Schneider Electric InRow DX 10 kW Air Cooled User Guide

Operation and Maintenance Manual
InRow® Air-Cooled, Direct Expansion
InRow® DX 10 kW
ACRD100, ACRD101
990-3212D-001
Publication Date: March 2019
Schneider Electric IT Corporation Legal Disclaimer
The information presented in this manual is not warranted by the Schneider Electric IT Corporation to be
authoritative, error free, or complete. This publication is not meant to be a substitute for a detailed operational
and site specific development plan. Therefore, Schneider Electric IT Corporation assumes no liability for
damages, violations of codes, improper installation, system failures, or any other problems that could arise
based on the use of this Publication.
The information contained in this Publication is provided as is and has been prepared solely for the purpose of
evaluating data center design and construction. This Publication has been compiled in good faith by Schneider
Electric IT Corporation. However, no representation is made or warranty given, either express or implied, as to
the completeness or accuracy of the information this Publication contains.
IN NO EVENT SHALL SCHNEIDER ELECTRIC IT CORPORATION, OR ANY PARENT, AFFILIATE OR
SUBSIDIARY COMPANY OF SCHNEIDER ELECTRIC IT CORPORATION OR THEIR RESPECTIVE
OFFICERS, DIRECTORS, OR EMPLOYEES BE LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL,
PUNITIVE, SPECIAL, OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR
LOSS OF BUSINESS, CONTRACT, REVENUE, DATA, INFORMATION, OR BUSINESS INTERRUPTION)
RESULTING FROM, ARISING OUT, OR IN CONNECTION WITH THE USE OF, OR INABILITY TO USE THIS
PUBLICATION OR THE CONTENT, EVEN IF SCHNEIDER ELECTRIC IT CORPORATION HAS BEEN
EXPRESSLY ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SCHNEIDER ELECTRIC IT
CORPORATION RESERVES THE RIGHT TO MAKE CHANGES OR UPDATES WITH RESPECT TO OR IN
THE CONTENT OF THE PUBLICATION OR THE FORMAT THEREOF AT ANY TIME WITHOUT NOTICE.
Copyright, intellectual, and all other proprietary rights in the content (including but not limited to software, audio,
video, text, and photographs) rests with Schneider Electric It Corporation or its licensors. All rights in the
content not expressly granted herein are reserved. No rights of any kind are licensed or assigned or shall
otherwise pass to persons accessing this information.
This Publication shall not be for resale in whole or in part.
Table of Contents
Safety................................................................................. 7
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Notices During Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
General Information .........................................................10
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Save these instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cross-reference symbol used in this manual . . . . . . . . . . . . .
Manual updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Environmental considerations . . . . . . . . . . . . . . . . . . . . . . . . .
10
10
10
10
Commissioning ................................................................11
Inspection Checklists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Initial inspection checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical inspection checklist . . . . . . . . . . . . . . . . . . . . . . . . .
Mechanical inspection checklist . . . . . . . . . . . . . . . . . . . . . . .
User interface inspection checklist . . . . . . . . . . . . . . . . . . . . .
Start-up inspection checklist . . . . . . . . . . . . . . . . . . . . . . . . . .
Final inspection checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11
12
13
14
14
14
Charging With Refrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Calculating R410A charge . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Charging the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Compressor Oil Charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Oil charging procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operation .........................................................................21
Display Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the Display Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Scrolling status screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main menu screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Navigating the main menu . . . . . . . . . . . . . . . . . . . . . . . . . . .
Navigating the sub-menus . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Path statement . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Password entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Start the cooling unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stop the cooling unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
InRow RD 10 kW Air Cooled Operation and Maintenance
22
22
23
23
24
24
25
25
3
General Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Cooling unit configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
View the state of input and output contacts . . . . . . . . . . . . . . . 27
Edit the normal state of input and output contacts . . . . . . . . . 27
Cooling Group Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Configure the cooling group . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Identify the cooling unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Configure Modbus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Control the Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
How the Cool mode works . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
See Supply Air and Return Air on page 33 for more information. 30
Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
PID settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Tune the PID loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Run hours . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Thresholds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Service intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Password and time-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjust display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
34
34
35
35
Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Configure network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
View Status Readings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Scrolling status screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling unit status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling group status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
About the cooling unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
36
36
37
37
Event Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
View the event log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Clear the event log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Respond to Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
View active alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Clear active alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Alarm messages and suggested actions . . . . . . . . . . . . . . . . 38
4
InRow RD 10 kW Air Cooled Operation and Maintenance
Network Management Card.............................................41
Quick Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TCP/IP configuration methods . . . . . . . . . . . . . . . . . . . . . . . .
Device IP Configuration Wizard . . . . . . . . . . . . . . . . . . . . . . .
.ini file utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BOOTP & DHCP configuration . . . . . . . . . . . . . . . . . . . . . . . .
Local access to the control console . . . . . . . . . . . . . . . . . . . .
Remote access to the control console . . . . . . . . . . . . . . . . . .
Control console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
41
41
42
42
42
43
44
44
Access a Configured Network Management Card . . . . . . . . . . . . . . . . 45
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Telnet and SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Simple Network Management Protocol (SNMP) . . . . . . . . . 46
FTP/SCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Modbus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Recover From a Lost Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Maintenance ....................................................................48
Monthly Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleanliness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
48
48
49
49
Quarterly Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Functional tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Semi-Annual Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 51
Cleanliness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Troubleshooting ...............................................................52
InRow RD 10 kW Air Cooled Operation and Maintenance
5
Safety
Important Safety Information
Read the instructions carefully to become familiar with the equipment before trying to install, operate, service,
or maintain it. The following special messages may appear throughout this manual or on the equipment to warn
of potential hazards or to call attention to information that clarifies or simplifies a procedure.
The addition of this symbol to a Danger or Warning safety label indicates that an electrical hazard
exists which will result in personal injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible injury or death.
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, can result in death
or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, can result in minor
or moderate injury.
NOTICE
NOTICE addresses practices not related to physical injury including certain environmental
hazards, potential damage or loss of data.
InRow RD 10 kW Air Cooled Operation and Maintenance
7
Safety Notices During Operation
Read and adhere to the following important safety considerations when working with this equipment. Follow all
local and national regulations when handling refrigerants.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work
practices. See NFPA 70E or CSA Z462.
• This equipment must be installed and serviced by qualified personnel only.
• Turn off all power supplying this equipment before working on or inside the equipment.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace all devices, doors, and covers before turning on power to this equipment.
Failure to follow these instructions will result in death or serious injury.
WARNING
HAZARD TO EQUIPMENT OR PERSONNEL
All work must be performed by Schneider Electric qualified personnel.
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
WARNING
HAZARD FROM MOVING PARTS
Keep hands, clothing, and jewelry away from moving parts. Check the equipment for
foreign objects before closing the doors and starting the equipment.
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
WARNING
HAZARD OF EQUIPMENT FALLING OVER
• Use two or more persons at all times to move or turn this equipment.
• Always push, pull, or turn while facing the front and rear of this equipment. Never push,
pull, or turn while facing the sides of this equipment.
• Slowly move this equipment across uneven surfaces or door thresholds.
• Lower leveling feet to floor when this equipment is at rest.
• Lower leveling feet and attach joining brackets to adjacent racks when this equipment is
in final position.
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
8
InRow RD 10 kW Air Cooled Operation and Maintenance
CAUTION
HAZARD TO EQUIPMENT OR PERSONNEL
Ensure that all spare parts and tools are removed from the equipment before operating it
Failure to follow these instructions can result in injury or equipment damage.
NOTICE
STATIC ELECTRICITY HAZARD
Circuit boards contained within this unit are sensitive to static electricity. Use one or more
electrostatic-discharge devices while handling the boards.
Failure to follow these instructions can result in equipment damage.
InRow RD 10 kW Air Cooled Operation and Maintenance
9
General Information
Overview
Save these instructions
This manual contains important instructions that must be followed during installation, operation, and
maintenance of the cooling unit.
Cross-reference symbol used in this manual
See another section of this document or another document for more information on this subject.
Manual updates
Check for updates to this manual on the Schneider Electric Web site, www.schneider-electric.com/support.
Select the Download Documents and Software link under the Support tab and enter the manual part number
or SKU for your equipment in the search field. See the back cover of this manual for the part number.
Environmental considerations
Wind: The equipment is not intended for installation in areas of high wind. Consult your sales representative for
information on any applicable options for installation in areas of high wind.
Earthquakes: The equipment is not intended for installation in areas at risk of seismic activity. Consult your
sales representative for information on any applicable options for installation in areas at risk of seismic activity.
ATEX: The equipment is not intended for use in potentially explosive atmospheres and does not comply with
Directive 2014/34 / EU (ATEX).
Corrosion: The equipment is not intended for use in a potentially corrosive environment.
10
InRow RD 10 kW Air Cooled Operation and Maintenance
Commissioning
After installation is complete, verify that all components are working properly and that the cooling unit is ready
to begin operation.
Inspection Checklists
Initial inspection checklist
WARNING
OPERATIONAL HAZARDS
• The cooling unit operates under pressure. Take proper safety precautions when
connecting gauges or servicing piping.
• Do not operate the cooling unit with any cover, guard, door, or panel removed unless the
instructions indicate otherwise. Then, proceed with extreme caution.
• Do not run service utilities in front of the fan outlets.
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
NOTE: The vapor barrier minimizes moisture infiltration. Without a vapor barrier, it will be difficult to maintain
the humidity in the room. Do not introduce unconditioned outside air into the space.
The initial inspection ensures that the cooling unit has been properly installed, the location of the cooling unit
has been properly prepared, and the cooling unit is free of damage.
NOTE: A minimum of 900 mm (36 in.) of clear floor space in front of and behind the cooling unit is required for
service access. To roll the cooling unit out of the row, there must be a minimum of 1200 mm (48 in.) of clear
floor space in front of or behind the cooling unit. Out-of-row service requires 760 mm (30 in.) of side clearance
in addition to the front and rear clearance.
Ensure that:

The installation procedure is complete according to the installation manual.

The walls, floor, and ceiling of the room where the cooling unit is located are sealed with a vapor barrier.

There is no evidence of damage to the cooling unit.

The cooling unit is level and joined to the adjacent racks.

The cooling unit is not installed at the open end of a row.

The clearance around the cooling unit is in accordance with local and national codes and regulations as
well as the installation manual.
InRow RD 10 kW Air Cooled Operation and Maintenance
11
Electrical inspection checklist
WARNING
ELECTRICAL HAZARD
• Electrical service must conform to local and national electrical codes and regulations.
• The equipment must be grounded.
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
The electrical inspection verifies that all electrical connections are secure and correct and that the cooling unit
is properly grounded.
Ensure that the:
12

Incoming voltages match the phase and voltage listed on the nameplate.

