Revised on March 24. 2014

2014 S/S Monitor Version 1.0

Vertical

Rock the World with 21:9

7 Target Customers’ In-Depth Interview

Different Needs from Different Working Environment

Things to Know before NPI

How To OFFER? : Get the Ideas

Best Matching

Products

For UM95/ UM65/ UB65/ MB85/ MB65 / MB35

INTERNAL USE ONLY

MUST KNOW before you start…

This presentation is for TRAINING PURPOSE ONLY.

DO NOT use the contents

(especially, images) of this presentation for publication as some may cause legal issues.

Picture images may differ from actual ones. Especially image of bezel may artificially be modified on selected scenes.

• Information on the product may be subject to change.

• Some features including this presentation may vary or differ depending on country as each country runs different specifications.

• Some features are also available with selected models. Therefore, consumers need to check detailed specifications for the model they are looking for.

Table of Contents

1. Design & Specification

2. Vertical Usage by Target Customer

3. Certification Standard

4. Appendix

1. Design & Specification

1. New 21:9 UltraWide Monitor Series : UM95 / UM65 / UB65

2. New ColorPrime Monitor Series: MB85

3. New B2B Monitor Series : MB65 / MB35

Design &

Specification

New 21:9 UltraWide Monitor Series :

UM95 / UM65 / UB65

Design

21:9 UltraWide Monitor Series

: 34UM95

Narrow Bezel

Crystal Floatstand

• Wall Mount: VESA Compatible (100mmx100mm)

Simple height Adjustment

Two height levels are available to install

Design

21:9 UltraWide Monitor Series

: 34UM65 / 29UM65 / 25UM65

Narrow Bezel

Crystal Floatstand

Simple Height Adjustment

Two height levels are available to install

• Wall Mount: VESA Compatible (100mmx100mm)

• Wall Mount: VESA Compatible (75mmx75mm) • Wall Mount: VESA Compatible (75mmx75mm)

Design

21:9 UltraWide Monitor Series

: 29UB65

Narrow Bezel

Aluminum Extrusion

90˚ PIVOT

• Wall Mount: VESA Compatible (75mmx75mm)

Specification

UM/UB Series : 34UM95 / 34UM65 / 29UM65 / 25UM65 / 29UB65

Inch

Display Type

Color Gamut (CIE1931)

Color Depth(Number of

Colors)

Aspect Ratio

Resolution

Brightness(Typ.)

Response Time(GTG)

Viewing Angle(CR≥10)

Jack Input / Output

Speaker

Control Key

Feature

Stand

Dimension (with Stand)

Accessory

34UM95

34

8bit+FRC, 1.07B colors

3440 x 1440

320 nits

HDMI*2

DisplayPort

Thunderbolt*2

Headphone Out

USB 3.0 (1up/1down), 2.0(2down)

Color Calibrated

4-Screen Split(Software)

Super Energy Saving

True color finder(Software)

Dual Linkup

Reader mode, Flicker Safe

Detachable

Tilt(Angle) -5~15 Degree

Wall Mount

(

VESA:100mm*100mm)

829.9x172.9x468.9

Power Cable

HDMI

DisplayPort

34UM65

34

LED IPS sRGB over 99%

29UM65

29

8bit, 16.7M

Power Cable

HDMI

25UM65

25

21:9

2560 x 1080

300 nits

5ms

R/L 178 (Typ.), U/D178 (Typ.)

DVI-DX1

HDMI*2

DisplayPort

PC Audio In

Headphone Out

Speaker 7W*2 / 2ch (L/R)

Joystick

Detachable

Tilt(Angle) -5~15 Degree

Wall Mount(

VESA:100mm*100mm)

829.9x172.9x468.9

250 nits

Speaker 3W*2

Color Calibrated

4-Screen Split(Software)

Auto Resolution (Software)

Super Energy Saving

Dual Linkup

Reader mode, Flicker Safe

Detachable

Tilt(Angle) -5~20 Degree

Wall Mount(

VESA:75mm*75mm)

703.0x181.0x418.0

609x188.4x383

* Specifications may vary by countries, and the 4-screen split software may not work with some programs.

29UB65

29

LED, IPS sRGB over 99%

8bit, 16.7M

21:9

2560 x 1080

300 nits

5ms

R/L 178 (Typ.), U/D178 (Typ.)

DVI-DX1, HDMIX2, Display Port ,

PC Audio In, H/P Out

Speaker 7W*2 / 2ch (L/R)

Joystick

Color Calibrated

4-Screen Split(Software)

Auto Resolution (Software)

Super Energy Saving

Dual Linkup

Reader mode, Flicker Safe

Height Range 110mm

Pivot (90)

Wall Mount(

VESA:75mm*75mm

)

703.0x225.0x425.0

Power Cable

HDMI

Design &

Specification

New ColorPrime Monitor Series MB85

Design

ColorPrime Monitor Series

: 27MB85Z / 27MB85R

90˚ PIVOT

• Wall Mount: VESA Compatible (100mmx100mm)

Specification

MB Series : 27MB85Z / 27MB85R

Inch

Variation

Resolution

Display, BLU

Brightness

Color Gamut

Contrast Ratio

Viewing Angle

Response Time (GTG)

Control Key

MB85

27

27MB85Z

2560x1440

LED, IPS

350nits

AdobeRGB 99%

27MB85R

<

<

< sRGB over 99%

1000:1 (Static)

178 / 178 <

5ms

Touch Type ( 5 Key : Menu, MODE/<, SES/>, OK, Power)

Interface

VESA

Power

Stand

Feature

Accessories

Thunderbolt x 2

DVI-D dual link x 1Display Port x 1

HDMI x 1 USB3.0(1up 3down)Audio out

Mini DP x 1

DVI-D dual link x 1Display Port x 1

HDMI x1USB3.0(1up 3down)Audio out

Yes : 100mm*100mm

Power Built-in

Tilt (-5˚ ~ +35˚)

Height Range 130mm

Pivot / Tilt / Swivel

<

<

H/W CalibrationColor Calibrated (Delta E<2) PBP/PIP DICOM / Reader / Calibration Mode / SES/

Flicker Safe

DP cable, DVI-D dual,

USB3.0 up cable, Power Cable,True Color Pro

(Calibration Software)Calibrator (Optional)

DP cable, DVI-D dual,

USB3.0 up cable, Power Cable, True Color Finder

(Calibration Software)

Remark

Thunder bolt x 2 (MB85Z only)

Mini DP (MB85R only)

DICOM for clinical review application

* Specifications may vary by countries

Design &

Specification

New B2B Monitor

Series MB65 / MB35

Design

B2B Monitor Series

: 27MB65 / 24MB65 / 22MB65

90˚ PIVOT

* Information on this page are based on 24-inch model

24MB65PY

• Wall Mount: 100mmx100mm/ 100mmx200mm

Design

MB Series : 24MB35 / 23MB35 / 22MB35 / 19MB35

24MB35PY

• Wall Mount: VESA Compatible (100mmx100mm)

* Information on this page are based on 24-inch model

Specification

MB Series : MB65(27’/24’/22’) / MB35(24’/23’/21.5’/19N’)

Inch

Variation

Resolution

Display, BLU

Brightness

Color Gamut

Contrast Ratio

Viewing Angle

Response Time

(GTG)

Control Key

27

PY

MB65

24W

PY/PM

22W

PY/PM/P

1920 x 1080(16:9) 1920 x 1200(16:10) 1680 x 1050(16:10)

LED, IPS LED, IPS

250 nits

CIE1976 72%

Mega (10,000,000:1)

178 / 178

LED, TN

170/160

5ms

6 Key (Including power button, Tact style)

23.8

PY/PU/PM/P/DM/D

LED, IPS

178 / 178

Interface

VESA

Power

Tilt

Stand

Feature

23

PY/PM/PH/P

1920 x 1080(16:9)

MB35

21.5

PU/P/DM/D

LED, IPS LED, TN

250 nits

CIE1976 72%

Mega (10,000,000:1)

178 / 178 170/160

5ms

6 Key (Including power button, Tact style)

19N

PM/P/D

1280 x 1024(4:3)

LED, IPS

178 / 178

P : D-sub, DVI, Height/Pivot/Swivel StandPM : P + SpeakerPY : PM +

Display Port + USB 1up 2down

D : D-sub, DVI / DM : D + Speaker P : D + Height/Pivot/Swivel StandPH : P + HDMI / PM : P +

SpeakerPU : PM + USB 1up 2downPY : PU + Displayport

Yes : 100mm*100mm /100mm*200mm

Power Built-in

-5˚ ~ +35˚ -5˚ ~ +20˚

Down Height : Min. 50mm, Range 130mm(22W : 120mm)

