CREATING RELIABLE PARTNERSHIPS FOR SOCIAL HOUSING.

CREATING RELIABLE PARTNERSHIPS FOR SOCIAL HOUSING.

CREATING RELIABLE

PARTNERSHIPS

FOR SOCIAL HOUSING.

WWW.IDEALBOILERS.COM

02

WELCOME

TO FIRST

CLASS.

OUR AWARD WINNING BOILERS GO

THROUGH 200 QUALITY CHECKS BEFORE

THEY LEAVE THE FACTORY, AND ARE

AVAILABLE WITH A RANGE OF FLEXIBLE

WARRANTY OPTIONS. YOU CAN REST

ASSURED RELIABILITY IS GUARANTEED

WHEN YOU PARTNER WITH IDEAL.

WELCOME

TO FIRST

CLASS.

OUR AWARD WINNING BOILERS GO

THROUGH 200 QUALITY CHECKS BEFORE

THEY LEAVE THE FACTORY, AND ARE

AVAILABLE WITH A RANGE OF FLEXIBLE

WARRANTY OPTIONS. YOU CAN REST

ASSURED RELIABILITY IS GUARANTEED

WHEN YOU PARTNER WITH IDEAL.

CONTENTS.

04 THE IDEAL PRODUCT RANGE

06 LOGIC COMBI

14 LOGIC SYSTEM

22 LOGIC HEAT

30 LOGIC CODE COMBI ES

38 LOGIC COMBI ES

46 CONTROLS

50 LPG CONVERSION KITS

52 FLUE SITING

54 ACCESSORIES

59 CONTACT IDEAL

03

04

THE IDEAL

PRODUCT

RANGE.

Representing the next generation in heating design, the Logic range of boilers offers state-of-the-art technology in a practical, compact unit that fits easily into any standard kitchen cupboard.

Available in a range of outputs, the Logic range comes complete with a flexible parts and labour warranty package.

THE IDEAL

PRODUCT

RANGE.

Representing the next generation in heating design, the Logic range of boilers offers state-of-the-art technology in a practical, compact unit that fits easily into any standard kitchen cupboard.

Available in a range of outputs, the Logic range comes complete with a flexible parts and labour warranty package.

LOGIC COMBI

Designed to be installed with minimal fuss.

LOGIC SYSTEM

A simple and reliable solution for a wide variety of sealed domestic systems.

LOGIC HEAT ONLY

Highly efficient and easy to operate, thanks to straightforward controls featuring a clear digital display.

LOGIC CODE COMBI ES

A simple one box solution, capable of supporting up to level 4 of the code for sustainable homes with built in flue gas heat recovery.

LOGIC COMBI ES

A high efficiency combination boiler particularly beneficial for small, social new build properties.

05

06

LOGIC COMBI.

24 30 35

HIGH EFFICIENCY

COMBINATION BOILERS.

Designed to be installed with the minimum of fuss Logic appliances offer a speedy installation.

Compact LPG

Conversion Kit*

Frost

Protection

Flue

Variants

NOx

Class 5

Flexible

Warranty

LOGIC COMBI

• Pre-heat function

• 75mm deep translucent condensate siphon

• Clear alpha-numeric display

• Fully modulating operation to low outputs

• Automatic bypass

• Four optional language user instructions**

• Visually impaired user fascia option

RELIABLE

• Energy Saving Trust endorsed product

• Flexible warranty

• Boiler frost protection

• Built-in, easy to use filling loop

• Simple diverter valve design

• Two stage flame sensing for greater reliability

• Latest generation Honeywell gas valve

• ErP compliant

EASY TO INSTALL

• Compact cupboard fit

• Fast fix flues

• Wide range of additional flueing options

• Low lift weight (32kg)

• Easy access to PRV and AAV

• Preformed copper tails

• Pre-wired mains lead (2m)

• Universal condensate connection

• Stand-off kit including piping option

• Compatible with a range of additional controls inc. weather compensation

• LPG conversion kit available for 24 kW & 30 kW boilers

* Available with 24 & 30 kW models.

** Available to download from www.idealboilers.com

07

CLEARANCES AND DIMENSIONS.

DIMENSIONS:

Height: 700mm

Width: 395mm

Depth: 278mm

08

FLUE LENGTHS.

COMBI 24

9m Max horizontal**

Max vertical**

Powered vertical†

Note: The minimum front clearance when built in to a cupboard is 5mm from the cupboard door but 450mm overall clearance with the cupboard door open is required for servicing.

*Bottom clearance after installation can be reduced to

5mm. However, 100mm is required for servicing.

COMBI 30

8m

7.5m

22m

COMBI 35

6m

TECHNICAL SPECIFICATION.

Weight (packaged) kg

Max installation weight kg

CH output (kW) min/max

@ 70°C

CH output (kW) min/max

@ 40°C

DHW output (kW) max

DHW flow rate l/min.

35°C rise

SEDBUK rating (2005) %

SEDBUK rating (2009) %

NOx classification

Adjustable to LPG

Condensing boiler

Seasonal space heating efficiency class

Rated heat output kW

Seasonal space heating energy efficiency η son

%

Sound power level, indoors L

WA dB

Water heating energy efficiency class

COMBI 24

36.3

31.8

4.8 - 24.2

5.1 - 25.6

24.2

9.9

91

89.0

Yes

45

89.0

CLASS 5

Yes

Yes

A

24

93

45

A

COMBI 30

36.5

32

6.1 - 24.2

6.4 - 25.6

30.3

12.4

91.1

Available flue extensions 0.5m, 1m and 2m. Multiple flue kits available.

** Each 90° elbow used is at the expense of 1000mm of straight flue run, and each 45° elbow is used at the expense of 600mm of straight flue run.

† Typical combined primary and secondary length. See installation instructions for more details. Note: The Flue Deflector Kit is used at the expense of 1000mm of straight flue run.

COMBI 35

36.5

32

7.1 - 24.2

7.5 - 25.6

35.3

14.5

91

88.9

No

44

09

10

TROUBLESHOOTING.

POINTS FOR THE

BOILER USER

Note. In line with our current

warranty policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit.

Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer.

NO HOT WATER

Check the mains switch (fused spur) is turned on and ensure switch mode control knob (D) (Control Panels: 46) is in the summer or winter position

Is water coming out of the hot water tap when turned on?