Electrical wiring complies with local and national codes and regulations.

The cooling unit is properly grounded.

Electrical connections are tight, including contactors, terminal blocks, controllers, switches, relays,
auxiliary devices, and field connections.
InRow RD 10 kW Air Cooled Operation and Maintenance
Mechanical inspection checklist
NOTICE
HAZARD TO EQUIPMENT
• The equipment is shipped from the factory with a nitrogen holding charge. Remove the
nitrogen holding charge using the service valves located on the internal refrigerant piping.
• Improperly installed piping may result in improper operation and possible damage to the
cooling unit or surrounding equipment.
Failure to follow these instructions can result in equipment damage.
The mechanical inspection verifies that all mechanical components and connections are secure and tight and
ready for start-up and system charging. The inspection ensures that field piping is properly installed to promote
oil return to the compressor.
Ensure that the:

Fans are turning freely and that the blades are not distorted or bent.

Condensate drain line is at least the size of the drain connection.

Piping joints are tight.

Mechanical connections are tight, including compressor and receiver rotolock connections.

Refrigerant piping size is correct according to the line size table in the installation manual.

Vertical, horizontal, and total run lengths of the liquid, discharge, and suction lines are recorded.

Number of 45- and 90-degree bends in the refrigerant piping are recorded.

Field-installed traps and piping are in accordance with the installation manual and follow proper piping
practices.

Refrigerant piping is adequately supported and isolated when necessary.

Field-installed service valves are open.

Pressure relief valve is installed in accordance with the installation manual as well as local and national
codes and regulations.

Piping in the building and on the roof is properly insulated.

Covers and guards are in place.
InRow RD 10 kW Air Cooled Operation and Maintenance
13
User interface inspection checklist
The user interface inspection verifies that the sensors and internal communications links of the cooling unit are
installed properly.
Ensure that:

An A-Link bus is connected to each cooling unit in the group and a terminator is plugged into all unused
A-Link connectors.

The input contacts and output relays are connected correctly.

The building management system is connected correctly and a terminator is wired into the final unit
between Modbus D0 and Modbus D1.

The rack temperature sensors are installed correctly.

The network port is connected correctly and an IP address has been assigned to the equipment.
Start-up inspection checklist
The start-up inspection ensures that the cooling unit is operating properly after the initial start-up. This
inspection verifies that all modes of operation are working correctly and that the cooling unit is ready for normal
operation.
While the cooling unit is operating, ensure that the:

Cooling unit is free from malfunctions, unusual vibrations, or other irregularities in each mode of
operation.

Cool cycles engage.

Air filters are clean and free of debris. Replace air filters with Schneider Electric part number 875-2013.

Clogged filter alarm is operating properly:
Cover 1/3 of the filter area and monitor alarm performance.

Compressor suction and discharge pressures are recorded.

Sight glass moisture sensor is green.
Final inspection checklist
The final inspection verifies that the system is clean and the start-up form has been sent to Schneider Electric.
Ensure that:
14

System is clean and free from debris.

Packaging materials are disposed of properly.

Start-up form was completed and sent to Schneider Electric.
InRow RD 10 kW Air Cooled Operation and Maintenance
Charging With Refrigerant
Calculating R410A charge
Use the following table and formula when calculating the total R410A charge.
Condenser
Model
Condenser Flooded Charge in kg (lb) for Different
Minimum Outdoor Ambient Temperatures
Selected
Condenser
Ambient
Summer
Temperature
Charge
°C (°F)
kg (lb)
4°C
(40 °F)
–7°C
(20°F)
–18°C
(0°F)
–29°C
(–20°F)
–40°C
(–40°F)
ACCD75214
35 (95)
2.2 (4.9)
5.48 (12.1)
5.85 (12.9)
6.03 (13.3)
6.17 (13.6)
6.30 (13.9)
ACCD75214
40 (105)
2.2 (4.9)
5.48 (12.1)
5.85 (12.9)
6.03 (13.3)
6.17 (13.6)
6.30 (13.9)
ACCD75215
46 (115)
3.85 (8.5)
9.57 (21.1)
10.16 (22.4)
10.48 (23.1)
10.70 (23.6) 10.93 (24.1)
ACCD75216
35 (95)
1.36 (3)
3.08 (6.8)
3.26 (7.2)
3.36 (7.4)
3.45 (7.6)
3.49 (7.7)
ACCD75218
ACCD75220*
40 (105)
1.36 (3)
3.08 (6.8)
3.26 (7.2)
3.36 (7.4)
3.45 (7.6)
3.49 (7.7)
ACCD75217
ACCD75219
46 (115)
2.27(5)
6.12 (13.5)
6.53 (14.4)
6.71 (14.8)
6.89 (15.2)
7.03 (15.5)
* ACCD75220 is CCC certified for use in China.
Type of Fitting or Valve – Equivalent Length of Pipe in m (ft)
ACR Pipe Size (OD)
Gate Valve Standard Elbow 90 ° Reduced Coupling Side Outlet T
Angle Valve
1/2 in.
0.18 (0.6)
0.43 (1.4)
0.43 (1.4)
0.82 (2.7)
1.83 (6.0)
5/8 in.
0.21 (0.7)
0.49 (1.6)
0.49 (1.6)
0.91 (3.0)
2.13 (7.0)
Recommended Line Sizes
Equivalent length m (ft)
15 (50)
30 (100)
16 (150)
Line Type
Air-Cooled ACRD Units
Discharge line (horizontal)
Discharge line (vertical)
Liquid line
Discharge line (horizontal)
Discharge line (vertical)
Liquid line
Discharge line (horizontal)
Discharge line (vertical)
Liquid line
5/8 in. OD ACR
1/2 in. OD ACR
1/2 in. OD ACR
5/8 in. OD ACR
1/2 in. OD ACR
1/2 in. OD ACR
5/8 in. OD ACR
1/2 in. OD ACR
1/2 in. OD ACR
NOTE: All refrigerant pipes must be straight ACR to have 39 bar (565 psig) or above MWP. Equivalent length of
1/2 in. OD discharge line pipe should be kept less than 18 m (60 ft). Total equivalent length of the discharge line
should be less than 46 m (150 ft) to prevent excessive hot gas pressure drop which can increase the discharge
pressure during hot summer days. To have 61 m (200 ft) total equivalent discharge pipe length the load must
be reduced by 5%.
Total charge = Equipment charge + condenser summer charge + condenser flooded charge (for minimum
possible ambient temperature) + liquid R410A in liquid pipe
Equipment charge: 1.6 kg (3.5 lb)
InRow RD 10 kW Air Cooled Operation and Maintenance
15
Quantity of R410A in 1/2 in. OD liquid line: (area) x (length in ft) x (density): 0.0010554 (ft2) x L (ft) x 61.0 (lbm/
ft3)
Density of liquid R410A at 40.6 °C (105 °F) and 260 psig: 0.98 g/cm3 (61.0 lbm/ft3 )
Cross sectional area for 1/2 in. OD pipe is 0.0010554 ft2.
Liquid line charge for 1/2 in. OD ACR copper tube: 0.095 kg/m (0.0644 lb/ft).
Cross sectional area for 5/8 in. OD pipe is 0.001619 ft2.
Quantity of R410A in 5/8 in. OD liquid line: (area) x (length in ft) x (density): 0.001619 (ft2) x L (ft) x 61.0 (lbm/
ft3).
Liquid line charge for 5/8 in. OD ACR copper tube: 0.146 kg/m (0.099 lb/ft).
Example:
Calculate the total R410A charge for an FCB5 condenser with 25 ft of 1/2 in. OD liquid piping. Minimum outdoor
design temperature is -28.9°C (-20 °F).
NOTE: Imperial units are used in this example.
Total R410A charge: 3.5 + 4.9 + 13.6 + (25*0.0644) = 23.6 lb.
16
InRow RD 10 kW Air Cooled Operation and Maintenance
Charging the equipment
WARNING
HAZARD TO EQUIPMENT OR PERSONNEL
All work must be performed by Schneider Electric qualified personnel.
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
CAUTION
HAZARD OF HIGH PRESSURE REFRIGERANT OR EQUIPMENT DAMAGE
• Use R410a refrigerant only.
• Use hose and manifold set suitable for R410a with a minimum pressure rating of 50 bar
(725 PSIG).
• The unit display should be used to obtain pressure readings.
Failure to follow these instructions can result in injury or equipment damage.
NOTICE
HAZARD TO EQUIPMENT
Introducing a fast charge of liquid refrigerant through the suction port may damage the
compressor.
Failure to follow these instructions can result in equipment damage.
R410A is a blend refrigerant. When charging equipment with blend refrigerants, only liquid refrigerant must be
charged.
1. Ensure the ball valves are open.
2. Confirm the calculated system charge.
3. Connect the refrigerant cylinder to the charging or gauge port on the receiver outlet valve. Open the
receiver valve approximately half way.
4. Charge liquid refrigerant into the high side of the system until the system pressures equalize. While the
unit is NOT operational, charge liquid to the suction (low side) line to simply equalize pressures
throughout the system DO NOT start the system until the pressure equalizes. Please note charging
liquid to the suction port during operation may damage or reduce the life of the compressor.
5. Prior to starting the system, make sure all system valves are open and the system high side pressure
remains above 24.8 bar (360 psi). This may require blocking the condenser inlet slightly. Remove any
blocking panels after charging is complete.
6. Start the cooling unit. See “Start the cooling unit” on page 25 for more information.
7. Once the system is operational, front seat the receiver service valve and continue charging liquid at the
service port down stream of the receiver shutoff valve, until the calculated charge is complete. When
this procedure is complete, fully back seat the receiver shutoff valve. Leave charging hoses in place in
the event additional charging is required.
8. Charge the rest of the calculated liquid refrigerant very slowly through the suction port.
InRow RD 10 kW Air Cooled Operation and Maintenance
17
9. Verify that the sight glass is clear. If there is excessive bubbling in the sight glass, make sure the system
high side pressure is above 23.4 bar (340 psi) and superheat and sub-cooling are within parameters
(10–12 for superheat and 8–10 for sub-cooling). If additional charging is required, front seat the receiver
shutoff valve and weigh in the additional charge at the service port.
NOTE: Since good performance during low ambient temperatures depends on proper refrigerant
charge, it is very important that this phase of the installation procedure be done carefully. Poor system
performance can be due to too little or too much charge.
18
InRow RD 10 kW Air Cooled Operation and Maintenance
Compressor Oil Charge
NOTICE
HAZARD TO EQUIPMENT
Be careful not to charge more oil than is necessary. Excessive oil in the system may
cause system damage, including the following:
• Failure of compressor due to oil slugging.
• Excessive oil carryover.
• Loss of evaporator performance due to oil level build-up in the low-pressure side of the
system.
Failure to follow these instructions can result in equipment damage.
NOTICE
HAZARD TO EQUIPMENT
• This procedure is to be done by qualified personnel only.
• Do not charge the compressor with too much oil, or compressor damage could result.
The only way to drain oil from the compressor is to remove the compressor from the
equipment, which cannot be done when the equipment is in the row.
Failure to follow these instructions can result in equipment damage.
You may need to add oil to air-cooled equipment, depending on the condenser size and the lengths of tube
running between the equipment and the condenser.
Oil charging procedure
1. Calculate the approximate amount of additional oil needed using the following formula:
0.7 x {(R x 0.022 x 16) – (C x 0.10)} = A
– R — Refrigerant in the system (this amount should have been recorded during installation)
– C — Compressor oil charge (in fluid ounces)
– A — Amount of additional oil (in fluid ounces).
NOTE: The compressor used in this equipment comes with an internal oil charge of 1064 ml (36 fl
oz).
In the following example, there are 20 pounds of refrigerant in the system.
(20 x 0.022 x 16)–(36 x 0.10)
0.7{(20 X 0.022 X 16) - (36 x 0.1)} = 2.3 fluid ounces of additional oil.
InRow RD 10 kW Air Cooled Operation and Maintenance
19
2. Prepare to add oil:
a. Use a new, sealed oil can and a manual oil pump. The pump hose must be sized for 1/4 in. flare
fittings and must include a valve depressor at its end, which will open the valve on the service port
of the compressor.
b. At a minimum, use a quality POE oil with a viscosity of 32 cst, 160 sus at 40°C (104°F).
Suggested oils: Danfoss Maneurop 160 PZ Polyolesteroil, the approved type of oil for this
equipment. Approved alternative oil types:
• CPI (Lubrizol) reference: CP-2931AH or CP-2931A or equivalent
• ICI_UNIQUEMA reference: Emkarate RL32H or equivalent
3. Purge the pump and hose:
a. Ensure that the oil pump is clean. Insert the pump in the oil container and make sure that the
container is open to the atmosphere for as short a period of time as possible. When available, use
a plug adapter kit to further reduce the exposure of the oil to the atmosphere.
b. Bleed all air from the pump and hose with a few strokes of the pump. Purging the pump removes
the moisture-saturated oil left inside the hose from previous usage.
c. Connect the hose to the service port of the compressor immediately after purging to avoid
moisture contamination.
4. While the equipment is running, charge the oil through the suction service port. Pump the oil very slowly.
NOTE: Dispose of the oil waste appropriately.
20
InRow RD 10 kW Air Cooled Operation and Maintenance
Operation
Display Interface
ESC
Status
Check
Log
?
Warning
na1582a
Critical
Item
Function

