TRENDnet User’s Guide
Contents
t ....................................................................................................... 1
Product Overview ............................................................................ 5
Features ...................................................................................................................5
TV‐IP420P
System – System Settings ..................................................................................... 16
Basic Information .......................................................................................... 16
Time Settings ................................................................................................. 17
DST ................................................................................................................ 18
Package Contents ....................................................................................................5
Configuring RS‐485 ........................................................................................ 18
Open the cover ........................................................................................................6
System – Maintenance ......................................................................................... 19
Reset Button ............................................................................................................6
Upgrade & Maintenance ............................................................................... 19
.................................................................................................................................6
Log ................................................................................................................. 20
Cables ......................................................................................................................6
System Service .............................................................................................. 20
SD Card Slot .............................................................................................................6
Security Audio Log......................................................................................... 21
Warnings..................................................................................................................7
System – Security ................................................................................................. 22
Cautions ...................................................................................................................7
Authentication .............................................................................................. 22
Plan for installation location ............................................................ 8
IP Filter .......................................................................................................... 22
Viewing angle ..........................................................................................................8
Security Service ............................................................................................. 23
Weather Conditions.................................................................................................8
Advanced Security ......................................................................................... 23
Cabling .....................................................................................................................8
System – User Management ................................................................................ 24
Waterproof cap .......................................................................................................8
User Management ........................................................................................ 24
Live View ......................................................................................... 9
Online Users .................................................................................................. 24
Live View ..................................................................................................................9
Network – Basic Settings ...................................................................................... 25
Toolbar ............................................................................................................ 9
TCP/IP ............................................................................................................ 25
PTZ................................................................................................................. 10
DDNS ............................................................................................................. 26
Live View Quick Setup ................................................................................... 13
PPPoE ............................................................................................................ 26
Playback ................................................................................................................ 14
Port................................................................................................................ 27
Picture .................................................................................................................. 14
NAT ................................................................................................................ 27
Configuration ..................................................................................15
Multicast ....................................................................................................... 28
Local...................................................................................................................... 15
Network – Advanced Settings .............................................................................. 29
© Copyright 2021 TRENDnet. All Rights Reserved.
2
TRENDnet User’s Guide
TV‐IP420P
SNMP............................................................................................................. 29
Clear Config ................................................................................................... 49
Email.............................................................................................................. 30
Prioritize PTZ ................................................................................................. 49
Platform Access ............................................................................................. 31
Event – Basic Event ............................................................................................... 50
HTTPS ............................................................................................................ 32
Motion Detection .......................................................................................... 50
QoS ................................................................................................................ 33
Video Tampering ........................................................................................... 52
802.1x ............................................................................................................ 34
Configuring Alarm Input ................................................................................ 53
Integration Protocol ...................................................................................... 34
Configuring Alarm Output ............................................................................. 53
Network Service ............................................................................................ 35
Exceptions ..................................................................................................... 54
HTTP Listening ............................................................................................... 35
Event – Smart Event ............................................................................................. 55
Video/Audio.......................................................................................................... 36
Audio Exception Detection ........................................................................... 55
Video ............................................................................................................. 36
Intrusion Detection ....................................................................................... 56
Audio ............................................................................................................. 38
Line Crossing Detection................................................................................. 57
ROI ................................................................................................................. 39
Region Entrance Detection ........................................................................... 59
Display Info on Stream .................................................................................. 40
Region Exist Detection .................................................................................. 60
Image .................................................................................................................... 40
Unattended Baggage Detection .................................................................... 60
Display Settings ............................................................................................. 40
Object Removal Detection ............................................................................ 62
OSD Settings .................................................................................................. 43
Storage – Schedule Settings ................................................................................. 63
Image Parameters Switch ............................................................................. 44
Record Schedule............................................................................................ 63
PTZ ........................................................................................................................ 45
Capture.......................................................................................................... 65
Basic Settings ................................................................................................ 45
Storage – Storage Management ........................................................................... 66
Limit .............................................................................................................. 46
HDD Management ........................................................................................ 66
Initial Position ............................................................................................... 46
Net HDD (NAS) .............................................................................................. 66
Park Action .................................................................................................... 47
Storage – Advanced Settings ................................................................................ 68
Privacy Mask ................................................................................................. 47
FTP ................................................................................................................. 68
Schedule Tasks .............................................................................................. 48
Appendix ....................................................................................... 70
Scheduled Tasks ............................................................................................ 48
Direct video access ‐ RTSP .................................................................................... 70
© Copyright 2021 TRENDnet. All Rights Reserved.
3
TRENDnet User’s Guide
TV‐IP420P
Regulations .....................................................................................70
Federal Communication Commission Interference Statement ................................ 70
RoHS .................................................................................................................... 70
Europe – EU Declaration of Conformity ............................................................... 71
Limited Warranty ............................................................................72
© Copyright 2021 TRENDnet. All Rights Reserved.
4
TRENDnet User’s Guide
Product Overview
TV‐IP420P
Package Contents
TV‐IP420P package includes:
• TV‐IP420P
• Quick Installation Guide
• Camera mounting hardware
(Optional power adapter not included)
Drilling Template
Features
TRENDnet’s Indoor/Outdoor 3MP Motorized PTZ Dome Mira IP Camera,
model TV‐IP420P, provides PTZ and powerful 3MP resolution in low‐light
environments. This PTZ IP camera delivers year‐round surveillance with an
IP66 weather rated housing to withstand harsh outdoor environments. Use
the included complimentary Mira software and mobile apps to view live video
up to 350° with the motorized pan tilt function.
© Copyright 2021 TRENDnet. All Rights Reserved.
Mounting Screws
Network Cable
Waterproof Accessories
If any package content is missing or damaged, please contact the retail store, online
retailer, or reseller/distributor from which the product was purchased.
5
TRENDnet User’s Guide
TV‐IP420P
Open the cover
Cables
Loosen the mounting plate screws and base screws, twist the bottom housing
to open.
Alarm line in, line out
and grounding wires
RS‐485 wires
Reset Button
Push and hold the reset button then power on the camera. Keep holding the
reset button for more than 10 seconds to reset configuration to factory
default.
Network cable
connection
SD Card Slot
SC Card slot is located on the other side from the reset button. Insert a SD
card up to 128G for local storage.
SD card slot
© Copyright 2021 TRENDnet. All Rights Reserved.
Reset Button
6
TRENDnet User’s Guide
TV‐IP420P
Warnings
Cautions
Serious injury or death may be caused if any of these warnings are neglected.
Follow these safety guards to prevent serious injury or death.
Injury or equipment damage may be caused if any of these cautions are
neglected. Follow these precautions to prevent potential injury or material
damage.
• If using the power adapter, please choose the power adapter that
meets the safety extra low voltage (SELV) standard or IEC60950‐1 and
Limited Power Source standard.
• If the product does not work properly, please contact your dealer or
the nearest service center. Never attempt to disassemble the camera
yourself. Disassembling the product will void the warranty and may
cause harm or injury.
• To reduce the risk of fire or electrical shock, do not expose this product
to rain or water.
• The installation should be done by a qualified service person and
should conform to all construction and electric regulations and other
local codes.
• Make sure the power supply voltage is correct before using the Camera.
• Do not drop the camera or subject to physical shock.
• Do not touch sensor modules with fingers. If cleaning is necessary, use
a clean cloth with a bit of ethanol and wipe it gently. If the camera will
not be used for an extended period of time, put on the lens cap to
protect the sensor from dirt.
• Do not aim the camera lens at the strong light such as the Sun or an
incandescent lamp. Strong light can damage the camera sensor.
• The sensor may be burned out by a laser beam, so when any laser
equipment is being used, make sure that the surface of the sensor will
not be exposed to the laser beam.
• Do not place the camera in extremely hot, cold temperatures (the
operating temperature should be between ‐10°C to 60°C), dusty or
damp environment, and do not expose it to high electromagnetic
radiation.
• To avoid heat accumulation, good ventilation is required for a proper
operating environment.
• Keep out of water and any liquid.
• While shipping, the camera should be packed in its original packing.
© Copyright 2021 TRENDnet. All Rights Reserved.
7
TRENDnet User’s Guide
Plan for installation location
Viewing angle
The TV‐IP420P is a dome camera with varifocal lens that provides non‐
distorted and detailed images. Choose the location where has good angle to
shoot the image you expect to see. The motion detection area should also be
considered when installing the camera.
Weather Conditions
The TV‐IP420P is a dome camera, which fits most installations indoor and
outdoor. The camera can work under a wide range of weather conditions.
For severe weather conditions, a camera housing with temperature and
moisture control is recommended. Using the camera in milder weather
conditions will help extend the camera’s product life and preserve the quality
of the video image.
• Moisture: Avoid damp or moist environments whenever you can. The
TV‐IP420P is an IP66 grade, IK10 water proof camera, and it will work
in moist environments. However, rain may affect the picture quality,
especially at night, water may reflect the light from the infra‐red
illumination and degrade picture quality.
• Temperature: TV‐IP420P works within a specified temperature range.
Areas with severe temperatures should be avoided when installing the
camera. It’s recommended that you use an enclosure with a heater and
blower if you plan on using this camera outside of the specified
temperature range.
© Copyright 2021 TRENDnet. All Rights Reserved.
TV‐IP420P
• Sunlight: Avoid direct sun light exposure. Direct sun light will damage
the image sensor. If sunlight is necessary for your viewing purposes,
provide protection for the image sensor.
• Lighting: Consider installing your camera faces the same direction of
the light sources. Shooting images with top‐down position outdoor or
next to the existing light source are good choices. Avoid the light source
if it creates a shade that darkens the viewing area.
Cabling
It’s recommended that the wiring the cable in your home or office by a
professional. If you already have the cable deployed, make sure the cable and
the connectors meet the category 5 Ethernet cable standards. At least 2 pairs
of twisted lines are required for power and data. Poor cable quality may cause
unexpected problems. Testing your cable or running a new cable is suggested
for new camera installation.
Waterproof cap
The camera itself is IP66 grade water and dust proof. There is a set of network
cable water proof caps that comes with the package as well. Run your cable
going through the accessories, and then crimp the cable with an RJ45 module.
Plug in the network cable and then tighten the waterproof cap to prevent
water running into camera through the cable.
8
TRENDnet User’s Guide
Live View
Use Mira app or VMS to activate and setup the camera, if you would like to
access camera’s configuration page, please find the camera IP from Camera
Utility or Mira VMS to access it.
TV‐IP420P
Menu Bar:
Click each tab to enter Live View, Playback, Picture, and Configuration page
respectively.
Live View Window:
Live View
Display the live video.
The live view page allows you to view the real‐time video, capture images,
and configure video parameters. Log in the network camera to enter the live
view page, or you can click Live View on the menu bar of the main page to
enter the live view page.
Toolbar
Toolbar allows you to adjust the live view window size, the stream type, and
the plug‐ins. It also allows you to process the operations on the live view page,
e.g., start/stop live view, capture, record, audio on/off, two‐way audio,
start/stop digital zoom, etc.
For IE (Internet Explorer) users, plug‐ins as webcomponents and quick time
are selectable. And for Non‐IE users, webcomponents, quick time, VLC or
MJPEG is selectable if they are supported by the web browser.
Note:
For camera that supports plug‐in free live view, when Google Chrome 45 and
its above version or Mozilla Firefox 52 and its above version are used, plug‐in
installation is not required. But Picture and Playback functions are hidden. To
use mentioned function via web browser, change to their lower versions, or
change to Internet Explorer 8.0 and its above version.
© Copyright 2021 TRENDnet. All Rights Reserved.
9
TRENDnet User’s Guide
/
TV‐IP420P
Start/Stop live view.
PTZ
4:3 window size.
On the live view page, click next to the right side of the live view window to
16:9 window size.
show the PTZ control panel and click
Original widow size.
Click the direction buttons to control the pan/tilt movements.
to hide it.
Self‐adaptive window size.
Original ratio window size.
,
, etc.
Live view with the different video streams.
Click to select the third‐party plug‐in.
Manually capture the picture.
Manually start/stop recording.
Click the zoom/focus/iris buttons to realize lens control.
1. There are eight direction arrows ( ,
,
,
,
,
,
,
) in the
control panel. Click the arrows to realize adjustment in the relative
positions.
© Copyright 2021 TRENDnet. All Rights Reserved.
10
TRENDnet User’s Guide
TV‐IP420P
2. For the cameras which support lens movements only, the direction
3. Setting a Preset
buttons are invalid.
Icon
Use the PTZ control buttons to move the lens to the desired
position
Description
Zoom in/out
Focus near/far
Iris +/‐
PTZ speed adjustment
Light on/off
Wiper on/off
Auxiliary focus
Initialize lens
Adjust speed of pan/tilt movements
Start Manual Tracking
Start 3D Zoom
© Copyright 2021 TRENDnet. All Rights Reserved.
‐
Pan the camera to the right or left
‐
Tilt the camera up or down
‐
Zoom in or out
‐
Refocus the lens
‐
Click
‐
You can click
to finish the setting of the current preset.
to delete the preset.
11
TRENDnet User’s Guide
4. Calling a Preset
‐
This feature enables the camera to point to a specified preset scene
TV‐IP420P
5. Setting / Calling a Patrol
Please setup at least 2 presets before setting up a patrol.
Steps:
manually or when an event takes place.
‐
‐
For the defined preset, you can call it at any time to the desired
‐
Click
preset scene.
‐
Select a path No., and click
In the PTZ control panel, select a defined preset from the list and
‐
Select the preset, and input the patrol duration and patrol
click
‐
to enter the patrol configuration interface.
to add the configured presets.
speed.
to call the preset.
Or you can place the mouse on the presets interface, and call the
‐
Click OK to save the first preset.
preset by typing the preset No. to call the corresponding presets.
‐
Follow the steps above to add the other presets.
‐
Click OK to save a patrol.
‐
Click
‐
(Optional) Click
© Copyright 2021 TRENDnet. All Rights Reserved.
to start the patrol, and click
to stop it.
to delete a patrol.
12
TRENDnet User’s Guide
TV‐IP420P
Live View Quick Setup
scene. This makes it possible to see the detail of the image that
It allows quick setup of image/video related parameters on live view page.
would normally be hidden.
Steps:

