User`s Manual

WMC252-1W-1T-300

User Manual

P/N 1073055 • REV

A

• ISS 15OCT15

Copyright © 2015 United Technologies Corporation

Interlogix is part of UTC Building & Industrial Systems, Inc. a unit of United

Technologies Corporation. All rights reserved.

Trademarks and

The WMC252 Series name and logo are trademarks of United Technologies.

patents

Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.

Manufacturer Interlogix

3211 Progress Drive, Lincolnton, NC 28092 USA

Authorized EU manufacturing representative:

UTC Climate Controls & Security B.V.,

Kelvinstraat 7, 6003 DH Weert, Netherlands

Intended use

Use this product only for the purpose it was designed for; refer to the data sheet and user documentation for details. For the latest product information, contact your local supplier or visit us online at www.interlogix.com.

Certification

N4131

ACMA compliance

Notice! This is a Class B product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

European Union

2004/108/EC (EMC Directive): Hereby, UTC Building & Industrial Systems, Inc.

directives

declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his/her own expense. Any changes or modifications not expressly approved by UTC could void the user’s authority to operate this equipment under the rules and regulations of the FCC.

FCC Caution:

To assure continued compliance, (for example, use only shielded interface cables when connecting to computer or peripheral devices) any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference

(2) This device must accept any interference received, including interference that may cause undesired operation.

II

Federal Communication Commission (FCC) Radiation Exposure Statement

This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation.

CAUTION: Changes or modifications not expressly approved by UTC for compliance could void the user’s authority to operate the equipment.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy saving, please remove the DC-plug to disconnect the device from the power circuit. Without removing the DC-plug, the device still consumes power from the power circuit. In view of Saving the Energy, it is strongly suggested to remove the DC-plug for the device if this device is not intended to be active.

Canadian Compliance

This Class B digital apparatus meets all requirements of the Canadian Interference Causing

Equipment Regulations. Cet appareil numérique de la classe B respects toutes les exigences du

Règlement sur le matériel brouilleur du Canada.

Canada - Industry Canada (IC)

The wireless radio of this device complies with RSS 247 and RSS 102 of Industry Canada.

This Class B digital device complies with Canadian ICES-003 (NMB-003).

Cet appareil numérique de la classe B respects toutes les exigences du Règlement sur le matériel brouilleur du Canada.

This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the

following two conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that may cause undesired

operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d'en compromettre le fonctionnement.

WMC252-1W-1T-300 complies with IC requirements, IC: 20201-WMC252300.

III

This radio transmitter (IC: 20201-WMC252300) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

 Built-in 14dBi Dual-Polarization Antenna

Le présent émetteur radio (IC: 20201-WMC252300) a été approuvé par Industrie Canada pour

fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur .

Intégré 14dBi antenne double polarisation

LE-LAN devices shall contain instructions related to the restrictions mentioned in the above sections, namely that:

1. the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;

2. for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit;

3. for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate; and

4. the worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in Section 6.2.2(3) of RSS-247 shall be clearly indicated.

The maximum conducted output power shall not exceed 250 mW or 11 + 10 log

10

B, dBm, whichever is less. The power spectral density shall not exceed 11 dBm in any 1.0 MHz band.

The maximum e.i.r.p. shall not exceed 1.0 W or 17 + 10 log

10

B, dBm, whichever is less. B is the 99% emission bandwidth in megahertz. Note that devices with a maximum e.i.r.p. greater than 500 mW shall implement TPC in order to have the capability to operate at least 6 dB below the maximum permitted e.i.r.p. of 1 W.

2) Unwanted emission limits i) For devices with both operating frequencies and channel bandwidths contained within the band

5250-5350 MHz, the device shall comply with the following: a. All emissions outside the band 5250-5350 MHz shall not exceed -27 dBm/MHz e.i.r.p. if the equipment is intended for outdoor use; or b. All emissions outside the band 5150-5350 MHz shall not exceed -27 dBm/MHz e.i.r.p. and any emissions within the band 5150-5250 MHz shall meet the power spectral density limits of

Section 6.2.1

of RSS-247. The device shall be labelled “for indoor use only.”

IV

ii) For devices with operating frequencies in the band 5250-5350 MHz but having a channel bandwidth that overlaps the band 5150-5250 MHz, the devices’ unwanted emission shall not exceed

-27 dBm/MHz e.i.r.p. outside the band 5150-5350 MHz and its power shall comply with the spectral power density for operation within the band 5150-5250 MHz. The device shall be labelled “for indoor use only.”

3) Additional requirements

In addition to the above requirements, devices operating in the band 5250-5350 MHz with a maximum e.i.r.p. greater than 200 mW shall comply with the following e.i.r.p. at different elevations, where

θ is the angle above the local horizontal plane (of the Earth) as shown below:

1. -13 dBW/MHz for 0° ≤ θ < 8°

2. -

13 − 0.716 (θ-8) dBW/MHz for 8° ≤ θ < 40°

3. -

35.9 − 1.22 (θ-40) dBW/MHz for 40° ≤ θ ≤ 45°

4. -42 dBW/MHz for θ > 45°

The measurement procedure defined in Annex A of RSS-247 shall be used to verify the compliance to the e.i.r.p. at different elevations.

Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from UTC

Fire and Security.

UTC, reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of UTC to provide notification of such revision or change. UTC provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. UTC may make improvements or changes in the product(s) described in this manual at any time.

CAUTION: TO ENSURE REGULATORY COMPLIANCE, USE ONLY THE PROVIDED POWER AND

INTERFACE CABLES.

CAUTION: DO NOT OPEN THE UNIT. DO NOT PERFORM ANY SERVICING OTHER THAN THAT

CONTAINED IN THE INSTALLATION AND TROUBLESHOOTING INSTRUCTIONS. REFER ALL

SERVICING TO QUALIFIED SERVICE PERSONNEL.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN

PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and

Satellite Earth Station Equipment) as of April 8, 2000.

V

Safety

This equipment is designed with the utmost care for the safety of those who install and use it.

However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment.

Wireless LAN and your Health

The WMC252-1W-1T-300 like other radio devices, emits radio frequency electromagnetic energy, but operates within the guidelines found in radio frequency safety standards and recommendations.

Restrictions on Use of Wireless Devices

In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or responsible representatives of the organization. For example, these situations may include:

. Using wireless equipment in any environment where the risk of interference to other devices or services is perceived or identified as harmful.

If you are uncertain of the applicable policy for the use of wireless equipment in a specific organization or environment, you are encouraged to ask for authorization to use the device prior to turning on the equipment.

The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of the devices included with this product, or the substitution or attachment of connecting cables and equipment other than specified by the manufacturer. Correction of interference caused by such unauthorized modification, substitution, or attachment is the responsibility of the user.

The manufacturer and its authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from failing to comply with these guideline documentation that comes with the product.

Postpone router installation until there is no risk of thunderstorm or lightning activity in the area.

Do not overload outlets or extension cords, as this can result in a risk of fire or electric shock.

Overloaded AC outlets, extension cords, frayed power cords, damaged or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or fire hazard.

Route power supply cords so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords where they are attached to plugs and convenience receptacles, and examine the point where they exit from the product.

Place this equipment in a location that is close enough to an electrical outlet to accommodate the length of the power cord.

Place this equipment on a stable surface.

When using this device, basic safety precautions should always be followed to reduce the risk of fire,

electric shock and injury to persons, including the following:

VI

. Read all of the instructions {listed here and/or in the user manual} before you operate this equipment.

Give particular attention to all safety precautions.

Retain the instructions for future reference.

. Comply with all warning and caution statements in the instructions. Observe all warning and caution symbols that are affixed to this equipment.

. Comply with all instructions that accompany this equipment.

. Avoid using this product during an electrical storm. There may be a risk of electric shock from lightning. For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet, and disconnect the cable system.

This will prevent damage to the product due to lightning and power surges. We also recommend the use of ESP300 20Kv protection on the input at the switch or network.

. Operate this product only from the type of power source indicated on the product’s marking label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

. Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in safe operating condition.

It is recommended that the customer install an AC surge protector in the AC outlet to which this device is connected. This is to avoid damaging the equipment by local lightning strikes and other electrical surges.

Different types of cord sets may be used for connections to the main supply circuit. Use only a main

line cord that complies with all applicable product safety requirements of the country of use. Installation of this product must be in accordance with national wiring codes.

Place unit to allow for easy access when disconnecting the power cord/adapter of the device from the

AC wall outlet.

Wipe the unit with a clean, dry cloth. Never use cleaning fluid or similar chemicals. Do not spray cleaners directly on the unit or use forced air to remove dust.

This product was qualified under test conditions that included the use of the supplied cables between system components. To be in compliance with regulations, the user must use these cables and install them properly. Connect the unit to a grounding type AC wall outlet using the power adapter supplied with the unit.

Do not cover the device, or block the airflow to the device with any other objects. Keep the device away from excessive heat and humidity and keep the device free from vibration and dust.

Installation must at all times conform to local regulations

VII

National Restrictions

This device is intended for home and office use in all EU countries (and other countries following the

EU directive 1999/5/EC) without any limitation except for the countries mentioned below:

Country

Bulgaria

France

Italy

Luxembourg

Norway

Restriction Reasons/remarks

None

General authorization required for outdoor use and public service

Outdoor use; limited to 10 mW e.i.r.p. within the

GHz band has been ongoing in recent years to allow current relaxed regulation. Full band 2454-2483.5 MHz

Military Radiolocation use. Reframing of the 2.4 implementation planned 2012

None

None

If used outside of own premises, general authorization is required

General authorization required for network and service supply(not for spectrum)

Implemented

None

This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Ålesund

Only for indoor applications Russian

Federation

Note: Please don’t use the product outdoors in France.

