IFS WMC303-1W-1T-1200

Dual Band Wireless Access Point

User Manual

P/N 1073050 • REV A • ISS 15OCT15

Copyright © 2015 United Technologies Corporation

Interlogix is part of UTC Building & Industrial Systems, Inc. a unit of United

Technologies Corporation. All rights reserved.

Trademarks and

The WMC303-1W-1T-1200 name and logo are trademarks of United

patents

Technologies.

Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.

Manufacturer Interlogix ( UTC Fire and Security)

3211 Progress Drive, Lincolnton, NC 28092 USA

Authorized EU manufacturing representative:

UTC Climate Controls & Security B.V.,

Kelvinstraat 7, 6003 DH Weert, Netherlands

Intended use

Use this product only for the purpose it was designed for; refer to the data sheet and user documentation for details. For the latest product information, contact your local supplier or visit us online at www.interlogix.com.

Certification

N4131

ACMA compliance

Notice! This is a Class B product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

European Union

2004/108/EC (EMC Directive): Hereby, UTC Building & Industrial Systems, Inc.

directives

declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his/her own expense. Any changes or modifications not expressly approved by UTC could void the user’s authority to operate this equipment under the rules and regulations of the FCC.

FCC Caution:

To assure continued compliance, (for example, use only shielded interface cables when connecting to computer or peripheral devices) any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference

(2) This device must accept any interference received, including interference that may cause undesired operation.

II

Federal Communication Commission (FCC) Radiation Exposure Statement

This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation.

CAUTION: Changes or modifications not expressly approved by UTC for compliance could void the user’s authority to operate the equipment.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy saving, please remove the DC-plug to disconnect the device from the power circuit. Without removing the DC-plug, the device still consumes power from the power circuit. In view of Saving the Energy, it is strongly suggested to remove the DC-plug for the device if this device is not intended to be active.

Canadian Compliance

This Class B digital apparatus meets all requirements of the Canadian Interference Causing

Equipment Regulations. Cet appareil numérique de la classe B respects toutes les exigences du

Règlement sur le matériel brouilleur du Canada.

Canada - Industry Canada (IC)

The wireless radio of this device complies with RSS 247 and RSS 102 of Industry Canada.

This Class B digital device complies with Canadian ICES-003 (NMB-003).

Cet appareil numérique de la classe B respects toutes les exigences du Règlement sur le matériel brouilleur du Canada.

This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the

following two conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that may cause undesired

operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d'en compromettre le fonctionnement.

WMC303-1W-1T-1200 complies with IC requirements, IC: 20201-WMC3031200.

III

This radio transmitter (IC: 20201-WMC3031200) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

 Dual Built-in the PCBA (2 x 2.4GHz 2.5dBi PCBA antenna)

 Dual Built-in the PCBA (2 x 5GHz 4dBi PCBA antenna)

Le présent émetteur radio (IC: 20201-WMC3031200) a été approuvé par Industrie Canada pour

fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur .

Intégré 2.5dBi antenne double polarisation X 2

Intégré 4dBi antenne double polarisation X 2

LE-LAN devices shall contain instructions related to the restrictions mentioned in the above sections, namely that:

1. the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;

2. for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit;

3. for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate; and

4. the worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in Section 6.2.2(3) of RSS-247 shall be clearly indicated.

The maximum conducted output power shall not exceed 250 mW or 11 + 10 log

10

B, dBm, whichever is less. The power spectral density shall not exceed 11 dBm in any 1.0 MHz band.

The maximum e.i.r.p. shall not exceed 1.0 W or 17 + 10 log

10

B, dBm, whichever is less. B is the 99% emission bandwidth in megahertz. Note that devices with a maximum e.i.r.p. greater than 500 mW shall implement TPC in order to have the capability to operate at least 6 dB below the maximum permitted e.i.r.p. of 1 W.

2) Unwanted emission limits i) For devices with both operating frequencies and channel bandwidths contained within the band

5250-5350 MHz, the device shall comply with the following: a. All emissions outside the band 5250-5350 MHz shall not exceed -27 dBm/MHz e.i.r.p. if the equipment is intended for outdoor use; or

IV

b. All emissions outside the band 5150-5350 MHz shall not exceed -27 dBm/MHz e.i.r.p. and any emissions within the band 5150-5250 MHz shall meet the power spectral density limits of

Section 6.2.1

of RSS-247. The device shall be labelled “for indoor use only.” ii) For devices with operating frequencies in the band 5250-5350 MHz but having a channel bandwidth that overlaps the band 5150-5250 MHz, the devices’ unwanted emission shall not exceed

-27 dBm/MHz e.i.r.p. outside the band 5150-5350 MHz and its power shall comply with the spectral power density for operation within the band 5150-5250 MHz. The device shall be labelled “for indoor use only.”

3) Additional requirements

In addition to the above requirements, devices operating in the band 5250-5350 MHz with a maximum e.i.r.p. greater than 200 mW shall comply with the following e.i.r.p. at different elevations, where θ is the angle above the local horizontal plane (of the Earth) as shown below:

1. -13 dBW/MHz for 0° ≤ θ < 8°

2. -

13 − 0.716 (θ-8) dBW/MHz for 8° ≤ θ < 40°

3. -

35.9 − 1.22 (θ-40) dBW/MHz for 40° ≤ θ ≤ 45°

4. -42 dBW/MHz for θ > 45°

The measurement procedure defined in Annex A of RSS-247 shall be used to verify the compliance to the e.i.r.p. at different elevations.

Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

Digital Transmission Systems (DTSs)

DTSs include systems that employ digital modulation techniques resulting in spectral characteristics similar to direct sequence systems. The following applies to the bands 902-928 MHz and 2400-2483.5

MHz.

(1) The minimum 6 dB bandwidth shall be 500 kHz.

(2) The transmitter power spectral density conducted from the transmitter to the antenna shall not be greater than 8 dBm in any 3 kHz band during any time interval of continuous transmission. This power spectral density shall be determined in accordance with the provisions of Section 5.4(4), (i.e. the power spectral density shall be determined using the same method as is used to determine the conducted output power).

For DTSs employing digital modulation techniques operating in the bands 902-928 MHz and

2400-2483.5 MHz, the maximum peak conducted output power shall not exceed 1W. Except as provided in Section 5.4(5), the e.i.r.p. shall not exceed 4 W.

As an alternative to a peak power measurement, compliance can be based on a measurement of the maximum conducted output power. The maximum conducted output power is the total transmit power delivered to all antennas and antenna elements, averaged across all symbols in the signalling alphabet when the transmitter is operating at its maximum power control level. Power must be summed across all antennas and antenna elements. The average must not include any time intervals during which the transmitter is off or transmitting at a reduced power level. If multiple modes of operation are

V

implemented, the maximum conducted output power is the highest total transmit power occurring in any mode.

(5) Fixed point-to-point systems in the bands 2400-2483.5 MHz and 5725-5850 MHz are permitted to have an e.i.r.p. higher than 4 W provided that the higher e.i.r.p. is achieved by employing higher gain directional antennas and not higher transmitter output powers. Point-to-multipoint systems,2 omnidirectional applications and multiple co-located transmitters transmitting the same information are prohibited from exceeding an e.i.r.p. of 4 W.

(6) Transmitters may operate in the band 2400-2483.5 MHz, employing antenna systems that emit multiple directional beams simultaneously or sequentially, for the purpose of directing signals to individual receivers or to groups of receivers, provided that the emissions comply with the following:

(i) Different information must be transmitted to each receiver.

(ii) If the transmitter employs an antenna system that emits multiple directional beams, but does not emit multiple directional beams simultaneously, the total output power conducted to the array or arrays that comprise the device (i.e. the sum of the power supplied to all antennas, antenna elements, staves, etc., and summed across all carriers or frequency channels) shall not exceed the applicable output power limit specified in sections 5.4(2) and 5.4(4). However, the total conducted output power shall be reduced by 1 dB below the specified limits for each 3 dB that the directional gain of the antenna/antenna array exceeds 6 dBi. The directional antenna gain shall be computed as the sum of

10 log (number of array elements or staves) plus the directional gain of the element or stave having the highest gain.

(iii) If a transmitter employs an antenna that operates simultaneously on multiple directional beams using the same or different frequency channels, the power supplied to each emission beam is subject to the applicable power limit specified in sections 5.4(2) and 5.4(4). If transmitted beams overlap, the power shall be reduced to ensure that their aggregate power does not exceed the applicable limit specified in sections 5.4(2) and 5.4(4). In addition, the aggregate power transmitted simultaneously on all beams shall not exceed the applicable limit specified in sections 5.4(2) and 5.4(4) by more than 8 dB.

(iv) Transmitters that transmit a single directional beam shall operate under the provisions of sections

5.4(2), 5.4(4) and 5.4(5).

5.5 Unwanted Emissions

In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated device is operating, the RF power that is produced shall be at least 20 dB below that in the

100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided that the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of root-mean-square averaging over a time interval, as permitted under Section

5.4(4), the attenuation required shall be 30 dB instead of 20 dB. Attenuation below the general field strength limits specified in RSS-Gen is not required.

No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from UTC

VI

Fire and Security.

UTC, reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of UTC to provide notification of such revision or change. UTC provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. UTC may make improvements or changes in the product(s) described in this manual at any time.

CAUTION: TO ENSURE REGULATORY COMPLIANCE, USE ONLY THE PROVIDED POWER AND

INTERFACE CABLES.

CAUTION: DO NOT OPEN THE UNIT. DO NOT PERFORM ANY SERVICING OTHER THAN THAT

CONTAINED IN THE INSTALLATION AND TROUBLESHOOTING INSTRUCTIONS. REFER ALL

SERVICING TO QUALIFIED SERVICE PERSONNEL.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN

PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and

Satellite Earth Station Equipment) as of April 8, 2000.

Safety

This equipment is designed with the utmost care for the safety of those who install and use it.

However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment.

Wireless LAN and your Health

The WMC303-1W-1T-1200 like other radio devices, emits radio frequency electromagnetic energy, but operates within the guidelines found in radio frequency safety standards and recommendations.

Restrictions on Use of Wireless Devices

In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or responsible representatives of the organization. For example, these situations may include:

. Using wireless equipment in any environment where the risk of interference to other devices or services is perceived or identified as harmful.

If you are uncertain of the applicable policy for the use of wireless equipment in a specific organization or environment, you are encouraged to ask for authorization to use the device prior to turning on the equipment.

The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of the devices included with this product, or the substitution or attachment of connecting

VII

cables and equipment other than specified by the manufacturer. Correction of interference caused by such unauthorized modification, substitution, or attachment is the responsibility of the user.

The manufacturer and its authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from failing to comply with these guideline documentation that comes with the product.

Postpone router installation until there is no risk of thunderstorm or lightning activity in the area.

Do not overload outlets or extension cords, as this can result in a risk of fire or electric shock.

Overloaded AC outlets, extension cords, frayed power cords, damaged or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or fire hazard.

Route power supply cords so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords where they are attached to plugs and convenience receptacles, and examine the point where they exit from the product.

Place this equipment in a location that is close enough to an electrical outlet to accommodate the length of the power cord.

Place this equipment on a stable surface.

When using this device, basic safety precautions should always be followed to reduce the risk of fire,

electric shock and injury to persons, including the following:

. Read all of the instructions {listed here and/or in the user manual} before you operate this equipment.

Give particular attention to all safety precautions.

Retain the instructions for future reference.

. Comply with all warning and caution statements in the instructions. Observe all warning and caution symbols that are affixed to this equipment.

. Comply with all instructions that accompany this equipment.

. Avoid using this product during an electrical storm. There may be a risk of electric shock from lightning. For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet, and disconnect the cable system.

This will prevent damage to the product due to lightning and power surges. We also recommend the use of ESP300 20Kv protection on the input at the switch or network.

. Operate this product only from the type of power source indicated on the product’s marking label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

. Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in safe operating condition.

It is recommended that the customer install an AC surge protector in the AC outlet to which this device is connected. This is to avoid damaging the equipment by local lightning strikes and other electrical surges.

Different types of cord sets may be used for connections to the main supply circuit. Use only a main

line cord that complies with all applicable product safety requirements of the country of use. Installation

VIII

of this product must be in accordance with national wiring codes.

Place unit to allow for easy access when disconnecting the power cord/adapter of the device from the

AC wall outlet.

Wipe the unit with a clean, dry cloth. Never use cleaning fluid or similar chemicals. Do not spray cleaners directly on the unit or use forced air to remove dust.

This product was qualified under test conditions that included the use of the supplied cables between system components. To be in compliance with regulations, the user must use these cables and install them properly. Connect the unit to a grounding type AC wall outlet using the power adapter supplied with the unit.

Do not cover the device, or block the airflow to the device with any other objects. Keep the device away from excessive heat and humidity and keep the device free from vibration and dust.

Installation must at all times conform to local regulations.

National Restrictions

This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below:

Country

Bulgaria

France

Italy

Luxembourg

Norway

Restriction Reasons/remarks

None

General authorization required for outdoor use and public service

Outdoor use; limited to 10

Military Radiolocation use. Reframing of the 2.4 GHz mW e.i.r.p. within the band band has been ongoing in recent years to allow current

2454-2483.5 MHz relaxed regulation. Full implementation planned 2012

None

None

Implemented

None

If used outside of own premises, general authorization is required

General authorization required for network and service supply(not for spectrum)

This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Ålesund

Only for indoor applications Russian

Federation

Note: Please don’t use the product outdoors in France.

WEEE regulation

To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately.

IX

Contact Information For contact information, see www.interlogix.com

or www.utcfssecurityproducts.eu

.

