Schneider Electric Model IMT30A Magnetic Flow Signal Converter. Master Instruction Sheet

Instruction
MI 021-517 en
APR 2020
Model IMT30A Magnetic Flow Transmitter
Master Instruction
: IMPRINT ::::::::::::::::::::::::::::::::::::::::::::
All rights reserved. It is prohibited to reproduce this documentation, or any part thereof, without
the prior written authorisation of Schneider Electric Systems USA, Inc.
Copyright 2019-2020 Schneider Electric Systems USA, Inc.
2
www.se.com
MI 021-517 en - APR 2020
CONTENTS
IMT30A
1 Safety instructions
1.1
1.2
1.3
1.4
6
Software history ............................................................................................................... 6
Intended use ..................................................................................................................... 7
Certifications .................................................................................................................... 7
Safety instructions from the manufacturer ..................................................................... 8
1.4.1
1.4.2
1.4.3
1.4.4
1.4.5
Copyright and data protection ................................................................................................ 8
Disclaimer ............................................................................................................................... 8
Product liability and warranty ................................................................................................ 9
Information concerning the documentation........................................................................... 9
Warnings and symbols used................................................................................................. 10
1.5 Safety instructions for the operator............................................................................... 11
2 Device description
12
2.1 Scope of delivery............................................................................................................. 12
2.2 Device description .......................................................................................................... 13
2.3 Nameplates .................................................................................................................... 14
3 Installation
3.1
3.2
3.3
3.4
3.5
3.6
15
General notes on installation ......................................................................................... 15
Storage ........................................................................................................................... 15
Transport ........................................................................................................................ 15
Installation specifications .............................................................................................. 15
Mounting of the compact version................................................................................... 16
Mounting of the wall housing, remote version .............................................................. 16
4 Electrical connections
18
4.1 Safety instructions.......................................................................................................... 18
4.2 Important notes on electrical connection...................................................................... 18
4.3 Electrical cables for remote device versions, notes...................................................... 19
4.3.1 Notes on signal cable A ........................................................................................................ 19
4.3.2 Notes on field current cable C.............................................................................................. 19
4.3.3 Requirements for signal cables provided by the customer ................................................. 20
4.4 Preparing the signal and field current cables ............................................................... 21
4.4.1
4.4.2
4.4.3
4.4.4
4.4.5
4.4.6
Signal cable A (type DS 300), construction........................................................................... 21
Preparing signal cable A, connection to transmitter ........................................................... 22
Length of signal cable A........................................................................................................ 23
Preparing field current cable C, connection to transmitter ................................................ 24
Preparing signal cable A, connection to flow tube............................................................... 26
Preparing field current cable C, connection to flow tube .................................................... 27
4.5 Connecting the signal and field current cables ............................................................. 28
4.5.1 Connecting the signal and field current cables to the transmitter, remote version........... 29
4.5.2 Connection diagram for signal and field current cable ....................................................... 30
MI 021-517 en - APR 2020
www.se.com
3
CONTENTS
IMT30A
4.6 Grounding the flow tube ................................................................................................. 31
4.7 Connecting the power supply ......................................................................................... 31
4.8 Inputs and outputs, overview ......................................................................................... 33
4.8.1 Description of the CG number .............................................................................................. 33
4.8.2 Fixed, non-alterable output versions ................................................................................... 33
4.9 Description of the inputs and outputs............................................................................ 34
4.9.1 Current output ...................................................................................................................... 34
4.9.2 Pulse output and frequency output ...................................................................................... 35
4.9.3 Status output and limit switch .............................................................................................. 36
4.10 Electrical connection of the outputs ............................................................................ 37
4.10.1 Electrical connection of the outputs................................................................................... 37
4.10.2 Laying electrical cables correctly....................................................................................... 38
4.11 Connection diagrams of outputs .................................................................................. 38
4.11.1
4.11.2
4.11.3
4.11.4
Important notes................................................................................................................... 38
Description of the electrical symbols ................................................................................. 39
Basic and Modbus outputs.................................................................................................. 40
HART connection................................................................................................................. 45
5 Start-up
47
5.1 Switching on the power .................................................................................................. 47
5.2 Starting the transmitter ................................................................................................. 47
6 Operation
48
6.1 Safety instructions for the use of the magnet pencil..................................................... 48
6.2 Display and operating elements .................................................................................... 48
6.2.1
6.2.2
6.2.3
6.2.4
Display in measuring mode with 2 or 3 measured values ................................................... 50
Display for selection of submenu and functions, 3 lines ..................................................... 50
Display when setting parameters, 4 lines ............................................................................ 51
Display when previewing parameters, 4 lines...................................................................... 52
6.3 Menu structure ............................................................................................................... 53
6.4 Function tables ............................................................................................................... 55
6.4.1
6.4.2
6.4.3
6.4.4
Menu "A quick setup"............................................................................................................ 55
Menu "B test" ........................................................................................................................ 57
Menu "C setup" ..................................................................................................................... 58
Set free units......................................................................................................................... 67
6.5 Description of functions ................................................................................................. 68
6.5.1 Reset counter in the menu "quick setup" ............................................................................ 68
6.5.2 Deleting error messages in the menu "quick setup"........................................................... 68
6.6 Status messages and diagnostic information................................................................ 69
4
www.se.com
MI 021-517 en - APR 2020
CONTENTS
IMT30A
7 Service
73
7.1 Spare parts availability................................................................................................... 73
7.2 Availability of services .................................................................................................... 73
7.3 Returning the device to the manufacturer..................................................................... 73
7.3.1 General information.............................................................................................................. 73
7.3.2 Preapproval form - Customer returned process-wetted products..................................... 74
7.4 Disposal .......................................................................................................................... 75
8 Technical data
76
8.1 Measuring principle........................................................................................................ 76
8.2 Technical data................................................................................................................. 77
8.3 Dimensions and weight .................................................................................................. 84
8.3.1 Housing ................................................................................................................................. 84
8.3.2 Mounting plate, wall version................................................................................................. 86
8.4 Flow tables ..................................................................................................................... 87
8.5 Measuring accuracy ....................................................................................................... 89
9 Notes
MI 021-517 en - APR 2020
90
www.se.com
5
1 SAFETY INSTRUCTIONS
IMT30A
1.1 Software history
The "Electronic Revision" (ER) is consulted to document the revision status of electronic
equipment according to NE 53 for all devices. It is easy to see from the ER whether
troubleshooting or larger changes in the electronic equipment have taken place and how that
has affected the compatibility.
1
Downwards compatible changes and fault repair with no effect on operation
(e.g. spelling mistakes on display)
2-_
Downwards compatible hardware and/or software change of interfaces:
3-_
H
HART®
M
Modbus
X
all interfaces
Downwards compatible hardware and/or software change of inputs and outputs:
I
Current output
F, P
Frequency / pulse output
S
Status output
L
Limit switch
X
all inputs and outputs
4
Downwards compatible changes with new functions
5
Incompatible changes, i.e. electronic equipment must be changed
Table 1-1: Description of changes
NOTICE!
In the table below, "_" is a placeholder for possible multi-digit alphanumeric combinations,
depending on the available version.
Release date
Electronic revision
Changes and
compatibility
Issue date of
documentation
2016
ER3.0.3_
Initial version
FEB 2016
2017
ER3.0.3_
-
MAY 2017
APR 2020
Table 1-2: Changes and effect on compatibility
6
www.se.com
MI 021-517 en - APR 2020
SAFETY INSTRUCTIONS 1
IMT30A
1.2 Intended use
The electromagnetic flowmeters are designed exclusively to measure the flow and conductivity
of electrically conductive, liquid media.
WARNING!
If the device is not used according to the operating conditions (refer to chapter "Technical
data"), the intended protection could be affected.
NOTICE!
This device is a Group 1, Class A device as specified within CISPR11:2009. It is intended for use
in industrial environment. There may be potential difficulties in ensuring electromagnetic
compatibility in other environments, due to conducted as well as radiated disturbances.
WARNING!
NOT
SUIT
ABLE
FOR
DIG
PROC
OCESS
CO
NTRO
ROL
NO
T SUI
TABL
E FO
R DI
GITAL PR
OC
ESS C
ONT
RO
L
Do not use this product for digital control of a process.
Electromagnetic noise can cause the HART communication channel to stop responding,
requiring a power cycle to the transmitter to recover.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
1.3 Certifications
CE marking
The manufacturer certifies successful testing of the product by applying the CE mark.
This device fulfils the statutory requirements of the relevant EU directives.
For full information of the EU directives and standards and the approved certifications, please
refer to the EU Declaration of Conformity or the website of the manufacturer.
Other approvals and standards
• NAMUR recommendations NE 21 and NE 43
MI 021-517 en - APR 2020
www.se.com
7
1 SAFETY INSTRUCTIONS
IMT30A
1.4 Safety instructions from the manufacturer
1.4.1 Copyright and data protection
The contents of this document have been created with great care. Nevertheless, we provide no
guarantee that the contents are correct, complete or up-to-date.
The contents and works in this document are subject to copyright. Contributions from third
parties are identified as such. Reproduction, processing, dissemination and any type of use
beyond what is permitted under copyright requires written authorisation from the respective
author and/or the manufacturer.
The manufacturer tries always to observe the copyrights of others, and to draw on works created
in-house or works in the public domain.
The collection of personal data (such as names, street addresses or e-mail addresses) in the
manufacturer's documents is always on a voluntary basis whenever possible. Whenever
feasible, it is always possible to make use of the offerings and services without providing any
personal data.
We draw your attention to the fact that data transmission over the Internet (e.g. when
communicating by e-mail) may involve gaps in security. It is not possible to protect such data
completely against access by third parties.
We hereby expressly prohibit the use of the contact data published as part of our duty to publish
an imprint for the purpose of sending us any advertising or informational materials that we have
not expressly requested.
1.4.2 Disclaimer
The manufacturer will not be liable for any damage of any kind by using its product, including,
but not limited to direct, indirect or incidental and consequential damages.
This disclaimer does not apply in case the manufacturer has acted on purpose or with gross
negligence. In the event any applicable law does not allow such limitations on implied warranties
or the exclusion of limitation of certain damages, you may, if such law applies to you, not be
subject to some or all of the above disclaimer, exclusions or limitations.
Any product purchased from the manufacturer is warranted in accordance with the relevant
product documentation and our Terms and Conditions of Sale.
The manufacturer reserves the right to alter the content of its documents, including this
disclaimer in any way, at any time, for any reason, without prior notification, and will not be liable
in any way for possible consequences of such changes.
8
www.se.com
MI 021-517 en - APR 2020
SAFETY INSTRUCTIONS 1
IMT30A
1.4.3 Product liability and warranty
The operator shall bear responsibility for the suitability of the device for the specific purpose.
The manufacturer accepts no liability for the consequences of misuse by the operator. Improper
installation or operation of the devices (systems) will cause the warranty to be void. The
respective "Standard Terms and Conditions" which form the basis for the sales contract shall
also apply.
1.4.4 Information concerning the documentation
To prevent any injury to the user or damage to the device it is essential that you read the
information in this document and observe applicable national standards, safety requirements
and accident prevention regulations.
If this document is not in your native language and if you have any problems understanding the
text, we advise you to contact your local office for assistance. The manufacturer can not accept
responsibility for any damage or injury caused by misunderstanding of the information in this
document.
This document is provided to help you establish operating conditions, which will permit safe and
efficient use of this device. Special considerations and precautions are also described in the
document, which appear in the form of icons as shown below.
MI 021-517 en - APR 2020
www.se.com
9
1 SAFETY INSTRUCTIONS
IMT30A
1.4.5 Warnings and symbols used
Safety warnings are indicated by the following symbols.
DANGER!
This warning refers to the immediate danger when working with electricity.
DANGER!
This warning refers to the immediate danger of burns caused by heat or hot surfaces.
DANGER!
This warning refers to the immediate danger when using this device in a hazardous
atmosphere.
DANGER!
These warnings must be observed without fail. Even partial disregard of this warning can lead
to serious health problems and even death.
WARNING!
Disregarding this safety warning, even if only in part, poses the risk of serious health problems.
There is also the risk of damaging the device or parts of the operator's plant.
CAUTION!
Disregarding these instructions can result in damage to the device or to parts of the operator's
plant.
NOTICE!
These instructions contain important information for the handling of the device.
LEGAL NOTICE!
This note contains information on statutory directives and standards.
• HANDLING
This symbol designates all instructions for actions to be carried out by the operator in the
specified sequence.
i RESULT
This symbol refers to all important consequences of the previous actions.
10
www.se.com
MI 021-517 en - APR 2020
SAFETY INSTRUCTIONS 1
IMT30A
1.5 Safety instructions for the operator
WARNING!
In general, devices from the manufacturer may only be installed, commissioned, operated and
maintained by properly trained and authorized personnel.
This document is provided to help you establish operating conditions, which will permit safe
and efficient use of this device.
MI 021-517 en - APR 2020
www.se.com
11
2 DEVICE DESCRIPTION
IMT30A
2.1 Scope of delivery
NOTICE!
Inspect the packaging carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
NOTICE!
Do a check of the packing list to make sure that you have all the elements given in the order.
