Ikea 504.964.80 SVALNA Fridge 300 Integrated Instruction manual

SVALNA
GB
ENGLISH
Please refer to the last page of this manual for the full list of
IKEA appointed After Sales Service Provider and relative
national phone numbers.
ENGLISH
4
ENGLISH
4
Contents
Safety information
Safety instructions
Installation
Product description
Control panel
First use
Daily Use
Hints and tips
4
6
8
13
13
14
14
15
Care and cleaning
Troubleshooting
Noises
Technical data
Information for test institutes
Environmental concerns
IKEA guarantee
16
16
20
20
21
22
22
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
Children and vulnerable people safety
•
•
•
•
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
Children aged from 3 to 8 years are allowed to load and
unload the appliance provided that they have been properly
instructed.
This appliance may be used by persons with very extensive
and complex disabilities provided that they have been
properly instructed.
Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
ENGLISH
•
•
•
5
Children should be supervised to ensure that they do not
play with the appliance.
Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
Keep all packaging away from children and dispose of it
appropriately.
General Safety
•
•
•
•
•
•
•
•
•
This appliance is for storing food and baverages only.
This appliance is designed for single household domestic
use in an indoor environment.
This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
To avoid contamination of food respect the following
instructions:
– do not open the door for long periods;
– clean regularly surfaces that can come in contact with
food and accessible drainage systems;
– store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
Do not use water spray and steam to clean the appliance.
ENGLISH
•
•
•
•
6
Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
When the appliance is empty for long period, switch it off,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
Safety instructions
Installation
Warning! Only a qualified person
must install this appliance.
•
•
•
•
•
•
•
•
•
•
•
Remove all the packaging.
Do not install or use a damaged
appliance.
Do not use the appliance before installing
it in the built-in structure due to safety
manner.
Follow the installation instructions
supplied with the appliance.
Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
Make sure the air can circulate around
the appliance.
At first installation or after reversing the
door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow back
in the compressor.
Before carrying out any operations on the
appliance (e.g. reversing the door),
remove the plug from the power socket.
Do not install the appliance close to
radiators or cookers, ovens or hobs.
Do not expose the appliance to the rain.
Do not install the appliance where there is
direct sunlight.
•
•
Do not install this appliance in areas that
are too humid or too cold.
When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
Electrical connection
Warning! Risk of fire and electric
shock.
Warning! When positioning the
appliance, ensure the supply cord
is not trapped or damaged.
Warning! Do not use multi-plug
adapters and extension cables.
•
•
•
•
The appliance must be earthed.
Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
Always use a correctly installed
shockproof socket.
Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
ENGLISH
•
•
•
Warning! Risk of injury, burns,
electric shock or fire.
The appliance contains flammable
gas, isobutane (R600a), a natural gas with a
high level of environmental compatibility. Be
careful not to cause damage to the
refrigerant circuit containing isobutane.
•
•
•
•
•
•
•
separately: These lamps are intended to
withstand extreme physical conditions in
household appliances, such as
temperature, vibration, humidity, or are
intended to signal information about the
operational status of the appliance. They
are not intended to be used in other
applications and are not suitable for
household room illumination.
The mains cable must stay below the level
of the mains plug.
Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
Use
•
7
Do not change the specification of this
appliance.
Any use of the built-in product as freestanding is strictly prohibited.
Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
Do not let hot items to touch the plastic
parts of the appliance.
Do not store flammable gas and liquid in
the appliance.
Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
Do not touch the compressor or the
condenser. They are hot.
Care and cleaning
Warning! Risk of injury or
damage to the appliance.
•
•
•
Service
•
•
•
Internal lighting
Warning! Risk of electric shock.
•
•
This product contains a light source of
energy efficiency class G.
Concerning the lamp(s) inside this
product and spare part lamps sold
Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
This appliance contains hydrocarbons in
the cooling unit. Only a qualified person
must do the maintenance and the
recharging of the unit.
Regularly examine the drain of the
appliance and if necessary, clean it. If the
drain is blocked, defrosted water collects
in the bottom of the appliance.
•
To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
Please note that self-repair or nonprofessional repair can have safety
consequences and might void the
guarantee.