X

CONTENTS

Chapter 1.Product Introduction ........................................................................................................... 1

Chapter 2.Hardware Installation ........................................................................................................ 10

Chapter 3.Connecting to the AP ........................................................................................................ 12

Chapter 4.Quick Installation Guide ................................................................................................... 15

Chapter 5.Configuring the AP ............................................................................................................ 19

Chapter 6.Quick Connection to a Wireless Network ..................................................................... 101

Appendix A: Troubleshooting .......................................................................................................... 112

Appendix B: Glossary ....................................................................................................................... 114

XI

FIGURE

F

IGURE

2-1

WMC303-1W-1T-1200 P

RODUCT

D

RAWING

......................................................................... 10

F

IGURE

2-2

WMC303-1W-1T-1200 P

ANEL

L

AYOUT

................................................................................. 11

F

IGURE

3-1

WMC303-1200 I

NSTALLATION

D

IAGRAM

1 ............................................................................. 12

F

IGURE

3-2

WMC303-1200 I

NSTALLATION

D

IAGRAM

2 ............................................................................. 13

F

IGURE

3-3

WMC303-1200 I

NSTALLATION

D

IAGRAM

3 ............................................................................. 13

F

IGURE

3-4

WMC303-1200 I

NSTALLATION

D

IAGRAM

4 ............................................................................. 14

F

IGURE

3-5

WMC303-1200 I

NSTALLATION

D

IAGRAM

4 ............................................................................. 14

F

IGURE

4-1

TCP/IP S

ETTING

................................................................................................................... 16

F

IGURE

4-2

W

INDOWS

S

TART

M

ENU

........................................................................................................ 16

F

IGURE

4-3

S

UCCESSFUL RESULT OF

P

ING COMMAND

............................................................................... 17

F

IGURE

4-4

F

AILED

R

ESULT OF

P

ING

C

OMMAND

....................................................................................... 17

F

IGURE

4-5

L

OGIN BY DEFAULT

IP

ADDRESS

.............................................................................................. 18

F

IGURE

4-6

L

OGIN

W

INDOW

..................................................................................................................... 18

F

IGURE

5-1

M

AIN

M

ENU

.......................................................................................................................... 19

F

IGURE

5-2

S

ETUP

W

IZARD

..................................................................................................................... 19

F

IGURE

5-3

LAN I

NTERFACE

S

ETUP

T

OPOLOGY

........................................................................................ 20

F

IGURE

5-4

W

IZARD

– LAN I

NTERFACE

S

ETUP

......................................................................................... 20

F

IGURE

5-5

T

IME

Z

ONE

S

ETUP

T

OPOLOGY

............................................................................................... 20

F

IGURE

5-6

W

IZARD

– T

IME

Z

ONE

S

ETUP

................................................................................................. 21

F

IGURE

5-7

W

IZARD

– W

IRELESS

5GH

Z

B

ASIC

S

ETTINGS

......................................................................... 21

F

IGURE

5-8

W

IZARD

– W

IRELESS

5GH

Z

S

ECURITY

S

ETUP

........................................................................ 22

F

IGURE

5-9

5GH

Z

W

IRELESS

S

ECURITY

S

ETUP

– WEP S

ETTING

.............................................................. 22

F

IGURE

5-10

5GH

Z

W

IRELESS

S

ECURITY

S

ETUP

– WPA S

ETTING

............................................................ 23

F

IGURE

5-11

W

IZARD

– W

IRELESS

2.4GH

Z

B

ASIC

S

ETTINGS

.................................................................... 23

F

IGURE

5-12

W

IZARD

– W

IRELESS

2.4GH

Z

S

ECURITY

S

ETUP

................................................................... 24

F

IGURE

5-13

2.4GH

Z

W

IRELESS

S

ECURITY

S

ETUP

– WEP S

ETTING

......................................................... 24

F

IGURE

5-14

2.4GH

Z

W

IRELESS

S

ECURITY

S

ETUP

– WPA S

ETTING

......................................................... 25

F

IGURE

5-15

S

ETUP

W

IZARD

F

INISHED

.................................................................................................. 26

F

IGURE

5-16

LAN S

ETTING

..................................................................................................................... 27

F

IGURE

5-17

5GH

Z

W

IRELESS

M

AIN

M

ENU

.............................................................................................. 29

F

IGURE

5-18

5GH

Z

W

IRELESS

B

ASIC

S

ETTINGS OF

AP ............................................................................ 30

F

IGURE

5-19

5GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– M

ULTIPLE

AP ............................................................... 32

F

IGURE

5-20

5GH

Z

M

ULTIPLE

-SSID ........................................................................................................ 33

F

IGURE

5-21

5GH

Z

U

NIVERSAL

R

EPEATER

-1 ........................................................................................... 34

F

IGURE

5-22

5GH

Z

U

NIVERSAL

R

EPEATER

-2 ........................................................................................... 34

F

IGURE

5-23

5GH

Z

U

NIVERSAL

R

EPEATER

-3 ........................................................................................... 35

F

IGURE

5-24

5GH

Z

U

NIVERSAL

R

EPEATER

-4 ........................................................................................... 35

F

IGURE

5-25

5GH

Z

U

NIVERSAL

R

EPEATER

-5 ........................................................................................... 35

F

IGURE

5-26

5GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– C

LIENT

........................................................................ 36

F

IGURE

5-27

C

LIENT

– S

URVEY

............................................................................................................... 38

F

IGURE

5-28

C

LIENT

– AP L

IST

................................................................................................................ 39

F

IGURE

5-29

C

LIENT

– S

ECURITY

............................................................................................................. 39

XII

F

IGURE

5-30

C

LIENT

– S

TATUS

................................................................................................................ 40

F

IGURE

5-31

5GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– WDS ........................................................................... 41

F

IGURE

5-32

5GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– WDS+AP .................................................................... 43

F

IGURE

5-33

W

IRELESS

A

DVANCED

S

ETTINGS

– 5GH

Z

............................................................................. 45

F

IGURE

5-34

RF O

UTPUT

P

OWER

– 5GH

Z

............................................................................................... 47

F

IGURE

5-35

W

IRELESS

S

ECURITY

S

ETTINGS

– 5GH

Z

.............................................................................. 47

F

IGURE

5-36

W

IRELESS

A

CCESS

C

ONTROL

– 5GH

Z

................................................................................. 49

F

IGURE

5-37

W

IRELESS

A

CCESS

C

ONTROL

– D

ENY

.................................................................................. 50

F

IGURE

5-38

WDS M

ODE

– 5GH

Z

........................................................................................................... 52

F

IGURE

5-39

WDS S

ETTINGS

– 5GH

Z

..................................................................................................... 52

F

IGURE

5-40

WDS – S

ET

S

ECURITY

........................................................................................................ 53

F

IGURE

5-41

S

ITE

S

URVEY

– 5GH

Z

......................................................................................................... 54

F

IGURE

5-42

WPS-PBC – 5GH

Z

-1 ......................................................................................................... 56

F

IGURE

5-43

WPS-PBC – 5GH

Z

-2 ......................................................................................................... 56

F

IGURE

5-44

WPS-PIN – 5GH

Z

-1 ........................................................................................................... 57

F

IGURE

5-45

WPS-PIN – 5GH

Z

-2 ........................................................................................................... 57

F

IGURE

5-46

WPS-PIN – 5GH

Z

-3 ........................................................................................................... 57

F

IGURE

5-47

S

CHEDULE

5GH

Z

.............................................................................................................. 58

F

IGURE

5-48

2.4GH

Z

W

IRELESS

M

AIN

M

ENU

........................................................................................... 59

F

IGURE

5-49

2.4GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– AP ........................................................................... 60

F

IGURE

5-50

2.4GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– M

ULTIPLE

AP ............................................................ 62

F

IGURE

5-51

2.4GH

Z

M

ULTIPLE

-SSID ..................................................................................................... 63

F

IGURE

5-52

2.4GH

Z

U

NIVERSAL

R

EPEATER

-1 ........................................................................................ 64

F

IGURE

5-53

2.4GH

Z

U

NIVERSAL

R

EPEATER

-2 ........................................................................................ 64

F

IGURE

5-54

2.4GH

Z

U

NIVERSAL

R

EPEATER

-3 ........................................................................................ 65

F

IGURE

5-55

2.4GH

Z

U

NIVERSAL

R

EPEATER

-4 ........................................................................................ 65

F

IGURE

5-56

2.4GH

Z

U

NIVERSAL

R

EPEATER

-5 ........................................................................................ 65

F

IGURE

5-57

2.4GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– C

LIENT

..................................................................... 66

F

IGURE

5-58

C

LIENT

– S

URVEY

............................................................................................................... 68

F

IGURE

5-59

C

LIENT

– AP L

IST

................................................................................................................ 69

F

IGURE

5-60

C

LIENT

– S

ECURITY

............................................................................................................. 70

F

IGURE

5-61

C

LIENT

– S

TATUS

................................................................................................................ 70

F

IGURE

5-62

2.4GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– WDS ........................................................................ 71

F

IGURE

5-63

2.4GH

Z

W

IRELESS

B

ASIC

S

ETTINGS

– WDS+AP ................................................................. 73

F

IGURE

5-64

W

IRELESS

A

DVANCED

S

ETTINGS

– 2.4GH

Z

.......................................................................... 75

F

IGURE

5-65

RF O

UTPUT

P

OWER

– 2.4GH

Z

............................................................................................ 77

F

IGURE

5-66

W

IRELESS

S

ECURITY

S

ETTINGS

– 2.4GH

Z

........................................................................... 78

F

IGURE

5-67

W

IRELESS

A

CCESS

C

ONTROL

– 2.4GH

Z

.............................................................................. 80

F

IGURE

5-68

W

IRELESS

A

CCESS

C

ONTROL

– D

ENY

.................................................................................. 81

F

IGURE

5-69

WDS M

ODE

– 2.4GH

Z

........................................................................................................ 82

F

IGURE

5-70

WDS S

ETTINGS

– 2.4GH

Z

.................................................................................................. 83

F

IGURE

5-71

WDS – S

ET

S

ECURITY

........................................................................................................ 83

F

IGURE

5-72

S

ITE

S

URVEY

– 2.4GH

Z

...................................................................................................... 85

F

IGURE

5-73

WPS-PBC – 2.4GH

Z

-1 ...................................................................................................... 87

F

IGURE

5-74

WPS-PBC – 2.4GH

Z

-2 ...................................................................................................... 87

XIII

F

IGURE

5-75

WPS-PIN – 2.4GH

Z

-1 ........................................................................................................ 88

F

IGURE

5-76

WPS-PIN – 2.4GH

Z

-2 ........................................................................................................ 88

F

IGURE

5-77

WPS-PIN – 2.4GH

Z

-3 ........................................................................................................ 88

F

IGURE

5-78

S

CHEDULE

– 2.4GH

Z

.......................................................................................................... 89

F

IGURE

5-79

M

ANAGEMENT

– M

AIN

M

ENU

............................................................................................... 90

F

IGURE

5-80

S

TATUS

............................................................................................................................... 91

F

IGURE

5-81

S

TATISTICS

......................................................................................................................... 92

F

IGURE

5-82

T

IME

Z

ONE

S

ETTINGS

.......................................................................................................... 93

F

IGURE

5-83

S

CHEDULE

R

EBOOT

............................................................................................................ 94

F

IGURE

5-84

S

CHEDULE

R

EBOOT

E

XAMPLE

........................................................................................... 95

F

IGURE

5-85

S

YSTEM

L

OG

...................................................................................................................... 96

F

IGURE

5-86

U

PGRADE

F

IRMWARE

.......................................................................................................... 97

F

IGURE

5-87

S

AVE

/R

ELOAD

S

ETTINGS

..................................................................................................... 98

F

IGURE

5-88

P

ASSWORD

S

ETUP

.............................................................................................................. 99

F

IGURE

5-89

LED C

ONTROL

.................................................................................................................. 100

F

IGURE

5-90

L

OGOUT

............................................................................................................................ 100

F

IGURE

6-1

S

YSTEM

T

RAY

– W

IRELESS

N

ETWORK

I

CON

......................................................................... 101

F

IGURE

6-2

C

HOOSE A WIRELESS NETWORK

........................................................................................... 101

F

IGURE

6-3

E

NTER THE NETWORK KEY

................................................................................................... 102

F

IGURE

6-4

C

HOOSE A WIRELESS NETWORK

-C

ONNECTED

.................................................................... 102

F

IGURE

6-5

N

ETWORK ICON

................................................................................................................... 103

F

IGURE

6-6

WLAN A

UTO

C

ONFIG

........................................................................................................... 103

F

IGURE

6-7

T

YPE THE NETWORK KEY

..................................................................................................... 104

F

IGURE

6-8

C

ONNECTING TO A

N

ETWORK

............................................................................................... 104

F

IGURE

6-9

C

ONNECTED TO A

N

ETWORK

................................................................................................ 104

F

IGURE

6-10

M

AC

OS – N

ETWORK ICON

................................................................................................ 105

F

IGURE

6-11

H

IGHLIGHT AND SELECT THE WIRELESS NETWORK

............................................................... 105

F

IGURE

6-12

E

NTER THE

P

ASSWORD

..................................................................................................... 106

F

IGURE

6-13

C

ONNECTED TO THE

N

ETWORK

.......................................................................................... 106

F

IGURE

6-14

S

YSTEM

P

REFERENCES

..................................................................................................... 107

F

IGURE

6-15

S

YSTEM

P

REFERENCES

-N

ETWORK

................................................................................. 107

F

IGURE

6-16

S

ELECT THE

W

IRELESS

N

ETWORK

..................................................................................... 108

F

IGURE

6-17

I

P

HONE

– S

ETTINGS ICON

.................................................................................................. 109

F

IGURE

6-18

W

I

-F

I

S

ETTING

.................................................................................................................. 109

F

IGURE

6-19

W

I

-F

I

S

ETTING

– N

OT

C

ONNECTED

.................................................................................... 110

F

IGURE

6-20

T

URN ON

W

I

-F

I

................................................................................................................. 110

F

IGURE

6-21

I

P

HONE

-E

NTER THE

P

ASSWORD

...................................................................................... 111

F

IGURE

6-22

I

P

HONE

-C

ONNECTED TO THE

N

ETWORK

.......................................................................... 111

XIV

Chapter 1. Product Introduction

1.1 Package Contents

Thank you for choosing IFS WMC303-1W-1T-1200. Before installing the AP, please verify the contents inside the package box.

WMC303-1W-1T-1200 Quick Guide CD-ROM

Mounting Bracket Mounting Kit

(User Manual included)

If there is any item missing or damaged, please contact the seller immediately.

-1-

1.2 Product Description

Ceiling Mount Designed for Highly-efficient Wireless Coverage

Featuring attractive flying saucer appearance and ceiling-mount design, the WMC303-1200 can be firmly installed on the ceiling or the wall conveniently. The ceiling-mount design is smartly integrated into the environment. Its streamlined body without the protruding antennas also gives effects of embellishment in the surroundings. Moreover, the WMC303-1200 is compliant with the IEEE 802.3at PoE standard, so it is easy and flexible in client-side installation. It is definitely nice to have this eye-catching access point mount on the ceilings and walls of villas, hotels, exhibit halls, and other establishments.

Brand-new 11ac Wireless Technology

The WMC303-1200 supports IEEE 802.11a/b/g/n/ac dual band standards with 2T2R MIMO technology; therefore, it provides the wireless speed up to 300+867Mbps, which is 16X faster than the 11a access point at

5GHz frequency and 5.5X faster than the 11g access point at 2.4GHz frequency. Moreover, the WMC303-1200 is equipped with Gigabit Ethernet Port. Compared with the general wireless APs, the WMC303-1200 offers faster transmission speed for the network applications and less interference to enhance data throughput. The incredible wireless speed makes it ideal for handling multiple HD movie streams, high-resolution on-line games, stereo music, VoIPs and data streams at the same time stably and smoothly.