YES

NO

See boiler “Fault Codes” section. If ‘0’ is displayed then contact Ideal Customer

Services Helpline if your appliance is under warranty or a Gas Safe

Registered Engineer, in IE a Registered

Gas Installer (RGII), if out of warranty

Contact a Gas Safe Registered Engineer or in IE a Registered Gas Installer (RGII)

NO CENTRAL HEATING

Check the mains switch (fused spur) is turned on and ensure switch mode control knob (D)

(Control Panels: 46) is in the winter position

Check the programmer (internal or external to the boiler) is in an “ON” position and the room thermostat is turned up

Does the boiler operate and provide central heating?

YES

Check the time settings on the programmer are as you require and adjust if necessary

NO

See boiler “Operation Modes” and

“Fault Codes” section. If “0” is displayed then contact a Gas

Safe Registered Engineer or in IE a Registered Gas Installer (RGII)

NO HOT WATER OR

CENTRAL HEATING

Check the fused spur is turned on and ensure switch mode control knob (D) (Control

Panels: 46) is in the winter position

Does the boiler have a display showing on the front control panel?

See boiler “Operation

Modes” and “Fault Codes” section

Contact a Gas Safe

Registered Engineer or

in IE a Registered Gas

Installer (RGII)

11

OPERATIONS MODE.

DISPLAY CODE

ON THE BOILER

DESCRIPTION

The boiler is in standby mode awaiting either a central heating call or hot water demand.

The boiler has a call for central heating but the appliance has reached the desired temperature set on the boiler.

The boiler has a call for hot water but the appliance has reached the desired temperature set on the boiler.

The boiler is operating in central heating mode.

The boiler is operating in hot water mode.

The boiler is operating in pre-heat mode.

The boiler is operating in frost mode.

12

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION ACTION

Outside sensor failure

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Low mains voltage Contact a qualified electrician or your electricity provider.

Unconfigured PCB Unconfigured PCB. Please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Boiler resets in

15 minutes

1. Turn power off and on at the fused spur.

2. If the boiler fails to operate please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer RGII).

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION ACTION

False flame lockout Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC activation fault Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC fault Check the correct BCC is fitted for the boiler, and securely inserted into the slot at the front left of the PCB. (Identified by the label on the

BCC). If yes then replace the current BCC with a new one correctly labelled for the boiler. If it is incorrect (turn off the power) then insert correctly into PCB after switching power back on restart the boiler.

Low water pressure Check system pressure is between 1 & 1.5bar on the pressure gauge.

If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Flow temperature overheat or no water flow

Flame loss

Fan fault

Is the boiler and CH heating system filled and all isolation vales and radiators open? If not then fill and vent the system and open all isolation valves and restart the boiler. Check that the pumps are rotating freely and the flow and return have a differential across the boiler in excess of 30°C.

1. Check other gas appliances in the house are working to confirm a supply is present in the property.

2. If other appliances do not work or there are no other appliances, check the gas supply is on at the meter and/or pre payment meter has credit. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Flow thermistor

Return thermistor

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

13

14

LOGIC SYSTEM.

15 18 24 30

HIGH EFFICIENCY

SYSTEM BOILERS.

The Logic system range of appliances from Ideal provide a simple and reliable solution for a wide variety of sealed domestic systems.

Compact LPG

Conversion Kit*

Frost

Protection

Flue

Variants

NOx

Class 5

Flexible

Warranty

LOGIC SYSTEM

• Digital display and simple diagnostics

• Fully modulating operation down to 4.8 kW**

• Weather compensation kit option

RELIABLE

• Energy Saving Trust endorsed product

• Flexible warranty

• Boiler frost protection

• Built-in condensate trap

• Latest generation Honeywell gas valve

• ErP compliant

• Two stage flame sensing for better reliability

EASY TO INSTALL

• Compact cupboard fit

• Wide range of flueing options

• Concealed pipe connections

• Low lift weight (28kg)†

• Preformed copper tails

• LPG Conversion kit available for 24 kW & 30 kW boilers

• Stand-off kit and pre-pipe options

• Pre-wired mains lead

• Easy Access to PRV and AAV

• Universal condensate connection

* Available with 24 & 30 kW models.

** (30 kW only - 6.1 kW).

† Weight with front panel removed.

15

CLEARANCES AND DIMENSIONS.

DIMENSIONS:

Height: 700mm

Width: 395mm

Depth: 278mm

FLUE LENGTHS.

Note: The minimum front clearance when built in to a cupboard is 5mm from the cupboard door but 450mm overall clearance with the cupboard door open is required for servicing.

*Bottom clearance after installation can be reduced to

5mm. However, 100mm is required for servicing.

SYSTEM 15 SYSTEM 18

16

Max horizontal

Max vertical

Powered vertical

9m

7.5m

22m

SYSTEM 24

9m

7.5m

22m

SYSTEM 30

8m

Max horizontal

Max vertical

Powered vertical

SYSTEM 15

9m

7.5m

22m

SYSTEM 18

TECHNICAL SPECIFICATION.

SYSTEM 15

Weight (packaged) kg

Max installation weight kg

CH output (kW) min/max

@ 70°C

CH output (kW) min/max

@ 40°C

DHW output (kW) max

DHW flow rate l/min.

35°C rise

SEDBUK rating (2005) %

SEDBUK rating (2009) %

NOx classification

Adjustable to LPG

Condensing boiler

Seasonal space heating efficiency class

Rated heat output kW

Seasonal space heating energy efficiency η son

%

Sound power level, indoors L

WA dB

Water heating energy efficiency class

4.8 - 15.0

5.1 - 15.9

91.1

89.3

No

15

93

41

SYSTEM 18

34.4

28

SYSTEM 24

4.8 - 18.0

5.1 - 19.1

4.8 - 24.2

5.1 - 25.6

n/a n/a

91

89.2

91

89.5

CLASS 5

No Yes

Yes

A

18

93

42

24

93

45 n/a

SYSTEM 30

6.1 - 30.3

6.4 - 31.0

91.1

89.6

Yes

30

93

45

Multiple flue kits available.

SYSTEM 24

9m

SYSTEM 30

8m

7.5m

22m

17

18

TROUBLESHOOTING.

POINTS FOR THE

BOILER USER

Note. In line with our current warranty

policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit. Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any prearranged visit where access is not gained by the engineer.

NO HOT WATER

Check the mains switch (fused spur) is turned on and ensure mode control knob (B) (Control Panels: 46) is in the ON position

Check the programmer is in an “ON” position and the cylinder thermostat is turned up

Does the boiler operate and provide hot water?