The following spare parts will be available
for 7 years after the model has been
discontinued: thermostats, temperature
sensors, printed circuit boards, light
sources, door handles, door hinges, trays
and baskets. Please note that some of
these spare parts are only available to
professional repairers, and that not all
spare parts are relevant for all models.
Door gaskets will be available for 10 years
after the model has been discontinued.
ENGLISH
8
•
Disposal
Warning! Risk of injury or
suffocation.
•
•
•
•
Disconnect the appliance from the mains
supply.
Cut off the mains cable and discard it.
Remove the door to prevent children and
pets to be closed inside of the appliance.
The refrigerant circuit and the insulation
materials of this appliance are ozonefriendly.
•
The insulation foam contains flammable
gas. Contact your municipal authority for
information on how to discard the
appliance correctly.
Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
Installation
Warning! Refer to Safety
chapters.
Warning! Refer to installation
instruction document to install
your appliance.
Warning! Fix the appliance in
accordance with installation
instruction document to avoid a
risk of instability of the appliance.
Inspection checklist
Please follow the inspection checklist before using your appliance. If any answer
is "NO", follow the relevant action. Remember to write down the product serial
number and article number as required and attach your receipt to this page.
Product serial number (Ser. No.):
.....................................
Product article number (Art. No.):
.....................................
Purchasing date:
.....................................
Art. No.
XXXXXXXXX
XXX l
FREEZER NET CAPACITY
GEFRIERSCHRANK NUTZINHALT
XX l
FREEZING CAPACITY
GEFRIERVERMOEGEN
X kg/24h
RISING TIME
LAGERZEIT BEI STORUNG
CLASS
KLASSE
Made in Hungary
@ Inter IKEA Systems B.V. 1999
xxxxx
XXXXXXXXXXXX
PNC
XXXXXXXXX XX
SER.N.
XXXXXXXX
XX h
XX/X/XX/X
TYPE-TYP
XXXXXXXXXX
230-240V 50 Hz
1.0 A
REFRIGERANT
KAELTEMITTEL
IKEA of Sweden AB
SE 343 81 Älmhult
MODEL
xxxx
XXX l
REFRIGERATOR NET CAPACITY
KUEHLSCHRANK NUTZINHALT
PQM
GROSS CAPACITY
BRUTTO INHALT
TYPE I
XXXXXXXXX
DEFROST HEATER
ABTAUWIDERSTAND
XXX W
Ser. No.
To check
Check if the evaporative tray
above the compressor is
placed under the water outlet
(refer to section "Evaporative
tray").
If the answer is YES
No action
If the answer is NO
Place the evaporative tray under
the water outlet.
ENGLISH
To check
9
If the answer is YES
If the answer is NO
Make sure gasket seals all
around the door when the
door is closed.
No action
Refer to the assembly instruction door alignment.
Check if there is no collision
between parts/furniture while
opening and closing the door.
No action
Refer to the assembly instruction door alignment.
Install the appliance in the
built-in structure.
No action
Follow the assembly instruction for
the proper installation.
Make sure that at first installa‐ No action
tion or after reversing the
door the appliance stands in
vertical position for at least 4
hours before it is connected to
the power supply.
Wait 4 hours before connecting the
appliance to the power supply.
Evaporative tray
Before using the appliance make sure that
evaporative tray above the compressor is
placed below the melting water outlet.
ENGLISH
10
D3
D1
Dimensions
W1
90
D2
°
W3
A
B
H1
W2
Space required in use ²
Overall dimensions ¹
H1
mm
873
D2
mm
551
W1*
mm
548
A
mm
880
D1
mm
549
B
mm
36
¹ the height, width and depth of the
appliance without the handle
* including the width of the bottom hinges (8
mm)
Space required in use ²
H2 (A+B)
mm
916
W2*
mm
548
² the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of the
cooling air
* including the width of the bottom hinges (8
mm)
ENGLISH
11
Overall space required in use ³
H3 (A+B)
mm
916
W3*
mm
548
D3
mm
1071
³ the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of the
cooling air, plus the space necessary to allow
door opening to the minimum angle
permitting removal of all internal equipment
* including the width of the bottom hinges (8
mm)
Location
Electrical connection
Caution! Any electrical work
required to install this appliance
should be carried out by a
qualified electrician or competent
person.
Warning! This appliance must be
earthed.
The manufacturer declines any
liability should these safety
measures not be observed.