11ac Innovations Bring Excellent Data Link Speed

-2-

The WMC303-1200 is built-in with high power amplifier and 4 highly-sensitive antennas which provide stronger signal and excellent coverage even in the wide-ranging or bad environment. With adjustable transmit power option, the administrator can flexibly reduce or increase the output power for various environments, thus reducing interference to achieve maximum performance. To provide extremely high-speed user experience, the

WMC303-1200 adopts IEEE 802.11ac technology to extend the 802.11n 40MHz channel binding to 80MHz and the implementation of 256-QAM modulation where higher transmitting/receiving rates go up to 867Mbps in

5GHz less interference frequency band. In addition, the WMC303-1200 is equipped with gigabit LAN port to eliminate the restriction of 100Mbps Fast Ethernet wired connection to let users fully enjoy the high speed provided by wireless. The IEEE 802.11ac also optimizes MU-MIMO (Multi-User MIMO) mechanism to serve multiple devices simultaneously.

Full Support of Wireless Security Encryption and Wireless Value-added Features

In aspect of security, besides 64/128-bit WEP encryption, the WMC303-1200 is integrated with WPA / WPA2,

WPA-PSK / WPA2-PSK and 802.1x Radius authority to secure and protect your wireless LAN. It provides the wireless MAC filtering and SSID broadcast control to consolidate the wireless network security and prevent unauthorized wireless connection. Being an access point, the WMC303-1200 supports the VLAN function to allow multiple SSIDs (10 sets of SSIDs) to access Internal VLAN topology. Moreover, its Wi-Fi Multimedia (WMM) mechanism provides enhanced QoS over wireless connection for better performance in multimedia transmission like on-line gaming and video streaming, which are classified as a top priority.

-3-

Multiple Operation Modes for Various Applications

The WMC303-1200 supports AP, Client, WDS Bridge, Repeater and Universal Repeater modes, through which it provides more flexibility for users when wireless network is established. Compared with general wireless access point, the WMC303-1W-1T-1200 offers more powerful and flexible capability for wireless clients.

Flexible Deployment with PoE Feature

Compliant with the IEEE 802.3at Power over Ethernet standard, the WMC303-1200 can be powered and networked by a single UTP cable. It thus reduces the needs of extra cables and dedicated electrical outlets on the wall, ceiling or any other place where it is difficult to reach. The wireless network deployment becomes more flexible and worry-free from the power outlet locations.

-4-

Easy Installation and Management

With user-friendly Web UI and step-by-step Quick Setup Wizard, the WMC303-1200 is easy to install, even for users who never experience setting up a wireless network. Furthermore, with SNMP-based management interface, the WMC303-1200 is convenient to be managed and configured remotely in a small business wireless network.

-5-

1.3 Product Features

Standard Compliant Hardware Interface

Complies with IEEE 802.11ac (draft 2.0) and IEEE 802.11a/b/g/n standards

1 x 10/100/1000Base-TX Port with 1-port PoE (PD, Powered Device)

IEEE 802.3at Power over Ethernet design

RF Interface Characteristics

Features 2.4GHz (802.11b/g/n) and 5GHz (802.11a/n/ac) concurrent dual band for more efficiency of carrying high load traffic

2T2R MIMO technology for enhanced throughput and coverage

Provides multiple adjustable transmit power control

High speed up to 1.2Gbps (300Mbps for 2.4GHz + 867Mbps for 5GHz) wireless data rate

Comprehensive Wireless Advanced Features

Multiple Wireless Modes: AP, Client, WDS PtP/ PtMP, WDS Repeater, Universal Repeater

Supports up to 10 multiple-SSIDs (2.4GHz+5GHz) to allow users to access different networks through a single AP

Supports VLAN function to limit the clients to access the specific internal network resource

Supports WMM (Wi-Fi Multimedia) and wireless QoS to enhance the efficiency of multimedia application

Supports IAPP (Inter Access Point Protocol) and wireless roaming to enable clients to roam across different wireless networks

Supports 5-level Transmitting Power Control to adapt various environments

Supports wireless schedule to automatically enable or disable the wireless function based on predefined schedule

Secure Network Connection

Advanced security: 64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK (TKIP/AES encryption) and 802.1x Radius Authentication

Supports MAC address filtering

Easy Installation & Management

Flexible deployment with standard 802.3at PoE/ PD supported

Web-based UI and Quick Setup Wizard for easy configuration

Remote Management allows configuration from a remote site

SNMP-based management interface

System status monitoring includes DHCP Client and System Log

-6-

1.4 Product Specifications

Product

Antenna Structure

Modulation

Data Modulation

WMC303-1W-1T-1200

1200Mbps 802.11ac Dual Band Ceiling Mount Wireless Access Point

Hardware Specifications

Interfaces

Antennas

LAN

Gain:

1 x 10/100/1000Base-T RJ45 port

Auto-negotiation and Auto MDI/MDI-X

2 x 2.4GHz 2.5dBi PCBA antenna

2 x 5GHz 4dBi PCBA antenna

Reset Button

LED Indicators

Material

Dimensions

(Φ x H)

Weight

Power Requirements

Power Consumption

Mounting

Reset button on the top cover

Press over 7 seconds to reset the device to factory default

PWR

Allow LED to turn off via software control

Plastic

194 x 49 mm

300 ±5g

802.3at PoE, 48-56V DC input

20W (max.)

Ceiling Mount

Wireless Interface Specifications

Standard

IEEE 802.11ac (Draft 2.0) 5GHz

IEEE 802.11a/n 5GHz

IEEE 802.11b/g/n 2.4GHz

802.11ac: 2T2R MU-MIMO

802.11n: 2T2R MIMO

DSSS

802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)

802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)

802.11b: DSSS (DBPSK / DQPSK / CCK)

Band Mode

2.4G / 5G concurrent mode

Frequency Range

2.4GHz

America/ FCC: 2.412~2.462GHz

Europe/ ETSI: 2.412~2.484GHz

5GHz

America/ FCC: 5.180~5.240GHz, 5.725~5.850GHz

Europe/ ETSI: 5.180~5.240GHz

Operating Channels

Channel Width

2.4GHz

America/ FCC: 1~11

Europe/ ETSI: 1~13

5GHz

America/ FCC:

36, 40, 44, 48, 149, 153, 157, 161, 165

Europe/ ETSI:

36, 40, 44, 48

5GHz channel list will vary in different countries according to their regulations.

802.11ac: 20/40/80MHz

802.11n: 20/40MHz

-7-

Data Transmission

Rates

Transmission Distance

Max. RF Power

Receive Sensitivity

802.11ac (VHT20, Nss2-MCS8): Up to 173.3Mbps

802.11ac (VHT40, Nss2-MCS9): Up to 400Mbps

802.11ac (VHT80, Nss2-MCS9): Up to 867Mbps

802.11n (HT40): 270/243/216/162/108/81/54/27Mbps

135/121.5/108/81/54/40.5/27/13.5Mbps (dynamic)

802.11n (HT20): 130/117/104/78/52/39/26/13Mbps

65/58.5/52/39/26/19.5/13/6.5Mbps (dynamic)

802.11g: 54/48/36/24/18/12/9/6Mbps (dynamic)

802.11b: 11/5.5/2/1Mbps (dynamic)

802.11ac (draft): up to 30m

802.11n: up to 70m

802.11g: up to 30m

The estimated transmission distance is based on the theory. The actual distance will vary in different environments.

5GHz:

802.11ac (VHT20): 22dBm

802.11ac (VHT40): 22dBm

802.11ac (VHT80): 22dBm

802.11n (HT20): 22dBm

802.11n (HT40): 22dBm

802.11a: 22dBm

2.4GHz:

802.11n: 17 ±2.5dBm

802.11b/g: 20 ±2.5dBm

5GHz:

802.11ac (VHT20): -91dBm @ Nss1-MCS0, -64dBm @ Nss2-MCS8

802.11ac (VHT40): -89dBm @ Nss1-MCS0, -59dBm @ Nss2-MCS9

802.11ac (VHT80): -86dBm @ Nss1-MCS0, -56dBm @ Nss2-MCS9

802.11n (HT20): -92dBm @ MCS0, -71dBm @ MCS7

802.11n (HT40): -89dBm @ MCS0, -66dBm @ MCS15

802.11a: -93 @ 6Mbps, -75dBm @ 54Mbps

2.4GHz:

802.11n 20MHz (MCS7): -69dBm @10% PER

802.11n 40MHz (MCS15): -66dBm @10% PER

802.11g (54Mbps): -74dBm @10% PER

802.11b (11Mbps): -88dBm @10% PER

Software Features

Wireless Mode

Encryption Security

Universal Repeater

(AP+Client)

Repeater

(WDS+AP)

AP (Access Point)

WDS PTP (Point to Point)

WDS PTMP (Point to Multipoint)

Client

WEP (64/128-bit) encryption security

WPA / WPA2 (TKIP/AES)

WPA-PSK / WPA2-PSK (TKIP/AES)

Wireless Security

Provides wireless LAN ACL (Access Control List) filtering

Wireless MAC address filtering

-8-

Supports WPS (Wi-Fi Protected Setup)

Enable/ Disable SSID Broadcast

WMM (Wi-Fi Multimedia): 802.11e Wireless QoS

Multiple SSID: up to 5 at 2.4GHz and 5GHz, respectively

Wireless Advanced

Max. Clients

Wireless Isolation: Enables to isolate each connected wireless client from communicating with each other

IAPP (Inter Access Point Protocol): 802.11f Wireless Roaming

Provides Wireless Statistics

Wire: 253

2.4GHz Wireless: 32

5GHz Wireless: 32

Built-in DHCP server supporting static IP address distributing

Supports UPnP

LAN

Supports 802.1d Spanning Tree

Supports 802.1Q VLAN

Web-based (HTTP) management interface

SNTP time synchronize

System Management

Easy firmware upgrade

Supports Scheduling Reboot

Standards Conformance

IEEE Standards

IEEE 802.11ac (Draft 2.0, 2T2R, up to 867Mbps)

IEEE 802.11n (2T2R, up to 300Mbps)

IEEE 802.11g

IEEE 802.11b

IEEE 802.11i

IEEE 802.3 10Base-T

IEEE 802.3u 100Base-TX

IEEE 802.3ab 1000Base-T

IEEE 802.3x Flow Control

Other Protocols and

CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, SNTP

Standards

Environment & Certification

Operating: 0 ~ 50 degrees C

Temperature

Storage: -40 ~ 70 degrees C

Humidity

Regulatory

Operating: 10 ~ 90% (non-condensing)

Storage: 5 ~ 90% (non-condensing)

FCC Part 15B & 15C, IC, RoHS

-9-

Chapter 2. Hardware Installation

Please follow the instructions below to connect WMC303-1W-1T-1200 to the existing network devices and your computers.

2.1 Product Outlook

Dimensions: 194 x 49 mm

(

Φ x H)

Drawing :

Figure 2-1 WMC303-1W-1T-1200 Product Drawing

-10-

2.1.1 Panel Layout

The front and rear panel provide a simple interface monitoring the AP. Figure 2-2 shows the hardware interface of the WMC303-1W-1T-1200.

Hardware Interface

Figure 2-2 WMC303-1W-1T-1200 Panel Layout

2.1.2 Hardware Description

LED definition

LED

PWR

COLOR STATUS

Green

On

Green

Orange

Off

On

Orange

Blinking

FUNCTION

Device power on

Device power off (control by S/W)

System initializing, turned it off when system completed

Detect and identify the LED (control by S/W)

1) Position LED on: LED blinks continuously.

2) Position LED off: the LED is off.

Button definition

Object

Reset

Description

To restore to the factory default setting, press and hold the Reset Button over 7 seconds, and then release it.

Port definition

Object

PoE Port

(802.3at PoE)

Description

10/100/1000Mbps RJ-45 port , Auto MDI/ MDI-X

Connect PoE port to the IEEE 802.3at PSE to power on the device.

-11-

Chapter 3. Connecting to the AP

3.1 System Requirements

 Broadband Internet Access Service (Cable/xDSL/Ethernet connection)

 One IEEE 802.3at PoE switch (supply power to the WMC303-1200)

PCs with a working Ethernet Adapter and an Ethernet cable with RJ-45 connectors

PCs running Windows 98/ME, NT4.0, 2000/XP, Windows Vista / Win 7, MAC OS 9 or later, Linux,

UNIX or other platforms compatible with TCP/IP protocols

1. The AP in the following instructions refers to IFS WMC303-1200.

2. It is recommended to use Internet Explorer 7.0 or above to access the AP.

3.2 Installing the AP

Before installing the AP, make sure your PoE switch is connected to the Internet through the broadband service successfully at this moment. If there is any problem, please contact your local ISP. After that, please install the

AP according to the following steps. Don't forget to pull out the power plug and keep your hands dry.

Step 1. Drill the outlet hole indicated on the mounting label and stick the given mounting label to the installation location to let the Ethernet cable penetrate the outlet hole. Then, drill the mounting holes as indicated on the label.

Figure 3-1 WMC303-1200 Installation Diagram 1

Step 2. Take the mounting bracket, put it on the target place by aligning the holes and fix it with the supplied

-12-

screws.

※ IEEE 802.3at PoE switch is required.

Figure 3-2 WMC303-1200 Installation Diagram 2

Step 3. Plug the RJ-45 Ethernet cable into the PoE port of the WMC303-1W-1T-1200.

Figure 3-3 WMC303-1200 Installation Diagram 3

Step 4. Load the device into the mounting bracket, and be sure the device is mated with two fixed screws.

Then, rotate the device clockwise to lock it in position.

-13-

Figure 3-4 WMC303-1200 Installation Diagram 4

Step 5. Plug the other end of the Ethernet cable into the PoE switch.

Figure 3-5 WMC303-1200 Installation Diagram 4

-14-

Chapter 4. Quick Installation Guide

This chapter will show you how to configure the basic functions of your AP within minutes.

A computer with wired Ethernet connection to the Wireless AP is required for the first-time configuration.

4.1 Manual Network Setup - TCP/IP Configuration

The default IP address of the WMC303-1200 is

192.168.0.253

. And the default Subnet Mask is 255.255.255.0.

These values can be changed as you want. In this guide, we use all the default values for description.

Connect the WMC303-1200 with your PC by an Ethernet cable plugging in LAN port on one side and in LAN port of PC on the other side. Please power on the WMC303-1200 by PoE switch through the PoE port.

In the following sections, we’ll introduce how to install and configure the TCP/IP correctly in Windows 7. And the procedures in other operating systems are similar. First, make sure your Ethernet Adapter is working, and refer to the Ethernet adapter manual if needed.

4.1.1 Configuring the IP Address Manually

Summary:

 Set up the TCP/IP Protocol for your PC.

 Configure the network parameters. The IP address is 192.168.1.xxx (if the default IP address of the

WMC303-1200 is 192.168.0.253, and the DSL router is 192.168.0.253, the "xxx" can be configured to any number from 1 to 252), Subnet Mask is 255.255.255.0.

