Graco 406616A 249449 Console Bracket Kit For Matrix Electronic Meters Owner's Manual

GENUINE GRACO PARTS AND ACCESSORIES
249440 Console Bracket Kit
For Matrix™ Electronic Meters
Important Safety Instructions
Read all warnings and instructions in manual 309497.
Save those instructions.
406616A
WARNING
To reduce the risk of serious injury whenever you are instructed to relieve pressure, always
follow the Pressure Relief Procedure. See Instruction Manual 309497.
Ref No.Part No.
Description
Qty.
1
15F918
CONSOLE, Bracket
2
2
3
100450
111303
SCREW, cap hex head
NUT, hex
4
4
1
2
1.750”
3.062”
.375” hole diameter
3
TI6652A
TI6645A
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
406616 Rev. A 4/2005 Printed in USA
Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001