YES

Check the time settings on the programmer are as you require and adjust if necessary

NO

See boiler “Operation Modes” and

“Fault Codes” section. If “0” is displayed then contact a Gas Safe

Registered Engineer or in IE a

Registered Gas Installer (RGII)

NO CENTRAL HEATING

Check the mains switch (fused spur) is turned on and ensure mode control knob (B) (Control

Panels: 46) is in the

ON position

Check the programmer is in an “ON” position and the room thermostat is turned up

Does the boiler operate and provide central heating?

YES

Check the time settings on the programmer are as you require and adjust if necessary

NO

See boiler “Operation Modes” and “Fault Codes” section. If “0” is displayed then contact a Gas

Safe Registered Engineer or in

IE a Registered Gas Installer

(RGII)

OPERATIONS MODE.

DISPLAY CODE

ON THE BOILER

DESCRIPTION

The boiler is in standby mode awaiting either a central heating call or hot water demand.

The boiler has a call for central heating / hot water but the appliance has reached the desired temperature set on the boiler.

The boiler is operating for central heating / hot water.

The boiler is operating in frost mode.

19

20

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION

Boiler chip card

(BCC) not fitted

ACTION

Please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Outside sensor failure

Reset the appliance - if the boiler fails to operate then please contact

Ideal (if under warranty) or alternatively a Gas Safe Registered

Engineer if outside of the warranty period. In IE contact a Registered

Gas Installer (RGII).

Low mains voltage Contact a qualified electrician or your electricity provider.

PCB fault PCB Fault. Please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In

IE contact a Registered Gas Installer (RGII).

Boiler resets in 15 minutes

1. Turn power off and on at the fused spur.

2. If the boiler fails to operate please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer

(RGII).

False flame lockout Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC activation fault Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC fault Check system pressure is between 1 & 1.5 bar on the pressure gauge. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

DISPLAY CODE ON THE BOILER DESCRIPTION ACTION

Low water pressure Check system pressure is between 1 & 1.5bar on the pressure gauge. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

Flow temperature overheat

Is the boiler and CH heating system filled and all isolation vales and radiators open? If not then fill and vent the system and open all isolation valves and restart the boiler. Check that the pumps are rotating freely and the flow and return have a differential across the boiler in excess of 30°C.

Flame loss 1. Check other gas appliances in the house are working to confirm a supply is present in the property.

2. If other appliances do not work or there are no other appliances, check the gas supply is on at the meter and/or pre payment meter has credit. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

Fan fault

Control / no flow thermistor

Return thermistor

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

21

22

LOGIC HEAT.

12 15 18 24 30

HIGH EFFICIENCY

HEAT BOILERS.

Designed to be installed with the minimum of fuss Logic appliances offer a speedy installation.

Compact LPG

Conversion Kit*

Frost

Protection

Flue

Variants

NOx

Class 5

Flexible

Warranty

Direct Rear

Flue

LOGIC HEAT

• Fully modulating operation down to 4.8 kW**

• Weather compensation kit option

• Water flow sensor

• Four optional language user instructions*

2

RELIABLE

• Energy Saving Trust endorsed product

• Flexible warranty

• Boiler frost protection

• Two stage flame sensing for greater reliability

• Latest generation Honeywell gas valve

• ErP compliant

EASY TO INSTALL

• Compact cupboard fit

• Direct 80mm diameter rear flue option

• Wide range of flueing options

• Low lift weight (23kg)†

• Top system connections

• 75mm deep translucent condensate siphon

• Stand-off kit

• Terminal wall plate kit

• Security bracket kit

• Low minimum head requirement

• LPG conversion kit available for 24 kW & 30 kW boilers

* Available with 24 & 30 kW models. ** (30 kW only - 6.1 kW).

*

2 Available to download from www.idealboilers.com

† Weight with front panel removed.

23

CLEARANCES AND DIMENSIONS.

DIMENSIONS:

Height: 700mm

Width: 395mm

Depth: 278mm

FLUE LENGTHS.

Note: The minimum front clearance when built in to a cupboard is 5mm from the cupboard door but 450mm overall clearance with the cupboard door open is required for servicing.

*Bottom clearance after installation can be reduced to 5mm. However, 100mm is required for servicing.

** Rear flue option - top clearance 100mm.

24

Max horizontal

Max vertical

Powered vertical

HEAT 12 HEAT 15

9m

HEAT 18

7.5m

22m

HEAT 24 HEAT 30

8m

Max horizontal

Max vertical

Powered vertical

HEAT 12 HEAT 15

9m

HEAT 18

7.5m

22m

TECHNICAL SPECIFICATION.

HEAT 12

Weight (packaged) kg

Max installation weight kg

CH output (kW) min/max

@ 70°C

CH output (kW) min/max

@ 40°C

DHW output (kW) max

DHW flow rate l/min.

35°C rise

SEDBUK rating (2005) %

4.8 - 12.0

5.1 - 13.0

91.2

89.4

SEDBUK rating (2009) %

NOx classification

Adjustable to LPG

Condensing boiler

Seasonal space heating efficiency class

Rated heat output kW

Seasonal space heating energy efficiency η son

%

Sound power level, indoors L

WA dB

Water heating energy efficiency class

No

12

93

40

HEAT 15

4.8 - 15.0

5.1 - 15.9

91.1

89.3

No

15

93

41

91

89.2

CLASS 5

No

Yes

A

18

93

42 n/a

HEAT 18

28.5

22.8

4.8 - 18.0

5.1 - 19.1

n/a n/a

HEAT 24

4.8 - 24.2

5.1 - 25.6

6.1 - 30.3

6.4 - 31.0

91

89.5

Yes

24

93

45

HEAT 30

91.1

89.6

Yes

30

93

45

Multiple flue kits available.

HEAT 24 HEAT 30

8m

25

26

TROUBLESHOOTING.

POINTS FOR THE BOILER USER

Note. In line with our current warranty policy we would ask that you check

through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit. Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer.

NO CENTRAL HEATING OR

HOT WATER

Check the mains switch (fused spur) is turned on and ensure mode control knob (B)

(Control Panels: 47) is in the

ON position

Check the Timer is in an

“ON” position, and the room thermostat is turned up

Does the boiler operate and provide central heating?

YES

Check the time settings on the programmer are as you require and adjust if necessary

NO

See boiler “Operation Modes” and “Fault Codes” section. If “0” is displayed then contact a Gas

Safe Registered Engineer or in

IE a Registered Gas Installer

(RGII)

OPERATIONS MODE.