Critical Alarm LED (red)
When lit, a critical alarm condition exists and requires immediate attention.

Warning Alarm LED
(yellow)
When lit, a warning alarm condition exists. Failure to correct this condition
could cause a critical alarm.

Check Log LED (yellow)
When lit, at least one new event has been logged since the last time the log
was checked. Only events that pertain to the operation of the cooling unit will
activate the LED.

Status LED (green)
When lit, the cooling unit is receiving electrical power. When flashing green,
the cooling unit is downloading firmware for the controller. Downloads may
take up to ten minutes.

Liquid Crystal Display
(LCD)
View alarms, status data, and context-sensitive help. Modify configurable
settings.

Up and down arrow keys
Select menu items and access information.

ESC key
Return to previous screen or cancel current operation.

Enter key
Open menu items and input changes to cooling group level and cooling unit
level settings.

Help key
Display context-sensitive help. Press the help key for information about each
option on the screen and for instructions on performing tasks.
InRow RD 10 kW Air Cooled Operation and Maintenance
21
Using the Display Interface
Every time power is applied to the cooling unit, the display interface initializes, causing the LEDs to cycle and
the alarm-tone to activate.
Scrolling status screens
After start-up, the interface displays the firmware revision number on the display interface. The display interface
then scrolls automatically and continuously through screens of status information.
Status Screen Name
Status Information Displayed
InRow RD
• On/Standby/Idle/Service
• User Defined Name
• User Defined Location
Group
• Alarms/No Alarms
• Cool Output kW
• Cool Setpoint °C (or °F)
• Maximum Rack Temperature °C (or °F )
Unit
• Alarms/No Alarms
• Cool Output kW
• Air Flow l/s (liters per second) or CFM (cubic feet per minute)
• Rack Inlet °C (or °F)
Press the up or down arrow key to interrupt the automatic scrolling and view a specific status screen. From a
main menu screen, press ESC to return to the scrolling status screens.
Main menu screens
On any top-level status screen, press the ENTER or ESC key to open the first main
menu screen.
For information on setting the time-out duration, see “Timeout:” on
page 34.
NOTE: Once a period of inactivity - at the display interface - exceeds the
Password Timeout setting, the display interface returns to the scrolling status
screens.
All main menu choices are displayed on a series of six main menu screens.
On/Standby
View Alarms
Clear Alarms
View Event Log
Clear Event Log
Configure Modbus
Set Date & Time
Set Password
Set Display Units
Configure Display
Configure Network
About InRow RD
Set Identification
Service Intervals
Set Group PID
Set Unit Threshlds
View Unit Status
View Group Status
22
na1636d
View Run Hours
Configure Unit
Configure Group
Set Group Setpoint
InRow RD 10 kW Air Cooled Operation and Maintenance
Navigating the main menu
Clear Event Log
Configure Modbus
Set Date & Time
Set Password
na1623h
Selector arrow: Press the up or down arrow key to move the selector arrow  to a main menu option. Press
the ENTER key to view the selected sub-menu screen. In the example shown below, the selector arrow points to
the Set Date and Time setting. To select that item, press the ENTER key.
NOTE: If the selector arrow is on the top line of a main menu screen, press the up arrow key to move the
selector arrow to the top line of the previous screen.
Clear Event Log
Configure Modbus
Set Date & Time
Set Password
na1623f
Continue arrows: Continue arrows  indicate that additional options or settings are available on a menu or
status screen. Press the up or down arrow key to view the additional items.
Navigating the sub-menus
Time: 13:15:23
Date: 18-Nov-2010
Format: dd/mm/yyyy
na1623g
Selecting a main menu option displays the sub-menu screen for that option. In this example, the selector arrow
is on the top line of the Set Date and Time sub-menu screen.
Use the up or down arrow key to move the selector arrow to an option, and press the ENTER key.
• List of choices. If the setting is a list of choices, an input arrow  displays next to the setting. Press the
up or down arrow key to select the menu option to change. Then press the ENTER key to exit the input
mode and save the setting. Press the ESC key to exit without saving.
• Numbers or text fields. If the setting is a number or text field, use the arrow keys to select the value of
the first character, and press the ENTER key to move to the next character. Press the ENTER key after the
last character is set to exit the input mode and save the setting. Press the ESC key to exit without saving.
If an invalid value is entered, the display interface beeps and restores the previous valid value to the
field.
Time: 13:15:23
Date: 18-Nov-2010
Format: dd/mm/yyyy
InRow RD 10 kW Air Cooled Operation and Maintenance
na1622aa
Input arrows: Input arrows  next to a selected setting indicate that the setting can be modified by pressing
the up or down arrow key. Press the ENTER key to save the change or the ESC key to cancel the change.
23
Using the Path statement
Select the main- and sub-menu options specified in the path statement to view or configure a setting. The path
statement lists the main- and sub-menu items you select to navigate to the item to view or modify. The parts of
the path statement are defined below:
Path: Main > Set Password > Change Passwords
Main: Your starting point is the main menu.
Set Password: Scroll to and select this option from the main menu.
Change Passwords: Scroll to and select this option from the sub-menu.
Subsequent options are listed and defined under the path statement.
Password entry
The cooling unit has two levels of password protection:
• Device password allows Device Users to change basic and environmental settings.
• Admin password allows all privileges granted for Device Users, and also allows the Administrator to
modify settings that control the components in the cooling unit or change advanced options.
When you try to change a setting, the display interface prompts you to enter your Admin password. The default
value for both the Device and Admin password is apc (lowercase). To enter your password, use the up or down
arrow key to scroll through the available character set. Press the ENTER key to select the current character and
move the cursor to the next character position. After selecting the last character of your password, press the
ENTER key once more to submit your password.
Once the password is entered, it remains in effect until the period of inactivity exceeds the Password Timeout
setting.
See “Timeout:” on page 34.
NOTE: Passwords are case-sensitive.
24
InRow RD 10 kW Air Cooled Operation and Maintenance
Start the cooling unit
Path: Main > Operation > On/Standby
1. To start the cooling unit, press the ENTER key until the cursor is on the Operation > On/Standby menu
item.
2. Press the ENTER key again to show the toggle state arrow to the right of Operation.
3. Use the up and down arrow keys to change from Standby to On.
See “Path: Main > Operation > Limit Access” below if you are prompted to enter a password
before changing the On/Standby setting.
4. Press the ENTER key again to set the On position.
a. The fans will start.
b. The cooling unit will run according to the configured settings.
NOTE: On/Standby only affects the local cooling unit. You must set the On/Standby option for
each cooling unit in the cooling group.
Path: Main > Operation > Limit Access
The default setting for the Limit Access password protection option is No. If the Limit Access option has been
set to Yes, you will be prompted to enter the Device password before a change can be made to the On/
Standby setting.
Stop the cooling unit
Path: Main > Operation > On/Standby
1. To stop the cooling unit, press the ENTER key until the cursor is on the Operation > On/Standby menu
item.
2. Press the ENTER key again to show the toggle state arrow to the right of Operation.
3. Use the up and down arrow keys to change from On to Standby.
See “Path: Main > Operation > Limit Access” above if you are prompted to enter a
password before changing the On/Standby setting.
4. Press the ENTER key again to change the setting to Standby. The cooling unit will enter the standby
mode.
WARNING
ELECTRICAL HAZARD
The Standby option does not remove power from the cooling unit. You must disconnect
power at the mains to remove power from the cooling unit.
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
InRow RD 10 kW Air Cooled Operation and Maintenance
25
General Configuration
The cooling group configuration options are set during the commissioning of the cooling units in the
cooling group.
NOTE: All changes to settings must be performed by qualified personnel.
Cooling unit configuration
Path: Main > Configure Unit > General
Use the General menu to set the start-up delay, idle on leak, and refrigerant fill settings.
Start-up Dly (Start-up Delay): The delay begins when the cooling unit is started and initialized. The cooling
unit cannot begin operation until this delay expires. Use the start-up delay to restart equipment sequentially
after a scheduled downtime or a power outage.
Idle on Fail: When set to Yes, the cooling unit will enter idle mode if the cooling unit is unable to supply
conditioned air. Set to No to disable the cooling unit from entering idle mode if a Cooling Failure is detected.
Idle On Leak: When set to Yes, the cooling unit will enter idle mode if a Water Detection Fault activates. Set to
No to disable the cooling unit from entering idle mode if a leak is detected.
NOTE: The leak sensor (Schneider Electric part number AP9325) is optional.
NOTE: There are three alarms that will cause the cooling unit to enter idle mode when Idle On Fail and Idle on
Leak are set to Yes:
• Water Detection Fault
• Condensate Pump Fault
• Cooling Failure
See “Alarm messages and suggested actions” on page 38 for more information on alarms.
Refrig Fill: Set to Start to add refrigerant to the system. This setting turns on the compressor and sets the fans
to maximum speed until the compressor suction pressure drops below 50 psi for two minutes, twenty minutes
elapse, or the property setting is changed to Abort.
NOTE: The Refrig Fill setting is intended only for charging the unit with refrigerant.
Role Override: Set to ON, forces the cooling unit to be the Primary cooling unit in the group. Set to Auto,
allows the system to choose the role of the cooling unit. Select ON if you have Runtime Balancing enabled
and you DO NOT want a particular unit in the group to become a backup unit. See page 29 for more
information.
26
InRow RD 10 kW Air Cooled Operation and Maintenance
Contacts
View the state of input and output contacts
Path: Main > Configure Unit > Discrete I/O
Each cooling unit supports a user-defined input contact and a user-defined output contact. Each contact
monitors a sensor and responds to changes in the state of the sensor (open or closed).
Input State: Indicates the actual state of the input contact (Open or Closed). A cooling unit is On when the
state is normal and in Standby when the state is not normal.
Output State: Indicates the actual state of the output contact (Open or Closed). An alarm will cause the output
contact to change from the normal state.
OHE Input State: Indicates the actual state of the input contact (Open or Closed) for the Outdoor Heat
Exchanger.
Edit the normal state of input and output contacts
Path: Main > Configure Unit > Discrete I/O > Normal State
Configure the input contacts to cause alarm conditions based on the user-defined normal state. Output
contacts can map internal alarms and events to outside devices.
Input Norm: Set the normal state of the contact (Open or Closed). The cooling unit changes its operating
mode to Closed when the actual state differs from the normal state.
Output Norm: Set the normal state of the contact (Open or Closed). If the state of an alarm or event mapped
to this contact changes from the normal state, the contact also changes state.
Outpt Src: Define the type of output source (alarm), either Any Alrm or Critical, that causes the output to
change from its normal state.
OHE In Norm: Set the normal state of the contact (Open or Closed) for the Outdoor Heat Exchanger.
InRow RD 10 kW Air Cooled Operation and Maintenance
27
Cooling Group Configuration
Use the cooling group configuration settings to add cooling units to the group and to define group operation.
