VMX Digital Solid State Soft Starter User Manual 1 | P a g e

Chapter 1 - Introduction

1.1 General Description

The VMX Series is a digitally programmable solid-state reduced voltage soft starter. Its six SCR design features a voltage/current ramp with an anti-oscillation circuit for smooth load acceleration. The SCRs are sized to withstand starting currents of 350% for 30 seconds and up to 600% for 10 seconds. The VMX Series features smooth, stepless ramp control, which reduces motor inrush current and excessive wear on the mechanical drive train components. The VMX Series includes a programmable keypad for setting operating parameters for the ideal starting cycle and protection features, plus easy to understand diagnostic LEDs. Starting torque, ramp time, current limit, dual ramp, and Decel control are standard features on the VMX Series, as well as the integrated Batch Process Timer and Time Clock Controller used for automated applications. By simply adjusting the unit‟s starting torque, ramp time and current limit functions, the starting electrical characteristics of the motor can be matched to the mechanical characteristics of the drive train for controlled acceleration of the load.

The VMX Series includes solid-state electronic overload protection in addition to numerous other protective features. It requires 120VAC

(220VAC optional) control power and uses dry contact inputs for Start /

Stop control. Programmable auxiliary contacts and provisions for interlocking are also included.

Acceleration Adjustments

Dual Ramp Settings

1.1.1 Control Features

Programmable Ramp Types:

Voltage Ramp (VR) or closed loop Current Ramp (CR)

Starting Torque: 0 - 100% of line voltage (VR)

or 0 - 600% of motor FLA (CR)

Ramp Time: 1 to 120 seconds

Current Limit: 200 - 600% (VR or CR)

4 Options:

Ramps 1 & 2 = VR,

Ramp 1 = VR, Ramp 2 = CR,

Ramps 1 & 2 = CR;

Ramp 1 = CR, Ramp 2 = VR

Dual Ramp Control:

Ramp #1 = Default,

Ramp #2 = Selectable via dry contact input

Deceleration Adjustments

Begin Decel Level: 0 - 100% of line voltage

Stop Level: 0 to 1% less than Begin Decel Level

Decel Time: 1 - 60 seconds

Programmable to Decel or coast to stop upon overload trip

Jog Settings

Jog function selected via dry contact closure input.

Jog Voltage: 5 - 100%

Time of Jog Voltage: 1 - 20 seconds

Jog Current: 100 - 500%

Kick Start Settings

Kick Voltage: 10 - 100%

Kick Time: 0.1 - 2 seconds

Process Timer

(2 modes)

Minimum Batch Timer: Runs until timer expires

Maximum Batch Timer: Runs unless timer expires

Range: 0 - 9999 minutes

Real Time Clock (RTC)

Controller

24/7 Time Clock Controller

Range: 1-24 hours, and 1- 7 days per week,

1 - 7 start events per day, works with Process Timer for run time

VMX Digital Solid State Soft Starter User Manual 1 | P a g e

Thermal Model Electronic

Overload Protection

1.1.2 Advanced Motor Protection Features

A sophisticated Thermal Model of the motor operation is created in the microprocessor to accurately track all starting, stopping and running conditions thus, providing maximum motor protection.

Two Stage

Overload Curves

Starting: Programmable for Class 5 or 10

Run: Programmable for Class 5 through 30 when "At-Speed" is detected.

Overload Reset

Manual (default) or automatic.

Retentive Thermal Memory

Dynamic Reset Capacity

Current Imbalance Trip

PTC Input Trip

Over Current Trip

(Electronic Shear Pin)

Phase Loss

Equipment Ground Fault

Protection

Load Loss Trip

Coast Down (Back Spin)

Lockout Timer

Starts-per-hour Lockout

Overload circuit retains thermal condition of the motor regardless of control power status. Unit uses real time clock to adjust for off time.

Overload will not reset until thermal capacity available in the motor is enough for a successful restart. Starter learns and retains this information by monitoring previous successful starts.

Trip Level: 5 - 30% Imbalance in any two phases

Trip Delay: 1 -20 seconds

Trips on greater than 750 ohms resistance on a dedicated PTC input. Can be used with an Emergency Stop or any other External Lockout.

Trip Level: 50 - 300% of motor FLA

Trip Delay: 1 - 20 seconds

Trips on any phase current less than 20% of unit rating.

Can be disabled in programming for testing with smaller loads.

Type: Residual Current Trip

Range: 5

– 90% of unit CT ratio

Trip Delay: 1

– 60 seconds

Under Current Trip Level: 10

–90 % of motor FLA

Trip Delay: 1

– 60 seconds

Prevents restart when motor may be spinning backwards.

Coast Down Time Range: 1

– 60 minutes.

– 10 successful starts per hour

Minimum Time between

Starts Lockout

Restart Delay

Auto Reset

Power Device Monitoring

Range: 1

– 60 minutes between start attempts

Sequential Start Feature for restarting delay after a power outage.

1-999 seconds after a power loss.

Can be programmed to attempt resetting after selected faults.

– 10 Attempts, 0 – 999 minutes delay between attempts.

Shorted SCR Lockout (1 shorted SCR) and independent Shunt Trip (multiple shorted SCRs). Can be disabled in programming.

VMX Digital Solid State Soft Starter User Manual 2 | P a g e

1.1.3 Design Specifications

Three phase AC induction motors.

Type of Load:

AC Supply Voltage:

Power Ratings:

Universal, 208 - 600VAC ±10%, 50/60 Hz.

18 - 1250 Amps, 7.5 - 1000 HP @ 460V.

Unit Capacity - Continuous

Max. Amp rating is UL Listed continuous rating.

Unit Capacity - Overload Rating

(Percent of motor FLA)

Power Circuit

SCR Firing Angle Detection

350% - 30 seconds.

600% - 10 seconds.

6 SCRs, full phase ang le firing using a hard fire picket firing circuit and “Back

Porch” DC carryover to avoid motor transient problems.

6 pulse Independent Locked Phase Tracking with Auto-synchronization, prevents misfiring on unstable source frequency.

SCR PIV Ratings

(Peak Inverse Voltage)

1600V

Phase Rotation

Operates with any phase sequence, or programmable rotation trip, ABC / ACB / Off.

Transient Protection

RC snubber dV/dt networks on each phase.

Cooling

Fan assisted convection.

Bypass Contactor

Standard on all NEMA 12 enclosed units.

Units 160A and less: Standard on all open panel units (-BP versions).

Units 210A and over: Optional on open panel units (-BP versions).

Bypass Contactor Rating Shunt rated or can be sized for Line start rated contactor. (see charts)

Bypass Contactor Control Integral control is included, but contactor can be externally controlled as well.

Open panel mount units: 0° to 50 °C (32° to 122°F)

Ambient Condition Design

Control Power

Inputs

Programmable Outputs

Output Relay Contact Rating

Dedicated Fault Output

Approvals

Factory enclosed units: 0° to 40°C (32° to 104°F)

5 - 95% relative humidity.

0 - 3300 ft. (1000m) above sea level without derating.

120VAC (customer supplied), 240VAC optional.

6 Dry (voltage free) contact inputs using 24VDC from an internal power supply.

3 relays, 2 each Form C (SPDT), 1 each Form A (SPST).

Can be programmed for 26 functions, with delays or flashing.

5 Amps, 240VAC max. (1200VA)

AC triac solid state switch.

240VAC/DC, 50mA max.

UL Listed, Canadian UL (cUL) Listed CE Approved.

VMX Digital Solid State Soft Starter User Manual 3 | P a g e

Table 1.2 VMX Series Range

Model

Number

Current

Range

Min.- Max.

VMX-18-BP

VMX-28-BP

VMX-39-BP

VMX-48-BP

VMX-62-BP

VMX-78-BP

VMX-92-BP

VMX-112-BP

VMX-150-BP

VMX-160-BP

VMX-210-BP or -P

VMX-276-BP or -P

VMX-360-BP or -P

VMX-450-BP or -P

VMX-550-BP or -P

VMX-600-BP or -P

VMX-862-BP or -P

VMX-900-BP or -P

VMX-1006-BP or -P

VMX-1250-BP or -P

80 - 160

105 - 210

138 - 275

181

– 361

225

– 450

275

– 550

300 - 600

431 - 862

450 - 900

503 - 1006

625 - 1250

9 - 18

14 - 28

19 - 39

24 - 48

36 - 62

39 - 78

46 - 92

56 - 112

75 - 150

1.2 Sizes and Ratings

The Motortronics VMX Series starters are current rated controllers.

Max. Amp ratings are for continuous duty and must not be exceeded.

Always check the motor nameplate FLA and Service Factor to ensure proper sizing.

Each size has an adjustable current range from 50% to 100% of the

Max Amp rating. Table 1.2 shows the Current Ratings available.

1.2.1 Selecting for Service Factor Utilization

Many NEMA design motors include a design rating referred to as Service Factor (SF) that may allow continuous operation above the nameplate current rating. If using this Service

Factor, the VMX Series starter must be sized for the total amps used. For proper selection of the VMX Series starter when using SF continuously, multiply the nameplate FLA by the stated Service Factor, or use stated Service Factor Amps

(SFA) if listed on the nameplate. The following excerpt is from the NEMA MG-1 standards for AC Motors that describes the issues concerning the use of Service Factor ratings.

"When an induction motor is operated at any service factor

greater than 1.0, it may have efficiency, power factor and speed different than those at rated load. Locked rotor torque and current and breakdown torque will remain the same. A motor operating continuously at any service factor greater than

1.0 will have a reduced life expectancy compared to operating

at its nameplate horsepower."

When using this feature, simply program the VMX Series

Service Factor (F002) to the nameplate rating. (See section

5.6.1.) All other adjustments to the protection circuits are done automatically within the VMX Series.

1.2.2 Selecting for Across the Line Bypass

If you need to be able to start the motor Across-the-Line when the VMX Series electronics are out of service, the starter can also be selected based upon the rating of the Bypass

Contactor. Some users may also elect to size their Bypass

Contactors per NEMA guidelines. When doing this, please refer to the Product Selection Guide for details and notes, and see Appendix 5 for special considerations

regarding Overload Protection.

 Note:

The

VMX…-BP Series starters include the ability to connect a dry contact directly to the Bypass Contactor coil control circuit. These terminals are covered when shipped and should be used ONLY when necessary for Emergency Bypass operation and with an external Overload Relay. See Appendix 5 for additional information.

No field wiring to these terminals is necessary if this feature is not used.

VMX Digital Solid State Soft Starter User Manual 4 | P a g e

Chapter 2 - Installation

2.1 Receiving and Unpacking

Upon receipt of the product, you should immediately do the following:

 Carefully unpack the unit from the shipping carton and inspect it for shipping damage. If damaged, notify the freight carrier and file a

claim within 15 days of receipt.

 Verify that the model number on the unit matches your purchase order.

 Confirm that the ratings nameplate on the unit matches or is greater t han the motor‟s HP and current rating with which it is to be used.

2.2 Choosing a Location

Proper location of the VMX Series is necessary to achieve specified performance and normal operational lifetime. The VMX Series should always be installed in an area where the following conditions exist:

 Ambient operating temperature:

Panel (open chassis) unit: 0 to 50°C (32 to 122°F)

Enclosed unit: 0 to 40°C (32 to 104°F)

 Protected from rain, moisture and direct sun.

 Humidity: 5 to 95% non-condensing

 Free from metallic particles, conductive dust and corrosive gas.

 Free from excessive vibration. (below 0.5G)

 Open panel units must be mounted in the appropriate type of enclosure. Enclosure size and type must be suitable to dissipate heat generated by the soft starter and any other components mounted inside with it.

 Units with –BP Bypass Contactors produce less heat than units without. Throughout all sizes, maximum heat dissipation of the

VMX…-BP Series electronics, contactor coils and fans is less than

50W.

 Units without the –BP Bypass Contactor (optional on 210A and above), must have ventilation adequate for heat dissipation of the

SCRs. This is estimated at 4.5 watts per running load amp. For example, a 200HP 460V motor with 240FLA, the maximum wattage loss of a starter w/o bypass will be 240 x 4.5, or 1080 watts. The enclosure ventilation (or air conditioning) must be capable of dissipating the amount of heat due to this wattage loss to maintain the enclosure below temperature limits.

 Care should always be taken to maximize the available space inside of the enclosure. See section 2.5.1 or contact factory for assistance in sizing enclosures.

2.3 Initial Unit Inspection

Make a complete visual check of the unit for damage that may have occurred during shipping and handling. Do not attempt to continue installation or start up the unit if it is damaged.

 Check for loose mechanical assemblies or broken wires which may have occurred during transportation or handling. Loose electrical connections will increase resistance and cause the unit to function improperly.

 Prior to beginning the installation, verify that the motor and VMX

Series unit are rated for the proper amperage and voltage.

VMX Digital Solid State Soft Starter User Manual 5 | P a g e

2.4 SERVICE WARNING!

Do not service equipment with voltage applied! The unit can be the source of fatal electrical shocks! To avoid shock hazard, disconnect main power and control power before working on the unit. Warning labels must be attached to terminals, enclosure and control panel to meet local codes. Use Lock Out tags such as the one shown when servicing equipment.

2.5 Mounting and Cleaning

When drilling or punching holes in the enclosure, cover the electrical assembly to prevent metal filings from becoming lodged in areas which can cause clearance reduction or actual electrical shorts. After work is complete, thoroughly clean, vacuum the area, and re-inspect the unit for foreign material.

2.5.1 Clearances

Make sure there is sufficient clearance all around the unit for cooling, wiring and maintenance purposes. To conserve panel space, the VMX

Series

– BP models were designed for close vertical clearances of only

1 inch (25mm) on either side. A minimum horizontal clearance of 4”

(100 mm) on the top and bottom is necessary to maximize effective airflow and cooling. Also the unit must be installed with its heat sink ribs oriented vertically and running parallel to the mounting surface. Keep in mind that these are minimums. Wiring may require more clearance, particularly on the bottom.

4" minimum (100 mm)

1" minimum (25 mm)

VMX Series

Starter

4" minimum (100 mm)

Figure 2.5: VMX minimum mounting clearances

VMX Digital Solid State Soft Starter User Manual 6 | P a g e

VMX-18 ~

VMX-48

Line

R/L1 S/L2

1.50"

(38.07 mm)

T/L3

Load

V/T2

U/T1 W/T3/

1.10"

(27.92 mm)

WARNING!

Remove all sources of power before cleaning the unit.

In dirty or contaminated atmospheres, the unit should be cleaned on a regular basis to ensure proper cooling. Do not use any chemicals to clean the unit. To remove surface dust use clean, dry compressed air only, 80 to 100 psi. A three-inch, high quality, dry paintbrush is helpful to loosen up the dust prior to using compressed air on the unit. Do not use wire brushes or other conductive cleaning materials

2.6 Power Terminations

Load

All line and load power terminations are to be made to tin plated copper

Bus Tabs located on each unit. Bus tabs are pre-drilled to accept industry standard bolts. Some sizes come with saddle clamp terminals, however the connecting lugs are the responsibility of the user.

Motortronics recommends using crimp-on lugs, although mechanical lugs are suitable as well. The following diagrams show sizes of the bus tab holes and critical spacing between them for determining the size of lug that can be used.

Note: All wiring must be sized according to local code standards.

VMX-62 ~

VMX-112



0.19"

(4.82 mm)

Line

1.82"

(46.19 mm)

Load

1.73"

(43.91 mm)



0.38"

(9.64 mm)

0.45"

(11.42 mm)

Figure 2.6.1 Critical clearances for bus tab connections

1.23"

(31.22 mm)

R/L1

S/L2

Line

0.60"

(15.23 mm)

T/L3

U/T1

V/T2

W/T3

Load

1.13"

(28.68 mm)

Figure 2.6.2 Critical clearances for bus tab connections

VMX Digital Solid State Soft Starter User Manual 7 | P a g e

2.6 Power Connections (cont.)

VMX-150 ~

VMX-160

0.14"

(3.55 mm)

Line Load

1.52"

(38.58 mm)

1.54"

(39.09 mm)

2.81"

(71.32 mm)

T/L3

R/L1

S/L2

Line

0.60"

(15.23 mm)

U/T1

V/T2

Load

W/T3



0.38"

(9.64 mm)

Figure 2.6.3 Critical clearances for bus tab connections

Note: Consult factory for bus tab critical dimensions for units 210A

and above

VMX Digital Solid State Soft Starter User Manual 8 | P a g e

2.6.1 Power Terminals:

Connection points for units of 160A and below are saddle clamps suitable for stranded wire. Connection points for units of 210A and above are bus tabs with pre-drilled holes (see below). Use appropriate compression or mechanical lugs for termination to these bus tabs.

Suggested wire sizes and tightening torques for factory-supplied connectors for conductors rated for 75



C are shown in the chart below.

Always consult local codes and industry standard practices for proper wires sizes to accommodate voltage drop and ambient conditions.

Table 2.6: VMX Series Wire Ranges and Torque Specifications

Model

Number

VMX-18-BP

VMX-28-BP

VMX-39-BP

VMX-48-BP

VMX-62-BP

VMX-78-BP

VMX-92-BP

VMX-112-BP

VMX-150-BP

VMX-160-BP

VMX-210-BP or -P

VMX-276-BP or -P

VMX-360-BP or -P

VMX-450-BP or -P

VMX-550-BP or -P

VMX-600-BP or -P

VMX-862-BP or -P

VMX-900-BP or -P

VMX-1006-BP or -P

VMX-1250-BP or -P

Current Range

Min.- Max.

9 - 18

14 - 28

19 - 39

24 - 48

Suggested

Wire Size

AWG

Tightening

Torque in.-lbs.

Screw / Bolt

Size

1 x M5

(included)

36 - 62

39 - 78

46 - 92

56 - 112

1 x M8

(included)

75 - 150

80 - 160

2/0

1 x M8

(included)

105 - 210

138 - 276

180 - 360

225 - 450

275 - 550

300

– 600

431

– 862

450

– 900

503 - 1006

4/0

300 kCMIL

500 kCMIL

2 x 250 kCMIL

TBD

200

TBD

1 x 0.38" hole

(M10) for User supplied

lugs

TBD

625 - 1250

TBD TBD

Note: TBD = To Be Determined at a later date

TBD

Tightening

Torque

TBD

2.7

Remote Keypad Mounting

The keypad / operator interface unit can be remotely mounted up to 10‟

(3 meters) away from the starter, i.e. on the enclosure door. A remote mounting kit is necessary, which consists of an adaptor plate, a doorframe for NEMA 1 or NEMA 12 enclosures and a pre-assembled ribbon cable available in 1-meter length increments. Detailed assembly instructions and an enclosure cutout template are included with the kit.

See Product Selection Guide for part numbers of the available kits.

Adaptor Plate

NEM A 1 or

NEM A 12

Door Frame

~ ~

Figure 2.7

Remote Keypad Mounting Kit

Components

Suggested

Wire Size

ISOmm

120

150

300

2 x 150

TBD

Ribbon Cable ,

1, 2 or 3 me te rs

VM X Starte r

VMX Digital Solid State Soft Starter User Manual 9 | P a g e

Enclosure

2.8

Dimensions (consult price catalog for enclosed units)

Model Number

Table 2.8: VMX Dimensions and Weights

Inches

(mm)

Overall

Inches

(mm)

Inches

(mm)

Inches

(mm)

Mounting

Inches

(mm)

Inches

(mm)

Weight lbs

(kg)

VMX-18-BP through

VMX-48-BP

9.06

(230)

8.00

(203)

6.68

(169.7)

8.06

(204.7)

7.00

(177.8)

0.22

(5.6)

13 (5.9)

VMX-62-BP through

VMX-112-BP

14.00

(355.6)

8.00

(203)

6.68

(169.7)

13.25

(336.6)

6.75

(171.5)

0.28

(7.1)

(10.4)

VMX-150-BP and

VMX-160-BP

19.21

(487.9)

8.00

(203)

6.68

(169.7)

18.25

(463.6)

6.75

(171.5)

0.28

(7.1)

(15.9)

Panel (open) with integral bypass contactor

VMX -210-BP and

VMX-275-BP

VMX-361-BP and

VMX-450-BP

VMX-550-BP through

VMX -600-BP

VMX-862-BP through

VMX-900-BP

28.50

(723.9)

29.29

(744)

30.98

(786.9)

44.25

(1124)

12.5

(317.5)

12.5

(317.5)

12.5

(317.5)

25.5

(647.7)

9.03

(229.4)

9.03

(229.4)

9.05

(229.9)

11.86

(301.3)

27.38

(695.5)

27.38

(695.5)

10.75

(273.1)

10.75

(273.1)

27.38

(695.5)

10.75

(273.1)

27.38

(695.5)

10.75

(273.1)

0.40

(10.2)

0.40

(10.2)

0.40

(10.2)

0.40

(10.2)

(40.9)

105

(47.7)

120

(55)

Contact

Factory

Panel

(open), fan cooled, without bypass contactor

VMX-1006-BP through

VMX -1250-BP

50.77

(1289.6)

25.5

(647.7

13.28

(337.3)

27.38

(695.5)

Under 210A, use

–BP version as shown above

10.75

(273.1)

VMX-210-P through

VMX-1250-P

20.25

(514.35)

12.5

(317.5)

9.05

(229.9)

19.00

(482.6)

0.40

(10.2)

10.75

(273.1)

0.40

(10.16)

Contact

Factory

Contact

Factory

F dia.

Figure 2.8: VMX Dimensions

~ ~

B C

VMX Digital Solid State Soft Starter User Manual 10 | P a g e

Chapter 3 - Motor Overload Protection

MOTOR FLA (F001) must be programmed for unit to operate!

3.1 Solid State Overload Protection

The VMX Series Starter provides true U.L. listed I

2 t Thermal Overload

Protection as a built-in function of the main digital processor for maximum motor protection. It simulates the tripping action of a bimetallic overload relay, with the accuracy and repeatability of a digital control system. It is adjustable over a wide range and can be easily programmed for different trip curves.

Examples:

H 100

100% Thermal Capacity remaining at rest

H 057

57% Thermal Capacity remaining after starting

(43% used)

3.1.1 Thermal Memory

The VMX Series microprocessor uses a sophisticated “Thermal

Register” in the digital memory to keep track of motor heating and cooling over time regardless of the start er‟s power status. By using nonvolatile memory, the VMX Series does not “forget” that the motor has been running even if power to the starter is turned off and turned back on. Continuous overload protection is provided based on the true thermal condition of the motor.

3.1.2 Thermal Capacity

The Thermal Register is displayed as a percentage. This percentage is the motor‟s remaining thermal capacity. The percentage value begins at

100, showing that the motor is cool (has 100% of its capacity available).

As the motor heats up or moves toward an overload condition, the percentage begins to drop. The Thermal Capacity is derived from the programmed motor nameplate Full Load Amps (FLA) in Function F001, the Service Factor rating in Function F002, and the Overload Trip Class in Functions F003 and F004. Setting these functions to the proper values provides maximum protection and eliminates nuisance tripping.

The Remaining Thermal Capacity can be viewed by using the UP or

DOWN arrow keys when in the Status Display mode. From the default

Phase A Current screen (dot on right side), press the UP arrow key 4 times to display [H100] meaning there is 100% of the Thermal Capacity

(H = Heat capacity) remaining in the motor. After starting or running, the motor will use this capacity and the display will show a lower number.

For example, after a cold start, the display may read [H065] which indicates that the motor has 65% of its thermal capacity remaining (35% used). The Status Display screens cycle back to the beginning, so the

Down arrow keys can access this display as well.