NOTICE!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Figure 2-1: Scope of delivery
1
2
3
4
12
Device in the version as ordered
Magnet pencil (to operate the transmitter when the housing is closed)
Documentation (calibration report, DVD with product documentation for flow tube and transmitter)
Signal cable (only for remote version)
www.se.com
MI 021-517 en - APR 2020
DEVICE DESCRIPTION 2
IMT30A
2.2 Device description
Electromagnetic flowmeters are designed exclusively to measure the flow and conductivity of
electrically conductive, liquid media.
Your measuring device is supplied ready for operation. The factory settings for the operating
data have been made in accordance with your order specifications.
The following versions are available:
• Compact version (the transmitter is mounted directly on the flow tube)
• Remote version (electrical connection to the flow tube via field current and signal cable)
Figure 2-2: Device versions
1 Compact version
2 Flow tube with connection box
3 Wall version
MI 021-517 en - APR 2020
www.se.com
13
2 DEVICE DESCRIPTION
IMT30A
2.3 Nameplates
NOTICE!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Figure 2-3: Example of a nameplate
1
2
3
4
5
6
14
Manufacturer address
Data for power supply
Software revision number (Electronic Revision)
Maximum working pressure
GK/GKL values (flow tube constants), size (mm/inch), field frequency, ingress protection and materials of wetted parts
Product designation, serial number, manufacturing date and country, disposal and China RoHs marking
www.se.com
MI 021-517 en - APR 2020
INSTALLATION 3
IMT30A
3.1 General notes on installation
NOTICE!
Inspect the packaging carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
NOTICE!
Do a check of the packing list to make sure that you have all the elements given in the order.
NOTICE!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
3.2 Storage
•
•
•
•
Store the device in a dry, dust-free location.
Avoid continuous direct sunlight.
Store the device in its original packing.
Storage temperature: -40...+70°C / -40...+158°F
3.3 Transport
Transmitter
• No special requirements.
Compact version
• Do not lift the device by the transmitter housing.
• Do not use lifting chains.
• To transport flange devices, use lifting straps. Wrap these around both process connections.
3.4 Installation specifications
NOTICE!
The following precautions must be taken to ensure reliable installation.
• Make sure that there is adequate space to the sides.
• The device must not be heated by radiated heat (e.g. exposure to the sun) to an electronics
housing surface temperature above the maximum permissible ambient temperature. If it is
necessary to prevent damage from heat sources, a heat protection (e.g. sun shade) has to be
installed.
• Transmitters installed in control cabinets require adequate cooling, e.g. by fan or heat
exchanger.
• Do not expose the transmitter to intense vibrations. The measuring devices are tested for a
vibration level as described in the chapter "Technical data".
MI 021-517 en - APR 2020
www.se.com
15
3 INSTALLATION
IMT30A
3.5 Mounting of the compact version
NOTICE!
The transmitter is mounted directly on the flow tube. For installation of the flowmeter, please
observe the instructions in the supplied product documentation for the flow tube.
3.6 Mounting of the wall housing, remote version
NOTICE!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 3-1: Mounting of the wall housing
1 Prepare the holes with the aid of the mounting plate. For further information refer to Mounting
plate, wall version on page 86.
2 Fasten the device securely to the wall with the mounting plate.
16
www.se.com
MI 021-517 en - APR 2020
INSTALLATION 3
IMT30A
g h
f
e
Figure 3-2: Dimensions of mounting plate and distances when mounting multiple devices next to each other
1 277 mm / 10.89"
2 310 mm / 12.2"
[mm]
[inch]
a
Ø6.5
Ø0.26
b
Ø8.1
Ø0.3
c
15
0.6
d
40
1.6
e
96
3.8
f
20
0.8
g
248
9.8
h
268
10.5
k
35
1.4
l
55
2.2
Table 3-1: Dimensions in mm and inch
MI 021-517 en - APR 2020
www.se.com
17
4 ELECTRICAL CONNECTIONS
IMT30A
4.1 Safety instructions
DANGER!
All work on the electrical connections may only be carried out with the power disconnected.
Take note of the voltage data on the nameplate!
DANGER!
Observe the national regulations for electrical installations!
WARNING!
Observe without fail the local occupational health and safety regulations.
Any work done on the electrical components of the measuring device may only be carried out by
properly trained specialists.
NOTICE!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
4.2 Important notes on electrical connection
DANGER!
Electrical connection is carried out in conformity with the VDE 0100 directive "Regulations for
electrical power installations with line voltages up to 1000 V" or equivalent national
specifications.
CAUTION!
• Use suitable cable entries for the various electrical cables.
• The flow tube and transmitter have been configured together at the factory. For this reason,
please connect the devices in pairs. Ensure that the flow tube constant GKL (refer to
information on the nameplates) are identically set.
• If delivered separately or when installing devices that were not configured together, set the
transmitter to the DN size and GKL of the flow tube, refer to Function tables on page 55.
18
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.3 Electrical cables for remote device versions, notes
4.3.1 Notes on signal cable A
NOTICE!
Signal cable A (type DS 300) with double shield ensures proper transmission of measured
values.
Observe the following notes:
•
•
•
•
Lay the signal cable with fastening elements.
It is permissible to lay the signal cable in water or in the ground.
The insulating material is flame-retardant.
The signal cable does not contain any halogens and is unplasticized, and remains flexible at
low temperatures.
• The connection of the inner shield (10) is carried out via the stranded drain wire (1).
• The connection of the outer shield (60) is carried out via the stranded drain wire (6).
4.3.2 Notes on field current cable C
DANGER!
A shielded 2-wire copper cable is used for the field current cable. The shielding MUST be
connected in the housing of the flow tube and transmitter.
NOTICE!
The field current cable is not part of the scope of delivery.
MI 021-517 en - APR 2020
www.se.com
19
4 ELECTRICAL CONNECTIONS
IMT30A
4.3.3 Requirements for signal cables provided by the customer
NOTICE!
If the signal cable was not ordered, it is to be provided by the customer. The following
requirements regarding the electrical values of the signal cable must be observed:
Electrical safety
• According to low voltage directive or equivalent national regulations.
Capacitance of the insulated conductors
• Insulated conductor / insulated conductor < 50 pF/m
• Insulated conductor / shield < 150 pF/m
Insulation resistance
• Riso > 100 GΩ x km
• Umax < 24 V
• Imax < 100 mA
Test voltages
• Insulated conductor / inner shield 500 V
• Insulated conductor / insulated conductor 1000 V
• Insulated conductor / outer shield 1000 V
Twisting of the insulated conductors
• At least 10 twists per meter, important for screening magnetic fields.
20
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.4 Preparing the signal and field current cables
NOTICE!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
4.4.1 Signal cable A (type DS 300), construction
• Signal cable A is a double-shielded cable for signal transmission between the flow tube and
transmitter.
• Bending radius: ≥ 50 mm / 2"
Figure 4-1: Construction of signal cable A
1 Stranded drain wire (1) for the inner shield (10), 1.0 mm2 Cu / AWG 17 (not insulated, bare)
2 Insulated wire (2), 0.5 mm2 Cu / AWG 20
3
4
5
6
Insulated wire (3), 0.5 mm2 Cu / AWG 20
Outer sheath
Insulation layers
Stranded drain wire (6) for the outer shield (60)
MI 021-517 en - APR 2020
www.se.com
21
4 ELECTRICAL CONNECTIONS
IMT30A
4.4.2 Preparing signal cable A, connection to transmitter
NOTICE!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
• Connection of the two shields in the transmitter is carried out via the stranded drain wires.
• Bending radius: ≥ 50 mm / 2"
Required materials
•
•
•
•
PVC insulating tube, Ø2.5 mm / 0.1"
Heat-shrinkable tubing
2 wire end ferrules to DIN 46228: E 1.5-8 for the stranded drain wires (1, 6)
2 wire end ferrules to DIN 46228: E 0.5-8 for the insulated conductors (2, 3)
Figure 4-2: Preparation of signal cable A
a = 80 mm / 3.15"
1 Strip the conductor to dimension a.
2 Cut off the inner shield (10) and the outer shield (60). Make sure not to damage the stranded
drain wires (1, 6).
3 Slide the insulating tubes over the stranded drain wires (1, 6).
4 Crimp the wire end ferrules onto the stranded drain wire.
5 Crimp the wire end ferrules onto the conductors (2, 3).
6 Pull the heat-shrinkable tubing over the prepared signal cable.
22
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.4.3 Length of signal cable A
NOTICE!
For temperatures of the medium above 150°C / 300°F, a special signal cable and a ZD
intermediate socket are necessary. These are available including the changed electrical
connection diagrams.
Flow tube
Nominal size
DN [mm]
[inch]
Min. electrical
conductivity
[µS/cm]
Curve for signal
cable A
8400A
10...150
3/8...6
20
A1
8500A
2.5...100
1/10…4
20
A1
9500A
25...150
1...6
20
A1
200...1200
8...48
20
A2
9600A
10...150
3/8...6
20
A1
9700A
10...150
3/8...6
20
A1
200...1200
8...48
20
A2
Table 4-1: Length of signal cable A
Figure 4-3: Maximum length of signal cable A
1 Maximum length of signal cable A between the flow tube and transmitter [m]
2 Maximum length of signal cable A between the flow tube and transmitter [ft]
3 Electrical conductivity of the medium being measured [μS/cm]
MI 021-517 en - APR 2020
www.se.com
23
4 ELECTRICAL CONNECTIONS
IMT30A
4.4.4 Preparing field current cable C, connection to transmitter
DANGER!
A shielded 2-wire copper cable is used as the field current cable. The shielding MUST be
connected in the housing of the flow tube and transmitter.
NOTICE!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
• Field current cable C is not part of the scope of delivery.
• Bending radius: ≥ 50 mm / 2"
Required materials:
• Shielded, at least 2-wire copper cable with suitable heat-shrinkable tubing
• Insulating tube, size according to the cable being used
• Wire end ferrules to DIN 46228: size according to the cable being used
Length
[m]
Cross-section AF (Cu)
[ft]
[mm2]
[AWG]
0...150
0...492
2 x 0.75 Cu 1
2 x 18
150...300
492...984
2 x 1.5 Cu 1
2 x 14
300...600
984...1968
2 x 2.5 Cu 1
2 x 12
Table 4-2: Length and cross-section of field current cable C
1 Cu = copper cross-section
24
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
Figure 4-4: Field current cable C, preparation for the transmitter
a = 80 mm / 3.15"
1 Strip the conductor to dimension a.
2 If a stranded drain wire is present, remove the shield that is present. Make sure not to damage
the stranded drain wire.
3 Slide an insulating tube over the stranded drain wire.
4 Crimp a wire end ferrule onto the stranded drain wire.
5 Crimp the wire end ferrules on the conductors.
6 Pull a shrinkable tube over the prepared cable.
MI 021-517 en - APR 2020
www.se.com
25
4 ELECTRICAL CONNECTIONS
IMT30A
4.4.5 Preparing signal cable A, connection to flow tube
NOTICE!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
• The outer shield (60) is connected in the terminal compartment of the flow tube directly via
the shield and a clip.
• Bending radius: ≥ 50 mm / 2"
Required materials
•
•
•
•
PVC insulating tube, Ø2.0...2.5 mm / 0.08...0.1"
Heat-shrinkable tubing
Wire end ferrule to DIN 46228: E 1.5-8 for the stranded drain wire (1)
2 wire end ferrules to DIN 46228: E 0.5-8 for the insulated conductors (2, 3)
Figure 4-5: Preparing signal cable A, connection to flow tube
a = 50 mm / 2"
b = 10 mm / 0.4"
1 Strip the conductor to dimension a.
2 Trim the outer shield (60) to dimension b and pull it over the outer sheath.
3 Remove the stranded drain wire (6) of the outer shield and the inner shield. Make sure not to
damage the stranded drain wire (1) of the inner shield.
4 Slide an insulating tube over the stranded drain wire (1).
5 Crimp the wire end ferrules onto conductors 2 and 3 and the stranded drain wire (1).
6 Pull the heat-shrinkable tubing over the prepared signal cable.
26
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.4.6 Preparing field current cable C, connection to flow tube
NOTICE!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
• The field current cable is not part of the scope of delivery.
• The shield is connected in the terminal compartment of the flow tube directly via the shield
and a clip.
• Bending radius: ≥ 50 mm / 2"
Required materials
•
•
•
•
Shielded 2-wire insulated copper cable
Insulating tube, size according to the cable being used
Heat-shrinkable tubing
Wire end ferrules to DIN 46228: size according to the cable being used
Figure 4-6: Preparation of field current cable C
a = 50 mm / 2"
b = 10 mm / 0.4"
1
2
3
4
Strip the conductor to dimension a.
Trim the outer shield to dimension b and pull it over the outer sheath.
Crimp wire end ferrules onto both conductors.
Pull a shrinkable tube over the prepared cable.
MI 021-517 en - APR 2020
www.se.com
27
4 ELECTRICAL CONNECTIONS
IMT30A
4.5 Connecting the signal and field current cables
DANGER!
Cables may only be connected when the power is switched off.
DANGER!
The device must be grounded in accordance with regulations in order to protect personnel
against electric shocks.
WARNING!
Observe without fail the local occupational health and safety regulations.
Any work done on the electrical components of the measuring device may only be carried out by
properly trained specialists.