The system automatically assigns the state of Backup to units in the group. A unit whose Role Override
setting is set to ON will automatically be set as a Primary cooling unit. A unit in the Standby or Failed state is
not considered a potential backup unit. The system periodically reviews the state of the units to maintain the
proper number of ON and Backup units. If no units are available to assign to the Backup role, then the No
Backup Units Available alarm is initiated.
NOTE: This procedure is to be performed by qualified personnel only. The settings in the Configure Group
menu are defined by Schneider Electric authorized personnel when the cooling group is commissioned.
Configure the cooling group
Path: Main > Configure Group
The Configure Group menu contains settings that identify the number of cooling units installed in this cooling
group and the physical arrangement of those cooling units.
Num Units: Enter the number of cooling units in this cooling group. Up to 12 cooling units can be joined
together to work as a single cooling group.
Type: Set the rack deployment strategy for the cooling units of this cooling group:
• Spot: The cooling unit is used as a stand-alone unit.
• In-Row: Air flow is not ducted. Hot-aisle air is cooled and the cooled-air supply is shared by all loads in
the row.
• RACS (Rack Air Containment System): Air flow in the enclosure is controlled by a ducting system
fitted to the enclosure.
• HACS (Hot Aisle Containment System): Air flow in the room is controlled by enclosing the hot air aisle.
The loads share an enclosed common hot aisle.
Capacity Ctrl: Set the capacity control of the cooling unit:
• Disc (Discrete): The cooling unit operates as a room air conditioner. The evaporator fan speed will
remain constant at the user setting and the compressor will cycle on and off to maintain the cool
setpoint.
NOTE: The Disc mode is only available in a Spot cooling configuration.
• Prop (Proportional): The cooling unit matches the cooling output to the load demand. This is
accomplished using hot gas adjustment and fan speed control. Load demand is determined by the cool
setpoint and the temperature sensor at the rear of the cooling unit (in Spot configurations) or the
temperature sensor at the front of the load rack (in In-Row and RACS configurations).
Fan Cntrl: This selection allows air flow to be controlled automatically by the cooling unit or manually by userselected fan speed preference. This property only applies to Spot (Proportional), InRow, RACS and HACS
deployments.
• Auto: Air flow is automatically controlled by the unit.
• Manual: The air flow is fixed to the value of the Fan Speed Preference property.
Availability: Redundancy, Runtime Balancing, and Assist modes are only supported in Spot, HACS and RACS
configurations.
• Backup Units: The cooling unit is not running but is ready to run if a unit fails, is unable to cool or needs
cooling assistance.
• Load Asst (Load Assist): The unit was previously in the Backup mode but is now running due to a
request for cooling assistance. When the assistance is no longer needed, the unit will return to the
28
InRow RD 10 kW Air Cooled Operation and Maintenance
Backup state. If a failure occurs on a cooling unit while the backup unit is assisting, the backup unit will
take over for the failed cooling unit.
• Runtm Bal (Runtime Balancing): The system will maintain similar runtimes between units in the group.
When the difference between the runtime hours of the cooling units in the system exceeds 72 hours, the
system will automatically exchange modes between the longest running Primary cooling unit and the
Backup with the least Runtime hours.
NOTE: The Runtime Balancing cap is not adjustable.
Runtime hours are hours that the cooling unit is actually operating and NOT 72 consecutive hours (three
days) of time.
Identify the cooling unit
Path: Main > Set Identification
The Set Identification menu contains settings that identify the name and location of the cooling unit.
Name: Assign a Name of up to 40 alpha-numeric characters to this cooling unit.
Location: Enter the Location, up to 40 alpha-numeric characters, of the cooling unit.
NOTE: Only the first 19 characters (of the 40 that are possible to enter) will display on the display interface. You
must use Telnet, the Control console or the Web to access all 40 characters. See page 45 for more information.
Configure Modbus
Path: Main > Configure Modbus
Use the Configure Modbus menu to set up communication between the cooling unit and the building
management system.
Modbus: Enable or Disable the Modbus communication protocol.
Target Id: Each Modbus device must have a unique target identification number. Enter a unique number, from
1 to 247, for this cooling unit.
Baud Rate: Select either 9600 bps or 19200 bps.
Fixed settings: 8 data bits, no parity, 1 stop bit. These settings cannot be modified.
InRow RD 10 kW Air Cooled Operation and Maintenance
29
Control the Environment
The primary function of the cooling unit is to cool air from the hot aisle and deliver it to the cold aisle at the
temperature setpoint. The control strategies employed by the cooling unit depend upon the deployment
strategy of the cooling group.
In an InRow environment, the cooling unit supplies constant-temperature supply air to the common cold aisle.
The fan speed is modulated to ensure that the desired volume of air reaches the IT equipment. The fan speed
is determined by the difference between the cooling setpoint and the maximum rack air inlet temperature.
In a HACS or RACS environment, the cooling unit neutralizes the heat accumulated in the common hot aisle
and expels it back into the surrounding environmental space while maintaining the desired temperature in the
cold aisle.
In a CACS environment, the cooling unit supplies constant temperature supply air to the enclosed cold aisle.
The fan speed is modulated to ensure that the required volume of air reaches the IT equipment.
How the Cool mode works
Cool: The cooling unit uses a direct expansion coil, a variable speed compressor to modulate refrigerant flow
through the coil, and a set of fans to control airflow through the coil. The cooling output is determined by the
difference between the supply setpoint and the supply air temperature of the cooling unit.
The airflow control is varied based on configuration.
• InRow: The fan speed is controlled by comparing the rack inlet temperature to the cooling set point. As
the rack temperature increases compared to the cooling set point the fans increase output to maintain
the set point. As rack inlet temperature decreases compared to the cooling set point the fans decrease
output to maintain the set point.
• RACS/HACS: When Active Flow Controller (AFC) devices are present, the controller utilizes differential
pressure data supplied by the AFC(s) to supply the correct amount of airflow to the IT load. When AFC
devices are not present the fan speed is controlled by the fan speed preference setting. The fan speed
can be selected based on the temperature differential across the cooling unit. As return temperatures
deviate from the fan speed preference setting, the fan speed increases to bring the temperature
difference back down to the setpoint or decreases fan output to increase the unit temperature
differential. By maintaining the desired temperature differential, the system matches the airflow
requirements of the load.
• CACS: When AFC devices are present, the controller utilizes differential pressure data supplied by the
AFC(s) to supply the correct amount of airflow to the IT load. When AFC devices are not present the
evaporator fan speed is controlled by comparing the rack inlet temperature to the cooling setpoint. As
the rack temperature increases compared to the cooling setpoint the fans increase output to maintain the
setpoint. As rack temperature decreases compared to the cooling set point the fans decrease output to
maintain the setpoint.
The cooling unit is equipped with compressor cycling control that tries to minimize the number of times the
compressor cycles on and off. The compressor will cycle off when the supply air temperature drops below 15°C
(59° F) whether or not the minimum compressor on time of 3 minutes has elapsed. Once off, the compressor
will not normally cycle on until the supply temperature reaches its setpoint and the minimum off time of 2
minutes has elapsed. However, if the rack inlet temperature reaches 25°C (78°F), the compressor will cycle on
regardless of whether the minimum off time has elapsed (InRow and CACS only).
Compressor cycles are monitored over a 7-day period. If the number of cycles average more than 12 per hour
over that period, the Excessive Compressor Cycling alarm is set.
See Supply Air and Return Air on page 33 for more information.
30
InRow RD 10 kW Air Cooled Operation and Maintenance
Setpoints
Path: Main > Set Group Setpoint
A setpoint is the target value that a cooling group will maintain. The default setpoints are appropriate for most
cooling applications. The setpoints for each mode must be within the following ranges:
• Cool: 18.0 – 32.2 °C (64.4 – 90°F)
• Deadband: 0 – 10.1°F
• Supply Air: 13.8 – 21.0 °C (57 – 69.8°F) Spot (Proportional) only
15 – 21.0 °C (59 – 69.8°F) HACS, RACS or InRow
NOTE: The Supply Air setting is defined by Schneider Electric authorized personnel only when the
cooling group is commissioned.
NOTE: The Supply Air setpoint must never be set higher than the Cool setpoint.
• Fan Speed: When the unit is programmed for HACS or RACS mode, this property specifies the
necessary temperature difference (DT) across the IT equipment. When the cooling unit is programmed
for Spot (Proportional), InRow, HACS or RACS with the Fan Control property set to Manual, this
property defines the fan speed. When the cooling unit is programmed for Spot (Discrete), the fan speeds
are also selected from the following table but the Fan Control property is irrelevant.
– Low: 16.7°C (30°F) DT (60% of maximum fan speed)
– Med-Low: 13.9°C (25°F) DT (70% of maximum fan speed)
– Med: 11.1°C (20°F) DT (80% of maximum fan speed)
– Med-High: 6.3°C (15°F) DT (90% of maximum fan speed)
– High: 5.6°C (10°F) DT (100% of maximum fan speed)
• Active Flow Control Bias: This setting is used to change the bias of the controller by adjusting the
contained aisle pressure threshold. Zero is the default setting. Only qualified service personnel can
make changes to these settings.
– Hot Aisle Containment (HACS)
• If the cooling units seem to be under-cooling, select Negative or Slightly Negative to adjust the
aisle pressure for additional cooling.
• If the cooling units seem to be over-cooling, select Positive or Slightly Positive to adjust the
aisle pressure for less cooling.
– Cold Aisle Containment (CACS)
• If the cooling units seem to be under-cooling, select Positive or Slightly Positive to adjust the
aisle pressure for additional cooling.
• If the cooling units seem to be over-cooling, select Negative or Slightly Negative to adjust the
aisle pressure for less cooling.
Setting
Blue LED – HACS
Red LED – CACS
Setpoint
Green LED
Red LED – HACS
Blue LED – CACS
Positive
< –0.008 in. ±3%
0.004 ±0.0004 in.
> 0.016 in. ±3%
Slightly Positive
< –0.010 in. ±3%
0.002 ±0.0004 in.
> 0.014 in. ±3%
Zero
< –0.012 in. ±3%
0.000 ±0.0004 in.
> 0.012 in. ±3%
Slightly Negative
< –0.014 in. ±3%
–0.002 ±0.0004 in.
> 0.010 in. ±3%
Negative
< –0.016 in. ±3%
–0.004 ±0.0004 in.
> 0.008 in. ±3%
• Active Flow Control Status: The status of the Active Flow Control indicates whether the correct
amount of airflow is being provided to the load. This status is not configurable.
NOTE: AFC compatibility may require upgrading the cooling unit controller.
InRow RD 10 kW Air Cooled Operation and Maintenance
31
PID settings
Path: Main > Set Group PID
The Proportional plus Integral plus Derivative (PID) loop controls the output of the fans.
NOTE: This procedure is to be performed by Schneider Electric authorized personnel only. Improperly set PID
controls could result in equipment damage.
There are two sets of PID coefficients stored in the unit. One set is used when the unit is programmed for Spot
(Proportional) mode and the other set is used when the cooling unit is programmed for InRow mode. Only one
set can be active at a time. The active PID set is determined by the value of the Type and Capacity Ctrl
properties (Path: Main > Configure Group). The active set can be read, written or set to default.
