording will play back in the same window on the

Teacher

.

145

NetOp Teacher

The window title bar will next to the window name show the

Recording name

.

The toolbar below contains these playback controls:

Stop: Click, click the title bar menu Stop command or use a window Close control to stop playing the recording and close the window.

Pause: Click or click the title bar menu Pause command to pause playing the recording.

Play: Click or click the title bar menu Play command to start or resume playing the recording.

Back: Click or click the title bar menu Back command to return to the beginning of the recording.

Speed: Use the up/down controls to multiply the playback speed by a factor up to x20.

The automatically scrolling pane will have scrollbars.

The bottom status bar has a colored blocks progress indicator and will show elapsed playing time in the format HH:MM:SS.

3.2.4.6 Tests View

This is the

Class control panel

Tests view

:

It enables you to create, manage and execute

Class

Tests

and

Surveys

and manage their

Results

and

manage

Student groups

.

A moveable horizontal separation divides it into two panes:

·

The upper

Tests view

pane enables you to create, manage and execute

Class

Tests

and

Surveys

and

manage their

Results

.

·

The lower

Groups

pane enables you to manage

Class

Student groups

shown as icons or records.

146

NetOp Teacher

3.2.4.6.1 Tests View Pane

This is the

Tests view

pane:

Its title bar will show the name of the view, initially with the addition (Public), and the name of the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The left folders pane will initially contain a Tests root folder. Right-click in the folders pane to show this context menu:

It contains these commands:

· Cut: Select a user created folder and click to remove the folder with its contents to place it on the clipboard.

· Copy: Select a folder and click to place a copy of the folder with its contents on the clipboard.

· Paste: Click to paste the clipboard contents into the selected folder.

·

New folder: Click to create a folder in the selected folder showing this window:

147

NetOp Teacher

Specify the folder name and click OK to create.

· Delete: Select a user created folder and click to show a confirmation window to confirm deleting the folder with its contents.

· Rename: Select a user created folder and click to show this window:

Edit the folder name and click OK to rename.

·

Public tests: Click to show (Public) in the

Tests view pane

title bar to show in the pane only folders and records that are shared by all users of the

Teacher

computer. Public folders and tests will be stored in

an All Users

User configuration files

folder Tests sub-folder.

· Private tests: Click to show (Private) in the

Tests view pane

title bar to show in the pane only folders and

records that are private to the user logged in to the

Teacher

computer. Private folders and tests will

initially be stored in a personal

User configuration files

folder Tests sub-folder.

· Private folder: Click to show a Browse for folder window that initially will show the path to your initial private Tests sub-folder. Select another folder to make it your private folder.

The right records pane will show selected folder records on three tabs named

Tests

,

Results

and

Surveys

in

a table with these column contents:

·

Name:

Test

or

Survey

name, on the

Results

tab also run date and time.

· Author:

Test

or

Survey

author name (optional, not on the

Results

tab).

·

Time:

Test

or

Survey

most recent modification date and time (not on the

Results

tab).

· Description:

Test

or

Survey

description (optional, not on the

Results

tab).

· Class:

Test

or

Survey

run

Class

name (

Results

tab only).

·

Score:

Test

or

Survey

run average score percentage (

Results

tab only).

· Group:

Test

or

Survey

run

Student group

name, if applicable (

Results

tab only).

Right-click in the records pane to show this context menu:

It contains these commands:

· Rename: Select a record and click to rename it in this window:

148

NetOp Teacher

Edit the

Test

or

Survey

name and click OK to rename.

· Edit: Not included on the

Results

tab. Select a record and click or double-click the record to show the

Test designer

or

Survey

window to edit the

Test

or

Survey

.

· Cut: Select one or multiple (pressing SHIFT or CTRL) records and click to remove records to place them on the clipboard.

· Copy: Select one or multiple (pressing SHIFT or CTRL) records and click to place a copy of them on the clipboard.

· Paste: Click to paste the clipboard contents into the records pane.

·

New test: Included only on the

Tests

tab. Click to show the

New test

window.

·

View: Included only on the

Results

tab. Click to show the

Test report

window.

· New survey: Included only on the

Surveys

tab. Click to show the

New survey

window.

·

Delete: Select one or multiple (pressing SHIFT or CTRL) records and click to show a confirmation window to confirm deleting them.

·

Properties: Not included on the

Results

tab. Select a record and click to show a read-only

Options

window to view

Test

or

Survey

properties.

Double-click a

Result

record to show the

Test report

window.

Drag or press CTRL and drag selected records to a folder and drop them to move or copy selected records to the folder.

You can run a

Test

or

Survey

:

·

on

Student group

connected

Students

by dragging a

Test

or

Survey

record to a

Groups

pane

Student group

and drop it.

·

from the

Action

menu

Run test

command.

·

from a

Toolbar

Run

menu

Run test

or

Run survey

sub-command.

·

from a

Student context menu

Run a test on this student

or

Run a survey on this student

command.

·

from a

Student group context menu

Run a test on this group

or

Run a survey on this group

command.

149

NetOp Teacher

Tests

The

Tests view pane

Tests

tab will initially include a SampleTest that illustrates the available

Question types

.

To create a

Test

, click the

Tests view pane

Tests

tab context menu

New test

command to show this window:

Specify the

Test

Name and optionally a Description.

Note: The Name in capital letters and any Description will be shown in the

NetOp test

window when the

Test

opens on

Student

computers.

Click OK to show this window:

150

NetOp Teacher

To work in the

Test designer

window instead of in the

Test wizard

, click Advanced.

Click Next to show this window:

151

NetOp Teacher

It enables you to create the

Test

Questions

. Click Add to show this window:

Its pane contains named icons of available

Question types

:

·

Drop-down list

: To answer the

Question

, click a drop-down box list element.

152

NetOp Teacher

·

Essay

: To answer the

Question

, write a text.

·

Label image

: To answer the

Question

, drag labels and drop them on matching image elements.

·

Match image

: To answer the

Question

, drag images and drop them next to a matching text.

·

Match text

: To answer the

Question

, drag text elements and drop them in a matching vacant position in

a text.

·

Multiple choice

: To answer the

Question

, click one, alternatively multiple answer options.

·

Ordering

: To answer the

Question

, drag elements and drop them in the correct order.

·

Question and answer

: To answer the

Question

, write an answer.

·

Text completion

: To answer the

Question

, from dictation write words into fields to complete a text.

Select a

Question type

and click OK to show a window like this:

This is a

Question editor

window that enables you to specify the details of each

Question

and its answer options. Click OK to close the

Question editor

to show the

Question

as a record in the

Test wizard

Questions

window table.

Note: Click a

Question type

hotspot above to jump to the section that explains its

Question editor .

The

Test wizard

Questions

window table will contain

Question

records with these column details:

· Topic: An optional

Question

description specified in the

Question editor

.

·

Type: The

Question

type selected in the

Choose question type

window.

· Resource: Yes if any

Question resources

are included, otherwise No.

153

·

Weight: The

Question weight

specified in the

Scoring extension

.

· Passed: The

Question passed

score specified in the

Scoring extension

.

To remove a

Question

record, select it and click Remove.

Before continuing, click Scoring to show this

Scoring

lower extension of the window:

NetOp Teacher

The graphic shows the

Test

composed of gray

Question

blocks. The width of each gray block represents the

Question weight

(percent of

Test

) and the gray block height represents the

Question passed

score (percent

correct). The selected

Question

block will be darker than the others. Click a block to select it. You can drag

the internal borders of the selected

Question

block to adjust its

Question weight

and

Question passed

score.

You will notice that the

Question weight

and

Question passed

score figures to the right and in the table above

will change in concert with your changes in the graphic.

You can also change the figures to the right and press ENTER to recalculate.

A

Question

answer will count as Passed if its score passes the

Question passed

score, otherwise as Failed.

The sum of Passed

Question weights

will typically make up the

Test

score that will be compared with the

specified

Test passed

score.

If you check the Award negative box, Failed

Question

answers will count negatively. The sum of Passed

Question weight

minus the sum of Failed

Question weight

percentages will make up the

Test

score that will

be compared with the specified

Test passed

score.

Click Next to show this window:

154

NetOp Teacher

It enables you to select the colors and patterns style of the

NetOp test

window in which the

Test

will be shown on

Students

.

Click Next to show this window:

155

NetOp Teacher

It enables you to specify

Test

options in these elements:

·

Description []: You can edit the

Test Description

.

Settings

· Author []: Optionally, select a

Test

author name in the drop-down box list or specify it in the field.

· Created/Modified: Will show the dates and times the

Test

was created and most recently modified.

· Test type: Select your preferred option in the drop-down box list to show it in the field:

·

Unrestricted: The

NetOp test

window shown on

Students

will include a table of contents to enable the

user to return and change answers to previous

Questions

.

· Restricted: The

NetOp test

window shown on

Students

will include no table of contents. The user can

only run the

Test

from begin to end without returning to previous

Questions

.

·

Time limit [] Minutes: To apply a time limit in minutes for completing the

Test

, specify a number. The

remaining number of minutes will be shown to the

Student

user in the lower left corner of the

NetOp test

window.

·

þ Autostart test: Leave checked to automatically start the

Test

when distributed to

Students

and

automatically terminate the

Test

when all

Students

have submitted their answers. Uncheck to start and

terminate the

Test

manually from

NetOp test monitor

.

·

þ Prompt for name before test begins: Leave checked to show a window on

Students

that requests the

user to specify a name before starting the

Test

.

156

NetOp Teacher

·

þ Perform real-time reporting during test: Leave checked to show

Students'

Test

performance real time in

NetOp test monitor

.

·

þ Send test result when: []: Leave checked to send the

Test

result (Score percentage and Passed Yes/No)

to

Students

. Select your preferred option in the drop-down box list to show it in the field:

·

Test received: When each

Student

has submitted the

Test

and answers have been evaluated (as

Students

finish the

Test

).

· Test terminated: When the

Test

has been terminated automatically

or manually by closing the

NetOp test monitor

window (all

Students

at the same time).

Click Finish to end the

Test wizard

closing the window.

This is the alternative

Test designer :

Its table matches the

Test wizard

Questions

window table.

The Add question, Remove question and Scoring buttons match

Test wizard

Questions

window buttons. The

Add question button down pointer will show the

Choose question type

window contents in a menu.

The Style button will show the

Test wizard

Style

window contents in a Style window.

The Options button will show the

Test wizard

Options

window contents in an Options window.

Note: Private

Test

.nxt files will be stored in the user personal

Teacher

User configuration files

Tests folder.

Public

Test

.nxt files will by default be stored in the All users

Teacher

User configuration files

Tests folder.

You can change the public

Test

files folder in the

Options

window

Sharing

tab

Tests - public folder

element.

157

NetOp Teacher

Drop-Down List Question

In the

Choose question type

window or menu, select

Drop-down list

to show this

Question editor :

It enables you to specify the properties of a

Drop-down list

Question

in these elements:

· Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

· Text []: Specify a text that includes the true answer element. Select the true answer element and click

Select to emphasize it to include it in a drop-down box list among false answer elements.

· False answers []: Click Add to show Write a false answer here highlighted in the pane. Overwrite by a false answer element. You can add multiple false answer elements. To remove a false answer element, select it and click Remove.

· Time limit: Click to show this window:

158

NetOp Teacher

·

To set a time limit for answering this

Question

, check the box, specify a number in the field, click Seconds or Minutes and click OK. To remove the time limit, click the button, uncheck the box and click OK.

Resources: Click to show this window:

It enables you to include file resources with the

Question .

Click Add to show this window:

159

NetOp Teacher

Click [...] to show a Windows Open window to open a resource file to show its name in the Name field and its path in the Source field. Click OK to add the resource file to show the Name field contents in the

Question resources

window left pane.

Click a left pane resource name to preview resource contents in the right Preview pane.

Double-click a left pane resource name to show the

Resource

window to edit resource properties.

Click a left pane resource name and click Remove to remove the resource.

Note: Included file resources will be available in the

NetOp test

window below the

Question

.

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

160

Essay Question

In the

Choose question type

window or menu, select

Essay

to show this

Question editor :

NetOp Teacher

·

·

It enables you to specify the properties of a

Essay

question in these elements:

·

Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

Note: Answering an

Essay

question with any text will score as a correct answer regardless of the text

contents.

Time limit: Click to show the

Time limit

window.

Resources: Click to show the

Question resources

window.

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

161

NetOp Teacher

Label Image Question

In the

Choose question type

window or menu, select

Label image

to show this

Question editor :

·

·

It enables you to specify the properties of a

Label image

question in these elements:

·

Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

· Add image: Click to show a Windows Open window to open an image file to show the image in the Answer pane.

· Add label: Click to add a label with the text Write label text here. Replace this text by the desired label text and click outside the label. Drag the label to the desired position. You can add almost any number of labels.

· Remove label: Click a label to select it. Click Remove label to remove the selected label.

Time limit: Click to show the

Time limit

window.

Resources: Click to show the

Question resources

window.

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

162

NetOp Teacher

Match Image Question

In the

Choose question type

window or menu, select

Match image

to show this

Question editor

:

It enables you to specify the properties of a

Match image

question in these elements:

·

Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

· Add: Click to show a Windows Open window to open an image file to show the image in an Answer pane section with the image to the left and a text area to the right. Specify in the text area the text that the image shall match. Preferably add between three and six images.

Note: All images will be shown in the size 100 x 100 pixels. Therefore, images should be trimmed to a square shape and clearly show relevant details when resized to 100 x 100 pixels.

·

Remove: Select an Answers pane section and click to remove it.

·

Time limit: Click to show the

Time limit

window.

163

NetOp Teacher

·

Resources: Click to show the

Question resources

window.

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

Match Text Question

In the

Choose question type

window or menu, select

Match text

to show this

Question editor :

·

·

It enables you to specify the properties of a

Match text

question in these elements:

· Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

·

Text []: Specify, typically by pasting clipboard text from another application by pressing CTRL+V, the entire text in which

Student

users must match text elements. Select a text element, typically one or multiple

words, and click Select to emphasize the text element and show it in the Word list pane. You can select almost any number of text elements. To unselect a selected text element, select it in the Text pane and click Unselect.

Time limit: Click to show the

Time limit

Resources: Click to show the

window.

Question resources

window.

164

NetOp Teacher

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

Multiple Choice Question

In the

Choose question type

window or menu, select

Multiple choice

to show this

Question editor :

·

·

It enables you to specify the properties of a

Multiple choice

question in these elements:

· Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

· Click Add to add an Answers pane section with a select button and a text area. Click the select button to select it to select this answer as the correct answer. Specify in the text area the correct answer. Add typically two to four more Answers pane sections with incorrect answers. To remove an Answers pane section, select it and click Remove.

· A

Multiple choice

question with round select buttons enables only one correct answer. To enable multiple

correct answers, check the Multiple correct answers box to replace round select buttons by square check boxes. Correct answer boxes must be checked. Incorrect answer boxes must be unchecked.

· To show available answers in a random order in the

NetOp test

window, check the Random order box.

Time limit: Click to show the

Time limit

window.

Resources: Click to show the

Question resources

window.

165

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

Ordering Question

In the

Choose question type

window or menu, select

Ordering

to show this

Question editor

:

NetOp Teacher

·

·

It enables you to specify the properties of an

Ordering

question in these elements:

· Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

· Click Add to add an Answer pane section numbered 1 with a text area. Specify in the text area the word, sentence or number that

Student

users must place first in the order of sections. Click Add again to add a section numbered 2 below to specify the element that must be placed second, etc. In the

NetOp test

window, unnumbered sections will be shown in a random order.

· To remove a section, select it and click Remove to automatically rearrange section numbering. A new section will always be added at the bottom.

Time limit: Click to show the

Time limit

Resources: Click to show the

window.

Question resources

window.

166

NetOp Teacher

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

Question and Answer Question

In the

Choose question type

window or menu, select

Question and answer

to show this

Question editor

:

It enables you to specify the properties of a

Question and answer

question in these elements:

· Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

·

Click Add to add an Answers pane section with a text area. Specify in the text area a correct answer. You

can add multiple sections with a correct answer. When creating the

Question

and correct answers, take into account that for a specified answer to score as correct, it must exactly match an answer specified in an Answers pane section.

· To remove a section, select it and click Remove.

·

Time limit: Click to show the

Time limit

window.

Resources: Click to show the

Question resources

window.

·

·

Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

167

NetOp Teacher

Text Completion Question

In the

Choose question type

window or menu, select

Text completion

to show this

Question editor :

·

·

It enables you to specify the properties of a

Text completion

question in these elements:

· Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

· Completion text []: Specify, typically by pasting clipboard text from another application by pressing CTRL

+V, the entire text in which

Student

users from dictation must type words into fields to complete the text.

Select a word and click Select to emphasize the word and show it in the Word list pane. You can select almost any number of words. To unselect a selected word, select it in the Completion text pane and click

Unselect.

Time limit: Click to show the

Time limit

window.

Resources: Click to show the

Question resources

window.

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Question

record in the

Test

Questions

table.

168

NetOp Teacher

Surveys

To create a

Survey

, click the

Tests view pane

Surveys

tab context menu

New survey

command to show this

window:

Specify a

Survey

Name that will be shown in capital letters when the

Survey

opens on

Student

computers

and click OK to show this window:

It enables you to specify the properties of a

Survey

in these elements:

Note: A NetOp School

Survey

consists of one

Multiple choice question

. No

Styles

or

Options

are available.

· Topic (Optional) []: Optionally, specify a topic that will be shown in capital letters above the

Question .

· Question/Instructions []: Specify the

Question

text and/or answering instructions.

· Click Add to add an Answers pane section with a select button and a text area. Specify the answer in the text area. You can add multiple Answers pane sections with answers. To remove an Answers pane

169

NetOp Teacher

section, select it and click Remove.

· A

Multiple choice

question with round select buttons enables selecting only one answer. To enable

selecting multiple answers, check the Multiple answers box to replace round select buttons by square check boxes.

Note: A

Survey

asks for user attitudes, not for correct answers. Although scoring as such is therefore

irrelevant, you can use the scoring functionality to measure

Survey

bias towards the attitude of one or

multiple answer options.

·

Resources: Click to show the

Question resources

window.

· Preview: Click to preview the

Question

in a maximized Preview window.

Click OK to insert the

Survey

record on the

Test view pane

Surveys

tab.

Note: Private

Survey

.nxs files will be stored in the user personal

Teacher

User configuration files

Tests

folder. Public

Survey

.nxs files will by default be stored in the All users

Teacher

User configuration files

Tests

folder. You can change the public

Survey

files folder in the

Options

window

Sharing

tab

Surveys - public folder

element.

170

NetOp Teacher

Results

When you start running a

Test

or

Survey

, this window will be shown on the

Teacher computer screen:

It monitors

Test

and

Survey

progress in these elements:

· Run: Will be green (enabled) if the selected

Test

or

Survey

is paused. Click to run the selected

Test

or

Survey

. Will be gray (disabled) if the selected

Test

or

Survey

is running or stopped.

·

Pause: Will be green (enabled) if the selected

Test

or

Survey

is running. Click to pause the selected

Test

or

Survey

. Will be gray (disabled) if the selected

Test

or

Survey

is paused or stopped.

·

Stop: Will be red (enabled) if the selected

Test

or

Survey

is running or paused. Click to stop the

selected

Test

or

Survey

to remove it on

Students

. Will be gray (disabled) if the selected

Test

or

Survey

is

stopped. You cannot restart a stopped

Test

or

Survey

.

·

: The list of this drop-down box will contain the names of active

Tests

or

Surveys

. The buttons to the left will control the

Test

or

Survey

whose name is shown in the field. Select a name in the list to change button control.

The pane will show these data for each active

Test

or

Survey

:

171

NetOp Teacher

·

Test name:

Test

or

Survey

name.

· Passing score: The

Test

Scoring extension

specified

Test passed

score, for a

Survey

always 100.00%.

·

Student

records in a table with these column details:

·

User:

Student

name.

· Progress: For each

Test

Question

a light bulb icon with these attributes:

·

·

·

: Unanswered

: Current

:

Question

score passed the

Test

Scoring extension

specified

Question passed

score

· :

Question

score failed the

Test

Scoring extension

specified

Question passed

score

·

Score: Current

Test

score

· Passed: Yes if the current

Test

score passed the

Test

Scoring extension

specified

Test passed

score, otherwise No.

To manually terminate active

Tests

and

Surveys

, close

NetOp test monitor

from a title bar Close window control to show a confirmation window to confirm termination.

Upon manual or automatic termination, a

Test

will show this window:

Student

records will show the

Test

passed

or failed icon and score and individual

Questions

passed or

failed icons and scores. You can expand each

Student

record into its details:

172

NetOp Teacher

Wrong answers will be shown in red text.

Upon termination, a

Survey

will show this window (expanded):

173

NetOp Teacher

The upper section will show the number of hits on each answer from all

Students

that answered the

Survey

.

The

Tests view pane

Results

tab will show the average score of each

Test

or

Survey

run:

174

NetOp Teacher

Click a record context menu

View

command or double-click a record to show detailed

Test

or

Survey

results in the

Test report

window.

Note:

Result

.nxr files will be stored in the folder of the matching

Test

or

Survey

.

3.2.4.7 Activity View

This is the

Class control panel

Activity view

:

It enables you to view and control which

Applications

and

Websites

are being used on

Student

computers.

