Handshake Solutions

HT80C51 User Manual

Handshake Solutions

HT80C51 User Manual

Document Information

Document Information

Document Title

Date of Creation

HT80C51 User Manual

27/06/2005

Date of last change

File name

27/06/2005

HT80C51-UserManual.doc

Status Release

Version Number 1.7

Client / Target Audience System architects,and software developers using the HT80C51

Summary This document describes and illustrates the general architecture, the standard peripherals and the instruction set for the HT80C51.

Contact Handshake Solutions

High Tech Campus

Prof. Holstlaan 4

Mailbox WAM01

5656 AA Eindhoven

The Netherlands phone: +31-40-27 46114 [email protected]

www.handshakesolutions.com

© 2005 Koninklijke Philips Electronics N.V.

All rights reserved. Reproduction in whole or in part in any way, shape or form, is prohibited without the written consent of the copyright owner. All information in this document is subject to change without notice.

Page 2 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Table of Contents Handshake Solutions

Table of Contents

1.

Introduction to HT80C51 ............................................................................................................... 5

1.1.

Compatibility ..................................................................................................................... 5

1.2.

Modules.............................................................................................................................. 6

2.

Memory Organization .................................................................................................................... 9

2.1.

Memory Map ...................................................................................................................... 9

2.2.

Accessing Program Memory ......................................................................................... 10

2.3.

Accessing External Data Memory ................................................................................. 10

2.4.

Internal Data Memory: Direct and Indirect Address Area........................................... 11

2.5.

Special Function Registers............................................................................................ 13

2.5.1.

Accumulator ACC .............................................................................................. 14

2.5.2.

Register B.......................................................................................................... 14

2.5.3.

Program Status Word PSW............................................................................... 14

2.5.4.

Stack Pointer SP ............................................................................................... 14

2.5.5.

Data Pointer DPTR DPH DPL ........................................................................... 15

2.5.6.

Power Saving Modes PCON ............................................................................. 15

2.5.7.

External RAM Page XRAMP (option HT80C51_CPU_XRAMP)....................... 17

2.6.

MOVC protection (option HT80C51_CPU_MOVCP)..................................................... 17

3.

Reset ............................................................................................................................................. 18

4.

Clocks ........................................................................................................................................... 19

4.1.

CPU Cock......................................................................................................................... 19

4.1.1.

Clockless (Aynchronous) Cnfiguration .............................................................. 19

4.1.2.

Clock synchronization (Option HT80C51_CPU_SYNC) ................................... 19

4.2.

Peripheral clocks ............................................................................................................ 19

5.

Peripheral Modules...................................................................................................................... 20

5.1.

Interrupt Controller ......................................................................................................... 20

5.1.1.

Options .............................................................................................................. 20

5.1.2.

Special function registers (IEN0 IEN1 IP0 IP1) ................................................. 20

5.1.3.

Operation ........................................................................................................... 22

5.1.4.

Setting up the Interrupt Controller ..................................................................... 25

5.2.

Timers 0 and 1................................................................................................................. 26

5.2.1.

Options .............................................................................................................. 26

5.2.2.

Special function registers (TMOD TCON TL0 TL1 TH0 TH1)........................... 26

5.2.3.

Interrupts............................................................................................................ 28

5.2.4.

Operation ........................................................................................................... 29

5.2.5.

Setting up the Timers ........................................................................................ 31

5.3.

Standard Serial Interface (SIO0).................................................................................... 33

5.3.1.

Options .............................................................................................................. 33

5.3.2.

Special function registers (SCON SBUF SMOD) .............................................. 33

© Philips Electronics N.V. 2005 Page 3 of 132

Handshake Solutions

HT80C51 User Manual

Table of Contents

5.3.3.

Interrupts............................................................................................................ 34

5.3.4.

Operation ........................................................................................................... 34

5.3.5.

Setting up the serial port.................................................................................... 40

5.4.

General Purpose IOs ...................................................................................................... 42

5.4.1.

Options .............................................................................................................. 42

5.4.2.

Special function registers (POUTx PINx) .......................................................... 42

5.4.3.

Interrupts............................................................................................................ 43

5.4.4.

Operation ........................................................................................................... 43

5.5.

I

2

C Interface (SIO1).......................................................................................................... 44

5.5.1.

Options .............................................................................................................. 44

5.5.2.

Special function registers (S1CON S1ADR S1DAT S1STA ) ........................... 44

5.5.3.

Interrupts............................................................................................................ 46

5.5.4.

Operation ........................................................................................................... 46

5.5.5.

Slave-only version ............................................................................................. 73

5.5.6.

Application notes ............................................................................................... 73

5.6.

Serial Peripheral Interface (SPI) .................................................................................... 74

5.6.1.

Options .............................................................................................................. 74

5.6.2.

Special function registers (SPCR SPSR SPDR) ............................................... 74

5.6.3.

Interrupts............................................................................................................ 76

5.6.4.

Operation ........................................................................................................... 76

5.7.

Watchdog Timer (under development) ......................................................................... 80

5.7.1.

Options .............................................................................................................. 80

5.7.2.

Special function registers (T3)........................................................................... 80

5.7.3.

Interrupts............................................................................................................ 80

5.7.4.

Operation ........................................................................................................... 80

5.8.

Triple-DES Converter...................................................................................................... 82

5.8.1.

Options .............................................................................................................. 82

5.8.2.

Special function registers (DCON DKEY DTXT) ............................................... 82

5.8.3.

Interrupts............................................................................................................ 83

5.8.4.

Operation ........................................................................................................... 83

5.8.5.

Software view .................................................................................................... 84

6.

80C51 Family Instruction Set...................................................................................................... 87

6.1.

80C51 Instruction Set Summary.................................................................................... 87

6.2.

Instruction definitions .................................................................................................... 91

Appendix ............................................................................................................................................ 130

A1: List of Tables ................................................................................................................. 130

A2: List of Figures ............................................................................................................... 131

A3: Document History ......................................................................................................... 132

Page 4 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Introduction to HT80C51 – Compatibility

1. Introduction to HT80C51

Handshake Solutions

The Handshake Technology 80C51 (referred to as HT80C51) is an improved version of the ultra lowpower 80C51 (known as ulp80C51). This ulp80C51 has been used in several products such as pagers, game controllers, telephony controllers, and Mifare ProX and SmartMX smart card controllers.

Millions of these ICs have been shipped.

The HT80C51 implementation offers several unique features, which are detailed below.

The HT80C51 is extremely low power (the CPU consumes only 0.1 nano joules per instruction).

The HT80C51 has very low electromagnetic emission (EME).

The HT80C51 has low supply-current peaks (at least a factor five lower than traditional, clocked implementations), thus facilitating integration with analog and RF circuitry.

The HT80C51 CPU consumes zero stand-by power while in sleep mode, yet is immediately available for full-speed full-functional operation.

The HT80C51 has an asynchronous and optionally a synchronous mode of operation. When both are present, the actual mode can be dynamically selected on an instruction-per-instruction base. This is controlled via a dedicated input.

In asynchronous mode of operation, the CPU runs at its natural speed, and a slow core clock does not slow it down.

In synchronous mode, the CPU synchronizes with a clock on a machine cycle basis after each instruction in such a way that the number of clock cycles for that instruction is the same as the number of machine cycles for a synchronous implementation.

The HT80C51 core is configurable, and has a range of configuration options, offering selective instantiations of 80C51 peripherals and customization of memory interfaces.

The HT80C51 peripherals consume zero power when not actively used.

Optional dual datapointer (for more compact code).

Optional MOVC protection (only grants program code from lower program memory permission to read lower program memory).

1.1. Compatibility

The HT80C51 implementation is functionally compatible to the instruction set and the peripherals of the original 80C51.

The HT80C51 and its peripherals have been designed in Haste, which is the high-level programming language of the Handshake Technology design flow. This design flow is to a large extent technology independent. Mapping onto various VLSI technologies from different vendors is supported.

For production testing, both functional and scan-test version are supported. The scan-test version is compatible with standard ATPG tools.

© Philips Electronics N.V. 2005 Page 5 of 132

Handshake Solutions

1.2. Modules

HT80C51 User Manual

Introduction to HT80C51 – Modules

Following modules are currently available for a HT80C51 microcontroller system

HT80C51 CPU with optional

-

Prefetch unit to increase performance

-

Dual datapointer

-

MOVC protection

-

Synchronization to external clock

Interrupt controller

-

With configurable number of interrupt lines (1 to 15)

Timer 0 and timer1

UART

SPI

I2C

-

Master/slave or

-

Slave only

Watchdog Timer

DES

Bridge to synchronous SFR bus

-

Supports legacy synchronous peripheral units

Other peripherals are being developed or can be implemented on demand.

Page 6 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Introduction to HT80C51 – Modules

RAM

external data memory code memory internal data address

B ACC tmp2 tmp1 stack pointer control instruction register

PSW

ALU

HT80C51

PCON

Handshake Solutions code address external data address

XRAMP buffer register

PC incrementer

PC

DPTR

DPTR1 peripheral special function registers peripheral logic

external logic

[Figure 1] HT80C51 Architecture (CPU centered)

© Philips Electronics N.V. 2005 Page 7 of 132

up to

64Kbytes program memory up to

64Kbytes external data memory

(optional) up to

256bytes internal data memory handshake peripherals synchronous peripherals

Handshake Solutions

external HT80C51

HT80C51 User Manual

Introduction to HT80C51 – Modules int_req_i[ ] interrupt controller int4,5,6 int_ack_o[ ] int0..3

timer 0 / 1 t1_overflow

UART

I

2

C

80C51

CPU

SPI

Watchdog

DES synchronous

SFR bus bridge

HT-SFR bus

[Figure 2] HT80C51 Achitecture

GPIO gpio_pinX[ ] gpio_poutX[ ]

Page 8 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Memory Organization – Memory Map Handshake Solutions

The 80C51 architecture comprises several different and separated address areas. The following chapter describes the map of these memory areas, which are described in more detail thereafter.

The 80C51 has separate address spaces for program memory, external and internal data memory.

[Figure 3] shows a map of the 80C51 memory areas.

program memory

(CODE) external data memory

(XDATA) internal data memory

(IDATA, DATA)

FFFH

up to

64 Kbytes up to

64 Kbytes

FFH

up to

256 bytes

000H 00H

[Figure 3] HT80C51 Memory Map

The Program memory (CODE) can be up to 64Kbytes. It can be accessed by instruction fetches and by the MOVC instruction.

The 80C51 can address up to 64k bytes of external data memory (XDATA). Historically this area was located outside the chip (hence the name external), which is usually not the case for embedded systems. The MOVX instruction is used to access the external data memory.

The 80C51 can address up to 256 bytes of on-chip RAM, plus a number of Special Function Registers

(SFRs).

The lower 128 bytes of RAM can be accessed either by direct addressing (MOV data addr) or by indirect addressing (MOV @Ri). The upper 128 bytes of RAM can be accessed by indirect addressing only. Using addresses 80H to FFH with direct addressing accesses the special function registers.

[Figure 4] shows the internal data memory organization.

© Philips Electronics N.V. 2005 Page 9 of 132

Handshake Solutions

HT80C51 User Manual

Memory Organization – Accessing Program Memory

internal data memory

FFH upper area of

RAM

(128 bytes) special functions registers (SFRs)

80H

7FH lower area of

RAM

(128 bytes)

00H

indirect addressing

(IDATA) direct addressing

(DATA)

[Figure 4] Memory map of Internal Data

2.2. Accessing Program Memory

The program memory is readable only and can be accessed by two access methods:

Instruction fetches using the 16bit program counter (PC) as the address or move-code instructions using the 16bit data pointer (MOVC @DPTR) or again the PC (MOVC @PC) as reference.

2.3. Accessing External Data Memory

In contrast to the program memory the external data memory is read- and writeable. Accesses to external data memory can be done thru the MOVX-instruction only, which comes in two flavors:

MOVX @DPTR uses the data pointer to form the 16bit address.

MOVX @Ri uses one of the index registers to form the lower 8bits of the address with the upper part of the address being defined by the SFR

XRAMP

.

The first variant is usually faster and a more general access method. The second variant (MOVX @Ri) can be used as a paging access to a rather small area of data.

Page 10 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Memory Organization – Internal Data Memory: Direct and Indirect Address Area Handshake Solutions

2.4. Internal Data Memory: Direct and Indirect Address Area

The lower 128 bytes of RAM can be accessed by both direct and indirect addressing and they can be

divided into three segments as listed below and shown in [Figure 5].

7FH scratch pad area

30H

2FH bit addresses

00 … 7F bit addressable segment

20H

1FH

18H

17H

10H register bank 3 register bank 2 register banks

0FH

08H

07H

00H register bank 1 register bank 0

[Figure 5] Lower 128 bytes of RAM, direct and indirect addressing

1. Register Banks 0-3:

Locations 00H through 1FH (32 bytes). The device after reset defaults to register bank 0. To use the other register banks, the user must select them in software. Each register bank contains eight 1-byte registers 0 through 7. Reset initializes the stack pointer to location 07H, and it is incremented once to start from location 08H, which is the first register (

R0

) of the second register bank. Thus, in order to use more than one register bank, the

SP

should be initialized to a different location of the RAM where it is not used for data storage (i.e., the higher part of the RAM).

The register bank is selected by bits

RS0

and

RS1

in the program status word.

2. Bit Addressable Area:

16 bytes have been assigned for this segment, 20H-2FH. Each one of the 128 bits of this segment can be directly addressed (0-7FH). The bits can be referred to in two ways, both of which are accept-

© Philips Electronics N.V. 2005 Page 11 of 132

Handshake Solutions

HT80C51 User Manual

Memory Organization – Internal Data Memory: Direct and Indirect Address Area able by most assemblers. One way is to refer to their address (i.e., 0-7FH). The other way is with reference to bytes 20H to 2FH. Thus, bits 0-7 can also be referred to as bits 20.0-20.7, and bits 8-FH are the same as 21.0-21.7, and so on. Each of the 16 bytes in this segment can also be addressed as a byte.

3. Scratch Pad Area:

30H through 7FH are available to the user as data RAM. However, if the stack pointer has been initialized to this area, enough bytes should be left aside to prevent overwriting of stack data.

Page 12 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Memory Organization – Special Function Registers Handshake Solutions

The upper address range of the direct addressable data memory is occupied by the special function registers (SFRs). These registers not only serve as data storage, they also have special function for

the CPU or peripherals they are attached to. A map of this area is shown in [Figure 6].

F8

F0

B

E8

FF

F7

EF

D8

C8

XRAMP

C0

B8

IP

B0

A8

IE

A0

98

SBUF

90

80

E7

DF

D7

CF

C7

BF

B7

AF

↑ SFRs in this column are bit addressable

A7

9F

97

8F

87

[Figure 6] SFR memory map

Note that in the SFR-map not all of the addresses are occupied. Unoccupied addresses are not implemented on the chip. Read accesses to these unimplemented SFR locations will in general return random data, and write accesses will have no effect. User software should not write 1s to these unimplemented locations, since they may be used in other 80C51 Family derivative products to invoke new features.

There are two types of special functions registers: registers, which are part of the CPU and often directly used by certain instructions, and SFRs, which are implemented in peripheral blocks. The SFRs of the CPU are available in all derivatives of this microcontroller and are described in the text below.

Peripheral blocks are optional and so are the SFRs, which are implemented inside these peripherals.

Therefore the peripheral SFRs are described with the peripheral blocks in Chapter 5.

© Philips Electronics N.V. 2005 Page 13 of 132

Handshake Solutions

2.5.1. Accumulator ACC

HT80C51 User Manual

Memory Organization – Special Function Registers

ACC

is the Accumulator register. The mnemonics for Accumulator-Specific instructions, however, refer to the Accumulator simply as

A

.

ACC (A)

Accumulator

addr = E0H reset value = 00H bits 7 6 5 4 3 2 1 0

ACC

The B-register is used during multiply and divide operations. For other instructions it can be treated as another scratch pad register.

B

Register B

addr = F0H reset value = 00H bits 7 6 5 4 3 2 1 0

B

2.5.3. Program Status Word PSW

The program status word (

PSW

) register contains program status information as detailed below.

PSW

Program Status Word

addr = D0H reset value = 00H bits 7 6 5 4 3 2 1 0

bit symbol function

PSW.7 CY

PSW.6 AC

PSW.5 F0

PSW.4

PSW.3

RS1

RS0

Auxiliary Carry Flag.

Flag 0 available to the user for general purpose.

0 0

0 1

1 0

1 1

Register Bank selector bit 1.

Register Bank selector bit 0.

(RS1, RS0) select the register bank as follows:

Bank 0 (00H .. 07H)

Bank 1 (08H .. 0FH)

Bank 2 (10H .. 17H)

Bank 3 (18H .. 1FH)

Register Bank selector bit 0 (see note). PSW.3 RS0

PSW.2 OV

PSW.1 -

PSW.0 P

Usable as a general-purpose flag.

Parity flag. Set/cleared by hardware each instruction cycle to indicate an odd/even number of ‘1’ bits in the accumulator, that means even parity.

2.5.4. Stack Pointer SP

The Stack Pointer (

SP

) register is 8 bits wide. It is incremented before data is stored during PUSH and

CALL executions. While the stack may reside anywhere in on-chip RAM, the Stack Pointer is initialized to 07H after a reset. This causes the stack to begin at locations 08H.

Page 14 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Memory Organization – Special Function Registers Handshake Solutions

SP

Stack Pointer

addr = 81H reset value = 07H bits 7 6 5 4 3 2 1 0

SP

2.5.5. Data Pointer DPTR DPH DPL

The Data Pointer (

DPTR

) consists of a high byte (

DPH

) and a low byte (

DPL

). Its intended function is to hold a 16-bit address for MOVX and MOVC instructions. It may be manipulated as a 16-bit register or as two independent 8-bit registers.

DPH

Data Pointer High byte

addr = 83H reset value = 00H bits 7 6 5 4 3 2 1 0

DPH

DPL

Data Pointer Low byte

addr = 82H reset value = 00H bits 7 6 5 4 3 2 1 0

DPL

2.5.5.1. Dual data pointer (option HT80C51_CPU_DUALDPTR)

Optional two data pointer registers can be implemented,

DPTR0

and

DPTR1

. Only one data pointer can be used at a time. This can be selected by bit

DPS

in SFR

PCON

(see below).

All instructions using the

DPTR

,

DPL

or

DPH

use either

DPTR0

or

DPTR1

as selected by SFR bit

DPS

.

The

DPS

bit should be saved by software when switching between

DPTR0

and

DPTR1

within procedures or interrupt routines.

2.5.6. Power Saving Modes PCON

The HT80C51 has two power reducing modes, Idle and Power Down. The input through which backup power is supplied during these operations is

VDD

.

In the Idle mode (

IDL

= 1), the oscillator continues to run and the Interrupt, Serial Port, and Timer blocks continue to be clocked, but the clock signal is gated off to the CPU.

In Power Down (

PD

= 1), the oscillator is frozen.

Since switching on or off the oscillator is done outside the microcontroller, dedicated output pins indicate idle mode (

cpu_idle_o

) and power down (

cpu_powerdown_o

). External circuits needs to observe these signals to switch off the clocks (in power down) or to change the supply voltage.

Setting bits in Special Function Register

PCON

activate the Idle and Power Down Modes.

© Philips Electronics N.V. 2005 Page 15 of 132

Handshake Solutions

HT80C51 User Manual

Memory Organization – Special Function Registers

PCON

Power Control Register

addr = 87H reset value =

0XX00000

Bits 7 6 5 4 3 2 1 0

SMOD - - (DPS)

Bit symbol Function

PCON.7 SMOD

Double baud rate (see chapter 5.3 “Standard Serial Interface”)

1: If timer 1 is used to generate the baudrate and the serial interface is used in modes 1, 2 or 3, then the baudrate is doubled.

PCON.6

PCON.5

-

0: The baudrate is not influenced

Reserved (write 0, reads 0)

PCON.4 (DPS)

PCON.3 GF1

1:

0:

Data pointer select; implemented with dual data pointer option, only, otherwise reserved bit (write 0, reads 0)

Select select

DPTR1

DPTR0

for all

for all

DPTR

DPTR

accesses (and for

accesses (and for

General-purpose flag bit.

DPL

DPL

and

and

DPH

DPH

)

)

PCON.2 GF0 General-purpose flag bit.

PCON.1 PD Power-Down bit. Setting this bit activates power-down operation, which is also indicated at output pin

cpu_powerdown_o

.

PCON.0 IDL Idle mode bit. Setting this bit activates idle mode operation, which is also indicated at output pin

cpu_idle_o

.

Note: If 1s are written to

PD

and

IDL

at the same time,

PD

takes precedence.

User software should never write 1s to unimplemented bits, since they may be used in other 80C51

Family products.

An instruction that sets

PCON.0

immediately switches into the idle mode, so no further instruction is executed. The clock signal is gated off from the CPU but not to the Timer and Serial Port functions.

The CPU status is preserved in its entirety; the Stack Pointer, Program Counter, Program Status

Word, Accumulator, and all other registers maintain their data during Idle.

The port pins hold the logical states they had at the time Idle was activated.

There are two ways to terminate the Idle. Activation of any enabled interrupt will cause

PCON.0

to be cleared by hardware, terminating the idle mode. The interrupt will be serviced, and following RETI, the next instruction to be executed will be the one following the instruction that put the device into Idle.

The flag bits

GF0

and

GF1

can be used to give an indication if an interrupt occurred during normal operation or during an Idle. For example, an instruction that activates Idle can also set one or both flag bits. When Idle is terminated by an interrupt, the interrupt service routine can examine the flag bits.

The other way of terminating the idle mode is with a hardware reset, which starts the processor in the same manner as a power-on reset.

An instruction that sets

PCON.1

immediately switches into the Power Down mode. In the Power Down mode, the CPU clock and all peripheral clocks can be stopped completely to lower the power consumption. This has to be done be external circuits, which observe the output pin

cpu_powerdown_o

, that indicates the power down mode. With the clocks frozen, all functions are stopped, the contents of the on-chip RAM and Special Function Registers are maintained. The port pins output the values held by their respective SFRs.

The only exit from Power Down is a hardware reset. Reset redefines all the SFRs, but does not change the on-chip RAM.

Page 16 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Memory Organization – MOVC protection (option HT80C51_CPU_MOVCP) Handshake Solutions

In the Power Down mode of operation, VDD can be reduced to a level that is still sufficient for logic and RAM to keep their contents. Care must be taken, however, to ensure that VDD is not reduced before the Power Down mode is invoked, and that VDD is restored to its normal operating level, before the Power Down mode is terminated. The reset that terminates Power Down also should switch on the core clock again. The reset should not be activated before VDD is restored to its normal operating level, and must be held active long enough to allow an oscillator to restart and stabilize.

2.5.7. External RAM Page XRAMP (option HT80C51_CPU_XRAMP)

The MOVX-instruction comes in two flavors: MOVX @DPTR and MOVX @Ri. For the second version

(MOVX @Ri) the contents of one index register

Ri

specify the lower half of the 16bit address for the access to the external data memory. The upper half is not specified by the instruction, but the SFR

XRAMP

supplies it. In other words, the external data memory is divided into pages of 256bytes, with

XRAMP

selecting the page and @Ri addressing within this page.

XRAMP

External RAM Page

addr = C9H reset value = 00H bits 7 6 5 4 3 2 1 0

XRAMP

2.6. MOVC protection (option HT80C51_CPU_MOVCP)

This optional feature protects a memory region in program memory from being read out by a program outside this region. Thus any MOVC instruction, that is executed outside the protected region and tries to access the protected region, will return the value 00H instead of the real memory content. The protection is only one-way, so a protected program can read the complete program memory area.

The protected region is defined to start at address 0000H. The upper limit of the protected region is defined by static inputs

ht80c51_movcp_uaddr_i

, so the protected code memory region is from

0000H <= addr <

ht80c51_movcp_uaddr_i

. The value of this upper limit is under control of the customer, but must not change during execution. Usually it is hard wired to a constant value.

© Philips Electronics N.V. 2005 Page 17 of 132

Handshake Solutions

3. Reset

HT80C51 User Manual

Reset

The reset input is the

Z_R

pin. An asynchronous reset is accomplished by holding the

Z_R

pin low.

The minimum low time is not depending on the clock frequency but it depends on the standard cell library, placement and routing. However, usually a reset pulse of about 100ns is sufficient.

A reset initializes most of the SFRs. The following table lists the SFR reset values. The internal RAM is not affected by reset. On power up the RAM content is not defined.

TMOD

TCON

TH0

TL0

TH1

TL1

SCON

SBUF

POUT0

POUT1

POUT2

POUT3

PC

ACC

B

PSW

SP

DPTR

PCON

IEN0

IEN1

IP0

IP1

S1CON

S1STA

S1DAT

S1ADR

SPCR

SPSR

SPDR

DCON

DKEY

DTXT

00H

XX

FFH

FFH

FFH

FFH

00H

00H

00H

00H

00H

00H

0000H

00H

00H

00H

07H

0000H

0xx0 000

00H

00H

00H

00H

00H

F8H

00H

00H

0000 0100

00H

00H

XX

XX

XX

Note: “XX” means no initialization on reset.

[Table 1] 80C51 SFR Reset Values

Page 18 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Clocks – CPU Cock

4. Clocks

Handshake Solutions

4.1.1. Clockless (Aynchronous) Cnfiguration

A handshake circuit does not require a clock to work, it simply adapts its speed to the environment

(other blocks, supply voltage, temperature, etc.). This is a complete asynchronous mode of operation and our standard configuration of the core.

4.1.2. Clock synchronization (Option HT80C51_CPU_SYNC)

Some applications or programs require a precisely defined timing behavior of the instruction execution, for instance, when timing or waiting loops are used. For this case an optional synchronization feature is offered.

