Insert memory ca rd
Switch on the frame
For additional features and instructions please refer to the user manual.
Automatic slideshow will begin in a
few seconds.
3
Plug the power adapter into an
electrical outlet.
Insert AC Power
adapter into the input jack.
2
Insert memory card
into the card slot labeled SD/MMC/MS/xD
or the card slot labeled CF.
1
1
Technical Specifications & Warranty.........14
Troubleshooting.............................................13
SyncPix™ Desktop.........................................12
Connecting to a Computer...........................11
Copying and Deleting Files...........................10
View Your Pictures
Listen to Your Music
View Your Videos
Settings
The Three Modes.........................................7-9
Getting Started
How to Insert Memory Card
How to Select Memory Card..............................6
How to Display the Frame..................................5
Introduction......................................................4
What’s Included...............................................3
Important Safety Precautions.......................2
Table of Contents
Important Safety Precautions
Always follow these basic safety precautions when using your
digital picture frame. This will reduce the risk of fire, electric
shock, and injury.
Warning: To reduce the risk of fire or shock hazard, do not
expose this product to rain or moisture.
Warning: To prevent the risk of electric shock, do not
remove the cover. There are no user-serviceable parts inside.
Refer all servicing to qualified personnel.
• The digital picture frame is for indoor use only.
• Unplug the digital picture frame before performing
care and maintenance.
• Do not block the ventilation holes on the back of the
digital picture frame at any time.
• Keep your digital picture frame out of direct sunlight
and heat sources.
• Protect the power cord. Route power cords so that
they are not likely to be walked on or pinched by items
placed on or against them. Pay particular attention to
the point where the cord attaches to the digital picture
frame.
• Only use the AC adapter included with the digital
picture frame.
Using any other power adapter will void your warranty.
• Unplug the power cord from the outlet when the unit
is not in use.
2
What's Included
Digital Picture Frame
AC Power Adapter (9V, 2.0A)
This User's Guide
Remote Control
USB Cable
Stand
Light sensor
5 Way button
Stand
Memory card slots
USB Ports
Power input jack
3
Introduction
Congratulations on your new Smartparts SyncPix™ digital
picture frame! SyncPix™ frames include revolutionary
technology that makes transferring photos from a memory
card to the frame virtually effortless.
Your new picture frame does some amazing things.
• Your new digital picture frame lets you view photos and
videos and listen to music – all without a computer.
• An automatic, continuous slide show lets you enjoy all of
your photos with ease.
• The included remote control makes it simple to select
photos, change settings, and more.
• Photos can be viewed directly from memory cards or from
the frame’s built-in memory.
• The frame can be connected to a computer to quickly and
easily transfer pictures from your hard drive.
4
How to Display the Frame
To begin using your SyncPix™ digital picture frame, start by
connecting the stand or hanging the frame on a wall.
The stand is connected by inserting the round knobs at the
top into the opening on the back of the frame and sliding it
upward. The display angle of the frame can be adjusted by
sliding the stand up or down. The frame can be displayed
vertically by rotating the stand 90 degrees counter-clockwise.
The slot on the back of the frame can also be used to hang
the unit on a wall.
5
Getting Started
To begin using your digital picture frame right away, follow
these simple steps.
1. Connect the AC power adapter to the frame and plug
the adapter into an electrical outlet. (100-240 V, 50-60Hz)
2. Insert a memory card into the appropriate card slot, or
plug a USB flash drive into the USB port on the side of the
frame.
3. To turn on the frame press the switch to the side of the
frame to the on position.
4. Slide show begins automatically. To stop press Exit.
How to Insert Memory Card
There are two memory card slots on the side of the digital
picture frame. The smaller slot is for Secure Digital™, MultiMedia Card™, Memory Stick™, Memory Stick Pro™,
Memory Stick Duo™, Memory Stick Pro Duo™ and xD
Picture Cards. The larger slot will accept Compact Flash cards.
A card can be inserted in only one direction. It should fit
snugly when properly inserted. Do not force a card or you
will risk damaging your digital picture frame and the card.
How to Select Memory Card
To select from the various types of memory, press Exit until
the memory devices are highlighted at the bottom of the
screen, and then use the left and right arrow buttons to select
the desired memory type. Press OK to access the selected
memory type.
6
7
Highlight Listen to Your Music and press OK. Use the up and
down arrow buttons to highlight the song you want to hear
and press OK to play the song. To stop, press Exit.Your digital
picture frame can play music files in the WMA file format.
If music files are present, the music will also be played in the
background during the slide show.
Listen to Your Music
Highlight View Your Pictures and press OK. Use the arrow
buttons to highlight the photo you want to view. Press OK
to view the photo. While viewing a single photo you can move
to the previous or next photo by using the left and right arrow
buttons. The up and down arrow buttons are used to rotate the
photo on the screen. To see a slide show of your pictures,
press the Slideshow button on the remote control. To end the
slide show, press Exit.
View Your Pictures
There are three modes for using your digital picture frame.
To change modes, press the Exit button until the options on
the left side of the screen are highlighted. Use the up and down
arrows to highlight the desired mode and then press Enter
The Three Modes
8
Slide Show Speed - The slide show speed can be set to Fast,
Medium or Slow.