Initially, the

Activity view

will be passive showing no activity details. The text Press start button will flash next

to the lower

Active applications and sites

bar

Start activity control

button. Click

Start activity control

to retrieve

connected

Students

information on running applications and viewed websites to show this information by

Student

in the upper

Activity view

pane and by

Application

and

Website

in the lower

Active applications and sites

pane.

175

NetOp Teacher

3.2.4.7.1 Activity View Pane

This is the

Activity view

pane:

Its title bar will show the name of the view and the name of the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The title bar right end will show a part/whole button:

Click it to switch between part mode without the upper right sector and whole mode with the upper right sector. In part mode, only connected

Students

will be shown in the pane. In whole mode, also unconnected

Student

members of the

Class

will be shown.

Below, two tabs with

Class

Student

record tables are available.

The

Current applications

tab table has these column contents:

·

Student display name:

Student

name as selected in the

Options

window

General

tab

Student display name

section.

· Running applications: Icons of applications running on the

Student

computer with a red frame around the active application icon.

· Current: The activity of the

Student

computer active application when it became the active application.

·

Policy:

Student

Policy

name.

Right-click an application icon to show this menu:

It contains these commands:

Close: Click to unload the record

Student

computer application.

Deny: Click to unload the record

Student

computer application denying reloading it during this connection.

Hide: Click to hide the record

Student

computer application window until unhidden or end of connection.

Unhide: Click to unhide the hidden record

Student

computer application window.

176

Properties: Click to show this record

Student

computer application window:

NetOp Teacher

It will show the application program file path and activity title.

History: Click to show this all connected

Student

computer applications window:

It will show ordered by

Student

or by application the Started time, Stopped time and Duration of applications run on connected

Student

computers since the

Activity view

was activated. Click Refresh to refresh data. Click Save

to show a Windows Save as window to save data in a comma separated values (.csv) file. Click Print to print out data.

Task manager: Click to show this record

Student

computer window:

177

NetOp Teacher

This simplified two-tabs Task manager enables you to remotely view and end

Student

computer running applications and processes.

The

Current websites

tab table has matching website column contents and the same context menu, the only

difference being that the

Deny

command is disabled.

3.2.4.7.2 Active Applications and Sites Pane

This is the

Activity view

Active applications and sites

pane:

Its title bar contains these buttons:

Stop activity control: Click to stop retrieving connected

Students

information on running

Applications

and

viewed

Websites

to stop showing this information in the panes.

178

NetOp Teacher

Start activity control: Click to start retrieving connected

Students

information on running

Applications

and

viewed

Websites

to show this information in the panes.

Note: Clicking

Stop activity control

will not neutralize the effect of an issued

Deny

or

Hide

command.

The table has these column contents:

·

Running applications:

Application

icon and name or

Website

URL. Different versions of the same

application may be shown in separate records.

·

Count: The number of

Student

computers on which the

Application

runs or the

Website

is shown.

· Students: The names of

Students

on whose computer the

Application

runs or the

Website

is shown.

Right-click a record to show this menu:

It contains these commands:

Close: Click to unload the record

Application

on all

Student

computers that run it.

Deny: Click to unload the record

Application

on all

Student

computers that run it denying reloading it

during this connection.

Hide: Click to hide the record

Application

window on all

Student

computers that run it until unhidden or end of connection.

Unhide: Click to unhide the hidden record

Application

window.

History: Click to show the

Application history

window.

Refresh: Click to refresh the

Active applications and sites

pane contents.

179

3.2.4.8 Class Setup View

This is the

Class control panel

Class setup view :

NetOp Teacher

It enables you to set up

Class

Students

and

Student groups

.

A moveable horizontal separation divides it into two panes:

· The upper

Class setup view

pane will show

Class

Students

as named icons in an

All students

element

and

Student

members of

Student groups

as shortcut icons in named

Student group

elements in a

Student groups

element.

· The lower

Available students

pane can show

Students

that are available for any

Class

as named icons or table records.

3.2.4.8.1 Class Setup View Pane

This is the

Class setup view

pane:

Its title bar will show the name of the view and the running

Class

.

Click the

Change class

down pointer button to the right of the

Class

name to open the

Change class

menu.

The pane will contain these elements:

· A

Student groups

element that will expand into available named

Student group

elements that will expand

into named member

Student

shortcut icons.

180

·

An

All students

element that will expand into all

Class

Student

icons.

Student

icons and shortcut icons can show these attributes:

: Connected, not in session or help requested.

: Connected, in session or help requested.

: Unconnected.

Right-click to show this context menu:

NetOp Teacher

It contains these commands:

·

Cut: Will be enabled if an

All students

element

Student

icon or a

Student group

element

Student

shortcut

icon was right-clicked. Click to place the

Student

on the clipboard. If a

Student

shortcut icon was

right-clicked, it will be removed when pasting into another

Student group

element.

· Copy: Will be enabled if an

All students

element

Student

icon or a

Student group

element

Student

shortcut icon was right-clicked. Click to place a copy of the

Student

on the clipboard to paste it into another

Student group

element.

· Paste: Will be enabled if there are

Students

on the clipboard. Click to add clipboard

Students

to the

All students

element and, if selected, to a

Student group

element.

·

Add student to group: Will be enabled if a

Student group

element or a

Student

shortcut icon under it is

selected. Click to show this window:

The pane will contain records of all

Class

Students

. Select a record and click OK to add the record

Student

icon to the selected

Student group

element.

Note: Each

Student

can be a member of any number of

Student groups

. You can also add a

Student

to a

181

NetOp Teacher

Student group

by dragging an

All students

icon

Student

icon to a

Student group

element and dropping it. In the other views, you can add a

Student

to a

Student group

by dragging a

Student

record, icon or thumbnail

to a

Groups

pane

Student group

icon or record and dropping it.

· New: Will expand into these commands:

· Create student: Click to show this window:

It enables you to specify these properties of a new

Student

account:

·

Student login name []: The name specified on the

Student

Options

window

Student login

tab.

·

PC name (computer name) []:

Student

computer name.

·

Computer domain []:

Student

computer domain.

·

Windows login name []:

Student

computer user Windows login name.

· Windows login domain []:

Student

computer user Windows login domain.

· Wake on LAN MAC address []:

Student

computer network card MAC address.

Note: You can

start a

Student

computer equipped with a Wake on LAN network card from the

Teacher

.

Note: You can create a

Student

account in the

Student information

window only if you specify at least

one of

Student login name

,

Computer name

or

Windows login name

. You should always specify the

Student login name

because a connecting

Student

will be identified as an existing

Student

account only

if the connecting

Student

Student login name

matches the existing

Student

account

Student login name

.

In that case, other existing

Student

account names will be overwritten by the matching names of the connecting

Student

.

Click OK to close the window to add the new

Student

icon under the

All students

element and, if a

Student group

element or a

Student group

element

Student

shortcut icon was selected, create a matching

Student

shortcut icon under the

Student group

element.

Note: You can also create a

Student

account by making the

Student

connect to the

Class

after in the

Teacher

Options

window

General

tab

Options

section checking the

Save new students between classes

box. You can also create a

Student

account by copying or dragging an available

Student

icon or record

from the

Available students

pane and pasting or dropping it in the

Class setup view

pane or on a

Student group

element in it if the

Student

shall be a member of the

Student group

.

· Create group: Will be enabled if the

Student groups

element or a

Student group

element under it is

selected. Click to show this window:

182

NetOp Teacher

Specify the

Student group

name and click OK to create.

Note: In other views with a

Groups

pane, create a

Student group

from the

Groups

pane right-click

context menu.

·

Delete: Will be enabled if

Student

icon,

Student group

element or

Student

shortcut icon is selected. Click to show a confirmation window to confirm deleting the element. You cannot delete a connected

Student

icon.

Note: Deleting an

All students

element

Student

icon will delete the

Student

account and matching

Student

shortcut icons under

Student group

elements. Deleting a

Student group

element will delete

Student

shortcut icons under it. Deleting a

Student

shortcut icon will delete only that.

·

Wake on LAN: Will be enabled if an

All students

element unconnected

Student

icon, an unconnected

Student

shortcut icon, the

All students

element with unconnected

Student

icons under it or a

Student group

element with unconnected

Student

shortcut icons under it is selected. Click to send a Wake on LAN command to selected unconnected

Students

to start their computers if equipped with a Wake on LAN

network card whose MAC address is specified in their

Student information

window.

· Student information: Will be enabled if an

All students

element

Student

icon is selected. Click to show the

Student information

window with the properties of the selected

Student

account. If you selected a connected

Student

icon, the

Student information

window fields will be disabled so that you cannot change their contents.

Note: You can start

Action

menu command and

Toolbar

button actions with one

Student

from a

Class setup view

pane

Student

icon, but the

Student context menu

and the

Student group context menu

are unavailable.

Many more action options are available in the other views.

3.2.4.8.2 Available Students Pane

This is the

Class setup view

Available students pane :

Provided that the

Options

window

General

tab

Options

section

Get available students

box is checked, the

Available students

pane will enable you to see, connect and invite available

Students

.

A

Student

that

Joins class

by the

Options

window

Class

tab

Be available for any class

option will

automatically connect to a running

Class

of which it is a member. If no

Class

of which the

Student

is a member is running, the

Student

will - visibly in the

Available students

pane - be available for any

Class

.

The

Available students

pane will contain available

Students

as named icons or records.

You can select available

Students

by one of these methods:

·

Click an icon or record to select it.

· Click icons while holding down the SHIFT or CTRL key to select them.

· Starting outside icons, drag a dotted rectangle to select icons covered by the rectangle.

183

NetOp Teacher

·

Click one record and pressing the SHIFT key click another record to select clicked and in between records.

· Click one record and pressing the CTRL key click other records to select clicked records.

· Starting outside records, drag a dotted rectangle to select records covered by the rectangle.

Right-click selected available

Students

to show this menu:

It contains these commands:

· Copy: Will be enabled if available

Students

are selected. Click to copy selected available

Students

to the clipboard to enable pasting them in the

Class setup view

pane.

Note: Pasting available

Students

on the clipboard in the

Class setup view

pane will connect them to the

Class

and make them members of the

Class

. Alternatively, drag selected available

Students

to the

Class setup view

pane and drop them. Pasting in or dropping on a

Student group

element will also make

Students

members of the

Student group

.

·

Invite: Will be enabled if selected available

Students

are not invited. Click or click the

Available students

pane title bar button to show this window:

It enables you to invite available

Students

to join the

Class

.

Optionally, specify in the pane an invitation text as shown and click OK to send the invitation. The

Invite

button and the icons or records of available

Students

to which the invitation was sent will indicate that an

invitation is pending. This window will appear on invited available

Students

:

184

NetOp Teacher

The available

Student

user has the option to click OK to accept or Cancel to decline the invitation.

Note: If the

Student

user declines, the

Student

will remain in the

Available students

pane changing back to its not invited appearance.

·

Large icons: Click to show available

Students

as horizontal rows of large icons.

· Small icons: Click to show available

Students

as horizontal rows of small icons.

· List: Click to show available

Students

as vertical columns of small icons.

· Details: Click to show available

Students

as table records with these column contents:

· Computer name:

Student

computer name.

·

Student login name: The name specified on the

Student

Options

window

Student login

tab.

·

Windows login name:

Student

user Windows login name.

· Windows login domain:

Student

user Windows login domain.

·

Address:

Student

computer IP address if using

TCP/IP

communication or MAC address if using

IPX

or

NetBIOS

communication.

3.2.5 Status Bar

This is the

Teacher

window status bar:

When the mouse pointer is over a

menu command, the status bar will show a hint to the command.

The right end of the status bar will show these indicators:

All students: The number indicates the number of

Students

in the

Class

.

Connected students: The number indicates the number of connected

Students

in the

Class

.

Selected students: The number indicates the number of selected

Students

in the

Class

.

Available students: The number indicates the number of available

Students

in the

Available students

pane.

NetOp Name Server: Will be included if the

Advanced TCP/IP configuration

window

Use NetOp name server

box is checked. These availability indicators can be shown on the yellow pages icon:

· Nothing: Selected NetOp Name Servers are available.

185

·

Red exclamation mark: One of two selected NetOp Name Servers is available.

· Red X: No NetOp Name Server is available.

3.2.6 Teacher Tools

This section explains

Teacher

tools in these sections:

·

Options

·

Help request

3.2.6.1 Options

Click the

Tools

menu

Options

command to show typically this window:

NetOp Teacher

It provides access to

Option

tabs.

Right-click in the window pane to show this menu:

It contains these commands:

· Open: Will be enabled if an icon is right-clicked. Click or double-click an icon to show the

Option

tab

window.

· Large icons: Will be enabled from the small icons window shown below. Click to show the large icons window shown above.

·

Small icons: Will be enabled from the large icons window shown above. Click to show this small icons window:

186

NetOp Teacher

· Options as tabs: Click to show this tabs window after closing and reopening the

Options

window:

To return to the icons window, click the

Tools

menu

Options as icons

command.

The

Options

window contains these tabs:

·

General

·

Class

·

Teachers

187

·

Protection

·

Sharing

·

Connection

·

Menu/toolbar

·

Web update

·

Demonstrate

·

Attention

·

Control

·

Audio-video chat

·

Run

·

Policy

3.2.6.1.1 General Tab

This is the

Teacher

Options

window

General

tab:

NetOp Teacher

It enables you to specify

Teacher

General

properties in these elements:

Options

þ Save new students between classes: Check to retain

Students

that have connected to a

Class

as

members of the

Class

.

þ Get available Students: Check to make the

Available students

pane show

Students

that are available and make available

Students

that are members of the

Class

connect to the

Class

.

Student display name

Click one of these options to identify Students in the

Classroom view

,

Thumbnail view

,

Activity view

and

188

NetOp Teacher

Class setup view

by the selected name type.

¤ Student login name: The name type or name specified on the

Student

Options

window

Student login

tab.

¡ Windows login name: The name by which the

Student

computer user is logged in to Windows.

¡ Computer name: The Windows name of the

Student

computer.

Note: if the selected name type of an unconnected

Student

is unavailable on the

Teacher

, the

Student

will be

identified by another name type in brackets.

Display custom columns in details view

¨ Check to enable the fields to the right to add the column specified in the fields in the

Details view pane

to

the right of the default columns.

· Title []: Specify the column heading name.

· Column value []: Specify the environment variable or Windows registry key and value name whose value shall appear in the column.

Connection password

· Specify a password to enable only

Students

whose

Options

window

General

tab

Connection password

section contains the same password to connect.

3.2.6.1.2 Class Tab

This is the

Teacher

Options

window

Class

tab:

It enables you to specify

Teacher

Class

properties in these elements:

Class

· Class name []: Will be disabled if

Use class server

is checked. The drop-down box list will contain the

names of available

Teacher

specified

Classes

. Click one to show it in the field as selected to run the selected

Class

when clicking OK.

Caution: Changing the

Class

will disconnect connected

Students

.

189

·

Add: Will be disabled if

Use class server

is checked. Click to show this window:

NetOp Teacher

Specify the

Class

name in the field and click OK to create the

Class

showing its name in the

Class name

drop-down box field.

· Copy: Will be disabled if

Use class server

is checked. Click to show the

New class

window to create a

Class

with the

Student

members of the

Class

whose name is shown in the

Class name

drop-down box field.

· Delete: Will be disabled if

Use class server

is checked. Click to delete the

Class

whose name is shown in the

Class name

drop-down box field to show the next drop-down box list entry in the field. You cannot delete the running

Class

.

¨ Use class server [Setup]: Check to disable the elements above to use a

Class server

Class

specification instead of a

Teacher

Class

specification. Click [Setup] to show the

Class server setup

window to set up the

Teacher

to use a

Class server

.

¨ Always select class at startup: Check to always show this

Class

tab when the

Teacher

is loaded. Leave

unchecked to:

·

if the

Use class server

box is unchecked, run the

Class

that was running when the

Teacher

was last unloaded.

·

if the

Use class server

box is checked, show the

Select class

window.

þ Notify when students join late: Leave checked to show this Windows taskbar notification area

Teacher

icon notification if a

Student

connects to the running

Class

some time after it started running:

Auto join demo, monitor, chat and attention

· Auto join []: Click in the drop-down box list one of these options to show it in the field as selected:

·

No - never: Newly connected

Students

will not join an ongoing

Demonstrate

,

Attention

,

Monitor

,

Audio-video chat

or

Chat

session.

· Yes - automatic: Newly connected

Students

will automatically join an ongoing

Demonstrate

,

Attention

,

Monitor

,

Audio-video chat

or

Chat

session.

· Prompt before join: Show this window when a

Student

connects during an ongoing

Demonstrate

,

Attention

,

Monitor

,

Audio-video chat

or

Chat

session.

190

NetOp Teacher

Click Yes to join the newly connected

Student

or No to not join.

Policy

Startup policy []: The drop-down box list will contain the names of available

Policies

in the

Class

selected in

the

Class name

drop-down box or if the

Use class server

box is checked in any Course or Lesson that is

available to the

Teacher

from the

Class server

. Click one to show it in the field to apply it to

Students

that

connect to the

Class

.

Class Server Setup

Click the

Class

tab

Setup

button to show this window:

It enables you to set up the

Teacher

to use

NetOp School class management

in these elements:

·

Class server []: Specify the Class server ID specified on the used

NetOp Class Server

.

¨ IP address or DNS name (if on another subnet) []: If the used

NetOp Class Server

is on an IP subnet

different from the

Teacher

computer IP subnet, you must check the box and specify the

NetOp Class Server

computer IP address or DNS name.

þ Extend lesson: Leave checked to enable the

Teacher

user to extend a

Lesson

beyond its scheduled end

time. Uncheck to disable.

Identify teacher by

Click one of these options for identifying the

Teacher

to the

NetOp Class Server

:

¤ Windows login name: By the name by which the

Teacher

user is logged in to Windows.

¡ Computer name: By the

Teacher

computer Windows name.

¡ Teacher profile name: By the

Teacher

user

Teacher profile

name.

Note: This selection must be compatible with the

NetOp School class management

Teacher

identification.

When a

Teacher

that is set up to

Use class server

is loaded, it will request

Class

information from the used

NetOp Class Server

to show this window:

191

NetOp Teacher

The

Teacher

user can at any time show this window from the

Change class

menu

Ask class server

command.

It enables the

Teacher

user to select an available

Class

to run it.

If

NetOp School class management

runs in

Non-scheduled mode

, the names of

Courses

to which the

Teacher

is assigned will be shown in the pane. Select a

Course

name to show only the

Teacher

name in

the fields below. Click OK to run a

Class

of the selected

Course

.

If

NetOp School class management

runs in

Scheduled mode

, if a

Lesson

of a

Course

to which the

Teacher

is assigned is running, the

Course

name will be shown in the pane. Select a

Course

name to show

Lesson

From time, To time,

Classroom

name and

Teacher

name in the fields below. Click OK to run the selected

Course Lesson

. If no

Lesson

of a

Course

to which the

Teacher

is assigned is running, the user can select

to show upcoming

Course Lessons

in the

Select class

window to select one to run it.

Click Cancel to close the window without changing the

Class

. If no

Class

was running before the

Select class

window was shown, My class will run.

192

3.2.6.1.3 Teachers Tab

This is the

Teacher

Options

window

Teachers

tab:

NetOp Teacher

It enables you to specify the use of

Teacher profiles

for authenticating

Teacher

users in these elements:

Authentication

¨ Use teacher profiles: Leave unchecked to not require users to log in to the

Teacher

. Check to require users to log in to the

Teacher

to replace the

Teacher name

section below by a

Teacher profiles

section.

Note: Using

Teacher profiles

enables protecting the

Teacher

against misuse.

If the

Use teacher profiles

box is checked, the

Authentication

section will include this box:

¨ Validate using Windows security management: Leave unchecked to use

NetOp teacher profiles

. Check to

use

Windows teacher profiles

.

Teacher name

This section enables identifying the

Teacher

to

Students

by a title and a name:

Title []: Optionally, specify a title.

Name []: Optionally, replace the default name Teacher by another name.

Note: This title and name will apply to all users of the

Teacher

.

193

NetOp Teacher

NetOp Teacher Profiles

If on the

Teachers

tab the

Use teacher profiles

box is checked and the

Validate using Windows security management

box is unchecked to use

NetOp teacher profiles

, the

Teachers

tab will contain these sections:

It enables you to specify

NetOp teacher profiles

in these Teacher profiles section elements:

Teacher profiles

·

The table will contain

NetOp teacher profile

records with these column contents:

·

User name:

NetOp teacher profile

user name.

· Add user: Click to show this window:

It enables you to specify a

NetOp teacher profile

in these elements:

Login

194

NetOp Teacher

·

User name []: Specify the

NetOp teacher profile

user name by which the user must log in to the

Teacher

.

· Change password: Click to show this window:

·

Change password for []: Will show the

NetOp teacher profile

User name

.

· Old password []: Specify the current

NetOp teacher profile

password (initially none).

·

New password []: Specify the new

NetOp teacher profile

password.

·

Confirm password []: Re-specify the new

NetOp teacher profile

password for confirmation.

Note: Password characters will show as dots or asterisks. To require no password, leave the

New password

and

Confirm password

fields empty.

