User Manual

RSB-4210 Evaluation

Kit

Freescale i.MX53 Processor -

ARM® Cortex™ A8 Architecture

Copyright

The documentation and the software included with this product are copyrighted 2012 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use.

Acknowledgements

ARM is trademarks of ARM Corporation.

Freescale is trademarks of Freescale Corporation.

Microsoft Windows are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation. Advantech assumes no liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For outof-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1.

Collect all the information about the problem encountered. (For example, CPU speed, Advantech products used, other hardware and software used, etc.) Note anything abnormal and list any onscreen messages you get when the problem occurs.

2.

Call your dealer and describe the problem. Please have your manual, product, and any helpful information readily available.

3.

If your product is diagnosed as defective, obtain an RMA (return merchandize authorization) number from your dealer. This allows us to process your return more quickly.

4.

Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service.

5.

Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer.

RSB-4210 User Manual

Part No. 2062421011

Printed in Taiwan ii

Edition 1

September 2012

Packing List

Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately.

RSB-4210 (P/N: RSB-4210CF-A78AAE)

7" LED PANEL 320N 4WR T/S 800X480(G), 97G070V1N0F-2, P/N: 96LEDK-

A070WV32RB1)

LCD Backlight Cable (P/N: 1700019577)

LVDS Cable (P/N: 1700014418)

Touch Cable (P/N: 1700000194)

SQFlash SD Card SLC 2G, 2CH(-40 ~ 85° C) (P/N: SQF-ISDS2-2G-ETE)

A CABLE SATA 15P/1*4P-2.5 35cm for AIMB-213 (P/N: 1700018785)

M Cable SATA 7P/SATA 7P 8CM C=R 180/180 (P/N:1700004711)

Mini USB Host Cable (P/N: 1700019076)

Mini USB Client Cable (P/N: 1700019077)

USB Type-A Cable (P/N: 1700019129)

ADAPTER 100-240 V 65 W 19 V 3.42 A 9NA0651256 (P/N: 1757003734)

A Cable 2*8P-2.0/SPEAKER*2+DC JACK*3 40CM(P/N: 1700019546-11)

F Cable IDE#2 10P-2.0/D-SUB 9P(M) 25CM (P/N: 1700100250)

Terminal connector 9P Female (P/N: 1654909900)

DVD-ROM for RSB-4210 Evaluation Kit (P/N: 2062421011)

RS-232 and RS-485 cable (P/N: 1700019474)

RS-422 cable (P/N: 1700019476)

Power Cord (Optional)

3 pin Power Cord for USA standard (P/N: 1700001524)

3 pin Power Cord for Europe standard (P/N: 170203183C)

3 pin Power Cord for UK standard (P/N: 170203180A)

Charger Board & Battery (Optional)

A cable 1*6P-2.5/1*6P-2.5 140 mm (P/N: 1700018394)

A cable 2*4P-2.0/2*4P-2.0 90 mm (P/N: 1700018395)

PCM-739 Battery charger Board (P/N: 969K073900E)

Battery 11.1 V 6300 mAh 3S3P (P/N: 1760001300) iii RSB-4210 User Manual

Safety Instructions

1.

Read these safety instructions carefully.

2.

Keep this User Manual for later reference.

3.

Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning.

4.

For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.

5.

Keep this equipment away from humidity.

6.

Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause damage.

7.

The openings on the enclosure are for air convection. Protect the equipment from overheating. DO NOT COVER THE OPENINGS.

8.

Make sure the voltage of the power source is correct before connecting the equipment to the power outlet.

9.

Position the power cord so that people cannot step on it. Do not place anything over the power cord.

10.

All cautions and warnings on the equipment should be noted.

11.

If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

12.

Never pour any liquid into an opening. This may cause fire or electrical shock.

13.

Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.

14.

If one of the following situations arises, get the equipment checked by service personnel:

The power cord or plug is damaged.

Liquid has penetrated into the equipment.

The equipment has been exposed to moisture.

The equipment does not work well, or you cannot get it to work according to the user's manual.

The equipment has been dropped and damaged.

The equipment has obvious signs of breakage.

RSB-4210 User Manual iv

Contents

Chapter 1

Overview

...............................................1

1.1

1.2

1.3

1.4

Introduction ............................................................................................... 2

Features .................................................................................................... 2

Hardware Specifications ........................................................................... 3

Board Block Diagram ................................................................................ 4

Figure 1.1 RSB-4210 Board Block Diagram ................................ 4

Chapter 2

H/W Installation

....................................5

2.1

2.2

Development Kit H/W Installation.............................................................. 6

Figure 2.1 RSB-4210 Development Kit Assembly ....................... 7

2.1.1

RSB-4210 (Part-A)........................................................................ 8

2.1.2

7" LVDS LCD Module (Part-B1).................................................... 8

2.1.3

LCD Backlight Cable (Part-B2) ..................................................... 8

2.1.4

LVDS Cable (Part-B3)................................................................... 8

2.1.5

Touch Cable (Part-B4) .................................................................. 8

2.1.6

SQFlash SD Card (Part-C) ........................................................... 8

2.1.7

SATA Power Cable (Part-D) ......................................................... 8

2.1.8

SATA Cable (Part-E)..................................................................... 8

2.1.9

Mini USB Host Cable (Part-F)....................................................... 8

2.1.10 Mini USB Client Cable (Part-G) .................................................... 8

2.1.11 USB Type-A Cable (Part-H).......................................................... 9

2.1.12 Jumper (Part-I).............................................................................. 9

2.1.13 Null modem cable (Part-J) ............................................................ 9

2.1.14 19 V Power Adapter (Part-K) ........................................................ 9

2.1.15 Power Cord (Part-L)...................................................................... 9

2.1.16 Speaker & Audio Cables (Part-M)................................................. 9

2.1.17 Power Cable for Charger Board (Part-N1).................................... 9

2.1.18 Signal Cable for Charger Board (Part-N2) .................................... 9

2.1.19 Charger Board (Part-N3)............................................................... 9

2.1.20 Battery (Part-N4)........................................................................... 9

2.1.21 Keypad Cable (Part-O1) ............................................................... 9

2.1.22 Keypad (Part-O2).......................................................................... 9

2.1.23 Cable for Suspend/Reset Button (Part-P)................................... 10

2.1.24 COM Port Cable (D-SUB 9P to Housing) (Part-Q) ..................... 10

2.1.25 RS-232 Loopback (Part-R) ......................................................... 10

2.1.26 Terminal Block for CAN/RS-485 (Part-S).................................... 10

RSB-4210 Connectors ............................................................................ 10

2.2.1

Wafer for 4-wire Resistive Type Touch Screen (CN1)............... 11

Figure 2.2 Wafer for 4-wire Resistive Type Touch Screen ....... 11

2.2.2

Phoenix Connector for CAN Bus (CN2)...................................... 12

Figure 2.3 Phoenix Connector for CAN Bus .............................. 12

Figure 2.4 CAN Application ....................................................... 12

Figure 2.5 Schematics of CAN on RSB-4210............................ 12

2.2.3

Phoenix Connector for COM3, RS-485 (CN3) ............................ 13

Figure 2.6 Phoenix Connector for COM3, RS-485 .................... 13

Figure 2.7 RS-485 Application................................................... 13

Figure 2.8 Schematics of RS-485 on RSB-4210 ....................... 13

2.2.4

System Bus (CN4) ...................................................................... 14

Figure 2.9 System Bus .............................................................. 14

2.2.5

Pin Header for COM5, RS-232 (TX/RX/RTS/CTS) (CN5) .......... 15

Figure 2.10Pin Header for COM5, RS-232 (TX/RX/RTS/CTS) .. 15

2.2.6

Pin Header for COM4, 3.3V TTL (TX/RX/RTS/CTS) (CN6)........ 16

Figure 2.11Pin Header for COM4, 3.3V TTL (TX/RX/RTS/CTS) 16

v RSB-4210 User Manual

RSB-4210 User Manual

2.2.7

Pin Header for I2S (CN7)............................................................ 16

Figure 2.12Pin Header for I2S.................................................... 16

2.2.8

LVDS0 LCD Connector (CN8) .................................................... 17

Figure 2.13LVDS0 LCD Connector ............................................ 17

2.2.9

Pin Header for COM1, RS-232 (TX/RX) (CN9) .......................... 18

Figure 2.14Pin Header for COM1, RS-232 (TX/RX)................... 18

2.2.10 Pin Header for SD2 (CN10) ........................................................ 19

Figure 2.15Pin Header for SD2 .................................................. 19

2.2.11 Wafer for Backlight Power and Controller (CN11) ...................... 20

Figure 2.16Wafer for Backlight Power and Controller ................ 20

2.2.12 MiniPCIe Connector-Latch (CN12) and Connector (CN13)........ 20

Figure 2.17MiniPCIe Connector-Latch (CN12) and Connector

(CN13)...................................................................... 20

2.2.13 LVDS1 LCD Connector (CN14) .................................................. 22

Figure 2.18LVDS1 LCD Connector ............................................ 22

2.2.14 Pin Header for Jtag (CN15) ........................................................ 23

Figure 2.19Pin Header for Jtag .................................................. 23

2.2.15 Wafer for SATA power (CN16) ................................................... 24

Figure 2.20Wafer for SATA power ............................................. 24

2.2.16 Wafer for Power ON/OFF (CN17)............................................... 25

Figure 2.21Pin Header for Power Button.................................... 25

2.2.17 Ethernet LAN1&2 Connector (CN18).......................................... 26

Figure 2.22Ethernet LAN1 & LAN2 Connector........................... 26

2.2.18 Wafer for Coin Battery (CN19).................................................... 26

Figure 2.23Wafer for Coin Battery.............................................. 26

2.2.19 SIM Card slot (CN20) ................................................................. 27

Figure 2.24SIM Card slot............................................................ 27

2.2.20 Pin Header for Reset (RST_BTN1) ............................................ 27

Figure 2.25Pin Header for Reset................................................ 27

2.2.21 Pin Header for Suspend (SUS_BTN1) ....................................... 28

Figure 2.26Pin Header for Suspend ........................................... 28

2.2.22 Pin Header for Matrix Keypad (KEYPAD1)................................. 29

Figure 2.27Pin Header for Matrix Keypad .................................. 29

2.2.23 Pin Header for I2C/SPI (CN21)................................................... 30

Figure 2.28Pin Header for I2C/SPI............................................. 30

2.2.24 Pin Header for 20x pins GPIO (GPIO1)...................................... 31

Figure 2.29Pin Header for GPIO ................................................ 31

2.2.25 SATA Connector (SATA_CN1)................................................... 32

Figure 2.30SATA Connector ...................................................... 32

2.2.26 Pin Header for USB_HUB1 (USB1)............................................ 32

Figure 2.31Pin Header for USB_HUB1 ...................................... 32

2.2.27 Wafer for Battery Charger Board - Power (BAT_CN1) ............... 33

Figure 2.32Wafer for Battery Charger Board - Power ................ 33

2.2.28 Wafer for Battery Charger Board -Control Signal (BAT_CN2).... 34

Figure 2.33Wafer for Battery Charger Board - Control Signal.... 34

2.2.29 USB OTG MINI-AB Connector (USB_OTG1)............................. 34

Figure 2.34USB OTG MINI-AB Connector ................................. 34

2.2.30 USB HUB_2&3 (Standard Type-A) (USB2) ................................ 35

Figure 2.35USB CSB_HUB_2&3 (Standard Type-A) ................. 35

2.2.31 VGA Connector (CRT1).............................................................. 35

Figure 2.36VGA Connector (D-SUB15)...................................... 35

2.2.32 HDMI Connector (HDMI_CN1) ................................................... 36

Figure 2.37HDMI Connector....................................................... 36

2.2.33 Box Header for LINE-OUT, LINE-IN, MIC-IN and L&R Speakers

(AUDIO1) .................................................................................... 37

Figure 2.38Box Header for LINE-OUT, LINE-IN, MIC-IN and L&R

Speakers .................................................................. 37

2.2.34 D-Sub9 Connector for COM2, RS-232 (TX/RX/RTS/ CTS) (COM1)

38

Figure 2.39D-Sub9 Connector for COM2, RS-232 (TX/RX/RTS/

vi

2.3

CTS) ......................................................................... 38

2.2.35 DC-IN Power Jack(DCIN1) ......................................................... 39

Figure 2.40DC-IN Power Jack .................................................... 39

2.2.36 SD Card Slot (SD1)..................................................................... 39

Figure 2.41SD card Slot ............................................................. 39

Mechanical .............................................................................................. 40

2.3.1

Connector Location..................................................................... 40

Figure 2.42RSB-4210 Connector Position (Top) ........................ 40

Figure 2.43RSB-4210 Connector Position (Bottom)................... 40

2.3.2

RSB-4210 Board Dimension....................................................... 41

Figure 2.44RSB-4210 Board Dimension .................................... 41

Chapter 3

Software Functionality

......................43

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

Introduction ............................................................................................. 44

Package Content..................................................................................... 44

3.2.1

Package for Making Linux System SD Storage Card ................. 44

Figure 3.1 Contents of package for making Linux system SD storage card.................................................................... 44

3.2.2

Source Code Package ................................................................ 45

Figure 3.2 Contents of Source code package ........................... 45

Setup Building Environment.................................................................... 47

3.3.1

Setenv.sh .................................................................................... 48

Building Instructions ................................................................................ 48

3.4.1

Building U-boot image "u-boot.bin" ............................................. 48

3.4.2

Building Linux Kernel image "uImage"........................................ 48

3.4.3

Build Log ..................................................................................... 49

Source Code Modification ....................................................................... 49

3.5.1

Adding a Driver to Kernel by menuconfig ................................... 49

Figure 3.3 Linux Kernel Configuration ....................................... 49

Figure 3.4 Selecting Seiko Instruments S-35390A .................... 50

Figure 3.5 Integrate Code for Seiko Instruments S-35390A...... 50

3.5.2

Changing the Boot Logo ............................................................. 50

Making Linux System Booting Media ...................................................... 51

3.6.1

Making a Linux System SD Storage Card .................................. 51

3.6.2

Booting from Onboard Flash....................................................... 52

3.6.3

Booting from SATA DOM............................................................ 52

Debug Message ...................................................................................... 52

Figure 3.6 HyperTerminal Settings for Terminal Setup ............. 53

Linux Software Applications on RSB-4210 ............................................. 53

3.8.1

Writing Your Own "Hello World!" Application and Executing on

RSB-4210 ................................................................................... 53

3.8.2

Running Pre-installed Applications on RSB-4210....................... 54

Figure 3.7 QT Demo Applications.............................................. 54

Figure 3.8 QT - Fluidlauncher demo.......................................... 55

Figure 3.9 Video demo .............................................................. 55

Figure 3.10Photo demo .............................................................. 56

Figure 3.11Result of memory testing.......................................... 56

VGA/HDMI Configuration on RSB-4210 ................................................. 57

Figure 3.12Block diagram of video configuration on RSB-4210 . 57

3.9.1

Auto Mode................................................................................... 57

Table 3.1: Output Resolution of RSB-4210 Auto Mode............. 57

3.9.2

Bypass Mode .............................................................................. 57

Table 3.2: 44 Built-in Timings of RSB-4210 Bypass Mode........ 58

Table 3.3: Auto Parameters....................................................... 59

Figure 3.13Change directory to configure CH7033B.................. 59

Figure 3.14Display all built-in timing settings.............................. 59

Figure 3.15Bypass mode configuration ...................................... 60

Figure 3.16Auto parameter selection.......................................... 60

vii RSB-4210 User Manual

3.10

3.11

3.12

GPIO mapping define on RSB4210 ........................................................ 60

3.10.1 What is a GPIO?......................................................................... 60

3.10.2 Paths in Sysfs ............................................................................. 61

3.10.3 GPIO Mapping Table .................................................................. 63

Interface Device Reference Documentation ........................................... 63

3.11.1 I2C .............................................................................................. 63

3.11.2 C example................................................................................... 63

3.11.3 UART .......................................................................................... 67

3.11.4 CAN bus ..................................................................................... 77

3.11.5 SD card /iNand /USB Disk/SATA Disk........................................ 83

3.11.6 LAN............................................................................................. 84

3.11.7 RTC ............................................................................................ 84

3.11.8 WatchDog ................................................................................... 92

3.11.9 Audio........................................................................................... 96

3.11.10Keypad/Touchscreen.................................................................. 96

Backlight Adjustment ............................................................................ 101

RSB-4210 User Manual viii

Chapter

1

1

Overview

This chapter briefly introduces the

RSB-4210 Platform and RSB-4210

Evaluation Kit.

1.1

Introduction

In order to offer potential RISC-based Design-to-Order-Service (DTOS) project customers with a more efficient and low risk evaluation tool, Advantech provides a variety of RISC-based evaluation kits. Before DTOS projects kicking-off, customers can check their designs with these kits in detail more easily. The evaluation kits have already equipped with all of the necessary H/W and S/W parts which customer will need, thus these can reduce design efforts and speed up application developments to meet customers' requirements.

The RSB-4210 is designed as a single board computer (SBC) solution, with adopting

Freescale i.MX53 processor based on ARM® Cortex™ A8 architecture, which is a complete 32-bit, up to 1GHz speed SoC engine. It provides customers with a high performance board subsystem based on ARM® Cortex™ A8 technology with characteristics of ready-to-run, compact, and easy-to-expansion in order to meet customers' versatile needs. With the flexible I/O interfaces and complete hardware and software solutions, RSB-4210 is a fast time-to-market platform for customers to develop their applications and products easily without considering system integration.

The RSB-4210 Evaluation Kit is a complete system designed for customers to evaluate the RSB-4210. It integrates all of the solutions that developers will need, based on the RSB-4210 main board, into a package that provides customers an effortless system platform for project evaluation, application development, and solution feasibility testing that decreases lead-time and lowers initial expense. The RSB-4210 Evaluation Kit has already integrated complete certified functions under Linux's test kits making project development and implementation becomes an easy and risk-free way at the starting point.