Gain (P): The proportional multiplier (gain) for this mode or actuator. The proportional multiplier adjusts for the
difference (error) between the measured value and the setpoint.
Rate (I): The integral multiplier (reset rate) for this mode or actuator. The integral multiplier adjusts for error
measurement and the amount of time that the error has existed. The integral multiplier adds to or subtracts
from the output in small increments to correct for the offset error caused by the proportional contribution.
Deriv (D): The derivative multiplier (derivative) for this mode or actuator. The derivative multiplier adjusts the
output for rapid changes in the error, correcting for the rate of change of the error over time.
Reset to Deflts (InRow or Spot (Proportional) only): The Gain, Rate and Derivative coefficients return to
their default values.
Tune the PID loop
Tune the PID loop to optimize the performance of the cooling group.
NOTE: This procedure is to be performed by Schneider Electric authorized personnel only. The PID loop must
be tuned after the equipment in the room is installed and running. The loop should be tuned periodically to
account for changes in the room load.
1. Adjust the integral and derivative constants to zero and the proportional constant to 1.0.
2. Set the temperature setpoint value and start the cooling group.
3. When the temperature reaches a stable value, increase the proportional constant by 0.5. If the
temperature does not respond to this change, adjust the setpoint.
4. Repeat step 3 until the temperature value starts to oscillate and the peak amplitude of the oscillations is
constant.
5. Note the time, in minutes, between the peaks of the oscillations. This is the Ultimate Period, PU.
6. Note the value of the proportional constant. This is the Ultimate Gain, GU.
7. Compute the PID constants using the table below. Use the equations for that control method in the row
to compute the values for each constant.
Control Method
P
P+I
P+I+D
Proportional
0.5 * GU
0.45 * GU
0.6 * GU
Integral
Derivative
–
0.54 * GU / PU
1.2*GU/PU
–
–
0.075 * GU * PU
8. Set each constant according to these calculations.
You may need to further tune the PID loop in the following ways to account for changes in the room
load:
Loop Behavior
PID Tuning Correction
Slow response to temperature changes
Increase the proportional multiplier or increase the derivative
multiplier.
32
InRow RD 10 kW Air Cooled Operation and Maintenance
Loop Behavior
PID Tuning Correction
Overcooling/undercooling after changes in the room Increase the derivative or the proportional multiplier.
load or changes in setpoint
Environmental temperature never reaches the
Increase the integral multiplier.
setpoint
Overcooling/undercooling on constant room load
Decrease the integral multiplier.
Run hours
The cooling unit records the number of hours each of its components has operated. When a component is
replaced, use the Reset Run Hours option to reset the run hours for the displayed component to zero.
Path: Main > View Run Hours
• Air Filter
– Reset Run Hours
NOTE: Replace air filters with Schneider Electric part number 875-2013 only.
• Fans
– Fan Number
• Reset Run Hours
• Compressor
– Reset Run Hours
• Condensate Pump
– Reset Run Hours
• Fan Power Supplies
– Reset Run Hours
Thresholds
Set alarms to alert you to threshold violations.
Path: Main > Set Unit Thresholds
When the monitored input exceeds the unit threshold, an alarm occurs. Set high temperature thresholds for the
following sensors:
• Rack Inlet: The temperature of the air entering the rack at the rack inlet sensors
• Supply Air: The average temperature of the air output from the cooling unit as measured between the
upper and lower supply air temperature sensors.
• Return Air: The temperature of the air entering the cooling unit at the temperature sensor
Service intervals
Path: Main > Service Intervals
The air filters should be serviced regularly. The service interval depends on environmental cleanliness.
• Air Filter Interval: Set the number of weeks before service is required for the Air Filter Interval. The
default is 18 weeks.
• Alarm: The interval setting has an alarm (Enable or Disable). If enabled, an audible alarm activates
when the interval has elapsed. The alarm is cleared by selecting Clear Alarms in the main menu.
NOTE: The Air Filter interval alarm is enabled by default.
InRow RD 10 kW Air Cooled Operation and Maintenance
33
Display Settings
Set display interface settings including the time and date, units of measure, passwords, and time-out settings.
You can also adjust the contrast, key click, beeper volume, and beep-on-alarm settings.
Password and time-out
Path: Main > Set Password
NOTE: The default user password is apc (lowercase). See “Password entry” on page 24 for information on
passwords.
Change passwords: Set the Admin and Device passwords.
1. Move the selector arrow next to the Change Passwords option and press the ENTER key.
2. Select the password to change (either Admin or Device).
3. Enter a new password (up to 8 characters).
4. Press the ENTER key to confirm.
Timeout: Set the length of time which can elapse when no keys are pressed before the display interface
returns to the scrolling screen status. The password must then be entered to regain access.
Invalidate Now: Override the password timeout and require password entry immediately.
Date and time
Path: Main > Set Date & Time
Set the time: Enter the correct time, and press the ENTER key. The Time setting is displayed on some status
screens and is also used in the alarm/event log to time-stamp events.
Set the date: Enter the day, month, and year, and press the ENTER key. The Date setting is displayed on some
status screens and is also used in the alarm/event log to date-stamp events.
Set the format: Use the up or down arrow key to select the date Format setting.
• mm/dd/yyyy (11/16/2007) (Default)
• yyyy-mm-dd (2007-11-16)
• dd-mmm-yy (16-Nov-07)
• mmm-dd-yy (Nov-16-07)
• dd.mm.yyyy (16.11.2007)
34
InRow RD 10 kW Air Cooled Operation and Maintenance
Adjust display settings
Path: Main > Configure Display
Contrast: Adjust the visibility of the screen text. Lower numbered settings provide darker text; higher numbers
provide lighter text. Settings range from 0 – 7.
Key Click: Set to ON or OFF will enable or disable an audible tone that sounds every time a key is pressed on
the display interface.
Beeper Volume: Set the volume (Low, Medium, High or OFF) of the audible tone that sounds every time a
key is pressed on the display interface.
Beep on Alarm: Set to ON or OFF. When set to ON, the cooling unit will sound an audible tone every 30
seconds when a new alarm occurs. Silence the audible tone by pressing any key on the display interface.
When the alarm clears itself, the tone will stop on its own.
Display units
Path: Main > Set Display Units
Set the units of measure for the cooling unit to either US or Metric.
Network Configuration
The cooling unit is shipped with a Network Management Card that enables the cooling unit to be managed over
a network. Configure the network settings for the Network Management Card for this cooling unit from the
display interface. The management card allows remote control and configuration of the equipment.
Configure network
Path: Main > ConfigureNetwork
MAC Address: Displays the unique network identifier which was assigned to the Network Management Card
of this cooling unit at the factory.
Boot Mode: Set the method by which the Network Management Card of the cooling unit acquires network
settings.
• Manual: Enter the IP address, subnet mask, and default gateway using the IP Address menu.
• BOOTP: Set the Network Management Card of the cooling unit to obtain its network settings from a
BOOTP server.
• DHCP: Set the Network Management Card of the cooling unit to obtain its network settings from a DHCP
server.
By default, DHCP requires a cookie before it will accept an IP address. See “BOOTP & DHCP
configuration” on page 42 for more information.
• BOOTPDHCP: Set the Network Management Card of the cooling unit to search for its network settings
from either a BOOTP or a DHCP server.
IP Address: You will be prompted to enter an Admin password. Enter the password and press ENTER to return
to the IP screen. Press ENTER again to change the network settings for Manual boot mode only.
• IP: Enter the IP address assigned to the Network Management Card of this cooling unit.
• SM: Enter the subnet mask for the Network Management Card of this cooling unit.
• GW: Enter the default gateway for the Network Management Card of this cooling unit.
InRow RD 10 kW Air Cooled Operation and Maintenance
35
View Status Readings
The display interface has several options for viewing the status of the cooling unit, the cooling group to which
the cooling unit belongs, and the environment being controlled. The status readings for the cooling unit are
available under the View Unit Status option in the main menu, and status readings for the cooling group are
available under the View Group Status option on the main menu or on the scrolling status screens.
Scrolling status screens
When the display interface is idle, it scrolls through screens of status information. Press the up or down arrow
key to interrupt the automatic scrolling and view a specific status screen.
Cooling unit status
Path: Main > View Unit Status
The cooling unit status screens contain information specific to this cooling unit.
Op Mode: The cooling unit is in one of the following modes:
• On: The cooling unit is cooling.
• Standby: The cooling unit is receiving power but not enabled for cooling.
• Idle: The cooling unit is not operating in normal mode due to active critical alarms.
For more information, see “Idle on Fail:” on page 26.
Cool Outpt: The actual cooling output of the cooling unit.
Cool Demnd: The amount of cooling that the rack currently requires.
Rack Inlet: The temperature of the air entering the rack.
Supply Air: The temperature of the air leaving the cooling unit.
Return Air: The temperature of the air entering the cooling unit.
Fan Speed: The speed of the fans that regulate the air flow through the cooling unit.
Suction Temp: The temperature of the refrigerant in the suction line of the compressor.
Air Flow: The rate of air moved by the cooling unit.
Filter DP: The air filter differential pressure.
Input State: The state of the input contact.
Output State: The state of the output contact.
OHE Input St: The state of the input contact that controls the outdoor heat exchanger.
OHE Outpt St: The state of the output contact that controls the outdoor heat exchanger.
Suction: The suction pressure of the compressor.
Discharge: The discharge pressure of the compressor.
Superheat: The superheat temperature of the compressor.
Compressor: The state of the compressor (On/Off).
36
InRow RD 10 kW Air Cooled Operation and Maintenance
Cooling group status
Path: Main > View Group Status
View information about the cooling group.
Cool Output: The combined output of the cooling group.
Cool Demand: The cooling output required to meet the current heat load of the conditioned space.
Cool Setpt: The temperature you set to maintain the room environment.
Air Flow: The combined airflow output of the cooling units in the cooling group.
Max Rack: The highest rack temperature reported by any cooling unit in the cooling group.
Min Rack: The lowest rack temperature reported by any cooling unit in the cooling group.
Max Return: The highest return temperature reported by any cooling unit in the cooling group.
Min Return: The lowest return temperature reported by any cooling unit in the cooling group.
About the cooling unit
Path: Main > About InRow RD
View identifying information that is helpful when obtaining service:
• Model: Model number
• S/N: Serial number
• F/W: Firmware revision
• H/W: Hardware revision
• Made: Date of manufacture
• APP Ver: Application version
• AOS Ver: Operating System version
Event Log
The event log saves status information and a message each time a change in the cooling group is detected.
Alarms and events are recorded in the log and displayed on the active alarms screen. Status information and
system configuration changes are displayed in the event log only.
View the event log
Path: Main > View Event Log
The event log keeps a record of all alarms and events. The screen displays the following information:
• The name of the event
• The time and date the event occurred