1. Click
OSD
Set text information displayed on screen. Alignment adjustment is
button on the right of the live view window to show the PTZ
available for Text Overlay. Save the settings after configuration.
control panel. Click
to hide it.

2. Specify PTZ, Display, OSD and Video/Audio and VCA resource
Resolution and Max. Bit rate are adjustable. Click
parameters. For more settings, go to Configuration > Image and
Display Settings

Scene: Select a scene according to actual installation
environment. (Only certain camera models support.)

WDR: The WDR (Wide Dynamic Range) function helps the
camera provide clear images even under back light
to
change stream.
Configuration > Video/Audio.

Video/Audio

VCA Resource
VCA Resource offers options to enable certain VCA functions and
hide others. It helps allocate more resources to the wanted
functions. A reboot is required after setting the VCA Resource.
Note:
circumstances. When there are both very bright and very dark
areas simultaneously in the field of view, WDR balances the

models.
brightness level of the whole image and provide clear images
with details. You can enable or disable the WDR function and
set the level.

VCA Resource function varies according to different camera

VCA options are mutually exclusive.

The function may not be supported by some camera models.
HLC: High Light Compensation makes the camera identify and
suppress the strong light sources that usually flare across a
© Copyright 2021 TRENDnet. All Rights Reserved.
13
TRENDnet User’s Guide
TV‐IP420P
Playback
You can playback the video recording on the network storage and download
the video clip and snapshots to your local computer.
You can playback the snapshots on the network storage and download the
images to your local computer.
© Copyright 2021 TRENDnet. All Rights Reserved.
14
TRENDnet User’s Guide
Configuration
TV‐IP420P

Play Performance: Set the live view performance to Shortest Delay,
Balanced, Fluent or Custom. For Custom, you can set the frame rate
Local
for live view.
The local configuration refers to the parameters of the live view, record files

Rules: It refers to the rules on your local browser, select enable or
disable to display or not display the colored marks when the motion
and captured pictures. The record files and captured pictures are the ones
detection, face detection, or intrusion detection is triggered. E.g.,
you record and capture using the web browser and thus the saving paths of
enabled as the rules are, and the face detection is enabled as well,
them are on the PC running the browser.
when a face is detected, it will be marked with a green rectangle on
Steps:
the live view.
1. Enter the Local Configuration interface: Configuration > Local.

Display POS Information: Enable the function, feature information
2. Configure the following settings:
of the detected target is dynamically displayed near the target in the

live image.
Live View Parameters: Set the protocol type and live view performance.

The feature information of different functions is different. For
Protocol Type: TCP, UDP, MULTICAST and HTTP are selectable.
TCP: Ensures complete delivery of streaming data and better video
example, ID and waiting time for Queue Management, height for
quality, yet the real‐time transmission will be affected.
People Counting, etc.
UDP: Provides real‐time audio and video streams.
Note:
HTTP: Allows the same quality as of TCP without setting specific
Display POS Information is only available for certain camera models.
ports for streaming under some network environments.

Image Format: Choose the image format for picture capture.
MULTICAST: It’s recommended to select MCAST type when using
the Multicast function. For detailed information about Multicast,
refer to Section 7.1.1 Configuring TCP/IP Settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
15
TRENDnet User’s Guide

Record File Settings: Set the saving path of the recorded video files. Valid
for the record files you recorded with the web browser.

Record File Size: Select the packed size of the manually recorded and
TV‐IP420P
System – System Settings
Basic Information
downloaded video files to 256M, 512M or 1G. After the selection, the
maximum record file size is the value you selected.

Save record files to: Set the saving path for the manually recorded
video files.

Save downloaded files to: Set the saving path for the downloaded
video files in playback mode.

Picture and Clip Settings: Set the saving paths of the captured pictures
and clipped video files. Valid for the pictures you capture with the web
browser.

Save snapshots in live view to: Set the saving path of the manually
captured pictures in live view mode.



Save snapshots when playback to: Set the saving path of the
captured pictures in playback mode.
In the System Settings, you can edit the Device Name and Device No. Other
Save clips to: Set the saving path of the clipped video files in
information of the network camera, such as Model, Serial No., Firmware
playback mode.
Version, Encoding Version, Number of Channels, Number of HDDs, Number
Note: You can click Browse to change the directory for saving the
of Alarm Input and Number of Alarm Output are displayed. The information
clips and pictures, and click Open to open the set folder of clips and
cannot be changed in this menu. It is the reference for maintenance or
picture saving.
modification in future.
3. Click Save to save the settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
16
TRENDnet User’s Guide
Time Settings
TV‐IP420P
(3) (Optional) You can click the Test button to test the time
synchronization function via NTP server.
Note: If the camera is connected to a public network, you should use a NTP
server that has a time synchronization function, such as the server at the
National Time Center (IP Address: 210.72.145.44). If the camera is set in a
1. Select the Time Zone of your location from the drop‐down menu.
2. Configure the NTP settings.
(1) Click to enable the NTP function.
(2) Configure the following settings:
Server Address: IP address of NTP server.
NTP Port: Port of NTP server.
customized network, NTP software can be used to establish a NTP server for
time synchronization.
 Configure the manual time synchronization.
(1) Check the Manual Time Sync. to enable the manual time
synchronization function.
(2) Click the icon
to select the date, time from the pop‐up calendar.
(3) (Optional) You can check Sync. with computer time item to
Interval: The time interval between the two synchronizing actions
with NTP server.
© Copyright 2021 TRENDnet. All Rights Reserved.
synchronize the time of the device with that of the local PC.
 Click Save to save the settings.
17
TRENDnet User’s Guide
DST
TV‐IP420P
Configuring RS‐485
Daylight Saving Time (DST) is a way of making better use of the natural
daylight by setting your clock forward one hour during the summer months,
and back again in the fall.
Configure the DST according to your actual demand.
Steps:
1. Enter the DST configuration interface.
Configuration > System > System Settings > DST
The RS‐485 serial port is used to control the PTZ of the camera. The
configuring of the PTZ parameters should be done before you control the PTZ
unit.
Steps:
1. Enter RS‐485 Port Setting interface:
Configuration> Advanced Configuration> System > RS‐485
2.
Set the RS‐485 parameters and click SAVE to save the settings.
2. Select the start time and the end time.
3. Select the DST Bias.
Note:
4. Click Save to activate the settings.
The Baud rate, PTZ Protocol and PTZ Address parameters of the speed dome
should be exactly the same as those of the control device.
© Copyright 2021 TRENDnet. All Rights Reserved.
18
TRENDnet User’s Guide
TV‐IP420P
System – Maintenance
This operation requires admin password to proceed.
Upgrade & Maintenance
For the exported file, you also have to create an encryption password.
The encryption password is required when you import the file to other
cameras.
Diagnose Information: click to download log and system information.

Import Config. File
Configuration file is used for the batch configuration of the cameras.
Steps:
The upgrade & maintenance interface allows you to process the operations,

Reboot: Restart the device.

Restore: Reset all the parameters, except the IP parameters and user
information, to the default settings.
Click Browse to select the saved configuration file.
2.
Click Import and input the encryption password that you set during
exporting.
including reboot, partly restore, restore to default, export/import the
configuration files, and upgrade the device.
1.
Note: You need to reboot the camera after importing configuration file.

Upgrade: Upgrade the device to a certain version.
Steps:
1. Select firmware or firmware directory to locate the upgrade file.
Firmware: Locate the exact path of the upgrade file.

Default: Restore all the parameters to the factory default.