Teacher name

This section enables identifying the

Teacher

to

Students

by a title and a name:

· Title []: Optionally, specify a title.

· Name []: Optionally, replace the default name Teacher by another name.

Note: This title and name will apply only to the

NetOp teacher profile

user.

Click OK to create the

NetOp teacher profile

showing the

NetOp teacher profile

User name

in the

Teacher profiles

section table.

·

Edit: Select a table record and click to show the

Teacher profile

window to edit it.

· Delete: Select a table record and click to delete it.

If

NetOp teacher profiles

are used, this window will be shown in front of the

Teacher

window when loading

the

Teacher

and after logging off from the

Teacher :

Specify your

NetOp teacher profile

User name

and Password and click OK to log in to the

Teacher

.

Note: If

NetOp teacher profiles

are used, the

NetOp teacher profile

User name

will replace the running

Class

name in the

Teacher

window

Title bar

.

To log off from the

Teacher

, select the

Tools

menu

Log off

command that will be is included in the

Tools

menu only if

NetOp Teacher profiles

or

Windows teacher profiles

are used.

195

NetOp Teacher

Windows Teacher Profiles

If on the

Teachers

tab the

Use teacher profiles

box is checked and the

Validate using Windows security management

box is checked to use

Windows teacher profiles

, the

Teachers

tab will contain these sections:

It enables you to specify

Windows teacher profiles

in these

Teacher profiles

section elements:

Teacher profiles

·

[]: The table will contain

Windows teacher profile

records with these column contents:

·

User name:

Windows teacher profile

user or group name.

· Domain:

Windows teacher profile

user or group domain.

·

Add user: Click to show this window:

It enables you to specify a user

Windows teacher profile

in these elements:

196

NetOp Teacher

Login

· Domain []: The drop-down box list will contain the names of reachable domains. Click the name of the domain in which the user

Windows teacher profile

user shall be authenticated to show it in the field.

· User name []: The drop-down box list will contain the user names in the domain selected above. Click the user name by which the user

Windows teacher profile

user must log in to show it in the field.

Teacher name

This section enables identifying the

Teacher

to

Students

by a title and a name:

· Title []: Optionally, specify a title.

· Name []: Optionally, replace the default name Teacher by another name.

Note: This title and name will apply only to the user

Windows teacher profile

user.

Click OK to create the user

Windows teacher profile

showing its

User name

and

Domain

in the

Teacher profiles

section table.

·

Add group: Click to show this window:

It enables you to specify a group

Windows teacher profile

in these elements:

Login

· Domain []: The drop-down box list will contain the names of reachable domains. Click the name of the domain in which the group

Windows teacher profile

user shall be authenticated to show it in the field.

· Group name []: The drop-down box list will contain the group names in the domain selected above. Click

the name of the group of which a group

Windows teacher profile

user must be a member to show it in

the field.

Teacher name

This section enables identifying the

Teacher

to

Students

by a title and a name:

·

Title []: Optionally, specify a title.

· Name []: Optionally, replace the default name Teacher by another name.

Note: This title and name will apply only to the group

Windows teacher profile

group members.

Click OK to create the group

Windows teacher profile

showing its

Group name

and

Domain

in the

Teacher profiles

section table.

· Edit: Select a table record and click to show the

Teacher profile

window to edit it.

· Delete: Select a table record and click to delete it. You cannot delete the active

Teacher profile .

197

NetOp Teacher

If

Windows teacher profiles

are used, this window will be shown in front of the

Teacher

window when loading the

Teacher

and after logging off from the

Teacher :

Specify your Windows login user name, password and domain and click OK to log in to the

Teacher

.

Note: If

Windows teacher profiles

are used, the Windows login user name will replace the running

Class

name in the

Teacher

window

Title bar

.

To log off from the

Teacher

, select the

Tools

menu

Log off

command that will be is included in the

Tools

menu only if

NetOp Teacher profiles

or

Windows teacher profiles

are used.

3.2.6.1.4 Connection Tab

This is the

Teacher

Options

window

Connection

tab:

It enables you to specify

Teacher

Connection

properties in these elements:

Max packet size

Click one of these options:

198

NetOp Teacher

¤ Automatic: Let NetOp determine the maximum size of data packets sent from the

Teacher

to

Students

.

¡ Specify [] (512 - 5120): Specify in the interval 512 to 5120 bytes the maximum size of data packets sent

from the

Teacher

to

Students

.

Note: A large packet size that will typically work on a local network but not on the Internet will provide a higher data transfer speed. A small packet size may contribute to solving a communication problem.

Communication profile

·

The drop-down box list will contain available

Communication profiles

. Click one to show it in the field as selected.

·

New: Click to show the Communication profile edit window to create a

Communication profile

.

· Edit: Click to show the Communication profile edit window to edit the selected

Communication profile

.

·

Delete: Click to delete the selected

Communication profile

.

NetOp Name Server

·

Name space ID []: To connect to

Students

using

NetOp name management

, this field must contain the

Name space ID

specified in the matching field on

Students

.

Student polling

By default, no communication will take place between the

Teacher

and connected

Students

between actions,

in which case a lost connection will not be detected and restored. Polling

Students

at intervals will detect and

if possible restore a lost connection.

¨ Polling every [] Sec.: If you frequently experience lost connections to

Students

, check the box and specify

a number in the field to poll

Students

with an interval of the specified number of seconds.

Note: For

Connection

tab changes to apply, you must reload the

Teacher

.

3.2.6.1.5 Menu/Toolbar Tab

This is the

Teacher

Options

window

Menu/Toolbar

tab:

199

NetOp Teacher

It enables you to customize the

Action

menu and

Toolbar

.

In the pane, right-click elements to uncheck/check boxes to remove/restore

Action

menu and

Toolbar

elements.

¨ Enable desktop toolbar: Check to add a desktop

Toolbar

along a screen edge or in a floating window. In

addition to

Toolbar

buttons it will include an

Options

button and a

Student

and

Student group

selection

button.

3.2.6.1.6 Web Update Tab

This is the

Teacher

Options

window

Web update

tab:

It enables you to update the

Teacher

installation from the web in these elements:

· Update server []: Specify the web address of the server from which to download

Teacher

update files

(default: update.netop.com, the NetOp web update server on the Internet).

Note: To support the update of many NetOp installations in an organization, we recommend to

Publish new updates

to an internal web update server.

· HTTP proxy [] [Detect]: Specifying a

HTTP proxy

is typically not required. Before specifying a

HTTP proxy

,

click

Update now

to test the web update connection. If this yields a message indicating connection to the update server, specify no

HTTP proxy

. If

Update now

yields no connection, click [Detect] to make NetOp attempt to detect the

HTTP proxy

server to show its name and port number in the

HTTP proxy

field. Click

Update now

to test the connection. If unsuccessful, consult with your network/system administrator about what must be specified in the

HTTP proxy

field (format: <Server name>:<Port number>).

·

Update now: Click to connect to the update server specified in the

Update server

field. A Web update

message will notify you if connection to the update server failed, if no updates are available or if updates are available and in the latter case ask you if you want to download and install updates.

·

Schedule: Click to show the

Web update schedule

window.

200

NetOp Teacher

Web Update Schedule

Click the

Teacher

or

Student

Options

window

Web update

tab

Schedule

button to show this window:

It enables you to specify a

Web update

schedule in these elements:

Schedule

Click one of these options:

¤ Disabled: Scheduled

Web update

will be disabled. The other sections in the window will be disabled.

¡ Automatic download, prompt before install: Scheduled

Web update

will download available new update files and prompt the user when downloaded.

¡ Automatic download and install: Scheduled

Web update

will download and install available new update files.

¨ Allow system restart after install: Leave unchecked to show a message if restarting the computer is required after installing update files. Check to restart the computer after installing update files, if required.

Run

Click one of these options:

¤ At loading: Check for new updates when the

Teacher

or

Student

is loaded. The Delay section in the image

above will be shown.

Delay

[0] minute delay: Specify in the range 0 to 99 the number of minutes after loading the

Teacher

or

Student

Web update

shall run.

¡ Daily: Check for new updates on a daily basis. This section will be shown instead of the Delay section:

201

NetOp Teacher

Start at

[12:00] every [1] day: Specify the time of the day and by a number in the range 1 to 99 the interval in days.

¨ Randomize within the hour: Check to randomize within the hour following the specified time to avoid crowding.

Note: If the

Teacher

or

Student

is not loaded at the scheduled time,

Web update

will run when the

Teacher

or

Student

is loaded next time.

¡ Weekly: Check for new updates on a weekly basis. This section will be shown instead of the Delay section:

Start at

[12:00] every [1] week: Specify the time of the day and by a number in the range 1 to 99 the interval in weeks.

¨ <Weekday>: Check boxes to check for new updates on selected weekdays.

¨ Randomize within the hour: Check to randomize within the hour following the specified time to avoid crowding.

Note: If the

Teacher

or

Student

is not loaded at the scheduled time,

Web update

will run when the

Teacher

or

Student

is loaded next time.

¡ Monthly: Check for updates on a monthly basis. This section will be shown instead of the Delay section:

Start at

[12:00] on the [1] day of the month: Specify the time of the day and by a number in the range 1 to 28 the day of the month.

¨ Randomize within the hour: Check to randomize within the hour following the specified time to avoid crowding.

Note: If the

Teacher

or

Student

is not loaded at the scheduled time,

Web update

will run when the

Teacher

or

Student

is loaded next time.

Start date

Year [] Month [] Day []: Select in the drop-down boxes the

Web update

schedule start date.

202

3.2.6.1.7 Demonstrate Tab

This is the

Teacher

Options

window

Demonstrate

tab:

NetOp Teacher

It enables you to specify general

Demonstrate

properties in these elements:

·

Default settings: Click to show the

Demonstrate

window to specify the

Demonstrate

default action and

Demonstrate

action details.

On demoed student

¨ Lock keyboard and mouse: Check to initially disable the demonstrated

Student

computer keyboard and

mouse.

·

Session properties: Click to show the

Session properties

window to specify

Remote control

session

properties.

Note: The

Teacher

will

Remote control

a demonstrated

Student .

On teacher during student demo

þ Hide teacher main window and show demo in full screen at startup: Check to initially minimize the

Teacher

window and show the demonstrated

Student

screen image in full screen mode.

Note: Leaving checked will not hide a

Desktop toolbar

.

On receiving students

þ Show demo in full screen at startup: Check to initially show the demonstration in full screen mode.

¨ Demo in bitmap mode: Check to transfer a demonstrated screen image in bitmap mode. With some computer hardware setups, certain screen image details may be missing with the faster command mode transfer.

¨ Launch toolbox: Check to show the

Student demo toolbox

when receiving a screen image demonstration.

203

3.2.6.1.8 Attention Tab

This is the

Teacher

Options

window

Attention

tab:

NetOp Teacher

It enables you to specify what shall be shown on the computer screen of

Students

during an

Attention

session.

Show attention

Click one of these options to show a lower section that enables you to specify option details:

¤

Bitmap

¡

Text

¡

Text file

¡

Web page

204

NetOp Teacher

Attention Bitmap

On the

Attention

tab, in the

Show attention

section select Bitmap to show this lower

Attention bitmap

section:

It enables you to specify the properties of the image shown on a

Student

computer

Attention

screen in these

elements:

Attention bitmap

· File name [] [Browse]: Initially, the drop-down box field will be empty.

Attention bitmap

will use the image of

the netopsch.bmp file that resides in the folder in which the

Student

is installed. For

Attention bitmap

to use

a different image, click [Browse] to show a Windows Open window to open a .bmp file to show its path in the field. If other images have been used before, the paths of their .bmp files will be available in the drop-down box list. Click a list path to show it in the field to use its image. To use the image of the

netopsch.bmp file, clear the field contents.

Note: If the specified file is not found on a

Student

computer, the

Teacher

will attempt to distribute the file

to the

Student

computer. If unsuccessful, the

Attention

screen will show a File not found message instead

of the image.

Bitmap display method

Select one of these options:

¤ Centered: Will show the image centered on the

Student

computer screen.

¡ Stretched: Will resize the image to cover the

Student

computer screen.

· Background color: Click to show the Windows Color window to select a background color to fill out the part

of the

Student

computer screen not covered by a Centered image.

205

NetOp Teacher

Attention Text

On the

Attention

tab, in the

Show attention

section select Text to show this lower

Attention text

section:

It enables you to specify the properties of the text shown on a

Student

computer

Attention

screen in these

elements:

Attention text

·

Specify the text of maximum 128 characters that shall be shown on the

Student

computer

Attention

screen. Use CTRL+ENTER for line breaks.

þ Center text: Leave checked to center the text on the

Student

computer

Attention

screen. Uncheck to place

the text in the upper left corner of the

Student

computer

Attention

screen.

· Background color: Click to show the Windows Color window to select a background color for the text.

·

Font: Click to show the Windows Font window to select a text font.

206

NetOp Teacher

Attention Text File

On the

Attention

tab, in the

Show attention

section select Text file to show this lower

Attention text file

section:

It enables you to specify the properties of the text shown on a

Student

computer

Attention

screen in these

elements:

Attention text file

· Default text file [] [Browse]: Click [Browse] to show a Windows Open window to open a text file to show its path in the field. The text file contents will be shown on a

Student

computer

Attention

screen.

þ Center text: Leave checked to center the text file contents on the

Student

computer

Attention

screen.

Uncheck to place the text file contents in the upper left corner of the

Student

computer

Attention

screen.

· Background color: Click to show the Windows Color window to select a background color for the text file contents.

· Font: Click to show the Windows Font window to select a text file contents font.

207

NetOp Teacher

Attention Web Page

On the

Attention

tab, in the

Show attention

section select Web page to show this lower

Attention web page

section:

It enables you to specify the web page shown on a

Student

computer

Attention

screen in this element:

Attention web page

Web page address []: Specify the address of the web page that shall be shown on a

Student

computer

Attention

screen.

Note: If a

Student

computer is unable to show the specified web page, the

Attention

screen will show an error message instead of the web page.

208

3.2.6.1.9 Control Tab

This is the

Teacher

Options

window

Control

tab:

NetOp Teacher

It enables you to specify the default

Control

action and general

Remote control

and

Monitor

properties in

these elements.

Default control button

Click one of these options:

¤ Remote control: Start a

Remote control

session when clicking the

Action

menu

Control

command or the

Toolbar

Control

button.

¡ Monitor: Start a

Monitor

session when clicking the

Action

menu

Control

command or the

Toolbar

Control

button.

Remote control

¨ Lock student keyboard and mouse: Check to initially disable the

Student

computer keyboard and mouse.

¨ Show remote control in full screen: Check to initially show the

Student

computer screen image in full

screen mode on the

Teacher

computer.

¨ Remote control in bitmap mode: Check to transfer the

Student

computer screen image in bitmap mode.

With certain computer hardware setups, some screen image details may be missing with the faster command mode transfer.

Monitor students

· Monitor interval between [15] s.: Specifies the number of seconds in the range 4 to 999 between monitoring a new selected

Student .

¨ Monitor students in full screen: Check to initially show the

Student

computer screen image in full screen

mode on the

Teacher

computer.

¨ Monitor in bitmap mode: Check to transfer the

Student

computer screen image in bitmap mode. With

209

NetOp Teacher

some computer hardware setups, certain screen image details may be missing with the faster command mode transfer.

·

Session properties: Click to show the

Session properties

window.

3.2.6.1.10 Audio-Video Chat Tab

This is the

Teacher

Options

window

Audio-video chat

tab:

It enables you to specify

Teacher

Audio-video chat

properties in these elements.

Microphone sensitivity

· Silence level: Drag the slide to set the microphone sound input below which no audio data shall be sent.

·

Line hold: Drag the slide to set the time after falling below the Silence level audio data shall continue to be sent.

Note: Optimize by changing slide positions while running an

Audio-video chat

session.

·

Advanced: Click to show the

Advanced audio settings

window.

· Check sound system: Click to check the

Teacher

computer sound system to show a check result message.

210

Advanced Audio Settings

Click the

Audio-video chat

tab

Advanced

button to show this window:

NetOp Teacher

It enables you to select the preferred playback and record sound device and prioritize the use of available audio compression codecs in these elements:

Playback

· Preferred device []: The drop-down box field will initially show <Use any available device>. If audio

playback devices are connected to the

Teacher

computer, <Use any available device> may use the

computer sound system or a connected device. To use your preferred device, click its name in the drop-down box list to show it in the field.

Record

·

Preferred device []: The drop-down box field will initially show <Use any available device>. If audio recording devices are connected to the

Teacher

computer, <Use any available device> may use the

computer sound system or a connected device. To use your preferred device, click its name in the drop-down box list to show it in the field.

Audio compression

· Try audio compression codecs in the following order []: The pane will contain a prioritized list of

Teacher

computer available audio compression codecs. An

Audio-video chat

session will use the highest prioritized

codec that is also available on selected

Student

computers. You can change the list priority with these

controls:

· Up/Down: Select a codec and click to move the codec up or down in the prioritized list.

· Use defaults: Click to restore the default Windows priority.

211

3.2.6.1.11 Run Tab

This is the

Teacher

Options

window

Run

tab:

NetOp Teacher

It enables you to add, edit or delete

Run

menu programs in these elements:

The table will specify

Run

menu program records with these column contents:

·

Description: The program icon and description that will appear in the

Run

menu.

·

Path: The

Teacher

computer program file path.

Manage records from these buttons:

· Add: Click to show this window:

212

NetOp Teacher

It enables you to add or edit a

Run

menu program command in these elements:

· Click [Browse] to show a Windows Open window to open a program file to show its name in the

Description field and its

Teacher

computer path in the File name field. You can also

Run

files other than

program files, such as text files.

· Description []: Will specify the

Run

menu program command text that you can edit.

· File name []: Will specify the path from which the computer will run the program.

· Command line switches []: To apply command line switches to running the program, specify them in the field.

·

Translate: Click to replace File name field path elements by available environment variables to facilitate path identification on

Student

computers regardless of language differences.

Run

Click one of these options:

¤ Normal:

Run

in a normal window.

¡ Maximized:

Run

in a maximized window.

¡ Minimized:

Run

minimized.

·

Properties: Select a record and click to show the

Run

window to view or edit record properties.

· Delete: Select a record and click to delete it.

213

3.2.6.1.12 Policy Tab

This is the

Teacher

Options

window

Policy

tab:

NetOp Teacher

It enables you to create, edit, copy, delete and rename

Policies

and select the default

Policy

in these

elements:

The table will specify

Policy

records with these column contents:

·

Description:

Policy

icon and name.

Note: The basic Allow all and Deny all

Policies

will always be included. The default

Policy

name will be

enclosed by asterisks.

· New: Click to show this window:

Specify a new

Policy

name and click Continue to show the

Edit policy

window.

· Edit: Select a

Policy

record and click to show the

Edit policy

window.

Note: You cannot edit, delete or rename a basic

Policy

.

· Copy: Select a

Policy

record and click to show this window:

214

NetOp Teacher

Specify a name for the new

Policy

that will initially be identical to the selected

Policy

.

· Delete: Select a

Policy

record and click to show a confirmation window to confirm deleting the

Policy .

·

Rename: Select a

Policy

record and click to show this window:

Specify a new name for the

Policy

.

· Set as default: Select a

Policy

record and click to mark the

Policy

name with asterisks to apply this

Policy

to selected

Students

when clicking the

Action

menu

Policy

command or the

Toolbar

Policy

button.

þ Show notification on students: Leave checked to show a

Policy

icon in the

Student

computer screen

Windows taskbar notification area if a

Policy

is applied and show a notification from this icon when the

Policy

is applied or changed.

Note:

Policy

.xml files will by default be stored in the

Teacher

User configuration files

Policies folder. You can change the

Policy

files folder in the

Options

window

Sharing

tab

Policies

element.

215

NetOp Teacher

Edit Policy

In the

New policy

window, click

Continue

or on the

Policy

tab, click

Edit

to show this window:

It enables you to create or edit

Policy

properties. The title bar will show the

Policy

name. The window has

these tabs:

·

Application Tab

·

Internet Tab

216

Application Tab

This is the

Edit policy

window

Application

tab:

NetOp Teacher

It enables you to create or edit

Policy

Application

properties in these elements:

Click one of these basic

Policies :

¤ Allow all: Allow

Students

to run all applications except those shown in the Except pane.

¡ Deny all: Allow

Students

to run only the applications shown in the Except pane.

Click Rescan to show these Applications pane folder contents:

·

Desktop: Will contain

Teacher

computer user Desktop application shortcut names and comments and .exe

file names ordered alphanumerically.

·

Start menu: Will contain

Teacher

computer user Start menu folder Programs folder application shortcut

names and comments ordered alphanumerically.

·

Default programs dir: Will contain

Teacher

computer default program folder (typically C:\Program files) .exe

file names ordered alphanumerically.

· User defined: Will initially be empty.

217

NetOp Teacher

Double-click a folder to show/hide its contents.

Right-click any folder to show a New command. Click it to show a Windows Open window to open a file to add its path in the User defined folder.

Right-click any application shortcut or file name to show this menu:

It contains these commands:

· New: Click to show a Windows Open window to open a file to add its path in the User defined folder.

·

Rename: Click to show a Rename window to change the application shortcut or file name only in the

Applications pane.