Use the arrow keys to scroll through the list of events and display the date and time for each event.
Clear the event log
Path: Main > Clear Event Log
A confirmation screen displays when this option is selected. Enter the Admin password to erase the log. Select
YES to erase all of the events in the log. Select NO to return to the main screen.
InRow RD 10 kW Air Cooled Operation and Maintenance
37
Respond to Alarms
When an alarm is triggered, the cooling unit alerts you through the display interface by the following methods:
• Active alarm screen entry on scrolling status screens
• LEDs on the front panel display
• An optional audible alarm, if enabled, every 30 seconds
View active alarms
Path: Main > View Alarms
The View Alarms screen provides the number of alarms, the severity level of each active alarm, and a brief
description of each alarm. Press the arrow keys to view the rest of the list.
Clear active alarms
Path: Main > Clear Alarms
A confirmation screen displays when this option is selected. Enter the Admin password to clear the alarm list.
Select YES to clear all of the alarms in the list. Select NO to return to the main screen. If the conditions that
caused the alarm still exist, those conditions will cause the alarm to be regenerated.
Alarm messages and suggested actions
Alarm Message
Severity
Action Required
Cool Fail
Critical
• A hardware failure exists. For assistance, contact Schneider
Electric technical support.
High Rack Temp
(Rack Temperature High
Violation)
Critical
• Make sure the temperature sensors are located properly.
• If the problem persists, replace the sensor or contact Schneider
Electric technical support.
Air Fltr Clogged
(Air Filter Clogged)
Warning
• Clean or replace the air filter.
• If the problem persists, contact Schneider Electric technical
support.
Rtn Air Snsr Fault
Critical
• Make sure the temperature sensor is connected properly.
• If the problem persists, contact Schneider Electric technical
support.
Sply Air Snsr Fault
(Supply Air Sensor # Fault)
Critical
• Make sure the temperature sensor is connected properly.
• If the problem persists, contact Schneider Electric technical
support.
Rack Temp Snsr Fault
(Rack Temperature Sensor
Fault)
Critical
• Make sure the temperature sensor is connected properly.
• If the problem persists, contact Schneider Electric technical
support.
High Dischrg Pres
(High Discharge Pressure)
Critical
• Check the condenser for obstructions.
• If the problem persists, contact Schneider Electric technical
support.
Low Suction Pres
(Low Suction Pressure)
Warning
• Check the air filter and fans for obstructions.
• For assistance, contact Schneider Electric technical support.
High Suction Pres
(High Suction Pressure)
Warning
• If the problem persists, contact Schneider Electric technical
support.
(Return Air Sensor # Fault)
38
InRow RD 10 kW Air Cooled Operation and Maintenance
Alarm Message
Severity
Action Required
Fan Num Fault
(Fan # Fault)
Warning
• A hardware failure exists. For assistance, contact Schneider
Electric technical support.
Water Detected
Warning
• Identify the source of the leak. Water could be from the
condensate pump, condensate carryover from the evaporator, or
condensation.
• For assistance, contact Schneider Electric technical support.
Conds Pump Fault
(Condensate Pump Fault)
Warning
• A hardware failure exists. For assistance, contact Schneider
Electric technical support.
Pan Full
(Condensate Pan Full Fault)
Critical
• Empty the pan and make sure the drain line is not clogged.
• If the problem persists, contact Schneider Electric technical
support.
Fan PwrSp Fault
(Upper Fan Power Supply
Fault)
Warning
• Make sure the power supplies are seated properly and the Input
and Output Healthy LEDs are lit.
• If the problem persists, contact Schneider Electric technical
support.
Fan PwrSp Fault
(Lower Fan Power Supply
Fault)
Warning
• Make sure the power supplies are seated properly and the Input
and Output Healthy LEDs are lit.
• If the problem persists, contact Schneider Electric technical
support.
Air Fltr RnHr Violation
(Air Filter Run Hours Violation)
Warning
• Reset the Air Filter Run Hours after the air filter is cleaned or
replaced.
Grp Comm Fault
(Group Communication Fault)
Warning
• Make sure the number of cooling units in the group is configured
properly and the A-Link connections between cooling units are
correct.
• Make sure the system is receiving power and is connected
properly.
• A hardware failure exists. For assistance, contact Schneider
Electric technical support.
Sply Air High Temp
(Supply Air High Temperature
Violation)
Warning
• Make sure the Supply Air threshold is set correctly in the Set
Unit Threshlds screen.
• If the problem persists, contact Schneider Electric technical
support.
Rtn Air High Temp
(Return Air High Temperature
Violation)
Warning
• Make sure the Return Air threshold is set correctly in the Set
Unit Threshlds screen.
• If the problem persists, contact Schneider Electric technical
support.
Filter DP Sensor Failure
Warning
• Make sure the sensor is connected properly.
• If the problem persists, replace the sensor or contact Schneider
Electric technical support.
Suction Temperature Sensor
Failure
Warning
• Make sure the sensor is connected properly.
• If the problem persists, replace the sensor or contact Schneider
Electric technical support.
Suction Pressure Sensor
Failure
Warning
• Make sure the sensor is connected properly.
• If the problem persists, replace the sensor or contact Schneider
Electric technical support.
InRow RD 10 kW Air Cooled Operation and Maintenance
39
Alarm Message
Severity
Action Required
Dischrg Pressure Sensor
Failure
Warning
• Make sure the sensor is connected properly.
• If the problem persists, contact Schneider Electric technical
support.
Input Contact Fault
Warning
• Make sure the Input Normal state is defined correctly in the
Configure Unit> Discrete I/O screen. See page 27 for more
information.
• Clear the problem that caused the input contact switch to change
from the normal state.
• If the problem persists, contact Schneider Electric technical
support.
Persistent High Discharge
Pressure Fault
Critical
• Indicates there were three High Discharge Pressure shutdowns
in 30 minutes. Alarms must be cleared manually.
• If the problem persists, contact Schneider Electric technical
support.
Persistent Low Suction
Pressure Fault
Critical
• Indicates there were 3 Low Suction Pressure shutdowns in 30
minutes. Alarms must be cleared manually.
• If the problem persists, contact Schneider Electric technical
support.
Rack Inlet
(Rack Inlet Temperature High
Threshold)
Critical
• Make sure the Rack Inlet setting is correct in the Set Unit
Threshlds screen.
• If the problem persists, contact Schneider Electric technical
support.
Supply Air
(Supply Air Temperature High
Threshold)
Critical
• Make sure the Supply Air setting is correct in the Set Unit
Threshlds screen.
• If the problem persists, contact Schneider Electric technical
support.
Return Air
(Return Air Temperature High
Threshold)
Critical
• Make sure the Return Air setting is correct in the Set Unit
Threshlds screen.
• If the problem persists, contact Schneider Electric technical
support.
No Backup Units Available
Warning
• Check to make sure cooling units in the group are set to
Configure Unit > General > Role Override > Auto and that
cooling units are available (not in a failed state).
• For assistance, contact Schneider Electric technical support.
40
InRow RD 10 kW Air Cooled Operation and Maintenance
Network Management Card
Quick Configuration
The cooling unit is shipped with a Network Management Card that enables the cooling unit to be managed over
a network. Configure the Network Management Card to control this cooling unit through a network.
Overview
You must configure the following TCP/IP settings before the Network Management Card can operate on a
network:
• IP address of the Network Management Card
• Subnet mask
• Default gateway
IMPORTANT: Never use the loopback address (127.0.0.1) as the default gateway address for the
Network Management Card. Doing so will disable the card and will require you to reset TCP/IP settings
to their defaults using a local serial login.
NOTE: If a default gateway is unavailable, use the IP address of a computer that is located on the same
subnet as the Network Management Card and that is usually running. The Network Management Card
uses the default gateway to test the network when traffic is very light.
See “Watchdog Features” in the “Introduction” of the User Guide for more information about
the watchdog role of the default gateway.
TCP/IP configuration methods
Use one of the following methods to define the basic TCP/IP settings needed by the Network Management
Card:
• Device IP Configuration Wizard (See “Device IP Configuration Wizard” on page 42.)
• BOOTP or DHCP server (See “BOOTP & DHCP configuration” on page 42.)
• Networked computer (See “Remote access to the control console” on page 44.)
InRow RD 10 kW Air Cooled Operation and Maintenance
41
Device IP Configuration Wizard
You can use the Device IP Configuration Wizard at a computer running Microsoft® Windows® 2000, Windows®
Server 2003, or Windows® XP to configure a Network Management Card.
NOTE: Most software firewalls must be temporarily disabled for the Wizard to discover unconfigured Network
Management Cards.
To configure one or more Network Management Cards from a user configuration file, see the User’s
Guide on the Utility CD.
1. Insert the Utility CD into a computer on your network.
2. If autorun is enabled, the user interface of the CD starts when you insert the CD. If autorun is not
enabled, open the file contents.htm on the CD.
3. When the Wizard discovers the unconfigured Network Management Card, follow the on-screen
instructions.
NOTE: If you leave the Start a Web browser when finished option enabled, you can use apc for both
the user name and password to access the Network Management Card through your browser.
.ini file utility
You can use the .ini file export utility to export .ini file settings from configured Network Management Cards to
one or more unconfigured Network Management Cards. The utility and documentation are included on the
Utility CD.
BOOTP & DHCP configuration
The default TCP/IP configuration setting, BOOTP & DHCP, assumes that a properly configured BOOTP or
DHCP server is available to provide TCP/IP settings to Network Management Cards. The Network
Management Card first attempts to discover a properly configured BOOTP server, and then a DHCP server. It
repeats this pattern until it discovers a BOOTP or DHCP server.
If neither of these servers is available, see “Local access to the control console” on page 43 or
“Remote access to the control console” on page 44 to configure the needed TCP/IP settings.
A user configuration (.ini) file can function as a BOOTP or DHCP boot file. For more information, see
the TCP/IP configuration section of the User’s Guide, available from the Utility CD or the Schneider
Electric Web site, www.schneider-electric.com.
BOOTP: For the Network Management Card to use a BOOTP server to configure its TCP/IP settings, it must
find a properly configured RFC951-compliant BOOTP server.
1. In the BOOTPTAB file of the BOOTP server, enter the MAC address of the Network Management Card,
the IP address, the subnet mask, default gateway, and an optional boot-up file name. Look for the MAC
address on the display interface (Path: Main > Configure Network) or on the label on the back of the
Network Management Card.
2. When the Network Management Card reboots, the BOOTP server provides it with the TCP/IP settings.
– If you specified a boot-up file name, the Network Management Card attempts to transfer that file from
the BOOTP server using TFTP or FTP. The Network Management Card assumes all settings
specified in the boot-up file.
– If you did not specify a boot-up file name, you can configure the other settings of the Network
Management Card remotely through its Web interface or control console; user name and password
are both apc, by default.
See your BOOTP server documentation to create a boot-up file.
42
InRow RD 10 kW Air Cooled Operation and Maintenance
DHCP: You can use a RFC2131/RFC2132-compliant DHCP server to configure the TCP/IP settings for the
Network Management Card.
This section summarizes communication between the Network Management Card and a DHCP
server. For more detail about how a DHCP server can configure the network settings for a Network