Information Export
Firmware Directory: Only the directory the upgrade file belongs to
Device Parameters: click to export the current configuration file of the
is required.
camera.
© Copyright 2021 TRENDnet. All Rights Reserved.
19
TRENDnet User’s Guide
2.
Click Browse to select the local upgrade file and then click Upgrade
TV‐IP420P
System Service
to start remote upgrade.
Note: The upgrading process will take 1 to 10 minutes. Please don't
disconnect power of the camera during the process, and the camera
reboots automatically after upgrade.
Log
System service settings refer to the software and hardware service the
camera supports. Supported functions vary according to the different
cameras. For the cameras support IR LED, ABF (Auto Back Focus), Auto Defog,
or Status LED, you can select to enable or disable the corresponding service
The operation, alarm, exception and information of the camera can be stored
according to the actual demands.
in log files. You can also export the log files on your demand.
1. Set the log search conditions to specify the search, including the Major
Type, Minor Type, Start Time and End Time.
2. Click Search to search log files. The matched log files will be displayed on
the log list interface.
3. To export the log files, click Export to save the log files.
© Copyright 2021 TRENDnet. All Rights Reserved.
20
TRENDnet User’s Guide
Security Audio Log
The Security Audit Log refers to the security operation logs. You can search
and analyze the security log files of the camera so that to find out the illegal
intrusion and troubleshooting the security events.
Security audit logs can be saved on device flash. The log will be saved every
half hour after device booting.
Due to limited saving space of the flash, you can also save the logs on a log
server. Configure the server settings at Advanced Settings.
TV‐IP420P

Searching Logs
1. Enter the Security Audit Log interface:
Configuration > System > Maintenance > Security Audit Log
2. Set the log search conditions to specify the search, including the Major
Type, Minor Type, Start Time and End Time.
3. Click Search to search log files. The matched log files will be displayed on
the Log list interface.
4. To export the log files, click Export to save the log files in your computer.

Setting Log Server
1. Check Enable Log Upload Server.
2. Input Log Server IP and Log Server Port.
3. Click Test to test settings.
4. Install certificates. Client certificate and CA certificate are required.

Client Certificate
(1) Click Create button to create the certificate request. Fill in the
required information in the popup window.
(2) Click Download to download the certificate request and submit
it to the trusted certificate authority for signature.
(3) Install the signed certificate to the device.

CA Certificate
(1) Install the CA certificate to the device.
© Copyright 2021 TRENDnet. All Rights Reserved.
21
TRENDnet User’s Guide
System – Security
TV‐IP420P
IP Filter
Authentication
You can specifically secure the stream data of live view.
1.
Set up authentication method for RTSP authentication and WEB
authentication.
Caution:
1. Check the checkbox of Enable IP Address Filter.
2. Select the type of IP Address Filter in the drop‐down list, Forbidden and
Digest is the recommended authentication method for better data
security. You must be aware of the risk if you adopt basic as the
authentication method.
2.
Click Save to save the settings.
Allowed are selectable.
3. Set the IP Address Filter list.

Add an IP Address
Steps:
(1) Click the Add to add an IP.
(2) Input the IP Adreess.
(3) Click the OK to finish adding.
© Copyright 2021 TRENDnet. All Rights Reserved.
22
TRENDnet User’s Guide

Modify an IP Address
TV‐IP420P
Advanced Security
Steps:
(1) Left‐click an IP address from filter list and click Modify.
(2) Modify the IP address in the text filed.
(3) Click the OK to finish modifying.

Delete an IP Address or IP Addresses.
Select the IP address (es) and click Delete.
4. Click Save to save the settings.
Security Service
Advanced security offers options to manage more network security settings
of the device.

Illegal Login Lock: it is used to limit the user login attempts. Login attempt
Security Reinforce
Security reinforce is a solution to enhance network security. With the
function enabled, risky functions, protocols, ports of the device are
disabled and more secured alternative functions, protocols and ports are
enabled.
from the IP address is rejected if admin user performs 7 failed user
name/password attempts (5 times for the operator/user).
Function
Status
Control Timeout Settings
Enabled
Digest Algorithm
MD5 is disabled. SHA256 is
enabled
Note: If the IP address is rejected, you can try to login the device after 30
minutes.
© Copyright 2021 TRENDnet. All Rights Reserved.
23
TRENDnet User’s Guide
TV‐IP420P
ONVIF
Disabled
TLS
TLS1.1 is disabled. TLS1.2 is
enabled
SDK
SDK Service is disabled. Enhanced
SDK Service is enabled
SNMP
Disabled
RTSP Authentication and HTTP
Authentication
Only digest is supported
HTTPS
Enabled
HTTPS Browsing
Enabled. Accessing the device
can only use HTTPS protocol
IEEE 802.1X
Only EAP‐TLS (TLS1.2) is
supported. The function is
disabled
System – User Management
User Management
The admin user has all permissions by default and can
create/modify/delete other accounts.
The admin user cannot be deleted and you can only change the admin
password.
Notes:
●
Up to 31 user accounts can be created.
●
Users of different levels own different default permissions.
Operator and user are selectable.

Control Timeout Settings
If you enable the function and set timeout period, you will be logged out
when you make no operation to the device via web browser (Viewing
live image and playback are not included.) for the set timeout period.

Algorithm
Displays the currently active digest algorithm. If Security Reinforce is
enabled, MD5 is disabled and SHA256 is enabled instead.
© Copyright 2021 TRENDnet. All Rights Reserved.
Online Users
24
TRENDnet User’s Guide
You can see the current users who are visiting the device through this
TV‐IP420P
1. Configure the basic network settings, including the NIC Type, IPv4 or IPv6
interface. User information, such as user name, level, IP address, and
Address, IPv4 or IPv6 Subnet Mask, IPv4 or IPv6 Default Gateway, MTU
operation time, is displayed in the User List.
settings and Multicast Address.
2. (Optional) Check the checkbox of Enable Multicast Discovery, and then
the online network camera can be automatically detected by client
Network – Basic Settings
TCP/IP
software via private multicast protocol in the LAN.
3. Configure the DNS server. Input the preferred DNS server, and alternate
DNS server.
4. Click Save to save the above settings.
Notes:

The valid value range of MTU is 1280 to 1500.

The Multicast sends a stream to the multicast group address and allows
multiple clients to acquire the stream at the same time by requesting a
copy from the multicast group address. Before utilizing this function,
you have to enable the Multicast function of your router.

© Copyright 2021 TRENDnet. All Rights Reserved.
A reboot is required for the settings to take effect.
25
TRENDnet User’s Guide
DDNS
TV‐IP420P
PPPoE
1. Check the Enable DDNS checkbox to enable this feature.
2. Select DDNS Type. NO‐IP.
1.
Check the Enable PPPoE checkbox to enable this feature.
2.
Enter User Name, Password, and Confirm password for PPPoE access.
Note: The User Name and Password should be assigned by your ISP.

Steps:
For your privacy and to better protect your system against security risks,
we strongly recommend the use of strong passwords for all functions and
(1)
Enter the Server Address as www.noip.com
network devices. The password should be something of your own
(2)
Enter the Domain name you registered.
choosing (using a minimum of 8 characters, including at least three of
(3)
Enter the User Name and Password.
the following categories: upper case letters, lower case letters, numbers
(4)
Click Save and then you can view the camera with the
and special characters) in order to increase the security of your product.
domain name.

Proper configuration of all passwords and other security settings is the
responsibility of the installer and/or end‐user.
3.
© Copyright 2021 TRENDnet. All Rights Reserved.
Click Save to save and exit the interface.
26
TRENDnet User’s Guide
Port
TV‐IP420P
NAT
HTTP Port: The default port number is 80, and it can be changed to any
port No. which is not occupied.
RTSP Port: The default port number is 554 and it can be changed to any
NAT interface allows you to configure the UPnP™ parameters.
port No. ranges from 1 to 65535.
Universal Plug and Play (UPnP™) is a networking architecture that provides
HTTPS Port: The default port number is 443, and it can be changed to
compatibility among networking equipment, software and other hardware
any port No. which is not occupied.
devices. The UPnP protocol allows devices to connect seamlessly and to
Server Port: The default server port number is 8000, and it can be
simplify the implementation of networks in the home and corporate
changed to any port No. ranges from 2000 to 65535.
environments.
With the function enabled, you don’t need to configure the port mapping for
each port, and the camera is connected to the Wide Area Network via the
router.
© Copyright 2021 TRENDnet. All Rights Reserved.
27
TRENDnet User’s Guide
1.
Check the checkbox to enable the UPnP™ function.
TV‐IP420P
Multicast
Note:
Only when the UPnP™ function is enabled, ports of the camera are
active.
2.
Choose a friendly name for the camera, or you can use the default
name.
3.
Select the port mapping mode. Manual and Auto are selectable.
Note:
If you select Auto, you should enable UPnP™ function on the router.
If you select Manual, you can customize the value of the external port
and complete port mapping settings on router manually.
Multicast is group communication where data transmission is addressed to a
group of destination devices simultaneously. After setting up active multicast,
you can send the source efficiently to multiple devices.
1. Enter the Multicast setting interface.
4.
Click Save to save the settings.
Configuration >Network > Basic Settings > Multicast
2. Set IP Address, Stream Type, Video Port, and Audio Port of the camera.

IP Address stands for the address of multicast.

Video port and audio port of each video stream of each camera
channel can be specified by selecting a stream in Video Stream and
inputting port number in Video Port and Audio Port.
3. Click Save to save the settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
28
TRENDnet User’s Guide
Network – Advanced Settings
SNMP
TV‐IP420P
You can set the SNMP function to get camera status, parameters and alarm
related information, and manage the camera remotely when it is connected
to the network.
Before you start:
Before setting the SNMP, please download the SNMP software and
manage to receive the camera information via SNMP port. By setting
the Trap Address, the camera can send the alarm event and
exception messages to the surveillance center.
Note: The SNMP version you select should be the same as that of the
SNMP software. And you also need to use the different version
according to the security level you required. SNMP v1 provides no
security and SNMP v2 requires password for access. And SNMP v3
provides encryption and if you use the third version, HTTPS protocol
must be enabled.
Notes:
•
A reboot is required for the settings to take effect.
•
To lower the risk of information leakage, you are suggested to enable
SNMP v3 instead of SNMP v1 or v2.
© Copyright 2021 TRENDnet. All Rights Reserved.
29
TRENDnet User’s Guide
Email
TV‐IP420P
Email Encryption: None, SSL, and TLS are selectable. When you select
SSL or TLS and disable STARTTLS, e‐mails will be sent after encrypted by
SSL or TLS. The SMTP port should be set as 465 for this encryption
method. When you select SSL or TLS and enable STARTTLS, emails will
be sent after encrypted by STARTTLS, and the SMTP port should be set
as 25.
Note: If you want to use STARTTLS, make sure that the protocol is
supported by your e‐mail server. If you check the Enable STARTTLS
checkbox when the protocol is not supported by your e‐mail sever, your
e‐mail will not be encrypted.
Attached Image: Check the checkbox of Attached Image if you want to
send emails with attached alarm images.
Interval: The interval refers to the time between two actions of sending
Steps:
attached pictures.
1.
Enter the Email Settings interface: Configuration > Network >Advanced
Authentication (optional): If your email server requires authentication,
Settings > Email.
check this checkbox to use authentication to log in to this server and
Configure the following settings:
input the login user name and password.
2.
Sender: The name of the email sender.
Sender’s Address: The email address of the sender.

For your privacy and to better protect your system against security
SMTP Server: IP address or host name (e.g., smtp.263xmail.com) of the
risks, we strongly recommend the use of strong passwords for all
SMTP Server.
functions and network devices. The password should be something
SMTP Port: The SMTP port. The default TCP/IP port for SMTP is 25 (not
of your own choosing (using a minimum of 8 characters, including
secured). And the SSL SMTP port is 465.
at least three of the following categories: upper case letters, lower
© Copyright 2021 TRENDnet. All Rights Reserved.
30
TRENDnet User’s Guide
case letters, numbers and special characters) in order to increase
TV‐IP420P
Platform Access
the security of your product.