WEEE regulation

To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately.

Contact Information For contact information, see www.interlogix.com

or www.utcfssecurityproducts.eu

.

VIII

CONTENTS

Chapter 1.Product Introduction ......................................................................................................... 13

1.1

Package Contents ............................................................................................................. 13

1.2

Product Description .......................................................................................................... 14

1.3

Product Features ............................................................................................................... 15

1.4

Product Specifications ..................................................................................................... 16

Chapter 2.Hardware Installation ........................................................................................................ 19

2.1

Hardware Description ....................................................................................................... 19

2.1.1

The Bottom Panel – Port ........................................................................................ 20

Chapter 3.Connecting to the AP ........................................................................................................ 23

3.1

Preparation before Installation ........................................................................................ 23

3.1.1

Professional Installation Required .......................................................................... 23

3.1.2

Safety Precautions .................................................................................................. 23

3.2

Installation Precautions .................................................................................................... 23

3.3

Installing the AP ................................................................................................................ 25

3.4

Standard Pole Mounting ................................................................................................... 26

Chapter 4.Quick Installation Guide ................................................................................................... 27

4.1

Manual Network Setup - TCP/IP Configuration .............................................................. 27

4.1.1

Configuring the IP Address Manually ..................................................................... 27

4.2

Starting Setup in the Web UI ............................................................................................ 30

Chapter 5.Configuring the AP ............................................................................................................ 33

5.1

Operation Mode ................................................................................................................. 33

5.1.1

Access Point ........................................................................................................... 33

5.1.2

Client ....................................................................................................................... 35

5.1.3

WDS AP .................................................................................................................. 36

5.1.4

WDS Client ............................................................................................................. 37

5.1.5

AP Router ............................................................................................................... 38

5.1.6

Wireless ISP ........................................................................................................... 39

5.1.7

Security Setting ....................................................................................................... 40

5.1.8

Advanced Settings .................................................................................................. 45

5.1.9

Access Control ........................................................................................................ 48

5.1.10

WAN Port Settings .................................................................................................. 49

5.1.11

Dynamic DNS Settings ........................................................................................... 51

5.1.12

Remote Management ............................................................................................. 54

5.1.13

DHCP Server Settings ............................................................................................ 54

IX

5.1.14

DMZ Settings .......................................................................................................... 55

5.1.15

Virtual Server Settings ............................................................................................ 56

5.1.16

IP Filtering Settings ................................................................................................. 56

5.1.17

Port Filtering Settings ............................................................................................. 57

5.1.18

MAC Filtering Settings ............................................................................................ 58

5.1.19

Bandwidth Control .................................................................................................. 58

5.1.20

SNMP...................................................................................................................... 59

5.2

System Configuration ....................................................................................................... 60

5.2.1

Default IP Settings .................................................................................................. 60

5.2.2

Time Settings .......................................................................................................... 61

5.2.3

Password Settings .................................................................................................. 61

5.2.4

System Management .............................................................................................. 62

5.2.5

Ping Watchdog ........................................................................................................ 63

5.2.6

Firmware Upgrade .................................................................................................. 64

5.2.7

Configuration Save and Restore ............................................................................ 64

5.2.8

Factory Default ....................................................................................................... 65

5.2.9

Reboot System ....................................................................................................... 65

5.2.10

Schedule Reboot .................................................................................................... 65

5.3

Tools ................................................................................................................................... 68

5.3.1

Network Ping .......................................................................................................... 68

5.3.2

Network Traceroute ................................................................................................ 68

5.4

Device Status ..................................................................................................................... 70

5.4.1

Device Information .................................................................................................. 70

5.4.2

Wireless Information ............................................................................................... 71

5.4.3

LAN Information ...................................................................................................... 72

5.4.4

Wireless Client Table .............................................................................................. 73

5.4.5

System Log ............................................................................................................. 73

5.5

Logout ................................................................................................................................ 75

Appendix A: Troubleshooting ............................................................................................................ 76

Appendix B: FAQ ................................................................................................................................. 78

Q1: How to set up the AP Client Connection ........................................................................... 78

Q2: How to set up the WDS Connection .................................................................................. 86

X

FIGURES

F

IGURE

2-1

T

HREE

-

WAY

V

IEW

.................................................................................................................. 19

F

IGURE

2-2

LED ..................................................................................................................................... 20

F

IGURE

2-3

B

OTTOM

P

ANEL

..................................................................................................................... 21

F

IGURE

2-4

P

O

E I

NJECTOR

...................................................................................................................... 21

F

IGURE

3-1

C

ONNECT THE

A

NTENNA

........................................................................................................ 25

F

IGURE

3-2

C

ONNECT THE

E

THERNET CABLE

............................................................................................ 25

F

IGURE

3-3

C

ONNECT THE

P

O

E

INJECTOR

................................................................................................ 26

F

IGURE

3-4

P

OLE

M

OUNTING

................................................................................................................... 26

F

IGURE

4-1

TCP/IP S

ETTING

................................................................................................................... 28

F

IGURE

4-2

W

INDOWS

S

TART

M

ENU

........................................................................................................ 29

F

IGURE

4-3

S

UCCESSFUL RESULT OF

P

ING COMMAND

............................................................................... 29

F

IGURE

4-4

F

AILED RESULT OF

P

ING COMMAND

......................................................................................... 30

F

IGURE

4-5

L

OGIN BY DEFAULT

IP

ADDRESS

.............................................................................................. 30

F

IGURE

4-6

L

OGIN

W

INDOW

..................................................................................................................... 31

F

IGURE

4-7

WMC252-300 W

EB

UI S

CREENSHOT

.................................................................................... 31

F

IGURE

4-8

C

HOOSE

O

PERATION

M

ODE

................................................................................................... 32

F

IGURE

4-9

C

ONFIGURE

W

IRELESS

S

ETTINGS

.......................................................................................... 32

F

IGURE

5-1

M

AIN

M

ENU

.......................................................................................................................... 33

F

IGURE

5-2

O

PERATION

M

ODE

................................................................................................................. 33

F

IGURE

5-3

B

ASIC

S

ETTINGS

AP ............................................................................................................ 34

F

IGURE

5-4

B

ASIC

S

ETTINGS

C

LIENT

...................................................................................................... 35

F

IGURE

5-5

B

ASIC

S

ETTINGS

– WDS AP .................................................................................................. 37

F

IGURE

5-6

B

ASIC

S

ETTINGS

– WDS C

LIENT

............................................................................................ 37

F

IGURE

5-7

B

ASIC

S

ETTINGS

– AP R

OUTER

............................................................................................. 38

F

IGURE

5-8

B

ASIC

S

ETTINGS

– WISP ...................................................................................................... 39

F

IGURE

5-9

S

ECURITY

S

ETTINGS

............................................................................................................. 40

F

IGURE

5-10

S

ECURITY

S

ETTINGS

– WEP ............................................................................................... 41

F

IGURE

5-11

S

ECURITY

S

ETTINGS

– WPA P

ERSONAL

............................................................................... 41

F

IGURE

5-12

S

ECURITY

S

ETTINGS

– WPA E

NTERPRISE

............................................................................ 42

F

IGURE

5-13

S

ECURITY

S

ETTINGS

– WPA2 P

ERSONAL

............................................................................. 43

F

IGURE

5-14

S

ECURITY

S

ETTINGS

– WPA2 E

NTERPRISE

.......................................................................... 43

F

IGURE

5-15

S

ECURITY

S

ETTINGS

– WPA-M

IXED

P

ERSONAL

.................................................................... 44

F

IGURE

5-16

S

ECURITY

S

ETTINGS

– WPA-M

IXED

E

NTERPRISE

................................................................. 44

F

IGURE

5-17

A

DVANCED

S

ETTINGS

.......................................................................................................... 45

F

IGURE

5-18

WMM C

ONFIGURATION

....................................................................................................... 46

F

IGURE

5-19

A

CCESS

C

ONTROL

.............................................................................................................. 48

F

IGURE

5-20

WAN P

ORT

S

ETTINGS

– DHCP ........................................................................................... 49

F

IGURE

5-21

WAN P

ORT

S

ETTINGS

– S

TATIC

IP ....................................................................................... 49

F

IGURE

5-22

WAN P

ORT

S

ETTINGS

– PPPOE ......................................................................................... 50

XI

F

IGURE

5-23

D

YNAMIC

DNS S

ETTINGS

.................................................................................................... 51

F

IGURE

5-24

R

EMOTE

M

ANAGEMENT

....................................................................................................... 54

F

IGURE

5-25

DHCP S

ERVER

S

ETTINGS

................................................................................................... 54

F

IGURE

5-26

DMZ S

ETTINGS

................................................................................................................... 55

F

IGURE

5-27

V

IRTUAL

S

ERVER

S

ETTINGS

................................................................................................. 56

F

IGURE

5-28

IP F

ILTERING

S

ETTINGS

....................................................................................................... 57

F

IGURE

5-29

P

ORT

F

ILTERING

S

ETTINGS

.................................................................................................. 57

F

IGURE

5-30

M

AC

F

ILTERING

S

ETTINGS

................................................................................................... 58