1.2

Features

RSB-4210 adopts Freescale i.MX53 Processor - ARM® Cortex™ A8 architecture as its SoC solution. The main features of this platform are heatsink-less, compact, reliable & great power management. Therefore, the platform will be suitable for the following applications:

Economical HMI (Human Machine Interface)

Self Service / Access Control

Fleet management / Navigation

Hand-held data collector

And the main features of Freescale i.MX53 processor are shown as follows:

ARM® Cortex™-A8 1GHz high performance processor

Supports OpenGL ES 2.0 and OpenVG® 1.1 hardware accelerators

Supports full HD 1080p video decode and HD 720p video encode hardware engine Freescale Smart Speed® Technology support low power consumption

I/O through 3.3 V I/O voltage and wide working temperature by industrial design concept

Rich I/O for high expansion capability: UART(5), Dual LVDS, Audio, USB Host,

USB OTG, Dual LAN, SD(2), SATA(1), GPIO(20), I2C(2), SPI(1), I2S(1),

CAN(1), Keypad 6X6, Touch, Mini PCI-E and System Bus

Supports SATA storage interface and CAN bus for vehicle application

Supports Android2.3, Embedded Linux2.6 and Windows Embedded Compact 7

Support wide working temperature -40 ~ 85° C operation temperature

(optional)

RSB-4210 User Manual 2

1.3

Hardware Specifications

Item Description

Kernel

CPU Freescale i.MX53 1GHz (ARM Cortex A8)

2D/3D Accelerators Support OpenGL ES 2.0 and OpenVG™ 1.1 hardware accelerators

System RAM

Onboard Flash

RTC

Watchdog Timer

Reset

I/O

512MB (Optional: 256MB)

2GB (Optional: None)

Yes

Yes

H/W reset & S/W reset

COM

Ethernet LAN

USB Port

USB OTG

SD/MMC

Mini PCI-E

SIM Card slot

SATA

Touch Screen

System Bus

I

2

C Interface

I

2

S Interface

SPI Interface

CAN BUS

COM 1, RS-232, 2–wire(TX/RX), Pin header, (Debug port)

COM 2, RS-232, D-Sub9 Connector(TX/RX/RTS/CTS)

COM 3, RS-485, 2-pin Phoenix Connector

COM 4, 3.3 V TTL, 4–wire(TX/RX/RTS/CTS), Pin header

COM 5, RS-232, 4–wire(TX/RX/RTS/CTS), Pin header

2 x 10/100 BASE-T (RJ-45)

3 x USB 2.0 (High speed)

1 x USB 2.0 OTG (High speed)

2 x SDIO/MMC interface (SD slot x 1+ pin header x 1)

1 x (Control by USB interface only)

1 x

1 x

1 x 4 - wire resistive type interface

Yes (Address: 25 pins, data: 16 pins)

2 x

1 x

1 x

1 x

Hotkey/

Matrix keypad

GPIO

Buzzer control

Multimedia

Graphic Chip

Support 6 x 6 matrix keypad

20 pins 3.3 V TTL level GPIOs

Yes

LCD Resolution

Dual LVDS

HDMI

VGA

Brightness/

Backlight Control

Audio

Power

DC-input

Battery Support

CPU internal LCD controller

Default: 800 x 480 7” WVGA

Optional: 320 x 240 ~ 1920 x 1080

2 x 24-bit LVDS

1 x (Co-lay with VGA)

1 x (Co-lay with HDMI)

Yes

Line-in(Stereo),Line-out(Stereo),Speak-Out(Stereo)&Mic-in(Mono)

9 ~ 24 V 5%

Yes (With external battery and charger board thru connector)

3 RSB-4210 User Manual

Power Consumption

Power Control

Power Management

Normal Run ~2.3 W

Full Run ~3.8 W

1 x Power ON/OFF Pin header

1 x H/W reset Pin header

1 x Suspend Pin header

-Standard mode

-Idle mode

Mechanical and Environmental

Board size 146 x 102 x 20 mm (PCB thickness 1.6 mm; 8 layer)

Weight

Operation Temperature

110 g

0 ~ 60

°

C (32 ~ 140

°

F)

(-40 ~ 85

°

C by component change)

Operating Humidity 5% ~ 95% Relative Humidity, non condensing

Vibration 3.5 G, 1000 times

Others

RoHS

Certification

Yes

O.S

CE/FCC Class A

Embedded Linux 2.6.35 (Default), Android 2.3.4, and Windows Embedded Compact 7

1.4

Board Block Diagram

RSB-4210 User Manual

Figure 1.1 RSB-4210 Board Block Diagram

4

Chapter

2

2

H/W Installation

This chapter introduces the setup procedures of the RSB-4210 hardware, including instructions on setting jumpers and connecting peripherals, switches, indicators and mechanical drawings.

Be sure to read all safety precautions before you begin this installation procedure.

2.1

Development Kit H/W Installation

The Figure 2-1 is RSB-4210 Evaluation Kit Assembly, and the detail descriptions with

Advantech P/N are shown as below.

Item Description

Part-A

Part-B1

RSB-4210

7” LCD-LED Backlight, LVDS, 800x480, T/S,

97G070V1N0F-2

Part-B2 LCD Backlight Cable

Part-B3 LVDS Cable

Part-B4 Touch Cable

Part-C SQFlash SD Card, SLC 2GB, (-40~85°C)

Part-D

Part-E

SATA Power Cable

SATA Cable

Part-F Mini USB Host Cable

Part-G Mini USB Client Cable

Part-H

Part-J

Part-K

Part-L

USB Type-A Cable

Null modem cable

ADAPTER, 100-240V, 19V, 3.42A.

3 pin Power Cord (USA Standard) [Optional]

3 pin Power Cord (Europe standard) [Optional]

3 pin Power Cord (UK standard) [Optional]

Part-M Speaker & Audio Cables

Part-N1 Power Cable for Charger Board [Optional]

Part-N2 Signal Cable for Charger Board [Optional]

Part-N3 Charger Board [Optional]

Part-N4 Battery [Optional]

Part-O1 8*8 Keypad Cable [Optional]

Part-O2 8*8 Keypad [Optional]

Part-Q COM Port Cable

Part-R

Part-S

RS-232 Loopback

Terminal Block for CAN/RS-485

Advantech P/N

(P/N: RSB-4210CF-A78AAE)

(P/N: 96LEDK-A070WV32RB1)

(P/N: 1700019577)

(P/N: 1700014418)

(P/N: 1700000194)

(P/N: SQF-ISDS2-2G-ETE)

(P/N: 1700018785)

(P/N: 1700004711)

(P/N: 1700019076)

(P/N: 1700019077)

(P/N: 1700019129)

(P/N: 1700091002)

(P/N: 1757003734)

(P/N: 1700001524)

(P/N: 170203183C)

(P/N: 170203180A)

(P/N: 1700019546-11)

(P/N: 1700018394)

(P/N: 1700018395)

(P/N: 969K073900E)

(P/N: 1760001300)

(P/N: 1703200180)

(P/N: 96969315A0E)

(P/N: 1700100250)

(P/N: 1654909900)

(P/N: 1652002209)

RSB-4210 User Manual 6

Figure 2.1 RSB-4210 Development Kit Assembly

7 RSB-4210 User Manual

2.1.1

RSB-4210 (Part-A)

RSB-4210 is a cost-effective, low-power, and high-performance SBC (Single Board

Computer) without a heatsink, geared to satisfy the needs for various industrial computing equipments. Based on Freescale i.MX53 Processor - ARM® Cortex™ A8 architecture, there are DDR3, iNAND flash and other main ICs. RSB-4210 offers convenient connector layout, simple assembly, multiple common I/Os, and includes dual

10/100Mbps Ethernet, three USB (Universal Serial Bus) 2.0 and five serial ports for easy system expansibility.

2.1.2

7" LVDS LCD Module (Part-B1)

The 7.0 inch Color TFT-LCD Module with 4-wires resistive type touch sensor. The module is designed with wide viewing angle; wide operating temperature and long life

LEDs backlight is well suited to be the display units for Industrial Applications. LED driving board for backlight unit is included in this panel and the structure of the LED units is replaceable. It's built in timing controller and LVDS interface. The display supports the WVGA (800 (H) x 480(V)) screen format and 16.2 M colors (RGB 24bits) or

262 K (RGB 18 bits) selectable.

2.1.3

LCD Backlight Cable (Part-B2)

The LVDS backlight cable connects RSB-4210 (CN11) with the LCD backlight connector of 7" LVDS LCD Module.

2.1.4

LVDS Cable (Part-B3)

The LVDS cable connects RSB-4210 LVDS0 connector (CN8) with the LCD signal connector of 7" LVDS LCD Module.

2.1.5

Touch Cable (Part-B4)

The touch cable connects RSB-4210 (CN1) with the touch connector of 7" LVDS LCD

Module.

2.1.6

SQFlash SD Card (Part-C)

The SQFlash SD card is a standard SD device. It is the flash-based solid-state drive available and uses SLC NAND flash memory, making it ideal as an embedded SSD solution. It connects on SD1 of RSB-4210.

2.1.7

SATA Power Cable (Part-D)

The SATA power cable provides the power signal for SATA HDD by connecting RSB-

4210 (CN16) and the SATA HDD.

2.1.8

SATA Cable (Part-E)

The SATA cable provides the control signal with SATA HDD by connecting RSB-4210

(SATA_CN1) with the SATA HDD.

2.1.9

Mini USB Host Cable (Part-F)

The mini USB Host cable connects RSB-4210 (USB_OTG1) with one USB client device. For example, USB mouse/keyboard.

2.1.10

Mini USB Client Cable (Part-G)

The mini USB Client cable connects RSB-4210 (USB_OTG1) with PC or NB.

RSB-4210 User Manual 8

2.1.11

USB Type-A Cable (Part-H)

The USB extend cable provide Type-A for USB device. For example, USB mouse/ keyboard.

2.1.12

Jumper (Part-I)

When plug-in the adapter with the wafer (CN17) shorted by this jumper, the system will power-on.

2.1.13

Null modem cable (Part-J)

The null modem cable connects RSB-4210 COM ports with a serial device.

2.1.14

19 V Power Adapter (Part-K)

The AC-to-DC power device provides a 19 V DC output (65 W max) with constant voltage sources (100 V ~ 240 V).

2.1.15

Power Cord (Part-L)

3P Power Cord (USA, Europe or UK standard) for 19 V Power Adapter AC input.

2.1.16

Speaker & Audio Cables (Part-M)

The cable connects with RSB-4210 (AUDIO1) and LINE-OUT, LINE-IN, MIC-IN and

L&R Speakers.

2.1.17

Power Cable for Charger Board (Part-N1)

The cable provides the power for charger board. It connects RSB-4210 (BAT_CN1) with the charger board (CN2).

2.1.18

Signal Cable for Charger Board (Part-N2)

The cable provides the control signal for charger board. It connects RSB-4210

(BAT_CN2) with the charger board (CN1).

2.1.19

Charger Board (Part-N3)

The charger board provides 12 V power to charge the battery when plug-in a 19 V adapter, and RSB-4210 can read the battery status through this charger board.

Note!

It is necessary to use 19 V adapter for charger board rather than 12 V.

2.1.20

Battery (Part-N4)

The battery can provide the power with RSB-4210 without any adapter.

2.1.21

Keypad Cable (Part-O1)

The keypad cable connects RSB-4210 (KEYPAD1) with the keypad.

2.1.22

Keypad (Part-O2)

8*8 arrays of 64 normally open single-pole switches. (6*6 region of keypad are available when using RSB-4210.)

9 RSB-4210 User Manual

2.1.23

Cable for Suspend/Reset Button (Part-P)

The cable is used to extend the Suspend/Reset function by a specific button.

2.1.24

COM Port Cable (D-SUB 9P to Housing) (Part-Q)

The cable is used to extend COM port 9pin header from RSB-4210 to D-SUB 9P serial port connector.

2.1.25

RS-232 Loopback (Part-R)

The terminal connector 9P female is used to test RS-232 loopback function.

2.1.26

Terminal Block for CAN/RS-485 (Part-S)

The terminal block can be extended with extra two cables to connect RSB-4210

CAN/RS-485 function with the others CAN/RS-485 devices.

2.2

RSB-4210 Connectors

The following table shows the connector list of RSB-4210.

Connector

CN 16

CN 17

CN 18

CN 19

CN 20

RST_BTN1

SUS_BTN1

KEYPAD1

CN21

GPIO1

SATA_CN1

USB1

BAT_CN1

CN 8

CN 9

CN 10

CN 11

CN 12

CN 13

CN 14

CN 15

CN 1

CN 2

CN 3

CN 4

CN 5

CN 6

CN 7

Description

Wafer for 4-wire Resistive Type Touch Screen

Phoenix Connector for CAN Bus

Phoenix Connector for COM3, RS-485

System Bus

Pin Header for COM5, RS-232 (TX/RX/RTS/CTS)

Pin Header for COM4, 3.3V TTL (TX/RX/RTS/CTS)

Pin Header for I2S

LVDS0 LCD Connector

Pin Header for COM1, RS-232 (TX/RX)

Pin Header for SD2

Wafer for Backlight Power and Controller

MiniPCIe Connector-Latch

MiniPCIe Connector

LVDS1 LCD Connector

Pin Header for Jtag

Wafer for SATA Power

Wafer for Power ON/OFF

Ethernet LAN1&2 Connector

Wafer for Coin Battery

SIM Card Slot

Pin Header for Reset

Pin Header for Suspend

Pin Header for Matrix Keypad

Pin Header for I2C/SPI

Pin Header for 20x pins GPIO

SATA Connector

Pin Header for USB_HUB1

Wafer for Battery Charger Board – Power

RSB-4210 User Manual 10

BAT_CN2

USB_OTG1

USB2

CRT1

HDMI_CN1

AUDIO1

COM1

DCIN1

SD1

Wafer for Battery Charger Board – Control Signal

USB OTG MINI-AB Connector

USB_HUB_2&3 (Standard Type-A)

VGA Connector

HDMI Connector

Box Header for LINE-OUT, LINE-IN, MIC-IN and L&R Speakers

D-Sub9 Connector for COM2, RS-232 (TX/RX/RTS/CTS)

DC-IN Power Jack

SD Card Slot

2.2.1

Wafer for 4-wire Resistive Type Touch Screen (CN1)

The touch screen interface performs all sampling, averaging, ADC range checking, and control for a wide variety of analog resistive touch screens. This controller only interrupts the processor when a meaningful change occurs.

Figure 2.2 Wafer for 4-wire Resistive Type Touch Screen

Pin

1

3

Description

Touch_Y-

Touch_X-

Pin

2

4

Description

Touch_Y+

Touch_X+

11 RSB-4210 User Manual

2.2.2

Phoenix Connector for CAN Bus (CN2)

RSB-4210 supports one CAN bus, while CN2 is a phoenix connector for CAN bus.

Note!

For CAN applications, the two ends of the cable will have a termination resistor connected across the two wires. Without termination resistors, reflections of fast driver edges can cause multiple data edges that can cause data corruption. Please refer to Figure 2.4 and Figure 2.5 to adding a termination resistor (120 ohms) on your end device (R271 of RSB-

4210, default is none) to avoid this situation.

Figure 2.3 Phoenix Connector for CAN Bus

Pin

1

Description

CAN_D+

Pin

2

Description

CAN_D-

Figure 2.4 CAN Application

Figure 2.5 Schematics of CAN on RSB-4210

RSB-4210 User Manual 12

2.2.3

Phoenix Connector for COM3, RS-485 (CN3)

RSB-4210 supports one RS-485 interface, while CN3 is a phoenix connector for RS-

485.

Note!

For RS-485 applications, the two ends of the cable will have a termination resistor connected across the two wires. Without termination resistors, reflections of fast driver edges can cause multiple data edges that can cause data corruption. Please refer to Figure 2.7 and Figure 2.8 to adding a termination resistor (120 ohms) on your end device (R289 of

RSB-4210, default is 120 ohms) to avoid this situation.

Figure 2.6 Phoenix Connector for COM3, RS-485

Pin

1

Description

RS485_TXD-

Pin

2

Description

RS485_TXD+

Figure 2.7 RS-485 Application

Figure 2.8 Schematics of RS-485 on RSB-4210

13 RSB-4210 User Manual

2.2.4

System Bus (CN4)

The RSB-4210 provides the system bus via PCI104+ connector for extend device used. The pin assignment is shown as below.

Figure 2.9 System Bus

Pin Description

A1 N/C

A2 GND

A3 EX_GPIO_8

A4 N/C

A5 SysBus_A0

A6 SysBus_A2

A7 SysBus_A4

A8 SysBus_A6

A9 SysBus_A16

A10 SysBus_A18

A11 SysBus_A20

A12 SysBus_A22

A13 DIO_3V3

A14 SysBus_D0

A15 SysBus_D2

A16 SysBus_D4

A17 SysBus_D6

A18 N/C

A19 N/C

A20 N/C

A21 N/C

A22 N/C

A23 N/C

A24 N/C

A25 N/C

Pin Description

B1 GND

B2 N/C

B3 IMX_GPIO4

B4 N/C

B5 SysBus_A1

B6 SysBus_A3

B7 SysBus_A5

B8 SysBus_A7

B9 SysBus_A17

B10 SysBus_A19

B11 SysBus_A21

B12 SysBus_A23

B13 N/C

B14 SysBus_D1

B15 SysBus_D3

B16 SysBus_D5

B17 SysBus_D7

B18 N/C

B19 N/C

B20 N/C

B21 N/C

B22 N/C

B23 N/C

B24 N/C

B25 N/C

Pin Description Pin Description

C1 N/C

C2 DIO_3V3

C3 IMX_GPIO3

C4 DIO_3V3

C5 SysBus_A15

C6 SysBus_A13

C7 SysBus_A11

C8 SysBus_A9

C9 SysBus_A24

C10 N/C

C11 SysBus_RW

C12 N/C

C13 SysBus_CS0

C14 SysBus_D15

C15 SysBus_D13

C16 SysBus_D11

D1

D2

D3

D4

D5

D6

D7

D8

D9

N/C

DIO_3V3

IMX_GPIO2

DIO_3V3

SysBus_A14

SysBus_A12

SysBus_A10

SysBus_A8

N/C

D10 SysBus_OE

D11 GND

D12 N/C

D13 SysBus_CS1

D14 SysBus_D14

D15 SysBus_D12

D16 SysBus_D10

C17 SysBus_D9

C18 N/C

C19 N/C

C20 N/C

D17 SysBus_D8

D18 N/C

D19 N/C

D20 N/C

C21 N/C D21 N/C

C22 SysBus_BCLK D22 GND

C23 N/C

C24 SysBus_EB1

C25 N/C

D23 GND

D24 DIO_3V3

D25 DIO_3V3

RSB-4210 User Manual 14

A26 SysBus_nEB0 B26 N/C

A27 N/C

A28 SysBus_WP

B27 SysBus_LBA

B28 N/C

A29 N/C

A30 SysBus_Wait

B29 N/C

B30 N/C

C26 N/C

C27 5 V_EXT

C28 SysBus_Wait

C29 N/C

C30 GND

D26 N/C

D27 5V_EXT

D28 N/C

D29 N/C

D30 N/C

2.2.5

Pin Header for COM5, RS-232 (TX/RX/RTS/CTS) (CN5)

CN5 is a 4-wire (TX/RX/RTS/CTS) RS-232 port which provides connections between serial devices (For example, GPS, GSM and Bluetooth devices etc.) or a communication network.

