SDM-S95DR
It Displays
The Sony SDM-S95DR is designed for human performance™. Sony StylePro™ LCD’s are thoughtfully designed
to optimize comfort and enhance productivity with the ErgoStand™ design including digital and analog input.
These latest displays are customized to meet the demands of today’s office environments-all while remaining true
to the Sony® tradition of renowned quality, reliability and style.
O
O
O
O
O
O
O
O
Pass-through audio out
Convenient audio connection for headphones
that switches with PC input
5 Gamma presets
A greater ability to set proper tonal curve to
match the application
Auto-input sensing
Easy set up: connect and go without manually
switching inputs
VESA Wall Mount
Centered to allow for pivot/rotation
Tilt and Swivel
All models with a base-stand include a tilt and
wide 350° swivel
Streamlined profile
Space-efficient design keeps workspace looking
organized and clutter-free
ErgoBright™ technology
Optimizes brightness at the push of a button,
reducing eyestrain
Versatile and easy to use
Sony’s automatic image adjustment feature
optimizes your display’s performance instantly.
Macintosh® and PC compatible
SDM-S95DR
It Displays
specifications
Screen Size: 19.0"
Cable Management System: Yes
ErgoStand™ Design: Ergonomic Fixed Height
Kensington® Lock: Yes
On Screen Controls: Power, Menu, Contrast,
Brightness, Eco Mode, Color, Temperature,
Backlight, Auto Adjust, H/V Adjust, Phase,
Pitch, Reset, Gamma, Menu Lock, OSD
Position
Stand Swivel Range: 350º
Stand Tilt Range: -5° to +20°
Wall/Arm Mount: 100mm
Multiple Language Display: English, French,
Spanish, Italian, German, Japanese, Dutch,
Swedish, Russian, Chinese
Auto-Sensing Input: Yes
Color Systems: N/A
Mount Design: N/A
Remote Control: N/A
Analog Audio Input(s): 1 (Rear)
Analog Video Input(s): 1 (Rear) - Analog
(HD-15)
DVI Connection Input(s): 1 (Rear) - Digital
(DVI-D)
Headphone Output(s): 1 (Stereo minjack)
PC Audio Input(s): 1 (per input)
PC Video Input(s): 2 (1-DVI-D, 1-HD15)
Audio Pass-thru HPJ: Yes (Switched Audio)
Colors: 16.2 million
Luminance: 250cd/m²
Pixel Pitch: 0.294mm
Screen Treatment: Anti-Glare, Protective
Coating
Vertical Refresh Range: 48-75Hz
Horizontal Scan (KHz) for PC: 28-80KHz
Closed Caption Decoder: N/A
Contrast Ratio: 550:1
Display Resolution: 1280 x 1024
Display Response Time:8ms
Image Retention Protection: N/A
Viewing Angle: Horizontal: 160°, Vertical: 160°
Internal Power Supply: Yes
Power Consumption: Normal Operation: 50W
(max), Standard Operation: 38W (typical),
Active Off: 1W (max), Main Switch Off: 1W
Power Requirements: 100V - 240V AC,
50-60Hz
Emissions/Ergonomics: TCO'99
Energy Star® Compliant: Yes
Plug & Play: DDC/Ci
Safety Regulations: UL1950, CSA 22.2, EMI
CE, FCC Class B, IC Class B, CCC, C-Tick,
CB, CPA, FCC Class B, IC Class B, ECO Info
Extended Warranty: 4th and 5th year available
Limited Warranty: 3 years parts, 3 years labor,
3 years backlight
Operating System Compatibility: PC2001,
Windows® 98, 2000, NT, XP and
Macintosh®
Picture Modes: N/A
Color Temperature: 9300k, 6500k, 5000k
ErgoBright™ Technology: Yes
Panel Type: a-Si-TFT Active Matrix LCD Panel
Screen or Display Technology: LCD
Video Processing: N/A
Dimensions (Approx) Width: 16.3" (414mm)
Dimensions (Approx) Height: 17.3" (439mm)
Weight: 16.1 lbs; 11.5 lbs w/o base stand;
22.1 lbs packaged
Dimensions (WHD): 16.3" x 17.3" x 8.9";
16.5" x 13.7" x 2.7" w/o base stand
Supplied Accessories: CD-ROM User Manual
AC Power Cord
DVI-D Digital Cable
HD15 Video Signal Cable
Quick Setup Guide
Windows® & Macintosh® Utility Files
Warranty Card
service and warranty
Extended Warranty: 4th and 5th year available
Limited Warranty: 3 years parts, 3 years labor,
3 years backlight
©2005 Sony Electronics Inc.
Features and specifications are subject to change without notice. Non-metric weights and measures are approximate.
Sony and ErgoStand are trademarks of Sony. All other trademarks are property of their respective owners. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries. Macintosh is a registered trademarks of Apple Computer, Inc.
®
Sony Electronics Inc. • 16450 West Bernardo Drive • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com/businesssolutions
Last Updated 2005-10-18