With this feature come two additional input pins:

cpu_clk_i

and

cpu_sync_i

.

cpu_clk_i

delivers the machine clock and thus the speed of the CPU, input

cpu_sync_i

decides, whether the CPU should be synchronized to

cpu_clk_i

or not:

In synchronous mode (

cpu_sync_i

=1), the CPU synchronizes with

cpu_clk_i

on a machine cycle basis after each instruction in such a way that the number of clock cycles for that instruction is the same as the number of machine cycles for a synchronous implementation. Since there are no clock dividers attached, one

cpu_clk_i

cycle equals to one machine cycle.

In asynchronous mode of operation (

cpu_sync_i

=0), the CPU runs at its natural speed, and a slow

cpu_clk_i

does not slow it down.

In a traditional (synchronous) 80C51 system, all clocks for peripherals are derived from the clock for the CPU or from the CPU’s machine cycle, which is usually 1/12 or 1/6 of the CPU clock frequency, depending on the implementation of the CPU. Hence all timing specifications like timer overflow times or baud rates were specified in relation to the CPU clock.

In a handshake design no single, global clock source is needed, the clock for the CPU can even be omitted (which is the standard configuration for the HT80C51). Thus for each peripheral that needs a clock, e.g. timers, serial interfaces or the synchronous SFR bus, a dedicated clock input is provided.

So the optimum clock frequency can be supplied to each peripheral, completely independent from all other clock frequencies. Also note, that there is no internal clock divider implemented (divide by 12 or

6). Thus, compared to a synchronous design, the same timings (e.g. baud rates) can be achieved with a lower input clock frequency resulting in lower power consumption.

The timing specifications of the peripherals are related to their specific input clock frequencies.

© Philips Electronics N.V. 2005 Page 19 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Interrupt Controller

For the HT80C51 a number of standard peripherals like timers and serial interfaces exist. They are compatible to the standard peripherals in synchronous implementations. The peripherals can be ordered along with the CPU and are then part of a combined delivery. The following chapters describe these peripherals in detail with further options (if available) and their SFRs.

This module handles the enabling and priority decoding of interrupt requests as well as entering and leaving the interrupt routines. The number of interrupt inputs can be configured from 0 up to 15.

5.1.1. Options

The interrupt controller can be ordered by option

HT80C51_INT

.

The number of interrupt inputs

int_req_i

can be selected (ordered) by using option

HT80C51_INT_COUNT

.

5.1.2. Special function registers (IEN0 IEN1 IP0 IP1)

The number of implemented SFRs for the interrupt controller and even the number of bits within these

SFRs depends on the selected number of interrupt inputs. For each interrupt input

int_req_i[x]

one interrupt enable bit and one interrupt priority bit exists. All interrupt enable bits are collected in two

SFRs:

IEN0

and

IEN1

. All interrupt priority bits are collected in further two SFRs:

IP0

and

IP1

.

If the number of interrupt inputs is greater than 0, SFRs

IEN0

and

IP0

exist.

If the number of interrupt inputs is greater than 7, SFRs

IEN1

and

IP1

exist, too.

IEN0

(IE)

Interrupt enable register 0

addr = A8H reset value = 00H bits 7 6 5 4 3 2 1 0

EA IEN0.6

bit symbol Function

IEN0.7 EA

1:

0:

General enable/disable control. If

Any individually enabled interrupt will be accepted.

No interrupt is enabled.

EA

= 0,

IEN0.6

IEN0.5 ES1

IEN0.4 ES0

Enable interrupt input

int_req_i[6]

.

Enable I2C interrupt (if available) or interrupt input

int_req_i[5]

.

Enable UART interrupt (if available) or interrupt input

int_req_i[4]

.

IEN0.3

IEN0.2

IEN0.1

ET1

EX1

ET0

Enable timer 1 overflow interrupt (if available) or interrupt input

int_req_i[3]

.

Enable external interrupt from timer 1 (

IE1

) (if available) or interrupt input

int_req_i[2]

.

Enable timer 0 overflow interrupt (if available) or interrupt input

int_req_i[1]

.

IEN0.0 EX0 Enable external interrupt from timer 0 (

IE0

) (if available) or interrupt input

int_req_i[0]

.

Bit values: 0 = interrupt disabled; 1 = interrupt enabled.

Page 20 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Interrupt Controller

IEN1

Handshake Solutions

Interrupt enable register 1

addr = E8H reset value = 00H bits 7 6 5 4 3 2 1 0

IEN1.7 IEN1.6 IEN1.5 IEN1.4 IEN1.3 IEN1.2 IEN1.1 IEN1.0

bit symbol Function

IEN1.7

IEN1.6

IEN1.5

Enable interrupt input “int_req_i[14]”.

Enable interrupt input “int_req_i[13]”.

Enable interrupt input “int_req_i[12]”.

IEN1.4

IEN1.3

IEN1.2

Enable interrupt input “int_req_i[11]”.

Enable interrupt input “int_req_i[10]”.

Enable interrupt input “int_req_i[9]”.

IEN1.1 Enable interrupt input “int_req_i[8]”.

IEN1.0 Enable interrupt input “int_req_i[7]”.

Bit values: 0 = interrupt disabled; 1 = interrupt enabled.

IP0

(IP)

Interrupt priority register 0

addr = B8H reset value = 00H bits 7 6 5 4 3 2 1 0

- IP0.6 PS1 PS0 PT1 PX1 PT0 PX0

bit symbol Function

IP0.7 - reserved.

IP0.6

IP0.5

IP0.4

IP0.3

IP0.2

ES1

ES0

ET1

EX1

Priority level for interrupt input

int_req_i[6]

.

Priority level for I2C interrupt (if available) or interrupt input

int_req_i[5]

.

Priority level for UART interrupt (if available) or interrupt input

int_req_i[4]

.

Priority level for timer 1 overflow interrupt (if available) or interrupt input

int_req_i[3]

.

Priority level for external interrupt from timer 1 (

IE1

) (if available) or interrupt input

int_req_i[2]

.

IP0.1 ET0 Priority level for timer 0 overflow interrupt (if available) or interrupt input

int_req_i[1]

.

IP0.0 EX0 Priority level for external interrupt from timer 0 (

IE0

) (if available) or interrupt input

int_req_i[0]

.

Bit values: 0 = low priority; 1 = high priority.

© Philips Electronics N.V. 2005 Page 21 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Interrupt Controller

IP1

Interrupt priority register 1

addr = F8H reset value = 00H bits 7 6 5 4 3 2 1 0

IP1.7 IP1.6 IP1.5 IP1.4 IP1.3 IP1.2 IP1.1 IP1.0

bit symbol Function

IP1.7

IP1.6

IP1.5

IP1.4

IP1.3

Priority level for interrupt input

int_req_i[14]

.

Priority level for interrupt input

int_req_i[13]

.

Priority level for interrupt input

int_req_i[12]

.

Priority level for interrupt input

int_req_i[11]

.

Priority level for interrupt input

int_req_i[10]

.

IP1.2

IP1.1

IP1.0

Priority level for interrupt input

int_req_i[9]

.

Priority level for interrupt input

int_req_i[8]

.

Priority level for interrupt input

int_req_i[7]

.

Bit values: 0 = low priority; 1 = high priority.

5.1.3. Operation

The HT80C51 provides up to 15 interrupt inputs. Depending on the configuration of standard peripherals, some of these inputs are already internally connected to interrupt sources in these peripherals.

For a description of these interrupt sources, please, see the description of the peripheral blocks.

[Table 2] shows these default connections.

All of the bits that generate interrupts can be set or cleared by software, with the same result as though it had been set or cleared by hardware. That is, interrupts can be generated or pending interrupts can be canceled in software.

Each of these interrupt sources can be individually enabled or disabled by setting or clearing a bit in

Special Function Registers

IEN0

and

IEN1

.

IEN0

also contains a global disable bit,

EA

, which disables all interrupts at once.

5.1.3.1. Interrupt Priority Level Structure

Each interrupt source can also be individually programmed to one of two priority levels by setting or clearing a bit in Special Function Registers

IP0

and

IP1

. A low-priority interrupt can itself be interrupted by a high-priority interrupt, but not by another low-priority interrupt. A high-priority interrupt can’t be interrupted by any other interrupt source.

If two requests of different priority levels are received simultaneously, the request of higher priority level is serviced. If requests of the same priority level are received simultaneously, an internal polling sequence determines which request is serviced. Thus within each priority level there is a second prior-

ity structure determined by the polling sequence, as summarized in [Table 2].

Page 22 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Interrupt Controller Handshake Solutions

interrupt interrupt input standard internal connection

(if peripheral is selected)

vector address enable priority select priority within level

int 8 int 9 int 10 int 11 int 12 int 13 int 4 int 5 int 6 int 7 int 0 int 1 int 2 int 3 int_req_i[0] IE0 int_req_i[1] TF0 int_req_i[2] IE1 int_req_i[3] TF1 int_req_i[4] RI or TI int_req_i[5] SI int_req_i[6] SPIF int_req_i[7] int_req_i[8] int_req_i[9] int_req_i[10] int_req_i[11] int_req_i[12] int_req_i[13] timer 0 timer 0 timer 1 timer 1

0003H

000BH

0013H

001BH

SI0(UART) 0023H

I2C 002BH

SPI 0033H

003BH

0043H

004BH

0053H

005BH

0063H

006BH

IP1.1

IP1.2

IP1.3

IP1.4

IP1.5

IP1.6

IP0.0

IP0.1

IP0.2

IP0.3

IP0.4

IP0.5

IP0.6

IP1.0

IEN1.1

IEN1.2

IEN1.3

IEN1.4

IEN1.5

IEN1.6

IEN0.0

IEN0.1

IEN0.2

IEN0.3

IEN0.4

IEN0.5

IEN0.6

IEN1.0 int 14 int_req_i[14] 0073H IEN1.7 IP1.7 lowest

Note: The “priority within level” structure is only used to resolve simultaneous requests of the same priority level. highest

[Table 2] Interrupt Signals, Vectors and Priorities.

5.1.3.2. How Interrupts Are Handled

The interrupt flags are sampled at every start of an instruction. The samples are polled at the start of the following instruction. If one of the flags was in a set condition at the preceding cycle, the polling cycle will find it and the interrupt system will generate an LCALL to the appropriate service routine, provided this hardware-generated LCALL is not blocked by any of the following conditions:

1. An interrupt of equal or higher priority level is already in progress.

2. The instruction in progress is RETI or any write to the

IENx

or

IPx

registers.

Any of these two conditions will block the generation of the LCALL to the interrupt service routine.

Condition 2 ensures that if the instruction in progress is RETI or any access to

IENx

or

IPx

, then at least one more instruction will be executed before any interrupt is vectored to.

The polling cycle is repeated with each new instruction, and the values polled are the values that were present at the start of the previous instruction. Note that if an interrupt flag is active but not being responded to for one of the above conditions, if the flag is not still active when the blocking condition is removed, the denied interrupt will not be serviced. In other words, the fact that the interrupt flag was once active but not serviced is not remembered. Every polling cycle is new.

© Philips Electronics N.V. 2005 Page 23 of 132

Handshake Solutions

Machine

Cycle

C1 C2 C3

HT80C51 User Manual

Peripheral Modules – Interrupt Controller

C4 C5

Interrupt

Goes

Active

E

Interrupt

Latched

Interrupts

Are Poled

Long Call to

Interrupt

Vector Address

Interrupt Routine

[Figure 7] Interrupt Response Timing Diagram

The polling cycle/LCALL sequence is illustrated in [Figure 7]. Note that if an interrupt of higher priority level goes active prior to the instruction labeled C3 in [Figure 7], then in accordance with the above

rules it will be vectored to during C5 and C6, without any instruction of the lower priority routine having been executed.

Thus the processor acknowledges an interrupt request by executing a hardware-generated LCALL to the appropriate servicing routine. In some cases it also clears the flag that generated the interrupt, and in other cases it doesn’t. It never clears the Serial Port flag. This has to be done in the user’s software.

It clears an external interrupt flag (

IE0

or

IE1

) only if it was transition-activated. The hardwaregenerated LCALL pushes the contents of the Program Counter on to the stack (but it does not save the

PSW

) and reloads the PC with an address that depends on the source of the interrupt being vec-

tored to, as shown in column “vector address” in [Table 2].

Execution proceeds from that location until the RETI instruction is encountered. The RETI instruction informs the processor that this interrupt routine is no longer in progress, then pops the top two bytes from the stack and reloads the Program Counter. Execution of the interrupted program continues from where it left off. Note that a simple RET instruction would also have returned execution to the interrupted program, but it would have left the interrupt control system thinking an interrupt was still in progress, making future interrupts impossible.

The external sources can be programmed to be level-activated or transition-activated by setting or clearing bit

IT1

or

IT0

in Register

TCON

. If

ITx

= 0, external interrupt x is triggered by a detected low at the

t01_intx_n_i

pin. If

ITx

= 1, external interrupt x is edge triggered. In this mode if the interrupt input (

t01_int0_n_i

for

IT0

,

t01_int1_n_i

for

IT1

) shows a high to low transition, interrupt request flag

IEx

in

TCON

is set. Flag bit

IEx

then requests the interrupt. Since the external interrupt pins are not sampled, there is no minimum low duration specified.

IEx

will be automatically cleared by the CPU when the service routine is called.

If the external interrupt is level-activated, the external source has to hold the request active until the requested interrupt is actually generated. Then it has to deactivate the request before the interrupt service routine is completed, or else another interrupt will be generated.

The

t01_int0_n_i

and

t01_int1_n_i

levels are inverted and latched into

IE0

and

IE1

. The values are not actually polled by the circuitry until the next start of an instruction. If a request is active and conditions are right for it to be acknowledged, a hardware subroutine call to the requested service routine will be the next instruction to be executed. The call itself takes two cycles. Thus, a minimum of three complete machine cycles elapse between activation of an external interrupt request and the beginning of execution of the first instruction of the service routine.

Page 24 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Interrupt Controller Handshake Solutions

A longer response time would result if the request were blocked by one of the 2 previously listed conditions. If an interrupt of equal or higher priority level is already in progress, the additional wait time obviously depends on the nature of the other interrupt’s service routine. If the instruction in progress is not in its final cycle, the additional wait time cannot be more the 3 cycles, since the longest instructions

(MUL and DIV) are only 4 cycles long, and if the instruction in progress is RETI or an access to

IE

or

IP

, the additional wait time cannot be more than 5 cycles (a maximum of one more cycle to complete the instruction in progress, plus 4 cycles to complete the next instruction if the instruction is MUL or

DIV).

Thus, in a single-interrupt system, the response time is always more than 3 cycles and less than 9 cycles.

5.1.4. Setting up the Interrupt Controller

To use any of the interrupts in the 80C51 Family, the following three steps must be taken. the (enable all) bit in the

IE

register to 1.

2. Set the corresponding individual interrupt enable bit in the

IE

register to 1.

3. Begin the interrupt service routine at the corresponding Vector Address of that interrupt (see

[Table 2]).

In addition, for external interrupts (input pins

t01_int0_n_i

and

t01_int1_n_i

) depending on whether the interrupt is to be level or transition activated, bits

IT0

or

IT1

in the

TCON

register may need to be set to 1.

ITx

= 0 level activated

ITx

= 1 transition activated

5.1.4.1. Assigning a Higher Priority to One or More Interrupts

In order to assign higher priority to an interrupt, the corresponding bit in the

IPx

register must be set to

1.

Remember that while an interrupt service is in progress, it cannot be interrupted by a lower or same level interrupt.

© Philips Electronics N.V. 2005 Page 25 of 132

Handshake Solutions

5.2. Timers 0 and 1

HT80C51 User Manual

Peripheral Modules – Timers 0 and 1

This module comprises two 16bit timers/counters: timer0 and timer1. Both can be configured to operate either as timers or event counters.

In the “Timer” function, the register is incremented every timer clock cycle (clock input

t01_clk_i

).

Thus, if the operation of the CPU is synchronized to the same clock, one can think of it as counting machine cycles of the CPU.

In the “Counter” function, the register is incremented in response to a 1-to-0 transition at its corresponding external input pin,

t0_count_i

or

t1_count_i

. By design there are no restrictions on the duty cycle or the frequency of the external input signals. However, depending on the standard cell library, that is used, and the actual layout some maximum limits will apply.

5.2.1. Options

This module can be enabled (ordered) by using option

HT80C51_T01

.

5.2.2. Special function registers (TMOD TCON TL0 TL1 TH0 TH1)

TMOD

Timer/Counter Mode Control

addr = 89H reset value = 00H bits 7 6 5 4 3 2 1 0

GATE1 C/T1 T1M1 T1M0 GATE0 C/T0 T0M1 T0M0

bit symbol Function

TMOD.7 GATE1 Timer 1 gating control

1:

0:

Timer/Counter 1 is enabled only while input pin

t01_int1_n_i

is high and

TR1

(

TCON

) is 1.

Timer/Counter 1 is enabled if

TR1

is set.

TMOD.6 C/T1

TMOD.5

TMOD.4

T1M1

T1M0

1:

0:

00:

01:

10:

11:

Timer 1 operation selection counter operation (clock source is input pin

t1_count_i

) timer operation (clock source is the clock input

t01_clk_i

)

Timer 1 mode selection

8048 timer mode,

TL1

serves as a 5bit prescaler

16bit timer/counter:

TH1

and

TL1

are cascaded; no prescaler

8bit auto-reload timer/counter:

TH1

holds the value which is loaded into

TL1

each time it overflows stopped

TMOD.3 GATE0 Timer 0 gating control

1:

0:

Timer/Counter 0 is enabled only while input pin

t01_int0_n_i

is high and

TR0

(

TCON

) is 1.

Timer/Counter 1 is enabled if

TR0

is set.

TMOD.2 C/T0

1:

0:

Timer 0 operation selection counter operation (clock source is input pin

t0_count_i

) timer operation (clock source is the clock input

t01_clk_i

)

TMOD.1

TMOD.0

T0M1

T0M0 00:

01:

10:

11:

Timer 0 mode selection

8048 timer mode,

TL0

serves as a 5bit prescaler

16bit timer/counter:

TH0

and

TL0

are cascaded; no prescaler

8bit auto-reload timer/counter:

TH0

holds the value which is loaded into

TL0

each time it overflows

TL0

is an 8bit timer/counter controlled by standard timer 0 control bits.

TH0

is a further 8bit timer controlled by timer 1 control bits.

Page 26 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Timers 0 and 1

TCON

Handshake Solutions

Timer/Counter Control

addr = 88H reset value = 00H bits 7 6 5 4 3 2 1 0

TL0 bit symbol Function

TCON.7 TF1

TCON.6 TR1

TCON.5 TF0

TCON.4 TR0

TCON.3 IE1

TCON.2 IT1

TCON.1 IE0

TCON.0 IT0

1:

0:

Timer 1 overflow flag.

Set by hardware on Timer/Counter overflow.

Cleared by hardware when processor vectors to interrupt routine, or clearing the bit in software.

Timer 1 Run control bit. Set/cleared by software to turn Timer 1 on/off.

Timer 1 on.

Timer 1 off.

Timer 0 overflow flag.

Set by hardware on Timer/Counter overflow.

Cleared by hardware when processor vectors to interrupt routine, or clearing the bit in software.

1:

0:

Timer 0 Run control bit. Set/cleared by software to turn Timer 1 on/off.

Timer 0 on.

Timer 0 off.

Interrupt 1 edge flag. Set by hardware when external interrupt is detected. Cleared when interrupt is processed.

1:

0:

Interrupt 1 type control bit.

External interrupt

t01_int1_n_i

is edge sensitive (falling edge).

External interrupt

t01_int1_n_i

is level sensitive (low level).

Interrupt 0 edge flag. Set by hardware when external interrupt is detected. Cleared when interrupt is processed.

1:

0:

Interrupt 0 type control bit.

External interrupt

t01_int0_n_i

is edge sensitive (falling edge).

External interrupt

t01_int0_n_i

is level sensitive (low level).

Timer 0 Counter Register, Low Byte

addr = 82H reset value = 00H bits 7 6 5 4 3 2 1 0

TL0

TH0

Timer 0 Counter Register, High Byte

addr = 84H reset value = 00H bits 7 6 5 4 3 2 1 0

TH0

TL1

Timer 1 Counter Register, Low Byte

addr = 83H reset value = 00H bits 7 6 5 4 3 2 1 0

TL1

TH1

Timer 1 Counter Register, High Byte

addr = 85H reset value = 00H bits 7 6 5 4 3 2 1 0

TH1

© Philips Electronics N.V. 2005 Page 27 of 132

Handshake Solutions

5.2.3. Interrupts

HT80C51 User Manual

Peripheral Modules – Timers 0 and 1

Each of the timers can generate two separate interrupt signals, which are directly connected to inter-

rupt request lines of the interrupt controller. The following table and [Figure 8] describe these sources

and connections. For interrupt priorities and interrupt vectors see the description of the interrupt controller.

interrupt source

Description Interrupt signal

timer 0: IE0 int0

Set by hardware when external interrupt

t01_int0_n_i

is detected. If SFR bit

IT0

is set, the flag is set on a falling edge of the external interrupt, if

IT0

is cleared, a low level on the external interrupt line cause an interrupt.

Cleared when interrupt is processed. int1

Set by hardware on Timer/Counter overflow.

Cleared by hardware when processor vectors to interrupt routine, or clearing the bit in software. timer 1: IE1 int2

Set by hardware when external interrupt

t01_int1_n_i

is detected. If SFR bit

IT1

is set, the flag is set on a falling edge of the external interrupt, if

IT1

is cleared, a low level on the external interrupt line cause an interrupt.

Cleared when interrupt is processed. int3

Set by hardware on Timer/Counter overflow.

Cleared by hardware when processor vectors to interrupt routine, or clearing the bit in software. t01_int0_n_i

0

1

IT0

TF0 t01_int1_n_i

0

1

IT1

IE0

IE1 int0 int1 int2

Page 28 of 132

TF1

[Figure 8] Interrupt Sources From the Timers 0 and 1

int3

© Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Timers 0 and 1

5.2.4. Operation

Handshake Solutions

The timer- or counter-function is selected by control bits

C/Tx

in the special function register

TMOD

.

These two timer/counters have four operating modes, which are selected by bit-pairs (

M1

,

M0

) in

TMOD

.

Modes 0, 1, and 2 are the same for both timers/counters.

Mode 3 is different. The four operating modes are described in the following text.

Putting either timer into mode 0 makes it look like an 8048 timer, which is an 8-bit counter with a di-

vide-by-32 prescaler.[Figure 9] shows the mode 0 operation as it applies to timer 1.

In this mode, the timer register is configured as a 13-bit register. As the count rolls over from all 1s to all 0s, it sets the timer interrupt flag

TF1

. The counted input is enabled to the timer when

TR1

= 1 and either

GATE1

= 0 or pin

t01_int1_n_i

= 1. Setting

GATE1

= 1 allows the timer to be controlled by external input

t01_int1_n_i

, to facilitate pulse width measurements).

TR1

is a control bit in the special function register

TCON

.

GATE1

is in

TMOD

.

The 13-bit register consists of all 8 bits of

TH1

and the lower 5 bits of

TL1

. The upper 3 bits of

TL1

are indeterminate and should be ignored. Setting the run flag (

TR1

) does not clear the registers.

Mode 0 operation is the same for the timer 0 as for timer 1. Substitute

TR0

,

TF0

,

GATE0

,

C/T0

,

t0_count_i

and

t01_int0_n_i

for the corresponding timer 1 signals in [Figure 9].

t

01_clk_i t1_count_i

C/T1=0

C/T1=1

Control

TH1

(5 Bits)

TH1

(8 Bits)

TF1 interrupt

TR1

GATE1 t01_int1_n_i

[Figure 9] Timer/Counter mode 0: 13bit counter

Mode 1 is the same as mode 0, except that the timer register is being run with all 16 bits.

Mode 2 configures the timer register as an 8bit counter (

TL1

) with automatic reload, as shown in

[Figure 10]. Overflow from

TL1

not only sets

TF1

, but also reloads

TL1

with the contents of

TH1

, which is preset by software. The reload leaves

TH1

unchanged. Mode 2 operation is the same for timer/counter

0.

© Philips Electronics N.V. 2005 Page 29 of 132

Handshake Solutions t

01_clk_i

HT80C51 User Manual

Peripheral Modules – Timers 0 and 1

C/T1=0

C/T1=1

TL1

(8 Bits)

TF1 interrupt t1_count_i

Control

GATE1 t01_int1_n_i

TR1

TH1

(8 Bits)

Reload

[Figure 10] Timer/counter Mode 2: 8bit auto-reload

.

Timer 1 in mode 3 simply holds its count. The effect is the same as setting

TR1

= 0.

Timer 0 in mode 3 establishes

TL0

and

TH0

as two separate counters. The logic for mode 3 on timer 0

is shown in [Figure 11].

TL0

uses the timer 0 control bits:

C/T0

,

GATE0

,

TR0

,

t01_int0_n_i

and

TF0

.

TH0

is locked into a timer function (counting timer clocks

t01_clk_i

) and takes over the use of

TR1

and

TF1

from timer 1. Thus,

TH0

now controls the “timer 1” interrupt.

Mode 3 is provided for applications requiring an extra 8-bit timer on the counter. With timer 0 in mode

3, an 80C51 can look like it has three timer/counters. When timer 0 is in mode 3, timer 1 can be turned on and off by switching it out of and into its own mode 3, or can still be used by the serial port as a baud rate generator, or in fact, in any application not requiring an interrupt. t

01_clk_i t0_count_i

C/T0=0

C/T0=1

Control

TL0

(8 Bits)

TF0 int1

TR0

GATE0 t01_int0_n_i t01_clk_i

TH0

(8 Bits)

TF1 int3

TR1

[Figure 11] Timer/counter 0 mode 3: Two 8bit counters

.

Page 30 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Timers 0 and 1

5.2.5. Setting up the Timers

Handshake Solutions

[Table 3] and [Table 4] give some values for

TMOD

, which can be used to set up Timer 0 in different modes.

For these tables it is assumed that only one timer is being used at a time. If it is desired to run Timers

0 and 1 simultaneously, in any mode, the value in

TMOD

for Timer 0 must be ORed with the value

shown for Timer 1 ([Table 5] and [Table 6]).