F

IGURE

5-31

B

ANDWIDTH

C

ONTROL

S

ETTINGS

......................................................................................... 58

F

IGURE

5-32

SNMP S

ETTINGS

................................................................................................................ 59

F

IGURE

5-33

S

YSTEM

C

ONFIGURATION DEFAULT PAGE

.............................................................................. 60

F

IGURE

5-34

D

EFAULT

IP S

ETTINGS

......................................................................................................... 60

F

IGURE

5-35

T

IME

S

ETTINGS

................................................................................................................... 61

F

IGURE

5-36

P

ASSWORD

S

ETTINGS

......................................................................................................... 62

F

IGURE

5-37

S

YSTEM

M

ANAGEMENT

........................................................................................................ 62

F

IGURE

5-38

P

ING

W

ATCHDOG

................................................................................................................ 63

F

IGURE

5-39

F

IRMWARE

U

PGRADE

.......................................................................................................... 64

F

IGURE

5-40

C

ONFIGURATION

S

AVE AND

R

ESTORE

................................................................................... 64

F

IGURE

5-41

F

ACTORY

D

EFAULT

.............................................................................................................. 65

F

IGURE

5-42

R

EBOOT

S

YSTEM

................................................................................................................ 65

F

IGURE

5-43

S

CHEDULE

R

EBOOT

............................................................................................................ 66

F

IGURE

5-44

S

CHEDULE

R

EBOOT

E

XAMPLE

........................................................................................... 67

F

IGURE

5-45

N

ETWORK

P

ING

.................................................................................................................. 68

F

IGURE

5-46

N

ETWORK

T

RACEROUTE

...................................................................................................... 69

F

IGURE

5-47

D

EVICE

S

TATUS

................................................................................................................... 70

F

IGURE

5-48

D

EVICE

I

NFORMATION

.......................................................................................................... 70

F

IGURE

5-49

W

IRELESS

I

NFORMATION

..................................................................................................... 71

F

IGURE

5-50

LAN I

NFORMATION

.............................................................................................................. 72

F

IGURE

5-51

W

IRELESS

C

LIENT

T

ABLE

..................................................................................................... 73

F

IGURE

5-52

S

YSTEM

L

OG

...................................................................................................................... 74

F

IGURE

5-53

L

OGOUT

.............................................................................................................................. 75

F

IGURE

5-54

R

E

-

LOGIN

........................................................................................................................... 75

XII

Chapter 1. Product Introduction

1.1 Package Contents

Thank you for choosing IFS WMC252-1W-1T-300. Before installing the AP, please verify the contents inside the package box.

WMC252-1W-1T-300 Quick Installation Guide

PoE Injector & Power Cord Plastic Strap x 1

If there is any item missing or damaged, please contact the seller immediately.

-13-

1.2 Product Description

IFS WMC252-300 Wireless Outdoor Access Point provides a higher transmission speed, higher power and better performance designed for outdoor wireless application.

Faster Speed and longer Distance

Adopting the IEEE 802.11n advanced 2T2R MIMO technology; the WMC252-300 provides high speed, reliable wireless network coverage, and incredible improvement in the wireless performance. As an IEEE 802.11a/n compliant wireless device, the WMC252-300 is able to give stable and efficient wireless performance for long distance application. Thus, it delivers a data rate of up to 300Mbps three times faster than the normal 802.11a wireless device. With its adjustable output power up to 500mW, it can extend the coverage of an outdoor area.

Multiple Operation and Wireless Modes

The WMC252-300 supports multiple wireless communication connectivity’s (AP, Client CPE, WDS PtP, WDS

PtMP and WISP), meeting user’s application requirements. It also helps user to easily extend the existing wireless network.

Advanced Wireless Security

In aspect of security, besides 64/128- bit WEP encryption, the WMC252-300 is integrated with WPA / WPA2,

WPA-PSK / WPA2-PSK and 802.1x authority to secure and protect your wireless LAN. The wireless MAC filtering and SSID broadcast help to consolidate the wireless network security and prevent unauthorized wireless connection.

Perfect Solution for Outdoor Environment

The WMC252-300 is perfectly suitable to be installed in outdoor environments. With its IP55 casing protection, the WMC252-300 can perform normally under rigorous weather conditions including heavy rain and wind.

With the passive Power over Ethernet (PoE) design, the WMC252-300 can be easily installed in the areas where power outlets are not available. Thus, the WMC252-300 is ideal for outdoor wireless access applications between buildings on campuses, and in business and rural areas.

Easy Installation and Management

With user-friendly Web UI and step by step Setup Wizard, user can set up a wireless network without any difficulty.

-14-

1.3 Product Features

Industrial Compliant Wireless LAN & LAN

Compliant with the IEEE 802.11n wireless technology (with data rate of up to 300Mbps)

Backward compatible with 802.11a standard

Equipped with 10/100Mbps RJ45 ports for LAN & WAN; auto MDI/ MDI-X supported

Fixed-network Broadband Router

Supported connection types: Dynamic IP, Static IP, PPPoE

Supports Virtual Server, DMZ for various networking applications

Supports DHCP Server, UPnP, Dynamic DNS

RF Interface Characteristics

Built-in 14dBi Dual-Polarization Antenna

High Output Power Up to 500mW with multiple adjustable transmit power control

Outdoor Environmental Characteristics

IP55 enclosure

Passive Power over Ethernet design

Operating temperature: -20~70°C

Multiple Operation and Wireless Modes

Multiple operation modes: Bridge, WISP

Multiple wireless modes: AP, Client CPE(WISP), WDS PtP, WDS PtMP

Supports multiple SSIDs to allow users to access different networks through a single AP

Supports WMM (Wi-Fi multimedia)

Secure Network Connection

Supports software Wi-Fi Protected Setup (WPS)

Advanced security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK(TKIP/AES) and 802.1x authentication

Supports IP / Protocol-based access control and MAC filtering

Easy Installation and Management

Web-based UI and quick Setup Wizard for easy configuration

SNMP-based management interface

System status monitoring includes DHCP Client, System Log

-15-

1.4 Product Specifications

Product

WMC252-1W-1T-300

300Mbps 802.11a/n Wireless Outdoor CPE

Hardware

Standard Support

Chipset

Memory

PoE

IEEE802.11a/n

IEEE 802.3

IEEE 802.3u

IEEE 802.3x

Atheros AR9344

64 Mbytes DDR SDRAM

16 Mbytes Flash

Passive PoE

Interface

Antenna

Data Rate

Wireless IEEE802.11a/n, 2T2R

PoE LAN (LAN 1): 1 x 10/100BASE-TX, auto-MDI/MDIX, passive PoE

LAN 2: 1 x 10/100BASE-TX, auto-MDI/MDIX, passive PoE out pass-through

Built-in 14dBi Dual-Polarization Antenna

- Horizontal: 30 degrees

- Vertical: 20 degrees

IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54Mbps

IEEE 802.11n (20MHz): up to 150Mbps

IEEE 802.11n (40MHz): up to 300Mbp

Media Access Control

CSMA/CA

Modulation

Frequency Band

Transmission/Emission type: OFDM

Data modulation type: OFDM with BPSK, QPSK, 16-QAM, 64-QAM

5.180GHz ~ 5.825GHz

Operating Channel

5.180GHz

5.200GHz

5.220GHz

5.240GHz

5.260GHz

5.280GHz

5.300GHz

5.320GHz

CH36

CH40

CH44

CH48

CH52

CH56

CH60

CH64

5.580GHz

5.600GHz

5.620GHz

5.640GHz

5.660GHz

5.680GHz

5.700GHz

5.745GHz

CH116

CH120

CH124

CH128

CH132

CH136

CH140

CH149

5.500GHz

5.520GHz

5.540GHz

5.560GHz

CH100

CH104

CH108

CH112

5.765GHz

5.785GHz

5.805GHz

5.825GHz

CH153

CH157

CH161

CH165

*The 24 channels are defined by the theory. The actual application will vary based on the regulation in different regions and countries.

RF Output Power (dBm)

802.11a: up to 26 ± 1

-16-

802.11n: up to 25 ± 1

Receiver Sensitivity

(dBm)

802.11a: -94 dBm

802.11n: -93 dBm

Output Power Control

12~27dBm

Power Consumption

12W

LAN

Power Requirements

24VDC, 1A/ Passive PoE

Pin 4,5 VDC+

Pin 7,8 VDC-

Pin 3 Reset

Environment & Certification

Operating Temperature

-20~70°c

Operating Humidity

10~95% non-condensing

IP Level

IP55

Regulatory

Software

CE, FCC, RoHS

LAN

WAN

Operation Modes

Firewall

Wireless Modes

Channel Width

Wireless Isolation

Encryption Type

Built-in DHCP server supporting static IP address distribution

Support 802.1d STP (Spanning Tree)

 Static IP

 Dynamic IP

PPPoE

 Bridge

 WISP

NAT firewall with SPI (Stateful Packet Inspection)

Built-in NAT server supporting Virtual Server, and DMZ

Built-in firewall with Port/ IP address/ MAC/ URL filtering

 AP

 Client

 WDS PTP

 WDS PTMP

 WISP

20MHz / 40MHz

Enable it to isolate each connected wireless client so that they cannot access mutually.

