MC75 Poster
PANTONE 285 BLACK
MC75
Quick Start Guide
1
2
12
3
FEATURES
9
10
11
8 (Note 1)
7
6
5
4
1
2
3
4
Scan/Action Button
Up/Down Button
Microphone
I/O Connector
5
6
7
8
Keypad
Scan/Action Button
Touch Screen
(with screen protector)
Power Button
9 Scan/Decode LED
10 Charging/Battery
Status LED
11 Radio Status LED
12 Phone Speaker
Note 1: To reset the MC75, press and hold the Power button for five (5) seconds.
KEYPADS
13 Battery Door
14 Handstrap
15 Handstrap Slot
16 Headset Jack
16
17
18
19
20
21
22
13
14
15
17 Camera Flash
18 Camera
19 Speaker
20 Exit Window
(see Data Capture Options)
21 Stylus
22 Tether Point
23 Scan/Action Button
24 Action Button
25 Back Housing Bracket
26 Memory Card Cover
27 IrDA Window
28 Battery Door Latch
28
25
24
23
26
27
1 Talk
2 Soft Key
3 Navigation
4 Scan/Action Button
5 End
6 Orange Key
7 Backlight
8 Blue Key
9 OK
10 Phonepad*
11 Menu*
12 Start Menu
7
12
2 3
1
1
8
2
3
4
4 3
3
12
11
10
8
7
* Alpha-numeric keypad only.
6
9
Blue Key
Use this key to launch applications and select items (shown on the keypad in blue).
> Press the key once to activate this mode followed by another key.
Orange Key
Use this key to access the secondary layer of characters and actions.
> Press the key once to lock the keypad in the Alpha state.
> Press the key a second time to return to the normal state.
2
5
6
2
5
9
3
GETTING STARTED
1
Insert the Battery
1
4
Note 2: 3600 mAh capacity battery and door shown.
2
2
Charge the MC75
1-Slot Cradle
24hr *
4-Slot Cradle
Charging/Battery Status LED
3
Install ActiveSync ®
Download ActiveSync ® 4.5 or higher from http://www.microsoft.com and follow the instructions to install ActiveSync onto the host computer.
4
Communicate with Host
Charging/Battery Status LED
Slow Blinking Amber = Charging
Solid Amber = Fully Charged
Fast Blinking Amber = Charging Error
* It is recommended that this product be charged for 24 hours before the first use to ensure that the internal battery is fully charged.
5
Create a Partnership
Follow the on-screen ActiveSync instructions to establish a connection between the MC75 and the host computer.
PANTONE 285 BLACK
SUPPORT INFORMATION
More Information on the MC75
Visit the Motorola Web site at http://www.motorola.com/mc75
Setting up, using and troubleshooting the MC75
MC75 User Guide
MC75 Integrator Guide
Available at: http://www.motorola.com/mc75
Additional Software
Check Motorola web site for approved applications.
http://www.motorola.com/mc75
Connecting and synchronizing with the host computer
ActiveSync ® Help on the host computer. To view help, start ActiveSync ® ,
Click Help - Microsoft ActiveSync Help.
Information on using programs on the MC75
Tap Start – Help within the specific program.
Service and Warranty
MC75 Regulatory Guide
Motorola, Inc.
One Motorola Plaza Holtsville, New York 11742-1300, USA
MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their respective owners.
© Motorola, Inc. 2008
72-103079-02 Rev. A — August 2008
MC75
Quick Start Guide
SIM Card Installation (Located Under Battery)
Stylus
(MC75X6 only)
1 Use stylus to open door 2 Lift door
ACCESSORIES
Screen Protector
Motorola recommends the use of a screen protector to minimize wear and tear. Screen protectors enhance the usability and durability of touch screen displays. Benefits include:
• Protection from scratches and gouges
• Durable writing and touch surface with tactile feel
• Abrasion and chemical resistance
• Glare reduction
• Keeping the device’s screen looking like new
• Quick and easy installation.
Not using a screen protector can affect your warranty coverage.
An initial screen protector is already applied to your MC75.
Contact your local account manager or Motorola, Inc. for more information and purchasing details. Part number:
KT-67525-01R Screen Protector 3/pk.
Vehicle Cradle
3
5
7
Place SIM card with contacts facing down
4
6
Snap door closed
Replace battery and door Ensure Phone is turned on.
Press red Power button for five seconds to warm boot
MicroSD Card Installation
Contacts Face Up http://www.motorola.com/mc75
3600 mAh Capacity Battery: ~ 5 hours
Charge in Cradle
Flashing Amber: Battery charging
Solid Amber: Battery fully charged
4800 mAh Capacity Battery: ~ 7 hours
Spare Battery Charger
Flashing Amber: Battery charging
Solid Amber: Battery fully charged
Snap-On Accessories
Magnetic Stripe Reader Cables
DATA CAPTURE OPTIONS
Exit Window
Laser scanner or Imager
Camera Lens
OPTIMUM SCANNING AND IMAGING AVOID EXTREME WRIST ANGLES
Scanning/Imaging
Scanning
GPS INFORMATION
When using the GPS feature of the MC75:
•
Acquiring satellite signals may take a few minutes. It is best to be
• outside and have a clear, unobstructed view of the sky.
Without a clear view, acquisition takes much longer and could result in the MC75 being unable to compute the initial position quickly.
•
Obtain a satellite fix before moving.
•
Shutdown GPS application when not in use.
Imaging
AVOID EXTREME
WRIST ANGLES