For example, if it is desired to run Timer 0 in mode 1

GATE

(external control), and Timer 1 in mode 2

COUNTER

, then the value that must be loaded into

TMOD

is 69H (09H from [Table 3] ORed with 60H

from [Table 6]). Moreover, it is assumed that the user, at this point, is not ready to turn the timers on

and will do that at a different point in the program by setting bit

TRx

(in

TCON

) to 1.

mode timer 0

2

3

0

1

function internal control

(note 1)

TMOD external control

(note 2)

13bit timer

16bit timer

8bit auto-reload two 8bit timers

[Table 3] Timer 0 as a Timer

00H

01H

02H

03H

08H

09H

0AH

0BH

mode timer 0 function internal control

(note 1)

TMOD external control

(note 2)

2

3

0

1

13bit timer

16bit timer

8bit auto-reload two 8bit timers

04H

05H

06H

07H

0CH

0DH

0EH

0FH

[Table 4] Timer 0 as a Counter

NOTES:

1. The Timer is turned ON/OFF by setting/clearing bit

TR0

in the software.

2. The Timer is turned ON, if both

t01_int0_n_i

= 1 and

TR0

= 1 (hardware control).

© Philips Electronics N.V. 2005 Page 31 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Timers 0 and 1

mode timer 1

2

3

0

1

function

TMOD internal control

(note 1)

13bit timer

16bit timer

8bit auto-reload two 8bit timers

[Table 5] Timer 1 as a Timer

00H

10H

20H

30H

external control

(note 2)

80H

90H

A0H

B0H

mode timer 1 function internal control

(note 1)

TMOD external control

(note 2)

2

3

0

1

13bit timer

16bit timer

8bit auto-reload two 8bit timers

40H

50H

60H

70H

C0H

D0H

E0H

F0H

[Table 6] Timer 1 as a Counter

NOTES:

1. The timer is turned ON/OFF by setting/clearing bit

TR1

in the software.

2. The Timer is turned ON, if both

t01_int0_n_i

= 1 and

TR0

= 1 (hardware control).

Page 32 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0)

5.3. Standard Serial Interface (SIO0)

Handshake Solutions

This module implements a buffered, full duplex asynchronous serial interface with multimaster support.

5.3.1. Options

This module can be enabled (ordered) by using option

HT80C51_SIO

.

5.3.2. Special function registers (SCON SBUF SMOD)

SCON

Serial Port Control Register

addr = 98H reset value = 00H bits 7 6 5 4 3 2 1 0

bit symbol Function

SCON.7

SCON.6

SCON.5

SM0

SM1

SM2

00:

01:

10:

11: serial mode selection: ( mode 0: shift register mode 1: 8bit UART mode 2: 9bit UART mode 3: 9bit UART

SM0

,

SM1

): f f sio_clk_i depending on f t01_overflow sio_clk_i

/64 or f sio_clk_i

/32 depending on f t01_overflow

multiprocessor communication in modes 2 and 3.

If

SM2

=1 in modes 2 and 3, then

RI

will not be activated if the received

9 th

data bit (

RB8

) is 0.

If

SM2

=1 in mode 1, then

RI

will not be activated if a valid stop bit was not received.

SCON.4

SCON.3

SCON.2

SCON.1

REN

TB8

RB8

TI

In mode 0

SM2

should be 0.

Enables serial reception. Set by software to enable reception. Clear by software to disable reception.

The 9th data bit that will be transmitted in Modes 2 and 3. Set or clear by software as desired.

In Modes 2 and 3, is the 9th data bit that was received. In Mode 1, it

SM2

=0,

RB8

is the stop bit that was received. In Mode 0,

RB8

is not used.

Transmit interrupt flag. Set by hardware at the end of the 8th bit time in

Mode 0, or at the beginning of the stop bit in the other modes, in any serial transmission. Must be cleared by software.

SCON.0 RI Receive interrupt flag. Set by hardware at the end of the 8th bit time in

Mode 0, or halfway through the stop bit time in the other modes, in any serial reception (except see

SM2

). Must be cleared by software.

The serial port control and status register is the Special Function Register

SCON

. This register contains not only the mode selection bits, but also the 9th data bit for transmit and receive (

TB8

and

RB8

), and the serial port interrupt bits (

TI

and

RI

).

SBUF

Serial Port Buffer

addr = 99H reset value = XX bits 7 6 5 4 3 2 1 0

SBUF

The serial port receive and transmit registers are both accessed thru special function register

SBUF

.

Writing to

SBUF

loads the transmit register, and reading

SBUF

accesses a physically separate receive register.

© Philips Electronics N.V. 2005 Page 33 of 132

Handshake Solutions

PCON

Power Control Register

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0) addr = 87H reset value =

0xxx0000 bits 7 6 5 4 3 2 1 0

SMOD GF1 GF0 PD IDL

bit symbol Function

PCON.7 SMOD Double baud rate

1: If timer 1 is used to generate the baudrate and the serial interface is used in modes 1, 2 or 3, then the baudrate is doubled.

PCON.6..0

0: The baudrate is not influenced

See description of

PCON

register in CPU section.

5.3.3. Interrupts

The serial interface has two flags to indicate interrupt conditions:

TI

for transmit interrupts and

RI

for receive interrupts. However, there is only one interrupt output, that has to be shared by these interrupt sources. So, if any of the flags

TI

and

RI

is set, an interrupt request will be generated. The software has to check, then, which source was the cause.

interrupt source

Description interrupt signal

UART: TI

RI

Transmit interrupt flag.

Receive interrupt flag.

The logical OR of

TI

and

RI

generates the interrupt request signal. int4

Note: To comply with the standard specification, the serial interface does not support transmitbuffering. So the transmit interrupt is issued when the transmission has been completed (instead of as soon as the contents of

SBUF

are copied to the transmit shift register).

Interrupt flags are set by hardware and have to be reset by software.

5.3.4. Operation

The UART function is full duplex, meaning it can transmit and receive simultaneously. It is also receive-buffered, meaning it can commence reception of a second byte before a previously received byte has been read from the register. (However, if the first byte still hasn’t been read by the time reception of the second byte is complete, one of the bytes will be lost.) The serial port receive and transmit registers are both accessed thru special function register

SBUF

. Writing to

SBUF

loads the transmit register, and reading

SBUF

accesses a physically separate receive register.

The serial port can operate in 4 modes:

Mode 0: Serial data enters at input pin

sio_rxd_i

and exits through output pin

sio_txd_o

. Pin

sio_clk_o

outputs the shift clock during transmission. 8 bits are transmitted/received

(LSB first). The baud rate is fixed at the clock input

sio_clk_i

. This mode is restricted to half duplex operation only.

Page 34 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0) Handshake Solutions

Mode 1: 10 bits are transmitted (through

sio_txd_o

) or received (through

sio_rxd_i

): a start bit

(0), 8 data bits (LSB first), and a stop bit (1). On receive, the stop bit goes into

RB8

in Special Function Register

SCON

. The baud rate is derived from the overflow rate of timer 1.

Mode 2: 11 bits are transmitted (through

sio_txd_o

) or received (through

sio_rxd_i

): start bit

(0), 8 data bits (LSB first), a programmable 9th data bit, and a stop bit (1). On Transmit, the 9th data bit (

TB8

in

SCON

) can be assigned the value of 0 or 1. Or, for example, the parity bit (

P

, in the

PSW

) could be moved into

TB8

. On receive, the 9th data bit goes into

RB8

in Special Function Register

SCON

, while the stop bit is ignored. The baud rate is programmable to either 1/32 or 1/64 of the clock input

sio_clk_i

.

Mode 3: 11 bits are transmitted (through

sio_txd_o

) or received (through

sio_rxd_i

): a start bit

(0), 8 data bits (LSB first), a programmable 9th data bit, and a stop bit (1). In fact, Mode 3 is the same as Mode 2 in all respects except baud rate. The baud rate in Mode 3 is derived from the overflow rate of timer 1.

In all four modes, transmission is initiated by any instruction that uses

SBUF

as a destination register.

Reception is initiated in Mode 0 by the condition

RI

= 0 and

REN

= 1. Reception is initiated in the other modes by the incoming start bit if

REN

= 1.

5.3.4.2. Baud Rates

The baud rate in mode 0 has a fixed relation to the clock input

sio_clk_i

:

Mode 0 Baud Rate =

f

sio_clk_i

The baud rate in Mode 2 depends on the value of bit

SMOD

in special function register

PCON

. If

SMOD

= 0 (which is the value on reset), the baud rate is 1/64 of the frequency on clock input

sio_clk_i

. If

SMOD

= 1, the baud rate is 1/32 of the frequency at

sio_clk_i

.

Mode 2 Baud Rate =

2

SMOD

64

×

f

sio_clk_i

The baud rates in Modes 1 and 3 are determined by the Timer 1 overflow rate.

5.3.4.3. Using Timer 1 to Generate Baud Rates

When Timer 1 is used as the baud rate generator, the baud rates in Modes 1 and 3 are determined by the Timer 1 overflow rate and the value of

SMOD

as follows:

Mode 1, 3 Baud Rate =

2

SMOD

32

×

(

Timer

1

overflow rate

)

The Timer 1 interrupt should be disabled in this application. The Timer itself can be configured for either “timer” or “counter” operation, and in any of its 3 running modes. In the most typical applications, it is configured for “timer” operation, in the auto-reload mode (high nibble of

TMOD

= 0010B). In that case the baud rate is given by the formula:

Mode 1, 3 Baud Rate =

2

SMOD

32

×

f t

01 _

256

(

clk

_

TH i

1

)

One can achieve very low baud rates with Timer 1 by leaving the Timer 1 interrupt enabled, and configuring the Timer to run as a 16-bit timer (high nibble of

TMOD

= 0001B), and using the Timer 1 inter-

rupt to do a 16-bit software reload. [Table 7] lists various commonly used baud rates and how they can

be obtained from Timer 1.

© Philips Electronics N.V. 2005 Page 35 of 132

Handshake Solutions sio mode baud rate

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0)

Timer 1 clock input clock frequency SMOD sio_clk_i X

1, 3

1, 3

1, 3

1, 3

1, 3

1, 3

1, 3

1, 3

1, 3

1, 3

1, 3

1, 3

691.2k

345.6k

230.4k

115.2k

115.2k

19.2k

19.2k

9.6k

4.8k

2.4k

1.2k

137.5 t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i t01_clk_i

11.059 MHz

11.059 MHz

11.059 MHz

11.059 MHz

1.8432 MHz

0.9216 MHz

1.8432 MHz

1.8432 MHz

1.8432 MHz

1.8432 MHz

1.8432 MHz

1 MHz

2

2

2

2

2

2

2

2

2

2

2

2

0

0

0

0

0

0

0

0

0

0

0

0

1

0

1

1

1

1

1

1

0

0

0

0

1, 3

1, 3

110 t01_clk_i 0.5 MHz 0 0 2

110 t01_clk_i 1.8432 MHz 0 0

[Table 7] Timer 1 Generated Commonly Used Baud Rates

1

72H

FDF4H

5.3.4.4. More About Mode 0

Serial data enters at input pin

sio_rxd_i

and exits through output pin

sio_txd_o

. Pin

sio_clk_o

outputs the shift clock during transmission. 8 bits are transmitted/received (LSB first). The baud rate is fixed at the clock input

sio_clk_i

.[Figure 12] shows a simplified functional diagram of the serial port

in Mode 0. This mode should be used in half duplex operation only.

Transmission is initiated by any instruction that uses

SBUF

as a destination register.

SEND

enables the output of the shift register to be routed to output pin

sio_txd_o

and also enables shift clock to the output pin

sio_clk_o

. The output data is always stable on the rising edge of the shift clock. Every clock cycle in which

SEND

is active, the contents of the transmit shift are shifted to the right one position.

Reception is initiated by the condition

REN

= 1 and

RI

= 0.

RECEIVE

enables the shift clock to the output pin

sio_clk_o

. The input data on pin

sio_rxd_i

is sampled on the falling edge of the shift clock. Every clock cycle in which

RECEIVE

is active, the contents of the receive shift register are shifted to the left one position. At the 8th shift clock cycle

RI

is set (and

RECEIVE

is cleared)

Clearing bit

REN

during reception immediately stops the receiver.

FFH

FEH

FDH

FAH

FFH

FDH

FAH

FAH

F4H

E8H

D0H

1DH

Page 36 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0) Handshake Solutions

HT-SFR bus

SBUF read only SBUF write only sio_rxd_i sio_txd_o

RI

TI

>=1 sio_clk_i int[4]

& sio_clk_o

SEND

RECEIVE

>=1 sio_active_o notRI

REN

&

RECEIVE

1 sio_mode0_o

[Figure 12] Block Diagram of Serial Interface in Mode 0

5.3.4.5. More About Mode 1

10 bits are transmitted (through

sio_txd_o

) or received (through

sio_rxd_i

): a start bit (0), 8 data bits (LSB first), and a stop bit (1). On receive, the stop bit goes into

RB8

in Special Function Register

SCON

. The baud rate is derived from the overflow rate of timer 1. [Figure 13]shows a simplified func-

tional diagram of the serial port in mode 1.

Transmission is initiated by any instruction that uses

SBUF

as a destination register. Transmission actually commences immediately after the next rollover in the divide-by-16 counter. (Thus, the bit times are synchronized to the divide-by-16 counter, not to the “write to

SBUF

” signal.) After sending the start-bit and 8 data bits, the

TI

bit is set and the stop-bit is sent.

Reception is initiated by the detection of a 1-to-0 transition at

sio_rxd_i

. For this purpose

sio_rxd_i

is sampled at a rate of 16 times whatever baud rate has been established. When a transition is detected, the divide-by-16 counter is immediately reset, thus it aligns its rollovers with the boundaries of the incoming bit times. At the 7th, 8th, and 9th counter states of each bit time, the bit detector samples the value of

sio_rxd_i

. The value accepted is the value that was seen in at least 2 of the 3 samples. This is done for noise rejection. If the value accepted during the first bit time is not 0,

© Philips Electronics N.V. 2005 Page 37 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0) the receive circuits are reset and the unit goes back to looking for another 1-to-0 transition. This is to provide rejection of false start bits. After the 8 data bits and the stop-bit have been received, the result is loaded into

SBUF

and

RB8

, and

RI

is set to 1, but that is only done, if the following conditions are met:

1.

RI

= 0, and

2. Either = 0, or the received stop bit = 1.

If either of these two conditions is not met, the received frame is irretrievably lost. If both conditions are met, the stop bit goes into

RB8

, the 8 data bits go into

SBUF

, and

RI

is activated. Then the unit goes back to looking for a 1-to-0 transition in

sio_rxd_i

.

5.3.4.6. More About Modes 2 and 3

These modes are very similar to mode 1, with the main difference, that here 9 data bits are used instead of 8 data bits in mode 0.

11 bits are transmitted (through

sio_txd_o

) or received (through

sio_rxd_i

): start bit (0), 8 data bits (LSB first), a programmable 9th data bit, and a stop bit (1). On Transmit, the 9th data bit (

TB8

in

SCON

) can be assigned the value of 0 or 1. On receive, the 9th data bit goes into

RB8

in Special Function Register

SCON

, while the stop bit is ignored. In mode 2 the baud rate is programmable to either

1/32 or 1/64 of the clock input

sio_clk_i

. In mode 3 the baud rate is derived from the overflow rate

of timer 1. [Figure 13] shows a simplified functional diagram of the serial port in modes 2 and 3.

The receive portion is exactly the same as in Mode 1. The transmit portion differs from Mode 1 only in the 9th bit of the transmit shift register.

Transmission is initiated by any instruction that uses

SBUF

as a destination register. Transmission actually commences immediately after the next rollover in the divide-by-16 counter. (Thus, the bit times are synchronized to the divide-by-16 counter, not to the “write to

SBUF

” signal.) After sending the start-bit and 9 data bits, the

TI

bit is set and the stop-bit is sent.

Reception is initiated by the detection of a 1-to-0 transition at

sio_rxd_i

. For this purpose

sio_rxd_i

is sampled at a rate of 16 times whatever baud rate has been established. When a transition is detected, the divide-by-16 counter is immediately reset, thus it aligns its rollovers with the boundaries of the incoming bit times. At the 7th, 8th, and 9th counter states of each bit time, the bit detector samples the value of

sio_rxd_i

. The value accepted is the value that was seen in at least 2 of the 3 samples. This is done for noise rejection. If the value accepted during the first bit time is not 0, the receive circuits are reset and the unit goes back to looking for another 1-to-0 transition. This is to provide rejection of false start bits. After the 9 data bits and the stop-bit have been received, the result is loaded into

SBUF

and

RB8

, and

RI

is set to 1, but that is only done, if the following conditions are met:

1.

RI

= 0, and

2. Either = 0, or the received stop bit = 1.

If either of these two conditions is not met, the received frame is irretrievably lost. If both conditions are met, the first 8 data bits go into

SBUF

, the 9 th

data bit goes into

RB8

, and

RI

is activated.

Then the unit goes back to looking for a 1-to-0 transition in

sio_rxd_i

.

Page 38 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0) Handshake Solutions

HT-SFR bus start-bit detector

SBUF read only SBUF write only not SEND

>=1 sio_rxd_i bit sampler sio_txd_o

RI TI

>=1

RB8 TB8 int[4] sio_clk_i t1_overflow

2

1

3

1/2

1

0

1/16 mode sio_clk_o

SEND

0

>=1 sio_active_o

RECEIVE sio_mode0_o

0

[Figure 13] Block Diagram of Serial Interface in Mode 1, 2, and 3

Multiprocessor Communications

Modes 2 and 3 have a special provision for multiprocessor communications. In these modes, 9 data bits are received. The 9th one goes into

RB8

. Then comes a stop bit. The port can be programmed such that when the stop bit is received, the serial port interrupt will be activated only if

RB8

= 1. This feature is enabled by setting bit

SM2

in

SCON

. A way to use this feature in multiprocessor systems is as follows:

When the master processor wants to transmit a block of data to one of several slaves, it first sends out an address byte that identifies the target slave. An address byte differs from a data byte in that the 9th bit is 1 in an address byte and 0 in a data byte. With

SM2

= 1, no slave will be interrupted by a data byte. An address byte, however, will interrupt all slaves, so that each slave can examine the received byte and see if it is being addressed. The addressed slave will clear its

SM2

bit and prepare to receive the data bytes that will be coming.

The slaves that weren’t being addressed leave their

SM2

s set and go on about their business, ignoring the coming data bytes.

SM2

has no effect in Mode 0, and in Mode 1 it can be used to check the validity of the stop bit. In a

Mode 1 reception, if

SM2

= 1, the receive interrupt will not be activated unless a valid stop bit is received.

© Philips Electronics N.V. 2005 Page 39 of 132

Handshake Solutions

5.3.5. Setting up the serial port

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0)

[Table 8] summarizes the initialization values for

SCON

to select different modes of the

UART

.

baud rate SCON

SM0 SM1

SMOD = 0 SMOD = 1

SM2 = 0: single processor environment

SM2 = 1: multi processor environment

0

0

1

1

0

1

0

1 mode 0: shift register mode 1: 8bit UART mode 2: 9bit UART mode 3: 9bit UART f sio_clk_i f t01_overflow

/32 f sio_clk_i

/64 f t01_overflow

/32 f sio_clk_i f t01_overflow

/16 f sio_clk_i

/32 f t01_overflow

/16

10H

50H

90H

D0H

NA

70H

B0H

F0H

[Table 8] Serial Port Setup

5.3.5.1. Generating Baud Rates

Serial Port in Mode 0:

Mode 0 has a fixed baud rate which is the frequency at clock input

sio_clk_i

. To run the serial port in this mode none of the Timer/Counters need to be set up. Only the

SCON

register needs to be defined.

Baud Rate

=

f

sio

_

clk

_

i

Serial Port in Mode 1:

Mode 1 has a variable baud rate. Timer 1 generates the baud rate.

For this purpose, Timer 1 is used in mode 2 (Auto-Reload). Refer to the initialization section of the

timer description (Chapter 5.2.5).

Baud Rate

=

32

K

×

×

f

[

256

t

01

_

(

clk

_

TH i

1

)

]

If

SMOD

= 0, then

K

= 1.

If

SMOD

= 1, then

K

= 2 (

SMOD

is in the

PCON

register).

Most of the time the user knows the baud rate and needs to know the reload value for

TH1

.

TH

1

=

256

K

×

f

t

01 _

clk

32

×

(

baud

_

i

rate

)

TH1

must be an integer value. Rounding off

TH1

to the nearest integer may not produce the desired baud rate. In this case, the user may have to choose another crystal frequency.

Since the

PCON

register is not bit addressable, one way to set the bit is logical ORing the

PCON

register

(i.e., ORL PCON,#80H). The address of

PCON

is 87H.

Serial Port in Mode 2:

The baud rate is fixed in this mode and is 1/32 or 1/64 of the frequency at clock input

sio_clk_i

, depending on the value of the

SMOD

bit in the

PCON

register.

Page 40 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Standard Serial Interface (SIO0) Handshake Solutions

In this mode none of the Timers are used and the clock comes from the serial clock input

sio_clk_i

.

SMOD

= 1, Baud Rate = 1/32 of the frequency at

sio_clk_i

.

SMOD

= 0, Baud Rate = 1/64 of the frequency at

sio_clk_i

.

To set the

SMOD

bit:

ORL PCON,#80H. The address of

PCON

is 87H.

Serial Port in Mode 3:

The baud rate in mode 3 is variable and sets up exactly the same as in mode 1.

© Philips Electronics N.V. 2005 Page 41 of 132

Handshake Solutions

5.4. General Purpose IOs

HT80C51 User Manual

Peripheral Modules – General Purpose IOs

This module comprises unidirectional, parallel input and/or output ports to read in signals from the environment or set signals for the system.

5.4.1. Options

The number and addresses of output ports can be selected (ordered) by using options

HT80C51_GPIO_POUT_COUNT

and

HT80C51_GPIO_POUT_ADDRESSES

.

The number and addresses of input ports can be selected (ordered) by using options

HT80C51_GPIO_PIN_COUNT

and

HT80C51_GPIO_PIN_ADDRESSES

.

Note: If an output port is placed at an address ending with 0H or 8H, the bits of the port are directly addressable.

5.4.2. Special function registers (POUTx PINx)

POUT0

Output Port 0

addr = 80H

(configurable) reset value = FFH bits 7 6 5 4 3 2 1 0

POUT0

bit symbol Function

POUT0.7

..

POUT0.0

set the output values of output pins

gpio_pout0_o[7:0]

POUT1

Output Port 1

addr = 90H

(configurable) reset value = FFH bits 7 6 5 4 3 2 1 0

POUT1

bit symbol Function

POUT1.7

..

POUT1.0

set the output values of output pins

gpio_pout1_o[7:0]

POUT2

Output Port 2

addr = A0H

(configurable) reset value = FFH bits 7 6 5 4 3 2 1 0

POUT2

bit symbol Function

POUT2.7

..

POUT2.0

set the output values of output pins

gpio_pout2_o[7:0]

Page 42 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – General Purpose IOs Handshake Solutions

POUT3

Output Port 3

addr = B0

(configurable) reset value = FFH bits 7 6 5 4 3 2 1 0

POUT3

bit symbol Function

POUT3.7

..

POUT3.0

set the output values of output pins

gpio_pout3_o[7:0]

POUTx

Output Port x, x>3

addr =

(configurable) reset value = FFH bits 7 6 5 4 3 2 1 0

POUTx

bit symbol Function

POUTx.7

..

POUTx.0

set the output values of output pins

gpio_poutx_o[7:0]

PINx

Input Port x

addr =

(configurable) reset value = not applicable bits 7 6 5 4 3 2 1 0

PINx

bit symbol Function

PINx.7 ..

PINx.0

Read the values of input pins

gpio_pinx_o[7:0]

Write accesses have no effect.

.

5.4.3. Interrupts

No interrupts are generated.

5.4.4. Operation

Write accesses to output ports directly set the related output pins. There is no synchronization to any external clocks done. Read accesses to output ports return the contents of the output latches.

Read accesses to input port return the values that are applied to their related input pins. Write accesses to an input port have no effect.

© Philips Electronics N.V. 2005 Page 43 of 132

Handshake Solutions

5.5. I

2

C Interface (SIO1)

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

The Handshake Technology I2C (referred to as HT-I2C) is a low power version of the standard 80C51

I2C (as used in the 8XC552 80C51).

The HT-I2C implementation offers several unique features, which are detailed below.

The HT-I2C consumes almost zero stand-by power while in sleep mode, yet is immediately available for full-speed full-functional operation.

The HT-I2C has very low electromagnetic emission (EME).

The HT-I2C has low supply-current peaks, thus facilitating integration with analog and RF circuitry.

The HT-I2C use a dedicated special function register (HT-SFR) bus for interconnects with the

HT80C51 micro-controller.

5.5.1. Options

A master-slave combination of the I2C interface can be ordered by option

HT80C51_I2C

.

A slave-only I2C interface can be ordered by using option

HT80C51_I2C_SLAVEONLY

.

5.5.2. Special function registers (S1CON S1ADR S1DAT S1STA )

S1CON

SIO1 control register

addr = D8H reset value = 00H bits 7 6 5 4 3 2 1 0

CR2

ENS1

STA

STO SI AA CR1 CR0

bit symbol Function

S1CON.7 CR2 Clock rate bit 2 (not implemented in slave-only version)

S1CON.6 ENS1

S1CON.5

S1CON.4

S1CON.3

STA

STO

SI

1:

0:

SIO1

enable bit

SIO1

enabled

SIO1

disabled

STArt flag, starts transmission (not implemented in slave-only version)

STOp flag, stops transmission

Serial Interrupt; set by hardware, when an interrupt request is generated; must be reset be software

S1CON.2 AA

S1CON.1 CR1

S1CON.0 CR0

Assert Acknowledge flag; type of acknowledge to be returned

1:

0: return NOT ACK return ACK

Clock rate bit 1 (not implemented in slave-only version)

Clock rate bit 0 (not implemented in slave-only version)

Note: For “not implemented” bits always write 0s, read accesses always return 0.