 3.1.2.a

Motor Full Load (FLA) Setting

Use Function F001 to enter motor FLA as indicated on the motor nameplate. (Do not calculate for service factor, this is programmed separately in F002).

 Note:

All VMX Series starters are shipped from the factory with F001 set to a default value of 0000. If F001 is left at the factory default, the unit will not operate. If the user attempts to start the VMX Series without entering the motor nameplate FLA, the starter will Fault and the display will read “nFLA” (no Full Load Amps).

VMX Digital Solid State Soft Starter User Manual 11 | P a g e

3.1.3 Disabling the Overload Protection

The Overload Protection feature can be disabled if necessary. When using external devices such as Motor Protection Relays or when the

VMX Series is wired downstream from an existing starter, this feature can be disabled to prevent conflicts with external overload protection devices. When the VMX Series is controlling multiple motors, the builtin Overload protection must be disabled and individual thermal overload relays must be installed on the motor leads going to each motor (see appendix 5 for additional details). To disable the Overload Protection function, use F005.

WARNING!

Do NOT disable Overload Protection unless another Thermal Overload Protection

device exists in the circuit for all three phases. Running a motor without Overload

Protection presents serious risk of motor damage or fire.

 3.1.3.a

Manual Reset

The factory default setting is Manual Reset. This means that when the Overload Trip is activated, the starter cannot be restarted without pressing the Reset key. The Overload Trip will not reset until the motor cools down (see 3.1.3.d). The Manual Reset function is also “trip free”. Holding in the Reset key will not prevent the

Overload Trip from activating and protecting the motor.

 Note:

When the Overload Trip activates, the Overload LED will be on solid. When the motor cools down, the LED will begin to flash, indicating that the Overload Trip can be reset.

 3.1.3.b

Automatic Reset

If Automatic Reset is necessary, change from Manual Reset to

Automatic Reset by using Function F005. (See Section 5 for details). In this mode, a 3-wire control circuit will be capable of restart when the VMX Series has reset itself after the cool down period.

WARNING!

Two-wire control systems may restart without warning when Auto

Reset of the overload protection is selected. Extreme caution should be exercised. To prevent automatic restarting with 2-wire control systems, use external interlocking to provide sufficient warning and safety to operators. A Warning Label similar to that shown below (and the one provided in the packet with this manual) must be located where visible (on the starter enclosure and/or the driven equipment) as required by local code.

WARNING: MOTOR CONNECTED TO THIS EQUIPMENT

MAY START AUTOMATICALLY WITHOUT WARNING

VMX Digital Solid State Soft Starter User Manual 12 | P a g e

 3.1.3.c

Overload Protection During Bypass

When an integral Bypass Contactor is used to shunt power around the SCRs in the VMX Series

(as in the VMX…-BP version), overload protection is maintained as long as the VMX Series is directly controlling the contactor. No additional Overload Relay is

necessary for normal operation.

Caution:

If a Bypass Contactor is added by the user in the field (i.e. 210A units and above), care must be taken to ensure proper power routing to ensure functioning of the Overload protection. Consult factory for assistance.

 When the Bypass Contactor on a VMX…-BP Series has been selected to be used for Across-the-Line restart (reference section

1.2.3), supplemental overload protection may be necessary. For this application, refer to the External Overload Relay Applications supplement and wiring diagram in Appendix 5 and section 4.2.6.a.

 3.1.3.d

Dynamic Reset Capacity

The VMX Series includes the ability to dynamically track the

Thermal Capacity needed for a successful restart after an overload trip. It averages the Thermal Capacity consumed in the previous three successful starts, and calculates a Thermal Capacity to Start

(viewed in Function F059). After tripping on Overload, the Thermal

Reset will be allowed. If the display reads [ Inh] when attempting to reset an overload trip, it is indicating that the starter is Inhibited from being reset.

Refer to details of Function F071 for information on emergency override of lockouts such as this.

3.2 NEMA Class Trip Curves

NEMA Class trip curves are based on a common tripping point of 600% of motor Full Load Amps (FLA). Curves vary by the amount of time before the unit trips. As an example, a Class 20 curve will trip in 20 seconds at 600% of FLA. The factory default setting of Class 10 will trip in 10 seconds at 600% of FLA.

3.2.1 Dual Overload Trip Curves

The VMX Series Soft Starter provides two separate Overload Trip

Protection Curves, one for starting and one for running conditions. The starter‟s At-Speed detection circuit determines when the motor has reached full speed. When the At-Speed condition is reached, the overload trip curve will shift from the Start to the Run level, as programmed in Functions F003 and F004. See Section 5.6.1 for programming details.

3.2.2 Starting Overload Trip Curve

During the start mode, Overload Trip Curves are selectable from NEMA

Class 5 through Class 20 only. The default setting of Class 10 allows protection for the overload capacity of the soft starter as well as the motor. Use a higher Trip Class only if nuisance tripping occurs with the default setting.

VMX Digital Solid State Soft Starter User Manual 13 | P a g e

3.2.3 Running Overload Curve

During the Run mode, Overload trip curves are selectable from NEMA

Class 5, 10, 15, 20, 25, and 30. Program the appropriate curve according to the characteristics of your motor and load.

3.2.4 Overload Trip Curve Chart

Figure 3.2.4: VMX Series Overload Trip Curves

VMX Digital Solid State Soft Starter User Manual 14 | P a g e

Chapter 4 – Connections

Disconnect or

Circuit

Breaker

R /

U /

S /

V /

MTR

T /

W /

VMX Starter

Solid State .

Over Load .

Integral

Bypass

Contactor*

Figure 4.1:

VMX Power Connections

4.1 Power Connections

Referring to local code standards for wire sizing and length, connect power conductors to the unit input terminals marked L1, L2, L3 (R, S, T for IEC users). Connection points for units of 160A and below are saddle clamps suitable for stranded wire. Connection points for units of

210A and above are bus tabs with pre-drilled holes (see section 2). Use appropriate compression or mechanical lugs for termination to these bus tabs. Avoid routing power wires over the control board or display.

Connect the motor leads to the unit terminals marked T1, T2, T3 (U, V,

W for IEC users). If control power is present, but line power is disconnected from L1, L2, L3, the display will show [n3PH] indicating

“no 3 Phase”.

Caution!

Never interchange input and output connections to the unit. This could cause excessive voltage in the control logic circuit and may damage the unit.

4.1.1 Bypass Contactor

Bypass Contactors are integral (builtin) on all VMX…-BP (panel mount), and all VMX…–E (NEMA 12 enclosed) versions. See sections

3.2.1.c and 4.2.5 for more details on contactor control and overload protection details.

4.1.2 Power Factor Correction Capacitors

Power factor correction capacitors can be connected to motors controlled by VMX Series starters, however they must be off-line during ramping. Connect PFC capacitors to the Line side of the starter with a separate capacitor control contactor.

*Larger units (210A and above) can be ordered with fan cooling instead of

Bypass Contactors, but are intended for use in NEMA 1 ventilated enclosures only. Do not use the VMX starter in a sealed enclosure without a bypass contactor.

WARNING!

Never connect power factor correction capacitors on the load side of the unit. The SCRs will be seriously damaged if capacitors are located on the load side.

4.1.3 Grounding

Connect the ground cable to the ground terminal as labeled on the unit.

Refer to the National Electrical Code or your local Code for the proper ground wire sizing and be sure that the ground connector is connected to earth ground. In ungrounded systems, it is not necessary to connect a ground to the unit however local codes should always be consulted.

VMX Digital Solid State Soft Starter User Manual 15 | P a g e

4.1.4 Testing

The VMX Series can be tested with a load smaller than the motor it was originally selected to control, however additional steps must be taken to avoid tripping on Phase Current Loss. See section 5.6.9.a under “Phase

Loss Protection” for additional details on performing this task.

 Notes:

The unit cannot be tested without a motor or other test load connected to the load side of the unit. It may be necessary to use a load bank to test the unit without a motor.

 Line voltage will appear across the output terminals if there is no motor or load connected to the unit.

4.1.5 Lightning Protection

As with all electronic power controllers, protection from damage by lightning surges is recommended in areas where lightning is a significant problem. Stationary air gap lightning arrestors should be considered and utilized on the input power source. The best method of protection is to have an Isolation Contactor in front of the starter that is open when the soft starter is not in use.

4.2 Control Connections

TB1: 12 terminals, #1-12

N C RAMP2

JOG PTC

Control connections on the VMX Series starter are divided into 2 groups. With the unit oriented vertically, TB1 is a 12-point DC terminal block (on the left), and TB2 is a 10 point AC terminal block (on the right side). These are removable terminal blocks for ease of connection and servicing, and are provided with different spacing (pitch) between the header pins so they are not interchangeable. Following are descriptions of control connection points.

 Note:

Terminal numbers are shown on the side of the first and last terminal of each block. An additional 3 point terminal on the far left side is for serial communication connections (see section 5.6.11).

TB2: 10 Terminals, #13-22

OPTO

NC NO .

NO .

A1 A2

1 2 3 ............................................... 11 12 13 14 ...........................19 20

24VDC from internal supply

= Factory installed jumpers

Opto-Isolated Triac Switch

10-250VAC/DC 50mA max.

240VAC max. from customer source

120VAC Control Power

(or 240VAC if ordered)

Figure 4.2: Control Terminal Blocks

VMX Digital Solid State Soft Starter User Manual 16 | P a g e

NC NO .

NO .

A1 A2

Figure 4.2.1

Control Pow er Supply Connection

TB-2

120VAC

Supply

VMX

…-BP

Model

VMX-18 to 48

VMX-62 to 112

VMX-150 to 160

VMX- 210 to 276*

VMX-360 to 450*

4.2.1 AC Control Power Supply Connection

Separate AC Control Power supply is required to power the electronics of the VMX Series starter. 120VAC is standard, order 240 VAC

(optional) if necessary for your line power supply configuration. The control voltage must be connected to terminals marked A1 and A2 of

TB-2 as shown in figure 4.2.1 (these are also Terminal

No.‟s 21 and 22).

This control voltage must be customer supplied, unless an optional control power transformer (see table below) has been supplied with the unit.

Table 3: VMX Series AC Control Power VA Requirements

Boards

Fans

(inc. in PCB)

100

150

-BP: Bypass

Contactor

Inrush

220

298

380

571

-BP: Bypass

Contactor

Sealed

12.3

11.6

Recommended minimum

CPT

Rating

100

250

500

750

VMX-550* 48 200 1000 29 1000

Note: * -P versions (w/o bypass) still require PCB and fans, plus user supplied bypass (if any).

 4.2.1.a

Control Power Requirements

When sizing a control power transformer for the

VMX…-BP Series starter use the above chart for minimum sizes or supply capacity.

Any additional control devices powered by the same CPT must be added to the above values to ensure proper operation of the Bypass

Contactor.

 Note:

VMX-210 and larger units are available without the Bypass

Contactor, but fans are still included. CPT can be sized for fan loads only if used in NEMA 1 ventilated enclosures.

 4.2.1.b

Control Fusing

The output relay contacts (TB2) must be protected from currents in excess of 5A by either using fuses or other suitable current protection devices.

 A dedicated fault output for use in PLC or interposing relay control is available on TB1. This opto-isolated triac switch is rated for 50mA max., 10-250V AC/DC. Any circuit connected to it must be fused accordingly.

VMX Digital Solid State Soft Starter User Manual 17 | P a g e

1 2 3

Connect 3 wire control here as shown

1 2 3

Connect 2 wire control / PLC output here

N C

RAMP2

JOG

RAMP2 JOG

PTC

Figure 4.2.2

3 Wire Control Connection

TB-1

PTC

Figure 4.2.3

2 Wire Control Connection

TB-1

OPTO

4.2.2 Three-Wire Control Connection

For standard 3-wire control, connect dry (voltage free) contacts for the

Stop / Start buttons as shown on the diagram directly above the terminal strip. Connect the NO contact of the Start button to Terminal 1 (far left terminal), the common point between the Stop and Start to Terminal 2

(2 nd

from left) and the NC from the Stop button to Terminal 3 (3 rd

from left).

 4.2.2.a

Seal In Contact

The VMX Series uses an internally prewired “seal-in” contact around the Start button (Terminals 1 and 2). No external relay or auxiliary output connection is necessary.

4.2.3 Two Wire Control: Relay / PLC Connection

An alternate connection for automated or unattended operation replaces the start/stop push buttons by connecting a dry (voltage free) maintained contact closure between terminals 1 and 3 as shown in

Figure 4.2.3. When this contact is closed, the VMX Series starter will start and run. When it is opened, it is the same as a Stop command.

 4.2.3.a

Automatic Functions and 2 Wire Control

If using the Time Clock functions (F032-F039) or Auto Reset functions (F052

– F053), special consideration must be given to using 2 wire control. Refer to Appendix 3 for additional details and information on time clock functions, and section 5.6.9 for details on using Auto-Reset functions.

 Note:

When a maintained contact is used for start/stop it is advisable to set the overload relay to the manual reset position. This will prevent the motor from restarting if the thermal overload trips and then cools down.

N C

RAMP2 JOG PTC

4 5

Remove factory jumper and connect external interlock device here

Figure 4.2.

External Interlock Connection

TB-1

OPTO

CAUTION!

Control Terminals 1-10 of TB1 are configured using solid state devices powered internally with a 24VDC power supply. To prevent damage to the VMX Series control board, use dry (unpowered) contact closures only when connecting to these terminals.

If existing 120VAC or other powered control circuit must be interfaced, use isolating relays or control the VMX Series with 2 wire control as shown above.

4.2.4 Interlock Connection

TB1 provides a connection point for an external dry (voltage free) N.C.

(Normally Closed) interlock device between terminals 4 and 5.

Examples where this interlock connection would be used include low oil, high temperature, or excess vibration dropout from user supplied devices. A factory-installed jumper is provided which allows the VMX

Series unit to operate if external interlocks are not used. If this jumper is removed and an interlock is not used, the VMX Series unit will not function.

VMX Digital Solid State Soft Starter User Manual 18 | P a g e

N C RAMP2

JOG

6 7 8

RAM P 1 RAM P 2

Figure 4.2.5.a:

Dual Ramp Connections

TB-1

N C RAMP2

JOG

6 7 8

Figure 4.2.5.b:

Jog Connections

TB-1

N C RAMP2

JOG

PTC

OPTO

PTC OPTO

RUN JOG

PTC OPTO

6 7 8

RAM P 2

RUN JOG

4.2.5 Enabling the Dual Ramp and Jog Features

TB1 includes provisions for enabling the Dual Ramp and Jog functions by using external contact closures. Both features use a common

+24VDC from Terminal 7 however, they can be used independently of each other or together. See sections 5.6.2 and 5.6.3 for full function descriptions and setup.

 4.2.5.a

Dual Ramp Command

Closing a dry (voltage free) contact between TB1, terminals 6 and 7 will enable Ramp 2, and the VMX Series starter will respond to the settings for Ramp 2 in F015 - F018. If no contact closure is present, the VMX Series starter defaults to the Ramp 1 parameters (F011

–

F014). See Section 5.6.2.a for setup of the Dual Ramp Feature.

The Dual Ramp feature is useful in instances where the load changes significantly. Example: a loaded or unloaded conveyor belt.

The characteristics for starting an unloaded conveyor can be programmed for ramp 1. The characteristics for starting a loaded conveyor can be programmed for ramp 2. Ramp 2 can also be programmed for Full Voltage / Across-the-Line starting by setting the ramp time to 0 and Current to 600%.

Dual Ramp is also useful in 2-speed motor applications. Simply use an auxiliary contact from one of the speed contactors to select

Ramp 2 so that separate ramp profiles can be used.

 4.2.5.b

Jog / Remote Command

Connecting a dry (voltage free) contact between TB1, Terminals 7 and 8 will enable the Jog feature. A Start command (Run Command or Start button) is required to activate the Jog feature. See Section

5.6.3 for setup of the Jog Function.

The Jog feature can be used for tasks such as lining up machines for blade or bit changes or inching belts along to check tracking.

This input is also used to change the function of the Serial

Communications port control through F068. For additional information, see instructions of that function in section 5.6.11.

 4.2.5.c

Using Both Commands

It may be useful to initialize the Ramp 2 and Jog command simultaneously when jogging. If this is the case, terminals 6 and 8 can be jumped together and controlled with one contact closure to

Terminal 7 (the common 24VDC).

Figure 4.2.5.c:

Dual Ramp / Jog Connections

TB-1

VMX Digital Solid State Soft Starter User Manual 19 | P a g e

N C

RAMP2 JOG

Figure 4.2.6:

PTC Resistor Connection

TB-1

PTC

9 10

PTC Re sistor in M otor

OPTO

** Re mov e factory jumpe r

from Te rminals 9 and 10

4.2.6 PTC Thermistor Input

The VMX Series starter is provided with input terminals for connecting a

PTC (Positive Temperature Coefficient) Thermistor that may be imbedded in the motor. These are specialized resistors imbedded in some motor windings that increase in resistance as the temperature increases. When the VMX Series detects that the PTC input resistance is too high, it initiates a PTC trip, and displays [ PTc ] on the readout.

This is independent of the Thermal Register overload current protection and provides supplemental protection for high motor ambient temperature applications. Terminals for this input are provided with a factory jumper that must be removed if the PTC input is used. These are

Terminals 9 and 10 located on TB1.

PTC resistors are also found in other devices such as bearings, air receivers, oil or coolant reservoirs and air discharge systems that may require shutdown of the motor.

PTC Resistor Values:

The resistance must be greater than or equal to 750



at 25ºC. If multiple resistors are used in the motor, the sum of all resistors in series must equal or exceed this value.

N C

RAMP2 JOG

Optional

Emergency Stop PB

PTC

9 10

External OL Relays

OLR 1 OLR 2

OPTO

Figure 4.2.6.a:

External Overload Relay(s) and/or E-Stop PB Connection

TB-1

** Remove factory jumper

from Terminals 9 and 10

 4.2.6.a

External Over Load Relay Connection

If an external Over Load Relay (OLR) is used (see Section 3.1.3.c and Appendix 5), connect the NC aux. contact of the OLR to the

PTC input after removing the jumper. When the external OLR trips, the contact will open, opening the resistance input to the PTC circuit

(the resistance goes to infinity). This indicates an immediate Over

Load to the starter, which trips and displays [ PTc ] on the readout to differentiate from the internal Thermal Over Load trip. If multiple

OLRs are used, i.e. multiple motors controlled by the same VMX

Series starter, simply wire the Aux Contacts in series as shown in

Figure 4.2.6.a. See Appendix 5 for additional information.

 Note:

An Emergency Stop Push Button or any other field device may be wired to the PTC input using NC contacts. When the contacts open, the starter will detect it as a PTC trip. Even if a PTC is used in the motor, field devices can still be added as long as the total circuit resistance is not exceeded.

 This feature is especially useful when using Decel Control because it will immediately shut off power to the motor even if Decel is active. If used this way, instruct the users as to the trip indication issues (i.e. the display will show [ PTc ] and the Overload LED will be on).

VMX Digital Solid State Soft Starter User Manual 20 | P a g e

Control Powe r or PLC Source

Figure 4.2.7:

Fault Output Opto-Triac Connection

TB-1

Internal Connections

RAMP2 JOG

NC NO .

PTC

NO .

A1 A2

13 14 15 16 17 18 19 20

AUX.

RELAY #1

N C

AUX.

RELAY #2

AUX.

RELAY #3

Figure 4.2.8

Auxiliary Relay Connections

TB-2

OPTO

11 12

Exte rnal Fault Re lay or PLC Input

4.2.7 Fault Signal

An optically isolated Triac output is dedicated as a fault indicator on

TB1, terminals 11 and 12, labeled “Opto”. The output Triac switch is rated for 10 - 250 VAC/DC, 50 mA (maximum). If the three programmable Output Auxiliary Relays are being used for other functions, this output can easily be hooked up to a PLC or small external relay to provide a Fault signal. This Fault Output operation is permanently fixed at “Any Trip”, duplicating the Relay setting 16 as shown in Table 5.6.10.

This output is permanently set to this function and is not

programmable.

4.2.8 Output (Auxiliary) Relay Contacts

Three programmable auxiliary relays are on TB2. The VMX Series starter comes with three programmable dry relay output contacts.

Outputs 1 and 2 are Form C (SPDT), with a Common, N.O. and N.C.

Output 3 is a Form A, (SPST), N.O. contact. It is not necessary to use the programmable output auxiliary relays in the Start / Stop circuit. An internal seal-in relay is provided elsewhere (see 4.2.2.a above).

Motortronics recommends fusing all outputs with external fuses.

The relays are rated for 240 VAC, 5 A and 1200 VA.

Factory default settings for these relays are as follows:

 AUX 1 – Run / Stop (see F060).This contact changes state upon a

Start command, returns to normal on Stop (or Begin Decel if active).

 AUX 2 – At-Speed / Stop (see F061).This contact changes state upon the VMX Series detecting At-Speed, and returns to normal on

Stop. At-Speed is determined by the VMX Series detecting the current dropping after reaching End-of-Ramp, or a maximum of 30 seconds after Start.

 AUX 3 – Any Trip (see F062) This contact closes when any trip condition 5

– 15 (as defined in Table 5.6.10) occurs.

All relays can be reprogrammed for a wide variety of functions.

See Section 5.6.10 for additional relay programming details.

VMX Digital Solid State Soft Starter User Manual 21 | P a g e

4.2.9 Bypass Contactor Control

VMX…-BP version (and NEMA 12 enclosures) starters, an internal dedicated connection is used at the factory for automatically controlling the Bypass Contactor. Field wiring for Bypass Contactor operation is not required.

 4.2.9.a

Independent Bypass Contactor Control

The

VMX…-BP Series starters use standard industrial contactors that can be controlled independent of the starter electronics if necessary. When doing so, it is necessary to size the starter based upon the ATL (Across-the-Line) selection chart so that the contactors are rated for ATL duty instead of normal Shunt Duty.

(see section 1.2.3). Supplemental overload protection will be required (see section 3.1.3.c).

Units have external terminal blocks marked for this purpose (see

Appendix 5 for drawings). A dry (voltage free) contact closure between these terminals will close the bypass contactor immediately. The Bypass Contactor coil voltage is the same as the control voltage (120VAC unless the optional 240VAC control is specified), and the voltage on these terminals is the same as the coil voltage.

No field wiring is necessary to these terminals if this feature is

not used.

For all other styles of VMX Series, the At-Speed signaling can be programmed into any of the three Output relays (section 4.2.8 and

Table 5.6.10).

VMX Digital Solid State Soft Starter User Manual 22 | P a g e

Chapter 5 - Programming

MOTOR FLA (F001) must be programmed for unit to operate!

Figure 5.2: Digital Interface

5.1 Introduction

It is best to operate the motor at its full load starting conditions to achieve the proper time, torque and ramp settings. Initial factory settings are set to accommodate general motor applications and provide basic motor protection. Advanced features must be enabled via programming.

The only parameter that MUST be set by the user is motor FLA (F001).

5.2 Digital Interface

The VMX Series Soft Starter includes a digital keypad with eight LEDs, seven command keys, and an LED display with four alphanumeric digits.

Table 5.2: VMX Series Display Features

Keys

Reset

Up and

Down

Arrows

Right and Left

Arrows

Clears the Trip indication and releases the Trip Relay.

Enters or exits the Program Mode.

Navigates through the Status Display Mode, scrolls up and down through the Function List, increases or decreases the value of the active (flashing) digit and scrolls through the fault history. When entering values, holding the key down for more than 2 seconds will activate Auto-step, which increases its rate the longer the key is held down.

