LUFTIG Extractor hood

LUFTIG

ENGLISH 4

Safety information

Product description

Care and cleaning

Safety information

For your safety and correct operation of the appliance, read this manual carefully before installation and use. Always keep these instructions with the appliance even if you move or sell it. Users must fully know the operation and safety features of the appliance.

Recommendations and suggestions

• This appliance is intended to be used in household and similar applications such as:

• Farm houses.

• By clients in serviced apartments, holiday

apartments and other residential type

environments.

• The manufacturer will not be held liable for any damages resulting from incorrect or improper installation.

• The minimum safety distance between the cooker top and the extractor hood is: for electrical hob 500mm and for gas hob 650mm.

• If the instructions for installation for the gas hob specify a greater distance, this must be respected.

• Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood.

• For Class I appliances, check that the domestic power supply guarantees adequate earthing.

• Connect the extractor to the exhaust flue through a pipe of minimum diameter 120 mm. The route of the flue must be as short as possible.

• Do not connect the extractor hood to exhaust ducts carrying combustion fumes (boilers, fireplaces, etc.).

• If the extractor is used in conjunction with nonelectrical appliances (e.g. gas burning appli-

What to do if...

Technical data

Environment concerns

IKEA GUARANTEE ances), a sufficient degree of aeration must be guaranteed in the room in order to prevent the backflow of exhaust gas. When the cooker hood is used in conjunction with appliances supplied with energy other than electric, the negative pressure in the room must not exceed

0,04 mbar to prevent fumes being drawn back into the room by the cooker hood.

• WARNING: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.

• If the supply cord is damaged, it must be replaced from the manufacturer or its service agent.

• Connect the plug to a socket complying with current regulations, located in an accessible place.

• Connect the hood to the power net by using a bipolar switch having a contact gap of at least 3 mm.

• With regards to the technical and safety measures to be adopted for fume discharging it is importat to closely follow the regulations provided by the local authorities.

• WARNING: Before installing the Hood, remove the protective films (white and transparent).

Use

• The extractor hood has been designed exclusively for domestic use to eliminate kitchen smells.

• Never use the hood for purposes other than for which it has been designed.

• Never leave high naked flames under the hood when it is in operation.

• Adjust the flame intensity to direct it onto the bottom of the pan only, making sure that it

ENGLISH 5

does not engulf the sides.

• Deep fat fryers must be continuously monitored during use: overheated oil can burst into flames.

• Do not flambè under the range hood; risk of fire.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

Accessible parts may become hot when used with cooking appliances.

Product description

Upper Chimney

Lower Chimney

Hood body

Lighting

Grease filter

Control Pannel

A B C D E

BUTTON FUNCTION

one.

Turns the Motor OFF..

C =

Speed Set the Motor at Speed two.

D =

Speed Set the Motor at speed three.

ENGLISH

Care and cleaning

Switch off or unplug the appliance from the mains supply before carrying out any maintenance work.

Clean the hood using a damp cloth and a neutral liquid detergent.

Charcoal Filter

These filters are not washable and cannot be regenerated, and must be replaced approximately every 4 months of operation, or more frequently with heavy usage.

Replacing the lamps

Unscrew the bulbs, by using the gloves, and replace them with new ones having the same characteristics 28W (Connection type: E14).

6

Grease Filters

Clean or replace the filters continuously according to below time intervals, to maintain good performance of the hood and to prevent a potential fire hazard, caused by excessive grease build-up.

The grease filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher.

ENGLISH 7

What to do if...

If there is a fault, first try to find a solution to the problem yourself. If you cannot find a solution to the problem yourself, contact the After Sales

Service.

PROBLEM

Appliance not stable

POSSIBLE CAUSE

If you operated the appliance wrongly, or the installation was not carried out according to the Assembly instructions, the visit from the

After Sales Service technician may not take place free of charge, even during the warranty period.