The wires in the mains lead are coloured in
accordance with the following code:
A
B
To ensure appliance's best functionality, you
should not install the appliance in the nearby
of the heat source (oven, stoves, radiators,
cookers or hobs) or in a place with direct
sunlight. Make sure that air can circulate
freely around the back of the cabinet.
This appliance should be installed in a dry,
well ventilated indoor position.
C
This appliance is intended to be used at
ambient temperature ranging from 10°C to
43°C.
D
E
The correct operation of the
appliance can only be guaranteed
within the specified temperature
range.
If you have any doubts regarding
where to install the appliance,
please turn to the vendor, to our
customer service or to the
nearest Authorised Service
Centre.
It must be possible to disconnect
the appliance from the mains
power supply. The plug must
therefore be easily accessible
after installation.
• A - green and yellow: Earth
• C - brown: Live
• D - blue: Neutral
As the colours of the wires in the mains lead
of this appliance may not correspond with
the coloured markings identifying the
terminals in your plug, proceed as follows:
1. Connect the wire coloured green and
yellow to the terminal marked either
with the letter “E“ or by the earth symbol
or coloured green and yellow.
ENGLISH
2. Connect the wire coloured blue to the
terminal either marked with the letter
“N“ or coloured black.
3. Connect the wire coloured brown to the
terminal either marked with the “L“ or
coloured red.
4. Check that no cut, or stray strands of
wire is present and the cord clamp (E) is
secure over the outer sheath.
Make sure the electricity supply voltage
is the same as that indicated on the
appliance rating plate.
5. Switch on the appliance.
The appliance is supplied with a 13 amp fuse
(B). In the event of having to change the fuse
in the plug supplied, a 13 amp ASTA
approved (BS 1362) fuse must be used.
Warning! A cut off plug inserted
into a 13 amp socket is a serious
safety (shock) hazard. Ensure that
it is disposed of safely.
Ventilation requirements
The airflow behind the appliance must be
sufficient.
12
5 cm
min.
200 cm2
min.
200 cm2
Caution! Refer to the installation
instructions for the installation.
Door reversibility
Please refer to the separate document with
instructions on installation and door
reversal.
Caution! At every stage of
reversing the door protect the
floor from scratching with a
durable material.
ENGLISH
13
Product description
Product overview
1
2
3
4
5
6
1
2
3
4
5
6
7
8
9
Drawer glass cover
Glass shelves
Control unit and light
Dairy compartment with lid
Sliding door balcony
Door balcony
Bottle balcony
Vegetable drawer
Rating plate (inside)
Least cold zone
Intermediate temperature zone
Coldest zone
9
8
7
Control panel
Switching on
1. Insert the plug into the wall socket.
2. Turn the temperature regulator
clockwise to a medium setting.
Switching off
To turn off the appliance, turn the
temperature regulator to the "O" position.
Temperature regulation
The temperature is regulated automatically.
However, you can set a temperature inside
the appliance yourself.
Choose the setting keeping in mind that the
temperature inside the appliance depends
on:
• room temperature,
• frequency of opening the door,
• quantity of food stored,
• appliance location.
A medium setting is generally the most
suitable one.
To operate the appliance:
1. Turn the temperature regulator
clockwise to obtain a lower temperature
inside the appliance.
2. Turn the temperature regulator
counterclockwise to obtain a higher
temperature inside the appliance.
ENGLISH
14
First use
Cleaning the interior
Before using the appliance for the first time,
the interior and all internal accessories
should be washed with lukewarm water and
some neutral soap to remove the typical
smell of a brand-new product, then dried
thoroughly.
Caution! Do not use detergents,
abrasive powders, chlorine or oilbased cleaners as they will
damage the finish.
Daily Use
Caution! This refrigerating
appliance is not suitable for
freezing foodstuffs.
2. Reposition as required.
Accessories
Egg tray
x1
Positioning the door balconies
To permit storage of food packages of
various sizes, the door shelves can be placed
at different heights.
1. Gradually pull the shelf up until it comes
free.
The model is equipped with a sliding
door balcony which is fitted under a
dairy compartment and can be slid
sideways.
Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the shelves
can be positioned as desired.
ENGLISH
15
Do not move the glass shelf
above the vegetable drawer to
ensure correct air circulation.