28
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.5.1 Connecting the signal and field current cables to the transmitter, remote version
NOTICE!
The compact version is supplied pre-assembled from the factory.
Connect the electrical conductors as follows:
1 Press with a screwdriver in the slot on the spring terminal.
2 Insert the electrical conductor into the plug.
3 The conductor will be clamped as soon as the screwdriver is pulled out of the slot.
Figure 4-7: Connecting the signal and field current cables
1
2
3
4
5
6
7
8
9
Cable entry for field current cable
Cable entry for signal cable
Electrical conductor (7)
Electrical conductor (8)
Connecting the field current cable shield
Stranded drain wire (1) of the inner shield (10) of the signal cable
Electrical conductor (2)
Electrical conductor (3)
Stranded drain wire (S) of the outer shield (60)
MI 021-517 en - APR 2020
www.se.com
29
4 ELECTRICAL CONNECTIONS
IMT30A
4.5.2 Connection diagram for signal and field current cable
DANGER!
The device must be grounded in accordance with regulations in order to protect personnel
against electric shocks.
• A shielded 2-wire copper cable is used as the field current cable. The shielding MUST be
connected in the housing of the flow tube and transmitter.
• The outer shield (60) is connected in the terminal compartment of the flow tube directly via
the shield and a clip.
• Bending radius of signal and field current cable: ≥ 50 mm / 2"
• The following illustration is schematic. The positions of the electrical connection terminals
may vary depending on the housing version.
Figure 4-8: Connection diagram for signal and field current cable
1
2
3
4
5
30
Electrical terminal compartment in the transmitter
Signal cable A
Field current cable C
Electrical terminal compartment in the flow tube
Functional ground FE
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.6 Grounding the flow tube
CAUTION!
There should be no difference in potential between the flow tube and the housing or protective
earth of the transmitter!
• The flow tube must be properly grounded.
• The grounding cable should not transmit any interference voltages.
• Do not use the grounding cable to connect any other electrical devices to ground at the same
time.
• The flow tubes are connected to ground by means of a functional grounding conductor FE.
• Special grounding instructions for the various flow tubes are provided in the separate
documentation for the flow tube.
• The documentation for the flow tube also contain descriptions on how to use grounding rings
and how to install the flow tube in metal or plastic pipes or in pipes which are coated on the
inside.
4.7 Connecting the power supply
DANGER!
• To protect operators from electrical shock, during installation the cable for the power
supply must be run with sheathing insulation up to the mains cover. The insulated individual
wires have to be only below the mains cover!
• If there is no mains cover or if it has been lost, the 100...230 VAC device may only be
operated from the outside (with a magnet pencil) while closed!
• The housings of the devices, which are designed to protect the electronic equipment from
dust and moisture, should be kept well closed at all times. Creepage distances and
clearances are dimensioned to VDE 0110 and IEC 60664 for pollution severity 2.
Supply circuits are designed for overvoltage category III and the output circuits for
overvoltage category II.
• Fuse protection (IN ≤ 16 A) for the infeed power circuit, and also a separator (switch, circuit
breaker) to isolate the transmitter must be provided.
MI 021-517 en - APR 2020
www.se.com
31
4 ELECTRICAL CONNECTIONS
IMT30A
Figure 4-9: Terminal compartment for power
1
2
3
4
5
Cable entry for power supply
Mains cover
Ground terminal
100...230 VAC (-15% / +10%)
24 VDC (-30% /+30%)
• To open the cover of the electrical terminal compartment, lightly press in the side walls of the
mains cover 2.
• Flip the mains cover up.
• Connect the power supply.
• Close the mains cover again by flipping it down.
100...230 VAC (tolerance range: -15% / +10%)
• Note the power supply voltage and frequency (50...60 Hz) on the nameplate.
NOTICE!
240 VAC + 5% is included in the tolerance range.
24 VDC (tolerance range: -30% / +30%)
• Note the data on the nameplate!
• When connecting to functional extra-low voltages, provide a facility for protective separation
(PELV) (acc. to VDE 0100 / VDE 0106 and/or IEC 60364 / IEC 61140 or relevant national
regulations).
32
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.8 Inputs and outputs, overview
4.8.1 Description of the CG number
Figure 4-10: Marking (CG number) of the electronics module and output variants
1
2
3
4
5
ID number: 0
ID number: 0 = standard; 9 = special
Power supply
Display (language versions)
Output version
4.8.2 Fixed, non-alterable output versions
This transmitter is available with various output combinations.
• The grey boxes in the tables denote unassigned or unused connection terminals.
• In the table, only the final digits of the CG no. are depicted.
• Terminals D- and A- are connected for active pulse/frequency output (no galvanic isolation
anymore).
• Available are an active or passive pulse/frequency output, or the active or passive status/limit
output. It's not possible to use both at the same time!
CG no.
100
R00
Connection terminals
S
D-
1
Pp / Sp passive
connected to
A-
D
D+
A-
A
A+
Ip + HART® passive 2
Pa active
Pp / Sp passive
connected to
D-
Ia + HART® active 2
Ia + HART® active 2
Table 4-3: Basic outputs (I/Os)
1 Shielding
2 Function changed by reconnecting
MI 021-517 en - APR 2020
www.se.com
33
4 ELECTRICAL CONNECTIONS
CG no.
R00
IMT30A
Connection terminals
B-
B
B+
S
Sign. A (D0-)
Common
Sign. B (D1+)
Shielding
Table 4-4: Modbus (I/O) (option)
Ia
Ip
Current output active or passive
Pa
Pp
Pulse/frequency output active or passive
Sa
Sp
Status output/limit switch active or passive
Table 4-5: Description of used abbreviations
4.9 Description of the inputs and outputs
4.9.1 Current output
NOTICE!
Depending on the version, the outputs must be connected passively or actively!
• All outputs are electrically isolated from each other and from all other circuits.
• All operating data and functions can be adjusted.
• Passive mode: external power Uext ≤ 32 VDC at I ≤ 22 mA
• Active mode: load impedance RL ≤ 750 Ω at I ≤ 22 mA
•
•
•
•
Self-monitoring: interruption or load impedance too high in the current output loop
Error message possible via status output, error indication on LC display.
Current value error detection can be adjusted.
Automatic range conversion via threshold. The setting range for the threshold is between 5
and 80% of Q100%, ± 0...5% hysteresis (corresponding ratio from smaller to larger range of
1:20 to 1:1.25).
Signaling of the active range possible via a status output (adjustable).
• Forward / reverse flow measurement (F/R mode) is possible.
NOTICE!
For further information refer to Connection diagrams of outputs on page 38 and refer to
Technical data on page 77.
34
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.9.2 Pulse output and frequency output
NOTICE!
Depending on the version, the outputs must be connected passively or actively!
• All outputs are electrically isolated from each other and from all other circuits.
• All operating data and functions can be adjusted.
• Passive mode:
External power supply required: Uext ≤ 32 VDC
I ≤ 100 mA at f ≤ 10 kHz (over range up to fmax ≤ 12 kHz)
• Active mode:
Use of the internal power supply: Unom = 20 VDC
IPeak < 100 mA
IAverage ≤ 10 mA at f ≤ 10 kHz (over range up to fmax ≤ 10 kHz)
• Scaling:
Frequency output: in pulses per time unit (e.g. 1000 pulses/s at Q100%);
Pulse output: quantity per pulse.
• Pulse width:
symmetric (pulse duty factor 1:1, independent of output frequency)
automatic (with fixed pulse width, duty factor approx. 1:1 at Q100%) or
fixed (pulse width adjustable as required from 0.05 ms...2 s)
• Forward / reverse flow measurement (F/R mode) is possible.
• The pulse and frequency output can also be used as a status output / limit switch.
NOTICE!
For further information refer to Connection diagrams of outputs on page 38 and refer to
Technical data on page 77.
MI 021-517 en - APR 2020
www.se.com
35
4 ELECTRICAL CONNECTIONS
IMT30A
4.9.3 Status output and limit switch
NOTICE!
Depending on the version, the outputs must be connected passively or actively!
• The status outputs / limit switches are electrically isolated from each other and from all
other circuits.
• The output stages of the status outputs/limit switches during simple active or passive
operation behave like relay contacts and can be connected with any polarity.
• All operating data and functions can be adjusted.
• Passive mode:
External power supply required: Uext ≤ 32 VDC; I ≤ 100 mA
• Active mode:
Use of the internal power supply: Unom = 20 VDC; I ≤ 20 mA
• For information on the adjustable operating states refer to Function tables on page 55.
NOTICE!
For further information refer to Connection diagrams of outputs on page 38 and refer to
Technical data on page 77.
36
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.10 Electrical connection of the outputs
NOTICE!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
4.10.1 Electrical connection of the outputs
DANGER!
All work on the electrical connections may only be carried out with the power disconnected.
Take note of the voltage data on the nameplate!
Figure 4-11: Electrical connection of the outputs
1 Cable entry, remote version
2 Cable entry, compact version (right cable entry is optional)
3 Terminal block for the connection of outputs
•
•
•
•
Open the housing cover
Push the prepared cables through the cable entries and connect the necessary conductors.
Connect the shield.
Close the housing cover.
NOTICE!
Ensure that the housing gasket is properly fitted, clean and undamaged.
MI 021-517 en - APR 2020
www.se.com
37
4 ELECTRICAL CONNECTIONS
IMT30A
4.10.2 Laying electrical cables correctly
Figure 4-12: Protect housing from dust and water
1 For compact versions with nearly horizontally-oriented cable entries, lay the necessary electric cables with a drip loop as shown in the illustration.
2 Tighten the screw connection of the cable entry securely.
3 Seal cable entries that are not needed with a plug.
4.11 Connection diagrams of outputs
4.11.1 Important notes
NOTICE!
Depending on the version, the outputs must be connected passively or actively!
• All groups are electrically isolated from each other and from all other output circuits.
• Passive mode: An external power supply is necessary to operate (activation) the subsequent
devices (Uext).
• Active mode: The transmitter supplies the power for operation (activation) of the subsequent
devices, observe max. operating data.
• Terminals that are not used should not have any conductive connection to other electrically
conductive parts.
Ia
Ip
Current output active or passive
Pa
Pp
Pulse/frequency output active or passive
Sa
Sp
Status output/limit switch active or passive
Table 4-6: Description of used abbreviations
38
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.11.2 Description of the electrical symbols
mA meter
0...20 mA or 4...20 mA and other
RL is the internal resistance of the measuring point including the cable
resistance
DC voltage source (Uext), external power supply, any connection polarity
DC voltage source (Uext), observe connection polarity according to
connection diagrams
Internal DC voltage source
Controlled internal power source in the device
Electronic or electromagnetic counter
At frequencies above 100 Hz, shielded cables must be used to connect the
counters.
Ri Internal resistance of the counter
Button, N/O contact or similar
Table 4-7: Description of the electrical symbols
MI 021-517 en - APR 2020
www.se.com
39
4 ELECTRICAL CONNECTIONS
IMT30A
4.11.3 Basic and Modbus outputs
CAUTION!
Observe connection polarity.
NOTICE!
For further information refer to Description of the inputs and outputs on page 34 and refer to
HART connection on page 45.
Current output active (HART®)
• Uint, nom = 20 VDC
• I ≤ 22 mA
• RL ≤ 750 Ω
• HART® at connection terminals A
Figure 4-13: Current output active Ia
40
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
Current output passive (HART®)
• Uext ≤ 32 VDC
• I ≤ 22 mA
• U0 ≤ 2 V at I = 22 mA
• RL, max = (Uext - U0) / Imax
• HART® at connection terminals A
Figure 4-14: Current output passive Ip
MI 021-517 en - APR 2020
www.se.com
41
4 ELECTRICAL CONNECTIONS
IMT30A
NOTICE!
• For frequencies above 100 Hz, shielded cables are to be used in order to reduce effects from
electrical interferences (EMC).
• Shielding takes place at the electrical connection (S) of the output terminal block.
NOTICE!
• Independent of connection polarity.
• The output is open if the transmitter is not powered.
Pulse/frequency output passive
• Uext ≤ 32 VDC
• fmax in the operating menu set to fmax ≤ 100 Hz:
I ≤ 100 mA
RL ≤ 47 kΩ
closed:
U0 ≤ 0.2 V at I = 10 mA
U0 ≤ 2 V at I = 100 mA
open:
I ≤ 0.05 mA at Uext = 32 V
• fmax in operating menu set to 100 Hz < fmax ≤ 10 kHz:
(over range up to fmax ≤ 12 kHz)
I ≤ 20 mA
RL ≤ 10 kΩ for f ≤ 1 kHz
RL ≤ 1 kΩ for f ≤ 10 kHz
closed:
U0 ≤ 1.5 V at I = 1 mA
U0 ≤ 2.5 V at I = 10 mA
U0 ≤ 5 V at I = 20 mA
open:
I ≤ 0.05 mA at Uext = 32 V
Use shielded cables!
• The minimum load impedance RL, min is calculated as follows:
RL, min = (Uext - U0) / Imax
• Can also be set as status output; for the electrical connection refer to status output connection diagram.
Figure 4-15: Pulse/frequency output passive Pp
42
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
NOTICE!
• The active output is galvanically coupled with the current output.