64/128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 802.1X

Wireless Security

Provides wireless LAN ACL (Access Control List) filtering

Wireless MAC address filtering

Enable/Disable SSID Broadcast

Max. Wireless Clients

25

Max. WDS Peers

8

Max. Wired Clients

WMM

60

Supports Wi-Fi multimedia

-17-

QoS

NTP

Self Healing

Management

Diagnostic Tool

Supports Quality of Service for bandwidth control

Network Time Management

Supports Schedule Reboot

Web UI, DHCP Client, Configuration Backup & Restore, Dynamic DNS, SNMP

System Log, Ping Watchdog

-18-

Chapter 2. Hardware Installation

Please follow the instructions below to connect the WMC252-300 to the existing network devices and your computers.

2.1 Hardware Description

Dimensions: 127 x 63 x 254 mm (W x D x H)

Appearance

Figure 2-1 Three-way View

-19-

Rear Panel – LED

Figure 2-2 LED

LED Definition

LED

Power

Signal Indicator

(Client Mode)

LAN 1

LAN 2

Off

On

Off

On

Off

State

On

Off

On

Meaning

System On

System Off

Indicates the wireless signal strength of remote AP

No remote wireless signal

Port linked.

No link.

Port linked.

No link.

Table 2-1 The LED indication

2.1.1 The Bottom Panel – Port

The Bottom panel provides the physical connectors connected to the power adapter and any other network device.

Figure 2-3

shows the bottom panel of the WMC252-300.

-20-

Bottom Panel

Figure 2-3 Bottom Panel

PoE Injector

Reset Button

H/W Interface Definition

Object

PoE LAN

(Passive PoE)

LAN 2

Figure 2-4 PoE Injector

Description

10/100Mbps RJ45 port , auto MDI/ MDI-X and passive PoE supported

Connect LAN port to the PoE injector to power on the device.

Pin assignment:

Pin 4, 5 (+)

Pin 7, 8 (-)

Pin 3 (Reset)

10/100Mbps RJ45 port , auto MDI/ MDI-X

Connect this port to the network equipment.

When the option “Enable POE Pass Through” on the System

Management page is checked, the LAN2 can supply passive PoE power to the second WMC252-300 or WMC252-300 through LAN 2.

-21-

Reset

Press the Reset button on the device or on the PoE injector over 5 seconds to return to factory default setting.

If you have connected with the ESP300, please DO NOT press the

reset button on the PoE injector to prevent the ESP300 from being damaged.

Table 2-2 The PoE Injector Indication

-22-

Chapter 3. Connecting to the AP

3.1 Preparation before Installation

3.1.1 Professional Installation Required

Please seek assistance from a professional installer who is well trained in the RF installation and knowledgeable in the local regulations.

3.1.2 Safety Precautions

1. To keep you safe and install the hardware properly, please read and follow these safety precautions.

2. If you are installing the WMC252-300 for the first time, for your safety as well as others’, please seek assistance from a professional installer who has received safety training on the hazards involved.

3. Keep safety as well as performance in mind when selecting your installation site, especially where there are electric power and phone lines.

4. When installing the WMC252-300, please note the following things:

Do not use a metal ladder;

Do not work on a wet or windy day;

Wear shoes with rubber soles and heels, rubber gloves, long sleeved shirt or jacket.

5. When the system is operational, avoid standing directly in front of it. Strong RF fields are present when the transmitter is on.

3.2 Installation Precautions

 Users MUST use a proper and well-installed surge arrestor and grounding kit with the WMC252-300; otherwise, a random lightning could easily cause fatal damage to the WMC252-300. (Lightning

DAMAGE IS NOT COVERED UNDER WARRANTY).

 Users MUST use the “Power cord and PoE Injector” shipped in the box with the WMC252-300. Use of other options will cause damage to the WMC252-300.

-23-

OUTDOOR INSTALLATION WARNING

!

IMPORTANT SAFETY PRECAUTIONS:

LIVES MAY BE AT RISK! Carefully observe these instructions and any special instructions that are included with the equipment you are installing.

CONTACTING POWER LINES CAN BE LETHAL. Make sure no power lines are anywhere where possible contact can be made. Antennas, masts, towers, guy wires or cables may lean or fall and contact these lines. People may be injured or killed if they are touching or holding any part of equipment when it contacts electric lines. Make sure that equipment or personnel do not come in contact directly or indirectly with power lines.

The horizontal distance from a tower, mast or antenna to the nearest power line should be at least twice the total length of the mast/antenna combination. This will ensure that the mast will not contact power if it falls either during installation or later.

TO AVOID FALLING, USE SAFE PROCEDURES WHEN WORKING AT HEIGHTS ABOVE GROUND.

Select equipment locations that will allow safe, simple equipment installation.

Don’t work alone. A friend or co-worker can save your life if an accident happens.

Use approved non-conducting lasers and other safety equipment. Make sure all equipment is in good repair.

If a tower or mast begins falling, don’t attempt to catch it. Stand back and let it fall.

If anything such as a wire or mast does come in contact with a power line, DON’T TOUCH IT OR ATTEMPT TO

MOVE IT. Instead, save your life by calling the power company.

Don’t attempt to erect antennas or towers on windy days.

MAKE SURE ALL TOWERS AND MASTS ARE SECURELY GROUNDED, AND ELECTRICAL CABLES CONNECTED TO

ANTENNAS HAVE LIGHTNING ARRESTORS. This will help prevent fire damage or human injury in case of lightning, static build-up, or short circuit within equipment connected to the antenna.

The base of the antenna mast or tower must be connected directly to the building protective ground or to one or more approved grounding rods, using 1 OAWG ground wire and corrosion-resistant connectors.

Refer to the National Electrical Code for grounding details.

IF A PERSON COMES IN CONTACT WITH ELECTRICAL POWER, AND CANNOT MOVE:

DON’T TOUCH THAT PERSON, OR YOU MAY BE ELECTROCUTED.

Use a non-conductive dry board, stick or rope to push or drag them so they no longer are in contact with electrical power.

Once they are no longer contacting electrical power, administer CPR if you are certified, and make sure that emergency medical aid has been requested.

-24-

3.3 Installing the AP

Please install the AP according to the following steps. Don't forget to pull out the power plug and keep your hands dry.

Step 1. Push the latch in the bottom of the WMC252-300 to remove the sliding cover.

Figure 3-1 Connect the Antenna

Step 2. Plug the RJ45 Ethernet cable into the PoE LAN Port of the WMC252-300.

Figure 3-2 Connect the Ethernet cable

-25-

Step 3.

Plug the power cord into the DC port and the other end into the AC socket. Then, plug the RJ45 cable

(as shown in picture 4 under Step 1) into the POE port of the PoE injector.

Figure 3-3 Connect the PoE injector

3.4 Standard Pole Mounting

Place the strap through the slots on the back of the WMC252-300 and then around the pole. Tighten the strap to secure the WMC252-300.

Figure 3-4 Pole Mounting

-26-

Chapter 4. Quick Installation Guide

This chapter will show you how to configure the basic functions of your AP within minutes.

A computer with wired Ethernet connection to the Wireless AP is required for the first-time configuration.

4.1 Manual Network Setup - TCP/IP Configuration

The default IP address of the WMC252-300 is

192.168.0.100

. And the default Subnet Mask is 255.255.255.0.

These values can be changed as you desire. In this guide, we use all the default values for description.

Connect the WMC252-300 with your PC via an Ethernet cable which is then plugged into a LAN port of the PoE injector with one end and into a LAN port of the PC with the other end. Then power on the WMC252-300 via PoE injector or PoE switch.

In the following sections, we’ll introduce how to install and configure the TCP/IP correctly in Windows 7. And the procedures in other operating systems are similar. First, make sure your Ethernet adapter is working, and refer to the Ethernet adapter’s manual if needed.

4.1.1 Configuring the IP Address Manually

Summary:

 Set up the TCP/IP Protocol for your PC.

 Configure the network parameters. The IP address is 192.168.1.xxx ("xxx" is any number from 2 to

252), Subnet Mask is 255.255.255.0, and Gateway is 192.168.0.100 (The AP's default IP address)

1

Select Use the following IP address radio button.

2

If the AP's LAN IP address is 192.168.0.100, enter IP address 192.168.1.x (x is from 2 to 254), and Subnet

mask 255.255.255.0.

3 Select Use the following DNS server addresses radio button. In the Preferred DNS Server field, you can enter the DNS server IP address which has been provided by your ISP.

-27-

Figure 4-1 TCP/IP Setting

Now click OK to save your settings.

Now, you can run the ping command in the command prompt to verify the network connection between your

PC and the AP. The following example is in Windows 7 OS. Please follow the steps below:

1. Click on Start > Run.

2. Type “cmd” in the Search box.

-28-

Figure 4-2 Windows Start Menu

3. Open a command prompt and type ping 192.168.0.100, and then press Enter.

If the result displayed is similar to

Figure 4-3

, it means the connection between your PC and the AP has been established well.

Figure 4-3 Successful result of Ping command

-29-

If the result displayed is similar to

Figure 4-4

, it means the connection between your PC and the AP has failed.

Figure 4-4 Failed result of Ping command

If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your AP. Some firewall software programs may block a DHCP request on newly installed adapters.

4.2 Starting Setup in the Web UI

It is easy to configure and manage the WMC252-300 with the web browser.

Step 1.

To access the configuration page, open a web browser and enter the default IP address http://192.168.0.100 in the web address field of the browser.

Figure 4-5 Login by default IP address

After a moment, a login window will appear. Enter admin for the User Name and Password, both in lower case letters. Then click the OK button or press the Enter key.