Vegetable drawer
There is a special drawer in the bottom part
of the appliance suitable for storage of fruits
and vegetables.
Hints and tips
Hints for energy saving
•
•
•
•
•
Most efficient use of energy is ensured in
the configuration with the drawers in the
bottom part of the appliance and shelves
evenly distributed. Position of the door
bins does not affect energy consumption.
Do not open the door frequently or leave
it open longer than necessary.
Do not set too high temperature to save
energy unless it is required by the
characteristics of the food.
If the ambient temperature is high and
the temperature control is set to low
temperature and the appliance is fully
loaded, the compressor may run
continuously, causing frost or ice
formation on the evaporator. In this case,
set the temperature control toward
higher temperature to allow automatic
defrosting and to save energy this way.
Ensure a good ventilation. Do not cover
the ventilation grilles or holes.
•
•
•
Hints for food refrigeration
•
•
•
•
Hints for fresh food refrigeration
•
•
•
•
The medium temperature setting ensures
good preservation of fresh food.
Higher temperature setting inside the
appliance may lead to shorter shelf life of
food.
Cover the food with packaging to
preserve its freshness and aroma.
Always use closed containers for liquids
and for food, to avoid flavours or odours
in the compartment.
To avoid the cross-contamination
between cooked and raw food, cover the
cooked food and separate it from the raw
one.
It is recommended to defrost the food
inside the fridge.
Do not insert hot food inside the
appliance. Make sure it has cooled down
at room temperature before inserting it.
To prevent food waste the new stock of
food should always be placed behind the
old one.
•
•
•
•
Fresh food compartment is the one
marked (on the rating plate) with
.
Meat (all types): wrap in a suitable
packaging and place it on the glass shelf
above the vegetable drawer. Store meat
for at most 1-2 days.
Fruit and vegetables: clean thoroughly
(eliminate the soil) and place in a special
drawer (vegetable drawer).
It is advisable not to keep the exotic fruits
like bananas, mangos, papayas etc. in the
refrigerator.
Vegetables like tomatoes, potatoes,
onions, and garlic should not be kept in
the refrigerator.
Butter and cheese: place in an airtight
container or wrap in an aluminium foil or
a polythene bag to exclude as much air as
possible.
Bottles: close them with a cap and place
them on the door bottle shelf, or (if
available) on the bottle rack.
Always refer to the expiry date of the
products to know how long to keep them.
ENGLISH
16
Care and cleaning
Cleaning the interior
Before using the appliance for the first time,
the interior and all internal accessories
should be washed with lukewarm water and
some neutral soap to remove the typical
smell of a brand-new product, then dried
thoroughly.
Caution! Do not use detergents,
abrasive powders, chlorine or oilbased cleaners as they will
damage the finish.
during normal use. The defrost water drains
out through a trough into a special container
at the back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the
defrost water drain hole in the middle of the
refrigerator compartment channel to
prevent the water overflowing and dripping
onto the food inside.
For this purpose use the tube cleaner
provided with the appliance.
Caution! The accessories and
parts of the appliance are not
suitable for washing in a
dishwasher.
Periodic cleaning
The equipment has to be cleaned regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral soap.
2. Regularly check the door seals and wipe
them clean to ensure they are clean and
free from debris.
3. Rinse and dry thoroughly.
Defrosting of the refrigerator
Frost is automatically eliminated from the
evaporator of the refrigerator compartment
Period of non-operation
When the appliance is not in use for long
period, take the following precautions:
1. Disconnect the appliance from electricity
supply.
2. Remove all food.
3. Clean the appliance and all accessories.
4. Leave the door open to prevent
unpleasant smells.
Troubleshooting
Warning! Refer to Safety
chapters.
What to do if...
Problem
The appliance does not oper‐
ate.
Possible cause
Solution
The appliance is switched off. Switch on the appliance.
ENGLISH
Problem
17
Possible cause
Solution
The appliance does not oper‐
ate.
The mains plug is not con‐
nected to the mains socket
correctly.
Connect the mains plug to
the mains socket correctly.
The appliance does not oper‐
ate.
There is no voltage in the
mains socket.
Connect a different electrical
appliance to the mains sock‐
et. Contact a qualified electri‐
cian.
The appliance is noisy.
