hp digital projector vp6100 series hp digital projector

hp digital projector vp6100 series

hp digital projector vp6100 series

Create clear, sharp, detailed on-screen images in your office, classroom or small meeting room with a HP Digital Projector vp6100 series projector. Powerful yet quiet, they are portable and easy to operate and HP quality ensures durability.

Ideal for people working in education, mobile professionals and first-time users who need a good value projector which offers high brightness and is simple to set up and use. Its portability makes it easy to move between different locations and to share with other users.

Produce big results for a small investment and see your presentations come to life.

• High brightness of 1500* or even 2000** lumens improves visibility of the projected image and gives you flexibility to present in different lighting conditions.

• Make a powerful impact: distinct 800 x 600 SVGA resolution* or 1024 x 768 XGA resolution** ensure text is easy to read, graphics are precise and images are realistic and accurate.

• A high contrast ratio of 2000:1 enhances the clarity of projected text and images to produce projections that are easy to see and understand.

Be as mobile as you need with this conveniently portable and easy-to-use projector.

• Get going quickly as the on-screen display is intuitive and the menus are quickly understood and mastered.

• No tiresome delays as the presentation source (a PC, VCR, PDA or other device) is automatically detected and the resolution is automatically scaled.

• Maintain seamless control by keeping track of your presentations via an external monitor.

• Weighing only 3 kg (6.6 lb), the projector is easily portable and can be ceiling-mounted.

Its compact design makes it easy to store securely.

Engineered for robustness and durability to deliver performance you can depend on.

• Quiet operation means a better experience for you and your audience and for enhanced audio you can use the small, effective 3 watt speaker.

• Convey your message dynamically using the S-video or component inputs for clear, smooth video projections to create presentations with impact.

• Integrate all the components of your presentation seamlessly using the various ports available:

Connect your computer, PDA, video or DVD player or even a game console.

* HP Digital Projector vp6110

**HP Digital Projector vp6120

hp digital projector vp6100 series

hp digital projector vp6100 series

technical specifications

brightness native display resolution resolutions supported through scaling weight dimensions images technology image contrast noise level audio colour lens projection size throw distance frequency keystoning signal interface user interface product certification video compatibility power consumption power supply lamp mounting capability mounting environmental warranty

HP Digital Projector vp6110: 1500 lumens

HP Digital Projector vp6120: 2000 lumens

HP Digital Projector vp6110: Native SVGA (800 x 600)

HP Digital Projector vp6120: Native XGA (1024 x 768)

HP Digital Projector vp6110: Scales up from VGA (640 x 480) and scales down from XGA (1024 x 768)

HP Digital Projector vp6120: Scales up from SVGA (800 x 600) and scales down from SXGA (1280 x 1024)

3 kg

HP Digital Projector vp6110/vp6120: 308 x 238 x 95 mm; packaged: 460 x 455 x 293 mm

HP Digital Projector vp6110/vp6120: DLP technology with 0.55" 12 degrees tilt DMD

HP Digital Projector vp6110/vp6120: 2000:1 Full on/off

HP Digital Projector vp6110/vp6120: 35 dB(A) under 25º C; 32 dB(A) in lamp saving mode

One 4 ohm 3W speaker

24-bit, 16.7 million colours

F/2.6, f=23.2 to 28.38 mm with 1.2:1 manual zoom and manual focus

HP Digital Projector vp6110: 0.74 to 4.76 m (diagonal)

HP Digital Projector vp6120: 0.95 to 6.09 m (diagonal)

1.5 to 8 m

HP Digital Projector vp6110/vp6120: horizontal frequency: 15-81 kHz, vertical frequency: 50-100 Hz

±7º (14º total) vertical keystoning except 1080i/1035i

Advanced electronic keystone correction

HP Digital Projector vp6110/vp6120: Input: 15-pin VGA input connector, YPbPr RCA jack (green/red/blue), video RCA jack (yellow), audio RCA jack (white/red), 3.5 mm stereo mini jack, S-video connector, UART mini-DIN 8-pin connector; output: B-type USB terminal for mouse port, 15-pin VGA output connector

Wireless IR remote controller: Power light – blue; lamp light – orange; temperature light – orange

OSD: Buttons on the top case include the following functions: “Power On/Off”, “OSD navigation”,

“Menu access”, “Enter”

Europe (EN 60950), USA/Canada (cULus), Mexico (NOM-1-NYCE), Singapore (PSB), Russia GOST, Poland

(B mark), China (CCC), Japan (SHOAN)

S-video, composite, component, HDTV (up to 1080i)

330 watts maximum

Input voltage 100 to 240 VAC (± 10%), 50/60 Hz (± 3 Hz)

Lamp life: up to 3,000 hours in lamp saver mode

250 watt UHP projector bulb

Lamp power supply is automatically shut-off when door is open

HP Digital Projector vp6110/vp6120: Ceiling and tripod mountable

10 to 90% RH, 10 to 35º C

2 year warranty on projector with pick-up and return service and 90 days warranty on light bulb

ordering information

L1595A hp digital projector vp6110, user manual on CD, quick set-up guide, warranty information, video port instruction card, power cord,

VGA cable, RCA cable, PC audio cable, credit card remote control, battery

L1596A hp digital projector vp6120, as above

L1624A

L1629A

L1630A

L1631A

L1633A

L1634A

L1635A accessories & supplies lamp module vp6100 carry case vp6100 ceiling mount kit vp6100 remote control premium with

USB cable screen mobile 60" standard cable, component video 1.8 m cable, S-video 1.8 m service & support

U4802A/E hp care pack: 3 years advanced unit replacement service http://www.hp.com