Figure 2.10 Pin Header for COM5, RS-232 (TX/RX/RTS/CTS)

Pin

1

3

5

7

9

Description

N/C

COM5_RXD

COM5_TXD

N/C

GND

Pin

2

4

6

8

10

Description

N/C

COM5_RTS

COM5_CTS

N/C

N/C

15 RSB-4210 User Manual

2.2.6

Pin Header for COM4, 3.3V TTL (TX/RX/RTS/CTS) (CN6)

CN6 is a 4-wire (TX/RX/RTS/CTS) 3.3 V TTL signal which provides connections between serial devices (For example, GPS, GSM and Bluetooth devices etc.) or a communication network.

Figure 2.11 Pin Header for COM4, 3.3V TTL (TX/RX/RTS/CTS)

2.2.7

Pin Header for I2S (CN7)

RSB-4210 provides one I2S interface for user to expand their applications, and CN7 is the pin header for I2S interface.

Pin

1

3

5

7

9

Description

AUDIO_CLK

AUD3_TXC

AUD3_TXFS

AUD3_RXD

GND

RSB-4210 User Manual

Figure 2.12 Pin Header for I2S

Pin

2

4

6

8

10

Description

AUD3_TXD

N/C

N/C

N/C

DIO_3V3

16

2.2.8

LVDS0 LCD Connector (CN8)

RSB-4210 supports dual LVDS LCD Interfaces (24+24 bit), in which CN8 is LVDS0

(24 bit) while CN14 is LVDS1 (24bit). The pin assignment of LVDS0 (CN8) is shown as below.

Pin

7

9

11

13

15

17

19

1

3

5

Description

3.3 V

3.3 V

LVDS0_TX0-

GND

LVDS0_TX1+

LVDS0_TX2-

GND

LVDS0_CLK+

3.3 V

LVDS0_TX3-

Figure 2.13 LVDS0 LCD Connector

Pin

8

10

12

14

16

18

20

2

4

6

Description

3.3 V

3.3 V

LVDS0_TX0+

LVDS0_TX1-

GND

LVDS0_TX2+

LVDS0_CLK-

GND

N/C

LVDS0_TX3+

17 RSB-4210 User Manual

2.2.9

Pin Header for COM1, RS-232 (TX/RX) (CN9)

CN9 is a 2-wire (TX/RX) RS-232 port which provides connections between serial devices (For example, GPS, GSM and Bluetooth devices etc.) or a communication network.

Figure 2.14 Pin Header for COM1, RS-232 (TX/RX)

Pin

1

3

5

7

9

Description

N/C

COM1_RXD

COM1_TXD

N/C

GND

Pin

2

4

6

8

10

Description

N/C

N/C

N/C

N/C

N/C

RSB-4210 User Manual 18

2.2.10

Pin Header for SD2 (CN10)

The SD/MMC Slots are 3.3 V powered, which are able to be extended for SD slot module and SDIO interface module with the following features:

Fully compatible with the MMC system specification version 3.2

Compatible with the SD Memory Card specification 1.01, and SD I/O specification 1.1 with 1/4 channel(s)

Block-based data transfer between MMC card and SDHC (stream mode not supported)

100 Mbps maximum data rate in 4-bit mode, SD bus clock up to 25MHz

Pin

7

9

11

1

3

5

Description

GND

SD4_DATA1

SD4_DATA0

SD4_DATA3

SD4_DATA2

N/C

Figure 2.15 Pin Header for SD2

Pin

8

10

12

2

4

6

Description

GND

SD4_CLK

SD4_CMD

SD4_CD

3V3

N/C

19 RSB-4210 User Manual

2.2.11

Wafer for Backlight Power and Controller (CN11)

This wafer provides DC +12 V, DC +5 V, back-light on/off control signal and 0 ~ 5 V

PWM dimming control to inverter. Strongly suggest user chooses the inverter that dimming control is by PWM to fit development kit design.

Figure 2.16 Wafer for Backlight Power and Controller

Pin

1

3

5

7

Description

GND

BLK_PWR_EN

Brightness

12 V

Pin

2

4

6

8

Description

GND

BLK_PWR_EN

PWM1

5 V

2.2.12

MiniPCIe Connector-Latch (CN12) and Connector (CN13)

RSB-4210 supports a MiniPCIe Interface. The pin assignment is shown as below.

Figure 2.17 MiniPCIe Connector-Latch (CN12) and Connector (CN13)

RSB-4210 User Manual 20

Description

nWAKE

N/C

N/C nCLKREQ

GND

PCIe_CLK_N

PCIe_CLK_P

GND

N/C

N/C

GND

PCIe_RX0_N

PCIe_RX0_P

GND

GND

PCIe_TX0_N

PCIe_TX0_P

GND

GND

N/C

N/C

GND

N/C

N/C

N/C

N/C

N/C

GND

Pin

41

43

45

47

33

35

37

39

49

51

53

55

25

27

29

31

17

19

21

23

9

11

13

15

5

7

1

3

Description

DIO_3V3

N/C

IO_1V5

UIM_PWR

UIM_DATA

UIM_CLK

UIM_RESET

UIM_VPP

GND

N/C nRESET_OUT

DIO_3V3

GND

IO_1V5

PCIe_SMBCLK

PCIe_SMBDAT

GND

USB_HUB4_D-

USB_HUB4_D+

GND

LED_WWAN

LED_WLAN

LED_WPAN

IO_1V5

GND

DIO_3V3

N/C

GND

Pin

42

44

46

48

34

36

38

40

50

52

54

56

26

28

30

32

18

20

22

24

10

12

14

16

6

8

2

4

21 RSB-4210 User Manual

2.2.13

LVDS1 LCD Connector (CN14)

RSB-4210 supports dual LVDS LCD Interfaces (24+24bit), in which CN8 is LVDS0

(24 bit) while CN14 is LVDS1 (24 bit). The pin assignment of LVDS1 (CN14) is shown as below.

Pin

7

9

11

13

15

17

19

1

3

5

Description

5 V

5 V

LVDS1_TX0-

GND

LVDS1_TX1+

LVDS1_TX2-

GND

LVDS1_CLK+

N/C

LVDS1_TX3-

Figure 2.18 LVDS1 LCD Connector

Pin

8

10

12

14

16

18

20

2

4

6

Description

5 V

5 V

LVDS1_TX0+

LVDS1_TX1-

GND

LVDS1_TX2+

LVDS1_CLK-

GND

N/C

LVDS1_TX3+

RSB-4210 User Manual 22

2.2.14

Pin Header for Jtag (CN15)

RSB-4210 provides one Jtag interface for debugging CPU. CN15 is the pin header for Jtag interface.

Pin

1

3

5

7

9

Description

JTAG_TCK

JTAG_TMS

JTAG_TDO

JTAG_TDI

JTAG_TRST

Figure 2.19 Pin Header for Jtag

Pin

2

4

6

8

10

Description

GND

GND

GND

IO_3V3

N/C

23 RSB-4210 User Manual

2.2.15

Wafer for SATA power (CN16)

CN16 provides DC +5 V for SATA device. The pin assignment is shown as below.

Pin

1

3

Description

SATA_5 V

GND

Figure 2.20 Wafer for SATA power

Pin

2

4

Description

GND

N/C

RSB-4210 User Manual 24

2.2.16

Wafer for Power ON/OFF (CN17)

When plug-in the adapter with CN17 shorted by a jumper, the system will power-on.

Or you can connect this wafer with an external button to control the power ON/OFF.

Note!

If your system cannot power-on with an adapter, please check this wafer in advance. There should be a jumper or external button on the wafer.

Pin

1

Description

PWR_BTN+

Figure 2.21 Pin Header for Power Button

Pin

2

Description

PWR_BTN-

25 RSB-4210 User Manual

2.2.17

Ethernet LAN1&2 Connector (CN18)

RSB-4210 supports dual LAN. One is extended from CPU module board directly and another is extended from system bus. Both of them support 10/100 Mbps transfer rates and are compliant with IEEE 802.3.

Note!

LAN connector with LED indicator: green LED indicates Ethernet active, while yellow LED indicates Ethernet speed 10/100.

Figure 2.22 Ethernet LAN1 & LAN2 Connector

2.2.18

Wafer for Coin Battery (CN19)

CN19 is used for connecting with coin battery. The pin assignment is shown as below.

Pin

1

Description

COIN_RTC

Figure 2.23 Wafer for Coin Battery

Pin

2

Description

GND

RSB-4210 User Manual 26

2.2.19

SIM Card slot (CN20)

RSB-4210 provides a SIM card slot for MiniPCIe devices.

Figure 2.24 SIM Card slot

2.2.20

Pin Header for Reset (RST_BTN1)

RST_BTN1 is used for resetting the system. You can connect it with an external button for application. The pin assignment is shown as below.

Pin

1

Description

nRESET

Figure 2.25 Pin Header for Reset

Pin

2

Description

GND

27 RSB-4210 User Manual

2.2.21

Pin Header for Suspend (SUS_BTN1)

SUS_BTN1 is used to making system entering into suspend mode or resume from suspend mode. You can connect it with an external button for applications. The pin assignment is shown as below.

Pin

1

Description

nSUSPEND

Figure 2.26 Pin Header for Suspend

Pin

2

Description

GND

RSB-4210 User Manual 28

2.2.22

Pin Header for Matrix Keypad (KEYPAD1)

The keypad circuitry scans a 6*6 array of 36 normal-open, single-pole switches. Any one or two keys depressed will be de-bounced and decoded. An interrupt is generated whenever a stable set of depressed keys is detected. The keypad interface:

Provides scanning, de-bounce, and decoding for a 36-key switch array

Scans a 6-row by 6-column matrix

May decode 2 keys at once

Generates an interrupt when a new stable key is determined

Generates a 3-key reset interrupt as well

Pin

5

7

1

3

9

11

Description

KEY_COL2

KEY_COL3

KEY_COL4

KEY_COL5

KEY_COL6

KEY_COL7

Figure 2.27 Pin Header for Matrix Keypad

Pin

6

8

2

4

10

12

Description

KEY_ROW2

KEY_ROW3

KEY_ROW4

KEY_ROW5

KEY_ROW6

KEY_ROW7

29 RSB-4210 User Manual

2.2.23

Pin Header for I2C/SPI (CN21)

RSB-4210 provides two I2C and one SPI interface with user to expand their applications. CN21 is the pin header for I2C/SPI interface. The pin assignment is shown as below.

Pin

7

9

11

1

3

5

Description

GND

I2C1_SCL

I2C1_SDA

I2C3_SCL

I2C3_SDA

DIO_3V3

Figure 2.28 Pin Header for I2C/SPI

Pin

8

10

12

2

4

6

Description

SPI_IRQ

SPI_MISO

SPI_MOSI

SPI_CS0

SPI_CLK

DIO_3V3

RSB-4210 User Manual 30

2.2.24

Pin Header for 20x pins GPIO (GPIO1)

GPIO1 is extended for 20x pins 3.3V TTL Level GPIO. GPIO1~4 pins are coming from CPU directly while GPIO5~20 pins are extended from IC PCA9555. The pin assignment is shown as below.

Pin

7

9

11

13

15

1

3

5

17

19

21

Description

GND

IMX_GPIO1

IMX_GPIO3

EX_GPIO_5

EX_GPIO_7

EX_GPIO_9

EX_GPIO_11

EX_GPIO_13

EX_GPIO_15

EX_GPIO_17

EX_GPIO_19

Figure 2.29 Pin Header for GPIO

Pin

8

10

12

14

16

2

4

6

18

20

22

Description

DIO_3V3

IMX_GPIO2

IMX_GPIO4

EX_GPIO_6

EX_GPIO_8

EX_GPIO_10

EX_GPIO_12

EX_GPIO_14

EX_GPIO_16

EX_GPIO_18

EX_GPIO_20

31 RSB-4210 User Manual

2.2.25

SATA Connector (SATA_CN1)

RSB-4210 supports one SATA Interface thru SATA_CN1. (Both SATA DOM and

SATA HDD support.) The pin assignment is shown as below.

Figure 2.30 SATA Connector

Pin

5

7

1

3

Description

GND

SATA_TX-

SATA_RX-

GND

Pin

2

4

6

Description

SATA_TX+

GND

SATA_RX+

2.2.26

Pin Header for USB_HUB1 (USB1)

The USB port is extended from USB_HUB1. The pin assignment is shown as below.

Figure 2.31 Pin Header for USB_HUB1

Pin

1

3

5

Description

5V

CSB_HUB1_Data +

GND (Chassis Ground)

Pin

2

4

Description

CSB_HUB1_Data -

GND

RSB-4210 User Manual 32

2.2.27

Wafer for Battery Charger Board - Power (BAT_CN1)

BAT_CN1 provides the power with battery charger board. +VIN_ADP is the voltage from adapter to battery charge board; +VIN is the voltage from battery charge board to RSB-4210. The pin assignment is shown as below.

Figure 2.32 Wafer for Battery Charger Board - Power

Pin

1

3

5

Description

+VIN_ADP (For Battery)

GND

+VIN (For RSB-4210)

Pin

2

4

6

Description

+VIN_ADP (For Battery)

GND

+VIN (For RSB-4210)

33 RSB-4210 User Manual

2.2.28

Wafer for Battery Charger Board -Control Signal (BAT_CN2)

BAT_CN2 provides the I2C control signal with battery charger board. The pin assignment is shown as below.

Figure 2.33 Wafer for Battery Charger Board - Control Signal

Pin

1

3

5

7

Description

3.3 V_STB

I2C3_SCL_BAT

I2C3_SDA_BAT

Charger_board_IN#

Pin

2

4

6

8

Description

GND

N/C

N/C

N/C

2.2.29

USB OTG MINI-AB Connector (USB_OTG1)

The RSB-4210 has a single USB OTG mini-AB port which can be used as a USB client to link with PC or a USB host device. For USB client applications, users could upload or download files to any folder in Windows CE and create a synchronous folder between PC and RSB-4210 thru this connector. For USB host applications, users can connect with USB devices, for example, USB mouse and USB keypad.

Pin

1

3

5

Description

5V

Data +

GND

RSB-4210 User Manual

Figure 2.34 USB OTG MINI-AB Connector

34

Pin

2

4

Description

Data -

USBOTG_ID

2.2.30

USB HUB_2&3 (Standard Type-A) (USB2)

The USB interface provides full speed serial communications ports, which includes the following features:

Compliance with the USB 2.0 specification

Transceiver buffers integrated, over-current protection on ports

Supports power management

Operates as a master on the bus

Figure 2.35 USB CSB_HUB_2&3 (Standard Type-A)

2.2.31

VGA Connector (CRT1)

RSB-4210 supports a standard VGA Interface (D-SUB15). The pin assignment is shown as below.

Pin

9

11

13

15

5

7

1

3

Description

CRT_R

CRT_B

GND

GND

+5 V

N/C

HSYNC

DDC_SC_CRT

Figure 2.36 VGA Connector (D-SUB15)

Pin

10

12

14

6

8

2

4

Description

CRT_G

N/C

GND

GND

GND

DDC_SD_CRT

VSYNC

35 RSB-4210 User Manual

2.2.32

HDMI Connector (HDMI_CN1)

RSB-4210 supports a standard HDMI Interface. The pin assignment is shown as below.

Pin

7

9

11

13

1

3

5

15

17

19

Description

HDMI_TD2+

HDMI_TD2-

GND

HDMI_TD0+

HDMI_TD0-

GND

HDMI_CEC

DDC_SC_HD

GND

HPD

Figure 2.37 HDMI Connector

Pin

8

10

12

14

2

4

6

16

18

Description

GND

HDMI_TD1+

HDMI_TD1-

GND

HDMI_CLK+

HDMI_CLK-

HDMI_Reserved

DDC_SD_HD

+5V_HDMI

RSB-4210 User Manual 36

2.2.33

Box Header for LINE-OUT, LINE-IN, MIC-IN and L&R Speakers

(AUDIO1)

The box header is used for audio input / output signal port, and the speaker-out uses a 2W amplifier. The pin assignment is shown as below.

Figure 2.38 Box Header for LINE-OUT, LINE-IN, MIC-IN and L&R Speakers

Pin

9

11

13

15

5

7

1

3

Description

LINE_OUT_R

LINE_OUT_L

SPK_R+

N/C

LINE_IN_R

N/C

N/C

MIC_IN

Pin

10

12

14

16

6

8

2

4

Description

SPK_R-

SPK_L-

SPK_L+

AGND

LINE_IN_L

AGND

N/C

AGND

37 RSB-4210 User Manual

2.2.34

D-Sub9 Connector for COM2, RS-232 (TX/RX/RTS/ CTS)

(COM1)

COM1 port supports RS-232 (TX/RX/RTS/CTS). The pin assignment is shown as below.