-30-

Figure 4-6 Login Window

Default IP Address: 192.168.0.100

Default User Name: admin

Default Password: admin

If the above screen does not pop up, it may mean that your web browser has been set to a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it.

After entering the username and password, the Operation Mode page screen appears as in Figure 4-8

Figure 4-7 WMC252-300 Web UI Screenshot

Step 2.

You can choose an Operation Mode. Please refer to the instructions in the next chapter for configuring

-31-

the other Operation Modes.

Figure 4-8 Choose Operation Mode

Step 3.

Please enter the SSID and configure your Encryption Settings, Pre-Shared Key, etc. Then click the

Save button to make the configuration take effect immediately.

Figure 4-9 Configure Wireless Settings

-32-

Chapter 5. Configuring the AP

This chapter delivers a detailed presentation of AP’s functionalities and features under 4 main menus

(Operation Mode, System Configuration, Tools and Device Status) below, allowing you to manage the AP with ease.

Figure 5-1 Main Menu

5.1 Operation Mode

On this page, you can select different operation modes of the WMC252-300, including Access Point, Client,

WDS AP, WDS Client, AP Router and Wireless ISP.

Figure 5-2 Operation Modes

5.1.1 Access Point

Click “Operation Mode

 “Access Point” and the following page will be displayed. This section allows you to configure the Access Point mode.

-33-

Object

Regulatory Domain

Network SSID

Site Survey

Enable Wireless

Disable SSID Broadcasting

Figure 5-3 Basic Settings - AP

Description

Select your domain from the list.

It is the wireless network name. The default SSID is

WMC252-300.

Click “Site Survey” to check the signal of remote sites.

Check it to enable Wireless function.

Enable Isolated

Radio Mode

Channel

Data Rate

Security Setting

Transmit Power

Transmit Distance

TDMA

Check it to disable SSID broadcasting.

Check it to isolate each connected wireless client so that they cannot access each other.

Select the channel width to “Auto Select”, “5G 11NA HT20” or

5G 11NA HT40

Select the operating channel you would like to use. The channel range will be changed by selecting a different domain.

Select MCS0~15 or Auto from the pull-down menu. The default is

Auto”.

Press “Setup” for more configurations. Please refer to 5.1.7

Security Setting for more information.

The range of transmit power is “12~27 dbm”. In case of shortening the distance and the coverage of the wireless network, input a smaller value to reduce the radio transmission power.

Select a specified distance of the two nodes.

Displays the System Time.

-34-

Advanced Settings

Access Control

Press “Setup” for more configurations. Please refer to 5.1.8

Advanced Settings for more information.

Press “Setup” for more configurations. Please refer to 5.1.9

Access Control for more information.

5.1.2 Client

Click “Operation Mode

 “Client” and the following page will be displayed. This section allows you to configure the Client mode.

Figure 5-4 Basic Settings - Client

Description Object

Regulatory Domain

Network SSID

Select your domain from the list.

It is the wireless network name. The default SSID is

WMC252-300.

Click “Site Survey” to find the remote sites to associate.

Site Survey

Enable Wireless

Check it to enable Wireless function.

Disable SSID Broadcasting

Check it to disable SSID broadcasting.

Enable Isolated

Check it to isolate each connected wireless clients so that they cannot access each other.

-35-

Lock to AP MAC

Radio Mode

Data Rate

Security Setting

Transmit Power

Transmit Distance

TDMA

Advanced Settings

Access Control

Enter the Mac address of the remote AP.

Select the channel width to “Auto Select”, “5G 11NA HT20” or

5G 11NA HT40

Select MCS0~15 or Auto from the pull-down menu. The default is “Auto”.

Press “Setup” for more configurations. Please refer to 5.1.7

Security Setting for more information.

The range of transmit power is “12~27 dbm”. In case of shortening the distance and the coverage of the wireless network, input a smaller value to reduce the radio transmission power.

Select a specified distance of the two nodes.

Displays the System Time.

Press “Setup” for more configurations. Please refer to 5.1.8

Advanced Settings for more information.

Press “Setup” for more configurations. Please refer to 5.1.9

Access Control for more information.

5.1.3 WDS AP

Click “Operation Mode

 “WDS AP” and the following page will be displayed. This section allows you to configure the WDS AP mode. For each wireless parameter, please refer to section 5.1.1 AP for more information.

-36-

Figure 5-5 Basic Settings – WDS AP

5.1.4 WDS Client

Click “Operation Mode

 “WDS Client” and the following page will be displayed. This section allows you to configure the WDS Client mode. For each wireless parameter, please refer to section 5.1.2 Client for more information.

Figure 5-6 Basic Settings – WDS Client

-37-

5.1.5 AP Router

Click “Operation Mode

 “AP Router” and the following page will be displayed. This section allows you to configure the AP Router mode.

Figure 5-7 Basic Settings – AP Router

-38-

5.1.6 Wireless ISP

Click “Operation Mode

 “Wireless ISP” and the following page will be displayed. This section allows you to configure the Wireless ISP mode.

Figure 5-8 Basic Settings – WISP

-39-

5.1.7 Security Setting

Choose the operation mode you required, and then enter “Security Setting” by clicking the Setup button next to it and the following page will be displayed. This section allows you to configure the wireless security settings.

Figure 5-9 Security Settings

Object

Select Encryption

Description

Select the encryption that you need.

None: No security required

WEP: Input 5, 13 (ASCII) or 10, 26 (HEX) character for

WEP key.

WPA: Enter ASCII characters between 8 and 63 character or 8 to 64 hexadecimal characters.

WPA2: Enter ASCII characters between 8 and 63 character or 8 to 64 hexadecimal characters.

WPA-Mixed: Enter ASCII characters between 8 and 63 character or 8 to 64 hexadecimal characters.

None

Authentication is disabled and no password/key is required to connect to the access point.

WEP

WEP (Wired Equivalent Privacy) is a basic encryption. For a higher level of security consider using the WPA encryption.

-40-

Figure 5-10 Security Settings – WEP

Object

Authentication

Key Length

Key Format

Encryption Key

WPA

Description

You can select Open System, Shared Key or Auto.

Choose the WEP key length. You can choose 64-bit or 128-bit.

You can choose ASCII or Hex.

Enter the keys in the fields.

Figure 5-11 Security Settings – WPA Personal

-41-

Figure 5-12 Security Settings – WPA Enterprise

Object

Encryption Type

Description

Pre-Authentication

Select “Personal (Pre-Shared Key)” or “Enterprise (RADIUS)” encryption type.

Set the WPA to be TKIP, AES or Auto.

Pre-Shared Key

Enter the keys in the fields.

WPA2

RADIU Server IP

Enter the RADIUS server host IP address.

Address

Set the UDP port used in the authentication protocol of the RADIUS

RADIU Server Port server. Value must be between 1 and 65535.

RADIU Server

Enter a shared secret/password between 1 and 99 characters in length.

Password

EAP

Reauthorization

Set duration of session timeout in seconds between 300 and 3600.

Period

RSN

Enable or disable RSN reauthorization.

Reauthorization

WPA Group

Set duration of session timeout in seconds between 300 and 3600.

Re-key Interval

-42-

Please refer to WPA for more information.

Figure 5-13 Security Settings – WPA2 Personal

Figure 5-14 Security Settings – WPA2 Enterprise

-43-

WPA-Mixed

Please refer to WPA for more information.

Figure 5-15 Security Settings – WPA-Mixed Personal

Figure 5-16 Security Settings – WPA-Mixed Enterprise

-44-

5.1.8 Advanced Settings

Choose the operation mode you require, and then enter “Advanced Settings” by clicking the Setup button next to it and the following page will be displayed. This section allows you to configure the wireless advanced settings.

Object

RTS/CTS

Threshold

Beacon Interval

DTIM

Fragment Size

Figure 5-17 Advanced Settings

Description

When the length of a data packet exceeds this value, the router will send an RTS frame to the destination wireless node, and the latter will reply with a CTS frame, and thus they are ready to communicate. The default value is 2347.

Set beacon interval, the value range is from 20 to 999. The default value is 100.

Set the DTIM (delivery traffic indication message) period value of the wireless radio. The default value is 1.

A data packet that exceeds this value in length will be divided into multiple packets. The number of packets influences wireless network performance. Avoid setting this value low. Default at 2346.

-45-

Short GI

Aggregation

Guard intervals are used to ensure that distinct transmissions do not interfere with one another. Only effect under Mixed Mode.

A part of the 802.11n standard that allows sending multiple frames per single access to the medium by combining frames together into one larger frame. It creates the larger frame by combining smaller frames with the same physical source, destination end points, and traffic class

(QoS) into one large frame with a common MAC header

Determines the number of frames combined in the new larger frame.

Aggregated

Frames Number

Maximum

Aggregated Size

Determines the size (in bytes) of the larger frame.

Tx ChainMask

Rx ChainMask

WMM Capable

Displays the number of independent spatial data streams the device is transmitting (TX) and receiving (RX) simultaneously within one spectral channel of bandwidth. Multiple chains increase data transfer performance significantly.

Displays the number of independent spatial data streams the device is transmitting (TX) and receiving (RX) simultaneously within one spectral channel of bandwidth. Multiple chains increase data transfer performance significantly.

Wi-Fi Multimedia (WMM) is a Wi-Fi Alliance interoperability certification based on the IEEE 802.11e standard, which provides Quality of Service

(QoS) features to IEE 802.11 networks. WMM prioritizes traffic according to four categories: background, best effort, video and voice.