• This output is intended to drive mechanical or electronic counters directly.
Pulse/frequency output active
• Uint, nom ≤ 20 V
• RV = 1 kΩ
• C = 1000 µF
• High current mechanical counter
fmax ≤ 1 Hz
• Low current mechanical counter
I ≤ 20 mA
RL ≤ 10 kΩ for f ≤ 1 kHz
RL ≤ 1 kΩ for f ≤ 10 kHz
closed:
U0 ≥ 12.5 V at I = 10 mA
open:
I ≤ 0.05 mA at Unom = 20 V
Figure 4-16: Pulse/frequency output active Pa
MI 021-517 en - APR 2020
www.se.com
43
4 ELECTRICAL CONNECTIONS
IMT30A
NOTICE!
• Independent of connection polarity.
• The output is open if the transmitter is not powered.
Status output / limit switch passive
• Uext ≤ 32 VDC
• I ≤ 100 mA
• RL = 47 kΩ
• closed:
U0 ≤ 0.2 V at I = 10 mA
U0 ≤ 2 V at I = 100 mA
open:
I ≤ 0.05 mA at Uext = 32 V
Figure 4-17: Status output / limit switch passive Sp
44
www.se.com
MI 021-517 en - APR 2020
ELECTRICAL CONNECTIONS 4
IMT30A
4.11.4 HART connection
NOTICE!
The current output always has HART® capability and is connected at connection terminals
A+/A-/A.
All HART® connections (point-to-point and multi-drop operation) both work actively and
passively.
Example for active HART® connection (point-to-point)
Figure 4-18: HART® connection active (Ia)
1 HART® communicator
The parallel resistance to the HART® communicator must be R ≥ 230 Ω.
MI 021-517 en - APR 2020
www.se.com
45
4 ELECTRICAL CONNECTIONS
IMT30A
Example for passive HART® connection (multi-drop mode)
• I: I0% ≥ 4 mA
• Multi-drop mode I: Ifix ≥ 4 mA = I0%
• Uext ≤ 32 VDC
• R ≥ 230 Ω
Figure 4-19: HART® connection passive (Ip)
1 HART® communicator
2 Other devices with HART® capability
46
www.se.com
MI 021-517 en - APR 2020
START-UP 5
IMT30A
5.1 Switching on the power
Before connecting to power, please check that the system has been correctly installed.
This includes:
•
•
•
•
The device must be mechanically safe and mounted in compliance with the regulations.
Remove the magnet pencil and keep it on a save place (is only valid for the display version).
The power connections must have been made in compliance with the regulations.
The electrical terminal compartments must be secured and the covers have been screwed
on.
• Check that the electrical operating data of the power supply are correct.
• Switching on the power.
5.2 Starting the transmitter
The measuring device, consisting of the flow tube and the transmitter, is supplied ready for
operation. All operating data have been set at the factory in accordance with your order
specifications.
When the power is switched on, a self test is carried out. After that the device immediately
begins measuring, and the current values are displayed.
Figure 5-1: Displays in measuring mode (examples for 2 or 3 measured values)
x, y and z denote the units of the measured values displayed
It is possible to change between the two measured value windows, the trend display and the list
with the status messages by pressing the keys ↑ and ↓. For information about possible status
messages, their meaning and cause refer to Status messages and diagnostic information on
page 69.
MI 021-517 en - APR 2020
www.se.com
47
6 OPERATION
IMT30A
6.1 Safety instructions for the use of the magnet pencil
To operate the transmitter when the housing is closed, 4 magnetic keys are available. They are
activated by a magnet pencil.
WARNING!
The magnet pencils can be dangerous for people with cardiac pacemakers or other metal
implants. Make sure that these people do not use the magnet pencil or meet minimum
clearances! Observe the relevant national and local regulations and requirements!
6.2 Display and operating elements
Figure 6-1: Display and operating elements (Example: flow indication with 2 measuring values)
1
2
3
4
5
6
7
Indicates a possible status message in the status list
Tag number (is only indicated if this number was entered previously by the operator)
Indicates when a key has been pressed
1st measured variable in large representation
Bargraph indication
Push buttons for operation with open housing (see table below for function and representation in text)
Magnet keys for operation with closed housing (see table below for function and representation in text)
NOTICE!
• After 5 minutes of inactivity, there is an automatic return to measuring mode. Previously
changed data is not saved.
48
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
Key
Measuring mode
Menu mode
Submenu or function
mode
Parameter and data
mode
>
Switch from measuring
mode to menu mode;
press key for 2.5 s, "A
quick setup" menu is
then displayed
Access to displayed
menu, then 1st
submenu is displayed
Access to displayed
submenu or function
For numerical values,
move cursor one
position to the right
^
Reset of display
Return to measuring
mode but prompt
whether the data should
be saved
Press 1 to 3 times,
return to menu mode,
data saved
Return to submenu or
function, data saved
↓ or ↑
Switch between display
pages: measured
value 1 + 2, trend page
and status page
Select menu
Select submenu or
function
Use highlighted cursor
to change number, unit,
property and to move
the decimal point
Esc (> + ↑)
-
-
Return to menu mode
without acceptance of
data
Return to submenu or
function without
acceptance of data
Table 6-1: Description of key functionality
MI 021-517 en - APR 2020
www.se.com
49
6 OPERATION
IMT30A
6.2.1 Display in measuring mode with 2 or 3 measured values
Figure 6-2: Example for display in measuring mode with 2 or 3 measured values
1
2
3
4
5
Indicates a possible status message in the status list
Tag number (is only indicated if this number was entered previously by the operator)
1st measured variable in large representation
Bargraph indication
Depiction with 3 measured values
6.2.2 Display for selection of submenu and functions, 3 lines
Figure 6-3: Display for selection of submenu and functions, 3 lines
Indicates a possible status message in the status list
Menu, submenu or function name
Number relating to 6
Indicates position within menu, submenu or function list
Next menu(s), submenu or function
(_ _ _ signals in this line the end of the list)
6 Current menu(s), submenu or function
7 Previous menu(s), submenu or function
(_ _ _ signals in this line the beginning of the list)
1
2
3
4
5
50
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
6.2.3 Display when setting parameters, 4 lines
Figure 6-4: Display when setting parameters, 4 lines
Current menu(s), submenu or function
Number relating to 7
Denotes factory setting
Denotes permissible value range
Permissible value range for numeric values
Currently set value, unit or function (when selected, appears with white text, blue background)
This is where the data is changed.
7 Current parameter
8 Factory setting of parameter
1
2
3
4
5
6
MI 021-517 en - APR 2020
www.se.com
51
6 OPERATION
IMT30A
6.2.4 Display when previewing parameters, 4 lines
Figure 6-5: Display when previewing parameters, 4 lines
1
2
3
4
5
6
7
52
Current menu(s), submenu or function
Number relating to 6
Denotes a changed parameter (simple check of changed data when browsing through lists)
Next parameter
Currently set data from 6
Current parameter (for selection press key >; then see previous chapter)
Factory setting of parameter
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
6.3 Menu structure
NOTICE!
• The menu structure for the standard device is described.
• Special functions for Modbus are described in detail in the corresponding supplementary
instructions.
• Note the key function within and between the columns.
Measuring mode
^
Select
menu
↓ Select menu and/or submenu
↑ ↓↑
Select
function
and set
data
↓↑>
Press
> 2.5 s
A quick setup
> A1 language
^
> ^
>
^
A2 HART
> A2.1 tag
^
A3 RS 485 / Modbus
> A3.1 tag
^
A3.2 slave address
A4 reset?
> A4.1 reset errors
^
A4.2 counter 1
A4.3 counter 2
A5 analogue outputs
> A5.1 range
^
A5.2 time constant
A5.3 low flow cutoff
A6 digital outputs
> A6.1 max. pulse rate
^
A6.2 pulse value unit
A6.3 value p. pulse
A7 process input
> A7.1 device serial no.
^
A7.2 zero calibration
A7.3 size
A7.4 GKL
A7.5 field frequency
A7.6 flow direction
^
B test
> B1 simulation
^
B2 actual values
> For details about the
^ submenus refer to Menu
"B test" on page 57.
>
^
B3 information
↓↑
↓↑
↓↑
↓↑>
Table 6-2: Menu structure "A quick setup" and "B test"
MI 021-517 en - APR 2020
www.se.com
53
6 OPERATION
Measuring mode
^
IMT30A
Select
menu
↓ Select menu and/or submenu
↑ ↓↑
Select
function
and set
data
↓↑>
Press
> 2.5 s
C setup
> C1 process input
^
> C1.1 calibration
^
C1.2 filter
>
^
C1.3 empty pipe detect
C1.4 information
C1.5 simulation
> C2 I/O (input/output)
^
^
> C2.1 hardware
^
C2.1 - 1
>
^
C2.1 current output A 1
C2.5 - 1
C2.5 frequency out D 1
C2.5 pulse output D 1
C2.5 status output D 1
C2.5 limit switch D 1
^
> C3 I/O counter
^
> C3.1 counter 1
^
C3.2 counter 2
>
^
^
> C4 HART
^
> C4.1 HART (on/off)
^
C4.2 address
>
^
C4.3 message
C4.4 description
C4.5 HART units
> C6 device
^
^
> C6.1 device info
^
C6.2 display
>
^
C6.3 1. meas. page
C6.4 2. meas. page
C6.5 graphic page
C6.6 special functions
C6.7 units
C6.8 quick setup
↓↑
↓↑
↓↑
↓↑>
Table 6-3: Menu structure "C setup"
1 Depending on settings in "C2.2 hardware"
54
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
6.4 Function tables
NOTICE!
• The functions for the standard device are described in the following tables.
• Special functions for Modbus are described in detail in the corresponding supplementary
instructions.
• Depending on the device version, not all functions are available.
6.4.1 Menu "A quick setup"
Function
Setting / Description
A1 language
A1 language
Language selection depends on the device version.
A2 HART
A2.1 tag
Measuring point identifier (Tag no.) appears in the LC display header (up to 8 digits).
A3 RS485/Modbus
A3.1 tag
Measuring point identifier (Tag no.) appears in the LC display header (up to
16 digits). The first 8 digits are identical to the HART® measuring point (see above).
A3.2 slave address
Setting the device address at the Modbus interface.
A4 reset?
A4.1 reset errors
Query: reset errors?
Select: no / yes
A4.2 counter 1
Query: reset counter?
Select: no / yes (available if activated in C5.9.1)
A4.3 counter 2
Query: reset counter?
Select: no / yes (available if activated in C5.9.2)
A5 analogue outputs
A5.1 range
Measuring range for the analogue outputs (current output, frequency output and
display).
A5.2 time constant
Time constant for the analogue outputs (current output, frequency output and
display).
A5.3 low flow cutoff
Low flow cutoff for the analogue outputs (current output and frequency output).
MI 021-517 en - APR 2020
www.se.com
55
6 OPERATION
IMT30A
A6 digital outputs
A6.1 max. pulse rate
Setting the maximum pulse rate.
Limit is 120% of this pulse rate.
A6.2 pulse value unit
Selection of the unit from a list, depending on the "measurement".
A6.3 value p. pulse
Setting for pulse output D (volume or mass value per pulse).
Setting: xxx.xxx in L or kg or in the unit selected in A6.2
A7 process input
A7.1 device serial no.
Shows the serial number of the system (C5.1.3).
The following process input parameters are only available, if the quick access has been activated in the menu "setup /
device / quick setup" (C6.8.3).
A7.2 zero calibration
Display of actual zero calibration value.
Query: calibrate zero?
For settings refer to C1.1.1.
A7.3 size
Select from size table.
A7.4 GKL
Set value according to information on nameplate; range: 0.5…20
A7.5 field frequency
Setting as on flow tube nameplate = line frequency x value (from the following list):
1/2; 1/4; 1/6; 1/8; 1/12; 1/18; 1/36; 1/50
A7.6 flow direction
Define the polarity of the flow direction.
Select: normal direction (according to the arrow on the flow tube) / reverse
direction (in the opposite direction to the arrow)
Table 6-4: Menu "A quick setup"
56
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
6.4.2 Menu "B test"
Function
Setting / Description
B1 simulation
B1.1 volume flow
B1.1 mass flow
Depending on the selection, simulation of the volume or mass flow according to the
following sequence:
Select: set value / break (exit function without simulation)
Query: start simulation?
Select: no (exit function without simulation) / yes (start simulation)
B1.2 current output A
Simulation X
B1.3 pulse output D
B1.3 frequency out X
[X stands for one of the connection terminals A or D]
Sequence and settings similar to B1.2, see above!
B1.3 limit switch D
For the pulse output the set number of pulses are displayed once in a second!
B1.3 status output D
B2 actual values
B2.1 operating hours
Display the actual operating hours.
Exit the displayed function with the ^ key.
B2.2 act. flow speed
Display the actual flow speed.
Exit the displayed function with the ^ key.
B2.3 electr. temperature
Display the actual electronics temperature.
Exit the displayed function with the ^ key.
B2.4 act. coil resistance
Display the actual resistance of the field coils.
B3 information
B3.1 C number
This number clearly identifies the electronics.
B3.2 Electronic Revision ER
Reference identification number, electronic revision and production date of the
device; includes all hardware and software changes
B3.3 device serial no.