Proper configuration of all passwords and other security settings is
the responsibility of the installer and/or end‐user.
Platform access provides you an option to manage the devices via platform.
Steps:
The Receiver table: Select the receiver to which the email is sent. Up to
3 receivers can be configured.
Receiver: The name of the user to be notified.
1. Enter the Platform Access interface.
Configuration > Network > Advanced Settings > Platform Access
Receiver’s Address: The email address of user to be notified.
3.
Click Save to save the settings.
2. Check the checkbox of Enable to enable the platform access function of
the device.
3. Select the Platform Access Mode from the dropdown list.
4. Set the Server IP.
5. Click SAVE to save the settings
© Copyright 2021 TRENDnet. All Rights Reserved.
31
TRENDnet User’s Guide
HTTPS
TV‐IP420P
3. Create the self‐signed certificate or authorized certificate.
Create the self‐signed certificate

(1) Select Create Self‐signed Certificate as the Installation Method.
(2) Click Create button to enter the creation interface.
(3) Enter the country, host name/IP, validity and other information.
(4) Click OK to save the settings.
Note: If you already had a certificate installed, the Create Self‐signed
Certificate is grayed out.
HTTPS provides authentication of the web site and its associated web server,
which protects against Man‐in‐the‐middle attacks.
Create the request and import the authorized certificate

‐
installation as the Installation Method.
Note:
‐

For the camera that supports plug‐in free live view, when you use HTTPS
to visit the camera, you should enable Websockets for live view. Go to
If HTTPS is enable d by default, the camera creates an unsigned
certificate automatically. When you visit the camera via HTTPS, the web
browser will send a notification about the certificate issue. Install a
signed‐certificate to the camera to cancel the notification.
1. Check Enable to access the camera via HTTP or HTTPS protocol.
2. Check Enable HTTPS Browsing to access the camera only via HTTPS
protocol.
© Copyright 2021 TRENDnet. All Rights Reserved.
Click Create button to create the certificate request. Fill in the
required information in the popup window.
‐
Configuration > Network > Advanced Settings > Network Service.

Select Create the certificate request first and continue the
Click Download to download the certificate request and submit
it to the trusted certificate authority for signature.
‐
After receiving the signed valid certificate, you can import the
certificate in two ways:
.4 Select Signed certificate is available, Start the installation
directly. Click Browse and Install to import the certificate to the
device.
.5 Select Create the certificate request first and continue the
installation. Click Browse and Install to import the certificate to
32
TRENDnet User’s Guide
the device.
TV‐IP420P
QoS
4. There will be the certificate information after your successfully creating
and installing the certificate.
1. Configure the QoS settings, including Video/Audio DSCP, Event/Alarm
DSCP and Management DSCP.
The valid value range of the DSCP is 0 to 63. The bigger the DSCP value
is, the higher the priority is.
Note: DSCP refers to the Differentiated Service Code Point; and the DSCP
value is used in the IP header to indicate the priority of the data.
5. Export and save the certificate for verification when adding the device
to client software.
2. Click Save to save the settings.
Note:
The exported certificate should be saved in the certificate folder of your
client software before adding the device to your PC client.
6. Click the Save button to save the settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
33
TRENDnet User’s Guide
802.1x
TV‐IP420P
3. Enter the user name and password to access the server.
4. Click Save to finish the settings.
Integration Protocol
The IEEE 802.1X standard is supported by the network cameras, and when
the feature is enabled, the camera data is secured and user authentication is
needed when connecting the camera to the network protected by the IEEE
802.1X.
Before you start:
The authentication server must be configured. Please apply and register a
user name and password for 802.1X in the server.
If you need to access to the device through ONVIF protocol, you can configure
ONVIF user in this interface. Refer to ONVIF standard for detailed
configuration rules.
1. Check the Enable IEEE 802.1X checkbox to enable the feature.
2. Configure the 802.1X settings, including Protocol, EAPOL version, User
Name, Password and Confirm.
Note: The EAPOL version must be identical with that of the router or the
switch.
© Copyright 2021 TRENDnet. All Rights Reserved.
1. Check the Enable ONVIF checkbox to enable the function.
2. Add ONVIF users. Up to 32 users are allowed.
Set the user name and password, and confirm the password. You can set
the user as media user, operator, and administrator.
34
TRENDnet User’s Guide
TV‐IP420P

Note: ONVIF user account is different from the camera user account. You
TLS (Transport Layer Security)
The device offers TLS 1.1 and TLS 1.2. Enable one or more protocol
versions according to your need.
have set ONVIF user account independently.
3. Save the settings.
Note: User settings of ONVIF are cleared when you restore the camera.
HTTP Listening
Network Service
Alarm information can be sent to destination IP or Host via HTTP protocol.
You can control the ON/OFF status of certain protocol that the camera
supports.
Steps:
Supported services vary according to camera models.
1.
Input destination IP or host name, URL, and port number.
Keep unused function OFF for security concern.
2.
Click Test to see if the service is available.

SDK Service and Enhanced SDK Service
If you want to add the device to the client software, you should
enable SDK Service or Enhanced SDK Service.
HTTP data transmission should be supported by the destination IP or Host.
SDK Service: SDK protocol is used.
Enhanced SDK Service: SDK over TLS protocol is used.
Communication between the device and the client software is
secured by using TLS (Transport Layer Security) protocol.
© Copyright 2021 TRENDnet. All Rights Reserved.
35
TRENDnet User’s Guide
Video/Audio
Video
TV‐IP420P
Video Quality:
When bitrate type is selected as Variable, 6 levels of video quality are
selectable.
Frame Rate:
Set the frame rate. The frame rate is to describe the frequency at which
the video stream is updated and it is measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video
stream, as it maintains image quality throughout.
Max. Bitrate:
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds
to the higher video quality, but the better bandwidth is required.
Note: The maximum limit of the max. bitrate value varies according to
different camera platforms. For certain cameras, the maximum limit is
8192 Kbps or 12288 Kbps.
Video Encoding:
The camera supports multiple video encodings types, such as H.264,
Video Type:
H.265, MJPEG, and MPEG4. Supported encoding type for different stream
Select the stream type to video stream, or video & audio composite
types may differ. H.265 is a new encoding technology. Compared with
stream. The audio signal will be recorded only when the Video Type is
H.264, it reduces the transmission bitrate under the same resolution,
Video & Audio.
frame rate and image quality.
Resolution:
Note: Selectable video encoding types may vary according to different
Select the resolution of the video output.
camera modes.
Bitrate Type:
H.264+ and H.265+:
Select the bitrate type to constant or variable.
© Copyright 2021 TRENDnet. All Rights Reserved.
36
TRENDnet User’s Guide
•
•
TV‐IP420P
H.264+: If you set the main stream as the stream type, and H.264 as
according the requirements of the actual scene in order to realize the
the video encoding, you can see H.264+ available. H.264+ is an
set maximum average bitrate in the long term. The camera needs at
improved compression coding technology based on H.264. By
least 24 hours to adapt to a fixed monitoring scene.
enabling H.264+, users can estimate the HDD consumption by its
Max. Average Bitrate:
maximum average bitrate. Compared to H.264, H.264+ reduces
When you set a maximum bitrate, its corresponding recommended
storage by up to 50% with the same maximum bitrate in most scenes.
maximum average bitrate will be shown in the Max. Average Bitrate box.
H.265+: If you set the main stream as the stream type, and H.265 as
You can also set the maximum average bitrate manually from 32 Kbps to
the video encoding, you can see H.265+ available. H.265+ is an
the value of the set maximum bitrate.
improved compression coding technology based on H.265. By
Profile:
enabling H.265+, users can estimate the HDD consumption by its
When you select H.264 or H.265 as video encoding, you can set the profile.
maximum average bitrate. Compared to H.265, H.265+ reduces
Selectable profiles vary according to camera models.
storage by up to 50% with the same maximum bitrate in most scenes.
I Frame Interval:
You need to reboot the camera if you want to turn on or turn off the
Set I Frame Interval from 1 to 400.
H.264+/H.265+. If you switch from H.264+ to H.265+ directly, and vice
SVC:
versa, a reboot is not required by the system.
Scalable Video Coding is an extension of the H.264/AVC and H.265
Notes:
standard. Select OFF/ON to disable/enable the SVC function. Select Auto
•
Upgrade your video player to the latest version if live view or playback
and the device will automatically extract frames from the original video
does not work properly due to compatibility.
when the network bandwidth is insufficient.
With H.264+/H.265+ enabled, the parameters such as profile, I frame
Smoothing:
interval, video quality, and SVC are greyed out.
It refers to the smoothness of the stream. The higher value of the
•
•
•
With H.264+/H.265+ enabled, some functions are not supported. For
smoothing is, the better fluency of the stream will be, though, the video
those functions, corresponding interfaces will be hidden.
quality may not be so satisfactory. The lower value of the smoothing is,
H.264+/H.265+ can spontaneously adjust the bitrate distribution
the higher quality of the stream will be, though it may appear not fluent.
© Copyright 2021 TRENDnet. All Rights Reserved.
37
TRENDnet User’s Guide
1. Click Save to save the settings.
Note:
The video parameters vary according to different camera models.
Refer to the actual display page for camera functions.
Audio
TV‐IP420P
Audio Input: When an intercom is connected to the speed dome, you
need to set this option to LineIn. When a microphone is connected to the
speed dome, you need to set this option to MicIn.
Audio Stream Bitrate: When the Audio Encoding is selected as MP2L2, you
can configure the Audio Stream Bitrate in the dropdown list. The greater
the value is, the better the audio quality will be.
Sampling Rate: When the Audio Encoding is selected as MP2L2, you can
configure the Sampling Rate in the dropdown list. The greater the value is,
the better the audio quality will be.
Input Volume: Slid the bar to turn up/down the volume. The value ranges
from 0 to 100.
Environmental Noise Filter: Select ON or OFF in the dropdown list to
enable or disable the function. It’s recommended to enable the function
when the sampling rate is lower than 32 kHz.
3. Click SAVE to save the settings.
1. Enter the Audio settings interface
Configuration > Video/Audio > Audio
2. Configure the following settings.
Audio Encoding: G.722.1, G.711ulaw, G.711alaw, MP2L2, G.726 and PCM
are selectable.
© Copyright 2021 TRENDnet. All Rights Reserved.
38
TRENDnet User’s Guide
ROI
TV‐IP420P
Note: ROI function varies according to different camera models.
Steps:
1.
Enter the ROI settings interface: Configuration > Video/Audio > ROI.
2.
Select the Stream Type for ROI encoding.
3.
Check the checkbox of Enable under Fixed Region item.
4.
Set Fixed Region for ROI.
(1) Select the Region No. from the drop‐down list.
(2) Check the Enable checkbox to enable ROI function for the chosen
region.
(3) Click Drawing. Click and drag the mouse on the view screen to draw
a red rectangle as the ROI region. You can click Clear to cancel
former drawing. Click Stop Drawing when you finish.
(4) Select the ROI level.
(5) Enter a region name for the chosen region.
(6) Click Save the save the settings of ROI settings for chosen fixed
region.
(7) Repeat steps (1) to (6) to setup other fixed regions.
5.
Set Dynamic Region for ROI.
ROI (Region of Interest) encoding helps to discriminate the ROI and
(1) Check the checkbox to enable Face Tracking.
background information in video compression, which means, the technology
Note: To enable face tracking function, the face detection function
assigns more encoding resource to the region of interest, thus to increase the
should be supported and enabled.
quality of the ROI whereas the background information is less focused.
(2) Select the ROI level.
© Copyright 2021 TRENDnet. All Rights Reserved.
39
TRENDnet User’s Guide
6.
Click Save to save the settings.
Note: ROI level means the image quality enhancing level. The larger the value
is, the better the image quality would be.
TV‐IP420P
Display Settings
Display Info on Stream
1. Enter the Dual‐VCA settings interface:
Configuration > Video/Audio > Display Info. on Stream
2. Check the checkbox to enable the function of Dual‐VCA which can be
used cooperatively with NVR to implement dual‐VCA retrieval during
playback.
3. Click Save to save the settings.

