Contents
Video Display
11/09-01 PC
User manual
349311
349312
Contents
1 Introduction and basic functions
5
4 House automation functions
■■ General information
■■ Your Video Display: use it now!
✔✔ Video door entry function keys
✔✔ Navigation keys
■■ Menu functions
✔✔ Volume adjustment
✔✔ Monitor adjustment
✔✔ Camera swing
✔✔ Bells adjustment
✔✔ Paging
6
6
■■
■■
■■
■■
■■
2 Trouble shooting
8
15
✔✔ Push to Talk mode
3 CCTV functions
■■
■■
■■
■■
■■
■■
Activation
Intercommunication
Camera
Cycle cameras
Staircase lights
Call exclusion
19
20
20
21
21
22
22
Scenarios
Alarms
Sound system
Temperature control
Multimedia menu
23
24
25
26
27
29
5 Services
31
■■ The “Settings” menu
■■ Services
✔✔ Professional studio
✔✔ Hands free
✔✔ Door state
✔✔ Alarm messages
■■ Messages
32
33
35
Notes
4
1 Introduction and basic functions
■■ General information
■■ Your Video Display: use it now!
✔✔ Video door entry function keys
✔✔ Navigation keys
■■ Menu function
✔✔ Volume adjustment
✔✔ Monitor adjustment
✔✔ Camera swing
✔✔ Bells adjustment
✔✔ Paging
1
5
1
Introduction and basic functions
■■ General information
■■ Your Video Display: use it now!
The Video Display offers the normal video door entry and CCTV functions
and can also interact with your My home system.
Fitting in with My Home
•Scenarios:
Runs the scenarios saved in the Scenario module.
•Alarms:
Signals the last alarm events which have occurred and the division of
the system.
7
6
•Sound system:
Manages the BTicino digital sound system.
5
•Temperature control:
Displays and adjusts the temperature in the various zones of the home
and the state of the control unit.
4
2
LCD screen note
The LCD screen has been manufactured using advanced high
precision technology. It is however possible that sometimes up to
5 small black or coloured dots (red, blue, green) may appear on the
LCD screen. This is an absolutely normal result of the manufacturing process and is not indicative of a malfunction and/or fault.
8
3
1
1 - Entrance panel and cycling
switching ON key
2 - Door lock key
3 - Connection key
4 - Call exclusion LED*
WARNINGS
■ Incorrect use of the Video Display and of all the devices
connected to it excludes any guarantee!
■ For cleaning only use a damp or antistatic cloth. Avoid the
use of alcohol or chemical detergents.
6
5 - Navigation keys
6 - Microphone
7 - LCD 2,5” colour display
8 - Loudspeaker
* It lights up when the bell volume is set to 0.
Introduction and basic functions
✔✔ Video door entry function keys
✔✔ Navigation keys
Activation Entrance Panel/Cycling
It activates the switching on of the associated Entrance
Panel and, if present, allows the cycling display of the
other Entrance Panels/cameras.
Door lock key
When there is a call it opens the door lock of the Entrance Panel
from which the call was made, at rest that of the associated
Entrance Panel. The LED signals that it is activated.
keys
Inside the menu they change the value set.
In audio/video connection they allow rapid
access to the volume and monitor settings.
7
keys
Inside the menu they select the previous or next
item.
Connection key
Activates/deactivates the audio connection.
When a call has been received the LED flashes; press
once to answer: the LED shines steadily.
At rest activates the paging function (if enabled).
key
Allows access to the menu; confirms the
selection made.
keys
Returns to the previous window. If you are
already on the first window it switches the
display off.
1
1
Introduction and basic functions
■■ Menu functions
COMMUNICATION
Use the OK key to access the main menu:
Main menu example with programming of just the communication
commands.
1
2
3
1
1
1
1) Activation
2) Intercommunication
3) Camera
4) Cycle cameras
5) Settings
SETTINGS
1
Use the
ACTIVATION I
1
2
3
4
5
HOUSE AUTOMATION
keys to select the functions from those available:
Main menu example with communication and house-automation
submenu.