The master and slave operate on a common clock signal, which depends on the actual values of the signals

CR0

,

CR1

and

CR2

. Changing one or more of the following bits

CR0

,

CR1

or

CR2

during a data transfer may lead to unpredictable results. The baud rates are derived from a dedicated clock input pin

(

i2c_clk_i

).

Note: Baud rate generation and clock input pin (

i2c_clk_i

) are not available for the slave-only version.

Page 44 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions i2c_clk_i

/256 i2c_clk_i

/224 i2c_clk_i

/192 i2c_clk_i

/160 i2c_clk_i

/960 i2c_clk_i

/120 i2c_clk_i

/60

1 1 1 Timer 1 overflow rate / 8

S1ADR

SIO1 slave address register

addr = DBH reset value = 00H bits 7 6 5 4 3 2 1 0

S1DAT bit symbol Function

S1ADR.7

S1ADR.6

S1ADR.5

S1ADR.4

S1ADR.3

S1ADR.2

S1ADR.1

Own slave address in slave mode.

S1ADR.0 GC General Call enable

1:

0:

General call address is recognized.

General call address is not recognized.

SIO1 data register

addr = DAH reset value = 00H bits 7 6 5 4 3 2 1 0 transmit / receive data

bit symbol Function

S1DAT.7

S1DAT.6

S1DAT.5

S1DAT.4

S1DAT.3

S1DAT.2

S1DAT.1

S1DAT.0

Data byte to be transmitted or been received.

S1DAT

remains unchanged by hardware, as long as

SI

(in

S1CON

) is set.

© Philips Electronics N.V. 2005 Page 45 of 132

Handshake Solutions

S1STA

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

SIO1 status register

addr = D9H reset value = F8H bits 7 6 5 4 3 2 1 0

bit symbol Function

S1STA.7

S1STA.6

S1STA.5

S1STA.4

S1STA.3

Status code. The status is valid as long as

SI

is set. When no relevant status is available,

S1STA

contains the value F8H.

S1STA.2

S1STA.1

S1STA.0

Always 0.

5.5.3. Interrupts

The HT-I2C can generate only one interrupt. If the bit

SI

in the SFR

S1CON

is set, an interrupt is requested on line

int_req_i[5]

.

SI

is set by hardware but has to be cleared by software, for instance in the interrupt service routine.

5.5.4. Operation

The I2C bus uses two wires (SDA and SCL) to transfer information between devices connected to the bus. The main features of the bus are:

Bidirectional data transfer between masters and slaves

Multimaster bus (no central master)

Arbitration between simultaneously transmitting masters without corruption of serial data on the bus

Serial clock synchronization allows devices with different bit rates to communicate via one serial bus

Serial clock synchronization can be used as a handshake mechanism to suspend and resume serial transfer

The I2C bus may be used for test and diagnostic purposes

The HT-I2C logic (here also named SIO1) provides a serial interface that meets the I2C bus specification and supports all transfer modes (other than the low-speed mode) from and to the I2C bus. The

HT-I2C logic handles bytes transfer autonomously. It also keeps track of serial transfers, and a status register (

S1STA

) reflects the status of HT-I2C and the I2C bus.

The CPU interfaces to the I2C logic via the following four special function registers:

S1CON

(SIO1 control register),

S1STA

(SIO1 status register),

S1DAT

(SIO1 data register), and

S1ADR

(SIO1 slave address register). The SIO1 logic interfaces to the external I2C bus via two port 1 pins: SCL (serial clock line) and SDA (serial data line).

A typical I2C bus configuration is shown in [Figure 14]. [Figure 15] shows how a data transfer is ac-

complished on the bus. Depending on the state of the direction bit (R/W), two types of data transfers are possible on the I2C bus:

1. Data transfer from a master transmitter to a slave receiver. The first byte transmitted by the master is the slave address. Next follows a number of data bytes. The slave returns an acknowledge bit after each received byte.

Page 46 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

2. Data transfer from a slave transmitter to a master receiver. The first byte (the slave address) is transmitted by the master. The slave then returns an acknowledge bit. Next follows the data bytes transmitted by the slave to the master. The master returns an acknowledge bit after all received bytes other than the last byte. At the end of the last received byte, a “not acknowledge” is returned.

The master device generates all of the serial clock pulses and the START and STOP conditions. A transfer is ended with a STOP condition or with a repeated START condition. Since a repeated

START condition is also the beginning of the next serial transfer, the I2C bus will not be released.

5.5.4.1. Modes of Operation

The on-chip SIO1 logic may operate in the following four modes:

1. Master Transmitter mode (not available for slave-only version)

Serial data output through SDA while SCL outputs the serial clock. The first transmitted byte contains the slave address of the receiving device (7 bits) and the data direction bit. In this mode the data direction bit (R/W) will be logic 0, and we say that a “W” is transmitted. Thus the first byte transmitted is

SLA+W.

Serial data is transmitted 8 bits at a time. After each byte is transmitted, an acknowledge bit is received. START and STOP conditions are output to indicate the beginning and the end of a serial transfer.

2. Master Receiver Mode (not available for slave-only version)

The first transmitted byte contains the slave address of the transmitting device (7 bits) and the data direction bit. In this mode the data direction bit (R/W) will be logic 1, and we say that an “R” is transmitted. Thus the first byte transmitted is SLA+R.

Serial data is received via SDA while SCL outputs the serial clock. Serial data is received 8 bits at a time. After each byte is received, an acknowledge bit is transmitted. START and STOP conditions are output to indicate the beginning and end of a serial transfer.

3. Slave Receiver mode:

Serial data and the serial clock are received through SDA and SCL. After each byte is received, an acknowledge bit is transmitted. START and STOP conditions are recognized as the beginning and end of a serial transfer. Address recognition is performed by hardware after reception of the slave address and direction bit.

4. Slave Transmitter mode:

The first byte is received and handled as in the Slave Receiver mode. However, in this mode, the direction bit will indicate that the transfer direction is reversed. Serial data is transmitted via SDA while the serial clock is input through SCL. START and STOP conditions are recognized as the beginning and end of a serial transfer.

In a given application, SIO1 may operate as a master and as a slave. In the Slave mode, the SIO1 hardware looks for its own slave address and the general call address. If one of these addresses is detected, an interrupt is requested. When the microcontroller wishes to become the bus master, the hardware waits until the bus is free before the Master mode is entered so that a possible slave action is not interrupted. If bus arbitration is lost in the Master mode, SIO1 switches to the Slave mode immediately and can detect its own slave address in the same serial transfer.

© Philips Electronics N.V. 2005 Page 47 of 132

Handshake Solutions

I

2

C bus

Rp

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

Rp

V

DD

SDA

SCL

P1.7/SDA

P89C66x

P1.6/SCL

OTHER DEVICE WITH

I

2

C INTERFACE

OTHER DEVICE WITH

I

2

C INTERFACE

[Figure 14] Typical I

2

C Bus Configuration

SDA

MSB

STOP

CONDITION

REPEATED

START

CONDITION

SLAVE ADDRESS

R/W

DIRECTION

BIT

ACKNOWLEDGMENT

SIGNAL FROM RECEIVER

ACKNOWLEDGMENT

SIGNAL FROM RECEIVER

CLOCK LINE HELD LOW WHILE

INTERRUPTS ARE SERVICED

SCL

1 2 7 8 9

ACK

1 2 3-8 9

ACK

S

REPEATED IF MORE BYTES

ARE TRANSFERRED

P/S

START

CONDITION

[Figure 15] Data Transfer on the I

2

C Bus

5.5.4.2. SIO1 Implementation and Operation

[Figure 16] shows how the on-chip I2C bus interface is implemented, and the following text describes

the individual blocks.

Input Filters and Output Stages

The input filters should have I2C compatible input levels. If the input voltage is less than 1.5 V, the input logic level is interpreted as 0; if the input voltage is greater than 3.0 V, the input logic level is interpreted as 1. For low speed implementations it is advisable to use input filter circuits for the pins

SDA and SCL, to suppress noise on these signals.

Page 48 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

The output stages should consist of open drain transistors that can sink 3mA at VOUT < 0.4 V. These open drain outputs should not have clamping diodes to VDD. Thus, if the device is connected to the

I2C bus and VDD is switched off, the I2C bus is not affected.

Address Register, S1ADR

This 8-bit special function register may be loaded with the 7-bit slave address (7 most significant bits) to which SIO1 will respond when programmed as a slave transmitter or receiver. The LSB (GC) is used to enable general call address (00H) recognition.

Comparator

The comparator compares the received 7-bit slave address with its own slave address (7 most significant bits in

S1ADR

). It also compares the first received 8-bit byte with the general call address (00H). If equality is found, the appropriate status bits are set and an interrupt is requested.

Shift Register, S1DAT

This 8-bit special function register contains a byte of serial data to be transmitted or a byte, which has just been received. Data in

S1DAT

is always shifted from right to left; the first bit to be transmitted is the

MSB

(bit 7) and, after a byte has been received, the first bit of received data is located at the

MSB

of

S1DAT

. While data is being shifted out, data on the bus is simultaneously being shifted in;

S1DAT

always contains the last byte present on the bus.

Thus, in the event of lost arbitration, the transition from master transmitter to slave receiver is made with the correct data in

S1DAT

.

© Philips Electronics N.V. 2005 Page 49 of 132

Handshake Solutions external pad drivers HT80C51

S1ADR ADDRESS REGISTER

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

8

SDA

SCL

COMPARATOR

INPUT

FILTER i2c_sda_i

OUTPUT

STAGE i2c_sda_o S1DAT SHIFT REGISTER ACK

INPUT

FILTER

OUTPUT

STAGE i2c_scl_i i2c_scl_o t1_overflow

S1CON

ARBITRATION &

SYNC LOGIC

SERIAL CLOCK

GENERATOR

CONTROL REGISTER

TIMING

&

CONTROL

LOGIC

8 i2c_clk_i

INTERRUPT

8

STATUS BITS

STATUS

DECODER

S1STA STATUS REGISTER

Page 50 of 132

8

[Figure 16] I

2

C Bus Serial Interface Block Diagram

© Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

Arbitration and Synchronization Logic

Handshake Solutions

In the Master Transmitter mode, the arbitration logic checks that every transmitted logic 1 actually appears as a logic 1 on the I2C bus. If another device on the bus overrules a logic 1 and pulls the SDA line low, arbitration is lost, and SIO1 immediately changes from master transmitter to slave receiver.

SIO1 will continue to output clock pulses (on SCL) until transmission of the current serial byte is complete.

Arbitration may also be lost in the Master Receiver mode. Loss of arbitration in this mode can only occur while SIO1 is returning a “not acknowledge: (logic 1) to the bus. Arbitration is lost when another device on the bus pulls this signal LOW. Since this can occur only at the end of a serial byte, SIO1

generates no further clock pulses. The arbitration procedure is illustrated in [Figure 17].

The synchronization logic will synchronize the serial clock generator with the clock pulses on the SCL line from another device. If two or more master devices generate clock pulses, the “mark” duration is determined by the device that generates the shortest “marks,” and the “space” duration is determined

by the device that generates the longest “spaces.” [Figure 18] shows the synchronization procedure.

A slave may stretch the space duration to slow down the bus master. The space duration may also be stretched for handshaking purposes. This can be done after each bit or after a complete byte transfer.

SIO1 will stretch the SCL space duration after a byte has been transmitted or received and the acknowledge bit has been transferred. The serial interrupt flag (

SI

) is set, and the stretching continues until the serial interrupt flag is cleared.

(3)

(1) (1) (2)

SDA

SCL

1 2 3 4 8 9

ACK

(1) Another device transmits identical serial data.

(2) Another device overrules a logic 1 (dotted line) transmitted by SIO1 (master) by pulling the SDA line low. Arbitration is lost, and SIO1 enters the slave receiver mode.

not generate clock pulses for the next byte. Data on SDA originates from the new master once it has won arbitration.

[Figure 17] Arbitration Procedure

© Philips Electronics N.V. 2005 Page 51 of 132

Handshake Solutions

SDA

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

(1) (3) (1)

SCL

(2)

SPACE DURATION

MARK

DURATION

(1) Another service pulls the SCL line low before the SIO1 "mark" duration is complete. The serial clock generator is immediately reset and commences with the "space" duration by pulling SCL low.

(2) Another device still pulls the SCL line low after SIO1 releases SCL. The serial clock generator is forced into the wait state until the SCL line is released.

(3) The SCL line is released, and the serial clock generator commences with the mark duration.

[Figure 18] Serial Clock Synchronization

Serial Clock Generator

This programmable clock pulse generator provides the SCL clock pulses when SIO1 is in the Master

Transmitter or Master Receiver mode. It is switched off when SIO1 is in a Slave mode. The programmable output clock frequencies are: f i2c_clk_i

/60 to f i2c_clk_i

/256 and the Timer 1 overflow rate divided by eight. The output clock pulses have a 50% duty cycle unless the clock generator is synchronized with other SCL clock sources as described above.

Timing and Control

The timing and control logic generates the timing and control signals for serial byte handling. This logic block provides the shift pulses for

S1DAT

, enables the comparator, generates and detects start and stop conditions, receives and transmits acknowledge bits, controls the master and Slave modes, contains interrupt request logic, and monitors the I2C bus status.

Control Register, S1CON

This 7-bit special function register is used by the microcontroller to control the following SIO1 functions: start and restart of a serial transfer, termination of a serial transfer, bit rate, address recognition, and acknowledgment.

Status Decoder and Status Register

The status decoder takes all of the internal status bits and compresses them into a 5-bit code. This code is unique for each I2C bus status. The 5-bit code may be used to generate vector addresses for fast processing of the various service routines. Each service routine processes a particular bus status.

There are 26 possible bus states if all four modes of SIO1 are used. The 5-bit status code is latched

Page 52 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions into the five most significant bits of the status register when the serial interrupt flag is set (by hardware) and remains stable until the interrupt flag is cleared by software. The three least significant bits of the status register are always zero. If the status code is used as a vector to service routines, then the routines are displaced by eight address locations. Eight bytes of code are sufficient for most of the service routines.

5.5.4.3. The Four SIO1 Special Function Registers

The microcontroller interfaces to SIO1 via four special function registers. These four SFRs (

S1ADR

,

S1DAT

,

S1CON

, and

S1STA

) are described individually in the following sections.

The Address Register, S1ADR

The CPU can read from and write to this 8-bit, directly addressable SFR.

S1ADR

is not affected by the

SIO1 hardware. The contents of this register are irrelevant when SIO1 is in a Master mode. In the

Slave modes, the seven most significant bits must be loaded with the microcontroller’s own slave address, and, if the least significant bit is set, the general call address (00H) is recognized; otherwise it is ignored.

7 6 5 4 3 2 1 0

S1ADR (DBH)

own slave address GC

The most significant bit corresponds to the first bit received from the I2C bus after a start condition. A logic 1 in S1ADR corresponds to a high level on the I2C bus, and a logic 0 corresponds to a low level on the bus.

The Data Register, S1DAT

S1DAT

contains a byte of serial data to be transmitted or a byte, which has just been received. The

CPU can read from and write to this 8-bit, directly addressable SFR while it is not in the process of shifting a byte. This occurs when

SIO1

is in a defined state and the serial interrupt flag is set. Data in

S1DAT

remains stable as long as

SI

is set. Data in

S1DAT

is always shifted from right to left: the first bit to be transmitted is the

MSB

(bit 7), and, after a byte has been received, the first bit of received data is located at the

MSB

of

S1DAT

. While data is being shifted out, data on the bus is simultaneously being shifted in;

S1DAT

always contains the last data byte present on the bus. Thus, in the event of lost arbitration, the transition from master transmitter to slave receiver is made with the correct data in

S1DAT

.

7 6 5 4 3 2 1 0

S1DAT (DAH)

SD7 SD6 SD5 SD4 SD3 SD2 SD1 SD0

SD7 - SD0:

← shift direction

Eight bits to be transmitted or just received. A logic 1 in

S1DAT

corresponds to a high level on the I2C bus, and a logic 0 corresponds to a low level on the bus. Serial data shifts through

S1DAT

from right to

left. [Figure 19] shows how data in

S1DAT

is serially transferred to and from the SDA line.

S1DAT

and the

ACK

flag form a 9-bit shift register which shifts in or shifts out an 8-bit byte, followed by an acknowledge bit. The ACK flag is controlled by the SIO1 hardware and cannot be accessed by the

CPU. Serial data is shifted through the

ACK

flag into

S1DAT

on the rising edges of serial clock pulses

© Philips Electronics N.V. 2005 Page 53 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) on the SCL line. When a byte has been shifted into

S1DAT

, the serial data is available in

S1DAT

, and the acknowledge bit is returned by the control logic during the ninth clock pulse. Serial data is shifted out from

S1DAT

via a buffer (

BSD7

) on the falling edges of clock pulses on the SCL line.

When the CPU writes to

S1DAT

,

BSD7

is loaded with the content of

S1DAT.7

, which is the first bit to be

transmitted to the SDA line (see [Figure 20]). After nine serial clock pulses, the eight bits in

S1DAT

will have been transmitted to the SDA line, and the acknowledge bit will be present in

ACK

. Note that the eight transmitted bits are shifted back into

S1DAT

.

The Control Register, S1CON

The CPU can read from and write to this 8-bit, directly addressable SFR. Two bits are affected by the

SIO1 hardware: the

SI

bit is set when a serial interrupt is requested, and the

STO

bit is cleared when a

STOP condition is present on the I2C bus. The

STO

bit is also cleared when

ENS1

= “0”.

7 6 5 4 3 2 1 0

S1CON (D8H)

CR2 ENS1 STA STO SI AA CR1 CR0

ENS1, the SIO1 Enable Bit:

ENS1

= “0”: When is “0”, the SDA and SCL outputs are in a high impedance state. SDA and

SCL input signals are ignored, SIO1 is in the “not addressed” slave state, and the

STO

bit in

S1CON

is forced to “0”. No other bits are affected.

ENS1

= “1”: When is “1”, SIO1 is enabled.

ENS1

should not be used to temporarily release SIO1 from the I2C bus since, when

ENS1

is reset, the

I2C bus status is lost. The

AA

flag should be used instead (see description of the

AA

flag in the following text).

SDA

BSD7

INTERNAL BUS

8

S1DAT ACK

SCL

Page 54 of 132

SHIFT PULSES

[Figure 19] Serial Input/Output Configuration

© Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

SDA D7 D6 D5 D4

SCL

SHIFT ACK &

S1DAT

ACK

D3 D2 D1 D0 A

(2) (2) (2) (2) (2) (2) (2) (2) A

Handshake Solutions

SHIFT IN

S1DAT (1) (2) (2) (2) (2) (2) (2) (2) (2) (1)

SHIFT OUT

SHIFT BSD7

BSD7 D7 D6 D5 D4 D3 D2 D1 D0 (3)

LOADED BY THE CPU

(1) Valid data in S1DAT

(2) Shifting data in S1DAT and ACK

(3) High level on SDA

[Figure 20] Shift-in and Shift-out Timing

In the following text, it is assumed that

ENS1

= “1”.

The “START” Flag, STA

STA STA

bit is set to enter a Master mode, the SIO1 hardware checks the status of the I2C bus and generates a START condition if the bus is free. If the bus is not free, then SIO1 waits for a STOP condition (which will free the bus) and generates a

START condition after a delay of half a clock period of the internal serial clock generator.

If

STA

is set while SIO1 is already in a Master mode and one or more bytes are transmitted or received, SIO1 transmits a repeated START condition.

STA

may be set at any time.

STA

may also be set when SIO1 is an addressed slave.

STA STA

bit is reset, no START condition or repeated START condition will be generated.

The STOP Flag, STO

STO STO

bit is set while SIO1 is in a Master mode, a STOP condition is transmitted to the I2C bus. When the STOP condition is detected on the bus, the SIO1 hardware clears the

STO

flag. In a Slave mode, the

STO

flag may be set to recover from an error condition. In this case, no STOP condition is transmitted to the I2C bus. However, the SIO1 hardware behaves as if a STOP condition has been received and

© Philips Electronics N.V. 2005 Page 55 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) switches to the defined “not addressed” Slave Receiver mode. The

STO

flag is automatically cleared by hardware.

If the

STA

and

STO

bits are both set, the a STOP condition is transmitted to the I2C bus if SIO1 is in a Master mode (in a Slave mode, SIO1 generates an internal STOP condition which is not transmitted). SIO1 then transmits a START condition.

STO STO

bit is reset, no STOP condition will be generated.

The Serial Interrupt Flag, SI

SI SI

flag is set, then, if the

EA

and

ES1

(interrupt enable register) bits are also set, a serial interrupt is requested.

SI

is set by hardware when one of 25 of the 26 possible SIO1 states is entered. The only state that does not cause

SI

to be set is state F8H, which indicates that no relevant state information is available.

While

SI

is set, the low period of the serial clock on the SCL line is stretched, and the serial transfer is suspended. A high level on the SCL line is unaffected by the serial interrupt flag.

SI

must be reset by software.

SI SI

flag is reset, no serial interrupt is requested, and there is no stretching of the serial clock on the SCL line.

The Assert Acknowledge Flag, AA

AA AA

flag is set, an acknowledge (low level to SDA) will be returned during the acknowledge clock pulse on the SCL line when:

AA

= “0”:

-

-

-

-

The “own slave address” has been received

The general call address has been received while the general call bit (

GC

) in

S1ADR

is set

A data byte has been received while SIO1 is in the Master Receiver mode

-

-

A data byte has been received while SIO1 is in the addressed Slave Receiver mode if the AA flag is reset, a not acknowledge (high level to SDA) will be returned during the acknowledge clock pulse on SCL when:

A data has been received while SIO1 is in the Master Receiver mode

A data byte has been received while SIO1 is in the addressed Slave Receiver mode

When SIO1 is in the addressed Slave Transmitter mode, state C8H will be entered after the last serial

is transmitted (see [Figure 11]).

When

SI

is cleared, SIO1 leaves state C8H, enters the not addressed Slave Receiver mode, and the

SDA line remains at a high level. In state C8H, the

AA

flag can be set again for future address recognition.

When SIO1 is in the not addressed Slave mode, its own slave address and the general call address are ignored. Consequently, no acknowledge is returned, and a serial interrupt is not requested. Thus,

SIO1 can be temporarily released from the I2C bus while the bus status is monitored. While SIO1 is released from the bus, START and STOP conditions are detected, and serial data is shifted in. Address recognition can be resumed at any time by setting the

AA

flag. If the

AA

flag is set when the part’s own Slave address or the general call address has been partly received, the address will be recognized at the end of the byte transmission.

Page 56 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

The Clock Rate Bits CR0, CR1, and CR2

These three bits determine the serial clock frequency when SIO1 is in a Master mode. The various

serial rates are shown in [Table 9].

A 12.5 kHz bit rate may be used by devices that interface to the I2C bus via standard I/O port lines which are software driven and slow. 100 kHz is usually the maximum bit rate and can be derived from a 16 MHz, 12 MHz, or a 6 MHz oscillator. A variable bit rate (0.5 kHz to 62.5 kHz) may also be used if

Timer 1 is not required for any other purpose while SIO1 is in a Master mode.

The frequencies shown in [Table 9] are unimportant when SIO1 is in a Slave mode. In the Slave

modes, SIO1 will automatically synchronize with any clock frequency up to 100 kHz.

The Status Register, S1STA

S1STA

is an 8-bit read-only special function register. The three least significant bits are always zero.

The five most significant bits contain the status code. There are 26 possible status codes. When

S1STA

contains F8H, no relevant state information is available and no serial interrupt is requested. All other

S1STA

values correspond to defined SIO1 states. When each of these states is entered, a serial interrupt is requested (

SI

= “1”). A valid status code is present in

S1STA

one machine cycle after

SI

is set by hardware and is still present one machine cycle after

SI

has been reset by software.

CR2 CR1 CR0

6 MHz bit rate (kbit/s) at f iClk

12 MHz 16 MHz 24 MHz f iClk

divided by

30 MHz

1

1

1

1

0

0

0

0

0

0

1

1

0

0

1

1

0

1

0

1

0

1

0

1

23

27

31

37

6.25

50

100

0.24..62.5

0..255

47

54

63

75

12.5

100

200

0.49..62.5

0..254

62.5

71

83.3

100

17

133

267

0.65..55.6

0..253

94

107

125

150

25

200

400

0.98..50.0

0..251

117

134

155

188

31

250

500

1.22..52.1

0..250

256

224

192

160

960

120

60

256-(reload value timer 1) reload value timer 1, mode 2

[Table 9] Serial Clock Rates

(needs update)

NOTES:

1. These frequencies exceed the upper limit of 100 kHz of the I2C-bus specification and cannot be used in an I2C-bus application.

2. At fOSC = 24 MHz/30 MHz the maximum I2C bus rate of 100 kHz cannot be realized due to the fixed divider rates.

5.5.4.4. More Information on SIO1 Operating Modes

The four operating modes are:

Master Transmitter

Master Receiver

Slave Receiver

Slave Transmitter

Data transfers in each mode of operation are shown in [Figure 21] to [Figure 24].

© Philips Electronics N.V. 2005 Page 57 of 132

Handshake Solutions

These figures contain the following abbreviations:

Abbreviation Explanation

S Start condition

SLA

R

W

A

7-bit slave address

Read bit (high level at SDA)

Write bit (low level at SDA)

Acknowledge bit (low level at SDA)

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

A

Data

P

Not acknowledge bit (high level at SDA)

8-bit data byte

Stop condition

In [Figure 21] to [Figure 24], circles are used to indicate when the serial interrupt flag is set. The num-

bers in the circles show the status code held in the

S1STA

register. At these points, a service routine must be executed to continue or complete the serial transfer. These service routines are not critical since the serial transfer is suspended until the serial interrupt flag is cleared by software.

When a serial interrupt routine is entered, the status code in

S1STA

is used to branch to the appropriate service routine. For each status code, the required software action and details of the following

serial transfer are given in [Table 10] to [Table 14].