Serial number of the system.
B3.4 electronic serial no.
Serial number of the electronics.
Table 6-5: Menu "B test"
MI 021-517 en - APR 2020
www.se.com
57
6 OPERATION
IMT30A
6.4.3 Menu "C setup"
Function
Setting / Description
C1 process input
C1.1 calibration
C1.1.1 zero calibration
Display of actual zero calibration value.
Query: calibrate zero?
Select: break (return with ^ key) / standard (factory setting) / manual (display last
value, set new value, range: -1.00…+1 m/s) / automatic (shows the current value as
the new zero calibration value)
C1.1.2 size
Select from size table.
C1.1.3 GKL
Set value acc. to the information on the nameplate.
Range: 0.5…20
C1.1.4 measurement
Select: volume flow (default setting) / mass flow (using the fixed density, the volume
flow is converted into mass flow)
C1.1.5 range
Measuring range for the analogue outputs (current output, frequency output and
display).
Range: 0.0…100%
C1.1.6 density
For calculating the mass flow from the volume flow.
Range: 0.1…5 kg/L
C1.1.7 target conduct.
Reference value for on-site calibration.
Range: 1.000...50000 μS/cm
C1.1.8 EF electr. factor
For calculation of the conductivity based on the electrode impedance.
Query: calibrate EF?
Select: break (return with ^ key) / standard (with factory setting) / manual (set
desired value) / automatic (determines EF according to the setting in C1.1.10)
C1.1.9 field frequency
Setting as on flow tube nameplate = line frequency x value (from the following list):
1/2; 1/4; 1/6; 1/8; 1/12; 1/18; 1/36; 1/50
C1.1.10 select settling
Select settling (special function).
Select: standard (fixed allocation) / manual (manual time setting for the settling
time for the field current)
C1.1.11 settling time
Only available if "manual" is selected in C1.1.10.
Range: 1.0…250 ms
C1.1.12 line frequency
Setting the line frequency.
Select: 50 Hz or 60 Hz
C1.1.13 act. coil resistance
58
Display of the actual resistance of the field coil.
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
C1.2 filter
C1.2.1 limitation
Limitation of all flow values, before smoothing by time constant, affects all outputs.
Settings: -xxx.x / +xxx.x m/s; condition: 1st value < 2nd value
Range 1st value: -100.0 m/s ≤ value ≤ -0.001 m/s
Range 2nd value: +0.001 m/s ≤ value ≤ +100 m/s
C1.2.2 flow direction
Define the polarity of the flow direction.
Select: normal direction (according to the arrow on the flow tube) / reverse
direction (in the opposite direction to the arrow)
C1.2.3 time constant
Time constant of all flow measurements.
xxx.x s; range: 0.0…100 s
C1.2.4 pulse filter
Suppresses noise due to solids, air/gas bubbles and sudden changes in pH.
Select: off (without pulse filter) / on (with pulse filter) / automatic (with new pulse
filter)
Pulse filter "on": The change from one measurement value to the next one is
limited to the value "pulse limitation" for the total time "pulse width".
This filter allows a faster signal tracking for slowly changing flow values.
Pulse filter "automatic": The raw flow values are collected into a buffer, covering
two times the "pulse width" values. This filter is called "median" filter.
This filter allows a better suppression of pulse shaped disturbances (particles or air
bubbles in very noisy environment).
C1.2.5 pulse width
Length of interference and delays to be suppressed on sudden changes in flow.
Only available, if pulse filter (C1.2.4) is "on" or "automatic".
xx.x s; range for "on": 0.01…10 s or for "automatic": 0.1...20 s
C1.2.6 pulse limitation
Dynamic limitation from one measured value to the next; only if pulse filter (C1.2.4)
is "on".
xx.x s; range: 0.01...100 m/s
C1.2.7 low flow cutoff
Sets low flow values to "0"; affects all outputs
x.xxx ± x.xxx L/h; range: 0.0…10 L/h
(1st value = switching point / 2nd value = hysteresis),
condition: 2nd value ≤ 1st value
C1.3 empty pipe detection
C1.3.1 empty pipe detect
Select: off / empty pipe (F); empty pipe (S); empty pipe (I)
Flow indication "= 0" when "empty pipe"
C1.3.2 limit empty pipe
Only available if "empty pipe [..]" is activated in C1.3.1.
Range: 0.0…9999 μS (set about 50% of the lowest occurring conductivity in
operation.
Conductivity below this value means a signal as "empty pipe".
C1.3.3 act. conductivity
Only available if "empty pipe [..]" is activated in C1.3.1.
Actual conductivity is indicated. Activation takes place only after setting mode is
exited!
C1.3.4 time constant
Only available if "empty pipe [..]" is activated in C1.3.1.
Range: xxx.x s; 0.1...100 s
A damping is set for empty pipe detection.
MI 021-517 en - APR 2020
www.se.com
59
6 OPERATION
IMT30A
C1.4 information
C1.4.1 liner
Shows the material of the liner.
C1.4.2 electr. material
Shows the material of the electrodes.
C1.4.3 calibration date
Shows the date on which the flow tube was calibrated.
C1.4.4 serial no. sensor
Shows the serial number of the flow tube.
C1.4.5 V no. sensor
Shows the order number of the flow tube.
C1.4.6 sensor electr. info
Shows the serial number of the circuit board, the software version number and the
calibration date of the circuit board.
C1.5 simulation
C1.5.2 volume flow
C1.5.2 mass flow
For sequence refer to B1.1.
Table 6-6: Menu C1
Function
Setting / Description
C2 I/O (Inputs/Outputs)
C2.1 hardware
C2.1.1 terminals A
Select: off (switched off) / current output
C2.1.2 terminals D
Select: off (switched off) / frequency output / pulse output / status output / limit
switch
C2.2 current output A
C2.2.1 range 0%…100%
Current range for the selected "measurement", e.g. 4...20 mA, corresponds to
0…100%
xx.x…xx.x mA; range: 0.00…20 mA
Condition: 0 mA ≤ 1st value ≤ 2nd value ≤ 20 mA
C2.2.2 extended range
Min. and max. limits of current values. If the current range is exceeded, the current
is set to these limits.
xx.x … xx.x mA; range: 03.5…21.5 mA
Condition: 0 mA ≤ 1st value ≤ 2nd value ≤ 21.5 mA and out of current range
C2.2.3 error current
Specify error current.
xx.x mA; range: 3…22 mA
Condition: outside of extended range
C2.2.4 error condition
Set the error conditions.
Select: error in device (error category [F]) / application error (error category [F]) /
out of specification (error category [F] & [S])
C2.2.5 polarity
Set polarity; please note flow direction in C1.2.2!
Select: both polarities (plus and minus values are displayed) / positive polarity
(display for negative values = 0) / negative polarity (display for positive values = 0) /
absolute value (always displays positive, with both negative and positive values)
60
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
Function
Setting / Description
C2.2.6 low flow cutoff
Sets the measurement to "0" for low values.
x.xxx...x.xxx%; range: 0.0…20%
(1st value = switching point / 2nd value = hysteresis);
condition: 2nd value ≤ 1st value
C2.2.7 time constant
Range: 000.1…100 s
C2.2.8 information
Serial number of the I/O board, software version number and production date of the
circuit board.
C2.2.9 simulation
For sequence refer to "B1.2 current output A".
C2.2.10 4mA trimming
Trimming of the current at 4 mA.
Reset to 4 mA restores the factory calibration.
Used for HART® setting.
C2.2.11 20mA trimming
Trimming of the current at 20 mA.
Reset to 20 mA restores the factory calibration.
Used for HART® setting.
C2.3 frequency out X
C2.3.1 pulse shape
Specify the pulse shape.
Select: symmetric (about 50% on and 50% off) / automatic (constant pulse with
about 50% on and 50% off at 100% pulse rate) / fixed (fixed pulse rate; for setting
refer to "C2.3.3 100% pulse rate")
C2.3.2 pulse width
Only available if set to "fixed" in C2.3.1.
Range: 0.05…2000 ms
Note: max. setting value Tp [ms] ≤ 500 / max. pulse rate [1/s], gives the pulse
width = time where the output is activated
C2.3.3 100% pulse rate
Pulse rate for 100% of the measuring range.
Range: 1…10000 Hz
Limitation 100% pulse rate ≤ 100/s: Imax ≤ 100 mA
Limitation 100% pulse rate > 100/s: Imax ≤ 20 mA
C2.3.4 polarity
Set polarity; please note flow direction in C1.2.2!
Select: both polarities (plus and minus values are displayed) / positive polarity
(display for negative values = 0) / negative polarity (display for positive values = 0) /
absolute value (always displays positive, with both negative and positive values)
C2.3.5 low flow cutoff
Sets the measurement to "0" for low values.
x.xxx ± x.xxx L/h; range: 0.0…20 L/h
(1st value = switching point / 2nd value = hysteresis),
condition: 2nd value ≤ 1st value
C2.3.6 time constant
Range: 000.1…100 s
C2.3.7 invert signal
Select: off (activated output: switch closed) / on (activated output: switch open)
C2.3.8 information
Serial number of the I/O board, software version number and production date of the
circuit board.
C2.3.9 simulation
For sequence refer to "B1.3 frequency out D".
MI 021-517 en - APR 2020
www.se.com
61
6 OPERATION
IMT30A
C2.3 pulse output D
C2.3.1 pulse shape
Specify the pulse shape.
Select: symmetric (about 50% on and 50% off) / automatic (constant pulse with
about 50% on and 50% off at max. pulse rate) / fixed (fixed pulse rate, for setting
refer to "C2.3.3 max. pulse rate")
C2.3.2 pulse width
Only available if set to "fixed" in C2.3.1.
Range: 0.05…2000 ms
Note: max. setting value Tp [ms] ≤ 500 / max. pulse rate [1/s], gives the pulse
width = time where the output is activated
C2.3.3 max. pulse rate
Setting the maximum pulse rate.
Limit is 120% of this pulse rate.
C2.3.4 pulse value unit
Selection of the unit from a list, depending on the "measurement".
C2.3.5 value p. pulse
Set value for volume or mass per pulse.
xxx.xxx, measured value
C2.3.6 polarity
Set polarity; please note flow direction in C1.2.2!
Select: both polarities (plus and minus values are displayed) / positive polarity
(display for negative values = 0) / negative polarity (display for positive values = 0) /
absolute value (always displays positive, with both negative and positive values)
C2.3.7 invert signal
Select: off (activated output: switch closed) / on (activated output: switch open)
C2.3.8 information
Serial number of the I/O board, software version number and production date of the
circuit board.
C2.3.9 simulation
For sequence refer to "B1.3 pulse output D".
C2.3 status output D
C2.3.1 mode
Measuring conditions of the output.
Select: out of specification (output set, signals status of category "error in device"
or "application error" or "out of specification" refer to Status messages and
diagnostic information on page 69) /
application error (output set, signals status of the category "error in device" or
"application error" refer to Status messages and diagnostic information on page
69) /
polarity flow (polarity of the current flow) /
over range flow (over range of the flow) /
counter 1 preset (activates counter 1 when preset value is reached) /
counter 2 preset (activates counter 2 when preset value is reached) /
output A (displays the polarity at output A) /
off (switched off) /
empty pipe (when pipe empty, output activated) /
error in device (output set, signals status of the category "error in device" refer to
Status messages and diagnostic information on page 69)
C2.3.2 invert signal
Select: off (activated output: switch closed) / on (activated output: switch open)
C2.3.3 information
Serial number of the I/O board, software version number and production date of the
circuit board.
C2.3.4 simulation
For sequence refer to "B1.3 status output D".
62
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
C2.3 limit switch D
C2.3.1 threshold
Switching level, set threshold with hysteresis
C2.3.2 polarity
Set polarity; please note flow direction in C1.2.2!
Select: both polarities (plus and minus values are displayed) / positive polarity
(display for negative values = 0) / negative polarity (display for positive values = 0) /
absolute value (always displays positive, with both negative and positive values)
C2.3.3 time constant
Range: 000.1…100 s
C2.3.4 invert signal
Select: off (activated output: switch closed) / on (activated output: switch open)
C2.3.5 information
Serial number of the I/O board, software version number and production date of the
circuit board.
C2.3.6 simulation
For sequence refer to "B1.3 limit switch D".
Table 6-7: Menu C2
Function
Setting / Description
C3 I/O counter
C3.1 counter 1
Set function of counter.
C3.2 counter 2
_ stands for 1, 2 (= counter 1, 2)
C3._.1 funct. of counter
Select: sum counter (counts positive + negative values) / + counter (counts only the
positive values) / - counter (counts only the negative values) / off (counter is
switched off)
C3._.2 preset value
If this value is reached, positive or negative, a signal is generated that can be used
for a status output at which "preset counter X" has to be set.
Preset value (max. 8 digits) x.xxxxx in selected unit; refer to C5.7.10 and C5.7.13
C3._.3 reset counter
Query: reset counter?
Select: no / yes (available if activated in C5.9.1)
C3._.4 set counter
Set counter _ to the desired value.
Select: break (exit function) / set value (opens the editor to make the entry)
Query: set counter?
Select: no (exit function without setting the value) / yes (sets the counter and exits
the function)
C3._.5 stop counter
Counter _ stops and holds the current value.