Figure 5-18 WMM Configuration

-46-

WMM Capable

BE

BK

VI

VO

AIFS, Interlogixn

CWMin

CWMax

Txop

Traditional IP data, medium throughput and delay.

High throughput, non time sensitive bulk data e.g. FTP

Time sensitive video data with minimum time delay.

Time sensitive data such as VoIP and streaming media with minimum time delay.

Arbitration Inter-Frame Space (milliseconds): Specifies additional time between when a channel goes idle and the

AP/client sends data frames. Traffic with a lower AIFS,

INTERLOGIXN value has a higher priority.

Maximum Contention Window (milliseconds): This value is the upper limit to random backoff value doubling (see above).

Arbitration Inter-Frame Space (milliseconds): Specifies additional time between when a channel goes idle and the

AP/client sends data frames. Traffic with a lower AIFS,

INTERLOGIXN value has a higher priority.

Transmission Opportunity (milliseconds): The maximum interval of time an AP/client can transmit. This makes channel access more efficiently prioritized. A value of 0 means only one frame per transmission. A greater value effects higher priority.

-47-

5.1.9 Access Control

Choose the operation mode you require, and then enter “Access Control” by clicking the Setup button next to it and the following page will be displayed. This section allows you to configure the wireless access control settings.

Object

Wireless Access

Control Mode

Mac Address

Comment

Figure 5-19 Access Control

Description

You can choose “Disable”, “Allow Listed” or “Deny Listed”.

The MAC address to be filtered.

Enter a comment of this setting.

-48-

5.1.10 WAN Port Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “WAN Port Settings” by clicking the Setup button next to it. This section allows you to configure the internet connection settings.

DHCP (Auto Config)

Choose “DHCP” and the router will automatically obtain IP addresses, subnet masks and gateway addresses from your ISP.

Figure 5-20 WAN Port Settings – DHCP

Static Mode (Fixed IP)

If your ISP offers you static IP Internet connection type, select “Static Mode" and then enter IP address, subnet mask, primary DNS and secondary DNS information provided by your ISP in the corresponding fields.

Object

IP Address

Assigned by

Your ISP

IP Subnet Mask

ISP Gateway IP

Address

Figure 5-21 WAN Port Settings – Static IP

Description

Enter the WAN IP address provided by your ISP. Enquire your ISP if you are not clear.

Enter WAN Subnet Mask provided by your ISP.

Enter the WAN Gateway address provided by your ISP.

-49-

Primary DNS

Server

Secondary DNS

Server

PPPOE (ADSL)

Enter the necessary DNS address provided by your ISP. Default is

8.8.4.4.

Enter the other DNS address if your ISP provides you with 2 such addresses. Default is 8.8.8.8.

Select PPPOE if your ISP is using a PPPoE connection and provide you with PPPoE user name and password info.

Object

User Name

Password

Verify Password

Figure 5-22 WAN Port Settings – PPPOE

Description

Enter the User Name provided by your ISP.

Enter the password provided by your ISP.

Enter the password again to verify if it is correct.

-50-

5.1.11 Dynamic DNS Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “Dynamic DNS Settings” by clicking the Setup button next to it. This section allows you to configure the DDNS settings.

Figure 5-23 Dynamic DNS Settings

Object Description

Disable: Disable DDNS function

DDNS option

Enable Easy DDNS: Enable “www.yourddns.com” DDNS

Enable Dynamic DDNS: You are allowed to modify the DDNS settings.

Dynamic DNS Provider

Select a server provider or disable the existing server.

Account

Enter the DDNS user name of the DDNS account.

Password

DDNS

Enter the DDNS password of the DDNS account.

Enter the host name or domain name provided by DDNS provider.

Click “Operation Mode

 “AP Router” or “Wireless ISP”, select Dynamic DNS Settings and press “Setup”.

-51-

Step 1. Select “Enable Dynamic DDNS” from the list.

Step 2. Configure the DDNS account that has been registered in a DDNS website.

Account: Enter your DDNS host (format: xxxddns.com

, xxx is the registered domain name)

Password: Enter the password of your account.

DDNS: Enter your DDNS host again.

Step 3. Go to “Remote Management” to enable remote access from WAN port.

Step 4. Go to “WAN Port Settings” to configure WAN connection to Static Mode (fixed IP).

-52-

Step 5. Save the setting and connect your WAN port of the Wireless AP to the internet via Ethernet cable.

In a remote computer, enter the DDNS host name as the figure shown below. Then, you should be able to login the WMC252-300 remotely.

Example of Easy DDNS Settings:

This service is not required to register any DDNS account.

Please refer to the procedure listed as follows to configure using a DDNS service.

Step 1. Select “Enable Easy DDNS” to use the DDNS service.

Easy Domain Name: Display the specified domain name for this device. (Format: xxxxxx.ddns.com

, xxxxxx is the last six-digit of the WAN Port MAC address)

Step 2. Go to “Remote Management” to enable remote access from WAN port.

Step 3. Go to “WAN Port Settings” to configure WAN connection to Static Mode (fixed IP).

Step 6. Save the setting and connect your WAN port of the Wireless AP to the internet via Ethernet cable.

In a remote computer, enter the Easy Domain Name displayed in

Step 1

. Then, you should be able to login the

-53-

WMC252-300 remotely.

5.1.12 Remote Management

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “Remote Management” by clicking the Setup button next to it. This section allows you to enable or disable the remote management through the WAN port.

Figure 5-24 Remote Management

Object

Remote management

(via WAN)

Ping from WAN

Description

Enable or Disable this function.

Enable or Disable this function.

5.1.13 DHCP Server Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “DHCP Server Settings” by clicking the Setup button next to it. This section allows you to configure the DHCP server.

Figure 5-25 DHCP Server Settings

-54-

Object

DHCP Server

Lease Time

From

To

Description

Select as DHCP server or disable the function.

Select the time for using one assigned IP from the dropdown list. After the lease time, the AP automatically assigns new IP addresses to all connected computers.

The start IP address of all the available successive IPs.

The end IP address of all the available successive IPs.

5.1.14 DMZ Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “DMZ Settings” by clicking the

Setup button next to it. This section allows you to configure the DMZ server.

Object

DMZ Setting

DMZ IP Address

Figure 5-26 DMZ Settings

Description

Disable or Enable DMZ function.

Enter the DMZ IP address.

-55-

5.1.15 Virtual Server Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “Virtual Server Settings” by clicking the Setup button next to it. This section allows you to configure the virtual server.

Object

Virtual Server

Protocol

IP Address

Port Range

Comment

Figure 5-27 Virtual Server Settings

Description

Enable or disable Virtual Server.

You can choose TCP, UDP or Both.

Enter the LAN IP.

Set the range of public port.

Set a name for the rule.

5.1.16 IP Filtering Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “IP Filtering Settings” by clicking the Setup button next to it. This section allows you to configure the IP filtering settings.

-56-

Figure 5-28 IP Filtering Settings

Object

Filtering

Protocol

IP Address

Comment

Description

Enable or disable IP Filtering.

You can choose TCP, UDP or Both.

Enter the IP address to be filtered.

Set a name for the rule.

5.1.17 Port Filtering Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “Port Filtering Settings” by clicking the Setup button next to it. This section allows you to configure the port filtering settings.

Object

Filtering

Protocol

Port Range

Comment

Figure 5-29 Port Filtering Settings

Description

Enable or disable IP Filtering.

You can choose TCP, UDP or Both.

Enter the range of Port to be filtered.

Set a name for the rule.

-57-

5.1.18 MAC Filtering Settings

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “Mac Filtering Settings” by clicking the Setup button next to it. This section allows you to configure the MAC filtering settings.

Figure 5-30 Mac Filtering Settings

Object

Filtering

Mac Address

Comment

Description

Enable or disable Mac Filtering.

Enter the Mac address to be filtered.

Set a name for the rule.

5.1.19 Bandwidth Control

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “Bandwidth Control” by clicking the Setup button next to it. This section allows you to configure the bandwidth control.

Figure 5-31 Bandwidth Control Settings

-58-

Object

Quality of

Service

Type

Description

Enable or disable the QoS service.

Select QoS type IP Address or Mac Address.

Local IP Address

The IP address segment which uses this QoS rule.

MAC Address

Comment

The Mac address which uses this QoS rule.

Uplink BandWidth

Set the maximum uplink bandwidth allowed by the listed QoS rules.

(Kbps)

Downlink

Set the maximum downlink bandwidth allowed by the listed QoS rules.

BandWidth (Kbps)

Set a name for the rule.

5.1.20 SNMP

Click “Operation Mode

 “AP Router” or “Wireless ISP” and then enter the “SNMP” by clicking the Setup button next to it. This section allows you to configure the SNMP.

Figure 5-32 SNMP Settings

Object

SNMP

Read Community

Write Community

Trap IP 1

Trap Community

Description

Enable or disable the SNMP service.

Enter a Read Community name for verification with the SNMP manager for SNMP Read requests.

Enter a Write Community name for verification with the SNMP manager for SNMP Write requests.

Enter the Trap IP address.

Enter an SNMP Trap Community name for verification with the SNMP manager for SNMP Trap requests.

-59-

5.2 System Configuration

On this page, you can configure the system of the WMC252-300, including IP settings, Time settings, Password settings, System management, Ping Watchdog, Firmware upgrade, Configuration save and restore, Factory default, Reboot and Schedule reboot.