Master Transmitter mode (not available for slave-only version)

In the Master Transmitter mode, a number of data bytes are transmitted to a slave receiver (see

[Figure 21]). Before the Master Transmitter mode can be entered,

S1CON

must be initialized as follows:

S1CON (D8H)

7 6 5 4 3 2 1 0

CR2 ENS1 STA STO SI AA CR1 CR0 rate rate

CR0

,

CR1

, and

CR2

define the serial bit rate.

ENS1

must be set to logic 1 to enable SIO1. If the

AA

bit is reset, SIO1 will not acknowledge its own slave address or the general call address in the event of another device becoming master of the bus. In other words, if

AA

is reset, SIO0 cannot enter a Slave mode.

STA

,

STO

, and

SI

must be reset.

The Master Transmitter mode may now be entered by setting the

STA

bit using the SETB instruction.

The SIO1 logic will now test the I2C bus and generate a start condition as soon as the bus becomes free. When a START condition is transmitted, the serial interrupt flag (

SI

) is set, and the status code in the status register (

S1STA

) will be 08H. This status code must be used to vector to an interrupt service routine that loads

S1DAT

with the slave address and the data direction bit (

SLA+W

). The

SI

bit in

S1CON

must then be reset before the serial transfer can continue.

When the slave address and the direction bit have been transmitted and an acknowledgment bit has been received, the serial interrupt flag (

SI

) is set again, and a number of status codes in

S1STA

are possible. There are 18H, 20H, or 38H for the Master mode and also 68H, 78H, or B0H if the Slave mode was enabled (

AA

= logic 1). The appropriate action to be taken for each of these status codes is

detailed in [Table 10]. After a repeated start condition (state 10H). SIO1 may switch to the Master Re-

ceiver mode by loading

S1DAT

with

SLA+R

).

Page 58 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

Master Receiver mode (not available for slave-only version)

In the Master Receiver mode, a number of data bytes are received from a slave transmitter (see

[Figure 22]). The transfer is initialized as in the Master Transmitter mode. When the start condition has

been transmitted, the interrupt service routine must load

S1DAT

with the 7-bit slave address and the data direction bit (

SLA+R

). The

SI

bit in

S1CON

must then be cleared before the serial transfer can continue.

When the slave address and the data direction bit have been transmitted and an acknowledgment bit has been received, the serial interrupt flag (

SI

) is set again, and a number of status codes in

S1STA

are possible. These are 40H, 48H, or 38H for the Master mode and also 68H, 78H, or B0H if the Slave mode was enabled (

AA

= logic 1). The appropriate action to be taken for each of these status codes is

detailed in [Table 11].

ENS1

,

CR1

, and

CR0

are not affected by the serial transfer and are not referred to in Table 5. After a repeated start condition (state 10H), SIO1 may switch to the Master Transmitter mode by loading

S1DAT

with

SLA+W

.

Slave Receiver mode

In the Slave Receiver mode, a number of data bytes are received from a master transmitter (see

[Figure 23]). To initiate the Slave Receiver mode,

S1ADR

and

S1CON

must be loaded as follows:

7 6 5 4 3 2 1 0

S1ADR (DBH)

own slave address GC

The upper 7 bits are the address to which SIO1 will respond when addressed by a master. If the

LSB

(

GC

) is set, SIO1 will respond to the general call address (00H); otherwise it ignores the general call address.

7 6 5 4 3 2 1 0

S1CON (D8H)

CR2 ENS1 STA STO SI AA CR1 CR0

X 1 0 0 0 1 X X

CR0

,

CR1

, and

CR2

do not affect SIO1 in the Slave mode.

ENS1

must be set to logic 1 to enable SIO1.

The

AA

bit must be set to enable SIO1 to acknowledge its own slave address or the general call address.

STA

,

STO

, and

SI

must be reset.

When

S1ADR

and

S1CON

have been initialized, SIO1 waits until it is addressed by its own slave address followed by the data direction bit which must be “0” (

W

) for SIO1 to operate in the Slave Receiver mode. After its own slave address and the

W

bit have been received, the serial interrupt flag (I) is set and a valid status code can be read from

S1STA

. This status code is used to vector to an interrupt service routine, and the appropriate action to be taken for each of these status codes is detailed

in [Table 12]. The Slave Receiver mode may also be entered if arbitration is lost while SIO1 is in the

Master mode (see status 68H and 78H).

If the

AA

bit is reset during a transfer, SIO1 will return a not acknowledge (logic 1) to SDA after the next received data byte. While

AA

is reset, SIO1 does not respond to its own slave address or a general call address. However, the I2C bus is still monitored and address recognition may be resumed at any time by setting

AA

. This means that the

AA

bit may be used to temporarily isolate SIO1 from the

I2C bus.

© Philips Electronics N.V. 2005 Page 59 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

Slave Transmitter mode

In the Slave Transmitter mode, a number of data bytes are transmitted to a master receiver (see

[Figure 24]). Data transfer is initialized as in the Slave Receiver mode. When

S1ADR

and

S1CON

have been initialized, SIO1 waits until it is addressed by its own slave address followed by the data direction bit which must be “1” (

R

) for SIO1 to operate in the Slave Transmitter mode. After its own slave address and the

R

bit have been received, the serial interrupt flag (

SI

) is set and a valid status code can be read from

S1STA

. This status code is used to vector to an interrupt service routine, and the appro-

priate action to be taken for each of these status codes is detailed in [Table 12]. The Slave Transmitter

mode may also be entered if arbitration is lost while SIO1 is in the Master mode (see state B0H).

If the

AA

bit is reset during a transfer, SIO1 will transmit the last byte of the transfer and enter state

C0H

or

C8H

. SIO1 is switched to the “not addressed” Slave mode and will ignore the master receiver if it continues the transfer. Thus the master receiver receives all 1s as serial data. While

AA

is reset,

SIO1 does not respond to its own slave address or a general call address. However, the I2C bus is still monitored, and address recognition may be resumed at any time by setting

AA

. This means that the

AA

bit may be used to temporarily isolate SIO1 from the I2C bus.

Page 60 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

MT

SUCCESSFUL TRANSMISSION

TO A SLAVE RECEIVER

S

08H

SLA

NEXT TRANSFER STARTED WITH

A REPEATED START CONDITION

W A

18H

DATA

NOT ACKNOWLEDGE RECEIVED

AFTER THE SLAVE ADDRESS

NOT ACKNOWLEDGE RECEIVED

AFTER A DATA BYTE

ARBITRATION LOST IN SLAVE

ADDRESS OR DATA BYTE

ARBITRATION LOST AND

ADDRESSED AS SLAVE

A

28H

P

S SLA W

10H

A P

20H

R

TO MST/REC MODE

ENTRY=MR

A P

30H

A or A

OTHER MST

CONTINUES

A or A

OTHER MST

CONTINUES

38H 38H

A

OTHER MST

CONTINUES

68H 78H 80H

TO CORRESPONDING STATES

IN SLAVE MODE

FROM MASTER TO SLAVE

FROM SLAVE TO MASTER

DATA A ANY NUMBER OF DATA BYTES AND THEIR ASSOCIATED ACKNOWLEDGE BITS n

THIS NUMBER (CONTAINED IN S1STA) CORRESPONDS TO A DEFINED STATE OF THE I C BUS: SEE TABLE 4

[Figure 21] Format and States in the Master Transmitter mode

© Philips Electronics N.V. 2005 Page 61 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

MR

SUCCESSFUL RECEPTION

FROM A SLAVE TRANSMITTER

S

08H

SLA

NEXT TRANSFER STARTED WITH

A REPEATED START CONDITION

R A

40H

DATA A DATA A

50H 58H

P

NOT ACKNOWLEDGE RECEIVED

AFTER THE SLAVE ADDRESS

A

48H

P

S

10H

SLA R

W

ARBITRATION LOST IN SLAVE

ADDRESS OR ACKNOWLEDGE BIT

ARBITRATION LOST AND

ADDRESSED AS SLAVE

A or A

38H

OTHER MST

CONTINUES

A

OTHER MST

CONTINUES

68H 78H 80H

TO CORRESPONDING STATES IN

SLAVE MODE

TO MST/TRX MODE

ENTRY=MT

A

OTHER MST

CONTINUES

38H

FROM MASTER TO SLAVE

FROM SLAVE TO MASTER

DATA A ANY NUMBER OF DATA BYTES AND THEIR ASSOCIATED ACKNOWLEDGE BITS n

THIS NUMBER (CONTAINED IN S1STA) CORRESPONDS TO A DEFINED STATE OF THE I

2

C BUS: SEE TABLE 5

[Figure 22] Format and States in the Master Receiver Mode

Page 62 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

RECEPTION OF THE OWN SLAVE

ADDRESS AND ONE OR MORE DATA

BYTES ALL ARE ACKNOWLEDGED

S SLA W A

60H

LAST DATA BYTE RECEIVED IS NOT

ACKNOWLEDGED

Handshake Solutions

DATA A

80H

DATA A P or S

80H

A0H

A P or S

88H

ARBITRATION LOST AS MST AND ADDRESSED AS

SLAVE

RECEPTION OF THE GENERAL CALL ADDRESS

AND ONE OR MORE DATA BYTES

A

68H

GENERAL

CALL

A

70H

LAST DATA BYTE IS NOT ACKNOWLEDGED

DATA A

90H

DATA A P or S

90H

A0H

A

P or S

98H

ARBITRATION LOST AS MST AND ADDRESSED AS

SLAVE BY GENERAL CALL

A

78H

FROM MASTER TO SLAVE

FROM SLAVE TO MASTER

DATA A ANY NUMBER OF DATA BYTES AND THEIR ASSOCIATED ACKNOWLEDGE BITS n

THIS NUMBER (CONTAINED IN S1STA) CORRESPONDS TO A DEFINED STATE OF THE I

2

C BUS: SEE TABLE 6

[Figure 23] Format and States in the Slave Receiver mode

© Philips Electronics N.V. 2005 Page 63 of 132

Handshake Solutions

RECEPTION OF THE OWN SLAVE

ADDRESS AND ONE OR MORE

DATA BYTES ALL ARE

ACKNOWLEDGED

S SLA R A

FROM MASTER TO SLAVE

FROM SLAVE TO MASTER

DATA

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

A DATA A P or S

A8H

A

B8H

ARBITRATION LOST AS MST

AND ADDRESSED AS SLAVE

C0H

B0H

LAST DATA BYTE TRANSMITTED.

SWITCHED TO NOT ADDRESSED

SLAVE (AA BIT IN S1CON= "0")

A

C8H

All "1"s

P or S

DATA A ANY NUMBER OF DATA BYTES AND THEIR ASSOCIATED ACKNOWLEDGE BITS n

C BUS: SEE TABLE 7

[Figure 24] Format and States of the Slave Transmitter mode

Page 64 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

status code

S1STA status of the I2C bus and SIO1 hardware application software response to/from S1DAT to S1CON

STA STO SI AA next action taken by SIO1 hardware

X 0 0 08H A START condition has been Load SLA+W transmitted

10H A repeated START condition Load SLA+W or has been transmitted Load SLA+R

X

X

0

0

0

0

X SLA+W will be transmitted;

ACK bit will be received

X

X

As above

SLA+W will be transmitted;

SIO1 will be switched to MST/REC mode

18H SLA+W has been transmitted; ACK has been received

Load data byte or no S1DAT action or no S1DAT action or no S1DAT action

1

0

0

1

0

1

0

1

0

0

0

0

X

X

X

X

Data byte will be transmitted;

ACK bit will be received

Repeated START will be transmitted;

STOP condition will be transmitted;

STO flag will be reset

STOP condition followed by a

START condition will be transmitted;

STO flag will be reset

20H SLA+W has been transmitted; NOT ACK has been received

Load data byte or no S1DAT action or no S1DAT action or no S1DAT action

1

0

0

1

0

1

0

1

0

0

0

0

X

X

X

X

Data byte will be transmitted;

ACK bit will be received

Repeated START will be transmitted;

STOP condition will be transmitted;

STO flag will be reset

STOP condition followed by a

START condition will be transmitted;

STO flag will be reset

28H

Data byte in S1DAT has been transmitted; ACK has been received

Load data byte or no S1DAT action or no S1DAT action or no S1DAT action

1

0

0

1

0

1

0

1

0

0

0

0

X

X

X

X

Data byte will be transmitted;

ACK bit will be received

Repeated START will be transmitted;

STOP condition will be transmitted;

STO flag will be reset

STOP condition followed by a

START condition will be transmitted;

STO flag will be reset

30H

Data byte in S1DAT has been transmitted; NOT ACK has been received

Load data byte or no S1DAT action or no S1DAT action or no S1DAT action

1

0

0

1

0

1

0

1

0

0

0

0

X

X

X

X

Data byte will be transmitted;

ACK bit will be received

Repeated START will be transmitted;

STOP condition will be transmitted;

STO flag will be reset

STOP condition followed by a

START condition will be transmitted;

STO flag will be reset

38H

Arbitration lost in

SLA+R/W or

Data bytes

No S1DAT action or no S1DAT action

0

1

0

0

0

0

X

X

I2C bus will be released; not addressed slave will be entered

A START condition will be transmitted when the bus becomes free

[Table 10] Master Transmitter mode (not available for slave-only version)

© Philips Electronics N.V. 2005 Page 65 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

status code

S1STA status of the I2C bus and SIO1 hardware application software response to/from S1DAT to S1CON

STA STO SI AA next action taken by SIO1 hardware

08H A START condition has been Load SLA+R transmitted

10H A repeated START condition Load SLA+R or has been transmitted Load SLA+W

38H

Arbitration lost in

NOT ACK bit no S1DAT action

40H SLA+R has been transmitted; No S1DAT action or

ACK has been received no S1DAT action

X

X

X

0

1

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

X SLA+W will be transmitted;

ACK bit will be received

X

X

As above

SLA+W will be transmitted;

SIO1 will be switched to MST/TRX mode

X

X

I2C bus will be released;

SIO1 will enter slave mode

A START condition will be transmitted when the bus becomes free

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

48H SLA+R has been transmitted; No S1DAT action or

NOT ACK has been received no S1DAT action or no S1DAT action 1

1

0

1

0

1

0

0

0

X

X

X

Repeated START will be transmitted

STOP condition will be transmitted;

STO flag will be reset

STOP condition followed by a

START condition will be transmitted;

STO flag will be reset

50H

Data byte has been received; Read data byte or

ACK has been returned read data byte

0

0

0

0

0

0

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

58H

Data byte has been received; Read data byte or

NOT ACK has been returned read data byte or read data byte 1

1

0

1

0

1

0

0

0

X

X

X

Repeated START will be transmitted

STOP condition will be transmitted;

STO flag will be reset

STOP condition followed by a

START condition will be transmitted;

STO flag will be reset

[Table 11] Master Receiver Mode (not available for slave-only version)

Page 66 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

status code

S1STA status of the I2C bus and SIO1 hardware application software response to/from S1DAT to S1CON

STA STO SI AA

Next action taken by SIO1 hardware

60H Own SLA+W has been received; ACK has been returned

No S1DAT action or no S1DAT action

68H Arbitration lost in SLA+R/W No S1DAT action or as master; Own SLA+W has has been received;

ACK has been returned no S1DAT action

70H

General call address (00H) No S1DAT action or has been received; ACK has been returned no S1DAT action

X

X

X

X

X

X

X

X

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

78H Arbitration lost in SLA+R/W No S1DAT action or as master; General call address (00H) has been no S1DAT action received; ACK has been returned

80H

Previously addressed with own SLV address; DATA has been received; ACK has been returned

Read data byte or read data byte

88H

Previously addressed with own SLA; DATA has been received; NOT ACK has been returned

Read data byte or read data byte or read data byte or read data byte

90H

Previously addressed with

General Call; DATA has been received; ACK has been returned

98H

Previously addressed with

General Call; DATA has been received; NOT ACK has been returned

Read data byte or read data byte

Read data byte or read data byte or 0

0

X

X

1

1

0

0

X

X

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

0

1

1

0 Switched to not addressed SLV mode; no recognition of own SLA or General call address

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1

Switched to not addressed SLV mode; no recognition of own SLA or General call address. A

START condition will be transmitted when the bus becomes free

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1. A START condition will be transmitted when the bus becomes free.

0

1

Data byte will be received;

NOT ACK bit will be returned

Data byte will be received;

ACK bit will be returned

1

0 Switched to not addressed SLV mode; no recognition of own SLA or General call address

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1

© Philips Electronics N.V. 2005 Page 67 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) read data byte or read data byte

1

1

0

0

0

0

0

1

Switched to not addressed SLV mode; no recognition of own SLA or General call address. A

START condition will be transmitted when the bus becomes free

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1. A START condition will be transmitted when the bus becomes free.

A0H

A STOP condition or No S1DAT action or repeated START condition has been received while still addressed as

SLV/REC or SLV/TRX no S1DAT action or no S1DAT action or no S1DAT action

0

0

1

1

0

0

0

0

0

0

0

0

0

1

1

0

Switched to not addressed SLV mode; no recognition of own SLA or General call address

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1

Switched to not addressed SLV mode; no recognition of own SLA or General call address. A

START condition will be transmitted when the bus becomes free

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1. A START condition will be transmitted when the bus becomes free.

[Table 12] Slave Receiver mode

Page 68 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1) Handshake Solutions

status code

S1STA status of the I2C bus and SIO1 hardware application software response to/from S1DAT to S1CON

STA STO SI AA next action taken by SIO1 hardware

A8H Own SLA+R has been received; ACK has been returned

Load data byte or load data byte

B0H Arbitration lost in SLA+R/W Load data byte or as master; Own SLA+R has has been received;

ACK has been returned load data byte

X

X

X

X

0

0

0

0

0

0

0

0

0

1

Last data byte will be transmitted;

ACK bit will be received

Data byte will transmitted;

ACK bit will be received

0

1

Last data byte will be transmitted;

ACK bit will be received

Data byte will transmitted;

ACK bit will be received

B8H Data byte in S1DAT has been transmitted; ACK has been returned

Load data byte or load data byte

C0H

Data byte in S1DAT has been transmitted; NOT

ACK has been returned

C8H

Last data byte in S1DAT has been transmitted

(AA = 0); ACK has been returned

No S1DAT action or no S1DAT action or no S1DAT action or no S1DAT action

0

0

0

0

0

0

0

0

1

1

0

0

X

X

0

0

0

0

0

1

Last data byte will be transmitted;

ACK bit will be received

Data byte will transmitted;

ACK bit will be received

0

1

1

0 Switched to not addressed SLV mode; no recognition of own SLA or General call address

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1

Switched to not addressed SLV mode; no recognition of own SLA or General call address. A

START condition will be transmitted when the bus becomes free

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1. A START condition will be transmitted when the bus becomes free.

No S1DAT action or no S1DAT action or no S1DAT action or no S1DAT action

0

1

1

0

0

0

0

0

0

0

0

0

1

1

0

0 Switched to not addressed SLV mode; no recognition of own SLA or General call address

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1

Switched to not addressed SLV mode; no recognition of own SLA or General call address. A

START condition will be transmitted when the bus becomes free

Switched to not addressed SLV mode; Own SLA will be recognized; General call address will be recognized if S1ADR.0 = logic 1. A START condition will be transmitted when the bus becomes free.

[Table 13] Slave Transmitter mode

© Philips Electronics N.V. 2005 Page 69 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

status code

S1STA status of the I2C bus and SIO1 hardware application software response to/from S1DAT to S1CON

STA STO SI AA next action taken by SIO1 hardware

F8H No relevant state information available; SI = 0

No S1DAT action No S1CON action Wait or proceed current transfer

00H Bus error during MST or selected Slave modes, due

No S1DAT action to an illegal START or

STOP condition. State 00H can also occur when interference causes SIO1 to enter an undefined state.

0 1 0 X Only the internal hardware is affected in the MST or addressed SLV modes. In all cases, the bus is released and SIO1 is switched to the not addressed SLV mode. STO is reset.

[Table 14] Miscellaneous States

There are two

S1STA

codes that do not correspond to a defined SIO1 hardware state (see [Table 14]).

These are discussed below.

S1STA = F8H

This status code indicates that no relevant information is available because the serial interrupt flag,

SI

, is not yet set. This occurs between other states and when SIO1 is not involved in a serial transfer.

S1STA = 00H

This status code indicates that a bus error has occurred during an SIO1 serial transfer. A bus error is caused when a START or STOP condition occurs at an illegal position in the format frame. Examples of such illegal positions are during the serial transfer of an address byte, a data byte, or an acknowledge bit. A bus error may also be caused when external interference disturbs the internal SIO1 signals. When a bus error occurs,

SI

is set. To recover from a bus error, the

STO

flag must be set and

SI

must be cleared. This causes SIO1 to enter the “not addressed” Slave mode (a defined state) and to clear the

STO

flag (no other bits in

S1CON

are affected). The SDA and SCL lines are released (a STOP condition is nottransmitted).

5.5.4.6. Some Special Cases

The SIO1 hardware has facilities to handle the following special cases that may occur during a serial transfer.

Simultaneous Repeated START Conditions from Two Masters

A repeated START condition may be generated in the Master Transmitter or Master Receiver modes.

A special case occurs if another master simultaneously generates a repeated START condition (see

[Figure 25]). Until this occurs, arbitration is not lost by either master since they were both transmitting

the same data.

If the SIO1 hardware detects a repeated START condition on the I2C bus before generating a repeated START condition itself, it will release the bus, and no interrupt request is generated. If another master frees the bus by generating a STOP condition, SIO1 will transmit a normal START condition

(state 08H), and a retry of the total serial data transfer can commence.

Page 70 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

Data Transfer After Loss of Arbitration

Handshake Solutions

Arbitration may be lost in the Master Transmitter and Master Receiver modes (see [Figure 17]). Loss

of arbitration is indicated by the following states in

S1STA

: 38H, 68H, 78H, and B0H (see [Figure 21]

and [Figure 22]).

If the

STA

flag in

S1CON

is set by the routines which service these states, then, if the bus is free again, a START condition (state 08H) is transmitted without intervention by the CPU, and a retry of the total serial transfer can commence.

Forced Access to the I2C Bus

In some applications, it may be possible for an uncontrolled source to cause a bus hang-up. In such situations, the problem may be caused by interference, temporary interruption of the bus or a temporary short-circuit between SDA and SCL.

If an uncontrolled source generates a superfluous START or masks a STOP condition, then the I2C bus stays busy indefinitely. If the

STA

flag is set and bus access is not obtained within a reasonable amount of time, then a forced access to the I2C bus is possible. This is achieved by setting the STO flag while the

STA

flag is still set. No STOP condition is transmitted. The SIO1 hardware behaves as if a STOP condition was received and is able to transmit a START condition. The

ST0

flag is cleared by

hardware (see [Figure 26]).

RECEPTION OF THE OWN SLAVE

ADDRESS AND ONE OR MORE

DATA BYTES ALL ARE

ACKNOWLEDGED

S

08H

SLA W A

18H

DATA A S

28 H

BOTH MASTERS CONTINUE

WITH SLA TRANSMISSION

OTHER MASTER SENDS REPEATED

START CONDITION EARLIER

[Figure 25] Simultaneous Repeated START Conditions from 2 Masters

© Philips Electronics N.V. 2005 Page 71 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

TIME OUT

STA FLAG

SDA LINE

SCL LINE

START CONDITION

[Figure 26] Forced Access to a Busy I2C Bus

I2C Bus Obstructed by a Low Level on SCL or SDA

An I2C bus hang-up occurs if SDA or SCL is pulled LOW by an uncontrolled source. If the SCL line is obstructed (pulled LOW) by a device on the bus, no further serial transfer is possible, and the SIO1 hardware cannot resolve this type of problem. When this occurs, the problem must be resolved by the device that is pulling the SCL bus line LOW.

If the SDA line is obstructed by another device on the bus (e.g., a slave device out of bit synchroniza-

tion), the problem can be solved by transmitting additional clock pulses on the SCL line (see [Figure

27]). The SIO1 hardware transmits additional clock pulses when the

STA

flag is set, but no START condition can be generated because the SDA line is pulled LOW while the I2C bus is considered free.

The SIO1 hardware attempts to generate a START condition after every two additional clock pulses on the SCL line. When the SDA line is eventually released, a normal START condition is transmitted, state 08H is entered, and the serial transfer continues.

If a forced bus access occurs or a repeated START condition is transmitted while SDA is obstructed

(pulled LOW), the SIO1 hardware performs the same action as described above. In each case, state

08H is entered after a successful START condition is transmitted and normal serial transfer continues.

Note that the CPU is not involved in solving these bus hang-up problems.

Bus Error

A bus error occurs when a START or STOP condition is present at an illegal position in the format frame. Examples of illegal positions are during the serial transfer of an address byte, a data, or an acknowledge bit.

The SIO1 hardware only reacts to a bus error when it is involved in a serial transfer either as a master or an addressed slave. When a bus error is detected, SIO1 immediately switches to the “not addressed” Slave mode, releases the SDA and SCL lines, sets the interrupt flag, and loads the status register with 00H. This status code may be used to vector to a service routine which either attempts

the aborted serial transfer again or simply recovers from the error condition as shown in [Table 14].

Page 72 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – I2C Interface (SIO1)

STA FLAG

SDA LINE

(1) (1)

Handshake Solutions

(2) (3)

SCL LINE

START CONDITION

(1) Unsuccessful attempt to send a Start condition

(2) SDA line released

(3) Successful attempt to send a Start condition; state 08H is entered.

[Figure 27] Recovering from a Bus Obstruction Caused by a Low Level on SDA

The description above covers the full featured version of the HT-I2C module with master and slave modes. The slave-only version of the HT-I2C implements a subset of these features.