The appliance is not suppor‐
ted properly.
Check if the appliance stands
stable.
The following noises can be
heard: bubbling, whirring,
hissing, cracking or clicking.
This is normal. Refer to
"Noises" chapter.
The compressor operates
continually.
Temperature is set incorrect‐
ly.
Refer to "Control Panel"
chapter.
The compressor operates
continually.
Many food products were put Wait a few hours and then
in at the same time.
check the temperature again.
The compressor operates
continually.
The room temperature is too
high.
Refer to "Installation" chap‐
ter.
The compressor operates
continually.
Food products placed in the
appliance were too warm.
Allow food products to cool
to room temperature before
storing.
The compressor operates
continually.
The door is not closed cor‐
rectly.
Refer to "Closing the door"
section.
Door is misaligned or inter‐
feres with ventilation grill.
The appliance is not levelled.
Refer to installation instruc‐
tions.
Door does not open easily.
You attempted to re-open the Wait a few seconds between
door immediately after clos‐ closing and re-opening of the
ing.
door.
The lamp does not work.
The lamp is in stand-by
mode.
Close and open the door.
The lamp does not work.
The lamp is defective.
Refer to "Replacing the lamp"
section.
There is too much frost and
ice.
The door is not closed cor‐
rectly.
Refer to "Closing the door"
section.
There is too much frost and
ice.
The gasket is deformed or
dirty.
Refer to "Closing the door"
section.
ENGLISH
Problem
18
Possible cause
Solution
There is too much frost and
ice.
Food products are not wrap‐
ped properly.
Wrap the food products bet‐
ter.
There is too much frost and
ice.
Temperature is set incorrect‐
ly.
Refer to "Control Panel"
chapter.
There is too much frost and
ice.
Appliance is fully loaded and
is set to the lowest tempera‐
ture.
Set a higher temperature. Re‐
fer to "Control Panel" chap‐
ter.
There is too much frost and
ice.
Temperature set in the appli‐ Set a higher temperature. Re‐
ance is too low and the ambi‐ fer to "Control Panel" chapter
ent temperature is too high.
and "Location" section.
Water flows on the rear plate
of the refrigerator.
During the automatic de‐
frosting process, frost melts
on the rear plate.
This is correct.
There is too much condensed Door was opened too fre‐
water on the rear wall of the quently.
refrigerator.
Open the door only when
necessary.
There is too much condensed Door was not closed com‐
water on the rear wall of the pletely.
refrigerator.
Make sure the door is closed
completely.
There is too much condensed Stored food was not wrap‐
water on the rear wall of the ped.
refrigerator.
Wrap food in suitable pack‐
aging before storing it in the
appliance.
Water flows inside the refrig‐
erator.
Food products prevent the
water from flowing into the
water collector.
Make sure that food products
do not touch the rear plate.
Water flows inside the refrig‐
erator.
The water outlet is clogged.
Clean the water outlet.
Water flows on the floor.
The evaporative tray above
the compressor is not placed
below the melting water out‐
let.
Make sure the tray is placed
below the melting water out‐
let.
Water flows on the floor.
Door was left open for a long
time.
Open the door only when
necessary.
Water flows on the floor.
The gasket is deformed or
damaged.
Contact the Authorised Serv‐
ice Centre.
The temperature in the appli‐ The temperature is not set
ance is too low/too high.
correctly.
Set a higher/lower tempera‐
ture.
ENGLISH
Problem
19
Possible cause
Solution
The temperature in the appli‐ The door is not closed cor‐
ance is too low/too high.
rectly.
Refer to "Closing the door"
section.
The temperature in the appli‐ The food products' tempera‐
ance is too low/too high.
ture is too high.
Let the food products tem‐
perature decrease to room
temperature before storage.
The temperature in the appli‐ Many food products are stor‐
ance is too low/too high.
ed at the same time.
Store less food products at
the same time.
The temperature in the appli‐ The door has been opened
ance is too low/too high.
often.
Open the door only if neces‐
sary.
The temperature in the appli‐ There is no cold air circula‐
ance is too low/too high.
tion in the appliance.
Make sure that there is cold
air circulation in the appli‐
ance. Refer to "Hints and
Tips" chapter.
If the advice does not lead to the
desired result, call the nearest
Authorized Service Centre.