1

Select Use the following IP address radio button, and then configure the IP address of the PC.

2

For example, as the default IP address of the WMC303-1200 is 192.168.0.253 and the DSL router is

192.168.0.253, you may choose from 192.168.0.1 to 192.168.0.252.

-15-

Figure 4-1 TCP/IP Setting

Now click OK to save your settings.

Now, you can run the Ping command in the command prompt to verify the network connection between your

PC and the AP. The following example is in Windows 7 OS. Please follow the steps below:

1. Click on Start > Run.

2. Type “cmd” in the Search box.

Figure 4-2 Windows Start Menu

-16-

3. Open a command prompt, type ping 192.168.0.253 and then press Enter.

If the result displayed is similar to

Figure 4-3

, it means the connection between your PC and the AP has been established well.

Figure 4-3 Successful result of Ping command

If the result displayed is similar to

Figure 4-4

, it means the connection between your PC and the AP has failed.

Figure 4-4 Failed Result of Ping Command

If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your AP. Some firewall software programs may block a DHCP request on newly installed adapters.

-17-

4.2 Starting Setup in the Web UI

It is easy to configure and manage the AP with the web browser.

Step 1.

To access the configuration utility, open a web-browser and enter the default IP address http://192.168.0.253

in the web address field of the browser.

Figure 4-5 Login by default IP address

After a moment, a login window will appear. Enter admin for the User Name and Password, both in lower case letters. Then click the OK button or press the Enter key.

Figure 4-6 Login Window

Default IP Address: 192.168.0.100

Default User name: admin

Default Password: admin

If the above screen does not pop up, it may mean that your web-browser has been set to a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings on the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it.

-18-

Chapter 5. Configuring the AP

This chapter delivers a detailed presentation of AP’s functionalities and features under 6 main menus below, allowing you to manage the AP with ease.

Figure 5-1 Main Menu

During operation, if you are not clear about a certain feature, you can refer to the “Help” section in the right side of the screen to read all related helpful info.

5.1 Setup Wizard

The Setup Wizard will guide the user to configure the WMC303-1200 easily and quickly. Select the Setup Wizard on the left side of the screen and by clicking on Next on the Setup Wizard screen shown below, you will then name your WMC303-1200 and set up its security.

Figure 5-2 Setup Wizard

-19-

Step 1: LAN Interface Setup

Figure 5-3 LAN Interface SetupTopology

Figure 5-4 Wizard – LAN Interface Setup

The page includes the following fields:

Object

IP Address

Subnet Mask

Default Gateway

Description

Displays the current IP address of the AP. (Default = 192.168.0.100)

Displays LAN mask of the AP. (Default = 255.255.255.0)

IP address of the associated router. (Default = 192.168.0.253)

Step 2: Time Zone Setting

Figure 5-5 Time Zone Setup Topology

-20-

Figure 5-6 Wizard – Time Zone Setup

The page includes the following fields:

Object

Enable NTP client update

Automatically adjust

Daylight Saving

Time Zone Select

NTP Server

Enable NTP client update

Description

Check this box to connect NTP Server and synchronize internet time.

Check this box and system will adjust the daylight saving automatically.

Select the Time Zone from the drop-down menu.

Select the NTP Server from the drop-down menu.

Check this box to connect NTP Server and synchronize internet time.

Step 3: Wireless 5GHz Basic Settings

Figure 5-7 Wizard – Wireless 5GHz Basic Settings

The page includes the following fields:

-21-

Object

Band

Mode

SSID

Channel Width

Control Sideband

Channel Number

Description

Supports 802.11a, 802.11n, 802.11ac and mixed. Please choose its band according to your clients.

Supports AP, Client, WDS and AP+WDS mode.

Service Set Identifier identifies your wireless network.

Select 80MHz if you use 802.11ac; select 40MHz if you use 802.11n; otherwise, 20MHz for the 802.11a mode.

It is only valid when you choose channel width 40MHz.

Indicates the channel setting for the AP.

Step 4: Wireless 5GHz Security Settings

Secure your wireless network by turning on the WPA or WEP security feature on the router. For this section you can set WEP and WPA-PSK security mode.

Figure 5-8 Wizard – Wireless 5GHz Security Setup

Encryption: WEP

The following picture shows how to set the WEP security.

Figure 5-9 5GHz Wireless Security Setup – WEP Setting

The page includes the following fields:

Object

Key length

Key Format

Key Setting

Description

WEP supports 64-bit or 128-bit security key.

User can enter key in ASCII or Hex format.

Enter the key whose format is limited by the Key format, ASCII or Hex.

-22-

Encryption: WPA-PSK

The following picture shows how to set up WPA-PSK security. You can select

WPA (TKIP)

,

WPA2 (AES)

and

Mixed mode

.

Figure 5-10 5GHz Wireless Security Setup – WPA Setting

The page includes the following fields:

Object

Pre-Shared Key Format

Pre-Shared Key

Description

Specify the format of the key, pass phrase or hex.

Enter the key whose format is limited by the key format.

Step 5: Wireless 2.4GHz Basic Settings

Figure 5-11 Wizard – Wireless 2.4GHz Basic Settings

-23-

The page includes the following fields:

Object

Band

Mode

SSID

Channel Width

Control Sideband

Channel Number

Description

Supports 802.11b, 802.11g, 802.11n and mixed. Please choose its band according to your clients.

Supports AP, Client, WDS and AP+WDS mode.

Service Set Identifier, it identifies your wireless network.

Select 40MHz if you use 802.11n, otherwise 20MHz for the 802.11b/g mode.

It is only valid when you choose channel width 40MHz.

Indicates the channel setting for the AP.

Step 6: Wireless 2.4GHz Security Settings

Secure your wireless network by turning on the WPA or WEP security feature on the router. For this section you can set WEP and WPA-PSK security mode.

Figure 5-12 Wizard – Wireless 2.4GHz Security Setup

Encryption: WEP

The following picture shows how to set the WEP security.

Figure 5-13 2.4GHz Wireless Security Setup – WEP Setting

-24-

The page includes the following fields:

Object

Key Length

Key Format

Key Setting

Description

WEP supports 64-bit or 128-bit security key.

User can enter key in ASCII or Hex format.

Enter the key whose format is limited by the Key format, ASCII or Hex.

Encryption: WPA-PSK

The following picture shows how to set WPA-PSK security. You can select

WPA (TKIP)

,

WPA2 (AES)

and

Mixed mode

.

Figure 5-14 2.4GHz Wireless Security Setup – WPA Setting

The page includes the following fields:

Object

Pre-Shared Key Format

Pre-Shared Key

Description

Specify the format of the key, pass phrase or hex.

Enter the key whose format is limited by the key format.

Click the Finished button to make your wireless configuration to take effect and finish the Setup Wizard.

-25-

Figure 5-15 Setup Wizard - Finished

After rebooting, please check whether you can access the Internet or not on the “Status” page.

-26-

5.2 TCP / IP Settings

This page is used to configure the parameters for local area network which connects to the LAN port of your AP.

Here you may change the setting for IP address, subnet mask, DHCP, etc.

5.2.1 LAN Settings

On the LAN Settings page, you can configure the IP parameters of the LAN on the screen as shown below.

Figure 5-16 LAN Setting

The page includes the following fields:

Object

IP Address

Description

The default LAN IP address of the WMC303-1W-1T-1200 is

192.168.0.100. You can change it according to your request.

Default is 255.255.255.0. You can change it according to your request.

Subnet Mask

Default Gateway

DHCP

DHCP Client Range

Default is 192.168.0.253. You can change it according to your request.

You can select a Disabled, Client, and Server. Default is Disabled, meaning the WMC303-1200 must connect to a router to assign IP addresses to clients.

For the Server mode, you must enter the DHCP client IP address range in the field. And you can click the “Show Client” button to show

-27-

the Active DHCP Client Table.

Static DHCP

Click the “Set Static DHCP” button and you can reserve some IP addresses for those network devices with the specified MAC addresses anytime when they request IP addresses.

Default is IFS.

Domain Name

802.1d Spanning Tree

You can enable or disable the Spanning Tree function.

Clone MAC Address

UPnP Enable

You can input an MAC address here for using clone function.

You can enable or disable the UPnP function.

The UPnP feature allows the devices, such as Internet computers, to access the local host resources or devices as needed. UPnP devices can be automatically discovered by the UPnP service application on the LAN.

If you change the IP address of LAN, you must use the new IP address to login the

AP.

When the IP address of the WMC303-1200 is changed, the clients on the network often need to wait for a while or even reboot before they can access the new IP address. For an immediate access to the AP, please flush the netbios cache on the client computer by running the “nbtstat –r” command before using the device name of the WMC303-1200 to access its Web Management page.

-28-

5.3 WLAN1 (5GHz)

The wireless menu of WLAN1 (5GHz) contains submenus of the settings about wireless network. Please refer to the following sections for the details.

Figure 5-17 5GHz Wireless Main Menu

5.3.1 Basic Settings

Choose menu “WLAN1 (5GHz)

Basic Settings” and you can configure the 5GHz basic settings for the wireless network on this page. After the configuration is done, please click the “Apply Changes” button to save the settings.

First of all, the wireless AP supports multiple wireless modes for different network applications, which include:

AP

Multiple SSIDs

Universal Repeater

Client

WDS

AP+WDS

It is so easy to combine the WMC303-1W-1T-1200 with the existing wired network. The WMC303-1W-1T-1200 definitely provides a total network solution for the home and the SOHO users.

-29-

AP

Standard Access Point

Figure 5-18 5GHz Wireless Basic Settings of AP

-30-

The page includes the following fields:

Object Description

Disable Wireless LAN

Check the box to disable the wireless function.

Interface

Band

Mode

Select the desired mode. Default is “5GHz (A+N+AC)”. It is strongly recommended that you set the Band to “5GHz (A+N+AC)”, and all of

802.11a, 802.11n, and 802.11ac wireless stations can connect to the

WMC303-1W-1T-1200.

5 GHz (A): 802.11a mode, rate is up to 54Mbps

5 GHz (N): 802.11n mode, rate is up to 300Mbps

5 GHz (AC): 802.11n mode, rate is up to 867Mbps(2T2R)

5 GHz (A+N): 802.11a/n mode, rate is up to 300Mbps

5 GHz (N+AC): 802.11n/ac mode, rate is up to 300Mbps or

867Mbps

5 GHz (A+N+AC): 802.11a/n/ac mode, rate is up to 54Mbps,

300Mbps, or 867Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

SSID

Channel Width

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID functions.

The ID of the wireless network. User can access the wireless network through it only. However, if you switch to Client Mode, this field becomes the SSID of the AP you want to connect with.

Default: IFS AP 5G

You can select 20MHz, 40MHz or 80MHz.

Channel Number

Broadcast SSID

Data Rate

You can select the operating frequency of wireless network.

Default: 40

If you enable “Broadcast SSID”, every wireless station located within the coverage of the AP can discover its signal easily. If you are building a public wireless network, enabling this feature is recommended. In private network, disabling “Broadcast SSID” can provide better wireless network security.

Default is “Enabled”.

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data

-31-

transfer rate automatically, it’s not necessary to change this value

unless you know what will happen after modification.

Default is “Auto”.

Associated Clients

Enable Universal

Repeater Mode

(Acting as AP and client simultaneously)

Click the “Show Active Clients” button to show the status table of active wireless clients.

Universal Repeater is a technology used to extend wireless coverage.

To enable Universal Repeater Mode, check the box and enter the

SSID you want to broadcast in the field below. Then please click

“Security” submenu for the related settings of the AP you want to connect with.

Multiple-SSID

Enable multiple-SSID can broadcast multiple WLAN SSID's using virtual interfaces. You can have different encryption settings for each WLAN and you can restrict what they have access to.

Choose menu “WLAN1 (5GHz)

→ Basic Settings → Multiple AP” to configure the device as a general wireless access point with multiple SSIDs.

Figure 5-19 5GHz Wireless Basic Settings – Multiple AP

The device supports up to four multiple Service Set Identifiers. You can back to the Basic Settings page to set the Primary SSID. The SSID’s factory default setting is IFS 5G VAP1~4 (Multiple-SSID 1~4). The SSID can be easily changed to connect to an existing wireless network or to establish a new wireless network.

-32-

When the information for the new SSID is finished, click the Apply Changes button to let your changes take effect.

Figure 5-20 5GHz Multiple-SSID

Once you have applied and saved those settings, you can then go to the “WLAN1 (5GHz)

→ Security” page on the AP to set up security settings for each of the SSIDs.

Universal Repeater

This mode allows the AP with its own BSS to relay data to a root AP to which it is associated with WDS disabled. The wireless repeater relays signal between its stations and the root AP for greater wireless range.

1. Example of how to configure Universal Repeater Mode. Please take the following steps:

To configure each wireless parameter, please go to the “WLAN1 (5GHz)

→ Basic Settings” page.

Step 1. Configure wireless mode to “AP” and then check “Enable Universal Repeater Mode (Acting as AP

and client simultaneously)”. Click “Apply Changes” to take effect.

-33-

Figure 5-21 5GHz Universal Repeater-1

Step 2. Go to 5GHz Site Survey page to find the root AP. Select the root AP that you want to repeat the signal and then click “Next”.

Figure 5-22 5GHz Universal Repeater-2

Step 3. Select the correct encryption method and enter the security key. Then, click “Connect”.

-34-

Figure 5-23 5GHz Universal Repeater-3

Step 4. Check “Add to Wireless Profile” and click “Reboot Now”.

Figure 5-24 5GHz Universal Repeater-4

Step 5. Go to “Management-> Status” page to check whether the state of Repeater interface should be

Connected”.

Figure 5-25 5GHz Universal Repeater-5

-35-

Client (Infrastructure)

Combine the Wireless Router to the Ethernet devices such as TV, game player, or HDD and DVD, to make them be wireless stations.

Figure 5-26 5GHz Wireless Basic Settings – Client

-36-

The page includes the following fields:

Object Description

Disable Wireless LAN

Check the box to disable the wireless function.

Interface

Band

Mode

Select the desired mode. Default is “5GHz (A+N+AC)”. It is strongly recommended that you set the Band to “5GHz (A+N+AC)”, and all of

802.11a, 802.11n, and 802.11ac wireless stations can connect to the

WMC303-1200.

5 GHz (A): 802.11a mode, rate is up to 54Mbps

5 GHz (N): 802.11n mode, rate is up to 300Mbps

5 GHz (AC): 802.11n mode, rate is up to 867Mbps(2T2R)

5 GHz (A+N): 802.11a/n mode, rate is up to 300Mbps

5 GHz (N+AC): 802.11n/ac mode, rate is up to 300Mbps or

867Mbps

5 GHz (A+N+AC): 802.11a/n/ac mode, rate is up to 54Mbps,

300Mbps, or 867Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID function.