Figure 2.39 D-Sub9 Connector for COM2, RS-232 (TX/RX/RTS/CTS)

Pin

1

3

5

7

9

Description

N/C

COM2_TXD

GND

COM2_RTS

N/C

Pin

2

4

6

8

Description

COM2_RXD

N/C

N/C

COM2_CTS

RSB-4210 User Manual 38

2.2.35

DC-IN Power Jack(DCIN1)

The DC-in power jack DCIN1 provides the power with RSB-4210 (+9 ~ 24 V).

Figure 2.40 DC-IN Power Jack

2.2.36

SD Card Slot (SD1)

The SD card Slot (SD1) is powered with 3.3 V, which includes the following features:

Fully compatible with the MMC system specification version 3.2

Compatible with the SD Memory Card specification 1.01, and SD I/O specification 1.1 with 1/4 channel (s)

Block-based data transfer between MMC card and SDHC (stream mode not supported)

100 Mbps maximum data rate in 4-bit mode, SD bus clock up to 25 MHz

Figure 2.41 SD card Slot

39 RSB-4210 User Manual

2.3

Mechanical

2.3.1

Connector Location

Figure 2.42 RSB-4210 Connector Position (Top)

Figure 2.43 RSB-4210 Connector Position (Bottom)

RSB-4210 User Manual 40

2.3.2

RSB-4210 Board Dimension

Figure 2.44 RSB-4210 Board Dimension

41 RSB-4210 User Manual

RSB-4210 User Manual 42

Chapter

3

3

Software Functionality

This chapter details the Linux operating system on the RSB-

4210 platform.

3.1

Introduction

The RSB-4210 platform is one embedded system with Linux kernel 2.6.35 as default.

Its major functions include all system-required shell commands and driver ready for

RSB-4210 platform. Advantech Linux package does not offer developing environment. User can develop it under an Ubuntu environment.

There are three major boot components for Linux, "u-boot.bin", "uImage" and "File

System". The "u-boot.bin" is for initial peripheral hardware parameter. The "uImage" is the Linux kernel image. And the "File System" is for Linux O.S. used.

The system will not boot into Linux environment successfully if one of these files is not exist on booting media (SD storage card or onboard flash).

The purpose of this chapter is to get you going with developing software for the RSB-

4210 on a Linux development host only.

Note!

All instructions in this guide are for Ubuntu 10.04 LTS. At this time, it is the only supported Linux host distribution for development.

Note!

The "u-boot.bin" file has been installed on NOR flash of RSB-4210 as default.

3.2

Package Content

There are two kinds of Linux package for RSB-4210. One is for making Linux system

SD storage card, and another is source code package.

3.2.1

Package for Making Linux System SD Storage Card

RSB-4210 supports booting from SD storage card. Users can use this package to make a Linux system SD storage card. The package contains mkmmc-linux.sh, uboot.bin, uImage and rootfs folder.

Figure 3.1 Contents of package for making Linux system SD storage card

The description of RSB-4210_Linux_system_SD package contents: mkmmc-linux.sh

A script to make the Linux system SD card quickly.

u-boot.bin

U-boot image uImage

Linux kernel image rootfs

Root file system (include "mk_inand")

Note!

Please contact with your Advantech contact window if you need it.

RSB-4210 User Manual 44

3.2.2

Source Code Package

RSB-4210 source code package contains many software components which are accessed by RSB-4210 products. Some are developed by Advantech and some are developed in and by the open source community. This package contains seven main folders, "cross_compiler", "image", "logo", "mk_inand", "rootfs", "scripts", and

"source".

Figure 3.2 Contents of Source code package

The description of RSB-4210_Linux_Source_Code package contents:

"cross_compiler"'

This folder contains source code for cross compiler.

"image"

This folder contains the uImage, and the script for making Linux system media automatically.

"logo"

This folder contains Advantech logo.

"mk_inand"

Linux system files for onboard flash/SATA disk booting used.

(Including mkmmc-linux.sh/mksata-linux.sh, u-boot.bin, uImage, sfdisk.)

"rootfs"

This folder contains source code for Linux file system

"scripts"

This folder contains scripts for configure system and compile images automatically.

"source"

This folder contains source code for Linux kernel image

3.2.2.1

Cross Compiler

You can use the cross compiler to compile the uImage and related applications.

(gcc version is 4.4.4_09_06_2010)

3.2.2.2


This folder includes the files as follows: mkmmc-linux.sh

A script to make the Linux system SD card quickly.

u-boot.bin

U-boot image uImage

Linux kernel image

And the "uImage" is compiled from Chapter 3.1.2.5.

3.2.2.3

Rootfs (Root File System)

The Linux root file system is usually thought of in a tree structure. The tree of the file system starts at the trunk or slash, indicated by a forward slash (/). This directory, containing all underlying directories and files, is also called the root directory or "the root" of the file system.

Directories that are only one level below the root directory are often preceded by a slash, to indicate their position and prevent confusion with other directories that could have the same name. When starting with a new system, it is always a good idea to take a look in the root directory.

The main folders contained in "rootfs" are listed as follows: bin'

Common programs, shared by the system, the system administrator and the users.

45 RSB-4210 User Manual

boot'

The startup files and the kernel. In some recent distributions also grub data. Grub is the GRand Unified Boot loader and is an attempt to get rid of the many different boot-loaders we know today.

dev'

Contains references to all the CPU peripheral hardware, which are represented as files with special properties.

etc'

Most important system configuration files are in /etc, this directory contains data similar to those in the Control Panel in Windows home'

Home directories of the common users.

lib'

Library files, includes files for all kinds of programs needed by the system and the users.

lost+found'

Every partition has a lost+found in its upper directory. Files that were saved during failures are here.

mnt'

Standard mount point for external file systems.

opt'Typically contains extra and third party software.

proc'

A virtual file system containing information about system resources.

More information about the meaning of the files in proc is obtained by entering the command man proc in a terminal window. The file proc.txt discusses the virtual file system in detail.

root'

The administrative user's home directory. Mind the difference between /, the root directory and /root, the home directory of the root user.

sbin'

Programs for use by the system and the system administrator.

tmp'

Temporary space for use by the system, cleaned upon reboot, so doesn't use this for saving any work!

usr'

Programs, libraries, documentation etc. for all user-related programs.

var'

Storage for all variable files and temporary files created by users, such as log files, the mail queue, the print spooler area, space for temporary storage of files downloaded from the Internet.

3.2.2.4

Scripts

Some scripts developed by Advantech will help you configure system or build the images more quickly. Please check them as follows: setenv.sh

A script to setup the developing environment quickly.

cfg_kernel.sh

A script to configure the kernel building setup quickly.

mk_kernel.sh

A script to build the kernel(uImage) and copy the "uImage" to

"image" and "mk_inand" folders after building.

cfg_uboot.sh

A script to configure the u-boot building setup quickly.

mk_uboot.sh

A script to build the u-boot(u-boot.bin) and copy the "u-boot.bin" to "image" and "mk_inand" folders after building.

3.2.2.5

Source

The source folder contains folder- "linux-2.6.35.3". It is the source code for Linux kernel image.

Linux is a clone of the operating system UNIX. It has all the features you would expect in a modern fully-fledged UNIX, including true multitasking, virtual memory, shared libraries, demand loading, shared copy-on-write executables, proper memory management, and multitask networking including IPv4 and IPv6.

Linux is easily portable to most general-purpose 32- or 64-bit architectures as long as they have a paged memory management unit (PMMU) and a port of the GNU C compiler (gcc) (part of The GNU Compiler Collection, GCC). Linux has also been ported to a number of architectures without a PMMU, although functionality is then obviously somewhat limited. Linux has also been ported to itself. You can now run the kernel as a user space application - this is called User Mode Linux (UML).

RSB-4210 User Manual 46

The main folders contained in "linux-2.6.35.3" are listed as follows: arch'

The items related to hardware platform, most of them are for CPU.

block'

The setting information for block. crypto'

The encryption technology that kernel supports.

Documentation'

The documentation for kernel.

drivers'

The drivers for hardware.

firmware'

Some of firmware data for old hardware.

fs'

The file system the kernel supports.

include'

The header definition for the other programs used. init'

The initial functions for kernel.

ipc'

Define the communication for each program of Linux O.S.

kernel'

Define the Kernel process, status, schedule, signal.

lib'

Some of libraries.

mm'

The data related the memory.

net'

The data related the network.

security'

The security setting.

sound'

The module related audio.

virt'

The data related the virtual machine.

There are plenty of documentation or materials available on the Internet and in books, both Linux-specific and pertaining to general UNIX questions.

And there are various README files in the /linux-2.6.35.3/Documentation: these typically contain kernel-specific installation notes for some drivers for example. See

Documentation/00-INDEX for a list of what is contained in each file.

3.3

Setup Building Environment

All instructions in this guide are for Ubuntu 10.04 LTS. Please install the Ubuntu

10.04 LTS at your PC/NB in advance.

When you got the RSB-4210 Linux source code package, you can refer to the following steps to unzip to your developing environment:

1.

Copy "RSB4210_Linux_BSP.tar.gz" package to your desktop.

2.

Open "Terminal" utility.

3.

Type #sudo su (Change to "root" authority)

4.

Type user password

5.

Type #cd Desktop/

6.

Type #tar xvf RSB4210_Linux_BSP.tar.gz (Unzip file)

7.

Then you can see folder "RSB4210_BSP" on desktop

8.

Finish.

Advantech has written a script to setup the developing environment quickly. You can refer to the following steps to setup your developing environment:

1.

Open "Terminal" utility

2.

Type #sudo su (Change to "root" authority)

3.

Type user password

4.

Type #cd Desktop/RSB4210_BSP/scripts/

5.

Type #. setenv.sh (To configure the developing environment automatically)

6.

Then you can start to code the source code, build images, or compile applications.

47 RSB-4210 User Manual

3.3.1

Setenv.sh

The script "setenv.sh" is mainly used to configure the developing environment quickly. It will configure the important folder paths for system, and you can also add/ modify the setenv.sh by yourself if you have added/changed the folder paths.

The default code of setenv.sh is shown as following:

#!/bin/bash export SRCROOT=${PWD}/..

export CC_PATH=${SRCROOT}/cross_compiler/arm-fsl-linux-gnueabi export CROSS_COMPILE=$CC_PATH/bin/arm-none-linux-gnueabiexport ARCH=arm export KROOT=${SRCROOT}/source/linux-2.6.35.3

export ROOTFS=${SRCROOT}/rootfs export LOG=${SRCROOT}/Build.log

rm -rf ${LOG}

Note!

You have to run "setenv.sh" once you open a new "Terminal" utility every time.

Note!

It is suggested to change to "root" authority to use the source code.

3.4

Building Instructions

This section will guide you how to build the U-boot - "u-boot.bin" and the Linux kernel

- "uImage".

3.4.1

Building U-boot image "u-boot.bin"

Advantech has written a script to build the "u-boot.bin" quickly. You can build the image by referring to the following steps:

1.

Open "Terminal" utility.

2.

Type #sudo su (Change to "root" authority)

3.

Type user password

4.

Type #cd Desktop/RSB4210_BSP/scripts/

5.

Type #. setenv.sh (To configure the developing environment automatically)

6.

Type #. cfg_uboot.sh (To set the u-boot.bin configuration automatically)

7.

Type #. mk_uboot.sh (Start to build the u-boot.bin)

8.

Then you can see "u-boot.bin" under folders "image" and "mk_inand"

9.

Finish.

3.4.2

Building Linux Kernel image "uImage"

Advantech has written a script to build the "uImage" quickly. You can build the image by referring to the following steps:

1.

Open "Terminal" utility.

2.

Type #sudo su (Change to "root" authority)

3.

Type user password

RSB-4210 User Manual 48

4.

Type #cd Desktop/RSB4210_BSP/scripts/

5.

Type #. setenv.sh (To configure the developing environment automatically)

6.

Type #apt-get install libncurses5-dev (To get the menuconfig library)

7.

Type #apt-get install jigit (To get mkimage)

8.

Type #. cfg_kernel.sh (To set the uImage configuration automatically)

9.

Type #. mk_kernel.sh (Start to build the uImage)

10.

Then you can see "uImage" under folders "image" and "mk_inand"

11.

Finish.

3.4.3

Build Log

When an error occurs during building kernel, it will record in this file. This build.log is under folder "/RSB4210_BSP".

3.5

Source Code Modification

This section will guide you how to use the Linux source code. Several examples for source code applications will be shown in this section as well.

3.5.1

Adding a Driver to Kernel by menuconfig

You can add a driver to kernel by menuconfig. Here is an example to guide you adding a RTC driver (Seiko Instruments S-35390A) to Linux kernel. Please refer to the following steps:

Example:

1.

Open "Terminal" utility.

2.

Type #sudo su (Change to "root" authority)

3.

Type user password

4.

Type #cd Desktop/RSB4210_BSP/scripts/

5.

Type #. setenv.sh (To configure the developing environment automatically)

6.

Type #. cfg_kernel.sh menuconfig

7.

Then you will see a GUI screen (Linux Kernel Configuration) as below:

Figure 3.3 Linux Kernel Configuration

49 RSB-4210 User Manual

8.

Go to "Device Drivers"'"Real Time Clock", then you can see the "Seiko Instruments S-35390A" on the list. Select this option then exit and save the configuration.

Figure 3.4 Selecting Seiko Instruments S-35390A

9.

Go to folder "source/linux-2.6.35.3/arch/arm/mach-mx5", and edit the

"mx53_smd.c", to add these codes.

Figure 3.5 Integrate Code for Seiko Instruments S-35390A

10.

Then you can refer to Chapter 3.3.2 to rebuild the kernel with RTC driver (Seiko

Instruments S-35390A).

Note!

If you cannot find any drivers that can drive your hardware, you have to contact with hardware vender.

3.5.2

Changing the Boot Logo

System will show the boot logo when booting up RSB-4210. You can replace the default boot logo with yours by referring to the following steps:

1.

You have to download "netpbm" package firstly, then install it by typing #sudo apt-get install netpbm .

2.

Prepare a picture for boot logo. For example: bootlogo.png (Under folder Desktop/bootlogo)

RSB-4210 User Manual 50

Note!

This picture should be PNG format that under 224 kinds of colors. And it is better when the image resolution and LCD panel size are equal.

3.

Open "Terminal" utility.

4.

Type #cd Desktop/bootlogo (Go into the folder that bootlogo.png located)

5.

Type #pngtopnm bootlogo.png | pnmtoplainpnm > logo_linux_clut224.ppm

6.

Type #cp logo_linux_clut224.ppm /home/user/Desktop/

RSB4210_BSP/source/ linux-2.6.35.3/drivers/video/logo

7.

Then you can refer Chapter 3.3.2 to rebuild the kernel with your own boot logo.

3.6

Making Linux System Booting Media

RSB-4210 supports booting from SD storage card and onboard flash. This section will guide you how to make the Linux system booting media for RSB-4210.

3.6.1

Making a Linux System SD Storage Card

3.6.1.1

From Linux_System_SD Package

When you get the package for making a Linux system SD storage card, you can refer to the following steps to make it for booting, and Advantech has developed a script

"mkmmc-linux.sh)" to help you build the "uImage" quickly.

1.

Copy "RSB4210_Linux_image.tar.gz" package to your desktop.

2.

Open "Terminal" utility.

3.

Type #sudo su (Change to "root" authority)

4.

Type your password.

5.

Type #cd Desktop/

6.

Type #tar xvf RSB4210_Linux_image.tar.gz (Unzip files)

7.

Insert one SD card to your developing computer

8.

Type #df -h 'to check the SD card code name (EX: /dev/sdf)

9.

Type #cd Desktop/RSB-4210_Linux_image

10.

Type #./mkmmc-linux.sh /dev/sdf u-boot.bin uImage rootfs

11.

Type #y (Start to copy files, waiting a few minutes until it shows [Done])

12.

Finish.

Then insert the Linux system SD storage card to CN41 of RSB-4210 and it will boot into Linux environment after powering on the device.

3.6.1.2

From Source Code Package

When you get the RSB-4210 Linux source code package, you can refer to the following steps to make a Linux system SD storage card for booting, and Advantech has written a script "mkmmc-linux.sh" to help you to build the "uImage" quickly.

1.

Open "Terminal" utility.

2.

Type #sudo su (Change to "root" authority)

3.

Type your password.

4.

Insert one SD card to your developing computer

5.

Type #df -h 'to check the SD card code name (EX: /dev/sdf)

6.

Type #cd Desktop/RSB4210_BSP/image/

51 RSB-4210 User Manual

7.

Type #./mkmmc-linux.sh /dev/sdf u-boot.bin uImage ../rootfs

8.

Type #y (Start to copy files, waiting few minutes until it shows [Done])

9.

Finish.

Then insert the Linux system SD storage card to CN41 of RSB-4210 and it will boot into Linux environment when powering up the device.

3.6.2

Booting from Onboard Flash

Another way to boot up RSB-4210 is through onboard flash, which can be realized with the following steps. Besides, the script "mkmmc-linux.sh" will be helpful to build the "uImage" in an efficient way.

1.

Refer to Chapter 3.4.1 to make a Linux system SD storage card

2.

To demount SD card from File Browser and remove it.

3.

Insert this Linux system SD card to RSB-4210 and boot into Linux.

4.

On RSB-4210 platform, type #root (login)

5.

On RSB-4210 platform, type #cd /mk_inand

6.

On RSB-4210 platform, type #sh mkmmc-linux.sh /dev/mmcblk0 u-boot.bin uImage rootfs.tar.gz

7.

On RSB-4210 platform, type #y (Start to copy files, waiting a few minutes until it shows [Done])

8.

Power off and remove this SD card.

9.

Finish.

Now you can boot from onboard flash without SD card.

3.6.3

Booting from SATA DOM

When you get the package for making a Linux system SD storage card, you can refer to the following steps to boot form SATA DOM. The script "mkmmc-linux.sh" will be helpful to build the "uImage".

1.

Refer to Chapter 3.4.1 to make a Linux system SD storage card

2.

To demount SD card from File Browser and remove it.

3.

Insert this Linux system SD card to RSB-4210 and boot into Linux.