SOLUTION

Oil and grease on metal filters

Appliance doesn't work

The lamp is not working

The lamp is not correctly fixed

The lamp is faulty the motor group or the plug is connected to the socket

Verify that the lamp is screwed properly to the lampholder

Replace the lamp bulb

Technical data

Dimensions

Height

Depth

Lamp

Total connection rating

Type of lamp and socket

Airflow Max - Exhaust

Noice Max - Exhaust

Airflow Max - Recirculation

Noice Max - Recirculation

Installation Min. Height - Gas Hob

Installation Min. Height - Electric Hob

Weight

Min.620 mm - Max.995 mm

471 mm

2 x 28 W

181 W

Halogen 28 W E14

400 m

64 dB(A)

260 m

70 dB(A)

650 mm

500 mm

6,4 Kg

ENGLISH

The technical information is situated in the rating plate on the internal side of the appliance.

8 Environment concerns

Maintenance

• The symbol on the product or on its packaging indicates that this product may

ENGLISH 12

collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for

Electrical connection for Australia

Power Cord and Plug: Declared Article –

Mandatory Approval Applies:

Current Australian Approval Certi cates will need to be forwarded, showing compliance city office, your household waste disposal service or the shop where you purchased the product.

Packaging materials

The materials with the symbol are recyclable. Dispose the packaging in suitable collection containers to recycle it.

Electrical connection for Australia

Plug and Cord to have approval marking, as required by the relevant Approval

Certi cate

· AS/NZS 3112: 2004 with Amendment 1, for

Plug

Power Cord and Plug: Declared Article –

Mandatory Approval Applies:

Current Australian Approval Certificates will need to be forwarded, showing compliance with applicable Australian Standards, as noted below. Plug to have insulated pins.

Plug and Cord to have approval marking, as

· AS 3191: 2008, for Cord, or;

· ‘HAR’ Certi cation, for Cord

· ‘HAR’ Certification, for Cord

IKEA GUARANTEE

How long is the IKEA guarantee valid?

This guarantee is valid for  ve (5) years from the original date of purchase of your appliance at IKEA, unless the appliance is named LAGAN in which case two (2) years of guarantee apply. The original sales receipt, is required as proof of purchase. If service work is carried out under guarantee, this will not extend the guarantee period for the appliance.

Which appliances are not covered by the

IKEA  ve (5) years guarantee?

The range of appliances named LAGAN .

Who will execute the service?

IKEA has appointed Whirlpool (Australia)

Pty Ltd as the authorised service network partner.

• If you encounter any trouble with the appliance and wish to register a call with

Whirlpool, please call:

Australia contact centre:

1300 363 344.

What does this guarantee cover?

The guarantee covers applicable faults of the appliance, as per the terms and conditions, from the date of purchase from IKEA. This guarantee applies to domestic use only. The exceptions are speci ed under the headline

“What is not covered under this guarantee?”

Within the guarantee period, the costs to remedy the fault e.g. repairs, parts, labour and travel will be covered, provided that the appliance is accessible for repair without special expenditure. Replaced parts become the property of IKEA.

The services will be in-home service for domestic appliances, and must to be done by of cial Whirlpool service network.

Goods presented for repair may be replaced by refurbished goods of the same type rather than being repaired.

Refurbished parts may be used to repair the goods.

If the authorized service agent requests you to deliver the product directly to them, please ensure that the appliance is suitably packaged to prevent any damage during transportation.

What will IKEA do to correct the problem?

IKEA appointed service provider will examine the product and decide, at its

ENGLISH 5

• Keep children and pets away from the appliance when it operates or when it cools down. Accessible parts are hot.

• If the appliance has a child safety device, we recommend you activate it.

• Cleaning and user maintenance shall not be made by children without supervision.

First use

Activating and deactivating the appliance

The indicator comes on when the oven heats up.

• Children of less than 3 years should be kept away unless continuously supervised.

ENGLISH

• Keep children and pets away from the appliance when it operates or when it cools down. Accessible parts are hot.

• If the appliance has a child safety device, we recommend you activate it.