Management Card, see “DHCP Configuration” in the User Guide.
1. A Network Management Card sends out a DHCP request that uses the following to identify itself:
– A Vendor Class Identifier (APC by default)
– A Client Identifier (by default, the MAC address value of the Network Management Card)
– A User Class Identifier (by default, the identification of the application firmware of the Network
Management Card)
2. A properly configured DHCP server responds with a DHCP offer that includes all of the settings that the
Network Management Card needs for network communication. The DHCP offer also includes the
Vendor Specific Information option (DHCP option 43). By default, the Network Management Card will
ignore DHCP offers that do not encapsulate the cookie in the Vendor Specific Information option using
the following hexadecimal format:
Option 43 = 01 04 31 41 50 43
where
– the first byte (01) is the code
– the second byte (04) is the length
– the remaining bytes (31 41 50 43) are the cookie
See your DHCP server documentation to add code to the Vendor Specific Information
option.
To disable the requirement that a DHCP offer include the cookie, use the DHCP Cookie Is
setting in the control console:
Network>TCP/IP>Boot Mode>DHCP only>Advanced>DHCP Cookie Is.
Local access to the control console
You can use a computer connected to the serial port on the main board holding the Network Management Card
to access the control console.
1. Select a serial port at the local computer, and disable any service that uses that port.
2. Use the provided configuration cable to connect the selected port to the serial port on the main board
holding the Network Management Card.
3. Run a terminal program (such as HyperTerminal) and configure the selected port for 9600 or 19200
bps, 8 data bits, no parity, 1 stop bit, and no flow control. Save the changes.
4. Press ENTER to display the User Name prompt.
5. Use apc for the user name and password.
See “Control console” on page 44 to finish the configuration.
InRow RD 10 kW Air Cooled Operation and Maintenance
43
Remote access to the control console
From any computer on the same subnet as the Network Management Card, you can use ARP and Ping to
assign an IP address to a Network Management Card, and then use Telnet to access the control console of
that Network Management Card and configure the needed TCP/IP settings.
NOTE: After the IP address of the Network Management Card is configured, you can use Telnet without first
using ARP and Ping to access that Network Management Card.
1. Use the MAC address for the Network Management Card in the ARP command to define the IP
address. For example, to define an IP address of 156.205.14.141 for a Network Management Card that
has a MAC address of 00 c0 b7 63 9f 67, use one of the following commands:
– Windows command format:
arp -s 156.205.14.141 00-c0-b7-63-9f-67
– LINUX command format:
arp -s 156.205.14.141 00:c0:b7:63:9f:67
NOTE: The MAC address is available on the display interface at:
Path: Main > Configure Network or look at the label on the back of the Network Management Card for the
MAC address.
1. Use Ping with a size of 113 bytes to assign the IP address defined by the ARP command. For the IP
address defined in step 1, use one of the following Ping commands:
– Windows command format:
ping 156.205.14.141 -l 113
– LINUX command format:
ping 156.205.14.141 -s 113
2. Use Telnet to access the Network Management Card at its newly assigned IP address. For example:
telnet 156.205.14.141
3. Use apc for both user name and password.
See “Control console” on page 44 to finish the configuration.
Control console
After you log on at the control console, as described in “Local access to the control console” on page 43 or
“Remote access to the control console” on page 44:
1. Choose Network from the Control Console menu.
2. Choose TCP/IP from the Network menu.
3. If you are not using a BOOTP or DHCP server to configure the TCP/IP settings, select the Boot Mode
menu and then select Manual boot mode.
4. Set the System IP, Subnet Mask, and Default Gateway address values. (Changes will take effect
when you log out.)
5. Press ENTER to return to the TCP/IP menu.
6. Press CTRL+C to exit to the Control Console menu.
7. Log out (option 4 in the Control Console menu).
NOTE: If you disconnected a cable from the local computer during the procedure described in “Local
access to the control console” on page 43, reconnect that cable and restart the associated service.
44
InRow RD 10 kW Air Cooled Operation and Maintenance
Access a Configured Network Management Card
Overview
After the Network Management Card is running on your network, you can access the configured Network
Management Card through the following interfaces:
• Web interface (HTTP or HTTPS protocol)
• Telnet or Secure SHell (SSH)
• SNMP
• FTP or Secure CoPy (SCP) to upgrade firmware
• Modbus
For more information on the interfaces, see the User Guide.
Web interface
Use Microsoft Internet Explorer® (IE) 5.5 and higher (on Windows operating systems only), Mozilla-based
browsers that support Firefox® 1.x (on all operating systems), or Netscape® 7.x and higher (on all operating
systems) to access the Web interface of the cooling unit. Other commonly available browsers also may work
but have not been fully tested by Schneider Electric.
You can use either of the following protocols when you use the Web interface:
• The HTTP protocol (enabled by default), which provides authentication by user name and password but
no encryption.
• The HTTPS protocol, which provides extra security through Secure Sockets Layer (SSL); encrypts user
names, passwords, and data being transmitted; and authenticates the Network Management Card by
means of digital certificates.
To access the Web interface and configure the security of your device on the network:
1. Address the Network Management Card by its IP address or DNS name (if configured).
2. Enter the user name and password (by default, apc and apc for an Administrator).
3. To enable or disable the HTTP or HTTPS protocols, use the Network menu on the Administration tab.
Select the access option under the Web heading on the navigation menu.
For more information on selecting and configuring network security, see the Security
Handbook, available from the Schneider Electric Web site, www.schneider-electric.com.
4.
Telnet and SSH
You can access the control console through Telnet or Secure SHell (SSH), depending on which is enabled.
Select the Administration tab, the Network option on the top menu bar, and then the access option under
Console on the left navigation menu. By default, Telnet is enabled. Enabling SSH automatically disables
Telnet.
Telnet for basic access: Telnet provides the basic security of authentication by user name and password, but
not the high-security benefits of encryption. To use Telnet to access the control console of the Network
Management Card:
1. At a command prompt, use the following command line, and press ENTER:
telnet address
As address, use the IP address of the Network Management Card (or DNS name if configured).
InRow RD 10 kW Air Cooled Operation and Maintenance
45
2. Enter the user name and password (by default, apc and apc for an Administrator, or device and apc for
a Device User).
SSH for high-security access: If you use the high security of SSL for the Web interface, use Secure SHell
(SSH) for access to the control console. SSH encrypts user names, passwords, and transmitted data.
The interface, user accounts, and user access rights are the same whether you access the control console
through SSH or Telnet, but to use SSH, you must first configure SSH and have an SSH client program installed
on your computer.
See the User Guide for more information on configuring and using SSH.
Simple Network Management Protocol (SNMP)
SNMPv1 only: After you add the PowerNet® MIB to a standard SNMP MIB browser, you can use that browser
to access the Network Management Card. All user names, passwords, and community names for SNMP are
transferred over the network as plain text. The default read community name is public; the default read/write
community name is private.
SNMPv3 only: For SNMP GETs, SETs, and trap receivers, SNMPv3 uses a system of user profiles to identify
users. An SNMPv3 user must have a user profile assigned in the MIB software program to perform GETs and
SETs, browse the MIB, and receive traps. The default settings are no authentication and no privacy.
NOTE: To use SNMPv3, you must have a MIB program that supports SNMPv3.
NOTE: The Network Management Card supports only MD5 authentication and DES encryption.
SNMPv1 and SNMPv3: To use StruXureWare Data Center Expert to manage the Network Management Card,
you must have SNMPv1 enabled in the interface of the cooling unit. Read access allows InfraStruXure devices
to receive traps from the cooling unit. Write access is required while you set the InfraStruXure device as a trap
receiver.
To enable or disable SNMP access, you must be an Administrator. Select the Administration tab, select the
Network menu on the top menu bar, and use the access option under SNMPv1 or SNMPv3 on the left
navigation menu.
FTP/SCP
You can use FTP (enabled by default) or Secure CoPy (SCP) to transfer downloaded firmware to the Network
Management Card, or to access a copy of the event or data logs of the cooling unit. SCP provides the higher
security of encrypted data transmission and is enabled automatically when you enable SSH.
To use StruXureWare Data Center Expert to manage the Network Management Card, you must have FTP
Server enabled in the Network Management Card. To enable or disable FTP Server access, you must be an
Administrator. On the Administration tab, select the Network menu on the top menu bar, and use the FTP
server option on the left navigation menu.
In the User Guide, see the following sections:
• To transfer firmware, see “File Transfers.”
• To retrieve a copy of the event or data log, see “Use FTP or SCP to retrieve log files.”
46
InRow RD 10 kW Air Cooled Operation and Maintenance
Modbus
Use Modbus to view the Network Management Card through the interface of your building management
system. It is read-only.
The Modbus interface supports 2-wire RS-485, plus ground.
NOTE: Modbus can be configured to run at either 9600 or 19200 bps.
To access the Modbus register map, go to the Schneider Electric Web site,
www.schneider-electric.com.
Recover From a Lost Password
You can use a local computer (a computer that connects to the Network Management Card through the serial
port) to access the control console.
1. Select a serial port at the local computer, and disable any service that uses that port.
2. Connect the provided RS-232 configuration cable to the selected port on the computer and to the RS232 console port at the Network Management Card.
3. Run a terminal program (such as HyperTerminal) on your computer and configure the selected port for
9600 or 19200 bps, 8 data bits, no parity, 1 stop bit, and no flow control.
4. Press ENTER, repeatedly if necessary, to display the User Name prompt. If you are unable to display
the User Name prompt, verify the following:
– The serial port is not in use by another application.
– The terminal settings are correct as specified in step 3.
– The correct cable is being used as specified in step 2.
5. Press the Reset switch. The Status LED will flash alternately orange and green. Press the Reset button
a second time immediately while the LED is flashing to reset the user name and password to their
defaults temporarily.
6. Press ENTER as many times as necessary to redisplay the User Name prompt, then use the default,
apc, for the user name and password. (If you take longer than 30 seconds to log on after the User
Name prompt is redisplayed, you must repeat step 5 and log on again.)
7. From the Control Console menu, select System, then User Manager.
8. Select Administrator, and change the User Name and Password settings, both of which are now
defined as apc.
9. Press CTRL+C, log off, reconnect any serial cable you disconnected, and restart any service you
disabled.
InRow RD 10 kW Air Cooled Operation and Maintenance
47
Maintenance
Monthly Preventive Maintenance
Photocopy the following pages and use them during the maintenance procedures. After they have been
completed, save them for future reference.
Prepared By: ________________________________
Model Number: ______________________________
Serial Number: _______________________________
Date: ______________________________________
Environment

