FOREWORD
The Santa Margarita Region Hydrology Model (SMRHM) is a tool for analyzing the
hydromodification effects of land development projects and sizing solutions to mitigate the
increased stormwater runoff from these projects.
This section of the guidance
documentation provides background information on the definition and effects of
hydromodification and relevant findings from technical analyses conducted in response to
regulatory requirements. It also summarizes the current Hydromodification Management
Standard and general design approach for hydromodification control BMPs, which led to
the development of the SMRHM.
Regulatory Context
The California Regional Water Quality Control Board (Regional Board) requires
stormwater programs to address the increases in stormwater runoff rate and volume from
New Development and Redevelopment projects where those increases could cause
increased erosion of receiving channels. Phase 1 municipal separate stormwater system
(MS4) permits in Riverside County contain requirements to develop and implement
hydromodification management plans (HMPs) and to implement associated management
measures.