Hot Key : Super Energy Saving/ Reader Mode

Flicker Safe

Color CalibratedMechanical SwitchARC : Size

/ format selection

Hot Key : Super Energy

Saving/ Reader Mode

Flicker Safe

Mechanical

SwitchARC : Size /

format selection

Height : Min. 100mm,

Range 120mm

Yes : 100mm*100mm

Power Built-in

-5˚ ~ +20˚

Height : Min. 60mm,

Range 110mm

Height : Min. 70mm,

Range 110mm

Hot Key : Super Energy Saving/ Reader Mode

Flicker SafeColor Calibrated

Hot Key : Super Energy

Saving/ Reader Mode

Flicker Safe

Height : Min. 70mm,

Range 110mm

Hot Key : Super Energy

Saving/ Reader Mode

Flicker SafeFactory

Calibration

* Specifications may vary by countries

2. Vertical Usages by Target Customer

Optimum model : for each target customers

Software : commonly used by target customers

PRE-INTERVIEW : User profile

1. Sound Editor

2. Video Editor

3. Photographer

4. Graphic Designer

5. Office Manager

6. Stock Manager

Optimum model :

for customer

SOUND EDITOR

Target Customers

VIDEO EDITOR PHOTO GRAPHER GRAPHIC DESIGNER OFFICE MANAGER STOCK MANAGER

NEW

21:9 UltraWide

Series

NEW

ColorPrime

Series

NEW

Normal B2B

Series

34UM95

1) 21:9 ratio for sequence S/W

2) Use the powerful MAC’s

MIDI Sequencer App via

Thunderbolt™

3) Offering the Upgraded Multi-

In/out port

34UM65

34UM95

1) 21:9 ratio for sequence S/W

2) Use the powerful MAC’s

Sequence App via

Thunderbolt™

3) Built-in 7w*2 speaker

34UM65

1) 21:9 ratio for sequence S/W

34UM95/29UM65 /25UM65/

29UB65

1) 21:9 Optimal Work Space for

Horizontal Designing

29UB65

1) 21:9 Optimal Work Space for

Vertical Designing

- 90 degree Pivot

34UM65/29UM65/25UM95

1)21:9 ratio & wide viewing

34UM65/29UM65

1)21:9 ratio & 34’ wide viewing

&Dual Link-up and market condition chart

- simultaneously

29UB65

2) Eye comfortable display

1) 21:9 ratio & wide viewing

-Reader Mode&Flicker safe

2) Multitasking with 4-Screen Split

&Dual Link-up

3) Ergonomic design

27MB85Z

27MB85Z/R

1) Total Color Management

1) Total Color Management

- AdobeRGB 99%, 1.07 billion

- AdobeRGB 99%, 1.07 billion colors / True color Pro software / colors / True color Pro software /

Built-in scaler / Color calibrated

Built-in scaler / Color calibrated

2) Advanced Picture Quality and

2) Advanced Picture Quality and

Wide color gamut

Wide color gamut

- 2560x1440 WQHD IPS

- 2560x1440 WQHD IPS

3) Outstanding Work Performance

3) Outstanding Work Performance via Thunderbolt™ 2 via Thunderbolt™ 2/ Mini DP

24MB65PY

1) Eye comfortable display

-Reader Mode&Flicker safe

2)Tilt-

5˚+30˚,Height50~130mm

Ergonomic design

3)16:10 ratio for document work

24MB35PY

1) Eye comfortable display

-Reader Mode&Flicker safe

2)Tilt-5

˚+20˚,Height100~130mm

3)Low power consumption

-Reasonable decision for multi-monitor environment

24MB65PY/24MB35PY

1) Eye comfortable display

-Reader Mode&Flicker safe

2) Ergonomic design

3) 16:10 ratio for advanced document work (MB65 only)

4) Upgraded usability

Software :

Commonly used by customer

SOUND EDIT

Pro Tools

Logic Pro X

FL Studio

Ableton Live

VIDEO EDIT

Finalcut PRO

AVID Media composer

Premiere Pro

Vegas™ Pro

PHOTO EDIT

Paintshop Pro

Capture one

Photoshop

GRAPHIC DESIGN : 2D

Illustrator

Photoshop

Indesign

CorelDraw

SOUND COMPOSITION

Sonar

CUBASE

GOLDWAVE

FL Studio

Nuendo

LOGIC X

VIDEO EFFECT

VEGAS

Aftereffect

AVID

Inferno

GRAPHIC DESIGN : 3D

C4D

ZBrush

Real floor

WEB EDIT

DreamWeaver

Illustrator

Photoshop

Indesign

Edit Plus

WEB FLASH

Flash

OFFICE MANAGE

MS Office

MAC Keynote

MAC Page

MAC Number

STOCK MANAGE

-HTS

Home trading system

Pre-Interview

User Profile

SOUND EDITOR _ ‘Miguel, 31’

…I have a bunch of recording devices like mixers, controllers, and big monitoring speakers that are over 170 Watts. How frequently I use them? Not really, actually. Because the Pro Tools and Logic Pro

X provide virtual mixers and controllers nowadays, I prefer working them on the virtual controller or mixer

….”

VIDEO EDITOR _ ‘Darren, 33’

“….

When I’m working on a movie or a T.V. program that is over two hours long, I have to keep adjusting the length of the track. That’s a major strain on the eyes. That means I have to keep activating and deactivating the track and effect plug-in too. The screen ratio is small, so it’s nearly impossible to work on more than two task pads

…….

GRAPHIC DESIGNER(2D) _ ‘Emily 29’

“…

One case I use two monitors side by side is when I open Photoshop on one monitor and the Illustrator on the other. ……In that case, however, it makes me bother that color tones are slightly different between two monitors even if the monitors are same models from same brand….”

OFFICE MANAGER _ ‘Tina 37’

“…I keep all those programs activated. Well, Outlook,

Excel, Word, Powerpoint and Explorer? I guess four to five programs. Yes, it’s impossible to work with all these programs activated on my Ultra PC monitor. So I connect the computer to a bigger monitor and work there….”

PHOTO GRAPHER _ ‘Demian, 39’

“…I am also very picky to choose the monitors as much as to choose cameras in order to review and retouch my pictures. It should cover over 99% of Adobe RGB color space with 10 bit color depth in super-high resolution display. It would be a plus if it is easily connecting to Mac devices

…”

STOCK MANAGER _ ‘Serena, 34’

“Yes, I use six 23 inch monitors from D brand. Of course, all the monitors show different contents. Okay, the upper three monitors show me monthly trend, market status and favorite stocks. The lower three show the daily trend, which is the most important real-time trade and our intranet….”

IN-DEPTH INTERVIEW

Miguel , Sound Editor & Composer

Age 31

Usage software :

Logic X PRO(Mac OS) /Cubase(Win OS)

Usage Device :

Triple-Monitor(27”) Quadro graphic-card(NVIDIA) / Master

keyboard / Audio interface / Synthesizer / YAMAHA Mix console /

Shure MIC / Monitoring speaker YAMAHA msp7studio / etc

I

have a bunch of recording devices like mixers, controllers, and big monitoring speakers that are over 170

Watts. How frequently I use them? Not really, actually. Because the Pro Tools and Logic Pro X provide virtual mixers and controllers nowadays, I prefer working them on the virtual controller or mixer, and there is no problem with a single monitor when I am dealing with short time tracks or a commercial

TV.

But you know, when it comes to work on music tracks for movies, which are over an hour long, now I am getting in trouble. It is hard to display the virtual controller console and multi-track window all at the same screen, I use

three

27” monitors in order to widen the sequence track horizontally as much as possible.

Oh, and I compose music whenever I can. When I use MIDI software, I need to use VST and actual instrument input devices, unlike when I am only editing.

I usually work with a master keyboard, a synthesizer and a audio interface.

The rest I get from Cubase’s VSTs.

I do not personally require that many of input devices than my buddies usally do, but even if so, I still run out of USB or Audio ports. That’s why I choose D monitor, which support 4 USB ports.”

: From the In-depth interview note

Summary

Q. What does he

USE

?

The Worlds 1

st

34-inch 21:9 UltraWide QHD

(34UM95)

for Pro Sound Editor

PROTOOL

LOGIC X

FL Studio

Ableton Live

Sonar

CUBASE Nuendo

GOLDWAVE

Q. What to

SUGGEST

?

34UM95, 34UM65

Q. How to OFFER ?

If he prioritizes this ………..…………….……. Recommend this!

Using two or more monitors for long sequencers, and struggling with the work space?

Need to transfer the sound source for Mac Pro?

Struggle with the number of audio interface and in/out ports on your PC?

34UM95, 34UM65

34UM95

34UM95

The brand new LG 21:9 UltraWide QHD monitor provides the best working environment ever while enhancing its screen size to 34-inch.

21:9 UltraWide is always a right choic

e especially for those of customer who requires the horizontal trackers and activating all the mixers or controllers at the same display.

W hy 34UM95?

1

World’s First 34-inch 21:9 UltraWide QHD Monitor

The brand new LG 34-inch 21:9 UltraWide QHD monitor has returned even more powerfully. Compared to the 21:9 UltraWide Full HD monitor (29EA73), the previous version of 21:9 UltraWide monitor series, 34UM95 becomes bigger and wider in both vertical and horizontal ways, so that this powerful monitor allows the user to activate more sound footages(loops), virtual mixer, controller, and trackers than they did in 29-inch of 21:9 monitor, not to mention in the Full HD

16:9 monitor. Even in a full screen, 34UM95 can open a proportionately large tracker editing window and activate up to four Cubase VST windows(100% size) at the same time

(while 29EA73 previously could open up to four windows in 65~70% size), and also 34UM65 allows to use 18 more multi-controllers at 100% size ratio than 27inch 16:9 ratio conventional monitor when using MIDI sequencer programs such as logic X.

2

Get the Ultra-fast and Ultrasimple from Thunderbolt™ 2

Thunderbolt™ 2 is a revolutionary cable technology that simultaneously supports high-resolution displays and high-performance data devices through a single, compact port. With 34UM95’s Thunderbolt™ 2 technology, sound editors can take advantage of data transfer speeds up to 20 Gbps and easily expand computing capability by connecting up to six devices via simple daisy-chain configuration. Now sound editors can connect Mac Pro® and storage device to the monitor simultaneously through Thunderbolt™ 2.

3

Offering the Upgraded Multi-In/out port

Offers up to four USB ports, two HDMI ports and a Displayport. Provides In-out ports that can support almost any studio equipment.

Provides external audio interface, master keyboard, synthesizer and controller console. The most efficient tool for professional editors who wanted more connection ports on their PC for their MIDI devices when composing.

W hy 34UM65?

1

21:9 Optimal Ratio for Sequencing

The 34 inch wide screen comes in 21:9 ratio, which is the best to work on horizontal trackers. This allows the user to activate far more

Virtual input devices(*VST) and loops with trackers than they did with Full HD 16:9 monitors. Unlike conventional monitors, the user does not need to drastically minimize trackers or continuously raise and lower the effect preset taskpads.