1
2
3
1) Submenu and commands
2) Use the settings icon to access a series of adjustments/services
described below
1) Communication
2) Scenarios
3) Alarms
4) Sound system
Three possible solutions for drawing up the main menu are given below:
• menu with COMMUNICATION functions;
• menu with HOME AUTOMATION functions;
• CUSTOMISED menu.
5) Temperature control
SCENARIOS
For more explanations consult the complete User Manual in the CD supplied.
8
4
6) Settings
5
6
Introduction and basic functions
1
CUSTOMISED MENU
The installer has given the exact configuration of your Video Display
the tables below; if he has not filled it in ask for it.
The customised menu allows more intuitive use of the Video Display
functions. In fact the menu only displays the functions in your My
Home system and the text of each command can be customised in the
installation phase.
COMMUNICATION
Using the customised menu also lets you:
FUNCTIONS
• Have the PROFESSIONAL STUDIO, HANDS FREE, PAGING and
MULTIMEDIA functions, which otherwise can only be called from the
SETTINGS menu, in the main page or in another page.
1
2
DESCRIPTION
3
1) Communication
2) Professional studio
3) Hands free
4) Paging
5) Multimedia
SETTINGS
4
HOUSE AUTOMATION
6) Settings
5
SUB-MENU
6
Scenarios
Alarms
SOUND SYSTEM
TEMPERATURE CONTROL
MULTIMEDIA INTERFACE
9
SYSTEM FOUND
1
Introduction and basic functions
✔✔ Volume adjustment
NOTE: During a video door entry call you can access the Adjustments
menu directly by pressing the or key.
Inside the menu select
one of the items
(e.g. Bells)
Select
Adjustments
Press OK to access
the menu
ADJUSTMENTS
Adjust the volume to
the level required.
BELLS
IMPOSTAZIONI
S
EP SOUND = sound volume when talking to the entrance panel.
INTERCOM = sound volume when holding an intercom conversation.
Press OK
to confirm
BELLS = volume level for all the bells.
SOUND SYSTEM = sound system volume.
VOLUME
10
Introduction and basic functions
1
✔✔ Monitor adjustment
NOTE: During a video door entry call you can access the Adjustments
menu directly by pressing the or key.
Select
Adjustments
Inside the menu select
one of the items
(e.g. Contrast)
Press OK to access
the menu
ADJUSTMENTS
COLOUR
IMPOSTAZIONI
Select
Monitor
Make
the adjustment
Press OK
to confirm
CONTRAST
MONITOR
11
1
Introduction and basic functions
✔✔ Camera swing
NOTE: This menu can only be accessed during the connection with the
entrance panel, if this is set up for the camera swing.
Select
Adjustments
Adjust the correct
camera angle
Press OK to access
the menu
ADJUSTMENTS
Select
Swing
Press OK
to confirm
SWING BRACKET
12
Introduction and basic functions
1
✔✔ Bells adjustment
You can associate one of sixteen tunes to each call event.
01
Choose the tune
Adjust the volume
TUNE
Select
Bells
Select Confirm and then OK to
save the selection and return to the
previous page
Press OK to access
the menu
BELLS
CALL FROM EP = call from the entrance panel (S=0 o S=1)
IMPOSTAZIONI
INTERNAL INTERCOM = call from the intercom in your apartment
EXTERNAL INTERCOM = call from an intercom in another apartment
Select
the event
CALL TO THE FLOOR = call from the pushbutton near your entrance door
Press OK
to confirm
CALL FROM EP (S=0)
13
1
Introduction and basic functions
✔✔ Paging
If your system is set up, using the icon in the main menu a “paging” call
can be sent to the system:
•Basic: only sound system
•Enhanced: on the speaker* audio handsets as well
Select
Paging
Press OK
to confirm
PAGING
Once the communication is activated the voice will be played on the whole
system.
The page function can be activated directly by pressing the key
* Configurate with Software
(if the installer has configured it).
14
2 Trouble shooting
✔✔ Push to Talk mode
2
15
2
Trouble shooting
PROBLEM
On pressing the Entrance panel Activation/Cycling key (
appears.