Each keypress shifts the active (flashing) digit to the right or left by one position, allowing you to change higher values of functions without waiting to Auto-step though large numbers.

Power

Control power is available at A1 and A2

Green

LEDs

Yellow

LEDs

Display

Speed

Shunt

Trip

Shorted

SCR

Over

Current

Phase

Loss

Over

Temp

Over

Load

8888.

The motor is at full power and the Bypass Contactor has been commanded to pull in.

The SCRs are at full conduction and current has dropped.

Two or more SCRs in opposing phases have shorted, and power is flowing to the motor in the Off mode. See section 8 for additional information.

There is no voltage drop across at least one SCR phase assembly, indicating that at least one SCR is shorted. See section 8 for additional information.

Overcurrent LED lights for three sets of fault conditions:

1) During start, the unit saw current exceed the normal rate of increase in the first 250ms.

2) During Run, current exceeded either the OC setting in F042 for the delay set in F043. This LED will be accompanied by oCA, oCC or oCd on the display.

3) The unit has seen a Short Circuit exceeding 10x

FLA for 12.5ms. This LED will be accompanied by

SCA, SCC or SCD display.

One or more of the phase currents dropped below the threshold during starting or running.

Starter has tripped due to excess heat sink temperature. This will automatically reset.

Starter has tripped due to the Thermal Register reaching 0000. The Overload must reset before this fault can be cleared.

4 digit 7 segment display with a decimal point on the right side indicating Phase A.

VMX Digital Solid State Soft Starter User Manual 23 | P a g e

5.3 Display Modes

There are three modes of display: The Status Display Mode, the

Program Mode, and the Fault Mode.

5.3.1 Status Display Mode (Default Display)

The Status Display Mode di splays seven “screens” of information. Motor

Currents (3 phases), Remaining Thermal Capacity, Ground Current,

Remaining Time on the Process Timer, and Time Base of the Time

Clock Controller. This is also the entry screen for going into the Program

Mode.

Status mode:

[0000.] The initial display on power up is four digits and the decimal.

This indicates the motor current for Phase A of the motor.

[0000] Scroll UP to display four digits only (no decimal). This indicates the motor current for Phase B. While viewing Phase B, press the UP arrow again to view Phase C current.

[G000]

Scroll UP to display the “G”. This shows the value of the current flowing to ground on the motor leads.

[H000]

Scroll UP to display the “H”. This indicates the value of the remaining thermal capacity percentage of the motor (i.e. H070 = 70% remaining thermal capacity)

[0000] Scroll UP again to display the Process Batch Timer (described in

Section 5.6.7). If this entire screen is flashing, the Timer is active.

[00.00] Scroll UP to display two pairs of digits separated by a point: This indicates the time base of the Time Clock Controller (described in section 5.6.7). If the display shows [00.00], the TCC is not enabled. This follows the time settings in F075

– F080.

Example: Figure 5.3.1

Reading the Status Display

[0120.] Indicates Phase A is drawing 120 amps.

Press the UP arrow

[0121] Indicates Phase B is drawing 121 amps.

NOTE: Decimal points are not present in the

readouts for Phases B and C.

Press the UP arrow

[0120] Indicates Phase C is drawing 120 amps.

Press the UP arrow

[G002] Indicates that there are 2 amps of current flowing to ground in the motor leads or motor.

Press the UP arrow

[H083] Indicates the motor has 83% of its thermal capacity remaining (H = Heat).

Press the UP arrow

[0060] Indicates there is 60 minutes remaining on the

Process Timer. If flashing, the timer is active.

Press the UP arrow

[13.30] Indicates the time base of the Time Clock

Controller is 1:30 PM (24hr time). If flashing, the

time clock is active and pending the next event.

Press the UP arrow

[0120.] Loop back to Phase A current indication

Pre ss

Ke y...

Display

Shows...

0120.

0121

0120

G002

H083

0060

13.. 30

0120.

M e ans...

Phase A

Curre nt

Phase B

Curre nt

Phase C

Curre nt

Ground Fault

Curre nt

Re maining

The rmal Capacity

Proce ss Time r

Re maining Time

Time Clock

Time Base

Loop Back to

Phase A Curre nt

Figure 5.3.1: Reading the Status Display

VMX Digital Solid State Soft Starter User Manual 24 | P a g e

5.4 Program Mode

The starter must be OFF in order to enter the Program Mode.

Use the Program Mode to view or change Function (Fn) settings. To enter the Program Mode, press the [Fn] key once from the Status

Screen described in 5.3.1 above. The first time you enter the Program

Mode after power has been cycled to the starter, the initial function

[F001] should be displayed with the selected digit flashing. If the VMX

Series starter has been programmed and power to the unit has not been cycled, the readout will display the last function viewed or changed. To change to a different function, use the arrow keys.

5.4.1 Viewing Function Programming and Values

The programming of each individual Function can be viewed without making changes (values can also be viewed in the Run Mode however, no changes can be made). Each Function is signified by the letter “F” in the beginning of the data, the 4 digit value of the function follows after pushing the [READ/ENTER] key

•

[F001]

The “F” indicates the programmable Function.

•

[0000] This is the present setting of the applicable function. This display may include decimals between digits depending on the function setting‟s range and incremental steps.

Example: Figure 5.4.1

Viewing a Function’s Set Value:

Motor FLA Setting

[0000.] Indicates that Phase A is drawing no current

(unit is in Off mode).

Press the Fn key

[F001] Indicates that this is Function 001 (Motor FLA).

Press Read / Enter key to view the F001’s value

[0306] Indicates that the programmed motor FLA is

360 Amps.

Press the Fn key to return to the function

[F001] Indicates that you have returned to the Function

Select screen.

Press the Fn key again to return to the Status Display Mode

[0000.] Default screen.

Press

Key...

READ

ENTER

Display

Shows...

0000.

F001

0360

F001

0000.

M eans...

Default Display:

Phase A Current

Selecting

Function #1

Fn 1 Value:

FLA = 360A

Return to Function

# Selection

Return to

Default Display

Without Change

Figure 5.4.1:

View ing a Function's Set Value

 Note:

If password protection has been enabled, the operator will need to obtain password access before function settings can be changed.

See Section 5.6.12 and Appendix 3.

VMX Digital Solid State Soft Starter User Manual 25 | P a g e

5.4.2 Enabling Password Protection / Parameter Lock

The VMX Series starter is shipped with the password protection disabled (F070 = 0). If it becomes necessary to prevent parameters from being changed inadvertently, set the password in function F070.

See Appendix 3 for details. If the display reads [ Loc] when the

[READ/ENTER] key is pressed, the parameter lock is enabled.

5.4.3

Changing a Function’s Set Value

From the instructions above, after pressing the [READ/ENTER] key the display will show the value of that function with one digit flashing

(usually the rightmost digit). Flashing indicates this is the digit to be altered (similar to cursor position). Use the UP arrow key to increment the value of the flashing digit. Use the DOWN arrow key to decrement the value of the flashing digit. Use the LEFT or RIGHT arrow to select the next digit to be altered. Values can only be changed within the

Adjustment Range of the function parameter.

Example 1: Figure 5.4.3

Viewing a Function’s Set Value

Example 1: Setting the Motor FLA

[0000.] Indicates Phase A is drawing no current

(unit is in Off mode).

Press the [Fn] key

[F001] Indicates this is Function 001 (Motor FLA).

Press [READ/ENTER] key to view the F001 value

[0048] Indicates the programmed motor FLA is 48 Amps.

The right most digit (8) is flashing, indicating that this is the digit that you will alter (cursor position).

Press the UP Arrow key to increase this digit value

[0049] Indicates you have increased the right most digit to a value of 9.

Press the LEFT Arrow key to shift left to the next digit

[0049] The second digit from the right is now flashing, indicating a new cursor position.

Change FLA from 48 to 59A

Press

Key...

READ

ENTER

Display

Shows...

0000.

F001

0048

0049

M eans...

Phase A

Current

Function #1

Selected

Previous Setting of Function #1

New Value of

First Digit

Cursor (flashing)

Position Shift

Press the UP Arrow key to increase this digit value

[0059] Indicates you have increased the 2 nd to a value of 5 (10‟s place).

to right digit

Press [READ/ENTER] key to store the new value

[End]

The word “End” will flash briefly to indicate that the new value has been entered and accepted.

After flashing once, the display will revert to showing the Function number.

READ

ENTER

0059

End

F001

New Value of

Second Digit

Value Accepted

(flashes once)

Return to

Function # Display

Figure 5.4.3:

Changing a Function Value

VMX Digital Solid State Soft Starter User Manual 26 | P a g e

 5.4.3.a

Changing a Value by Increments

Although it may be easier to shift the cursor position, it is also possible to increase or decrease values by pressing the UP or

DOWN arrow keys successively. This will change the Function value by the incremental amount associated with that Function. The

Function List shows increment values for each Function.

Example 2: Figure 5.4.3.a

Changing a Function’s Value by Increments

[0000.] Indicates that Phase A is drawing no current

(unit is in Off mode).

Press the [Fn] key

[F001] Indicates that this is Function 001 (Motor FLA).

The right most digit (1) is flashing, indicating this is the digit that you will alter (cursor position)

Press the UP Arrow key twice to increase this digit value to 3

[F003] Indicates that this is Function 003

(OL Class During Start).

Press [READ/ENTER] key to view the F003 value

[0010] Indicates that the programmed OL is Class 10 during the Start Mode. Cursor flashing on right most digit.

Example 2: Setting the OL Curve

During Start

Change from Class 10 to Class 20

Press

Key...

READ

ENTER x2

Display

Shows...

0000.

F001

F003

0010

M eans...

Phase A

Current

Function #1

Displayed

New Value of

First Digit

Previous Setting of Function #3

Press the UP Arrow key to increase this digit value

[0015] Indicates that you have increased the Function value by the increment assigned to it, a value of 5 in this case.

Press the UP Arrow key again to increase this digit value

[0020] Indicates that you have again increased the

Function value by the increment assigned to it.

READ

ENTER

0015

0020

End

Value Increased by 1 Increment

Value Accepted

(flashes once)

F003

Return to

Function # Display

Press [READ/ENTER] key to store the new value

[End]

Th e word “End” will flash briefly to indicate that the new value has been entered and accepted.

After flashing once, the display will revert to showing the Function number.

Figure 5.4.3.a:

Changing a Function Value by Increments

5.4.4 Storing the Altered Value of a Function

Once the desired value is displayed, press the [READ/ENTER] key.

This stores the value in memory. The readout momentarily displays

[End] and then returns to the function code.

Caution!

If the Fn key is pressed or power is lost before the [READ/ENTER] key is pressed, the VMX

Series Starter will not store the selected value in memory.

VMX Digital Solid State Soft Starter User Manual 27 | P a g e

5.4.5 Fault Mode

The Fault Mode Display provides information to the operator when a fault occurs and allows the operator to review fault history. Refer to

Section 7 for details. Fault codes are displayed by 3 alpha characters.

The first and second characters (reading left to right) are the initials for the applicable English-language fault name. The third or right-most character can be either A, c, or d to denote when the fault occurred. “A” denotes Acceleration

. “c” denotes Constant speed. “d” denotes Decel.

Example: Figure 5.4.5

Viewing a Fault and History

[ PLA.] Indicates that there was a Phase Loss during

Acceleration. The Decimal point on the right signifies that this is the current fault.

Press the UP Arrow key

[IBc]

Displays the previous fault, a Phase Imbalance during Constant Speed (running)

Press the UP Arrow key

[ oLc] Displays the oldest fault, an Over Load trip during

Constant speed (running).

Press [RESET] key

[rSt ]

Flashes once to indicate a successful Reset of the current fault. If it cannot be reset, the display will read [ inH ] for Inhibited.

[0000.] Returns to Default Display, indicating that the unit is ready to re-start.

Figure 5.4.5.b

Rem ote Reset Connection

TB-2

NC NO .

Control Pow er

Supply

NO .

A1 A2

Rem ote Reset

This Fault History can only be accessed during a fault condition. While the active fault number is being displayed, use the Up and Down Arrow keys to scroll through the Fault History. An additional Fault History complete with Time and Date stamps is also available for viewing at any time in F085 through F093.

 5.4.5.a

Resetting Faults

Once a fault condition has been corrected, pressing the Reset key will return the readout to the Status Display mode. To reset faults, press the [RESET] key on the keypad. Alternatively, most faults will reset upon removal and return of control power. Over Load trips will

NOT be reset in this way unless sufficient time has passed for the

Thermal Register to regain sufficient capacity for a successful restart (see section 3.1).

 5.4.5.b

Remote Reset

Because most trips can be reset by removing control power, remote reset can be accomplished this way. A NC remote contact (or pushbutton) can be placed in the control power supply to A1 or A2 and opened to facilitate a trip reset. See figure 5.4.5.b for a suggested connection.

VMX Digital Solid State Soft Starter User Manual 28 | P a g e

 5.4.5.c

Automatic Reset

The VMX Series starter provides for automatic reset on certain noncritical faults and Over Load. For non-critical fault resets, see section 5.6.9 for program details of F052 and F053. For automatic

Over Load reset, see section 3.1 and 5.6.1 for programming details.

 5.4.5.d

Lockout Functions

Lockout functions such as Minimum Time Between Starts and

Starts per Hour are not true fault conditions. They are based on the internal Real Time Clock (RTC). When control power is removed, the RTC value is quickly stored. Upon return of power, the timer values are updated from the RTC for elapsed time. If the Lockout

Time has not expired, the VMX Series cannot be started. To reset the Lockout Times for emergency restart, see section 5.6.12, under

F071.

 5.4.5.e

Changing to Default Screen During Fault

In some cases it may be necessary to alter programmed parameters in order to test or make changes to clear a fault (such as Phase Loss) or to view the more detailed fault history in F085

–

F097. To accomplish this, you must get to the Status Screen so the

Fn button becomes active. When in a Fault Screen, pressing the

Right or Left Arrow buttons will take you to the Status Screen. From there, you can press the [Fn] key to enter the Programming Mode and move to different functions.

VMX Digital Solid State Soft Starter User Manual 29 | P a g e

Fn # Group

F001

F002

F003

F004

5.5 The VMX Function List

5.5.1 Motor FLA, Service Factor and Overload Protection

Functions

Function Description Adjustment / Display Range

Setting

Increments

Factory

Setting

Section

Motor Nameplate FLA

FLA must be programmed for starter to function.

Motor Nameplate

Service Factor

Overload Class During Start

Overload Class During Run

50-100% of Max Amp Rating.

Upper limit of range automatically adjusts downward as Service factor is increased.

1.00 - 1.30 SF

NEMA / UL Class 5 - 20

NEMA / UL Class 5 - 30

1 amp

0.05

1.0 SF

Class 10

5.6.1 and

3.2

F005 Overload Reset

0 = Manual

1 = Auto

2 = Disabled Overload

(Manual)

F006

F009

Reserved for factory use

Table 5.5.1: Motor and Overload Function Group

Fn # Group

F010

F011

5.5.2 Starting Mode Functions

Function Description Adjustment / Display Range

Ramp Type Selection:

VR = Voltage Ramp

CR = Current PID Ramp

1 = Ramp 1, 2 = Ramp 2

Initial Torque (VR) of Ramp 1

Setting 1 = VR1 + VR2

Setting 2 = CR1 + CR2

Setting 3 = VR1 + CR2

Setting 4 = CR1 + VR2

0-100% Line Voltage

F012

F013

F014

Initial Torque (CR) of Ramp 1 0-600% Motor Current

Accel Ramp Time of Ramp 1

Max Current Limit of Ramp 1

1-120 seconds

200 - 600% Motor Current

Setting

Increments

1 second

Factory

Setting

VR1+VR2

60%

200%

10 seconds

350%

Section

5.6.2 and

Append.

F015

F016

Initial Torque (VR) of Ramp 2 0-100% Line Voltage

Initial Torque (CR) of Ramp 2 0-600% Motor Current

1-120 seconds F017 Accel Ramp Time of Ramp 2

F018 Max Current Limit of Ramp 2

Table 5.5.2: Starting Mode Function Group

200 - 600% Motor Current

1 second

60%

200%

10 seconds

350%

5.6.2,

Append.

1 and

4.2.5.b

VMX Digital Solid State Soft Starter User Manual 30 | P a g e

5.5.3 Jog Mode Functions

Fn # Group

F019

Function Description

Voltage Jog

Adjustment / Display Range

– 100% Line Voltage

F020 Time of Voltage Jog

F021 Current Jog

Table 5.5.3: Jog Mode Function Group

– 20 Seconds

100

– 500% Motor

Current

5.5.4 Kick Start Mode Functions

Fn # Group

F022

Function Description

Kick Start Voltage

F023 Kick Start Time

Table 5.5.4: Kick Start Mode Function Group

Adjustment / Display Range

0 = Disabled, or

10 - 100% Line Voltage

0.1 - 2 Seconds

Setting

Increments

1 second

Setting

Increments

Factory

Setting

Disabled

0.1second

Factory

Setting

50%

10 seconds

150%

0.8 seconds

Fn # Group

F024

5.5.5 Decel Mode Functions

Function Description Adjustment / Display Range

Deceleration Ramp

Pump Flex Control /

0 = Disabled (coast to stop)

1 = Enabled, except after OL trip

2 = Enabled, continued Decel even if there is an OL trip

Setting

Increments

F025

Begin Decel Level (BDL),

Immediate Drop Down Torque

0 - 100 % of Output Voltage

F026 Decel Shut Off Voltage 0 to (BDL minus 1)% Voltage

F027 Decel Ramp Time

Table 5.5.5: Pump Flex Decel Mode Function Group

– 60 Seconds

5.5.6 Restart Function

Fn # Group

F028

Function Description

Restart Delay Time

(Sequential Start Delay)

Adjustment / Display Range

0 = Disabled, or

1-999 seconds after a Power Loss

(Status can be read in F054)

F029

Reserved for Factory Use

Table 5.5.6: Restart Function Group

1 second

Setting

Increments

1 second

Factory

Setting

Disabled

60%

30%

10 seconds

Factory

Setting

Disabled

Section

5.6.3 and

4.2.5.b

Section

5.6.4

Section

5.6.5 and

Append.

Section

5.6.6

VMX Digital Solid State Soft Starter User Manual 31 | P a g e

5.5.7 Process Timer Features

Fn # Group

F030

Function Description

Run Timer Selection

Adjustment / Display Range

0 = Disabled (No timer operation)

1 = Minimum (Batch) Run Timer

2 = Permissive Run Timer

F031

F032

F033

Run Timer Time for use in F030 above

24hr

Time Clock Controller (TCC)

Start Event Mode.

Chose “One Shot” or 1 to 7 “Start Events” from F033

– F039

Run time for this mode comes from F030 above.

Start Event #1 Start Time

1-9999 minutes after a Start

Command or Start Event from TCC

Start Event Cycle (SEC) Settings.

1 = Loop SEC every day

2 = Loop SEC every 2 nd

day

3 = Loop SEC every 3

4 = Loop SEC every 4 rd th

day

5 = Loop SEC every 5 th

day

6 = Loop SEC every 6 th

day

7 = Loop SEC one day per week

8 = Single 24hr SEC

(until programmed again)

0 = One Shot: Start Event comes from Start command only

00:00-23:59 (hh:mm) or OFF

Setting

Increments

Factory

Setting

Disabled

One Shot

OFF

Section

5.6.7 and

Append.

F034

F035

00:00-23:59 (hh:mm) or OFF

OFF

F036

F037

F038

F039

Start Event #2 Start Time

Start Event #3 Start Time

Start Event #4 Start Time

Start Event #5 Start Time

Start Event #6 Start Time

Start Event #7 Start Time

00:00-23:59 (hh:mm) or OFF

OFF

Table 5.5.7: Run Timer and Time Clock Controller Function Group

5.5.8 Current and Ground Fault Protection Features

Fn # Group

F040

F041

Function Description Adjustment / Display Range

Current Imbalance Trip

0 = Disabled, or

5 - 30% imbalance

Current Imbalance Trip Delay 1 - 20 seconds

Setting

Increments

1 second

Factory

Setting

Disabled

2 seconds

F042 Over Current Trip

0 = Disabled, or

100 - 300% of motor FLA

Disabled

1 second 1 second F043

F044

F045

Over Current Trip Delay

Under Current Trip

Under Current Trip Delay

1 - 20 seconds

0 = Disabled, or

10 - 90% of motor FLA

1 - 60 seconds

F046 Ground Fault Trip

Ground Fault Trip Delay

0 = Disabled, or

5 - 90% of CT ratio from Fn 74

F047 1 - 60 seconds

Table 5.5.8: Current and Ground Protection Features Group

1 second

Disabled

2 seconds

Disabled

2 seconds

Section

5.6.8

VMX Digital Solid State Soft Starter User Manual 32 | P a g e

5.5.9 Lockouts, Reset and Internal Protection Functions

Fn # Group

F048

F049

Function Description

Coast Down (Back Spin)

Lockout Timer

Maximum Starts per Hour

Adjustment / Display Range

0 = Disabled, or 1 - 60 minutes

0 = Disabled, or 1

– 10 starts

Setting

Increments

1 minute

Factory

Setting

Disabled

F050

F051

F052

F053

F054

F055

Minimum Time Between

Starts

Internal Protection Settings

Auto Reset on Selected Faults

Auto Reset Attempts

Restart Delay Time Value

Readout (for F028) for F048

Coast Down Timer Value

0 = Disabled, or 1 - 60 minutes

– 127

See“ F051 Definition Table”

Fault Preferences 1

– 12

See Table 5.6.8:

”Auto-Reset Selected Faults”

0 = Disabled, or 1-10 attempts

0-999 Minutes

1-3600 Seconds

1 minute

Disabled

127

Enable all

Phase

Loss only

Section

5.6.9

5.6.9.a

5.6.9.b

F056

F057

F058

F059

Starts Per Hour Timer Value for F049

Starts Per Hour

For F049 for F050

Time Value Between Starts

Thermal Capacity to Start for F005

1-3600 Seconds

1-10 Starts

1-3600 Seconds

0-100 % Thermal Capacity

5.6.9.c

Table 5.5.9: Lockouts, Reset and Internal Protection Group

Fn # Group

F060

F061

F062

F063

F064

5.5.10 Output Relay Programming Features

Function Description Adjustment / Display Range

Setting

Increments

Aux Relay 1 setting

Operation # 1

– 26: see

”Aux. Relay Settings Chart”

Aux Relay 2 setting

Operation # 1

– 26: see

”Aux. Relay Settings Chart”

Aux Relay 3 setting

Aux. Relay Delay Timer

(for Operations 23-26)

Reserved for factory use

Operation # 1

– 26: see

”Aux. Relay Settings Chart”

0 (Disabled), or 1-999 seconds

1 second

Table 5.5.10: Output Relay Function Group

Factory

Setting

No Delay

Section

5.6.10

Notes:

Check wiring to each relay before changing programming to ensure there are no unintended consequences.

Relays programmed to some protection features will not operate if function is disabled elsewhere.