In what type of room is the cooling unit located?
__________________________________________________

Is the cooling unit maintaining the temperature setpoint?
___________________________________________________
Temperature setpoint _________________________________

Is there visible damage to the cooling unit (dents, scratches)?
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________

Check for environmental damage (dirt, dust, debris, liquid stains) around the cooling unit installation area.
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________

Record the room temperature near the air return of the cooling unit.
Temperature ________________

Record the alarm history for the last month.
___________________________________________________________________________________
___________________________________________________________________________________
Cleanliness
48

Check the condition of the air filters. Clean or change if necessary.

Check for accumulation of debris in the drain pan. Clean as required.
InRow RD 10 kW Air Cooled Operation and Maintenance
Mechanical
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work
practices. See NFPA 70E or CSA Z462.
• This equipment must be installed and serviced by qualified personnel only.
• Turn off all power supplying this equipment before working on or inside the equipment.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace all devices, doors, and covers before turning on power to this equipment.
Failure to follow these instructions will result in death or serious injury.

Check the fans. All components should be moving freely with no signs of binding or damages.

Verify that the condensate line is flowing freely.
Electrical
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work
practices. See NFPA 70E or CSA Z462.
• This equipment must be installed and serviced by qualified personnel only.
• Turn off all power supplying this equipment before working on or inside the equipment.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace all devices, doors, and covers before turning on power to this equipment.
Failure to follow these instructions will result in death or serious injury.

Inspect the electrical panel for tight connections and for overheated connections from loose contact
terminals.

Confirm that the incoming main power matches the rating listed on the nameplate of the cooling unit. The
measurement should be within 10% of the nameplate listing.
InRow RD 10 kW Air Cooled Operation and Maintenance
49
Quarterly Preventive Maintenance
Perform all the Monthly Preventive Maintenance items and the items below.
Prepared By: _________________________________
Model Number: _______________________________
Serial Number: _______________________________
Date: ______________________________________
Mechanical
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work
practices. See NFPA 70E or CSA Z462.
• This equipment must be installed and serviced by qualified personnel only.
• Turn off all power supplying this equipment before working on or inside the equipment.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace all devices, doors, and covers before turning on power to this equipment.
Failure to follow these instructions will result in death or serious injury.

Verify that the fan hardware is tight.

Clean or replace the air filters.

Clean the condensate drain line.

Clean the dust from door perforations.

Clean the dust from fan bezels.
Functional tests

50
Verify the cooling operation mode is functioning properly.
InRow RD 10 kW Air Cooled Operation and Maintenance
Semi-Annual Preventive Maintenance
Perform all the Monthly/Quarterly Preventive Maintenance items and the items below.
Prepared By: _________________________________
Model Number: _______________________________
Serial Number: _______________________________
Date: ______________________________________
Cleanliness

Check the cleanliness of the evaporator coil. Clean if required.
InRow RD 10 kW Air Cooled Operation and Maintenance
51
Troubleshooting
Problem
Possible Cause
Corrective Action
Controls erratic or
inoperative
• Inlet temperature to cooling
unit is higher than rated
maximum temperature
• Power supplies are not
operating properly
• Reduce the load or add additional cooling equipment.
Fans fail to start
Cooling unit cannot
obtain setpoint
Water carryover
Temperature control
not tight enough
Water on outside of
cooling unit
• Failed power supply
• Cooling unit shutdown due to
an external command
• Single fan fails to start
• Improper placement of remote
temperature sensor
• Dirty filter
• Dirty coil
• Application error
• Heat load is too far away
• Improper fan speed selected
• Improper placement of remote
temperature sensor
• Condensate drain hose is not
connected or not properly
routed outside the cooling unit
• Leak in piping system
• Cooling unit not leveled
properly
• Damaged piping insulation
Display interface not • Display interface not
operational but
connected properly
cooling unit operates
Incorrect air pressure • False filter clogs
Alarms do not show • External monitoring
up on monitoring
equipment is not receiving
equipment (Customer power or is not functioning
Output Contact)
properly
52
• Confirm that the power supplies are seated properly and
fully engaged. This is indicated by a green LED.
• Confirm that the cooling unit is plugged in and is receiving
power.
• Replace the power supply if the LED is red.
• Temporarily remove the user contact cable, if it is
connected.
• Replace the fan.
• Verify that the remote temperature sensor is properly
located in the cold aisle.
• Clean the filter.
• Clean the coil.
• For assistance, contact Schneider Electric technical
support.
• Place the cooling unit closer to the heat load.
• RACS and HACS modes only. Select the next highest fan
speed setting. For example, change the fan speed setting
from Low to Med/Low.
• Verify that the remote temperature sensor is properly
located in the cold aisle.
• Verify that the condensate drain hose is properly connected
to the pump and properly routed outside of the cooling unit.
• Verify that the condensate drain line does not exceed 4.9
meters (16 feet) lift and 15.4 meters (50.0 feet) horizontal
run.
• Locate and repair the leak.
• Adjust the leveling feet of the cooling unit.
• Identify damaged area and repair the insulation.
• Verify that the display interface cable is connected properly.
• Verify that the ends of the clear plastic air tubes are not
obstructed.
• Verify that the clear plastic air tubes are connected to the
controller.
• Verify that the clear plastic air tubes are not pinched.
• Confirm that power, if required, is being supplied to the
external equipment.
• If the cooling unit (+12 V or +24 V) is providing power to the
external equipment, verify that the external equipment is
<50 mA.
• Test the external equipment by bypassing the output
contact.
• Verify Customer Output Contact settings. See “Contacts”
on page 27.
InRow RD 10 kW Air Cooled Operation and Maintenance
Problem
Possible Cause
Cooling unit does not • Drive voltage
shut down on
command
No communication
• Improper connection
with building
management system
(BMS) port
Cooling units are not • A-Link failure
communicating with
each other
Output air is 17°C
• Upper or lower supply air
sensor fault
(62°F) and fans are
running at a very high
rate of speed.
InRow RD 10 kW Air Cooled Operation and Maintenance
Corrective Action
• Verify that there is a drive voltage entering the input of the
cooling unit. You may use the available +12 V or +24 V.
You must then also use the ground.
• Verify Customer Input Contact settings. See “Contacts” on
page 27.
• Confirm that the cooling unit is connected to the BMS port
and not to the Control port.
• Make sure that the wire polarity is correct.
Using a DC voltmeter, test the signal with no transmissions
in progress. Pin 2 should be greater than Pin 1 by at least
200 mV. Measure the cooling unit with the cable
disconnected, and then measure it again with the cable
connected. If the signal is less than 200 mV, the cooling unit
may be reverse-wired.
• Make sure that every cooling unit has either two sets of
wires in its connector or one set of wires and a 100-ohm
resistor (a terminating resistor of 100 to 120 ohms).
• Verify the actual number of cooling units in the group
matches the group number setting.
• Verify that the A-Link ports of every cooling unit have either
two cables or one cable and a terminator.
• Confirm that the A-Link cables are connected to the A-Link
ports and that a network cable is connected to the network
port.
• Either the upper or lower supply air temperature sensor has
a fault. Verify that both supply air temperature sensors are
installed and working properly.
53