4.

On RSB-4210 platform, type #root (login)

5.

On RSB-4210 platform, type #cd /mk_inand

6.

On RSB-4210 platform, type #sh mkmmc-linux.sh /dev/sda u-boot.bin uImage rootfs.tar.gz

7.

On RSB-4210 platform, type #y (Start to copy files, waiting a few minutes until it shows [Done])

8.

Power off and remove this SD card.

9.

Finish.

Now you can boot from onboard flash without SD card.

3.7

Debug Message

RSB-4210 can communicate with a host server (Windows or Linux) by using serial cables. Common serial communication programs such as HyperTerminal, Tera Term or PuTTY can be used in this case. The example as below describes the serial terminal setup using HyperTerminal on a Windows host:

1.

Connect RSB-4210 (UART1, CN27 of RTX-CSB) with your Windows PC by using a serial cable.

2.

Open HyperTerminal on your Windows PC, and select the settings as shown in

Figure 3-6.

RSB-4210 User Manual 52

3.

After the bootloader is programmed on SD card, press "POWER" key to power up the board. The bootloader prompt is displayed on the terminal screen.

Figure 3.6 HyperTerminal Settings for Terminal Setup

3.8

Linux Software Applications on RSB-4210

This section will guide you to develop your own application under Linux. Firstly an example "Hello World" will be shown, and some of the pre-installed applications on

RSB-4210 platform will be introduced in detail then.

3.8.1

Writing Your Own "Hello World!" Application and Executing on RSB-4210

This section will guide you how to write a sample application "Hello World". You can refer to the following steps:

1.

Open "Terminal" utility

2.

Type #sudo su (Change to "root" authority)

3.

Type user password.

4.

Type #cd Desktop/RSB-4210_BSP/scripts/

5.

Type #. setenv.sh (To configure the developing environment automatically)

6.

Type #cd /home/user/Desktop

7.

Type #mkdir helloworld (Create your own work directory on the Desktop)

8.

Type #cd helloworld (Enter the work directory)

9.

Type # gedit helloworld.c (Create a new C source file)

10.

Edit the helloworld.c with the following source code:

#include <stdio.h> void main()

{ printf("Hello World!\n");

}

53 RSB-4210 User Manual

11.

Save the file and exit.

12.

Type #$CC -o helloworld helloworld.c (To compile helloworld.c)

13.

Then you can see "helloworld" in the work directory. (/Desktop/helloworld/)

14.

Insert the Linux system SD card to your developing computer.

15.

Type #cp helloworld /media/rootfs/tool (/media/rootfs is the partition of your Linux system SD card)

16.

Remove this SD card and insert it to RSB-4210 for booting.

17.

On RSB-4210 platform, type #root (login)

18.

On RSB-4210 platform, type #cd /tool

19.

On RSB-4210 platform, type #./helloworld

20.

Finish. A "Hello World!" will be shown on RSB-4210.

3.8.2

Running Pre-installed Applications on RSB-4210

The filesystem comes with a number of pre-installed applications. This section shows how to execute those applications in the provided filesystem.

3.8.2.1

Running QT Demos

There are many QT demo applications at path /usr/share/QT/demos.

Figure 3.7 QT Demo Applications

Below is an example for Fluidlauncher QT demo application. Execute the following commands to run this QT demo application on RSB-4210:

Example:

1.

Type #root (login)

2.

Type #cd /usr/share/QT/demos/embedded/fluidlauncher

3.

Type #./fluidlauncher -qws

4.

Then you can see the Fluidlauncher demo on the LCD panel.

RSB-4210 User Manual 54

Figure 3.8 QT - Fluidlauncher demo

3.8.2.2

Running Audio Demo

Execute the following commands to run the Audio demo application on RSB-4210.

1.

Type #root (login)

2.

Type #cd /unit_tests

3.

Type #aplay audio8k16S.wav

4.

Then you can hear the music from speaker/head-sets.

3.8.2.3

Running Video Demo

Execute the following commands to run the Video demo application on RSB-4210.

1.

Type #root (login)

2.

Type #cd /unit_tests

3.

Type #gplay akiyo.mp4

4.

Then you can watch the video demo on the LCD panel.

Figure 3.9 Video demo

3.8.2.4

Running Photo Demo

Execute the following commands to run the Photo demo application on RSB-4210.

1.

Type #root (login)

2.

Type #cd /tools

3.

Type #./fbv Advantech.JPG

4.

Then you can see the photo demo on the LCD panel.

55 RSB-4210 User Manual

Figure 3.10 Photo demo

3.8.2.5

Running Buzzer Testing

Execute the following commands to test the buzzer function of RSB-4210.

1.

Type #root (login)

2.

Type #cd /tools

3.

Type #./test_buzzer.sh

4.

Then you can hear the buzzer sound from RSB-4210.

3.8.2.6

Running Memory Testing

Execute the following commands to test the memory of RSB-4210.

1.

Type #root (login)

2.

Type #cd /tools

3.

Type #./memtester 10M 1 (Testing Size=10M Bytes; Loop=1 time)

4.

Then system will start to test and show the memory testing result.

RSB-4210 User Manual

Figure 3.11 Result of memory testing

56

3.9

VGA/HDMI Configuration on RSB-4210

In this section, we will introduce how to configure VGA/HDMI on RSB-4210. As depicted in Figure 3-12, IC CH7033B on RSB-410 board will be used for transferring

TTL signal to VGA/HDMI output.

Figure 3.12 Block diagram of video configuration on RSB-4210

There are two output modes for VGA/HDMI signals on RSB-4210 as shown below:

Auto mode: CH7033B controls output timing.

Bypass mode: CPU Freescale i.MX53 controls output timing.

The following sections will introduce each of the output modes in detail.

Note!

Several of resolution settings of your panel might cause the screen output being cut partially. This is due to the panel compatibility limitation. To solve this issue, it would be necessary to finetune the timing for specific resolution settings of your panel.

3.9.1

Auto Mode

Auto mode is the default setting of RSB-4210 VGA/HDMI output. In auto mode, the display interface 0 signal (DI0) has already been modified to output 720P60 (1280 x

720 @ 60) in advance. As illustrated in Table 3-13, there are three default input resolution timing settings for HDMI and one for VGA for reference.

When connecting a HDMI panel with the board, the output resolution of the panel will be adjusted to the most optimal default setting automatically by CH7033B. (For example, if the panel supports 1080P as its max resolution, CH7033B will detect and adjust its output resolution to 1080P after connecting the panel with RSB-4210.)

When connecting a VGA panel with the board, the output resolution of the panel will be adjusted to 1024x768 output resolution no matter what the max resolution your

VGA panel supports is.

Table 3.1: Output Resolution of RSB-4210 Auto Mode

Interface

HDMI

VGA

Resolution

1080P60,720P60,480P60

1024 x 768 @ 60

Note

Auto detection

3.9.2

Bypass Mode

Bypass mode is an output alternative that the output resolution will be determined by default timing settings of your panel. There are 44 built-in timings provided by Advantech on RSB-4210, you can choose either one of them to match the timing setting of

57 RSB-4210 User Manual

your panel. (For example, if your panel supports UXGA60 as its max resolution, you may choose value "2".)

Table 3.2: 44 Built-in Timings of RSB-4210 Bypass Mode

Value Name Pixel Clock Resolution

28

29

30

31

24

25

26

27

20

21

22

23

16

17

18

19

12

13

14

15

8

9

10

11

6

7

4

5

2

3

0

1

36

37

38

39

32

33

34

35

40

41

42

WUXGA60

UXGA60

1080P60

1080P50

1080I60

1080I50

WSXGA+60

SXGA+75

SXGA+60

SXGA85

SXGA75

SXGA60

SXGA50

1280x960P60

1440x900P75

1440x900RDC

1440x900P60

WXGA75

WXGA60

1366x768P60

1366x768CTM

1360x768P60

1280x768P75

1280x768RDC

1280x768VESA

1280x768TV

XGA85

XGA75

XGA70

XGA60

720P60

720P50

WSVGA60

WSVGA_YING

SVGA85

SVGA75

SVGA60

PAL-TV

NTSC-TV

VGA85

VGA75

VGA72

VGA60

79500

80120

94500

78750

75000

65000

74250

74250

106500

106500

71000

76000

72350

85500

102250

68250

101000

157500

135000

108000

75428

108000

136750

88750

154000

162000

148500

148500

74250

74250

119000

156000

47360

45000

56250

49500

40000

27000

27000

36000

31500

31500

25200

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

[email protected]

RSB-4210 User Manual 58

Table 3.2: 44 Built-in Timings of RSB-4210 Bypass Mode

43

44

255

720x400P85

640x400P85

Auto Mode

35500

31500

[email protected]

[email protected]

Furthermore, an auto parameter provided by Advantech can be set to decide which panel is the primary screen (VGA/HDMI or LVDS interface). As listed in Table 3-15, there are three kinds of auto parameters with different limitations, you can choose either one of them to meet your requirements.

Table 3.3: Auto Parameters

Auto Parameter Description

9

19

23

VGA/HDMI and LVDS are the same screen

VGA/HDMI is primary screen,

LVDS is secondary screen

LVDS is primary screen,

VGA/HDMI is secondary screen

Note

This mode only supports

1080P60

LVDS only supports 800x480.

LVDS only supports 800x480.

To change RSB-4210 output to bypass mode (auto mode as default), please refer to the following steps:

1.

Type #root (login)

2.

Type # cd /sys/bus/i2c/drivers/ch7033b/

(Change directory to configure CH7033B)

Figure 3.13 Change directory to configure CH7033B

3.

Type # cat mode (Display all built-in timings)

Figure 3.14 Display all built-in timing settings

59 RSB-4210 User Manual

4.

Type # echo 2 > mode (Configure bypass mode)

Figure 3.15 Bypass mode configuration

Note!

You can choose the value which corresponds with your panel resolution setting. Above is an example for 1920 x 1080p resolution.

5.

Type # echo 19 > auto_video (Use auto parameter function)

Figure 3.16 Auto parameter selection

Note!

You can choose the auto parameter corresponds with your requirement.

Above is an example for VGA/HDMI as primary screen.

6.

Type #reboot (Restart the system)

7.

Finish

3.10

GPIO mapping define on RSB4210

3.10.1

What is a GPIO?

General Purpose Input/Output (GPIO) is a generic pin on a chip whose behavior

(including whether it is an input or output pin) can be controlled (programmed) through software. It is a flexible software-controlled digital signal. They are provided from many kinds of chip, and are familiar to Linux developers working with embedded and custom hardware. Each GPIO represents a bit connected to a particular pin.

Board schematics show which external hardware connects to which GPIOs. Drivers

RSB-4210 User Manual 60

can be written generically, so that board setup code passes such pin configuration data to drivers.

3.10.2

Paths in Sysfs

There are three kinds of entry in /sys/class/gpio:

Control interfaces used to get userspace control over GPIOs;

GPIOs themselves; and

GPIO controllers ("gpio_chip" instances).

That's in addition to standard files including the "device" symlink. The control interfaces are write-only:

/sys/class/gpio/

"export" ... Userspace may ask the kernel to export control of a GPIO to userspace by writing its number to this file.

#echo 19 > export

Will create a "gpio19" node for GPIO #19, if that's not requested by kernel code.

"unexport" ... Reverses the effect of exporting to userspace.

"echo 19 > unexport"

Will remove a "gpio19" node exported using the "export" file.

GPIO signals have paths like /sys/class/gpio/gpio42/ (for GPIO

#42) and have the following read/write attributes:

/sys/class/gpio/gpioN/

"direction"

"value" reads as either "in" or "out". This value may normally be written. Writing as "out" defaults to initializing the value as low. To ensure glitch free operation, values "low" and "high" may be written to configure the

GPIO as an output with that initial value. Note that this attribute *will not exist* if the kernel doesn't support changing the direction of a

GPIO, or it was exported by kernel code that didn't explicitly allow userspace to reconfigure this GPIO's direction.

reads as either 0 (low) or 1 (high). If the GPIOis configured as an output, this value may be written; any nonzero value is treated as high. If the pin can be configured as interrupt-generating interrupt and if it has been configured to generate interrupts (see the description of "edge"), you can poll(2) on that file and poll(2) will return whenever the interrupt was triggered. If you use poll(2), set the events POLLPRI and POL-

LERR. If you use select(2), set the file descriptor in exceptfds. After poll(2) returns, either lseek(2) to the beginning of the sysfs file and read the new value or close the file and re-open it to read the value.

61 RSB-4210 User Manual

"edge" reads as either "none", "rising", "falling", or "both". Write these strings to select the signal edge(s) that will make poll(2) on the "value" file return.

This file exists only if the pin can be configured as aninterrupt generating input pin.

"active_low" reads as either 0 (false) or 1 (true). Write any nonzero value to invert the value attribute both for reading and writing. Existing and subsequent poll(2) support configuration via the edge attribute for "rising" and "falling" edges will follow this setting.

GPIO controllers have paths like /sys/class/gpio/gpiochip42/ (for the controller implementing GPIOs starting at #42) and have the following read-only attributes:

/sys/class/gpio/gpiochipN/

"base" ... same as N, the first GPIO managed by the chip

"label" ... provided for diagnostics (not always unique)

"ngpio" ... how many GPIOs this manges (N to N + ngpio - 1)

Board documentation should in most cases cover what GPIOs are used for what purposes. However, those numbers are not always stable; GPIOs on a daughtercard might be different depending on the base board being used, or other cards in the stack. In such cases, you may need to use the gpiochip nodes (possibly in conjunction with schematics) to determine the correct GPIO number to use for a given signal.

Exporting from Kernel code

Kernel code can explicitly manage exports of GPIOs which have already been requested using gpio_request():

/* export the GPIO to userspace */ int gpio_export(unsigned gpio, bool direction_may_change);

/* reverse gpio_export() */ void gpio_unexport();

/* create a sysfs link to an exported GPIO node */ int gpio_export_link(struct device *dev, const char

*name, unsigned gpio)

/* change the polarity of a GPIO node in sysfs */ int gpio_sysfs_set_active_low(unsigned gpio, int value);

After a kernel driver requests a GPIO, it may only be made available in the sysfs interface by gpio_export(). The driver can control whether the signal direction may change. This helps drivers prevent userspace code from accidentally clobbering important system state.

(More detail please reference "source/linux-2.6.35.3/Documentation/ gpio.txt")

RSB-4210 User Manual 62

3.10.3

GPIO Mapping Table

Logical Number

12

13

14

15

8

9

10

11

16

17

18

19

20

6

7

4

5

1

2

3

ROM-1210

Physical Number

227

228

229

230

231

232

233

234

235

236

237

238

239

149

148

147

33

175

176

226

Logical Number

12

13

14

15

8

9

10

11

16

17

18

19

20

6

7

4

5

1

2

3

RSB-4210

Physical Number

227

228

229

230

231

232

233

234

235

236

237

238

239

176

148

147

33

224

225

226

3.11

Interface Device Reference Documentation

3.11.1

I2C

Usually, i2c devices are controlled by a kernel driver. But it is also possible to access all devices on an adapter from userspace, through the /dev interface. You need to load module i2c-dev for this. Each registered i2c adapter gets a number, counting from 0. You canexamine /sys/class/i2c-dev/ to see what number corresponds to which adapter. Alternatively, you can run "i2cdetect -l" to obtain a formated list of all i2c adapters present on your system at a given time. i2cdetect is part of the i2c-tools package.

I2C device files are character device files with major device number 89 and a minor device number corresponding to the number assigned as explained above. They should be called "i2c-%d" (i2c-0, i2c-1, ..., i2c-10, ...). All 256 minor device numbers are reserved for i2c.

3.11.2

C example

To access an i2c adapter from a C program. The first thing to do is "#include <linux/ i2c-dev.h>". Please note that there are two files named "i2c-dev.h" out there, one is distributed with the Linux kernel and is meant to be included from kernel driver code, the other one is distributed with i2c-tools and is meant to be included from userspace programs. You obviously want the second one here.

Now, you have to decide which adapter you want to access. You should inspect /sys/ class/i2c-dev/ or run "i2cdetect -l" to decide this. Adapter numbers are assigned

63 RSB-4210 User Manual

somewhat dynamically, so you cannot assume much about them. They can even change from one boot to the next.

Next thing, open the device file, as follows:

int file;

int adapter_nr = 2; /* probably dynamically determined */

char filename[20];

snprintf(filename, 19, "/dev/i2c-%d", adapter_nr);

file = open(filename, O_RDWR);

if (file < 0) {

/* ERROR HANDLING; you can check errno to see what went wrong */

exit(1);

}

When you have opened the device, you must specify with what device address you want to communicate:

int addr = 0x40; /* The I2C address */

if (ioctl(file, I2C_SLAVE, addr) < 0) {

/* ERROR HANDLING; you can check errno to see what went wrong */

exit(1);

}

Well, you are all set up now. You can now use SMBus commands or plain I2C to communicate with your device. SMBus commands are preferred if the device supports them. Both are illustrated below.

__u8 register = 0x10; /* Device register to access */

__s32 res;

char buf[10];

/* Using SMBus commands */

res = i2c_smbus_read_word_data(file, register);

if (res < 0) {

/* ERROR HANDLING: i2c transaction failed */

} else {

/* res contains the read word */

}

/* Using I2C Write, equivalent of

i2c_smbus_write_word_data(file, register, 0x6543) */

RSB-4210 User Manual 64

buf[0] = register;

buf[1] = 0x43;

buf[2] = 0x65;

if (write(file, buf, 3) ! =3) {

/* ERROR HANDLING: i2c transaction failed */

}

/* Using I2C Read, equivalent of i2c_smbus_read_byte(file) */

if (read(file, buf, 1) != 1) {

/* ERROR HANDLING: i2c transaction failed */

} else {

/* buf[0] contains the read byte */

}

Note that only a subset of the I2C and SMBus protocols can be achieved by the means of read() and write() calls. In particular, so-called combined transactions (mixing read and write messages in the same transaction) aren't supported. For this reason, this interface is almost never used by user-space programs.

Note!

because of the use of inline functions, you *have* to use '-O' or some variation when you compile your program!