Select: no (exits the function without stopping the counter) / yes (stop the counter
and exits the function)
C3._.5 start counter
Start counter _ after that counter is stopped.
Select: no (exits the function without starting the counter) / yes (starts the counter
and exits the function)
C3._.7 information
Serial number of the I/O board, software version number and production date of the
circuit board.
Table 6-8: Menu C3
MI 021-517 en - APR 2020
www.se.com
63
6 OPERATION
Function
IMT30A
Setting / Description
C4 I/O HART
The dynamic variables are fixed to the following values:
PV: flow (volume flow or mass flow, depending on the selection of "measurement" in C1.1.4)
SV: counter 1
TV: counter 2
4V: operating time
C4.1 HART
HART® communication is activated or deactivated.
Select: on (HART® is activated; default setting) / off (HART® is disabled)
C4.2 address
Setting the address for multi-drop operation.
If "address 0" is selected, the current output is in normal operation. For all other
addresses, the current at the output is set to the 0% value.
C4.3 message
Entry of individual text.
C4.4 description
Entry of individual text.
C4.5 HART units
Unit change of dynamic variables in the display.
Select: break (return with ^ key) / HART® display (copies the settings for the
display units to the settings for the DVs) / load defaults (resets the DVs to the factory
defaults)
Table 6-9: Menu C4
Function
Setting / Description
C6 device
C6.1 device info
C6.1.1 tag
Settable characters (max. 8 digits):
A…Z; a…z; 0…9; / - , .
C6.1.2 C number
CG number, cannot be changed; describes the transmitter version.
C6.1.3 device serial no.
Serial number of the system; cannot be changed.
C6.1.4 electronic serial no.
Serial number of the electronic assembly; cannot be changed.
C6.1.5 SW.REV.MS
Serial number of the circuit board, version number of the main software, production
date of the circuit board.
C6.1.6 Electronic Revision ER
Reference identification number, electronic revision and production date of the
device; includes all hardware and software changes.
C6.2 display
C6.2.1 language
Language selection depends on the device version.
C6.2.2 contrast
Adjust display contrast for extreme temperatures.
Setting: -9…0…+9
This change takes place immediately, not just when setting mode is exited!
C6.2.3 default display
Specification of the default display page that is returned to after a short delay
period.
Select: none (current page is always active) / 1. meas. page (shows this page) /
2. meas. page (shows this page) / status page (shows only status messages) /
graphic page (trend of the 1st measurement)
64
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
Function
Setting / Description
C6.2.4 magnet keys
For activating or deactivating the magnet keys.
Select: on (magnet keys are enabled) / off (magnet keys are disabled)
C6.2.5 status indication LED
This function is only available for device versions without display.
Status display via a green or red LED (in case of device error, application error or
out of specification).
SW.REV.UIS
Serial number of the circuit board, version number of user interface software,
production date of the circuit board.
C6.3 1. meas. page
C6.3.1 format 1.line
Number of decimal places specified (depending on available space) for "1.line" of
"1. meas. page".
C6.4 2. meas. page
C6.4.1 format 1.line
Number of decimal places specified (depending on available space) for "1.line" of
"2. meas. page".
C6.4.2 format 2.line
Number of decimal places specified (depending on available space) for "2.line" of
"2. meas. page".
C6.4.3 format 3.line
Number of decimal places specified (depending on available space) for "3.line of "2.
meas. page".
C6.5 graphic page
C6.5.1 select range
Select: manual (set range in C6.5.2) / automatic (automatic depiction based on the
measured values)
Reset only after parameter change or after switching off and on.
C6.5.2 range
Set the scaling for the Y axis. Only available if "manual" is set in C6.5.1.
±xxx...±xxx%; range: -100…+100%
(1st value = lower limit / 2nd value = upper limit), condition: 1st value ≤ 2nd value
C6.5.3 time scale
Set the time scaling for the X axis, trend curve
xxx min; range: 0…100 min
C6.6 special function
C6.6.1 reset errors
Query: reset errors?
Select: no / yes
C6.6.2 save settings
Save current settings.
Select: break (exit function without saving) / backup 1 (saves the settings in the
backup 1 storage place) / backup 2 (saves the settings in the backup 2 storage
place)
Query: go on with copy? (cannot be undone)
Select: no (exit function without saving) / yes (copy current settings to storage
backup 1 or backup 2)
MI 021-517 en - APR 2020
www.se.com
65
6 OPERATION
IMT30A
Function
Setting / Description
C6.6.3 load settings
Load saved settings.
Select: break (exit function without loading) / factory settings (reload factory
settings) / backup 1 (loads the settings from the backup 1 storage place) / backup 2
(loads the settings from the backup 2 storage place) / load sensor data (restore
factory setting of the values for the flow tube. Display and I/O settings are retained!)
Query: go on with copy? (cannot be undone)
Select: no (exit function without saving) / yes (load data from the selected storage
place)
C6.6.4 password quick set
Password required to change data in the menu "quick setup".
0000 (= to this menu without password)
xxxx (password required); range 4 digits: 0001…9999
C6.6.5 password setup
Password required to change data in the menu "setup".
0000 (= to this menu without password)
xxxx (password required); range 4 digits: 0001…9999
C6.7 units
C6.7.1 volume flow
m³/h; m³/min; m³/s; L/h; L/min; L/s (L = litres);
cf/h; cf/min; cf/s; gal/h; gal/min; gal/s;
IG/h; IG/min; IG/s;
free unit (set factor and text in the next two functions, sequence see below)
C6.7.2 Text free unit
For text to be specified refer to Set free units on page 67:
C6.7.3 [m³/s]*factor
Specification of the conversion factor, based on m³/s:
xxx.xxx refer to Set free units on page 67
C6.7.4 mass flow
kg/s; kg/min; kg/h; t/min; t/h; g/s; g/min; g/h;
lb/s; lb/min; lb/h; ST/min; ST/h (ST = Short Ton); LT/h (LT = Long Ton);
free unit (set factor and text in the next two functions, sequence see below)
C6.7.5 Text free unit
For text to be specified refer to Set free units on page 67:
C6.7.6 [kg/s]*factor
Specification of the conversion factor, based on kg/s:
xxx.xxx refer to Set free units on page 67
C6.7.7 volume
m³; L; hL; mL; gal; IG; in³; cf; yd³;
free unit (set factor and text in the next two functions, sequence see below)
C6.7.8 Text free unit
For text to be specified refer to Set free units on page 67:
C6.7.9 [m³]*factor
Specification of the conversion factor, based on m³:
xxx.xxx refer to Set free units on page 67
C6.7.10 mass
kg; t; mg; g; lb; ST; LT; oz;
free unit (set factor and text in the next two functions, sequence see below)
C6.7.11 Text free unit
For text to be specified refer to Set free units on page 67:
C6.7.12 [kg]*factor
Specification of the conversion factor, based on kg:
xxx.xxx refer to Set free units on page 67
C6.7.13 flow speed
m/s; ft/s
C6.7.14 density
kg/L; kg/m³; lb/cf; lb/gal;
free unit (set factor and text in the next two functions, sequence see below)
C6.7.15 Text free unit
For text to be specified refer to Set free units on page 67:
66
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
Function
Setting / Description
C6.7.16 [kg/m³]*factor
Specification of the conversion factor, based on kg/m³:
xxx.xxx refer to Set free units on page 67
C6.8 quick setup
Activate quick access in menu "quick setup"; default setting: "quick setup" is active (yes)
Select: yes (activated) / no (not activated)
C6.8.1 reset counter 1
Reset counter 1 in menu "quick setup".
Select: yes (activated) / no (not activated)
C6.8.2 reset counter 2
Reset counter 2 in menu "quick setup".
Select: yes (activated) / no (not activated)
C6.8.3 process input
Activate quick access to the important process input parameters.
Select: yes (activated) / no (not activated)
Table 6-10: Menu C6
6.4.4 Set free units
Free units
Sequences to set texts and factors
Texts
Volume flow, mass flow and density
3 digits before and after the slash
xxx/xxx (max. 6 characters plus a "/")
Permissible characters
A…Z; a…z; 0…9; / - + , . *; @ $ % ~ () [] _
Conversion factors
Desired unit
= [unit see above] * conversion factor
Conversion factor
Max. 9 digits
Shift decimal point
↑ to the left and ↓ to the right
Table 6-11: Sequences to set texts and factors
MI 021-517 en - APR 2020
www.se.com
67
6 OPERATION
IMT30A
6.5 Description of functions
6.5.1 Reset counter in the menu "quick setup"
NOTICE!
It may be necessary to activate resetting of the counter in the menu "quick setup".
Key
Function
Description
>
A quick setup
Press and hold for 2.5 s, then release the key.
>
A1 language
-
3x↓
A4 reset
-
>
A4.1 reset errors
-
↓
A4.2 counter 1
Select desired counter.
↓
A4.3 counter 2
>
Query: reset counter?
Select: no
-
↓ or ↑
Query: reset counter?
Select: yes
-
^
A4.2 counter 1 or A4.3
counter 2
Counter has been reset.
3x^
Measuring mode
-
Table 6-12: Reset counter in the menu "quick setup"
6.5.2 Deleting error messages in the menu "quick setup"
NOTICE!
For the detailed list of the possible error messages refer to Status messages and diagnostic
information on page 69.
Key
Function
Description
>
A quick setup
Press and hold for 2.5 s, then release the key.
>
A1 language
-
3x↓
A4 reset
-
>
A4.1 reset errors
-
>
Query: reset errors?
Select: no
-
↓ or ↑
Query: reset errors?
Select: yes
-
^
A4.1 reset errors
Error has been reset.
3x^
Measuring mode
-
Table 6-13: Deleting error messages in the menu "quick setup"
68
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
6.6 Status messages and diagnostic information
Messages on the display Description
Actions
Status: F _ _ _ _ _
Operational fault in device, mA output ≤ Repair necessary.
3.6 mA or set fault current (depending
on the seriousness of the fault), status
output open, pulse / frequency output:
no pulses
F error in device
Error or failure of device. Parameter or
hardware error. No measurement possible.
Group message, when one of the following
or some other severe error occurs.
F IO 1
Error, operational fault in IO 1. Parameter
or hardware error. No measurement
possible.
Load settings (C4.6.3) (backup 1, backup 2
or factory settings). If status message still
does not disappear, replace electronic unit.
F parameter
Error, operational fault of data manager,
electronic unit, parameter or hardware
error. Parameters no longer usable.
F configuration
Invalid configuration: display software, bus
parameter or main software do not match
existing configuration.
If device configuration unchanged:
defective, replace electronic unit.
F display
Error, operational fault in display.
Parameter or hardware error. No
measurement possible.
Defective, replace electronic unit.
F sensor electronic
Error, operational fault in flow tube
electronics. Parameter or hardware error.
No measurement possible.
Defective, replace electronic unit.
F sensor global
Data error in the global data of the flow tube
electronic equipment.
Load settings (C5.6.3) (backup 1, backup 2
or factory settings). If status message still
does not disappear, replace electronic unit.
F sensor local
Data error in the local data of the flow tube
electronic equipment.
Defective, replace electronic unit.
F field current local
Data error in the local data of the field
current supply.
Defective, replace electronic unit.
F current output A
Error, operational fault in current output.
Parameter or hardware error. No
measurement possible.
Defective, replace electronic unit.
F software user interface
Fault revealed by CRC check of operation
software.
Replace electronic unit.
F hardware settings
The set hardware parameters do not match
the identified hardware. A dialogue appears
in the display.
Answer queries in dialogue mode, follow
directions.
Defective, replace electronic unit.
F hardware detection
Existing hardware cannot be identified.
Defective, replace electronic unit.
F RAM/ROM error IO1
A RAM or ROM error is detected during the
CRC check.
Defective, replace electronic unit.
F current output C
Table 6-14: Operational faults in device
MI 021-517 en - APR 2020
www.se.com
69
6 OPERATION
IMT30A
Messages on the display Description
Actions
Status: F _ _ _ _ _
Application-dependent fault, device OK, Application test or operator action
but measured values affected.
necessary.
F application error
Application-dependent fault, but device is
OK.
Group message, when errors as described
below or other application errors occur.
F empty pipe
1 or 2 measuring electrodes are not in
contact with the medium; measured value is
set to zero. No measurement possible.
Measuring pipe not filled; function
dependent on C1.3.2. Check installation. Or
electrodes completely insulated e.g. by oil
film. Clean!
F flow exceeding limit
Measuring range exceeded, filter setting
limits measured values. No message if
empty pipe.
Limitation C1.2.1, increase values.
If this limit occurs sporadically in processes with air pockets, solid contents or low
conductivity, then either the limit has to be increased or a pulse filter used so as to quell
the error messages and also reduce the measurement errors.
F field frequency too high
Field frequency is not reaching steady state,
a measured flow value is still being supplied
but may have errors. Measured values are
still supplied, but they are always too low.
No message if coil broken or bridged.
If "C1.1.14 settling time" is set to "manual",
increase value in C1.1.15. If "standard" is
set, set the field frequency in C1.1.13
according to the transmitter nameplate.
F DC offset
ADC over-ranged by DC offsets. No
measurement can be performed, the flow is
set to zero. No message if empty pipe.