·

Add to exception list: Click or drag the application shortcut or file name to the Except pane and drop to add the shortcut or file name application to the exceptions from the basic policy selected above.

·

Delete: Click to delete the application shortcut or file name only in the Applications pane.

If Allow all is selected above, Except pane entries will show this icon: .

If Deny all is selected above, Except pane entries will show this icon: .

To remove an Except pane entry, right-click it and select Delete.

218

Internet Tab

This is the

Edit policy

window

Internet

tab:

NetOp Teacher

It enables you to create or edit

Policy

Internet

properties in these elements:

Click one of these basic

Policies :

¤ Allow all: Allow

Students

to access all Internet addresses except those shown in the Except pane.

¡ Deny all: Allow

Students

to access only the Internet addresses shown in the Except pane.

The Internet addresses pane will contain one User defined folder that will initially be empty.

Double-click the folder to show/hide its contents.

Right-click the folder to show this window:

219

NetOp Teacher

Specify an Internet address or an Internet address fragment such as game, sex or violence and click OK to create this item in the User defined folder.

Right-click an item in the User defined folder to show this menu:

It contains these commands:

· New: Click to show the

New item

window to create an item in the User defined folder.

· Rename: Click to show a Rename window to change the item.

·

Add to exception list: Click or drag the item to the Except pane and drop to add the item to the exceptions from the basic policy selected above.

· Delete: Click to delete the item only in the Internet addresses pane.

If Allow all is selected above, Except pane entries will show this icon: .

If Deny all is selected above, Except pane entries will show this icon: .

To remove an Except pane entry, right-click it and select Delete.

Note: In the

Options

window

Sharing

tab

Blocking page

element, you can specify the Internet address of a

web page that shall be shown instead of the web page of a denied Internet address.

220

3.2.6.1.13 Sharing Tab

This is the

Teacher

Options

window

Sharing

tab:

NetOp Teacher

It enables you to specify shared folders for some of the

Teacher

created files to enable sharing these files with other

Teachers

.

It contains these elements:

·

Lesson plans [] [Browse]: Click [Browse] to show the Browse for folders window to select a local computer

or network shared folder to share

Lesson plans

with other

Teachers

that specify the same shared folder.

· Policies [] [Browse]: Click [Browse] to show the Browse for folders window to select a local computer or network shared folder to share

Policies

with other

Teachers

that specify the same shared folder.

· Recordings [] [Browse]: Click [Browse] to show the Browse for folders window to select a local computer or network shared folder to share

Recordings

with other

Teachers

that specify the same shared folder.

· Snapshots [] [Browse]: Click [Browse] to show the Browse for folders window to select a local computer or network shared folder to share

Remote control

or

Monitor

session

Print screen to file

snapshots with other

Teachers

that specify the same shared folder.

· Tests - public folder [] [Browse]: Click [Browse] to show the Browse for folders window to select a local computer or network shared folder to share

Public tests

view

Tests

with other

Teachers

that specify the

same shared folder.

221

NetOp Teacher

·

Surveys - public folder [] [Browse]: Click [Browse] to show the Browse for folders window to select a local computer or network shared folder to share

Public tests

view

Surveys

with other

Teachers

that specify the same shared folder.

· Blocking page (specify URL prefixed by HTTP://) []: If an Internet address is blocked by a

Policy

, a blocking page will be shown instead. The default blocking page has the URL path

http://www.netop.com/blocking/

.

To replace the default blocking page by another web page, specify its URL path.

Note: The specified URL path will be stored in the

NetOp.ini

file

[TEACHER]

section

BLOCKPATH

key.

3.2.6.1.14 Protection Tab

This is the

Teacher

Options

window

Protection

tab:

It enables you to protect selected

Options

window tabs by a password in these elements:

Protection password

Change protection password: Click to show this window:

Specify the

Protection password

in these fields:

·

Old password []: Specify the current

Protection password

(disabled if no

Protection password

is applied).

·

New password []: Specify the new

Protection password

(leave empty if no

Protection password

shall be

222

NetOp Teacher

applied).

· Confirm password []: Re-specify the new

Protection password

for confirmation.

Click OK and close the

Options

window to apply.

Protect options

The section contains check boxed names of the available

Options

window tabs (except

Protection

that will

always be protected by a

Protection password

). Check boxes to protect tabs.

Note: In the

Options as tabs

mode, the

Options

window but not the individual tabs will be protected by the

Protection password .

3.2.6.2 Help Request

A connected

Student

can send a

Help request

to the

Teacher

.

When a

Help request

arrives, the

Teacher

user will be alerted by a sound being played and this icon being

shown in the Windows taskbar notification area:

Right-click to show a list of the

Students

with a pending

Help request

.

A

Help request

will typically be accompanied by a problem description that will be shown in the

Details view

pane

Information

column.

Respond to a

Help request

by any

Action

menu or

Toolbar

action, typically by double-clicking the

Details view

pane

Student

record,

Classroom view

pane

Student

icon or

Thumbnails view

pane

Student

thumbnail to start

a

Remote control

session with the

Student

. A responded to

Help request

will be cleared.

.

To clear a

Help request

, right-click the

Details view

pane

Student

record,

Classroom view

pane

Student

icon

or

Thumbnails view

pane

Student

thumbnail to show the

Student context menu

and select

Clear help request

3.3 NetOp Screen Image

NetOp screen image

is a

Teacher

tool for capturing screen images.

To load

NetOp screen image

, click Start > All programs > NetOp School > Tools > Screen image or run the

file ScreenGrabber.exe in the Screen image folder under the folder in which

NetOp Teacher

is installed to

show this window:

223

NetOp Teacher

It enables you to specify

NetOp screen image

setup on these tabs:

·

Capture

·

Image of

·

Save as

·

Preferences

After setup, click OK to minimize

NetOp screen image

into this button in the Windows taskbar notification area:

To capture a screen image as specified in

NetOp screen image

setup, press the

Capture key

specified on the

Capture

tab.

To restore the

NetOp screen image

setup window, click the button context menu Open command.

To unload

NetOp screen image

, click the button context menu Close command or the

NetOp screen image

setup window Cancel button or a title bar Close control.

3.3.1 Capture Tab

This is the

NetOp screen image

setup window

Capture

tab:

It enables you to specify

Capture

setup in these elements:

· Capture key []: The drop-down box list contains from F1 to F10 referring to these keyboard keys. Click a key in the list to show it in the field as the selected

Capture key

.

Note: If your first choice

Capture key

appears to be used by another functionality, select another.

Delay

þ Delay before capture (1 - 60 seconds) []: Leave checked and adjust the number in the spin box to delay capture to enable preparations before capturing the image. Uncheck to capture without delay.

224

3.3.2 Image of Tab

This is the

NetOp screen image

setup window

Image of

tab:

NetOp Teacher

It enables you to select which screen area to capture in this element:

Click one of these options:

¤ Active window: Will capture the computer screen active window.

¡ Client window: Will capture the computer screen active window without its title bar.

¡ Full screen: Will capture the entire computer screen.

¡ Rectangular area: Will change the mouse pointer into a pointing hand. Drag a rectangle to capture its contents.

3.3.3 Save As Tab

This is the

NetOp screen image

setup window

Save as

tab:

It enables you to specify image file save properties in these elements:

· Save as name []: Will be disabled if the

Name automatically

box is checked. The drop-down box list will contain image file names used before. Click one to show it in the field as selected or specify a name in the field.

225

NetOp Teacher

Note: A captured image file will without warning overwrite any older file in the same location with the same name.

þ Name automatically: Leave checked to automatically name captured image files image<Number> using the next available number not used by image files in the same location.

· Save as type []: The drop-down box list contains these image file types:

·

Windows bitmap (*.bmp)

·

JPEG (*.jpg)

·

GIF (*.gif)

·

PNG (*.png)

Click an image type to show it in the field as selected.

Save in directory: [] [...]: Will initially specify a NetOp ScreenImages folder in your My documents folder.

Click [...] to show the Browse for folder window to select a folder whose path will be specified

3.3.4 Preferences Tab

This is the

NetOp screen image

setup window

Preferences

tab:

It enables you to specify capture preferences in these elements:

¨ Remove button: Check to remove the notification area

NetOp screen image

button while capturing.

þ Notify upon completion: Leave checked to play a sound and show this notification upon capture completion:

226

NetOp Teacher

3.4 NetOp Screen Video

NetOp screen video

is a

Teacher

tool for recording screen videos.

To load

NetOp screen video

, click Start > All programs > NetOp School > Tools > Screen video or run the

file ScreenCapture.exe in the Screen video folder under the folder in which

NetOp Teacher

is installed to show this window:

It enables you to record a screen image area video sequence like this:

1. Click the

Toolbar Record

button to show a mouse moveable recording region.

2. Move the mouse to position the region. Click to start recording showing flashing colored corners.

3. Click the

Toolbar Stop

button to show a Windows Save as window.

4. Specify a file name and click Save to save the recording file.

Note: The recording .avi file will play in Windows media player.

The

NetOp screen video

window contains these elements:

·

Title bar

·

Menu bar

·

Toolbar

3.4.1 Title Bar

This is the

NetOp screen video

window title bar:

You can unload and minimize

NetOp screen video

with the available window controls.

While pausing recording, Paused will flash in the title bar.

3.4.2 Menu Bar

This is the

NetOp screen video

window menu bar:

It contains these menus:

·

File

·

Region

·

Options

·

About

227

NetOp Teacher

3.4.2.1 File Menu

This is the

NetOp screen video

window

File

menu:

It contains these commands:

·

Record: Click, click the

Toolbar Record

button or press the

Record/Pause

keyboard shortcut to start recording. Recording region options are explained in

Region

menu. Other options are explained in

Options

menu.

·

Stop: Click, click the

Toolbar Stop

button or press the

Stop

keyboard shortcut to stop recording.

·

Pause: Click, click the

Toolbar Pause

button or press the

Record/Pause

keyboard shortcut to pause

recording. While pausing, the

Title bar

will flash Paused. To resume recording, click

Record

.

· Exit: Click or use a

Title bar

Close window control to unload

NetOp screen video

closing the

NetOp screen video

window.

3.4.2.2 Region Menu

This is the

NetOp screen video

window

Region

menu:

It contains these commands:

· Dragged region: Click to check mark as the selected region option to show cross hairs to drag a region when starting recording.

· Specified region: Click check mark as the selected region option to show this window:

228

NetOp Teacher

It enables you to specify the recording region in these elements:

· Specify: Click to change the mouse pointer into pencil cross hairs. Drag a rectangular frame to enter its dimensions into the enabled fields below.

· Width [] px: Specify the pixels region width.

· Height [] px: Specify the pixels region height.

¨ Fixed top left corner: Check to enable the fields below to specify the region top left corner offset from the screen top left corner.

Note: If Fixed top left corner is checked, the region will be fully defined. Recording will start immediately without showing a mouse moveable recording region.

· Left offset [] px: Specify the region left border pixels distance from the screen left border.

· Top offset [] px: Specify the region top border pixels distance from the screen top border.

·

Full screen: Click to check mark as the selected region option to record a full screen video when starting recording.

3.4.2.3 Options Menu

This is the

NetOp screen video

window

Options

menu:

It contains these commands:

· Video options: Click to show this window:

229

NetOp Teacher

It enables you to specify video properties in these elements:

·

Video codec []: The drop-down box list will contain the names of available video codecs. Click a video codec name to show it in the field as selected.

· About: Click to show information on the selected video codec.

· Configure: Will be enabled only if a configurable video codec is selected. Click to show the matching configuration window.

· Quality: Drag this slide to select the video quality as shown by a number between 0 and 100 to the right.

A higher quality video file will be larger.

You can auto adjust or specify frame rates. Initially, the Auto adjust box will be checked to disable the fields and enable the bottom frame rate slide. Its left Max frame rate end represents recording 200 frames/second and its right end represents recording 1 frame/minute. It will automatically specify field numbers in two ranges:

Recording frame rate Set key frames every Capture frame every Playback rate

200 - 1 frames/second Second

60 - 1 frames/minute 20 frames

0.005 - 1 second

1 - 60 seconds

Recording frame rate

20 frames/second

Uncheck the Auto adjust box to disable the bottom frame rate slide and enable the fields to specify numbers in these ranges:

· Set key frames every [] frames: 1 - 200.

Note: Playback will synchronize at each key frame.

·

Capture frame every [] milliseconds: 1 - 7200000 (2 hours).

Note: A large number of frames will make a large file.

230

·

Playback rate [] frames/second: 1 - 200.

· Cursor options: Click to show this window:

NetOp Teacher

It enables you to specify cursor properties in these elements:

Cursor display

Click one of these options:

¡ Hide cursor: Do not include the cursor in the recording.

¤ Show cursor: Include the cursor in the recording. Select one of these sub-options:

¤ Use default cursor: Include the screen cursor in the recording.

¡ Use custom cursor []: The drop-down box list will contain the names of available custom cursors.

Click a name to show it in the field. Include this cursor in the recording.

¡ Use cursor from file []: Click the

button to show a Windows Open window with the contents of the Windows Cursors directory. Open a cursor file to include this cursor in the recording.

Note: The selected cursor will be shown in the upper right part of the section.

Cursor highlight

¨ Highlight cursor: Check to show a highlight around the cursor.

· Size []: Drag the slide to change the size of the cursor highlight. Its half size will be shown to the right.

·

Shape [] [Color]: The drop-down box list will contain available cursor highlight shape names. Click a shape name to show it in the field as selected. Click the Color button to show the Windows Color window to select a cursor highlight color.

· Record audio: Click to check mark to record sound playing on the computer and input to the computer from e.g. a microphone. Click the check marked command to uncheck it.

· Audio options: Click to show this window:

231

NetOp Teacher

It enables you to specify audio properties in these elements:

Audio capture device []: The drop-down box list will contain the names of available audio capture devices.

Click a name to show it in the field as selected.

Recording format []: The drop-down box list will contain the names of available recording formats. Click a format to show it in the field as selected.

Compression format [] [] [Choose compression format]: The two upper fields will show the type and attributes of the selected compression format. Click Choose compression format to show this window:

It enables you to specify an audio compression format in these elements:

· Name: [] [Save as] [Remove]: The drop-down box list will contain the names of saved audio compression formats. Click a name to show it in the field as selected. Click Save as to show this window:

232

NetOp Teacher

Specify the name by which the audio compression format shall be saved.

Click Remove to remove the selected saved audio compression format.

· Format []: The drop-down box list will contain the names of available audio compression formats. Click a name to show it in the field as selected.

· Attributes []: The drop-down box list will contain available sets of compression format attributes. Click a set to show it in the field as selected.

Interleave video and audio

þ Interleave every [] ¡ Frames/¤ Milliseconds: Leave checked to interleave video and audio. Specify a number in the field. Select Frames or Milliseconds.

·

Enable autopan: Click to check mark to automatically move the recording region center towards the mouse pointer position while recording. Click the check marked command to uncheck it to not move the region.

· Autopan speed: Click to show this window:

Drag the slide to set the maximum pan speed in the range 1 - 200. The pan speed of the slider position will be shown in the lower right corner of the window.

· Program options: Expands into these commands:

· Minimize upon recording: Click to check mark to minimize the

NetOp screen video

window to the

Windows taskbar when recording.

· Suppress flashing frame: Click to check mark to suppress the selected region flashing frame during recording.

· Recording thread priority: Expands into these commands:

· Normal: Click to check mark to assign normal priority to the recording thread.

· Above normal: Click to check mark to assign above normal priority to the recording thread.

· Highest: Click to check mark to assign highest priority to the recording thread.

· Time critical: Click to check mark to assign time critical priority to the recording thread.

· Keyboard shortcuts: Click to show this window:

233

NetOp Teacher

Record/Pause key []: The drop-down box list will contain available keyboard shortcuts. Click one to show it in the field as the selected Record/Pause keyboard shortcut.

Stop key []: The drop-down box list will contain available keyboard shortcuts. Click one to show it in the field as the selected Stop keyboard shortcut.

Cancel recording key []: The drop-down box list will contain available keyboard shortcuts. Click one to show it in the field as the selected Cancel recording keyboard shortcut.

Note: A canceled recording leaves no file to be saved.

3.4.2.4 About Menu

This is the

NetOp screen video

window About menu:

About: Click to show this window:

234

NetOp Teacher

It shows the

NetOp screen video

version and build number that will be asked for if you request technical

support.

3.4.3 Toolbar

This is the

NetOp screen video

window toolbar:

It contains these buttons:

Record: Click, click the

File

menu

Record

command or press the

Record/Pause

keyboard shortcut

to start recording. Recording region options are explained in

Region

menu. Other options are

explained in

Options

menu.

Pause: Click, click the

File

menu

Pause

command or press the

Record/Pause

keyboard shortcut to

pause recording. While pausing, the

Title bar

will flash Paused. To resume recording, click

Record

.

Stop: Click, click the

File

menu

Stop

command or press the

Stop

keyboard shortcut to stop recording.

235

NetOp Student

4 NetOp Student

This section explains

Student

properties in these sections:

·

Load and unload Student

·

Student window

4.1 Load and Unload Student

The

Student

will typically be set up to

Load at Windows startup

, to

Join class when loaded

and to

Minimize

into this Windows taskbar notification area button:

The button tool tip will show the

Student

Status

and its computer IP address if communicating using the

TCP/

IP

Communication device

.

Right-click the

NetOp Student

button to show this menu:

It contains these commands:

·

Restore: Click to show the

Student

window.

· Exit: Click to unload the

Student

.

· Request help: Will be enabled if connected to a

Class

. Click to

Request help

from the

Teacher

that runs

the

Class

.

Alternatively, the

Student

can be set up not to

Load at Windows startup

, not to

Join class when loaded

and not to

Minimize

and further to load in

Stealth mode

where nothing on the computer screen will show that the

Student

is loaded.

Load

To load the

Student

if not loaded, click typically Start > All programs > NetOp School > Student. If this does not show either the

Student

window or the

NetOp Student

button, the

Student

is probably already loaded in

Stealth mode .

Alternative loading methods are explained in the

Loading alternatives

section.

When loading the

Student

for the first time after a typical

Installation

, the

Setup wizard

will run to enable initial

Student

setup.

Unload

To unload the

Student

, click the

NetOp Student

button menu or

File

menu

Exit

command or use a

Title bar

Close window control.

Unloading the

Student

can be protected by a

Protection password

to show this window when you attempt to

unload the

Student :

236

NetOp Student

To unload, specify the

Protection password

and click OK.

This section contains these sections:

·

Loading alternatives

·

Setup wizard

4.1.1 Loading Alternatives

These

Student

loading alternatives are available:

1. In the folder where

NetOp Student

was installed, typically C:\Program files\Danware Data\NetOp School

\Student, run (double-click) the

Student

program file nstdw32.exe.

2. Create a desktop shortcut to the

Student

program file nstdw32.exe. Double-click this shortcut.

3. From a Windows Run or Command prompt window, execute the

Student

program file nstdw32.exe.

To load the

Student

from another application, use a command that you can expand with command line switches according to this syntax: nstdw32 [/C:<Communication profile>] [/N:<Class name>]

If the

Class

name contains spaces, it must be enclosed within quotation marks.

If any of the switches are not used, the parameters that applied when the

Student

was last unloaded by any user will be used.

Examples

To load the

Student

with the

Communication profile

named IPX to join the

Class

named Geography, use this command line: nstdw32 /C:IPX /N:Geography

To load the

Student

with the

Communication profile

that was used when it was last unloaded but to join the

Class

named Dr. Nelson, use this command line:

nstdw32 /N:"Dr. Nelson"

237

NetOp Student

4.1.2 Setup Wizard

When any user loads the

Student

for the first time after an

Installation

that did not like

Student deployment

install the

Student

in a fully set up state, this

Setup wizard

will run. You can also run the

Setup wizard

from

the

Student

window

Tools

menu

Run setup wizard

command, unless it is unavailable to you by

Protection password

protection. This window will be shown in front of the

Student

window:

The

Setup wizard

will guide you through initial

Student

setup.

Click Next to show this window:

238

NetOp Student

It enables you to select how the

Student

shall load and start.

þ Join class at program startup: Leave checked to let the

Student

Join class

(start communicating) when

loaded to connect to a running

Class

that is ready for it. Uncheck to

Join class

manually.

þ Load student at Windows startup: Leave checked to load the

Student

when Windows starts running on the computer. Uncheck to load the

Student

manually.

þ Minimize student at program startup: Leave checked to load the

Student

minimized into a Windows

taskbar notification area

NetOp Student

button. Uncheck to load the

Student

showing the

Student

window.

¨ Stealth mode (hide student when started): Leave unchecked to load the

Student

visible on the computer screen. Check to load the

Student

hidden.

Note: You can change these selections in the

Student

Options

window

General

tab

Startup

section.

Click Next to show this window:

239

NetOp Student

It enables you to select how the

Student

shall connect to a

Class

and identify itself to

Teachers

.

Click one of these options:

¤ Connect to class []: Specify a

Class

name to, when

Joining class

, connect to this

Class

if it runs or when it starts running.

¡ Browse for classes: When

Joining class

, get a list of running

Classes

for the

Student

user to decide which

of these

Classes

to connect to.