3.11.2.1

Full interface description

The following IOCTLs are defined: ioctl(file, I2C_SLAVE, long addr)

Change slave address. The address is passed in the 7 lower bits of the argument (except for 10 bit addresses, passed in the 10 lower bits in this case).

ioctl(file, I2C_TENBIT, long select)

Selects ten bit addresses if select not equals 0, selects normal 7 bit addresses if select equals 0. Default 0. This request is only valid if the adapter has I2C_FUNC_10BIT_ADDR.

ioctl(file, I2C_PEC, long select)

Selects SMBus PEC (packet error checking) generation and verification if select not equals 0, disables if select equals 0. Default 0. Used only for SMBus transactions.

This request only has an effect if the the adapter has I2C_FUNC_SMBUS_PEC; it is still safe if not, it just doesn't have any effect.

ioctl(file, I2C_FUNCS, unsigned long *funcs)

Gets the adapter functionality and puts it in *funcs.

ioctl(file, I2C_RDWR, struct i2c_rdwr_ioctl_data *msgset)

65 RSB-4210 User Manual

Do combined read/write transaction without stop in between.

Only valid if the adapter has I2C_FUNC_I2C. The argument is a pointer to a

struct i2c_rdwr_ioctl_data {

struct i2c_msg *msgs; /* ptr to array of simple messages

*/

int nmsgs; /* number of messages to exchange

*/

}

The msgs[] themselves contain further pointers into data buffers. The function will write or read data to or from that buffers depending on whether the I2C_M_RD flag is set in a particular message or not. The slave address and whether to use ten bit address mode has to be set in each message, overriding the values set with the above ioctl's.

ioctl(file, I2C_SMBUS, struct i2c_smbus_ioctl_data *args)

Not meant to be called directly; instead, use the access functions

below.

You can do plain i2c transactions by using read(2) and write(2) calls. You do not need to pass the address byte; instead, set it through ioctl I2C_SLAVE before you try to access the device.

You can do SMBus level transactions (see documentation file smbus-protocol for details) through the following functions:

__s32 i2c_smbus_write_quick(int file, __u8 value);

__s32 i2c_smbus_read_byte(int file);

__s32 i2c_smbus_write_byte(int file, __u8 value);

__s32 i2c_smbus_read_byte_data(int file, __u8 command);

__s32 i2c_smbus_write_byte_data(int file, __u8 command, __u8 value);

__s32 i2c_smbus_read_word_data(int file, __u8 command);

__s32 i2c_smbus_write_word_data(int file, __u8 command, __u16 value);

__s32 i2c_smbus_process_call(int file, __u8 command, __u16 value);

__s32 i2c_smbus_read_block_data(int file, __u8 command, __u8 *values);

__s32 i2c_smbus_write_block_data(int file, __u8 command, __u8 length, __u8 *values);

All these transactions return -1 on failure; you can read errno to see what happened.

The 'write' transactions return 0 on success; the 'read' transactions return the read value, except for read_block, which returns the number of values read. The block buffers need not be longer than 32 bytes.

The above functions are all inline functions, that resolve to calls to the i2c_smbus_access function, that on its turn calls a specific ioctl with the data in a specific format. Read the source code if you want to know what happens behind the screens.

RSB-4210 User Manual 66

3.11.2.2

Implementation details

For the interested, here's the code flow which happens inside the kernel when you use the /dev interface to I2C:

1.

Your program opens /dev/i2c-N and calls ioctl() on it, as described in section "C example" above.

2.

These open() and ioctl() calls are handled by the i2c-dev kernel driver: see i2cdev.c:i2cdev_open() and i2c-dev.c:i2cdev_ioctl(), respectively. You can think of i2c-dev as a generic I2C chip driver that can be programmed from user-space.

3.

Some ioctl() calls are for administrative tasks and are handled by i2c-dev directly. Examples include I2C_SLAVE (set the address of the device you want to access) and I2C_PEC (enable or disable SMBus error checking on future transactions.)

4.

Other ioctl() calls are converted to in-kernel function calls by i2c-dev. Examples include I2C_FUNCS, which queries the I2C adapter functionality using i2c.h:i2c_get_functionality(), and I2C_SMBUS, which performs an SMBus transaction using i2c-core.c:i2c_smbus_xfer().

The i2c-dev driver is responsible for checking all the parameters that come from user-space for validity. After this point, there is no difference between these calls that came from user-space through i2c-dev and calls that would have been performed by kernel I2C chip drivers directly. This means that I2C bus drivers don't need to implement anything special to support access from user-space.

5.

These i2c-core.c/i2c.h functions are wrappers to the actual implementation of your I2C bus driver. Each adapter must declare callback functions implementing these standard calls. i2c.h:i2c_get_functionality() calls i2c_adapter.algo->functionality(), while i2c-core.c:i2c_smbus_xfer() calls either adapter.algo-

>smbus_xfer() if it is implemented, or if not, i2c-core.c:i2c_smbus_xfer_emulated() which in turn calls i2c_adapter.algo->master_xfer().

After your I2C bus driver has processed these requests, execution runs up the call chain, with almost no processing done, except by i2c-dev to package the returned data, if any, in suitable format for the ioctl.

More detail please reference "source/linux-2.6.35.3/Documentation/i2c/dev-interface"

3.11.3

UART

3.11.3.1

Driver Interface

open() close() write() put_char() flush_chars() write_room() ioctl()

Called when a device is opened. May sleep

Called when a device is closed. At the point of return from this call the driver must make no further ldisc calls of any kind. May sleep

Called to write bytes to the device. May notsleep. May occur in parallel in special cases. Because this includes panic paths drivers generally shouldn't try and do clever locking here.

Stuff a single character onto the queue. Thedriver is guaranteed following up calls to flush_chars.

Ask the kernel to write put_char queue

Return the number of characters tht can be stuffed into the port buffers without overflow (or less).The ldisc is responsible for being intelligent about multi-threading of write_room/write calls

Called when an ioctl may be for the driver

67 RSB-4210 User Manual

set_termios() set_ldisc()

Called on termios change, serialized against itself by a semaphore. May sleep.

Notifier for discipline change. At the point this is done the discipline is not yet usable. Can now sleep (I think) throttle() unthrottle() stop()

Called by the ldisc to ask the driver to do flow control. Serialization including with unthrottle is the job of the ldisc layer.

Called by the ldisc to ask the driver to stop flow control.

Ldisc notifier to the driver to stop output. As with throttle the serializations with start() are down to the ldisc layer.

Ldisc notifier to the driver to start output.

start() hangup() break_ctl()-

Ask the tty driver to cause a hangup initiated from the host side.

[Can sleep ??]

Send RS232 break. Can sleep. Can get called in parallel, driver must serialize (for now), and with write calls.

wait_until_sent() Wait for characters to exit the hardware queue of the driver. Can sleep send_xchar() Send XON/XOFF and if possible jump the queue with it in order to get fast flow control responses.

3.11.3.2

Line Discipline Methods

(A). Flags

Line discipline methods have access to tty->flags field containing the following interesting flags:

TTY_THROTTLED Driver input is throttled. The ldisc should call tty-

>driver->unthrottle() in order to resume reception when it is ready to process more data.

TTY_DO_WRITE_WAKEUP If set, causes the driver to call the ldisc's write_wakeup() method in order to resume transmission when it can accept more data to transmit.

TTY_IO_ERROR If set, causes all subsequent userspace read/write calls on the tty to fail, returning -EIO.

TTY_OTHER_CLOSED

TTY_NO_WRITE_SPLIT

Device is a pty and the other side has closed.

Prevent driver from splitting up writes into smaller chunks.

(B). Locking

Callers to the line discipline functions from the tty layer are required to take line discipline locks. The same is true of calls from the driver side but not yet enforced.

Three calls are now provided ldisc = tty_ldisc_ref(tty);

Takes a handle to the line discipline in the tty and returns it. If no ldisc is currently attached or the ldisc is being closed and re-opened at this point then NULL is returned. While this handle is held the ldisc will not change or go away.

tty_ldisc_deref(ldisc)

RSB-4210 User Manual 68

Returns the ldisc reference and allows the ldisc to be closed. Returning the reference takes away your right to call the ldisc functions until you take a new reference.

ldisc = tty_ldisc_ref_wait(tty);

Performs the same function as tty_ldisc_ref except that it will wait for an ldisc change to complete and then return a reference to the new ldisc.

While these functions are slightly slower than the old code they should have minimal impact as most receive logic uses the flip buffers and they only need to take a reference when they push bits up through the driver.

Caution! The ldisc->open(), ldisc->close() and driver->set_ldisc functions are called with the ldisc unavailable. Thus tty_ldisc_ref will fail in this situation if used within these functions. Ldisc and driver code calling its own functions must be careful in this case.

3.11.3.3

RS422/RS485 Tips

Transmit RS422/RS458 as soon as setting GPIO 61/62 "high". Receive RS485 as soon as setting GPIO 61/63 low.

3.11.3.4

Software Tips

This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation; either version 2 of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful, but WITHOUT ANY

WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS

FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.

#include <stdarg.h>

#include <termio.h>

#include <sys/timeb.h>

#include <pthread.h>

#include <stdio.h>

#include <string.h>

#include <unistd.h>

#include <fcntl.h>

#include <signal.h>

#include <errno.h>

#include <stdlib.h>

#define DEFAULT_RATE 115200; unsigned int get_time(void)

{

struct timeb tb;

unsigned int realNow;

69 RSB-4210 User Manual

( void ) ftime( &tb );

realNow = (unsigned int )(((tb.time%4290) * 1000000 ) + ( tb.millitm * 1000 ));

return(realNow);

} static speed_t baudrate_map(unsigned long b)

{

speed_t retval;

switch(b)

{

case 110:

retval = B110;

break;

case 300:

retval = B300;

break;

case 1200:

retval = B1200;

break;

case 2400:

retval = B2400;

break;

case 4800:

retval = B4800;

break;

case 9600:

retval = B9600;

break;

case 19200:

retval = B19200;

break;

case 38400:

retval = B38400;

break;

RSB-4210 User Manual 70

case 57600:

retval = B57600;

break;

case 115200:

retval = B115200;

break;

#ifdef B230400

case 230400:

retval = B230400;

break;

#endif

#ifdef B460800

case 460800:

retval = B460800;

break;

#endif

#ifdef B500000

case 500000:

retval = B500000;

break;

#endif

#ifdef B576000

case 576000:

retval = B576000;

break;

#endif

#ifdef B921600

case 921600:

retval = B921600;

break;

#endif

#ifdef B1000000

case 1000000:

retval = B1000000;

break;

#endif

#ifdef B1152000

71 RSB-4210 User Manual

case 1152000:

retval = B1152000;

break;

#endif

#ifdef B1500000

case 1500000:

retval = B1500000;

break;

#endif

#ifdef B2000000

case 2000000:

retval = B2000000;

break;

#endif

#ifdef B2500000

case 2500000:

retval = B2500000;

break;

#endif

#ifdef B3000000

case 3000000:

retval = B3000000;

break;

#endif

#ifdef B3500000

case 3500000:

retval = B3500000;

break;

#endif

#ifdef B4000000

case 4000000:

retval = B4000000;

break;

#endif

default:

retval = 0;

break;

}

RSB-4210 User Manual 72

return(retval);

} int trun, rrun; int fd; int size = 10000; unsigned int tcount, rcount;

FILE *furead; void *Uartsend(void * threadParameter)

{ int *tx; double speed; double time; tcount = 0; tx = malloc(size); memset(tx, 0x0f, size); while(trun) { sleep(1); tx[0] = 0x55; time = get_time(); write(fd, tx, size); time = get_time() - time; speed = size * 8 / (time/1000000); tcount += size; printf("sent %d bytes with speed %fbps\n", size, speed);

} free(tx); return 0;

} void *Uartread(void * threadParameter)

{ char *rx; int iores, iocount; rcount = 0; while(rrun) { iocount = 0; iores = ioctl(fd, FIONREAD, &iocount); if(!iocount) continue;

rx = malloc(iocount);

73 RSB-4210 User Manual

/* Read in and wrap around the list */

iores = read(fd, rx, iocount); rcount += iores; fwrite(rx, 1, iores, furead); free(rx);

} return 0;

} static void print_usage(const char *pname)

{ printf("Usage: %s device [-S] [-O] [-E] [-HW] [-B baudrate]"

"\n\t'-S' for 2 stop bit"

"\n\t'-O' for PARODD "

"\n\t'-E' for PARENB"

"\n\t'-HW' for HW flow control enable" pname);

"\n\t'-B baudrate' for different baudrate\n",

} int main(int argc, char *argv[])

{ int i, ret; struct termios options; unsigned long baudrate = DEFAULT_RATE; char c = 0; pthread_t p_Uartsend, p_Uartread; void *thread_res; if (argc < 2 || strncmp(argv[1], "/dev/ttymxc", 11)) { print_usage(argv[0]); return -1;

} fd = open(argv[1], O_RDWR | O_NOCTTY); if (fd == -1) { printf("open_port: Unable to open serial port - %s", argv[1]); return -1;

} fcntl(fd, F_SETFL, 0);

RSB-4210 User Manual 74

tcgetattr(fd, &options); options.c_cflag &= ~CSTOPB; options.c_cflag &= ~CSIZE; options.c_cflag |= PARENB; options.c_cflag &= ~PARODD; options.c_cflag |= CS8; options.c_cflag &= ~CRTSCTS; options.c_lflag &= ~(ICANON | IEXTEN | ISIG | ECHO); options.c_oflag &= ~OPOST; options.c_iflag &= ~(ICRNL | INPCK | ISTRIP | IXON |

BRKINT ); options.c_cc[VMIN] = 1; options.c_cc[VTIME] = 0; options.c_cflag |= (CLOCAL | CREAD); for(i = 2; i < argc; i++) { if (!strcmp(argv[i], "-S")) { options.c_cflag |= CSTOPB; continue;

} if (!strcmp(argv[i], "-O")) { options.c_cflag |= PARODD; options.c_cflag &= ~PARENB; continue;

} if (!strcmp(argv[i], "-E")) { options.c_cflag &= ~PARODD; options.c_cflag |= PARENB; continue;

} if (!strcmp(argv[i], "-HW")) { options.c_cflag |= CRTSCTS; continue;

} if (!strcmp(argv[i], "-B")) { i++; baudrate = atoi(argv[i]); if(!baudrate_map(baudrate)) baudrate = DEFAULT_RATE; continue;

}

} if(baudrate) { cfsetispeed(&options, baudrate_map(baudrate));

75 RSB-4210 User Manual

cfsetospeed(&options, baudrate_map(baudrate));

} tcsetattr(fd, TCSANOW, &options); printf("UART %lu, %dbit, %dstop, %s, HW flow %s\n", baudrate, 8,

(options.c_cflag & CSTOPB) ? 2 : 1,

(options.c_cflag & PARODD) ? "PARODD" : "PARENB",

(options.c_cflag & CRTSCTS) ? "enabled" : "disabled"); trun = 1; rrun = 1; furead = fopen("uart_read.txt","wb"); ret = pthread_create(&p_Uartsend, NULL, Uartsend, NULL); if(ret < 0) goto error; ret = pthread_create(&p_Uartread, NULL, Uartread, NULL); if(ret < 0) { ret = pthread_join(p_Uartsend, &thread_res); goto error;

} printf("test begin, press 'c' to exit\n"); while(c != 'c'){ c = getchar();

} trun = 0; ret = pthread_join(p_Uartsend, &thread_res); if(ret < 0) printf("fail to stop Uartsend thread\n"); printf("tcount=%d\n",tcount); i = 5; while((tcount > rcount) && i) { i--; sleep(1);

} rrun = 0; ret = pthread_join(p_Uartread, &thread_res); if(ret < 0) printf("fail to stop Uartread thread\n"); printf("rcount=%d\n",rcount); error: fclose(furead);

RSB-4210 User Manual 76

close(fd); printf("test exit\n"); return 0;

}

(More detail please reference "source/linux-2.6.35.3/Documentation/serial/tty.txt")

3.11.4

CAN bus

CAN bus is a set of open source CAN drivers and a networking stack contributed byVolkswagen Research to the Linux kernel. Formerly known as Low Level CAN

Framework (LLCF).

Typical CAN communication layers. With SocketCAN (left) or conventional (right).

Traditional CAN drivers for Linux are based on the model of character devices. Typically they only allow sending to and receiving from the CAN controller. Conventional implementations of this class of device driver only allow a single process to access the device, which means that all other processes are blocked in the meantime. In addition, these drivers typically all differ slightly in the interface presented to the application, stifling portability. The SocketCAN concept on the other hand uses the model of network devices, which allows multiple applications to access one CAN device simultaneously. Also, a single application is able to access multiple CAN networks in parallel.

The application first sets up its access to the CAN interface by initialising a socket

(much like in TCP/IP communications), then binding that socket to an interface (or all interfaces, if the application so desires). Once bound, the socket can then be used like a UDP socket via read, write, etc...

The following is a simple (incomplete) example, that sends a packet, then reads back a packet using the raw interface. It is based on the notes documented in the Linux

Kernel.