VMX Digital Solid State Soft Starter User Manual 33 | P a g e

5.5.11 Serial Communications

Fn # Group

F065

Function Description

Communications

Adjustment / Display Range

0 = Disabled

1 = Enabled (11Bit)

2 = Enabled (10Bit)

F066

F067

Baud Rate

Modbus Address

4.8, 9.6 and 19.2 KB

1 - 247

F068 Remote Starter Control

0 = Disabled

1 = Enabled w/ Start button

2 = Enabled w/o Start button

3 = Enabled via Jog-Remote Input

F069 Reserved for factory use

Table 5.5.11: Serial Communications Function Group

Fn # Group

F070

F071

F072

5.5.12 System Settings

Function Description Adjustment / Display Range

Parameter Lock

Customer Password

System Clear / Reset

Reserved for Factory Use

– 999

0 = Disabled

Any Other Numbers = Password

0 = Disabled

1 = Clear THR and Lockout Timers

2 = Reset to Factory Default Settings

F073

F074

F075

F076

F077

F078

F079

Frame Rating

CT Value

Year

Month

Day

Hour

Minute

18 - 550

40-1200

2000 - 2047

1 - 12

1 - 31

0 - 23

0 - 59

Setting

Increments

3 rates

Setting

Increments

1 year

1 Month

1 Day

1 Hour

1 Minute

Factory

Setting

9.6 KB

Factory

Setting

(displays encrypted code)

By Model

(defaults to 48)

By Model

(defaults to 40)

2000

Section

5.6.11

Section

5.6.12 and

Append.

5.6.12

5.6.12.a

F080 Second

F081 Revision #

F082

–

F084

Reserved for factory use

Table 5.5.12: System Settings Function Group

0 - 59

1 Second

Factory

Setting

VMX Digital Solid State Soft Starter User Manual 34 | P a g e

Fn # Group

F085

F086

5.5.13 Fault History and Run Time

Function Description Adjustment / Display Range

Fault History #1, Latest Fault

Based on F078-80

Time Stamp, Fault #1

0 = No fault history, or

Fault # 1 - 27: see Fault code list

00.00-23.59 (hh.mm)

[hh = 00-23; mm = 00-59]

F087

Date Stamp, Fault #1

Based on F076-77

01.01

– 12.31 (MM.DD)

[MM = 01-12; DD = 01-31]

F088

F089

F090

F091

F092

F093

F094

Fault History #2, Previous

Fault

Date Stamp, Fault #2

Time Stamp, Fault #2

Fault History #3, Oldest Fault

Time Stamp, Fault #3

Date Stamp, Fault #3

Run Time, Hours

0 = No fault history, or

Fault # 1 - 27: see Fault code list

00.00-23.59 (hh.mm)

[hh = 00-23; mm = 00-59]

01.01

– 12.31 (MM.DD)

[MM = 01-12; DD = 01-31]

0 = No fault history, or

Fault # 1 - 27: see Fault code list

00.00-23.59 (hh.mm)

[hh = 00-23; mm = 00-59]

01.01

– 12.31 (MM.DD)

[MM = 01-12; DD = 01-31]

000.0

– 999.9 hours

F095

F096

F097

Run Time,

1000 Hour Overflow

Run Cycle Counter

10K overflow

0000

– 9999 thousand hours

0000

– 9999 times

0000

– 9999 10 thousand times

Table 5.5.13: Fault History and Run Data Group

Setting

Increments

Factory

Setting

1 0

Section

00.01

00.00

01.01

00.01

00.00

01.01

00.01 00.00

00.01

0.1 hours

01.01

1 k-hour

1 times

10k times 0

5.6.13

5.6.13.

VMX Digital Solid State Soft Starter User Manual 35 | P a g e

MOTOR FLA (F001) must be programmed for unit to operate!

5.6 Function Descriptions

Your VMX Series starter is set at the factory with typical default settings that perform well in most applications. Following are detailed descriptions of each Function and the factory default settings.

5.6.1 Motor and Overload Function Descriptions

F001= Motor FLA

Factory Setting = 0

Range = 50 - 100% of Unit Max. Current.

Set the value of this function to the motor nameplate Full Load

Amps (FLA). Adjustments for service factor are not necessary when programming this function. (See note below). If the motor nameplate FLA is not available, use typical values as shown in

NEC, NEMA standard MG-1 or other reputable third party source (motor manufacturer, etc.).

 Note:

To prevent adjusting the settings beyond the starter Max Amp rating, the range of adjustment for the Motor Nameplate FLA will vary in accordance with the Service Factor as programmed into

F002. At the default setting of 1.0SF, the full range of adjustment from 50 - 100% of the Max Amp rating is available. As the Service

Factor is increased, the FLA range will drop by an equal ratio. For example if F002 = 1.15 (a 1.15 Service Factor), the maximum FLA programmable into F001 will be limited to 85% of the starter Max.

Amp rating (100% - 15%).

F002 = Service Factor

Factory Setting = 1.0 S.F.

Range = 1.00 - 1.30

Set value according to the Service Factor (SF) data provided on the motor‟s nameplate. This value affects several protection features so it must be accurate. Setting the SF too high may result in motor damage in an overload condition. Setting SF too low may cause nuisance trips however; a 1.0 SF setting is safest if SF is unknown.

 Note:

The combination of F002 and F001 (FLA x SF) cannot exceed the

Unit Max Amp rating. If when programming F002 you are not allowed to raise the setting, the combined total has been exceeded.

F003 = Overload Class During Start

Factory Setting = 10 (Class 10)

Range = NEMA / UL Class 5 - 20

Set value to the motor protection overload class required for the application. It is recommended that you try the factory setting first. (If possible, keep values for F003 and F004 the same.)

Increase F003 above F004 only if nuisance tripping occurs during start. See Section 3.2 for details on trip curves.

VMX Digital Solid State Soft Starter User Manual 36 | P a g e

F004 = Overload Class During Run

Factory Setting = 10 (Class 10)

Range = 5 - 30 NEMA / UL Class

Set value according to the instructions provided by your motor / equipment manufacturer. This trip curve will not be enabled until the motor has reached full speed.

F005 = Overload Reset

Factory Setting = 0 (Manual)

Range = 0

– 2

Set value to determine starter behavior after an overload condition has cleared.

When set to 0 = Manual, the operator must press the [RESET] key before restarting the motor. Once the motor windings have cooled sufficiently AND the [RESET] key is pressed, the unit will accept a restart command.

When set to 1 = Automatic mode, and once sufficient time has elapsed allowing motor windings to cool, the motor will be restarted upon a start command. If 2-wire control is used, the unit will restart immediately.

When set to 2 = Disabled Overload, the VMX Series will not trip on Motor Thermal Overload. This is provided for applications where either an external Overload Relay or Motor

Protection Relay is used, or where multiple motors are connected and each one requires having an individual Overload

Relay. See Appendix 5 for more details.

WARNING:

Setting F005 = 1 (Automatic) may present significant operational risk.

When F005 = 2 (Disabled Overload), a separate external thermal overload protection device must be in the circuit.

 Note:

Because of the risk of fire or equipment damage, cycling control power will NOT reset an Overload Trip. If F005 = 2 (Automatic

Reset), cycling control power will allow reset ONLY if the Thermal

F006 - F009 = Reserved

VMX Digital Solid State Soft Starter User Manual 37 | P a g e

5.6.2 Starting Mode

The VMX Series is capable of several different starting modes, but is set from the factory for the most common applications. A second ramp profile is available for use should it be required. Unless wired to do so, the VMX Series defaults to Ramp 1. This section describes functions for

Ramp 1, with references to function numbers that do the same thing for

Ramp 2 (if required). Refer to Appendix 2 for a detailed description of the differences in Ramp Profiles and their uses. All current percentages are based on the Motor FLA as programmed in F001.

F010 = Ramp Profile Selection

Factory Setting = 1

Range = 1

– 4

This Function selects the type of Ramp Profile desired. Ramp profiles can be either Voltage Ramp or Current Ramp. See

Appendix 2 for details. Each Ramp Profile consists of 3 settings:

Initial Torque, Ramp Time and Maximum Current Limit.

Because there are two ramps available, there are 4 settings to cover the combinations of profiles possible. If you are not using the 2 nd

ramp, the VMX Series will ignore all settings in reference to Ramp 2.

Ramp 1

(Dual Ramp Input Open)

Ramp 2

(Dual Ramp Input Closed)

F010

Setting

Ramp Profile

Voltage

Current

Voltage

Current

Ramp Profile

Voltage

Current

Voltage

Table 5.6.2: Ramp Type selection Settings

Select Voltage Ramp by setting F010 = 1 (factory default)

When Voltage Ramp is selected,

Set Initial Torque (Voltage) with F011 (see below)

Set Ramp Time with F013 (see below)

Set Maximum Current Limit with F014 (see below)

Or;

Select Current Ramp by setting F010 = 2

When Current Ramp is selected,

Set Initial Torque (Current) with F012 (see below)

Set Ramp Time with F013 (see below)

Set Maximum Current Limit with F014 (see below)

 Note:

When either Ramp is set to “Voltage Ramp”, the corresponding

“Initial Torque (Current)” setting is ignored. Conversely, when set to

“Current Ramp”, the “Initial Torque (Voltage)” is ignored.

VMX Digital Solid State Soft Starter User Manual 38 | P a g e

F011 = Initial Voltage of Ramp 1

Factory Setting = 60%

Range = 0 - 100%

Sets the initial voltage of ramp 1 when F010 = 1 or 3. The initial torque level should be set to provide just enough torque to make the motor shaft begin to rotate while preventing torque shock damage to mechanical components.

F012 = Initial Current of Ramp 1

Factory Setting = 200%

Range = 0 - 600%

Sets the initial current of ramp 1 when F010 = 2 or 4. The initial torque level should be set to provide just enough torque to make the motor shaft begin to rotate while preventing torque shock damage to mechanical components.

F013 = Accel Ramp Time of Ramp 1

Factory Setting = 10 seconds

Range = 1 - 120 seconds

Sets the time between the initial torque set with F011 or F012 and either the Max Current Limit set with F014 or full output voltage. Set the time to enable soft starts without stalls. Also, consider the motor‟s application. For example, centrifugal pumps may require a shorter ramp time.

 Note:

Ramp time is affected by the following conditions:

1. Current limit will extend the ramp time if the motor does not reach full speed while in current limit mode.

2. Anti-oscillation circuit may shorten the ramp time if the motor reaches full speed before end of ramp.

F014 = Max Current Limit of Ramp 1

Factory Setting = 350%

Range = 200 - 600%

Sets the maximum motor current that the VMX Series starter will allow during Ramp 1. This limit applies to both voltage and current ramping. Current will be limited to this setting until either the motor reaches full speed or the over load protection feature trips (F003).

VMX Digital Solid State Soft Starter User Manual 39 | P a g e

 5.6.2.a

Ramp 2 (user-optional ramp)

This ramp is selected by closing the input for Ramp 2, TB1

– terminals 5 & 6 (see section 4.2.5). If this input is left open, the VMX

Series will respond only to Ramp 1 settings as listed above. Since ramp 2 is always used as an alternate to the default Ramp 1, different combinations of ramp profiles can be selected in F010.

Refer to Appendix 1 for additional information on ramp profiles.

F015 = Initial Torque (Voltage) of Ramp 2

Factory Setting = 60%

Range = 0 - 100%

Sets the initial voltage of Ramp 2 when F010 = 1 or 4. The initial torque level should be set to provide just enough torque to make the motor shaft begin to rotate while preventing torque shock damage to mechanical components.

F016 = Initial Torque (Current) of Ramp 2

Factory Setting = 200%

Range = 0 - 600%

Sets the initial current of Ramp 2 when F010 = 2 or 3. The initial torque level should be set to provide just enough torque to make the motor shaft begin to rotate while preventing torque shock damage to mechanical components.

F017 = Accel Ramp Time of Ramp 2

Factory Setting = 10 seconds

Range = 1 - 120 seconds

Sets the time between the initial torque set with F015 or F016 and either the Max Current Limit set with F018 or full output voltage. Set the time to enable soft starts without stalls. Also consider the motor‟s application. For example, centrifugal pumps may require a shorter time. See notes for F013 for more details.

F018 = Max Current Limit of Ramp 2

Factory Setting = 350%

Range = 200 - 600%

Sets the maximum motor current that the VMX Series starter will allow during ramp 2. (This limit applies to both voltage and current-type ramping.) The current will be limited to this setting until either the motor reaches full speed or the over load protection feature trips (F003).

 Note:

Ram p 2 is often useful as a “bump start” or as a temporary Acrossthe-Line start mode. Consult Appendix 1 for details.

VMX Digital Solid State Soft Starter User Manual 40 | P a g e

5.6.3 Jog Mode

The Jog Function is another user optional feature and is controlled by closing the input on TB1 Terminals 6 and 7. If this input is left open, the

VMX Series will ignore all Jog settings. Engaging the Jog feature along with the Start / Run Command provides an output from the SCRs, but will not continue ramping to full acceleration. This feature can Jog the motor at either a preset Voltage (F019

– F021) or a preset Current

(F021) depending upon the settings of the Ramp Type from F010, and can be initiated along with Ramp 1 or Ramp 2 (see Dual Ramp Select,

Section 4.2.5 and 5.6.2.a). It is also sometimes useful to use Jog in combination with Ramp 2, see section 4.2.5.c.

Note: Jog functions may become disabled by Comm port function F068 setting 3.

See section 5.6.11 for details.

Setting from

F010

Ramp 1 (Dual Ramp Input

Open)

Ramp &

Jog

Type

Voltage

Current

Voltage

Current

Initial

Torque from…

F011

F012

F011

F012

Jog

Torque from…

F021

F019

Ramp 2 (Dual Ramp Input

Ramp &

Jog

Type

Current

Closed)

Initial

Torque from…

F019 Voltage F015

F016

F021 Voltage F015

Jog

Torque from…

F019

F021

F019

Table 5.6.3: Jog Settings

Jog Voltage

Setting

Jog

Command

M ax.

Jog

Time

Voltage Ramp

New Start

Command

Caution:

Although the Thermal Register tracks all motor current use, continuous usage of the Jog feature risks thermal motor damage or nuisance tripping.

F019 = Voltage Jog

Factory Setting = 50%

Range = 5 - 100%

Sets the voltage level of the Jog feature and is typically used to check rotation, alignment, or to slowly move a load into position.

Jogging at a set voltage has no current control so the duration of the applied voltage must be limited to prevent excessive motor heating.

Time

Figure 5.6.3.1:

Voltage Jog and Jog Time

Jog Current

Setting

Current Ramp

F020 = Time of Voltage Jog

Factory Setting = 10 seconds

Range = 1 - 20 seconds

Set to minimize motor heating during a voltage jog. This setting is the maximum allowable time for jogging the motor using voltage only.

Jog

Command

New Start

Command

F021 = Current Jog

Factory Setting = 150%

Range = 100 - 500%

Sets output of a current Jog. The current jog feature is typically used to check rotation, alignment, or slowly move a load into position. This is not time-limited but should be used cautiously.

Time

Figure 5.6.3.2:

Curre nt Jog

VMX Digital Solid State Soft Starter User Manual 41 | P a g e

Kick Start

Voltage Setting

Kick

Time

Start

Command

Kick Start

Voltage Setting

Ramp Initial

Voltage Setting

Normal Ramp

Figure 5.6.4:

Kick Start

Normal

Voltage Ramp

Kick

Time

Figure 5.6.4.a:

Dwe ll Start Using Kick Start

5.6.4 Kick Start Mode

Kick Start applies a pulse of voltage to the motor producing a momentary “kick” of high torque to break the motor load free from high friction or frozen components. This pulse is limited to 2 seconds.

F022 = Kick Start Voltage

Factory Setting = 0 (Disabled)

Range = 10 - 100%

When F022

≠ 0, a voltage “pulse” is applied before the initial torque setting of F011 (or F012 if Current Ramp). This sets the voltage level and the duration of the pulse is set by F023. This setting should be higher than F011 (except for Dwell Starting, see below) and high enough to provide a benefit in the worst starting condition.

F023 = Kick Time

Factory Setting = 0.8 seconds

Range = 0.1 - 2 seconds

Sets the duration of time the Kick Start voltage is applied.

 5.6.4.a “Dwell” operation using Kick Start

In some applications such as chain drive machinery, the Kick Start feature can be used to slowly take up slack in the drive chain before applying full torque. This is referred to as “Dwell Starting” because the torque output stays low for a short time. To take advantage of this feature, simply set the Kick Start to the same level as the Initial

Torque setting. This will only work in Voltage Ramp mode.

 Note:

Do not use the Kick Start feature unless you determine that you need it. Using this feature may eliminate many of the mechanical and electrical benefits of using a Soft Starter.

VMX Digital Solid State Soft Starter User Manual 42 | P a g e

5.6.5 Pump-Flex



Decel Mode (F025 through F028)

Pump-Flex



deceleration is a feature of the VMX Series Soft Starter that slowly decreases the applied voltage to the motor when a stop command is given, resulting in a gentle decrease in motor torque.

Deceleration provides a way to extend the stopping time so that abrupt stopping does not occur. Deceleration is useful with centrifugal pumps, material handlers, and conveyors where abrupt stopping could be damaging to the equipment and/or load.

SEE APPENDIX 2 AT THE END OF THIS MANUAL for typical Pump-

Flex



Decel feature applications and more detailed descriptions of the following functions.

F024 = Deceleration Ramp

Factory Setting = 0 (Disabled)

Range = 0

– 2

When F024 = 0, the deceleration feature is disabled.

When F024 = 1, the deceleration feature is enabled AND the overload protection feature (F003 - F005) remains active (power off on

OL trip).

When F024 = 2, the deceleration feature is enabled and deceleration will continue even when an overload condition trips.

Full Spe e d

WARNING!

Setting F025 = 2 presents significant risk of over-heating the motor beyond its design limits which could result in motor damage and fire hazard. Do this only in circumstances where

the potential for mechanical damage outweighs the risk of motor damage.

Stop Command

(Bypass Contactor Opens)

F025: Begin Decel Level

(Immediate step down)

F026: Stop Level

(VMX Output Off)

F025 = Begin Decel Level (BDL)

Factory Setting = 60%

Range = 0 - 100% of line voltage

Used to drop voltage to a level where there is a noticeable effect on motor torque during initial Decel mode.

F026 = Decel Shut Off Voltage

Factory Setting = 30%

Range = 0 to (BDL -1)%

Sets the level where the starter is turned off, corresponding to where motor torque during Decel is no longer effective. Always set this function lower than the setting of F026.

Time

F027: Decel Ramp Time

(Determines slope)

Figure 5.6.5:

Pump-Fle x De ce l Ramp Se ttings

F027 = Decel Ramp Time

Factory Setting = 10 seconds

Range = 1 - 60 seconds

Sets the maximum time for the deceleration ramp to go from the

Begin Decel Level setting (F026) to the Decel Shut Off Voltage

(F027).

 Note:

When using the Decel function, count these cycles as additional

“starts” when determining maximum starts-per-hour of the motor.



Caution!

Decel is THE OPPOSITE of braking. Enabling the Decel feature will make the motor take

LONGER to stop than if it were simply turned off.

VMX Digital Solid State Soft Starter User Manual 43 | P a g e

5.6.6 Restart Delay

The VMX Series can be programmed to delay restarting upon restoration of line power after an outage. This allows multiple units to be programmed to restart at staggered times in an effort to avoid causing additional problems with the power supply system. Another term for this is “Sequential Start Delay”.

F028 = Restart Delay Time

Factory Setting = 0 (Disabled)

Range = 0 = Disabled (no delay), or 1 - 999 seconds

Sets a delay time before the starter can be restarted after a complete loss of power. Use this if multiple motors are connected to a supply system that may have trouble providing adequate power to restart them all at the same time. By using different Restart Delay Times on each unit, a sequential restart can be achieved.

 Note:

This is similar to the Coast Down Lockout Timer in F048, however it only activates on Power Loss.

F029 = Reserved

VMX Digital Solid State Soft Starter User Manual 44 | P a g e

5.6.7 Process Timer Control Mode (F030 through F039):

The following special functions allow the VMX Series starter to operate automatically from a Process Control Timer using an internal Real Time

Clock.

Only brief descriptions of the functions are provided here.

REFER TO APPENDIX 4 at the end of this manual for detailed

operations and instructions.

 Note:

These functions may interact with the Coast Down Lockout (F048),

Starts-per-Hour Lockout (F049), Minimum Time Between Starts

(F050), Auto-Reset (F052 and F053) and Restart Delay Time

(F028) functions if enabled. Be sure to review and understand settings for these functions before using the Process Timer.

F030 = Process Control Timer Selection

Factory Setting = 0 (Disabled)

Range = 0, 1, 2

This function enables a Process Control Timer, which may be used alone or in conjunction with the Time Clock Controller feature (F032-F039). This timer offers two operating modes, selected by entering 1 or 2 into the function parameter:

Setting 1 = Minimum (Batch) Run Timer: After a Start

Command, the starter runs until the batch timer expires. If stopped and restarted it will complete that batch time sequence.

Setting 2 = Permissive Run Timer. After a Start Event from the TCC, the starter can be started and stopped as necessary, until the timer expires.

F031 = Process Timer Value

Factory Setting = 1

Range = 1

– 9999 minutes

This function loads a value into the Process Timer above. When initialized, the value counts down towards 0.

 Note:

The above Process Control Timer in F030

– F031 works in conjunction with the Time Clock Controller in F032

– F039. When the TCC is set to One-Shot (F032 = 0), this timer will activate whenever a Start Command is given. When F032 = any other setting, this timer activates according to that schedule.

VMX Digital Solid State Soft Starter User Manual 45 | P a g e

F032 = Real Time Clock Controller

Factory Setting = 0 (One Shot)

Range = 0 - 8 settings

This function is used to select the operating mode of the 24hr /

7 Day Time Clock Controller (TCC). F032 sets the number of days in which the TCC will repeat the Start Event Cycle up to seven discrete Start Events selected in F033 through F039.

After each Start Event, the VMX Series will run per the time value set in F030 above. If F030 = 0, the TCC settings are ignored. See Appendix 4 for additional details.

1 = 1 day per week,

2 = 2 days per week

…

7 = 7 days per week

8 = A single 24HR event, non-repeating

0 = One-Shot. When set to 0, the VMX Series responds only to each Start input command. Use this setting to allow the Process

Timer to operate without the TCC (see Appendix 4 if F030=2).

F033 = Event #1 Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #1 in the

RTCC above. Once started by this event, the VMX will run the motor according to the selections entered into F030 and F031.

F034 = Event #2 Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #2 in the

TCC above.

F035 = Event #3 Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #3 in the

TCC above.

F036 = Event #4 Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #4 in the

TCC above.

F037 = Event #5Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #5 in the

TCC above.

F038 = Event #6 Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #6 in the

TCC above.

F039 = Event #7 Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #7 in the

TCC above.

VMX Digital Solid State Soft Starter User Manual 46 | P a g e

F042: O. C.

Trip Setting

Running

Current

Time

F044: U.C.

Trip Setting

Normal

Running

Current

Time

Over Current Trip

F043: O.C.

Trip Delay

Figure 5.6.8.a:

Ov e r Curre nt Trip

Under Current

Trip

F045: U.C.

Trip Delay

Figure 5.6.8.b:

Unde r Curre nt Trip

5.6.8 Current and Ground Fault Protection Features

F040

– F050 set extended protection features that may be used in the

VMX Series starter. Percentages shown are all based automatically upon the Motor FLA setting from F001 except Ground Fault, F046. No additional calculations are necessary.

 Note:

All of these features are disabled at the factory and must be

enabled via user programming as follows:

F040 = Current Imbalance Trip

Factory Setting = 0 (Disabled)

Range = 5 - 30% or 0 (Disabled)

Use to set the trip level for when current imbalance between any two phases exceeds this amount for the time specified

F041.