SOLUTION
) no picture
- the audio/video channel may be busy, wait for it to become free
(from 1 to 3 minutes) and try again.
On pressing the OK key the menu does not switch on and the
handset gives a busy sound
- the audio/video channel is busy, wait for it to become free (from 1 to 3
minutes) and try again.
When called the handset does not ring
- check that the call has not been excluded (the call exclusion LED is
ON);
- check the configuration of the devices.
At the entrance panel it is difficult to hear the caller
- talk at a maximum distance of 40 centimetres from the Video
Display microphone;
- check the entrance panel settings with the installer and if necessary
reduce the microphone volume;
- you can communicate in PUSH TO TALK mode (see description on
next page).
At the handset it is difficult to hear the caller
- check the volume setting on the Video Display;
- make sure that there are no strong noise sources near the Video Display;
- you can communicate in PUSH TO TALK mode (see description on
next page).
16
Trouble shooting
✔✔ Push to Talk mode
Receiving a call from the entrance panel.
Press the Connection key to answer the call.
The connection LED lights up.
During the conversation you can activate the PUSH TO TALK function.
Press the Connection key for at least 2 seconds to talk to the entrance
panel.
The LED remains ON.
17
2
2
Trouble shooting
Release the key to hear from the entrance panel.
The LED becomes red.
To end the connection press the connection key briefly.
The LED goes out.
18
3 CCTV functions
■■ Activation
■■ Intercommunication
■■ Camera
■■ Cycle cameras
■■ Staircase lights
■■ Call exclusion
3
19
3
CCTV functions
■■ Activation
■■ Intercommunication
This function activates an actuator or an entrance panel. As an example
you can activate the opening of a secondary gate.
This function allows conversation with other video handsets/ handsets
installed in your home or in other apartments.
ACTIVATION I
Press OK to access
the Main menu
Press OK to access
the Main menu
Select
the function
Select
the extension to call
INTERCOMMUNICATING I
Press OK
to confirm
Press OK
to confirm
Command Performed appears on
the screen briefly
COMMAND PERFORMED
To quit the menu press the C key
COMMAND PERFORMED
20
Command Performed appears briefly
and then the screen switches off
If the audio/video channel is occupied
by another user you hear a sound and
the command is not performed.
Wait until the channel is free and
try again.
If there is a call from the entrance panel,
the conversation is interrupted.
CCTV functions
3
■■ Camera
■■ Cycle cameras
This function lets you monitor your home, activating one of the cameras
in the apartment and in the common areas (e.g. garage or garden).
This lets you display the pictures taken by all the cameras installed one
after the other. Once activated the Video Display displays the first camera
for 10 seconds, then goes to the next. When the cycle is complete, the
screen switches off.
You can stop on the display of one camera by pressing the Connection key.
The working camera remains active and if it belongs to an entrance panel
the sound communication is activated as well.
Press OK to access
the Main menu
Select
Cycle cameras
Select the camera
to activate
CYCLE CAMERAS
CAMERA I
Press OK
to confirm
The picture taken by the camera
selected appears on the screen (if
the audio/video channel is occupied
by another user the command is not
performed. Wait until the channel is
free and try again).
If there is a call from the entrance panel,
the connection will be interrupted.
21
Press OK to Confirm
(if the audio/video
channel is occupied
by another user the
command is not
performed. Wait until
the channel is free and
try again).
If there is a call from
the entrance panel,
the connection will be
interrupted.
3
CCTV functions
■■ Staircase lights
■■ Call exclusion
Lets you switch on the lights at the entrance or on the stairs.
This lets you enable/disable the call bell.
If the bell is disabled the call exclusion LED lights up.
Led
Press OK to access the
Main menu
Select the Staircase
light function
STAIRCASE LIGHTS
To activate the call exclusion set the “Bell” volume to zero (see Volume Adjustments chapter, page 10).
Press OK to confirm
COMMAND PERFORMED
Command Performed appears on
the screen briefly then the Main
menu returns.