This means, the slave-only version covers the behaviour and features as described for the complete version, but some features and pins are not implemented. It comprises

• no master transmit mode

• no master receiver mode

• no baud rate generator

• bits

CR1

,

CR2

,

CR3

and

STA

in the SFR

S1CON

are reserved (0)

• no clock input pin

i2c_clk_i

An I2C byte-oriented system driver is described in application note AN435. Please visit http://www.semiconductors.philips.com/products/all_appnotes.html

© Philips Electronics N.V. 2005 Page 73 of 132

Handshake Solutions

5.6. Serial Peripheral Interface (SPI)

HT80C51 User Manual

Peripheral Modules – Serial Peripheral Interface (SPI)

This serial peripheral interface is a full-duplex, high-speed, synchronous communication bus with two operation modes: Master mode and Slave mode. The main features are:

Full Duplex, Three-Wire Synchronous Transfers

Master or Slave Operation

Four Programmable Master Bit Rates

Programmable Clock Polarity and Phase

End-of-Transmission Interrupt Flag

Write Collision Flag Protection

5.6.1. Options

The SPI interface can be selected (ordered) by using option

HT80C51_SPI

.

5.6.2. Special function registers (SPCR SPSR SPDR)

SPCR

SPI control register

addr = F5H reset value = 0000

0100 bits 7 6 5 4 3 2 1 0

SPIE SPE DWOM MSTR CPOL CPHA SPR1 SPR0

bit Symbol Function

SPCR.7 SPIE SPI interrupt enable

SPCR.6 SPE

1:

0:

SPI interrupt enabled: SFR bit

SPIF

causes an SPI interrupt

(

int_req_i[6]

)

SPI interrupt disabled: no SPI interrupt generated

SPI interface enable

1:

0:

SPI interface enabled, output pin

spi_spe_o

is 1

SPI interface disabled, output pin

spi_spe_o

is 0

SPCR.5 DWOM

Port D Wire-OR Mode; connected to output pin

spi_dwom_o

.

The environment can use the signal of this output pin to select the output mode:

1:

0:

spi_dwom_o

= 1: use open drain outputs

spi_dwom_o

= 0: use standard CMOS outputs

DWOM is not used by the SPI interface internally.

Page 74 of 132

1:

0: master mode slave mode

SPCR.3 CPOL

spi_sck_o

in master mode,

spi_sck_i

in slave mode) (see [Figure 29])

1:

0: shift clock is active low shift clock is active high

SPCR.1

SPCR.0

SPR1

SPR0

1:

0:

As soon as input pin

spi_ss_n_i

goes low, the transaction begins and the first edge of

spi_sck_i

invokes the first data sample.

If input pin

spi_ss_n_i

is 0, the outputs are enabled.

Baudrate select bits.

In master mode these bits select the clock divisor for generating the clock output

spi_sck_o

(see table below).

In slave mode these bits have no effect.

© Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Serial Peripheral Interface (SPI) Handshake Solutions spi_clk_i

/ 1 spi_clk_i

/ 2 spi_clk_i

/ 8 spi_clk_i

/ 16

SPSR

SPI status register

addr = F6H reset value = 00H bits 7 6 5 4 3 2 1 0

bit Symbol Function

SPSR.7 SPIF SPI data complete flag

1:

SPIF is set upon completion of a data transfer. If

SPIF

=1 and SFR bit

SPIE

(

SPCR.7

) is set, an SPI interrupt is generated.

While

SPIF

is 1, any write attempts to

SPDR

are inhibitted until

SPDR

is read.

0:

SPIF

has to be cleared by software by reading

SPDR

afterwards.

SPSR

first and accessing

SPSR.5

SPSR.4

SPSR.3

SPSR.2

SPSR.1

SPSR.0

1:

0: set by hardware, when

SPDR

is written while a data transfer is in progress cleared by hardware, when first

SPSR

is read and then

SPDR

is accessed. bits write always 0, read 0

SPDR

SPI data register

addr = F7H reset value = 00H bits 7 6 5 4 3 2 1 0

SPDR

bit Symbol Function

SPDR.7

..

SPDR.0

Data to transmit or received by the SPI interface.

The data register

SPDR

is used to communicate transmit and receive data between the controller and the SPI. Transmit data is provided by writing to this register and receive data can be read from this register. Only a write to this register will initiate transmission/reception of another byte, and this will only occur in the master device. At the completion of transmitting a byte of data, the

SPIF

status bit is set in both the master and the slave devices.

When the controller reads

SPDR

, a buffer is actually read. The corresponding

SPIF

must be cleared by the time a second transfer of data from the shift register to the read buffer is initiated or an overrun condition will exist. In cases of overrun, the byte that causes the overrun is lost.

© Philips Electronics N.V. 2005 Page 75 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Serial Peripheral Interface (SPI)

A write to

SPDR

is not buffered; the data is directly stored into the shift register for transmission.

5.6.3. Interrupts

When a data transfer is completed, bit

SPIF

(

SPSR.7

) is set. If

SPIF

=1 and SFR bit

SPIE

(

SPCR.7

) is set, an SPI interrupt on interrupt line

int6

is generated.

SPIF

has to be cleared by software by reading

SPSR

first and accessing

SPDR

afterwards.

5.6.4. Operation

[Figure 28] shows a block diagram of the serial peripheral interface circuitry. When a master device

transmits data to a slave device via the MOSI line, the slave device responds by sending data to the master device via the master’s MISO line. This implies full duplex transmission with both data out and data in synchronized with the same clock signal. Thus, the byte transmitted is replaced by the byte received and eliminates the need for separate transmit-empty and receiver-full status bits. A single status bit (

SPIF

) is used to signify that the l/O operation has been completed.

The SPI is double buffered on read, but not on write. If a write is performed during data transfer, the transfer occurs uninterrupted, and the write will be unsuccessful. This condition will cause the write collision (

WCOL

) status bit in the

SPSR

to be set. After a data byte is shifted, the

SPIF

flag of the

SPSR

is set.

Page 76 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Serial Peripheral Interface (SPI) spi_clk_i

DIVIDER

BY 1, 2, 8, 16

SELECT

SPI CONTROL

SPI clock (master)

8-BIT SHIFT REGISTER

READ DATA BUFFER clock

CLOCK LOGIC

MSTR

SPE

Handshake Solutions spi_miso_o spi_miso_i

MISO spi_mosi_o

MOSI spi_mosi_i spi_sck_i spi_sck_o

SCK spi_ss_n_i SS spi_mstr_o spi_spe_o

SPI STATUS REGISTER SPI CONTROL REGISTER

SPI interrupt request internal data bus

[Figure 28] SPI block diagram

In the master mode, the SCK clock is driven to the output pin

spi_sck_o

. It idles high or low, depending on the

CPOL

bit in the

SPCR

, until data is written to the shift register, at which point eight clocks are generated to shift the eight bits of data and then SCK goes idle again. Data is shifted out thru output pin

spi_mosi_o

and shifted in from input pin

spi_miso_i

.

In a slave mode, the slave start logic receives a logic low at pin

spi_ss_n_i

and the clock at input pin

spi_sck_i

. Thus, the slave is synchronized with the master. Data from the master is received serially at the slave MOSI line (

spi_mosi_i

) and loads the 8-bit shift register. After the 8-bit shift register is loaded, its data is parallel transferred to the read buffer. During a write cycle, data is written into the shift register, then the slave waits for a clock train from the master to shift the data out on the slave’s MISO line (

spi_miso_o

).

Master In Slave Out (MISO)

The MISO line is configured as an input in a master device (

spi_miso_i

) and as an output in a slave device (

spi_miso_o

). It is used to transfer data from the slave to the master, with the most significant bit sent first. The MISO line of a slave device should be placed in the high-impedance state if the slave is not selected.

© Philips Electronics N.V. 2005 Page 77 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Serial Peripheral Interface (SPI)

Master Out Slave In (MOSI)

The MOSI line is configured as an output in a master device (

spi_mosi_o

) and as an input in a slave device (

spi_mosi_i

). It is used to transfer data from the master to a slave, with the most significant bit sent first.

Serial Clock (SCK)

The serial clock is used to synchronize data movement both in and out of the device through its MOSI and MISO lines. The master and slave devices are capable of exchanging a byte of information during a sequence of eight clock cycles. Since the master device generates SCK, this line becomes an input on a slave device (

spi_sck_i

) and an output at the master device (

spi_sck_o

).

As shown in [Figure 29], four possible timing relationships may be chosen by using control bits

CPOL

and

CPHA

in the serial peripheral control register (

SPCR

). Both master and slave devices must operate with the same timing. The master device always places data on the MOSI line a half-cycle before the clock edge (SCK), in order for the slave device to latch the data.

Two bits (

SPR0

and

SPR1

) in the

SPCR

of the master device select the clock rate. In a slave device,

SPR0

and

SPR1

have no effect on the operation of the SPI.

Slave Select (SS)

The slave select input line (

spi_ss_n_i

) is used to select a slave device. It has to be low prior to data transactions and must stay low for the duration of the transaction.

The

spi_ss_n_i

line on the master must be tied high.

SCK CYCLE #

(FOR REFERENCE)

SCK (CPOL = 0)

SCK (CPOL = 1)

1 2 3 4 5 6 7 8

SAMPLE INPUT

(CPHA = 0) DATA OUT

SAMPLE INPUT

(CPHA = 1) DATA OUT

MSB 6

MSB 6

5

5

4

4

3

3

2

2

1 LSB

1 LSB

SS (TO SLAVE)

[Figure 29] Data Clock Timing Diagram

When

CPHA

= 0, the shift clock is the OR of

spi_ss_n_i

with SCK. In this clock phase mode,

spi_ss_n_i

must go high between successive characters in an SPI message. When

CPHA

= 1,

spi_ss_n_i

may be left low for several SPI characters. In cases where there is only one SPI slave, its

spi_ss_n_i

line could be tied to 0 as long as

CPHA

= 1 clock modes are used.

Due to data direction register control of SPI outputs and the port D wire-OR mode (

DWOM

) option, the

SPI system can be configured in a variety of ways. Systems with a single bidirectional data path rather than separate MISO and MOSI paths can be accommodated.

Page 78 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Serial Peripheral Interface (SPI) Handshake Solutions

If the SPI slaves can selectively disable their MISO output, a broadcast message protocol is also possible.

Master Slave

8-BIT SHIFT

REGISTER

MISO

MOSI

MISO

MOSI

8-BIT SHIFT

REGISTER

SPI CLOCK

GENERATOR

SPICLK

PORT

SPICLK

SS

[Figure 30] SPI Single Master Single Slave Configuration

© Philips Electronics N.V. 2005 Page 79 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Watchdog Timer (under development)

5.7. Watchdog Timer (under development)

This module comprises an 8bit watchdog timer with prescaler.

5.7.1. Options

The watchdog timer can be selected (ordered) by using option t.b.d. .

5.7.2. Special function registers (T3)

T3

watchdog timer register

addr = reset value = bits 7 6 5 4 3 2 1 0

T3

bit Symbol Function

T3.7 ..

T3.0

Watchdog timer count register. Specifies the interval until the next timer overflow. Writeable, when input

wdt_ena_i

= 1.

5.7.3. Interrupts

No interrupts are generated.

If the watchdog timer expires, a pulse on the reset output

wdt_rst_o

is generated.

5.7.4. Operation

The Watchdog Timer consists of an 11-bit prescaler and an 8-bit timer.

It is controlled by the Watchdog Enable pin (

wdt_ena_i

). When

wdt_ena_i

= 1, the timer is enabled and the Power-down mode is disabled. When

wdt_ena_i

= 0, the timer is disabled and the Powerdown mode is enabled. In the Idle mode the Watchdog Timer and reset circuitry remain active.

The Watchdog Timer is shown in 0.

The timer interval is derived from the frequency of clock input

wdt_clk_i

using the following formula: watchdog time interval =

2048

f

×

wdt

(

256

_

clk

_

i

T

3

)

When a timer overflow occurs, a reset output pulse is generated at the pin

wdt_rst_o

for 3 clock cycles.

To prevent a system reset the timer must be reloaded in time by the application software. If the processor suffers a hardware/software malfunction, the software will fail to reload the timer. This failure will produce a reset upon overflow thus preventing the processor running out of control.

The Watchdog Timer can only be reloaded if the condition flag

WLE

(

PCON.4

) has been previously set by software. At the moment the counter is loaded the condition flag is automatically cleared.

The time interval between the timer reloading and the occurrence of a reset is dependent upon the reloaded value. For example, this time period may range from 2 ms to 500 ms when using a clock frequency f wdt_clk_i

= 1 MHz.

Page 80 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Watchdog Timer (under development) Handshake Solutions

[Figure 31] Functional Diagram of the T3 Watchdog Timer

© Philips Electronics N.V. 2005 Page 81 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Triple-DES Converter

DES stands for `Data Encryption Standard’ and is a widely used standard for enciphering and deciphering blocks of data. This coprocessor can autonomously do a complete single- or triple- DES encryption or decryption.

Features:

• two 56bit key registers

64bit text register for encryption and decryption

• single DES encryption

• single DES decryption

• triple DES encryption

• triple DES decryption

5.8.1. Options

The triple-DES converter can be selected (ordered) by using option

HT80C51_DES

.

5.8.2. Special function registers (DCON DKEY DTXT)

DCON

DES control register (write only)

addr = C0H reset value = XX bits 7 6 5 4 3 2 1 0

- - - - - DCMD

bit symbol Function

DCON.7

DCON.6

DCON.5

DCON.4

DCON.3

DCON.2

DCON.1

DCON.0 write always 0, read 0

Command for triple DES-converter. For a list of commands, see table below.

The

DCON

register is write-only. The value, which is written into

DCON

, determines the command for the triple-DES converter. This command is started immediately after

DCON

has been written.

0

1

2

3

Store key in KEY0

Store key in KEY1

Swap KEY0 and KEY1

Reverse the order of bytes in text register

Page 82 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Triple-DES Converter

DKEY

Handshake Solutions

DES key register (write only)

addr = C1H reset value = XX bits 7 6 5 4 3 2 1 0

DKEY

bit symbol Function

DKEY.7

DKEY.6

DKEY.5

DKEY.4

DKEY.3

DKEY.2

DKEY.1

DKEY.0

7bit slice of the key register. Used to shift in a 56bit key, which can be stored in either key register

KEY0

or

KEY1

.

Ignored

DTXT

DES data register

addr = C2H reset value = XX bits 7 6 5 4 3 2 1 0

DTXT

bit symbol Function

DTXT.7

..

DTXT.0

5.8.3. Interrupts

8bit slice of a complete 64bit data block for encryption or decryption. A write access shifts in 8bits, a read access shifts out 8bits.

No interrupts generated.

5.8.4. Operation

Write accesses to all three registers are supported. However only read accesses from

DTXT

are supported (read accesses from the other registers have no effect). Each supported access on the 8-bit slice of either the key or the text register is followed by a permutation of the corresponding register.

Writing the 64-bit text register takes 8 write accesses to

DTXT

. Reading the text register takes 8 read accesses from

DTXT

after which the contents of the text register are back in the original state. Writing the 56-bit key register takes also 8 write accesses to

DKEY

. In these accesses the least significant bit of each byte is discarded.

To support triple DES, the converter has two internal key registers:

KEY0

and

KEY1

. After a key has been shifted in, its value has to be stored in

KEY0

or

KEY1

before it can be used. A single-DES conversion uses

KEY0

and a triple-DES conversion uses first

KEY0

, then

KEY1

and finally

KEY0

again.

After a command has been written into

DCON

, it will be executed. Only the three least significant bits in register

DCON

have a meaning.

The conversions take so little time that no additional synchronization mechanism (interrupt or ready bit in status information) is needed. Instead the handshaking mechanism is used to obtain the required synchronization between the micro-controller and the DES converter. As long as the unit is busy in a conversion it does not accept any accesses to one of its SFRs. Therefore after having given a conversion command, the micro-controller can immediately start reading the resulting text. If in the case of a triple-DES conversion the result is not yet available, the first read access is held up in a handshake until the conversion is completed (no busy waiting).

© Philips Electronics N.V. 2005 Page 83 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Triple-DES Converter

For an encryption or decryption using the Triple-DES module, the following steps are neccesary:

• store the key in the key register (or both keys for triple-DES)

• write the text into the DES module

• start the encryption or decryption

• read the encrypted or decrypted text

These steps are described in further detail below.

5.8.5.1.

The key

Storing a key into auxiliary register KEY

B1B2B3B4B5B6B7B8 can be stored in key register

KEY0

or

KEY1

by writing the sequence

B8 B7 B6 B5 B4 B3 B2 B1 to SFR

DKEY

. Then the contents of

DKEY

can be copied into

KEY0

, by writing 00H to

DCON

, or it can be copied to

KEY1

by writing 01H to

DCON

.

5.8.5.2.

The text

Writing a text into the triple-DES module

3D9D3FA9FC8AD337 can be transferred to the DES module by writing the sequence

37 D3 8A FC A9 3F 9D 3D to SFR

DTXT

.

Alternatively the reverse sequence

3D 9D 3F A9 FC 8A D3 37 can be written to

DTXT

followed by the command 03H to

DCON

, which reverses the order of the bytes.

5.8.5.3. DES encryption or decryption

All encryptions or decryptions, be it single-DES or triple-DES, can be simply performed by writing the apporopiate command into the SFR

DCON

. The single-DES encryption or decryption uses

KEY0

only.

The triple-DES encryption and decryption use first

KEY0

, then

KEY1

and finally

KEY0

.

5.8.5.4. Reading the text result from register the triple-DES module

If the generated text result is

3D9D3FA9FC8AD337 reading from

DTXT

will deliver the sequence

37 D3 8A FC A9 3F 9D 3D after which the internal register will again contain the original text result.

The text can also be read in the reverse order by first giving the reverse-text command.

Page 84 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

Peripheral Modules – Triple-DES Converter

5.8.5.5. Examples

A single DES encryption with key

B1B2B3B4B5B6B7B8 and plain text

3D9D3FA9FC8AD337 can be done using following code:

; Store key in KEY0

MOV DKEY, #B8h

MOV DKEY, #B7h

MOV DKEY, #B6h

MOV DKEY, #B5h

MOV DKEY, #B4h

MOV DKEY, #B3h

MOV DKEY, #B2h

MOV DKEY, #B1h

MOV DCON, #00h

; Write plain text into DTXT

MOV DTXT, #37h

MOV DTXT, #D3h

MOV DTXT, #8Ah

MOV DTXT, #FCh

MOV DTXT, #A9h

MOV DTXT, #3Fh

MOV DTXT, #9Dh

MOV DTXT, #3Dh

; Invoke a single-DES encrytion

MOV DCON, #4

; the generated cipher text is F64E59B5B5A36506

; Reading the result:

MOV R0, DTXT

MOV R1, DTXT

MOV R2, DTXT

MOV R3, DTXT

MOV R4, DTXT

MOV R5, DTXT

MOV R6, DTXT

MOV R7, DTXT

; will result with value 06h in R0, 65h in R1, etc.

Handshake Solutions

© Philips Electronics N.V. 2005 Page 85 of 132

Handshake Solutions

HT80C51 User Manual

Peripheral Modules – Triple-DES Converter

Sometimes the text is in a different (reversed) byte order. Then following sequence can be used:

; Store key in KEY0

MOV DKEY, #B8h

MOV DKEY, #B7h

MOV DKEY, #B6h

MOV DKEY, #B5h

MOV DKEY, #B4h

MOV DKEY, #B3h

(the byte order of the keys cannot be changed)

MOV DKEY, #B2h

MOV DKEY, #B1h

MOV DCON, #00h

; Write plain text into DTXT (reversed order)

MOV DTXT, #3Dh

MOV DTXT, #9Dh

MOV DTXT, #3Fh

MOV DTXT, #A9h

MOV DTXT, #FCh

MOV DTXT, #8Ah

MOV DTXT, #D3h

MOV DTXT, #37h

MOV DCON, #3 ; reverse byte order

; Invoke a single-DES encrytion

MOV DCON, #4

; the generated cipher text is F64E59B5B5A36506

; Reading the result (reversed order)

MOV DCON, #3

MOV R7, DTXT

; reverse byte order for read-out

MOV R6, DTXT

MOV R5, DTXT

MOV R4, DTXT

MOV R3, DTXT

MOV R2, DTXT

MOV R1, DTXT

MOV R0, DTXT

; will result with value 06h in R0, 65h in R1, etc.

Page 86 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – 80C51 Instruction Set Summary

6. 80C51 Family Instruction Set

6.1. 80C51 Instruction Set Summary

Instructions that affect flag settings

(1)

Instruction Flag Instruction Flag

Handshake Solutions

C,bit

DIV 0 ORL

DA X

RRC X

ORL

MOV

C,/bit

RLC X CJNE X

SETB C 1

(1) Note that operations on SFR byte address 208 or bit addresses 209-215 (i.e., the PSW or bits in the PSW) will also affect flag settings.

Notes on instruction set and addressing modes:

Rn direct

@Ri

#data

Register R7-R0 of the currently selected Register Bank.

8-bit internal data location’s address. This could be an Internal Data RAM location (0-127) or a

SFR [i.e., I/O port, control register, status register, etc. (128-255)].

8-bit internal data RAM location (0-255) addressed indirectly through register R1 or R0.

8-bit constant included in the instruction.

#data 16 16-bit constant included in the instruction addr 16 16-bit destination address. Used by LCALL and LJMP. A branch can be anywhere within the

64k-byte Program Memory address space. addr 11 11-bit destination address. Used by ACALL and AJMP. The branch will be within the same 2k-byte page of program memory as the first byte of the following instruction.

Rel Signed (two’s complement) 8-bit offset byte. Used by SJMP and all conditional jumps. Range is

–128 to +127 bytes relative to first byte of the following instruction.

Bit Direct Addressed bit in Internal Data RAM or Special Function Register.

© Philips Electronics N.V. 2005 Page 87 of 132

Handshake Solutions

MNEMONIC DESCRIPTION

HT80C51 User Manual

80C51 Family Instruction Set – 80C51 Instruction Set Summary

ARITHMETIC OPERATIONS

ADD A,Rn Add register to Accumulator

ADD

ADD

A,direct

A,@Ri

Add direct byte to Accumulator

Add indirect RAM to Accumulator

ADD

ADDC

ADDC

ADDC

A,#data

A,Rn

A,direct

A,@Ri

Add immediate data to Accumulator

Add register to Accumulator with carry

Add direct byte to Accumulator with carry

Add indirect RAM to Accumulator with carry

ADDC

SUBB

SUBB

SUBB

A,#data

A,Rn

A,direct

A,@Ri

SUBB A,#data

INC A

INC Rn

Add immediate data to Accumulator with carry

Add register to Accumulator with borrow

Add direct byte to Accumulator with borrow

Add indirect RAM to Accumulator with borrow

Add immediate data to Accumulator with borrow

INC @Ri

DEC A

DEC Rn

DEC direct

DEC @Ri

Increment indirect RAM

Decrement direct byte

Decrement indirect RAM

1

2

1

2

1

1

2

1

1

2

1

2

1

2

1

2

2

1

1

1

1

1

1

1

ANL

ANL

ORL

ORL

ORL

ORL

ORL

ORL

XRL

MUL

DIV

AB

AB

Multiply A and B

Divide A by B

DA A

LOGICAL OPERATIONS

Decimal Adjust Accumulator

ANL

ANL

ANL

ANL

A,Rn

A,direct

A,@Ri

A,#data

AND Register to Accumulator

AND direct byte to Accumulator

AND indirect RAM to Accumulator

AND immediate data to Accumulator

XRL direct,A direct,#data

A,Rn

A,direct

A,@Ri

A,#data direct,A direct,#data

A,Rn

A,direct

AND Accumulator to direct byte

AND immediate data to direct byte

OR register to Accumulator

OR direct byte to Accumulator

OR indirect RAM to Accumulator

OR immediate data to Accumulator

OR Accumulator to direct byte

OR immediate data to direct byte

Exclusive-OR register to Accumulator

Exclusive-OR direct byte to Accumulator

2

3

1

2

1

2

1

2

2

3

1

2

1

2

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

4

1

2

4

1

2

1

1

1

1

1

1

1

2

1

1

1

1

Page 88 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – 80C51 Instruction Set Summary

MNEMONIC DESCRIPTION

LOGICAL OPERATIONS (continued)

XRL A,@Ri Exclusive-OR indirect RAM to Accumulator

XRL

XRL

A,#data direct,A

Exclusive-OR immediate data to Accumulator

Exclusive-OR Accumulator to direct byte

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

MOV

CLR A

CPL A

RL

RLC

A

A

RR

RRC

A

A

SWAP A

DATA TRANSFER

A,Rn

A,direct

A,@Ri

A,#data

Rn,A

Rn,direct

RN,#data direct,A

Rotate Accumulator left

Rotate Accumulator left through the carry

Rotate Accumulator right

Rotate Accumulator right through the carry

Swap nibbles within the Accumulator

Move register to Accumulator

Move direct byte to Accumulator

Move indirect RAM to Accumulator

Move immediate data to Accumulator

Move Accumulator to register

Move direct byte to register

Move immediate data to register

Move Accumulator to direct byte direct,Rn direct,direct direct,@Ri direct,#data

Move register to direct byte

Move direct byte to direct

Move indirect RAM to direct byte

Move immediate data to direct byte

@Ri,A

@Ri,direct

Move Accumulator to indirect RAM

Move direct byte to indirect RAM

@Ri,#data Move immediate data to indirect RAM

DPTR,#data16 Load Data Pointer with a 16-bit constant

MOVC

MOVC

MOVX

MOVX

A,@A+DPTR

A,@A+PC

A,@Ri

A,@DPTR

Move Code byte relative to DPTR to A

Move Code byte relative to PC to A

CC

Move external RAM (8-bit addr) to A

CC

CC

Move external RAM (16-bit addr) to A

CC

MOVX A,@Ri,A Move to external RAM (8-bit addr)

MOVX @DPTR,A Move to external RAM (16-bit addr)

PUSH

POP

XCH

XCH

XCH

XCHD direct direct

A,Rn

A,direct

A,@Ri

A,@Ri

Push direct byte onto stack

Pop direct byte from stack

Exchange register with Accumulator

Exchange direct byte with Accumulator

Exchange indirect RAM with Accumulator

Exchange low-order digit indirect RAM with A

CC

© Philips Electronics N.V. 2005

Handshake Solutions

BYTE

MACHINE

CYCLES

1

1

1

2

3

1

2

1

1

1

1

1

1

1

1

2

1

1

1

1

1

1

2

3

1

2

2

3

2

3

2

2

1

2

1

2

1

2

1

2

1

2

2

2

2

2

1

1

1

2

1

1

1

1

2

2

1

1

1 2

1 2

1 2

1 2

2

2

2

2

1

2

1

1

1 1

1 1

Page 89 of 132

Handshake Solutions

HT80C51 User Manual

80C51 Family Instruction Set – 80C51 Instruction Set Summary

MNEMONIC DESCRIPTION BYTE

MACHINE

CYCLES

BOOLEAN VARIABLE MANIPULATION

CLR C

CLR bit

SETB C

Clear direct bit

Set direct bit SETB bit

CPL C

CPL

ANL bit

C,bit

ANL

ORL

ORL

MOV

MOV

JC

JNC

JB

JNB

JBC

C,/bit

C,bit

C,/bit

C,bit bit,C rel rel rel rel bit,rel

PROGRAM BRANCHING

ACALL addr11

Complement direct bit

AND direct bit to carry

AND complement of direct bit to carry

OR direct bit to carry

OR complement of direct bit to carry

Move direct bit to carry

Move carry to direct bit

Jump if carry is set

Jump if carry not set

Jump if direct bit is set

Jump if direct bit is not set

Jump if direct bit is set and clear bit

Absolute subroutine call

LCALL addr16

RET

RETI

AJMP addr11

Return from subroutine

Return from interrupt

LJMP addr16

SJMP

JMP

JZ

JNZ

CJNE

CJNE

CJNE

CJNE rel

@A+DPTR rel rel

A,direct,rel

A,#data,rel

RN,#data,rel

Short jump (relative addr)

Jump indirect relative to the DPTR

Jump if Accumulator is zero

Jump if Accumulator is not zero

Compare direct byte to A

CC and jump if not equal

Compare immediate to A

CC and jump if not equal

Compare immediate to register and jump if not equal

@Ri,#data,rel Compare immediate to indirect and jump if not equal

DJNZ

DJNZ

Rn,rel direct,rel

NOP

Decrement register and jump if not zero

Decrement direct byte and jump if not zero

3

3

2

2

2

3

3

3

1

1

1

2

3

2

1

2

3

3

3

2

2

3

2

2

2

2

1

2

1

2

2

2

1

2

2

2

2

2

2

1

2

2

2

1

1

1

1

2

2

1

1

All mnemonics copyrighted © Intel Corporation 1980

2

2

2

2

2

2

2

2

1

2

2

2

2

2

2

2

2

Page 90 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions Handshake Solutions

ACALL addr11

Function: Absolute Call

Description: ACALL unconditionally calls a subroutine located at the indicated address. The instruction increments the PC twice to obtain the address of the following instruction, then pushes the 16-bit result onto the stack (low-order byte first) and increments the Stack Pointer twice. The destination address is obtained by successively concatenating the five high-order bits of the incremented PC, opcode bits 7-5, and the second byte of the instruction. The subroutine called must therefore start within the same 2k block of the program memory as the first byte of the instruction following

ACALL. No flags are affected. ing the instruction,

ACALL SUBRTN at location 0123H, SP will contain 09H, internal RAM locations 08H and 09H will contain 25H and

01H, respectively, and the PC will contain 0345H.