#include <can_config.h>

#include <getopt.h>

#include <libgen.h>

77 RSB-4210 User Manual

#include <signal.h>

#include <stdio.h>

#include <stdlib.h>

#include <string.h>

#include <unistd.h>

#include <limits.h>

#include <net/if.h>

#include <sys/ioctl.h>

#include <sys/socket.h>

#include <sys/types.h>

#include <sys/uio.h>

#include <time.h>

#include <sys/time.h>

#include <linux/can.h>

#include <linux/can/raw.h> extern int optind, opterr, optopt; static void print_usage(char *prg)

{ fprintf(stderr,

"Usage: %s [<can-interface>] [Options] <can-msg>\n"

"<can-msg> can consist of up to 8 bytes given as a space separated list\n"

"Options:\n"

" -i, --identifier=IDCAN Identifier (default = 1)\n"

" -r --rtrsend remote request\n"

" -e --extendedsend extended frame\n"

" -f, --family=FAMILYProtocol

PF_CAN = %d)\n" family (default

(default SOCK_RAW = %d)\n"

" -p, --protocol=PROTOCAN protocol (default CAN_RAW

= %d)\n"

" -l send message infinite times\n"

" --loop=COUNTsend message COUNT times\n"

" -v, --verbosebe verbose\n"

" -h, --helpthis help\n"

" -R, --relayRelay Packet\n"

" --versionprint version information and exit\n", prg, PF_CAN, SOCK_RAW, CAN_RAW);

}

RSB-4210 User Manual 78

enum {

VERSION_OPTION = CHAR_MAX + 1,

}; void sigalrm_fn(int sig)

{ printf("CAN Bus Error\n"); exit(1);

} int main(int argc, char **argv)

{ struct can_frame frame = {

.can_id = 1,

}; struct ifreq ifr; struct sockaddr_can addr; char *interface; int family = PF_CAN, type = SOCK_RAW, proto = CAN_RAW; int loopcount = 1, infinite = 0; int s, opt, ret, i, rtr = 0, extended = 0,Relay=0; int verbose = 0; unsigned char test_pattern[8]; struct option long_options[] = {

{ "help",no_argument,0, 'h' },

{ "identifier",required_argument,0, 'i' },

{ "rtr",no_argument,0, 'r' },

{ "extended",no_argument,0, 'e' },

{ "family",required_argument,0, 'f' },

{ "protocol",required_argument,0, 'p' },

{ "type",required_argument,0, 't' },

{ "version",no_argument,0, VERSION_OPTION},

{ "verbose",no_argument,0, 'v'},

{ "loop",required_argument,0, 'l'},

{ "relay",no_argument,0, 'R'},

{ 0, 0, 0, 0 },

}; while ((opt = getopt_long(argc, argv, "hf:t:p:vi:lreR", long_options, NULL)) != -1) { switch (opt) { case 'h': print_usage(basename(argv[0])); exit(0); case 'f': family = strtoul(optarg, NULL, 0);

79 RSB-4210 User Manual

break; case 't': type = strtoul(optarg, NULL, 0); break; case 'p': proto = strtoul(optarg, NULL, 0); break; case 'v': verbose = 1; break; case 'l': if (optarg) loopcount = strtoul(optarg, NULL, 0); else infinite = 1; break; case 'i': frame.can_id = strtoul(optarg, NULL, 0); break; case 'r': rtr = 1; break; case 'e': extended = 1; break; case 'R':

Relay=1; break; case VERSION_OPTION: printf("cansend %s\n", VERSION); exit(0); default: fprintf(stderr, "Unknown option %c\n", opt); break;

}

} if (optind == argc) {

RSB-4210 User Manual 80

print_usage(basename(argv[0])); exit(0);

} if (argv[optind] == NULL) { fprintf(stderr, "No Interface supplied\n"); exit(-1);

} interface = argv[optind];

%d\n", printf("interface = %s, family = %d, type = %d, proto =

interface, family, type, proto); s = socket(family, type, proto); if (s < 0) { perror("socket"); return 1;

} addr.can_family = family; strcpy(ifr.ifr_name, interface); if (ioctl(s, SIOCGIFINDEX, &ifr)) { perror("ioctl"); return 1;

} addr.can_ifindex = ifr.ifr_ifindex;

{ if (bind(s, (struct sockaddr *)&addr, sizeof(addr)) < 0) perror("bind"); return 1;

}

/*set alarm to sigalrm_fm*/ signal(SIGALRM, sigalrm_fn); srand(time(NULL)); if (extended) { frame.can_id &= CAN_EFF_MASK; frame.can_id |= CAN_EFF_FLAG;

} else { frame.can_id &= CAN_SFF_MASK;

}

81 RSB-4210 User Manual

if (rtr) frame.can_id |= CAN_RTR_FLAG; if (verbose) { printf("id: %d ", frame.can_id); printf("dlc: %d\n", frame.can_dlc); for (i = 0; i < frame.can_dlc; i++) printf("0x%02x ", frame.data[i]); printf("\n");

}

// if(!Relay)

{

/*set 10 seconds to alarm */ alarm(10); while (infinite || loopcount--) { for (i= 0 ;i<8;i++) test_pattern[i]=random()%255; test_pattern[i]=0xFF; printf("Send Data :"); for (i = 0; i < 8; i++) { printf("%d ",test_pattern[i]); frame.data[i] = test_pattern[i];

} printf("\n"); frame.can_dlc = 8; can_frame)); ret = write(s, &frame, sizeof(struct if (ret == -1) { perror("write"); break;

}

/*clear buffer*/ for (i = 0; i < 8; i++) { frame.data[i] = 0;

}

/* receice relay packet*/ if ((read(s, &frame, sizeof(struct can_frame)))

< 0) { perror("read"); return 1;

} else {

RSB-4210 User Manual 82

printf("Receive data: "); for(i =0; i<8 ;i++)

{ printf("%d ",frame.data[i]); if(frame.data[i] != test_pattern[i])

{ printf("CAN Bus Error\n"); return 1;

}

} printf("\n");

}

}

} else /*relay packet*/

{ int nBytes; while(1)

{ if ((nBytes=read(s,&frame, sizeof(struct can_frame))) < 0) { perror("read"); return 1;

} else { printf("Receive data: "); for(i=0;i<8;i++) printf("%d ",frame.data[i]); printf("\n"); write(s, &frame, sizeof(struct can_frame));

}

} close(s);

} return 0;

}

(More detail please reference "source/linux-2.6.35.3/Documentation/networking/ can.txt")

3.11.5

SD card /iNand /USB Disk/SATA Disk

SD-Cards, iNand, USB, and SATA Mass Storage devices are not mounted automatically in Linux systems. In order to access them, they have to be mounted manually from the console, using their devices nodes. The SD Card and iNand can be found under /dev/mmcblk0 and /dev/mmcblk1. its single partitions are located under /dev/ mmcblk0pX with X being a positive number. The USB and SATA mass storage devices can be found under /dev/sdX with X=a..z, its single partitions under /dev/ sdXY with Y being a positive number as table below:

83 RSB-4210 User Manual

SD card iNand

USB Disk

SATA Disk

/dev/mmcblk1

/dev/mmcblk0

/dev/sdx

/dev/sdx

You can use open/close/write/read functions to control this storage.

3.11.6

LAN

Refer to Socket Programming (http://www.tenouk.com/cnlinuxsockettutorials.html)

3.11.7

RTC

Because Linux supports many non-ACPI and non-PC platforms, some of which have more than one RTC style clock, it needed a more portable solution than expecting a single battery-backed MC146818 clone on every system. Accordingly, a new "RTC

Class" framework has been defined. It offers three different userspace interfaces:

* /dev/rtcN ... much the same as the older /dev/rtc interface

*/sys/class/rtc/rtcN...sysfs attributes support readonly access to some RTC attributes.

* /proc/driver/rtc ... the first RTC (rtc0) may expose itself using a procfs interface.

More information is (currently) shown here than through sysfs.

The RTC Class framework supports a wide variety of RTCs, ranging from those integrated into embeddable system-on-chip (SOC) processors to discrete chips using

I2C, SPI, or some other bus to communicate with the host CPU. There's even support for PC-style RTCs ... including the features exposed on newer PCs through

ACPI.

The new framework also removes the "one RTC per system" restriction. For example, maybe the low-power battery-backed RTC is a discrete I2C chip, but a high functionality RTC is integrated into the SOC. That system might read the system clock from the discrete RTC, but use the integrated one for all other tasks, because of its greater functionality.

3.11.7.1

SYSFS INTERFACE

The sysfs interface under /sys/class/rtc/rtcN provides access to various rtc attributes without requiring the use of ioctls. All dates and times are in the RTC's timezone, rather than in system time.

date: hctosys:

RTC-provided date max_user_freq:

1 if the RTC provided the system time at boot via the

CONFIG_RTC_HCTOSYS kernel option, 0 otherwise

The maximum interrupt rate an unprivileged user may request from this RTC.

name: since_epoch: time:

The name of the RTC corresponding to this sysfs directory

The number of seconds since the epoch according to the RTC

RTC-provided time

RSB-4210 User Manual 84

wakealarm: The time at which the clock will generate a system wakeup event. This is a one shot wakeup event, so must be reset after wake if a daily wakeup is required. Format is either seconds since the epoch or, if there's a leading +, seconds in the future.

IOCTL INTERFACE

---------------

The ioctl() calls supported by /dev/rtc are also supported by the RTC class framework. However, because the chips and systems are not standardized, some PC/AT functionality might not be provided. And in the same way, some newer features -including those enabled by ACPI -- are exposed by the RTC class framework, but can't be supported by the older driver.

* RTC_RD_TIME, RTC_SET_TIME ... every RTC supports at least reading time, returning the result as a Gregorian calendar date and 24 hour wall clock time.

To be most useful, this time may also be updated.

* RTC_AIE_ON, RTC_AIE_OFF, RTC_ALM_SET, RTC_ALM_READ ... when the RTC is connected to an IRQ line, it can often issue an alarm IRQ up to 24 hours in the future. (Use RTC_WKALM_* by preference.)

* RTC_WKALM_SET, RTC_WKALM_RD ... RTCs that can issue alarms beyond the next 24 hours use a slightly more powerful API, which supports setting the longer alarm time and enabling its IRQ using a single request (using the same model as EFI firmware).

* RTC_UIE_ON, RTC_UIE_OFF ... if the RTC offers IRQs, it probably also offers update IRQs whenever the "seconds" counter changes. If needed, the RTC framework can emulate this mechanism.

* RTC_PIE_ON, RTC_PIE_OFF, RTC_IRQP_SET, RTC_IRQP_READ ...

another feature often accessible with an IRQ line is a periodic IRQ, issued at settable frequencies (usually 2^N Hz).

In many cases, the RTC alarm can be a system wake event, used to force Linux out of a low power sleep state (or hibernation) back to a fully operational state. For example, a system could enter a deep power saving state until it's time to execute some scheduled tasks.

Note that many of these ioctls need not actually be implemented by your driver. The common rtc-dev interface handles many of these nicely if your driver returns ENOIO-

CTLCMD. Some common examples:

* RTC_RD_TIME, RTC_SET_TIME: the read_time/set_time functions will be called with appropriate values.

* RTC_ALM_SET, RTC_ALM_READ, RTC_WKALM_SET,

RTC_WKALM_RD: the set_alarm/read_alarm functions will be called.

85 RSB-4210 User Manual

* RTC_IRQP_SET, RTC_IRQP_READ: the irq_set_freq function will be called to set the frequency while the framework will handle the read for you since the frequency is stored in the irq_freq member of the rtc_device structure. Your driver needs to initialize the irq_freq member during init. Make sure you check the requested frequency is in range of your hardware in the irq_set_freq function. If it isn't, return -EINVAL. If you cannot actually change the frequency, do not define irq_set_freq.

* RTC_PIE_ON, RTC_PIE_OFF: the irq_set_state function will be called.

If all else fails, check out the rtc-test.c driver!

/****************************************************

/* Real Time Clock Driver Test/Example Program

/* Compile with:*gcc -s -Wall -Wstrict-prototypes rtctest.c -o rtctest

/* Released under the GNU General Public License, version 2,

/* included herein by reference.

/* ****************************************************/

#include <stdio.h>

#include <linux/rtc.h>

#include <sys/ioctl.h>

#include <sys/time.h>

#include <sys/types.h>

#include <fcntl.h>

#include <unistd.h>

#include <stdlib.h>

#include <errno.h>

/*

* This expects the new RTC class driver framework, working with

* clocks that will often not be clones of what the PC-AT had.

* Use the command line to specify another RTC if you need one.

*/ static const char default_rtc[] = "/dev/rtc0"; int main(int argc, char **argv)

{ int i, fd, retval, irqcount = 0; unsigned long tmp, data; struct rtc_time rtc_tm; const char *rtc = default_rtc; switch (argc) {

RSB-4210 User Manual 86

case 2: rtc = argv[1];

/* FALLTHROUGH */ case 1: break; default: fprintf(stderr, "usage: rtctest [rtcdev]\n"); return 1;

} fd = open(rtc, O_RDONLY); if (fd == -1) { perror(rtc); exit(errno);

} fprintf(stderr, "\n\t\t\tRTC Driver Test Example.\n\n");

/* Turn on update interrupts (one per second) */ retval = ioctl(fd, RTC_UIE_ON, 0); if (retval == -1) { if (errno == ENOTTY) { fprintf(stderr,

"\n...Update IRQs not supported.\n"); goto test_READ;

} perror("RTC_UIE_ON ioctl"); exit(errno);

} fprintf(stderr, "Counting 5 update (1/sec) interrupts from reading %s:", rtc); fflush(stderr); for (i=1; i<6; i++) {

/* This read will block */ retval = read(fd, &data, sizeof(unsigned long)); if (retval == -1) { perror("read"); exit(errno);

} fprintf(stderr, " %d",i); fflush(stderr); irqcount++;

}

87 RSB-4210 User Manual

rtc:"); fprintf(stderr, "\nAgain, from using select(2) on /dev/ fflush(stderr); for (i=1; i<6; i++) { struct timeval tv = {5, 0}; /* 5 second timeout on select */ fd_set readfds;

FD_ZERO(&readfds);

FD_SET(fd, &readfds);

/* The select will wait until an RTC interrupt happens. */ above. */ retval = select(fd+1, &readfds, NULL, NULL, &tv); if (retval == -1) {

perror("select");

exit(errno);

}

/* This read won't block unlike the select-less case retval = read(fd, &data, sizeof(unsigned long)); if (retval == -1) {

perror("read");

exit(errno);

} fprintf(stderr, " %d",i); fflush(stderr); irqcount++;

}

/* Turn off update interrupts */ retval = ioctl(fd, RTC_UIE_OFF, 0); if (retval == -1) { perror("RTC_UIE_OFF ioctl"); exit(errno);

} test_READ:

/* Read the RTC time/date */ retval = ioctl(fd, RTC_RD_TIME, &rtc_tm); if (retval == -1) { perror("RTC_RD_TIME ioctl"); exit(errno);

} fprintf(stderr, "\n\nCurrent RTC date/time is %d-%d-%d,

%02d:%02d:%02d.\n",

RSB-4210 User Manual 88

1900, rtc_tm.tm_mday, rtc_tm.tm_mon + 1, rtc_tm.tm_year + rtc_tm.tm_hour, rtc_tm.tm_min, rtc_tm.tm_sec);

/* Set the alarm to 5 sec in the future, and check for rollover */ rtc_tm.tm_sec += 5; if (rtc_tm.tm_sec >= 60) { rtc_tm.tm_sec %= 60; rtc_tm.tm_min++;

} if (rtc_tm.tm_min == 60) { rtc_tm.tm_min = 0; rtc_tm.tm_hour++;

} if (rtc_tm.tm_hour == 24) rtc_tm.tm_hour = 0; retval = ioctl(fd, RTC_ALM_SET, &rtc_tm); if (retval == -1) { if (errno == ENOTTY) { fprintf(stderr,

"\n...Alarm IRQs not supported.\n"); goto test_PIE;

} perror("RTC_ALM_SET ioctl"); exit(errno);

}

/* Read the current alarm settings */ retval = ioctl(fd, RTC_ALM_READ, &rtc_tm); if (retval == -1) { perror("RTC_ALM_READ ioctl"); exit(errno);

} fprintf(stderr, "Alarm time now set to

%02d:%02d:%02d.\n", rtc_tm.tm_hour, rtc_tm.tm_min, rtc_tm.tm_sec);

/* Enable alarm interrupts */ retval = ioctl(fd, RTC_AIE_ON, 0); if (retval == -1) { perror("RTC_AIE_ON ioctl"); exit(errno);

}

89 RSB-4210 User Manual

*/ fprintf(stderr, "Waiting 5 seconds for alarm..."); fflush(stderr);

/* This blocks until the alarm ring causes an interrupt retval = read(fd, &data, sizeof(unsigned long)); if (retval == -1) { perror("read"); exit(errno);

} irqcount++; fprintf(stderr, " okay. Alarm rang.\n");

/* Disable alarm interrupts */ retval = ioctl(fd, RTC_AIE_OFF, 0); if (retval == -1) { perror("RTC_AIE_OFF ioctl"); exit(errno);

} test_PIE:

/* Read periodic IRQ rate */ retval = ioctl(fd, RTC_IRQP_READ, &tmp); if (retval == -1) {

/* not all RTCs support periodic IRQs */ if (errno == ENOTTY) { fprintf(stderr, "\nNo periodic IRQ support\n"); goto done;

} perror("RTC_IRQP_READ ioctl"); exit(errno);

} fprintf(stderr, "\nPeriodic IRQ rate is %ldHz.\n", tmp); fprintf(stderr, "Counting 20 interrupts at:"); fflush(stderr);

/* The frequencies 128Hz, 256Hz, ... 8192Hz are only allowed for root. */ for (tmp=2; tmp<=64; tmp*=2) { rate */ retval = ioctl(fd, RTC_IRQP_SET, tmp); if (retval == -1) {

/* not all RTCs can change their periodic IRQ if (errno == ENOTTY) { fprintf(stderr,

RSB-4210 User Manual 90

long));

"\n...Periodic IRQ rate is fixed\n"); goto done;

} perror("RTC_IRQP_SET ioctl"); exit(errno);

} fprintf(stderr, "\n%ldHz:\t", tmp); fflush(stderr);

/* Enable periodic interrupts */ retval = ioctl(fd, RTC_PIE_ON, 0); if (retval == -1) { perror("RTC_PIE_ON ioctl"); exit(errno);

} for (i=1; i<21; i++) {

/* This blocks */ retval = read(fd, &data, sizeof(unsigned if (retval == -1) { perror("read"); exit(errno);

} fprintf(stderr, " %d",i); fflush(stderr); irqcount++;

}

/* Disable periodic interrupts */ retval = ioctl(fd, RTC_PIE_OFF, 0); if (retval == -1) { perror("RTC_PIE_OFF ioctl"); exit(errno);

}

} done: fprintf(stderr, "\n\n\t\t\t *** Test complete ***\n"); close(fd); return 0;

}

More detail please reference "source/linux-2.6.35.3/Documentation/rtc.txt"

91 RSB-4210 User Manual

3.11.8

WatchDog

Usually an userspace daemon will notify the kernel watchdog driver via the/dev/ watchdog special device file that userspace is still alive, at regular intervals. When such a notification occurs, the driver will usually tell the hardware watchdog that everything is in order, and that the watchdog should wait for yet another little while to reset the system. If userspace fails (RAM error, kernel bug, whatever), the notifications cease to occur, and the hardware watchdog will reset the system (causing a reboot) after the timeout occurs.