Figure 5-33 System Configuration default page

5.2.1 Default IP Settings

Click “System Configuration

 “Device IP Settings” and the following page will be displayed.

The page includes the following fields:

Figure 5-34 Default IP Settings

Object

IP Address

IP Subnet Mask

Description

WMC252-300’s LAN IP.

The default is 192.168.0.100. You can change it according to your needs.

WMC252-300’s LAN subnet mask.

-60-

Gateway IP Address

Primary DNS Server

Secondary DNS Server

The Gateway IP address of WMC252-300.

Enter the DNS server. The default is 8.8.4.4.

Enter the DNS server. The default is 8.8.8.8.

5.2.2 Time Settings

Click “System Configuration

 “Time Settings” and the following page will be displayed.

Figure 5-35 Time Settings

Object

Enable NTP

Description

Enable it to support NTP (Network Time Protocol) for automatic time and date setup.

Server Name

NTP Request Interval

Enter the host name or IP address of the time server if you wish.

Specify a frequency (in hours) for the access point to update/synchronize with the NTP server.

Local Time Zone

Select the time zone of your country/region. If your country/region is not listed, please select another country/region whose time zone is

Local Date and Time the same as yours.

Set the access point’s date and time manually.

5.2.3 Password Settings

Click “System Configuration

 “Password Settings” and the following page will be displayed.

-61-

Figure 5-36 Password Settings

Object

Current Password

New Password

Re-enter New

Password

Description

Set the access point’s administrator password. This is used to log in to the browser based on the configuration interface.

Enter a new password.

Enter the new password again.

5.2.4 System Management

Click “System Configuration

 “System Management” and the following page will be displayed.

Figure 5-37 System Management

Object

Device Name

POE Passthrough

Description

Enter a name for this access point. Default is WMC252-300.

Enable the POE Passthrough function.

※ When the option “Enable POE Passthrough” in the System

-62-

UPnP

Syslog

IGMP

Management page is checked, the LAN2 can supply passive PoE power to the second WMC252-300.

Check to enable the UPnP function.

The UPnP feature allows the devices, such as Internet computers, to access the local host resources or devices as needed. UPnP devices can be automatically discovered by the UPnP service application on the LAN. This option is only available in AP

Router mode.

Check to enable Syslog function.

Check to enable the IGMP Proxy function.

This option is only available in AP Router mode.

5.2.5 Ping Watchdog

Click “System Configuration

 “Ping Watchdog” and the following page will be displayed.

Object

Ping Watchdog

IP Address 1

Ping Frequency

Failed tries

Action

Figure 5-38 Ping Watchdog

Description

Enable or Disable this function.

Enter the IP address which pings every time interval

Set times from 10 to 999.

Select failed tries from 1 to 5.

System will reboot when failing to ping the IP.

-63-

5.2.6 Firmware Upgrade

Click “System Configuration

 “Firmware Upgrade” and the following page will be displayed.

Object

Browse

Figure 5-39 Firmware Upgrade

Description

Click Browse to select the firmware file and click Upgrade to upgrade the firmware.

5.2.7 Configuration Save and Restore

Click “System Configuration

 “Configuration Save and Restore” and the following page will be displayed.

Object

SAVE

Browse

Figure 5-40 Configuration Save and Restore

Description

Click SAVE to save the configuration to a management host.

Click Browse to select the configuration file and click Restore to restore the configuration file.

-64-

5.2.8 Factory Default

Click “System Configuration

 “Factory Default” and the following page will be displayed.

Press YES to restore to factory default.

Figure 5-41 Factory Default

5.2.9 Reboot System

Click “System Configuration

 “Reboot System” and the following page will be displayed.

Press YES to reboot the system.

Figure 5-42 Reboot System

5.2.10 Schedule Reboot

Click “System Configuration

 “Schedule Reboot” and the following page will be displayed.

This page allows you to enable and configure system reboot schedule. The device can regularly reboot according to the reserved time when connecting to the Internet.

-65-

Figure 5-43 Schedule Reboot

-66-

Object

Schedule Reboot

Reboot Time

Reboot Plane

Weekday

Description

Enable or Disable this function.

Enter the time that you want to reboot this device.

Select Weekday to reboot in the day you choose or Every day.

Select the day that you want to reboot.

1. This setting will only take effect when the Internet connection is accessible and the GMT time is configured correctly.

2. You must select at least one day when choosing “Weekday” as your reboot plan.

3. When choosing “Every day” as your reboot plan, the “Weekday” will be grayed out

(disabled), which means Every day will auto reboot at the time that you schedule.

 Example of how to configure Schedule Reboot. Please take the following steps:

Before configuring schedule reboots, please ensure the Internet connection is accessible and the GMT time is configured correctly according to NTP Settings page.

Step 1. Enable the “Schedule Reboot”.

Step 2. Enter the Reboot Time (24-hour format) to enable this function to take effect. For example, if you want this function to work at 23:00 every Sunday, choose "Weekday" in the Reboot Plan field.

Figure 5-44 Schedule Reboot - Example

Step 3. Click the “Apply Changes” button to take this function effect.

-67-

5.3 Tools

5.3.1 Network Ping

Click “Tools

 “Network Ping” and the following page will be displayed.

Ping is a network tool used to test whether a particular host is reachable across an IP network.

Enter the IP, Ping Count, and click “Ping” to diagnostic your internet connection.

Figure 5-45 Network Ping

5.3.2 Network Traceroute

Click “Tools

 “Network Traceroute” and the following page will be displayed.

Traceroute is a computer network diagnostic tool for displaying the route (path) and measuring transit delays of packets across an Internet Protocol (IP) network. It can help identify connection problems.

Enter the IP and click “Traceroute” to diagnostic your internet connection.

-68-

Figure 5-46 Network Traceroute

-69-

5.4 Device Status

Figure 5-47 Device Status

5.4.1 Device Information

Click “Device Status

 “Device Information” and the following page will be displayed.

Figure 5-48 Device Information

-70-

The page includes the following fields:

Object

Firmware Version

Device IP

Device MAC

Gateway IP

DNS IP

Wireless MAC

Uptime

CPU Loading

Description

Displays current F/W version.

Displays IP of AP.

Displays AP’s LAN MAC address.

Displays Gateway IP of AP.

Displays DNS IP of AP.

Displays AP’s Wireless MAC address.

Displays the uptime of AP.

Displays the CPU loading of AP.

5.4.2 Wireless Information

Click “Device Status

 “Wireless Information” and the following page will be displayed.

The page includes the following fields:

Figure 5-49 Wireless Information

Object

Operation Mode

Physical address

SSID

Description

Displays current Operation Mode.

Displays AP’s Wireless MAC address.

It is the wireless network name. The default SSID is

WMC252-300.

-71-

Band

Radio Channel

Wireless Encryption

Transmit Power

Displays operating channel width which is Auto Select, 5G

11NA HT20 or 5G 11NA HT40.

Displays the channel you would like to use. The channel range will be changed by selecting a different domain.

Displays the encryption type that you would like to use.

Display the TX power that you would like to use.

5.4.3 LAN Information

Click “Device Status

 “LAN Information” and the following page will be displayed.

Figure 5-50 LAN Information

The page includes the following fields:

Object

Physical Address

Description

Displays AP’s LAN MAC address.

IP Address

Displays IP of AP.

Network Mask

Default Gateway

Displays Network Mask of AP.

Displays Gateway IP of AP.

DHCP Server

Enable or Disable DHCP server.

DHCP Start IP Address

DHCP Finish IP

Address

Enter the starting IP address for the DHCP server’s IP assignment.

Enter the ending IP address for the DHCP server’s IP assignment.

-72-

5.4.4 Wireless Client Table

Click “Device Status

 “Wireless Client Table” and the following page will be displayed.

The page includes the following fields:

Figure 5-51 Wireless Client Table

Object

No.

Mac Address

Description

Displays the number of connecting device.

Displays Mac address of AP.

Connection Speed

Signal Strength

Displays connection speed of device.

Display signal strength of device.

The signal strength between “-30 and -70” can set up a reliable connection.

5.4.5 System Log

Choose menu “Device Status

System Log” to view the logs of the Wireless AP.

-73-

Figure 5-52 System Log

-74-

5.5 Logout

Select “Logout” to logout the system.

Figure 5-53 Logout

Figure 5-54 Re-login

-75-

Appendix A: Troubleshooting

If you found the AP is working improperly or stop responding to you, please read this troubleshooting first before contacting the IFS Tech Support for help. Some problems can be solved by yourself within very short time.

Scenario Solution

The AP is not responding to me when

I want to access it by web browser. a. Please check the connection of the power cord and the

Ethernet cable of this AP. All cords and cables should be correctly and firmly inserted to the AP. b. If all LEDs on this AP are off, please check the status of power adapter, and make sure it is correctly powered. c. You must use the same IP address section that AP uses. d. Are you using MAC or IP address filter? Try to connect the AP by another computer and see if it works; if not, please reset the AP to the factory default settings (Press the ‘reset’ button for over 10 seconds). e. If you did a firmware upgrade and this happens, contact the IFS Tech Support for help. f. If all the solutions above don’t work, contact the IFS

Tech Support for help.