1

No need to drastically reduce trackers nor raise and lower mixer controllers for mixing and editing.

T

he brand new LG 34-inch 21:9 UltraWide, especially 21:9 UltraWide QHD monitor has returned even more powerfully. Compared to the UltraWide 21:9 Full

HD monitor (29EB73), the previous version of 21:9 UltraWide monitor series,

34UM95 becomes bigger and wider in both vertical and horizontal ways, so that this 34UM95 allows the user to activate far more video footages and effect presets with trackers than they did in 29-inch of 21:9 monitor, not to mention in the Full HD 16:9 monitor. Even in a full screen, user can enjoy the sharpest picture quality on the biggest screen. With a resolution supported by UltraWide

QHD technology, the 3440x1440 UltraWide QHD display offers pixel area, that is about 1.8 times larger than 21:9 UltraWide Full HD monitor and is about 2.4 times larger than a 16:9 Full HD monitor.

27inch 16:9

1 Track for Editing

2 VST for

Composit for ion

Composition

VS.

L

evel controller and input devices(real instrument) were the most important for MIDI composition. As

Miguel mentioned previously, however, most composing tools nowadays provide virtual instrument(*VST) and virtual level controllers. That means it is better to activate a tracker and a

VST or virtual level controllers at one sight in a single screen.

1 Track for Editing

1 volume level for Editing

2 VST for

Composition

2 Controller for Composition

F

or the same reason, 34UM65 is a still perfect choice for the sound editors who are looking for 21:9

UltraWide Full HD monitors in a bigger screen. Compared to the conventional

16:9 screen, 34UM65 can open a proportionately large tracker editing window and activate up to four

Cubase VST windows(70% size) at the same time. Now, 34UM65 allows you to edit and compose all at once on one screen when using MIDI sequencer programs such as X2 or

Cubase providing multiple VST*Plugin for composing with a minimal effort of playing real instrument.

User does not need to drastically reduce trackers nor raise and lower mixer controllers for mixing and editing.

34UM95

UI : Cubase 8

* Activating track,VST,level,controller at one screen with 100% size ratio, and results may vary by user’s environment.

* 21:9 Screen or 3440x1440 (60Hz) resolution may not be available depending on contents, device, interface or graphic card

2

View More Tracks, Use More Virtual Controller & Mixer

2

1:9 UltraWide monitor is always a right choice for sound editors who are mixing and producing sound sources on the sequencing programs like Pro Tools. It is much better to view more sequences and tracks horizontally as it means they can work on more time-tracks. With more time of tracks and more controllers, both 34UM95 and 34UM65 wins over 27” 16:9 Full HD monitor while they do not have to repeat activating or deactivating virtual mixer controller task pad any more. While the conventional 27” 16:9 Full

HD shows only 3 minute-long sound track, 34UM95 can open a proportionately larger editing window up to 5 minutes at 100% size ratio and 34UM65 with 4 minute-long one.

Track time and number of controllers comparison on a single screen

Comparative experiment was conducted under all other things being equal .

9 instrument track

5min11sec

49 controllers

4min11sec

6 instrument track

39 controllers

34” 21:9 QHD (34UM95)

* This comparison is tested internally under same condition, but results may vary by user’s environment.

* 21:9 Screen or 3440x1440 (60Hz) resolution may not be available depending on contents, device, interface or graphic card

34” 21:9 Full HD (34UM65)

3min11sec

21 controllers

27” 16:9 Full HD (“A”

brand)

3

Thunderbolt™ 2

= USB 3.0 x 4 times Faster

T

hunderbolt™ 2 is a revolutionary cable technology that simultaneously supports highresolution displays and high-performance data devices through a single, compact port. With

34UM95’s Thunderbolt™ 2 technology, sound editors can take advantage of data transfer speeds up to 20 Gbps and easily expand computing capability by connecting up to six devices via simple daisy-chain configuration. Now sound editors can connect Mac Pro® and storage device to the monitor simultaneously through

Thunderbolt™ 2.

“No Need to Confine Yourself to Mac Display

Even Without Extra Thunderbolt™ Connector!”

Many sound editors most likely had to choose Mac display because conventional monitors do not have Thunderbolt™ port and require an additional Thunderbolt™ connector. However,

34UM95 provides a Thunderbolt™ port that is compatible with Mac devices and editing tools for Mac OS. Now, sound editors can freely use the high capacity sound sources(Virtual instruments) and the Mac OS sequencing software.

* A daisy-chain configuration may not be available depending on PC performance, interface or graphic card.

4

Connectivity as Strong as

an Audio Interface

3

4UM95 is a very efficient tool which

S

upporting one 3.0 USB (1up/1down) and two 2.0 USB (2down), 34UM95 has In-out ports that are as diverse and allows users to connect various input strong as ports on PCs for composition devices such as master keyboard and or audio interfaces. Most users feel that synthesizers directly into the monitor there are not nearly enough USB ports ports, instead of to connect to their PC to support all their composing devices, or audio interface. This minimizes data which usually consist of a master latency caused by audio interface. keyboard, synthesizer, mixer console, external audio interface, monitoring speaker, monitoring headphone and other in/output devices.

Get the idea!

Exceptional Experience with Two 34UM95 monitors!

M

ost editors use a double- or triple-monitor setting as they want to work on wider track task pad. For sound editors’ work environment, this simulation gives an amazing two-monitor setting idea that they can think of.

Two 34UM95 setting is especially attractive with Thunderbolt™ 2 because of super-fast data transferring and super-simple connection via simple daisy-chain configuration. When

27” 16:9 Full

HD two-monitor only shows up to 7 minute-long, two 34UM95s would allow 40% more room for trackers up to 10 minutes, which is a huge impact in sound-editing work.

First monitor: 34UM95 Second monitor: 34UM95

Fully stretch the work track for editing

Up to

10min 20sec

in 100% size ratio

External storage

* 21:9 Screen or 3440x1440 (60Hz) resolution may not be available depending on contents, device, interface or graphic card

“Two 27” 16:9 ratio monitor shows

ONLY up to

6min 50sec.”

New

Mac Pro®

Plus Tips !

Comfort eyes with Flicker Safe certified by TUV

IPS display has flicker safe function, which stops invisible black bars from flashing continuously on the screen. This greatly reduces optical strain for pro sound editors, who work long hours staring at the monitor.

Certified as “Flicker Free” by

TUV (LG IPS Monitors)

January 2014

LG monitors with Flicker Safe feature provides stable image regardless user’s brightness & frequency control.

Conventional

Monitors

Conventional Monitors: The darker the Screen, the more flicker.

IN-DEPTH INTERVIEW

Darren, Video Editor

Age 33

Usage software :

Final cut PRO / Adobe Aftereffect etc

Usage Device :

Two 27” Mac display with Mac Pro® / Master keyboard /

PROMISE Pegasus2 / etc.

N

owadays, instead of Adobe’s sequencing program, we prefer Final

Cut Pro, which is for Mac OS only.

That’s why the Mac Pro® is a “musthave” equipment in the video editing industry. That’s also the reason why we use Thunderbolt display monitors.

There are bigger displays that provide a higher definition with 21:9 aspect ratio, but most of them are incompatible with

Mac Pro. Also, most of them require an additional thunderbolt connector, do not provide high quality pictures above Full

HD, and require HDMl Ports, which are slow in display data t ransmission…We’ would rather not have them at all.

The biggest reason why I use a 27 inch display on two-monitor setting is because it enables horizontal track processing. Sure, there’s no problem when I’m working on a commercial song that’s about a minute long,

When I’m working on a movie or a T.V. program that is over two hours long, I have to keep adjusting the length of the track. That’s a major strain on the eyes.

That means I have to keep activating and deactivating the track and effect plug-in too. The screen ratio is small, so it’s nearly impossible to work on more than two task pads.”

We also do motion-graphics, which is needed for post-production with Adobe

After Effects. So when we do the effecting jobs, we use two monitors; one for Final Cut, and the other for After

Effects.

: From the In-depth interview note

Summary

Q. What does he

USE

?

Finalcut PRO AVID Premiere Aftereffect

Vegas™ Pro

Q. What to

SUGGEST for him?

34UM95, 34UM65

Q. How to OFFER ?

If he prioritizes this ………..…………….……. Recommend this!

Using two monitors for long sequencers?

34UM95, 34UM65

Need to transfer the video/sound source for Mac Pro?

34UM95

Looking for QHD-level resolution?

34UM95

* 34UM65 supports

34” 21:9 Full HD (2560x1080) resolution

The Worlds 1

st

34-inch 21:9 UltraWide QHD

(34UM95)

for Professional Video Editor

The brand new LG 21:9 UltraWide QHD monitor provides the best working environment ever while enhancing its screen size to 34-inch.

21:9 UltraWide is always a right choic

e especially for those of customer who requires the horizontal trackers

and activating all the mixers or controllers at the same time.

W hy 34UM95?

1

Worlds first 34-inch 21:9 UltraWide QHD monitor

The brand new LG 34-inch 21:9 UltraWide QHD monitor has returned even more powerfully. Compared to the 21:9 UltraWide Full HD monitor (29EA73), the previous version of 21:9 UltraWide monitor series, 34UM95 becomes bigger and wider in both vertical and horizontal ways, so that this powerful monitor allows the user to activate more video footages and effect presets with trackers than they did in 29-inch of 21:9 monitor, not to mention in the 16:9 Full HD monitor. Even in a full screen, user can enjoy the sharpest picture quality on the biggest screen. With a resolution supported by UltraWide QHD technology, the

3440x1440 UltraWide QHD display offers pixel area, that is about 1.8 times larger than 21:9 UltraWide Full HD monitor and is about 2.4 times larger than 16:9

* 21:9 Screen or 3440x1440 (60Hz) resolution may not be available depending on contents, device, interface or graphic card

Full HD 16:9 monitor.