F041 = Current Imbalance Trip Delay

Factory Setting = 2 seconds

Range = 1 - 20 seconds

Provides a time delay to prevent nuisance trips from shortduration transients. Using default settings, if the difference in output current between two phases exceeds 10% of FLA for more than 2 seconds, the starter will trip.

F042 = Over Current Trip / Shear Pin Trip

Factory Setting = 0 (Disabled)

Range = 100 - 300%, 0 (Disabled)

When a value other than 0 is entered for F042, the starter will trip when the output current of any phase exceeds the amount set and the time specified in F043. This is also referred to as a

“Shear Pin Trip” and can be used to protect mechanical components from damage due to jammed loads.

F043 = Over Current Trip Delay

Factory Setting = 1 second

Range = 1 - 20 seconds

Provides a time delay to prevent nuisance trips from shortduration transients. For example using default settings, if the output current of any phase exceeds F042 for more than 1 second, the starter will trip.

F044 = Under Current Trip

Factory Setting = 0 (Disabled)

Range = 10 - 90%, or 0 (Disabled)

When a value other than 0 is entered for F044, the starter will trip when the output current of any phase drops below the amount set, and the time specified by F045. This fault condition is often referred to as a “Load Loss Trip” and can be used to detect a broken shaft, V belt or other mechanical drive system component failure. In pumping applications, this can be used as a “Loss of Prime” trip.

F045 = Under Current Trip Delay

Factory Setting = 2 seconds

Range = 1 - 60 seconds

Provides a time delay to prevent nuisance trips from shortduration transients. Using the default setting, if the output current of any phase drops below F044 for more than 2 seconds, the starter will trip.

VMX Digital Solid State Soft Starter User Manual 47 | P a g e

 5.6.8.a

Ground Fault

F046

– F047 provides Ground Fault protection for equipment only

(a.k.a. Arcing Ground Fault) using the Residual Current method.

Trip settings are based on the CT ratio as shown in F074 (see below). A delay time can be set by F047 to help prevent nuisance trips. Ground current can always be viewed in the Status Display, shown with a “G” prefix (see section 5.3.1).

WARNING!

THIS IS NOT INTENDED TO BE USED AS "PERSONNEL PROTECTION" GROUND FAULT!

This feature is only intended to provide a level of equipment protection against damaging ground currents. Ground faults are potentially dangerous conditions and must be corrected immediately for safety of operating personnel.

F046 = Ground Fault Trip

Factory Setting = 0 (Disabled)

Range = 5 - 90% of CT value, or 0 (Disabled)

When a value other than 0 is entered for F046, the starter will trip if current to ground exceeds this percentage of the unit CT value. The CT value is shown in F074 (see section 5.6.12). This value is different from the Unit Rating or FLA setting. To calculate actual ground current, multiply the CT value of F074 by the setting of F046.

Example:

210A starter, desired Ground Fault Trip level is 20A:

On this unit, the CT value reading from F074 will be 250 (250:5)

20 / 250 = 0.08 (8%).Set F046 to 8

F047 = Ground Fault Trip Delay

Factory Setting = 2 seconds

Range = 1 - 60 seconds

Provides a time delay to prevent nuisance trips from shortduration transients. Using default setting, if the Ground Fault current exceeds the level set in F046 for more than 2 seconds, the starter will trip.

CAUTION:

This method of Ground Fault sensing may not provide adequate equipment protection in resistance-grounded systems. We recommend providing external GF protection using a core balanced Zero Sequence CT for those types of applications.

Consult factory for additional assistance.

VMX Digital Solid State Soft Starter User Manual 48 | P a g e

Figure 5.6.9:

Coast Down Lockout Timer

5.6.9 Lockouts, Reset and Internal Protection Features

F048

– F050 provide lockout protection for motors and equipment that may have potentially damaging consequences from premature restart or with limited duty cycles. Time and count values for these lockouts can be viewed in F055

– F058. Time values are based on the Real Time

Clock and DONOT reset when power is lost or disconnected.

Emergency clearing of lockouts can be accomplished in F071.

 Note:

When F048 through F050 are used with 3 wire control systems, a

Start command will not seal in during lockout time. When time has expired, a new Start command will be necessary.

WARNING!

When F048 through F050 are used with 2-wire control, the starter may re-start automatically when time has expired. Adequate warnings similar to those in Section

3.1.3.b should be observed.

F048 = Coast Down Lockout Timer (Back Spin Timer)

Factory Setting = 0 (Disabled)

Range = 1 - 60 minutes, or 0 (Disabled)

F048 = 1 - 60, sets the number of minutes that the starter must be off before a restart can be attempted. This function is useful in applications such as pump motor backspin protection (where you need to prevent the pump motor from restarting if it is spinning backwards), 2 speed operations where speed changes require a minimum disconnect (spin-down timer), or reversing applications to prevent plugging (anti-plugging timer).

F049 = Maximum Starts per Hour Lockout

Factory Setting = 0 (Disabled)

Range = 1 - 10 or 0 (Disabled)

F049= 1 - 10, counts the number of start commands within a 1 hour period. If the setting (maximum starts per hour) is exceeded, starting is prohibited until sufficient time has expired.

This timer initiates upon the first start in an hour. It resets after 1 hour from that start and waits until another subsequent start to initiate again. (Often used in conjunction with F050).

 Notes:

 Consult the motor manufacturer for a “Starts-per-Hour” or “Starting

Duty Cycle” rating. Larger motors tend to have lower starts-per-hour ratings.

 When using the Decel function (F025) or an electronic braking option, count these cycles as additional “starts” when determining maximum starts-per-hour.

VMX Digital Solid State Soft Starter User Manual 49 | P a g e

F050 = Minimum Time Between Starts Lockout

Factory Setting = 0 (Disabled)

Range = 1 - 60 minutes, or 0 (Disabled)

When F050 is set to 1 through 60, the motor cannot be restarted within the time specified after the first start. Time between starts is calculated from the time of the first start command to the next regardless of run time or off time.

Example:

If F050 = 15, motor will not be allowed to re-start within 15 minutes of the first start.

This function is useful as a “Short-Cycle Timer” to prevent excessive motor wear when automatic demand control may occasionally cycle on and off too quickly. e.g. compressors or sump pumps.

 5.6.9.a

Internal Protection Features

The VMX Series starter contains additional protection features that are built-into the hardware and are factory preset. Function F051 is provided to alter these settings via numerical preset programming.

For maximum protection, all of these features are turned ON as a factory default and should not be changed unless necessary for service purposes, testing or to accommodate non-standard applications. Factory default settings are as follows:

 Phase Rotation: Protection is ON. The expected rotation sequence is set for A-B-C.

 Phase Current Loss (Running): Protection is ON. The unit trips at

<20% of unit Max amps after 3 seconds of acceleration and at full speed.

 Shorted SCR: Protection is ON. The unit will lock out if one SCR is shorted (no voltage drop across the SCR).

 Shunt Trip: Protection is ON. The unit trips if current flows in any phase while in the OFF mode.

 PTC Trip: Protection is ON. The unit will trip if the PTC Input resistance exceeds set value (or open).

 Line Phase Loss (Stopped): Protection is ON. The unit will trip if any phase voltage is not present while the unit is not accelerating or stopped.

F051 = Internal Protection Features

Factory Setting = 255 (all enabled)

Range = 1

– 255: Decimal value representing bit locations

F051 represents the decimal value for the binary setting of 8 bits (byte) of memory. Each of the 8 bits is set to a 1 or 0 and enables or disables the protection features depending on the setting. By adding (enable) or subtracting (disable) the decimal value associated with each of the protection features to the

F051 total allows changes to be simply made by entering the new value via the keypad. The Factory Default value is

F051 = 0255 (binary 11111111), which enables all features.

The decimal values for each feature are as follows:

VMX Digital Solid State Soft Starter User Manual 50 | P a g e

Phase Rotation Protection:

The VMX Series is set up to monitor an expected phase rotation and will trip if this changes. Control of this feature is divided into two categories: On-Off and Expected Sequence. The default setting is On, with an Expected Sequence of A-B-C.

The ability to turn this feature ON or OFF is useful in applications where the VMX Series starter is going to be used downstream from an existing reversing contactor / starter, or to avoid conflicts with other protection devices.

 Rotation Trip On-Off Control Decimal value = 1 (b 00000001)

If this feature is On (default setting) and you want to turn it Off,

Subtract 1 from F051. If this feature is Off and you want to turn it

On, add 1 to F051.When set to On, a trip will occur when the

Expected Sequence (see below) is incorrect.

On large motors where large multiple cables are used, it may be easier to change the Expected Sequence in the VMX Series starter rather than to swap the cables.

 Expected Phase Rotation Sequence Decimal Value = 2

(b 00000010

The A-B-C rotation is the default setting. To change to A-C-B, subtract 2 from F051. To change from A-C-B rotation to A-B-C, add 2 to F051.

If the Rotation Trip is set to Off (see above), this setting is ignored.

Phase Current Loss (Running) Protection:

This feature will cause a Trip if the current in any phase (or all 3) is less than 12% of the CT value after 3 seconds from a Start Command. (Note that this is based on the Max Amp rating and not the programmed FLA).

Turn it OFF if the motor no-load current is exceptionally low such as in high inertia machines, or if you are testing a large starter with a

small motor.

 Phase Loss (Running) Protection Decimal Value = 4

(b 00000100)

This feature is On (default setting). To turn it Off, Subtract 4 from F051.

If this feature is Off and you want to turn it On, add 4 to F051.

Shorted SCR Lockout protection:

This feature will cause a Lockout if at least one SCR is shorted, based on the expected voltage drop across the SCR assembly when the unit is

OFF. (Note- A shorted SCR cannot be detected while the unit is running or in Bypass mode). If qualified personnel knowing the ramifications of having a shorted SCR issue requires an emergency restart, this feature can be turned to OFF. This is not the same as a Shunt Trip circuit (see below). This is a lockout of the NEXT start command.

 Shorted SCR Lockout Decimal Value = 8 (b 00001000)

This feature is On (default setting). To turn it Off, Subtract 8 from

F051. If this feature is Off and you want to turn it On, add 8 to F051

VMX Digital Solid State Soft Starter User Manual 51 | P a g e

Shunt Trip:

Shunt Trip is a feature that will cause an immediate Trip if the VMX

Series detects current flowing through any phase (or all) while the VMX is in the Off state. The trip function is typically associated with the Aux.

Relay setting 7 (see F060-63), wired to a Shunt Trip coil in an upstream circuit breaker or an in-line contactor. This function is to interrupt power flow to the motor windings in order to prevent damage. The usual cause is multiple shorted SCRs or a welded Bypass Contactor. The only time this function should be turned off is for troubleshooting by qualified service personnel.

 Shunt Trip Decimal Value = 16 (b 00010000)

This feature is On (default setting). To turn it Off, Subtract 16 from

F051. To turn it On, add 16 to F051.

PTC Trip:

This feature controls the inclusion of the PTC Input (see Section 4.2.7).

When it is ON (default setting), a jumper wire or other circuit must be installed on the PTC input if a PTC resistor is not included in the motor.

Turn this feature to OFF for troubleshooting or if a jumper wire is not used.

 PTC Trip Decimal Value = 32 (b 00100000)

This feature is On (default setting). To turn it Off, Subtract 32 from

F051.To turn it On, add 32 to F051.

Line Phase Loss (Stopped) Trip:

This feature will prevent the VMX Series starter from attempting to start if the voltage in one (or more) of the incoming phases is not present.

This can be used to detect a blown fuse or power supply loss provided control power is still available. It differs from the Phase Loss (Running)

Trip in that it is based upon line voltage and does not require that a Start

Command be given. This trip function resets itself after determining that all 3 phases have voltage applied. The voltage level at which this feature activates is fixed at approximately 100VAC. It is not adjustable and should not be used as Under Voltage protection.

 Line Phase Loss (Stopped) Trip Decimal Value = 64

(b 01000000)

This feature is On (default setting). To turn it Off, Subtract 64 from F051.

To turn it On, add 64 to F051.

 Notes:

1) When using an In-Line Isolation Contactor, it may be necessary to turn Off this protection (by subtracting a numeric value of 64 from F051) in order to avoid nuisance tripping whenever the In-Line

Contactor opens.

2) This protection will automatically reset itself when line voltage is present on all 3 phases. When using 3-wire control, the VMX Series will not attempt to restart unless the Start Command is re-initiated.

 Caution:

When using 2-wire control, the starter will restart when this

feature resets itself after all 3 phases are present.

VMX Digital Solid State Soft Starter User Manual 52 | P a g e

5.6.9.a (continued) Function 51: Internal Protection Features

Bit

Fault

Display

Code

Protection

Function

Description

0 ROT*

Phase

Rotation

Trip

Phase Rotation protection.

Phase rotation must match selection in Bit #2 below. Setting to Off (0) will make the VMX insensitive for use behind a reversing contactor

1 ABC

Expected

Phase

Sequence

2 = A-B-C Phase Rotation Sequence Only

0 = A-C-B Phase Rotation Sequence Only

PLa or

PLc*

SS*

Phase

Current

Loss

Shorted

SCR

Phase Current Loss, any phase current reading that is less than 12% of the CT rating after 3 seconds from Start command.

At least one SCR is shorted; There is no voltage drop across the SCR phase assembly.

ST*

PTc*

Shunt

Trip

PTC Input

Trip

Shunt Trip of the main Circuit Breaker or Isolation

Contactor (if provided and wired to an Aux. relay in F060-F061). Two or more SCRs have shorted in opposing phases so current is flowing to the motor while the VMX was in the Off state.

PTC Trip function. This can be disabled so that a jumper is not required across the PTC inputs.

PLd or n3Ph

Line Phase

Loss Trip

Protection against loss of input line voltage.

Disable when using an In-Line Isolation Contactor or any other system that normally removes line power from the starter. Resets automatically when line voltage returns.

7 --- Reserved Reserved for factory use

* = Operating Mode designation. See Fault Code List for description.

Table 5.6.9.a: Function 51 table of Hardware Protection Features

Default

Bit

Setting

1 (On)

(A-B-C

Rotation)

1 (On)

0 (Off)

Decimal

Value

128

 Note:

To restore all settings back to the factory default, enter a value of

127. A value other than the default value of 127 indicates that one or more functions have been changed. To determine which of the protective functions have been changed/turned-off subtract the value displayed from 127 and compare the result against the

„decimal value‟ column shown in table 5.6.9.a.

Example: F051 reads a value of 109. Subtract 109 from 127 and a value of 18 remains. The value 18 does not represent a single bit value indicating that more than one function has been changed.

Referring to Table 5.6.9.a, find the largest decimal value as shown in the „decimal value‟ column smaller than 18. In this case a value of

16 (bit 4). This leaves a value of 2 (18 minus 16) which represents bit 1 (2). So in this example a value of 109 indicates that the Shunt

Trip feature had been turned off (bit 4), and the Expected Phase

Sequence had been changed to A-C-B (bit 1).

Instead of determining the previous selection add up all values in

„decimal value‟ column of the functions to be turned off and subtract this value from 127 and program the result into F051.

VMX Digital Solid State Soft Starter User Manual 53 | P a g e

 5.6.9.b

Auto-Reset Programming (F052

– F054)

The VMX Series can be programmed to automatically attempt a reset based on the selected

„auto-reset‟ faults (F52), provided a

Start Command is present (see Section 4.2) and no fault condition is active. Function

F52 selects the „Auto-Reset‟ faults and function

F53 sets the number of reset attempts. If F053 is set to 0 (default setting), the VMX Series auto-reset function is disabled.

 Note:

When using 3 wire control:

For safety reasons the VMX Series will not attempt restarting unless the Start Command is reinitiated and maintained during a restart attempt.

F052 = Auto-Reset Selected Faults

Factory Setting = 0 (Disabled)

Range = 1 - 12, or 0 (Disabled)

If F052 = 1 through 12, the VMX Series will attempt to restart after the fault(s) coded in the following table. Only one selection can be entered.

F052

Setting

Fault Condition Description

Auto Reset Disabled

Over Temperature Trip

Over Current (Shear Pin) Trip

Under Current Trip

Phase Loss Trip

Current Unbalance Trip

Ground Fault Trip

Short Circuit Trip

Faults 1, 2 or 3 above

Faults 4, 5 or 6 above

Any Fault except 7

Any Fault except 6 & 7

Any Fault above, 1 - 7

Display Readout

Reference

---

PLa or PLc

OT, OC or UC

PL, UB or GF

No SC

No GF and no SC

OT, OC, UC, PL, UB or GF

Note 1: UC, OC or UB require operation to resume before the fault can be detected.

Note 2: Cycling and / or restoration of control power will reset all of the above faults.

Note 3: Overload Trip reset function is programmed only in F005. See Section 3 for details

Note 4: Reset attempts with a fault condition present will cause a new fault. This will be logged into the the fault history (F085

– F093) and may overwrite previous fault records. Line Loss Trip

(see F051) will automatically reset and is not included in this list.

Table 5.6.9.b: Faults Selected for Auto-Restart

F053 = Auto-Restart Attempts

Factory Setting = 0 (Disabled)

Range = 1 - 10 Attempts, or 0 (Disabled)

If F053 = 1 through 10, the VMX Series will attempt to restart if the Start Command is present for this number of times. If set to

Zero, the starter will not attempt to reset automatically.

VMX Digital Solid State Soft Starter User Manual 54 | P a g e

 5.6.9.c

Timer Value Readouts for Protection Features

F054

– F059 provide display of timer or register values for information only. The user cannot alter them. Upon power loss and restoration, these values are updated for time elapsed.

F054 = Restart Delay Time Readout

Factory Setting = Not Applicable

Range = 1 - 999 Seconds

Remaining time value readout of F028, the Auto-Restart Delay

Timer.

F055 = Coast Down (Backspin) Timer Value

Factory Setting = Not Applicable

Range = 1 - 3600 Seconds

Remaining time value readout of F048, the Coast Down

Lockout Timer.

F056 = Starts per Hour Timer Value

Factory Setting = Not Applicable

Range = 1 - 3600 Seconds

Remaining time value readout of F049, the Starts-per-Hour

Lockout Timer.

F057 = Starts per Hour Counter Readout

Factory Setting = Not Applicable

Range = 1 - 10 Starts

Incremental counter value readout of F050, the Starts-per-Hour

Lockout.

F058 = Time Value Between Starts Readout

Factory Setting = Not Applicable

Range = 1 - 3600 Seconds

Remaining time value readout of F050, the Minimum Time

Between Starts Timer.

F059 = Thermal Capacity to Start Readout

Factory Setting = Not Applicable

Range = 0 - 100 % Thermal Capacity

Readout only for the user‟s viewing of the motor Thermal

Capacity percentage required to allow a Reset after an

Overload Trip. Use this function in conjunction with the

Remaining Thermal Capacity (in the Status Screen group) to be able to predict when a restart will be allowed. This value is automatically updated by the VMX Series CPU whenever a successful start sequence has been accomplished. The VMX

Series essentially “learns” how much Thermal Capacity is needed in the motor in order to successfully restart, and stores the information at this Function. Upon power loss and restoration, this value is updated for elapsed time.

VMX Digital Solid State Soft Starter User Manual 55 | P a g e

5.6.10

Output Relays

There are three programmable relays (rated 240VAC, 5A, 1200 VA) in the VMX Series. They can be programmed for change of state indication for any one of the 25 conditions identified in the following chart.

F060 = Aux Relay 1: Form C (SPDT)

Factory Setting = 1 (Run / Stop)

Range = 1 - 27 (See list)

Use to program the desired operation for Relay # 1.

F061 = Aux Relay 2: Form C (SPDT)

Factory Setting = 2 (At Speed / Stop)

Range = 1 - 27 (See list)

Use to program the desired operation for Relay # 2.

F062 = Aux Relay 3: Form A (SPST, N.O.)

Factory Setting = 16 (Any Trip, 5 - 15)

Range = 1 - 27 (See list)

Use to program the desired operation for Relay # 3.

F063 = Aux Relay Delay Timer for Settings 23

– 26

Factory Setting = 0 (Disabled)

Range = 1

– 999 seconds, or 0 (Disabled)

Use to program the desired On Delay for any Aux. Relay that has been programmed for Settings 23 through 26 from the chart below.

Setting

Relay Operation Description

Run / Stop (Changes on Start Command, resets on Stop)

At Speed / Stop

At Speed / End of Decel

Start / End of Decel

Short SCR Trip

Phase Loss Trip

Shunt Trip

OL (Motor Thermal Overload) Trip

OT (Starter Thermal Over Temperature) Trip

Short Circuit Trip

Current Unbalance Trip

Over Current (Shear-Pin) Trip

Under Current Trip

Ground Fault Trip

Phase Rotation Trip

Any Trip (#5 - #15)

Any Trip, (#5-#15) flashing output*

Coast Down Time Lockout

Starts Per Hour Lockout

Time Between Starts Lockout

Any Lockout (#18-#20)

Run Timer (F030) Engaged

Run / Stop with On-delay from F063

At Speed / Stop with On-delay from F063

At Speed / End of Decel with On-delay from F063

Start / End of Decel with On-delay from F063

Power Loss (nCP No Control Power) Trip

*Note: Flash rate for Setting #17 is ½ second On and Off

Table 5.6.10: Output Relay Programming

F064 = Reserved

VMX Digital Solid State Soft Starter User Manual 56 | P a g e

Special Note when using Serial Comm:

When F068 = 3, the function of the Jog /

Remote Input on TB-1 terminals 7 and 8 will change. Closing the Input will cause the

Comm. port control to function as per setting

F068=1. Leaving the input open will cause the Comm. port to function as per setting

F068=0.

When F068 = 1, 2 or 3, the Jog function will cease to operate. Since Jogging is a local function, set F068 to 0 when using it.

N C

RAMP2 JOG

6 7 8

PTC

Local Remote

Figure 5.6.11:

Local - Remote Control Connections to TB-1

Only when F068 = 3

OPTO

5.6.11

Communications

The VMX Series starter is shipped from the factory ready to accept

RS-485 Serial Communications using Modbus RTU protocol. Additional detailed instructions on accomplishing communications are available in a Serial Communication Supplement to this manual. F065

– F067 are used to set the communications parameters in the starter for use by the adaptor module. F068 determines how the Start / Stop functions work through the comm. port.

F065 = Communications

Factory Setting = 0 (Disabled)

Range = 0

– 2

This enables serial communications with remote monitoring and control systems and sets the format for Modbus RTU protocol.

Once Enabled, the local start / stop inputs are altered to avoid inadvertent starting. See F068 for details.

F065 = 0, communications are disabled.

F065 = 1, uses the std 11 bit Modbus format w/ parity bit.

F065 = 2, a non-standard 10-bit format without a parity bit is

used to accommodate some systems using this

method.

F066 = Baud Rate

Factory Setting = 9.6 KB

Range = 4.8 to 19.2 KB

Set value to either 4.8 KB, 9.6 KB or 19.2 KB and match the setting of the host device.

F067 = Modbus Address

Factory Setting = 1

Range = 1

– 247

Using Modbus communications protocol, up to 247 VMX Series starters can be networked using RS485 standard communication, each having a unique address. Two devices with the same address will result in a communications error.

F068 = Remote Starter Control

Factory Setting = 0 (disabled)

Range = 0

– 3

This determines how the VMX Series starter is to be controlled when using serial communications.

When F068 = 0, the starter can be monitored by the Comm port, but not controlled.

When F068 = 1, the starter will be controlled by the comm port.

In addition, the Start / Stop inputs are altered as follows: The hardwired Start command is put in “AND” logic with the Comm port; both Start commands must be on for the VMX to start. The

Stop function is put in “OR” logic; either the Comm. port Stop command OR the hard-wired Stop will cause the VMX to stop.