I can’t get connected to the Internet. a. Check the Internet connection status from the router that is connected with the AP. b. Please be patient. Sometimes, Internet is just that slow. c. If you have connected a computer to Internet directly before, try to do that again, and check if you can get connected to Internet with your computer directly attached to the device provided by your Internet service provider. d. Check PPPoE / L2TP / PPTP user ID and password in your router again. e. Call your Internet service provider and check if there’s something wrong with their service. f. If you just can’t connect to one or more website, but you can still use other internet services, please check

URL/Keyword filter. g. Try to reset the AP and try again later. h. Reset the device provided by your Internet service provider. i. Try to use IP address instead of hostname. If you can use IP address to communicate with a remote server, but can’t use hostname, please check DNS setting.

I can’t locate my AP by my wireless a. ‘Broadcast ESSID’ set to off? device. b. The antenna is properly secured. c. Are you too far from your AP? Try to get closer.

-76-

d. Please remember that you have to input ESSID on your wireless client manually, if ESSID broadcast is disabled.

File downloading is very slow or a. Are you using QoS function? Try to disable it and try breaks frequently. again. b. Internet is slow sometimes; try to be patient. c. Try to reset the AP and see if it’s better after that. d. Try to know what computers do on your local network. If someone’s transferring big files, other people will think

Internet is really slow. e. If this never happens before, call you Internet service provider to know if there is something wrong with their network.

I can’t log into the web management interface; The password is wrong. a. Make sure you’re connecting to the correct IP address of the AP. b. Password is case-sensitive. Make sure the ‘Caps Lock’ light is not illuminated. c. If you really forget the password, do a hardware reset.

The AP becomes hot a. This is not a malfunction, if you can keep your hand on the AP’s case. b. If you smell something wrong or see the smoke coming out from AP or A/C power adapter, please disconnect the AP and A/C power adapter from utility power (make sure it’s safe before you’re doing this!), and call your dealer for help.

-77-

Q1: How to set up the AP Client Connection

Topology:

Appendix B: FAQ

Step 1. Use static IP in the PCs that are connected with AP-1(Site-1) and AP-2(Site-2). In this case, Site-1 is

192.168.0.100”, and Site-2 is “192.168.1.200”.

-78-

Step 2. In AP-1, go to “Operation Mode” to configure it to Access Point Mode.

You can also configure it in “AP Router” mode if you want to connect the WAN port of the AP

to the internet directly.

STEP 3. Click “Setup” to configure the following parameters and then click Save & Restart to save the settings.

1)

Network ID (SSID)

: set to a unique value

2) Channel: set to a fixed one

3)

Security Setting

: strongly suggested to configure it.

In this case, we configure it to WPA2-PSK, AES

-79-

-80-

Step 4. In AP-2, modify the default IP to the same IP range but different from AP-1.

In this case, the IP is changed to 192.168.1.252.

Step 5. In AP-2, configure it in “Client” mode and click “Setup”.

-81-

Step 6. Click “Setup” and then click Site Survey to find the AP-1.

Step 7. Select the AP-1 from the list.

-82-

Step 8. Click “SET SECURITY” to configure the Pre-Shared Key and then click “Save” to close the window.

Step 9. Click “OK” and “Save & Restart” to apply the setting.

-83-

Step 10. In AP-1, go to “Device Status-> Wireless Client Table” to check whether AP-2 should be in the list.

Step 11. Use command line tool to ping each other to ensure the link is successfully established.

From Site-1, ping 192.168.0.100.

-84-

Step 12. Configure the TCP/IP settings of Site-2 to “Obtain an IP address automatically”.

Step 13. Use command line tool to ping the DNS (e.g., Google) to ensure Site-2 can access internet through the wireless connection.

The attention of the following hints should be paid:

1) The encryption method must be the same as that of both sites if configured.

2) Both sites should be Line-of-Sight.

3) For the short distance connection less than 1km, please reduce the "Transmit power" of both sites.

4) For the long distance connection over 1km, please adjust the "Transmit Distance" to the actual distance or double of the actual distance.

-85-

Q2: How to set up the WDS Connection

Topology:

Step 1. Use static IP in the PCs that are connected with WMC252-300-1 (Site-1) and WMC252-300-2 (Site-2). In this case, Site-1 is “192.168.0.100”, and Site-2 is “192.168.1.200”.

-86-

Step 2. In AP-1, go to “Operation Mode” to configure it in Access Point Mode.

Step 3. Click “Setup” to configure the following parameters and then click Save & Restart to save the settings.

4)

Network ID (SSID)

: set to a unique value

5) Channel: set to a fixed one

6)

Security Setting

: strongly suggested to configure it.

In this case, we configure it to WPA2-PSK, AES

-87-

-88-

Step 4. In AP-2, modify the default IP to the same IP range but different from AP-1.

In this case, the IP is changed to 192.168.1.252.

Step 5. In AP-2, configure it in “Client” mode and click “Setup”.

-89-

Step 6. Click “Setup” and then click Site Survey to find AP-1.

Step 7. Select AP-1 from the list.

Step 8. Click “SET SECURITY” to configure the Pre-Shared Key and then click “Save” to close the window.

-90-

Step 9. Click “OK” and click “Save & Restart” to apply the setting.

-91-

Step 10. In AP-1, go to “Device Status-> Wireless Client Table” to check whether AP-2 should be in the list.

Step 11. Use command line tool to ping each other to ensure the link is successfully established.

From Site-1, ping 192.168.1.200; and in Site-2, ping 192.168.0.100.

The attention of the following hints should be paid:

1) The encryption method must be the same as that of both sites if configured.

2) Both sites should be Line-of-Sight.

3) For the short distance connection less than 1km, please reduce the "Transmit power" of both sites.

4) For the long distance connection over 1km, please adjust the "Transmit Distance" to the actual distance or double of the actual distance.

-92-

English

Česky

Dansk

EC Declaration of Conformity

Hereby, IFS declares that this 300Mbps 802.11a/n

Wireless Outdoor CPE is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Lietuviškai

Šiuo IFS, skelbia, kad 300Mbps 802.11a/n Wireless

Outdoor CPE tenkina visus svarbiausius 1999/5/EC direktyvos reikalavimus ir kitas svarbias nuostatas.

Společnost IFS, tímto prohlašuje, že tato 300Mbps

802.11a/n Wireless Outdoor CPE

splňuje základní požadavky a další příslušná ustanovení směrnice 1999/5/EC.

Magyar

A gyártó IFS, kijelenti, hogy ez a 300Mbps 802.11a/n

Wireless Outdoor CPE megfelel az 1999/5/EK irányelv alapkövetelményeinek és a kapcsolódó rendelkezéseknek.

IFS, erklærer herved, at følgende udstyr 300Mbps

802.11a/n Wireless Outdoor CPE overholder de væsentlige krav og øvrige relevante krav i direktiv

1999/5/EF

Malti

Hawnhekk, IFS, jiddikjara li dan 300Mbps 802.11a/n

Wireless Outdoor CPE jikkonforma malħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC

Hierbij verklaart , IFS, dat 300Mbps 802.11a/n

Wireless Outdoor CPE in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG

Deutsch

Eestikeeles

Hiermit erklärt IFS, dass sich dieses Gerät

300Mbps 802.11a/n Wireless Outdoor CPE in

Übereinstimmung mit den grundlegenden

Anforderungen und den anderen relevanten

Vorschriften der Richtlinie 1999/5/EG befindet".

(BMWi)

Nederlands

Käesolevaga kinnitab IFS, et see 300Mbps

802.11a/n Wireless Outdoor CPE vastab Euroopa

Nõukogu direktiivi 1999/5/EC põhinõuetele ja muudele olulistele tingimustele.

Polski

Ελληνικά

Español

Français

ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ , IFS, ΔΗΛΩΝΕΙ ΟΤΙ ΑΥΤΟ

300Mbps 802.11a/n Wireless Outdoor

CPE

ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ

ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ

ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ

Português

Por medio de la presente, IFS, declara que

300Mbps 802.11a/n Wireless Outdoor CPE

cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE

Par la présente, IFS, déclare que les appareils du

300Mbps 802.11a/n Wireless Outdoor CPE sont conformes aux exigences essentielles et aux autres dispositions pertinentes de la directive

1999/5/CE

Slovensky

Slovensko

Niniejszym firma IFS, oświadcza, że 300Mbps

802.11a/n Wireless Outdoor CPE

spełnia wszystkie istotne wymogi i klauzule zawarte w dokumencie

„Directive 1999/5/EC”.

IFS, declara que este 300Mbps 802.11a/n Wireless

Outdoor CPE está conforme com os requisitos essenciais e outras disposições da Directiva

1999/5/CE.

Výrobca IFS, týmto deklaruje, že táto 300Mbps

802.11a/n Wireless Outdoor CPE je v súlade so základnými požiadavkami a ďalšími relevantnými predpismi smernice 1999/5/EC.

IFS, s tem potrjuje, da je ta 300Mbps 802.11a/n

Wireless Outdoor CPE skladen/a z osnovnimi zahtevami in ustreznimi določili Direktive 1999/5/EC.

Italiano

Latviski

Con la presente , IFS, dichiara che questo

300Mbps 802.11a/n Wireless Outdoor CPE è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva

1999/5/CE.

Ar šo IFS, apliecina, ka šī 300Mbps 802.11a/n

Wireless Outdoor CPE

atbilst Direktīvas

1999/5/EK pamatprasībām un citiem atbilstošiem noteikumiem.

Suomi

Svenska

IFS, vakuuttaa täten että 300Mbps 802.11a/n

Wireless Outdoor CPE tyyppinen laite on direktiivin

1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.

Härmed intygar, IFS, att denna 300Mbps 802.11a/n

Wireless Outdoor CPE står i överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

-93-