2

Get the Thunderbolt™ 2 All the Way Work

Thunderbolt™ 2 of 34UM95 is a revolutionary cable technology that simultaneously supports high-resolution displays and high-performance data devices through a single, compact port. Especially for video editors, 34UM95’ s Thunderbolt™ 2 technology gives the advantage of faster transfer speeds up to 20

Gbps and easier expand computing capability by connecting up to six devices via simple daisy-chain configuration. Now video editors can connect New Mac

Pro® and storage device to the monitor simultaneously through Thunderbolt

™ 2 and run Final Cut Pro with big video sources from their storage device.

* A daisy-chain configuration may not be available depending on PC performance, interface or graphic card.

3

Utilize 7wx2 Built-in Stereo Speakers as Monitoring Speaker

Video editors rarely need to do delicate sound design but sometimes required to do preliminary sound editing or monitor the accuracy between video and sound at the same time. So they do not required to equip an super expensive external speakers like sound designer/editors but it still in needed for reasons.

Thus, 34UM95 is a perfect solution for video editors while providing powerful sound coming from the two 7W built-in stereo speakers.

W hy 34UM65?

1

21:9 Optimal Ratio for Sequencing

The 34 inch wide screen comes in 21:9 ratio, which is the best to work on horizontal trackers. This allows the user to activate far more video footages and effect presets with trackers than they did with 16:9 Full HD monitors. Unlike conventional monitors, the user does not need to drastically minimize trackers or continuously raise and lower the effect preset taskpads.

* 21:9 Screen or 2560x1080 (60Hz) resolution may not be available depending on contents, device, interface or graphic card

2

Utilize 7wx2 Built-in Stereo Speakers as Monitoring Speaker

Video editors rarely need to do delicate sound design but sometimes required to do preliminary sound editing or monitor the accuracy between video and sound at the same time. So they do not required to equip an super expensive external speakers like sound designer/editors but it still in needed for reasons.

Thus, 34UM65 is a perfect solution for video editors while providing powerful sound coming from the two 7W built-in stereo speakers.

1

Optimal Ratio for Horizontally-long Track

34-inch 21:9 series becomes BIGGER and WIDER in both vertical and horizontal ways than ever before!

T

he 34 inch wide screen comes in 21:9 ratio, which is the best to work on horizontal trackers. This allows the user to activate far more video footages and effect presets with trackers than they did with

16:9 monitors. Unlike the users of 27inch

16:9 monitors,

34UM95’s users do not need to drastically minimize trackers or

Under the same size thumbnail setting condition(50% size height), 34UM95s clips show up to 8 more than 27inch

16:9 monitors.

With a resolution supported by

UltraWide QHD technology, the

3440x1440 UltraWide QHD display offers pixel area, that is about 1.8 continuously raise and lower the effect preset windows.

With more work spaces,

Keep focusing on your work!

times larger than 21:9 UltraWide Full

HD monitor and is about 2.4 times larger than a 16:9 Full HD monitor.

Mac Finalcut Pro Adobe After Effect

34

” 21:9 QHD (34UM95)

More

Indicator!!

13.5 thumbnails

21.5 thumbnails

8 more clips!!

27

” 16:9 Full HD (“A” brand)

34

” 21:9 QHD (34UM95)

* This comparison is tested internally under the same condition, but the number of footages and thumbnail views may change upon on the user’s environment.

2

Work on Both

‘After Effect’ & ‘Finalcut Pro’ at Once

W

e have mentioned in 29EB73’s

B2B Sales Kit that 21:9 monitor enabled to activate both After Effect and Finalcut Pro at once without switching multiple programs over and over again in a single 16:9 screen.

But that’s not the end of the story.

N

ow with 34” of big screen, both 34UM95 and 34UM65 empower the users to activate both programs on a 1:1 ration and at least

30% larger size of the taskpad to prioritize the task progresses than 29EB73, not to mention 16:9 Full HD monitor. This allows convenient and proactive work since users can compare the work done on each program to work simultaneously from

‘editing’ and ‘effecting.’

* 21:9 Screen or 3440x1440 (60Hz) resolution may not be available depending on contents, device, interface or graphic card

3

Get the Thunderbolt™ 2 All the Way Work

Connect Two 34UM95 Monitors by Daisy Chain to New Mac Pro®

34UM95

New Mac Pro®

34UM95

External storage

T

hunderbolt™ 2 of 34UM95 is a

Now video editors can connect New Mac revolutionary cable technology that simultaneously supports high-resolution

Pro® and storage device to the monitor simultaneously through Thunderbolt displays and high-performance data devices and run Final Cut Pro with big video through a single, compact port. Especially for sources from their storage device. video editors, 34UM95’ s Thunderbolt™ 2

™ 2 technology gives the advantage of faster transfer speeds up to 20 Gbps and easier expand computing capability by connecting up to six devices via simple daisy-chain configuration.

4

Utilize 7wx2 Built-in Stereo Speakers

as Monitoring Speaker

V

ideo editors commonly do the sound editing works too while do their job because sound usually comes over video and they need to monitor the sound to check the flow goes well. For that reason, most video sequencers provide sound trackers separated from video trackers.

Since they are not the sound editor, however, they do not require to equip an expensive monitoring speakers. Thus,

34UM95 and 34UM65 are a perfect solution for video editors while providing powerful sound coming from the two

7W built-in stereo speakers.

Plus Tips !

34UM65

Comfort eyes with Flicker Safe certified by TUV

IPS display has flicker safe function, which stops invisible black bars from flashing continuously on the screen. This greatly reduces optical strain for pro video editors, who work long hours staring at the monitor.

Certified as “Flicker Free” by

TUV (LG IPS Monitors)

January 2014

LG monitors with Flicker Safe feature provides stable image regardless user’s brightness & frequency control.

Conventional

Monitors

Conventional Monitors: The darker the Screen, the more flicker.

* A daisy-chain configuration may not be available depending on PC performance, interface or graphic card.

5

Versatile Connectivity

The monitor has been upgraded to support more diverse In/Out connections, including Display port

/HDMI/USB3.0.

This allows users to connect various devices such as monitoring display/ roll keyboard/ monitoring headphones and speakers/ external hard drives without having to form an additional hub.

34UM95

IN-DEPTH INTERVIEW

Damien , Photographer

Age 39

Usage software :

Capture One / Adobe Photoshop

Usage Device :

5D Mark3 - Eizo ColorEDGE

27(Capture Monitor)

/ iMac27(re-touching)

/ etc.

I

have many kind of cameras with me, but primarily use 5D Mark III. Yes- it is quiet expensive, but I think it is definitely worth to invest, and I believe most of photographers would understand why.

The most important thing I always focus on is to get the subject as much as it is, so that I can share what I feel throughout the lenses with my audiences.

However, I cannot pass my feelings on audience only with the high-quality camera. Here comes why I need great display monitors. What if the monitor cannot show the whole color space that my 5D Mark III caught? No way!

In that sense, I am also very picky to choose the monitors as much as to choose cameras in order to review and retouch my pictures. It should cover over

99% of Adobe RGB color space with 10 bit color depth in super-high resolution display. It would be a plus if it is easily connecting to Mac devices while I am usually dealing with Mac for high resolution images.

W

hen I work on an image that is vertically long at Photoshop,

I need to adjust the size of photos.

While working on, adjusting the sizes to optimized ratio is really annoying for me.

Oh, you know what? I do not use dual monitors. This might be a personal preference, but as I mentioned, because I need to review and retouch images at the same time, it is annoying me to set the same color space between two monitors.

Yes, I calibrate on a regular basis, so it would be great if the monitor itself came with a specific preset option. That would really reduce the hassle. The monitor calibration function is really limited and unreliable, so I calibrate using other external products such as spider.”

: From the In-depth interview note

Summary

Q. What does he

USE

?

Paintshop Pro Capture one Photoshop

Q. What to

SUGGEST for him?

27MB85Z

Q. How to OFFER ?

If he prioritizes this ………..…………….……. Recommend this!

• Extremely sensitive with color expression so that looking for a hardware calibration and factory calibrated monitor?

27MB85Z

• Need to transfer massive media data among Camera/ Mac Pro/ Storages?

ColorPrime Monitor

(27MB85)

for Professional Photographer

A device for a true professional photographer. Provides total color management with

Software, Hardware Calibration

and Adobe RGBs color

space and 10 bit color depth .

W hy 27MB85?

1

Total Color Management for Professional Photographer

For professional photographers, who is very sensitive about color, 27MB85 is a musthave monitor as the name of “ColorPrime” represents.

27MB85Z supports AdobeRGB 99% color space as well as 10 bit color depth and accuracy on a 2560x1440 WQHD resolution, 4 times of HD, along with IPS picture quality. Thanks to the specialized color expression, the user is able to display pictures taken by professional cameras such as 5D Mark3 on monitors without experiencing color degradation and by extension color distortion. The monitor itself is equipped with a built-in Scaler and True Color Pro software to directly adjust the color settings to a user defined set point

2

Advanced Picture Quality and Wide color gamut

27MB85Z keeps the ColorPrime series alive! As a series of ColorPrime and as a followup model of 27EA83, the “Best Photo Monitor 2013” of

TIPA Award, 27MB85 proudly presents a new level of viewing pleasure with 2560x1440 WQHD resolution over IPS’s outstanding picture quality. LG IPS monitor has won several prestigious awards for its utmost picture quality. It is the perfect solution for those who need the most lifelike color expression, which brings the original image alive to the screen.

3

Outstanding Work Performance via Thunderbolt™ 2

(27MB85Z)

Thunderbolt™ 2 is a revolutionary cable technology that simultaneously supports high-resolution displays and high-performance data devices through a single, compact port.

With Thunderbolt™ 2 technology, users can take advantage of transfer speeds up to 20 Gbps and easily expand computing capability by connecting up to six devices via simple daisy-chain configuration. Connecting MB85Z simply with Thunderbolt port would allow users to freely use outstanding Mac apps for image viewing and photo editing, such as Capture One. Now users con connect

New Mac Pro® laptop and storage device to the monitor simultaneously through Thunderbolt™ and run Photoshop with high resolution images from the storage device.