DISPLAY CODE

ON THE BOILER

DESCRIPTION

The boiler is in standby mode awaiting either a central heating call or hot water demand.

The boiler has a call for central heating / hot water but the appliance has reached the desired temperature set on the boiler.

The boiler is operating for central heating / hot water.

The boiler is operating in frost mode.

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION ACTION

BCC activation fault Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC fault Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Unconfigured PCB Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Flame loss See Action - Fault Code L 2.

27

28

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION

Fan fault

Flow thermistor

ACTION

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Return thermistor Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Outside sensor failure

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Low mains voltage Contact a qualified electrician or your electricity provider.

PCB fault

Flow/return reversed

Please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Please contact a Gas Safe Registered Engineer. In IE contact a

Registered Gas Installer (RGII).

No water flow Please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

DISPLAY CODE ON THE BOILER DESCRIPTION

Flow temperature overheat or unconfigured PCB

Ignition lockout

ACTION

Check system pressure is between 1 & 1.5bar on the pressure gauge. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

1. Check other gas appliances in the house are working to confirm a supply is present in the property.

2. If other appliances do not work or there are no other appliances, check the gas supply is on at the meter and/or pre payment meter has credit. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas

Safe Registered engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Boiler resets in

15 minutes

1. Turn power off and on at the fused spur.

2. If the boiler fails to operate please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered

Gas Installer (RGII).

False flame lockout Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

29

30

LOGIC

CODE COMBI ES.

26 33 38

HIGH EFFICIENCY

COMBINATION BOILERS.

Designed to take the headache out of meeting Building

Regulations, the Logic Code Combi ES from Ideal is a simple one-box solution, capable of supporting up to level 4 of the

Code for Sustainable homes.

Compact LPG

Conversion Kit*

Frost

Protection

Flue

Variants

NOx

Class 5

Flexible

Warranty

LOGIC CODE COMBI ES

• Complete range of Logic combination boilers for social new build developers

• Achieves optimum SAP and DER ratings for standard combination boiler usage

• Higher DHW flow rates than standard boiler

– approximately 10% increase

RELIABLE

• Energy Saving Trust endorsed product

• Flexible warranty

• High DHW efficiency - reduced running costs

• Less waste DHW water as DHW inlet is preheated

• Reduced pluming on DHW

• ErP compliant

EASY TO INSTALL

• One single appliance to install – quick and easy

• Built-in pipework; no extra space at the side of the product needed

• Standard combination connections

• No additional maintenance requirement

• Compact and light solution for social new build or retrofit installations

* Available with 38 kW model.

31

CLEARANCES AND DIMENSIONS.

DIMENSIONS:

Height: 830mm

Width: 395mm

Depth: 278mm

Note: The minimum front clearance when built in to a cupboard is 5mm from the cupboard door but 450mm overall clearance with the cupboard door open is required for servicing.

*Bottom clearance after installation can be reduced to 5mm. However, 100mm is required for servicing.

32

FLUE LENGTHS.

Max horizontal**

Max vertical**

Powered vertical†

CODE COMBI ES 26 CODE COMBI ES 33 CODE COMBI ES 38

9m 6m 8m

7.5m

22m

TECHNICAL SPECIFICATION.

Weight (packaged) kg

Max installation weight kg

CH output (kW) Min/Max

@ 70°C

CH output (kW) Min/Max

@ 40°C

DHW output (kW) Max

DHW flow rate l/min.

35°C rise

SEDBUK rating (2005)

SEDBUK rating (2009)

CODE COMBI ES 26 CODE COMBI ES 33 CODE COMBI ES 38

41.3

41.4

41.6

35.9

36.0

36.2

4.8 - 24.2

5.1 - 25.6

26.1

10.7

91

89.0

6.1 - 24.2

6.4 - 25.6

32.7

13.4

91.1

89.0

7.1 - 24.2

7.5 - 25.6

38.2

15.7

91

88.9

NOx classification

Adjustable to LPG

Condensing boiler

Seasonal space heating efficiency class

Rated heat output kW

Seasonal space heating energy efficiency η son

%

Sound power level, indoors L

WA dB

Water heating energy efficiency class

No

45

CLASS 5

No

Yes

A

24

93

45

A

Yes

44

Multiple flue kits available.

** Each 90° elbow used is at the expense of 1000mm of straight flue run, and each 45° elbow is used at the expense of 600mm of straight flue run.

† Typical combined primary and secondary length. See installation instructions for more details. Note: The Flue Deflector Kit is used at the expense of 1000mm of straight flue run.

33

34

TROUBLESHOOTING.

POINTS FOR THE

BOILER USER

Note. In line with our current

warranty policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit.

Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer.

NO HOT WATER

Check the mains switch (fused spur) is turned on and ensure switch mode control knob (D) (Control Panels: 47) is in the summer or winter position

Is water coming out of the hot water tap when turned on?

YES

NO

See boiler “Fault Codes” section. If ‘0’ is displayed then contact Ideal Customer

Services Helpline if your appliance is under warranty or a Gas Safe

Registered Engineer, in IE a Registered

Gas Installer (RGII), if out of warranty

Contact a Gas Safe Registered Engineer or in IE a Registered Gas Installer (RGII)

NO CENTRAL HEATING

Check the mains switch (fused spur) is turned on and ensure switch mode control knob (D)

(Control Panels: 47) is in the winter position

Check the programmer (internal or external to the boiler) is in an “ON” position and the room thermostat is turned up

Does the boiler operate and provide central heating?

YES

Check the time settings on the programmer are as you require and adjust if necessary

NO

See boiler “Operation Modes” and

“Fault Codes” section. If “0” is displayed then contact a Gas

Safe Registered Engineer or in IE a Registered Gas Installer (RGII)

NO HOT WATER OR

CENTRAL HEATING

Check the fused spur is turned on and ensure switch mode control knob (D) (Control

Panels: 47) is in the winter position

Does the boiler have a display showing on the front control panel?

NO

YES

See boiler “Operation

Modes” and “Fault Codes” section

Contact a Gas Safe

Registered Engineer or

in IE a Registered Gas

Installer (RGII)

35

OPERATIONS MODE.

DISPLAY CODE

ON THE BOILER

DESCRIPTION

The boiler is in standby mode awaiting either a central heating call or hot water demand.

The boiler has a call for central heating but the appliance has reached the desired temperature set on the boiler.

The boiler has a call for hot water but the appliance has reached the desired temperature set on the boiler.