• Cleaning and user maintenance shall not be made by children without supervision.

First use

Activating and deactivating the appliance

The indicator comes on when the oven heats up.

IKEA GUARANTEE

How long is the IKEA guarantee valid?

This guarantee is valid for five (5) years from the original date of purchase of Your appliance at IKEA Pty Ltd, ABN

84006270757 or at Cebas Pty Ltd, ABN 15

009 156 003 (Both Trading as IKEA) unless the appliance is named LAGAN in which case two (2) years of guarantee apply. The original sales receipt is required as proof of purchase. If service work is carried out under guarantee, this will not extend the guarantee period for the appliance.

Which appliances are not covered by the

IKEA five (5) years guarantee?

The range of appliances named LAGAN .

Who will execute the service?

IKEA service provider will provide the service through its own service operations or authorized service partner network. Contact

IKEA for further information.

If you encounter any trouble with the appliance and wish to register a service call or make a claim, please refer to www.ikea.com.au for your local store after

IKEA GUARANTEE

How long is the IKEA guarantee valid?

This guarantee is valid for five (5) years from the original date of purchase of Your appliance at IKEA Pty Ltd, ABN

84006270757 or at Cebas Pty Ltd, ABN 15

ENGLISH

Which appliances are not covered by the

IKEA five (5) years guarantee?

How long is the IKEA guarantee valid?

This guarantee is valid for five (5) years from the original date of purchase of Your appliance at

If you encounter any trouble with the

5

Ltd, ABN 15 009 156 003 (Both Trading as IKEA) unless the appliance is named LAGAN in which case two (2) years of guarantee apply. The origi-

• Children of less than 3 years should be kept away unless continuously this will not extend the guarantee period for the appliance.

Which appliances are not covered by the

IKEA five (5) years guarantee?

The range of appliances named LAGAN .

Who will execute the service?

IKEA service provider will provide the service through its own service operations or authorized service partner network. Contact IKEA for further information.

If you encounter any trouble with the appliance and wish to register a service call or make a claim, please refer to www.ikea.com.au for your sales customer service center phone phone number, online email and opening times.

The principal address and contact details in

Australia are:

For Queensland, New South Wales, and

Victorian customers please contact:

IKEA Pty Ltd

IKEA Service Office

L1 Clock Tower, 630 Princes Highway

Tempe, NSW 2044

Contact - IKEA Customer Service at www.IKEA.com.au

For Western Australian and South

Australian customers please contact:

Cebas Pty Ltd

8c Sunray Drive, Innaloo WA 6018

Australia

Contact - IKEA Customer Service at www.IKEA.com.au

sales customer service center phone number, online email and opening times.

The principal address and contact details in

Australia are:

For Queensland, New South Wales, and

Victorian customers please contact:

IKEA Pty Ltd

IKEA Service Office

L1 Clock Tower, 630 Princes Highway

Tempe, NSW 2044

Contact - IKEA Customer Service at www.IKEA.com.au

For Western Australian and South

Australian customers please contact:

Cebas Pty Ltd

8c Sunray Drive, Innaloo WA 6018

Australia

Contact - IKEA Customer Service at www.IKEA.com.au

9

What does this guarantee cover?

The guarantee covers faults of the appliance, which have been caused by faulty construction or material faults from the date of purchase from

IKEA. This guarantee applies to domestic use only. The products have been designed and tested for domestic purposes only and this guarantee does not cover damage arising from use of the Product in a commercial environment.

The exceptions are specified under the headline

“What is not covered under this guarantee?”

Within the guarantee period, the costs to remedy the fault e.g. repairs, parts, labour and travel will be covered, provided that the appliance is accessible for repair without special expenditure.

Replaced parts become the property of IKEA.

The guarantee exists only if the appliance complies and is installed in accordance with:

• The technical specifications.

• The Assembly Instructions and user manual

Safety Information.

IKEA’s guarantee is subject to Australian Consumer Law - see Schedule 2 to Competition and

Consumer Act, 2010. This guarantee is in addition to (and does not exclude, restrict or modify in any way) any non-excludable statutory warranties in Australia.

