ARGUS smoke detector© Merten2005V5480-561-0003/08
GB
Smoke detector signals
½
ARGUS smoke detector
Operating instructions
|
Connections, displays and operating
elements
DANGER
Smoke fumes are poisonous and can quickly lead
to a loss of consciousness. In the event of fire, inform everyone in the household (smoke will not
wake people up, children tend to hide when in a
panic) and leave the building immediately. If there
is a lot of smoke, crawl along the floor. Do not expose yourself to unnecessary danger. Inform the
fire brigade (WHO, WHERE, WHAT)! - Your local
fire brigade is happy to advise you.
|
The next examples show you how many smoke detector
are necessary for the minimal und optimal protection rate:
A maximum of 25 detectors can be connected via wire.
Between two detectors the network cable may not be
longer than 25 m.
Minimal
Make sure that everyone in the building is familiar
with the signals of the smoke detector!
¼
G
The following LED and tone signals show the dependend status of the smoke detector:
A
...........
Wire networking is allowed with ARGUS smoke
detectors Connect only.
Wired networking with ARGUS smoke detectors
230 V/Connect 230 V is not allowed.
Smoke alarm
Think about how you can prevent fires and what
to do in case of a fire (escape plan, assembly
point, location of fire extinguishers, etc.).
CAUTION
F
B
...........
1
0
D
C
Getting to know the smoke detector
ARGUS smoke detector Connect
Art. no. MTN5480..
The ARGUS smoke detector Connect (referred to below
as the smoke detector) is a battery-powered smoke detector for early detection of smouldering fires and open
fires with smoke building-up indoor.
Normal operation
The red LED flashes every 40 seconds.
Accessories
– Sealing pin for ARGUS smoke detector
(Art. no. MTN547000)
– System relay flush-mounted for ARGUS smoke detector (Art. no. MTN548001)
You can use sealing pins to see whether the smoke detector is manipulated.
The flush-mounted system relay controls external alarm
devices.
For your safety
CAUTION
• Do not paint the smoke detector!
• The loud warning tone can damage your hearing (protect your ears when performing the
functional test).
• Smoke detectors do not extinguish a fire!
• Smoke detectors detect smoke, but no flames
or heat!
• The smoke detector only works with a functioning, correctly connected and inserted battery.
Installation without battery is not possible!
• Do not use rechargeable batteries or power
packs!
• The smoke detector monitors a specific area
around where it has been installed and not necessarily other rooms or other floors!
• There is a risk of explosion if the battery is not
replaced in the correctly. Do not damage, crush
or short circuit the battery. Do not use pointed
or sharp tools when replacing the battery. Only
use batteries of the same type when replacing
used batteries.
½
40 s
...........
Battery connection
C
Test button and LED (red)
D
Smoke detector
E
Switch for radio networking
F
Connection terminal for cable networking
G
Base
If you are away for longer than 30 days, you will
not hear the warning tone. Therefore, perform a
functional test directly after you return.
Battery empty
40 s
...........
40 s
...........
1
0
1
0
When you combine a radio smoke detector network with a wire smoke alarm network, there may
only be one smoke detector with active radio
operation in the wire smoke detector network!
How to mount the smoke detector
CAUTION
The smoke detector monitors a specific area
around where it has been installed and not necessarily other rooms or other floors!
1
1
0
1
0
1
0
=
1
0
=
1
0
1
0
... max. 10
There are group and device IDs.
• Group ID: for establishing a smoke detector group
• Device ID: for establishing an individual device address (for later use)
2
These group IDs are set using the 4 switches of the
switch bank located directly next to the network terminal.
When one smoke detector is triggered, the warning
tones of the other smoke detectors in the transmission
radius with the same group ID are triggered (the LED
only glows on the smoke detector triggered initially).
These smoke detectors are no longer able to transmit
the signal by radio, as they can only be receivers or
transmitters!
Watch out the following criterias for installing a smoke
detector:
3
min. 0,5 m
... max. 10
1
0
With a radio network, it is possible to assign different ID
numbers to ensure that other smoke detectors in the
neighbourhood (where the reception ranges overlap) are
not triggered, for example.
max. 8 m
The detector which detected the smoke will transmit the
alarm signal for at least 60 seconds and until it no longer
detects smoke. A receiving detector will check for an
alarm signal every 50 seconds. If no alarm signal comes
from the transmitting detector, the receiving detector will
also stop the alar.
=
1
0
Selecting the installation site
½
1
0
Optimal
CAUTION
If the alarm persists for more than five seconds, the radio
module will activate all other smoke detectors equipped
with a radio module in the range and they will also sound
the alarm.
|
Battery (9 V monobloc)
B
=
1
0
min. 0,5 m
max. 6 m
|
Defect of the smoke detector
...........
min. 0,3 m
...........
max. 60 m²
Do not install the smoke detector
• in areas where there is a draught (next to windows,
doors, etc.)
• in areas where there is steam/exhaust fumes/dust,
etc.
• next to lighting fixtures and ballasts (at least 1 m distance)
1 Mount the base with 2 srews.
2 Connect a 9 V battery and put it into the smoke detector.
3 Press the smoke detector from below to the base
and turn it anti-clockwise.