The boiler is operating in central heating mode.

The boiler is operating in hot water mode.

The boiler is operating in frost mode.

36

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION ACTION

Outside sensor failure

Reset the appliance - if the boiler fails to operate then please contactIdeal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Low mains voltage Contact a qualified electrician or your electricty provider.

Unconfigured PCB Unconfigured PCB. Please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

No water flow thermistor

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION

Boiler resets in

15 minutes

ACTION

1. Turn power off and on at the fused spur.

2. If the boiler fails to operate please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

False flame lockout Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC activation fault Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC fault Check the correct BCC is fitted for the boiler, and securely inserted into the slot at the front left of the PCB. (Identified by the label on the BCC). If yes then replace the current BCC with a new one correctly labelled for the boiler. If it is incorrect (turn off the power) then insert correctly into PCB after switching power back on restart the boiler.

Low water pressure Check system pressure is between 1 & 1.5bar on the pressure gauge. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

Flow temperature overheat

Is the boiler and CH heating system filled and all isolation vales and radiators open? If not then fill and vent the system and open all isolation valves and restart the boiler. Check that the pumps are rotating freely and the flow and return have a differential across the boiler in excess of 30°C.

No water flow

Flame loss

Fan fault

Flow thermistor

Return thermistor

1. Check other gas appliances in the house are working to confirm a supply is present in the property.

2. If other appliances do not work or there are no other appliances, check the gas supply is on at the meter and/or pre payment meter has credit. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

37

38

LOGIC COMBI ES.

24 30 35

HIGH EFFICIENCY

COMBINATION BOILERS.

Optimised for new build compliance following the SAP

2009 design procedure, the Logic Combi ES is particularly beneficial for new build properties.

Compact LPG

Conversion Kit*

Frost

Protection

Flue

Variants

NOx

Class 5

Flexible

Warranty

LOGIC COMBI ES

• Complete range of Logic combination boilers for social new build developers

• Achieves optimum SAP and DER ratings for standard combination boiler usage

• 75mm deep translucent condensate siphon

• Fully modulating operation to low outputs

• Automatic bypass

RELIABLE

• Energy Saving Trust endorsed product

• Flexible warranty

• Boiler frost protection

• Built-in, easy to use filling loop

• Simple diverter valve design

• Two stage flame sensing for greater reliability

• Latest generation Honeywell gas valve

• ErP compliant

EASY TO INSTALL

• Compact cupboard fit

• Fast fix flues

• Wide range of additional flueing options

• Low lift weight (33kg)

• Easy access to PRV and AAV

• Preformed copper tails

• Pre-wired mains lead (2m)

• Universal condensate connection

• Stand-off kit including piping option

• Compatible with a range of additional controls inc. weather compensation

• LPG conversion kit available for 30 kW boilers

* Available with 30 kW model.

39

CLEARANCES AND DIMENSIONS.

40

DIMENSIONS:

Height: 700mm

Width: 395mm

Depth: 278mm

FLUE LENGTHS.

COMBI ES 24

9m Max horizontal**

Max vertical**

Powered vertical†

Note: The minimum front clearance when built in to a cupboard is 5mm from the cupboard door but 450mm overall clearance with the cupboard door open is required for servicing.

*Bottom clearance after installation can be reduced to

5mm. However, 100mm is required for servicing.

COMBI ES 30

8m

7.5m

22m

COMBI ES 35

6m

TECHNICAL SPECIFICATION.

Weight (packaged) kg

Max installation weight kg

CH output (kW) min/max

@ 70°C

CH output (kW) min/max

@ 40°C

DHW output (kW) max

DHW flow rate l/min.

35°C rise

SEDBUK rating (2005) %

SEDBUK rating (2009) %

NOx classification

Adjustable to LPG

Condensing boiler

Seasonal space heating efficiency class

Rated heat output kW

Seasonal space heating energy efficiency η son

%

Sound power level, indoors L

WA dB

Water heating energy efficiency class

COMBI ES 24

37.7

32.7

4.8 - 24.2

5.1 - 25.6

24.2

9.9

91

89.0

No

45

89.0

CLASS 5

Yes

Yes

A

24

93

45

A

COMBI ES 30

37.8

32.8

6.1 - 24.2

6.4 - 25.6

30.3

12.4

91.1

Available flue extensions 0.5m, 1m and 2m. Multiple flue kits available.

** Each 90° elbow used is at the expense of 1000mm of straight flue run, and each 45° elbow is used at the expense of 600mm of straight flue run.

† Typical combined primary and secondary length. See installation instructions for more details. Note: The Flue Deflector Kit is used at the expense of 1000mm of straight flue run.

COMBI ES 35

38

33

7.1 - 24.2

7.5 - 25.6

35.3

14.5

91

88.9

No

44

41

42

TROUBLESHOOTING.

POINTS FOR THE

BOILER USER

Note. In line with our current

warranty policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit.

Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer.

NO HOT WATER

Check the mains switch (fused spur) is turned on and ensure switch mode control knob (D) (Control Panels: 47) is in the summer or winter position

Is water coming out of the hot water tap when turned on?

NO

YES

See boiler “Fault Codes” section. If ‘0’ is displayed then contact Ideal Customer

Services Helpline if your appliance is under warranty or a Gas Safe

Registered Engineer, in IE a Registered

Gas Installer (RGII), if out of warranty

Contact a Gas Safe Registered Engineer or in IE a Registered Gas Installer (RGII)

NO CENTRAL HEATING

Check the mains switch (fused spur) is turned on and ensure switch mode control knob (D)

(Control Panels: 47) is in the winter position

Check the programmer (internal or external to the boiler) is in an “ON” position and the room thermostat is turned up

Does the boiler operate and provide central heating?

YES

Check the time settings on the programmer are as you require and adjust if necessary

NO

See boiler “Operation Modes” and

“Fault Codes” section. If “0” is displayed then contact a Gas

Safe Registered Engineer or in IE a Registered Gas Installer (RGII)

NO HOT WATER OR

CENTRAL HEATING

Check the fused spur is turned on and ensure switch mode control knob (D) (Control

Panels: 47) is in the winter position

Does the boiler have a display showing on the front control panel?

NO

YES

See boiler “Operation

Modes” and “Fault Codes” section

Contact a Gas Safe

Registered Engineer or

in IE a Registered Gas

Installer (RGII)

43

OPERATIONS MODE.

DISPLAY CODE

ON THE BOILER

DESCRIPTION

The boiler is in standby mode awaiting either a central heating call or hot water demand.