3.11.8.1

The Simplest API

All drivers support the basic mode of operation, where the watchdog activates as soon as /dev/watchdog is opened and will reboot unless the watchdog is pinged within a certain time, this time is called the timeout or margin. The simplest way to ping the watchdog is to write some data to the device. So a very simple watchdog daemon would look like this source file as below:

#include <stdio.h>

#include <stdlib.h>

#include <unistd.h>

#include <fcntl.h> int main(void)

{ int fd = open("/dev/watchdog", O_WRONLY); int ret = 0; if (fd == -1) { perror("watchdog"); exit(EXIT_FAILURE);

} while (1) { ret = write(fd, "\0", 1); if (ret != 1) { ret = -1; break;

} sleep(10);

} close(fd); return ret;

}

3.11.8.2

Magic Close feature

If a driver supports "Magic Close", the driver will not disable the watchdog unless a specific magic character 'V' has been sent to /dev/watchdog just before closing the file. If the userspace daemon closes the file without sending this special character, the driver will assume that the daemon (and userspace in general) died, and will stop pinging the watchdog without disabling it first. This will then cause a reboot if the watchdog is not re-opened in sufficient time.

RSB-4210 User Manual 92

3.11.8.3

The ioctl API

All conforming drivers also support an ioctl API.

Pinging the watchdog using an ioctl:

All drivers that have an ioctl interface support at least one ioctl, KEEPALIVE. This ioctl does exactly the same thing as a write to the watchdog device, so the main loop in the above program could be replaced with: while (1) { ioctl(fd, WDIOC_KEEPALIVE, 0); sleep(10);

} the argument to the ioctl is ignored.

Setting and getting the timeout:

For some drivers it is possible to modify the watchdog timeout on the fly with the

SETTIMEOUT ioctl, those drivers have the WDIOF_SETTIMEOUT flag set in their option field. The argument is an integer representing the timeout in seconds. The driver returns the real timeout used in the same variable, and this timeout might differ from the requested one due to limitation of the hardware.

int timeout = 45;

ioctl(fd, WDIOC_SETTIMEOUT, &timeout);

printf("The timeout was set to %d seconds\n", timeout);

This example might actually print "The timeout was set to 60 seconds" if the device has a granularity of minutes for its timeout.

Starting with the Linux 2.4.18 kernel, it is possible to query the current timeout using the GETTIMEOUT ioctl.

ioctl(fd, WDIOC_GETTIMEOUT, &timeout);

printf("The timeout was is %d seconds\n", timeout);

3.11.8.4

Pretimeouts:

Some watchdog timers can be set to have a trigger go off before the actual time they will reset the system. This can be done with an NMI, interrupt, or other mechanism.

This allows Linux to record useful information (like panic information and kernel coredumps) before it resets.

pretimeout = 10;

ioctl(fd, WDIOC_SETPRETIMEOUT, &pretimeout);

Note that the pretimeout is the number of seconds before the time when the timeout will go off. It is not the number of seconds until the pretimeout. So, for instance, if you set the timeout to 60 seconds and the pretimeout to 10 seconds, the pretimout will go of in 50 seconds. Setting a pretimeout to zero disables it.

93 RSB-4210 User Manual

There is also a get function for getting the pretimeout:

ioctl(fd, WDIOC_GETPRETIMEOUT, &timeout);

printf("The pretimeout was is %d seconds\n", timeout);

Not all watchdog drivers will support a pretimeout.

Get the number of seconds before reboot:

Some watchdog drivers have the ability to report the remaining time before the system will reboot. The WDIOC_GETTIMELEFT is the ioctl that returns the number of seconds before reboot.

ioctl(fd, WDIOC_GETTIMELEFT, &timeleft);

printf("The timeout was is %d seconds\n", timeleft);

3.11.8.5

Environmental monitoring:

All watchdog drivers are required return more information about the system, some do temperature, fan and power level monitoring, some can tell you the reason for the last reboot of the system. The GETSUPPORT ioctl is available to ask what the device can do: struct watchdog_info ident; ioctl(fd, WDIOC_GETSUPPORT, &ident); the fields returned in the ident struct are: identity firmware_version a string identifying the watchdog driver the firmware version of the card if available options a flags describing what the device supports

WDIOF_OVERHEAT Reset due to CPU overheat

The machine was last rebooted by the watchdog because the thermal limit was exceeded

WDIOF_FANFAULT Fan failed

A system fan monitored by the watchdog card has failed

WDIOF_EXTERN1 External relay 1

External monitoring relay/source 1 was triggered. Controllers intended for real world applications include external monitoring pins that will trigger a reset.

WDIOF_EXTERN2 External relay 2

External monitoring relay/source 2 was triggered

RSB-4210 User Manual 94

WDIOF_POWERUNDER Power bad/power fault

The machine is showing an undervoltage status

WDIOF_CARDRESET Card previously reset the CPU

The last reboot was caused by the watchdog card

WDIOF_POWEROVER Power over voltage

The machine is showing an overvoltage status. Note that if one level is under and one over both bits will be set - this may seem odd but makes sense.

WDIOF_KEEPALIVEPING Keep alive ping reply

The watchdog saw a keepalive ping since it was last queried.

WDIOF_SETTIMEOUT

The watchdog can do pretimeouts.

Can set/get the timeout

WDIOF_PRETIMEOUT Pretimeout (in seconds), get/set

For those drivers that return any bits set in the option field, the GETSTATUS and

GETBOOTSTATUS ioctls can be used to ask for the current status, and the status at the last reboot, respectively.

int flags;

ioctl(fd, WDIOC_GETSTATUS, &flags);

or

ioctl(fd, WDIOC_GETBOOTSTATUS, &flags);

Note that not all devices support these two calls, and some only support the GET-

BOOTSTATUS call.

Some drivers can measure the temperature using the GETTEMP ioctl. The returned value is the temperature in degrees fahrenheit.

int temperature;

ioctl(fd, WDIOC_GETTEMP, &temperature);

Finally the SETOPTIONS ioctl can be used to control some aspects of the cards operation.

int options = 0;

95 RSB-4210 User Manual

ioctl(fd, WDIOC_SETOPTIONS, &options);

The following options are available:

WDIOS_DISABLECARDTurn off the watchdog timer

WDIOS_ENABLECARDTurn on the watchdog timer

WDIOS_TEMPPANICKernel panic on temperature trip

More detail please reference "source/linux-2.6.35.3/Documentation/watchdog/watchdog-api.txt"

3.11.9

Audio

3.11.9.1

Kernel Configuration

To enable ALSA support you need at least to build the kernel with primary sound card support (CONFIG_SOUND). Since ALSA can emulate OSS, you don't have to choose any of the OSS modules.

Enable "OSS API emulation" (CONFIG_SND_OSSEMUL) and both OSS mixer and

PCM supports if you want to run OSS applications with ALSA.

If you want to support the WaveTable functionality on cards such as SB Live! then you need to enable "Sequencer support" (CONFIG_SND_SEQUENCER).

To make ALSA debug messages more verbose, enable the "Verbose printk" and

"Debug" options. To check for memory leaks, turn on "Debug memory" too. "Debug detection" will add checks for the detection of cards.

Please note that all the ALSA ISA drivers support the Linux isapnp API (if the card supports ISA PnP). You don't need to configure the cards using isapnptools.

3.11.9.2

Creating ALSA Devices

This depends on your distribution, but normally you use the /dev/MAKEDEV script to create the necessary device nodes. On some systems you use a script named 'snddevices'.

3.11.9.3

Module Parameters

The user can load modules with options. If the module supports more than one card and you have more than one card of the same type then you can specify multiple values for the option separated by commas.

More detail please reference "source/linux-2.6.35.3/Documentation/sound/alsa/

ALSA-Configuration.txt"

3.11.10

Keypad/Touchscreen

3.11.10.1

Introduction

This is a collection of drivers that is designed to support all input devices under Linux.

While it is currently used only on for USB input devices, future use (say 2.5/2.6) is expected to expand to replace most of the existing input system, which is why it lives in drivers/input/ instead of drivers/usb/.

The centre of the input drivers is the input module, which must be loaded before any other of the input modules - it serves as a way of communication between two groups of modules:

A. Device drivers

RSB-4210 User Manual 96

These modules talk to the hardware (for example via USB), and provide events

(keystrokes, mouse movements) to the input module.

B. Event handlers

These modules get events from input and pass them where needed via various interfaces - keystrokes to the kernel, mouse movements via a simulated PS/2 interface to GPM and X and so on.

3.11.10.2

Simple Usage

For the most usual configuration, with one USB mouse and one USB keyboard, you'll have to load the following modules (or have them built in to the kernel): input mousedev keybdev usbcore uhci_hcd or ohci_hcd or ehci_hcd usbhid

After this, the USB keyboard will work straight away, and the USB mouse will be available as a character device on major 13, minor 63: mice crw-r--r-- 1 root root 13, 63 Mar 28 22:45

This device has to be created.

The commands to create it by hand are: cd /dev mkdir input mknod input/mice c 13 63

After that you have to point GPM (the textmode mouse cut&paste tool) and XFree to this device to use it - GPM should be called like:

And in X: gpm -t ps2 -m /dev/input/mice

Section "Pointer"

Protocol "ImPS/2"

Device "/dev/input/mice"

ZAxisMapping 4 5

EndSection

When you do all of the above, you can use your USB mouse and keyboard.

3.11.10.3

Detailed Description

1.

Device drivers

97 RSB-4210 User Manual

Device drivers are the modules that generate events. The events are however not useful without being handled, so you also will need to use some of the modules from section 3.10.9.3.2.

A. usbhid

usbhid is the largest and most complex driver of the whole suite. It handles all HID devices, and because there is a very wide variety of them, and because the USB

HID specification isn't simple, it needs to be this big.

Currently, it handles USB mice, joysticks, gamepads, steering wheels keyboards, trackballs and digitizers.

However, USB uses HID also for monitor controls, speaker controls, UPSs, LCDs and many other purposes.

The monitor and speaker controls should be easy to add to the hid/input interface, but for the UPSs and LCDs it doesn't make much sense. For this, the hiddev interface was designed. See Documentation/usb/hiddev.txt for more information about it.

The usage of the usbhid module is very simple, it takes no parameters, detects everything automatically and when a HID device is inserted, it detects it appropriately.

However, because the devices vary wildly, you might happen to have a device that doesn't work well. In that case #define DEBUG at the beginning of hid-core.c and send me the syslog traces.

B. usbmouse

For embedded systems, for mice with broken HID descriptors and just any other use when the big usbhid wouldn't be a good choice, there is the usbmouse driver.

It handles USB mice only. It uses a simpler HIDBP protocol. This also means the mice must support this simpler protocol. Not all do. If you don't have any strong reason to use this module, use usbhid instead.

C. usbkbd

Much like usbmouse, this module talks to keyboards with a simplified HIDBP protocol. It's smaller, but doesn't support any extra special keys. Use usbhid instead if there isn't any special reason to use this.

D. wacom

This is a driver for Wacom Graphire and Intuos tablets. Not for Wacom PenPartner, that one is handled by the HID driver. Although the Intuos and Graphire tablets claim that they are HID tablets as well, they are not and thus need this specific driver.

E. iforce

A driver for I-Force joysticks and wheels, both over USB and RS232. It includes

ForceFeedback support now, even though Immersion Corp. considers the protocol a trade secret and won't disclose a word about it.

2.

Event handlers

Event handlers distribute the events from the devices to userland and kernel, as needed.

A. keybdev keybdev is currently a rather ugly hack that translates the input events into architecture-specific keyboard raw mode (Xlated AT Set2 on x86), and passes them into the handle_scancode function of the keyboard.c module. This works well enough on all architectures that keybdev can generate rawmode on, other architectures can be added to it.

RSB-4210 User Manual 98

The right way would be to pass the events to keyboard.c directly, best if keyboard.c would itself be an event handler. This is done in the input patch, available on the webpage mentioned below.

B. mousedev mousedev is also a hack to make programs that use mouse input work. It takes events from either mice or digitizers/tablets and makes a PS/2-style (a la /dev/ psaux) mouse device available to the userland. Ideally, the programs could use a more reasonable interface, for example evdev

Mousedev devices in /dev/input (as shown above) are: crw-r--r-- 1 root root 13, 32 Mar 28 22:45 mouse0 mouse1 crw-r--r-- 1 root root 13, 33 Mar 29 00:41 mouse2 crw-r--r-- 1 root root 13, 34 Mar 29 00:41 mouse3 crw-r--r-- 1 root root 13, 35 Apr 1 10:50

...

...

crw-r--r-- 1 root root 13, 62 Apr 1 10:50 mouse30 crw-r--r-- 1 root root 13, 63 Apr 1 10:50 mice

Each 'mouse' device is assigned to a single mouse or digitizer, except the last one

- 'mice'. This single character device is shared by all mice and digitizers, and even if none are connected, the device is present. This is useful for hotplugging USB mice, so that programs can open the device even when no mice are present.

CONFIG_INPUT_MOUSEDEV_SCREEN_[XY] in the kernel configuration are the size of your screen (in pixels) in XFree86. This is needed if you want to use your digitizer in X, because its movement is sent to X via a virtual PS/2 mouse and thus needs to be scaled accordingly. These values won't be used if you use a mouse only.

Mousedev will generate either PS/2, ImPS/2 (Microsoft IntelliMouse) or ExplorerPS/2 (IntelliMouse Explorer) protocols, depending on what the program reading the data wishes. You can set GPM and X to any of these. You'll need ImPS/2 if you want to make use of a wheel on a USB mouse and ExplorerPS/2 if you want to use extra (up to 5) buttons.

C. joydev

Joydev implements v0.x and v1.x Linux joystick api, much like drivers/char/joystick/ joystick.c used to in earlier versions. See joystick-api.txt in the Documentation subdirectory for details. As soon as any joystick is connected, it can be accessed in /dev/input on: crw-r--r-- 1 root root 13, 0 Apr 1 10:50 js0 crw-r--r-- 1 root root 13, 1 Apr 1 10:50 js1 crw-r--r-- 1 root root 13, 2 Apr 1 10:50 js2 crw-r--r-- 1 root root 13, 3 Apr 1 10:50 js3

...

And so on up to js31.

D. evdev

99 RSB-4210 User Manual

evdev is the generic input event interface. It passes the events generated in the kernel straight to the program, with timestamps. The API is still evolving, but should be useable now.

This should be the way for GPM and X to get keyboard and mouse events. It allows for multihead in X without any specific multihead kernel support. The event codes are the same on all architectures and are hardware independent.

The devices are in /dev/input: crw-r--r-- 1 root root 13, 64 Apr 1 10:49 event0 crw-r--r-- 1 root root 13, 65 Apr 1 10:50 event1 event2 crw-r--r-- 1 root root 13, 66 Apr 1 10:50 crw-r--r-- 1 root root 13, 67 Apr 1 10:50 event3

...

And so on up to event31.

3.

Verifying if it works

Typing a couple keys on the keyboard should be enough to check that a USB keyboard works and is correctly connected to the kernel keyboard driver.

Doing a cat /dev/input/mouse0 (c, 13, 32) will verify that a mouse is also emulated, characters should appear if you move it.

You can test the joystick emulation with the 'jstest' utility, available in the joystick package (see Documentation/input/joystick.txt).

You can test the event devices with the 'evtest' utility available in the LinuxConsole project CVS archive (see the URL below).

4.

Event interface

Should you want to add event device support into any application (X, gpm, svgalib ...)

I <[email protected]> will be happy to provide you any help I can. Here goes a description of the current state of things, which is going to be extended, but not changed incompatibly as time goes:

You can use blocking and nonblocking reads, also select() on the /dev/input/eventX devices, and you'll always get a whole number of input events on a read. Their layout is: struct input_event { struct timeval time; unsigned short type; unsigned short code; unsigned int value;

};

'time' is the timestamp, it returns the time at which the event happened.

Type is for example EV_REL for relative moment, EV_KEY for a keypress or release.

More types are defined in include/linux/input.h.

'code' is event code, for example REL_X or KEY_BACKSPACE, again a complete list is in include/linux/input.h.

'value' is the value the event carries. Either a relative change for EV_REL, absolute new value for EV_ABS (joysticks ...), or 0 for EV_KEY for release, 1 for keypress and

2 for autorepeat.

RSB-4210 User Manual 100

More detail please reference "source/linux-2.6.35.4/Documentation/input/input.txt".

3.12

Backlight Adjustment

The brightness of the display backlight can be adjusted in a range from 0 to 255. The value is exported as a virtual file in the sysfs under /sys/class/backlight/ pwm_backlight/brightness. It can be accessed using the standard file operations open(), read(), write() and close().

Example 1: Reading and adjusting the current backlight brightness on the console root #cat /sys/class/backlight/pwm-backlight/brightness

255 root # echo 100 > /sys/class/backlight/pwm-backlight/brightness root #cat /sys/class/backlight/pwm-backlight/brightness

100

Please note that this value is not persistent, i.e. it gets lost when the device is rebooted. In order to change the brightness permanently, it has to be set in the XML configuration, which is also mapped into the sysfs under /sys/class/misc/guf_xml/ configurationFile/variables/display/backlight/level_ac.

The PWM settings used allow the adjustment of the duty cycle in 255 steps.

101 RSB-4210 User Manual

www.advantech.com

Please verify specifications before quoting. This guide is intended for reference purposes only.

All product specifications are subject to change without notice.

No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permission of the publisher.

All brand and product names are trademarks or registered trademarks of their respective companies.

© Advantech Co., Ltd. 2012

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