¡ Be available for any class: When

Joining class

, connect to a running

Class

of which the

Student

is a

member. If no

Class

of which the

Student

is a member is running, running

Class

Teacher

users can connect

or invite the

Student

to connect to their

Class

.

¡ Select class: When

Joining class

, the

Student

user can specify a

Class

name, alternatively a computer IP

address or DNS name to connect if the specified

Class

runs or when it starts running, alternatively if any

Class

runs on the specified address computer or when it starts running.

Note: You can change this selection on the

Student

Options

window

Class

tab.

Identify student by []: The drop-down list will contain user, computer and specified name variants as explained in the

Student login tab

section. Click typically

Computer name

if the

Student

runs on a network

computer or

Windows login name

if the

Student

runs in a terminal server client session.

Note: You can change this selection on the

Student

Options

window

Student login

tab.

Click Next to show this window:

240

NetOp Student

It enables you to select how the

Student

shall communicate.

Communication profile []: The drop-down box list will contain the names of the

Communication profiles

that

are available on the

Student

. If you have no other preferences, TCP/IP, if available, will most likely be the right selection for you.

NetOp Name Server

¨ Use NetOp Name Server: Only if the

Teachers

and

Students

in this

Student's

environment shall connect

by using

NetOp Name Management

, check to enable the elements below.

·

Primary []: Specify the

Primary

NetOp Name Server IP address or DNS name.

· Secondary []: Specify the

Secondary

NetOp Name Server IP address or DNS name.

·

Name space ID []: Specify the

Name space ID

used by this

Student's

environment.

Note: You can change these selections from the

Student

Options

window

Connection

tab.

Click Next to show this window:

241

NetOp Student

It enables you to register your license with the manufacturer.

Note: Registering your license with the manufacturer may prove useful if you lose your license certificate and if you want to upgrade to a newer version of the product. Do not register if the license was already registered.

Select one of these options:

¤ Yes, I want to register my NetOp license on-line: When clicking Next, the NetOp product registration website will open for you to register before continuing.

¡ No, but remind me later: When the

Student

is loaded next time, this window will be shown.

¡ No, I do not want to register my NetOp license now: You will not be reminded of registration any more.

Click Next to show this window:

242

NetOp Student

Click Finish to end the

Setup wizard

closing the window.

4.2 Student Window

This is the

Student

window:

It contains these elements:

243

NetOp Student

·

Title bar

·

Menu bar

·

Toolbar

·

Tab panel

·

Status bar

4.2.1 Title Bar

This is the

Student

window title bar:

Click the left

Student

button or right-click anywhere in the title bar to show a window control menu.

These

Status

indications will be shown next to the window name:

·

Loading: The

Student

is loading.

·

Not in class: The

Student

has not

Joined class

(is not communicating).

·

Joining: The

Student

is

Joining class

(is starting communicating).

· Waiting for <Class name>: The

Student

has

Joined class

(is communicating) and is ready to connect to

<Class name> when it becomes available.

· <Nothing>: The

Student

has

Joined class

(is communicating) and is browsing for

Classes

.

· <Available>: The

Student

has

Joined class

(is communicating) and is available for any

Class

.

·

<

Class

name>: The

Student

has

Joined class

(is communicating) and is connected to <

Class

name>.

·

Controlled by <

Class

name>: The

Student

has

Joined class

(is communicating) and is in a session that is controlled by the

Teacher

that runs <

Class

name>.

· Leaving: The

Student

is

Leaving class

(is disconnecting if applicable and stopping communicating).

4.2.2 Menu Bar

This is the

Student

window menu bar:

It contains these menus:

·

File

·

View

·

Action

·

Tools

·

Help

4.2.2.1 File Menu

This is the

Student

window

File

menu:

It contains this command:

244

NetOp Student

·

Exit Alt+F4: Click, click the

NetOp Student

button menu Exit command, press ALT+F4 or use a

Title bar

window control Close functionality to unload the

Student

.

Note: Exit can be protected by a

Protection password

.

4.2.2.2 View Menu

This is the

Student

window

View

menu:

It contains this command:

· Toolbar: Click to remove/restore the

Toolbar

removing/restoring the check mark next to the command..

4.2.2.3 Action Menu

This is the

Student

window

Action

menu:

It contains these commands:

· Join class: Will be enabled if the

Student

Status

is

Not in class

. Click or click the

Toolbar

Join class

button

to

Join class

(start communicating).

·

Leave class: Will be enabled if the

Student

Status

is not

Loading

,

Not in class , Joining

or

Leaving

. Click or

click the

Toolbar

Leave class

button to

Leave class

(disconnect if applicable and stop communicating).

Note:

Leave class

can be protected by a

Protection password

.

· Rejoin class: Will be enabled if the

Student

Status

is not

Loading

,

Not in class , Joining

or

Leaving

. Click or

click the

Toolbar

Rejoin class

button to

Leave class

and immediately

Join class

(disconnect if applicable

and stop and start communicating).

Note:

Rejoin class

can be protected by a

Protection password

.

· Request help: Will be enabled if the

Student

is connected to a

Class

and no

Help request

is pending. Click or click the

Toolbar

Request help

button, click the

NetOp Student

button menu or

NetOp help request

button

Request help

command or double-click the

NetOp help request

button to show this window:

Describe the problem for which you are requesting help and click OK to send the

Help request

.

·

Cancel help: Will be enabled if a

Help request

is pending. Click or click the

Toolbar

Cancel help

button,

click the

NetOp help request

button menu

Cancel help

command or double-click the

NetOp help request

245

NetOp Student

button to cancel the

Help request

on

Student

and

Teacher

.

· End session: Will be enabled if the

Student

is engaged in a session. Click to end the session.

Note: End session can be protected by a

Protection password

.

4.2.2.4 Tools Menu

This is the

Student

window

Tools

menu:

It contains these commands:

·

Options: Click to show the

Options

window that is explained in the

Options

section.

Note:

Options

can be protected by a

Protection password

.

· Options as icons: Will be included if the

Options

window tabs version is enabled. Click to enable the

Options

window icons version.

·

Protection password: Click to show the

Protection password

window that is explained in the

Protection password

section.

Note:

Protection password

can be protected by a

Protection password

.

·

Check for new updates: Click to check for new updates to the

Student

installation on the update server

specified on the

Web update

tab.

· Run setup wizard: Click to run the

Student

Setup wizard

.

Note:

Run setup wizard

can be protected by a

Protection password

.

·

Debug trace: To include this command, press ALT+Z while showing the

About NetOp School Student

window. Click to save a log of recent

Student

communication, which will assist NetOp professionals in diagnosing communication problems. The debug trace is a plain text file. Interpreting its contents requires special NetOp skills.

4.2.2.5 Help Menu

This is the

Student

window

Help

menu:

It contains these commands:

· Contents: Click to open the NetOp Student Help window that has a graphical table of contents in its left pane.

· Online support: Click to open the Support for NetOp School web page to request technical support.

·

Apply license/Online registration: Will be Apply license if a trial version is installed and Online registration if a licensed version is installed.

246

NetOp Student

·

Apply license: Click to show this window:

Specify your licensee name and your

Student

license number and click OK to replace the trial version licensee name and license number by the specified licensee name and license number.

· Online registration: Click to open the NetOp product registration web page to register your license with the NetOp manufacturer.

· About: Click to show this window:

It contains information on your

Student

installation. The build number in format YYYYDDD (Y=year number

digit, D=day number digit) is enclosed in parentheses next to the version number.

System Info: Click to show the

System info

window.

4.2.3 Toolbar

This is the

Student

window

Toolbar :

247

NetOp Student

You can drag the

Toolbar

to place it inside or outside the

Student

window.

You can hide and restore the

Toolbar

from the

View

menu

Toolbar

command.

The

Toolbar

contains these buttons:

Join class: Will be enabled if the

Student

Status

is

Not in class

. Click or click the

Action

menu

Join class

command to

Join class

(start communicating).

Leave class: Will be enabled if the

Student

Status

is not

Loading

,

Not in class , Joining

or

Leaving

.

Click or click the

Action

menu

Leave class

command to

Leave class

(disconnect if applicable and stop communicating).

Note:

Leave class

can be protected by a

Protection password

.

Rejoin class: Will be enabled if the

Student

Status

is not

Loading

,

Not in class , Joining

or

Leaving

.

Click or click the

Action

menu

Rejoin class

command to

Leave class

and immediately

Join class

(disconnect if applicable and stop and start communicating).

Note:

Rejoin class

can be protected by a

Protection password

.

Request help: Will be enabled if the

Student

is connected to a

Class

and no

Help request

is pending.

Click or click the

Action

menu

Request help

command, click the

NetOp Student

button menu or

NetOp help request

button

Request help

command or double-click the

NetOp help request

button to

show the

Help request

window to specify a problem description and send the

Help request

.

Cancel help: Will be enabled if a

Help request

is pending. Click or click the

Action

menu

Cancel help

command, click the

NetOp help request

button menu

Cancel help

command or double-click the

NetOp help request

button to cancel the

Help request

on

Student

and

Teacher

.

4.2.4 Tab Panel

This is the

Student

window

Tab panel

:

It contains these tabs:

·

General

·

Class

·

Messages

·

Recordings

248

NetOp Student

4.2.4.1 General Tab

This is the

Student

window

General

tab:

It contains these sections:

·

Status []: Will almost like the

Title bar

show the

Student

status like this:

·

Loading: The

Student

is loading.

· Not in class: The

Student

has not

Joined class

(is not communicating).

· Joining: The

Student

is

Joining class

(is starting communicating).

·

Waiting for <Class name>: The

Student

has

Joined class

(is communicating) and is ready to connect to

<Class name> when it becomes available.

·

<Nothing>: The

Student

has

Joined class

(is communicating) and is browsing for

Classes

.

·

<Available>: The

Student

has

Joined class

(is communicating) and is available for any

Class

.

· In <

Class

name>: The

Student

has

Joined class

(is communicating) and is connected to <

Class

name>.

· Controlled by <

Class

name>: The

Student

has

Joined class

(is communicating) and is in a session that

is controlled by the

Teacher

that runs <

Class

name>.

·

Leaving: The

Student

is

Leaving class

(is disconnecting if applicable and stopping communicating).

·

Computer and student login name []: Will show the

Student

computer name and

Student login

name.

Note: A prompted for

Student login

name will not be shown.

·

Connection method []: Will show the

Class

connection method.

249

4.2.4.2 Class Tab

This is the

Student

window

Class

tab:

If the

Student

is connected to a

Class

, it will show the

Students

in the

Class

.

Its table will contain connected

Student

records with details in these columns:

· Status: Can show these status icons:???

Engaged in a

Demonstrate

session.

Engaged in an

Attention

session.

Engaged in a

Remote control

session.

Engaged in a

Monitor

session.

Engaged in an

Audio-video chat

session.

Engaged in a

Chat

session.

Assistant

Teacher

in a

Workgroup

session.

Engaged in a

Distribute files

session.

Engaged in a

Collect files

session.

Engaged in a

File manager

session.

Has a pending

Help request

.

· Student display name: The name by which the

Teacher

displays the

Student

.

You cannot execute any actions on this tab.

NetOp Student

250

NetOp Student

4.2.4.3 Messages Tab

This is the

Student

window

Messages

tab:

It enables you to manage received

NetOp messages

.

Note: When received,

NetOp messages

will be saved as .rtf files in the

Student

User configuration files

folder Messages folder.

NetOp messages

in this folder will be shown in the

Messages

tab table.

The

Messages

tab table will contain

NetOp message

records with details in these columns:

·

Received:

NetOp message

icon and received date and time.

·

From: The

Teacher

Options

window

Teachers

tab

Teacher name

section specified

Title

and

Name

.

·

Subject: First

NetOp message

line contents.

Right-click a record to show this menu:

It contains these commands:

·

View: Click to show the

NetOp message

in this window:

From the menus and toolbar buttons, you can save the message in a different location with a different file name, print the message text, copy selected text and search for text elements.

251

NetOp Student

·

Delete: Click to delete the

NetOp message

.

4.2.4.4 Recordings Tab

This is the

Student

window

Recordings

tab:

It enables you to manage received

NetOp recordings .

Note:

Students

will receive

Teacher

NetOp recordings

distributed via a

Groups

pane

Student group

icon or

record in the

Student

User configuration files

folder screcord folder.

NetOp recordings

in this folder will be

available in the

Recordings

tab Recordings folder.

The

Recordings

tab contains a left folders pane and a right records pane.

The left folders pane will initially contain a Recordings root folder. Right-click in the folders pane to show this context menu:

It contains these commands:

· Cut: Select a user created folder and click to remove the folder with its contents to place it on the clipboard.

· Copy: Select a folder and click to place a copy of the folder with its contents on the clipboard.

·

Paste: Click to paste the clipboard contents into the selected folder.

· New folder: Click to create a folder in the selected folder showing this window:

252

NetOp Student

Specify the folder name and click OK to create.

· Delete: Select a folder and click to show a confirmation window to confirm deleting the folder with its contents.

· Rename: Select a folder and click to show this window:

Edit the folder name and click OK to rename

The right records pane will show selected folder recording records in a table with these column contents:

· Name: Recording name.

·

Recorded: Recording date and time.

· Duration: Recording duration.

· Teacher: Recording type of NetOp module.

Right-click in the records pane to show this context menu:

It contains these commands:

·

Playback recording: Click to play back the most recently clicked record recording in the

Recording playback

window.

· Cut: Select one or multiple (pressing SHIFT or CTRL) records and click to remove records to place them on the clipboard.

· Copy: Select one or multiple (pressing SHIFT or CTRL) records and click to place a copy of them on the clipboard.

·

Paste: Click to paste the clipboard contents into the records pane.

· New: Expands into:

· Folder: Click to show the

New folder

window to create a folder in the selected folder.

· Delete: Select one or multiple (pressing SHIFT or CTRL) records and click to show a confirmation window to confirm deleting them.

Drag or press CTRL and drag selected records to a folder and drop them to move or copy selected records to the folder.

253

NetOp Student

4.2.5 Status Bar

This is the

Student

window

Status bar

:

Its right end will show the

Student

computer IP address if the

Student

is communicating by a

Communication profile

that uses the

TCP/IP

Communication device

. If the

Student

uses multiple IP addresses, a + will be shown to the right of the IP address. Click the + to show other used IP addresses.

A yellow pages icon will be shown if the

Advanced TCP/IP configuration

window

Use NetOp Name Server

box is checked. These symbols can be shown on the icon:

·

Nothing: Specified NetOp Name Servers are available.

· Red exclamation mark (!): One of two specified NetOp Name Servers is available.

· Red X: No NetOp Name Server is available.

When the mouse pointer is over a menu command or

Toolbar

button, the

Status bar

left end will show a hint

to the menu command or

Toolbar

button.

4.2.6 Student Tools

This section explains these

Student

tools:

·

Options

·

Protection password

4.2.6.1 Options

Click the

Student

window

Tools

menu

Options

command to show this window:

It provides access to

Options

tabs.

Right-click in the window pane to show this menu:

254

NetOp Student

It contains these commands:

·

Open: Will be enabled if an option icon is right-clicked. Click or double-click an option icon to show the option tab window.

·

Large icons: Will be enabled if the small icons

Options

window below is shown. Click to show the large icons

Options

window above.

·

Small icons: Will be enabled if the large icons

Options

window above is shown. Click to show this window:

· Options as tabs: Click to show this

Options

window with tabs instead of icons after closing and opening

the

Options

window:

To return to the

Options

window with icons, click the

Tools

menu

Options as icons

command.

The

Options

window contains these tabs:

·

General

255

·

Class

·

Student login

·

Protection

·

Audio-video chat

·

Help request

·

Connection

·

Web update

4.2.6.1.1 General Tab

This is the

Student

Options

window

General

tab:

NetOp Student

It enables you to specify

Student

Startup

and

Control session

properties and a

Connection password

in these elements:

Startup

þ Join class at program startup: Leave checked to let the

Student

Join class

(start communicating) when

loaded to connect to a running

Class

that is ready for it. Uncheck to

Join class

manually.

þ Load student at Windows startup: Leave checked to load the

Student

when Windows loads on the computer. Uncheck to load the

Student

manually.

þ Minimize student at program startup: Leave checked to load the

Student

minimized into a Windows

taskbar notification area

NetOp Student

button. Uncheck to load the

Student

showing the

Student

window.

¨ Stealth mode (hide student when started): Leave unchecked to load the

Student

visible on the computer screen. Check to load the

Student

hidden.

Note: To unhide a

Stealth mode

Student

, run (double-click) the showhost.exe file that resides in the folder in

which the

Student

is installed. Unhiding a

Stealth mode

Student

can be protected by a

Protection password

.

Control session

¨ Minimize student in control session: Check to minimize the

Student

window into a a Windows taskbar

notification area

NetOp Student

button when a

Teacher

starts a

Remote control

or

Monitor

session with it.

256

NetOp Student

¨ Student top most in control session: Check to show the

Student

window in front of any other window when

a

Teacher

starts a

Remote control

or

Monitor

session with it.

Connection password

· Specify a password to enable only

Teachers

whose

Options

window

General

tab

Connection password

section contains the same password to connect.

4.2.6.1.2 Class Tab

This is the

Student

Options

window

Class

tab:

It enables you to select how the

Student

shall connect to a

Class

.

Click one of these options:

¤ Connect to class []: The drop-down box list will contain the names of

Classes

connected to before. Click a

Class

name to show it in the field as selected. When

Joining class

(starting communicating), the

Student

will

browse for the selected

Class

to connect to it if running or wait for it to run and then connect.

¡ Browse for classes: When

Joining class

(starting communicating), the

Student

will browse for running

Classes

to show responses in this window:

257

NetOp Student

The Available classes pane will show the names of responding running

Classes

. Select one and click OK

to connect to it. Click Cancel to

Leave class

. Click Browse to browse again.

¡ Be available for any class: When

Joining class

(starting communicating), the

Student

will announce being available for any

Class

. A

Teacher

that runs a

Class

of which the

Student

is a member will respond to make the

Student

connect to the

Class

. The users of other

Teachers

that run a

Class

can see that the

Student

is

available to connect or invite the

Student

to connect to their

Class

. A

Class

invitation can look like this:

Click OK to accept the invitation to automatically connect to the

Class

. Click Cancel to decline.

¡ Select class: When

Joining class

(starting communicating), the

Student

will show this window:

258

NetOp Student

The drop-down box list will contain

Class

names, IP addresses and DNS names that have been used

before.

Click Class name and click a

Class

name in the list or specify it in the field. Click Connect to browse for the selected

Class

to connect to it if running or wait for it to run and then connect.

Click IP address or DNS name and click an IP address or DNS name in the list or specify it in the field.

Click Connect to connect to the specified address to connect to the

Class

run by the

Teacher

on the

specified address computer or show an error message if no

Teacher

is found on the specified address.

¡ Use class server [Setup]: When

Joining class

(starting communicating), the

Student

will retrieve

Class

information from a

NetOp Class Server

and connect accordingly. Click [Setup] to show the

Class server setup

window to set up the

Student

to use a

NetOp Class Server

.

Class Server Setup

Click the

Student

Options

window

Class

tab

Setup

button to show this window:

It enables you to set up the

Student

to use

NetOp School class management

in these elements:

·

Class server []: Specify the Class server ID specified on the used

NetOp Class Server

.

¨ IP address or DNS name (if on another subnet) []: If the used

NetOp Class Server

is on an IP subnet

different from the

Student

computer IP subnet, you must check the box and specify the

NetOp Class Server

259

NetOp Student

computer IP address or DNS name.

þ Rejoin on disconnect from Teacher: Leave checked to make the

Student

Rejoin class

if it becomes

disconnected from a running

Class

. Uncheck to disable.

¨ Show class list: Leave unchecked to offer no

Class

options to the

Student

user. Check to show this window when the

Student

Joins class

or when its

Class

ends:

The pane will always include <Available for any class>. Select and click OK for the

Student

to become

Available for any class

.

If

NetOp School class management

runs in

Non-scheduled mode

, the names of

Courses

to which the

Student

is assigned will be shown in the pane. Select a

Course

name to show only the

Teacher

name in the fields below. Click OK to connect to a selected

Course

running

Class

or wait for it to run and then

connect.

If

NetOp School class management

runs in

Scheduled mode

, if a

Lesson

of a

Course

to which the

Student

is assigned is running, the

Course

name will be shown in the pane. Select a

Course

name to show

Lesson

From time, To time,

Classroom

name and

Teacher

name in the fields below. Click OK to connect to the

Lesson

. If no

Lesson

of a

Course

to which the

Student

is assigned is running, the user can select to show the

Course

names of upcoming

Lessons

in the

Select class

window to select one to wait for it to run and then connect.

Click Cancel to close the

Select class

window for the

Student

to become

Not in class

. If the

Student

cannot

Leave class

by

Protection password

protection, it will become

Available for any class

.

Identify student by

Click one of these options for identifying the

Student

to the

NetOp Class Server

:

¤ Windows login name: By the name by which the

Student

user is logged in to Windows.

¡ Computer name: By the

Student

computer Windows name.

¡ Student login name: By the name specified on the

Student login

tab.

Note: This selection must be compatible with the

NetOp School class management

Student

identification.