The boiler has a call for central heating but the appliance has reached the desired temperature set on the boiler.

The boiler has a call for hot water but the appliance has reached the desired temperature set on the boiler.

The boiler is operating in central heating mode.

The boiler is operating in hot water mode.

The boiler is operating in frost mode.

44

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION ACTION

Outside sensor failure

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Low mains voltage Contact a qualified electrician or your electricity provider.

Unconfigured PCB Unconfigured PCB. Please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Boiler resets in

15 minutes

1. Turn power off and on at the fused spur.

2. If the boiler fails to operate please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer RGII).

False flame lockout Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

FAULT CODES.

DISPLAY CODE ON THE BOILER DESCRIPTION ACTION

BCC activation fault Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

BCC fault Check the correct BCC is fitted for the boiler, and securely inserted into the slot at the front left of the PCB. (Identified by the label on the BCC). If yes then replace the current BCC with a new one correctly labelled for the boiler. If it is incorrect (turn off the power) then insert correctly into PCB after switching power back on restart the boiler.

Low water pressure Check system pressure is between 1 & 1.5bar on the pressure gauge.

If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Flow temperature overheat or no water flow

Flame loss

Is the boiler and CH heating system filled and all isolation vales and radiators open? If not then fill and vent the system and open all isolation valves and restart the boiler. Check that the pumps are rotating freely and the flow and return have a differential across the boiler in excess of 30°C.

1. Check other gas appliances in the house are working to confirm a supply is present in the property.

2. If other appliances do not work or there are no other appliances, check the gas supply is on at the meter and/or pre payment meter has credit. If the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas

Installer (RGII).

Fan fault

Flow thermistor

Return thermistor

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe

Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII).

45

46

BOILER CONTROLS.

LOGIC COMBI.

24 30 35

BOILER CONTROLS

A. Pre-heat On/Off

B. DHW Temperature Control

C. CH Temperature Control

D. Mode Control

E. Boiler Status

F. Burner ‘on’ Indicator

G. Pressure Gauge

H. Condensate Drain

J. Economy Mode

A B E F C J D

G

LOGIC SYSTEM.

15 18 24 30

H

BOILER CONTROLS

A. CH Temperature Control

B. Mode Control

C. Boiler Status

D. Burner ‘on’ Indicator

E. Pressure Gauge

F. Condensate Drain

G. Economy Mode

A G C D B

F

E

In normal operation the control unit (E) will show the following codes:

O - Standby - no demand for heat, C - Central Heating being supplied,

D - DHW being supplied, P - DHW preheat, F - Boiler frost protection

(boiler fires if temperature is below 5°C).

In normal operation the control unit (E) will show the following codes:

If the pressure is seen to fall below the original installation pressure of

1-2 bar over a period of time then a water leak may be indicated. In this event conduct the re-pressurising procedure as shown on page 4 of the User Manual.

BOILER CONTROLS

A. Pre-heat On/Off

B. DHW Temperature Control

C. CH Temperature Control

D. Mode Control

E. Boiler Status

F. Burner ‘on’ Indicator

G. Pressure Gauge

H. Condensate Drain

J. Economy Mode

LOGIC HEAT.

12 15 18 24 30

BOILER CONTROLS

A. Temperature Control

B. Mode Control

C. Boiler Status

D. Burner ‘on’ Indicator

E. Condensate Drain

F. Economy Mode

A F C D B

E

LOGIC COMBI ES/ LOGIC CODE COMBI ES.

24 30 35 26 33 38

A B E F C J D

BOILER CONTROLS

A. Blank

B. DHW Temperature Control

C. CH Temperature Control

D. Mode Control

E. Boiler Status

F. Burner ‘on’ Indicator

G. Pressure Gauge

H. Condensate Drain

J. Economy Mode

H

G

WINTER OPERATION: COMBI.

1. Ensure gas and electric supplies are available and on

(i.e. card meters are topped up).

2. Ensure boiler thermostat (C) is on and set 2/3rds of the way round.

3. Set room thermostat to desired temperature, normally between 20-23°C.

4. Control individual room via Thermostatic Radiator

Valves. 1 - Low, 2 - Low/Average, 3 - Average,

4 - Average/High, 5 - High.

5. Control the heating times by using programmer/clock and not by switching the boiler on and off.

6. Preheat will operate with the preheat switch (A) set to on.

7. For periods of intense cold leave the system on 24 hours a day. Switch the room thermostat down to 10°C overnight. This will maintain comfort levels and ensure the system doesn’t freeze.

(FOR FULL INSTRUCTION DETAILS REFER TO THE

IDEAL LOGIC USERS GUIDE)

47

COMBINATION BOILER

CONTROLS.

PROGRAMMABLE THERMOSTATS AND TIMERS.

Here at Ideal we believe that choosing the right control to meet the needs of your customer is almost as important as choosing the right product; this is why our boilers are fully compatible with a range of thermostats and timers for the ultimate in home comfort.

MECHANICAL TIMER.

(Part No. 204839)

Simple heating control through a plug in analogue timer. 24 hour tappet operation with off/timed/continuous periods.

ELECTRONIC TIMER.

(Part No. 204545)

Easy to use heating control through a plug in digital timer. Plain text operating and diagnostics information. 7 day and up to 3 time periods/day. Automatic summer/ winter time update.

EXTERNAL

ROOM CONTROLS

RF MECHANICAL

PROGRAMMABLE

THERMOSTAT.

(Part No. 204824)

Wireless radio frequency (RF) analogue timer and room thermostat providing heat control. Easy to use 24 hour tappet control.

Image shown is 208774

48

RF MECHANICAL

TIMER AND ROOM

THERMOSTAT KITS.

(Part No. 208352)

RF ELECTRONIC

PROGRAMMABLE

THERMOSTAT.

(Part No. 204789)

Wireless radio frequency (RF) digital timer and room thermostat providing heating control. 7 day, plain text operating and diagnostics display. Automatic summer/winter time update.

Easy to use radio frequency timer (RF), complete with room thermostat. The timer is prewired with plug-in connections to the boiler wiring and features a 24hr tappet operation with off/timed continuous period.

The room thermostat can be freestanding or wallmounted and has a compact design with LCD display and simple symbols to indicate the control.

COMBI, HEAT ONLY & SYSTEM

CONTROLS.

WEATHER COMPENSATION OUTDOOR SENSOR.