Image Adjustment
Brightness describes bright of the image, which ranges from 1 to 100.
Contrast describes the contrast of the image, which ranges from 1 to 100.
© Copyright 2021 TRENDnet. All Rights Reserved.
40
TRENDnet User’s Guide
Saturation describes the colorfulness of the image color, which ranges
from 1 to 100.
Sharpness describes the edge contrast of the image, which ranges from
1 to 100.

TV‐IP420P
Night: the camera stays at night mode.
Auto: the camera switches between the day mode and the night mode
according to the illumination automatically. The sensitivity ranges from
0 to 7, the higher the value is, the easier the mode switches. The filtering
Exposure Settings
time refers to the interval time between the day/night switch. You can
If the camera is equipped with the fixed lens, only Manual is selectable,
set it from 5s to 120s.
and the iris mode is not configurable.
Scheduled‐Switch: Set the start time and the end time to define the
If Auto is selected, you can set the auto iris level from 0 to 100.
duration for day/night mode.
The Exposure Time refers to the electronic shutter time, which ranges
Triggered by alarm input: The switch is triggered by alarm input. You can
from 1 to 1/100,000s. Adjust it according to the actual luminance
set the triggered mode to day or night.
condition.
Smart Supplement Light: Set the supplement light as ON, and Auto and
Gain of image can also be manually configured from 0 to 100. The bigger
Manual are selectable for light mode.
the value is, the brighter would the image be, and the noise would also
be amplified to a larger extent.
Select Auto, and the supplement light changes according to the actual
luminance. E.g., if the current scene is bright enough, then the

Day/Night Switch
supplement light adjusts itself to lower power; and if the scene is not
Select the Day/Night Switch mode according to different surveillance
bright enough, the light adjusts itself to higher power.
demand.
Select Manual, and you can adjust the supplement by adjusting the
Day, Night, Auto, Scheduled‐Switch, and Triggered by alarm input are
distance. E.g., if the object is near the camera, the device adjusts the
selectable for day/night switch.
supplement light to lower power, and the light is in higher power if the
Day: the camera stays at day mode.
object is far away.
© Copyright 2021 TRENDnet. All Rights Reserved.
41
TRENDnet User’s Guide
 Backlight Settings
TV‐IP420P
 Image Enhancement
BLC Area: If you focus on an object against strong backlight, the object
Digital Noise Reduction: DNR reduces the noise in the video stream. OFF,
will be too dark to be seen clearly. BLC compensates light to the object in
Normal and Expert are selectable. Set the DNR level from 0 to 100 in
the front to make it clear. OFF, Up, Down, Left, Right, Center, Auto, and
Normal Mode. Set the DNR level from both space DNR level [0‐100] and
Custom are selectable.
time DNR level [0‐100] in Expert Mode.
Note: If BLC mode is set as Custom, you can draw a red rectangle on the
live view image as the BLC area.
D‐WDR: Wide Dynamic Range can be used when there is a high contrast
of the bright area and the dark area of the scene.
HLC: High Light Compression function can be used when there are strong
lights in the scene affecting the image quality.
 White Balance
White balance is the white rendition function of the camera used to
adjust the color temperature according to the environment.
Defog Mode: You can enable the defog function when the environment
is foggy and the image is misty. It enhances the subtle details so that the
image appears clearer.
EIS (Electrical Image Stabilizer): EIS reduces the effects of vibration in a
video.
Grey Scale: You can choose the range of the grey scale as [0‐255] or [16‐
235].
 Video Adjustment
Mirror: It mirrors the image so you can see it inversed. Left/Right,
Up/Down, Center, and OFF are selectable.
Rotate: To make a complete use of the 16:9 aspect ratio, you can enable
the rotate function when you use the camera in a narrow view scene.
When installing, turn the camera to the 90 degrees or rotate the 3‐axis
lens to 90 degrees, and set the rotate mode as on, you will get a normal
view of the scene with 9:16 aspect ratio to ignore the needless
© Copyright 2021 TRENDnet. All Rights Reserved.
42
TRENDnet User’s Guide
information such as the wall, and get more meaningful information of
TV‐IP420P
OSD Settings
the scene.
Scene Mode: Choose the scene as indoor or outdoor according to the
real environment.
Video Standard: 50 Hz and 60 Hz are selectable. Choose according to the
different video standards; normally 50 Hz for PAL standard and 60 Hz for
NTSC standard.
Lens Distortion Correction: For cameras equipped with motor‐driven
lens, image may appear distorted to some extent. Turn on this function
to correct the distortion.
© Copyright 2021 TRENDnet. All Rights Reserved.
43
TRENDnet User’s Guide
1. Check the corresponding checkbox to select the display of camera name,
TV‐IP420P
Image Parameters Switch
date or week if required.
2. Edit the camera name in the text field of Camera Name.
3. Select from the drop‐down list to set the time format and date format.
4. Select from the drop‐down list to set the time format, date format,
display mode, OSD size and OSD color.
5. Configure the text overlay settings.
(1) Check the checkbox in front of the textbox to enable the on‐screen
display.
(2) Input the characters in the textbox.
Note: Up to 8 text overlays are configurable.
6. Adjust the OSD position and alignment.
You can configure Link to Preset or Scheduled‐Switch in order to switch to
linked scene in certain time.

Link to Preset: Set the time period and linked scene for the preset and
check the corresponding checkbox to go to the linked scene in the
configured time period.

Scheduled‐Switch: Set the time period and linked scene and it will go to
the linked scene in the configured time period when you check the
corresponding checkbox.
7. Character align right, character align left, all align right, all align left and
custom are selectable. If you select character align right, character align
left, all align left or all align right, you can set the left and right margins
and up and down margins. 1 Character, 2 character and none are
available. If you select custom, you can use the mouse to click and drag
text frames in the live view window to adjust their positions.
8. Click Save to save the settings.
This function varies depending on different camera models
1. Enter the Image Parameters Switch interface:
Configuration > Image > Image Parameters Switch
2. Check the checkbox of Link to Preset or Scheduled‐Switch to enable the
function. (Only one function can be enabled in the same time.)
3. When you enable the function of Link to Preset, select one preset from
the dropdown list, check the corresponding checkbox, set the time period
© Copyright 2021 TRENDnet. All Rights Reserved.
44
TRENDnet User’s Guide
and the linked scene for the selected preset. (Up to 4 periods can be
configured for one preset.)
TV‐IP420P
PTZ
Basic Settings
Basic Parameters
Enable PTZ Control:
Enable Proportional Pan:
If you enable this function, the pan/tilt speeds
change according to the amount of zoom.
Enable Preset Freezing:
This function enables the live view to switch
directly from one scene defined by a preset to
another, without showing the middle areas
between these two, to ensure the surveillance
efficiency. It can also reduce the use of
bandwidth in a digital network system.
Preset Speed:
You can set the speed of defined preset from 1
to 8.
Manual Control Speed:
This function enables the live view to switch
directly from one scene defined by a preset to
another, without showing the middle areas
between these two, to ensure the surveillance
efficiency. It can also reduce the use of
bandwidth in a digital network system.
4. When you enable the function of Scheduled‐Switch, check the
corresponding checkbox, set the time period and the linked scene.
5. Click Save to save the settings.
The two functions are not enabled by default.
Enable this function to use PTZ fucntion
Keyboard Control Speed:
Zooming Speed:
Define the speed of PTZ control by a keyboard as
Low, Medium or High.
The speed of zooming is adjustable.
PTZ OSD
© Copyright 2021 TRENDnet. All Rights Reserved.
Zoom Status:
Set the OSD duration of zooming status as 2
seconds to 10 seconds, always on or off.
PT Status:
Set the angle display duration white panning
and tilting as 2 seconds to 10 seconds,
always on or off.
45
TRENDnet User’s Guide
Preset Status:
TV‐IP420P
Set the preset name display duration as 2
seconds to 10 seconds, always on or off.
1.
POWER OFF MEMORY
Set Resume Time Point:
Steps
The camera can resume its previous PTZ status
or actions after it is restarted from a power‐off.
You can set the time point of which the camera
resumes its PTZ status from 30 seconds up to
600 seconds before power‐off.
Click Save to save the changes
Limit
2.
3.
Check the Enable Limit box and select Manual Stops or Scan Stops from the
Limit Type list.
a. When manual limit stops re set, you can operate the PTZ control panel
manually only in the limited area.
b. When scan limit stops are set, all the scan actions are performed only
in the limited area.
Click the PTL control buttons to find the left/right/up/down stop limits, you can
also call the presets and set them as the limits for the camera.
Click Set to save the limits and Clear to clear the limits.
Initial Position
Set the camera initial position, you can also call a preset for the position. Click Set to
save the limits and Clear to clear the limits.
© Copyright 2021 TRENDnet. All Rights Reserved.
46
TRENDnet User’s Guide
Steps:
1. Click the PTZ control buttons to find a position as the initial position
of the speed dome; you can also call a defined preset and set it as the
initial position of the speed dome.
2. Click Set to save the position.
3. Call/delete an Initial Position:
TV‐IP420P
Privacy Mask
Create masking area to keep your privacy. You can create up to four
independent masking areas by clicking and dragging on the screen.
You can click
to call the initial position. You can click
to delete the
initial position and restore the factory default initial position.
Park Action
The feature allows the camera to start at a predefined park action. (scan,
preset, pattern) automatically after a period of inactivity (park time).
Scheduled Tasks function has higher priority over Park Action function
therefore when two functions are set at the same time, Scheduled Tasks
function takes effect.
Private Mask
Enable Privacy Mask:
Check this box to enable privacy masking.
Draw Area:
Click this button to start drawing.
Stop Drawing:
Click this button to stop drawing.
Clear All:
Add:
Delete:
Click this button to clear all the masking areas.
Click this button to add the mask.
Click this button to delete the mask.
Click Save to save the changes
© Copyright 2021 TRENDnet. All Rights Reserved.
47
TRENDnet User’s Guide
TV‐IP420P
Schedule Tasks
You can configure the camera to perform a certain action automatically in a
user‐defined time period.
Enable the Scheduled Task, select the task(s) that you would like to perform
at certain time.
1. Choose the day you would like to set the task schedule
2. Click All Day or Customize to enter the Start Time and End Time for
each task.
3. Choose the task type from the drop down list.
4. Click OK to save the settings.
Scheduled Tasks
You can configure the network speed dome to perform a certain action
automatically in a user‐defined time period.
1.
Enter the Scheduled Task settings interface:
Configuration> PTZ > Scheduled Tasks
2.
Check the checkbox of Enable Scheduled Task.
3.
Set the Park Time. You can set the park time (a period of inactivity)
before the speed dome starts the scheduled tasks.
4.
Select the task type from the dropdown list. You can choose scan,
preset, pattern and etc.
Note: The time for each task cannot be overlapped, up to 10 tasks can be
configured for each day.
© Copyright 2021 TRENDnet. All Rights Reserved.
48
TRENDnet User’s Guide
TV‐IP420P
Clear Config
You can clear PTZ configurations all at once in this section, select the desire
function and click Save to clear.
5.
Select the timeline of a certain day, click and drag the the mouse to set
the recording schedule (the start time and end time of the recording
task).
6.
After you set the scheduled task, you can click
other days (optional).
and copy the task to
Prioritize PTZ
The time of each task cannot be overlapped. Up to 10 tasks can be
configured for each day.
7.
1. Select Network or RS‐485 from the dropdown list
2. Set the delay time (Range 2‐200s)
3. Click Save to save the settings
Click Save to save the settings
© Copyright 2021 TRENDnet. All Rights Reserved.
49
TRENDnet User’s Guide
TV‐IP420P
Event – Basic Event
You can configure the basic events by following the instructions in this section,
including motion detection, video tampering, alarm input, alarm output, and
exception, etc. These events can trigger the linkage methods, such as Notify
Surveillance Center, Send Email, etc.
Note: Check the checkbox of Notify Surveillance Center if you want the alarm
information to be pushed to PC or mobile client software as soon as the alarm
is triggered.
Motion Detection
Motion detection detects the moving objects in the configured surveillance
area, and a series of actions can be taken when the alarm is triggered.
In order to detect the moving objects accurately and reduce the false alarm
rate, normal configuration and expert configuration are selectable for
different motion detection environment.
1.
Check the checkbox of Enable Motion Detection.
2.
Check the checkbox of Enable Dynamic Analysis for Motion if you want
to mark the detected objects with green rectangles.
© Copyright 2021 TRENDnet. All Rights Reserved.
50
TRENDnet User’s Guide
TV‐IP420P
Note: Select Disable for rules if you don’t want the detected objected
displayed with the green rectangles. Select disable rules from
period.
3.
Configuration > Local Configuration > Live View Parameters‐rules.
3.
Click Draw Area. Click and drag the mouse on the live video to draw a
motion detection area. Click Stop Drawing to finish drawing one area.
4.
(Optional) Click Clear All to clear all of the areas.
5.
(Optional) Move the slider to set the sensitivity of the detection.
Steps:
(Optional) Click Delete to delete the current arming schedule, or click
Save to save the settings.
4.
Move the mouse to the end of each day, a copy dialogue box pops up,
and you can copy the current settings to other days.
5.
Click Save to save the settings.
Note: The time of each period can’t be overlapped. Up to 8 periods can be
configured for each day.
1.
Click Arming Schedule to edit the arming schedule.
Task 3: Set the Linkage Method for Motion Detection
2.
Click on the time bar and drag the mouse to select the time period.
Check the checkbox to select the linkage method. Audible Warning, Send
Email, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Trigger
Channel and Trigger Alarm Output are selectable. You can specify the linkage
method when an event occurs.
Note: Click on the selected time period, you can adjust the time period
Note: The linkage methods vary according to the different camera models.
to the desired time by either moving the time bar or input the exact time
© Copyright 2021 TRENDnet. All Rights Reserved.
51
TRENDnet User’s Guide