1

Total Color Management for Pr ofessional Photographer

S

ince 27MB85Z itself is equipped with a built-in

Scaler and True Color Pro software to directly adjust the color settings to a user defined set point, the photographers can enjoy the color expression without experiencing color degradation and color distortion. By conducting calibration test from the production line, it gives assurance about color accuracy. All of which prevents gaps in color space and expressions between the original photo shot images, monitor screen and the printed result.

(Optional)

Adobe RGB99% sRGB99%

27MB85

F

or professional photographers, who is very sensitive about color, 27MB85 is a must-have monitor as the name of “ColorPrime” represents. 27MB85Z supports AdobeRGB over 99% color space as well as 10 bit color depth and accuracy on a 2560x1440 WQHD resolution, 4 times of HD, along with IPS picture quality.

Most photographers’ major interest is that how same the printout image comes out with the pictures taken by professional cameras such as 5D Mark3.

Printed Output Picture on MB85Zs display

Original picture on DSLR

27MB85

2

Advanced Picture Quality and Wide Color Gamut

27MB85Z keeps the ColorPrime series alive! As a series of ColorPrime and as a follow-up model of

27EA83, the “Best Photo Monitor 2013” of TIPA Award, 27MB85 proudly presents a new level of viewing pleasure with 2560x1440 WQHD resolution over IPS’s outstanding picture quality. LG IPS monitor has won several prestigious awards for its utmost picture quality. It is the perfect solution for those who need the most lifelike color expression, which brings the original image alive to the screen.

Full HD with Non IPS Display

WQHD combined with IPS (27MB85)

3

Fast & Easy Editing via

Thunderbolt™ 2

2

Maximized Ergonomics

For Convenience

27MB85Z has a pivot function that enables to photographer rotate origin pictures up to 90 degrees depending on the ratio of the work space. They do not have to reduce size of image, or drag and scroll the vertically long image all the way down any more.

E

specially for Photographer, Thunderbolt

™ 2 technology gives the advantage of faster transferring high resolution image files up to 20

Gbps and easily expand computing capability by connecting up to six devices via simple daisychain configuration. Connecting MB85Z with

Thunderbolt port would allow photographers to freely use outstanding Mac apps for image viewing and photo editing. Now professional photographers can connect New Mac Pro® laptop and storage device to the monitor simultaneously through Thunderbolt™ and run Photoshop with high resolution images from the storage device.

Transferring

‘RAW’ format origin image

27MB85

27MB85

* The display supports 10-bit color over DisplayPort

* Dual Link-up requires specific combination of HDMI/DisplayPort/DVI-D(Dual link) connection with each device.

* Hardware Calibration requires True Color Finder (Only compatible with Windows XP/7/8 by DisplayPort; Windows 7/8 by Thunderbolt; or New Mac Pro® by DisplayPort/Thunderbolt), and compatible calibrator (not included).

Plus Tips !

Comfort eyes with Flicker Safe certified by TUV

IPS display has flicker safe function, which stops invisible black bars from flashing continuously on the screen. This greatly reduces optical strain for photographers, who work long hours staring at the monitor.

Certified as “Flicker Free” by

TUV (LG IPS Monitors)

January 2014

LG monitors with Flicker Safe feature provides stable image regardless user’s brightness & frequency control.

Conventional

Monitors

Conventional Monitors: The darker the Screen, the more flicker.

IN-DEPTH INTERVIEW

Emily , Graphic Designer

Age 29

Usage Softeware :

Adobe Photoshop/ Illustrator / InDesign / etc

Usage Device :

Two 27-inch Monitors / WACOM Intuos4 12*19

M

ost graphic work takes me more than one tool. Most of graphic designers like me would prefer a multimonitor environment, and I use two 27

” monitors side by side as well. As you probably know, you can switch layers among Adobe graphic tools by dragging and dropping, so we use more than one graphic tool on each monitor.

Hmm.. One case I use two monitors side by side is when I open Photoshop on one monitor and the Illustrator on the other. Or, I use two monitors when

I need graphic tools like Photoshop and Illustrator for 2D graphics as well as InDesign for editorial. I use one monitor to work on the graphic design, and then I drag the work layer over to the other monitor screen, where the

InDesign program is active. That’s where I work on the visual, layout and text altogether.

In that case, however, it makes me bother that color tones are slightly different between two monitors even if the monitors are same models from same brand. For that reason, I always need to spend some times to adjust the two as same as possible.

The other case of using two monitors side by side is when I work drawing on an horizontally-long image. I use both monitors as a single drawing board, but in such case, the bezels inbetween two screens also bother me to focus on my work

….”

: From the In-depth interview note

Summary

Q. What does she

USE

?

Photoshop Indesign

CorelDraw

Illustrator

Q. What to

SUGGEST for her?

34UM95, 34/29/25UM65,

29UB65, 27MB85Z/R

Q. How to OFFER ?

If he prioritizes this ………..…………….……. Recommend this!

• Struggling with your small work space?

34UM95

34/29/25UM65,

29UB65

• Doing a lot of vertically long graphic work?

29UB65

• Working on graphic for ‘print’, so you need to be sensitive about color accuracy?

27MB85Z/R

* Recommend to offer 21:9 UltraWide series depending on the customer’s preference on the size of monitor.

27MB85

Optimal Work Space with Richer

Color Experience

for Professional Graphic Designer

21:9 UltraWide ratio is a perfect choice for graphic designers

while having optimal productive work space as well as experiencing richer colors.

The minimalistic Ltype stand design (only for 29UM65) will

also satisfy their aesthetic taste and inspire

creativity into them .

W hy 34UM95, 34/29/25UM65, and 29UB65?

1

Horizontally Perfect

34UM95, 34/29/25UM65, and 29UB65

:Optimal Work Space for Graphic Designing with 21:9 UltraWide Ratio

Most of 2D designers widely use programs that are provided by Adobe-Photoshop, Illustrator, InDesign, etc,. Users drag and drop subjects to alter subject layers or exchange images side by side while activating Photoshop and Illustrator together, usually on a two monitor setting. With a 21:9 UltraWide monitor, however, users can keep track of the workspace and tool bar and also can simultaneously activate two different tools just like a two monitor setting without having the bezel or other color coming in between the monitors.

21:9 is also optimal ratio f or working on horizontally long images as well. Most graphic designers work on Photoshop or Illustrator for various sizes of graphic design. In the case of wider books, the 21:9 aspect ratio monitor allows all sizes, an all types of tools can be activated. The expected outcome can be verified perfectly in a single monitor without having to scroll or downsize. Also, the short screen ratio may have the user continuously selecting & deselecting the anchor of the pen tool option on the Illustrator’s taskpad. However, 29UM65 and 25UM65

’ s wide ratio display eliminates the need for this tedious task.

* Offer the appropriate model depending on the customer’s personal preference on the size of the monitor.

2

Vertically Perfect

29UB65

:Optimal Work Space in Any Form of Artwork

“Pivot”, Newly added in 2014, maximizes work efficiency for those of doing graphic work on vertical frames such as web/magazine editors and bloggers. The vertical layout of 21:9 pivot monitor is more convenient with its wider screen than 16:9. Simply rotate the screen as needed and view the display without scrolling. The height adjustment feature adds convenience.

* 21:9 Screen or 2560x1080 (60Hz) resolution may not be available depending on content, device, interface or graphic card.

W hy 27MB85?

1

Total Color Management for Professional Graphic Designer

27MB85Z supports a resolution of WQHD and 99% of AdobeRGB with 10 bit color depth and accuracy. With a built-in Scaler and True

Color Pro software, 27MB85Z adjust the color settings to a user defined set point without experiencing color degradation and by extension color distortion. By conducting calibration test from the production line, it gives assurance about color accuracy. All of which prevents gaps in color space and expressions between the original images, monitor screen and the printed result. This definitely supports enhanced efficiency by saving time and process which would suitable for the professionals.

27MB85R supports sRGB over 99% color space with color calibration solution called, True Color Finder. 27MB85R would be recommended to web designers or semi-professional graphic designers who normally use sRGB color space rather than AdobeRGB or composing at all.

Advanced Picture Quality and Wide color gamut

2

27MB85Z keeps the ColorPrime series alive! As a series of ColorPrime and as a followup model of 27EA83, the “Best Photo Monitor

2013” of TIPA Award, 27MB85 proudly presents a new level of viewing pleasure with 2560x1440 WQHD resolution over IPS’s outstanding picture quality. LG IPS monitor has won several prestigious awards for its utmost picture quality. It is the perfect solution for those who need the most lifelike color expression, which brings the original image alive to the screen.

Outstanding Work Performance via Thunderbolt

™ 2

(27MB85Z)

and Mini Display Port

(27MB85R)

3

MB85Z comes with Thunderbolt port, which allows the user to directly connect Mac and storage devices. Thunderbolt2 is unique interface that can transfer data, video, audio simultaneously with super fast speed of 20Gbps. It helps creative professionals who have to works with huge multi-media data efficiently. MB85R supports miniDP which is widely adopted by major graphic cards instead of

Thunderbolt™ 2.

The Perfect Choice for Graphic Editing

The brand new LG 21:9 UltraWide QHD monitor 34UM95 brings

the most efficient environment for graphic editing programs. 21:9

UltraWide screen displays all the editing image, tools, and program menus in 100% view without overlapping whereas 27” 16:9 screen displays only up to 66.7% view with editing tools over the images.

Thus, graphic editors enjoy working on QHD images without scrolling or zooming in and out while editing with the 34UM95.

34UM95 is especially perfect for web graphic designers as it

supports sRGB over 99% color space Since website has sRGB color space, 34UM95’s sRGB color space with 3440x1440

UltraWide

QHD resolution on IPS’s lifelike picture quality all together optimize web graphic designers’ working environment.