22
4 House automation functions
■■ Scenarios
■■ Alarms
■■ Sound system
■■ Temperature control
■■ Multimedia menu
4
23
4
House automation functions
■■ Scenarios
Your Video Display communicates with the BTicino automation system,
activating the scenarios.
The installer has given a brief description of the scenarios set in the
tables below, if he has not filled it in ask for it.
SCENARIO
Inside the Main menu
select Scenarios
SCENARIO I
SCENARIO II
SCENARIO III
Press OK
to confirm
SCENARIO IV
SCENARIOS
SCENARIO V
Select the scenario
you want to activate
Press OK
to confirm
SCENARIO I
Command Performed appears on
the screen briefly
To quit the menu press the C key.
24
DESCRIPTION
House automation functions
■■ Alarms
Your Video Display communicates with the BTicino burglar-alarm
system, in particular giving information on the system state, the active
zones and the last 3 alarms given.
Alarms icons key:
Inside the Main menu
select Alarms
Press OK
to confirm
ARMED
ANTIPANIC
DISARMED
TECHNICAL
INTRUSION
TAMPERING
FREEZER
FIRE
EMERGENCY
CALL
GAS LEAK
TELERESCUE
FLOOD
ALARMS
The information screen appears
25
4
4
House automation functions
■■ Sound system
The information in the screen is read as indicated below:
If your Video Display is connected to the BTicino sound system you can
check it.
2
Inside the Main menu
select Sound system
3
1
Press OK to access
the menu
SOUND SYSTEM
1) State of the 8 zones managed by the burglar-alarm system: the
corresponding number (from 1 to 8) is indicated for each active zone
Using the -
2) System state = ON/OFF
3) Information on the last 3 alarms:
Type of alarm, Zone or Channel of origin
SOUND SYSTEM
Technical Alarms:
GAS LEAK c=1
FREEZER c=2
FLOOD c=3
EMERGENCY CALLc=4
TECHNICAL GENERICc=5,6,7
FIREc=8
TELERESCUEc=9
NOTE: when the burglar alarm is switched on, the memory of the
last 3 alarms is cancelled; if the siren is active, a further alarm can’t be
visualized.
CD
+
keys
you can activate/deactivate the sound
system*, adjust the
volume, select the
CD track or change
the radio station and
select the musical
source.
* –One-channel system: general activation, of the single room and of the single amplifier if
the Video Display is programmed by PC.
–Multi-channel system: activation of the single room and of the single amplifier if the
Video Display is programmed by PC.
26
House automation functions
4
■■ Temperature control
Your Video Display lets you control and adjust the temperature inside
the home, interacting with the BTicino temperature control system.
1
SOUND SYSTEM
2
3
4
Inside the Main menu
select Temperature
control system
5
CD
1)
2)
3)
4)
5)
Press OK
to confirm
Press the - and + keys to select amplifier
Press the - and + ON/OFF the system
Press the - and + adjust the volume
Press the + key to select the music source (radio, CD, etc.)
Press the - and + keys to change the radio station or choose the
CD track
TEMPERAT. CONTROL
TEMP. CONTROL UNIT
20.5 °C
You can set the manual mode and
adjust the temperature with the
- + keys.
Set the heat protection
27
4
House automation functions
You can set the temperature on different levels in the various system
zones.
1
1
ZONES: 01
TEMP. CONTROL UNIT
2
20.5 °C
3
2
4
4
1) Press the - and + keys to select Temperature control unit/Zones
2) To set the manual mode and adjust the temperature use the - and
+ keys and then press OK to confirm
3) To set the Weekly mode; press OK to confirm (the last weekly
program selected on the Temperature control unit is set)
4) Press the + key to set the protection (antifreeze for winter or heat
protection for summer);
Pressing the - key switches the system OFF
3
20.5 °C
22.5 (+2)
18.5 °C
5
1) Press the - and + keys to select Temperature control unit/Zones
2) To set the manual mode and adjust the temperature use the - and
+ keys and then press OK to confirm
3) To set the Automatic mode; press OK to confirm (in this case resets
the mode set on the Temperature control unit for this zone)
4) Press the + key to set the protection (antifreeze for winter or heat
protection for summer);
Pressing the - key switches the zone OFF
5) Display the zone’s current state.