Send Email
TV‐IP420P
Video Tampering
Send an email with alarm information to a user or users when an event
occurs.

Notify Surveillance Center
Send an exception or alarm signal to remote management software
when an event occurs.

Upload to FTP/ NAS
Capture the image when an alarm is triggered and upload the picture to
a FTP server.
Notes:
●
Set the FTP address and the remote FTP server first
●
Go to Configuration > Storage > Schedule Settings> Capture >
Capture Parameters page, enable the event‐triggered snapshot,
and set the capture interval and capture number.
●
The captured image can also be uploaded to the available SD card
or network disk.
You can configure the camera to trigger the alarm when the lens is covered
and take certain alarm response actions.
© Copyright 2021 TRENDnet. All Rights Reserved.
52
TRENDnet User’s Guide
Detection area for this alarm is the whole screen.
1.
Check Enable Video Tampering checkbox to enable the video tampering
TV‐IP420P
Configuration > Event > Basic Event > Alarm Input
2. Choose the alarm input No. and the Alarm Type. The alarm type can be
NO (Normally Open) and NC (Normally Closed).
detection.
2.
Click Edit to edit the arming schedule for video tampering. The arming
schedule configuration is the same as the setting of the arming schedule
for motion detection. Check the checkbox to select the linkage method
taken for the video tampering.
3.
Click Save to save the settings.
Configuring Alarm Input
3. Edit the name in
name for the alarm input (optional).
to set a
4. Click Arming Schedule tab to enter the arming schedule setting interface.
The arming schedule configuration is the same as the setting of the arming
schedule for motion detection.
5. Click Linkage Method tab to select the linkage method taken for alarm
input, including Notify Surveillance Center, Send Email, Upload to
FTP/Memory, Trigger Alarm Output and Trigger Recording.
6. You can also choose the PTZ linking for the alarm input. Check the relative
checkbox and select the No. to enable Preset Calling, Patrol Calling or
Pattern Calling.
7. You can copy your settings to other alarm inputs.
8. Click Save to save the settings.
Configuring Alarm Output
1. Enter the Alarm Input settings interface:
© Copyright 2021 TRENDnet. All Rights Reserved.
53
TRENDnet User’s Guide
TV‐IP420P
Exceptions
The exception type can be HDD full, HDD error, network disconnected, IP
1.
2.
Enter the Alarm Output settings interface:
Configuration> Event > Basic Event > Alarm Output
Select one alarm output channel in the Alarm Output dropdown list.
3.
Set a name in Alarm Name for the alarm output (optional).
4.
The Delay time can be set to 5sec, 10sec, 30sec, 1min, 2min, 5min,
10min or Manual. The delay time refers to the time duration that the
alarm output remains in effect after alarm occurs.
5.
Click Arming Schedule tab to enter the arming schedule setting
interface. The time schedule configuration is the same as the settings of
the arming schedule for motion detection.
6.
You can copy the settings to other alarm outputs.
7.
Click Save to save the settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
address conflicted and illegal login to the cameras.
54
TRENDnet User’s Guide
TV‐IP420P
Event – Smart Event
Steps:
Audio Exception Detection
1.
Check the checkbox of Audio Loss Exception to enable the audio loss
detection function.
Audio exception detection function detects the abnormal sounds in the
2.
Check the checkbox of Sudden Increase of Sound Intensity Detection to
surveillance scene, such as the sudden increase/decrease of the sound
detect the sound steep rise in the surveillance scene. You can set the
intensity, and some certain actions can be taken when the alarm is
detection sensitivity and threshold for sound steep rise.
triggered.
3.
Check the checkbox of Sudden Decrease of Sound Intensity Detection
to detect the sound steep drop in the surveillance scene. You can set the
Note: Audio exception detection function varies according to different
detection sensitivity and threshold for sound steep drop.
camera models.
Notes:

Sensitivity: Range [1‐100], the smaller the value is, the more severe
the change should be to trigger the detection.

Sound Intensity Threshold: Range [1‐100], it can filter the sound in
the environment, the louder the environment sound, the higher the
value should be. You can adjust it according to the real environment.