(Part No. 211326 - combi models only)

(Part No. 211332 - heat only and system models)

The Logic and Logic Code Combi ES ranges provide weather compensation when fitted with an outdoor sensor (which is available as an optional accessory). Weather compensation works by measuring the temperature outside the home and adjusting the temperature (or flow) of the radiators inside.

If the weather is particularly cold outside, the outdoor sensor will communicate with the boiler intelligently to increase the radiator temperature. This process also works in reverse, as the outdoor temperature increases, the flow to the radiators too will decrease. This process allows the system to operate more efficiently by only heating to the minimum temperature necessary and also preventing spikes in heating activity.

49

50

LPG

CONVERSION KITS.

Designed for use with Logic combi, heat and system 24 & 30 kW

(combi ES 30 kW only) boilers and the new Code Combi ES 38 kW, the Ideal LPG (propane) conversion kit provides a simple and robust gas conversion solution.

With kits available inclusive of natural gas to LPG kits, and LPG to natural gas kits, these quick to install accessories provide a simple and pragmatic solution without the need for products to be adjusted.

Each kit contains specific components for each required boiler type.

FEATURES.

• Available for all product types (combi, heat & system)

• Suitable for most property sizes

• Fast & simple conversion with preset gas valve for no product adjustment

APPLICABLE MODELS.

• Logic Code Combi ES 38

• Logic Combi 24 & 30

• Logic Combi ES 30

• Logic Heat 24 & 30

• Logic System 24 & 30

SPECIFICATION.

BOILER MODEL

Min. output (kW)

Max. output (kW)

COMBI CODE

8.0

24.3

Max DHW output (kW) 30.3

8.7

24.2

38.2

HEAT

8.0

30.3

N/A

SYSTEM

8.0

30.3

N/A

NG-LPG

CONVERSION KIT

LOGIC CODE COMBI ES33

LOGIC CODE COMBI ES33

LOGIC CODE COMBI ES38

LOGIC CODE COMBI ES38

LOGIC COMBI 24

LOGIC COMBI 30

LOGIC COMBI 30

LOGIC COMBI ES30

LOGIC COMBI ES30

LOGIC HEAT 24

LOGIC HEAT 30

LOGIC HEAT 30

LOGIC SYSTEM 24

LOGIC SYSTEM 30

LOGIC SYSTEM 30

PRODUCT

CODE

210391

211381

210394

211382

212115

207649

211370

208433

211379

212114

207651

211372

TBA

207653

211374

LPG-NG

CONVERSION KIT

LOGIC CODE COMBI ES33

LOGIC CODE COMBI ES33

LOGIC CODE COMBI ES38

LOGIC CODE COMBI ES38

LOGIC COMBI 24

LOGIC COMBI 30

LOGIC COMBI 30

LOGIC COMBI ES30

LOGIC COMBI ES30

LOGIC HEAT 24

LOGIC HEAT 30

LOGIC HEAT 30

LOGIC SYSTEM 24

LOGIC SYSTEM 30

LOGIC SYSTEM 30

NATURAL GAS TO LPG KIT CONTENTS

EACH KIT COMPRISES:

• Gas valve (preset operation)

• Burner injector

• BCC (boiler chip card)

• Data plate labels

• Instructions

Use of the preset gas valve ensures the safety feature of a non adjustable gas valve is retained during conversion.

Two data plate labels are provided in the kits inclusive of a new data plate providing LPG details and a label to retain boiler serial number identity.

PRODUCT

CODE

177370

177527

177371

177528

177868

176657

177514

176823

177525

177867

176659

177516

TBA

176661

177518

51

FLUE SITING.

There are a substantial number of flueing options available with the Ideal ranges, giving excellent siting flexibility for almost all applications.

The range of options include standard and telescopic flues as well as roof flue and powered vertical flue options.

To ensure siting issues are kept to a minimum High Level Flue Outlet kit options and Flue

Deflector kits are available.

Minimum dimensions of flue terminal positions.

FLUE TERMINAL POSITION

1. Directly below, above or alongside an opening window, air vent or

other ventilation opening.

2. Below guttering, drain pipes or soil pipes.

BS5440-1 2008

3. Below eaves.

BS5440-1 2008

4. Below balconies or car port roof.

BS5440-1 2008

5. From vertical drain pipes or soil pipes.

BS5440-1 2008

6. From an internal or external corner or to a boundary alongside the

terminal.

BS5440-1 2008

7. Above ground, roof or balcony level.

8. From a surface or a boundary facing a terminal.

9. From a terminal facing a terminal.

10. From an opening in a car port (eg. door or window) into dwelling.

11. Vertically from a terminal on the same wall.

12. Horizontally from a terminal on the wall.

MIN. SPACING

300mm (12")

25mm (1")*

75mm (3")

25mm (1")*

200mm (8")

25mm (1")*

200mm (8")

25mm (1")*

150mm (6")

25mm (1")*

300mm (12")

300mm (12")

600mm (24")

1200mm (48")

1200mm (48")

1500mm (60")

300mm (12")

VERTICAL FLUES

13. Above the roof pitch with roof slope of all angles. Above flat roof.

14. From a single wall face.

From corner walls.

15. Below velux window.

16. Above or side of velux window.

300mm (12")

300mm (12")

300mm (12")

300mm (12")

2000mm (79")

600mm (24")

* Only one reduction down to 25mm is allowable per installation otherwise BS5440-1 2008 dimensions must be followed.

52

1

4

7

8/9

14

6

10

1

2/3

13

15/16

6

6

12

12

5

7

11

11

B

B

A

A

A

A

A

B

A = 600mm

B = 2000mm

The flue terminal shall not penetrate the shaded area of the roof.

RF9807

If chimney penetrates dotted area such that A is less than 300mm, B shall not be less than 300mm.

53

54

ACCESSORIES.

LOGIC COMBI (ES), SYSTEM & HEAT

FLUEING ACCESSORIES

Telescopic B pack flue

Horizontal flue terminal

(600mm long)

Horizontal flue terminal

(1000mm long)

Flue elbow 90° kit (60/100) packaged

Flue elbow 45° kit (60/100) packaged (pair)

Flue extension 1000mm (Pack D)

Flue extension kit 500mm

(Pack D)

Flue extension kit 2000mm (Pack D)

Flue vertical connector

Powered vertical flue kit 100mm

Flue deflector 60 dia

Weather collar (universal) 100mm

Weather collar (flat roof) 100mm

Flue finishing kit

Roof flue kit

Powered flue kit

Rear flue outlet kit (55/80)

Flue finishing kit (55/80)

Secondary flue extension (1000x80mm) pair

211037

211038

208175

203134

208176

152258

152259

155988

211039

203136

205990

206151

203142

IDEAL

PART NO.