* 21:9 Screen or 3440x1440 (60Hz) resolution may not be available depending on contents, device, interface or graphic card

34UM95

1

Drawing and Painting at once

W

hen working with both Photoshop and

Illustrator activated on a conventional 16:9 two-monitor setting, it is common for one workspace to move into the other monitor due to changes in image size. Here, the bezel between the monitors or slight discrepancy in color temperature and resolution between the monitor can cause a gap, undermining accurate image work.

However, the user can activate both programs on a single screen using

34UM95, 34/29/25UM65, and 29UB65, which is horizontally wide with a ratio of

21:9.

This allows fast and efficient work without any of the discomfort that comes from using a two-monitor setting. Work is especially tedious for most designers who use a tablet pen on a monitor smaller than 25 or 29 inches. They have to cut their strokes(pen tool’s anchor), and it is hard for them to take in all their workspace. Therefore 21:9

UltraWide monitor series are the best display device for graphic work.

2

Optimal

Work Space in Any Form of Artwork

25UM65

29UM65

* 21:9 Screen or 3440x1440 / 2560x1080 (60Hz) resolution may not be available depending on content, device, interface or graphic card.

29UB65

2

9UB65 has a wide 21:9 ratio display, which is the best for 2D design. It especially comes with a 90’ pivot function for designers who work on design and vertical magazine editing. This provides the best setting for work, as designers do not need to reduce a vertical image to work on a horizontal display.

Tip!

By activating more than two Adobe tools on one screen, users can drag and drop objects to exchange them or their layers, capitalizing on Adobe’s high compatibility. This way, the user does not need to constantly change the ratio of the workspaces.

27MB85

3

Advanced Color Management

For Outstanding Output

M

B85Z supports AdobeRGB 99% and 100% sRGB color space as well as

10 bit color depth and accuracy on a 2560x1440 WQHD resolution, 4 times of HD, along with IPS picture quality.

It can display most images on

Photoshop or InDesign in color that is close to the standard. Even when printing middle or large sized images bigger than A1 size, the monitor can minimize the color difference between the image on display and image that is printed.

This ensures optimum graphic output.

Close to origin color value

M

B85Z, it had already got preset at factory and software calibration on display. It provides “Color Calibrated” and “External calibration” to keep the standard color value. This prevents gaps in color space and expressions between the original images, monitor screen and the printed result.

.

I

n the end, this also enables longterm color modification without the aid of additional calibrator or calibration software such as Spider. This definitely supports enhanced efficiency by saving time and process which would suitable for the professionals. Besides that, MB85R has no calibrator preset options.

(Optional)

Adobe RGB99% sRGB 100%

27MB85

Plus Tips !

Comfort eyes with Flicker Safe certified by TUV

IPS display has flicker safe function, which stops invisible black bars from flashing continuously on the screen. This greatly reduces optical strain for graphic designers, who work long hours staring at the monitor.

Certified as “Flicker Free” by

TUV (LG IPS Monitors)

January 2014

LG monitors with Flicker Safe feature provides stable image regardless user’s brightness & frequency control.

Conventional

Monitors

Conventional Monitors: The darker the Screen, the more flicker.

IN-DEPTH INTERVIEW

Tina, Office manager

Age 37

Usage software :

MS Office(Excel, Powerpoint, Word,

Outlook etc)

Usage Device :

LG Z360 Ultra PC, / 24” Monitor

I

am working at a law firm from 9 a.m. to 6 p.m., Monday through Friday. I do most of my job on MS Office programs such as Outlook, Document,

PowerPoint, and Excel to place in order and Internet Explorer. You can sometimes find me in the reception room for consulting my clients, but most likely

I spend time in my room, sitting at the desk and reading a bunch of stuffs all day long. For that reason, even if I have a Ultra PC for easy to carry around, I also must have a dual screen monitor on the side at my desk. I have one 24” monitor for dual screen and review financial statements, or presentation documents .... You know- that kind of stuff.

I think I usually keep 7 to 8 programs activated on the screen all at the same time, and I am super fast at switching programs as I got used to do so.

H

owever, switching many programs are still tired for me as well. Especially when I need to compare or contrast document while reading texts, I go crazy to switch programs over and over again. Also, when I have to have above10 or more programs all together, I can’t manage them all at the same time. In that case, I thought myself having second monitor sometimes.”

: From the In-depth interview note

Summary

Q. What does she

USE

?

MS Office

MAC Number

MAC Keynote

MAC Page

Q. What to

SUGGEST for her?

34UM65 / 29UM65 / 25UM65 / 29UB65

/ 24MB65PY / 24MB35PY

Q. How to OFFER ?

If he prioritizes this ………..…………….……. Recommend this!

• Operating a bunch of applications at once, so that can’t manage them

34UM65,

29UM65, 29UB65,

all at the same time?

25UM65

(Recommend to offer 21:9 UltraWide series depending on the customer’s preference on the size of monitor.)

• Need to adjust stand height?

29UB65,

24MB65PY, 24MB35PY

• Avoid all the complexity but seek the best efficiency and practicability?

24MB65PY, 24MB35PY

(24MB65PY and 24MB35PY represent a selected size of MB65 and MB35 series respectively.)

* 21:9 Screen or 2560x1080 (60Hz) resolution may not be available depending on content, device, interface or graphic card.

Perfect Multitasking Monitor for Office manager

Make Life Easier!

21:9 UltraWide ratio gives you more advantages than conventional 16:9 monitor.

This will help your

work efficiency from multitasking

that conventional 16:9 ratio screen cannot provides. Also it will maximize your satisfaction with its amazing ultra-high picture quality.

29UB65

W

hy 34/29/25UM65 and 29UB65?

1

A New Efficient Multitasking Environment with 21:9 UltraWide Ratio

21:9 ratio provides a better environment for multitasking in comparison to conventional 16:9 monitors. Users will see the full lengths of spreadsheets, and be able to research in a separate window, spaciously located beside it. MS Word, for example, 34UM65 is possible to activate up to four 100% view pages on one screen without making any reductions. Of course, the horizontally long ratio makes it possible to activate Powerpoint and Excel on the same scale to drag and drop objects between programs, expediting the process. Maximize work efficiency and eliminate scrolling and window switching.

* 21:9 Full Screen or 2560x1080 resolution may not be available depending on content, device, interface or graphic card.

2

All about ‘Convenience’

With a 21:9 wide screen ratio, now users can multitask with 4 programs on one screen at the same time. This 4-Screen Split feature conveniently divides the monitor screen from 2 to 4 customizable subscreens of preferred size, without any overlapping of windows. Compatible with Mac®, it provides 8 different screen ratios, changeable by a single click and increases not only user’s convenience but also productivity. 4-

Screen Split software includes an auto-fitting function. With a simple drag or a double click, a new window will automatically fit into the marginal room of the screen. Also with the Dual Link-up feature, that allows an HDMI+HDMI link, users can display two devices simultaneously on a single screen. Now one user and the other can simply bring each other’s devices and connect to a single monitor to share and compare information.

* 4-Screen Split software requires DVI-D(Dual link), DisplayPortor HDMI connection with Windows XP/Vista/7/8 or Mac OS® X 10.7 (Lion)/10.8(Mountain Lion)/10.9(Mavericks).

* Dual Link-up requires specific combination of HDMI/DisplayPort/DVI-D(Dual link) connection with each device.

3

Comfort Eyes with Flicker Safe Certified by TUV and Reader Mode

Protect eyes from exhausting flickers and blue lights. LG’s new Flicker Safe system is always on to reduce the flicker level to almost-zero. In addition, activate the Reader Mode to minimize harmful blue lights with a simple touch of a hot-key. Spend as long as you want working without burdening your eyes.

W

hy 29UB65?

1

Maximized Ergonomics for the Best Convenience

Like other smart devices, the 29UB65’s Pivot&Height Adjustable feature allows user to simply rotate the screen to fit vertically long images or files. When pivoting, user can easily adjust its height too. Leave dragging and scrolling behind.

* Recommend to offer 21:9 UltraWide series depending on the customer’s preference on the size of the monitor.

W

hy 24MB65PY and 24MB35PY?

1

Best Viewing Pleasure with Eye-care Features

The monitor is designed to help office managers who must process large amounts of text documents at their desk. For these managers,

24MB65PY offers a Flicker Safe Function which eliminates the consistent flicker (invisible to the naked eye) on the screen. And, the Reader Mode automatically modifies colors into softer tones so that looking at screens is no more tiring than reading a book. This minimizes the fatigue that builds up in office managers. Also specially, B2B(Business to Business) monitor such as 24MB65PY/24MB35PY designed not to shining glass or steel material, it’s not reflect light, so that looking at monitor is no more tired.

2

Ergonomic design for office workers

The user can adjust the tilt angle from -5’ to +30’, and the height from 50mm to 130mm(24MB35PY : 5’ to +20’, and the height from 100mm to 120mm).

This enables the user to adjust the monitor settings according to their preference.

3

16:10 ratio for advanced document work *

MB65 Only

While most monitors have 16:9 ratio, 24MB65PY has 16:10. The user is able to activate A4 size Word documents (the most common format in document processing) on a 1:1 scale. This prevents the text from getting cut, helps the user type accurately and quickly, and refer to other documents with ease.

4

Upgraded usability

The display port has up to three USB ports, so the user can connect mouse, keyboard and other office devices. This makes it possible for the office manager to set up office devices according to their style and working environment.

5

Eco-friendly work environment

The monitor has a Super Energy Saving Hotkey, which reduces electricity consumption. The more monitors an office has, the more it can benefit from this function in efficiency and economic feasibility.

* 24MB65PY and 24MB35PY represent a selected size of MB65 and MB35 series respectively.

* Recommend to offer the series depending on the customer’s preference on the size and specification of the monitor.