Network Type

SSID

Broadcast SSID

In Infrastructure, the wireless LAN serves as a wireless station. And the user can use the PC equipped with the WMC303-1200 to access the wireless network via other access points. In Ad hoc, the wireless

LAN will use the Ad-hoc mode to operate.

Default is “Infrastructure”.

Note: Only while the wireless mode is set to “Client”, then the

Network Type can be configured.

The ID of the wireless network. User can access the wireless network via its ID. However, if you switch to Client mode, this field becomes the

SSID of the AP you want to connect with.

Default: WMC303 5G

If you enable “Broadcast SSID”, every wireless station located within the coverage of the WMC303-1200 can discover its signal easily. If you are building a public wireless network, enabling this feature is recommended. In private network, disabling “Broadcast SSID” can provide better wireless network security.

-37-

Data Rate

Default is “Enabled”.

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically, it’s not necessary to change this value

unless you know what will happen after modification.

Default is “Auto”.

Enable Mac Clone

(Single Ethernet Client)

Enable Mac Clone.

Example of how to configure Client Mode. Please take the following steps:

To configure each wireless parameter, please go to the “WLAN1 (5GHz)

→ Basic Settings” page.

Step 1. Go to “WLAN1 (5GHz)

→ Site Survey” page and click “Site Survey” button.

Figure 5-27 Client – Survey

Step 2. Choose the root AP from the list. If the root AP is not listed in the table, re-click “Site Survey” to update the list.

-38-

Figure 5-28 Client – AP List

Step 3. Enter the Security Key of the root AP and then click “Connect”.

Figure 5-29 Client – Security

Step 4. Wait until the connection established. Check the “Add to Wireless Profile” option and then reboot it.

-39-

Figure 5-30 Client – Status

WDS

Connect this Wireless AP with up to 8 WDS-capable wireless APs to expand the scope of network.

-40-

Figure 5-31 5GHz Wireless Basic Settings – WDS

The page includes the following fields:

Object Description

Disable Wireless LAN

Check the box to disable the wireless function.

Interface

Band

Select the desired mode. Default is “5GHz (A+N+AC)”. It is strongly recommended that you set the Band to “5GHz (A+N+AC)”, and all of

802.11a, 802.11n, and 802.11ac wireless stations can connect to the

WMC303-1200.

5 GHz (A): 802.11a mode, rate is up to 54Mbps

5 GHz (N): 802.11n mode, rate is up to 300Mbps

5 GHz (AC): 802.11n mode, rate is up to 867Mbps(2T2R)

5 GHz (A+N): 802.11a/n mode, rate is up to 300Mbps

5 GHz (N+AC): 802.11n/ac mode, rate is up to 300Mbps or

-41-

Mode

Channel Width

Control Sideband

Channel Number

Data Rate

867Mbps

5 GHz (A+N+AC): 802.11a/n/ac mode, rate is up to 54Mbps,

300Mbps, or 867Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID function.

You can select 20MHz, 40MHz or 80MHz.

You can select Upper or Lower.

You can select the operating frequency of wireless network.

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically, it’s not necessary to change this value

unless you know what will happen after modification.

Default is “Auto”.

-42-

AP+ WDS

Connect this wireless AP with up to 8 WDS-capable wireless APs, and connect another AP to provide service for all wireless stations within its coverage.

Figure 5-32 5GHz Wireless Basic Settings – WDS+AP

-43-

The page includes the following fields:

Object Description

Disable Wireless LAN

Check the box to disable the wireless function.

Interface

Country

Band

Mode

Select your region from the pull-down list.

This field specifies the region where the wireless function of the Router can be used. It may be illegal to use the wireless function of the Router in a region other than one of those specified in this field. If your country or region is not listed, please contact your local government agency for assistance.

Select the desired mode. Default is “5GHz (A+N+AC)”. It is strongly recommended that you set the band to “5GHz (A+N+AC)”, and all of

802.11a, 802.11n, and 802.11ac wireless stations can connect to the

WMC303-1200.

5 GHz (A): 802.11a mode, rate is up to 54Mbps

5 GHz (N): 802.11n mode, rate is up to 300Mbps

5 GHz (AC): 802.11n mode, rate is up to 867Mbps(2T2R)

5 GHz (A+N): 802.11a/n mode, rate is up to 300Mbps

5 GHz (N+AC): 802.11n/ac mode, rate is up to 300Mbps or

867Mbps

5 GHz (A+N+AC): 802.11a/n/ac mode, rate is up to 54Mbps,

300Mbps, or 867Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

SSID

Channel Width

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID functions.

The ID of the wireless network. User can access the wireless network via its ID only. However, if you switch to Client Mode, this field becomes the SSID of the AP you want to connect with.

Default: WMC303 5G

You can select 20MHz, 40MHz or 80MHz.

Control Sideband

Channel Number

Broadcast SSID

You can select Upper or Lower.

You can select the operating frequency of wireless network.

If you enable “Broadcast SSID”, every wireless station located within the coverage of the WMC303-1200 can discover its signal easily. If you are building a public wireless network, enabling this feature is

-44-

Data Rate

recommended. In private network, disabling “Broadcast SSID” can provide better wireless network security.

Default is “Enabled”.

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically, it’s not necessary to change this value

unless you know what will happen after modification.

Default is “Auto”.

Associated Clients

Enable Universal

Repeater Mode

(Acting as AP and client simultaneously)

Click the “Show Active Clients” button to show the status table of active wireless clients.

Universal Repeater is a technology used to extend wireless coverage.

To enable Universal Repeater mode, check the box and enter the

SSID you want to broadcast in the field below. Then please click

“Security” submenu for the related settings of the AP you want to connect with.

5.3.2 Advanced Settings

Choose menu “WLAN1 (5GHz)

Advanced Settings” and you can configure the 5GHz advanced settings for the wireless network on this page. After the configuration, please click the “Apply” button to save the settings.

Figure 5-33 Wireless Advanced Settings – 5GHz

The page includes the following fields:

-45-

Object

Fragment Threshold

RTS Threshold

Beacon Interval

IAPP

Protection

Aggregation

Short GI

WLAN Partition

STBC

LDPC

Description

You can specify the maximum size of packet during the fragmentation of data to be transmitted. If you set this value too low, it will result in bad performance.

Default is “2346”.

When the packet size is smaller than the RTS threshold, the access point will not use the RTS/CTS mechanism to send this packet.

Default is “2347”.

The interval of time that this access point broadcasts a beacon.

Beacon is used to synchronize the wireless network. Default is “100”.

IAPP (Inter-Access Point Protocol) enabled is recommended as it describes an optional extension to IEEE 802.11 that provides wireless access-point communications among multivendor systems.

Default is “Enabled”.

It is recommended to enable the protection mechanism. This mechanism can decrease the rate of data collision between 802.11b and 802.11g wireless stations. When the protection mode is enabled, the throughput of the AP will be a little lower due to the transmission of heavy frame traffic.

Default is “Disabled”.

It is a function where the values of multiple rows are grouped together.

Default is “Enabled”

It is used to set the time that the receiver waits for RF reflections to settle out before sampling data.

Default is “Enabled”

This feature is also called “WLAN isolation” or “Block Relay”. If this is enabled, wireless clients cannot exchange data through the

WMC303-1200.

Default is “Disabled”.

Activate Space Time Blocking Code (STBC) which does not need channel statement information (CSI).

Default Setting: "Enabled"

Low-density Parity-check Code is wireless data transmit algorithm.

Default Setting: "Enabled"

5.3.3 RF Output Power

Choose menu “WLAN1 (5GHz)

RF Output Power” to adjust to different levels of transmitting power for the wireless network according to various environments on this page. After the configuration, please click the “Apply

Changes” button to save the settings.

-46-

Figure 5-34 RF Output Power – 5GHz

RF Output Power Control provides the flexibility to control the Wi-Fi transmit power to optimize the wireless range. Wi-Fi power consumption for an Access Point could be reduced to up to 75% from its peak power consumption for serving small to medium size homes, while boosted to maximum power for large homes and businesses. The WMC303-1200 supports output power control levels up to 5. You can change the RF output power level here in accordance with various environments and signal strength.

5.3.4 Security

Choose menu “WLAN1 (5GHz)

Security” and you can configure the settings of wireless security for the wireless network on this page. After the configuration, please click the “Apply Changes” button to save the settings.

Figure 5-35 Wireless Security Settings – 5GHz

-47-

The page includes the following fields:

Object

Select SSID

Encryption

Description

Select the SSID you want to configure the wireless security function, which includes the root one and the client one.

Disable:

No security setup for wireless connection.

WEP:

It is based on the IEEE 802.11 standard. And the default setting of authentication is Automatic, which can select Open System or Shared Key authentication type automatically based on the wireless station's capability and request. Furthermore, you can select Key Length and enter 10 and 26

Hexadecimal digits (any combination of 0-9, a-f, A-F, zero key is not promoted) or 5 and 13 ASCII characters in the Encryption Key field.

WPA:

WPA is a medium level encryption and is supported by most wireless devices and operating systems.

WPA2:

WPA2 is a high level encryption and is supported by most wireless devices and operating systems.

WPA / WPA2 / WPA-Mixed:

WPA Mixed Mode allows the use of both WPA and WPA2 at the same time.

Authentication Mode

Enterprise (RADIUS)

When you select the authentication mode based on Enterprise (Radius

Server), please enter the IP Address, Port, and Password of the Radius

Server.

Personal (Pre-Shared Key)

When you select the other authentication mode based on Personal

(Pre-Shared Key), please enter at least 8 ASCII characters (Passphrase) or

64 Hexadecimal characters. All of the Cipher Suites support TKIP and AES.

802.1x Authentication

Enable 802.1x authentication function and then please enter the IP Address,

Port, and Password of the Radius Server.

5.3.5 Access Control

Choose menu “WLAN1 (5GHz)

Access Control” to allow or deny the computer of specified MAC address to connect with the WMC303-1200 on this page. After the configuration, please click the “Apply Changes” button to save the settings.

-48-

Figure 5-36 Wireless Access Control – 5GHz

The page includes the following fields:

Object

Wireless Access

Control Mode

MAC Address

Description

You can choose to set the Allowed-List, Denied-List, or disable this function.

Comment

Enter the MAC address you want to allow or deny connection to the

WMC303-1200 in the field.

You can make some comment on each MAC address on the list.

Current Access Control

List

You can select some MAC addresses and click the “Delete Selected” button to delete it.

To deny a PC at the MAC address of 9c:F6:1A:00:00:01 (for example) to connect to your wireless network, do as follows:

Step 1.

Select “Deny” from MAC Address Filter drop-down menu.

Step 2.

Enter 9c:F6:1A:00:00:01 in the MAC address box and click “Add”.

Step 3.

Click the “OK” button to save your settings and you can add more MAC addresses, if you like, simply repeat the above steps.

-49-

Figure 5-37 Wireless Access Control – Deny

-50-

5.3.6 WDS

WDS (Wireless Distribution System) feature can be used to extend your existing 2.4G or 5G wireless network coverage. Here we present you how to configure such feature in 2.4GHz, which also applies to 5GHz.

Before configuring the WDS Setting page, you have to select the wireless mode to “WDS” on the WLAN1 (5GHz)

-> Basic Settings web page.

-51-

Figure 5-38 WDS Mode – 5GHz

Choose menu “WLAN1 (5GHz)

WDS Settings” to configure WDS to connect the WMC303-1W-1T-1200 with another AP on this page. After the configuration, please click the “Apply Changes” button to save the settings.

Figure 5-39 WDS Settings – 5GHz

-52-

The page includes the following fields:

Figure 5-40 WDS – Set Security

Object

Enable WDS

MAC Address

Data Rate

Description

Check the box to enable the WDS function. Please select WDS or

AP+WDS in the Mode of Wireless Basic Settings before you enable

WDS on this page.

You can enter the MAC address of the AP you want to connect with.

Default is “Auto”.

Comment

Set Security

You can make some comment for each MAC address on the list.

Click the “Set Security” button to configure the wireless security parameters of the AP you want to connect via WDS.

Click the “Show Statics” button to show the WDS AP.

Show Statics

Current WDS AP List

You can select some MAC addresses of the AP and click the “Delete

Selected” button to delete it.

WDS feature can only be implemented between 2 wireless devices that both support the WDS feature. Plus, channel, security settings and security key must be the same on both such devices.

To encrypt your wireless network, click “Set Security”. For the detail of wireless security, see

section 5.3.3

. Do remember to reboot the device after you save your wireless security settings;

otherwise, the WDS feature may not function.

-53-

5.3.7 Site Survey

Choose menu “WLAN1 (5GHz)

Site Survey” to scan the available local AP. If any Access Point is found, you could choose any one to connect with manually when the Client Mode is enabled.

Figure 5-41 Site Survey – 5GHz

5.3.8 WPS

WPS (Wi-Fi Protected Setup) is designed to ease setup of security Wi-Fi networks and subsequently network management. This Wireless Router supports WPS features for AP mode, AP+WDS mode,

Infrastructure-Client mode, and the wireless root interface of Universal Repeater mode.

Simply enter a PIN code or press the software PBC button or hardware WPS button (if any) and a secure wireless connection is established.

PBC: If you find the WPS LED blinking for 2 minutes after you press the hardware WPS button on the device, it means that PBC encryption method is successfully enabled. And an authentication will be performed between your router and the WPS/PBC-enabled wireless client device during this time; if it succeeds, the wireless client device connects to your device, and the WPS LED turns off. Repeat steps mentioned above if you want to connect more wireless client devices to the device.

PIN:To use this option, you must know the PIN code from the wireless client and enter it in corresponding field on your device while using the same PIN code on client side for such connection.

-54-

The page includes the following fields:

Object

Disable WPS

Description

You can check the box to disable the WPS function.

WPS Status

Self-PIN Number

Here you can check if the connection via WPS is established or not.

It is the PIN number of the WMC303-1W-1T-1200 here.

Push Button

Configuration

Client PIN Number

Click the “Start PBC” to activate WPS as well in the client device within

2 minutes.

In addition to the PBC method, you can also use the PIN method to activate the WPS. Just enter the PIN number of the client device in the field and click the “Start PIN” button.

The WPS encryption can be implemented only between your Router and another

WPS-capable device.

Example of how to establish wireless connection using WPS. Please take the following steps:

Step 1. Choose menu “WLAN1 (5GHz)

WPS” to configure the setting for WPS. After the configuration, please click the “Apply Changes” button to save the settings.

Step 2. Add a new device.

If the wireless adapter supports Wi-Fi Protected Setup (WPS), you can establish a wireless connection between wireless adapter and AP using either Push Button Configuration (PBC) method or PIN method.

To build a successful connection by WPS, you should also do the corresponding configuration of the new device for WPS function.

A. By Push Button Configuration (PBC)

-55-

i. Click the “Start PBC” Button on the WPS page of the AP.