Bytes: 2

Cycles: 2

Encoding: a10 a9 a8 1 0 0 0 1 a7 a6 a5 a4 a3 a2 a1 a0

Operation: ACALL

(PC)

(PC) + 2

(SP)

(SP) + 1

(SP)

(PC

7-0

)

(SP)

(SP) + 1

(SP)

(PC

15-8

)

(PC

10-0

)

← page address

© Philips Electronics N.V. 2005 Page 91 of 132

Handshake Solutions

ADD A,<src-byte>

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: ADD adds the byte variable indicated to the Accumulator, leaving the result in the Accumulator.

The carry and auxiliary-carry flags are set, respectively, if there is a carry-out from bit 7 or bit 3, and cleared otherwise. When adding unsigned integers, the carry flag indicates an overflow occurred.

OV is set if there is a carry-out of bit 6 but not out of bit 7, or a carry-out of bit 7 but not bit 6; otherwise OV is cleared. When adding signed integers, OV indicates a negative number produced as the sum of two positive operands, or a positive sum from two negative operands.

Four source operand addressing modes are allowed: register, direct, register-indirect, or immediate. tion,

ADD A,R0 will leave 6DH (01101101B) in the Accumulator with the AC flag cleared and both the Carry flag and OV set to 1.

ADD A,Rn

Encoding:

0 0 1 0 1 r r r

ADD A,direct

(A)

(A) + (R n

)

Encoding:

ADD A,@Ri

(A)

(A) + (direct)

Encoding:

0 0 1 0 0 1 1 i

ADD A,#data

(A)

(A) + ((R i

))

Encoding:

Page 92 of 132

(A)

(A) + #data

© Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

ADDC A,<src-byte>

Handshake Solutions

Description: ADDC simultaneously adds the byte variable indicated, the carry flag and the Accumulator contents, leaving the result in the Accumulator. The carry and auxiliary-carry flags are set, respectively, if there is a carry-out from bit 7 or bit 3, and cleared otherwise. When adding unsigned integers, the carry flag indicates an overflow occurred.

OV is set if there is a carry-out of bit 6 but not out of bit 7, or a carry-out of bit 7 but not out of bit 6; otherwise OV is cleared. When adding signed integers, OV indicates a negative number produced as the sum of two positive operands, or a positive sum from two negative operands.

Four source operand addressing modes are allowed: register, direct, register-indirect, or immediate.

ADDC A,Rn

flag set. The instruction,

ADDC A,R0 will leave 6EH (01101110B) in the Accumulator with AC cleared and both the Carry flag and OV set to 1.

Encoding:

0 0 1 1 1 r r r

ADDC A,direct

(A)

(A) + (C) + (R n

)

Encoding:

ADDC A,@Ri

(A)

(A) + (C) + (direct)

Encoding:

0 0 1 1 0 1 1 i

ADDC A,#data

(A)

(A) + (C) + ((R i

))

Encoding:

(A)

(A) + (C) + #data

© Philips Electronics N.V. 2005 Page 93 of 132

Handshake Solutions

AJMP addr11

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: AJMP transfers program execution to the indicated address, which is formed at run-time by concatenating the high-order five bits of the PC ( after incrementing the PC twice), opcode bits 7-5, and the second byte of the instruction. The destination must therefore be within the same 2k block of program memory as the first byte of the instruction following AJMP.

AJMP JMPADR is at location 0345H and will load the PC with 0123H.

Encoding:

a10 a9 a8 0 0 0 0 1 a7 a6 a5 a4 a3 a2 a1 a0

(PC)

(PC) + 2

(PC

10-0

)

← page address

ANL <dest-byte>,<src-byte>

Description: ANL performs the bitwise logical-AND operation between the variables indicated and stores the results in the destination variable. No flags are affected.

The two operands allow six addressing mode combinations. When the destination is the Accumulator, the source can use register, direct, register-indirect, or immediate addressing; when the destination is a direct address, the source can be the Accumulator or immediate data.

Note: When this instruction is used to modify an output port, the value used as the original port data will be read from the output data latch, not the input pins. struction,

ANL A,R0 will leave 41H (01000001B) in the Accumulator.

When the destination is a directly addressed byte, this instruction will clear combinations of bits in any RAM location or hardware register. The mask byte determining the pattern of bits to be cleared would either be a constant contained in the instruction or a value computed in the Accumulator at run-time. The instruction,

ANL P1,#01110011B will clear bits 7, 3, and 2 of output port 1.

Page 94 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

ANL A,Rn

Encoding:

0 1 0 1 1 r r r

ANL A ,direct

(A)

(A)

(R n

)

Encoding:

ANL A,@Ri

(A)

(A)

(direct)

Encoding:

0 1 0 1 0 1 1 i

ANL A,#data

(A)

(A)

((R i

))

Encoding:

ANL direct,A

(A)

(A)

#data

Encoding:

(A)

←( direct)

(A)

ANL direct,#data

Encoding:

(direct)

←( direct)

#data

© Philips Electronics N.V. 2005

Handshake Solutions

Page 95 of 132

Handshake Solutions

ANL C,<src-bit>

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: If the Boolean value of the source bit is a logical 0 then clear the carry flag; otherwise leave the carry flag in its current state. A slash (“/”) preceding the operand in the assembly language indicates that the logical complement of the addressed bit is used as the source value, but the source bit itself is not affected. No other flags are affected.

Only direct addressing is allowed for the source operand.

MOV C,P1.0 ;LOAD CARRY WITH INPUT PIN STATE

ANL C,ACC.7 ;AND CARRY WITH ACCUM. BIT 7

ANL C,/OV ;AND WITH INVERSE OF OVERFLOW FLAG

ANL C,bit

Encoding:

1 0 0 0 0 0 1 0 address

(C)

(C)

(bit)

ANL C,/bit

Encoding:

1 0 1 1 0 0 0 0 bit

(C)

(C)

∧ ¬

(bit)

Page 96 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

CJNE <dest-byte>,<src-byte>,rel

Handshake Solutions

Description: CJNE compares the magnitudes of the first two operands, and branches if their values are not equal. The branch destination is computed by adding the signed relative-displacement in the last instruction byte to the PC, after incrementing the PC to the start of the next instruction. The carry flag is set if the unsigned integer value of <dest-byte> is less than the unsigned integer value of

<src-byte>; otherwise, the carry is cleared. Neither operand is affected.

The first two operands allow four addressing mode combinations: the Accumulator may be compared with any directly addressed byte or immediate data, and any indirect RAM location or working register can be compared with an immediate constant.

CJNE R7,#60H,NOT_EQ

; ... .... ; R7 = 60H.

NOT_EQ: JC REQ_LOW ; IF R7 < 60H.

; ... .... ; R7 > 60H. sets the carry flag and branches to the instruction at label NOT_EQ. By testing the carry flag, this instruction determines whether R7 is greater or less than 60H.

If the data being presented to Port 1 is also 34H, then the instruction,

WAIT: CJNE A,P1,WAIT clears the carry flag and continues with the next instruction in sequence, since the Accumulator does equal the data read from P1. (If some other value was being input on P1, the program will loop at this point until the P1 data changes to 34H.)

CJNE A,direct,rel

Encoding:

address rel.

(PC) + 3

IF (A) < > (direct)

THEN

IF (A) < (direct)

THEN

(PC)

(PC) + relative offset

1

ELSE

0

© Philips Electronics N.V. 2005 Page 97 of 132

Handshake Solutions

CJNE A,#data,rel

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Encoding:

data rel.

(PC) + 3

IF (A) < > data

THEN

IF (A) < data

THEN

ELSE

(PC)

(C)

(C)

(PC) + relative offset

1

0

CJNE Rn,#data,rel

Encoding:

1 0 1 1 1 r r r immediate address

(PC) + 3

IF (R n

) < > data

THEN

IF (R n

) < data

THEN

ELSE

(PC)

(C)

(C)

(PC) + relative offset

1

0

CJNE @Ri,#data,rel

Encoding:

1 0 1 1 0 1 1 i immediate address

(PC) + 3

IF ((R i

)) < > data

THEN

IF ((R i

)) < data

THEN

ELSE

(PC)

(C)

(C)

(PC) + relative offset

1

0

Page 98 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

CLR A

Description: The Accumulator is cleared (all bits reset to zero). No flags are affected.

CLR A will leave the Accumulator set to 00H (00000000B).

Handshake Solutions

Encoding:

1 1 1 0 0 1 0 0

Operation: CLR

(A)

0

CLR bit

Description: The indicated bit is cleared (reset to zero). No other flags are affected. CLR can operate on the carry flag or any directly addressable bit.

CLR P1.2 will leave the port set to 59H (01011001B).

CLR C

Encoding:

1 1 0 0 0 0 1 1

Operation: CLR

(C)

0

CLR bit

Encoding:

1 1 0 0 0 0 1 0 bit

Operation: CLR

(bit)

0

© Philips Electronics N.V. 2005 Page 99 of 132

Handshake Solutions

CPL A

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: Each bit of the Accumulator is logically complemented (one’s complement). Bits which previously contained a one are changed to a zero and vice-versa. No flags are affected.

CPL A will leave the Accumulator set to 0A3H (10100011B).

Encoding:

1 1 1 1 0 1 0 0

(A)

← ¬

(A)

CPL bit

Description: The bit variable specified is complemented. A bit which had been a one is changed to zero and vice-versa. No other flags are affected. CPL can operate on the carry or any directly addressable bit.

Note: When this instruction is used to modify an output pin, the value used as the original data will be read from the output data latch, not the input pin.

CPL P1.1

CPL P1.2 will leave the port set to 5BH (01011011B).

CPL C

Encoding:

1 0 1 1 0 0 1 1

(C)

←¬

(C)

CPL bit

Encoding:

1 0 1 1 0 0 1 0 bit

(bit)

← ¬

(bit)

Page 100 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

DA A

Handshake Solutions

Description: DA A adjusts the eight-bit value in the Accumulator resulting from the earlier addition of two variable (each in packed-BCD format), producing two four-bit digits. Any ADD or ADDC instruction may have been used to perform the addition.

If Accumulator bits 3-0 are greater than nine (xxx1010-xxx1111), or if the AC flag is one, six is added to the Accumulator, producing the proper BCD digit in the low-order nibble. This internal addition would set the carry flag if a carry-out of the low-order four-bit field propagated through all high-order bits, but it would not clear the carry flag otherwise.

If the carry flag is now set, or if the four high-order bits now exceed nine (1010xxx-111xxxx), these high-order bits are incremented by six, producing the proper BCD digit in the high-order nibble.

Again, this would set the carry flag if there was a carry-out of the high-order bits, but wouldn’t clear the carry. The carry flag thus indicates if the sum of the original two BCD variables is greater than 100, allowing multiple precision decimal addition. OV is not affected.

All of this occurs during the one instruction cycle. Essentially, this instruction performs the decimal conversion by adding 00H, 06H, 60H, or 66H to the Accumulator, depending on initial Accumulator and PSW conditions.

Note: DA A cannot simply convert a hexadecimal number in the Accumulator to BCD notation, nor does DA A apply to decimal subtraction. decimal number 56. Register 3 contains the value 67H (01100111B) representing the packed

BCD digits of the decimal number 67. The carry flag is set.. The instruction sequence,

ADDC A,R3

DA A will first perform a standard two’s-complement binary addition, resulting in the value 0BEH

(10111110B) in the Accumulator. The carry and auxiliary carry flags will be cleared.

The Decimal Adjust instruction will then alter the Accumulator to the value 24H (00100100B), indicating the packed BCD digits of the decimal number 24, the low-order two digits of the decimal sum of 56, 67, and the carry-in. The carry flag will be set by the Decimal Adjust instruction, indicating that a decimal overflow occurred. The true sum 56, 67, and 1 is 124.

BCD variables can be incremented or decremented by adding 01H or 99H. If the Accumulator initially holds 30H (representing the digits of 30 decimal), the the instruction sequence,

ADD A,#99H

DA A will leave the carry set and 29H in the Accumulator, since 30 + 99 = 129. The low-order byte of the sum can be interpreted to mean 30 – 1 = 29.

Encoding:

1 1 0 1 0 1 0 0

–contents of Accumulator are BCD

IF [[(A

3-0

) > 9]

[(AC) = 1]]

THEN (A

3-0

)

(A

3-0

) + 6

AND

IF [[(A

7-4

) > 9]

[(C) = 1]]

THEN (A

7-4

)

(A

7-4

) + 6

© Philips Electronics N.V. 2005 Page 101 of 132

Handshake Solutions

DEC byte

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: The variable indicated is decremented by 1. An original value of 00H will underflow to 0FFH. No flags are affected. Four operand addressing modes are allowed: accumulator, register, direct, or register-indirect.

Note: When this instruction is used to modify an output port, the value used as the original data will be read from the output data latch, not the input pin.

40H, respectively. The instruction sequence,

DEC @R0

DEC R0

DEC @R0 will leave register 0 set to 7EH and internal RAM locations 7EH and 7FH set to 0FFH and 3FH.

DEC A

Encoding:

0 0 0 1 0 1 0 0

(A)

(A) – 1

DEC Rn

Encoding:

0 0 0 1 1 r r r

(R n

)

(R n

) – 1

DEC direct

Encoding:

(direct)

(direct) – 1

DEC @Ri

Encoding:

0 0 0 1 0 1 1 i

((R i

))

((R i

)) – 1

Page 102 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

DIV AB

Handshake Solutions

Description: DIV AB divides the unsigned eight-bit integer in the Accumulator by the unsigned eight-bit integer in register B.

The Accumulator receives the integer part of the quotient; register B receives the integer remainder. The carry and OV flags will be cleared.

Exception: if B had originally contained 00H, the values returned in the Accumulator and Bregister will be undefined and the overflow flag will be set. The carry flag is cleared in any case.

The instruction,

DIV AB will leave 13 in the Accumulator (0DH or 00001101B) and the value 17 (11H or 00010001B) in B, since 251 = (13 x 18) + 17. Carry and OV will both be cleared.

Encoding:

1 0 0 0 0 1 0 0

(A)

15-8

(A)/(B)

(B)

7-0

© Philips Electronics N.V. 2005 Page 103 of 132

Handshake Solutions

DJNZ <byte>,<rel-addr>

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: DJNZ decrements the location indicated by 1, and branches to the address indicated by the second operand if the resulting value is not zero. An original value of 00H will underflow to 0FFH. No flags are affected. The branch destination would be computed by adding the signed relativedisplacement value in the last instruction byte to the PC, after incrementing the PC to the first byte of the following instruction. The location decremented may be a register or directly addressed byte.

Note: When this instruction is used to modify an output port, the value used as the original port data will be read from the output data latch, not the input pins.

DJNZ Rn,rel

The instruction sequence,

DJNZ 40H,LABEL_1

DJNZ 50H,LABEL_2

DJNZ 60H,LABEL_3 will cause a jump to the instruction at LABEL_2 with the values 00h, 6FH, and 15H in the three

RAM locations. The first jump was not taken because the result was zero.

This instruction provides a simple was of executing a program loop a given number of times, or for adding a moderate time delay (from 2 to 512 machine cycles)

←ith a single instruction. The instruction sequence,

MOV R2,#8

TOGGLE: CPL P1.7

DJNZ R2,TOGGLE will toggle P1.7 eight times, causing four output pulses to appear at bit 7 of output Port 1. Each pulse will last three machine cycles, two for DJNZ and one to alter the pin.

Encoding:

1 1 0 1 1 r r r rel.

(PC)

(PC) + 2

(R n

)

(R n

) – 1

IF (R n

) > 0 or (R n

) < 0

THEN

DJNZ direct,rel

(PC)

(PC) + rel

Encoding:

1 1 0 1 0 1 0 1 direct address

Page 104 of 132

(PC)

(PC) + 2

(direct)

(direct) – 1

IF (direct) > 0 or (direct) < 0

THEN

(PC)

(PC) + rel

© Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

INC <byte>

Handshake Solutions

Description: INC increments the indicated variable by 1. An original value of 0FFH will overflow to 00H. No flags are affected. Three addressing modes are allowed: register, direct, or register-indirect.

Note: When this instruction is used to modify an output port, the value used as the original port data will be read from the output data latch, not the input pins.

40H, respectively. The instruction sequence,

INC @R0

INC R0

INC @R0 will leave register 0 set to 7FH and internal RAM locations 7EH and 7FH holding (respectively)

00H and 41H.

INC A

Encoding:

0 0 0 0 0 1 0 0

(A)

(A) + 1

INC Rn

Encoding:

0 0 0 0 1 r r r

(R n

)

(R n

) + 1

INC direct

Encoding:

(direct)

(direct) + 1

INC @Ri

Encoding:

0 0 0 0 0 1 1 i

((R i

))

((R i

)) + 1

© Philips Electronics N.V. 2005 Page 105 of 132

Handshake Solutions

INC DPTR

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: Increment the 16-bit data pointer by 1. A 16-bit increment (modulo 2

16

) is performed; an overflow of the low-order byte of the data pointer (DPL) from 0FFH to 00H will increment the high-order byte (DPH). No flags are affected.

This is the only 16-bit register which can be incremented.

INC DPTR

INC DPTR

INC DPTR will change DPH and DPL to 13H and 01H.

Encoding:

1 0 1 0 0 0 1 1

(DPTR)

(DPTR) + 1

JB bit,rel

Description: If the indicated bit is a one, jump to the address indicated; otherwise proceed with the next instruction. The branch destination is computed by adding the signed relative-displacement in the third instruction byte to the PC, after incrementing the PC to the first byte of the next instruction. The bit tested is not modified. No flags are affected. instruction sequence,

JB P1.2,LABEL1

JB ACC.2,LABEL2 will cause program execution to branch to the instruction at label LABEL2.

Encoding:

0 0 1 0 0 0 0 0 address rel.

(PC)

(PC) + 3

IF (bit) = 1

(PC) + rel

Page 106 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

JBC bit,rel

Handshake Solutions

Description: If the indicated bit is a one, branch to the address indicated; otherwise proceed with the next instruction. The bit will not be cleared if it is already a zero. The branch destination is computed by adding the signed relative-displacement in the third instruction byte to the PC, after incrementing the PC to the first byte of the next instruction. No flags are affected.

Note: When this instruction is used to test an output pin, the value used as the original data will read from the output data latch, not the input pin.

JBC ACC.3,LABEL1

JBC ACC.2,LABEL2 will cause program execution to continue at the instruction identified by the LABEL2, with the Accumulator modified to 52H (01010010B).

Encoding:

0 0 0 1 0 0 0 0 bit address

(PC)

(PC) + 3

IF (bit) = 1

THEN

(bit)

(PC)

0

(PC) + rel

JC rel

Description: If the carry flag is set, branch to the address indicated; otherwise proceed with the next instruction. The branch destination is computed by adding the signed relative-displacement in the second instruction byte to the PC, after incrementing the PC twice. No flags are affected.

JC LABEL1

CPL C

JC LABEL2 will set the carry and cause program execution to continue at the instruction identified by the label

LABEL2.

Encoding:

0 1 0 0 0 0 0 0 rel.

(PC)

(PC) + 2

IF (C) = 1

(PC) + rel

© Philips Electronics N.V. 2005 Page 107 of 132

Handshake Solutions

JMP @A+DPTR

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: Add the eight-bit unsigned contents of the Accumulator with the sixteen-bit data pointer, and load the resulting sum to the program counter. This will be the address for subsequent instruction fetches.

Sixteen-bit addition is performed (modulo 2

16

): a carry-out from the low-order eight bits propagates through the higher-order bits. Neither the Accumulator nor the Data Pointer is altered. No flags are affected. branch to one of four AJMP instructions in a jump table starting at JMP_TBL:

MOV DPTR,#JMP_TBL

JMP @A+DPTR

JMP_TBL: AJMP LABEL0

AJMP LABEL1

AJMP LABEL2

AJMP LABEL3

If the Accumulator equals 04H when starting this sequence, execution will jump to label LABEL2.

Remember that AJMP is a two-byte instruction, so the jump instructions start at every other address.

Encoding:

0 1 1 1 0 0 1 1

(PC)

(A) + (DPTR)

JNB bit,rel

Description: If the indicated bit is a zero, branch to the indicated address; otherwise proceed with the next instruction. The branch destination is computed by adding the signed relative-displacement in the third instruction byte to the PC, after incrementing the PC to the first byte of the next instruction.

The bit tested is not modified. No flags are affected. instruction sequence,

JNB P1.3,LABEL1

JNB ACC.3,LABEL2 will cause program execution to continue at the instruction at label LABEL2.

Encoding:

0 0 1 1 0 0 0 0 bit address

Page 108 of 132

(PC)

(PC) + 3

IF (bit) = 0

THEN (PC)

(PC) + rel

© Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

JNC rel

Handshake Solutions

Description: If the carry flag is a zero, branch to the address indicated; otherwise proceed with the next instruction. The branch destination is computed by adding the signed relative-displacement in the second instruction byte to the PC, after incrementing the PC twice to point to the next instruction. The carry flag is not modified.

JNC LABEL1

CPL C

JNC LABEL2 will clear the carry and cause program execution to continue at the instruction identified by the label LABEL2.

Encoding:

0 1 0 1 0 0 0 0 rel.

(PC)

(PC) + 2

IF (C) = 0

THEN (PC)

(PC) + rel

JNZ rel

Description: If any bit of the Accumulator is a one, branch to the indicated address; otherwise proceed with the next instruction. The branch destination is computed by adding the signed relative-displacement in the second instruction byte to the PC, after incrementing the PC twice. The Accumulator is not modified. No flags are affected.

JNZ LABEL1

INC A

JNZ LABEL2 will set the Accumulator to 01H and continue at label LABEL2.

Encoding:

0 1 1 1 0 0 0 0 rel.

(PC)

(PC) + 2

IF A

≠ 0

THEN (PC)

(PC) + rel

© Philips Electronics N.V. 2005 Page 109 of 132

Handshake Solutions

JZ rel

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: If all bits of the Accumulator are zero, branch to the indicated address; otherwise proceed with the next instruction. The branch destination is computed by adding the signed relative-displacement in the second instruction byte to the PC, after incrementing the PC twice. The Accumulator is not modified. No flags are affected.

JZ LABEL1

DEC A

JZ LABEL2 will change the Accumulator to 00H and cause program execution to continue at the instruction identified by the label LABEL2.

Encoding:

0 1 1 0 0 0 0 0 rel.

LCALL addr16

(PC)

(PC) + 2

IF A = 0

THEN (PC)

(PC) + rel

Description: LCALL calls a subroutine located at the indicated address. The instruction adds three to the program counter to generate the address of the next instruction and then pushes the 16-bit result onto the stack (low byte first), incrementing the Stack Pointer by two. The high-order and loworder bytes of the PC are then loaded, respectively, with the second and third bytes of the LCALL instruction. Program execution continues with the instruction at this address. The subroutine may therefore begin anywhere in the full 64k-byte program memory address space. No flags are affected. tion 1234H. After executing the instruction,

LCALL SUBRTN at location 0123H, the Stack Pointer will contain 09H, internal RAM locations 08H and 09H will contain 26H and 01H, and the PC will contain 1235H.

