Graco 309028ZAT, Uni-Drum Supply System Instructions

Instructions - Parts List
Uni-Drum™
Supply System
309028ZAT
EN
Bulk Supply System for 300 Gallon (1200 Liter) Magnadrums. For professional use only.
Not approved for use in explosive atmospheres or hazardous (classified) locations.
The Uni-Drum Supply System evacuates 300 gallon (1200 liter) magnadrums or other tote drums of the same size
and capacity. The Uni-Drum Supply System pumps and transfers flowable and highly viscous materials such as
sealant, adhesives, and sound deadeners from bulk drums with maximum efficiency.
The Uni-Drum Supply System is designed to work with other high pressure equipment to optimize material use.
See page 4 for model information.