1
Replacing the lamp
Caution! The appliance is
equipped with a longlife LED
interior light.
It is strongly recommended to use
original spare parts only.
Caution! Disconnect the plug
from the mains socket.
1. Pull the left side of the lamp cover with
your fingers to unlock it. Remove the
cover by pulling it towards yourself.
2
1
2. Replace the lamp with one of the same
power and shape, specifically designed
for household appliances.
No incandescent bulbs are
allowed.
3. Reassemble the lamp cover.
4. Connect the plug to the mains socket.
5. Open the door.
Make sure that the light switches on.
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
installation instructions.
ENGLISH
20
3. If necessary, replace the defective door
gaskets. Contact the Authorised Service
Centre.
Noises
SSSRRR!
BRRR!
CLICK!
HISSS!
BLUBB!
Technical data
Product category
Product Type
Refrigerator
Installation Type
Built-in only
Product dimensions
Height
873 mm
Width
548 mm
ENGLISH
Depth
21
549 mm
Net volume
Fresh food compartment (Fridge)
142 l
auto
Annual energy consumption
117 kWh/y
Airborne acoustical noise emissions
38 dB (A)
Energy efficiency class
F
Voltage
230 - 240 V
Frequency
50 Hz
The technical information (including the serial
number) is situated in the rating plate on the
internal left side of the appliance and in the
energy label.
GROSS CAPACITY
BRUTTO INHALT
XXX l
REFRIGERATOR NET CAPACITY
KUEHLSCHRANK NUTZINHALT
XXX l
FREEZER NET CAPACITY
GEFRIERSCHRANK NUTZINHALT
FREEZING CAPACITY
GEFRIERVERMOEGEN
XX l
X kg/24h
RISING TIME
LAGERZEIT BEI STORUNG
CLASS
KLASSE
XX h
XXXXXXXXX
xxxxx
REFRIGERANT
KAELTEMITTEL
DEFROST HEATER
ABTAUWIDERSTAND
xxxxxxxxx
IKEA of Sweden AB
SE 343 81 Älmhult
MODEL
XXXXXXXXXXXX
PNC
XXX XXX XXX
XX/X/XX/X
XXXXXXXXXX
230-240V 50 Hz
1.0 A
TYPE-TYP
The QR code on the energy label supplied
with the appliance provides a web link to the
information related to the performance of
the appliance in the EU EPREL database.
Keep the energy label for reference together
with the user manual and all other
documents provided with this appliance.
Made in Hungary
@ Inter IKEA Systems B.V. 1999
SER.N.
PQM
Fresh food compartment (Fridge)
xxxx
Defrost system
XXXXXXXX
TYPE I
XXX W
eprel.ec.europa.eu and the model name and
product number that you find on the rating
plate of the appliance.
See the link www.theenergylabel.eu for
detailed information about the energy label.
It is also possible to find the same
information in EPREL using the link https://
Information for test institutes
Installation and preparation of the appliance
for any EcoDesign verification shall be
compliant with EN 62552. Ventilation
requirements, recess dimensions and
minimum rear clearances shall be as stated
in this User Manual at Chapter 3. Please
contact the manufacturer for any other
further information, including loading plans.
ENGLISH
22
Environmental concerns
Recycle materials with the symbol
. Put
the packaging in relevant containers to
recycle it. Help protect the environment and
human health by recycling waste of electrical
and electronic appliances. Do not dispose of
appliances marked with the symbol
with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
IKEA guarantee
How long is the IKEA guarantee valid?
This guarantee is valid for 5 years from the
original date of purchase of your appliance
at IKEA. The original sales receipt is required
as proof of purchase. If service work is
carried out under guarantee, this will not
extend the guarantee period for the
appliance.
Who will execute the service?
own service operations, will then, at its sole
discretion, either repair the defective
product or replace it with the same or a
comparable product.
What is not covered under this
guarantee?
•
•
IKEA service provider will provide the service
through its own service operations or
authorized service partner network.
What does this guarantee cover?
The guarantee covers faults of the appliance,
which have been caused by faulty
construction or material faults from the date
of purchase from IKEA. This guarantee
applies to domestic use only. The exceptions
are specified under the headline “What is not
covered under this guarantee?” Within the
guarantee period, the costs to remedy the
fault e.g. repairs, parts, labour and travel will
be covered, provided that the appliance is
accessible for repair without special
expenditure. On these conditions the EU
guidelines (Nr. 99/44/EG) and the respective
local regulations are applicable. Replaced
parts become the property of IKEA.
