Generac G0070190 Manual

EXPLODED VIEW: EV MOD PLTFRM 3100PSI
GROUP EV
DRAWING #: 0L6564
ITEM
PART#
QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
0K8430
0L4739
10000012847
0L6431
0J1449
10000009382
0H9640
0K0921
0J3052
0K9974
0J3079
0H9617S
0L4740
0K1663
0J3315
G092479
G067989
0G5442
10000027441
G021217
0L2091
0K4078A
0J3374
0K6007
10000021533
0J6276
G022304
1
1
1
1
2
1
1
1
1
2
4
1
1
1
4
4
8
2
1
4
1
1
1
1
2
2
2
REVISION: CN-0025308-F
DATE :4/2/19
DESCRIPTION
ENGINE
HANDLE C-GRIP
HANDLE KIT PW RESI NO DECAL
HOLSTER GUN
FASTENER RIBBED SHANK CHRSTM T
GUN VP M22 ORANGE WITH ICONS
LANCE ASSY-20" LONG
HOSE 25'X1/4" W/M22 CONN
HOOK-HOSE
PUSH NUT 1/2
GROMMET-NOZZLE
KIT-NOZZLE
DECAL NOZZLE BILLBOARD 3100
PUMP AXIAL
SCREW SHC M8-1.25X25 C8.8 ZP
WASHER LOCK M8 RIBBED
NUT HEX FL WHIZ M8-1.25
SNAP BUTTON
CRADLE KIT 6821 6822 6823
VIB MOUNT
DECAL NO NOT USE BLEACH
CAP CHEM TANK W/HOSE CUTOUT
DECAL QUICK START
DECAL QUICK START
PIN AXLE
WHEEL 10 X 1.75X0.5 DIA
WASHER