28
House automation functions
4
If your system has the Multimedia Interface (item 3465), you can access
your menu via the dedicated icon.
Inside the
Main menu select
Multimedia
Press OK to access
the menu
MULTIMEDIA INTERFACE
✎ To navigate the menu of the multimedia
interface use the same keys as its remote
control:
MY HOME
Automation
Lighting
Burglar alarm
Loads
Temperature control
SETTINGS
✎ The "MENU" key of the multimedia interface can be activated by
The display of your Video Display
displays the main window of the
Multimedia Interface.
Settings
pressing and holding down C on the Video Display.
✎ Inside the menu of the multimedia interface the videostation will
not switch off automatically. To exit and switch the monitor off
press the pushbutton
1/2
29
Notes
30
5 Services
■■ The “Settings” menu
■■ Services
✔✔ Professional studio
✔✔ Hands free
✔✔ Door state
✔✔ Alarm messages
■■ Messages
5
31
5
Services
■■ The “Settings” menu
The main menu always has the SETTINGS icon. Selecting it gives access
to a wide range of customisations which let you get the most from your
Video Display.
SETTINGS
ADJUSTMENT
VOLUME
MONITOR
SWING
Inside the Main menu
select Settings
Services
Press OK to access
the menu
PROF. STUDIO
HANDS FREE
DOOR STATE
ALARM MSG
SETTINGS
Messages
1
2
3
BELLS
The following page is displayed
with the icons:
SERVICES
4
INFORMATION
1) Adjustments (see chapter 1)
2) Services
3) Messages
4) Bells
5) Information
6) Configuration
5
CAUTION
CONFIGURATION
6
32
Only the installer has access to the
CONFIGURATION menu; incorrect
operations could affect the operation
of the Video Display.
Services
5
✔✔ Professional studio
The Professional Studio function lets you set the automatic opening of
the door lock when there is a call from the Entrance Panel. It cannot be
activated at the same time as the Door State function.
SERVICES
The Hands Free function automatically activates the microphone and
loudspeaker when there is a call, avoiding having to press the Connection
key to answer (the connection is established immediately the call is
made).
Select
Services
Select
Settings
Press OK
to confirm
Press OK
to confirm
SERVICES
IMPOSTAZIONI
Enable or disable
the function
PROF. STUDIO
If you enable this function your Video
Display door lock LED flashes to
remind you.
IMPOSTAZIONI
Enable or disable
the function
HANDS FREE
33
If you enable this function your Video
Display door lock LED flashes to
remind you.
5
Services
✔✔ Door state
✔✔ Alarm messages
This function tells you about the door lock state. If it is open the “door
lock LED” flashes, if it is closed it remains OFF.
NOTE: it can only be activated if your system allows it (ask your installer
for more information); it can not be activated at the same time as the
Professional Studio function.
If it is activated the Video Display tells you if the antiintrusion system has
detected an alarm. The three LED flash alternately until a key is pressed
to display the message (if locally supplied the message will be displayed
automatically).
To cancel the message press the C key when the message is displayed. If
not the signal will appear the next time a key is pressed.
SERVICES
Select
Services
Select
Services
Press OK
to confirm
Press OK
to confirm
SERVICES
IMPOSTAZIONI
IMPOSTAZIONI
Select
Door state
Select
Alarm MSG
Enable or disable
the function
Enable or disable
the function
DOOR STATE
ALARM MSG
34
Services
■■ Messages
Select
Messages
Press OK
to confirm
MESSAGES
- 1 +
Message from
switchboard
Select the message
you want to display
Press C to return to
the previous page
There are messages, the menu can be selected.
No messages, the menu cannot be selected.
35
5
BTicino SpA reserves at any time the right to modify the contents of this booklet and to communicate,
in any form and modality, the changes brought to the same.
BTicino SpA
Via Messina, 38
20154 Milano - Italy
www.bticino.it
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