•
•
•
•
What will IKEA do to correct the problem?
IKEA appointed service provider will examine
the product and decide, at its sole discretion,
if it is covered under this guarantee. If
considered covered, IKEA service provider or
its authorized service partner through its
•
Normal wear and tear.
Deliberate or negligent damage, damage
caused by failure to observe operating
instructions, incorrect installation or by
connection to the wrong voltage, damage
caused by chemical or electro-chemical
reaction, rust, corrosion or water damage
including but not limited to damage
caused by excessive lime in the water
supply, damage caused by abnormal
environmental conditions.
Consumable parts including batteries and
lamps.
Non-functional and decorative parts
which do not affect normal use of the
appliance, including any scratches and
possible color differences.
Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of filters, drainage systems or
soap drawers.
Damage to the following parts: ceramic
glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.
Cases where no fault could be found
during a technician’s visit.
ENGLISH
•
Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where nonoriginal parts have been used.
• Repairs caused by installation which is
faulty or not according to specification.
• The use of the appliance in a nondomestic environment i.e. professional
use.
• Transportation damages. If a customer
transports the product to their home or
other address, IKEA is not liable for any
damage that may occur during transport.
However, if IKEA delivers the product to
the customer's delivery address, then
damage to the product that occurs during
this delivery will be covered by this
guarantee.
• Cost for carrying out the initial installation
of the IKEA appliance. However, if an IKEA
service provider or its authorized service
partner repairs or replaces the appliance
under the terms of this guarantee, the
service provider or its authorized service
partner will re-install the repaired
appliance or install the replacement, if
necessary.
This restriction do not apply to fault-free
work carried out by a qualified specialist
using our original parts in order to adapt the
appliance to the technical safety
specifications of another EU country.
23
•
the technical specifications of the country
in which the guarantee claim is made;
• the Assembly Instructions and User
Manual Safety Information;
The dedicated After Sales Service for IKEA
appliances:
Please do not hesitate to contact IKEA After
Sales Service to:
1. make a service request under this
guarantee;
2. ask for clarification on installation of the
IKEA appliance in the dedicated IKEA
kitchen furniture. The service won’t
provide clarifications related to:
• the overall IKEA kitchen installation;
• connections to electricity (if machine
comes without plug and cable), to
water and to gas since they have to
be executed by an authorized service
engineer.
3. ask for clarification on user manual
contents and specifications of the IKEA
appliance.
To ensure that we provide you with the best
assistance, please read carefully the
Assembly Instructions and/or the User
Manual section of this booklet before
contacting us.
How to reach us if you need our service
How country law applies
The IKEA guarantee gives you specific legal
rights, which covers or exceed local
demands. However these conditions do not
limit in any way consumer rights described
in the local legislation.
Area of validity
For appliances which are purchased in one
EU country and taken to another EU country,
the services will be provided in the
framework of the guarantee conditions
normal in the new country. An obligation to
carry out services in the framework of the
guarantee exists only if the appliance
complies and is installed in accordance with:
Please refer to the last page of this manual
for the full list of IKEA appointed contacts
and relative national phone numbers.
ENGLISH
In order to provide you with a
quicker service, we recommend
that you use the specific phone
numbers listed at the end of this
manual. Always refer to the
numbers listed in the booklet of
the specific appliance you need
an assistance for. Before calling
us, assure that you have to hand
the IKEA article number (8 digit
code) and the Serial Number (8
digit code that can be found on
the rating plate) for the appliance
of which you need our assistance.
SAVE THE SALES RECEIPT! It is
your proof of purchase and
required for the guarantee to
apply. Note that the receipt
reports also the IKEA article name
and number (8 digit code) for
each of the appliances you have
purchased.
Do you need extra help?
For any additional questions not related to
After Sales of your appliances, please contact
our nearest IKEA store call centre. We
recommend you read the appliance
documentation carefully before contacting
us.