Slide Show Transition – This allows you to choose from among
several transition effects.
Multiple Picture Display – Turning this feature on will result in
photos being displayed on the screen four at a time.
Slide Show – Press enter to start the slide show. This is how
you would start the slide show without the use of the remote
control.
Highlight Settings and press Enter. Use the up and down arrow
buttons to highlight the setting you would like to change and
press Enter to access it.
Settings
Highlight View Your Videos and press OK. Use the up and
down arrow buttons to highlight the video clip you want to
watch and press OK. To stop the video, press Exit.Your digital
picture frame can play video clips that are in the AVI Motion
JPEG format, up to 640x480 resolution and up to 30 frames
per second.
View Your Videos
9
Reset Settings – Select Yes to restore your digital picture
frame to its factory default settings.
Language – Select English, French or Spanish.
Light Sensor -- When activated, the frame's built-in light sensor
automatically turns the frame off when the room is darkened
and back on when it is light.
Alarm – Select On to use the alarm function. The alarm can
be set to ring at a specific time each day. The hours and
minutes are set in the same manner as used in setting the
Clock.
Clock – Select On to have a clock displayed on the menu
screen. After pressing On the year will be highlighted. Use the
up and down arrow buttons to change the number, then use
the right arrow button to move to the next number. Continue
until the date and time are correct and then press OK.
Repeat – Select Repeat One to have each individual video or
music file repeat continuously. Select Repeat All to have all
video or music files repeat continuously. Select Repeat Off to
have video or music files played only once.
Display Image Size – Select Original to have your photos show
in their original shape even if they do not match the shape of
the screen. Select Optimal to have your photos fill the screen
(some cropping may occur).
10
To delete, highlight the file or files as above and select the
delete option from the menu.
Copying music and video files is done in a very similar manner.
However, to select multiple files, use the right arrow button
to add the check mark next to each file.
To copy multiple pictures at once you can select them
before accessing the Copy Picture to function. To select a
photo for copying, highlight it in the thumbnail screen and
press the Up Volume button on the remote control.
A check mark will appear in the corner of the thumbnail.
Select all the photos you would like to copy and then press
Menu and Copy Picture to as described above.
To copy one photo, highlight the thumbnail and press the
Menu button. Highlight Copy Picture to and press OK.
Only the available memory types will be shown. Highlight
the type of memory that you want to save your picture to
and press OK. The picture will be copied.
Photos, music and video files can be deleted or copied to
another type of memory. For example, you can copy your
pictures from the memory card you normally use in your
camera to the Expansion Memory or Internal Memory.
Copying and Deleting Files
11
The frame must be disconnected from the computer to
display photos or videos or play music.
1. Find the pictures to transfer
2. Optimize your pictures
3. Finally transfer your picture to your frame and enjoy the
slide show!
With the frame turned off, connect the small end of the cable
to the frame and the large end to your computer. Turn the
frame on and allow the computer a few moments to
recognize the device. The frame’s internal memory and any
memory cards inserted in the frame will appear as external
storage devices on the computer. Compatible picture, audio
and video files can be copied to the internal memory or
memory cards in the frame through normal copy-and-paste
or drag-and-drop methods or by using Smartparts
Sync™Pix desktop software you can optimize and transfer
pictures in three easy steps:
Using the supplied USB cable, you can connect your digital
picture frame to a computer to transfer files between the
two devices.
Connecting to a computer
12
• SMART VIEW - Convert pdf, powerpoint, and many
image formats for viewing on your picture frame.
• SMART SCALE – Automatically corrects for rotation,
optimizes the size and characteristics of each photo to
match your particular frame allowing the frame to hold
up to 2000 pictures.
• SMART FIT – Using advanced image understanding
technology, photographs can be automatically focused on
the most important areas without distorting the picture.
A Smartparts’ EXCLUSIVE!
• SMART COPY - Copying your pictures from your
computer to your frame is as easy as 1-2-3
You can also use SyncPix desktop software with your
SyncPix frame.
Visit www.syncpix.com to download your complementary copy
of the software. Use SyncPix Desktop to do the following:
SyncPix™ Desktop
Troubleshooting
13
Technical Specifications
12” LCD Digital Picture Frame with
SyncPix™technology
Product :
Secure Digital™ , Multi Media Card™ ,
Compact Flash™ ,xD-Picture Card™ ,
Memory Stick™ ,Memory Stick PRO™,
Memory Stick Duo™, Memory
Stick PRO Duo™ and USB Flash Drives
Input Formats:
h
h
File Format:
JPEG, AVI Motion JPEG, MPEG-1, MP3
Internal Memory:
256MB
USB Ports:
Mini -USB (for file transfer)
USB (for USB Flash Drives)
Power Input:
100V -240V AC, 50~60HZ
Power Output:
12V DC, 1.5A
Features:
Play picture, music & video files
Auto-optimization of photos
Extendable/removable stand
Remote control
Variable speed slide show
Range of transition styles for slide show
Warranty
Smartparts, Inc. warrants its digital picture frames against manufacturing defects for a period of 90 days from date of purchase.
For technical support, please visit our web site at:
www.smartpartsproducts.com.
14
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