Figure 5-42 WPS-PBC – 5GHz-1

Figure 5-43 WPS-PBC – 5GHz-2 ii. iii.

Press and hold the WPS Button equipped on the adapter directly for 2 or 3 seconds. Or you can click the WPS button with the same function in the configuration utility of the adapter. The process must be finished within 2 minutes.

Wait for a while until the next screen appears. Click OK to complete the WPS configuration.

B. By PIN

If the new device supports Wi-Fi Protected Setup and the PIN method, you can add it to the network by PIN with the following two methods.

Method One: Enter the PIN of your Wireless adapter into the configuration utility of the AP i. Enter the PIN code of the wireless adapter in the field behind Client PIN Number in the following figure. Then click Start PIN.

The PIN code of the adapter is always displayed on the WPS configuration screen.

-56-

Figure 5-44 WPS-PIN – 5GHz-1

Figure 5-45 WPS-PIN – 5GHz-2 ii. For the configuration of the wireless adapter, please choose the option that you want to enter PIN

into the AP (Enrollee) in the configuration utility of the WPS and click Next until the process finishes.

Method Two: Enter the PIN of the AP into the configuration utility of your Wireless adapter i. Click the “Start PBC” Button on the WPS page of the AP. Get the Current PIN code of the AP in WPS page (each AP has its unique PIN code).

Figure 5-46 WPS-PIN – 5GHz-3 ii. For the configuration of the wireless adapter, please choose the option that you want to enter the PIN

of the AP (Registrar) in the configuration utility of the Wireless adapter and enter it into the field.

Then click Next until the process finishes.

-57-

5.3.9 Schedule

Wireless Schedules will enable or disable your wireless access at a set time based on your predefined schedule.

This feature is often used for restricting access to all users (such as children, employees and guests) during specific times of the day for parental control or security reasons.

Choose menu “WLAN1 (5GHz)

Schedule” to configure the schedule rule of enabling wireless function. After the configuration, please click the “Apply Changes” button to save the settings.

Figure 5-47 Schedule - 5GHz

-58-

When setting the Wireless Schedule, it is important to ensure that your System Clock settings have been configured. If not, your Wireless Schedule will not function correctly.

5.4 WLAN2 (2.4GHz)

The Wireless menu contains submenus of the settings about wireless network. Please refer to the following sections for the details.

Figure 5-48 2.4GHz Wireless Main Menu

5.4.1 Basic Settings

Choose menu “WLAN2 (2.4GHz)

Basic Settings” to configure the 2.4GHz basic settings for the wireless network on this page. After the configuration is done, please click the “Apply Changes” button to save the settings.

First of all, the wireless AP supports multiple wireless modes for different network applications, which include:

AP

Multiple SSIDs

Universal Repeater

Client

WDS

AP+WDS

It is so easy to combine the WMC303-1200 with the existing wired network. The WMC303-1200 definitely provides a total network solution for the home and the SOHO users.

AP

-59-

Standard Access Point

Figure 5-49 2.4GHz Wireless Basic Settings – AP

-60-

The page includes the following fields:

Object Description

Disable Wireless LAN

Check the box to disable the wireless function.

Interface

Band

Mode

Select the desired mode. Default is “2.4GHz (B+G+N)”. It is strongly recommended that you set the Band to “2.4GHz (B+G+N)”, and all of

802.11b, 802.11g, and 802.11n wireless stations can connect to the

WMC303-1W-1T-1200.

2.4 GHz (B): 802.11b mode, rate is up to 11Mbps

2.4 GHz (G): 802.11g mode, rate is up to 54Mbps

2.4 GHz (N): 802.11n mode, rate is up to 300Mbps(2T2R)

2.4 GHz (B+G): 802.11b/g mode, rate is up to 11Mbps or 54Mbps

2.4 GHz (G+N): 802.11g/n mode, rate is up to 54Mbps or 300Mbps

2.4 GHz (B+G+N): 802.11b/g/n mode, rate is up to 11Mbps,

54Mbps, or 300Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

SSID

Channel Width

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID function.

The ID of the wireless network. User can access the wireless network via the ID only. However, if you switch to Client Mode, this field becomes the SSID of the AP you want to connect with.

Default: WMC303 2G

You can select 20MHz, or 40MHz.

Channel Number

Broadcast SSID

Data Rate

You can select the operating frequency of wireless network.

Default: 11

If you enable “Broadcast SSID”, every wireless station located within the coverage of the AP can discover its signal easily. If you are building a public wireless network, enabling this feature is recommended. In private network, disabling “Broadcast SSID” can provide better wireless network security.

Default is “Enabled”.

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically, it’s not necessary to change this value

-61-

unless you know what will happen after modification.

Default is “Auto”.

Associated Clients

Enable Universal

Repeater Mode

(Acting as AP and client simultaneously)

Click the “Show Active Clients” button to show the status table of active wireless clients.

Universal Repeater is a technology used to extend wireless coverage.

To enable Universal Repeater mode, check the box and enter the

SSID you want to broadcast in the field below. Then please click

“Security” submenu for the related settings of the AP you want to connect with.

Multiple-SSID

Enable multiple-SSID can broadcast multiple WLAN SSID's using virtual interfaces. You can have different encryption settings for each WLAN and you can restrict what they have access to.

Choose menu “WLAN1 (2.4GHz)

→ Basic Settings → Multiple AP” to configure the device as a general wireless access point with multiple SSIDs.

Figure 5-50 2.4GHz Wireless Basic Settings – Multiple AP

The device supports up to four multiple Service Set Identifiers. You can back to the Basic Settings page to set the Primary SSID. The SSID’s factory default setting is IFS 2.4G VAP1~4 (Multiple-SSID 1~4). The

SSID can be easily changed to connect to an existing wireless network or to establish a new wireless network. When the information for the new SSID is finished, click the Apply Changes button to let your changes take effect.

-62-

Figure 5-51 2.4GHz Multiple-SSID

Once you have applied and saved those settings, you can then go to the “WLAN1 (2.4GHz)

→ Security” page on the AP to set up security settings for each of the SSIDs.

Universal Repeater

This mode allows the AP with its own BSS to relay data to a root AP to which it is associated with WDS disabled. The wireless repeater relays signal between its stations and the root AP for greater wireless range.

2. Example of how to configure Universal Repeater Mode. Please take the following steps:

To configure each wireless parameter, please go to the “WLAN2 (2.4GHz)

→ Basic Settings” page.

Step 1. Configure wireless mode to “AP” and then check “Enable Universal Repeater Mode (Acting as AP

and client simultaneously)”. Click “Apply Changes” to take effect.

-63-

Figure 5-52 2.4GHz Universal Repeater-1

Step 2. Go to 2.4GHz Site Survey page to find the root AP. Select the root AP that you want to repeat the signal, and then click “Next”.

Figure 5-53 2.4GHz Universal Repeater-2

Step 3. Select the correct encryption method and enter the security key. Then, click “Connect”.

-64-

Figure 5-54 2.4GHz Universal Repeater-3

Step 4. Check “Add to Wireless Profile” and click “Reboot Now”.

Figure 5-55 2.4GHz Universal Repeater-4

Step 5. Go to “Management-> Status” page to check whether the state of Repeater interface should be

Connected”.

Figure 5-56 2.4GHz Universal Repeater-5

Client (Infrastructure)

Combine the Wireless Router to the Ethernet devices such as TV, Game player, or HDD and DVD, to make them be wireless stations.

-65-

Figure 5-57 2.4GHz Wireless Basic Settings – Client

The page includes the following fields:

Object Description

Disable Wireless LAN

Check the box to disable the wireless function.

Interface

Band

Select the desired mode. Default is “2.4GHz (B+G+N)”. It is strongly recommended that you set the Band to “2.4GHz (B+G+N)”, and all of

802.11b, 802.11g, and 802.11n wireless stations can connect to the

WMC303-1200.

-66-

Mode

Network Type

SSID

Broadcast SSID

2.4 GHz (B): 802.11b mode, rate is up to 11Mbps

2.4 GHz (G): 802.11g mode, rate is up to 54Mbps

2.4 GHz (N): 802.11n mode, rate is up to 300Mbps(2T2R)

2.4 GHz (B+G): 802.11b/g mode, rate is up to 11Mbps or 54Mbps

2.4 GHz (G+N): 802.11g/n mode, rate is up to 54Mbps or 300Mbps

2.4 GHz (B+G+N): 802.11b/g/n mode, rate is up to 11Mbps,

54Mbps, or 300Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID function.

In Infrastructure, the wireless LAN serves as a wireless station. And the user can use the PC equipped with the WMC303-1200 to access the wireless network via other access points. In Ad hoc, the wireless

LAN will use the Ad-hoc mode to operate.

Default is “Infrastructure”.

Note: only while the wireless mode is set to “Client”, then the Network

Type can be configured.

The ID of the wireless network. User can access the wireless network via the ID only. However, if you switch to Client Mode, this field becomes the SSID of the AP you want to connect with.

Default: IFS AP 2G

If you enable “Broadcast SSID”, every wireless station located within the coverage of the WMC303-1200 can discover its signal easily. If you are building a public wireless network, enabling this feature is recommended. In private network, disabling “Broadcast SSID” can provide better wireless network security.

Default is “Enabled”.

Data Rate

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically, it’s not necessary to change this value

unless you know what will happen after modification.

Default is “Auto”.

Enable Mac Clone

(Single Ethernet Client)

Enable Mac Clone.

-67-

Example of how to configure Client Mode. Please take the following steps:

To configure each wireless parameter, please go to the “WLAN2 (2.4GHz)

→ Basic Settings” page.

Step 1. Go to “WLAN2 (2.4GHz)

→ Site Survey” page and click “Site Survey” button.

Figure 5-58 Client – Survey

-68-

Step 2. Choose the root AP from the list. If the root AP is not listed in the table, re-click “Site Survey” to update the list.

Figure 5-59 Client – AP List

-69-

Step 3. Enter the Security Key of the root AP and then click “Connect”.

Figure 5-60 Client – Security

Step 4. Wait until the connection established. Check the “Add to Wireless Profile” option and then reboot it.

Figure 5-61 Client – Status

WDS

Connect this Wireless AP with up to 8 WDS-capable wireless APs to expand the scope of network.

-70-

Figure 5-62 2.4GHz Wireless Basic Settings – WDS

-71-

The page includes the following fields:

Object

Disable Wireless LAN

Interface

Description

Check the box to disable the wireless function.

Band

Mode

Channel Width

Select the desired mode. Default is “2.4GHz (B+G+N)”. It is strongly recommended that you set the Band to “2.4GHz (B+G+N)”, and all of

802.11b, 802.11g, and 802.11n wireless stations can connect to the

WMC303-1200.

2.4 GHz (B): 802.11b mode, rate is up to 11Mbps

2.4 GHz (G): 802.11g mode, rate is up to 54Mbps

2.4 GHz (N): 802.11n mode, rate is up to 300Mbps(2T2R)

2.4 GHz (B+G): 802.11b/g mode, rate is up to 11Mbps or 54Mbps

2.4 GHz (G+N): 802.11g/n mode, rate is up to 54Mbps or 300Mbps

2.4 GHz (B+G+N): 802.11b/g/n mode, rate is up to 11Mbps,

54Mbps, or 300Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID function.

You can select 20MHz, or 40MHz

Control Sideband

Channel Number

Data Rate

You can select Upper or Lower.

You can select the operating frequency of wireless network.

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically, it’s not necessary to change this value

unless you know what will happen after modification.

Default is “Auto”.

AP+ WDS

Connect this Wireless AP with up to 8 WDS-capable wireless APs, and connect another AP to provide service for all wireless stations within its coverage.

-72-

Figure 5-63 2.4GHz Wireless Basic Settings – WDS+AP

The page includes the following fields:

Object Description

Disable Wireless LAN

Check the box to disable the wireless function.

Interface

Country

Select your region from the pull-down list.

This field specifies the region where the wireless function of the Router can be used. It may be illegal to use the wireless function of the Router

-73-

Band

Mode

SSID

Channel Width

Control Sideband

Channel Number

Broadcast SSID

Data Rate

in a region other than one of those specified in this field. If your country or region is not listed, please contact your local government agency for assistance.

Select the desired mode. Default is “2.4GHz (B+G+N)”. It is strongly recommended that you set the Band to “2.4GHz (B+G+N)”, and all of

802.11b, 802.11g, and 802.11n wireless stations can connect to the

WMC303-1200.

2.4 GHz (B): 802.11b mode, rate is up to 11Mbps

2.4 GHz (G): 802.11g mode, rate is up to 54Mbps

2.4 GHz (N): 802.11n mode, rate is up to 300Mbps(2T2R)

2.4 GHz (B+G): 802.11b/g mode, rate is up to 11Mbps or 54Mbps

2.4 GHz (G+N): 802.11g/n mode, rate is up to 54Mbps or 300Mbps

2.4 GHz (B+G+N): 802.11b/g/n mode, rate is up to 11Mbps,

54Mbps, or 300Mbps

There are four kinds of wireless mode selections:

AP

Client

WDS

AP+WDS

If you select WDS or AP+WDS, please click “WDS Settings” submenu for the related configuration. Furthermore, click the “Multiple AP” button to enable multiple SSID function.

The ID of the wireless network. User can access the wireless network via the ID only. However, if you switch to Client Mode, this field becomes the SSID of the AP you want to connect with.

Default: IFS AP 2G

You can select 20MHz, or 40MHz

You can select Upper or Lower.

You can select the operating frequency of wireless network.

If you enable “Broadcast SSID”, every wireless station located within the coverage of the WMC303-1200 can discover its signal easily. If you are building a public wireless network, enabling this feature is recommended. In private network, disabling “Broadcast SSID” can provide better wireless network security.

Default is “Enabled”.

Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically, it’s not necessary to change this value

unless you know what will happen after modification.

Default is “Auto”.

-74-

Associated Clients

Enable Universal

Repeater Mode

(Acting as AP and client simultaneously)

Click the “Show Active Clients” button to show the status table of active wireless clients.

Universal Repeater is a technology used to extend wireless coverage.

To enable Universal Repeater Mode, check the box and enter the

SSID you want to broadcast in the field below. Then please click

“Security” submenu for the related settings of the AP you want to connect with.

5.4.2 Advanced Settings

Choose menu “WLAN2 (2.4GHz)

Advanced Settings” to configure the 2.4GHz advanced settings for the wireless network on this page. After the configuration, please click the “Apply” button to save the settings.

Figure 5-64 Wireless Advanced Settings – 2.4GHz

-75-

The page includes the following fields:

Object

Fragment Threshold

RTS Threshold

Beacon Interval

IAPP

Protection

Aggregation

Short GI

WLAN Partition

STBC

LDPC

20/40MHz Coexist

Description

You can specify the maximum size of packet during the fragmentation of data to be transmitted. If you set this value too low, it will result in bad performance.