24
25
Country
Phone number
België
070 246016
Belgique
Call Fee
Opening time
Binnenlandse gesprekskosten
8 tot 20 Weekdagen
Tarif des appels nationaux
8 à 20. En semaine
От 8:30 до 17:30 ч в работни дни
България
+359 2 492 9397
Според тарифата на оператора
за обаждания към стационарен
номер
Česká Republika
246 019721
Cena za místní hovor
Danmark
70 15 09 09
Landstakst
Deutschland
+49 1806 33 45 32*
* 0,20 €/Verbindung aus dem Festnetz max. 0,60 €/Verbindung
aus dem Mobilfunknetz
Werktags von 8.00 bis 20.00
Ελλάδα
211 176 8276
Υπεραστική κλήση
8 έως 20 κατά τις εργάσιμες ημέρες
España
91 1875537
Tarifa de llamadas nacionales
De 8 a 20 en días laborables
France
0170 36 02 05
Tarif des appels nationaux
9 à 21. En semaine
00385 1 6323 339
Cijena ovisi o pružatelju telefonske
usluge korisnika
radnim danom od ponedjeljka
do petka od 08:00 do 16:00
Hrvatska
8 až 20 v pracovních dnech
man. - fre. 09.00 - 20.00
lør. - søn. 09.00 - 18.00
Ireland
0 14845915
National call rate
8 till 20 Weekdays
Ísland
+354 5852409
Innanlandsgjald fyrir síma
9 til 18. Virka daga
Italia
02 00620818
a applicata
alle chiamate nazionali
dalle 8 alle 20 nei giorni feriali
Κυπρος
22 030 529
Υπεραστική κλήση
8.30 έως 16.30 κατά τις εργάσιμες
ημέρες
Lietuva
5 230 06 99
Nacionalinių pokalbių tarifai
Pr. - Ketv.: 8:00 - 12:00, 12:45 - 17:00 Pnkt.:
8:00 - 12:00, 12:45 - 15:45
Magyarország
06-1-252-1773
Belföldi díjszabás
Hétköznap 8.00 és 17.00 óra között
Nederland
Luxembourg
0900 - 235 45 32
(0900-BEL IKEA)
0031 - 50 316 8772
(internationaal)
Geen extra kosten.
Alleen lokaal tarief.
ma-vr: 8.00 - 21.00
zat: 9.00 - 21.00
zon / pub. vakantie: 10.00 - 18.00
Norge
22 72 35 00
Takst innland
8 til 20 ukedager
Österreich
+43-1-2056356
max. 10 Cent/min.
Mo - Fr 8.00 - 20.00 Uhr
Polska
801 400 711 and
+48 22 749 60 99
Koszt zgodny z taryfą operatora
Od 8 do 20 w dni robocze
Portugal
211557985
Chamada Nacional
9 às 21. Dias de Semana
*excepto feriados
România
021 211 08 88
Tarif apel naţional
8 - 20 în zilele lucrătoare
Россия
8 495 6662929
Действующие телефонные
тарифы
с 8 до 20 по рабочим дням
Время московское
Schweiz
Suisse
031 5500 324
Svizzera
Tarif für Anrufe im Bundesgebiet
8 bis 20 Werktage
Tarif des appels nationaux
8 à 20. En semaine
a applicata
alle chiamate nazionali
dalle 8 alle 20 nei giorni feriali
Slovenija
+38618108621
lokalni strošek je običajna tržna vrednost, odvisna od ponudnika telefonije
8.00 – 16.00 ob delavnikih
Slovensko
(02) 3300 2554
Cena vnútroštátneho hovoru
8 až 20 v pracovných dňoch
Suomi
030 6005203
pvm/mpm
Ma – To 8:00 -18:00
Pe 9:00 -16:00
Sverige
0775 700 500
lokalsamtal (lokal taxa)
mån-fre 8.30 - 20.00
lör-sön 9.30 - 18.00
United Kingdom
020 3347 0044
National call rate
9 till 21. Weekdays
Србија
+381 11 7 555 444
(ако позивате изван Србије)
011 7 555 444
(ако позивате из Србије)
Цена позива у националном
саобраћају
Понедељак – субота: 09 – 20
Недеља: 09 – 18
Eesti, Latvija, Україна
www.ikea.com
*
211627148-B-442021
© Inter IKEA Systems B.V. 2021
21552
AA-2242524-2

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