260

4.2.6.1.3 Student Login Tab

This is the

Student

Options

window

Student login

tab:

NetOp Student

It enables you to specify the

Student login name

by a name type or name in this section:

Note: Each

Student

in a

Class

must have a unique

Student login name

. A

Student

that attempts to connect

to a

Class

that already contains a

Student

with the same

Student login name

will be rejected.

Student login name

Identify student by []: The drop-down box list contains these options:

· Windows login name: The

Student login name

will be the

Student

user Windows login name.

· Windows login name and \domain: The

Student login name

will be the

Student

user Windows login name and domain name separated by a backslash character (\).

·

Windows full name: The

Student login name

will be the

Student

user Windows full name.

· Windows full name and \domain: The

Student login name

will be the

Student

user Windows full name and

domain name separated by a backslash character (\).

·

Computer name: The

Student login name

will be the

Student

computer Windows name.

· Computer name and \domain: The

Student login name

will be the

Student

computer Windows name and

domain name separated by a backslash character (\).

Note: For

Students

that run on a terminal server, do not select a

Student login name

option based on

Computer name

. All

Students

that run on a terminal server share the same

Computer name

. For

Students

that run on network computers,

Computer name

is a safe choice for the

Student login name

.

·

Prompt for login name: When the

Student

Joins class

, this window will be shown:

261

NetOp Student

Specify the

Student login name

and click OK to apply.

If on the

Options

window

Class

tab

Browse for classes

is selected, this combined window will be shown:

Specify the

Student login name

and select an available

Class

and click OK to connect.

· Login as: Will enable the Enter name field below.

Enter name []: Specify the

Student login name

or an environment variable whose value will be the

Student login name

.

Click an option in the list to show it as selected in the field.

·

This is the name that identifies the student on the teacher: Will show the

Student login name

according to the selected name type. A

Prompt for login name

name cannot be shown.

262

4.2.6.1.4 Protection Tab

This is the

Student

Options

window

Protection

tab:

NetOp Student

It enables you to protect the

Student

against unwanted

Teacher

actions.

Note: Protecting the

Student

applies typically to an adult teaching environment where

Student

users are in

full control of

Student

Options

and do not want to be tightly controlled from the

Teacher

.

Protection

¨ Enable protection: Check to enable the

Prevent teacher from

section below.

Prevent teacher from

¨ Locking PC during attention and demonstrate: Check to disable full screen

Attention

or

Demonstrate

sessions with this

Student

.

¨ Viewing thumbnail: Check to disable showing a miniature image of this

Student

computer's screen in

Thumbnails view

.

¨ Controlling without confirm access: Check to show this window before a

Remote control

or

Monitor

session is started with this

Student

:

263

NetOp Student

Click to Allow or Deny the session.

¨ Using file manager: Check to disable running a

File manager

session with this

Student

.

¨ Distributing files: Check to disable running a

Distribute files

session with this

Student

.

¨ Collecting files: Check to disable running a

Collect files

session with this

Student

.

¨ Running program: Check to disable

Run program

on this

Student

computer.

¨ Executing command: Check to disable executing

Commands

on this

Student

computer.

¨ Assigning microphone: Check to disable assigning the microphone to this

Student

in an

Audio-video chat

session.

¨ Applying policy: Check to disable applying a

Policy

on this

Student

.

¨ Monitoring activity: Check to disable monitoring

Activity

on this

Student

computer.

4.2.6.1.5 Audio-Video Chat Tab

This is the

Student

Options

window

Audio-video chat

tab:

It enables you to specify

Student

Audio-video chat

properties in these elements.

Microphone sensitivity

· Silence level: Drag the slide to set the microphone sound input below which no audio data shall be sent.

· Line hold: Drag the slide to set the time after falling below the Silence level audio data shall continue to be sent.

Note: Optimize by changing slide positions while running an

Audio-video chat

session.

·

Advanced: Click to show the

Advanced audio settings

window.

· Check sound system: Click to check the

Student

computer sound system to show a check result message.

264

Advanced Audio Settings

Click the

Audio-video chat

tab

Advanced

button to show this window:

NetOp Student

It enables you to select the preferred playback and record sound device in these elements:

Playback

· Preferred device []: The drop-down box field will initially show <Use any available device>. If audio

playback devices are connected to the

Student

computer, <Use any available device> may use the computer sound system or a connected device. To use your preferred device, click its name in the drop-down box list to show it in the field.

Record

· Preferred device []: The drop-down box field will initially show <Use any available device>. If audio recording devices are connected to the

Student

computer, <Use any available device> may use the

computer sound system or a connected device. To use your preferred device, click its name in the drop-down box list to show it in the field.

4.2.6.1.6 Help Request Tab

This is the

Student

Options

window

Help request

tab:

It enables you to add a

Help request

button in this element:

265

NetOp Student

¨ Add help request icon to the tray: Check to add this button in the Windows taskbar notification area:

If the

Student

is connected to a

Class

, right-click to show a Request help/Cancel help command. Click it or

double-click the button to request help or cancel a pending help request.

Note: A

NetOp help request

button will not be hidden when the

Student

is running in

Stealth mode

.

4.2.6.1.7 Connection Tab

This is the

Student

Options

window

Connection

tab:

It enables you to specify

Student

Connection

properties in these elements:

Communication profile

· The drop-down box list will contain available

Communication profiles

. Click one to show it in the field as selected.

· New: Click to show the

Communication profile edit

window to create a

Communication profile

.

·

Edit: Click to show the

Communication profile edit

window to edit the selected

Communication profile

.

·

Delete: Click to delete the selected

Communication profile

.

NetOp Name Server

·

Name space ID []: To connect to a

Teacher

using

NetOp name management

, this field must contain the

Name space ID

specified in the matching field on the

Teacher

.

Subnet assistant

If a cluster of

Students

is located on a subnet very remote from the

Teacher

, you can improve

communication by making one of the cluster

Students

a

Subnet assistant

that will route communication

between the

Teacher

and cluster

Students

.

¨ Enable: Check to enable this

Student's

routing capabilities.

266

NetOp Student

·

Address to reach teacher []: Specify the

Teacher

address (IP address or DNS name if communicating by

TCP/IP

).

Note: For

Connection

tab changes to apply, you must

Rejoin class

.

4.2.6.1.8 Web Update Tab

This is the

Student

Options

window

Web update

tab:

It enables you to update the

Student

installation from the web in these elements:

· Update server []: Specify the web address of the server from which to download

Student

update files

(default: update.netop.com, the NetOp web update server on the Internet).

Note: To support the update of many NetOp installations in an organization, we recommend to

Publish new updates

to an internal web update server.

· HTTP proxy [] [Detect]: Specifying a

HTTP proxy

is typically not required. Before specifying a

HTTP proxy

,

click

Update now

to test the web update connection. If this yields a message indicating connection to the update server, specify no

HTTP proxy

. If

Update now

yields no connection, click [Detect] to make NetOp attempt to detect the

HTTP proxy

server to show its name and port number in the

HTTP proxy

field. Click

Update now

to test the connection. If unsuccessful, consult with your network/system administrator about what must be specified in the

HTTP proxy

field (format: <Server name>:<Port number>).

·

Update now: Click to connect to the update server specified in the

Update server

field. A Web update

message will notify you if connection to the update server failed, if no updates are available or if updates are available and in the latter case ask you if you want to download and install updates.

·

Schedule: Click to show the

Web update schedule

window.

267

4.2.6.2 Protection Password

Click the

Student

window

Tools

menu

Protection password

command to show this window:

NetOp Student

It enables you to protect

Student

setup and certain user actions by a

Protection password

in these elements:

Change protection password: Click to show this window:

Specify the

Protection password

in these fields:

·

Old password []: Specify the current

Protection password

(disabled if no

Protection password

is applied).

· New password []: Specify the new

Protection password

(leave empty if no

Protection password

shall be applied).

· Confirm password []: Re-specify the new

Protection password

for confirmation.

Note: When a

Protection password

is applied, the

Tools

menu

Protection password

command will be protected by the

Protection password

.

Protection password required for

¨ Configuration: Check to protect the

Tools

menu

Options

and

Run setup wizard

commands by the

Protection password

.

¨ End session, Leave class, Exit, Unhide: Check to protect the

Student

user actions

End session

,

Leave class

,

Exit

and

Unhide

by the

Protection password

.

Protect security configuration files

Click one of these options:

¤ Protect by protection password only (if applies): Protect

Student

setup only by any applied

Protection password

protection that does not protect

Student

User configuration files

.

¡ Protect files when connected: Protect

Student

User configuration files

and disable

Tools

menu setup commands when the

Student

is connected to a

Class

to prevent a connected

Teacher

from changing

268

NetOp Student

Student

setup.

¡ Protect files when connected and class joined: Protect

Student

User configuration files

and disable

Tools

menu setup commands when the

Student has

Joined class

to prevent a

Student

user that by

Protection password

protection is unable to

Leave class

or

Exit

the

Student

from changing the

Student

setup.

Note: Checking boxes and clicking

Protect files when connected and class joined

will provide maximum

protection against

Student

users that want to disrupt the

Class

environment.

269

5 Common Tools

This section explains tools that are common to

Teacher

and

Student

.

It contains the sections:

·

Communication devices

·

System info

Common Tools

5.1 Communication Devices

NetOp uses the term Communication devices for the NetOp adaptations of general communication protocols and the NetOp proprietary protocols developed for NetOp applications.

NetOp modules use different configurations of

Communication devices

for communicating with other NetOp

modules in different environments. Such

Communication device

configurations that are given individual

names are called Communication profiles.

While a range of default

Communication profiles

are included when a NetOp module is installed for the first

time, a user will typically want or need to create new

Communication profiles

that are optimized for the user

environment.

This section explains

Communication devices

and how NetOp

Communication profiles

are created and

managed.

In the

Teacher

or

Student

Options

window

Connection

tab

Communication profile

section, click New or Edit

to show this window:

It enables you to create or edit a

Communication profile

in these elements:

Communication information

· Description of communication profile []: If shown from New, the field will be empty. If shown from Edit, the

270

Common Tools

field will show the name of the selected

Communication profile

. Specify a

Communication profile

name or edit it, if desired.

· Communication device []: The drop-down box list will contain the names of available

Communication devices

that for NetOp School includes:

·

NetBIOS

·

IPX

·

TCP/IP

·

Terminal server

(available only on NetOp modules that run on a terminal server).

Select a

Communication device

in the list to show it in the field to make this

Communication profile

use the

selected

Communication device .

¨ Use dial-up networking: Will be enabled only if

TCP/IP

is selected in the

Communication device

drop-down

box. Check to enable creating or editing a connection via modem to a network.

The lower window section will be named by the

Communication device

selection and have different contents

with different selections. Click a hotspot in the list above to jump to the section that explains the

Communication device

and its available options in the lower section of the

Communication profile edit

window.

5.1.1 TCP/IP

TCP/IP

(Transmission Control Protocol/Internet Protocol) is a suite of widely used network communication

protocols. NetOp School uses a NetOp adapted version of the TCP/IP suite networking protocol UDP (User

Datagram Protocol) named

TCP/IP .

NetOp School utilizes the ability of UDP to send and receive name identified

Broadcast communication

on a local IP network segment. UDP can also send and receive IP address and DNS name addressed

Unicast communication

across large segmented IP networks including the Internet. This combination of local network segment

Broadcast communication

and remote network segments

Unicast communication

enables running

physical

Classes

on a local network segment as well as virtual

Classes

on a large network or on the Internet.

This section includes these sections:

·

TCP/IP settings

·

TCP/IP communication profile edit

5.1.1.1 TCP/IP Settings

Communication profile

To use

TCP/IP

communication, in the

Options

window

Connection

tab

Communication profile

section select

a

Communication profile

that uses the

TCP/IP

Communication device

(initially TCP/IP for local area network,

Internet for Internet and Wireless for wireless network communication).

Identification

Teachers

identify themselves to

Students

by their running

Class

name.

Students

identify themselves to

Teachers

by their

Student login

name,

Windows login

name and

Computer

name.

Computers identify themselves by one or multiple IP addresses and a DNS name.

NetOp School

TCP/IP

communication identifies

Teachers

and

Students

by their names and IP addresses.

Communication problems

271

Common Tools

If NetOp School modules do not communicate as expected, use these diagnostic tools:

1. Verify that an IP connection is available between computers by using the PING utility explained below.

2. Read the

TCP/IP communication profile edit

section and verify that all required specifications are in place.

3. Read the

NetOp School communication

section.

4. As a last resort, submit a support request by using the Support for NetOp products form on the www.netop.com

homepage.

PING utility

To verify that that an IP connection is available between two computers across a network using TCP/IP, on one computer from a command prompt type:

PING <Other computer IP address>

The PING utility will send four data packets that request a reply. If replies are received, an IP connection is available.

Resources

NetOp modules can use one TCP/IP port for sending and receiving communication.

We generally recommend that you use port number 1971 that is officially registered to NetOp School.

In special situations, you can use other port numbers but remember that the

Teacher

send port number must

always match the

Student

receive port number and vice versa.

5.1.1.2 TCP/IP Communication Profile Edit

The

Communication profile edit

window will have these contents if

TCP/IP

and

Use dial-up networking

are

selected:

The

Communication information

section contents are explained in the

Communication devices

section. This section will explain the other sections.

TCP/IP network connection

272

Common Tools

This section enables you to create or edit dial-up network profiles in these elements:

· Dial-up network profile []: The drop-down box list will contain the names of dial-up network profiles that have been used before. Click one to show it in the field.

· Dialing from and Calling card: Will show the names of these properties for the selected dial-up network profile.

· Configure: Click to show the Windows <Dial-up network profile name> properties window to reconfigure the selected dial-up network profile.

· Dialing properties: Click to display the Windows Phone and modem options window to edit the dialing properties of the selected dial-up network profile.

· Add profile: Click to show the Windows New connection wizard to create a new dial-up network profile.

TCP/IP

This section enables you to specify the

TCP/IP

communication properties of this

Communication profile

in these elements:

· Max packet size (MTU) [] (512 – 5146 bytes): Specifies the maximum data packet size in the shown range.

Note: A high MTU can increase transfer speed and a low MTU can contribute to solving communication problems.

¨ Optimize for Internet communication: Check to optimize MTU, compression and cache memory to communicate across the Internet.

·

Advanced: Click to show the

Advanced TCP/IP configuration

window.

· IP broadcast list: Click to show the

IP broadcast list

window.

273

Common Tools

5.1.1.2.1 Advanced TCP/IP Configuration

In the

TCP/IP communication profile edit

window

TCP/IP

section, click

Advanced

to show this window:

It enables you to specify advanced

TCP/IP

communication properties in these elements:

Specify IP address

þ Use all available IP addresses: Leave checked to use all of the computer's IP addresses for this

Communication profile's

communication. Uncheck to use only one IP address for this

Communication profile's

communication to enable the field below.

· IP address []: Specify the computer IP address that shall be used.

Specify port numbers

þ Use default port numbers: Leave checked to use the official NetOp School port number 1971 for Receive

port and Send port. Uncheck to enable fields for both port numbers.

Note: Except for special situations, we recommend using the official port number. Remember that the

Teacher

Send port number must match the

Student

Receive port number and vice versa.

NetOp Name Server

¨ Use NetOp Name Server: Leave unchecked to connect without using

NetOp name management

. Check to use

NetOp name management

to connect swiftly across large segmented networks including the Internet.

· Primary []: Leave nns1.netop.com to use this primary

NetOp Name Server

on the Internet. If a local

primary

NetOp Name Server

is available, specify its IP address or DNS name.

274

Common Tools

·

Secondary []: Leave nns2.netop.dk to use this secondary

NetOp Name Server

on the Internet. If a local

secondary

NetOp Name Server

is available, specify its IP address or DNS name.

¨ Ignore port information from Name Server: Check to replace the destination module Receive port number

received from

NetOp Name Server

by the port number specified below.

Note: Some types of firewalls replace sent Receive port numbers by invalid port numbers to protect network computers against connection attempts. In that case,

NetOp Name Server

will receive, store and return

invalid Receive port numbers that must be replaced by valid Receive port numbers.

·

Use port []: Specify the port number that shall replace the Receive port number received from

NetOp

Name Server

(typically 1971).

Note: To use

NetOp name management

, in the

Options

window

Connection

tab

NetOp Name Server

section specify the applicable

Name space ID

.

Unicast (only on

Teacher

)

¨ Enable: Check to supplement

Broadcast communication

by

Unicast communication

to each

Class

Student

.

Multicast (only on

Teacher

)

¨ Enable: Check to supplement

Broadcast communication

by multicast communication via multicast routers.

Select one of these options:

¤ Automatic: Let NetOp specify a multicast IP address.

¡ Specify []: Specify a multicast IP address.

5.1.1.2.2 IP Broadcast List

In the

TCP/IP communication profile edit

window

TCP/IP

section, click

IP broadcast list

to show this window:

If

NetOp name management

is not used, for

TCP/IP

Broadcast communication

to reach computers on remote network segments computer IP addresses or DNS names must be in the

IP broadcast list

.

The pane will show specified IP addresses, IP address ranges and DNS names.

· Add: Click to show this window:

275

Common Tools

Specify an IP address, IP address range ( - between addresses) or DNS name and click OK.

Note: Specifying an IP address range will send individual packets to all IP addresses in the specified range. To avoid excess network traffic, do not specify a larger IP address range than required.

· Edit: Select an IP address, IP address range or DNS name in the pane and click to show the

IP broadcast list enter

window to edit it.

· Delete: Select an IP address, IP address range or DNS name in the pane and click to delete it.

¨ Disable local subnet broadcast: Check to disable

Broadcast communication

to local network segment computers.

5.1.2 Terminal Server

Terminal server

is a NetOp proprietary

Communication device

that is available only on NetOp modules

installed on a Windows terminal server.

NetOp School

Teacher

and

Student

installed on a terminal server can run in client sessions. Each client session

Teacher

can communicate with client session

Students

using a

Terminal server

Communication profile

.

A

NetOp Gateway

that runs on the terminal server console can route communication between client session

NetOp School modules and NetOp School modules that run on network computers or other terminal servers.

Note: The particulars of installing, setting up and running NetOp School in terminal server environments are explained in the

NetOp School in terminal server environments

section.

This section includes these sections:

·

Terminal server settings

·

Terminal server communication profile edit

5.1.2.1 Terminal Server Settings

Communication profile

To use

Terminal server

communication, in the

Options

window

Connection

tab

Communication profile

section

select a

Communication profile

that uses the

Terminal server

Communication device

(initially Terminal server

).

Identification

Teachers

identify themselves to

Students

by their running

Class

name.

Students

identify themselves to

Teachers

by their

Student login

name,

Windows login

name and

Computer

name.

Note: All

Teachers

and

Students

on a terminal server share the same

Computer

name.

Terminal server client sessions identify themselves by the

Windows login

name of the user logged in to the terminal server.

NetOp School

Terminal server

communication identifies

Teachers

and

Students

by their names.

Communication problems

276

Common Tools

If NetOp School modules do not communicate as expected, use these diagnostic tools:

1. Read the

NetOp School in terminal server environments

section that explains the particulars of installing,

setting up and running NetOp School on a terminal server.

2. Read the

NetOp School communication

section.

3. As a last resort, submit a support request by using the Support for NetOp products form on the www.netop.com

homepage.

Resources

When NetOp School is properly installed on a terminal server, the required resources are available.

5.1.2.2 Terminal Server Communication Profile Edit

The

Communication profile edit

window will have these contents if

Terminal server

is selected:

The

Communication information

section contents are explained in the

Communication devices

section.

The Terminal server section is empty. No options or settings are available with the

Terminal server

Communication device

.

5.1.3 IPX

IPX

(Internetwork Packet Exchange) is a networking communication protocol developed by Novell.

IPX

is

typically used in network environments with NetWare servers and clients.

NetOp School utilizes the ability of

IPX

to send and receive name identified

Broadcast communication

on a

local network including interconnected Novell networks. This enables running physical

Classes

on a local network as well as virtual

Classes

across interconnected Novell networks.

This section includes these sections:

·

IPX Settings

·

IPX Communication Profile Edit

5.1.3.1 IPX Settings

Communication profile

To use

IPX

communication, in the

Options

window

Connection

tab

Communication profile

section select a

Communication profile

that uses the

IPX

Communication device

(initially IPX).

Identification

Teachers

identify themselves to

Students

by their running

Class

name.

Students

identify themselves to

Teachers

by their

Student login

name,

Windows login

name and

Computer

name.

277

Common Tools

Computers identify themselves by the MAC address of their network card. A MAC address consists of 0x followed by a 12 digit hexadecimal number, e.g. 0x080005AF341A.

NetOp School

IPX

communication identifies

Teachers

and

Students

by their names and computer network

card MAC address.

Communication problems

If NetOp School modules do not communicate as expected, use these diagnostic tools:

1. Read

Finding network numbers

below and the

IPX communication profile edit

section to identify and specify the network numbers of modules located on remote networks.

2. Experiment with the

NetOp.ini

setting explained below.

3. Read the

NetOp School communication

section.

4. As a last resort, submit a support request by using the Support for NetOp products form on the www.netop.com

homepage.

Finding network numbers

To find the network number for a computer with a known name, type this from a command prompt: nlist user=<Name> /a (NetWare 4.x) or userlist /a (NetWare 3.x)

If you are attached to a NetWare server that recognizes the name, it will respond with the network number in the address field.