For remote transmitter, check the
connection of the signal cable.
F open circuit A
Load on current output A too high, effective
current too low.
Current not correct, mA output cable has
open circuit or load too high. Check cable,
reduce load (set < 750 Ω).
The current or the corresponding measured
value is limited by a filter setting.
Check with "C2.1 hardware" or the sticker in
the terminal compartment, which output is
connected to the terminal.
If current output: extend "C2.x.6 range" and
"C2.x.8 limitation".
If frequency output: extend values in
"C2.x.5" and "C2.x.7".
F open circuit C
F over range A
F over range C
F over range D
The pulse rate or the corresponding
measured value is limited by a filter setting.
Or the demanded pulse rate is too high.
F active settings
Error during the CRC check of the active
settings.
Upload backup 1 or backup 2 settings, check
and adjust if necessary.
F factory settings
Error during the CRC check of the factory
settings.
-
F backup 1 settings
Error during the CRC check of the backup 1
or 2 settings.
Save active settings in backup 1 or 2.
F backup 2 settings
Table 6-15: Application error
70
www.se.com
MI 021-517 en - APR 2020
OPERATION 6
IMT30A
Messages on the display Description
Actions
Status: S _ _ _ _ _
Out of specification, measurement
continues, accuracy possibly less.
Maintenance required.
S uncertain measurement
Device maintenance necessary; measured
values only conditionally usable.
Group message, when errors as described
below or other influences occur.
S empty pipe
1 or 2 measuring electrodes are not in
contact with the medium; measured value is
set to zero. No measurement possible.
Measuring pipe not filled, function
dependent on C1.3.2. Check installation.
Or electrodes completely insulated e.g. by
oil film. Clean!
S field coil broken
Field coil resistance too high.
S field coil bridged
Field coil resistance too low.
Check field coil connections to the
electronic module (for remote versions:
field current cable) for open circuit / short
circuit
S electronic temperature
Upper limit for the permissible electronic
temperature has been exceeded.
Ambient temperature too high, direct solar
radiation or, for C version, process
temperature too high.
S overflow counter 1
This is counter 1. Counter has overrun and
started again at zero.
-
S overflow counter 2
This is counter 2. Counter has overrun and
started again at zero.
-
S backplane invalid
The data record on the backplane is invalid.
The CRC check has revealed a fault.
No data can be loaded from the backplane
when replacing electronics. Save the data to
the backplane again (Service).
S field frequency too high
The field frequency is set so high that the
field current cannot settle. The measured
values displayed are too low.
Set field frequencey lower; refer to C1.1.13.
Table 6-16: Measurements out of specification
Messages on the display Description
Actions
Status: C _ _ _ _ _
Output values partially simulated or
fixed
Maintenance required.
C checks in progress
Test mode of the device. Measured values
are possibly simulated values or values with
fixed settings.
Message depending on the situation via
HART® or FDT.
C test sensor
Test function of the flow tube electronics is
active.
-
Table 6-17: Simulation of the measured values
Messages on the display Description
Actions
Status: I _ _ _ _ _
Information (current measurement OK)
I counter 1 stopped
This is counter 1. The counter has stopped.
I counter 2 stopped
This is counter 2. The counter has stopped.
I power fail
The device was not in operation for an
unknown period of time, because the power
was switched off. This message is for
information only.
MI 021-517 en - APR 2020
www.se.com
If counter to continue counting, activate
"yes" in "C2.y.9 start counter".
Temporary power failure. Counters did not
run during it.
71
6 OPERATION
IMT30A
Messages on the display Description
Actions
Status: I _ _ _ _ _
Information (current measurement OK)
I over range display 1
1st line on page 1 (2) of display limited by
filter setting.
Menu display C4.3 and/or C4.4, select 1st or
2nd meas. page and increase values in
"C4.z.3 range" and/or "C4.z.4 limitation".
I over range conductivity
The limits for the conductivity measurement
have been exceeded (>10000 µS/cm) or are
lower than permitted (<0.1 µS/cm).
If the flow tube has been properly connected
and filled with medium, this does not affect
the flow measurement. The conductivity
measured values cannot be used.
I backplane sensor
The data on the backplane are not usable
because they have been generated with an
incompatible version.
-
I backplane settings
The global settings on the backplane are not
usable because they have been generated
with an incompatible version.
-
I backplane difference
The data on the backplane differ from the
data in the display. If the data are usable, a
dialogue is indicated in the display.
-
I conductivity off
Conductivity measurement switched off.
Changing of settings in C1.3.1.
I empty pipe
1 or 2 measuring electrodes are not in
contact with the medium; measured value is
set to zero. No measurement possible.
Measuring pipe not filled, function
dependent on C1.3.2. Check installation.
Or electrodes completely insulated e.g. by
oil film. Clean!
I diagnosis channel off
Diagnosis value switched off.
Changing of settings in C1.3.17.
I over range display 2
Table 6-18: Information
72
www.se.com
MI 021-517 en - APR 2020
SERVICE 7
IMT30A
7.1 Spare parts availability
The manufacturer adheres to the basic principle that functionally adequate spare parts for each
device or each important accessory part will be kept available for a period of 3 years after
delivery of the last production run for the device.
This regulation only applies to spare parts which are subject to wear and tear under normal
operating conditions.
7.2 Availability of services
The manufacturer offers a range of services to support the customer after expiration of the
warranty. These include repair, maintenance, technical support and training.
NOTICE!
For more precise information, please contact your local sales office.
7.3 Returning the device to the manufacturer
7.3.1 General information
This device has been carefully manufactured and tested. If installed and operated in accordance
with these operating instructions, it will rarely present any problems.
WARNING!
Should you nevertheless need to return a device for inspection or repair, please pay strict
attention to the following points:
• Due to statutory regulations on environmental protection and safeguarding the health and
safety of the personnel, the manufacturer may only handle, test and repair returned devices
that have been in contact with products without risk to personnel and environment.
• This means that the manufacturer can only service this device if it is accompanied by the
following certificate (see next section) confirming that the device is safe to handle.
WARNING!
If the device has been operated with toxic, caustic, radioactive, flammable or waterendangering products, you are kindly requested:
• to check and ensure, if necessary by rinsing or neutralising, that all cavities are free from
such dangerous substances,
• to enclose a certificate with the device confirming that it is safe to handle and stating the
product used.
MI 021-517 en - APR 2020
www.se.com
73
7 SERVICE
IMT30A
7.3.2 Preapproval form - Customer returned process-wetted products
LEGAL NOTICE!
In compliance with U.S. Federal OSHA Standard 29CFR1910.1200 process information must be
reviewed previous to receiving authorization to return material to Schneider Electric Systems
USA, Inc.
NO PRODUCT EXPOSED TO HYDROFLUORIC ACID OR MERCURY WILL BE ACCEPTED!
Date: ________________
Customer information
Customer’s name:
Address:
Phone no:
Fax no.:
Contact’s name:
Rep information
Rep’s name:
Address:
Phone no:
Fax no.:
Contacts’ name:
Product being returned:
Model No.:
Serial no.:
Under warranty?
YES
NO
Copies of MSDS sheets for all processes including cleaning solutions may be required.
Type of process (what chemicals/materials were processed through the unit):
Explain what steps were taken to decontaminate the unit: (was unit steam cleaned, rinsed out with water,
chemically cleaned etc.)
Form completed by:
_________________________
Print name
_________________________
Signature
Date: ________________
74
www.se.com
MI 021-517 en - APR 2020
SERVICE 7
IMT30A
CLEANING STATEMENT
(Note: Your item will not be serviced unless the following cleaning statement has been signed):
I certify that the above referenced item has been properly purged and cleaned, complies with U.S.
Department of Transportation shipping requirements and DOES NOT present a health and/or safety hazard
(as defined by OSHA) to our Customer Repair personnel.
Print name: _________________________
Signature: _________________________
Print title: ___________________________
Date: _____________________________
Please fax the completed form to the Customer Satisfaction Center +1-508-549-4999
7.4 Disposal
LEGAL NOTICE!
Disposal must be carried out in accordance with legislation applicable in your country.
Separate collection of WEEE (Waste Electrical and Electronic Equipment) in the European Union:
According to the directive 2012/19/EU, the monitoring and control instruments marked with the
WEEE symbol and reaching their end-of-life must not be disposed of with other waste
waste.
The user must dispose of the WEEE to a designated collection point for the recycling of WEEE or
send them back to our local organisation or authorised representative.
MI 021-517 en - APR 2020
www.se.com
75
8 TECHNICAL DATA
IMT30A
8.1 Measuring principle
An electrically conductive fluid flows inside an electrically insulated pipe through a magnetic
field. This magnetic field is generated by a current, flowing through a pair of field coils.
Inside of the fluid, a voltage U is generated:
U=v*k*B*D
in which:
v = mean flow velocity
k = factor correcting for geometry
B = magnetic field strength
D = inner diameter of flowmeter
The signal voltage U is picked off by electrodes and is proportional to the mean flow velocity v
and thus the flow rate Q. A signal transmitter is used to amplify the signal voltage, filter it and
convert it into signals for totalizing, recording and output processing.
Figure 8-1: Measuring principle
1
2
3
4
76
Field coils
Magnetic field
Electrodes
Induced voltage (proportional to flow velocity)
www.se.com
MI 021-517 en - APR 2020
TECHNICAL DATA 8
IMT30A
8.2 Technical data
NOTICE!
• The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local sales office.
• Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website.
Measuring system
Measuring principle
Faraday's law of induction
Application range
Continuous measurement of current volume flow, flow velocity, conductivity,
mass flow (at constant density), coil temperature of the flow tube
Design
Modular construction
The measuring system consists of a flow tube and a transmitter.
Flow tube
8400A
DN10...150 / 3/8…6"
8500A
DN2.5...100 / 1/10…4"
9500A
DN25...1200 / 1…48"
9600A
DN10...150 / 3/8...6"
9700A
DN10...1200 / 3/8…48"
Transmitter
Compact (integral) version (C)
IMT30A 2 & IMT30A 4
Wall-mounted remote version (W)
IMT30A M & IMT30A N
Options
Outputs
Current output (including HART®), pulse output, frequency output, status output
and/or limit switch
Note: It's not possible to use the pulse/frequency output with the status output
at the same time!
Counter
2 internal counters with a max. of 10 counter places (e.g. for counting volume
and/or mass units)
Verification
Integrated verification, diagnostic functions: measuring device, empty pipe
detection, stabilisation
Communication interfaces
HART®
Modbus
MI 021-517 en - APR 2020
www.se.com
77
8 TECHNICAL DATA
IMT30A
Display and user interface
Graphic display
LC display, backlit white
Size: 128 x 64 pixels, corresponds to 59 x 31 mm = 2.32" x 1.22"
Ambient temperatures below -25°C / -13°F may affect the readability of the
display.
Operating elements
4 push buttons for operating the transmitter when the housing is open.
4 magnet keys for operating the transmitter when the housing is closed.
Remote control
Only generic and not device-specific DDs and DTMs available!
PACTwareTM (including Device Type Manager (DTM))
HART® Communicator
AMS®
All DTMs and drivers are available free of charge from the manufacturer's
website.
Display functions
Operating menu
Setting the parameters using 2 measuring pages, 1 status page, 1 graphic page
(measured values and graphics are freely adjustable)
Language display texts (as language
package)
Standard: English, French, German, Dutch, Portuguese, Swedish, Spanish,
Italian
Eastern Europe: English, Slovenian, Czech, Hungarian
Northern Europe: English, Danish, Polish, Finnish
Southern Europe: English, Turkish
China: English, German, Chinese
(check www.BuyAutomation.com for availability)
Russia: English, German, Russian
Units
Metric, British and US units selectable as required from lists for volume / mass
flow and counting, flow velocity, electrical conductivity, temperature
Measuring accuracy
Max. measuring accuracy
Standard:
±0.5% of the measured value ± 1 mm/s
Option (optimised accuracy with extended calibration):
±0.25% of the measured value ± 1.5 mm/s
For detailed information and accuracy curves refer to Measuring accuracy on
page 89.
Special calibrations are available on request.
Current output electronics: ±10 µA; ±100 ppm/°C (typically: ±30 ppm/°C)
Repeatability
78
±0.1%
www.se.com
MI 021-517 en - APR 2020
TECHNICAL DATA 8
IMT30A
Operating conditions
Temperature
Process temperature
Refer to technical data for the flow tube.
Ambient temperature
Depending on the version and combination of outputs.
It is a good idea to protect the transmitter from external heat sources such as
direct sunlight as higher temperatures reduce the life cycle of all electronic
components.
Ambient temperatures below -25°C / -13°F may affect the readability of the
display.
Storage temperature
-40…+70°C / -40…+158°F
Pressure
Medium
Refer to technical data for the flow tube.
Ambient pressure
Atmosphere
Chemical properties
Electrical conductivity
All media except for water: ≥ 5 µS/cm
(also refer to the technical data for the flow tube)
Water: ≥ 20 µS/cm
State of aggregation
Conductive, liquid media
Solid content (volume)
≤ 10%
Gas content (volume)
≤ 3%
Flow rate
For detailed information, refer to chapter "Flow tables".