Default is “2346”.

When the packet size is smaller than the RTS threshold, the access point will not use the RTS/CTS mechanism to send this packet.

Default is “2347”.

The interval of time that this access point broadcasts a beacon.

Beacon is used to synchronize the wireless network. Default is “100”.

IAPP (Inter-Access Point Protocol) enabled is recommended as it describes an optional extension to IEEE 802.11 that provides wireless access-point communications among multivendor systems.

Default is “Enabled”.

It is recommended to enable the protection mechanism. This mechanism can decrease the rate of data collision between 802.11b and 802.11g wireless stations. When the protection mode is enabled, the throughput of the AP will be a little lower due to the transmission of heavy frame traffic.

Default is “Disabled”.

It is a function where the values of multiple rows are grouped together.

Default is “Enabled”

It is used to set the time that the receiver waits for RF reflections to settle out before sampling data.

Default is “Enabled”

This feature also called “WLAN isolation” or “Block Relay”. If this is enabled, wireless clients cannot exchange data through the

WMC303-1200.

Default is “Disabled”.

Activate Space Time Blocking Code (STBC) which does not need channel statement information (CSI).

Default Setting: "Enabled"

Low-density Parity-check Code is wireless data transmit algorithm.

Default Setting: "Enabled"

Configure 20/40MHz coexisting scheme.

If you set up as "Enabled", "20MHz" and "40MHz" will coexist.

Default Setting: "Disabled"

-76-

5.4.3 RF Output Power

Choose menu “WLAN2 (2.4GHz)

RF Output Power” to adjust to different levels of transmitting power for the wireless network according to various environment on this page. After the configuration, please click the “Apply

Changes” button to save the settings.

Figure 5-65 RF Output Power – 2.4GHz

RF Output Power Control provides the flexibility to control the Wi-Fi Transmit power to optimize the wireless range. Wi-Fi power consumption for an Access Point could be reduced to up to 75% from its peak power consumption for serving small to medium size homes, while boosted to maximum power for large homes and businesses. The WMC303-1200 supports output power control levels up to 5. You can change the RF output power level here in accordance with various environments and signal strength.

-77-

5.4.4 Security

Choose menu “WLAN2 (2.4GHz)

Security” to configure the settings of wireless security for the wireless network on this page. After the configuration, please click the “Apply Changes” button to save the settings.

Figure 5-66 Wireless Security Settings – 2.4GHz

The page includes the following fields:

Object

Select SSID

Encryption

Description

Select the SSID you want to configure the wireless security function, which includes the root one and the client one.

Disable:

No security setup for wireless connection.

WEP:

It is based on the IEEE 802.11 standard. And the default setting of authentication is Automatic, which can select Open System or Shared Key authentication type automatically based on the wireless station's capability and request. Furthermore, you can select Key Length and enter 10 and 26

Hexadecimal digits (any combination of 0-9, a-f, A-F, zero key is not promoted) or 5 and 13 ASCII characters in the Encryption Key field.

WPA:

WPA is a medium level encryption and is supported by most wireless devices and operating systems.

WPA2:

WPA2 is a high level encryption and is supported by most wireless devices and operating systems.

-78-

WPA / WPA2 / WPA-Mixed:

WPA Mixed Mode allows the use of both WPA and WPA2 at the same time.

Authentication Mode

Enterprise (RADIUS)

When you select the authentication mode based on Enterprise (Radius

Server), please enter the IP Address, Port, and Password of the Radius

Server.

Personal (Pre-Shared Key)

When you select the other authentication mode based on Personal

(Pre-Shared Key), please enter at least 8 ASCII characters (Passphrase) or

64 Hexadecimal characters. All of the Cipher Suites support TKIP and AES.

802.1x Authentication

Enable 802.1x authentication function and then enter the IP Address, Port, and Password of the Radius Server.

-79-

5.4.5 Access Control

Choose menu “WLAN2 (2.4GHz)

Access Control” to allow or deny the computer of specified MAC address to connect with the WMC303-1200 on this page. After the configuration, please click the “Apply Changes” button to save the settings.

Figure 5-67 Wireless Access Control – 2.4GHz

The page includes the following fields:

Object

Wireless Access

Control Mode

MAC Address

Description

You can choose to set the Allowed-List, Denied-List, or disable this function.

Comment

Enter the MAC address you want to allow or deny connection to the

WMC300-1200 in the field.

You can make some comment on each MAC address on the list.

Current Access Control

List

You can select some MAC addresses and click the “Delete Selected” button to delete it.

Wireless Access Control example:

To deny a PC at the MAC address of 9c:F6:1A:00:3c:01 to connect to your wireless network, do as follows:

Step 1. Select “Deny” from MAC Address Filter drop-down menu.

Step 2. Enter 9c:F6:1A:00:3c:01 in the MAC address box and click “Add”.

Step 3. Click the “OK” button to save your settings and you can add more MAC addresses, if you like, simply

-80-

repeat the above steps.

Figure 5-68 Wireless Access Control – Deny

-81-

5.4.6 WDS

WDS (Wireless Distribution System) feature can be used to extend your existing 2.4G or 5G wireless network coverage. Here we present you how to configure such feature in 2.4GHz, which also applies to 2.4GHz.

Before configuring the WDS Setting page, you have to select the wireless mode to “WDS” on the WLAN2

(2.4GHz) -> Basic Settings web page.

Figure 5-69 WDS Mode – 2.4GHz

-82-

Choose menu “WLAN2 (2.4GHz)

WDS Settings” to configure WDS to connect the WMC300-1200 with another AP on this page. After the configuration, please click the “Apply Changes” button to save the settings.

Figure 5-70 WDS Settings – 2.4GHz

The page includes the following fields:

Figure 5-71 WDS – Set Security

-83-

Object

Enable WDS

MAC Address

Data Rate

Comment

Set Security

Description

Check the box to enable the WDS function. Please select WDS or

AP+WDS in the Mode of Wireless Basic Settings before you enable

WDS on this page.

You can enter the MAC address of the AP you want to connect with.

Default is “Auto”.

You can make some comment for each MAC address on the list.

Click the “Set Security” button to configure the wireless security parameters of the AP you want to connect via WDS.

Click the “Show Statics” button to show the WDS AP.

Show Statics

Current WDS AP List

You can select some MAC addresses of the AP and click the “Delete

Selected” button to delete it.

WDS feature can only be implemented between 2 wireless devices that both support the

WDS feature. Plus, channel, security settings and security key must be the same on both such devices.

To encrypt your wireless network, click “Set Security”. For the detail of wireless security,

see

section 5.5.4

. Do remember to reboot the device after you save your wireless

security settings; otherwise, the WDS feature may not function.

-84-

5.4.7 Site Survey

Choose menu “WLAN2 (2.4GHz)

Site Survey” to scan the available local AP. If any Access Point is found, you could choose any one to connect with manually when the Client Mode is enabled.

Figure 5-72 Site Survey – 2.4GHz

5.4.8 WPS

WPS (Wi-Fi Protected Setup) is designed to ease setup of security Wi-Fi networks and subsequently network management. This Wireless Router supports WPS features for AP mode, AP+WDS mode,

Infrastructure-Client mode, and the wireless root interface of Universal Repeater mode.

Simply enter a PIN code or press the software PBC button or hardware WPS button (if any) and a secure wireless connection is established.

PBC: If you find the WPS LED blinking for 2 minutes after you press the hardware WPS button on the device, it means that PBC encryption method is successfully enabled. And an authentication will be performed between your router and the WPS/PBC-enabled wireless client device during this time; if it succeeds, the wireless client device connects to your device, and the WPS LED turns off. Repeat steps mentioned above if you want to connect more wireless client devices to the device.

PIN:To use this option, you must know the PIN code from the wireless client and enter it in corresponding field on your device while using the same PIN code on client side for such connection.

-85-

The page includes the following fields:

Object

Disable WPS

Description

You can check the box to disable the WPS function.

Here you can check if the connection via WPS is established or not.

WPS Status

Self-PIN Number

Push Button

Configuration

Client PIN Number

It is the PIN number of the WMC303-1W-1T-1200 here.

Click the “Start PBC” to activate WPS as well in the client device within

2 minutes.

In addition to the PBC method, you can also use the PIN method to activate the WPS. Just enter the PIN number of the client device in the field and click the “Start PIN” button.

The WPS encryption can be implemented only between your Router and another

WPS-capable device.

Example of how to establish wireless connection using WPS. Please take the following steps:

Step 1. Choose menu “WLAN2 (2.4GHz)

WPS” to configure the setting for WPS. After the configuration, please click the “Apply Changes” button to save the settings.

Step 2. Add a new device.

If the wireless adapter supports Wi-Fi Protected Setup (WPS), you can establish a wireless connection between wireless adapter and AP using either Push Button Configuration (PBC) method or PIN method.

To build a successful connection by WPS, you should also do the corresponding configuration of the new device for WPS function.

-86-

A. By Push Button Configuration (PBC)

i. Click the “Start PBC” Button on the WPS page of the AP.

Figure 5-73 WPS-PBC – 2.4GHz-1 ii.

Figure 5-74 WPS-PBC – 2.4GHz-2

Press and hold the WPS Button equipped on the adapter directly for 2 or 3 seconds. Or you can click the WPS button with the same function in the configuration utility of the adapter. The process must be finished within 2 minutes. iii. Wait for a while until the next screen appears. Click OK to complete the WPS configuration.

B. By PIN

If the new device supports Wi-Fi Protected Setup and the PIN method, you can add it to the network by PIN with the following two methods.

Method One: Enter the PIN of your Wireless adapter into the configuration utility of the AP i. Enter the PIN code of the wireless adapter in the field behind Client PIN Number in the following figure and then click Start PIN.

The PIN code of the adapter is always displayed on the WPS configuration screen.

-87-

Figure 5-75 WPS-PIN – 2.4GHz-1

Figure 5-76 WPS-PIN – 2.4GHz-2 ii. For the configuration of the wireless adapter, please choose the option that you want to enter PIN

into the AP (Enrollee) in the configuration utility of the WPS and click Next until the process finishes.

Method Two: Enter the PIN of the AP into the configuration utility of your Wireless adapter i. Click the “Start PBC” Button on the WPS page of the AP. Get the Current PIN code of the AP in WPS page (each AP has its unique PIN code). ii.

Figure 5-77 WPS-PIN – 2.4GHz-3

For the configuration of the wireless adapter, please choose the option that you want to enter the PIN

of the AP (Registrar) in the configuration utility of the Wireless adapter and enter it into the field.

Then click Next until the process finishes.

-88-

5.4.9 Schedule

Wireless Schedules will enable or disable your wireless access at a set time based on your predefined schedule.

This feature is often used for restricting access to all users (such as children, employees and guests) during specific times of the day for parental control or security reasons.

Choose menu “WLAN2 (2.4GHz)

Schedule” to configure the schedule rule of enabling wireless function.

After the configuration, please click the “Apply Changes” button to save the settings.

Figure 5-78 Schedule – 2.4GHz

-89-

When setting the Wireless Schedule, it is important to ensure that your System Clock settings have been configured. If not, your Wireless Schedule will not function correctly.

5.5 Management

This section focuses on how to maintain AP, including Restore to Factory Default Setting, Backup/Restore,

Firmware Upgrade, Reboot, Password Change and Syslog.

Figure 5-79 Management – Main Menu

5.5.1 Status

You can use this function to realize the instantaneous information of the Wireless AP. The Information displayed here may vary on different configurations.

Choose menu “Management

Status” to show the current status and some basic settings of the

WMC303-1200.

-90-

Figure 5-80 Status

5.5.2 Statistics

Choose menu “Management

Statistics” to show the packet counters for transmission and reception regarding wireless and Ethernet network.

-91-

Figure 5-81 Statistics

The page includes the following fields:

Object

Wireless LAN

Sent Packets

Wireless LAN

Received Packets

Ethernet WAN

Sent Packets

Ethernet WAN

Received Packets

Refresh

5.5.3 NTP Settings

Description

It shows the statistic count of sent packets on the wireless LAN interface.

It shows the statistic count of received packets on the wireless LAN interface.

It shows the statistic count of sent packets on the Ethernet WAN interface.

It shows the statistic count of received packets on the Ethernet WAN interface.

Click the refresh the statistic counters on the screen.

This section assists you in setting the Wireless AP’s system time. You can either select to set the time and date manually or automatically obtain the GMT time from Internet.

Choose menu “Management

NTP Settings” to configure the system time. You can also maintain the system time by synchronizing with a public time server over the Internet. After the configuration, please click the “OK” button to save the settings.

The configured time and date settings are lost when the Wireless AP is powered off.

-92-

The page includes the following fields:

Figure 5-82 Time Zone Settings

Object

Current Time

Time Zone Select

Description

Input current time manually.

You can click “Copy Computer Time” button to copy the PC’s current time to the AP.

Select the time zone of the country you are currently in. The router will set its time based on your selection.

Automatically Adjust

Daylight Saving

Enable NTP client update

NTP Server

Select the time offset, if your location observes daylight saving time.

Check to enable NTP update. Once this function is enabled, AP will automatically update current time from NTP server.

User may select prefer NTP sever or input address of NTP server manually.

-93-

If the AP loses power for any reason, it cannot keep its clock running, and will not have the correct time when it is started again. To maintain correct time for schedules and logs, either you must enter the correct time after you restart the AP, or you must enable the

NTP Server option.

5.5.4 Schedule Reboot

This page allows you to enable and configure system reboot schedule. The device can regularly reboot according to the reserved time when connecting to the Internet.

Figure 5-83 Schedule Reboot

The page includes the following fields:

Object

Schedule Reboot

Setting

Reboot Time

Reboot Plan

Description

Enable or disable the Schedule Reboot function.

Enter the Reboot Time (24-hour format) to enable this function to take effect.

There are two Reboot Plans supported in the AP:

Weekday: select this option to let the device reboot automatically according to the reserved time in one or more days of a week.

Every day: select this option to let the device reboot automatically according to the reserved time every day.

-94-

Weekday

Check one or more days to let the device auto reboot on schedule.

When choosing “Every day” as your reboot plan, the “Weekday” will be grayed out (disabled), which means Every day will auto reboot at the time that you scheduled.

1. This setting will only take effect when the Internet connection is accessible and the GMT time is configured correctly.

2. You must select at least one day when choosing “Weekday” as your reboot plan.

3. When choosing “Every day” as your reboot plan, the “Weekday” will be grayed out

(disabled), which means Every day will auto reboot at the time that you schedule.

 Example of how to configure Schedule Reboot. Please take the following steps:

Before configured schedule reboots, please ensure the Internet connection is accessible and the GMT time is configured correctly according to NTP Settings page.

Step 1. Select the Schedule Reboot Setting checkbox.

Step 2. Enter the Reboot Time (24-hour format) to enable this function to take effect. For example, if you want this function to work at 23:00 every Sunday, choose "Weekday" in the Reboot Plan field.