Encoding:

0 0 0 1 0 0 1 0 addr15-addr8 addr7-addr0

Page 110 of 132

(PC)

(PC) + 3

(SP)

(SP) + 1

((SP))

(PC

7-0

)

(SP)

(SP) + 1

((SP))

(PC

15-8

)

(PC)

← addr

15-0

© Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

LJMP addr16

Handshake Solutions

Description: LJMP causes an unconditional branch to the indicated address, by loading the high-order and low-order bytes of the PC (respectively) with the second and third instruction bytes. The destination may therefore be anywhere in the full 64k program memory address space. No flags are affected. struction,

LJMP JMPADR at location 0123H will load the program counter with 1234H.

Encoding:

0 0 0 0 0 0 1 0 addr15-addr8 addr7-addr0

(PC)

← addr

15-0

MOV <dest-byte>,<src-byte>

Description: The byte variable indicated by the second operand is copied into the location specified by the first operand. The source byte is not affected. No other register or flag is affected.

This is by far the most flexible operation. Fifteen combinations of source and destination addressing modes are allowed. input port 1 is 11001010B (0CAH). The instruction sequence,

MOV R0,#30H ;R0 < = 30H

MOV A,@R0 ;A < = 40H

MOV R1,A ;R1 < = 40H

MOV B,@R1 ;B < = 10H

MOV @R1,P1 ;RAM (40H) < = 0CAH

MOV P2,P1 ;P2 #0CAH leaves the value 30H in register 0, 40H in both the Accumulator and register 1, 10H in register B, and 0CAH (11001010B) both in RAM location 40H and output on port 2.

MOV A,Rn

Encoding:

1 1 1 0 1 r r r

(A)

(R n

)

© Philips Electronics N.V. 2005 Page 111 of 132

Handshake Solutions

*MOV A,direct

Encoding:

MOV A,@Ri

(A)

(direct)

Encoding:

1 1 1 0 0 1 1 i

MOV A ,#data

(A)

((R i

))

Encoding:

(A)

#data

MOV Rn,A

Encoding:

1 1 1 1 1 r r r

MOV Rn,direct

(R n

)

(A)

Encoding:

MOV Rn,#data

(R n

)

(direct)

Encoding:

(R n

)

#data

*MOV A,ACC is not a valid instruction.

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Page 112 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

MOV direct,A

Encoding:

MOV direct,Rn

(direct)

(A)

Encoding:

(direct)

(R n

)

MOV direct,direct

Encoding:

(direct)

(direct)

MOV direct,@Ri

Encoding:

(direct)

((R i

))

MOV direct,#data

Encoding:

MOV @Ri,A

(direct)

#data

Encoding:

1 1 1 1 0 1 1 i

((R i

))

(A)

© Philips Electronics N.V. 2005

Handshake Solutions

Page 113 of 132

Handshake Solutions

MOV @Ri,direct

Encoding:

((R i

))

(direct)

MOV @Ri,#data

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Encoding:

((R i

))

#data

MOV <dest-bit>,<src-bit>

Description: The Boolean variable indicated by the second operand is copied into the location specified by the first operand. One of the operands must be the carry flag; the other may be any directly addressable bit. No other register or flag is affected. written to output Port 1 is 35H (00110101B). The instruction sequence,

MOV P1.3,C

MOV C,P3.3

MOV P1.2,C will leave the carry cleared and change Port 1 to 39H (00111001B).

MOV C,bit

Encoding:

1 0 1 0 0 0 1 0 bit

(C)

(bit)

MOV bit,C

Encoding:

1 0 0 1 0 0 1 0 bit

(bit)

(C)

Page 114 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

MOV DPTR,#data16

Handshake Solutions

Description: The Data Pointer is loaded with the 16-bit constant indicated. The 16-bit constant is loaded into the second and third bytes of the instruction. The second byte (DPH) is the high-order byte, while the third byte (DPL) holds the low-order byte. No flags are affected.

This is the only instruction which moves 16 bits of data at once.

MOV DPTR,#1234H will load the value 1234H into the Data Pointer: DPH will hold 12H and DPL will hold 34H.

Encoding:

(DPTR)

DPH

MOVC A,@A+<base-reg>

□ DPL

#data

15-8

(#data

15-0

)

□ #data

7-0

Description: The MOVC instructions load the Accumulator with a code byte, or constant from program memory. The address of the byte fetched is the sum of the original unsigned eight-bit Accumulator contents and the contents of a sixteen-bit base register, which may be either the Data Pointer or the

PC. In the latter case, the PC is incremented to the address of the following instruction before being added with the Accumulator; otherwise the base register is not altered. Sixteen-bit addition is performed so a carry-out from the low-order eight bits may propagate through higher-order bits.

No flags are affected. in the Accumulator to one of four values defined by the DB (define byte)

←irective:

REL_PC: INC A

MOVC A,@A+PC

RET

DB 66H

DB 77H

DB 88H

DB 99H

If the subroutine is called with the Accumulator equal to 01H, it will return with 77H in the Accumulator. The INC A before the MOVC instruction is needed to “get around” the RET instruction above the table. If several bytes of code separated the MOVC from the table, the corresponding number would be added to the Accumulator instead.

© Philips Electronics N.V. 2005 Page 115 of 132

Handshake Solutions

MOVC A,@A+DPTR

Encoding:

1 0 0 1 0 0 1 1

(A)

((A) + (DPTR))

MOVC A,@A+PC

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Encoding:

1 0 0 0 0 0 1 1

(PC)

(PC) + 1

(A)

((A) + (PC))

MOVX <dest-byte>,<src-byte>

Description: The MOVX instructions transfer data between the Accumulator and a byte of external data memory, hence the “X” appended to MOV. There are two types of instructions, differing in whether they provide an eight-bit or sixteen-bit indirect address to the external data RAM.

In the first type, the contents of R0 or R1 in the current register bank provide an eight-bit address.

Eight bits are sufficient for external I/O expansion decoding or for a relatively small RAM array.

For somewhat larger arrays, the SFR XRAMP be used to define higher-order address bits. These pins would be set by a move instruction to XRAMP preceding the MOVX.

In the second type of MOVX instruction, The Data Pointer generates a sixteen-bit address. This form is faster and more efficient when accessing very large data arrays (up to 64k bytes), since no additional instructions are needed to set up the output ports.

It is possible in some situations to mix the two MOVX types. A large RAM array with its high-order address lines can be addressed via the Data Pointer, or with code to output high-order address bits to XRAMP followed by a MOVX instruction using R0 or R1.

MOVX A,@Ri

ters 0 and 1 contain 12H and 34H. Location 34H of the external RAM holds the value 56H. The instruction sequence,

MOVX A,@R1

MOVX @R0,A copies the value 56H into both the Accumulator and external RAM location 12H.

Encoding:

1 1 1 0 0 0 1 i

(A)

((R i

))

Page 116 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

MOVX A,@DPTR

Encoding:

1 1 1 0 0 0 0 0

MOVX @Ri,A

(A)

((DPTR))

Handshake Solutions

Encoding:

1 1 1 1 0 0 1 i

((R i

))

(A)

MOVX @DPTR,A

Encoding:

1 1 1 1 0 0 0 0

((DPTR))

(A)

MUL AB

Description: MUL AB multiplies the unsigned eight-bit integers in the Accumulator and register B. The loworder byte of the sixteen-bit product is left in the Accumulator, and the high-order byte in B. If the product is greater than 255 (0FFH) the overflow flag is set; otherwise it is cleared. The carry flag is always cleared. instruction,

MUL AB will give the product 12,800 (3200H), so B is changed to 32H (00110010B) and the Accumulator is cleared. The overflow flag is set, carry is cleared.

Encoding:

1 0 1 0 0 1 0 0

(A)

7-0

(A) x (B)

(B)

15-8

© Philips Electronics N.V. 2005 Page 117 of 132

Handshake Solutions

NOP

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: Execution continues at the following instruction. Other than the PC, no registers or flags are affected. ple SETB/CLR sequence would generate a one-cycle pulse, so four additional cycles must be inserted. This may be done (assuming are enabled) with the instruction sequence,

CLR P2.7

NOP

NOP

NOP

NOP

SETB P2.7

Encoding:

0 0 0 0 0 0 0 0

(PC)

(PC) + 1

ORL <dest-byte>,<src-byte>

Description: ORL performs the bitwise logical-OR operation between the indicated variables, storing the results in the destination byte. No flags are affected.

The two operands allow six addressing mode combinations. When the destination is the Accumulator, the source can use register, direct, register-indirect, or immediate addressing; when the destination is a direct address, the source can be the Accumulator or immediate data.

Note: When this instruction is used to modify an output port, the value used as the original port data will be read from the output data latch, not the input pins.

ORL A,R0 will leave the Accumulator holding the value 0D7H (11010111B). When the destination is a directly addressed byte, the instruction can set combinations of bits in any RAM location or hardware register. The pattern of bits to be set is determined by a mask byte, which may be either a constant data value in the instruction or a variable computed in the Accumulator at run-time. The instruction,

ORL P1,#00110010B will set bits 5, 4, and 1 of output Port 1.

ORL A,Rn

Encoding:

0 1 0 0 1 r r r

(A)

(A)

(R n

)

Page 118 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

ORL A,direct

Encoding:

ORL A,@Ri

(A)

(A)

(direct)

Encoding:

0 1 0 0 0 1 1 i

ORL A,#data

(A)

(A)

((R i

))

Encoding:

ORL direct,A

(A)

(A)

#data

Encoding:

(direct)

(direct)

(A)

ORL direct,#data

Encoding:

(direct)

(direct)

#data

Handshake Solutions

© Philips Electronics N.V. 2005 Page 119 of 132

Handshake Solutions

ORL C,<src-bit>

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: Set the carry flag if the Boolean value is a logical 1; leave the carry in its current state otherwise.

A slash (“/”) preceding the operand in the assembly language indicates that the logical complement of the addressed bit is used as the source value, but the source bit itself is not affected. No other flags are affected.

ORL C,P1.0 ;LOAD CARRY WITH INPUT PIN P10

ORL C,ACC.7 ;OR CARRY WITH THE ACC. BIT 7

ORL C,/OV ;OR CARRY WITH THE INVERSE OF OV.

ORL C,bit

Encoding:

0 1 1 1 0 0 1 0 bit

(C)

(C)

(bit)

ORL C,/bit

Encoding:

1 0 1 0 0 0 0 0 bit

(C)

(C)

¬

(bit)

Page 120 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

POP direct

Handshake Solutions

Description: The contents of the internal RAM location addressed by the Stack Pointer is read, and the Stack

Pointer is decremented by one. The value read is then transferred to the directly addressed byte indicated. No flags are affected. contain the values 20H, 23H, and 01H, respectively. The instruction sequence,

POP DPH

POP DPL will leave the Stack Pointer equal to the value 30H and the Data Pointer set to 0123H. At this point the instruction,

POP SP will leave the Stack Pointer set to 20H. Note that in this special case the Stack Pointer was decremented to 2FH before being loaded with the value popped (20H).

Encoding:

PUSH direct

(direct)

((SP))

(SP)

(SP) – 1

Description: The Stack Pointer is incremented by one. The contents of the indicated variable is then copied into the internal RAM location addressed by the Stack Pointer. Otherwise no flags are affected.

0123H. The instruction sequence,

PUSH DPL

PUSH DPH will leave the Stack Pointer set to 0BH and store 23H and 01H in internal RAM locations 0AH and

0BH, respectively.

Encoding:

(SP)

(SP) + 1

((SP))

(direct)

© Philips Electronics N.V. 2005 Page 121 of 132

Handshake Solutions

RET

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: RET pops the high- and low-order bytes of the PC successively from the stack, decrementing the

Stack Pointer by two. Program execution continues at the resulting address, generally the instruction immediately following an ACALL or LCALL. No flags are affected. the values 23H and 01H, respectively. The instruction,

RET will leave the Stack Pointer equal to the value 09H. Program execution will continue at location

0123H.

Encoding:

0 0 1 0 0 0 1 0

(PC

15-8

)

((SP))

(SP)

(SP) – 1

(PC

7-0

)

(SP)

((SP))

(SP) – 1

RETI

Description: RETI pops the high- and low-order bytes of the PC successively from the stack, and restores the interrupt logic to accept additional interrupts at the same priority level as the one just processed.

The Stack Pointer is left decremented by two. No other registers are affected; the PSW is not automatically restored to its pre-interrupt status. Program execution continues at the resulting address, which is generally the instruction immediately after the point at which the interrupt request was detected. If a lower- or same-level interrupt has been pending when the RETI instruction is executed, that one instruction will be executed before the pending interrupt is processed. tion ending at location 0122H. Internal RAM locations 0AH and 0BH contain the values 23H and

01H, respectively. The instruction,

RETI will leave the Stack Pointer equal to 09H and return program execution to location 0123H.

Encoding:

0 0 1 1 0 0 1 0

(PC

15-8

)

((SP))

(SP)

(SP) – 1

(PC

7-0

)

(SP)

((SP))

(SP) – 1

Page 122 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

RL A

Handshake Solutions

Description: The eight bits in the Accumulator are rotated one bit to the left. Bit 7 is rotated into the bit 0 position. No flags are affected.

RL A leaves the Accumulator holding the value 8BH (10001011B) with the carry unaffected.

Encoding:

0 0 1 0 0 0 1 1

(A n+1

)

(A n

), n = 0 – 6

(A0)

(A7)

RLC A

Description: The eight bits in the Accumulator and the carry flag are together rotated one bit to the left. Bit 7 moves into the carry flag; the original state of the carry flag moves into the bit 0 position. No other flags are affected.

RLC A leaves the Accumulator holding the value 8AH (10001010B) with the carry set.

Encoding:

0 0 1 1 0 0 1 1

(A n+1

)

(A n

), n = 0 – 6

(A0)

(C)

(C)

(A7)

© Philips Electronics N.V. 2005 Page 123 of 132

Handshake Solutions

RR A

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: The eight bits in the Accumulator are rotated one bit to the right. Bit 0 is rotated into the bit 7 position. No flags are affected.

RR A leaves the Accumulator holding the value 0E2H (11100010B) with the carry unaffected.

Encoding:

0 0 0 0 0 0 1 1

(A n

)

(A7)

(A n+1

), n = 0 – 6

(A0)

RRC A

Description: The eight bits in the Accumulator and the carry flag are together rotated one bit to the right. Bit 0 moves into the carry flag; the original state of the carry flag moves into the bit 7 position. No other flags are affected.

RRC A leaves the Accumulator holding the value 62 (01100010B) with the carry set.

Encoding:

0 0 0 1 0 0 1 1

(A n

)

(A n+1

), n = 0 – 6

(A7)

(C)

(C)

(A0)

Page 124 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

SETB <bit>

Handshake Solutions

Description: SETB sets the indicated bit to one. SETB can operate on the carry flag or any directly addressable bit. No other flags are affected. instructions,

SETB C

SETB P1.0 will leave the carry flag set to 1 and change the data output on Port 1 to 35H (00110101B).

SETB C

Encoding:

1 1 0 1 0 0 1 1

(C)

1

SETB bit

Encoding:

1 1 0 1 0 0 1 0 bit

(bit)

1

SJMP rel

Description: Program control branches unconditionally to the address indicated. The branch destination is computed by adding the signed displacement in the second instruction byte to the PC, after incrementing the PC twice. Therefore, the range of destinations allowed is from 128 bytes preceding this instruction to 127 bytes following it. struction,

SJMP RELADR will assemble into location 0100H. After the instruction is executed, the PC will contain the value

0123H. ( Note: Under the above conditions the instruction following SJMP will be at 102H. Therefore, the displacement byte of the instruction will be the relative offset (0123H-0102H) = 21H. Put another way, an SJMP with a displacement of 0FEH would be a one-instruction infinite loop.)

Encoding:

1 0 0 0 0 0 0 0 rel.

(PC)

(PC) + 2

(PC)

(PC) + rel

© Philips Electronics N.V. 2005 Page 125 of 132

Handshake Solutions

SUBB A, <src-byte>

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: SUBB subtracts the indicated variable and the carry flag together from the Accumulator, leaving the result in the Accumulator. SUBB sets the carry (borrow) flag if a borrow is needed for bit 7, and clears C otherwise. (If C was set before executing a SUBB instruction, this indicates that a borrow was needed for the previous step in a multiple precision subtraction, so the carry is subtracted from the Accumulator along with the source operand.) AC is set if a borrow is needed for bit 3, and cleared otherwise. OV is set if a borrow is needed into bit 6, but not into bit 7, or into bit

7, but not bit 6. When subtracting signed integers OV indicates a negative number produced when a negative value is subtracted from a positive value, or a positive result when a positive number is subtracted from a negative number.

The source operand allows four addressing modes: register, direct, register-indirect, or immediate.

SUBB A,Rn

is set. The instruction,

SUBB A,R2 will leave the value 74H (01110100B) in the Accumulator, with the carry flag and AC cleared but

OV set. Notice that 0C9H minus 54H is 75H. The difference between this and the above result is due to the carry (borrow) flag being set before the operation. If the state of the carry is not known before starting a single or multiple-precision subtraction, it should be explicitly cleared by a CLR C instruction.

Encoding:

1 0 0 1 1 r r r

SUBB A,direct

(A)

(A) – (C) – (R n

)

Encoding:

SUBB A,@Ri

(A)

(A) – (C) – (direct)

Encoding:

1 0 0 1 0 1 1 i

SUBB A,#data

(A)

(A) – (C) – (R i

)

Encoding:

Page 126 of 132

(A)

(A) – (C) – (#data)

© Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

SWAP A

Handshake Solutions

Description: SWAP A interchanges the low- and high-order nibbles (four-bit fields) of the Accumulator (bits 3-0 and bits 7-4). The operation can also be thought of as a four-bit rotate instruction. No flags are affected.

SWAP A leaves the Accumulator holding the value 5CH (01011100B).

Encoding:

1 1 0 0 0 1 0 0

XCH A,<byte>

(A

3-0

)

↔ (A

7-4

)

Description: XCH loads the Accumulator with the contents of the indicated variable, at the same time writing the original Accumulator contents to the indicated variable. The source/destination operand can use register, direct, or register-indirect addressing. location 20H holds the value 75H (01110101B). The instruction,

XCH A,@R0 will leave the RAM location 20H holding the values 3FH (00111111B) and 75H (01110101B) in the Accumulator.

XCH A,Rn

Encoding:

1 1 0 0 1 r r r

XCH A,direct

(A)

↔ (R n

)

Encoding:

(A)

↔ (direct)

XCH A,@Ri

Encoding:

1 1 0 0 0 1 1 i

(A)

↔ ((R i

))

© Philips Electronics N.V. 2005 Page 127 of 132

Handshake Solutions

XCHD A,@Ri

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

Description: XCHD exchanges the low-order nibble of the Accumulator (bits 3-0), generally representing a hexadecimal or BCD digit, with that of the internal RAM location indirectly addressed by the specified register. The high-order nibbles (bits 7-4) of each register are not affected. No flags are affected. location 20H holds the value 75H (01110101B). The instruction,

XCHD A,@R0 will leave RAM location 20H holding the value 76H (01110110B) and 35H (00110101B) in the Accumulator.

Encoding:

1 1 0 1 0 1 1 i

(A

3-0

)

↔ ((Ri

3-0

))

XRL <dest-byte>,<src-byte>

Description: XRL performs the bitwise logical Exclusive-OR operation between the indicated variables, storing the results in the destination. No flags are affected.

The two operands allow six addressing mode combinations. When the destination is the Accumulator, the source can use register, direct, register-indirect, or immediate addressing; when the destination is a direct address, the source can be the Accumulator or immediate data.

( Note: When this instruction is used to modify an output port, the value used as the original port data will be read from the output data latch, not the input pins.) instruction,

XRL A,R0 will leave the Accumulator holding the value 69H (01101001B).

When the destination is a directly addressed byte, this instruction can complement combinations of bits in any RAM location or hardware register. The pattern of bits to be complemented is then determined by a mask byte, either a constant contained in the instruction or a variable computed in the Accumulator at run-time. The instruction,

XRL P1,#00110001B will complement bits 5, 4, and 0 of output Port 1.

Page 128 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

80C51 Family Instruction Set – Instruction definitions

XRL A,Rn

Encoding:

0 1 1 0 1 r r r

XRL A,direct

(A)

(A)

(R n

)

Encoding:

XRL A,@Ri

(A)

(A)

(direct)

Encoding:

0 1 1 0 0 1 1 i

XRL A,#data

(A)

(A)

(R i

)

Encoding:

XRL direct,A

(A)

(A)

#data

Encoding:

(direct)

(direct)

(A)

XRL direct,#data

Encoding:

(direct)

(direct)

#data

© Philips Electronics N.V. 2005

Handshake Solutions

Page 129 of 132

Handshake Solutions

HT80C51 User Manual

List of Tables

Appendix

A1:

List of Tables

[Table 1] 80C51 SFR Reset Values................................................................................................. 18

[Table 2] Interrupt Signals, Vectors and Priorities. .......................................................................... 23

[Table 3] Timer 0 as a Timer............................................................................................................ 31

[Table 4] Timer 0 as a Counter ........................................................................................................ 31

[Table 5] Timer 1 as a Timer............................................................................................................ 32

[Table 6] Timer 1 as a Counter ........................................................................................................ 32

[Table 7] Timer 1 Generated Commonly Used Baud Rates ............................................................ 36

[Table 8] Serial Port Setup............................................................................................................... 40

[Table 9] Serial Clock Rates (needs update) ................................................................................... 57

[Table 10] Master Transmitter mode (not available for slave-only version)....................................... 65

[Table 11] Master Receiver Mode (not available for slave-only version)........................................... 66

[Table 12] Slave Receiver mode........................................................................................................ 68

[Table 13] Slave Transmitter mode.................................................................................................... 69

[Table 14] Miscellaneous States ........................................................................................................ 70

Page 130 of 132 © Philips Electronics N.V. 2005

HT80C51 User Manual

List of Figures

A2:

List of Figures

Handshake Solutions

[Figure 1] HT80C51 Architecture (CPU centered) .............................................................................. 7

[Figure 2] HT80C51 Achitecture.......................................................................................................... 8

[Figure 3] HT80C51 Memory Map....................................................................................................... 9

[Figure 4] Memory map of Internal Data ........................................................................................... 10

[Figure 5] Lower 128 bytes of RAM, direct and indirect addressing ................................................. 11

[Figure 6] SFR memory map............................................................................................................. 13

[Figure 7] Interrupt Response Timing Diagram................................................................................. 24

[Figure 8] Interrupt Sources From the Timers 0 and 1...................................................................... 28

[Figure 9] Timer/Counter mode 0: 13bit counter ............................................................................... 29

[Figure 10] Timer/counter Mode 2: 8bit auto-reload. ....................................................................... 30

[Figure 11] Timer/counter 0 mode 3: Two 8bit counters.................................................................. 30

[Figure 12] Block Diagram of Serial Interface in Mode 0 ................................................................. 37

[Figure 13] Block Diagram of Serial Interface in Mode 1, 2, and 3.................................................. 39

[Figure 14] Typical I

2

C Bus Configuration........................................................................................ 48

[Figure 15] Data Transfer on the I

2

C Bus ........................................................................................ 48

[Figure 16] I

2

C Bus Serial Interface Block Diagram......................................................................... 50

[Figure 17] Arbitration Procedure..................................................................................................... 51

[Figure 18] Serial Clock Synchronization......................................................................................... 52

[Figure 19] Serial Input/Output Configuration .................................................................................. 54

[Figure 20] Shift-in and Shift-out Timing .......................................................................................... 55

[Figure 21] Format and States in the Master Transmitter mode...................................................... 61

[Figure 22] Format and States in the Master Receiver Mode.......................................................... 62

[Figure 23] Format and States in the Slave Receiver mode............................................................ 63

[Figure 24] Format and States of the Slave Transmitter mode........................................................ 64

[Figure 25] Simultaneous Repeated START Conditions from 2 Masters ........................................ 71

[Figure 26] Forced Access to a Busy I2C Bus................................................................................. 72

[Figure 27] Recovering from a Bus Obstruction Caused by a Low Level on SDA .......................... 73

[Figure 28] SPI block diagram ......................................................................................................... 77

[Figure 29] Data Clock Timing Diagram........................................................................................... 78

[Figure 30] SPI Single Master Single Slave Configuration .............................................................. 79

[Figure 31] Functional Diagram of the T3 Watchdog Timer............................................................. 81

© Philips Electronics N.V. 2005 Page 131 of 132

Handshake Solutions

A3:

Document History

Date Author

17.3.2005 UK

22.3.2005 UK

Version-No

1.1

1.1.1

12.4.2005 UK

25.4.2005 UK

25.4.2005 UK

30.05.2005 CV, UK

27.6.2005 CV

1.3

1.4

1.5

1.6

1.7

Change Report

HT80C51 User Manual

Document History

HT80C51 block diagram added.

Initialization chapters for interrupt controller, timers 0/1 and

UART added.

Pins ExtInt0_n and ExtInt1_n used as external interupt inputs for the timers 0/1.

Clock input for timers and serial interfaces is the core clock

(pin CClk), now.

SFR XRAMP added.

Description of I

2

C interface added.

Names of pins adapted.

Description of SPI and DES added.

Block diagrams of HT80C51 changed.

Chapter about clocks added.

SFR map updated.

Reset values updated.

Option names added.

Description of SIO condensed.

Minor changes in description of SIO.

Description of DKEY for the DES changed.

Some typos removed.

Update of illustrations (Ch. 1-5.4 and 5.8-end) and formats.

Description of DES updated and extended.

Update of illustrations (Ch. 5.5, 5.6).

Update of figure 6 and table 7.

Page 132 of 132 © Philips Electronics N.V. 2005

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