Other conditions
Ingress protection according to
IEC 60529
IP66/67 (according to NEMA 4/4X)
Installation conditions
Installation
For detailed information, refer to chapter "Installation".
Inlet / outlet sections
Refer to technical data for the flow tube.
Dimensions and weight
For detailed information refer to chapter "Dimensions and weight".
Materials
Transmitter housing
Aluminum with a polyester topcoat
Flow tube
For housing materials, process connections, liners, grounding electrodes and
gaskets, refer to technical data for the flow tube.
MI 021-517 en - APR 2020
www.se.com
79
8 TECHNICAL DATA
IMT30A
Electrical connection
General
Electrical connection is carried out in conformity with the VDE 0100 directive
"Regulations for electrical power installations with line voltages up to 1000 V" or
equivalent national specifications.
Power supply
100…230 VAC (-15% / +10%), 50/60 Hz;
240 VAC + 5% is included in the tolerance range.
24 VDC (-30% / +30%)
Power consumption
AC: 15 VA
DC: 5.6 W
Signal cable
Only necessary for remote versions.
DS 300 (type A)
Max. length: 600 m / 1968 ft (depending on electrical conductivity and flow tube
version)
Cable entries
Standard: M20 x 1.5 (8...12 mm)
Option: 1/2 NPT, PF 1/2
Outputs
General
All outputs are electrically isolated from each other and from all other circuits.
All operating data and output values can be adjusted.
Description of abbreviations
80
Uext = external voltage; RL = load + resistance;
Uo = terminal voltage; Inom = nominal current
www.se.com
MI 021-517 en - APR 2020
TECHNICAL DATA 8
IMT30A
Current output
Output data
Flow
Settings
Without HART®
Q = 0%: 0…20 mA; Q = 100%: 10…21.5 mA
Error identification: 20…22 mA
With HART®
Q = 0%: 4…20 mA; Q = 100%: 10…21.5 mA
Error identification: 3…22 mA
Operating data
Basic I/Os
Active
Observe connection polarity.
Uint, nom = 20 VDC
I ≤ 22 mA
RL ≤ 750 Ω
HART® at terminals A
Passive
Observe connection polarity.
Uext ≤ 32 VDC
I ≤ 22 mA
U0 ≤ 2 V at I = 22 mA
RL, max = (Uext - U0) / Imax
HART® at terminals A
HART®
Description
HART® protocol via active and passive current output
HART® version: V5
Universal Common Practice HART® parameter: completely supported
Load
≥ 230 Ω at HART® test point;
Note maximum load for current output!
Multi-drop mode
Yes, current output = 4 mA
Multi-drop address adjustable in operation menu 1…15
MI 021-517 en - APR 2020
www.se.com
81
8 TECHNICAL DATA
IMT30A
Pulse or frequency output
Output data
Flow
Function
Can be set as a pulse output or frequency output
Pulse rate/frequency
0.01...10000 pulses/s or Hz
Settings
Pulses per volume or mass unit or max. frequency for 100% flow
Pulse width: adjustable as automatic, symmetric or fixed (0.05...2000 ms)
Operating data
Basic I/Os + Modbus
Active
This output is intended to drive mechanical or electronic counters directly.
Uint, nom ≤ 20 V
RV = 1 kΩ
C = 1000 µF
High current mechanical counter
fmax ≤ 1 Hz
Low current mechanical counter
I ≤ 20 mA
RL ≤ 10 kΩ for f ≤ 1 kHz
RL ≤ 1 kΩ for f ≤ 10 kHz
closed:
U0 ≥ 12.5 V at I = 10 mA
open:
I ≤ 0.05 mA at Unom = 20 V
Passive
Independent of connection polarity.
Uext ≤ 32 VDC
fmax in operating menu set to fmax ≤ 100 Hz:
I ≤ 100 mA
open:
I ≤ 0.05 mA at Uext = 32 VDC
closed:
U0, max = 0.2 V at I ≤ 10 mA
U0, max = 2 V at I ≤ 100 mA
fmax in operating menu set to 100 Hz < fmax ≤ 10 kHz:
I ≤ 20 mA
open:
I ≤ 0.05 mA at Uext = 32 VDC
closed:
U0, max = 1.5 V at I ≤ 1 mA
U0, max = 2.5 V at I ≤ 10 mA
U0, max = 5.0 V at I ≤ 20 mA
82
www.se.com
MI 021-517 en - APR 2020
TECHNICAL DATA 8
IMT30A
Low flow cut off
Function
Switching point and hysteresis separately adjustable for each output, counter
and the display
Switching point
Set in increments of 0.1%.
0…20% (current output, frequency output) or 0...±9.999 m/s (pulse output)
Hysteresis
Set in increments of 0.1%.
0...5% (current output, frequency output) or 0...5 m/s (pulse output)
Time constant
Function
The time constant corresponds to the elapsed time until 67% of the end value
has been reached according to a step function.
Settings
Set in increments of 0.1 seconds.
0…100 seconds
Status output / limit switch
Function and settings
Adjustable as automatic measuring range conversion, display of flow direction,
counter overflow, error, switching point or empty pipe detection
Valve control with activated dosing function
Status and/or control: ON or OFF
Operating data
Basic I/Os + Modbus
Passive
Independent of connection polarity.
Uext ≤ 32 VDC
I ≤ 100 mA
open:
I ≤ 0.05 mA at Uext = 32 VDC
closed:
U0 = 0.2 V at I ≤ 10 mA
U0 = 2 V at I ≤ 100 mA
Modbus
Description
Modbus RTU, Master / Slave, RS485
Address range
1…247
Broadcast
Supported with function code 16
Supported Baud rate
1200, 2400, 3600, 4800, 9600, 19200, 38400, 57600, 115200 Baud
Approvals and certificates
CE
This device fulfils the statutory requirements of the relevant EU directives.
The manufacturer certifies successful testing of the product by applying the CE
mark.
For full information of the EU directives & standards and the approved
certifications, please refer to the EU declaration or the manufacturer website.
Other standards and approvals
Vibration resistance
Tested according to IEC 60068-2-64
NAMUR
NE 21, NE 43, NE 53
MI 021-517 en - APR 2020
www.se.com
83
8 TECHNICAL DATA
IMT30A
8.3 Dimensions and weight
8.3.1 Housing
Figure 8-2: Dimensions of wall version
Dimensions [mm]
a
Version with &
without display
b
157
c
40
80
d
e
120
248
f
111.7
Weight
[kg]
g
h
k
260
28.4
51.3 1.9
Table 8-1: Dimensions and weight in mm and kg
Dimensions [inch]
Version with &
without display
a
b
c
d
e
f
6.18
1.57
3.15
4.72
9.76
4.39
g
10.24
Weight
[lb]
h
k
1.12
2.02 4.2
Table 8-2: Dimensions and weight in inch and lb
84
www.se.com
MI 021-517 en - APR 2020
TECHNICAL DATA 8
IMT30A
Figure 8-3: Dimensions of compact version
Dimensions [mm]
a
Version with &
without display
b
157
c
40
d
80
e
148.2
f
101
g
260
Weight
[kg]
95.5 1.8
Table 8-3: Dimensions and weight in mm and kg
Dimensions [inch]
a
Version with &
without display
6.18
b
1.57
c
d
3.15
5.83
e
3.98
f
10.24
g
Weight
[lb]
3.76 4.0
Table 8-4: Dimensions and weight in inch and lb
MI 021-517 en - APR 2020
www.se.com
85
8 TECHNICAL DATA
IMT30A
8.3.2 Mounting plate, wall version
g h
f
e
Figure 8-4: Dimensions of mounting plate, wall version
[mm]
[inch]
a
Ø6.5
Ø0.26
b
Ø8.1
Ø0.3
c
15
0.6
d
40
1.6
e
96
3.8
f
20
0.8
g
248
9.8
h
268
10.5
k
35
1.4
l
55
2.2
Table 8-5: Dimensions in mm and inch
86
www.se.com
MI 021-517 en - APR 2020
TECHNICAL DATA 8
IMT30A
8.4 Flow tables
Q100 % in m3/h
v [m/s]
0.3
1
DN [mm]
Minimum flow
3
12
Nominal flow
Maximum flow
2.5
0.005
0.02
0.05
0.21
4
0.01
0.05
0.14
0.54
6
0.03
0.10
0.31
1.22
10
0.08
0.28
0.85
3.39
15
0.19
0.64
1.91
7.63
20
0.34
1.13
3.39
13.57
25
0.53
1.77
5.30
21.21
32
0.87
2.90
8.69
34.74
40
1.36
4.52
13.57
54.29
50
2.12
7.07
21.21
84.82
65
3.58
11.95
35.84
143.35
80
5.43
18.10
54.29
217.15
100
8.48
28.27
84.82
339.29
125
13.25
44.18
132.54
530.15
150
19.09
63.62
190.85
763.40
200
33.93
113.10
339.30
1357.20
250
53.01
176.71
530.13
2120.52
300
76.34
254.47
763.41
3053.64
350
103.91
346.36
1039.08
4156.32
400
135.72
452.39
1357.17
5428.68
450
171.77
572.51
1717.65
6870.60
500
212.06
706.86
2120.58
8482.32
600
305.37
1017.90
3053.70
12214.80
700
415.62
1385.40
4156.20
16624.80
800
542.88
1809.60
5428.80
21715.20
900
687.06
2290.20
6870.60
27482.40
1000
848.22
2827.40
8482.20
33928.80
1200
1221.45
3421.20
12214.50
48858.00
Table 8-6: Flow rate in m/s and m3/h
MI 021-517 en - APR 2020
www.se.com
87
8 TECHNICAL DATA
IMT30A
Q100 % in US gallons/min
v [ft/s]
1
3.3
DN [inch]
Minimum flow
10
40
Nominal flow
Maximum flow
1/10
0.02
0.09
0.23
0.93
1/6
0.06
0.22
0.60
2.39
1/4
0.13
0.44
1.34
5.38
3/8
0.37
1.23
3.73
14.94
1/2
0.84
2.82
8.40
33.61
3/4
1.49
4.98
14.94
59.76
1
2.33
7.79
23.34
93.36
1.25
3.82
12.77
38.24
152.97
1.5
5.98
19.90
59.75
239.02
2
9.34
31.13
93.37
373.47
2.5
15.78
52.61
159.79
631.16
3
23.90
79.69
239.02
956.09
4
37.35
124.47
373.46
1493.84
5
58.35
194.48
583.24
2334.17
6
84.03
279.97
840.29
3361.17
8
149.39
497.92
1493.29
5975.57
10
233.41
777.96
2334.09
9336.37
12
336.12
1120.29
3361.19
13444.77
14
457.59
1525.15
4574.93
18299.73
16
597.54
1991.60
5975.44
23901.76
18
756.26
2520.61
7562.58
30250.34
20
933.86
3112.56
9336.63
37346.53
24
1344.50
4481.22
13445.04
53780.15
28
1829.92
6099.12
18299.20
73196.79
32
2390.23
7966.64
23902.29
95609.15
36
3025.03
10082.42
30250.34
121001.37
40
3734.50
12447.09
37346.00
149384.01
48
5377.88
17924.47
53778.83
215115.30
Table 8-7: Flow rate in ft/s and US gallons/min
88
www.se.com
MI 021-517 en - APR 2020
TECHNICAL DATA 8
IMT30A
8.5 Measuring accuracy
Every electromagnetic flowmeter is calibrated by direct volume comparison. The wet calibration
validates the performance of the flowmeter under reference conditions against accuracy limits.
The accuracy limits of electromagnetic flowmeters are typically the result of the combined effect
of linearity, zero point stability and calibration uncertainty.
Reference conditions
•
•
•
•
Medium: water
Temperature: +5...+35°C / +41...+95°F
Operating pressure: 0.1...5 barg / 1.5...72.5 psig
Inlet section: ≥ 5 DN; outlet section: ≥ 2 DN
Figure 8-5: Measuring accuracy
X [m/s]: flow velocity
Y [%]: accuracy of measured value (mv)
DN [mm]
DN [inch]
Standard accuracy 1
Optimised accuracy 2
8400A
10…150
3/8…6
±0.5% of mv ± 1 mm/s
8500A
2.5...100
1/10…4
only 9500A / 9700A:
±0.25% of mv ± 1.5 mm/s
9500A
25…1200
1…48
9600A
10…150
3/8…6
9700A
10…1200
3/8…48
Extended calibration at
2 points
Table 8-8: Measuring accuracy
MI 021-517 en - APR 2020
www.se.com
89
9 NOTES
90
IMT30A
www.se.com
MI 021-517 en - APR 2020
NOTES 9
IMT30A
MI 021-517 en - APR 2020
www.se.com
91
MI 021-517 en - APR 2020
Schneider Electric Systems USA, Inc.
38 Neponset Avenue
Foxboro, MA 02035
United States of America
http://www.se.com
Global Customer Support
Inside U.S.: 1-866-746-6477
Outside U.S.: 1-508-549-2424
https://pasupport.schneider-electric.com
Copyright 2020 Schneider Electric Systems USA, Inc.
All rights reserved.
The Schneider Electric brand and any trademarks of
Schneider Electric SE or its subsidiaries are the property
of Schneider Electric SE or its subsidiaries.
All other trademarks are the property of their respective
owners.
APR 2020

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