You can view the real‐time volume of the sound on the interface.
4.
Click Arming Schedule to set the arming schedule.
5.
Click Linkage Method and select the linkage methods for audio
exception, including Notify Surveillance Center, Send Email, Trigger
Channel for recording and Trigger Alarm Output.
6.
© Copyright 2021 TRENDnet. All Rights Reserved.
Click Save to save the settings.
55
TRENDnet User’s Guide
Intrusion Detection
Intrusion detection function detects people, vehicle or other objects which
enter and loiter in a pre‐defined virtual region, and some certain actions can
TV‐IP420P
Steps:
1.
Check the checkbox of Enable to enable the function.
2.
Select a region number from the drop‐down list of Region.
Region: A pre‐defined vertexes area on the live view image. Targets, such
be taken when the alarm is triggered.
as, people, vehicle or other objects, who enter and loiter in the region
Note: Intrusion detection function varies according to different camera
will be detected and trigger the set alarm.
models.
3.
Set the Max. Size and Min. Size for valid targets. Targets smaller or larger
than the valid target size are not able to trigger detection. Select a point
in the live image as the start to draw a rectangle as the max. size or min.
size.
Max. Size: The maximum size of a valid target. Targets with larger sizes
would not trigger detection.
Min. Size: The minimum size of a valid target. Targets with smaller sizes
would not trigger detection.
4.
Set the Detection Area. Click on the live video to specify the four vertexes
of the detection region, and right click to complete drawing.
5.
Select the detection target. Human and vehicle are available. If the
detection target is not selected, all the detected targets will be reported,
including the human and vehicle.
6.
© Copyright 2021 TRENDnet. All Rights Reserved.
Set the time threshold for intrusion detection.
56
TRENDnet User’s Guide
Threshold: Range [0s‐10s], the threshold for the time of the object
TV‐IP420P
Line Crossing Detection
loitering in the region. If you set the value as 0, alarm is triggered
immediately after the object entering the region.
7.
Line crossing detection function detects people, vehicle or other objects
Drag the slider to set the sensitivity value.
which cross a pre‐defined virtual line, and some certain actions can be taken
Sensitivity: Range [1‐100]. Sensitivity stands for the percentage of the
when the alarm is triggered.
body part of an acceptable target that enters the pre‐defined region.
Sensitivity = 100 – S1/ST*100
Note: Line crossing detection function varies according to different camera
models.
S1 stands for the target body part that goes across the pre‐defined region.
ST stands for the complete target body.
Example: if you set the value as 60, the action can be counted as an
intrusion only when 40 percent body part enters the region.
Note: The Sensitivity of the detection is supported by certain models.
Refer to actual display for details.
8.
Repeat the above steps to configure other regions. Up to 4 regions can
be set. You can click the Clear button to clear all pre‐defined regions.
9.
Click Arming Schedule to set the arming schedule.
10. Click Linkage Method to select the linkage methods for intrusion
detection, including Notify Surveillance Center, Send Email, Upload to
FTP/Memory Card/NAS, Trigger Alarm Output.
11. Click Save to save the settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
57
TRENDnet User’s Guide
TV‐IP420P
Steps:
B‐>A: Only the object crossing the configured line from the B side to the
A side can be detected.
1.
Check the checkbox of Enable to enable the function.
2.
Select the line from the drop‐down list.
3.
Set the Max. Size and Min. Size for valid targets. Targets smaller or larger
Sensitivity: Range [1‐100]. It stands for the percentage of the body part
than the valid target size are not able to trigger detection.
of an acceptable target that goes across the pre‐defined line.
7.
Max. Size: The maximum size of a valid target. Targets with larger sizes
Sensitivity = 100 – S1/ST*100
would not trigger detection.
S1 stands for the target body part that goes across the pre‐defined line.
Min. Size: The minimum size of a valid target. Targets with smaller sizes
ST stands for the complete target body.
would not trigger detection.
4.
Example: if you set the value as 60, the action can be counted as a line
Set the detection area. Drag the line, and you can locate it on the live
crossing action only when 40 percent or more body part goes across the
video as desired.
5.
6.
Drag the slider to set the sensitivity value.
line.
Select the detection target. Human and vehicle are available. If the
detection target is not selected, all the detected targets will be reported,
Note: The Sensitivity of the detection is supported by certain models.
including the human and vehicle.
Refer to actual display for details.
Select the direction for line crossing detection. And you can select the
directions as A<‐>B, A ‐>B, and B‐>A.
A<‐>B: The object going across the plane with both directions can be
detected and alarms are triggered.
8.
Repeat the above steps to configure other lines. Up to 4 lines can be set.
You can click the Clear button to clear all pre‐defined lines.
9.
Click the Arming Schedule to set the arming schedule.
10. Click Linkage Method to select the linkage methods for intrusion
A‐>B: Only the object crossing the configured line from the A side to the
detection, including Notify Surveillance Center, Send Email, Upload to
B side can be detected.
FTP/Memory Card/NAS, and Trigger Alarm Output
11. Click Save to save the settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
58
TRENDnet User’s Guide
Region Entrance Detection
TV‐IP420P
3.
Set the detection area. Click on the live video to specify the four vertexes
of the detection region, and right click to complete drawing.
Region entrance detection function detects people, vehicle or other objects
4.
Select the detection target. Human and vehicle are available. If the
detection target is not selected, all the detected targets will be reported,
which enter a pre‐defined virtual region from the outside place, and some
including the human and vehicle.
certain actions can be taken when the alarm is triggered.
5.
Repeat the above steps to configure other regions. Up to 4 regions can
be set. You can click the Clear button to clear all pre‐defined regions.
6.
Click Arming Schedule to set the arming schedule.
7.
Click Linkage Method to select the linkage methods for intrusion
detection, including Notify Surveillance Center, Send Email, and Upload
to FTP/Memory Card/NAS
8.
Click Save to save the settings.
Steps:
1.
Check the Enable checkbox to enable the function.
2.
Select the Region from the drop‐down list for detection settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
59
TRENDnet User’s Guide
Region Exist Detection
TV‐IP420P
11. Set the detection area. Click on the live video to specify the four vertexes
of the detection region, and right click to complete drawing.
Region Exist detection function detects people, vehicle or other objects which
12. Select the detection target. Human and vehicle are available. If the
exit a pre‐defined virtual region from the outside place, and some certain
detection target is not selected, all the detected targets will be reported,
actions can be taken when the alarm is triggered.
including the human and vehicle.
13. Repeat the above steps to configure other regions. Up to 4 regions can
be set. You can click the Clear button to clear all pre‐defined regions.
14. Click Arming Schedule to set the arming schedule.
15. Click Linkage Method to select the linkage methods for intrusion
detection, including Notify Surveillance Center, Send Email, and Upload
to FTP/Memory Card/NAS
16. Click Save to save the settings.
Unattended Baggage Detection
Unattended baggage detection function detects the objects left over in the
pre‐defined region such as the baggage, purse, dangerous materials, etc. A
series of actions can be taken when the alarm is triggered.
Steps:
9.
Check the Enable checkbox to enable the function.
10. Select the Region from the drop‐down list for detection settings.
© Copyright 2021 TRENDnet. All Rights Reserved.
60
TRENDnet User’s Guide
TV‐IP420P
5.
Set the Max. Size and Min. Size for valid targets. Targets smaller or larger
than the valid target size are not able to trigger detection.
Max. Size: The maximum size of a valid target. Targets with larger sizes
would not trigger detection.
Min. Size: The minimum size of a valid target. Targets with smaller sizes
would not trigger detection.
6.
Click Stop Drawing when finish drawing.
7.
Set the time threshold and detection sensitivity for unattended baggage
detection.
Threshold: Range [5‐100s], the threshold for the time of the objects left
over in the region. If you set the value as 10, alarm is triggered after the
object is left and stay in the region for 10s.
8.
Drag the slider to set the sensitivity value.
Sensitivity: Range [1‐100]. Sensitivity stands for the percentage of the
body part of an acceptable target that enters the pre‐defined region.
Steps:
Sensitivity = 100 – S1/ST*100
S1 stands for target body part that enters the pre‐defined region. ST
1.
Check Enable checkbox to enable the function.
2.
Select the Region from the drop‐down list for detection settings.
3.
Click Area Settings and click Draw Area to start the area drawing.
Example: if you set the value as 60, a target is possible to be counted as
4.
Click on the live video to specify the four vertexes of the detection region,
an unattended baggage only when 40 percent body part of the target
and right click to complete drawing.
enters the region.
© Copyright 2021 TRENDnet. All Rights Reserved.
stands for the complete target body.
61
TRENDnet User’s Guide
TV‐IP420P
Note: The Sensitivity of the detection is supported by certain models.
Refer to actual display for details.
9.
Repeat the above steps to configure other regions. Up to 4 regions can
be set. You can click the Clear button to clear all pre‐defined regions.
10. Click Arming Schedule to set the arming schedule.
11. Click Linkage Method to select the linkage methods.
12. Click Save to save the settings.
Object Removal Detection
Object removal detection function detects the objects removed from the pre‐
defined region, such as the exhibits on display, and a series of actions can be
taken when the alarm is triggered.
Steps:
1.
Check Enable checkbox to enable the function.
2.
Select the Region from the drop‐down list for detection settings.
3.
Click Area Settings and click Draw Area button to start the area drawing.
4.
Click on the live video to specify the four vertexes of the detection region,
and right click to complete drawing.
© Copyright 2021 TRENDnet. All Rights Reserved.
62
TRENDnet User’s Guide
5.
TV‐IP420P
Set the Max. Size and Min. Size for valid targets. Targets smaller or larger
Note: The Sensitivity of the detection is supported by certain models.
than the valid target size are not able to trigger detection.
Refer to actual display for details.
Max. Size: The maximum size of a valid target. Targets with larger sizes
would not trigger detection.
9.
Repeat the above steps to configure other regions. Up to 4 regions can
be set. You can click the Clear button to clear all pre‐defined regions.
Min. Size: The minimum size of a valid target. Targets with smaller sizes
10. Click Arming Schedule to set the arming schedule.
would not trigger detection.
11. Click Linkage Method to select the linkage methods.
6.
Click Stop Drawing when finish drawing.
7.
Set the time threshold for object removal detection.
12. Click Save to save the settings.
Threshold: Range [5‐100s], the threshold for the time of the objects
Storage – Schedule Settings
removed from the region. If you set the value as 10, alarm is triggered
Record Schedule
after the object disappears from the region for 10s.
8.
Drag the slider to set the sensitivity value.
Sensitivity: Range [1‐100]. It stands for the percentage of the body part
of an acceptable target that leaves the pre‐defined region.
Sensitivity = 100 – S1/ST*100
S1 stands for the target body part that leaves the pre‐defined region. ST
stands for the complete target body.
Example: if you set the value as 60, a target is possible to be counted as
a removed object only when 40 percent body part of the target leaves
Steps:
the region.
1. Check the checkbox of Enable to enable scheduled recording.
© Copyright 2021 TRENDnet. All Rights Reserved.
63
TRENDnet User’s Guide
TV‐IP420P
2. Click Advanced to set the camera record parameters.

If you select Motion Detection, the video will be recorded when the
Pre‐record: The time you set to start recording before the scheduled
motion is detected.
time or the event. For example, if an alarm triggers recording at 10:00,
Besides configuring the recording schedule, you have to set the
and the pre‐record time is set as 5 seconds, the camera starts to
motion detection area and check the checkbox of Trigger Channel in
record at 9:59:55.
the Linkage Method of Motion Detection Settings interface. For
The Pre‐record time can be configured as No Pre‐record, 5s, 10s, 15s,
detailed information.
20s, 25s, 30s or not limited.

Post‐record: The time you set to stop recording after the scheduled
time or the event. For example, if an alarm triggered recording ends
at 11:00, and the post‐record time is set as 5 seconds, the camera


Record Triggered by Alarm
If you select Alarm, the video will be recorded when the alarm is
triggered via the external alarm input channels.
records until 11:00:05.
Besides configuring the recording schedule, you have to set the
The Post‐record time can be configured as 5s, 10s, 30s, 1 min, 2 min,
Alarm Type and check the checkbox of Trigger Channel in the
5 min or 10 min.
Linkage Method of Alarm Input Settings interface. Record Triggered
Stream Type: Select the stream type for recording.
by Motion & Alarm
Note: The record parameter configurations vary depending on the camera
If you select Motion & Alarm, the video will be recorded when the
model.
motion and alarm are triggered at the same time.
3. Select a Record Type. The record type can be Continuous, Motion
Besides configuring the recording schedule, you have to configure
Detection, Alarm, Motion | Alarm, Motion & Alarm, and Event.
the settings on the Motion Detection and Alarm Input Settings

interfaces. Record Triggered by Motion | Alarm
Continuous
If you select Continuous, the video will be recorded automatically
according to the time of the schedule.

If you select Motion | Alarm, the video will be recorded when the
external alarm is triggered or the motion is detected.
Record Triggered by Motion Detection
© Copyright 2021 TRENDnet. All Rights Reserved.
64
TRENDnet User’s Guide
TV‐IP420P
Besides configuring the recording schedule, you have to configure
You can configure the scheduled snapshot and event‐triggered snapshot. The
the settings on the Motion Detection and Alarm Input Settings
captured picture can be stored in the local storage or network storage.
interfaces. Record Triggered by Events
If you select Event, the video will be recorded if any of the events is
Steps:
1.
triggered. Besides configuring the recording schedule, you have to
configure the event settings.
Settings > Capture.
2.
Go to Capture Schedule tab to configure the capture schedule by click‐
and‐drag the mouse on the time bar. You can copy the record schedule
4. Select the record type, and click‐and‐drag the mouse on the time bar to
to other days by clicking the green copy icon on the right of each time
set the record schedule.
bar.
5. Click Save to save the settings.
Capture
Enter the Capture Settings interface: Configuration > Storage > Storage
3.
Click Advanced to select stream type.
4.
Click Save to save the settings.
5.
Go to Capture Parameters tab to configure the capture parameters.
(1) Check the Enable Timing Snapshot checkbox to enable continuous
snapshot.
(2) Select the picture format, resolution, quality and capture interval.
(3) Check the Enable Event‐triggered Snapshot checkbox to enable
event‐triggered snapshot.
(4) Select the picture format, resolution, quality, capture interval, and
capture number.
© Copyright 2021 TRENDnet. All Rights Reserved.
65
TRENDnet User’s Guide
TV‐IP420P
Storage – Storage Management
HDD Management
6.
Set the time interval between two snapshots.
7.
Click Save to save the settings.
Net HDD (NAS)
The network disk should be available within the network and properly
configured to store the recorded files, log files, pictures, etc.
1. Add Net HDD.
(1) Enter the Net HDD settings interface, Configuration > Storage >
Storage Management > Net HDD.
© Copyright 2021 TRENDnet. All Rights Reserved.
66
TRENDnet User’s Guide
TV‐IP420P
(2) Enter the IP address of the network disk, and enter the file path.
(3) Select the mounting type. NFS and SMB/CIFS are selectable. And
you can set the user name and password to guarantee the security
if SMB/CIFS is selected.
Note: Please refer to the NAS User Manual for creating the file path.