NetOp.ini setting

This setting can be used in a

NetOp.ini

file

[IPX] section:

Key Value Explanation

Max_Packet_Size= <Number> The number specifies the maximum packet size in bytes. If you encounter communication problems, try reducing the maximum packet size to the minimum 512 bytes.

Resources

NetOp School uses IPX socket 8641 (hex) when communicating between a

Teacher

and a

Student

.

Novell has assigned this socket to NetOp.

278

5.1.3.2 IPX Communication Profile Edit

The

Communication profile edit

window will have these contents if

IPX

is selected:

Common Tools

The

Communication information

section contents are explained in the

Communication devices

section.

IPX

This section enables you to specify the

IPX

communication properties of this

Communication profile

in these

elements:

Novell networks

Select one of the options:

¤ Local network only: Communicate to the local network only.

¡ User defined list of networks: Enables the Network list button. Click it to show the

Novell network numbers

window.

¡ Build list of known networks: Let NetOp browse the network to build a list of known networks to enable communication to these networks.

279

Common Tools

The pane will show 8-digit hexadecimal network numbers of remote networks.

· Add: Click to show this window:

Specify an 8-digit hexadecimal network number or edit it and click OK to apply.

· Edit: Select a network number in the pane and click to show it in the

Novell network number

window to

edit it.

· Delete: Select a network number in the pane and click to delete it.

5.1.4 NetBIOS

NetBIOS

(Network Basic Input/Output System) is a simple networking communication protocol for local area

network communication.

NetOp School utilizes the ability of

NetBIOS

to send and receive name identified

Broadcast communication

on a local network segment. Communication that uses

NetBIOS

in its basic mode (in Windows: Microsoft

NetBEUI) cannot pass network connection elements like routers. Communication that uses

NetBIOS

over

IPX

or

TCP/IP

can pass network connection elements. Communicating modules must use the same

NetBIOS

mode. Different

NetBIOS

modes use different

NetBIOS adapter numbers

.

This section includes these sections:

·

NetBIOS settings

·

NetBIOS communication profile edit

280

Common Tools

5.1.4.1 NetBIOS Settings

Communication profile

To use

NetBIOS

communication, in the

Options

window

Connection

tab

Communication profile

section select

a

Communication profile

that uses the

NetBIOS

Communication device (initially NetBIOS).

Identification

Teachers

identify themselves to

Students

by their running

Class

name.

Students

identify themselves to

Teachers

by their

Student login

name,

Windows login

name and

Computer

name.

Computers identify themselves by the MAC address of their network card. A MAC address consists of 0x followed by a 12 digit hexadecimal number, e.g. 0x080005AF341A.

NetOp School

IPX

communication identifies

Teachers

and

Students

by their names and computer network

card MAC address.

Communication problems

If NetOp School modules do not communicate as expected, use these diagnostic tools:

1. Verify that

Teacher

and

Student

use the same

NetBIOS

mode, see

NetBIOS

and

NetBIOS communication profile edit

.

2. Experiment with the

NetOp.ini

settings explained below.

3. Read the

NetOp School communication

section.

4. As a last resort, submit a support request by using the Support for NetOp products form on the www.netop.com

homepage.

NetOp.ini settings

These settings can be used in a

NetOp.ini

file [NetBIOS] section:

Key Value Explanation

Max_Packet_Size= <Number> The number specifies the maximum packet size in bytes. If you encounter communication problems, try reducing the maximum packet size to the minimum 512 bytes.

Rcv_DG_Threads= 1 or 2 By default, NetOp uses 2 datagram threads. Under certain circumstances, 2 datagram threads cause problems, and 1 can be specified.

Resources

No particular resources are used by the

NetBIOS

communication device.

281

5.1.4.2 NetBIOS Communication Profile Edit

The

Communication profile edit

window will have these contents if

NetBIOS

is selected:

Common Tools

The

Communication information

section contents are explained in the

Communication devices

section.

NetBIOS

This section enables you to specify the

NetBIOS

communication properties of this

Communication profile

in

this element:

· Adapter number [] (0-255) [List]: Click [List] to show this window:

The table will show records of available NetBIOS modes with these column contents:

· Number: Adapter number.

·

Description: Mode description.

· Version: Software version number.

· Type: Software type.

· Max packet size: Maximum packet size in bytes.

· MAC address: Network adapter MAC address.

Note: Table information is retrieved from Windows. Valid mode records will show the computer network card MAC address. The table may contain other records with random MAC addresses. They are invalid and must be disregarded.

Select a record and click OK to enter the adapter number in the Adapter number field.

282

5.2 System Info

In the

About...

window, click the

System info

button to show this window:

Common Tools

It shows various system information in these elements:

·

The upper section shows summary program and system information.

· The middle section shows summary screen information.

· The lower section shows summary driver information.

It has these menus:

·

Click a command to show detailed screen display information in a Screen info window.

·

Click Net addresses to show this window:

283

Common Tools

The pane will show enabled computer network addresses.

Note:

Teacher

network addresses will be enabled when the

Teacher

runs a

Class

.

Student

network

addresses will be enabled when the

Student

has

Joined class

(is communicating).

284

Advanced Tools

6 Advanced Tools

This section explains

Advanced tools

that are of interest mainly to system or network administrators.

It includes these sections:

·

NetOp.ini

·

NetOp configuration files

·

NetOp School communication

·

NetOp School in terminal server environments

·

NetOp name management

·

NetOp School class management

6.1 NetOp.ini

Installing

a NetOp program on a computer for the first time will create a

NetOp.ini

file in the Windows (or

WINNT) folder.

NetOp.ini

will be read when a NetOp program is

Installed

on the computer to determine among other things

the default

Installation

folder and program folder and will automatically be updated with each additional

NetOp program

Installation

.

NetOp.ini

will be read when a NetOp module is loaded. It can contain special setup information that will be applied to the NetOp module.

Typically, you do not need to worry about

NetOp.ini

, but you can edit it to provide desired installation and

loading options.

NetOp.ini

uses the standard Windows .ini file format with sections, keys and values. It is a plain text file that can be opened and edited in a standard text editor:

285

Advanced Tools

NetOp.ini

can contain the sections:

·

[INSTALL]

: Always included. Specifies

Installation

settings.

·

[COEXISTENCE]

: Always included. Specifies settings for running different NetOp modules on a computer

at the same time.

·

[TEACHER]

: Optional. Specifies

Teacher

settings.

·

[STUDENT]

: Optional. Specifies

Student

settings.

·

[IPX]

: Optional. Specifies

IPX

settings.

·

[NetBIOS]

: Optional. Specifies

NetBIOS

settings.

·

[DTL]

: Optional. Specifies communication settings.

Other optional sections can be included in

NetOp.ini

.

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

286

Advanced Tools

6.1.1 [INSTALL] Section

The

NetOp.ini

file always included

[INSTALL]

section will contain keys that specify the folder path and

program folder name of the most recently installed NetOp programs. These NetOp School keys are typically included:

SCHOOL_DIRECTORY=C:\Program Files\Danware Data\

SCHOOL_FOLDER=NetOp School

TEACHER_DIRECTORY=C:\Program Files\Danware Data\NetOp School\Teacher\

STUDENT_DIRECTORY=C:\Program Files\Danware Data\NetOp School\Student\

The values of these keys are the default suggestions when reinstalling NetOp programs.

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

6.1.2 [COEXISTENCE] Section

The

NetOp.ini

file always included

[COEXISTENCE]

section will contain keys that specify if different NetOp

programs can be loaded on the computer at the same time.

It can contain these keys:

COEXIST=<0, 1 or 2>

This key will always be included.

The value 0 will not allow loading a NetOp module if another NetOp module is loaded.

The value 1 will allow loading a NetOp module temporarily suspending a loaded different NetOp module. A

Student

connected to a

Class

cannot be suspended.

The value 2 will allow loading a NetOp module while a different NetOp module is loaded.

LOAD_WARNING=<0 or 1>

This key is optional.

The value 0 will not show a warning message.

The value 1 or no key will show a warning message that enables the user to accept or deny temporarily suspending a loaded module to load another module if COEXIST has the value 1.

DEBUG=<0 or 1>

This key is optional.

The value 0 or no key will hide a window that shows the loader program commands executing.

The value 1 will show a window that shows the loader program commands executing.

Note: If two NetOp modules shall run on a computer at the same time, they must use different

Communication device

settings (with

TCP/IP

different port numbers).

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

6.1.3 [TEACHER] Section

The

NetOp.ini

file optional

[TEACHER]

section can contain keys that modify certain

Teacher

properties.

It can contain these keys:

DATAPATH=<Path>

Teacher

User configuration files

will be stored in the specified <Path> instead of their default location.

LESSONPATH=<Path>

287

Advanced Tools

Teacher

Lesson plan

files will be stored in the specified <Path> instead of their default location.

POLICYPATH=<Path>

Teacher

Policy

files will be stored in the specified <Path> instead of their default location.

RECORDPATH=<Path>

Teacher

Recording

files will be stored in the specified <Path> instead of their default location.

SNAPSHOTPATH=<Path>

Teacher

Print screen to file

files will be stored in the specified <Path> instead of their default location.

TESTPATH=<Path>

Teacher

Test

files will be stored in the specified <Path> instead of their default location.

SURVEYPATH=<Path>

Teacher

Survey

files will be stored in the specified <Path> instead of their default location.

BLOCKPATH=<URL path>

This key will store a

Teacher

Options

window

Sharing

tab

Blocking page

specified URL path.

Note: You can use environment variables in the <Path> parameter.

Max_Students=<Number>

A number between 5 and 200 will specify the maximum number of

Students

in a

Class

. Default is 50.

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

6.1.4 [STUDENT] Section

The

NetOp.ini

file optional

[STUDENT]

section can contain keys that modify certain

Student

properties.

It can contain this key:

DATAPATH=<Path>

Student

User configuration files

will be stored in the specified <Path> instead of their default location.

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

6.1.5 [IPX] Section

The

NetOp.ini

file optional

[IPX]

section can contain keys that modify certain

IPX

properties.

It can contain this key:

Max_Packet_Size=<Number>

A number between 512 and 5000 will specify the maximum data transmission packet size in bytes.

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

6.1.6 [NetBIOS] Section

The

NetOp.ini

file optional

[NetBIOS]

section can contain keys that modify certain

NetBIOS

properties.

It can contain these keys:

Max_Packet_Size=<Number>

A number between 512 and 5000 will specify the maximum data transmission packet size in bytes.

RCV_DG_THREADS=<1 or 2>

288

Advanced Tools

1 or 2 will specify the number of received datagram threads.

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

6.1.7 [DTL] Section

The

NetOp.ini

file optional

[DTL]

section can contain keys that modify certain communication properties.

It can contain these keys:

MinTimeOut=<Number>

MaxTimeOut=<Number>

Each of these keys will replace NetOp’s automatic calculation of minimum or maximum waiting time for receiving an acknowledgement of data packet reception by the specified number of tics (1/18 second).

TimeOutTimes=<Number>

A number between 1 and 50 will add this number of timeout attempts to the default 10.

Use these keys to overcome communication problems in crowded networks where data packets take a long time to get through or get lost.

Note: The

www.netop.com

website Support section

KnowledgeBase

section Documentation section

NetOp.ini settings section explains available

NetOp.ini

settings.

6.2 NetOp Configuration Files

The setup of NetOp modules is stored in configuration files, typically with the extension .ndb.

When a NetOp module is installed on a computer, its setup will be stored in Installed configuration files in the folder where the NetOp module is installed.

When a user loads a NetOp module for the first time after it was installed, Installed configuration files will be

copied to a user folder to serve as

User configuration files

.

Unless the NetOp module is installed in a fully set up state by

deployment , the

Setup wizard

will run for the

user to create a customized setup, the settings of which will be written to the

User configuration files

.

Folders for other NetOp files created by the user will be created in the

User configuration files

folder.

NetOp log files created by the user will be saved in the

User configuration files

folder.

This table provides an overview of NetOp School configuration and other files, their location and contents:

File name

Common files:

comiplst.ndb

Location File contents

IP broadcast list comprof.ndb

<Teacher> and

<Student>

<Teacher> and

<Student>

Communication profiles

Teacher files:

classrms.ndb

locstd.ndb

loctch.ndb

nowconf.ndb

runprog.ndb

stdgrps.ndb

stdinfo.ndb

teachers.ndb

<Teacher>

<Teacher>

<Teacher>

<Teacher>

<Teacher>

<Teacher>

<Teacher>

<Teacher>

Classes

Student file locations

Teacher file locations

Teacher setup

Run program specifications

Student groups

Student information

Teacher profiles

289

Advanced Tools

*.log, *.rlg

*.xml

*.xml

<Teacher>\DeployLog Student deployment logs

<Teacher>\Lessonpl Lesson plans

<Teacher>\Policies Policies

*.dwr

<Teacher>\screcord Recordings

*.ndb, setup.iss

<Teacher>\StudentNDB Student deployment setup files

*.nxt, *.nxs, *.nxr <Teacher>\Tests

Student file:

Tests, surveys, results nhstconf.ndb

<Student> Student setup

The meanings of <Teacher> and <Student> are explained in the

Default location of user configuration files

section.

When a user changes the setup of a NetOp module during use, changes will be written to the

User configuration files

immediately or when the NetOp module is unloaded.

When a user loads a NetOp module, the

User configuration files

will be read to re-establish the setup that

existed when the user last unloaded the NetOp module.

If

User configuration files

are write protected or access to the folders in which they reside is denied, user setup changes cannot be written to files and will not be retained.

The setup of a NetOp School module can be protected by applying a

Protection password

.

Student

User configuration files

can be

protected when the

Student

is connected to a

Class

or has

Joined class

.

If

User configuration files

are deleted, the user setup of deleted

User configuration files

will be lost. When the

module is loaded after deleting

User configuration files

, a new user setup in new

User configuration files

will

be created.

Most configuration files are written in a NetOp proprietary format that cannot be read or edited separately.

6.2.1 Default Location of User Configuration Files

If user profiles are implemented on the computer,

Teacher

User configuration files

will by default be stored in user folder of the user logged in to Windows.

Student

User configuration files

will by default be stored in the

All users (Vista: ProgramData) folder.

User profiles are implemented with Windows Vista, XP, 2000 and NT and can be implemented with Windows

ME, 98 and 95:

· On Windows Vista, user folders are typically C:\Users\<Windows login user name>.

· On Windows XP and 2000, user folders are typically C:\Documents and settings\<Windows login user name>.

· On Windows NT, user folders are typically C:\WINNT\Profiles\<Windows logon user name>.

· On Windows ME, 98 and 95, user folders, if implemented, are typically are C:\Windows\Profiles\<Windows logon user name>.

By default,

User configuration files

will reside in the path <User folder>\Application data\<NetOp module

path>, where <NetOp module path> is the full path to the folder in which the NetOp module is installed. If the

NetOp module is installed in the C:\Program files folder, only the path from that folder is used in <NetOp module path>.

Note: Application data is a hidden folder. To show it and its contents, on the Windows folder options window

View tab select Show hidden files and folders.

If user profiles are implemented, this is the meaning of <Teacher> and <Student> in the

NetOp configuration files

section table.

If user profiles are not implemented using Windows ME, 98 or 95,

User configuration files

will by default

reside in a Config folder in the folder in which the NetOp module is installed.

You can store

User configuration files

in other locations, see

Other locations of user configuration files

.

290

Advanced Tools

6.2.2 Other Locations of User Configuration Files

You can store NetOp

User configuration files

and other user created files in other user individual or general locations by specifying some or all of these keys in the NetOp.ini file:

[TEACHER]

DATAPATH=<Path>

LESSONPATH=<Path>

POLICYPATH=<Path>

RECORDPATH=<Path>

SNAPSHOTPATH=<Path>

TESTPATH=<Path>

SURVEYPATH=<Path> and/or

[STUDENT]

DATAPATH=<Path>

- where <Path> is the full path to the folder in which

User configuration files

or other user created files shall be stored.

In this case, this is the meaning of <Teacher> and <Student> in the

NetOp configuration files

section table.

6.3 NetOp School Communication

NetOp School uses two different types of communication between

Teachers

and

Students

, namely

Broadcast communication

and

Unicast communication

.

Broadcast communication

Broadcast communication

will communicate to all reachable recipients.

Broadcast communication will reach local network computers but will typically not pass routers and other network connection elements to reach remote network computers.

Using

TCP/IP

, local

Broadcast communication

can be extended by sending the same communication by

Unicast communication

to individual IP addresses and/or DNS names of computers beyond the local network specified in an

IP broadcast list

or received by using

NetOp Name Server

.

Unicast communication

Unicast communication

will communicate to a specific recipient.

Initial

Unicast communication

must contain destination computer or terminal server client session

identification.

TCP/IP

identifies computers by their IP address or DNS name.

Terminal server

identifies client

sessions by their Windows login user name.

IPX

and

NetBIOS

identify computers by their MAC address.

Responses to

Broadcast communication

and

Unicast communication

will be sent by

Unicast communication

that can pass the network connection elements passed by the communication responded to.

NetOp

Unicast communication

will (unless being extended

Broadcast communication

) request a communication receipt acknowledgement returned to the sender.

NetOp School uses

Broadcast communication

for these actions:

Announcement

An

Announcement

is

Broadcast communication

that does not request a response.

When a

Teacher

loads with a

Class

name,

Reannounces class

,

Changes class

or

Unloads

, it will send an

Announcement

.

·

A

Student

that is

Waiting for

the announced

Class

will return

Unicast communication

to connect to the

291

Advanced Tools

Class .

·

A

Student

that is

Available

will in response to a

Class

Announcement

return

Unicast communication

stating its

Status

, which will add the

Student

in the

Teacher

Available students

pane. If the responding

Student

is a member of the

Class

, the

Teacher

will by

Unicast communication

request the

Student

to

connect, which the

Student

will do by

Unicast communication

.

·

A

Student

that while connected receives an

Announcement

that the

Teacher

Changes class

or

Unloads

will disconnect.

When a

Student

Joins class

with the

Options

window

Class

tab

Be available for any class

option selected,

or with this option selected becomes

Available

, it will send an

Announcement

.

·

On

Teachers

that run a

Class

, the

Announcement

will add the

Student

in the

Available students

pane.

·

A

Teacher

that runs a

Class

in which the

Announcement

Student

is a member will by

Unicast communication

request the

Student

to connect, which the

Student

will do by

Unicast communication

.

When a

Student

from being

Available

Leaves class

or connects to a

Class

to no longer be

Available

, it will

send an

Announcement

.

·

On

Teachers

that run a

Class

, the

Announcement

will remove the

Student

in the

Available students

pane.

Browse

A

Browse

is

Broadcast communication

that requests a response from specified recipients.

When a

Student

Joins class

with the

Options

window

Class

tab

Browse for classes

option selected, it will send

Broadcast communication

that requests a response from

Teachers

that run a

Class

.

Teachers

that

run a

Class

will respond by

Unicast communication

to enable the

Student

to build a list of available

Classes

. If the

Student

user selects a

Class

in the list and clicks OK, the

Student

will connect by

Unicast communication

.

When a

Student

Joins class

with the

Options

window

Class

tab Connect to class: <Class name> option

selected, it will send

Broadcast communication

that requests a response from the

Teacher

that runs <

Class

name>. If the

Student

receives a response, it will connect by

Unicast communication

. If the

Student

does not receive a response, it will become

Waiting for <Class name>

to respond to a

Teacher

Announcement

of <

Class

name>.

Most other NetOp School communication including in-

Class

communication will be by

Unicast communication

.

6.4 NetOp School in Terminal Server Environments

You can install NetOp School on a Windows terminal server to run

Classes

between

Teachers

and

Students

in client sessions in a terminal server environment (TSE).

A

NetOp Gateway

that runs on the terminal server console can route communication between client session

NetOp School modules and NetOp School modules that run on network computers or other terminal servers to run

Classes

in a mixed terminal server and network environment.

This section will explain the particulars of NetOp School in a TSE in these sections:

·

Installation (TSE)

·

Teacher and student setup (TSE)

·

NetOp Gateway setup (TSE)

·

NetOp School functionality (TSE)

6.4.1 Installation (TSE)

On a terminal server, you cannot install by running the product .msi file.

Click Start > Control panel > Add or remove programs to install from the Add new programs button.

292

Advanced Tools

Always install

Teacher

and

Student

.

To enable communicating with

Teachers

and

Students

outside the terminal server, also install

NetOp

Gateway

.

6.4.2 Teacher and Student Setup (TSE)

Teacher setup

When a specific user in a terminal server client session loads the

Teacher

for the first time after

Installation

,

the

Teacher

Setup wizard

will run for the user to create an initial personal

Teacher

setup.

In the

Class management

window, click

Windows login name

to initially use this name option for the

Student display name

because all

Students

in a TSE share the same

Computer name

.

In the

Communication profile

window, select Terminal server to enable communicating in the TSE.

The

Teacher

User configuration files

and user created files will be stored in the user's user profile folder on

the terminal server to apply when loading the

Teacher

from the user's terminal server client session.

Student setup

When any user in a terminal server client session loads the

Student

for the first time after

Installation

, the

Student

Setup wizard

will run for the user to create an initial general

Student

setup.