When F068 = 2, the VMX starter is in full control of the Comm. port only. Local Start / Stop inputs become completely inactive.

Use this function only when controlled shutdown is a priority.

When F068 = 3, the VMX starter will change the function of the

Jog / Remote Input to cause a switch between the functions of setting 0 and setting 1 as listed above. When the input is open, the starter will respond to the Comm port as per setting F068=0 above. When the Jog / Remote Input is closed, the starter will respond as per setting F068=1 above. Use this function if it is necessary to have a return to local start/stop control should the communications system fail or become disconnected.

VMX Digital Solid State Soft Starter User Manual 57 | P a g e

F069= Reserved

5.6.12

System Settings

The following functions set operator interface controls and unit programming. Also contained here are the Clock settings used for history functions. Change the Clock settings if accurate time values are important.

F070 = Parameter Lock / User Password

Factory Setting = 0 (disabled)

Range = 0

– 999

Use only when necessary to prevent unauthorized access.

Provides users with the ability to prevent unauthorized operators from making changes to the programmed functions. If you do NOT need to take advantage of this feature, do not enter anything into this function. The factory default is disabled, and no Password is necessary to make changes to the program.

See Appendix 3 at the end of this manual for detailed instructions on using and altering the Parameter Lock / User Password feature.

F071 = Emergency Clear / Reset

Factory Setting = 0 (disabled)

Range = 0

– 2

This Function serves two purposes. It can clear the memory values used for lockouts and overload protection, and it can reset all functions to the factory default settings. This is a “One-

Shot” feature, so when another value is entered as shown below, this function automatically returns to the default state.

 When F071 = 0, the feature is disabled.

 When F071 = 1, the values stored in the Thermal Register and all of the Lockout Timers will be cleared. This will allow an Emergency

Restart without having to wait for proper cool down time or lockout timers to expire.

WARNING!

Clearing the Thermal Register to allow restarting without proper cool-down time after an

Overload Trip can result in motor damage and fire. Use only where emergency restart is

necessary with knowledge of these potential hazards.

 When F071 = 2, the values of all functions will be reset to the factory default settings. Use this feature when setting conflicts have occurred or parameters have been tampered with. The Fault History is also cleared with this function.

 Note:

This will not reset F070 = Parameter Lock / User Password. See

Appendix 3 for resetting this feature.

F072 = Reserved

VMX Digital Solid State Soft Starter User Manual 58 | P a g e

F073 = Unit Frame Rating:

Read Only. Reserved for Factory Use

F074 = CT Ratio:

Read Only. Primary value of the VMX Series internal Current

Transformers (CTs) for use in determining the GF trip settings

(F046). CTs cannot be used for external metering. Alteration is reserved for factory use only.

 5.6.12.a

Real Time Clock Settings

Functions F075 through F080 set the system real time clock. The time clock is used in the 24hr Time Clock Controller operation (F032

– F039) and for date/time stamping of the Fault History. The clock automatically adjusts for leap years and is backed up by a Lithium ion battery for long life.

 Note:

The time clock does not automatically adjust for daylight savings time.

F075= Year

Factory Setting = Year of manufacture

Range = 2000 to 2047

F076 = Month

Factory Setting = Month of manufacture

Range = 1

– 12

F077 = Day

Factory Setting = Day of manufacture

Range = 1

– 31

F078 = Hour

Factory Setting = Actual (EST)

Range = 0 - 23 (12:00 midnight is hour 0)

F079 = Minute

Factory Setting = Actual (EST)

Range = 0

– 59

F080 = Second

Factory Setting = Actual (EST)

Range = 0

– 59

F081 = Firmware revision number for Factory Use

F082 -F084 = Reserved

VMX Digital Solid State Soft Starter User Manual 59 | P a g e

5.6.13 Fault History and Statistical Data

F085

– F097 contain the Fault History and Statistical data for the Run

Mode.

 5.6.13.a

Fault History

Fault codes for each of the three latest events are stored with time and date stamps; see Chapter 7 for a complete list of fault codes and corresponding error displays.

Time stamps use the 24hr HH.MM format, so for example 3:19 PM would display as [15.19]

Date stamps use the MM.DD format, so for example September 3 rd would display [09.03]

Fault #1

(Latest Fault)

Fault #2

(Previous Fault)

Fault #3

(Oldest Fault)

Fault code:

(See Chapter 7)

Time Stamp

(HH.mm)

Date Stamp

(MM.DD)

F085

F086

F087

F088

F089

F090

F091

F092

F093

Table 5.6.13.a: Fault History Configuration

F085 = Latest Fault Code (Fault #1)

Factory Setting = 0 (No Fault)

Range = 0

– 27

This Function displays the Fault Code of the latest fault event.

F086 = Time Stamp of the Latest Fault

Factory Setting = 00.00 (No Fault)

Range = 00.00

– 23.59 (24hr time format)

This Function displays the time of the latest fault event.

F087 = Date Stamp of the Latest Fault

Factory Setting = 00.00 (No Fault)

Range = 01.01

– 12.31

This Function displays the date of the latest fault event.

F088 = Same as F085 except for the Previous Fault (Fault #2)

F089 = Same as F086 except for the Previous Fault.

F090 = Same as F087 except for the Previous Fault.

F091 = Same as F085 except for the Oldest Fault (Fault #3)

F092 = Same as F086 except for the Oldest Fault

F093 = Same as F087 except for the Oldest Fault

VMX Digital Solid State Soft Starter User Manual 60 | P a g e

 5.6.13.b

Statistical Data

F094 - F097 display information from the Run Time / Elapsed Time meter and Run-Cycle counter.

Run Time includes Accel, Run, Decel, and Jog operations.

Run Cycles are counted only when the starter reaches At-Speed mode.

F094 = Run Time, Hours

Factory Setting = 0000

Range = 000.9 - 999.9 hours

Run times in excess of 999.9 are recorded in F095.

F095 = Run Time, K Hours

Factory Setting = 0000

Range = 0000 - 9999 K hours

0001 in readout means a run time of 1,000 hours.

F096 = Run Counts

Factory Setting = 0000

Range = 0000

– 9999

Run counts in excess of 9999 are recorded in F097.

F097 = Run Counts, 10K Times

Factory Setting = 0000

Range = 0000 - 9999, 10 thousand times

0001 in readout means a run count of 10,000 operations.

Examples:

F095 F094

Run Time

23,047 Hours

Overflow

Value

Basic

Value

0002 3047

F097 F096

Run Counts

18,702 Starts

0001 8702

Table 5.5.15: Statistical Data Examples

VMX Digital Solid State Soft Starter User Manual 61 | P a g e

Chapter 6 - Start-up

F001

F002

F003

Fn #

F004

F005

F010

F011

F013

F014

F015

– F018

F019

– F052

F053

F054

– F059

F060

F061

F062

F063

F065

– F068

F070

F071

F073

– F080

6.1

Basic Startup

Your new VMX Series Soft Starter is factory preset for a wide variety of applications and often can be used with minimal adjustment.

6.1.1

Three Step Process

1. Connect L1, L2, and L3 to the input voltage source and

T1, T2, and T3 to motor.

2. Connect control wires and control power.

3. Program motor FLA (F001).

6.1.2 Start-up Parameters and Factory Defaults

In the initial start-up, test the performance of the starter with the initial factory presets, if required adjust or enable the more advanced features to meet your specific application requirements.

Function

Name

Factory

Setting

Description / Factory Setting

FLA must be programmed for the starter to operate.

Motor Nameplate FLA.

Motor Nameplate

Service Factor

Overload Class During Start

Overload Class During Run

1.0 SF

Class 10

Change only if necessary and for motors rated above 1.0SF

NEMA / UL Class 10

Overload Reset

Ramp Profile

0 (Manual)

0 = Manual

Ramp 1 and Ramp 2 =

Voltage Ramp with Current Limit

Initial Torque 60 60% Initial Voltage

Ramp Time

Current Limit

Ramp 2 settings

350

---

10 Second Ramp (Ramp 1)

350% of programmed FLA

Inactive unless Ramp 2 Input is closed

Software protection and control features

--- Inactive unless selected

127 All active Internal hardware protection features

Timer and counter value readouts

Aux Relay #1

Aux Relay #2

Aux Relay #3

Aux Relay Delay

Communications

Parameter Lock

Reset Function

System settings and time clock

---

----

---

Read only

Run / Stop

At-Speed / Stop

Any Fault

No Delay

Not Used unless without optional

Comm Adaptor.

User password disabled

Use to reset to default values

User choice to adjust clock

F085

– F093

Fault History --- Read only

Table 6.1.2: Factory Presets

VMX Digital Solid State Soft Starter User Manual 62 | P a g e

6.2 Start-up Check List

Supply voltage matches the rated supply voltage of the unit.

Horsepower and current ratings of the motor and starter have the same rating or the starter has a higher rating.

Initial ramp time and torque adjustments have been checked.

Input voltage source are connected to the starters input terminals

L1, L2 and L3.

Motor leads are connected to the starter output terminals T1, T2, and T3.

Appropriate control power is applied and/or control connections have been made.

“Power On” light located on the front of the unit turns on when control power is applied.

Four 7-segment LED readout is visible.

The motor‟s FLA has been programmed in function F001.

The thermal overload is properly set. (Use F003 and F004 to set OL

Class.)

The motor area and equipment are clear of personnel and parts before start-up.

6.3 Sequence of Operation

 Apply three-phase power to the unit. The motor should not run until the start command is applied.

 Apply control power and check that the “Power On” LED comes on.

 Status Display should read [0000.] showing no current in Phase A

(minor flickering of the first digit is common).

 Apply the Run (Start) command. The motor should begin to accelerate. Status display will read Phase A Amps at an increasing rate.

 When the motor reaches full speed, the “At Speed” LED comes on.

Status display should show a sharp decrease in Phase-A amps.

 If a Bypass Contactor is present (VMX…-BP model), the Bypass

Contactor should pull in.

 If the motor does not fully accelerate, decelerates, or stops during the acceleration period, push the Stop button immediately and open the disconnect line.

If Pump-Flex Decel is programmed in F025:

 Remove the Run Command (or push the Stop button). At-Speed

LED will go out.

 If a Bypass Contactor is present (VMX…-BP model), the Bypass

Contactor should drop out.

 Status display should read Phase-A amps increasing as motor begins to decelerate.

 Motor should begin to slow down. Status display should begin to show decreasing motor amps.

 When motor reaches Stop Level, starter should turn off. Status display will again show [0000.]

If the unit does not follow this operational sequence please refer to the

Service and Troubleshooting Guide section.

VMX Digital Solid State Soft Starter User Manual 63 | P a g e

6.4 Testing with a smaller motor

 To test the VMX Series starter in combination with a motor that draws less than 20% of the starters Max Amp rating, the Phase

Current Loss (Running) protection must be disabled as per instructions in section 5.6.9.a. If this feature is not disabled, the

VMX Series will trip on a Phase Loss fault after running for 3 seconds at low current levels.

Chapter 7 - Fault Conditions

Additional information on Fault Codes and possible causes can be found in the Service and Troubleshooting Guide.

7.1

Fault Codes and Numbers (in History)

A three-character fault code is displayed in the LED display at the time of the trip event. The first two digits indicate the trip condition (see Table

7.1). The third digit is a suffix showing the VMX Series operating mode when the trip occurred. Operating modes are as follows:

Code suffix “A”: Acceleration, meaning that the VMX Series was ramping up but had not yet achieved “At-Speed” status (see section

4.2.9.b for a brief description of At-Speed indication).

Code suffix “c”: Constant Speed (running), meaning that the VMX

Series has reached the At-Speed condition and the motor was running when the trip occurred.

Code suffix “d”: Decel or Stop, meaning that VMX Series was either stopped (off, but power applied), or if the Pump-Flex Decel function was enabled, it was engaged in the Soft Stop routine set up by F024-27. ???

IMPORTANT NOTE:

Fault code SSd may display if there is no output load (motor) connection when control power is applied!

In addition to these fault display codes, each trip condition has a corresponding numeric code that is stored in the Fault History (see section 5.6.13.a). The numeric codes follow the display codes exactly.

Table 7.1 shows the Fault Display Codes, Fault Number Codes and

LED indicators for each fault condition. Additional details are available in the Service and Troubleshooting Guide.

Example: If Function F003 (starting overload protection) is set too low for the size of the load and causes a trip, the fault code “oLA” will be displayed. Its corresponding number will be entered into the fault history. In this case, the number 0010 will be shown on the display in function F085 (Fault History). The time the fault occurred is available in function F086 shown as “hh.mm.” Example: if the “oLA” fault occurred at

10:00 am, F086 would display

“10.00.” The date the fault occurred is available in function F087. The date is shown as

“mm.dd”. If the “oLA” fault occurred on March 1, F077 shows

“03.01.” If no fault history is available F085 reads 0000.

VMX Digital Solid State Soft Starter User Manual 64 | P a g e

Fault Condition Description

No Full Load Amps entered into F001

Over Current during Acceleration

Over Current during Constant speed

Over Current during Deceleration

Phase Loss during Acceleration

Phase Loss during Constant speed

Phase Loss during Deceleration

Line Voltage Loss (no 3 phase prior to start)

Over Temperature during Acceleration

Over Temperature during Constant speed

Over Temperature during Deceleration

Over Load during Acceleration

Over Load during Constant speed

Over Load during Deceleration

Shorted SCR during Acceleration

Shorted SCR during Constant speed

Shorted SCR during Deceleration or Stop

Shunt Trip during Acceleration

Shunt Trip during Constant speed

Shunt Trip during Deceleration

Current Imbalance during Acceleration

Current Imbalance during Constant speed

Current Imbalance during Deceleration

Under Current during Acceleration

Under Current during Constant speed

Under Current during Deceleration

Short Circuit during Acceleration

Short Circuit during Constant speed

Short Circuit during Deceleration

Ground Fault during Acceleration

Ground Fault during Constant speed

Ground Fault during Deceleration

Bypass Discrepancy during Acceleration

Bypass Discrepancy during Constant speed

Bypass Discrepancy during Deceleration

PTC Trip during Acceleration

PTC Trip during Constant speed

PTC Trip during Deceleration

Rotation Trip during Acceleration

Rotation Trip during Constant speed

Rotation Trip during Deceleration

Table 7.1: Fault code List

Fault Display

Code

Readout nFLA ocA occ ocd

PLA

PLc

PLd n3Ph oTA otc otd oLA oLc oLd

SSA

SSc

SSd st st st

IBA

IBc

IBd

UcA

Ucc

Ucd

ScA

Scc

Scd

GFA

GFc

GFd

BPA

BPc

BPd

PtA

Ptc

Ptd rtA rtc rtd

Fault Number

Code used in

History,

F085, F088 and F091

LED

Indicator

Over

Current

Phase

Loss

Over

Temp

Over Load

Shorted

SCR or no load

Shunt Trip

---

Over

Current

---

Over Load

---

VMX Digital Solid State Soft Starter User Manual 65 | P a g e

Appendix 1 - Ramp Profile Details

The VMX Series offers four different types of starting ramp profiles.

Simply select the one that best matches your motor / load requirements.

In addition, two separate ramps are available that can be selected via contact closure (see section 4.2.5.a), and each one can be set up for any ramp type as shown in the table below.

R a m p

T y p e

Voltage

Current

Voltage

Current

R a m p 1 S e t t t i n g s

I n i i t t i i a l l

T o r q u e f f r o m

…

F011

R a m p

T i m e f f r o m

…

F013

F012

F011

F012

F013

C u r r r e n t t

L i i m i i t f f r o m

…

F014

“Ramp Type

Selection” from F010

Ramp

Type

Voltage

Current

Voltage

Ramp 2 Settings

Initial Ramp

Torque from…

F015

Time from…

F017

F016

F015

F017

Current

Limit from…

F018

Table APP 1.1: Ramp Selection Choices and Settings

Initial Torque

Time

Initial Torque

Time

Ramp Time

Full Speed

Figure APP 1.1:

Voltage Ramp w/o Curre nt Limit

Ramp Time

Full Speed

Curre nt

Limit Se tting

Figure APP 1.2:

Voltage Ramp with Curre nt Limit

Following are descriptions of the four types of Ramp Profiles

1. Voltage Ramping is the most reliable starting method, due to the fact that at some point the starter will reach an output voltage high enough to allow the motor to draw full current and develop full torque. This method is useful for applications where the load conditions change frequently and significantly enough to require different levels of starting torque. Examples where this is effective are:

 Material handling conveyers

 Positive displacement pumps

 Drum mixers, grinders etc.

Voltage is increased from a starting point (Initial Torque) to full voltage over an adjustable time period (Ramp Time). To achieve Voltage

Ramping, set the Ramp Profile (F010) to 0001 or 0003 (Voltage Ramp), and the Maximum Current Limit setting (F014) to maximum (600%).

Since this is essentially Locked Rotor Current on most motors, there will be little or no Current Limit effect on the Ramp profile. Initial Torque setting comes from the Initial Voltage function F011.

2. Voltage Ramping with Current Limit works similar to mode 1, except this mode adds an adjustable maximum current output. Voltage is increased gradually until the motor current reaches the Maximum

Current Limit setting (F014) . The motor current is held at this level until the motor accelerates to full speed. When the motor current drops below the limit setting the output voltage is automatically increased to maximize torque until the VMX Series is At-Speed. This may be necessary in applications where the electrical power is limited.

Examples would be:

 Portable or emergency generator supplies

 Utility power near the end of a transmission line or other starting power demand restrictions.

Using Current Limit will override the Ramp Time setting if necessary, so use this feature when acceleration time is not critical. The Ramp Time setting however still determines the slope of the ramp up to the Current

Limit setting to apply the softest possible acceleration. To achieve

Voltage Ramping with Current Limit, set the Ramp Profile (F010) to

0001 or 0003 (Voltage Ramp), and the Maximum Current Limit setting

(F014) to a desired lower setting, as determined by your application requirements.

VMX Digital Solid State Soft Starter User Manual 66 | P a g e

Initial Torque

Time

Initial Torque

Current Limit

Time

Ramp Time

Current Limit

Figure APP 1.3:

Curre nt / Torque Ramp

Figure APP 1.4:

Curre nt Ste p Starting

Speed

3. Closed Loop Current (Torque) Ramping provides smooth linear acceleration of output torque. Ramp Time becomes the time from Initial

Torque and Current Limit settings. Output torque is constantly updated using an internal PID feedback loop to provide a linear ramp, therefore the available torque is maximized at any given speed. The best use of this feature is for applications where rapid changes in torque may result in load damage or equipment changes. Examples would be:

 Long overland conveyors where belt stretching may occur.

 Low pressure pumps where slight surges at the end-of-ramp may pose mechanical problems.

 Fans and mixers where blade warping is a problem.

 Material handling systems where stacked products may fall over or break.

This feature can be used with or without the Maximum Current Limit setting.

To achieve Torque Ramping with the VMX Series, set the Ramp Profile

(F010) to 0002 or 0004 (Current Ramp), and the Maximum Current Limit setting (F014) to the desired level. Initial Torque setting comes from the

Initial Current function F012.

4. Current Limit Only (Current Step) uses the Current Limit feature exclusively without the benefit of soft starting by ramping the voltage or current first (also known as Pedestal Starting). This will maximize the effective application of motor torque within the limits of the motor. In this mode, Initial Torque is set to maximum and Ramp Time is set to minimum, so that the output current jumps to the Current Limit setting immediately. Examples of when to use this mode are:

 Applications with a severely limited power supply

 When starting a difficult load such as a centrifuge or deep well pump

 When the motor capacity is barely adequate without stalling or overloading.

 It is a good choice when other starting modes fail.

Since ramp times are set to minimum, this mode functions in either

Voltage Ramp or Current Ramp setting.

Ramp Parameter Descriptions

Following are detailed descriptions of the individual settings that make up each ramp profile.

Initial Torque (Initial Voltage or Initial Current).

These functions set the initial start point of either the Voltage Ramp or

Current Ramp as programmed in F010. Every load requires at least some amount of torque to start from a standstill. It is not efficient to begin ramping the motor from zero every time, since between zero and the (WK

) breakaway torque level, no useful work is being performed.

The initial torque level should be set to provide just enough torque to make the motor shaft begin to rotate, enabling the softest possible start and preventing torque shock damage to the mechanical components.

Setting this function too high will not damage the starter, but may reduce or eliminate the soft start advantages.

VMX Digital Solid State Soft Starter User Manual 67 | P a g e

Accel Ramp Time. This Function sets the maximum allowable time for ramping from the Initial Torque setting to either of the following:

1) Current limit setting when the motor is still accelerating, or

2) Full output voltage if the Current Limit is set to maximum.

Increasing the Ramp Time softens the start process by lowering the slope of increase in voltage or current. This should be set to provide the softest possible start without stalling unless it is determined that the application has other considerations. Applications where this setting should be shorter include Centrifugal Pumps, because pump problems may occur as a result of insufficient torque during acceleration through the pump curve.

 Note:

Ramp Time is affected by the following conditions:

1. Current Limit will automatically override the Ramp Time if set to

Voltage Ramp (F010=1) and if the motor does not reach full speed while in current limit mode.

An “Anti-Oscillation” circuit built-in to the VMX Series will shorten the Ramp Time if the motor reaches full speed before end of ramp.

Current Limit. This Function sets the maximum motor current that the starter allows during Ramping. It is active in both the Voltage Ramp and

Current Ramp modes. As the motor begins to ramp, this feature will set a maximum at which the current draw will be held. Current Limit will remain in effect until one of the following two events occur:

1. The motor reaches full speed as detected by the At-Speed detection circuit.

2. The Overload Protection trips on Motor Thermal Overload (see

Ch.3).

Once the motor has reached full speed, the Current Limit feature becomes inactive.

 In the Voltage Ramp Profile, the Voltage output is increased until the Current Limit is reached. The Ramp Time is the maximum time it will take for the voltage to increase until the Current Limit setting takes over. Under some load conditions, Current Limit may be reached before the Ramp Time has expired.

 In the Current Ramp Profile, output voltage varies to provide a linear increase in current up to the Current Limit setting, and Ramp

Time is the time that it will take to get there. A closed loop feedback of motor current allows continuous updating of the output to maintain this ramp profile.

Because most AC induction motors will not start below 200% current, the current limit set point is adjustable down to only 200%.

Caution:

While in the Start mode there is no maximum Current Limit time.

Excessive start time may lead to motor stalling, causing an

Overload Trip. If this happens, try raising the Current Limit setting to accommodate your load conditions. If the Current Limit setting cannot be increased, try using Current Limit without ramping

features (“Current Limit Only” as described previously).

VMX Digital Solid State Soft Starter User Manual 68 | P a g e

Appendix 2: Pump-Flex



Decel Mode Application Considerations

Coast-to-Stop

(using Ele ctro-M e ch. starte r)

Pump On

Pump-Flex



Deceleration (Soft Stop) is a unique feature of Motortronics

Solid State Soft Starters. It provides a slow decrease in the output voltage, accomplishing a gentle decrease in motor torque during the stopping mode. This is the OPPOSITE OF BRAKING in that it will take

longer to come to a stop than if the starter were just tuned off.

Pump Flow

Pump Off

Check Valve

Ope n

Back Flow

Check Valve

Slams

The primary use of this function is with centrifugal pumps as a means to reduce the sudden changes in pre ssure that are associated with “Water

Hammer” and slamming of check valves. Decel control in pump applications is often referred to as Pump Control.