Radio operation is switched off when the ID has
been set to 0.0 (all switches to "0"). This is useful
if the smoke detector is only networked by cable.
For all other switch settings, radio operation is always switched on!
1
1
2
2
3
3
4
4
1
0
=0
1
0
=0
=
How to network the smoke detector
When using several smoke detectors it can make sense
to network the detectors with each other. When one detector is triggered, this triggers the rest of the detectors
in the network.
• Dispose used batteries according to the relevant regulations and without harming the environment.
1.
2.
...max. 40
ARGUS Connect smoke detectors can be connected via
the network terminal by wire or by integrated radio. Wired
networking is carried out via a separate cable (e.g. telephone cable).
V5480-561-00 03/08
½
40 s
If the battery is not supplying enough power, a tone will
sound every 40 seconds to supplement the flashing red
LED. The smoke detector will continue to function for another 30 days.
A
1
0
=
1
0
E
Network a maximum of 40 smoke detectors
How to operate the smoke detector
Technical data
Conduct a functional test
Battery:
• After installation
• Every time you change the battery
1.1
• After a long absence (more than 30 days)
= max. 40
1.x
1.4
1.2
1.x
max. 10
• At least once a year
Battery failure signal:
Optical display:
Sensitivity:
Volume of the signal
transmitter:
1.3
As a rule, several smoke detectors are combined to form
a system. More than 40 smoke detectors should never
be networked, regardless of whether the connections
are wireless or wired. If more than 40 radio detectors are
networked, then the time required until the last detector
has reacted will be too long to guarantee a reliable fire
alarm.
Maximum of 10 radio-networked smoke detectors
in one radio cell
Network:
Network cable:
1 Press the test button for at least 1 second.
As long as the test button is pressed, a pulsating warning
tone sounds and the red LED flashes.
If not, check the battery/battery connection or replace
the smoke detector.
2
3
1
Σ = max. 10
7
∅ 30 m
5
6
4
10
The smoke detector transmits a test alarm for 60 seconds. All other networked Connect smoke detectors will
detect this within 50 seconds and sound the alarm as
well.
We recommend that you replace your smoke detector after about ten years.
8
9
The maximum radio module range of 30 m means that
devices are surrounded by a radio cell with a diameter of
30 m. Within such a radio cell, 10 Connect smoke detectors may be radio-networked together.
In reality, the size of a radio cell is reduced by many factors. Structural conditions are just as much a factor as
with all other radio components. Walls and furniture, etc.
also cause attenuation, which must be taken into account. This is why a functional test is obligatory before final installation!
How to change the battery
½
up to 30 m/up to 100 m
0 °C to +60 °C
IP 42
112x44 mm (ø x H)
G207119
EN 14604
Schneider Electric Industries SAS
If you have technical questions, please contact the
Customer Care Center in your country.
www.schneider-electric.com
This product must be installed, connected and used in
compliance with prevailing standards and/or installation
regulations. As standards, specifications and designs
develop from time to time, always ask for confirmation of
the information given in this publication.
2
1.5
1.1
2.1
• There is a risk of explosion if the battery is not
replaced in the correctly. Do not damage, crush
or short circuit the battery. Do not use pointed
or sharp tools when replacing the battery. Only
use batteries of the same type when replacing
used batteries.
1
1.4
1.3
CAUTION
Cable length
Radio frequency:
Transmission range
Indoor/outdoor:
Operating temperature
range:
Type of protection
Dimensions:
VdS approval:
Accordring to:
approx. 85 dB(A) at a
distance of 3 m
up to 40 smoke alarms
Type: J.Y(St)Y 2x2x0.6
(e. g. telephone cable with
wire diametre of 0.6 mm)
up to 500 m total
868 MHz
• Dispose used batteries according to the relevant regulations and without harming the environment.
Maximum of 2 radio-networked smoke detectors in
one wired line
1.2
Battery life:
Device life:
Supply voltage:
9 V, monobloc battery, IEC
6LR61 (alkaline)
approx. 2 years
approx. 10 years
AC 230 V -15%/+10%
50 Hz
every 30 sec., 30 days
LED, red
EN 14604:2005
2.3
2.2
2.4
3.2
3.1
3.3
If 2 radio-networked smoke alarms already exist in the
wired line, then no additional wired lines may be connected to this system via radio.
Again, the reason is the running time for the signals,
which would be too long in such a system. The time between triggering the first detector and the reaction of the
last one would be too long to guarantee a reliable fire
alarm.
If there is only one radio-networked smoke alarm in wired
lines, then up to 10 wired lines may be networked via radio. The radio-networked smoke alarms of these wired
lines must all be in the same radio cell.
1 Turn the smoke detector clockwise and pull it downwards away from the base.
2 Change the battery.
3 Mount the smoke detector again.
Maintenance and care
Wipe the smoke detector clean (using a moist cloth only), carefully remove dust using a brush.
Carry out a functional test afterwards.
V5480-561-00 03/08
When Connect smoke detectors are wired to one another, they form a wired line. Within a line like this, a maximum of 2 radio-networked smoke alarms is allowed.
Each of these smoke alarms must always be assigned to
a different group ID. This type of network is conceivable
in a multiple family house, where two flats are connected
to each other. Radio operation for all other smoke detectors in this wired line must be switched off (ID = 0.0).