208169

208171

COMBI

ü

ü

208174

ü

203130

ü

203131

ü

203129

ü

ü

ü

ü

ü

ü

ü

ü

ü

û

û

ü

ü

ü

HEAT SYSTEM

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

ü

û

û

ü

ü

ü

ü

ü

ü

ü

INSTALLATION ACCESSORIES

Stand off kit

Stand off kit (Heat only)

Stand off kit (Inc. piping, 206679)

Condensate pump kit

Terminal wall plate PS replacement kit

(Combi/System)

Terminal wall plate RS replacement kit (Heat)

Pressure gauge extension kit

Weather compensation kit

Weather compensation kit

Pre-piping kit

Pre-piping kit

Security bracket kit

Opentherm harness kit

PRV wall outlet pipe kit

DHW expansion vessel kit

LOGIC (ALL MODELS)

Balcony flue outlet kit

Soffit kit

Raised horizontal flue outlet kit

IDEAL

PART NO.

211103

206153

211108

159991

211318

206164

206712

211326

211332

211041

211331

205217

211327

205126

205419

COMBI

ü

ü

ü

û

ü

û

ü

û

ü

û

ü

ü

ü

ü

ü

HEAT SYSTEM

û

ü

û

ü

ü

û

ü

ü

û

ü

û

û

û

û

û

ü

û

211330

ü

ü

ü

ü

ü

û

û

ü

û

û

ü

û

IDEAL

PART NO.

208177

211302

208290

55

56

ACCESSORIES.

HIGH LEVEL FLUE OUTLET KIT

These easy to install kits allow the boiler flue outlet to be extended external to the building, upwards to provide a flue exit at high level, overcoming problems associated with plume emission. The kit can be simply fitted retrofitted if necessary (excluding rear outlet of

Logic Heat).

An external 60mm diameter flue leads from the boiler terminal (which includes a 90° elbow at the flue exit) to terminate with a 90° elbow complete with grille. Push fit one metre extension pipes are used as required, and the fixing clips supplied support the system from the wall.

Both 90° and 45° elbows are available to provide routing options.

THE KIT COMPRISES:

Flue elbow - 1 off

60mm flue exit elbow - 1 off

60mm horizontal flue exit - 1 off

60mm x 500mm flue outlet Extension pipe - 1 off

This kit is specified for use with the normal standard B pack.

The standard terminal nose is replaced with the high level terminal.

Diagram representative only.

The kit comprises: Concentric terminal including fitted 90˚ flue elbow.

(This is specified in place of the normal standard B pack terminal).

60mm flue elbow and terminal.

diagram representative only

IMPORTANT

Flue must always slope at least 1 1 /

2

˚ back to the boiler

Vertical

Horizontal left or right 45˚ left or right

Telescopic B pack flue

Ideal Part No.

204768

Flue vertical connector

Horizontal flue terminal

(600 long)

Horizontal flue terminal

(1000 long)

Ideal Part No.

204644

Powered vertical flue kit 100mm

Ideal Part No.

204664

Flue deflector

60 dia

LOGIC (ALL MODELS) IDEAL

PART NO.

208178 High level flue outlet kit

Logic Heat rear flue outlet (55/80) ONLY high level flue outlet kit (55/80)

1m x 60mm extension pipe (with bracket)

205989

203228

90° elbow 203229

Flue Elbow 90º kit (60/100)

Flue Elbow 45º kit (60/100) packaged (pair) following resistances (metres) from the maximum boiler flue length.

LOGIC (ALL MODELS)

90° elbow

45° elbow (pair)

Ideal Part No.

203130

Ideal Part No.

203131

Weather collar

(universal)

100mm

Weather collar

(flat roof) 100mm

METRES

1.4

1.25

Ideal Part No.

204913

Flue finishing kit

Stand off kit **

Inc. piping

Ideal Part No.

204872

Condensate

Pump Kit

57

Ideal Part No.

204645

Ideal Part No.

203134

Ideal Part No.

203137

Ideal Part No.

152258

Flue high level outlet kit

A B

C

High level flue extension kit (1m)

High level flue

90º elbow

High level flue

45º elbow (pair)

Ideal Part No.

152259

Ideal Part No.

155988

Ideal Part No.

******

Ideal Part No.

204912

Ideal Part No.

203228

Ideal Part No.

203229

Ideal Part No.

203230

ACCESSORIES.

LOGIC CODE COMBI ES

FLUEING ACCESSORIES

Telescopic B pack flue

Horizontal flue terminal (600mm long)

Horizontal flue terminal (1000mm long)

Flue elbow 90° kit (60/100) packaged

Flue elbow 45° kit (60/100) packaged (pair)

Flue extension 1000mm (Pack D)

Flue vertical connector

Powered vertical flue kit 100mm

Flue deflector 60 dia

Weather collar (universal) 100mm

Weather collar (flat roof) 100mm

Flue finishing kit

Roof flue kit

Powered flue kit

Concentric flue screw retaining kit

Secondary flue extension (1000x80mm) pair

58

INSTALLATION ACCESSORIES

Stand off kit

Stand off kit Inc. piping

Condensate pump kit

DHW expansion vessel kit

Pressure gauge extension kit

Weather compensation kit

Pre-piping kit

Security bracket kit

Opentherm harness kit

PRV wall outlet pipe kit

IDEAL PART NO.

208176

152258

152259

155988

211039

203136

205024

203142

208169

208171

208174

203130

203131

203129

208175

203134

IDEAL PART NO.

206383

206679

159991

205419

206712

204914

206704

206708

204915

205126

CONTACT US.

Should you need assistance from any of our specialist teams they are on hand to help you

7 days a week, 364 days a year.

CUSTOMER SERVICE

Tel: 01482 498660

SALES ORDERS AND ENQUIRIES

Tel: 0844 498056

TECHNICAL HELP

Tel: 01482 498663

IDEAL GENUINE PARTS

Tel: 01482 498665

MAIN RECEPTION

Tel: 01482 492251

59

GREAT

BOILERS

FROM

GREAT

BRITAIN.

Ideal Boilers

PO Box 103

National Avenue

Kingston upon Hull

East Yorkshire

HU5 4JN

T 01482 492251

WWW.IDEALBOILERS.COM

09.2015 211133 v6

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