1

34/29/25UM65 and 29UB65

Ultimate Multitasking Powerhouse

T

he 21:9 ratio’s spacious working environment, convenient features (4-Screen Split

and Dual Link-up) and even eye comfort features (Flicker Safe and Reader Mode)

…..!!

All together are best companion of office workers, and everything comes out in

21:9 UltraWide monitor series.

Certified as “Flicker Free” by TUV

(LG IPS Monitors January 2014)

25UM65

34UM65

29UM65

2

Eye Comfort Display

Certified by TUV

Certified as “Flicker Free” by TUV

(LG IPS Monitors)

January 2014

2

014 New LG 24MB65,24MB35 monitor

A

lso, the Reader Mode automatically including 21:9 UltraWide monitor series are modifies colors into softer tones so that designed to ease the eyes of office looking at screens is no more tiring than managers who must process large reading a book. This minimizes the fatigue amounts of text documents at their desk. that builds up in office managers. Protect

Flicker Safe function supported eyes from exhausting flickers and blue

24MB65/24MB35 that is certified as

“Flicker Free” by TUV, is always on to lights! reduce the flicker level to almost zero.

3

16:10 ratio for advanced documentation work

W

hile most monitors have 16:9 ratio,

Conventional 16:9 monitor

24MB65PY has 16:10. The user is able to activate A4 size Word documents (the most common format in document processing) on

100% ratio A4 Size document

a 1:1 scale. This prevents the text from getting cut, helps the user type accurately and quickly, and refer to other documents with ease.

Some part of doc be cut

100% ratio A4 Size document

2

Tinting : -5 to +30

5

Upgraded usability

6

Eco-friendly display

Height : 50mm to 130mm

24MB65PY/24MB35PY has up to three USB ports, so the user can connect mouse, keyboard and other office devices.

24MB65PY/24MB35PY has a Super

Energy Saving Hotkey, which reduces electricity consumption. The more monitors an office has, the more it can benefit from this function in efficiency and economic feasibility.

2Up 1Down

4

24MB65PY

Ergonomic design and upgraded usability for office worker

T

he user can adjust the tilt angle from -5’ to +30’, and the height from 50mm to 130mm (24MB35PY : 5’ to +20’, and the height from 100mm to 120mm). This enables the user to adjust the monitor settings according to their preference.

This ergonomic design was specially created in regards to the long, sedentary work style that office managers are accustomed to.

IN-DEPTH INTERVIEW

Serena, Stock manager

Age 34

Usage software : HTS(Home Trading

System)/MS Office /Intranet

Usage Device :

23” D Monitor*6

W

e have to manage each desktop and each monitor separately, so sometimes it is hard to tell which desktop is connected to which monitor. That’s because we installed monitors that are same in size ratio without regarding priority, so it is inevitable.

Y

es, I use six 23 inch monitors from D brand. Of course, all the monitors show

This is complicated because when we different contents. Okay, the upper three activate the trade window or intranet monitors show me monthly trend, market simultaneously on one monitor, we can’t status and favorite stocks. The lower three see the tiny numeric data. This is critical show the daily trend, which is the most because we need these programs to important real-time trade and our intranet

…pivot does not necessarily make split-second decisions. There’s nothing much we can do about that, required for me because most of stock because it may complicate our work trading data is in horizontal shape, but I even further. ” think I somewhat need tilt and height to adjust.

Of course, window activation changes according to the situation, but that is the basic layout . Yes, it is hard to track all these numbers simultaneously. And you can’t stare at them all day either, because they cause headaches and even nausea.

As we use six computers, we do not have a graphic card that supports all of them.

Therefore, we connect them to two desktops. This can sometimes cause a problem.

: From the In-depth interview note

Summary

Q. What does she

USE

?

HTS (Home Trading System)

Q. What to

SUGGEST for her?

34UM65 / 29UB65/ 29UM65

24MB65PY / 24MB35PY

Q. How to OFFER ?

If he prioritizes this ………..…………….……. Recommend this!

• Struggle with multi-monitor and dealing with horizontally long data?

34UM65, 29UB65,

29UM65

(Recommend to offer 21:9 UltraWide series depending on the customer’s preference on the size of monitor.)

• Avoid all the complexity but seek the best efficiency and practicability for your multi-monitor environment?

24MB65PY, 24MB35PY

(24MB65PY and 24MB35PY represent a selected size of MB65 and MB35 series respectively.)

* 21:9 Full Screen or 2560x1080 resolution may not be available depending on content, device, interface or graphic card.

Best Work Companion

for Stock Manager

W

hy 34UM65 / 29UB65 / 29UM65?

1

A New Efficient Multitasking Environment with 21:9 UltraWide Ratio

21:9 ratio provides a better environment for multitasking in compare to conventional 16:9 monitors. Stock managers will see the full lengths of year stock data graphs, and be able to research in a separate window, spaciously located beside it. Especially, If the 34UM65, 29UB65, or 29UM65 is replaced for the main monitor, it would be effective for using the HTS (Home Trading System) program and the intranet messenger or real-time stock order taskpad. It also promises faster action and more efficient trading. Thanks for 21:9 ratio wide display, you can more focus on your work without missing critical information. It is all about

‘Work Performance.” In a financial office, work meetings are held in conference rooms several times a day. The data most frequently used are daily and monthly trade volume charts, which are drawn horizontally. 34UM65’s 21:9 ratio wide screen can display all these data without reducing them or cutting them off. The user no longer needs to display sheets at a reduced ratio. The wide viewing angle of 178’/178’ gives managers a clear view of the data images and monthly trade volume chart texts without any distortions. In addition, the monitor can be wall-mounted without a stand, depending on the design of the office environment.

* 21:9 Full Screen or 2560x1080 resolution may not be available depending on content, device, interface or graphic card.

2

Comfort Eyes with Flicker Safe Certified by TUV and Reader Mode for in a Multi-monitor Environment

The monitor is designed to help stock managers who must work long hours at their desk, constantly looking at four or monitors filled with stock data . For these managers, the monitor offers a Flicker Safe Function which eliminates the consistent flicker in the screen. Also, the Reader Mode automatically modifies colors into softer tones so that looking at screens is no more tiring than reading a real-document. This minimizes the fatigue that builds up in stock managers.

W

hy 29UB65 ?

1

Best Convenience from Maximized Ergonomics: Only for 29UB65

The stock manager can adjust the tilt angle from -5 to +15 degrees and the height up to 110mm. This ergonomics helps the stock manager who may easily feel tired of its pre-settled ergonomics while adjusting the 29UB65 settings according to their preference for working long hours staring at the monitor.

* Recommend to offer 21:9 UltraWide series depending on the customer’s preference on the size of the monitor.

W

hy 24MB65PY and 24MB35PY?

1

Build a optimum Multi-Monitor system without eye strain

The monitor is designed to help stock managers who must work long hours at their desk, constantly looking at four or monitors filled with complicated stock datas and HTS taskpads. For these managers, the monitor offers a Flicker Safe Function which eliminates the consistent flicker in the screen. Also, the

Reader Mode automatically modifies colors into softer tones so that looking at screens is no more tiring than reading a real-document. This minimizes the fatigue that builds up in stock managers. Also specially, B2B(Business to Business) monitor such as 24MB65PY/24MB35PY designed not to shining glass or steel material, it’s not reflect light, So that looking at monitor is no more tiring.

2

Ergonomic design for Stock manager

The monitor is designed to help stock managers who must work at divided multi-monitor environment.

The stock manager can adjust the tilt angle from -5’ to +30’, and the height from 50mm to 130mm(24MB35PY : 5’ to +20’, and the height from 100mm to 120mm). This enables the stock manager to adjust the monitor settings according to their preference of multi-monitor environment

3

16:10 ratio for advanced document work *

MB65 Only

While most monitors have 16:9 ratio, 24MB65PY has 16:10. The user is able to activate A4 size market condition chart document on a 1:1 scale.

This prevents the stock data from getting cut, helps the user type accurately and quickly, and refer to other documents with ease.

* 24MB65PY and 24MB35PY represent a selected size of MB65 and MB35 series respectively.

* Recommend to offer the series depending on the customer’s preference on the size and specification of the monitor.

1

34UM65/ 29UB65 / 29UM65

Manage Your Work Efficiency

Daily chart & Real time price

Priority stock list &

Stock order browser

Activating Multi-HTSs Taskpad on One Screen

N

ow, the stock manager can activate the daily trade volume chart, real-time trading window and intranet messenger all at the same time on a wide, 21:9 ratio display. They can use the

UltraWide monitor as a main console, and having all the important data on one screen helps the managers make rational and quick decisions.

The data most frequently used are daily and monthly trade volume charts, which are drawn horizontally. 21:9

UltraWide screen can display them all data without reducing or cutting off.

Furthermore, 21:9 UltraWide monitor series including 34UM65,

29UB65, and 29UM65 is designed to help stock manager who works long hours at their desk, constantly looking at monitors filled with stock data. 21:9 UltraWide series’ Flicker

Safe on IPS display technology and Reader mode function automatically modifies colors into softer tones so that looking at screens is no more tired. This minimizes the tiredness that stacked with stock managers.

Plus Tips !

Comfort eyes with Flicker Safe certified by TUV

IPS display has flicker safe function, which stops invisible black bars from flashing continuously on the screen. This greatly reduces optical strain for stock traders, who work long hours staring at the monitor.

Certified as “Flicker Free” by

TUV (LG IPS Monitors)

January 2014

LG monitors with Flicker Safe feature provides stable image regardless user’s brightness & frequency control.

Conventional

Monitors

Conventional Monitors: The darker the Screen, the more flicker.

3

24MB65/ 24MB35

Optimum Multi-Monitor System Without Eye Strain

New LG B2B monitor series including 24MB65 and 24MB35 are designed to ease the eyes of stock managers, who must work long hours at their desk, constantly looking at four or more monitors filled with data.