Figure 5-84 Schedule Reboot - Example

Step 3. Click the “Apply Changes” button to take this function effect.

-95-

5.5.5 LOG

Choose menu “Management

LOG” to configure the settings of system log. You can check the box of the items you want to record it in the log. After the configuration, please click the “Apply” button to save the settings.

Figure 5-85 System Log

The page includes the following fields:

Object

Enable Log Check to enable log function.

Description

System all

Wireless

Enable Remote Log

Check this option to display all the system logs.

Check this option to display only the logs related to wireless module.

Enable this option if you have a syslog server currently running on the LAN and wish to send log messages to it.

Enter the LAN IP address of the Syslog Server.

Log Server IP

Address

Refresh

Clear

Click this button to update the log.

Click this button to clear the current log.

-96-

5.5.6 Upgrade Firmware

This page allows you upgrade the Access Point firmware to new version. Please note, do not power off the device during the upload because it may crash the system.

Choose menu “Management

Upgrade Firmware” to upgrade the firmware of the WMC303-1W-1T-1200.

Select the new firmware file downloaded from the IFS website and then click “Upload” button to upgrade it.

The page includes the following fields:

Figure 5-86 Upgrade Firmware

Object

Select File

Description

Browse and select file you want to upgrade and press Upload to perform upgrade.

Please wait till the related information is shown on the screen after

upgrade is finished.

Do not disconnect the Wireless AP from your management PC (the PC you use to configure the device) or power off it during the upgrade process; otherwise, it may be permanently damaged. The Wireless AP will restart automatically when the upgrade process, which takes several minutes, to complete.

5.5.7 Reload Settings

Choose menu “Management

Reload Settings” to back up or reset the configuration of the WMC303-1200.

Once you have configured the Wireless AP the way you want it, you can save these settings to a configuration file on your local hard drive that can later be imported to your Wireless AP in case the device is restored to factory default settings.

-97-

The page includes the following fields:

Figure 5-87 Save/Reload Settings

Object Description

Save Settings to File

Click the “Save…” button to back up the configuration of the

WMC303-1200 and then save the “config.dat” in your computer.

Load Settings from File

Select the configuration file of the WMC303-1200 and then click the

Upload” button to reload the configuration back into the

WMC303-1W-1T-1200.

Reset Settings to

Default

Click the “Reset” button to reset all settings of the WMC303-1200 to factory default.

Factory Default Settings:

User Name: admin

Password: admin

IP Address: 192.168.0.100

Subnet Mask: 255.255.255.0

Default Gateway: 192.168.0.253

DHCP: Disabled

5GHz SSID: IFS AP 5G

2.4GHz SSID: IFS AP 2G

Wireless Security: None

To activate your settings, you need to reboot the Wireless AP after you reset it.

-98-

5.5.8 Password

To ensure the Wireless AP’s security, you will be asked for your password when you access the Wireless AP’s

Web-based Utility. The default user name and password are “admin”. This page will allow you to add or modify the user name and password.

Choose menu “Management

User Management” to change the user name and password which is inputted to access the web UI of the WMC303-1200.

Figure 5-88 Password Setup

The page includes the following fields:

Object

User Name

Description

Enter user name.

Input password for this user.

New Password

Confirmed Password

Confirm password again.

For the sake of security, it is highly recommended that you change default login password and user name.

-99-

5.5.9 LED Control

This section allows the user to determine the router packets are talking to particular host.

Figure 5-89 LED Control

The page includes the following fields:

Object

Power LED

Position LED

Description

Click On or Off to turn on/off the Power LED.

The LED to detect and identify the AP.

1) Position LED on: the position LED is on.

2) Position LED blink: the position LED blinks continuously.

2) Position LED off: the position LED is off.

5.5.10 Logout

To logout the WMC303-1W-1T-1200, please select “Logout” from the left-side menu.

Figure 5-90 Logout

-100-

Chapter 6. Quick Connection to a Wireless Network

In the following sections, the default SSID of the WMC303-1200 is configured to “default”.

6.1 Windows XP (Wireless Zero Configuration)

Step 1: Right-click on the wireless network icon displayed in the system tray

Figure 6-1 System Tray – Wireless Network Icon

Step 2: Select [View Available Wireless Networks]

Step 3: Highlight and select the wireless network (SSID) to connect

(1) Select SSID [default]

(2) Click the [Connect] button

Figure 6-2 Choose a wireless network

-101-

Step 4: Enter the encryption key of the Wireless AP

(1) The Wireless Network Connection box will appear

(2) Enter the encryption key that is configured in section 5.3.3

(3) Click the [Connect] button

Figure 6-3 Enter the network key

Step 5: Check if “Connected” is displayed

Figure 6-4 Choose a wireless network -- Connected

Some laptops are equipped with a “Wireless ON/OFF” switch for the internal wireless LAN. Make sure the hardware wireless switch is switched to “ON” position.

-102-

6.2 Windows 7 (WLAN AutoConfig)

WLAN AutoConfig service is built-in in Windows 7 that can be used to detect and connect to wireless network.

This built-in wireless network connection tool is similar to wireless zero configuration tool in Windows XP.

Step 1: Right-click on the network icon displayed in the system tray

Figure 6-5 Network icon

Step 2: Highlight and select the wireless network (SSID) to connect

(1) Select SSID [default]

(2) Click the [Connect] button

Figure 6-6 WLAN AutoConfig

If you will be connecting to this Wireless AP in the future, check [Connect automatically].

-103-

Step 4: Enter the encryption key of the Wireless AP

(1) The Connect to a Network box will appear

(2) Enter the encryption key that is configured in section 5.3.3

(3) Click the [OK] button

Figure 6-7 Type the network key

Figure 6-8 Connecting to a Network

Step 5: Check if “Connected” is displayed

Figure 6-9 Connected to a Network

-104-

6.3 Mac OS X 10.x

In the following sections, the default SSID of the WMC303-1200 is configured to “default”.

Step 1: Right-click on the network icon displayed in the system tray

The AirPort Network Connection menu will appear

Figure 6-10 Mac OS – Network icon

Step 2: Highlight and select the wireless network (SSID) to connect

(1) Select and SSID [default]

(2) Double-click on the selected SSID

Figure 6-11 Highlight and select the wireless network

Step 4: Enter the encryption key of the Wireless AP

(1) Enter the encryption key that is configured in section 5.3.3

(2) Click the [OK] button

-105-

Figure 6-12 Enter the Password

If you will be connecting to this Wireless AP in the future, check [Remember this

network].

Step 5: Check if the AirPort is connected to the selected wireless network.

If “Yes”, then there will be a “check” symbol in the front of the SSID.

Figure 6-13 Connected to the Network

-106-

There is another way to configure the MAC OS X Wireless settings:

Step 1: Click and open the [System Preferences] by going to Apple > System Preference or Applications

Figure 6-14 System Preferences

Step 2: Open Network Preference by clicking on the [Network] icon

Figure 6-15 System Preferences -- Network

-107-

Step 3: Check Wi-Fi setting and select the available wireless network

(1) Choose the AirPort on the left-menu (make sure it is ON)

(2) Select Network Name [default] here

If this is the first time to connect to the Wireless AP, it should show “Not network selected”.

Figure 6-16 Select the Wireless Network

-108-

6.4 iPhone / iPod Touch / iPad

In the following sections, the default SSID of the WMC303-1200 is configured to “default”.

Step 1: Tap the [Settings] icon displayed in the home screen

Figure 6-17 iPhone – Settings icon

Step 2: Check Wi-Fi setting and select the available wireless network

(3) Tap [General] \ [Network]

(4) Tap [Wi-Fi]

If this is the first time to connect to the Wireless AP, it should show “Not Connected”.

Figure 6-18 Wi-Fi Setting

-109-

Figure 6-19 Wi-Fi Setting – Not Connected

Step 3: Tap the target wireless network (SSID) in “Choose a Network…

(1) Turn on Wi-Fi by tapping “Wi-Fi

(2) Select SSID [default]

Figure 6-20 Turn on Wi-Fi

Step 4: Enter the encryption key of the Wireless AP

(1) The password input screen will be displayed

(2) Enter the encryption key that is configured in section 5.3.3

(3) Tap the [Join] button

-110-

Figure 6-21 iPhone -- Enter the Password

Step 5: Check if the device is connected to the selected wireless network.

If “Yes”, then there will be a “check” symbol in the front of the SSID.

Figure 6-22 iPhone -- Connected to the Network

-111-

Appendix A: Troubleshooting

If you find the AP is working improperly or stop responding to you, please read this troubleshooting first before contacting the dealer for help. Some problems can be solved by yourself within a very short time.

Scenario Solution

The AP is not responding to me when I want to access it by Web browser. a. Please check the connection of the power cord and the

Ethernet cable of this AP. All cords and cables should be correctly and firmly inserted to the AP. b. If all LED on this AP is off, please check the status of power adapter, and make sure it is correctly powered. c. You must use the same IP address section which AP uses. d. Are you using MAC or IP address filter? Try to connect the AP by another computer and see if it works; if not, please reset the AP to the factory default settings

(pressing ‘reset’ button for over 7 seconds). e. If you did a firmware upgrade and this happens, contact your dealer of purchase for help. f. If all the solutions above don’t work, contact the dealer for help.

I can’t get connected to the

Internet. a. Go to ‘Status’ -> ‘Internet Connection’ menu on the router connected to the AP, and check Internet connection status. b. Please be patient, sometimes Internet is just that slow. c. If you’ve connected a computer to Internet directly before, try to do that again, and check if you can get connected to Internet with your computer directly attached to the device provided by your Internet service provider. d. Check PPPoE / L2TP / PPTP user ID and password entered in the router’s settings again. e. Call your Internet service provider and check if there’s something wrong with their service. f. If you just can’t connect to one or more website, but you can still use other internet services, please check

URL/Keyword filter. g. Try to reset the AP and try again later. h. Reset the device provided by your Internet service provider too. i. Try to use IP address instead of host name. If you can use IP address to communicate with a remote server, but can’t use host name, please check DNS setting.

-112-

I can’t locate my AP by my a. ‘Broadcast ESSID’ set to off? wireless device. b. Both two antennas are properly secured. c. Are you too far from your AP? Try to get closer. d. Please remember that you have to input ESSID on your wireless client manually, if ESSID broadcast is disabled.

File downloading is very slow or breaks frequently. a. Are you using QoS function? Try to disable it and try again. b. Internet is slow sometimes. Please be patient. c. Try to reset the AP and see if it’s better after that. d. Try to know what computers do on your local network. If someone’s transferring big files, other people will think

Internet is really slow. e. If this never happens before, call you Internet service provider to know if there is something wrong with their network.

I can’t log into the web management interface; the password is wrong.

The AP becomes hot a. Make sure you’re connecting to the correct IP address of the AP! b. Password is case-sensitive. Make sure the ‘Caps Lock’ light is not illuminated. c. If you really forget the password, do a hard reset. a. This is not a malfunction, if you can keep your hand on the AP’s case. b. If you smell something wrong or see the smoke coming out from AP or A/C power adapter, please disconnect the AP and power source from utility power (make sure it’s safe before you’re doing this!), and call your dealer of purchase for help.

-113-

Appendix B: Glossary

802.11ac

- 802.11ac is a wireless networking

standard in the

802.11

family (which is marketed under the brand name Wi-Fi), developed in the IEEE Standards Association process, providing high-throughput wireless local area networks

(WLANs) on the

5 GHz band

.

802.11n - 802.11n builds upon previous 802.11 standards by adding MIMO (multiple-input multiple-output). MIMO uses multiple transmitter and receiver antennas to allow for increased data throughput via spatial multiplexing and increased range by exploiting the spatial diversity, perhaps through coding schemes like Alamouti coding. The Enhanced Wireless Consortium (EWC) [3] was formed to help accelerate the IEEE 802.11n development process and promote a technology specification for interoperability of next-generation wireless local area networking (WLAN) products.

802.11a

-

802.11a was an amendment to the IEEE 802.11 wireless local network specifications that defined requirements for an orthogonal frequency division multiplexing (OFDM) communication system. It was originally designed to support wireless communication in the unlicensed national information infrastructure (U-NII) bands (in the 5–6 GHz frequency range) as regulated in the United

States by the Code of Federal Regulations, Title 47, Section 15.407.

802.11b - The 802.11b standard specifies a wireless networking at 11 Mbps using direct-sequence spread-spectrum (DSSS) technology and operating in the unlicensed radio spectrum at 2.4GHz, and

WEP encryption for security. 802.11b networks are also referred to as Wi-Fi networks.

802.11g - specification for wireless networking at 54 Mbps using direct-sequence spread-spectrum

(DSSS) technology, using OFDM modulation and operating in the unlicensed radio spectrum at

2.4GHz, and backward compatibility with IEEE 802.11b devices, and WEP encryption for security.

DDNS (Dynamic Domain Name System) - The capability of assigning a fixed host and domain name to a dynamic Internet IP Address.

DHCP (Dynamic Host Configuration Protocol) - A protocol that automatically configure the TCP/IP parameters for the all the PC(s) that are connected to a DHCP server.

DMZ (Demilitarized Zone) - A Demilitarized Zone allows one local host to be exposed to the Internet for a special-purpose service such as Internet gaming or videoconferencing.

DNS (Domain Name System) - An Internet Service that translates the names of websites into IP addresses.

Domain Name - A descriptive name for an address or group of addresses on the Internet.

DSL (Digital Subscriber Line) - A technology that allows data to be sent or received over existing traditional phone lines.

ISP (Internet Service Provider) - A company that provides access to the Internet.

-114-

MTU (Maximum Transmission Unit) - The size in bytes of the largest packet that can be transmitted.

NAT (Network Address Translation) - NAT technology translates IP addresses of a local area network to a different IP address for the Internet.

PPPoE (Point to Point Protocol over Ethernet) - PPPoE is a protocol for connecting remote hosts to the Internet over an always-on connection by simulating a dial-up connection.

SSID - A Service Set Identification is a thirty-two character (maximum) alphanumeric key identifying a wireless local area network. For the wireless devices in a network to communicate with each other, all devices must be configured with the same SSID. This is typically the configuration parameter for a wireless PC card. It corresponds to the ESSID in the wireless Access Point and to the wireless network name.

WEP (Wired Equivalent Privacy) - A data privacy mechanism based on a 64-bit or 128-bit or 152-bit shared key algorithm, as described in the IEEE 802.11 standard.

Wi-Fi - A trade name for the 802.11b wireless networking standard, given by the Wireless Ethernet

Compatibility Alliance (WECA, see http://www.wi-fi.net), an industry standards group promoting interoperability among 802.11b devices.

WLAN (Wireless Local Area Network) - A group of computers and associated devices communicate with each other wirelessly, which network serving users are limited in a local area.

-115-