In a pump system, liquid is being pushed uphill. The force exerted by gravity on the column of liquid as it goes up hill is called the “Head

Pressure” in the system. The pump is sized to provide enough Output

Pressure to overcome the Head Pressure and move the fluid up the pipe. When the pump is turned off, the Output Pressure rapidly drops to zero and the Head Pressure takes over to send the fluid back down the hill. A “Check Valve” is used somewhere in the system to prevent this (if necessary) by only allowing the liquid to flow in one direction.

Pump Off

Check Valve

Close d

Pump-Flex



Soft Stop

(using VMX Series starte r)

Pump

Soft Stop

Pump Off

((( SHOCK WAVE )))

Neutralized Flow

Check Valve

Close s Slowly

NO SHOCK WAVE

Check Valve

Close d

Kinetic energy in that moving fluid is suddenly trapped when the valve slams closed. Since fluids can‟t compress, that energy is transformed into a “Shock Wave” that travels through the piping system looking for an outlet in which to dissipate. The sound of that shock wave is referred to as “Water Hammer”. The energy in that shock wave can be extremely damaging to pipes, fittings, flanges, seals and mounting systems.

SOLUTION:

By using the Pump-Flex



Decel feature of the VMX Series, the pump output torque is gradually and gently reduced, which slowly reduces the pressure in the pipe. When the Pump Output Pressure is just slightly lower than the System Head Pressure, the flow slowly reverses and closes the Check Valve. By this time there is very little energy left in the moving fluid and the Shock Wave is avoided. When the output voltage to the motor is low enough to no longer be needed, the VMX Series will end the Pump-Flex



Decel cycle and turn itself off.

Caution!

Decel is THE OPPOSITE of braking. Enabling the Decel feature will make the motor take LONGER to stop than if it were simply turned off.

VMX Digital Solid State Soft Starter User Manual 69 | P a g e

Setup and Use

Pump systems vary greatly. To accommodate this, the Pump-Flex



Decel control feature is designed to provide complete flexibility in how the deceleration process takes place by using the following settings.

Decel begins when a Stop command is given (or the Run command is removed). If there is a Bypass Contactor, it will open immediately, putting the power control back to the SCRs.

Stop Command

(Bypass Contactor Opens)

Full Spe e d

F025: Begin Decel Level

(Immediate step down)

Check Valve

Closes

F026: Decel Shut Off

(VMX Output Off)

F027: Decel Ramp Time

Time

Figure APP2.2: Pump-Flex Decel Graph

= Motor Torque

= Pump Output

F024 = Deceleration Ramp

Factory Setting = 0 (Disabled)

Range = 0

– 2

When F024 = 0, the deceleration feature is disabled.

When F024 = 1, the deceleration feature is enabled AND the overload protection feature (from F003 - F005) remains active. When a

Stop command is given, the starter begins to apply Decel voltage. However, if an overload trip occurs, the starter ceases applying Decel voltage and the motor coasts to a stop to prevent additional motor heating and potential motor damage.

When F024 = 2, the deceleration feature is enabled and deceleration will continue even when an overload condition trips. This is to be used only when the risk of damage due to an uncontrolled shutdown is considered worse than the potential damage to the motor.

WARNING!

Setting F025 = 2 presents significant risk of over-heating the motor beyond its design limits which could result in motor damage and fire hazard. Do this only in circumstances where the potential for mechanical damage

outweighs the risk of motor damage and fire.

 Note:

The PTC Input will act as an Overload trip (disable), however it

ALWAYS shuts the starter down WITHOUT Decel (as in setting

F025=1 above) even if F025 is set to 2.

VMX Digital Solid State Soft Starter User Manual 70 | P a g e

F025 = Begin Decel Level (BDL)

Factory Setting = 60%

Range = 0 - 100% of line voltage

Used to drop voltage to a level where there is a noticeable effect on motor torque during Decel mode. Generally, systems with high head pressure need to start Decel near the top of the ramp (85-95%). Low head systems can drop to lower settings

(50-60%). System conditions vary greatly by pump type, pipe size and system head. Some experimentation with settings may be necessary.

F026 = Decel Shut Off Voltage

Factory Setting = 30%

Range = 0 to (BDL -1)%

Sets the level where the starter is turned off, corresponding to where motor torque during Decel is no longer effective. Always set this function lower than the setting of F026, Begin Decel

Level (this function is restricted from being less than F026 minus 1%). This function is used to shut the motor off once the check valve closes. Again, because systems vary greatly this setting may require adjustment several times. If you cannot hear or see the check valve close, observe fluid pressure or flow if available.

F027 = Decel Ramp Time

Factory Setting = 10 seconds

Range = 1 - 60 seconds

Sets the maximum time for the deceleration ramp to go from the

Begin Decel Level setting (F026) to the Decel Shut Off Voltage

(F027). This function is used to dampen the effect of reducing pump torque as much as possible. If the check valve still slams at the end of ramp, try extending this time function a little. Since motor heating increases as voltage is lowered, the setting should not exceed the time necessary to achieve the deceleration effect.

 Note:

When using the Decel function, count these cycles as additional

“starts” when determining maximum starts-per-hour.

Other Applications:

Another common application for Decel control is on material handling conveyors as a means to prevent sudden stops that may cause products to shift, fall over or to bump into one another.

In overhead crane applications, Soft Stopping of the Bridge or Trolley can prevent loads from beginning to over swing on sudden stops.

VMX Digital Solid State Soft Starter User Manual 71 | P a g e

Appendix 3: Parameter Lock / User Password Instructions

Provides users with the ability to prevent unauthorized operators from making changes to the programmed functions. If you do not need to

take advantage of this feature, do not enter anything into this

function. The factory default is disabled, and no Password is necessary to make changes to the program.

When any value other than 0000 is entered into this Function, the

Parameter Lock is enabled and that number becomes the User

Password. From that point forward, it will be necessary to enter the User

Password in this Function prior to making changes in any programmed function, including this one. When the Parameter Lock has been enabled, attempts to alter the program will result in the display reading

[Err ] whenever the [READ/ENTER] key is pressed.

To alter the program after the Parameter Lock has been enabled, go to

Function F070 and enter the correct user Password. The display will read an encoded value representing the existing password. As soon as you press the first Arrow key, the display will change to [0000] and start showing the actual value of your password entry. When the [READ/

ENTER] button is pressed, the display will read [PASS], indicating that the User Password is correct and the system is unlocked. You will have

5 minutes in which to make a change in the program. This 5-minute window resets whenever any key is pressed, so it floats to give you 5 minutes after the last entry. After 5 minutes of no keypad activity, the

Parameter Lock is reinstated with the current user Password.

Subsequent changes will require re-entering the User Password.

To change the User Password or to disable the Parameter Lock function, enter the programmed User Password first, and then set

Function F070 to 0, disabling the Parameter Lock. If you do not re-enter the Password or enter a new user password, the Parameter Lock feature will remain disabled. If you enter a different number into this

Function, the new number becomes your new User Password. Existing passwords are encoded to “hide” them in the display.

Caution:

DO NOT LOSE YOUR PASSWORD.

If the password has been lost or forgotten, contact Motortronics for assistance.

VMX Digital Solid State Soft Starter User Manual 72 | P a g e

Example: Figure App 3

Enabling Password Protection / Parameter Lock

Starting from the Status Display Mode, no previous function number entered, no existing password...

Press the Fn key.

Displays F001 to indicate the beginning of the function list.

Press the LEFT arrow key

Selects the second digit (from the right). Note: do it in this order because F000 would not have been a valid number

Press the UP arrow key seven times (7X)

Changes the function code to F071.

Press the RIGHT arrow key

Selects the first digit (from the right).

Press the DOWN arrow key

Changes the function code to F070.

Press the Read Enter key

The default display will show [3552] as long as no password has been previously entered. This is the default code for

“0000”, meaning that there is no password. As soon as you

press the first Arrow key, the display will change to [0000] and begin showing the actual value of your password entry.

Any initial display other than [3552] signifies that a password already exists. This means that you will need to change, rather than enter a new one (see below).

Use the UP arrow and the LEFT arrow keys…

to display the password you desire (Valid range is 0000 to

0999). In this example, 0123 has been selected.

Press the Read Enter key

Press

Key...

READ

ENTER

READ

ENTER

Example: Setting a Password x 3 x 2

Using Password 123

Display

Shows...

0000.

F070

3552

0003

0023

0123

End

M eans...

Phase A

Current

Select

Function #70

Default Setting of Function #70

New Value of

First Digit

Cursor (flashing)

Position Shift

New Value of

Second Digit

Cursor (flashing)

Position Shift

New Value of

Second Digit

Value Accepted

(flashes once)

The display will flash [End] to confirm you have entered a password. Then it will return to displaying thee Function #.

Changing passwords:

F070

Return to

Function # Display

Figure App 3:

Entering a Passw ord

To change an existing password, the steps are essentially the same as outlined above, except you must first enter the existing password. At

F070, press the [READ/ENTER] key to reveal the encoded password

(you must know that password before it can be changed). Use the

Arrow keys to enter the password. As soon as you press the first Arrow key, the display will change to [0000] and start showing the actual value of your entry. When you get to the existing password, press the

[READ/ENTER] key again. The display will flash [PASS] to indicate that the password was accepted. If it flashes [ Err ], you have entered the wrong password.

Resetting to Factory Defaults using F071 will NOT reset the password.

Disabling Password Protection / Parameter Lockout

Changing function F070 to [0000] will disable the user password. If the initial display reads [3552], the password is already set to [0000].

VMX Digital Solid State Soft Starter User Manual 73 | P a g e

Ramp 0mofile

Appendix 4: Process Control Timer Functions

F030 through F039; Overview of Process Timer Control and Time Clock Controller Features:

The following special functions allow your VMX Series starter to operate automatically from an internal Process

Control Timer and Time Clock Controller (TCC) using a real time clock. The Process Control Timer (F030 and

F031) can be used independently or together with the TCC feature (F032-39). The TCC requires using the

Process Control Timer to provide for Start commands (depending on the selected mode). Time progression and clock values can be read in the Status Screen (see section 5.3.1).

A convenient chart at the end of this appendix shows all settings and interactions.

F030 = Process Control Timer Selection

Factory Setting = 0 (Disabled)

Range = 0, 1, 2

This function enables a Process Control Timer, which offers two operating modes (Minimum Batch Run Timer and

Permissive Run Timer), selected by entering 1 or 2 here.

F030 = 1: Minimum Batch Run Timer

In this mode, the Process Control Timer ensures that the motor will run for a minimum amount of time, regardless of whether someone stops it intentionally, or power fails and returns. When selected, the Minimum Run Timer begins counting down after a Start command. The Time Value is set in

F031. When the time value reaches [0000] the starter will turn off, even if the Start command is still closed and there is no

Stop command.

To Reset the timer in this mode, initiate a Stop command after the timer has expired. If using the TCC (F032), reset is automatic when completed and no there is no other Run command is present.

If a Stop Command, power failure or Fault trip occurs during timed operation, the Process Control Timer is suspended and maintains its value. When the starter is then restarted, the timer resumes counting down to ensure that the motor has run for the programmed amount of time (finishes the batch).

Use this function to ensure that a load operates for a minimum amount of time regardless of other circumstances. Examples would be:

 Irrigation pumps where a specific amount of pumping time is required even if the pump is shut down on a low level alarm and then resets, or power fails and returns.

 Mixers that need to agitate for a specific amount of time yet may be shut down when power fails or as product is added.

 Aeration Blowers that must be run for minimum amounts of time to ensure that proper aeration (contact time) has been provided to a tank.

 Note:

In 2-wire control systems where the Run command is maintained, the starter will automatically restart after a power failure or a Fault is reset.

Use appropriate warnings as mentioned in section 3.1.3.b (see the following F032 description for an exception to this).

In 3-wire control systems, a new Start command will be required to restart the starter.

VMX Digital Solid State Soft Starter User Manual 74 | P a g e

Example: Figure App 4.1

Minimum Run (Batch) Timer

An irrigation pump needs to come on when called for by a soil moisture control system, and run for ½ hour. If during that ½ hour the well level drops and shuts the pump down, the pump needs to restart when the well recovers and finish the ½ hour pump time.

Set F030 to [0001] for Minimum Run Timer.

This will ensure that when the well level recovers and resets the run command, the starter will finish the time sequence.

Set F031 to [0030] (minutes)

This is the Run Time that ensures the proper amount of irrigation getting to the crop.

(Not Shown)

Ensure F032 is set to [0000] for One Shot

This will allow the Start command provided by the external control system to engage the starter at any time it is required.

(Another example of this function used with the Time Clock

Controller is provided further on)

Example: Process Timer for Well Pump

Pre ss

Ke y...

READ

ENTER

READ

ENTER

READ

ENTER

READ

ENTER x 3

Display

Shows...

F030

0000

0001

End

F031

0000

0030

End

F031

M e ans...

Starting at

Function #30

De fault Se tting of Function #30

Se t F030 = 1

M inimum Run Time r

Value Acce pte d

(flashe s once )

Change to

F031

De fault Se tting of Function #31

Change Se tting to 30 minute s

Value Acce pte d

(flashe s once )

Re turn to

Function # Display

Cycle Control Powe r to Acce pt Change s

Figure App 4.1:

Program m ing the Minim um Run Tim er Functions

 Notes on interactions with other functions:

When used with F028 (Auto-Restart Delay), the Minimum Batch

Timer will not resume counting down until F028 has expired and the starter has restarted. When used with 3 wire control, it may be necessary to maintain a Start Command until after F028 has expired, or repeat if momentary.

When used with F049

– F050 (Lockout Protection features), the

Minimum Batch Timer will not resume counting down until those settings have been satisfied and the VMX Series starter has restarted. When used with 3-wire control, it may be necessary to maintain a Start Command until after they are satisfied, or repeat if momentary.

When used with the Pump Flex Decel feature, the Decel Time

(F027) is counted as part of the Batch Run time for this feature.

VMX Digital Solid State Soft Starter User Manual 75 | P a g e

F030 = 2: Permissive Run Timer.

In this mode, the Process Control Timer engages differently according to the settings of the Time Clock Controller (TCC).

When the TCC is set to 0

(using “One Shot” operation), the

Process Control Timer begins counting down after the first Start command. Subsequent stop and start commands have no further affect on the timer status and can be used to fully control the starter. When the timer finishes (F031 = [0000]), the starter will shut off. Upon the next Start command, the timer will reset and begin counting down again. In 2 wire control systems, the starter will shut off even if the Run command is still closed, and will only reset after the Run command has been cycled (opened and reclosed).

Use this function in without the Time Clock Controller (One-Shot mode) to ensure that a load only operates for a maximum of the programmed amount of time, beginning with the first Start command. Examples would be:

 Pumps where the failure of a stop float may lead to dry run conditions if allowed to operate too long, or when the pump only needs to run when someone is present, but operate automatically via float switched (pump-out for service).

 Ventilation Blowers where operation is controlled by a manual switch but may be inadvertently left on when someone leaves.

When the TCC is set for 1 through 8 (using Start Event Cycles), the timer begins counting down immediately when a Start

Event is activated. Any Start / Stop Command that is given to the starter during this time will work normally. When the timer finishes (F031 = [0000]), the starter will shut off, and Start /

Stop commands will no longer function until the next Start

Event Cycle (SEC). In 2 wire control systems, If a Run command is already present when the SEC occurs, it will make no difference and the starter will start.

Reset of the Permissive Run Timer will occur only when the next Start Event Cycle is activated by the Time Clock Controller, or when changes are made to programming (see note on programming changes (see “Important Note” on page 80). Loss of control power without program changes will NOT reset the time.

Use this function in conjunction with the Time Clock Controller to ensure that a load only operates during the programmed amount of time, beginning with the Start Event Cycle. Examples would be:

 Air compressors where leaking of air lines during normal downtime causes the compressor to run unnecessarily

 Irrigation pumps where operation during parts of the day is undesirable.

 Energy Savings to prevent operation when Time-of-Use (TOU) metering discounts are provided to promote conservation.

VMX Digital Solid State Soft Starter User Manual 76 | P a g e

Example: Figure App 4.2

Permissive Run Timer

An air compressor controlled by a pressure switch feeds a large air distribution system that has small normally insignificant leaks.

If left on over night when the system is not in use, leaks drop the air pressure and the compressor cycles on and off even though the facility is unoccupied, wasting energy.

Set F030 to [0002] for Permissive Run Timer.

This will ensure that if not purposely turned off, the compressor will not run when the facility is shut down.

Example: Process Timer for Compressor

Press

Key...

READ

ENTER

Display

Shows...

F030

0000

M eans...

Starting at

Function #30

Default Setting of Function #30 x 2

0002

Set F030 = 2

Permissive

Run Timer

Set F031 to [0600] minutes (10 hours)

This is the longest Run Time after which the starter will automatically shut down. This ensures that it will not restart after the time expires and until a new Start Event occurs.

(Not Shown)

Ensure F032 is set to [0001] for Every Day, and F033 is set to

correspond to work start time (or 5 minutes prior)

This will allow the Run command provided by the pressure switch to engage the starter any time it is required after the shift begins.

With this setting, the compressor will start whenever the pressure switch calls for it after the Start Event set by the Time Clock

Controller, but if forgotten, it will shut itself off after 10 hours. If power is turned off or lost during those 10 hours, the timer is not cleared or reset, so even if it is turn back on 1 minute before the timer expires, it still shuts off at the end of that 10 hour period.

READ

ENTER

READ

ENTER x 2

READ

ENTER x 6

End

F031

0000

0600

End

F031

Value Accepted

(flashes once)

Change to

F031

Default Setting of Function #31

Change Setting to 600 minutes

Value Accepted

(flashes once)

Return to

Function # Display

Cycle Control Power to Accept Changes

Figure App 4.2:

Program m ing Perm issive Run Tim er Functions

Notes:

If the

Process Control Timer

(F030) is set for Minimum Batch Timer (value of 1), and the next

Start Event Cycle passes without a Start command, the previous event will be ignored in favor of the new one.

If a

Process Control Timer

setting from F031 is so long that it overlaps a Start Event Cycle setting in F032-F039, the original timer value becomes invalid. The new Start Event Cycle reloads the value of F031 and begins counting down again from the beginning.

F031 = Process Timer Value

Factory Setting = 1

Range = 1

– 9999 minutes

This function loads a value into the Process Control Timer above. When initialized, the value counts down towards 0.

F030 sets the operating mode and reset functions for this timer.

The value of this timer can be read directly in the main Status

Screen (see section 5.3.1). When the Process Control Timer has been enabled in F030, the Status Screen display for the value will flash once per second while timing. When completed, it will stop flashing and read [0000].

VMX Digital Solid State Soft Starter User Manual 77 | P a g e



IMPORTANT NOTE: When F030 or F031 is changed in program mode, the timer

will not respond to the new settings until after control power has been cycled (off

and back on again).

F032 = Time Clock Controller (TCC)

Factory Setting = 0 (One Shot)

Range = 1 - 8 settings

This function is used to select the operating mode of the 24hr /

7 Day Time Clock Controller (TCC).

F032 = 0 operates the SEC in a “One-Shot” mode (factory default setting). When set to 0, the Process Timer (F030) responds only to each NEW hard-wired START input command.

Use this setting to allow the Process Control Timer to operate without the TCC.

For safety purposes when using 2 wire control systems in this mode only, if power fails and the START/RUN command is present when power is restored, the starter will ignore this command until the input is cycled Off and back On (terminals

TB1-1 and 3 are opened and reclosed).

For automatic operations, F032 can also set the number of days in which the TCC will repeat a Start Event Cycle (SEC).

Each Start Event Cycle consists of from 1 to 7 Start Events as programmed in F033 through F039 below. Start Events can be non-sequential (see Note below).

F032 = 1 operates the SEC every day of the week.

F032 = 2 operates the SEC every 2 days (every other day)

F032 = 3 operates the SEC every 3 rd

day.

F032 = 4 operates the SEC every 4 th

F032 = 5 operates the SEC every 5 th

day.

F032 = 6 operates the SEC every 6 th

day.

day

F032 = 7 operates the SEC 1 day per week.

F032 = 8 operates the SEC for a single 24HR event, nonrepeating. Use this for testing or for “walk away” operations that need to run after you leave but not again.

Start Event Cycles allow the use of a Start Command (2-wire or

3-wire) ONLY AFTER the time of the Start Event has passed

(logic state AND). In a 3-wire control system, this is similar to having an Enable switch in series with the Stop button. In a 2wire control system, this is similar to having and Enable contacts in series with the Run contact. The Stop Button (or opening the Run contact) will always work to shut down the

VMX Series starter. If F032 is set to anything other that 0, the normal Start

– Stop functions will not longer work except as shown above.

Each Start Event is a timed operation based on the Process

Timer settings in F030 above.

Important:

If F030 = 0 (Disabled), the TCC will be ignored. So if F032 = 1-8 and F030 = 0, the starter will not operate!

Make sure that if F030 = 0, F032 = 0 as well.

VMX Digital Solid State Soft Starter User Manual 78 | P a g e

F033 = Event #1 Start Time

Factory Setting = OFF

Range = 00:00 through 23:59, or OFF

This function is used to select the start time for Event #1 in the

TCC above. Once given a Start command after this event time, the starter will run the motor according to the selections entered into F030 and for the time entered into F031.

F034 = Event #2 Start Time Same as above, except for event #2

F035 = Event #3 Start Time Same as above, except for event #3

F036 = Event #4 Start Time Same as above, except for event #4

F037 = Event #5 Start Time Same as above, except for event #5

F038 = Event #6 Start Time Same as above, except for event #6

F039 = Event #7 Start Time Same as above, except for event #7

 Note:

Start Events are completely independent of one another, and can be programmed in any order. For instance, the Start Time in F037 can be earlier than the Start Time in F033. This allows easier alterations or additions of new Start Times after a unit is already installed.

VMX Digital Solid State Soft Starter User Manual 79 | P a g e

Fn#

Function

Type

Setting

Function Description / Range

Timer

Initiated

By…

Motor

Starts

When…

No Process Control Timer operation (default setting from factory)

Motor

Stops

When…

Timer

Reset

When…

F030

Process

Control

Timer

Mode

Minimum (Batch) Run Timer

(works the same with or without TCC control)

Permissive Run Timer, without TCC

(F032 =0, “One Shot”)

Permissive Run Timer, with TCC

(F032 = 2 thru 8)

Start command and/or

TCC

Start command

TCC Start

Event only

Start command

Time

Expires,

Trip, or

Stop

Command

Time

Expires +

Stop command only

Time

Expires

Next SEC only

F031

Process

Timer

Value

Run

Time

Value

Timer value setting used by F030

Range: 1

– 9999 minutes (166.65 hours)

--- ---

Per F030 setting

0 One-Shot, follows Start command only

Start command

Per F030 setting

1 Loop the Start Even Cycle (SEC) daily

F032

24 hr /

7 day

Time Clock

Controller

Loop the 24hr SEC every other day

Loop the 24hr SEC every 3 rd

day

Loop the 24hr SEC every 4 th

day

Loop the 24hr SEC every 5 th

day

Loop the 24hr SEC every 6 th

day

24hr Real

Time

Clock on day of program change

Continuous unless program is changed

F033 Event #1

F034 Event #2

F035 Event #3

F036 Event #4

F037 Event #5

F038 Event #6

F039 Event #7

Chart APP 4.1

Loop the 24hr SEC one day per week

Single 24hr SEC, without repeating

(until programmed again)

Start time

24hr TCC Start Time for Event #1

24hr TCC Start Time for Event #2

24hr TCC Start Time for Event #3

24hr TCC Start Time for Event #4

24hr TCC Start Time for Event #5

24hr TCC Start Time for Event #6

24hr TCC Start Time for Event #7

Process Timer and TCC Operations Logic Chart

F032 =1-8

Per F030 setting

Change of

Program

Continuous unless program is changed



Note:

These functions may interact with the Coast Down Lockout (F048),

Stars-per-Hour Lockout (F049), Minimum Time Between Starts

(F050), Auto-Reset (F052) and Restart Delay Time (F028) functions if enabled. Be sure to read and understand descriptions of those functions, then check settings before using the Process Control

Timer.