What will IKEA do to correct the problem?

IKEA appointed service provider will examine the product and decide, at its sole discretion, if it is covered under this guarantee.

They will notify you as to whether your claim

ENGLISH 10

is covered under this guarantee. If your claim is approved, the IKEA service provider or its authorized service partner, will then, at its sole discretion, either repair the defective product or replace it with the same or a comparable product.

What is not covered under this guarantee?

• Normal wear and tear.

• Deliberate or negligent damage, damage caused by failure to observe operating instructions, incorrect installation or by connection to the wrong voltage, dam age caused by chemical or electro-chemical reaction, rust, corrosion or water damage including but not limited to damage caused by excessive lime in the water supply, damage caused by abnormal environmental conditions.

• Consumable parts including batteries and lamps.

• Non-functional and decorative parts which do not affect normal use of the appliance, including any scratches and possible colour differences.

• Accidental damage caused by foreign objects including insect or vermin infestation or substances and cleaning or unblocking of filters, drainage systems or soap drawers.

• Damage to the following parts: ceramic glass, accessories, crockery and cutlery baskets, feed and drainage pipes, seals, lamps and lamp covers, screens, knobs, casings and parts of casings. Unless such damages can be proved to have been caused by production faults.

• Cases where no fault could be found during a technician’s visit.

• Repairs not carried out by our appointed service providers and/or an authorized service contractual partner or where non-original parts have been used.

• Repairs caused by installation which is faulty or not according to specification.

• The use of the appliance in a non-domestic environment i.e. professional use.

• Transportation damages. If a customer transports the product to their home or other address, IKEA is not liable for any damage that may occur during transport. However, if

IKEA delivers the product to the customer’s delivery address, then damage to the product that occurs during this delivery will be covered by this guarantee.

• Cost for carrying out the initial installation of the IKEA appliance. However, if an IKEA service provider or its authorized service partner repairs or replaces the appliance under the terms of this guarantee, the service provider or its authorized service partner will reinstall the repaired appliance or install the replacement, if necessary.

• The appliance’s serial number or warranty seal has been removed or defaced.

How country law applies

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law (ACL). You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.

You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

This guarantee is not intended in any way to limit or exclude such rights and remedies that you may have under law.

You can find out more information about the

Australian Consumer Law on the ACCC website: www.accc.gov.au

Area of validity

This IKEA guarantee applies only to products purchased and installed in AUSTRALIA .

What you must do to make a claim under the guarantee:

To make a claim under the guarantee contact

IKEA after sales customer service center at the above address, the IKEA catalogue or refer to www.ikea.com.au for your local store customer

ENGLISH 11

service phone number, online email and opening times. Please describe the problem that you are facing with the appliance in detail along with your product article number (8 digit code) and date of purchase at the time of call registration.

Please do not hesitate to contact the dedicated after sales customer service center for IKEA appliances to:

1. Make a service request under this guarantee;

2. Ask for clarification on installation of the IKEA appliance in the dedicated IKEA kitchen furniture.

3. Ask for clarification on user manual contents and specifications of the IKEA appliance.

To ensure that we provide you with the best assistance, please read carefully the Assembly

Instructions and/or the User Manual section of this booklet before contacting us.

How to reach us if you need our service

SAVE THE SALES RECEIPT!

Kindly keep all these details and original invoice of purchase handy during the service technician’s visit to enable him to carry out the job. It is your proof of purchase and required for the guarantee to apply. Note that the receipt reports also the IKEA article name and number (8 digit code) for each of the appliances you have purchased.

The IKEA after sales customer service centre will assist you on the phone with basic trouble shooting for your appliance at the time of service call request. Please refer to the IKEA catalogue or www.ikea.com.au and select your local store for local store phone numbers and opening times.

Please describe the problem that you are facing with the appliance in detail along with your product article number ( 8 digit code ) and date of purchase at the time of call registration

Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