LG’s new

Flicker Safe that is certified as “Flicker Free” by TUV, is always on to reduce the flicker level to almost zero. In addition, the Reader Mode automatically modifies harmful blue lights into softer tones so that looking at screens is no more tiring than reading a book. Protect eyes from exhausting flickers and blue lights!

Daily, Weekly, Monthly, Yearly chart Stock Analysis

Certified as “Flicker Free” by TUV

(LG IPS Monitors)

January 2014

Stock Analysis

Daily Chart Order Taskpad Stock Price

: MB85Z for Medical Consulting

1

Specialized ‘Gamma’ Preset

For Clinical Consulting

H

ospitals, healthcare centers requires a lot of displays that can express medical images correctly, even it is not an medical display so that users can check MRI or CT scans. Displays in hospitals do not need to express a wide range of colors. Rather, hospital displays need to show clear contrast so that doctors can discern the difference between muscles, bone, fat and blood.

Today, DICOM standard is widely accepted as the standard for medical display monitors. However, medical monitors that can express DICOM gamma tend to be far more expensive than others. Therefore, it is difficult for clinics and educational institutions to purchase a large number of these screens. Only major hospitals and university hospitals can afford these monitors.

MB85Z/R supports DICOM Simulation preset and also the True Color Pro calibration SW supports DICOM correction. Therefore user can calibrate the display according to the DICOM gamma standards whenever they want. This enables MB85Z to display medical images such as MRIs and X-rays with accuracy and clarity. As it comes at a reasonable price compared to diagnostic DICOM Display and has equivalent color display, MB85Z is an attractive option for healthcare clients

* MB85 is not a medical-certified equipment and cannot be used for diagonal purpose.

Selective color mode UI*

MB85Z : Use the DICOM Simulation preset

Conventional display

3. Certification Standard

Certification Standard

Safety standard

Electromagnetic

compatibility

UL

TUV

CB

FCC-B

CE

KC

Energy standard

EPA (6.0)

ROHS

REACH

34UM95 34UM65 29UM65 25UM65 29UB65 27MB85 24MB65PY 24MB35PY

(Mar/End)

(Mar/End)

● ● ●

● ● ● ●

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

Certification Standard_34UM95

Certification Standard_34UM65

Certification Standard_29UM65

Certification Standard_25UM65

Certification Standard_29UB65

Certification Standard

24MB65

24MB35

4. Appendix

Appendix. Upgraded Dual Link-Up Function: System Requirement for 34UM95

‘13

UltraWide QHD

3440X1440

UltraWide Full HD

2560X1080

PBP

Combination

HDMI1

Main (Left)

HDMI1 HDMI2 DP DVI

X

X

Sub

(Right)

HDMI2

DP

DVI

X

X

-

X

X

-

X

29EA73, 29EB73

‘14

Main (Left)

PBP

Combination

HDMI1 HDMI2 DP

HDMI1 -

Sub

(Right)

HDMI2

DP X

Thunder

-bolt

X

-

X

X

-

X

Thunder

-bolt

X

-

34UM95

PBP

Combination

Main (Left)

HDMI1 HDMI2 DP

HDMI1 -

● ●

Sub

(Right)

HDMI2

DP

DVI

-

X

-

UM65 Series, 29UB65

DVI

X

-

Appendix. Compatibility : System Requirement for 34UM95

Key requirement is PC graphic card performance. It depends on what resolution PC graphic card supports

(at least 3440X1440 must be supported). You may need to enforce custom settings from the graphic card control panel or update to the latest graphic card driver at the graphic card manufacturers' website.

Win

OS

UM95

Resolution support

(3440x1440

Graphic card

Intel

AMD

HD4400

HD7000

Thunderbolt

60hz

60hz

Interface to Monitor

Displayport

60hz

60hz

NVIDIA

Geforce 650 or higher 60hz

60hz

UM95 Graphic card

Thunderbolt

Interface to Monitor

Displayport

Mac

OS

Resolution support

(3440x1440

AMD

Dual AMD

FirePro

D300 or

D500 or

D700

60hz

New Mac Pro®

60hz

* For connection with Mac® , Thunderbolt cable

1)

, HDMI to HDMI cable is required.

* The Thunderbolt to Ethernet Adapter

2)

lets you easily connect to a high-performance Ethernet network. It connects to the Thunderbolt port on UM95

* Daisy-Chain(MST : Multi Stream Transport) connect two high-resolution 34UM95 monitor to New Mac Pro®

HDMI

50hz

50hz

50hz

HDMI

50hz

Appendix. Compatibility : System Requirement for 34UM95

4-Screen Split software is required to install, and the software CD is packed with monitor.

Once it is installed, the tray menu is created on your PC.

Interface to Monitor

UM95

Thunderbolt Displayport HDMI

Calibration Software

(True Color Finder) support

Win PC

Mac* o o o o o o

O/S Version

Displayport/HDMI : XP/Vista/Win7/Win8

Thunderbolt : Win7/8

New Mac Pro®

Calibration Software (True Color Finder) with 34UM95 is available after installation of software CD, that is packed with monitor.

Connecting 34UM95 to PC via HDMI may not result in exact value when calibrating even if it is still running True Color Finder.

Compatible OS for True Color Finder are XP/WIN7/WIN8, and Mac® .

Interface to Monitor

UM95

O/S Version

Thunderbolt Displayport HDMI

Calibration Software

(True Color Finder) support

Win PC

Mac* o o o o x x

DisplayPort: XP/Win7/Win8

Thunderbolt : Win7/8

New Mac Pro®

Appendix. Compatibility : System Requirement for 34UM95

Key requirement is PC graphic card performance. It depends on what resolution PC graphic card supports

(at least 2560X1080 must be supported). You may need to enforce custom settings from the graphic card control panel or update to the latest graphic card driver at the graphic card manufacturers' website

UM65

UB65

Intel

Graphic card

DVD-I (Dual Link)

O

Interface to Monitor

Display port

O

Resolution support

(2560x1080)

AMD

NVIDIA

HD3000 or higher

HD54XX/64XX/77XX or higher

GeForce 300 or higher

O

O

O

O

* You may be required to enforce custom settings from the graphic card control panel or update to the latest graphic card driver.

* For HDMI connections with Mac® , 2560 x 1080 resolution is not available.

* For connection with Mac® , Mini-DP to DVI-D(Dual)/DisplayPort/HDMI adapter(cable), HDMI to HDMI cable is required.

Mini-DP to DVI-D(Dual) adapter

HDMI

O

O

O

Mini-DP to

Thunderbolt

Mini-DP to HDMI

4-Screen Split software is required to install, and the software CD is provided with the product.

When the software is installed, the tray menu is created on your PC.

Interface to Monitor

UM65

UB65

DVD-I (Dual Link) Display port HDMI

4-Screen Split support

Win PC

Mac*

O

O

O

O

O

O

XP/Vista/Win7/Win8

10.7(Lion)/10.8(Mountain Lion)/10.9

Appendix. Compatibility : System Requirement for 27MB85

Window

Resolution support

(2560x1080)

Intel

AMD

NVIDIA

Graphic card

Over HD4400

Over HD7000

Over GTX 650

Thunderbolt ( )

O

-

-

HDMI

O

Interface to Monitor

DP or Mini DP (DisplayPort)

O

O

O

O

O

DVI-D

O

O

O

* Thunderbolt ( ) is supported in Windows 7, Windows 8 or later.

* In order to set the resolution to 2560 x 1440, you may be required to configure the custom settings from the graphics card control panel or update to the latest graphics card driver.

* Using the full 2560 x 1440 resolution requires a DVI-D Dual cable. * Support settings are subject to change.

MAC

Intel

Graphic card

Over HD4400

Thunderbolt ( )

O

HDMI

O

Interface to Monitor

DP or Mini DP (DisplayPort)

O

AMD

Over HD7000

O O

Resolution support

(2560x1080)

NVIDIA

Over GTX 650

O O

* Thunderbolt ( ) is supported in Mac OS 10.9.1 or later.

* You can connect (daisy-chain) up to two additional monitors through the Thunderbolt ( ).

* In order to set the resolution to 2560 x 1440, you may be required to configure the custom settings from the graphics card control panel or update to the latest graphics card driver.

* Using the full 2560 x 1440 resolution requires a DVI-D Dual cable. * Support settings are subject to change.

O

O

DVI-D

O

O

O

Appendix. Compatibility : System Requirement for 27MB85

- Usage: The monitor displays screens for 2 input sources simultaneously.

* To use the Dual Link-up feature, one of the two inputs must be connected via DP (DisplayPort) or Thunderbolt

(27MB85Z)/Mini DP (27MB85R).

Window

Main screen (Left)

DVI-D

HDMI

DP

TBT(27MB85Z) mDP(27MB85R)

DVI-D

-

X

O

O

O

HDMI

X

-

O

O

O

Sub screen (Right)

DP

O

O

-

X

X

TBT(27MB85Z)

O

O

X

-

X mDP(27MB85R)

O

O

X

X

-

MAC

Main screen (Left)

DVI-D

HDMI

DP

TBT(27MB85Z) mDP(27MB85R)

DVI-D

-

X

O

O

O

HDMI

X

-

O

O

O

Sub screen (Right)

DP

O

O

-

X

X

* DP : DisplayPort/ TBT : Thunderbolt / mDP : Mini DisplayPort

* For details on using the software, refer to the product user manual.

* The product user manual is included on the CD provided and is available for download from the LG Electronics website.

TBT(27MB85Z)

O

O

X

-

X mDP(27MB85R)

O

O

X

X

-

Appendix. Intuitive and Convenient Control

It shows all display content in one sight without overlapping the display contents. The use of a joystick key has enabled faster OSD control by its intuitive convenience.

Free to be overlapped with the display contents

OK

Left / Right

Intuitive Control by Joystick

Up / Down

New 5:9 Extra View

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