VMX Digital Solid State Soft Starter User Manual 80 | P a g e

Example: Figure App 4.3

Time Clock Controller with Minimum Run Timer

An irrigation pump fed from a well with a single float level control needs to come on every other day at 5:30 PM, and run for ½ hour.

If during that ½ hour the well level drops and shuts the pump down, the pump needs to restart when the well recovers and finish the ½ hour pump time.

Set F030 to [0001] for Minimum Run Timer.

This will ensure that when the well level recovers and resets the run command, the starter will finish the time sequence.

Set F031 to [0030] (minutes)

This is the Batch Time that ensures the proper amount of irrigation getting to the crop.

Set F032 to [0002] for Every 2 nd

Day

This will begin the Start Even Cycle on the day of programming and every other day from then on.

Set F033 to [17.30]

This is the 24HR time value representing 5:30 PM. At this time, every other day, the VMX Series starter will automatically start

(provided the Stop float in the well is closed) and run for 30 minutes as programmed in F030.

If the pump needs to come on again at 7:00 PM, program F034 to

[19.00]. If later on it is needed to come on at 6:00 AM as well, simply change any other unused start time, i.e. F038 to [06.00].

Even though this is Event #6 and the lower numbered events had later start times in the program, the starter will execute #6 on time in the next available cycle.

If the pump needs to come on every day, program F032 to [0001].

Example: Process Timer and TCC for Irrigation Pump

Pre ss

Ke y...

READ

ENTER

READ

ENTER

READ

ENTER

READ

ENTER

READ

ENTER

READ

ENTER

READ

ENTER x 3 x 2

Display

Shows...

F030

0000

0001

End

F031

0000

0030

End

F032

0000

0002

End

F033

17..30

End

F033

M e ans...

Starting at

Function #30

De fault Se tting of Function #30

Se t F030 = 1

M in. Batch Time r

Value Acce pte d

(flashe s once )

Change to

F031

De fault Se tting of Function #31

Change Se tting to 30 minute s

Value Acce pte d

(flashe s once )

Change to

F032

De fault Se tting of Function #32

Se t to 2:

Ev e ry 2nd Day

Value Acce pte d

(flashe s once )

Change to

F033

Se t to 17.30

(5:30 PM military)

Value Acce pte d

(flashe s once )

Re turn to

Function # Display

Cycle Control Powe r to Acce pt Change s

Figure App 4.3: Program m ing Tim er Functions

 Note:

If programming is entered AFTER the set time value, the TCC will wait until the next valid time before executing (i.e. if you entered the above example program changes at 5:35 PM, the pump would not come on automatically until 5:30 PM 2 days from now).

VMX Digital Solid State Soft Starter User Manual 81 | P a g e

Appendix 5 – External Over Load Relay Applications

Your VMX Series starter comes equipped with a very intelligent internal electronic overload protection system, and does not need an external

Over Load Relay (OLR). There are instances however where external

OLRs are needed or desired because of the application. These fall into three categories; Higher Level Protection systems, Redundant Backup applications and Special Motor applications.

 Note:

If the Decel Function is activated (F024), additional consideration must be put into determining how the starter is to operate in the event of an Over Load Trip. See Section 5.6.5 for issues regarding this application.

HIGHER LEVEL PROTECTION SYSTEMS

Because of a desire for uniformity and/or operator familiarity in some facilities, Motor Protection Relays or other coordinated OEM protection systems may be used in lieu of the VMX Series protection (even though most of the features are the same or better). In these instances the

VMX Series Over Load protection can simply be turned off, deferring protection to the external devices. Care should be taken however to ensure that the external device is properly wired into the starter control circuit to facilitate shutdown of the motor. The VMX Series provides a

PTC input that can be wired to the NC aux contact of the external device so that a fault will still shut down the VMX Series and be annunciated on the display. See section 4.7.2.a for more details on using the PTC input.

REDUNDANT BYPASS STARTER APPLICATIONS:

In some applications, it may be necessary to provide an independent means of starting and protecting the motor should be VMX Series starter become inoperable. If this were the case, the Bypass Contactor could be used for Across-the-Line (D.O.L) starting of the motor. The

VMX…BP version with Integral Bypass Contactors is designed for that possibility, as long as the starter is properly selected when ordered. To do so, select the starter based upon the ATL (Across-the-Line) selection chart so that the contactor is rated for ATL duty instead of the normal

Shunt Duty (see section 1.2.3 for Selection charts).

Under normal operations, the Bypass Contactor is controlled internally by the VMX Series PC board and an internal pilot relay. For redundant backup purposes however, terminals B1 and B2 of TB4 are provided for field connection of a dry contact closure in parallel to the pilot relay contact, allowing control even if the electronics are out of service. AC control power must still be applied to TB2 terminals A1 and A2, but no other electronics or power supplies need to be functioning. It is in this instance that an external OLR must be added to the motor power circuit and wired into that coil control circuit. TB4 is located in different areas of each frame size in the VMX Series. Refer to the following diagram for the location on your unit.

VMX Digital Solid State Soft Starter User Manual 82 | P a g e

VMX Bypass Control Terminal Location Diagrams

Bypass Control

Terminals

18 - 48A Units

Note:

Use these terminals only when separate control of the Bypass Contactor is necessary

Bypass Control

Terminals

62 - 160A Units

Bypass Control

Terminals:

210

– 550A with or without integral bypass

VMX Digital Solid State Soft Starter User Manual 83 | P a g e

Appendix 5 (cont.) External OL Relay Applications

Across-the-Line (Direct-on-Line) Bypass

A suggested control schematic is shown below for using the

VMX …-BP

Series rated for Across-the-Line Bypass with an External Overload:

AC CONTROL POWER

Start / Run

Command

Disconnect or

Circuit

Breaker

(2-wire or 3-wire )

R /

S /

T /

VMX Starter

Solid State

Over Load .

Off

S S A-T-L

97 98

Exte rnal

U /

V /

W /

Bypass

Contactor

"BP"

External

Over Load

1 2

VMX-TB-1

(24VDC)

VMX-

TB-4

B1 B2 A1 A2

VMX-

TB-2

Control Pow er

Potential

Inte rnal Bypass

Pilot Re lay

Bypass

Contactor

Coil

VMX...-BP Series

Internal Wiring

MTR

Figure APP5.2: VMX Wiring for Across-the-Line Bypass Operation with External Overload Relay

(Only the terminals necessary for this operation are shown)

In this example:

The Start / Run command (2-wire or 3-wire) energizes a control Relay

“CR”. If the selector Switch is in the “SS” (Soft Start) position, the contact of CR closes the 24VDC control signal to TB1, terminals 1 and 3 of the VMX Series, which begins ramping. When At-Speed status is reached, an internal Bypass Pilot Relay is used to close the Bypass

Contactor. While in this mode, the VMX Series CPU provides full motor protection, even when the Bypass Contactor closes.

When the Selector Switch is placed in the “A-T-L” (Across-the-Line) position, a 2 nd

isolated contact of CR is used to close the circuit between

B1 and B2 of TB4 which are internally connected in parallel to the

Bypass Pilot Relay contact in the Bypass Contactor coil circuit. Since the VMX Series electronics may be out of service, an External Overload is added which only operates in this mode and protects the motor by dropping out the connection between B1 and B2.

Caution:

The circuit on TB-4 is at the same potential as the AC control voltage, but should not be

directly connected to it. PC board damage may result.

VMX Digital Solid State Soft Starter User Manual 84 | P a g e

Appendix 5 (cont.) External OL Relay Applications

SPECIAL MOTOR APPLICATIONS

Multiple Motors

When more than one motor is connected downstream from the VMX

Series starter, the internal electronic overload protection cannot provide proper protection of the individual motors. Codes require the use of separate OLRs for each motor, which would need to be external devices.

In these instances the VMX Series Over Load protection should be turned off, deferring protection to the separate OLRs. Care should be taken to ensure that the External OLR is properly wired into the starter control circuit to facilitate shutdown of the motor. The VMX Series provides a PTC input that can be wired to the NC auxiliary contact of the external OLR so that a trip will still shut down the VMX Series and be annunciated on the display. Multiple OLRs would then be wired in series for the same effect. See section 4.7.2.a for details on using the PTC input.

120VAC CONTROL POWER

A1 A2

VMX-TB-2

Disconnect or

Circuit

Breaker

External

OL 1

External

OL 2

Start / Run

Command

R /

S /

T /

VMX Starter

Solid State

Over Load

1 2

VMX-TB-1

(24VDC)

3 9 10

VMX-TB-1

(PTC Input)

VMX...-BP Series

Control Wiring

Bypass

Contactor

"BP"

U /

V /

W /

External

Over Load 1

External

Over Load 2

MTR

VMX Digital Solid State Soft Starter User Manual 85 | P a g e

Appendix 5 (cont.) External OL Relay Applications

SPECIAL MOTOR APPLICATIONS

2S2W Motors

2 speed / 2 winding motor applications require a separate OLR sized for each set of windings. These would need to be external OLRs.

Disconnect or

Circuit

Breaker

120VAC CONTROL POWER

A1 A2

VMX-TB-2

2S2W Starter

(Logic not shown for clarity)

R /

S /

T /

VMX Starter

Solid State

Over Load

U /

V /

W /

Bypass

Contactor

"BP"

MS MF

Slow

Fast

1 2

VMX-TB1

(24VDC)

6 7

VMX-TB1

(Ramp 2)

VMX-TB1

(PTC Input)

VMX...-BP Series

Control Wiring

External 2-Speed 2-Winding (2S2W) Starter

Slow

Over Load

Fast

Over Load

2S2W

MTR

In this example:

The VMX Series is used ahead of an existing 2S2W starter, which already has separate OLRs for each speed. Dry Aux. contacts of the

2S2W starter are used to provide a Run command to the VMX Series so that all existing controls can be used. In addition, another dry Aux. of the Fast contactor is used to select Ramp 2. When started in Slow,

Ramp 1 (default) is used. If started in Fast, different ramp settings are necessary so Ramp 2 is used. (See section 4.2.5.a for Dual Ramp info.)

Either OLR will trip the VMX Series, which will display [ Ptc] and light the “Overload” LED.

VMX Digital Solid State Soft Starter User Manual 86 | P a g e

F010

F011

F012

F013

F014

F015

F016

F017

F018

F019

F020

F021

Appendix 6 - Soft Starter Settings Record

The following chart may be used to record the changes made to the factory settings.

Fn # Group Function Description Adjustment / Display Range

Setting

Increments

Factory

Setting

Setting Setting

F001

Motor Nameplate FLA

FLA must be programmed for starter to function.

50-100% of Max Amp Rating.

Upper limit of range automatically adjusts downward as Service factor is increased.

1 amp 0

F002

Motor Nameplate

Service Factor

1.00 - 1.30 SF 0.05 1.0 SF

F003 Overload Class During Start NEMA / UL Class 5 - 20 5 Class 10

F004

F005

Overload Class During Run

Overload Reset

NEMA / UL Class 5 - 30

0 = Manual

1 = Auto

2 = Disabled Overload

Class 10

(Manual)

F006-9

Reserved for factory use

F022

F023

Ramp Type Selection

VR = Voltage Ramp

CR = Current PID Ramp

1 = Ramp 1, 2 = Ramp 2

Setting 1 = VR1 + VR2

Setting 2 = CR1 + CR2

Setting 3 = VR1 + CR2

Setting 4 = CR1 + VR2

Initial Torque (VR) of Ramp 1 0-100% Line Voltage

Initial Torque (CR) of Ramp 1 0-600% Motor Current

Accel Ramp Time of Ramp 1

Max Current Limit of Ramp 2

1-120 seconds

200 - 600% Motor Current Max Current Limit of Ramp 1

Initial Torque (VR) of Ramp 2 0-100% Line Voltage

Initial Torque (CR) of Ramp 2 0-600% Motor Current

Accel Ramp Time of Ramp 2 1-120 seconds

200 - 600% Motor Current

Voltage Jog

Time of Voltage Jog

Current Jog

– 100% Line Voltage

– 20 Seconds

100

– 500% Motor

Current

Kick Start Voltage

Kick Start Time

0 = Disabled, or

10 - 100% Line Voltage

0.1 - 2 Seconds

VR1+VR2

1 second

60%

200%

10 seconds

350%

60%

200%

10 seconds

350%

1 second

0.1second

50%

10 seconds

150%

Disabled

0.8 sec

VMX Digital Solid State Soft Starter User Manual 87 | P a g e

F033

F034

F035

F036

F037

F038

F039

Appendix 6 (cont.) Soft Starter Settings Record

Fn # Group

F024

F025

Function Description Adjustment / Display Range

Pump Flex Control /

Deceleration Ramp

0 = Disabled (coast to stop)

1 = Enabled, except after OL trip

2 = Enabled, continued Decel even if there is an OL trip

Begin Decel Level (BDL),

Immediate Drop Down Torque

0 - 100 % of Output Voltage

Setting

Increments

Factory

Setting

Disabled

Setting Setting

1% 60%

F026 Decel Shut Off Voltage 0 to (BDL minus 1)% Voltage 1% 30%

F027 Decel Ramp Time 1

– 60 Seconds

1 second

10 seconds

F028

F029

Restart Delay Time

(Sequential Start Delay)

Reserved for Factory Use

0 = Disabled, or

1-999 seconds after a Power Loss

(Status can be read in F054)

1 second

Disabled

F030

F031

Process Control Timer

Selection

Run Timer Time for use in F030 above

0 = Disabled (No timer operation)

1 = Minimum Batch Run Timer

2 = Permissive Run Timer

1-9999 minutes after a Start

Command or Start Event from TCC

Disabled

F032

24hr

Time Clock Controller (TCC)

Start Event Mode.

Chose from “One Shot” or 1 to 7 “Start Events” in F033

– F039

Run time for this mode comes from F030 above.

Start Event Cycle (SEC) Settings

0 = One Shot: Start Event comes from Start command only

1 = Loop SEC every day

2 = Loop SEC every 2 nd

day

3 = Loop SEC every 3 rd

4 = Loop SEC. every 4 th

day

5 = Loop SEC. every 5 th

6 = Loop SEC. every 6 th

day

7 = Loop SEC one day per week

8 = Single 24hr SEC

(until programmed again)

One Shot

Start Event #1 Start Time

Start Event #2 Start Time

Start Event #3 Start Time

Start Event #4 Start Time

Start Event #5 Start Time

Start Event #6 Start Time

Start Event #7 Start Time

00:00-23:59 (hh:mm) or OFF

OFF

VMX Digital Solid State Soft Starter User Manual 88 | P a g e

Fn # Group

F040

F041

Function Description

Current Imbalance Trip

Adjustment / Display Range

0 = Disabled, or

5 - 30% imbalance

Current Imbalance Trip Delay 1 - 20 seconds

F042

F043

F044

F045

F046

F047

Over Current Trip

Over Current Trip Delay

Under Current Trip

Under Current Trip Delay

Ground Fault Trip

Ground Fault Trip Delay

0 = Disabled, or

100 - 300% of motor FLA

1 - 20 seconds

0 = Disabled, or

10 - 90% of motor FLA

1 - 60 seconds

0 = Disabled, or

5 - 90% of CT ratio from Fn 74

1 - 60 seconds

F048

F049

F050

F051

F052

F053

F054

F055

F056

F057

F058

F059

F060

Coast Down (Back Spin)

Lockout Timer

Maximum Starts per Hour

Minimum Time Between

Starts

Internal Protection Settings

Auto Reset on Selected Faults

Auto Reset Attempts

Restart Delay Time Value

Readout (for F028)

Coast Down Timer Value for F048

Starts Per Hour Timer Value for F049

Starts Per Hour

For F049

Time Value Between Starts for F050

Thermal Capacity to Start for F005

Aux Relay 1 setting

0 = Disabled, or 1 - 60 minutes

0 = Disabled, or 1

0-999 Minutes

1-3600 Seconds

1-10 Starts

1-3600 Seconds

– 10 starts

0 = Disabled, or 1 - 60 minutes

– 255

See 5.6.9.a

Fault Preferences 1

– 12

See 5.6.9.b Fault Reset Selection

Table

0 = Disabled, or 1-10 attempts

F061

F062

F063

F064

Aux Relay 2 setting

Aux Relay 3 setting

Aux. Relay Delay Timer

(for Operations 22-26)

Reserved for factory use

0-100 % Thermal Capacity

Operation # 1

– 27: see

”Aux. Relay Settings Chart”

Operation # 1

– 27: see

”Aux. Relay Settings Chart”

Operation # 1

– 27: see

”Aux. Relay Settings Chart”

0 (Disabled), or 1-999 seconds

Setting

Increments

1 second

1 minute

Factory

Setting

Disabled

2 seconds

Disabled

1 second

Disabled

2 seconds

Disabled

2 seconds

Disabled

127

Enable all

Phase

Loss only

Setting Setting

1 1

1 0

1 1

1 2

1 16

1 second

No Delay

VMX Digital Solid State Soft Starter User Manual 89 | P a g e

Appendix 6 (cont.) Soft Starter Settings Record

Fn # Group

F065

F066

F067

F068

F069

F070

F071

F072

F073

F074

F075

F076

F077

F078

F079

F080

F081

F082

–

F084

Function Description

Communications

Baud Rate

Modbus Address

Remote Starter Control

Reserved for factory use

Parameter Lock

Customer Password

System Clear / Reset

Reserved for Factory Use

Frame Rating

CT Value

Year

Month

Day

Hour

Minute

Second

Revision #

Reserved for factory use

Adjustment / Display Range

Setting

Increments

Factory

Setting

0 = Disabled

1 = Enabled (11Bit)

2 = Enabled (10Bit)

4.8, 9.6 and 19.2 KB

1 - 247

0 = Disabled

1 = Enabled w/ Start button

2 = Enabled w/o Start button

3 = Enabled by Jog / Remote Input

3 rates

9.6 KB

– 999

0 = Disabled

Any Other Numbers = Password

(displays encrypted code)

0 = Disabled

1 = Clear THR and Lockout Timers

2 = Reset to Factory Default Settings

18 - 550

40-1200

2000 - 2047

1 - 12

1 - 31

0 - 23

0 - 59

1 0

1 year

1 Month

1 Day

1 Hour

1 Minute

1 Second

By Model

(defaults to 48)

By Model

(defaults to 40)

2000

Factory

Setting

Setting Setting

VMX Digital Solid State Soft Starter User Manual 90 | P a g e

Appendix 6 (cont.) Soft Starter Settings Record

Fn # Group

F085

F086

F087

F088

F089

F090

F091

F092

F093

F094

F095

F096

F097

Function Description

Fault History #1, Latest Fault

Time Stamp, Fault #1

Based on F078-80

Date Stamp, Fault #1

Based on F076-77

Fault History #2, Previous

Fault

Time Stamp, Fault #2

Date Stamp, Fault #2

Fault History #3, Oldest Fault

Time Stamp, Fault #3

Date Stamp, Fault #3

Run Time, Hours

Run Time,

1000 Hour Overflow

Run Cycle Counter

10K overflow

Adjustment / Display Range

0 = No fault history, or

Fault # 1 - 27: see Fault code list

00.00-23.59 (hh.mm)

[hh = 00-23; mm = 00-59]

01.01

– 12.31 (MM.DD)

[MM = 01-12; DD = 01-31]

0 = No fault history, or

Fault # 1 - 27: see Fault code list

00.00-23.59 (hh.mm)

[hh = 00-23; mm = 00-59]

01.01

– 12.31 (MM.DD)

[MM = 01-12; DD = 01-31]

0 = No fault history, or

Fault # 1 - 27: see Fault code list

00.00-23.59 (hh.mm)

[hh = 00-23; mm = 00-59]

01.01

– 12.31 (MM.DD)

[MM = 01-12; DD = 01-31]

000.0

– 999.9 hours

0000

– 9999 thousand hours

0000

– 9999 times

0000

– 9999 10 thousand times

Setting

Increments

Factory

Setting

1 0

00.01

0.1 hours

1 k-hour

1 times

1 10k times

00.00

01.01

00.00

01.01

00.00

01.01

Setting Setting

VMX Digital Solid State Soft Starter User Manual 91 | P a g e

Warranty information.

1 Year Warranty:

Phasetronics Inc., dba Motortronics, (hereinafter “Company”) warrants the VMX Series products to be free from defects in material and/or workmanship for a period of one (1) year from the date of sale, or a maximum of 18 months from the date of manufacture (if no sales records are available) as indicated by the unit‟s date code. The Company reserves the right to repair or replace any malfunctioning units or sub assemblies under warranty at the Company‟ sole option. Warranty repairs may be performed at the Company‟s facility, in the field by a factory-authorized technician, or by the customer only with prior approval and at the specific direction of the

Company‟s Technical Services personnel. During the 1 year period, malfunctions of the control boards will be dealt with by replacement of the Modular Control Assembly (MCA), which contains the

User Interface Panel, Digital Control Unit, Bypass control (if any) and Communications Interface. The MCA is designed to be replaced quickly without the need for tools (plug-in), and as such will constitute the majority of warranty replacements.

Warranty Service Procedure:

In the event that warranty service becomes necessary, contact the distributor where the starter was purchased, or Motortronics Technical Services department directly at (727) 573-1819. Be prepared to provide the complete

Model number, Serial Number, date and place of purchase. It is also helpful to know the date of initial commissioning. When Technical Services has determined the nature of the problem and that sending replacement parts or assemblies can repair it, they will require a purchase order for replacement parts and issue a Return Material Authorization (RMA) for the defective parts or assemblies. If any components or assemblies are received at the factory without the proper RMA documentation, the shipment(s) will be refused.

When the replacement parts are received and evaluated at the factory, any warranty determination will result in an offsetting credit being issued for the replacement parts already sent out. If the unit is not needed for immediate operation, an alternative is to have the Technical Services representative provide an RMA for the components, and they will be evaluated and repaired at the factory, and returned. In either circumstance, freight/shipping costs are the responsibility of the purchaser.

Responsibility:

Company is not responsible for the misuse or misapplication of its products, intentional or otherwise. Improper application, installation, failure to provide safety devices or protective measures, or operation above its ratings, and failure to properly maintain or service products are all beyond the control and responsibility of the Company.

Under no circumstances shall the Company be liable for loss of profits, indirect, incidental, special, consequential or other similar damages arising out of the misuse, misapplication or failure to maintain the Company‟s products.

SCR power devices used in the VMX Series (and all other solid state motor control products) are covered under warranty only when it has been determined by the Company that a failure of another system within the MCA or firing board circuit has directly caused damage to the SCRs. Although every effort is provided to prevent SCR damage, it can still occur as a result of circumstances beyond the control of the Company. Improper starting conditions such as under sizing, rapid duty cycling and improper settings, or external power problems such as lightning strikes, capacitor switching, shorted motor windings or locked rotor currents can all cause damage to

SCRs under the wrong circumstances. Failures under those conditions are not covered under warranty.

VMX Digital Solid State Soft Starter User Manual 92 | P a g e

Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