For your privacy and to better protect your system against
security risks, we strongly recommend the use of strong
passwords for all functions and network devices. The password
should be something of your own choosing (using a minimum of
8 characters, including at least three of the following categories:
upper case letters, lower case letters, numbers and special
characters) in order to increase the security of your product.

Proper configuration of all passwords and other security
(2) If the status of the disk is Uninitialized, check the corresponding
checkbox to select the disk and click Format to start initializing the
settings is the responsibility of the installer and/or end‐user.
disk.
(4) Click Save to add the network disk.
When the initialization completed, the status of disk will become
2. Initialize the added network disk.
Normal.
(1) Enter the HDD Settings interface, Configuration > Storage > Storage
Management > HDD Management, in which you can view the
capacity, free space, status, type and property of the disk.
3. Define the quota for record and pictures.
(1) Input the quota percentage for picture and for record.
(2) Click Save and refresh the browser page to activate the settings.
Note:
Up to 8 NAS disks can be connected to the camera.
© Copyright 2021 TRENDnet. All Rights Reserved.
67
TRENDnet User’s Guide
TV‐IP420P
Storage – Advanced Settings
FTP
You can configure the FTP/SFTP server related information to enable the
uploading of the captured pictures to the FTP/SFTP server. The captured
pictures can be triggered by events or a timing snapshot task.
1. Select the FTP protocol.
2. Input the server address and port.
3. Configure the FTP/SFTP settings; and the user name and password are
required for the FTP server login.
© Copyright 2021 TRENDnet. All Rights Reserved.
68
TRENDnet User’s Guide

TV‐IP420P
For your privacy and to better protect your system against security
Picture Name: Set the naming rule for captured picture files. You can
risks, we strongly recommend the use of strong passwords for all
choose Default in the drop‐down list to use the default rule, that is,
functions and network devices. The password should be something
IP address_channel number_capture time_event type.jpg
of your own choosing (using a minimum of 8 characters, including
at least three of the following categories: upper case letters, lower
Or you can customize it by adding a Custom Prefix to the default naming
case letters, numbers and special characters) in order to increase the
rule.
security of your product.

Proper configuration of all passwords and other security settings is
the responsibility of the installer and/or end‐user.
4. Set the directory structure and picture filing interval.
5. Check the Upload Picture checkbox to enable the function.
Upload Picture: To enable uploading the captured picture to the FTP
server.
Directory: In the Directory Structure field, you can select the root
Anonymous Access to the FTP Server (in which case the user name and
directory, parent directory and child directory. When the parent
password won’t be required.): Check the Anonymous checkbox to
directory is selected, you have the option to use the Device Name,
enable the anonymous access to the FTP server.
Device Number or Device IP for the name of the directory; and when the
Child Directory is selected, you can use the Camera Name or Camera No.
as the name of the directory.
Picture Filing Interval: For better picture management, you can set the
Note: The anonymous access function must be supported by the FTP
server.
6. Click Save to save the settings.
picture filing interval from 1 day to 30 days. Pictures captured in the
same time interval will be saved in one folder named after the beginning
date and ending date of the time interval.
© Copyright 2021 TRENDnet. All Rights Reserved.
69
TRENDnet User’s Guide
Appendix
Direct video access ‐ RTSP
To access the video directly through RTSP, just visit the camera IP address on
port 554 by default.
Regulations
TV‐IP420P
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of
the following measures:
•
•
•
•
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
This transmitter must not be co‐located or operating in conjunction with any
other antenna or transmitter.
The availability of some specific channels and/or operational frequency
bands are country dependent and are firmware programmed at the factory
to match the intended destination. The firmware setting is not accessible by
the end user.
RoHS
This product is RoHS compliant.
© Copyright 2021 TRENDnet. All Rights Reserved.
70
TRENDnet User’s Guide
TV‐IP420P
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the Directive
2004/108/EC and 2006/95/EC. The following test methods have been applied
in order to prove presumption of conformity with the essential requirements
of the Directive 2004/108/EC and 2006/95/EC:
Safety：EN60950‐1:2006+A11:2009+A1:2010+A12:2011+A2:2013
EMC: EN 55022:2010 CLASS B
EN50130‐4:2011
EN 61000‐3‐2:2014
EN 61000‐3‐3:2013
Directive： EMC Directive 2004/108/EC, RoHS Directive 2011/65/EU
WEEE Directive 2012/19/EU, REACH Regulation No.1907/2006
Česky [Czech]
TRENDnet tímto prohlašuje, že tento TV‐IP420P je ve shodě se
základními požadavky a dalšími příslušnými ustanoveními
směrnice 2004/108/ES a 2006/95/ES.
Dansk [Danish]
Undertegnede TRENDnet erklærer herved, at følgende udstyr
TV‐IP420P overholder de væsentlige krav og øvrige relevante
krav i direktiv 2004/108/EF og 2006/95/EF.
Hiermit erklärt TRENDnet, dass sich das Gerät TV‐IP420P in
Übereinstimmung mit den grundlegenden Anforderungen und
den übrigen einschlägigen Bestimmungen der Richtlinie
2004/108/EG und 2006/95/EG befindet.
Deutsch [German]
Eesti [Estonian]
English
Español [Spanish]
Ελληνική [Greek]
Käesolevaga kinnitab TRENDnet seadme TV‐IP420P vastavust
direktiivi 2004/108/EÜ ja 2006/95/EÜ põhinõuetele ja
nimetatud direktiivist tulenevatele teistele asjakohastele
sätetele.
Hereby, TRENDnet, declares that this TV‐IP420P is in
compliance with the essential requirements and other relevant
provisions of Directive 2004/108/EC and 2006/95/EC.
Por medio de la presente TRENDnet declara que el TV‐IP420P
cumple con los requisitos esenciales y cualesquiera otras
disposiciones aplicables o exigibles de la Directiva 2004/108/CE
y 2006/95/CE.
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑTRENDnet ΔΗΛΩΝΕΙ ΟΤΙ TV‐IP420P
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ
© Copyright 2021 TRENDnet. All Rights Reserved.
Français [French]
Italiano[Italian]
Latviski [Latvian]
Lietuvių
[Lithuanian]
Nederlands
[Dutch]
Malti [Maltese]
Magyar
[Hungarian]
Polski [Polish]
Português
[Portuguese]
Slovensko
[Slovenian]
Slovensky [Slovak]
Suomi [Finnish]
Svenska [Swedish]
ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2004/108/EK,
2006/95/ΕΚ και.
Par la présente TRENDnet déclare que l'appareil TV‐IP420P est
conforme aux exigences essentielles et aux autres dispositions
pertinentes de la directive 2004/108/CE, 2006/95/CE et.
Con la presente TRENDnet dichiara che questo TV‐IP420P è
conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 2004/108/CE e 2006/95/CE.
AršoTRENDnetdeklarē, ka TV‐IP420P atbilstDirektīvas
2004/108/EK un 2006/95/EK būtiskajāmprasībām un citiemar
to saistītajiemnoteikumiem.
Šiuo TRENDnet deklaruoja, kad šis TV‐IP420P atitinka esminius
reikalavimus ir kitas 2004/108/EB ir 2006/95/EB Direktyvos
nuostatas.
Hierbij verklaart TRENDnet dat het toestel TV‐IP420P in
overeenstemming is met de essentiële eisen en de andere
relevante bepalingen van richtlijn 2004/108/EG en 2006/95/EG.
Hawnhekk, TRENDnet, jiddikjara li dan TV‐IP420P jikkonforma
mal‐ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li
hemm fid‐Dirrettiva 2004/108/KE u 2006/95/KE.
Alulírott, TRENDnet nyilatkozom, hogy a TV‐IP420P megfelel a
vonatkozó alapvetõ követelményeknek és az 2004/108/EK és a
2006/95/EK irányelv egyéb elõírásainak.
Niniejszym TRENDnet oświadcza, że TV‐IP420P jest zgodny z
zasadniczymi wymogami oraz pozostałymi stosownymi
postanowieniami Dyrektywy 2004/108/WE i 2006/95/.
TRENDnet declara que este TV‐IP420P está conforme com os
requisitos essenciais e outras disposições da
Directiva2004/108/CE e 2006/95/CE.
TRENDnet izjavlja, da je ta TV‐IP420P v skladu z bistvenimi
zahtevami in ostalimi relevantnimi določili
direktive2004/108/ES in 2006/95/ES.
TRENDnettýmtovyhlasuje, že TV‐IP420P
spĺňazákladnépožiadavky a
všetkypríslušnéustanoveniaSmernice 2004/108/ES a
2006/95/ES.
TRENDnet vakuuttaa täten että TV‐IP420P tyyppinen laite on
direktiivin2004/108/EY ja 2006/95/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen mukainen.
Härmed intygar TRENDnet att denna TV‐IP420P står I
överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 2004/108/EG
och 2006/95/EG.
71
TRENDnet User’s Guide
TV‐IP420P
Limited Warranty
TRENDNET NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME
FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION
MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
TV‐IP420P – 3 Years Warranty
If a product does not operate as warranted during the applicable warranty period,
TRENDnet shall reserve the right, at its expense, to repair or replace the defective
product or part and deliver an equivalent product or part to the customer. The
repair/replacement unit’s warranty continues from the original date of purchase. All
products that are replaced become the property of TRENDnet. Replacement products
may be new or reconditioned. TRENDnet does not issue refunds or credit. Please
contact the point‐of purchase for their return policies.
TRENDnet shall not be responsible for any software, firmware, information, or
memory data of customer contained in, stored on, or integrated with any products
returned to TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product by any unauthorized service center. This warranty is voided if (i)
the product has been modified or repaired by any unauthorized service center, (ii)
the product was subject to accident, abuse, or improper use (iii) the product was
subject to conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet within the applicable
warranty period and providing a copy of the dated proof of the purchase. Upon
proper submission of required documentation a Return Material Authorization (RMA)
number will be issued. An RMA number is required in order to initiate warranty
service support for all TRENDnet products. Products that are sent to TRENDnet for
RMA service must have the RMA number marked on the outside of return packages
and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment.
Customers shipping from outside of the USA and Canada are responsible for return
shipping fees. Customers shipping from outside of the USA are responsible for
custom charges, including but not limited to, duty, tax, and other fees.
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS
WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT TRENDNET’S
OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE
EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
© Copyright 2021 TRENDnet. All Rights Reserved.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT
EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT,
IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR
MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY
ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO
EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN
CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL,
INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE
POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT,
OR REFUND OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS
DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY
PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Some TRENDnet products include software code written by third party developers.
These codes are subject to the GNU General Public License (“GPL”) or GNU Lesser
General Public License (“LGPL”).
Go to http://www.trendnet.com/gpl or http://www.trendnet.com Download section
and look for the desired TRENDnet product to access to the GPL Code or LGPL Code.
These codes are distributed WITHOUT WARRANTY and are subject to the copyrights
of the developers. TRENDnet does not provide technical support for these codes.
Please go to http://www.gnu.org/licenses/gpl.txt or http://www.gnu.org/licenses/
lgpl.txt for specific terms of each license.
2.2.2021
TV‐IP420P 2.0
72

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