In the

Classroom

window, click the preferred

Class

connect option and in the

Identify student by

drop-down box select an option that is not based on the computer name because all

Students

in a TSE share the same

computer name.

In the

Communication profile

window, select Terminal server to enable communicating in the TSE.

The

Student

User configuration files

will be stored in the All users folder on the terminal server to apply when

any user loads the

Student

from a terminal server client session.

Protected student setup

To apply a uniform protected

Student

setup that will prevent

Student

users from changing the

Student

setup

to disrupt the

Class

environment, an administrator should set up the

Student

with maximum

Protection password

protection before other users are allowed to load the

Student .

Individual student setup

In an adult teaching environment, you may prefer to apply an individual

Student

setup for each user.

To store

Student

User configuration files

in each user's user profile folder on the terminal server, assuming that the

Student

is installed in its default folder add this key in the terminal server

NetOp.ini

file

[STUDENT]

section:

DATAPATH=%USERPROFILE%\Application Data\Danware Data\NetOp School\Student\

6.4.3 NetOp Gateway Setup (TSE)

To enable communication between inside TSE

Teachers

and

Students

and outside TSE

Teachers

and

Students

, a correctly set up

NetOp Gateway

must be running on the terminal server console.

NetOp Gateway

is an extended NetOp Remote Control Host with the capability to route communication

between different

Communication devices

.

With

NetOp School in TSE

, the task is to route between inside TSE communication that uses the

Terminal server

Communication device

and outside TSE communication that uses typically the

TCP/IP

Communication device .

NetOp Gateway

setup in general is explained in the NetOp Remote Control documentation that will be

available with

NetOp Gateway

. Pay special attention to this:

· Set up

NetOp Gateway

from the terminal server keyboard, mouse and screen (the terminal server

console).

· Be sure to observe the NetOp net number rules, particularly if multiple terminal servers are connected to

293

Advanced Tools

the same network.

· When installed,

NetOp Gateway

will in the

Advanced TCP/IP configuration

window typically specify the

NetOp Remote Control default port number 6502. Be sure to change it into your NetOp School port number, typically 1971.

·

If

Teachers

and

Students

running on one terminal server shall communicate with

Teachers

and

Students

running on another terminal server connected to the same network, add these keys to the

NetOp.ini

file

[DTL]

section on both terminal servers:

GWRestrictedBroadcast=0

GWAllowFullBroadcast=1

Explanation: Routing communication through two

NetOp Gateways

across a network is generally disabled

because it can in some setups cause an uncontrolled propagation of network traffic (broadcast storm).

These keys will safely enable communication through two TSE

NetOp Gateways

across a network.

6.4.4 NetOp School Functionality (TSE)

NetOp School has in most respects the same functionality in a TSE as in a network environment. However,

some

Teacher

Commands

actions work differently:

·

Log off

,

Restart

and

Shut down

will log off the

Student

user from the terminal server client session.

Caution: The same commands executed on a

Student

that runs on the terminal server console will execute

like in a network environment affecting the entire terminal server.

6.5 NetOp Name Management

To connect swiftly between network computer

Teachers

and

Students

across large segmented networks

including the Internet without the need to specify destination addresses in an

IP broadcast list

, use

NetOp name management

.

NetOp name management

runs using

NetOp Name Server

that is an extended NetOp Remote Control Host with the capability to resolve the names of NetOp modules that communicate using the

TCP/IP

Communication device

into their IP address.

To use

NetOp name management

, in the selected

TCP/IP

Communication profile

Advanced TCP/IP configuration

window

NetOp Name Server

section check the

Use NetOp Name Server

box and specify in the

Primary

and

Secondary

fields the DNS name or IP address of the

NetOp Name Servers

you will use. In the

Teacher

or

Student

Options

window

Connection

tab

NetOp Name Server

section

Name space ID

field,

specify the up to 32 characters word that identifies your private name space. All

Teachers

and

Students

that

shall connect by

NetOp name management

must specify the same

NetOp Name Servers

and

Name space

ID

.

When you connect by a

Class

or

Student

name,

NetOp Name Server

will resolve it into its matching IP address by which you will connect.

Two

NetOp Name Servers

with the DNS names nns1.netop.com and nns2.netop.dk run permanently on the

Internet for public use. Your private

Name space ID

will ensure full privacy.

NetOp Name Server

is also available for private installation.

When a NetOp module that uses

NetOp name management

starts communicating (

Teacher

loads running a

Class

,

Student

Joins class

), it will send its names and IP address to

NetOp Name Server

to enable resolving names into the matching IP address. To ensure that the stored information is always up to date,

NetOp

Name Server

will request renewal of the information every few minutes and delete information that is not

renewed.

For further details on

NetOp name management

, see the www.netop.com

website Support section

KnowledgeBase section Documentation section Manuals section.

NetOp name management

documentation

is included in the NetOp Remote Control Administrator's manual.

294

Advanced Tools

6.6 NetOp School Class Management

NetOp School class management

provides centralized control of a teaching organization's NetOp School

Classes

.

It consists of these elements:

·

NetOp Class Server

: A NetOp Remote Control Host with the added capability of providing

Class

information from a central

Class database

to

Teachers

and

Students

.

·

Class database

: A database server residing

Class

information database.

·

NetOp Class Manager

: A database client application by which you can create and manage the

Class database

.

Teachers

and

Students

interact with

NetOp School class management

as illustrated in this diagram:

1a./1b. Request class information: When

Teachers

load and

Students

Join class

and after they end a

Class

, they will request

Class

information from

NetOp Class Server

.

Teacher

users can request

Class

information at any time.

2. Query class database:

NetOp Class Server

will query the

Class database

for requesting

Teacher

and

Student

Class

information.

3a./3b. Return class information:

NetOp Class Server

will return this

Class

information to requesting

Teachers

and

Students

.

4. Connect:

Teacher

users can select an available

Class

to run it.

Students

can be set up to:

· connect to or wait for a running

Class

to which they are assigned, or

·

enable the user to select a running, upcoming or generally available

Class

to connect to or wait for it or

295

Advanced Tools

select to be

Available for any class

.

NetOp School class management

can in a specified

Term

run in one of two modes:

·

Non-scheduled mode

:

Teachers

and

Students

will be assigned to

Courses .

NetOp School class management

will not schedule

Course

Classes

.

Teachers

can run

Classes

of

Courses

to which they are

assigned, typically according to a schedule specified outside

NetOp School class management

.

Students

will or can connect to

Classes

of

Courses

to which they are assigned.

·

Scheduled mode

:

Teachers

and

Students

will be assigned to

Courses

.

NetOp School class management

will schedule

Course Lessons

in

Classrooms

, typically on a weekly basis.

Teachers

and

Students

will or

can connect in

Classes

according to this schedule.

NetOp School class management

including

NetOp Class Server

and

NetOp Class Manager

is available for

installation on a teaching organization's network.

For further details on

NetOp School class management

, see the

www.netop.com

website Support section

KnowledgeBase section Download products section NetOp School section. Click the current NetOp School version in your preferred language to show available download options. Under NetOp School Class Server,

click Manual (PDF) to download the current

NetOp School class management

user's manual.

296

Index

[

[COEXISTENCE] Section 287

[DTL] Section 289

[INSTALL] Section 287

[IPX] Section 288

[NetBIOS] Section 288

[STUDENT] Section 288

[TEACHER] Section 287

A

About Menu 234

About NetOp School Student window 247

About NetOp School Teacher window 37

Action Menu 33, 245

Active Applications and Sites Pane 178

Activity View 175

Activity View Pane 176

Add command 139

Advanced Audio Settings 211, 265

Advanced button 210, 264, 273

Advanced TCP/IP Configuration 274

Advanced Tools 285

All students element 181

Announcement 291

Application history window 177

Application Tab 217

Apply attention on this group command 130

Apply attention on this student command 128

Ask class server command 126

Assistant teacher 80

Attention 56

Attention Bitmap 205

Attention bitmap section 205

Attention Tab 204

Attention Text 206

Attention Text File 207

Attention text file section 207

Attention text section 206

Attention Web Page 208

Attention web page section 208

Attention_command 33

Audio-Video Chat 72

Audio-Video Chat Tab 210, 264

Audio-video chat with this group command 130

Audio-video chat with this student command 128

Authentication section 193

Autostart test check box 156

Available status 249

B

Be available for any class option 258

Blocking page element 222

BLOCKPATH key 288

Bold button 78

Bold command 77

Index

297

Broadcast communication 291

Browse 292

Browse for classes option 257

C

Cancel help button 248

Cancel help command 245, 266

Capture key drop-down box 224

Capture Tab 224

Change Lesson Plan 139

Change lesson plan down pointer button 138

Change or Remove 18

Character command 77

Chat 73

Chat with this group command 130

Chat with this student command 128

Choose question type window 152

Class Control Panel 121

Class database 295

Class list window 126

Class management window 29

Class name drop-down box 189

Class Server Setup 191, 259

Class Setup View 180

Class Tab 189, 250, 257

Classroom 296

Classroom View 131

Classroom window 240

Clear All button 44

Clear help request command 129

Clone Files button 116

Clone files command 100

Close command 101

Collect Files 91

Collect files from students window 96

Collection wizard 91

Commands 84

Commands command 34

Common Tools 270

Communicate 71

Communication device drop-down box 271

Communication Devices 270

Communication information section 270

Communication profile 270

Communication profile edit window 270

Communication profile section 199

Communication profile window 30, 241

Compression Tab 67

Computer name column 125

Computer name option 29, 261

Computer name select button 189

Confirm password field 195

Confirmation Tab 111

Connect to class option 257

Connection password section 189, 257

Connection Tab 198, 266

Contents command 36

Continue button 214

Control 57

298

Control command 33

Control menu 57

Control session section 256

Control Tab 209

Copy button 78

Copy command 77

Copy Files button 115

Copy files command 99

Copy/Move/Synchronize/Clone 102

Course 296

Create group command 131

Current applications tab 176

Current websites tab 178

Custom setup window 14

Cut button 78

Cut command 77

D

Default button action drop-down box 55

Default control button section 209

Default Location of User Configuration Files 290

Default settings button 203

Delete button 116

Delete command 101, 131

Delete Marker 49

Demo command 82

Demo in bitmap mode check box 203

Demo this student command 128

Demo to this group command 130

Demonstrate 39

Demonstrate command 33

Demonstrate Tab 203

Demonstrate window 55

Deny command 176, 179

Deploy 24

Deployment Wizard 20

Description column 138

Desktop Tab 68

Details button 116

Details command 108

Details View 123

Display custom columns in details view section 189

Display Tab 65

Distribute Files 85

Distribute files to students window 89

Distribution wizard 85

Draw Arrow button 44

Draw Ellipse button 44

Draw Freehand button 44

Draw Lines button 44

Draw Rectangle button 44

Drop-down list option 152

Drop-Down List Question 158

E

Edit button 214

Edit Menu 76, 106

Edit Policy 216

Edit_command 139

Index

299

Enable desktop toolbar check box 200

End session button 62

Entire Desktop 40

Essay option 153

Essay Question 161

Execute command on this group command 130

Execute command on this student command 129

Exit command 33, 245

F

Figure Marker Menu 46

Figure Marker Tool Menu 46

Figure Markers 45

File collection window 97

File distribution window 90

File Manager 98

File manager command 34

File Menu 33, 76, 99, 228, 244

File transfer with this student command 129

Files 84

Files command 34

Find button 78

Find command 77

Finding network numbers section 278

Format Menu 77

G

General Tab 188, 249, 256

Get available students check box 188

Group domain drop-down box 197

Group name drop-down box 197

H

Help button 45

Help Menu 36, 115, 246

Help Request 223

Help Request Tab 265

Help request window 245

Hide command 176, 179

History Tab 105

HTTP proxy field 200, 267

I

Identify student by drop-down box 240

Image of Tab 225

Information column 125

Installation 10

Installation [TSE] 292

Interactive Installation 10

Internet Tab 219

Introduction 9

Invite button 184

IP Broadcast List 275

IP broadcast list button 273

IP broadcast list enter window 276

IPX 277

IPX Communication Profile Edit 279

IPX Settings 277

300

Italic button 78

Italic command 77

J

Join class at program startup check box 256

Join class button 248

Join class command 245

Joining status 249

K

Keyboard/Mouse Tab 66

L

Label image option 153

Label Image Question 162

Large Icons button 116

Large icons command 107

Launch toolbox check box 203

Layout Tab 114

Leave class button 248

Leave class command 245

Leaving status 249

Lesson 296

Lesson action menu 138

Lesson Plan View 138

Lesson plan window 140

Lesson plans element 221 license.dat file 12

List button 116

List command 107

Load and Unload Student 236

Load and Unload Teacher 26

Load student at Windows startup check box 256

Loading Alternatives 26, 237

Loading status 249

Local button 116

Local command 108

Local playback command 144

Location window 89

Lock keyboard and mouse button 62

Log off command 34, 84

Lower Toolbar 45

M

Magnifier Menu 48

Manage lesson plans window 140

Marker Properties and Help 49

Match image option 153

Match Image Question 163

Match text option 153

Match Text Question 164

Media File 50

Media File on the Web 53

Menu Bar 32, 75, 99, 227, 244

Menu/Toolbar Tab 199

Message Pane 79

Messages Tab 251

Minimize student at program startup check box 256

Index

301

Monitor 69

Monitor students command 57

Monitor this group command 130

Monitor this student command 128

Monitor Toolbox 70

Move Files button 116

Move files command 100

Multiple choice option 153

Multiple Choice Question 165

N

Name automatically check box 226

Name column 144, 253

Name field 193

Name space ID field 199, 266

NetBIOS 280

NetBIOS adapter numbers window 282

NetBIOS Communication Profile Edit 282

NetBIOS Settings 281

NetOp Class Manager 295

NetOp Class Server 295

NetOp Configuration Files 289

NetOp File Manager-Advanced (Delete) window 112

NetOp File Manager-Advanced (Overwrite) window 113

NetOp File Manager-Delete window 111

NetOp File Manager-Overwrite window 112

NetOp Gateway Setup [TSE] 293

NetOp help request button 266

NetOp Magnifier 48

NetOp Magnifier window 48

NetOp Marker Utility 42

NetOp marker utility button 62

NetOp Marker Utility Button Menu 44

NetOp Marker Utility Title Bar Menu 43

NetOp Marker Utility window 42

NetOp message window 251

NetOp Name Management 294

NetOp Name Server 294

NetOp Name Server section 199, 274

NetOp School Class Management 295

NetOp School Communication 291

NetOp School Functionality [TSE] 294

NetOp School in Terminal Server Environments 292

NetOp Screen Image 223

NetOp Screen Video 227

NetOp Student 236

NetOp Student button 236

NetOp Teacher 26

NetOp Teacher Profiles 194

NetOp Test Monitor window 171

NetOp test window 155

NetOp.ini 285

New button 78

New class window 190

New command 76

New Folder button 116

New folder command 100

New folder window 127, 143, 147, 252

New item window 220

302

New password field 195

New policy window 214

New survey command 149

New survey window 169

New test command 149

New test window 150

Non-scheduled mode 296

Not in class status 249

Novell network number window 280

Novell network numbers window 280

O

On receiving students section 203

On teacher during student demo section 203

Open button 78

Open command 76

Options 55, 186, 254

Options as icons command 34, 246

Options as tabs command 187, 255

Options button 116

Options command 34, 39, 108, 246

Options Menu 108, 229

Options section 188

Options window 156

Ordering option 153

Ordering Question 166

Other Locations of User Configuration Files 291

P

Pane 63

Pass the Chalk 49

Pass the chalk button 41

Paste button 78

Paste command 77

Pause button 235

Pause command 228

Play Media File 52

Playback recording command 253

Policies element 221

Policy 119

Policy command 34

Policy section 191

Policy Tab 214

Preferences Tab 226

Prepare Media File 51

Prevent teacher from section 263

Primary field 274

Print button 78

Print command 76

Print screen to file button 62

Program path drop-down box 83

Progress Tab 104

Prompt for login name option 261

Properties button 116

Properties command 101

Protect files when connected and class joined option 269

Protection Password 268

Protection password command 246

Protection password section 222

Index

303

Protection Tab 222, 263

Public tests command 148

Publish new updates command 35

Q

Question and answer option 153

Question and Answer Question 167

Question editor window 153

Question passed percentage 154

Question record 153

Question resources window 159

Question weight percentage 154

Questions window 152

Quick distribution section 90

R

Ready to install window 16

Reannounce class command 34

Record 119

Record button 62, 235

Record command 228

Record Panel 117

Record/Pause key 234

Recording 53

Recording Playback 145

Recording toolbox 119

Recordings element 221

Recordings Tab 252

Recordings View 142

Recordings View Pane 143

Refresh Rate window 49

Region Menu 228

Rejoin class button 248

Rejoin class command 245

Remote Control 58

Remote control command 57

Remote control this student command 128

Remote Control Window 59

Request help button 248

Request help command 236, 245

Request the chalk button 41

Resource window 160

Restart command 84

Restart student computer button 62

Results tab 148

RTF data 77

Run 81

Run a survey on this group command 130

Run a survey on this student command 129

Run a test on this group command 130

Run a test on this student command 129

Run Program 82

Run Program Browse 83

Run program command 34

Run setup wizard command 35, 246

Run student deployment command 35

Run Survey 82

Run Tab 212

Run Test 82

304

Run test command 34

Run window 213

S

Save As Tab 225

Save button 78

Save command 76

Save new students between classes check box 188

Schedule button 200, 267

Scheduled mode 296

Scoring extension 154

Screen Control Toolbox 40

Search Menu 77

Secondary field 275

Select By button 116

Select by command 107

Select class window 192, 260

Select Color button 45

Select Font button 45

Select Pen Thickness button 45

Select Student installation source window 21

Selected Desktop Area 50

Selected View Menu 36

Send keystrokes command 60

Send Message 75

Send message button 78

Send message command 76

Send message to this group command 130

Send message to this student command 128

Session History Tab 106

Session Properties 64

Setup button 190, 259

Setup Wizard 27, 238

Sharing Tab 221

Show attention section 204

Show Free Text button 44

Show Magnifier button 44

Shut down command 84

Small Icons button 116

Small icons command 107

Snapshots element 221

Sound transfer button 40

Source window 86

Specific Monitor 53

Start activity control button 179

Start NetOp Pack'n Deploy window 22

Start/stop NetOp marker utility button 41

Startup policy drop-down box 191

Startup section 256

Status Bar 45, 63, 79, 185, 254

Status column 124

Status section 249

Stealth mode check box 256

Stop activity control button 178

Stop button 235

Stop command 228

Stop key 234

Stop workgroup session command 128

Student Context Menu 128

Index

305

Student Demo Toolbox 41

Student Deployment 19

Student Desktop 54

Student display name section 188

Student Group Context Menu 129

Student groups element 180

Student information window 182

Student login name section 261

Student login name select button 189

Student Login Tab 261

Student Tools 254

Student Window 243

Style window 155

Subject column 251

Subnet assistant section 266

Survey window 169

Surveys public folder element 222

Surveys tab 148

Sync files command 100

Synchronize 110

Synchronize Files button 116

System Info 283

System info button 37

T

Tab Panel 248

TCP/IP 271

TCP/IP Communication Profile Edit 272

TCP/IP section 273

TCP/IP Settings 271

Teacher and Student Setup (TSE) 293

Teacher name section 193

Teacher profile window 194

Teacher profiles section 194, 196

Teacher Tools 186

Teacher Window 32

Teachers Tab 193

Term 296

Terminal Server 276

Terminal Server Communication Profile Edit 277

Terminal Server Settings 276

Test description 150

Test designer window 157

Test passed percentage 154

Test report window 172

Test wizard welcome window 151

Tests 150

Tests public folder element 221

Tests tab 148

Tests View 146

Tests View Pane 147

Text completion option 153

Text Completion Question 168

Text Marker 46

Text Marker Menu 47

Text Marker window 47

Thumbnails View 134

Thumbnails View Pane 135

Time limit window 159

306

Title Bar 32, 42, 59, 75, 99, 227, 244

Title field 193

Toolbar 37, 78, 115, 235, 247

Toolbar command 245

Toolbar or Toolbox 61

Tools Menu 34, 246

Transfer only if file exists 110

Transfer only one way 110

Transfer sound button 62, 70

Transfer sound command 61

Transfer Status 103

Transfer Tab 110

U

Unconnected icon 124

Underline button 78

Underline command 77

Undo button 44, 78

Undo command 77

Unhide 256

Unicast communication 291

Unload student 236

Update now button 200, 267

Update server field 200, 267

Upper Toolbar 44

Use class server check box 190

Use dial-up networking check box 271

Use NetOp Name Server check box 274

Use teacher profiles check box 193

User configuration files 289

User domain drop-down box 197

User name drop-down box 197

User name field 195

V

Validate using Windows security management check box 193

Video options window 230

View command 149

View Menu 107, 245

W

Waiting for class status 249

Wake on LAN command 183

Web Update Schedule 201

Web Update Tab 200, 267

Windows firewall configuration window 16

Windows login name column 125

Windows login name option 261

Windows login name select button 189

Windows login name selection 29

Windows Teacher Profiles 196

Workgroup 79

Workgroup command 33

Workgroup session for this group command 130

Index

307

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
